Ocularis-X

User Guide

© 2012 On-Net Surveillance Systems Inc.

On-Net Surveillance Systems, Inc.

One Blue Hill Plaza, 7 th

Floor, PO Box 1555

Pearl River, NY 10965

Phone: (845) 732-7900 | Fax: (845) 732-7999

Web: www.onssi.com

Ocularis-X 1.0

000091912-1220-OCX1.0(1.0.0.27)

Legal Notice

This product manual is intended for general information purposes only, and due care has been taken in its preparation.

Any risk arising from the use of this information rests with the recipient, and nothing herein should be construed as constituting any kind of warranty.

© 2002-2012 On-Net Surveillance Systems, Inc. All rights reserved. OnSSI and the ‘Eye’ logo are registered trademarks of On-Net

Surveillance Systems, Inc. Ocularis, Ocularis Client, Ocularis Client Lite, Ocularis Video Synopsis, Ocularis-X, NetEVS, NetDVMS,

NetDVR, ProSight, NetGuard, NetGuard-EVS, NetSwitcher, NetMatrix, NetCentral, NetTransact, NetPDA and NetCell are trademarks of On-Net Surveillance Systems, Inc. All other trademarks are property of their respective owners.

On-Net Surveillance Systems, Inc. reserves the right to change product specifications without prior notice.

Patents Applied For in the U.S. and Abroad

Ocularis-X User Guide

Contents

Table of Contents

INTRODUCTION............................................................................................................................................................2

O

CULARIS

-X C

OMPONENTS

............................................................................................................................................2

S

PECIFICATIONS

............................................................................................................................................................2

Ocularis-X Client....................................................................................................................................................2

GETTING STARTED .....................................................................................................................................................4

L

AUNCHING

O

CULARIS

-X C

LIENT

....................................................................................................................................4

L

OGGING

I

N TO

O

CULARIS

-X ..........................................................................................................................................4

OCULARIS-X CLIENT INTERFACE..............................................................................................................................5

M

ENU

B

AR

...................................................................................................................................................................5

A

PPLICATION

C

ONTROLS

................................................................................................................................................6

CONFIGURING OCULARIS-X ......................................................................................................................................7

To Create an Ocularis-X View.......................................................................................................................................... 7

To Modify an Ocularis-X View ........................................................................................................................................ 8

To Delete an Ocularis-X View.......................................................................................................................................... 8

VIEWING LIVE VIDEO ..................................................................................................................................................9

To Display a View ............................................................................................................................................................ 9

Changing View Panes ....................................................................................................................................................... 9

T

HE

V

IEW

(L

IVE

) .........................................................................................................................................................10

Image Bar ............................................................................................................................................................10

Full Screen ..........................................................................................................................................................10

Digital Zoom ........................................................................................................................................................11

VIEWING RECORDED VIDEO ....................................................................................................................................12

Browse Mode.......................................................................................................................................................12

T

HE

V

IEW

(B

ROWSE

)...................................................................................................................................................12

To Browse Recorded Video ............................................................................................................................................ 13

On-Net Surveillance Systems, Inc. i

Introduction Ocularis-X User Guide

Introduction

Ocularis-X provides full framerate video from multiple megapixel cameras over limited bandwidth connections.

Ocularis-X brings the experience of desktop video surveillance to browsers and mobile video clients. With the increasing popularity of bandwidth intensive megapixel cameras, web and mobile users face the need to compromise either on the number of cameras viewed (often limited to a single camera), the quality of the video or the smoothness of the video delivered. This can result in choppy, low framerate live viewing and playback.

Ocularis-X, an add-on to Ocularis, delivers up to nine HD video streams simultaneously using OnSSI’s HDIS (High

Definition Interactive Streaming) technology. Frame rates up to 30 frames per second can be delivered over limited bandwidth networks such as 3G, 4G and broadband.

Ocularis-X extends the look and feel of OnSSI’s award winning Ocularis Client to web browsers and mobile devices. It allows security personnel in the field to perform live monitoring and synchronized playback of multiple megapixel cameras through a standard web browser.

Ocularis-X Components

There are two components to Ocularis-X. One is the Ocularis-X Server, which typically resides on a stand alone server and is used to communicate with an installation of Ocularis Base. The second is the Ocularis-X Client. This client is used to view the video delivered by Ocularis-X and can be used on any number of devices or platforms.

Ocularis-X works with Ocularis Base versions 3.0 or later.

The Ocularis-X Client works with a standard web browser. It is run by logging into a website on the Ocularis-X Server which subsequently logs into Ocularis Base. Ocularis Base authenticates user credentials and permissions and passes the appropriate video streams from the recorder(s) to the Ocularis-X Server to be transcoded and sent to the requesting Ocularis-X Client. The device using Ocularis-X Client may be inside or outside the local area network.

Specifications

Ocularis-X Client

The Ocularis-X Client, used to view live and recorded video, is displayed using a web browser. The following web browsers are supported:

Microsoft Internet Explorer version 7 and higher

Mozilla Firefox version 14.0 and higher

Google Chrome version 21.0 and higher

Opera version 12.1 and higher

Apple Safari version 5.1.7 and higher

Note:

Adobe Flash

Adobe Flash is required as a separate installation in some browsers.

2 On-Net Surveillance Systems, Inc.

Ocularis-X User Guide

Introduction

Chrome

Certain versions of Google’s Chrome browser have a documented known issue with its Flash plug-in. In these cases, you will see an "Attention" screen with instructions directing you to disable the browser’s PPAPI plug-in

Internet Explorer

When using Microsoft Internet Explorer version 9, the hardware acceleration must be turned off if you want to run

Ocularis-X Client in windowed mode (as opposed to full screen/maximized). To disable graphics acceleration in

IE9:

1. Open Internet Explorer.

2. Select the Internet Options item in the Tools menu.

3. In the Advanced tab, ensure that the box is checked under Accelerated graphics: Use software rendering instead of GPU rendering

4. Click Apply and then OK.

5. Close Internet Explorer and then restart it for changes to take effect.

See Microsoft’s instructions on turning off hardware acceleration for more details.

( http://support.microsoft.com/kb/2528233 )

On-Net Surveillance Systems, Inc. 3

Contact Information

Getting Started

Use any of the supported web browsers to access video with Ocularis-X.

Ocularis-X User Guide

Launching Ocularis-X Client

1. Open a web browser.

2. In the URL, enter the following: http://Ocularis-X_Server_IP_Address/ocularis-x/client

Where:

Ocularis-X_Server_IP_Address is the IP Address where Ocularis Server installation files are located.

Note: Certain versions of Google’s Chrome browser have a documented known issue with its

Flash plug-in. In these cases, you will see an “Attention” screen with instructions directing you to disable the browser’s PPAPI plug-in

Logging In to Ocularis-X

1. Prior to accessing Ocularis-X, you are presented with a log in screen. Enter your login information as follows:

User Name

Password

Server

A user account is required to gain access to system video. This account is your Ocularis account and may be used to access video via Ocularis-X Client or Ocularis Client.

Enter the password corresponding to the user account above

Enter the IP Address for the Ocularis Base

2. When complete, click the Login button.

Ocularis Base authenticates the user credentials entered and provides Ocularis-X with the information authorized to this user account. This currently includes which cameras streams are accessible to this user. After authentication is complete, the video stream travels from the recorder to the Ocularis-X Server and then to the

Ocularis-X Client.

4 On-Net Surveillance Systems, Inc.

Ocularis Installation & Licensing Guide

Ocularis-X Client Interface

When you successfully log in to Ocularis-X for the first time, the screen presented is a blank slate:

Contact Information

Application

Controls

Menu Bar

View Area

Figure 1 Ocularis-X Client Window

In the top part of the screen there is a menu bar on the left and application controls in the upper right portion of the page. The general view area takes up largely the rest of the screen.

Menu Bar

The upper left portion of the screen includes a menu bar with the following items:

Menu

Debug Console Overlay

Cameras

Views

Browse

Description

The icon may be used to toggle the Debug Console on and off as needed for troubleshooting purposes.

Lists all cameras to which the user account has privileges as defined on the Ocularis Base

Lists all Ocularis-X views created by the user. See To

Create an Ocularis-X view on page 7 for more informaiton.

Click this menu option to toggle between Browse mode

(recorded video) and Live mode.

On-Net Surveillance Systems, Inc. 5

Contact Information

Ocularis-X User Guide

Application Controls

The upper right portion of the Menu Bar contains functions known as ‘Application Controls’. These functions are defined as follows:

Control

Log off - click this icon to log Ocularis-X.

Logging off will stop the current session.

Graphic/Icon

Help – click this icon to open the Ocualris-

X Client documentation.

About - click this icon to view the

Ocularis-X version number.

6 On-Net Surveillance Systems, Inc.

Ocularis Installation & Licensing Guide

Contact Information

Configuring Ocularis-X

Configuring Ocularis-X includes the creation of views. A View is the fundamental display when observing video from a client application such as Ocularis-X. The screen is divided into one or more panes, each of which may display a different camera stream. Ocularis-X supports up to nine HD video streams simultaneously at their original frame rate

(up to 30 FPS).

Views in Ocularis-X are configured by the user and are stored on the computer which is used to create the view.

When you configure a view of cameras, the browser on the local machine saves the configuration information for your user account. Therefore, if you were to go to another computer and log in to Ocularis-X, that local computer would need to be reconfigured. Similarly, if you stayed on the same PC but launched a different browser and logged in to

Ocularis-X, configuration will also need to be redone. Lastly, if you clear the browser’s cache, configuration changes are lost and must be redone upon next login.

T

O

C

REATE AN

O

CULARIS

-X V

IEW

1. In the Ocularis-X Client, select the Views menu and choose Configure Views.

Layout Tabs

Configure

Tabs

Figure 2 Configure Views

The Configure Views screen allows you to create different views populated by the cameras you choose in the layout selected.

2. Select the desired layout from the Layout Tabs. Available selections include: 1 x 1 View, 2 x 2 View and 3

x 3 View. The screen will adjust accordingly based upon the view selected.

3. Each section or rectangle making up the view is called a pane. To populate each pane, simply drag and drop a camera displayed in the list on the Cameras tab to the desired pane.

On-Net Surveillance Systems, Inc. 7

Contact Information

Ocularis-X User Guide

Figure 3 Drag and drop to populate a pane with a camera stream

4. Continue to drag and drop cameras for each available pane. If you change your mind about which camera should populate which pane, simply drag a new camera and drop it on top of the existing camera in the pane.

5. When complete, enter a name for the view in the View name field. The name is displayed in the Views menu for you to access later. View names should be created so that you can easily identify the cameras it includes.

View names are not case sensitive and may include spaces.

7. You may continue to create additional views. When finished, click Close.

Note: Remember that views are saved with the browser settings on the local machine. If you open another manufacturer’s browser, move to another PC, or clear the browser’s cache, you will need to reconfigure views from scratch.

T

O

M

ODIFY AN

O

CULARIS

-X V

IEW

1. In the Ocularis-X Client, select the Views menu and choose Configure Views.

Existing views are listed.

3. Select the view you wish to modify and then click Edit View.

The configured view is displayed.

4. Make the changes you desire.

6. If you wish to edit another view, repeat steps 2 through 6. Otherwise, click Close.

T

O

D

ELETE AN

O

CULARIS

-X V

IEW

1. In the Ocularis-X Client, select the Views menu and choose Configure Views.

Existing views are listed.

3. Select the view you wish to modify and then click Delete View.

The configured view is deleted.

4. If you wish to delete another view, repeat step 3 for each view. Otherwise, click Close.

8 On-Net Surveillance Systems, Inc.

Ocularis Installation & Licensing Guide

Contact Information

Viewing Live Video

Ocularis-X video is displayed through the use of a view. Each user creates his or her own views. Once views are created, they may be accessed by the user each time they use Ocularis-X. The last view displayed will be presented to the user upon the next log in.

T

O

D

ISPLAY A

V

IEW

1. Display a preconfigured view by selecting the Views menu.

Views are listed in the order in which they were created.

2. Click the view name you would like to display.

C

HANGING

V

IEW

P

ANES

There are occasions where you may want to see video from a different camera not displayed in the current view. You can display another view containing the desired camera or you can simply replace one of the panes displayed with video from the alternate camera.

2. From the list of cameras, drag and drop the desired camera from the list displayed onto the desired pane.

Note: Changes made using this method are only temporary. If you re-load the view or logout and log in, the view will return to displaying the original cameras.

On-Net Surveillance Systems, Inc. 9

Contact Information

The View (Live)

The following is a sample 2 x 2 view shown in Live mode.

Ocularis-X User Guide

View Title

Area


Bar

Live

indicator

Figure 4 Sample View in Live mode

Image Bar

Each pane in a view has a top section called the Image Bar. On the left of the Image Bar is the name of the camera as it is defined in Ocularis Base. On the right of the Image Bar is an indicator showing that the camera stream is Live.

The name of the view will dynamically appear in the View Title Area when the mouse rolls over the top of the screen.

Full Screen

You can switch the pane of a view to full screen by clicking the Image Bar.

10 On-Net Surveillance Systems, Inc.

Ocularis Installation & Licensing Guide

Contact Information

Figure 5 Full Screen Video

Click the Image Bar again to return to the original view.

Digital Zoom

You may use digital zoom on any camera image. Draw a rectangle over the zoom area by drawing a diagonal line.

Release the mouse to perform the zoom.

Figure 6 Digital Zoom

A PIP (Picture in Picture) appears in the upper right corner of the view pane. To return to the original, zoomed out image, click the PIP.

On-Net Surveillance Systems, Inc. 11

Contact Information

Ocularis-X User Guide

Viewing Recorded Video

When an incident occurs, viewing recorded video is easily done by switching the screen to Browse mode. Settings related to recorded video (such as when to record) are configured on the camera’s corresponding recording component.

Browse Mode

Click Browse in the main menu to switch to Browse mode. Once in Browse mode, the menu item will change to Live for returning to Live monitoring.

The View (Browse)

Playback

Controls

Figure 7 A Sample View in Browse mode

The Live indicator no longer appears in the image bar of each pane. At the bottom of the screen, a set of Playback

Controls appears along with the date and timestamp of the displayed video.

Browse mode in Ocularis-X displays all cameras synchronously. Actions performed with the playback controls apply to all visible video panes. For instance, playing video from 6:00 a.m. will result in all panes playing video from 6:00 a.m. (assuming it was recorded in the first place).

12 On-Net Surveillance Systems, Inc.

Ocularis Installation & Licensing Guide

The following defines the function for each playback control:

Date & Time of video

Contact Information

Go to specific time/date

Move back one second

Move back one frame /

Pause

Timeline

Timeline slider handle

Speed indicator

Move forward one frame /

Pause

Move forward one second

Move to newest frame

T

O

B

ROWSE

R

ECORDED

V

IDEO

There are many different ways to view recorded video.

Click on the timeline to the left of the Timeline slider handle. This will play the video backwards.

Click on the timeline to the right of the Timeline slider handle. This will play the video forwards.

Drag the Timeline slider handle to the left or the right to play video backwards or forwards. o

The Speed indicator let’s you know the speed of the playback. A negative number (e.g. -25X) indicates that the video is traveling backwards.

On-Net Surveillance Systems, Inc. 13

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
