Incredible Beauty
Incredible Performance
Incredible Audio
Asus Consumer
Product List
February 2012
Asus Consumer
Product List
February 2012
15’ Multimedia
17’ Multimedia
Professional
Ultra Portable
K53U-SX168V
X54H-SO180V
K53E-SX961V
K53E-SX962V
K53E-SX963V
K53SC-SX307V
N55SF-S2213V
K73E-TY210V
K73E-TY213V
K73E-TY324V
K73E-TY325V
N75SL-V2GTY071V
P53E-SO057X
P53E-SO102X
B53E-SO123X
U36SG-RX107X
U46SV-WX044X
ZENBOOK
UX21E-KX004V
Lamborghini
VX7-SZ058Z
Gaming
G53SW-IX097Z
G53SX-IX122V
G74SX-91131Z
ACCESSORIES
BAG / MOUSE
15’ Multimedia
Data Sheet - ASUS K53U
The Perfect Fit for Work and Play
Classy Metallic Design
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you
to do more with your K53 Series in complete confidence.
K53U-SX168V
CPU
AMD® Fusion APU E-450 (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
IceCool Technology Keeps Your Hands Cool
Panel
15.6” HD TFT (1366x768, Color-Shine)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Graphics
AMD Radeon® HD 6310
HDD
320GB (5400rpm)
Memory
3G (2048x1, 1024x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Palm Proof Technology Prevents
Accidental Input
Speaker
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
PC Card Slot
4 -in-1 card reader ( SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - X54H
The Perfect Fit for Work and Play
X54H-SO180V
Processor
Intel® Celeron® B800 (1.5GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Color-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Palm Proof Technology Prevents Accidental Input
Battery
4 cell
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
Warranty
1 year global
Keyboard
Numeric
Power4Gear with self-adjusting fan speeds
Card Reader
Power4Gear’s self-adjusting fan helps you conserve battery
power and provides for a more peaceful computing environment
4 -in-1 card reader ( SD/ MS/
MS Pro/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.8 x 25.3 x 3.56 ~ 3.72 cm (WxDxH)
2.60 kg (with 4 cell battery)
Colour
Black (Matte)
Immersive Multimedia Experience
The ASUS X Series notebooks deliver an immersive multimedia
experience through its high definition LED panel and Altec
Lansing® speakers with SonicFocus software fine-tuning. Your
ASUS X Series notebooks can also connect to HDMI-compatible
TVs, consoles and entertainment systems.
IceCool Technology Keeps Your Hands Cool
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heatpipes and vents, palm rests and typing surfaces stay
cooler than the body temperature so they’re cool even during the
longest computing sessions.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53E
The Perfect Fit for Work and Play
Classy Metallic Design
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you
to do more with your K53 Series in complete confidence.
K53E-SX961V
CPU
Intel ® Pentium® B950 (2.1GHz)
OS
Genuine Windows® 7 Home Premium
64bit
IceCool Technology Keeps Your Hands Cool
Panel
15.6” HD TFT (1366x768, Color-Shine)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Graphics
Integrated Intel® GMA HD
HDD
500GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Palm Proof Technology Prevents
Accidental Input
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader ( SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53E
The Perfect Fit for Work and Play
Classy Metallic Design
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you
to do more with your K53 Series in complete confidence.
K53E-SX962V
CPU
Intel® Core™ i3-2330M (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
IceCool Technology Keeps Your Hands Cool
Panel
15.6” HD TFT (1366x768, Color-Shine)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Graphics
Integrated Intel® GMA HD
HDD
500GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Palm Proof Technology Prevents
Accidental Input
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader (SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53E
The Perfect Fit for Work and Play
Classy Metallic Design
The highly durable premium aluminum textures retain their looks
and quality even during extensive, prolonged use, allowing you
to do more with your K53 Series in complete confidence.
K53E-SX963V
CPU
Intel® Core™ i5-2430M (2.4GHz)
OS
Genuine Windows® 7 Home Premium
64bit
IceCool Technology Keeps Your Hands Cool
Panel
15.6” HD TFT (1366x768, Color-Shine)
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Graphics
Integrated Intel® GMA HD
HDD
640GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Palm Proof Technology Prevents
Accidental Input
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader (SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K53SC
The Perfect Fit for Work and Play
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant colour scheme based on premium aluminum textures,
the new K53 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K53 Series
in complete confidence.
IceCool Technology Keeps Your Hands Cool
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Palm Proof Technology Prevents
Accidental Input
K53SC-SX307V
CPU
Intel® Core™ i5-2430M (2.4GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Panel
15.6” HD TFT (1366x768, Color-Shine)
Graphics
NVIDIA® GeForce® GT 520MX - 1G
DDR3
HDD
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
ODD
DVD Super Multi Dual Layer
Speaker
Built-in speakers and microphone
Altec Lansing® speakers
PC Card Slot
4 -in-1 card reader (SD/ MS/ MS Pro/
MMC)
I/O Port
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LAN
10/100/1000 Mbps
WLAN
802.11 BGN
Webcam
Yes
Numeric Keypad
Yes
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Battery
6 cell
Warranty
1 year global
Dimension
37.8 x 25.3 x 2.83 ~ 3.49 cm (WxDxH)
Weight
2.60 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - N55SF
Incredible in Sound
N55SF-S2213V
Fusing Classical and Post-Modern Design
Processor
Intel® Core™ i7-2670QM (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD+ TFT (1600x900, Color-Shine)
Graphic Card
NVIDIA® GeForce® GT 555M - 2GB
DDR3 VRAM
Storage
750GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
Notebook Audio Elevated to New Levels
ODD
Blu-Ray Combo
Co-developed with Bang & Olufsen ICEpower®, ASUS
SonicMaster Technology brings an evolution of notebook design
with an exclusive combination of advanced hardware and
software to create an immersive audio experience. Improved
and refined for new N Series notebooks, it offers living audio
with the most precise processing protocols and codecs,
superior speaker construction and large resonance chambers
for unforgettable enjoyment – it’s like going to a concert, the
fidelity revitalises vocals and every sound comes to life through
professional enhancement. No more tinny notebook audio
and noise distortion – welcome to an era of true hi-fi on PC.
The bundled SonicMaster subwoofer adds superb deep note
performance for even better audio output.
Wireless
802.11 BGN (WIDI)
LAN
10/100/1000 Mbps
Webcam
HD Web Camera
Bluetooth
Yes (Optional V3.0+HS)
Battery Pack & Life
6 Cell: 5200 mAh 56 Whrs
Warranty
2 year global
Keyboard
Numeric
Simple yet sleek design by David Lewis creates a unique
mood of sophisticated elegance and modernity, featuring
piano-gloss covers and polished metal frames. The new N
Series is also extremely user-focused, delivering comfortable
soft-feel touchpads, fast-type keys with reinforced springs, and
a smoothed-out integrated power button. Intelligent design
and meticulous craftsmanship combine to embody a spirit of
advanced computing and purely sensational simplicity.
Card Reader
3 -in-1 card reader (SD/ MS/ MS Pro Duo/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
2 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And Microphone
Bang & Olufsen ICEpower®
SonicMaster
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
37.9 x 26.1 x 3.7 ~ 3.75 cm (WxDxH)
2.7 kg (with 6 cell battery)
Colour
Black (Piano Gloss)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
17’ Multimedia
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
K73E-TY213V
Processor
Intel Pentium® B950 (2.1GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
3G (2048x1, 1024x1)
Type
DDRIII 1066
IceCool Technology Keeps Your Hands Cool
Optical Drive
DVD Super Multi Dual Layer
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery Pack & Life
6 cell (5200mAh 56 Whrs)
Palm Proof Technology Prevents
Accidental Input
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
Classy Metallic Design
The new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
IF Award-winning Ergonomic Chiclet Keyboard
Extra-wide dust-repellent keys stay comfortable even during
extended typing sessions for improved productivity and
interaction.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
The new K73 Series offers an expressive combination of
technology and style. The highly durable premium aluminum
textures retain their looks and quality even during extensive,
prolonged use, allowing you to do more with your K73 Series in
complete confidence.
IceCool Technology Keeps Your Hands Cool
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
Palm Proof Technology Prevents
Accidental Input
Intelligent touchpad distinguishes between palm and finger
contact to prevent inadvertent cursor movements during typing.
IF Award-winning Ergonomic Chiclet Keyboard
Extra-wide dust-repellent keys stay comfortable even during
extended typing sessions for improved productivity and
interaction.
K73E-TY324V
Processor
Intel Pentium® B960 (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery Pack & Life
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 ports
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant color scheme based on premium aluminum textures, the
new K73 Series offers an expressive combination of technology
and style. The highly durable premium aluminum textures
retain their looks and quality even during extensive, prolonged
use, allowing you to do more with your K73 Series in complete
confidence.
Incredible Processing Power
The new K73 Series ships with 2nd Generation Intel® Core™
Processors, as optimized for notebook use with awesome
computing power – in particular, these new mobile CPUs
enhance multitasking, so you can get more done at the same
time, more smoothly.
IceCool Technology Keeps Your Hands Cool
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
K73E-TY210V
Processor
Intel® Core™ i3-2330M (2.2GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery Pack & Life
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS K73E
Stay Cool with Metallic Chic
Classy Metallic Design
Featuring 2nd Generation Intel® Core™ Processors and an
elegant color scheme based on premium aluminum textures, the
new K73 Series offers an expressive combination of technology
and style. The highly durable premium aluminum textures
retain their looks and quality even during extensive, prolonged
use, allowing you to do more with your K73 Series in complete
confidence.
Incredible Processing Power
The new K73 Series ships with 2nd Generation Intel® Core™
Processors, as optimized for notebook use with awesome
computing power – in particular, these new mobile CPUs
enhance multitasking, so you can get more done at the same
time, more smoothly.
IceCool Technology Keeps Your Hands Cool
IceCool Technololgy makes your PC experience cool and
comfortable even during the longest computing sessions.
Exclusive dual-sided motherboard design places hot
components on the underside and away from users. Combined
with heat pipes and vents, palm rests and typing surfaces stay
cooler.
K73E-TY325V
Processor
Intel® Core™ i3-2350M (2.3GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Memory
4G (2048x2)
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Numeric Keypad
Yes
Battery Pack & Life
6 cell (5200mAh 56 Whrs)
Warranty
1 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys, Numeric Keyboard
Lan/Modem
10/100/1000 Mbps LAN built-in
Card Reader
3 -in- 1 card reader, (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
4 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Numeric KB Lock
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.0 x 3.68 cm (W x D x H)
3.20 kg (with 6 cell battery)
Colour
Brown (Matte Metallic)
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS N75SL
Incredible in Sound
N75SL-V2G-TY071V
Processor
Intel® Core™ i5-2450M (2.5GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
17.3”HD+ TFT (1600 x 900, Colour Shine)
Graphic Card
NVIDIA® GeForce® GT 6350M - 2G
DDR3 VRAM
Storage
500GB (5400rpm)
Memory
6G (2048x1, 4096x1)
Type
DDRIII 1066
Optical Drive
Blu-Ray Combo
Notebook Audio Elevated to New Levels
Wireless
802.11 BGN
Co-developed with Bang & Olufsen ICEpower®, ASUS
SonicMaster Technology brings an evolution of notebook design
with an exclusive combination of advanced hardware and
software to create an immersive audio experience. Improved
and refined for new N Series notebooks, it offers living audio
with the most precise processing protocols and codecs,
superior speaker construction and large resonance chambers
for unforgettable enjoyment – it’s like going to a concert, the
fidelity revitalises vocals and every sound comes to life through
professional enhancement. No more tinny notebook audio
and noise distortion – welcome to an era of true hi-fi on PC.
The bundled SonicMaster subwoofer adds superb deep note
performance for even better audio output.
LAN
10/100/1000 Mbps
Bluetooth
Yes
Webcam
Yes
Numeric Keypad
Yes
Battery Pack
6 cell
Warranty
2 year global
Keyboard
Numeric Keypad
Card Reader
5 -in- 1 card reader (SD,MMC,MS,MSPro,XD)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (S/PDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 ports (optional)
2 x USB 2.0 ports
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x E-SATA (Combo with USB 2.0)
Audio
Built-in speaker and microphone
Bang & Olufsen ICEpower®
SonicFocus
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
42.0 x 28.7 x 3.67~4.05 cm (W x D x H)
3.40 kg (with 6 cell battery)
Colour
Black (Piano Gloss)
Fusing Classical and Post-Modern Design
Simple yet sleek design by David Lewis creates a unique
mood of sophisticated elegance and modernity, featuring
piano-gloss covers and polished metal frames. The new N
Series is also extremely user-focused, delivering comfortable
soft-feel touchpads, fast-type keys with reinforced springs, and
a smoothed-out integrated power button. Intelligent design
and meticulous craftsmanship combine to embody a spirit of
advanced computing and purely sensational simplicity.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Professional
Data Sheet - ASUS P53E
The Trusted Business Solution
P53E-SO102X
Intelligent Performance
Processor
Intel® Core™ i3-2330M (2.2GHz)
OS
Genuine Windows® 7 Professional 64bit
Display
15.6” HD TFT (1366x768, Color-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Clear display even in bright environments
Memory
2G (2048 x 1)
Glare-proof screens use advanced panel layering manufacturing
methods that allow users to see and read with comfort and
clarity even under bright lights. This is particularly useful when
outdoors.
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
Webcam
Yes
Durable anti-shock hard drive
Battery Pack & Life
6 cell
ASUS ShockShield motion sensors and anti-shock cushions
safeguard the hard drive and valuable data against damage.
Warranty
1 year global
Keyboard
Numeric Keyboard
ASUS Secure Delete - permanently erases
sensitive data
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps
An easy-to-use interface that allows you to permanently remove
confidential data from the recycle bin. Simply launch Secure
Delete and drag and drop the files to be deleted.
Card Reader
4 -in-1 card reader ( SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Numeric KB Lock
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
37.8 x 25.3 x 3.17~ 3.60 cm (WxDxH)
2.60 kg (with 6 cell battery)
Colour
Black (Matte)
ASUSPRO P Series notebooks with 2nd generation Intel® core
processors feature improved adaptive performance that speeds
up when you need extra power, and built-in graphics capabilities
for a noticeably better PC experience.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS P53E
The Trusted Business Solution
P53E-SO057X
Intelligent Performance
Processor
Intel® Core™ i3-2330M (2.2GHz)
OS
Genuine Windows® 7 Professional 64bit
Display
15.6” HD TFT (1366x768, Color-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
320GB (5400rpm)
Clear display even in bright environments
Memory
4G (2048x2)
Glare-proof screens use advanced panel layering manufacturing
methods that allow users to see and read with comfort and
clarity even under bright lights. This is particularly useful when
outdoors.
Type
DDRIII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
Webcam
Yes
Durable anti-shock hard drive
Battery
6 cell
ASUS ShockShield motion sensors and anti-shock cushions
safeguard the hard drive and valuable data against damage.
Warranty
1 year global
Keyboard
Numeric Keyboard
ASUS Secure Delete - permanently erases
sensitive data
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps
An easy-to-use interface that allows you to permanently remove
confidential data from the recycle bin. Simply launch Secure
Delete and drag and drop the files to be deleted.
Card Reader
4 -in-1 card reader (SD/ MS/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
LED Status Indicator
Numeric KB Lock
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Audio
Built-in Speakers And Microphone
SonicFocus
Altec Lansing® Speakers
Software
ASUSDVD 6-in-1
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus Multi-Frame
ASUS Wireless Console
Virtual Camera
ASUS Splendid
Asus Screen Saver
Fancy Start
eManual
AI Recovery
ASUS FastBoot
ControlDeck
Dimension & weight
37.8 x 25.3 x 3.17~ 3.60 cm (WxDxH)
2.60 kg (with 6 cell battery)
Colour
Black (Matte)
ASUSPRO P Series notebooks with 2nd generation Intel® core
processors feature improved adaptive performance that speeds
up when you need extra power, and built-in graphics capabilities
for a noticeably better PC experience.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - ASUS B53E
Pro Notebooks for Business Pros
Top Quality Commercial Notebooks
ASUSPRO B Series notebooks are all strictly quality tested to
surpass industry standards, surviving drop tests, hinge test
cycles and panel pressure testing.
Smart card access, fingerprint readers
and optional TPM
Strict gatekeeping and privacy controls to guarantee only
authorized users have access to important files.
ASUS Secure Delete - permanently erases
sensitive data
An easy-to-use interface that allows you to permanently remove
confidential data from the recycle bin. Simply launch Secure
Delete and drag and drop the files to be deleted.
ASUS Power Station II
Uncompromising, expansive connectivity through a detachable
docking station that allows for the quick connection of
peripherals, communication devices, and power cables.
B53E-SO123X
Processor
Intel® Core™ I5-2430M (2.4GHz)
OS
Genuine Windows® 7 Professional 64bit
Display
15.6” HD TFT (1366x768, Color-Shine)
Graphic Card
Integrated Intel® GMA HD
Storage
500GB (5400rpm)
Memory
4G (2048x2)
Type
DDRII 1066
Optical Drive
DVD Super Multi Dual Layer
Wireless
802.11 BGN
LAN
10/100/1000 Mbps
Webcam
Yes
Finger Print
Yes
Security
TPM
Battery
8 cell
Warranty
1 year global
Keyboard
Numeric Keyboard
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps
Card Reader
5 -in- 1 card reader (SD,MMC,MS,MSPro,XD)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
1 x E-SATA (USB2.0 Combo) Ports
1 x RJ11 Modem jack for phone line
1 x Express card
1 x Display Port
1 x Fingerprint
LED Status Indicator
Numeric KB Lock
Power-on/Suspend
Battery Charging/full/low
Storage device access
Capital Lock
Wireless on status indicator
Audio
Built-in speaker and microphone
Altec Lansing® speakers
Dimension & weight
38.4 x 26.3 x 3.30 ~ 3.50 cm (W x D x H)
2.69 kg
Colour
Black (Matte)
spill proof
keyboard*
docking station
optional
*Spill proof Repels Up to 120cc of Liquid
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - B53E Docking Station
ASUS Power Station II Uncompromised,
expansive connectivity
The detachable docking station allows for the quick
connection of peripherals, communication devices,
and power cables.
ASUS Xpress Charge - quick charges to 90% capacity
in just 90 minutes. Detachable docking station,
and multitask on up to three displays
Docking Power Station II
90-N0LDK1003Y:
Device Compatibility
B53E Notebook only
Interface
1x Kensington® Lock Port
4x USB 2.0 port(s)
1x RJ-45 LAN Port
1x VGA Port
1x Display (DVI-D) Output
1x HDMI Port
1x COM Port
1x Parallel Port
1x PS2 Port
2x Audio Jacks
1x Power (DC) Input
All specifications are subject to change without notice. Please check with your supplier
for exact offers. Products/features may not be available in all markets.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Gaming
Data Sheet - G53SW
Ignite True-to-life Battles
Processing muscle
The popular G53 series has been updated with the recent
release of Intel’s® 2nd generation Core™ i7 for an even faster
notebook. With performance rivaling that of a desktop computer,
the G53SW is ready for anything that you throw at it, from office
applications to video encoding and gaming.
Always cool
With its eye-catching design, the G53SW deploys unique cooling
and noise dampening, with two huge rear venting exhausts that
push both heat and noise away from users. This results in a cool
and quiet environment.
Awesome audio
EAX and THX surround audio boosts game enjoyment and
immersion with realistic effects and enveloping sound, while
redefining sonic performance in music and movies.
Comfort first
The ergonomic illuminated keyboard sits at a 5 degree angle
to increase usability even during long gaming sessions, plus
surfaces come wrapped in a rubberized material for even greater
ease of use.
Gorgeous graphics
The G53SW utilizes the brand new NVIDIA GTX 460M with a
massive 1.5GB GDDR5. Based on Fermi technology, this new
graphics processor offers native DirectX11 for a huge graphics
gain in high definition gaming, plus dedicated video acceleration.
Bundled with the G53SW is 3DTV Play from NVIDIA, which
projects the high definition graphics of this notebook onto any
compatible 3DTV via HDMI 1.4. This includes 3D video, games
and photos, taking the experience into the living room.
G53SW-IX097Z
Processor
Intel® Core™ i7-2630QM (2.0 GHz), can
be turbo up to 2.93 GHz
OS
Genuine Window® 7 Ultimate 64bit
Display
15.6” HD TFT (1366x768, Color-Shine),
3D Panel
Graphic Card
NVIDIA® GeForce® GTX 460M - 1.5G
DDR5 VRAM
Storage
1TB (500GBx2) (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray Combo
Wireless Network
802.11BGN
Bluetooth
Yes
LAN
10/100/1000 Mbps LAN built-in
Webcam
2.0 Mega Pixel web camera
Battery
8 Cell
Warranty
2 year global
Numeric Keyboard
Yes
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps LAN built-in
Keyboard
19mm full size 88 Key with MS Windows
function keys
Card Reader
5 -in-1 card reader (SDXC/ MS/ MS Pro/
MS Duo/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And EAX Advanced HD 5.0
THX TruStudio
Software
ASUSDVD 6-in-1
WinDVD8 BD
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2009
ASUS Win flash for BIOS and Driver live Update
Asus Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
Asus Live Update
Power 4 Phone
Asus NB Probe +
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Fancy Start
AI Recovery
Supplied Accessories
3D Glasses + Headset + Gaming Bag
& Mouse
Dimension & weight
39.1 x 29.7 x 2.00 ~ 5.00 cm (W x D x H)
3.6 kg (with 8 cell battery)
Colour
Black (Matte)
*subject to system configuration and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - G53SX
Ignite True-to-life Battles
Processing muscle
The popular G53 series has been updated with the recent
release of Intel’s® 2nd generation Core™ i7 for an even faster
notebook. With performance rivaling that of a desktop computer,
the G53SW is ready for anything that you throw at it, from office
applications to video encoding and gaming.
Always cool
With its eye-catching design, the G53SW deploys unique cooling
and noise dampening, with two huge rear venting exhausts that
push both heat and noise away from users. This results in a cool
and quiet environment.
Awesome audio
EAX and THX surround audio boosts game enjoyment and
immersion with realistic effects and enveloping sound, while
redefining sonic performance in music and movies.
Comfort first
The ergonomic illuminated keyboard sits at a 5 degree angle
to increase usability even during long gaming sessions, plus
surfaces come wrapped in a rubberized material for even greater
ease of use.
Gorgeous graphics
The G53SW utilizes the brand new NVIDIA GTX 460M with a
massive 1.5GB GDDR5. Based on Fermi technology, this new
graphics processor offers native DirectX11 for a huge graphics
gain in high definition gaming, plus dedicated video acceleration.
Bundled with the G53SW is 3DTV Play from NVIDIA, which
projects the high definition graphics of this notebook onto any
compatible 3DTV via HDMI 1.4. This includes 3D video, games
and photos, taking the experience into the living room.
G53SX-IX122V
Processor
Intel® Core™ i7-2670QM (2.3GHz), can
be turbo up to 3.1GHz
OS
Genuine Windows® 7 Home Premium
64bit
Display
15.6” HD TFT (1366x768, Color-Shine),
3D Panel
Graphic Card
NVIDIA® GeForce® GTX 560M - 2G
DDR5 VRAM
Storage
1TB (500GBx2) (5400rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray Combo
Wireless Network
802.11BGN
Bluetooth
Yes
LAN
10/100/1000 Mbps LAN built-in
Webcam
2.0 Mega Pixel web camera
Battery Pack & Life
8 Cell
Warranty
2 year global
Numeric Keyboard
Yes
Bluetooth
Yes
Lan/Modem
10/100/1000 Mbps LAN built-in
Keyboard
19mm full size 88 Key with MS Windows
function keys
Card Reader
5 -in-1 card reader (SDXC/ MS/ MS Pro/
MS Duo/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in Speakers And EAX Advanced HD 5.0
THX TruStudio
Software
ASUSDVD 6-in-1
WinDVD8 BD
Adobe Acrobat Reader 9.0
Trend Micro Internet Security 2009
ASUS Win flash for BIOS and Driver live Update
Asus Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
Asus Live Update
Power 4 Phone
Asus NB Probe +
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Fancy Start
AI Recovery
Supplied Accessories
3D Glasses + Headset + Gaming Bag & Mouse
Dimension & weight
39.1 x 29.7 x 2.00 ~ 5.00 cm (W x D x H)
3.6 kg (with 8 cell battery)
Colour
Black (Matte)
*subject to system configuration and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - G74SX
Hail to the King!
The world of portable gaming has a new reigning king.
The G74SX is a performance notebook that imposes its will with
the combined power of a second generation Intel® Core™ i7
CPU and NVIDIA® GTX 560M GPU with 3GB of GDDR5 VRAM.
A score of P2008 in 3DMark11 and P9180 in 3DMark Vantage
takes over the reins as the fastest notebook in the land. Support
for DirectX®11 ensures that you’ll not only have the fastest rig in
town, but also the ability to play games as they were meant to be
seen for a long time.
G74SX-91131Z
Processor
Intel® Core™ i7-2630QM (2.0GHz), can
be turbo up to 2.93GHz
OS
Genuine Windows® 7 Ultimate 64bit
Display
17.3” Full HD TFT (1920x1080, ColorShine), 3D Panel
Graphic Card
NVIDIA® GeForce® GTX 560M - 3G
DDR5 VRAM
Storage
1.5TB (750GBx2) (7200rpm)
Stealth and Strength
Memory
8G (4096x2)
Like its predecessor, the G74SX design was inspired by sharp
polygonal shapes, but this time inspiration came from the US
Navy’s Sea Shadow stealth ship and modern day aircraft carriers.
Like the stealth ship, opponents will never know what hit ‘em, and
like an aircraft carrier, the G74 has the firepower to shock and
awe the competition.
Type
DDRIII 1333
Optical Drive
Blu-Ray RW
Wireless Network
802.11 BGN
Bluetooth
Yes
Webcam
Yes
True-to-life 3D Video & Audio
Battery Pack & Life
8 cell
The G74SX is great for gaming, but its hardware is serious
business. It offers the best 3D ecosystem for PCs, offering 3D
content creation and editing. It’s powered with NVIDIA® 3D
Vision™, so games, photos and movies are all able to be enjoyed
like never before. There’s also the ability to output the G74SX to
a 3D TV, so you can enjoy 3D entertainment from the living room.
Pair that up with THX + EAX 5.0 3D gaming audio technology,
and together they make the G74 not only a great gaming
notebook, but also a hub for multimedia entertainment.
Warranty
2 year global
Lan/Modem
10/100/1000 Base T
Keyboard
19mm full size 88 Key with MS Windows
function keys (Numeric keypad)
Card Reader
8 -in-1 card reader (SD/ Mini-SD/ MS/
MS Pro/ MS Duo/ MS Pro Duo/ xD/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in 2 Speakers And Digital Array
Microphone
Built-in Azalia compliant audio chip, with
3D effect
Supplied Accessories
3D Glasses + Headset + Gaming Bag & Mouse
Software
WinDVD8 BD
Adobe Acrobat Reader 9.0
NERO 8 Essentials
Power2Go
Trend Micro Internet Security 2009/2010
ASUS SmartLogon
Asus Power4Gear Hybrid
Asus Live Update
Asus NB Probe +
ASUS Life Frame 3
ASUS Wireless Console
Virtual Camera
ASUS Splendid
ASUS Hotkey
ASUS Express Gate
Asus Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
32.5 x 42 x 2.09 ~ 6.2 cm (WxDxH)
4.28 kg (with 8 cell battery)
Colour
Black (Matte)
Get Comfy
Gaming is something to be enjoyed, so why not be more
comfortable for extended gaming sessions? Fatigue will be
a thing of the past, thanks to the G74’s 5° incline keyboard
designed to provide a better ergonomic angle, as well as super
comfortable rubber-like palm rests that’s easy on the palm
and wrist. There’s also more space between the keyboard and
number pad, so it more resembles a desktop keyboard.
*subject to system configuration and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
THE ULTIMATE 17” GAMING LAPTOP
ASUS ROG G74
S T R I K E
I N
S I L E N C E
Hail to the King!
True-to-life 3D Video & Audio
The world of portable gaming has a new reigning king.
The G74SX is a performance notebook that imposes its will
with the combined power of a second generation Intel®
Core™ i7 CPU and NVIDIA® GTX 560M GPU with 3GB of
GDDR5 VRAM. A score of P2008 in 3DMark11 and P9180
in 3DMark Vantage takes over the reins as the fastest
notebook in the land. Support for DirectX®11 ensures that
you’ll not only have the fastest rig in town, but also the
ability to play games as they were meant to be seen for a
long time.
The G74SX is great for gaming, but its hardware is serious
business. It offers the best 3D ecosystem for PCs, offering
3D content creation and editing. It’s powered with NVIDIA®
3D Vision™, so games, photos and movies are all able to be
enjoyed like never before. There’s also the ability to output
the G74SX to a 3D TV, so you can enjoy 3D entertainment
from the living room. Pair that up with THX + EAX 5.0 3D
gaming audio technology, and together they make the
G74 not only a great gaming notebook, but also a hub for
multimedia entertainment.
Stealth and Strength
Like its predecessor, the G74SX design was inspired by
sharp polygonal shapes, but this time inspiration came
from the US Navy’s Sea Shadow stealth ship and modern
day aircraft carriers. Like the stealth ship, opponents will
never know what hit ‘em, and like an aircraft carrier, the
G74 has the firepower to shock and awe the competition.
Intel® Core™ i7 CPU and up to 8GB memory
NVIDIA® GTX 560M GPU with 3GB of GDDR5
Huge vents for max cool and min noise
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Lamborghini
Data Sheet - Lamborghini VX7
Experience a new style of speed with the ASUSAutomobili Lamborghini VX7
Ultra-luxe design inspired by the world-famous Italian supercars
meets ASUS technological excellence. It’s our most powerful
notebook to date, ready to take you for a ride.
Looks Stunning
Taking design cues from the Automobili Lamborghini and
Murcielago LP640, the VX7 retains their aerodynamic and
aggressive stance for a style that stands out from the crowd.
Expect people to notice. Premium materials, sleek textures and
bold colors complete this notebook, revving up your high-octane
computing.
Packed with Tech
When you get your hands on the VX7 with Genuine Windows®
7 Ultimate, you’re assured performance that races past the
competition. This is the crème de la crème of portable PCs.
VX7-SZ058Z
Processor
Intel® Core™ i7-2630QM (2.0GHz), can
be turbo up to 2.93GHz
OS
Genuine Windows® 7 Ultimate (64bit)
Display
15.6” Full HD TFT (1920x1080)
Graphic Card
NVIDIA® GeForce® GTX 460M - 3GB
GDDR5 VRAM
Storage
1.5TB (750GBx2) (7200rpm)
Memory
8G (4096x2)
Type
DDRIII 1333
Optical Drive
Blu-Ray Combo
Wireless
802.11 BGN
Webcam
2.0 Mega Pixel web camera
Bluetooth
Built-in Bluetooth™ V2.1+EDR
Bag/Mouse
Lamborghini bag & mouse included
Battery
8 cell
NVIDIA® GeForce™ GTX 460M graphics with giant 3GB video
memory set the stage for high res gaming and none of the
compromise lesser notebooks force on you. This is the real deal.
Warranty
2 year global
Keyboard
19mm full size 88 Key with MS Windows
function keys + numeric keypad
All new Intel® 2nd Generation Core™ i7 Processors propel
computing with extreme quad-core performance for better HD
multimedia and multitasking so you get more done – faster.
Lan/Modem
10/100/1000 Base T
Card Reader
8 -in-1 card reader (SD/ Mini-SD/ MS/
MS Pro/ MS Duo/ MS Pro Duo/ xD/ MMC)
Security
BIOS Booting / HDD User Password
Protection and security lock
Kensington lock hole
Fingerprint
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s)
3 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in 2 Speakers And Digital Array
Microphone
Built-in Azalia compliant audio chip,
with 3D effect
Software
ASUS AIRecovery, ASUS Smart Logon, ASUS Power4Gear
Hybrid, ASUS Winflash, ASUS Live Update, ASUS Fast
Boot, ASUS Color Enhancement (Splendid), ASUS Virtual
Camera, ASUS LifeFrame3, ASUS ControlDeck, ASUS
Wireless Console 3, ASUS FancyStart, ASUS Screen Saver,
eManual, Trend Micro Internet Security 2010 30-day trial,
Syncables Desktop SE, Power recovery, Asus Access Link,
Asus WebStorage, Express Gate Cloud, Windows Live3
package & Toolbar, Google package & Toolbar, GamePark
Console(JPN image not installed),@Vibe, Video Magic
player
Accessories Supplied
Bag & Mouse
Dimension & weight
40.2 x 30.9 x 5.00 ~ 5.79 cm (WxDxH)
3.82 kg (with 8 cell battery)
Colour
Black (Glossy)
Up to 16GB DDR3 main memory ensure a grand touring
experience of smooth performance and better output in every
application.
New Super-Speed USB 3.0 runs up to ten times faster than USB
2.0, an ideal fit for your HD content and files.
*subject to system configuration and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Ignite the might of the most powerful notebook ever from ASUS, The ASUS AUTOMOBILI
Lamborghini VX7. Experience the sheer force of a 2nd generation Intel® quad-core Core™
i7 CPU, driven by Microsoft Genuine Windows® 7 and massive NVIDIA® GeForce™ GTX
460M graphics with 3GB dedicated video memory, as the VX7 launches your computing into
an entirely higher plane of excitement and sophistication with a design reflecting the flowing
and aggressive look of Lamborghini supercars.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Ultra Portable
Data Sheet - U46SV
Power in a thin and light design
U46SV-WX044X
Processor
Intel® Core™ i5-2410M (2.3GHz)
OS
Genuine Windows® 7 Professional 64bit
Display
14.0” 16:9 HD (1366x768) Color-Shine
Graphic Card
NVIDIA® GeForce® GT 540M - 1G
DDR3 VRAM
Storage
500GB (5400rpm)
Memory
4G (2048x2) DDRIII 1066 RAM
Optical Drive
DVD Super Multi Dual Layer
Powerful 2nd generation Intel® Core™ processors
and NVIDIA® GeForce® GPU
Wireless
802.11 BGN
LAN
10/100/1000 Base T
Standard voltage, uncompromising Core™ i5 CPUs easily
handle more intense multitasking, higher definition and smoother
multimedia, plus faster productivity for a portable PC you can rely on
in any application. The discrete NVIDIA® GeForce® GT 540M GPU
boosts visual output with native DirectX® 11 compatibility for the
latest in graphics, so that everything from HD movies to high-end PC
games runs smoothly and in incredible detail.
Webcam
Yes
Bluetooth
Yes
Battery Pack & Life
8 cell: 5600 mAh
Warranty
2 year global
Lan/Modem
Atheros AR8132M 10/100Mb
Card Reader
4 -in-1 card reader (SD/ MS/ MS Pro/
MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speaker and microphone
SonicFocus
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
33.3 x 24.5 x 2.46 ~ 2.70 cm (W x D x H)
2.08 kg (with 4 cell battery)
Colour
Champagne Gold (Silver)
Under an inch thick!
The ultra-thin and light design fits more technology into a compact
form factor that’s easy to carry and use. The slim bezel means a
bigger screen can be attached to a more slender chassis, while
the spun aluminum finish creates a very unique look. ASUS has
also engineered a special hinge-forward design for the new U46SV,
allowing for a wider opening angle and easier viewing even in the
confines of an aircraft seat.
Extended battery life
Highly efficient technology and optimized energy requirements give
you the benefit of a finely-tuned battery that can last up to 10 hours*
on one charge. This means true all-day computing wherever you go,
with no need to stop and seek out an inconvenient wall socket.
*May vary by actual usage conditions
Up to 10 hours
battery life
*subject to system configuration
and prevailing usage.
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - U36SG
Power in a thin and light design
U36SG-RX107X
Super thin notebook with Intel standard
voltage CPU
Processor
Intel® Core™ i5-2430M (2.4GHz)
OS
Genuine Windows® 7 Professional 64bit
In today’s world, more of our daily computing is done on the
move and notebooks have become an essential part of our lives.
In the past, having a notebook that was thin and lightweight
meant sacrificing performance. Not anymore. Introducing the
ASUS U36, the world’s first 19mm thin notebook with an Intel®
standard voltage CPU. Along with ASUS Super Hybrid Engine
technology giving a boost in performance when needed, the
U36 offers the absolute best combination of performance for
the size. With the U36 weighing in at a mere 1.6kg with an 8-cell
battery, it is also
the lightest notebook with a standard voltage CPU, challenging
the way you think about lightweight notebooks.
Display
13.3” HD TFT (1366x768, Color-Shine,
LED)
Graphic Card
NVIDIA® GeForce® GT 610M - 1GB
DDR3 VRAM
Storage
500GB (5400rpm)
Memory
4G (2048x2) DDRIII 1066 RAM
Optical Drive
N/A
Wireless
802.11 BGN
LAN
10/100/1000 Base T
Webcam
Yes
Bluetooth
Yes (Optional V2.1+EDR or V3.0+HS)
Battery Pack & Life
8 cell: 5600 mAh 83Whrs
Warranty
2 year global
Keyboard
Numeric
Lan/Modem
Atheros AR8132M 10/100Mb
Card Reader
5 -in-1 card reader (SD/ MS/ MS Pro/
xD/ MMC)
Interface
1 x Microphone-in jack
1 x Headphone-out jack (SPDIF)
1 x VGA port/Mini D-sub 15-pin for
external monitor
1 x USB 3.0 port(s) (Optional)
2 x USB 2.0 port(s)
1 x RJ45 LAN Jack for LAN insert
1 x HDMI
Audio
Built-in speakers and microphone
Altec Lansing® speakers
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Software
ASUSDVD 6-in-1
ASUS Win flash for BIOS and Driver live Update
ASUS SmartLogon
ASUS Net 4 switch
ASUS Live Update
ASUS Multi-Frame
ASUS NB Probe +
ASUS Wireless Console
ASUS Data Security Management(ADSM)
Virtual Camera
ASUS Splendid
ASUS Express Gate
ASUS Screen Saver
Fancy Start
eManual
AI Recovery
Dimension & weight
32.8 x 23.8 x 1.9 cm (WxDxH)
1.66 kg (with 8 cell battery)
Colour
Black (Matte)
Exclusive thermal technology
Like humans, the harder a computer works, the hotter its internal
temperature gets. The problem with pushing a computer to
the limit is the amount of heat it generates and how to get rid
of it. With the U36, ASUS engineers tackled this problem by
developing exclusive thermal technology to keep not only
the system cooler, but the palm rest area as well. Using dual
lightweight heat pipes and an efficiently-designed layout, heat is
transferred away from the palm rest for a more comfortable user
experience.
Up to 10 hours
battery life
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Data Sheet - UX21E
UX21E-KX004V
Power in a ultra thin and light design
Incredible Beauty
The ZENBOOK™ uses a precision-crafted design measuring only
3mm at the front and 9mm at the rear. The form features razor
thin edges and a curved centre section, which is both practical
and attractive – while accommodating the powerful computing
components within, this design also looks totally unique. It embodies
beauty and strength in complete balance and harmony.
Incredible Responsiveness
Exclusive ASUS Super Hybrid Engine II with Instant On enables
2-second resume of the notebook from sleep, with up to two weeks
of standby time with open files and other pending data kept safe in
memory. Plus, automatic data backup when the battery reaches
5% charge further helps secure your work.
Processor
Intel® Core™ i5-2467M (1.6GHz)
OS
Genuine Windows® 7 Home Premium
64bit
Display
11.6” HD (1366x768) LED
Graphic Card
Integrated Intel® GMA HD
Storage
128GB SSD SATA 3 Hard Drive
Memory
4G (4096x1) DDRIII 1066 MHz SDRAM
Wireless
802.11 BGN
Webcam
Yes
Bluetooth
Bluetooth 4.0
Battery Pack & Life
35 Whrs Polymer Battery (5 Hours)
Warranty
1 year global
Interface
1 x Headphone-out jack (Audio-in Combo)
1 x USB 3.0 port(s)
1 x USB 2.0 port(s)
1 x micro HDMI
1 x Mini VGA
Audio
Built-in speaker and microphone
Bang & Olufsen ICEpower®
SonicFocus
LED Status Indicator
HDD
Power-on/Suspend
Capital Lock
Wireless on status indicator
Bluetooth on status indicator
Dimension & weight
Only 3 mm at the front and 9 mm at the
rear
29.9 x 19.6 x 0.3 ~1.7 cm (WxDxH)
Only 1.1 kg
Sleeve
Yes
Colour
Silver (Aluminium)
Incredible Performance
ASUS is proud to deliver the world’s first ultrabook with SATA 3
128GB solid state storage, making for an amazingly smooth and fast
computing experience. Additionally, the ASUS ZENBOOK™ UX21E
ships with SuperSpeed USB 3.0 as standard, multiplying the transfer
rates of current USB 2.0 by as much as a factor of 10 to 1.
Incredible Audio
Another ASUS exclusive, SonicMaster technology was codeveloped with Bang & Olufsen ICEpower® to deliver breathtaking,
lifelike audio that far exceeds the limitations of conventional
notebook PC sound performance.
Optional EU Travel adapter
N45W-01 ADAPTER/EU/BK
90-XB34N0PW00000Y
For UX21E/UX31E
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Accessories
Data Sheet - Notebook Accessories
ASUS TERRA SLIM CARRY BAG
Terra slim bags feature strong construction that helps keep valuables safe,
while they can be used as both sleeves and traditional carriers. The slim
design is conducive to fast-paced professional and social living, utilising
intelligent layouts to get more into the bag without letting go of great style and
convenience. Fits up to 16” laptops. Available in grey or blue.
Terra Slim Carry Bag
Device Compatibility
For 16” Laptop exterior dimension
Dimensions
400(L) x 50(W) x 300(H) mm
Suitable Laptops
B series, K series,
N55 series & P series
Grey
90-XB1F00BA00050-
Blue
90-XB1F00BA00060-
WT400 Mouse - Mix and Match for Ultimate Comfort
Expand your range with precision 2.4GHz wireless control that lets you do more with unlimited freedom, and has a
fittingly interesting art design. even – it’s an experience all your own. Comfort can be easy, and cost-conscious – the
WT400 features smart power saving when at idle, so it’s not only pretty, it works better.
WT400 Mouse
Connectivity
Technology
Wireless
Wireless Technology
RF 2.4GHz
Tracking
Optical
Resolution
1000dpi
OS Support
Windows® 7
Windows® Vista
Windows® 2000
Windows® XP
Mac OS X 10 or higher
RF Distance
10m
Dimensions & Weight
Mouse: 92 (L) x 52 (W) x 35 (H) mm,
72.8g
Receiver: 18 (L) x 14 (W) x 5.4 (H) mm,
80g
Contents
1x WT400 mouse
2x AAA battery
1x Manual
Brown
90-XB1G00MU00010-
Grey
90-XB1G00MU00020-
asus.co.uk
© ASUS 2008. All Rights Reserved. ASUS, ASUS Advantage and ASUS Green are trade marks or registered trade marks of ASUS Computers in Taiwan, other countries or both. Models pictured are for illustration purposes only and may not
correspond to advertised product specifications. All trademarks and registered names are the property of respective owners. Offers are for business customers only and are subject to availability. Product specifications may be modified at any
time without notice. ASUS is not responsible for typographical or photographic errors. Information advertised has no contractual effect.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
