PRODUCT BROCHURE

Wired

Communication

Analog Partyline Intercom

Digital Network Partyline Intercom

Connectivity Solutions

Intercom Accessories

About Intercom Technology

An intercom (intercommunication system) is a standalone, closed-circuit system for one-way “simplex” and/or two-way “duplex” communication. The general purpose of a professional intercom system is to facilitate simple to complex communication setups for a few to thousands of users who need to be continuously on talk and/or listen mode. Two-way communication systems can operate in half-duplex or full-duplex. With half-duplex systems, one party talks while the other party listens. With full-duplex systems, both parties can talk and listen at the same time as if they are in a natural conversation in person.

Users, who have different roles in a particular operation, can be in a conference or partyline together. Or they can be sub-divided into a matrix of independent groups in any one or many private intercom channels. In addition to establishing communication points, intercom can also interface with third-party devices such as 2-way radios,

4-wire audios, telephone, TV cameras, AES3 digital audio, relay control (for signal light activation or door control), etc. Coordinating activities via voice or through third-party devices such as relay controls require low-latency (delays measured in milliseconds).

The core technology of an intercom system could be based on one of the following platforms: 2-wire/analog, 4-wire/digital, wireless, and IP networks. The decision to deploy one platform over the other will greatly depend on requirements, environment and budget. These intercom platforms operate independently or can be integrated to form a larger system in order to address specific unique communication workflow needs. Moreover, intercom systems can be bridged together with different communication systems as part of a multi-platform solution.

In certain applications, intercom systems need to be geographically distributed to support the various communication positions in a given workflow. Therefore, they can be connected over 2-wire or 4-wire; MADI for close-distance connections such as floor-to-floor; optical fiber for short to long distances within a building; E1/T1 for inner-city connections; and IP networks (LAN, WAN, or Internet) for connections across a wide area, across town, and across the country.

WIRED COMMUNICATION

Table of Contents

For decades, Clear-Com has been the leader in wired communication solutions. Clear-Com was the first to market distributed wired beltpacks to the live performance market and has since installed its full-duplex, group communication solutions to tens of thousands of facilities worldwide. Today, Clear-Com is still the unmatched trusted provider in analog and digital network partyline technologies.

pg 4

Analog Partyline Intercom

Analog 2-wire, group communication systems with intuitive plug-and-play design and superior audio clarity best known as the “Clear-Com Sound”.

pg 10

Digital Network Partyline Intercom

Flexible, scalable, and intelligent digital network partyline system platform for dynamic group communication. pg 14

Connectivity Solutions

Collection of connectivity products that link local or geographically distributed intercom systems over Ethernet/IP networks and/or optical fiber. pg 16

System Diagram

pg 18

Other Clear-Com Offerings

Clear-Com | 3

WIRED COMMUNICATION

ANALOG PARTYLINE

Analog Partyline Systems offer unsurpassed 2-wire, group communication capabilities. All intercom systems provide full-duplex communications, intuitive plug-and-play design, superior audio clarity with the embedded “Clear-Com

Sound,” and reliable communication technology for the most demanding applications.

> Clear-Com Encore

®

Clear-Com Encore

®

From main stations to remote stations, wall-mounted speaker stations to wired beltpacks, Clear-Com

Encore is a 2-wire intercom system family for reliable group communications. This platform is highly compatible with other Clear-Com or third-party products in order to address growing communications needs.

Main Stations

Two- or four- channel rackmount or portable main stations for talk, listen and call operations with built-in fail-safe intercom power supply, internal speaker, microphone and headset connections. Up to 40 user beltpacks can be supported.

Sales Part #

CS-702

MS-702

MS-704

SB-704

2

4

5

Channels

2

CS-702

MS-704

Internal Power Supply Internal Speaker

Yes, 2-amp

Yes, 2-amp

Yes, 2-amp

Yes, 2-amp

Yes

Yes

Yes

No

SB-704

MS-702

Routing

No

No

No

Yes, includes 10 source assignment switches

Source Assignment Panel

Ideal for medium to large installations where channel assignments to remote stations frequently change. Master channel sources can be assigned to any 24 remote station destinations.

Expandable up to 15 x 72 channels.

Sales Part #

RCS-2700

Remote Stations

Two- or four-channel rackmount remote systems for talk and/or listen operations on another or both channels. Systems are powered by intercom line.

4 | Clear-Com

Sales Part #

RM-702

RM-704

Channels

8 x 24-channels

RM-702

Channels

2

4

Routing

No

Speaker

Yes

Yes

RCS-2700

RM-704

WIRED COMMUNICATION

Wired Beltpacks

One- or two- channel analog beltpacks with XLR-3 line connector and XLR-4M headset connector. Microphone preamp with a dynamic range of 130 db enables intelligible voice communication for every volume level. The beltpacks feature high headroom, low noise audio and shaped frequency contour

(Clear-Com Sound) to deliver crystal-clear audio.

Sales Part #

RS-701

RS-702

RS-703

RS-702

2

2

Channels

1

RS-701 RS-702 RS-703

Cable

3-PIN XLR

6-PIN XLR

3-PIN XLR (TWC-701 or RTS Power Supply equivalent required)

Speaker Stations

One- or two-channel, flush-mount speaker stations provide users with basic talk/listen operations. Integrated speaker, electret microphone connections, push-to-talk capability are built-in features of these stations.

Sales Part #

KB-701

KB-702

KB-702GM

V-Box

KB-701 KB-702GM

V-Box

KB-702

Channels

1

Mount Options

V-Box or HelixNet S-Mount

2 V-Box or HelixNet S-Mount

2, with headset connector, Mic Jack and VOX V-Box or HelixNet S-Mount

Enclosure for KB Speaker Stations Permits either angled or vertical portable, desktop or wall mounting.

Both male and female 3-pin XLR connectors on side panel

Headset Stations

Two- or four-channel, flush-mount headset stations provide users with internal and external controls allow users to tailor the stations to their needs. Momentary or latching talk switch, remote mic kill, and LED lights for visual cueing are standard features of these stations.

Sales Part #

HB-702

HB-704

HB-702

Channels

2

4

HB-704

Mount Options

Wall or Console

Wall or Console

Clear-Com | 5

WIRED COMMUNICATION

Interfaces

System interfaces enable Encore to connect with external audio sources.

Sales Part #

TW-47

IF4W4

EF-701M

TW-12C

TWC-701

1

1

1

Channels

1

4

TW-47 EF-701M

TWC-701

IF4W4

Interface connections

Connects 2-way radio/walkie-talkie

Connects to TV cameras, 2-way radios, satellite links, and other communications devices through either headset jacks or 4-wire circuits

Connects to 4-wire audio, while also converting call signals to RS-422 data (and back)

Connects one intercom system to another (Clear-Com-to-Clear-Com, Clear-Com-to-RTS, and RTS-to-RTS system configurations)

Two-channel cable adapter combines two intercom channels onto a single 3-pin XLR cable

TW-12C

Que-com Partyline System

High-performance, economical partyline communications system that features a wide frequency response and high audio output; and individual volume control and mic on/off switch for each station with a permanently attached, rugged, noise-isolating headset. The

PK-7 is a suitable power supply option.

SMQ-1

Intercom Power Supplies

Intercom Power Supplies deliver sufficient power to support one to four channels of intercom, up to 40 beltpacks, 10 speaker stations or 12 headset stations.

Sales Part #

PK-7

PS-702

PS-704

2

4

Channels

1

PK-7

# of Beltpacks

8 RS-600 Series or 16 RS-700 Series

40 RS-600 Series or 80 RS-700 Series

40 RS-600 Series or 80 RS-700 Series

Mount

Portable

Rack

Rack

Power

0.4 Amp

1 Amp

2 Amp

PS-702

PS-704

6 | Clear-Com

WIRED COMMUNICATION

Wired IFB

IFB systems allow Talent coordinators to speak directly to on-air talents and crew members. IFB system sends one of two program audio signals to individual

Talent Receivers via standard, two conductor shielded mic cables. Communication is one-directional. Receivers via standard, two conductor shielded mic cables.

Sales Part #

AB-120

AX-704/ MA-704

PIC-4744

TR-50

TR-50

AB-120

AX-704 MA-704

PIC-4744

Description

On-Air Announcer Console

Integrates all of the inputs, outputs, and controls necessary at the announce position, including intercom

“Talkback,” IFB receiver, and a silent “Mute” button that provides noise-free cough and “mic on/off” switching

IFB Expansion Control Panel

Console-mount or rack-mount units control “program interrupt” (IFB) to the talent. MA-704 also includes gooseneck mic connector and illuminated “All Talent”. CEP-RK rack mount fixture is available for both panels

Program Interrupt Router

Handles up to four talent outputs with selectable wet/dry switch. Use with MA-704 and AX-704 IFB Control

Panels or intercom stations. Contains the circuitry for selecting one of four program sources, sending the program to the IFB channels, and interrupting it via the talent control station

Monaural IFB Talent Receiver

Single-channel talent beltpack with volume control. Connects to the program interrupt controller with a standard microphone cable. Includes a mini earphone jack output and a talent earset, paired with the

CC-010A IFB ear set

Wireless IFB

Wireless IFB (interruptible fold back) systems operate between 486.4 and

691.1MHz. Wireless IFBs are used for one-directional communication.

Directors and other management can use this to monitor program audio, or for talent cueing and crew communications during a production. The PRC-2 receiver provides simplicity and flexibility in a package that is intuitive for untrained users to operate. Wireless IFB uses +/-20 kHz FM deviation for efficient use of the bandwidth, with compandor noise reduction circuitry for an excellent signal to noise ratio.

NOTE: This product is not approved for sale in Europe.

PTX-3

PRC-2

Sales Part #

PRC-2

PTX-3

Description

Wireless IFB Receiver

Uses +/-20 kHz FM deviation for efficient use of the bandwidth with compandor noise reduction circuitry for an excellent signal to noise ratio. Paired with the CC-010A IFB ear set

Wireless IFB Transmitter

The wireless IFB transmitter base station has 256 selectable UHF frequencies at 100 kHz increments.

Stand alone or rack mountable with the PRK-2 kit. (486.4 - 691.1 MHz)

Clear-Com | 7

WIRED COMMUNICATION

Intercom Accessories

Sales Part #

FL-7

Description

Call Signal Flasher

Visual and audible indication of a call signal on the intercom channel


MT-701

WP-2

WP-6

YC-36

SP-3

HS-6

Isolation Box for Clear-Com analog Partyline

Reduces hum in Clear-Com Encore partyline systems and bridges two Encore partyline systems together

Two-channel 3-Pin Selectable Intercom Outlet Wall Plate

Allows user on the a single-channel beltpack to talk on either of two intercom channels

Two-channel 6-Pin Intercom Outlet Wall Plate

Allows user on the a two-channel beltpack to talk on both intercom channels

Dual-channel Beltpack Adapter

A 3-pin to 6-pin adapter that combines 2 single-channel 3-pin cables into a single two-channel 6-pin connector

Intercom Line Splitter

3-way intercom line splitter with one 3-pin female and three 3-pin male

XLR type connectors

Telephone-style handset with wall/console mount hanger, push-to-talk switch

PT-7

Push-to-talk, hand-held microphone

8 | Clear-Com

WIRED COMMUNICATION

Compatible Intercom Headsets

Clear-Com offers a versatile range of headsets designed to give excellent audio quality, comfort and ease of use to suit every need. Our range of headsets can be used with all Clear-Com

Partyline system and beltpacks.

CC-110

CC-400 CC-40

CC-220

CC-60

CC-300

CC-15

CC-30 CC-26K CC-010A

Sales Part #

CC-110-X4

CC-220-X4

CC-300-X4

CC-400-X4

CC-40

CC-60

CC-15-MD4 / CC-15-X4

CC-30-MD4 / CC-30-X4

CC-26K

CC-010A

Headset Mic type Mic/Headphone Impedance Mic Boom

Light-weight single-ear Dynamic 200/400 Ohms

Light-weight double-ear Dynamic 200/400 Ohms

Single-ear

Double-ear

Single-ear

Dynamic

Dynamic

Dynamic

200/400 Ohms

200/400 Ohms

200/400 Ohms

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

Adjustable

Double-ear

Single-ear

Double-ear

Light-weight single-ear

Single-ear

Dynamic

Electret

Electret

Dynamic

Dynamic

200/400 Ohms

2.2K / 40 Ohms

2.2K / 40 Ohms

200/200 Ohms

200 Ohms

Adjustable

360-degrees rotation for left or right side use

360-degrees rotation for left or right side use

360-degrees rotation for left or right side use

None (Listen only)

Compatible Intercom Microphones

Compatible with Encore Analog Partyline systems, GM and GN microphones have superior audio sensitivity and durable construct. Each type of gooseneck microphones is available in a variety of sizes.

GM-9 / GM-18

GN-250 / GN-450

Sales Part #

GM-9 / GM-18

GN-250 / GN-450

Length

9 inches/18 inches

25 cm (10")/ 45 cm (18")

Compatible With

Encore analog systems

Encore analog systems

Clear-Com | 9

WIRED COMMUNICATION

DIGITAL NETWORK PARTYLINE

Digital Network Partyline is a wired intercom platform for full-duplex dynamic group communication, with I.V.Core technologies at the core and offers all the benefits of digital audio and network-friendly characteristics.

> HelixNet

®

HelixNet

HelixNet Digital Network Partyline System uniquely delivers all features and functions of industry- standard partyline systems with digital audio clarity as well as IP connectivity to any digital network.

Not only can HelixNet operate over any standard shielded twisted-pair cable (microphone or

CAT5/6), but all audio channels, program audio and distributed Power-over-Ethernet (PoE) can run on a facility’s standard IT network infrastructure via an Ethernet/LAN connection.

HelixNet Main Station

The HMS-4X Main Station offers

24 channels of full-duplex audio and program audio. It features the legendary

“Clear-Com Sound” quality for a highly intelligible audio experience. Hardware auto-discovery, intuitive menu operations, and channel accessibility are also unique features that make system setup and maintenance effortless.

Multiple systems may also be linked together over a fiber or Ethernet connection to support an even greater number of users.

• High Channel Density. 12 channels of audio and power are standard per

Main Station. 24 channels are available via an optional expansion. Up to three

Main Stations may be linked to share

I/O expansion slots and up to 24 intercom channels of audio/power

(optional channel expansion required).

• Any combination of Main Stations and Remote Stations (up to a total of

6) may be stacked in order to have one headset and mic used to address all channels.

• No Hum. No Buzz. All-digital system offers immunity to electro-magnetic interference and ground loops.

• High User Capacity. A single Main

Station can support up to 60 users over Ethernet and 20 over mic cable.

• Single Cable Operation. All networked intercom channels and power for beltpacks or a combination of user devices can be transmitted over a single shielded twisted-pair cable

(Ex. Microphone cable for powerline,

CAT5 or CAT6 cable for PoE).

• Seamless Linking. System resources are shared over a LAN or fiber link so users can select local or remote partyline channels and program audio feeds. Optional 2- or 4-wire interface modules further extends connectivity to existing analog partyline or matrix intercoms.

• Easy Configuration. Using Clear-Com’s

Core Configuration Manager (CCM),

HelixNet system configuration and setup is easy through the free, browser-based software. It provides the same menu functionality as

HelixNet Main menus. Supported by the latest versions of all major browsers on Mac, PC and tablet platforms.

HMS-4X Front HMS-4X Rear*

10 | Clear-Com

WIRED COMMUNICATION

HelixNet User Devices

HelixNet devices consist of the HRM-4X

Remote Station, HKB-2X Speaker Station and the HBP-2X Digital Beltpack. Digital

Beltpacks are powered via Powerline over standard mic cable while Remote and

Speaker Stations are powered via Power- over-Ethernet (PoE), or a Universal AC wall adapter. By using a combination of power sources, up to 60 user devices can effectively be on the system simultaneously.

HKB-2X

HBP-2X

HRM-4X

Sales Part #

HRM-4X

Description

Remote Station

Channel Access

Up to 4 of any 24 system channels*

Cable Operation

All audio data, control data and power received via a single shielded twisted- pair cable

Power Options

• Powerline

• Power-over-Ethernet (PoE)

• Universal power ad apter

HKB-2X

HBP-2X

Similar capabilities as the HMS-4X Main Station. Rotary channel level controls. Line/LAN status indicators.

No option module bays at the rear

Headset and Speaker Station Up to 4 of any 24 system channels*

All audio data, control data and power received via a single shielded twisted- pair cable

• Powerline,

• Power-over-Ethernet (PoE)

• AC/DC universal power adapter

Large Format OLED Displays. Up to 10 Characters for User-defined Labels. Speaker and Program Level Controls.

Display Tilts Up and Down for Best Viewing. Fits 4-Gang Standard Electrical Wall Box (US ANSI/NEMA OS-1 Standard

Size) or Optional S-Mount Enclosure

Digital beltpack Up to 2 of any 24 system channels*

All audio data, control data and power received via a single shielded twisted- pair cable

• 3-pin XLR MIC cable

Configurable in daisy-chain or star topology without active split boxes. System configuration and firmware upgrades are centrally managed from the Main Station

*Optional 12-channel expansion license required

S-Mount (Enclosure for HKB-2X)

The S-Mount is a desktop or wall mounting kit for the HelixNet Speaker

Station. The S-Mount is easily adjustable to different angles to suit user’s requirements.

• AC/DC universal power adapter

• Ethercon Ethernet Connector

• XLR-3M and XLR-3F powerline intercom ports

• Adjustable rake for best viewing options

• Anti-slip feet

• Screw-holes for easy wall mounting

Speaker Station sold separately

Clear-Com | 11

WIRED COMMUNICATION

HelixNet Option Modules

HelixNet optional modules allow for system expansion over fiber or Ethernet as well as can interface with 2-wire and 4-wire communication systems. Each module fits into one of three built-in expansion bays located at the rear of an HMS-4X Main Station.

Interface Modules

The HLI-2W2 2-wire interface module connects two single-channel 2-wire analog audio circuits to HelixNet intercom channels. Two 3-pin XLR-F connectors on the module connect intercom lines of Clear-Com or RTS

2-wire systems, and can be assigned via the Main Station menu.

Sales Part #

HLI-2W2

HLI-4W2

Port Count

2

2

HLI-2W2 HLI-4W2

The HLI-4W2 interface module enables

4-wire audio paths, such as matrix ports, cameras and telephone circuits to interface with HelixNet intercom channels.

It connects two 4-wire analog audio circuits to HelixNet intercom channels.

Two RJ-45 connectors on the module connect the external 4-wire circuits and can be assigned via the Main Station menu.

Each of the two ports utilizes both transformer and electrical balancing for hum and noise-free audio paths.

Interface with

Analog 2-wire intercoms (Clear-Com and RTS compatible). Requires external analog partyline power

Digital 4-wire intercoms (Matrix ports, cameras, and telephone circuits)

Linking Modules

HelixNet uniquely offers Ethernet or fiber based linking of multiple HelixNet Main

Stations. Once connected, Main Stations share partyline channels and program audio, and make them available to any station and beltpack on the networked system. Fiber

Modules can be mixed with Ethernet

Modules in the same network.

Sales Part #

HLI-ET2

HLI-FBS

Port Count

Ethernet

Fiber

Interface with

Dual LAN interface

Daisy-chain fiber interface

HelixNet Partyline Station-to-Station Networked Linking

Up to three Main Stations may be linked using any combination of HLI-ET2

Ethernet or HLI-FBS Fiber modules.

HLI-ET2 HLI-FBS

12 | Clear-Com

WIRED COMMUNICATION

Compatible Intercom Headsets

Clear-Com offers a versatile range of headsets designed to give excellent audio quality, comfort and ease of use to suit every need. Our range of headsets can be used with all Clear-Com

Partyline system and beltpacks.

CC-110

CC-400 CC-40

CC-220

CC-60

CC-300

CC-15

CC-30 CC-26K CC-010A

Sales Part #

CC-110-X4

CC-220-X4

CC-300-X4

CC-400-X4

CC-40

CC-60

CC-15-MD4 / CC-15-X4

CC-30-MD4 / CC-30-X4

CC-26K

CC-010A

Headset Mic type Mic/Headphone Impedance Mic Boom

Light-weight single-ear Dynamic 200/400 Ohms

Light-weight double-ear Dynamic 200/400 Ohms

Single-ear

Double-ear

Single-ear

Dynamic

Dynamic

Dynamic

200/400 Ohms

200/400 Ohms

200/400 Ohms

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

300-degrees rotation for muting mic on/off

Adjustable

Double-ear

Single-ear

Double-ear

Light-weight single-ear

Single-ear

Dynamic

Electret

Electret

Dynamic

Dynamic

200/400 Ohms

2.2K / 40 Ohms

2.2K / 40 Ohms

200/200 Ohms

200 Ohms

Adjustable

360-degrees rotation for left or right side use

360-degrees rotation for left or right side use

360-degrees rotation for left or right side use

None (Listen only)

Compatible Intercom Microphone

Compatible with HelixNet Partyline

Systems, the 110 Series gooseneck condenser microphones offer excellent frequency response and audio sensitivity.

This range of microphones comes supplied with a threaded 3-pin male DIN connector and windscreens.

Sales Part #

110/100

110/340

110/490

Length

10 cm (3.9”)

34 cm (13.4”)

49 cm (19.3”)

Compatibility with

HelixNet

Clear-Com | 13

WIRED COMMUNICATION

CONNECTIVITY SOLUTIONS

Clear-Com offers connectivity solutions designed for linking multiple intercom systems together over IP networks, routing and distributing audio and video signals over optical fiber networks, and interfacing communication solutions with SIP protocols and 2-way radios.

> LQ Series

> ProGrid

> Clear-Com Gateway

LQ

Series: Intercom Connectivity Solution over IP Networks

LQ devices extend and connect any combination of 2-wire partyline intercom, 4-wire intercom/audio or 4-wire with GPIO options over IP circuits (House LAN, Corporate WAN or Internet connections).

For extending intercom systems to remote locations:

Simply connect an LQ device to the house intercom system and place other

LQ devices at remote locations where beltpacks or KB units are necessary.

Then, establish links between LQ devices using the Core Configuration

Manager from any browser.

Features:

• Brand agnostic—connect any brand intercom system to LQ

• Up to five RS Series beltpacks can be powered by a 12V DC-powered LQ unit; only 1 RS beltpack can be power by PoE-powered LQ unit

• Auto-null circuit

• Low latency - no audible delays

LAN/WAN

Internet

LQ-2W2 LQ-2W2

For linking multiple systems from different locations:

Place an LQ device at each end of the intercom system, then establish links among the LQ devices using the

Core Configuration Manager from any browser.

LAN/WAN

Internet

RTS partyline system

LQ-2W2

LQ-2W2

Linking 2-wire with

Third-party partyline

4-wire

LQ-4W2

For linking remote systems to an

Eclipse HX matrix:

Remotely connect intercom or audio sources via LQ Series devices to an Eclipse HX matrix using an

IVC-32-HX card.

LAN/WAN

Internet

LQ-R4WG8

LQ-R2W4-4WG4

IVC-32-HX

Linking matrix to GPIO, 2-wire or 4-wire intercom system

Clear-Com or third-party GPIO devices

Clear-Com or third-party

4-wires and GPIO devices

14 | Clear-Com

WIRED COMMUNICATION

ProGrid

ProGrid is a world-class audio and signal transport solution, for ultra-fast transport, distribution, and routing of audio, intercom, video signals* and control data. Based on the open AES3 and AES10 (MADI) standards, the ProGrid devices runs on the

OPTOCORE

®

(Optical Fiber) and

SANE (Synchronous Audio Network

+Ethernet) platforms. All serial data, word clock sync, analog, AES, MADI audio with timecode, and all major brand intercom signals are transmitted synchronously at extremely low latency and across long distances over ProGrid.

Multiple Encore analog systems connected over ProGrid

MS-702

Studio 1

EF-701M

PG4-Intercom

ProGrid Network

Over Fiber

PG4-Intercom

MS-702

Studio 2

EF-701M

Rehearsal Hall

PG-YG2

PG-Y3R-TP

PG-Y3R-TP

PG16-8MI-8LO-FX

Multiple venues connected to a Studio/Radio Station with HelixNet Intercom over ProGrid

Theater

Local Inputs

Outputs to Monitoring Systems

PG16-16MI-FX

PG16-16MI-TP

PG16-16LO-TP

Fiber Patch

PG8-INTERCOM

PG16-16LI-FX

PG16-16LI-FX

PG16-16LI-FX

PG16-16LI-FX

PG16-16LI-FX

PG16-16LI-FX

PG16-16LO-TP

Stage

FOH

PG16-16MI-FX

PG16-16MI-TP

PG8-INTERCOM

Black Box

Radio Station

PG16-8MI-8LO-FX

PG2-MADI-FX

DigiDesign Console

ProTools

PG-YG2

PG-Y3R-TP

PG-Y3R-TP

PG16-8MI-8LO-FX

Clear-Com Gateway

Clear-Com Gateway is an interoperability solution for linking and bridging disparate communication systems from different platforms such as radios, intercoms, telephones, and

IP networks.

Analog Radios

SIP

RTP

RoIP

EF-701M

* Composite video is available over the Optocore network using the PG2-MADI-FX and PG32-AES-FX units.

HD SDI video is available through the use of the BroaMan MUX-22-CC.

2-wire Partyline

Clear-Com | 15

WIRED COMMUNICATION

Clear-Com Intercom and

Connectivity Solution Diagram

There are many applications that need to support considerable size communication teams. Their workflows often span within a building, across a wide campus area, and across geography, as well as involve many different types of communication systems. These applications require a flexible, reliable and extensible communication and connectivity solution for linking people or systems together.

Clear-Com’s Integrated Wired,

Wireless and IP solutions can be connected with Eclipse HX matrix systems. Multi-system connections are possible over intelligent linking via IP networks, fiber, E1/T1, MADI,

SIP, and four-wire.

In addition, intercom and data signals flowing through the Eclipse HX system can be distributed, routed, transported across long distances over an Optical

Fiber platform along with signals from audio and video.

2-way radios

SIP/RTP/RoIP

4-Wire

Gateway

Multi-User Administration

EHX

LAN

Eclipse HX-Delta Digital Matrix

Delta

Production/

Logic Maestro

Interactive IFB

IMF-103

Encore Partyline

Interfaces for:

Analog Telephones

2-way Radios

GPI

Relays

AES3

DX410

FreeSpeak II Wireless

Eclipse HX-PiCo Digital Matrix i-Station

Intelligent Linking via

IP

Fiber

E1/T1

MADI

4-Wire

Data

HelixNet Partyline

MUX-22-CC

Eclipse HX-Omega Digital Matrix Eclipse HX-Median Digital Matrix

Internet or IP

LQ Interface

4-wire with GPIO

4-wire 2-wire

V-Series

PA system

Intercom system

2-way radio

Internet or IP

Concert Clients

LAN

Agent-IC

ProGrid Signal Transport

16 | Clear-Com

WIRED COMMUNICATION

2-way radios

SIP/RTP/RoIP

4-Wire

Gateway

Multi-User Administration

EHX

LAN

Eclipse HX-Delta Digital Matrix

Delta

Production/

Logic Maestro

Interactive IFB

IMF-103

Encore Partyline

Interfaces for:

Analog Telephones

2-way Radios

GPI

Relays

AES3

DX410

FreeSpeak II Wireless

Eclipse HX-PiCo Digital Matrix i-Station

Intelligent Linking via

IP

Fiber

E1/T1

MADI

4-Wire

Data

HelixNet Partyline

MUX-22-CC

Eclipse HX-Omega Digital Matrix Eclipse HX-Median Digital Matrix

Internet or IP

LQ Interface

4-wire with GPIO

4-wire 2-wire

V-Series

PA system

Intercom system

2-way radio

Internet or IP

Concert Clients

LAN

Agent-IC

ProGrid Signal Transport

Clear-Com | 17

WIRED COMMUNICATION

Matrix and IP Communication Solutions

Eclipse HX

Eclipse HX Digital Matrix Platform enables critical intercommunications among teams who need direct (pointto-point) and one-to-many (group and partyline or conference) connections.

Eclipse HX is a large scale matrix communication solution that has extensively integrated IP connectivity and IP communications into its platform, making it the leader in matrix and integrated IP intercom solutions in the industry.

IP-based Communication Points

Clear-Com Concert

Clear-Com Concert is an IP-based software client that integrates directly with Eclipse Systems, enabling remote users to connect back to the central intercom system. Permitted Concert users on PCs simply connect to the internet, LAN or WAN, and immediately communicate with other members on the Clear-Com partyline and/or matrix intercom circuit who are using hardwired panels and wireless beltpacks.

Agent-IC

®

The Agent-IC mobile app enables remote users of Eclipse HX Matrix intercom systems to access intercom audio from a mobile devices such as smart phones and tablets over 3G, 4G or Wi-Fi / IP networks. Fully featured with point-to-point calling, point-to- multi-point group calling, partyline,

PTT, local cross-point audio level control and notification functions.

Access to the host Eclipse HX matrix is secure, using UserID/password and audio encryption.

18 | Clear-Com

Wireless Intercom Systems

FreeSpeak II—1.9GHz & 2.4GHz

FreeSpeak II

®

is the most powerful and sophisticated distributed wireless solution. Its ability to maintain a strong and continuous wireless connection across an expansive coverage area while providing crystal-clear digital audio makes FreeSpeak II the ideal wireless roaming solution.

WIRED COMMUNICATION

DX Series—2.4GHz

All DX Series wireless intercom systems feature Spectrum-Friendly™ technology for interference-free operation. The DX Series enable full-duplex communications in a range of system offerings, from a portable base station for few wireless users to co-located rack-mount base stations for up to 16 full-duplex users on two channels. DX

Series intercoms are cost-effective, easy to set up, and deliver exceptional sound clarity.

WBS—518-608MHz and

614-686MHz

WBS Systems operate in select frequency UHF bands. Whether WBS is used as a standalone wireless communication system or combined with wired intercoms, its frequency agility, rich feature set, audio clarity and performance reliability make every WBS system an excellent choice.

Clear-Com | 19

Corporate Description

Clear-Com, an HME company, is a trusted global provider of professional real-time communications solutions and services since 1968. We innovate market proven technologies that link people together through wired and wireless systems.

Clear-Com was first to market portable wired and wireless intercom systems for live performances. Since then, our history of technological advancements and innovations has delivered significant improvements to the way people collaborate in professional settings where real-time communication matters.

For the markets we serve – broadcast, live performance, live events, sports, military, aerospace and government – our communication products have consistently met the demands for high quality audio, reliability, scalability and low latency, while addressing communication requirements of varying size and complexity.

Our reputation in the industry is not only based on our product achievements, but also on our consistent level of customer engagement and dedication to delivering the right solutions for specialized applications, with the expertise to make it work. Around the globe and across markets, Clear-Com’s innovations and solutions have received numerous awards and recognitions for ingenuity and impact to customers.

Americas and Asia-Pacific Headquarters

California, United States

Tel: +1.510.337.6600

Email: [email protected]

Email: [email protected]

Europe, Middle East, and Africa Headquarters

Cambridge, United Kingdom

Tel: +44 1223 815000

Email: [email protected]

China Representative Office

Beijing, P.R.China

Sales/Marketing Tel: +86 10 59002608

Service Tel: +86 10 59000198

Email: [email protected]

www.clearcom.com

© 2016. Clear-Com LLC. All rights reserved. ® Clear-Com and the

Clear-Com logo are registered trademarks of Clear-Com LLC.

Optocore and SANE are registered trademarks of OPTOCORE GmbH.

v.3_9/16

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
