Important facts to know:
1. Containment Doors are available in several heights, order depending on
the height and size of the cabinets being used.
2. Aisle widths encountered can also affect the door widths needed. Dual
Sliding Doors can accommodate 48” to 72” wide aisles. A single 36” wide
door may be best for smaller aisle widths of 36” or less.
3. Dual Containment Doors come in 5 standard nominal heights, each of
which increase in 3.5” increments.
4. Containment doors can be used for all makes of cabinets as long as there
are mounting points available on top of the cabinet and the cabinet is deep
enough to hold the side panels without protruding out the rear. They are
designed best to work with Legrand cabinets.
5. Door opening width for dual doors is approximately 48” wide.
6. Clear door insert panels come in either .125” thick polycarbonate or 8mm
thick double wall “Polygal”, UL rated plastics. Cleaning of plastic surfaces
is done by using a soft cotton cloth with a mild soapy dish water solution.
Prevent scratching of plastic surfaces and do not use reactive chemicals.
7. There are five basic types of containment doors available.
a.Dual Sliding doors with double 24”W doors for cabinet to cabinet layouts.
b.Single left or right 36”W Sliding Doors for cabinet to cabinet layouts.
c.Single left or right 36”W Sliding Doors for cabinet to wall layouts.
