LIGHTING AND CINE

SUPPORT SOLUTIONS

2006/07

02

LIGHTING AND CINE

Manfrotto offers the widest and most professional choice of lighting support solutions to serve the photographic, motion picture, broadcast and entertainment industries. The company’s unrivalled experience combines revolutionary concepts and innovative design with advanced production technology, ensuring quality products that are unmatched for performance and value.

Grouped into two broad families - Lighting and Cine - Manfrotto lighting products and accessories meet the demands of any photographic or video application be it in the studio or on location.

Every studio and location requirement, from lighting support and control to rigging, suspension, mounting and lifting is answered by Manfrotto’s comprehensive range of Stands, Clamps, Arms, Brackets, Bars, Grip Head System, Pump Cup and Wall Plates, Lighting Booms, Autopole ® System, Background Support Systems, Sky Track System, Still Life Tables,

Multiclamp System, Lighting Control, Lighting Control Mountings and Adapters.

Safety is a priority for Manfrotto: all equipment is designed to meet international regulations such as DIN 15560, TUV, CE and ISO standards. Examples of safety features include cranks that cannot accidentally unwind, captive lock-off knobs, stainless steel or rust proof dachromatic treated sockets, high efficiency wheel brake shoes, rock-solid stand locking collars which ensure all-weather operation and first class quality components in steel, stainless steel, aluminum tube and die cast aluminum.

Manfrotto assures a fast and effective after-sales support, including full availability of spare parts for all of our products

SUPPORT SOLUTIONS

This catalog of products is the result of over 30 years of experience in manufacturing stands and supports for the lighting industry. Manfrotto’s extensive cooperation with world-leading lighting manufacturers and technicians guarantees a perfect match between professional requirements and tools.

CONTENTS

LIGHTING SUPPORTS

CINE SUPPORTS

LIGHTING AND CINE ACCESSORIES

KEY TO SYMBOLS

Minimum

Height

Maximum

Height

Closed

Length

Footprint

Diameter

Weight Spigot

Size

*

Socket

Size

*

Grip Head

Size

Top Tube

Diameter

Suggested

Wheels

Maximum

Evenly

Distributed

Load on Level

Ground

Maximum

Load on

Fully

Extended

Stand at 6°

Inclination

Gravity

Cast

Black Air

Cushioned

Black

Chrome

17mm Stand

Female

Attachment

German Safety

Standard

* NOTE: in product specifications you will often see a note referring to the spigot/socket type of the product (e.g.

"type 14"). This type number refers to the spigot and socket variants shown on page 197.

For stands with maximum load over 3kg, this brochure specifies, in accordance with DIN 15560 norm, the load when the stand is fully extended at an inclination of 6˚ from vertical.

DIN 15560 specifies the maximum load on a ‘non-windup’ stand is 18kg.

Optional wheels invalidate the height and load specifications according to DIN 15560.

ORDERING

Products may be ordered by using the product code together with its title.

Optional Black (B) finish, Air Cushioned (AC), Black Chrome (CB) finish and 17mm female attachment (J) versions are available where indicated.

Add B, AC, CB or J to the product code when ordering.

Lighting Stands don't fall inside the European directive 98/37/CE and for this reason they don't need "CE" mark.

03

04 lighting

Manfrotto’s Lighting line includes everything you need in a photographic or video studio. You can find a wide range of lighting stands, background supports, booms, ceiling suspension systems, still life tables, light and heavy hooks and a large selection of accessories allowing extreme customization of products and set-ups.

Innovative designs and high quality materials make these products safe and user friendly. In every single product you can spot several technical/manufacturing solutions designed to solve day-to-day transportation and handling problems.

Last but not least our products’ design allows for quick and simple maintenance.

Contents

STANDS

CLAMPS

ARMS, BRACKETS, BARS AND PUMP CUP

LIGHTING BOOMS

AUTOPOLE SYSTEM

BACKGROUND SUPPORT SYSTEMS

SKY TRACK SYSTEM

STILL LIFE TABLES AND MULTICLAMP SYSTEM lighting 05

06 lighting

Manfrotto’s range of stands consists of several product families which differ in design and materials depending both on the applications they are intended for and on the light type they have to support.

These supports can be distinguished by the materials they are made of.

Our range includes products with aluminum components, which allow high wear strength and linearity in column extension. We offer two tubing technologies: electric welded aluminum and steel.

Special attention has been paid to multiple technical solutions like pneumatic damping and levelling legs, making these stands unique.The existing versions allow for extensions between

21cm and 585cm, with payloads between 1,5kg and 180kg.

Contents

Quick Guide

Baby Lightweight Stands

Stacker Stands

Boom Stands

Junior Stands

Roller Stands

Wind Up Stands

Microphone & Speaker Stands

Page

18

20

30

34

38

8

10

16 lighting 07

Manfrotto’s range of stands consists of different product families which differ in design and materials depending both on the applications for which they are intended and on the type of light they support.

To make reference to this section as easy and as useful as possible we have grouped the stands by load capacity: by knowing the weight of the light for which you need a stand you will be able to choose the one that match you needs from the different versions.

MAX

LOAD

1,5kg 2kg 3kg

730cm:

Maximum Height

4kg 5kg 8kg

500cm

9kg

730

10kg 12kg 15kg

400cm

392 392 392 392

385 385

340

300cm

315

322

300

290

272

240

250 250 250 250 250

200cm

217

212

190 190

173

100cm

0cm

123 121

110

48

49

91

48

85

64

66

40

156BLB

p. 11

001B

p. 11

050BAC

p. 14

9

012B

p. 11

305B

p. 17

67

051NBAC

p. 12

86

88

049B

p. 12

86

88

87

89

052BAC

p. 13

306B

p. 17

35

231B

p. 31

35

121

109

107

112

110

131

113

131

113

103

101

231CS

p. 31

004B

p. 14

307B

p. 17

420B

p. 19

420NSB

p. 19

005BAC

p. 13

269HDBU

p. 27

8

003MF

p. 11

9,7

003M

p. 11

108

105

131

113

131

113

124

122

131

112

129

125

135

299B

p. 32

420CSU

p. 19

420CSUNS

p. 19

007BU

p. 23

008BU

p. 21

298B

p. 32

256BUAC-3

p. 23

9

003B

p. 11

0,62 kg

0,93 kg

1,65 kg

1,32 kg

1,1 kg

1,1 kg

1,28 kg

1,28 kg

1,3 kg

6,4 kg

8 kg

2,15 kg

2,3 kg

2,7 kg

2,7 kg

2,05 kg

10 kg

0,5 kg

0,52 kg

4,8 kg

5,6 kg

5,6 kg

3 kg

4,2 kg

6 kg

3,7 kg

1 kg

018 -

+

Art. 015

+

Art. 015

-

-

+

Art. 015

-

+

Type 18

Type 1 +

Spigot

Art. 013

+

Art. 015

-

+

Art. 015

+

Art. 015

-

017

-

017 018

+

Art. 015

-

+

Art. 015

-

-

Type 1 +

Spigot

Art. 013

Type 1 +

Spigot

Art. 013

+

Art. 015

-

018 018 018

103,

104,

104G

-

+

Art. 015

-

-

Type 25 +

Spigot

Art. 013

Type 25 +

Spigot

Art. 013

Type 3 +

Spigot

Art. 013

Type 14 Type 1 -

-

Type 33 -

018

-

018

-

109,

110,

110G

-

109,

110,

110G

-

-

-

109,

110,

110G

-

-

Type 3 +

Spigot

Art. 013

Type 25 +

Spigot

Art. 013

Type 25 +

Spigot

Art. 013

Type 14 Type 14 Type 14 Type 14

Type 1 +

Spigot

Art. 013

Closed Length

Minimum Height

Maximum Height

Weight

Suggested Wheels

Spigot Size

Socket Size

08 lighting

20kg 25kg 30kg 35kg 40kg 45kg 80kg

477 477

455

380 380

370

366

190

333 333

325 325 325

276 276

247

218

207

109

216 216 216

123

120

124

122

124

122

124

122

155

146

155

146

132

116

132

116

132

116

144

134

155

135

181

167

147

105

88

129

112

144

147

105

88

131 131

144 144

153

139

156

156

21

36

36

28

52

21

52

28

256BUAC

p. 22

297CS

p. 31

007BSU

p. 23

007CSU

p. 24

007XU

p. 24

111BSU

p. 25

111CSU

p. 25

008BSU

p. 21

008CSU

p. 22

008XU

p. 22

087NWBL

p. 35

087NWSH

p. 36

087NW

p. 37

070BU

p. 21

083NWLB

p. 35

269BU

p. 26

299FBASE

p. 33

299BBASE

p. 33

297FBASE

p. 33

297BBASE

p. 33

070CSU

p. 21

126BSU

p. 24

126CSU

p. 25

270BSU

p. 26

270CSU

p. 27

083NW

p. 35

387XU

p. 37

3 kg

109,

110,

110G

-

6,8 kg

7,3 kg

7,3 kg

-

-

109,

110,

110G

-

109,

110,

110G

-

7,3 kg

109,

110,

110G

-

9 kg

103,

104,

104G

-

9 kg

6,4 kg

6,4 kg

6,4 kg

16 kg

15,5 kg

21,4 kg

6,3 kg

11 kg

103,

104,

104G

-

109,

110,

110G

-

109,

110,

110G

-

109,

110,

110G

-

-

104,

104G,

347-10

-

104,

104G,

347-10

-

103,

104,

104G

-

-

8 kg

103,

104,

104G

-

3,5 kg

4,8 kg

4,4 kg

5,7 kg

6,8 kg

-

-

-

-

-

-

-

-

103,

104,

104G

-

8,3 kg

8,3 kg

13,5 kg

13,5 kg

16 kg

32,5 kg

109,

110,

110G

-

109,

110,

110G

-

103,

104,

104G

-

103,

104,

104G

-

-

-

374

-

Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 Type 14 28mm lighting 09

Electric welded aluminum tubing for smoother movements, higher mechanical performance and reduced weight.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Pre-painting sandblasting to achieve a perfect degreasing and optimal adhesion and resistance of finishing.

Anti-rotation 3/8’’ top screw fixing, plus 1/4” adapter for matching any requirement.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Versions featuring air cushioning for preventing damage to the lighting fixture during column retraction.

Double braced legs for extra stability, resistance and safety.

10 lighting

MINI BACKLITE BASE

FEMALE ATTACHMENT

003MF

8cm 40cm 0,5kg

10kg Type 1

The hole at the end of each leg enables the user to nail the stand to the floor, hang it on a wall or fix it to the ceiling.

MINI BACKLITE BASE

MALE ATTACHMENT

003M

9,7cm 40cm 0,52kg

10kg Type 33

Same as 003MF but with 16mm male attachment (Type 33).

BACKLITE BASE

003B

9cm 60cm 1kg

15kg Type 1 + Spigot Art. 013

Fold away base.

BACKLITE

STAND

012B

9cm 85cm 48cm 60cm 1,32kg Pole type 18 + type 19

3kg Base type 1 + Spigot Art. 013

Black steel base with detachable aluminium column.

2 sections, 1 riser. Ø: 22, 19mm. Solid flat legs: 20 x 5mm.

A versatile stand allowing fixtures to mount on the ground or on the included pole for extra height.

LOW MINI PRO STAND

156BLB

40cm 123cm 40cm 45cm 0,62kg

1,5kg Type 19 + Adapter art. 015

Aluminium stand. 4 sections, 3 risers.

Ø: 25, 22, 19, 16mm. Leg Ø: 16mm.

Perfect for background lights.

NANO STAND

001B

49cm 190cm 48cm 100cm 0,93kg

1,5kg Type 19 + Adapter art. 015

Aluminium stand. 5 sections, 4 risers.

Ø: 25, 22, 19, 16, 13mm. Solid flat legs 15 x 5mm.

An ideal stand for kits due to its compact design.

lighting 11

MINI COMPACT STAND

051NB

67cm 240cm 67cm 94kg 1,1kg

4kg [email protected] Type 19 + Adapter art. 015

Aluminium stand, air cushioned.

4 sections, 3 risers.

Ø: 25, 22, 19, 16mm.

Leg Ø: 16mm.

QUICK LOCK COMPACT STAND

049B

88cm 250cm 86cm 109cm 1,28kg

5kg 017 2,[email protected] Type 19 + Adapter art. 015

Aluminium stand. 4 sections, 3 risers.

Ø: 25, 22, 19, 16mm. Leg Ø: 19mm.

Quick lock stands are designed to be set-up quickly and securely without the need to turn any knobs.

12 lighting

COMPACT STAND

052B

88cm 250cm 86cm 109cm 1,28kg

5kg 017 2,[email protected] Type 19 + Adapter art. 015

Aluminium stand, air cushioned.

3 sections, 2 risers.

Ø: 25, 22, 19mm.

Leg Ø: 19mm.

RANKER STAND

005B

103cm 290cm 101cm 109kg 2,05kg

10kg 2,[email protected] 018 Type 3 + Spigot art. 013

Aluminium stand, air cushioned.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

lighting 13

QUICK LOCK STAND

050B

110cm 340cm 91cm 108cm 1,65kg

2kg 018 Type 19 + Adapter art. 015

Aluminium stand, air cushioned.

4 sections, 3 risers.

Ø: 28, 25, 22, 19mm. Leg Ø: 22mm.

Featuring the unique quick lock levers providing fast set-up.

MASTER STAND

004B

109cm 385cm 107cm 109cm 2,15kg

9kg 0,[email protected] 018 Type 19 + Adapter art. 015

Aluminium stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm. Leg Ø: 22mm.

14 lighting

POLE FOR

BACKLITE STAND

122B

0,32kg Top type 18 Bottom type 19

2 section (Ø 22, 19mm) aluminium pole.

Minimum height: 48cm.

Maximum height: 80cm.

BABY STAND

EXTENSION

099B

0,6kg Top type 19 Bottom type 1

3 section (Ø 25, 22, 19mm) aluminium extension.

Minimum height: 88cm.

Maximum height: 235cm.

lighting 15

Electric welded aluminum tubing for higher mechanical performance and reduced weight.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Clever room-saving concept for folding stands flat when not in use or during transportation (you can pack 7 Stacker stands in the space of 4 normal stands).

Double braced legs for extra stability, resistance and safety.

16 lighting

3/8’’ screw top fixing, plus 1/4” adapter for matching any requirement.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Clip system for moving 2, 3 or 4 stands together during loading/unloading.

Supplied with threaded hole for optional strap.

MINI STACKER STAND

305B

66cm 217cm 64cm 79cm 1,1kg

4kg 0,[email protected] Type 19 + Adapter art. 015

Aluminium stand. 4 sections, 3 risers.

Ø: 25, 22, 19, 16mm.

Leg Ø: 19mm.

PATENTED

STACKER STAND

306B

89cm 250cm 87cm 108cm 1,3kg

5kg 1,[email protected] Type 19 + Adapter art. 015

Aluminium stand. 3 sections, 2 risers.

Ø: 25, 22, 19mm.

Leg Ø: 19mm.

PATENTED

MAXI STACKER STAND

307B

112cm 385cm 110cm 107cm 2,3kg

9kg 0,[email protected] Type 19 + Adapter art. 015

Aluminium stand. 4 sections, 3 risers.

Ø: 35, 30, 25, 20mm. Leg Ø: 22mm.

PATENTED lighting 17

5/8” top fixing with 3/8’’ screw fixing

(adjustable 90°) and 1/4” adapter for matching any requirement.

Sandbag counterweight available.

A special articulated coupler allows this model to be used either as a normal stand or boom.

18 lighting

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Electric welded aluminum tubing for higher mechanical performance and reduced weight.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

All versions feature leveling leg for better stability.

Double braced legs for extra stability, resistance and safety.

COMBI-BOOM STAND

WITH SANDBAG

420B

131cm 392cm 113cm 109cm 2,7kg

9kg 0,[email protected] 018 Type 25 + Spigot art. 013

Aluminium stand.

Supplied with sandbag counterweight (empty) for maximum stability and smoothness.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg Ø: 22mm.

Minimum extension boom: 19cm

Maximum extension boom: 191cm

Maximum load at boom full extension: 2kg with counterweight.

COMBI-BOOM STAND

WITHOUT SANDBAG

420NSB

Not illustrated

Same as 420B without counterweight.

COMBI-BOOM STAND HD

WITH SANDBAG

420CSU

131cm 392cm 113cm 109cm 5,6kg

12kg 1,[email protected]

018

Type 25 + Spigot art. 013

Same as 420B but with legs and column in steel, last two sections in aluminium.

Maximum load at boom full extension: 5kg with 35kg of counterweight.

COMBI-BOOM STAND HD

WITHOUT SANDBAG

420CSUNS

Not illustrated

Same as 420CSU without counterweight.

lighting 19

28mm (or 16mm) die cast aluminum socket and 16mm stud.

Parts and knobs made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

All versions feature leveling leg for better stability.

Aluminum feet for improved stability and longer durability.

20 lighting

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Chrome steel, black zinc and silver or black aluminium versions.

Chrome-plated steel versions: this surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Aluminium versions: electric welded aluminum tubing for higher mechanical performance and reduced weight.

Double braced legs for extra stability, resistance and safety.

All stands in this series can be equipped with wheels

(including types with brakes).

BLACK ALU FOLLOW

SPOT STAND

070BU

88cm 147cm 105cm 109cm 6,3kg

35kg [email protected] Type 14 103, 104, 104G

Black aluminium stand. 2 sections, 1 riser.

Ø: 50, 40mm. Leg Ø: 30mm.

1 levelling leg. Memory collar included.

FOLLOW

SPOT STAND

070CSU

88cm 147cm 105cm 109cm 6,8kg

40kg [email protected] Type 14 103, 104, 104G

Chrome plated stand. 2 sections, 1 riser.

Ø: 50, 40mm. Leg Ø: 30mm.

1 levelling leg. Memory collar included.

This stand was named for its low height and high payload allowing the lighting technician to easily follow on actor.

ALU-CINE BLACK STAND

008BU

131cm 212cm 112cm 118cm 4,2kg

15kg [email protected]

Type 14

109, 110, 110G

Black Aluminium stand. 2 sections, 1 riser.

Ø: 35, 30mm. Leg Ø: 22mm. 1 levelling leg.

BLACK CINE STAND

008BSU

132cm 216cm 116cm 118cm 6,4kg

30kg [email protected]

Type 14

109, 110, 110G

Black zinc plated stand. 2 sections, 1 riser.

Ø: 35, 30mm. Leg Ø: 22mm. 1 levelling leg.

lighting 21

CINE STAND

008CSU

132cm 216cm 116cm 118cm 6,4kg

30kg [email protected] Type 14 110, 110G

Chrome plated steel stand.

2 sections, 1 riser.

Ø: 35, 30mm.

Leg Ø: 22mm.

1 levelling leg.

SELF LOCK STAND

256BUAC

109cm 218cm 109cm 126cm 3kg

20kg [email protected] Type 14 109, 110, 110G

Shorter version of 256UAC-3.

2 sections, 1 riser.

Ø: 40, 35mm.

Leg Ø: 22mm.

1 levelling leg.

22 lighting

CINE STAND

008XU

132cm 216cm 116cm 118cm 6,4kg

30kg [email protected] Type 14 110, 110G

Stainless steel stand.

2 sections, 1 riser.

Ø: 35, 30mm.

Leg Ø: 22mm.

1 levelling leg.

ALU SENIOR STAND

007BU

124cm 315cm 122cm 118cm 3kg

12kg 2,[email protected] Type 14 109, 110, 110G

Alluminium stand.

3 sections, 2 riser.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

1 levelling leg.

SENIOR STAND

007BSU

124cm 325cm 122cm 118cm 7,3kg

20kg 6,[email protected] Type 14 109, 110, 110G

Black chrome plated steel stand.

3 sections, 2 riser.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

1 levelling leg.

HIGH SELF LOCK STAND

256BUAC-3

135cm 322cm 135cm 126cm 3,7kg

15kg [email protected] Type 14 109, 110, 110G

Steel base, aluminium sections.

3 sections, 2 risers.

Ø: 40, 35, 30mm. Leg Ø: 22mm.

1 levelling leg.

Air-cushioned stand with unique self-lock collars that block the stand safely at the desired height without any levers or knobs.

To lower, raiser slightly, open the safety lever and drop the extension.

lighting 23

SENIOR STAND

007CSU

124cm 325cm 122cm 118cm 7,3kg

20kg 6,[email protected] Type 14 109, 110, 110G

Chrome plated steel stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

1 levelling leg.

HEAVY DUTY STAND

126BSU

131cm 333cm 131cm 126cm 8,3kg

40kg [email protected] Type 14 109, 110, 110G

Chrome plated steel stand.

3 sections, 2 risers.

Ø: 40, 35, 30mm.

Leg Ø: 22mm.

1 levelling leg.

24 lighting

SENIOR STAND

007XU

124cm 325cm 122cm 118cm 7,3kg

20kg 6,[email protected] Type 14 109, 110, 110G

Stainless steel stand.

3 sections, 2 risers.

Ø: 35, 30,25mm.

Leg Ø: 22mm.

1 levelling leg.

HEAVY DUTY

STAND

126CSU

131cm 333cm 131cm 126cm 8,3kg

40kg [email protected] Type 14 109, 110, 110G

Chrome plated steel stand.

3 sections, 2 risers.

Ø: 40, 35, 30mm.

Leg Ø: 22mm.

1 levelling leg.

TALL STAND

111CSU

146cm 380cm 155cm 102cm 9kg

25kg [email protected] Type 14 103, 104, 104G

Chrome plated steel stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm. Leg Ø: 22mm.

1 levelling leg. The small footprint makes this stand perfect for tight spaces.

TALL STAND

111BSU

146cm 380cm 155cm 102cm 9kg

25kg [email protected] Type 14 103, 104, 104G

Black chrome plated steel stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

1 levelling leg.

The small footprint makes this stand perfect for tight spaces.

lighting 25

SUPER ALU STAND

269BU

144cm 455cm 144cm 174cm 8kg

35kg 6,[email protected] Type 14 103, 104, 104G

Aluminium stand.

4 sections, 3 risers.

Ø: 50, 45, 40, 35mm.

Leg Ø: 30mm.

1 levelling leg.

26 lighting

SUPER STEEL STAND

270BSU

144cm 477cm 144cm 174cm 13,5kg

40kg [email protected] Type 14 103, 104, 104G

Black chrome plated steel stand.

4 sections, 3 risers.

Ø: 50, 45, 40, 35mm.

Leg Ø: 30mm.

1 levelling leg.

There is a reason we call this the super stand!

Incredible reach of 477cm that can support fixtures up to 40kg.

SUPER STEEL

STAND

270CSU

144cm 477cm 144cm 174cm 13,5kg

40kg

[email protected]

Type 14

103, 104, 104G

Chrome plated steel stand.

4 sections, 3 risers.

Ø: 50, 45, 40, 35mm.

Leg Ø: 30mm.

1 levelling leg.

HIGH SUPER

ALU STAND

269HDBU

190cm 730cm 173cm 174cm 10kg

10kg [email protected] Type 14 103, 104, 104G

Alluminium stand.

6 sections, 5 risers.

Ø: 50, 45, 40, 35, 30, 25mm.

Leg Ø: 30mm.

1 levelling leg.

lighting 27

PEG ADAPTER SET

087PA

0,6kg

To be used where, for safety reasons, the stand must be secured to the floor.

ø 80mm . Set of three.

WIND-BRACING KIT

087WBK

1kg

Wind bracing kit of 3 ropes.

Length: 10m.

Not supplied with the stand.

SAFETY COLLAR 30MM

697

Secondary safety system for all speaker stands.

When locked into position, it stops upper stand sections from dropping when you open the stand locking knob.

SAFETY COLLAR 35MM

698

Same as 697, for 35mm tube.

SAFETY COLLAR 40MM

699

Same as 697, for 40mm tube.

28 lighting

BLACK ALU STAND

EXTENSION

142B

2,4kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) black aluminium extension.

Minimum height: 125cm.

Maximum height: 210cm.

STAND EXTENSION

142CS

3,6kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) chrome steel extension.

Minimum height: 125cm.

Maximum height: 210cm.

BLACK ALU STAND

EXTENSION

142ABS

2,1kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) black aluminium extension.

Length: 104cm.

BLACK ALU HIGH

STAND EXTENSION

146B

2,8kg Top type 14 Bottom type 37

3 sections (Ø 35, 30, 25mm) black aluminium extension.

Minimum height: 137cm.

Maximum height: 314cm.

BLACK ALU SHORT

EXTENSION

142SHB

2kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) black aluminium extension.

Minimum height: 75cm.

Maximum height: 110cm.

SHORT STAND

EXTENSION

142CSSH

3kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) chrome steel extension.

Minimum height: 75cm.

Maximum height: 110cm.

STAND EXTENSION

142ACS

2,1kg Top type 14 Bottom type 37

2 sections (Ø 35, 30mm) chrome steel extension.

Minimum height: 125cm.

Length: 104cm.

HIGH STAND

EXTENSION

146CS

4,8kg Top type 14 Bottom type 37

3 sections (Ø 35, 30, 25mm) chrome steel extension.

Minimum height: 137cm.

Maximum height: 314cm.

lighting 29

17,5mm female attachment plus spigot.

28mm (or 16mm) die cast aluminum socket and 16mm stud.

All stands are equipped with free running wheels.

Leveling Leg.

30 lighting

Quick action folding legs.

Aluminium versions

Electric welded aluminum tubing for higher mechanical performance and reduced weight.

Steel versions

Chrome-plated steel tubing.

This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Practical and quick positioning of light fixture.

Low profile for easy positioning in the studio.

STEEL STUDIO STAND

297CS

123cm 207cm 120cm 100cm 6,8kg

20kg [email protected] Type 14

Black steel base, chrome steel sections, complete with wheels.

2 sections, 1 riser.

Ø: 35, 30mm.

1 levelling leg.

COLUMN STAND

231CS

35cm 250cm 121cm 100cm 8kg

8kg [email protected] Type 1 + Spigot Art. 013

Chromium plated steel post: Ø: 35mm.

Height of light fixture: from ground level to 250cm.

Complete with braked wheels.

1 levelling leg.

ALU COLUMN

STAND

231B

35cm 250cm 121cm 100cm 6,4kg

8kg [email protected] Type 1 + Spigot Art. 013

Black aluminium post: Ø: 35mm.

Height of light fixture: from ground level to 250cm.

Complete with braked wheels.

1 levelling leg.

lighting 31

BABY STUDIO STAND

299B

108cm 272cm 105cm 75cm 4,8kg

12kg 2,[email protected] Type 3 + Spigot Art. 013

Black steel base, silver anodised aluminium sections, complete with wheels.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

1 levelling leg.

ALU STUDIO STAND

298B

129cm 300cm 125cm 100cm 6kg

15kg [email protected] Type 14

Black steel base, silver anodised aluminium sections, complete with wheels.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

1 levelling leg.

32 lighting

These bases can be used for backlights of most sizes.

Simply add a century stand column to create your own rolling stand.

For leg storage fold up in a small package.

Universal head with 28mm sockets plus either 16mm socket or “pop-up” spigot.

Low profile base that slips easily into position on sets.

Leg levelling feature.

FOOT BASE SMALL

299FBASE

21cm 36cm 75cm 3,5kg

40kg Type 14

1 levelling leg.

Complete with feet.

BRAKE BASE SMALL

299BBASE

28cm 36cm 75cm 4,8kg

40kg Type 14

1 levelling leg.

Complete with braked wheels.

FOOT BASE LARGE

297FBASE

21cm 52cm 100cm 4,4kg

40kg Type 14

1 levelling leg.

Complete with feet.

For compatible extensions see page 29.

BRAKE BASE LARGE

297BBASE

28cm 52cm 100cm 5,7kg

40kg Type 14

1 levelling leg.

Complete with braked wheels.

lighting 33

Maximum payload up to 80kg at 366cm.

Simultaneous extension and retraction of all sections.

All components inside transmission box are made of carbon-nitrided casehardened steel for improving wear resistance.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Assembled using bolts instead of rivets for simpler maintenance.

Double braced legs for extra stability, resistance and safety.

All stands in this series can be equipped with wheels

(including types with brakes).

34 lighting

28mm (or 16mm) socket and 5/8” + 3/8” stud.

Cable transmission is fully inside sections.

Chrome-plated steel tubing.

This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Third internal safety cable.

“Safe finger” protection.

Fold away crank handle for reducing protrusions during storage.

All models feature leveling leg.

Footrest for easy access to top section.

Aluminum feet for improved stability and longer durability.

2 SCT LOW BASE

WIND-UP STAND

083NWLB

129cm 190cm 112cm 100cm 11kg

35kg 2,[email protected] Type 14

Geared centrepost steel stand.

2 sections, 1 riser.

Ø: 55, 45mm.

1 levelling leg.

Fitted with braked wheels.

3 SCT LOW BASE WIND-UP

STAND

087NWLB

144cm 276cm 134cm 100cm 16kg

30kg 5,[email protected] Type 14

Geared centrepost steel stand.

3 sections, 2 risers.

Ø: 55, 45, 38mm.

1 levelling leg.

Fitted with braked wheels.

2 SCT WIND-UP

STAND

083NW

139cm 247cm 153cm 128cm 16kg

45kg [email protected] Type 14 104, 104G, 374-10

Chrome steel stand with geared column.

Elevation: 2.2cm per handle turn.

2 sections, 1 riser.

Ø: 55, 45mm.

Leg Ø: 30mm.

1 levelling leg.

lighting 35

36 lighting

SHORT WIND-UP STAND

087NWSH

135cm 276cm 155cm 128cm 15,5kg

30kg [email protected] Type 14 104, 104G, 374-10

Short version of 087NW.

3 sections, 2 risers.

Ø: 55, 45, 38mm.

Leg Ø: 30mm.

1 levelling leg.

WIND-UP STAND

087NW

167cm 370cm 181cm 128cm 21,4kg

30kg [email protected] Type 14 104, 104G, 374-10

Chrome steel stand with geared column.

2 risers extend simultaneously at an elevation of 4.4cm per handle turn.

Safety cable ensures simultaneous retrieval of all sections.

3 sections, 2 risers.

Ø: 55, 45, 38mm. Leg Ø: 30mm.

1 levelling leg.

SUPER WIND-UP

STAINLESS STEEL STAND

387XU

156cm 366cm 179cm 180cm 32,5kg

80kg [email protected] 28mm 374

Heavy lift stand with strenghtened stainless steel column and legs, chrome steel risers and geared column.

3 section Ø: 70, 60, 50mm.

2 risers which extended simultaneously at 4.4cm per handle turn.

Safety cable ensures simultaneous retrieval of all sections.

Rapid adjustment. Leg Ø 35mm. 1 levelling leg.

PATENTED lighting 37

35mm tot tube diameter.

Wide base with double leg braces for added stability and safety.

38 lighting

3/8’’ microphone top fitting.

Complete with grip collar that allows the stand to be set at the required height with single operation.

Lightweight rubber base reducing

”bottom end” frequencies being transmitted through the stand.

ALU MICROPHONE STAND

622B

195cm 108cm 2,7kg

2kg Type 36

Aluminium microphone stand.

STEEL MICROPHONE STAND

622CS

195cm 108cm 3,2kg

2kg Type 36

Chrome steel microphone stand.

MICROPHONE CLIP

MICC1

0,05kg

Standard type microphone clip.

MICROPHONE

SPRING CLIP

MICC2

0,05kg

Universal type microphone clip.

Grabs microphones from diameter 20mm to 35mm.

TABLE TOP TRIPOD

209B

4,5cm 13cm 13cm 0,09kg 2kg

Small and portable, this table top tripod complete with 3/8" top attachment for microphone fits into any small holdall ready to give quick support, in any location.

Supplied without microphone holder.

UNIVERSAL SHOCK MOUNT

MICROPHONE HOLDER

MICC4

0,121kg

Made in aluminium supplied with a rubber dampening system to prevent shocks and vibrations.

This rubber system allows efficient rapid microphone mounting.

The swiveling yoke has a 3/8” threaded hole that allows convenient mounting to the range of carbon fiber microphone booms.

Accepts a large variety of microphones.

lighting 39

LE LOW STAND

602BSM

125cm 205cm 104cm 118cm 5,7kg

50kg [email protected] 35mm 109, 110,110G

Black chrome plated steel stand.

2 sections, 1 riser.

Ø: 40 - 35mm.

Leg Ø: 22mm.

LE LEVELLING LEG STAND

126BMUAC

106cm 218cm 106cm 126cm 2,5kg

30kg [email protected] 35mm 109, 110,110G

Black aluminium stand, air cushioned.

2 sections, 1 riser.

Ø: 40, 35mm.

Leg Ø: 22mm.

1 levelling leg.

40 lighting

LE SELF LOCK STAND

256BMUAC

109cm 218cm

106cm

126cm 2,5kg

20kg [email protected] 35mm 109, 110, 110G

Black steel base, aluminium sections, air cushioned stand.

2 sections, 1 riser.

Ø: 40, 35mm.

Leg Ø: 22mm.

1 levelling leg.

SELF LOCK SYSTEM PATENTED

LE MIDI STAND

604BSM

154cm 260cm 132cm 126cm 6,6kg

40kg [email protected] 35mm 109, 110, 110G

Chrome plated steel stand.

2 sections, 1 riser.

Ø: 40 - 35mm.

Leg Ø: 22mm.

LE MAXI STAND

606BSM

182cm 316cm 160cm 126cm 7,2kg

40kg [email protected] 35mm 109, 110, 110G

Chrome plated steel stand.

2 sections, 1 riser.

Ø: 40 - 35mm.

Leg Ø: 22mm. lighting 41

42 lighting

PAN SPIGOT M10

616-10

Rotating 28mm spigot with M10 screw attachment.

Smooth rotation is assured by a Teflon bearing.

Complete with locking knob to block panoramic position.

PAN SPIGOT M12

616-12

Not illustrated

Same as 616-10 with M12 screw attachment.

STAND TOP M10

611-10

M10 Bolt fixing for 32/38mm tube.

STAND TOP M12

611-12

Not illustrated

Same as 611-10 with M12 screw.

LE 16MM ADAPTER

623

Designed to fit speaker stands, it forms a top fixing which mounts luminaires that have a 16mm spigot.

Fits top tubes with diameters between

32mm and 38mm.

28MM ADAPTER

617

Designed to fit speaker stands, it forms a top stand fixing which mounts luminaires with a 28mm spigot.

Fits top tubes with diameters between

32mm and 38mm.

SPEAKER ADAPTER

FOR 28MM BUSHING

618

This speaker adapter (35mm diameter) can be mounted on all lightstands equipped with a 28mm bushing.

SPEAKER ADAPTER

FOR STAND

619

Female adapter equipped with 35mm stud for stands with top tube diameter between

32mm and 38mm.

TILTING SPEAKER

ADAPTER

624

Designed to be mounted onto tubes from 32mm to 38mm diameter.

It is equipped with a 35mm speaker stud tilting from 0° to 20°.

0° to 20°

CABINET FITTINGS

612

Ramsa / Bose universal adaptor for 32/38mm tube.

SAFETY COLLAR 35MM

698

Secondary safety system for all speaker stands.

When locked into position, it stops upper stand sections from dropping when you open the stand locking knob. lighting 43

44 lighting

Sometimes a stand simply can’t fit on set during a shoot, so Manfrotto has developed several families of clamps to position lights and accessories practically anywhere. The original SUPERCLAMP - world famous and widely copied - stands out for its versatility and numerous accessories, but the entire range of clamps ensures there’s always a solution to your problem, no matter the size of the object or the surface you’re clamping to. Designed with many years of experience in the field, our clamps’ quick-action locking buttons help the operators and make their life easier.

Contents

Spring Clamps

Pipe Clamps and Quick Action Clamps

Super Clamps

Super Clamps Accessories

Page

46

47

48

49 lighting 45

Wide choice of spring clamps and grips covers a huge range of applications.

Constructed of aluminium or sheet steel, the clamps have thousands of uses, from supporting lights to clamping backgrounds to crossbars.

SPRING CLAMP

175

SPRING CLAMP WITH

FLASH SHOE

175F

0,32kg Type 1 Type 17

Clamps onto bars up to Ø 40mm.

Type 17

Ø 40mm max

0,33kg Type 1 Type 17 2kg

Clamps onto bars up to Ø 40mm.

Supplied with a position able miniature ball head with a flash shoe attachment to allow it to clip and position a flash unit wherever it is needed.

156mm

MINI SPRING CLAMP

275

0,11kg Type 1 Type 17

Clamps onto bars up to Ø 35mm.

It can be mounted also on 16mm extension arms.

107mm

Type 17

Ø 35mm

max

SKY HOOK

043

0,65kg Type 22 Type 1+ Spigot art. 013

Gaffer grip with adjustable jaws.

Grip from: 25mm to 65mm.

Type 1 + Spigot Art. 0

13

Ty pe

2

2

Ø 65mm

Ø

2

5mm

46 lighting

255mm

MULTICLIP

375

0,08kg

This versatile double clip can be used to hold gels in front of lights or small reflecting panels.

114mm

SKY HOOK

043R

Ty pe

2

2

0,8kg Type 22 Type 22

Gaffer grip with adjustable jaws.

Grip from: 25mm to 65mm.

Type 22

Ø 65mm

Ø 25mm

255mm

Manfrotto Pipe Clamps are made in aluminium alloy or rugged gravity cast aluminium for extra strength.

Clamping range encompasses pipes from 2mm to 78mm diameter.

All standard luminaire attachments available, from 16/28mm bushing to 16mm pins and 1/4” - 3/8” - M10 and M12 male thread.

MINI CLAMP

171

0,16kg 16mm

Clamps on bars up to Ø 35mm.

Ø 16mm

83mm

Ø 5mm

Ø 35mm

MICRO CLAMP

196AC

0,06kg

Grips items from 2mm to 16mm thick.

55mm

Ø 2mm

Ø 16m m

PANEL CLAMP

271

0,29kg 16mm

Clamps onto round and square tubes from Ø 22mm to 30mm.

Ideal for supporting reflector panels or hanging objects from pipes.

120mm

Ø 16mm

SAFETY CABLE

C155

Ø 4mm. Length 100cm. Max Load: 30 kg.

SAFETY CABLE

C155-01

Not illustrated

Ø 3,5mm. Length 70cm. Max Load: 20 kg.

QUICK RELEASE CLAMP

649

0,57kg 16mm 7kg

Different from the other versions that are used mainly on round pipes, this version will also work on square and rectangular tubes.

Extremely light, with a good "coupling range", this version also offers an incredible number of attachment sizes. Ideal for photographic applications and dedicated accessories. Pipe size 5-80mm.

PATENTED

4,54,5

135mm

16mm

3/8”W

Ø 5mm

Ø 80mm

16mm

25mm

1/4”W

1/4”W

3/8”W

SAFETY CABLE

C155-02

Not illustrated

Ø 5mm. Length 70cm. Max Load: 50 kg.

SAFETY CABLE

C155-03

Not illustrated

Ø 6mm. Length 100cm. Max Load: 60 kg.

lighting 47

Quite simply the most versatile single piece of light grip gear ever.

You name it and Super Clamp grips it, you imagine where you want it and Super Clamp holds it there.

Friction-lined screw-operated jaws grip everything from 13mm to 55mm.

Hexagonal socket with unique secondary safety lock system holds items in place even if the screw lock comes undone.

Supplied with a wedge to square off the jaws for mounting to flat surfaces.

This masterpiece of practicality and solidity is the most widely copied clamp in the world!

1/4” UNC

5/8” H ex agonal n°2 holes x M5

Ø 55mm

Ø 13mm

SUPER CLAMP

035

0,41kg 15kg

Ideal clamp for photographic application.

Ergonomic lever to securely lock clamping position.

STAINLESS SUPER CLAMP

035X

Not illustrated

Identical to the 035 with a weather resistant solution, provided with a stainless steel threaded shaft locking screw.

QUICK ACTION

SUPER CLAMP

635

0,47kg 15kg 16mm hexagonal + M5 & 1/4” threads

The rapid action locking jaw has also been applied to the most well known clamp in the world, the original Super Clamp.

These modifications allow us to keep its extreme versatility adding unrivaled speed in locking and unlocking.

Supplied with wedge to allow the clamp to fit on flat surface.

DOUBLE SUPER CLAMP

038

0,83kg

Set of two Super Clamps fastened together at fixed right angle to provide extra strength support for tubes or bars.

48 lighting

POLE FOR

BACKLITE STAND

122B

0,32kg Top Type 18 Bottom type 19

Extendable arm with double male spigot.

Min. height 48cm, max. height 80cm.

MINI ARTICULATED ARM

196A

0,35kg Type 17 Type 17 1kg

Swivelling arm; each section is separately locked.

Length: 60cm.

MINI ARTICULATED ARM WITH

CAMERA BRACKET

196

Not illustrated

Same as 196A with Camera/Umbrella Bracket 143BKT.

MAGIC ARM

143N

1,07kg Type 17 Type 17 3kg

Articulated arm with centre lever to lock all 3 movements.

Length: 53cm.

MAGIC ARM WITH

CAMERA BRACKET

143A

Not illustrated

Same as 143N with Camera/Umbrella Bracket 143BKT.

FLEX ARM

237

0,3kg Type 18 16mm 0,3kg

Flexible arm, Ø 12mm, 55cm long with hexagon stud to fit Super Clamp 035 with 3/8" female thread and 16mm stud with 1/4" male thread type 18.

TILT-TOP HEAD

155

0,5kg 16mm 16mm + Camera

Bracket Art. 143BKT

Twin swivelling 16mm spigots and single lever lock.

Supplied with: Camera/Umbrella Bracket 143BKT.

Height: 14.5cm.

VARIABLE FRICTION

ARM

244N

1,09kg Type 17 Type 17 3kg

Features as 143N, but a large locking knob takes the place of the cam-lever.

Variable friction and locking of arm obtained by adjusting knob.

VARIABLE FRICTION ARM

WITH CAMERA BRACKET

244

Not illustrated

Same as 244N with Camera/Umbrella Bracket 143BKT only.

FLEX ARM

HEAVY DUTY

237HD

0,3kg Type 18 16mm 0,5kg

Same as 237, but Ø 18mm.

TILT-TOP HEAD

155BKL

0,4kg 16mm 16mm

Tilt-top head alone, available separately without Camera/Umbrella Bracket.

lighting 49

NARROW “U” HOOKS

040

0,44kg

Set of two narrow "U" cross bar holders.

Plugs into Super Clamp 035.

Width: 15mm.

MINI “U” HOOKS

176

0,1kg

Set of two Mini “U” Hooks.

MINI B/P SINGLE

HOOKS

177

0,125kg

Set of two Mini “B/P” Single Hooks.

MINI

“L” BRACKETS

204

0,13kg

Set of two small brackets.

Sizes: 12 x 3 x 3cm.

MINI EXTENSION

ARM

203

0,15kg Type 1 + Spigot Art.013

Same as 042.

Length: 12cm.

ADDITIONAL

SOCKET

335AS

0,14kg

Provides an additional 16mm socket to Super Clamp 035.

50 lighting

“U” HOOKS

039

0,16kg

Set of two cross bar holders.

Width: 40mm

B/P SINGLE

HOOKS

059

0,42kg

Set of two wall fixing background paper holders for one Expan 046.

Plugs into Super Clamp 035 socket.

“L” BRACKETS

041

0,29kg

Set of two brackets to use in combination with Super Clamp 035 to support shelves, etc.17cm long x 4cm deep.

EXTENSION

ARM

042

0,21kg

8kg

Type 1 + Spigot Art.013

Plugs into Super Clamp 035 socket.

Length: 19,5cm.

SUPER CLAMP

WEDGES

035WDG

0,03kg

To allow the Super Clamp 035 to fit on plane surfaces.

Set of four.

ADAPTER SPIGOT

013

0,07kg

Universal 16mm spigot with double male thread 1/4” and 3/8”.

SHORT 16MM SPIGOT

WITH 1/4”+ 3/8”

SCREW

118

0,04kg

Universal short 16mm spigot with double male thread 1/4” and 3/8”.

ADAPTER SPIGOT

1/4”F + 3/8” F

THREADS

119

0,032kg

Universal short 16mm spigot with double female thread 1/4” and 3/8”.

LIGHTING STUD 3/8”

036-38

0,07kg

Plugs into Super Clamp 035 for lighting fixtures or connecting 2 Super Clamps

035 allowing them to rotate.

16mm stud with 3/8” male threads.

LIGHTING STUD 1/4”

036-14

0,07kg

Same as 036-38 with 1/4” male threads.

LIGHT STUD

036I

0,038kg

Special spigot for De Sisti & laniro lighting fixture.

CAMERA STUD

037

0,04kg

Plugs into Super Clamp 035 socket.

To mount cameras, directly or with a camera head. 3/8” and 1/4” threads.

JOINING STUD

061

0,025kg

Connects 2 Super Clamp 035 with 6 step fixed rotation.

JOINING STUD RA

061RA

0,025kg

Connects 2 Super Clamps 035 at right angles or 45° steps.

DOUBLE FEMALE

THREAD STUD

066

0,025kg

Plugs into Super Clamp 035 to provide either a 3/8” or 1/4” female thread fixing.

ROUNDED 16MM

LIGHTING STUD

M10

264

0,072kg

Rounded stud for stirrup’s fixture for a rapid connection to a Super Clamp.

HEXAGONAL 16MM

LIGHTING STUD

M10

174

0,062kg

Hexagonal Lighting stud for stirrup’s fixture for a rapid connection to a Super Clamp.

STUD FOR STIRRUP

066BT

0,048kg

16 mm stud with female thread M10.

It has been specifically designed to mount it on a stirrup’s fixture and easily connect it to a Super Clamp. Designed to be tightly lock with a wrench.

EXTENSION BAR

133

0,1kg

Used to fix 2 Super Clamps 035 at a distance of 15cm from each other. Length 16,5cm.

LIGHT STUD MR

036MR

0,04kg

Plugs into Super Clamp 035 for lighting fixtures, Grip Heads or connect 2 Super

Clamps 035 with 360° rotating capability.

lighitng 51

52 lighting

Used in conjunction with stands or clamps, the range of Manfrotto articulated arms, multi positioning arms and attachments enable accurate positioning of lighting and effects. Among the most remarkable products in this range are the double articulated arms, enabling quick positioning thanks to their quick lock knobs.

They are also renowned for being very light as well as very rigid. The Articulated Magic Arm and the Variable Friction Arm are also outstanding, using a single convenient and fast action locking lever or knob to lock or partially lock the two arms and the two swivel studs.

Contents

Arms

Brackets

Bars

Pump Cup

Page

54

58

58

59 lighting 53

Wherever you need to position your camera, light or accessory, we have an arm, a bracket or a bar to fit the task.

Can be combined with clamps, mounting plates and connectors and use in conjunction with virtually any product in the Manfrotto range.

MAGIC ARM KIT

143

2,55kg 16mm with 1/4” female attachment

3kg 16mm with 3/8” female attachment + Camera Bracket Art. 143BKT

Articulated arm with centre lever to lock all 3 movements.

Length: 53cm.

Supplied with: Camera/Umbrella Bracket 143BKT,

Super Clamp 035, Backlite Base 003.

VARIABLE FRICTION ARM WITH CAMERA BRACKET

244

1,09kg 16mm with 1/4” female attachment

3kg 16mm with 3/8” female attachment + Camera Bracket Art. 143BKT

Features as 143A, but a large locking knob takes the place of the cam-lever.

Variable friction and locking of arm obtained by adjusting knob.

Comes complete with Camera/Umbrella Bracket 143BKT only.

VARIABLE FRICTION ARM

244N

Not illustrated

Friction arm only, no accessories.

MAGIC ARM WITH CAMERA BRACKET

143A

1,07kg 16mm with 1/4” female attachment

3kg 16mm with 3/8” female attachment + Camera Bracket Art. 143BKT

Magic arm with camera bracket only.

MAGIC ARM

143N

Not illustrated

Magic arm only, no accessories.

CAMERA/UMBRELLA BRACKET

143BKT

Not illustrated

Camera bracket only.

54 lighting

FLEX ARM

237

0,4kg Type 18

16mm 0,3kg

Flexible arm, Ø 13mm, 55cm long with hexagon stud to fit Super Clamp 035 with 3/8" female thread and 16mm stud with 1/4" male thread type 18.

HEAVY DUTY FLEX ARM

237HD

0,75kg Type 18

16mm 0,5kg

Same as 237, but Ø 18mm.

CAMERA FLASH ARM

233B

0,44kg 1kg

Type 1 + Adapter Art.118

2 section (Ø 19 and 16mm) telescopic lift.

Minimum heigth: 30cm

Maximum heigth: 45cm.

BASE FOR ARTICULATED ARM

196BASE

2,2kg Type 1

Floor desk base for 196, 143, 237, 237HD and 244.

lighting 55

Manfrotto broadens its family of articulated arms, providing end users with a versatile and robust range of products with excellent performance.

The new articulated arms have been designed to be compact and lightweight yet offer high loads capacity and optimum arm length in order to guarantee extreme ease of use, practicality and positioning flexibility with improved safety and reliability.

SINGLE ARTICULATED ARMS: 2 & 3 SECTIONS

A more versatile version with telescopic features that make this product even more compact than before. Two available versions – at two and three sections- in order to ensure broad range of length, from 605 to 850 mm

Code

196AB-2

2

Sections

196AB-3

196B-2

196B-3

3

2

3

Top attachment

16mm spigot 3/8" light attachment

16mm spigot 3/8" light attachment camera bracket with 16mm spigot and camera attachment camera bracket with 16mm spigot and camera attachment

Bottom attachment

16mm spigot (compatible with

Superclamp) with 1/4" thread

16mm spigot (compatible with

Superclamp) with 1/4" thread

16mm spigot (compatible with

Superclamp) with 1/4" thread

16mm spigot (compatible with

Superclamp) with 1/4" thread

Max length

605mm

850mm

605mm

850mm

Max load at full extensions Weight

1,5kg 0,4kg

1kg 0,5kg

1,5kg

1kg

0,53kg

0,63kg

56 lighting

196AB-2

196AB-3

196B-2

196B-3

Sliding extensions allow for flexible positioning -

Easy to use, even in reduced spaces.

Just turn knob to click-stop and arm position is immediately locked.

Double-anchored spigot with hexagonal (for Super Camp attachment)

& universal (for maximum compatibility) sections.

Gives extra strength and anti-rotation rigidity.

DOUBLE ARTICULATED ARMS:

2 & 3 SECTIONS

Excellent performance: robustness, lightness and versatility... these are the features of the new double articulated arm range.

The 396 family has been developed to provide greater robustness than the 196 range and to support heavier loads (upto 5kg), though keeping versatility thanks to its extendable sliding arm system (extends upto 860mm), further enhanced by its quick lock system.

The new bottom attachment adds to the strength and versatility of the 396, with a spigot that combines both a hexagonal part

(for anti-rotation fixing to the Superclamp system) and a universal adapter section (for fitting to a wide range of stands, clamps and accessories).

Code

396AB-2

2

Sections

396AB-3

396B-2

396B-3

3

2

2

Top attachment

16mm spigot 3/8" light attachment

16mm spigot 3/8" light attachment camera bracket with 16mm spigot and camera attachment camera bracket with 16mm spigot and camera attachment

Bottom attachment

Double-anchored 16mm hexagonal/universal spigot

Double-anchored 16mm hexagonal/universal spigot

Double-anchored 16mm hexagonal/universal spigot

Double-anchored 16mm hexagonal/universal spigot

Max length

625mm

860mm

625mm

860mm

Max load at full extensions Weight

5kg 0,5kg

4,5kg 0,79kg

5kg

4,5kg

0,64kg

0,9kg

396AB-2

396AB-3

396B-2

396B-3 lighting 57

EXTENSION ARM

042

0,21kg 8kg Type 1 + Spigot Art. 013

Fits into Super Clamp 035 socket.

Length: 19,5cm.

MINI EXTENSION ARM

203

0,15kg 5kg

Fits into Mini Clamp 171 socket.

Length: 12cm.

“L” BRACKETS

041

0,29kg

Set of two brackets to use in combination with Super Clamp 035 to support shelves, etc. 17cm long x 4cm deep.

MINI “L” BRACKETS

204

0,13kg

Set of two small brackets for Mini Clamp 171.

Sizes: 12 x 3 x 3cm.

EXTENSION BAR

133

0,1kg

Used to fix 2 Super Clamps 035 at a distance of 15cm from each other.

Length: 16,5cm.

LIGHTING GANTRY BAR

135

0,9kg

For mounting lighting fixtures. Length: 2m.

To be fixed between 2 Autopoles by means of Narrow “U” Hooks 040.

Measurements: 200 x 3,5 x 1,5cm.

MICROPHONE SUPPORT

154

0,79kg 16mm 16mm + Spigot Art. 013

65cm long T Bar with 3 x 16mm sockets plus 3 x 16mm Spigot Art. 013.

Designed to fit on stand or bracket with 16mm pin.

58 lighting

FIVE SOCKET BRACKET

169

6,10kg 28mm 28mm 50kg*

100cm long T Bar with 5 x 28mm sockets for attaching up to 5 lighting fixtures.

Designed to fit on stand or bracket with 28mm socket.

*When load on one side only, max load capacity: 15kg.

T BAR

613

6 x Lantern T Bar 1420mm long.

T BAR

614

Not illustrated

4 x Lantern T Bar 1220mm long.

T BAR

615

Not illustrated

2 x Lantern T Bar 610mm long.

T BAR

613PAR

“T” Bar specifically design to carry six PAR 57 or 64 luminaires.

Supplied with a built in TV male spigot.

Max load capacity: 6kg on each attachments, only at the ends 12kg on each side.

PUMP CUP WITH 16MM

SWIVEL SOCKET

241

1,2kg 2kg 16mm

Suction cup for small fixtures and lightweight equipment.

Ø: 150mm. 16mm bushing with safety pin.

PUMP CUP WITH 16MM

SOCKET

241S

1,2kg 2kg 16mm

A suction cup with a fixed 16mm socket incorporating a safety pin for added security.

lighting 59

60 lighting

Lighting booms provide the ideal unobtrusive way to position lighting and reflector equipment directly above the subject.

The incredible number and variety of flash and continuous lights used, as well as their positioning requirements, have quickly made this range one of our most comprehensive lines.

We also have a wide selection of accessories available for customizing booms and make them easier to use.

Contents

Lighting Booms

Lighting Booms Accessories

Page

62

66 lighting 61

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 62

Boom arms allow you to position your lights in the most difficult positions.

Strong steel or tubular aluminium construction; counterweighted for smoothness of operation and stability.

Our considerable range allows you to choose the length, load capacity and support type that suits you, whether you’re working from the ground on lighting stands, or directly from the wall or ceiling.

MEGA BOOM (STAND

NOT INCLUDED)

425B

15kg 6kg* 16mm/28mm

Largest boom in the range, remote control of pan, tilt and rotation of laminar plus geared telescopic extension.

Combination of black zinc steel and black anodised aluminium tubes.

2 sections (Ø: 45, 55mm). Folded length: 220cm. Supplied with carrying bags.

Min. extension from stand attachment: 50cm. Max. extension from stand attachment: 320cm. Suggested stand: Wind-Up series.

* 6kg at maximum extension.

BLACK LIGHT BOOM

(STAND NOT INCLUDED)

085BSL

8,9kg 6kg* Type 25 + Spigot Art. 013

Ø 35mm. 3 section boom arm complete with Pivoting Clamp 123, Counter Weight 022, cable clips and locking key.

Load: 6kg at 230cm with 20kg of counter weight. Weight: 2.2kg, boom only.

Dismantled length: 100cm. Assembled: 280cm.

* 6kg at maximum extension.

BLACK SUPER BOOM

(STAND NOT INCLUDED)

025BSL

10,8kg 5kg* Type 17 + Rapidapter Art. 014-38

Ø 35mm. 1 section boom complete with Pivoting Clamp 123, Counter Weight 022, cable clips.

Load: 5kg at 200cm with 20kg of counter weight. Weight: 4.1kg, boom only. Remote control of lighting movement. 270cm long.

* 5kg at maximum extension.

62 lighting

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 63

BLACK LIGHT BOOM

(STAND INCLUDED)

085BS

Not illustrated

16,4kg Type 25 + Spigot Art. 013

Ø 35mm 3 section boom arm complete with Pivoting Clamp 123, Counter Weight 022,

Cine Stand with casters, cable clips and locking key.

Load: 6kg at 230cm with counter weight. Weight: 2.2kg, boom only. 16.4kg including stand.

Dismantled length: 100cm. Assembled: 280cm.

BLACK SUPER BOOM

(STAND INCLUDED)

025BS

Not illustrated

21kg Type 17 + Rapidapter Art. 014-38

Ø 35mm 1 section boom arm complete with Pivoting Clamp 123, Counter Weight 022,

Cable Clips and Cine Stand 008 with casters.

Load: 5kg at 200cm with 20kg of counter weight. Weight: 4.1kg, boom only. Remote control of lighting movement.

270cm long.

lighting 63

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 64

64 lighting

Wall Bracket included

LIGHT BOOM (STAND NOT INCLUDED)

024B

5,7kg Type 25 + Spigot Art. 013

Boom attaches to the shaft of most lightstands with diameters of 19, 20, 25, 28mm.

Ø: 25mm 3 sections boom arm complete with Pivoting Clamp 124,

Counter Weight 023, cable clips and locking key.

Weight: 1.4kg (boom only). Load: 3kg at 170cm with counter weight.

Dismantled length: 71cm. Assembled length: 200cm

AUTOBOOM (STAND NOT INCLUDED)

254B

5,3kg Type 25 + Spigot Art. 013 + type 37

Boom arm for heavy stand or wall bracket mounting featuring self balancing spring system.

Maximum load: 4kg at Maximum extension, 8kg at Minimum extension.

Supplied with wall bracket.

Minimum extension: 110cm. Maximum extension: 200cm.

SUPER BOOM WITH COLUMN STAND

025TM

18,5kg Type 17 + Rapidapter Art. 014-38

Ø 35mm. 1 section boom arm complete with Pivoting Clamp 123,

Counter Weight 022, Cable Clips and Column Stand with casters.

Load: 5kg at 200cm with 20kg of counter weight.

Weight: 4.1kg, boom only. 140cm long.

WALL BOOM (STAND NOT INCLUDED)

098B

2,3kg Type 25 + Spigot Art. 013

Wall mounted boom arm. 2 section (Ø 35, 29mm).

Rotation: 160° vertically and 180° horizontally.

Load, at full extension: 4.5kg.

Minimum extension: 120cm. Maximum extension: 210cm.

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 65

SHORT WALL BOOM

(STAND NOT INCLUDED)

098SHB

Not illustrated

2kg Type 25 + Spigot Art. 013

Load: 5kg.

Minimum extension: 78cm. Maximum extension: 122cm.

lighting 65

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 66

MINI BOOM

173B

0,32kg Type 18 and Type 19

Boom shaft Ø: 20mm. Length: 109cm.

LONG MINI BOOM

173HOB

Not illustrated

Long version of 173B. Length: 150cm.

G-PESO

022

6,7kg

Counterweight. Clamps on Ø 22mm to 35mm.

L-PESO

023

Not illustrated

4,3kg

MINI COUNTER WEIGHT

172

1,3kg

Clamps on bars from Ø 13mm to 30mm.

66 lighting

E0647_62-67*LIGHTING BOOMS.qxd 12-01-2006 8:41 Pagina 67

PIVOTING BOOM CLAMP

123

0,72kg

Pivoting clamp for Ø 35mm boom shaft

Ø 28mm male and Ø 16mm attachment.

PIVOTING BOOM CLAMP

124

0,67kg

Pivoting clamp for Ø: 19, 20, 25 and 28mm boom shafts

(or any tubes of these diameters).

BABY DROP

DOWN PIN

E700

0,62kg 16mm 16mm

For a more accurate light positioning: it helps keeping the light in horizontal position independently on the angle of the boom. Specifically designed to be used on boom arm with light attachment with 16 mm pin.

JUNIOR DROP

DOWN PIN

E710

1,32kg Type 35 Type 34

Same as E700, designed to be used on boom arm with light attachment with 28 mm bushing.

lighting 67

E0647_68-69.qxd 12-01-2006 8:41 Pagina 68

68 lighting

E0647_68-69.qxd 12-01-2006 8:41 Pagina 69

The ultimate adjustable lighting pole system can be used to create a background support, structure a lighting grid, or for hundreds of other studio applications. Its unique single action cantilever locking system exerts the correct amount of pressure to assure a secure fit, wedging the protective rubber ends in place wall to wall or ceiling to floor.

The cantilever system incorporates a safety lock to prevent accidental de-tensioning or movement.

Contents

Autopole

Autopole 2

Autopole accessories

Mini Autopole

Page

70

71

72

73 lighting 69

Unique cantilever single action locking system exerts pressure to securely wedge the rubber suction cup ends in place.

Cantilever system incorporates safety lock.

Floor to ceiling, or wall to wall fixing for strong vertical or horizontal support of lighting.

Loading limits

The following figures are valid for use with rigid floors and ceilings, and with the protection-cups mounted on the suction-cups.

AUTOPOLE

032

0,5m

1m

2,2kg

Extends from 210cm to 370cm.

Pole Ø: 45mm and 40mm.

F0 F1

F2

AUTOPOLE

076

1,83kg

Extends from 150cm to 270cm.

Pole Ø: 45mm and 40mm.

Load [kg]

Model

032

076

077

332-1,7

332-2,7

332-3,7

432-1,7

432-2,7

432-3,7

F0: maximum axial load

F1: maximum load with 0,5m arm

F2: maximum load with 1m arm

2m

Autopole Extension

F

Double Super

Clamp 038

Model

032

076

077

332-1,7

332-2,7

332-3,7

432-1,7

432-2,7

432-3,7

Load [kg]

F

20

20

20

20

20

20

20

20

20

70 lighting

AUTOPOLE

077

1,5kg

Extends from 100cm to 170cm.

Pole Ø: 45mm and 40mm.

AUTOPOLE 2

432-3.7

2,6kg

Two position variable thrust.

Extends from 210cm to 370cm.

Pole Ø: 45mm and 40mm.

PATENTED

AUTOPOLE 2

432-2.7

2,23kg

Two position variable thrust.

Extends from 150cm to 270cm.

Pole Ø: 45mm and 40mm.

PATENTED

AUTOPOLE 2

432-1.7

1,9kg

Two position variable thrust.

Extends from 100cm to 170cm.

Pole Ø: 45mm and 40mm.

PATENTED

MINI AUTOPOLE

332-3.7

1,38kg

Extends from 210cm to 370cm.

Pole Ø: 35mm and 32mm.

MINI AUTOPOLE

332-2.7

1,13kg

Extends from 150cm to 270cm.

Pole Ø: 35mm and 32mm.

MINI AUTOPOLE

332-1.7

0,85kg

Extends from 100cm to 170cm.

Pole Ø: 35mm and 32mm.

Autopole2 ® locking system with 2 setting for thrust tension.

lighting 71

AUTOPOLE BASE

032BASE

86cm 126cm 1,2kg

For tubes: Ø 45mm.

Legs Ø: 22mm.

72 lighting

MINI POLE BASE

170BASE

62cm 106cm 0,67kg

For tubes: Ø 28mm.

Legs Ø: 22mm.

AUTOPOLE SPIRIT LEVEL

032SPL

Spirit level for use on Autopole ® , or on tubes of 25mm to 60mm diameter.

AUTOPOLE PROTECTION CAPS

032PC

Set of four protection caps for rubber feet with inner hole.

Ø: 16.5mm. Suitable for use with all Autopoles except Midi Autopole ® 332 and Mini Pole 170.

EXTENSION TUBE

033

0,69kg

Autopole ® Extension tube.

Ø: 40mm.

Length: 2m.

Suitable for Autopole2 ® and Autopole ® .

EXTENSION TUBE

034

0,53kg

Autopole ®

Ø: 40mm.

Extension tube.

Length: 1,5m.

Suitable for Autopole2 ® and Autopole ® .

MINI POLE

170

0,87kg

Spring loaded mini pole.

Extends from 175cm to 330cm.

Post Ø: 25mm and 28mm.

lighting 73

74 lighting

Our extremely modular background support system is reliable, simple to use and flexible enough to match most of your support needs for paper, drapable, hand-painted or canvas backgrounds, in the studio or on location. For core mounted backgrounds the system used is based on the EXPAN chain operated drive developed by Manfrotto.

The EXPAN can be mounted on dedicated hooks which vary in shape and design depending on the number of backgrounds to be used.

If, as usually happens with canvas backgrounds, there is no central core around which to wrap the background material,

Manfrotto provides a three section telescopic pole that can be attached on top of a set of two stands, making it ideal for location assignments.

Contents

Page

Motorised Expand Background Support System 76

Background Support System 78 lighting 75

Manfrotto motorised background support system composed by:

Background roll supporting spigots Single version only (1 pair for each background to be supported):

Code: 850

Control box with Infra Red remote controller 2 versions are available depending on voltage of local mains electric supply:

Code: 851 (for 110V supply)

Code: 852 (for 220V supply)

Hooks (pair)

3 versions to support 4/6/10 backgrounds:

Code: 854-4

Code: 854-6

Code: 854-10

Mains electric power cable 3 different power leads are available to fit the most common electric sockets:

Code: 850US

Code: 850EU

Code: 850UNIV

CONTROL BOX - 220V

852

Main control box power supply voltage - 230V 50Hz

(European version) with Infra Red remote controller.

Manfrotto’s motorised EXPAN system is based on the well known manual

EXPAN device, a fast and efficient paper background drive set designed by Manfrotto to easily and rapidly roll and unroll all types of backgrounds

(using a similar technique to that used on window blinds). The 852 and 851

EXPAN background units build on the practicality of the original concept and add motorised, remote controlled practicality and ease of use to perfectly control the deployment of up to 10 backgrounds.

Controls up to 10 motors (therefore 10 backgrounds).

Operating functions controlled by included IR remote controller.

Advanced IR communication functions.

- Remote controller and control box are both programmable for operation on one of seven different channels - therefore if two control box systems are used in the same room, they can be set to different channels to avoid interference. In this case, it is not possible to control both main control boxes with one remote IR controller.

- Communication protocol IRUP - Infra Red over UPSEC Protocol.

- Advanced IR receiver is very sensitive to remote controller signal but extremely disruption-proof.

- Advanced background motor control functions.

- Each channel has independent, programmable background stop levels for max and min extension positions. Positions are remembered even after power off.

- Manual mode background positioning.

- “Overload sensor” - automatically stops motor to protect equipment in case of overloading.

- “All backgrounds up” function - automatically rolls all backgrounds with a single touch of a button.

- “Background Start-up” function for easy background positioning in manual mode.

- “Fast stop” function - stops the background immediately, also reduces motor inertia after power off.

- Advanced background rolling modes, which speed-up system operation i.e. rolling up unused backgrounds.

Integrated easy-read display (digit height 45mm) shows selected background number.

Standby mode for minimised power consumption.

Internal software upgrades possible via ordinary PC (cable and software upgrades supplied separately).

Communication follows UPSEC protocols to permit future extensions of the product (e.g. control by PC, radio, etc.).

Sound signals for easy operation.

Customisable - user can change parameters of the control box such as background working modes, sound on/off, etc.

Owing to differences in international standards, main power supply cable is not included.

Each control box has two “test” functions, which roll selected backgrounds up and down.

76 lighting

CONTROL BOX - 110V

851

Not illustrated

Main control box power supply voltage - 110V 50/60Hz

(Asia/US version) with Infra Red remote controller.

BACKGROUND ROLL

SUPPORTING SPIGOT

850

Supplied in sets (one set = 1 passive roller and 1 active motor drive).

Heavy duty motor to allow operation of heavy backgrounds

(up to 12kg) Smooth operation thanks to cardan - type clutch

Equipped with hall-effect electronic position sensors, enable positioning precision down to 1/3 of a turn.

Very easy to install - just plug in jacks.

Cable to Main control Unit 1.5 meter length.

HOLDER FOR 4 BACKGROUNDS

854-4

Set of two universal holders for 4 backgrounds.

Can be hung from wall or ceiling.

Holders max load (depending on wall/ceiling) 100kg.

Supplied screws may not be suitable for all wall/ceiling types.

MAIN POWER CABLE - USA

850US

Main power cable for Control Box USA plug.

Type NEMA5-15P - 2.5mt long.

HOLDER FOR 6 BACKGROUNDS

854-6

Set of two universal holder for 6 backgrounds.

Can be hung from wall or ceiling.

Holders max load 140kg when holders are attached to the ceiling,

70kg if attached to the wall.

Supplied screws may not be suitable for all wall/ceiling types.

MAIN POWER CABLE - EUROPEAN

850EU

Main power cable for Control Box European plug.

Type CEE7-Y11 - 2.5mt long.

HOLDER FOR 10 BACKGROUNDS

854-10

Set of two universal holder for 10 backgrounds.

Can be hung from wall or ceiling.

Holders max load 180kg (depending on wall/ceiling).

Supplied screws may not be suitable for all wall/ceiling types.

MAIN POWER CABLE

850UNIV

Main power cable for Control WITHOUT PLUG.

- 2.5mt long.

MOTORISED EXPAN 220V WITH HOLDER

FOR 4 BACKGROUNDS

852K-4

Not illustrated

Composed by 852 + 854-4 + 850EU and four 850.

MOTORISED EXPAN 110V WITH HOLDER

FOR 4 BACKGROUNDS

851K-4

Not illustrated

Composed by 851 + 854-4 + 850EU and four 850.

lighting 77

The Manfrotto background support system is based on the Expan, a fast and efficient background drive set.

Insert the EXPAN into the background roll, block and use the chain to roll the paper up and down as you wish.

A system of hooks is available in pairs and can support 1, 3 or 6 backgrounds when used in conjunction with the Expan.

B/P Hooks can be attached to Autopole by using the Super Clamp code 035 or screwed directly onto a wall or ceiling.

EXPAN

046

1,2kg 10kg

Background paper drive set for one roll. Including plastic chain and weight.

Expands from: Ø 46mm to 78mm.

EXPAN WITH METAL CHAIN

046MC

Not illustrated

Same as 046 with metal chain.

78 lighting

B/P TRIPLE HOOKS

045

2,05kg

Set of two background paper holders for three Expan 046.

Can be fixed to a wall with supplied studs and screws, or to Super Clamp 035 by means of supplied screw set.

B/P HOOKS

045-6

4,4kg

Set of two brackets for six Expan 046 sets.

To be fixed to a wall with supplied screws.

B/P CLAMPS

044

2,85kg

Same as 045 but ready for use on Autopoles ®, including two Super Clamp 035.

B/P SINGLE HOOKS

059WM

0,54kg

Wall fixing background paper holder set for one Expan 046.

Complete with screw set.

B/P SINGLE HOOKS

059

0,42kg

Set of two wall fixing background paper holders for one Expan 046. Plugs into Super Clamp 035 socket.

MINI SINGLE HOOKS

177

0,125kg

Set of two hooks for Expan 046 background paper holder to fit on Mini Clamp 171.

lighting 79

EXPAN CHAIN - 1M LONG, GREY

091G

0,06kg

1m extra chain for Expan 046 to extend the standard one.

Available also in the following colours:

Red - code 091R;

Black - code 091B.

EXPAN CHAIN - 3M LONG, GREY

091FLG

Not illustrated

3m extra chain for Expan 046.

Available also in the following colours:

Red - code 091FLR;

Black - code 091FLB.

EXPAN RED METALLIC CHAIN

091MCR

0,6kg

Can replace plastic chain on Expan 046.

Total length: 3.5m.

Available also in the following colours:

Grey - code 091MCG;

Black - code 091MCB.

CHAIN WEIGHT

094

0,3kg

Provides weight to keep Expan chain tight.

B/P COUNTERWEIGHT

062-2

0,85kg

Counterweight for background paper in 2 sections.

Length: 275cm.

80 lighting

ALU-CORE

047-2

1,28kg

Aluminium core in 2 sections Ø: 50mm for uncored back round paper.

Has adhesive tape for sticking on paper. Length: 275cm.

ALU-CORE

047-3

Not illustrated

Same as 047-2 but longer. Lenght: 366cm.

SET STANDS KIT

314B

4,2kg 10kg*

Designed to support rolls or sheets of background paper or any other background material.

The kit comprises of:

1 x 3 Section Telescopic Pole Art. 272,

2 x Baby Stand Art. 052,

2 x Mini Spring Clamp Art.275 and Transport Kit Bag.

* distributed on background roll

TELESCOPIC POLE

272B

Not illustrated

3 section telescopic background pole on it’s own.

Minimum extension: 112cm.

Maximum extension: 298cm.

Weight: 0.25kg.

Attachments: type 25.

lighting 81

82 lighting

Ideal for all photo and video studios where the floor needs to be kept totally clear of power cables and lighting stands, the Sky Track System permits rapid manoeuvre and setting of suspended large lights or lights with awkwardly sized accessories like soft boxes.

It solves positioning problems even on complex sets or in studios of the most unusual dimensions, and offers considerable advantages and ease of use compared to traditional floor stands.

Manfrotto Sky Track System has a broad range of accessories to adapt your space to the ideal studio and to provide perfect compatibility with all types of lights, whether photographic, video or film.

Contents

Rails

Rails attachments

Carriages

Fixed supports

Cable Carriages

Accessories and Adapters

Pantographs

Telescopic Posts and Extensions

Power Supply and Remote Controls

Kits

Page

91

92

94

95

84

85

88

90

95

96 lighting 83

The Sky Track System is a comprehensive range of lighting suspension for all situations from small studios to the largest ones.

Manfrotto line includes the versatile ceiling mounted, rails, manual and motorised pantographs and a wide range of brackets and support.

3M RAIL ANODIZED (BLACK)

FF6003B

These rails are made in section of black anodized aluminium in standard lengths as listed.

For fixed rails, longer sizes are obtainable by fitting two or more rails together.

Sliding rails cannot be joined. To connect two fixed rails use code FF3208. You must always support the junction of two rails with a ceiling attachment placed on the junction itself.

Moving rails longer than 3m must be supported with more than two fixed rails.

The maximum distance (B) between any of these fixed rails is 2m (see drawing).

ANCHORAGE POINT

The spacing of the rail support brackets depends on the load anticipated on the rail itself, but should generally be in accordance with the table below, “A” indicates the distance between two anchorage points.

However we advise that fixing brackets should not be spaced more than 2m apart.

4M RAIL ANODIZED (BLACK)

FF6004B

Not illustrated

5M RAIL ANODIZED (BLACK)

FF6005B

Not illustrated

RAIL

SECTION

Mobile Rails

B B

34,5mm

RAIL WORKING MAX LOAD CHART

A (mm) WEIGHT (kg)

1000

1500

2000

200

100

50

84 lighting

MAX

1m/40kg

Fixed Rails

Ceiling Attachments

A

A

A

BRACKET FOR CEILING

ATTACHMENT

FF3210

Bracket for ceiling attachment of the rail.

It is advisable to pre-assemble these brackets onto the rails at ground level to ensure correct alignment before screwing to a ceiling.

ANGLE BRACKET (“L”-SHAPED)

FOR FIXING TO BEAMS

FF3212

Bracket for wall attachment of the rail.

ADJUSTABLE BRACKET FOR

IRREGULAR CEILINGS

FF3215

Allows height differences in ceilings of maximum

2cm; combining two brackets you can compensate for differences of maximum 4cm.

DOUBLE BRACKET FOR

RAIL CROSSINGS

FF3211

This is used to permanently attach two rails at a right angle or parallel.

lighting 85

CEILING BRACKET WITH

30CM EXTENSION

FF3216

CEILING BRACKET WITH

50CM EXTENSION

FF3218

Not illustrated

CEILING BRACKET WITH

100CM EXTENSION

FF3220

Not illustrated

Used alone or in combinated these brakets allow the attachment of the rails at the desidered height.

86 lighting

EXTENSION BRACKET FOR

VARIOUS HEIGHTS

FF3215A

Its length is adjustable from 10cm to 15,5cm. Using the clamp screw, you can obtain all intermediate sizes. Provided with a security lock, in case the regulating screw loosens, blocks the bracket at maximum extension. It's used to compensate for height differences in ceilings of

5,5cm or more, with combinations of other brackets. It's also used for obtaining intermediate sizes in combination with the extendable ceiling brackets.

KIT OF 4 END STOPS WITH 4

CABLE CARRIAGES

FF3207

These fit to the holes on the ends of a rail to prevent carriages leaving the rail and to prevent moving rails leaving their carriages.

IMPORTANT: must be fitted to upper and lower holes on moving rails but only to lower holes on fixed rails

BRACKET FOR TUBE

ATTACHMENT

FF3214

This can be fastened to tubes with diameters from 35mm to 50mm inclusive.

It's used to directly support the rail that can be fixed in place either longitudinally or transversely.

This bracket can be used as a brace for fixed supports, as well.

BRACKET FOR CEILING

ATTACHMENT

FF3214A

Can be attached directly by screws or rods with a maximum diameter of 1/2". Before mounting the bracket it is advisable to standardize the length of both the rods and screws.

Fix the bracket between a nut allowing the screw on the inside of the bracket to protrude about 1,5cm. When fixture is completed, it is then possible to regulate a perfect rail levelness by adjusting the nuts which fasten the brackets.

RAIL MOUNTING KIT

WITH M12 STUD

FF3214B

Comprised of a bracket to be attached to the ceiling with 4 screws, a 1m long

M12 rod completely threaded, 4 M12 nuts, and a bracket for the rail fixture.

The rod can be cut to the desidered size and then attached to the bracket by way of the nuts supplied.

The rod must protrude approx 1cm on the inside of the bracket.

When fixture is completed, it is then possible to regulate a perfect rail levelness by adjusting the nuts which fasten the brackets.

ALIGNING CONNECTORS

FOR FIXED RAILS

FF3208

A pair of clamp plates with screws to join two fixed rails together by clamping across the junction on the upper guide, using holes provided in the rail.

IMPORTANT: the junction must always be supported by a rail-mounting bracket placed astride lighting 87

DISMOUNTABLE SLIDING CARRIAGE WITH

4 WHEELS AND 16MM SPIGOT

FF3228

This carriage can be inserted directly at any point on the rail by unscrewing the wheel plate. This is used when it becomes necessary to add a supplementary carriage to an already assembled RAIL SYSTEM installation. It is free-sliding and is suitable for normal loads.

4-WHEELED SLIDING CARRIAGE

WITH 16MM SPIGOT

FF3230

It is free-sliding carriage.

It is suitable for normal weight loads up to 60kg.

MOTORISED CARRIAGE

WITH 16MM SPIGOT

FF3340

It is powered with a 24 Vdc motor and must be fed and operated by an electronic power supply, code FF3288M/FF3286M.

4-WHEELED SLIDING CARRIAGE WITH

BRAKE AND 16MM SPIGOT

FF3229

This is provided with a brake which keeps it locked in the position where it is placed. It is suitable for normal loads up to 60kg.

To release brake pull down on wire with operating pole.

MOTORISED HEAD

FF3450

Motorised head with 2 motors for the rotation made up of a small bank, flash or television camera. It has a 16mm spigot on both sides.

It can be positioned between a pantograph and utilisation

(illuminator, small bank, flash, video camera, etc.) or it can also be mounted onto a stand. It allows a combined rotation of 360° on axis X and 110° on axis Y. It is powered by two 24 Vdc motors that must be fed and operated by an electronic power supply FF3288M/FF3286M1; motor powers the rotation on axis X and the other on the axis Y.

88 lighting

DOUBLE SLIDING CARRIAGE

FF3232

Both the upper carriage and the lower one are free-sliding.

DOUBLE SLIDING CARRIAGE

WITH DOUBLE BRAKE

FF3235

This is equipped with brakes on both upper and lower carriages.

The upper brake blocks the carriage on the fixed rail, while the lower carriage's brake blocks the sliding of the moving rail.

DOUBLE SLIDING CARRIAGE

WITH ONE BRAKE

FF3236

This is provided with a brake on only one carriage. Normally, the carriage with brake is mounted on the fixed rail so that it is locked into place enabling the mobile rail to slide. If the carriage with brake is mounted onto the mobile rail, you obtain the opposite effect, that is, the sliding of the mobile rail gets blocked, while the carriage can freely slide on the fixed rail.

MOTORISED DOUBLE CARRIAGE

FF3350

The upper carriage is powered by a 24 Vdc motor which must be fed and operated by an electronic power supply code FF3288M/FF3286M.

The lower carriage is equipped with a brake which blocks the mobile rail from sliding.

DOUBLE SLIDING CARRIAGE

WITH AN EXTRA HEIGHT

FF3325

It is used together with the motorized carriage code FF3350.

The upper carriage, is as high as the motorized carriage.

Both the upper carriages and the lower one are free-sliding.

lighting 89

FIXED BRACKET ON RAIL

WITH 16MM SPIGOT

FF3856

The 16mm spigot allow the mounting of lights or accessories with 16mm female attachment.

FIXED BRACKET ON RAIL WITH

FEMALE ATTACHMENT 16MM

FF3221

The 16mm socket allows the mounting of lights or accessories with 16mm male attachments.

SET OF 2 SUPPORTS WITH TRIPLE

BACKGROUND HOOKS

FF3224

These can be fixed directly onto the rails in order to have the backgrounds in a fixed position, or they can be fixed to simple carriages with the help of the fixed brackets code FF3221, in order to have a background in a movable position.

90 lighting

KIT OF 5 CABLE CARRIAGES

WITH BEARING

FF3226C

These are from the end of the rail and run on ball-bearings.

They are suitable for heavy cables.

KIT OF 5 CABLE

CARRIAGES

FF3226

These are inserted from the end of the rail.

They do not need wheels as they they slide along the rail and are suitable for normal cables.

CABLE HOLDER CARRIAGES FOR

LARGE SECTION CABLES

FF3226V

Runs on ball bearings.

Holds cables up to 16mm diameter.

KIT OF 5 DISMOUNTABLE

CABLE CARRIAGES

FF3226S

By slightly opening them, they can be inserted at any point on the rail.

They are suitable for light weight cables.

OPERATING POLE

428-2.5

4 sections, 3 risers. Ø: 28, 24, 20, 16mm.

Minimum extension: 100cm. Maximum extension: 250cm.

Closed length: 80cm.

OPERATING POLE

428-4.0

Not illustrated

4 sections, 3 risers. Ø: 28, 24, 20, 16mm.

Minimum extension: 140cm. Maximum extension: 400cm.

Closed length: 120cm.

OPERATING POLE

428-7.5

Not illustrated

3 sections, 2 risers. Ø: 28, 24, 20mm.

Minimum extension: 260cm. Maximum extension: 750cm.

Closed length: 210cm.

lighting 91

SPIGOT ADAPTER 16MM FEMALE

28MM FEMALE

FF3257

It has a 16mm female attachment on one side and a 28mm female attachment on the other.

It is used to fit accessories with 28 spigot to the RAIL SYSTEM.

SPIGOT ADAPTER

16MM/28MM

FF3260

This adapter has a 16mm spigot on one side and a 28mm female attachment on the other. It is used to connect accessories with 28mm spigot to the RAIL SYSTEM. It comes complete with safety pins.

SPIGOT ADAPTER

013

Both sides have 16mm spigot.

Used to connect two units with 16mm female attachment or to obtain 16mm spigot from a 16mm female attachment.

16MM FEMALE ADAPTER

158

Both sides have a 16mm attachment.

Used to connect two units with 16mm spigot, or to obtain a 16mm female attachment from 16mm spigot.

BALANCE ADJUSTMENT

BRACKET

FF3261

It has 16mm female attachment, to be fitted between pantograph and unbalaced lighting fixtures or other appliances.

Easy adjustment, by means of a single lever, allows the pantographs to work properly.

92 lighting

POLE OPERATED

TELESCOPIC BAR

362

Designed to support heavy light fittings, and provide pole operated pan plus tilt.

Closed length: 35,5cm.

Maximum height: 49cm.

Male attachment Ø 28mm and 16mm.

OVERHEAD OUTLET-BOX WITH

3 UNIVERSAL SOCKETS

FF3272

It has a 16mm female attachment with shear pin and locking screw.

Comes complete with 5m of three-pole cable (3 x 1,5 Sq.mm) without plug.

Max load 2000 Watts.

BRACKET FOR MULTIPLE

MOUNTING

FF3262

Has seven 16mm spigot and can be mounted, either in a horizontal or a vertical position, to pantograph or extensions.

Can carry up to six appliances.

POWER SUPPLY CABLE

FF3278

15m of three-core cable (3 x 1.5 Sqmm) with special sockets for lighting fixture.

UNIVERSAL SUPPORT FOR FLASH

GENERATORS AND BALLAST

FF3265

Maximum width is 52cm and max height 22cm.

A 16mm spigot mounted on the bracket allows fitting to RAIL SYSTEM.

lighting 93

PANTOGRAPH TOP 4C

FF3514N86

The pantograph is made of aluminium (P-Al MgSi UNI 3569) and manufactured according to DIN 15560-46. The attachments at both ends of the pantograph are 16mm, male on the bottom and female on the top. The load is supported by a steel cable of 2mm. diameter (safety factor 12). Loads up to 12Kg can be suspended using only the patented friction device, while loads up to a maximum of 18kg require the use of the optional springs. The pantograph can be regulated to keep suspended loads from 1 to 18kg perfectly balanced. By turning the coulored notched ring you can adjust the pantograph’s friction; this will ensure that the load remains stable when set in position, but that it will move smoothly up and down when necessary. In any case, it is always advisable to use the springs to aid raising your pantograph. When choosing the additional spring(s) for your pantograph, you will first need to know exactly which model of pantograph you have, in order that you can select the spring of the correct length. If you have one of the new compact pantographs (with grey-painted

"scissors"), look at the colour of notched ring the 2m version has a red notched ring, while the 3.8m version has a blue notched ring. After having identified the length of the pantograph, choose the appropriate spring(s) by refering to the table below.

Model

Lifting Rope

Safety Factor rope

Self Weight

Max working Load

Closed Length

Max Extension

Width

FF3514N86

2mm wire rope

12

7.3kg

18Kg

38cm

380cm

15cm

FF3512N86

2mm wire rope

12

4.7kg

18Kg

27cm

200cm

15cm

Width

PANTOGRAPH TOP 2C

FF3512N86

Same as FF3514N86 but shorter.

94 lighting

SPRING TYPE 4 RED

FF3531

Additional Spring for pantograph top 2C.

SPRING TYPE

12 RED

FF3532

Not illustrated

Additional Spring for pantograph top 2C.

SPRING TYPE

Without Spring

Type 4

Type 4 + Type 4

Type12

Type 4 + Type 12

SPRING TYPE 4 BLUE

Additional Spring for pantograph top 4C.

SPRING TYPE

12 BLUE

FF3534

Not illustrated

Additional Spring for pantograph top 4C.

COUNTER BALANCED WEIGHT

From 0kg to 4kg

From 3kg to 8kg

From 8kg to 14kg

From 9kg to 16kg

From 13kg to 18kg

FF3533

TELESCOPIC POST EXTENDABLE

FROM 85CM TO 203CM

FF3248

A telescopic system for the balanced suspension of loads.

Adjustable in height with automatic positioning at the desired position. A female attachment with safety plug and locking lever is fitted at each end. The safety plug has a latch with push-button releaselatch with push-button release.

To adjust the balance of the load, rotate the handle clockwise or counterclockwise.It sustains loads from 1.5kg up to 12kg max.

SMALL TELESCOPIC POST EXTENDABLE

FROM 60CM TO 128CM

FF3249

Not illustrated

Same as FF3248, extendable from 60cm to 128cm.

EXTENSION TUBE 50CM LONG

FF3240

These are fixed extenders which have a female 16mm attachment at each end. You fix them directly on the spigot of single carriages or to the fixed support FF3222.

EXTENSION TUBE 100CM LONG

FF3242

Not illustrated

Same as FF3240, 100cm long.

SAFETY STEEL CABLE

FF3276

Complete with spring catch and hook-up slot. Recommended for TELESCOPIC POST and TOP PANTOGRAPH in order to avoid accidental falling of equipment.

Ø 2mm - Length 350mm.

POWER SUPPLY KIT 8 CHANNEL

FF3288MKIT

The kit is composed of:

1 Power unit to convert 220Vac to 24Vdc - FF3288M.

1 Remote control with 8 up/down push buttons - FF3289M.

POWER SUPPLY KIT 4 CHANNEL

FF3286MKIT

Not illustrated

The kit is composed of:

1 Power unit to convert 220Vac to 24Vdc - FF3286M.

1 Remote control with 4 up/down push buttons - FF3287M.

lighting 95

TOP TWIST

FF3290

Large lighting banks can be hung from the ceiling and manoeuvred using the Top Twist, thanks to its combination of tracks/rails, carriages and remotely-controlled motor groups.

Two parellel rails, mounted on double carriages that run on the ceiling rails, carry the bank suspension group and allow it to be manually moved backwards and forwards.

The central plate allows 360° motorised rotation (around the axis) and permits manual movement side to side on the rails.

The bank supported on the rail/central support can be raised & lowered at three points, each of which is controlled by an independent motor.

Manual movements are made easier by the supplied cables (with handles).

Motorised movements are bi-directional and run by an electronic control box with remote control unit.

The kit is composed of:

3 Rails 3m long - FF6003B.

1 Rotation kit composed of complete 360° rotation plate, rail spacers and string complete with handgrips - FF3285.

8 Endstops - FF3207.

1 Motor group complete with sliding carriage - FF3282.

1 Double motor group complete with sliding carriage - FF3283.

1 4-channels electronic power supply - FF3286M.

Attention: Please note that the following parts are not included in the kit here pictured, and they should be ordered separetely:

Rail fixing brackets.

4 end stops.

4 double carriages.

Cable carriages.

Remote control.

For soft box with max size: 2,5 x 1,3-1,5mt

Max load: 22kg

96 lighting

TOP TWIST/S

FF3400

Large lighting banks can be hung from the ceiling and manoeuvred using the Top Twist, thanks to its combination of tracks/rails, carriages and remotely-controlled motor groups.

Two parellel rails, mounted on double carriages that run on the ceiling rails, carry the bank suspension group and allow it to be moved backwards and forwards.

The central plate allows 360° motorised rotation (around the axis) and permits manual movement side to side on the rails.

The bank supported on the rail/central support can be raised & lowered at three points, each of which is controlled by an independent motor.

All movements are motorised & bi-directional, run by an electronic control box with remote control unit.

The kit is composed of:

3 Rails 3m long - FF6003B.

1 Motorised rotation kit with 2 TOP COPTER/S, motors, composed of 360° rotation plate, rail spacers and string complete with handgrips - FF3408.

8 Endstops - FF3207.

1 Motor group complete with sliding carriage - FF3282.

1 Double motor group complete with sliding carriage - FF3283.

1 8-channels electronic power supply - FF3288M.

Attention: Please note that the following parts are not included in the kit here pictured, and they should be ordered separetely:

Rail fixing brackets.

4 end stops.

2 double motorised carriages, FF3350.

2 double sliding carriages, FF3325.

Cable carriages.

Remote control.

For soft box with max size: 2,5 x 1,3-1,5mt

Max load: 22kg lighting 97

TOP SYSTEM 32

FF3032

Complete kit for small studios composed of 3 rails

3M long (two fixed and one mobile) and supports for 2 light sources (2 Telescopic Post).

The kit is composed of:

3 Rails 3m long - FF6003B.

2 Kits of 4 endstops - FF3207.

6 Brackets for ceiling fixture - FF3210.

2 Kits of 5 cable carriages - FF3226.

2 4-wheeled sliding carriages with 16mm spigot - FF3230.

1 Double sliding carriages - FF3232.

1 Double sliding carriages with single brake - FF3236.

2 Telescopic Post extendable from 85cm to 203cm - FF3248.

2 Universal spigot adapters 16mm - 013.

2 Safety steel cable - FF3276.

2m

4m

TOP SYSTEM 33

FF3033

Complete kit for small studios composed of 2 fixed rails

3m long, 2 mobile rails 3m long and supports for

3 light sources (1 Top Pantograph and 2 Telescopic Post).

The kit is composed of:

4 Rails 3m long- FF6003B.

3 Kits of 4 endstops - FF3207.

6 Brackets for ceiling fixture - FF3210.

3 Kits of 5 cable carriages - FF3226.

3 4-wheeled sliding carriages with 16mm spigot - FF3230.

2 Double sliding carriages - FF3232.

2 Double sliding carriages with single brake - FF3236.

2 Telescopic Post extendable from 85cm to 203cm - FF3248.

1 Top Pantograph extendable from 40cm to 200cm - FF3512N86.

2 Universal spigot adapters 16mm - 013.

3 Safety steel cable - FF3276.

2m

98 lighting

4m

TOP SYSTEM 43

FF3043

Complete kit for medium-sized studios composed of 2 fixed rails 4m long, 2 mobile rails 3m long and supports for 3 light sources (3 Top Pantographs).

The kit is composed of:

2 Rails 3m long - FF6003B.

2 Rails 4m long - FF6004B.

3 Kits of 4 endstops - FF3207.

6 Brackets for ceiling fixture - FF3210.

3 Kits of 5 cable carriages - FF3226.

3 4-wheeled sliding carriages with 16mm spigot - FF3230.

2 Double sliding carriages - FF3232.

2 Double sliding carriages with single brake - FF3236.

3 Top Pantograph extendable from 40cm to 200cm - FF3512N86.

3 Safety steel cable - FF3276.

2m

3m

4m

TOP SYSTEM 54

FF3054

Complete kit for large studios composed of 2 fixed rails 5m long, 3 mobile rails 3m long and supports for 5 light sources (4 Top Pantographs).

The kit is composed of:

2 Rails 5m long - FF6005B.

3 Rails 3m long - FF6003B.

4 Kits of 4 endstops - FF3207.

8 Brackets for ceiling fixture - FF3210.

4 Kits of 5 cable carriages - FF3226.

4 4-wheeled sliding carriages with 16mm spigot - FF3230.

3 Double sliding carriages - FF3232.

3 Double sliding carriages with single brake - FF3236.

4 Top Pantograph extendable from 40cm to 200cm - FF3512N86.

4 Safety steel cable - FF3276.

2m

4 m lighting 99

100 lighting

Indispensable for all professional still life photographers, Manfrotto Still Life tables are made with lightweight aluminum tubing, dedicated clamps and translucent white Perspex covers for back- or front-lighting of your subject. Their design allows continuous adjustment of the curved backdrop at different angles, making them ideal for product photography. Full modularity makes the table easy to assemble and disassemble. The Manfrotto Still Life line is complete with the well-known Multiclamp system. This extremely flexible and modular system allows you to design and create all sorts of supports that can be easily set up, dismantled and reused for completely different applications. Several accessories will allow you to deal with specific problems.

Contents

Still life tables

Clamps

Feet and wheels

Miscellaneous

Panels and holders

Page

102

104

107

108

109 lighting 101

Multi-purpose shooting tables.

Model 220 is fully compatible with the Multiclamp range giving you the possibility to modify and adapt its features to your needs.

Easily assembled/disassembled aluminium structure.

STILL LIFE TABLE

220

18,6kg 15kg

Still Life Table with white, translucent perspex cover for back or front lighting.

Size of panel: 200cm x 122cm.

Distance from floor to flat surface: 83cm.

Height with back on vertical position: 193cm.

Adjustable tilting back.

STILL LIFE TABLE

WITHOUT COVER

220PSL

Not illustrated

Same as 220, without perspex cover.

PERSPEX COVER

FOR STILL LIFE TABLE

220PX

Not illustrated

White, translucent perspex cover for back or front lighting.

Size of panel: 200 x 122cm.

Quick-change spring clips hold the table cover to the frame.

102 lighting

Adjustable tilting back.

Easy tool-free assembly.

MINI STILL LIFE TABLE

320

10kg 10kg

Smaller version of Still Life Table model 220.

Size of panel: 150 x 78cm.

Distance from floor to flat surface: 70cm.

Height with back in vertical position: 157cm.

Adjustable tilting back and adjustable front legs.

MINI STILL LIFE TABLE

WITHOUT COVER

320PSL

Not illustrated

Same as 320, without perspex cover.

PERSPEX COVER FOR MINI

STILL LIFE TABLE

320PX

Not illustrated

White, translucent perspex cover for back or front lighting.

Size of panel: 150 x 78cm.

Adjustable tilting back Easy tool-free assembly.

lighting 103

A modular system of tubes and clamps that can be combined together to provide a very fast and re-usable structure to support or suspend all or part of the subject that you are shooting.

Extreme flexibility and ease of assembly thanks to the choice between two fixture systems - permanent mounting using nuts and bolts, or temporary mounting using locking levers, which require no tools.

Clamps are available only in black.

The tubes, made of lightweight high resistance aluminium alloy, are available black or silver anodised.

Tubes measure 35mm in diameter and are available in four different lengths: 50, 100, 150 and 200cm.

A separate tube cutter is also available to adapt the standard lengths to your specific needs.

104 lighting

BASIC CLAMPS

MT001

Used to connect tubes at a right angle.

38

85

47

23

64

VARIABLE ANGLE CLAMP

MT002

Used in conjunction with MT001 to create a structural pivot.

46

DOUBLE VARIABLE

ANGLE CLAMP

MT003

Used in conjunction with two MT001, to bridge one structural pivot into two.

53 53

“T” CLAMP

MT004

Used like MT001, when a stronger connection is required.

80

23

23

M8

30

50

30

M8

RIGHT ANGLE CLAMP

MT005

Used to connect a third or fourth crossing tube on the same axis.

ARTICULATED JOINT 180°

MT045

Two tubes can be fixed at any angle from 90° to +90°.

M8

30

97

47

30

M8

ARTICULATED JOINT 360°

MT046

Joins two tubes at any angle from 180° to +180°.

lighting 105

85

38

47

90°CURVED CLAMP

MT029

Joins two tubes at 90° to each other.

47

85

38

80

98

31

55

160

FIVE-WAY BASE CLAMP

MT056

Joins upto five tubes on the same plane at 72° to each other, plus one tube on the perpendicular plane.

PANEL CLAMP

MT013

Used to clamp large panels.

27 20

35

0-20

PARALLEL CLAMP

MT014

Used to clamp two tubes in parallel.

49

35

35

M10

30

8

M8

FOOT ADAPTER

MT021

Expands and locks into tubes enabling the connection of various accessories (MT022, MT023, MT027, etc.).

22

60

38

46

WALL TO WALL ADAPTER

MT024

Used to fix tubes from wall to wall.

106 lighting

35

47

ADJUSTABLE FOOT

MT022

Must be connected with MT021.

M10

55

48

8

65

LARGE FOOT ADAPTER

MT036

Used to fix a tube to wall or floor.

30

10

M8

63

RUBBER TUBE FOOT

MT015

Set of 2.

25

15

15

30

DISK FOOT

MT030

Must be connected with MT021 or MT025.

50

350

8

12

39

46

45

RUBBER TUBE COVER

MT016

Set of 2.

M10

80

OUTDOOR SPIKE

MT023

Must be connected with MT021 or MT025.

120

11

60

DISK BASE

MT065

Base plate for added stability.

WHEEL SET

103

Ø: 80mm without brakes, with M10 attachment.

Set of three.

WHEEL SET

104G

Ø: 100mm without brakes, with M10 attachment.

Set of three.

WHEEL SET

104

Wheel set Ø: 75mm with brakes and M10 attachment.

Set of three.

lighting 107

63

30

RUBBER SUCKER

MT034

Used to support smooth panels/glass above horizontal tubes.

Can be used as a foot below horizontal tubes (set of 2).

16MM SOCKET

MT025

Used to mount stardard 16mm light fixtures.

M8

30

13

17

TUBE END PLUG

MT017

Closes the ends of tubes.

Not suitable for use as a foot (set of 2).

35

4

TUBE CONNECTOR

MT020

Used to connect two tubes end to end.

M8

60 100

16

4-38

185

160

TUBE CUTTER

MT018

Cut multiclamp tubing to the exact length you need for made-to-measure structures.

50CM LONG

ALUMINIUM TUBE

MT105

108 lighting

SLIDING SUPPORT ARM

231ARM

Quick release arm, used to mount standard 16mm light fixtures, attachments 16mm female and Spigot 013

(16mm male and 1/4” - 3/8” screws).

9

30

35

100CM LONG

ALUMINIUM TUBE

MT110

150CM LONG

ALUMINIUM TUBE

MT115

200CM LONG

ALUMINIUM TUBE

MT120

500-750-1000-1500

PANEL WITH HOLES

MT007

These panels have plastic clips at either end which grip onto tubes to allow the creation of continuos planes (non-walkable) for use as shelves, supports or narrow walls.

Length: 500mm.

PANEL WITH HOLES

MT008

Not illustrated

Length: 750mm.

150

PANEL

MT007P

Same as MT007, without holes.

Length: 500mm.

PANEL

MT008P

Not illustrated

Length: 750mm.

500-750-1000-1500

150

PANEL WITH HOLES

MT009

Not illustrated

Length: 1000mm.

PANEL

MT009P

Not illustrated

Length: 1000mm.

PANEL WITH HOLES

MT011

Not illustrated

Length: 1500mm.

PANEL

MT011P

Not illustrated

Length: 1500mm.

300

220

BROCHURE HOLDER

MT062

53

40

40

78

35-45

78

AUTOPOLE TO MULTITUBE ADAPTER

MT052

Used in conjunction with MT021 to connect multitube with 40-45mm tubes.

lighting 109

110 cine

Manfrotto’s Cine line, hallmarked by the AVENGER brand, includes everything you need in a motion picture studio. There you can find a wide range of lighting stands and supports, light modifiers, hooks, booms, articulated arms, pump cup supports, bars, clamps and a large selection of accessories allowing customization of products and set-ups.

Product quality is the hallmark of this range, which can withstand extreme use, rough atmospheric conditions, very high stress and heavy loads. All products have been designed under the supervision of the most demanding film grippers to match the strict quality standards and performance needs of the motion picture industry. Last but not least, the design of our products and the full use of bolts instead of rivets allow quick and simple maintenance.

All AVENGER products in this brochure are highlighted by the logo, which you will also find on the products themselves.

Contents

STANDS

SCRIMS & FLAGS MOUNTINGS AND SUPPORT SYSTEM

BUTTERFLY MOUNTINGS & SUPPORT SYSTEM

CLAMPS

BOOMS, ARMS, BRACKETS, BARS

PUMP CUP AND WALL PLATES cine 111

112 cine

The Avenger stand range includes several product families, featuring different designs and materials depending both on the applications they are intended for and on the light type they have to support. These supports have been designed for to be both safe and reliable. For that reason, all materials are top quality and are tested in order to withstand extreme uses in rough weather conditions. Assembly is made either with bolts – instead of rivets – for allowing quick and easy maintenance, or by welding or broaching, in order to ensure maximum operating reliability. These technical solutions make these stands unique and prevent the column sections from coming out, the knobs from getting lost and allow for quick leveling of the legs.

The existing versions allow for extensions between 40cm and 610cm, with payloads between 2kg and 100kg.

Contents

Quick guide

Baby Lightweight Stands

Roller Stands

Combo Stands

Boom Stands

Wind Up Stands

Strato Safe Stands

Wincher Stand

Page

114

116

120

124

128

130

136

142 cine 113

Manfrotto’s range of stands consists of different product families which differ in design and materials depending both on the applications for which they are intended and on the type of light they support.

To make reference to this section as easy and as useful as possible we have grouped the stands by load capacity: by knowing the weight of the light for which you need a stand you will be able to choose the one that match you needs from the different versions.

MAX LOAD

803cm:

Maximum Height

2kg 4kg 9kg 10kg

600cm

12kg 15kg 20kg 25kg

500cm

114 cine

400cm

300cm

200cm

100cm

0cm

Closed Length

Minimum Height

Maximum Height

430

413 413 413

392

385 385

340

330 330

297

315

290

268

267

250

239

198

120

98

90

91

107

109

122

132

115

95

139

124

108

98

115

105

131

113

124

118

124

122

138

134

66 66

69

40

20

A615B

p. 117

A608B

p. 117

A625B

p. 117

A630B

p. 118

A635B

p. 119

A400B

p. 118

A410B

p. 119

A475B

p. 129

A660

p. 121

A665

p. 121

A470

p. 129

A420

p. 121

A645B

p. 126

A430

p. 123

106

47

51

A450

p. 117

122

106

109

107

103

101

A416JM

p. 118

A004MT

p. 119

A005MT

p. 118

130

124

A690

p. 122

122

110

93

132

115

70

80

A680

p. 121

A125B

p. 125

A410C

p. 119

095 kg

1,4 kg

1 kg

2,2 kg

2,5 kg

3,5 kg

4 kg

4,6 kg

6 kg

6,3 kg

8,4 kg

6,4 kg

3 kg

6,9 kg

3,3 kg

7,3 kg

4,5 kg

4 kg

10,7 kg

8 kg

6 kg

6,1 kg

-

110,

100G

110,

100G

A9000 -

Type 21

Type 21

+

16mm

-

Type

16mm

16mm Type 21 Type 21 Type 33 Type 33 Type 33 Type 33 Type 33 Type 33 Type 33

-

110,

100G

-

Type 34

-

Type 33 Type 33

-

-

-

-

110,

100G

018 A9000B -

-

Type 3

Type 19

-

-

Type 3

+Spigot

Art. 013

Type 34 Type 34 Type 34

Type 33

-

Weight

Suggested Wheels

Spigot Size

Socket Size

30kg 35kg 40kg 45kg 70kg 80kg 90kg 100kg

610

500

467

428

427

408 408

390

386

360

345

333

350

325

330

325

296

220

58

48

74

94

83

141

158

118

116

134

167

188

201

181

165

143

175

153

261

198

209

134

130

153

131

158

134

146

142

167

143

173

153

184

153

185

155

172

101

93

225

190

154

196

172

192

222

174

186

155

136

122

97

165

A128

p. 125

A122

p. 125

A650

p. 126

A115B

p. 126

A105B

p. 127

A700

p. 129

B200

p. 132

B201

p. 133

A120

p. 125

A510

p. 122

A626BU

p. 127

A110

p. 126

A500

p. 123

A100

p. 127

B205

p. 131

B100

p. 139

B140XL

p. 140

B140

p. 140

B150

p. 140

B130

p. 138

B250X

p. 132

B120

p. 138

B300P

p. 139

B105

p. 137

3,7

kg

5,9

kg

A9000 A9000

7,5

kg

110,

100G

6,2 kg

A9000B

-

6,9

kg

15 kg

24 kg

17,8 kg

7,8 kg

13,6 kg

8,3 kg

11 kg

15,4 kg

12,2 kg

19 kg

41 kg

60 kg

62 kg

A9000B A9000

-

-

-

A9000

-

-

109,

110,

100G

-

A9000

-

A9000

-

-

-

-

-

-

71 kg

52 kg

39 kg

42 kg

-

-

-

-

-

-

-

-

64 kg

30 kg

-

-

-

-

Type 34 Type 34 Type 34 Type 34 Type 34 Type 34 Type 14 Type 14 Type 34 Type 34 Type 14 Type 34 Type 34 Type 34 Type 14 28mm 28mm 28mm 28mm 28mm 28mm 28mm 28mm 28mm cine 115

Aluminium versions

Electric welded aluminum tubing for higher mechanical performance and reduced weight.

Steeel versions

Chrome-plated steel tubing.

This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

116 cine

Double braced legs for extra stability, resistance and safety.

Top spigot available with 3/8”, 5/8” screw thread or type 3.

Spigot is broached inside aluminum tube for resistance and robustness.

Spigot is welded inside steel tube for maximum mechanical performance.

Parts made by die cast aluminium to ensure longer lasting mechanical performance and extension linearity of column.

Anti-extraction collars.

Captive lock offs thread into rust free steel inserts.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Assembled using bolts instead of rivets for simpler maintenance.

BACKLITE STAND

H.D.

A608B

20cm 98cm 66cm 68cm 1,4kg

4kg Base 16mm Pole type 21 + 16mm

Black steel legs and aluminium riser.

2 sections, 1 riser.

Ø: 25, 20mm. Leg Ø: 16mm.

MIGHTY BABY STAND

A450

51cm 106cm 47cm 44cm 3,30kg

15kg [email protected] Type 33

Chrome steel stand. 3 sections, 2 risers.

Ø: 35, 30, 25mm. Leg: 20 x 20mm.

1 levelling leg.

MINI KIT STAND

A615B

40cm 120cm 40cm 45cm 0,95kg

2kg Type 21

Black steel legs and aluminium risers.

4 sections, 3 risers. Ø: 25, 22, 19, 16mm.

Leg Ø: 16mm.

MIDI KIT STAND

A625B

69cm 239cm 66cm 94cm 1kg

4kg 16mm

Aluminium stand.

4 sections, 3 risers. Ø: 25, 22, 19, 16mm.

Leg Ø: 19mm.

cine 117

BABY J STAND

A416JM

122cm 267cm 106cm 116cm 7kg

15kg [email protected] Type 3

Chrome steel stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg: 20 x 20mm.

ALU-BABY STAND

A400B

112cm 268cm 95cm 129cm 3,5kg

10kg [email protected] Type 33

Black aluminium stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg: 20 x 20mm.

1 levelling leg.

RANKER STAND

A005MT

103cm 290cm 101cm 109cm 4kg

20kg [email protected] 018 Type 3 + Spigot Art.013

Zinc steel stand.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

Leg Ø: 22mm.

MIDI-MAX KIT STAND

A630B

91cm 330cm 90cm 96cm 2,2kg

9kg 1,[email protected] Type 21 110-110G

Black aluminium stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg Ø: 22mm.

This stand features captive lock-off T-knobs, high efficency, brake shoe locking risers and anodised black coating.

118 cine

MAXI KIT STAND

A635B

109cm 385cm 107cm 109cm 2,5kg

9kg 0,[email protected] Type 21 110-110G

Black aluminium stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg Ø: 22mm.

MASTER STAND

A004MT

109cm 385cm 107cm 109cm 4,5kg

15kg 2,[email protected] Type 19 018

Zinc steel stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg Ø: 22mm.

HIGH ALU-BABY

STAND

A410B

132cm 413cm 115cm 129cm 4kg

10kg [email protected] Type 33

Black aluminium stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg: 20 x 20mm.

1 levelling leg.

HIGH BABY STAND

A410C

132cm 413cm 115cm 129cm 6,1kg

25kg [email protected] Type 33

Black chrome steel stand.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg: 20 x 20mm.

1 levelling leg.

Fitted with grip truck mounts plus square legs, this high performance stand features double bracing.

cine 119

16mm stand top attachment.

28mm socket plus either 16mm socket or pop – up 16mm stud.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Anti-extraction collars.

Captive lock offs thread into rust free steel

Chrome-plated steel tubing: this surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Low profile for easy positioning in the studio.

120 cine

All stands are equipped with free running wheels and brake locks.

Assembled using bolts instead of rivets for simpler maintenance.

Double braced legs for extra stability, resistance and safety.

Quick action folding legs.

LOWBOY JUNIOR FOLDING BASE

STUDIO STAND

A680

80cm 122cm 70cm 75cm 8kg

25kg 3,[email protected] Type 34

Legs and column in steel, risers in aluminium, complete with wheels.

3 sections, 2 risers.

Ø: 45, 40, 35mm.

1 levelling leg.

BABY FOLDING BASE

STUDIO STAND

A660

108cm 250cm 98cm 75cm 6kg

12kg 2,[email protected] Type 33

Legs and column in steel, risers in aluminium, complete with wheels.

3 sections, 2 risers.

Ø: 35, 30, 25mm.

1 levelling leg.

BABY ROLLER STAND

A420

124cm 297cm 118cm 106cm 6,4kg

12kg [email protected] Type 33

Legs and column in steel, risers in aluminium, complete with wheels.

3 sections, 2 risers.

Ø: 35, 30, 25mm

Leg: 20 x 20mm.

HIGH BABY FOLDING BASE

STUDIO STAND

A665

115cm 330cm 105cm 75cm 6,3kg

12kg 1,[email protected] Type 33

Legs and column in steel, risers in aluminium, complete with wheels.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

1 levelling leg.

cine 121

HIGH JUNIOR FOLDING

BASE STUDIO STAND

A690

130cm 340cm 124cm 100cm 10,7kg

20kg [email protected] Type 34

Legs and column in steel, risers in aluminium, complete with wheels.

5 sections, 4 risers.

Ø: 45, 40, 35, 30mm.

1 levelling leg.

JUNIOR ROLLER STAND

A510

134cm 360cm 130cm 129cm 13,6kg

40kg [email protected] Type 34

Chrome steel stand, complete with wheels.

3 sections, 2 risers.

Ø: 45, 40, 35mm.

Leg: 25 x 25mm.

122 cine

HIGH JUNIOR ROLLER

STAND

A500

146cm 428cm 142cm 129cm 15,4kg

40kg 5,[email protected] Type 34

Chrome steel stand, complete with wheels.

4 sections, 3 risers.

Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm.

HIGH BABY ROLLER

STAND

A430

138cm 430cm 134cm 106cm 6,9kg

12kg [email protected] Type 33

Legs and column in steel, risers in aluminium, complete with wheels.

4 sections, 3 risers.

Ø: 35, 30, 25, 20mm.

Leg: 20 x 20mm.

cine 123

28mm (or 16mm) die cast aluminum socket and 16mm stud.

Aluminium version

Electric welded aluminum tubing for higher mechanical performance and reduced weight.

Steel version

Chrome-plated steel tubing.

This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

All versions have levelling leg for better stability.

Shock-resistant square section tubing.

124 cine

All stands in this series can be equipped with wheels

(including types with brakes).

All knobs are made of aluminum and threads are riveted for preventing losses.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Anti-extraction collars.

Captive lock offs thread into rust free steel.

Assembled using bolts instead of rivets for simpler maintenance.

Storage pin.

Double braced legs for extra stability, resistance and safety.

MINI LOW COMBO

A128

48cm 74cm 58cm 60cm 3,7kg

30kg Type 34 A9000

Chrome steel stand with aluminum riser.

2 sections, 1 riser. Ø: 35, 30mm.

Leg: 20 x 20mm. 1 levelling leg.

MINI LOW COMBO

STAND

A122

94cm 141cm 83cm 80cm 5,9kg

30kg [email protected] Type 34 A9000

Legs and column in steel.

Riser in aluminium.

2 sections, 1 riser. Ø: 45, 40mm.

Leg: 25 x 25mm. 1 levelling leg.

BLACK LOW ALU COMBO

STAND

A125B

110cm 198cm 93cm 80cm 6kg

25kg [email protected] Type 34 A9000B

Aluminium legs with aluminium risers.

3 sections, 2 risers. Ø: 45, 40, 35mm.

Leg: 25 x 25mm. 1 levelling leg.

LOW COMBO STAND

A120

101cm 198cm 93cm 80cm 7,8kg

35kg [email protected] Type 34

A9000

Chrome steel stand.

3 sections, 2 risers. Ø: 45, 40, 35mm.

Leg: 25 x 25mm. 1 levelling leg.

cine 125

CINE COMBO STAND

A650

118cm 220cm 116cm 118cm 7,5kg

30kg [email protected] Type 34 110-110G

Chrome steel stand.

2 sections, 1 riser. Ø: 35, 30mm.

Leg Ø: 22mm. 1 levelling leg.

ALU-CINE COMBO STAND

A645B

124cm 315cm 122cm 118cm 3kg

12kg 4,[email protected] Type 34 110-110G

Aluminium legs with aluminium risers.

3 sections, 2 risers. Ø: 35, 30, 25mm.

Leg Ø: 22mm. 1 levelling leg.

COMBO STAND

A110

158cm 325cm 134cm 135cm 11kg

40kg [email protected] Type 34 A9000

Chrome steel stand.

3 sections, 2 risers. Ø: 45, 40, 35mm.

Leg: 25 x 25mm. 1 levelling leg.

126 cine

BLACK ALU-COMBO

STAND

A115B

158cm 325cm 134cm 135cm 6,2kg

30kg [email protected] Type 34 A9000B

Aluminium legs with aluminium risers.

3 sections, 2 risers. Ø: 45, 40, 35mm.

Leg: 25 x 25mm. 1 levelling leg.

BLACK HEAVY DUTY STAND

A626BU

153cm 330cm 131cm 126cm 8,3kg

40kg [email protected] Type 14 109,110,110G

Black zinc plated stand.

3 sections, 2 risers. Ø: 40, 35, 30mm.

Leg Ø: 22mm. 1 levelling leg.

HIGH COMBO STAND

A100

167cm 408cm 143cm 135cm 12,2kg

40kg [email protected] Type 34 A9000

Chrome steel stand.

4 sections, 3 risers. Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm. 1 levelling leg.

BLACK ALU-COMBO STAND

A105B

167cm 408cm 143cm 135cm 6,9kg

30kg 2,[email protected] Type 34 A9000B

Aluminium legs with aluminium risers.

4 sections, 3 risers. Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm. 1 levelling leg.

cine 127

Top spigot is available with 5/8” male or 1” and 1/8” female fixing.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Chrome-plated steel tubing. This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

A special articulated coupler allows this model to be used either as normal stand or boom.

Excellent protection against corrosion and wear is ensured by aluminum anodization.

Assembled using bolts instead of rivets for simpler maintenance.

Can be equipped with brake-type wheels.

Double braced legs for extra stability, resistance and safety.

128 cine

Balancing weight or sandbag counterweight available.

BABY STEEL COMBI-BOOM

STAND

A470

131cm 392cm 113cm 109cm 8,4kg

12kg [email protected] Type 33 A9000

Chrome steel stand.

4 sections, 3 risers. Ø: 35, 30, 25, 20mm.

Leg: 20 x 20mm. 1 levelling leg.

COMBO BOOM STAND

A700

188cm 500cm 165cm 135cm 15kg

30kg [email protected] Type 34 A9000

Chrome steel stand. 4 sections, 3 risers.

Ø: 45, 40, 35, 30mm. Leg: 25 x 25mm. 1 levelling leg.

Min extension boom 155cm. Max load 30kg.

Max extension boom 266cm. Max load 8kg.

BABY COMBI-BOOM STAND

A475B

139cm 413cm 124cm 129cm 4,6kg

10kg 2,[email protected] Type 33

Supplied with sandbag counterweight (empty) for maximum stability and smoothness. Black aluminium stand.

4 sections, 3 risers. Ø: 35, 30, 25, 20mm.

Leg: 20 x 20mm. 1 levelling leg.

Min extension boom 113cm. Max load 15kg.

Max extension boom 213cm. Max load 5kg.

BABY DROP

DOWN PIN

E700

0,62kg 16mm 16mm

For a more accurate light positioning: it helps keeping the light in horizontal position independently on the angle of the boom.

Specifically designed to be used on boom arm with light attachment with 16 mm pin (e.g., D600).

JUNIOR DROP

DOWN PIN

E710

1,32kg Type 35 Type 34

Same as E700, designed to be used on boom arm with light attachment with 28 mm bushing (e.g., D650 or A700).

cine 129

28mm socket.

All components inside transmission box are made of carbon-nitrided casehardened steel for improving wear resistance.

Cable transmission is fully inside sections.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column.

Third internal safety cable.

28mm (or 16mm) socket or

5/8” + 3/8” stud.

Chilled top fixing for extra performance.

Chrome-plated steel tubing.

This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Simultaneous extension and retraction of all sections.

Fold away crank handle for reducing protrusions during storage.

Zinc-plated steel crank handle.

Footrest for easy access to top section.

Assembled using bolts instead of rivets for simpler maintenance.

Double braced legs or reinforced single braced legs for extra stability, resistance and safety.

130 cine

Free running wheels and braked wheels available.

Aluminum feet for improved stability and longer durability.

All models feature leveling leg.

2 SCT WIND-UP STAND

WITH BRAKED WHEELS

B205

153cm 261cm 173cm 152cm 19kg

45kg [email protected] Type 14

Chrome steel stand.

2 sections, 1 riser.

Ø: 55, 45mm.

Leg Ø: 30mm.

1 levelling leg.

cine 131

132 cine

SUPER WIND-UP STAINLESS STEEL

STAND WITH BRAKED WHEELS

B250X

172cm 386cm 196cm 180cm 39kg

80kg [email protected] 28mm

Heavy lift stand with strenghtened stainless steel column and legs, chrome steel risers and geared column.

3 section Ø: 70, 60, 50mm.

2 risers which extended simultaneously at 4.4cm per handle turn.

Safety cable ensures simultaneous retrieval of all sections.

Rapid adjustment. Leg Ø 35mm. 1 levelling leg.

PATENTED

Complete with braked wheels.

WIND-UP STAND WITH

BRAKED WHEELS

B200

181cm 390cm 201cm 142cm 24kg

30kg [email protected] Type 14

Chrome steel stand.

3 sections, 2 risers.

Ø: 55, 45, 38mm.

Leg Ø: 30mm.

1 levelling leg.

SHORT WIND-UP STAND

WITH BRAKED WHEELS

B201

153cm 296cm 175cm 142cm 17,8kg

30kg [email protected] Type 14 A9000

Chrome steel stand.

3 sections, 2 risers.

Ø: 55, 45, 38mm.

Leg Ø: 30mm.

1 levelling leg.

cine 133

134 cine

LONG STEEL STAND EXTENSION

C626

1,89kg Top type 34 Bottom type 35

Chrome lenght plated steel extension. Lenght 52cm.

MEDIUM STEEL STAND EXTENSION

C624

1,72kg Top type 34 Bottom type 35

Chrome lenght plated steel extension. Lenght 39cm.

CONKA BONKA

C590

Set of 3 Cine extensions.

Big version:

Extension: 675mm – Total length: 790mm – Weight: 1,75kg

Medium version:

Extension: 270mm – Total length: 385mm – Weight: 1,25kg

Small version:

Extension: 150mm – Total length: 265mm – Weight: 1,09kg

SMALL STEEL STAND EXTENSION

C622

1,59kg Top type 34 Bottom type 35

Chrome lenght plated steel extension. Lenght 28cm.

cine 135

Working height up to 610cm.

Long-extension versions can replace towers for lighting or loudspeakers.

Double safety mechanism with rack direct transmission and secondary safety lock in each section, with neither pulley nor cables.

No drag adjustment needed.

Anti-fall safety drag.

Parts made by die cast aluminum to ensure longer lasting mechanical performance and extension linearity of column, all components inside transmission box are made via precision casting.

Chrome-plated steel tubing. This surface finishing lasts longer, prevents oxidation and gives the product a polished look.

Detachable steel crank handle with top spider housing.

136 cine

Standard version features braked rubber wheels. More wheels and feet available, including tire-equipped wheels.

28mm socket.

Windbracing lugs included.

Assembled using bolts instead of rivets for simpler maintenance.

Steel or aluminum square section single braces on legs for maximum stability, resistance and safety.

Handle on lower spider for easier folding of base.

Patented technology keeps wheels vertical even when the stand is closed, for ease of movement.

STRATO SAFE STAND SHORT BASE

WITH BRAKED WHEELS

B105N

105cm 175cm 126cm 120cm 27kg

100kg [email protected] 28mm

Aluminium legs with chrome steel column.

Complete with braked wheels.

2 sections, 1 riser.

Ø: 70, 60mm.

Leg: 35 x 35mm.

cine 137

2 SECTION STRATO SAFE STAND

WITH BRAKED WHEELS

B120

136cm 222cm 174cm 213cm 42kg

90kg [email protected] 28mm

Chrome steel stand complete with braked wheels.

2 sections, 1 riser.

Ø: 90, 80mm.

Leg: 35 x 35mm.

138 cine

3 SECTION STRATO SAFE STAND

WITH BRAKED WHEELS

B130

Not illustrated

154cm 338cm 192cm 213cm 52kg

80kg [email protected] 28mm

Chrome steel stand complete with braked wheels.

3 sections, 2 risers.

Ø: 90, 80, 70mm.

Leg: 35 x 35mm.

Included Wind Brace Kit code B9000W.

STRATO SAFE SHORT BASE STAND

WITH BRAKED WHEELS

B100

153cm 345cm 184cm 182cm 41kg

70kg [email protected] 28mm

Alluminium legs with chrome steel colums.

Complete with braked wheels.

3 sections, 2 risers.

Ø: 70, 60, 50mm.

Leg: 35 x 35mm.

Not clutch adjustments necessary

Steel inserts for strength and added durability

Smart tracking wheels that locks in 6 positions

SAFE CRANK STAND

B300P

155cm 350cm 186cm 182cm 64kg

90kg [email protected] 28mm

Chrome steel stand complete with bracked wheels.

3 sections, 2 risers.

Ø: 90, 80, 70mm.

Leg: 35 x 35mm.

cine 139

FLAT JUMPER STRATO

SAFE STAND WITH

BRAKED WHEELS

B140XL

155cm 427cm 185cm 182cm 60kg

70kg [email protected] 28mm

Chrome steel stand complete with braked wheels.

4 sections, 3 risers.

Ø: 90, 80, 70, 60mm.

Leg: 35 x 35mm.

4 SECTION STRATO SAFE STAND

WITH BRAKED WHEELS

B140

Not illustrated

172cm 467cm 209cm 213cm 62kg

70kg [email protected] 28mm

Chrome steel stand complete with braked wheels.

3 sections, 2 risers.

Ø: 90, 80, 70mm.

Leg: 35 x 35mm.

Included Wind Brace Kit code B9000W.

5 SECTION STRATO SAFE STAND

WITH BRAKED WHEELS

B150

190cm 610cm 225cm 213cm 71kg

70kg [email protected] 28mm

Chrome steel stand, complete with bracked wheels.

5 sections, 4 risers.

Ø: 90, 80, 70, 60, 50mm.

Leg: 35 x 35mm.

Includes Wind Brace Kit code B9000W.

140 cine

EXTENSION KIT

B199

With the B199 kit you can convert a 2 section Strato Safe stand (Code B120) into a 3 section stand (Code B130).

EXTENSION KIT

B198

Not illustrated

With the B198 kit you can convert a 3 section Strato Safe stand (Code B130) into a 4 section stand (Code B140).

EXTENSION KIT

B197

Not illustrated

With the B197 kit you can convert a 4 section Strato Safe stand (Code B140) into a 5 section stand (Code B150).

REDUCTION KIT

B143

With the B143 kit you can convert a 5 section Strato Safe stand (Code B150) into a 4 section stand (Code B140).

REDUCTION KIT

B144

Not illustrated

With the B144 kit you can convert a 4 section Strato Safe stand (Code B140) into a 3 section stand (Code B130).

REDUCTION KIT

B145

Not illustrated

With the B145 kit you can convert a 3 section Strato Safe stand (Code B130) into a 2 section stand (Code B120).

WIND-BRACING

KIT

087WBK

3 rope wind-bracing kit.

Length: 10m.

Not supplied with the stand.

PNEUMATIC WHEELS

B9000PS

300kg

Set of 3 inflatable pneumatic wheels for Strato Safe stands.

Complete with double brake mechanism that can lock wheel and pivot separately.

Pivoting mechanism has 6 locking positions.

PNEUMATIC WHEELS

B9000P

250kg

Set of 3 pneumatic wheels for Strato Safe stands.

Supplied with double brake mechanism that can lock wheel and pivot separately.

Pivoting mechanism has 12 locking positions.

LEVELLING JACKS

B9000J

Set of 3 levelling jacks allows you to place stands on non horizontal surfaces.

RATCHET HANDLE

B9005R

Standard handle for all Strato Safe stands.

FIXED HANDLE

B9005F

Optional handle.

cine 141

Triple-Steel Wire Ropes.

142 cine

Transportation Handle.

Belt Protection Carter.

Column & Legs Coated in

Scratch-Resistant Paint.

Protective Bellows.

Adjustable Stabilizers.

28mm Spigot Slot + Joining Holes for Extra Support.

Teflon Coated Sliding Guides.

Polyester Belt.

Professional Winch.

Slots for Safety Pin.

Collapsible Legs.

Rubber-Coated Shock-Absorbing

Base Supports.

WINCHER STAND

317-6

190cm 585cm 190cm 220cm 58kg

180kg [email protected] 28mm

The first 4-stage, telescopic and compact lifter made entirely in aluminium.

Not only is there a weight reduction but also a saving in the overall dimensions for transportation whilst maintaining all the performance features of steel models.

The purpose designed aluminium column extensions run smoothly on Teflon coated guides.

The winch mechanism is designed for loads up to 500kg and lifts the first column by means of a polyester belt providing a smooth and uniform performance; the additional columns are each lifted by two steel wire ropes.

The support legs can be independently adjusted to ensure the Wincher is vertical even on irregular surfaces.

Two wheels assist transportation.

The Wincher series is designed to lift lighting fixtures, speakers, aluminium trusses etc. safely.

cine 143

144 cine

You can find EVERYTHING you need for controlling lighting beams by means of Scrims, Flags, Dots & Fingers, from the famous C-Stand to the GRIP HEAD system. The latter is designed with special arms and heads for positioning your scrim or flag exactly where you need it, even in the most difficult circumstances.

Contents

Century Stands

Grip Heads

Scrims & Flags

Page

146

150

152 cine 145

The Avenger Century stand is unlike any other. Fitted with captive handles that do not vibrate free; utilizing a new lightweight steel making them up to 1kg lighter but just as strong; triple chrome plating resistant to corrosion; collar castings that protect fingers; field serviceable parts; all these features make this stand the best on the market.

20", 30”,40” and 60" stands - with loads up to 10kg.

Fold away, spring loaded legs with unique mounts which are easy to replace.

Deep inset plastic feet that do not come off in use.

High quality finish resists all weather conditions.

Detachable base stand - also available as turtle base only.

Captive “T” handles.

The innovative design on the Century stand base allows individual legs to be set at any angle, and can be positioned in locations not possible for classic stands.

20” MINI BASE CENTURY STAND

A280S

84cm 175cm 84cm 75cm 4kg 7kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” MINI BASE CENTURY STAND

BLACK

A280SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 2.9kg. DIN15560: [email protected]

Important! Counterweight sandbags must always be used on the legs to ensure safe, stable operation even at fullheight extension.

20” CENTURY STAND

A255S

Not illustrated

84cm 175cm 84cm 95cm 4,3kg 8kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” CENTURY STAND BLACK

A255SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 3kg. DIN15560: [email protected]

30” CENTURY STAND

A235S

Not illustrated

110cm 253cm 110cm 95cm 4,8kg 10kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

30” CENTURY STAND BLACK

A235SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 3,3kg. DIN15560: 0,[email protected]

146 cine

40” CENTURY STAND

A205S

Not illustrated

134cm 328cm 134cm 95cm 5,5kg 10kg 0,[email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

40” CENTURY STAND BLACK

A205SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 4kg. DIN15560: 0,[email protected]

60” CENTURY STAND

A208S

Not illustrated

185cm 428cm 185cm 95cm 6,8kg 10kg Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

60” CENTURY STAND BLACK

A208SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 5,1kg.

20” MINI BASE SLIDING LEG

CENTURY STAND

A285S

84cm 175cm 84cm 75cm 4kg 7kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” MINI BASE SLIDING LEG

CENTURY STAND BLACK

A285SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 2.9kg. DIN15560: [email protected]

20” SLIDING LEG

CENTURY STAND

A256S

Not illustrated

84cm 175cm 84cm 95cm 4,3kg 8kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” SLIDING LEG CENTURY

STAND BLACK

A256SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 3kg. DIN15560: [email protected]

30” SLIDING LEG

CENTURY STAND

A245S

Not illustrated

110cm 253cm 110cm 95cm 5,8kg 10kg [email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

30” SLIDING LEG CENTURY

STAND BLACK

A245SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 3,3kg. DIN15560: 0,[email protected]

40” SLIDING LEG

CENTURY STAND

A215S

Not illustrated

134cm 328cm 134cm 95cm 5,5kg 10kg 0,[email protected] Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

40” SLIDING LEG CENTURY

STAND BLACK

A215SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 4kg. DIN15560: 0,[email protected]

60” SLIDING LEG

CENTURY STAND

A218S

Not illustrated

185cm 482cm 185cm 95cm 6,8kg 10kg Type 33

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

60” SLIDING LEG CENTURY

STAND BLACK

A218SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 5,1kg.

cine 147

Double Riser Column

Turtle Base

20” MINI DETACHABLE

CENTURY STAND BASE

A290S

84cm 155cm 84cm 75cm 5,2kg 7kg [email protected] 28mm Type 33

+

Type 35

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” MINI DETACHABLE CENTURY

STAND BLACK BASE

A290SB

Not illustrated

Black steel legs and aluminium risers. Weight: 4,6kg.

DIN15560: [email protected]

148 cine

20” DETACHABLE CENTURY

STAND BASE

A257S

84cm 155cm 84cm 95cm 5,6kg 10kg [email protected] 28mm Type 33

+

Type 35

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

20” DETACHABLE CENTURY

STAND BLACK BASE

A257SB

Not illustrated

Black steel legs and aluminium risers. Weight: 4,9kg.

DIN15560: [email protected]

30” DETACHABLE CENTURY

STAND BASE

A247S

110cm 222cm 110cm 95cm 5,9kg 10kg [email protected]

28mm Type 33

+

Type 35

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

30” DETACHABLE CENTURY

STAND BLACK BASE

A247SB

Not illustrated

Black steel legs and aluminium risers. Weight: 5kg.

DIN15560: 0,[email protected]

40” DETACHABLE CENTURY

STAND BASE

A225S

134cm 300cm 134cm 95cm 6,2kg 10kg 0,[email protected] 28mm Type 33

+

Type 35

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

40” DETACHABLE CENTURY

STAND BLACK BASE

A225SB

Not illustrated

Black steel legs and aluminium risers. Weight: 5kg.

DIN15560: 0,[email protected]

60” DETACHABLE CENTURY

STAND BASE

A228S

185cm 454cm 185cm 95cm 7,55kg 10kg

Chromium plated steel stand.

3 sections, 2 risers. Ø: 35, 30, 25mm. Leg Ø: 25mm.

28mm Type 33

+

Type 35

60” DETACHABLE CENTURY

STAND BLACK BASE

A228SB

Not illustrated

Black steel legs and aluminium risers.

Weight: 6,7kg.

20” DOUBLE RISER

COLUMN

A275S

68cm 139cm 2,2kg Type 33 + Type 35

3 sections (Ø: 35, 30, 25mm.) chrome steel column.

20” DOUBLE RISER COLUMN

BLACK

A275SB

Not illustrated

Black aluminium column.

Weight: 1,7kg

30” DOUBLE RISER

COLUMN

A272S

95cm 206cm 2,8kg Type 33 + Type 35

3 sections (Ø: 35, 30, 25mm.) chrome steel column.

30” DOUBLE RISER COLUMN

BLACK

A272SB

Not illustrated

Black aluminium column.

Weight: 1,9kg

40” DOUBLE RISER

COLUMN

A270S

118cm 285cm 3,3kg Type 33 + Type 35

3 sections (Ø: 35, 30, 25mm.) chrome steel column.

40” DOUBLE RISER COLUMN

BLACK

A270SB

Not illustrated

Black aluminium column.

Weight: 2,2kg

60” DOUBLE RISER

COLUMN

A278S

169cm 438cm 4,5kg Type 33 + Type 35

3 sections (Ø: 35, 30, 25mm.) chrome steel column.

60” DOUBLE RISER COLUMN

BLACK

A278SB

Not illustrated

Black aluminium column.

Weight: 2,8kg

SMALL SAND BAG

G100

6kg

(Sand not supplied).

LARGE SAND BAG

G200

10kg

(Sand not supplied).

Turtle Base Century stands offer the most features allowing you to use the base separately as a backlight stand of flexibility of using various sized columns to meet your needs.

TURTLE BASE

A265S

27cm 95cm 3kg 28mm

MINI TURTLE BASE

A268S

Not illustrated

27cm 75cm 2,7kg 28mm cine 149

Our Grip Heads have been specifically designed to hold scrims, flags, floppies & cutters mounted on Century stands, or butterfly frames mounted on overhead stands during film, video or photo shoots.

Extension offset arms, used in combination with Grip Heads, provide an extended grip point for scrims, flags and small lights, and are available in two lengths: 20”(51cm) and 40” (102cm).

The Grip Head can be combined with other accessories to solve most light and light modification accessory positioning problems.

Grip Heads are available in two specific diameters, the standard is 2 1/2“ (8mm) the Jumbo version is 4 1/2“ (10mm).

The 4 1/2“ (10mm) version slotted disc accepts round tubes of 10/13/16mm diameter while the square version accept tubes from 5mm to 8mm diameter.

The Jumbo 4” Grip head slotted disc accepts round tubes of 10/13/16/25mm diameter.

All Grip Heads are equipped with special non slip grip pads for secure and precise control.

SNAP-IN GRIP

HEAD

D210

21/2” GRIP HEAD

D200

0,63kg

Combining the multi-functional

D200 Grip Head with a hex pin to interface with the original Super Clamp.

The D210 allows you to hang flags and scrims in positions that light stands can't reach.

0,55kg 16mm

Avenger's most popular grip accessory. The D200 Grip Head has hundreds of functions. Unlike any other grip head, the D200 utilizes a series of washers for extra locking torque and the use of automotive-quality brake pad discs for secure, non-slip security.

SUPER CLAMP GRIP

HEAD

D230

0,95kg

Like the D210, this kit includes the D200 Grip Head and the

Avenger C1575B Super Clamp.

GRIP HELPER

D220

1,1kg Type33

Just as the name suggests, the Grip Helper is like three Grip Heads in one.

Two independent grip heads sandwich a third with a fixed 16mm pin.

This system allows multiple light control accessories to mount in front of fixtures without the need for numerous light stands.

GAG GOBO

D250

0,46kg

This unique double Grip Head system provides the flexibility of a second grip head allowing hundreds of uses including doubling up scrims and flags.

DOUBLE GRIP HEAD

0,87kg

A combination of two sets of gripheads discs mounted on a steel plate with a 10mm rod.

Attachment: 10mm x 135mm rod.

150 cine

D100

GRIP HEAD

W/SWIVEL PIN

D240

1,25kg

Two famous accessories connected together to assure a wide range of fixing solutions.

Attachments: 16mm male pin + 16mm female socket 28mm male pin.

ADDA HEAD

D260

0,52kg

Like the D230, but available as a separate unit.

The Add ahead provides quick application of a Grip Head into the Super clamp system.

SET OF 6

BLUE T-TOP

D050

Rubber cover gives better grip for 80mm

T-handles, even in cold weather.

Available also in the following colours:

Red - code D050R

Yellow - code D050Y

Green - code D050G

Light Blue - code D050LB

Black - code D050B

41/2” JUMBO GRIP

HEAD

D400

2,35kg

Type 35 28mm

Designed to convert a Junior Stand into an overhead stand, the D400 incorporates a 4-1/2” (10mm) grip head with a junior stud and receiver.

JUMBO ADD AHEAD

D410

0,9kg

Like the smaller D260 version, this Jumbo Add ahead allows one to support lightweight overheads utilizing the Super Clamp system.

JUMBO GAG GOBO

D420

1,3kg

This double 4-1/2” (10mm) Grip Head allows for multiple overheads to be used simultaneously.

JUMBO GRIP

HELPER

D430

1,9kg

A combination of two set of grip heads discs mounted on a aluminium plate with a 16mm rod.

Attachment: 16mm x 150mm rod.

40” EXTENSION

GRIP ARM

D520

1,6kg

Normally used in combination with a Grip head (art. D200) it provides an extended grip point for scrims and flags or small lights. Pipe length 1020mm.

20” EXTENSION

GRIP ARM

D500

1,35kg

Normally used in combination with a Grip head (art. D200) it provides an extended grip point for scrims and flags.

Pipe length 510mm.

FUN GRIP ARM

D550

1,35kg

With its strong joint it solves all positioning problems of scrim, flags or small lights.

107cm length.

GRIP KIT

D800KIT

Set of accessories that work on their own or in combination with stands to support scrims, flags and lighting fixtures to provide precision and secure control.

Kit comprises of:

D200B

E600

D520B

C1575B

H4BAG

Black grip head.

Snap-in 16mm pin.

Black 40" extension arm.

Black Super Clamp.

Grip Kit bag.

SNAP-IN PIN

E600

Specifically designed to connect Grid Head to Super Clamp. Aluminum made.

SNAP-IN PIN

E600C

Not illustrated

Same as E600, chromed plated steel made.

cine 151

SCRIMS AND FLAGS

Made of steel spring tube combined with unique fabrics, Scrims and Flags are light and strong and cut or soften light with great effects.

To achieve the ideal positioning performance of Scrims and Flags, Manfrotto provides a complete Grip Head system.

All textiles are also sold separately as spares in case your originals become damaged.

Size (Inches) 12 x 18

Fabric

Solid Black Flag

Single Scrim

Double Scrim

Triple Scrim

Single Scrim White

Double Scrim White

Triple Scrim White

Silk Scrim l/4 Stop Silk Scrim

China Silk

Open Frame only

Closed frame only

Size (cm) 30 x 45

I 600B

I 600S

I 600D

I 600T

I 600SW

I 600DW

I 600TW

I 600K

I 600K4

I 600CK

I 600

I 601

18 x 24

45 x 60

I 650B

I 650S

I 650D

I 650T

I 650SW

I 650DW

I 650TW

I 650K

I 650K4

I 650CK

I 650

I 651

24 x 30

60 x 75

I 700B

I 700S

I 700D

I 700T

I 700SW

I 700DW

I 700TW

I 700K

I 700K4

I 700CK

I 700

I 701

24 x 36

60 x 90

I 750B

I 750S

I 750D

I 750T

I 750SW

I 750DW

I 750TW

I 750K

I 750K4

I 750CK

I 750

I 751

30 x 36

75 x 90

I 780B

I 780S

I 780D

I 780T

I 780SW

I 780DW

I 780TW

I 780K

I 780K4

I 780CK

I 780

I 781

48 x 48

120 x 120

I 1024

I 790S

I 790D

I 790T

I 790SW

I 790DW

I 790TW

I 790K

I 790K4

I 790CK

-

I 1024FRAME

HIGH QUALITY

Every item is made with care for all details from cutting to sewing of the material to the frame.

A special design of the frame allows perfect

90°corners without losing elasticity of the frame.

SPARE PARTS

The unique design of our scrims and flags allows them to be repaired easily.

A velcro locking system fixes the cover to the frame while a built in pin maintains the perfect tension in the steel wire.

To order spare part covers for scrims and flags add the letter “R” in front of the order code. I.e. RI650K is the spare part cover for the item I650K SILK SCRIM.

SCRIMS AND COLOUR CODES

All our scrims are made using high temperature resistance Webbing. We used a colour code system to easily identify the different kind of textile; see table.

Silk (artificial)

Silk 1/4 Stop

China Silk

Yellow

Blue

Purple

Black Single (scrims)

Black Double (scrims)

Black Triple (scrims)

Green

Red

Black

LABELLING

A label sewed close the handle will tell you the dimension of the frame in inches and centimetres.

White Single (scrims)

White Double (scrims)

White Triple (scrims)

White

Grey

Brown

COLLAPSIBLE SCRIMS AND FLAGS

Innovative and easy to use, this collapsible frame system lets you save space and, at the same time, protect scrims during transport.

Order Notes: Frame & Textile must be ordered separately. *Kit comprises: 2 Frames, 1 each Textile & 1 Bag.

Fabric

Single Scrim

Double Scrim

Silk

Solid Black

Kit with Bag*

Frame only

Size (Inches)

Size (cm)

12 x 18

30 x 45

I 610S

I 610D

I 610K

I 610B

I 610KIT

I 610

18 x 24

45 x 60

I 660S

I 660D

I 660K

I 660B

I 660KIT

I 660

24 x 36

60 x 90

I 760S

I 760D

I 760K

I 760B

I 760KIT

I 760

152 cine

FLOPPIES AND CUTTERS

Description

Meat Axe Flag

Mini Meat AF

Cutter

Cutter

Cutter

Cutter

Cutter

Floppy Cutter

Floppy Cutter

Code

I 1010

I 1011

I 1020

I 1021

I 1022

I 1023

I 1024

I 1030

I 1031

Size (Inches)

30 x 36

24 x 48

10 x 42

18 x 48

24 x 72

40 x 40

48 x 48

24 x 72

48 x 48

Size (cm)

75 x 90

60 x 120

25 x 106

46 x 120

60 x 182

102 x 102

120 x 120

60 x 182

120 x 120

Description

36"x 30" Closed Frame Only

24"x 48" Closed Frame Only

10"x 42" Closed Frame Only

18"x 48" Closed Frame Only

24"x 72" Closed Frame Only

40"x 40" Closed Frame Only

48"x 48" Closed Frame Only

Code

I 1010FRAME

I 1011FRAME

I 1020FRAME

I 1021FRAME

I 1022FRAME

I 1023FRAME

I 1024FRAME

Floppies and Cutters FRAMES. If you wish to order the frame alone without fabric please refer to this chart.

To order spare part covers for floppies and cutters add the letter “R” in front of the order code.

I.e. RI1021, is the spare part cover for the item I1021 CUTTER 18 x 48.

Made of Black Commando fabrics,

Cutters and Floppies stop light completely and are used to control or cut illumination sources, whether natural or artificial. They can also be used to protect camera lenses from flare.

All our flags, floppies and cutters are made using a strong webbing all around the frame, to protect the edges from wear.

Extra layer sewing point

Floppies are Cutters made with an additional piece of fabric, which is fixed with Velcro and can be unfolded, becoming twice its original size. See drawing to understand where the extra layer is sewed on the frame.

DOT & FINGER KIT

I1550 KIT

Comprising:

1 x 3" (7.5cm) Single+Double,

1 x 6" (15cm) Single+Double,

1 x 6" (15cm) Silk,

2 x 6" (15cm) Flags,

1 x 12" (30cm) Single,

1 x 14" (36cm) Silk,

1 x 14" (36cm) Flag,

2 x Mini Flex Arm, 1 Bag.

DOTS AND FINGERS

Fabric Description

Size (Inches)

Size (cm)

Single Scrim

Double Scrim

Silk

Solid Black

Sunlite / White

Gold / Silver

Dot

3

7.6

I 100S

I 100D

I 100K

I 100B

I 100SW

I 100GS

Dot

6

15

I 200S

I 200D

I 200K

I 200B

I 200SW

I 200GS

Dot

10

25

I 300S

I 300D

I 300K

I 300B

I 300SW

I 300GS

Dot

2 x 12

5 x 30

I 400S

I 400D

I 400K

I 400B

I 400SW

I 400GS

Designed to be mounted on flex or articulated arms, Dots and Fingers are essential tools to create precise light effects on small areas. Our complete range, available in different dimensions and various fabric types, provides the right solution to your needs.

Dot

4 x 14

10 x 35

I 500S

I 500D

I 500K

I 500B

I 500SW

I 500GS cine 153

UNIVERSAL ARTICULATED

ARM KIT

D580

1,22kg

Articulated Arm, Mini Clamp, 3/8" Square

Adapter, 10mm Socket Adapter, Super Clamp,

Hexagonal Adapter, Black Plastic Flag.

Arm length: 90cm.

154 cine

UNIVERSAL FLEXTENTION

KIT

D390

1,15kg

Comprising: Flextension Arm, Mini Clamp, 3/8"

Square Adapter, 10mm Socket Adapter, Super

Clamp, Hexagonal Adapter, Black Plastic Flag.

Arm length: 50cm.

CAMERA FLEXTENTION

KIT

D340

0,6kg

Flextension Arm, with 2 Mini Clamps,

3/8" Adapter, 10mm Socket Adapter,

Black Plastic Flag.

40cm

25cm

BLACK METAL FLAG

I800

0,29kg

Thickness: 1mm.

BLACK PLASTIC FLAG

I810

0,15kg

Thickness: 3mm.

BALL AND SOCKET

FLAG ARM

D560

0,32kg

Length: 43cm.

35cm

20cm cine 155

FORK

143F

0,14kg

Fork attachment for styrene gobos: supplied with 1/4” and 3/8” female attachment.

Size 12.5 x 20cm.

DOUBLE HINGED FORK

143FV

0,5kg Type 1

Holds 2 styrene gobos to reflect or cut light on a subject.

Size 12.5 x 20cm.

DOUBLE FIXED FORK

143FD

0,2kg

Holds 2 styrene gobos to reflect or cut light on a subject.

Size 12.5 x 20cm.

COLLAPSIBLE REFLECTOR

HOLDER

D700B

0,7kg Type 1

Extension Arm.

Max Length: 122cm - Min Length: 47cm.

COLLAPSIBLE REFLECTOR

HOLDER LONG

D705B

0,8kg Type 1

Extension Arm Long.

Max Length: 185cm - Min Length: 66cm.

156 cine

40MM (1.6”)

TELESCOPIC

POLYHOLDER

D750

2,5kg 15kg 16mm

Max Size Holding: 156cm.

Folded Length: 91cm.

30MM (1,2”)

POLYHOLDER

F1501

0,8kg Type 1

A foamcore support clamp to enable precise positioning.

Mounts via a 16mm socket.

Polystyrene is one of the most widely used light bouncers, but it’s not the easiest material to handle.

Now our Poly-Holder gives you total control. It grips any thickness, is telescopic to hold most full sheet sizes; then just fixes into the lighting

Grip Head (code D200) mounted on a stand or clamp. What could be easier?

50MM (2”) POLYHOLDER

WITH SWIVEL JOINT

28MM SPIGOT

F1520

2,5kg 28mm

The Polyholder has a 28 mm spigot with a ball-and-socket joint to allow rotation and flexible positioning. The board "clamp" has two sides, one white for the reflective side of the polystyrene; one black for the light-stopping side. It doesn’t damage the poly.

Two metal spikes (on wire retainers) keep the polystyrene board firmly in place. The structure is robustly built to hold thick polystyrene boards, and also has a secondary safety hook to anchor the polyholder to the lightstand/clamp/etc. Plate dimensions: 150 x 220mm.

Mounts via a 28 mm pin.

MOUNTING STIRRUP FOR 40”

REFLECTOR BOARD

I8030CB

2,5kg 16mm

Will fit reflector board from 5mm to 25mm thickness.

Board not supplied.

FOAMCORE FORK

16MM PIN

F1504

0,25kg Type 33

Similar to the F1501, but includes four pointed pins to mount thicker foam core or gator-board.

Mounts via a 16mm pin.

50MM (2”) POLYHOLDER

WITH 16MM SPIGOT

F1521

2,5kg 16mm

The polyholder has a 16mm spigot. The “board” clamp has two sides, one white for the reflective side of the polystyrene; one black for the black lightstopping side. It doesn’t damage the poly. Plate dimensions: 150 x 220mm cine 157

158 cine

You can find EVERYTHING you need for controlling lighting beams by means of Butterflies (frames up to 600cm x 600cm), from dedicated overhead stands to the wide range of fold away or modular frames.

Contents

Overhead Stands

Frames

Butterfly Textiles

Page

160

162

164 cine 159

Overhead stands are designed to support butterfly frames and backdrops, but their use is virtually limitless due to their high reach and wide base.

The top of the stand is fitted with a 115cm grip head, which accepts the butterfly ears; and a 28mm socket for fixtures with a junior pin. The stands with wheels have a special casting to protect the wheels during storage.

Wide base for greatest stability at maximum heights.

Legs may be locked partially open for working in tight environments.

Roller versions fitted with efficient braked wheels.

WIDE BASE HIGH

OVERHEAD STAND

A320

199cm 557cm 195cm 196cm 16,8kg

40kg 9,[email protected] 28mm 115mm A9000

Chrome steel stand. 4 sections, 3 risers.

Ø: 45, 40, 35, 30mm. Leg: 25 x 25mm.

1 levelling leg.

160 cine

SUPER HIGH OVERHEAD STAND

A330

240cm 808cm 203cm 198cm 21kg

30kg [email protected] 28mm 115mm

Chrome steel stand. 5 sections, 4 risers.

Ø: 50, 45, 40, 35, 30mm. Leg: Ø 30mm.

1 levelling leg.

MEDIUM OVERHEAD

STAND

A312

Not illustrated

143cm 423cm 135cm 129cm 11,8kg

40kg 4,[email protected] 28mm 115mm A9000

Chrome steel stand.

4 sections, 3 risers.

Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm.

MEDIUM OVERHEAD ROLLER STAND

WITH BRAKED WHEELS

A310

152cm 432cm 150cm 154cm 16kg

40kg [email protected] 28mm 115mm

Chrome steel stand complete with braked wheels.

4 sections, 3 risers.

Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm.

HIGH OVERHEAD

STAND

A302

Not illustrated

177cm 588cm 167cm 129cm 14kg

40kg [email protected] 28mm 115mm A9000

Chrome steel stand.

4 sections, 3 risers.

Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm.

HIGH OVERHEAD ROLLER STAND

WITH BRAKED WHEELS

A300

Not illustrated

186cm 579cm 182cm 154cm 18,3kg

40kg 28mm 115mm

Chrome steel stand complete with braked wheels.

4 sections, 3 risers.

Ø: 45, 40, 35, 30mm.

Leg: 25 x 25mm.

Important! Counterweight sandbags must always be used on the legs to ensure safe, stable operation even at full height extension.

C-BOOM/FISHPOLE

HOLDER

D610

0,62kg

For tubes of max diameter 35mm.

4 1/2” JUMBO GRIP

HEAD

D400

2,35kg

Type 35 28mm

Designed to convert a Junior Stand into an overhead stand, the D400 incorporates a 4-1/2” (10mm) grip head with a junior stud and receiver.

cine 161

This unique overhead frame allows rapid fold-out and set-up, ready to mount on stands in seconds!

Precisely engineered, the hinged connection points will easily fold to get the frame from set to set or through doorways without having to remove the fabric. The Fold Away is very compact for transportation and storage.

FOLD AWAY FRAME

Code

H2006

H2008

H2012

Frame Sizet

Feet

6 x 6

8 x 8

12 x 12

Frame Size cm

183 x 183

244 x 244

366 x 366

2

2

Tube

Thickness mm

2

Frame

Support

Ear Type 2

Ear Type 2

Ear Type 2

Transport

Dimension mm

1915 x 150 x 30

2525 x 150 x 30

3740 x 150 x 30

Weight kg

10.5

11.5

13.5

FOLD-OUT AND SET UP

Just fix the frame holder and it is ready to mount!

To order Ear support alone use code RH02015.

FOLD-DOWN AND BRING UP

Need to move the frame quickly from set to set?

No problem, just remove the frame holder, fold down the frame and carry the frame with the textile still fitted!!

FOLD AWAY FRAME COMPACT

Code

H2508

H2512

Frame Size

Feet

8 x 8

12 x 12

Frame Size cm

244 x 244

366 x 366

2

2

Tube

Thickness mm

Frame

Support

Ear Type 2

Ear Type 2

Transport

Dimension mm

1298 x 165 x 85

1905 x 165 x 85

Weight kg

14.8

17

FOLD-DOWN AND BRING UP

Fold Away Compact is the evolution of the standard version.

A Locking mechanism (shown in fig 3) allows the frame to be folded even smaller for even easier transportation.

Fabric and stands are not included.

162 cine

LIGHTWEIGHT FRAMES

The Manfrotto Deluxe Fast-Loc Frame kit is lightweight and quick to set up.

The square section aluminium tubes slide and lock together to provide a strong frame which supports lighting control textiles of

(4’ x 4’ and 6’ x 6’ in size).

Code Frame Size

Feet

H440 4 x 4

H660 6 x 6

Frame Size cm

122 x 122

183 x 183

1

1

No. of tubes Tube Length x per side Thickness mm

640 x 1.4

1205 x 1.4

Stud Type (code RH01051) Ear Type (code RH01016)

The Manfrotto Butterfly Frames uses two methods of support. Ear and Stud as illustrated.

Tube Frame

Connection Support

Insert

Insert

Stud Type x 1

Stud Type x 2

Weight kg

5.9

6.9

Optional

Frame Bag

H6BAG

H6BAG

Insert Tube Connection

MODULAR FRAMES

Heavy duty 3mm square section tubes-slot and pin-lock together, rapidly providing a stable frame for lighting control textiles. By reducing or adding tubes you can create any frame size.

Code Modular

Frame Size

H400M 4 x 4

H600M 6 x 6

H800M

H1200M

H2000M

8 x 8

12 x 12

20 x 20

Size cm

122 x 122

183 x 183

244 x 244

366 x 366

610 x 610

No. of tubes Tube Length x per side

1

1

1

2

3

5

Thickness mm

1205 x 3

1205 x 3

610 x 3

1205 x 3

1205 x 3

1205 x 3

Tube

Connection Support

N/A

Pin

Pin

Pin

Pin

Frame

Ear Type x 1

Ear Type x 2

Ear Type x 2

Ear Type x 2

Ear Type x 2

Weight kg

7.3

11.4

Optional

Frame Bag

H6BAG

H6BAG

13.6

19

32.6

H6BAG

H6BAG

H6BAG

MODULAR FRAME CONVERSION KIT

Code

H406EXT

H408EXT

H806EXT

H812EXT

H1220EXT

Conversion kit (ft.) from 4 x 4 to 6 x 6 from 4 x 4 to 8 x 8 from 20 x 20, 12 x 12 and 8 x 8 to 6 x 6 from 8 x 8 to 12 x 12 from 12 x 12 to 20 x 20

Conversion kit (cm)

122 x 122 to 183 x 183

122 x 122 to 244 x 244

610 x 610, 366 x 366 and 244 x 244 to 183 x 183

244 x 244 to 366 x 366

366 x 366 to 610 x 610

Pin Tube Connection

D.I.Y. BUTTERFLY PIPE CORNER KIT

Pipe specifications for use with the D.I.Y Butterfly Pipe Corner Kits.

Code

H9000

H9500

Nominal Bore

(Inches)

1 1/2”

1 1/4”

Outside Diameter

(Inches)

1 29/32”

1 11/16”

Nominal Bore

(mm)

38

32

These two different kits, which contain corners and supports, give you the possibility of making frames of any dimension, using standard aluminium pipes.

See the above chart for the right diameter of pipes to use.

Outside Diameter

(mm)

48.3

42.4

Pipe Connection cine 163

BUTTERFLY TEXTILES

A wide range of butterfly textiles for the perfect stage and set lighting effects, indoor or out.

Fabric Size (Feet) 4 x 4 6 x 6

Size (cm)

Black Commando

Black Single Net

Black Double Net

White Single Net

White Double Net

Grifolyn Black / White

Silk (artificial)

Silk 1/4 Stop

China Silk

Soft Diffuser (Grid)

Soft Diffuser Light (Light Grid)

White Block

Silver / White

White / Gold

Sunfire / Silver

Muslin Bleached

Muslin Unbleached

Cromakey Blue

Cromakey Green

120 x 120

I 905BL*

I 905BSN

I 905BDN

I 905WSN

I 905WDN

I 905GBW

I 905K

I 905K4

I 905CK

I 905SD

I 905SDL

I 905WB*

I 905SW*

I 905WG*

I 905SUS

I 905MB*

I 905MU*

I 905CKB

I 905CKG

180 x 180

* Textile obtained by sewing two or more pieces of fabric together.

I 910BL*

I 910BSN

I 910BDN

I 910WSN

I 910WDN

I 910GBW

I 910K*

I 910K4

I 910CK*

I 910SD*

I 910SDL*

I 910WB*

I 910SW*

I 910WG*

I 910SUS*

I 910MB*

I 910MU*

I 910CKB*

I 910CKG*

8 x 8

240 x 240

I 915BL*

I 915BSN

I 915BDN

I 915WSN

I 915WDN

I 915GBW

I 915K*

I 915K4

I 915CK*

I 915SD*

I 915SDL*

I 915WB*

I 915SW*

I 915WG*

I 915SUS*

I 915MB

I 915MU

I 915CKB*

I 915CKG*

12 x 12

360 x 360

I 920BL*

I 920BSN

I 920BDN

I 920WSN

I 920WDN

I 920GBW

I 920K*

I 920K4*

I 920CK*

I 920SD*

I 920SDL*

I 920WB*

I 920SW*

I 920WG*

I 920SUS*

I 920MB*

I 920MU*

I 920CKB*

I 920CKG*

20 x 20

600 x 600

I 930BL*

I 930BSN

I 930BDN

I 930WSN

I 930WDN

I 930GBW*

I 930K*

I 930K4*

I 930CK*

I 930SD*

I 930SDL*

I 930WB*

I 930SW*

I 930WG*

I 930SUS*

I 930MB*

I 930MU*

I 930CKB*

I 930CKG*

ALL IN ONE

All our butterfly textiles are supplied complete with clear bottomed bag and elastic hook kit (code I910SET - set of 16 pcs).

BUTTERFLY BAGS

A well designed bag is supplied with our butterfly textiles; it has a clear base so you can see the content of the bag without opening it.

An additional pocket holds stickers or carton tags for additional information like Code, dimensions, textile type etc.

Stored in the proper way on your warehouse shelf it will speed up inventory or picking procedures avoiding mistakes and time loss.

To order the bag alone refer to the chart below.

H44BAG

H88BAG

H2020BAG

H2020XBAG

S

M

L

BAG FOR 4 X 4 AND 6 X 6 BUTTERFLY TEXTILES

BAG FOR 8 X 8 AND 12 X 12 BUTTERFLY TEXTILES

BAG FOR 20 X 20 BUTTERFLY TEXTILES

XL BAG FOR 20 X 20 CROMAKEY TEXTILES

LABELLING AND WEBBING

A textile label sewn close to each corner shows butterfly textile dimensions and fabric. This simple but important improvement will avoid mistakes in shipping and storing operations.

The webbing material used on our butterfly textile has been chosen for high temperature resistance.

164 cine

FABRIC SPECIFICATION

Fabric

Black Commando (solid)

Black Single Net

White Single Net

Grifolyn Black

Grifolyn Black / White

Grifolyn White

Soft Diffuser

Soft Diffuser

White Block

Silver / White

Gold / White

Sunfire / Silver

Muslin Bleached

Muslin Unbleached

Fabric Width

(Meters)

2m

7.32m

7.32m

3.6m

3.6m

3.6m

1.5m

1.5m

1.1m

1.5m

1.5m

1.5m

3m

3m

1.8

100%

1.4

100%

100%

100%

100%

Light loss

(stops)

100%

0.7

0.5

100%

100%

100%

2.5

Fabric

Cromakey Blue

Cromakey Green

Sunfire / White

Silver / Gold

Silk (artificial)

Silk 1/4 Stop

China Silk

Black Single (scrims)

Black Double (scrims)

Black Triple (scrims)

White Single (scrims)

White Double (scrims)

White Triple (scrims)

2.95m

1.36m

7.32m

7.32m

7.32m

7.32m

7.32m

7.32m

Fabric Width

(Meters)

1.3m

1.3m

1.5m

1.1m

1.5m

FABRIC WIDTH SEAM

The measures in the column show the maximum width of different fabrics used for our butterfly textile system; you can calculate how many seams the butterfly textile has, depending on the type and size chosen.

For example, the Black Commando 20 x 20 (600 x 600cm), with a fabric width of 2m, has 2 seams, whereas the Black Single of the same size has no seams.

LIGHT LOSS

The chart shows the light loss of an incandescent light source. The main light reading is 32

9

/

10

F Stop.

The light loss has been calculated positioning the luxmeter at 2m from the light source and the butterfly textile halfway between them.

0.8

1.2

0.8

1.5

2.9

0.7

1

1.6

Light loss

(stops)

100%

100%

100%

100%

1.6

Scrims color code

Yellow

Blue

Purple

Green

Red

Black

White

Grey

Brown light textile

1m

Fabric swatch book.

Code I999.

2m luxmeter

TEXTILES ROLLS

I950BL

I950WB

I950BSN

I950WSN

I950K

I950K4

I950CK

I950SD

I950SDL

I950MB

I950MU

I950GBW

I950SW

I950WG

I950SUS

I950CKB

I950CKG

Fabric roll 10m x 2m Black Solid

Fabric roll 10m x 1.1m White Solid

Fabric roll 10m x 7.32m Black Single Net

Fabric roll 10m x 9.15m White Single Net

Fabric roll 10m x 1.5m Silk

Fabric roll 10m x 2.95m 1/4 Stop Silk

Fabric roll 10m x 1.36m China Silk

Fabric roll 10m x 1.5m Soft Diffuser

Fabric roll 10m x 1.5m Soft Diffuser Light

Fabric roll 7m x 3m Muslin Bleached

Fabric roll 7m x 3m Muslin Unbleached

Fabric roll 10m x 3.55m Griffolyn Black/White

Fabric roll 10m x 1.5m Silver/White

Fabric roll 10m x 1.5m Gold/White

Fabric roll 10m x 1.5m Sunfire/Silver

Fabric roll 10m x 1.3m Cromakey Blue

Fabric roll 10m x 1.3m Cromakey Green

OVAL REFLECTORS

Fabric Size (Feet)

Size (cm)

Translucent

Sunfire / White

Silver / White

Silver / Gold

Gold / White

Bags for oval reflectors

20 x 15

50 x 38

I 2007

I 2008

I 2031

I 2034

I 2041

I 2000BAG

37 x 28

95 x 70

I 3807

I 3808

I 3831

I 3834

I 3841

I 3800BAG

48 x 35

120 x 90

I 4807

I 4808

I 4831

I 4834

I 4841

I 4800BAG

73 x 48

185 x 120

I 6207

I 6208

I 6231

I 6234

I 6241

I 7200BAG cine 165

166 cine

Our family of Avenger clamps stands out for supporting heavy loads and for clamping any kind of prop, be it a square or round section pipe (up to 78mm diameter), or IPE bar (up to IPE160). For that reason, the various models are made of aluminum castings or by extruded aluminum, so that they can ensure high mechanical performance, well suited for the required use. Avenger clamps also feature neat clamping solutions, in order to provide easy operation and quick locking.

Our range of clamps is backed up by a wide choice of accessories.

Contents

Telescopic Hanger Clamps

Pipe Clamps

Hook Clamp & Stage Clamps

Quick Action Clamps

LP Eye Couplers

MP Eye Couplers

MP Slim Eye Couplers

Grab Clamps

Page

168

169

172

173

174

175

176

177 cine 167

A convenient method of suspending luminaires from above for unobstructed floor areas.

Avenger telescopic hangers are renowned for their strength and versatility.

Available with either a stirrup or universal head, all hangers come with a safety pin to prevent the riser from slipping.

TELESCOPIC HANGER WITH

UNIVERSAL HEAD

C825

121cm 201cm 5,1kg Type 34

Max Load with 16mm spigot 10kg.

Max Load with 28mm socket 40kg.

TELESCOPIC HANGER

WITH STIRRUP

C820

117cm 197cm 5,4kg 40kg

Luminaire attachment - Stirrup Ø 40mm.

LONG TELESCOPIC HANGER

WITH UNIVERSAL HEAD

C827

Not illustrated

212cm 381cm 6,8kg Type 34

Max Load with 16mm spigot 10kg.

Max Load with 28mm socket 40kg.

Safety Pin

LONG TELESCOPIC HANGER

WITH STIRRUP

C822

Not illustrated

210cm 379cm 6,8kg 40kg

Luminaire attachment - Stirrup Ø 40mm.

Safety Pin

TELESCOPIC HANGER WITH

UNIVERSAL HEAD

C888UH

76cm 161cm 4,6kg Type 34

Max Load with 16mm spigot 10kg.

Max Load with 28mm socket 40kg.

TELESCOPIC HANGER WITH

STIRRUP

C888ST

73cm 157cm 4,7kg 40kg

Luminaire attachment - Stirrup Ø 40mm.

168 cine

Manfrotto Pipe Clamps are made from in aluminium alloy or rugged gravity cast aluminium for extra strength.

Clamping range encompasses pipes from 28mm to 78mm diameter.

SWIVELLING “C” CLAMP

C150

1,6kg 10/75kg* 28mm

Works on diameters from 28mm to 78mm.

* 10kg on 16mm attachment,

75kg on 28mm attachment.

Ø 28mm

Ø 78mm

60mm

28mm

122mm

16mm

SWIVELLING “C” CLAMP

WITH M12 SCREW

C151

1,07kg 100kg M12

Works on diameters from 28mm to 78mm.

PELICAN GAFFER GRIP

1,4kg 10kg Type 2 Type 33

Works on diameters from 15mm to 80mm.

C500

Ø 28mm

Ø 78mm

179mm

M 12

371mm

Type 33

Ø

8

0m m

Ø

15m m cine 169

SQUARE CLAMP

WITH 16MM PIN

C720

0,24kg Type 33

Fits square pipe 35mm x 35mm.

SQUARE CLAMP WITH

16MM RECEIVER

C700

0,30kg Type 1

Fits square pipe 35mm x 35mm.

BARREL CLAMP

C350N

0,8kg 100/300kg* 17mm/28mm

Works on diameters from 42mm to 52mm.

* 100kg on 16mm attachment.

300kg on 28mm attachment.

BARREL CLAMP

WITH KNOB

C350NK

Not illustrated

Same as C350N but with knob.

GRID CLAMP

C300

1,1kg 50/30kg* 35mm

Works on diameters from 25mm to 55mm.

* 50kg on vertical position.

30kg on horizontal position.

170 cine

Type 33

35mm

70mm

Ø 16mm

70mm

35mm

Ø 25mm

Ø 55mm

132mm

Ø 35mm

54mm

BABY PIPE CLAMP

WITH 16MM STUD

C210

0,62kg 100kg Type 33

Works on diameters from 10mm to 55mm.

JUNIOR PIPE CLAMP

WITH 28MM SOCKET

C100

1,13kg

250kg 28mm

Works on diameters from 20mm to 55mm.

SUPER CLAMP

C1575B

0,45kg 15kg

Ideal clamp for Cine, Broadcast or

Lighting & Entertainment application.

Clamping system achieved via a metal knob ensuring extra solidity.

Works on diameters from 13mm to 55mm.

SAFETY CABLE

Diameter 4mm. Length 100cm.

C155

82 mm

Ø 1

0m m

Ø 55m m

Type 33

127 mm

90mm

Ø 20 mm

Ø 5

5m m

28mm

26mm

HEAVY DUTY

SUPER CLAMP

C1550

0,45kg

15kg

Extra strong version of Super Clamp because of a special manufacturing process named gravity casting, allowing heavier manipulation.

Works on diameters from 13mm to 55mm.

SAFETY CABLE

C155-01

Not illustrated

Diameter 3,5mm. Length 70cm.

SAFETY CABLE

C155-02

Not illustrated

Diameter 5mm. Length 70cm.

SAFETY CABLE

C155-03

Not illustrated

Diameter 6mm. Length 100cm.

cine 171

SLIM HOOK CLAMP

C356

0,8kg 500kg M10x25

A strong, sturdy clamp combining an all steel hook with an aluminium locking jaw.

Clamps perfectly on pipes from 50mm to 52mm.

89mm 61mm

M 10

Work on diameters from 30mm to 52mm.

The double locking knob position always provides an optimal grip point.

STAGE CLAMP

C280

0,37kg 50kg 13mm hole

For multipurpose applications.

STAGE CLAMP WITH

16MM STUD

C285

0,47kg 50kg Type 33

Supplied with 16mm stud.

91mm

Ø 13

Ø 30mm

Ø 52mm

STAGE CLAMP WITH

28MM STUD

C290

0,9kg 50kg Type 33

Supplied with 28mm stud.

172 cine

STAGE CLAMP WITH

28MM SOCKET

C295

0,75kg 50kg 28mm

Supplied with 28mm stud.

The mechanical concept on which we based this new range of clamps allows an incredible speed in locking and unlocking the clamp’s jaws.

Fastening the clamp to a pipe or any other support is quick and simple allowing you to position your lighting equipment securely.

The Quick Action line of clamps consists of four models that differ in dimension, load capacity (from 7kg to 100kg) and coupling range (from 5mm to 80mm).

QUICK ACTION JUNIOR

CLAMP 28MM BUSHING

C337

1,27kg 100kg 28mm

Made in gravity cast aluminium, this clamp is ideal to hang all types of luminaries in TV studios and theaters.

Its incredible "coupling range" sets almost no limitations to its capability to clamp to almost all the industry standard pipe diameters. To meet all safety requirements, we have designed a dedicated slot for flexible steel safety cables.

Supplied with T-top padded handle to improve grip.

Pipe size 40-70mm. PAT. PENDING.

46mm

101mm

Ø 4

0m m

Ø 7

0mm

28mm

32mm

QUICK ACTION BABY

CLAMP 16MM PIN

C338

0,76kg 50kg Type 33

Very slim and lightweight, this version has been designed for small luminaries, virtually unlimited in application.

To meet all safety requirements, we have designed a dedicated slot for flexible steel safety cables.

Pipe size 20-52mm. PAT. PENDING.

Ø 20m m

Ø 52m m

81mm

Type 33 cine 173

EYE COUPLER family: safer, easier to use and lighter, with the reliability and high performance that you expect from Manfrotto.

The new high-performance EYE COUPLER range has been developed with professional users’ needs in mind.

Improved safety, full TUV certification, optimised ergonomics and unique design are the key features of new

EYE COUPLERS, developed for professionals in entertainment and film industries.

The complete EYE COUPLER range is made up of

LP EYE COUPLERS: industry standard clamp range from 48 to 52 mm

MP EYE COUPLERS: wider clamp range from 42 to 52 mm and special flattened shape of lower jaw

MP SLIM EYE COUPLERS: same features as MP coupler, but narrower in profile and lighter in weight

LP EYE COUPLER

C460

LP EYE COUPLER WITH

28MM SPIGOT

C461

0,36kg 500kg 13mm hole

The base model of LP eye coupler for any customised application.

0,57kg 500kg Type 35

Supplied with 28mm spigot for TV/broadcast luminaires

LP EYE COUPLER WITH

16MM SPIGOT

C462

0,41kg 500kg Type 33

Designed with 16mm spigot suitable for lightweight luminaires.

LP EYE COUPLER WITH

LIFTING RING

C463

0,55kg 300kg Ring

Provided with lifting ring for multipurpose use with chains, wires and ropes.

LP EYE COUPLER WITH

M12 BOLT PLUS NUT

C464

0,40kg 500kg M12x27

Supplied with M12 bolt and nut for custom solutions

LP EYE COUPLER

W/28MM BUSHING

C465

0,84kg 300kg 28mm

Designed with 28mm bushing suitable for 2K+stirrup luminaires.

LP PARALLEL EYE

COUPLER

C480

0,76kg 300kg

Twin couplers fixed parallel for firm, quick and easy interconnection for truss, bars or pipes.

174 cine

LP 90° FIXED EYE

COUPLER

C481

0,76kg 300kg

Twin couplers fixed at 90° for firm, quick and easy interconnection for truss, bars or pipes.

LP SWIVEL EYE

COUPLER

C482

0,76kg 300kg

Twin couplers free to rotate 360° for firm, quick and easy interconnection for truss, bars or pipes.

CONNECTION KIT FOR

LP EYE COUPLER

C466

Kit to connect two C460 clamps.

MP EYE COUPLER

C4460

0,39kg 500kg 13mm hole

The base model of MP eye coupler for any customised application.

MP EYE COUPLER WITH

16MM TV SPIGOT

C4462

0,44kg 500kg Type 33

Designed with 16mm spigot suitable for lightweight luminaires.

MP EYE COUPLER WITH

M12 BOLT PLUS NUT

C4464

0,43kg 500kg M12x27

Supplied with M12 bolt and nut for custom solutions.

MP EYE COUPLER WITH

28MM SPIGOT

C4461

0,60kg 500kg Type 35

Supplied with 28mm spigot for TV/broadcast luminaires.

MP EYE COUPLER WITH

LIFTING RING

C4463

0,58kg 300kg Ring

Provided with lifting ring for multipurpose use with chains, wires and ropes.

MP EYE COUPLER W/28MM

BUSHING

C4465

0,87kg 300kg 28mm

Designed with 28mm bushing suitable for 2K+ stirrup luminaires.

cine 175

MP EYE COUPLER WITH

16MM BUSHING

C4469

0,52kg 500kg 16mm

Supplied with 16mm spigot for light fixing accessories.

MP SWIVEL EYE

COUPLER

C4482

0,81kg

Twin couplers free to rotate 360° for firm, quick and easy coupling of trusses, bars or pipes.

MP SLIM EYE

COUPLER

C4560

0,26kg 300kg 13mm hole

The base model of MP slimlight version eye coupler.

176 cine

MP TILT & SWIVEL EYE

COUPLER

C4470

1,3kg 300kg Type 35

Provided with 28mm spigot to enable to rig a bar or a frame structure between two stands with 360° spigot rotation and swivel system.

MP EYE COUPLER SWIVEL AND TILT

TRUSS SUPPORT 150-250

C4485

2,78kg Type 35

Min. Lenght - 150mm.

Max. Lenght - 250mm.

Truss Support Coupler with a tilt/swivel connection to the stand pin. It avoids torsion and mounting problems when lifting a truss using two stands simultaneously.

MP EYE COUPLER SWIVEL AND TILT

TRUSS SUPPORT 200-400

C4486

Not illustrated

2,85kg Type 35

Min. Lenght - 200mm. Max. Lenght - 400mm.

MP EYE COUPLER

12MM BOLT + NUT

C4564

0,3kg 300kg M12x27mm

Supplied with M12 bolt and nut for custom solutions.

The Grab Clamp is flexible and fast to use thanks to its pincer jaw design and rapid locking and release mechanism.

It can be fixed to a wider range of supports than traditional clamps and is suitable for use in TV, video and photographic studios, theatres and rigging structures. The grab clamp will hold all kinds of lights, scenery, monitors and much more besides.

The grab clamp has been designed to be mounted on a wide range of beams, pipes and bars, whether round, square or rectangular in section. It needs no adapter - just open and clamp it.

IPE 80

HEB 160

ø 40mm

ø 65mm

36x36mm 47x47mm

Clamp Range: 40mm to 65mm

GRAB CLAMP

C339

1,2kg 150kg 12,5mm Hole

Supplied without attachment, but with a 12.5mm hole for custom fixings.

Clamp Range: 36mm to 47mm Clamp Range: IPE 80 to IPE 160

HEB 80 to HEB 160

GRAB CLAMP WITH

28MM TV SPIGOT

C339JS

1,4kg 150kg Type 35

Supplied with 28mm spigot.

GRAB CLAMP WITH

16MM BUSHING

C339BB

1,35kg 50kg 16mm

Comes with 16mm bushing complete with push button for extra-safe attachment.

GRAB CLAMP WITH

UNIVERSAL HEAD

C339UH

1,95kg 75kg 28mm 16mm

Provided with a universal fixed

(non-rotating) head.

GRAB CLAMP WITH

LIFTING EYE

C339LE

1,4kg 150kg Ring

Complete with standard lifting eye for chain or rope fixture.

GRAB CLAMP WITH

SPINNING PULLEY

C339SP

1,65kg 150kg Pulley

Fitted with a 100mm diameter pulley to offer a quick and robust hanging point for TV and theatre sceneries.

cine 177

178 cine

Avenger booms, articulated arms, multi-positioning arms and adapters, when used in conjunction with stands or clamps, allow accurate positioning of lighting and effects, assuring the typical practicality, robustness and flexibility of Avenger products.

Contents

Lighting booms

Lighting booms accessories

Arms

Brackets & Bars

Page

180

181

182

183 cine 179

Boom arms allow you to position your lights in the most difficult positions.

Strong steel counterweighted for smoothness of operation and stability.

EXTENSION ARM WITH

SWIVEL PIN

D570

1,1kg Type 33

Arm Length: 91cm

16mm female stand attachment.

MINI BOOM

D600

3,6kg Type 33

Min extension 117cm-Max load 30kg.

Max extension 212cm-Max load 7kg.

16mm female stand attachment.

JUNIOR BOOM ARM

D650

14,8kg Type 34

Min extension 163cm-Max load 40kg.

Max extension 300cm-Max load 10kg.

28mm male stand attachment.

180 cine

MINI COUNTER WEIGHT

172

1,3kg

G-PESO

022

6,7kg

L-PESO

023

Not illustrated

4,3kg cine 181

BABY TRIPLE HEADER 5 X 16MM

PIN & 16MM SOCKET

F900

1,3kg

Length: 650mm

COLUMN ARM

F1200

3,1kg 10kg Type 33 28mm

Length: 51cm

JUNIOR ADJUSTABLE SIDE

ARM-28MM SOCKET

F200

2,1kg

Length: 41cm

BABY OFFSET ARM/TWIN 16MM

PIN & 16MM SOCKET

F600

0,7kg

Length: 38cm

BABY SIDE ARM TWIN

16MM PIN

F700

2,1kg

Length: 38cm

182 cine

JUNIOR OFFSET ARM-28MM

PIN & 28MM SOCKET

F100

1,5kg

Length: 50cm

FIXED BABY SIDE ARM

C330

1,37kg 20kg Type 33

Clamps on diameters from 48mm to 52mm.

Length: 44cm.

FIXED JUNIOR SIDE ARM

C335

1,42kg 20kg 28mm

Clamps on diameters from 48mm to 52mm.

Length: 47cm.

SNAP IN ARTICULATED

ARM

D301

0,63kg 0,35kg

Length: 78cm.

ARTICULATED ARM WITH

HEXAGONAL END

D306

Not illustrated

Similar to the D301 but with a hexagonal attachment at one end and a 16mm pin at the other.

ARTICULATED ARM WITH

SPRING CLAMP

D300

0,85kg 0,25kg

Length: 91cm.

MINI-FLEX ARM

D310

0,09kg

Flexible arm, Ø 10mm. Length: 11cm.

Attachment bushing and stud 6mm diam.

MAXI-FLEX ARM

D315

0,16kg

Flexible arm, Ø 15mm. Length: 12,5cm.

Attachment bushing and stud 10mm diam.

cine 183

184 cine

When you need to hold a light, panel or accessory but the available surface is flat as a mirror, with no way to clamp to it, we still provide a solution: a complete system of plates equipped with standard pins and bushings or a suction pump cup for stunning bonds to glass surfaces.

Contents

Pump Cup

Wall Plates

Page

186

187 cine 185

186 cine

PUMP CUP WITH 16MM BABY

SWIVEL SPIGOT

F1000

1,1kg

2kg Type 33

Ideal for mounting small lights and camera systems onto flat, non-porous surfaces such as glass.

A perfect tool for rigging car shoots

PUMP CUP WITH 16MM BABY

FIXED SPIGOT

F1100

0,7kg

2kg Type 33

Like the F1000, but with a fixed baby pin for added stability.

BABY PLATE WITH

90° PIN

F809

0,65kg

16mm

When a light stand or a clamp cannot be used to support fixtures, this baby plate with a right angle can be mounted on the wall.

BABY PLATE WITH 16MM

SWIVEL SPIGOT

F810

0,8kg

Type 33

Unique to the Avenger line, this baby plate allows fixtures to be fine-tuned with the built in swiveling baby pin.

BABY PLATE

“T” PIN

F815

0,94kg

Type 33

Height: 38cm.

JUNIOR WALL

PLATE

F300

0,68kg

28mm

A wall plate with a junior receiver to mount larger fixtures.

3” BABY WALL

PLATE

F800

0,4kg

16mm

Baby plates allow for the quick mounting of fixtures in places where light stands and clamps cannot be used.

Length: 3”.

6” BABY WALL

PLATE

F805

0,72kg

16mm

Baby plates allow for the quick mounting of fixtures in places where light stands and clamps cannot be used.

Length: 6”.

9” BABY WALL

PLATE

F808

0,85kg

16mm

Baby plates allow for the quick mounting of fixtures in places where light stands and clamps cannot be used.

Length: 9”.

cine 187

188

All Manfrotto products provide for a high level of customization, thanks to a wide range of accessories like wheels, swivelling joints and adapters that can accept any lighting fixture, in order to match any requirement.

Contents

CABLE CLIPS

CABLE GRIPS

WHEELS

16MM FEMALE ADAPTERS

16MM MALE ADAPTERS

28MM MALE ADAPTERS

SPECIAL ADAPTERS

SUPER CLAMP ADAPTERS

SWIVELLING ADAPTERS

STAND ATTACHMENTS

189

E0647_190-191.qxd 20-02-2006 12:34 Pagina 190

LARGE CABLE CLIP

093

0,03kg

Clamps on Ø: 28mm to 40mm.

Allen key not supplied.

Set of four.

CABLE CLIP

206

0,02kg

Clamps on Ø: 25mm to 28mm.

Allen key not supplied.

Set of four.

SMALL CABLE CLIP

064

0,02kg

Clamps on Ø: 18mm to 26mm.

Allen key not supplied.

Set of four.

ADJUSTABLE

MINI CLIP

201

0,03kg

Mini clip to hold light panels from 0mm to 12.5mm thickness.

Adjustable from: 0mm to 12.5mm.

Set of four clips.

CABLE GRIPS

371

Set of ten Cable Grips.

Self-gripping double-sided velcro strips for wrapping and storing cables of any type and length.

Cable Grip is fast, sure, reusable, and dirt-resistant.

Available in the following sizes and colours:

COLOURS: Black (B), Red (R), Yellow (Y), Blue (BL) and White (W)

SIZE (cm.)

2.5 x 15 (2515)

2.5 x 25 (2525)

2.5 x 40 (2540)

4.0 x 40 (4040)

4.0 x 60 (4060)

4.0 x 90 (4090) (Set of 5 Cable Grips.)

Order code

To order, combine product code, colour code and size code.

For example: 371B - 4060 Black Cable Grip 4,0 x 60 cm.

190

STAND HOLDER

027

2,8kg

Holder for 8 light stands.

Width: 115cm.

Distance between fixing holes: 64.4cm.

Depth: 19cm.

MINI CLIP

178

0,02kg

Set of four clips for maximum thickness of 6mm.

E0647_190-191.qxd 20-02-2006 12:34 Pagina 191

CASTER WHEEL

SET

017

0,45kg 10kg

Caster wheel set for stands with legs Ø: 19mm.

Set of three.

CASTER WHEEL

SET

018

0,54kg 10kg

Caster wheel set for stands with legs Ø: 22mm.

Set of three.

WHEEL SET

104

1,5kg 75kg

Ø: 75mm with brakes and M10 attachment.

Set of three.

WHEEL SET

110

1,7kg 75kg

Ø: 75mm with brakes and adapter for legs Ø: 22mm.

Set of three.

WHEEL SET

103

1,24kg 60kg

Ø: 80mm without brakes, with M10 attachment.

Set of three.

WHEEL SET

104G

3kg 100kg

Ø: 100mm with brakes and M10 attachment.

Set of three.

WHEEL SET

109

1,43kg 60kg

Ø: 80mm without brakes and adapter for legs Ø: 22mm.

Set of three.

WHEEL SET

110G

3,2kg 100kg

Ø: 100mm with brakes and adapter for legs Ø: 22mm.

Set of three.

WHEELS FOR SUPER

WIND UP

251

4,5kg 100kg

Ø: 125mm with brakes.

Set of three.

BRAKED WHEEL

A9000

3,3kg 90kg

Ø: 100mm for 25 x 25mm square legs.

Set of three.

WHEELS FOR SUPER

WIND UP

374

7,2kg 300kg

Ø: 160mm with brakes.

Set of three.

WHEELS FOR

WIND UP

374-10

Not illustrated

7,2kg 300kg

Ø: 160mm with brakes and M10 attachment.

Set of three.

191

192

All measurements shown are metric unless otherwise stated.

Indicates an external thread or stud diameter

Metric Imperial

Indicates an internal thread or socket diameter

Metric Imperial

W

: Whitworth thread

16MM FEMALE ADAPTERS

014-14 014-38

18

37.5

3 /

8

” w

18

37.5

3 /

8

” w

014BIM

5 /

8

3 /

8

” w

014MS

5 /

8

M10

25

18

37.5

40

5 /

8

152

17.5

153

5 /

8

5 /

8

45

48

159

33

5 /

8

1 /

2

5 /

8

57

179

31

40

5 /

8

3 /

8

80

193

40

5 /

8

7

13

3 /

8

” w

3 /

8

37.5

5 /

8

194

37.5

5 /

8

7

13

1 /

4

” w

3 /

8

37.5

5 /

8

016

8

1 /

4

” w

12

52

39

5 /

8

1 /

4

” w

5 /

8

31

3 /

8

” w

158

65

5 /

8

189

E390

10.2

45

16.2

76

5 /

8

16MM MALE ADAPTERS

013

7

25.4

3 /

8

” w

5 /

8

7

25.4

1 /

4

” w

5 /

8

151

7

25.4

1 /

4

” w

5 /

8

3 /

8

” w

185

188

25.4

1 /

4

” w

5 /

8

3 /

8

E250

30

5 /

8

43

17

24

5 /

8

118

182

7

25.4

1 /

4

” w

5 /

8

15

3 /

8

186

5 /

8

25.4

25.4

5 /

8

191

E300

7

26

7

1 /

4

” w

5 /

8

3 /

8

” w

14

25.4

3 /

8

” w

5 /

8

27

63

5 /

8

69

32

5 /

8

119

1 /

4

” w

5 /

8

31

3 /

8

” w

184

7

3 /

8

” w

16

43

187

3 /

8

” w

5 /

8

25.4

25.4

M10

195

10

24

1 /

4

” w

5 /

8

E650

113

27

5 /

8

193

194

28MM MALE ADAPTERS

163-10

M10

120

35

110

620-10

30

1

1 /

8

M10

110

1

1 /

8

163-12

35

M12

120

110

620-12

30

1

1 /

8

M12

110

1

1 /

8

SPECIAL ADAPTERS

015

1 /

4

” w

7

13

3 /

8

” w

088

149

C1005

7

13

3 /

8

” w

1 /

4

” w

3 /

8

20

1 /

4

” w

019

7

25.4

3 /

8

” w

5 /

8

088LBP

192

25.4

25.4

5 /

8

1

1 /

8

3 /

8

” w

30

1 /

4

” w

3 /

8

C1100

27

5 /

8

163-38

25

3 /

8

” w

120

E200

110

30

1

1 /

8

5 /

8

110

1

1 /

8

019-14

7

25.4

1 /

4

” w

5 /

8

148KN

4.5

1

1 /

8

3 /

8

” w

1 /

4

” w

C1000

27

5 /

8

D350

25

6

E100 E620

25

E610

27

5 /

8

E110

27

5 /

8

M10

120

5

/

8”

163-58F

5 /

8

27

5

/

8”

SUPER CLAMP ADAPTERS

1 /

4

036-38 036-14

7

25,4

7

25,4

25

25

3 /

036MR

25

E600

E600C

5 /

8

50

066

25

1 /

4

5 /

8

066BT

5 /

8

119

31

3 /

8

1 /

4

” w

5 /

8

264

3 /

8

” w

25

25.4

M10

M10

036I

42

25.4

5 /

8

061

50

5

013

174

7

25.4

3 /

8

” w

5 /

8

7

25.4

1 /

4

” w

5 /

8

M10

25

25

037

1 /

4

” w

7

7

13

13

7

13

3 /

8

” w

061RA

25

25

118

7

26

7

1 /

4

” w

5 /

8

3 /

8

” w

195

SWIVELLING ADAPTERS

F820 F820RH F820TH

5 /

8

F825

5 /

8

5 /

8

F825RH

5 /

8

5 /

8

F825TH

5 /

8

F830

5 /

8

5 /

8

F830RH

5 /

8

5 /

8

5 /

8

F830TH

5 /

8

196

155

5 /

8

32

1 /

4

” w

5 /

8

5 /

8

155BKL

32

3 /

8

” w

5 /

8

32

1 /

4

” w

5 /

8

026

5 /

8

1 /

4

” w

5 /

8

17.5

3 /

8

” w

1 /

4

” w

17.5

5 /

3 /

8

” w

This type number refers to the spigot and socket variants shown in product specifications.

STAND ATTACHMENTS

1

5 /

8

36 1

1 /

8

5 /

8

3 /

8

” w

25.4

7

39

2

3

17.5

14

17.5

17

25.4

5 /

8

18

7

25.4

1 /

4

" w

5 /

8

21

5

8.5

11.5

5

11.5

5 /

8

33

8

19

5 /

8

43

36

9,5

3 /

8

” w

19

7

25.4

3 /

8

” w

5 /

8

22

7.2

18.8

16

15.5

34

1

1 /

8

5 /

8

"

19

13

38

20

4

26

17

25

5 /

8

5 /

8

35

26

10

44

30

5

1

1 /

8

37

1

1 /

8

50

25

5

197

198

Art N°

050B

051NB

052B

059

059WM

061

061RA

062-2

064

066

043

043R

044

045

045-6

046

046MC

047-2

047-3

049B

038

039

040

041

042

036-14

036-38

036I

036MR

037

032B

032PC

032SPL

033

033B

034

034B

035

035WDG

035X

066BT

070BU

070CSU

076

076B

077

077B

083NW

083NWLB

085BS

085BSL

087NW

087NWLB

087NWSH

087PA

087WBK

014-38

014BIM

014MS

015

016

017

018

019

019-14

022

023

024B

025BS

025BSL

025TM

026

027

032BASE

032BBASE

032

001B

003B

003M

003MF

004B

004BAC

005B

007BSU

007BU

007BUAC

007CSU

007XU

008BSU

008BU

008CSU

008XU

012B

013

014-14

Description

BLACK NANO STAND

BACKLITE BASE

MINI BACKLITE BASE MALE ATTACHMENT

MINI BACKLITE BASE FEMALE ATTACHMENT

BLACK MASTER STAND

MASTER STAND

BLACK RANKER STAND

SENIOR STAND

ALU BLACK SENIOR STAND

BLACK AIR CUSHIONED ALU SENIOR STAND

SENIOR STAND

SENIOR STAND

BLACK CINE STAND

ALU-CINE BLACK STAND

CINE STAND

CINE STAND

BLACK BACKLITE STAND

ADAPTER SPIGOT

16MM FEMALE ADAPTER

16MM FEMALE ADAPTER

16MM FEMALE ADAPTER

16MM FEMALE ADAPTER

SPECIAL ADAPTER

16MM FEMALE ADAPTER

CASTER WHEEL SET

CASTER WHEEL SET

SPECIAL ADAPTER

SPECIAL ADAPTER

G-PESO

L-PESO

BLACK LIGHT BOOM (STAND NOT INCLUDED)

BLACK SUPERBOOM (STAND INCLUDED)

BLACK SUPERBOOM (STAND NOT INCLUDED)

SUPER BOOM WITH COLUMN STAND

SWIVELLING ADAPTER

STAND HOLDER

AUTOPOLE®

BLACK AUTOPOLE®

BASE AUTOPOLE® BASE

BASE BLACK AUTOPOLE® BASE

AUTOPOLE® PROTECTION CAPS

AUTOPOLE® SPIRIT LEVEL

EXTENSION TUBE

BLACK EXTENSION TUBE

EXTENSION TUBE

BLACK EXTENSION TUBE

SUPER CLAMP

SUPER CLAMP WEDGES

SUPER CLAMP STAINLESS

LIGHTING STUD 1/4"

LIGHTING STUD 3/8"

LIGHT STUD

LIGHT STUD MR

CAMERA STUD

DOUBLE SUPER CLAMP

“U” HOOKS

NARROW “U”HOOKS

“L” BRACKETS

EXTENSION ARM

SKY HOOK

SKY HOOK

B/P CLAMPS

B/P TRIPLE HOOKS

B/P HOOKS

EXPAN

EXPAN WITH METAL CHAIN

ALU-CORE

ALU-CORE

BLACK QUICK LOCK COMPACT STAND

BLACK QUICK LOCK STAND

BLACK MINI COMPACT STAND

BLACK COMPACT STAND

B/P SINGLE HOOKS

B/P SINGLE HOOKS

JOINING STUD

JOINING STUD RA

B/P COUNTERWEIGHT

SMALL CABLE CLIP

DOUBLE FEMALE THREAD STUD

STUD FOR STIRRUP

ALU BLACK FOLLOW SPOT STAND

FOLLOW SPOT STAND

AUTOPOLE®

BLACK AUTOPOLE®

AUTOPOLE®

BLACK AUTOPOLE®

2 SCT WIND-UP STAND

2 SCT LOW BASE WIND-UP STAND

BLACK LIGHT BOOM 35 (STAND INCLUDED)

BLACK LIGHT BOOM 35 (STAND NOT INCLUDED)

WIND-UP STAND

3 SCT LOW BASE WIND-UP STAND

SHORT WIND-UP STAND

PEG ADAPTER SET

WIND-BRACING KIT

Description

SPECIAL ADAPTER

SPECIAL ADAPTER

EXPAN CHAIN - 1M LONG, BLACK

EXPAN CHAIN - 3M LONG, BLACK

EXPAN CHAIN - 3M LONG, GREY

EXPAN CHAIN - 3M LONG, RED

EXPAN CHAIN - 1M LONG, GREY

EXPAN BLACK METALLIC CHAIN

EXPAN GREY METALLIC CHAIN

EXPAN RED METALLIC CHAIN

EXPAN CHAIN - 1M LONG, RED

LARGE CABLE CLIP

CHAIN WEIGHT

BLACK WALL BOOM (STAND NOT INCLUDED)

BLACK SHORT WALL BOOM (STAND NOT INCLUDED)

BLACK BABY STAND EXTENSION

WHEEL SET

WHEEL SET

WHEEL SET

WHEEL SET

WHEEL SET

WHEEL SET

BLACK TALL STAND

TALL STAND

SHORT 16MM SPIGOT WITH 1/4"+3/8" SCREW

ADAPTER SPIGOT 1/4"F+3/8"F THREADS

BLACK POLE FOR BACKLITE STAND

PIVOTING BOOM CLAMP

PIVOTING BOOM CLAMP

HEAVY DUTY STAND

HEAVY DUTY STAND AIR CUSHIONED

HEAVY DUTY STAND

HEAVY DUTY STAND AIR CUSHIONED

BLACK LE LEVELLING LEG STAND AIR CUSHIONED

EXTENSION BAR

BLACK EXTENSION BAR

LIGHTING GANTRY BAR

BLACK LIGHTING GANTRY BAR

BLACK STAND EXTENSION

STAND EXTENSION

BLACK ALU STAND EXTENSION

STAND EXTENSION

SHORT STAND EXTENSION

BLACK ALU SHORT STAND EXTENSION

MAGIC ARM KIT

MAGIC ARM WITH CAMERA BRACKET

CAMERA/UMBRELLA BRACKET

FORK

DOUBLE FIXED FORK

DOUBLE HINGED FORK

MAGIC ARM

ALU BLACK ALU HIGH STAND EXTENSION

HIGH STAND EXTENSION

SPECIAL ADAPTER - SET OF 5

SPECIAL ADAPTER

16MM MALE ADAPTER

16MM FEMALE ADAPTER

16MM FEMALE ADAPTER

MICROPHONE SUPPORT

BLACK MICROPHONE SUPPORT

TILT TOP HEAD

TILT TOP HEAD

BLACK LOW MINI PRO STAND

16MM FEMALE ADAPTER

16MM FEMALE ADAPTER

28MM MALE ADAPTER

28MM MALE ADAPTER

28MM MALE ADAPTER

SPECIAL ADAPTER

FIVE SOCKET BRACKET

MINI POLE

BLACK MINI POLE

MINI POLE BASE

BLACK MINI POLE BASE

MINI CLAMP

MINI COUNTER WEIGHT

BLACK MINI BOOM

BLACK LONG MINI BOOM

HEXAGONAL 16MM LIGHTING STUD M10

SPRING CLAMP

SPRING CLAMP WITH FLASH SHOE

MINI “U”HOOKS

MINI B/P SINGLE HOOKS

MINI CLIP

16MM FEMALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM FEMALE ADAPTER

16MM MALE ADAPTER

SPECIAL ADAPTER

16MM FEMALE ADAPTER

Page Art N°

14

12

13

50-79

79

51-195

51-195

80

190

51-195

78

78

80

80

12

46

46

79

79

79

51-195

51-195

51-195

51-195

51-195

48

50

50

50-58

50-58

73

73

48

50

48

72

73

73

73

73

51-195

21

21

70

70

70

70

35

35

63

36

28

28-141

62

36

35

66-181

64

63

62

64

196

190

70

70

72

191

191

194

194

66-181

192

192

192

194

192

22

22

11

51-92-193-195

192

23

24

24

21

21

14

14

13

23

23

11

11

11

11

154B

155

155BKL

156BLB

158

159

163-10

163-12

163-38

163-58F

169

170

170B

170BASE

170BBASE

171

172

173B

173HOB

174

149

151

152

153

154

143FV

143N

146B

146CS

148KN

142ACS

142B

142CS

142CSSH

142SHB

143

143A

143BKT

143F

143FD

179

182

184

185

186

175

175F

176

177

178

187

188

189

191

192

193

109

110

110G

111BSU

111CSU

118

119

122B

123

124

126BSU

126BSUAC

126CSU

126CSUAC

126MBUAC

133

133B

135

135B

142ABS

088

088LBP

091B

091FLB

091FLG

091FLR

091G

091MCB

091MCG

091MCR

091R

093

094

098B

098SHB

099B

103

104

104G

Page

47

66-181

66

66

51-195

58

73

73

72

72

58

49-196

49-196

11

92-192

192

194

194

194

195

156

49-54

29

29

194

194

193

192

192

58

54

49-54

54

156

156

29

29

29

29

29

46

46

50

50-79

190

192

193

193

193

193

193

193

192

193

194

192

51-193-195

51-193-195

15-49

67

67

191

191

191

25

25

51-58

51-58

58

58

29

24

24

25

25

40

65

15

107-191

107-191

107-191

80

80

190

80

64

80

80

80

80

80

194

194

80

80

Art N°

374

374-10

375

387XU

396AB-2

396AB-3

396B-2

396B-3

420B

420CSU

320PX

332-1.7

332-1.7B

332-2.7

332-2.7B

332-3.7

332-3.7B

335AS

362

371

270CSU

271

272B

275

297BBASE

297CS

297FBASE

298B

299B

299BBASE

299FBASE

305B

306B

307B

314B

317-6

320

320B

320PSL

320PSLB

420CSUNS

420NSB

425B

428-2.5

428-4.0

428-7.5

432-1.7

432-1.7B

432-2.7

432-2.7B

432-3.7

432-3.7B

602BSM

604BSM

606BSM

611-10

220PX

231ARM

231B

231CS

233B

237

237HD

241

241S

244

244N

251

254B

256BUAC

256MBUAC

256UAC-3

264

269BU

269HDBU

270BSU

194

195

196

196A

196AB-2

196AB-3

196AC

196B-2

196B-3

196BASE

201

203

204

206

209B

220

220B

220PSL

220PSLB

Description

16MM FEMALE ADAPTER

16MM MALE ADAPTER

MINI ARTICULATED ARM WITH CAMERA BRACKET

MINI ARTICULATED ARM

2 SECTION SINGLE ARTICULATED ARM

3 SECTION SINGLE ARTICULATED ARM

MICRO CLAMP

2 SECTION SINGLE ARTICULATED ARM WITH CAMERA ATTACHMENT

3 SECTION SINGLE ARTICULATED ARM WITH CAMERA ATTACHMENT

BASE FOR ARTICULATED ARM

ADJUSTABLE MINI CLIP

MINI EXTENSION ARM

MINI “L” BRACKETS

CABLE CLIP

TABLE TOP TRIPOD

STILL LIFE TABLE

BLACK STILL LIFE TABLE

STILL LIFE TABLE WITHOUT COVER

BLACK STILL LIFE TABLE WITHOUT COVER

PERSPEX COVER FOR STILL LIFE TABLE

SLIDING SUPPORT ARM

ALU COLUMN STAND

COLUMN STAND

CAMERA FLASH ARM

FLEX ARM

FLEX ARM HEAVY DUTY

PUMP CUP WITH 16MM SWIVEL SOCKET

PUMP CUP WITH 16MM SOCKET

VARIABLE FRICTION ARM WITH CAMERA BRACKET

VARIABLE FRICTION ARM

WHEELS FOR SUPER WIND UP

BLACK AUTOBOOM (STAND NOT INCLUDED)

BLACK SELF LOCK STAND

BLACK LE SELF LOCK STAND AIR CUSHIONED

HIGH SELF LOCK STAND

ROUNDED 16MM LIGHTING STUD M10

BLACK SUPER ALU STAND

BLACK HIGH SUPER ALU STAND

SUPER STEEL STAND

SUPER STEEL STAND

PANEL CLAMP

TELESCOPIC POLE

MINI SPRING CLAMP

BRAKE BASE LARGE

STEEL STUDIO STAND

FOOT BASE LARGE

BLACK ALU-STUDIO STAND

BLACK BABY STUDIO STAND

BRAKE BASE SMALL

FOOT BASE SMALL

BLACK MINI STACKER STAND

BLACK STACKER STAND

BLACK MAXI STACKER STAND

SET STANDS KIT

WINCHER STAND

MINI STILL LIFE TABLE

BLACK MINI STILL LIFE TABLE

MINI STILL LIFE TABLE WITHOUT COVER

BLACK MINI STILL LIFE TABLE WITHOUT COVER

PERSPEX COVER FOR MINI STILL LIFE TABLE

MINI AUTOPOLE®

BLACK MINI AUTOPOLE®

MINI AUTOPOLE®

BLACK MINI AUTOPOLE®

MINI AUTOPOLE®

BLACK MINI AUTOPOLE®

ADDITIONAL SOCKET

POLE OPERATED TELESCOPIC BAR

CABLE GRIPS

WHEELS FOR SUPER WIND UP

WHEELS FOR SUPER WIND UP

MULTICLIP

SUPER WIND-UP STAINLESS STEEL STAND

2 SECTION DOUBLE ARTICULATED ARM

3 SECTION DOUBLE ARTICULATED ARM

2 SECTION DOUBLE ARTICULATED ARM WITH CAMERA ATTACHMENT

3 SECTION DOUBLE ARTICULATED ARM WITH CAMERA ATTACHMENT

BLACK COMBI-BOOM STAND (WITH SANDBAG)

COMBI-BOOM STAND HD

COMBI-BOOM STAND HD (WITHOUT SANDBAG)

BLACK COMBI-BOOM STAND (WITHOUT SANDBAG)

MEGA BOOM (STAND NOT INCLUDED)

OPERATING POLE

OPERATING POLE

OPERATING POLE

AUTOPOLE2®

BLACK AUTOPOLE2®

AUTOPOLE2®

BLACK AUTOPOLE2®

AUTOPOLE2®

BLACK AUTOPOLE2®

BLACK LE LOW STAND

BLACK LE MIDI STAND

BLACK LE MAXI STAND

STAND TOP M10

Page Art N°

57

57

57

19

19

191

191

46

37

57

71

71

50

93

190

103

71

71

71

71

143

103

103

103

103

33

17

17

17

81

31

33

32

32

33

27

47

81

46

33

91

71

71

71

71

19

19

62

91

91

41

41

42

71

71

40

49-54

191

64

22

40

23

51-195

26

27

26

49-55

49-55

59

59

49-54

102

108

31

31

55

55

190

50-58

50-58

190

39

102

102

102

102

56

56

47

56

56

192

193

49

49

A215SJB

A215SJCB

A218S

A218SB

A218SCB

A218SJ

A218SJB

A218SJCB

A225S

A225SB

A225SCB

A225SJ

A225SJB

A225SJCB

A228S

A228SB

A228SCB

A228SJ

A228SJB

A228SJCB

A120

A122

A125B

A128

A205S

A205SB

A205SCB

A205SJ

A205SJB

A205SJCB

A208S

A208SB

A208SCB

A208SJ

A208SJB

A208SJCB

A215S

A215SB

A215SCB

A215SJ

A235S

A235SB

A235SCB

A235SJ

A235SJB

A235SJCB

A245S

A245SB

A245SCB

A245SJ

A245SJB

A245SJCB

A247S

A247SB

A247SCB

A247SJ

852K-4

854-10

854-4

854-6

A004MT

A005MT

A100

A105B

A110

A115B

697

698

699

850

850EU

850UNIV

850US

851

851K-4

852

618

619

620-10

620-12

622B

622CS

623

624

635

649

611-12

612

613

613PAR

614

615

616-10

616-12

617

Description Page

148

148

148

148

148

148

148

148

148

148

147

147

147

148

148

147

147

147

147

147

146

147

147

147

147

146

146

146

146

146

146

146

146

146

146

125

125

125

125

146

146

147

147

147

147

146

146

146

146

146

147

147

148

148

148

148

118

127

127

126

126

77

77

77

77

119

28

28-43

28

76

77

77

77

76

77

76

39

43

43

48

47

43

43

194

194

39

59

59

42

42

42

42

43

59

59

STAND TOP M12

CABINET FITTINGS

T BAR

T BAR

T BAR

T BAR

PAN SPIGOT M10

PAN SPIGOT M12

28MM ADAPTER

SPEAKER ADAPTER FOR 28MM BUSHING

SPEAKER ADAPTER FOR STAND

28MM MALE ADAPTER

28MM MALE ADAPTER

BLACK ALU MICROPHONE STAND

STEEL MICROPHONE STAND

LE 16MM ADAPTER

TILTING SPEAKER ADAPTER

QUICK ACTION SUPER CLAMP

QUICK RELEASE CLAMP

SAFETY COLLAR

SAFETY COLLAR

SAFETY COLLAR

BACKGROUND ROLL SUPPORTING SPIGOTS

MAIN POWER CABLE - EUROPEAN

MAIN POWER CABLE

MAIN POWER CABLE - USA

CONTROL BOX - 110V

MOTORIZED EXPAN KIT

CONTROL BOX - 220V

MOTORIZED EXPAN KIT

HOLDER FOR 10 BACKGROUNDS

HOLDER FOR 4 BACKGROUNDS

HOLDER FOR 6 BACKGROUNDS

MASTER STAND

RANKER STAND

HIGH COMBO STAND

BLACK ALU-COMBO STAND

COMBO STAND

BLACK ALU-COMBO STAND

LOW COMBO STAND

MINI LOW COMBO STAND

BLACK LOW ALU COMBO STAND

MINI LOW COMBO

40” CENTURY STAND BLACK

40” CENTURY STAND

BLACK CHROME 40” CENTURY STAND BLACK

17MM FEMALE ATTACH. 40” CENTURY STAND BLACK

17MM FEMALE ATTACH. 40” CENTURY STAND

BLACK CHROME 17MM FEMALE ATTACH. 40” CENTURY STAND BLACK

60” CENTURY STAND

60” CENTURY STAND BLACK

BLACK CHROME 60” CENTURY STAND

17MM FEMALE ATTACH. 60” CENTURY STAND

17MM FEMALE ATTACH. 60” CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 60” CENTURY STAND

40” SLIDING LEG CENTURY STAND

40” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 40” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 40” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 40” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 40” SLIDING LEG CENTURY STAND

60” SLIDING LEG CENTURY STAND

60” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 60” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 60” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 60” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 60” SLIDING LEG CENTURY STAND

40” DETACHABLE CENTURY STAND BASE

40” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 40” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 40” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 40” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 17MM FEMALE ATTACH. 40” DETACHABLE CENTURY STAND BASE

60” DETACHABLE CENTURY STAND BASE

60” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 60” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 60” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 60” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 17MM FEMALE ATTACH. 60” DETACHABLE CENTURY STAND BASE

30” CENTURY STAND

30” CENTURY STAND BLACK

BLACK CHROME 30” CENTURY STAND

17MM FEMALE ATTACH. 30” CENTURY STAND

17MM FEMALE ATTACH. 30” CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 30” CENTURY STAND

30” SLIDING LEG CENTURY STAND

30” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 30” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 30” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 30” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 30” SLIDING LEG CENTURY STAND

30” DETACHABLE CENTURY STAND BASE

30” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 30” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 30” DETACHABLE CENTURY STAND BASE

199

200

Art N°

A312

A320

A330

A400B

A410B

A410C

A416JM

A420

A430

A450

A285SJCB

A290S

A290SB

A290SCB

A290SJ

A290SJB

A290SJCB

A300

A302

A310

A275SJ

A275SJB

A275SJCB

A278S

A278SB

A278SCB

A278SJ

A278SJB

A278SJCB

A280S

A280SB

A280SCB

A280SJ

A280SJB

A280SJCB

A285S

A285SB

A285SCB

A285SJ

A285SJB

A470

A475B

A500

A510

A608B

A615B

A625B

A626BU

A630B

A635B

A645B

A650

A660

A665

A680

A690

A257SJCB

A265S

A265SCB

A268S

A268SCB

A270S

A270SB

A270SCB

A270SJ

A270SJB

A270SJCB

A272S

A272SB

A272SCB

A272SJ

A272SJB

A272SJCB

A275S

A275SB

A275SCB

A247SJB

A247SJCB

A255S

A255SB

A255SCB

A255SJ

A255SJB

A255SJCB

A256S

A256SB

A256SCB

A256SJ

A256SJB

A256SJCB

A257S

A257SB

A257SCB

A257SJ

A257SJB

Description

17MM FEMALE ATTACH. 30” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 17MM FEMALE ATTACH. 30” DETACHABLE CENTURY STAND BASE

20” CENTURY STAND

20” CENTURY STAND BLACK

BLACK CHROME 20” CENTURY STAND

17MM FEMALE ATTACH. 20” CENTURY STAND

17MM FEMALE ATTACH. 20” CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 20” CENTURY STAND

20” SLIDING LEG CENTURY STAND

20” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 20” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 20” SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 20” SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 20” SLIDING LEG CENTURY STAND

20” DETACHABLE CENTURY STAND BASE

20” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 20” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 20” DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTACH. 20” DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 17MM FEMALE ATTACH. 20” DETACHABLE CENTURY STAND BASE

TURTLE BASE

BLACK CHROME TURTLE BASE

MINI TURTLE BASE

BLACK CHROME MINI TURTLE BASE

40” DOUBLE RISER COLUMN

40” DOUBLE RISER COLUMN BLACK

BLACK CHROME 40” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 40” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 40” DOUBLE RISER COLUMN BLACK

BLACK CHROME 17MM FEMALE ATTACH. 40” DOUBLE RISER COLUMN

30” DOUBLE RISER COLUMN

30” DOUBLE RISER COLUMN BLACK

BLACK CHROME 30” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 30” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 30” DOUBLE RISER COLUMN BLACK

BLACK CHROME 17MM FEMALE ATTACH. 30” DOUBLE RISER COLUMN

20” DOUBLE RISER COLUMN

20” DOUBLE RISER COLUMN BLACK

BLACK CHROME 20” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 20” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 20” DOUBLE RISER COLUMN BLACK

BLACK CHROME 17MM FEMALE ATTACH. 20” DOUBLE RISER COLUMN

60” DOUBLE RISER COLUMN

60” DOUBLE RISER COLUMN BLACK

BLACK CHROME 60” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 60” DOUBLE RISER COLUMN

17MM FEMALE ATTACH. 60” DOUBLE RISER COLUMN BLACK

BLACK CHROME 17MM FEMALE ATTACH. 60” DOUBLE RISER COLUMN

20” MINI BASE CENTURY STAND

20” MINI BASE CENTURY STAND BLACK

BLACK CHROME 20” MINI BASE CENTURY STAND

17MM FEMALE ATTACH. 20” MINI BASE CENTURY STAND

17MM FEMALE ATTACH. 20” MINI BASE CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 20” MINI BASE CENTURY STAND

20” MINI BASE SLIDING LEG CENTURY STAND

20” MINI BASE SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 20” MINI BASE SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 20” MINI BASE SLIDING LEG CENTURY STAND

17MM FEMALE ATTACH. 20” MINI BASE SLIDING LEG CENTURY STAND BLACK

BLACK CHROME 17MM FEMALE ATTACH. 20” MINI BASE SLIDING LEG CENTURY STAND

20” MINI DETACHABLE CENTURY STAND BASE

20” MINI DETACHABLE CENTURY STAND BLACK BASE

BLACK CHROME 20” MINI DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTCH. 20” MINI DETACHABLE CENTURY STAND BASE

17MM FEMALE ATTCH. 20” MINI DETACHABLE CENTURY STAND BASE BLACK

BLACK CHROME 17MM FEMALE ATTCH. 20” MINI DETACHABLE CENTURY STAND BASE BL

HIGH OVERHEAD ROLLER STAND WITH BRAKED WHEELS

HIGH OVERHEAD STAND

MEDIUM OVERHEAD ROLLER STAND WITH BRAKED WHEELS

MEDIUM OVERHEAD STAND

WIDE BASE HIGH OVERHEAD STAND

SUPER HIGH OVERHEAD STAND

ALU-BABY STAND

HIGH ALU-BABY STAND

HIGH BABY STAND

BABY J STAND

BABY ROLLER STAND

HIGH BABY ROLLER STAND

MIGHTY BABY STAND

BABY STEEL COMBI-BOOM STAND

BABY COMBI-BOOM STAND

HIGH JUNIOR ROLLER STAND

JUNIOR ROLLER STAND

BACKLITE STAND H.D.

MINI KIT STAND

MIDI KIT STAND

BLACK HEAVY DUTY STAND

MIDI-MAX KIT STAND

MAXI KIT STAND

ALU-CINE COMBO STAND

CINE COMBO STAND

BABY FOLDING BASE STUDIO STAND

HIGH BABY FOLDING BASE STUDIO STAND

LOWBOY JUNIOR FOLDING BASE STUDIO STAND

HIGH JUNIOR FOLDING BASE STUDIO STAND

Page Art N°

119

118

121

123

117

161

160

160

118

119

148

148

161

161

161

147

148

148

148

148

147

147

147

147

147

146

146

146

146

146

149

149

149

149

146

149

149

149

149

149

117

117

127

118

119

129

129

123

122

117

126

126

121

121

121

122

149

149

149

149

149

149

149

149

149

149

149

149

149

149

149

148

149

149

149

149

148

148

148

148

148

147

147

147

147

147

146

146

146

146

147

148

148

146

146

C460

C461

C462

C463

C464

C465

C480

C481

C482

C500

C4461

C4462

C4463

C4464

C4465

C4469

C4470

C4482

C4485

C4486

C339BB

C339JS

C339LE

C339SP

C339UH

C350N

C350NK

C356

C466

C4460

C280

C285

C290

C295

C300

C330

C335

C337

C338

C339

C590

C622

C624

C626

C700

C720

C820

C822

C825

C827

C888ST

C888UH

D050

D050B

D050G

D050LB

C1100

C150

C151

C155

C1550

C155-01

C155-02

C155-03

C1575B

C210

B250X

B300P

B9000J

B9000P

B9000PS

B9005F

B9005R

C100

C1000

C1005

B143

B144

B145

B150

B197

B198

B199

B200

B201

B205

A700

A9000

A9000B

B100

B105N

B120

B130

B140

B140XL

Description

JUNIOR BOOM STAND

BRAKED WHEEL

BLACK BRAKED WHEEL

STRATO SAFE SHORT BASE STAND WITH BRAKED WHEELS

STRATO SAFE STAND SHORT BASE WITH BRAKED WHEELS

SECTION STRATO SAFE STAND WITH BRAKED WHEELS

SECTION STRATO SAFE STAND WITH BRAKED WHEELS

SECTION STRATO SAFE STAND WITH BRAKED WHEELS

FLAT JUMPER STRATO SAFE WITH BRAKED WHEELS

REDUCTION KIT

REDUCTION KIT

REDUCTION KIT

SECTION STRATO SAFE STAND WITH BRAKED WHEELS

EXTENSION KIT

EXTENSION KIT

EXTENSION KIT

WIND-UP STAND WITH BRAKED WHEELS

SHORT WIND-UP STAND WITH BRAKED WHEELS

SCT WIND-UP STAND WITH BRAKED WHEELS

SUPER WIND-UP STAINLESS STEEL STAND WITH BRAKED WHEELS

SAFE CRANK STAND

LEVELLING JACKS

PNEUMATIC WHEELS

PNEUMATIC WHEELS

FIXED HANDLE

RATCHET HANDLE

JUNIOR PIPE CLAMP WITH 28MM SOCKET

SPECIAL ADAPTER

SPECIAL ADAPTER

SPECIAL ADAPTER

SWIVELLING “C” CLAMP

SWIVELLING “C” CLAMP WITH M12 SCREW

SAFETY CABLE

HEAVY DUTY SUPER CLAMP

SAFETY CABLE

SAFETY CABLE

SAFETY CABLE

SUPER CLAMP

BABY PIPE CLAMP WITH 16MM STUD

STAGE CLAMP

STAGE CLAMP WITH 16MM STUD

STAGE CLAMP WITH 28MM STUD

STAGE CLAMP WITH 28MM SOCKET

GRID CLAMP

FIXED BABY SIDE ARM

FIXED JUNIOR SIDE ARM

QUICK ACTION JUNIOR CLAMP 28MM BUSHING

QUICK ACTION BABY CLAMP 16MM PIN

GRAB CLAMP

GRAB CLAMP WITH 16MM BUSHING

GRAB CLAMP WITH 28MM TV SPIGOT

GRAB CLAMP WITH LIFTING EYE

GRAB CLAMP WITH SPINNING PULLEY

GRAB CLAMP WITH UNIVERSAL HEAD

BARREL CLAMP

BARREL CLAMP WITH KNOB

SLIM HOOK CLAMP

LP EYE COUPLER CONNECTION KIT

MP EYE SLIM COUPLER

MP EYE COUPLER WITH 28MM TV SPIGOT

MP EYE COUPLER WITH 16MM SPIGOT

MP EYE COUPLER WITH LIFTING EYE

MP EYE SLIM COUPLER WITH M12 BOLT PLUS NUT

MP EYE COUPLER W/28MM FEMALE ATTACHMENT

MP EYE COUPLER WITH 16MM BUSHING

MP EYE TILT & SWIVEL EYE COUPLER

SWIVEL MP EYE COUPLER

MP EYE COUPLER SWIVEL AND TILT TRUSS SUPPORT 150

MP EYE COUPLER SWIVEL TRUSS AND TILT SUPPORT 200

LP EYE COUPLER

LP EYE COUPLER WITH 28MM TV SPIGOT

LP EYE COUPLER WITH 16MM SPIGOT

LP EYE COUPLER WITH LIFTING EYE

LP EYE COUPLER WITH M12 BOLT PLUS NUT

LP EYE COUPLER W/28MM FEMALE ATTACHMENT

PARALLEL LP EYE COUPLER

FIXED 90 LP EYE COUPLER

SWIVEL LP EYE COUPLER

PELICAN GAFFER GRIP

CONKA BONKA

SMALL STEEL STAND EXTENSION

MEDIUM STEEL STAND EXTENSION

LONG STEEL STAND EXTENSION

SQUARE CLAMP WITH 16MM RECEIVER

SQUARE CLAMP WITH 16MM PIN

TELESCOPIC HANGER WITH STIRRUP

LONG TELESCOPIC HANGER WITH STIRRUP

TELESCOPIC HANGER WITH UNIVERSAL HEAD

LONG TELESCOPIC HANGER WITH UNIVERSAL HEAD

TELESCOPIC HANGER WITH STIRRUP

TELESCOPIC HANGER WITH UNIVERSAL HEAD

SET OF 6 BLUE T-TOPS

SET OF 6 BLACK T-TOPS

SET OF 6 GREY T-TOPS

SET OF 6 LIGHT BLUE T-TOPS

Page

174

174

174

175

169

174

174

174

174

174

176

176

176

176

176

175

175

175

175

175

170

170

172

175

176

177

177

177

177

177

183

183

173

173

177

172

172

172

172

170

170

168

168

168

168

135

135

135

135

170

168

168

151

151

151

151

194

169

169

47-170

171

47-170

47-170

47-170

171

171

141

141

171

194

194

132

139

141

141

141

141

141

133

133

131

141

141

141

140

141

137

138

138

140

140

129

191

191

139

Art N°

F1504

F1520

F1521

F200

F300

F600

F700

F800

F805

F808

E610

E620

E650

E700

E710

F100

F1000

F1100

F1200

F1501

D750

D800KIT

E100

E110

E200

E250

E300

E390

E600

E600C

D560

D570

D570B

D580

D600

D600CB

D610

D650

D700B

D705B

F809

F810

F815

F820

F820RH

F820TH

F825

F825RH

F825TH

F830

F830RH

F830TH

F900

FF3032

FF3033

FF3043

D420

D420B

D430

D430B

D500

D500B

D520

D520B

D550

D550B

D306

D310

D315

D340

D350

D390

D400

D400B

D410

D410B

D220B

D230

D240

D240B

D250

D250B

D260

D260B

D300

D301

D050R

D050Y

D100

D100B

D200

D200B

D210

D210B

D220

Description

SET OF 6 RED T-TOPS

SET OF 6 YELLOW T-TOPS

DOUBLE GRIP HEAD

BLACK DOUBLE GRIP HEAD

2 1/2" GRIP HEAD

BLACK 2 1/2" GRIP HEAD

SNAP-IN GRIP HEAD

BLACK SNAP-IN GRIP HEAD

GRIP HELPER

BLACK GRIP HELPER

SUPER CLAMP GRIP HEAD

GRIP HEAD W/SWIVEL PIN

BLACK GRIP HEAD W/SWIVEL PIN

GAG GOBO

BLACK GAG GOBO

ADDAHEAD

BLACK ADDAHEAD

ARTICULATED ARM WITH SPRING CLAMP

SNAP IN ARTICULATED ARM

ARTICULATED ARM WITH HEXAGONAL END

MINI-FLEX ARM

MAXI-FLEX ARM

CAMERA FLEXTENTION KIT

SPECIAL ADAPTER

UNIVERSAL FLEXTENTION KIT

4 1/2" JUMBO GRIP HEAD

BLACK 4 1/2" JUMBO GRIP HEAD

JUMBO ADDAHEAD

BLACK JUMBO ADDAHEAD

JUMBO GAG GOBO

BLACK JUMBO GAG GOBO

JUMBO GRIP HELPER

BLACK JUMBO GRIP HELPER

20" EXTENSION GRIP ARM

BLACK 20" EXTENSION GRIP ARM

40" EXTENSION GRIP ARM

BLACK 40" EXTENSION GRIP ARM

FUN GRIP ARM

BLACK FUN GRIP ARM

BALL AND SOCKET FLAG ARM

EXTENSION ARM WITH SWIVEL PIN

BLACK EXTENSION ARM WITH SWIVEL PIN

UNIVERSAL ARTICULATED ARM KIT

MINI BOOM

BLACK CHROME MINI BOOM

C-BOOM/FISHPOLE HOLDER

JUNIOR BOOM ARM

COLLAPSIBLE REFLECTOR HOLDER

COLLAPSIBLE REFLECTOR HOLDER LONG

40MM (1.6") TELESCOPIC POLY HOLDER

GRIP KIT

SPECIAL ADAPTER

SPECIAL ADAPTER

28MM MALE ADAPTER

16MM MALE ADAPTER

16MM MALE ADAPTER

16MM FEMALE ADAPTER

SNAP-IN PIN FOR SUPER CLAMP

STEEL SNAP-IN PIN FOR SUPER CLAMP

SPECIAL ADAPTER

SPECIAL ADAPTER

SPECIAL ADAPTER

BABY DROP DOWN PIN

JUNIOR DROP DOWN PIN

JUNIOR OFFSET ARM-28MM PIN & 28MM SOCKET

PUMP CUP WITH 16MM BABY SWIVEL SPIGOT

PUMP CUP WITH 16MM BABY FIXED SPIGOT

COLUMN ARM

30MM (1.2") POLYHOLDER

FOAMCORE FORK 16MM PIN

50MM (2") POLYHOLDER W/SWIVEL JOINT, 28 MM SPIGOT

50MM (2") POLYHOLDER W/SWIVEL JOINT, 16 MM SPIGOT

JUNIOR ADJUSTABLE SIDE ARM-28MM SOCKET

JUNIOR WALL PLATE

BABY OFFSET ARM/TWIN 16MM PIN & 16MM SOCKET

BABY SIDE ARM TWIN 16MM PIN

3" BABY WALL PLATE

6" BABY WALL PLATE

9" BABY WALL PLATE

BABY PLATE WITH 90 PIN

BABY PLATE WITH 16MM SWIVEL SPIGOT

BABY PLATE "T" PIN

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

SWIVELLING ADAPTER

BABY TRIPLE HEADER 5 X 16MM PIN & 16MM SOCKET

TOP SYSTEM 32

TOP SYSTEM 33

TOP SYSTEM 43

Page Art N°

182

182

187

187

187

157

157

157

182

187

195

195

193

67-127

67-127

182

186

186

182

157

193

193

192

151-195

151-195

157

151

195

195

194

180

161

180

156

156

155

180

180

154

180

196

196

196

196

196

187

187

187

196

196

196

196

182

98

98

99

151

151

151

151

151

151

151

151

151

151

154

151-161

151-161

151

151

183

183

183

154

194

150

150

150

183

183

150

150

150

150

150

150

150

150

150

150

151

151

150

150

H406EXT

H408EXT

H440

H44BAG

H600M

H660

H6BAG

H800M

H806EXT

H812EXT

H1220EXT

H2000M

H2006

H2008

H2012

H2020BAG

H2020XBAG

H2508

H2512

H400M

FF3532

FF3533

FF3534

FF3856

FF6003B

FF6004B

FF6005B

G100

G200

H1200M

FF3288MKIT

FF3290

FF3325

FF3340

FF3350

FF3400

FF3450

FF3512N86

FF3514N86

FF3531

H88BAG

H9000

H9500

I100B

I100D

I100GS

I100K

I100S

I100SW

I1010

I1010FRAME

I1011

I1011FRAME

I1020

I1020FRAME

I1021

FF3226V

FF3228

FF3229

FF3230

FF3232

FF3235

FF3236

FF3240

FF3242

FF3248

FF3249

FF3257

FF3260

FF3261

FF3262

FF3265

FF3272

FF3276

FF3278

FF3286MKIT

FF3054

FF3207

FF3208

FF3210

FF3211

FF3212

FF3214

FF3214A

FF3214B

FF3215

FF3215A

FF3216

FF3218

FF3220

FF3221

FF3224

FF3226

FF3226C

FF3226S

Page

163

163

163

163

163

163

163

163

164

163

164

164

162

162

163

163

163

162

162

162

84

84

149

149

163

94

94

94

90

84

97

88

94

94

94

95

96

89

88

89

153

153

153

153

153

164

163

163

153

153

153

153

153

153

153

153

93

93

95

93

95

95

92

92

92

93

89

89

95

95

95

91

88

88

88

89

90

90

91

91

91

85

86

86

86

86

85

85

87

87

87

99

87

87

85

Description

TOP SYSTEM 54

KIT OF 4 END STOPS WITH 4 CABLE CARRIAGES

ALIGNING CONNECTORS FOR FIXED RAILS

BRACKET FOR CEILING ATTACHMENT

DOUBLE BRACKET FOR RAIL CROSSINGS

ANGLE BRACKET (“L” - SHAPED) FOR FIXING TO BEAMS

BRACKET FOR TUBE ATTACHMENT

BRACKET FOR CEILING ATTACHMENT

RAIL MOUNTING KIT WITH M12 STUD

ADJUSTABLE BRACKET FOR IRREGULAR CEILINGS

EXTENSION BRACKET FOR VARIOUS HEIGHTS

CEILING BRACKET WITH 30CM EXTENSION

CEILING BRACKET WITH 50CM EXTENSION

CEILING BRACKET WITH 100CM EXTENSION

FIXED BRACKET ON RAIL WITH FEMALE ATTACHMENT 16MM

SET OF 2 SUPPORTS WITH TRIPLE BACKGROUND HOOKS

KIT OF 5 CABLE CARRIAGES

KIT OF 5 CABLE CARRIAGES WITH BEARING

KIT OF 5 DISMOUNTABLE CABLE CARRIAGES

CABLE HOLDER CARRIAGE FOR LARGE SECTION CABLES

DISMOUNTABLE SLIDING CARRIAGE WITH 4 WHEELS AND 16MM SPIGOT

4-WHEELED SLIDING CARRIAGE WITH BRAKE AND 16MM SPIGOT

4-WHEELED SLIDING CARRIAGE WITH 16MM SPIGOT

DOUBLE SLIDING CARRIAGE

DOUBLE SLIDING CARRIAGE WITH DOUBLE BRAKE

DOUBLE SLIDING CARRIAGE WITH ONE BRAKE

EXTENSION TUBE 50CM LONG

EXTENSION TUBE 100CM LONG

TELESCOPIC POST EXTENDABLE FROM 85CM TO 203CM

SMALL TELESCOPIC POST EXTENDABLE FROM 60CM TO 128CM

SPIGOT ADAPTER 16MM FEMALE 28MM FEMALE

SPIGOT ADAPTER 16MM/28MM

BALANCE ADJUSTMENT BRACKET

BRACKET FOR MULTIPLE MOUNTING

UNIVERSAL SUPPORT FOR FLASH GENERATORS AND BALLAST

OVERHEAD OUTLET-BOX WITH 3 UNIVERSAL SOCKETS

SAFETY STEEL CABLE

POWER SUPPLY CABLE

POWER SUPPLY KIT 4 CHANNEL

POWER SUPPLY KIT 8 CHANNEL

TOP TWIST

DOUBLE SLIDING CARRIAGE WITH AN EXTRA HEIGHT

MOTORISED CARRIAGE WITH 5/8" SPIGOT

MOTORISED DOUBLE CARRIAGE

TOP TWIST/S

MOTORISED HEAD

PANTOGRAPH TOP 2C

PANTOGRAPH TOP 4C

SPRING TYPE 4 RED

SPRING TYPE 12 RED

SPRING TYPE 4 BLUE

SPRING CLAMP 12 BLUE

FIXED BRACKET ON RAIL WITH 16MM SPIGOT

3M RAIL ANODIZED (BLACK)

4M RAIL ANODIZED (BLACK)

5M RAIL ANODIZED (BLACK)

SMALL SAND BAG

LARGE SAND BAG

MODULAR FRAME 12X12"

MODULAR FRAME CONVERSION KIT FROM 12X12" TO 20X20"

MODULAR FRAME 20X20"

FOLD AWAY FRAME 6X6"

FOLD AWAY FRAME 8X8"

FOLD AWAY FRAME 12X12"

BAG FOR 20X20" BUTTERFLY TEXTILES

BAG FOR 20X20" CROMAKEY TEXTILES

AVENGER FOLD AWAY FRAME COMPACT 8X8"

AVENGER FOLD AWAY FRAME COMPACT 12X12"

AVENGER MODULAR FRAME 4X4"

AVENGER MODULAR FRAME CONVERSION KIT FROM 4X4" TO 6X6"

AVENGER MODULAR FRAME CONVERSION KIT FROM 4X4" TO 8X8"

LIGHTWEIGHT FRAME 4X4"

BAG FOR 4X4" AND 6X6" BUTTERFLY TEXTILES

MODULAR FRAME 6X6"

LIGHTWEIGHT FRAME 6X6"

FRAME BAG

MODULAR FRAME 8X8"

MODULAR FRAME CONVERSION KIT FROM 20X20", 12X12" AND 8X8" TO 6X6"

MODULAR FRAME CONVERSION KIT FROM 8X8" TO 12X12"

BAG FOR 8X8" AND 12X12" BUTTERFLY TEXTILES

D.I.Y. BUTTERFLY PIPE CORNER KIT 1 1/2"

D.I.Y. BUTTERFLY PIPE CORNER KIT 1 1/4"

DOT AND FINGER - SOLID BLACK 3"

DOT AND FINGER - DOUBLE SCRIM 3"

DOT AND FINGER - GOLD/SILVER 3"

DOT AND FINGER - SILK 3"

DOT AND FINGER - SINGLE SCRIM 3"

DOT AND FINGER - SUNLITE/WHITE 3"

FLOPPIE AND CUTTER - MEAT AXE FLAG 30X36"

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 30X36"

FLOPPIE AND CUTTER - MINI MEAT AXE FLAG 24X48"

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 24X48"

FLOPPIE AND CUTTER - CUTTER 10X42"

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 10X42"

FLOPPIE AND CUTTER - CUTTER 18X48"

201

202

Art N°

I610S

I6207

I6208

I6231

I6234

I6241

I650

I650B

I650CK

I650D

I600S

I600SW

I600T

I600TW

I601

I610

I610B

I610D

I610K

I610KIT

I500K

I500S

I500SW

I600

I600B

I600CK

I600D

I600DW

I600K

I600K4

I400SW

I4800BAG

I4807

I4808

I4831

I4834

I4841

I500B

I500D

I500GS

I650DW

I650K

I650K4

I650S

I650SW

I650T

I650TW

I651

I660

I660B

I660D

I660K

I660KIT

I660S

I700

I700B

I3807

I3808

I3831

I3834

I3841

I400B

I400D

I400GS

I400K

I400S

I2031

I2034

I2041

I300B

I300D

I300GS

I300K

I300S

I300SW

I3800BAG

I1021FRAME

I1022

I1022FRAME

I1023

I1023FRAME

I1024

I1024FRAME

I1030

I1031

I1550KIT

I2000BAG

I2007

I2008

I200B

I200D

I200GS

I200K

I200S

I200SW

Description

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 18X48"

FLOPPIE AND CUTTER - CUTTER 24X72"

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 24X72"

FLOPPIE AND CUTTER - CUTTER 40X40"

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 40X40"

FLOPPIE AND CUTTER - CUTTER 48X48

FLOPPIE AND CUTTER - CLOSE FRAME ONLY 48X48"

FLOPPIE AND CUTTER - FLOPPY CUTTER 24X72"

FLOPPIE AND CUTTER - FLOPPY CUTTER 48X48"

DOTS & FINGER KIT

BAG FOR OVAL REFLECTOR 20X15"

OVAL REFLECTOR - TRANSLUCENT 20X15"

OVAL REFLECTOR - SUNFIRE / WHITE 20X15"

DOT AND FINGER - SOLID BLACK 6"

DOT AND FINGER - DOUBLE SCRIM 6"

DOT AND FINGER - GOLD/SILVER 6"

DOT AND FINGER - SILK 6"

DOT AND FINGER - SINGLE SCRIM 6"

DOT AND FINGER - SUNLITE/WHITE 6"

OVAL REFLECTOR - SILVER / WHITE 20X15"

OVAL REFLECTOR - SILVER / GOLD 20X15"

OVAL REFLECTOR - GOLD / WHITE 20X15"

DOT AND FINGER - SOLID BLACK 10"

DOT AND FINGER - DOUBLE SCRIM 10"

DOT AND FINGER - GOLD/SILVER 10"

DOT AND FINGER - SILK 10"

DOT AND FINGER - SINGLE SCRIM 10"

DOT AND FINGER - SUNLITE/WHITE 10"

BAG FOR OVAL REFLECTOR 37X28"

OVAL REFLECTOR - TRANSLUCENT 37X28"

OVAL REFLECTOR - SUNFIRE / WHITE 37X28"

OVAL REFLECTOR - SILVER / WHITE 37X28"

OVAL REFLECTOR - SILVER / GOLD 37X28"

OVAL REFLECTOR - GOLD / WHITE 37X28"

DOT AND FINGER - SOLID BLACK 2X12"

DOT AND FINGER - DOUBLE SCRIM 2X12"

DOT AND FINGER - GOLD/SILVER 2X12"

DOT AND FINGER - SILK 2X12"

DOT AND FINGER - SINGLE SCRIM 2X12"

DOT AND FINGER - SUNLITE/WHITE 2X12"

BAG FOR OVAL REFLECTOR 48X35"

OVAL REFLECTOR - TRANSLUCENT 48X35"

OVAL REFLECTOR - SUNFIRE / WHITE 48X35"

OVAL REFLECTOR - SILVER / WHITE 48X35"

OVAL REFLECTOR - SILVER / GOLD 48X35"

OVAL REFLECTOR - GOLD / WHITE 48X35"

DOT AND FINGER - SOLID BLACK 4X14"

DOT AND FINGER - DOUBLE SCRIM 4X14"

DOT AND FINGER - GOLD/SILVER 4X14"

DOT AND FINGER - SILK 4X14"

DOT AND FINGER - SINGLE SCRIM 4X14"

DOT AND FINGER - SUNLITE/WHITE 4X14"

SCRIM AND FLAG - OPEN FRAME ONLY 12X18"

SCRIM AND FLAG - SOLID BLACK FLAG 12X18"

SCRIM AND FLAG - CHINA SILK 12X18"

SCRIM AND FLAG - DOUBLE SCRIM 12X18"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 12X18"

SCRIM AND FLAG - SILK SCRIM 12X18"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 12X18"

SCRIM AND FLAG - SINGLE SCRIM 12X18"

SCRIM AND FLAG - SINGLE SCRIM WHITE 12X18"

SCRIM AND FLAG - TRIPLE SCRIM 12X18"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 12X18"

SCRIM AND FLAG - CLOSED FRAME ONLY 12X18"

COLLAPSIBLE SCRIM AND FLAG - FRAME ONLY 12X18"

COLLAPSIBLE SCRIM AND FLAG - SOLID BLACK 12X18"

COLLAPSIBLE SCRIM AND FLAG - DOUBLE SCRIM 12X18"

COLLAPSIBLE SCRIM AND FLAG - SILK 12X18"

COLLAPSIBLE SCRIM AND FLAG - KIT WITH BAG 12X18"

COLLAPSIBLE SCRIM AND FLAG - SINGLE SCRIM 12X18"

OVAL REFLECTOR - TRANSLUCENT 73X48"

OVAL REFLECTOR - SUNFIRE / WHITE 73X48"

OVAL REFLECTOR - SILVER / WHITE 73X48"

OVAL REFLECTOR - SILVER / GOLD 73X48"

OVAL REFLECTOR - GOLD / WHITE 73X48"

SCRIM AND FLAG - OPEN FRAME ONLY 18X24"

SCRIM AND FLAG - SOLID BLACK FLAG 18X24"

SCRIM AND FLAG - CHINA SILK 18X24"

SCRIM AND FLAG - DOUBLE SCRIM 18X24"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 18X24"

SCRIM AND FLAG - SILK SCRIM 18X24"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 18X24"

SCRIM AND FLAG - SINGLE SCRIM 18X24"

SCRIM AND FLAG - SINGLE SCRIM WHITE 18X24"

SCRIM AND FLAG - TRIPLE SCRIM 18X24"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 18X24"

SCRIM AND FLAG - CLOSED FRAME ONLY 18X24"

COLLAPSIBLE SCRIM AND FLAG - FRAME ONLY 18X24"

COLLAPSIBLE SCRIM AND FLAG - SOLID BLACK 18X24"

COLLAPSIBLE SCRIM AND FLAG - DOUBLE SCRIM 18X24"

COLLAPSIBLE SCRIM AND FLAG - SILK 18X24"

COLLAPSIBLE SCRIM AND FLAG - KIT WITH BAG 18X24"

COLLAPSIBLE SCRIM AND FLAG - SINGLE SCRIM 18X24"

SCRIM AND FLAG - OPEN FRAME ONLY 24X30"

SCRIM AND FLAG - SOLID BLACK FLAG 24X30"

Description

SCRIM AND FLAG - CHINA SILK 24X30"

SCRIM AND FLAG - DOUBLE SCRIM 24X30"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 24X30"

SCRIM AND FLAG - SILK SCRIM 24X30"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 24X30"

SCRIM AND FLAG - SINGLE SCRIM 24X30"

SCRIM AND FLAG - SINGLE SCRIM WHITE 24X30"

SCRIM AND FLAG - TRIPLE SCRIM 24X30"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 24X30"

SCRIM AND FLAG - CLOSED FRAME ONLY 24X30"

BAG FOR OVAL REFLECTOR 73X48"

SCRIM AND FLAG - OPEN FRAME ONLY 24X36"

SCRIM AND FLAG - SOLID BLACK FLAG 24X36"

SCRIM AND FLAG - CHINA SILK 24X36"

SCRIM AND FLAG - DOUBLE SCRIM 24X36"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 24X36"

SCRIM AND FLAG - SILK SCRIM 24X36"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 24X36"

SCRIM AND FLAG - SINGLE SCRIM 24X36"

SCRIM AND FLAG - SINGLE SCRIM WHITE 24X36"

SCRIM AND FLAG - TRIPLE SCRIM 24X36"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 24X36"

SCRIM AND FLAG - CLOSED FRAME ONLY 24X36"

COLLAPSIBLE SCRIM AND FLAG - FRAME ONLY 24X36"

COLLAPSIBLE SCRIM AND FLAG - SOLID BLACK 24X36"

COLLAPSIBLE SCRIM AND FLAG - DOUBLE SCRIM 24X36"

COLLAPSIBLE SCRIM AND FLAG - SILK 24X36"

COLLAPSIBLE SCRIM AND FLAG - KIT WITH BAG 24X36"

COLLAPSIBLE SCRIM AND FLAG - SINGLE SCRIM 24X36"

SCRIM AND FLAG - OPEN FRAME ONLY 30X36"

SCRIM AND FLAG - SOLID BLACK FLAG 30X36"

SCRIM AND FLAG - CHINA SILK 30X36"

SCRIM AND FLAG - DOUBLE SCRIM 30X36"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 30X36"

SCRIM AND FLAG - SILK SCRIM 30X36"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 30X36"

SCRIM AND FLAG - SINGLE SCRIM 30X36"

SCRIM AND FLAG - SINGLE SCRIM WHITE 30X36"

SCRIM AND FLAG - TRIPLE SCRIM 30X36"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 30X36"

SCRIM AND FLAG - CLOSED FRAME ONLY 30X36"

SCRIM AND FLAG - CHINA SILK 48X48"

SCRIM AND FLAG - DOUBLE SCRIM 48X48"

SCRIM AND FLAG - DOUBLE SCRIM WHITE 48X48"

SCRIM AND FLAG - SILK SCRIM 48X48"

SCRIM AND FLAG - 1/4 STOP SILK SCRIM 48X48"

SCRIM AND FLAG - SINGLE SCRIM 48X48"

SCRIM AND FLAG - SINGLE SCRIM WHITE 48X48"

SCRIM AND FLAG - TRIPLE SCRIM 48X48"

SCRIM AND FLAG - TRIPLE SCRIM WHITE 48X48"

BLACK METAL FLAG

MOUNTING STIRRUP FOR 40" REFLECTOR BOARD

BLACK PLASTIC FLAG

BUTTERFLY TEXTILE - BLACK DOUBLE NET 4X4"

BUTTERFLY TEXTILE - BLACK COMMANDO 4X4"

BUTTERFLY TEXTILE - BLACK SINGLE NET 4X4"

BUTTERFLY TEXTILE - CHINA SILK 4X4"

BUTTERFLY TEXTILE - CROMAKEY BLUE 4X4"

BUTTERFLY TEXTILE - CROMAKEY GREEN 4X4"

BUTTERFLY TEXTILE - GRIFOLYN WHITE 4X4"

BUTTERFLY TEXTILE - SILK (ARTIFICIAL) 4X4"

BUTTERFLY TEXTILE - SILK 1/4 STOP 4X4"

BUTTERFLY TEXTILE - MUSLIN BLEACHED 4X4"

BUTTERFLY TEXTILE - MUSLIN UNBLEACHED 4X4"

BUTTERFLY TEXTILE - SOFT DIFFUSER (GRID) 4X4"

BUTTERFLY TEXTILE - SOFT DIFFUSER LIGHT (LIGHT GRID) 4X4"

BUTTERFLY TEXTILE - SUNFIRE SILVER 4X4"

BUTTERFLY TEXTILE - SILVER / WHITE 4X4"

BUTTERFLY TEXTILE - WHITE BLOCK 4X4"

BUTTERFLY TEXTILE - WHITE DOUBLE NET 4X4"

BUTTERFLY TEXTILE - WHITE / GOLD 4X4"

BUTTERFLY TEXTILE - WHITE SINGLE NET 4X4"

BUTTERFLY TEXTILE - BLACK DOUBLE NET 6X6"

BUTTERFLY TEXTILE - BLACK COMMANDO 6X6"

BUTTERFLY TEXTILE - BLACK SINGLE NET 6X6"

BUTTERFLY TEXTILE - CHINA SILK 6X6"

BUTTERFLY TEXTILE - CROMAKEY BLUE 6X6"

BUTTERFLY TEXTILE - CROMAKEY GREEN 6X6"

BUTTERFLY TEXTILE - GRIFOLYN WHITE 6X6"

BUTTERFLY TEXTILE - SILK (ARTIFICIAL) 6X6"

BUTTERFLY TEXTILE - SILK 1/4 STOP 6X6"

BUTTERFLY TEXTILE - MUSLIN BLEACHED 6X6"

BUTTERFLY TEXTILE - MUSLIN UNBLEACHED 6X6"

BUTTERFLY TEXTILE - SOFT DIFFUSER (GRID) 6X6"

BUTTERFLY TEXTILE - SOFT DIFFUSER LIGHT (LIGHT GRID) 6X6"

ELASTIC HOOK SET

BUTTERFLY TEXTILE - SUNFIRE SILVER 6X6"

BUTTERFLY TEXTILE - SILVER / WHITE 6X6"

BUTTERFLY TEXTILE - WHITE BLOCK 6X6"

BUTTERFLY TEXTILE - WHITE DOUBLE NET 6X6"

BUTTERFLY TEXTILE - WHITE / GOLD 6X6"

BUTTERFLY TEXTILE - WHITE SINGLE NET 6X6"

BUTTERFLY TEXTILE - BLACK DOUBLE NET 8X8"

BUTTERFLY TEXTILE - BLACK COMMANDO 8X8"

BUTTERFLY TEXTILE - BLACK SINGLE NET 8X8"

Page Art N°

165

152

152

152

152

152

165

165

165

165

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

153

153

153

152

152

165

165

153

153

153

153

165

165

165

165

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

153

153

153

153

153

165

165

165

165

165

153

153

153

153

165

165

165

165

153

153

153

153

153

153

153

153

165

165

165

153

153

153

153

153

153

153

153

153

153

I905GW

I905K

I905K4

I905MB

I905MU

I905SD

I905SDL

I905SUS

I905SW

I905WB

I905WDN

I905WG

I905WSN

I910BDN

I910BL

I910BSN

I910CK

I910CKB

I910CKG

I910GW

I790TW

I800

I8030CB

I810

I905BDN

I905BL

I905BSN

I905CK

I905CKB

I905CKG

I780TW

I781

I790CK

I790D

I790DW

I790K

I790K4

I790S

I790SW

I790T

I910K

I910K4

I910MB

I910MU

I910SD

I910SDL

I910SET

I910SUS

I910SW

I910WB

I910WDN

I910WG

I910WSN

I915BDN

I915BL

I915BSN

I780

I780B

I780CK

I780D

I780DW

I780K

I780K4

I780S

I780SW

I780T

I750SW

I750T

I750TW

I751

I760

I760B

I760D

I760K

I760KIT

I760S

I700CK

I700D

I700DW

I700K

I700K4

I700S

I700SW

I700T

I700TW

I701

I7200BAG

I750

I750B

I750CK

I750D

I750DW

I750K

I750K4

I750S

Page

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

152

155

157

155

164

152

152

152

152

152

152

152

152

152

152

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

152

165

152

152

152

152

152

152

152

152

152

152

152

152

Art N°

I950WG

I950WSN

I999

MICC1

MICC2

MICC4

MT001

MT002

MT003

MT004

I950GBW

I950K

I950K4

I950MB

I950MU

I950SD

I950SDL

I950SUS

I950SW

I950WB

I930CKB

I930CKG

I930GW

I930K

I930K4

I930MB

I930MU

I930SD

I930SDL

I930SUS

I930SW

I930WB

I930WDN

I930WG

I930WSN

I950BL

I950BSN

I950CK

I950CKB

I950CKG

MT005

MT007

MT007P

MT008

MT008P

MT009

MT009P

MT011

MT011P

MT013

MT014

MT015

MT016

MT017

MT018

MT020

I920CK

I920CKB

I920CKG

I920GW

I920K

I920K4

I920MB

I920MU

I920SD

I920SDL

I920SUS

I920SW

I920WB

I920WDN

I920WG

I920WSN

I930BDN

I930BL

I930BSN

I930CK

I915CK

I915CKB

I915CKG

I915GB

I915K

I915K4

I915MB

I915MU

I915SD

I915SDL

I915SUS

I915SW

I915WB

I915WDN

I915WG

I915WSN

I920BDN

I920BL

I920BSN

Description

BUTTERFLY TEXTILE - CHINA SILK 8X8"

BUTTERFLY TEXTILE - CROMAKEY BLUE 8X8"

BUTTERFLY TEXTILE - CROMAKEY GREEN 8X8"

BUTTERFLY TEXTILE - GRIFOLYN BLACK 8X8"

BUTTERFLY TEXTILE - SILK (ARTIFICIAL) 8X8"

BUTTERFLY TEXTILE - SILK 1/4 STOP 8X8"

BUTTERFLY TEXTILE - MUSLIN BLEACHED 8X8"

BUTTERFLY TEXTILE - MUSLIN UNBLEACHED 8X8"

BUTTERFLY TEXTILE - SOFT DIFFUSER (GRID) 8X8"

BUTTERFLY TEXTILE - SOFT DIFFUSER LIGHT (LIGHT GRID) 8X8"

BUTTERFLY TEXTILE - SUNFIRE SILVER 8X8"

BUTTERFLY TEXTILE - SILVER / WHITE 8X8"

BUTTERFLY TEXTILE - WHITE BLOCK 8X8"

BUTTERFLY TEXTILE - WHITE DOUBLE NET 8X8"

BUTTERFLY TEXTILE - WHITE / GOLD 8X8"

BUTTERFLY TEXTILE - WHITE SINGLE NET 8X8"

BUTTERFLY TEXTILE - BLACK DOUBLE NET 12X12"

BUTTERFLY TEXTILE - BLACK COMMANDO 12X12"

BUTTERFLY TEXTILE - BLACK SINGLE NET 12X12"

BUTTERFLY TEXTILE - CHINA SILK 12X12"

BUTTERFLY TEXTILE - CROMAKEY BLUE 12X12"

BUTTERFLY TEXTILE - CROMAKEY GREEN 12X12"

BUTTERFLY TEXTILE - GRIFOLYN WHITE 12X12"

BUTTERFLY TEXTILE - SILK (ARTIFICIAL) 12X12"

BUTTERFLY TEXTILE - SILK 1/4 STOP 12X12"

BUTTERFLY TEXTILE - MUSLIN BLEACHED 12X12"

BUTTERFLY TEXTILE - MUSLIN UNBLEACHED 12X12"

BUTTERFLY TEXTILE - SOFT DIFFUSER (GRID) 12X12"

BUTTERFLY TEXTILE - SOFT DIFFUSER LIGHT (LIGHT GRID) 12X12"

BUTTERFLY TEXTILE - SUNFIRE SILVER 12X12"

BUTTERFLY TEXTILE - SILVER / WHITE 12X12"

BUTTERFLY TEXTILE - WHITE BLOCK 12X12"

BUTTERFLY TEXTILE - WHITE DOUBLE NET 12X12"

BUTTERFLY TEXTILE - WHITE / GOLD 12X12"

BUTTERFLY TEXTILE - WHITE SINGLE NET 12X12"

BUTTERFLY TEXTILE - BLACK DOUBLE NET 20X20"

BUTTERFLY TEXTILE - BLACK COMMANDO 20X20"

BUTTERFLY TEXTILE - BLACK SINGLE NET 20X20"

BUTTERFLY TEXTILE - CHINA SILK 20X20"

BUTTERFLY TEXTILE - CROMAKEY BLUE 20X20"

BUTTERFLY TEXTILE - CROMAKEY GREEN 20X20"

BUTTERFLY TEXTILE - GRIFOLYN WHITE 20X20"

BUTTERFLY TEXTILE - SILK (ARTIFICIAL) 20X20"

BUTTERFLY TEXTILE - SILK 1/4 STOP 20X20"

BUTTERFLY TEXTILE - MUSLIN BLEACHED 20X20"

BUTTERFLY TEXTILE - MUSLIN UNBLEACHED 20X20"

BUTTERFLY TEXTILE - SOFT DIFFUSER (GRID) 20X20"

BUTTERFLY TEXTILE - SOFT DIFFUSER LIGHT (LIGHT GRID) 20X20"

BUTTERFLY TEXTILE - SUNFIRE SILVER 20X20"

BUTTERFLY TEXTILE - SILVER / WHITE 20X20"

BUTTERFLY TEXTILE - WHITE BLOCK 20X20"

BUTTERFLY TEXTILE - WHITE DOUBLE NET 20X20"

BUTTERFLY TEXTILE - WHITE / GOLD 20X20"

BUTTERFLY TEXTILE - WHITE SINGLE NET 20X20"

TEXTILE ROLL - FABRIC ROLL 10M X 2M BLACK SOLID

TEXTILE ROLL - FABRIC ROLL 10M X 9.15 BLACK SINGLE NET

TEXTILE ROLL - FABRIC ROLL 10M X 1.36M CHINA SILK

TEXTILE ROLL - FABRIC ROLL 10M X 1.35M CROMAKEY BLUE

TEXTILE ROLL - FABRIC ROLL 10M X 1.35M CROMAKEY GREEN

TEXTILE ROLL - FABRIC ROLL 10M X 3.55M GRIFFOLYN BLACK

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M SILK

TEXTILE ROLL - FABRIC ROLL 10M X 2.95M 1/4 STOP SILK

TEXTILE ROLL - FABRIC ROLL 7M X 3M MUSLIN BLEACHED

TEXTILE ROLL - FABRIC ROLL 7M X 3M MUSLIN UNBLEACHED

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M SOFT DIFFUSER

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M SOFT DIFFUSER LIGHT

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M SUNFIRE / SILVER

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M SILVER / WHITE

TEXTILE ROLL - FABRIC ROLL 10M X 1.1M WHITE SOLID

TEXTILE ROLL - FABRIC ROLL 10M X 1.5M GOLD / WHITE

TEXTILE ROLL - FABRIC ROLL 10M X 9.15 WHITE SINGLE NET

SWATCH TEXTILE SAMPLES

MICROPHONE CLIP

MICROPHONE SPRING CLIP

UNIVERSAL SHOCK MOUNT MICROPHONE HOLDER

BASIC CLAMPS

VARIABLE ANGLE CLAMP

DOUBLE VARIABLE ANGLE CLAMP

“T” CLAMP

RIGHT ANGLE CLAMP

PANEL WITH HOLES

PANEL

PANEL WITH HOLES

PANEL

PANEL WITH HOLES

PANEL

PANEL WITH HOLES

PANEL

PANEL CLAMP

PARALLEL CLAMP

RUBBER TUBE FOOT

RUBBER TUBE COVER

TUBE END PLUG

TUBE CUTTER

TUBE CONNECTOR

Page Art N°

39

105

105

105

105

165

165

165

39

39

165

165

165

165

165

165

165

165

165

165

165

165

165

165

165

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

109

109

109

109

106

105

109

109

109

109

106

107

107

108

108

108

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

164

MT045

MT046

MT052

MT056

MT062

MT065

MT105

MT105B

MT110

MT110B

MT021

MT022

MT023

MT024

MT025

MT029

MT030

MT034

MT036

MT115

MT115B

MT120

MT120B

Description

FOOT ADAPTER

ADJUSTABLE FOOT

OUTDOOR SPIKE

WALL TO WALL ADAPTER

16MM SOCKET

90CURVED CLAMP

DISK FOOT

RUBBER SUCKER

LARGE FOOT ADAPTER

ARTICULATED JOINT 180

ARTICULATED JOINT 360

AUTOPOLE2® TO MULTITUBE ADAPTER

FIVE-WAY BASE CLAMP

BROCHURE HOLDER

DISC BASE

50CM LONG ALUMINIUM TUBE

BLACK 50CM LONG ALUMINIUM TUBE

100CM LONG ALUMINIUM TUBE

BLACK 100CM LONG ALUMINIUM TUBE

150CM LONG ALUMINIUM TUBE

BLACK 150CM LONG ALUMINIUM TUBE

200CM LONG ALUMINIUM TUBE

BLACK 200CM LONG ALUMINIUM TUBE

STAND ATTACHMENT

As after sale service Manfrotto can supply the spare parts of all products those are described in this catalogue.

You can find all the drawings in our web site www.manfrotto.com

Page

107

108

108

108

108

105

105

109

106

109

108

108

108

108

197

108

106

107

108

106

106

106

107

106

203

Lino Manfrotto + Co., S.p.A.

Via Sasso Rosso 19

I-36061 Bassano del Grappa (VI) Italia

Tel +39 0424 555 855

Fax +39 0424 808 999 www.manfrotto.com

Cover image by Roberto Bigano/Multistudio: Bugatti Coupè Atalante SC

"In the dark, lit by the butterfly textile, Atlante is a dazzling vision. Atlante is very difficult to light, so I had to use all my experience and Manfrotto and Avenger range of accessories to point out its shape. Among my photos, this is the one that most thoroughly represents the concept of lighting control".

Product photography: Roberto Bigano/Multistudio

Concept: Claim adv

© Gruppo Manfrotto 2006

Whilst every effort has been made to ensure that the information contained within this catalogue is correct, Gruppo Manfrotto srl accepts no liability for errors or omissions. Technical specifications and data are provided for guidance only. All rights are strictly reserved, Products shown in this catalogue are protected by international patents, while this publication (in whole or in part) without written consent from Gruppo Manfrotto srl is strictly forbidden and punishable by law. Because we constantly aim to improve our products, we reserve the right to amend or alter at any time and without prior notice the specifications of any item detailed in this publication.

ISSUE CODE LCAT06,G ISSUE NUMBER N°1 - 01/06

LIGHTING AND CINE

SUPPORT SOLUTIONS

2006/07

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
