Gentech Lighting

Gentech Lighting

Gentech Lighting

37 Miles Street, Mulgrave, Victoria 3170, Australia

Ph +613 9561 5688 Fax +613 9561 5666 [email protected]

www.gentechlighting.com.au

Gentech

Lighting

2014

CONTENTS

Line drawing measurements throughout this catalogue are in millimetres.

Round Cut Hole Rectangular Cut Hole

Please note: Actual products should be used to confirm all cut hole sizes prior to installation

Whilst every care has been taken in the production of this catalogue Gentech Lighting reserve the right, without prior notification, to change or modify specifications contained within.

56

56

60

60

61

61

62

64

66

67

50

50

52

53

39

39

42

43

43

49

37

37

38

38

16

16

35

36

5

14

15

6

6

79

79

80

81

82

72

72

74

77

78

70

70

70

71

n

DOWNLIGHTS

LED

RECESSED

SEMI RECESSED

SURFACE MOUNT

DICHROIC

RECESSED

SEMI RECESSED

SURFACE MOUNT

G4 HaLOGEN

RECESSED

aR111

RECESSED

GU10-GZ10

RECESSED

SURFACE MOUNT

FLUORESCENT

RECESSED

SURFACE MOUNT

METaL HaLIDE

RECESSED

SURFACE MOUNT

PaRTS aND aCCESSORIES

n

CABINET LIGHTING

LED

12V

240V

n

LED PANELS

RECESSED PaNELS

n

STRIP LIGHTING

LED TWISTER

LED SNaKE

PaRTS aND aCCESSORIES

n

EXTRUSIONS

SURFaCE MOUNT

RECESSED

PaRTS aND aCCESSORIES

n

SPOTLIGHTS

LED

DICHROIC aR111

GU10-GZ10

PLC

METaL HaLIDE

LINEaR HaLOGEN

PaR LaMP

PaRTS aND aCCESSORIES

CONTENTS

n

INTEGRAL SPOTLIGHTS

84

SPOTLIGHT SLAB RAILS 84

SINGLE SPOTLIGHTS

IT

T11

86

86

86 n

TRACK LIGHTING

SINGLE CIRCUIT

87

88

TRACK LIGHTS

88

LED 88

DICHROIC 90

AR111 91

GU10-GZ10 91

PLC 92

METAL HALIDE

LINEAR HALOGEN

PAR LAMP

TRACKS

ACCESSORIES

92

93

93

93

94

MULTI CIRCUIT

TRACK LIGHTS

96

96

LED 96

DICHROIC 99

AR111 99

GU10-GZ10 100

PLC 100

LINEAR HALOGEN

METAL HALIDE

PAR LAMP

SURFACE MOUNT TRACKS

RECESSED TRACKS

ACCESSORIES

100

101

101

102 n

SURFACE MOUNT

FLUORESCENT

GX53

T5

PLC

INCANDESCENT

n

DISPLAY LIGHTS

LED

12V

n

WALL LIGHTS

WALL RECESSED

LED

12V

240V

WALL SURFACEMOUNT

LED

240V n

PENDANTS

GLASS PENDANTS

METAL PENDANTS

PARTS AND ACCESSORIES

108

109

109

109

111

111

112

113

115

116

117

117

121

124

124

124

132

134

134

137

138

Gentech Lighting

n

TRAPEZE

FIXTURES

COMPONENTS

n

FLEXI LIGHTING

FIXTURES

COMPONENTS

140

141

143

146

146

148

n

OUTDOOR LIGHTING

WALL LIGHTS

151

152

SURFACE MOUNT 152

LED 152

12V 153

240V 159

RECESSED 165

LED 165

12V 168

240V 170

FLOOD LIGHTS

LED

METAL HALIDE

DECK LIGHTS

172

172

173

174

INGROUND UPLIGHTERS

LED

12V

POND LIGHTS

GARDEN SPOTLIGHTS

PATH LIGHTS

BOLLARDS

POST TOPS

PARTS AND ACCESSORIES

184

186

187

187

175

175

177

180

180

n

LAMPS

LED

MR16

G4 BI-PIN

AR111

GU10

PAR

E27 and B22 GLS n

CONTROL GEAR

LED DRIVERS

CONSTANT CURRENT

195

195

CONSTANT VOLTAGE

195

198

CONSTANT VOLTAGE IP RATED 200

LV TRANSFORMERS

ELECTRONIC

ELECTRONIC IP RATED

IRON CORE

IRON CORE IP RATED

201

201

202

202

203

188

189

189

190

192

193

194

194

1

REFERENCE INFORMATION

The following chart is to be used for a quick comparison on selecting lamp types in respect of energy saving. It is prepared on an averaged data supplied from different manufacturers.

Accurate lumen output on a specific lamp should be obtained from the manufacturer.

Lamp Type

Incandescent

Lamp Lumens Efficacy

Watts (Lumen/Watt)

100W 1800 18

Tungsten Halogen 250W 5500

Low Voltage Halogen 50W 1200

GU/GZ10 Halogen

LED

50W 750

22

24

15

1W 90 90

Fluorescent 36W 3240 90

Low Pressure Sodium 180W 32400 180

High Pressure Sodium 400W 50000

Metal Halide 400W 40000

Mercury Vapour 400W 23200

125

100

58

Energy Efficient Lighting

Changes to the building code in 2010 mean there are new demands to meet energy efficient requirements. With this rising demand for energy efficient lighting systems we have increased our range of products with additions to our LED,

PL, PLC Metal Halide, GX53 compact fluorescent ranges providing you with low power consumption, and long lamp life, offering cost effective lighting solutions. Lamp selection is very important i.e. for correct colour and performance for each lighting task. For assistance in determining your lighting requirements, and working in-line with the Building Code of

Australia, we advise consulting with your lighting specialist.

Recommended Maintenance Illuminance for various types of tasks, activities or interiors according to AS1680

Representative activities/interiors Class of task

Movement & orientation

Rough intermittent

Simple

Moderately easy

Moderately difficult

Difficult

Very difficult

Extremely difficult

Recommended illuminance, as lux

40

80

160

240

400

600

800

1200

Corridors; cable tunnels; indoor storage tanks; walkways

Locker rooms; loading bays; live storage of bulky materials

Waiting rooms; rough checking of stock; rough bench work; entrance halls

Food preparation; counters for transactions; medium woodworking

Reading; writing; typing; fine woodworking

Fine manufacture; colour matching; fine inspection

Hand tailoring; extra-fine bench work; graphic art inspection

Jewellery and watchmaking

About Cable Length Required

Low voltage dichroic light fittings carry approximately 20 times (240V/12V) the current intensity than that of standard light fittings. It is therefore important to carefully determine the cross section size of the cable and the length from transformer to the fitting.The following chart is a simplified form recommending cable length per run.

5m 10m 15m 20m 25m 30m

20W 0.75mm

2

1.5mm

2

2.5mm

2

2.5mm

2

4.00mm

2

4.0mm

2

6.0mm

2

50W 2.5mm

2

4.0mm

2

6.0mm

2

6.0mm

2

10.0mm

2

10.0mm

2

16.0mm

2

100W 4.0mm

2

6.0mm

2

10.0mm

2

16.0mm

2

16.0mm

2

25.0mm

2

25.0mm

2

150W 6.0mm

2 10.0mm

2 16.0mm

2 25.0mm

2 25.0mm

2

200W 6.0mm

2 16.0mm

2 25.0mm

2 25.0mm

2

250W 10.0mm

2

16.0mm

2

25.0mm

2

300W 10.0mm

2

25.0mm

2

REFERENCE INFORMATION

Types of protection against dust and water in accordance with IEC,AS1939 regulation

1st numeral: 1: protection against solid object larger than 50mm,

2: objects larger than 12mm,

3: objects larger than 2.5mm,

4: objects larger than 1mm,

5: protection against dust but not entirely prevented,

6: no ingress of dust.

2nd numeral: 1: protection of dropping water,

2: drops of water when the object is tilted by 15 deg from normal position

3: spraying water at up to 60 deg from vertical,

4: splashing and spraying water from any direction,

5: water jet from any direction at low pressure,

6: strong water jet from any direction,

7: water immersed to 1 metre,

8: water immersed to a specified depth

Degree of protection

1st digit: protection against foreign bodies

Foreign bodies larger than 12mm

Foreign bodies larger than 12mm

Foreign bodies larger than 12mm

Foreign bodies larger than 1mm

Foreign bodies larger than 1mm

Ingress of dust, not prevented entirely

Ingress of dust, not prevented entirely

Ingress of dust, not prevented entirely

No ingress of dust

No ingress of dust

Degree of protection

2nd digit: protection against water

Abbreviation examples

Type of protection

Vertical dripping water

Spray water at an angle up to

60 degrees

IP20 Covered

IP21

IP23

Drip proof

Spray proof

Splash water from any direction

Spray water at an angle up to

60 degrees

Splash water from any direction

IP40 Covered

IP44

IP50

IP53

IP54

Water jet from any direction at low pressure

IP65

Against ingress or water immersed IP67

Splash proof

Dust proof

Dust and rain proof

Dust and splash proof

Protected against dust and water jet

Dust and water proof

Recessed Luminaire Heat Shields

Gentech Lighting has an extensive range of recessed luminaires with heat shields attached.Testing and installation clearances have been approved and provided by a NATA accredited laboratory. Fittings with heat shields attached have clearance labelling and installation parameter leaflets supplied in each box.

Heat shields are available for retro-fit on existing fittings in our range

(70 mm, 78 mm, 85 mm and 90 mm options).

Fire Rated Downlight

In compliance with the relevant building regulations our Fire Rated downlight range has been tested and passed to 90 minute ceiling-floor system. They feature intumescent material at the top of the fitting and around the rim of the housing which swell and seal the fitting in case of fire. The fittings closed construction offers better acoustic insulation, eliminates moisture transfer and draught.

Gentech Lighting

3

About LED

Innovation in lighting fixtures and fittings has progressed in the area of the LED light source.

LED fittings and lamps are available for linear lighting, downlighting, spotlighting, display and cabinet lighting. Its compact size offers long life, in perfect conditions, energy efficiency and no UV or IR radiation. LED is an application specific light source which provides pin-point light. LED’s are sensitive to power variation, heat and humidity which affect lamp life and colour. A large percentage of our LED range comes with quick connectors and leads, which are compatible with our drivers. In providing the fittings with this option it ensures correct installation so as not to damage your LED.

We suggest that quick connectors be used where possible (refer to working example and pictures right).

REFERENCE INFORMATION

Quick connection by plug and socket

Features and Benefits of LED Lighting

1. LED light contains no harmful ultra violet and infra red heat that can cause damage to sensitive pieces of art or fabric

2. Environmentally friendly by energy saving and contains no poisonous material

3. Safe to use in terms of extra low voltage

4. LED light radiates very little heat and is generally touchable whilst in operation

5. Offers long life span without maintenance

6. Its compact size fits in many tight space applications

7. Excellent colour saturation may produce desired coloured light without special coloured lens.

8. High impact and vibration resistance compared to all other types of lamps

9. Instant on-off light and easier system control on synchronisation and varying colours.

4

Gentech Lighting

Gentech Lighting

5

LED RECESSED

6

LED-360 9W LED Downlight

Dimmable with Leading or Trailing dimmers. Features inbuilt 350mA driver, thermal protection and large terminal for easy wiring. Comes with 35000hrs lamp life and two year warranty.

Material Cast Alloy, Poly Carbonate lens

Size 97 (Diameter) x 52 (Height) mm

Colour White

Lamp 9W Samsung LED

Led Colour Cool White – 4000K

Warm White – 3000K

Lumen Output Cool White – 600 Lm

Warm White – 550 Lm

Beam Angle 120°

Power Input: 220-240V~ 50/60Hz

Cut Hole 75mm

LED-361 12W LED Downlight

Dimmable with Leading or Trailing dimmers. Features inbuilt 500mA driver, thermal protection and large terminal for easy wiring. Comes with 35000hrs lamp life and two year warranty.

Material

Size

Cast Alloy, Poly Carbonate lens

120 (Diameter) x 52 (Height)mm

Colour White

Lamp 12W Samsung LED

Led Colour Cool White – 4000K

Warm White – 3000K

Lumen Output Cool White – 800 Lm

Warm White – 750 Lm

Beam Angle 120°

Power Input: 220-240V~ 50/60Hz

Cut Hole 97mm

LED-361N 12W LED Fixed Downlight

Dimmable with Leading or Trailing dimmers. Features inbuilt LED driver, and thermal protection. Comes with

35000hrs lamp life and two year warranty.

Material Cast Alloy, Poly Carbonate lens

Size 110 (Diameter) x 53 (Height) mm

Colour White

Lamp 12W LED (18 chips)

Led Colour Cool White – 4000K

Warm White – 3000K

Lumen Output Cool White – 900Lm

Warm White – 800Lm

Beam Angle 100°

Power Input: 220-240V AC ~ 50/60Hz

Power factor >0.9

Cut Hole 90mm

Gentech Lighting

LED-362 16W LED Downlight

Dimmable with Leading or Trailing dimmers. Features inbuilt 660mA driver, thermal protection and large terminal for easy wiring. Comes with 35000hrs lamp life and two year warranty.

Material Cast Alloy, Poly Carbonate lens

Size 145 (Diameter) x 55 (Height) mm

Colour White

Lamp 16W Samsung LED

Led Colour Cool White – 4000K

Warm White – 3000K

Lumen Output Cool White – 1100 Lm

Warm White – 1000 Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

125mm

LED-363 18W LED Downlight

Dimmable with Leading or Trailing dimmers. Features inbuilt 550mA driver, thermal protection and large terminal for easy wiring. Comes with 35000hrs lamp life and two year warranty.

Material

Size

Cast Alloy, Poly Carbonate lens

168 (Diameter) x 55 (Height) mm

Colour White

Lamp 18W Samsung LED

Led Colour Cool White – 4000K

Warm White – 3000K

Lumen Output Cool White – 1300 Lm

Warm White – 1150 Lm

Beam Angle 120°

Power Input: 220-240V~ 50/60Hz

Cut Hole 145mm

G9435-LED LED Shop Fitter 35W

35W LED adjustable down light. Features Frosted glass lens and enclosed back. Offers 55° tilt. Includes 700mA

Tridonic LED Driver, 900mm lead and 3 pin plug.

Material

Size

Die-cast Aluminium

230 x 140 x 135 (Depth)

Colour White

Lamp 35W LG LED 105 chips

Led Colour Warm White – 3000K

Cool White – 4000K

Lumen Output Cool White – 2800 Lm

Warm White – 2800 Lm

Beam Angle 120°

Power

Cut Hole

240V AC

214 x 120 mm

Gentech Lighting

LED RECESSED

7

LED RECESSED

8

LED-134-R LED 20W Dimmable Round

20W LED downlight. Dimmable with Leading Edge dimmer. Available in Cool White and Warm White.

Complete with LED driver flex and plug. Total power consumption 20W (±10%)

Material Aluminium

Size

Colour

Lamp

110 (Diameter) x 85 (Height) mm

Black, Silver, White

1 x 20W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 1100 Lm

Warm White – 950 Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

90mm

LED-137-R LED 20W Dimmable

Round Gimble

Adjustable 20W LED downlight. Dimmable with Leading

Edge dimmer. Available in Cool White and Warm White.

Complete with 700mA LED driver flex and plug. Total power consumption 20W (±10%)

Material Aluminium

Size

Colour

Lamp

110 (Diameter) x 85 (Height) mm

Silver, White

1 x 20W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 1100Lm

Warm White – 950Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

90mm

LED-138-S LED 20W Dimmable Square

20W LED downlight. Dimmable with Leading Edge dimmer. Available in Cool White and Warm White.

Complete with LEDdriver flex and plug. Total power consumption 20W (±10%)

Material Aluminium

Size 95 x 95 x 80 (Height) mm

Colour Silver, White

Lamp 1 x 20W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 1100 Lm

Warm White – 950 Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

80 x 80mm

Gentech Lighting

LED-139-R LED 13W Dimmable Round

13W LED downlight. Dimmable with Leading Edge dimmer. Features120° beam angle. Available in Cool

White or Warm White. Complete with driver flex and plug. Total power consumption 13W (±10%)

Material Aluminium

Size 95 X 80 (Height) mm

Colour White

Lamp 1 x 13W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 650 Lm

Warm White – 570 Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

70mm

LED-140-R LED 13W Dimmable

Round Gimble

Adjustable 13W LED downlight. Dimmable with Leading

Edge dimmer. Available in Cool White and Warm White.

Complete with LED driver flex and plug. Total power consumption 13W (±10%)

Material Aluminium

Size

Colour

Lamp

80 (Diameter) x 75 (Height) mm

Silver, White

1 x 13W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 650Lm

Warm White – 570Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

70mm

LED-141-R LED 16W Dimmable Round

16W LED downlight. Dimmable with Leading Edge dimmer. Available in Cool White and Warm White.

Complete with 700mA LED driver and optional flex and plug. Total power consumption 16W (±10%)

Material Aluminium

Size 110 (Diameter) x 50 (Height) mm

Colour White, Natural Brushed Chrome

Lamp 16W Osram LED

Led Colour Cool White – 6000K

Warm White – 3000K

Lumen Output Cool White – 820Lm

Warm White –700Lm

Beam Angle 120°

Power

Cut Hole

Input: 220-240V~ 50/60Hz

90mm

Gentech Lighting

LED RECESSED

9

LED RECESSED

10

LED112 LED Fixed Downlight

LED fixed downlight with driver. Features prismatic glass lens and 140 degree beam angle. Driver is included.

Available in warm white light colour.

IES File available on request

Material Diecast Aluminium

Size 110 (Diameter) x 70 (Depth) mm

Colour White

Lamp 12W SMD LED

Led Colour Warm White – 3000K

Lumen Output 834Lm

Beam Angle 120°

Power

IP Rating

Cut Hole

700mA Constant Current

IP40

90mm

LED108 Led 3x3W Down Light

3 x 3W LED Recessed fixed down light.

Features Cree LEDs and 35mm lead.

Available in warm white and cool white.

Material

Size

Cast Alloy

82 (Diameter) x 85 (Depth) mm

Colour

Lamp

Two-tone White

3 x 3W Cree LED

Led Colour Cool White – 6000K

Warm White – 3000K

Power

Cut Hole

700mA Constant Current

75mm

LED109 Led 3x3W Adjustable Downlight

3 x 3W LED Recessed adjustable down light.

Features Cree LEDs and 35cm lead.

Available in warm white and cool white.

Material

Size

Cast Alloy

88 (Diameter) x 56 (Depth) mm

Colour

Lamp

Two-tone White

3 x 3W Cree LED

Led Colour Cool White – 6000K

Warm White – 3000K

Power

Cut Hole

700mA Constant Current

70mm

Gentech Lighting

LED-305 LED Bathroom Baffle Downlight

3x3W LED recessed baffle downlight. Recessed frost acrylic diffuser offers a soft uniform light. Fitting has 45cm lead and connector. IES File available on request

Material

Size

Diecast Aluminium

95 (Diameter) x 85 (Height) mm

Colour

Lamp

Silver, White

3 x 3W LED

Led Colour Warm White – 3000K

Lumen Output 260 Lm

Power

IP Rating

Cut Hole

700mA Constant Current

IP44

82mm

LED-306 LED 10.8W Wet Areas

Downlight

LED 9 x 1.2W downlight suitable for wet areas.

Features recessed opal diffuser 40 degree cut-off angle and 45cm lead with connector.

Material

Size

Diecast Aluminium

125 (Diameter) x 100 (Height) mm

Colour White

Lamp LED 9 x 1.2W

Led Colour Warm White – 3000K

Beam Angle 40°

Power

IP Rating

Cut Hole

350mA Constant Current

IP44

105mm

LED-307 LED 14.4W Wet Areas

Downlight

LED 12 x 1.2W downlight suitable for wet areas.

Features recessed opal diffuser 40 degree cut-off angle and 45cm lead with connector.

Material

Size

Diecast Aluminium

164 (Diameter) x 135 (Height) mm

Colour White

Lamp LED 12 x 1.2W

Led Colour Warm White – 3000K

Lumen Output 520 Lm

Beam Angle 40°

Power 350mA Constant Current

IP Rating

Cut Hole

IP44

128mm

Gentech Lighting

LED RECESSED

11

LED RECESSED

12

LED-308 LED 18W Wet Areas Downlight

LED 15 x 1.2W downlight suitable for wet areas.

Features recessed opal diffuser 40 degree cut-off angle and 45cm lead with connector.

Material Diecast Aluminium

Size 187 (Diameter) x 144 (Height) mm

Colour White

Lamp LED 15 x 1.2W

Led Colour Warm White – 3000K

Lumen Output 880 Lm

Beam Angle 40°

Power

IP Rating

Cut Hole

350mA Constant Current

IP44

150mm

LED124 LED 4.8W Square Commercial

Downlight

LED 4 x 1.2W Square Downlight with diecast aluminium mounting frame. Features safety glass and in-built 350mA

Driver. 240V input connection for easy installation.

Material Die-cast aluminium mounting frame, powder coated steel housing, Tempered glass lens

Size 115 x 115 x 105 (Depth) mm

Colour White

Lamp LED 4 x 1.2W Osram LED

Led Colour Warm White – 3000K

Power Input: 220-240V~ 50/60Hz

Cut Hole 99 x 99mm

LED128 LED 9.6W Square Commercial

Downlight

LED 8 x 1.2W Square Downlight. Features dicast aluminium mounting frame safety glass and in-built

350mA Driver. 240V input connection for easy installation.

Material Die-cast aluminium mounting frame, powder coated steel housing, Tempered glass lens

Size 145 X 145 x 120 (Depth) mm

Colour White

Lamp LED 8 X 1.2W Osram LED

Led Colour Warm White – 3000K

Power

Cut Hole

Input: 220-240V~ 50/60Hz

130 x 130mm

Gentech Lighting

LED103 Doti

1x1W LED recessed mini marker light. Fitting has 50cm lead and quick connector.

Material Anodised Aluminium.

Size

Colour

22 (Diameter) x 30 (Height) mm

Anodised Aluminium

Lamp 1W LED

Led Colour Warm White – 3000K

Power

IP Rating

Cut Hole

350mA Constant Current

IP65

19mm

G801N-LED-10W-WW

150mm 10W LED

With G801N Conversion Plate

Input Power 350mA Constant Current

G800N-LED-10W-WW

200mm 10W LED

With G800N Conversion Plate

Input Power 350mA Constant Current

G802-LED-10W-WW

230mm 10W LED

With G802 Conversion Plate

Input Power 350mA Constant Current

LED RECESSED

Gentech Lighting

13

LED SEMI-RECESSED

14

LED101 White Diamond

1x1W LED semi recessed decorative sparkler. Fitting has

50cm lead and connector.

Material

Size

Anodised Aluminium

30 (Diameter) x 60 (Depth)

30 (Profile) mm

Colour

Lamp

Led Colour Cool White, Warm White

Power 350mA Constant Current

IP Rating

Cut Hole

Anodised Aluminium

1W LED

IP67

19mm

LED102 Crystal

1x1W LED semi recessed decorative sparkler. Fitting has

30cm lead and quick connector.

Material

Size

Anodised Aluminium

50 (Diameter) x 57 Depth) x

33 (Profile) mm

Colour

Lamp

Led Colour Warm White

Power 350mA Constant Current

IP Rating

Cut Hole

Anodised Aluminium

1W LED

IP67

38mm

LED304 Zip

1x1W LED semi-recessed decorative marker. Features anodised aluminium trim, frost disc centre and has 29cm lead with quick connector.

Material

Size

Anodised Aluminium trim, Frosted clear acrylic disc lens

45 (Diameter) x 33 (Depth) x

13 (Profile) mm

Colour

Lamp

Led Colour Blue, Warm White

Power 350mA Constant Current

IP Rating

Cut Hole

Anodised Aluminium

1W LED

IP23

37mm

Gentech Lighting

LED335 Micro LED Light

1X1W LED slimline profile surface mount shelf light.

Fitting has 90cm lead and connector. Available in warm white light colour. Requires 350mA driver

Material Aluminium

Size 33 (Diameter) x 13 (Height) mm

Colour Aluminium

Lamp 1W LED

Led Colour Warm White

Lumen Output 80 Lm

Power

IP Rating

350mA Constant Current

IP41

LED336 Mini LED Light

3x1W LED slimline profile surface mount shelf light.

Fitting has 90 cm lead and connector. Available in warm white light colour. Requires 350mA driver

Material Aluminium

Size 70 (Diameter) x 14 (Height) mm

Colour Aluminium

Lamp 3 x 1W LED

Led Colour Warm White

Lumen Output 180 Lm

Power 350mA Constant Current

IP Rating IP41

LED338 Treble LED Downlight

3x3W LED Cube surface mount downlight. Features 60 degree lens and in-built 9W/700mA driver. 240V input for easy connection.

Material

Size

Aluminium housing, Poly carbonate lens

75 x 75 x 55 (Height) mm

Colour Aluminium

Lamp 3 x 3W LED

Led Colour Cool White, Warm White

Beam Angle 60°

Power Input: 220-240V~ 50/60Hz

IP Rating IP54

G821-LED-700MA

Surface Mount LED Gimble 700mA

Surface mount LED gimble. Features inbuilt dimmable

700mA LED driver. Suitable LED lamps available.

Material

Size

Aluminium, Steel

135 (Diameter) x 122 (Height) mm

Colour

Lamp

Power

Output

Black, White

Max. 11W LED MR16

Input: 220-240V AC ~ 50/60Hz

14-16V 11W Max. 700mA Constant

Current

Gentech Lighting

LED SURFACE MOUNT

15

DICHROIC RECESSED

16

G3111 Twist Cap Single Gyro

European design gyro ring with swivel and tilt adjustment.

Enclosed back

Material Aluminium steel

90

Size

Colour

Lamp

Power

Cut Hole

108 (Length) x

108 (Width) x

90 (Height) mm

108

Grey, White

95 mm x 95 mm

90

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90

108

108

90

G3112 Twist Cap Dual Gyro Rectangular

European design gyro ring with swivel and tilt adjustment.

Enclosed back

Material Aluminium steel

90

90

108

202

Size

Colour

Lamp

Power

Cut Hole

202 (Length) x

108 (Width) x

90 (Height) mm

108

108

Grey, White

202

Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

108

108

184 x 92 mm

108

90

90

Enclosed back

Material

Size

Colour

Lamp

Power

Cut Hole

202

Aluminium steel

296 (Length) x

108 (Width) x

90 (Height) mm

90

90

108

202

296

Grey, White

90

Max 3 x 12V 50W MR16 Dichroic

Optional LED lamps available

202

202

12V AC

296

285 x 92 mm

90

202

European design gyro ring with swivel and tilt adjustment.

Enclosed back

90

202

Material Aluminium steel

Size 202 (Length) x 202

(Width) x

90 (Height) mm

202

Colour Grey

Lamp

202

Max 4 x 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

190 x 190 mm

Gentech Lighting

G3131 Twist Cap Single Gyro Square

New design die-cast aluminium fitting with gyro ring with swivel and tilt adjustment. Features bevelled trim black twist baffle with lamp positioned back for low glare.

Material

Size

Colour

Lamp

Aluminium, steel

115 (Length) x 115 (Width) x

128 (Height) mm

Ash White

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

100 x 100 mm

G3132 Twist Cap Dual Gyro Square

New design die-cast aluminium fitting with gyro ring with swivel and tilt adjustment. Features bevelled trim black twist baffle with lamp positioned back for low glare.

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

195 (Length) x 115 (Width) x

128 (Height) mm

Ash White

Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

175 x 100 mm

G3133 Twist Cap Triple Gyro Square

New design die-cast aluminium fitting with gyro ring with swivel and tilt adjustment. Features bevelled trim black twist baffle with lamp positioned back for low glare.

Material

Size

Colour

Lamp

Aluminium, steel

275 (Length) x 115 (Width) x

128 (Height) mm

Ash White

Max 3 x 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

255 x 100 mm

G3011 Baffle Single Gyro Square

Single baffle square downlight with swivel and tilt adjustment. Features enclosed back and easy to install mechanical clips

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

100 (Length) x 100 (Width) x

118 (Height) mm

Silver, White

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90 x 90 mm

Gentech Lighting

DICHROIC RECESSED

17

DICHROIC RECESSED

18

G3012 Baffle Dual Gyro Rectangular

Dual baffle rectangular downlight with swivel and tilt adjustment. Features enclosed back and easy to install mechanical clips

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

172 (Length) x 100 (Width) x

118 (Height) mm

Silver, White

Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90 x 158 mm

G3013 Baffle Triple Gyro Rectangular

Triple baffle rectangular downlight with swivel and tilt adjustment. Features enclosed back and easy to install mechanical clips

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

245 (Length) x 100 (Width) x

118 (Height) mm

Silver, White

Max 3 x 12V 35W MR16 Dichroic

Optional LED lamps available

12V AC

90 x 227 mm

G3161 Single Step Square

Two step recessed panel featuring die-cast aluminium frame with swivel and tilt downlight centre inserts.

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

150 (Length) x 150 (Width) x

46 (Height) mm

White, Silver, Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

135 x 135 mm

G3162 Dual Step Rectangular

Two step recessed panel featuring die-cast aluminium frame with swivel and tilt downlight centre inserts.

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, steel

300 (Length) x 150 (Width) x

46 (Height) mm

White, Silver, Chrome

Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

285 x 135 mm

Gentech Lighting

G3163 Triple Step Rectangular

Two step recessed panel featuring die-cast aluminium frame with swivel and tilt downlight centre inserts.

Material Aluminium, steel

Size

Colour

Lamp

Power

Cut Hole

450 (Length) x 150 (Width) x

46 (Height) mm

White, Silver, Chrome

Max 3 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

435 x 135 mm

150

G3164 Quad Step Square

Two step recessed panel featuring die-cast aluminium frame with swivel and tilt downlight centre inserts.

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, steel

300 (Length) x 300 (Width) x

46 (Height) mm

Brass, Silver

Max 4 x 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

285 x 285 mm

150

200

200

360

G753 Wall-Washer Rectangular

Architectural design with easy light beam adjustment.

Lamp recessed depth 42mm

Material Aluminium

Size 180 (Length) x 90 (Height) mm

Colour Grey

Lamp

150

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

170 x 70mm

520

G3152 Dual Lamp Rectangular

Each lamp angle may be adjusted individually. Lamp recessed depth 42mm

Material Aluminium

100

Size 180 (Length) x

90 (Width) x

100 (Height) mm

90

180

Colour Grey

Lamp Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

170 x 70mm

Gentech Lighting

DICHROIC RECESSED

19

DICHROIC RECESSED

FLASH DASH

G3182 Oval Adjustable Dual Downlight

Each lamp angle may be adjusted individually. Lamp recessed depth 42mm

Material Aluminium

Size 166 (Length) x 87 (Width) x

78 (Height) mm

Colour White

Lamp Max 2 x 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

Oval Cut Out, Template provided with fitting

FLASH LV Pre-wired Gimble Kit

Features twist front gimble with SGS Laboratory approved heat can Osram lamp and dimmable 60VA electronic transformer

Material Aluminium

Size

Colour

105 (Diameter) x 90 (Height) mm

White, Natural Brushed Chrome

Lamp

Power

Cut Hole

12V 50W MR16 Dichroic

12V AC

92 mm

DASH LV Pre-Wired Downlight Kit

Features twist front downlight with SGS Laboratory approved heat can Osram lamp and dimmable 60VA

Electronic Transformer

Material Aluminium

Size 82 (Diameter) x 90 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Natural Brushed Chrome

12V 50W MR16 Dichroic

12V AC

70 mm

20

Gentech Lighting

ECO-FLASH Energy Saving LV Pre-Wired

Gimble Kit

Features twist front gimble down light with SGS

Laboratory approved heat can and dimmable 60VA

Electronic Transformer. Available as Premium with Osram

IRC 35W 5000 hour lamp or Standard with IRC 35W

2000 hour lamp

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

105 (Diameter) x 90 (Height) mm

Natural Brushed Chrome, White

12V 35W IRC MR16 Dichroic

12V AC

92 mm

ECO-DASH Energy Saving LV Pre-Wired

Down light Kit

Features twist front fixed down light with SGS

Laboratory approved heat can and dimmable 60VA

Electronic Transformer. Available as Premium with Osram

IRC 35W 5000 hour lamp or Standard with IRC 35W

2000 hour lamp

Material Aluminium

Size 82 (Diameter) x 90 (Height) mm

Colour

Lamp

Natural Brushed Chrome, White

12V 35W IRC MR16 Dichroic

Power

Cut Hole

12V AC

70 mm

ECO-FLASH

G755 Square Baffle Sealed

Architectural design. Pressed steel enclosed back silver grey baffle. Lamp recessed depth 28mm

Material Pressed steel

Size 80 (Length) x 80 (Width) x

65 (Height) mm

Colour Silver

Lamp

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

70 x 70 mm

G756 Round Baffle Square Sealed

Round baffle designed for round cut hole. Features enclosed back and silver baffle. Lamp recessed depth

28mm

Material Aluminium

Size 100 (Length) x 100 (Width) x

60 (Height) mm

Colour Silver

Lamp

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90 mm

Gentech Lighting

DICHROIC RECESSED

ECO-DASH

21

DICHROIC RECESSED

22

G757 Square Baffle

Architectural design with slim square trim. Pressed steel.

Black baffle. Adjustable lamp angle. Lamp recessed depth

28 mm

Material

Size

Aluminium pressed steel

90 (Length) x 90 (Width) x

98 (Height) mm

Colour

Lamp

Power

Cut Hole

Grey with Black Baffle

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

76 x 76 mm

G758-CAN Round Baffle Square Twist Cap

Round baffle designed for round cut hole. Pressed steel twist cap down light. Adjustable lamp angle. Lamp recessed depth 20mm. Also available as an open back option.

Material

Size

Colour

Lamp

Aluminium pressed steel

100 (Length) x 100 (Width) x

96 (Height) mm

Silver-Black, White-Black

Power

Cut Hole

Max: 12V 50W MR16

Optional LED lamps available

12V AC

90 mm

G759 Round Baffle Square

Round baffle designed for round cut hole. Pressed steel adjustable lamp angle. Lamp recessed depth 20mm.

Heat Shield options available.

Material

Size

Aluminium pressed steel

100 (Length) x 100 (Width) x

65(Height) mm

Colour

Lamp

Power

Cut Hole

Silver Trim/Black Baffle, White Trim/White

Baffle, White Trim/Black Baffle

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90 mm

G774-S Square Glass Downlight 12V IP44

Square recessed low voltage downlight with Pre-Mount for wet or steamy areas. Features tempered glass lens deep anti-glare baffle and pull front face for lamp replacement.

Material

Size

Aluminium glass lens

85 (Length) x 85 (Width) mm

Colour

Lamp

Silver, White

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP44 (Under ceiling)

78 mm

Gentech Lighting

G774-R Round Glass Downlight 12V IP44

Round recessed low voltage downlight with Pre-Mount for wet or steamy areas. Features tempered glass frosted lens deep anti-glare baffle and pull front face for lamp replacement.

Material Aluminium, glass lens

Size 84 (Diameter) mm

Colour White

Lamp Max. 12V 50W MR16 Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP 44

66 mm

G764 Round Pin Hole Downlight with

Flange

Features outer flange for easy removal of front for lamp replacement. Lamp recessed depth 12mm. Heat Shield options available.

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

100 (Diameter) x 53 (Height) mm

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

88 mm

G764S Square Pin Hole Downlight with Flange

Features outer flange for easy removal of front for lamp replacement. Lamp recessed depth 12mm

Material Aluminium

100 (Diameter) x 53 (Height) mm Size

Colour

Lamp

Power

Cut Hole

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

88 mm

G765 Round Slot Downlight with Flange

Features outer flange for easy removal of front for lamp replacement. Lamp recessed depth 12mm. Heat Shield options available.

Material Aluminium

Size

Colour

Lamp

100 (Diameter) x 53 (Height) mm

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

88 mm

Gentech Lighting

DICHROIC RECESSED

23

DICHROIC RECESSED

24

G765S Square Slot Downlight with Flange

Features outer flange for easy removal of front for lamp replacement. Lamp recessed depth 12mm. Heat Shield options available.

Material Aluminium

Size 100 (Diameter) x 53 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

88 mm

G770N Mini Pin Hole Downlight

Mini pin hole downlight. Features controlled light spread.

To be used with either pre-mount sleeve or heat shield can.

Material Aluminium

Size

Colour

Lamp

86 (Diameter) x 33 (Height) mm

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

73 mm

G770N-CAN-GLS Mini Pin Hole

Downlight with Can + Glass

Mini pin hole downlight with heat shield can and glass.

Features controlled light spread and pull front face for lamp replacement.

Material

Size

Aluminium glass lens

86 (Diameter) x 103 (Height) mm

Colour

Lamp

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP44

73 mm

G771N Mini Slot Downlight

Mini slot downlight. Features controlled light spread. To be used with either pre-mount sleeve or heat shield can.

Material Aluminium steel

Size

Colour

Lamp

86 (Diameter) x 33 (Height) mm

White, Black

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

73 mm

Gentech Lighting

G771N-CAN-GLS Mini Slot Downlight with Can + Glass

Mini slot downlight with heat shield can and glass.

Features controlled light spread and pull front face for lamp replacement.

Material Aluminium, steel, glass lens

Size

Colour

Lamp

Power

IP Rating

Cut Hole

86 (Diameter) x 103 (Height) mm

White, Black

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

IP44

73 mm

G775-SL-ANTWH Deluxe Pin Hole

Downlight

Deluxe mini pin hole downlight with pre-mount. Features recessed lamp for controlled light spread and pull front face for easy lamp replacement.

Material Aluminium

Size 90 (Diameter) x 44 (Height) mm

Colour Antique White, Black

Lamp

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

68 mm

G776-SL-GLS-ANTWH Baffle Downlight with Lens

Baffled downlight. Features recessed lamp for controlled light spread fitted with clear glass lens and pull front face for easy lamp replacement.

Material Aluminium

Size

Colour

Lamp

Power

IP Rating

Cut Hole

90 (Diameter) x 44 (Height) mm

Antique White, Black

Max 12V 50W Dichroic

Optional LED lamps available

12V AC

IP44 Rating below ceiling

68 mm

G778 Deep Baffle Adjustable

Twist cap downlight with centre tilt adjustment. Features textured matt white finish and floating lamp holder.

Material Aluminium

Size 90 (Diameter) x 58 (Height) mm

Colour

Lamp

Power

Textured Matt White

Max. 12V 50W Dichroic

Optional LED lamps available

12V AC

Cut Hole 82 mm

Gentech Lighting

DICHROIC RECESSED

25

DICHROIC RECESSED

26

G833 Slide Baffle

Lamp position is adjustable inside the baffle. Suitable where matching optimum light output and glare reduction.

Material Aluminium

Size 80 (Diameter) x 72 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

70 mm

G835N Deep Baffle

Unwanted glare is cut yet the light spread maintained intact. Available in multifaceted, or plain reflector, and black or white baffle. Lamp recessed depth 28mm.

Material Aluminium

Size 105 (Diameter) x 43(Height) mm

Colour White

Lamp Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power 12V AC

Cut Hole 94 mm

G822MR Mini Round Stainless Steel

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material 316 Stainless steel

Size

Colour

82 (Diameter) x 22 (Height) mm

Polished stainless steel Brushed stainless steel

Lamp

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

70 mm

G822MS Mini Square Stainless Steel

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material

Size

Colour

Lamp

Power

Cut Hole

316 Stainless steel

85 x 85 x 22 (Height) mm

Polished stainless steel. Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

70 mm

Gentech Lighting

G822R Round Stainless Steel Downlight

12V MR16

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material

Size

Colour

316 Stainless steel

95 (Diameter) x 22 (Height) mm

Lamp

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

80 mm

G822S Square Stainless Steel Downlight

12V MR16

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material

Size

Colour

316 Stainless steel

95 x 95 x 22 (Height) mm

Lamp

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

80 mm

G823R Round Stainless Steel Downlight

12V Recessed Lamp

316 stainless steel for corrosive areas. Lamp angle adjustable internally for reduced glare. Precision formation with polished or brushed surface. Lamp recessed depth

24mm. Heat Shield options available

Material

Size

Colour

316 Stainless steel

95 (Diameter) x 22 (Height) mm

Lamp

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

80 mm

Gentech Lighting

DICHROIC RECESSED

27

DICHROIC RECESSED

28

G823S Square Stainless Steel Downlight

12V Recessed

316 stainless steel for corrosive areas. Lamp angle adjustable internally for reduced glare. Precision formation with polished or brushed surface. Lamp recessed depth

24mm. Heat Shield options available

Material

Size

Colour

316 Stainless steel

95 x 95 x 22 (Height) mm

Lamp

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

80 mm

G826R Round Adjustable Stainless Steel

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material

Size

Colour

316 Stainless steel

95 (Diameter) x 22 (Height) mm

Lamp

Power

Cut Hole

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

80 mm

G826S Square Adjustable Stainless Steel

316 stainless steel for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps. Heat Shield options available.

Material

Size

Colour

316 Stainless steel

95 x 95 x 22 (Height) mm

Lamp

Polished stainless steel, Brushed stainless steel

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

80 mm

Gentech Lighting

G7521 Fire Rated Twist Cap Down Light

White twist cap fixed downlight featuring double insulated steel cone intumescent material at top of the cone and around trim of the housing. Tested and passed to 90 minute ceiling-floor system in accordance with BS476PT22.

Material Aluminium

Size 80 (Diameter) x 110 (Height) mm

Colour White

Lamp Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

70 mm

G7523 Fire Rated Centre Tilt Down Light

White twist cap centre tilt downlight featuring double insulated steel cone intumescent material at top of cone and around trim of the housing. Tested and passed to 90 minute ceiling-floor system in accordance with BS476PT22.

Material Aluminium

Size 94 (Diameter) x 110 (Height) mm

Colour White

Lamp Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

85 mm

G895 Swivel Snorkel

Periscope wall washer. Features 360 degree rotation and

80 deg. tilt.

Material Aluminium

Size 112 (Diameter) x 75 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Black, Chrome, Brass

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

100 mm

G896 Guided Tilt Swivel Snorkel

Square sided periscope wall washer. Features 360 deg. rotation and 80 deg. tilt.

Material Aluminium

Size 130 (Diameter) x 80 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Black, Chrome, Brass,

Satin Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

100 mm

Gentech Lighting

DICHROIC RECESSED

29

DICHROIC RECESSED

30

G888 Designer Gimble

Australian designed gimble. Features easy grip cap full 360 deg. rotation and 40 deg. tilt. Optional Decorative Glass

Ring, and Heat Shield.

92mm

Material Aluminium

47mm

Size

Colour

Lamp

105 (Diameter) x

47 (Height) mm

105mm

White, Black, Beige, Satin Chrome,

Chrome Brass

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

92 mm

G888C 360 Degree Gimble

Full 360 deg. rotation and 35 deg. tilt gimble with flush twist cap. Heat Shield options available.

Material Aluminium

Size 105 (Diameter) x 47 (Height) mm

Colour White

Lamp

Power

94mm

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

110mm

Cut Hole 92 mm

41mm

G752 Economy Twist Cap

Aluminium die-cast twist cap downlight to compliment

G745.

Material Aluminium

Size 80 (Diameter) x 39 (Height) mm

Colour

Lamp

Brushed Brass, Brushed Chrome, Satin

Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

70 mm

Optional Baffle

G892 Twist Cap Round Downlight

Aluminium die-cast twist cap downlight. Optional

Decorative Glass Ring. Heat Shield options available.

Material Aluminium

Size 82 (Diameter) x 31 (Height) mm

Colour

Lamp

White, Beige, Satin Chrome, Brushed

Chrome, Chrome Brass

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

70 mm

Gentech Lighting

G745N Twist Cap Gimble

Aluminium die-cast twist cap gimble.Heat Shield options available

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

105 (Diameter) x 42 (Height) mm

White, Beige, Brass, Chrome, Satin

Chrome, Brushed Brass, Brushed

Chrome, Natural Brushed Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

92 mm

G836 Twist Cap Centre Tilt

Well balanced mechanical design featuring tight gap between centre and trim. Single arm clip for easy installation. 25 degree tilt. Optional baffle to reduce glare.

Heat Shield options available.

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

96 (Diameter) x 48 (Height) mm

White, Black, Satin, Chrome, Silver,

Brushed Chrome, Chrome, Brass

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

85 mm

Optional Can

G838 Gimble

Classic original face clip-on design gimble with floating lampholder plus improved clip mechanism. Heat Shield options available.

Material Aluminium

Size 105 (Diameter) x 55 (Height) mm

Colour White, Satin Chrome, Brushed Chrome,

Chrome, Brass, Brushed Aluminium

Lamp

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

94 mm

G632 Adjustable Downlight 12V MR16

Swivel & tilt adjustable downlight. Featuring pre-mount device. Optional heat can available. (CAN-90D1)

Material Aluminium

Size 102 (Diameter) x 44 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Brushed Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

85 mm

Gentech Lighting

DICHROIC RECESSED

Optional Baffle

31

DICHROIC RECESSED

32

With Optional Baffle

G839 Twist Cap Square

Aluminium die-cast square downlight featuring twist cap front. Heat Shield options available.

Material Aluminium

Size 82 (Length) x 82 (Width) x

38 (Height) mm

Colour

Lamp

White, Satin Chrome, Brushed Chrome,

Chrome, Brass

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

70 mm

G825 Square Centre Tilt

Well balanced mechanical design featuring tight gap between centre and trim. 25 degree tilt angle. Optional baffle to reduce glare.

Material Aluminium

Size 95 (Length) x 95 (Width) x

45 (Height) mm

Colour

Lamp

Power

Cut Hole

Satin Chrome, Brushed Chrome

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

80 x 80 mm

G827 Square Centre Tilt Round Cut Hole

Square trim complete with mechanical square centre for adjusting lamp position to 35 degree.

Material Aluminium

Size 118 (Length) x 118 (Width) x

50 (Height) mm

Colour

Lamp

Power

Cut Hole

White, Silver

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

105 mm

G828 Square Tilt Round Cut Hole

Square trim complete with mechanical round centre for adjusting lamp position to 35 degree. Heat Shield options available

Material Aluminium

Size 102 (Length) x 102 (Width) x

40 (Height) mm

Colour

Lamp

Power

Cut Hole

Brushed Aluminium, White

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

90 mm

Gentech Lighting

G808 Downlight for Wet Area Square

Aluminium cast body and trim. Features enclosed back twist front trim with silicon rubber seal and round cut-out.

Material

Size

Colour

Lamp

Aluminium glass lens

100 (Length) x 100 (Width) x

105 (Height) mm

White, Silver

Max 12V 50W MR16 Dichroic or

50W G4 Halogen

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP53

75 mm

100mm

25mm

G806 Downlight for Wet Area Round

Aluminium cast body and trim. Twist front with silicon rubber seal.

112mm

100mm

Aluminium glass lens

25mm

Material

Size

Colour

Lamp

Power

IP Rating

Cut Hole

White, Silver

Max 12V 50W MR16 Dichroic or 50W

G4 Halogen

Optional LED lamps available

100mm

70mm

12V AC

63mm

IP53

75 mm

70mm

G898 Floating Ring

63mm which will not dislodge with heavy vibration. Ideal for vehicles and vessels.

68mm

Material Aluminium

31mm

Size 80 (Diameter) x

30 (Height) mm

80mm

Colour

Lamp

31mm

Power

Cut Hole

Max 12V 50W MR16 Dichroic

Optional LED lamps available

80mm

12V AC

70 mm

78mm

G899 Trio Ring

33mm

Material Aluminium

Size

Colour

90 (Diameter) x

31 (Height) mm

White, Black,

Satin Chrome, Chrome

Lamp

Power

Cut Hole

78mm

90mm

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

80 mm

33mm

Gentech Lighting

DICHROIC RECESSED

33

DICHROIC RECESSED

34

G7541N CNC Aluminium Cut Round

Low voltage downlight with two/tone pull front centre for lamp replacement. Lamp positioned back in housing to reduced glare. Heat Shield options available.

Material

Size

CNC Aluminium

93 (Diameter) x 23 (Height) mm

Colour

Lamp

Power

Brushed Aluminium

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

Cut Hole 75 mm

G7542N CNC Aluminium Cut Square

Low voltage downlight with two/tone pull front centre for lamp replacement. Lamp positioned back in housing to reduced glare. Heat Shield options available.

Material

Size

Colour

Lamp

Power

Cut Hole

CNC Aluminium

93 (Length) x 93 (Width) x

23 (Height) mm

Brushed Aluminium

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

75 mm

G7543N CNC Aluminium Cut Round

Adjustable

Swivel and centre tilt two/tone low voltage downlight with pull front centre for lamp replacement. Lamp positioned back in fitting to reduce glare. Heat Shield options available.

Material CNC Aluminium

Size

Colour

Lamp

Power

Cut Hole

93 (Diameter) x 23 (Height) mm

Brushed Aluminium

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

75 mm

G7544N CNC Aluminium Cut Square

Adjustable

Swivel and centre tilt two/tone low voltage downlight with pull front centre for lamp replacement. Lamp positioned back in fitting to reduce glare. Heat Shield options available.

Material

Size

Colour

Lamp

Power

Cut Hole

CNC Aluminium

93 (Length) x 93 (Width) x

23 (Height) mm

Brushed Aluminium

Max 12V 50W MR16 Dichroic

Optional LED lamps available

12V AC

75 mm

Gentech Lighting

DICHROIC RECESSED

G7535 CNC Aluminium Cut MR11 Round

Compact round recessed mini downlight with centre tilt adjustment. Lamp positioned back in housing to reduce glare. Features pull front centre for lamp replacement.

Material

Size

CNC Aluminium

65 (Diameter) x 18 (Height) mm

Colour

Lamp

Power

Cut Hole

Brushed Aluminium

Max 12V 35W MR11 Dichroic

Optional LED lamps available

12V AC

57 mm

G7536 CNC Aluminium Cut MR11 Square

Compact square recessed mini downlight with centre tilt adjustment. Lamp positioned back in housing to reduce glare.

Features two/tone pull front centre for lamp replacement.

Material

Size

Colour

Lamp

CNC Aluminium

65 (Length) x 65 (Width) x

18 (Height) mm

Brushed Aluminium

Max 12V 35W MR11 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

57 mm

G820 Square Dropped Glass

Fashionable dropped glass downlight featuring deep anti-glare baffle with decorative glass.

Material

Size

Pressed steel, glass lens

100 x 100 x 70 (Height) mm

Colour Silver

Lamp Max. 12V/50W Dichroic

Optional LED lamps available

Power

Cut Hole

12V a.c.

90 mm

G881 Perspective

Decorative frost glass trim downlight.

Material Pressed steel glass

Size

Colour

Lamp

100 (Diameter) x 52 (Height) mm

Frost Blue

Max 12V 50W MR16 Dichroic

Optional LED lamps available

Power

Cut Hole

12V AC

70 mm

Gentech Lighting

DICHROIC SEMI-RECESSED

35

DICHROIC SEMI-RECESSED

G883 Dropped Glass

Fashionable dropped glass downlight featuring deep anti-glare baffle and front glass diffuser.

Material Pressed steel, glass lens

Size 110 (Diameter) x 45 (Height) mm

Colour White

Lamp

Power

Cut Hole

Max. 12V/50W Dichroic

Optional LED lamps available

12V AC

94 mm

DICHROIC SURFACE MOUNT

36

G821 Surface Mount Gimble

Surface mount gimble comes with optional inbuilt transformer.

Material

Size

Colour

Lamp

Power

Aluminium, steel

135 (Diameter) x

122 (Height) mm

White, Black

Max. 12V/50W Dichroic

Optional LED lamps available

12V AC

122

135

G851 MR16 35W Surface Mount Push in Gyro Square

MR16-1 x 35W Aluminium surface mount gyro down light. Features round wire lamp retainer clip and in built transformer.

Optional LED version

Material CNC Aluminium

Size 100 x 100 x 136 (Height) mm

Colour Aluminium

Lamp

Power

MR16. 35W Max

Optional LED lamps available

12V AC

G852 MR16 2x35W Surface Mount Push in Dual Gyro Square

MR16-2 x 35W Aluminium surface mount gyro down light. Features round wire lamp retainer clips and in built transformer.

Optional LED version

Material

Size

CNC Aluminium

188 x 100 x 136 (Height) mm

Colour Aluminium

Lamp MR16. 2 x 35W Max

Optional LED lamps available

Power 12V AC

Gentech Lighting

70mm

100mm

94mm

G781 Diffused Perspective

Compact glass downlight with enclosed back and twist face for easy lamp replacement.

110mm

45mm

Material Pressed steel, glass lens

Size

Colour

Lamp

Power

Cut Hole

100 (Diameter) x 45 (Height) mm

Blue, Frost

Max. 12V/35W Bi-Pin Burner

94mm

Optional LED lamps available

12V AC

70 mm

110mm

72mm

23mm

G885 Glass Dome

Glass dome downlight suitable for wet areas. Features thick frost dome glass diffuser silicon rubber seal and enclosed back.

47mm

Material Pressed steel, glass lens

Size 110 (Diameter) x

41 (Height) mm

94mm

105mm

41mm

Colour

Lamp

Power

IP Rating

White, Chrome, Brass

Max. 12V/50W Bi-Pin

Optional LED lamps available

12V AC

IP53

110mm

Cut Hole 94 mm

G891N Stepped Glass Downlight

Stepped glass downlight suitable for wet areas. Features thick frost stepped glass silicon rubber seal and enclosed back.

Material

Size

Colour

Lamp

Power

Pressed steel, glass lens

110 (Diameter) x

41 (Height) mm

White, Chrome, Brass

Max. 12V/50W Bi-Pin

Optional LED lamps available

12V AC

94mm

110mm

41mm

IP Rating

Cut Hole

IP53

94 mm

G4 HALOGEN RECESSED

Gentech Lighting

37

AR111 RECESSED

38

G3171 Single Gang Square

Steel frame featuring twist and tilt gyro downlight inserts.

Enclosed back.

Material Aluminium

105

Size 207 x 207 x

105 (Height) mm

Colour Grey

207

Lamp AR111 G53

Optional LED lamps available

105

207

Power

Cut Hole

12V AC

180 x 180 mm

207

105

207

Pre-mount box

Enclosed back.

Material Aluminium

Size 207 x 355 x

105 (Height) mm

Colour Grey

Lamp

Power

Cut Hole

2xAR111 G53

Optional LED lamps available

12V AC

180 x 330 mm

105

207

105

105

207

207

105

G3173 Triple Gang Rectangular

Enclosed back.

Material Aluminium

Size 500 x 207 x

105 (Height) mm

Colour Grey

Lamp

Power

Cut Hole

3xAR111 G53

Optional LED lamps available

12V AC

180 x 457 mm

105

207

355

355

500

500

500

G3191-ALU Single Trimless AR111

Solid CNC aluminium trim less single downlight. Features twist and tilt gyro downlight insert in a plaster board mounting box.

Material CNC Aluminium

Size 195 x 195 x 175 (Depth) mm

Colour Aluminium

Lamp Max. 1 x 75W AR111

Optional LED Lamps available

Power

Cut Hole

12V AC

195 x 195 mm

Gentech Lighting

AR111 RECESSED

G3192-ALU Dual Trimless AR111

Solid CNC aluminium trim less dual downlight. Features twist and tilt gyro downlight insert and plaster board mounting box.

Material CNC Aluminium

Size 380 x 195 x 175 (Depth) mm

Colour Aluminium

Lamp Max. 2 x 75W AR111

Optional LED Lamps available

Power

Cut Hole

12V AC

380 x 195 mm

G730 Dual Ring

Twist and tilt gyro vented fitting with 30 degree tilt

Material Aluminium

Size 187 (Diameter) x 105 (Height) mm

Colour White

Lamp AR111 G53

Optional LED lamps available

Power

Cut Hole

12V AC

167 mm

GU3111 Twist Cap Single Gyro GU10

European design gyro ring with swivel and tilt adjustment.

Enclosed back

Material Aluminium

Size 108 (Length) x 108 (Width) x

145 (Depth) mm

Colour

Lamp

Power

Cut Hole

Grey, White

GU10 / GZ10 50W Max.

Optional LED lamps available

240V AC 50Hz

95 x 95 mm

GU3112 Twist Cap Dual Gyro GU10

European design gyro rings with swivel and tilt adjustment. Enclosed back

Material Aluminium

Size 202 (Length) x 108 (Width) x

145 (Depth) mm

Colour

Lamp

Power

Cut Hole

Grey, White

GU10 / GZ10 2 x 50W Max.

Optional LED lamps available

240V AC 50Hz

184 x 95 mm

Gentech Lighting

GU10-GZ10 RECESSED

39

GU10-GZ10 RECESSED

40

GU3113 Twist Cap Triple Gyro GU10

European design gyro rings with swivel and tilt adjustment. Enclosed back

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

296 (Length) x 108 (Width) x

145 (Depth) mm

Grey, White

GU10 / GZ10 3 x 50W Max.

Optional LED lamps available

240V AC 50Hz

285 x 95 mm

GU622R Round Stainless Steel Downlight

240V GU10

316 stainless steel downlight for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps.

Material 316 Stainless steel

Size

Colour

Lamp

Power

Cut Hole

94 (Diameter) x 125 (Height) mm

Stainless steel

GU10 / GZ10 CFL

Optional LED lamps available

240V AC 50Hz

80 mm

GU622S Square Stainless Steel Downlight

240V GU10

316 stainless steel downlight for corrosive areas. Precision formation with polished or brushed surface. Optional glass lens may be added to stop water affecting lamps or simply use glass front lamps.

Material

Size

Colour

316 Stainless steel

96 (Length) x 96 (Width) x

125 (Height) mm

Stainless steel

Lamp

Power

Cut Hole

GU10 / GZ10 CFL

Optional LED lamps available

240V AC 50Hz

80 mm

GU759 Round Baffle Square GU10

Downlight

Round baffle designed for round cut hole. Pressed steel with adjustable lamp angle.

Material

Size

Colour

Lamp

Power

Cut Hole

Pressed steel

100 (Length) x 100 (Width) x 83

(Height) mm

Silver Trim/Black Baffle, white

GU10 / GU10 CFL

Optional LED lamps available

240V AC 50Hz

90 mm

Gentech Lighting

GU836

Centre Tilt Round

Energy saver well balanced mechanical design featuring tight gap between centre and trim. Single arm clip for easy installation. 25 degree tilt. Heat Shield option available

Material Aluminium

Size

Colour

Lamp

94 (Diameter) x 84 (Height) mm

White, Natural Brushed Chrome

GU10 / GU10 CFL

Optional LED lamps available

Power

Cut Hole

240V AC 50Hz

85 mm

GU-7521

Fire Rated Twist Cap Down Light GU10

White twist cap fixed downlight featuring double insulated steel cone, intumescent material at top of the cone and around trim of the housing. Tested and passed to 90 minute ceiling-floor system in accordance with

BS476PT21.

Material Aluminium

Size 86 (Diameter) x 115mm (Height)

Colour White

Lamp Max.240V 50W GU10 GZ10

Optional LED lamps available

Power

Cut Hole

240V AC

70 mm

GU-7523

Fire Rated Centre Tilt Down Light GU10

White twist cap centre tilt downlight featuring double insulated steel cone, intumescent material at top of the cone and around trim of the housing. Tested and passed to 90 minute ceiling-floor system in accordance with

BS476PT21.

Material Aluminium

Size 96 (Diameter) x 115mm (Height)

Colour White

Lamp Max.240V 50W GU10 GZ10

Optional LED lamps available

Power

Cut Hole

240V AC

85 mm

Gentech Lighting

GU10-GZ10 RECESSED

41

GU10-GZ10 RECESSED

GU838 GU10 Gimbal

Aluminium cast housing. Tilt adjustable. Large looping terminal block. Heat Shield option available

Material Aluminium

Size

Colour

Lamp

Power

Cut hole

104 (Diameter) x 128 (Height) mm

White, Brushed Chrome, Natural

Brushed Chrome

Max. GU10 GZ10 240V 50W halogen

Optional LED lamps available

240V AC 50Hz

94mm

GU892 Twist Cap Round

Aluminium cast housing. Large looping terminal block.

Heat Shield option available

Material Aluminium

Size 80 (Diameter) x 108 (Height) 83 mm

Colour

Lamp

Power

Cut Hole

White, Brass

Max. GU10 GZ10 50W 240V halogen

Optional LED lamps available

240V AC 50Hz

70mm

GU632 Adjustable Downlight

Swivel & tilt adjustable. Featuring pre-mount device.

Material Aluminium

Size

Colour

Lamp

Power

Cut Hole

102 (Diameter) x 87 (Height) mm

White, Brushed Chrome

Max. GU10 GZ10 50W 240V halogen

Optional LED lamps available

240V AC 50Hz

85mm

GU10-GZ10 SURFACE MOUNT

42

GU635 Cube Metal

Cube surface mount downlight. Features side mount screw access for lamp replacement.

Material Aluminium

Size 80 (Length) x 80 (Width) x

86 (Height) mm

86

80

Colour

Lamp

Power

Silver, white

GU10 35W Max Halogen or LED

Optional LED lamps available

240V AC 50Hz

Gentech Lighting

GU10-GZ10 SURFACE MOUNT

GU635L Cuboid Metal

Longer version of the popular Cube surface mount downlight, allows for longer versions of GU10 LED lamps.

Features side mount screw access for lamp replacement.

Material Aluminium

Size

Colour

Lamp

Power

80 (Length) x 80 (Width) x

110 (Height) mm

Silver, white , black

GU10 35W Max Halogen or LED

Optional LED lamps available

240V AC 50Hz

110

80

GU640 GU10 Surface Mount Cube

Down Light

GU10 1 x 35W Aluminium compact surface mounted down light. Pull front face for easy lamp replacement.

Material Aluminium

Size 82 (Length) x 82 (Width) x

94 (Height) mm

Colour Aluminium

Lamp GU10 35W Max Halogen or LED

Optional LED lamps available

Power 240V AC 50Hz

G103NR Round Glass Vertical Downlight

Compact 240V down light. Features twist front trim with frost glass. E27 ceramic lamp holder with adjustable lamp holder position to suit various lamp sizes

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, pressed steel

120 (Diameter) x 160 mm (adjustable)

Satin Nickel, White

Max. 240V/60W ES or 18W Energy

Saver

240V AC 50Hz

100 mm

G105 Round Glass Horizontal Downlight

Compact 240V down light. Features twist front trim with frost glass. E27 ceramic lamp holder with adjustable lamp holder position to suit various lamp sizes

Material Aluminium, pressed steel

Size

Colour

Lamp

152 (Diameter) x 130 mm (adjustable)

Satin Nickel, White

Max. 240V/75W ES or 18W Energy

Saver

Power

Cut Hole

240V AC 50Hz

138 mm

Gentech Lighting

FLUORESCENT RECESSED

43

FLUORESCENT RECESSED

44

G104P Multi Facet PL-PLC Downlight

Commercial downlight with satin edge for low glare.

ATCO iron-core ballast or optional electronic ballast available.

Material Aluminium, pressed steel

Size

Colour

Lamp

Power

Cut Hole

135 (Diameter) x

243 (Height) mm

White Trim/Multi

Facet Reflector

9W PL 10W/13W or 18W PLC

240V AC 50Hz

110 mm

1m

1m

2m

2m

G104P/13W

G104P/13W

310-40Lux

310-40Lux

2.2m

2.7m

2.7m

3m

3m

4m

4m

3.8m

3.8m

G106P Multi Facet PLC Downlight

Commercial downlight with satin edge for low glare.

Material Aluminium, pressed steel

Size 173 (Diameter) x

250 (Height) mm

G106P/18W

G106P/18W

Colour

Lamp

Power

Cut Hole

White Trim/Multi

Facet Reflector

13W/18W PLC

240V AC 50Hz

150 mm

1m

1m

2m

2m

3m

3m

4m

4m

750-40Lux

750-40Lux

180-25

3.3m

80-15

4.5m

4.5m

G107G Glass Face PLC Downlight

Commercial downlight designed for wet steamy areas.

Features low glare reflector and twist glass front for lamp replacement. ATCO iron-core ballast or optional electronic ballast available

Material

Size

Aluminium, pressed steel, glass lens

195 (Diameter) x 210 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim/Silver Reflector

18W/26W PLC

4-pin for electronic or 2-pin for iron core

240V AC 50Hz

160 mm

1m

2m

3m

G119PC 2x9W PL Downlight with

PC Diffuser

4m

780-140Lux

1.9m

220-90

2.8m

120-35

5.2m

Low profile 2x9W PL downlight with clear or optional opal diffuser. Ideal for wet steamy areas. Complete with

ATCO ironcore ballast

Material

Size

Colour

Lamp

Aluminium, pressed steel, clear or opal acrylic lens

198 (Diameter) x

93 (Height) mm

1m

White Trim

2x9W PL 4-pin for electronic or

2-pin for iron core

2m

3m

4m

360-30Lux

1.8m

100-20

2.4m

45-12

3.4m

Power 240V AC 50Hz

Cut Hole 180 mm

Gentech Lighting

G118P 2x18W PLC Downlight

Commercial 2x18W PLC downlight with ribbed edge for low glare. Complete with ATCO ironcore ballast or optional electronic ballast available.

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, pressed steel

210 (Diameter) x

170 (Height) mm

White Trim/Silver

Reflector

1m

2m

3m

4m

780-140Lux

1.9m

220-90

2.8m

120-35

5.2m

2x18W PLC

4-pin for electronic or 2-pin for iron core

240V AC 50Hz

182 mm

G126P 2x26W PLC Downlight

available on request

1m

360-30Lux

Commercial 2x26W PLC downlight with extra deep reflector for low glare. Complete with ATCO iron-core ballast or optional electronic ballast available. IES File

4m

45-12

3.4m

Material Aluminium, pressed steel

Size 228 (Diameter) x 150 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim/Silver Reflector

2x26W PLC

4-pin for electronic or 2-pin for iron core

240V AC 50Hz

200 mm

G218PG 2x18W PLC Downlight with

Glass Diffuser

Commercial 2x18W PLC downlight with ribbed edge for low glare. Complete with ATCO iron-core ballast or optional electronic ballast available. Features decorative drop glass diffuser.

Material

Size

Aluminium, pressed steel, glass lens

210 (Diameter) x 170 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim

2x18W PLC

4-pin for electronic or 2-pin for iron core

240V AC 50Hz

182 mm

G226PG 2x26W PLC Downlight with

Glass Diffuser

Commercial 2x26W PLC downlight with extra deep reflector for low glare. Complete with ATCO iron-core ballast or optional electronic ballast available. Features decorative drop glass diffuser.

Material

Size

Aluminium, pressed steel, glass lens

228 (Diameter) x 150 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim

2x26W PLC

4-pin for electronic or 2-pin for iron core

240V AC 50Hz

200 mm

Gentech Lighting

FLUORESCENT RECESSED

45

FLUORESCENT RECESSED

46

G129 PLC Downlight Square dropped glass

Square dropped glass PLC downlight. Features decorative frost glass with silver mountings. Options: ATCO ironcore ballast dimmable and non dimmable electronic ballast. IES File available on request

Material

Size

Aluminium, pressed steel, glass lens

250 x 250 x 115 (Height) mm

(260 x 260 mm glass)

Colour White/Frost

Lamp 2x18W/2x26W PLC

4-pin electronic or 2-pin iron-core

Power

Cut Hole

240V AC 50Hz

200 x 200 mm

G121 PLC Downlight Round for wet areas

Commercial PLC downlight designed for wet steamy areas. Features recessed chain attached frost lens.Options:

ATCo iron-core ballast dimmable and non-dimmable electronic ballast

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, pressed steel, glass lens

165 (Diameter) x 110 (Height) mm

White Trim/Chrome Baffle

2x13W PLC

4-pin electronic or 2-pin iron-core

240V AC 50Hz

145 mm

G123N PLC Downlight square for wet areas 163 x 163

Commercial 2x13W/2 x 18W PLC downlight designed for wet steamy areas. Features hinged prismatic glass cover. Options: ATCO iron-core ballast dimmable and non-dimmable electronic ballast.

Material

Size

Aluminium, pressed steel, glass lens

163 x 163 x 85 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim

2x13W/2x18W PLC

4-pin electronic or 2-pin iron-core

240V AC 50Hz

145 x 145 mm

G125 PLC Downlight square for wet areas

202 x 202

Commercial use 2x18/26W PLC downlight designed for wet steamy areas. Fitting has spring loaded frost glass diffuser. Complete with non-dimmable integral electronic ballast.Optional dimmable electronic ballast available. IES

File available on request

Material Aluminium, pressed steel, glass lens

Size

Colour

Lamp

Power

Cut Hole

202 x 202 x 115 (Height) mm

White Trim

2x18W/2x26W PLC

4-pin electronic or 2-pin iron-core

240V AC 50Hz

182 x 182 mm

Gentech Lighting

G132 PLC Downlight deep beehive facet reflector

Round deep aluminium beehive facet reflector. Options:

ATCO iron-core ballast dimmable and non-dimmable electronic ballast. IES File available on request

Material Aluminium, pressed steel,

Size

Colour

Lamp

Power

Cut Hole

225 (Diameter) x 150 (Height) mm

White Trim/Silver Reflector

2x13W/18W/26W PLC

4-pin electronic or 2-pin iron-core

240V AC 50Hz

190 mm

G135 Glass Lens PLC Downlight

Spring locked prismatic glass diffuser. Aluminium cast trim.

Options: ATCO iron-core ballast dimmable and nondimmable electronic ballast. IES File available on request

Material Aluminium, pressed steel, glass lens

Size

Colour

Lamp

Power

Cut Hole

230 (Diameter) x 130 (Height) mm

White Trim/Frost Glass

2x13W/2x18W PLC

4-pin electronic or 2-pin iron-core

240V AC 50Hz

215 mm

G136 Cross Baffle Square PLC Downlight

Spring locked aluminium cast trim. Cross baffle for optimum light output with minimum glare. Options:

ATCO iron-core ballast dimmable and non-dimmable electronic ballast. IES File available on request

Material Aluminium, pressed steel.

Size

Colour

Lamp

225 x 225 x 130 (Height) mm

White Trim/Silver Reflector

2x18W/2x26W PLC

4-pin electronic or 2-pin iron-core

Power

Cut Hole

240V AC 50Hz

210 x 210 mm

G137 Cross Baffle Round PLC Downlight

Cross baffle for optimum light output with minium glare.

Options: ATCO iron-core ballast dimmable and nondimmable electronic ballast. IES File available on request

Material Aluminium, pressed steel.

Size

Colour

225 (Diameter) x 140 (Height)mm

White Trim/Silver Reflector

Lamp 2x13W/2x18W/2x26W

4-pin electronic or 2-pin iron-core

Power

Cut Hole

240V AC 50Hz

200 mm

Gentech Lighting

FLUORESCENT RECESSED

47

FLUORESCENT RECESSED

48

G146-WH PLC High Output Reflector

Recessed Round

Polished baffle for optimum light output. Options: ATCO iron-core ballast dimmable and non-dimmable electronic ballast

Material

Size

Colour

Lamp

Power

Cut Hole

Aluminium, pressed steel.

225 (Diameter) x 140 (Height) mm

White Trim/Polished Silver Reflector

2x13W / 2x18W / 2x26W PLC

4-pin electronic / 2-pin iron-core

240V AC 50Hz

200 mm

G146-WH-AGR PLC Anti Glare Reflector

Recessed Round

Satin baffle for redused glare and optimum light output.

Options: ATCO iron-core ballast dimmable and nondimmable electronic ballast

Material

Size

Aluminium, pressed steel.

225 (Diameter) x 140 (Height) mm

Colour

Lamp

Power

Cut Hole

White Trim/Satin Silver Reflector

2x13W / 2x18W / 2x26W PLC

4-pin electronic / 2-pin iron-core

240V AC 50Hz

200 mm

G142 Glass PLC Downlight

Decorative glass round PLC downlight. Features thick twist lock glass for easy lamp replacement. Options:

ATCO iron-core ballast dimmable and non-dimmable electronic ballast. IES File available on request

Material

Size

Aluminium, pressed steel, glass lens.

220 (Diameter) x 95 (Height) mm

Colour Frost

Lamp 2x18W PLC

4-pin electronic or 2-pin iron-core

Power

Cut Hole

240V AC 50Hz

162 mm

G145 2x26W PLC Wall Washer

Commercial use 2x26W PLC downlight with smooth satin reflector. Options: ATCO iron-core ballast dimmable and non-dimmable electronic ballast.

Material Aluminium, pressed steel.

Size

Colour

Lamp

260 (Diameter) x 250 (Height) mm

White Trim/Silver Reflector

2x26W PLC

4-pin electronic or 2-pin iron-core

Power

Cut Hole

240V AC 50Hz

230 mm

Gentech Lighting

FLUORESCENT RECESSED

G7557 GX53 Fluoro Recessed

Recessed 7-9W shelf or wall light. Features low profile and energy efficient. Lamp not included.

Material Aluminium.

Size 95 (Diameter) mm

Colour White

Lamp Max. 240V/GX53/7-9W

Power

Cut Hole

240V AC 50Hz

83 mm

G138 Cross Baffle PLC Surface Mount

Clear anodised aluminium reflector. Easy access for relamping. Options: ATCO iron-core ballast, dimmable and non-dimmable electronic ballast.

Material Aluminium

Size 180 (Height) x 230 (Diameter) mm

Colour White

Lamp

Power

2x18W PLC (4-pin electronic or 2-pin iron-core)

240V AC 50Hz

G140 PLC Surface Mount

Commercial surface mount PLC downlight features aluminium beehive reflector and twist glass front for lamp replacement. Options: ATCO iron-core ballast, dimmable and non-dimmable electronic ballast.

Material Aluminium

Size 225 (Diameter) x 160 (Height) mm

Colour White

Lamp 1 x 18W/1 x26W, 2x18W/2x26W PLC

(4-pin electronic or 2-pin iron-core)

Power 240V AC 50Hz

FLUORESCENT SURFACE MOUNT

Gentech Lighting

49

METAL HALIDE RECESSED

50

G3121 Single Gyro Square

Gyro ring with swivel and tilt adjustment. Features twist cap lens for lamp replacement.

Material Aluminium, pressed steel 150

Size

Colour

Lamp

200 (Length) x

200 (Width) x

150 (Height) mm

Black, Grey, White

200

150

200

Power

Cut Hole

Max. G12 70W Metal

Halide

240V AC 50Hz

175 x 175 mm

200

200

150

G3122 Dual Gyro Rectangular

150

Gyro ring with swivel and tilt adjustment. Features twist cap lens for lamp replacement.

Material Aluminium, pressed steel

150

360

200

Size 360 (Length) x

200 (Width) x

150 (Height) mm

Black, Grey, White

200

360

Colour

Lamp

Power

Cut Hole

240V AC 50Hz

335 x 175 mm

200

200

Gyro ring with swivel and tilt adjustment. Features twist cap lens for lamp replacement.

200

Material

Size

Aluminium, pressed steel

520 (Length) x

200 (Width) x

150 (Height) mm

150

100

520

Colour

Lamp

Black, Grey, White

Max. G12 3x70W

Metal Halide

200

90

100

Power

Cut Hole

240V AC 50Hz

500 x 175 mm

90

180

G92150C Metal Halide 150W Round

G9270C Metal Halide 70W Round

Round 150W or 70W Metal Halide downlight with vented trim easy clip on glass lens and wide angle light beam spread. IES File available on request.

90

180

Material Aluminium

Size 228 (Diameter) x 116 (Height) mm

Colour White

Lamp 150W or 70W Double Ended Metal

Halide

Power

Cut Hole

240V AC 50Hz

200 mm

Gentech Lighting

G94150 Metal Halide 150W Square Tilt

G9470 Metal Halide 70W Square Tilt

Metal Halide tilt downlight with hinged glass lens and fully enclosed back

Material Aluminium, pressed steel, Tempered glass lens. Frosted or Clear glass

Size

Colour

230 (Length) x 140 (Width) x

102 (Height) mm

White, Black, Brushed Aluminium

Frosted or Clear glass

Lamp

Power

Cut Hole

150W or 70W Double Ended Metal

Halide

240V AC 50Hz

212 x 123 mm

G96150

Metal Halide 150W Adjustable Round

G9670

Metal Halide 70W Adjustable Round

Swivel and tilt 150W or 70W Metal Halide downlight.

Features wide angle light spread and vented trim. IES File available on request

Material

Size

Aluminium, Tempered glass lens

254 (Diameter) x 200 (Height) mm

Colour White

Lamp

Power

Cut Hole

150W or 70W Double Ended Metal

Halide

240V AC 50Hz

230 mm

G9881 Metal Halide G8.5 Adjustable

Compact 35/70W metal halide snorkel. Features 360 deg. rotation with pull front face for lamp replacement. IES File available on request

Material

Size

Aluminium, Tempered glass lens

155 (Diameter) x 155 (Height) mm

Colour

Lamp

Power

Cut Hole

Ash White/Silver

35 - 70W G8.5 Metal Halide

240V AC 50Hz

144 mm

G9882 Metal Halide G12 Adjustable

Narrow angle light spread for highlight application.

Features multi-facet reflector swivel and tilt. IES File available on request

Material Aluminium, Tempered glass lens

Size 185 (Diameter) x 170 (Height) mm

Colour White

Lamp

Power

35 - 70W G12 Metal Halide

240V AC 50Hz

Cut Hole 175 mm

Gentech Lighting

METAL HALIDE RECESSED

51

METAL HALIDE RECESSED

G9883

Metal Halide G12 Downlight

Compact metal halide housing with fully enclosed back and ribbed reflector. Features pull front glass cover for easy lamp replacement. IES File available on request

Material Aluminium, Tempered glass lens

Size 160 (Diameter) x 115 (Height) mm

Colour White

Lamp

Power

Cut Hole

35 - 70W G12 Metal Halide

240V AC 50Hz

140 mm

G9886

Metal Halide G8.5 Snorkel

Classic snorkel style metal halide. Fully enclosed back with twist cap face for easy lamp replacement. Offers

360 deg. rotation and 80 deg. tilt. IES File available on request

Material

Size

Aluminium, Tempered glass lens

165 (Diameter) x 125 (Height) mm

Colour White

Lamp Max 70W G8.5 Metal Halide

Power 240V AC 50Hz

METAL HALIDE SURFACE MOUNT

G141-150W

150W Metal Halide Surface Mount

G141-70W

70W Metal Halide Surface Mount

Surface mount 150W or 70W metal halide fitting with smooth satin reflector and twist glass front for lamp replacement.

Material

Size

Aluminium, Tempered glass lens

225 (Diameter) x 160 (Height) mm

Colour

Lamp

Power

Black, White

150W or 70W Double Ended Metal

Halide RX7s

240V AC

52

Gentech Lighting

LED-MR16-CONVERTER

LED MR16 12V AC To 12V DC Converter

LED Converter converts 12V AC power to 12V DC.

Suitable for use with 12V DC compatible MR16 or Bi-pin

LED globes. Non dimmable.

Size

Lamp

55 x 29 x 18 mm, 120 mm lead

12V LED MR16 or 12V LED G4 Halogen

Power

Output

Input : 12VAC

Output : 12V DC

G801N-D Downlight Conversion Plate

150mm

Conversion plate to suit a fixed downlight or 13 watt

LED downlight. Covers up to 145 mm hole

Material Steel

Size 158 mm Diameter

Colour White, Brushed Chrome, Brass

G801N-G Gimbal Conversion Plate

150mm

Conversion plate to suit a gimbal downlight. Covers up to

145mm hole

Material Steel

Size 158 mm Diameter

Colour White, Brass

G801-D-316-SS Stainless Steel Conversion

Plate 150mm

316 Marine grade stainless steel conversion plate to suit G822R, G823R, G826R & GU622R. Covers up to

148mm hole

Material 316 Stainless steel

Size

Colour

Cut Hole

156 mm Diameter

Stainless Steel

≥ 105 mm up to 148 mm

G800N-D Downlight Conversion Plate

200mm

Conversion plate to suit a fixed downlight or 13 watt

LED downlight. Covers up to 195 mm hole

Material Steel

Size 200 mm Diameter

Colour White, Brushed Chrome, Brass

Gentech Lighting

PARTS AND ACCESSORIES

53

PARTS AND ACCESSORIES

G800N-G

Gimbal Conversion Plate 200mm

Conversion plate to suit a gimbal downlight. Covers up to

195 mm hole

Material Steel

Size 200 mm Diameter

Colour White, Brushed Chrome, Brass

G802-G-WH

Gimble Conversion Plate 230mm

Conversion plate to suit a gimbal down light. Covers up to 225 mm hole

Material Steel

Size 230 mm Diameter

Colour White

Cut Hole From 190 to 225 mm

G803-G-WH

Gimble Conversion Plate 270mm

Conversion plate to suit a gimbal down light. Covers up to 265 mm hole

Material Steel

Size 270 mm Diameter

Colour White

PA12GZ10-KIT GU10 Lampholder Kit

GU10 lamp holder bracket and junction box kit. Features earth wire and 120 mm double insulated lead from lamp holder to enclosed terminal box.

Size

Lamp

Power

Bracket Height- 85 mm

240V GU10 GZ10

240V AC

54

Gentech Lighting

BAFFLE-TWIST Baffle Twist

Baffle for twist cap down lights. Suits G825, G836, G839 and G892 fittings.

Material Steel

Size

Colour

59 (Diameter) x 35 (Depth) mm

Black, Brass, Chrome, White

CLAMP1 Handy Lamp Clamp

An implement to assist with fitting removing or replacing lamps in light fixtures with fixed lamp holders

CAN-ACOUSTIC

Acoustic Heat Can for Down Lights

Acoustic sound absorbing and fire containing downlight canister. Designed to sound proof and restrict fire penetration in to ceiling void. Test reports and figures available on request. Suitable for various downlight options.

Material

Size

Cut Hole

Spun steel can, Porcelain terminal block

94 (Diameter) x 144 (Height) mm

94 mm

PARTS AND ACCESSORIES

Gentech Lighting

55

LED

56

LED-301-1W 30 Degree Fixed Cabinet

Light 1.2W

Diecast aluminium 1.2W LED recessed cabinet light.

Features 30 deg. beam angle lens and reflector. 50 cm lead with connector. Available in cool white and warm white light colour. Requires a 350 mA driver

Material

Size

Powder coated die-cast aluminium

40 (Diameter) x 22 (Depth) mm

Colour

Lamp

Silver, White

1 x 1.2W OSRAM LED

Led Colour Cool White, Warm White

Lumen Output Warm White – 68 Lm

Cool White – 85 Lm

Beam Angle 30°

Power 350mA Constant Current

Cut Hole 33 mm

LED-301-3W 30 Degree Fixed Cabinet

Light 3W

Diecast aluminium 3W LED recessed cabinet light.

Features 30 deg. beam angle lens and reflector. 50 cm lead with connector. Available in cool white and warm white light colour. Requires a 700 mA driver.

Material

Size

Powder coated die-cast aluminium

40 (Diameter) x 22 (Height) mm

Colour

Lamp

Silver, White

1 x 3W OSRAM LED

Led Colour Cool White, Warm White

Lumen Output Warm White – 108 Lm

Cool White – 135 Lm

Beam Angle 30°

Power

Cut Hole

700mA Constant Current

33 mm

Gentech Lighting

LED-301-SM-3W Shelf Light 1 x 3W LED

Compact 3W LED shelf downlight. Features inbuilt

LED chip and 150mm double insulated cable for screw terminal LED Driver. Recessed or surface mount option.

Material Aluminium

Size 45 (Diameter) x 25 (Sleeve height) mm

– Surface Mount, 22 (Fitting depth) mm

Colour Silver

Lamp 1 x 3W LED

Led Colour Cool White, Warm White

Lumen Output Cool White –180Lm

Warm White – 150Lm

Beam Angle 80°

Power

Cut Hole

700mA Constant Current

37 mm (For recessed option)

LED-133 Shelf Light 3 x 1W LED

Compact 3W LED shelf downlight. Features three inbuilt

LED chips and 150mm double insulated cable for screw terminal LED Driver. Recessed or surface mount option.

Material Aluminium

Size 77 (Diameter) x 25 (sleeve height) mm -

Surface mount,

22( fitting depth) mm

Colour Silver

Lamp 3 x 1W Edison LED

Led Colour Cool White, Warm White

Lumen Output Cool White – 203Lm

Warm White – 154Lm

Beam Angle 80°

Power 350mA Constant Current

Cut Hole 63 mm (For recessed option)

LED-136 Shelf Light 6 x 1W LED

Compact 6W LED shelf downlight. Features six inbuilt

LED chips and 150mm double insulated cable for screw terminal LED Driver. Recessed or surface mount option.

Material Aluminium

Size 85 (Diameter) x 38 (sleeve height) mm -

Surface mount

32( fitting depth) mm

Colour Silver

Lamp 6 x 1W Osram LED

Led Colour Cool White, Warm White

Lumen Output Cool White – 820Lm

Warm White – 700Lm

Beam Angle 80°

Power 350mA Constant Current

Cut Hole 75 mm (For recessed option)

Gentech Lighting

LED

57

LED

58

LED302

15Deg Adjustable Cabinet Downlight

Aluminium 1W LED recessed centre tilt downlight.

Features 15 deg. beam angle lens and reflector. 50 cm lead with connector.Available in cool white and warm white light colour. Requires 350 mA driver

Material Aluminium

22

Size

Colour

Lamp

52(Diameter) x 22mm

Anodised Aluminium

1W LED

52

Led Colour Cool White, Warm White

Lumen Output Cool White – 88.95Lm

Warm White – 54.07Lm

Beam Angle 15° Lens

Power

IP Rating

Cut Hole

350mA Constant Current

IP20

44 mm

80 52

32

22

LED303 Adjustable Cabinet Downlight

3x1W LED recessed downlight.Well balanced design features optimum merge of 3 LED beams into 1 wider beam. 50c m lead with connector. Cool white and warm white light colour. Requires 350 mA driver

Material Aluminium

32

Size

Colour

Lamp

80 (Diameter) x 32 mm

Anodised Aluminium

3 x 1W LED

Led Colour Cool White, Warm White

Lumen Output Cool White – 255 Lm

Warm White – 185 Lm

Beam Angle 15° Lens

Power 350mA Constant Current

IP Rating

Cut Hole

IP20

70 mm

80

LED304 Zip

1x1W LED semi-recessed decorative marker. Features anodised aluminium trim, frost disc centre and has 29 cm lead with quick connector.

Material

Size

Colour

Anodised Aluminium trim, Frosted clear acrylic disc lens

45 mm (Diameter) x 33 mm (Depth) x

13 mm (Profile)

Anodised Aluminium

Lamp

Led Colour Blue, Warm White

Power 350mA Constant Current

IP Rating

Cut Hole

1W LED

IP23

37 mm

Gentech Lighting

LED335 Micro LED Light

1X1W LED slimline profile surface mount shelf light.

Fitting has 90 cm lead and connector. Available in warm white light colour. Requires 350mA driver

Material Aluminium

Size 33 (Diameter) x 13 (Height) mm

Colour Aluminium

Lamp 1W LED

Led Colour Warm White

Lumen Output 80 Lm

Power

IP Rating

350mA Constant Current

IP41

LED336 Mini LED Light

3x1W LED slimline profile surface mount shelf light.

Fitting has 90 cm lead and connector. Available in warm white light colour. Requires 350mA driver

Material Aluminium

Size 70 (Diameter) x 14 (Height) mm

Colour Aluminium

Lamp 3 x 1W LED

Led Colour Warm White

Lumen Output 180 Lm

Power

IP Rating

350mA Constant Current

IP41

G847-LED LED Shelf Downlight Metal

A robust metal mini 3W LED shelf downlight. Features inbuilt cool white LED chip frost glass lens clip-on lens holder and 150 mm double insulated cable for screw terminal LED Driver. Recessed or surface mount option.

Material

Size

Colour

Pressed metal, Poly Carbonate lens

66 (Diameter) x 22 (Height) mm

Brass, Black, Polished Chrome, Satin

Chrome, White

Lamp 1 x 3W LED

Led Colour Cool White

Power

Cut Hole

700mA Constant Current

58 mm (recessed option)

Gentech Lighting

LED

59

12V

240V

G847 Shelf Downlight Metal

A robust metal mini shelf downlight glass clip-on lens holder. Built-in reflector. Recessed or surface mount.

Material Pressed metal, glass lens

Size

Colour

Lamp

Power

Cut Hole

66 (Diameter) x

23 (Height) mm

66

White, Black, Satin Chrome, Chrome,

Brass

Max. 20w Bi-Pin Burner

Optional LED lamps available

12V AC

58 mm (recessed option)

23

GHX-7S Energy Badge

Surface mount 7W T2 shelf light. Complete with lamp.

Material Plastic

Size 99 (Diameter)mm x 32 (Height) mm

(Including 24 mm lamp)

Colour White

Lamp Max. 240V GX53 7W

Power 240V AC 50Hz

GHX-9S Energy Button

Surface mount 9W shelf or wall low profile and energy efficient.

Material Plastic

Size 82 x 17 mm (less lamp)

Colour White

Lamp Max. 240V/GX53/9W

Optional LED lamps available

Power 240V AC 50Hz

60

Gentech Lighting

LED-PL600X600

LED Recessed Ceiling Panel 600 X 600

Led ceiling panel features aluminium frame, poly carbonate diffuser and female connector for LED driver.

Offers uniform light distribution. Includes 24V LED driver with connector and three pin flex and plug.

Material Aluminium, Poly carbonate

Size

Colour

Lamp

600 x 600 x 10 (Height) mm

Aluminium trim, Opal diffuser

36W LED 5630 SMD

Led Colour Cool White, 5600K +/- 300K

Lumen Output 2600 ~ 2800 Lm

Beam Angle 180°

Power Input: 24V DC

Cut Hole 600 X 600 mm

LED-PL1200X300

LED Recessed Ceiling Panel 1200 x 300

Led ceiling panel features aluminium frame, poly carbonate diffuser and female connector for LED driver.

Offers uniform light distribution. Includes 24V LED driver with connector and three pin flex and plug.

Material

Size

Aluminium, Poly carbonate

1200 x 300 x 10 (Height) mm

Colour

Lamp

Aluminium trim, Opal diffuser

36W LED 5630 SMD

Led Colour Cool White, 5600K +/- 300K

Lumen Output 2600 ~ 2800 Lm

Beam Angle 180°

Power Input: 24V DC

Cut Hole 1200 x 300 mm

Gentech Lighting

RECESSED PANELS

61

63

LED TWISTER

64

9W

LED-TW-12V-5W LED Twister

Flexible light system for indoor applications. Offers high illumination with no colour fading and features 3M adhesive fixing.

Size 10 (Width) x 3.4(Height) mm

(Height may vary)

0.16W LED (4.8W per metre) Lamp

Led Colour Red, Yellow, Blue, Cool White, Orange,

Green, Warm White

Power 12V DC

LED-TW-PR-12V LED Twister Premium 12V

Flexible light system for indoor and outdoor application.

Offers high illumination with no colour fading and features 3M adhesive fixing.

Size 10 (Width) x 3.4 (Height) mm

(Height may vary)

0.2W LED (6W per metre) Lamp

Led Colour Red, Yellow, Blue, Cool White, Green,

Warm White

Power

IP Rating

12V DC

IP63

14W

LED-TW-PR-24V

LED Twister Premium 24V

Flexible light system for indoor & outdoor application.

Offers high illumination with no colour fading and twin adhesive fixing. Available as 9W per metre and 14W per metre version

Size

Lamp

Power

IP Rating

10 (Width) x 3.4 (Height) mm

(Height may vary)

9W per metre

14W per metre

24V DC

IP63

LED-TW-PR-12V-RGB

LED Twister 12V – RGB

Flexible light system for indoor and outdoor application.

Offers high illumination with no colour fading, multiple light functions via RGB Remote Control and features 3M adhesive fixing.

Size 10 (Width) x 3.4 (Height) mm

(Height may vary)

0.2W LED (6W per metre) Lamp

Led Colour RGB

Requires RGB Remote Control

Power

IP Rating

12V DC

IP63

Gentech Lighting

LED TWISTER

LED-TW-PR-24V-RGB

LED Twister 24V – RGB

Flexible light system for indoor and outdoor application.

Offers high illumination with no colour fading, multiple light functions via RGB Remote Control and features 3M adhesive fixing.

Size 10 (Width) x 3.4(Height) mm

(Height may vary)

Lamp 0.2W LED (6W per metre)

Led Colour RGB

Requires RGB Remote Control

Power 24V DC

IP Rating IP63

Stock Code

12V Standard

LED-TW-12-5W-1M-BL

LED-TW-12-5W-1M-CW

LED-TW-12-5W-1M-GR

LED-TW-12-5W-1M-OR

LED-TW-12-5W-1M-RE

LED-TW-12-6W-1M-RGB

LED-TW-12-5W-1M-WW

LED-TW-12-5W-1M-YE

LED

Colour

Power IP Max Power Max Run Cuttable #LEDs per

(Watts / (metres) Length Cuttable metre Length

Blue

Cool White

Green

Orange

12V DC IP 20

12V DC IP 20

12V DC IP 20

12V DC IP 20

Red

RGB

12V DC

12V DC

IP 20

IP 20

Warm White 12V DC IP 20

Yellow 12V DC IP 20

12V Premium

LED-TW-PR-12-6W-1M-BL Blue

LED-TW-PR-12-6W-1M-CW Cool White

LED-TW-PR-12-6W-1M-GR Green

LED-TW-PR-12-6W-1M-RE Red

LED-TW-PR-12-6W-1M-RGB RGB

12V DC

12V DC

12V DC

IP 63

IP 63

IP 63

12V DC IP 63

12V DC IP 63

LED-TW-PR-12-6W-1M-WW Warm White 12V DC IP 63

LED-TW-PR-12-6W-1M-YE Yellow 12V DC IP 63

4.8

6

4.8

4.8

4.8

4.8

4.8

4.8

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

6

50mm

50mm

50mm

50mm

50mm

50mm

50mm

50mm

100mm

100mm

100mm

100mm

100mm

100mm

100mm

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

24V Premium – 9W per metre

LED-TW-PR-24-9W-1M-CW Cool White

LED-TW-PR-24-9W-1M-RGB RGB

24V DC

24V DC

IP 63

IP 63

LED-TW-PR-24-9W-1M-WW Warm White 24V DC IP 63

24V Premium – 14W per metre

LED-TW-PR-24-14W-1M-CW Cool White 24V DC IP 63

LED-TW-PR-24-14W-1M-WW Warm White 24V DC IP 63

9W

9W

9W

14W

14W

6

6

6

6

6

150mm

150mm

150mm

100mm

100mm

6

6

6

6

6

Gentech Lighting

65

LED SNAKE

LED-SN-2P-12V LED Snake 12V

Flexible light system for indoor and outdoor application.

Optional step and linear mounting profiles. Also available in 24V for longer runs.

Size 12 (Width) x 6 (Height) mm

Lamp 0.08W LED (2.88W per metre)

Led Colour Red, Green, Blue, Cool White, Warm White

Power

IP Rating

12V DC

IP67

LED-SN-2P-24V LED Snake 24V

Flexible light system for indoor and outdoor application.

Optional step and linear mounting profiles. Also available in 12V for shorter runs.

Size

Lamp

12 (Width) x 6 (Height) mm

0.08W LED (2.88W per metre)

Led Colour Amber, Green, Blue, Cool White, Warm White

Power 24V DC

IP Rating IP67

LED-SN-4P-24V-RGB LED Snake RGB

Flexible light system for indoor and outdoor application.

Features multiple light functions via RGB Remote Control.

Size

Lamp

15 (Width) x 7.6 (Height) mm

0.17W LED (5.28W per metre)

Led Colour RGB, Requires RGB Remote Control

Power 24V DC

IP Rating IP67

66

Stock Code

12V

LED

Colour

Power IP Max Power Max Run Cuttable #LEDs per

(Watts / metre

(metres) Length Cuttable

Length

LED-SN-2P-12V-BL-1M

LED-SN-2P-12V-GR-1M

Blue

Green

12V DC IP 67

12V DC IP 67

LED-SN-2P-12V-NW-1M

LED-SN-2P-12V-RE-1M

Natural White

Red

12V DC

12V DC

IP 67

IP 67

LED-SN-2P-12V-XWW-1M Extra Warm White 12V DC IP 67

2.88

2.88

2.88

2.16

2.88

33

33

33

44

33

83.4mm

83.4mm

83.4mm

139mm

185mm

3

5

3

3

3

24V

LED-SN-2P-24V-AM

LED-SN-2P-24V-BL-1M

Amber

Blue

LED-SN-2P-24V-GR-1M Green

LED-SN-2P-24V-WH-1M White

LED-SN-2P-24V-WW-1M Warm White

LED-SN-4P-24V-RGB RGB

24V DC IP 67

24V DC IP 67

24V DC IP 67

24V DC IP 67

24V DC IP 67

24V DC IP 67

2.16

2.88

2.88

2.88

2.88

5.28

88

66

66

66

66

30

278mm

166.8mm

166.8mm

166.8mm

166.8mm

185mm

6

6

6

6

10

6

Gentech Lighting

LED-CONNECTOR-2P-TAIL

Two Pin LED Connector

Two pin connectors to connect LED Drivers to LED

Strip Lights. Available as Male or Female plugs or sockets.

Complete with 20cm leads

Size

Power

20 cm

12 OR 24V DC

LED-TW-SN-CONNECT-1F-2M

Two Way LED Driver Splitter

Two pin connectors to connect two LED Strip Lights to a single driver

Size 33 cm

Power 12 OR 24V DC

LED-TW-SN-CONNECT-1F-3M

Three Way LED Driver Splitter

Two pin connectors to connect three LED Strip Lights to a single driver

Size 33 cm

Power 12 OR 24V DC

LED-CONNECTOR-4P-TAIL

Four Pin LED Connector

Four pin connectors to connect LED Drivers to LED

(RGB) Strip Lights. Available as Male or Female plugs or sockets. Complete with 20cm leads

Size

Power

14 cm

12 OR 24V DC

LED-SN-2P-LINEAR-ENDCAP

Snake End Cap

Plastic end cap for aluminium linear profile

Colour Silver

LED-SN-2P-CONNECTOR-TI

T Connector 1

T Connector (protrusion on the bottom male connector face down)

Gentech Lighting

PARTS AND ACCESSORIES

67

PARTS AND ACCESSORIES

68

LED-SN-2P-CONNECTOR-TL

T Connector 2

T Connector (protrusion on the right male connector face down)

LED-SN-2P-CONNECTOR-L

L Connector

L Connector (1 male & 1 female connector)

LED-SN-2P-STAIR-NOSE

Stair Tread Nose

1.5 metre aluminium step profile

Colour Silver

LED-SN-2P-LINEAR-PROFILE

Wall-Floor Nose

1.5 metre aluminium linear profile

Colour Silver

LED-SN-2P-CHANNEL

Plastic Mounting Track

1 metre plastic channel

Size 6 (Height) x 12 (Width) mm,

1000 (length) mm

LED-IRC160

Remote Control

Remote Control for LED-MR16-RGB

LED-TW-12-RGB-AMP

12V RGB Amplifier

12V RGB Amplifier to synchronize the colour changing sequence. Any installations consisting of more than 2 x

6m runs of RGB LED strip require the use of an amplifier.

Size 102 x 64 x 24 mm

Power 12V DC

Gentech Lighting

LED-SN-24-RGB-AMP

24V RGB Amplifier

24V RGB Amplifier to synchronize the colour changing sequence. Any installations consisting of more than

2 x 6m runs of RGB LED strip require the use of an

Amplifier.

Size 102 x 64 x 24

Power 24V DC

LED-TW-SN-12-24-RGB-CON

12-24V RGB Controller

Wireless remote control for RGB Twister and Snake which effectively operates up to a distance of 50 metres.

Multimode selection and pause function. Brightness and speed adjustment. Features static colour selection, and colour fade.

Material Plastic

Size 121 x 75 x 25 (Height) mm

Power

Output

12-24V DC

Max. 4A each Colour

Temperature -20°C- 60°Ct

LED-REMOTE-DIMMER

LED Remote Dimmer

Dimmer to suit Led Snake and Twister

Power

Output

12V - 24V DC

12V Max load – 72W

24V Max load – 144W

PARTS AND ACCESSORIES

Gentech Lighting

69

SURFACE MOUNT

RECESSED

70

EXTR-001-SM

Low Profile Surface Mount Extrusion

Low profile surface mount extrusion for LED strip lights.

Complete with opal diffuser.

Standard lengths in 1m 1.5m or

2.5m lengths. Cut to length service available.

Material Aluminium, polycarbonate

Size

Colour

17.13 (Width) x 8.8 (Height) mm

Aluminium with Opal Diffuser

EXTR-004-CNR

Corner profile Extrusion

Corner Profile Extrusion for LED

Strip Lights. Complete with opal diffuser. Standard lengths in 1m

1.5m or 2.5m lengths. Cut to length service available.

Material Aluminium, polycarbonate

Size

Colour

18.42 (Width) x 18.42 (Height) mm,

90° angle

Aluminium with Opal Diffuser

EXTR-003-LPR

Low Profile Recessed Extrusion

Low profile recessed extrusion for

LED Strip Lights. Complete with opal diffuser. Standard lengths in 1m

1.5m or 2.5m lengths. Cut to length service available.

Material

Size

Colour

Aluminium, polycarbonate

17.2 (Width) x 9 (Height) mm; and 23.4 mm (width including profile lip)

Aluminium with Opal Diffuser

Gentech Lighting

RECESSED

EXTR-002-DPR

Deep Profile Recessed Extrusion

Deep profile recessed extrusion for LED Strip Lights.

Complete with opal diffuser. Standard lengths in 1m 1.5m or 2.5m lengths. Cut to length service available.

Material

Size

Colour

Aluminium, polycarbonate

16.5 (Width) x 14.5 (Height) mm; and 22 mm (width including profile lip)

Aluminium with Opal Diffuser

EXTR-001-SM-EC

Surface Mount Extrusion End Caps

End caps to tidy up an LED Strip light fitted in a Low

Profile Surface Mount Extrusion. Provided as a set of two one solid and the other with a hole to allow for cable entry.

Material Plastic

Colour Grey

EXTR-001-SM-CLIP

Surface Mount Extrusion Mounting Clip

Plastic Mounting Clip for Surface Mount Extrusion. The flat mounting surface has a countersunk screw hole to accommodate a flat head screw and the arms consist of grooves to grip the extrusion.

Material Plastic

Size 20 (Width) x 9 (Height) x

14 (Length) mm

Colour Clear

EXTR-004-CNR-EC

Corner Extrusion End Caps

End caps to tidy up an LED Strip fitted in a Corner

Profile Extrusion. Provided as a set of two one solid and the other with a hole to allow for cable entry.

Material Plastic

Colour Grey

EXTR-004-CNR-CLIP

Corner Extrusion Mounting Clip

Plastic Mounting clip for Corner Profile Extrusion. One of the flat mounting surfaces has a countersunk screw hole to accommodate a flat head screw and the arms consist of grooves to grip the extrusion.

Material Plastic

Size 23 (Length) x 17 (Width) x

23 (Height) mm

Colour Clear

Gentech Lighting

PARTS AND ACCESSORIES

71

LED

72

LED504 LED 3.6W Barrel Spotlight

Osram LED 3 x 1.2W spotlight. Features anti glare baffle, safety glass, anodized aluminium housing and solid rectangular back plate with in-built driver. Offers 355 degree rotation and 90 degree tilt. 240V input connection for easy installation.

Material

Size

Anodised Aluminium

Base 125 x 200 mm

Colour Black

Lamp 3 x 1.2W LED

Led Colour Natural White

Power Input: 240V AC

Output

IP Rating

350mA Constant Current

IP44

G-LED-326-DW LED Spotlight 3 x 3W

3x3W LED surface mount cylinder spotlight with in-built driver. Adjustable head angle indicator dial on stem. Also available as three wire or four wire track spotlights

Material Aluminium

Size Head 60 (Diameter) x 130 (Length) mm

Stem100 (Length) mm

Colour Silver

Lamp 3 x 3W LED

Led Colour Daylight White

Lumen Output 510 Lm

Power Input 240V AC

Gentech Lighting

G-LED-327-DW LED Spotlight 6 x 3W

Large LED surface mount spot with in-built LED driver.

Features adjustable head angle indicator dial on stem.

Also available as three wire or four wire track spotlights

Material Aluminium

Size Head: 86 (Diameter) x 180 (Length) mm

Colour

Lamp

Anodised Silver

6 x 3W Edison LED

Led Colour Cool White

Lumen Output 1020 Lm

Beam Angle 60°

Power 220-240V AC - 50/60Hz

LED421 LED 1x6W Single Spotlight

LED 1 x 6W single head spotlight. Features sturdy square back plate 355 degree rotation and in-built 700mA driver.

240V input connection for easy installation.

Material

Size

CNC Aluminium

120 (Length) x 120 (Width) x

130 (Height) mm

Colour Aluminium

Lamp 1 x 6W LED

Led Colour Warm White

Power Input 240V AC

Output

IP Rating

700mA 12V DC

IP20

LED422 LED 2x6W Double Spotlight

LED 2 x 6W two head spotlight. Features sturdy rectangular back plate 355 degree rotation and in-built

700mA driver. 240V input connection for easy installation.

Material

Size

CNC Aluminium

270 (Length) x 120 (Width) x

130 (Height) mm

Colour Aluminium

Lamp 2 x 6W LED

Led Colour Warm White

Power Input 240V AC

Output

IP Rating

700mA 28V DC

IP20

Gentech Lighting

LED

73

LED

DICHROIC

74

LED423 LED 3x6W Triple Spotlight

LED 3x6W Spotlight. Features sturdy rectangular back plate 355 degree rotation and in-built 700mA driver.

240V input connection for easy installation.

Material

Size

CNC Aluminium

420 (Length) x 120 (Width) x

130 (Height) mm

Colour Aluminium

Lamp 3 x 6W LED

Led Colour Warm White

Power Input 240V AC

Output

IP Rating

700mA 41V DC

IP20

LED-TORCH-FLEXI

LED Flexi-Neck Torch

LED Flexi Torch with magnetic base which enables torch to be attached to metal work. Goose neck enables adjustment of torch to desired angle.

Material

Size

High Density Reinforced Aluminium Alloy

450mm (Whole Body Length) x 35mm

(Goose neck) x 33mm (Head)

Colour

Lamp

Gun Metal

3W LED

Led Colour Cool White

Lumen Output 150 Lm (CW)

Power 3 x AAA Batteries included

G296B-LV

Contemporary Cuboid Spot Light

Contemporary cuboid spot light with attached transformer and powder coated aluminium housing.

Features secure front cover ring for easy lamp access.

Offers 355 degree rotation and 180 degree tilt.

Optional LED version available

Material Aluminium

Size Cuboids: 60 x 60 x 100 mm Stem: 45 mm

Colour

Lamp

Power

Black, Silver, White

MR16 Dichroic 12V/50W max.

240V AC

G804 Pencil Head Spotlight

Short elbow spotlight head where lamp is prominent.

355 deg. swivel and 90 deg. tilt. Standard with 50mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome, Satin

Chrome, Silver

Lamp

Power

Max. 12V/50W Dichroic

12V AC

Gentech Lighting

G853 Mini Studio Spot light

Artistic spotlight features adjustable wings. For use where a precise beam spread and low glare is required.

360 deg. swivel and 150 deg. vertical rotation. Standard with 75mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour Black, Chrome

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G855 Butterfly Head Spotlight

Compact winged spotlight for wrapping around the lamp.

355 deg. swivel and 90 deg. tilt. Standard with 52 x 52 mm square back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G859 Barndoor Spotlight

Four winged front barndoor spotlight. Lamp seated back.

355 deg. swivel and 90 deg. Tilt. Standard with 75mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G861 Round Head Spotlight

Barrel spotlight complete with a twist front face. 360 deg. swivel and 150 deg. vertical rotation. Standard with

75mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome, Satin

Chrome, Silver

Lamp

Power

Max. 12V/50W Dichroic

12V AC

Gentech Lighting

DICHROIC

75

DICHROIC

76

G863 Square Head Spotlight

Cube spotlight with a wire lamp retaining ring. 360 deg. swivel and 150 deg. vertical rotation. Standard with

75mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome, Silver

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G864 Bullet Head Spotlight

Bullet spotlight complete with a twist front face.355 deg. swivel and 90 deg. tilt. Standard with 75mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome Satin,

Chrome, Silver

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G865 Stepped Glass Spotlight

Conical glass stepped front spotlight with vented back to soften the light. 355 deg. swivel and 90 deg. tilt. Standard with 75 mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G867 Torch Head Spotlight

Streamline spotlight complete with a twist front face.

355 deg. swivel and 90 deg. tilt. Standard with 75 mm round back plate. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour White, Black, Brass, Chrome,

Satin Chrome, Silver

Lamp

Power

Max. 12V/35W Dichroic

12V AC

Gentech Lighting

G876 Manta Spotlight

A new design flat circular spotlight. 355 deg. swivel and 170 deg. vertical rotation. Options: Extension rods, various back plates, hinged elbow and 90 deg. ball.

Optional LED version available

Material Aluminium

Colour Chrome, Satin Nickel

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G877 Swing Spotlight

Compact suspended spotlight used for directing a precise light. 355 deg. swivel and 170 deg. vertical rotation.

Options: Extension rods, various back plates, hinged elbow and 90 deg. ball. Optional LED version available

Material Aluminium

Colour Chrome, Satin Nickel

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G878 Rocket Spotlight

Streamline spotlight complete with a decorative plastic disc. 355 deg. swivel and 90 deg. tilt. Options: Options:

Extension rods, various back plates, hinged elbow and 90 deg. ball. Optional LED version available

Material Aluminium

Colour Chrome, Satin Nickel

Lamp

Power

Max. 12V/50W Dichroic

12V AC

G871 AR111 Surface Mount Spot

AR111 Surface mount multi directional spot light with in-built transformer. LED option available

Size Spotlight head: 120 (Diameter) x

135 (Width) x 80 (Profile) mm

Base: 162 x 60 x 60 (Height) mm

Colour White

Lamp

Power

AR111 50W Max

12V AC

G872

AR111 Surface Mount Two Light Spot

AR111 Surface mount multi directional two light spot light with in-built transformer. LED option available

Size Spotlight head: 120 (Diameter) x

135 (Width) x 80 (Profile) mm

Base: 252 x 60 x 60 (Height) mm

Colour White

Lamp AR111 2 X 50W Max

Power 12V AC

Gentech Lighting

DICHROIC

AR111

77

AR111

GU10-GZ10

78

G873

AR111 Surface Mount Three Light Spot

AR111 Surface mount multi directional three light spot light with in-built transformer. LED option available

Size Spotlight head: 120 (Diameter) x

135 (Width) x 80 (Profile) mm

Base : 401 x 60 x 60 (Height) mm

Colour White

Lamp AR111 3X 50w Max

Power 12V AC

GU295

GU10 Dapper Barrel Spot Light

Dapper barrel 240V spot light. Features secure front cover ring for easy lamp access and flexible knuckle on stem for 90 deg. tilt and 355 deg. swivel adjustment.

Material Aluminium

Size

Colour

Lamp

Power

Barrel: 60 (Diameter) mm

94 (Length) mm Stem: 65 mm

Black Silver White

Max. 50W GU/GZ10 Halogen

Optional LED lamps available

240V AC

GU296C

GU10 Contemporary Cube Spot Light

GU10 50W cube spot light. Features secure front cover ring for easy lamp access and powder coated aluminium housing. Offers 355 degree rotation and 90 degree tilt.

Optional extension rods, backplates, track adaptors

Material Aluminium

Size Cube: 60 x 60 x 100 mm Stem: 50 mm

Colour

Lamp

Power

Black, Silver, White

Max. 50W GU/GZ10 Halogen

Optional LED lamps available

240V AC

GU280 Retro Spot Light

Contemporary GU10 spot light with 50mm back plate.

Features flexible knuckle joint on stem for 355 degree swiwel and 90 degree tiltl adjustment. Optional extension rods various back plates and track adaptors available.

Material

Size

Colour

Lamp

Power

Cast Aluminium

Height including back plate: 165 mm

Length from knuckle to face: 100 mm

Back plate: 52 (Diameter) x 20 (Height) mm

Black, Satin Nickel, White

Max. 50W GU/GZ10 Halogen

Optional LED lamps available

240V AC

Gentech Lighting

GU304N

GU10 Basic Barrel Head Spot Light

Compact barrel spot light with 50mm back plate.

Features flexible joint on stem for full adjustment 355 deg. swivel and 90 deg. tilt. . Optional decorative skirt

(50W size only) also extension rods various back plates and track adaptors available.

Material Cast Aluminium

Size

Colour

Lamp

Power

Height including back plate: 102mm

Optional Decorative Skirt: 54 (Diameter)

25 (Height) mm

Black, Satin Nickel, Silver, White

Max. 75W GU/GZ10 Halogen

Optional LED lamps available

240V AC

G9601 Spotlight 26W PLC

Energy saver 26W PLC Spotlight. Features wide chrome reflector with movement and head rotation.

Material Aluminium

Size 225 x 145 x 80mm (reflector)

Colour

Lamp

Power

White, Siilver

Max. 26W PLC

240V AC 50Hz

G9241 Barrel Metal Halide Spotlight

Surface mount 35W/70W metal halide spotlight complete with in-built electronic control gear. Adjustable head with angle degree indicators on saddle. Optional barndoor accessory available. IES File available on request

Material Aluminium

Size 125 (Diameter) x 280 (Length) mm

Colour

Lamp

Power

Silver, Black

35W, or 70W G12 Metal Halide

240V AC

G9571

Metal Halide Flood Light Surface Mount

Architectural design surface mount 70W metal halide flood light. Features in-built electronic control gear centre pivot reflector movement.

Material

Size

Aluminium, pressed steel

200 (Length) x 200 (Width) x

80 (Height) mm

Colour

Lamp

Power

Black, Silver

Max. 70W Double Ended RX7s

240V AC

Gentech Lighting

GU10-GZ10

With optional

Decorative

Skirt

PLC

METAL HALIDE

With optional

Barndoor accessory

79

METAL HALIDE

LINEAR HALOGEN

80

G9575 Spotlight Metal Halide G12

70W G12 metal halide spotlight with in-built electronic gear. Features adjustable head movement matte faceted reflector and twist off face for lamp replacement.

Size 110 x 55 x 32 mm

Colour

Lamp

Power

White, Black, Silver

Max. 70W G12 Metal Halide

240V AC 50Hz

G9576 Spotlight Metal Halide G8.5

35W G8.5 metal halide spotlight with in-built electronic gear. Features adjustable head movement chrome faceted reflector 30degree beam angle and twist off face for lamp replacement.

Size 220 x 146 mm

Colour White

Lamp Max 35W G8.5 Metal Halide

Power 240V AC 50Hz

G-J-684 Linear Halogen 100W spotlight

Linear Halogen 100W spotlight. Features powdercoated aluminium housing and safety glass. Offers 355 degree rotation and 90 degree tilt. Optional extension rods various back plates for surface mount versions single and multi circuit track versions available.

Material Aluminium

Size 157 (Length) x 115 (Width) x

180 (Diameter) mm

Colour Silver

Lamp Max. 100W Linear Halogen R7s

Power 240V AC

G-J-683 Shutter Flood with back plate

Surface Mount barndoor front compact linear halogen spotlight. 355 deg. swivel and 90 deg. tilt. Options:

Extension rods, various back plates, hinged elbow.

Material Aluminium

Colour White, Black

Lamp

Power

Max. 150W Linear Halogen R7s 78mm

240V AC

Gentech Lighting

G811S Plain Head Spotlight

Large Surface mount barrel spotlight. Features 355° swivel and 90° elbow tilt. Standard with round back plate. Optional extension rods, various back plates & hinged elbows, also avaialble as single or three circuit track spotlight.

Material Steel

Size

Colour

Lamp

Head: 45 (Diameter) x 63 (Length) mm

White, Black, Chrome

Power

Max.150W Halogen E27 PAR 38, PAR

30, PAR 20

Optional LED lamps available

220-240V AC - 50/60Hz

G606 Venus Spot Par 20

Large PAR 20 barrel surface mount spotlight Features hinged elbow with 355° swivel and 90° tilt. Complete with 75mm back plate. Optional extension rods, Various back plates and track adaptors available.

Material Aluminium

Size

Colour

Lamp

Power

Head: 93 (Diameter) x 128 (Length) mm

Stem: 85 mm

Black, Silver, White

Max. 100W Halogen PAR 20 ES

Optional LED lamps available

220-240V AC - 50/60Hz

G607 Jupiter Spot Par 30

Large barrel surface mount spotlight with a hinged elbow. 355 degree swivel and 90 degree tilt.

Complete with 75 mm back plate.

Optional extension rods, various back plates and track adaptors available.

Material Aluminium

Size Head: 112 (Diameter) x 153 (Length) mm

Stem: 85 mm

Colour

Lamp

Power

Black, Silver, White

LED Par 30 ES 14W

Max. 100W Halogen

Max. 240V 20W Compact Flourescent

Input 240V AC

G608 Saturn Spot Par 38

Large barrel can spotlight with hinged elbow and 110mm back plate. Offers 355 degree swivel and 90 degree tilt.

Optional extension rod. Various back plates and track adaptors.

Material Aluminium

Size

Colour

Lamp

Power

Head: 140 (Diameter) x 160 (Length) mm

Stem: 90 mm

Black, Silver, White

Max. 100W Halogen PAR 38 ES

Optional LED lamps available

220-240V AC - 50/60Hz

Gentech Lighting

PAR LAMP

81

ACCESSORIES

82

BP75, BP50, BP52-SQ Back Plates

BP75 Round 75 mm, BP50 Round 50 mm,

BP62-SQ Square 52 x 52 mm

Material Aluminium

Colour White, Black, Brass, Chrome,

Satin Chrome, Silver

BP80E Easy Fit Back Plate

Flush 80 mm diameter flat back plate with mounting clips for easy installation.

Material Aluminium

Colour White, Black, Brass, Chrome,

Satin Chrome

Cut Hole 60 mm

BP110, BP115 Large Back Plates

Round or dome back plate to house built-in integral transformer. BP110 Round 110mm diameter. BP115

Dome 115 mm diameter.

Material Aluminium

Colour White, Black, Brass, Chrome Satin,

Chrome, Silver

T11 Square Back Plate Electronic Integral

Square architectural ribbed backplate with in-built integral electronic transformer.

Material Aluminium

Size

Colour

Power

90 (Length) x 90 (Width) x

42 (Height) mm

White, Black, Silver, Chrome

240V AC

PA-ROD Extension Rods For Spotlights

Available in standard 150, 300, 600, 900, 1200 and

1500mm lengths. Various colour finishes. Male thread on one end and female thread on the other end.

Material Aluminium

Colour White, Black, Brass, Chrome, Satin

Chrome, Silver, Satin Nickel

Gentech Lighting

PA46 Goose Neck

Flexible goosenecks.

PA46F-150mm, PA462-300mm and PA463-400mm

Colour White, Black, Chrome

PA43 90 Degree Joint Ball

For additional 90 degree applications.

Material Aluminium

Colour White, Black, Brass, Chrome

PA45 Knuckle

For flexible angle joints.

Material Aluminium

Colour White, Black, Brass, Chrome,

Satin Chrome

PA12 Low Voltage Lampholders

Various length leads, square (PA12), round (PA11), pushin and screw-in ( PA12LS) type heads.

Power 12V AC / DC

PA8 Tempered Glass Lens

50mm Diameter glass lens to suit dichroic lamps

Colour Amber, Green, Blue, Red, Frost, Clear

PA8HOLDER 50mm Glass Lens Holder

Designed to hold 50mm lens on dichroic lamp.

Gentech Lighting

ACCESSORIES

83

SPOTLIGHT SLAB RAILS

G861-SLAB2-SC

G863-SLAB2-WH

Mix and Match

Two Light Slab Rail

New slimline rail.

Various low voltage spotlight heads with inbuilt dimmable transformers.

240V options.

Optional LED version available.

Material Aluminium, Pressed Steel

Size

Colour

Lamp

Power

355 (Length) x 55 (Width) x

27 (Height) mm

Black, Brass, Chrome, Satin Chrome,

Silver, White

Max. 2 x 12V 50W Dichroic

240V AC

G865-SLAB2-WH

G867-SLAB2-CH

84

Gentech Lighting

Mix and Match

Three Light Slab Rail

New slimline rail.

Various low voltage spotlight heads with inbuilt dimmable transformers.

240V options.

Optional LED version available.

Material Aluminium, Pressed Steel

Size

Colour

Lamp

Power

560 (Length) x 55 (Width) x

27 (Height) mm

Black, Brass, Chrome, Satin Chrome,

Silver, White

Max. 3 x 12V 50W Dichroic

240V AC

SPOTLIGHT SLAB RAILS

G861-SLAB3-WH

G861-SLAB3-BB

G864-SLAB3-SI

G863-SLAB3-WH

G861-SLAB3-BK

Gentech Lighting

85

SINGLE SPOTLIGHTS IT

G861-IT-WH

G864-IT-WH

G864-IT-BB

G863-IT-BK

Single Integral Spotlights

Various low voltage spotlight heads on round back plate with inbuilt dimmable electronic transformer. May also be made up with a dome back plate.

Optional LED version available

Material

Size

Colour

Lamp

Power

Aluminium

110 mm diameter back plate

Black, Brass, Chrome, Satin

Chrome, Silver White

Max. 12V 50W Dichroic

240V AC

SINGLE SPOTLIGHTS T11

G861-T11-SI

G864-T11-CH

G863-T11-BK

G867-T11-WH

Single Integral Spotlights with T-11 Base

Various low voltage spotlight heads on square back plate with inbuilt dimmable electronic transformer.

Material

Size

Aluminium

Base: 90 x 90 x 42 (Height) mm

Colour

Lamp

Power

Black, Chrome, Silver White

Max. 12V 50W Dichroic

240V AC

86

Gentech Lighting

Gentech Lighting

87

SINGLE CIRCUIT TRACK LIGHTS – LED

EXT-LED-12VDC-296B

LED 12V DC Contemporary Cuboid Track

Light Single Circuit

Contemporary cuboid tracklight spot with built in LED driver. Features secure front cover ring for easy lamp access. Offers 355° rotation and 180° tilt.

Material

Size

Powder coated aluminium

Cuboids: 60 (Length) x 60 (Width) x

100 (Height) mm / Stem: 45 mm

Colour

Lamp

Power

White, Black, Silver

Max. LED-MR16 10W

220-240V AC - 50/60Hz

EXT-LED-700MA-296B

LED 700MA Contemporary Cuboid Track

Light Single Circuit

Contemporary cuboid tracklight spot with built in 700mA dimmable LED driver. Features secure front cover ring for easy lamp access. Offers 355° rotation and 180° tilt.

Material Powder coated aluminium

Size

Colour

Lamp

Power

Cuboids: 60 (Length) x 60 (Width) x

100 (Height) mm / Stem: 45 mm

White, Black, Silver

Max. LED-MR16 8W HP

220-240V AC - 50/60Hz

EXT-LED-700MA-D-861

Round Head Dimmable LED

Track Light Single Circuit

* Spotlight specifications on page 75

EXT-LED-700MA-D-863

Square Head Dimmable LED

Track Light Single Circuit

* Spotlight specifications on page 76

Three wire track spots suitable for

LED lamps

Single circuit LED track fittings. Features single circuit track adaptor with inbuilt 700mA 11W dimmable LED driver.

Material

Size

Track Adaptor: Plastic

Spotlight: Aluminium

Track Adaptor: 123 x 38 x 30 (Height) mm

For spotlight specifications see page references provided

Lamp LED-MR16-8W-D-CW-HP

(8W Dimmable Cool White)

LED-MR16-8W-D-WW-HP

(8W Dimmable Warm White)

Power 240V AC

EXT-LED-700MA-D-804

Pencil Head Dimmable LED

Track Light Single Circuit

* Spotlight specifications on page 74

EXT-LED-700MA-D-859

Barndoor Dimmable LED

Track Light Single Circuit

* Spotlight specifications on page 75

88

Gentech Lighting

EXT-LED-700MA-864

Bullet Head 6W LED Track Light Single

Circuit

Single circuit LED track fitting. Features single circuit track adaptor with inbuilt 700mA non-dimmable LED driver.

Material

Size

Track Adaptor: Plastic

Spotlight: Aluminium

Track Adaptor: 123 x 38 x 30 (Height) mm

For spotlight specifications see page references provided

Lamp LED-MR16-7W-CW

(7W non-dimmable Cool White)

LED-MR16-7W-WW

(7W non-dimmable Warm White)

Power 240V AC

EXT-HD-LED-326

LED Tracklight 3 x 3W Single Circuit

Small LED trackspot with in-built LED driver. Features adjustable head angle indicator dial on stem. IES File available on request.

Material Aluminium

Size Head: 60 (Diameter) x 130 (Length) mm

Colour

Lamp

Anodised Silver

3 x 3W Edison LED

Led Colour Cool White

Lumen Output 510Lm

Beam Angle 60°

Power 220-240V AC - 50/60Hz

EXT-LED-328

LED Trackspot 1x10W Single Circuit

Directional LED modular trackspot. Featuresadjustable head and built in LED driver.

Material Aluminium

Size Head: 60 (Diameter) x 90 (Length) mm /

Driver Box: 81 (Length) x 40 (Width) x

120 (Height) mm

Colour

Lamp

Silver, White

1 x 10W LED

Led Colour Cool White

Lumen Output 600Lm

Beam Angle 38°

Power 220-240V AC - 50/60Hz

SINGLE CIRCUIT TRACK LIGHTS – LED

* Spotlight specifications on page 76

Gentech Lighting

89

SINGLE CIRCUIT TRACK LIGHTS – LED

* Spotlight specifications on page 77

EXT-LED-871 3 Wire AR111 LED Track Light

AR111 Multi directional track light. Features single circuit track adaptor with in built 16W dimmable LED driver.

Material Spotlight: Aluminium

Track Adaptor: Plastic

Size Spotlight head: 120 (Diameter) x

135 (Width) x 80 (Profile) mm

Track Adaptor: 123 x 38 x 30 (Height) mm

Colour White

Lamp LED-AR111-14W-CW (14W Cool White)

LED-AR111-14W-WW (14W Warm White)

Power 240V AC

SINGLE CIRCUIT TRACK LIGHTS – DICHROIC

Various Low Voltage

Dichroic Spot lights fitted with single circuit track adaptor and in built 12V transformer. Dimmable on

Trailing or leading edge dimmers

Lamp Max. 12V/50W

Dichroic

Power 220-240V AC –

50/60Hz

EXT-811

EXT-LV-861

EXT-LV-853

EXT-LV-804

EXT-LV-296B

Contemporary Cuboid

Track Light Single Circuit

* Spotlight specifications on page 74

EXT-LV-804

Pencil Head Track Light

Single Circuit

* Spotlight specifications on page 74

EXT-LV-861

Round Head Track Light

Single Circuit

* Spotlight specifications on page 75

EXT-LV-863

Square Head Track Light

Single Circuit

* Spotlight specifications on page 76

EXT-LV-864

Bullet Head Track Light

Single Circuit

* Spotlight specifications on page 76

EXT-LV-865

Stepped Glass Track Light

Single Circuit

* Spotlight specifications on page 76

EXT-LV-867

Torch Head Track Light

Single Circuit

* Spotlight specifications on page 76

90

Gentech Lighting

SINGLE CIRCUIT TRACK LIGHTS – DICHROIC

EXT-LV-877

Swing Track Light Single

Circuit

* Spotlight specifications on page 77

EXT-LV-853

Mini Studio Track Light

Single Circuit

* Spotlight specifications on page 75

EXT-LV-855

Butterfly Track Light Head

Single Circuit

* Spotlight specifications on page 75

EXT-LV-859

Barndoor Track Light

Single Circuit

* Spotlight specifications on page 75

SINGLE CIRCUIT TRACK LIGHTS – AR111

50W AR111 single circuit track light. Features single circuit track adaptor with inbuilt 12V 50W transformer, dimmable with leading or trailing edge dimmers.

For spotlight specifications see page references above

Material

Size

Lamp

Power

Track Adaptor: Plastic

Spotlight: Aluminium

Track Adaptor: EXT-T3A 120 x 35 x

28 (Height) mm

Max. 50W AR111

220-240V AC - 50/60Hz

EXT-LV-871

AR111 Tracklight Single

Circuit

* Spotlight specifications on page 77

EXT-LV-875

AR111 50W Tracklight

Single Circuit

SINGLE CIRCUIT TRACK LIGHTS – GU10-GZ10

Various GU10 Spot lights fitted with choice of Standard,

Heavy duty, or Flush single circuit 240V track adaptors.

Material

Size

Track Adaptor: Plastic

Spotlight: Aluminium

240V Adaptor Standard: 40 x 35 x

30 (Height) mm

Heavy Duty Adaptor: 95 x 30 x

28 (Height) mm

Flush Adaptor: 80 x 35 mm

Colour

Lamp

Power

For spotlight specifications see page references below

Black, Silver, White

Max. GU10 50W

220-240V AC - 50 60Hz

EXT-GU296C

* Spotlight specifications on page 78

EXT-GU295

* Spotlight specifications on page 78

EXT-GU304

* Spotlight specifications on page 79

Gentech Lighting

EXT-FL-GU304

* Spotlight specifications on page 79

91

SINGLE CIRCUIT TRACK LIGHTS – GU10-GZ10

EXT-HD-GU280

* Spotlight specifications on page 78

EXT-FL-GU280

* Spotlight specifications on page 78

EXT-GU280

* Spotlight specifications on page 78

SINGLE CIRCUIT TRACK LIGHTS – PLC

EXT-HD-9601

26W PLC single circuit track light, fitted with heavy duty track adaptor.

Material

Size

Colour

Lamp

Power

Track Adaptor: Plastic

Spotlight: Aluminium

Track Adaptor: 95 x 30 x 28 (Height) mm

For spotlight specifications see page ???

Silver, White

Max. 26W PLC

220-240V AC - 50/60Hz

SINGLE CIRCUIT TRACK LIGHTS – METAL HALIDE

Single Circuit Metal Halide track lights

For spotlight specifications see page references above.

Material Track Adaptor: Plastic

Spotlight: Aluminium, Glass diffuser

Size Track Adaptor:

EXT- ADAPTOR 40 x 35 x

30 (Height) mm

EXT-HD- ADAPTOR 95 x 30 x

28 (Height) mm

Power 220-240V AC - 50/60Hz

EXT-9571

Metal Halide Flood Light

Single Circuit

* Spotlight specifications on page 79

EXT-9575

Metal Halide Track Light

Single Circuit G12

* Spotlight specifications on page 80

92

EXT-9576N

Metal Halide Track Light

Single Circuit G8.5

* Spotlight specifications on page 80

Gentech Lighting

SINGLE CIRCUIT TRACK LIGHTS – LINEAR HALOGEN

Linear Halogen single circuit track light.

For spotlight specifications see page references above.

Size

Power

Track Adaptor:

EXT-ADAPTOR 40 x 35 x

30 (Height) mm

EXT-HD-ADAPTOR 95 x 30 x

28 (Height) mm

220-240V AC - 50/60Hz

EXT-683

Shutter Flood Track Light

Single Circuit

* Spotlight specifications on page 80

EXT-HD-684

Linear Halogen Track Light

Single Circuit

* Spotlight specifications on page 80

SINGLE CIRCUIT TRACK LIGHTS – PAR LAMP

240V PAR single circuit track light, fitted with 240V track adaptor.

For spotlight specifications see page references above.

Material

Size

Power

Track Adaptor: Plastic

Spotlight: Aluminium

EXT-ADAPTOR 40 x 35 x

30 (Height) mm

EXT-HD-ADAPTOR 95 x 30 x

28 (Height) mm

SPOT LIGHTS See page references above

220-240V AC - 50/60Hz

EXT-811

Plain Head Tracklight Single

Circuit

* Spotlight specifications on page 81

EXT-HD-606

Venus Track light Single

Circuit

* Spotlight specifications on page 81

EXT-HD-607

Jupiter Track Light Single

Circuit

* Spotlight specifications on page 81

SINGLE CIRCUIT TRACKS

EXT-600, EXT-1000, EXT-2000

3 wire single circuit track complete with dead ends. 20 Kg weight load.

Material: Aluminium

Size : Track width 35mm height 15 mm.

Length: EXT-600: 600 mm

EXT-1000: 1000 mm

EXT-2000: 2000 mm

Colour :

Power :

Black, Silver, White

240V AC 50Hz

Gentech Lighting

93

SINGLE CIRCUIT ACCESSORIES

A

C

E

G

94

I

B

D

F

H

A: EXT-L Live End Single Circuit Track

Live End to feed power to 3 wire track.

Material Plastic

Colour Black, Silver, White

B: EXT-D End Cap Single Circuit Track

End cap to suit three wire single circuit track

Material Plastic

Colour Black, Silver, White

C: EXT-J Track Joiner Straight Single Circuit

Joiner to connect two tracks.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

D: EXT-BJ Live Joiner Single Circuit Track

Live Joiner to connect two tracks. Mains power may be connected from this joiner.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

E: EXT-FJ Live flexible joiner

Live flexible joiner to connect two tracks in a flexible angle. Mains power may be connected from this joiner.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

F: EXT-EJ Elbow L Joiner Single Circuit Track

Elbow joiner to join two tracks in a 90 degree angle.

Mains power may be connected from this joiner.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

G: EXT-TJ T Live joiner

T live Joiner to connect three tracks. Mains power may be connected from this joiner.

Material Plastic

Colour Black, Silver ,White

Power 240V AC 50Hz

H: EXT-XJ X Live Joiner

X live Joiner to connect four tracks. Mains power may be connected from this joiner.

Material Plastic

Colour White, Black

Power 240V AC 50Hz

I: EXT-WIRE-S-N Wire Suspension Kit

Adjustable 3 metre or 1.5 metre maximum length suspension kits designed for track systems.

Material

Size

Aluminium, Steel cable

EXT-WIRE-3M-SN – Cable 3 metres

EXT-WIRE-1.5-SN - Cable 1.5 metres

Colour Silver

Gentech Lighting

SINGLE CIRCUIT ACCESSORIES

J: EXT-T3A 12V Single Circuit Track Adaptor

Low voltage track adaptor for single circuit track. Features inbuilt 12V 60 VA electronic dimmable transformer.

Material Plastic

Size 120 X 35 X 28 (Height) mm

Colour

Power

Black, Silver, White

Primary: 220-240V AC ~ 50/60Hz

Output 11.4V ~ eff, 5A, 20-60W / VA

Temperature ta : 50°C, tc : 75°C

K: EXT-700MA-11W-ADP Single Circuit

Dimmable LED Track Adaptor

Single circuit track adaptor with in buit 700mA 11W dimmable LED driver.

Material Plastic

Size 123 x 38 x 30 (Height) mm

Colour Black, Silver, White

Power

Output

Primary: 220-240V AC~ 50/60Hz, 0.13A

Constant Current: 700mA, Voltage: 4-16V DC

Temperature ta= 50°C tc= 72°C

L: EXT-700MA-D-16W-ADP Single Circuit

Dimmable LED Track Adaptor 16W

Single circuit track adaptor with in- built 700mA 16W dimmable LED driver.

Material Plastic

Size 123 x 38 x 30 (Height) mm

Colour

Power

Black, Silver, White

Primary: 220-240V AC~ 50/60Hz, 0.15A

Output Constant Current: 700mA, Voltage: 2-24V DC

Temperature ta= 40°C tc= 85°C

M: EXT-ADAPTOR 240V Adaptor

A universal connection designed to adapt spotlight head to a 240V 3 wire track. 10kg weight bearing capacity.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

N: EXT-ADAPTOR-HD

Single Circuit Heavy Duty Track Adaptor

A robust adaptor designed to adapt a spotlight head to a

240V single circuit track. Features two locking arms 10kg weight bearing capacity.

Material Plastic

Size

Colour

Power

95 x 30 x 42 (Height) mm

Black, Silver, White

240V AC 50Hz

O: EXT-E01 240V Flush Adaptor

A sophisticated connection flush with track designed to adapt spotlight head to a 240V 3 wire track.

Material Plastic

Colour

Power

White, Black, Silver

240V AC 50Hz

M

Gentech Lighting

J

K, L

O

N

95

MULTI-CIRCUIT TRACK LIGHTS – LED

EXT4-LED-334

40W LED Track Light Three Circuit

40W LED Three circuit track light with attached gear box and inbuilt Mean Well LED driver. Features high quality reflector with LOR 86%, and glass cover. Offers 355° rotation and 180° tilt. IES File available on request

Material

Size

Die-cast Aluminium

Head: 126(Diameter) x 161.5(Height) mm

Gear Box: 119.5 x 169.5 x 46 mm

Black, White, Silver Colour

Lamp 40W Citizen LED

Led Colour Warm White

Lumen Output Warm White: 2142 Lm

Beam Angle 34°

Power 240V AC

EXT4-LED-333

28W LED Track Light Three Circuit

28W LED Three circuit track light with attached gear box and inbuilt Mean Well LED driver. Features high quality reflector with LOR 94.3%, and glass cover. Offers 355° rotation and 180° tilt. IES File available on request.

Material

Size

Die-cast Aluminium

Head: 89.5(Diameter) x 162.5(Height) mm

Gear Box: 84 x 184 x 46.5 mm

Black, White, Silver Colour

Lamp 28W Citizen LED

Led Colour Warm White

Lumen Output Warm White: 1946 Lm

Beam Angle 45°

Power 240V AC

EXT4-LED-327

LED Tracklight 6 x 3W Three Circuit

Large LED trackspot with in-built LED driver. Features adjustable head angle indicator dial on stem. IES File available on request

Material Aluminium

Size Head: 86 (Diameter) x 180 (Length) mm

Colour

Lamp

Anodised Silver

6 x 3W Edison LED

Led Colour Cool White

Lumen Output 1020Lm

Beam Angle 60°

Power 220-240V AC - 50/60Hz

96

Gentech Lighting

MULTI-CIRCUIT TRACK LIGHTS – LED

EXT4-LED-326

LED Tracklight 3 x 3W Three Circuit

Small LED trackspot with in-built LED driver. Features adjustable head angle indicator dial on stem. IES File available on request

Material Aluminium

Size Head: 60 (Diameter) x 130 (Length) mm

Colour

Lamp

Anodised Silver

3 x 3W Edison LED

Led Colour Cool White

Lumen Output 510Lm

Beam Angle 60°

Power 220-240V AC - 50/60Hz

EXT4-LED-328

LED Trackspot 1x10W Three Circuit

Directional LED modular trackspot. Features adjustable head and built in LED driver.

Material Aluminium

Size

Colour

Lamp

Head: 60 (Diameter) x 90 (Length) mm /

Driver Box: 81 (Length) x 40 (Width) x

120 (Height) mm

Silver, White

1 x 10W LED

Led Colour Cool White

Lumen Output 600Lm

Beam Angle 38°

Power 220-240V AC - 50/60Hz

Four wire track spots suitable for

LED lamps

Multi Circuit LED Track fittings. Features three circuit track adaptor with in-built 700mA 11W dimmable LED driver.

Material Track Adaptor: Plastic

Spotlight: Aluminium

Size

Lamp

Power

Track Adaptor: 180 x 38 x 30 (Height) mm

* For spotlight specifications see page references provided

LED-MR16-8W-D-CW-HP

(8W Dimmable Cool White)

LED-MR16-8W-D-WW-HP

(8W Dimmable Warm White)

240V AC

EXT4-LED-700MA-D-861

Round Head LED Track Light

Three Circuit

* Spotlight specifications on page 75

EXT4-LED-700MA-D-863

Square Head LED Track

Light Three Circuit

* Spotlight specifications on page 76

EXT4-LED-700MA-D-804

Pencil Head LED Track Light

Three Circuit

* Spotlight specifications on page 74

Gentech Lighting

EXT4-LED-700MA-D-859

Barndoor LED Track Light

Three Circuit

* Spotlight specifications on page 75

97

MULTI-CIRCUIT TRACK LIGHTS – LED

EXT4-LED-700MA-864

Bullet Head LED Track Light Three Circuit

Multi circuit LED track fitting. Features three circuit track adaptor with inbuilt 700mA non-dimmable LED driver.

Material Spotlight: Aluminium

Track Adaptor: Plastic

Size Track adaptor: 180 x 38 x 30 (Height) mm

Spot light: 58 (Face Diameter x

95 (length) mm, 45 (Stem) mm

Colour Black, Silver, White

Lamp LED-MR16-7W-CW

(7W non-dimmable Cool White)

LED-MR16-7W-WW

(7W non-dimmable Cool White)

Power 240V AC

EXT4-LED-871

4 Wire AR111 LED Track Light

AR111 Multi directional track light. Features multi circuit track adaptor with in built 700mA 16W dimmable LED driver.

Material Spotlight: Aluminium

Track Adaptor: Plastic

Size Spotlight head: 120 (Diameter) x

135 (Width) x 80 (Profile) mm

Track Adaptor: 180 x 38 x

30 (Height) mm

Colour White

Lamp LED-AR111-14W-CW

LED-AR111-14W-WW

Power 240V AC

98

Gentech Lighting

MULTI-CIRCUIT TRACK LIGHTS – DICHROIC

Various Low Voltage Dichroic Spot lights fitted with three circuit track adaptor and in built 12V transformer.

Dimmable on trailing or leading edge dimmers.

Custom made service availabe to modify track fittings with extension rods and knuckles etc.

Material Track Adaptor: Plastic

Spotlight: Aluminium

Size Track Adaptor: 172 x 38 x

30 ( Height) mm

For spotlight specifications see page references below

Black, Silver, White Colour

Lamp

Power

Max. 12V 50W Dichroic

220-240V AC - 50/60Hz

EXT4-LV-296B

Spotlight specs on page 74

Dimmable transformer housed in attached gear box.

EXT4-LV-804

Spotlight specs on page 74

EXT4-LV-861

Spotlight specs on page 75

EXT4-LV-863

Spotlight specs on page 76

EXT4-LV-864

Spotlight specs on page 76

EXT4-LV-865

Spotlight specs on page 76

EXT4-LV-867

Spotlight specs on page 76

EXT4-LV-853

Spotlight specs on page 75

EXT4-LV-855

Spotlight specs on page 75

EXT4-LV-859

Spotlight specs on page 75

MULTI-CIRCUIT TRACK LIGHTS – AR111

50W AR111 three circuit track light. Features three circuit track adaptor with inbuilt 12V 50W transformer, dimmable with leading or trailing edge dimmers.

For spotlight specifications see page references above

Material Track Adaptor: Plastic

Spotlight: Aluminium

Size

Lamp

Track Adaptor:

EXT4-LV-ADAPTOR

172 x 36 x 30 (Height) mm

Max. 50W AR111

Power 220-240V AC - 50/60Hz

EXT4-LV-871

AR111 Tracklight Three

Circuit

* Spotlight specifications on page 77

Gentech Lighting

EXT4-LV-875

AR111 50W Tracklight Three

Circuit

99

MULTI-CIRCUIT TRACK LIGHTS – GU10-GZ10

EXT4-GU296C

GU10 Contemporary Cube

Three Circuit Track Light

* Spotlight specifications on page 78

EXT4-GU295

GU10 Dapper Barrel Three

Circuit Track Light

* Spotlight specifications on page 78

Various GU10 Spot lights fitted with three circuit 240V track adaptors.

Material Track Adaptor: Plastic

Spotlight: Aluminium

Size EXT4-ADAPTOR:

84 x 33 x 30 (Height) mm

For spotlight specifications see page references below:

Colour

Lamp

Power

Black, Silver, White

Max. GU10 50W

220-240V AC - 50 60Hz

EXT4-GU304

GU10 Basic Barrel Head

Three Circuit Track Light

* Spotlight specifications on page 79

EXT4-GU280

Retro Spot Track Light

Three Circuit

* Spotlight specifications on page 78

MULTI-CIRCUIT TRACK LIGHTS – PLC

* Spotlight specifications on page 79

EXT4-9601 PLC Track Light Three Circuit

26W PLC spot light, fitted with 240V three circuit track adaptor.

Material

Size

Colour

Lamp

Power

Track Adaptor : Plastic

Spotlight: Aluminium

Track Adaptor: EXT4-ADAPTOR:

84 X 33 X 30 (Height) mm

For spotlight specifications see page

Silver, White

Max. 26W PLC

220-240V AC - 50/60Hz

MULTI-CIRCUIT TRACK LIGHTS – LINEAR HALOGEN

Linear Halogen three circuit track lights.

For spotlight specifications see page references above.

Size Track Adaptor:

EXT4-ADAPTOR

84 X 33 X 30 (Height) mm

Power 220-240V AC - 50/60Hz

EXT4-683

Shutter Flood Track Light

Three Circuit

* Spotlight specifications on page 80

100

EXT4-684

Linear Halogen Track Light

Three Circuit

* Spotlight specifications on page 80

Gentech Lighting

MULTI-CIRCUIT TRACK LIGHTS – METAL HALIDE

Three circuit Metal Halide track lights.

For spotlight specifications see page references above.

Material Track Adaptor: Plastic

Spotlight: Aluminium , Glass diffuser

Size

Power

Track Adaptor: EXT4-ADAPTOR

84 X 33 X 30 (Height) mm

220-240V AC - 50/60Hz

EXT4-9241

Barrel Metal Halide Track

Light Three Circuit

* Spotlight specifications on page 79

EXT4-9571

Metal Halide Flood Light

Three Circuit Track

* Spotlight specifications on page 79

EXT4-9575

G12 Metal Halide Track

Light Three Circuit

* Spotlight specifications on page 80

EXT4-9576N

G8.5 Metal Halide Track

Light Three Circuit

* Spotlight specifications on page 80

MULTI-CIRCUIT TRACK LIGHTS – PAR LAMP

EXT4-811

Plain Head Tracklight Single

Circuit

Spotlight specifications on Page 81

EXT4-606

Venus Track light Single Circuit

Spotlight specifications on Page 81

240V PAR lamp spot lights, fitted with 240V three circuit track adaptor.

For spotlight specifications see page references above.

Material Track Adaptor: Plastic

Spotlight: Aluminium

Size

Power

Track Adaptor:

EXT4-ADAPTOR: 84 x 33 x

30 (Height) mm

220-240V AC - 50/60Hz

EXT4-607

Jupiter Track Light Single

Circuit

Spotlight specifications on Page 81

EXT4-308

Saturn Track Light Three Circuit

Spotlight specifications on Page 81

Gentech Lighting

101

MULTI-CIRCUIT SURFACE MOUNT TRACKS

N

N

Elbow

Joiner 1

N

N

Live End

N

N

Track

Elbow

Joiner 2

EXT4B-1M, EXT4B-2M, EXT4B-3M,

EXT4B-4M

Surface mount 4-wire track. Maximum 16A for 3 circuits total. 25Kg weight load. Guide Lug for joiners and adaptors installation

Material Aluminium

Size

Colour

Power

Track width 33mm height 33mm.

Length:

EXT4B-1M: 1000 mm

EXT4B-2M: 2000 mm

EXT4B-3M: 3000 mm

EXT4B-4M: 4000 mm

Black, Silver, White

240V AC 50Hz

Example 1 – Basic Straight Option.

Ensure guide lug on track aligns with live end. As track has no direction it can be reversed to line up with live end.

Example 2 – Square Track Option

In this example consistent EJ joiners are used in the square to ensure neutral (green line) is maintained throughout the run.

Elbow

Joiner 4

Elbow

Joiner 3

Elbow

N

Joiner 1

N

N

Elbow

Joiner 2

Example 3 – Left/Right Angles Option

In this example different EJ joiners are used to ensure neutral (green line) is maintained throughout the run.

A

102

B

LEFT RIGHT

A: EXT4B-L Live End Three Circuit

Track B

4 Wire Live End to feed power to track. Picture showing left & right Live End.

Material Plastic

Colour White, Black, Silver

Power 240V AC 50Hz

B: EXT4B-IJ Straight Joiner Three Circuit

B Track

4 wire straight joiner suited to connect two three circuit tracks.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

Gentech Lighting

C: EXT4B-BJ Live Joiner Three Circuit

Track B

4 wire live joiner to connect two three circuit tracks in a straight line. Mains power may be connected from this joiner.

Material Plastic

Colour

Power

Black, Silver, White

240V AC 50Hz

D: EXT4B-FJ Flexible Joiner Three Circuit

B Track

4 wire flexible joiner suited to connect two three circuit tracks.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

E: EXT4B-EJ

Elbow Joiner 3 Circuit B Track

Joiner for 90 degree angles. Picture showing Left & Right

End.

Material Plastic

Colour White, Black, Silver

Power 240V AC 50Hz

MULTI-CIRCUIT SURFACE MOUNT TRACKS

C

LEFT

RIGHT

D

E

F: EXT4B-TJ

T Joiners 3 Circuit B Track

T Joiners for 3 circuit B Track.

Available as left and right T Joiners

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

G: EXT4B-XJ

Cross Joiner Three Circuit B Track

4 wire live cross joiner suited to connect four three circuit tracks. Mains power may be connected from this joiner.

Material Plastic

Colour Black, Silver, White

Power 240V AC 50Hz

H: EXT4B-END

End Cap 3 Circuit B Track

Track B End Cap to terminate track run.

Material Plastic

Colour White, Black, Silver

G

Gentech Lighting

F

H

103

MULTI-CIRCUIT SURFACE MOUNT TRACKS

J

I

I: EXT4B-SUSP-CLIPLOCK

Clip Lock Suspension Kit For Four

Wire Track

Suspension Kit for 4 wire track with clip lock Carabiner.

Adjustable 3 metre maximum length.

Material Aluminium, steel cable

Size 3M

Colour Black, Silver, White

J: EXT4B-SUSP-KIT

Suspension Kit For Four Wire Track

Suspension Kit for 4 wire track. Adjustable 3 metre maximum. length.

Material Aluminium, steel cable

Size 3M

Colour Black, Silver, White

K

K: EXT4B-ROD-SUSP

Rod Suspension for Three Circuit Track

Adjustable rod suspension kit to suit 3 circuit track.

Adjust from 200mm to 1000mm

Material

Size

Colour

Steel & copper

Max 850 mm length.

Black, Silver, White

104

Gentech Lighting

EXT4C-2M, EXT4C-3M

4 Wire Multi Circuit Track Recessed

Recess mount 4-wire track. Maximum 16A for 3 circuits total. Four isolated copper conductors grounded via a separate copper bus bar in the track. Mounting brackets recommended

Material : Aluminium

Size : Track width 33 mm (55 mm with Flange) height 33 mm.

Length:

EXT4B-2M 2000 mm

EXT4B-3M 3000 mm

Colour White

Power 240V AC 50Hz

A: EXT4C-L

Live End for Recessed Track

Recessed 4 wire live end to feed power to track.

Available as Left or Right Live-ends.

Material Plastic

Colour White

Power 240V AC 50Hz

B: EXT4C-BJ

Live Joiner Three Circuit Recessed Track

4 wire live joiner to connect two recessed tracks in a straight line. Mains power may be connected from this joiner.

Material Plastic

Colour White

Power 240V AC 50Hz

C: EXT4C-EJ

Elbow Joiner Three Circuit Recessed Track

4 wire live elbow joiner to connect two recessed tracks at a 90° angle. Available as Left or Right Elbow Joiners.

Mains power may be connected from this joiner

Material Plastic

Colour White

Power 240V AC 50Hz

D: EXT4C-MB

Mounting Bracket

Mounting bracket for recessed track

Material Steel

A

C

MULTI-CIRCUIT RECESSED TRACKS

B

D

Gentech Lighting

105

MULTI-CIRCUIT RECESSED TRACKS

Installation of 3 Circuits Track Adaptor

A

1. Turn dial to “off ” position.

2. Switch lever to open.

B

Insert track adaptor

Removing of 3 Circuits Track Adaptor

C

1. Switch lever and ock into place.

2. Turn dial to number selection.

A

1. Turn dial to “off ” position.

2. Switch lever to open.

B

Remove track adaptor angle from dial end of adaptor.

MULTI-CIRCUIT ACCESSORIES

A

A: EXT4-M-ADAPTOR

Mechanical Track Adaptor

Mechanical Track Adaptor for 4wire Track

Material Aluminium

Colour White

B

B: EXT4-LV-ADAPTOR

12V Three Circuit Track Adaptor

Low Voltage Track adaptor for 3 circuit track. Features inbuilt 12V 60 VA electronic dimmable transformer with

3 way switch.

Material Plastic

Size

Colour

Power

Output

172 X 38 X 30( Height) mm

Black, Silver, White

220-240V AC ~ 50/60Hz

11.4V ~ eff, 5A, 20-60W / VA

Temperature ta: 50°C, tc: 75°C

106

Gentech Lighting

C: EXT4-ADAPTOR

Track Adaptor

4 wire 240V Track Adaptor.

Material Plastic

Colour

Power

White, Black, Silver

240V AC 50Hz

D: EXT4-700MA-D-11W-ADP

Multi Circuit Dimmable LED Track

Adaptor 11W

Multi circuit track adaptor with in built 700mA 11W dimmable LED driver.

Material Plastic

Size

Colour

180 x 38 x 30 (Height) mm

Black, Silver, White

Power

Output

Primary : 220-240V AC~ 50/60Hz, 0.13A

Constant Current : 700mA, Voltage :

4-16V DC

Temperature ta= 50°C, tc= 72°C

E: EXT4-700MA-D-16W-ADP

Multi Circuit Dimmable LED Track

Adaptor 16W

Multi circuit track adaptor with in built 700mA 16W dimmable LED driver.

Material Plastic

Size 180 x 38 x 30 (Height) mm

Colour

Power

Black, Silver, White

Primary: 220-240V AC~ 50/60Hz, 0.15A

Output Constant Current: 700mA,

Voltage: 2-24V DC

Temperature ta= 40°C, tc= 85°C

MULTI-CIRCUIT ACCESSORIES

C

D, E

Gentech Lighting

107

108

Gentech Lighting

G7560 Ice Stone GX53

Compact surface mount energy saver fitting. Features stylish aluminium surround with screw cap face and decorative sealed frost glass.

Material Aluminium frost lens

Size

Colour

Lamp

Power

IP Rating

102 (Diameter) x 60 (Height) mm

Brushed Aluminium/Frost

Max. 240V/GX53/7W with 24mm thickness

Optional LED lamps available

240V AC 50Hz

IP54

G7561 Rocco GX53

Compact surface mount energy saver fitting. Features stylish aluminium surround with screw cap face and flush frost glass.

Material Aluminium frost lens

Size

Colour

Lamp

Power

IP Rating

89 (Diameter) x 60 (Height) mm

Brushed Aluminium/Frost

Max. 240V/GX53/13W

Optional LED lamps available

240V AC 50Hz

IP54

GX53 Lamp Options

7W: 300 Lumens

24mm Thickness

FLUORESCENT GX53

9W: 400 Lumens

36mm Thickness

LGX53-7W

G2520 Grace Vanity Light

Surface mount T5 fluorescent vanity light. Features chrome end caps and opal acrylic wrap around diffuser lamp not included.

Material

Size

Plastic, acrylic

8W/340mm 14W/595mm

24W/595mm

Colour Chrome/Frost

Lamp T5 8W, 14W, and 24W

Power 240V AC 50Hz

IP Rating IP41

Gentech Lighting

LGX53-9W

FLUORESCENT T5

109

FLUORESCENT T5

110

G2525 Cosmos Wall Light

Attractive and functional wall light. Features slim clean lines decorative frost/opal glass frost glass front strip. Allen key access for lamp replacement.

Material Aluminium, glass

Size 585 (Length) x 38 (Height) x

85 mm (Projection)

Colour Opal/Aluminium

Lamp

Power

T5 14W Max.

240V AC 50Hz

G2531 Elegance Vanity Light 600mm

Surface mount T5 vanity fluorescent with low profile satin adjustable reflector and frost diffuser lamp not included.

Material Plastic, acrylic

Size 600 (Length) x 70 (Depth) mm

Colour Frost/Silver

Lamp

Power

T5 14W, and 24W

240V AC 50Hz

G740-22W Opal Acrylic Round 22W

Classic design T5 circular fluorescent with round acrylic opal diffuser and electronic ballast. Back plate fitted with slot diffuser clips for stability and easy operation. Suitable for domestic and commercial environments.

Material

Size

Aluminium, acrylic

280 mm (Diameter)

Colour

Lamp

Power

White, opal

T5 22W Circular Fluoroscent

240V AC 50Hz

G740-32W Opal Acrylic Round 32W

Classic design T5 circular fluorescent with round acrylic opal diffuser and electronic ballast. Back plate fitted with slot diffuser clips for stability and easy operation. Suitable for domestic and commercial environments.

Material

Size

Aluminium, acrylic

350 mm (Diameter)

Colour

Lamp

Power

White, opal

T5 32W Circular Fluoroscent

240V AC 50Hz

Gentech Lighting

FLUORESCENT T5

G741-22W Opal Acrylic Square 22W

G741-32W Opal Acrylic Square 32W

Classic design T5 circular fluorescent with square acrylic opal diffuser and electronic ballast. Back plate fitted with plastic diffuser locks for stability and easy operation.

Suitable for domestic and commercial environments.

Material Aluminium, acrylic

Size

Colour

Lamp

Power

G741-22W – 280 (Length) x

280 (Width) mm

G741-32W – 350 (Length) x

350 (Width)mm

White, opal

T5 32W Circular Fluoroscent

240V AC 50Hz

G7147 Square Clipper

Square polycarbonate wall light with easy clip front diffuser offering easy access for lamp replacement.

Material Polycarbonate

Size 195 (Length) x 195 (Width) x

75 (Profile) mm

Colour

Lamp

Power

IP Rating

White/Opal, Black/Opal

Max. 40W E14

Optional 13W, 18W PLC kits availabl

Optional Led lamp available

240V AC 50Hz

IP44

EX3-DS Satin Oyster 30cm

Decorative satin glass oyster. Brass or chrome clip colour optional.

Material

Size

Pressed Metal, Glass

30 cm

Colour

Lamp

Power

Satin Frost-Brass, Satin Frost-Chrome

1x60W ES

240V AC 50Hz

EX4-DS Satin Oyster 40cm

Decorative satin glass oyster. Brass or chrome clip colour optional.

Material Pressed Metal, Glass

Size 40cm

Colour Satin Frost-Brass, Satin Frost-Chrome

Lamp

Power

2x60W ES

240V AC 50Hz

Gentech Lighting

FLUORESCENT PLC

INCANDESCENT

111

LED

LED331 Showcase I

Single arm cabinet display light. 1W(350mA) Osram LED.

Features flexible gooseneck giving full adjustment. Stem can be altered to desired length. Requires 350mA driver

Material Light head : Anodized Aluminium

Flexible Tube : Powder coated Steel

Stick : Powder coated Copper

Size Stem 283 mm / Gooseneck/head 92mm

Colour Aluminium

Lamp 1.2W Osram LED

Led Colour Cool White

Lumen Output 1200cd

Beam Angle 15°

Power 350mA Constant Current

LED332 Showcase II

2 Light cabinet display light. 2x1W(350mA) Osram LED.

Features flexible knuckle joints on head for 90° tilt and

355° rotation. Stem can be altered to desired length.

Requires 350mA driver

Material

Size

Light head : Anodized Aluminium

Flexible Tube : Powder coated Steel

Stick : Powder coated Copper

Stem 312mm

Colour Aluminium

Lamp 2 x 1.2W Osram LED

Led Colour Cool White

Lumen Output 1200cd

Beam Angle 15°

Power 350mA Constant Current

G370-LED Tiffany Showcase

Unique aluminium cabinet display light. Features 1W led and glass lens. Sturdy design in white powder coated finish.

Material Aluminium

Size 200 (Height) x 8 (Thick) mm,

35 (Diameter) mm

Colour White

Lamp 1W Cree LED

Led Colour Warm White :3000K

Lumen Output 90Lm

Power 350mA Constant Current

Gentech Lighting

113

LED

114

G371-LED Jacob Showcase

Unique aluminium cabinet display light. Features 1W led and glass lens. Sturdy design in white powder coated finish.

Material Aluminium

Size 300 (Height) x 8 (Thick) x 70 (Profile) mm,

35 (Diameter) mm

Colour White

Lamp 1W Cree LED

Led Colour Warm White:3000K

Lumen Output 90Lm

Power 350mA Constant

Current

LED-5STAR-S LED 5 Star

Plug and play LED strip light. Offers a versatile low profile easy with installation and on/off switch. Comes with

90cm lead and connector. Selectable rear or side wire connections.

Material Aluminium

Size 470 (Length) x 28 (Width) x

12 (Height) mm

Colour Aluminium

Lamp 5 x 1W LED

Led Colour Cool White, Warm White

Power 12V DC or 24V DC

IP Rating IP41

LED-RULE LED Rule

Versatile linkable strip light. Features a low profile making it ideal for orientation display and accent lighting with easy installation. Available with a range of accessories to suit most applications.

Material

Size

Anodized Aluminium, Plastic

24LED: 300 (Length) x 15 (Width) x

10 (Height) mm

48LED: 600 (Length) x 15 (Width) x

10 (Height) mm

Colour Silver

Lamp 24LED: 24 x 0.06W LED

48LED: 48 x 0.06W LED

Led Colour Cool White, Warm White

Lumen Output 24LED Warm White - 136 Lm

48LED Warm White - 293 Lm

Power

IP Rating

24V DC

IP20

Gentech Lighting

LED-RULE-LE

Live End LED Rule

Live end for LED-RULE with rear or side wire connections selectable

LED-RULE-FJ

Flexible Joiner LED Rule

Flexible Joiner for LED Rule

Size 15 x 10 x 45mm

LED-RULE-EC

End Cap LED Rule

End Cap for LED Rule

LED-RULE-LE

LED-RULE-LE

LED-RULE-FJ

LED-RULE

LED-RULE-EC

LED-RULE-FJ

LED

LED-RULE-EC

12V

G805 Cabinet Display Spot

Versatile cabinet display light. Stem can be cut to size required. Optional LED version available

Material Copper

Size 210 (Height) mm

Colour Chrome

Lamp

Power

Max. 12V/35W MR11 Dichroic

12V AC

Gentech Lighting

115

LED-320-R

Round Slot LED Floor Washer

LED 1W recessed round aluminium wall light. Features 1 x Edison LED and quick connect plug for easy connection.

Requires 350mA constant current driver.

Material Aluminium

Size 50 (Diameter) x 45 (Depth) mm

Colour Aluminium

Lamp 1W Edison LED

Led Colour Cool White (4500k)

Warm White (3000k)

Lumen Output Cool White: 92 Lm

Warm White: 85 Lm

Power

Cut Hole

350mA Constant Current

42mm

LED-320-SQ

Square Slot LED Floor Washer

LED 1W recessed square aluminium wall light. Features 1 x Edison LED and quick connect plug for easy connection.

Requires 350mA constant current driver.

Material Aluminium

Size 50 (Width) x 50 (Height) x

45 (Depth) mm

Colour Aluminium

Lamp 1W Edison LED

Led Colour Cool White (4500k)

Warm White (3000k)

Lumen Output Cool White: 92 Lm

Warm White: 85 Lm

Power

Cut Hole

350mA Constant Current

42mm

LED-330-R

Round Slit LED Floor Washer

LED 1W semi recessed round aluminium wall light.

Features 1 x Edison LED and quick connect plug for easy connection.

Material Aluminium

Size 40 (Diameter) mm, 40 (Depth) mm

Colour Aluminium

Lamp 1W Edison LED

Led Colour Cool White (4500k)

Warm White (3000k)

Lumen Output Cool White: 92 Lm

Warm White: 85 Lm

Power

Cut Hole

350mA Constant Current

25mm

Gentech Lighting

WALL RECESSED LED

117

WALL RECESSED LED

118

LED-330-SQ

Square Slit LED Floor Washer

LED 1W semi recessed square aluminium wall light.

Features 1 x Edison LED and quick connect plug for easy connection.

Material Aluminium

Size 40 (Width) x 40 (Height) x

40 (Depth) mm

Colour Aluminium

Lamp 1W Edison LED

Led Colour Cool White (4500k)

Warm White (3000k)

Lumen Output Cool White: 92 Lm

Warm White: 85 Lm

Power

Cut Hole

350mA Constant Current

25mm

G901-LED-RE

Kindel Recessed

3W LED recessed wall light. Offers 352° rotation on lamp bode and 90° tilt on lamp shaft. Features inbuilt

700mA LED driver, LED chip and lens. Indicator light option available.

Material Aluminium

Size 115 (Overall Diameter) x 33 (Profile) mm;

40 (Depth) mm

Colour Silver

Lamp 1 x 3W Osram LED

Led Colour Cool White : 4000K

Warm White : 3000K

Beam Angle 60°

Power 100~240V AC, 50/60Hz

Cut Hole 77mm

G905-LED-RE

Colin Reading Light

Stylish reading light. Square flat panel face with adjustable luminaire, offers 355° rotation and 20° tilt. Features

20° cut-off angle for visual comfort, and inbuilt 350mA constant current LED driver

Material

Size

Die-cast Aluminium

85 x 85 x 59 (Depth) mm

Colour Silver

Lamp 1 x 3W OSRAM OSLON LED

LED Colour Warm White

Lumen Output 139 Lm

Power

Cut Hole

240V AC

73mm

Gentech Lighting

G906-LED-RE

William Reading Light

Stylish reading light. Rectangular flat panel face with adjustable luminaire, offers 355° rotation and 20° tilt.

Features 20° cut-off angle for visual comfort, and inbuilt

350mA constant current LED driver

Material

Size

Die-cast Aluminium

160 x 85 x 44.3 (Depth) mm

Colour Silver

Lamp 1 x 3W OSRAM OSLON LED

LED Colour Warm White

Lumen Output 139 Lm

Power

Cut Hole

240V AC

Oblong cut out

Refer to template

LED-GW033

LED Mini Square Wall Light

LED 3W recessed wall light with tempered frost glass diffuser. Complete with 700mA constant current driver.

Material Aluminium

Size 90 (Width) x 90 (Height) mm

Colour Grey

Lamp 3W Epistar Chip

Led Colour Warm White

Lumen Output 300 Lm

Power 700mA Constant Current

Cut Hole 70 x 70mm

G845-LED

Wall Washer

LED wall washer or floor washer. Features glare shield and easy re-lamp access. LED lamp and driver included.

Material Aluminium

Size 102 (Width) x 102 (Height) x

42 (Depth) mm

Colour White

Lamp LED Bi-Pin 12VDC up to 3W

Led Colour Warm White

Power 12V DC

Cut Hole 95 x 95mm

Gentech Lighting

WALL RECESSED LED

119

WALL RECESSED LED

120

LED-PANEL-18W

LED Rectangular Downlight - Wall Light

18W Rectangular LED Downlight / Wall Light.

Available in Cool White and Warm White.

LED Driver Included.

Material Aluminium

Size 250 (Length) x 125 (Width) x

25 (Height) mm

Colour Aluminium

Lamp 18W LED

Led Colour Cool White, Warm White

Power Input: 220-240V~ 50/60Hz

Cut Hole 215 x 105 mm

G840N-LED

LED Mini Square

LED 3W recessed wall light. Attractive and functional, features inbuilt warm white LED chip, magnetic mounting face with frost diffuser, 150mm double insulated cable for screw terminal LED Driver.

Material Aluminium

Size

Colour

68 (Width) x 68 (Height) x

32 (Depth) mm

Brass, Brushed Chrome, Satin Chrome,

White

1 x 3W LED Lamp

Led Colour Warm White

Power 700mA Constant Current

Cut Hole 57 x 57 mm

G841-LED

LED Midi Square

LED 3W recessed wall light. Attractive and functional, features clip on face and frost glass diffuser and 150mm of double insulated cable for screw terminal LED driver.

Material

Size

Aluminium, tempered glass lens

112 (Width) x 112 (Height) x

62 (Depth) mm

Colour

Lamp

Brushed Chrome, Satin Chrome, White

3W LED

LED Colour Warm White

Power 700mA Constant Current

Cut Hole 82 x 82 mm

Gentech Lighting

WALL RECESSED LED

G843P-LED

LED Square Clip On

Attractive and functional LED square wall light with in built LED and satin reflector for efficient light distribution.

Features clip-on face and frost glass diffuser.

Available in blue cool white and warm white.

Material

Size

Aluminium frame, Tempered glass lens

90 x 90 x 60 mm

Colour Grey

Lamp 1.2W LED

Led Colour Blue, Cool white, Warm white

Power 350mA Constant Current

Cut Hole 72 x 72 mm

G840N Mini Square

Attractive and functional recessed fitting. Features magnetic mounting face with frost glass diffuser or louvre.

Material

Size

Aluminium, tempered glass lens

68 (Width) x 68 (Height) x

32 (Depth) mm

Colour

Lamp

Power

Cut Hole

White, Brass, Satin Chrome,

Brushed Chrome

Max. 12V 20W G4 Halogen

Optional LED lamps available

12V AC

57 x 57 mm

G840N-L Mini Square Louvre

Attractive and functional recessed fitting. Features magnetic mounting face with frost glass diffuser or louvre.

Material

Size

Aluminium, tempered glass lens

68 (Width) x 68 (Height) x

32 (Depth) mm

Colour White

Lamp Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

57 x 57 mm

Gentech Lighting

WALL RECESSED 12V

121

WALL RECESSED 12V

122

G841N Midi Square

Attractive and functional recessed fitting. Features clip on face and frost glass diffuser.

Material

Size

Aluminium, tempered glass lens

112 (Width) x 112 (Height) x

42 (Depth) mm

Colour

Lamp

White, Brass, Satin Chrome,

Brushed Chrome

Max. 12V 50W G6.35 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

82 x 82 mm

G843P Plain Face

Attractive and functional recessed fitting. Features clip-on face and frost glass diffuser.

Material

Size

Aluminium, tempered glass lens

90 (Width) x 90 (Height) x

31 (Depth) mm

Colour Silver

Lamp Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

75 x 75 mm

G843C Cross Face

Attractive and functional recessed fitting. Features clip-on face and frost glass diffuser.

Material

Size

Aluminium, tempered glass lens

90 (Width) x 90 (Height) x

31 (Depth) mm

Colour Silver

Lamp Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

75 x 75 mm

G843L Louvre Face

Attractive and functional recessed fitting. Features clip-on face and frost glass diffuser.

Material

Size

Aluminium, tempered glass lens

90 (Width) x 90 (Height) x

31 (Depth) mm

Colour Silver

Lamp Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

75 x 75 mm

Gentech Lighting

G843S Screen Face

Attractive and functional recessed fitting. Features clip-on face and frost glass diffuser.

Material

Size

Aluminium, tempered glass lens

90 (Width) x 90 (Height) x

31 (Depth) mm

Colour Silver

Lamp Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

75 x 75 mm

GW033 Mini Square Floor Washer

Low voltage recessed wall light with tempered frost glass diffuser.

Material Aluminium

Size 90 (Width) x 90 (Height) x

90 (Depth) mm

Colour Grey

Lamp Max. 12V 50W G6.35 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

70 x 70 mm

GW034 Long Shovel Floor Washer

Low voltage recessed wall light.

Material Aluminium

Size 80 (Width) x 235 (Height) x

70 (Depth) mm

Colour Grey

Lamp Max. 12V 50W G6.35 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

215 x 66 mm

GW036 Up-Down Wall Washer

Low voltage up-down wall light with ribbed reflector.

Centre cover strip detaches for easy lamp replacement.

Material Aluminium

Size 140 (Width) x 250 (Height) x

75 (Depth) mm

Colour Grey

Lamp Max. 2 x 12V 50W G6.35 Halogen

Optional LED lamps available

Power

Cut Hole

12V AC

120 x 220 mm

Gentech Lighting

WALL RECESSED 12V

123

WALL RECESSED 240V

GW035 Wide Shovel Floor Washer

Electronic Ballast

Compact fluorescent recessed wall light. Available with choice of 10 or 13W Electronic or Iron core ballast.

Material Aluminium

Size 190 (Width) x 245 (Height) x

80 (Depth) mm

Colour Grey

Lamp For Electronic ballast – 10 or

13W G24q-1 PLC

For Iron core ballast –

10 or 13W G24d-1 PLC

Power

Cut Hole

240V AC 50Hz

235 x 175 mm

GW037 Wide Shovel Floor Washer

Magnetic Ballast

Compact fluorescent recessed wall light with satin reflector and decorative slot on face of fitting.

Material Aluminium

Size 192 (Width) x 247 (Height) x

55 (Depth) mm

Colour Grey

Lamp Max. 13W G24d-1 PLC

Power

Cut Hole

240V AC 50Hz

235 x 175 mm

WALL SURFACE MOUNT LED

124

LED325 Bookworm Square

LED mini aluminium wall light with on/off switch on base.

Wall light head is fitted with a 3W LED. Arm rotates giving full head adjustment. In-built LED driver in base.

240V input connection for easy installation.

Material Aluminium

Size Head 29 (Length) x 29 (Width) x

100 (Height) mm,

Backplate: 70 (Length) x 70 (Width) x

33 (Height) mm

Colour

Lamp

Aluminium, Brushed Brass, Brass, Brown

3W LED

Led Colour Cool White

Power 240V AC ~ 50/60Hz

In-built 700mA 3.5W DC Driver

Gentech Lighting

LED325R-BR Bookworm Round Brass

LED mini aluminium wall light with on/off switch on base.

Wall light head is fitted with a 3W LED. Arm rotates giving full head adjustment. In-built LED driver in base.

240V input connection for easy installation.

Material Aluminium

Size Head 30 (Diameter) mm x 100 mm,

Backplate 87 (Diameter) mm x

35 (Height) mm

Colour

Lamp

White, Black, Aluminium, Polished Brass

3W LED

Led Colour Cool White

Power 240V AC ~ 50/60Hz

In-built 700mA 3.5W DC Driver

LED325R-BK Bookworm Round Black

Mini aluminium wall light with on/off switch on base. Wall light head is fitted with a 3W LED. Arm rotates giving full head adjustment. In-built LED driver in base. 240V input connection for easy installation. Available in cool white light colour.

Material Aluminium

Size Head 30 (Diameter) mm x

100 (Length) mm,

Back plate 87 (Diameter) mm x

35 (Height) mm

Colour

Lamp

Matt Black

3W LED

Led Colour Cool White

Power 240V AC ~ 50/60Hz

In-built 700mA 3.5W Constant Current

Driver

LED325R-ALU

Bookworm Round Aluminium

Mini aluminium wall light with on/off switch on base. Wall light head is fitted with a 3W LED. Arm rotates giving full head adjustment. In-built LED driver in base. 240V input connection for easy installation.

Material Aluminium

Size Head 30 (Diameter) mm x

100 (Lenght) mm

Back plate 87 (Diameter) mm x

35 (Height) mm

Colour

Lamp

Brushed Aluminium

3W LED

Led Colour Cool White

Power 240V AC ~ 50/60Hz

In-built 700mA 3.5W Constant Current

Driver

Gentech Lighting

WALL SURFACE MOUNT LED

125

WALL SURFACE MOUNT LED

126

LED325R-WH

Bookworm Round White

LED mini aluminium wall light with on/off switch on base.

Wall light head is fitted with a 3W LED. Arm rotates giving full head adjustment. In-built LED driver in base.

240V input connection for easy installation.

Material Aluminium

Size Head 30 (Diameter) mm x

100 (Length) mm,

Backplate 87 (Diameter) mm x

35 (Height) mm

Colour White

Lamp 3W LED

Led Colour Cool White

Power 240V AC ~ 50/60Hz

In-built 700mA 3.5W DC Driver

G901-LED-SM Kindel Surface Mount

3W LED surface mount wall light. Offers 352° rotation on upper deck and 90° tilt on lamp shaft. Features inbuilt

700mA LED driver, LED chip and lens. Indicator light option available.

Material Aluminium

Size 76 (Diameter) x 53 (Profile) mm

Colour Silver

Lamp 1 x 3W Osram LED

Led Colour Cool White : 4000K

Warm White : 3000K

Beam Angle 60°

Power 100~240V AC, 50/60Hz

LED-322-R

Round Slot LED Floor Washer

Surface Mount

LED 1W surface mount wall light. Features 1 x 1W

Edison LED and quick connect plug for easy connection.

Available in Commercial White and Warm White.

Material Aluminium

Size 50mm (Diameter), 36mm (Depth)

Colour Aluminium

Lamp 1 X 1W Edison LED

Led Colour Commercial White (4500K)

Warm White (3000K)

Lumen Output Commercial White – 92 Lm

Warm White – 85 Lm

Power 350mA Constant Current

Gentech Lighting

PA-322R-SLEEVE

Surface Mount Round Sleeve LED-322-R

Round aluminium sleeve to surface mount LED-322.

Includes 2 x 10mm flat head screws for mounting.

Material Aluminium

Size 50mm (Diameter) 33mm (Depth)

Colour Aluminium

LED323 Night Owl

LED 1 x 3W anodised aluminium wall light with flexible goose neck and on/off switch on base. Inbuilt 700mA driver in base. 240V input connection for easy installation.

Material Aluminium

Size Head: 65 mm, Gooseneck: 295mm,

Backplate: 80 (Length) x 65 (Width) x

30 (Height) mm

Colour

Lamp

Anodised Aluminium

3W LED

Led Colour Cool White

Lumen Output 53Lm

Power 240V AC ~ 50/60Hz

Induilt 700mA 3.5W DC Driver

LED511

LED 1x3W Surface Mount Wall Light

Compact LED up or down wall light. Features contemporary design with frost diffuser and in-built

350mA driver.

Material

Size

Colour

Die-cast Aluminium

110 (Width) x 70 (Height) x

40 (Profile) mm

Aluminium, White

Lamp 1 x 3W Samsung LED

Led Colour Warm White

Power

IP Rating

240V AC 50Hz

IP54

LED512

LED 2x3W Surface Mount Wall Light

Compact LED up or down wall light. Features contemporary design with frost diffuser and in-built

350mA driver.

Material

Size

Die-cast Aluminium

170 (Width) x 75 (Height) x

45 (Profile) mm

Colour White

Lamp 2 x 3W Citizen LED

Led Colour Warm White

Power 240V AC 50Hz

IP Rating IP54

Gentech Lighting

WALL SURFACE MOUNT LED

127

WALL SURFACE MOUNT LED

128

LED513

LED 3x3W Surface Mount Wall Light

Compact LED up or down wall light. Features contemporary design with frost diffuser and in-built 350mA driver.

Material

Size

Die-cast Aluminium

230 (Width) x 75 (Height) x

45 (Profile) mm

Colour White

Lamp 3 x 3W Citizen LED

Led Colour Warm White

Power

IP Rating

240V AC 50Hz

IP54

LED514 LED 3W Up and Down Wall Light

Compact LED up and down wall light. Features contemporary design. Requires 350mA Constant Current Driver.

Material

Size

Die-cast Aluminium

110(Width) x 62(Height) x

32(Profile) mm

Colour White

Lamp 1 x 3W Citizen LED

Led Colour Warm White

Power 350mA Constant Current

IP Rating IP54

GW056-LED Venus Wall Light LED

Unique design wall light features aluminium body, frost glass and coin slot feature. Complete with 2 x 5W LEDs and an in-built 10.8W 350mA constant current LED driver.

Material Aluminium

Size 132 (Height) x 132 (Width) x

135 (Profile) mm

Colour Silver

Lamp 2 x 5W Edison LED

Led Colour Warm White

Power Input : 220-240V AC ~ 50/60Hz

Output

IP Rating

Driver : 350mA Constant Current 1 -

10.8W Max. ; 3-31V DC

IP44

LED415

LED 6W Ribbed Reflector Wall Washer

Stylish surface mounted LED wall light. Features conical aluminium reflector, clear glass diffuser and in-built

700mA driver.

Material

Size

Die-cast Aluminium

180 (Width) x 30 (Height) x

137 (Profile) mm

Colour White

Lamp 1 x 6W Citizen LED

Led Colour Warm White

Power 240V AC 50Hz

IP Rating IP20

Gentech Lighting

LED416

LED 6W Curved Reflector Wall Washer

Stylish surface mounted LED wall light. Features convex white reflector, clear glass diffuser and in-built 700mA driver.

Material Die-cast Aluminium

Size 180 (Width) x 200 (Height) x

136 (Profile) mm

Colour White

Lamp 1 x 6W Citizen LED

Led Colour Warm White

Power

IP Rating

240V AC 50Hz

IP54

LED401 LED 2x3W Up-Down Wall Light

LED 2 x 3W compact aluminium surface mount up-down wall light. Features 2 x 3W LED and frost diffusers.

Material Aluminium

Size 80 (Length) x 75 (Width) x

17 (Profile) mm

Colour White, Aluminium

Lamp 2 x 3W LED CITIZEN

Led Colour Warm White

Power 350mA (Constant Current)

LED402 LED 1x3W Wall Light

LED 1 x 3W compact aluminium surface mount wall light.

Features 1 x 3W LED and frost diffuser.

Material Aluminium

Size 90 (Length) x 75 (Width) x

17 (Profile) mm

Colour Aluminium

Lamp 1 x 3W LED CITIZEN

Led Colour Warm White

Power 350mA (Constant Current)

G424-LED Bittern Wall Light

Contemporary wall light for interior and exterior locations. Features solid housing and 4W LED.

Material

Size

CNC Aluminium

80 (Width) x 110 (Profile) x 40 (Height) mm

Colour White

Lamp 4W Samsung LED

Led Colour Warm White:3000K

Lumen Output 300Lm

Power

IP Rating

100-240V AC

IP54

Gentech Lighting

WALL SURFACE MOUNT LED

129

WALL SURFACE MOUNT LED

130

G426-LED-HG Tuile Wall Light Gloss

Classy wall light with a high gloss finish for interior use.

Features solid housing and 2 x 3W LED. Offers warm soft two way up and down light.

Material Aluminium

Size

Colour

200 (Width) x 63 (Profile) x 120 (Height) mm

High Gloss White,

High Gloss Black

Lamp 2 x 3W Citizen LED

Led Colour Warm White :3000K

Lumen Output 500Lm

Power Input: 220-240V AC ~ 50/60Hz

Power factor Driver: λ= .4

Output Driver: 350mA Constant Current 6-9W,

18-28V DCG426-LED-HG

G428-LED Tuile Wide Wall Light

Classy wall light with a matt finish for interior use.

Features solid housing and 2 x 27 x .3W LED. Offers warm soft two way up and down light.

Material Aluminium

Size 400 (Width) x

63 (Profile) x

120 (Height) mm

Colour White

Lamp 2 x 27x.3W Samsung LED

Led Colour Warm White:3000K

Lumen Output 1620Lm

Power Input: 220-240V AC ~ 50/60Hz

Power factor Driver: λ= .4

Output Driver: 350mA Constant Current 6-9W,

18-28V DC

G429-LED Lorne Wall Light

Stylish hollow wall light. Features solid powder coated aluminium housing, offers reflective light for soft even spread.

Material CNC Aluminium

Size 60 (Height) x

182 (Width) x

100 (Profile) mm

Colour White

Lamp 18 x 0.3W Samsung LED

Led Colour Warm White:3000K

Lumen Output 540Lm

Power Input: 220-240V AC ~ 50/60Hz

Output

IP Rating

Driver: 700mA Constant Current

6-9W,12V DC

IP54

Gentech Lighting

G430-LED Corinella Wall Light

Stylish hollow wall light. Features solid powder coated aluminium housing, offers up and down reflective light for soft even spread.

Material

Size

CNC Aluminium

80 (Height) x

182 (Width) x

120 (Profile) mm

182

120

Colour White

Lamp 18 x 0.3W Samsung LED

Led Colour Warm White: 3000K

Lumen Output 540Lm

Power

Output

IP Rating

Input: 220-240V AC ~ 50/60Hz

Driver: 700mA Constant Current

6-9W,12V DC

IP54

G431-LED Toora Wall Light

Stylish hollow wall light. Features solid powder coated aluminium housing, offers up and down reflective light for soft even spread.

Material

Size

CNC Aluminium

100 (Height) x

100 (Width) x

120 (Profile) mm

Colour White

Lamp 18 x 0.3W Samsung LED

Led Colour Warm White: 3000K

Lumen Output 540Lm

Power

Output

Input: 220-240V AC ~ 50/60Hz

IP Rating

Driver: 700mA Constant Current

6-9W,12V DC

IP54

G432-LED Nelson Wall Light

Stylish hollow wall light. Features solid powder coated aluminium housing, offers up and down reflective light for soft even spread.

Material

Size

CNC Aluminium

60 (Height) x 300 (Width) x 175 (Profile) mm

Colour White

Lamp 18 x 0.3W Samsung LED

Led Colour Warm White: 3000K

Lumen Output 540Lm

Power Input: 220-240V AC ~ 50/60Hz

Output

IP Rating

Driver: 350mA Constant Current

4-7.2W, 10.5-21V DC

IP54

Gentech Lighting

WALL SURFACE MOUNT LED

131

WALL SURFACE MOUNT 240V

GU810 GU10 Aluminium Single

Adjustable Spot Light

240V Aluminium single adjustable spot light.

LED option available

Size Base -– 44 x 42 x 54mm;

Length-76mm, Depth-57mm

Colour Aluminium

Lamp GU10 35W Max Halogen or LED

Power 240V a.c. 50Hz

W107 Duet Wall Light

Two in one wall light. Low profile round satin frost glass with chrome clips. Optional clip-on brushed chrome square trim.

Material Aluminium, Satin Frost Glass

Size

Colour

Lamp

Power

Glass Size: 145 (Diameter) x

25 (Height) mm

Trim Size: 160 (Length) x 160 (Width) x

20 (Height) mm

Satin Frost Glass, Brushed Chrome

Max. 240V 25W G9

Optional LED lamp available

240V AC 50Hz

GW047 Cube Wall Light

Contemporary cube wall light. Features frost glass diffuser with coin slot at top of unit. Side screw mounting for easy access when replacing lamp.

Material

Size

Die-cast Aluminium

80 (Length) x 80 (Width) x

85 (Height) mm

Colour Silver

Lamp Max. 240V 25W G9

Optional LED lamp available

Power 240V AC 50Hz

132

Gentech Lighting

GW049 Cube Glass Wall Light

Cube glass wall light.Pull glass front for easy lamp replacement.

Material Die-cast Aluminium, Frost-opal Glass

Size

Colour

Lamp

Power

75 (Length) x 75 (Width) x

95 (Height) mm

Satin Frost Glass, Silver

Max. 240V 25W G9

Optional LED lamp available

240V AC 50Hz

GW056 Venus Wall Light G9

Unique design wall light features aluminium body, frost glass and coin slot feature.

Material Aluminium

Size 132 (Height) x 132 (Base Width) x

135 (Profile) mm

Colour Silver

Lamp Max 40W G9

Power

IP Rating

220-240V AC ~ 50/60Hz

IP44

GW061 “U Turn’’ Wall Light

Contemporary T5 wall light. Die-cast aluminium fitting with crisp clean lines and low profile.

Material

Size

Colour

Die-cast Aluminium

675 (Length) x 45 (Width) x

90 (Height) mm

Silver, White

Lamp

Power

Max. 24W T5 Linear

240V AC 50Hz

WALL SURFACE MOUNT 240V

Gentech Lighting

133

GLASS PENDANTS

134

PGS1 Glass Shade Pendant

Various choices of canopies, suspension kits, back plates and extension rods. Glass shade canopy hole size: 25mm

Material Glass

Size Glass 110 (Diameter) x 70 (Height) mm

Colour Amber/White Blue/White Red/White

Frost/White Frost

Lamp

Power

Max. 12V/50W Bi-Pin burner

Optional LED lamps available

12V AC

W-PT399 Straight Cone Glass Shade

Low voltage straight cone glass pendant complete with

1.5 metre jack suspension kit and lamp. For optional back plates select from W-CT01D, W-CT01, Trapeze and Flexi rail accessories

Material Aluminium, glass

Size Shade 97 (Diameter) mm x

195 (Height) mm

Colour Blue/White Frost/White

Lamp Max. 12V/50W Bi-Pin Burner

Optional LED lamps available

Power 12V AC

Gentech Lighting

W-PT450 Rainbow Glass Shade

Conical shaped glass complete with1.5 metre jack suspension kit and lamp. For optional back plates select from WT-CT01D, W-CT01, Trapeze and Flexi rail accessories

Material

Size

Aluminium, glass

Shade 100 (Diameter) x

240 (Height) mm

Colour Satin/Frost

Lamp Max. 12V/50W Bi-Pin Burner

Optional LED lamps available

Power 12V AC

W-G32 Dome Glass Shade

Transparent coloured glass well balanced in size for dual glass application. Various choices of suspension kits, back plates and extension rods

Material Glass

Size Shade 128 (Diameter) x 95 (Height) mm

Colour Amber, Blue, Green, Clear

Lamp 50W

Optional LED lamps available

Power 12V AC

W-GUL Ribbed Glass Shade – only

Frost glass shade which can be used in dual glass application or on its own. Various choices of suspension kits, back plates and extension rods

Material Glass

Size Shade 90 (Diameter) x 67 (Height) mm

Colour Amber, Blue, Frost, Green

Lamp 50W

Optional LED lamps available

W-G56 Cube Glass – only

Decorative satin frost cube glass only. Various accessories for Trapeze, Flexi rail & pendant options

Material Glass

Size 74 (Length) x 74 (Width) x

74 (Height) mm

Colour Satin/Frost

Lamp Max.12V/50W Bi-Pin Burner

Optional LED lamps available

Example only

GLASS PENDANTS

Gentech Lighting

135

GLASS PENDANTS

136

PGS9 Orbit Glass Pendant

Elegant low voltage pendant with 1.5 metre jack suspension kit. For optional back plates select from

W-CT01D, W-CT01, Trapeze and Flexi-rail accessories

Material

Size

Aluminium, glass

Shade 45 (Diameter) mm x

196 (Height) mm

Colour Smoke/Frost

Lamp Max. 12V/50W Bi-Pin burner

Optional LED lamps available

Power 12V AC

PGS12 Jewel Pendant

Stylish 240V pendant featuring adjustable 2.5 metre suspension chrome metal-ware and trim with clear outer glass shade and frost inner glass.Shade size: Clear 158 x

296mm Back plate: 110mm

Material

Size

Aluminium, glass

Glass 158 (Diameter) mm x

296 (Height) mm

Colour Clear/Chrome

Lamp Max. 240V/60W E14

Optional LED lamps available

Power 240V AC

PGS6 Brandy Glass Pendant

Balloon glass 240V pendant featuring swirl at base of glass. Complete with 2 metre suspension kit and back plate. Back plate: 110mm diameter

Material

Size

Colour

Lamp

Power

Aluminium, glass

Glass 210 (Length) x 130 (Width) x

250 (Height) mm

Blue White

Max. 240V/G9/40W

Optional LED lamps available

240V AC

PGS14 204V Tubular Pendant

240V Tubular Opal Pendant. Features ES lamp holder

3 metre adjustable suspension kit and 80mm diameter polished chrome back plate.

Material

Size

Colour

Lamp

Power

Aluminium, glass

Glass 98 (Diameter) x 300 (Height) mm

Length

Frost White glass with polished chrome trim

E27 60W max.

Optional LED lamps available

240V AC

Gentech Lighting

GLASS PENDANTS

W-MH1 Taj High Bay

Sophisticated high bay pendant. Features housing for optional inbuilt control gear adjustable suspension and matt silver metal-ware. Frost glass shade with floating halo glass diffuser

Material

Size

Aluminium, glass

Shade 345 (Diameter) x 220 (Height) mm

Colour

Lamp

Power

Frost glass, matt silver metal-ware

E27 150W max Metal Halide 42W max

CFL or LED lamp

240V AC

PMS7-LED 3W LED Pendant

LED 3W pendant light. Features 3W Cree LED and 3m adjustable cable. Available as a kit with a satin chrome easy fit back plate and 350mA Driver. Also available as

Surface Mount.

Material Aluminium

Size 25mm Diameter 130mm Length.

Recessed Back Plate 80mm Diameter

Colour

Lamp

Satin Chrome + Polished Chrome

1 x 3W Cree LED

Led Colour Commercial White (4500K)

Warm White (3000K)

Lumen Output Commercial White: 150 Lm

Warm White: 120 Lm

Beam Angle 45°

Power 350mA Constant Current

Cut Hole (Recessed Back Plate) 60mm

PMS1 Metal Shade – only

Various choices of canopies, suspension kits, back plates and extension rods. Metal Shade canopy hole size: 25 mm

Material Aluminium

Size

Colour

Lamp

Shade 110(Diameter) x 70mm

Brass, Black, Chrome, Satin Chrome

Max. 12V/50W Dichroic or

12V 20W bi-pin

Optional LED lamps available

Example only

PMS2 Metal Shade Pendant

Metal shade straight cone low voltage pendant complete with 1.5 metre jack suspension. Jack socket back plate not included. For optional back plates select from W-CT01D

W-CT01 Trapeze and Flexi-rail accessories

Material Aluminium

Size Shade 94 (Diameter)x 210mm

Colour Brushed Chrome, Copper Finish

Lamp

Power

Max. 12V/50W Dichroic or

12V 20W bi-pin

Optional LED lamps available

12V AC

Gentech Lighting

METAL PENDANTS

137

METAL PENDANTS

PMS5 Bistro Pendant

Contemporary aluminium shade features decorative perforations at top of shade. Ceiling canopy diameter 123 mm Suspension Length 1.5 metres

Material Aluminium

Size Shade 260 (Diameter) mm x

260 (Height) mm

Colour Aluminium

Lamp Max. 240V/75W E27 or 15W/ES

Energy Saver

Power 240V AC

PMS11 Saloon Pendant

Chunky aluminium shade with frost glass diffuser secured by side clips featured. Ceiling canopy diameter 108 mm

Suspension length 1.5 metres

Material Aluminium

Size Shade 450 (Diameter) mm x

430 (Height) mm

Colour Aluminium / Frost

Lamp

Power

Max. 240V/100W E27 or

15W/ES Energy Saver

240V AC

PMS12 Linx Pendant

Trendy T5 energy efficient pendant available in various wattage. Features adjustable suspension chrome reflector and frost acrylic diffuser

Material Aluminium

Size 910 (Length) x 65 (Width) x

56 (Height) mm

Colour Silver/Frost

Lamp T5 Flourescent 21W/39W

Power 240V AC

PARTS AND ACCESSORIES

138

W-CY230 Silver Wire Suspension Kit

Standard 2 metre maximum length non-jack suspension kit for low voltage application. Optional back plates available

Size Length 2.0m

Colour Chrome

Lamp 50W

Power 12V

Gentech Lighting

PSCD1 Flex Suspension Kit

2 metre length. Optional back plates available

Size Length 2.0m

Colour Black

Lamp 50W

Power 12V

W-CT200 Jack Suspension Kit

Low voltage applications Standard 1.5 metre length

Size

Colour

Length 1.5m

Chrome, Satin Chrome

Lamp 50W

Power 12V

W-CT01D

Jack Socket Compact Back Plate

Jack Socket Compact Back Plate

Size Diameter 55mm

Colour Chrome, Satin Chrome

W-CT01

Jack Socket Flat Back Plate

Jack Socket Flat Back Plate

Size Diameter 75mm

Colour Chrome, Brushed Brass, Satin Nickel,

Satin Chrome

PARTS AND ACCESSORIES

Gentech Lighting

139

TW-001 Straight Fixture

Trapeze basic economical straight fixture. Lamp can only be adjusted downward.

Material Plated Brass

Size 220 mm

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

Power 12V AC

220

220

220

TW-001A Twist Action Fixture

Trapeze multi functional trapeze fixture featuring two way lamp movement.

Material

Size

Plated Brass

220 mm

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

Power 12V AC

220

220

220

TW-006 Tilt Action Fixture

Trapeze V shaped tilt action trapeze fixture featuring one way lamp movement. Available in 200, 300 or 500mm lengths.

Material Plated Brass

Size 200, 300, and 500 mm

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

Power 12V AC

L

L

L

TW-008 Hoop Fixture

Trapeze circular trapeze fixture. No lamp movement.

Material Plated Brass

Size 150 (Diameter) mm

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

Power 12V AC

150

150

TW-011A Elbow Twist Fixture

Trapeze multi functional fixture featuring centre hinge for height adjustment and two way lamp movement.

220

Material

Size

Plated Brass

220 mm

220

100

100

100

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

100

Power 12V AC

220

L

L

120

120

FIXTURES

141

FIXTURES

TW-E01N

Trapeze Jack Socket

TW-E01N

With G877-JACK

150

150

220

220

100

100

TW-012A Extension Twist Fixture

Trapeze multi functional extension twist fixture featuring extended arms and offering two way lamp movement.

Available in 100, 200 or 300mm lengths.

Material Plated Brass

220

Size 100, 200, and 300 mm

220

L

Colour Chrome

L

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

Power 12V AC

TW-028 Gyro Fixture

Trapeze multi functional fixture featuring gyro ring with swivel and tilt adjustment.

Material

Size

Plated Brass

120 (Diameter) mm

Colour Chrome

Lamp Max. 12V 50W Dichroic

Optional LED lamps available.

120

120

Power 12V AC

TW-E01N Trapeze Jack Socket

Trapeze jack fixture for mounting spotlights and pendants.

Material Plated Brass

Size 220 mm

Colour Chrome-Black

Power 12V AC

W-PT399

Straight Cone Glass Shade

G628-JACK

Classic Spotlight with

W-GU Glass

W-CT200

Jack Suspension Kit

May be used to adapt various low voltage glass and metal shades to the trapeze system.

G876-JACK

Manta Spotlight Jack

142

G877-JACK

Swing Spotlight Jack

Gentech Lighting

TW-CABLE-4P Trapeze Cable 4mm & PVC

TW-CABLE-6 Trapeze Cable 6mm

TW-CABLE-6P Trapeze Cable 6mm + PVC

Trapeze cable which is weaved copper fabricated wire around a centre 3M nylon core providing conductivity and durability. Available by the roll or per metre.

TW-Cable-4P 4mm with clear PVC covering

TW-Cable-6 6mm

Material

Power

Kevlar Insulated

12V AC

60 100

A: TW-P01-6 Turnbuckle

48

Trapeze wall or ceiling fixture. Features side hole for cable exit and easy installation. Offers 4cm tension adjustment.

A

Material

Size

Plated Brass

160 (Length) mm

Colour Chrome

48

48

60

60

100

100

106

Trapeze wall or ceiling fixture as per TW-P01-6 with added feature of fixing base being insulated from the conductive end of the turnbuckle.

60

32

106

Material Plated Brass

Size 166 (Length) mm

48

50

Colour Chrome

48

60

106

C: TW-P02-S Fixed End

32

60

106

Trapeze economical wall or ceiling fixture to secure trapeze cable. Cannot be used as a tensioner for trapeze cable.

Material Plated Brass

Size 50 (Length) mm

32

Colour Chrome

32

50

D:TW-P02-A Adjustable End

32

90

Trapeze economical wall or ceiling fixture to secure trapeze cable. Offers 2cm max. tension adjustment. Cable may twist on tensioning.

32

50

50

Material

Size

Plated Brass

100 (Length) mm

Colour Chrome

32

100

E:TW-P03 Pulley End

Trapeze fixed end anchor fixture. Designed for change of direction and angle for trapeze cable. Note: This is not a cable tensioning mechanism.

Material

Size

Plated Brass

50 (Length) mm

Colour Chrome

32

32

32

32

100

50

100

120

C

E

F:TW-P03B Standoff

Trapeze heavy duty stand-off to support cable in a straight line or works as an anchor point when changing direction or angling of trapeze cable.

Material

Size

Plated Brass

60, 100, 200, 300, 460 mm

Colour Chrome

32

L

90

Gentech Lighting

B

D

F

COMPONENTS

143

32

120

L

COMPONENTS

I

K

Looping

Connector

N

144

G

H

L

Power Feed

Connectors

J

O

M

Breakthrough

Connectors

G: TW-P03BS Angle Support

Trapeze counter pull fixture used to increase the strength and security on a standoff or other mounting fixture.

Adds additional support to longer standoffs.

Material Plated Brass

230

230

Size 230 (Length) mm

22

22

Colour Chrome

H: TW-P04 Surface Mount Transformer

Trapeze UFO profile slimline surface mounted transformer. Available with a 200VA and 300VA robust toroidal transformer offering long life and reliable performance. Non-Dimmable. 1 per 10 amp circuit breaker 2 per 16 amp circuit breaker.

Size 200 (Diameter) x 55 (Height) mm

Colour Chrome

Power 12V AC

55

55

200

200

I: TW-P07 Insulated Tensioner

Trapeze insulated cable tensioning mechanism to provide additional tension for long trapeze runs. Divides one cable run into two independent circuits.

Material

Size

Plated Brass

130 (Length) mm

Colour Chrome

J: TW-P07C Conductive Tensioner

Trapeze conductive cable tensioning mechanism to provide additional adjustment for long trapeze runs.

Material Plated Brass

Size 135 (Length) mm

Colour Chrome

Power 12V AC

K: TW-P08

Trapeze cable joining device which can also be used to tidy up trapeze cable end.

L: TW-P98

Connectors to attach power source to trapeze system.

Set of two

M: TW-P99

Breakthrough connector for trapeze. Already included with trapeze fixtures. Set of two.

Material Plated Brass

Colour Chrome

Power 12V AC

N: TW-P09 Insulated Cross Spacer

Trapeze insulated spacer to enable crossing trapeze cable.

Allows creation of X intersections.

Material Plated Brass

Colour Black

O: TW-P09C Conductive Cross Spacer

Trapeze conductive spacer to enable crossing trapeze cable to form bi-directional cable runs.

Material Plated Brass

Colour Chrome

Power 12V AC

Gentech Lighting

P: TW-P010 Joiner Insulated Trapeze

Trapeze insulated mechanism to join trapeze cable. Can be used to cut one cable run into two independent circuits. Small runs only.

Material Plated Brass

Colour Chrome

Q: TW-P010C Conductive Joiner

Trapeze conductive mechanism to join trapeze cable.

Small runs only.

Material Plated Brass

Colour Chrome

Power 12V AC

R: TW-BARNDOOR Black Barn Door

Trapeze barndoor accessory used to reduce glare whilst maintaining the light angle as required. TW-LL Holder is required when using TW-Barndoor.

Material Steel

Colour Black

S: TW-LL Holder

Trapeze holding ring for barndoor, mesh or glass lens.

Material Aluminium

Colour Chrome

P

R

Surface

Transformer

Insulated

Joiner

Jack Socket

Pullet Rerouter

Angle

Support

S

Q

COMPONENTS

Turnbuckle

Straight

Fixture

Standoff

Fixed End

Transformer

Ordering Trapeze Check List

Trapeze Cable:

Turnbuckle:

Determine the length per run, two wires per run plus the lead length to connect to transformer.

Standard run requires 4 turnbuckles, but in short runs (within 5m) 2 turnbuckles may be replaced by 2 fixed ends or adjustable ends

Transformer: Calculate power required according to watts and number of lamps used. Determine if to be surface mount or hidden remote. Normal electronic transformers may not be suitable for Trapeze.

Standoff:

To maintain a straight level run a pair of standoffs may be required to be spaced at 1.5m to 3m

intervals.

Insulated Joiner/Tensioner: When a run becomes too long to a power connection, splitting the run into two isolated power supplies is necessary.

Fixtures: Refer to catalogue for individual needs.

Supporting accessories:

Refer to catalogue for individual needs.

Gentech Lighting

145

Low Voltage Bendable Rail Lighting System

Rail, Support, Power Feed, Joiner, Spotlight, Glass Shade, Accessories

AR-J06

AR-740

AR-735

AR-E01

G628/Jack + GU Glass

TW-GO

FIXTURES

146

AR-740 Flexi Twist Spotlight

Flexi Twist Spotlight.

Material

Colour

Lamp

Power

Diecast Alloy

Chrome, Satin Nickel

Max. 12V 50W Dichroic

Optional LED lamps available

12V AC

Gentech Lighting

FIXTURES

AR-735 Flexi Glass Adaptor

Flexi rail glass shade adaptor.

Material Diecast Alloy

Colour

Lamp

Power

Chrome, Satin Nickel

12V 50W G4 Halogen

Optional LED lamps available

12V AC

To be used with:

TW-GS

Steped Glass Shade

TW-GO

Mushroom Glass Shade

AR-E01 Flexi Jack Socket

Flexi rail spotlight adaptor for jack spotlight.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

To be used with:

G877-JACK

Swing Spotlight Jack

G876-JACK

Manta Spotlight Jack

G878-JACK

Rocket Spotlight Jack

G628-JACK-GU

Classic Spotlight with W-GU

Glass

W-CT200

Jack Suspension Kit

May be used to adapt various Low

Voltage shades to the Flexi Rail System

Gentech Lighting

147

COMPONENTS

A B

C

E

F

148

D

E

G

A. AR-RAIL Flexi rail

Flexi rail available in 1.5 metre and 1 metre length.

Material

Size

Colour

Power

Plated Copper

1.0 metre, 1.5 metres

Chrome, Satin Nickel

12V AC

B. AR-PF1 Power Feed

Flexi rail power feed with 700 mm leads.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

C. AR-PFA

Flexi Rail Support and Power Feed

Flexi rail support and power feed with 900 mm leads.

Material

Size

Diecast Alloy

115 (Diameter) x 105 (Length) mm

Colour

Power

Chrome, Satin Nickel

12V AC

D. AR-PFE

Flexi rail end power feed

Flexi rail end power feed.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

E. AR-PFD

Flexi rail compact end power feed

Flexi rail compact end power feed.

Material

Size

Diecast Alloy

55 (Diameter) x 50 (Length) mm

Colour

Power

Chrome, Satin Nickel

12V AC

F. AR-PFW24

Flexi rail wall support and power feed

Flexi rail wall support and power feed.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

G. AR-J01

Joiner Conductive Flexi Rail

Flexi rail conductive straight joiner.

Material

Colour

Power

Diecast Alloy

Chrome, Satin Nickel

12V AC

Gentech Lighting

H. AR-J02

Joiner Insulated Flexi Rail

Flexi rail insulated straight joiner.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

I. AR-J07

Flexible Joiner Flexi Rail

Flexi rail conductive flexible joiner.

Colour Chrome, Satin Nickel

Power 12V AC

J. AR-J04 Angle Joiner

Flexi rail adjustable angle joiner.

Material Diecast Alloy

Colour

Power

Chrome, Satin Nickel

12V AC

K. AR-J10 Conductive Docking Module

Flexi rail 4 way docking module which can be used as a corner support.Also available as insulated (AR-J11).

Material

Size

Diecast Alloy

105 mm

Colour

Power

Chrome, Satin Nickel

12V AC

L. AR-J11 Insulated Docking Module

Flexi rail 4 way docking module which can be used as a corner support.Also available as conductive (AR-J10).

Material

Size

Diecast Alloy

105 mm

Colour

Power

Chrome, Satin Nickel

12V AC

M. AR-J06 Support

Flexi rail support. Optional extension rod.

Material Diecast Alloy

Size 105 mm

Colour Chrome, Satin Nickel

Power 12V AC

H

J

K, L

M

I

COMPONENTS

Gentech Lighting

149

COMPONENTS

N O

P

R

Q

N. AR-J06R Tilt Support

Flexi rail tilt support. Optional extension rod.

Material

Size

Colour

Power

Diecast Alloy

105 mm

Chrome, Satin Nickel

12V AC

O. AR-ROD-J06 AR-ROD for Flexi Rail

Flexi rail extension rod for support and tilt support.

Material

Size

Colour

Diecast Alloy

300 mm, 600 mm, 900 mm

Chrome, Satin Nickel

P. AR-RWS24 Flexi rail wall support

Flexi rail wall support with 610 mm wire length.

Material Diecast Alloy

Colour Chrome

Power 12V AC

Q. AR-BALANCE-KIT

Flexi rail balance kit to be used in conjunction with wire suspension.

Material Diecast Alloy

Colour Chrome

R. AR-J09 Wire Suspension

Flexi rail wire suspension.

Size 3.0 metres

Colour Chrome, Satin Nickel

150

Gentech Lighting

Gentech Lighting

151

WALL LIGHTS SURFACE MOUNT – LED

152

LED501 Cylinder Column Up-Down

Cylinder up/down LED wall light. Features decorative frost acrylic inserts and in-built 700mA driver.

Material

Size

Aluminium, Acrylic

65 (Diameter) x 180 (Height) x

85 (Profile) mm

Colour Aluminium

Lamp 2 x 3W LED

Led Colour Cool White, Warm White

Power 240V AC 50Hz

IP Rating IP55

LED502 Square Column Up-Down

Square up/down LED wall light. Features decorative clear acrylic inserts and in-built 700mA driver.

Material

Size

Aluminium, Acrylic

70 (Length) x 70 (Width) x

158 (Height) x 93 (Profile) mm

Colour Aluminium

Lamp 2 x 3W LED

Led Colour Cool White

Power 240V AC 50Hz

IP Rating IP55

LED500 Archer Wall Light

Mini LED wedge wall light. Features smooth curved profile with inbuilt 350mA driver.

Material Aluminium

Size 60 (Width) x 180 (Height) x

59 (Profile) mm

Colour Aluminium

Lamp 1 x 5W SMD LED

Led Colour Cool White, Warm White

Power 240V AC 50Hz

IP Rating IP53

LED504 LED 3.6W Barrel Spotlight

Osram LED 3 x 1.2W spotlight. Features anti glare baffle, safety glass, anodized aluminium housing and solid rectangular back plate with in-built driver. Offers 355 degree rotation and 90 degree tilt. 240V input connection for easy installation.

Material

Size

Anodised Aluminium

Base 125 x 200 mm

Colour Black

Lamp 3 x 1.2W LED

Led Colour Natural White

Power

Output

IP Rating

Input: 240V AC

350mA Constant Current

IP44

Gentech Lighting

F216P-LED

Minnow Bunker – Plain Face LED

Small round stainless steel trim LED bunker. Features a low profile with frost suede dome glass and 15 high luminance LED.

Material Stainless Steel, Tempered glass

Size

Colour

140 (Diameter) x 45 (Profile) mm

Stainless Steel

Lamp 1.5W LED

Led Colour Cool White

Power

IP Rating

240V AC 50Hz

IP44

F216E-LED

Minnow Bunker – Eyelid Face LED

Small round eyelid stainless steel trim LED bunker.

Features a low profile with frost suede dome glass and

15 high luminance LED.

Material

Size

Stainless Steel, Tempered glass

140 (Diameter) x 45 (Profile) mm

Colour

Lamp

Stainless Steel

1.5W LED

Led Colour Cool White

Power 240V AC 50Hz

IP Rating IP44

See page 127 to 133 for more IP rated wall lights.

WALL LIGHTS SURFACE MOUNT – LED

B-C034-WALL-SPOT

Turbo Wall Spot Light

Solid brass wall light. Features screw cap housing for easy lamp access. Compact rectangular back plate.

Material

Size

Solid Brass, Tempered glass lens

Colour

Lamp

61 (Diameter) x 127 (Height) x

105 (Profile) mm

Antique Bronze, Stainless Steel

Max. 12V 20W Dichroic

Optional LED lamps available

Power

IP Rating

IP Rating

12V AC

IP65

IP65

WALL LIGHTS SURFACE MOUNT – 12V

Gentech Lighting

153

WALL LIGHTS SURFACE MOUNT – 12V

154

B-C035-UP-DOWN-SPOT-SS

Turbo Up-Down Wall light Stainless Stee

B-C035-UP-DOWN-SPOT-AB

Turbo Up-Down Wall light Antique Bronze

Solid brass Up/Down wall light. Features antique bronze or stainless steel finish. Screw cap housing for easy lamp access. Compact rectangular back plate.

Material Solid Brass, Tempered glass lens

Size

Colour

Lamp

Power

IP Rating

68 (Diameter) x 175 (Height) x

105 (Profile) mm

Antique Bronze, Stainless steel

Max. 2 x 12V 20W Dichroic

Optional LED lamps available

12V AC

IP65

B-D002-TURBO Turbo Wink

Compact solid brass wall light. Features eyelid face, frost glass diffuser and 900mm cable.

Material

Size

Colour

Lamp

Solid Brass, Tempered glass lens

97 (Diameter) x 50 (Profile) mm

Antique Bronze, Stainless Steel

Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

IP Rating

12V AC

IP54

B-D003 Turbo Surface Mount

Surface mount solid brass eyelid wall light. Features cable access at rear and side, side screw faceplate mounting.

Low profile with frost glass lens.

Material Solid Brass, Tempered glass lens

Size

Colour

Lamp

Power

IP Rating

115 (Width) x 75 (Height) x

60 (Profile) mm

Antique Bronze

Max. 12V 20W G4 Halogen

Optional LED lamps available

12V AC

IP54

F209-LV Comet Wall Light

Compact stainless steel or copper wall light with frosted glass diffuser. Fitting comes complete with lamp. Available in 12V and 240V

Material Copper or 316 Stainless

Steel

85

98

Size

Colour

Lamp

Power

93 (Width) x 98 (Height) x 58 (Profile) mm

Copper, Stainless Steel

12V 20W G4 Halogen

Optional LED lamps available

12V AC

93

58

IP Rating IP23

Gentech Lighting

163

58

116

58

WALL LIGHTS SURFACE MOUNT – 12V

F206-LV Dusk Wall Light – Copper

Size

Copper, Tempered glass lens

160 (Width) x

160 (Height) x

120 (Profile) mm

120

163

Exterior copper wall light. Features stylish shade design with frosted glass diffuser. Fitting comes complete with halogen lamp

116

Material

160

Colour Copper

Lamp 12V 50W G4 Halogen

Optional LED lamps available

Power

IP Rating

12V AC

IP23

160

F207-LV Dusk Wall Light – 316 Stainless Steel

Exterior Stainless Steel wall light. Features stylish shade with frosted glass diffuser. Fitting comes complete with lamp. Available in 12V and 240V

Material

Size

Colour

316 Stainless Steel, Tempered glass lens

160 (Width) x 160 (Height) x

120 (Profile) mm

Stainless Steel

120

Lamp

Power

IP Rating

12V 50W G4 Halogen

Optional LED lamps available

12V AC

IP23

160

160

F201N Stainless Steel Cylinder Wall Light

Stainless steal weatherproof cylinder wall light. Features twist cap lens and rectangular backplate which holds optional electronic transformer or LED driver.

Material

Size

Colour

316 Stainless Steel, Tempered glass lens

55 (Diameter) x 95 (Height) x

112 (Profile) mm

Stainless Steel

Lamp

Power

IP Rating

Max. 12V 35W Dichroic

Optional LED lamps available

12V AC

IP55

F202N Stainless Steel Cylinder Wall Light

Up and Down

Stainless steal weatherproof cylinder Up/Down wall light.

Features twist cap lens and rectangular backplate which holds optional electronic transformer or LED driver.

Material

Size

Colour

Lamp

Power

IP Rating

316 Stainless Steel, Tempered glass lens

55 (Diameter) x 180 (Height) x

120 (Profile) mm

Stainless Steel

Max. 2 x 12V 35W Dichroic

Optional LED lamps available

12V AC

IP55

Gentech Lighting

155

190

55

90

WALL LIGHTS SURFACE MOUNT – 12V

156

F203N Stainless Steel Square Column Down

Stainless steel weatherproof square wall light. Features rectangular backplate which holds optional electronic transformer or LED driver.

Material 316 Stainless Steel, Tempered glass lens

Size

Colour

Lamp

Power

IP Rating

58 (Diameter) x 100 (Height) x

116 (Profile) mm

Stainless Steel

Max. 12V 35W Dichroic

Optional LED lamps available

12V AC

IP55

100

58

116

F204N Stainless Steel Square Column Up and Down

Stainless steel weatherproof square Up/Down wall light.

Features rectangular backplate which holds optional electronic transformer or LED driver.

Material

Size

Colour

Lamp

316 Stainless Steel, Tempered glass lens

58 (Diameter) x 163 (Height) x 116 (Profile) mm

Stainless Steel

Max. 2 x 12V 20W Dichroic

Optional LED lamps available

163

58

Power

IP Rating

12V AC

IP55

116

F0113 Cylinder Wall Light

Weatherproof wall light. Features twist cap lens and optional in-built transformer back plate available.

Material

Size

Die-cast Aluminium, Tempered glass lens

55 (Diameter) x 123 (Height) x 90 (Profile) mm

55

Colour

Lamp

Black, Silver

Max. 12V 50W Dichroic

Optional LED lamps available

123

90

Power

IP Rating

12V AC

IP55

Colour

Lamp

Power

IP Rating

160

F0123 Cylinder Up-Down Wall Light

Weatherproof Up/Down wall light. Features twist cap lens and optional in-built transformer back plate available.

160

Material

Size

Die-cast Aluminium, Tempered glass lens

55 (Diameter) x 190 (Height) x 90 (Profile) mm

Black, Silver

55

Max. 2 x 12V 50W Dichroic

Optional LED lamps available

190

90

12V AC

IP55

Gentech Lighting

100

58

116

AP-EN2+T

Mounting Box for F0113 and F0123

Weather proof mounting box with in-built toroidal transformer.

Size 142 x 95 x 65 (Height) mm

Input Power 240V AC 50Hz

Output Power 12V AC 20-60W Max.

IP 55

F216P-LV

Minnow Bunker – Plain Face 12V

Small round stainless steel trim bunker. Features a low profile with frost suede dome glass.

Material

Size

304 Stainless Steel, Tempered glass lens

140 (Diameter) x 45 (Profile) mm

Colour

Lamp

Power

IP Rating

Stainless Steel

Max. 12V 20W G4 Halogen

Optional LED lamps available

12V AC (Remote transformer recommended or Built-in LED Dirver available)

IP44

F216E-LV

Minnow Bunker – Eyelid Face 12V

Small round eyelid stainless steel trim bunker. Features a low profile with frost suede dome glass.

Material

Size

304 Stainless Steel, Tempered glass lens

140 (Diameter) x 45 (Profile) mm

Colour

Lamp

Power

IP Rating

Stainless Steel

Max. 12V 20W G4 Halogen

Optional LED lamps available

12V AC (Remote transformer recommended or Built-in LED Dirver available)

IP44

WALL LIGHTS SURFACE MOUNT – 12V

Gentech Lighting

157

WALL LIGHTS SURFACE MOUNT – 12V

Selection of faces:

F101-W

Wall Light Back Plate Range

Make your own wall light with a selection of faces and glass. Stone texture finish is acid and alkaline resistant, cast tempered glass. Wall back plate only (pictured here with

G101GLS-DOME-CLR). Optional ribbed or frost dome glass available.

Material:

Size:

Die-cast Aluminium, Tempered glass lens

90 (Diameter) mm

Colour: Silver

Lamp: Max. 12V 20W G4 Halogen

Optional LED lamps available

Power:

IP Rating:

12V AC

IP 65

Glasses

F101-GYRO F101-RING F101GLS-DOME-CLR

– Clear Dome Glass for F101

F101GLS-DOME-FRS

– Frost Dome Glass for F101

F101GLS-DOME-RIB

– Ribbed Dome Glass for F101

Example Kits:

F101-GRATE F101-LENEZ

F101 Wall Plate with Wink face and Ribbed

Dome Glass

F101 Wall Plate with Grate face and Ribbed

Dome Glass

F101 Wall Plate with Sash face and Ribbed

Dome Glass

F101SASH F101-WINK

158

Gentech Lighting

F211N-316 Marina Wall Light

Marine grade stainless steel weatherproof cylinder wall light. Features solid design, compact back plate and twist cap lenses for easy lamp replacement.

Material

Size

Colour

Lamp

Power

IP Rating

316 Stainless Steel, Tempered glass

Back Plate: 70 (Diameter) x 30 mm

Cylinder: 55 (Diameter) x 119 (Height) x

90 (Profile) mm

Stainless Steel

Max.35W GU10

240V AC 50Hz

IP65

58

F212N-316 Marina Up-Down Wall Light

Stainless steel weatherproof cylinder up/down wall light.

Features solid design, compact back plate and twist cap lenses for easy lamp replacement.

163

116

Material

Size

316 Stainless Steel, Tempered glass

60 (Diameter) x 180 (Height) x

90 (Profile) mm

Colour

Lamp

Power

IP Rating

Stainless Steel

Max. 2 x 35W GU10

Optional LED lamp available

240V AC 50Hz

IP65

WALL LIGHTS SURFACE MOUNT – 240V

F206-G9 Dusk Wall Light – Copper

Exterior copper wall light. Features stylish shade design with frosted glass diffuser. Fitting comes complete with halogen lamp

163

58

Material

Size

Copper, Tempered glass lens

160 (Weight) x 160 (Height) x 120 (Profile) mm

116

160

Colour Copper

Lamp Max. 240V 40W G9

Optional LED lamps available

Power

IP Rating

240V AC

IP23

120

160

F207-G9 Dusk Wall Light – 316 Stainless

Steel

Exterior Stainless Steel wall light. Features stylish shade with frosted glass diffuser. Fitting comes complete with lamp. Available in 12V and 240V

Material 316 Stainless Steel, Tempered glass lens

Size

Colour

Lamp

Power

IP Rating

160 (Width) x 160 (Height) x 120 (Profile) mm

Stainless Steel

Max. 240V 40W G9

Optional LED lamps available

240V AC

IP23

120

160

160

Gentech Lighting

159

WALL LIGHTS SURFACE MOUNT – 240V

160

F209 Comet Wall Light

Compact stainless steel or copper wall light with frosted glass diffuser. Fitting comes complete with lamp. Available in 12V and 240V

Material

Size

Colour

Lamp

Copper or 316 Stainless Steel

93 (Width) x 98 (Height) x 58 (Profile) mm

Copper, Stainless Steel

85

93

58

98

Power

IP Rating

Max. 240V 25W G9

Optional LED lamps available

240V AC

IP23

F208 Wedge Wall Light

Wedge exterior wall light. Stylish stainless steel shade with frosted glass diffuser.

Material 316 Stainless Steel, Tempered glass

Size 80 (Width) x 188 (Height) x

95 (Profile) mm

Colour

Lamp

Power

IP Rating

Stainless Steel

Max. 35W GU10 or GU10 CFL

Optional Led lamp available

240V AC 50Hz

IP23

GW062 Liberty Wall Light

Stylish energy saver wall light. Can be used both in external and internal application. Fitting has integral electronic gear and features frost glass with decorative strip.

Material

Size

Colour

Lamp

Aluminium, Acrylic

60 (Width) x 191 (Height) x

110 (Profile) mm

Aluminium + Frosted Acrylic

Power

IP Rating

Max. 1 x 18W PLC (4-Pin)

Optional Led lamp available

240V AC 50Hz

IP54

EX420 Nautilis Solid Brass Bunker

Large solid brass bunker. Features frost glass lens and sand-blast finish, sturdy housing.

Material

Size

Solid Brass, Tempered glass

250 (Width) x 140 (Height) x

90 (Profile) mm

Colour

Lamp

Power

IP Rating

Brass Sand Blasted

Max. 100W E27 or

E27 CFL Energy Saver Lamp

Optional Led lamp available

240V AC 50Hz

IP54

Gentech Lighting

WALL LIGHTS SURFACE MOUNT – 240V

EX421 Calais Stainless Steel Trim Bunker

Small plain oval bunker. Features stainless steel trim and ribbed frost glass lens.

Material 304 Stainless Steel, Tempered glass

Size

Colour

Lamp

Power

IP Rating

212 (Width) x 145 (Height) x

95 (Profile) mm

Stainless Steel

Max. 60W E27 or E27 CFL Energy Saver

Optional PLC kits and Led lamp available

240V AC 50Hz

IP44

EX425P Tuscany Bunker – Plain Face

Stylish Die-cast aluminium bunker with frost glass lens.

Material

Size

Die-cast aluminium, Tempered glass

180 (Width) x 260 (Height) x

135 (Profile) mm

Colour

Lamp

Power

IP Rating

Black, Silver, White

Max. 100W E27 or

E27 CFL Energy Saver

Optional PLC kits and Led lamp available

240V AC 50Hz

IP54

Capri Bunkers

Energy saver bunker features solid cast aluminium housing, polycarbonate opal diffuser and allen key fixing on trim.

Material Die-cast aluminium housing, poly carbonate diffuser

Size

Colour

Lamp

265 (Diameter) x 100 (Profile) mm

Black, Silver

Power

IP Rating

Max. 1x 26W PLC

Optional LED lamps available

240V AC 50Hz

IP 54

EX427P

Capri Energy Saving Bunker

– Plain Face

EX427C

Capri Energy Saving Bunker

– Cross Face

Minnow Bunkers

Small round stainless steel bunker. Features a low profile with frost suede dome glass.

Material 304 grade stainless steel housing, tempered glass diffuser

Size

Colour

Lamp

140 (Diameter) x 45(Profile) mm

Stainless steel

Power

IP Rating

Max. 25W G9 Halogen

Optional LED lamps available

240V AC 50Hz

IP 44

F216P

Minnow Bunker – Plain Face

240V

F216E

Minnow Bunker – Eyelid

Face 240V

Gentech Lighting

161

WALL LIGHTS SURFACE MOUNT – 240V

EX3092 Nova Bunker

Tall shade die-cast aluminium bunker

Material Die-cast aluminium, Tempered glass

Size

Colour

Lamp

137 (Width) x 190 (Height) mm

Black, Silver, White

Max. 60W E27

Optional LED lamp available

Power

IP Rating

240V AC 50Hz

IP54

G709C Plastic Frame Bunker

Caged oval bunker. Features rust free plastic frame and glass diffuser. Suitable in salty air location.

Material

Size

Plastic, Tempered glass

175 (Width) x 95 (Height) x

90 (Profile) mm

Colour

Lamp

Power

IP Rating

White, Black

Max. 60W E27

Optional LED lamp available

240V AC 50Hz

IP44

EXC8100B Angled Bunker

Angled aluminium bunker with flat frost glass.

Material Die-cast aluminium, Tempered glass

Size

Colour

Lamp

220 (Width) x 155 (Height) x

125 (Profile) mm

Black, Silver, White

Power

Max. 60W E27

Optional 13W PLC kits available

Optional LED lamp available

240V AC 50Hz

EX9100

Paris Energy Saving Bunker

– Plain

EX9101

Paris Energy Saving

Bunker – Half Eye

IP Rating IP44

Paris Energy Saving Bunkers

Round die-cast aluminium PLC bunker with polycarbonate diffuser.

Material Die-cast aluminium, polycarbonate diffuser

Size

Colour

Lamp

Power

IP Rating

270 (Diameter) x 75(Profile) mm

Black, Silver, White

Max. 2 x 9W PLC

240V AC 50Hz

IP55

162

Gentech Lighting

WALL LIGHTS SURFACE MOUNT – 240V

Plastic Oval Bunkers

Material

Size

Colour

Lamp

Power

IP Rating

Plastic frame, Opal polycarbonate diffuser

198 (Length) x 127 (Width) x 95

(Profile) mm

Black, Silver, White

240V AC 50Hz

Optional LED lamp available

240V AC 50Hz

IP44

G2082

Plain Plastic Oval Bunker

G2083

Eyelid Plastic Oval Bunker

Oval Dome Bunkers

Small EX3083 Half Eye

Material

Size

Colour

Lamp

Power

IP Rating

Die-cast aluminium frame, Tempered glass lens

210 (Length) x 143(Width) x

110 (Profile) mm

Black, Silver

Max. 60W E27,

Optional LED lamp available

240V AC 60Hz

IP54

Large

Material

Size

Colour

Lamp

Power

IP Rating

EX4082 Plain

EX4083 Half Eye

Die-cast aluminium frame, Tempered glass lens

320 (Length) x 205(Width) x

125 (Profile) mm

Black, Silver, White

Max. 100W E27,

Optional LED lamp available

240V AC 60Hz

IP54

Plain

G2084

Grill Plastic Oval Bunker

Half Eye

Gentech Lighting

163

WALL LIGHTS SURFACE MOUNT – 240V

Plain

Eyelid

Plain

Eyelid

Caged

Louvred

Caged

Louvred

Round Bunkers

Small G705C Small Caged

Material

Size 176 (Diameter) x 90 (Profile) mm

Colour: Black

Lamp:

Power:

IP Rating:

Die-cast aluminium frame, Tempered glass lens

Max. 75W E27,

Optional LED lamp available

240V AC 60Hz

IP44

Large

Material

Size

Colour

Lamp

Power

IP Rating

G706C Large Caged

G706P Large Plain

G706E Large Eyelid

G706L Large Louvred

Die-cast aluminium frame, Tempered glass lens

240 (Diameter) x 130 (Profile) mm

Black, White

Max. 100W E27,

Optional LED lamp available

240V AC 60Hz

IP44

Oval Bunkers

Small

Material

Size

Colour

Lamp

Power

IP Rating

G707P Small Plain

G707C Small Caged

G707E Small Eyelid

Die-cast aluminium frame, Tempered glass lens

212 (Length) x 105 (Width) x

95 (Profile) mm

Beige, Black, White

Max. 75W E27,

Optional LED lamp available

240V AC 60Hz

IP44

Large

Material

Size

Colour

Lamp

Power

IP Rating

G708P Large Plain

G708C Large Caged

G708E Large Eyelid

G708L Large Louvred

Die-cast aluminium frame, Tempered glass lens

240 (Length) x 130 (Profile) mm

Black, White

Max. 100W E27,

Optional LED lamp available

240V AC 60Hz

IP44

164

Gentech Lighting

F404-LED Walle Exterior

Exterior horizontal centre tilt wall light. Features anodised aluminium housing and pre-mount box. Includes inbuilt

3W LED and LED Driver.

Material

Size

CNC Aluminium

Fitting: 117 (Width) x 73 (Height) x 37 (Depth) mm

Pre-mount:

108.6 (Width) x

61.6 (Height) x

65 (Depth) mm

Colour

Lamp

Anodized Aluminium

1 x 3W Citizen LED

Led Colour Warm White :3000K

Lumen Output 250Lm

Power

Output

IP Rating

Cut Hole

Input: 220-240V AC ~ 50/60Hz

Driver: 350mA Constant Current

1-3.6W, 3-10.5V DC

IP54

108.6 x 61.6 mm

F405-LED Eve Exterior

Exterior vertical centre tilt wall light. Features anodised aluminium housing and pre-mount box. Includes inbuilt

3W LED and LED Driver.

Material

Size

CNC Aluminium

Fitting: 73 (Width) x

117 (Height) x 45 (Depth) mm

Pre-mount:

61.6 (Width) x

108.6 (Height) x

65 (Depth) mm

Colour

Lamp

Anodized Aluminium

1 x 3W Citizen LED

Led Colour Warm White :3000K

Lumen Output 250Lm

Power

Output

IP Rating

Cut Hole

Input: 220-240V AC ~ 50/60Hz

Driver: 350mA Constant Current

1-3.6W, 3-10.5V DC

IP54

61.6 x 108.6 mm

WALL LIGHTS RECESSED – LED

Gentech Lighting

165

WALL LIGHTS RECESSED – LED

166

LED313

LED-313-350MA

Round LED Wall Light

Mini round LED recessed wall light. Features spring clips for easy wall mounting.

Material 304 Stainless Steel face,

Frost polycarbonate lens

Size

Colour

Lamp

43 (Diameter) x 45 (Height) mm

Stainless Steel

1 x 1W LED

Led Colour Cool White, Warm White

Lumen Output Warm White: 265 Lm

Cool White: 290 Lm

Power 12V AC (for 12V – Iron Core

Transformer Recommended) or 350mA Constant Current

IP Rating

Cut Hole

IP65

37mm

LED314

LED314-350MA

Square LED Wall Light

Mini square LED recessed wall light. Features spring clips for easy wall mounting.

Material 304 Stainless Steel face,

Frost polycarbonate lens

Size

Colour

Lamp

45 (Length) x 45 (Width) x

45 (Height) mm

Stainless Steel

1 x 1W LED

Led Colour Cool White, Warm White

Lumen Output Warm White: 265 Lm

Cool White: 290 Lm

Power 12V AC (for 12V – Iron Core

Transformer Recommended) or 350mA Constant Current

IP Rating

Cut Hole

IP65

37mm

LED315 Bob Square Mini

LED mini square steplight. Features opal lens, 9 LED’s and pre-mount housing.

Material 304 Stainless Steel face opal polycarbonate lens

Size

Colour

Lamp

70 (Width) x 70 (Height) x 55 (Depth) mm

Stainless Steel

9 x 0.1W LED

Led Colour Daylight White, Warm White

Power 240V AC

IP Rating

Cut Hole

IP54

60mm x 60mm

Gentech Lighting

WALL LIGHTS RECESSED – LED

LED316 Ben Rectangular Mini

LED mini rectangular LED steplight.Features opal lens,

12 LED’s and pre-mount housing.

Material 304 Stainless Steel face opal polycarbonate lens

Size 110 (Width) x 45 (Height) x

55 (Depth) mm

Colour

Lamp

Stainless Steel

12 x 0.1W LED

Led Colour Daylight White, Warm White

Power

IP Rating

Cut Hole

240V AC

IP54

104mm x 30mm

LED317 Tardis Wall Light

Recessed LED path or wall light. Features eyelid face with frost glass lens. Includes pre-mount canister with rubber seal, 1 metre lead and plaster board clip accessories.

Material Anodised Aluminium, Tempered glass lens

Size

Colour

Lamp

45 (Diameter) x 107 (Height) mm

Anodised Silver

1 x 1W LED

Led Colour Cool White

Power 350mA Constant Current

IP Rating

Cut Hole

IP67

40mm

LED318 Dalek Wall Light

Recessed LED path or wall light. Features grate face with frost glass lens. Includes pre-mount canister with rubber seal, 1 metre lead and plaster board clip accessories.

Material Anodised Aluminium, Tempered glass lens

Size

Colour

Lamp

45 (Diameter) x 107 (Height) mm

Anodised Silver

1 x 1W LED

Led Colour Cool White

Power 350mA Constant Current

IP Rating IP67

Cut Hole 40mm

LED-341 EX-Plain Steplight

Anodised aluminium recessed plain face steplight.

Features opal/frost glass lens and screw cap trim. Fitting has 45cm lead and connector.

Material Anodised Aluminium, Tempered glass lens

Size

Colour

Lamp

75 (Diameter) x 39 (Height) mm

Anodised Aluminium

1 x 3W LED

Led Colour Warm White

Power 700mA Constant Current

IP Rating IP65

Cut Hole 66mm

Gentech Lighting

167

WALL LIGHTS RECESSED – LED

WALL LIGHTS RECESSED – 12V

LED-342

EX-Wink Steplight

Anodised aluminium recessed eyelid steplight. Features opal/frost glass lens and screw cap trim. Fitting has 45cm lead. Requires screw terminal driver.

Material Anodised Aluminium, Tempered glass lens

Size

Colour

75 (Diameter) x 52 (Height) mm

Anodised Aluminium

Lamp 1 x 3W LED

Led Colour Warm White

Power

IP Rating

Cut Hole

700mA Constant Current

IP65

66mm

B-D006

Turbo Recessed

Recessed brass wall light. Rear or side cable entry. Low profile with frost glass lens.

Material

Size

Colour

Lamp

Solid brass, tempered glass lens

115 (Width) x 75 (Height) x

98 (Depth) mm

Antique Bronze

Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP44

85 x 60mm

B-D007

Turbo Eyelid

Recessed brass eyelid wall light. Rear or side cable entry.

Low profile with frost glass lens.

Material

Size

Solid brass, tempered glass lens

115 (Width) x 75 (Height) x

110 (Depth) mm

Colour

Lamp

Antique Bronze

Max. 12V 20W G4 Halogen

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP44

85 x 60mm

168

Gentech Lighting

F205-R Stainless Steel Floor Washer

Plain face stainless steel recessed wall light.

Material 316 stainless steel with clear coating protection

Size

Colour

Lamp

114 (Width) x 144 (Height) x

61 (Depth) mm

Stainless Steel

Max: 12V 20W G4 Halogen

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP55

113 x 85mm

F205L

Louvred Stainless Steel Floor Washer

Louvre face stainless steel recessed wall light.

Material 316 stainless steel with clear coating protection

Size

Colour

Lamp

114 (Width) x 144 (Height) x

61 (Depth) mm

Stainless Steel

Max: 12V 20W G4 Halogen

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP55

113 x 85mm

F5065

Mini Square Stainless Steel Wall Light

Compact recessed low voltage wall light. Solid construction flush frost glass.

Material Stainless steel face, Die-cast aluminium housing, Tempered glass lens

Size

Colour

Lamp

62 (Width) x 62 (Height) x

98 (Depth) mm

Stainless Steel

Power

IP Rating

Cut Hole

Max: 12V 20W Bi-Pin Burner

Optional LED lamps available

12V AC

IP67

50 x 50 mm

F721 Stainless Steel Wink

In ground or wall mounted stainless steel eyelid.

Material

Size

Colour

Lamp

Power

IP Rating

Cut Hole

316 Stainless Steel, Tempered glass lens

97(Diameter) x 110 (Depth) mm

Stainless Steel

Max. 12V/20W Dichroic

Optional LED lamps available

12V AC

110

97

IP65

75mm

75

Gentech Lighting

WALL LIGHTS RECESSED – 12V

169

WALL LIGHTS RECESSED – 240V

170

F712 Slimline Brick Light – Plain

Plain Low profile frame frost glass diffuser. Flush Allen

Key screws. LED version available.

Material

Size

Die-cast aluminium, Tempered glass lens

250 (Width) x 69 (Height) x

62 (Depth) mm

Colour

Lamp

Power

IP Rating

White, Black

9W PL G23

240V AC 50Hz

IP23

62

250

69

F713 Slimline Brick Light – Louvre

Louvered Low profile brick light with frost glass diffuser.

Flush Allen Key screws. LED version available.

Material Die-cast aluminium, Tempered glass lens

Size 250 (Width) x 69 (Height) x

62 (Depth) mm

232

Colour

Lamp

Power

IP Rating

White, Black

9W PL G23

240V AC 50Hz

IP23

62

250

69

F71X-PRE-MOUNT

Slim Line Bricklight Pre Mount

Suitable for F712 and F713 slim line brick lights

Size

75 (Depth) mm

77

232

G701-IPM Brick Light – Louvre

Louvered brick light with frost glass lens. Pre-Mount included. Optional stainless steel face available.

Material

62

Plastic pre-mount

Size

Colour

Lamp

69

Fitting only: 232 (Width) x 86 (Height) x

77 (Depth) mm

White, Black, Stainless Steel

Power

IP Rating

Max. 40W E27 or 9W PL G23

Optional LED lamps available

86

240V AC 50Hz

77

IP23

232

Gentech Lighting

WALL LIGHTS RECESSED – 240V

G702-IPM Brick Light – Plain

Plain brick light with frost glass lens. Pre-Mount included.

Optional stainless steel face available.

Material

62

Plastic pre-mount

Size

Colour

Lamp

Fitting only: 232 (Width) x 86 (Height) x

77 (Depth) mm

White, Black, Stainless Steel

Max. 40W E27 or 9W PL G23

Optional LED lamps available

77

86

232

Power

IP Rating

240V AC 50Hz

IP23

69

G703-IPM Brick Light – Grill

Material

Size

Colour

Lamp

Power

IP Rating

62

250

Die-cast aluminium, Tempered glass lens,

Plastic pre-mount

Fitting only: 232 (Width) x 86 (Height) x

77 (Depth) mm

White, Black

Max. 40W E27 or

9W PL G23

Optional LED lamps available

240V AC 50Hz

IP23

77

86

232

69

G701-FACE-SS

Stainless Steel Face for Brick Light –

Louvred

G702N-FACE-SS

Stainless Steel Face for Brick Light – Plain

Stainless Steel face for brick light with protective coating.

Available in 304 grade and 316 grade Stainless Steel.

To be used with G701 or G702 brick lights

G701-FACE-SS

Stainless Steel Face for

Brick Light – Louvred

G702N-FACE-SS

Stainless Steel Face for

Brick Light – Plain

Gentech Lighting

171

FLOOD LIGHTS LED

172

FL010-LED

LED Flood Light 10W

Robust LED flood light.

Material Die-cast Aluminium, Tempered glass

Size 115 (Length) x 86 (Width) x

105 (Height) mm

Colour Silver

Lamp 1 x 10W LED

Led Colour Cool White, Warm White, Blue,

Green, Red

Lumen Output 800Lm (CW), 700Lm (WW)

Beam Angle 120°

Power 240V AC 50Hz

Temperature -40°C to 55°C

IP Rating IP 65

FL020-LED

LED Flood Light 20W

Robust LED flood light.

Material Die-cast Aluminium, Tempered glass

Size 225 (Width) x 185 (Height) x

126 (Profile) mm

Colour Silver

Lamp 1 x 20W LED

Led Colour Cool White, Warm White, Blue, Green,

Red

Lumen Output 1500Lm (CW), 1300Lm (WW)

Beam Angle 100°

Power 240V AC 50Hz

Temperature -40°C to 55°C

IP Rating IP65

FL030-LED

LED Flood Light 30W

Robust LED flood light.

Material Die-cast Aluminium, Tempered glass

Size 225 (Width) x 185 (Height) x

126 (Profile) mm

Colour Silver

Lamp 1 x 30W LED

Led Colour Cool White, Warm White, Blue, Green,

Red

Lumen Output 2200Lm (CW), 2000Lm (WW)

Beam Angle 120°

Power 240V AC 50Hz

Temperature -40°C to 55°C

IP Rating IP65

Gentech Lighting

FLOOD LIGHTS LED

FL050-LED

LED Flood Light 50W

Robust LED flood light.

Material Die-cast Aluminium, Tempered glass

Size 290 (Width) x 236 (Height) x

150 (Profile) mm

Colour Silver

Lamp 1 x 50W LED

Led Colour Cool White, Warm White, Blue, Green,

Red

Lumen Output 4000Lm (CW), 3800Lm (WW)

Beam Angle 100°

Power 240V AC 50Hz

Temperature -40°C to 55°C

IP Rating IP65

FL080-LED

LED Flood Light 80W

Robust LED flood light.

Material Die-cast Aluminium, Tempered glass

Size 285 (Width) x 360 (Height) x

110 (Profile)mm

Colour Silver

Lamp 1 x 80W LED

Led Colour Cool White, Warm White

Lumen Output 6400Lm (CW), 5600Lm (WW)

Beam Angle 80°

Power 240V AC 50Hz

Temperature -40°C to 55°C

IP Rating IP65

FLOOD LIGHTS METAL HALIDE

GW068 Metal Halide Flood Light E27

70W or 150W

Weatherproof floodlight.Available in 70W and 150W models. Features die-cast aluminium body tempered front glass and silicon rubber gasket. Adjustable u-bracket mount with in-built gear.

Material Aluminium

Size 280 (Length) x 230 (Depth) x

215 (Height) mm

Colour Charcoal

Lamp 70W, or 150W E27 Metal Halide

Power

IP Rating

240V AC

IP65

Gentech Lighting

173

FLOOD LIGHTS METAL HALIDE

DECK LIGHTS

174

GW069 Metal Halide Flood Light 150W

Double Ended

Weatherproof floodlight.Available in 150W. Features die-cast aluminium body tempered front glass and silicon rubber gasket. Adjustable U-bracket mount with in-built gear.

Material Aluminium

Size 265 (Length) x 140 (Depth) x

415 (Height) mm

Colour Black

Lamp

Power

IP Rating

Max. 150W Double Ended RX7s

240V AC

IP65

LED310

LED-310-350MA

Round Deck Light

Mini round LED deck light. Comes with pre-mount sleeve.

Material

Size

Colour

Lamp

304 Stainless Steel face, frost polycarbonate lens

43 (Diameter) x 45 (Height) mm

Stainless steel

1 x 1W LED

Led Colour Cool White, Warm White, Blue

Lumen Output Warm White – 265 Lm

Cool White – 290 Lm

Power 12V AC (for 12V – Iron Core

Transformer Recommended) or 350mA Constant

IP Rating IP65

Cut Hole 39mm

LED311

LED-311-350MA

Square Deck Light

Mini square LED deck light. Comes with pre-mount sleeve.

Material 304 Stainless Steel face, frost polycarbonate lens

Size 45 (Length) x 45 (Width) x

45 (Height) mm

Colour

Lamp

Led Colour Cool White, Warm White, Blue

Lumen Output Warm White – 265 Lm

Cool White – 290 Lm

Power

Stainless steel

1 x 1W LED

IP Rating

Cut Hole

12V AC (for 12V – Iron Core

Transformer Recommended) or 350mA Constant

IP65

39mm

Gentech Lighting

INGROUND UPLIGHTERS LED

G321-LED-350MA LED Micro Uplighter

1W High power LED mini in ground up lighter. Features mounting clips and double insulated low voltage colour coded cable for LED controller.

Material

Size

316 grade Stainless Steel housing, tempered glass lens

31(Diameter) x 45(Depth) mm

1000mm cable

Colour Stainless Steel

Lamp 1W LED

LED Colour Blue, Cool White, Warm White

Power

IP Rating

Cut Hole

350 mA Constant Current

IP68

26mm

F5064 LED Mini Round Uplighter

3W High power LED mini in ground up lighter. Features mounting sleeve and waterproof silicone seal.

Material Aluminium housing, 316 grade stainless steel face, 12mm tempered glass lens

Size

Colour

Lamp

50 (Diameter) x 71 (Height) mm;

Mounting Sleeve: 72 (Diameter) x

90 (Height) mm

Stainless Steel

3W High power LED

Led Colour Cool White – 4000K

Warm White – 3000K

RGB – (RGB option requires LED-TW-

SN-12-24-RGB-CON remote controller).

Lumen Output Cool White – 67 Lm

Warm White – 57 Lm

RGB – 57 Lm

Beam Angle 30°

Power

IP Rating

24V DC

IP67

F5066-RND-LED LED Fixed Round

Uplighter

Fixed LED Uplighter. Features Pre-mount sleeve and 1.4m lead.

Material

Size

316 Stainless Steel, Tempered glass lens

66 (Diameter) x 126 (Height) mm

Colour

Lamp

Stainless Steel

1 X 5W Bridgelux LED

Led Colour Warm White - 3000K

Lumen Output Warm White - 240 Lm

Beam Angle 20°

Power 12V DC

IP Rating

Cut Hole

IP67

61mm

Gentech Lighting

175

INGROUND UPLIGHTERS LED

176

F5066-SQ-LED

LED Fixed Square Uplighter

Fixed LED Uplighter. Features Pre-mount sleeve and 1.4m lead.

Material

Size

Colour

316 Stainless Steel, Tempered glass lens

66 (Length) x 66 (Width) x

126 (Height) mm

Stainless Steel

Lamp 1 X 5W Bridgelux LED

Led Colour Warm White – 3000K

Lumen Output Warm White – 240 Lm

Beam Angle 20°

Power

IP Rating

Cut Hole

12V DC

IP67

61mm

F5067-RND-LED

LED Adjustable Round Uplighter

Adjustable LED Uplighter. Features internal lamp adjustment and Pre-mount sleeve fitted with

1.4m lead.

Material

Size

316 Stainless Steel, Tempered glass lens

84 (Diameter) x 150 (Height) mm

Colour Stainless Steel

Lamp 1 X 5W Bridgelux LED

Led Colour Warm White – 3000K

Lumen Output Warm White –240 Lm

Beam Angle 40°

Power

IP Rating

Cut Hole

12V DC

IP67

77mm

F5067-SQ-LED

LED Adjustable Square Uplighter

Adjustable Square LED Uplighter fitted with Bridgelux

LED. Features internal lamp adjustment, Pre-mount sleeve and 1.4m lead.

Material

Size

316 Stainless Steel, Tempered glass lens

84 (Length) x 84 (Width) x

150 (Height) mm

Colour

Lamp

Stainless Steel

1 X 5W Bridgelux LED

Led Colour Warm White – 3000K

Lumen Output Warm White – 240 Lm

Beam Angle 40°

Power

IP Rating

Cut Hole

12V DC

IP67

77mm

Gentech Lighting

F721 Stainless Steel Wink

In ground or wall mounted stainless steel eyelid.

Material 316 Stainless Steel, Tempered glass lens

Size

Colour

Lamp

97(Diameter) x 110 (Depth) mm

Stainless Steel

Max. 12V/20W Dichroic

Optional LED lamps available

90

97

120

70

Power

IP Rating

Cut Hole

12V AC

IP65

75mm

110

120

70

75

F5010 Uplight

90

Small outdoor uplight providing an elegant and compact appearance. Flush glass lens prevents water residual and

75 dirt accumulation

50

Material Aluminium, Tempered glass lens

Size 98 (Diameter) x 100 (Height) mm

Colour Black

73

Lamp Max. 12/50W Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP66

75mm

100

75

F5050 Brass Uplight

Solid brass die-cast uplight for a sturdy and classy dirt accumulation

98 installation. Flush glass lens prevents water residual and

98

Material Solid Brass

Size

Colour

Lamp

Power

IP Rating

Cut Hole

Brass, Antique Brass

Max.12V/50W Dichroic

Optional LED lamps available

12V AC

IP66

75mm

100

98

F5050-PRE-MOUNT

Pre Mounts for Brass Uplight

F5050-RPM

– Round Pre Mount

F5050-SPM

– Square Pre Mount

INGROUND UPLIGHTERS 12V

Gentech Lighting

177

INGROUND UPLIGHTERS 12V

F5060-RPM

Round Pre Mount

F5060 Stainless Steel Uplight Round

Small outdoor uplight providing an elegant and compact appearance. Flush glass lens prevents water residual and dirt accumulation.

Material 304, 316 Stainless Steel, Tempered glass lens

Size

Colour

Lamp

97 (Diameter) x 100 (Height) mm

Stainless Steel

Max.12V/35W Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP66

75mm

F5060-RPM+T

Round Pre Mount with Tube

F5060-PRE-MOUNT

Pre Mount for Round Stainless Steel

Uplight

F5060-RPM

– Round Pre Mount

F5060-RPM+T

– Round Pre Mount with Tube

F5060-SPM

– Square Pre Mount

F5060-SPM+T

– Square Pre Mount with Tube

F5060-SPM

Square Pre Mount

178

F5060-SPM+T

Square Pre Mount with Tube

F5062 Stainless Steel Uplight Square

Small outdoor inground uplight. Clean line on face plate with flush glass lens to prevent dirt accumulation.

Material

Size

316 Stainless Steel, Tempered glass lens

Colour

Lamp

97 (Length) x 97 (Width) x

100 (Height) mm

Stainless Steel

Max. 12V/35W Dichroic

Optional LED lamps available

Power

IP Rating

Cut Hole

12V AC

IP66

75mm

Gentech Lighting

F5062-PRE-MOUNT

Pre Mount for Square Stainless Steel

Uplight

F5062-SPM

– Pre Mount

F5062-SPM+T

– Pre-Mount with Tube

F101HOUSING Uplight Housing Range

Make your own uplight with a selection of faces and glass.

Stone texture finish is acid and alkaline resistant, cast tempered glass.

Material

Size

Die-cast Aluminium Housing and accessories,Tempered glass lens

90 (Diameter) x 80 mm

Colour Silver

Lamp Max. 12V 35W Dichroic

Optional LED lamps available

Power

IP Rating

12V AC

IP 65

Glasses Faces

INGROUND UPLIGHTERS 12V

F101GLS-FLUSH-FRS

– Frost flush glass for F101

Housing

F101GLS-FLUSH-RIB

– Ribbed flush glass for F101

Housing

F101-GYRO F101-RING

F101-LENEZ

Other Accessories

F101SASH

F101-GRATE

F101-WINK

Round pre-mount for F101 Square pre-mount for F101 U bracket for F101

Gentech Lighting

179

POND LIGHTS

GARDEN SPOTLIGHTS

180

F5000BKT Aquatic

Die-cast aluminium compact submersible pond light with

3 metet lead. (Not suitable for swimming pools). Optional clip-on colour lenses available.

120

Material Aluminium, Tempered glass lens

70

Size

Colour

90 (Diameter) x 120 mm

(overall)

Black, Pale Green

90

Lamp

Power

IP Rating

Max. 12V 35W Dichroic submersed /

Max. 12V 20W Dichroic open-air

Optional LED lamps available

12V AC

120

IP68

70

73

90

75

F5100 Poly Aquatic

Durable poly carb submersible pond light with 3 metre lead. Suitable in adverse water conditions. Optional colour lenses available.

50

Material

Size

Polycarbonate Plastic, Tempered glass lens

73 (Diameter) x 75 (Height) mm

Colour Black

Lamp Max. 12V 20W Dichroic

Optional LED lamps available

73

98

75

Power

IP Rating

12V AC

IP68

100

50

B-C022 Shield Spot

98

98 hooded lens cap, elbow adjustment and 1 metre lead.

Optional rod extension and mounting base available.

Material

Size

Solid Brass, Tempered glass lens

180 x 60 mm (head)

Colour

Lamp

Power

IP Rating

Antique Bronze, Stainless Steel

Max. 12V/50W MR16 Dichroic

Optional LED lamps available

12V AC

IP56

100

98

B-C032-MR11 Mini Shield Spot MR11

Mini MR11 garden spotlight with spike. Features adjustable hooded lens cap and elbow adjustment.

Optional rod extension and mounting base available.

Material

Size

Solid Brass, Tempered glass lens

80 x 40 mm (head)

Colour

Lamp

Power

IP Rating

Antique Bronze, Stainless Steel

Max. 12V/20W MR11

Optional LED lamps available

12V AC

IP56

Gentech Lighting

B-C033 Mini Shield Spot

Mini MR8 garden spotlight with spike.

Features adjustable hooded lens cap and elbow adjustment. Optional rod extension and mounting base available.

Material Solid Brass, Tempered glass lens

Size

Colour

Lamp

80 x 40 mm (head)

Antique Bronze Stainless Steel

Max. Ministar Bi-Pin Reflector,

12V/20W MR8

Optional LED lamps available

Power

IP Rating

12V AC

IP56

B-C044 Oval Shield Spot

Antique bronze garden spotlight with spike. Compact size, offers in-built reflector, frost glass lens and elbow adjustment. Optional rod extension and mounting base available.

Material

Size

Solid Brass, Tempered glass lens

110 x 60 mm (head)

Colour

Lamp

Power

IP Rating

Antique Bronze

Max. 12V 20W G4 Halogen

Optional LED lamps available

12V AC

IP56

B-MB Mounting Base

Mounting base for solid brass garden spot lights.

Available in stainless steel or antique bronze finishes.

B-ROD-30 Mounting Rod

Extension posts for solid brass garden spot lights.

Length: 30 cm

Available in stainless steel or antique bronze finishes.

GARDEN SPOTLIGHTS

Gentech Lighting

181

GARDEN SPOTLIGHTS

F7060N-316-HEAD

Stainless Steel Spot light head only

Round head stainless steel spotlight head only. Features twist cap face for easy lamp replacement. Pictured with optional spike.

Material 316 Stainless Steel, Tempered glass lens

Size

Colour

Lamp

55 (Diameter) x 80 mm (head only)

Stainless Steel

Max. 12V/35W Dichroic

Optional LED lamps available

Power

IP Rating

12V AC

IP65

F7060N-316

With back plate

F7060N

With in-built transformer

AP-MB-SS-RND

Stainless Steel Round Base

Back plate to suit stainless steel garden spot light.

Size 70 (Diameter) x 30 (Height) mm

F7060-ROD-400 Stainless Steel Spike

Extension spike to suit stainless steel garden spot light

Available in 304 grade stainless steel.

AP-MB-SS-RND

Stainless Steel Round Base

F7060-ROD-400

Stainless Steel Spike

F7030N-BK Optic Spot

Die-cast aluminium spotlight complete with spike.

Features twist lock lens cap and elbow adjustment.

Optional mounting plate or mounting box with in-built transformer.

Material

Size

Aluminium, Tempered glass lens

76 (Diameter) x 83 mm (head only)

Colour Black

Lamp Max. 12V/50W Dichroic

Optional LED lamps available

Power

IP Rating

12V AC

IP56

182

Gentech Lighting

F7150 Shield Flood

Die-cast aluminium spotlight complete with spike.

Features twist lock hooded lens cap elbow adjustment and 1.5 metre lead.

Material

Size

Aluminium, Tempered glass lens

76 (Diameter) x 130 mm (head only)

Colour

Lamp

Power

IP Rating

Black, Silver

Max. 12V/50W Dichroic

Optional LED lamps available

12V AC

IP56

F7160 Round Shield

Die-cast aluminium spotlight complete with spike.

Features round body with twist lock hooded lens cap and elbow adjustment. Optional mounting plate or mounting box with in-built transformer.

Material

Size

Aluminium, Tempered glass lens

75 (Diameter) x 125 mm (head)

Colour Black

Lamp Max 12V/50W Dichroic

Optional LED lamps available

Power

IP Rating

12V AC

IP56

AP-MB Mounting Plate for F7150, F7160, and F7030

Aluminium mounting plate for garden spot lights

Size 90 (Diameter) mm

Colour Black, Silver

AP-ER-ROD Plastic Extension Rods for

F7150, F7160, and F7030

Plastic extension rods garden spotlights.

Sizes 200, 250 and 300 mm, with 15 mm riser coupling.

Colour Black

AP-MB

AP-EN+T Mounting Box for F7150, F7160, and F7030

Weather proof mounting box with in-built toroidal transformer.

Size

Colour

142 x 95 x 65 (Height) mm

Black, Silver

Input Power 240V AC 50Hz

Output Power 12V AC 20-60W Max.

IP Rating IP 55

Gentech Lighting

GARDEN SPOTLIGHTS

F7150+AP-EN+T

With in-built transformer

AP-ER-ROD

183

PATH LIGHTS

B-D101-TURBO

184

B-D100-TURBO Turbo Solid Brass Bollard

Compact brass bollard features solid glass diffuser and

1000mm of 16 AWG cable.

Material

Size

Solid Brass, Glass lense

600 mm (Height) x 60 mm (Diameter)

Colour

Lamp

Power

IP Rating

Antique Bronze, Stainless Steel

Max. 12V 35W Dichoric

Optional LED lamps available

12V AC or 12V DC

IP65

B-D103-TURBO

Solid Brass Hooded Path light

Die-cast brass path light. Features dome hood clear glass diffuser. Complete with spike and 900mm 18 AWG cable.

Optional extension post and mounting base available.

Material

Size

Colour

Lamp

Solid Brass, Tempered glass diffuser

460 mm (post) 70 mm x 155 mm

(Diameter)

Antique Bronze, Stainless Steel

Max. 12V G4 Halogen 20W

Optional LED lamps available

Power

IP Rating

12V AC / DC

IP54

B-D102-TURBO

Solid Brass Adjustable Path light

Spun brass path light. Features adjustable conical hood frost glass diffuser. Complete with spike and 900mm 18

AWG cable. Optional mounting base available

Material

Size

Colour

Lamp

Solid Brass, Tempered glass diffuser

600 mm (post) 85 mm x 140 mm

(Diameter)

Antique Bronze, Stainless Steel

Max. 12V G4 Halogen 20W

Optional LED lamps available

Power

IP Rating

12V AC / DC

IP54

B-D101-TURBO Turbo Mounting Base

Mounting base for Turbo path lights

Available in stainless steel or antique bronze finishes.

BRASS-STAKE Brass Spike

Solid brass spike for Turbo path lights

Available in stainless steel or antique bronze finishes.

BRASS-STAKE

Gentech Lighting

F2501 Lighthouse Path Light

Stainless steel path light complete with spike

Material 304 Stainless Steel

Size

Colour

Lamp

350 x 57 mm

Stainless Steel

Max. 12V/20W Bi-Pin Burner

Optional LED lamps available

Power

IP Rating

12V AC

IP54

F4501 Bravo Path Light

Compact path light featuring internal cone shaped acrylic reflector complete with spike. Optional extension post available in 150 and 300 mm.

Material

Size

Aluminium, Acrylic diffuser

164 x 57 mm

Colour

Lamp

Power

IP Rating

Black, Silver

Max. 12V/20W Dichroic

(Not aluminium backed lamps)

Optional LED lamps available

12V AC

IP54

F5501 Capella Path Light

Compact path light featuring two angle refracted light beam spread complete with spike. Optional extension post available in 150 and 300 mm.

Material

Size

Aluminium, Acrylic diffuser

167 x 57 mm

Colour Black

Lamp Max. 12V/20W Dichroic

Optional LED lamps available

Power

IP Rating

12V AC

IP54

F08215 and F08230

Aluminium Extension Post for F4501 and F5501

Size F08215 150 mm

F08230 300 mm

Available in Black or Silver

Gentech Lighting

PATH LIGHTS

185

BOLLARDS

A

186

D

B

E

C

A. EX2000 Bollard

Three tier aluminium bollard head complete with PVC post.

Material Aluminium, PVC post

Size Post size: 77 (Diamter) x 1000 mm /

Top Size: 158 (Diamtere) x 215 mm

Colour Black

Lamp Max. 60W E27, 13W PLC kit

Optional LED lamps available

Power

IP Rating

240V AC 50Hz

IP33

B. EXC1081 Large Bollard

Ten tier aluminium bollard head and post.

Material Aluminium

Size Post size: 122 (Diamter) x 1000 mm

Base: 150( Diameter) mm

Overall height: 1105 mm

Colour Black

Lamp Max. 60W E27, 13W, 18W PLC kit

Optional LED lamps available

Power

IP Rating

240V AC 50Hz

IP33

C. G2005 Pillar Bollard

Aluminium bollard head and post with polycarbonate diffuser. Features sturdy mounting base. Available in two height sizes.

Material

Size

Aluminium, Polycarbonate diffuser

122 (Diamter) mm

Overall heights: 600 mm, 1000 mm

Colour Black

Lamp Max. 60W E27, 13W, 18W, 26W PLC kit

Optional LED lamps available

Power

IP Rating

240V AC 50Hz

IP33

D. G2003 Beacon Bollard

Energy saver bollard with integral gear. Features opal acrylic diffuser which unscrews for lamp replacement.

Allen key side fixing at base.

Material

Size

Aluminium, Acrylic diffuser

90 (Diameter) x 600 mm

Colour Aluminium

Lamp Max. 18W PLC (2-Pin)

Optional LED lamps available

Power

IP Rating

240V AC 50Hz

IP54

E. LED503 Pyramid

3x3W LED pathlight complete with in-built driver.

Features clear acrylic diffuser with decorative frost insert.

Comes with 60cm lead.

Material Aluminium, Acrylic diffuser

Size 80 (Diameter) x 380 mm

160 mm (flange)

Colour Aluminium

Lamp 3 x 3W LED

Led Colour Warm White, Cool White

Power 240V AC 50Hz

IP Rating IP55

Gentech Lighting

POST TOPS

Poly carbinate post top garden lights to suit

61 mm diameter post. Available in 200, 250 and

300mm diameter sizes.

Material Poly Carbonate

Colour

Lamp

Opal, Smoke

200 mm: Max: 60W E27 or 13W PLC Kit

250 mm: Max:75W E27 or 13W PLC Kit

300 mm: Max: 100W E27 or 18W PLC Kit

Optional LED lamps available

Power 240V AC 50Hz

G51O

Poly Carbonate Post Top

Opal 200mm

G52O

Poly Carbonate Post Top

Opal 250mm

G53O

Poly Carbonate Post Top

Opal 300mm

G53-BASKET Basket

Poly carbonate basket accessory for 300 mm post top.

Available in black.

G51S

Poly Carbonate Post Top

Smoke 200mm

G52S

Poly Carbonate Post Top

Smoke 250mm

G53S

Poly Carbonate Post Top

Smoke 300mm

With Basket Accessory

PARTS AND ACCESSORIES

CABLE-18-FLT

1mm² two core flat cable

CABLE-18-RND

1mm² two core round cable

CABLE-12

4mm² two core flat cable

CABLE-8

8.5mm² two core flat cable

CA60010

Weather proof Junction box for flat cable

CA60020

Weather proof Junction box for round cable

LSCABLE

Low Voltage Landscape Cable

Gentech Lighting

187

188

Gentech Lighting

LED MR16

LED-MR16-DE3 LED-MR16-5W LED-MR16-5W-SHARP LED-MR16-KE-5W

LED-MR16-7W LED-MR16-8W-D-HP LED-MR16-RGB LED-IRC-160

Product Code and Name

Size LED Colour Wattage Lumen

Output

Beam Power

Angle

LED-MR16-DE3

Diamond Eye III

LED-MR16-5W

LED MR16 5W Low |

Temperature Lamp:

Dimmable, can be enclosed

50 (Diameter) x

48 (Length) mm

50 (Diameter) x

38 (Length) mm

LED-MR16-5W-SHARP 50 (Diameter) x

MR16 SHARP LED Lamp 45 (Length) mm

Cool White

Cool White,

Warm White

3W

5W EPISTAR

Cool White, 5W

Warm White

LED-MR16-KE-5W-D

50 (Diameter) Cool White: 5W

LED MR16 KE 5W Lamp x 40 (Length) mm 4100K,

Dimmable Warm White:

2100K

100Lm

CW: 200Lm

WW: 185Lm

CW: 355Lm

WW: 310Lm

CW: 220Lm

WW: 220Lm

30°

45°

45°

45°

12V AC/DC

12V AC/DC

12V AC/DC

12V AC/DC

LED-MR16-7W

LED MR16 7W Lamp

49.2 (Diameter) Cool White, 7W EPISTAR CW: 460Lm 45° 12V AC/DC x 38.2 (Length) mm Warm White WW: 380Lm

LED-MR16-8W-D-HP

LED MR16 8W High

50 (Diameter) Cool White, 8W CREE XGP CW: 505Lm 52° 12V AC/DC x 48 (Length) mm Warm White WW: 390Lm

Powered Dimmable

LED-MR16-RGB

LED RGB Lamp

50 (Diameter) Red Green x 46 (Length) mm Blue

5W EPISTAR 50° 12V AC

LED-IRC-160

Remote Controller for LED MR16 RGB Globes. Features sixteen pre set single colour keys

Remote Control for MR16 and four pre-set colour changing modes: Flash, Strobe, Fade quickly and Fade slowly.

RGB Lamp Maximum operable distance –10m. Power: 2 x AA Batteries

Gentech Lighting

189

LED G4 BI-PIN

LED-BI-PIN-0.2W

LED-BI-PIN-0.5W

LED-BI-PIN-1W LED-BI-PIN-1.5W-24

LED-BI-PIN-1.8W-13C LED-BI-PIN-18C LED-BI-PIN-3.2W-24 LED-BI-PIN-3W-45

LED-BI-PIN-1.4W

LED-BI-PIN-1H LED-BI-PIN-1W-4C LED-BI-PIN-2W-12C

190

Gentech Lighting

LED G4 BI-PIN

Product Code and Name

LED-BI-PIN-0.2W

Size

Length:19mm

+ Pins: 14mm

LED-BI-PIN-0.5W

LED-BI-PIN-1W

Length:19mm

+ Pins : 14mm

Length :21mm

+ Pins : 12mm

LED-BI-PIN-1.5W-24 Length:15mm

+ Pins : 8mm

Diameter: 15mm

LED-BI-PIN-1.8W-13C Length:23mm

+ Pins: 12mm

Diameter: 18mm

LED Colour

Blue, Green, Red

Red, Yellow

Warm White

Warm White

Warm White

LED-BI-PIN-18C

LED-BI-PIN-3.2W-24 Length:14mm

+ Pins : 7mm

Diameter: 15mm

LED-BI-PIN-3W-45

Length:31mm

+ Pins: 9mm

Diameter: 18mm

Length:26mm

+ Pins: 7mm

Diameter: 18mm

LED-BI-PIN-1.4W

Diameter:29mm,

Suitable to be enclosed Length with pins: 35mm

LED-BI-PIN-1H

Diameter:20mm,

Length with pins: 28mm

LED-BI-PIN-1W-4C Diameter:13mm,

Length with pins: 31mm

Blue, Warm White

Warm White

Cool White,

Warm White

Cool White,

Warm White

Blue, Warm White

Warm White

LED-BI-PIN-2W-12C Diameter: 26.1mm, Cool White, Warm White

Length with pins: 34.5mm

Wattage

Daylight White, Warm White, 0.2W

Daylight White, Warm White, 0.5W

0.7W

1.5W

1.8W

1.8W

3.2W

3W

1.4W

0.5W

1W

2W

Lumen

Output

38Lm

100Lm

120Lm

Warm White:

62Lm

230Lm

Cool White: 12V AC/DC

204Lm

Warm White:

190Lm

Cool White: 12V DC

115Lm

Warm White: xx Lm

Power

12V AC/DC

12V AC/DC

12V AC/DC

12-30V AC/DC

12-30V AC/DC

Blue: 62Lm 12V AC/DC

12-30V AC/DC

Blue: 14Lm 12V AC/DC

Warm White:

18Lm

12Lm 12V AC/DC

CW:180Lm 12-30V AC/DC

WW : 170Lm

Gentech Lighting

191

LED AR111

Product Code

Description

Size

LED Colour

LED-AR111-14W

6 x 2W CREE XPE LED

Dimmable with DC LED Driver.

Not suitable for enclosed fittings.

Diameter: 111 x Length: 58mm

Cool White, Warm White

Colour Temperature Cool White: 6000K

Warm White: 3000K

Wattage 14W

Lumen Output

Cool White: 685 Lm

Warm White: 484 Lm

Beam Angle 32°

Power

12V DC

LED-AR111-16W

6 x 2.5W CREE XPE LED

Dimmable with DC LED Driver.

Not suitable for enclosed fittings.

Diameter: 111 x Length: 58mm

Natural White

Natural White: 4000K

16W

Natural White: 880 Lm

16°

12V DC

192

Gentech Lighting

LED GU10

LED-GU10-DE3 LED-GU10-5W-SHARP LED-GU10-5W LED-GU10-D-KE-6W

LED-GU10-7W-D LED-GU10-ECO-7W LED-GU10-8W-HP

Product Code and Name

Size LED Colour Colour

Temperature

Wattage Lumen

Output

LED-GU10-DE3

Face Diameter: Cool White

50mm Warm White

Length: 65mm

3W

LED-GU10-5W-SHARP Face Diameter: Cool White

Cool White: 5W

(Non Dimmable) 49mm Warm White 6000K

Length: 58mm Warm White:

3000K

LED-GU10-5W

Suitable for enclosed fittings

Face Diameter: Cool White Cool White: 5W

50mm Warm White 6000K

Length: 53mm Warm White:

3000K

355 Lm

Warm White:

310 Lm

Warm White:

185 Lm

Beam Power

Angle

30°

Cool White: 45°

200-240V

50/60Hz

200-240V

50/60Hz

Cool White: 50° 100-240V

200 Lm 50/60Hz

LED-GU10-D-KE-6W

Face Diameter: Cool White Cool White: 6W

Dimmable) 50mm

Length: 53mm

Warm White 4100K

Warm White:

2800K

LED-GU10-7W-D

(Dimmable)

Face Diameter: Cool White Cool White: 7W

49mm

Length: 46mm

Warm White 6000K

Warm White:

3000K

LED-GU10-ECO-7W

Face Diameter: Cool White Cool White: 7W

(Non Dimmable) 51mm Warm White 6000K

Length: 65mm Warm White:

3000K

LED-GU10-8W-HP

(Dimmable)

Cool White: 45°

220 Lm

Warm White:

220 Lm

380 Lm

Warm White:

350 Lm

200-240V

50/60Hz

Cool White: 50° 200-240V

460 Lm

Warm White:

50/60Hz

Cool White: 47° 200-240V

420 Lm 50/60Hz

Face Diameter: Cool White Cool White: 8W

50mm Warm White 6000K

Cool White: 52°

CREE XPG 505 Lm

200-240V

50/60Hz

Length: 80mm Warm White:

3000K

Warm White:

390 Lm

Gentech Lighting

193

LED PAR

LED-PAR20-ES-8W LED-PAR30-ES-14W LED-PAR38-18W-IP65

Product Code LED-PAR20-ES-8W

Wattage 8W

Size

Lamp

63 (Diameter) x

86 (Length) mm

3 x 2.5W CREE

XRE LED

LED-PAR30-ES-14W

Suitable for out doors

14W

96 (Diameter) x

93 (Length) mm

9 x 1.2W CREE

XRE LED

LED Colour Warm White,

Cool White

Warm White,

Cool White

Lumen Output Warm White: 560 Lm Warm White: 720 Lm

Cool White: 700 Lm Cool White: 900 Lm

Beam Angle

Power

40°

240V AC

21°

240V AC

LED-PAR38-20W

LED-PAR38-18W-IP65 LED-PAR38-20W

18W

120 (Diameter) x

122 (Length) mm

9 x 2W NICHIA LED

Warm White,

Cool White

20W

120 (Diameter) x

122 (Length) mm

16 x .8W NICHIA LED

Warm White,

Cool White

Warm White: 1000 Lm Warm White: 1000 Lm

Cool White: 1300 Lm Cool White: 1300 Lm

21°

240V AC

40°

240V AC

LED E27 GLS

LED-GLS-ES-9W LED-GLS-BC-9W LED-FR-ES-3W

Product Code LED-GLS-ES-9W

LED 9W ES

Wattage 9W

LED-GLS-BC-9W

LED 9W BC

9W

LED-FR-ES-3W

Fancy Round ES

3W

Size

Lamp

Power

60 (Diameter) x110 (Length) mm 60 (Diameter) x110 (Length) mm 36 (Diameter) x 16 (Length) mm

CREE MX6 LED CREE MX6 LED 3W Epistar LED

LED Colour Warm White, Cool White

Lumen Output Warm White : 411 Lm

Cool White : 518 Lm

Beam Angle 120°

240V AC

Warm White, Cool White

Warm White: 411 Lm

Cool White: 518 Lm

120°

240V AC

Warm White, Cool White

Warm White: 230 Lm

Cool White: 260 Lm

270°

240V AC

194

Gentech Lighting

LED DRIVERS CONSTANT CURRENT

Constant Current Driver (power supply)

Typical for 350mA and 700mA LED lighting

Serial Connection (polarization required) must be RED(+) connected to BLACK(-) and BLACK(-) to RED(+)

LED Serial Connection

LED terminal blocks with 1m lead, to connect multiple quick connect LED fittings to a single constant current quick connect

LED driver. The terminal blocks complete the serial connection required for constant current runs. Various extension leads available in 1, 2, 3 and 5 metre lengths with connectors.

Terminal for two fittings to one driver

Power: 350mA

LED-1M-350MA-TERM-2-1

Two to one 350mA Terminal Block

LED-1M-350MA-TERM-3-1

Three to one 350mA Terminal Block

LED-1M-350MA-TERM-6-1

Six to one 350mA Terminal Block

Terminal for three fittings to one driver

Terminal for six fittings to one driver

Power: 700mA

LED-1M-700MA-TERM-2-1

Two to one 7000mA Terminal Block

LED-1M-700MA-TERM-3-1

Three to one 7000mA Terminal Block

LED-1M-700MA-TERM-6-1

Six to one 7000mA Terminal Block

Gentech Lighting

195

LED DRIVERS CONSTANT CURRENT

E3-350MA-3W-MINI E3-350MA-3W E3-350MA-18W-QC-ST

E9-350MA-12W-ST E7-700MA-9W E9-700MA-18W-ST

Product Code

E3-350MA-3W-MINI

Quick Connect or

Screw Terminal

E3-350MA-3W

Quick Connect or

Screw Terminal

Power Size Output

Primary: 220-240V AC 50 (Length) x

50/60Hz 28 (Width) x

20 (Height) mm

Current: 350mA constant

Voltage: 3-9V DC

Wattage: 3W max.

Primary: 220-240V AC 54.6 (Length) x

50/60Hz 39 (Width) x

Current: 350mA constant

20 (Height) mm Voltage: 3-9V DC

Wattage: 1-3W max

Temperature Power ta= -20°C - λ=0.40

+50°C, tc= 70°C factor

E3-350MA-4W

Quick Connect

E3-350MA-6W

Screw Terminal

Primary: 220-240V AC 72.8 (Length) x

50/60Hz 40 (Width) x

Current: 350mA constant ta= -20°C - λ=0.55

+50°C,

16 (Height) mm Voltage: 3-12V DC

Wattage: 1-4W max. tc= 70°C

Primary: 220-240V AC 104 (Length) x

50/60Hz 39 (Width) x

25 (Height) mm

Current: 350mA constant

Voltage: 3-22V DC

Wattage: 6W max.

ta= +50°C, tc= 80°C

E3-350MA-12W-QC-ST Primary: 220-240V AC 167 (Length) x

50/60Hz

Current: 350mA

38.4 (Width) x constant

29.3 (Height) mm Voltage: 18-36V DC

Wattage: 6-12W max. ta= -20°C - λ=0.95

+50°C, tc= 70°C

196

Gentech Lighting

LED DRIVERS CONSTANT CURRENT oduct Code Power Size Output Temperature Power factor

E3-350MA-18W-QC-ST Primary: 220-240V AC 153 (Length) x

50/60Hz 67 (Width) x

Current: 350mA constant

30.5 (Height) mm Voltage: 30-54V DC

Wattage: 10-18W max.

ta= -20°C - λ=0.95

+50°C, tc= 70°C

E7-700MA-3W

Quick Connect or

Screw Terminal

E7-700MA-6W-ST

Primary: 220-240V AC 50 (Length) x

50/60Hz 40 (Width) x

Primary: 220-240V AC 104 (Length) x

50/60Hz 39 (Width) x

Current: 700mA constant

20 (Height) mm Voltage:4.5V DC

Wattage: 3W max.

Current: 700mA constant

25 (Height) mm Voltage:5-9V DC

Wattage: 6W max.

ta= -20°C -

λ=0.40

+50°C, tc= 70°C ta= +50°C, tc= 80°C

λ=0.40

E7-700MA-9W

Quick connect or

Screw Terminal

Primary: 220-240V AC 114 (Length) x

50/60Hz 42 (Width) x

29 (Height) mm

Current: 700mA constant

Voltage: 4-13V DC

Wattage: 3-9W max. ta= -20°C - λ=0.40

+50°C, tc= 70°C

E7-700MA-18W-QC-ST Primary: 220-240V AC 115 (Length) x

50/60Hz 43 (Width) x

28 (Height) mm

Current: 700mA constant

Voltage: 15-18V DC

Wattage: 18W max. ta= -45°C,

λ=0.92 tc= 85°C ta=45°C, tc= 85°C

λ=0.90

E9-700MA-10W-ST

Dimmable

E9-350MA-12W-ST

Dimmable

Primary: 220-240V AC 112 (Length) x

50/60Hz 40 (Width) x

Current: 700mA constant

26 (Height) mm Voltage: 16V DC

Wattage: 10W max.

Primary: 220-240V AC 112 (Length) x

50/60Hz 40 (Width) x

Current: 350mA constant

26 (Height) mm Voltage: 43V DC

Wattage: 12W max.

ta= 45°C, tc= 85°C

λ=0.90

E9-350MA-18W-ST

Dimmable

E9-700MA-18W-ST

Dimmable

Primary: 220-240V AC 145 (Length) x

50/60Hz 47 (Width) x

28 (Height) mm

Primary: 220-240V AC 144 (Length) x

50/60Hz 37 (Width) x

29 (Height) mm

Current: 350mA constant

Voltage: 43V DC

Wattage: 18W max.

Current: 700mA constant

Voltage: 23V DC

Wattage: 18W max.

ta= 50°C, tc= 80°C ta= 40°C, tc= 80°C

λ=0.95

λ=0.95

Gentech Lighting

197

LED DRIVERS CONSTANT VOLTAGE

DC12V and DC24V Constant Voltage Driver (power supply)

Typical for LED Strip or Rope Lighting (i.e. LED Twister, Snake, Rule etc).

Parallel Connection (polarization required) all RED(+) wires connected together and BLACK(-) wires with BLACK wires together

LED Parallel Connection

E5-24VDC-3W E5-12VDC-6W-ST E5-12VDC-8-4W

E9-12VDC-8W-ST E5-12VDC-12W E5-24VDC-60W

Product Code

E5-12VDC-4.2W

Screw Terminals

E5-12VDC-6W

Screw Terminals

Product Name

12V DC 4.2W

LED Driver

12V DC 6W

LED Driver

Power Size

Primary: 220-240V

~50/60Hz;

Driver: 49 (Length) x

40 (Width) x

Secondary: 12V DC 23 (Height) mm;

Voltage:

12V DC

Wattage:

0-4.2W max. Terminal Box:

72 (Length) x

38 (Width) x

29 (Height) mm

Primary: 220-240V~ 48 (Length) x

50/60Hz; 50 (Width) x

Secondary: 12V DC 23 (Height) mm

Output

Voltage:

12V DC

Wattage:

0-6W max.

Temperature ta= 50°C tc= 70°C ta= 50°C tc= 70°C

E5-12VDC-8-4W

Transformer

Screw Terminals 12V DC 8-4W

Primary: 220-240V~

50/60Hz;

Driver: 62 (Length) x

28 (Width) x

Secondary: 12V DC 35 (Height) mm;

Terminal Box:

72 (Length) x

38 (Width) x

29 (Height) mm

E9-12VDC-8W-ST 12V DC 8W Lead

Primary: 220-240V~ 112 (Length) x

Dimmable & Trail Edge 50/60Hz; 40 (Width) x

Dimmable Driver Secondary: 12V DC 26 (Height) mm

Voltage:

12V DC

Wattage:

0-8.4W max.

Voltage: ta= 50°C

12-16V DC tc= 80°C

Wattage:

0-8W max.

ta= 50°C tc= 75°C

198

Gentech Lighting

Product Code

E5-12VDC-10W

Screw Terminals

Product Name

12V DC 10W

LED Driver

E5-12VDC-12W 12V DC 12W

LED Driver

E5-12VDC-12W-T Transformer

Screw Terminals 12V DC 12W

E5-12VDC-24W

E5-12VDC-60W

E5-12VDC-90W

E5-24VDC-3W

Screw Terminals

12V DC 24W

LED Driver

12V DC 60W

LED Driver

12V DC 90W

LED Driver

24V DC 3W

LED Driver

E5-24VDC-12W

Screw Terminals

E5-24VDC-20W

Screw Terminals

24V DC 12W

LED Driver

24V DC 20W

LED Driver

E5-24VDC-24W

E5-24VDC-60W

24V DC 24W

LED Driver

24V DC 60W

LED Driver

E5-24VDC-120W

24V DC 120W

LED Driver

LED DRIVERS CONSTANT VOLTAGE

Power Size

Primary: 220-240V~ 125 (Length) x

50/60Hz; 38 (Width) x

Secondary: 12V DC 25 (Height) mm

Primary: 220-240V~ 131 (Length) x

50/60Hz; 43 (Width) x

Secondary: 12V DC 31 (Height) mm

Primary: 220-240V~ 86 (Length) x

50/60Hz; 41 (Width) x

Secondary: 12V DC 23 (Height) mm

Primary: 220-240V~ 131 (Length) x

50/60Hz; 43 (Width) x

Secondary: 12V DC 31 (Height) mm

Primary: 220-240V~ 152 (Length) x

50/60Hz; 57 (Width)x

Secondary: 12V DC 31 (Height) mm

Primary: 220-240V~ 172 (Length) x

50/60Hz; 61 (Width) x

Secondary: 12V DC 37 (Height) mm

Primary: 220-240V~ 56 (Length) x

50/60Hz; 39 (Width) x

Secondary: 24V DC 20 (Height) mm

Primary: 220-240V~ 85 (Length) x

50/60Hz; 41 (Width) x

Secondary:24V DC 22 (Height) mm

Primary: 220-240V~ 167 (Length) x

50/60Hz; 38 (Width) x

Secondary: 24V DC 30 (Height) mm

Primary: 220-240V~ 128 (Length) x

50/60Hz; 43 (Width) x

Secondary: 24V DC 31 (Height) mm

Primary: 220-240V~ 151 (Length) x

50/60Hz; 57 (Width) x

Secondary: 24V DC 31 (Height) mm

Primary: 220-240V~ 174 (Length) x

50/60Hz; 59 (Width) x

Secondary: 24V DC 36 (Height) mm

Output

Voltage:

12V DC

Wattage:

0-10W max.

Temperature ta= 45°C tc= 75°C

Voltage:

12V DC ta= -29° -

50°C

Wattage: tc= 75°C

0-12W max.

Voltage:

12V DC ta= -20° -

50°C

Wattage: tc= 85°C

0-12W max.

Voltage:

12V DC ta= -20° -

45°C

Wattage: tc= 75°C

0-24W max.

Voltage: ta= -29° -

12V DC 45°C

Wattage: tc= 75°C

0-60W max.

Voltage:

12V DC ta= -29° -

45°C

Wattage: tc= 75°C

0-90W max.

Voltage:

24V DC ta= -20° -

50°C

Wattage: tc= 70°C

0-3W max.

Voltage:

24V DC ta= -20° -

50°C

Wattage: tc= 85°C

0-12W max.

Voltage: ta= -20° -

24V DC 50°C

Wattage: tc= 75°C

0-20W max.

Voltage:

24V DC ta= -29° -

50°C

Wattage: tc= 75°C

0-24W max.

Voltage:

24V DC ta= -29° -

45°C

Wattage: tc= 75°C

0-60W max.

Voltage:

24V DC ta= -29° -

50°C

Wattage: tc= 75°C

0-120W max.

Gentech Lighting

199

LED DRIVERS CONSTANT VOLTAGE IP RATED

E5-12VDC-150W-WP E5-24VDC-16W-WP

E5-12VDC-100W-WP E5-24VDC-150W-WP

Product Code Power Size

E5-12VDC-16W-WP Primary: 100-240V AC 130 (Length) x

LED 12V DC Weather 50/60Hz

Proof Driver 16W

37 (Width) x

27 (Height) mm

E5-12VDC-100W-WP Primary: 100-240V AC

215 (Length) x

LED 12V DC Weather 50/60Hz 70 (Width) x

Proof Driver 100W 38 (Height) mm

E5-12VDC-150W-WP Primary: 100-240V AC 225 (Length) x

12V DC 150W Weather 50/60Hz 70 (Width) x

Proof LED Driver 40 (Height) mm

E5-24VDC-16W-WP Primary: 100-240V AC 128 (Length) x

24V Weather Proof

Driver 16W

50/60Hz 36 (Width) x

26 (Height) mm

E5-24VDC-150W-WP Primary: 100-240V AC

224 (Length) x

24V Weather Proof 50/60Hz 69 (Width) x

Driver 150W 39 (Height) mm

IP Rating Output

IP68

Temperature

Voltage: 12V DC ta= 50°C

Wattage: 16W max. tc= 80°C

IP65 Voltage: 12V DC ta= 50°C

Wattage: 100W max. tc= 85°C

IP67

IP68

IP67

Voltage: 12V DC

Wattage: 150W max. tc= 90°C

Voltage: 24V DC

Wattage: 16W max.

Voltage: 24V DC ta= 50°C ta= 50°C tc= 85°C ta= 50°C

Wattage: 150W max. tc= 80°C

200

Gentech Lighting

LV TRANSFORMERS ELECTRONIC

Common Low Voltage (240V a.c. 50Hz) and Extra Low Voltage (12V a.c. 50Hz)

No polarization required (equivalent to parallel connection)

12V-240V AC Parallel Connection

E60POD

Product Code Power

E60POD

60VA Pod

220-240V ~

50/60Hz 0.25A

E60RND

E60 Toroidal

E61RND

E61 Round

220-240V ~

50/60Hz 0.26A

220-240V ~

50/60Hz 0.25A

E70GENIE

Genie

220-240V ~

50/60Hz 0.29A

E105SPARKIE 220-240V ~

105VA Sparkie 50/60Hz 0.43A

E150SPARKIE 220-240V ~

150VA Sparkie 50/60Hz 0.62A

E60RND E70GENIE

Size Output Temperature Power factor

121 (Length) x 43 (Width) x Sec: 11.4V AC ta: 50°C tc: 75°C λ = 0.98

23 (Height) mm 20 - 60W

75 (Diameter) x

24 (Height) mm

58 (Diameter) x

22(Height) mm

Sec: 11.4V AC ta: 50°C tc: 80°C λ = 0.98

20 - 60W

Sec: 11.4V AC ta: 50°C tc: 82°C λ = 0.98V

20 - 60W

121 (Length) x 43 (Width) x Sec: 11.4V AC ta: 50°C tc: 75°C λ = 0.9870VA

23 (Height) mm 20 - 70W

145 (Length) x 38 (Width) x Sec: 11.4V AC ta: 45°C tc: 80°C λ = 0.98

26 (Height) mm 35 - 105W

147 (Length) x 46 (Width) x Sec: 11.4V AC ta: 45°C tc: 80°C λ = 0.98

35 (Height) mm 50 - 150W

Gentech Lighting

201

LV TRANSFORMERS ELECTRONIC IP RATED

EW105BURIAL

Product Code Power

EW105BURIAL

220-240V ~

105VA Electronic Burial 50/60Hz 0.45A

EW60BURIAL 220-240V ~

105VA Electronic Burial 50/60Hz 0.26A

EW60BURIAL

Size

59 (Width) x

32 (H) mm

IP Rating Output

135 (Length) x IP 68

135 (Length) x IP 68

59 (Width) x

32 (Height) mm

Temperature Power factor

Sec: 11.4V; ta: 45°C

35 - 105W tc: 75°C

Sec: 11.4V; ta: 50°C

20 - 60W tc: 75°C

λ = 0.98

λ = 0.98

LV TRANSFORMERS IRON CORE

Product Code Power

TM12A Iron Core 12V AC 12W Primary: 100-240V AC 50/60Hz

TM20A Iron Core 12V AC 20W Primary: 100-240V AC 50/60Hz

LVHW-050

LVHW-100

Primary: 240V AC / 50Hz

Primary: 240V AC / 50Hz

LVHW-200

LVHW-300

Primary: 240V AC / 50Hz

Primary: 240V AC / 50Hz

Size Output

50 x 80 x 48 mm

50 x 80 x 48 mm

Voltage: 12V AC

Wattage: 12W max.

Voltage: 12V AC

Wattage: 20W max.

186 X 122 X 112 mm Voltage: 12V AC

Wattage: 50W max.

186 X 122 X 112 mm Voltage: 12V AC

Wattage: 100W max.

186 X 122 X 112 mm Voltage: 12V AC

Wattage: 200W max.

186 X 122 X 112 mm Voltage: 12V AC

Wattage: 300W max.

202

Gentech Lighting

LV TRANSFORMERS IRON CORE IP RATED

Product Code

LVWP-020

Power

Primary: 100-240V AC

Iron Core 12V AC 20VA Dimmable 50/60Hz

Size

115 x 105 x 70 mm

IP Rating Output

IP 67 12V AC 20W Max.

12V AC 50W Max. LVWP-050 Primary: 100-240V AC 115 x 105 x 70 mm IP 67

Iron Core 12V AC 50VA Dimmable 50/60Hz

LVWP-100 Primary: 100-240V AC 115 x 105 x 70 mm IP 67

Iron Core 12V AC 100VA Dimmable 50/60Hz

12V AC 100W Max.

12V AC 150W Max. LVWP-150 Primary: 100-240V AC 165 x 150 x 75 mm IP 67

Iron Core 12V AC 150VA Dimmable 50/60Hz

LVWP-200 Primary: 100-240V AC 165 x 150 x 75 mm IP 67

Iron Core 12V AC 200VA Dimmable 50/60Hz

LVWP-300 Primary: 100-240V AC 165 x 150 x 75 mm IP 67

Iron Core 12V AC 300VA Dimmable 50/60Hz

LVWP-400 Primary: 100-240V AC 165 x 150 x 75 mm IP 67

Iron Core 12V AC 400VA Dimmable 50/60Hz

12V AC 200W Max.

12V AC 300W Max.

12V AC 400W Max.

Gentech Lighting

203

INDEX

AP-EN+T 183

AP-EN2+T 157

AP-ER-ROD 183

AP-MB 183

AP-MB-SS-RND 182

AR-735 147

AR-740 146

AR-BALANCE-KIT 150

AR-E01 147

AR-J01 148

AR-J02 149

AR-J04 149

AR-J06 149

AR-J06R 150

AR-J07 149

AR-J09 150

AR-J10 149

AR-J11 149

AR-PF1 148

AR-PFA 148

AR-PFD 148

AR-PFE 148

AR-PFW24 148

AR-RAIL 148

AR-ROD-J06 150

AR-RWS24 150

BAFFLE-TWIST 55

B-C022 180

B-C032-MR11 180

B-C033 181

B-C034-WALL-SPOT 153

B-C035-UP-DOWN-SPOT-AB 154

B-C035-UP-DOWN-SPOT-SS 154

B-C044 181

B-D002-TURBO 154

B-D003 154

B-D006 168

B-D007 168

B-D100-TURBO 184

B-D101-TURBO 184

B-D102-TURBO 184

B-D103-TURBO 184

B-MB 181

BP110, BP115

BP50, BP52-SQ, BP75

82

82

BP80E 82

BRASS-STAKE 184

B-ROD-30 181

CA60010 187

CA60020 187

CAN-ACOUSTIC 55

CLAMP1 55

DASH 20

E105SPARKIE 201

E150SPARKIE 201

E3-350MA-12W-QC-ST 196

E3-350MA-18W-QC-ST 197

204

E3-350MA-3W 196

E3-350MA-3W-MINI 196

E3-350MA-4W 196

E3-350MA-6W 196

E5-12VDC-100W-WP 200

E5-12VDC-10W 199

E5-12VDC-12W 199

E5-12VDC-12W-T 199

E5-12VDC-150W-WP 200

E5-12VDC-16W-WP 200

E5-12VDC-24W 199

E5-12VDC-4.2W 198

E5-12VDC-60W 199

E5-12VDC-6W 198

E5-12VDC-8-4W 198

E5-12VDC-90W 199

E5-24VDC-120W 199

E5-24VDC-12W 199

E5-24VDC-150W-WP 200

E5-24VDC-16W-WP 200

E5-24VDC-20W 199

E5-24VDC-24W 199

E5-24VDC-3W 199

E5-24VDC-60W 199

E60POD 201

E60RND 201

E61RND 201

E70GENIE 201

E7-700MA-18W-QC-ST 197

E7-700MA-3W 197

E7-700MA-6W-ST 197

E7-700mA-9W 197

E9-12VDC-8W-ST 198

E9-350MA-12W-ST 197

E9-350MA-18W-ST 197

E9-700MA-10W-ST 197

E9-700MA-18W-ST 197

ECO-DASH 21

ECO-FLASH 21

EW105BURIAL 202

EW60BURIAL 202

EX2000 186

EX3083 163

EX3092 162

EX3-DS 111

EX4082 163

EX4083 163

EX420 160

EX421 161

EX425P 161

EX427C 161

EX427P 161

EX4-DS 111

EX9100 162

EX9101 162

EXC1081 186

EXC8100B 162

Gentech Lighting

EXT-1000 93

EXT-2000 93

EXT4-606 101

EXT4-607 101

EXT4-608

EXT4-J-683 100

EXT4-J-684 100

EXT4-700MA-D-11W-ADP

EXT4-700MA-D-16W-ADP

107

107

EXT4-811S 101

EXT4-9241 101

EXT4-9571 101

EXT4-9575 101

EXT4-9576N 101

EXT4-9601 100

EXT4-ADAPTOR 107

EXT4B-1M 102

EXT4B-2M 102

EXT4B-3M 102

EXT4B-4M 102

EXT4B-BJ 103

EXT4B-EJ 103

EXT4B-End 103

EXT4B-FJ 103

EXT4B-IJ 102

EXT4B-L 102

EXT4B-ROD-SUSP 104

EXT4B-SUSP-CLIPLOCK 104

EXT4B-SUSP-KIT 104

EXT4B-TJ 103

EXT4B-XJ 103

EXT4C-2M 105

EXT4C-3M 105

EXT4C-BJ 105

EXT4C-EJ 105

EXT4C-L 105

EXT4C-MB 105

EXT4-GU280 100

EXT4-GU295 100

EXT4-GU296C 100

EXT4-GU304 100

EXT4-LED-326 97

EXT4-LED-327 96

EXT4-LED-328 97

EXT4-LED-333 96

EXT4-LED-334 96

EXT4-LED-700MA-864 98

EXT4-LED-700MA-D-804 97

EXT4-LED-700MA-D-859 97

EXT4-LED-700MA-D-861 97

EXT4-LED-700MA-D-863 97

EXT4-LED-871 98

EXT4-LV-296B 99

EXT4-LV-804 99

EXT4-LV-853 99

EXT4-LV-855 99

EXT4-LV-859 99

EXT4-LV-861 99

EXT4-LV-863 99

EXT4-LV-864 99

EXT4-LV-865 99

EXT4-LV-867 99

EXT4-LV-871 99

EXT4-LV-875 99

EXT4-LV-ADAPTOR 106

EXT4-M-ADAPTOR 106

EXT-600 93

EXT-J-683 93

EXT-HD-J-684 93

EXT-700MA-11W-ADP 95

EXT-700MA-D-16W-ADP 95

EXT-811 93

EXT-9571 92

EXT-9575 92

EXT-9576N 92

EXT-ADAPTOR 95

EXT-ADAPTOR-HD 95

EXT-BJ 94

EXT-D 94

EXT-E01 95

EXT-EJ 94

EXT-FJ 94

EXT-FL-GU280 92

EXT-FL-GU304 91

EXT-GU280 92

EXT-GU295 91

EXT-GU296C 91

EXT-GU304 91

EXT-HD-606 93

EXT-HD-607 93

EXT-HD-9601 92

EXT-HD-GU280 92

EXT-HD-LED-326 89

EXT-J 94

EXT-L 94

EXT-LED-12VDC-296B 88

EXT-LED-328 89

EXT-LED-700MA-296B 88

EXT-LED-700MA-864 89

EXT-LED-700MA-D-804 88

EXT-LED-700MA-D-859 88

EXT-LED-700MA-D-861 88

EXT-LED-700MA-D-863 88

EXT-LED-871 90

EXT-LV-296B 90

EXT-LV-804 90

EXT-LV-853 91

EXT-LV-855 91

EXT-LV-859 91

EXT-LV-861 90

EXT-LV-863 90

EXT-LV-864 90

EXT-LV-865 90

EXT-LV-867 90

EXT-LV-871 91

EXT-LV-875 91

EXT-LV-877 91

EXTR-001-SM 70

EXTR-001-SM-CLIP 71

EXTR-001-SM-EC 71

EXTR-002-DPR 71

EXTR-003-LPR 70

EXTR-004-CNR 70

EXTR-004-CNR-CLIP 71

EXTR-004-CNR-EC 71

EXT-T3A 95

EXT-TJ 94

EXT-WIRE-S-N 94

EXT-XJ 94

F0113 156

F0123 156

F08215 185

F08230 185

F101GLS-DOME-CLR 158

F101GLS-DOME-FRS 158

F101GLS-DOME-RIB 158

F101GLS-FLUSH-FRS 179

F101GLS-FLUSH-RIB 179

F101-GRATE 158, 179

F101-GYRO 158, 179

F101HOUSING 179

F101-LENEZ 158, 179

F101-RING 158, 179

F101RPM 179

F101SASH 158, 179

F101SPM 179

F101UBRACKET 179

F101-W 158

F101-W Example Kits 158

F101-WINK 158, 179

F201N 155

F202N 155

F203N 156

F204N 156

F205L 169

F205-R 169

F206-G9 159

F206-LV 155

F207-G9 159

F207-LV 155

F208 160

F209-G9 160

F209-LV 154

F211N-316 159

F212N-316 159

F216E 161

F216E-LED 153

F216E-LV 157

F216P 161

F216P-LED 153

F216P-LV 157

Gentech Lighting

INDEX

F2501 185

F404-LED 165

F405-LED 165

F4501 185

F5000BKT 180

F5010 177

F5050 177

F5050-PRE-MOUNT 177

F5060 178

F5060-PRE-MOUNT 178

F5062 178

F5062-PRE-MOUNT 179

F5064 175

F5065 169

F5066-RND-LED 175

F5066-SQ-LED 176

F5067-RND-LED 176

F5067-SQ-LED 176

F5100 180

F5501 185

F7030N-BK 182

F7060N-316-HEAD 182

F7060-ROD-400 182

F712 170

F713 170

F7150 183

F7160 183

F71X-PRE-MOUNT 170

F721 177

F721 169

FL010-LED 172

FL020-LED 172

FL030-LED 172

FL050-LED 173

FL080-LED 173

FLASH-WH 20

G103NR 43

G104P 44

G105 43

G106P 44

G107G 44

G118P 45

G119PC 44

G121 46

G123N 46

G125 46

G126P 45

G129 46

G132 47

G135 47

G136 47

G137 47

G138 49

G140 49

G141-150W 52

G141-70W 52

G142 48

205

INDEX

G145 48

G146-WH 48

G146-WH-AGR 48

G2003 186

G2005 186

G2082 163

G2083 163

G2084 163

G218PG 45

G226PG 45

G2520 109

G2525 110

G2531 110

G296B-LV 74

G3011 17

G3012 18

G3013 18

G3111 16

G3112 16

G3113 16

G3114 16

G3121 50

G3122 50

G3123 50

G3131 17

G3132 17

G3133 17

G3152 19

G3161 18

G3162 18

G3163 19

G3164 19

G3171 38

G3172 38

G3173 38

G3182 20

G3191-ALU 38

G3192-ALU 39

G321-LED-350MA 175

G370-LED 113

G371-LED 114

G424-LED 129

G426-LED-HG 130

G428-LED 130

G429-LED 130

G430-LED 131

G431-LED 131

G432-LED 131

G51O 187

G51S 187

G52O 187

G52S 187

G53-BASKET 187

G53O 187

G53S 187

G606 81

G607 81

206

G608 81

G628-JACK 142

G628-JACK-GU 147

G632 31

G-J-683 80

G-J-684 80

G701-FACE-SS 171

G701-IPM 170

G702-IPM 171

G702N-FACE-SS 171

G703-IPM 171

G705C 164

G706C 164

G706E 164

G706L 164

G706P 164

G707C 164

G707E 164

G707P 164

G708C 164

G708E 164

G708L 164

G708P 164

G709C 162

G7147 111

G730 39

G740-22W 110

G740-32W 10

G741-22W 111

G741-32W 111

G745N 31

G752 30

G7521 29

G7523 29

G753 19

G7535 35

G7536 35

G7541N 34

G7542N 34

G7543N 34

G7544N 34

G755 21

G7557 49

G756 21

G7560 109

G7561 109

G757 22

G758-CAN 22

G759 22

G764 23

G764S 23

G765 23

G765S 24

G770N 24

G770N-CAN-GLS 24

G771N 24

G771N-CAN-GLS 25

Gentech Lighting

G774R 23

G774S 22

G775-SL-ANTWH 25

G776-SL-GLS-ANTWH 25

G778 25

G781 37

G800N-D 53

G800N-G 54

G800N-LED-10W-WW 13

G801-D-316-SS 53

G801N-D 53

G801N-G 53

G801N-LED-10W-WW 13

G802-G-WH 54

G802-LED-10W-WW 13

G803-G-WH 54

G804 74

G805 115

G806 33

G808 33

G811S 81

G820 35

G821 36

G821-LED-700MA 15

G822MR 26

G822MS 26

G822R 27

G822S 27

G823R 27

G823S 28

G825 32

G826R 28

G826S 28

G827 32

G828 32

G833 26

G835N 26

G836 31

G838 31

G839 32

G840N 121

G840N-L 121

G840N-LED 120

G841-LED 120

G841N 122

G843C 122

G843L 122

G843P 122

G843P-LED 121

G843S 123

G845-LED 119

G847 60

G847-LED 59

G851 36

G852 36

G853 75

G855 75

G859 75

G861 75

G861-IT-WH 86

G861-SLAB2-SC 84

G861-SLAB3-BB 85

G861-SLAB3-WH 85

G861-T11-SI 86

G863 76

G863-IT-BK 86

G863-SLAB2-WH 84

G863-SLAB3-WH 85

G863-T11-BK 86

G864 76

G864-IT-BB 86

G864-IT-WH 86

G864-SLAB3-SI 85

G864-T11-CH 86

G865 76

G865-SLAB2-WH 84

G867 76

G867-SLAB2-CH 84

G867-T11-WH 86

G871 77

G872 77

G873 78

G876 77

G876-JACK 142, 147

G877 77

G877-JACK 142, 147

G878 77

G878-JACK 147

G881 35

G883 36

G885 37

G888 30

G888C 30

G891N 37

G892 30

G895 29

G896 29

G898 33

G899 33

G901-LED-RE 118

G901-LED-SM 126

G905-LED-RE 118

G906-LED-RE 119

G92150C 50

G9241 79

G9270C 50

G94150 51

G9435-LED 7

G9470 51

G9571 79

G9575 80

G9576N 80

G9601 79

G96150 51

G9670 51

G9881 51

G9882 51

G9883 52

G9886 52

GHX-7S 60

GHX-9S 60

G-LED-326 72

G-LED-327 73

GU280 78

GU295 78

GU296C 78

GU304N 79

GU3111 39

GU3112 39

GU3113 40

GU622R 40

GU622S 40

GU632 42

GU635 42

GU635L 43

GU640 43

GU-7521 41

GU-7523 41

GU759 40

GU810 132

GU836 41

GU838 42

GU892 42

GW033 123

GW034 123

GW035 124

GW036 123

GW037 124

GW047 132

GW049 133

GW056 133

GW056-LED 128

GW061 133

GW062 160

GW068 173

GW069 174

LED101 14

LED102 14

LED103 13

LED108 10

LED109 10

LED112 10

LED124 12

LED128 12

LED-133 57

LED-134-R 8

LED-136 57

LED-137-R 8

LED-138-S 8

LED-139-R 9

LED-140-R 9

Gentech Lighting

INDEX

LED-141-R 9

LED-1M-350MA-TERM-2-1 195

LED-1M-350MA-TERM-3-1 195

LED-1M-350MA-TERM-6-1 195

LED-1M-700MA-TERM-2-1 195

LED-1M-700MA-TERM-3-1 195

LED-1M-700MA-TERM-6-1 195

LED-301-1W 56

LED-301-3W 56

LED-301-SM-3W 57

LED302 58

LED303 58

LED304 14, 58

LED-305 11

LED-306 11

LED-307 11

LED-308 12

LED310 174

LED-310-350MA 174

LED311 174

LED-311-350MA 174

LED313

LED-313-350MA

LED314

166

166

166

LED-314-350MA 166

LED315 166

LED316 167

LED317 167

LED318 167

LED-320-R 117

LED-320-SQ 117

LED-322-R 126

LED323 127

LED325 124

LED325R-ALU 125

LED325R-BK 125

LED325R-BR 125

LED325R-WH 126

LED-330-R 117

LED-330-SQ 118

LED331 113

LED332 113

LED335

LED336

15, 59

15, 59

LED338 15

LED-341 167

LED-342 168

LED-360 6

LED-361 6

LED-361N 6

LED-362 7

LED-363 7

LED401 129

LED402 129

LED415 128

LED416 129

LED421 73

207

INDEX

LED422 73

LED423 74

LED500 152

LED501 152

LED502 152

LED503 186

LED504 72, 152

LED511 127

LED512 127

LED513 128

LED514 128

LED-5STAR-S 114

LED-AR111-14W 192

LED-AR111-16W 192

LED-BI-PIN-0.2W 191

LED-BI-PIN-0.5W 191

LED-BI-PIN-1.4W 191

LED-BI-PIN-1.5W-24 191

LED-BI-PIN-1.8W-13C 191

LED-BI-PIN-18C 191

LED-BI-PIN-1H 191

LED-BI-PIN-1W 191

LED-BI-PIN-1W-4C 191

LED-BI-PIN-2W-12C 191

LED-BI-PIN-3.2W-24 191

LED-BI-PIN-3W-45 191

LED-CONNECTOR-2P-TAIL 67

LED-CONNECTOR-4P-TAIL 67

LED-FR-ES-3W 194

LED-GLS-BC-9W 194

LED-GLS-ES-9W 194

LED-GU10-5W 193

LED-GU10-5W-SHARP 193

LED-GU10-7W-D 193

LED-GU10-8W-HP 193

LED-GU10-DE3 193

LED-GU10-D-KE-6W 193

LED-GU10-ECO-7W 193

LED-GW033 119

LED-IRC160 68

LED-IRC-160 189

LED-MR16-5W 189

LED-MR16-5W-SHARP 189

LED-MR16-7W 189

LED-MR16-8W-D-HP 189

LED-MR16-CONVERTER 53

LED-MR16-DE3 189

LED-MR16-KE-5W-D 189

LED-MR16-RGB 189

LED-PANEL-18W 120

LED-PAR20-ES-8W 194

LED-PAR30-ES-14W 194

LED-PAR38-18W-IP65 194

LED-PAR38-20W 194

LED-PL1200X300 61

LED-PL600X600 61

LED-REMOTE-DIMMER 69

LED-RULE 114

LED-RULE-EC 115

LED-RULE-FJ 115

LED-RULE-LE 115

LED-SN-24-RGB-AMP 69

LED-SN-2P-12V 66

LED-SN-2P-24V 66

LED-SN-2P-CHANNEL 68

LED-SN-2P-CONNECTOR-L 68

LED-SN-2P-CONNECTOR-TI 67

LED-SN-2P-CONNECTOR-TL 68

LED-SN-2P-LINEAR-ENDCAP 67

LED-SN-2P-LINEAR-PROFILE 68

LED-SN-2P-STAIR-NOSE 68

LED-SN-4P-24V-RGB 66

LED-TORCH-FLEXI 74

LED-TW-12-RGB-AMP 68

LED-TW-12V-5W 64

LED-TW-PR-12V 64

LED-TW-PR-12V-RGB 64

LED-TW-PR-24V 64

LED-TW-PR-24V-RGB 65

LED-TW-SN-12-24-RGB-CON 69

LED-TW-SN-CONNECT-1F-2M 67

LED-TW-SN-CONNECT-1F-3M 67

LGX53 LAMP OPTIONS 109

LSCABLE 187

LVHW-050 202

LVHW-100 202

LVHW-200 202

LVHW-300 202

LVWP-020 203

LVWP-050 203

LVWP-100 203

LVWP-150 203

LVWP-200 203

LVWP-300 203

LVWP-400 203

Mix and Match Three Light Slab Rail 85

Mix and Match Two Light Slab Rail 84

PA12 83

PA12GZ10-KIT 54

PA-322R-SLEEVE 127

PA43 83

PA45 83

PA46 83

PA8 83

PA8HOLDER 83

PA-ROD 82

PGS1 134

PGS12 136

PGS14 136

PGS6 136

PGS9 136

PMS1 137

PMS11 138

PMS12 138

PMS2 137

PMS5 138

PMS7-LED 137

PSCD1 139

T11 82

TM12A 202

TM20A 202

TW-001 141

TW-001A 141

TW-006 141

TW-008 141

TW-011A 141

TW-012A 142

TW-028 142

TW-BARNDOOR 145

TW-CABLE-4P 143

TW-CABLE-6 143

TW-CABLE-6P 143

TW-E01N 142

TW-GO

TW-GS

147

147

TW-LL 145

TW-P010 145

TW-P010C 145

TW-P01-6 143

TW-P01-6S 143

TW-P02-A 143

TW-P02-S 143

TW-P03 143

TW-P03B 143

TW-P03BS 144

TW-P04 144

TW-P07 144

TW-P07C 144

TW-P08 144

TW-P09 144

TW-P09C 144

TW-P98 144

TW-P99 144

W-107 132

W-CT01 139

W-CT01D 139

W-CT200 139, 142, 147

W-CY230 138

W-G32 135

W-G56 135

W-GUL 135

W-MH1 137

W-PT399 134, 142

W-PT450 135

208

Gentech Lighting

Gentech Lighting

37 Miles Street, Mulgrave, Victoria 3170, Australia

Ph +613 9561 5688 Fax +613 9561 5666 [email protected]

www.gentechlighting.com.au

Gentech

Lighting

2014

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
