MCITP Self-Paced Training Kit (Exam 70-685

MCITP Self-Paced Training Kit (Exam 70-685
●●●●●●●●●●●
How to access
your CD files
The print edition of this book includes a CD. To access the
CD files, go to http://aka.ms/627093/files, and look for the
Downloads tab.
Note: Use a desktop web browser, as files may not be
accessible from all ereader devices.
Questions? Please contact: [email protected] Microsoft Press
Exam 70-685: Pro: Windows 7, Enterprise ­Desktop
Support Technician
objective
Location in Book
Identifying Cause of and Resolving Desktop Application Issues
Identify and resolve new software installation issues.
Chapter 9, Lesson 1
Identify and resolve software configuration issues.
Chapter 9, Lesson 2
Identify cause of and resolve software failure issues.
Chapter 9, Lesson 1
Identifying Cause of and Resolving Networking Issues
Identify and resolve logon issues.
Chapter 4, Lesson 1
Identify and resolve network connectivity issues.
Chapter 2, Lesson 1
Identify and resolve names resolution issues.
Chapter 2, Lesson 2
Identify and resolve network printer issues.
Chapter 3, Lesson 1
Managing and Maintaining Systems That Run Windows 7 Client
Identify and resolve performance issues.
Chapter 8, Lessons 1 and 2
Identify and resolve hardware failure issues.
Chapter 1, Lessons 1 and 2
Supporting Mobile Users
Identify and resolve wireless connectivity issues.
Chapter 2, Lesson 3
Identify and resolve remote access issues.
Chapter 6, Lessons 1 and 2
Identifying Cause of and Resolving Security Issues
Identify and resolve Windows Internet Explorer security issues.
Chapter 4, Lesson 2
Identify and resolve issues due to malicious software.
Chapter 5, Lesson 1
Identify and resolve encryption issues.
Chapter 4, Lesson 3
Identify and resolve software update issues.
Chapter 7, Lesson 1
Exam Objectives The exam objectives listed here are current as of this book’s publication date. Exam objectives are
subject to change at any time without prior notice and at Microsoft’s sole discretion. Please visit the Microsoft Learning
Web site for the most current listing of exam objectives: http://www.microsoft.com/learning/en/us/Exam.aspx?ID=70-685.
MCITP Self-Paced Training Kit
(Exam 70-685): Windows 7
Enterprise Desktop Support
Technician
®
Tony Northrup
J.C. Mackin
PUBLISHED BY
Microsoft Press
A Division of Microsoft Corporation
One Microsoft Way
Redmond, Washington 98052-6399
Copyright © 2010 by Tony Northrup and J.C. Mackin
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means
without the written permission of the publisher.
Library of Congress Control Number: 2010921440
ISBN: 978-0-7356-2709-3
Printed and bound in the United States of America.
5 6 7 8 9 10 11 12 13 QGT 7 6 5 4 3 2
Distributed in Canada by H.B. Fenn and Company Ltd.
A CIP catalogue record for this book is available from the British Library.
Microsoft Press books are available through booksellers and distributors worldwide. For further information about
international editions, contact your local Microsoft Corporation office or contact Microsoft Press International directly at
fax (425) 936-7329. Visit our Web site at www.microsoft.com/mspress. Send comments to [email protected]
Microsoft, Microsoft Press, Access, Active Directory, ActiveX, Aero, BitLocker, ESP, Forefront, Hyper-V, Internet Explorer,
Jscript, MS, MSDN, MSN, Outlook, ReadyBoost, SpyNet, SQL Server, Win32, Windows, Windows Live, Windows Media,
Windows NT, Windows PowerShell, Windows Server, and Windows Vista are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries. Other product and company names mentioned herein
may be the trademarks of their respective owners.
The example companies, organizations, products, domain names, e-mail addresses, logos, people, places, and events depicted
herein are fictitious. No association with any real company, organization, product, domain name, e-mail address, logo,
person, place, or event is intended or should be inferred.
This book expresses the author’s views and opinions. The information contained in this book is provided without any
express, statutory, or implied warranties. Neither the authors, Microsoft Corporation, nor its resellers, or distributors will
be held liable for any damages caused or alleged to be caused either directly or indirectly by this book.
Acquisitions Editors: Ken Jones and Martin DelRe
Developmental Editor: Maria Gargiulo
Project Editors: Denise Bankaitis and Carol Vu
Editorial Production: Christian Holdener, S4Carlisle Publishing Services
Technical Reviewer: Bob Dean; Technical Review services provided by Content Master, a member of CM Group, Ltd.
Cover: Tom Draper Design
Body Part No. X16-75082
[2012-02-10]
For my Gramma June.
—Tony Northrup
To my nieces Cassidy and Mckenna, and to my nephew Ralph.
—J.C. Mackin
Contents
Introduction
xix
Hardware Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix
Practice Setup Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx
Using the Companion CD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xx
How to Install the Practice Tests
xxi
How to Use the Practice Tests
xxii
How to Uninstall the Practice Tests
xxiii
Microsoft Certified Professional Program. . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii
Support for This Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii
We Want to Hear from You. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiv
Chapter 1Troubleshooting Hardware Failures
1
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Lesson 1: Using Windows 7 Hardware Troubleshooting Tools. . . . . . . . . . . 2
Troubleshooting with the Windows 7 Action Center
2
Troubleshooting with Windows 7 Troubleshooters
4
Troubleshooting with Device Manager
15
Troubleshooting with Reliability Monitor
17
Troubleshooting with Event Viewer
19
Troubleshooting Startup Failures with Startup Repair
21
Troubleshooting RAM with Windows Memory Diagnostic
24
Troubleshooting Hard Disk Problems with Chkdsk
29
Troubleshooting Hard Disk Problems with Disk Defragmenter
31
Lesson Summary
33
Lesson Review
34
What do you think of this book? We want to hear from you!
Microsoft is interested in hearing your feedback so we can continually improve our
books and learning resources for you. To participate in a brief online survey, please visit:
www.microsoft.com/learning/booksurvey/
vii
Lesson 2: Troubleshooting Hardware Components. . . . . . . . . . . . . . . . . . . 35
Distinguishing Hardware Failures from
Software Failures
35
Understanding the Boot Process
36
Troubleshooting the Power Supply Unit
37
Troubleshooting the Motherboard
38
Troubleshooting RAM
40
Troubleshooting Hard Disks
41
Lesson Summary
44
Lesson Review
44
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Case Scenario 1: Troubleshooting Stop Errors
46
Case Scenario 2: Troubleshooting System Crashes
46
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Identify and Resolve Hardware Failure Issues
47
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Chapter 2Networking
49
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Lesson 1: Troubleshooting Network Connectivity. . . . . . . . . . . . . . . . . . . . . . 51
How to Use Windows Network Diagnostics
51
Network Troubleshooting Tools
54
How to Troubleshoot an APIPA Address
60
How to Troubleshoot Connectivity Problems
61
Lesson Summary
68
Lesson Review
68
Lesson 2: Troubleshooting Name Resolution. . . . . . . . . . . . . . . . . . . . . . . . . 70
viii
Contents
How to Troubleshoot Name Resolution Problems
70
How to Manage the DNS Cache
72
Lesson Summary
75
Lesson Review
75
Lesson 3: Troubleshooting Wireless Networks. . . . . . . . . . . . . . . . . . . . . . . . . 77
Wireless Networking Overview
77
Connecting to Wireless Networks
78
Reconfiguring a Wireless Network
84
Changing the Priorities of Wireless Networks
85
Wireless Networking Security
86
Configuring WPA-EAP Security
88
Configuring Wireless Network Profile Types
91
Troubleshooting Common Wireless Network Problems
92
Using Event Viewer to Analyze Wireless Connection
Problems
95
Lesson Summary
98
Lesson Review
98
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Case Scenario 1: Troubleshooting a Network Problem
101
Case Scenario 2: Troubleshooting Problems Connecting
to a Wireless Network
101
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Identify and Resolve Network Connectivity Issues
102
Identify and Resolve Names Resolution Issues
102
Identify and Resolve Wireless Connectivity Issues
103
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Chapter 3Printers
105
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Lesson 1: Troubleshooting Network Printers. . . . . . . . . . . . . . . . . . . . . . . . 107
Using the Printer Troubleshooter
107
Monitoring Printer Events
108
Group Policy Settings for Troubleshooting
110
Troubleshooting Server Problems
111
Troubleshooting Driver Problems
113
Contents
ix
Troubleshooting Network Problems
116
Lesson Summary
123
Lesson Review
123
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Case Scenario 1: Troubleshooting Insufficient
Privileges
126
Case Scenario 2: Troubleshooting a Printer Problem
126
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Identify and Resolve Network Printer Issues
126
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Chapter 4Security
129
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Lesson 1: Authenticating Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
What Is Authentication?
132
How to Use Credential Manager 133
How to Troubleshoot Authentication Issues
135
Lesson Summary
145
Lesson Review
145
Lesson 2: Configuring and Troubleshooting Internet
Explorer Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Internet Explorer Add-Ons
147
Adding Sites to the Trusted Sites List
154
Protected Mode
155
How to Troubleshoot Certificate Problems
158
How to Identify Group Policy Restrictions
160
Lesson Summary
164
Lesson Review
165
Lesson 3: Using Encryption to Control Access to Data. . . . . . . . . . . . . . . . 167
x
Contents
Encrypting File System (EFS)
167
BitLocker
175
Lesson Summary
186
Lesson Review
187
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Case Scenario 1: Recommend Data Protection Technologies
189
Case Scenario 2: Unwanted Internet Explorer Add-On
190
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Identify and Resolve Logon Issues
190
Identify and Resolve Encryption Issues
191
Identify and Resolve Windows Internet Explorer
Security Issues
191
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
Chapter 5Protecting Client Systems
193
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Lesson 1: Resolving Malware Issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Understanding Malware
195
Understanding UAC
197
Protecting Clients from Spyware with Windows Defender
205
Determining When Your System Is Infected with Malware
211
How to Resolve Malware Infections
212
Lesson Summary
215
Lesson Review
216
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Case Scenario. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Case Scenario 1: Resolving Malware Infections
219
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Identify and Resolve Issues Due to Malicious Software
219
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Contents
xi
Chapter 6Understanding and Troubleshooting Remote
Access Connections
221
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Lesson 1: Understanding VPN Client Connections. . . . . . . . . . . . . . . . . . . 223
Understanding VPNs
223
Understanding Windows 7 VPN Tunneling
Protocols
232
Understanding the Remote Access VPN
Connectivity Process
236
Troubleshooting VPN Client Connectivity
239
Lesson Summary
249
Lesson Review
249
Lesson 2: Understanding DirectAccess Client Connections . . . . . . . . . . . 251
Overview of DirectAccess
251
Understanding DirectAccess and IPv6 Transition
Technologies
252
Understanding DirectAccess Infrastructure Features
255
Configuring DirectAccess Client Settings for IPv6
Manually
259
Configuring IPv6 Internet Features on the DirectAccess
Server Manually
260
Understanding the DirectAccess Connection Process
261
Troubleshooting DirectAccess Connections
261
Lesson Summary
264
Lesson Review
265
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Case Scenario 1: Troubleshooting a Remote
Access VPN
267
Case Scenario 2: Troubleshooting DirectAccess
267
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Identify and Resolve Remote Access Issues
268
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
xii
Contents
Chapter 7Updates
269
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Lesson 1: Updating Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
Methods for Deploying Updates
271
How to Check Update Compatibility
273
How to Install Updates
274
How to Verify Updates
280
How to Troubleshoot Problems Installing
Updates
282
How to Remove Updates
283
Lesson Summary
288
Lesson Review
289
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Case Scenario 1: Distribute Updates
291
Case Scenario 2: Audit Updates
291
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Identify and Resolve Software Update Issues
292
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Chapter 8Performance
295
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
Lesson 1: Forwarding Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
How Event Forwarding Works
298
How to Configure Event Forwarding in AD DS
Domains
299
How to Configure Event Forwarding in Workgroup
Environments
306
How to Troubleshoot Event Forwarding
307
Lesson Summary
313
Lesson Review
313
Contents
xiii
Lesson 2: Troubleshooting Performance Problems. . . . . . . . . . . . . . . . . . . 315
Task Manager
315
Performance Monitor
319
Data Collector Sets and Reports
321
Troubleshooting Disk Performance Problems
326
Configuring Power Settings
329
System Configuration
330
Lesson Summary
333
Lesson Review
333
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 336
Case Scenario 1: Monitoring Kiosk Computers
336
Case Scenario 2: Troubleshooting a Performance Problem
337
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
Identify and Resolve Performance Issues
337
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338
Chapter 9Troubleshooting Software Issues
339
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339
Lesson 1: Understanding and Resolving Installation Failures. . . . . . . . . . 340
Verifying Software Installation Requirements
340
Understanding Installation Restrictions with AppLocker
344
Lesson Summary
353
Lesson Review
353
Lesson 2: Resolving Software Configuration
and Compatibility Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
Resolving Software Configuration Issues
355
Understanding Application Compatibility
357
Lesson Summary
365
Lesson Review
366
Chapter Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
xiv
Contents
Chapter Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Key Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Case Scenarios. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
Case Scenario 1: Restricting Software with AppLocker
369
Case Scenario 2: Configuring Application Compatibility
Settings
369
Suggested Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
Identify and Resolve New Software Installation Issues
370
Identify and Resolve Software Configuration Issues
370
Identify Cause of and Resolve Software Failure Issues
370
Take a Practice Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
Appendix A: Configuring Windows Firewall
371
Appendix B: Managing User Files and Settings
395
Appendix C: Configuring Startup and Troubleshooting
Startup Issues
439
Appendix D: Troubleshooting Hardware, Driver, and Disk Issues
491
Appendix E: Troubleshooting Network Issues
533
Appendix F: Troubleshooting Stop Messages
597
Answers
619
Glossary
641
Index
645
What do you think of this book? We want to hear from you!
Microsoft is interested in hearing your feedback so we can continually improve our
books and learning resources for you. To participate in a brief online survey, please visit:
www.microsoft.com/learning/booksurvey/
Contents
xv
Acknowledgments
T
his book was put together by a team of respected professionals, and we, the authors,
would like to thank them all for the great job they did. At Microsoft, Ken Jones and
Martin DelRe worked out our contracts, and Maria Gargiulo was our developmental editor.
Denise Bankaitis, Carol Vu, and Christian Holdener were the project editors, coordinating the
many other people who worked on the book. Among those, Susan McClung was our copy
editor, who was responsible for making sure the book is readable and consistent, and
Lindsey Valich, Paul ­Connelly, and Nicole Schlutt provided additional editorial proofreading.
Bob Dean and Bob Hogan provided a technical review to help make the book as accurate
as possible.
Tony Northrup would also like to thank his friends for helping him relax after long days
of writing, especially Eddie and Christine Mercado (for the dinners), Jose and Lucy ­Mercado
(por el arroz y los frijoles), Brian and Melissa Rheaume (for the drinks), Diane Glenn
(for the cake), Jose Gonzalez (for the laughs), and Madelyn Knowles (for the patience).
J.C. Mackin would like to thank all his friends and family for their support
and ­encouragement.
It makes a huge difference when you consider the people you work with to be friends.
Having a great team not only improves the quality of the book, it makes it a more ­enjoyable
experience. Writing this book was our most enjoyable project yet, and we hope we get
the chance to work with everyone again in the future.
xvii
Introduction
T
his training kit is designed for IT support personnel who support Windows 7 at the Tier 1 or
Tier 2 level in a wide range of environments and who plan to take the ­Microsoft ­Certified
Information Technology Professional (MCITP) exam 70-685. We assume that ­before you begin
using this kit you have a solid foundation-level understanding of Microsoft ­Windows ­client
­operating systems and common Internet technologies. The Preparation Guide for Exam 70-685
is available at http://www.microsoft.com/learning/en/us/exam.aspx?ID=70-685.
By using this training kit, you will learn how to do the following:
n
Identify cause of and resolve desktop application issues
n
Identify cause of and resolve networking issues
n
Manage and maintain systems that run Windows 7 client
n
Support mobile users
n
Identify cause of and resolve security issues
Refer to the objective mapping page in the front of this book to see where in the book
each exam objective is covered.
Hardware Requirements
You can complete almost all the practice exercises in this book, other than those in Lesson 3
of Chapter 2 (which requires a wireless network adapter), using virtual machines rather than
server hardware. The minimum and recommended hardware requirements for Windows 7
are listed in Table I-1.
Table I-1 Windows 7 Minimum Hardware Requirements
Hardware Component
Minimum Requirements
Recommended
Processor
1 GHz (x86), 1.4 GHz (x64)
2 GHz or faster
RAM
1 GB
2 GB or greater
Disk Space
16 GB
40 GB or greater
You also need to be able to install Windows Server 2008 R2, which is 64-bit. Therefore, you
must use hardware or virtual machine software that supports 64-bit operating systems. As of
the time of this writing, Microsoft Windows Virtual PC and Microsoft Virtual Server 2005 do not
xix
s­ upport 64-bit guests. Sun VirtualBox does support 64-bit guests and can be ­downloaded for free
from http://www.virtualbox.org. Alternatively, you can use the Hyper-V feature of Windows Server
2008 R2, as described at http://www.microsoft.com/windowsserver2008/en/us/hyperv-main.aspx.
If you intend to implement several virtual machines on the same computer
(­recommended), a higher specification will enhance your user experience. In particular,
a ­computer with 4 GB RAM and 60 GB free disk space can host all the virtual machines
­specified for all the practices in this book.
Practice Setup Instructions
The practice exercises in this training kit require a minimum of three computers or virtual
machines, as follows:
n
One server running Windows Server 2008 R2 Standard and configured as a domain
controller. Name the server DC1. Name the domain nwtraders.msft.
n
Two computers running Windows 7 and configured as domain members. Name
the computers CLIENT1 and CLIENT2.
When installing the operating systems, accept all default settings except for the computer
names listed above.
Using the Companion CD
The companion CD included with this training kit contains the following:
tests You can reinforce your understanding of how to support Windows 7 by
using electronic practice tests that you customize to meet your needs from the pool of
Lesson Review questions in this book, or you can practice for the 70-685 certification
exam by using tests created from a pool of about 200 realistic exam questions, which
give you many practice exams to ensure that you are prepared.
nPractice
n
Practice exercises Some chapters in this book include scripts that configure your test
computers for the practice exercises at the end of every lesson. To install the scripts
on your hard disk, run Setup.exe in the Practice Exercises folder on the companion CD.
The default installation folder is \My Documents\Microsoft Press\MCITP Self-Paced
Training Kit Exam 70-685.
n
An eBook An electronic version (eBook) of this book is included for times when you
do not want to carry the printed book with you. The eBook is in Portable Document
Format (PDF), and you can view it by using Adobe Acrobat or Adobe Reader.
Digital Content for Digital Book Readers: If you bought a digital-only edition of this book, you can
enjoy select content from the print edition’s companion CD.
Visit http://www.microsoftpressstore.com/title/9780735627093 to get your downloadable content. This content
is always up-to-date and available to all readers.
xx Introduction
System Requirements for the Companion CD
T
o use the companion CD-ROM, you need a computer running Windows 7,
­Windows Server 2008, Windows Vista, Windows Server 2003, or Windows XP.
The computer must meet the following minimum requirements:
n
1 GHz 32-bit (x86) or 64-bit (x64) processor
n
1 GB of system memory
n
A hard disk partition with at least 1 GB of available space
n
A monitor capable of at least 800 × 600 display resolution
n
A keyboard
n
A mouse or other pointing device
n
An optical drive capable of reading CD-ROMs
The computer must also have the following software:
n
A Web browser such as Microsoft Internet Explorer version 6 or later
n
An application that can display PDF files, such as Adobe Acrobat Reader, which
can be downloaded at http://www.adobe.com/reader
These requirements support use of the companion CD-ROM. To perform
the ­practice exercises in this training kit, you will require additional hardware
or ­software, as detailed previously.
How to Install the Practice Tests
To install the practice test software from the companion CD to your hard disk, perform
the following steps:
1. Insert the companion CD into your CD drive and accept the license agreement.
A CD menu appears.
Note If the CD menu does not appear
If the CD menu or the license agreement does not appear, AutoRun might be disabled
on your computer. Refer to the Readme.txt file on the CD for alternate installation
instructions.
2. Click Practice Tests and follow the instructions on the screen.
Introduction xxi
How to Use the Practice Tests
To start the practice test software, perform these steps:
1. Click Start, click All Programs, and then select Microsoft Press Training Kit Exam Prep.
A window appears that shows all the Microsoft Press training kit exam prep suites
installed on your computer.
2. Double-click the lesson review or practice test you want to use.
Note Lesson reviews versus practice tests
Select (70-685) Windows 7, Enterprise Desktop Support Technician Lesson Review to
use the questions from the “Lesson Review” sections of this book. Select Windows 7,
­Enterprise Desktop Support Technician Practice Test to use a pool of more than
200 ­questions (per exam), similar to those that appear on the 70-685 certification exam.
Lesson Review Options
When you start a lesson review, the Custom Mode dialog box appears so that you can
­configure your test. You can click OK to accept the defaults, or you can customize the number
of questions you want, how the practice test software works, which exam objectives you
want the questions to relate to, and whether you want your lesson review to be timed. If you
are retaking a test, you can select whether you want to see all the questions again or only
the questions you missed or did not answer.
After you click OK, your lesson review starts as follows:
n
To take the test, answer the questions and use the Next and Previous buttons to move
from question to question.
n
After you answer a question, if you want to see which answers are correct—along with
an explanation of each correct answer—click Explanation.
n
If you prefer to wait until the end of the test to see how you did, answer all
the ­questions and then click Score Test. You will see a summary of the exam ­objectives
you chose and the percentage of questions you got right, both overall and per
­objective. You can print a copy of your test, review your answers, or retake the test.
Practice Test Options
When you start a practice test, you choose whether to take the test in Certification Mode,
Study Mode, or Custom Mode:
Mode Closely resembles the experience of taking a certification exam.
The test has a set number of questions. It is timed, and you cannot pause and restart
the timer.
nCertification
xxii Introduction
Mode Creates an untimed test, during which you can review the correct
­answers and the explanations after you answer each question.
nStudy
n
Custom Mode Gives you full control over the test options so that you can customize
them as you like.
In all modes, the user interface when you are taking the test is basically the same but
with different options enabled or disabled depending on the mode. The main options
are ­discussed in the previous section, “Lesson Review Options.”
When you review your answer to a practice test question, a “References” section is
­ rovided that lists where in the training kit you can find the information that relates to that
p
question and provides links to other sources of information. After you click Test Results to
score your entire practice test, you can click the Learning Plan tab to see a list of references
for every objective.
How to Uninstall the Practice Tests
To uninstall the practice test software for a training kit, use the Uninstall A Program option
in Windows Control Panel.
Microsoft Certified Professional Program
Microsoft certifications provide the best method for proving your command of current ­Microsoft
products and technologies. The exams and corresponding certifications are ­developed to
validate your mastery of critical competencies as you design and develop, or implement
and ­support, solutions with Microsoft products and technologies. Computer professionals
who ­become Microsoft certified are recognized as experts and are sought after industry-wide.
­Certification brings a variety of benefits to the individual and to employers and organizations.
More Info All the Microsoft certifications
For a full list of Microsoft certifications, go to http://www.microsoft.com/learning/mcp/
default.asp.
Support for This Book
Every effort has been made to ensure the accuracy of this book and the contents of
the ­companion CD. As corrections or changes are discovered, they will be added to
a ­Microsoft Knowledge Base article accessible via the Microsoft Help and Support site.
­Microsoft Press provides support for books, including instructions for finding Knowledge
Base articles, at the following Web site:
http://www.microsoft.com/learning/support/books/
Introduction xxiii
If you have questions regarding the book that are not answered by visiting the site
above or viewing a Knowledge Base article, send them to Microsoft Press via e-mail to
[email protected]
Please note that Microsoft software product support is not offered through these ­addresses.
We Want to Hear from You
We welcome your feedback about this book. Please share your comments and ideas via
the following short survey:
http://www.microsoft.com/learning/booksurvey
Your participation will help Microsoft Press create books that better meet your needs
and your standards.
Note Connect with Microsoft Press
We hope that you will give us detailed feedback via our survey. If you have questions about
our publishing program, upcoming titles, or Microsoft Press in general, we encourage you
to interact with us via Twitter at http://twitter.com/MicrosoftPress. For support issues, use
only the e-mail address shown above.
xxiv Introduction
CHAPTE R 5
Protecting Client Systems
A
ny computer that is connected to the Internet faces a barrage of network-based threats
in the form of malicious software attacks. These threats are growing in number and
sophistication every year, and as an enterprise support technician, you are responsible for
protecting client systems from these evolving dangers.
As part of your company’s broad defense strategy, you need to know how to configure
in Windows 7 the features whose purpose is to protect your clients. Specifically, you need
to know how to minimize the risk of damage from malware by implementing User ­Account
Control (UAC) at an appropriate level, by using Windows Defender, and by removing
­unwanted software if it is discovered.
Exam objective in this chapter:
n
Identify and resolve issues due to malicious software.
Lesson in this chapter:
n
Lesson 1: Resolving Malware Issues 195
Before You Begin
To perform the exercises in this chapter, you need:
n
A domain controller running Windows Server 2008 R2
n
A client computer running Windows 7 that is a member of the same domain
Real World
J.C. Mackin
I
often hear people repeating a number of misconceptions about viruses and other
malware, and I’m convinced that these misconceptions have lulled users and
administrators into a false sense of security about the dangers their systems face.
Often these misconceptions are based on an accurate understanding of what was
the state of malware threats about 10 years ago. But the nature of these threats has
evolved significantly, and it continues to evolve. So in the interest of learning how best
to defend ourselves today, let’s deal with the most common of these misconceptions.
CHAPTER 5
193
n
“As long as you keep Windows updated, you’re fine.”
It’s certainly true that you need to keep Microsoft Windows updated, but
you need to keep all your software updated. Security holes can be found
in applications as easily as they can be found in operating systems, and the
security holes in many of these can be exploited to completely compromise
a system. Microsoft Office applications in particular are often targeted.
Remember that your systems are not safe from exploits if you are keeping only
Windows updated.
n
“As long as you aren’t tricked into opening anything, you’re fine.”
A long time ago, it was true that malicious software needed user assistance
to be installed on a system. Now, the situation is completely different.
Merely browsing to the wrong site, for example, can lead to a secret driveby download of malicious software. Even worse, some of the most harmful
attacks come from Internet worms, which need no user involvement
whatsoever. It is still essential for users to avoid opening unknown software,
but this preventative measure alone is not enough to keep your systems safe
from infection.
n
“As long as you keep your antivirus software up to date and scan daily, you’re fine.”
This might be the most common of all misconceptions regarding malware.
While it’s true that a robust anti-malware solution is one of the essential pillars
of a sound client protection strategy, the sad truth is that such software has its
limitations. Malware developers who are serious about exploiting computers
naturally design their programs in a way that avoids detection by antivirus
solutions. For example, a rootkit is a relatively new type of malware that—so
far—few anti-malware applications have had good success in detecting. But
even more familiar types of malware can be designed to evade detection. As
a result, when your antivirus software fails to detect malware on a system, you
should know that the system still could very easily be infected.
These three misconceptions all have a common thread running through them: the
belief that you can protect your systems by adopting a small number of well-known
defenses against malware. In truth, adequately protecting client systems requires
your company to adopt a wide array of strategies that include effective software
updates, antivirus software, user education, firewalls, and most important of all,
effective management of these and other security features.
194
CHAPTER 5
Protecting Client Systems
Lesson 1: Resolving Malware Issues
The number of new malware applications being released today actually exceeds that of new
legitimate applications. As an enterprise support technician, you need to adequately protect
your clients from these mounting threats and know how to handle malware infections once
they are discovered.
Windows 7 includes two features that assist you in this fight against malware. User Account
Control (UAC) helps prevent programs from secretly altering protected areas of the operating
system, and Windows Defender scans your system for spyware and offers to remove any
unwanted software that is detected.
Though you will need to use additional applications such as Microsoft Forefront and
a managed anti-malware solution to protect your network, understanding how to use and
configure these built-in features of Windows 7 represents part of the essential skill set you
need on your job.
After this lesson, you will be able to:
n
n
n
Configure User Account Control (UAC) to display notifications in a way that
suits the needs of your organization.
Configure Windows Defender settings.
Detect and remove some malware manually in case your anti-malware
­applications fail.
Estimated lesson time: 30 minutes
Understanding Malware
Malware is an umbrella term for many different types of unwanted software. It’s important
to understand the nature of these different threats, but it’s also important to recognize that
many malware applications blend features from more than one of these malware types.
The following list discusses the most common types of malware:
n
Virus A virus is a self-replicating program that can install itself on a target c­ omputer.
Viruses do not propagate over networks automatically; they need to be spread
through e-mail or another means. Once installed, viruses usually alter, damage,
or compromise a system in some way.
n
Worm A worm is a self-replicating program that can spread automatically over
a network without any help from a user or a program such as an e-mail client or Web
browser. Worms vary greatly in the potential damage they can cause. Some worms
simply replicate and do little other than consume network bandwidth. Others can be
used to compromise a system completely.
Lesson 1: Resolving Malware Issues
CHAPTER 5
195
n
Trojan horse A Trojan horse is a program that is presented to users as a desirable
­ pplication but that is intentionally written to harm a system. Unlike viruses and
a
worms, Trojan horses do not copy themselves automatically or install themselves
­automatically; they rely on users to install them.
n
Spyware Spyware is a type of privacy-invasive software that secretly records
information about user behavior, often for the purposes of market research. Typically
spyware is injected into a system when a user installs a free tool or visits a Web site
with browser security settings set to a low level. The most common function of such
spyware is to record the Web sites that a user visits. More rarely, some spyware, such
as keyloggers (which record every keystroke), can be installed deliberately by a third
party and be used to gather personal information. The biggest threat posed by most
spyware is system performance degradation. All types of spyware reduce system
performance by hijacking the resources of the computer for their own purposes. Unlike
viruses and worms, spyware does not self-replicate.
n
Adware Adware is similar to spyware and is often installed alongside it. The purpose
of adware is to display unsolicited advertisements to the user in the form of pop-up
windows or Web browser alterations. Adware can also download and install spyware.
Note Spyware and adware
The term spyware is often used as a general term for all unwanted software that runs in
the background and that gathers market research information, displays advertisements,
or alters the behavior of applications such as Web browsers. Microsoft uses the phrase
“spyware and potentially unwanted software” to refer to the type of software that is
unwanted but is not unambiguously harmful.
n
Backdoor A backdoor is a program that gives a remote, unauthorized party c­ omplete
control over a system by bypassing the normal authentication mechanism of that
­system. Backdoors have been known to be installed by worms that exploit a weakness
in a well-known program. To protect your system against backdoors, it is essential to
keep your applications (not just your operating system) updated.
n
Rootkit A rootkit is a persistent type of malware that injects itself beneath the
­ pplication level and that as a result, tends to be much harder to detect from within
a
the operating system. A rootkit can alter the core functionality of the operating
­system, or it can install itself as its own operating system invisible to the user and to
most anti-malware software. Other rootkits can operate at the firmware (BIOS) level.
Typically, a rootkit is used to provide a backdoor to a system.
Although malware has been proliferating in type and number, the defenses against these
threats have improved as well. When UAC is enabled in Windows 7, for example, a malware
application cannot install itself easily without the user's knowledge. This next section provides an
overview of UAC, which was introduced in Windows Vista and has been refined in Windows 7.
196
CHAPTER 5
Protecting Client Systems
Understanding UAC
UAC is a set of security features designed to minimize the danger of running Windows as an
administrator and to maximize the convenience of running Windows as a standard user. In
versions of Windows before Windows Vista, the risks of logging on as an administrator were
significant, yet the practice of doing so was widespread. Meanwhile, running as a standard
user was generally safe, but the inconveniences prevented many from adopting the practice.
In versions of Windows before Windows Vista, malware could use the credentials of
a ­locally logged-on administrator to damage a system. For example, if you were logged
on to Windows XP as an administrator and unknowingly downloaded a Trojan horse from
a ­network source, this malware could use your administrative privileges to reformat your hard
disk drive, delete all your files, or create a hidden administrator account on the local system.
The main reason that users in previous versions of Windows often ran as ­administrators
despite these dangers is that many common tasks, such as installing an application or a
­ dding
a printer, required a user to have administrator privileges on the local machine. Because
in ­previous ­versions of Windows there was no easy way to log on as a standard user and
“elevate” to an ­administrator only when necessary, organizations whose users occasionally
needed ­administrator privileges simply tended to configure their users as administrators on
their local machines.
Note What is elevation?
The term elevation is used when a user adopts administrator privileges to perform a task.
How Does UAC Address the Problem of Administrator Privileges?
UAC is the result of a new Windows security design in which both standard users and
administrators use the limited privileges of a standard user to perform most actions. When
users are logged on, UAC prompts them in different ways to confirm actions that make
important changes to the computer. If an administrator is logged on, the action is performed
only if he or she confirms it. If a standard user is logged on, the action is performed only if
he or she can provide administrator credentials. In both cases, the elevation to administratorlevel privileges is temporary and used to perform only the action required. Through this new
system, UAC inhibits malware from secretly using a logged-on administrator’s privileges.
Understanding UAC Notifications for Administrators
By default, UAC is configured to notify administrators only when programs request ­elevation.
For example, administrators see UAC notification when they attempt to run a program
(such as Cmd.exe) at elevated administrator privileges, as shown in Figure 5-1. According to
this default setting, administrators in Windows 7 do not see a UAC notification when they
adjust Windows settings that require administrator privileges.
Lesson 1: Resolving Malware Issues
CHAPTER 5
197
Figure 5-1 Opening an elevated command prompt
Note Changes in Windows 7 UAC behavior
For administrators, the default behavior of UAC in Windows 7 has changed significantly
from that in Windows Vista and Windows Server 2008. In those operating systems, UAC
generated a prompt by default whenever any type of elevation was requested, including
when an administrator attempted to change Windows settings. Administrators see UAC
prompts less frequently in Windows 7.
The UAC notification that normally appears for administrators is called a consent prompt
and is shown in Figure 5-2. Note that by default, the entire screen darkens when the
­notification appears and freezes until the user responds to the prompt. This feature is called
the Secure Desktop and can be disabled.
Note Educate users about UAC prompts!
The point of UAC notifications is to alert users when malware might be harming your
­computer. If malware were to request elevation for a particular purpose, it too would
­generate a notification such as the one shown in Figures 5-2 or 5-3. Consequently,
an essential factor in the ability of UAC to thwart malware is appropriate user response. You
need to educate users—and gently remind your fellow administrators—that they should
click No or Cancel whenever they see a UAC notification message that they did not initiate.
198
CHAPTER 5
Protecting Client Systems
Figure 5-2 By default, UAC displays a consent prompt on a Secure Desktop to administrators who
­request to run a program with elevation.
Understanding UAC Notifications for Standard Users
The UAC notifications shown to standard users are distinct from those shown to
administrators in that the notifications for standard users prompt these users to provide
administrator credentials. As with administrators, standard users by default receive UAC
notifications when they attempt to run a program such as a command prompt at elevated
privileges, or when a program independently requests elevation. In addition, standard users
by default receive UAC notifications when they attempt to make changes on the system that
require administrator privileges. For example, if standard users open the System page in
Control Panel and click Remote Settings, they see the credential prompt shown in Figure 5-3.
Note The default behavior of UAC is the same for standard
users in Windows 7
Although UAC in Windows 7 offers many notification levels that did not exist in ­Windows
Vista or Windows Server 2008, the default behavior for standard users is the same.
­Whenever standard users attempt to make a change that requires administrator privileges,
a credential prompt appears on a Secure Desktop.
Lesson 1: Resolving Malware Issues
CHAPTER 5
199
Figure 5-3 By default, UAC displays a credential prompt on a Secure Desktop to standard users who
request elevation.
Configuring UAC in Control Panel
In a domain environment, it is recommended that UAC be controlled centrally by Group
Policy instead of by configuration settings on each local machine. However, in workgroup
­environments or in domain environments in which Group Policy allows local UAC
configuration, you can configure UAC through Control Panel.
To configure UAC in Control Panel, perform the following steps:
1. In Control Panel, click System and Security.
2. Under Action Center, click Change User Account Control Settings, as shown in Figure 5-4.
Figure 5-4 You can access UAC settings through the Action Center.
200
CHAPTER 5
Protecting Client Systems
This step opens the User Account Settings window, one version of which is shown in
Figure 5-5. Note that the set of options that appears is different for administrators and
standard users, and that each user type has a different default setting.
Figure 5-5 UAC allows you to choose among four notification levels.
3. Choose one of the following notification levels:
n
Always Notify This level is the default for standard users, and it configures UAC
to act as it does in Windows Vista. At this level, users are notified whenever any
changes that require administrator privileges are attempted on the system.
n
Notify Me Only When Programs Try To Make Changes To My Computer This
level is the default for administrators and is not available for standard users.
At this level, administrators are not notified when they make changes that require
­administrator privileges. However, users are notified through a consent prompt
when a program requests elevation.
n
Always Notify Me (And Do Not Dim My Desktop) This level is not available for
administrators. It is similar to the default setting for standard users, except that at
this particular level, the Secure Desktop is never displayed. Disabling the Secure
Desktop tends to reduce protection against malware, but it improves the user
­experience. This setting might be suitable for standard users who very frequently
need to request elevation.
Lesson 1: Resolving Malware Issues
CHAPTER 5
201
n
Notify Me Only When Programs Try To Make Changes To My Computer
(Do Not Dim The Desktop) This level is available for both standard users
and ­administrators. At this level, the behavior is the same as with the default
administrator level (“Notify me only when programs try to make changes to my
computer”), but with this option the Secure Desktop is not displayed.
n
Never Notify This level disables notifications in UAC. Users are not notified of
any changes made to Windows settings or when software is installed. This option is
­appropriate only when you need to use programs that are incompatible with UAC.
4. Click OK.
Configuring UAC Through Group Policy
You can configure UAC through Local Security Policy or Group Policy settings. To find
­UAC-related policy settings in a GPO, navigate to the following node:
Computer Configuration\Policies\Windows Settings\Security Settings\Local Policies
\Security Options
This location is shown in Figure 5-6.
Figure 5-6 You can find UAC settings in Security Options in a GPO or in Local Security Policy
The following 10 UAC-related policy settings are available. The next section describes each
of these configurable settings.
202
CHAPTER 5
Protecting Client Systems
n
User Account Control: Admin Approval Mode For The Built-in Administrator
­Account This policy applies only to the built-in Administrator account, and not to
other accounts that are members of the local Administrators group. When you enable
this policy setting, the built-in Administrator account sees UAC notifications just as other
administrative accounts do. When you disable the setting, the built-in Administrator
account behaves just like it does in Windows XP, and all processes run using
Administrator privileges. This setting is disabled in Local Security Policy by default.
n
User Account Control: Allow UIAccess Applications to Prompt For Elevation Without
Using The Secure Desktop This setting controls whether user Interface Accessibility
(UIAccess) programs can disable the Secure Desktop automatically. When enabled,
UIAccess applications (such as Remote Assistance) automatically disable the Secure
Desktop for elevation prompts. Disabling the Secure Desktop causes elevation prompts to
appear on the standard desktop. By default, this setting is disabled in Local Security Policy.
n
User Account Control: Behavior Of The Elevation Prompt For Administrators In
­Admin Approval Mode This policy setting controls the behavior of the elevation
prompt for administrators. Six options are available:
• Elevate Without Prompting With this option, administrators never see elevation
prompts.
• Prompt For Credentials On The Secure Desktop When this option is chosen,
administrators see credential prompts on a Secure Desktop when elevation is
­requested.
• Prompt For Consent On The Secure Desktop With this option, administrators
see a consent prompt on a Secure Desktop when elevation is requested.
• Prompt For Credentials When this option is selected, administrators see
a ­credential prompt on a normal desktop when elevation is requested.
• Prompt For Consent When this option is selected, administrators see a consent
prompt on a normal desktop when elevation is requested.
• Prompt For Consent For Non-Windows Binaries This option is the default
s­ etting in Local Security Policy. It causes a consent prompt to appear any time
an application requests elevation.
n
User Account Control: Behavior Of The Elevation Prompt For Standard Users This
policy setting controls the behavior of the elevation prompt for standard users. Three
options are available:
• Automatically Deny Elevation Requests When this option is enforced, standard
users are not able to perform tasks that require elevation.
• Prompt For Credentials On The Secure Desktop With this option (the default
setting in Local Security Policy), standards users see a credential prompt on the
Secure Desktop when elevation is requested.
• Prompt For Credentials When this option is chosen, standard users see
a credential prompt on the normal desktop whenever elevation is requested.
Lesson 1: Resolving Malware Issues
CHAPTER 5
203
n
User Account Control: Detect Application Installations And Prompt For
­Elevation When enabled, this policy setting configures UAC to prompt for
administrative credentials when the user attempts to install an application that
makes changes to protected aspects of the system. When disabled, the prompt won’t
appear. Domain environments that use delegated installation technologies such as
Group Policy Software Install (GPSI) or Microsoft Systems Management Server (SMS)
can disable this feature safely because installation processes can escalate privileges
automatically without user intervention. By default, this setting is enabled in Local
Security Policy.
n
User Account Control: Only Elevate Executables That Are Signed And
Validated When this policy setting is enabled, Windows 7 refuses to run any
executable that isn’t signed with a trusted certificate, such as a certificate generated
by an internal Public Key Infrastructure (PKI). When disabled, this policy setting allows
users to run any executable, potentially including malware. If your environment
requires all applications to be signed and validated with a trusted certificate, including
internally developed applications, you can enable this policy to increase security
greatly in your organization. This setting is disabled in Local Security Policy by default.
n
User Account Control: Only Elevate UIAccess Applications That Are Installed In
Secure Locations When enabled, this policy setting causes Windows 7 to grant
user interface access only to those applications that are started from Program Files
or subfolders, from Program Files (x86) or subfolders, or from \Windows\System32\.
When disabled, the policy setting grants user interface access to applications
regardless of where they are started in the file structure. This policy setting is enabled
by default in Local Security Policy.
n
User Account Control: Run All Administrators In Admin Approval Mode This
policy setting, enabled by default in Local Security Policy, causes all accounts with
administrator privileges except for the local Administrator account to see consent
prompts when elevation is requested. If you disable this setting, administrators never
see consent prompts and the Security Center displays a warning message.
n
User Account Control: Switch To The Secure Desktop When Prompting For
Elevation The Secure Desktop is a feature that darkens the screen and freezes
all activity except for the UAC prompt. It reduces the possibility that malware can
function, but some users might find that the feature slows down their work too much.
When enabled, this policy setting causes the Secure Desktop to appear with a UAC
prompt. When disabled, this policy setting allows UAC prompts to appear on a normal
desktop. This policy setting is enabled by default in Local Security Policy.
n
User Account Control: Virtualize File And Registry Write Failures To Per-User
Locations This policy setting, enabled by default in Local Security Policy, improves
compatibility with applications not developed for UAC by redirecting requests for
protected resources. When disabled, this policy setting allows applications not
developed for UAC to fail.
204
CHAPTER 5
Protecting Client Systems
Disabling UAC Through Local or Group Policy
To force UAC to a disabled state, you can use Local Security Policy or Group Policy. First, set
the User Account Control: Behavior Of The Elevation Prompt For Administrator In Admin
Approval Mode setting to Elevate Without Prompting. Then, disable the User Account
Control: Detect Application Installations And Prompt For Elevation and User Account Control:
Run All Administrators In Admin Approval Mode settings. Finally, set User Account Control:
Behavior Of The Elevation Prompt For Standard Users setting to Automatically Deny Elevation
Requests. Then, restart the computers on which you want to apply the new settings.
Best Practices for Using UAC
To receive the security benefits of UAC while minimizing the costs, follow these best practices:
n
Leave UAC enabled for client computers in your organization.
n
Have all users—especially IT staff—log on with standard user privileges.
n
Each user should have a single account with only standard user privileges. Do not give
standard domain users accounts with administrator privileges to their local computers.
n
Domain administrators should have two accounts: a standard user account that they
use to log on to their computers, and a second administrator account that they can use
to elevate privileges.
n
Train users not to approve a UAC prompt if it appears unexpectedly. UAC prompts
should appear only when the user is installing an application or starting a tool that
requires elevated privileges. A UAC prompt that appears at any other time might have
been initiated by malware. Rejecting the prompt helps prevent malware from making
permanent changes to the computer.
Quick Check
n
Which Group Policy setting could you enable to prevent executables from
running if they aren’t signed with a trusted certificate?
Quick Check Answer
n
User Account Control: Only Elevate Executables That Are Signed And Validated
Whereas UAC is a set of features that broadly aims to protect core areas of the ­operating
system, another Windows 7 tool—Windows Defender—has a much narrower goal of
­detecting and removing unwanted software.
Protecting Clients from Spyware with Windows Defender
Windows Defender is a tool in Windows 7 whose purpose is to detect and remove spyware
on a client system. By default, Windows Defender is configured to download new spyware
definitions regularly through Windows Update and then use these definitions to scan for
Lesson 1: Resolving Malware Issues
CHAPTER 5
205
spyware on the local system. Often, you do not need to change this default configuration,
though in large networks you might want to disable some Windows Defender features
through Group Policy.
Note Use Windows Defender in small networks
Windows Defender is a basic anti-malware program that is suitable for use in small
­networks or as a temporary solution before an advanced anti-malware solution is
­purchased. In large networks, you should use a centrally managed anti-malware solution
such as Microsoft Forefront Client Security.
To view Windows Defender, open Control Panel, select View By Large Icons, and then scroll
down to click Windows Defender, as shown in Figure 5-7. (Alternatively, you can click Start,
type windows defender, and select Windows Defender in the Start menu.)
Figure 5-7 Opening Windows Defender Windows Defender is shown in Figure 5-8.
By default, Windows Defender provides two types of protection:
n
Automatic scanning Windows Defender is configured by default to download new
definitions and then perform a quick scan for spyware at 2 a.m. daily.
n
Real-time protection With this feature, Windows Defender constantly monitors
computer usage in areas such as the Startup folder, the Run keys in the registry, and
Windows add-ons. If an application attempts to make a change to one of these areas,
Windows Defender prompts the user either to Permit (allow) or Deny (block) the change.
206
CHAPTER 5
Protecting Client Systems
Figure 5-8 Windows Defender automatically checking for spyware
Besides providing this automatic functionality, Windows Defender also lets you perform
a manual scan of the system. You can start a manual scan by selecting Quick Scan, Full Scan,
or Custom Scan from the Scan menu, as shown in Figure 5-9.
Figure 5-9 Performing a manual scan in Windows Defender
Lesson 1: Resolving Malware Issues
CHAPTER 5
207
These three scan types are described in the following list:
n
Quick Scan This type of scan scans only the areas of a computer most likely to be
infected by spyware or other potentially unwanted software. These areas include the
computer’s memory and portions of the registry that link to startup applications.
A quick scan is sufficient to detect most spyware.
n
Full Scan This type of scan scans every file on the computer, including common types
of file archives and applications already loaded in the computer’s memory. A full scan
typically takes several hours and can even take more than a day. You need to run a full
scan only if you suspect that a user’s computer is infected with unwanted software
after the quick scan is run.
n
Custom Scan Custom scans begin with a quick scan and then perform a detailed scan
on the specific portions of a computer that you choose.
Note You can work on a computer while a scan is in progress
Although scans slow the computer down, a user can continue to work on the computer
while a scan is in progress. Note also that scans consume battery power on mobile
­computers very quickly.
Handling Detected Spyware
If Windows Defender finds spyware or potentially unwanted software as a result of a scan,
it displays a warning and provides you with four options for each item detected:
n
Ignore This option allows the detected software to remain untouched on your
c­ omputer and stay detectable by Windows Defender whenever the next scan is
­performed. This option might be appropriate when you need to research the software
that Windows Defender has found before you decide to remove it.
n
Quarantine This option isolates the detected software. When Windows Defender
quarantines software, it moves it to another location on your computer and then
prevents the software from running until you choose to restore it or remove it from
your computer. This option is used most often when the detected software cannot be
removed successfully.
n
Remove This option deletes the detected software from your computer. You should
choose this option unless you have a compelling reason not to.
n
208
Always Allow The option adds the software to the Windows Defender Allowed list
and allows it to run on your computer. Windows Defender stops alerting you to actions
taken by the program. You should choose this option only if you trust the software and
the software publisher.
CHAPTER 5
Protecting Client Systems
Configuring Windows Defender Through Group Policy
In an AD DS environment, it is recommended that you configure clients by using Group
Policy instead of individually on each machine. To find the Group Policy settings for ­Windows
­Defender, open a GPO and navigate to Computer Configuration\Policies\Administrative
­Templates\Windows Components\Windows Defender, as shown in Figure 5-10.
Figure 5-10 Group Policy settings for Windows Defender
The following seven policy settings for Windows Defender are available:
n
Turn On Definition Updates Through Both WSUS And Windows Update If you
enable or do not configure this policy setting and the Automatic Updates client is
­configured to point to a WSUS server, Windows Defender obtains definition updates
from Windows Update if connections to that WSUS server fail. If you disable this
­setting, Windows Defender checks for updates only according to the setting defined for the Automatic Updates client—either by using an internal WSUS server or
­Windows Update.
n
Turn On Definition Updates Through Both WSUS And The Microsoft Malware
­Protection Center If you enable or do not configure this policy setting and the
Automatic Updates client is configured to point to a WSUS server, Windows Defender
checks for definition updates from both WSUS and the Microsoft Malware Protection
Center if connections to that WSUS server fail. If you disable this setting, Windows
Defender checks for updates only according to the setting defined for the Automatic
Updates client—either by using an internal WSUS server or Windows Update.
n
Check For New Signatures Before Scheduled Scans If you enable this policy setting,
Windows Defender always checks for new definitions before it begins a scheduled
scan of the computer. When you disable or do not configure this setting, Windows
­Defender does not check for new definitions immediately before beginning
scheduled scans.
Lesson 1: Resolving Malware Issues
CHAPTER 5
209
n
Turn Off Windows Defender If you enable this policy setting, Windows Defender no
longer performs any real-time or scheduled scans. (However, users can still p
­ erform
manual scans.) You should enable this setting if you have implemented a more
­advanced anti-spyware solution such as Microsoft Forefront Client Security. If you
disable or do not configure this policy setting, Windows Defender performs both
­real-time scans and any scheduled scans.
n
Turn Off Real-Time Monitoring If you enable this policy setting, Windows Defender
does not automatically prompt users to allow or block activity in protected areas of
the operating system. If you disable or do not configure this policy setting, by default
Windows Defender prompts users to allow or block potential spyware activity on their
computers.
n
Turn Off Routinely Taking Action If you enable this policy setting, Windows
­Defender only prompts the user to choose how to respond to a threat but not to take
any automatic action. If you disable or do not configure this policy setting, Windows
Defender automatically takes action on detected threats after approximately 10 minutes.
n
Configure Microsoft SpyNet Reporting SpyNet is an online community that pools
information about threats experienced by its members. SpyNet learns from the user
responses to these threats to determine which threats are benign and which are
­malicious.
If you enable this policy setting and choose the "No Membership" option, SpyNet
membership is disabled, and no information is sent to Microsoft. If you enable this
­policy setting and choose the "Advanced" option, SpyNet membership is set to
­Advanced, and information about detected threats and the responses to those threats
is sent to Microsoft.
If you disable or do not configure this policy setting, SpyNet membership is disabled
by default, but local users can change the membership setting.
Note Using a bootable antivirus CD
When a computer has become severely infected with malware, the computer might run
so slowly that it’s difficult to perform an anti-malware scan. In this case, it’s a good idea
to p
­ erform an offline scan from a bootable CD if you have one available. By performing
the scan outside of Windows, you avoid running the malware programs that consume
­resources and slow down the system.
Best Practices for Using Windows Defender
To receive the security benefits of Windows Defender while minimizing the costs, follow these
best practices:
n
210
Before deploying Windows 7, test all applications with Windows Defender enabled
to ensure that Windows Defender does not alert users to normal changes that the
­application might make. If a legitimate application does cause warnings, add the
­application to the Windows Defender Allowed list.
CHAPTER 5
Protecting Client Systems
n
Change the scheduled scan time to meet the needs of your business. By default,
­Windows Defender scans at 2 a.m. If third-shift staff uses computers overnight, you
might want to find a better time to perform the scan. If users turn off their computers
when they are not in the office, you should schedule the scan to occur during the day.
n
Use WSUS to manage and distribute signature updates.
n
Use antivirus software with Windows Defender. Alternatively, you might disable
­Windows Defender completely and use client-security software that provides both
anti-spyware and antivirus functionality.
n
Do not deploy Windows Defender in large enterprises. Instead, use Forefront or
a third-party client-security suite that can be managed more easily in enterprise
­environments.
More Info Windows Defender
For more information about Windows Defender, visit the Windows Defender ­Virtual Lab
Express at http://www.microsoftvirtuallabs.com/express/registration.aspx?LabId=92e04589cdd9-4e69-8b1b-2d131d9037af.
Determining When Your System Is Infected with Malware
As a enterprise support technician, you need to know how to recognize the symptoms of
a malware infection on your client computers. Then, if your antivirus and anti-spyware are not
functioning or not detecting any malware, you need to know how to remove malware manually.
Here are a few common signs of a computer being infected by a virus, worm, or Trojan
horse:
n
Sluggish computer performance
n
Unusual error messages
n
Distorted menus and dialog boxes
n
Antivirus software repeatedly turning itself off
n
Screen freezing
n
Computer crashing
n
Computer restarting
n
Applications not functioning correctly
n
Inaccessible disk drives, or a CD-ROM drive that automatically opens and closes
n
Notification messages that an application has attempted to contact you from the
Internet
n
Unusual audio sounds
n
Printing problems
Lesson 1: Resolving Malware Issues
CHAPTER 5
211
Note that, although these are common signs of infection, these symptoms might also
­indicate other types of hardware or software problems that are unrelated to malware.
Signs of a spyware infection tend to be slightly different from those of other types of
­malware. If you see any of the following symptoms, suspect spyware:
n
A new, unexpected application appears.
n
Unexpected icons appear in the system tray.
n
Unexpected notifications appear near the system tray.
n
The Web browser home page, default search engine, or favorites change.
n
New toolbars appear, especially in Web browsers.
n
The mouse pointer changes.
n
The Web browser displays additional advertisements when visiting a Web page,
or pop-up advertisements appear when the user is not using the Web.
n
When the user attempts to visit a Web page, she is redirected to a completely different
Web page.
n
The computer runs more slowly than usual.
Some spyware might not have any noticeable symptoms, but it still might compromise
private information.
How to Resolve Malware Infections
The most important way to resolve malware infections is to prevent them in the first place
by running antivirus and anti-spyware programs daily with the latest virus and spyware
definitions. If malware is discovered on a system, use the application to remove the malware
if possible and quarantine it if not. If it is a new malware program, you might need to run
a removal tool or perform a series of steps to remove it manually.
These steps naturally apply to malware that is detected. However, as important as it is to
remember to use antivirus and anti-spyware daily, it is just as important to remember that
no anti-malware application is foolproof. Many malware programs are in fact written around
anti-malware software so that they cannot be detected. And if even a single malicious feature
remains after a scan, that remaining malware program can install other malware programs.
If you suspect a problem related to malware after running antivirus and anti-spyware
­applications with the latest definitions, take the following steps:
1. If you notice changes to Windows Internet Explorer, such as unwanted add-ons
or a new home page, use Control Panel to look for and uninstall any unnecessary
­programs.
2. Use the Startup tab of the System Configuration utility (Msconfig.exe) to clear any
unnecessary startup programs. Note the Registry entry associated with any of these
programs. (You can use this Registry information to delete the associated Registry keys
if necessary.) Use the Services tab to disable any unnecessary services.
212
CHAPTER 5
Protecting Client Systems
3. Open Task Manager. Note any unusual services listed on the Services tab or unusual
processes listed on the Processes tab. (Be sure to click Show Processes From All Users
so you can see all running processes.) Use the Go To Process option on the Services
tab and the Go To Service(s) option on the Processes tab to help learn the connection
between services and processes that are unknown to you. Then, perform Web searches
on services and processes that lack descriptions or that otherwise seem suspicious.
If you can determine from your research that any services or processes are associated
with malware, right-click them to stop them. Then, in the Services console, disable the
associated service so that it cannot run again.
4. Open the Registry Editor (Regedit.exe). Navigate to HKLM\Software\Microsoft\
Windows\CurrentVersion\Run. In the details pane, note any Registry values associated
with unwanted started programs. Write the path names provided to the target files in
the Data column, as shown in Figure 5-11, and then delete the Registry values. Then,
navigate to HKCU\Software\Microsoft\Windows\CurrentVersion\Run and do the same.
Figure 5-11 Copy down the path names to files associated with unwanted startup programs,
and then delete the Registry values.
5. Using the path name information that you copied in step 4, visit these locations in the
Windows file structure and delete the target files.
6. If you still see signs of malware, install an additional anti-spyware and antivirus
application from a known and trusted vendor. Your chances of removing all traces of
malware increase by using multiple applications, but you should not configure multiple
applications to provide real-time protection.
7. If problems persist, shut down the computer and use the Startup Repair tool to
perform a System Restore. Restore the computer to a date prior to the malware
infection. System Restore typically removes any startup settings that cause malware
applications to run, but it does not remove the executable files themselves. Do this
only as a last resort: Although System Restore does not remove a user’s personal files,
it can cause problems with recently installed or configured applications.
Performing this series of steps resolves a great majority of malware problems. However,
once malware has run on a computer, you can never be certain that the software is removed
completely. In particular, rootkits are difficult to detect and remove. In these circumstances,
if you suspect a rootkit and cannot remove it, you might be forced to reformat the hard disk,
reinstall Windows, and then restore user files using a backup created prior to the infection.
Lesson 1: Resolving Malware Issues
CHAPTER 5
213
Pr actice
Enforcing an Anti-Malware Policy Through Group Policy
In this practice, you use Group Policy to enforce specific settings for UAC and Windows
­Defender. These exercises require a domain controller running Windows Server 2008 R2 and
a client running Windows 7 that is a member of the same domain.
E xercise 1 Enforcing UAC Settings Through Group Policy
In this exercise, you enforce new UAC default settings on computers running Windows 7 in
the domain.
1. Log on to the domain controller.
2. Open Group Policy Management by clicking Start\All Programs\Administrative Tools\
Group Policy Management.
3. In the Group Policy Management console tree, navigate to Group Policy Management\
Forest: Forest Name\Domains\Domain Name\Default Domain Policy.
4. Right-click Default Domain Policy, and then click Edit from the shortcut menu. The
Group Policy Management Editor opens.
5. In the Group Policy Management Editor, navigate to Default Domain Policy\
Computer Configuration\Policies\Windows Settings\Security Settings\Local Policies\
Security Options.
6. In the details pane, double-click to open User Account Control: Switch To The Secure
Desktop When Prompting For Elevation.
7. On the Security Settings tab, click Define This Policy Setting, select Disabled, and then
Click OK.
8. In the details pane, double-click to open User Account Control: Behavior Of The
­Elevation Prompt For Standard Users.
9. On the Security Settings tab, click Define This Policy Setting, select Prompt For
­Credentials from the drop-down list, and then Click OK.
These settings remove the Secure Desktop from all UAC prompts.
10. Click OK.
11. Switch to the client running Windows 7. Restart the client, and then log on to the
­domain from the client as a domain administrator.
12. Open an elevated command prompt by clicking Start\All Programs\Accessories, then
right-clicking Command Prompt and clicking Run As Administrator from the shortcut
menu.
13. A consent prompt appears without a Secure Desktop.
14. Log off the client, and then log on again to the domain from the client as a standard
user without administrative privileges.
15. In Control Panel, beneath User Accounts, click Change Account Type. A credential
prompt appears without a Secure Desktop.
16. Log off the client.
214
CHAPTER 5
Protecting Client Systems
E xercise 2 Disabling Real-Time Monitoring for Windows Defender
A large corporate network should use a managed anti-spyware solution, which Windows
Defender is not. Using Windows Defender to provide a secondary daily scan for malware
on clients is a good idea, but you should not have two applications performing real-time
monitoring. If your managed anti-spyware solution provides real-time monitoring, you should
disable the same feature on Windows Defender by using Group Policy.
In this exercise, you use Group Policy to disable real-time monitoring for Windows Defender.
1. Log on to the domain controller.
2. Using the steps described in Exercise 1, open Group Policy Management and then
choose to edit the Default Domain Policy.
3. In the Group Policy Management Editor, navigate to Default Domain Policy\Computer
Configuration\Policies\Administrative Templates\Windows Components\Windows
Defender.
4. In the details pane, double-click to open Turn Off Real-Time Monitoring.
5. In the Turn Off Real-Time Monitoring dialog box, select Enabled, and then click OK.
6. Switch to Client1. Log on to the domain from Client1 as a domain administrator.
7. Open a command prompt and type gpupdate. You might see a notification bubble
appear indicating that Windows Defender is turned off.
8. After the command finishes executing, click Start, type windows defender, and then
click Windows Defender in the Start menu.
9. In Windows Defender, click Tools, and then click Options.
10. Select Real-Time Protection from the list of options.
11. The settings are dimmed. Real-time monitoring is disabled.
12. Return to the domain controller and the Default Domain Policy. Revert the Turn Off
Real-Time Monitoring policy setting to Not Configured, and then click OK.
13. Rerun gpupdate on Client1, and then close all open windows on both computers.
Lesson Summary
n
UAC helps prevent malware from secretly installing itself on Windows systems by
­notifying the user whenever a request is made to write to protected areas of the
­operating system. Users must be educated to dismiss these notifications if they have
not initiated them.
n
You can configure the behavior of UAC notifications. By default, administrators see
consent prompts on a Secure Desktop when a program requests elevation. ­Standard
users by default see credential prompts on a Secure Desktop whenever they or
a ­program requests elevation.
Lesson 1: Resolving Malware Issues
CHAPTER 5
215
n
Windows Defender is a built-in feature of Windows 7 that provides basic spyware
­filtering and detection. Often Windows Defender needs no configuration, but you
might want to disable it in larger networks that require a managed anti-spyware
solution.
n
You should how to check for and remove malware manually in case your anti-malware
solution isn't functioning as desired. To do so, investigate unknown processes and
­services to stop and disable them if necessary, and look in the Registry for programs
that are set to run automatically. Delete associated files.
Lesson Review
You can use the following questions to test your knowledge of the information in Lesson 2,
“Resolving Malware Issues.” The questions are also available on the companion CD if you
prefer to review them in electronic form.
Note Answers
Answers to these questions and explanations of why each answer choice is correct
or incorrect are located in the “Answers” section at the end of the book.
1. You work as an enterprise support technician in a large company. Your manager
reports that some network administrators are using the built-in Administrator account
for the domain and that, when logged on with this account, they are not seeing UAC
notifications. She asks you to change configuration settings so that users logged on to
the domain with the built-in Administrator account see UAC consent prompts. What
should you do?
A. Configure Local Security Policy to set the User Account Control: Admin Approval
Mode For The Built-in Administrator Account option to Enabled.
B. Configure Group Policy to set the User Account Control: Admin Approval Mode
For The Built-in Administrator Account option to Enabled.
C. Configure Local Security Policy to set the User Account Control: Run All
­Administrators In Admin Approval Mode option to Enabled.
D. Configure Group Policy to set the User Account Control: Run All Administrators In
Admin Approval Mode option to Enabled.
2. You work as an enterprise support technician in a company whose AD DS domain
c­ onsists of 20 servers running Windows Server 2008 R2 and 500 client computers
running Windows 7, 10 of which are portable and are used by employees who travel
globally for work. These users have complained that Windows Defender tends to start
a scan when the computer is operating on the battery source, and the scan quickly
216
CHAPTER 5
Protecting Client Systems
consumes battery power. You want to prevent Windows Defender from consuming
needed battery power without reducing the protection that it provides. What should
you do?
A. Instruct the users to perform a manual scan when their computers are connected
to a power source.
B. Choose the option to run a scan only when idle.
C. Instruct the users to adjust the schedule for automatic scanning.
D. Disable automatic scanning on all 10 computers.
Lesson 1: Resolving Malware Issues
CHAPTER 5
217
Chapter Review
To further practice and reinforce the skills you learned in this chapter, you can perform the
following tasks:
n
Review the chapter summary.
n
Review the list of key terms introduced in this chapter.
n
Complete the case scenario. The scenario sets up a real-world situation involving the
topics of this chapter and asks you to create a solution.
n
Complete the suggested practices.
n
Take a practice test.
Chapter Summary
n
Windows Firewall blocks all incoming connection requests by default. To allow
a network program to initiate a connection with a computer running Windows 7, you
need to create a firewall exception for that program.
n
To combat malware, you need to educate yourself and users continually about the
evolving nature of threats. You also need to manage antivirus software, anti-spyware
software such as Windows Defender, and UAC effectively. Finally, you need to know
how to recognize classic symptoms of an infection and how to remove an infection
manually if needed.
Key Terms
Do you know what these key terms mean? You can check your answers by looking up the
terms in the glossary at the end of the book.
n
Exception
n
Malware
n
Spyware
n
Virus
n
Worm
Case Scenario
In the following case scenario, you apply what you’ve learned about protecting client systems.
You can find answers to these questions in the “Answers” section at the end of this book.
218
CHAPTER 5
Protecting Client Systems
Case Scenario 1: Resolving Malware Infections
You work as an enterprise support technician for Contoso, Ltd., a marketing research firm
with 500 employees. You receive a call from the help desk to investigate a research assistant’s
notebook computer that is apparently running very slowly. A help desk support technician
was unable to resolve the issue.
You perform some basic testing on the computer, and you discover that several toolbars
associated with spyware are installed in Internet Explorer. Your company uses a combined
antivirus/anti-spyware solution, and Windows Defender is disabled on the network.
You conduct interviews with the Research Assistant and the Help Desk Support Technician.
Interviews
The following is a list of company personnel interviewed and their statements:
n
Research Assistant “The problem has been getting progressively worse for about
six months. It’s gotten to the point that everything takes forever. I used to take this
­computer home with me, but now I don’t even bother.”
n
Help Desk Support Technician “I tried to run an anti-malware scan, but nothing
seemed to happen.”
Questions
1. You want to immediately stop any malware that might be running. How should you
achieve this?
2. Your testing reveals that the anti-malware client software installed on the computer
does not run when it is opened. What can you do to perform an anti-malware scan on
the computer?
Suggested Practices
To help you master the exam objectives presented in this chapter, complete the following
tasks.
Identify and Resolve Issues Due to Malicious Software
Perform these practices to learn about tools that help detect and remove malware.
n
Practice 1 Perform a Web search for the term “Sysinternals Suite” or visit
http://technet.microsoft.com/en-us/sysinternals/bb842062.aspx. Download the
­Sysinternals Suite and unzip the file. Within the suite, locate Autoruns. Run Autoruns to
discover the programs that are configured to start up automatically on your computer.
Then, locate and run Rootkitrevealer to discover any rootkits on your system.
Suggested Practices
CHAPTER 5
219
n
Practice 2 Perform a Web search for the term “bootable anti-malware CD” and
research the various bootable anti-malware CDs that are available online. Create or
download a bootable anti-malware CD and then use it to perform a malware scan on
your system.
Take a Practice Test
The practice tests on this book’s companion CD offer many options. For example, you can test
yourself on just one exam objective, or you can test yourself on all the 70-685 ­certification
exam content. You can set up the test so that it closely simulates the experience of taking
a certification exam, or you can set it up in study mode so that you can look at the correct
answers and explanations after you answer each question.
More Info Practice tests
For details about all the practice test options available, see the section entitled “How to
Use the Practice Tests,” in the Introduction to this book.
220
CHAPTER 5
Protecting Client Systems
CHAPTE R 9
Troubleshooting Software
Issues
S
oftware errors can appear during the installation process, immediately after i­nstallation,
or long afterwards. Those that appear during installation tend to result from policy
or permission constraints, availability issues, or installation settings. Those that appear
­immediately after installation tend to be associated with policy restrictions or ­compatibility
problems. Those that appear long after installation tend to result from configuration
changes.
In this chapter, we look at the various causes of software errors and provide strategies for
how to resolve them.
Exam objectives in this chapter:
n
Identify and resolve new software installation issues.
n
Identify and resolve software configuration issues.
n
Identify cause of and resolve software failure issues.
Lessons in this chapter:
n
Lesson 1: Understanding and Resolving Installation Failures 340
n
Lesson 2: Resolving Software Configuration and Compatibility Issues 355
Before You Begin
To perform the exercises in this chapter, you need:
n
A domain controller running Windows Server 2008 R2
n
A client running Windows 7 Enterprise that is a member of the domain
CHAPTER 9
339
Lesson 1: Understanding and Resolving
Installation Failures
To troubleshoot installation failures, you need to understand the requirements of a ­successful
installation. These requirements include—among other factors—administrator privileges,
compatibility with Windows 7, availability of installation code and data, and the status of
application dependencies. You also need to understand how administrative features such
as Software Restriction Policies (SRP) and AppLocker can block an installation even when
these requirements are met. This lesson provides an overview of issues such as these that are
­related both to successful and unsuccessful installations.
After this lesson, you will be able to:
n
n
n
n
Troubleshoot software installation failures by verifying a number of well-known
installation requirements.
Understand how AppLocker can prevent software installations.
Understand many of the feature improvements of AppLocker over Software
Restriction Policies.
Use AppLocker to block a Windows Installer program from running.
Estimated lesson time: 30 minutes
Verifying Software Installation Requirements
You can install new software on clients running Windows 7 in two general ways. First, you can
push applications to clients by means of a software deployment technology such as Group
Policy, Microsoft System Center Configuration Manager, or a third-party solution. The second
option is to install a program manually.
Although some of the requirements for successful software installation are ­particular
to the way in which the software is deployed, most requirements apply to all software
­installation methods. To begin troubleshooting a failed installation, therefore, you can verify
the general requirements described in the following section.
Verifying Administrator Rights
One of the most basic requirements for a successful software installation is that the user
­account running the installer program needs local administrator privileges, and to have these
local administrator privileges on a particular computer, the account needs to be a ­member of
the Administrators group on that computer.
If you are not able to get past the User Account Control prompt when you ­attempt to install
a program, therefore, you should verify that the account used for installation is granted local
administrator privileges on the computer in question. Typically, having domain ­administrator
privileges is sufficient because by default, domain administrators are members of the local
340
CHAPTER 9
Troubleshooting Software Issues
Administrators group on every computer that is a member of the same domain. However, you
should perform this ­verification even if you are already a domain administrator because the
Domain Admins group might have been removed from the local Administrators group.
To determine whether you are a member of the local Administrators group on a ­particular
computer, you can use the Local Users And Groups console. To open this console in
­Windows 7, you can click Start, type edit local users and groups, and then press Enter.
(Note that you can perform this step even if you are not already a local administrator.)
Then, in the ­console tree of the Local Users And Groups console, select Groups, and then
double-click the ­Administrators group in the details pane. This procedure opens the
Administrators Properties dialog box, which is shown in Figure 9-1. This dialog box lists all the
local administrators for that machine.
Figure 9-1 Viewing the local administrators
If you are a local administrator, you can then use the Add button in the ­Administrators
Properties dialog box to add other local administrators if desired. Note, however, that in
an enterprise network, it is preferable to control local group membership by using the
­Restricted Groups feature in Group Policy.
Running an installation program as AN Administrator
If you can verify that you are a local administrator but you still see a message indicating
that administrator rights are required to perform the installation, you should choose the
­option to run the installer program as an administrator. To do this, right-click the installation
icon for the program, and then click Run As Administrator, as shown in Figure 9-2. If a User
­Account Control consent or credential prompt appears, provide confirmation or administrator
­credentials as needed.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
341
Figure 9-2 Running an installation with administrator privileges
Verifying Windows 7 Compatibility
If an application is known to be incompatible with Windows 7, you might receive a message
informing you of this fact when you attempt to install the program. If no updated version
of the software is available, you can try altering the compatibility settings on the installer
program or hosting the application in a virtual environment. Handling software c­ ompatibility
issues such as these is discussed in detail in Lesson 2 of this chapter, “Resolving Software
­Configuration and Compatibility Issues.”
Verifying Trusted Publishers
When you install a new program, Windows 7 checks for a certificate and a digital ­signature
to authenticate the publisher of the program. To verify this digital signature properly, the
local computer must trust the root certification authority (CA) for the publisher ­certificate.
Stated another way, the local computer must have installed in its Trusted Root ­Certification
­Authorities certificate store the root certificate in the certificate chain of the publisher
­certificate. An ­administrator can install this root certificate manually on a local computer or
the ­certificate can be deployed to the Trusted Root Certification Authority certificate store on
many clients through Group Policy.
342
CHAPTER 9
Troubleshooting Software Issues
If the certificate in the installer program is from a trusted publisher and the digital
s­ ignature is verified, the installation proceeds normally. However, if no digital signature
is present, or if the local computer is not configured to trust the publisher, you will see
a ­warning message similar to the one shown in Figure 9-3.
Figure 9-3 Avoid installing programs from untrusted publishers.
In general, you should avoid installing programs from unsigned publishers in an ­enterprise
environment. Such programs might fail during installation, and even if they do install
­successfully, they could present stability problems or introduce malware into your ­network.
Verifying Software Logo Testing on a Client Running Windows 7
Occasionally, when you attempt to install an application, you will receive a warning that the
application has not passed Windows 7 logo testing. In this case, you should avoid installing
the software.
For an application to pass Windows 7 logo testing, it must meet a number of
r­ equirements, including compliance with specific anti-spyware guidelines, isolation from
­protected resources in Windows, a reversible installation, and a digital signature on all files.
Verifying the Installation Media Location
Before you attempt to install an application, ensure that all the files needed for installation
are ­available in the required locations. For example, if you have copied an installer program
from a ­network source to a local computer, be sure that you also copy all the associated
­secondary files that are called by the installer program when it runs. (These secondary files
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
343
can include .cab files or .ini files.) If you are installing an application from over the network,
verify that any s­ econdary files are also accessible from the local computer and that you have
Read and E
­ xecute permissions on these files.
Verifying Installation Settings
When you attempt to install an application, ensure that the settings that you have chosen for
the installation are configured properly; otherwise, the installation might fail. For example,
if you choose to install a program on a read-only disk, the installation fails.
Verifying External Connections
Certain applications require connectivity to external sources of data. For example, the
­application might require a connection to a database, mainframe, Web site, license server,
or other application server. In this case, verify that the installation program can reach these
external connections.
Verifying Licensing and Other Application Constraints
An application might include constraints that will prevent it from installing successfully.
For example, a license or product key might be required to install the application, or the
­application might need to be installed with a specific user account. Verify also that the
­application architecture is compatible with the local processor. For example, you cannot
install a 64-bit application on a computer with a 32-bit CPU.
Verifying Application Dependencies
Some applications can be installed only after you first install other updates, features, service
packs, or other applications. Be sure to prepare the client running Windows 7 for application
installation by first installing all the necessary software dependencies.
More Info Deploying applications
The following Web sites are good resources for automating the installation of applications,
as well as other deployment topics:
n
AppDeploy.com at http://www.appdeploy.com
This Web site provides information about deploying applications that are packaged
­using a variety of technologies.
n
SourceForge at http://unattended.sourceforge.net
This Web site describes how to automate the installation of many older installers.
Understanding Installation Restrictions with AppLocker
Occasionally, when you are attempting to install an application, you might receive an error
such as the one shown in Figures 9-4 or 9-5.
344
CHAPTER 9
Troubleshooting Software Issues
Figure 9-4 An installation prevented by AppLocker
Figure 9-5 An installation prevented by SRP
If you see such a message, the AppLocker or SRP feature has been used to prevent the
application from being installed. Both technologies are available in Windows 7 and Windows
Server 2008 R2. AppLocker is essentially a new and improved version of SRP, but SRP is still
included in these newer operating systems for compatibility with networks running older
­versions of Windows.
As with SRP, you configure AppLocker through Group Policy. To locate AppLocker, open
a Group Policy Object (GPO) and navigate to Computer Configuration\Policies\Windows
­Settings\Security Settings\Application Control Policies\AppLocker, as shown in Figure 9-6.
(In Local Security Policy, the path is simply Security Settings\Application Control Policies.)
Figure 9-6 AppLocker is configured in a GPO.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
345
You can see that the container for AppLocker (Application Control Policies) is found
­immediately below SRP.
The next section introduces AppLocker and describes the differences between it and SRP.
Overview of AppLocker
AppLocker is a new feature in Windows 7 and Windows Server 2008 R2. It allows
­administrators to restrict the programs that users can run or install in your organization.
AppLocker resembles SRP in a number of ways. First, you configure both AppLocker and
SRP in a GPO. Also like SRP, AppLocker allows you to create rules specifying an application
to which you want to allow or deny access. Finally, as in SRP, in AppLocker you can define
a ­program by specifying—among other methods—a hash of or a path to its file.
AppLocker, however, provides the following important improvements over SRP:
n
Publisher rule condition
In AppLocker, you can specify a program by extracting information from its ­digital
signature, as shown in Figure 9-7. You can then use part of or all of this publisher
­information to define the programs you want to allow or deny. This publisher condition
essentially replaces Certificate Rules in SRP.
Figure 9-7 With AppLocker, you can specify an application by digital signature.
346
CHAPTER 9
Troubleshooting Software Issues
Using publisher information from a digital signature is by far the best way to specify
an application in AppLocker. First, you can use this publisher information to c­ reate
rules at various levels of specificity: You can make the rule apply to the publisher
in general, to any version of the particular application, or to specific versions of the
application (including all previous or future versions). Second, the publisher condition
solves a key problem with SRP: In SRP, there is no comparable way to restrict access to
an application through multiple updates. If you specify a path to an application that
you want to restrict, users can simply move the program to a new path to avoid the
­restriction. If you specify a hash for the application, you have to create a new rule every
time the application is updated.
n
AppLocker blocks all programs that are not specifically allowed
In SRP, rules by default are used to block access to chosen applications. However, ­within
any company network, the number of applications that you want to block typically
far exceeds the number that you want to allow. AppLocker accounts for this ­disparity
by locking all applications that are not allowed. More specifically, ­AppLocker rules are
­enabled for one of four file type (executables, Windows Installer programs, scripts,
or DLL files) when you first create a rule for that file type. Then, when ­AppLocker
is enabled, all applications of that file type are locked if they are not allowed by
a rule. To prevent system lockouts, AppLocker provides the Create Default Rules and
­Automatically Create Rules options. These options create allow-type rules for most
­applications. You can then create additional rules to change this default ­configuration.
n
Assign Rules to Specific Users and Groups
In AppLocker, you can create rules that apply to everyone or only to specific users
and groups. In SRP, you can create only rules that apply to everyone.
n
Exceptions
AppLocker enables you to create a rule with an exception. For example, you can create
a rule that allows any application to run except a specific .exe file. This feature is not
available in SRP.
n
Audit-only mode
Unlike SRP, AppLocker includes an audit-only mode. Through auditing, you can test
your configuration without enforcing AppLocker rules. When you configure AppLocker
to audit AppLocker rules for a chosen file type (such Windows Installer programs),
events are written to the event log when AppLocker would normally block access to
that application.
Audit mode is configured in the properties of the AppLocker node in a GPO, as shown
in Figure 9-8. Audit events as they appear in Event Viewer are shown in Figure 9-9.
n
Import and export rules
In AppLocker, you can export and import rules to and from other computers, which
allows administrators to copy and edit rules easily.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
347
Figure 9-8 Configuring AppLocker rules for audit only
Figure 9-9 Audit-only events for AppLocker
348
CHAPTER 9
Troubleshooting Software Issues
Real World
J.C. Mackin
A
ppLocker is a great feature in many ways, but I don’t believe it sufficiently
warns administrators about the dangers of configuring it incorrectly. If you
create a new rule without also creating the default rules, for example, you can easily
lock yourself and everyone else out of your computer.
I actually experienced this problem firsthand when I originally saw AppLocker in
a Windows 7 beta. I simply made a rule in Local Security Policy denying access to
Notepad.exe, and I ignored the messages prompting me to create the default rules.
Immediately afterwards, I was dismayed to see that Windows could not start. What
I didn’t know at the time was that AppLocker is enabled when you create the first
rule. After you create that first rule, all programs of the same type—executables,
in this case—are denied if you have not allowed them.
Luckily for me, this was only a virtual environment, and I had made a data ­snapshot
of the computer before making any changes. It was easy for me to return the
­computer to the previous state. But I thought—what if this were a real ­environment?
It’s not unusual for administrators to explore new features on their own machines.
Few people would suspect that the punishment for incorrectly configuring such
a feature would be locking themselves out of their computer indefinitely. Worse yet,
what if someone actually applied such a policy to the entire domain, and the domain
controllers themselves were rendered unusable? It could be a disastrous situation.
What you should remember is always to create the default rules first in AppLocker
and then create additional rules to modify the behavior of those default rules. When
creating new rules, always test your results first in audit-only mode or use a virtual
machine environment so that you can easily revert to a previous state if necessary.
Quick Check
n
How do you find messages related to AppLocker in Event Viewer?
Quick Check Answer
n
In the Event Viewer console tree, navigate to Event Viewer (Local)\Applications
and Services Logs\Microsoft\Windows\AppLocker.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
349
AppLocker Availability and compatibility
AppLocker rules are enforced on computers running only Windows Server 2008 R2,
­Windows 7 Ultimate, and Windows 7 Enterprise. AppLocker rules are not enforced on
­computers running other versions of Windows, such as Windows Server 2008, Windows 7
Professional, or Windows Vista.
In a GPO containing only SRP rules, the rules are enforced on all computers running
­Windows, including those running Windows Server 2008 R2, Windows 7 Ultimate, and
­Windows 7 Professional. However, if a GPO contains both SRP rules and AppLocker rules,
these same three operating systems read only the AppLocker rules. The SRP rules are applied
to computers running other Windows operating systems.
AppLocker Relies on the Application Identity Service
AppLocker rules are enforced on eligible clients only when those clients are running the
­Application Identity Service. By default, this service is not configured to start automatically on
computers running Windows 7. If you want to enforce AppLocker rules, therefore, you should
use Group Policy to set the Startup Type parameter to Automatic for the Application Identity
Service.
Pr actice
Preventing Software Installation with AppLocker
In this practice, you download an .msi file from the Microsoft Web site and then prevent
installation of that .msi file through AppLocker.
E xercise 1 Obtaining an .msi File
In this exercise, you download the file SharedView.msi from the Microsoft Download Center.
You then begin a new installation to test its functionality.
1. Log on to the domain from the client running Windows 7 (Computer1) as a domain
administrator.
2. In Windows Internet Explorer, visit the Microsoft Download Center at http://download
.microsoft.com. Search for the file “SharedView.msi,” and save it to your Downloads
folder on Computer1. (If you do not have Internet access from Computer1, you can
download the file from another computer and copy it to Computer1.)
Note You can use any .msi file
Although we will use the file SharedView.msi in this exercise, you can replace this file
with any other that you can locate and copy to the Downloads folder on Computer1.
3. Share the Downloads folder by granting Read access to Everyone. To perform this step,
right-click the Downloads folder, choose Share With on the shortcut menu, and then
click Specific People. In the File Sharing window, type Everyone, click Share, and then
click Done.
350
CHAPTER 9
Troubleshooting Software Issues
4. Open the Downloads folder and double-click SharedView.msi to begin the installation.
5. If an Open File-Security Warning message box appears and asks if you want to run the
file, click Run.
6. The first page of the Microsoft SharedView Setup wizard appears. The fact that the
wizard has started indicates that the .msi file is not blocked.
7. Click Cancel and then Yes to close the Microsoft SharedView Setup wizard.
E xercise 2 Configuring AppLocker to Block an .msi
In this exercise, you create a GPO, and then, in the new GPO, you create the default rules for
AppLocker in the Windows Installer rule collection. Finally, you create a new Windows Installer
rule that denies SharedView.msi.
1. Switch to the domain controller (DC1), and log on as a domain administrator.
2. Open Group Policy Management, which is available through the Start menu in the
Administrative Tools folder.
3. In the Group Policy Management console tree, locate and expand the Domains
­container, and then select the domain (Nwtraders.msft) node.
4. Right-click the Nwtraders.msft node, and then click Create A GPO In This Domain,
And Link It Here in the shortcut menu.
5. In the New GPO dialog box, type AppLocker Block SharedView.msi, and then
click OK.
6. In the Group Policy Management console, in the details pane, right-click the ­AppLocker
Block SharedView.msi GPO, and then click Edit. The Group Policy ­Management Editor
opens.
7. In the Group Policy Management Editor console tree, navigate to Computer
­ onfiguration\Policies\Windows Settings\Security Settings\Application Control
C
­Policies\AppLocker\Windows Installer Rules.
8. Select and then right-click the Windows Installer Rules node, and then click Create
Default Rules from the shortcut menu.
In the details pane, three new rules appear. These rules allow everyone to run all
­digitally signed Windows Installer files, everyone to run all Windows Installer files
(signed or not) in the %Systemdrive%\Windows\Installer directory, and administrators
to run all Windows Installer files without exception.
9. Right-click the Windows Installer Rules node, and then click Create New Rule on the
shortcut menu. The Before You Begin page of the Create Windows Installer Rules
­wizard opens.
10. Read all of the text on the page, and then click Next.
11. On the Permissions page, click Deny, and then click Next.
12. On the Conditions page, leave the default selection of Publisher, and then click Next.
13. On the Publisher page, click Browse.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
351
14. In the Open window, in the File Name field, type \\computer1\users\username\
Downloads\SharedView.msi, and then click Open. For the variable username, specify
the name of the account that you used in Exercise 1 to copy SharedView.msi to the
Downloads folder. On the Publisher page, the information from the digital signature in
the .msi file has populated the gray fields next to the slider.
15. Raise the slider two notches so that it is positioned next to Product Name. Next to the
slider, MICROSOFT SHAREDVIEW still appears in the associated field, but the two fields
beneath contain only an asterisk (“*”).
16. Click Next.
17. On the Exceptions page, click Next.
18. On the Name And Description page, type Block SharedView.msi in the Name text
box, and then click Create. The new Deny rule now appears in the details pane.
19. In the Group Policy Management Editor console tree, navigate to Computer
­Configuration\Policies\Windows Settings\Security Settings\System Services.
20. In the details pane, double-click to open the Application Identity service.
The ­Application Identity Properties dialog box opens.
21. In the Application Identity Properties dialog box, check Define This Policy Setting, click
Automatic, and then click OK. Clients need to run this service for AppLocker to work.
22. Close the Group Policy Management Editor console and the Group Policy ­Management
console.
23. Switch to Computer1, and then restart Computer1.
E xercise 3 Testing the Configuration
In this exercise, you test the results of implementing the new GPO that you created in the last
exercise.
1. After Computer1 has finished restarting, log on to the domain from Computer1 as
a domain administrator.
2. Open your Downloads folder, and then double-click SharedView.msi.
3. If an Open File-Security Warning message box appears and asks if you want to run the
file, click Run.
4. A Windows Installer warning message appears, indicating that the system
­administrator has set policies to prevent this installation.
5. Click OK to close the message.
6. Return to DC1. In the Group Policy Management console tree, locate the GPO named
AppLocker Block SharedView.msi.
7. Right-click the AppLocker Block SharedView.msi GPO, and clear Link Enabled on the
shortcut menu. This step effectively disables the policy.
8. Log off both computers.
352
CHAPTER 9
Troubleshooting Software Issues
Lesson Summary
n
The successful installation of software depends on many requirements. These
­requirements include local administrator privileges, Windows 7 compatibility, proper
installation settings, and other factors. To troubleshoot problems with an installation,
you should verify that all of these requirements are met.
n
A Windows Installer program can also be blocked by SRP or AppLocker.
n
AppLocker is an improved version of SRP that is new to Windows 7 and Windows
Server 2008 R2. Improvements in AppLocker include the publisher rule condition, the
ability to assign rules to specific users and groups, and audit-only mode.
Lesson Review
You can use the following questions to test your knowledge of the information in Lesson 1,
“Understanding and Resolving Installation Failures.” The questions are also available on the
companion CD if you prefer to review them in electronic form.
Note Answers
Answers to these questions and explanations of why each answer choice is correct or
­incorrect are located in the “Answers” section at the end of the book.
1. You work for Fabrikam, Inc., a firm whose network consists of a single Active Directory
Domain Services (AD DS) domain.
Fabrikam’s development team periodically tests new software tools for v­ arious
­departments. Recently the team has been testing a tool created by another company,
a new partner named Contoso.com. Whenever authorized users attempt to install the
program, h
­ owever, they receive a warning informing them that the program is from
an unknown ­publisher.
You want to allow authorized users to install applications made by Contoso without
­receiving a warning. What should you do?
A. Ensure that all authorized users are administrators of the computers on which they
are installing the software.
B. Provide authorized users with the credentials of a domain administrator and
i­nstruct them to provide these credentials at the User Account Control prompt
when they attempt to install the software.
C. Use Group Policy to deploy the public certificate provided with the software to the
Trusted Publishers certificate store on all required computers.
D. Use Group Policy to deploy the root certificate for Contoso.com to the Trusted
Root Certification Authorities certificate store on all required computers.
Lesson 1: Understanding and Resolving Installation Failures CHAPTER 9
353
2. You want to use AppLocker to prevent users from running a file named NewApp.msi
for versions 7.0 and earlier. You have already created the default rules. How can you
achieve this objective?
354
A. Create a new Executable rule with the Publisher rule condition.
B. Create a new Executable rule with the File Hash rule condition.
C. Create a new Windows Installer rule with the Publisher rule condition.
D. Create a new Windows Installer rule with the File Hash rule condition.
CHAPTER 9
Troubleshooting Software Issues
Lesson 2: Resolving Software Configuration
and Compatibility Issues
If a program that fails is known to be compatible with Windows 7, the failure is typically the
result of a faulty configuration. In this case, resolving the issue requires you to review the
­program settings to pinpoint the configuration error causing the problems ­experienced.
If on the other hand a program that fails is not fully compatible with Windows 7, you can
often resolve the issue by adjusting compatibility settings or finding an alternate host for the
­application.
After this lesson, you will be able to:
n
n
n
n
Understand strategies and features used to resolve software configuration errors.
Understand the features in Windows 7 that are most likely to create
an ­application compatibility problem.
Configure an application to run with settings compatible with an older version of
Windows.
Understand Group Policy settings that can affect compatibility handling
and ­reporting.
Estimated lesson time: 30 minutes
Resolving Software Configuration Issues
Installed applications that have been working properly sometimes malfunction or fail
­unexpectedly for an unknown reason. Application errors such as these often result from
changes in configuration settings that are specific to the application, but there are some
­general guidelines that can help you in your efforts to resolve these issues.
The following list includes general strategies and features to use in troubleshooting
­software configuration problems.
n
Review application settings If an application suddenly fails, it is often the result
of a configuration change. If you can open the application, proceed systematically
through the available menus and configuration areas of the interface to see if any
­settings have been set improperly. If an application relies on a database or specific
type of file (such as Microsoft Outlook, which relies on .pst files), then make sure that
the ­database or file in question is accessible and not corrupted. If the application relies
on a network resource, check network settings and ensure that the network resource is
both accessible and available.
During this phase of troubleshooting, you should also perform research on the Web
about the issue experienced and contact the application manufacturer if necessary.
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
355
n
Using Event Viewer As part of your troubleshooting process, you should use Event
Viewer to find error messages related to the application you are troubleshooting.
Event Viewer can help you determine when errors related to the application started
­appearing and ultimately help you determine the cause of failure. Pay special attention
to the Application log and any logs that are specific to the application in question. Use
the Filter Current Log function to locate only Critical, Warning, and Error messages.
If you find errors that seem relevant, perform Web searches on these errors to learn
more about them if necessary.
n
Using Event Forwarding Troubleshooting a network-wide application issue might
require you to review logs on multiple computers. To simplify this procedure, you
can use Event Forwarding, a feature in which multiple computers are configured to
­forward a particular event to a collecting computer. Using the Event Forwarding
feature r­ equires that you configure both the forwarding computers, called the source
­computers, and the collecting computer, called the collector.
To configure event forwarding, perform the following steps:
1. On each source computer, type the following at an elevated command prompt:
winrm quickconfig
2. On the collector computer, type the following at an elevated command prompt:
wecutil qc
3. Add the computer account of the collector computer to the local Administrators
group on each of the source computers.
4. In Event Viewer on the collector computer, choose Create Subscription, and then
follow the prompts to specify both the event you want to collect and the source
computers on which you want to collect them.
Note Event Forwarding requires certain services to be running
Event forwarding depends on the Windows Remote Management (WinRM) service and
the Windows Event Collector (Wecsvc) service. Both of these services must be running
on computers participating in the forwarding and collecting process.
n
System Restore An application can fail because of changes to the operating
s­ ystem. If an application stops functioning after you ­install an update or make
a ­system change, consider using the System Restore f­ eature to r­ evert the computer’s
­configuration to a time when the application ­functioned ­properly. Although this
­feature does not remove or change user files such as ­documents or e-mail, it will
remove any applications, updates, or system changes that have occurred since the
system restore point.
Note Opening System Restore
To start the System Restore Wizard, click Start, type system restore, and then
press Enter.
356
CHAPTER 9
Troubleshooting Software Issues
n
Repairing or reinstalling software If software stops functioning but you cannot
revert to an earlier state manually or automatically, you should attempt to repair the
software in question. A repair option, if available, essentially reinstalls the application
while preserving user files and settings for that application. If no such repair option is
available, you can back up the user files and simply reinstall the software. To perform
a fresh installation, you might need to uninstall the software first.
n
Restoring from backup If a critical application fails but you cannot repair it by
­ sing any of the methods listed previously, you should restore the entire system from
u
a ­backup of the last functioning version of the computer. Before doing so, be sure to
perform a backup of the user’s personal files and folders.
Understanding Application Compatibility
Each release of Windows includes new features and capabilities that affect how ­applications
run. Before making adjustments to improve application compatibility, you should gain
some understanding of the particular features in Windows 7 that are most likely to cause
­application compatibility problems. These particular features can generally be classified as
security enhancements and operating system changes.
Security Enhancements Affecting Application Compatibility
Many organizations deploying Windows 7 will be replacing Windows XP on their clients, not
Windows Vista. Compared to Windows XP, the Windows 7 environment offers a number of
important security-related enhancements. The following security features are the ones most
likely to lead to compatibility problems with third-party applications:
n
User Account Control Introduced in Windows Vista, User Account Control (UAC)
separates standard user privileges from administrator privileges in a way that helps
reduce the effect of malware, unauthorized software installation, and unapproved
system changes. If you are logged on as an administrator, UAC by default prompts
you to confirm some tasks that you want to perform that require administrator
privileges. If you are logged on as a standard user and attempt to perform a task that
requires ­administrator privileges, UAC gives you an opportunity to enter administrator
­credentials instead of denying you the right to perform the task outright.
UAC can introduce problems in applications that are not compliant with this
t­ echnology enhancement. For this reason, it is important to test applications with UAC
enabled before you deploy them.
n
Windows Resource Protection (also called File and Registry Virtualization) Windows
Resource Protection is a feature in Windows Vista and Windows 7 that intercepts any
application requests to write to protected system files or registry locations and then
redirects these requests to safe and temporary locations. Although most applications
can handle this redirection without generating an error, some applications require full
access to the protected areas and cannot handle the redirection process.
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
357
n
Internet Explorer Protected Mode Protected Mode is a feature of Windows Internet
Explorer 8 that protects computers from malware by restricting the browser’s a
­ ccess
within the registry and file system. Although Protected Mode helps maintain the
integrity of client computers, it can affect the proper operation of older applications,
ActiveX controls, and other script code.
n
Operating system and Internet Explorer versioning Many applications check the
v­ ersion of the operating system and behave differently or fail to run when an ­unexpected
version number is detected. You can resolve this ­issue by setting ­appropriate
compatibility modes or applying versioning shims ­(application-compatibility fixes).
Operating System Changes Affecting Application Compatibility
Of the many operating system changes introduced by Windows 7, the following features are
most likely to lead to application compatibility difficulties:
n
New system Application Programming Interfaces (APIs) APIs expose layers of the
Windows 7 operating system differently than they did in previous versions of Windows.
Antivirus and firewall software are examples of applications that rely on these new APIs
to monitor and protect Windows 7.
Applications that relied on outdated APIs will need to be upgraded or replaced for
Windows 7.
n
Windows 7 64-bit Neither 16-bit applications nor 32-bit drivers are supported in the
Windows 7 64-bit environment. The automatic registry and system file redirection that
allows some older applications to function in the 32-bit version of Windows 7 are not
available for the 64-bit environment. For these reasons, new 64-bit applications must
comply fully with Windows 7 application standards.
n
Operating system version Many older applications check for a specific version of
Windows and stop responding when they fail to find this specific version. Features built
into Windows 7 such as the Program Compatibility Assistant (discussed in the next
­section) can usually resolve this type of issue automatically.
n
New folder locations User folders, My Documents folders, and folders with ­localization
have changed since Windows XP. Applications with hard-coded paths may fail.
Using Windows 7 Built-in Compatibility Tools
Although you should perform extensive application compatibility testing before you deploy
Windows 7, compatibility problems may unexpectedly appear or persist after deployment.
To help you improve the compatibility of older programs after deployment, Windows 7
provides three tools: the Program Compatibility Assistant (PCA), the Program Compatibility
T­roubleshooter, and the Compatibility tab in a program’s Properties dialog box.
nPCA The PCA is a tool that automatically appears when Windows 7 detects known
compatibility issues in older programs. When it does appear, the PCA can offer to
fix the problem. For example, the PCA can resolve conflicts with UAC, or it can run
the program in a mode that simulates earlier v­ ersions of Windows. If you agree to the
changes PCA proposes, these changes are then p
­ erformed automatically. ­Alternatively,
358
CHAPTER 9
Troubleshooting Software Issues
if the compatibility issue detected is serious, the PCA can warn you or block the
­program from running.
When the PCA recognizes a problem but cannot offer a fix, it will give you an option to
check online for possible solutions, as shown in Figure 9-10.
Figure 9-10 The PCA triggers a message when a program incompatibility is found.
n
Program Compatibility Troubleshooter The Program Compatibility Troubleshooter
is a Control Panel program that you can use to configure the compatibility settings for
an older program if you notice that the program is not running smoothly. For ­example,
you can configure the program to run in a simulated environment of a previous ­version
of Windows, to run with specific display settings, or to run with Administrator privileges.
To start the wizard, in Control Panel, first click Programs, and then, in the Programs and
Features category, click Run Programs Made For Previous Versions Of ­Windows. You can
also start the Program Compatibility Troubleshooter by right-clicking an ­application and
selecting Troubleshoot Compatibility from the shortcut menu, as shown in Figure 9-11.
Figure 9-11 Launching the Program Compatibility Troubleshooter
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
359
A page of the Program Compatibility Troubleshooter is shown in Figure 9-12.
Figure 9-12 The Program Compatibility Troubleshooter
n
Compatibility Tab As an alternative to running the Program Compatibility
­ roubleshooter, you can simply configure compatibility settings on the ­Compatibility
T
tab within the Properties sheet of any given program. The options provided on this
tab are the same as those you can configure through the Program Compatibility
­Troubleshooter. The Compatibility Tab is shown in Figure 9-13.
Figure 9-13 The Compatibility tab of an application
360
CHAPTER 9
Troubleshooting Software Issues
Note that adjusting the compatibility settings of a program does not always fix the
problem. If issues persist, you should attempt alternate hosting or obtain an updated
version of the program.
Alternate Hosting for Application Compatibility
In some cases, your organization will need to support an application whose compatibility
issues with Windows 7 cannot be resolved immediately. For example, if you are running
a ­6 4-bit version of Windows 7, you cannot run 16-bit applications by merely adjusting
the compatibility settings of the program. Until a newer, more compatible version of the
­application appears (or until your organization finds an alternate application), you must find
a temporary fix for the application compatibility problem.
The most common temporary fix for unresolved application compatibility problems such
as this is simply to run the program within the old operating system in a virtual machine,
on a remote server that can be accessed through Remote Desktop, or both.
The following list describes various options of hosting an older application on an older
operating system:
n
Microsoft Virtual PC 2007 You can use Virtual PC to run applications that ­function
properly only with older versions of Windows. For example, if your organization needs
to support a 16-bit application within a 64-bit version of Windows 7, you can use ­Virtual
PC 2007 to run the program within a virtual machine running a previous ­version of
Windows. Although virtual machine software such as Virtual PC is required to run 16-bit
applications in 64-bit versions of Windows 7, the use of Virtual PC need not be reserved
only for this purpose. Virtual PC also lets users keep a previous version of Windows until
upgraded versions of older applications are developed. Whenever you need to support
an older application that does not run smoothly in Windows 7 and that cannot be
upgraded, you should consider running the application inside a virtual machine.
n
Windows XP Mode Windows XP Mode is essentially a downloadable ­enhancement
to Virtual PC that is available in Windows 7 Professional, Enterprise, and Ultimate.
­Windows XP Mode also requires special virtualization technology. Specifically,
­Windows XP Mode requires a CPU with Intel-VT or AMD-V technology, and this
­technology must be enabled in the BIOS.
For eligible computers, Windows XP Mode enables you to access through the Start
menu in Windows 7 any applications installed in a Windows XP guest virtual machine
in Virtual PC. You then interact with these applications exactly as if they were installed
natively in Windows 7. Windows XP Mode also provides an enormous performance
advantage: It gives the Windows XP guest operating system direct access to the system
hardware, so performance is much better than it is in Virtual PC alone.
To install Windows XP Mode is easy: First download and install Virtual PC, and then
download and install Windows XP Mode. You can perform both tasks from the
Virtual PC Web site at http://www.microsoft.com/windows/virtual-pc/download.aspx.
(Both ­Virtual PC and Windows XP Mode are free.)
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
361
More Info Windows XP Mode
For step-by-step instructions on using Windows XP Mode, including installing and using
applications, visit http://www.microsoft.com/windows/virtual-pc/support/default.aspx.
You can also view a five-minute introduction to Windows XP Mode at
http://windows.microsoft.com/en-us/windows7/help/videos/using-windows-xp-mode.
n
Hyper-V on Windows Server 2008 Hyper-V is a high-performance virtualization
environment available in Windows Server 2008. It allows you to create guest virtual
machines with direct access to the hardware. On the virtual machines, you can install
any version of Windows.
If you choose to host an application on a virtual machine inside Hyper-V, clients
r­ unning Windows 7 or other operating systems can then connect remotely to this
­application from over the network.
Hyper-V requires a 64-bit processor with virtualization technology (Intel-VT or AMD-V).
n
Remote Desktop Services for Hosting Applications Hosting older applications on
Remote Desktop Services lets you deliver Windows-based applications or the ­Windows
desktop itself to virtually any computer device on your network. Clients running
Windows 7 can connect to these application-hosting environments through Remote
Desktop.
Quick Check
n
Which CPU technology must be available to use Windows XP Mode on a client
­running Windows 7?
Quick Check Answer
n
Intel-VT or AMD-V
Understanding the Application Compatibility Toolkit (ACT)
The Application Compatibility Toolkit (ACT) is a tool you can use to identify application
­compatibility issues before Windows 7 deployment.
The following are some of the major components that make up the ACT solution:
n
362
Application Compatibility Manager A tool that enables you to collect and ­analyze
your data so that you can identify any issues prior to deploying a new operating
system or deploying a Windows update in your organization. You use this program
heavily during the initial phases of an application migration project. Consider this tool
as the primary user interface for ACT.
CHAPTER 9
Troubleshooting Software Issues
n
Application Compatibility Toolkit Data Collector The Application Compatibility
Toolkit Data Collector is distributed to each computer. It then performs scans by ­using
compatibility evaluators. Data is collected and stored in the central compatibility
­database.
n
Setup Analysis Tool (SAT) The SAT automates the running of application installations
while monitoring the actions taken by each application’s installer.
n
Standard User Analyzer (SUA) The SUA determines the possible issues for
­applications running as a standard user in Windows 7.
ACT is an important tool for testing applications across a wide variety of computers
and operating systems within your organization.
Configuring Application Compatibility Diagnostics
Through Group Policy
Windows Server 2008 includes a set of policy options related to application compatibility
diagnostics. To browse these settings in a GPO, browse to Computer Configuration\Policies\
Administrative Templates\System\Troubleshooting And Diagnostics\Application Compatibility
Diagnostics.
The Application Compatibility Diagnostics container includes the following six policies:
n
Notify Blocked Drivers This policy setting determines whether the PCA will notify
the user if drivers are blocked because of compatibility issues. If you enable this policy
setting, the PCA notifies the user of blocked driver issues and provides the user with
an option to check the Microsoft Web site for solutions. (This behavior is also the
default behavior in Windows 7.) If you disable this policy setting, the PCA does not
notify the user of blocked driver issues. Note that if this policy setting is configured as
disabled, the user is not presented with solutions to blocked drivers.
n
Detect Application Failures Caused By Deprecated Windows COM Objects This
policy setting determines whether the PCA will notify the user when a COM object
creation failure is detected in an application. If you enable this policy setting, the PCA
detects programs creating older COM objects that are removed in this version of
Windows. (This behavior is also the default behavior in Windows 7.) When this failure
is detected, after the program is terminated, PCA notifies the user about this problem
and provides an option to check the Microsoft Web site for solutions. If you disable this
policy setting, the PCA does not detect programs creating older COM objects.
n
Detect Application Failures Caused By Deprecated Windows DLLs This policy setting
determines whether the PCA will notify the user when a DLL load failure is detected
in an application. If you enable this policy setting, the PCA detects programs trying
to load older Microsoft Windows DLLs that are removed in this version of Windows.
(This behavior is also the default behavior in Windows 7.) When this failure is detected,
PCA notifies the user about this problem after the program is terminated and ­provides
an option to check the Microsoft Web site for solutions. If you disable this policy
­setting, the PCA does not detect programs trying to load older Windows DLLs.
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
363
n
Detect Application Install Failures This policy setting configures the PCA to notify
the user when an application installation has failed. If you enable this policy setting,
the PCA detects application installation failures and provides the user with an option
to restart the installer in Windows XP compatibility mode. (This behavior is also the
­default behavior in Windows 7.) If you disable this policy setting, the PCA does not
detect program installation failures.
n
Detect Application Installers That Need To Be Run As Administrator This policy
setting determines whether the PCA will notify the user when application installations
have failed because they need to be run as an administrator. If you enable this policy
setting, the PCA detects such installation failures and provides the user with an option
to restart the installer programs as an administrator. (This behavior is also the default
behavior in Windows 7.) If you disable this policy setting, the PCA does not notify users
when installer program failures have occurred for this reason.
n
Detect Applications Unable To Launch Installers Under UAC This policy setting
c­ onfigures the PCA to notify the user when UAC is preventing an application from
launching an installer (typically an updater program). If you enable this policy setting,
the PCA detects programs that fail to start installers and grants administrator ­privileges
that allow this task to be performed the next time the program is run. (This behavior is
also the default behavior in Windows 7.) If you disable this policy setting, the PCA does
not detect applications that fail to launch installers run under UAC.
Exam Tip
You need to understand these application compatibility diagnostics Group Policy settings
for the 70-685 exam.
Pr actice
Configuring Application Compatibility Diagnostics
In this exercise, you configure application compatibility settings in Group Policy.
E xercise Creating a Policy for Application Compatibility Settings
In this exercise, you create a new GPO named Application Compatibility Diagnostics Policy.
In the GPO, you enable two settings that enable particular behaviors in the PCA.
1. Log on to the domain controller as a domain administrator.
2. Click Start, type Group Policy Management, and then click OK. The Group Policy
Management console opens.
3. In the Group Policy Management console tree, expand Forest: nwtraders.msft and then
Domains.
4. Beneath the Domains container, select and right-click the Nwtraders.msft icon, and
then click the option to Create A GPO In This Domain, And Link It Here. The New GPO
dialog box opens.
364
CHAPTER 9
Troubleshooting Software Issues
5. In the New GPO dialog box, type Application Compatibility Diagnostics Policy,
and then click OK.
6. In the Details pane of the Group Policy Management console, ensure that the Linked
Group Policy Objects tab is selected. Then, in the list of GPOs, right-click Application
Compatibility Diagnostics Policy, and then click Edit. A Group Policy Management
­Editor window opens.
7. In the console tree of the Group Policy Management Editor, navigate to ­Computer
Configuration\Policies\Administrative Templates\System\Troubleshooting
and ­Diagnostics\Application Compatibility Diagnostics.
8. In the details pane of the Group Policy Management Editor, double-click the policy
named Detect Application Failures Caused By Deprecated Windows DLLs. The
­associated policy setting Properties dialog box opens.
9. Read the description of the policy setting. Note that the Diagnostic Policy Service
and the Program Compatibility Assistant Service must be running on Windows 7 for
the Program Compatibility Assistant to execute. These services run by default on
domain-joined computers running Windows 7.
10. Click Enabled.
11. In the Scenario Execution Level drop-down list box, ensure that Detection,
­Troubleshooting, And Resolution is selected.
12. Click OK. In the details pane of the Group Policy Management Editor, the policy setting
should now appear as Enabled.
13. In the details pane of the Group Policy Management Editor, double-click the policy
setting named Detect Application Install Failures. The associated policy setting
­Properties dialog box opens.
14. Read the description of the policy setting, and then click Enabled.
15. Click OK. In the details pane of the Group Policy Management Editor, the policy setting
should now appear as Enabled.
16. Close all open windows.
Lesson Summary
n
If an application malfunctions after it has been working correctly, the problem is
­usually a result of a configuration error or a system change. To discover or undo the
error, you should use a variety of strategies, such as reviewing application settings,
­reviewing event logs, using System Restore, repairing or reinstalling the application,
and restoring the system from backup.
n
Each new release of Windows introduces features that affect the functionality of
­programs written for earlier operating systems. With Windows 7, the features most
likely to affect application compatibility include UAC, Windows Resource Protection,
and new system APIs.
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
365
n
Windows 7 includes tools that help detect and mitigate compatibility problems for
older applications. The PCA automatically appears when Windows 7 detects known
compatibility issues. The Program Compatibility Troubleshooter is a wizard that
­enables you to run an older program with settings used in a previous version of
­Windows. You can configure these same compatibility settings on the Compatibility
Tab of the program.
n
If you need to support an application that is not compatible with Windows 7, you
can run the program in a compatible operating system within a virtual machine.
­Alternatively, you can use a Remote Desktop connection to a computer running the
application and a compatible operating system.
n
Windows 7 includes several Group Policy settings that allow you to determine how the
PCA will diagnose and troubleshoot application compatibility problems.
Lesson Review
You can use the following questions to test your knowledge of the information in Lesson 2,
“Resolving Software Configuration and Compatibility Issues.” The questions are also available
on the companion CD if you prefer to review them in electronic form.
Note Answers
Answers to these questions and explanations of why each answer choice is correct
or ­incorrect are located in the “Answers” section at the end of the book.
1. You receive a call from the help desk about a user who is experiencing problems with
an application on a computer running Windows 7. The application was f­ unctioning
well until the user installed an optional update to Windows. She has made no other
changes to the system since. Now, however, she is unable to start the a
­ pplication.
­Unfortunately, neither she nor the help desk staff has been able to return the
­application to its original functioning state.
Which of the following steps should you take to solve the problem?
A. Use the System Restore feature to return the computer to the point in time just
before the user installed the optional update to Windows.
B. Restore her user files from the latest backup.
C. Configure Event Forwarding to forward messages in the application log to your
computer.
366
D. Uninstall and reinstall the application.
CHAPTER 9
Troubleshooting Software Issues
2. After upgrading the client computers in your organization from Windows XP to
­ indows Vista, you discover that a certain application installs without error but no
W
longer runs properly in the new operating system. How can you ensure that users will
receive any possible notifications telling them why the application has failed?
A. In Group Policy, enable the Detect Application Failures Caused By Deprecated
Windows DLLs Or COM Objects policy.
B. In Group Policy, enable the Notify Blocked Drivers policy.
C. In Group Policy, enable the Detect Application Install Failures policy.
D. In Group Policy, enable the Detect Application Installers That Need To Be Run As
Administrator policy.
3. Which of the following applications is least likely to run on the 32-bit version of
­Windows 7 without a software update?
A. A 16-bit application written for Microsoft Windows 2000
B. A 32-bit application written for Windows XP that requires administrative privileges
to run properly
C. An application written for Windows 2000 that writes to a protected area of the
registry
D. An application written for Windows XP that writes to protected system files
Lesson 2: Resolving Software Configuration and Compatibility Issues
CHAPTER 9
367
Chapter Review
To further practice and reinforce the skills you learned in this chapter, you can perform the
following tasks:
n
Review the chapter summary.
n
Review the list of key terms introduced in this chapter.
n
Complete the case scenarios. These scenarios set up real-world situations involving the
topics of this chapter and ask you to create a solution.
n
Complete the suggested practices.
n
Take a practice test.
Chapter Summary
n
To troubleshoot installation issues, verify administrator rights, Windows 7 ­compatibility,
installation settings, application constraints and dependencies, resource availability,
and any policy restrictions set in SRP or AppLocker.
n
Applications can fail because of an improper configuration or because of
a ­fundamental compatibility issue with Windows 7. For configuration issues, first
­attempt to identify and fix the problem manually, but if necessary, you can use System
Restore, software repair, or system backups to resolve the issue. For compatibility
issues, you can modify the program's compatibility settings, find a remote or virtual
older host for the application, or simply upgrade your software to a newer version that
is compatible with Windows 7.
Key Terms
Do you know what these key terms mean? You can check your answers by looking up the
terms in the glossary at the end of the book.
n
Event Forwarding A feature in which multiple source computers on a network are
configured to forward particular events to a single collector computer.
n
Windows Resource Protection A feature of Windows Vista and Windows 7 in
which requests by programs to write to protected areas of the operating system are
­intercepted and redirected to safe areas.
n
Windows XP Mode In Windows 7, a downloadable enhancement to Virtual PC in
which you can access and interact with programs transparently in a guest ­Windows XP
virtual machine. Windows XP Mode requires a CPU with Intel-VT or AMD-V ­technology.
368
CHAPTER 9
Troubleshooting Software Issues
Case Scenarios
In the following case scenarios, you apply what you’ve learned about protecting client
systems. You can find answers to these questions in the “Answers” section at the end of this
book.
Case Scenario 1: Restricting Software with AppLocker
You work as an enterprise support technician in a large company whose network consists of
a single AD DS domain. All the clients in the company are running Windows 7, and all the
domain controllers are running Windows Server 2008 R2.
You want to use AppLocker to allow users to run Windows Installer programs from
­Microsoft. You also want to prevent them from running Windows Installer programs from
other companies. You begin by creating a new GPO and linking it to the domain.
With this scenario in mind, answer the following questions:
1. You are creating a Windows Installer rule in the new GPO. What kind of rule condition
should you specify if you want to allow Windows Installer programs from Microsoft to
be run?
2. You successfully create a Windows Installer rule that allows everyone to run .msi files
from Microsoft. You have not created any default rules. If the GPO is enforced without
making further changes, will users be able to run Windows Installer programs created
by other companies? Why or why not?
Case Scenario 2: Configuring Application
Compatibility Settings
You work as an enterprise support technician for Contoso, Inc. The Contoso network includes
20 computers running Windows Server 2008 R2, 150 client computers running Windows XP
Professional, and 100 client computers on which Windows 7 Professional has been installed
recently.
You currently are handling issues related to application compatibility on the clients
­running Windows 7.
With this scenario in mind, answer the following questions:
1. A certain application used infrequently by the Advertising department was written
for Windows XP. Users report that the application is unstable in Windows 7. Assuming
that no updates for the application are yet available, what is the first remedy that you
should investigate?
2. Users report that sometimes applications fail to install, but that they receive no
­ otification about the failure. What can you do to ensure that users receive notification
n
when applications fail to install?
Case Scenarios
CHAPTER 9
369
Suggested Practices
To help you master the exam objectives presented in this chapter, complete the following
tasks.
Identify and Resolve New Software Installation Issues
Perform the following activities to learn to resolve common installation issues:
n
Practice 1 Attempt to install on Windows 7 an older program that was ­written
for Windows XP or Windows 2000. If the installation fails, run the installation as
an ­administrator and see if it succeeds.
n
Practice 2 In a test domain, obtain a certificate from a third-party software p
­ ublisher.
Use Group Policy to deploy that certificate to the Trusted Publishers ­certificate store on
all clients in the domain.
Identify and Resolve Software Configuration Issues
Perform the following activity to learn to troubleshoot many computers on a network:
n
Practice 1 In a test domain, enable Event Forwarding on multiple source computers.
Enable Event Forwarding on the collector computer, and then specify a common error
to collect in order to test the results.
Identify Cause of and Resolve Software Failure Issues
Perform the following activity to learn one way to resolve an application compatibility issue:
n
Practice 1 On a computer whose CPU includes Intel-VT or AMD-V technology, ­enable
that feature in the BIOS. Then, download and install Virtual PC, and then download
and install Windows XP Mode. Use Windows XP Mode to access applications installed
in a virtual machine from the Start menu of Windows 7.
Take a Practice Test
The practice tests on this book’s companion CD offer many options. For example, you can test
yourself on just one exam objective, or you can test yourself on all the 70-685 ­certification
exam content. You can set up the test so that it closely simulates the experience of taking
a certification exam, or you can set it up in study mode so that you can look at the correct
answers and explanations after you answer each question.
More info Practice tests
For details about all the practice test options available, see the section entitled “How to
Use the Practice Tests,” in the Introduction to this book.
370
CHAPTER 9
Troubleshooting Software Issues
Index
Symbols and
Numbers
6to4, 253, 257
802.1X, 87
802.1X authentication, 142
A
Account expiration, 138
Account lockout, 136
Accounts
untrusted, 143–44
Action Center
alerts, 3–4
definition, 2
troubleshooting with, 2–3
ActiveX, 150
ActiveX add-ons, 150–52
ActiveX Installer Service, 152–54
ActiveX Opt-in configuration,
150–51
AD DS browsing, 111
AD DS domain
environments
add-ons and, 149
AD DS domains, 299
collecting computer, 301–02
event subscription, 302–05
forwarding computer, 299–301
HTTPS, 305–06
AD DS environments
Nblookup and, 540
Nbtstat, 542
Windows Boot Performance
Diagnostics, 444
Add-On List, 149
Add-ons, 147
ActiveX add-ons, 150–52
ActiveX Installer Service, 152–54
AD DS domain environments, 149
enabling and disabling, 148
starting without, 149
Admin Approval Mode, 203–04
Administrator privileges, 197
Administrator rights
verification of, 340–41
Administrators
UAC notifications for, 197–98
Adware, 196
Alerts
enabling, 3–4
All Users profile (User Profile), 421
Allow Print Spooler To Accept Client
Connections, 111
Allow rules, 373
Allowed programs
(exceptions), 383–84
Alternate hosting, 311
Always-on connectivity
DirectAccess, 252
Antivirus software
misconceptions about, 194
Windows Defender and, 211
Antivirus tools
installation of, 614
AppData (User Profile), 422
Application compatibility, 308–10
alternate hosting, 311
Application Compatibility
Diagnostics and Group Policy
settings, 312–13
Application Compatibility
Toolkit (ACT), 311–12
operating system changes, 310
security enhancements, 310
Stop messages, 614
Windows 7 built-in compatibility
tools, 310–11
Application Compatibility
Diagnostics, 312–13
Application Compatibility
Manager, 362
Application Compatibility Toolkit
(ACT), 311–12
Application Compatibility Toolkit
Data Collector, 363
Application connectivity problems,
64–66, 576–80
Application constraints
verification of, 344
Application dependencies
verification of, 344
Application Identity Service, 350
Application install failures, 364
Application installers, 364
Application layer protocols, 264
Application Program Interfaces
(APIs), 358
AppLocker, 344–352
Arp (Arp.exe), 533, 536–37
Arp cache, 537
ATA disk diagnostic tools, 616
Audit Account Logon Events, 139
Audit Logon Events, 139
Auditing
authentication problems, 138–41
Authentication, 132, 229
auditing, 138–41
Credential Manager, 133–34
definition, 132–33
lesson review, 145–46
645
Authorization
lesson summary, 145
logon restriction
identification, 135–38
network issues, 142
practices, 144–45
UAC compatibility problems, 135
untrusted certification
authority, 142–43
untrusted computer
accounts, 143–44
Authorization, 229
Automatic (Delayed Start), 300–01
Automatic logon, 465–66
Automatic Private IP Address
(APIPA), 60–61, 538–39
Automatic Prompting For ActiveZ
Controls, 151
Automatic software
installation, 277–79
Automatic synchronization, 401
B
Backdoor, 196
Background Intelligence Transfer
Service (BITS), 554
Background Registry
Roaming, 424
Backup
restoration from, 357
Baseline, 323
Basic input/output system
(BIOS), 36, 39, 447–48
BCD registry file
manual updates to, 473–74
BCD store, 441–43
BCD Windows Management
Instrumentation (WMI)
provider, 441
BCDEdit output
interpretation of, 460–61
BCDEdit settings
backup and restoration of, 461
BCDEdit.exe, 441, 444, 460–65
Bi-directional access
through DirectAccess, 252
Biometrics, 132–33
646
BitLocker Drive
Encryption, 130, 175
data recovery, 181–83
disabling or removing, 183–84
enabling, 178–80
Group Policy settings, 178
key management on local
computers, 180–81
problems, 184
Trusted Platform Module (TPM)
hardware, 176–77
USB flash drives, 177
BITS Net Utilization, 554
Blackhole routers, 558
Blocked drivers, 363
Blue screen, 597
Bluetooth problems, 528–29
Boot applications
optional, 443
Boot code, 448
Boot configuration data
(BCD), 440–43
configuration of, 503
registry file, 440–43
Boot entry removal, 464, 490
Boot log analysis, 484–85
Boot logging, 479–80
Boot Manager menu
items, 462
Boot menu time-out, 462
Boot process
understanding, 36–37
Boot sector
manual repairs to, 473
Bootable partition, 448
Bootcfg.exe, 441
BootPRO, 441
BootRec.exe, 444, 470–71
Bootsect.exe, 444, 473
Browser, 554
Bugcheck Information, 600
Built-in compatibility
tools, 310–11
Built-in data collector
sets, 322–23
Built-in diagnostics, 507
Built-in troubleshooting
packs, 492–93
C
Cache
nonvolatile, 519–20
CDPs, 258
Certificate problems
Internet Explorer, 158–59
Certificate revocation list
(CRL), 232, 258
Certificate server, 231
Certificates
EFS, 168–70
personal, 172
Certification authority (CA)
untrusted, 142–43
Change Settings, 13
Change Troubleshooting
Settings, 13–14
Checklist, 612–13
hardware, 615–17
software, 613–15
Chkdsk, 444
definition, 29
troubleshooting
with, 29–31
using, 514–19
Client authentication, 158
Client IPv6 settings, 259
Client software, 226–28
Client systems protection
(malware issues), 193–95
case scenario, 218–19
chapter practice test, 220
chapter practices, 219–20
chapter review, 218
chapter summary, 218
detected spyware, 208
key terms, 218
lesson practices, 214–15
lesson review, 216–17
lesson summary, 215–16
resolution of, 212–13
system infection, 211–12
types of, 195–96
UAC, 197
administrator
privileges, 197
best practices, 205
Disk problems
Control Panel
configuration of, 200–02
disabling (through
Local Security
Policy or
Group Policy), 205
Group Policy settings
configuration of, 202–04
notifications for
administrators, 197–98
notifications for standard
users, 199
Windows Defender
best practices, 210–11
Group Policy settings, 209–10
spyware, 205–08
Code Red worm, 270
Collecting computer, 356
configuration, 301–02
definition, 298
Collector-initiated
subscriptions, 301
COM objets, 363
Command Prompt, 444
Compatibility
of software updates, 273–74
Compatibility logging, 156–57
Compatibility tab, 358–61
Complete memory dump
files, 602, 605
Complex traffic types, 375
Computer accounts
untrusted, 143–44
Computer Configuration, 277–78
Configuration Data
Collector, 324
Configuration
Manager 2007, 271, 273
Connection Manager, 226, 228
Connection Manager
Administration Toolkit
(CMAK), 228
Connection Security Rules, 386
Connectivity issues
PathPing and, 552–53
Connectivity process
DirectAccess, 261
VPN client connections, 236–39
Connectivity troubleshooting
DirectAccess, 261–64
VPN client connections, 239
Contacts folder (User Profile), 421
Control Panel
Change Troubleshooting
Settings, 13–14
UAC configuration in, 200–02
Windows Firewall, 382–83
Control Panel troubleshooters, 7–8
Control sets, 451–54
Controller settings, 616
Crashes, 18–19
Credential Manager, 133–34
Critical update, 273–74
Custom data collector sets, 324
D
Data authentication, 226, 266
Data collector sets
diagnosis, 507–08
network issues, 555–56
performance and, 321–25
Data recovery, 181–83
Data recovery agents (DRAs), 172–75
Debug and Dump Status
Information, 600–01
Debugger settings
viewing and updating, 464–65
Default operating system
entry, 461–62
Default profile, 422
Defragmentation, 327
Deny All Add-Ons Unless
Specifically Allowed In
The Add-On List, 149
Detected spyware, 208
Device Driver Roll Back, 485–86
Device Manager, 501, 523
startup problems, 483–84
troubleshooting with, 15–17
Device removal
temporary, 617
Device replacement, 617
Devices and Printers
troubleshooter, 9–11
DHCP server, 231
Diagnosis, 501
built-in diagnostics, 507
data collector sets, 507–08
diagnostic tools, 504–05
disk-related problems, 505–07
hardware configuration, 502–04
hardware problems, 472
physical computer setup, 501–02
Reliability Monitor, 507
system firmware and peripheral
firmware, 504
Windows Device Manager, 501
Windows Memory Diagnostics,
508–13
Diagnostic Policy Service, 496
Diagnostic tools, 504–05, 616
Diagnostics
boot performance, 444–45
built-in, 507
disk failure, 495–96
memory, 495, 508–13
DirectAccess, 221–22, 251
benefits of, 252
client IPv6 settings, 259
connection process, 261
infrastructure features, 255–59
IPv6 Internet features
configuration, 260
lesson review, 265
lesson summary, 264–65
overview, 251–52
practice, 264
transition technologies, 252–55
troubleshooting, 261–64
DirectAccess clients, 256–57
DirectAccess server, 256, 262
Disabled account, 138
Disaster recover features, 613
Disk Cleanup, 519
Disk Defragmenter
definition, 31
troubleshooting with, 31–32
Disk failure diagnostics, 495–96
Disk failures, 513–14
Disk problems, 513
ChkDsk, 514–19
diagnosis, 505–07
647
Disk Self Tests (DSTs)
Disk Cleanup, 519
disk failures, 513–14
nonvolatile cache
disabling, 519–20
performance, 326–28
unpredictable
symptoms, 500–01
Disk Self Tests (DSTs), 495–96
Disk space management, 407–09
Disk space requirements
(software), 611–13
Diskpart.exe, 444
DiskView, 529–30
DLLs, 363
DNS cache
cleaning, 73
disabling, 73
management, 72
viewing, 72
DNS lookups, 549–50
DNS records, 549
DNS server, 230
connectivity verification, 581–82
DirectAccess clients and, 263–64
NetBIOS names and, 542
Nslookup and, 547–50
Do Not Allow Users To Enable Or
Disable Add-Ons, 149
Domain controllers, 230, 257
Domain firewall profile, 263
Domain joining and logging
problems, 586–89
Domain Networks firewall
profile, 377
Download Signed ActiveX
Controls, 151
Download Unsigned ActiveX
Controls, 152
Downloads folder (User Profile), 421
Driver compatibility
Stop messages and, 614
Driver failure, 481–85
Driver information, 483
Driver Information, 600
Driver issues/problems, 491, 520
Device Manager and resource usage, 523
disk failure diagnostics, 495–96
648
driver reliability
improvements, 497
Driver Verifier, 520–22
error reporting
improvements, 497
File Signature Verification, 522–23
printers, 113–16
Resource Monitor, 494–95
self-healing NTFS, 496
System Restore, 524
unpredictable
symptoms, 500–01
updated drivers, 520
USB, 525
Windows Memory
Diagnostics, 495
Windows Troubleshooting
Platform, 491–93
Driver reliability improvements, 497
Driver updates, 615
Driver Verifier, 520–22
Drivers
blocked, 363
updated, 520
Dual in-line package (DIP)
switches, 502
Dynamic Host Configuration
Protocol (DHCP), 538–39
E
EASYBCD, 441
Elevation, 197, 203–04
Encrypting File System (EFS), 167
additional users, 170–72
certificate creation
and backup, 168–70
data recovery agents
(DRAs), 172–75
personal certificate imports, 172
steps, 168
Encryption, 167
BitLocker, 175
data recovery, 181–83
disabling or removing, 183–84
enabling, 178–80
Group Policy settings, 178
key management on local
computers, 180–81
problems, 184
Trusted Platform Module (TPM)
hardware, 176–77
USB flash drives, 177
Encrypting File System
(EFS), 167
additional users, 170–72
certificate creation
and backup, 168–70
data recovery agents
(DRAs), 172–75
personal certificate
imports, 172
steps, 168
lesson practices, 184–86
lesson review, 187
lesson summary, 186–87
Enterprise management tools, 111
Environment variables, 458
Error reporting, 615
Error reporting improvements, 497
Error scans
troubleshooters for, 12–13
Event Forwarding, 298, 356, 368
AD DS domains, 299
collecting computer, 301–02
event subscription, 302–05
forwarding computer, 299–301
HTTPS, 305–06
definition, 298
lesson review, 313–14
lesson summary, 313
practices, 310–13
process of, 298–99
troubleshooting, 307–09
workgroup environments, 306–07
Event Log, 19, 390
Event Log Readers, 301
Event monitoring
for printers, 108–10
Event subscription, 302–05
collecting computer
configuration and, 301–02
creation of, 302–05
definition of, 299
Event Trace Data Collector, 324
Hardware issues
Event Viewer, 356
logs, 614
network issues, 537–38
startup problems, 482
troubleshooting with, 19–20
wireless connection
problems, 95–96
Exceptions, 218, 373, 378–81
Execute Print Drivers In Isolated
Processes, 110
Executive initialization Stop
errors, 601
Extensible Firmware Interface
(EFI), 440, 448–49
External connections
verification of, 344
F
Faulty drivers, 16–17
File and Printer Sharing, 119,
589–91
File replacement, 474–75
File restoration, 413–17
File Signature Verification, 522–23
Files and settings management, 395
key terms, 438
offline files, 395
automatic synchronization, 401
disk space management, 407–09
Group Policy settings, 410–17
manual synchronization, 401–02
practice, 417–18
reasons for, 398
removing, 400
Sync Center for synchronization
management, 404–07
understanding, 396–98
viewing, 403
working offline, 402–03
working with, 398–99
roaming users, 419
Folder Redirection, 427–28
configuration of, 430–31
improvements in, 428–29
Folder Redirection Settings tab
options, 432–33
practice, 433–37
target folder location, 431–32
user profiles, 419–20
roaming profile
incompatibility, 425–27
Windows Vista and, 421–25
Firewall
configuration, 119–20
DirectAccess clients and, 263
Firmware
nondefault settings, 615
system and peripheral, 504
FIXBOOT, 471
FIXMBR, 471
Flash drives, 177, 327
Folder encryption, 168
Folder locations, 358
Folder Redirection, 427–28
configuration of, 430–31
definition, 427
improvements in, 428–29
Folder Redirection Settings
tab options, 432–33
Folder restoration, 413–17
Forefront, 211
Format.exe, 444
Forwarding computer
configuration, 299–301
definition, 298
Fragmentation, 326–27
Free space, 326–27
Fully qualified domain name
(FQDN), 263–64
G
Global debugger settings
viewing and updating, 464–65
Global IPv6, 262–63
Graphical Chkdsk interface, 516–17
Graphical tools
Windows Update configuration
using, 277
Group Policy Management Console
(GPMC), 430
Group Policy restrictions
Internet Explorer, 160
Group policy settings, 80–82
printers, 110–11
Group Policy settings
Application Compatibility
Diagnostics, 312–13
BitLocker, 178
disk failure diagnostics, 496
Folder Redirection, 428
offline files, 410–17
startup application disabling
through, 488–89
UAC configuration, 202–04
UAC disabling, 205
Windows Boot Performance
Diagnostics, 444
Windows Defender, 209–10
Windows Firewall, 387–89
Windows Update configuration
using, 277–79
H
Handle, 530–31
Hard disks
troubleshooting, 41–42
Hardware and Devices
troubleshooters, 12
Hardware and Sound
troubleshooters, 8
Hardware checklist, 615–17
Hardware clock speeds
nondefault, 616
Hardware configuration, 502–05
Hardware diagnostic tools, 616
Hardware failures
Reliability Monitor
diagnoses, 18–19
software failures versus, 35
Hardware installation
and connections, 616
Hardware installation problems, 498
Hardware issues, 491
diagnosis, 472, 501
built-in diagnostics, 507
data collector sets, 507–08
diagnostic tools, 504–05
disk-related problems, 505–07
649
Hardware malfunction messages
hardware configuration, 502–04
physical computer
setup, 501–02
Reliability Monitor, 507
system firmware and peripheral
firmware, 504
Windows Device Manager, 501
Windows Memory
Diagnostics, 508–13
Startup Repair, 472
Stop errors caused by, 601
summary, 532
troubleshooting process, 497
existing problems, 499–500
installation problems, 498
unpredictable
symptoms, 500–01
Windows starting problems, 497
troubleshooting tools, 529
DiskView, 529–30
Handle, 530–31
Process Monitor, 531–32
USB, 525
Windows 7 troubleshooting
improvements, 491
disk failure diagnostics, 495–96
driver reliability
improvements, 497
error reporting
improvements, 497
Resource Monitor, 494–95
self-healing NTFS, 496
Windows Memory
Diagnostics, 495
Windows Troubleshooting
Platform, 491–93
Hardware malfunction
messages, 612
Hardware troubleshooters, 12–13
Hardware-related updates, 616
Hibernation, 329
Home or Work (Private) Networks
firewall profile, 377
Hosting
alternate, 311
Hosts file, 582–83
Hotspots, 49
HTTP, 298
650
HTTPS, 298, 305–06
Hubs
USB, 527–28
Hyper-V, 362
I
ICMP, 554
ICMPv6, 554
Inbound exceptions, 378–81
Inbound traffic, 373
Infection (malware), 211–12
Information sources, 615, 617
Infrastructure features
of DirectAccess, 255–59
Initial startup phase, 446–49
Initialize And Script ActiveX
Controls Not Marked As Safe
For Scripting, 152
Installation Stop errors, 601
Intermittent connectivity
issues, 583–85
Internet Assigned Numbers
Authority (IANA), 222
Internet Explorer, 147
ActiveX Installer Service
exercise, 161
add-ons, 147
ActiveX add-ons, 150–52
ActiveX Installer Service, 152–54
AD DS domain
environments, 149
enabling and disabling, 148
starting without, 149
certificate problems, 158–59
certification issues
exercises, 161–64
group policy restrictions, 160
lesson review, 165–66
lesson summary, 164–65
Protected Mode, 155–57, 358
Trusted Sites list, 154–55
versioning, 358
Windows 7 (64-bit versions), 154
Internet Key Exchange version 2
(IKEv2), 232–33
Internet Printing Protocol (IPP), 119
Internet Security and Acceleration
(ISA) devices, 505
Intranet servers
DirectAccess clients and, 263–64
Intra-site Automatic Tunnel
Addressing Protocol
(ISATAP), 253
IpConfig, 54–55
IPConfig, 533, 536, 538–39
IP-HTTPS, 255, 257
IPSec, 258
Ipsec AuthIPv4, 554
IPv4, 222, 554
IPv4 NAT, 255
IPv6, 222, 257, 536
DirectAccess and, 262–63
Internet features
configuration, 260
Performance Monitor and, 554
settings, 259
IPv6 NAT, 255
IPv6 transition technologies, 252–55
IPv6-capable network, 257–58
ISATAP, 253
J
Jumpers, 502
K
Kernel debuggers, 608–10, 612, 615
Kernel loading phase, 451–55
Kernel memory dump files, 602,
604–05
Key management
on local computers, 180–81
Key pair, 231
Keyloggers, 196
L
Last Known Good Configuration,
478–79, 613, 615
Latency, 56, 58
Nblookup
Layer 2 Tunneling Protocol
(L2TP), 234–35
Libraries, 424–25
Licensing
verification of, 344
Links folder (User Profile), 421
Listener, 300
Local computers
key management on, 180–81
Local folder (User Profile), 422
Local printer exercise, 122
Local Security Policy
disabling UAC through, 205
LocalLow folder (User Profile), 422
Logo testing, 343
Logon
automatic, 465–66
domain accounts, 586–89
hour restrictions, 136
startup troubleshooting
after, 486–90
Logon phase, 456
Logon restriction
identification, 135–38
Logon scripts, 488–89
M
Machine accounts, 143
Malware issues, 193–95
case scenario, 218–19
chapter practice test, 220
chapter practices, 219–20
chapter review, 218
chapter summary, 218
detected spyware, 208
key terms, 218
lesson practices, 214–15
lesson review, 216–17
lesson summary, 215–16
misconceptions, 193–94
resolution of, 212–13
software updates and, 270
system infection, 211–12
types of, 195–96
UAC, 197
administrator privileges, 197
best practices, 205
Control Panel configuration
of, 200–02
disabling (through Local Security
Policy or Group Policy), 205
Group Policy settings
configuration of, 202–04
notifications for
administrators, 197–98
notifications for standard
users, 199
Windows Defender
best practices, 210–11
Group Policy settings, 209–10
spyware, 205–08
Mandatory Integrity Control
(MIC), 155
Manual file replacement, 474–75
Manual initiation
of Stop errors, 605–06
Manual repairs
boot sector, 473
Manual software
installation, 276–77
Manual synchronization, 401–02
Manual troubleshooting
for network connections, 62–64
Manual updates
BCD registry file, 473–74
Manual wireless connections, 78–79
Media access control (MAC), 536–37
Memory compatibility, 616
Memory diagnostics, 495, 508–13
Memory dump files, 602–03
complete, 602, 605
kernel, 602, 604–05
small, 602–04
stop error analysis and, 606–10
stop error initiation and, 605–06
Memory problems
automatic detection of, 510
Microsoft Baseline Security Analyzer
(MBSA), 280
Microsoft Debugging Tools, 598
Microsoft Deployment Toolkit, 275
Microsoft Help and Support, 598
Microsoft Kerberos SSP, 298
Microsoft Knowledge Base, 598
Microsoft Malware Protection
Center, 209
Microsoft Notepad, 71
Microsoft Online Crash Analysis
(MOCA), 495
Microsoft Outlook Web Access
(OWA), 252
Microsoft Product Support
Services, 598
Microsoft System Center
Configuration Manager 2007,
271, 273
Microsoft Virtual PC 2007, 361
Microsoft Virtual Server VRMC
Control, 147
Monitoring
printer events, 108–10
Monitoring node, 384
Motherboard
troubleshooting, 38–40
Mouse devices
troubleshooting, 15
Mouse Properties, 11
Mouse Settings, 11
Multifactor authentication, 132
My Documents, 421
My Music, 421
My Pictures, 421
My Videos, 421
N
Name resolution
definition of, 580
Name resolution issues, 70, 580–83
DNS cache cleaning, 73
DNS cache disabling, 73
DNS cache management, 72
DNS cache viewing, 72
lesson review, 75–76
lesson summary, 75
practices, 73–74, 102–03
problems, 70–72
Name Resolution Policy Table
(NRPT), 257
Native IPv6, 257
Nblookup, 540
651
NBT Connection
NBT Connection, 554
Nbtstat, 533, 540–42
Net (Net.exe), 533, 542–44
NET CLR Networking, 554
Net share, 543
Net view, 543–44
NetBIOS names, 540–42
Netdom, 144
NetSetup Log file, 587–88
Netsh, 536
Netsh wlan connect command, 83
Netstat, 533, 536, 544–45
Network Adapter troubleshooter, 8
Network Address Translation
(NAT), 255
Network authentication issues, 142
Network connectivity
issues, 51, 572–76
APIPA address, 60–61
lesson review, 68–69
lesson summary, 68
network troubleshooting
tools, 54
Ipconfig, 54–55
Nslookup, 59–60
PathPing, 56–58
Ping, 55–56
PortQry, 58–59
practices, 102
problems, 61–62
application, 64–66
manual troubleshooting, 62–64
practice, 66–67
Windows network
diagnostics, 51–54
Network Diagnostics, 592–93
Network Discovery, 589
Network Interface, 554
Network issues, 533
printers, 116–19
summary, 595
troubleshooting process, 570–71
application connectivity
problems, 576–80
domain joining and logging
problems, 586–89
file and printer
sharing, 589–91
652
name resolution
problems, 580–83
network connectivity
problems, 572–76
Network Discovery, 589
performance problems and
intermittent connectivity
issues, 583–85
Windows Firewall
problems, 594
wireless networks, 592–93
troubleshooting tools, 533–36
Arp (Arp.exe), 536–37
data collector sets, 555–56
Event Viewer, 537–38
IPConfig, 538–39
Nblookup, 540
Nbtstat, 540–42
Net (Net.exe), 542–44
Netstat, 544–45
Network Monitor, 546–47
Nslookup, 547–50
PathPing, 550–53
Performance Monitor, 553–55
Ping, 557–58
PortQry, 558–61
Resource Monitor, 556–57
routing, 561–63
service connectivity testing, 567
Task Manager, 563–66
TCPView, 566
Telnet Client, 566–67
Test TCP, 568–69
Windows Network
Diagnostics, 570
Network location server, 257
Network locations, 375–77
Network Monitor, 533, 546–47
Network Policy Server
(NPS), 226, 232
Network printers, 105–07
case scenarios, 125–26
chapter practice test, 127
chapter practices, 126–27
chapter review, 125
chapter summary, 125
driver problems, 113–16
events monitoring, 108–10
group policy settings, 110–11
key terms, 125
lesson practices, 120–22
lesson review, 123–24
lesson summary, 123
network problems, 116–19
Printer Troubleshooter, 107–08
server problems, 111–13
sharing, 112
Network troubleshooting
tools, 54
Ipconfig, 54–55
Nslookup, 59–60
PathPing, 56–58
Ping, 55–56
PortQry, 58–59
Networking, 49–50
case scenarios, 101
key terms, 100–01
name resolution issues, 70
DNS cache cleaning, 73
DNS cache disabling, 73
DNS cache management, 72
DNS cache viewing, 72
lesson review, 75–76
lesson summary, 75
practices, 73–74, 102–03
problems, 70–72
network connectivity issues, 51
APIPA address, 60–61
lesson review, 68–69
lesson summary, 68
network troubleshooting
tools, 54
Ipconfig, 54–55
Nslookup, 59–60
PathPing, 56–58
Ping, 55–56
PortQry, 58–59
practices, 102
problems, 61–62
application, 64–66
manual troubleshooting, 62–64
practice, 66–67
Windows network diagnostics,
51–54
review, 100
summary, 100
Printer management
wireless connectivity issues, 77
common problems, 92–95
Event Viewer, 95–96
group policy settings, 80–82
lesson review, 98–99
lesson summary, 98
manual connection, 78–79
overview, 77–78
practices, 96–97, 103
priorities changes, 85
profile types
configuration of, 91
reconfiguration, 84–85
scripts, 82–84
security, 86–88
wireless network profile, 79–80
WPA-EAP security, 88–90
New computers
software installation on, 275–76
Non-Microsoft tools
BCD registry modification
with, 441
Nonvolatile cache
disabling, 519–20
Notepad.exe, 444
Nslookup, 59–60, 533, 536,
547–50
NTFS
Chkdsk and, 517–19
self-healing, 496
Ntldr, 440, 443
NvrBoot, 441
O
Offline files, 395
automatic synchronization, 401
definition, 396
disk space management, 407–09
Group Policy settings, 410–17
manual synchronization, 401–02
practice, 417–18
reasons for, 398
removing, 400
Sync Center for synchronization
management, 404–07
understanding, 396–98
viewing, 403
working offline, 402–03
working with, 398–99
Operating system changes
application compatibility
and, 310
Operating system
updates, 615
Operating system versioning, 358
Operating systems
BCDEdit and, 462–64
Outbound traffic, 374
Override Print Driver Execution
Compatibility Setting Report
By Print Driver, 110
P
Partition table, 448
Password expiration, 137–38
PathPing, 56–58, 533, 536,
550–53, 585
PathPing output, 550–51
Performance, 295–97
case scenarios, 336–37
chapter review, 335
chapter summary, 335
event forwarding, 298
AD DS domains, 299
collecting computer, 301–02
event subscription, 302–05
forwarding computer, 299–301
HTTPS, 305–06
lesson review, 313–14
lesson summary, 313
practices, 310–13
process of, 298–99
troubleshooting, 307–09
workgroup environments, 306–07
key terms, 335
network issues, 583–85
PathPing, 552
practice test, 338
practices, 337–38
troubleshooting, 315
data collector sets
and reports, 321–25
disk performance
problems, 326–28
lesson review, 333–34
lesson summary, 333
Performance Monitor, 319–21
power settings, 329–30
practices, 331–33
system configuration, 330
Task Manager, 315–19
Performance Counter
Alert, 324
Performance Counter Data
Collector, 324
Performance Monitor
network issues, 553–55
network performance
problems, 533
troubleshooting, 319–21
USB problems, 526–27
Peripheral firmware, 504
Personal certificate imports, 172
Physical computer setup, 501–02
Pilot group, 274
Ping, 55–56, 536, 557–58
Playing Audio troubleshooter, 7
Point and Print, 115–16
Point-to-Point Tunneling Protocol
(PPTP), 235
PortQry, 58–59, 533, 536,
558–61, 578
Power settings, 329–30
Power supply unit
troubleshooting, 37–38
Power-on self test (POST), 446
Previous versions, 413–17
Print drivers
print servers and, 113–14
printer sharing clients, 114–15
Print queue, 112–13
Print servers, 111
driver updates for, 113–14
requirements for, 111–12
Print Spooler, 111–12
Printer drivers
automatic installation of, 111
Printer events
monitoring, 108–10
Printer management, 112
653
Printer sharing
Printer sharing
client sharing, 117–18
driver additions for, 114–15
practices, 120–22
server sharing, 118–20
steps in, 112
Printer Troubleshooter, 107–08
Printers, 105–07
case scenarios, 125–26
chapter practice test, 127
chapter practices, 126–27
chapter review, 125
chapter summary, 125
driver problems, 113–16
events monitoring, 108–10
group policy settings, 110–11
key terms, 125
lesson practices, 120–22
lesson review, 123–24
lesson summary, 123
network problems, 116–19
Printer Troubleshooter, 107–08
server problems, 111–13
Priorities changes
for wireless networks, 85
Private key infrastructure
(PKI), 231, 258
Process Identifiers (PIDs), 544–45
Process Monitor
hardware troubleshooting, 531–32
Processor time, 317–19
Profiles
domain firewall, 263
Windows Firewall, 377–78
Program Compatibility Assistant
(PCA), 358–59, 363–64
Program Compatibility
Troubleshooter, 358–60
Program stopping, 319
Protected Mode, 155–57
Protected Mode Compatibility
Layer, 156
Public key, 231
Public Networks firewall
profile, 377
Public profile, 422
Publishers
trusted, 342–43
654
Pull delivery mode, 303
Push delivery mode, 304
Q
Quality Assurance (QA), 274
R
RAM
troubleshooting, 40–41
Windows Memory
Diagnostic, 24–29
REBUILDBCD, 471
Recommend User Action, 600
Reconfiguration
of wireless networks, 84–85
Redirector, 554
Reliability Monitor
definition, 17
diagnosis, 507
hardware failure
diagnoses, 18–19
hardware problems, 491
troubleshooting with, 17–18
Remote access
authentication, 229
Remote access
connections, 221–22
case scenarios, 266–67
chapter review, 266
chapter summary, 266
DirectAccess, 251
client IPv6 settings, 259
connection process, 261
infrastructure features, 255–59
IPv6 Internet features
configuration, 260
lesson review, 265
lesson summary, 264–65
overview, 251–52
practice, 264
transition technologies, 252–55
troubleshooting, 261–64
key terms, 266
practice test, 268
practices, 268
VPN client connections, 223
connectivity process, 236–39
connectivity
troubleshooting, 239
lesson review, 249–50
lesson summary, 249
practices, 239–49
tunneling protocols, 232–35
understanding, 223–32
Remote access VPN
infrastructure, 226–32
Remote Desktop, 544–45
Remote Desktop Services, 362
Remote management
protocols, 560
Reports
performance data, 325
Resource Monitor
hardware problems, 491
network issues, 556–57
network performance
problems, 533
performance and connectivity
problems, 584
Windows 7 troubleshooting
improvements, 494–95
Resource usage
Device Manager and, 523
Restart Manager, 283
Roaming profile
incompatibility, 425–27
Roaming user profile, 419
Roaming user profile folder, 422
Roaming users, 419
Folder Redirection, 427–28
configuration of, 430–31
improvements in, 428–29
Folder Redirection Settings tab
options, 432–33
incompatibility, 425–26
practice, 433–37
target folder location, 431–32
user profiles, 419–20
roaming profile
incompatibility, 425–27
Windows Vista and, 421–25
Rootkit, 175, 194, 196, 213
Smart cards
Route, 536
Routine checks, 14
Routing, 561–63
Routing and Remote Access
Services (RRAS), 226, 229–30
Routing loops, 552
Routing tables, 561
Run ActiveX Controls And
Plug-Ins, 152
RunSynchronous commands, 275
S
Safe mode, 481–83, 614
SAN list, 159
Saved Games folder
(User Profile), 421
Scanning
in Windows Defender, 207–08
SCANOS, 471
Script ActiveX Controls Marked
Safe For Scripting, 152
Scripting
software updates, 279
Scripts, 82–84
SCSI configuration
verification of, 503
SCSI disk, 616
Seamless connectivity
of DirectAccess, 252
Searches folder
(User Profile), 421
Secure Desktop, 203–04
Secure Socket Tunneling Protocol
(SSTP), 232–34
Secure Sockets Layer (SSL), 298
Security, 129–31
authentication, 132
auditing, 138–41
Credential Manager, 133–34
definition, 132–33
lesson review, 145–46
lesson summary, 145
logon restriction
identification, 135–38
network issues, 142
practices, 144–45
UAC compatibility
problems, 135
untrusted certification
authority, 142–43
untrusted computer
accounts, 143–44
case scenarios, 189–90
chapter review, 188
chapter summary, 188–89
DirectAccess, 252
encryption, 167
BitLocker, 175
data recovery, 181–83
disabling or removing, 183–84
enabling, 178–80
Group Policy settings, 178
key management on local
computers, 180–81
problems, 184
Trusted Platform Module (TPM)
hardware, 176–77
USB flash drives, 177
Encrypting File System
(EFS), 167
additional users, 170–72
certificate creation
and backup, 168–70
data recovery agents
(DRAs), 172–75
personal certificate
imports, 172
steps, 168
lesson practices, 184–86
lesson review, 187
lesson summary, 186–87
Internet Explorer, 147
ActiveX Installer Service
exercise, 161
add-ons, 147
ActiveX add-ons, 150–52
ActiveX Installer Service, 152–54
AD DS domain
environments, 149
enabling and disabling, 148
starting without, 149
certificate problems, 158–59
certification issues
exercises, 161–64
group policy restrictions, 160
lesson review, 165–66
lesson summary, 164–65
Protected Mode, 155–57
Trusted Sites list, 154–55
key terms, 189
practice test, 192
practices, 190–91
printers and, 111
wireless networking, 86–88
WPA-EAP, 88–90
Security enhancements
application compatibility, 310
DirectAccess, 252
Security support provider
(SSP), 298–99
Self-healing NTFS, 496
Self-Monitoring Analysis and
Reporting Technology
(SMART), 495–96
Server authentication, 158
Server Certificate Policy, 153
Server problems
for printers, 111–13
Servers, 554, 591
Service connectivity
testing, 559–60, 567
Service disabling
during startup, 486
Service failure, 481–85
Service information, 483
Service pack, 273–74
Service pack updates, 614
Service Set Identifier
(SSID), 79–80
Session Manager, 454–55
Settings configuration
for troubleshooters, 13–15
Setup Analysis Tool (SAT), 363
Shift key
startup application disabling
through, 487–88
Shockwave Flash, 147
Signed ActiveX Controls, 153
Single-sign on feature, 133
Small memory dump
files, 602–04
Smart cards, 132
655
Sniffer
Sniffer, 546
Software checklist, 613–15
Software disk space
requirements, 611–12
Software failures, 35
Software installation, 274–75
automatic, 277–79
manual, 276–77
media location, 343–44
new computers, 275–76
scripting updates, 279
settings, 344
troubleshooting, 282–83
update removal, 283–84
verification, 280–81
Software installation failures, 340
AppLocker and installation
restrictions, 299–302
installation requirements
and, 296–99
Software installation
requirements, 296–99
Software installation
restrictions, 299–302
Software logo testing, 343
Software reinstallation, 357
Software repair, 357
Software Restriction Policies
(SRP), 340, 345–47
Software troubleshooting, 339
application compatibility, 308–10
alternate hosting, 311
Application Compatibility Diagnostics and Group Policy
settings, 312–13
Application Compatibility Toolkit
(ACT), 311–12
lesson review, 315–17
lesson summary, 314–15
operating system
changes, 310
practice, 313–14
security enhancements, 310
Windows 7 built-in compatibility
tools, 310–11
case scenarios, 318–19
chapter review, 317
chapter summary, 318
656
configuration issues, 308–10
installation failures, 340
AppLocker and installation restrictions, 299–302
installation requirements
and, 296–99
lesson review, 306–08
lesson summary, 306
practices, 302–06
key terms, 318
practice tests, 320
practices, 320
Software updates, 269–71
application methods, 271–73
case scenarios, 291–92
chapter practice test, 293
chapter practices, 292
chapter summary, 290
compatibility, 273–74
installation, 274–75
automatic, 277–79
manual, 276–77
new computers, 275–76
scripting updates, 279
troubleshooting, 282–83
update removal, 283–84
verification, 280–81
key terms, 290–91
lesson practices, 284–88
lesson review, 289
lesson summary, 288–89
removal of, 283–84
Sound disabling, 466
Source computer-initiated
subscriptions, 301
Source computers, 356
Source port, 560
SpyNet, 210
Spyware
definition, 196
detected, 208
Windows Defender
and, 205–08
SSL certificates, 159
SSTP, 232–34
Stack, 610
Standard User Analyzer
(SUA), 363
Standard users
UAC notifications for, 199
Standby, 329
Starting Windows logo
(troubleshooting after), 476–77
boot logging, 479–80
Device Driver Roll Back, 485–86
Last Known Good
Configuration, 478–79
safe mode, 481
service and driver failure, 481–85
service disabling, 486
Startup Repair, 478
System Restore, 479
Starting Windows logo
(troubleshooting
before), 467–68
BCD registry file manual
update, 473–74
boot sector manual
repairs, 473
BootReC.exe, 470–71
file replacement (manual), 474–75
hardware problem
diagnosis, 472
Startup Repair, 469–70
System Restore, 472
Windows reinstallement, 475–76
Windows XP recovery console
equivalents, 471
Startup and Recovery, 440–41
Startup and Recovery dialog
box, 458–59
Startup applications and processes
permanently disabling, 489–90
temporarily disabling, 487–89
Startup configuration and
troubleshooting, 439
boot configuration data, 440–43
important startup files, 457–58
initial startup phase, 446–49
kernel loading phase, 451–55
logon phase, 456
power-on self test (POST), 446
startup process and, 445–46
startup settings, 458
automatic logon, 465–66
BCDEdit, 460–65
System Restore
sound disabling, 466
Startup and Recovery dialog box,
458–59
startup process speed, 466–67
System Configuration
tool, 459–60
Windows Boot Loader
removal, 465
summary, 490
system recovery, 443–44
troubleshooting process, 467
logon (after), 486–90
Starting Windows logo
(after), 476–77
boot logging, 479–80
Device Driver
Roll Back, 485–86
Last Known Good
Configuration, 478–79
safe mode, 481
service and driver
failure, 481–85
service disabling, 486
Startup Repair, 478
System Restore, 479
Starting Windows logo
(before), 467–68
BCD registry file manual
update, 473–74
boot sector manual
repairs, 473
BootReC.exe, 470–71
file replacement
(manual), 474–75
hardware problem
diagnosis, 472
Startup Repair, 469–70
System Restore, 472
Windows reinstallement, 475–76
Windows XP recovery console
equivalents, 471
Windows 7 changes, 439–40
Windows Boot Loader, 450–51
Windows Boot
Manager, 449–50
Windows Boot Performance
Diagnostics, 444–45
Startup failures, 21
Startup files
important, 457–58
Startup process, 445–46
Startup process speed,
466–67
Startup Repair
definition, 21
launching, 21–24
startup troubleshooting, 21,
469–70, 478
Stop messages, 614
System Recovery and, 443
Startup settings, 458
automatic logon, 465–66
BCDEdit, 460–65
sound disabling, 466
Startup and Recovery dialog
box, 458–59
startup process speed, 466–67
System Configuration tool, 459–60
Windows Boot Loader
removal, 465
Startup sound disabling, 466
Stop error analysis
memory dump files and, 606–10
Stop error initiation
memory dump files and, 605–06
Stop error preparation, 610
kernel debugger and symbol
files, 612
software disk space
requirements, 611–12
Stop message recording
and saving, 611
system restart prevention, 610–11
Stop errors
manual initiation of, 605–06
memory dump files and, 606–10
types of, 601
Stop messages, 597, 599–600
Bugcheck information, 600
checklist, 612–13
hardware, 615–17
software, 613–15
complete memory dump
files, 605
Debug and Dump Status
Information, 600–01
definition, 597
Driver Information, 600
hardware malfunction
messages, 612
identification of, 598
kernel memory dump files, 604–05
memory dump files, 602–03
overview, 597
Recommend User Action, 600
recording and saving, 611
small memory dump files, 603–04
Stop error analysis and memory
dump files, 606–10
Stop error initiation and memory
dump files, 605–06
summary, 617
Technical Information, 600
troubleshooting information, 598
Subject Alternative Names
(SANs), 159
Symbol files, 608–10, 612
Sync Center, 404–07
Synchronization
automatic, 401
Folder Redirection, 428
manual, 401–02
Synchronization management
Sync Center for, 404–07
System Configuration, 330
System Configuration tool, 459–60
System Configuration utility, 330,
441–51, 486, 488
System firmware, 504
System Image Recovery, 444
System infection (malware), 211–12
System Information, 483
System Maintenance
troubleshooter, 14
System Recovery, 443–44, 469–70
System Recovery Options, 21–23, 26
System restart
prevention of, 610–11
safe mode, 614
System Restore, 356
driver problems, 524
Startup Repair and, 472
startup troubleshooting, 472, 479
System Recovery and, 443–44
657
Tab options
T
Tab options
Folder Redirection, 432–33
Target folder location, 431–32
Task Manager, 315–19, 533, 545
network issues, 563–66
performance and connectivity
problems, 584
TCP, 549–50
TCP Port, 559
TCPv4, 554
TCPv6, 554
TCPView, 545, 566
Technical Information, 600
Technical support, 617
Telnet Client, 533, 566–67, 578–80
Teredo, 254–55, 257
Test TCP, 568–69, 578
Third party software
BCD registry modification
with, 441
Tracert, 536
Traffic encryption, 158
Transition technologies, 252–55
Trojan horse, 196
Troubleshooting packs
built-in, 492–93
definition, 5
remote use of, 493
Trusted ActiveX Controls, 153
Trusted Platform Module (TPM)
hardware, 176–77
Trusted publishers
verification of, 342–43
Trusted Sites list, 154–55
Tunneling
definition, 225, 266
protocols, 232–35
VPN encapsulation and, 224–26
Turn Off Crash Detection, 149
U
UAC, 197
administrator privileges, 197
best practices, 205
658
Control Panel
configuration of, 200–02
disabling, 205
Group Policy settings
configuration of, 202–04
UAC compatibility
problems, 135
UAC notifications
administrators, 197–98
standard users, 199
UDP-based services, 561
UDPv4, 554
UDPv6, 554
UIAccess, 203–04
Uninstall, 489
Universal Resource Locator
(URL), 119
Unsigned ActiveX Controls, 153
Untrusted certification
authority, 142–43
Untrusted computer
accounts, 143–44
Updated drivers, 520
Updates
BCD registry file, 473–74
hardware-related, 616
misconceptions about, 194
Stop messages and, 615
USB flash drives, 177
USB hubs, 527–28
USB problems, 524–25
Bluetooth problems, 528–29
driver and hardware problem solving, 525
limitations, 525–26
Performance Monitor, 526–27
USB hubs, 527–28
User account
automatic logon to, 465–66
User Account Control
(UAC), 357
Application Compatibility, 364
User Configuration, 279
User profiles, 419–20
changes to, 421–25
definition, 419–21
roaming profile
incompatibility, 425–27
V
Verification
of software updates, 280–81
Virtual memory, 327–28
Virtual PC 2007, 361
Virus, 195
Volume Boot Record, 440
VPN (virtual private network), 221
VPN client, 226–28
VPN client connections, 223
connectivity process, 236–39
connectivity troubleshooting, 239
lesson review, 249–50
lesson summary, 249
limitations of, 251–52
practices, 239–49
tunneling protocols, 232–35
understanding, 223–32
VPN encapsulation, 224–26
VPN Reconnect, 232–33, 266
VPN server, 229–30
W
WFAS console, 384–86
Wi-Fi Protected Access
(WPA), 87
Windows 7
stratup changes, 439–40
Windows 7 64-bit, 154, 358
Windows 7 built-in compatibility
tools, 310–11
Windows 7 compatibility
verification of, 342
Windows 7 Disk Cleanup, 327
Windows 7 Hardware
Troubleshooting
Components, 35–44
boot process, 36–37
case scenarios, 46–47
chapter review, 45
chapter summary, 45
hard disks, 41–42
hardware failures versus software
failures, 35
key terms, 45
Windows XP recovery console equivalents
lesson review, 44
lesson summary, 44
motherboard, 38–40
power supply unit, 37–38
practice test, 47
practices, 47
RAM, 40–41
testing, 42–43
Windows 7 Hardware
Troubleshooting Tools, 2–34
Action Center, 2–3
alerts, 3–4
case scenarios, 46–47
chapter practice test, 47
chapter practices, 47
chapter review, 45
chapter summary, 45
Chkdsk, 29–31
Device Manager, 15–17
Disk Defragmenter, 31–32
Event Viewer, 19–20
key terms, 45
lesson practices, 32–33
lesson review, 34
lesson summary, 33
Reliability Monitor, 17–19
Startup Repair
launching, 21–24
startup failure
troubleshooting, 21
Windows 7 troubleshooters, 4–5
Control Panel
troubleshooter, 7–8
Devices and Printers
troubleshooter, 9–11
hardware troubleshooters, 12–13
settings configuration, 13–15
Windows Memory
Diagnostic, 24–29
Windows 7 logo testing, 343
Windows 7 troubleshooters, 4–5
Control Panel troubleshooter, 7–8
Devices and Printers
troubleshooter, 9–11
hardware troubleshooters, 12–13
settings configuration, 13–15
Windows 7 troubleshooting
improvements, 491
disk failure diagnostics, 495–96
driver reliability
improvements, 497
error reporting
improvements, 497
Resource Monitor, 494–95
self-healing NTFS, 496
Windows Memory
Diagnostics, 495
Windows Troubleshooting
Platform, 491–93
Windows Automated Installation
Kit (AIK), 115
Windows Boot Loader, 440,
450–51, 465
Windows Boot Loader
objects, 442
Windows Boot Manager, 26,
440, 449–50
EFI initial startup phase and, 448–49
Windows Memory Diagnostic
and, 25–26
Windows Boot Manager object, 442
Windows Boot Performance
Diagnostics, 444–45
Windows Defender
best practices, 210–11
Group Policy settings, 209–10
spyware and, 205–08
Windows Error Reporting
(WER), 483, 495, 606–08
Windows Event Collector, 299, 356
Windows executive, 451
Windows failures, 18–19
Windows Firewall, 371
chapter summary, 394
complex traffic types, 375
configuration of, 119–20
inbound exceptions, 378–81
inbound traffic, 373
network locations, 375–77
outbound traffic, 374
practices, 391–93
profiles, 377–78
troubleshooting, 381
allowed programs
(exceptions), 383–84
Control Panel, 382–83
event logs, 390
Group Policy settings, 387–89
logs, 389–90
WFAS console, 384–86
troubleshooting process, 594
understanding, 371–75
updates and, 299–300
Windows Hardware Quality Labs
(WHQL), 522
Windows Internet Naming Service
(WINS), 540
Windows Media Player, 147
Windows Memory Diagnostic, 440,
495, 508–13
definition, 24–25
System Recovery and, 444
troubleshooting with, 24–29
Windows Network Diagnostics,
51–54, 533, 570
Windows Preinstallation
Environment
(Windows PE), 443
Windows Recovery Environment
(WinRE), 21–23, 439, 467
Windows reinstallement, 475–76
Windows Remote Management,
299–300, 356
Windows Resource
Protection, 357, 368
Windows Resume Application, 440
Windows security
printers and, 111
Windows Server 2008 R2, 109–10
Windows Server Update Services
(WSUS), 209, 271–73
Windows starting
problems, 497
Windows System Image
Manager, 275
Windows Troubleshooting
Platform, 4–5, 491–93
Windows Update, 194, 209, 282–83
Windows Update client, 272
Windows Update Standalone
Installer (Wusa.exe), 279
Windows XP Mode, 361–62, 368
Windows XP recovery console
equivalents, 471
659
Wired Equivalent Protection (WEP)
Wired Equivalent Protection
(WEP), 87
Wireless connectivity issues
common problems, 92–95
Event Viewer, 95–96
group policy settings, 80–82
lesson review, 98–99
lesson summary, 98
manual connection, 78–79
practices, 96–97, 103
priorities changes, 85
660
profile types
configuration of, 91
reconfiguration, 84–85
scripts, 82–84
security, 86–88
wireless network
profile, 79–80
WPA-EAP security, 88–90
Wireless network profile
configuration of, 91
manual creation of, 79–80
Wireless networks
troubleshooting process, 592–93
Workgroup environments
event forwarding and, 306–07
Working offline, 402–03
Worm, 194–95, 270
WPA2, 87
WPA-EAP security, 87–90
WPA-PSK, 87
About the Authors
Tony Northrup, MVP, MCSE, MCTS, and CISSP, is a Microsoft
Windows consultant and author living in New London,
Connecticut. Tony started programming before Microsoft
Windows 1.0 was released, but he has focused on Windows
administration and development for the last 15 years. He has
written about 25 books covering Windows development,
networking, and security. Among other titles, Tony is coauthor
of Windows 7 Resource Kit, Windows Vista Resource Kit,
and Windows Server 2008 Networking and Network Access
Protection (NAP).
When he’s not writing, Tony enjoys photography and travel. Tony lives with his girlfriend,
Chelsea, her daughter, Madelyn, and three dogs. You can learn more about Tony by visiting his
personal Web site at http://www.northrup.org and his technical blog at http://www.vistaclues.com.
J.C . Mackin , MCITP, MCTS, MCSE, MCDST, and MCT, is
a ­consultant, trainer, and writer who has been working with
­Microsoft networks since Microsoft Windows NT 4.0. He is ­author
or coauthor of many Microsoft Press Self-Paced Training Kits
(including those for exams 70-291, 70-642, and 70-643) and of the
Windows Essential Business Server 2008 Administrator’s Companion.
When he’s not working with computers, J.C. can be found with a
camera wandering the streets of small medieval towns in Europe.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
