SRN-873S
Preliminary version
SRN-873S
8CH Network Video Recorder with PoE Switch
SRN-873S
Display
Video
Live
Inputs / Resolution
Protocols
Local Display
Multi Screen Display
Performance
Performance
Operating System Embedded
Compression
Recording Bandwidth
Resolution
Mode
Recording
Search &
Playback
Storage
Back up
Key Features
Sensor
Audio
• Up to 8CH 8M supported
• 64Mbps network camera recording
• Plug & play by 8 PoE/PoE+ ports
• Max. 2HDDs, e-SATA storage supported
• HDMI / VGA local monitor
Network
Linux
H.264, MJPEG
64Mbps, 2M 8 camera real-time recording
CIF ~ 8M
Normal, Scheduled, Event (Pre / Post)
Alarm input (4), Video loss, Camera event (Alarm in, MD, Video analytics)
Event Trigger
VA event [Tampering, Enter/Exit, Passing (Virtual line, (Dis)Appear,
Face detection, Audio detection)]
Event Action
E-mail, PTZ preset, Alarm out, Buzzer, Monitor out
Playback Bandwidth
32Mbps (Max. 3 users)
Performance
Max. 32Mbps (TBD)
Mode
Date & Time (Calendar) / Event log list / Text Search (POS)
Simultaneous Playback [Local monitor] Up to 8CH, [Web, CMS] Up to 8CH
Resolution
CIF ~ 8M
Fish-eye Dewarping
Via Smartviewer
Playback Control
Fast forward / backward, Move one step up / down
Default Built-in
2TB
Internal
2 SATA (Fixed)
External (DAS)
1 e-SATA
Max.Capacity
Internal (8TB = 2 x 4TB)
File Back up
[USB] : BU/Exe, [Web, CMS] : JPEG, AVI
Function
Max. 8CH play, Date-time/title display
Input / Output
4 / 3 (NO 2ea, NO/NC 1ea)
Input / Compression
8CH (Network) / G.711, G.726, AAC (16/48KHz)
Audio Communication 2-way
Protocol Support
DDNS
Transmission Bandwidth
Max. Remote Users
IP
Security
Language
GUI / Web
OS
Web Browser
Dimensions
Unit : mm (inch)
Viewer
Software
Functions
Camera Setup
Type
CMS Support
Register
Setup Items
320.0
(12.6")
320.0
(12.6")
327.7
(12.9")
327.7
(12.9")
Camera Control PoE
Easy Configuration
PTZ
Control / Preset
OS
Smart phone
Control
System Control
Indicator / Interface
Front
370.0(14.57")
(14.57")
370.0
44.0 (1.73")
(1.73")
44.0
50.7 (2")
50.7
(2")
Connections
System
Log
General
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client),
PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S)
Samsung iPOLiS DDNS
Max. 128Mbps (TBD)
Search 3 / Live unicast 10 / Live multicast 20
IPv4 / IPv6
IP address filtering, User access log, 802.1x authentication,
Encryption (ID/PW, Recording, Transmission, Back up)
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch,
Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian,
Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai (GUI)
Supported OS : Window XP (Service pack 2 or above), Vista, 7, 8,
Mac OS X (10.7 or above)
Microsoft Internet Explorer (Ver. 8 ~ 10),
Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25),
Apple Safari (Ver. 6.0.2(Mac OS X 10.8, 10.7 only), 5.1.7)
SSM, Webviewer, SmartViewer, iPOLiS mobile viewer
SDK / CGI (SUNAPI)
PnP mode, Manual mode
1) IP address, Add profile edit, Bitrate, Compression, GOP, Quality
2) Camera event setup
- MD
- VA (Upgrade Aug. 2015) : Tampering, Enter/Exit, Passing (Virtual line),
(Dis)Appear, Face detection, Audio detection)
3) Video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS,
WDR, D&N, SSNR, Shutter, SSDR, DIS)
1) Monitor PoE power consumption 2) On/Off control for each PoE camera
3) Remote reset for each PoE camera
Setup Wizard (Date/Time, Network, Auto camera configuration)
Via GUI, Webviewer, SPC-2000 / 255
Android, iOS
Live (4CH) : (4 DIV) CIF monitoring, (4/1 DIV) 1.3M monitoring
Playback (1CH) : Up to 1.3M
Mouse, IR Remocon, Web, SPC-2000 (USB controller)
Alarm
Reset / Power Cord
Power status LED 1ea, HDD action LED 1ea, Alarm status LED 1ea
Record status LED 1ea, Network action LED 1ea, Back up LED 1ea
2ea (Front 2ea)
1ea / 1ea
Out 1ea (RCA, Line)
8ea (PoE, 100Mbps) - 4 hPoE when 2 PoE ports aggregated to 1 port
- Each PoE port can be used as downlink port for camera / PoE Hub
1ea (LAN/WAN, 1Gbps) - LAN : Downlink to camera / PoE Hub
- WAN : Uplink to CMS
In 4ea (Terminal block) / Out 3ea (Terminal block)
Yes (Factory reset) / Included
Log List
Max. 20000 (System log, Event log each)
Indicator
USB
HDMI / VGA
Audio
Ethernet
Input Voltage / Current
Power Consumption
Operating Temperature
Environmental
Operating Humidity
Color / Material
Mechanical
Dimensions (WxHxD)
Weight (Without HDD)
IR Remocon / Mouse
Accessories
Viewer CD / IB
Power Cord / Terminal Block
Electrical
Up to 8CH / CIF ~ 8M
Samsung, ONVIF
HDMI / VGA
[Local monitor] 1 / 4 / 6 / 8 / Auto sequence, [Web] 1 / 4 / 8 / Auto sequence
[Local monitor] 8M (30fps), 5M (60fps), 3M (90fps), 2M (120fps),
720p (240fps), D1 (240fps)
[Web] 5M (30fps), 3M (60fps), 2M (120fps), 720p (240fps), D1 (240fps) (TBD)
100 ~ 240V AC
Set : (TBD)W (NVR w/ 1x HDD), PSE : Total 100W (Average 12.5W per each PoE port)
+0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 85% RH
Black / Metal
370.0 x 44.0 x 320.0mm (14.57" x 1.73" x 12.6") (1U)
TBD
Included / Included
Backup Viewer, Installation Manual / Included
Included / Included
* The latest product information / specification can be found at www.samsungsecurity.com
Preliminary
