Bilora 2342-8
100 Years
Quality
2012 2013
Since over
100 years
Photo Video Accessory
100 Years
Contents:
Quality
Products:
Page
TrIPODS
Bilora 100 Years Quality
The BILORA history started with the
foundation of the metal factory Kürbi &
Niggeloh on the 1st February in 1909
in Barmen-Rittershausen. In addition to
the just developed tripods diverse other
consumer durables like hanging lamps,
music stands and bicycle axis were
produced at that time. The brand name
BILORA has been created of the names
of the company‘s founder - Wilhelm KürBI, Carl NiggeLOh - and the city of the
company foundation RAdevormwald.
In 1911 production, development and offices moved to the new factory buildung
with 1200 m² in Radevormwald. During
the following years many good ideas for
tripods were realized. Also a significant
camera production was built up.
From 1935 to 1975 many photographers could enjoy high quality cameras
with melodic names like Bellina, Bella,
Boy and Bonita. More than one million
cameras of the well-priced BILORA Standard Box had been sold. Nowadays still
working cameras can be found among
collectors. Kürbi & Niggeloh produced
also cameras for big companies like
Voigtländer, Gevaert, Revue and even
Yashica. Additionally to the cameras different tripod models like Perfekt, Stabilo
Rotax, Biloret and Monaco became very
famous. The range of products has been
continuously completed by amateur and
professional tripods.
In 1988 the management decided to
follow the market development and
offered an enlarged selection of accessories. One of the products which was
represented exclusively in Germany was
the famous American FOTIMA photo
and video bags programme.
The following years the product range
continuously increased.
In 1994 the photo sales department has
been outsourced and a subsidiary company was founded to guarantee a
2
strategy of continuity, flexibility and a
good price-performance ratio. KÜRBI –
OTTO TÖNNES GmbH with the owner
Kurt-Eduard Kürbi and Hartmut Reck
had been born. Carsten Reck, the son of
Hartmut Reck, has joined the company
in 2006 to succeed Kurt-Eduard Kürbi
and Hartmut Reck in a few years.
The two founder of the company: Wilhelm
Kürbi (left) was responsible for the commercial and administrative division, Carl Niggeloh
addressed himself as engineer to the development and construction of new products.
best price qualitiy relation. Our customers shall enjoy our extremely fair prices,
so that they can use all the possibilities
the analogue and digital photography
are able to offer.
In 2008 KÜRBI-OTTO TÖNNES relocated within Radevormwald. The new,
larger and modern hall offers more
place for the continuously increasing
programme and permits to adapt more
flexible to customer requests. On Photokina 2008 BILORA introduced its new
Carbon - tripods made of a new high
quality 8-layer carbon fiber tubing.
After the integration of our earlier subsidiary Adolf Grützner jr. GmbH & Co KG
in the end of 2009 BILORA itself offers
now - under the brand name „GPI“ a wide and a high-quality range of
Lithium-Ion rechargeable batteries for
digital cameras.
In October 2011 Carsten Reck replaced
his father Hartmut Reck and Kurt Eduard
Kürbi and took over sole management.
In August 2012, the Kürbi-Otto Tönnes
GmbH has been renamed after the
brand name in BILORA GmbH.
Also in the future our BILORA– team will
give you the best support for a wide article selection, highest quality, attractive
design and maximum innovation at the
4
- Twister Neo
6
- Perfect Pro
8
- Professional
11
- Blue Mag Line
12
- Tripod heads
14
- Accessory
15
- Pro Line
16
- Action Line
17
- Compact-Tripods
18
- Mini-Tripods
19
- Video Pro Tripods
20
BAGS and CASES
After long lasting experience as representation for flashguns and accessories
BILORA itself extended its programme
by this new product line in 2007.
Now - after more than 100 years - the
company looks back on an eventful
and successful time. In the meantime
we offer about 1000 different accessory
articles for beginners and professionals
- not only for digital 35 mm cameras, but
also for SLR-cameras.
- Selection Criteria
100 Years
- Alpha
22
- DigiStar
24
- Promo Line
27
- Reflex Profi Line
28
- College Bag Line
30
- Cases / Transporter
32
- Bags for Digicams
34
Backpacks
40
Chargers / Batteries
44
Cleaning
46
Special Accessory
48
Flashes / Studio Equipment
50
Remote Controls
52
Filters
54
Lens Caps / Lens Hood
55
Screen Protection
56
Photo-Studio / Binoculars
58
Binoculars
59
Contact
60
Symbol Explanation
Quality
maximum
height
minimum
height
closed
leg
sections
diameter
upper leg
round
bubble level
bubble
level
weight
maximum
load
bag
quick rel.plate
art.no
Ø
3
We help you
Tripod Choice
100 Years
Quality
Ball head, 3-way-panhead or video head ?
You can loose and fix the ball
head by only one single lever.
It can be adjusted in each
direction within the holder suitable for quick picture
changes, if a precise image
section is not necessary.
The 3-way-panheads can be positioned
in three different directions:
1. left and right
2. up and down
3. inclination between portrait format and
landscape format
Each axis can be moved and fixed by its
own handle. So the photo will be precise
and controllable.
Which weight can be managed by you ?
The video heads are suitable
for photo cameras as well as for
video cameras. The positioning
is possible only in two directions,
because a video camera is
not able to record in portrait
format. The especially for filming
constructed lever allows smooth,
jerk-free panning.
Lightweight tripods:
Heavy tripods:
advantages:
disadvantages:
advantages:
disadvantages:
Easier to transport
Less load capacitance
Very robust,
with big loading capacity
Weight und height make the
transport more difficult
Compact and handy
Less height
High camera position without
moving out the center column
More favourable price
The stability will be affected by
moving out the center column
Good vibration stability,
protection against blurring
Please decide for yourself, which are the most important criteria for you. Usually it will be a compromise between easy
transport and stability. Make sure that the tripod is dimensioned for the load of camera, head and the complete equipment.
Which material: Carbon or Aluminium ?
Carbon:
Which weight can be managed by the head ?
Which combination of your camera equipment is the
heaviest ? Camera, lens, flashgun and further accessory
must be taken into account.
The centre of gravity of the main weight should be
located on the ground plate. Long and heavy additional
lenses or other equipment intensify the lever action and
necessitate stronger fixing.
Large-scale cameras, such as medium format or video
cameras need more extensive quick-release plates to
minimize vibrations.
Aluminium:
advantages:
disadvantages:
advantages:
disadvantages:
Lightweight
Higher price
More favourable price
Higher weight
Very low vibration, positive
effects in the case of time
exposure
A bit less stroke resistance
High stability
Mono Pod or Tripod ?
Especially sport photographer and
hobby photographer, who prefer a
bit less bearing load, appreciate the
mono pod. It perfectly protects against
camera shakes, which can take place
vertically. Besides that the mono pod
permits precise pannings only by body
turning. But it has to be hold permanently.
If you intend to realise pictures
without camera shakes in the case
of longer exposure time, the tripod is
the best alternative. It offers perfect
stability for your camera - provided
that the weight of the complete
camera equipment suits to the load
capacitance of the tripod.
Only by using a mono pod or tripod the photographer can completely take advantage of the picture sharpness performance the lenses offer.
4
5
100 Years
Twister Neo
Twister Neo
Quality
Twister Neo
Silver Art.No TN 255-3
Mono with head:
Max.height: 155 cm
incl. center column
Max.height: 128 cm
without center column
Mono without head:
Max.height: 145 cm
incl. center column
Max.height: 118,5 cm
without center column
The Twister Neo are characterized by
their slim shape and the multifunctional
solutions. Besides that they are relatively
lightweight. Both, legs and the center
column, are anti-twist safe. All three legs
are provided with a foam coating.
The high-quality ball head with panorama
function can be easily operated by
one button with slight pre-friction. An
integrated spirit level and a bubble level
in the camera base plate allow precise
alignment. The hexagon headless screw
guarantees the anti-twist safeguard
of the head. The large camera quick
release plate allows a more flexible, wide
positioning of the camera.
Twister Neo
Blue Art.No TN 255-2
The integrated monopod
makes this all-rounder flexible
and universal. An intelligent
folding mechanism reduces
the transport length to only
38 cm. The padded carrying
bag - included in delivery provides comfortable carrying.
The center column is equipped with an integrated
spring-mounted load hook.
The rubber feet are ideal for
sensitive subsurfaces. The
accompanying steel spikes
ensure secure grip on uneven
ground.
6
For ground-level shots, the base
plate with the ball head can
be mounted on the low angle
converter.
Ø
Twister Neo
Colour
Art.No
Blue
Silver
TN 255-2
TN 255-3
148 cm
21 cm
38 cm
5
25 mm


1620 g
6 kg

Art. 2256
7
100 Years
Perfect pro
Perfect Pro
Quality
The Perfect Pro Carbon series
offers the ultimate in strength,
lightweight, fast action and reliable
performance. These tripods are
made of the latest generation of
high quality 8-layer carbon fiber
tubing.
Perfect Pro
The particularly handy wing screw for fixing the
center column and the anti-twist feature ensure
an exceptionally safe and quick adjustment.
Head 2258
Aluminium
change with the standard
column can be made
easily with the included
tools.
8
Perfect Pro Heads
Art.No
Height
Weight
Max. Load
Quick release plate
Ball head small
2205
8,5 cm
320 g
4 kg
2220
Ball head big
2258
12 cm
780 g
10 kg
2228
To change the
rubber feet each
foot can be simply
unscrewed and the
hidden spike foot
is free. The spikes
secure stability on
natural terrain. The
rubber feet version
should be used on
sensible ground.
The ball head 2258 is equipped with a
large fixing screw, a friction screw, an
additional panorama function and a
double secured quick release plate. The
head 2205 is provided with a fixing screw,
a friction screw, a movable lever screw, a
bubble level and a secured quick release
plate.
The tool pouch is included in the delivery
of all three-leg tripods.The bubble level
serves for the adjustment of the tripod.
A 3-position leg angle
adjustment (25, 55 and
80°) arranges the tripod
to uneven terrain, various
shooting situations or
low angle shooting. The
sliding leg angle locks
allow an easy handling
and guarantee a quick
readiness to shoot.
To offer the ability for
near ground photography a short center
column is included. The
The center column can easily be reversed for
an alternative shooting angle or low level macro
work.
Carbon Art.No CM 284
Carbon
Art.No C 324
Our 3-leg- Alu tripods offer exactly
the same specifications as the
Carbon tripods.
The professional anti-twist tubelocking device ensures quick and
safe handling - each clamp can
be used in each desired order.
This improved rotary clamping
increases the stability by
approx. 20 % and allows
a quick fixing and
Carbon
releasing.
Perfect Pro Mono
Head 2205
The reversible mounting screw accomodates any standard tripod head
with the mounting thread 3/8“ or 1/4“.
Ø
Perfect Pro
Tripod
Carbon
Art.No
C 324
180 cm
22 cm
66 cm
4
32 mm

-
2150 g
10 kg

-
Carbon
C 283
164 cm
21,5 cm
68 cm
3
28 mm

-
1650 g
8 kg

-
Carbon
C 253
153,5 cm
22 cm
63 cm
3
25 mm

-
1350 g
4,5 kg

-
Alu
A 324
180 cm
22 cm
66 cm
4
32 mm

-
2850 g
10 kg

-
Alu
A 283
164 cm
21,5 cm
68 cm
3
28 mm

-
1950 g
8 kg

-
Alu
A 253
153,5 cm
22 cm
63 cm
3
25 mm

-
1590 g
4,5 kg

-
Multi page 10
A 333
172 cm
25,5 cm
78 cm
3
28 mm


2500 g
8 kg

2233-K
2333-G
Mono Carb.
CM 284
153 cm
53 cm
53 cm
4
28 mm
-
-
460 g
6 kg
-
-
Mono Alu
AM 324
170 cm
57 cm
57 cm
4
32 mm
-
-
730 g
8 kg
-
-
with head
9
Perfect Pro
100 Years
Professional
Multi
Quality
Professional multifunctio-
nal tripod with black anodised
aluminium-tube and die-cast
components made of lightweight
magnesium. Special highlights
are the removable mono pod, the
multi-purpose swivel-element for
the center column and the two
exchangeable ball heads (big
and small) included in delivery as
well as a robust carrying bag.
Perfect Pro
Multifunctional-Tripod
The robust reliable workmanship
Professional
Combi I
Art.No 1121
of the Professional Line with its sophisticated equipment - well proven
since years - already convinced
thousand of users.
Art.No A 333
Because the tripods offer successful
details and solutions a large potential of photographic possibilities
can be used and that - acccording
to BILORA custom - at a top priceperformance ratio.
Copying function
(1120,1121,1122)
Professional
Ball heads in big
und small included in delivery
3-spread stops
Combi II
Art.No 1122
3-spread stops
With removable
mono pod
(1120,1121,1122)
Professional
Multi
Art.No 1120
Close to the ground
(1120,1121,1122)
Swivel element for center column
Professional
Mono
Art.No 1119
Deep- and side-swivel-mode
Copying function
Quick Locks
(1119,1120,1121,1122)
Center column
removable as
mono tripod
Incl. short center column
Ø
Professional
Ø
Perfect Pro
Tripod
Multifunctional
Tripod
10
Art.No
A 333
172 cm
with head
25 cm
78 cm
3
28 mm


2500 g
8 kg

2233-K
2333-G
Tripod
Art.No
Mono
1119
172 cm
63 cm
63 cm
4
25,5 mm
1
-
1450 g
4 kg

189
Multi
1120
153 cm
51 cm
59 cm
3
22 mm
-
1
2640 g
3 kg

189+189-V
Combi I
1121
142 cm
39 cm
63 cm
3
22 mm
1
-
2300 g
3 kg

189
Combi II
1122
152 cm
43 cm
76 cm
3
25,5 mm
-
1
3000 g
5 kg

189
11
Blue mag Line
Blue Mag Line
100 Years
Quality
Blue Mag
Line III
Blue Mag
Line II
Art.No M 294
Art.No M 264
The Blue Mag Line offers excellent
equipment details regarding the unbeatable price-performance ratio. And it
presents itself in a fashionable look.
Blue Mag Line
Mono I Art.No MM 264
All die-cast components (heads, tripodshoulder and tube holder) are made of
an aluminium-magnesium-alloy to offer
more stability while reducing the weight.
The anti-twist device is additionally
increased by using a square center
column. Only the head with its panorama function swivels.
Blue Mag
Line Mono II
Art.No MM 294
Blue Mag
Line I
Art.No M 234
The reversible center column
can be used - together with the
heads - for repro-, tabletopand close-ups.
The models M 234, MM 264 and MM 294 will supplied with a ball head
(ca. 340 g).
Leg sections, fixable in three
stop angles, allow a free
alignment of the tripod - even
in rough ground.
Ø
Blue Mag Line
The models M264 and M294 are equipped with a 3-way-panhead (440 g resp.
580 g) with swivelling lever and high
size function.
12
Shots close to the ground are
possible with the short center
column included in delivery.
Tripod
Art.No
Blue Mag
Mono I
MM 264
163 cm
61 cm
61 cm
Blue Mag
Mono II
MM 294
173 cm
63 cm
63 cm
Blue Mag I
M 234
152 cm
25 cm
60 cm
4
23 mm

Blue Mag II
M 264
161 cm
23 cm
62 cm
4
26 mm

Blue Mag III
M 294
169 cm
26 cm
65 cm
4
29 mm


4
4
26 mm
29 mm

-

-

760 g
3,5 kg
840 g
3,5 kg
-
1580 g
3,5 kg

2223

1980 g
4 kg

2224
2360 g
5 kg

2225

2223
2223
13
Accessory
Tripod - heads
100 Years
Quality
Ball heads are suitable when a quick adjustment
is required while taking pictures. 3-way-panorama
heads are appreciated for precise und controlled
shots. Video-heads have an especially for filming
constructed lever allowing smooth, jerk-free panning.
Video-heads can also be used for photo cameras.
Perf.Pro Ball Head
Quick Release 1
Quick Release 2
Art.No 1157, black
Art.No 2270
Art.No 2280
It’s really simple: solve with
pressure - choose the position let go. The head is fixed
automatically.
For compact cameras
Ø 3,5 cm
For D-SLR and
Bridge cameras,
Ø 5 cm
Compact quick release plates in plate holder for mounting on all tripods with 1/4“ or 3/8“ camera/tripod screw. They make
tripods without quick release system ready for use. If you have got quick release systems for each camera und you have
mounted the holder on the tripods you can easily change between diverse manufacturers.
Ball Head
Perf.Pro Ball Head
Art.No 2258
black
friction
Prof. Auto-Ballgrip S
Art.No 1150
grey
Art.No 2205
black
Cross Extension Arm
fixing
fixing
3-D
Panorama-Head
up to 4 tripod-heads/cameras mountable
length: 61 cm
weight: 1700 g
Art.No 1113
friction
3-D
Panorama-Head
Art.No 1151
grey
Art.No 1152
grey
Mountable on every Professional tripod with 3/8“ camera screw. Up to 4 tripod heads/cameras can be installed: two at
the endings, two separately movable and adjustable, with 3/8“ camera screw.
2-D Video-Head Professional
2-D Video-Head
Art.No 1154
grey
Art.No 2936
black
Basic Dolly for all tripods
Art.No 1112
Your standard tripod changes
into a studio-roll tripod !
closed: 55 cm
diameter: 73 cm
weight: 2500 g
Robust construction, smooth-running
rollers, adjustable clamps, suitable for all
tripods.
14
Model
Art.No
Max.Height
Max.Load
Weight
Quick release plate Art.No
Professional Auto-Ballgrip S
1157
12,5 cm
3 kg
540 g
2237
Ball Head
1150
11 cm
4 kg
695 g
189+189-V
Perfect Pro Ball Head small
2205
8,5 cm
4 kg
320 g
2220
Perfect Pro Ball Head big
2258
12 cm
10 kg
780 g
2228
3-D Panorama Head
1151
14 cm
5 kg
900 g
189+189-V
3-D Panorama Head
1152
14,5 cm
5 kg
1080 g
173
2-D Video-Head Professional
1154
12 cm
4 kg
870 g
174
2-D Video-Head Pro 36
2936
12 cm
5 kg
1260 g
2236
15
100 Years
Action Line
Pro Line
Quality
3-Way-Panhead
Pro 27
Art.No 927
Two
Bubble Levels
Solid
Quality
Action Line
Art.No 265
Top-PricePerformance
Ratio
Specialized
Folding Grip
A ll three ACTION LINE models are
A ll three PRO LINE models are
equipped with:
equipped with:
•
•
•
•
•
•
•
•
• 3-way-panhead with
quick release plate
• bubble levels
• quick locking levers
• center column with elevator
and adjustable brace
• cross connection
3-way panhead
2 bubble levels
specialized folding grip
quick locking levers
crank center column
fixing cross connections
accessory hook
changeable foot spikes
The models 264 and 265
additionally have
• accessory-hook
• rotatable rubber legs
• handle
The Pro 27 reaches an impressive height
of 187,5 cm and is therefore suitable for very
tall users.
Ø
Ø
Pro Line
16
Action Line
Tripod
Art.No
Pro 22
922
152,5 cm
57 cm
3
22 mm


1465 g
2 kg

188
Pro 25
925
153,7 cm
57,3 cm
3
25 mm


1580 g
2,5 kg

188
Pro 27
927
187,5 cm
61 cm
4
27 mm

1760 g
2,5 kg


188
Tripod
Art.No
Eco II
263
113 cm
41 cm
4
18 mm


500 g
0,5 kg

186-S
Standard II
264
157 cm
60 cm
3
20 mm


1100 g
1,0 kg

170
Top II
265
171 cm
64 cm
3
27 mm


2000 g
1,5 kg

185
17
Mini Tripods
CompaCt - Tripods
100 Years
Quality
Digi Pod Super
Art.No 499-N
The compact and
Digi Pod
Mini Pod
Art.No 492
Art.No 1002
Digi Pod Mini
Mini Pod Colour
R
Art.No 1009
tough Digi Pod
Super has a push
center column, a ball
head with a great
camera plate and
1/4“ screw, 3 spread
stops for shots
close to the ground
(35 cm) and a case.
Art.No 1010
obust model
Completely made of metal, with ball head, twosection extendable legs and 1/4“ camera screw
5 colours sorted: silver, black, champagne, blue,
bordeaux.
E xtremely light mini tripod
Ideal light tripod for digital
cameras and camcorder, with
transparent 3-way panhead,
incl. case.
Stabilet
The metal table
Art.No 1018
tripod with ball head
and fold-out legs can
also be used as a grip
tripod.
By using the removable, height-adjustable
column the tripod can
be extended to a height
of 37 cm.
18
Very robust table tripod
with flexible legs, pin clip and
1/4“ camera screw.
with ball head, extendable
and lockable legs and 1/4“
camera screw, in silver.
TripoFlex
Flexible table-tripod
Art.No 1015
It provides - in addition to the
normal 3-leg positioning - the
possibility of the „3-legged
clamping“.
Mono Pod Super
Art.No 2116
Art.No 1016
Mono tripod,
H igh level quality,
best choice for sports,
leisure time and
vacation, for best
telephoto shots.
Features: 4-section
leg with quick locking
levers, metal ball
head, foot lock, changeable foot-spikes/
rubbers, loop and
case.
MonoFlex
A ction-Pod
Action Pod
Rubberized feet, foldout sidewise, provide a secure footing
on smooth surfaces. Two velcro
straps are used for fixing to
handlebars, stair railings, tree
branches or even on bicycle
helmets - for real action shots.
Art.No 1017
Tripod
Art.No
Mini Pod Super
1002
11 cm
12 cm
1
45 g
200 g
Tripod
Art.No
Mini Pod Colour
1009
12-19 cm
16 cm
2
80 g
300 g
Digi Pod Super
499-N
137 cm
46 cm
4
850 g
500 g
Digi Pod Mini
1010
29 cm
17 cm
4
210 g
350 g
Digi Pod
492
103 cm
26 cm
8
450 g
350 g
TripoFlex
1015
17 cm
19 cm
1
180 g
300 g
Stabilet
1018
37 cm
21 cm
2
300 g
500 g
MonoFlex
1016
-
-
1
40 g
300 g
Mono Pod Super
2116
163 cm
61 cm
4
575 g
3000 g
ActionPod
1017
-
7 x 2 x 4 cm
-
50 g
500 g
flexible, only 40 g
in weight, consists of a single
segment. This
can be wrapped
around diverse
objects and
offers a ¼“ screw
for the compact
cameras.
19
Video Pro Tripods
Video Pro Tripods
100 Years
Quality
Both tripods are equipped with a height fixation with quick locking
Video Pro
levers, a quick release plate with 1/4“ screw and video-pin, a bubble level,
a transportation fixing device and changeable foot spikes.
The tripod 933 additionally has a length adjustable lever hold for right- or
lefthand use, a center column quick lock as well as a hideable lever. The
model 936 provides the following features: double profile-legs for highest
twisting stability, grease-damped metal-video head - adjustable for optimal
height compensation -, full metal camera quick release plate with retractable video-pin, adjustable guide-lever and height adjustment with upper
clamp.
Art.No 933
Test report - Reference
Video Pro
Double-Profilo
Art.No 936
05/08
test winner
Hideable lever
933
Video Super Pro
Art.No 939
Heavy fluid-damped
metal video head in
levelling bowl, with two
long adjustable guide
levers
ProfiQuality
Top
Equipment
I
deal for heavy professional video
cameras. Equipped with a heavy
grease-damped metal-video head in
a 75 mm levelling bowl, a big metal
quick release plate with 1/4“ and
3/8“ camera screw, a bubble level,
two long adjustable guide levers, a
removable ground strutting at double
profile-legs for highest stability,
inclusive carrying case and carrying
strap.
Ground-double-spike
75 mm levelling bowl
Bubble level
933
Transportation
fixing device 936
Foot in strutting holder
Strutting
936
Super Pro Dolly for 939
Art.No 2239
Robust construction,
smooth-running rollers,
adjustable clamps,
suitable only for Profi
Video Tripod 939.
Ø
Video Pro Tripods
20
Tripod
Art.No
Video Pro
933
158 cm
69 cm
3
45 mm open


2195 g
5 kg

187
Doppel-Profilo
936
153 cm
75 cm
3
75 mm open

-
3260 g
5 kg

2236
Super Pro
939
174,5 cm
91 cm
3
100 mm open

-
9300 g
10 kg

2229
Closed: 51,5 cm
Weight: 4480 g
Your standard tripod changes
into a studio-roll tripod !
21
alpha
alpha
100 Years
Quality
Under the top
lid is a compartment
for memory
cards, fixable
with velcro,
underside
with display
protecting
lining
The gel-carrying strap and the
shoulder strap ensure a comfortable
wearing.
Soft protecting inside divider at
2403, 2404, 2405+2406
A lpha presents itself in a sportive design
with yellow „Rallye-stripe“.
Special advantage: The bags can be opened
from the body away, so that an easy access
is possible. The outer material is made of the
water-resistant 1680 D Polyester. With the exception of the models 2401 and 2402 all bags
are provided with feet paths.
2 velcro pads
for SLR-camera,
only for 2401
and 2402
Alpha 60
Art.No 2406
A
dditional bags at
the front, at the back
and on the sides offer
further more space for
the photo equipment.
Alpha 20
Art.No 2402
Ergonomically formed anti-slide
at the anti-twisting carrying strap
Under top lid
zipper-front
pocket with
compartments
for filter and
mesh pocket
for small parts,
at 2404, 2405
and 2406
Back
compartment
for manuals,
contains the
included
rain cape
22
Mesh pockets on the
side, for small parts,
tripod or drinking bottle.
Rain cape
Alpha
Art.No
Inner size
(w / d / h ) cm
Weight
g
Inside
dividers
Filter
compartments
in front bag
Front compartment
To open away
from the body
Storage space for:*
Alpha 10
2401
13,5 x 10 x 15
310
-
1

D-SLR, mobile, 2 MC
Alpha 20
2402
15 x 11,5 x 18
370
-
1

D-SLR, mobile, 2 MC
Alpha 30
2403
14,5 x 10,5 x 14
350
1
1

D-SLR, mobile, 2 MC
Alpha 40
2404
17,5 x 10,5 x 17,5
470
2
2

D-SLR, lens, flash, mobile, 3 MC
Alpha 50
2405
21 x 11 x 17,5
520
5
2

D-SLR, lens, flash, mobile, 3 MC
Alpha 60
2406
25 x 16 x 19
790
5
2

D-SLR, 2 lenses, flash, mobile, 4 MC
* D-SLR = single lens reflex camera, MC = memory card
23
Digi star
digi Star
100 Years
Quality
DigiStar
Midi
Art.No 4066
Digi Star presents itself in classical elegance, always appealing, espe-
cially when the protection and comfort of the equipment benefit. The bags
offer a padding for protection and storage space for cameras, lenses and
flashes. Naturally there is also space for small parts and other accessories.
Especially practical is that all bags can be opened away from the body.
DigiStar
Maxi
Art.No 4068
DigiStar Standard
Art.No 4072
This bag line offers a
DigiStar
Reflex
Art.No 4069
lot of practical details:
a belt-loop at the back,
zipper- and mesh
pockets, removable
shoulder straps, inside
dividers (except reflexmodels) as well as a
front compartment with
mesh pocket.
DigiStar
Compact
Art.No 4070
24
25
Promo Line
digi Star
100 Years
Quality
The bags of the Promo Line are practical and low-priced.
Solid
Quality
The models Standard and Compact are equipped with a
removable shoulder strap with slide protection, feet paths and
inside dividers. The Promo Swing backpack has a diagonal
strap, a safety belt, inside dividers and double-zipper. The
Reflex Promo is extremely lightweight and compact and also
has a double zipper.
Top-PricePerformance
Ratio
Promo
Standard
Art.No 287-90
DigiStar
XL
Promo
Swing
Art.No 4073
Art.No
288-90
Backpack top case
(max. w/d/h
16 x 12 x 14 cm)
with mesh pocket
Promo
Compact
Art.No 286-90
Reflex
Promo
Art.No 285-90
Art.
No
Inner size
(w / d / h ) cm
Weight
g
Inside
dividers
Front compartment with
mesh pocket
To open
away from
the body
Midi
4066
11 x 6 x 10
200
1


Video camera or Digital camera + 2 MC
Bridge S
4077
11 x 8,5 x 13
200
1


Bridge camera, accessory, MC
DigiStar
Storage space for:*
Bridge
4067
13 x 10 x 11
280
1


Video camera or Digital camera.+ lens, mobile, 2 MC
Reflex S
4079
13,5 x 8,5 x 13,5
240
-


System camera, accessory, MC
Reflex
4069
16 x 12 x 16
300
-


D-SLR, 2 MC
Maxi
4068
16 x 7 x 12
280
1


Video camera or Digital camera + mobile, 2 MC
Compact S
4080
20 x 9,5 x 13,5
380
2


System Camera, 2 lenses, flash, MC
Compact
4070
21 x 12 x 15
420
3


D-SLR, 2 lenses, flash, mobile, 3 MC
Standard
4072
28 x 13 x 16
640
3


Digital cam., D-SLR, 3 lenses, flash, mobile, 4 MC
XL
4073
38 x 18 x 16
1400
4


Bridge cam./Syst.cam., D-SLR, lens, flash, mobile, 4 MC
* D-SLR = single lens reflex camera, MC = memory card
26
Promo
Art.No.
Inner size main case
(w / d / h ) cm
Inner size front bag
(w/ d/ h ) cm
Weight
g
Inside
dividers
Storage space for:*
Reflex
285-90
14 x 9 x 16
-
140
-
D-SLR
Compact
286-90
20 x 12 x 15
19 x 1 x 11
285
1
D-SLR, mobile, 2 MC
Standard
287-90
26 x 12 x 15
25 x 1 x 11
400
4
D-SLR, lens, flash, 3 MC
Swing
288-90
24 x 16 x 12
13 x 3 x 14
600
3
Digital camera, D-SLR, 2 lenses, flash, mobile, 2 MC
* D-SLR = single lens reflex camera, MC = memory card
27
Reflex Profi Line
Reflex Profi Line
Reflex Profi Line 100
Art.No 4101
100 Years
Quality
The Reflex Profi Line is a premium bag line with
Premium
Quality
excellent features. The breathable cushion at the back
provides a superb wearing comfort and also serves as
belt tunnel. Further features are a pelvic restraint belt,
loops for accessory-bags (optional), diverse front compartments and a rain cape.
TopEquipment
Top-PricePerformance
Ratio
Loops for
accessory-bags
(optional)
Handle
Top lid compartment for memory
cards
Mesh pocket
under top lid
Reflex Profi Line 400
Art.No 4104
Reflex
Profi Line
100
Reflex Profi Line 300
Art.No 4103
Rain cape
Art.No
Inner size
(w / d / h ) cm
Weight
g
Inside
dividers
Front
compartment
To open away
from the body
4101
16 x 12 x 16
580
2
2

Storage space for:*
D-SLR or Profi D-SLR, mobile, 2 MC
200
4102
17 x 15 x 22
670
2
3

Profi D-SLR, lens, mobile, 2 MC
300
4103
17 x 15 x 28
760
2
3

Profi D-SLR, lens, mobile, 2 MC
400
4104
20 x 17 x 35
930
2
3

Profi D-SLR, lens, mobile, 2 MC
* D-SLR=single lens reflex camera, MC=memory card
Breathable cushion at the back,
belt tunnel
Diverse front compartments
with mesh pockets
Innver view
28
Wearing comfort by
pelvic restraint belt
29
College Bag line
College Bag Line
100 Years
Quality
College Bag
Bachelor
Art.No 4203
The following additional compartments have been provided: In the
While producing this bag line the creatives attached great importance
lid you find a compact zippered pocket that offers space for important small accessories. A large compartment in the front provide
organizer sections and there is also a flat compartment on the back.
The bags have got a handle and the wide shoulder strap with removable slide protection offers a special wearing comfort. A widely
overlapping cover, a velcro point and a circlip protect the valuable
content. Especially handy is the quick access to the equipment by a
dust-proof double zipper.
to a „Non-photo-Specific Design“. In addition these bags offer an affordable
carrying solution for the entire photographic equipment including netbook
or laptop and accessories. The removable inside dividers ensure an universal useability in free time.
College Bag
Master
Art.No 4205
College Bag
Exam
The adjustable inside dividers
are made of a soft material that
protects the camera equipment
against impacts.
The compartment nearby the
body is equipped for a 11“
netbook (Exam), for a 15“ minilaptop (Bachelor) or a max. 17“
laptop (Master).
Art.No 4201
College
Bag Line
Art.
No
Inner size
(w / d / h ) cm
Weight
g
Inside
dividers
Front
compartment
Laptop-Case
padded
Storage space for:*
Exam
4201
30-35 x 8-13 x 10
800
7

for 11“/max. 27 cm
2 D-SLR, 3 lens + accessory
Bachelor
4203
35-45 x 10-14 x 28
1100
8

for 15“/max. 37 cm
2 D-SLR., 4 lens, flash + accessory
Master
4205
44-45 x 11-15 x 31
1300
9

for 17“/max. 45 cm
3 D-SLR, 4 lens, flash + accessory
* D-SLR=single lens reflex camera
30
31
Transporter
Alu Cases
100 Years
Quality
Alu Cases Art.No 545 and 546
- protected metal edges
- locks with key
- handle
- dust protection between
top lid and body
- metal hinges
- foam inlay in cubes to form
any requested insert
- additional variable dividers
- plastic feet sideways
on the underpart
ArtNo
Outer size
w / d / h cm
Inner size
w / d / h cm
Weight
Storage space for *
545
32 x 25 x 15
30 x 23 x 14
1700 g
DSL-R, 2 lenses, flash
546
46 x 33 x 15
44 x 31 x 14
2400 g
Two Colours
Three Sizes
These sturdy cases are waterproof,
shockproof and dustproof. They are
made of a lightweight but strong material. The ergonomically designed handle
provides a comfortable transport. A
pressure compensation can be made
with the built-in valve.
DSL-R, 3 lenses, flash
* D-SLR=single lens reflex camera
Luxury
Alu Case Art.No 548
Inner size:
Outer size:
Weight:
Storage space for:
546
w/d/h 38/23/16 cm
w/d/h 40/28/19 cm
2,5 kg
DSL-R, 3 lenses, flash
D-SLR=single lens reflex camera
545
The foam paddings can be precisely cutted to your needs.
Transporter
XS
Colour
Art.No
Outer size
w/d/h cm
Inner size
w/d/h cm
kg
Storage space for*
black/yellow
550-1
33 x 12 x 28
29,5 x 8,5 x 21,5
1,5
D-SLR, 2 lenses + accessory
XS
yellow/black
550-3
33 x 12 x 28
29,5 x 8,5 x 21,5
1,5
D-SLR, 2 lenses + accessory
M
black/yellow
553-1
43 x 16 x 38
39 x 11 x 31,5
2,9
2 D-SLR, 2 lenses + accessory
M
yellow/black
553-3
43 x 16 x 38
39 x 11 x 31,5
2,9
2 D-SLR, 2 lenses + accessory
Equipment:
XL
black/yellow
556-1
51 x 20 x 41
48 x 18 x 35
4,2
3 D-SLR, 2 lens., flash + accessory
- High quality materials
- Metal hinges and chromium fittings
- Foam inlay in cubes
- variable dividers
- feet on 2 sides
- removable shoulder strap
XL
yellow/black
556-3
51 x 20 x 41
48 x 18 x 35
4,2
3 D-SLR, 2 lens., flash + accessory
Luxury Equipment-Case
Art.No 549
Inner size top:
w/d/h: 2 cases per 48 x 10 x 9,5 cm
Inner size bottom: w/d/h: 1 case
48 x 22 x 17 cm
Outer size:
w/d/h: 50 x 25 x 31 cm
Weight:
5 kg
Storage space for: DSL-R, Pofi-DSLR, 4 lenses and flash
* D-SLR=single lens reflex camera
Inclusive
• 2 waved foam inserts
• 2 pre-cut cube foam paddings
• o-ring
Transporter M
Art.No 553-1
Transporter XL
Art.No 556-3
D-SLR=single lens reflex camera
Equipment:
- two-storey
- chromium fittings
- lockable
- metal hinges
- robust carry handle
- robust feet
- variable dividers
32
33
100 Years
Up to date
Bags for Digicams
Quality
Jeans Bags - highly topical
Style - in large colour selection
Jeans are timeless - for young and old. Two sizes
with zip around are available in 3 trendy designs.
There are three different wearing options: You can
hang it round your neck with the shoulder strap.
For fixing the bag at your trousers you can use the
belt-loop on its back or the karabiner ring.
A mesh pocket provides space for accessories
and a velcro security for the camera-carryingloop protects the bag against loss.
The „Style“ bags are not only stylish, but
also practical. A soft cushioning protects the
camera inside and small accessories find
room in a mesh compartment.
There are three different wearing options:
You can hang it round your neck with the
shoulder strap. For fixing the bag at your
trousers you can use the belt-loop on its
back or the karabiner ring.
- 1 black
Digital camera bags can of course also be used
for mobile, i-phone or MP3 player.
Art.No
Colour
2370-1
black
Inner sizes
Model
Art.No
Colour
Style I
2370-2
blue
Jeans I
2350-1
black
Style I
2370-3
grey
Jeans I
2350-2
blue
Style I
2370-5
olive
Jeans I
2350-3
grey
Style I
2370-6
sand
Jeans II
2351-1
black
Style I
2370-8
red
Jeans II
2351-2
blue
Style I
2370-9
purple
Jeans II
2351-3
grey
Style I
2370-10
pink
Style I
2370-20
light green
Style I
2370-21
yellow
- 2 blue
- 3 grey
Cotton Bags - just cool
w / d/ h cm
7 x 3 x 10
- 5 olive
Inner sizes
Model
Art.No
Colour
w / d/ h cm
10 x 3 x 7
Cotton
2360-1
black
Cotton
2360-2
blue
Cotton
2360-3
grey
Cotton
2360-5
green
Cotton
2360-8
red
- 8 red
- 10 pink
34
Model
Style I
w/ d/ h cm
6 x 2,5 x 9,5
w/ d/ h cm
7 x 3 x 10
Cotton bags look pretty cool. They present themselves in soft, supple fabric and fancy creation.
Five colours to choose from.
The bags are lockable by a velcro-closure on the
front and they are portable by using the belt-loop
on the back. The Cotton Bags find easily room in a
handbag.
Inner sizes
w / d/ h cm
6 x 2,5 x 9,5
- 6 sand
Style I
2370-22
light blue
Style II
2371-1
black
Style II
2371-2
blue
Style II
2371-3
grey
Style II
2371-5
olive
Style II
2371-6
sand
Style II
2371-8
red
Style II
2371-9
purple
Style II
2371-10
pink
Style II
2371-20
light green
Style II
2371-21
yellow
Style II
2371-22
light blue
- 9 purple
- 20 light green
- 21 yellow
- 22 light blue
35
100 Years
Up to date
Bags for Digicams
Quality
Poppy Bags - in Flower Design
Shell Bags - Maximum Protection
Our Poppy Bags are available in many trendy colours. The interior cushioning is marvellous soft. The bags are
lockable with a velcro. A front compartment with zipper provides room for accessories. The Poppy bags are portable
by a belt loop on the back as well as by using the carrying strap included in delivery.
Poppy Bag
- 1 black
- 2 blue
- 3 grey
- 5 olive
Art.No
w/d/h inner size
2380 - add the
colour number
6,5 x 2,5 x 13 cm
A special hard-shell material
protects the camera from the outside. And a new shock-resistant
inner upholstery absorbs extreme
loading.
- 6 sand
- 1 black
- 8 red
- 9 purple
Shell Bags
Foam-upholstery
on both sides
- 10 pink
- 20 light green
- 21 yellow
- 6 sand
- 7 orange
- 22 grey
- 23 purple
- 8 red
Hard shell - soft core
Quick-Clip
shoulder strap
Strong belt loop
The equipment
includes furthermore a memory
card compartment
inside, a strap
and a belt loop.
- 10 pink
- 20 lime
- 30 metallic grey
- 21turquoise
- 31 metallic choco
- 40 flower black
- 24 choco
- 41 flower blue
SHELL Bag
Model
Art.No
w/d/h inner size
Shell Bag IV
363 - add colour number
5,5 x 2 x 9,5 cm
Shell Bag I
360 - add colour number
6 x 2,5 x 9 cm
Shell Bag II
361 - add colour number
7 x 3 x 10 cm
Shell Bag III
362 - add colour number
8 x 4 x 11 cm
- 50 strukture carbon
36
- 5 olive
22 light blue
Shock Proof
Velcro memory
card pocket
- 2 petrol
- 51 structure black
- 52 structure blue
- 53 structure silver
37
Up to date
Bags for Digicams
Fashion Bag
Starting trends, proving style!
Quality
Digi Cam Bags
You can choose between
three different sizes and six
different colours - suitable
for every taste and outfit.
practical and timeless
Memory card
pocket with
velcro, variably
fixable within the
bag
01 Nano L
Art.No 2301
Incl. belt loop,
shoulder strap,
front compartment!
Inner size
cm
model
Art.No
w/d/h
6x2x9
Fashion Bag Nano L
2341-1
w/d/h
6 x 2,5 x 10
w/d/h
7 x 3,5 x 9
Colours
black
Fashion Bag Nano L
2341-2
blue
Fashion Bag Nano L
2341-6
light grey
Fashion Bag Nano L
2341-7
orange
Fashion Bag Nano L
2341-8
red
Fashion Bag Nano L
2341-9
violet
Fashion Bag Micro S
2342-1
black
Fashion Bag Micro S
2342-2
blue
Fashion Bag Micro S
2342-6
light grey
Fashion Bag Micro S
2342-7
orange
Fashion Bag Micro S
2342-8
red
Fashion Bag Micro S
2342-9
violet
Fashion Bag Small
2343-1
black
Fashion Bag Small
2343-2
blue
Fashion Bag Small
2343-6
light grey
Fashion Bag Small
2343-7
orange
Fashion Bag Small
2343-8
red
Fashion Bag Small
2343-9
violet
100 Years
The little front compartment
for battery or memory card
offers an easy access from
the outside. Because it is
smartly placed behind the
frontage it wonderfully matches with the elegant style of
the bag.
The attractive design draws
the attention. The bag is
portable at the belt by using
the loop on the back. Or you
hang it round your neck with
the accompanying shoulder
strap.
Special highlight: This clever
zipper-solution offers the possibility to carry the digicam only
at the camera-hand-strap.
02 Micro S
Art.No 2302
03 Small
Art.No 2303
Inner size
w / d / h cm
Model
Art.No
6x2x9
01 Nano L
2301
6 x 2,5 x 10
02 Micro S
2302
7x4x9
03 Small
2303
Inner size
w / d / h cm
Model
Art.No
6x2x9
11 Nano L
2311
6 x 2,5 x 10
12 Micro S
2312
7x4x9
13 Small
2313
Digi Cam Bags
the stylish design
Memory card
pocket with
velcro, variably
fixable within the
bag
11 Nano L
Art.No 2311
12 Micro S
Art.No 2312
13 Small
Art.No 2313
Luxury Leather Cases
with Double-Magnetic Lock
1. High quality real leather
2. Hidden double-magnetic lock
3. Soft inner material
4. Loop safety locker
5. Inner memory card case
Digital-B format horizontal
Our product
range is
constantly
adjusted to the
existing camera models.
Inner size
w / d / h cm
Art.No
9x2x6
341
9 x 3,5 x 6
342
9,5 x 2 x 6
344
9,5 x 3 x 6,5
345
9,5 x 4 x 6,5
346
10 x 4 x 6,5
343
10,5 x 3 x 6,5
350
11 x 3 x 6
351
The bags are
made of high
grade leather.
Feel pure
luxury.
38
39
Backpacks
All Season Adventure
100 Years
Quality
Backpack 1
Backpack 3
Backpack 1 and 2 are
Art.No 320-R
320-R
320-R
equipped with a tripod- and back
carrying system consisting of an
adjustable shoulder strap as well
as a chest- and pelvic strap.
This multifunctional de luxe
model with its additional front
bag and its double zippers
offers many practical details and
highlights.
There are additionally straps for
stabilisation on the side.
The breathable back cushion is
ergonomically formed. A laptop
case with zipper is in the back.
In addition both backpacks are
equipped with a sewed on rain
cape, two front bags as well as
further accessory- and organizer
compartments.
The front bag is removable and
can separately be used as
backpack.The tripod carrying
system on the side is equipped
with a removable foot-bag, adjustable loop and elastic band.
Tripodcarrying system
on the side
Art.No 321-R
Additional front bag
with back carrying- and
pelvic strap
Size (w x d x h):
ca. 25-30 x 5-7 x 45 cm
The top lid has three transparent
zipper compartments. A laptop
case with zipper and a practical
holder for sleeping back, clothes
etc. also belong to the extensive
equipment. The back cushion is
formed all over and breathable.
320-R
321-R
320-R
The 320-R has a tripod carrying
system on the side with foot-bag
and adjustable loop. Double
zipper, twelve adjustable inside
dividers and a mobile bag complete the equipment.
Backpack 2
Ready for all excursions:
Art.No 322-R
15 big
adjustable
dividers and
additional
cushions
The back carrying system is
characterized by an adjustable
shoulder strap with chest- und
pelvic strap as well as pelvic
cushions with loops.
321-R
321-R
Pelvic cushion on the side,
ca. 12 x 19 cm, with loops
The 321-R has a special tripod
carrying system on the front as
well as loops on the side for
accessory bags.
The integrated rain cape protects
the valuable camera equipment
all-weather.
321-R
All Season
Adventure
Art.No.
Outer size
(w / d / h ) cm
Inner photo bag
(w / d / h ) cm
Laptop-Case
(w / d / h ) cm
Weight
g
Storage space for:*
Backpack 1
320-R
34 x 26 x 59
32 x 18 x 53
29 x 2,5 x 44
3200
Large-Format or 2 Profi D-SLR + 4 lenses, flash, mobile, 3 MC, Laptop
Backpack 2
321-R
38 x 24 x 54
35 x 14 x 47
33 x 2,5 x 44
3800
2 D-SLR, 4 lenses, flash, 3 MC, Laptop
Backpack 3
322-R
35 x 30 x 52
31 x 16 x 48
29 x 2,5 x 42
4600
Large-Format or D-SLR, Profi D-SLR + 4 lenses, flash, 4 MC, Laptop
* D-SLR=single lens reflex camera, MC=memory card
40
41
100 Years
Backpacks
All Season Adventure
Quality
Multi-Snap Pack 10
Multi-Snap Pack 30
Art.No 324-R
Art.No 325-R
Multi-Snap Pack 10 and
Swing Snap
Take hold: quick, easy and safe:
Art.No 326-R
Swing the backpack in front of the
body, one grip into the bag and
you have the camera ready. For
this mechanism to function properly, the „Swing-snap“ is equipped
30 are robust backpacks with
access from three sides and
with a tripod- and back carrying
system.
The back cushion is breathable and
ergonomically formed. It also serves as
storage for the belt system - practical for
the transportation on journey.
Optimal access from
three sides
In addition they are equipped
with safety locks, accessory
compartment, rain cape and
dust-tight zipper. In the top lid
of the top case, picture above
right, there are compartments
for memory cards and mesh
pockets. The back carrying
system consists of an adjustable double-shoulder strap with
chest- and pelvic strap. A tripod
can be transported on the front secured by a foot pocket and an
adjustable loop.
The two models differ only in the
size and the number of memory
card slots and internal dividers,
see table below right.
321-R
324-R
camera equipment organized by 4 inside dividers,
protected by a soft inner
padding
Wearing comfort
by climateupholstery back
with a stable diagonal strap as well
as an safety- and stabilisation belt.
The shoulder strap ist ergonomically formed – for superior wearing
comfort. The photographer will
also appreciate the climate-upholstery at the back. The main camera
case has four inside dividers and
two mesh pockets in the top lid.
The access to this case is secured
with quick clips. The front case
(size: 15 x 2 x 16 cm) with mesh
pocket serves for the storage of
further accessory. Even a mobile
phone pocket is integrated.
Main part cover
with partialor full access,
secured
with quick-clips
Swing in front of
the body possible
for right- and lefthander because
of the two-sided
access
Das wasserabweisende OberMaterial, die Soft-Innenverkleidung
sowie
ein Staub-und Regencape
mobile phone pocket
schützen die wertvolle Ausrüstung.
All Season
Adventure
Art.No
Outer Size
(w / d / h ) cm
Main Case
(w / d / h ) cm
Top Case
(w / d / h ) cm
Weight
g
Safety- and
stabilisation
belt for
higher
wearing
comfort
Inside
dividers
Storage space for:*
Multi-Snap Pack 10
324-R
27 x 22 x 44
25 x 16 x 25
22 x 16 x 15
1280
4
Profi D-SLR, 2 lenses, flash, mobile, 3 MC
Multi-Snap Pack 30
325-R
37 x 22 x 47
35 x 16 x 29
30 x 16 x 15
1780
10
Profi D-SLR, 3 lenses, flash, mobile, 5 MC
Swing Snap
326-R
25 x 21 x 42
23 x 14 x 26
23 x 14 x 16
800
4
D-SLR, 2 lenses, flash, mobile, 1 MC
* D-SLR=single lens reflex camera, MC=memory card
42
43
GPI
rechargeable Batteries
Chargers
100 Years
and Batteries
Quality
Our batteries keep the quality,
that they promise...
Memory space is becoming cheaper and more souvenir pictures are becoming increasingly popular. So
much the worse if the energy runs dry in the most beautiful moments and half of the wedding goes by
without photos, if the holiday in the album ends after a few days or the first words and steps of the little
darling can not be recorded. Shall all memories be recorded safely, then a second battery is absolutely
necessary. Having the second battery in your pocket, means security. And security for our GPI batteries
is for us the highest precept as well.
Premium-Quality
GPI batteries are produced
by one of the world‘s largest
manufacturer of rechargeable
camera batteries. He ensures
consistently high production
quality corresponding to his
ISO 9001-2000 quality management. Intensive monitoring of production, running
tests during the production
process and final safety tests
guarantee this certification
standard.
Li-ION !
Canon
Casio
Contax
Fuji
Kodak
Konica
Kyocera
Medion
Minolta
Minox
Nikon
Olympus
Praktica
Panasonic
Pentax
Ricoh
Rollei
Samsung
Sanyo
Sony
Voigtländer
Super Fast Charger
Eco Charger
Art.No 572
Art.No 589-25 N
Fast-Charging:
2 compartments max. 700 mA,
incl.4 precharged „Ready to use“
NiMH-batteries 1,2 V 2.100 mAh, AA
incl. power plug 220 V and
car adapter 12 V
charges simultaneously 2 or 4
batteries AA / AAA in up to 3 hours
• Charging control indicator
• Automatic trickle charge switch
(-Delta V)
• Reverse voltage protection
• Safety cut off
• Defective-, unchargeable battery
short-circuit-proof
Compact Plug in model
for 230 V
incl. 4 NiMH-batteries
1,2 V 2500 mAh, AA
•
•
•
•
charges simultaneously
2 or 4 batteries AA/AAA
with max. 200 mA
Charging control indicator
Reverse voltage protection
Defective-, unchargeable
battery short-circuit-proof
LCD Li-ION Multi-Charger
Art.No 592-M
Compact universal charger for almost all Li-Ionen-batteries
as for mobile phone batteries.
•
•
•
•
•
•
•
With power cable 100-240 Volt for worldwide use
Charges with 400 resp. 800 mA
Car adapter 12 V
Additional USB port for charging of 3,7 V batteries on
netbook/notebook
Illuminated LCD-display as charging control indicator,
automatic trickle charge switch, reverse voltage protection, safety cut off, defective-, unchargeable battery
short-circuit-proof
3 x energy-port
Gilded contact pins, memory card storage
Adjustable telescopic contact
pins allow an easy insertion
and a flexible adaptation to the
different batteries.
The equipment also include
a memory card slot.
Directpower
batteries are already precharged
and useable at once.
The capacity keeps considerably
longer compared with Ni-MH
rechargeable batteries, also for
all further charging.
Art.No
Directpower
Recharg.
batteries
model
AA
mAh
578
yes
4 pcs.
1,2 V
2100
579
yes
2 pcs.
1,2 V
2100
595
no
4 pcs.
1,2 V
2700
We register the placing of our electrical and electronic products
on the market at the ElektroAltgeräteRegister, EAR ( Reg.No
DE-53999944 ).
This symbol on products, packings and/or accompanying documents means, that used electrical/electronic products should
not be disposed of in normal houshold waste. Please bring old,
unused or defective products for disposal, conditioning and
recycling to your local collection center. As these waste products
are properly recycled, you save valuable resources and prevent
adverse effects on human health and the environment.
44
We register the placing of our accumulators and batteries on
the market at the Federal Environment Agency. This symbol on
accumulators and batteries means, that used accumulators and
batteries should not be disposed of in normal houshold waste.
Please bring old, unused or defective accumulators and batteries
for disposal, conditioning and recycling to your local collection
center or put them in the provided accumulation bin at your
dealer. As these waste products are properly recycled, you save
valuable resources and prevent adverse effects on human health
and the environment.
45
100 Years
Cleaning
Quality
Microfiber
Cleaning Cloth
One by one packed in an
attractive hard box
Art.No 199
35 pcs. in
display box
Lenspen Sensorklear Loupe
with illumination, incl. 3 batt. AG 5
Art.No 212
- Excellent cleaning results
- Washable and therefore repeatedly usable
- Size of cloth about 16 x 18 cm
- in display box (35 pcs)
Lenspen
Hurricane Blower
5 in 1
46
The only
sensor-loupe
with sight check
Best choice for Sensor-Cleaning
- removes dust like a hurricane
- for lenses, mirrors, filters and
- best for CCD-sensors
- double valve-design
- prevents breathing in dust
- fits into camera bag
Art.No 216
Art.No 200
For
spotless
beautiful
photos
- High Quality - sixfold magnification
- with 4 LongLife LEDs for best illumination
- fully adjustable for SLR or FourThirds systems
- easy handling and affixing
- fits nearly in each camera bag
Cloths in
blue and red
sorted
CleanKit
It works - It‘s easy to use - It‘s faster!
Widely used by manufacturer, service centers
and professionals!
Offers all accessories to clean the surfaces
of camera, lens and further equipment
1. Blower brush to remove loose dust
2. Lenses-cleaning paper
(25 sheets tear-away-booklet)
3. Optical cleaning fluid for
use with cleaning paper
4. Cotton swabs for heavily
accessible places (5 pcs.)
5. Soft cleaning tissue for camera
and accessory surface
Lenspen
Sensorklear II
Art.No 213
Sensor-Cleaning-Pen
Sensorklear bendable
for optimal handling
Lenspen
micro PRO
Art.No 215
Makes lens-cleaning easy
on ultra-compact-cameras !
Tiny Lens Cleaner
with retractable brush
- safe for all lenses
- patented dry carbon
compound
- best cleaning device
- easy handling
- fits into camera bags
- unique self-replenishing tip
47
special-Accessory
100 Years
Quality
Light Shade Mini
Art.No
Colour
inch
LSM-20
silver
2,0“
LSM-25
silver
2,5“
LSM-25b
black
2,5“
LSM-28
silver
2,8“
LSM-28b
black
2,8“
LSM-30
silver
3,0“
Light Shades offer
- a non-reflecting view on your display
(without incidence of light) and
- therefore a reliable evaluation and
correction of the motive with better
photo results
- ideal protection for your display by
integrated acryl-panel
For slipping on the standard camera
hot shoe
Art.No 115
Art.No 115 S
For slipping
on the standard camera
hot shoe
3D Art.No 117
2D Art.No116
Art.No 115 B
For slipping
on the standard camera
hot shoe,
with bubble
level
for 4 SD memory cards,
with key chain
6,5 x 2 x 6 cm, 40 g
For slipping on
the Sony
camera
hot shoe
For slipping
on the Sony
camera hot
shoe,
We also distribute the following brands:
Do not hesitate to ask for further information.
Art.No 115 BS
with bubble
level
SD Card Organizer
Art.No 160, for 10 pcs.
The ideal storage solution for
your SD memory cards including
inscribable memo field for noting
date and content.
USB Card Reader 1
USB Card Reader 2
Art.No 150
Art.No 151
USB Card Reader 3
with 3 Port Hub
incl. extension cord
incl. extension cord
Art.No 152
incl. extension cord
48
Art.No SR-1
Special air cushion cells guarantee a particularly high level wearing comfort. It is easily
to open by a snap lock and useable as a hand strap.
Our Luxury-Wrist Strap guarantees a carrying of the camera
without difficulty. Important camera functions can be used
one-handed. So the handling improves considerably.
The hand strap is suitable for all single-lens reflex cameras,
digital-single-lens reflex cameras and Bridge-cameras.
Hot Shoe-Coverings
Art.No 165
Air Cell Camera Strap
The wrist strap GR-A has
an additional safety device
available at the wrist.
Bubble levels
Plastic
SD Card Safe
For top wearing comfort !
Camera Wrist Strap
Luxury for SLR/DSLR
Art.No GR-A
The Light Shade Mini has to be
glued on, but it is still removable.
True for Art.150-152:
* Support USB 2.0
High Speed and are
downward compatible
to USB 1.1
* Read and write access
for 35 formats
* Plug and Play Installation
* Electric power supply
by USB
* Support Win 2000, XP
and Win 7,
Mac OSv9.x or
higher as well as
Linux 2,42 or higher
* Support all versions of
SD-, CF-, MMC-, MSand XD-cards
49
Flashguns
and Light
Studio-Flash
100 Years
Quality
Improving your photos by Ring Flashes ...
Canon
Test report - Reference
D 140 RF-C
Digital-Ring Flash
Art.No 122-C
for Canon E-TTL (2)
•
•
•
•
•
•
•
•
guide number: 14m/46ft at 100 ISO
automatic E-TTL (2) / i-TTL flash exposure control*
IGBT fast recycling circuitry
second curtain synchronisation*
flash exposure compensation control*
red eye reduction flash*
multiple mounting threads (Ø M52,M55,M58,M67)
suitable for macro-, scientific-, medicalor hobby photography
*camera body dependent features
Nikon
D 140 RF-N
Digital-Ring Flash
Art.No 122-N
for Nikon i-TTL
Which camera
suits to which
flash, please see
www.bilora.de
Studio Flash-Set
Sirius B 120 Art.No 135
Sirius B 160 Art.No 136
• 2 x Sirius B 120 / B 160 flash heads
à 120 Ws / 160 Ws power
• 2 x stands 190 cm
• 2 x umbrella boxes 80 cm incl. case
• 2 x power cable 3 m
• 2 x syncro cable 3 m
• 2 x halogen lamp max.220V/75W
for modelling light
• 1 x case (incl. storage space for
further accessory)
Sony
D 140 RF-S
Digital-Ring Flash
Art.No 122-S
for Sony TTL
Conical Snoot
with honeycomb
Art.No 126-LED
ca. 90° vertical
ca. 180° horizontal
Art.No 1363*
The LED lamp is a
perfect complement to the
video recording, whether
with D-SLR cameras or
video cameras.The big
advantages over other
light sources are the light
weight, the compact
dimensions, the constant
light color and the low
energy consumption - in
complete soundlessness.
Softbox 60 x 60 cm Art.No 1360
for self-assembly / foldable
create a narrow lustre cone and
thus a highly concentrated and
directional light - ideal for portrait- and product-photographie.
Can be used with or without
honeycombs.
*not useable with modelling light
A softbox produces a soft, evenly spread
and low-shadow light. Ideal for portrait- and
product-photographie.
• colour temperature 5300-5900 K°
• light ON time with new
alkaline batteries ca. 1 hr.
• Continuously light output
30 - 800 Lux/60cm
• 210 g, w x d x h: 14 x 4 x 8,9 cm
without foot
50
- servo-release integrated
- power range 1/1-1/8
- modelling light connectable
- sync-port 3,5 mm
- fuse/spare fuse
- test release
- optical flash ready
- acoustical flash ready
- recycle time 0,5 - 2 sec.
- 9,5 cm accessory-port
incl. powerpack for 4
pcs. AA batteries
and 4 adapter rings
LED Lamp
LED-lamp with 126 LEDs, combinable,
dimmable, battery-, rechargeable battery- and
power supply operation (delivery incl. mains
adapter, without batteries and rechargeable
batteries).
- umbrella stand
- swivel-type for spigot/
lighting tripod
Article
No
Product description
Sirius B 120 Set
135
compl. studio-flash-set, 2x 120 Ws
Sirius B 160 Set
136
compl. studio-flash-set, 2x 160 Ws
Softbox 60x60cm, 9,5
1360
foldable soft light solution in studio
Barn Door 9,5
1362
lighting with honeycomb
Conical Snoot 9,5
1363
spot-lighting with honeycomb
Spare syncro cable
1361
3,5 mm plug / PC-camera plug, 3 m
Modelling Lamp
1365
halogen lamp 220V / 50 Watt
Flash Tube
1364
spare flash tube for Sirius 120 / 160
Barn Door Set
with honeycomb (removable)
Art.No 1362*
Very practical to limit the
spread of light. Ideal for
portrait- und productphotographie.
*not useable with modelling light
51
Remote control
Remote Control
100 Years
Quality
Benefit of a remote control
The camera is mounted on a tripod and the release takes
place without touching the camera. This offers the
following advantages:
•
•
There is no impact to the camera. Thus, rigid shots
become possible even with long exposure time.
A remote control allows a distance of up to 100 m.
FB1:
Wireless Remote Control
operates in FSK 2,4 GHz band.
It offers
1. the wireless release of cameras
about a distance of max. 100 m
(without walls)
2. the wireless synchronization of
speed-lights (hot shoe)
3. the wireless synchronization
of studio-flashes (3,5 or
6,3 mm phone plug)
You can choose between 16 channels
and the receiver also serves as
shutter-release cable.
•
•
•
•
Please inform yourself about our current camera compatibilities on our website at www.bilora.de.
A free choice of delay time enables the photographer to join
the scene, even at greater distance from motif to camera.
Observation of production processes
A timer function offers a special kind of shots.
Documentation of slow movement sequences.
Examples: The opening of a flower can be recorded in fast
motion. The route of the sun or of the moon across the sky
can be reduced to minutes.
FB 3:
FB 2:
Wireless Timer Remote Control
operates in FSK 2,4 GHz band.
It offers
1. the wireless release of cameras
about a distance of max. 100 m
(without walls)
2. Delay time of 1 sec up to
99 hours - 99 min - 99 sec
3. Exposure time of 1 sec up to
99 hours - 99 min - 99 sec
4. Interval time of 1 sec up to
99 hours - 99 min - 99 sec
5. Number of shots from 1 to 399
You can choose between 16 channels
and the receiver also serves as shutterrelease cable.
Wireless Remote Control
operates in 433 MHz band.
It
1. offers the wireless release of
cameras about a distance of
max. 100 m (without walls)
2. works in preset single frameor serial shooting
3. operates with a time delay
of 3 sec
4. can be used in long-term
mode
You can choose between 16 channels and the receiver also serves as
shutter-release cable.
Art.No
FB1-C1
FB2-C1
FB3-C1
FB4-C1
FB5-C1
CANON Powershot G10/G12, CANON EOS 1100D/1000D/600D/60D/550D/500D/450D/400D/ 350D/300D
300/300V/50E/50/33/30, Pentax K10D/K110D/K100D/K20D/K200D/KM /Cs205 Remote Switch Shutter/*ist D/DS/DS2/DL/DL2/
K10/MZ-6, MZ-L, ZX-L Hasselblad H/H1/H2/H2D/H1D Contax 645/Nl/Nx/N/Digital/LA-50, Samsung GX-20 GX-10
GX-1L GX-1S etc.
Art.No
FB1-C3
FB2-C3
FB3-C3
FB4-C3
FB5-C3
Canon EOS Digital SLR, EOS 1D, 1D Mark II / 1D Mark II N / 1D Mark III / 1Ds/ 1Ds Mark II /1Ds Mark III
EOS 7D, 5D, 5D Mark
II / 10D / 20D / 30D / 40D / 50D /D30 / D60 / D2000
Canon EOS Film SLR EOS 1V 1VHS 3, Kodak DSC-530 etc.
Art.No
-
FB2-01
FB3-01
FB4-01
FB5-01
Olympus E-400 E-410 E-420 E-510 E-520 E-30,EP-1,EP-2, EP-L,EP-L2, SP-510UZ SP-550UZ SP-560UZ SP-565UZ SP-570UZ etc.
Art.No
FB1-N1
FB2-N1
FB3-N1
FB4-N1
FB5-N1
Nikon D200,D300,D300s,D700, Nikon D1 / D1h / D1x, Nikon D3 / D2 / D2H / D2Hs / D2X, Nikon F5 / F6 / F100 / F90 / F90x
Kodak DCS Pro 14n DCS620, Fuji S3 Pro/S5 Pro etc.
Art.No
FB1-N3
FB2-N3
FB3-N3
FB4-N3
FB5-N3
FB2-P1
FB3-P1
FB4-P1
FB5-P1
Nikon D90, 5000, 3000, 3100 etc.
Art.No
-
Panasonic FZ20, 20K, 25, 30, 50, 100, LC1, L1, L10, GH2, GH1,G2, G10, GF1, G1 etc.
Art.No
-
FB2-S1
FB3-S1
FB4-S1
FB5-S1
Sony Alpha DSLR-A100 A200 A300 A350 A500, A700, A850, A900, A550, A580, 33, 55
Konica-Minolta Maxxum/Dynax/AF 7D, 5D, 9, 7, 5, 4, 3
807si, 800si, 700si, 600si, 505si, 500si, XTSi, HTSi Plus, STS, 9xi, 7xi, 5xi, 9000i, 7000i, 9000, 7000, 5000
Minolta Dimage 7Hi, 7i, 7, 5, A1, A2, A200 etc.
IR Remote Control
FB 4:
FB 5:
It offers
1. the release of cameras with
about 80 cm cable
2. Delay time of 1 sec up to
99 hours - 99 min - 99 sec
3. Exposure time of 1 sec up to
99 hours - 99 min - 99 sec
4. Interval time of 1 sec up to
99 hours - 99 min - 99 sec
5. Number of shots from 1 to
399
It offers
1. the remote release
of cameras about
a distance of 5 m
2. works in preset
single frame- or
serial shooting
3. can be used in
long-term mode
Digital Timer Remote Control
52
Remote Control
with a length of 5 m.
Infrared-Remote Control
• offers the remote release of cameras about a
distance of max. 8 m (without obstacles)
•
FB-IRC
FB-IRN
FB-IRP
works in preset single frame- or serial shooting
(varies depending on camera-model)
FB-IRO
Art.
No
CameraCompatibility
FB-IRC
Canon 7D, 50D, 60D, 600D, 550D, 500D, 450D, 400D,
350D, 300D etc.
FB-IRN
Nikon D90, 80, 70, 70s, 60, 50, 40, 40x, Coolp 8400, 8800,
6000, 7000 etc.
FB-IRP
Pentax istDS2, istDS, istDL2, istDL, istD, K100D, 110D,
200D, 10D, 20D, K-M, K-7 etc.
FB-IRO
Olympus all E-System cameras, 2100, 2500 etc.
FB-IRS
Sony Alpha A230, 330, 380, 500, 550, 580, 700/ 800/
9007025-77, 33, 55 etc.
FB-IRS
53
Accessory
FIlterS
100 Years
Quality
Exciting photos with filters
The modern digital time filter perform an important task in photography.
Often the amateur or professional photographer spends a lot of his time in
correcting his shots by using image processing applications. By installing
a filter on the lens the quality of the pictures will often be far much better,
because filters are developed to create an optimal photo.
This does for example the UV (Ultraviolet) – filter.
It deletes the invisible UV radiations and therefore pale,
dusty and colourless pictures will be avoided.
BILORA offers this filter as a professional version as
well, and that in High Definition Multi Coating. With its
high quality coating it prevents reflections from the glass
surface.
The CLP (Cirkular-Pol Filter) deletes most
reflections on non-metallic surfaces, so water appears
more transparent and this filter makes the sight of
under-water life in several sight angles possible. Window
glasses show less reflections and colours become more
exciting and powerful.
54
each one UV-, CPL,
NDx4- and star filter
in case
Art.No
mm
7000-52
52
7000-58
58
7000-62
62
7000-67
67
7000-72
72
Filter Case
Art.No 7025-77
for 4 filters
up to 77 mm Ø
7010
Filter Case
M 46,52,55,58,
62,67,72,77
Art.No 7025-58
7011
M 52, 55, 58,
62, 67, 72, 77
for 4 filters
up to 58 mm Ø
7013
M 52,
55, 58,
62, 67,
72, 77
BILORA offers these 3 filters (7010, 7011 and 7013) in an especially narrow low profil, which makes it possible to use
these filters on wide-angle lenses without producing vignettings.
The Close up lens ( NL+3) is a valuable
accessory for the friends of close up photography. The
camera-to-subject distance can be shortened by ca.
1/4. Therefore this filter is particularly suitable for flowerand insect-shots. It takes no light, so that the depth of
sharpness can perfectly be optimized by using a small
aperture.
7015
The ND4 (Neutral Density) Filter produces
the pre-conditions to use bigger focal aperture or longer
shutter speeds in spite of good lighting conditions. And
therefore you can really recognize movement on photos
with moving motifs. Besides that you can create more
exciting portraits with a shorter depth of sharpness.
7018
Finally the Starfilter (Star 4) is a first-class
instrument of creativity. Boring inside - or night-shots turn
into works of art, because this filter generates 4-ray stars
on all powerful light sources in the picture and therefore
creates a fantastically atmospheric photo.
Filter-Set:
Lens Caps
The best
lens-protection !
M 52,
55, 58,
62, 67,
72, 77
M 52,
55, 58,
62, 67,
72, 77
7020
M 52,
55, 58,
62, 67,
72, 77
Art. No
mm
7050-49
49
7050-52
52
7050-55
55
7050-58
58
7050-62
62
7050-67
67
7050-72
72
7050-77
77
with
safe cord
Easyhood Lens Hood
Productdescription
Art.
No
Easyhood 52
7070-52
Easyhood 55
7070-55
Easyhood 58
7070-58
Easyhood 62
7070-62
Easyhood 67
7070-67
Easyhood 72
7070-72
Easyhood 77
7070-77
Easyhood 82
7070-82
Easyhood lens hood
prevent reflections in the
case of sidelight.
They are ergonomically
shaped, snap on filter
thread and they provide a
safety rubber that secures
the hood on the lens.
55
Display-Protection
Display-Protection
100 Years
Quality
Screen-Protector
universal
Art.No 204-1
For camera, mobile phone,
PDA, mini-tv or navisystem.
Guard/Acrylic Panel
Art.No
LCD Guard 2,5"
2002-25
LCD Guard 2,7"
2002-27
LCD Guard 2,8"
2002-28
LCD Guard 3,0"
2002-30
LCD Guard Canon EOS 7D
2003-1
LCD Guard Canon EOS 60D
2003-4
LCD Guard Canon Powershot G10
2003-5
LCD Guard Ixus 130
2003-10
LCD Guard Canon EOS 450D/500D
2003-11
LCD Guard Canon EOS 40D/50D
2003-12
LCD Guard Canon EOS 5D Mark II
2003-13
LCD Guard Canon EOS 5D Mark III
2003-14
LCD Guard Canon EOS 1D Mark III
2003-17
The high quality LCD screen protection film for the
sensitive display of your camera. Precisely cut to
size depending on inches resp. camera display.
LCD Guard Canon EOS 1D Mark IV
2003-18
LCD Guard Nikon D300s
2004-1
LCD Guard Nikon D90
2004-2
Please inform yourself about our current articles at
www.bilora.de.
LCD Guard Nikon D3100
2004-3
LCD Guard Nikon D7000
2004-4
For all displays
Protection against scratches, glare, wear and damage.
Suitable cutting to size and fixing up perfectly.
Contains: - Protection foil (5 pcs. for up to 12 screens of 2,5“)
- Squeegee card
- Screen size 91 x 113 mm each
- Screen pattern for 1,7“, 1,8“, 2,0“, 2,2“, 2,5“, 2,8“
and 3,0“.
LCD-Protection Film
cut to size
Model Protection Film
Art.No
LCD Guard Nikon Coolpix P100
2004-7
LCD Film 2,5"
2001-25
LCD Guard Nikon D 4
2004-10
LCD Film 2,7"
2001-27
LCD Guard Nikon D 800
2004-11
LCD Film 2,8"
2001-28
LCD Guard Nikon D 700
2004-12
LCD Film 3,0"
2001-30
LCD Guard Nikon Coolpix P 7100
2004-14
LCD Film 3,5“
2001-35
LCD Guard Olympus PEN-EP2
2005-1
LCD Film Canon Powershot SX1IS
2003-6
LCD Guard Pentax K-5
2006-1
LCD Film Canon Powershot G12
2003-7
LCD Guard Pentax K-x
2006-3
LCD Film Canon Powershot G11
2003-8
LCD Guard Pentax K-7
2006-4
LCD Film Ixus 210
2003-9
LCD Guard Panasonic GF1
2007-1
LCD Guard Panasonic FZ38
2007-2
LCD Guard Panasonic FZ45
2007-3
LCD Guard Panasonic TZ10
2007-5
LCD Guard Sony NEX3
2008-1
LCD Film Canon EOS 600D
2003-16
LCD Film Nikon D5000
2004-5
LCD Film Olympus E-620
2005-2
LCD Film Olympus E-600
2005-3
Easy to fix.,
bubble-free
LCD Film Panasonic FZ100
2007-4
LCD Guard Sony NEX5
2008-2
LCD Film Panasonic GH2
2007-6
LCD Guard Sony Alpha 290
2008-3
LCD Film Panasonic G2
2007-7
LCD Guard Sony Alpha 390
2008-4
LCD Film Panasonic TZ20
2007-8
LCD Guard Sony Alpha 450
2008-5
LCD Film Panasonic GF2
2007-9
LCD Guard Sony Alpha 550s
2008-6
LCD Film Panasonic TZ25
2007-10
LCD Guard Sony Alpha 560
2008-9
LCD Film Panasonic TZ31
2007-11
LCD Guard Sony Alpha 580
2008-10
LCD Film Sony Alpha 33
2008-7
LCD Guard Sony Alpha 850
2008-11
2008-8
LCD Guard Sony NEX 7
2008-12
LCD Film Sony Alpha 55V
56
Reliable Acryl-Protection
for your display
Please inform yourself
about our current articles at
www.bilora.de.
The precisely fitting LCD Acrylic Guard protects the
display against scratches, bumps and knocks. The guard
features special advantages:
• Polycarbonate, also known as acrylic, was refined with
a scratch resistant layer and additionally provided with
an UV protection.
• Due to the small thickness of only 1,2 mm, you can
use your current camera bag further on. Accessories
can be attached without barriers.
• This high quality screen protector let 96% of the light
(UV-reduced) pass and therefore does not interfere
while using the camera.
• The narrow adhesive strip of of only 2 mm width does
not cover the display.
• The thickness of the adhesive strip with only 0,6 mm
provides a tiny distance between the LCD Guard and
the display, so that a shock absorbing safety zone
emerges.
• If the LCD Guard is once scratched or damaged, it
can be residue-free removed. Any adhesive residue
can be easily removed with glass cleaner.
The LCD Guard offers an invaluable protection, because a
damaged screen may spell a total loss for your camera or
at least you are confronted with disproportionately high repair costs. Thus, the LCD Guard is the cheapest spending
for a long camera life.
57
100 Years
Binoculars
Photo-Studio
Quality
Mobile Photo-Studio
Art.No 130
Content:
- 1 metal-camera-tripod with ball head
- 2 tripod-lamps with 3 foldout metal feet and
swivelling reflector with high voltage-halogenreflector-lamps 50 watt
- 3 white, transparent side walls (each 40 x 40 cm)
see studio construction below
- 4 coloured cloth-backgrounds (40 x 80 cm) in white,
blue, red and black, with velcro, fixable in studio
- cloth bag, folded together 40 x 40 cm,
with front bags.
A ll binoculars are equipped with rubber armoured body
for protection against bumps and water, eye pieces for wear
glasses and with shoulder strap and pouch.
Bilogon ECO
8 x 21 ruby Art.No 9000-R
10 x 25 ruby Art.No 9002-R
Mini-Studio
portable
Bilogon ZOOM
8 - 24 x 50 ruby Art.No 9313-R
Powerful porro
prism binocular
with high level
optics and a special magnification
of 8 x - 24 x with
infinitely adjustment.
Flat
foldable
Fast ready
for use
T
he Bilogon LITE and Lux
are light-powerful, multicoated quality binoculars.
A rubber coating protects
against impact and splash.
Bilogon Lite
The high quality roof prism binoculars are outfitted with
a special ruby coating, which offers a better contrast of
the object and relax the eyes.
All models of the
„EAGLE“ line are
special powerful
porro prism
binoculars with
high level optics.
Bilogon Eagle
8 x 30 Art.No 9305
7 x 50 Art.No 9307
10 x 50 Art.No 9308
Tripod-Connection
Art.No 9070
Fits to all Bilogon
binoculars with
tripod thread in the
middle adjustment.
8 x 32 Art.No 9050
10 x 42 Art.No 9051
Article No:
Bilogon Lux
8 x 42 Art.No 9060
10 x 42 Art.No 9061
The Lux models are also
nitrogen filled, waterproof up
to 4 m and equipped with
BAK4 prisms.
58
Model
9000-R
9002-R
9305
9307
9308
9313-R
9050
9051
9060
9061
ECO
ECO
EAGLE
EAGLE
EAGLE
ZOOM
Lite
Lite
Lux
Lux
Magnification
8x
10 x
8x
7x
10 x
8 - 24 x
8x
10 x
8x
10 x
Front Lens Ø (mm)
21
25
30
50
50
50
32
42
42
42
Coating
red
red
yes
yes
yes
red
yes
yes
yes
yes
Luminosity
6,8
6,25
14
51
25
3,2-29
16
18
28
18
Twilight Factor
12,9
15,8
15,5
18,7
22,3
14,5-19
16
20,5
18,3
20,5
Exit Pupil (mm)
2,6
2,5
3,75
7,1
5
1,8-5,4
4
4,2
5,25
4,2
Field of View/1000 m
122
101
131
123
99
40-78
119
105
110
105
Waterproof
Height (mm)
Weight (g)
-
-
-
-
-
-
-
-
yes
yes
90
115
140
185
190
190
140
152
135
135
200
250
710
812
860
926
430
490
710
790
59
100 Years
Quality
Your contact in Germany:
BILORA GmbH
Industriestraße 31 - 42477 Radevormwald
Carlo Cammarota
phone: +49 2195 67 70 31
fax:
+49 2195 67 70 38
email: cammarota@bilora.de
www.bilora.de
Homepage
Your favourite dealer
The catalogue is created with
great care. Nevertheless, we
cannot give any warranty or
liability for the accuracy, actuality or completeness of the
information in this catalogue.
We cannot assume liability or
warranty for any material or
immaterial damage caused
by use, disuse or withholding
of incorrect or incomplete
information in this catalogue.
Technical product data and
the contents of the catalogue
are subject to change at any
time.
BILORA GmbH - Industriestraße 31 - 42477 Radevormwald
ph.: +49-2195-677032 - fax: +49-2195-677038 - email: bilora@bilora.de - www.bilora.de
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
