Speaker Catalogue
Commit to Innovation Speed to Market
MOTTO:
COMMIT TO INNOVATION,
SPEED TO MARKET
As a professional supplier of audio solution, LUMIAUDIO specializes in designing and manufacturing
speakers and audio equipment with excellence and value. We aim to provide innovative audio solutions
that focus on quality, ease of installation and functionality while presenting an aesthetically pleasing look.
LUMIADUIO have two privately ownedfactories with full experienced engineers and craftsmen. A wide
choice of machinery and the professional team are at your disposal to bring your ideas into reality. We
guarantee best products and services for global customers!
Currently, our products include in-wall & in-ceiling speakers, open-ceiling speaker, wall mounted speaker,
garden speaker,invisible speaker, TV partner speaker and various Speaker accessories. We are constantly
striving to develop new products and improve existing ones. If you are looking for a reliable, performance
proven speaker supplier, LUMIAUDIO is your best choice! CONTENTS
Wi-fi speaker ----------------------------------1-2
Frameless speaker ---------------------------- 3-8
Outdoor speaker ---------------------------- 9-12
Open-ceiling speaker ------------------------- 13
Mixing amplifier --------------------------------14
Volume control ---------------------------------15
Accessory ---------------------------------------16
mult-room audio solution
Option
1. Built-in Wi-Fi
2. Wireless network compratibility 802.11 b/g/n
3. Support online audio streaming media
4. Support audio format: MP3/WMA/AAC/ACC+/ALAC/FLAC/APE/WAV
RMS power: 2*35W
input: DC20V/[email protected]*35W
duomi.com
WSP-6
Amplifier feature
1. Type: Class D(digital)
2. RMS Power:2*50W/8 ohm
3. Power input: DC24V/5A
WSP-6
● Frequency Response:65Hz-20 Khz
● RMS Power: 60 watts
● Impedance: 8 ohms
● Sensitivity (1w/1m):90dB
● Woofer:6.5" (165mm) Kevlar Woven cone
● Tweeter:1.2" (30mm) Titanium Dome
● Treble attenuation: +3dB/-3dB
Windows
IOS
Android
Wi-Fi
Wireless speaker
WiFi feature
Wi Fi
Airplay
1
2
Y.QQ.COM
FRAMELESS
Speaker
Angled woofer technology
Elastic paint design Dog leg
Tweeter equalizer
OPTION
● Tweeter material: titanium
● Woofer material : PP cone
● 70/100V transformer: 15W
● Square grille
● FLC-5/FLC-6/FLC-6I/FLC-8/FLC-62/FLC-82
FLC-5
● Frequency Response: 70 Hz-20 kHz
FLC-6
FLC-8
● Frequency Response: 60 Hz-20 kHz
● Frequency Response: 50 Hz-20 kHz
● RMS Power:40 watts
● RMS Power:60 watts
● RMS Power:80 watts
● Impedance: 8 ohms
● Impedance: 8 ohms
● Impedance: 8 ohms
● Sensitivity (1w/1m): 90dB
● Sensitivity (1w/1m): 90dB
● Sensitivity (1w/1m): 90dB
● Woofer: 5.25" (133mm) kevlar woven cone
with rubber suspension, 1"(25mm)
ASV coil, 10 oz magnet
● Tweeter:1.2" (30mm) silk dome
● Woofer: 6.5" (165mm) kevlar woven cone
with rubber suspension, 1"(25mm)
ASV coil, 18 oz magnet
● Tweeter:1.2" (30mm) silk dome
● Woofer: 8" (203mm) kevlar woven cone
with rubber suspension, 1"(25mm)
ASV coil, 25 oz magnet
● Tweeter:1.2" (30mm) silk dome
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Cutout Dimensions: Φ179mm
● Cutout Dimensions: Φ210mm
● Cutout Dimensions: Φ258mm
●Overall Dimensions: Φ196x75mm
●Overall Dimensions: Φ227x87mm
●Overall Dimensions: Φ277x105mm
3
FLC-6I
● Frequency Response: 60 Hz-20 KHz
● RMS Power: 60 watts
● Impedance: 8 ohms
● Sensitivity (1w/1m): 90dB
● Drive Unit Complement
Woofer: 6.5" (165mm) Kevlar woven cone with
Rubber suspension, 1"(25mm) ASV coil,
18 OZ magnet
● Woofer tilt: 13 degree
● Tweeter: 1.2" (30mm) silk Dome
● Tweeter equalizer: +3dB/-3dB
● Cutout Dimensions: φ245mm
● Overall Dimensions: φ260*120mm
FLC-62
● Frequency Response: 55 Hz-20 kHz
FLC-82
● Frequency Response: 50 Hz-20 kHz
● RMS Power:60 watts
● RMS Power:80 watts
● Impedance: 4+4 ohms
● Impedance: 4+4 ohms
● Sensitivity (1w/1m): 90dB
● Sensitivity (1w/1m): 90dB
● Woofer: 6.5" (165mm) kevlar woven cone
with rubber suspension, 1"(25mm)
4-layer ASV coil, 18 oz magnet
● Tweeter:2x1.2" (30mm) silk dome
● Woofer: 8" (203mm) kevlar woven cone
with rubber suspension, 1"(30mm)
4-layer ASV coil, 25 oz magnet
● Tweeter:2x1.2" (30mm) silk dome
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Cutout Dimensions: Φ210mm
● Cutout Dimensions: Φ258mm
●Overall Dimensions: Φ227x87mm
●Overall Dimensions: Φ277x105mm
4
FRAMELESS
Speaker
OPTION
OPTION
● Tweeter material: titanium
● Woofer material : PP cone
● 70/100V transformer: 15W
● Square grille
● Tweeter material: titanium
●Woofer material : PP cone
●70/100V transformer: 15W
●FLW-5/FLW-6/FLW-8/FLW-55
FLW-55
FLB-6
FLW-5
FLW-6
Elastic paint design Dog leg
Tweeter equalizer
FLW-8
● Frequency Response: 55 Hz-20 KHz
● Frequency Response: 65 Hz-20 kHz
● Frequency Response: 70 Hz-20 kHz
● Frequency Response: 60 Hz-20 kHz
● Frequency Response: 50 Hz-20 kHz
● RMS Power: 60 watts
● RMS Power: 70 watts
● RMS Power:40 watts
● RMS Power:60 watts
●RMS Power:80 watts
● Impedance: 8 ohms
●Impedance: 8 ohms
● Sensitivity (1w/1m): 94dB
● Sensitivity (1w/1m): 90dB
● Woofer: 6.5" (165mm) kevlar woven cone
with Rubber suspension,
1"(25mm) ASV coil, 25 OZ magnet
● Tweeter: 1.42" (36mm) Silk Dome
● Woofer: 2x5.25" (135mm) kevlar woven cone with rubber
suspension, 1"(25mm) ASV coil,10 oz magnet
● Tweeter: 1.42" (36mm) silk dome
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Cutout Dimensions: φ210mm
● Cutout Dimensions: 365x155mm
● Overall Dimensions: φ227*88mm
● Overall Dimensions: 386x175x82mm
5
● Impedance: 8 ohms
● Impedance: 8 ohms
● Impedance: 8 ohms
● Sensitivity (1w/1m): 90dB
● Sensitivity (1w/1m): 90dB
● Sensitivity (1w/1m): 90dB
● Woofer: 5.25" (133mm) kevlar woven cone with
rubber suspension, 1"(25mm) ASV coil,
10 oz magnet
● Tweeter:1.42" (36mm) silk dome
● Woofer: 6.5" (165mm) kevlar woven cone with
rubber suspension, 1"(25mm) ASV coil,
18 oz magnet
● Tweeter:1.42" (36mm) silk dome
● Woofer: 8" (203mm) kevlar woven cone with
rubber suspension, 1"(25mm) ASV coil,
25 oz magnet
● Tweeter:1.42" (36mm) silk dome
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Tweeter equalizer: +3dB/-3dB
● Cutout Dimensions: 245x155mm
● Cutout Dimensions: 280x185mm
● Cutout Dimensions: 340x220mm
●Overall Dimensions: 267x175x75mm
● Overall Dimensions: 300x205x86.5mm
● Overall Dimensions: 362x242x105mm
6
FRAMELESS
Speaker
CC-6A
● Frequency Response: 70Hz-20kHz
CC-6B
CC-6C
● Frequency Response: 50Hz-20kHz
CC-6D
● Frequency Response: 60Hz-20kHz
● Frequency Response: 40Hz-20kHz
● RMS Power: 50 watts
● RMS Power: 60 watts
● RMS Power: 50 watts
● RMS Power: 60 watts
● Impedance: 8 ohms
● Impedance: 8 ohms
● Impedance: 8ohms
● Impedance: 8 ohms
● Transformer tapes: 70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
● Sensitivity (1w/1m): 90dB
● Transformer tapes: 70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
● Sensitivity (1w/1m): 91dB
● Transformer tapes: 70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
● Sensitivity (1w/1m): 90dB
● Transformer tapes: 70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
● Sensitivity (1w/1m): 91dB
● Woofer: 6.5" (165mm) mineral filled polypropylene
cone with rubber suspension, 1"(25mm)
ASV coil, 10 oz magnet
● Tweeter: 1.2" (30mm) PEI dome
● Woofer: 6.5" (165mm) Al cone with rubber
suspension, 1"(25mm) ASV coil,
springless design, 15 oz magnet
● Tweeter: 1.2" (30mm) PEI dome
● Woofer: 6.5" (165mm) mineral filled polypropylene
cone with rubber suspension, 1"(25mm)
ASV coil, 10 oz magnet
● Tweeter: 1.2" (30mm) PEI dome
● Woofer: 6.5" (165mm) Al cone with rubber
suspension, 1"(25mm) ASV coil,
springless design, 15 oz magnet
● Tweeter: 1.2" (30mm) PEI dome
● Cutout Dimensions: Φ265 mm
● Cutout Dimensions: Φ265 mm
● Overall Dimensions: Φ286x155mm
● Overall Dimensions: Φ286x155mm
7
Euro block connector
Safety cable ring
OPTION
● Tweeter material: 1.2"silk dome
or 1.2" titanium dome
Dog leg
Elastic paint design
● Cutout Dimensions: Φ265 mm
● Cutout Dimensions: Φ265mm
● Overall Dimensions: Φ286x215mm
● Overall Dimensions: Φ286x215mm
8
OUTDOOR
Two colour available
Speaker
Bass Radiator
Elastic paint design
OPTION
● Woofermaterial: non-press paper cone
● Tweeter material: silk
● OWS-5TWith Transformer tapes:
70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
OWS-5
OWM-5
●Frequency Response: 60Hz-20 KHz
Two colour available
●Frequency Response: 45Hz-20kHz
●RMS Power: 60 watts
●RMS Power: 60 watts
●Impedance: 8 ohms
●Impedance: 8 ohms
●Sensitivity (1w/1m): 90dB
●Sensitivity (1w/1m): 90dB
Special Features:
●Weatherproof
●Dual-axis mounting solution
●Range of Rotations 90° vertical and 170°
horizontal
●UV-resistant Polypropylene Enclosure
●OWM-5T with Transformer tapes:
70V: 32-16-B-4-2-1W & 8ohms
100V: 32-16-B-4-2W & 8ohms
●Enclosure material: ABS
●Grill material: aluminum
●Bracket material: aluminum
●Environment: IP56
●Woofer: 5.25"(133mm) mineral filled polypropylene cone
with rubber suspension, 1"(25mm) ASV coil,
15oz magnet, planar ellipse low-bass radiator
●Tweeter: 1.42"(36mm) titanium Dome
●Enclosure material: ABS
●Grill material: aluminum
●Stand material: aluminum
●Environment: Ip56
●Woofer: 5.25" (133mm) mineral filled
polypropylene cone with Rubber
suspension, 1"(25mm) ASV coil,
15 OZ magnet
●Tweeter: 1.42" (36mm) titanium Dome
●Overall Dimension:198x205x315mm
9
10
●Overall Dimensions: 190*256*225mm
OUTDOOR
Speaker
Two colour available
OPTION
● Tweeter material: silk
● Woofer material: mineral filled AL cone
OGT-5
OGS-5
●Frequency Response: 60Hz-20kHz
●RMS Power: 60 watts
●Impedance: 8 ohms
●Transformer tapes: 70V: 32-16-8-4-2W & 8 ohms
100V: 32-16-8-4W & 8 ohms
●Sensitivity (1w/1m): 90dB
●Enclosure material: LLDPE
●Environment: IP56
●Woofer: 5.25" (133mm) mineral filled
polypropylene cone with rubber
suspension, 1"(25mm) ASV coil, 10 oz magnet
●Tweeter: 1.2" (30mm) titanium Dome
●Overall Dimensions:Φ365 x H409 mm
11
OGT-6
OGT-8
●Frequency Response: 90Hz-20 kHz
●Frequency Response: 80Hz-20 kHz
●Frequency Response: 60Hz-20 KHz
●RMS Power: 40 watts
●RMS Power: 60 watts
●RMS Power: 80 watts
●Impedance: 8 ohms
●Impedance: 8 ohms
●Impedance: 8 ohms
●Transformer tapes: 70V: 16-8-4-2-1W & 8 ohms
100V: 16-8-4-2-1W & 8 ohms
●Sensitivity (1w/1m):88dB
●Transformer tapes: 70V: 32-16-8-4-2W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
●Sensitivity (1w/1m):88dB
●Transformer tapes: 70V: 64-32-16-8-4W & 8 ohms
100V: 64-32-16-8-4W & 8 ohms
●Sensitivity (1w/1m):88dB
●Enclosure material: Fiberglass
●Enclosure material: Fiberglass
●Enclosure material: Fiberglass
●Environment: IP56
●Environment: IP56
●Environment: IP56
●Woofer: 5.25" (133mm) mineral filled polypropylene
cone with rubber suspension,1"(25mm)
ASV coil, 10 oz magnet
● Tweeter: 1.2" (30mm) titanium Dome
●Woofer: 6.5" (165mm) mineral filled polypropylene
cone with rubber suspension,1.2"(30mm)
ASV coil,18 oz magnet
●Tweeter: 1.2" (30mm) titanium Dome
●Woofer: 8" (203mm) mineral filled polypropylene
cone with rubber suspension,1.5"(38mm)
ASV coil,30 oz magnet
●Tweeter: 1.2" (30mm) titanium Dome
●Overall Dimensions: 250x240x200mm
●Overall Dimensions: 320x230x270mm
●Overall Dimensions:440x300x300mm
12
OPEN-CEILING
MIXING Amplifier
Speaker
SPECIFICATIONS:
1. Output Power(Rated):240 W
2. Output Power(Max.):300 W
3. Audio Inputs:4 MIC/LINE,1 LINE(CD/Tuner/Tape/Aux) level
4. USB/SD Interface: MP3/WMA formats
5. Bluetooth: Apply to 2.0, 2.1, 3.0 version
INPUTS:
1. MIC(Impedance/Sensitivity):600Ω /2.7 mV balanced
2. LINE(Impedance/Sensitivity):47 kΩ /100 mV
3. AUX(Impedance/Sensitivity):20 kΩ /100 mV
PS-6
4. CD(Impedance/Sensitivity):47 kΩ /570 mV
CMA 240USB
5. Tuner(Impedance/Sensitivity):56 kΩ /300 mV
6. Tape(Impedance/Sensitivity):1 kΩ /1 V
OUTPUTS:
●Frequency Response: 45Hz-20 KHz
Two colour available
●RMS Power: 80 watts
1. Direct outputs: 4,8,16Ω /25,70,100 V
2. Zone outputs: 4 zones:100V(ONLY)
3. Pre-out:600Ω/1V
●Impedance: 8 ohms
OPTION
● Tweeter material: silk
● Woofermaterial: mineral filled AL cone
●Transformer tappings: 70V: 32-16-8-4-2-1W & 8 ohms
100V: 32-16-8-4-2W & 8 ohms
●Sensitivity (1w/1m): 90dB
4. Monitor output: 8Ω /1W
5. Frequency Response:30Hz-20KHz /±3DB
6. EQ Contorl(Bass):±10dB/25Hz-160Hz/Centre Frequency 60Hz
7. EQ Contorl(Treble):±10dB/4kHz-20kHz/Centre Frequency 10kHz
8. S/N ratio:>80 dB(LINE),>60 dB(MIC)
9. Total harmonic distortion: Less than 0.5% at 1KHz, rated power
10. Main Supply AC power: AC110/230V, 50Hz/60Hz
11. Dimensions:436x303x88mm
●Enclosure material: ABS
●Woofer: 6.5" (165mm) mineral filled Polypropylene
cone with Rubber suspension, 1.2"(30mm)
ASV coil, 18 OZ magnet
●Tweeter: 1.2" (30mm) titanium Dome
●Overall Dimensions:Φ308xH365 mm
13
14
VOLUME
ACCESSORY
Control
VC-100
● Power handing: 50 watts per channel
100 watts peak power
● Steps: 12(make before break)
● Total attenuation: 42 dB(Max)
● Frequency response: 20Hz-20KHz
● Depth:2-9/25" behind plate
● Color: white
VC-120
Rough in bracket
Rough in brackets are installed before
the sheetrock is installed, so they are
only used in new construction. Their
primary purpose is to indicate to the
sheet-rock installers where (and what size)
to cut holes for the speakers. They are
optional. If not used, you must secure
the speaker wire in place between the
studs or rafters, measure the exact location,
then cut the speaker hole and retrieve the
wire after the sheet-rock is installed.
Tile bridge
● Power handing: 60 watts per channel
120 watts peak power
Supports weight of speakers installed
in suspended ceilings
● Steps: 12(make before break)
● Total attenuation: 42 dB(Max)
Three colour available
● Frequency response: 20Hz-20KHz
● Depth:2-9/25" behind plate
white
almond
● Color: white
bone
15
16
DISTRIBUTOR SUPPORT
OEM / ODM SERVICE
●An experienced & talented design Team, including a considerate customer service team.
●Advanced hi-tech facilities with skilled craftsmen, offering strict quality control & quality assurance.
●We highly value the protection of customer's
intellectual property. We give definite confidential
guarantees as well as protection of technology or intellectual property involved in each project.
Welcome you to become a distributor of Lumiaudio
●We provide full support to lumiaudio distributors
●Regional / national exclusive distributorships are available ●Catalogue printed in your local language
●24/7 ongoing support from our expertly trained customer service and technical team
●Sharing the latest market information
●For more details, please get in contact with a LUMIAUDIO representative.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
