2011
TACTICAL SOLUTIONS
Tactical Solutions
PROFESSIONAL SOLUTIONS
Introduction
The Petzl story begins in caves. Fernand
Petzl spent much of his life exploring
passages deep underground. At the
same time he experimented with new
vertical-progression techniques and
equipment that would go on to
revolutionize caving and allow him to
break the world depth record in the
1950s. Over the years, Petzl adapted
these tools and solutions for use in
other vertical environments, both
recreational and professional, all the
while continuing to innovate.
Today, our product-development
process remains true to a few simple
core values: keeping close to and
valuing our customers, developing
innovative and practical approaches,
and creating only the highest quality
solutions.
It is in this spirit that we’re working to
meet the needs of tactical operators.
We’ve already combined close
collaboration with operators from
around the world with Petzl’s know-how
to create smart, reliable solutions for
movement and operations in the dark
and on rope.
© John Evans
Because tactical operators rely on their
gear in the field, they make quality their
top priority. Petzl is proud to produce
quality equipment that is trusted by
operators through proven performance.
Our EXO EASHOOK and tactical
headlamp line has been built from the
ground up to meet the needs of tactical
operators and other professionals. The
following pages contain more details. Visit
www.petzl.com for more information.
2
Individual Evacuation System
EXO EASHOOK D30015 CNN - D30015 CN
Individual Evacuation System
EASHOOK anchorage connector
The Technora (aramid fiber) rope is
particularly resistant to abrasion and high
temperatures.
NEW
7.5 mm static Technora rope
Self-braking system allows the user to
control and to stop the descent at any
point. It also allows rapid horizontal
movement. In case of a fall, the device
slides on the rope and limits the force
transmitted to the user.
EXO self-braking descender
OK TRIACT-LOCK carabiner
When the system is carried in the bag, it is
very compact and can be attached directly
to the harness, ready to use.
Nomex transport bag
Larger Cordura bag with leg
and MOLLE vest attachment
systems for up to 23m (75 ft)
of rope (sold separately)
• EASHOOK anchorage connector is easy to manipulate
• Technora (aramid fiber) 7.5mm diameter static rope:
- provides greater abrasion and heat resistance than nylon or
polyester rope
• Self-braking descent control device:
- easily gives slack
- facilitates controlling and stopping a descent
- limits the force transmitted to the user in case of a shock load
• Nomex (aramid fiber) bag for transporting and attaching the
system directly to the harness
• Available in two color versions:
- black EXO with black EASHOOK and black rope
- black EXO with silver EASHOOK and tan rope
• Available in 15m (50 ft) and 23m (75 ft) rope length versions
- other lengths available on special order
• Certification: CE EN 341 type D
• Weight: 1300g
1
PROFESSIONAL SOLUTIONS
Headlamps
TACTIKKA
TACTIKKA CAMO
TACTIKKA PLUS
TACTIKKA PLUS CAMO
TACTIKKA PLUS NVG
TACTIKKA E46 P2 - E46 PC2
Compact 3 LED light with pivoting red filter
• Simple sliding on/off switch and pivoting light
- allows users to aim the beam where needed
• 120 hours burn time
• One lighting level - 26 Lumens
• Lighting distance up to 27m / 88ft
• Available in two colors:
- Black with black band (E46 P2)
- Olive drab, camouflage band (E46 PC2)
• Water resistant - IP X4
• Weight: 78g including batteries
TACTIKKA PLUS E49 P - E49 PC
Compact 4 LED light with pivoting red filter
• Push button on/off switch
• Pivoting light allows users to aim the beam where needed
• 150 hour battery life on economic mode
• Three brightness settings and the strobe function
- 35 Lumens on Maximum
• Lighting distance up to 32m / 105ft
• Available in two colors:
- Black with black band (E49 P)
- Olive drab, camouflage band (E49 PC)
• Water resistant - IP X4
• Weight: 78g including batteries
TACTIKKA PLUS E49 PNG
© John Evans
Compact 4 LED light with pivoting NVG green filter
2
• Similar features as TACTIKKA PLUS except:
- Night Vision compatible (NVG) Green filter instead of red
TACTIKKA XP CAMO
ADAPT KIT
ULTRA
TACTIKKA XP DESERT
e+LITE
ULTRA BELT
TACTIKKA XP ADAPT
TACTIKKA XP E89 PC - E89 PD
ADAPT kit for TIKKA range E86900
ULTRA E52 AC
• Push button on/off switch
• Sliding lens quickly switches from long-distance to
promixity lighting
• 120 hour battery life on economic mode
• Three brightness levels, as well as, Strobe and BOOST
- 40 Lumens on BOOST mode
• Lighting distance up to 50m / 164ft (on BOOST)
• Red, NVG-compatible Green, and Blue lenses
• Pivoting light allows users to aim the beam where needed
• Battery life indicator
• Spare lens holder
• Available in two colors:
- NATO camouflage (E89 PC)
- DESERT camouflage (E89 PD)
• Water resistant - IP X4
• Weight: 95g including batteries
• Mounting kit for the TACTIKKA, TACTIKKA PLUS, and
TACTIKKA XP
• Allows the lighting unit to be quickly detached from the
headband and mounted on:
- a MOLLE-compatible jacket / belt clip
- an adhesive universal adapter clip
• Produces a constant light output of 350 lumens
• Automatically switches to reserve mode when battery
pack is almost discharged
• High-output rechargeable Lithium-Ion batteries
• Battery charge indicator test button
• Securely held on head
• Durable construction and is storm resistant (IP 66)
• Tiltable head
• Bulbs that do not need to be replaced
• Lighting distance to 120m.
• Burn time up to 16 hrs and 55 min
• Weight: 345g
Compact headlamp with single, high-power LED
TACTIKKA XP ADAPT E89 P
Compact headlamp with single, high-power LED
with ADAPT multi-mount system
• Similar features as TACTIKKA XP along with the
following additions:
• ADAPT system allows the light to be detached from
the headband and reattached to:
- a jacket/belt clip (MOLLE System compatible)
- an adhesive universal adapter clip (both attachments
included)
• Available in black
• Weight: 120g including batteries
Multi-mount kit for TACTIKKA and ZIPKA
e+LITE E02 P2
Emergency headlamp with protective case
• 360-degree pivoting head allows users to aim the
beam where needed
• Provides plenty of light for common tasks
• Two brightness levels and a strobe for the white LEDs
• One brightness level and strobe for the red LED
• Rotating on/off switch prevents accidental operation
• Waterproof down to 1m (IP X8)
• Resistant to extreme temperatures
- -30°C to +60°C (-22°F to +140°)
• Shelf life of up to 10 years
• Can be worn on the head, around wrist or neck or
attached to thin-edged articles with integrated clip
• Burn time up to 4 nights in a row (45 hours)
• Equipped with long-range whistle on headband
• Supplied with two CR2032 batteries
• Weight: 28g (including batteries)
• 10 year guarantee
Ultra-powerful headlamp
ULTRA BELT E53 AC
Ultra-powerful headlamp with remote
rechargeable battery
• Similar features as ULTRA along with the
following additions:
• Weight on the head is reduced to a minimum with
remote battery pack, which can easily be stowed in a
pack or carried in a pocket
• Burn time up to 34 hrs and 20 min
• Weight: 495g (lamp 230g + battery 265g)
3
PROFESSIONAL SOLUTIONS
Harnesses
NAVAHO SIT
PANDION
NAVAHO BOD C710FN B
8003 C05 N
NAVAHO SIT C790FN
• Wide, semi-rigid waistbelt for excellent support
• Waistbelt and suspension seat lined with breathable
perforated foam for maximum comfort when suspended
• The ventral attachment point distributes the weight
more evenly between the waistbelt and the leg loops
during suspended work
• The two lateral attachment points transfer the weight
evenly around the waistbelt for comfort when leaning
back in the belt (with support for the feet)
• A sternal and a dorsal attachment point for connecting a
fall arrest system
• A rear attachment point on the waistbelt for connecting
a restraint lanyard
• Three equipment loops with protective sheath
• Slots for CARITOOL tool holder
• Waistbelt and shoulder straps equipped with selflocking DoubleBack buckles
• Leg loops equipped with self-locking DoubleBack buckles
• Weight: 1800 - 2000g
• Certification:
- CE EN 358, EN 361, EN 813
- ANSI Z359 1 & 3 2007
- NFPA 1983 (2006 ed.) CLASS III
- CSA Z259.10-06 CLASS A, D, P
• Chest attachment point with two gear loops
• Adjustable shoulder straps and leg loops
• Available in two sizes
• Weight: 655 - 700g
• Certification: CE EN 12277 type A
• Wide, semi-rigid waistbelt for excellent support
• Waistbelt and suspension seat lined with breathable
perforated foam for maximum comfort when suspended
• The ventral attachment point distributes the weight more evenly
between the waistbelt and the leg loops during suspended work
• The two lateral attachment points transfer the weight
evenly around the waistbelt for comfort when leaning back
in the belt (with support for the feet)
• The rear attachment point on the waistbelt allows connection
of a restraint lanyard or a TOP chest harness
• Three equipment loops with protective sheath
• Slots for CARITOOL tool holder
• Waistbelt and leg looops equipped with self-locking
DoubleBack buckles
• Available in two sizes
• Weight: 1190 - 1300g
• Certification: CE EN 358, EN 813
- NFPA 1983 (2006 ed.) Class II
®
Rope access harness
4
®
Adjustable full body harness
NAVAHO HARNESS SIZING
Size 1
27.6’’-47.2’’ Waist
19.7’’-25.6’’ Leg
5’3’’-5’11’’ Stature
Size 2
31.5’’-55.1’’ Waist
23.6’’-29.5’’ Leg
5’9’’-6’7’’ Stature
Work positioning seat harness
(CE certified to EN 361 & NFPA 1983 Class III when joined with
the TOP chest harness)
PANDION C29 N
Ultra-lightweight adjustable harness
• Wide webbing distributes the load effectively
• Waist belt & leg loops are equipped with DoubleBack buckle
• One gear loop
• One size fits all
• Weight: 290g
• Certification: CE / UIAA
FALCON
SECUR
TOP
NEW
FALCON MOUNTAIN
FALCON C38AAN
TOP C81000
• Waistbelt and leg loops lined with breathable perforated
foam for maximum comfort and mobility
• The ventral attachment point distributes the weight more
evenly between the waistbelt and the leg loops
• Two textile lateral attachment points (for occasional use)
• Textile rear attachment point on the waistbelt for
connecting a restraint lanyard
• Rear attachment buckle for attaching the TOP or chest
harness to be attached when winching a load up to a
helicopter or for transforming the FALCON into a ropeaccess harness
• Waistbelt and leg loops equipped with two self-locking
DoubleBack buckles
• Four equipment loops
• Two slots for CARITOOL tool holder
• Available in two sizes
• Weight: 810-880g
• Certification: CE EN 358, EN 813
• Transforms the NAVAHO SIT seat harness into fall arrest harness
• Joins rear buckle and connects to ventral attachment point
• Sternal attachment point for connecting a fall arrest system
• No dorsal attachment point to get in the way of a bag or
load on the back
• Shoulder straps equipped with self-locking DoubleBack buckles
• Available in two sizes
• Weight: 585 - 635g
• CE certified to EN 361 & NFPA 1983 Class III when
joined with the NAVAHO SIT harness
Lightweight seat harness for rescue
FALCON MOUNTAIN C38CAA
Seat harness for mountain rescue
• Waistbelt and leg loops lined with breathable perforated
foam for maximum comfort
• Attachment bridge construction for optimum mobility
when progressing with climbing techniques
• Two textile lateral attachment points (for occasional use)
• Textile rear attachment point on the waistbelt for
connecting a restraint lanyard
• Waistbelt and leg loops equipped with two self-locking
DoubleBack buckles
• Four equipment loops
• Two slots for CARITOOL tool holder
• Available in two sizes
• Weight: 795-830g
• Certification: CE EN 358, EN 813, EN 12277 type C
DOG HARNESS
CHESTER
Chest harness for seat harness
CHESTER C64
Chest harness for seat harness
• Transforms the NAVAHO SIT into a fall arrest harness
when connected to the ventral attachment point of the
seat harness
• Sternal attachment point for connecting a fallarrest system
• Shoulder straps and chest strap equipped with selflocking DoubleBack buckles
• One size fits all
• Weight: 600g
• Certification: CE EN 12277 type D
SECUR
C74
Shoulder straps
• Adjustable shoulder straps designed to support a Croll
ascender or ventral rope clamp for ascending a rope
• Attaches via a girth hitch to the rear ring or waistbelt of
a sit harness
• One size fits all
• Weight: 120g
DOG HARNESS C99H
Harness for airlifting a dog
• Lightweight and compact harness
• Allows the dog to function normally while wearing it
• Designed for airlifting and using lanyards during
a search
• Numerous settings adapt to different canine shapes
and sizes
• Prepositioned elastic allows the harness to be easily
adjusted on the dog
• Removable foam makes maintenance easy
• Weight: 890g
5
PROFESSIONAL SOLUTIONS
Descenders
Belaying
Descent
Panic brake
Lock-off
Store
The I’D S descender's multi-function
handle allows the user to control the
descent and to get into position at the work
station. It also has an anti-panic function
that is engaged if the user pulls too hard
on the handle.
I’D S D200SN
The button on the multi-function handle
facilitates smooth movement along lowangle or horizontal terrain.
© John Evans
Self-braking descender with anti-panic function
6
• Multi-functional handle allows the user to:
- unblock the rope and control the descent with the
hand on the free end of the rope
- move more easily on horizontal or low-angle terrain
thanks to the button on the handle
- position himself while on the rope without tying off the device
• Anti-panic function is engaged if the user pulls too
hard on the handle: the pivoting cam is released and
automatically brakes to stop the descent
• Anti-error safety catch to reduce the risk of an accident due
to incorrect installation of the device on the rope. The shape
of the cam is designed to improve rope glide when ascending
• The safety gate on the moving side plate helps prevent
dropping the device and facilitates installation of the
rope and passing intermediate anchors
• Pivoting cam facilitates taking up the slack in the rope.
Can also be used to make a reversible haul system,
and for short ascents (in conjunction with a FOOTPRO
foot loop and an ASCENSION handled rope clamp)
• A screw (into the back of the device) allows the
moving side-plate to be locked so that the I’D S can be
part of a rescue kit
• For ropes between 10 and 11.5mm in diameter
• Certification: - CE EN 341 Class A,
- CE EN 12841 type C,
- NFPA 1983 Light Use
• Individually tested
• Weight: 530g
NEW
REVERSO3
GRIGRI2
PIRANA
The spring loaded handle
returns to the belay
Belay
position
Descent
Lock
Store
The RIG
descender's
multi-functional
handle allows the
user to control
the descent
and to get into
position at the
work station.
The automatic
return system on
the handle limits
risks in case of an
involuntary action
by the user.
RIG D21AN
Compact self-braking descender
• Designed for experienced rope access and rescue workers
• Multi-functional handle allows the user to:
- unblock the rope and control the descent with the
hand on the free end of the rope
- position himself while on the rope without tying off
the device
• The automatic return system on the handle limits risks
in case of an involuntary action by the user
• Handle storage position reduces the risk of snagging
when the descender is being carried on the harness
• The safety gate on the moving side plate helps prevent
dropping the device and facilitates installation of the
rope and passing intermediate anchors
• Pivoting cam facilitates taking up the slack in the rope
• Can also be used to make a reversible haul system,
and for short ascents (in conjunction with a FOOTPRO
foot loop and an ASCENSION handled rope clamp)
• For single ropes between 10.5 and 11.5mm in diameter
• Certification: - CE EN 12841 type C, CE EN 341 class A,
- NFPA 1983, Light Use
• Individually tested
• Weight: 380g
STOP
HUIT ANTIBRULURE
GRIGRI2 D14 2G
REVERSO3 D17 T
• Cam pivots to pinch rope if the rope suddenly comes
under tension (e.g. in a fall), thus helping the belayer
stop the climber’s fall
• Cam design allows excellent control during descent
• Can be used as a descender and positioning device
• For ropes of diameters from 8.9 to 11mm
• Weight: 185g
• Certification: CE
• Acts as a traditional belay rappel device
• Also offers the added versatility of being able to belay
one or two seconds with its self-braking feature
• Won’t twist ropes during rappel
• Weight: 72g
Assisted-braking belay device / single rope
descender
STOP D09 NOI
Self-braking descender
• For vertical descents
• Will not twist or kink the rope
• For single ropes of 10 -11mm diameter
• Weight: 326g
• Individually tested
• Certification: CE EN 341 class A
Belay / rappel device with self-braking function
for belaying the second
PIRANA D05 NOI
Descender for single or double rope
• Before starting the descent, the user can choose
between 3 different friction settings
- two cleats allow speed control during descent
• Rope installation method is very rapid
- helps prevent dropping the descender
- avoids girth hitch formation
• Tight interface between the PIRANA and the carabiner
doesn’t break noise discipline
• For single ropes of 8-13mm diameter
• Weight: 90g
• Individually tested
HUIT ANTIBRULURE D01
Square-shaped figure-8 descender
• Square shape to reduce kinking the ropes and
formation of a girth hitch
• Compact and lightweight
• Anti-burn tab helps avoid burning the fingers after a rappel
• For single and double ropes between 8 and 13mm
in diameter
• Weight: 110g
7
PROFESSIONAL SOLUTIONS
Ascenders
ASCENSION B17WRN - B17WLN
Handled ascender: right- and left-handed versions
The molded dual-density grips have an
area for the index finger and a wide,
supportive base to keep the hand from
slipping. This shape ensures a comfortable
and powerful grip, increasing efficiency
when ascending a rope.
RESCUCENDER
MICROCENDER
The safety catch on frame-loaded rope
clamps allows them to be installed or
removed with one hand at any point on the
rope. It can be easily manipulated, even
with gloves.
ASCENSION
TIBLOC
RESCUCENDER B50
• Designed for ascending and occasionally for hauling
(progress capture)
• Wide, ergonomic molded handle allows a comfortable
yet powerful grip
• Toothed cam with self-cleaning slot optimizes performance
under many conditions (e.g. frozen or dirty ropes)
• Lower holes for connecting a SPELEGYCA lanyard and
installing a FOOTPRO foot loop with a quick link
• Upper connection hole for creating a pulley/rope clamp
combination or for guiding the rope
• Comes in left-handed and right-handed versions:
- ASCENSION (B17 WRN): right-handed
- ASCENSION (B17 WLN): left-handed
• For single ropes between 8 and 13mm in diameter
• Certification:
- CE EN 567
- CE EN 12841 type B
- NFPA 1983 Light Use
• Weight: 195g
Cam-loaded rope clamp
• Removable axle can be used to install or remove the
clamp at any point on the rope
• Locking pin: reduces the risk of undoing the system
accidentally
• Designed for hauling heavy loads or as a progresscapture device
• Curved cam interface can act as a load limiter
• For single ropes between 9 and 13mm in diameter
• Certification: CE EN 567
• Weight: 250g
MICROCENDER B54
Compact cam-loaded rope clamp
• Lightweight and compact
• Removable axle can be used to install or remove the
clamp at any point on the rope
• Locking pin: reduces the risk of undoing the system
accidentally
• Designed for hauling or self-protection on fixed ropes
• Curved cam interface can act as a load limiter
• For single ropes between 9 and 13mm in diameter
• Certification: CE EN 567
• Weight: 160g
FOOTPRO C49
TIBLOC B01
• Can be attached to the ASCENSION handle for
rope ascents with included SPEEDY maillon
• Easily adjustable with the DoubleBack buckle
• Underfoot strap is abrasion-resistant and is easy
to step into
• Weight: 135g
• Lightweight emergency ascender
• Inclined teeth and self-cleaning slots to provide grip on
wet, icy or muddy ropes
• For use with single rope from 8 to 11mm in diameter
• Weight: 39g
• Certification: CE EN 567
Adjustable webbing foot loop
8
Emergency ascender/rope grab
Helmets
IMPROVED
VERTEX VENT A10VNA
®
Comfortable ventilated helmet for
work at height and rescue
• Six-point mesh liner conforms to the
shape of the head for improved comfort.
• Shock absorption achieved through
deformation of the outer shell.
• CenterFit adjustment system ensures
centering and optimal stability of the
helmet on the head
• Ventilation holes with sliding shutters
allow the ventilation to be adjusted as
needed from the outside
• Side slots for mounting hearing protection
• Inserts for accepting a VIZIR face shield
• Slot for mounting a PIXA headlamp
• Four clips for mounting a headlamp with
an elastic headband
• Chin strap designed to limit risk of losing
helmet during a fall (strength greater
than 50 daN)
• Size: 53-63cm / 20.9 in - 24.8 in
• Weight: 455g / 16 oz
• Certification:
- CE EN 12492*
- UIAA
- ANSI Z89.1-2009 Type I Class C
* Meets the requirements of the EN 397
and EN 12492 standards for protection
against impact.
Meets the optional requirements of the
EN 397 standard for lateral deformation
and use in low temperatures.
IMPROVED
VERTEX BEST A10BNA
Comfortable helmet for work at
height and rescue
• Six-point mesh liner conforms to the
shape of the head for improved comfort.
• Shock absorption achieved through
deformation of the outer shell.
• CenterFit adjustment system ensures
centering and optimal stability of the
helmet on the head
• Side slots for mounting hearing protection
• Inserts for accepting a VIZIR face shield
• Slot for mounting a PIXA headlamp
• Four clips for mounting a headlamp with
an elastic headband
• Chin strap designed to limit risk of losing
helmet during a fall (strength greater
than 50 daN)
• The helmet’s unventilated shell protects
against electrical hazards and molten
metal splash
• Size: 53-63cm / 20.9 in - 24.8 in
• Weight: 455g / 16 oz
• Certification:
- CE*
- ANSI Z89.1-2009 Type I Class E
* Meets the requirements of the EN 397
and EN 12492 standards for protection
against impact.
Meets the requirements of the EN 397 and
EN 50365 standards for electrical insulation.
Meets the optional requirements of the EN 397
standard for molten metal splash, lateral
deformation and use in low temperatures.
NEW
VIZIR A15
Protective face shield for VERTEX
helmets
• Easy to mount on VERTEX helmets with
purpose-built inserts
• Two positions:
- raised on top of helmet
- lowered in working position
• Scratch- and fog-resistant
• Weight: 60g
• Certification:
- CE EN 166, Particles at medium speed
- ANSI Z87.1-2003
NEW
Transparent stickers
A10100
• Page of 36 transparent stickers for
personalizing VERTEX helmets
Reflective stickers A10110
• Page of four pre-cut reflective stickers
for increased visibility
• For VERTEX helmets
Absorbent foam A10200
• Comfort foam absorbs perspiration
• Machine washable
• For VERTEX helmets
• Weight: 15g
Standard replacement
foams A10210
• Replacement foams do not absorb
perspiration
• Easy maintenance
• For VERTEX helmets
• Weight: 15g
9
Rope & Rope Accessories
VECTOR 12.5 r12
PROFESSIONAL SOLUTIONS
®
Low-stretch rope for rescue teams
VECTOR 11 r11
®
Low-stretch rope designed for
difficult to access environments
and for fall protection
RESCUE CORD R846/R892
8mm low-stretch rope designed
primarily for tying Prusik hitches on
VECTOR 11 & VECTOR 12.5 ropes
®
®
STANDARD ROPE BAG
ROPE BUCKET
CORDEX PLUS BLACK
VECTOR 12.5
®
VECTOR 11
®
consistent
performer with
Prusiks and
friction devices
• Fusion Process™ helps maintain the rope’s
shape and gives it excellent handling
with nylon core & polyester sheath
• Available in six colors for easier
identification of different kits
• Standard lengths:
- 46m / 150 ft: white (R1246 W)
- 46m / 150 ft: red (R1246 R)
- 46m / 150 ft: blue (R1246 B)
- 46m / 150 ft: yellow (R1246 Y)
- 46m / 150 ft: orange (R1246 O)
- 61m / 200 ft: white (R1261 W)
- 61m / 200 ft: red (R1261 R)
- 61m / 200 ft: blue (R1261 B)
- 61m / 200 ft: yellow (R1261 Y)
- 61m / 200 ft: orange (R1261 O)
- 183m / 600 ft: white (R12183 W)
- 183m / 600 ft: red (R12183 R)
- 183m / 600 ft: blue (R12183 B)
- 183m / 600 ft: yellow (R12183 Y)
- 183m / 600 ft: orange (R12183 O)
- 183m / 600 ft: black (R12183 N)
- 366m / 1200 ft: white (R12366 W)
- 366m / 1200 ft: black (R12366 N)
• MBS : 9,000 lbf (40.1kN)
• Weight: 7.7 lb/100 ft
• Certification:
- NFPA 1983 General Use (static ropes)
10
• Fusion Process™ helps maintain the rope’s
shape and gives it excellent handling
• Available in four colors for easier
identification of different kits
• Standard lengths:
- 46 m / 150 ft: white (R1146 W)
- 46 m / 150 ft: red (R1146 R)
- 46 m / 150 ft: blue (R1146 B)
- 46 m / 150 ft: black (R1146 N)
- 61 m / 200 ft: white (R1161 W)
- 61 m / 200 ft: red (R1161 R)
- 61 m / 200 ft: blue (R1161 B)
- 61 m / 200 ft: black (R1161 N)
- 183 m / 600 ft: white (R11183 W)
- 183 m / 600 ft: red (R11183 R)
- 183 m / 600 ft: blue (R11183 B)
- 183 m / 600 ft: black (R11183 N)
- 200 m / 656 ft: white (R11200 W)
- 200 m / 656 ft: black (R11200 N)
- 366 m / 1200 ft: white (R11366 W)
- 366 m / 1200 ft: black (R11366 N)
• MBS : 7,000 lbf (31.2kN)
• Weight: 6 lb/100 ft
• Certification:
- NFPA 1983 Light Use (static ropes)
rescue cord
consistently
produced
the shortest
stopping
distances with
VECTOR® in
tandem Prusik
belay
• Excellent performance when belaying
with the Tandem Prusik technique
• Also used for personal escape and
anchoring rope
• Available in four colors for easier
identification of different kits
• Standard lengths:
- 46m / 150 ft: red (R846 R)
- 46m / 150 ft: orange (R846 O)
- 46m / 150 ft: green (R846 G)
- 46m / 150 ft: black (R846 N)
- 92m / 300 ft: red (R892 R)
- 92m / 300 ft: orange (R892 O)
- 92m / 300 ft: green (R892 G)
- 92m / 300 ft: black (R892 N)
• Weight: 3.3 lb/100 ft
• Certification:
- NFPA 1983 Escape (static ropes)
CORDEX BLACK
STANDARD ROPE BAG R40 N
Heavy-duty handled rope bag
• Ergonomic handled bag that will hold up
to 200 feet of ½’’ rope.
• Single shoulder strap and rope log window
• Weight: 400g
ROPE BUCKET R41 N / R41XL N
Foam-lined rope bag
• A sturdy bag for up to 200 ft of ½’’ rope
(standard size) or 600 ft of 11mm rope
(XL size)
• Foam lining keeps bag open for easy
deployment & stuffing. Single shoulder
strap and rope log window
• Weight: 500g (standard) / 1181g (XL)
CORDEX PLUS K53 N
Rigging and rappel gloves
• Durable double layer of natural, high quality
leather in high-wear areas (fingertips,
palm, between thumb and index finger)
• Back is made of durable leather with
abrasion-resistant stretch nylon at key
flex areas
• Sizes: S - XL
• Weight: 150g
• Certification: EN 420, EN 388, 4143
CORDEX K52 N
Lightweight belay/rappel gloves
• Natural, high-quality leather
• Durable double layer of leather in highwear areas (fingertips, palm, between
thumb and index finger)
• Sizes: S - XL
• Weight: 140g
• Certification: EN 420, EN 388, 4142
Pulleys
PAW S
ø ≤ 13 mm
FIXE
PAW M
ø ≤ 13 mm
RESCUE
PAW L
ø ≤ 13 mm
FIXE P05W
Versatile compact pulley
• Fixed side plates allow quick installation
and coupling with a rope clamp
• Designed for hauling systems and deviations
• 21mm sheave sheave mounted on selflubricating bushings for efficiency (71%)
• Safe working load: 5kN
• MBS: 22kN
• Weight: 90g
• Certification: CE EN 12278
RESCUE P50A
High strength, high efficiency pulley
• For rescue professionals
• Designed to maneuver heavy loads or for
intensive use
• 38mm aluminum sheave mounted on sealed
ball bearings for excellent efficiency (95%)
• Accepts up to three carabiners to facilitate use
• Safe working load: 8kN (4kN on one rope end)
• MBS: 36kN
• Weight: 185g
• Certfication: - CE EN 12278
- NFPA 1983 (2006 ed.) General Use
MINI TRAXION P07
Compact, lightweight progress
capture pulley
• Lightweight self-lubricating pulley (71%
efficiency) with integrated toothed cam:
- works on dirty or icy ropes
- cam is easily triggered and can be locked
in open position for use as a simple pulley
• For use with ropes from 8 to 13mm
• Safe working load of pulley: 5kN
• Safe working load of progress capture: 2.5kN
• MBS: 20kN
• Weight: 165g
• Certification: CE EN 567, EN 12278
SWIVEL SMALL
PAW P63
Rigging plate
• For easy organization of the work
area and for creating multiple
anchor systems
• 19mm holes allow the locking sleeves
of most carabiners to pass through
• Made of aluminum: excellent strengthto-weight ratio
• Breaking strength: 36kN
• Available in three sizes:
- PAW S (P63 SN): small (weight: 55g)
- PAW M (P63 MN): medium (weight: 210g)
- PAW L (P63 LN): large (weight: 350g)
• Certification: CE EN 0197
- NFPA 1983 General Use
SWIVEL P58 S
Ball bearing swivel
• Prevents the rope from twisting when the
load is turning
• Excellent performance and reliability due
to maintenance-free sealed ball-bearings
• Compact
• Breaking strength: 23kN
• Weight: 95g
• Certification: CE
© Justin Roth
MINI TRAXION
11
Connectors
PROFESSIONAL SOLUTIONS
NEW
NEW
WILLIAM SCREW-LOCK
AM’D SCREW-LOCK
WILLIAM TRIACT-LOCK
AM’D TRIACT-LOCK
OXAN SCREW-LOCK
VULCAN SCREW-LOCK
OXAN TRIACT-LOCK
VULCAN TRIACT-LOCK
ATTACHE SCREW-LOCK
FREINO
VULCAN M73 SLN - M73 TLN
OXAN M72 SLN - M72 TLN
WILLIAM M36 SLN - M36 TLN
Am’D M34 SLN - M34 TLN
• Steel adapted to difficult use conditions
• For use with heavy loads
• Large size allows easier connection of
multiple elements
• Wide opening for connection to thick anchors
• Keylock system helps prevent snagging of
the carabiner during maneuvers
• Red indicator provides a visual warning
when the carabiner is unlocked (on
SCREW-LOCK version)
• Two locking systems available:
- VULCAN (M73 SLN): SCREW-LOCK
- VULCAN (M73 TLN): TRIACT-LOCK
• Major axis MBS: 40kN
• Minor axis MBS: 16kN
• Open gate MBS: 11kN
• Weight: 265g (M73 SLN), 330g (M73 TLN)
• Certification (M73 SLN):
- CE EN 362
- NFPA 1983 General Use
• Certification (M73 TLN):
- CE EN 362
- NFPA 1983 General Use
- ANSI Z359.1
- CSA Z259.12
• Steel adapted to difficult use conditions
• Keylock system helps prevent snagging of
the carabiner during maneuvers
• Red indicator provides a visual warning
when the carabiner is unlocked (on
SCREW-LOCK version)
• Two locking systems available:
- OXAN (M72 SLN): SCREW-LOCK
- OXAN (M72 TLN): TRIACT-LOCK
• Major axis MBS: 27kN
• Minor axis MBS: 16kN
• Open gate MBS: 7kN
• Weight: 250g
• Certification (M72 SLN):
- CE EN 362
- NFPA 1983 Light Use
• Certification (M72 TLN):
- CE EN 362
- NFPA 1983 Light Use
- ANSI Z359.1
- CSA Z259.12
• Large size and opening to allow easy
anchoring of several ropes and slings
• Wide pear shape facilitates belaying
with a Munter hitch
• Keylock system helps prevent snagging
of the carabiner during maneuvers
• Available in two different locking systems:
- WILLIAM (M36 SLN): SCREW-LOCK
- WILLIAM (M36 TLN): TRIACT-LOCK
• Major axis MBS: 25kN
• Minor axis MBS: 7kN
• Open gate MBS: 7kN
• Weight: 90g
• Certification: CE EN 362, EN 12275 type B & H
• Specifically adapted for connection of
equipment and use at the end of a lanyard
• Excellent strength-to-weight ratio
• Keylock system helps prevent snagging
of the carabiner during maneuvers
• Available in two different locking
systems:
- Am’D (M34 SLN): SCREW-LOCK
- Am’D (M34 TLN): TRIACT-LOCK
• Major axis MBS: 28kN
• Minor axis MBS: 7kN
• Open gate MBS: 8kN
• Weight: 75g
• Certification: CE EN 362, EN 12275 type B & K
High-strength steel locking carabiner
12
Steel symmetric locking carabiner
Large capacity aluminum carabiner
Asymmetrical aluminum carabiner
ATTACHE SCREW-LOCK M35 SLN FREINO M42
Manual locking carabiner
• Compact HMS carabiner with manual
screw-gate locking system
• Visual indicator shows unlocked gate
• Ideal for use with the PIRANA descender
• Keylock system
• Major axis MBS: 23kN
• Minor axis MBS: 7kN
• Open gate MBS: 6kN
• Weight: 80g
• Certification: CE EN 362, EN 12275 type H
Carabiner with friction spur
• The spur helps increase friction:
- during rappels or lowers
- to improve control with heavy loads
• TWIST LOCK automatic locking sleeve,
unlocked by a simple rotation
• Keylock system helps prevent snagging
of the carabiner during maneuvers
• Used, for example, with the I’D and RIG
self-braking descenders
• Major axis MBS: 25kN
• Minor axis MBS: 10kN
• Open gate MBS: 9kN
• Weight: 75g
• Certification: CE EN 362, EN 12275 type B & K
Connectors and Mountain Operations
VASAK
OK SCREW-LOCK
AZTAREX ADZE
SUMMIT
LASER SONIC
OK TRIACT-LOCK
SPIRIT STRAIGHT GATE
AZTAREX HAMMER
OK M33 SLN - M33 TLN
SUMMIT U13 52 / 59 / 66
• Versatile oval symmetric shape for
optimal positioning of equipment
(pulleys, rope clamps, mobile fall
arresters, etc.)
• Ideal for hauling
• Keylock system helps prevent snagging
of the carabiner during maneuvers
• Available in two different locking systems:
- OK (M33 SLN): SCREW-LOCK
- OK (M33 TLN): TRIACT-LOCK
• Major axis MBS: 24kN
• Minor axis MBS: 10kN
• Open gate MBS: 7kN
• Weight: 75g
• Certification: CE EN 362, EN 12275 type B & K
• Classic modern mountaineering ice axe
• Rubber coated shaft for excellent grip
and versatility
• Curved shaft allows the necessary
clearance on steep or icy terrain
• Hot-forged chromoly steel pick is curved
for solid purchase in ice and soft snow
• Available in three sizes:
- 52cm: U13 52 (495g)
- 59cm: U13 59 (535g)
- 66cm: U13 66 (570g)
• Type B axe
• Certification: CE EN 13089, UIAA
Oval aluminum carabiner
SPIRIT M15
Non-locking progression carabiner
• Non-locking, clips easily
• Keylock system helps prevent snagging
of the carabiner during maneuvers
• Major axis MBS: 25kN
• Minor axis MBS: 10kN
• Open gate MBS: 9kN
• Weight: 75g
• Certification: CE EN 362, EN 12275 type B & K
LASER
SUM’TEC
Mountaineering Axe
SUM’TEC U15 52 / 59
Lightweight Mountaineering Axe
• Lightweight, technical, classic
mountaineering ice axe
• Easily interchangeable re-curve, tapered
pick for solid placements on hard ice
• Adjustable TRIGREST allows for
maximum versatility on varied terrain:
- by placing it in upper position, shaft is
free to penetrate the snow
- in lower position, it makes for improved
grip, facilitating progress in steep sections
• Available in two sizes:
- 52cm: U15 52 (485g with TRIGREST)
- 59cm: U15 59 (505g with TRIGREST)
• Type T shaft / Type B pick
• Certification: CE EN 13089, UIAA
AZTAREX U11 P / U11 M
VASAK FLEXLOCK
climbing axe
• Comfortable to use, even leashless, due
to GRIPSWITCH hand rest
• High performance swing due to minimal
weight at rotation point
• GRIPSWITCH hand rest can be removed
and inserted into the axe handle for use
in piolet-canne mode and in hard snow.
• Two models available:
stability and traction
• Made from hardened chromoly steel
• Durable and lightweight
• Adjusts quickly without tools
• Comes with Antisnow plates
• Weight: 900g
• Certification: CE, UIAA
Technical mountaineering ice tool
• Versatile mountaineering and ice
AZTAREX P U11 P
Ice axe with adze
• Length: 50cm
• Weight: 500g
• Type B shaft / Type B pick
• Certification: CE, UIAA
AZTAREX M U11 M
Ice axe with hammer
• Length: 50cm
• Weight: 500g
• Type B shaft / Type B pick
• Certification: CE, UIAA
T05FL 02
Mountaineering crampons
• A versatile crampon that optimizes
LASER P71
High performance ice screw
• Aggressive teeth penetrates easily
• Placement possible with one hand
• Polished surface enables smooth placement
• Length:10cm Weight: 128g
13cm
146g
17cm
164g
21cm
184g
• Certification: CE, UIAA (except 10cm)
LASER SONIC P70
Ice screw with rotating hanger
• Rapid placement and removal with
integrated hanger / crank handle
• Similar features as LASER ice screws
• Length: 10cm
Weight: 149g
13cm
165g
17cm
185g
21cm
205g
• Certification: CE, UIAA (except 10cm)
13
Z33 ENG 2011 - USA
For more information on Petzl’s Tactical Solutions, please go to:
www.petzl.com/tactical
© Justin Roth
Distributed by:
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
