PREPARE THE TEK SERIES HANDHElD DEvICE

PREPARE THE TEK SERIES HANDHElD DEvICE

IMPORTANT SAFETY INFORMATION

Explanation of Attention Words and Symbols used in this guide

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION, used without the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in harm to your dog.

NOTICE is used to address safe use practices not related to personal injury.

• Not for use with aggressive dogs. Do not use this product if your dog is aggressive, or if your dog is prone to aggressive behavior. Aggressive dogs can cause severe injury and even death to their owner and others. If you are unsure whether this product is appropriate for your dog, please consult your veterinarian or a certified trainer.

• This device contains Lithium-Ion (Li-Ion) batteries; never incinerate, puncture, deform, shortcircuit, or charge with an inappropriate charger. Fire, explosion, property damage, or bodily harm may occur if this warning is not followed.

• Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the regulations in your area.

• Batteries should never be removed from the battery compartment for charging.

• Taking your product apart can cause damage and void your warranty.

• Do not charge the batteries in areas with high temperature (100°F +).

• Keep batteries away from children.

• Using your TEK

Series Location System while operating a motor vehicle can be distracting.

Always pay full attention to operating your vehicle.

• Always be alert to your surroundings when navigating to a way point. Do not cross dangerous terrain or obstacles as you move.

2 1-800-732-0144

Please read and follow the instructions in this manual. Proper fit of the collar is important.

• Avoid leaving the collar on the dog for more than 12 hours per day.

• When possible, reposition the collar on the dog’s neck every 1 to 2 hours.

• When using a separate collar for a lead, don’t put pressure on the GPS Collar.

• Wash the dog’s collar weekly with a damp cloth.

• Taking product apart can cause damage and void your warranty. Contact the Customer Care

Center for battery replacement service.

• Avoid using a high-powered radio (greater than 5 watts) in close proximity to the TEK

Location System. It may cause irreversible damage to the TEK Series Location System.

Series

• Avoid chemical cleaners and solvents that can damage plastic components.

• Do not store the TEK Series Location System where prolonged exposure to temperature extremes may occur, because permanent damage may result.

• When storing the device for an extended time, store within the following temperature range: from

32°F to 77°F (from 0° to 25°C).

• Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun in an unattended vehicle. To prevent damage, remove the device from the vehicle or store it out of direct sunlight, such as in the glove box.

sportdog.com/tEK 3

Thank you for choosing SportDOG Brand

®

. Used properly, this product will help you track your dog efficiently and safely. To ensure your satisfaction, please review this owner’s manual thoroughly. If you have questions regarding this product’s operation, please see this manual’s Frequently Asked

Questions or Troubleshooting section, contact our Customer Care Center at 1-800-732-0144, or visit our website at www.sportdog.com.

To get the most protection out of your warranty, please register your product within 90 days at www.sportdog.com. By registering, and keeping your receipt you will enjoy the product’s full warranty and should you ever need to call the Customer Care Center, we will be able to help you faster. Most importantly, SportDOG

will never give or sell your valuable information to anyone.

Complete warranty information is available online at www.sportdog.com.

4 1-800-732-0144

TAblE OF CONTENTS

COMPONENTS .............................................................................................................................................................................6

HOW THE SYSTEM WORKS.......................................................................................................................................................7

KEY DEFINITIONS ........................................................................................................................................................................8

ICON DEFINITIONS .................................................................................................................................................................. 10

MAIN MENU .............................................................................................................................................................................. 12

OPERATING THE TEK

SERIES .............................................................................................................................................. 13

PREPARE THE TEK SERIES HANDHElD DEvICE ............................................................................................................... 13

TO CAlIBRATE THE COMPASS ..............................................................................................................................................15

PREPARE THE GPS COllAR ....................................................................................................................................................17

PAIR COllARS TO THE HANDHElD DEvICE ...................................................................................................................... 20

FIT THE GPS COllAR ............................................................................................................................................................... 21

ADD YOUR DOG ......................................................................................................................................................................... 22

ACQUIRE GPS SATEllITE SIGNAlS .................................................................................................................................... 23

TRACK YOUR DOG .................................................................................................................................................................... 24 vIEW DOG STATUS ................................................................................................................................................................. 26

NAvIGATE WITH THE COMPASS AND GPS TOOlS ......................................................................................................... 27

MARK YOUR lOCATION WITH WAY POINTS .................................................................................................................... 27

SETTINGS MENU ...................................................................................................................................................................... 30

CHANGE GENERAl SETTINGS .............................................................................................................................................. 30

CHANGE COMMUNICATION SETTINGS ............................................................................................................................. 32

CHANGE MY COllARS SETTINGS ....................................................................................................................................... 33

CHANGE MY DOGS SETTINGS .............................................................................................................................................. 34

CHANGE UNIT SETTINGS ....................................................................................................................................................... 36

SET SYSTEM TIME ................................................................................................................................................................... 36

CHANGE DISPlAY SETTINGS................................................................................................................................................ 37

USE vEHIClE MODE ................................................................................................................................................................. 38

RESET HANDHElD DEvICE .................................................................................................................................................... 39

FREQUENTlY ASKED QUESTIONS ....................................................................................................................................... 40

TROUBlESHOOTING ................................................................................................................................................................ 42

TERMS OF USE AND lIMITATION OF lIABIlITY .............................................................................................................. 43

FCC COMPlIANCE .................................................................................................................................................................... 44

BATTERY DISPOSAl ................................................................................................................................................................ 45

INDEx .......................................................................................................................................................................................... 46

ADD-A-DOG ® ............................................................................................................................................................................. 48

sportdog.com/tEK 5

COMPONENTS

HOW THE SYSTEM WORKS

The SportDOG Brand

®

TEK

Series Location System has been proven safe, comfortable and effective for all dogs over 8 pounds. Consistent, correct use of this product allows you to track your dog from up to 7 miles. The Handheld Device receives your location from its built-in GPS antenna and receives location updates from the antenna mounted on the GPS Collar to track the location of your dog.

IMPORTANT : THE TEK SERIES lOCATION SYSTEM HAS A RANGE OF UP

TO 7 MIlES. DEPENDING ON THE WAY YOU HOlD THE HANDHElD DEvICE,

THE MAxIMUM RANGE MAY vARY. FOR CONSISTENT RESUlTS AT lONGER RANGES, HOlD THE HANDHElD DEvICE IN A vERTICAl POSITION

AWAY FROM YOUR BODY AND ABOvE YOUR HEAD. TERRAIN, WEATHER, vEGETATION, TRANSMISSIONS FROM OTHER RADIO DEvICES, AND OTHER

FACTORS WIll AFFECT THE MAxIMUM RANGE.

STIM

BUTTON 1

STIM

BUTTON 2

STIM

BUTTON 3

KEY DEFINITIONS

HANDHELD DEvICE

ANTENNA

GPS ANTENNA

ON/OFF BUTTON

BACK

BUTTON

TRACKING

BUTTON

DISPLAY

MENU

SELECTION PAD

CHARGING

JACK

HANDHElD DEvICE: Receives and displays location updates from the GPS Collar. It is waterproof and can be submerged in water to a depth of 5 feet.

ON/OFF BUTTON: Pressing and releasing this button turns the Handheld Device on and off, and also controls the display’s brightness level.

BACK BUTTON: While navigating menus, this button moves back to the previous menu screen.

TRACKING BUTTON: This button takes you to the tracking screen at any time and acts as an enter key when entering information in text entry fields.

MENU SElECTION PAD: This pad contains four arrow keys (up, down, left, and right) for use when navigating and selecting to menus.

USER-DEFINED STIM BUTTONS: These buttons

(button 1 on top, button 2 in the middle, and button 3 on the bottom) are used to send signals for the user-defined stimulation type when training your dog with the optional E-Collar module.

CHARGING JACK: For connecting the Handheld

Device to the wall charger.

GPS

ANTENNA

ON/OFF

BUTTON

CHARGING

JACK

GPS COLLAR

GPS

INDICATOR LIGHT

GPS COllAR: Receives location from GPS and transmits location updates to the Handheld

Device. It is waterproof and can be submerged in water to a depth of 25 feet.*

GPS ANTENNA: Receives GPS satellite signals.

GPS ON/OFF BUTTON: Pressing and releasing this button turns the collar on and off.

GPS INDICATOR lIGHT: Indicates when the GPS

Collar has been turned on or off, whether a GPS lock has been attained, is in pairing mode, and also serves as a low-battery indicator.

GPS CHARGING JACK: For connecting the GPS

Collar to the charger.

*Per NEMA 6P and IP67 standards.

GENERAL

TRAINING

9:40 AM

Time

Brightness

Battery Gauge

Up / Down Indicators

More / Select

Back

Text Enter

C

V

T

Continuous Stimulation

Vibration

Tone

My Dog

TRACKING

GPS Lock/Fix Indicator

Compass

R

M

P1

GENERAL

Dog Direction Indicator

ICON DEFINITIONS

9:40 AM

9:40 AM

GENERAl ICONS

9:40 AM

100 YDS

Time

SERIES Location software interface.

Time

Brightness

Time

Brightness

Brightness

Brightness

Scale Indicator

Up / Down Indicators

Up / Down Indicators

TRACKING

Rising Stim

Up / Down Indicators

More / Select

MORE / SElECT INDICATOR: Indicates more information is available. Use

Back

More / Select

Back

Momentary Stim

Back

Text Enter

100 YDS

P2

V

V

V

T

T

C

V

T

C

C

V

T

T

Continuous Stimulation

Vibration

Vibration

Tone

Tone

My Dog

My Dog

R

R

M

M

P1

P1

P2

P1

P1

P2

P2

R

R

M

M

P1

Rising Stim

Momentary Stim

Momentary Stim

Programmable 1

Programmable 1

Programmable 2

Programmable 2

GPS Lock/Fix Indicator

Compass

Compass

Dog Direction Indicator

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Dog On Point / Treed

Scale Indicator

Scale Indicator

Battery Gauge on Collar

Battery Gauge on Collar

GENERAL

9:40 AM

Time

Brightness

Battery Gauge

Up / Down Indicators

GENERAL

GENERAL

GENERAL

GENERAL

GENERAL

9:40 AM

9:40 AM

TRAINING

TRAINING

TRAINING

TRAINING

C

C

C

C

T

T

Time

Time

Time

Time

Brightness

Brightness

Brightness

Brightness

Battery Gauge

Battery Gauge

Battery Gauge

Battery Gauge

Up / Down Indicators

Up / Down Indicators

Up / Down Indicators

Up / Down Indicators

More / Select

More / Select

More / Select

More / Select

Back

Back

Back

Back

Text Enter

Text Enter

Text Enter

Text Enter

Text Enter

GENERAL

TRAINING

9:40 AM

C

V

T

Continuous Stimulation

Continuous Stimulation

Vibration

Vibration

Vibration

Tone

Tone

Tone

My Dog

My Dog

My Dog

My Dog

Time

Brightness

Battery Gauge

More / Select

Back

Text Enter

Continuous Stimulation

Vibration

Tone

TRACKING

TRACKING

TRACKING

TRACKING

TRACKING

ICON

TRACKING ICONS

TRAINING

Up / Down Indicators

100 YDS

100 YDS

100 YDS

R

M

P1

TRACKING

C

V

T

100 YDS

Rising Stim

Momentary Stim

Programmable 1

More / Select

Back

FUNCTION

GPS Lock/Fix Indicator

GPS Lock/Fix Indicator

Compass

Compass

Compass

Dog Direction Indicator

GPS Lock/Fix Indicator

Continuous Stimulation

Dog Direction Indicator

R

Dog Direction Indicator Communication Lost

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Dog On Point / Treed

Dog On Point / Treed

Scale Indicator

Scale Indicator

Scale Indicator

Battery Gauge on Collar

Battery Gauge on Collar

Battery Gauge on Collar

Battery Gauge on Collar

Battery Gauge on Collar

M

P1

P2

My Dog

R

P2

P2

P2

Programmable 2

Rising Stim

Rising Stim

Momentary Stim

Momentary Stim

Momentary Stim

Programmable 1

Programmable 1

Programmable 1

Programmable 2

Programmable 2

Programmable 2

Programmable 2

TRACKING

100 YDS

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

MAIN MENU

When you power on the Handheld Device or press the BACK button, the main menu displays. The main menu provides the following options:

DOG TRACKING: views the location of your dogs and way points in relation to you (Page 24).

DOG lIST: Suspend or resume tracking of a particular dog, and set the order of the dogs (Page 25).

STATUS: view a list of all dogs and their current status (Page 26).

COMPASS: view the electronic compass for navigation (Page 27).

SETTINGS: Change configuration for dogs, collars, units, time, display, and other settings (Page 30).

WAY POINTS: Add, change, or remove way points from the system (Page 27).

SET A START POINT: Set a way point to your starting location (Page 27).

ABOUT: view name, ID number and software/hardware version of your Handheld Device (Page 39).

OPERATING THE TEK

SERIES

The following terms are used throughout this manual:

SElECT: Move the highlighted area on the screen up, down, left, or right with the respective arrow keys on the Menu Selection Pad to select individual menu items. A selected item is highlighted in orange.

BACK: Press the BACK button on the top right side of the Handheld Device to go to the previous menu.

FIElD: The location on a page where data can be entered.

ENTER: Press the Tracking Toggle button in a text entry field to select a highlighted character.

STEP :: 01

PREPARE THE TEK SERIES HANDHElD DEvICE

You must complete these steps prior to using this device for the first time.

TO CHARGE THE HANDHElD DEvICE:

NOTE: Approximate battery life between charges is 20 hours, depending on the frequency of use.

1. Lift the rubber cover protecting the charging jack.

2. Connect one of the charger connectors to the charging jack.

3. Plug the charger into a standard 120/240-volt AC wall outlet.

4. Charge the Handheld Device for 2 hours.

5. When charging is complete, indicated by a full green battery on the screen, replace the rubber cover.

Using li-Ion technology, the Handheld Device only requires a 2 hour charge. It is not harmful to let the unit charge more than 2 hours.

TO TURN THE HANDHElD DEvICE ON:

On the top of the unit, firmly press and release the On/Off button. The start-up screen will display.

TO TURN THE HANDHElD DEvICE OFF:

Firmly press and hold the On/Off button until the display goes black.

TO ADJUST THE DISPlAY bRIGHTNESS:

The Handheld Device comes with brightness controls to allow you to adjust the backlight level for the optimum readability in the current environment.

NOTE: Higher brightness levels will decrease battery life between charges.

With the Handheld Device powered on, press and release the

On/Off button to increase/decrease brightness levels. There are

5 levels of brightness available. The Brightness Indicator will display the current level at the top of the display.

TO CAlIbRATE THE COMPASS

In order for the TEK

Series Handheld Device to accurately display your location, you must first calibrate the electronic compass. You should always calibrate the compass after you arrive at a new starting location, after periods of storage or after you install new batteries.

NOTE: Always calibrate the compass outdoors. Hold the compass level and away from objects that may generate magnetic fields, such as cars, buildings, or overhead power lines.

1. From the main menu, select COMPASS > CAlIBRATE. The compass screen appears.

2. Rotate the handheld device 2-3 times in all three dimensions as shown below. Rotate until the black indicators are as close as possible to the center of the green zone. If successful, your handheld device will beep and vibrate, as well as, display a message that says your

“CALIBRATION DATA HAS BEEN UPDATED SUCCESSFULLY.”

NOTE: If you are unable to get the compass to automatically update your calibration data, follow the remaining steps.

3. Rotate until the black indicators are as close as possible to the green zone and press the Menu

Selection Pad to continue.

4. At the prompt “DO YOU WANT TO SAvE THE NEW CALIBRATION DATA?” press the arrow keys to select YES.

5. Press BACK to return to the main menu.

TO SET THE MAGNETIC DEClINATION ANGlE:

Magnetic declination is the angle between magnetic north (the direction the north end of a compass needle points) and true north. The declination is positive when the magnetic north is east of true north and negative when the magnetic north is west of true north. To find your exact declination angle go to: www.ngdc.noaa.gov/geomagmodels/Declination.jsp.

NOTE: Incorrect magnetic declination will result in inaccurate compass readings.

1. From the main menu, select SETTINGS > GENERAl > MAG DEC ANGlE.

2. Press the up or down arrows on the Menu Selection Pad to select the amount of declination.

Magnetic declination ranges from -70 to 70. The default is 0.

3. Press the right arrow when finished.

4. Press BACK to return to the main menu.

20°

-20°

15°

-10°

-15°

10°

5° 0°

-5°

STEP :: 02

PREPARE THE GPS COllAR

TO CHARGE THE GPS COllAR :

1. Lift the rubber cover protecting the GPS

Charging Jack located on the bottom of the

GPS Collar next to the On/Off button.

2. Connect one of the charger connectors to the

GPS Charging Jack.

3. Plug the charger into a standard 120/240-volt

AC wall outlet.

4. Charge the GPS Collar for 2 hours.

5. When charging is complete, indicated by the

GPS Indicator Light blinking green, replace the rubber cover.

Using li-Ion technology, the GPS Collar only requires a 2 hour charge. It is not harmful to let the unit charge more than 2 hours.

NOTE: Approximate battery life between charges is 20 hours, depending on the frequency of use.

TO TURN THE GPS COllAR ON:

Press and release the GPS On/Off button when the GPS Indicator Light comes on green. The GPS

Collar will beep 1 to 5 times indicating which channel the collar is on, and the GPS Indicator Light will double blink every 3 seconds until GPS lock has been achieved. Once the GPS Collar has a lock, the GPS Indicator Light will single blink every 3 seconds.

TO TURN THE GPS COllAR OFF:

Press and hold the GPS On/Off button when the GPS Indicator Light comes on solid red and the

GPS Collar beeps for 2 seconds. To extend the battery life between charging cycles, turn off the

GPS Collar when it is not in use.

GPS INDICATOR lIGHT

OPERATIONAl

MODE lIGHT

COlOR lIGHT FUNCTION BATTERY

STATUS

SPEAKER FUNCTION

Unit is turned on via

On/Off button

Green Light is solid in color during beep sequence

N/A Beeps 1 to 5 times indicating which channel the collar is on

Unit is turned off via

On/Off button

Red Light is solid in color during beep sequence

N/A Beeps continuously for 2 seconds

Unit is on with GPS Fix Green Single blink every 3 seconds

Unit is on without

GPS Fix

Amber Single blink every 3 seconds

Red Single blink every 3 seconds

Green Double blink every 3 seconds

Amber Double blink every 3 seconds

Good

Medium

Low

Good

Medium

Red Double blink every 3 seconds

Low

Unit is in pairing mode Amber Light is solid in color N/A

N/A

N/A

N/A

N/A

N/A

N/A

N/A

Unit is charging

Unit is fully charged

Green Light is solid in color N/A

Green Single blink every 1 second

Good

N/A

N/A

AbOUT RECHARGEAblE bATTERIES

• The Handheld Device and GPS Collar contain Lithium-Ion (Li-Ion) batteries; never incinerate, puncture, deform, short-circuit, or charge with an inappropriate charger. Fire, explosion, property damage, or bodily harm may occur if this warning is not followed.

• Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries accordingly.

• Risk of explosion if batteries are charged in areas with high temperature (100°F+).

• Batteries should never be removed from the battery compartment for charging.

• The rechargeable Lithium Ion (Li-Ion) batteries are not memory sensitive, do not require depletion before charging and cannot be over charged.

• The batteries come partially charged from the factory, but will require a full charge before the first use.

• When storing the unit for long periods, remember to regularly give batteries a full charge. This should be done once every 3 to 4 months. Failure to do so will result in decreased battery life.

• You should expect hundreds of recharge cycles from your batteries. However, all rechargeable batteries lose capacity over time relative to the number of recharge cycles they experience.

This is normal. If your operating time drops to half of the original life, contact the Customer Care

Center.

• The batteries should last for a period of 3-5 years. When a battery needs replacement, call our

Customer Care Center at 1-800-732-0144. Please do not open the Handheld Device or GPS Collar.

• When storing the device for an extended time, store within the following temperature range: from

32°F to 77°F (from 0° to 25°C).

• Separate collection of spent batteries is required in many regions; check the regulations in your area before discarding spent batteries.

STEP :: 03

PAIR COllARS TO THE HANDHElD DEvICE

Your system will already be paired when you get it, but in the event you need to pair the Handheld

Device to the GPS Collar, follow the steps below. The Handheld Device can support up to 12 collars at a time. You must repeat this procedure for each GPS Collar that you want to monitor with this

Handheld Device.

TO PAIR THE COllARS TO THE HANDHElD DEvICE:

1. On the main menu, select SETTINGS > MY COllARS > COlOR where COLOR is the icon color that you want to associate with this collar.

2. Press the right arrow to open the configuration window.

3. To enable the GPS collar, select and press the right arrow key to set ACTIvE to Y.

4. On the GPS collar, press and hold the On/Off button until its indicator light is a solid amber. The collar is now in “pairing mode.”

5. On the handheld device, select PAIR COllAR and press the right arrow key to complete the pairing process. The indicator light on the collar will blink 5 times to confirm that it is paired to the handheld device.

6. When finished, press BACK to return to the main menu.

STEP :: 04

FIT THE GPS COllAR

IMPORTANT: The proper fit and placement of the GPS Collar is important for effective use.

Please read and follow the instructions in this manual.

• Avoid leaving the collar on the dog for more than 12 hours per day.

• When possible, reposition the collar on the dog’s neck every 1 to 2 hours.

• When using a separate collar for a lead, don’t put pressure on the GPS Collar.

• Wash the dog’s collar weekly with a damp cloth.

TO ENSURE A PROPER FIT, FOllOW THESE STEPS:

1. With your dog standing (4A), center the collar underneath your dog’s neck (4B).

2. The collar should fit snugly, yet loose enough to allow one finger to fit between the strap and your dog’s neck (4C).

3. Allow your dog to wear the collar for several minutes, and then recheck the fit. Check the fit again as your dog becomes more comfortable wearing the collar.

4A

Note: To ensure the best reception possible, make sure the GPS antenna is positioned on the back of your dog’s neck.

4C

4B

GENERAL

9:40 AM

Time

Brightness

STEP :: 05

Battery Gauge

ADD YOUR DOG

The TEK

Up / Down Indicators the dogs to the system. You must repeat this procedure for each dog that you want to work with the system.

TO ADD A DOG:

More / Select

1. From the main menu, select SETTINGS > MY DOGS > ADD

A DOG. A screen labeled DOG n appears where n is the next available number of the dog.

Back

2. To enter the dog’s name, select CHANGE NAME. A text entry screen displays. Select Clr and press ENTER (bottom-right button) to clear the name. Use the arrow keys to select letters to enter a new name. Select

TRAINING

Text Enter

3. Assign a collar to this dog by selecting COllAR. Use the arrow keys to select the color matching the desired collar from the previously paired collars.

4. Once a collar is assigned to the new dog, you are ready to track this dog. Press BACK to return to the main menu.

C

Continuous Stimulation

If desired, you can add an E-Collar Module to your system with the purchase of a TEK-T Add-A-Dog

®

.

R

V

Vibration

M

T

Tone

My Dog

P1

P2

TRACKING

100 YDS

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

GENERAL

TRAINING

9:40 AM

Time

Brightness

Battery Gauge

Up / Down Indicators

More / Select

Back

Text Enter

C

V

T

Continuous Stimulation

Vibration

Tone

My Dog

P1

P2

R

M

ACQUIRE GPS SATEllITE SIGNAlS

Before the TEK

SERIES Handheld Device can show your current location and the location of your dog(s), both units must acquire a GPS signal fix.

TO ACQUIRE GPS SIGNAl FIX:

NOTE: Acquiring a GPS signal fix can take several minutes.

1. Go outdoors to an open area with a clear view of the sky.

2. Once you are outdoors, turn the Handheld Device and GPS Collar on. The “Waiting for Lock” message will display until a good GPS fix is acquired. On the Handheld Device, the GPS Fix

Indicator displays when GPS fix is achieved. The GPS Indicator Light on the collar will single blink every 3 seconds when it has a GPS lock.

Compass

100 YDS

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

TRACK YOUR DOG

The DOG TRACKING screen allows you to view your location and track the location of your dog(s).

TO USE TRACKING MODE:

NOTE: You must have a clear view of the sky in order for the GPS to acquire a signal. The “Waiting for Lock” message will display until a good GPS fix is acquired. The Handheld Device will beep once and move to the tracking window when GPS lock is acquired.

From the main menu, select DOG TRACKING. The tracking screen displays.

Your location is marked by a black crosshair (+) in the center of the display. Dogs are marked by a direction arrow showing their direction of travel or an octagon if the dog is stationary. If you have set a start point, it appears as an x on the tracking display.

Any active way points are marked by their respective number.

The upper portion of the screen also displays your GPS status, current map scale, and compass direction.

A table on the lower portion of the screen shows the status of the first three dogs being tracked as follows:

• The name of each dog is displayed in the color of its assigned collar.

• The distance of each dog from your location is displayed.

TO ADJUST THE SCAlE:

On the DOG TRACKING screen, press the left or right arrow on the Menu Selection Pad to manually adjust the scale from 100 yards to 75 miles or set the scale to AUTO which will automatically adjust to keep your dog(s) on the display. The current scale is displayed just below the tracking area.

TO SUSPEND OR RESUME TRACKING A SPECIFIC DOG:

You can choose to suspend tracking of a specific dog without having to delete the dog from the system.

1. From the main menu, select DOG lIST. A list of current dogs displays.

2. Use the arrow keys to highlight the dog you want to suspend tracking.

3. Press the right arrow key. A message displays “DOG X SUSPEND” where DOG X is the name of the dog selected. The dog will no longer display on the tracking screen.

4. To resume tracking the dog, select DOG lIST.

5. Use the arrow keys to highlight the dog you want to resume tracking.

6. Press the right arrow key. A message displays “DOG X RESUME” where DOG X is the name of the dog selected. The dog will appear on the tracking screen.

TO SET THE ORDER IN DOG lIST:

You can choose to re-order how dogs are displayed in the system.

1. From the main menu, select DOG lIST > SET ORDER. A list of dogs displays.

2. Use the arrow keys to highlight the dog you want to move in the list and press the right arrow key.

3. Use the up or down arrow keys to move the selected dog in the list.

4. When the dog is in the desired order, press the right arrow key.

5. Repeat for each dog until they are in the desired order. Dogs will now appear in this order on tracking screen.

vIEW DOG STATUS

The STATUS screen allows you to view the status of the GPS Collar for each dog, the ID for your

Handheld Device and a list of dogs being tracked. For each dog, you can view its ID, GPS battery status, GPS lock status, update rate, and the time since its last update.

The update rate on your Handheld Device will update automatically according to the following GPS

Collar battery status:

• Good Battery - Every 2.5 seconds

• Medium Battery - Every 10 seconds

• Low Battery - Every 25 seconds

TO vIEW THE DOG STATUS:

1. From the main menu, select STATUS. The STATUS screen displays .

2. Select the dog whose status you want to view e.g. DOG 1.

3. Press the right arrow to view the DOG STATUS screen.

GENERAL

TRAINING

9:40 AM

Time

Brightness

Battery Gauge

Up / Down Indicators

More / Select

Back

Text Enter

C

V

T

Continuous Stimulation

Vibration

Tone

My Dog

TRACKING

100 YDS

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

P1

P2

R

M

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

NAvIGATE WITH THE COMPASS AND GPS TOOlS

GENERAL

The TEK

SERIES Location System comes with a built-in electronic compass and GPS tools to track your location and guide you to previously saved locations.

TRACKING

SET YOUR STARTING lOCATION

9:40 AM

Time prior to working the dogs in a particular area.

GPS Lock/Fix Indicator

Compass

1. From the main menu, select SET START POINT. A prompt appears, “You are about to change the

Battery Gauge

2. Select YES to set a new starting location.

Dog Direction Indicator

Dog Direction Indicator Communication Lost

TRAINING

The WAY POINTS screen allows you to save your current GPS location as a way point, navigate to, rename or delete existing way points. You can store up to 20 way points. If you have set a start point, it appears as an x on the tracking display. Other way points are shown by their respective number.

More / Select

TO MARK A NEW WAY POINT:

Back

1. From the main menu, select WAY POINTS > MARK NEW POINT. A text entry field appears.

2. Use the arrow keys to enter a name for the new way point.

3. Select

100 YDS

Continuous Stimulation Rising Stim

C

V

T

Vibration

Tone

My Dog

R

M

P1

P2

Momentary Stim

Programmable 1

Programmable 2

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

GENERAL TRACKING

9:40 AM

Time

Brightness

Battery Gauge

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Up / Down Indicators

Dog Direction Indicator Communication Lost

More / Select

TO RENAME A WAY POINT:

1. From the main menu, select WAY POINT > way point name where way point name is a previously marked way point.

Back

2. Select RENAME. A text entry screen displays.

3. Use the arrow keys to type in the new name.

100 YDS

4. Select

TRAINING

TO DElETE A WAY POINT:

NOTE: Deleting a way point cannot be undone.

1. From the main menu, select WAY POINT > way point name where way point name is a previously marked way point.

2. Select DElETE. deleted.

displays.

V

TO USE THE COMPASS:

From the main menu, select COMPASS . The COMPASS screen

T

Continuous Stimulation

Vibration

Tone

NOTE: When using the compass, hold the Handheld Device up to a

45° angle and point the antenna forward along your line of travel.

R

3. At the prompt, “ARE YOU SURE YOU WANT TO CONTINUE?” select YES. The way point is

M

P1

Rising Stim

Momentary Stim

Programmable 1

P2

Programmable 2 My Dog and track the bearing to pre-defined way points. The compass shows north as a red N and will rotate as you move to keep its orientation. Your current heading is shown at the lower right corner of the display.

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

TO GO TO YOUR START POINT:

NOTE: You must have first set a start point before you can use the compass to navigate to it (see page 27). And, you must have a good GPS fix of your current location.

1. From the main menu, select COMPASS. The compass screen displays.

2. Select GO TO START. The compass screen now displays the bearing and distance to your starting location.

3. Face the direction toward the starting location then follow the best route to that location.

Always be alert to your surroundings when navigating to a way point.

Do not cross dangerous terrain or obstacles as you move.

TO GO TO A WAY POINT:

NOTE: You must have first created a way point before you can use the compass to navigate to it (see page 27). And, you must have a good GPS fix of your current location.

1. From the main menu, select COMPASS. The compass screen displays.

2. Select GO TO POINT. A list of pre-defined way points displays.

3. Select the desired way point. The compass screen now displays the bearing and distance to the way point .

TO GO TO A WAY POINT

(vIA WAY POINT MENU):

1. From the main menu, select WAY POINT > way point name where way point name is a previously marked way point.

2. Select GO TO. The compass screen displays with the bearing and distance to the selected way point.

SETTINGS MENU

The SETTINGS screen allows you to customize the operation of the Handheld Device.

TO OPEN THE SETTINGS MENU:

From the main menu, select SETTINGS. The settings screen displays the following options.

• GENERAL: Includes tracking modes, stimulation settings (for optional E-Collar module), action, name, and magnetic declination.

• COMMUNICATION: Includes user ID, GPS channel, and optional E-Collar channel.

• MY COLLARS: Includes collar status, collar pairing, and collar sharing.

• MY DOGS: Includes adding a dog, changing dog name, changing color, enabling optional E-Collar, or deleting a dog from the system.

• UNITS: Includes distance and time modes.

• SET TIME: Sets the time used by the Handheld Device.

• DISPLAY: Includes the brightness dim timer, power off timer, and way point display options.

• vEHICLE MODE: Enables or disables vehicle mode.

• RESET ALL: Resets all settings to the factory default configuration.

CHANGE GENERAl SETTINGS

The GENERAL SETTINGS screen allows you to set the tracking mode, stimulation configuration

(for optional E-Collar module), identity, and magnetic declination.

TO TOGGlE TRACKING MODE:

The Handheld Device can be configured to operate in two modes: TRACKING ONlY and TRACK

& TRAIN. In TRACKING ONlY mode, the Handheld Device will only track the location of dogs and all stimulation functions will be disabled. In TRACK & TRAIN mode, all stimulation options are available for use with the optional E-Collar module.

1. From the main menu, select SETTINGS > GENERAl.

2. Press the right arrow to select TRACKING ONlY.

GENERAL TRACKING

9:40 AM

Time

TO ENAblE ACTION AlERTS:

GENERAL

Brightness

• Treed – used for hunting with trailing dogs to indicate the dog is “on the tree” and holding an animal at bay.

9:40 AM

1. From the main menu, select SETTINGS > GENERAl >ACTION:

2. Press the right arrow key to toggle among the action types: NONE, ON-POINT, TREED.

3. Press BACK to return to the main menu

TRACKING

TO SET THE ACTION AlERT TYPE:

The Handheld Device can alert you to an action with several alert types.

1. From the main menu, select SETTINGS > GENERAl >AlERT:

2. Press the right arrow key to toggle among the action types: NONE, TONE, vIBE, BOTH.

3. Press BACK to return to the main menu

TO SET A NAME:

3. Select the

Back

Up / Down Indicators

At initial set-up, you can name your Handheld Device.

More / Select

100 YDS

1. From the main menu, select SETTINGS > GENERAl >SET NAME. A text entry screen displays.

2. Use the arrow keys on the Menu Navigation Pad to enter a name.

TO ClEAR OR CHANGE A NAME:

TRAINING

2. Select Clr to clear the name.

C

Back previously entered name. A text entry screen displays.

Continuous Stimulation

.

Text Enter

R

100 YDS

Rising Stim

TRAINING

V

Vibration

M

Momentary Stim

GPS Lock/Fix Indicator

Compass

Scale Indicator

Battery Gauge on Collar

T

C

V

My Dog

Vibration

T

Tone

Continuous Stimulation

Tone

P1

P2

R

M

P1

Programmable 1

My Dog

P2

Programmable 2

CHANGE COMMUNICATION SETTINGS

The COMMUNICATION screen allows you to set the User ID, GPS channel, and E-Collar channel

(optional). The User ID is a unique identifier used by the Handheld Device and shared with the GPS

Collar. The GPS-channel is the radio channel used for communication between the GPS Collar and the Handheld Device, while the E-Collar channel is the radio channel used for communication between the optional E-Collar module and the Handheld Device. The collar learns the User ID and

GPS channel during the pairing process.

The Handheld Device uses an ID value to distinguish it from other Handheld Devices. This ID is factory set and for most users will never need attention. The ID value can be viewed on either the

STATUS or ABOUT screens.

If the factory-set User ID on your Handheld Device conflicts with another Handheld Device or similar device, you should change the User ID to eliminate the conflict. Alternately, if two users want to have the ability to monitor the same dog(s) with each user operating his own Handheld

Device, they can choose to set their User IDs to match.

The only reason to change the GPS channel is if there is outside interference (other radios in the area) causing communications problems.

TO CHANGE THE USER ID:

NOTE: Changing User ID requires that the collar be paired again to the handheld (See STEP 3).

1. From the main menu, select SETTINGS > COMMUNICATION > USER ID.

2. Press the up or down arrows to select a user ID number from 0 – 100.

NOTE: The User ID value is a number from 0 to 100 that is used to alter the actual ID value that the

Handheld Device uses for communication. A value of 0 is used to revert back to the factory set ID.

3. Press the right arrow to confirm your selection.

4. At the prompt, “ARE YOU SURE YOU WANT TO CONTINUE?” select YES.

5. Press BACK to return to the main menu.

TO CHANGE THE GPS CHANNEl:

NOTE: Changing GPS channel requires that the collar be paired again to the Handheld Device (See

STEP 3).

1. From the main menu, select SETTINGS > COMMUNICATION >GPS CHANNEl.

2. Press the right arrow key to toggle between available GPS channels, 1 to 5.

3. At the prompt “ARE YOU SURE YOU WANT TO CONTINUE?” select YES.

4. Press BACK to return to the main menu.

CHANGE MY COllARS SETTINGS

The MY COLLARS screen allows you to configure a new collar, pair the collar to work with your

Handheld Device, or share tracking of a collar from another Handheld Device. You can add up to 12 collars to the system.

TO ADD A COllAR:

1. From the main menu, select SETTINGS > MY COllARS.

2. Press the up or down arrow keys to select the color you want to use with the new collar.

3. Press the right arrow to open the configuration window.

4. To enable the GPS Collar, select and press the right arrow key to set ACTIvE to Y. If sharing a collar skip Steps 5 and 6 and move to the SHARE COLLARS section on the next page.

5. Put the new collar in “pairing mode” by pressing and holding the On / Off button on the collar until its indicator light is solid amber. See STEP 3 for details on pairing mode.

6. On the Handheld Device, select PAIR COllAR to allow the GPS Collar to connect to the

Handheld Device. This collar is now ready to be put on a dog.

TO SHARE COllARS:

GENERAL

You can track dogs associated with another Handheld Device. This is helpful if you and another person are working with multiple dogs.

9:40 AM

selected is what you want to use for the collar to be tracked.

2. Press the right arrow to select Y to enable collar sharing.

3. To enter a User ID, select ID and press the right arrow.

the ID Code.

5. To select a dog number, select DOG and press the right arrow.

7. When finished, press BACK to return to the main menu.

Brightness the Handheld Device whose dog you want to track. See Status Screen from Main Menu to find

Battery Gauge

6. Use the up or down arrow keys to enter the two-digit identifier of the specific dog to be tracked.

This is the code used by the other user to identify that dog.

Up / Down Indicators

CHANGE MY DOGS SETTINGS

TO ADD A DOG:

1. From the main menu, select SETTINGS > MY DOGS > ADD A DOG. A screen labeled DOG n appears where n is the next available number of the dog.

Back

2. Change the dog’s name by selecting CHANGE NAME. A text entry screen displays. Press the arrow keys to select Clr and press the tracking mode button to clear the name. Pressing the arrow keys select letters to enter a new name. Select

TRAINING

Text Enter the desired collar.

4. Once a collar is assigned to the new dog, you are ready to track this dog. Press BACK to return to the main menu.

to complete the new name.

3. Assign a collar to this dog by selecting COllAR. Use the arrow keys to select the color matching

C

Continuous Stimulation

V

Vibration

T

Tone

My Dog

TRACKING

100 YDS

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

P1

P2

R

M

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

GENERAL

9:40 AM

Time

Brightness

Battery Gauge

Up / Down Indicators

More / Select

TO CHANGE A DOG’S NAME:

Back name previously entered for this dog. A text entry screen displays.

2. Press the arrow keys to select Clr and press the tracking mode button to clear the name.

3. Press the arrow keys on the Menu Navigation Pad to enter a new name, if desired.

Text Enter

4. When finished, select .

TO CHANGE THE COllAR ASSIGNED TO A DOG:

TRAINING

MY COLLARS screen. The color will also be used to identify the dog on the TRACKING screen.

2. Select COllAR.

3. Press the arrow keys to select the color for the desired collar then press the right arrow key. You must select YES to confirm the new collar assignment. NOTE: If the selected collar has already

Vibration

4. When finished, press BACK to return to the main menu.

TO DElETE A DOG:

deleted.

C

V

T

Tone

R

M

P1

deleted from the system.

My Dog

2. Press the arrow keys to select DElETE and press the right arrow key.

3. A warning message displays. Select YES, if desired, to confirm.

P2

TRACKING

100 YDS

Rising Stim

Momentary Stim

Programmable 1

Programmable 2

GPS Lock/Fix Indicator

Compass

Dog Direction Indicator

Dog Direction Indicator Communication Lost

Dog On Point / Treed

Scale Indicator

Battery Gauge on Collar

CHANGE UNIT SETTINGS

The UNITS screen allows you to change distance units and time modes.

TO CHANGE DISTANCE UNITS:

1. From the main menu, select SETTINGS > UNITS > DISTANCE.

2. Press the right arrow on the Menu Navigation Pad to select YARDS or METERS. Distances will be displayed in the selected format. The default is YARDS.

3. Press BACK to return to the main menu.

TO CHANGE TIME MODE:

1. From the main menu, select SETTINGS > UNITS > TIME.

2. Press the right arrow on the Menu Navigation Pad to select 12H or 24H mode. All times will display in the selected format. The default is 12H.

3. Press BACK to return to the main menu.

SET SYSTEM TIME

NOTE: Be sure to accurately set the time to your current local time.

TO SET THE lOCAl TIME:

1. From the main menu, select SETTINGS > SET TIME. The SET TIME window displays.

2. Press the up or down arrows on the Menu Navigation Pad to set the current hours. Then, press the right arrow to move to the minute field.

3. Press the up or down arrows to set the current minute. Then, press the right arrow to move to the AM/PM field.

4. If in 12-hour mode, press the up or down arrows to toggle between AM/PM. Then, press the right arrow to set the time.

5. Press BACK to return to the main menu.

CHANGE DISPlAY SETTINGS

The DISPLAY screen allows you to configure the brightness display timer, power off timer, and way point display options.

TO CHANGE THE lIGHT DIM TIMER:

1. From the main menu, select SETTINGS > DISPlAY > lIGHT DIM.

2. Press the right arrow on the Menu Navigation Pad to toggle among timer settings: NO, 30 SEC,

60 SEC, OR 90 SEC. If not used, the display screen will dim after the number of seconds selected.

The default is 30 seconds.

3. Press BACK to return to the main menu.

TO CHANGE POWER OFF TIMER:

1. From the main menu, select SETTINGS > DISPlAY > POWER OFF.

2. Press the right arrow on the Menu Navigation Pad to toggle among timer settings: NO, 1 HR,

2 HR, 3 HR. If not used, the Handheld Device will then automatically power off after the time period selected. The default is 3 hours.

3. Press BACK to return to the main menu.

TO CHANGE WAY POINT DISPlAY OPTIONS:

1. From the main menu, select SETTINGS > DISPlAY > vIEW PNTS.

2. Press the right arrow on the Menu Selection Pad to toggle among display options: NONE,

START, All. NONE will hide all way points on the tracking screen. START will only display start points. ALL will display all way points within range. The default is START.

3. Press BACK to return to the main menu.

USE vEHIClE MODE

Using your TEK

Series Location System while operating a motor vehicle can be distracting. Always pay full attention to operating your vehicle.

Using vehicle mode disables the internal compass and allows your Handheld Device to rely on GPS for heading and bearing information. This allows your Handheld Device to provide stable readings and not be affected by the metal structure and magnetic fields within your vehicle.

TO ENAblE / DISAblE vEHIClE MODE:

1. From the main menu, select SETTINGS > vEHIClE MODE.

2. Use the right arrow on the Menu Selection Pad to select Y to enable or N to disable vehicle Mode.

3. Press BACK to return to the main menu.

RESET HANDHElD DEvICE

Reset restores the Handheld Device to its factory-default settings.

TO RESET HANDHElD DEvICE SETTINGS:

NOTE: Resetting the system cannot be undone. All information including way points will be lost.

1. From the main menu, select SETTINGS > RESET All. A confirmation window displays.

2. At the prompt, “ARE YOU SURE YOU WANT TO CONTINUE?” select YES. The handheld will reset to its default configuration and power off.

AbOUT

From the ABOUT screen you can view your Handheld Device’s name, ID number and software/hardware revision.

FREQUENTlY ASKED QUESTIONS

How old does a dog have to be before using the TEK

SERIES location System?

The collar may be too large for dogs under 8 pounds.

Is the GPS Collar waterproof?

Yes. It is waterproof and can be submerged in water to a depth of 25 feet.

Can my GPS Collar be used around salt water? If the collar is used in or around salt water, the collar should be rinsed with fresh water following each use.

Is the TEK SERIES location System capable of multi-dog tracking?

Yes. The TEK SERIES Location System is expandable to a maximum of 12 dogs.

Additional collars must be purchased separately (see back cover).

Can I use the TEK SERIES location System on aggressive dogs?

Will I get exactly 7 miles of range with the TEK

SERIES location System?

We do not recommend any of our products be used on aggressive dogs. We recommend that you contact your local veterinarian or professional trainer to determine if your dog might be aggressive.

The range you get with your TEK SERIES

Location System will vary according to terrain, weather, vegetation, as well as, transmission from other radio devices. For maximum amount of range, please refer to the “How the System

Works” section of this guide.

Can I attach a leash to the GPS Collar?

DO NOT attach a leash to the GPS Collar. You may put a separate non-metallic collar on your dog’s neck and attach a leash.

Can I add maps to the TEK

Series location

System?

Can I program my TEK Series location System to work with my other SportDog Brand

® systems?

Can I organize the way the dogs are displayed on the tracking screen?

How many dogs can I share?

Do I need to recalibrate my compass when I change locations?

How many WAY POINTS can I store?

Will the TEK Series location System interfere with my CB radio?

No. Maps cannot be added to your TEK Series

Location System.

Other SportDog Brand systems can be used in conjunction with your TEK Series Location

System, but are not compatible. If desired, you can add an E-Collar module to your system with the purchase of a TEK-T Add-A-Dog

® back cover).

(see

Yes. See “To Set The Order In Dog Lists” on

Page 25.

You can share up to 12 dogs. Sharing a dog is the same as adding a dog to an available slot on your Handheld Device.

For best results it is recommended that the compass be calibrated after you arrive at a new starting location.

You can store up to 20 way points, which includes if you set a way point specific to your starting location.

No. Your TEK Series Location System will not cause interference with your CB radio.

TROUblESHOOTING

The answers to these questions should help you solve any problem you have with this system. If they do not, please contact the Customer Care Center at 1-800-732-0144 or visit our website at www.sportdog.com.

PROBLEM

My Handheld Device does not turn on.

My GPS Collar does not turn on.

The GPS Collar is not responding to the

Handheld Device.

I cannot get my compass to calibrate.

My dog is not showing up on the tracking screen.

I can’t figure out how to set the declination angle.

My Handheld Device conflicts with another handheld or similar device.

SOLUTION

Check to make sure the unit was properly charged. Refer to “TO CHARGE THE

HANDHELD DEvICE” on Page 13.

Refer to “TO CHARGE THE GPS COLLAR” on

Page 17.

• Make sure the GPS Collar has been charged.

The GPS Collar will charge in 2 hours.

• verify the GPS Collar has been turned on.

Refer to “PREPARE THE GPS COLLAR” on

Page 17.

• Refer to “PAIR COLLARS TO THE HANDHELD

DEvICE” on Page 20.

Always calibrate the compass outdoors. Refer to the “TO CALIBRATE THE COMPASS” on

Page 15.

Use the Menu Selection Pad on the Tracking

Screen to set the scale to AUTO.

Refer to the “TO SET THE MAGNETIC

DECLINATION ANGLE” section for more information on Page 16.

Refer to “TO CHANGE THE USER ID” on

Page 32.

PROBLEM

My GPS Collar is experiencing outside interference.

SOLUTION

Refer to “TO CHANGE THE GPS CHANNEL” on

Page 33.

TERMS OF USE AND lIMITATION OF lIAbIlITY

1. TERMS OF USE

This Product is offered to you conditioned upon your acceptance without modification of the terms, conditions and notices contained herein. Usage of this Product implies acceptance of all such terms, conditions, and notices.

2. PROPER USE

This Product is designed for use with dogs where tracking is desired. The specific temperament of your dog may not work with this Product. We recommend that you not use this Product if your dog is less than 8 pounds or if your dog is aggressive. If you are unsure whether this is appropriate for your dog, please consult your veterinarian, certified trainer or contact our

Customer Care Center at 1-800-732-0144.

Proper use includes reviewing the entire Operating Guide provided with your Product and any specific Caution statements.

3. NO UNLAWFUL OR PROHIBITED USE

This Product is designed for use with dogs only. This dog tracking device is not intended to harm, injure, or provoke. Using this Product in a way that is not intended could result in violation of Federal, State or local laws.

4. LIMITATION OF LIABILITY

In no event shall Radio Systems incidental, special or consequential damages, or any damages whatsoever arising out of or connected with the use or misuse of this Product. Buyer assumes all risks and liability from the use of this Product.

®

Corporation be liable for any direct, indirect, punitive,

5. MODIFICATION OF TERMS AND CONDITIONS

Radio Systems Corporation reserves the right to change the terms, conditions and notices under which this Product is offered.

FCC COMPlIANCE

This equipment utilizes the MURS band to provide data communication between the Handheld

Device and GPS Collar. The unlicensed use of the MURS band is authorized under part 95 Subpart

J of the FCC rules. To insure continued compliance with FCC limits, SportDOG Brand

® that you only use antennas provided by SportDOG

for use with your TEK

System. Refer all servicing to the SportDOG Brand Customer Care Center.

recommends

Series Location

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a specific installation. If interference does occur to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Contact customer service or an experienced radio/Tv technician for assistance.

CAUTION: Unauthorized changes or modifications to the equipment may violate FCC regulations and could void the user’s authority to operate the equipment.

44 1-800-732-0144

bATTERY DISPOSAl

See important safety information on Page 2 related to the battery.

This system operates on two Li-Ion battery packs (1250mAh capacity for the GPS Collar and

1900mAh capacity for the Handheld Device). Call the Customer Care Center at 1-800-732-0144 if your battery needs to be replaced. Do not remove or attempt to remove the non-user-replaceable battery.

Separate collection of spent batteries is required in many regions; check the regulations in your area before discarding spent batteries.

This product is protected by the following patents:

U.S. Patent Numbers: 7,647,545; D615,438 and other patents pending.

sportdog.com/tEK 45

INDEX

About Batteries, 19

Action Alerts, 31

Add A Collar, 33

Add A Dog, 22, 34

Charging

GPS Collar, 17

Handheld Device, 13

Collars

add a collar, 33 change assigned, 35

Fit Your Dog, 21

Pairing to Handheld, 20

Sharing A Collar, 34

Communications

GPS Channel, 33

User ID, 32

Compass

calibration, 15 go to start point, 29 go to way point, 29 magnetic declination angle, 16 operation, 28 vehicle mode, 38

Definitions

icons, 10, 11 main components, 8, 9 main menu, 12 terms, 13

Delete A Dog, 35

Display

brightness, 14 dim timer, 37 way point options, 37

Display Brightness, 14

Dog

add a dog, 22, 34 change assigned collar, 35 delete a dog, 35 track a dog, 24 view status, 26

Dog list, 25

Frequently Asked Questions

(FAQ), 40, 41

GPS

acquire signal fix, 23 change GPS channel, 33

GPS Collar

charging, 17 indicator light, 9 turn on, 17

Handheld Device

charging, 13 pairing collars, 20 reset to default, 39 set name, 31 turn on, 14

How To

acquire GPS signal fix, 23 add a collar, 33 add a dog, 22, 34 adjust display brightness, 14 adjust map scale, 24 calibrate the compass, 15 change a dog’s name, 35 charge the GPS Collar, 17 charge the Handheld

Device, 13 delete a way point, 28 enable action alerts, 31 fit GPS Collar, 21 go to a way point, 29 go to your starting location, 29 mark a way point, 27 pair collars to Handheld

Device, 20 rename a way point, 28 set action alert type, 31 set the magnetic declination angle, 16 set your start point, 27 share a collar, 34 track your dog, 24 turn on GPS Collar, 17 turn on Handheld Device, 14 use the compass, 28 view dog status, 26

Icons, 10, 11 lights, 18

Magnetic Declination Angle, 16

Map

adjusting map scale, 24

Mark location

set start point, 27 set way point, 27

46 1-800-732-0144

Menu

main, 12 settings, 30

Modes

pairing, 20 toggle tracking mode, 30 tracking, 24

Pairing Mode, 20

Rechargeable Batteries, 19

Reset, 39

Settings

action alerts, 31 action alert type, 31 add a collar, 33 add a dog, 34 change a dog’s name, 35 change assigned collar, 35 change Handheld Device name, 31 delete a dog, 35 dim timer, 37 display brightness, 14 display options, 37 distance units, 36 magnetic declination angle, 16 map scale, 24 pair collar, 20 power off timer, 37 reset, 39 share a collar, 34 time, 36 time mode, 36 tracking mode, 30 unit settings, 36 user ID, 32 vehicle mode, 38 way point display, 37

Share Collars, 34

Status, 26

Time, 36

Tracking

dogs, 24 own location, 28

Troubleshooting, 42, 43

Turn On

GPS Collar, 17

Handheld Device, 14

User ID

change, 32 view, 26

vehicle Mode, 38

Way Points

delete way point, 28 display options, 37 go to start point, 29 go to way point, 29 mark start point, 27 mark way point, 27 rename way point, 28 sportdog.com/tEK 47

ADD-A-DOG

®

TEK-H

ORIGINAL HANDHELD FOR

TEK 1.0L & TEK 1.0LT

TEK-T

E-COLLAR FOR TEK 1.0LT

TEK-AD

ORIGINAL COLLAR FOR TEK 1.0LT

TEK-L

ORIGINAL COLLAR FOR TEK 1.0L

ADD-A-DOG

®

SPORTDOG.COM

©2011 RADIO SYSTEMS ® CORPORATION • 10427 Electric Avenue • Knoxville, TN 37932 • 1-800-732-0144

J400-1360

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
