NIGHT NOISE AUTHORIZATION Application Form

NIGHT NOISE AUTHORIZATION Application Form
Phone: (415) 554-5810
Fax: (415) 554-6161
www.sfgov.org/dpw
City and County of San Francisco
Department of Public Works
Bureau of Street-Use and Mapping
rd
1155 Market Street, 3 Floor
San Francisco, CA 94103
NIGHT NOISE AUTHORIZATION Application Form
Allow (5) five business work day for review. You must first obtain approval of your excavation or
temporary occupancy permit prior to scheduling of dates and time for night noise work.
5206 or ___TOC-______
13
Provide the SF/DPW Excavation Permit: ___EXC-_____
06/12/14
Date of Application: _______________
Permit Fee to be billed by SF/DPW $113.11
Location of Event (Street Name): 3rd Street & 16th Street Intersection
Between:
Or At Intersection:
N
__________ Street
.
List the Street Name, Size of the excavation
Plans and Drawings required w/
__________ Street
Reason for night work:
Submission of Application
Traffic Restriction
Other:
DPT Restriction: _________________________ SPT/Night Noise denying Waive
Start Date: 06/18/14
00 AM/PM to Complete Date: 06/19/14
at 8
__:___
5 00 AM/PM
at _:___
Note: Night Authorization in public right of way starts at 8:00 pm and ends at 7:00 am
SF/DPW BSM USE ___________________
FEE:_________
Rev/ 5e.1.31
Phone: (415) 554-5810
Fax: (415) 554-6161
www.sfgov.org/dpw
City and County of San Francisco
Department of Public Works
Bureau of Street-Use and Mapping
rd
1155 Market Street, 3 Floor
San Francisco, CA 94103
NIGHT NOISE AUTHORIZATION Application Form
Weekend Work: Saturday Yes/No
Sunday Yes/No
One Week Look-head Schedule: (Place and [X] in the time slot of work activity in date/time below)
Date
Time
Monday
Tuesday
Wednesday
Thursday
8:00 PM
X
X
9:00 PM
X
X
10:00 PM
X
X
11:00 PM
X
X
X
Midnight
Tuesday
Wednesday
Friday
Saturday
Sunday
Saturday
Sunday
Monday
X
Thursday
Friday
1:00 AM
X
X
2:00 AM
X
X
3:00 AM
X
X
4:00 AM
X
X
5:00 AM
X
X
6:00 AM
7:00 AM
Public Notification:
150 radius -Notification Mailer
Yes ■ No
Provide the documentation of this mailer form along with the contact list and dates distributed to the Public.
Scope/Type of work:
Raising Castings, Manhole Cover
Cable or inner-duct placement
Cable removal (wrecking)
Manhole entry to rod existing conduit
General Excavation _______________
Excavation, pipe installation and backfill.
Other:__________________________
Type of equipment (list the model number with dba level):
Provide Manufacturer’s Sheet with dba range & model number:
69 dBA
AIR COMPRESSOR___________________
85 dBA
BACK HOE__________________
CHAIN SAW_______________________
COMPACTOR_______________________
AIR COMPRESSOR___________
CONCRETE TRUCK_________________
CONCRETE MIXER__________________
CONCRETE PUMP___________
CONCRETE VIBRATOR______________
CRANE, DERRICK___________________
CRANE, MOBILE_____________
DOZER___________________________
DRILL RIG_________________________
101 dBA
EXCAVATOR________________
GENERATOR______________________
GRADALL_________________________
GRADER___________________
HOE RAM_________________________
SF/DPW BSM USE ___________________
FEE:_________
Rev/ 5e.1.31
Phone: (415) 554-5810
Fax: (415) 554-6161
www.sfgov.org/dpw
City and County of San Francisco
Department of Public Works
Bureau of Street-Use and Mapping
rd
1155 Market Street, 3 Floor
San Francisco, CA 94103
NIGHT NOISE AUTHORIZATION Application Form
IMPACT WRENCH__________________
110 dBA
JACK HAMMER_____________
LOADER__________________________
PAVER___________________________
PILE DRIVER_______________
HYDRAULIC PUMP_________________
ROCK DRILL______________________
ROLLER___________________
SCRAPER________________________
SLURRY MACHINE_________________
0 dBA
ARROW BOARD_____________
HOGG-DAVIS REEL TRAILER_________
PORTABLE GENERATOR____________
VEHICLE MOUNTED GENERATOR
WINCH TRUCK_____________________
________________________________
Overall Noise Level Range:
X
Skidsteer - 104 dBA
___________________________
Very Low
Low
X
Light Tower - 72 dBA
_________________________________
Medium
High
Chris Wallace
Applicant Representative Name:_________________________________________________
M Squared Construction
Name of Company: ___________________________________________________________
San Francisco
CA Zip:_____________
94122
1278 20th Ave, Suite C
Address:______________________________City__________State____
Chris Wallace
415.745.0229
Contact Person: ___________________Phone:______________
Pager:_________________
415-706-7559
Carlos
Grande
City Representative (if other than BSM): ___________________24/7 Phone:______________
415-725-1861
Mark Gallagher
Work in Progress 24/7 On-site Contact:__________PCS/Cell:________Pager:_____________
COMMENTS: No high level noise or impact noise to be made after 10PM.
N/A
Note: payment method will be done prior to night noise authorization approval. Once the submitted no refund is available. Allow
(5) five business work day for review. In the event your permitted work location is listed in the Department of Parking and Traffic’s
Blue Book, restricting work hours during the day, you may opt to obtain a Special Traffic Permit prior to applying for night noise
permit. If the Special Traffic Permit is denied by DPT, you will bring back the signed off STP/Night Noise Referral form to DPW
continue your processing of the Night Noise Application.
Digitally signed by Chris Wallace
DN: cn=Chris Wallace, o=M Squared Construction, ou,
[email protected], c=US
Date: 2014.06.12 12:49:08 -07'00'
Chris Wallace
Signature of Applicant___________________
SF/DPW BSM USE ___________________
6/12/14
Date_________________
FEE:_________
Rev/ 5e.1.31
Cat 420E Backhoe Loader
Page 1 of 4
United States / Canada [change] Find A Dealer Contact
Search
HOME
PRODUCTS
APPLICATIONS
PARTS & SERVICE
RENTAL
NEWS & EVENTS
ABOUT THE COMPANY
English
Products › Current Machine Line › Backhoe Loaders › 420E/420E IT
Current Machine Line
» Articulated Trucks
» Backhoe Loaders
› 416E
› 420E/420E IT
› 430E/430E IT
› 450E
» Cold Planers
» Compact Track and Multi
Terrain Loaders
» Compactors
» Feller Bunchers
» Forest Machines
» Forwarders
» Harvesters
» Hydraulic Excavators
» Lift Trucks
» Industrial Loaders
» Knuckleboom Loaders
» Material Handlers
» Motor Graders
» Off-Highway Trucks
» Paving Equipment
» Pipelayers
» Road Reclaimers
» Skid Steer Loaders
» Skidders
» Telehandlers
» Track Loaders
» Track-Type Tractors
» Tunnel Boring Machines
» Underground Mining
» Wheel Dozers
» Wheel Excavators
» Wheel Loaders
» Wheel Tractor-Scrapers
--- Select a Model ---
420E/420E IT
BACKHOE LOADER
OverviewSpecificaBenefits Standard Work Machine
Optional Tool Compari
&
Features Equip. Attachm
Configure a backhoe to meet your
needs and get a price from your
local dealer.
» Configure Your Machine
SPECIFICATIONS
Units: US | Metric
Engine
Net Power - SAE J1349
Engine Model (Standard)
93 hp
Cat® C4.4 ACERT® DIT
Net Power - ISO 9249
94 hp
Gross Power - SAE J1995
101 hp
Gross Power - ISO 14396
101 hp
Net Power - EEC 80/1269
94 hp
Bore
Discussion Forums
Join our community to interact with
construction and landscape
professionals.
» Go to Web Site
4.13 in
Stroke
5 in
Displacement
268 in3
Net Peak Power @ 1,800 rpm - ISO 9249
97 hp
Net Peak Power @ 1,800 rpm - SAE J1349
95 hp
Net Peak Power @ 1,800 rpm - EEC 80/1269
97 hp
Net Torque Rise @ 1400 rpm - Standard
36 %
Net Peak Torque @ 1400 rpm - Standard - SAE J1349
301 lb ft
420E/420E IT Backhoe Loader
» Download Product Brochure
RELATED LINKS
» Find a Used Backhoe Loader
Backhoe
Non-Current Machine Line
Dig Depth - Standard
Work Tool Attachments
E-Stick Retracted
14.44 ft
14.3 ft
Allied
E-Stick Extended
17.9 ft
Engines
Reach from Swing Pivot - Standard
18.43 ft
On-Highway Trucks
E-Stick Retracted
18.56 ft
Industrial/OEM Power
Systems
E-Stick Extended
Used Equipment
Bucket Rotation
Power Generation
Bucket Dig Force - Standard
13875 lb
Turbines
E-Stick Retracted
13863 lb
OEM Solutions
E-Stick Extended
13863 lb
Technology
Stick Dig Force - Standard
21.87 ft
205 Degrees
9662 lb
Gifts & Apparel
http://www.cat.com/cda/layout?m=308396&x=7
11/2/2011
Cat 420E Backhoe Loader
Page 2 of 4
9616 lb
E-Stick Retracted
E-Stick Extended
7023 lb
Stick Lift @ 2440 mm (8 ft) - Standard
5722 lb
E-Stick Retracted
5298 lb
E-Stick Extended
3564 lb
Loading Height - Standard
11.93 ft
E-Stick Retracted
11.74 ft
E-Stick Extended
13.6 ft
Loading Reach - Standard
5.8 ft
E-Stick Retracted
6.12 ft
E-Stick Extended
9.09 ft
Weights
Operating Weight - Maximum
24251 lb
Operating Weight - Nominal
15201 lb
Cab, ROPS/FOPS
573 lb
Auto-Shift Transmission
60 lb
Ride Control
55 lb
Four Wheel Drive
342 lb
Loader, IT w/QC
805 lb
Extendible Stick (no weights)
659 lb
Air Conditioning
86 lb
Counterweights (Option 1)
255 lb
Counterweights (Option 2)
510 lb
Counterweights (Option 3)
1075 lb
Loader
Bucket Capacity - General Purpose
1.25 yd3
Bucket Width - General Purpose
7.42 ft
Dump Height @ Max Angle - Single Tilt
8.44 ft
Dump Height @ Max Angle - IT with QC
8.23 ft
Dump Reach @ Max Angle - Single Tilt
2.8 ft
Dig Depth - Single Tilt
4 in
Lift Capacity @ Full Height - Single Tilt
Dump Reach @ Max Angle - IT with QC
Bucket Breakout Force - Single Tilt
Dig Depth - IT with QC
6457 lb
2.73 ft
10242 lb
6 in
Bucket Breakout Force - IT with QC
Lift Capacity @ Full Height - IT with QC
10593 lb
6975 lb
Hydraulic System
Circuit Type
Closed center, load sensing
Pump Capacity (@ 2200 rpm)
43 gal/min
System Pressure - Backhoe
3611 psi
System Pressure - Loader
3307 psi
Pump Type
http://www.cat.com/cda/layout?m=308396&x=7
Variable-flow, axial piston
11/2/2011
Cat 420E Backhoe Loader
Page 3 of 4
Front wheel
Steering Type
Power Steering
Hydrostatic, HMU
2WD Cylinder - Bore
2.6 in
Stroke
4.7 in
Rod Diameter
1.4 in
4WD Cylinder - Bore
2.6 in
Stroke
4.7 in
Rod Diameter
1.4 in
Brake System
Inboard, oil-immersed, multiple disc
Power Train
Power-Shuttle, Forward 1st
3.7 mph
Forward 2nd
5.9 mph
Forward 3rd
12 mph
Forward 4th
25 mph
Power-Shuttle, Reverse 1st
3.7 mph
Reverse 2nd
5.9 mph
Reverse 3rd
12 mph
Reverse 4th
25 mph
Auto-Shift (opt), Forward 1st
3.7 mph
Forward 2nd
5.9 mph
Forward 3rd
12 mph
Forward 4th
17 mph
Forward 5th
25 mph
Auto-Shift (opt), Reverse 1st
3.7 mph
Reverse 2nd
7.8 mph
Reverse 3rd
17 mph
Operating Specifications - Backhoe
Turning Circle: outside, front wheels
Turning Circle: outside, widest loading bucket
26.8 ft
36 ft
Axle Ratings
Front Axle, 2WD, Static
50582 lb
Dynamic
20233 lb
Front Axle, 4WD, Static
50582 lb
Dynamic
20233 lb
Rear Axle, Static
50582 lb
Dynamic
20233 lb
Service Refills
Cooling System
5.4 gal
Fuel Tank
45 gal
Engine Oil w/Filter
2 gal
Transmission-Torque Converter, 2WD, Power Shuttle
4.9 gal
Transmission-Torque Converter, 4WD, Power Shuttle
http://www.cat.com/cda/layout?m=308396&x=7
11/2/2011
Cat 420E Backhoe Loader
Page 4 of 4
4.9 gal
Rear Axle
4.4 gal
Rear Axle, Planetaries
0.4 gal
Front Axle, 4WD
2.9 gal
Front Axle, Planetaries
0.2 gal
Hydraulic System
25.1 gal
Hydraulic Tank
10 gal
Transmission-Torque Converter, 4WD, Auto Shift 5 gal
Standards
Brakes
SAE J/ISO 3450, ISO 3450 1996
Cab - ROPS
SAE J1040 May 1994/ISO 3741 1994
Cab - FOPS SAE J/ISO 3449 APR98 LEVEL II and ISO
3449: 1992 LEVEL II
Cab - Sound
ANSI/SAE J1166 Oct 98 is 79 dB (A)
Exterior Sound
SAE J88 JUN86 is 76 dB (A)
Engine Ratings
Tires
© 2011 Caterpillar All Rights Reserved
Mobile
http://www.cat.com/cda/layout?m=308396&x=7
Facebook
Legal Notices
Twitter
Site Map
Print Version
YouTube
Contact
Newsfeeds
11/2/2011
ECLIPSE®
AB 2220
STANDARD FEATURES
• Battery compartment provides space for
up to four 8D batteries accessible from the
front of the trailer
• Lockable, 12-gauge steel hinged cover
provides a flat deck surface
• 50 watt solar panel is standard and faces
upward in both operation and transport to
continuously collect energy and charge the
batteries
• Removable drawbar provides a tighter
turning radius and includes an adjustable
height, two inch ball and three inch pintle
hitch to adapt to a variety of towing vehicles
• Ultra-high efficiency LED lamps with
1-watt power consumption offer long-lasting, cost-effective performance
• Full coverage, three-year warranty on
arrowboard; five-year warranty on LED
lamps; twenty-year warranty on solar panels
(warranty does not extend to tires, running
lights, or batteries)
Brighter. Warmer. Safer.
Reliability, performance, and integrity since 1938
ECLIPSE®
AB 2220
SPECIFICATIONS
Trailer
10-gauge all-steel construction
4-side outriggers with screw jacks on drawbar
Double wall rotational molded polyethylene fenders
Straight, removable drawbar
Adjustable height, reversible combination 2 in. (50 mm) ball, 3 in. (75 mm) pintle hitch
Safety chains
Stop / turn / tail lights
Highly-visible safety orange
Solar Panel
50-watt class array (100-watt optional) with 20-year warranty
LED Lamps
PAR 46 size with 5-year warranty
Arrow Sign
15-lamp ALT or 25-lamp APF configurations available
Aluminum construction
Black alumiklad coating
360° lamp visors
Mode indicator lamps on back panel
Red low-voltage warning indicator
Electronic Controller
Allmand solid-state
3-year warranty
Weather-resistant controller mounted within sign panel
Display controls located on controller face panel
Lockable, hinged cover
Low-voltage indicator
Photocell located on bottom of sign to automatically control lamp intensity relative to ambient conditions
Batteries
1-8D, 12-volt, commercial deep-cycle battery (two, three, or four batteries optional)
Sign Lift
Single manual brake winch and pulley system provides equal force to both sides of swing arm
Dimensions
Options
Arrow panel: 48 in. x 96 in. (1.22m x 2.44m)
Jack stand: 69.5 in. x 56.6 in. (1.77m x 1.44m)
Overall length: 110 in. (2.79m)
Frame length: 101 in. (2.56m)
Overall width: 96 in. (2.44m)
Trailer width including fenders: 68 in. (1.73m)
Overall height raised: 135 in. (3.43m)
Overall height lowered: 95 in. (2.41m)
13 in. tires and wheels
Height to bottom of sign when raised: 85 in. (2.16m)
Screw jacks at four corners
Built-in 120 VAC 55A charger | power supply
100-watt solar array
Additional 8D batteries (up to three)
7-pole tail light connector
Hinged rear compartment door
Allmand Bros., Inc.
1502 West 4th Avenue
Holdrege, Nebraska 68949
P: (800) 562-1373
F: (308) 995-5887
www.allmand.com
Your Allmand Distributor:
REV D
Loader/Backhoe
580 Super L
ENGINE
HYDRAULIC SYSTEM
STEERING
Model.............................. Case 4T-390
Type .............. 4-stroke, turbocharged
Cylinders .......................................... 4
Fuel injection ........................... Direct
Bore/Stroke.................... 4.02" x 4.72"
Displacement .......................... 239 in3
Horsepower
Gross........................ 91 @ 2200 rpm
Net ........................... 86 @ 2200 rpm
Maximum torque
Gross.............. 259 lb·ft @ 1400 rpm
Net ................. 252 lb·ft @ 1400 rpm
Front mounted, positive displacement,
gear-type tandem. Heavy-duty oil cooler.
Hydrostatic power steering with
on-demand priority flow from the main
hydraulic pump. 2500 psi operating
pressure. One, double-acting steering
cylinder with a stop-to-stop turning
ratio of 2.75 turns.
DRIVELINE
Fully synchronized 4-speed forward
reverse shuttle transmission with
hydraulically actuated clutches and
clutch disconnect buttons on the transmission shifter and loader control
lever. Electronically activated
forward/reverse shuttle shift and 4WD
engagement with optional mechanical
front wheel drive. 4WD activation onthe-go. Maintenance-free,
self-adjusting, inboard mounted, wet
disc brakes are hydraulically
actuated.
TRAVEL SPEEDS (MPH)
1st
2nd
3rd
4th
Forward ...... 3.7 ...... 6.7 ..... 12.9 .... 25.8
Reverse....... 4.5 ...... 8.1 ..... 15.5 .... 31.1
NOTE: Engine at 2350 rpm and 19.5L x 24 rear
tires.Travel speeds will decrease with
OPERATOR ENVIRONMENT
Optional ROPS canopy or 2-door
pressurized cab with heater and
defroster – A/C optional. Optional
deluxe cab interior. Optional nonsuspension or deluxe suspension seats.
Hand and foot throttles. Key start.
Beverage holders. Storage box.
GAUGES AND WARNING LIGHTS
Converter oil temperature – Engine
coolant temperature – Fuel – Rear axle
oil temperature – Tachometer/hourmeter – Voltmeter – Alternator – Engine
oil
pressure – Hydraulic system filter –
LOADER HYDRAULIC PUMP CAPACITY
27.5 gpm @ 2200 rpm @ 3000 psi
31.4 gpm @ 2350 rpm @ 100 psi
LOADER CONTROL VALVE
2 or 3-spool sectional valve with single
lever control for lift, tilt and auxiliary
hydraulics. Positive hold “float” and
“return-to-dig”.
BACKHOE HYDRAULIC PUMP CAPACITY
37 gpm @ 2200 rpm @ 3000 psi
42 gpm @ 2350 rpm @ 100 psi
BACKHOE CONTROL VALVE
6 or 7-spool, sectional, open-center,
parallel circuits with regeneration for
boom, dipperstick, bucket, swing, two
stabilizers and Extendahoe dipperstick. Load-sensing priority swing
system.
CONTROL VALVE MAIN RELIEF PRESSURE
3000 + 100 - 0 psi
FILTRATION
7-micron, full flow replaceable car-
SERVICE CAPACITIES
Fuel tank ............................... 31.4 gal
Hydraulic reservoir............... 13.9 gal
Total hydraulic system ...... 33.0 gal
Transmission
2WD Total system................ 19.5 qt
2WD refill w/o filter ............. 16.9 qt
4WD Total system................ 22.0 qt
4WD refill w/o filter ............. 19.5 qt
4WD Front axle
Differential............................. 5.8 qt
Planetaries (each) .................. 1.6 qt
Rear axle
Differential........................... 15.0 qt
Planetaries (each) ................ 0.74 qt
Engine oil w/filter ................... 11.6 qt
Cooling system
w/heater................................ 17.4 qt
w/o heater............................. 16.7 qt
ELECTRICAL SYSTEM
Voltage ...... 12 Volts, negative ground
Alternator ............... 12 Volts, 65 amp
Battery .................. Maintenance-free
685 cold-cranking amps
@ -0° F
580 Super L Page 1 of 4
TIRE SIZE
Front
2WD ........................ 11L x 16, 10PR
4WD ......................... 12 x 16.5, 8PR
Rear ........................ 17.5L x 24, 10PR
19.5L x 24, 10PR
CURB CLEARANCE CIRCLE
2 WD w/17.5L rear tires
w/o brakes................................ 24'6"
w/brakes .................................. 21'2"
2 WD w/19.5L rear tires
w/o brakes................................ 24'8"
w/brakes .................................. 21'3"
4 WD w/17.5L rear tires axle disengaged
w/o brakes................................ 24'4"
w/brakes .................................. 22'0"
4 WD w/17.5L rear tires axle engaged
w/o brakes................................ 27'6"
w/brakes .................................. 22'6"
4 WD w/19.5L rear tires axle disengaged
w/o brakes................................ 25'3"
w/brakes .................................. 22'0"
4 WD w/19.5L rear tires axle
engaged
w/o brakes................................ 28'2"
OPERATING WEIGHT
Base Unit: 2WD, loader, 82" standard
loader bucket, backhoe, standard
dipperstick, 24" heavy-duty trenching
bucket, ROPS canopy, 11L x 16 front
tires, 17.5L x 24 rear tires, and
full fuel tank ......................... 13,283 lb
Add:
Cab with A/C.......................... +477 lb
4WD........................................ +286 lb
4-in-1 Bucket.......................... +598 lb
Extendahoe ............................ +496 lb
Extendahoe counterweight ... +440 lb
LOADER
LOADER DIMENSIONS
Single-lever control for lift and tilt with
positive hold float and return-to-dig.
Automatic self-leveling throughout the
lift cycle. In-line, reverse linkage with
dual parallel dump cylinders. Optional
front-end auxiliary hydraulics with
combined single-lever control for lift,
tilt and auxiliary. Clutch disconnect
button on the loader control disengages
the transmission for fast loading
cycles. Optional General Purpose or 4in-1 buckets available. Both buckets
are 82" wide with
1.0 yd3 capacity and feature bolt-on
cutting edge.
GENERAL PURPOSE
4-IN-1®
Overall operating height .................................................. 14'0"......................... 14'3"
Bucket rollback @ groundline ............................................. 40° ........................... 40°
Dump angle @ full height.................................................... 45° ........................... 45°
Digging depth below grade –
Bucket flat ...................................................................... 5.9" .......................... 6.8"
Clam open (dozing).......................................................... NA .......................... 4.4"
Dump clearance @ full height, 45° dump –
Bucket ........................................................................... 8'10" ........................ 8.11"
Clam open ........................................................................ NA........................... 9'8"
Dump reach @ full height, 45° dump –
Bucket ........................................................................... 27.7" ........................ 25.5"
Clam open ........................................................................ NA ........................ 11.9"
Reach from front axle centerline,
bucket on ground .......................................................... 75.2" ........................ 72.7"
Lift capacity to full height........................................... 6,182 lb.................... 5,514 lb
Height to bucket hinge pin raised ................................... 11'2"......................... 11'2"
Breakout force (dump cylinders) ............................... 9,667 lbf ................ 10,294 lbf
Breakout force (lift cylinders) .................................... 9,453 lbf .................. 8,859 lbf
Bucket cutting edge width .................................................. 82" ........................... 82"
Maximum grading angle................................................... 116° ......................... 116°
Maximum clam opening...................................................... NA ........................ 38.3"
Moldboard height ................................................................ NA ........................ 36.8"
Raising time to full height .......................................... 5.34 sec.................... 5.34 sec
Bucket dumping time .................................................. 1.06 sec.................... 1.06 sec
Lowering time, power down ........................................ 2.44 sec.................... 2.44 sec
Lowering time, return-to-dig....................................... 3.17 sec.................... 3.17 sec
LOADER BUCKET SIZES AND WEIGHTS
General Purpose Bucket
Width
82"
Weight
Struck
Heaped
864 lb
0.88 yd3
1.01 yd3
4-in-1 Bucket
Width
Weight
Struck
Heaped
BACKHOE
Over-center backhoe reduces transport
length and increases bucket clearance
with a higher angle of departure.
Open-center hydraulics at 37 gpm for
responsive, precision control. Variable
flow priority swing circuit provides a
constant, smooth swing speed for outstanding multi-function control.
194,200 lb·in swing torque to swing
heavy loads uphill or push dirt when
backfilling. 11" maximum width for
excellent visibility. Two or three lever
control pattern. Foot swing with three
lever pattern. Optional Extendahoe®
and variable-flow auxiliary hydraulics.
BACKHOE BUCKET SIZES AND WEIGHTS
Heavy-Duty Universal Trenching Bucket
Width
Weight
Heaped
12" ................... 311 lb........... 2.90 ft3
16" ................... 346 lb........... 3.60 ft3
18" ................... 359 lb........... 4.30 ft3
24" ................... 429 lb........... 6.40 ft3
30" ................... 496 lb........... 8.65 ft3
36" ................... 571 lb........... 10.8 ft3
Heavy-Duty High-Capacity Trenching
Bucket
Width
Weight
Heaped
24" ................... 430 lb........... 8.50 ft3
30" ................... 447 lb........... 10.6 ft3
NOTE: Specifications taken with 4WD and 19.5L x 24 rear tires.
BACKHOE LIFT CAPACITIES
HEIGHT ABOVE & BELOW
GROUND LEVEL
STANDARD BACKHOE
EXTENDAHOE®
RETRACTED
EXTENDED
BOOM LIFT
+16'................................................................................................................. 1290 lb
+14' ..................................... 2395 lb ................................. 1994 lb ............... 1603 lb
+12' ..................................... 2830 lb ................................. 2369 lb ............... 1733 lb
+10' ..................................... 2899 lb ................................. 2551 lb ............... 1812 lb
+8' ....................................... 2864 lb ................................. 2560 lb ............... 1842 lb
+6' ....................................... 2830 lb ................................. 2543 lb ............... 1847 lb
+4' ....................................... 2777 lb ................................. 2516 lb ............... 1847 lb
+2' ....................................... 2708 lb ................................. 2482 lb ............... 1847 lb
Ground Level...................... 2699 lb ................................. 2421 lb .............. 1842 lb
-2' ........................................ 2612 lb ................................. 2377 lb .............. 1803 lb
-4' ........................................ 2534 lb ................................. 2295 lb .............. 1786 lb
-6' ........................................ 2525 lb ................................. 2299 lb .............. 1786 lb
-8' ........................................ 2534 lb ................................. 2303 lb .............. 1794 lb
-10' ...................................... 2743 lb ................................. 2412 lb .............. 1847 lb
-12' ..................................................................................................................2007 lb
-14' ..................................................................................................................2408 lb
DIPPER LIFT
+14' ................................................................................................. .............. 2734 lb
+12' ..................................... 5092 lb ................................. 4509 lb .............. 2834 lb
+10' ..................................... 4800 lb ................................. 4339 lb .............. 2847 lb
+8' ....................................... 4826 lb ................................. 4313 lb .............. 3025 lb
+6' ....................................... 5444 lb ................................. 4831 lb .............. 3060 lb
+4' ....................................... 6758 lb ................................. 5744 lb .............. 3199 lb
+2'....................................................................................................................3539 lb
NOTE: Stated figures apply straight to the rear of prime mover. Equipped with 24" general purpose
trenching bucket and links. For heavy-duty universal bucket and coupler, deduct 150 lb.
580 Super L Page 2 of 4
BACKHOE OPERATIONAL DATA
EXTENDAHOE®
STANDARD BACKHOE
RETRACTED
EXTENDED
Digging depth
24" flat bottom ............................................................... 14'3" ....................................................... 14'8" ................................ 18'2"
Maximum....................................................................... 14'5" ..................................................... 14'10" ................................ 18'3"
Overall reach from
Rear axle centerline ...................................................... 21'8" ....................................................... 22'0" ................................ 25'5"
Swing pivot .................................................................... 18'1" ....................................................... 18'5" .............................. 21'10"
Loading height .................................................................. 11'2" ....................................................... 11'5" ................................ 13'3"
Loading reach ..................................................................... 8'9" ......................................................... 8'8" ................................ 11'6"
Swing arc ........................................................................... 180°........................................................ 180° ................................. 180°
Bucket rotation
#1 position ...................................................................... 180°........................................................ 180° ................................. 180°
#2 position ...................................................................... 160°........................................................ 160° ................................. 160°
Stabilizer spread
Operating position........................................................... 9'5" ......................................................... 9'5" .................................. 9'5"
Transport position ........................................................... 7'2" ......................................................... 7'2" .................................. 7'2"
Digging force
Bucket cylinder ..................................................... 13,126 lbf ............................................... 13,126 lbf ........................ 13,126 lbf
Dipper cylinder........................................................ 8,224 lbf ................................................. 7,784 lbf .......................... 5,635 lbf
Leveling angle
(maximum slope that backhoe
will make vertical cut ...................................................... 12°.......................................................... 12° ................................... 12°
DIMENSIONS
EXTENDAHOE®
STANDARD BACKHOE
RETRACTED
EXTENDED
Overall length – transport
General purpose bucket ................................................ 22'7" ....................................................... 22'7" .................................. NA
4-in-1 bucket .................................................................. 22'5" ....................................................... 22'6" ................................... NA
Overall height, maximum ................................................ 19'2" ....................................................... 19'6" .............................. 22'10"
Transport height ............................................................ 10'10" ....................................................... 11'3" ................................... NA
Overall width — transport................................................. 7'2" ......................................................... 7'2" .................................. 7'2"
Angle of departure............................................................... 20°.......................................................... 20° ................................... 20°
Height –
To top of canopy ............................................................... 8'9" ......................................................... 8'9" ................................... NA
To top of cab ................................................................... 8'10" ....................................................... 8'10" ................................... NA
To top of exhaust stack.................................................... 8'6" ......................................................... 8'6" ................................... NA
Ground clearance at
backhoe frame .................................................................. 15" .......................................................... 15" ................................... NA
Front wheel tread –
2WD ............................................................................... 67.5" ....................................................... 67.5" ................................... NA
4WD ............................................................................... 67.7" ....................................................... 67.7" ................................... NA
Rear wheel tread .............................................................. 61.2" ....................................................... 61.2" ................................... NA
Wheelbase –
2WD .................................................................................. 84" .......................................................... 84" ................................... NA
4WD ............................................................................... 84.5" ....................................................... 84.5" ................................... NA
NOTE: Specifications taken with 11L x 16 front tires (except that data marked 4WD is taken with 12 x 16.5 front tires), 19.5L x 24 rear tires, Cab, 14' backhoe
with
24" heavy-duty trenching bucket, loader with 82" general purpose bucket and standard equipment unless otherwise specified.
580 Super L Page 3 of 4
CASE CORPORATION
700 STATE STREET
RACINE, WI 53404 U.S.A.
CASE CANADA CORPORATION
3350 SOUTH SERVICE ROAD
BURLINGTON, ON L7N 3M6 CANADA
CASE is a Registered Trademark of CASE CORPORATION
© 1995 CASE CORPORATION
Printed in U.S.A.
580 Super L Page 4 of 4
IMPORTANT: Case Corporation reserves the
right to change these specifications without
notice and without incurring any obligation
relating to such change.
TIER II CERTIFIED
580 Super M
Series 2 Loader/Backhoe
ENGINE
POWERTRAIN
HYDRAULICS
Model .............. Case 445T/M2 diesel
Type............... 4-stroke, turbocharged
Cylinders ............................................ 4
Bore/Stroke.................... 4.09” x 5.19”
(104 x 132 mm)
Displacement ............... 272 in3 (4.5 L)
Fuel injection............................. Direct
Fuel............................................. Diesel
Fuel filter ...................... w/water trap
Air intake .......................... Cross-flow
Cooling...................................... Liquid
Engine speeds* (rpm)
Rated speed, full load ............. 2200
Low idle............................. 800 - 900
High idle, no load ........ 2380 - 2480
Horsepower
Gross......... 95 (71 kW) @ 2200 rpm
Net ............ 90 (67 kW) @ 2200 rpm
Maximum torque @ 1500 rpm
Gross..................... 294 lb·ft (398 N·m)
Net ........................ 289 lb·ft (392 N·m)
Torque rise at rated speed .......... 29%
Transmission .......................... 4-speed
synchromesh with hydraulically
actuated clutches and electric F/R
shuttle control, clutch disconnect
buttons on the transmission shifter
and loader control lever
Gear ratios
Forward
Reverse
1st...................... 5.491 ............. 4.550
2nd .................... 3.043 ............. 2.522
3rd..................... 1.584 ............. 1.313
4th ..................... 0.793 ............. 0.657
Torque converter
Ratio ........................................... 2.63
Differential lock................. On-the-go
push-button activation
Front 4WD axle
Differential ratio ......................... 2.0
Planetary hub ratio .................... 6.0
Total reduction ratio ................ 12.0
Rear axle
Differential ratio ..................... 2.333
Planetary hub ratio ................ 6.923
Total reduction ratio ............ 16.153
Service brakes.. Individually applied,
hydraulically actuated,
maintenance-free, self-adjusting,
inboard mounted, wet disc
Disc area ................... 53 in2 (.03 m2)
Parking brakes ............. Mechanically
applied with electric activation
sensors at each brake
Travel speeds – mph (km/h)
1st 2nd 3rd
4th
Forward...... 3.5 ..... 6.7.... 13.5..... 25.5
(5.7) (10.8) (21.7) (41.0)
Reverse ....... 4.3 ..... 8.1.... 16.3 .... 30.8
(6.9) (13.0) (26.2) (49.6)
Pump ................... Gear-type tandem,
transmission driven
Main relief pressure
3050 + 50 - 50 psi @ 38 gpm
(210 + 3 - 3 bar @ 144 L/min)
Filtration .............................. 7-micron,
full flow replaceable
cartridge on return line,
condition indicator light for filter
Oil cooler ........................ Heavy-duty
Loader flow @ rated engine rpm
28.5 gpm @ 3050 psi
(108L/min @ 210 bar)
Loader control valve ...... Monoblock
single lever control for
lift, tilt and auxiliary hydraulics,
positive hold float and
return-to-dig
Loader auxiliary hydraulics
with full loader flow available
14 to 28.5 gpm
(53 to 108 L/min)
Backhoe flow @ rated engine rpm
38 gpm @ 3050 psi
(144 L/min @ 210 bar)
Manual Backhoe Controls
Backhoe Control Valve... Monoblock
open-center, parallel circuits.
Boom and dipper, with pilot operated
checks
Pilot Backhoe Controls
Backhoe Control Valve....... Sectional
closed-center with inlet
compensator and
circuits in parallel.
Backhoe auxiliary hydraulics ...........
Uni-directional flow, adjustable
variable flow from 0 to 36 gpm
(136L/min)
Control operation
Manual... Foot switch activated
Pilot ........Button on left joystick
NOTE: *Engine speeds with standard transmission. Meets federal emission regulations.
ENGINE COOLING
Radiator
Core type ................... Square wave
Core size area....... 487 in2 (.315 m2)
Rows of tubes ................................ 5
Fan
Style ........................ 7 blade suction
Diameter ................ 19.6” (500 mm)
Ratio .......................................... 1.1:1
Water pump
Style ..................................... Integral
Engine oil
Pump....... Deep sump plate cooler
with pressurized
under-piston nozzles
Pump operating angle ratings
Side-to-side ...................... Rated 35°
Fore and aft...................... Rated 35°
Oil filtration ................ Replaceable,
full-flow cartridge
TIRES
Front
2WD – 11L x 16.1, 10-ply rating
4WD – 12 x 16.5, 8-ply rating
Rear
2/4WD – 17.5L x 24, 10-ply rating
2/4WD – 19.5L x 24, 10-ply rating
NOTE: Travel speeds at 2324 engine rpm with
19.5 x 24 tires.
ELECTRICAL
Voltage .... 12 volts, negative ground
Alternator ............................... 90 amp
Battery........ 850 cold-cranking amps
Optional batteries ................... (2) 600
cold-cranking amps
Power plugs.............. (2) 30 amps ea.
Page 1 of 6
Bi-Directional flow, variable flow from
0 to 38 gpm
(144 L/min) @ rated engine rpm
Control operation
Manual .................... Hand lever
Pilot ......Buttons on left joystick
OPERATOR ENVIRONMENT OPERATING WEIGHTS
LOADER
ROPS/FOPS canopy
Key start
Hydrostatic steering
Non-suspension seat w/180° swivel
Hand and foot throttles
Loader control lever w/push-button
activation of differential lock and
transmission de-clutch
Backhoe foot-swing w/3 lever
control
(2) Accessory power plugs (30 amp)
Anti-vandalism covers (canopy only)
Cup holder
Coat hook w/tether strap (cab only)
Interior rearview mirror
2” (51 mm) retractable seat belt
Storage compartment w/lid
Left side storage tray
Single-lever control for lift and tilt
Positive hold float
Return-to-dig
Automatic self-leveling
In-line, reverse linkage
Dual parallel dump cylinders
Clutch disconnect button on loader
control and shift levers
Bucket position indicator
INSTRUMENTATION
Gauges
Engine water temperature
Converter oil temperature
Fuel
Tachometer/hourmeter
Voltmeter
Warning lights
Air cleaner restriction
Alternator
A/C low/high pressure
Cold start
Engine oil pressure
Hydraulic oil filter bypass
Parking brake
Rear axle fluid temperature
sensing system
Low fuel
Audible alarms
Coolant temperature
Engine oil pressure
Parking brake engagement
Shuttle engagement/seat position
Backup alarm
Turn signal indicators
Horn - dual switched front & rear
TURNING DIAMETER
2WD
Brakes on................... 21’3” (6.48 m)
Brakes off................... 24’8” (7.52 m)
4WD – engaged
Brakes on................... 22’1” (6.72 m)
Brakes off................... 28’3” (8.62 m)
4WD – disengaged
Brakes on................... 22’0” (6.70 m)
Brakes off................... 25’3” (7.70 m)
NOTE: Turning diameter dimensions curb to
curb w/general purpose bucket.
Lightest Configuration
Unit equipped with 2WD, ROPS
canopy, non-suspension seat,
82” (2.08 m) general purpose loader
bucket, 24” (610 mm) Universal
backhoe bucket, standard dipper,
17.5L x 24 rear tires, 11L x 16.1
front tires, single battery, standard
cast stabilizer pads,
no operator........... 14,285 lb (6480 kg)
Heavy Configuration
Unit equipped with 4WD, ROPS cab,
suspension seat, 82” (2.08 m)
4 IN 1® loader bucket, 24” (610 mm)
Universal backhoe bucket,
Extendahoe® dipperstick, 19.5L x 24
rear tires, dual batteries,
flip stabilizer pads,
no operator........... 17,545 lb (7958 kg)
Add-on weights
Cab (over canopy) ... +454 lb (206 kg)
Counterweights........ +440 lb (200 kg)
+900 lb (408 kg)
Extendahoe®............... +496 lb (225kg)
4WD w/driveshaft guard....... +283 lb
(128 kg)
SERVICE CAPACITIES
Fuel tank ..................... 31.4 gal (119 L)
Optional tank ............ 40 gal (151 L)
Hydraulic system
Total ......................... 31.5 gal (119 L)
Total w/Extendahoe® .......... 33.0 gal
(125 L)
Reservoir w/filter.. 14.5 gal (54.9 L)
Reservoir w/o filter ... 14.0 gal (53 L)
Transmission
2WD Total system .. 19.5 qt (18.5 L)
4WD Total system .. 22.0 qt (20.8 L)
4WD Front axle
Differential................... 5.8 qt (5.5 L)
Planetaries (each)...... 0.7 qt (0.66 L)
Rear axle
Differential............... 15.0 qt (14.2 L)
Planetaries (each)........ 1.6 qt (1.5 L)
Engine oil w/filter ...... 14.4 qt (13.6 L)
Cooling system
w/heater ................... 19.0 qt (18.0 L)
w/o heater................ 18.3 qt (17.3 L)
Window washer reservoir......... 2.5 qt
(2.36 L)
580 Super M – page 2 of 6
Loader Bucket Sizes
General Purpose Bucket
Width Weight Struck Heaped
82”
686 lb* 0.87 yd3 1.03 yd3
(2.08 m) (311 kg) (0.67 m3) (0.79 m3)
93”
933 lb* 1.07 yd3 1.25 yd3
(2.36 m) (423 kg) (0.82 m3) (0.96 m3)
4 IN 1® Bucket
82” 1,462 lb 0.85 yd3 1.04 yd3
(2.08 m) (663 kg) (0.65 m3) (0.80 m3)
NOTE: *Add 103 lb (47 kg) for bolt-on cutting
edge.
BACKHOE
Over-center design
Cast, ductile iron boom, and swing
tower
Open-center hydraulics - Pro Control
System
17, 940 lb·ft (24 370 N·m) swing torque
Case attachment coupler
Foot-swing w/3 lever control
Wing stabilizers w/cleated dirt pad
Backhoe Bucket Sizes
Universal Buckets
Width
Weight
Heaped
12”................ 290 lb .......... 3.40 ft3
(305 mm)
(132 kg)
(0.10 m3)
16”................ 346 lb .......... 3.60 ft3
(406 mm)
(157 kg)
(0.10 m3)
18”................ 350 lb .......... 5.30 ft3
(457 mm)
(159 kg)
(0.15 m3)
24”................ 413 lb .......... 7.70 ft3
(610 mm)
(187 kg)
(0.22 m3)
30”................ 475 lb ......... 10.20 ft3
(762 mm)
(215 kg)
(0.29 m3)
36”................ 535 lb ......... 12.70 ft3
(914 mm)
(243 kg)
(0.60 m3)
High Capacity Buckets
Width
Weight
Heaped
24”................ 450 lb .......... 8.50 ft3
(610 mm)
(204 kg)
(0.24 m3)
30”................ 517 lb ......... 10.60 ft3
(762 mm)
(235 kg)
(0.3 m3)
J
D
A
N
B
E
H
C
G
O
L
K
M
LOADER DIMENSIONS
A.
B.
C.
D.
E.
F.
G.
H.
J.
K.
L.
General Purpose Bucket* 4 IN 1® Bucket
Overall operating height – fully raised...................................................................... 13’11” (4.25 m) ............. 14’3” (4.34 m)
Height to –
Bucket hinge pin fully raised....................................................................................... 11’2” (3.4 m)................ 11’2” (3.4 m)
Bucket hinge pin @ SAE carry ................................................................................ 13.1” (334 mm) ........... 14.6” (372 mm)
Dump angle @ full height................................................................................................................. 45° ................................ 45°
Dump clearance @ full height, 45° dump –
Bucket............................................................................................................................ 8’10” (2.69 m).............. 8’11” (2.72 m)
Clam open....................................................................................................................................... NA ............... 9’8” (2.95 m)
Dump reach @ full height, 45° dump –
Bucket ......................................................................................................................... 30.0” (763 mm) ........... 27.8” (707 mm)
Clam open....................................................................................................................................... NA ........... 14.3” (362 mm)
Bucket rollback –
@ groundline ................................................................................................................................... 40° ................................ 40°
@ SAE carry..................................................................................................................................... 45° ................................ 45°
@ full height....................................................................................................................... Adjustable ................... Adjustable
Digging depth below grade –
Bucket flat..................................................................................................................... 5.9” (149 mm) ............. 6.8” (180 mm)
Clam open (dozing) ...................................................................................................................... NA ............. 4.1” (103 mm)
Reach from front axle centerline – bucket on ground ............................................... 77.6” (1.97 m).............. 75.2” (1.91 m)
Lift capacity to full height ....................................................................................... 6,182 lb (2804 kg) ....... 5,514 lb (2501 kg)
Breakout force –
Lift cylinders....................................................................................................... 9,164 lbf (40 760 N) .... 8,904 lbf (39 600 N)
Dump cylinders ................................................................................................. 9,480 lbf (42 170 N) .. 10,302 lbf (45 820 N)
Bucket cutting edge width........................................................................ 82” (2.08 m)/93” (2.36 m)................. 82” (2.08 m)
Maximum grading angle ................................................................................................................ 116°............................... 116°
Maximum clam opening.................................................................................................................. NA ........... 38.3” (972 mm)
Moldboard height ............................................................................................................................. NA ........... 36.8” (934 mm)
Raising time to full height .......................................................................................................... 3.4 sec........................... 3.4 sec
Bucket dumping time.................................................................................................................. 1.5 sec........................... 1.5 sec
Lowering time –
Power down .............................................................................................................................. 2.4 sec........................... 2.4 sec
Return-to-dig............................................................................................................................. 3.2 sec........................... 3.2 sec
Clam –
Open time ....................................................................................................................................... NA........................... 2.3 sec
Close time ....................................................................................................................................... NA........................... 3.1 sec
NOTE: Loader dimensions taken with 4WD,
19.5L x 24 rear tires and 82” (2.08 m) general
purpose bucket *without bolt-on cutting edge.
580 Super M – page 3 of 6
DIMENSIONS
Standard Backhoe
Extendahoe®
Retracted
Extended
M. Overall transport length –
General purpose bucket ......................................... 22’10” (6.95 m) ............ 22’10” (6.95 m) ................................. NA
4 IN 1® bucket............................................................ 22’8” (6.92 m) .............. 22’8” (6.92 m) ................................. NA
Overall transport width................................................. 7’2” (2.18 m) ................ 7’2” (2.18 m) ................................. NA
Height –
To top of canopy.......................................................... 8’9” (2.67 m) ................ 8’9” (2.67 m) ................. 8’9” (2.67 m)
To top of cab............................................................... 8’10” (2.69 m) .............. 8’10” (2.69 m) ............... 8’10” (2.69 m)
To top of exhaust stack............................................... 8’6” (2.59 m) ................ 8’6” (2.59 m)................ 8’6” (2.59 m)
Transport .................................................................. 10’10” (3.29 m) .............. 11’3” (3.42 m) ................................. NA
N.
Ground clearance at backhoe frame........................ 14.6” (371 mm)............ 14.6” (371 mm) ............ 14.6” (371 mm)
Angle of departure .......................................................................... 20° ................................. 20°.................................. 20°
Front wheel tread –
2WD............................................................................. 67.5” (1.71 m) .............. 67.5” (1.71 m) ............... 67.5” (1.71 m)
4WD............................................................................. 67.7” (1.72 m) .............. 67.7” (1.72 m) ............... 67.7” (1.72 m)
Width across tires
17.5L x 24 .................................................................... 81.7” (2.07 m) .............. 81.7” (2.07 m) ............... 81.7” (2.07 m)
19.5L x 24 .................................................................... 81.4” (2.67 m) .............. 81.4” (2.67 m) ............... 81.4” (2.67 m)
Wheelbase –
O.
2WD................................................................................ 84” (2.13 m) ................. 84” (2.13 m) .................. 84” (2.13 m)
4WD............................................................................. 84.5” (2.15 m) .............. 84.5” (2.15 m) ............... 84.5” (2.15 m)
NOTE: Dimensions taken with 19.5L x 24 rear tires and 11L x 16 front tires except that data marked 4WD is taken with 12 x 16.5 front tires.
CYLINDERS
Bore Diameter
Rod Diameter
Stroke
Loader
Lift (2) ...................................................................... 3.25” (82.6 mm)........... 1.75” (44.5 mm) ............ 30.2” (766 mm)
Bucket (2) ..................................................................... 3.0” (76 mm)............. 1.5” (38.1 mm) ............ 20.6” (522 mm)
4 IN 1® clam (2) ........................................................... 3.0” (76 mm)........... 1.75” (44.5 mm) .............. 9.1” (231 mm)
Backhoe
Boom...................................................................... 5.25” (133.4 mm) ............ 2.50” (63.5mm) ............ 33.2” (842 mm)
Dipperstick ................................................................ 5.0” (127 mm)................ 2.5” (63 mm) ............ 22.9” (583 mm)
Bucket ........................................................................... 3.5” (89 mm)................ 2.5” (63 mm) ............ 34.3” (872 mm)
Extendahoe® ................................................................ 3.0” (76 mm)........... 1.75” (44.5 mm) ............... 42.0” (1.07 m)
Swing (2) ................................................................. 4.0” (101.6 mm)............. 2.0” (50.8 mm)............. 11.5” (292 mm)
Stabilizer (2)............................................................. 4.25” (108 mm)............. 2.0” (50.8 mm) ............ 21.8” (553 mm)
Steering
2WD ......................................................................... 2.75” (69.9 mm)............. 1.5” (38.1 mm) .............. 6.7” (170 mm)
4WD ............................................................................ 2.48” (63 mm)............. 1.5” (38.1 mm) ............ 9.53” (242 mm)
580 Super M – page 4 of 6
BACKHOE LIFT CAPACITIES
Boom and Dipper Lift Capacities are rated per SAE J31 and are 87% of the maximum
hydraulic lift force available with the specified options.
Standard Backhoe
Extendahoe®
Retracted
Distance from
swing pivot (m)
Backhoe lift
capacity - lb (kg)
Distance from
swing pivot (m)
Backhoe lift
capacity - lb (kg)
Extended
Distance from
swing pivot (m)
Backhoe lift
capacity - lb (kg)
Boom Lift
+16’ (4.87 m) .......................................................................................................................... 12’5” (3.79) ...... 1,350 (612)
+14’ (4.27 m) .... 8’7” (2.62) .... 2,750 (1247) ............ 9’6” (2.89) .... 2,350 (1066) .......... 14’7” (4.45) ...... 1,775 (805)
+12’ (3.66 m) .. 11’2” (3.40) .... 3,050 (1383) ........ 11’10” (3.61) .... 2,575 (1168) .......... 16’2” (4.93) ...... 1,850 (839)
+10’ (3.05 m) .. 12’9” (3.89) .... 3,100 (1406) .......... 13’4” (4.06) .... 2,700 (1225) .......... 17’2” (5.23) ...... 1,875 (850)
+8’ (2.44 m) .. 13’11” (4.24) .... 3,050 (1383) ............14’5” (4.40) .... 2,650 (1202) .......... 18’0” (5.49) ...... 1,875 (850)
+6’ (1.83 m) .... 14’7” (4.45) .... 3,000 (1361) .......... 15’2” (4.62) .... 2,600 (1179) .......... 18’7” (5.67) ..... 1,875 (850)
+4’ (1.22 m) .... 15’0” (4.57) .... 2,900 (1315) .......... 15’6” (4.72) .... 2,575 (1168) ........ 18’10” (5.74) ..... 1,875 (850)
+2’ (0.61 m) .... 15’1” (4.60) .... 2,850 (1293) .......... 15’7” (4.75) .... 2,525 (1145).......... 18’11” (5.77) ..... 1,850 (839)
Ground Level .. 14’11” (4.55) .... 2,775 (1259) .......... 15’5” (4.70) .... 2,425 (1100) ........ 18’10” (5.74) ...... 1,850 (839)
-2’ (0.61 m)...... 14’5” (4.40) .... 2,675 (1213) .......... 15’0” (4.57) .... 2,400 (1088) .......... 18’5” (5.62)..... 1,800 (816)
-4’ (1.22 m)...... 13’7” (4.14) .... 2,600 (1179) .......... 14’2” (4.32) .... 2,300 (1043) .......... 17’9” (5.41) ...... 1,800 (816)
-6’ (1.83 m)...... 12’4” (3.76) .... 2,600 (1179) ........ 12’10” (3.91) .... 2,300 (1043) .......... 16’9” (5.11) ..... 1,800 (816)
-8’ (2.44 m)...... 10’5” (3.18) .... 2,600 (1179) .......... 11’2” (3.40) .... 2,300 (1043) .......... 15’7” (4.75) ...... 1,800 (816)
-10’ (3.05 m)...... 7’6” (2.28) .... 2,825 (1281) ............ 8’7” (2.62) .... 2,425 (1099) ........ 13’11” (4.24) ...... 1,850 (839)
-12’ (3.66 m)............................................................................................................................ 11’7” (3.53) ...... 2,025 (918)
-14’ (4.27 m)............................................................................................................................ 7’11” (2.41)..... 2,450 (1111)
Dipper Lift
+14’ (4.27 m) .......................................................................................................................... 13’4” (4.06) .... 2,580 (1170)
+12’ (3.66 m) .. 10’1” (3.08) .... 4,940 (2241) .......... 10’7” (3.23) .... 4,360 (1978) .......... 14’3” (4.35) .... 2,680 (1216)
+10’ (3.05 m) .. 10’7” (3.23) .... 4,650 (2109) .......... 11’2” (3.40) .... 4,190 (1901) .......... 14’6” (4.42) .... 2,700 (1225)
+8’ (2.44 m) .... 10’6” (3.20) .... 4,680 (2123) ........ 10’11” (3.33) .... 4,160 (1887) .......... 14’5” (4.40) .... 2,880 (1306)
+6’ (1.83 m) ...... 9’7” (2.92) .... 5,290 (2400) .......... 10’2” (3.10) .... 4,680 (2123) ........ 13’11” (4.24) .... 2,910 (1320)
+4’ (1.22 m) ...... 7’5” (2.25) .... 6,610 (2998) ............ 8’3” (2.58) .... 5,590 (2536) ........ 12’11” (3.94) .... 3,050 (1383)
BACKHOE OPERATIONAL DATA
Extendahoe®
Standard Backhoe
Retracted
Extended
Digging depth –
Maximum....................................... 14’5” (4.39 m) ............................. 14’10” (4.52 m) .......................... 18’3” (5.56 m)
Maximum w/hi-capacity bucket.. 14’10” (4.52 m) ................................... 15’3” (4.65 m).............................. 18’8” (5.69 m)
2’ (610 mm) flat bottom ............... 14’3” (4.34 m) ............................... 14’8” (4.47 m) .......................... 18’2” (5.54 m)
8’ (2.44 m) flat bottom ................. 13’4” (4.06 m) ............................... 13’9” (4.19 m) .......................... 17’6” (5.33 m)
Overall reach from –
Rear axle centerline...................... 21’5” (6.53 m) ............................... 22’0” (6.70 m) .......................... 25’5” (7.75 m)
Swing pivot ................................... 18’1” (5.51 m) ............................... 18’5” (5.61 m) ........................ 21’10” (6.65 m)
Loading height ................................. 11’2” (3.40 m)................................ 11’5” (3.48 m) .......................... 13’3” (4.04 m)
Loading reach – dipper retracted .... 8’9” (2.67 m) ................................. 8’8” (2.64 m)........................... 11’6” (3.50 m)
Swing arc............................................................ 180° ................................................ 180° ........................................... 180°
Bucket rotation –
#1 position...................................................... 164° ................................................ 164° ........................................... 164°
#2 position...................................................... 200° ................................................ 190° ........................................... 190°
Stabilizer spread – operating ........... 9’5” (2.87 m) ................................. 9’5” (2.87 m) ............................ 9’5” (2.87 m)
Digging force –
Bucket cylinder ................. 12,821 lbf (57 031 N) .................... 12,821 lbf (57 031 N)............... 12,821 lbf (57 031 N)
Dipper cylinder................... 8,224 lbf (36 582 N) ...................... 7,784 lbf (25 066 N)................. 5,635 lbf (25 066 N)
w/bucket @ 50°
w/bucket @ 50°
w/bucket @ 51°
Leveling angle
maximum slope that backhoe
will make vertical cut ..................................... 12° .................................................. 12° ............................................. 12°
NOTE: Lift capacities apply straight to the rear of prime mover. Equipped with 24” (610 mm) Universal H.D. trenching bucket and Case
coupler except as noted.
580 Super M – page 5 of 6
STANDARD EQUIPMENT
OPERATOR’S COMPARTMENT
See page 2
ENGINE
Case 445T/M2 turbocharged
diesel
Integral crank driven balancer
Automatic fan belt tensioner
Integral engine oil cooling
Fuel filter w/water trap
KKSB starter timing control
Dual element air cleaner
with integral pre-cleaner
90 amp alternator
850 CCA 12-volt battery
Heavy-duty radiator w/deaeration
bottle
Non-spark-arresting muffler
LOADER
See page 2
BACKHOE
See page 2
POWERTRAIN
2WD
4F/4R Power shuttle synchromesh
transmission
Torque converter
Transmission de-clutch
Electro-hydraulic differential lock
Hydrostatic steering
Wet disc brakes
Remote lube front axle pivot
HYDRAULICS
2-spool loader control valve
6-spool backhoe control valve
Heavy-duty oil cooler
OTHER
Forward tilt engine hood
Replaceable, molded front bumpers
Front/rear tie downs
Reflective logos
Lights - Cab and Canopy
2 Rear tail/stop
2 Front flashers/turn
2 Rear flashers/turn
4 Front & 4 rear adjustable
halogen lights (55 w)
Canopy Convenience Package
Front windshield w/wiper &
washer
85 dB(A) sound
Floor mat
Sun visor
LOADER
Hydraulic attachment coupler
Attachment auxiliary hydraulics
Buckets (see page 2)
BACKHOE
Case hydraulic coupler
Buckets (see page 2)
Extendahoe®
Two-lever control
Pilot Operated Control System
Fingertip Proportional
Electrohydraulic stabilizer controls.
Thumb operated Proportional
Electrohydraulic Extendahoe
control
Thumb operated horn button
Thumb operated Auxiliary
Hydraulic Control
Infinitely Adjustable Towers
In-Cab Switchable “Excavator to
Backhoe” control pattern change
Stabilizer pads
Flip-over
Rubber pad
Front counterweights
440 lb (200 kg)
900 lb (408 kg)
ENGINE
Cold weather grid heater starting aid
Dual, 12-volt, 600CCA batteries
Fuel tank, 40 gal (151 L)
Exhaust aspirated air cleaner
POWERTRAIN
4WD w/outboard planetary drive,
on-the-go push-button activation
and 12 x 16.5 front tires
Powershift transmission with
Autoshift (4WD unit only)
HYDRAULICS
Auxiliary backhoe uni-directional
hydraulics
Auxiliary backhoe bi-directional
hydraulics
Hand lever operated for manual
controls
Button operated for pilot controls
OTHER
17.5L x 24 rear tires
19.5L x 24 rear tires
Tool box
Special paint
OPTIONAL EQUIPMENT
OPERATOR’S COMPARTMENT
Cab with –
Heater
Defroster
Dome light - door activated
Wipers, front and rear
Tinted glass
Floor mat
Side window partial hold open
Inside release for side windows
Operator Convenience Package
Tilt wheel
Windshield washer w/adjustable nozzles (front & rear)
Sun visor
Deluxe Cab Package
Operator Convenience Package
PLUS
Vinyl-covered interior
Radio-ready kit w/antenna and
speakers
Reduced sound level to 72 dB(A)
Vinyl or cloth-covered mechanical
suspension seat
Air Ride suspension seat
3” (76 mm) retractable seat belt
Cab air-conditioning, 100% filtered
air, in-cab filter access, 8
adjustable roof vents, 2 floor
vents, w/heater
Ride Control
Cab, right door
NOTE: All specifications are stated in accordance with SAE Standards or Recommended
Practices, where applicable.
Form No. CCE9030306
Replaces Form No. CE 252-10-00
IMPORTANT: Case, LLC reserves the right to
change these specifications without notice and
without incurring any obligation relating to
such change. Case, LLC does not warrant the
safety or reliability of attachments from other
manufacturers.
Visit us on the Web at:
http://www.casece.com
Printed in U.S.A.
© 2003 CASE, LLC.
All Rights Reserved.
A Brand of CNH
Page 6 of 6
CASE CONSTRUCTION EQUIPMENT
CONTACT INFORMATION
NORTH AMERICA/MEXICO:
700 STATE STREET
RACINE, WISCONSIN 53404
LATIN AMERICA:
AV. GENERAL DAVID SARNOFF 2237
32210 – 900 CONTAGEM – MG
BELO HORIZONTE BRAZIL
EUROPE/AFRICA/MIDDLE EAST:
18, PLACE DES NYMPHEAS
ZI PARIS NORD 11 95915
ROISSY CDG CEDEX FRANCE
ASIA PACIFIC:
31-67 KURRAJONG ROAD
ST. MARY’S
NEW SOUTH WALES 2760
AUSTRALIA
216B, 226B
®
Skid Steer Loaders
Cat Diesel Engine
Net Power
Gross Power
Operating Weight
Rated Operating Capacity
®
* High Flow (HF) version
216B
3024C
37 kW/50 hp
39 kW/52 hp
2589 kg
635 kg
226B
3024C T
43 kW/57 hp
46 kW/62 hp
2646 kg
680 kg
226B*
3024C T
43 kW/57 hp
46 kW/62 hp
2677 kg
680 kg
Caterpillar® 216B and 226B Skid Steer Loaders
Two versatile compact machines designed, built and backed by Caterpillar to deliver
exceptional performance, ease of operation and simplified service.
World-class Operator Station
Operator comfort and ease of operation
are designed into the operator’s station
from every aspect. Ergonomic features
such as low-effort joystick controls,
comfortable padded armrest and an
adjustable contoured seat reduce
operator fatigue. Excellent visibility
to the work tools helps enhance
productivity. pg. 4-5
High Performance Power Train
✔ The Cat 3024C engine provides high
®
engine horsepower and torque.
Exclusive anti-stall feature maximizes
power to the drive train and work tools
without stalling the engine, allowing
part-throttle operation for lower sound
levels and lower fuel consumption.
pg. 6
Built for Versatility.
The Caterpillar 216B and 226B Skid Steer Loaders
are ideal for multiple applications including:
construction, landscaping and agriculture.
They deliver traditional Cat reliability and
durability with excellent productivity.
✔ New feature
2
Advanced Hydraulic System
✔ The hydraulic system in the Cat
Skid Steer Loaders is designed for
maximum power and reliability.
Increased hydraulic power enables
better overall performance.
Reduced componentary translates
to fewer hydraulic connections
thus reducing potential leak points.
High Flow hydraulics are optional
on the 226B. pg. 7
Quick Coupler and Cat Work Tools
✔ A universal work tool interface and
quick coupler make the Cat Skid Steer
Loader the most versatile machine
on the jobsite. The wide range of
Caterpillar work tools optimise
machine performance for maximum
utility and production. pg. 8-9
Serviceability
✔ Cat Skid Steer Loaders offer quick and
easy routine maintenance and service.
The rear door opens 90 degrees and
the cooling package raises to provide
industry leading access to the engine
compartment. The cab also tilts up for
easy access. pg. 10
Customer Support
Caterpillar Dealers offer unmatched
customer support, with excellent
warranty programs and fast parts
availability, resulting in maximum
uptime and minimum repair costs.
Equipment maintenance services help
optimize machine performance and
reliability. pg. 11
3
Operator Station
World-class operator station provides exceptional working comfort with
excellent visibility, enhanced fingertip control and optimum instrumentation.
Ergonomic Design. Cat Skid Steer Loaders
feature an updated ergonomic cab design
that makes operation easier and more
comfortable. A choice of contoured,
adjustable seats offer increased operator
comfort. Careful placement of machine
controls make them feel like a natural
extension of the operator hands. A new
contoured armbar gives excellent support of
arms and wrists for easier machine control.
The cab features a removable floor mat
which acts as a foot rest and offers excellent
sound and heat insulation. The foot throttle
control is an ergonomically-designed pedal
that allows operation at variable engine
speeds for optimum performance while
minimizing fuel consumption. A standard
hand throttle also allows operation at any set
engine speed.
Cab Features. The ergonomically designed
cab provides the operator with easy to use
pilot controls in a comfortable working
environment. The standard offerings of
the Cat Skid Steer Loaders operator station
include:
12 volt power socket
Removable, sliding side windows
Enclosed cabs feature an automatic lockout switch which prevents accidental
damage by disabling the loader functions
when the door is open.
Low-Effort Machine Controls.
Ergonomic pilot-operated hydraulic controls
give operators precision control of Cat Skid
Steer Loaders with minimal effort. The left
joystick controls forward and reverse travel
speed plus direction and the right joystick
controls loader up/down and tilt control.
Both joysticks use an intuitive “S” control
pattern. Joysticks provide additional
auxiliary controls, using positive-action
buttons to provide precision fingertip control
of many machine functions, including:
One-touch continuous auxiliary
hydraulic flow
Momentary auxiliary hydraulic flow
Multiple auxiliary functions
Horn
Proportional auxiliary hydraulic
functionality (optional)
4
High-efficiency Climate Controls.
Operating in extreme temperatures is now
more comfortable with the optional cab
air conditioner and heater installed.
The air conditioner offers 14 250 kj
cooling capacity and the heater output is
18 690 kj. Six adjustable vents provide
excellent air flow throughout the cab and
makes defrosting the optional front door
and side windows easier. (Air conditioning
available on the 226B only.)
Visibility. The Cat Skid Steer Loader has
a wide cab opening providing exceptional
view of the work tool enhancing ease of
operation and productivity. The sloped
angle of the engine compartment allows
excellent visibility to the rear of the
machine. A new convex rearview mirror
option gives the operator a panoramic view
of the rear and sides of the machine.
For better visibility in low-light conditions,
the standard forward lights are adjustable
10 degrees in any direction.
Instrumentation. Cat Skid Steer Loaders
use instrument panels and gauges that are
simple, easy-to-use and reliable. Bright
indicator lights and audible warning,
signals any critical system situation.
An engine air cleaner restriction indicator
is situated in the cab for easier reference.
Access/Egress. The Cat Skid Steer Loader
cab is designed to make machine operation
simple, productive and comfortable.
Getting into and out of the cab is secure
and easy through a wide opening with
three-point grab handles and skid-resistant
steps. Tilt cylinders are neatly located
under the lift arms so not to interfere with
operator access and egress.
The deluxe cab package includes items
in the standard cab, plus
Deluxe suspension seat
Headliner
Additional working lights
Cab Packages. Several cab packages
and options are available.
The standard cab includes:
ROPS/FOPS cab
Contoured cushion seat with fore/aft
adjustment
Retractable seat belt
Cushioned, contoured armbar
Dual throttle controls - hand and foot
Dome light
Horn
Rear wall liner
Windows, top and rear
Two overhead instrument panels
Pilot-hydraulic joystick and fingertip
auxiliary controls
12 Volt power socket
A cold-weather cab package includes
items in the standard cab, plus:
Removable, sliding side windows
High-efficiency heater/defrost
Engine coolant heater
Heavy-duty 880 CCA starting battery
Debris barrier
Other cab options include:
Cab door (either glass or
polycarbonate) with wiper/washer
and loader arm lock-out
Air conditioner with heater/defrost
FOPS, Level II
Insulated floor mat with foot rest
Cup holder
76 mm seat belt
Additional controls for
– hydraulic quick coupler
– proportional auxiliary hydraulics
– work tool electrical requirements
– high flow hydraulics
5
Power Train
Caterpillar Hystat power train delivers aggressive performance and easy operation.
Anti-Stall System. An exclusive antistall system on the Cat Skid Steer
Loaders allows maximum power to
the wheels while minimizing engine
stalling. This exclusive system helps
maximize productivity for experienced
operators and makes it easier for novice
operators to become productive.
Axial Piston Pumps. Dual, variabledisplacement axial piston pumps are
driven directly off the engine and
provide hydraulic flow to the drive
motors via a closed loop system.
Drive motors transfer mechanical power
to the wheels via two high-strength,
pre-stressed chains per machine side.
Chains run in an oil bath for constant
lubrication and long life. Chains are
adjustable through slots in the axle
housings.
Cat Diesel Power.
The heart of the Cat Skid Steer Loader
power train is the Caterpillar 3024C
diesel engine, which is turbocharged in
the 226B model. This rugged, reliable
four-cylinder Stage II compliant Cat
engine offers aggressive performance
and a fast torque curve for quick
response.
6
Throttle Control.
Dual engine throttle controls allow
the operator to match engine speed to
the task. The hand throttle is ideal for
jobs requiring consistent engine speed such as cold planing or trenching.
The foot throttle enables the operator
to vary engine speed and minimize fuel
consumption for other tasks such as
load and carry, truck loading, grading
and dozing.
Drive Axles. Drive axles are forged and
induction hardened for maximum life.
They include a unique labyrinth seal
which consist of lip and outer seal to
help prevent debris such as wire and
twine from wrapping around the axle
and destroying the seal. An inner seal
is used for permanent lubrication of
axle bearings - no daily axle service
is required.
Hydraulic System
Hydraulic system has built-in reliability and provides exceptional wheel torque plus lift,
breakout and auxiliary power to work tools.
High-Flow Hydraulics. Optional highflow hydraulics provide increased
hydraulic horse power for high-speed,
high-power work tools such as cold
planers, landscape rakes, stump grinders
and trenchers. This system can be
ordered on new Cat 226B machines
or can be installed later by your local
Cat Dealer.
Front Hydraulics. Standard ON/OFF
front hydraulics are featured on the
216B and 226B. Optional proportional
front auxiliary hydraulics are also
available on these models.
Power and Reliability. Maximum power
and reliability are built into the Cat
Skid Steer Loader hydraulic system.
In addition to providing power to drive
the wheels, this system also provides
the loader lift and tilt functions, powers
the auxiliary circuit to drive work tools
and drives the engine cooling fan.
Hydraulic Pumps. Hydraulic pumps
are driven directly off the engine for
maximum hydraulic performance and
reliability - no belts are used. Pumps are
open center, fixed-displacement and
provide flow to the loader and auxiliary
hydraulic circuits.
Control of the loader lift and tilt
functions by hydraulically-operated
pilot controls enable low-effort and
precise operation.
Auxiliary Hydraulics. Standard auxiliary
hydraulics to power work tools is
available through quick-connect
hydraulic couplings that are rigidly
mounted to the loader arm. Cat XT hose
and O-Ring Face Seals help ensure
a leak-free system.
Reliability and Cleanliness.
Reduced potential leak points improve
reliability and result in a cleaner
machine. In addition, hydraulic oil
flows through a 4-micron spin-on filter.
A filter restriction indicator is located at
the operator station. A 74-micron screen
in the hydraulic tank prevents larger
debris from entering the system and
causing damage to the hydraulic
components.
Hydraulic Oil Cooler.
A high-efficiency hydraulic oil cooler
enables the Cat Skid Steer Loader
to work longer and harder in higher
ambient temperatures, even when using
continuous high flow work tools.
The high-capacity hydraulic oil
reservoir maintains lower operating
temperatures.
7
Quick Coupler and Caterpillar Work Tools
Choose from a wide variety of tools that are performance matched to Cat Skid Steer Loaders.
Quick Coupler. Work tools can be
changed quickly and easily with the
Cat Skid Steer’s quick coupler system.
The universal coupler interface
features:
Low profile side plates are designed
for the optimum match to work tools
and minimal material packing
Opposing wedges ensure a tight
tool fit
Rugged design and large contact area
absorbs loads and minimizes stress
Tool engagement and release are
quick and easy
Vertical pins are chrome-plated and
lubricated for smooth engagement
and prevention of corrosion
Coupler allows excellent visibility
to work tools and unobstructed entry
and exit to the cab.
8
The standard quick coupler features
manual engagement and disengagement
of work tools using two high-leverage
handles. An optional hydraulic quick
coupler is also available and allows
engagement and disengagement
of work tools without the need for
the operator to exit the machine.
Control of the coupler by use of
a rocker switch inside the cab,
making work tool changes quicker
and easier.
Cat Work Tools. They extend the versatility
of the Cat Skid Steer Loaders. Designed and
built for optimum performance and durability,
these tools deliver high productivity,
long service life and excellent value:
Angle blades
Augers
Backhoes
Brooms
Buckets:
– general purpose
– grapple
– light material
– multi purpose
– utility
Cold planers
Compactor vibratory
Hammers
Landscape rakes
Landscape tillers
Material handling arm
Pallet forks
Stump grinders
Trenchers
Wheel Saws
Augers. Caterpillar Augers are designed
for drilling holes for footings, fencing,
signs, trees and shrubs in construction,
agricultural and landscaping
applications.
Backhoes. The compact Caterpillar
Backhoe transforms the Skid Steer
Loader into a dedicated excavator for
digging our trenches, hammer use or
general excavating tasks.
Brooms. Caterpillar Angle Brooms
are ideal work tools for removing rock,
dirt and other debris from streets,
carparks, driveways, pavements and
factory floors.
Buckets - multi purpose.
Caterpillar Multi Purpose Buckets are
designed to optimize the versatility of
Cat Skid Steer Loaders when digging,
dozing, clamping, scraping, back
dragging, grading and levelling in
a wide range of applications.
Cold planers. Caterpillar Cold Planers
are designed for milling tarmac, asphalt,
concrete surfaces, prior to repair and
reinstatement.
Grapple Forks. Caterpillar Industrial
Grapple Forks are designed to easily
handle a wide array of bulky, loose,
objects encountered in demolition,
industrial, construction and other
aggressive applications.
Trenchers. Caterpillar Trenchers
are designed for cutting narrow straight
trenches in soil prior to laying electrical,
telephone lines, cable lines, water or
gas pipes.
Wheel Saws. Caterpillar Wheelsaws are
used to cut trenches in tarmac, asphalt,
concrete and permafrost surfaces prior
to laying cable, electrical, gas and water
pipes. (226B High Flow only)
9
Serviceability
Quick access and superior design make the Cat Skid Steer Loaders easy to maintain.
Service Access. The rear service door opens
90 degrees for easy access to both sides of
the in-line mounted engine.
Filters. All filters are spin-on and easily
accessible, which makes routine service
quicker and virtually spill-free.
Cooling System. The radiator, hydraulic oil
cooler and grill tilt up to increase access to
the cooling system during maintenance and
allows easier cleaning of debris from between
the grill and cooling package. The cooling fan
is hydraulically driven for quieter operation
and to eliminate the service and maintenance
that comes with belt-driven fans.
Easy Tilting Cab. The machine cab can now
be tilted rearward by a single person using
a single tool, and is held in place by a selflatching mechanism. When the cab is tilted
back, all hydraulic pumps, motors, valves,
lines and the fuel tank are accessible for quick,
easier service.
Removable Belly Pan. A removable belly pan
section on the floor of the machine’s lower
frame provides excellent access for periodic
cleaning.
Electrical and Hydraulic Lines.
Clean routings of electrical and hydraulic lines
improves reliability and simplifies service.
Maintenance Points. They are grouped
in easily accessible locations.
S•O•SSM Valves. Scheduled Oil Sampling
S•O•S valves are standard to allow regular
monitoring of the engine and hydraulic oil
quality.
Other Standard Service Features
Easy access to battery, air filter and single
engine belt
Sight glass on hydraulic tank and radiator
allow quick, easy level checks
Air filter restriction indicators are located
inside the operator station and at the air filter
Ecology drains simplify changing engine
and hydraulic oils
Grease fittings are countersunk to prevent
damage
Extended life coolant and 250-hour engine
oil change intervals
10
Complete Customer Support
Cat dealer services help you operate longer with lower costs.
Machine Selection. With nine different
Cat Skid Steer Loader and four Cat Multi
Terrain Loader to choose from, selecting
the right machine is even easier when you
consult your Caterpillar dealer. Your
dealer helps you make detailed machine
comparisons before you purchase.
Purchase Options. Available to let you
look beyond just the initial machine price.
With your Cat dealer, you can review
available financing options plus look at
day-to-day operating costs. You can also
look at dealer services that can be included
in the cost of the machine to yield lower
equipment owning and operating costs
over the life of the machine.
Customer Support Agreements.
These agreements offer you a variety of
service and maintenance options that can
be customized to best fit your specific
requirements. These can cover the entire
machine and include work tools to help
protect your investment.
Machine Support. It is one of your Cat
dealer’s primary goals. You will find high
availability of parts at our Dealer parts
counter. Cat Dealers utilize a worldwide
computer network to find in-stock parts
to minimize machine downtime.
Your Cat dealer can also save you money
by suggesting Cat Remanufactured parts
that carry the same warranty as new,
but with savings of 40 to 70 percent.
Maintenance Service Plans.
Help manage machine maintenance,
by choosing from a wide range of
maintenance plans and services at the time
you purchase a machine. Repair option
plans guarantee the cost of repairs up front.
Diagnostics programs such as Scheduled
Oil Sampling, Coolant Sampling and
Technical Analysis help you avoid
downtime and unscheduled repairs.
Operator Training. Cat dealers can
improve your operator’s techniques and
help boost your profits.
Cat Machine Security System.
Secure your investment with Caterpillar’s
Machine Security System (MSS),
a programmable key system that provides
maximum machine security for Cat
Skid Steer Loader owners.
MSS disables machine by interacting
with the machine’s Electronic Control
Modules (ECM)
Keys fit all existing Cat machines
(including machines without MSS)
Each machine can store up to 50 key
identifications
Each key can be configured to
operate a certain range of machines
or enable operation for a certain
period of time
Repair, Rebuild or Replace.
Choices become even more evident
when you consult your Caterpillar
dealer. Your Cat dealer can help
evaluate the costs involved
so you can make the right choice
every time.
11
Engine 3024C
Hydraulic System
216B
Ratings at 2600 rpm
Net power
Gross power
Dimensions
Bore
Stroke
226B
kW/hp
kW/hp
37/50
39/52
43/57
46/62
84 mm
100 mm
84 mm
100 mm
Caterpillar 3024C (216B) and 3024C T turbocharged (226B),
water-cooled, four-stroke cycle, four-cylinder diesel
Net power rating per ISO 9249 or EEC 80/1269
Meets EU directive 97/68/EC Stage II emission
requirements
Hydraulic Flow
Loader
Hydraulic pressure (kPa)
Hydraulic Flow (l/min)
216B
Std
226B
Std
*226B
HF
21 400
60
23 000
60
23 000
100
Features
Single, hydraulically-operated joystick controls lift,
lower and tilt functions
Open center, fixed displacement
* High Flow (HF) version
Operating Specifications
Power Train and Brakes
The specification for the 216B and 226B Skid Steer Loaders
are with 10 x 16.5 6 PR tires, 1525 mm dirt bucket,
full fuel 65 kg and a 75 kg operator.
Dual, closed-loop, axial piston hydrostatic pumps driven
directly off engine. Pumps provide pressure and flow to two
fixed displacement motors.
Rated operating capacity**
Rated operating capacity with
optional counterweight**
Operating weight
Tipping load
Breakout force
lift cylinder
tilt cylinder
216B
226B
*226B
kg
kg
kg
635
680
680
680
2589
1270
726
2646
1360
726
2677
1360
1386
1717
1515
1852
1499
1852
* High Flow (HF) version
** ISO 5998:1986
Travel speed
Forward
Reverse
216B
226B
*226B
km/h
km/h
km/h
12.5
12.5
12.7
12.7
12.7
12.7
Features
Single hydraulically-operated joystick, controls speed
and direction
Hydrostatic service brakes
Multi-disc, spring-applied hydraulically released
parking brake
Anti-stall system maximizes torque to the wheels
without stalling engine
* High Flow (HF) version
ROPS/FOPS
Sound
Rollover Protective Structure (ROPS) and Falling Objects
Protective Structure (FOPS).
ROPS meets ISO 3471:1994
FOPS meets ISO 3449:1998 Level I
FOPS Level II (optional) meets ISO 3449:1998 Level II
Operator Sound
The operator sound level measured according to
the procedures specified in ISO 6396 is 89 dB(A).
12
Exterior Sound
The labeled spectator sound power level measured
according to the test procedures and conditions specified
in 2000/14/EC is 104 dB(A).
216B and 226B Skid Steer Loader specifications
Dimensions
Dimensions shown are based on standard machine equipped with optional 10 x 16.5 6 PR tires and 1525 mm dirt bucket.
The specification for the 216B and 226B Skid Steer Loaders are static and conform to ISO 5998:1986.
All dimensions are approximate.
19
13
17
8
5
15
6
18
4
9
14
11
12
16
7
10
1
3
2
mm
1
2
3
4
5
6
7
8
9
Wheelbase
Length with bucket on ground
Length without bucket
Height to top of cab
Max overall height
Hinge pin height at max lift
Hinge pin height at carry position
Reach at max lift and dump
Clearance at max lift and dump
986
3233
2519
1950
3709
2854
239
505
2169
mm
10
11
12
13
14
15
16
17
18
19
Ground clearance
Departure angle
Bumper overhang behind rear axle
Maximum dump angle
Maximum width over tires
Turning radius from center
left
right
full
Reach with level arms and bucket
Rack back angle at max height
195
26°
967
40°
1525
1485
1199
1940
1280
97°
Service Refill Capacities
Liters
Chain box, each side
Cooling system
Engine crankcase
Fuel tank
Hydraulic system
Hydraulic tank
6
10
8
65
55
35
216B and 226B Skid Steer Loader specifications
13
Standard Equipment
Standard equipment may vary. Consult your Caterpillar dealer for specifics.
Air cleaner, dual element, radial seal
Alternator
216B: 65-amp
226B: 85-amp
Armrest, pull down
Battery, 12-volt, 850 CCA
Brake, parking, SAHR
Cleanout, belly pan
Controls, pilot-operated, hydraulic
Coupler, mechanical, quick
Ecology drains: engine, hydraulic oil
and coolant
Electric Socket, 12-volt
Engine, diesel:
216B: Cat 3024C naturally-aspirated
226B: Cat 3024C T turbocharged
Falling Object Protective Structure, Level I
Fan, hydraulically-driven
Filter
fuel, bayonet-type
hydraulic, spin-on, 4 micron
Fuel/water separator, spin-on
Hydraulics, auxiliary, front, ON/OFF
Hydraulics, continuous flow
Instrumentation:
Audible:
– engine coolant temperature
– engine oil pressure
– hydraulic oil temperature
Gauges:
– fuel level
– hour meter, digital
Indicators:
– air filter restriction
– alternator output
– armrest raised/operator out of seat
– engine coolant temperature
– engine oil pressure
– hydraulic filter restriction
– hydraulic oil temperature
– parking brake engaged
Muffler
Precleaner, self-unloading
Pump, hydraulic implement
Pump, hystat charge and hydraulic fan
Rear view mirror, internal
Safety control interlock system
Scheduled Oil Sampling (S•O•S) valves
Seat, static
Seat belt, retractable, 50 mm
Sight gauge, coolant and hydraulic oil
Starting aid, glow plugs
Support, lift arm
Switch, ignition
Tail lights
Throttle controls, hand and foot
Tie-downs, front and rear
Valve, hydraulic, three-section
Windows, top and rear
Low Side Wall.
The Cat LSW offers exceptional
puncture resistance and run-flat
capability. Ideal for general
construction and heavy-duty
applications.
14
216B and 226B Skid Steer Loader specifications
Premium Conventional.
The Cat Premium Conventional
tyre are equipped with the industry’s
deepest tread depth, thickest
sidewall and heaviest rim guard.
Provides optimum performance in
a variety of applications.
Optional Equipment
Optional equipment may vary. Consult your Caterpillar dealer for specifics
Air conditioning with heater/defrost (226B only)
Alarm, back up
Battery, 12-volt, 880 CCA
Control, work tool, electrical
Counterweight, adds 45 kg to ROC
Coupler, hydraulic
Cup holder
Debris barrier for cab
Door, front
laminated glass with wiper/washer
polycarbonate with wiper/washer, for demolition use
Falling Object Protective Structure, Level II,
attaches to existing FOPS
Floor mat
Headliner
Heater/Defrost, cab
Heater, engine coolant
Horn
Hydraulics, auxiliary, front, proportional
Hydraulics, auxiliary, front, proportional,
High Flow (226B only)
Hydraulics, self leveling, lift
Lifting provisions:
– four-point, or
– single-point
Lights, front and rear, working
Light, warning beacon
Machine Security System (MSS)
Seat, suspension
Seat belt, 76 mm
for static seat
for suspension seat
Synthetic hydraulic oil for cold weather operation
Windows, side, sliding, removable
Tires:
7 x 15 6 PR 1372 mm (54 in) Caterpillar (216B only)
10 x 16.5 8 PR 1524 mm (60 in)
Caterpillar Premium Conventional*
265-521 8 PR 1524 mm (60 in) Caterpillar Low Side Wall*
10 x 16.5 6 PR 1524 mm (60 in) GY SGL
10 x 16.5 8 PR 1524 mm (60 in) GY IT323*
10 x 16.5 8 PR 1524 mm (60 in) GALAXY*
10 x 16.5 10 PR 1524 mm (60 in) MICHELIN
10 x 16.5 8 PR 1676 mm (66 in)
Caterpillar Premium Conventional*
265-521 8 PR 1676 mm (66 in) Caterpillar Low Side Wall*
10 x 16.5 6 PR 1676 mm (66 in) GY SGL
10 x 16.5 8 PR 1676 mm (66 in) GY IT323
10 x 16.5 8 PR 1676 mm (66 in) GALAXY
10 x 16.5 10 PR 1676 mm (66 in) MICHELIN
* Denotes spare tire option available with supplement.
Premium Conventional
Flotation.
The Cat Premium
Conventional Flotation
tyre is most efficient on
soft terrain.
Extreme Duty Solid.
The Cat Solid tyre performs on
the toughest applications.
Profitability is improved through
the elimination of downtime and
repair costs. Ideal for foundary
and demolition job-sites.
216B and 226B Skid Steer Loader specifications
15
216B and 226B Skid Steer Loaders
HEHL3004 (12/2003) hr
Materials and specifications are subject to change without notice.
Featured machines may include additional equipment.
See your Caterpillar dealer for available options.
www.CAT.com
© 2004 Caterpillar
®
306_110-260 CFM_Compressor.qxd
10/7/04
9:44 PM
Page 1
110 CFM to 260 CFM
Portable Air Compressors
Distributed By:
www.onesourcerental.com
Long-lasting Dependability
Platinum Warranty
The value of owning an Ingersoll-Rand portable air
compressor has been enhanced and redefined. The
Platinum Series means peace of mind for you
because each unit is powered by an Ingersoll-Rand
efficient, direct-injection diesel engine — giving
you a single source for warranties, parts, and service.
The Platinum Series Warranty is a premium warranty available only
on units powered by an Ingersoll-Rand engine. This warranty is available
when original Ingersoll-Rand fluids, filters, and parts are used at the
prescribed intervals.
• 5-year / 10,000-hour extended warranty on the powertrain, which includes the engine,
the coupling, and the airend. These units are identified with the Platinum Series logo.
• 2-year / 4,000-hour warranty on the starter, alternator, and fuel system.
• Fully transferable warranty to the next owner.
• Single source for all warranty parts and service.
• Fuel / water separator comes as a standard feature in the Platinum Series.
306_110-260 CFM_Compressor.qxd
10/7/04
9:44 PM
Page 2
110 CFM to 260 CFM Portable Air Compressors
Specifications
KEY FEATURES / BENEFITS
■ Heavy-duty independent rubber-torsion
suspension running gear for less shock
transferred to internal components with
high ground clearance and 15" wheels
(13" on P110 and P135)
■ Folding “A” frame drawbar with
safety chains and hooks provides
easy hook-up to vehicle, stability
while towing, and reduces needed
space for transportation
■ Enclosure constructed of 14-gauge
sheet metal with durable textured paint
and heavy-duty composite material end
panels for improved corrosion resistance
■ Large interior toolbox with capacity for
two breakers and hose
■ Shock-mounted engine and compressor
to absorb vibration and reduce noise
■ Rear access panel for cleaning heat
exchangers minimizes shutdowns due
to overheating
■ Removable resilient polyethylene
fenders for improved, longer-lasting
appearance
■ Engine-mounted pusher fan (cool box)
maintains cooler temperature inside
unit for longer life of all components
■ Lockable side doors with pneumatic lift
springs and no-rust aluminum hinges
provide excellent access for servicing
MODEL
P110WIR
P135WIR P185WIR XP185WIR P260WIR
ENGINE – TIER 2
Make
Model
Number of Cylinders
Displacement cu in (L)
Rated Speed rpm
Idle Speed rpm
BHP @ Rated Speed
Electrical
Ingersoll-Rand Ingersoll-Rand Ingersoll-Rand Ingersoll-Rand Ingersoll-Rand
4IRH8N
4IRH8N
4IRI8N
4IRI8T
4IRI8T
4
4
4
4
4
134 (2.2)
134 (2.2)
203 (3.3)
203 (3.3)
203 (3.3)
2,000
2,400
2,500
2,500
2,300
1,700
1,700
1,700
1,700
1,700
36
40
69
86
79
12 V
12 V
12 V
12 V
12 V
COMPRESSOR – ROTARY SCREW / SINGLE STAGE
Free-Air Delivery cfm (m3/min)
Rated Operating Pressure psig (bar)
Pressure Range psig
(bar)
Air Discharge Outlet Size
in (NPT/mm)
Air Discharge Outlet Quantity
Fuel Tank Capacity gal (L)
110 (3.1)
100 (6.9)
70 – 125
(4.9 – 8.6)
.75 (19.0)
135 (3.8)
100 (6.9)
70 – 125
(4.9 – 8.6)
.75 (19.0)
185 (5.2)
100 (6.9)
80 – 125
(5.5 – 8.6)
.75 (19.0)
185 (5.2)
125 (8.6)
80 – 150
(5.5 – 10.4)
.75 (19.0)
260 (7.4)
100 (6.9)
80 – 125
(5.5 – 8.6)
.75 (19.0)
2
27 (102)
2
27 (102)
2
27 (102)
2
27 (102)
2
29 (110)
137.7 (3498)
68.5 (1739)
62.3 (1582)
137.7 (3498)
68.5 (1739)
62.3 (1582)
137.7 (3498)
68.5 (1739)
62.3 (1582)
137.7 (3498)
68.5 (1739)
62.3 (1582)
137.7 (3498)
68.5 (1739)
62.3 (1582)
59 (1499)
13"
2,020 (916)
2,209 (1002)
59 (1499)
13"
2,020 (916)
2,209 (1002)
59 (1499)
15"
2,130 (966)
2,325 (1054)
59 (1499)
15"
2,130 (966)
2,325 (1054)
59 (1499)
15"
2,510 (1139)
2,710 (1230)
DIMENSIONS WITH RUNNING GEAR
Overall Length in (mm)
Overall Width in (mm)
Overall Height in (mm);
Add 3.47" (88 mm) Exhaust Pipe
Track Width in (mm)
Tire Size
Shipping Weight — No Fuel lb (kg)
Working Weight — With Fuel lb (kg)
DIMENSIONS WITHOUT RUNNING GEAR
AVAILABLE OPTIONS
(FACTORY INSTALLED)
■ 4-in-1 combo gauge
Overall Length in (mm)
Overall Width in (mm)
Overall Height in (mm);
Add 3.47" (88 mm) Exhaust Pipe
Shipping Weight — No Fuel lb (kg)
Working Weight — With Fuel lb (kg)
87.9 (2233)
49.6 (1261)
54.3 (1380)
87.9 (2233)
49.6 (1261)
54.3 (1380)
87.9 (2233)
49.6 (1261)
54.3 (1380)
87.9 (2233)
49.6 (1261)
54.3 (1380)
87.9 (2233)
49.6 (1261)
54.3 (1380)
1,800 (816)
1,989 (902)
1,800 (816)
1,989 (902)
1,905 (864)
2,100 (953)
1,905 (864)
2,100 (953)
2,285 (1037)
2,485 (1127)
– Engine temperature
Product improvement is a continuing goal at Ingersoll-Rand.
– Volt meter
Designs and specifications are subject to change without notice or obligation.
– Engine oil pressure
– Discharge air temperature
■ 6 kW on-board generator with three
120 V duplex receptacles
■ Rear bumper
■ Air filter safety element (3-stage filtration)
■ Hose reel – 100' capacity for 3/4" (19 mm)
■ Rear drop leg; requires optional rear bumper
■ Lockable fuel fill (lock not included)
ID hose, single or double reel with OSHA
■ Padfoot instead of caster wheel
■ Key-lock side doors with two keys
valve(s), and 3/4" globe-type service valves
■ OSHA valves
■ Special paint – lead free only
■ In-line oilers for tool lubrication
■ Fuel level gauge
■ Filter kits
■ Electric or surge brakes (electric brakes
■ Engine block heater 110 V / 1 ph / 60 Hz
■ Amber roof light; revolving or strobe
standard on P260WIR)
Distributed By:
■ Less running gear
■ 1,000 CCA battery
■ Additional service outlets
www.irco.com
(877) IR BRAND
www.onesourcerental.com
© 2004 Ingersoll-Rand Co.
Form 08-0006
Printed in USA 08-04
Hydraulic Jackhammer Specifications
Technical Specifications
Weight, incl. hoses:
58 lb
Breaker Version:
Standard
Shank Size (mm):
28x152
Shank Size (inch):
1 1/8x6
Length:
30 inch
Oil flow:
317 - 476 gpm
Working pressure:
1595 - 1813 psi
Back Pressure, max:
218 psi
Impact rate:
1350 - 1750 blows/min
Vibration level 3 axes (ISO 28927-5), 10 lpm*:
18.2 m/s²
Sound power level guaranteed, Lw
(2000/14/EC)*:
110 dB(A)
Sound pressure level (ISO 11203)* Lp, r=1m:
95 dB(A)
EHTMA class:
PC
88MR
Midi-Excavator
PC88MR-8
ENGINE POWER
50,7 kW / 68,0 HP @ 1.950 rpm
OPERATING WEIGHT
8.100 - 8.750 kg
BUCKET CAPACITY
0,09 - 0,34 m³
Walk-Around
The new PC88MR-8 compact midi-excavator is the result of the competence and technology
that Komatsu has acquired over the past 80 years. It was designed and developed with
constant attention to the needs of customers from all over the world. The end product is a
user-friendly machine with top-class performances and a tight tail swing that protrudes over
the tracks by just 175 mm. The operator can concentrate on his work, without having to worry
about rear-swing impacts.
Outstanding
performances
•
•
•
•
•
Fast and precise movements
Large drawbar pull
Excellent controllability
2 automatic travel speeds
CLSS hydraulic system
Powerful and
environmentally
friendly
• High torque and fuel efficient Komatsu
ecot3 engine
• Meets EU Stage IIIA and EPA Tier III
• Auto-deceleration and eco-gauge
for a lower fuel usage
• 5 selectable working modes
• Low operating noise levels
2
PC88MR-8
ENGINE POWER
50,7 kW / 68,0 HP @ 1.950 rpm
OPERATING WEIGHT
8.100 - 8.750 kg
BUCKET CAPACITY
0,09 - 0,34 m³
First-class operator comfort
• Spacious and comfortable cab with
multi-position controls
• Quiet and ergonomic working environment
• Large multifunction colour LCD monitor
• Sliding door for easy entry and exit
• Automatic air conditioner
Total versatility
• Proportional control on joystick for auxiliary circuits
• Hydraulic pump oil flow adjustable on the
LCD monitor
• Standard hammer line
• Second auxiliary circuit and hydraulic quick-coupler
line (optional)
• Road liner (optional)
Easy maintenance
• Optimal maintenance layout
• Side-by-side coolers
• Equipment Management and Monitoring
System (EMMS)
• Standard fuel pre-filter with water separator
• Long maintenance intervals
Komatsu Satellite
Monitoring System
3
First-Class Operator Comfort
Operator’s environment
Thanks to its spacious cab, this
compact machine ensures outstanding comfort even to the most
demanding operator. With a double
slide mechanism, the seat and
PPC levers can be conveniently
adjusted for maximum productivity
and minimum fatigue. Wide front
and side windows - and an opening
skylight - enable better visibility in
any situation. The standard automatic air conditioner completes a
comfortable work environment by
maintaining a perfect temperature
in the cab, no matter the weather
outside.
Large multifunction LCD
monitor
A large and user-friendly colour monitor makes working in a
PC88MR-8 safe, accurate and
smooth. Its highly intuitive interface and easy-to-operate switches
give the operator access to a huge
range of functions and operating
information.
Opening skylight for overhead visibility
4
Wide glass surface for excellent all around
visibility
Large multi-lingual monitor
Outstanding Performances
Performance and controllability
The PC88MR-8 offers outstanding performances coupled with
excellent controllability for even the toughest job. It has a powerful swing force, can efficiently work on slopes, and it delivers exceptional drawbar pull. In conjunction with automatic down shift,
this machine is ideal on any terrain or for any application. The
Closed Load Sensing System (CLSS) ensures unbeatable speed
and control to all combined movements, no matter the load.
5
Powerful and Environmentally Friendly
Performance and ecology
The PC88MR-8 is fitted with an ecot3 engine that meets
EU Stage IIIA regulations. Together with an advanced
hydraulic system, this electronically controlled common-rail
engine with multi stage injection achieves a superior level of
productivity. Drastically reduced NOx emissions and noise
levels make this compact excavator perfect for confined
areas and urban jobsites.
High productivity and fuel saving
Depending on the load, operators can conveniently choose
between 5 working modes designed to match engine
speed, pump delivery and system pressure. Priority can be
given either to speed, for more productivity, or to fuel consumption for lighter applications. Fuel efficiency is further
improved with the auto-deceleration, a standard feature
that automatically slows down engine speed when levers
are in neutral position, and with the eco-gauge, visible on
the LCD monitor.
6
Total Versatility
Versatility
Maximum flexibility
Great care went into the design of
the PC88MR-8, to give it exceptional versatility and mobility for
work in confined areas. It offers
outstanding visibility and a reduced
tail overhang that lets the operator work without worrying about
rear impacts. A reduced front
swing radius and a left side swing
cylinder make trench digging a
cinch, and with its compact size
the PC88MR-8 is perfect for urban
or road-building jobsites. A wide
range of options - such as road
liners or an additional counterweight - are available to let customers perfectly match the machine to
their needs.
Thanks to auxiliary hydraulic lines,
the PC88MR-8 can use a wide
range of attachments. For breaking, crushing and all other applications, the optimal oil flow from the
hydraulic pump can be selected
directly on the LCD monitor. On the
joystick, proportional controls for
auxiliary circuits guarantee precision work with any tool.
7
Easy Maintenance
Excellent serviceability
Komatsu designed the PC88MR-8
with an easy access to all service points. Routine maintenance
and servicing are less likely to be
skipped, which can mean a reduction of costly downtime later on.
The radiator, aftercooler and oil
cooler are made of aluminium to
improve their efficiency and are
mounted in parallel for quicker
cleaning. The fuel and oil filters
as well as the fuel drain valve,
are all remote mounted and
easily accessible.
EMMS (Equipment Management and Monitoring
System)
Komatsu’s EMMS can
prevent a small problem
from becoming a major
service issue. The controller monitors all critical systems
and key engine features such as
engine oil pressure, coolant temperature, battery charge, air clogging etc. If an abnormality occurs,
it is displayed on the LCD. The
monitor also indicates when the oil
or the filters must be replaced.
All major maintenance points can be easily
reached from ground level
8
Fuel pre-filter with water separator
The LCD monitor informs about abnormalities and replacement times
Komatsu Satellite Monitoring System
KOMTRAX™ is a revolutionary
machine tracking system designed
to save you time and money. You
can now monitor your equipment
anytime and anywhere. Use valuable machine data received via the
KOMTRAX™ web site to optimise
your maintenance planning and
machine performances.
Machine working time - With the “daily working record” chart, get precise engine running
time data: when your machine was started
and when it was shut down, as well as total
engine running time.
Fleet location - The machine list instantly
locates all your machines, even those in
other countries.
Alarm notifications - You can receive notification of alarms both via the KOMTRAX™
website and by e-mail.
Added security - The “engine lock” feature
allows to program when a machine’s engine
can be started. And with “geo-fence”,
KOMTRAX™ sends notification every time
your machine moves in or out of a predetermined operating area.
With KOMTRAX™, you can:
• Check when & where your machines are at work
• Be informed of unauthorized machine use or movement
• Set and receive e-mail notification
for security alarms
For further details on KOMTRAX™,
please ask your Komatsu dealer for
the latest KOMTRAX™ brochure.
9
Specifications
ENGINE
HYDRAULIC SYSTEM
Model .......................................................... Komatsu SAA4D95LE-5
Type........ Common rail, multi injection, water cooled, turbocharged
Displacement......................................................................3.260 cm³
Bore × stroke......................................................... 95 mm × 115 mm
No. of cylinders ................................................................................4
Engine power
at engine speed ............................................................. 1.950 rpm
ISO 14396 ..........................................................50,7 kW / 68,0 HP
SAE J1349 .........................................................49,0 kW / 65,7 HP
Max. torque/engine speed ...................................266 Nm/1.600 rpm
Air cleaner .........................dry, double element type air cleaner with
dust indicator and auto-dust evacuator
Type..............HydrauMind. Closed-centre system with load sensing
and pressure compensation valves
Main pumps:
Pump for........................................boom, arm, bucket and travelling
Type ........................................ variable displacement, axial piston
Max. flow .......................................................................160 ltr/min
Pump for.................................................................. swing and blade
Type ............................................... fixed displacement gear pump
Max. flow .........................................................................70 ltr/min
Hydraulic motors:
Travel.........................................2 × piston motor with parking brake
Swing.............................. 1 × piston motor with swing holding brake
Relief valve setting:
Swing and blade ........................................ 21,1 MPa (215 kg/cm²)
Travel and work equipment ....................... 26,5 MPa (270 kg/cm²)
Bucket breakout force (ISO 6015) ................... 6.130 daN (6.525 kgf)
Arm crowd force, 1.650 mm arm
(ISO 6015) .................................................... 4.150 daN (4.230 kgf)
OPERATING WEIGHT
Operating weight, including 1.650 mm arm, 0,28 m³ bucket
(ISO 7451), blade, operator, liquids, filled tank and standard
equipment (ISO 6016).
SWING SYSTEM
Shoes
Width
Mono
boom
Two-piece
boom
Steel (450 mm)
2.320 mm
8.225 kg
8.575 kg
Steel (600 mm)
2.470 mm
8.395 kg
8.745 kg
Rubber (450 mm)
2.320 mm
8.175 kg
8.525 kg
Road liner (450 mm)
2.320 mm
8.305 kg
8.655 kg
Driven by ...................................................................hydraulic motor
Swing reduction gear ..................................................planetary gear
Swing circle lubrication .............................................. grease-bathed
Swing brakes.............................. automatic, with oil immersed disks
Swing speed........................................................................... 10 rpm
ELECTRIC SYSTEM
DRIVES AND BRAKES
Steering control .................................................. 2 levers with pedals
Transmission .................................................................... hydrostatic
Hydraulic motors ........................ variable displacement, axial piston
Max. drawbar pull.................................................66,9 kN (6.820 kgf)
Max. travel speeds Lo / Hi ................................. 2,9 km/h - 5,1 km/h
Service brake................................................................hydraulic lock
Parking brake ......................................................... mechanical discs
UNDERCARRIAGE
Construction...........................................X-frame centre section with
box section track-frames
Type..................................................................................fully sealed
Track adjuster...................................................................... hydraulic
Shoes (each side) ...........................................................................39
Carrier rollers (each side)..................................................................1
Track rollers (each side) ...................................................................5
Ground pressure .............................................................0,37 kg/cm²
BLADE
Width × height ..........................................................2.320 × 470 mm
Max. lifting above ground level .............................................500 mm
Max. depth below ground level .............................................440 mm
10
Voltage ........................................................................................24 V
Battery .......................................................................................55 Ah
Alternator.....................................................................................60 A
Starter motor ...........................................................................4,5 kW
SERVICE CAPACITIES
Fuel tank...................................................................................125 ltr
Cooling system...........................................................................10 ltr
Engine oil.................................................................................11,5 ltr
Final drive (each side)................................................................1,1 ltr
Swing drive................................................................................2,8 ltr
Hydraulic oil tank......................................................................100 ltr
CAB
Sound-proof cab, provided with safety glasses, liftable windscreen,
roof window, sliding door with lock, windscreen-wiper, electric
horn, adjustable seat with double slide, control system and
instrumentation, adjustable joysticks, outside air inlet.
ENVIRONMENT
Vibration levels (EN 12096:1997)*
Hand/arm.............................. ≤ 2,5 m/s² (uncertainty K = 1,2 m/s²)
Body ..................................... ≤ 0,5 m/s² (uncertainty K = 0,2 m/s²)
* for the purpose of risk assessment under directive 2002/44/EC,
please refer to ISO/TR 25398:2006.
Specifications
171
DIMENSIONS
35
1.3
40
1.3
2.320
785
53°
815
67
°
6.175 (6.350)
2.330
1.170
2.730
735
1.835
2.240 (2.615)
360
1.405
G.L
450
2.235
2.840
1.870
2.320
Bucket capacity (ISO 7451)
m³
0,077
0,109
0,181
0,235
0,282
Bucket width (without cutting edge)
mm
350
450
550
650
750
Bucket width (with cutting edge)
mm
450
550
650
750
825
11
Working Range
WORKING RANGE MONO BOOM
6.935 (7.345)
7
6
G
H
When boom swing
2.395
(2.545)
3
500
2
1.995
(1.545)
4.515 (4.720)
4
5.210 (5.235)
6.570 (6.750)
5
1
7
6
5
4
3
1
1
2.315
(2.165)
2
3
4
5
2.440
12
2
0
440
2.900 (3.165)
3.765 (4.250)
4.160 (4.615)
GL
0 8
Lifting Capacity
LIFTING CAPACITY MONO BOOM / WITH BLADE AT GROUND LEVEL
$
– Rating over front
When removing bucket, linkage
or cylinder, lifting capacities
can be increased by their
respective weights.
B – Bucket hook height
– Rating over side
C – Lifting capacities, including bucket (210 kg
– Rating at maximum reach
with 1.650 mm arm; 185 kg with 2.100 mm
arm), bucket linkage and bucket cylinder
%
&
A – Reach from swing centre
NJ
A
3,0 m
4,5 m
1.650 mm
1,5 m
5,0 m
3,0 m
0,0 m
-2,0 m
---------
------6.110*
------4.930*
----3.520*
5.210*
----2.040
2.070
--1.760*
3.060*
2.960*
--1.280
1.100
1.100
1.520*
1.650*
2.210*
2.770*
1.250
790
730
1.040
1.650 mm
Additional
counterweight
5,0 m
3,0 m
0,0 m
-2,0 m
+ 218 kg
+ 218 kg
+ 218 kg
+ 218 kg
------6.110*
------4.930*
----3.520*
5.210*
----2.220
2.250
--1.760*
3.060*
2.960*
--1.380
1.210
1.200
1.520*
1.640*
2.210*
2.770*
1.340
870
800
1.130
2.100 mm
B
5,0 m
3,0 m
0,0 m
-2,0 m
---------
------4.870*
------3.950*
----3.980*
5.440*
----1.990
1.980
--1.430*
2.860*
3.060*
--1.290
1.070
1.040
1.310*
1.430*
1.940*
2.460*
1.040
690
620
840
2.100 mm
Arm length
5,0 m
3,0 m
0,0 m
-2,0 m
+ 218 kg
+ 218 kg
+ 218 kg
+ 218 kg
------4.870*
------3.950*
----3.980*
5.440*
----2.170
2.160
--1.430*
2.860*
3.060*
--1.390
1.180
1.140
1.310*
1.430*
1.940*
2.460*
1.130
760
690
920
LIFTING CAPACITY MONO BOOM / WITH BLADE UP
A
3,0 m
4,5 m
1.650 mm
1,5 m
5,0 m
3,0 m
0m
-2,0 m
---------
------4.930*
------4.930*
----2.630
2.660
----2.040
2.070
--1.560
1.380
1.370
--1.280
1.100
1.100
1.520
980
910
1.300
1.250
790
730
1.040
1.650 mm
Additional
counterweight
5,0 m
3,0 m
0m
-2,0 m
+218 kg
+218 kg
+218 kg
+218 kg
------4.930*
------4.930*
----2.850
2.880
----2.220
2.250
--1.680
1.500
1.490
--1.380
1.210
1.200
1.520*
1.060
990
1.410
1.340
870
800
1.130
2.100 mm
B
5,0 m
3,0 m
0m
-2,0 m
---------
------3.950*
------3.950*
----2.580
2.570
----1.990
1.980
--1.430*
1.350
1.310
--1.290
1.070
1.040
1.270
860
790
1.060
1.040
690
620
840
2.100 mm
Arm length
5,0 m
3,0 m
0m
-2,0 m
+218 kg
+218 kg
+218 kg
+218 kg
------3.950*
------3.950*
----2.800
2.780
----2.170
2.160
--1.430*
1.470
1.430
--1.390
1.180
1.140
1.310*
940
870
1.160
1.130
760
690
930
Ratings are based on ISO standard 10567. Rated loads do not exceed 87% of hydraulic lift capacity or 75% of tipping load. Excavators used in object handling
operations must comply with the related local regulations and must be equipped with hose burst valves (boom & arm) and an overload warning device in
compliance with EN474-5.
- The values marked with an asterisk (*) are limited by the hydraulic capacities
- Calculations are based on the machine resting on a uniform and firm surface
- The lifting point is a hypothetical hook placed behind the bucket.
13
Working Range
WORKING RANGE TWO-PIECE BOOM
7.836
7.586
500
3.197
3.032
6.156
5.962
5.905
8.259
8.017
3.331
3.145
4.263
4.523
4.022
3.785
4.675
4.425
440
GL
2.440
7.398
7.655
14
Lifting Capacity
LIFTING CAPACITY TWO-PIECE BOOM / WITH BLADE AT GROUND LEVEL
$
– Rating over front
When removing bucket, linkage
or cylinder, lifting capacities
can be increased by their
respective weights.
B – Bucket hook height
– Rating over side
C – Lifting capacities, including bucket (210 kg
– Rating at maximum reach
with 1.650 mm arm; 185 kg with 1.900 mm
arm), bucket linkage and bucket cylinder
%
&
A – Reach from swing centre
NJ
A
1,5 m
4,5 m
1.650 mm
3,0 m
5,0 m
3,0 m
0,0 m
-2,0 m
---------
---------
---------
------3.890*
------1.860
--2.170*
2.980*
2.510*
--1.130
920
950
1.840*
1.650*
1.670*
1.500*
760
520
500
700
1.650 mm
Additional
counterweight
5,0 m
3,0 m
0,0 m
-2,0 m
+ 218 kg
+ 218 kg
+ 218 kg
+ 218 kg
---------
---------
------3.890*
------2.040
--2.170*
2.980*
2.510*
--1.240
1.030
1.050
1.840*
1.650*
1.670*
1.500*
840
590
570
780
1.900 mm
B
5,0 m
3,0 m
0,0 m
-2,0 m
---------
---------
---------
------4.110*
------1.810
--2.050*
2.960*
2.620*
--1.150
920
920
1.730*
1.520*
1.610*
1.480*
690
490
460
640
1.900 mm
Arm length
5,0 m
3,0 m
0,0 m
-2,0 m
+ 218 kg
+ 218 kg
+ 218 kg
+ 218 kg
---------
---------
------4.110*
------1.990
--2.050*
2.960*
2.620*
--1.250
1.020
1.030
1.730*
1.520*
1.610*
1.480*
770
550
530
710
LIFTING CAPACITY TWO-PIECE BOOM / WITH BLADE UP
A
1,5 m
4,5 m
1.650 mm
3,0 m
5,0 m
3,0 m
0m
-2,0 m
---------
---------
---------
------2.460
------1.860
--1.430
1.200
1.230
--1.130
920
950
960
680
660
900
760
520
500
700
1.650 mm
Additional
counterweight
5,0 m
3,0 m
0m
-2,0 m
+218 kg
+218 kg
+218 kg
+218 kg
---------
---------
------2.670
------2.040
--1.540
1.320
1.350
--1.240
1.030
1.050
1.050
750
730
990
840
590
570
780
1.900 mm
B
5,0 m
3,0 m
0m
-2,0 m
---------
---------
---------
------2.410
------1.810
--1.440
1.200
1.200
--1.150
920
920
880
640
620
820
690
490
460
640
1.900 mm
Arm length
5,0 m
3,0 m
0m
-2,0 m
+218 kg
+218 kg
+218 kg
+218 kg
---------
---------
------2.620
------1.990
--1.560
1.310
1.320
--1.250
1.020
1.030
970
710
690
910
770
550
530
710
Ratings are based on ISO standard 10567. Rated loads do not exceed 87% of hydraulic lift capacity or 75% of tipping load. Excavators used in object handling
operations must comply with the related local regulations and must be equipped with hose burst valves (boom & arm) and an overload warning device in
compliance with EN474-5.
- The values marked with an asterisk (*) are limited by the hydraulic capacities
- Calculations are based on the machine resting on a uniform and firm surface
- The lifting point is a hypothetical hook placed behind the bucket.
15
Midi-Excavator
PC88MR-8
Standard and Optional Equipment
ENGINE
Komatsu SAA4D95LE-5 common rail, multi
injection, water cooled, turbocharged diesel engine, z
EU Stage IIIA/EPA Tier III compliant
Alternator 24 V / 60 A
z
UNDERCARRIAGE
450 mm steel shoes
600 mm steel shoes
450 mm rubber shoes
450 mm road liner shoes
Track roller guard
HYDRAULIC SYSTEM
5-working mode selection system; Power mode,
economy mode, breaker mode, attachment mode
and lifting mode
One additional 2-way full-flow service valve with
hydraulic line for attachment on boom and arm
(HCU-A)
Additional auxiliary hydraulic circuit (HCU-B)
Relieve valve on service spool
2nd auxiliary hydraulic circuit (HCU-C) +
preparation for hydraulic quick-coupler
LIGHTING SYSTEM
Working light on boom
Front working light on cab
4 front working lights on cab
Rear working light on cab
Additional working light on boom
CAB
Automatic air conditioner
Adjustable seat with safety belt
Large multi-lingual LCD monitor
Radio pre-setting
12 V electric plug
Radio
z
z
z
z
z
{
z
{
{
{
{
z
z
z
z
{
z
{
{
{
{
SERVICE AND MAINTENANCE
Equipment Management and Monitoring System
z
(EMMS)
Double-element air filter
z
KOMTRAX™ - Komatsu satellite monitoring system z
{
Refuelling pump
SAFETY EQUIPMENT
Overload warning device
Travel acoustic alarm
Horn
Rear-view mirrors (left side, rear)
Hose burst valve on boom cylinder
Arm safety valve
Rotating beacon
Bucket linkage with lifting hook
ATTACHMENTS
2.320 mm blade
Bucket range (350 - 750 mm)
1.500 mm ditch cleaning bucket
1.650 mm ditch digging bucket (52°)
OTHER EQUIPMENT
Mono boom with cylinder protection
1.650 mm digging arm
Automatic 2-speed travel
Auto deceleration
Proportional roll switch on joystick for equipment
circuit
Two-piece boom (with positioner)
2.100 mm digging arm (for mono boom)
1.900 mm digging arm (for two-piece boom)
Additional counterweight (218 kg)
z
z
z
z
z
{
{
{
{
z
z
z
z
z
z
{
{
Further work equipment, accessories and special
application arrangements on request
z
{
{
{
Other attachments on request
z
{
standard equipment
optional equipment
Your Komatsu partner:
Komatsu Europe
International NV
Mechelsesteenweg 586
B-1800 VILVOORDE (BELGIUM)
Tel. +32-2-255 24 11
Fax +32-2-252 19 81
www.komatsu.eu
WESS006203
03/2012
Materials and specifications are subject to change without notice.
is a trademark of Komatsu Ltd. Japan.
Printed in Europe – This specification sheet may contain attachments and optional equipment that are not available in your area.
Please consult your local Komatsu distributor for those items you may require. Materials and specifications are subject to change without notice.
LightSource / L6 / L8
Light Towers
The POWER of Illumination
Ingersoll-Rand light towers are built with the professional-grade reliability and
durability you require. Our light towers feature dependable Kubota engines, a brighter,
larger coverage area, and protective reflector housings with tempered glass. If your
workday doesn't end, or if your event heats up after the sun goes down, then you
need to put the power of Ingersoll-Rand light towers to work for you.
LightSource / L6 / L8 Light Towers
Specifications
LIGHT TOWER HIGHLIGHTS
■ FLOODLIGHTS
– Four 1,000 watt metal halide lamps designed
for large area coverage
– Aluminum reflector housings and tempered
impact-resistant glass lenses
– Weather-resistant, twist-lock connections for
attaching floodlights
■ ENGINE
– Dependable Kubota power
– Automatic protective shutdowns for high
engine coolant temperature and low engine
oil pressure
■ TOWER
– Telescoping mast, with 360-degree rotation
and position lock
– Extends 12' to 30' with dual, hand-operated
winches and patented automatic safety brake
– Mast retracts and stows horizontally for travel
– Patented tower locking system to prevent
telescoping during travel
– Able to stand up to 65-mph wind speed with
outriggers extended and jacks down
– Combination hitch with 3" pintle eye and 2"
ball hitch (LightSource™)
OPTIONAL EQUIPMENT
■ ALUMINUM GLARE SHIELD DIRECTS
LIGHT DOWNWARD
■ ELECTRIC WINCHES WITH AUTOMATIC
SAFETY STOP
■ L6 AND L8 OPTIONS
– Fuel gauge with low fuel shutdown
– Fuel / water separator
– Electric or hydraulic brakes
– Super quiet package for even lower
decibel output
■ L6 AND L8 LAMP OPTIONS
– High pressure sodium 1,000 watt lamps
• Interchangeable with metal halide bulbs
• Ideal for foggy, dusty environments
– Tungsten halogen 1,000 watt lamps (L6 only)
and 1,500 watt lamps (L8 only)
– Internal lamp storage
– Achieve a larger illuminated area with two
additional lamps (L8 only)
MODEL
LIGHTSOURCE
L6
L8
Kubota
D905E2BG
3
55 (0.9)
Water
1,800
10.5 (7.8)
12 V
Diesel
27 (102)
62
Kubota
D905E2BG
3
55 (0.9)
Water
1,800
10.5 (7.8)
12 V
Diesel
27 (102)
62
Kubota
D1105E2BG
3
69 (1.1)
Water
1,800
13.6 (10.1)
12 V
Diesel
27 (102)
62
Leroy Somer
6
60
4 lights max
(1) 120 V, 20 A GFCI Duplex;
(1) 240 V, 30 A
Leroy Somer
6
60
4 lights max
(1) 120 V, 15 A GFCI Duplex;
(1) 240 V, 30 A
Leroy Somer
8
60
6 lights max (4 standard)
(2) 120 V, 15 A GFCI Duplex;
(1) 240 V, 30 A
Overall Length Including Drawbar – in (mm)
172 (4370)
Overall Width – in (mm)
62 (1575)
Overall Height Travel Position – in (mm)
70.5 (1790)
Track Width – in (mm)
49 (1245)
Tower Height – ft (m)
30 (9)
Tire Size
ST175/80D13
Shipping Weight — No Fuel – lb (kg)
1,825 (830)
Working Weight — w/ Fuel – lb (kg)
1,990 (900)
Max Axle Capability – lb (kg)
3,000 (1360)
182 (4625)
79 (2010)
89 (2260)
64 (1625)
30 (9)
ST175/80D13
2,110 (960)
2,270 (1030)
3,500 (1590)
182 (4625)
79 (2010)
89 (2260)
64 (1625)
30 (9)
ST175/80D13
2,110 (960)
2,270 (1030)
3,500 (1590)
TIER 2 ENGINE
Make
Model
Number Of Cylinders
Displacement – cu in (L)
Cooling
Rated Speed – rpm
Power – bhp (kW)
Electrical
Fuel
Fuel Capacity – gal (L)
Runtime w/ 4 Lights – hr
GENERATOR
Make
Output – kW
Frequency – Hz
Suitable For Lights
Available Receptacles
DIMENSIONS
Product improvement is a continuing goal at Ingersoll-Rand.
Designs and specifications are subject to change without notice or obligation.
Noise Level : 72 Dba
WARRANTY INFORMATION
■ LIGHT TOWER PACKAGE WARRANTY
– 1-year / 2,000-hour warranty
■ GENERATOR WARRANTY
– 2-year / 4,000-hour warranty for LightSource
– 1-year / 2,000-hour warranty from for L6 and L8
■ ENGINE WARRANTY
– 2-year / 2,000-hour full warranty
– 3-year / 3,000-hour major components, parts only
■ LIGHTSOURCE
– Low fuel shutdown with indicator light
– 50 Hz model available
www.irco.com
(877) IR BRAND
© 2005 Ingersoll-Rand Co.
Form 10-0003
Printed in USA 06-05
KOMATSU : Demolition Specifications - Construction & Mining Equipment
Page 1 of 2
Home > Products & Services > Construction & Mining Equipment / Product Outline > Special Applications > DEMOLITION
SPECIFICATIONS
Download catalog
pdf
djvu
demolition
demolition
The machine exclusively designed for
demolition work that can easily take on
tough jobs
Demolition-dedicated machine that has been nurtured by a long
track record
The machine best suited to hard demolition jobsites. Equipped
with additional hydraulic piping for attachments as a standard
specification, PC200/PC200LC with demolition specifications
can be installed with attachments like a hydraulic breaker and
crusher. Its work equipment and base machine have been
strengthened to ensure higher durability. It demonstrates
excellent operating performance even under severe working
conditions.
Fixed see-through skylight
Cab front guard, full height guard
(optional)
Model
Machine weight
kg
PC200
PC200LC
PC220
PC220LC
PC228US
21400
22300
23400
24400
24400
http://www.komatsu.com/ce/products/sa/hydraulic/glo/glo_pc200.html
11/2/2011
KOMATSU : Demolition Specifications - Construction & Mining Equipment
Bucket capacity
(SAE/CECE)
m3
Engine model
Flywheel power
kW(HP/PS) /
rpm
Page 2 of 2
0.8 / 0.7
1.0 / 0.9
0.8 / 0.7
KOMATSU
SAA6D102E–2
KOMATSU
SAA6D102E–2
KOMATSU
SAA6D102E–2
107(143 / 145) / 1950
125(168 / 170) / 2000
107(143 / 145) /
1950
Arm crowd force
kN(kgf)
*108(11000)
*129(13200)
*108(11000)
Bucket digging force
kN(kgf)
*149(15200)
*172(17500)
*149(15200)
Ground pressure
kPa[kgf/cm2]
48.1[0.49]
45.1[0.46]
52.0[0.53]
49.0[0.50]
53.0[0.54]
Max. digging height
mm
10000
10000
10700
Max. digging depth
mm
6620
6920
6620
Max. digging reach
mm
9875
10180
9875
Tail swing radius
mm
2940
2940
1680
Overall length
(in transport)
mm
9625
9885
8700
Overall height
(in transport)
mm
3000
3160
3035
Overall width
mm
Sound level
dB
2875
2980
102
2980
3180
103
2980
101
*Material handlers other than the above are also available.
Download catalog
pdf
djvu
demolition
demolition
Page Back
http://www.komatsu.com/ce/products/sa/hydraulic/glo/glo_pc200.html
Page Top
11/2/2011
