KUPO GRIP

Professional lighting stands and grip accessories

Index

Special features

Lightweight & Kit stands

Floor stand & Base stand & Roller stands

Steel stands & Combo stands

Combo stands

Cine stands & K stand

Wind-up stand & Follow spot stands

1-2

3-6

7-8

9-10

11-12

13-16

17-20

Master C stands

Grip heads & Grip arms & Flag frames

Extension columns & Boom arms

Overhead stands

Butterfly frames

Casters

Super viser & Chain clamps & Gaffer Grip

Convi clamp & Adapters

21-23

24-25

26-28

29

30-31

32

33-34

35-41

Grip accessories & Adapters

3 way & 4way clamps

Offset arm & Side arm & Articulated arm

Flex arm & Accessories

Poly holder & Foam core fork

Kino clamp & Wall spreader & Ruler clamp

Ali clamp & Off camera flash spring clamp

42-44

45

46-47

48

49

50

51

Max arms & Vision arm & Pincer clamp

Suction cups

Kupoles & Background paper supports

Tethermate

Super Joint & Textile

Couplers & Clamps & Safety wire

K-lok & CEE form connectors

Head-to-Ballast connectors/ Cable

Caps & Director chair

52-56

57

58-62

63

64-65

66-74

75-79

80

81

Sand Bags & Grip cases

Ku hand &Gaffer tapes & EZ-ties

CCTO/CTB filters & C47 & Honey combs

X-Bone & Cam step & Cable guards

Digi-fan & Intercom & Special effect

Product Index

82-83

84-86

87-88

89-90

91-96

97-102

KUPO Professional Lighting Stands

and Grip Accessories

Kupo offers a whole range of professional lighting stands and grip accessories for film, TV studio, location, photographic industry. To meet the professional requirements, there are various stand versions available.

It includes Lightweight and kit stand, Roller stand,

Combo stand, Wind-up stand, C stand, Overhead stand, Butterfly frame, Cine stand and Versatile mounting accessories...

Based on many years experience of professional stage lighting, we now offer some excellent machines for special effect usage on film and movie application.

Kupo support best to meet all your professional request.

Guide To Symbols

Maximum Height

Closed Length

Suggested Caster

(Optional accessory)

Maximum Load

Stand Top

Footprint Diameter

Weight

Stand Top

All of Kupo lighting stands are available with industry standard top fixings of mounting lighthead and lighting accessories.

A : 5/8” (16mm) fixing light stud T : Compact lightweight

aluminum stands with 5/8”

(16mm) fixing top and

3/8” -16 screw thread.

G : Permanently fitted 4 1/2”

grip head with additional

offset 1 1/8” (28mm) socket.

S : 5/8” (16mm) socket with a

detachable 5/8” (16mm)

light stud. One end

3/8” -16 and another end

1/4” -20 screw thread.

SJ : 17mm socket

(Japanese Type)

V : Triple function universal top

head with both 1 1/8”

(28mm) and 5/8” (16mm)

socket. Extra multi direction

5/8” (16mm) light stud.

VJ : Triple function universal

top head with both 25mm

and 17mm socket. Extra

multi direction 16mm light

stud. (Japanese Type)

A full range of locking mechanisms.

Stand riser columm collars are pressure die cast aluminum for strength and incorporate ergonomic locking knobs that hold the light exactly where positioned.

1

Unique bottom spider casting design makes folded stand can be set alone on its own.

Bottom spider casting with spring cushioned to prevent jarring of the lamp filament. For those steel stand recited with

''spring cushion''.

Assembled by bolts and nuts for easier maintenance and tightness adjustable instead of fixed rivets.

Double leg struts for extra strength and stability.

The stand leg is equipped with nylon feet to protect both leg and ground.

Leveling leg allows stand keeping vertical in any circumstance.

Upper spider casting with extender for hanging sandbag on the center position.

Solid cross pin design in aluminum stand for a better stand stud mount.

2

The lightweight aluminum stand with aluminum clamping riser which provide a good elasticity. Unlike plastic riser that has memory and result to break.

All the aluminum casting knob comes with a mold-in stainless steel bolt for lightweight

& long-lasting clamping operation.

Baby pin is welded directly to the riser instead of being pinned in steel stand.

Each KUPO Stand comes with velcro supplied to fasten the legs for better storage and cable management.

New innovation compact top head with multi direction 16mm

(5/8”) light stud.

Ear ring device for wind-bracing kit.

The stainless steel heli-coil insert is equipped inside the aluminum die-casting riser provides a durable threaded hole.

A sizable brake shoe to ensure a much better lock off.

013BS Backlite Base Stand

9cm

3.5”

15kg

33lbs

1kg

2.2lbs

T

60cm

23.6”

Fold away steel backlite base stand with KS-017 which is 16mm stud with

3/8’’ and 1/4’’ thread. Designed for mounting lighting fixture close to the floor or table.

013 Folding Base Mini Stand

48cm

18.9”

60cm

23.6”

85cm

33.46”

3kg

6.6lbs

1.3kg

2.87lbs

T

Fold away back steel base and aluminum collars with 5/8” socket and KS-017.

Universal 16mm light stud. Extension pole from 48cm to 80cm w/5/8” fixing top.

Provide flexible mounting of lights from floor level to nearly 85 cm high.

Fold flat for easy carry and storage

033 Low Mini Kit Stand

40cm

15.75”

45cm

17.8”

129cm

50.8”

1.5kg

3.3lbs

0.75kg

1.65lbs

T

3 risers, 4 sections.

Dia.: 1” , 7/8” , 3/4” , 5/8”

Leg dia.: 5/8”

Aluminum material

With KS-052, adapter for female thread

3/8” -16 to male 1/4” -20.

Designed for background lights.

3

055 Handy Stand

49cm

19.2”

102cm

40.1”

227cm

89.3”

2.5kg

5.5lbs

1.1kg

2.4lbs

T

4 risers, 5 sections.

Dia.: 1-1/8” , 1” , 7/8” , 3/4” , 5/8”

Solid flat legs: 15mm x 5mm

Aluminum material with KS-052, adapter for female thread

3/8” -16 to male 1/4” -20. Perfect for small lighting fixture on location and lightweight compact design makes it ideal for kits.

023 Midi Pro Stand

023AC Midi Pro Stand w/Air Cushion

86cm

33.9”

109cm

42.9”

250cm

98.4”

5kg

11lbs

1.3kg

2.87lbs

T

KC-064R (Optional)

2 risers, 3 sections.

Dia.: 1-1/8”, 1”, 7/8”

Leg dia.: 3/4”

Aluminum material

034 Mini Kit Stand

034-J Japanese Type

66cm

26”

236cm

93”

1kg

2.2lbs

90cm

35.4”

4kg

8.8lbs

T / SJ

3 risers, 4 sections.

Dia.: 1”, 7/8”, 3/4”, 5/8”

Leg dia.: 5/8”

Aluminum material

4

045 Medium Stand

95cm

37.4”

445cm

175.2”

109cm

42.9”

1kg

2.2lbs

KC-064R (Optional)

1.5kg

3.3lbs

T

4 risers, 5 sections.

Dia.: 1-1/8”, 1”, 7/8”, 3/4“, 5/8”

Leg dia.: 3/4”

Load: variable with height, maximum load 1kg at full extended.

Aluminum material

198 Universal Stand

198AC w/Air Cushion

198-J Japanese Type

107cm

42.1”

385cm

151.6”

2.3kg

5lbs

110cm

43.3”

9kg

19.8lbs

A

KC-080R (Optional)

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

Aluminum material

KS-028

Stand Leg Rubber Cover

For Leg dia.: 22mm

Set of 3

195 Baby Kit Stand

107cm

42.1”

110cm

43.3”

385cm

151.6”

9kg

19.8lbs

KC-080R (Optional)

A

2.3kg

5lbs

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

Aluminum material

Welding stand top

5

195S Baby Kit Stand W/ Square

Tubular Legs

124cm

48.9”

400cm

157.5”

4.5kg

9.9lbs

112cm

44.1”

10kg

22lbs

A

3 risers, 4 sections.

Dia.: 35mm,30mm, 25mm, 20mm

Leg size.: 22mm x 22mm

Aluminum material

With 1 leveling leg

Welding stand top

193

Medium Baby Kit Stand

88cm

34.6”

88cm

34.6”

288cm

113”

10kg

22lbs

2.5kg

5.5lbs

A

3 risers, 4 sections

Dia. 35mm, 30mm, 25mm, 20mm

Leg size: 22mm*22mm

Aluminum material

With one leveling leg

With welding stand top

169M

Class Stand

101cm

39.8”

109cm

42.9”

290cm

114.2”

10kg

22lbs

KC-080R (Optional)

2.05kg

4.5lbs

S

2 risers, 3 sections.

Dia.: 35mm, 30mm, 25mm

Leg dia.: 22mm

Aluminum material w/KS-017 Universal 16mm light stud.

6

175M

Shorty Stand

70cm

27.6”

68.6cm

27”

213cm

83.9”

9kg

19.8lbs

KC-080R (Optional)

2.3kg

5lbs

S

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

Aluminum material w/KS-017 Universal 16mm light stud.

355 Universal Floor Stand

35.1cm

12.4”

60cm

23.6”

13cm

5.12”

10kg

22lbs

1.05kg

2.31lbs

Low profile, lightweight compact folding floor stand. Constructed of anodized aluminum legs and central column With die-casting legs mount. Designed for a 28mm spigot, or a 19 mm spigot with supplied adaptor. (Optional adapter for 16mm is available.)

Detachable 19-28mm adaptor

May stand alone with legs folded

350 Runway Base Stand

26cm

10.2”

5.2kg

11.5lbs

28mm Socket

1-1/8”

75cm

29.5”

70kg

154.3lbs

The chrome plated steel Runway Base Stand is really low rolling stand base which is designed to work with the large lighting fixture. For backlites of most use. Meanwhile, add an extension column into the junior 1-1/8''(28mm) receiver can create a mobile rolling stand. The leg design allows to be folded parallel to one another for easy storage and transportation.

Junior receiver w/ extension tube

7

Folds for storage & travel

300M High Roller Stand

142cm

55.9”

428cm

168.5”

15.4kg

34lbs

129cm

50.8”

40kg

88.2lbs

V

3 risers, 4 sections.

Dia.: 45mm, 40mm, 35mm, 30mm

Leg: 25mm x 25mm

Chrome plated steel with KC-100S caster

Spring cushioned

May stand alone with legs folded

320M Junior Roller Stand

320M-J Japanese Type

114cm

44.9”

270cm

106.3”

7.55kg

15.1lbs

106cm

41.7”

12kg

26.5lbs

A / SJ

2 risers, 3 sections.

Dia.: 35mm, 30mm, 25mm

Leg: 22mm x 22mm

Chrome plated steel with KC-080S caster

8

330M Senior Roller Stand

130cm

51.2”

420cm

165.4”

10kg

22lbs

110cm

43.3”

12kg

26.5lbs

A

3 risers, 4 sections.

Dia.: 40mm, 35mm, 30mm, 25mm

Leg: 22mm x 22mm

Chrome plated steel with KC-080S caster

135MB-J Midi-Mix Kit Stand-Black

135MP-J Midi-Mix Kit Stand-Polish

Japanese Type

105cm

41.3”

350cm

137.8”

6kg

13.2lbs

104cm

40.9”

13kg

28.7lbs

SJ

KC-080R (Optional)

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

With 1 leveling leg

Black coating or Chrome plated steel

135M Midi-Max Kit Stand-Silver

105cm

41.3”

104cm

40.9”

350cm

137.8”

13kg

28.7lbs

5.8kg

12.8lbs

A / SJ

KC-080R (Optional)

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

Chrome plated steel

9

145M Heavy Duty Baby Stand

115cm

45.3”

400cm

157.5”

6kg

13.2lbs

120cm

47.2”

13kg

28.7lbs

A

KC-080R (Optional)

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm, 20mm

Leg dia.: 22mm

Chrome plated steel

155M High Baby Stand

107cm

42.1”

110cm

43.3”

420cm

165.4”

25kg

55.1lbs

8.2kg

18lbs

A

KC-080S (optional)

3 risers, 4 sections.

Dia.: 35mm, 30mm, 25mm

Leg: 22mm x 22mm

With 1 leveling leg

Chrome plated steel

10

227M Master Combo Alu Senior

227M-J Japanese Type

122cm

48”

315m

124”

3kg

6.6lbs

118cm

46.5”

12kg

26.5lbs

V / VJ

KC-080R (Optional)

2 risers, 3 sections.

Dia.: 35mm, 30mm, 25mm

Leg dia.: 22mm

With 1 leveling leg

Aluminum material

226MB Master Combo HD Stand Black

226MB-J Japanese Type Black

132cm

52”

340cm

133.9”

9.2kg

138cm

54.3”

40kg

88.2lbs

V / VJ

KC-080R (Optional)

2 risers, 3 sections.

Dia.: 40mm, 35mm, 30mm

Leg dia.: 22mm

With 1 leveling leg

Spring cushioned

Powder coated steel

11

226M Master Combo HD Stand

226M-J Japanese Type

132cm

52”

340cm

133.9”

9.2kg

20.3lbs

138cm

54.3”

40kg

88.2lbs

V / VJ

KC-080R (Optional)

2 risers, 3 sections.

Dia.: 40mm, 35mm, 30mm

Leg dia.: 22mm

With 1 leveling leg

Spring cushioned

Chrome plated steel

228M Master Combo Stand - Black

122cm

48”

118cm

46.5”

230cm

90.6”

30kg

66.1lbs

7.5kg

16.3lbs

V

1 riser, 2 sections.

Dia.: 35mm, 30mm

Leg dia.: 22mm

With 1 leveling leg

Black powder coated steel with KC-080R caster

Spring cushioned

12

228P Master Combo Stand - Polish

122cm

48”

118cm

46.5”

230cm

90.6”

30kg

66.1lbs

KC-080R (Optional)

7.5kg

16.3lbs

V

1 riser, 2 sections.

Dia.: 35mm, 30mm

Leg dia.: 22mm

With 1 leveling leg

Chrome plated steel

Spring cushioned

542M Master Cine Stand

542M-J Japanese Type

135cm

53.1”

325cm

128”

11kg

24.2lbs

138cm

54.3”

40kg

88.2lbs

V / VJ

KC-100S (Optional)

2 risers, 3 sections.

Dia.: 45mm, 40mm, 35mm

Leg : 25mm x 25mm

With 1 leveling leg

Chrome plated steel

13

542MB Master Cine Stand Black

542MB-J Japanese Type Black

135cm

53.1”

325cm

128”

11kg

24.2lbs

138cm

54.3”

40kg

88.2lbs

V / VJ

KC-100S (Optional)

2 risers, 3 sections.

Dia.: 45mm, 40mm, 35mm

Leg : 25mm x 25mm

With 1 leveling leg

Powder Coated Steel

543M Master High Cine Stand

543M-J Japanese Type

145cm

57.1”

420cm

165.4”

12kg

26.5lbs

140cm

55.1”

40kg

88.2lbs

V / VJ

KC-100S (Optional)

3 risers, 4 sections.

Dia.: 45mm, 40mm, 35mm, 30mm

Leg: 25mm x 25mm

With 1 leveling leg

Chrome plated steel

14

543MB Master High Cine Stand Black

543MB-J Japanese Type Black

145cm

57.1”

420cm

165.4”

12kg

26.5lbs

140cm

55.1”

40kg

88.2lbs

V / VJ

KC-100S (Optional)

3 risers, 4 sections.

Dia.: 45mm, 40mm, 35mm, 30mm

Leg: 25mm x 25mm

With 1 leveling leg

Powder Coated Steel

Kupo 546M K stand is Junior Boom Stand with one Leveling Leg. In addition to be a standard light stand for general use, it can be easy convert to a junior boom arm by pulling the central tube out from the stand. With sturdily constructed by chrome plated steel, square-end legs and strong pivoting collar, Kupo K stand offers most stable supporting for a medium sized light fixture with a softbox or umbrella. One leveling leg is also equipped to stabilize the load on uneven terrain.

The optional casters, KC-100S, is recommended to easily move the K stand to facilitate location

546M K Stand-Junior Boom Stand

160cm

63”

510cm

200”

15kg

33lbs

134cm

52.8”

30kg

66lbs

V

KC-100S (Optional)

3 Risers 4 sections

Dia.: 45mm, 40mm, 35mm, 30mm

Leg: 25X 25mm

Chrome Plated Steel

With one leveling leg

Min extension: 155cm (61'')

Max loading: 30 kg ( 66 lbs)

Max extension: 280cm (110'')

Max loading: 8 kg (17.6 lbs)

Standard light stand Boom arm stand

Pivoting collar with Big handle allows K stand to be easy used either as standard light stand or boom

The neck with dia. 14mm hole in the end of tube for counterweight

Triple function stand top included junior receiver and baby pin & receiver

15

185M Low Mighty Baby Stand

57cm

22.4”

101cm

39.8”

3.6kg

7.92lbs

48cm

18.9”

15kg

33lbs

A

2 risers, 3 sections

Dia.35mm, 30mm, 25mm

Leg: 22mmX22mm

Chrome plated steel

With 1 leveling leg

Designed to be used for heavy light head at low level.

310M Low Mighty Stand

310M-J Japanese Type

92cm

36.2”

205cm

80.7”

7.8kg

17.2lbs

104cm

40.9”

35kg

77.2lbs

V / VJ

KC-100S (Optional)

2 risers, 3 sections.

Dia.: 45mm, 40mm, 35mm

Leg: 25mm x 25mm

Chrome plated steel

With 1 leveling leg

16

653M Steel Senior Stand

155cm

61”

477cm

187.8”

17.5kg

38.6lbs

174cm

68.5”

45kg

99.2lbs

V

KC-100 (Optional)

3 risers, 4sections.

Dia.: 50mm, 45mm, 40mm, 35mm

Leg dia.: 30mm

With 1 leveling leg

Chrome plated steel

Kupo wind-up stands are constructed by chrome plated steel with geared column that enable a single operator to raise and lower heavy loads safely with just turn of a handle. Both risers extend simulataneously at one elevation of 4.4cm by per handle turn. The unique automatic self-locking mechanism is equipped to prevent the light stand from dropping unexpectedly making the operation safer.

Auto Self-Locking device stop unexpected drop-off, and make operation safer.

(PATENTED)

Lock postion

The safety pin will auto insert to the holey tube when wind-up.

Features of Wind-up stand :

The stand top mounted by a steel bolt through the top tube that offers most sturdy and solid assembly.

The tension of break shoe can be adjusted with Allen wrench.

Unlock position

The inside spring will bring the safety pin back.

The wind-up handle should be inserted in between center pole and legs to prevent the tube falling suddenly.

Velcro is supplied to fasten the legs for better storage and transportation.

Leveling legs should be set into horizontal at leanning location.

Top section tube can be adjusted by stepping on foot step.

Bright color warming sticker for safety operation.

483-BP Base Plate

Set for three available with 481,482, 483T, 470 stands.

Casters are optional for easily moving the stand. The stand foot is rugged zinc-casting. Dia.: 100mm with brake and M10 attachment.

A set is for three (KC-100).

17

483T 3 SCT Wind-Up Stand w/Auto Self-Locking Device Silver

483T-J Japanese Type Silver

181cm

71.3”

128cm

50.4”

380cm

149.7”

30kg

66.1lbs

22.4kg

49.4lbs

KC-100 (Optional)

V / VJ

3 sections.

Dia.: 55mm, 45mm, 38mm

Leg dia.: 30mm

2 risers extend simultaneously at one elevation of 4.4cm per handle turn.

Safety cable ensures simultaneous retrieval of all sections.

Chrome plated steel stand w/geared column.

With 1 leveling leg

18

483BT 3 SCT Wind-Up Stand w/Auto

Self-Locking Device Black

483BT-J Japanese Type Black

181cm

71.3”

128cm

50.4”

380cm

149.7”

30kg

66.1lbs

22.4kg

49.4lbs

KC-100 (Optional)

V / VJ

3 sections.

Dia.: 55mm, 45mm, 38mm

Leg dia.: 30mm

2 risers extend simultaneously at one elevation of 4.4cm per handle turn.

Safety cable ensures simultaneous retrieval of all sections.

Powder coated steel stand w/geared column.

With 1 leveling leg

484 Heavy Duty Wind-Up Stand with Braked Caster

3 sections., Dia.: 70mm, 60mm, 50mm, Leg dia.: 35mm,

2 risers extend simultaneously at one elevation of 4.4cm per handle turn

Top 2 sections: Chrome plated steel

Center tube & legs: Stainless steel

With 1 leveling leg

With Auto Self-Locking Device

With Braked Caster

196cm

77.2”

180cm

70.9”

386cm

152”

80kg

176.3lbs

39kg

86lbs

28mm

1-1/8”

28mm socket with

3 side holes for wind bracing kit

Auto Self-Locking Device stop unexpected drop-off, and make operation safer

Solid and strong handle with slipfree design offer excellent operation.

Industry 6’’ braked caster with angle adjustable plate allows

484 to stably stand on the ground when the caster is removed.

Larger foot step with skidproof texture design

U-shaped struts are made of stainless steel for extra stability and safety.

19

482T 2 SCT Wind-Up Stand

165cm

65”

128cm

50.4”

245cm

96.5”

45kg

99.2lbs

18.5kg

40.8lbs

V

KC-100 (Optional)

1 riser, 2 sections.

Elevation: 2.2cm per handle turn

Dia.: 55mm, 45mm

Leg dia.: 30mm

With 1 leveling leg

Auto Self-Locking device

481 2 SCT Wind-Up Followspot Stand

110cm

43.3”

110cm

43.3”

145cm

57.1”

50kg

110.2lbs

KC-100 (Optional)

13.5kg

29.8lbs

V

1 riser, 2 sections.

Elevation: 2.2cm per handle turn

Dia.: 55mm, 45mm

Leg dia.: 30mm

With 1 leveling leg

Auto Self-Locking device

Chrome plated steel with geared column

20

470 Followspot Stand

109cm

43”

110cm

43.3”

147cm

57.9”

40kg

88.2lbs

KC-100 (Optional)

8.7kg

19.2lbs

V

1 riser, 2 sections.

Dia.: 50mm, 40mm

Leg dia.: 30mm

With 1 leveling leg

Chrome plated centrepost memory collar

Kupo c stand w/Turtle Base is easy to set up, durable and solid stand specially designed for professional photographers, film makers and videographers. The unique leg locking system makes deploying and collapsing the legs a snap and can be done within second with pulling up the spring ring and twist the stand.

More features are including :

1. Zinc casting alloy makes the leg base holders most solid and sturdiest.

2. Stainless steel heli-coli give protection for the aluminum riser from being damaged by stainless steel

bolt of knob.

3. The unique hollow design of the junior pin receiver on the base also makes dust, sands and water pass

through easily for better cleaning and easy maintenance.

Master Series C Stand w/Turtle Base (Quick Release C Stand)

2 riser, 3 sections

Dia. 35mm, 30mm, 25mm

Chrome plated steel for silver

Powder coated steel for black

CT-20M/MB 20” C Stand (Silver/ Black)

102cm

40.2”

100cm

39.4”

180cm

70.9”

10kg

22lbs

6.7kg

14.8lbs

A

CT-30M/MB 30” C Stand (Silver/ Black)

127cm

50”

100cm

39.4”

260cm

102.4”

10kg

22lbs

7.5kg

16.5lbs

A

CT-40M/MB 40” C Stand (Silver/ Black)

152cm

59.8”

100cm

39.4”

335cm

131.9”

10kg

22lbs

8.3kg

18.3lbs

A

Japanese Type is available Upon request.

Patented!

The innovative spring ring locking system designed.

Demonstration of deploying Kupo turtle base C stand

1) Keep the legs up and pull up

the spring ring.

2) Twist the stand and release

the spring ring.

3) Completely setup after a snap

deploying.

21

C stand Base:

C stand base is chrome plated steel may be used as a very low stand for backlites or different types of stand with various extension columns. The compact size is also available for more lightweight, better storage and transportation.

CT-BS C Stand Base

35cm

13.8”

95cm

37.4”

3.5kg

7.72lbs

30kg

66.1lbs

28mm

1-1/8”

CT-SBS Compact C Stand Base

35cm

13.8”

75cm

29.5”

3.3kg

7.3lbs

30kg

66.1lbs

28mm

1-1/8”

Japanese Type is available Upon request.

Sliding leg C stand:

It features one sliding leg, which allows the stand to adapt to uneven terrain such as stairs or hillsides.

This feature provides optimum support of your light heads, reflectors or gobos.

Master Series C Stand with Sliding Leg

2 riser, 3 sections

Dia. 35mm, 30mm, 25mm

Chrome plated steel for silver

Podwer coated steel for black

CS-20M/MB 20” C Stand (Silver / Black)

97cm

38.2”

100cm

39.4”

180cm

70.9”

10kg

22lbs

5.3kg

11.7lbs

A

CS-30M/MB 30” C Stand (Silver / Black)

112cm

44.1”

100cm

39.4”

250cm

98.4”

10kg

22lbs

6kg

13.2lbs

A

CS-40M/MB 40” C Stand (Silver / Black)

137cm

54”

335cm

131.9”

6.9kg

15.2lbs

100cm

39.4”

10kg

22lbs

A

22

Master Series C Stand Kits w/Turtle Base (Quick Release C Stand) including one grip arm and 2.5” grip head

2 riser, 3 sections

Dia. 35mm, 30mm, 25mm

Chrome plated steel for silver

Podwer coated steel for black

CT-20MK/MKB 20” C Stand Kits (Silver/ Black)

including : CT-20M/B, KCP-200/B and KCP-220/B

102cm

40.2”

100cm

39.4”

180cm

70.9”

10kg

22lbs

6.7kg

14.8lbs

A

CT-40MK/MKB 40” C Stand Kits (Silver/ Black)

including : CT-40M/B, KCP-200/B and KCP-240/B

152cm

59.8”

100cm

39.4”

335cm

131.9”

10kg

22lbs

8.3kg

18.3lbs

A

Japanese Type is available Upon request.

Master Series C Stand Kits with Sliding Leg C-Stand including one grip arm and 2.5” grip head

2 riser, 3 sections

Dia. 35mm, 30mm, 25mm

Chrome plated steel for silver

Podwer coated steel for black

CS-20MK/MKB 20” C Stand Kits (Silver / Black)

including : CS-20M/B, KCP-200/B and KCP-220/B

97cm

38.2”

100cm

39.4”

180cm

70.9”

10kg

22lbs

5.3kg

11.7lbs

A

CS-40MK/MKB 40” C Stand Kits (Silver / Black)

including : CS-40M/B, KCP-200/B and KCP-240/B

137cm

54”

100cm

39.4”

335cm

131.9”

10kg

22lbs

6.9kg

15.2lbs

A

23

KUPO Grip Head (also Gobohead) is specially designed to be mounted on C-stand with its 16mm socket. Four different size and rotatable V jaw allows you to attach the scrims, flags, cutters, reflectors and backdrops to meet various requirements of lighting control.

More Feartures

:

1. Aluminum casting body with 16mm mounting hole for a 5/8" (Baby) stud or stand top.

2. Non-slip, Non stick aluminum braking pad instead of fiber which would be deteriorate

offering positive lock and precise control.

3. Large size T-handle is ergonomic design for biggest torque - follow right hand rule.

4. Four V jaws for different dia. (5/8”, 1/2”, 3/8”, 1/4”) pins or tube.

5. V jaws with special tooth design offers a better grip.

6. Steel material makes the located pin sturdier than aluminum casting pin.

7. Stainless steel central bolt with fixed solid pin provides most durable construction.

8. Dedicated bearing added to reinforce the torque for stronger grip.

9. A solid retaining pin to fix the casting body with stainless steel central bolt.

KCP-200B

2-1/2” Grip Head - Black

KCP-200

2-1/2” Grip Head - Silver

KCP-200B/P - J

Grip Head with

17mm Spigot - Black/ Silver

24

A solid retaining pin to fix the casting body with stainless steel central bolt.

Grip arm, (or boom arm or gobo arm) for C stand is normally used in cooperated with a KCP-200,

KCP-220

20” Extension Grip Arm - Silver

KCP-240B

40” Extension Grip Arm - Black

Extra reinforced roller pin to fix extension arm.

KCP-240

40” Extension Grip Arm - Silver

KCP-241

40’’

Extension Grip Arm with Baby Hex Pin-Silver

It features the arm terminated with a hex baby pin which is suitable for mounting a lighting fixture or anything with baby receiver.

Kupo Flag frame is made by dia.

5mm spring steel with a dia. 9.5mm mounting pin.

KCP-F1824

KCP-F2436

Flag Frame 18” x 24”

Flag Frame 24” x 36”

Kupo Open frame is made by dia. 6.3mm spring steel with a dia. 9.5mm mounting pin.

KCP-OF1824 Open Frame 18” x 24”

KCP-OF2436 Open Frame 24” x 36”

Baby hex pin

KS-022 Grip Arm Pin

5/8’’ steel baby pin, with 5’’ (12.7cm) length, is designed for fitting into the grip head and can be connected to the lighting fixtures or other grip accessories.

25

KCP-215P Grip Arm Support

This is specially designed for giving the most support for grip arm very easy. It is constructed by an extendable aluminum column and comes with the ball joint pivot clamp in one end and with an angle-adjustable attachments in the other end. The attachments is also easy to be fitted into KCP-930 which is lightweight aluminum clamp for quickly coupling the stand tube from

35mm to 50mm with its spring locking design. With this functional support arm, not only loading weight of grip arm could be increased but sliding problem could be solved.

56cm

22”

78cm

30.7”

0.5kg

1.1lbs

Tiny clamp with double ball Length adjustable knob

KCP-216 Boom Arm Support

Similar to KCP-215P but gives the support for boom arm instead of grip arm. This is constructured by an two sections extendable aluminum column and terminated with angle-adjustable attachement in both end.

With connecting with two 4 way clamps

KCP-950 on the stand tube and boom arm, the loading weight of boom arm is signiciantly increased.

56cm

22”

78cm

30.7”

0.5kg

1.1lbs

3-4 way clamp adapter

26

KCP-640M Steel Baby Boom

This boom arm can be used to position reflectors, flash heads, screams, tungsten lights and muslin backdrops. A chrome steel boom with 5/8” baby stud, telescopes from 3.8-7.8’ (1.1-

2.4M) and supports upto 11lbs (5KG) when fully extended. The heavy duty tilt locking device is designed to cooperate with standard grip head to provide a tightly lock ability and it allows the boom to slide within it to adjust the balance of your load. The hook end allows hanging a sandbag for added support.

118cm

46.5”

3.79kg

8.35lbs

240cm

46.5”

T

KCP-641B Aluminum Baby Boom

The same function as KCP-640M but with aluminum boom arm.

It telescopes from 3.8-7.8” (1.1-2.4M) and supports up to 6.6lbs

(3KG) when fully extended.

With 5/8” (16mm) light stud

2 risers, 2 sections

(Dia.: 25mm, 30mm)

118cm

46.5”

240cm

46.5”

2.28kg

5.02lbs

T added support.

KCP-630 Junior Drop Down

Designed for use on the end of a boom arm to maintain a constant downward angle of a mounted light fixture, as the angle of the boom arm is changed.

KCP-631 Baby Drop Down

The same function as KCP-630 but with baby receiver and baby pin. Additional knob on the elbow is made to keep the lighting fixture no moving while specific angle is needed.

27

KCP-645 Pivoting boom arm clamp

Kupo pivoting clamp is constructed by solid aluminum die-casting & plastic cardboard insert which can fit a wider tubing size from 30~35mm diameter boom. With 1-1/8" ( 28mm) male pin and 5/8"

(16mm) female receiver, the attachment of clamp can fit into junior receiver or mount on baby pin which gives great flexibility and adjustment.

Adjustable Extension Columns

Kupo offers various adjustable extension columns included lightweight aluminum and heavy duty steel columns to meet professional lighting control requirements by connecting with couplers, clamps, stands etc.

013-A

Pole for Folding Mini Stand

Aluminum material

1 riser, 2 sections

(Dia.: 1” , 7/8” )

48cm

19”

80cm

31.5”

0.35kg

0.77lbs

T

042 Baby Stand Extension

Aluminum material

3 risers, 4 sections

(Dia.: 1” , 7/8” , 3/4” , 5/8” )

42cm

16.6”

127cm

50”

0.4kg

0.91lbs

A

120M Stand Extension

Chrome plated steel

1 riser, 2 sections

(Dia.: 40mm, 35mm)

120cm

47.3”

210cm

82.6”

4.9kg

10.8lbs

V

CT-TUBE

Chrome plated steel C-Stand tube

2 risers, 3 sections

(Dia.: 35mm, 30mm, 25mm)

CT-20M-TUBE

69cm

27.1”

147cm

57.9”

CT-30M-TUBE

94cm

37”

227cm

89.4”

CT-40M-TUBE

119cm

46.8”

302cm

118.9”

3.2kg

7.1lbs

4kg

8.8lbs

4.1kg

10.4lbs

A

A

A

28

600M High Overhead Roller Stand

186cm

73.2”

156cm

61.4”

594cm

233.9”

40kg

88.2lbs

21.4kg

47.2lbs

G

3 risers, 4 sections.

Dia.: 50mm, 45mm, 40mm, 35mm

Leg: 30mm x 30mm

Chrome plated steel with KC-100G caster

Spring cushioned

KCP-450

4-1/2” Grip head w/ a junior stud and receiver

It is designed to convert a junior stand into an overhead stand. The V jaws feature 3/8” and 5/8” diameter and able to offer positive lock for a gobo arm, large flag or butterfly in all directions.

610M Medium Overhead Roller Stand

146cm

57.5”

156cm

61.4”

430cm

169.3”

40kg

88.2lbs

18kg

39.7lbs

G

3 risers, 4 sections.

Dia.: 50mm,45mm, 40mm, 35mm

Leg : 30mm x 30mm

Chrome plated steel with KC-100G caster

Spring cushioned

29

620M Wide Base High Overhead Stand

188cm

74”

196cm

77.2”

633cm

249.2”

40kg

88.2lbs

16.5kg

36.4lbs

G

KC-100G (Optional)

3 risers, 4 sections.

Dia.: 50mm, 45mm, 40mm, 35mm

Leg: 30mm x 30mm

With 1 leveling leg

Chrome plated steel

Spring cushioned

Kupo butterfly frames are made of heavy duty 30mm square section aluminum tubes, which can be easily and pin lock together and disassembled for storage and transportation.

KH-06 Butterfly frame

6’ x 6’ (1.8m x 1.8m)

KH-08 Butterfly frame

8’ x 8’ (2.4m x 2.4m)

KH-12 Butterfly frame

12’ x 12’ (3.6m x 3.6m)

KH-20 Butterfly frame

20’ x 20’ (6m x 6m)

FC15A A17 FC15B(NUT) FH10

FH20 SW-TB

Features:

Capture frame within the corners for storage and easy handling.

Easily slots and pin lock connector The corner contain all tubes in a captive state, for a convenient storage and transportation. No more loose pieces that could be lost or damaged.

30

Kupo Round Pipe Butterfly Frame Kits is made by 1.5mm thickness steel with chrome plated surface treatment. It contains corners, connectors and ears that offers the ability to make butterfly frames in desired sizes with standard size pipe inluded 1-1/2''( 38.1mm) or 1-1/4'' (31.88)mm.

KH-L114 Round Pipe Butterfly frame for 1-1/4'Pipe Kits

KH-L112 Round Pipe Butterfly frame for 1-1/2'' Pipe Kits

KHR-L114 Frame Corner

for 1-1/4” (31.8mm) Pipe

KHR-L112 Frame Corner

for 1-1/2” (38.1mm) Pipe

KHR-C114 Frame Connector

for 1-1/4” (31.8mm) Pipe

KHR-C112 Frame Connector

for 1-1/2” (38.1mm) Pipe

KHR-E114 Frame Ear

for 1-1/4” (31.8mm) Pipe

KHR-E112 Frame Ear

for 1-1/2” (38.1mm) Pipe

Features:

Steel ring welded on the corner to enhance stability of frames by strings.

Steel boss welded on the tube to keep the long-lasting operation of knobs.

Two drilled holes on the corner for checking if the pipe is securely tighten by knob.

31

Casters makes your light stand movable while doing work in the studio. It will protect the floors, keep things quite on set and of course, make repositioning the lighting fixtures that much easier.

All Kupo casters are sold in sets of three and come with equipped brakes that prevent the wheel from rolling and keeps your stand locked in place.

KC-064R

Caster with round adapter

Dia.: 64mm w/brakes

Leg Dia.: 3/4” (19mm)

Set for three

KC-080R

Caster with round adapter

Dia.: 80mm w/brakes

Leg Dia.: 7/8” (22mm)

Set for three

KC-100G

Caster with square adapter

Dia.: 100mm w/brakes

Leg size: 30 x 30mm

Set for three

KC-100S

Caster with square adapter

Dia.: 100mm w/brakes

Leg size: 25.4 x 25.4mm (1” )

Set for three

KC-080S

Caster with square adapter

Dia.: 80mm w/brakes

Leg size : 7/8” x 7/8” (22 x 22mm)

Set for three

KC-100

Caster

Dia.: 100mm w/brakes and M10 attachment (17.5mm length)

Set for three

32

Super Viser is built by aluminum die casting body making it sturdy and lightweight. The moveable jaws are designed for mounting on the tubes or planks upto 101mm ( 228mm is available for longer version KCP-601). With the innovative grooved design on the threaded shaft, the both jaws can be kelpt on the same direction all the way. In addition to the 16mm pin terminated at the end of shaft, the unique design of 16mm socket is also built on the clamp that allows all accessories of

Convi. Clamp can fit into Super viser

3 1

The groove

5

2

4

PU Pad on Jaws

Features:

1. The groove on the threaded shaft keeps both jaws in the same direction all the time.

2. The P.U. pad on the jaws offer excellent grasp and protection from surface of tube s or plank.

3. The threaded shaft terminates as a 16 mm pin for mounting lighting fixtures or grip accessories.

4. The adaptor socket complements the full range of Convi clamp.

5. The ergonomically designed handle provides biggest torque.

KCP-600 4”(11.40cm) Super Viser KCP-601 9”(22.90cm) Super Viser

Application:

33

KCP-605, is 11.9'' (30cm) long chain clamp with 6'' (10” is also available for KCP-606) of steel chain. With the flexible chains, it can hold around any shape of wide size objects and adjust quickly by turning 5/8'' baby stud in the rear of clamp. Meanwhile, the safety T-handle is also designed to eliminate any risks of unexpected looseness of the trigger.

KCP-605

6” (15.2cm) Chain Clamp

KCP-606

10 (25.5cm) C

Features:

1. Ideal for holds awkwardly shaped pieces.

2. Easy to adjust pressure and fit work with turning the 5/8'' baby stud in the rear of clamp.

3. The chain built by high-grade heat-treated alloy steel for maximum toughness and durability.

4. Two 5/8'' baby pin provides strong support for lighting fixture with opposite directions.

5. The embossed neck of 5/8'' baby studs offer the maximum friction for mounting lighting fixture.

Embossed neck offers the maxinmum friction

Always lock with safety

T-handle for better protection.

On the tree

On the steel tube

KCP-500 Large Gaffer Grip

Quick release multi-purpose clamp which will grip flat surface or barrels. It comes with a tension control knob and a 5/8'' socket & stud for two small fixtures or grip items. The clamp works on

305

16

KCP-550 Small Adjustable Gaffer Grip

Two small fixtures or grip items can be mounted onto the 5/8" spigots including one fixed on the clamp and the other is detachable stud, which is with 3/8'' and 1/4'' thread, embedded in the 5/8’’ female receiver. Jaws is adjustable from 0.98 - 2.56" (2.5 - 6.5cm).

Weight: 0.66kg( 1.5lbs)

16

KS-017

34

233

The Convi clamp, is made of lightweight cast alloy, can be securely mounted on any tube from 5 to

51mm and equipped with a saddle for mounting onto flat surfaces. The Elastic P.U. Pad also reduces surface damage and enhances gripping action. All mental parts are made of stainless steel for sturdier and anti-rusted features. The die -casting aluminum of locking knob provides with most rugged advantage.

With built-in female socket allows the use of any attachments to hold anything from backgrounds to lighting fixtures. The spring safety locking system also offers double insurance while the screw locking action is not completely finished.

KCP-700B Convi Clamp-Black

KCP-700P Convi Clamp-Silver

20kg

44lbs

0.45kg

1lbs

1/4”-20

M5

135

KCP-710B Convi Clamp w/Adjustable Handle-Black

KCP-710P Convi Clamp w/Adjustable Handle-Silver

The Convi clamp with Adjustable Steel Handle features a ratcheted handle that allows to reposition it should you not have clearance to rotate the handle in a complete circle to tighten or loosen it.

20kg

44lbs

0.45kg

1lbs

KCP-7SDL Convi Clamp Saddle

Allow to use the clamp on most flat Surface such as a table without a tool. Set for four.

KD-730B

Convi Clamp Double Socket-Black

KD-730P

Convi Clamp Double Socket-Silver

Offer an additional 5/8’’ ( 16mm) socket to Convi clamp

36

KCP-720B Double Convi Clamp-Black

KCP-720P Double Convi Clamp-Silver

Assembled by two Convi Clamps provides a 90 degree angle and perfect for supporting a crossbar for background on kupoles.

KCP-260B Grip Head w/Hex Stud

The Grip Head with Hex Stud is identical to the 2-1/2’’ Grip Head with big handle but not being mounting to a baby 5/8’’ (16mm) receiver, it’ s mounted to a hexagongal stud designed exclusively to fit the Convi clamp.

KCP-270B Convi Clamp Griphead

This is assembled by Convi clamp (KCP-700B) and Grip Head with Hex Stud (KCP-270B).

KCP-701P Toothy Convi Clamp - Silver

Designed for mounting on the trees with the teeth devices of clamp

KCP-265P Grip Head w/ Coupler

Weight: 0.65KG (1.4lbs)

Working load: 20KG (44lbs)

KCP-715P Toothy Convi Clamp w/ Coupler

Weight: 1KG (2.2lbs)

Working load: 15KG (33lbs)

37

KS-001

3/8” Snap In Pin

KS-002

1/2” Snap In Pin

KS-003

5/8” Snap In Pin

KS-004

M12 x 30 Stud

KS-005

M10 x 25 Stud

KS-006

M12 x 35 Threaded Socket

KS-007

M10 x 30 Threaded Socket

KS-008

Joining Stud/Swivel

KS-009

150mm Extension

KS-010

Offset Arm 215mm (8.4”)

KD-790B

Bracket Shelf Holder

L Bracket Shelf Holder

17cmW x 0.4cmD (Set for two)

KD-795B

U Hook

Compact U Hooks -

Black (Set for two)

Application:

KS-010 with Convi Clamp

KD-790P with Convi Clamp

38

KS-011 100mm Square Mounting plate KS-012 Swivel Steel U hook

Steel U hook with a hex pin perfect for hanging strobe packs, HMI babllasts, or rigging background crossbars to light stands.

KS-014 Hex Stud 3/8’’-16M & 1/4’’-20M

Solid bass hex camera stud is designed to

Convi clamp. It comes with 3/8” -16 male and 1/4’’ -male thread to Mount camera directly to with a camera head.

KS-014R Round stud 3/8’’-16M & 1/4’’-20M

Solid bass round camera stud with 3/8’’ -16 male and 1/4’’ -20 female thread to Mount camera directly to with a camera head.

This is replacement stud for the Tilting umbrella adapter.

KS-015 Hex Stud 3/8’’-16F & 1/4’’-20F

Solid bass hex adapter is designed to Convi clamp. It comes with 3/8” -16 female and

1/4’’ -20 female thread.

KS-015R Round Stud 3/8’’-16F & 1/4’’-20F

Solid bass round adapter comes with

3/8’’ -16 female and 1/4’’ -20 female.

This is replacement stud for the Tilting umbrella adapter.

KS-016 90/45 degree Joining Stud

Designed for Convi clamp can be joined back to back at right or repeatable angles.

KS-017 l

w/ 3/8’’-16M and 1/4’’-20M

Solid round brass made stud can fit into any 5/8’’ (16mm) receiver which can be the adapter from baby receiver to baby pin.

KS-018 5/8’’ (16mm) stud w/M10 thread

Easy to be mounted on the yoke of lighting fixture with the M10 thread and butteryfly knob. And connected with Convi clamp with 5/8’’ (16mm ) stud.

KS-020/B 5/8’’ compact Alu. Snap in Pin

Lightweight aluminum 5/8’’ (16mm) adapter with hex stud for Convi clamp and round head in the other side.

39

KS-023 3/8’’ head mounting plate w/ 5/8’’ stud

Round flat plate made to mount head or any other accessory tapped with a female 3/8’’ -16

KS-024 1/4’’ head mounting plate w/ 5/8’’ stud

Round flat plate made to mount head or any other accessory tapped with a female 1/4’’ -20

KS-025 Hex Camera stud 3/8’’-16

Hexagonal end is for Convi clamp and

3/8’’ -16 male in the end side for Camera.

Made by solid bass.

KS-026 Hex Camera stud 1/4’’-20

Hexagonal end is for Convi clamp and 1/4’’-20

KS-027 5/8’’ (16mm) Male Adapter ( M10)

Steel made 5/8’’ (16mm) Adapter with tapped

KS-052 3/8’’-16F to 1/4’’-20M adapter

Solid brass made small adapter that converts a

KS-063 3/8''-16M to 1/4-20'' F adapter

Solid brass made small adapter that converts a

3/8’’ -16 male thread to a 1/4’’ -20 female thread.

KS-053 Adapter for thread 3/8’’-16 to 1/4’’-20

Made to convert 3/8"-16 Thread for 1/4"-20 Screw

And set for 5.

KS-051 1/4"M - 1/4"M Adapter Spigot

Dual male stud with standard 1/4” 20 tripod thread

KS-054 3/8" M- 1/4"M Adapter Spigot

Dual male stud with 3/8’’ to 1/4’’ thread adapter.

40

KS-074

Long Double Stud-5/8’’

4.9’’ long double 5/8’’ baby stud designed to connect a light to Convi clamp or an arm with a grip head.

KS-076

5/8’’Stud with 1/4’’-20’’ Female Thread

3.5 inch long 5/8’’ baby stud with 1/4’’ -20 female thread which is designed to mount a stud on your tripod or anything with a 1/4-20" thread.

KS-031

Snap in Right Angle

Right angle 5/8’’ baby stud with hex stud in the other end for not rotating while fitting into

Convi clamp. Hex stud fits into Convi clamp and longer right angle 5/8” baby stud for mounting lighting fixture or grip head.

KS-043

Right Angle Baby Wall Plate

3 X 5’’ (9X5 cm) plate welded with a right angle

5/8’’ baby stud. 8 anchor points are for nail or screws giving options for mounting anywhere.

May be used on a wall, ceiling, or an apple box where there is not easy to set up a lighting stand or boom arm.

KS-044

9'' Baby Wall Plate

With the same plate size and function as baby wall plate , but with welded 9’’ long 5/8’’ baby stud.

KS-045

6'' Baby Wall Plate

With the same plate size and function as baby wall plate , but with welded 6” long 5/8’’ baby stud.

KS-046

3" Baby Wall Plate

With the same plate size and function as baby wall plate , but with welded 6’’ long 5/8’’ baby stud.

KS-048

Junior Wall plate

With the same plate size and function as baby wall plate, but welded with a 4’’ long 1-1/8’’ junior receiver for a larger lightings.

KS-047

Baby Receiver Plate

With the same plate size and function as baby wall plate , but welded with a 5/8’’ baby receiver.

Great tool to mount a lighting fixture or grip accessories to a wall. A reserve mounting to a baby stand directly or take off the knob for access into junior receiver used as platform for monitor, speaker or lighting fixture.

KS-057

Offset Baby Wall Plate

With the same plate size and function as baby wall plate , but with welded 9" long post with 2

Baby (5/8") mounting studs for fixtures.

41

KS-030

28mm steel spigot with M10 thread and wing nut, attaches it to lighting yoke then fits into standard lighting stand with 28mm receiver.

KS-032

28mm steel spigot with M12 thread and wing nut, attaches it to lighting yoke then fits into standard lighting stand with 28mm receiver.

KS-034

Solid steel 28mm TV spigot tapped for M10 screw with washer, ideal for mounting lighting fixture directly on to stands or any TV clamps with

28mm receiver.

KS-090 TVMP Adapter

The TV to Motion Picture adapter is designed to attach on the yoke of lighting fixture that can be mounted the stand or fitting into a junior receiver

KS-060

Locking adapter for 5/8" light stand allows vertical or horizontal mounting of a light fixture, flash, or camera that has a 1/4"-20 threaded receptor.

KS-062

Locking adapter for 5/8" light stand allows vertical or horizontal mounting of a light fixture, flash, or camera that has a 3/8"-16 threaded receptor.

KS-070

Female Adapter 16 to 17mm. This is an aluminum female to female adapter. Used to converts a converts 5/8" male light stand top to a to 17mm female socket or to obtain a 17 mm female attachment from 16 mm spigot.

KS-071 Double Baby Receiver Adapter

5/8" (16mm) to 5/8" (16mm) female adapter made by Chrome plated steel with welded

KS-040

28mm steel spigot with a 12cm round mounting plate fits into standard lighting stands or to convert a 28mm receiver to a M10 thread with wing nut.

28mm steel spigot with a 12cm round mounting plate fits into standard lighting stands or to convert a 28mm receiver to a M12 thread with wing nut.

42

KS-080 Ball Race Spigot M10

A rotating 28mm spigot with M10 screw attached. Use this to make a lighting fixture into a follow spot. The smooth panning action is assured by roller bearing inside and a locking knob to control the position.

KS-082 Ball Race Spigot M12

A rotating 28mm spigot with M12 screw attached.

Use this to make a lighting fixture into a follow spot. The smooth panning action is assured by roller bearing inside and a locking knob to control the position.

KS-029 Monitor Adapter

(Plate: 75mm x 75mm)

KD-M01P LCD Monitor Arm

Max. Load: 8 kg

Clamping Tube: Dia. 40 ~ 52mm

Mounting Plate: 75 x 75mm / 100 x 100mm

KS-200 Junior to Baby Adapter

This adapter converts 1-1/8” female receiver to 5/8” male stud. Well construction from solid steel with chrome plated. Very helpful to fits into a heavy duty light stands and T.V. clamps or turtle base C stand to mount standard studio flash or video lighting fixtures.

KS-049 Scraper

It is very handy for unusual placements. The 1.1mm thin metal plate for easily jamming into the seams between the door and wall, under a set of books on a bookshelf, held with a sandbag, clamped to a ladder step, in a rock crack, etc. The embossed neck of 16mm baby stud fixed on the plate also designed for firmly hanging small lighting fixture. Additional three anchor points for the screws and nails fixed on the woodenware or ground.

43

KCP-230 Griphead

w/ Swivel 5/8” Pin

KCP-310 EZ Grip Finger

The 16mm socket (inside) or 28mm

(outside) attached to the ball joint pivots from -45° to 90° while the collar rotates 360° incorporated a 5/8” pin.

KCP-311 EZ Grip Receiver

The 16mm socket attched to the ball joint pivots from -45° to 90° while the collar rotates 360° incorporated a

16mm socket.

KCP-320 EZ Grip Twins

The 5/8” attached to the ball joint pivots from -45° to 90° while the collar rotates

360° incorporated a 5/8” pin.

KCP-340 Baby Plate w/EZ Grip Finger

The square plate attached to the ball joint pivots from -45° to 90° while the collar rotates 360° incorporated another

5/8” pin. (Plate size: 15cm x 9cm)

KCP-330 Tiny Clamp

Steel tiny clamp is ideal for clamping round tube from 2mm to 16mm.

Thumbscrew and 1/4” male thread with locking ring for mounting a camera, radio transmitter and lightweight accessories.

KCP-400

Aluminum casting clamp with 5/8” baby receiver for attaching to 35x35mm

KCP-420

Aluminum casting clamp with 5/8” baby stud for attaching to 35x35mm square pipe.

The same function as KD-CM16P but with 5/8’’ ( Baby) receiver.

Designed for mounting a small light instrument from a drop ceiling frame with the 5/8” (Baby) stud.

44

Four way clamp is constructed of aluminum dia-casting which is very lightweight and durable. The unique spring locking device makes locking just a snap and easy. The equipped

P.U. pad also reduces surface damage and enhance gripping action. This is for coupling onto any tube size from 35mm to horizontal way. The safety loading weight is up to

30KG ( 66 lbs)

KCP-950P 4 Way Clamp

for 35mm to 50mm tube

KCP-930P 3 Way Clamp

for 25mm to 35mm tube

Application:

Adapters connectted with

4 way clamp

KS-091

Lightweight aluminum 5/8” stud for grip head

(total length: 108mm)

KS-092

Lightweight aluminum 5/8”

Male Adapter

(total length: 66mm)

KS-093

Lightweight aluminum 5/8”

Female Socket Adapter

KS-094

Solid steel right angle baby stud

KCP-620P

Lightweight aluminum Petite

Clamp for 16mm (5/8”) tube

Application

With Camare Bracket

45

With Lighting Fixture

KS-058 Baby Offset Arm

The 380mm Baby Offset Arm with two baby pins and one baby receiver, mounts on a baby stand where a light cannot be placed as close as desired to a subject or need to come over the top of the set to hide the stand behind a set wall. Caution: When offsetting a light also offsets the weight, it is necessary to place a sandbag or counterweight to prevent the tipping of the stand.

KS-059 Junior Offset Arm

The 470mm Junior Offset Arm with a junior pin and receiver, offset a large light fixture from its stand.

Mounts to a stand with a junior pin top, with junior receiver which light can be mounted either over or under way (a safety linchpin is attached).

KCP-808 Baby Side Arm

Baby side arm with heavy duty coupler fits on diameters from 40-52mm tube with total length 380mm and double baby pins. This enables you to position of a light head or grip head at a lower position or mounts an additional light without the need for another stand.

KCP-809 Junior Side Arm

A heavy duty couplers with 380mm side arm and junior receiver which allow offsetting or adding a large light fixture on a stand either over or under way (a safety linchpin is attached).

46

KCP-806 Side Arm with Baby Pin/ Receiver

The same function as KCP-808 but specially design for tube size from 31cm (1.25’’ ) to 38cm (1.50’’ ).

For example, it can fit into C-stand tube size 35 mm (1.4’’ ). With the welding adapters included one baby pin and baby receiver, it offers the flexibility of connecting the small lighting fixture with the baby pin and other accessories with the baby receiver.

KCP-300 Articulated Arm

Articulated arm to lock and hold small lighting and effects in accurate position.

The end socket is a 5/8" baby pin on the outside which can hold small lighting fixture.

The inside is a 3/8"-16 thread which will accept the standard dot and camera accessories.

KS-019 Swivel Extension Arm w/5/8’’ Receiver

A mini extension arm with 5/8’’ baby receiver and a hexagonal stud on the other side for fitting into Convi clamp. The double ball elbow joint offering the ability to articulate the two sides in any directions.

KD-735P Mini Flex Arm with Alligator Clip

The Mini Flex Arm with Alligatoe Clip is a flexible arm with a 3/8’’ -16 female thread tapped inside

A baby 5/8’’ (16mm) stud on one side and an alligator clip on the other. It’ s the perfect accceeory to hold small items such as a mini flag or reflector. It’ s 11.4’’ ( 29cm) in length.

47

KCP-343 Flex Arm Kit for Dots and Fingers

The kits comes with a 14mm diameter, 45cm long double 3/8"-16 female threads flex arm and two adapters included KS-038 which is hex adapter tapped with a 3/8” -16 female thread at one end and a 3/8"-16 male thread at the other for connecting to flex arm with Convi clamp and KS-038DR which is dot receiver with 3/8"-16 female thread and 16mm O.D. as a baby pin. Each adapter can be fixed with included M4 set screw, it offers the flexibility to fix or unfix the adapters from the arm whenever there is 3/8” -16 threads available. It is good for positioning of small gobos, flags, reflectors, props or flash head.

KCP-344 Flex Arm

The 45 cm long flex arm comes with double 3/8"-16 female threads which connected with the brass made 3/8"-16 female and 1/4" male thread adapters. It works great with Convi clamp or stand with3 /8"-16

The same way to fix and unfix the adapters from the arm by set screws as KCP-343 and KCP-345.

KCP-345 Flex Arm for French Flag

The 45 cm long flex arm comes with double 3/8"-16 female threads which attached with one side zinc casting clamp for connecting to camera and the other side with French flag holder which hold the flag to block unwanted light from hitting lens usually resulting in a lens flare.

KS-050 Flag holder

Designed to fit on KCP-345 Flex arm and made of zinc casting material with M6 thread.

KCP-346 French Flag

Black Metal French flag for blocking lightings (40 cm X 25cm)

KS-038 Hex Adapter

Hex adapter with3/8''-16 male thread

KS-038DR Dot Receiver

Dot receiver with 3/8''-16 male

48

KCP-610 Foamcore Fork

Four pointed steel pins with balck powder coated to mount foam core and comes with a 5/8” baby stud. Desiened to stab it into the side of foam coreand and may mount it on a stand, grip head or

Convi clamp.

Weight: 0.4kg (0.88 lbs)

KCP-611 Foamcore Clamp

U-shaped steel holder with black powder coated to mount foam core and comes with a dia. 10mm chrome plated steel stud to connect with grip head. Two spike pins are attached with strings for securely fixed the foam core through the holes drilled on the both sides and the bottom of holders.

Weight: 0.5kg (1.76 lbs)

KCP-614 Adjustable Poly Holder

Adjustable poly holder is made by lightweight aluminum central tube and two durable extendable steel holders with anti-refection black powder coating. This is designed for any thickness of polyboard, or foamcore sheets from 91cm ( 3 ft) to 156cm (5 ft). The extendable clip equipped in the end of each holder is used to hold a polyboard parallel to the floor while the poly holder is in a vertical position. The central aluminum tube comes with a 14.5cm length steel baby pin with milled flat on one side for mounting on C-stand through grip head KCP-200 securely. U-shaped handle is also fixed on the central tube to make it easy for moving or adjusting the angle of poly holder.

Weight: 2.5 kg (5.5lbs)

49

KCP-380 Kino Flo Fluorescent Lamp Holder

Designed for holding a single Kino Flo T-12 fluorescent lamp / tube with double spring steel clips.

Swivel ball joint design comes with neck-embossed 5/8" Baby stud can neatly mount in a grip head, c-stand, or gaffer grip for offering multi-positions. Metal adjustable lever handle is designed for a specific handle position is desired. Weight: 300 g (0.66 lbs)

KCP-381 Off-Set Female Mounting Plate Adapter - 5/8"

The welded steel with chrome plated off-center adpater offers the excellent balance for the weight of fluorescent light on the center of a light stand.

KCP-724 Wall Spreader 2” x 4”

Designed for a background support, or an overhead beam to hanging lighting fixtures by placing cut lumber at each end. It can be used both horizontal and vertical positions.

KCP-650 Ruler Clamp

Locks onto posts, beams and objects with spans to 56cm(22”) to support one or more lights or flags by included adapter with two 5/8” baby studs.

Max. Length: 55cm(21.6”)

Available Link two for Extend

KS-055 Junior Multi Header

5 x 28mm socket & 28mm pin

Length: 100cm (39.37” )

KS-056 6 x lantern T bar

1420mm (55.9” ) long with

KS-034 stud

50

KCP-350B Mini Ali Clamp - Black

KCP-350P Mini Ali Clamp - Polish

A compact clamp with 35mm clamping range similar to the Ali clamp but smaller. One of the most useful tool for photographer, it can mount to the top of any lighting stand with 5/8” socket or stud to hold props, reflectors and background drop or clip a small light fixture for tabletops shooting.

5/8" Socket

71

KCP-360B Ali Clamp - Black

KCP-360P Ali Clamp - Polish

It is a handy multi-purpose steel clamp features three attachment methods: a spring-tension with rubber feet protection clamp which has a clamping range of 5-40mm, a 5/8" female socket and a 5/8” stud so it can be mount into a lighting stand, Convi Clamp, Super Viser or Grip Head to hold reflectors, gels, foam cores or flash securely in the studio and on location.

5/8" Socket

3/8"-16

KCP-390 Off Camera Flash Spring Clamp

100

Constructed by lightweight aluminum Ali clamp and sturdy steel ball head for off camera flash light in a variety of situations. The clamp also comes with adjustable aluminum cold shoes which offers not only different size holder of flash lights but also long-lasting operation than plastic one. It's easy and convenient to attach the clamp to the plank or tube from 5~40mm with the strong spring steel equipped inside the clamp. The 16mm stud with 3/8''thread hole and the sockets are attached with the clamp can be connected with light stands and unbrella.

The holes designed for umbrella

Application

51

KCP-101

MAX ARM

The Max arm is specially designed for lighting, video, film or stills use. The multi-positioning arm with 90° pivoting, 360° rotating ends and a 360° elbow rotates. The center adjustable lever handle to control and lock all three movements, which allows partial loosening for safe and precise positioning of a small light fixture or camera exactly at the angle you need it. Both ends come with a ball joint 5/8”(16mm) studs; one is tapped for a 3/8” and the other is tapped for a 1/4”.

It is so versatile that can be set at any awkward position or odd place.

1KG ( 2.21lbs)

4KG ( 8.8lbs)

53CM ( 20.8inch)

6 milling flats

Teeth-device Adjustable lever handle

Features:

1. Metal adjustable lever handle for easy making slight adjustment and can be rest to any angle.

Ideal for clamping in a confined space, or a specific handle position is desired.

2. The metal-like engineering thermoplastic friction discs with teeth design offers a solid grip.

3. The storage length is 28.5cm and fully extend to 53cm with net weight 1kg only for compact &

portable.

4. Both ball joint stud with multi-milling flats that can fit into baby socket fast and hold object stable.

KCP-101W MAX ARM WITH WHEEL HANDLE

The function is as the same as KCP-101 Max Arm but with wheel handle which comes with rubber cover. This is standard accessory designed to KCP-101W for more comfortable and better torque while tightening the round knob especially for those users without gloves in cold working environment. This is made by silicon rubber which offers excellent weather ability for long-lasting operation.

1KG ( 2.21lbs)

4KG ( 8.8lbs)

53CM ( 20.8inch)

52

KS-CB01 CAMERA BRACKET

This Camera barkcet is designed for Max Arm. Constructed by aluminum die casting which makes it very lightweight and durable. In addition to a standard 1/4-20 inch thread mount for a small camera, it also comes with a 1/4'' to 3/8'' adaptor to meet different size of thread mount. Meanwhile, there are four 3/8'' female sockets availble on the bracket that can be connected two max arms from each side gives the most stable. The 7mm female socket is also built for the need of the umbrella reflector.

Steadiest support w/ two arms

KS-CB02 Quick Release Camera Plate

The quick release plate is easy to set up and works great offering the ability to quickly move from tripod to hand held photography. Safety lock is also equipped to prevent the quick release from inadvertantly opening. The standard 3/8"-16 thread is tapped on the bottom and a 1/4"-20 reducer bushing is attached makes it compatible with flash brackets, tripods, light stands, Convi clamps, etc.

KS-039 Adjustable Cold Shoe Mount

It’s constructed by lightweight and durable aluminum providing a secure mounting option for virtually any type of shoe-mounted device - radio slaves, speedlights, light meters, etc. It also comes with spring-tensioned adjustment knob accepts to ensure strength and a secure fit to almost any flat foot of flash. Standard 1/4"-20 mounting thread is tapped on the bottom for quickly and easily attach to flash brackets, tripods, light stands, Convi clamps, etc.

KS-041 Hot Shoe Adapter 3/8" - 1/4’’ W/ Barrel Adapter

This adapter can fit on the hot shoe of most cameras. It terminates with a 3/8’’ to 1/4’’ threaded stud and is used as a Monitor Bracket or anything else that has a 1/4’’ -20 receiver. Two large knurled locking nuts are quipped for easy adjustment of the tension. It comes with a 1/4’’ -20 double female barrel adapter as the standard accessory that makes the 1/4’’ -20 receiver is available.

53

KCP-101CB Max Arm w/ Camera Bracket

This is specially-designed articulated arm with a camera plate and ideal for mounting a camera or a camcorder exactly at the position you desire.

Works perfectly with Convi. clamp KCP-700 by baby stud with 6 milled flats on the neck of the Max arm.

KCP-101QW Max Arm w/Quick Release Plate

A variable friction Max arm equipped with a quick release camera plate for precise position. Works perfectly with Convi clamp KCP-700 or any clamps with 5/8’’ baby receiver.

KCP-101K Max Arm Kit

The Same fuction as KCP-101CB but with more standard accessories included

Convi clamp KCP-710, Max Arm KCP-101,

Camera Bracket KS-CB01 and backlite base 013BS.

Applications of Max Arm

With convi. clamp for camera With suction cup for DV

With backlite base stand for camera

With two Max arms on the bike for camera

With convi clamp for lighting With convi. clamp for camera

54

KS-101 Umbrella Swivel Bracket

Umbrella Swivel Bracket is made of aluminum and with 5/8'' (16mm) receiver in both ends that can connect stands or accessories with baby pin to make aiming the light or flash easy with swivel design. The locking umbrella socket also accepts umbrella shafts up to 3/8" diameter.

KS-102

Same function as KS-101 but with KS-014R

& KS-015R which are two removable, reversible 5/8’’studs with 1/4"-20 and 3/8’’ threads; and can be mounted various attachments like umbrella’s, soft boxes, strobe's and speedlites.

KS-103 Versatile Swivel Adapter

Versatile Swivel Adapter comes with a two ball joint 5/8’’ (16mm) stud:, one is tapped for

3/8’’ and the other is for 1/4’’ , offers you to clamp onto a support at odd angles with stands or suction cups. Both ball joint stud alsodesigned to fit into baby socket likes convi.

clamp, super viser and hold object stable.

KS-104

Versatile Swivel Adapter w/ KS-CB01

Same function as KS-103 but with

Camera bracket.

KS-105

Versatile Swivel Adapter w/ KS-CB02.

Sames function as KS-103 but with

Quick release camera plate.

Application

55

KCP-102 VISION ARM

The Kupo Vision Arm is functional, reliable, and durable articulated arm designed for a monitor or light accessories. Two arms and two swivel ball-joint attachments are locked solidly by rotate the single central lever which is adjustable help easy change the position of lever for your desired position. In addition the hot shoe adapter 3/8’’ -1/4’’ w/ barrel adapter is equipped that easily allows you to connect together two things with different thread sizes

Weight : 300G ( 0.65 lbs)

Length: 25cm ( 10 inch)

KCP-730B PINCER CLAMP

Pincer clamp is the mini version of Convi clamp with super lightweight and compact size advantage.

The pad on the jaw provide stronger grip on the round, square and flat shapes. With 1/4" and 3/8" female sockets, it is an ideal for any lighting accessory.

Weight

130 Loading

5.5KG

Fit tube size : 13~35mm Fit flat surface size : 5~20mm

Features:

1. Two jaws are aluminum extrusion makes it robust and durable.

2. Ergonomic aluminum casting knob offers better grip.

3. 1/4’’ and 3/8’’ female sockets can be used simultaneously without space limitation.

4. Inside steel spring keeps the jaws move smoothly while twisting the knob.

Application

With KS-017 Universal 16mm Stud With KS-062 16mm Socket

56

With KCP-730B Vision Arm

Kupo Pumping Suction Cup offers a temporary solid light mounting solution for smooth, nonporous surfaces. Each Kupo Suction cup comes with 5/8” baby pin or 3/8’’thread bolt to allow you to mount small lights or accessories on windows, mirrors, automobiles, boats and any smooth, nonporous surfaces. Because of excellent rubber material with silicon, it can be used at temperatures from

-12 degree to 49 degree C. It’s pumping in any adverse shooting circumstances.

KSC-01

9” Suction Cup with 16mm

Baby Pin Position the cup pump the handle until the red line is hidden. Check the red line indicator on the plunger frequently. And re-pump it without removing when you find the red line out for safety.

Max. Loading: 10KG (22lbs)

Weight: 1.05KG (2.3lbs)

KSC-02

Double Suction Cup with 16mm

Baby Pin Position the cup, push down the handle to remove air from between the rubber pad and the contact surface. Pull the handle vertically and remove the cup when not in use.

Max. Loading: 15KG (33.1lbs)

Weight: 1.7KG (3.7lbs)

KSC-03

6’’ pumping suction cup with 3/8” -16 thread x 5/8” length stud for use with ball head camera mounts .

( Supplied with pad protector)

Max. loading: 32KG( 70 lbs)

Weight:0.45 KG( 1 lbs)

KSC-04

6’’ pumping suction cup with fixed baby pin ( Supplied with pad protector)

Max. loading: 32KG( 70 lbs)

Weight:0.47KG( 1 .1lbs)

KSC-05

6” pumping suction cup with swiveling adapter, KS-103, which is detachable. Both ends of adapter come with a ball joint 5/8’’

(16mm stud); tapped for 3/8’’ and 1/4” . With pad protector,

Max. loading: 4.5KG(9 lbs)

Weight:0.7KG( 1.54 lbs)

KSC-06

6’’ pumping suction cup with swivel baby pin which is fixed with cup

( Supplied with pad protector)

Max. loading: 20KG( 44 lbs)

Weight:1 KG( 2.2lbs)

Application

57

KUPOLE

is strong, durable and cool adjustable lighting pole system. The unique locking device made in casting provides the pressure and locking system for holding the Kupole in place.

● Deluxe aluminum casting handle incorporates a safety lock.

● It can be used in vertical or horizontal support of lighting or backdrop.

● 2 adjustable settings for a variable tension adjustment.

● Manufacturing in pole dia.45mm and 40mm and three overlapping size up to 370cm.

● Both silver anodized and black powder coat finish available.

KP-L2137BD

Weight: 2.85KG (6.3lbs)

Extends from 210cm(83” ) to 370cm(145” )

KP-M1527BD

Weight: 2.45KG (5.4lbs)

Extends from 150cm(59” ) to 270cm(106” )

KP-S1017BD

Weight: 2.0KG (4.4lbs)

Extends form 100cm(39.4” ) to 170cm(67” )

KP-L2137PD

Weight: 2.85KG (6.3lbs)

Extends from 210cm(83” ) to 370cm(145” )

KP-M1527PD

Weight: 2.45KG (5.4lbs)

Extends from 150cm(59” ) to 270cm(106” )

KP-S1017PD

Weight: 2.0KG (4.4lbs)

Extends form 100cm(39.4” ) to 170cm(67” )

KP-X15P

KP-X15B

Weight: 0.53kg (1.2lbs)

Dia.: 40mm

Length: 1.5m (59.1” )

KP-X20P

KP-X20B

Weight: 0.7kg (15lbs)

Dia.: 40mm

Length: 2.0m (78.7” )

Safety lock Adjustable setting Spring cushion Horizontal for lighting

Loading limits

- Picture 1&2 are valid for using with rigid floor and ceilings, and with the rubber pad attached

on the rubber cover.

- Picture 3 is vaild for operating with rigid wall to wall, and with the rubber pad attached on the

rubber cover.

1.

59

2.

3.

Rubber cover & Rubber pad of kupole

KP-SP02 White Top

Rubber Cover

KP-SP03 White Bottom

Rubber Cover

KP-SP01 White Rubber Pad

KP-SP04 Black Top

Rubber Cover

KP-SP05 Black Bottom

Rubber Cover

KD-B126P Kupole Base

The Kupole base is designed to convert Kupole to conventional stand whenever the ceiling is higher than 12' (3.6M) or a free-standing background is needed. The center base accepts

45mm diameter tubes. Leg diameter: 22mm with 49.6( 126cm) footprint. Just remove the bottom rubber cover, silde on tripod base then replace the cover.

With Kupole

KD-R48P Kupole Disc Base

Thsi is a sturdy 19'' ( 48.3 cm) diameter and weight 12KG round metal base for Kupole. Use them for a clean streamlined look and ideal for visual merchandizing or displays.

KD-C50P Kupole Suspended

Ceiling Adapter

Designed for connnecting Kupole from a drop ceiling frame with the equipped adapter.

With Kupole

KD-T50P Kupole Adapter

weight: 0.55KG

Fits tube size from 48-51mm OD.

It connects the Kupole with the Truss

60

Assembling Kupo background support accessories with Kuploes and Convi.

clamps can easily create your own background system for shooting without any tool. It is very simple, reliable and flexible to meet you requirements of paper roll background system in the studio or on location shooting.

KP-DS01 Background Paper Drive set

Kupo Background paper drive set is a pair of adapters that expand and lock securely inside the core of roll of seamless paper. One adapter has a plastic cog that accepts a plastic drive chain so that you can adjust the length of your background comfortably and a tension control so the background doesn’ t unroll by itself due to gravity. The flexibility of this adapter can fit to 46mm~78mm dia. tube size. ( The plastic chain and chain weight are included)

KP-KS01 Single hooks

The hook set is designed for paper drive set holder which connects with a pair of

Convi clamps, and a set of paper drive set. (Set for two)

KP-KS02 Triple hooks

The same function as KP-KS01 but can accept three paper drive sets to support three rolls of seamless paper. It can also be mounted on a wall with screws or

KP-KS03B Plastic chain w/ 3.5M length ( Black)

KP-KS03O Plastic chain w/ 3.5M length ( Orange)

KP-KS03W

KP-KS03BL

Plastic chain w/3.5M length ( White)

Plastic chain w/ 3.5M length ( Blue)

Plastic Background Driving Set Chain is a replacement plastic chain with 3.5M ( 137’’ ) length for the background paper Drive Set. Different colors of chains are designed for easy color identification of different color paper rolls which are used on the Triple hooks. There are four colors included Black, White, Orange and Blue available.

KP-KS03B KP-KS03W KP-KS03O KP-KS03BL

61

KP-KS04 Chain weight

This is a replacement Chian Weight to keep the plastic chain straight toward the ground. ( Black)

Chain weight with chain

KP-X245P Aluminum tube

The Background Aluminum Tube is equipped with an aluminum solid core which allows you to assemble two sections of the tube quickly and securely with Allen key. The aluminum tube is designed for sliding into the seamless paper roll to connect between paper drive set and paper roll to prevent paper roll being bent because of gravity. The tube size is dia.50mm with 2.75M (9’ ) length.

Tube in the paper roll

KP-KS05 Background baby hook

The hook is built by sturdy steel with anti-reflection black painting. This is designed to attach background paper drive set on the hook and easily connect a 16mm (5/8” ) stud on the top riser of a light stand. The unique design of 28mm OD can be also inserted into 28mm receiver after removing the knobs for the universal top head. In addition to the background paper drive set, the V shape hook can also accept the pipe size from 19~25 mm as the axis for supporting the paper roll. in 16mm baby stud

62 in 28mm junior receiver

KS-300 Tethermate

Tethermate is specially designed for professional photographer with a portable and temporary plate mounted on the stand for ‘’ Tethered Shooting’’ to connect DSLR with lap top. It features an adapter beneath the plate with two 5/8’’ (16mm) baby receivers and 1/4’’ & 3/8’’ female thread which can fit to stands, tripods, Convi. Clamp, Max arm in seconds. With the advantages of lightweight aluminum material and the compact size 17.5’’ X 11.7’’ ( 445mmX 297mm),

Tethermate is the ideal tethering plate for studio and location shooting especial for traveling instead of special dedicated base.

With light stand With tripod

Features:

1.Two baby receivers are designed for horizontal and vertical application.

2.Velcro is equipped through the holes for fastening any objects on the plate securely.

3.Round edge treatment of the plate for better user friendly.

Application:

With KCP-600 Super Viser With KCP-101 Max Arm &

KCP-700 Convi Clamp

With KCP-310 EZ Grip Finger

63

KSJ-100B

Demo Kits Set

KSJ-200P

Grip Car A

KSJ-300P

Grip Car B

KD-C01B

Curved Clamp - Black

For Dia. 35mm

KD-C01P

Curved Clamp - Polish

For Dia. 35mm

KD-C02B

2 Ways Joint - Black

For Dia. 35mm

KD-C02P

2 Ways Joint - Polish

For Dia. 35mm

KD-C03B

Joint with Screw - Black

For Dia. 35mm

KD-C03P

Joint with Screw - Polish

For Dia. 35mm

KD-C04B

Universal Joint - Black

For Dia. 35mm

KD-C04P

Universal Joint - Polish

For Dia. 35mm

KD-C0500

( 500MM)

KD-C1000

(1000MM)

KD-C1500

(1500MM)

KD-C2000

(2000MM)

KD-840LB Panel W/Hole - Black

(Length: 1080mm)

KD-840MB Panel W/Hole - Black

(Length: 825mm)

KD-840SB Panel W/Hole - Black

(Length: 440mm)

KD-841LB Panel - Black

(Length: 1080mm)

KD-841MB Panel - Black

(Length: 825mm)

KD-841SB Panel - Black

(Length: 440mm)

KD-842LB Extension Panel W/Hole - Black

(Length: 1080mm)

KD-842MB Extension Panel W/Hole -Black

(Length: 825mm)

KD-842SB Extension Panel W/Hole - Black

(Length: 440mm)

KD-843LB Extension Panel - Black

(Length: 1080mm)

KD-843MB Extension Panel - Black

(Length: 825mm)

KD-843SB Extension Panel - Black

(Length: 440mm)

64

Diffusion

Chromakey

Reflection

Demo Kit

Reduction

Swatch Book

Open End Net Kits

TEXTILE-OENK1218S

(12” x 18”)

TEXTILE-OENK1824S

(18” x 24”)

TEXTILE-OENK2436S

(24” x 36”)

TEXTILE-OENK3036S

(30” x 36”)

TEXTILE-OENK1218D

(12” x 18”)

TEXTILE-OENK1824D

(18” x 24”)

TEXTILE-OENK2436D

(24” x 36”)

TEXTILE-OENK3036D

(30” x 36”)

● Single black net

● Artificial silk

Butterfly Textile

● Double black net

● 1/4 sike

● Single white net ● Double black net

● Standard Bag / Deluxe Bag with Separated pockets

Note: The butterfly textile is supplied with the color bag. It is easy to distinguis the size by different color.

All Size of Flags and Open End Nets are Available!

Custom Designs Welcome!

65

Lightweight & low profile KUPO professional couplers are constructed from high tensile aluminum extrusion and have been developed for installations where load capacities of up to

500KG are required. The KUPO professional couplers combine strength and durability with a high degree of safety. The couplers are designed to fit tubes with diameter between 48mm-51mm.

Most have been tested and certified with TUV approval for a safe working load of 500kg.

The standard finish is polished. Custom color or logo is upon request.

"CAPTIVE", on top of thread bolt to avoid wing nut falling off the clamp in the air

Kupo half type coupler (KCP-831) is approved by TUV Product Service listed with a safety working load at 500kg

Constructed from a high tensile-strength

6061 aluminum-extrusion

Attach securely to tubes with outside

Dia.48-51mm

Standard in polish finished. Black is available to specify order

Nylon lock nut

Designed for safe connection in trussing system

66

KCP-810 ARCH COUPLER

Constructed from aluminum gravity casting.

Big handle for easily using without obstructive bolt to palm and the brace.

Counter sunk for M12/M10 Bolt & lock nut

Fits tube size from 38-51mm OD.

Working Load: 150KG (330lbs)

Weight: 0.68KG (1.5lbs)

170

KCP-820

SLIM TYPE SWIVEL COUPLER

Fits tube size from 48-51mm OD.

Allow a full 360 degree of movement

Drift pin for fixed in a 90 degree configuration

Weight: 0.70KG (1.54lbs)

Working load: 300KG (660lbs)

KCP-830

M12

SLIM TYPE HALF COUPLER

Fits tube size from 48-51mm OD.

Square counter sunk

Weight: 0.3KG (0.66lbs)

Working load: 300KG (660lbs)

KCP-831

HALF COUPLER

With a reated M10 x 28 bolt & lock nut

Suitable for use with large lighting fixture

Weight: 0.55KG (1.21lbs)

Working load: 500KG (1100lbs)

110

1/2"-12

KCP-831-T

HALF COUPLER W/T-HANDLE

KCP-831B-T

BLACK FINISH

With counter sunk for M10 x 28 bolt & lock nut

Suitable for use with large lighting fixture

Weight: 0.55KG (1.21lbs)

Working load: 500KG (1100lbs)

M10

50

KCP-832

SWIVEL COUPLER

Fits tube size from 48-51mm OD.

Allow a full 360 degree of movement

Drift pin for fixed in a 90 degree configuration

Weight: 1.20KG (2.64lbs)

Working load: 500KG (1100lbs)

130

79mm

M10

L30mm

67

KCP-833

EYE RING COUPLER

Incorporate a freely rotating M12 eye ring

Weight: 0.65KG (1.43lbs)

Working load: 500KG (1100lbs)

KCP-834

SPIGOT COUPLER

Incorporate a 28mm (1-1/8”) TV spigot

Weight: 0.75KG (1.65lbs)

Working load: 500KG (1100lbs)

KCP-835

TRUSS COUPLER

Suitable for all triangular/square truss sections

Weight: 3.30KG (7.26lbs)

KCP-836

STUD COUPLER

Incorporatea 16mm (5/8”) stud

Weight: 0.62KG (1.4lbs)

KCP-828

SLIM TYPE HANDCUFF CLAMP

Save time and effort in hanging fixture

Mounted with M10 bolt & lock nut

Weight: 0.45KG (0.99lbs)

Working load: 100KG (220lbs)

25

KCP-838

HANDCUFF CLAMP

Save time and effort in hanging fixture

Double level’s counter sunk for M10 or M12 hex.

head bolt

Weight: 0.85KG (1.87lbs)

Working load: 200KG (440lbs)

For Max

φ 50.8mm Tube

40

M10

M12

For M10 & M12

HEX Screw

68

KCP-838-T

HANDCUFF CLAMP W/T-HANDLE

KCP-838B-T

BLACK COLOR

Weight: 0.65KG (1.43lbs)

Working load: 200KG (440lbs)

79

KCP-839

HANDCUFF CLAMP W/STUD

With KS-090 yoke to stand adaptor 28mm stud 16mm socket

Working load: 200KG (440lbs)

M12 hole

KCP-840P

HANDCUFF CLAMP W/28MM SOCKET

Fits tube 48~51mmOD. Supplied complete with

29mm socket with the safety lock system

Weight: 1.05KG (2.31lbs)

Working Load: 200KG (440lbs)

KCP-847

TUBE/ BARREL JOINER

For quickly connectiong two tubes together end to end

Working load: 300KG (660lbs)

KCP-851

MIGHTY COUPLER

For 2.5” (60mm) truss system

Supplied complete with a rated M10 x 28 bolt & lock nut, suitable for use w/ large lighting fixtures

Weight: 0.60KG (1.32lbs)

Working load: 500KG (1100lbs)

KCP-857

MIGHTY HALF SWIVEL COUPLER

For 2.5” (60mm) to 2” (50mm) truss system

Easily fixed in a 90° configuration w/drift pin

Allowing a full 360° of movement

Weight: 1.20KG (2.64lbs)

Working load: 500KG (1100lbs)

For 2.5"

Tube

M10

121

For

2.5"Tube

For

2" Tube

69

KCP-801

250mm ARM COUPLER

KCP-802

500mm ARM COUPLER

KCP-901

BURGER COUPLER

Light-Weight coupler for small fittings

For 2” truss system

Coming with T-Handle

Black and silver available

Working load: 75KG (165lbs)

Weight: 0.2KG (0.44lbs)

100

30

KCP-902

BURGER COUPLER SWIVEL TYPE

For 2” truss system

Coming with T-Handle

Black and silver available

Working load: 75KG (165lbs)

Weight: 0.4KG (0.88lbs)

M10

KCP-860 NUGGET COUPLER

Fits the tube diameter 1.25~1.50”

Double level’s counter sunk for

M10 or 3/8” hex screw

Unique window for safety wire

Working Load: 120KG (264lbs)

Weight: 0.3KG (0.66lbs) 84.5

KCP-862 NUGGET COUPLER SWIVEL TYPE

Fits the tube diameter 1.25~1.50”

Coming with T-handle

3/8” hex screw

Working Load: 120KG (264lbs)

Weight: 0.6KG (1.32lbs)

M10

31.5

KCP-841P

ARCH COUPLER WITH 28MM SOCKET

Fits tube 48~51mm OD. Supplied complete with

29mm socket with pull-to-release safety lock

Weight: 1.38KG (3.03lbs)

KCP-873

45-DEGREE COUPLER

Swivel for every 45°

Tighten or release to turn through hex tool

No drift pin required

70

TV coupler is made to hook up the lighting equipment coming with a 16mm receiver or 28 mm spigot. It is equipped with a “safety linchpin” , a security device allowing user to preset it in the pin hole of 28 mm spigot before completely tightening and keeps cooupler from unexpected drop-off.

KCP-844 Sliver

KCP-844B Black

B2

B1

B3

TV Coupler

B4

B5

B7

B6

B8

SWL

B1

B2

B3

B4

B5

B6

B7

B8

Weight

Features:

1. Constructed by rugged aluminum die-casting with TUV Approval.

2. With a 28 mm junior socket for luminaire or telescopic hanger.

3. The 3/8” threaded 16 mm baby stud is also available and alternated

with 16 mm baby socket by spring latch bolt for lightweight luminaire and accessories.

4. Hook strut of top opening section limits the open pace that offers assistance to rig.

5. The safety wire is bult with the clamp to ensure this essential safety aid is always on hand.

6. Linchpin is attached with the safety wire to keep it safety for pan adjustment of luminaire

while the knob of clamp is loosen.

300 KG

86 mm

119 mm

Ø 48-51 mm

115 mm

32 mm

64 mm

Ø 28 mm

Ø 16 mm

0.90 KG

KCP-100B T.V. Clamp

The KCP-100 T.V. Clamp is a heavy duty casting C clamp and supplied with a Tommy bar to improve grip. It terminates in a 28mm(1-1/8” ) junior receiver. Collar ring on bushing for supplied safety hitch pin to pass through fixture spigot. There is a dedicated aperture in clamp body for attaching safety cable. This clamp works for diameter from 22-54mm round tube with load capacity 100kgs. It is ideal to hang all types of luminaries in T.V. studio and theaters.

B5

B3

B1

B4

B2

SWL

B1

100 KG

220 mm

B2

B3

120 mm

90 mm

B4

Ø 29 mm

B5 Ø 22-54 mm

71

C-06 Heavy Duty Iron Casting Clamp

The old C clamp or pipe clamp is designed for most hanging applications. Intend for use from

1-1/2” to 2” O.D. iron pipe in theater. 2-1/2” long steel shaft with 1/2” -13 yoke bolt and wash.

A square head pan set screw allows you to rotate the fixture. Comes in black powder coat finish.

B1

B3

SWL

B1

B2

B3

100 KG

170 mm

1/2”-13

Ø 38-51 mm

B2

Note: when using c-clamps care must be taken do not over-tight the pipe bolt which affixes the clamp to the batten. If this bolt is over-tighten, it can easily dimple or “drill” into the batten seriously compromising the strength of the batten. A finger tight plus half turn with the wrench is all that required.

C-16 Baby Pipe Clamp

It is identical old C clamp but terminated with 16mm baby stud. The collar on the top of baby pin keeps it safety for pan adjustment of luminaries while the knob of clamp is loosened. The safety wire is also built with the clamp to ensure this essential safety aid is always on hand.

B4

B2

B3

B1

B2

B3

B4

SWL

B1

100 KG

197 mm

70 mm

Ø 16 mm

Ø 38-51 mm

72

KS-089

UNIVERSAL TV QUICK RECEIVER

An aluminum quick receiver which accepts and holds captive 28mm DIN or Euro spigot

Affixing C clamp or stage coupler atop turns to be a professional TV clamp (C clamp or stage coupler is optional); assembly through long hex or wrench socket driver

Allowing 360° rotation

C-05/B Hook Clamp

Aluminum alloy/Black

Working load: 150KG (330.7lbs)

106

C-05QP Hook Clamp

Quick Release auminum alloy

Working load: 150KG (330.7lbs)

105

55

55

KS-013

Ø 17mm spigot wi/ washer

& lock nut for C-05 family.

3/8"-16

KCP-702 Stage Clamp with 14mm Hole

65

75

14

KCP-704 Stage Clamp with 28mm Stud

65

75

3/8"-16

KCP-703 Stage Clamp with 16mm Stud

65

75

16

KCP-705 Stage Clamp with 29mm Socket

77

96

29

73

C-12 Heavy Duty Steel G Clamp

C-12 is made of 8mm x 38mm rolled steel with protective tab. A Tommy bar is included to provide a beter leverage to tighten the pipe. It is ideal for hanging big lighting fixture like moving head and

M12x1.75

C-12 Silver

C-12B Black

109

64

72

127

55

WS-140 WINGNUT MULTI-SPANNER

Its application is tighten large & small wingnut without damage.

Fits M12, M10 & M8 Hex. bolts.

Carbon steel with heat treatment.

Easy to carry (it can be hang on belt by the hook) and nice looking. The features are impressed & practical

Application

● 3 x Hex Bolt

● 2 x WingNut

● 2 x SetScrew

● 1 x Key Chain

● 1 x Bottle Opener

● 1 x Flat Screw Driver

Kupo safety wire is fabricated of galvanized steel wire, and constructed in accordance with DIN3055 and DIN3060. It is used as secondary bonding for rigging, lighting and other equipments to truss or stand, rendering a secondary flexible coupling in additional to regular fixture. Standard finish is metallic silver and black coating is available upon request.

SW-01 Safety Wire

Dia. 3.2mm / 75cm length

Safety load 10kg (22lbs)

SW-03 Safety Wire

Dia. 5mm / 100cm length

Safety load 50kg (110lbs)

SW-02 Safety Wire

Dia. 3mm (with PVC coat) / 70cm length

Safety load 5kg (11lbs)

SW-04 Safety Wire

Dia. 4.5mm (with PVC coat) / 75cm length

Safety load 10kg (22lbs)

74

K-LOK

Features for K-LOK Single Pole Connector :

Kupo manufactures the highest quality single pole connectors available. Kupo cam-type connector has a superior non-conductive retaining screw that passed through the entire contact for superior durability. These single pole connectors have been designedwith ease of assembly and disassembly in mind, no special tools are required. K-LOK series connectors mate with competitive CAM products.

E332947

Non-metallic retaining pin provides superior durability and insulation

Wide range cable access from 0.33” to 1”

Double set screw terminations

Technical Information:

Voltage Rating 600V Maximum

Amperage Rating

Base Compound

400A Maximum

Santoprene 105

rated

Contact Material

Terminal Accommodation

Retaining Pin Material

Brass

#6, #4, #2, 2/0, 4/0

Phenolic

75

Color

BLACK

RED

GREEN

WHITE

BLUE

BROWN

GREY

K-LOK / Plug

K-KOL / Receptacle

Male

KL-400LMBK

KL-400LMR

KL-400LMG

KL-400LMW

KL-400LMB

KL-400LMBN

KL-400LMGY

Female

KL-400LFBK

KL-400LFR

KL-400LFG

KL-400LFW

KL-400LFB

KL-400LFBN

KL-400LFGY

Thread stud type

Male

KL-400SMBK

KL-400SMR

KL-400SMG

KL-400SMW

KL-400SMB

KL-400SMBN

KL-400SMGY

Female

KL-400SFBK

KL-400SFR

KL-400SFG

KL-400SFW

KL-400SFB

KL-400SFBN

KL-400SFGY

(compatible with major brands of power connectors)

Double set Screws type

Male Female

KL-400SSMBK

KL-400SSMR

KL-400SSMG

KL-400SSFBK

KL-400SSFR

KL-400SSFG

KL-400SSMW

KL-400SSMB

KL-400SSMBN

KL-400SSMGY

KL-400SSFW

KL-400SSFB

KL-400SSFBN

KL-400SSFGY

To fit smaller sizes of cable, the copper contact can be made with two smaller dimensions of cable-accessing hole upon request as following:

1. Dia. 16.90 mm (Large hole; standard K-LOK)

2. Dia. 14.60mm (Medium hole; upon request)

3. Dia. 10.40mm (Small hole; upon request)

K-LOK Dust Cover

Weatherproof snap back protective cover to fit all compatible brands of

400A cam type receptacles. Standard frame dimension allows retrofit existing application easily. The gasket offers a NEMA 3R rated environmental seal that provides a protection against falling rain, dust or frost, and also provides a safe way to cover exposed metal, while keeping the weather out when the receptacle is not use. Kupo Dust Cover is made from a high impact resistant, flame retardant ABS material and corrosion resistant stainless steel hardware. Five colors available for phase identification.

Cat. Number

KL-DCBK

KL-DCW

KL-DCB

KL-DCR

KL-DCG

Color

BLACK

WHITE

BLUE

RED

GREEN

76

KUPO 150A Single Pole Connector (Mini-Cam)

Mini-Cam is a series of 150 Amp light duty single pole connector in addition to heavy duty 400 Amp ones. Like its heavy duty family members, Mini-Cam is also constructed of Santonprene, possessing a superior performance in insulation. With enhanced features on safety designs and wider range of cable accommodation, Mini-Cam is the ideal and reliable connector for your own job.

Mini-Cam / Plug

Male

KL-150LMBK

KL-150LMR

KL-150LMG

KL-150LMW

KL-150LMB

KL-150LMBN

KL-150LMGY

Female

KL-150LFBK

KL-150LFR

KL-150LFG

KL-150LFW

KL-150LFB

KL-150LFBN

KL-150LFGY

Color

Black

Red

Green

White

Blue

Brown

Gray

The tension hole at rear side of split contact retains the contact from too much pressed, so as to prevent the loose mating after several time of uses.

Features:

• The boot is made of UV-resistance Santonprene, providing greater protection. Much safer and

more durable.

• There comes a POM (Polyformaldehyde) ring in between boot and contact, fully encompassing

the copper contact to make the first layer of insulation. The profile of this POM ring is 2 times

longer than the others as to provide better insulation.

• Wider range of cable accommodation from #8 AWG to #2 AWG (outside diameter up to 13.60mm);

those positions are clearly engraved on the boot for easy identification.

• Applied with same design as 400A ones, the contact comes with double set screws so the cable

can be firmly engaged in the position.

• Largely-ribbed housing provides comfortable and secure gripping; prolonged body helps user to

hold it firmly.

• Comes with two different length of set screw for maximum flexibility of matching different size of cable.

• Wire stripping scale is shown on the boot for user easy check-up while assembling the cable;

outstanding arrow point provides convenient mark for mating the connectors.

• Compatible with other brands of same 150A rated connectors.

• UL/cUL certificated

Panel Mount Type

• The design of KUPO Panel Mount baby cam

is same as Advanced Device’ s.

• The instruction on the backside of body.

• The thread bolt is 19mm.

Mini-Cam / Receptacle

Male

KL-150SMBK

KL-150SMR

KL-150SMG

KL-150SMW

KL-150SMB

KL-150SMBN

KL-150SMGY

Female

KL-150SFBK

KL-150SFR

KL-150SFG

KL-150SFW

KL-150SFB

KL-150SFBN

KL-150SFGY

Color

Black

Red

Green

White

Blue

Brown

Gray

77

B&B stands for Blue lid and Black body, is specially designed for entertainment industry, for 250 voltage rating identification and antireflection with matt black finish. That makes the connectors harmonized with the background during a presentation of a production. The professional connector also has CE approval and IP 44 rating to meet the safety standard. It can work stable in low and high temperature indoor or outdoor environment; and widely applied to factor power distribution system, machinery, building site, stage equipments etc.

More Features:

1. Screw-free to lock the housings by twist-lock action.

2. Easy press by needle nose of tool to unlock and twist to open.

3. Lockable cable gland for a quick and firm grip.

4. Adjustable inner gasket for different cable diameters.

5. Constructed by anti-corrosive, high dielectric shock-resistance material.

B&B

KHTN213

B&B

KHTN013

B&B

KHTN413

CEE FORM CONNECTOR

Cat. No.

KHTN013

KHTN014

KHTN023

KHTN025

AMP

16

16

32

32

PIN

3

4

3

5

DESCRIPTION cable male (B&B) cable male cable male cable male

Cat. No.

KHTN213

KHTN214

KHTN223

KHTN225

KHTN413

AMP

16

16

32

32

16

PIN

3

5

3

4

3

DESCRIPTION cable female (B&B) cable female cable female cable female panel female (B&B)

SCHUKO CONNECTOR

Cat. No.

131

AMP

16

PIN

2

DESCRIPTION cable male

Cat. No.

CZ03

AMP

16

PIN

2

DESCRIPTION panel female

KHTN014 KHTN023 KHTN025 131

KHTN214 KHTN223 KHTN225 CZ03

CEE TESTER

Convenient and hand-held device to carry out testing for CEE extension cable. Also capable of diagnosing the condition of lamp without taking lamp out of fixture. Built-in LED indicator showing test result.

Ci r cui t

Regular

Open

Ground

Bul b Regular

Broken

78

Rubber Distribution Box

Kupo Power distribution boxes are designed from the rubber material for the body and the 1.2mm thickness steel material for the sinking front panel. The rubber material makes the power distribution box stronger. It is sturdy, durable and lightweight. The internal wiring consists 1.5mmsq silicon cable as standard. The sinking front panel for a better protection of each connector. The following is the range of power distribution boxes, other variations of power distribution boxes are available upon request.

KRB-01 Rubber Distribution Box with Stage 3 pin connectors

* 275mm (L) x 100mm (W) x 50mm (H)

* with 4 channels stage 3 pin female socket & 32A CEE form Line male connectors.

* with 40cm cable (wired)

KRB-02 Rubber Distribution Box with CEE form connectors

* 275mm (L) x 100mm (W) x 50mm (H)

* with 3 channels CEE form female socket & 32A CEE form Line male connectors.

* with 40cm cable (wired)

KRB-03 Rubber Pistribution Box with SHUKO connectors

* 275mm (L) x 100mm (W) x 50mm (H)

* with 4 channels SHUKO form female socket & 32A CEE form Line male connectors.

* with 40cm cable (wired)

Custom Designs Welcome!

79

Head-to-Ballast Connector

The KUPO HB connectors' range is designed to meet the needs of head to ballast connections. HB series covers the range of power from 575W to 18KW used by Arri.

Features:

* Compatible with Veam CIR connectors

* Machined aluminum bodies with ribbed coupling ring to provide easy

manual coupling and uncoupling

* Back-shell with scratch-resistant and black anodized

* Back-shell and cable clamps to fit different cable O.D.

* Waterproof to IP67

* Solder Type

WPC-2806LM

WPC-2809LF

WPC-2806LF

WPC-2809LM

WPC-2407LF

WPC-2407LM

6 PIN 2806 7 PIN 2407 9 PIN 2809

BRAND

575W

1200W

2500W

4000W

6000W

12KW

18KW

Cross Reference for Various Brands

ARRI

2407-W

2407-W

2407-O

2407-O

2806

2809

2809

De-Sisti

2407-Z

2407-W

2407-O

STRAND

2407-Z

2407-W

2407-O

MOLE

2407-Z

2407-W

SUNRAY

2407-Z

2407-W

2407-O

LTM

2407-O

CINEMILLS

2407-Z

2407-W

2407-O

* We keep all the above models in stock for inline male and female assembly.

* WPC-2407 series is available in different key position arrangement for various

lighting fixtures; WPC-2806 & WPC-2809 series are only for 6K-18K Arri lights.

HEAD TO BALLAST CABLE

Cat. No.

HB-1.2K-7M

HB-1.2K-15M

HB-4K-7M

HB-4K-15M

HB-6K-7M

HB-6K-15M

HB-12K-7M

HB-12K-15M

HB-18K-7M

HB-18K-15M

Description

1.5mm 7M, WPC-2407LM-W+WPC-2407LF-W (ARRI 575W /1200W)

1.5mm 15M, WPC-2407LM-W+WPC-2407LF-W (ARRI 575W/1200W)

2.5mm 7M, WPC-2407LM-O+WPC-2407LF-O (ARRI 2500W/4000W)

2.5mm 15M, WPC-2407LM-O+WPC-2407LF-O (ARRI 2500W/4000W)

3C x 16mm+3C x 1.5mm 7M, WPC-2806LM+WPC-2806LF (ARRI 6000W)

3C x 16mm+3C x 1.5mm 15M, WPC-2806LM+WPC-2806LF (ARRI 6000W)

4C x 16mm+5C x 1.5mm 7M, WPC-2809LM+WPC-2809LF (ARRI 12KW)

4C x 16mm+5C x 1.5mm 15M, WPC-2809LM+WPC-2809LF (ARRI 12KW)

4C x 16mm+5C x 1.5mm 7M, WPC-2809LM+WPC-2809LF (ARRI 18KW)

4C x 16mm+5C x 1.5mm 15M, WPC-2809LM+WPC-2809LF (ARRI 18KW)

80

Kupo Caps

Material: 100% cotton twill

KCAP-01

Features:

* Adjustable Velcro closure

* 6 Panel cap

* Full Lining

* Aluminum eyelets

* Perfect embroidery

* High Quality KUPO Label

* Good Ventilation

* Fit to Distinguish Different Duties on Location

Kupo Cap - Grip

KCAP-02 Kupo Cap - Lighting

OEM Welcome, Various Colors, Size and Customized Logo Are Available!

Director Chair

Due to popular demand Kupo now offer a range of light weight Aluminum directors chairs. Perfect for

Backstage, Studio or Location. They are an industry standard seating solution.

KAC-01

Standard Director Chair

A Table height chair at 18” (475mm) These Chairs are casual functional, versatile and come with side table and bag for more applications.

81

Kupo Director chair is available in

Black Blue Synthetic Canvas.

Personalised embroidered inscriptions or silk screened logos available on Request.

Sand Bags

The KUPO solution to stabilizing equipment is supplied empty for economy of freight and means you can choose your preferred and locally available anchoring medium be it sand, shot, washer centers or lead weights to a maximum 35 lbs / 15 kg.

Designed in the versatile ” sanddlebag” system the Kupo bags can either

Featuring:

Extra rivets combined with double stitching and Bias bindling inside for maximum strength.

Longer and wider carry strap for ease and comfort.

A generous Velcro seal of the highest available quality to ensure your load remains secure.

A Plated metal hanging point for secure non slip fixing in handging mode.

Double handle for easy use. One is short handle in the top ; The new design is the butterfly handle with Velcro on the back!

Kupo Bags come with the Kupo lather logo on.

Butterfly Handle

Custom Designs Welcome!

KSD-1680A

Dimension : 24cm (9.5” ) x 18cm (7” ) x 5cm (2” )

Construction : Reinforced Double Ply Nylon

Maximum loaded weight : 15 lbs / 6 kg

KSD-1680B

Dimension : 30cm (11.8” ) x 24cm (9.5” ) x 6cm (2.4” )

Construction : Reinforced Double Ply Nylon

Maximum loaded weight : 25 lbs / 11 kg

KSD-1680C

Dimension : 36cm (14” ) x 33cm (13” ) x 6cm (2.4” )

Construction : Reinforced Double Ply Nylon

Maximum loaded weight : 35 lbs / 15 kg

Application

82

Kupo Professional Kits Bags

Include:

Weatherproof

All Fabric used are fully treated with a ”teflon” fabric protector to repel watered in the process spills and stains that will diminish the appearance of your bag.

Level IV color

All Fabrics used conform with the highest specification Level 4 color fastness. With its associated high UV rating they resist fading even when exposed to theh harshest conditions.

Super-Strong Stitching

Using Advanced technological processes; the accuracy, and quality of the nylon stitching makes for the highest structural integrity creating incredibly reliable and durable bags designed for the most rugged of situations. These bags work hard and play hard!

KSD-LB01 Lighting Kits Bag

(I.D.: 80cm x 23cm x 23cm)

31.5” x 9.0” x 9.0”

Material:

*100%Nylon 1000Denier

*Tifco tactical buckle

*100%Nylon strap

*Dupont Teflon fabric protector

Custom Designs Welcome !

KSD-LB02 Grip Case - Black

Outside dimensions:

60cm (L) x 39.1cm (W) x 23cm (H)

23.6” (L) x 15.4“ (W) x 9.0” (H)

Weight: 7.8kg (17.2lbs)

Inside dimensions:

53.8cm (L) x 32cm (W) x 19.2cm (H)

21.18” (L) x 12.6” (W) x 7.6” (H)

Weight: 7.8kg (17.2lbs)

Replacement padded divider

* Watertight, airtight, unbreakable, crrosionproof and dustproof.

* With the retractable extension hanlde and wheels for traveling.

* With the balance air valve for opening the case cover.

* With the tool bag and paper bag inside.

83

KU-HAND

is designed for multi-use to protect users. Its applications could be rigging, staging, grip, installation. The ergonomic design brings comfort and fit for everyone. Plenty of unbelievable features favor all users. Leather top is excellent on ventilation with padded mesh. Also, the two-way stretch of leather top creates flexibility. Synthetic leather palm is soft and durable, and also has extra layer leather for better protection. The extra layer leather not only on leather palm but also on index finger and thumb for extra strength. Morever, smooth surface of fingers and reinforced fingertips make perfect on handling objects and reduce wear. To conclude, KU-HAND is your best partner that you cannot miss to achieve any kind of job.

KH-55 Series

Goat leather

KH-66 Series

Cattle leather

Heat resistance

Cat. No.

KH-55 MB

medium

KH-55 LB

large

KH-55 XLB

extral large

KH-55 XXLB

Double extral large

Cat. No.

KH-66 L

large

KH-66 XL

extral large

KH-66 XXL

Double extral large

Perfect for handling any work even the toughest - Top Quality

84

Gaffer Tape

KUPO delivers highly versatile and popular GAFFER TAPE widely used throughout the professional stage lighting/ photography/ motion picture/ television industries for holding and sealing applications.

Kupo GAFFER TAPE performs excellent over a wide range of temperatures, both indoors and outdoors.

However, it has highest tensile of any GAFFER TAPE, it is easily hand tearable. With hand tearable

GAFFER, you can do your work efficiency.

6 most requested colors of GAFFER, 4 most requested colors of MATTES GAFFER are available

Clean removal, leave with no residual non-transferring, high

Performance adhesive system

Size: 50mm (W) x 50M (L)

Baking Material: Cloth-WaterProof

Adhesive: Rubber Base

Heat Resistance: 80 degree C

Outstanding conformability to odd-shaped and irregualr surfaces

Gaffa Tape Matte Gaffa Tape Gaffa Tape

(GT-550BY)

Anti-slip Tape

(GT-550AS)

GAFFA TAPE

Cat. No.

GT-550B

GT-550W

GT-550G

Description

GAFFA 48mm x 50M Black Color

GAFFA 48mm x 50M White Color

GAFFA 48mm x 50M Gray Color

GT-550BU

GT-550R

GAFFA 48mm x 50M Blue Color

GAFFA 48mm x 50M Red Color

GT-550GN

GT-550BY

GAFFA 48mm x 50M Green Color

GAFFA 48mm x 50M Black & Yellow Color

MATTE GAFFA TAPE

Cat. No.

Description

GTM-550B

GTM-550G

GTM-550BU

MATTE GAFFA 48mm x 50M Black Color

MATTE GAFFA 48mm x 50M Gray Color

MATTE GAFFA 48mm x 50M Blue Color

GTM-550GN

MATTE GAFFA 48mm x 50M Green Color

Anti-slip Tape

GT-550AS Anti-Slip tape, 48mm x 5M Black & Yellow

85

EZ-TIE

is ideal for sound, lighting and audio/video equipment cable. EZ-TIE is made by Swiss-made looms and strict quality control to assure consistent quality with superior performance. Hook is made from A grade Nylon and has high peel and shear values with extended cycle life with average 55 hooks per sq inch. It is forming with high temperature to keep a better elastic and durable. The Un-Napped loop brings a very high cycle life with average 42 woofs per sq inch.

EZ-TIE has been tested under +93 degree C and -56.7 degree C for lasting 1000hrs matting without failed. The working temperature from 80 degree C to -20 degree C. High cycle life with over 10,000 closures. Washable, UV resistant to prevent discoloration.

The standard EZ-TIE available in two different sizes and five different colors:

Size (cm):

2.0 x 41 (EZ241)

10pcs per pack

5.0 x 60 (EZ560)

5pcs per pack

Colors: Black (B), Red (R), Yellow (Y), Blue (BU), and White (W)

Please specify color code when order

* allows to organize cables neatly with ease

* can be used as an identification labels

* cable management

* ideal for wrapping stand legs

* perfect for use to strap the equipments to desk

* double "O" ring buckle designed makes easily for extand

* can be used as a temporary hanger for during installation

* double "O" ring buckle designed features to against many surfaces to hold any kinds of equipment

MEZ-TIE

MEZ Tie features molded precise hook, which is lighter and thinner than EZ Tie. The gap between hook and loop is only 1mm, whereas EZ Tie is about 2~3mm. Though it is thin, it still provides fasten thoroughly and super strong shear strength (average over 1200 g/sq.cm)

Cat. No.

EZ241-B

2.0 x 41 cm black

EZ241-BL

2.0 x 41 cm blue

EZ241-R

EZ241-W

EZ241-Y

Description

2.0 x 41 cm red

2.0 x 41 cm white

2.0 x 41 cm yellow

Cat. No.

EZ560-B

EZ560-BL

5.0 x 60 cm blue

EZ560-R

EZ560-W

EZ560-Y

Description

5.0 x 60 cm black

5.0 x 60 cm red

5.0 x 60 cm white

5.0 x 60 cm yellow

Cat. No.

MEZ220-B

MEZ220-BL

MEZ220-R

MEZ220-W

MEZ220-Y

Description

2.0 (W1) / 1.3 (W2) X 20 cm (L) black - 50pcs per pack

2.0 (W1) / 1.3 (W2) X 20 cm (L) blue - 50pcs per pack

2.0 (W1) / 1.3 (W2) X 20 cm (L) red - 50pcs per pack

2.0 (W1) / 1.3 (W2) X 20 cm (L) white - 50pcs per pack

2.0 (W1) / 1.3 (W2) X 20 cm (L) yellow - 50pcs per pack

Owl cable clip

Owl cable clips are designed to hold the standard power cable along with the lighting stand or round tube in studio or on location. It is made of durable, flexible, one piece injection PC molded with a lowkey transparent finished. The cable clips accommodate two 3cx1.5mmsq and one 3cx0.75mmsq wires through. Owl clips are reusable and easy to mount onto 40-50mm tube in one hand operation. Lets you organize and route wires just about any way you want to. Owlet clips with the same function as Owl clip but fitting smaller tube for 25-35mm O.D. (4 per pack)

KD-C40P

Owl Clip (for 40~50mm )

KD-C25P

Owlet Clip (for 25-35mm )

86

Color Correction Series

Kupo Color Correction Filters are used in applications where it is desirable to change color temperature of various light sources. These subtle and less saturated tones are ideal for Film,

Movie, Photo Schemes. Better than gels!

Tungsten Conversion

Full C.T.B.

Converts 3200°K sources to daylight

Daylight Converison

Full C.T.O.

Converts 5500°K sources to 3200°K

Half C.T.B.

Converts 3200°K sources to 4200°K

Quarter C.T.B.

Converts 3200°K sources to 3600°K

Half C.T.O.

Converts 5500°K sources to 3800°K

Quarter C.T.O.

Converts 5500°K sources to 4500°K

Now we have a full series of CTO/CTB for ARRI Lighting.

* Glass Materials: Borofloat Glass

* Maximum Operation Temperature: 450 Degree C

* Cutting Tolerance : +/-0.1mm

* Thickness: 3.3mm

* Color Tolerance: +/-5nm of designed half height

* All filters come with the Metal Frame.

(Bigger filter will have the protected net.)

Frame Net For Better Protection.

Big Size Only!

CTB Tungsten Conversion:

KCTB-001 For ARRI Junior 300W

KCTB-002 For ARRI Junior 650W

KCTB-003 For ARRI Junior 1000W / Studio 1000W

KCTB-004 For ARRI Junior 2000W

CTO Daylight Conversion:

KCTO-001 For ARRI Compact 125W

KCTO-002 For ARRI Compact 200W/ Par 200W

KCTO-003 For ARRI Compact 575W / Par 575W

KCTO-004 For ARRI Compact 1200W

Custom Designs Welcome!

87

KCP-347 Wooden type C47 clothespin,

Wooden spring-type clothespin also called C47 is used to attach gels and diffusion to lighting fixtures and bran doors without heat transmission from the hot light. Also ideal for dying film and printing in the darkroom use as clips (50PCS per bag).

KCP-347 Package Application

Honeycomb

Honeycomb is made up of the aluminum foil with a hexagon shape. It can be a shild to prevent the dazzle of illuminators.

Features:

Dazzle prevention

Light weight

Control the light path

Quality approval:

RoHS certification

The consistency of painting coating

No painting fading under UV illumination

With 250 degree C heat resistance

Honeycomb with frame

Kupo is a professional manufactory.

We are very good at the hardware producing.

The Honeycomb can come with any kinds of frame you need by OEM base!

Custom Designs Welcome!

88

Specification:

Material : Aluminum foil

Color: Black , Silve

Available size

Square : 30mm - 300mm

Round: 30mm - 300mm

Available Thickness (Height)

3mm - 15mm

Aperture Size:

(1) 1/8” : 3.18mm

(Available thickness: 3 - 5mm)

(2) 3/16” : 4.76mm

(3) 1/4” : 6.35mm

KUPO X-Bone

is an ideal solution for needs on the move, featuring light weight, compact and durable.

The patent structure makes it easy to fold and unfold in minutes, and aluminum alloy makes it light but sturdy for frequent usage. Six different size of length leaves versatile appearances and applications.

Features:

(1) made of high intensity aluminum alloy (6061), enduring deformation and load for 4.8~5.0 tons /

square meter

(2) compact, light weight, and easy to build up and break down in around 2 minutes per set; need

less space to archive

(3) stylish and slim profile; treated with anodized coating for rust-free

(4) different sizes make flexible applications accessible

Item number

Accessory Kit

Plastic Foot Pad

KXB-001P

Cam-step is an ideal to location shooting specially designed for photographers, videographers and anyone who needs temporary platform with compact size, lightweight and easy to deploy. It can be set up within 1 min by one person without any tool. Also, aluminum material of the plates and legs which stored well with supplied bags makes cam-step lightweight and convenient for storage and transportation. Size: 900mm x 900mm, Weight: 16KG, Height: 840mm, Max. loading: 400KG.

The whole set cam-step are included:

1) Foldable aluminum legs ( I pc per set).

2) Two bags for legs, plates and holders.

3) Plate- holders ( 2 pcs per set)

4) Sturdy and lightweight aluminum plate ( 3 pcs per set)

TOOL

FREE

89

CABLE CROSSOVER

The cable crossover is the cable protector that protects cables from moisture, oils and solvents, and is hight impact and load bearing. The standard KUPO cable crossover is 3 cable ducts and

5 cable ducts made from high density pressure moulded latex, back with highly visible orange lid.

Each cable crossover has dog bone connector ends that can be connected to create any desired length. Easy to operation and protect a cable accross an average interior doorway. The operating temperature is -40 degree to 49 degree and the load bearing capacity is 2,000KG.

Part Number

KCG-301-B

KCG-501-B

35

35

310

42

18

485

42

40

65

55

90

Descrip ti on

3 CABLE DUCTS

Insulated: YES

Length: 1000mm

Width: 310mm

Height: 55mm

Ducts Height: 35, 35, 35mm

Max. Load: 2000 Kgs

5 CABLE DUCTS

Insulated: YES

Length: 770mm

Width: 485mm

Height: 65mm

Ducts Height: 42, 42, 18, 42, 42mm

Max. Load: 2000 Kgs

Weight (kg)

15

18

DigiFan DF-500

is a powerful and versatile special wind machine designed for studios, theaters, theme parks, touring, photographic and more. It is suitable for wide range application including blowing haze, smoke, bubbles, confetti or snow, cooling performers, dimmer racks or amplifiers even drying paint in studio. DF-500 can be controlled through standard DMX signal or master/slave operation through data link.

• Versatile yoke for overhead rigging, floor sitting or stand mounting.

Housing is constructed from a molded lightweight plastic venting

device with rugged tubular steel surrounded for transport and protection.

• The 11” one-piece blade and spiral front grill for creating narrow focus wind stream.

Compact, lightweight and powerful.

Specification:

• Power input: 80-240V AC, 1200W, Current Max. 10A.

One touch turbo function: 0-3500RPM within 5 sec.

• DMX mode: DMX on-off and volume control

• Memory: 9 mode memory setting available

Remote controller: Supplied w/3M cable

• Motor: 500W, Max. 3500RPM

Air volume: 1700CBM/hr

• Wind speed: 60KM/hr

• Dimension: 480x560x460mm

Weight: 12.5Kg

Four reasons DigiFan makes a vortex wind effect:

11” one piece deep pitch blade churn through the air, maximizing the amount of the air moved with the each turn of powerful motor.

The spiral shape designed front grill offset the direction of the air as it twists off the blade. This allows the air to travel long distance.

Air inlet duct tube ensures that the deep blade are fully enclosed in a cylindrical duct, air is sculpted into a column(beam of air).

91

To combine deep pitch blade, spiral grill, ducted tube and a switching power supply the multi function Digi fan is able to create a fully controllable vortex wind effect.

MPS-60

The MPS-60 is highly regulated 27VDC, 3.8Amp (cont.) power supply capable of supplying up to 60 BSP-1 beltpacks with all signal lights lit. It may be rack mounted or used as a table-top unit.

* Power required: 90-240VAC, 0.05A (None load),

[email protected] DC output 50-60Hz

* Power output: 27VDC+/-0.5V, 0-3.8A

* Audio termination: 200 Ohms unbalanced

* dimension: 4.5 x 48 x 23 cm, 1U high

* Weight: 3.5kg (7.75lbs)

BSP-1

BSP-1 is portable long-life comfort headset station. The easily control top panel for switching the microphone on and off, controlling listing level and signaling. The steel plate belt is elasticized for comfortable using. Compatible with all famous popular headset intercom.

* Headphone output:

9-4K Ohms acceptable, 200 Ohms ideal

* Sidetone rejection: >50db

* Dimension: 93.98 x 109.22 x 63.5 mm

* Microphone input: 300-600 Ohms,dynmaic

PS-30

* Power supply: 110V-0.2A/220V-0.1A, 50-60Hz

* Output: Max. DC24V/1.0A

* Auto: Max. DC27V/1.7A

* Dimension: 45 x 260 x 104 mm

* Weight: 1.8kg

SMH-075

Earphone fq.:80Hz-110KHz

Sensitivity: 90db

Max. Power: 200mw

Limpedance: 200Ohm

T.H.D.: <2%

Connector: XLR-4pin / 1.5M

DMH-075

Microphone: Dynamic, 200hms

Sensitivity: 90db

Max. Power: 200mw

Limpedance: 400Ohm

T.H.D.: <2%

DMH-095

Microphone: Dynamic, 200hms

Earphone fq.:30Hz-10KHz

Sensitivity: 90db

Max. Power: 200mw

Limpedance: 200Ohm

T.H.D.: <3%

TALKBACK LOUDSPEAKER STATION

TLS-3

is a remote, 3-channel, selectable talkback speaker

device, with the function to talk and/ or listen on the given channel. TLS comes with built-in 5W quality speaker and amplifier to monitor the communication clearly. LEDs on panel indicate which channel is selected or unselected to monitor. Receive- only provides paging function to existing intercom system without having to install separate paging amplifier and speaker. TLS-3 has a gooseneck-mic socket and feedback control circuit, giving hands-free full-duplex comunication without a headset.Power Input: DC/24-30V;

Max. 500mA Headset Mic Input: 200~600 Ohms, Dynamic

Headphone Output: 200 Ohms ideal

Audio Speaker Output: Max. 5W; 94db SPL at one meter

Dimension: 11.00 x 26.50 x 17.00 cm

Net/ Gross Weight: 4.0/ 4.5 KG

The

IFP-100

is an active device, used for feeding a signal into your intercom system from an external source, or for feeding a signal from your intercom system to another audio device (or both).

The IFP-100 accommodates a wide range of input and output levels; it contains a studio quality microphone transformer and accept a signal directly from a good quality, low impedance, balanced or unbalanced microphone, as well as line-level signals. In every pack the two systems being interfaced are transformer isloated from one another, provided the IFP-100 is used as directed.

Power Input: DC/24-30V

Input: -20db (High); +3db (Low)

Output: +3db/ 600 Ohms balanced

Dimension: 12.50 x 5.00 x 10.50 cm

92

FogMate is Kupo's latest contribution to the field of special effect. This miniature fog generator is driven by compact rechargeable DC12V battery and equipped with built-in microprocessor to control and present all the functions. With its light weight and small dimension advantages,

FogMate can be set promptly and flexibly where fog is needed. FogMate is an ideal alternative to the traditional fog machines for the locations of theatre, TV, film and photographic studio.

Standard Package:

FogMate Unit

- DC12V battery

- 100V to 240V AC

12V DC charger

- Fluid tank

- 500ml fluid

- Portable case

D-5000

Fogmate

Features:

* Power output: 70W

* Voltage: 12V battery

* Warm up: 1second

* Tank Capacity: 110ml

* Fluid consumption: 2ML/ min.

* Continuous output: 10min.

* Weight of unit: 900g

* Weight of battery: 680g

* Dimension: 226 (L) x 68 (W) x 113 (H) mm

DCP-12

120V - 230V AC to 12V DC transformer with dummy battery

MCR-1

Remote Controller

MCT-1

Timer Controller

93

FLQ-500

500ml Liquid

The

PG-400

Silk is a professional mist producer. It provides a light constant mist to enhance light beams. No more problems that you have met in the traditional fog machines. PG-400 Pro-Silk comes with a high quality air compressor instead of the heater and temperatrure control. Designed for movie, T.V. studios and live show....

Features:

* Fine & long hanging haze

* Leave no oil residue

* Built-in fan

* No need warm up, instant operation

* Powerful compressor for a bigger volume

* Portable and compact size

* Low oil consumption (1 liter liquid for 28Hrs.)

* Special designed tank to protect from liquid spill out

HC-1

Timer Controller

HC-1 is a special designed optional accessory for PG-500 and PG-400 haze machine.

It can control the haze output at intervals of 10-300 seconds with duration of 10-120 seconds.

Feaures:

* Dimensions (mm): 480(L) x 320(W) x 357(H)

* Weight: 21kgs

* Power Consumption: 250W

* Power: AC120V/ 60Hz or 230V/ 50Hz

* Cable Length: 10m

Optional Accessories

HCR-1

Wireless Remote Controller

Wireless remote controller for

PG-500 and haze machine.

Features:

* Wireless, up to 50m

* Connector: 1/4 stereo

LIQUID

HZL-1

is oil-based. It is a non-toxic solution that produces a pure translucent haze with an long hang time and low moisture content.

HZL-1W

is water-based. Both are 1 L for haze machine and comply with the strictest health and safety regulations.

94

M-5

Z-20

Fog Machine

Timer Controller

The features of M-5 is its tough and powerful output and added DMX control on-board. User can have completely control of his /her fog machine to create a totally extreme club atmosphere.

Features:

* Power: AC120V/ 60Hz, 230V/ 50Hz

* Heater: 1,500W

* Output: 20,000 cubic ft/ min.

* Tank Capacity: 10 liter

* Remote included: Z-20 (timer)

* Optional remotes: Z-30 (wireless)

* Weight: 15kg

* Dimensions (mm): 659(L) x 319(W) x 170(H)

Z-20 is the timer controller that timer with interval, duration and volume; continuous fogging; manual on/off cable lenght: 8m connector: 5PIN XLR

Optional Accessories

Z-30 Radio Wireless Remote Control

Cable length : 2M

Wireless range : up to 50meters

Connector : 5pin XLR

Radio frequent add : 0~8

LIQUID

FL-104 light fog liquid for fast dissipation (4L) FL-204 light fog liquid for long lasting (4L)

FL-104

FL-204

95

S-200 Silent Snow Dropper

* Power Consumption: 600W

* Output: 140ML/ min.

* Tank capacity: 5 Liter

* Weight: 12kg (26.5lbs)

* Power: AC120V/230V, 50Hz/60Hz

Features:

* The powerful big output S-200 can make an

abundant supply of snow and shoot at

considerable distance.

* The motor is attached with a rubber cushion that

reduces vibration and noise, generating only 63dB

that is as loud as people whisper lighty..

* Size & output volume of it can be regulate by

remote control SC-2.

* Function of series connection is available.

* Quick evaporation residue to keep a safety

environment.

* Supplied with remote control SC-1 and hanging bracket.

Snow Liquid

FL-203

snow juice designed for S-200 snow machine.

water based formula (safe) non-toxic and 100% biodegradable.

BM-0800 Super Bubble Machine

BM-0800 is designed to produce a solid, copious stream of bubbles. It can be operated continuously. Easy refills and its hanging bracket are its benefits.

Features:

* Optional Remotes: BCR-1

* Dimensions (mm): 341(L) x 170(W) x 172(H)

*Power Consumption: 25W

* Tank Capacity: 0.7 Liter

* Fluid Consumption: 2hurs / Liter

* Weight: 4.2kg

* Power: AC120V/240V, 50Hz/60Hz

Bubble Liquid

It is designed for use in the BM-0800 bubble machines, water based composition that creates vivid transparent bubbles, colorless, odorless and non-flammable

BL-1 bubble liquid (1L)

BL-5 bubble liquid (5L)

96

Description

Folding Base Mini Stand

Page

3

Pole for folding mini stand

Backlite base w/ female socket & KS-017 stud

28

3

Midi Pro Stand

Midi Pro Stand w/Air Cushion

Low mini Kit Stand

Mini Kit Stand

Mini Kit Stand - Japanese Type

Baby Stand Extension

4

28

3

4

4

4

Medium Stand

Handy stand

Stand Extension

16A/3P/230V(Shuko), Cable Male Connector

Midi-Max Kit Stand

Midi-Max Kit Stand - Japanese Type (Black)

Midi-Max Kit Stand - Japanese Type (Polish)

Master Heavy Duty Junior Stand

High Baby Stand

Master Classic Stand

Master Shorty Stand

Low Mighty Baby stand

Medium Baby Kit stand

9

9

9

9

28

78

4

3

10

6

6

16

6

Baby Kit Stand

Baby Kit stand W/ square legs

Universal Stand

Universal Stand w/Air Cushion

Universal Stand - Japanese Type

Master Combo HD Stand

Master Combo HD Stand - Japanese Type

Master Combo HD Stand

Master Combo HD Stand - Japanese Type

Master Combo Alu Senior

Master Combo Alu Senior - Japanese Type

Master Combo Stand - Black

Master Combo Stand - Polish

High Roller Stand

Low Mighty Stand

Low Mighty Stand - Japanese Type

Junior Roller Stand

Junior Roller Stand - Japanese Type

Senior Roller Stand

Runway Base Stand

Universal Floor Stand

Followspot Stand

2 SCT. Wind-up Followspot Stand

2 SCT. Wind-up Stand

Base Plate (Set of three)

3 SCT. Wind-Up Stand Black

3 SCT. Wind-Up Stand

3 SCT. Wind-Up Stand Japanese Type

7

7

8

8

8

16

16

8

20

20

20

18

18

18

18

5

11

11

11

5

5

5

5

11

10

10

12

12

300M

310M

310M-J

320M

320M-J

330M

350

355

470

481

482T

483-BP

195

195S

198

198AC

198-J

226M

226M-J

226MB

226MB-J

227M

227M-J

228M

228P

483BT

483T

483T-J

155M

169M

175M

185M

193

045

055

120M

131

135M

135MB-J

135MP-J

145M

Code

013

013-A

013BS

023

023AC

033

034

034-J

042

98

Description

4 SCT. Wind-Up Stand Japanese Type Black

Page

18

Heavy Duty Wind-Up Stainless Steel Stand

Master Cine Stand

19

13

Master Cine Stand Black

Master Cine Stand - Japanese Type

Master Cine Stand Black - Japanese Type

Master High Cine Stand

Master High Cine Stand Black

13

13

13

14

14

Master High Cine Stand - Japanese Type 14

Master High Cine Stand Black- Japanese Type 14

Master Cine K stand

High Overhead Roller Stand

Medium Overhead Roller Stand

Wide Base High Overhead Stand

15

29

29

29

Steel Senior Stand

Bubble Liquid (1L)

Bubble Liquid (5L)

Super Bubble Machine

Headset Station (Belt Pack)

Battery (DC12V) For D-5000III Fogmate

Aluminum Alloy Clamp w/5/8" Light Stud

93

93

73

16

96

96

96

Aluminum Alloy Clamp w/5/8" Light Stud-Black 73

Quick Actuion Aluminum Alloy Hook Clamp 73

Quickly Release Aluminum Alloy Hook Clamp 73

Iron Casting C Clamp

Steel Clamp-Sliver

72

74

Steel clamp-Black

Baby Pipe Clamp

Tester for CEE extension cable

20" C Stand w/ Sliding Legs

20" C Stand w/ Sliding Legs - Black

CS-20M - Japanese Type (BLACK)

22

22

20" C Stand w/ Sliding Legs - Japanese Type 22

20" C stand w/ Sliding Leg Kits ( Silver) 23

74

72

78

22

20" C stand w/ Sliding Leg Kits ( Black)

30" C stand w/ Sliding Legs

30" C stand w/ Sliding Legs - Black

CS-30M - Japanese Type (BLACK)

30" C stand w/ Sliding Legs - Japanese Type

40" C stand w/ Sliding Legs

40" C stand w/ Sliding Legs - Black

CS-40M - Japanese Type (BLACK)

40" C stand w/ Sliding Legs- Japanese Type

40" C stand w/ Sliding Leg Kits ( Silver)

40" C stand w/ Sliding Leg Kits ( Black)

20" C Stand w/ Turtle Base

20" C Stand w/ Turtle Base - Black

CT-20M - Japanese Type (BLACK)

20" C Stand w/ Turtle Base - Japanese Type

20" C stand w/ Turtle Base Kits ( Silver)

22

22

22

22

23

22

22

22

22

23

23

21

21

21

21

23

CS-20MKB

CS-30M

CS-30MB

CS-30MB-J

CS-30M-J

CS-40M

CS-40MB

CS-40MB-J

CS-40M-J

CS-40MK

CS-40MKB

CT-20M

CT-20MB

C-05B

C-05NQP

C-05QP

C-06

C-12

C-12B

C-16

CEE TESTER

CS-20M

CS-20MB

CS-20MB-J

CS-20M-J

CS-20MK

CT-20MB-J

CT-20M-J

CT-20MK

543MB-J

546M

600M

610M

620M

653M

BL-1

BL-5

BM-0800

BSP-1

C06003

C-05

Code

483BT-J

484

542M

542MB

542M-J

542MB-J

543M

543MB

543M-J

Description

20" C stand w/ Turtle Base Kits - Black

Extension column (Max. 147cm)

30" C stand w/ Turtle Base

30" C stand w/ Turtle Base - Black

CT-30M - Japanese Type - Black

30" C stand w/ Turtle Base - Japanese Type

Extension column (Max. 227cm)

40" C stand w/ Turtle Base

40" C stand w/ Turtle Base - Black

Page

23

28

21

21

21

21

21

21

28

CT-40M - Japanese Type - Black

40" C stand w/ Turtle Base - Japanese Type

40" C stand w/ Turtle Base Kits - Silver

40" C stand w/ Turtle Base Kits - Black

Extension column (Max. 302cm)

Century Stand Base

Compact Century Stand Base

16A/3P/230V(Shuko), Socket

FogMate III

Transformer w/ Dummy Batter

Digi Fan

Double Muff Headsets

Double Muff Headsets (Heavy Duty)

28

22

22

78

21

21

23

23

93

93

91

92

92

EZ-TIE Cable Grip 20mm X 410mm - Black

EZ-TIE Cable Grip 20mm X 410mm - Blue

EZ-TIE Cable Grip 20mm X 410mm - Red

EZ-TIE Cable Grip 20mm X 410mm - White

EZ-TIE Cable Grip 20mm X 410mm - Yellow

EZ-TIE Cable Grip 50mm X 600mm - Black

EZ-TIE Cable Grip 50mm X 600mm - Blue

EZ-TIE Cable Grip 50mm X 600mm - Red

EZ-TIE Cable Grip 50mm X 600mm - White

EZ-TIE Cable Grip 50mm X 600mm - Yellow

Corner for Butterfly Frame

Corner with Nut for Butterfly Frame

Timmer Controller

Remote Control

Frame Supporter for Butterfly Frame

Frame Support with Tube for Butterfly Frame

Light Fog Liquid For Fast Dissipation (4L)

Snow Juice

Dense Fog Liquid For Long Lasting (4L)

Liquid for D-5000III FogMate

Anti-slip Tape 48mm x 50M Black & Yellow

Gaffer Tape 48mm x 50M / Roll / Black

Gaffer Tape 48mm x 50M Roll / Blue

Gaffer Tape 48mm x 50M / Roll / Gray

93

93

30

30

95

95

95

93

85

85

85

Gaffer Tape 48mm x 50M / Roll / Blue & Yellow 85

85

85

Gaffer Tape 48mm x 50M / Roll / Green

Gaffer Tape 48mm x 50M / Roll / Red

Gaffer Tape 48mm x 50M / Roll / White

85

85

86

86

30

30

86

86

86

86

86

86

86

86

FC-2D (MCT-1)

FC-3D (MCR-1)

FH10

FH20

FL-104

FL-203

FL-204

FLQ-500

GT-550AS

GT-550B

GT-550BU

GT-550BY

GT-550G

EZ241-B

EZ241-BLUE

EZ241-R

EZ241-W

EZ241-Y

EZ560-B

EZ560-BLUE

EZ560-R

EZ560-W

EZ560-Y

FC15A

FC15B

GT-550GN

GT-550R

GT-550W

Code

CT-20MKB

CT-20M-TUBE

CT-30M

CT-30MB

CT-30MB-J

CT-30M-J

CT-30M-TUBE

CT-40M

CT-40MB

CT-40MB-J

CT-40M-J

CT-40MK

CT-40MKB

CT-40M-TUBE

CT-BS

CT-SBS

CZ03

D-5000III

DCP-12

DF-500

DMH-075

DMH-095

99

Description Page

Matt-surface Gaffer Tape 48mm x 50M / Black 85

Matt-surface Gaffer Tape 48mm x 50M / Blue 85

Matt-surface Gaffer Tape 48mm x 50M / Gray 85

Matt-surface Gaffer Tape 48mm x 50M / Green 85

1.5mm 15M (ARRI 575W; 1200W)

1.5mm 7M (ARRI 575W; 1200W)

80

80

4C x 16mm + 5C x 1.5mm 15M (ARRI 12KW) 80

4C x 16mm + 5C x 1.5mm 7M (ARRI 12KW) 80

4C x 16mm + 5C x 1.5mm 15M (ARRI 18KW) 80

4C x 16mm + 5C x 1.5mm 7M (ARRI 18KW)

2.5mm 15M (ARRI 2500W; 4000W)

2.5mm 7M (ARRI 2500W; 4000W)

3C x 16mm + 3C x 1.5mm 15M (ARRI 6KW)

3C x 16mm + 3C x 1.5mm 7M (ARRI 6KW)

Timmer Controller

Wireless Remote Controller

Custom-built item

Silk Liquid, Oil-Base (1L)

Silk Liquid, Water-Base (1L)

I/O Interface Pack

Standard Director Chair

Dia. 64mm Caster

Dia. 80mm Caster

Dia. 80mm Caster

Dia. 100mm Caster

Dia. 100mm Caster

Dia. 100mm Caster

Kupo Cap - Grip

Kupo Cap - Lighting

3C Cable Guard

5C Cable Guard

T.V. Clamp - Black

Max Arm

Max Arm with Camera Bracket

32

32

81

81

32

32

32

32

90

90

71

52

54

80

94

94

88

80

80

80

80

94

94

92

81

Max Arm Kit

Max Arm w/ Quick release camera bracket

MAX Arm with wheel handle

Version arm

2 1/2" Grip Head w/ Big handle - Silver

2 1/2" Grip Head w/ Big handle - Black

2 1/2" Grip Head - Black (Japanese pin)

2 1/2" Grip Head - Polish (Japanese pin)

Grip Arm Support

Boom arm support

26

26

20" Extension Grip Arm w/ Big handle - Polish 24

20" Extension Grip Arm w/ Big handle - Black 24

Griphead w/Swivel Pin 44

24

24

24

24

54

54

52

56

40" Extension Grip Arm w/ Big handle - Polish 24

40" Extension Grip Arm w/ Big handle - Black 24

40'' Grip arm with hex baby pin 24

KCAP-02

KCG-301

KCG-501

KCP-100B

KCP-101

KCP-101CB

KCP-101K

KCP-101QW

KCP-101W

KCP-102

KCP-200

KCP-200B

KCP-200B-J

HCR-1

Honeycomb

HZL-1

HZL-1W

IFP-100

KAC-01

KC-064R

KC-080R

KC-080S

KC-100

KC-100G

KC-100S

KCAP-01

KCP-200P-J

KCP-215P

KCP-216

KCP-220

KCP-220B

KCP-230

KCP-240

KCP-240B

KCP-241

Code

GTM-550B

GTM-550BU

GTM-550G

GTM-550GN

HB-1.2K-15M

HB-1.2K-7M

HB-12K-15M

HB-12K-7M

HB-18K-15M

HB-18K-7M

HB-4K-15M

HB-4K-7M

HB-6K-15M

HB-6K-7M

HC-1

KCP-630

KCP-631

KCP-640M

KCP-641B

KCP-645

KCP-650

KCP-700B

KCP-700P

KCP-701P

KCP-702

KCP-703

KCP-704

KCP-705

KCP-400

KCP-420

KCP-450

KCP-500

KCP-550

KCP-600

KCP-601

KCP-605

KCP-606

KCP-610

KCP-611

KCP-614

KCP-620P

KCP-710B

KCP-710P

KCP-715P

KCP-340

KCP-343

KCP-344

KCP-345

KCP-346

KCP-347

KCP-350B

KCP-350P

KCP-360B

KCP-360P

KCP-380

KCP-381

KCP-390

Code

KCP-260B

KCP-265P

KCP-270B

KCP-300

KCP-310

KCP-311

KCP-320

KCP-330

Description

Grip Head w/ Hex Stud - Black

Grip Head w/ Half coupler

Super Clamp Griphead

Articulated Arm

EZ Grip Finger

EZ Grip Reciver

EZ Grip Twins

Tiny Clamp

Baby Plate w/ EZ Grip Finger

Flex Arm Kit for Dots/ Fingers

Flex Arm

French Flag Arm

40 cm x 25 cm French Flag

Wood C47 Spring-type Clothspins

Mini Alli Clamp Black

Mini Alli Clamp Polish

Alli Clamp Black

Alli Clamp Polish

Kino Fluorescent Lamp Holder

51

50

Off-Set Female Mounting Plate Adapter - 5/8" 50

Off camra flash Spring clamp 51

44

Square Clamp w/Baby Receiver

Square Clamp w/Baby Stud

4 1/2" Grip head w/ 1 1/8" Spigot and Socket

Large Gaffer Grip

Adjustable Gaffer Grip

4" Super Viser

9" Super Viser

6" Chain Clamp

10" Chain Clamp

Foamcore Fork

Foamcore Clamp

Adjustable Poly holder

Petite Clamp for 16mm (5/8") Tube

44

29

34

34

33

33

34

34

49

49

49

45

88

51

51

51

48

48

48

48

Page

37

37

37

47

44

44

44

44

44

Junior Drop Down

Baby Drop Down Pin

Baby Boom - Steel

Photo Baby Boom - Aluminum

Pivoting Boom Arm clamp

Ruler Clamp

Convi. Clamp--Black

Convi. Clamp--Silver

Convi. Clamp with teeth-Silver

Stage Clamp w/13mm Hole

Stage Clamp w/16mm Stud

Stage Clamp w/28mm Stud

Stage Clamp w/28mm Socket with linch pin

Superb Clamp with Adjustable handle - Black 36

Superb Clamp with Adjustable handle - Silver 36

Toothy Convi. Clamp w/ Half coupler 37

28

50

36

36

27

27

27

27

37

73

73

73

73

100

KCP-901B

KCP-902

KCP-902B

KCP-930P

KCP-950P

KCP-F1824

KCP-F2436

KCP-OF1824

KCP-OF2436

KCTB-001

KCTB-002

KCTB-003

KCP-838-T

KCP-839

KCP-840P

KCP-841

KCP-844B

KCP-844P

KCP-847

KCP-851

KCP-857

KCP-860

KCP-862

KCP-873

KCP-901

KCTB-004

KCTO-001

KCTO-002

KCP-809

KCP-810

KCP-820

KCP-828

KCP-830

KCP-831

KCP-831-T

KCP-832

KCP-833

KCP-834

KCP-835

KCP-836

KCP-838

Code

KCP-720B

KCP-720P

KCP-724

KCP-730B

KCP-7SDL

KCP-801

KCP-802

KCP-806

KCP-808

Description

Double Superb Clamp - Black

Double Superb Clamp - Silver

Wall Spreader

Pincer Clamp

Superb Clamp Saddle

250mm Arm coupler

500mm Arm coupler

Side Arm for Tube size 1.25~1.5''

Baby Side Arm

Junior Side Arm

Arch Coupler

Slim Type Swivel Coupler

Slim Handcuff Clamp

1/2 Half Type Coupler

Half Coupler w/M10 Bolt

Half Coupler With T Handle

Swivel Coupler

Half Coupler w/Eye Ring

Half Coupler w/28mm TV spigot

Truss Adapter

Half Coupler w/16mm Stud

Handcuff Clamp

Handcuff Clamp with T Handle

Handcuff Clamp with Stud

Handcuff Clamp with w/28mm Socket

Arch Coupler W/28mm Socket

TV Coupler - Black

TV Coupler - Polish

Tube/Barrel Joiner

Mighty Coupler for 2.5" Tube

71

71

69

69

Mighty / Half Swivel Coupler for 2"~2.5" Tube 69

69

69

69

70

Nugget Coupler

Swivel type Nugget coupler

45 Degree Coupler

70

70

70

70

Burger Coupler

Burger Coupler-Blck

Swivel Type Burger Coupler

Swivel Type Burger Coupler-Black

3 Ways Clamp For 25mm to 35mm Tube

4 Ways Clamp For 35mm To 50mm Tube

Flag Frame 18" x 24"

Flag Frame 24" x 36"

45

25

25

25

70

70

70

45

Open end Flag Frame 18" x 24"

Open end Flag Frame 24" x 36"

CTB For ARRI Junior 300W

CTB For ARRI Junior 650W

CTB For ARRI Junior 1KW / Studio 1KW

25

87

87

87

CTB For ARRI Junior 2KW / Compact 1.2KW

87

CTO For ARRI Compact 125W

CTO For ARRI Compact 200W / Par 200W

87

87

67

67

67

67

46

67

67

68

68

68

68

68

68

Page

37

37

50

56

36

70

70

47

46

Description

CTO For ARRI Compact 575W / Par 575W

Page

87

CTO For ARRI Compact 1200W

Superb Clamp Double Socket-Black

87

36

Superb Clamp Double Socket-Silver

Mini Flex Arm with Clip

L Bracket Shelf holder (Set of Two) - Black

Compact U Hooks - Black

Panel with Hole - Black (Length: 1080mm)

36

47

38

38

64

Panel with Hole - Black (Length: 825mm)

Panel with Hole - Black (Length: 440mm)

Panel - Black (Length: 1080mm)

Panel - Black (Length: 825mm)

Panel - Black (Length: 440mm)

Extension Panel - Black (Length: 1080mm)

Extension Panel - Black (Length: 825mm)

Extension Panel - Black (Length: 440mm)

Extension Panel - Black (Length: 1080mm)

Extension Panel - Black (Length: 825mm)

Extension Panel - Black (Length: 440mm)

Kupole Base

Curved Clamp for Super Joint - Black

64

64

64

64

64

64

64

64

64

64

64

60

64

Curved Clamp for Super Joint - silver

2 Ways Joint for Super Joint - Black

2 Ways Joint for Super Joint - silver

Joint with Screw for Super Joint - Black

Joint with Screw for Super Joint - Silver

Basic Joint for Super Joint - Black

Basic Joint for Super Joint - Silver

500mm Tube , Dia.35mm - Silver

Foot adapter

1000mm Tube , Dia.35mm - Silver

1500mm Tube , Dia.35mm - Silver

2000mm Tube , Dia.35mm - Silver

4 pcs per pack

4 pcs per pack

Kupole Suspended Ceiling Adapter

Ceiling Clip with Female Socket

Ceiling Clip with Male Adapter

LCD Monitor Arm

Kupole Disc Base

Kupole Adapter for 5cm Pipe

6' X 6' Butterfly frame

8' X 8' Butterfly frame

12' X 12' Butterfly frame

20' X 20' Butterfly frame

Ku Hand - Large size

Ku Hand - Medium size

Ku Hand - Extra Large size

Ku Hand - Double XL size

Ku Hand - Medium size

43

60

50

30

86

60

44

44

30

30

30

84

84

84

84

84

64

64

64

64

64

64

64

64

64

64

64

64

86

KD-C40P

KD-C50P

KD-CF16P

KD-CM16P

KD-M01P

KD-R48P

KD-T50P

KH-06

KH-08

KH-12

KH-20

KH-55LB

KH-55MB

KD-C01P

KD-C02B

KD-C02P

KD-C03B

KD-C03P

KD-C04B

KD-C04P

KD-C0500P

KD-C07P

KD-C1000P

KD-C1500P

KD-C2000P

KD-C25P

KH-55XLB

KH-55XXLB

KH-66MB

KD-840SB

KD-841LB

KD-841MB

KD-841SB

KD-842LB

KD-842MB

KD-842SB

KD-843LB

KD-843MB

KD-843SB

KD-B126P

KD-C01B

Code

KCTO-003

KCTO-004

KD-730B

KD-730P

KD-735P

KD-790B

KD-795B

KD-840LB

KD-840MB

101

KL-150LMR

KL-150LMW

KL-150SFB

KL-150SFBK

KL-150SFBN

KL-150SFG

KL-150SFGY

KL-150SFR

KL-150SFW

KL-150SMB

KL-150SMBK

KL-150SMBN

KL-150SMG

KL-150LFB

KL-150LFBK

KL-150LFBN

KL-150LFG

KL-150LFGY

KL-150LFR

KL-150LFW

KL-150LMB

KL-150LMBK

KL-150LMBN

KL-150LMG

KL-150LMGY

KL-150SMGY

KL-150SMR

KL-150SMW

KL-400LFB

KL-400LFBK

KL-400LFBN

KL-400LFG

KL-400LFGY

KL-400LFR

KL-400LFW

Code

KH-66XLB

KH-66XXLB

KH-L112

KH-L114

KHR-C112

KHR-C114

KHR-E112

KHR-E114

KHR-L112

KHR-L114

KHTN013

KHTN023

KHTN213

KHTN233

KHTN413

Description

Ku Hand - Extra Large size

Ku Hand - Double XL size

Page

84

84

Round Pipe Butterfly frame for 1-1/2'' pipe set 31

Round Pipe Butterfly frame for 1-1/4'' pipe set 31

Frame Connector for 1-1/2" Pipe

Frame Connector for 1-1/4" Pipe

Frame Ear for 1-1/2" Pipe

Frame Ear for 1-1/4" Pipe

Frame Corner for 1-1/2" Pipe

Frame Corner for 1-1/4" Pipe

16A(CEE Form), Cable Male Connector

32A(CEE Form), Cable Male Connector

31

31

31

31

31

16A(CEE Form), Cable Female Connector

32A(CEE Form), Cable Female Connector

16A(CEE Form), Panel Female Socket

78

78

77

77

31

78

78

78

150A Line female-Blue

150A Line female-Black

150A Line female-Brown

150A Line female-Green

150A Line female-Gray

150A Line female-Red

150A Line female-White

150A Line male-Blue

150A Line male-Black

150A Line male-Brown

150A Line male-Green

150A Line male-Gray

150A Line male-Red

150A Line male-White

150A Panel Female-Blue

150A Panel Female-Black

150A Panel Female-Brown

150A Panel Female-Green

150A Panel Female-Gray

150A Panel Female-Red

77

77

77

77

77

77

77

77

77

77

77

77

77

150A Panel Female-White

150A Panel Male-Blue

150A Panel Male-Black

150A Panel Male-Brown

150A Panel Male-Green

77

77

77

77

77

77

77

77

77

77

77

77

150A Panel Male-Gray

150A Panel Male-Red

150A Panel Male-White

400AMP Female Plug - Blue

400AMP Female Plug - Black

400AMP Female Plug - Brown

400 AMP Female Plug - Green

400AMP Female Plug - Grey

400AMP Female Plug - Red

400AMP Female Plug - White

77

76

76

76

76

76

76

76

KP-L2137BD

KP-L2137PD

KP-M1527BD

KP-M1527PD

KP-S1017BD

KP-S1017PD

KP-SP01

KP-SP02

KP-SP03

KP-SP04

KP-SP05

KP-X15B

KL-DCBK

KL-DCG

KL-DCR

KL-DCW

KP-DS01

KP-KS01

KP-KS02

KP-KS03B

KP-KS03BL

KP-KS03O

KP-KS03W

KP-KS04

KP-KS05

KP-X15P

KP-X20B

KP-X20P

Code

KL-400LMB

KL-400LMBK

KL-400LMBN

KL-400LMG

KL-400LMGY

KL-400LMR

KL-400LMW

KL-400SFB

KL-400SFBK

KL-400SFBN

KL-400SFG

KL-400SFGY

KL-400SFR

KL-400SFW

KL-400SMB

KL-400SMBK

KL-400SMBN

KL-400SMG

KL-400SMGY

KL-400SMR

KL-400SMW

KL-DCB

Description

400AMP Male Plug - Blue

400AMP Male Plug - Black

400AMP Male Plug - Brown

400AMP Male Plug - Green

400AMP Male Plug - Grey

400AMP Male Plug - Red

400AMP Male Plug - White

400AMP Female Receptacle Blue

400AMP Female Receptacle - Black

400AMP Female Receptacle Brown

400AMP Female Receptacle Green

400AMP Female Receptacle Grey

400AMP Female Receptacle Red

400AMP Female Receptacle White

400AMP Male Receptacle Blue

400AMP Male Receptacle - Black

400AMP Male Receptacle Brown

400AMP Male Receptacle Green

400AMP Male Receptacle Grey

400AMP Male Receptacle Red

400AMP Male Receptacle White

K-LOK Dust Cover Blue

K-LOK Dust Cover Black

K-LOK Dust Cover Green

K-LOK Dust Cover Red

K-LOK Dust Cover White

Background Paper Drive Set

Single hook( 2 pcs/ set)

Triple hooks(2 pcs/ set)

Plastic Chian 3.5M (L) -Black

Plastic Chian 3.5M (L) -Blue

Plastic Chian 3.5M (L) -Orange

Plastic Chian 3.5M (L) -White

Chain Weight

Background Baby hook

Kupole- 210cm to 370cm - Black

Kupole -210cm to 370cm - Silver

Kupole - 150cm to 270cm - Black

Kupole - 150cm to 270cm - Silver

Kupole - 100cm to 170cm - Black

Kupole- 100cm to 170cm - Silver

White Rubber Pad

White Top Rubber Cover

White Bottom Rubber Cover

Black Top Rubber Cover

Black Bottom Rubber Cover

Extension tube (1.5M) - Black

Extension tube (1.5M) - Silver

Extension tube (2.0M) - Black

Extension tube (2.0M)- Silver

Page

62

59

59

59

61

61

61

62

59

59

59

60

60

59

59

59

60

60

60

59

76

76

76

76

76

76

76

76

76

61

61

61

61

76

76

76

76

76

76

76

76

76

76

76

76

76

76

76

76

76

102

Description

Aluminum tube for paper roll

Distribution Box w/ Stage 3 pin connectors

Distribution Box w/ CEE form connectors

Page

62

79

79

Distribution Box w/ SHUKO connectors

3/8" Snap In Pin

1/2" Snap In Pin

5/8" Snap In Pin

M12 x 30 Stud

79

38

38

38

38

M10 x 25 Stud

M12 x 35 Threaded Socket

M10 x 30 Threaded Socket

Joining Stud/Swivel

150mm Extension

Offest Arm

100mm Square Mounting Plate

Swivel U Hook

Dia. 17m Spigot

Camera Stud with 3/8" and 1/4" thread

KS-014 Round Shape

Double Female Thread Camera Stud

KS-015 Round Shape

38

38

39

39

38

38

38

38

73

39

39

39

39

90/45 Joining Stud

Universal 16mm Light Stud

16mm Stud w/M10 Thread

Swivel Extension Arm w/5/8" socket

5/8" Compact Alu. Snap in Pin

Grip Arm pin

3/8'' Head mounting palte with 5/8'' stud

1/4'' Head mounting plate w/ 5/8''

Camera Stud 3/8"-16 thread

Camera Stud 1/4"-20 thread

16mm Male Adapter

Stand Leg Cover

Monitor Arm Adapter

28mm Pin w/M10 Thread

Snap in right angle pin

28mm Pin w/M12 Thread

28mm Stud w/M10 Bolt

Hex Adapter

Dot Receiver

Adjustable cold shoe mount

28mm Pin w/M10 Thread & Plate

Hot shoe Adapter W/ barrel Adapter

28mm Pin w/M12 Thread & Plate

Right angle baby wall plate

9'' baby wall plate

6'' baby wall plate

3" Baby Wall Plate

Baby receiver wall plate

Junior Wall Plate

48

48

53

42

42

41

42

42

53

42

41

41

41

41

41

41

39

25

40

40

39

39

39

47

40

40

40

5

43

KS-030

KS-031

KS-032

KS-034

KS-038

KS-038DR

KS-039

KS-040

KS-041

KS-042

KS-043

KS-044

KS-045

KS-016

KS-017

KS-018

KS-019

KS-020

KS-022

KS-023

KS-024

KS-025

KS-026

KS-027

KS-028

KS-029

KS-046

KS-047

KS-048

KS-006

KS-007

KS-008

KS-009

KS-010

KS-011

KS-012

KS-013

KS-014

KS-014R

KS-015

KS-015R

Code

KP-X245P

KRB-01

KRB-02

KRB-03

KS-001

KS-002

KS-003

KS-004

KS-005

Description

Scraper

Flag Holder

1/4" + 1/4" Adapter Spigot

Adapter for 3/8"F- 16 to 1/4"-20 M

Adapter for 3/8''-16 to 1/4''-20

3/8" + 1/4" Adapter Spigot

Junior multi header

6 Lantern T Bar offset baby wall plate

Baby Offset Arm

Junior Ofset Arm

16mm Socket w/1/4" Thread

16mm Socket w/3/8" Thread

3/8''-16M to 1/4-20'' F adapter

Double Female Adapter-5/8"

Double baby receiver adapter

Long Double Stud - 5/8"

5/8" Stud with 1/4-20" Female Thread

Ball Race M10 Stud

Ball Race M12 Stud

28mm receiver Spigot

Yoke to Stand Adapter

5/8" Light Stud for 4 Way Clamp

5/8" Male Adapter for 4 Way Clamp

5/8" Female Adapter for 4 Way Clamp

Umbrella Swivel Bracket

Swiveling umbrella adapter

Versatile swiveling adapter

Versatile swiveling adapter w/ KS-CB01

Verstile swivel adapter with KS-CB02

Adapter 28mm/16mm Stud

Tethermate

9" Suction Cup with 16mm Baby Pin

Double Suction Cup w/ Baby Pin

Suction cup with3/8-16 thread stud

Suction cup with fixed baby pin

Suction cup with swiveling adapter KS-103

Suction cup with swivel baby pin

Camera Bracket

Quick release camera plate

Sand Bag (Max. load: 15 lbs / 6kg)

Sand Bag (Max. load: 25 lbs / 11kg)

Sand Bag (Max. load: 35 lbs / 15kg)

Lighting Kits Bag

Grip Case - Black

Super Joint Demo Kit

Grip Car A

CAM STEP

100cm Height X-BONE Brace

40cm Height X-BONE Brace

40

42

42

41

46

46

42

42

41

43

43

73

Page

43

48

40

40

40

40

50

50

41

53

53

82

82

57

57

57

57

82

83

83

64

64

89

89

89

55

55

55

55

42

45

45

45

55

43

63

57

57

KSC-03

KSC-04

KSC-05

KSC-06

KS-CB01

KS-CB02

KSD-1680A

KSD-1680B

KSD-1680C

KSD-LB01

KSD-LB02

KSJ-100B

KSJ-200P

KS-091

KS-092

KS-093

KS-101

KS-102

KS-103

KS-104

KS-105

KS-200

KS-300

KSC-01

KSC-02

KXB-001P

KXB-6-100

KXB-6-40

KS-058

KS-059

KS-060

KS-062

KS-063

KS-070

KS-071

KS-074

KS-076

KS-080

KS-082

KS-089

KS-090

Code

KS-049

KS-050

KS-051

KS-052

KS-053

KS-054

KS-055

KS-056

KS-057

103

Code

KXB-6-60

KXB-6-80

Description

60cm Height X-BONE Brace

80cm Height X-BONE Brace

KXB-AK

KXB-FP

Accessory Kit

Plastic Foot Pad

M-5

MEZ220-B

Fog Machine

MEZ-TIE 2cm x 20cm - Black

MEZ220-BL

MEZ220-R

MEZ-TIE 2cm x 20cm - Blue

MEZ-TIE 2cm x 20cm - Red

MEZ220-W

MEZ220-Y

MEZ-TIE 2cm x 20cm - White

MEZ-TIE 2cm x 20cm - Yellow

MPS-60

PG-400

Intercom Rack Mount Power Supply

Slik Haze Machine

PS-30

S-200

Power Suppler for 30pcs of Belt

Silent Snow Droper

SMH-075

Single Muff Headsets

SW-01

Dia. 3.5mm 80cm Safety Wire

SW-02

Dia. 3.0mm 75cm Safety Wire

SW-03

Dia. 5.0mm 105cm Safety Wire

SW-04

Dia. 4.5mm 80cm Safety Wire

SW-TB

Safety Wire for KH-20 Butterfly Frame

TLS-3

Talkback loudspeaker Statin

WPC-2407LF-0

Arri 2.5/4K Line Female

WPC-2407LF-W

Arri 575W/1.2K Line Female

WPC-2407LF-Z

575W/1.2K Line Female

WPC-2407LM-0

Arri 2.5/4K Line Male w/Locking Ring

WPC-2407LM-W

Arri 575W/1.2K Line Male w/Locking Ring

WPC-2407LM-Z

575W/1.2K Line Male w/Locking Ring

WPC-2407SF-0

Arri 2.5/4K Panel Female

WPC-2407SF-W

Arri 575W/1.2K Panel Female

WPC-2407SF-Z

575W/1.2K Panel Female

WPC-2407SM-0

Arri 2.5/4K Panel Male w/Locking Ring

WPC-2407SM-W

Arri 575W/1.2K Panel Male w/Locking Ring

WPC-2407SM-Z

575W/1.2K Panel Male w/Locking Ring

WPC-2806LF

Arri 6K Line Female Including Skintop

WPC-2806LM

Arri 6K Line Male including Skintop

WPC-2806SF

Arri 6K Panel Female

WPC-2809LF

Arri 12/18K Line Female

WPC-2809LM

Arri 12/18K Line Male Including Skintop

WPC-2809SF

Arri 12/18K Panel Female

WS-140

Wingnut Multi-Spanner

Z-20

Timmer Controller

Z-30

Radio Wireless Remote Control

Page

89

89

89

89

95

86

86

86

86

86

93

94

92

96

92

74

74

74

74

30

30

80

80

80

80

80

80

80

80

80

80

80

80

80

80

80

80

80

80

74

95

95

104

www.grip.com.tw

Kupo co., ltd (Headquater)

Tel: +886-2-2999-1906 Fax:+886-2-2999-1955

6F, No 4, Lane 609, Sec. 5, Chung Shin Rd., San Chung District,

New Taipei City 24159, Taiwan

E-mail : [email protected]

Kupo Shanghai (Branch office)

Tel: +86-21-5677-9636 Fax:+86-21-5677-9218

RM302, No. 86, Jiang Chang, 3rd Rd.,Shanghai, 200436, China www.kupo.com.cn

Vol. 2012.08

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
