Asus Consumer Product List
AUGUST 2012
Asus Consumer
Product List
August 2012
15’ Multimedia
17’ Multimedia
Professional
Ultra Portable
X54C-SX132V
K53U-SX297V
X53U-SX155V
X54C-SX323V
X54C-SX127V
X54C-SX294V
X54C-SX282V
X54C-SX318V
K53SD-SX1070V
K53SD-SX103V
K73E-TY213V
K73E-TY324V
K73E-TY210V
K73E-TY325V
B53E-SO123X
U36SG-RX107X
ZENBOOK
UX21E-KX004V
Lamborghini
VX7SX-S1126Z
15’
PERFORMANCE
Multimedia
17’
PERFORMANCE
Multimedia
N55SL-S2019V
N75SL-V2GTY071V
Gaming
G53SW-IX097Z
G53SX-IX122V
G75VW91121Z
ACCESSORIES
BAG / MOUSE
15’ Multimedia
Data Sheet - X54C
The Perfect Fit for Work and Play
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
Palm Proof Technology Prevents Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
Power4Gear with self-adjusting fan speeds
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment
X54C-SX132V
Processor
Intel® Celeron® B815 (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Battery
4 cell
Warranty
1 year global
Keyboard
Numeric
Card Reader
4 -in-1 card reader (SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~ 3.72 cm (WxDxH)
2.60 kg (with 4 cell battery)
Colour
Black (Matte)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53U
The Perfect Fit for Work and Play
Classy Design
Featuring the AMD Brazos Platform and an elegant colour
scheme, the new K Series offers an expressive combination
of technology and style. An elegant look along with ASUS’
extensive quality testing ensures that the K Series looks fantastic
even during prolonged use, allowing you to do more in complete
confidence.
Immersive Multimedia Experience
The ASUS K53U delivers an immersive multimedia experience
through its high definition LED panel and Altec Lansing®
speakers with SRS Premium Sound™. Your ASUS K53U can also
connect to HDMI-compatible TVs, consoles and entertainment
systems.
Palm Proof Technology Prevents
Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
K53U-SX297V
CPU
AMD® Fusion APU E-450 (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Panel
15.6” HD TFT (1366x768, Colour-Shine)
Graphics
AMD® Radeon® HD 6310
HDD
500GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Speaker
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
PC Card Slot
4 -in-1 card reader (SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X53U
The Perfect Fit for Work and Play
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning. Your
ASUS X Series notebooks can also connect to HDMI-compatible
TVs, consoles and entertainment systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
Go Faster
Now included is USB 3.0 for up to ten times the speed of USB
2.0, so all your files and content can be handled and backed up
expediently. Say goodbye to long frustrating waits, even a 25GB
Blu-ray movie takes a mere 70 seconds to process.
X53U-SX155V
Processor
AMD® Fusion APU E-450 (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” 16:9 HD (1366x768) LED Backlight
Graphic Card
AMD® Radeon® HD 6310
Storage
500GB (5400rpm)
Memory
4G (2048x2) DDR3 1066 MHz SDRAM
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000Mbps
Webcam
Yes
Battery Pack & Life
6 cell
Warranty
1 year global
Keyboard
Numeric
Card Reader
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Brown
Palm Proof Technology Prevents Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54C
The Perfect Fit for Work and Play
X54C-SX323V
Processor
Intel® Pentium® B940 (2.0GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
640GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Power4Gear with self-adjusting fan speeds
Battery Pack & Life
4 cell
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment.
Warranty
1 year global
Keyboard
Numeric
Palm Proof Technology Prevents Accidental Input
Card Reader
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning. Your
ASUS X Series notebooks can also connect to HDMI-compatible
TVs, consoles and entertainment systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54C
The Perfect Fit for Work and Play
X54C-SX127V
Processor
Intel® Pentium™ B960 (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Power4Gear with self-adjusting fan speeds
Battery Pack & Life
4 cell
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment.
Warranty
1 year global
Keyboard
Numeric
Palm Proof Technology Prevents Accidental Input
Card Reader
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers. Your ASUS X Series notebooks can also
connect to HDMI-compatible TVs, consoles and entertainment
systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54C
The Perfect Fit for Work and Play
X54C-SX294V
Processor
Intel® Core™ i3-2350M (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Power4Gear with self-adjusting fan speeds
Battery Pack & Life
4 cell
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment.
Warranty
1 year global
Keyboard
Numeric
Palm Proof Technology Prevents Accidental Input
Card Reader
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers. Your ASUS X Series notebooks can also
connect to HDMI-compatible TVs, consoles and entertainment
systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54C
The Perfect Fit for Work and Play
X54C-SX282V
Processor
Intel® Core™ i3-2350M (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
750GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Power4Gear with self-adjusting fan speeds
Battery Pack & Life
4 cell
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment.
Warranty
1 year global
Keyboard
Numeric
Palm Proof Technology Prevents Accidental Input
Card Reader
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning. Your
ASUS X Series notebooks can also connect to HDMI-compatible
TVs, consoles and entertainment systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54C
The Perfect Fit for Work and Play
X54C-SX318V
Processor
Intel® Core™ i3-2350M (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
750GB (7200rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Power4Gear with self-adjusting fan speeds
Battery Pack & Life
4 cell
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment.
Warranty
1 year global
Keyboard
Numeric
Palm Proof Technology Prevents Accidental Input
Card Reader
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~3.72 cm (WxDxH)
2.6 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning. Your
ASUS X Series notebooks can also connect to HDMI-compatible
TVs, consoles and entertainment systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53SD
The Perfect Fit for Work and Play
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant colour scheme based on premium aluminum textures, the
new K53 Series offers an expressive combination of technology
and style.
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you to
do more with your K53 Series in complete confidence.
K53SD-SX1070V
CPU
Intel ® Core™ i5-2450M (2.5GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Panel
15.6” HD TFT (1366x768, Colour-Shine)
Graphics
NVIDIA® GeForce® GT 610 - 2G DDR3
HDD
500GB (5400rpm)
IceCool Technology Keeps Your Hands Cool
Memory
6G (4096x1, 2048x1)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot components
on the underside and away from users. Combined with heat pipes
and vents, palm rests and typing surfaces stay cooler.
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader ( SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 ports
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Palm Proof Technology Prevents
Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53SD
The Perfect Fit for Work and Play
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant colour scheme based on premium aluminum textures, the
new K53 Series offers an expressive combination of technology
and style.
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you to
do more with your K53 Series in complete confidence.
K53SD-SX103V
CPU
Intel® Core™ i7-2670QM (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Panel
15.6” HD TFT (1366x768, Colour-Shine)
Graphics
NVIDIA® GeForce® GT 610 - 2G DDR3
HDD
500GB (5400rpm)
IceCool Technology Keeps Your Hands Cool
Memory
4G (2048x2)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot components
on the underside and away from users. Combined with heat pipes
and vents, palm rests and typing surfaces stay cooler.
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader ( SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for external monitor
3 x USB 2.0 ports
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Palm Proof Technology Prevents
Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
15’ Performance
Multimedia
Data Sheet - N55SL
Incredible in Sound
N55SL-S2019V
Fusing Classical and Post-Modern Design
Processor
Intel® Core™ i7-2670QM (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD+ TFT (1600x900, Colour-Shine)
Graphic Card
NVIDIA® GeForce® GT 635M - 2GB
DDR3 VRAM
Storage
750GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
Notebook Audio Elevated to New Levels
ODD
Blu-Ray Combo
Co-developed with Bang & Olufsen ICEpower®, ASUS
SonicMaster Technology brings an evolution of notebook design
with an exclusive combination of advanced hardware and
software to create an immersive audio experience. Improved
and refined for new N Series notebooks, it offers living audio
with the most precise processing protocols and codecs,
superior speaker construction and large resonance chambers
for unforgettable enjoyment – it’s like going to a concert, the
fidelity revitalises vocals and every sound comes to life through
professional enhancement. No more tinny notebook audio
and noise distortion – welcome to an era of true hi-fi on PC.
The bundled SonicMaster subwoofer adds superb deep note
performance for even better audio output.
Wireless
802.11 BGN (WIDI)
LAN
10/100/1000 Mbps
Webcam
HD Web Camera
Bluetooth
Yes
Battery
6 Cell
Warranty
1 year global
Keyboard
Numeric
Card Reader
3 -in-1 card reader (SD/ MS/MS Pro Duo/
MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And Microphone
Bang & Olufsen ICEpower®
SonicMaster
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.9 x 26.1 x 3.7 ~3.75 cm (WxDxH)
2.7 kg (with 6 cell battery)
Colour
Black (Piano Gloss)
Simple yet sleek design by David Lewis creates a unique
mood of sophisticated elegance and modernity, featuring
piano-gloss covers and polished metal frames. The new N
Series is also extremely user-focused, delivering comfortable
soft-feel touchpads, fast-type keys with reinforced springs, and
a smoothed-out integrated power button. Intelligent design
and meticulous craftsmanship combine to embody a spirit of
advanced computing and purely sensational simplicity.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
17’ Multimedia
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
K73E-TY213V
Processor
Intel Pentium® B950 (2.1GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
3G (2048x1, 1024x1)
Type
DDRIII 1066
IceCool Technology Keeps Your Hands Cool
Optical Drive
DVD Super Multi Dual Layer
IceCool Technology makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery
6 cell (5200mAh 56 Whrs)
Palm Proof Technology Prevents
Accidental Input
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Classy Metallic Design
The new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
IF Award-winning Ergonomic Chiclet Keyboard
Extra-wide dust-repellent keys stay comfortable even during
extended typing sessions for improved productivity and
interaction.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
The new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
IceCool Technology Keeps Your Hands Cool
IceCool Technology makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Palm Proof Technology Prevents
Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
IF Award-winning Ergonomic Chiclet Keyboard
Extra-wide dust-repellent keys stay comfortable even during
extended typing sessions for improved productivity and
interaction.
K73E-TY324V
Processor
Intel Pentium® B960 (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant colour scheme based on premium aluminum textures,
the new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
Incredible Processing Power
The new K73 Series ships with 2nd Generation Intel® Core™
Processors, as optimised for notebook use with awesome
computing power – in particular, these new mobile CPUs
enhance multitasking, so you can get more done at the same
time, more smoothly.
IceCool Technology Keeps Your Hands Cool
IceCool Technology makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
K73E-TY210V
Processor
Intel® Core™ i3-2330M (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant colour scheme based on premium aluminum textures,
the new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
Incredible Processing Power
The new K73 Series ships with 2nd Generation Intel® Core™
Processors, as optimised for notebook use with awesome
computing power – in particular, these new mobile CPUs
enhance multitasking, so you can get more done at the same
time, more smoothly.
IceCool Technology Keeps Your Hands Cool
IceCool Technology makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
K73E-TY325V
Processor
Intel® Core™ i3-2350M (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
17’ Performance
Multimedia
Data Sheet - ASUS N75SL
Incredible in Sound
N75SL-V2G-TY071V
Processor
Intel® Core™ i5-2450M (2.5GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
NVIDIA® GeForce® GT 6350M - 2G
DDR3 VRAM
Storage
500GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
Optical Drive
Blu-Ray Combo
Notebook Audio Elevated to New Levels
Wireless
802.11 BGN
Co-developed with Bang & Olufsen ICEpower®, ASUS
SonicMaster Technology brings an evolution of notebook design
with an exclusive combination of advanced hardware and
software to create an immersive audio experience. Improved
and refined for new N Series notebooks, it offers living audio
with the most precise processing protocols and codecs,
superior speaker construction and large resonance chambers
for unforgettable enjoyment – it’s like going to a concert, the
fidelity revitalises vocals and every sound comes to life through
professional enhancement. No more tinny notebook audio
and noise distortion – welcome to an era of true hi-fi on PC.
The bundled SonicMaster subwoofer adds superb deep note
performance for even better audio output.
LAN
10/100/1000 Mbps
Bluetooth
Yes
Webcam
Yes
Numeric Keypad
Yes
Battery
6 cell
Warranty
2 year global
Keyboard
Numeric Keypad
Card Reader
5 -in- 1 card reader (SD,MMC,MS,MSPro,XD)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (S/PDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 ports (optional)
2 x USB 2.0 ports
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x E-SATA (Combo with USB 2.0)
Audio
Built-in speaker and microphone
Bang & Olufsen ICEpower®
SonicFocus
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.7 x 3.67~4.05 cm (W x D x H)
3.40 kg (with 6 cell battery)
Colour
Black (Piano Gloss)
Fusing Classical and Post-Modern Design
Simple yet sleek design by David Lewis creates a unique
mood of sophisticated elegance and modernity, featuring
piano-gloss covers and polished metal frames. The new N
Series is also extremely user-focused, delivering comfortable
soft-feel touchpads, fast-type keys with reinforced springs, and
a smoothed-out integrated power button. Intelligent design
and meticulous craftsmanship combine to embody a spirit of
advanced computing and purely sensational simplicity.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Professional
Data Sheet - ASUS B53E
Pro Notebooks for Business Pros
Top Quality Commercial Notebooks
ASUSPRO B Series notebooks are all strictly quality tested to
surpass industry standards, surviving drop tests, hinge test
cycles and panel pressure testing.
Smart card access, fingerprint readers
and optional TPM
Strict gatekeeping and privacy controls to guarantee only
authorised users have access to important files.
ASUS Secure Delete - permanently erases
sensitive data
An easy-to-use interface that allows you to permanently remove
confidential data from the recycle bin. Simply launch Secure
Delete and drag and drop the files to be deleted.
ASUS Power Station II
Uncompromising, expansive connectivity through a detachable
docking station that allows for the quick connection of
peripherals, communication devices, and power cables.
B53E-SO123X
Processor
Intel® Core™ i5-2430M (2.4GHz)
OS
Genuine Windows® 7 Professional 64bit
Display
15.6” HD TFT (1366x768, Colour-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Finger Print
Yes
Security
TPM
Battery
8 cell
Warranty
1 year global
Keyboard
Numeric
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps
Card Reader
5 -in- 1 card reader (SD, MMC, MS,
MS-Pro, XD)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x E-SATA (USB2.0 Combo) Ports
1 x RJ11 Modem jack for phone line
1 x Express card
1 x Display Port
1 x Fingerprint
LED Status Indicator
Numeric KB Lock
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Audio
Built-in speaker and microphone
Altec Lansing® speakers
Dimension & weight
38.4 x 26.3 x 3.30 ~ 3.50 cm (W x D x H)
2.69 kg
Colour
Black (Matte)
spill proof
keyboard*
docking station
optional
*Spill proof Repels Up to 120cc of Liquid
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - B53E Docking Station
ASUS Power Station II Uncompromised,
expansive connectivity
The detachable docking station allows for the quick
connection of peripherals, communication devices,
and power cables.
ASUS Xpress Charge - quick charges to 90% capacity
in just 90 minutes. Detachable docking station,
and multitask on up to three displays
Docking Power Station II
90-N0LDK1003Y:
Device Compatibility
B53E Notebook only
Interface
1x Kensington® Lock Port
4x USB 2.0 port(s)
1x RJ-45 LAN Port
1x VGA Port
1x Display (DVI-D) Output
1x HDMI Port
1x COM Port
1x Parallel Port
1x PS2 Port
2x Audio Jacks
1x Power (DC) Input
All specifications are subject to change without notice. Please check with your supplier
for exact offers. Products/features may not be available in all markets.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Gaming
Data Sheet - G53SW
Ignite True-to-life Battles
Processing muscle
The popular G53 series has been updated with the recent
release of Intel’s® 2nd generation Core™ i7 for an even faster
notebook. With performance rivaling that of a desktop computer,
the G53SW is ready for anything that you throw at it, from office
applications to video encoding and gaming.
Always cool
With its eye-catching design, the G53SW deploys unique cooling
and noise dampening, with two huge rear venting exhausts that
push both heat and noise away from users. This results in a cool
and quiet environment.
Awesome audio
EAX and THX surround audio boosts game enjoyment and
immersion with realistic effects and enveloping sound, while
redefining sonic performance in music and movies.
Comfort first
The ergonomic illuminated keyboard sits at a 5 degree angle
to increase usability even during long gaming sessions, plus
surfaces come wrapped in a rubberised material for even greater
ease of use.
Gorgeous graphics
The G53SW utilises the brand new NVIDIA GTX 460M with a
massive 1.5GB GDDR5. Based on Fermi technology, this new
graphics processor offers native DirectX11 for a huge graphics
gain in high definition gaming, plus dedicated video acceleration.
Bundled with the G53SW is 3DTV Play from NVIDIA, which
projects the high definition graphics of this notebook onto any
compatible 3DTV via HDMI 1.4. This includes 3D video, games
and photos, taking the experience into the living room.
G53SW-IX097Z
Processor
Intel® Core™ i7-2630QM (2.0 GHz), can
be turbo up to 2.93 GHz
OS
Genuine Window® 7 Ultimate 64bit
Display
15.6” HD TFT (1366x768, Colour-Shine),
3D Panel
Graphic Card
NVIDIA® GeForce® GTX 460M - 1.5G
DDR5 VRAM
Storage
1TB (500GBx2) (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray Combo
Wireless Network
802.11BGN
Bluetooth
Yes
LAN
10/100/1000 Mbps LAN built-in
Webcam
2.0 Mega Pixel web camera
Battery
8 Cell
Warranty
2 year global
Numeric Keyboard
Yes
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps LAN built-in
Keyboard
19mm full size 88 Key with MS Windows
function keys
Card Reader
5 -in-1 card reader (SDXC/ MS/ MS Pro/
MS Duo/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers and EAX Advanced HD 5.0
THX TruStudio
Software
ASUSDVD 6-in-1
WinDVD8 BD
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2009
ASUS Win flash for BIOS and Driver live Update
Asus Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
Asus Live Update
Power 4 Phone
Asus NB Probe +
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Fancy Start
AI Recovery
Supplied Accessories
3D Glasses + Headset + Gaming Bag
& Mouse
Dimension & weight
39.1 x 29.7 x 2.00 ~ 5.00 cm (W x D x H)
3.6 kg (with 8 cell battery)
Colour
Black (Matte)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - G53SX
Ignite True-to-life Battles
Processing muscle
The popular G53 series has been updated with the recent release
of Intel’s® 2nd generation Core™ i7 for an even faster notebook.
With performance rivaling that of a desktop computer, the G53SX
is ready for anything that you throw at it, from office applications
to video encoding and gaming.
Always cool
With its eye-catching design, the G53SX deploys unique cooling
and noise dampening, with two huge rear venting exhausts that
push both heat and noise away from users. This results in a cool
and quiet environment.
Awesome audio
EAX and THX surround audio boosts game enjoyment and
immersion with realistic effects and enveloping sound, while
redefining sonic performance in music and movies.
Comfort first
The ergonomic illuminated keyboard sits at a 5 degree angle
to increase usability even during long gaming sessions, plus
surfaces come wrapped in a rubberized material for even greater
ease of use.
Gorgeous graphics
The G53SX utilises the brand new NVIDIA GTX 560M with a
massive 2GB GDDR5. Based on Fermi technology, this new
graphics processor offers native DirectX11 for a huge graphics
gain in high definition gaming, plus dedicated video acceleration.
Bundled with the G53SX is 3DTV Play from NVIDIA, which
projects the high definition graphics of this notebook onto any
compatible 3DTV via HDMI 1.4. This includes 3D video, games
and photos, taking the experience into the living room.
G53SX-IX122V
Processor
Intel® Core™ i7-2670QM (2.2GHz), can
be turbo up to 3.1GHz
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Colour-Shine),
3D Panel
Graphic Card
NVIDIA® GeForce® GTX 560M - 2G
DDR5 VRAM
Storage
1TB (500GBx2) (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray Combo
Wireless Network
802.11BGN
Bluetooth
Yes
LAN
10/100/1000 Mbps LAN built-in
Webcam
2.0 Mega Pixel web camera
Battery
8 Cell
Warranty
2 year global
Numeric Keyboard
Yes
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps LAN built-in
Keyboard
19mm full size 88 Key with MS Windows
function keys
Card Reader
5 -in-1 card reader (SDXC/ MS/ MS Pro/
MS Duo/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers and EAX Advanced HD 5.0
THX TruStudio
Software
ASUSDVD 6-in-1
WinDVD8 BD
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2009
ASUS Win flash for BIOS and Driver live Update
Asus Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
Asus Live Update
Power 4 Phone
Asus NB Probe +
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Fancy Start
AI Recovery
Supplied Accessories
3D Glasses + Headset + Gaming Bag & Mouse
Dimension & weight
39.1 x 29.7 x 2.00 ~ 5.00 cm (W x D x H)
3.6 kg (with 8 cell battery)
Colour
Black (Matte)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - G75VW
Uncompromised Performance
There’s a new emperor ruling the world of mobile gaming. The
G75VW breaks new performance barriers with the uncompromising
power of a third generation Intel® Core™ i7 CPU and an NVIDIA®
GeForce® GTX 670M GPU with 2GB of GDDR5 VRAM. The G75VW
establishes itself as the fastest notebook in the land and will not
only feed amazing gaming experiences today, but is primed to
continue delivering them for years to come. It also includes support
for 2 second instant on when equipped with an SSH or SSD hard
drive, meaning you no longer have to wait to frag.
G75VW-91121Z
Processor
Intel® Core™ i7-2670QM (2.2GHz)
OS
Genuine Windows® 7 Ultimate 64bit
Display
17.3” Full HD TFT (1920x1080, ColourShine), 3D Panel
Graphic Card
NVIDIA® GeForce® GTX 670M - 2G
DDR5 VRAM
Storage
2TB (1TB x 2) (5400rpm)
Memory
8G (4096 x 2)
Type
DDRIII 1600
Optical Drive
Blu-Ray RW
Wireless Network
802.11 BGN
Bluetooth
Yes
Webcam
Yes
Battery Pack & Life
8 cell
Gamer-centric Design
Warranty
2 year global
Gaming over long periods of time puts increasing demands on
both man and machine, but with the G75VW, conquering in comfort
is paramount to its success on the battlefield. Fatigue will stay
away for longer thanks to advancements in the G75’s design. The
anti-glare panel reduces eye-strain over long periods, while the
spacious, adjustable and back-illuminated seamless one-piece
keyboard with soft-touch palm rest and isolated arrow keys will
keep your mind on the task in hand for longer than ever.
Numeric Keyboard
Yes
Lan/Modem
10/100/1000 Mbps LAN built-in
Keyboard
19mm full size 88 Key with MS Windows
function keys
Card Reader
3 -in-1 card reader ( SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
4 x USB 3.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x SPIDIF speaker out
1 x mini Display Port
Audio
Built-in Speakers And Microphone
Built-in subwoofer
Supplied Accessories
3D Glasses + Headset + Gaming Bag
& Mouse
Software
WinDVD8 BD
Adobe Acrobat Reader 9.0
NERO 8 Essentials
Power2Go
Trend Micro Internet Security 2009/2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus NB Probe +
ASUS Life Frame 3
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Asus Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
41.5 x 32.0 x 1.70~5.2 cm (W x D x H)
4.5 kg (with 8 cell battery)
Colour
Black (Matte)
Incredible 3D Experiences
The G75VW is already destined to become one of the true greats
in the world of mobile gaming, but with support for NVIDIA®
3D Vision™ 2, including 3D Active Shutter and 3D LightBoost
technology, its place on the hall-of-fame is virtually guaranteed.
Games, photos and movies can be experienced like never before –
in Full HD and true 3D!
Incredible Thermal Efficiency
The G75VW packs a massive performance punch, which needs
to be kept cool – the dual fan filter system enables you to keep
your system running cooler and quieter, for longer. The unique,
intelligent thermal design improves power and thermal efficiency
by exhausting hot air from the back of the machine, enabling you to
leave the competition battling for survival in your wake.
*subject to system configuration and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Lamborghini
Data Sheet - Lamborghini VX7SX
Thrilling power
Feel the speed and muscle of a 2nd generation Intel® Core™
i7 processor as it blazes through intense multitasking and high
definition multimedia content. Energy efficient but supremely
capable, the new VX7SX with Genuine Windows® 7 Ultimate
represents the latest step in notebook PC evolution with a harmony
of great power and delectable design.
NVIDIA® GeForce® GTX 560M graphics with 3GB
GDDR5 video memory
Tour the best looking PC games and graphics applications with
the might of a discrete GeForce® GPU, native DirectX® 11
compatibility with the new generation CUDA architecture and a
huge 3GB of speedy GDDR5 video memory. The VX7SX runs all
the newest games in high detail and true HD with no compromise.
Welcome to the fast lane!
Official Automobili Lamborghini materials and
design
Custom-designed to bring out the decades-long legacy of
Lamborghini supercars, the VX7SX uses colors that are formulated
in exactly the same way as their automotive counterparts for a
genuine touch of high-octane luxury. Now in new and extra-durable
carbon black, the VX7SX is also available in official orange and
features many motifs from Lamborghini designs, including leathertrimmed palm rests, an engine start key, rear exhaust and taillight
assembly, and the world-famous bull logo.
VX7SX-S1126Z
Processor
Intel® Core™ i7-6310QM (2.4GHz)
OS
Genuine Windows® 7 Ultimate (64bit)
Display
15.6” 16:9 HD (1366x768) / HD 3D Panel
(1366x768 120Hz) / Full HD (1920x1080)
LED Backlight
Graphic Card
NVIDIA® GeForce® GTX 560M - 3GB
GDDR5 VRAM
Storage
1.5TB (750GB x 2) (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray RW
Wireless
802.11 BGN
Webcam
2.0 Mega Pixel web camera
Bluetooth
Built-in Bluetooth™ V2.1+EDR
Bag/Mouse
Lamborghini bag & mouse included
Battery Pack & Life
8 cell
Warranty
2 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys with numeric keypad
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
5 -in-1 card reader ( SDXC/ MS/ MS Pro/
MS Duo/ MMC)
Security
BIOS Booting / HDD User Password
Protection and security lock
Kensington lock hole
Colour
Black (Glossy)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for external monitor
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And Microphone
Creative Audigy HD
Software
ASUS AIRecovery, ASUS Smart Logon, ASUS Power4Gear
Hybrid, ASUS Winflash, ASUS Live Update, ASUS Fast
Boot, ASUS Color Enhancement (Splendid), ASUS Virtual
Camera, ASUS LifeFrame3, ASUS ControlDeck, ASUS
Wireless Console 3, ASUS FancyStart, ASUS Screen Saver,
eManual, Trend Micro Internet Security 2010 30-day trial,
Syncables Desktop SE, Power recovery, Asus Access Link,
Asus WebStorage, Express Gate Cloud, Windows Live3
package & Toolbar, Google package & Toolbar, GamePark
Console(JPN image not installed),@Vibe, Video Magic
player
Accessories Supplied
Bag & Mouse
Dimension & weight
40.2 x 30.9 x 5.00 ~5.79 cm (WxDxH)
3.82 kg (with 8 cell battery)
Superfast USB 3.0
Only the latest and fastest with the VX7SX – USB 3.0 updates
device connectivity and sets a new milestone in breakneck pace,
operating at up to ten times faster than USB 2.0. It also charges
devices much faster while consuming far less energy
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Ultra Portable
Data Sheet - U36SG
Power in a thin and light design
U36SG-RX107X
Super thin notebook with Intel standard
voltage CPU
Processor
Intel® Core™ i5-2430M (2.4GHz)
OS
Genuine Windows® 7 Professional 64bit
In today’s world, more of our daily computing is done on the move
and notebooks have become an essential part of our lives. In
the past, having a notebook that was thin and lightweight meant
sacrificing performance. Not anymore. Introducing the ASUS
U36, the world’s first 19mm thin notebook with an Intel® standard
voltage CPU. Along with ASUS Super Hybrid Engine technology
giving a boost in performance when needed, the U36 offers the
absolute best combination of performance for the size. With the
U36 weighing in at a mere 1.6kg with an 8-cell battery, it is also
the lightest notebook with a standard voltage CPU, challenging
the way you think about lightweight notebooks.
Display
13.3” HD (1366x768) LED
Graphic Card
NVIDIA® GeForce® GT 610M - 1GB
DDR3 VRAM
Storage
500GB (5400rpm)
Memory
4G (2048x2) DDRIII 1066 RAM
Optical Drive
N/A
Wireless
802.11 BGN
LAN
10/100/1000 Base T
Webcam
Yes
Bluetooth
Yes (Optional V2.1+EDR or V3.0+HS)
Battery Pack & Life
8 cell: 5600 mAh 83Whrs
Warranty
2 year global
Lan/Modem
Atheros AR8132M 10/100Mb
Card Reader
5 -in-1 card reader (SD/ MS/ MS Pro/
xD/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s) (Optional)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
32.8 x 23.8 x 1.9 cm (WxDxH)
1.66 kg (with 8 cell battery)
Colour
Black (Matte)
Exclusive thermal technology
Like humans, the harder a computer works, the hotter its internal
temperature gets. The problem with pushing a computer to
the limit is the amount of heat it generates and how to get rid
of it. With the U36, ASUS engineers tackled this problem by
developing exclusive thermal technology to keep not only
the system cooler, but the palm rest area as well. Using dual
lightweight heat pipes and an efficiently-designed layout, heat is
transferred away from the palm rest for a more comfortable user
experience.
*subject to system configuration and prevailing usage.
Up to 10 hours
battery life*
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - UX21E
UX21E-KX004V
Power in a ultra thin and light design
Incredible Beauty
The ZENBOOK™ uses a precision-crafted design measuring only
3mm at the front and 9mm at the rear. The form features razor
thin edges and a curved centre section, which is both practical
and attractive – while accommodating the powerful computing
components within, this design also looks totally unique. It embodies
beauty and strength in complete balance and harmony.
Incredible Responsiveness
Exclusive ASUS Super Hybrid Engine II with Instant On enables
2-second resume of the notebook from sleep, with up to two weeks
of standby time with open files and other pending data kept safe in
memory. Plus, automatic data backup when the battery reaches
5% charge further helps secure your work.
Processor
Intel® Core™ i5-2467M (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
11.6” HD (1366x768) LED
Graphic Card
Integrated Intel® GMA HD
Storage
128GB SSD SATA 3 Hard Drive
Memory
4G (4096x1) DDRIII 1066 MHz SDRAM
Wireless
802.11 BGN
Webcam
Yes
Bluetooth
Bluetooth 4.0
Battery Pack & Life
35 Whrs Polymer Battery (5 Hours)
Warranty
1 year global
Interface
1 x Headphone-out jack (Audio-in Combo)
1 x USB 3.0 port(s)
1 x USB 2.0 port(s)
1 x micro HDMI
1 x Mini VGA
Audio
Built-in speaker and microphone
Bang & Olufsen ICEpower®
SonicFocus
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Supplied Accessories
Sleeve only
Dimension & weight
Only 3 mm at the front and 9 mm at the
rear
29.9 x 19.6 x 0.3 ~1.7 cm (WxDxH)
Only 1.1 kg
Sleeve
Yes
Colour
Silver (Aluminium)
Incredible Performance
ASUS is proud to deliver the world’s first ultrabook with SATA 3
128GB solid state storage, making for an amazingly smooth and fast
computing experience. Additionally, the ASUS ZENBOOK™ UX21E
ships with SuperSpeed USB 3.0 as standard, multiplying the transfer
rates of current USB 2.0 by as much as a factor of 10 to 1.
Incredible Audio
Another ASUS exclusive, SonicMaster technology was codeveloped with Bang & Olufsen ICEpower® to deliver breathtaking,
lifelike audio that far exceeds the limitations of conventional
notebook PC sound performance.
Optional EU Travel adapter
N45W-01 ADAPTER/EU/BK
90-XB34N0PW00000Y
For UX21E/UX31E
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Accessories
Data Sheet - Notebook Accessories
ASUS TERRA SLIM CARRY BAG
Terra slim bags feature strong construction that helps keep valuables safe,
while they can be used as both sleeves and traditional carriers. The slim
design is conducive to fast-paced professional and social living, utilising
intelligent layouts to get more into the bag without letting go of great style and
convenience. Fits up to 16” laptops. Available in grey or blue.
Terra Slim Carry Bag
Device Compatibility
For 16” Laptop exterior dimension
Dimensions
400(L) x 50(W) x 300(H) mm
Suitable Laptops
B series, K series,
N55 series & P series
Grey
90-XB1F00BA00050-
Blue
90-XB1F00BA00060-
WT400 Mouse - Mix and Match for Ultimate Comfort
Expand your range with precision 2.4GHz wireless control that lets you do more with unlimited freedom, and has a
fittingly interesting art design. even – it’s an experience all your own. Comfort can be easy, and cost-conscious – the
WT400 features smart power saving when at idle, so it’s not only pretty, it works better.
WT400 Mouse
Connectivity
Technology
Wireless
Wireless Technology
RF 2.4GHz
Tracking
Optical
Resolution
1000dpi
OS Support
Windows® 7
Windows® Vista
Windows® 2000
Windows® XP
Mac OS X 10 or higher
RF Distance
10m
Dimensions & Weight
Mouse: 92 (L) x 52 (W) x 35 (H) mm,
72.8g
Receiver: 18 (L) x 14 (W) x 5.4 (H) mm,
80g
Contents
1x WT400 mouse
2x AAA battery
1x Manual
Brown
90-XB1G00MU00010-
Grey
90-XB1G00MU00020-
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
