EN
Operating Instructions
LCD
SI E40 BA0 UK
5
4a
3
2
6
1
14
7
13
8
9
12
10
11
SI DC30 BA0 UK
4b
4c
5
3
2
1
6
7
13
12
8
9
10
11
A
LCD
B1
B2
LCD
COT TON
C1
C2
LCD
D1
D2
LCD
E1
LCD
E2
G
F
LCD
LCD
H1
H2
LCD
I
J
LCD
LCD
K1
LCD
L I NE N
K2
en
GENERAL SAFETY RULES
• Do not operate the iron in case of damaged plug,
power cord or appliance, or in the presence of visible
damage or water leaks from the appliance. In such a
case the appliance must be inspected by the Hotpoint
authorized technical staff in order to avoid dangerous
situations.
• If the appliance was dropped, do not operate it.
• The appliance is not intended to be used by individuals
(children included up to 8 years of age) with impaired
physical, sensory or mental capabilities, inexpert
individuals or individuals who are not familiar with
the product, unless they are supervised by a person
responsible for their safety, or by individuals who have
not received preliminary instructions on the use of the
appliance.
• Supervise children to prevent them from playing with
the appliance.
• Never leave the appliance unattended when the plug
is connected into the electrical socket.
• After each use of the appliance, when filling and
emptying the water reservoir, as well as when
cleaning the appliance, set the steam regulator to Off.
Then place the appliance in a stable position, using
the stand, and disconnect the plug from the electrical
socket.
• The appliance must be used and placed on a stable,
flat horizontal surface. The use on an ironing board is
5
en
•
•
•
•
•
•
6
recommended.
For your safety, all repairs or maintenance operations
must be carried out exclusively the the Hotpoint
authorised technical staff.
Keep the iron and its cord out of reach of children less
than 8 years of age when it is energized or cooling
down.
Cleaning and user maintenance shall not be made by
children without supervision.
When placing the iron on its stand, ensure that the
surface on which the stand is placed is stable.
The plug must be removed from the socket-outlet
before the water reservoir is filled with water.
This steam iron is equipped with the safety device
Power off system. When the plug has been connected,
move the iron to switch it on.
en
DESCRIPTION
OF YOUR IRON
•
1. Shot of steam button
2. Spray button
3. Steam regulator
4a. Temperature buttons +/4b. Temperature control
4c. Temperature indicator light
5. Power cable holder
6. Cable winder
7.Stand
8. Auto-Clean button
9. Water reservoir
10. Maximum water level
11.Soleplate
12. Spray nozzle
13. Filler hole Lid
14.LCD
•
Not shown: water measurer
INTRODUCTION
Thank you for purchasing our Quick Perfection steam iron. In doing so, you have opted
for an effective high-performance appliance.
We advise you to register this product online
at www.hotpoint.co.uk to make sure you are
entitled to all benefits made available by Hotpoint’s Customer Service.
This appliance has been exclusively designed for domestic use and is not intended for industrial use.
Before using the appliance, carefully read
the instructions and keep them with care for
future use.
GENERAL SAFETY RULES
The safety of your steam iron complies with the technical specifications and standards in force.
The voltage of your electrical mains must
correspond to the voltage of the steam iron
(220-240 V). Improper connection may result in
irreversible damage for the appliance, voiding its
warranty.
•
•
Use the appliance only for its intended use as
described in this manual.
This product is intended only for ironing of
clothing and household laundry.
•
•
•
•
•
This appliance must be exclusively connected
to a grounded socket. When using an extension
cord, make sure that a grounded socket is
available.
Inspect the conditions of the power cord on a
regular basis.
Do not fill the water reservoir by holding the
appliance directly under the tap. Always use the
water measurer supplied with the appliance.
Make sure you have disconnected the plug from
the electrical socket before filling and emptying
the water reservoir and in any case after each
use.
Disconnect the plug from the socket by holding
the plug, and not by pulling the cable.
Avoid contact between the power cord and the
iron plate when hot.
Do not wind the power cord around the plate
when hot. Use the cord, instead.
skin.
The iron, water and steam coming out of the
plate are extremely hot and can burn the
•
Before storing the appliance, wait until it has
cooled down completely (a steam iron takes
about one hour to cool down). Use the handle to
store the appliance after use.
•
Do not direct the steam towards people or
animals and do not iron garments while worn.
•
After use, store the appliance in a stable position,
using the stand on the back of the iron.
•
Never add any perfume, vinegar, starch,
scale-removing agents, ironing products
or other chemicals in the water reservoir unless recommended by Hotpoint. Never use
contaminated water.
•
Never immerse the appliance in water or in any
other liquid.
•
The appliance must not be left outdoor and
exposed to weather agents.
•
Never leave or use the appliance in the proximity
of flames, ovens, flammable materials or other
heat sources.
•
Never use the appliance for any purposes other
than the ones for which it has been designed.
•
In case of suspected damage, immediately
disconnect the plug from the electrical socket.
•
The manufacturer assumes no responsibility in
case of damage resulting from the improper use
of the appliance.
This appliance must be earthed. The following operations should be carried out by a
qualified electrician.
7
en
Replacing the fuse
When replacing a faulty fuse, a 13 amp ASTA approved fuse to BS 1362 should always be used, and the
fuse cover re-fitted. If the fuse cover is lost, the plug
must not be used until a replacement is obtained.
If a 13 amp plug (BS 1363) is used it must be fitted
with a 13 amp fuse, either in the plug or adaptor or at
the distribution board.
If you are in any doubt regarding the electrical supply
to your machine, consult a qualified electrician before
use.
Replacement fuse covers
How to connect an alternative plug
If a replacement fuse cover is fitted, it must be of the
correct colour as indicated by the coloured marking or
the colour that is embossed in words on the base of
the plug. Replacements can be obtained directly from
your nearest Service Depot.
Removing the plug
The wires in this mains lead are coloured in accordance with the following code:
BLUE
BROWN GREEN & YELLOW NEUTRAL (N)
LIVE (L)
EARTH (E)
If your appliance has a non-rewireable moulded plug
and you should wish to re-route the mains cable through partitions, units etc., please ensure that either:
•
the plug is replaced by a fused 13 ampere rewireable plug bearing the BSI mark of approval.
or:
•
the mains cable is wired directly into a 13 amp
cable outlet, controlled by a switch, (in compliance with BS 5733) which is accessible without
moving the appliance.
Disposing of the plug
Ensure that before disposing of the plug itself, you
make the pins unusable so that it cannot be accidentally inserted into a socket.
The power supply cable must never be bent
or dangerously compressed.
Instructions for connecting cable to an
alternative plug
The power supply cable must only be replaced by an authorised serviceman.
The wires in the mains lead are coloured in
accordance with the following code:
GREEN & YELLOW
BLUE BROWN EARTH
NEUTRAL
LIVE
As the colours of the wires in the lead may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
•
•
•
8
Connect Green & Yellow wire to terminal marked
E or
or coloured Green or Green & Yellow.
Connect Brown wire to terminal marked L or coloured Red.
Connect Blue wire to terminal marked N or coloured Black.
BEFORE USE
Before using the appliance for the first time, remove
all stickers, protective plastic or cardboard case from
the soleplate of the iron.
Make sure that all adhesive parts have been
removed from the soleplate with a dampened soft
cloth and eliminate any residues or particles from
the manufacturing process, by repeatedly filling and
emptying the water reservoir.
When switching on the iron for the first
time, you may notice an unpleasant odour, a
little smoke and some impurities that will
disappear in a few minutes. When using the steam
function for the first time, do not direct the steam
jet on the garments because of the possible
presence of manufacturing residues in the steam
dispenser.
en
Filling the water reservoir (A)
damaging the fabric. In case of very delicate
fabrics, such as silk, wool, and synthetic
materials, iron the garment inside out to prevent
shiny marks. Start ironing the garments that
require a lower temperature, such as synthetic
fabrics.
Fabrics with this symbol on the label must
not be ironed.
We recommend using demineralised water.
Before filling the iron with water, make sure that
the iron is switched-off and disconnected from the
electrical socket.
1.
2.
3.
4.
Set the steam regulator (3) to Off.
Tilt the iron in such a position to make water
entrance easier.
Open the lid of the filler hole (13) and fill the water
reservoir using the water measurer supplied with
the iron. Never fill the water reservoir above the
maximum water level (10).
Close the lid of the filling hole.
GARMENT
LABEL
T E M P E R AT U R E
INDICATION
silk
mixed cotton
wool
mixed wool
cotton
linen
jeans
6.
In order to make reading this instructions manual
easier and identify the model of your Quick Perfect
iron, refer to the graphics on page II.
Select the steam level with the steam regulator
(3) or move it to Off to iron without steam. When
steam ironing, make sure that the water level in
the reservoir is at least ¼.
Your iron is supplied with Power Off System
safety device which automatically switches
the iron off when it is left unattended or tips over
and ensures maximum safety.
Selecting the temperature
and adjusting the steam (B2)
Selecting the temperature
and adjusting the steam (B1)
2.
1.
2.
3.
4.
5.
LCD
Connect the plug of the appliance into a
grounded socket (220/240V).
The LCD (14) lights up in red and starts flashing
to indicate that the iron is reaching the set
temperature.
Use the temperature buttons +/- (4a) to select
the desired temperature. Every time you press
one of the two buttons, the display lights up and
starts flashing to indicate that the steam iron is
reaching the selected temperature.
When the iron reaches the set temperature, the
LCD lights up in green and the set temperature
is shown in fixed mode to indicate that the iron
is ready for use.
Make sure to check the garment label in order
to identify the fabric type. In case of doubts, it
is recommended not to the use spray function
and iron a hidden corner in order to determine
the most appropriate temperature and avoid
STEAM
INDICATION
synthetic
Never add any perfume, vinegar, starch,
scale-removing agents, ironing products or
other chemicals in the water reservoir - unless
recommended
by
Hotpoint.
Never
use
contaminated water.
USING THE IRON
FABRIC TYPE
1.
3.
4.
Connect the plug of the appliance into a
grounded socket (220/240V).
Use the temperature control (4b) to select the
desired temperature. If you go from a lower
temperature to a higher temperature, the
temperature indicator light (4c) light up until the
selected temperature is reached.
When the iron reaches the set temperature, an
acoustic signal is emitted and the temperature
indicator light goes off.
We recommend to check the garment label
in order to identify the fabric type. In case of
doubts, it is recommended not to use the spray
function and iron a hidden corner in order to
determine the most appropriate temperature
and avoid damaging the fabric. In case of very
delicate fabrics, such as silk, wool, and synthetic
materials, iron the garment inside out to prevent
shiny marks. Start ironing the garments that
require a lower temperature, such as synthetic
fabrics.
9
en
Fabrics with this symbol on the label must
not be ironed.
GARMENT
LABEL
FABRIC TYPE
TEMPERATURE
INDICATION
synthetic
MIN
STEAM
INDICATION
no-steam and steam ironing mode.
1.
2.
3.
silk
mixed cotton
wool
mixed wool
cotton
linen
jeans
5.
If the water in the reservoir is finished, it
may be necessary to press the shot of
steam button several times to (re)activate the
pump, after filling the water reservoir again.
LINEN
Select the steam level with the steam regulator
(3) or move it to Off to iron without steam. When
steam ironing, make sure that the water level in
the reservoir is at least ¼.
USE
LCD
When switching on the iron for the first
time, you may notice an unpleasant odour, a
little smoke and some impurities from the
manufacturing process that will disappear in a
few minutes.
USE
When switching on the iron for the first
time, you may notice an unpleasant odour, a
little smoke and some impurities from the
manufacturing process that will disappear in a
few minutes.
Ironing without steam (C2)
1.
2.
Ironing without steam (C1)
1.
2.
Set the steam regulator (3) to Off (=no steam).
Select the recommended ironing temperature
with the temperature buttons +/- (4a) (see step B1
and chapter “Using the iron”, section “Selecting
the temperature and adjusting the steam”).
2.
Check that the water level in the reservoir is
higher than ¼.
Select the appropriate steam with the steam
regulator (3) and the recommended ironing
temperature with the temperature buttons +/(4a) (see step B1 and chapter “Using the iron”,
section “Selecting the temperature and adjusting
the steam”).
The iron starts producing steam as soon as
it reaches the set temperature.
1.
2.
Check that the water level in the reservoir is
higher than ¼.
Select the appropriate steam with the steam
regulator (3) and the recommended ironing
temperature with the temperature selector
(4b) (see step B2 and chapter “Using the iron”,
section “Selecting the temperature and adjusting
the steam”).
The iron starts producing steam as soon as
it reaches the set temperature.
Ironing with shot of steam (E2)
The shot of steam function allows you to eliminate
persistent wrinkles. You can use this function both in
no-steam and steam ironing mode.
Ironing with shot of steam (E1)
1.
The shot of steam function allows you to eliminate
persistent wrinkles. You can use this function both in
2.
10
Set the steam regulator (3) to Off (=no steam).
Select the recommended ironing temperature
with the temperature control (4b) (see step B2
and chapter “Using the iron”, section “Selecting
the temperature and adjusting the steam”).
Steam ironing (D2)
Steam ironing (D1)
1.
Check that the water level in the reservoir is
higher than ¼.
Select the recommended ironing temperature
with the temperature buttons +/- (4a) (see step B1
and chapter “Using the iron”, section “Selecting
the temperature and adjusting the steam”).
Press the shot of steam button (1) to obtain
an extra steam flow when ironing. If the shot
of steam function has not been used for some
time, it may be necessary to press the button
repeatedly to activate the pump.
Check that the water level in the reservoir is
higher than ¼.
Select the recommended ironing temperature
with the temperature control (4b) (see step B2
en
3.
and chapter “Using the iron”, section “Selecting
the temperature and adjusting the steam”).
Press the shot of steam button (1) to obtain
an extra steam flow when ironing. If the shot
of steam function has not been used for some
time, it may be necessary to press the button
repeatedly to activate the pump.
If the water in the reservoir is finished, it
may be necessary to press the shot of
steam button several times to (re)activate the
pump, after filling the water reservoir again.
FEATURES
Spray function (F)
The spray function is used to dampen the garment in
order to remove persistent wrinkles easily. You can
use the spray function both in no-steam and steam
ironing mode at any temperature.
1.
2.
Check that the water level in the reservoir is
higher than ¼.
With the iron in horizontal position, press the
spray button (2) to dampen the garment.
Vertical steam function (G)
The vertical steam function is useful to eliminate
wrinkles from hanging garments, curtains, etc. You
can use this function by simply placing the iron in
vertical position. All functions of the appliance will
remain unchanged also in this position (refer to
chapter “Use” according to the model).
worn.
Do not direct steam towards people or
animals and do not iron garments while
•
the iron switches off automatically after 30
seconds when left unattended in the ironing
position or sideways;
•
the iron switches off automatically after 10
minutes when left unattended in the rest position
(vertical).
If you leave the iron unattended, the display flashes a
green light and an acoustic signal is emitted to inform
that the automatic stand-by function is active.
Simply move the iron or press the temperature buttons
+/- (4a) to switch it back on.
Wait until the display becomes green before
starting ironing again.
Automatic switch-off
function (H2)
The automatic switch-off function guarantees total
safety.
This function automatically switches off the iron when
it is not used for a few minutes. In particular:
•
•
the iron switches off automatically after 30
seconds when left unattended in the ironing
position or sideways;
the iron switches off automatically after 10
minutes when left unattended in the rest position
(vertical).
If you leave the iron unattended an acoustic signal is
emitted to inform that the automatic switch-off function
is active.
Simply move the iron to switch it back on.
Wait until the temperature indicator light
turns off before starting ironing again.
Anti-drip function
The iron is provided with anti-drip function in order to
automatically interrupt the steam distribution when the
temperature is too low, thus preventing water dripping
out of the soleplate.
Do not use steam with low temperatures
(see chart in step B1 and B2, chapter “Using
the iron”, according to the type of iron you are
using).
Automatic Stand-By
function (H1)
This function automatically switches off the iron when
it is not used for a few minutes. In particular:
LCD
The automatic stand-by function guarantees total
safety.
CLEANING AND
MAINTENANCE
After use (I)
1.
2.
3.
Set the steam regulator (3) to Off, disconnect the
appliance plug from the electrical socket and let
the iron cool down.
Empty the water reservoir (9).
Wind the cord around the cable winder (6) and
store the iron in vertical position, in a dry safe
place.
Never store the iron in horizontal position.
Always use the stand at the back of the iron.
11
en
Cleaning (J)
Never use aggressive and/or abrasive
substances to clean the plastic parts and
the iron soleplate.
1.
2.
3.
4.
Set the steam regulator (3) to Off, disconnect the
appliance plug from the electrical socket and let
the iron cool down.
Use a dry or slightly dampened soft cloth to
clean the upper part of the iron.
For the ordinary cleaning and/or removal of
stains or other residues deposited on the plate,
clean with a dampened soft cloth and dry.
Use a dampened cotton tip to eliminate scale in
the steam holes that may impair the performance
of your iron.
In order to keep the soleplate perfectly
smooth and polished, avoid contacts with
metal objects, do not iron sharp objects, such as
buttons, studs and hinges in order to avoid
scratching the plate.
5.
Regularly rinse the reservoir with clean water.
After cleaning, always empty the water reservoir.
Auto-Clean Function (K1)
LCD
If you have been using water from the tap, we
recommend starting the Auto-Clean function after
ironing every time.
The use of the Auto-Clean function should
not be deemed the same as using demineralised water on a regular basis.
1.
2.
Check that the appliance is disconnected from
the electrical socket and the steam regulator is
(3) set to Off.
Fill the water reservoir (9) up to the maximum
water level (10).
Never add any perfume, vinegar, starch,
scale-removing agents, ironing products or
other chemicals in the water reservoir - unless
recommended
by
Hotpoint.
Never
use
contaminated water.
3.
4.
5.
6.
12
Connect the plug of the appliance into a
grounded socket (220/240V).
Set the temperature to the maximum value with
the temperature buttons +/- (4a).
Wait at least 2 or 3 minutes to warm the iron
completely.
Holding the iron above the sink or a container
made of resistant material, press the Auto-Clean
button (8) and shake gently.
Steam and boiling water will come out of the
soleplate with scale residues and other
impurities. Never use plastic containers for
collection.
7.
Switch off the iron and disconnect it from the
electrical socket.
8. Set the steam select to the maximum position.
9. Allow water to come out of the holes for at least
30 minutes.
10. Slide the iron gently on a cloth to eliminate any
stains from the soleplate.
11. Before using the iron again, press the shot of
steam button (1) repeatedly to eliminate any
scale residues.
When making this operation, keep the iron
away from the garments in order not to
stain them.
Auto-Clean Function (K2)
If you have been using water from the tap, we
recommend starting the Auto-Clean function after
ironing every time.
The use of the Auto-Clean function should
not be deemed the same as using demineralised water on a regular basis.
1.
2.
Check that the appliance is disconnected from
the electrical socket and the steam regulator is
(3) set to Off.
Fill the water reservoir (9) up to the maximum
water level (10).
Never add any perfume, vinegar, starch,
scale-removing agents, ironing products or
other chemicals in the water reservoir - unless
recommended
by
Hotpoint.
Never
use
contaminated water.
3.
4.
5.
6.
Connect the plug of the appliance into a
grounded socket (220/240V).
Set the temperature to the maximum value with
the temperature control (4b).
Wait at least 2 or 3 minutes to warm the iron
completely.
Holding the iron above the sink or a container
made of resistant material, press the Auto-Clean
button (8) and shake gently.
Steam and boiling water will come out of the
soleplate with scale residues and other
en
impurities. Never use plastic containers for
collection.
7.
Switch off the iron and disconnect it from the
electrical socket.
8. Set the steam select to the maximum position.
9. Allow water to come out of the holes for at least
30 minutes.
10. Slide the iron gently on a cloth to eliminate any
stains from the soleplate.
11. Before using the iron again, press the shot of
steam button (1) repeatedly to eliminate any
scale residues.
When making this operation, keep the iron
away from the garments in order not to
stain them.
This gives you the reassurance that if, within that time, your product
is proven to be defective because of either workmanship or materials,
we will, at our discretion, either repair or replace the product at no cost
to you.
This Guarantee is subject to the following conditions:
•
Documentary proof of original purchase date is provided.
•
Cosmetic damage must be reported within 14 days from the date
of purchase.
•
The product has been installed and operated correctly and in accordance with our operating and maintenance instructions.
•
The product is used only on the electricity supply printed on the
rating plate.
•
The product has been used for normal domestic purposes only.
•
The product has not been altered, serviced, maintained, dismantled, or otherwise interfered with by any person not authorised
by us.
•
Any repair work must be undertaken by us or our appointed
agent.
TIPS
•
•
•
The product is used in the United Kingdom or Republic of Ireland.
The Guarantee does not cover:
•
•
•
•
•
Any parts removed during repair work or any product that is replaced become our property.
Sort the garments out according to the fabric
type. This will reduce the need to adjust the
temperature according to the different fabrics.
Start with the garments that require a lower ironing
temperature and continue with the garments with
gradually higher ironing temperature.
If you are not sure about the composition of
the fabric, try ironing a hidden corner, such
as a seam, hem or internal section. Start with
a low temperature and gradually increase the
temperature in order to find the ideal ironing
setting.
When you reduce the ironing temperature to iron
delicate garments, wait approximately 2 minutes
to let the iron reach the new settings.
Pure wool (100% wool) garments can be ironed
as long as the temperature is set to wool. It is
recommended to use a cotton cloth to prevent
any shiny residues on the garment.
Never iron areas with evident perspiration
marks: the heat will fix the stains and make them
permanent.
GUARANTEE
12 months Parts and Labour Guarantee
This certificate of guarantee represents the guarantee (“Guarantee” hereinafter) offered by Indesit Company UK Limited with registered office
at Peterborough PE2 9JB in relation to products purchased in the United
Kingdom and Indesit Ireland Limited with registered office in Dublin 9,
Ireland for products purchased in the Republic of Ireland. This Guarantee does not affect your statutory rights.
Your product has the benefit of our manufacturer’s Guarantee, which
covers the product for twelve months from the date of purchase.
•
Damage resulting from transportation, improper use, neglect or
interference or as a result of improper installation.
•
Accidental damage, this includes but is not limited to, damage
which occurs as a result of an external action.
•
Replacement of any consumable item or accessory. These include but are not limited to:
•
plugs, cables, light bulbs, hoses, brushes, covers and filters.
•
Replacement of any removable parts made of glass or plastic.
After Sales Service
No one is better placed to care for your Hotpoint product during the
course of its working life than us – the manufacturer.
Essential Contact Information
Advice Line
We have a dedicated team who can provide free advice and assistance
with your product if you experience any technical difficulties. Simply call
our Hotpoint Service Hotline on 08448 240 055 (Republic of Ireland
0818 904 041) for telephone assistance.
Please note:
Our advisors will require the following information:
Model number:
Serial number:
Consumables and Accessories
We supply a full range of consumables and accessories to keep your
product functioning efficiently throughout its life.
UK: 08448 225 225
Republic of Ireland: 0818 313 413
www.hotpoint.co.uk
13
en
Recycling and Disposal Information
As part of Hotpoint’s continued commitment to helping the environment,
Hotpoint reserves the right to use quality, recycled components to keep
down customer costs and minimise material wastage.
Please dispose of packaging and old products carefully.
Register your new product and get a second year FREE!
DISPOSAL OF OLD ELECTRICAL
APPLIANCES
The European Directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE), requires that old hou-
We want to give you additional benefits of owner­ship of your product
sehold electrical appliances must not be disposed of in the
and offer you an additional free 2 year guarantee when you register your
normal unsorted municipal waste stream.
product with Hotpoint within 28 days of purchase. If you do not register
Old appliances must be collected separately in order to op-
your product with Hotpoint within 28 days, your product is guaranteed
timise the recovery and recycling of the materials they con-
for 1 year only.
tain and reduce the impact on human health and the envi-
To activate your 3 year guarantee register with us online at www.
ronment.
hotpoint.co.uk. Please note that the 3 year guarantee is only available in
The crossed out “wheeled bin” symbol on the product reminds you of
UK and Ireland and is subject to the same conditions as the 1 year Gua-
your obligation, that when you dispose of the appliance it must be sepa-
rantee. Please refer to the certifica­te of guarantee for more information.
rately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.
TROUBLESHOOTING
Problem
Possible cause / Solutions
The soleplate remains cold
and does not warm up.
•
The temperature indicator
light turns on and off.
•
The temperature indicator light turns on to indicate that the iron is
getting hot. The indicator light turns off when the set temperature is
reached.
Steam comes out in reduced
quantity or does not come
out.
•
•
•
The steam regulator is set to Off.
Not enough water in the water reservoir. Fill the water reservoir.
The iron is not sufficiently hot and/or the anti-drip function is active.
Replace the iron in vertical position, using the stand, and wait until
the temperature indicator light tuns off or the LCD becomes red
before starting to iron.
The plate temperature may be too low due to the excessively frequent
activation of the shot of steam button. Slightly increase the interval
between steam shots.
•
•
Impurities come out from
the soleplate and stain the
garments.
•
•
•
•
•
14
The plug may not be inserted into the electrical socket, or it may not
make contact.
Check that the temperature is not set to MIN.
There may be residues in the vaporisation chamber. Make the
cleaning operations (see chapter “Cleaning and maintenance”,
section “Auto-Clean Function” according to the model).
You are using perfume, vinegar, starch, vinegar, starch, scaleremoving agents, ironing products or other chemical substances.
Remember that these substances may damage the product. Rinse
the water reservoir.
.You are using starch. You can use starch directly on the inside out of
the fabrics and in any case never in the water reservoir.
The garment was not washed correctly or has some soap residues.
You are ironing a new garment that was not washed for the first time.
en
Water is dripping out of the
soleplate
•
•
•
•
•
•
The soleplate is dirty or dark
and may stain the fabrics.
The spray function does not
work.
•
The soleplate temperature may be too low due to the excessively
frequent activation of the shot of steam button. Slightly increase the
interval between steam shots.
The soleplate temperature is set to a too-low temperature.
You have replaced the iron horizontally without emptying it and/or
without setting the steam regulator to Off.
You did not close the lid of the filler hole correctly.
You have used the shot of steam function with a too-low temperature.
We recommend to use these functions with temperatures higher
than
.
You are using perfume, vinegar, starch, vinegar, starch, scaleremoving agents, ironing products or other chemical substances.
Remember that these substances may damage the product. Rinse
the water reservoir.
•
•
You are using a too-high temperature. Clean the soleplate (see
chapter “Cleaning and maintenance”, section “Cleaning”).
You are using starch. You can use starch directly on the inside out of
the fabrics and in any case never in the water reservoir.
The garment was not washed correctly or has some soap residues.
You are ironing a new garment that was not washed for the first time.
•
Not enough water in the water reservoir. Fill the water reservoir.
•
15
www.indesitcompany.com
Quick Perfection
09/2014 - ver.4.0
.
Indesit Company UK Ltd
Morley Way,
Peterborough PE2 9JB

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
