The Eco mark represents Samsung Techwin’s will to create environment-friendly products,
and indicates that the product satisfies the EU RoHS Directive.
Design and specifications are subject to change without notice.
DISTRIBUTED BY
SAMSUNG TECHWIN CO., LTD.
701, Sampyeong-dong, Bundang-gu, Seongnam-si, Gyeonggi-do Korea 463-400
Tel : +82-70-7147-8741~8749, 8752~8760 Fax : +82-31-8018-3745
www.samsungipolis.com www.samsungsecurity.com
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : +1-877-213-1222 Direct : +1-201-325-6920
Fax : +1-201-373-0124
www.samsungcctvusa.com
SAMSUNG TECHWIN EUROPE LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business Park
Chertsey, Surrey, UNITED KINGDOM KT16 OPS
Tel : +44-1932-45-5300 Fax : +44-1932-45-5325
TIANJIN SAMSUNG TECHWIN OPTO-ELECTRONICS CO., LTD.
No.11 Wei 6 Street. Micro-Electronic Industrial Park
Jingang Road, Tianjin, P.R. CHINA 300385
Tel : +86-22-23887788 Fax : +86-22-23887788
I.E-1108
Time for HD
Samsung 1.3M HD Network Camera
MEGA DSP
• Max. 1.3 Megapixel resolution support
• 16 : 9 HD (720p) resolution
• SSDR (Samsung Super Dynamic Range)
• SSNRIII (Samsung Super 3D+2D Noise Reduction)
• HLC (Highlight Compensation)
• Intelligent Video Analytics
1.3 Mega Pixel, Various Resolution Support
The Samsung HD Network Camera Series is capable of generating images at multiple resolutions, from CIF to 16 : 9 HD
and 1.3 megapixels. At the 16 : 9 HD or 1.3 megapixels resolution, images look much bigger, wider, and clearer than at
lower resolutions. Besides, a variety of resolutions are available—CIF 320 x 240, VGA 640 x 480, SVGA 800 x 600, and
more—to help create the optimum network environment.
CIF 320 x 240
VGA 640 x 480
SVGA 800 x 600
16 : 9 HD 1280 x 720
1.3M 1280 x 1024
Low Light Image Sensor
Samsung HD Megapixel Network Cameras are equipped with
the latest CMOS image sensor that achieves clearer images
than a normal megapixel CCD especially under low light
conditions.
Conventional 1.3M megapixels CCD
Network Camera
1.3M megapixels CMOS
Samsung HD Network Camera
Multiple Codec & Multiple Streaming
Multiple codec (H.264, MPEG-4 and MJPEG) can be
transmitted simultaneously, enabling multiple
purposes such as real time monitoring, high quality
or high efficiency recording, mobile monitoring,
Resolution
(Selectable)
Streaming
(Selectable)
Frame Rate
(Selectable)
Monitoring/Recording
(Selectable)
1280 x 720
H.264
10fps
Recording / Back up
800 x 600
MPEG-4
30fps
E-mail notification, and SD memory recording.
Monitoring / Control
320 x 240
MPEG-4
5fps
1280 x 1024
MJPEG
Snapshot
640 x 480 H.264 5fps
Monitoring on Smartphone
SD memory Recording
E-mail Notification
Intelligent Video Analytics
The intelligent video analytics feature included in WiseNet DSP enables more accurate video monitoring.
1) Disappearing Detection
Defined Area
Alarm
It activates an alarm immediately when an object
disappears from a defined monitoring area.
Disappearing Detection
2) Appearing Detection
Entire Area
It activates an alarm if a new object merges and
stays in a defined monitoring area longer than
a set duration.
Appearing Detection
3) Crossing Line Detection
Virtual Line
It activates an alarm when an intruder comes into a virtual
boundary line on the monitor.
Alarm
Defined Area
Alarm
4) Enter / Exit Detection
It activates an alarm when an object enters or leaves
a defined monitoring area.
Crossing Line Detection
Enter/Exit Detection
Control via Centralized
Management Software (CMS)
NET-I viewer is Samsung Techwin's centralized network management
software that are capable of managing a maximum of 32 channels. This
software provides PTZ control commands, various event types and map
monitoring options for a convenient and effective monitoring system.
* NET-i viewer : 16 channels per a monitor. Able to monitor 32 channels via dual monitor
Net-i viewer Live
Net-i viewer Map
SNB-5000
1.3Megapixel HD Network Camera
Technical Specifications
SNB-5000N/P
Video
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
Lens
Lens Type
Mount Type
Operational
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Network
Ethernet
Video Compression Format
Resolution
Product Design : 85%
Features and Functions : 85%
Ease of Installation : 80%
IVA Performance : 85%
Video Performance : 87%
Overall Rating : 84%
1.3M
PoE
D&N ICR
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
Max. Framerate
• H.264, MPEG-4, MJPEG multiple codec
Video Quality Adjustment
• PoE, SD memory, bi-directional audio support
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
Protocol
Unit : mm (inch)
Dimensions
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
AUDIO OUT AUDIO IN
SD CARD
SD SYSTEM POWER
VIDEO
Webpage Language
RESET
1 2 3 4 5
ACT
LINK
GND
Web Viewer
AC 24V
DC 12V
60.0 (2.36")
1,2 : ALARM IN 1,2
3 : GND
4,5 : ALARM OUT 1,2
NETWORK
72.0 (2.83")
136.8 (5.39")
Central Management Software
Environmental
Operating Temperature / Humidity
Electrical
Input Voltage / Current
Power Consumption
Mechanical
Color / Material
Dimensions (WxHxD)
Weight
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
Manual / DC auto iris
C / CS
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNRIII (2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR, CVBR, MJPEG : CVBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 6W
Dark gray / Metal
72.0 x 60.0 x 136.8mm (2.83" x 2.36" x 5.39")
440g (0.97 Ib)
SNV-5080
1.3Megapixel HD Vandal-Resistant Network Dome Camera
Technical Specifications
SNV-5080N/P
Video
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
1.3M
PoE
3.6x
V/F Lens
D&N ICR
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 2.8 ~ 10mm (3.6x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• PoE, SD memory, IP66, bi-directional audio support
Unit : mm (inch)
Ø160.0 (6.3")
Ø160.0 (6.3")
Max. Framerate
Video Quality Adjustment
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
134.5
134.5
(5.3")
(5.3")
Dimensions
S / N Ratio
Video Output
Lens
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
Pan / Tilt / Rotate
Pan Range
Tilt Range
Rotate Range
Operational
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Network
Ethernet
Video Compression Format
Resolution
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
125.0
125.0
(4.92")
(4.92")
Ø160.0 (6.3")
Ø160.0 (6.3")
Flush Type
Webpage Language
Web Viewer
Central Management Software
Environmental
Operating Temperature / Humidity
Ingress Protection
Electrical
Input Voltage / Current
Power Consumption
Mechanical
Color / Material
Dimensions (WxH)
Weight
Accessories (Optional)
SCX-300WM
SCX-300CM SCX-300HM1
SCX-300LM
SCX-300PM SCX-300KM
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
2.8 ~ 10mm (3.6x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNRIII (2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR, CVBR, MJPEG : CVBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
NET-i viewer
-40°C ~ +50°C (-40°F ~ +122°F) / Less than 90% RH
IP66 Grade (Waterproof)
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 8W (Heater off), Max. 11W (Heater on)
Light gray / Aluminum
Ø160.0 x 134.5mm (Ø6.3" x 5.3")
1.28Kg (2.82 lb)
SND-5080/5080F
1.3Megapixel HD Network Dome Camera
Technical Specifications
SND-5080(F)N/P
Video
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
SND-5080
1.3M
SND-5080F
PoE
3.6x
D&N ICR
V/F Lens
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 2.8 ~ 10mm (3.6x) varifocal lens
• H.264, MPEG-4, MJPEG multiple codec
• PoE, SD memory, bi-directional audio support
Max. Framerate
Video Quality Adjustment
Unit : mm (inch)
Dimensions
S / N Ratio
Video Output
Lens
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
Pan / Tilt / Rotate
Pan Range
Tilt Range
Rotate Range
Operational
Camera Title
Day & Night
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Alarm I/O
Network
Ethernet
Video Compression Format
Resolution
Bitrate Control Method
Streaming Capability
Audio I/O
Audio Compression Format
Audio Communication
IP
129.4 (5.09")
Protocol
SND-5080
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Ø133.0 (5.24")
SND-5080F
125.0 (4.92")
Ø159.9 (6.3")
Central Management Software
Environmental
Operating Temperature / Humidity
Electrical
Input Voltage / Current
Power Consumption
Mechanical
Color / Material
Dimensions (WxH)
Weight
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.3Lux (F1.2, 50IRE), 0.005Lux (Sens-up 60x)
B/W : 0.01Lux (F1.2, 50IRE), 0.0002Lux (Sens-up 60x)
50dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
2.8 ~ 10mm (3.6x) varifocal
F1.2
H : 94.6°(Wide) ~ 28.8°(Tele), V : 68.4°(Wide) ~ 21.6°(Tele)
DC auto iris
Board-in type
0° ~ 355°
0° ~ 90°
0° ~ 355°
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W / External B/W
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNRIII (2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
Input 1ea / Output 1ea (Relay)
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
H.264, MPEG-4 : CBR, CVBR, MJPEG : CVBR
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
G.711 u-law
Bi-directional audio
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access logg, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
NET-i viewer
-10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
12V DC, 24V AC, PoE (IEEE802.3af)
Max. 7W
White / Plastic
SND-5080 : Ø133.0 x 129.4mm (Ø5.24" x 5.09")
SND-5080F : Ø159.9 x 125.0mm (Ø6.3" x 4.92") (Flush mounting type)
SND-5080 : 523g (1.15 lb), SND-5080F : 650g (1.43 lb)
SNV-5010
1.3Megapixel HD Vandal-Resistant Network Flat Camera
Technical Specifications
SNV-5010N/P
1.3M
3mm
Video
Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output
Lens
Focal Length (Zoom Ratio)
Max. Aperture Ratio
Angular Field of View
Lens Type
Mount Type
Pan / Tilt / Rotate
Pan Range
Tilt Range
Operational
Camera Title
Backlight Compensation
Contrast Enhancement
Digital Noise Reduction
Motion Detection
Privacy Masking
Sens-up (Frame Integration)
Gain Control
White Balance
Electronic Shutter Speed
Flip / Mirror
Intelligent Video Analytics
Network
Ethernet
Video Compression Format
Resolution
PoE
Key Features
• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• Built-in 3mm fixed lens
• H.264, MPEG-4, MJPEG multiple codec
• PoE, IP66
Unit : mm (inch)
115.2 (4.54")
Dimensions
125.2 (4.93")
52.0 (2.05")
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 1Lux (F1.8, 50IRE), 0.016Lux (Sens-up 60x)
50dB
DIP connector type, 704 x 480(N), 704 x 576(P), for installation
3mm
F1.8
H : 91.2°, V : 72.3°
Fixed iris
Board-in type
-10° ~ 10°
0° ~ 90°
Off / On (Displayed up to 15 characters)
Off / BLC / HLC
SSDR (Samsung Super Dynamic Range) (Off / On)
SSNRIII (2D+3D noise filter) (Off / On)
Off / On (4 programmable zones)
Off / On (12 programmable zones)
Off / Auto (2x ~ 60x)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Off / On
Scene change, Virtual line, Enter / Exit, Appear / Disappear
RJ-45 (10/100BASE-T)
H.264, MPEG-4, MJPEG
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
H.264, MJPEG : 30fps
Max. Framerate
MPEG-4 : 25fps (1280 x 1024), 30fps (720P HD)
H.264, MPEG-4 : Compression level, Target bitrate level control
Video Quality Adjustment
MJPEG : Quality level control
Bitrate Control Method H.264, MPEG-4 : CBR, CVBR, MJPEG : CVBR
Streaming Capability
Multiple streaming (Up to 10 profiles)
IP
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
Protocol
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
Security
IP address filtering, User access log, 802.1x authentication
Streaming Method
Unicast / Multicast
Max. User Access
10 users at unicast mode
ONVIF Conformance
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Webpage Language
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Web Viewer
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
Central Management Software NET-i viewer
Environmental
Operating Temperature / Humidity -10°C ~ +50°C (-14°F ~ +122°F) / Less than 90% RH
Ingress Protection
IP66 Grade (Waterproof)
Electrical
Input Voltage / Current 12V DC, PoE (IEEE802.3af)
Power Consumption
Max. 6W
Mechanical
Color / Material
Ivory / Aluminum
Dimensions (WxHxD) 125.2 x 52.0 x 115.2mm (4.93" x 2.05" x 4.54")
Weight
435g (0.96 lb)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
