All-Purpose Light
Light is also indispensable for the „photographic“ vision. If natural light is not
sufficient or does not lead to the desired
result, „artificial“ light sources come
into operation.
But the nature of this light is no longer
„artificial“. There are many light sources that provide daylight or can be
adapted to daylight using conversion
filters. Using specific type of film, but
above all the features and possibilities
of digital cameras, also allow for an
adaptation to „natural light conditions“.
When shooting specific objects the
requirements for lighting may be complete opposites.
Light can be soft and even sometimes,
while it can be harsh and strong other
times, should avoid shadows or create
shadows, should highlight edges or
avoid reflections, should be directed to
places difficult to access, should eventually be heat free or be „subjectfriendly“ in other ways - the list of
requirements could go on and on.
The lamps themselves - their size,
shape and technology - as well as the
lighting units they are used in, determine one part of the illumination result,
the other part is controlled by the position and the set-up of the lights, and is
therefore based on the knowledge and
skills of the „lighting technician“.
Using flash makes high demands on
the experience of the photographer.
With continuous light sources as presented in this catalog the illumination
can be evaluated precisely before
shooting, because set-up and shooting
use the same light.
26
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 27
Soft Lights normally provide for very
soft and even lighting. They are especially useful with object photography with
shadowless illumination. They are
equipped with daylight-type fluorescent
lamps and can also be supplied for
high-frequency operation. That is why
they can be used with all kinds of digital cameras without any limitations,
also with scanning cameras, and that
is why they are often called „digital
light“. They can also be used in video
applications and in connection with
high-speed cameras. Their light is cool
so there is only a minor thermal load
on the object. All this, together with the
long service life of fluorescent lamps,
allows for extended operating times
and long shooting sessions and therefore high performance. Color rendition
remains constant over a long period of
time and power consumption is rather
low.
Halogen lights have high light output
and can cover wide spaces. Their light
is harsh and contrasty and you can
deliberately intensify contrast and shadows. In addition their light is „hot“.
That is why in most cases lighting units
are equipped with an extra cooling fan.
Lighting Units for Photo & Video
Halogen lighting units though are very
compact and light-weight, they are
easy to carry and are suitable for use
„on location“.
Lamps with screw-in thread, commonly
known as photofloods, have been around
for many years. They are used in
reflector lights, the reflector itself can
be fixed or exchangeable. The character of illumination is determined by the
shape and the surface of the reflector.
The universal E27 screw-in socket
accepts a variety of lamps: traditional
photofloods, halogen lamps (e.g.
CERAM) and fluorescent lamps.
If you have to photograph very small
objects, halogen spots are extremely
useful. They can be targeted to the
object or just a part of it with the help
of flexible gooseneck arms.
Close-up photography and photomicrography are the application fields
of cold light sources using flexible
fiber-optic light guides to get light
exactly to a specific area.
27
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 28
„proVision“ Soft Light
For even and soft illumination, especially suitable for digital photography and video shooting.
Fitted with 55 watt daylight fluorescents with
very low heat radiation. High-frequency operating system (approx. 40 kHz) for immediate
ignition and flicker-free operation for unrestricted use with all digital camera systems
including scanning cameras and scanbacks. High-gloss reflectors and intensifier
barn doors for exceptionally high lighting efficiency. Light output can be dimmed down to
10% of maximum. Compact aluminum housing. Light is tiltable, with mounting frame for
suitable stands/holding devices with 16 mm
standard spigot.
Color temperature: 5400 K (3200 K on
request)
Service life of lamps: approx. 8000 h
CRI: 90-100
3431 proVision 6.55 HF
Lamps: 6 x 55 watt, 5400 K
4 barn doors, cable remote control (3m/10 ft.)
for dimming.
Illuminating surface: 51 x 51 cm (20 x 20 in.)
Weight: 8.6 kg (18.9 lbs.)
3428 proVision 4.55 HF
Lamps: 4 x 55 watt, 5400 K
4 barn doors, cable remote control (3m/10 ft.)
for dimming.
Illuminating surface: 34 x 51 cm (13.4 x 20 in.)
Weight: 6.7 kg (14.8 lbs.)
3425 proVision 2.55 HF
Lamps: 2 x 55 watt, 5400 K
2 barn doors, dimmer on lighting unit.
Illuminating surface: 17 x 51 cm (6.7 x 20 in.)
Weight: 4.4 kg (9.7 lbs.)
3454/64 Fluorescent Lamp
Replacement lamp for 3425/3428/3431.
1 piece.
3454: 55 W, light color 12, approx. 5400 K
3464: 55 W, light color 32, approx. 3200 K
28
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
3433-35
Diffusion Screen
Seite 29
For use with „proVision“ soft lights.
Prismatic surface. 1 piece.
3433: for proVision 2.55 HF (3425)
3434: for proVisoin 4.55 HF (3428)
3435: for proVision 6.55 HF (3431)
3436-38
Soft Screen
For use with „proVision“ soft lights.
Frosted surface. 1 piece.
3436: for proVision 2.55 HF (3425)
3437: for proVisoin 4.55 HF (3428)
3438: for proVision 6.55 HF (3431)
3439
Diffusion Foil
For use with „proVision“ soft lights.
Can be cut to required size.
Dimensions: approx. 60 x 760 cm (2 x 25 ft.)
Lighting Units for Photo & Video
29
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 30
93325
„videolight 4“
Safety Lighting Unit
Technical data:
Halogen lamps:
Fuses:
Cord:
Weight:
2 x 1000 W, 3400 K
2 x F 6.3 A
4 m (13ft. 1 in.)
approx. 1500 g
(3 Ibs. 5 oz.)
Dimensions (handle approx. 145 x 155
folded down):
x 190 mm
(WxHxD):
(5.7 x 6.1 x 7.5 in.)
Height with handle: approx. 270 mm
(10.6 in.)
3075
3029
Conversion Filter
3094
93304
„videolight 6“
Safety Lighting Unit
Technical data:
Halogen lamp:
Fuse:
Cord:
Weight:
1000 W, 3400 K
F 6.3 A
4 m (13 ft. 1 in.)
approx. 1300 g
(2 Ibs. 14 oz.)
Dimensions (with
approx. 100 x 140
handle folded down): x 190 mm
(3.9 x 5.5 x 7.5 in.)
Height with handle: approx. 250 mm
(10 in.)
3075
3094
30
3002
Conversion Filter
Halogen lighting unit for photo, filming and
video shooting. Extremely quiet blower cooling for unlimited operation in every position.
Four large light flaps for direct-aim lighting.
Front attachment with diffusor screen of
heat-resistant safety glass for extra-soft
lighting.
The upper part can be tilted steplessly for
indirect lighting. The handle can be tilted
through 180° and when mounted on a tripod
assumes the function of a tilting head. For
economical storing, the handle folds snugly
onto the housing. Two stand threads 1/4“.
The lamps can be switched on separately
and have their own fuses. Additional switch
for modelling light (2 x 500 W). Supplied
complete with camera bracket and lamps.
Complete safety front attachment with light
flaps and conversion filter of safety glass for
videolight 4 (93325).
Dimensions (W x H x D): approx. 145 x 135
x 70 mm (5.7 x 5.3 x 2.8 in.)
Halogen lighting unit for photo, filming and
video shooting. Extremely quiet blower cooling for unlimited operation in every position.
Thermostat for automatic shut-off if overheating. Heat-resistant housing. Front attachment with safety-glass diffuser plate for
extra-soft lighting. Four large barn doors for
direct-aim lighting.
The upper part can be tilted steplessly for
indirect lighting. The handle can be tilted
through 180° and when mounted on a tripod
assumes the function of a tilting head. The
unit can then be tilted upward and downward. For economical storing, the handle
folds snugly onto the housing. Two stand
threads 1/4“. Supplied complete with lamp
and camera bracket.
Complete safety front attachment with light
flaps and conversions filter of safety glass for
videolight 6 (93304). Dimensions
(WxHxD): approx. 105 x 125 x 70 mm
(4.1 x 4.9 x 2.8 in.).
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
93307
„videolight 8 S“
Safety Lighting Unit
Seite 31
Halogen lighting unit for photo, filming and
video shooting. Unlimited continuous operation without extra cooling. Four barn doors.
Front attachment with diffuser made of
safety glass. Temperature-resistant reflector
casing, for indirect lighting tilts upward by
90° with five click-stops. Slot shoe for
mounting on camera. Thread 1/4“ for mounting on stand. On/off switch.
Technical data:
Halogen lamp:
Fuse:
Cord:
Weight:
Dimensions
(WxHxD):
93318
Conversion Filter
300 W, 3400 K
F2A
4 m (13 ft. 1 in.)
approx. 690 g (1 Ib. 8 oz.)
approx. 87 x 164 x 135 mm
(3.4 x 6.5 x 5.3 in.)
Safety front attachment with barn-doors and
safety glass conversion filter for videolight 8 S
(93307).
Dimensions: approx. 87 x 87 x 75 mm
(3.4 x 3.4 x 3 in.)
93392
„videolight 150“
Safety Lighting Unit
3058
3038
Halogen lighting unit for photo, filming and
video shooting. Unlimited continuous operation without extra cooling. Four barn doors
to direct the beam. Variable focusing: The
angle of light emersion can be adjusted continuously from 40° to 90°. Two mounting
possibilities: either flat on the housing - the
light tilts by 25° - or raised on pivoting
bracket. In this position the light can be tilted
upwards and downwards by a total of 100°.
1/4” tripod thread. On/off switch.
Technical data:
Halogen lamp: 150 W, 3400 K
Fuse:
F2A
Cord:
approx. 4 m (13 ft. 1 in.)
Weight:
approx. 600 g (1 lb. 5 oz.)
Dimensions
approx. 66 x 145 (100) x 125
(WxHxD):
mm (2.6 x 5.7 (3.9) x 4.9 in.)
93391
Conversion Filter
Complete attachment with light flaps and
conversion filter for „videolight 150“ (93392).
3003
Lighting Units for Photo & Video
31
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 32
93356
„Mini“ Portable Lighting Kit
Consisting of 300 W video light „videolight 8 S“
(93307), clamp (1512), reflector/shootthrough lighting umbrella (1522) and umbrella mounting rod.
In sturdy carrying case.
Dimensions: approx. 385 x 265 x 100 mm
(15.2 x 10.4 x 3.9 in.)
3058
3038
3047
300 W Portable Lighting Kit
Complete light-stand-umbrella combination.
Comprises „videolight 8 S“ 300 W safety
lighting unit (93307), light stand (5031), joint
with umbrella mount (5041), and white
umbrella (3080).
In carrying bag with handle and adjustable
shoulder strap.
3058
3038
3049
1000 W Portable Lighting Kit
Complete light-stand-umbrella combination.
Comprises „videolight 6“ 1000 W safety
lighting unit (93304), light stand (5031), joint
with umbrella mount (5041) and white studio
umbrella (3080).
In carrying bag with handle and adjustable
shoulder strap.
3075
3094
32
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 33
3152
„studiolight H“ Lighting Unit
Compact unit for continuous lighting for product shots, portrait, video and film.
With 1000 W halogen lamp and safety glass
bulb dome. Light output can be dimmed steplessly and switched over to maximum output
and back. Low-noise cooling fan for unlimited
operation. Front part with bayonet attachment
for accessories (reflectors, soft boxes), swivel
joint with locking lever, umbrella mount. Can
be mounted on suitable tripods/stands with
16 mm standard spigot. Includes halogen
lamp, exchangeable reflector (180 mm /
7.1 in. diameter) and protective lamp cover.
Halogen lamp: 1000 W, 3400 K
Fuse: F 6.3 A (for 230/240 V), F 10 A (for 120 V)
Lead: approx. 4 m (13 ft.)
Weight with reflector: approx. 1960 g (4.3 lbs.)
Dimensions without reflector: approx. 290 x
120 x 240 mm (11.4 x 4.7 x 9.4 in.),
with reflector: approx. 320 x 180
x 260 mm (12.6 x 7.1 x 10.2 in.)
3075
3094
3150
„studiolight C“ Lighting Unit
Compact unit for continuous lighting for product shots, portrait, video and film.
E27 screw-in fixture for photofloods up to
500 W. Low-noise cooling fan for unlimited
operation. Front part with bayonet attachment
for accessories (reflectors, soft boxes), swivel
joint with locking lever, umbrella mount. Can
be mounted on suitable tripods/stands with
16 mm standard spigot.
Includes exchangeable reflector (180 mm /
7.1 in. diameter), protective lamp cover and
250 W photoflood (3130) (only with 230/240 V
version).
Socket: E27 (120 V: E26)
Fuse: F 4 A (for 230/240 V), F 10 A (for 120 V)
Lead: approx. 4 m (13 ft.)
Weight with reflector: approx. 1820 g (4 lbs.)
Dimensions without reflector: approx. 210 x
120 x 240 mm (8.3 x 4.7 x 9.4 in.),
with reflector: approx. 360 x 180
x 260 mm (14.2 x 7.1 x 10.2 in.)
Lighting Units for Photo & Video
3124-3130
3137, 3138
33
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 34
3155
“studiolight H” Lighting Kit
Portable lighting system for product shots,
portrait, video and film.
Contains:
2 "studiolight H" halogen lighting units
(3152), each with 1000 W halogen lamp and
protective lamp cover, light output can be
dimmed steplessly and switched over to
maximum output and back, low-noise cooling fan for unlimited operation, front part
with bayonet attachment for accessories
(reflectors, soft boxes), swivel joint with
locking lever, detachable reflector (180 mm /
7.1 in. diameter),
2 heat resistant soft boxes 60 x 60 cm
(23.5 x 23.5 in.) (3177) and
2 light stands (setting height 70 - 230 cm /
27.6 – 90.6 in.).
In a sturdy carrying case with handle and
padded shoulder strap.
Case dimensions: approx. 94 x 30 x 27 cm
(37 x 11.8 x 10.6 in.)
3075
3094
34
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 35
3154
„studiolight C“ Lighting Kit
Portable lighting system for product shots,
portrait, video and film.
Contains:
2 „studiolight C“ lighting units (3150), each
with E27 screw-in socket for photofloods up
to 500 W, low-noise cooling fan for unlimited
operation, front part with bayonet attachment for accessories (reflectors, soft boxes),
swivel joint with locking lever, umbrella
mount, protective lamp cover, 250 W photoflood (only with 230/240 V version) and
exchangeable reflector (180 mm/ 7.1 in. diameter),
1 silver reflector umbrella (100 cm / 39.4 in.
diameter),
1 transmitted light umbrella (100 cm / 39.4 in.
diameter) and
2 light stands (setting height 70 - 230 cm /
27.6 – 90.6 in.).
In a sturdy carrying case with handle and
padded shoulder strap.
Case dimensions: approx. 94 x 30 x 27 cm
(37 x 11.8 x 10.6 in.)
3124-3130
3137, 3138
Lighting Units for Photo & Video
35
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 36
3177-78
Soft Box
Attaches to „studiolight C“ (3150) and
„studiolight H“ (3152).
Can be rotated and locked. Made of heatresistant materials. With four ventilation flaps.
3177: 60 x 60 x 35 cm (23.5 x 23.5 x
13.8 in.)
3178: 100 x 100 x 40 cm (39.5 x 39.5 x
15.7 in.)
3159
Interchangeable Reflector 280 mm
Attaches to „studiolight C“ (3150) and
„studiolight H“ (3152).
Narrow beam. Silver coating inside. Matte
black coating outside.
Diameter: approx. 280 mm (11 in.)
Depth: approx. 260 mm (10.2 in.)
3160
Interchangeable Reflector 400 mm
Attaches to „studiolight C“ (3150) and
„studiolight H“ (3152).
Wide beam. Silver coating inside. Matte
black coating outside.
With secondary reflector for even illumination
and reduced glare. Removable heat-resistant
fabric diffuser.
Diameter: approx. 400 mm (15.7 in.)
Depth: approx. 150 mm (5.9 in.)
3170
Background Reflector
Attaches to „studiolight C“ (3150) and
„studiolight H“ (3152).
45° angle. Silver coating inside. Matte black
coating outside.
Can be rotated and locked in any position.
Diameter: approx. 320/200 mm (12.6 / 7.9 in.)
Depth: approx. 345/95 mm (13.6/3.7 in.)
36
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
3121
Studio Light
3124-3130
3137, 3138
Seite 37
Reflector with white lacquered interior surface
for soft lighting. Outer surface of nonreflecting dull black enamel. Catch joint with
tightening screw and 3/8“ tripod bush. For
photofloods up to 500 W and all-purpose
lamps E 27.
Reflector diameter: 260 mm (10.2 in.)
Cord:
4 m (13 ft.)/
120 V: 2 m (6 1/2 ft.),
with cord switch
Supplied without lamp.
3124–30
Photoflood
With E 27 screw-in thread.
3124:
3125:
3126:
3128:
3129:
Opal Lamp 150 W, 3000 K
Reflector Lamp 500 W, 3200 K
500 W, 3200 K, without reflector
Reflector Lamp 150 W, 3200 K
Reflector Lamp 500 W, 5000 K
For use with daylight films
3130: 250 W, 3000 K, without reflector
3125
3129
3126
3128
3137-38
Ceram Lamp
Halogen lamp with E 27 screw-in thread.
Colour temperature 2900 Kelvin.
Provides 20 % more light output than regular
incandescent lamps. Integrated UV blocker.
2000 hours operating life.
3137: Ceram Lamp 150 W
3138: Ceram Lamp 230 W
Lighting Units for Photo & Video
37
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 38
Lamp Survey
3454/64
Dulux Fluorescent Lamps
Replacement lamps for soft lights 3425/3428 and 3431.
Power:
CRI:
Average service life at
steady color temperature:
Socket:
Length:
Tube diameter:
55 W
90-100
8000 hours
2 G 11
533 mm (21 in.)
2 x 17.5 mm (0.69 in.)
Please replace fluorescent lamps as a whole set if requirements
for color-correct lighting are high.
3454 Color temperature 5400 K, Light color 12, 1 piece
3464 Color temperature 3200 K, Light color 32, 1 piece
G4
100 hrs. 3288
147
3200 K
G 6,35
50 hrs.
93310
148
3054
12 V
100 W 3200 K
G 6,35
25 hrs.
3003
230 V1)
150 W 3400 K GX 6,35 20 hrs.
93392
31
3038
230 V2)
300 W 3200 K GX 6,35 75 hrs.
30-31, 33
3058
230 V1)
300 W 3400 K GX 6,35 15 hrs.
93307, 3152,
93304, 93325
3051
230 V1)
650 W 3400 K GX 6,35 15 hrs.
230 V2) 1000 W 3200 K GX 6,35 75 hrs.
3152, 93304,
93325
30, 33
3094
3075
230 V1) 1000 W 3400 K GX 6,35 15 hrs.
3137
230 V
150 W 2900 K
E 27
2000 hrs. 3121, 3150
3138
230 V
230 W 2900 K
E 27
2000 hrs.
1)
2)
38
also available in 120 V and 240 V
also available in 120 V
Catalog page
3200 K
50 W
Suitable for
20 W
12 V
Av. service life
Color temperature
6V
3028
Socket
Power
3027
Code no.
Voltage
Halogen Lamps
33, 37
02_gbAufnahmeleuchten
04.03.2009
16:41 Uhr
Seite 39
Stands, Umbrellas and Other Helpers
The heavier and bigger the lighting
unit, the more important the light stand.
It should stand firm, even when set to
maximum height.
The stand should „suit“ the light, and a
cheap solution could soon become an
expensive one, if in case of a „crash“
the light or other things could be
damaged.
Most of the lights have a mounting
bracket or a tiltable grip in order to
arrange for a specific position on the
stand. Additional joints and holding
devices provide easy attachment of
umbrellas. They are important when
light should not hit the subject with its
full power or harshness. Very often the
amount of light should be reduced to a
certain value. Studio and reflector
umbrellas are then of great help. The
umbrella is mounted at the proper
distance in front of the lighting unit.
Umbrellas with a black outside coating
provide powerful, but diffuse reflection
from the inside surface (= indirect
lighting). A white inner coating gives
soft, neutral reflections, a silver inside
surface leads to more accentuated
effects and a gold coated reflector
umbrella is the best solution for warm
color rendition when shooting portraits
or nudes. The transparent white
umbrella leads to similar results and
can also be used for portraits. As the
light is not only reflected but also transmitted, it can also be used for direct
lighting.
Lighting Units for Photo & Video
In the end an
umbrella provides
for softer, shadowless
and more even illumination.
If there is no room for placing stands, clamps and
mounting accessories are
valuable helpers to attach
lights on shelves, doors or to
tables.
39
39
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 40
5031
„Compact“ Light Stand
Light-weight stand with five-section telescope
centre column. Particularly suited for use in
portable equipment kits. Solid flat metal legs.
Reversible thread pin with 1/4” and 3/8”
mounting threads and with adapter sleeve for
standard 16 mm (5/8”) pivot pins. Made of
black anodized light alloy.
Setting height: approx. 49–190 cm
(19.3 - 74.8 in.)
Length closed: approx. 48 cm (18.9 in.)
Load:
max. 1.5 kg (3.3 lbs)
Weight:
approx. 930 g (2 lbs.)
5033
„Standard“ Light Stand
Light-weight stand with four-section telescope
centre column. Solid flat metal legs.
Reversible thread pin with 1/4” and 3/8”
mounting threads and with adapter sleeve for
standard 16 mm (5/8”) pivot pins. Made of
black anodized light alloy.
Setting height: approx. 88-250 cm
(34.6- 98.4 in.)
Length closed: approx. 86 cm (33.9 in.)
Load:
max. 5 kg (11 lbs.)
Weight:
approx. 1280 g (2.8 lbs)
5035
„Profi“ Light Stand
5031
5033
Heavy-weight stand with three-section telescope centre column. Reinforced tripod base.
Reversible thread pin with 1/4” and 3/8”
mounting threads and with adapter sleeve for
standard 16 mm (5/8”) pivot pins. Made of
black anodized light alloy.
Setting height: approx. 103–290 cm
(40.6 - 114.2 in.)
Length closed: approx. 101 cm (39.8 in.)
Load:
max. 10 kg (22 lbs.)
Gewicht:
approx. 2050 g (4.5 lbs.)
5035
5048
Reversible Thread Pin
1”
5/ ”
8
3/ ”
8
1”
1/ ”
4
5048
40
Pin with 1/4” and 3/8” mounting threads. For
5031, 5033, 5035, 3402, 3403, 3404, 3421,
3423, 5044, 5041, 5027, 5028, 5043, 5045.
Pin is mounted to the light and is inserted
into the 16 mm sleeve of the stand or mounting accessory.
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 41
3402
„Small“ Light Stand
Four-part extending center column with air
cushion, locked by big clamping ring. Centre
column and legs made of aluminium tube.
Reversible thread pin with 1/4” and 3/8”
mounting threads.
Setting height:
approx. 72–210 cm
(28.3 - 82.7 in.)
Length closed:
approx. 68 cm (26.8 in.)
Load:
max. 3 kg (6.6 lbs.)
Weight:
approx. 1400 g
(3.1 lbs.)
3403
„Medium“ Light Stand
Three-part extending center column with air
cushion, locked by big clamping ring. Centre
column and legs made of aluminium tube.
Reversible thread pin with 1/4” and 3/8”
mounting threads.
Setting height:
approx. 99–244 cm
(39 - 96.1 in.)
Length closed:
approx. 91 cm (35.8 in.)
Load:
max. 6 kg (13.2 lbs.)
Weight:
approx. 1700 g
(3.7 lbs.)
3404
„Large“ Light Stand
Four-part extending center column with air
cushion, locked by big clamping ring. Centre
column and legs made of aluminium tube.
Reversible thread pin with 1/4” and 3/8”
mounting threads.
Setting height:
approx. 101–325 cm
(39.8 - 128 in.)
Length closed:
approx. 96 cm (37.8 in.)
Load:
max. 10 kg (22 lbs.)
Weight:
approx. 1850 g
(4.1 lbs.)
3403
3404
3402
5049
Tripod Adapter
For mounting devices with 1/4” tripod bush
on tripods with 3/8” connecting thread. With
1/4” threaded pin and 3/8” threaded hole.
Height: approx. 27 mm (1.1 in.)
Lighting Units for Photo & Video
5049
41
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 42
3423
Studio Stand
Mobile light stand for heavy-duty service
(e.g. for proVision softlights), 28 mm (1.1 in.)
vertical mounting hole, two horizontal
mounting holes, 28 mm (1.1 in.) and 16 mm
(0.6 in.). With adapter for 28 mm receptacle
hole and 16 mm standard spigot with 3/8”
thread. Crank operated height adjustment,
with securing key and locking screw.
Setting height:
approx. 138-218 cm
(54.3 x 85.8 in.)
max. 30 kg/15 kg
(66 lbs./33 lbs.)
(vertical/horizontal)
approx. 10.4 kg
(22.9 lbs.)
Load capacity:
Weight:
3421
Studio Stand
Mobile and extremely stable light stand.
Folding tripod legs with fixable pivoting rollers. Centre column steplessly adjustable
between 1.40 m and 2.30 m (4.6 and 7.5 ft.)
Hole for standard 28 mm (1.1 in.) pivot pin
and with reducer to 16 mm (.6 in.).
Reversible thread insert with 3/8“ and 1/4“
mounting thread.
Setting height:
approx. 140 - 230 cm
(55.1 - 90.6 in.)
max. 50 kg on centre
(110 lbs.)
approx. 6.8 kg (15 Ibs.)
Load capacity:
Weight:
3421
3420
Studio Stand
Mobile and extremely stable light stand.
Folding legs with fixable pivoting rollers. Hole
for standard 28 mm (1.1 in.) pin, concealed
standard 16 mm (0.6 in.) pin.
3423
3420
Setting height: approx. 80 to 122 cm
(31.5 to 48 in.)
Load capacity: 25 kg (55 lbs.) on centre
Weight:
42
8 kg (17.6 lbs.)
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
3407
Background Support System
Seite 43
Complete system to support paper background rolls in widths of up to 275 cm (9 ft).
Consists of two stands, extendable to 3.25 m
(10.7 ft.), and a 3-section horizontal pole to
hold the background roll. The stands can
also be used separately as light stands.
Complete kit in a carrying case.
5923
Background Cardboard Holder
Holds 110 to 270 cm (3.6 x 8.9 ft.) width
background cardboard on rolls.
For mounting on tripods with 3/8“ thread.
Width: approx. 85 cm (33.5 in.)
5044
Universal Clamp with
Extension Arm
Lighting Units for Photo & Video
Universal clamping device for boards up to
30 mm (1.2 in.), also suitable for attachment
to tubes of 13 to 55 mm (.5 to 2.2 in.) diameter. Detachable extension arm with interchangeable 1/4“ and 3/8“ mounting threads.
43
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 44
5041
Joint with Umbrella Mount
Heavy-duty metal joint for attaching lighting
units to stands. Upper section can be tilted
and locked in any position. With hole (9.2
mm diam.) for reflector umbrella. Reversible
1/4“ and 3/8“ thread pin in upper section,
reversible 1/4“ and 3/8“ thread sleeve in
lower section.
Height: approx. 115 mm (4.5 in.)
1512
Clamp
For simple attachment of lightweight lighting
units. Removable accessory shoe on ball
joint. Tiltable to all sides in infinite steps,
lockable in any position. Additional connecting thread 1/4“. With reflector umbrella holder ø 9.2 mm. Clamp is impact-resistant plastic with non-slip rubber studs.
Clamp span: max. 40 mm (1.6 in.)
Height:
approx. 90 mm (3.5 in.)
3084
Umbrella Mounting Rod
Allows attachment of a studio/reflector
umbrella precisely in the line of the lighting
unit.
For use together with 5041.
Length: approx. 380 mm (15 in.),
hole for umbrella: approx. 9.2 mm (.36 in.)
1522
Reflector Umbrella
White, waterproof coated nylon fabric. For
use as a reflector and for shoot-through
lighting with small lamps or flash equipment.
Rods chrome or nickel-plated.
Diameter: approx. 37 cm (14.6 in.)
Height: approx. 30 cm (11.8 in.)
Rod-ø: approx. 7.9 mm (.31 in.)
44
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 45
3080
Studio Umbrella
With white nylon fabric. Suitable as reflector
or for shoot-through lighting. For use with
lighting units and flash equipment. Chromeplated rods, umbrella spoke tips of white
plastic.
Umbrella diameter: approx. 90 cm (35.4 in.)
Height:
approx. 58 cm (22.8 in.)
Rod-ø:
approx. 7.8 mm (.3 in.)
3081
Reflector Umbrella
For use with lighting units and flash equipment. Inside white. Chrome or nickel-plated
rods.
Umbrella-ø:
Height:
Rod-ø:
3080
3081
approx. 80 cm (31.5 in.)
approx. 55 cm (21.7 in.)
approx. 7.8 mm (.3 in.)
3042–43
Reflector Umbrella
For use with lamps and flash equipment. For
particularly soft lighting, high reflection.
Outside black PVC fabric. Rods chrome or
nickel-plated.
Umbrella-ø:
Height:
Rod-ø:
approx. 85 cm (33.5 in.)
approx. 58 cm (22.8 in.)
approx. 7.8 mm (.3 in.)
3042: inside silver coated for
accentuated illumination
3043: inside gold coated for warmer
colour reproduction
3042
3043
Lighting Units for Photo & Video
45
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 46
Being in a Tight Spot
Especially when shooting smaller
objects, accurate and controlled
lighting can be a problem. An irregular
shape might require light that bends
around a corner, for example when
covering openings or hollow spaces, or
a spectacular production calls for an
extremely precise set-up of several
light sources.
Photographic documentation of technical subjects or image capturing of pieces of evidence require above all accurate rendition of details without any
disturbing effects like shadows.
Small, flexible lights can be of great
help in these cases. They do not need
stands because they can be clamped
to a convenient spot and a bendable
gooseneck arm provides for exact positioning of the light. In the same way
you may also attach reflectors, foils
and even small and light-weight cameras.
And when you are definitely in a tight
spot, then you can even get the light
around the corner - with help of the
light guides of a fiber-optic lighting
system.
46
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
5960
20 W Halogen Light
Seite 47
With flexible arm, length approx. 50 cm
(19.7 in.), 14 mm (0.55 in.) diam., standard
16 mm (0.6 in.) pin. 1.8 m (5.9 ft.) power
cable with integrated cable switch.
Includes halogen lamp 12 V, 20 W, 3100 K,
60° angle of illumination.
5966/81/87
Halogen Lamp
For 5960 and 5965 Halogen Lights.
12 V, 3100 K.
5981 20 W, 10° angle of illumination
5987 20 W, 38° angle of illumination
5966 20 W, 60° angle of illumination
5965
50 W Halogen Light
5967-68/82-83/88-89
Halogen Lamp
With flexible arm, length approx. 50 cm (19.7
in.), 14 mm (0.55 in.) diam., standard 16 mm
(0.6 in.) pin. 2.5 m (8.2 ft.) power cable and
dimmer with end-position switch-off.
Includes halogen lamp 12 V, 50 W, 3100 K,
60° light angle. 20 W and 35 W halogen
lamps can also be used.
For 5965 halogen light. 12 V, 3100 K.
5982 35 W, 10° angle of illumination
5988 35 W, 38° angle of illumination
5967 35 W, 60° angle of illumination
5983 50 W, 10° angle of illumination
5989 50 W, 38° angle of illumination
5968 50 W, 60° angle of illumination
5027-28/5043
Clamp
To mount on tubes and boards.
Fits standard 16 mm (0.6 in.) pin.
5027: Small table clamp, clamping width:
35 mm (1.4 in.).
Weight: approx. 160 g (5.6 oz.).
5027
5028: Large table clamp, clamping width:
80 mm (3.1 in.).
Weight: approx. 450 g (15.8 oz.).
5043: Universal clamp, to mount on tubes of
13-55 mm (0.5-2.2 in.) diameter.
Supplied with a wedge. Then can be
mounted on approx. 30 mm (1.2 in.)
thick boards. Weight: approx. 450 g
(15.8 oz.).
Lighting Units for Photo & Video
5028
5043
47
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 48
5040
Magic Arm
5026/5038-39
Flexible Arm
5038
5039
5026
5045
Base for Flexible Arm
To mount and individually align cameras,
lights and accessories. Mounted with
reversible thread adapter on tripods and
clamps with a 16 mm (0.6 in.) sleeve.
Mounting platform with sliding 1/4”.
Camera screw, 3/8”. conversion thread and
reflector umbrella mount. Reversible thread
adapter with 1/4” and 3/8” internal thread
and with ball-and-socket joints at both ends.
Both ball-and-socket joints and the middle
joint are released and tightened by a central
locking disk. Max. load (in horizontal position):
4 kg (8.8 lbs.)
Flexible holding arm with standard 16 mm
(0.6 in.) pin, 1/4“ mounting thread, black.
5026: Approx. 50 cm (19.7 in.) long, 14 mm
(0.55 in.) diam., cable can be conducted through
the arm. With knurled counter-locking disk.
Load (in horiz. position): approx. 200 g (7oz).
5038: Approx. 55 cm (21.7 in.) long, 12 mm
(0.5 in.) diam., load (in horizontal position):
approx. 180 g (6.3 oz).
5039: Approx. 55 cm (21.7 in.) long, 18 mm
(0.7 in.) diam., load (in horizontal position):
approx. 600 g (21.1 oz).
Base for 5026/38/39 Flexible Arms and
5040 Magic Arm. With 16 mm (0.6 in.)
sleeve for standard pin. Variable leg distance
up to 48 cm (18.9 in.) max.
Weight: 2.2 kg (4.8 lbs.)
5029
Clamp Adapter
5046
Holding Clamp
48
For attachment of parts with circular profile
(ø 7-18 mm/0.3-0.7 in.), e.g. pen cameras,
LED light sources, fiber-optic light guides
etc. 1/4” connecting thread.
Double clamp, 20 mm (0.8 in.) max. open
width, to mount filter foils, reflectors, masks
and other accessories.
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
3102
Clamp-on Lamp Holder
Seite 49
Gooseneck lamp rod, pivotable and variable
adjustable. Shock-resistant plastic clamp
with non-slip rubber cleats.
For lamps up to 250 W, E 27.
Clamp span:
Lamp staff:
Cord:
40 mm (1.6 in.) max.
approx. 350 mm
(13.8 in.) long
2.9 m (9 1/2 ft.), with
cord switch
Supplied without lamp.
3128
3120
Clamp-on Lamp Holder
Lamp rod pivotable, tiltable, and adjustable
in height. Plastic-coated non-slip metal
clamp.
For lamps up to 250 W, E 27
Clamp span:
Lamp rod:
Cord:
60 mm (2.4 in.)
approx. 250 mm
(9.8 in.) long
1.5 m (4.9 ft.),
with cord switch
Supplied without lamp.
3128
Lighting Units for Photo & Video
49
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 50
5945
„macrospot 1500“
Fiber-Optic Lighting System
For pinpointed uniform and powerful lighting
for macro and micro photography, for tabletop photography and for lighting inaccessible
areas. Due to the very low heat development
and high light yield, cold light is also widely
used in microscopy, medicine, fine engineering etc. The two flexible, jointly detachable,
glass-fibres optical light guides with swan’s
neck sheathing can be moved into almost
any position required. Angle of reflection
approx. 67°. Two-stage switching for full and
reduced lighting power, with constant colour
temperature of 3200 Kelvin maintained.
Extremely low-noise fan cooling at the back
of the light source, so subjects not exposed
to heat. Only very slight heating of housing
due to special heat-dispersing design.
Illuminated on/off switch.
Technical data:
Halogen cold light
mirror lamp:15 V, 150 W, 3200 K
Cord:
approx. 2.50 m (8.2 ft.)
Weight:
approx. 4.8 kg (10 Ibs. 9 oz.)
Dimensions: approx. 230 x 115 x 205 mm
(9.1 x 4.5 x 8.1 in.) (without handle)
Length of optical light guide:
approx. 50 cm (19.7 in.)
5946
Iris Diaphragm
For adjusting the angle of reflection from
approx. 38° to 20° minimum and simultaneous dimming by max. five stops. With slot
for filter inserts. Can be mounted on light
guide. One piece.
5952
5947
Focus Attachment
5948
For Reducing the angle of reflection to 38°
approx. With slot for filter inserts. Can be
mounted on light guide. One piece.
5948–49/5955
Filter Inserts
5946
5947
5949
50
Filter screen for insertion into iris diaphragm
or focus attachment 5947.
5948: Conversion filter, 3 pieces
5949: Colour filter set, 3 filter screens each
in red, blue, green, yellow
5955: Polarisation filter, 3 pieces
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
5941
Light Source
5952
5952
Halogen Cold Light Mirror Lamp
5942–43
Optical Light Guide
Seite 51
Two-stage switching for full and reduced
lighting power, with constant colour temperature of 3200 Kelvin maintained. Extremely
low-noise fan cooling at the back of the light
source. Illuminated on/off switch.
Replacement lamp for lighting system 5945
and light source 5941. 15 V, 150 W, 3200 K,
average life approx. 50 hours.
For lighting system 5945 and light source
5941. 4 mm thick glass fibre cable with
gooseneck sheath. The self-retaining optical
light guide can be placed in almost any position. Length per optical light guide: approx.
50 cm (19.7 in.)
5942: 2-arm
5943: 3-arm
5944
Ring Light Attachment
Split ring light for especially homogeneous
and shadow-free illumination of subject field.
For fastening to camera lenses from 35 to
60 mm (1.4 to 2.4 in.) diameter.
With flexible cord, approx. 75 cm (29.5 in.)
5951
Light Guide with Adapter
Lighting Units for Photo & Video
Two-arm gooseneck optical conductor with
fastening adapter for the Kaiser TopTable
product table system and for the rod links on
most Kaiser copy lighting units (edge length
16 mm (.6 in.)). Flexible swan’s neck cord
with plug-in connection for lighting system
5945 and light source 5941, length approx.
90 cm (35.4 in.).
51
02_gbAufnahmeleuchten
04.03.2009
16:42 Uhr
Seite 52
Video Lighting
Basically light does not care if it
„works“ for a photo or film camera, a
video or TV camera, a conventional or
digital camera.
On the other hand some cameras ask
for special lighting or, at least, for light
with specific properties.
If a lighting unit is particularly light and
compact and carries its own power
source, it then is perfect for camcorders, analog and digital alike. These
lighting units can be found in the
„Video Light“ section starting on page
143.
52
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
