Kaiser Fototechnik MonoCR-C2
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 2
TWIN1: Not
TWIN1 R3/R4
The Wireless and
Wired Remote Release
for Your Camera
Twin1 R4 Infrared Transmitter/Receiver Kit
Transmitter
- Applicable as an IR remote shutter release and cable
release (for exceptions see survey below)
- Working range up to 100 m (330 ft.) with separate receiver, 50 m (165 ft.) (Nikon, Pentax, Samsung) or 25 m
(82 ft.) (Canon) with cameras with built-in receiver
R4N
- Two-step release button, delay shot
(wireless) and bulb shot mode
- Built-in flashlight LED
6167
- Includes 1 m (39 in.) release cable
TWIN1 R4 receiver (except for 6167)
- Streamlined design
- Two red LEDs for release control
- Size: 30 x 40 x 25 mm (1.2 x 1.6 x 1 in.)
TWIN1 R4N receiver (6167)
- Extremely small and light-weight (6 g / 0.2 oz.)
- Red LED for release control
- Powered by camera, needs no extra battery
- Size: 15 x 15 x 22 mm (0.6 x 0.6 x 0.9 in.)
R3
Twin1 R3
Transmitter only (similar to R4) for cameras
which are already equipped with a build-in IR
receiver. Release cable included.
Working range up to 50 m (165 ft.) with Nikon,
Pentax and Samsung cameras, up to 25 m (82
ft.) with Canon cameras.
Product Survey
6161
Twin1 RF
System
Canon: 1D, 1D Mark II, 1D Mark IIN, 1D Mark III, 1D Mark IV, 1DS, 1DS Mark II,
1 DS Mark III, 5D, 5D Mark II, 5D Mark III, 7D, 10D, 20D, 30D, 40D, 50D, D30, D60
6169
6178
6188
Canon: 1000D, 1100D, G12, Samsung: NX 5, NX 10, NX 11, NX 100, Sigma: SD14
6168
6177
6187
6168
6177
6187
6167
(R4N)
6179
(RFN)
6189
Canon: 300D, 350D, 400D, 450D, 500D, 550D, 600D, 650D, 60D, Samsung: GX-1L,
GX-1S, GX-10, GX-20, Pentax: *istD, *istDs, *istDs2, *istDL, *istDL2, K-5, K-7, K10D, K20D,
K30D, K100D, K110D, K200D
6161
Canon (IR only, no accessory terminal): EOS M, Pentax (IR only, no accessory terminal): K-m, K-x, K-r
6161
Nikon: D1, D1X, D1H, D2, D2H(s), D2X, D2Xs, D3(s), D3X, D4, D200, D300, D300s,
D700, D800, D800E, Fuji: S5pro, S3pro
Nikon: D90, D3200, D5000, D5100, D7000
6162
Nikon (IR only, no accessory terminal): D40(x), D50, D60, D70, D70s, D80, D3000, V1, J1,
Coolpix P7100
6162
NEW
Twin1 R4
System
Twin1 R3
System
MonoCR
System
6190
Nikon: D3100
6190
Sony: Alpha 33, 35, 37, 55, 65, 77, 100, 200, 300, 350, 450, 500, 550, 580, 700, 850, 900,
* Auslösung nur über Infrarot-Sender IR20, (6252, optionales Zubehör)
Minolta: 5D, 7D
6170
6180
6191
Panasonic: G1, GH1, GF1, G2, GH2, G3, G5, GX1, G10, FZ 20, FZ 30, FZ 50, FZ 100,
FZ 150, FZ200, LC1, L10, L1, Leica: Digilux 2/3, V-Lux 1/2/3
6181
6192
Olympus: Pen E-P1, Pen E-P2, Pen E-PL2, Pen E-P3, Pen E-PL3, Pen E-PM1; E-30, E-620,
E-520, E-510, E-420, E-410, SP-510UZ, SP-550UZ, SP-560UZ, SP-565UZ, SP-570UZ,
SP-590UZ, SP-810UZ, XZ-1, SZ-30MR, SZ-20, SZ-11, OM-D E-M5
2
6171
6193
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 3
t Only for Immediate Release
TWIN1 RF
The Radio-Controlled
Wireless and Wired
Remote Release
Twin1 RF transmitter
- Applicable as an RC remote shutter
release and cable release
- Working range up to 100 m
(330 ft.)
- Two-step release button, delay shot
(wireless) and bulb shot mode
6177
Twin1 RFN receiver (6179)
- Extremely small and light-weight
(6 g / 0.2 oz.)
- Red LED for release control
- Powered by camera, needs no extra battery
- Size: 15 x 15 x 22 mm (0.6 x 0.6 x 0.9 in.)
RFN
- Built-in flashlight LED
- Operation frequency: 2.4 GHz
- Size: 88 x 26 x 17 mm, 19 g
(3.5 x 1 x 0.7 in, 0.7 oz.)
- Includes 1 m (39 in.) release cable
6178
Twin1 RF receiver (except for 6179)
- Streamlined design
- Two red LEDs for release control
- Size: 30 x 40 x 25 mm (1.2x1.6x1 in.)
6180
6181
6179
Product survey: see table on previous page.
MonoCR – The Cable Release for
Your Camera
This compact and ergonomically shaped cable release
is very similar to your camera’s release button. Most
useful in macro photography, when using large telephoto lenses or for long exposures, a cable release
ensures vibration-free shooting.
Dimensions: approx. 105 x 34 x 23 mm
(4.1 x 1.3 x 0.9 in.)
Weight: approx. 30 g (1.1.oz.)
Product survey: see table on previous page.
Two-step release: At the first pressure point TTL metering and auto focus is activated, the second triggers
the shutter.
NEW
For bulb shots the button can be locked
(color indicator).
The release cable can be detached
and extended using the 2 m (6.6 ft.)
extension cable (code no. 6185).
Length of coiled cord (extended):
approx. 90 cm (35.4 in.)
6187-93
3
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 4
TWIN1 ISR The Multifunctional
Remote Shutter Release
• for interval exposure
• for long exposure
Release button lock
Set up button
Illumination button
Navigation button
Enter button
Release button
Display panel
• for timer-controlled exposure
• for continuous shooting
Delayed start is supported. Timer and interval time ranges from 1 second to 99 hours,
59 minutes, 59 seconds. Exposure numbers
range from 1 to 9.999. 4-way-operation button. All buttons can be locked to prevent
unintentional operation. Beep sound can be
switched off. Low battery warning. Normal
shutter release can be used without a battery fitted, all other functions require a battery.
Cable connection port
- Battery: 3V (CR 2032)
- Operating time: approx. 2 months
Battery cover
- Release cable length: approx. 1 m (39 in.)
- Size: 23 x 16 x 100 mm (0.9 x 0.6 x 3.9 in.)
- Weight: 26 g / 0.9 oz. (incl. batteries)
Product Survey
6131 Twin1 ISR iC, for Canon 1000D,
1100D, 650D 600D, 550D, 500D,
450D, 400D, 350D, 300D, 50D,
40D, 60D, 30D, 20D,10D, 7D, 5D
(Mark II/III), 1Dx, 1D(s) Mark
II(N)/III/IV, 1D(s), G12, D30, D60,
Pentax K200D, K110D, K100D,
istD..., K20D, K10D, K7, K5,
Samsung GX-.., NX 5, NX 10,
NX 11, NX 100, Sigma SD14
6133 Twin1 ISR iN, for Nikon D7000,
D3200 , D3100, D5100, D5000,
D90, D80, D70s, D700, D800,
D800E, D300(s), D200, D4, D3(x),
D3(s), D2, D2H(s), D2X(s), D1,
D1H, D1X, Fuji S3Pro, S5Pro
6134 Twin1 ISR i04, for Sony Alpha 33,
35, 37, 55, 65, 77, 100, 200, 300,
350, 450, 500, 550, 580, 700, 850,
900, Minolta 5D, 7D
Interval timer icon
Exposure count icon
Exposure time icon
Timer icon
Operation run indicator
Beep sound On/Off icon
6135 Twin1 ISR i07, for Leica Digilux 2/3,
V-Lux1, V-Lux2/3, Panasonic GX1, G1,
G2, G3, G10, GH2, FZ100, FZ150,
FZ20, FZ30, FZ50, L1, L10, LC1
Time indicator
Battery-low icon
4
Hold indicator
Exposure count icon
Display mode
Set up icon
Illuminated triple-spaced LCD.
Three types of display mode.
Easy user interface for all settings.
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 5
More to Release!
TWINLINK T2D:
A Combined
Radio Frequency
and Infrared
Flash Trigger
• two simultaneous
triggering signals
for high operational reliability
• for studio and
camera flash
systems
Set comprising transmitter and receiver for wireless triggering of studio and camera flashguns.
Simultaneous triggering via 2.4 GHz radio frequency and infrared signals using eight high performance LEDs. 16 user selectable channels.
Transmitter and receiver with LED panels that can
be illuminated and external aerials. Automatic
power off after pre-determined time.
Transmitter can be attached using the camera's
hot shoe or with an adhesive accessory shoe
mount attached in a convenient location. Receiver with tripod thread and mounting magnets for
attachment to metal surfaces or via an adhesive
metal plate supplied with the set. Receiver has a
hot shoe and trigger cable terminals for PC and
2.5 mm jack-plug. Battery or mains operation.
- Max working range: approx. 50 m (165 ft.)
indoors, approx. 200 m (660 ft.) outdoors.
- Max. sync. speed: 1/250 sec. (depending on
camera and flash)
- Batteries: Transmitter: 2x CR 2032, receiver:
3 x AAA (primary or rechargeable)
- External power supply: Mains adapter/charger for receiver only (will also charge
rechargeables).
- Dimensions: Transmitter: 40 x 68 x 35 mm
(1.6 x 2.7 x 1.4 in.), Receiver: 50 x 80 x 25
mm (2 x 3.1 x 1 in.)
- Weight: Transmitter: 35 g (1.2 oz.), Receiver:
53 g (1.9 oz.)
Product survey
Remote Flash Trigger
6140 TwinLink T2D
Receiver and transmitter. Includes
PC cable, 2.5/3.5 receiver cable,
3.5/6.3 adapter plug, adhesive
accessory shoe, adhesive metal
plate, AC power adapter, 3 AAA
batteries, 2 CR 2032 batteries,
receiver fixture clip
6141 TwinLink T2RxD
Additional receiver for TwinLink T2D
NEW
1503
1504
For wireless lag-free firing of a second flash unit. Range up to 20 m (65.6 ft.)
depending on the guide number of the flash unit and room brightness. 1/4" tripod
bush. Features an additional PC flash terminal to connect another flash unit.
1503: For flash units with standard ISO foot
1504: For flash units with 4-pin Sony/Minolta foot
5
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 6
Simply More
Options – Flash
Accessories
Flash Adapter
NEW
For firing flash units with
standard ISO foot and center contact mounted on a
Sony/Minolta DSLR camera
with proprietary 4-pin foot.
Features an additional PC
flash terminal to connect
another flash unit.
1304
Mounting Foot
Flash Bracket
Light metal bracket with
resilient contact surface.
Length: 16.5 cm (6.5 in.)
1300
Flash Shoe Adapter
For cameras with hot flash
shoe and flash equipment
without hot flash shoe.
With synchro flash socket.
1107
1200
Angle Bracket
Collapsible. Stable threepoint rest.
1301
Bounce Flash Shoe
For indirect flash illumination. Steplessly adjustable.
Height: 45 mm (1.8 in.).
1303
Flash Shoe Adapter
For cameras without hot
flash contact and flash
equipment with hot flash
contact. With synchro cable.
Flash Adapter For connecting flash guns to receivers
of RC remote releases, e.g.
Kaiser TwinLink, Pocket
Wizard, Skyport etc.
1407
PC-PC Flash Cable
With male PC plug at
both ends to connect
flashguns. Length: 5 m
(16.4 ft.)
6040
1405
NEW
1000
With accessory shoe
for lighting units, flash
guns etc. Tripod thread
1/4" for attachment on
tripods. Dimensions:
94 x 63 x 11 mm (3.7
x 2.5 x 0.4 in.)
PC-PC Spiral Cord
With male PC plug at
both ends to connect
flashguns. Length:
65 cm (25.6 in.)
1420: 0,5 m
1423: 2 m
1322
Triple PC Flash Outlet
For simultaneous use of
up to three flash units
with standard PC plugs.
6
1409
Flash Cable
With pull relief. 10 m
(33 ft.). PC plug and jack
plug ø 6.35 mm.
1450
Spiral Cord
For connecting flash equipment
and as extension cord. 2 m
(6.6 ft.), PC plug - PC socket.
1424: 3 m
1425: 5 m
1426: 10 m
Extension Cord
For connecting flash equipment. With right-angle plug
and socket (PC).
1215
Accessory Shoe Adapter
For cameras with Sony/
Minolta flash shoe.
Sony/Minolta c Standard/ISO
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 7
This?
. . .or That?
„digiShield“ LCD Glare Shield
• digiShield shields lateral and angular incidence of light from the LCD monitor and
improves the visibility of the monitor
image.
• digiShield folds down completely and
serves also as a cover and a screen
protector.
• digiShield fits almost all digital compacts
and is attached to the tripod socket.
• digiShield is available for 2.7” (digiShield2)
and 3.0” LCDs (digiShield3) in silver and in
black.
• digiShield has coil spring supported side flaps
which open automatically.
• digiShield3 flips up completely to ease the
operation of touch screen LCDs.
6054
6074
6054
6075
6055
Screen size
(diag.):*
2.7” (6.9 cm) 2.7” (6.9 cm)
3.0” (7.6 cm)
3.0” (7.6 cm)
Designation:
digiShield2
digiShield2
digiShield3
digiShield3
Colour:
silver
black
silver
black
6074
* eventually minor border covering with 6.9 cm (2.7”)
6075
. . .or This!
NEW
SL3 LCD Loupe
The SL3 LCD loupe has been designed for DSLRs and CSCs
with 3” LCD. It is not only a perfect shield against incident
light, but enables, in any ambient light situation,
an optimal examination of frame and focus
while shooting and during playback. The
built-in loupe has a double-side coated
lens element with 2.3 magnification
and diopter adjustment.
Attaches to the camera via selfadhesive mounting frame where
the hood clicks into place.
Eyecup can be positioned for left
or right eye viewing.
6084
7
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:31 Seite 8
Lens Hoods
Designed for the lenses of digital SLRs. Fits onto the matching
lens facing either forward for normal use or rearwards for storage (except 6887, mounts onto filter thread). Made of impactresistant plastic.
You Must
Have This!
EF 135/2.8 soft focus,
EF 70-210/3.5-4.5 USM,
EF 100-300/4.5-5.6 (USM)
NEW
6866: CT67, for Canon
EF 100/2.8 USM/Macro USM
NEW
6868: CT73, for Canon
EF 100/2.8 L Macro IS USM
NEW
6869: CT73B, for Canon EF 70300/4-5.6 L IS USM, white
6885: C65B, for Canon EF 70300/4.5-5.6 DO IS USM,
EF 70-300/4.0-5.6 IS USM
NEW
6870: CT74, for Canon EF 70200/4.0 L (IS) USM, white
6886: C67B, for Canon
EF-S 60/2.8 Macro USM
NEW
6871: CT83C, for Canon EF 100400/4.5-5.6 L IS USM, white
6887: C62, for Canon EF 50/1.8 II
NEW
6873: CT87, for Canon EF 70200/2.8 L IS II USM, white
NEW
6874: CW83F, for Canon
EF 24-70/2.8 L USM
NEW
6875: CW83G, for Canon EF 28300/3.5-5.6 L IS USM, white
NEW
6876: CW83H, for Canon
EF 24-105/4.0 L IS USM
NEW
6878: CW88, for Canon
EF 16-35/2.8 L II USM
NEW
6879: C78E, for Canon EF-S 1585/3.5-5.6 IS USM
6880: C60, for Canon
EF 28-90/4.0-5.6 II (USM),
EF 28-80 (II/USM),
EF-S 18-55/3.5-5.6 IS (USM/II),
EF 22-55/4.0-5.6
6881: C73, for Canon
EF 24-85/3.5-4.5 (USM)
6882: C78, for Canon
EF 28-135/3.5-5.6 IS USM
6883: C71, for Canon
EF 50/1.4 USM
6884: C65III, for Canon
EF 85/1.8 (USM),
EF 100/2.0 USM,
6888: C60T, for Canon EF 75300/4.0-5.6 III (USM),
EF 90-300/4.5-5.6 (USM),
EF-S 55-250/4.0-5.6 IS
6889: C73B, for Canon EF-S 1785/4.0-5.6 IS USM,
EF-S 18-135/3.5-5.6 IS (STM)
6890: C78D, for Canon
EF-S 18-200/3.5-5.6 IS,
EF 28-200/3.5-5.6 (USM)
6891: C83, for Canon
EF-S 10-22/3.5-4.5 USM,
EF 17-40/4.0L USM,
EF 16-35/2.8L USM (old
version)
6892: C83J, for Canon
EF-S 17-55/2.8 IS USM
6893: N32, for Nikon AF-S DX 1870/3.5-4.5G IF-ED,
AF-S 18-105/3.5-5.6 G ED VR,
AF-S 18-135/3.5-5.6 IF-ED
6894: N45, for Nikon AF-S DX 1855/3.5-5.6G ED/EDII/VR
NEW
6895: N37, for Nikon AF-S
DX 55-200/4.0-5.6G ED VR
6899: SH108, for Sony DT
18-55/3.5-5.6 SAM
Lens Hoods for Pancake Lenses
3-in-1 Lens Hoods
for lenses with 28 to 200 mm focal length (35 mm equivalent).
Made of matte black rubber, foldable. With light baffles. Metal
screw-in mount. Filter thread.
8
Wide angle
Standard
6820: ø 49 mm
6821: ø 52 mm
6822: ø 55 mm
6823: ø 58 mm
6824: ø 62 mm
6825: ø 67 mm
Telephoto
6826: ø 72 mm
6827: ø 77 mm
Made of matte black
rubber. Rotating connecting ring with metal
mount and locking screw.
Includes lens cap for use with
mounted lens hood.
6829: For Panasonic Lumix G with 1.7/20 mm or 2.5/14 mm
Pancake lens, also for JVC and Panasonic camcorders with
46 mm filter thread.
6831: For Olympus Pen with M.Zuiko Digital 2.8/17 mm Pancake
lens, M.Zuiko Digital 3.5-5.6/14-42- mm II, Panasonic
Lumix G X Vario PZ 14-42 mm 3.5-5.6, also for Canon,
JVC and Sony camcorders with 37 mm filter thread.
NEW
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 9
Protective Shield:
Screen Protectors for the
Camera LCD
Anti-Reflective Screen Protective Film
High-quality film for use with digital cameras. Protects the screen
from scratches, dirt and fingerprints. Glare-free by
anti-reflective layer. Has UV protection and
hard coating, optimized for touch-screens.
Attaches by adhesion due to silicon coating.
Easy to apply, no bubbling. Can be removed
without residues. 1 piece.
6085:
6086:
6087:
6090:
6092:
for
for
for
for
for
6,4 cm (2,5“) screens
6,9 cm (2,7“) screens
7,6 cm (3,0“) screens
8,9 cm (3,5“) screens
10,2 cm (4,0“) screens
Format 16:9
6095: for 7,6 cm (3,0“) screens
6097: for 8,9 cm (3,5“) screens
Also available custom-fit for
these digital SLRs and CSCs:
6615: for Canon 50D / 40D *
6616: for Canon 7D *
6618: for Canon 60D / 600D
6619: for Canon 1100D
6623: for Nikon D300(s) *
6625: for Nikon D3100
6626: for Olympus E450 / E420 / E520
6627: for Olympus E620
6628: for Panasonic G3 / GF3 / GF5 / GX1
6629: for Panasonic TZ18 / 22 / 25 / 31,
Leica V-Lux 30 / 40, Nikon P510
6630: for Panasonic GH1 / G1
6631: for Panasonic GF1 / GF2 / FZ45 /
LX5 / LX7, Leica D-Lux 5
6632: for Panasonic GH2 / G2 / FZ100,
FZ150, Leica V-Lux 2 / 3
6634: for Sony Alpha 230 / 290 / 450
6636: for Sony Alpha 500 / 550
6637: for Sony Alpha 580
UV protection
6638: for Sony Alpha 33 / 35 / 55 und
NEX 3 / C3 / 5 / 5N / 7 / F3
6640: for Sony Alpha 57 / 65 / 77,
NEW
DSC-HX200
NEW
6642: for Olympus OM-D E-M5
NEW
6644: for Nikon D3200
6645: for Nikon D7000 *
No color tint
6646: for Nikon D5100
NEW
6647: for Nikon 1 J1
6648: for Nikon 1 V1, Fujifilm HS 30
NEW
6649: for Nikon D800 *
NEW
NEW
6650: for Canon 5D Mark III
6651: for Canon 650D
NEW
Scratch
resistent
Effective
adhesion
Touch
optimised
Removable,
no residues
Bubble-free
application
„Standard“ LCD Screen Protective Film
Antireflection
Hardcoat
UV filter
PET
Silicon
Backing layer
* includes protective film for control panel
„Crystal Clear“ Screen Protective Film
High-quality clear film for use with digital cameras. Protects the
screen from scratches, dirt and fingerprints. High level of transparency, hardly visible. Has UV protection and hard coating, optimized for touch-screens. Attaches by adhesion due to silicon coating.
Easy to apply, no bubbling. Can be removed without residues.
1 piece.
NEW
6079:
6080:
6081:
6082:
for
for
for
for
6,9 cm (2,7“) screens
7,6 cm (3,0“) screens
8,9 cm (3,5“) screens
10,2 cm (4,0“) screens
Format 16:9
6093: for 7,6 cm (3,0“) screens
6094: for 8,9 cm (3,5“) screens
6078
For use with digital cameras, mobile phones and PDA's
(6076 also for GPS). Protects the screen from scratches,
dirt and fingerprints. Also for touch-screens. Can be removed without residues
6076: Set with three 4 x 3" (10 x 8 cm) sheets each, with
cutting lines for required size. Comes with cleaning
cloths and a squeegee card to apply the film.
6078: For 3" LCD screens. Can be cut to fit smaller
screens. Rounded corners. 3 pieces.
9
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 10
Even More for Your Lens
Rodenstock „HR Digital super MC“ and
„Digital pro MC“ Filters
Both these Rodenstock filter series are made
from tempered glass with highest possible surface quality and are also highly scratch-resistant.
Their flat slimline mounts prevent vignetting
with wide-angle lenses. The front thread allows
the use of a lens hood or of the lens cap with
the filter in place.
The filter mount of the less expensive Digital
pro MC series is made from tempered, black
anodized aluminum and is quite lightweight.
The filter mount of the HR Digital super MC
series is made from robust brass for optimum
smooth movement of both threads. An additional water and oil repellent coating provide for
the so-called lotus effect.
Due to the perfect color neutrality Rodenstock
UV blocking filters are also ideal protective filters that can be left on the lens at all times.
Rodenstock Neutral Density Filters ND 2x, 4x, 8x
They allow the extension of exposure times by
a factor of 2, 4 or 8 for impressive smear effects
or a further opening of the aperture for a considerably reduced depth of field.
Rodenstock UV Filters
Rodenstock UV blocking filters block out the
UV radiation exactly at the border to visible
light. This is extremely efficient and they are
perfectly color neutral.
Rodenstock Circular Polarizing Filters
Circular Polarizers reduce or eliminate reflections on surfaces, reduce the diffuse blue cast in
landscape photographs and produce an improved color saturation.
Rodenstock Variable Neutral Density Filter
If more than the fixed 2x, 4x and 8x ND levels
or a finer graduation is required, the Digital
Vario MC variable neutral density filter is the
right solution.
Camera Body Caps
6521:
6522:
6523:
6525:
6527:
6528:
10
for
for
for
for
for
for
Canon EOS
Minolta MD
Sony/Minolta AF
Nikon
Pentax K-Bajonett
Micro Four Thirds
NEW
Lens Rear Caps
6531:
6532:
6533:
6535:
6536:
6537:
6538:
for
for
for
for
for
for
for
Canon EOS
Minolta MD
Sony/Minolta AF
Nikon
Olympus OM
Pentax K-Bajonett
Micro Four Thirds
NEW
18449
18452
18455
18458
18462
18467
18472
18477
18482
-
NEW
18849
18852
18855
18858
18862
18867
18872
18877
18882
-
NEW
Digital Vario ND 2 - ND 400 MC
NEW
„HR Digital ND 0,9/8x MC“ Grey Filters
18249
18252
18255
18258
18262
18267
18272
18277
18282
-
„HR Digital ND 0,6/4x MC“ Grey Filters
18049
18052
18055
18058
18062
18067
18072
18077
18082
18086
18095
„HR Digital ND 0,3/2x MC“ Grey Filters
17849
17852
17855
17858
17862
17867
17872
17877
17882
-
„HR Digital CPL super MC, cirkular“ Polarizing Filters
17937
17939
17940
17943
17946
17949
17952
17955
17958
17962
17967
17972
17977
17982
17986
17995
„Digital pro CPL MC, cirkular“ Polarizing Filters
17734
17737
17740
17743
17746
17749
17752
17755
17758
17762
17767
17772
17777
17782
-
„HR Digital UV super MC“ UV Filters
34 mm
37 mm
39 mm
40,5 mm
43 mm
46 mm
49 mm
52 mm
55 mm
58 mm
62 mm
67 mm
72 mm
77 mm
82 mm
86 mm
95 mm
„Digital pro UV MC“ UV Filters
NEW
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
ø
18949
18952
18955
18958
18962
18967
18972
18977
18982
-
„Snap-On” Lens Caps
Reliable hold by clamp-on design. Includes
loss protection. Can also be used with lens
hood mounted.
6845: ø 37 mm 6835: ø 55 mm 6840: ø 77 mm
6847: ø 43 mm 6836: ø 58 mm 6841: ø 82 mm
6848: ø 46 mm 6837: ø 62 mm 6842: ø 86 mm
6833: ø 49 mm 6838: ø 67 mm
6834: ø 52 mm 6839: ø 72 mm
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 11
You Should
Have This!
ProDisk
Combination of white balance, grey card and colour
reference in a slim, foldable plastic housing. Colour
card and grey card located in lower and upper
covers. Translucent, white balance filter with
special surface pattern in centre.
Includes neck strap.
6602: ProDisk II
6601: ProDisk mini
White balance filter
White balance filter
for lenses up to 9 cm
for lenses up to 6 cm
(3.5 in.) diameter.
(2.4 in.) diameter.
Dimensions
Dimensions
(folded down):
(folded down):
145 x 101 x 11 mm
103 x 73 x 10 mm
(5.7 x 4.0 x 0.4 in.),
(4.1 x 2.9 x 0.4 in.),
weight: 75 g (2.6 oz.)
weight: 135 g (4.8 oz.)
„Vivicap“ White Balance Filter
Snap-on filter with specially designed prism structured surface
for white-balancing of digital cameras and camcorders. Easy
to use clamping mechanism provides for quick installation
and removal. Serves also as a lens cap and can also be attached when a lens hood is used.
6605:
6606:
6607:
6608:
ø
ø
ø
ø
52
55
58
62
mm
mm
mm
mm
6609: ø 67 mm
6610: ø 72 mm
6611: ø 77 mm
Digital Slide Duplicator
Suitable for digital cameras with filter thread. Connecting thread 52 mm.
With detachable achromatic macro lens. Full size copy can be obtained
using it with a lens with focal length of 80 – 120 mm, details with higher
focal length. Includes holder for two slides and 58-52 mm adapter ring.
Film Strip Carrier
For six 35mm negatives or unmounted
slides. For use with
Slide Duplicator
6506.
6506
6507
6506
11
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 12
Modern Tripods with
a History:
T
iltall tripods have been on the market since 66 years –
but this is another story, that can not be told now.
Here are the facts for today’s Tiltall tripods.
NEW
• 180 degrees reversible legs for reduced pack size
• One tripod leg is detachable and can be converted to
a monopod by adding the removable center column.
• Reversible center column for macro shots. Center
column can also be removed for close-to-ground
level-setting.
• Four-section tripod legs with anti-twist protection
and twist locks for fast and easy operation.
• Spread angle of legs can be individually adjusted
and locked in three positions, covered ratchet
toothing with release button.
• Extendable center column with anti-twist device, twist lock and spring
loaded hook.
• Rubber feet with retractable metal spikes made from stainless steel.
• 1/4” – 3/8” interchangeable thread.
• Eight-layer carbon fibre, reduced weight, very good vibration absorption
(6069-6071) or aircraft aluminum respectively.
• Padded carrying case with adjustable and detachable shoulder strap,
carry handle and inside tool pocket.
• All tripod legs with leg warmers for isolation against cold.
Code no.
Type
Material
Tube-ø, max. (mm)
Max. height (cm)
Min. height (cm)
Pack size (cm)
Monopod height
Weight (kg)
Max. load (kg)
Recommended
ball head
6066
6067
6068
TE-224 TE-254 TE-284
Alu
Alu
Alu
22
25,5
29
140
147
162
14
14
15
40
43
47
65-142 71-152 78-169
1,1
1,4
1,8
8
8
12
BH-10 BH-20 BH-30
(6001) (6002) (6003)
6069
6070
6071
TC-224 TC-254 TC-284
Carbon Carbon Carbon
22
25,5
29
140
147
162
14
14
15
40
43
47
65-142 71-152 78-169
0,9
1,1
1,4
8
8
12
BH-10 BH-20 BH-30
(6001) (6002) (6003)
• Solid ball head with dovetail
clamping for quick-release plates.
• Quick-release plate with non-slip
surface, detachable slide-off protection and 1/4" D-ring screw
with coin slot.
• Two spirit levels for exact
alignment.
• Adjustable friction.
• 360 degree panning socket with blocking screw
and graduated scale.
• 3/8” tripod bush.
• Quick-release plates are also available individually.
Code no.
6001
Typ
BH-10
Ball diameter (mm)
30
Socket diam. (mm)
45
Height (mm)
92
Weight (g)
360
Max. load (kg)
8
12
6002
BH-20
36
51
98
440
10
6003
BH-30
44
60
107
570
12
Monopod
NEW
NEW
Tiltall Ball Heads
Compact and sturdy Tiltall monopod
made from aircraft aluminum.
Quick set-up by simultaneous opening of all three twist locks. Four
sections with anti-twist protection,
rubber foot with retractable metal
spike, foam rubber leg warmer protects against cold, convenient wrist
strap. Carry bag included.
Max. height: 160 cm
Pack size / min. height: 51 cm
Exchangeable threads: B 1/4 / B 3/8
Max. load: 11 kg
Code no. 6060
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 13
Fits All!
5534
NEW
Camera Mounting Platform
For precise camera adjustment for close-up, macro
and copying.
6017
6018
Pro Ball-and-Socket Head
With adjustable friction brake and
panorama base. Weight 650 g
(1.4 lbs.), height 123 mm (4.8 in.),
base diameter 56 mm (2.2 in.),
max. load 8 kg (17.6 lbs.).
Ball-and-Socket Head
Rotating panorama base.
Weight 300 g (10.6 oz.),
height 98 mm (3.9 in.), base
diameter 45 mm (1.8 in.),
max. load 4 kg (8.8 lbs.).
Ball-and Socket Head
Weight 110 g (3.9 oz.),
height 67 mm (2.6 in.),
base diameter 30 mm
(1.2 in.), max. load
2 kg (4.4 lbs.).
Quick-Release Connector
For quick mounting of
camera on tripod.
6013
Ball-and Socket Head
Weight 45 g (1.6 oz.),
height 50 mm (2 in.),
base diameter 24 mm
(1 in.), max. load 1 kg
(2.2 lbs.).
NEW
6011
6020
6024
Quick Release Connector
Plate
Fits 6020.
High-Level Meeting: Spirit Levels:
Analogue and Digital
6386
Spirit Level
with circular bubble,
self-adhesive. Can also
be screwed on.
6385
Spirit Level
One level each for vertical
and horizontal shooting
position. With mounting
shoe and 1/4” tripod bush.
6380
Duplex Screw-In
Spirit Level
Mounts in between
camera and tripod.
6387
Duplex Spirit Level
With twin levels and
mounting feet for landscape and portrait position.
Action Level
Digital spirit levels for use in portrait and landscape formats using
LEDs of different colors for indication. Especially useful for levelling
the camera at night, at a high position for over-head shots and in all
situations where a traditional spirit level would be difficult or impossible to see.
Brightness and sensitivity can be adjusted (from +/- 0.2°). Fits into standard hot shoe.
Supplied with additional magnetic pedestal for attaching on other flat surfaces.
Action Level Sound
With beep sounds for indication (can be switched
off). Compact design.
Does not interfere with
most camera´s pop-up
flash. 32 x 25 x 17 mm
(1.3 x 1 x 0.7 in.), weighs
only 5 grams.
6383
Action Level Cross
Cross indicator with 13
LEDs for simultaneous
two-dimensional indication. Additional 7 LED side
level indicator. Diameter
approx. 32 mm (1.3 in.),
weighs only 6 grams.
6378
13
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 14
Quik Pod - for Snapshots at Arm’s
Y
Length
our arm is too short? Quik Pod can help – no matter whether you will take a picture of yourself or
just want to shoot over the head of crowds. Quik Pod
will give your arm 46 cm (18 in.) of additional length,
will convert to a table top tripod and is ready to become your all-time companion.
Quik Pod is an extendable hand-held
tripod for cameras and camcorders. It
has a lockable ball head, a camera support with 1/4” tripod thread and a small
mirror showing you roughly what the
camera will see. It is easy to extend and
to retract.
Specifications
Length (extended): approx.
46 cm (18 in.) (retracted):
approx. 19 cm (7.5 in.)
Weight: approx. 100 g
(3.5 oz.)
Max. load: 450 g (16 oz.)
Kit includes pocket clip,
hiking clip, wrist strap, tripod
legs and carrying bag.
Code no. 6046
Quik Pod DSLR
• Made of high quality polycarbonate and aluminium • Extends up to
135 cm (53 in.) • For digital SLRs,
camcorder and lights • Retracted
size 47 cm (18.5 in.) • Weight 270 g
(8.9 oz.) • Quik release platform
• 1/4“ tripod thread • Max. load: 2 kg / 4.4 lbs.
(handheld tripod), 3.5 kg /7.7 lbs. (monopod).
Q
uik Pod DSLR is a handheld tripod
and a monopod. It extends
your reach even more
and takes a higher
load.
Kit includes monopod foot, belly pad, hiking clip, wrist
strap and carrying bag. Code no. 6047
Small – But
Going Strong
T
able top tripods are extremely
compact, but provide a firm
support.
DSLR Table Top Tripod
With three-section telescopic
legs and extendable center
column. 3-way pan head
with tiltable camera platform.
Height: 18-30 cm (7.1-11.8 in.),
folded length: 21 cm (8.3 in.).
6045
6043
6044
Multi-Level Table Top Tripod
Height continuously adjustable, three-section telescopic
feet, folds-down to compact
size. Ball head with locking
screw (6043) or with pan and
tilt head (6044).
Small Table Top Tripod
Extendable telescopic feet,
folds down flat. Ball and
socket head with locking
screw. Titanium coloured.
6037
14
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 15
Keep It Clean
702002
K
inetronics’ SpeckGRABBER Pro SGP (702002) removes individual
particles of dust and dirt from sensitive surfaces without damaging
them. Suitable for cleaning camera sensors (manufacturers instructions
must be followed), SLR mirrors, lenses and oculars, films, slides, etc. With
rubber-coated handle.
702004
702001
702005
SpeckGRABBER Pro Kit SGL
With integrated mini lamp,
three tips, cleaning solution
and anti-static cloth in
robust box.
SpeckGRABBER Pro Kit SGK
With SpeckGRABBER Pro
handle, three tips, cleaning
solution and anti-static
cloth in robust box.
706518
700001
Anti-Static Micro-Fibre Cloth
Specially conductive fibres,
700001 for dry cleaning,
706518 for wet cleaning.
707025
ECK Optical Cleaning Set
With anti-static cloth 13 x
14.5 cm (5.1 x 5.7 in.) and
6 ml (0.2 oz.) of cleaning
solution in a drop bottle.
700010
6309/10
700030
Anti-Static-Brushes
For sensitive surfaces.
700010: width 10 mm
700020: width 20 mm
700030: width 30 mm
707001
Outdoor Photographer's
Optical Cleaning Kit
Cleaning solution, antistatic cloth and brush,
SpeckGRABBER SG, Swabs.
„Typhoon Blower“
Blower Bellows
„Mini“ Blower
Bellows
6314
Blower Brush
Flat brush with large
rubber blower bulb.
Display and Optics Cleaning Kit
Pump spray and a micro
fibre cleaning cloth.
6663
Cleaning Set
Cleaning pen and micro
fibre cloth.
6305
6308
6301
Lens Brush
In plastic tube. Lipstick
twist mechanism.
6662
Large rubber bulb for strong
blowing effect. Rugged front
air nozzle, rear air duct valve.
Easy to handle. Environmentfriendly. Cleaning brush included. 6316
Compact rubber bulb. Fine,
short front air nozzle, rear
air duct valve. Easy to handle.
SpeckGRABBER SG
With standard handle.
"Clear Gear" Compressed Air
For touch-free dust
removal.
6328
Micro Fibre Cleaning Cloth
Fluff-free, grease-absorbing. Hemmed edges.
6699
Cleaning Set
Lens cleaning paper, cleaning
leather and blower brush
6697
Cleaning Set
Optical-glass cleaning fluid,
cleaning paper and blower
brush.
15
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:32 Seite 16
Portable Protection
„EasyLoader“
Camera Bag
„SmartLoader“
Camera Bag
With accessory pockets inside the outer lid and
on both sides. Internal lid can be connected
via a Velcro closure. Spacious front pocket with
organizer pouches and zipper. This camera bag
allows quick access, as the top opens away
from the body and stays open in a fixed position. With carrying handle and detachable,
adjustable and padded shoulder strap. Inside
dimensions: 15.5 x 15 x 10 cm (6.1 x 5.9 x 3.9
in.)
Lid opens away from the body and stays
open in a fixed position thus providing
quick access to the camera. Three mesh
pockets. Zipped front pocket with overlapping cover and inside card pocket.
Main compartment with divider.
Padded handle. Adjustable carrying
strap and shoulder pad. Belt loops.
8825
SmartLoader S, for megazoom
cameras and camcorders.
Inside dimensions (WxHxD):
10 x 13 x 8 cm (3.9 x 5.1 x 3.1 in.).
8826
SmartLoader M, for bridge cameras,
mirror-less interchangeable-lens cameras
and camcorders. Inside dimensions (WxHxD):
16 x 10 x 9 cm (6.3 x 3.9 x 3.5 in.).
8827
8827
SmartLoader L, for DSLR cameras. With lens support divider.
Inside dimensions (WxHxD): 17.5 x 13 x 10 cm (6.9 x 5.1 x 3.9 in.).
Battery Box
Memory Card Box
Slim plastic box for secure storage of
two SD or CompactFlash memory cards.
Shaped rubber insert. Protects against
shock, dirt and moisture. With secure
latch.
For 4 AA or
AAA batteries.
2 pieces. Stackable.
Color: grey and blue.
„digiShell“ Hard Shell
Camera Bags
Compact camera bags with hard shell exterior
and two-way zipper. Interior accessory pocket.
With belt loop, detachable carrying strap and
snap hook.
digiShell 1,
9.5 x 6 x 2.5 cm*
(3.7 x 2.4 x 1 in.)
digiShell 2,
10.5 x 6.5 x 3.3 cm*
(4.1 x 2.6 x 1.3 in.)
8281 black
8282 blue
8283 grey
8287 black
8288 blue
8289 grey
6495:
grey
NEW
8818
6496:
neon
yellow
6497
*inside dimensions (WxHxD)
6494
Memory Card Box
Flat metal box for three SD/
Multimedia / xD / Memory
Stick cards. Dimensions:
approx. 9.5 x 6 x 0.5 cm
(3.7 x 2.4 x 0.2 in.)
16
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:33 Seite 17
Handy Stuff
Photo Functional Gloves
Half finger gloves with mitten cover
and thumb cover provide for perfect
mobility, secure grip and ideal protection against cold. Mitten and
thumb cover can be folded back
and fastened with a Velcro strip.
Made of breathable, skin-friendly
fleece with anti-slip coating.
6370:
6372:
6374:
6376:
Size
Size
Size
Size
M
L
XL
XXL
6701: „Profi“ professional
camera hand strap
6702: „Profi 2.0“ professional camera hand strap
with additional safeguard belt around the
wrist for more safety
and stability.
NEW
6702
Professional Camera Hand Strap
Suitable for larger compacts,
(D)SLRs and system cameras. Soft
padded genuine leather hand
support with adjustable fixtures.
Camera mounting plate with tripod thread and foldable legs providing a secure stand when put
on table or floor.
NEW
6701
6737 black
6752 black
6738 red
6753 red
6739 olive-green
6754 olive-green
6740 brown
6755 brown
6735/6745
Carrying Straps and Wrist Straps
For compacts with one fastening eye. Also suitable for
mobile phones, MP3 players etc.
6737-40 Wrist Strap, genuine leather, Length: approx. 22 cm (8.7 in.)
6752-55 Carrying Strap, genuine leather,
Length: approx. 46 cm (18.1 in.)
6735
6745
Silver chain with clear plastic cover
Wrist Strap, Length: approx. 24 cm (9.4 in.)
Neck Chain, Length: approx. 46 cm (18.1 in.)
6736
6746
Soft elastic textile fabric
Wrist Strap, Length: approx. 26 cm (10.2 in.)
Carrying Strap, Length: approx. 49 cm (19.3 in.)
6736/6746
6747 silver/black
6748 silver/red
6747/48 Reflective Carrying Strap, with quick release lock,
Length: approx. 47 cm (18.5 in.)
6742
6742
Neoprene Camera Strap. High carrying comfort, quick release
lock for camera, Length: approx. 53 cm (20.9 in.)
Camera Shoulder Straps
For cameras with two fastening eyes. Length adjustable.
6780
Neoprene strap. Detachable end sections, can be reconnected to serve as a wrist strap. Length: max. 140 cm
(55.1 in.).
6791
Professional camera strap. Heavy-duty strap with nonslip protection. Length: approx. 110 cm (43.3 in.).
6780
6791
6778/79 „Adventure“ camera strap. Heavy-duty strap with nonslip protection. Detachable end sections can be reconnected to serve as a wrist strap. Length: max. 145 cm
(57.1 in.)
6778: Denim
6778
6779: Khaki
NEW
NEW
6779
17
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:33 Seite 18
Light – Compactly Sized
V
ideo needs light – permanently – that is continuous light. Nowadays digital
cameras can shoot videos. Small add-on lights, portable and battery-powered,
provide adequate illumination in a close-up range when lighting conditions are bad.
StarCluster and Co. use up-to-date LED technology, provide energy-saving
operation with long-life light sources and can be mounted
on all camcorders and movie-making digital camera with
standard accessory shoe.
Kaiser StarCluster
This compact soft light works for both, stills and video
filming and is perfect for use with D-SLRs and CSCs.
It features 96 continuously dimmable white LEDs on a
panel of 8.5 x 6 cm (3.3 x 2.4 in.) and provides
approx. 600 lux of illumination at one meter (3 feet)
and 60° angle of radiation (half-value angle). The
colour temperature of 5600 Kelvin relates to daylight.
It is powered by five AA batteries fitted in the rear battery compartment or by a Canon LP-E6 battery, that
can be placed in an adapter on the battery cover. The
LP-E6 is the standard battery for Canon’s 5D Mk II, 7D
and 60D. There is also a connector for a mains adaptor (optional). The light comes with an diffusion screen
and an artificial light filter (3200 Kelvin) which attach
to the front of the light by magnetic attachments. The
package also contains a swivel joint for mounting to a
standard hot shoe.
3270
Specifications:
Operating time with fully charged
batteries: up to 2.5 hours
Colour temperature: 5600 Kelvin
Operating voltage: 5.8 - 16.8 V
Dimensions: 127 x 77 x 45 mm (5 x 3 x 1.8 in.)
Weight: 195 g / 6.9 oz. (without batteries)
Tripod thread: A 1/4
Accessories: 3271 mains adapter
Several lights can be
combined side by side
or on top of each other
using a clever catching
system.
18
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:33 Seite 19
More Light: Video Lights
with Three-chip-LEDs
3 Chip LEDs are LEDs that only require the space
of a single “common” LED. This allows for a particularly compact design, but makes high demands
on an effective heat dissipation. Technical characteristics of the L2S-5K and L10S-5K lights are similar with respect to lighting, otherwise they have differing concepts.
The similarities
•
•
•
•
•
•
•
•
•
7.5 x 5 cm (3 x 2 in.) panel with 96 three-chip LEDs.
Color temperature: 5400 Kelvin.
Continuously dimmable.
Extremely wide angle of radiation: 110 degrees (half-value
angle).
Electronically stabilized light output keeping the illuminance
constant when supply voltage goes down.
Automatic shutdown when batteries are exhausted to prevent
deep discharge and battery defects.
Rear LCD displays dimmer position.
Battery compartment for standard Sony L-type battery.
Connection for external power source.
Illuminance: 380 lux at 3 ft. (1 m) and 110 degrees angle of
radiation.
1/4" tripod thread.
Honey comb filter for more directional light, 7.2 V / 2200
mAh lithium-ion-battery, charger, swivel/tilt joint for mounting the light to the accessory shoe and Sony/Minolta hot
shoe adapter are supplied with the light.
Mains adapter (3263) is an optional accessory.
3260
The differences
L2S-5K LED Video Light
• Built-in blower cooling.
• Blower speed controlled automatically
and temperature-dependent.
• Blower speed can be controlled manually
in five levels.
• Rear LCD displays blower speed level.
• Modular design: LED panel can be removed and exchanged for a 3200 Kelvin
panel (3261, optional accessory).
• Operating time: up to 45 minutes
(depends on battery condition).
• Weight without battery: approx. 200 g
(0.4 lbs).
• Dimensions of light head: 93 x 75 x
43 mm (3.7 x 3 x 1.7 in.)
• Code no. 3260
3248
NEW
•
•
•
•
3255
L10S-5K LED Video Light
• Convective cooling via large built-in heat sink.
• Integrated LED panel.
• Operating time: up to 50 minutes
(depends on battery condition).
• Weight without battery: approx. 190 g (0.4 lbs).
• Dimensions of light head: 93 x 83 x 25 mm
(3.7 x 3.3 x 1 in.)
• Code no. 3255
3261
19
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:34 Seite 20
Even More Light . . .
R 48 Ring Light
providing shadowless illumination for macro work
and close-up shots. Colour temperature is at 6000
Kelvin. Mounting on the lens is easy as the unit slides
and locks on the suitable adapter ring. Six adapter
rings from 49 to 67 mm are included. The light is
powered by two AA rechargeable batteries (not included) housed in a separate battery compartment or by
a mains adapter 3271 (optional accessory). The 24
LEDs on the left or on the right can be switched on
separately.
Specifications:
Minimum working distance: 3 cm (1.2 in.)
Operating time with 2 NiMH rechargeables:
approx. 2.5 hours
Colour temperature: 6000 K +/- 500 K
Dimensions: Ring light: 11 x 13 x 3 cm
(4.3 x 5.1 x 1.2 in.)
Battery compartment: 5 x 9 x 5 cm
(2 x 3.5 x 2 in.)
Weight: Ring light: approx. 140 g (4.9 oz.)
Battery compartment: approx. 55 g
(1.9 oz.)
3248
KR 90 Ring Light
Professional ring light with 30 three-chip high performance LEDs. The light intensity corresponds to that of a
30 watt fluorescent light. extremely wide angle of radiation on 110°. A rechargeable lithium-ion battery and the
complete circuitry are integrated in the main body made
of highly durable duralumin. The light can be dimmed
down to 50 %. The basic connection thread is 77 mm,
several adapter rings from 55 to 72 mm are included. Light
can also be mounted on a tripod. No light loss due to battery consumption. A quick charger is included. Tripod
thread: 1/4"
Specifications:
Min. working distance: 3 cm (1.2 in.)
Operating time (continuous lighting and fully
charged battery): 2 hours
Battery capacity: 1500 mAh
Colour temperature: 5500 K +/- 500 K
Dimensions: ø 142 x 34 mm (ø 5.6 x 1.3 in.)
Weight: 300 g /10.6 oz.
3250
20
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:34 Seite 21
. . . and Useful Things
Camlight Nova
Compact camcorder light with 20 watt
halogen lamp. Specially designed reflector for even illumination. 3200 K colour
temperature. Slide-in foot for upright or
horizontal mounting, with blocking
screw and 1/4“ tripod thread. Powered
by NiMH rechargeables (5 x AA, not included). Operating time up to 40 minutes. Battery compartment inside light
housing. On/Off switch. Incl. 1108 Universal Accessory Bracket.
Dimensions: (WxHxD): 55 x 98 x 72
mm (2.2 x 3.9 x 2.8 in.)
Weight: 110 g (without batteries)
Hand Grip
For lighting units,
cameras, etc.
With foam shell and
grip shape. Connection
thread 1/4" and tripod
thread 1/4".
Includes snap-hook
with key-ring and fixture for tripod thread.
Height: approx. 120
mm (4.7 in.)
3272
3288
Accessory
Bracket
Universal Accessory Bracket
Angle piece
with accessory
shoe
Plug-in bracket with
detachable anti-twist
protection and tripod
adapter screw
1108
For raised mounting of a light,
microphone etc. next to the camcorder lens. Folding. With antitwist pin
for exact right-angled mounting on
camcorder. Widened three-point rest
on bottom side. Camera with mounted bracket stands firmly on all flat
surfaces.
NEW
Light metal bracket for
mounting two accessories with tripod
thread on a tripod, hand grip or swivel
joint. Especially suitable for attaching
two „StarCluster“ LED lights.
For camcorders and digital
SLRs/CVCs and compacts.
Allows for right side or left
side mounting of accessories such as lights or microphones. The bracket can be
aligned to the camera in
different ways.
Accessory
Bracket
3273
Two relocatable 1/4" tripod screws with
soft washers. Center placed 1/4" tripod
bush.
Length: approx.
15.5 cm (6.1")
Width: approx.
2.5 cm (1.0")
Mounting Foot
6040
With accessory shoe for lighting units, flashguns etc. Tripod thread 1/4" for attachment
on tripods. Dimensions: 94 x 63 x 11 mm
(3.7 x 2.5 x 0.4 in.)
1/4“ tripod thread.
93296
21
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:34 Seite 22
Enough Light
T
he lights of the „studiolight“ line are absolutely
suitable for the small home studio. They are compact, sturdy and can be combined with various light
modelling accessories. They are easy to use, and the
lighting situation is the same for
set-up and shooting.
3157
„studiolight H“ Lighting Unit
1000 watt studio light with dimmer and built-in blower cooling. Front section with bayonet attachment for accessories. Swivel joint and umbrella
mount. Supplied with 1000 watt halogen lamp, safety glass bulb dome,
lamp protector and 180 mm (7 in.) metal reflector. Code no. 3152
3154
„studiolight H Kit“ Lighting Kit
Comprised of 2 „studiolight H“ lighting units (3152), 2 heat-resistant soft
boxes 60 x 60 cm (23.5 x 23.5 in.) and 2 air cushioned light stands, 70230 cm (27.5 - 90.5 in.). In carrying bag 94 x 30 x 27 cm (37 x 11.8 x
10.6 in.). Code no. 3155
„studiolight H Trio“ Lighting Kit
Comprised of 3 „studiolight H“ lighting units (3152), 2 heat-resistant soft
boxes 60 x 60 cm (23.5 x 23.5 in.) and 3 air cushioned light stands (setting
height 70-230 cm / 27.5-90.5 in.). Set comes in a rugged trolley with plastic wheels and bumpers, telescopic handle, two carrying handles and
adjustable carrying strap with shoulder pod for easy carrying and safe storage. Customisable interior with removable dividers. Outside dimensions:
88 x 46 x 35 cm (34.6 x 18.1 x 13.8 in.). Code no. 3157
„studiolight C“ Lighting Unit
With screw-in fixture E 27 for photofloods up to 500 watts. Built-in blower cooling. Front section with bajonet attachment for accessories, swivel joint and umbrella mount. Includes 150 W lamp, lamp protector,
and 180 mm (7 in.) metal reflector. Code no. 3150
„studiolight C Kit“ Lighting Kit
Comprised of 2 „studiolight C“ lighting units (3150), 1 reflector umbrella,
silver, 100 cm (39.5 in.), 1 transmitted light umbrella, 100 cm (39.5 in.),
2 air cushioned light stands, 70 - 230 cm (27.5 - 90.5 in.). In carrying bag
94 x 30 x 27 cm (37 x 11.8 x 10.6 in.). Code no. 3154
Additional accessories for „studiolight H”, „studiolight C” and „studiolight 1010”
„studiolight C Trio“ Lighting Kit
3160
3177-78
Soft Boxes
Heat-resistant, with ventilation flaps. 60 x 60 cm / 23.5 x
23.5 in. (3177) and 100 x 100
cm / 39.5 x 39.5 in. (3178).
22
3159
Reflectors
3159: narrow beam, 3160:
wide beam, with deflector.
3170
Background Reflector
Rotatable, position lockable.
Comprised of 3 „studiolight C“ lighting units
(3150), 1 reflector umbrella, silver (100 cm / 39.5
in. diameter), 1 studio umbrella, white (100 cm
diameter) and 3 air cushioned light stands (setting
height 70-230 cm / 27.5-90.5 in.). Set comes in a
rugged trolley with plastic wheels and bumpers,
telescopic handle, two carrying handles and adjustable carrying strap with shoulder pod for easy
carrying and safe storage. Customisable interior
with removable dividers. Outside dimensions: 88 x
46 x 35 cm (34.6 x 18.1 x 13.8 in.). Code no. 3156
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:34 Seite 23
„studiolight 1010” Halogen Studio Lighting Unit
With 1000 Watt halogen lamp and protective lamp cover made
of safety glass. Brightness can be adjusted via step-up/step-down
buttons, two-digit display. Light can be switched from set brightness to full brightness and back. Low-noise blower cooling for
unlimited operation in every position. Bayonet attachment with
quick locking device for accessories (reflectors, soft boxes), swivel joint with locking lever, umbrella mount. Mounts on suitable tripods/stands with 16 mm standard spigot.
Includes halogen lamp, exchangeable
reflector (180 mm / 7 in. diameter)
and protective lamp cover.
Code no. 3164
3164
Light Stands
Sturdy matt black light stands with 1/4" / 3/8” reversible
thread pin, that can be attached either vertically or horizontally. The center column is air cushioned
and thus provides secure use.
„studiolight 1010 Kit” Lighting Kit
Comprised of 2 „studiolight 1010“ halogen lighting units (3164),
2 heat resistant soft boxes 60 x 90 cm (23.6 x 35.4 in.) and 2 aircushioned light stands (setting height 65-225 cm / 25.5-88.5 in.)
in a sturdy carrying case. Outside dimensions: 73 x 28 x 44 cm
(28.7 x 11 x 17.3 in.). Code no. 3165
300 W Portable Lighting Kit
Complete light-stand-umbrella combination.
Comprises „videolight 8 S“ 300 W safety lighting unit (93307), light stand (5031), joint with
umbrella mount (5041), and white studio
umbrella (3080). In carrying bag with handle
and adjustable shoulder strap.
3195: „Small“ Light Stand.
Four section center column. Setting height:
approx. 75 - 230 cm (29.5 – 90.6 in.)
Length closed: approx. 70 cm (27.6 in.)
Max. load: 3 kg (6.6 lbs.)
Weight: approx. 1650 g (3.6 lbs.)
NEW
3165
3196: „Large“ Light Stand.
Three section center column
Setting height: approx. 110 290 cm (43.3 - 114.2 in.)
Length closed: approx.
105 cm (41.3 in.)
Max. load: 10 kg (22 lbs.)
Weight: approx.
2200 g (4.9 lbs.)
1000 W Portable Lighting Kit
3047
3049
Complete light-stand-umbrella combination.
Comprises „videolight 6“ 1000 W safety lighting unit (93304), light stand (5031), joint with
umbrella mount (5041) and white studio
umbrella (3080). In carrying bag with handle
and adjustable shoulder strap.
3196
3195
23
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:34 Seite 24
Desktop Studios
5911
D
esktop studios can
be set up on your desk, on your
dining or living room table or wherever you like to
take your pictures. They are most suitable for small object
photography resulting in pictures you may need for your website, for
internet auctions, for online shops or for documentation of valuables or
collectables.
Studio-out-of-the-Box
Compact foldable studio for digital photography. Comprises table, background support, background material and trapeze stand for cameras up to
500 g (1.1 lbs.). On the trapeze stand the camera can be positioned in many
different positions and at different heights and distances from the object. The
camera platform is pivotable and relocatable and can be locked in a vertical
shooting position. Table can be extended up to 30 cm (11.8 in.), background
can be positioned at different heights. Background roll included, approx. 40
cm (15.7 in.) wide and 130 cm (4.25 ft.) long. To support wider backgrounds
a clip-on rail is included. Dimensions (folded): 59 x 6 x 33 cm (23.2 x 2.4 x
13 in.). Supplied with carrying box: 60,5 x 10 x 48,5 (23.8 x 3.9 x 19.1 in.).
A suitable Lighting Set (2 x 8 W, 4000 K) is available as an accessory (5914).
5876
5875
5883
"Open Tube 1" Shooting Table
The evenly curved background ("open tube" outline)
improves the distribution of light on the subject.
"ConCave" Background
5884
This shooting table is assembled by the user. The
background made of flexible plastic material is
inserted into the assembled table and fixed by
Velcro fittings. Dimensions 77 x 60 x 85 cm (30.3 x 23.6 x 33.5 in.). Side
frames of the table provide attachment points for one or more lighting modules in vertical or horizontal position.
Suitable lighting module, high frequency operated: 5884 (36 W, 5400 K).
24
Flexible plastic plate, can be bent into the desired shape and then be fixed
by means of two ”beads” and choice of respective holes. Dimensions of flat
plate: approx. 60 x 30 cm (23.6 x 11.8 in.).
5875: opaque plate for shooting with reflected light
5876: transparent plate, for shooting with reflected light and backlight
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:35 Seite 25
5891
5863
„Dome-Studio“ Light Tent
„Cube-Studio“ Light Tent
White translucent surfaces provide even and soft illumination.
Umbrella-type construction makes set-up and fold-down easy.
Equipped with „snow flaps“ for outdoor use to prevent it from
blowing away in strong winds.
This cube-shaped light tent allows for even and soft illumination. Detachable front
cover with slot for camera lens. Easy to set up, folds up automatically. Highly flexible frame, can be folded down to compact size. Includes reversible textile backdrops white/grey and black/blue and carrying pouch with wrist strap.
Supplied with reversible textile background (blue / grey) and protective cover with carrying straps.
5893: 50 x 50 x 50 cm (19.5 x 19.5 x 19.5 in.)
5894: 90 x 90 x 90 cm (35.5 x 35.5 x 35.5 in.)
5891: Floor size: 62x62 cm (24.5x24.5 in.), height: 51 cm (20 in.)
5892: Floor size: 75x75 cm (29.5x29.5 in.), height: 65 cm (25.5 in.)
Table-Top-Studio digital
Desktop Lighting
5861: Desktop Lighting Kit 1: reflector light, consisting of lamp holder 5860, reflector (27 cm / 10.6 in. diameter) with removable diffusing cover and light stand
5859. Without lamp.
5862: Desktop Lighting Kit 2, comprises two sets 5861
5860: Lamp Holder with E 27 ceramic socket, for photofloods up to 250 watts. With ON/OFF switch and swivel joint with umbrella mount. Mounts on suitable tripods/stands with 16 mm standard spigot. Mains lead
approx. 3,80 m (12.5 ft). 1 piece. Without lamp and
reflector.
5858: Desktop Light Stand, height 22-38 cm (8.7-15 in.)
5859: Desktop Light Stand, height 35-70 cm (13.8-27.6 in.)
3110: Energy Saving Lamp, 25 W, 6400 K, E27
5860
Desktop Shooting Kit
5994/96
Comprehensive Kit for object photography. Consists of a „Cube-Studio“ light tent
for even and soft light distribution and two reflector lights on desktop stands
(Desktop Lighting Kit 2, code no. 5862).
Complete desktop studio, consisting of Small Product Table 5931
and lighting Unit. Product table with white translucent concave
shaped acrylic background. Required desk space approx. 50 x 50
cm (20 x 20 in.). Lighting unit consists of two small soft lights for
even and smooth illumination and holding rods with multiple orientation possibilities, screw-on clamps for attachment.
NEW
Table-Top-Studio digital SN-HF (5993) with RB 218N HF daylight
lighting system (5464) with two compact fluorescents, 18 W
each, 5400 K, CRI = 90 - 100. Table-Top-Studio digital SN-HF
plus (5994) with additional camera clamp holder comprising a
swan-neck arm, a ball head and a desk clamp.
Also available with RB 5020 DS LED daylight lighting system
(5465) with 192 white high-CRI LEDs on each side: TableTop-Studio digital LED (5995) and Table-Top-Studio digital
LED plus (5996). Lights can be dimmed individually or synchronized, 5600 K, CRI > 85, angle of radiation: 60°.
5863: with Cube-Studio 50 x 50 x 50 cm (19.5 x 19.5 x 19.5 in.) (5893)
5864: with Cube-Studio 90 x 90 x 90 cm (35.5 x 35.5 x 35.5 in.) (5894)
Mini Magic Arm
Universal Clamp
To mount and individually align cameras, lights and accessories. 1/4” mounting thread. Central locking knob.
Comes with multiple mounting adapters. Maximum load in horizontal position: 1 kg (2.2 lbs.)
Attaches on tubes and boards. Span
width max. 42 mm (1.7 in.). Two threaded holes 1/4” and 3/8”. Includes spigot
with 1/4” and 3/8” threaded pins.
5055: Mini Magic Arm 1, total
length approx. 18 cm (7.1 in.)
5056: Mini Magic Arm 2, total
length approx. 29 cm (11.4 in.)
5023
More accessories
available: Holding
Frame (5934) and
„prolite basic 2“
Soft Light Source
(2425)
25
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:35 Seite 26
For Everything that
Won’t Fit Your Scanner!
J
ust in case something would not fit on your scanner – too big, too
bulky, too wide etc. – here is where it belongs. Combine these stands
with your camera and enjoy a perfect image capturing tool for all
“awkward” items that need to be photographed from above: the vintage LP cover, grandfather’s precious pocket watch or
just a section out of a large-sized road map.
Suitable lights – now also available with LEDs –
for even illumination, can easily be added.
RS 2 XA Camera Stand
NEW
Non-reflective matt grey baseboard with printed fine grid and cm/inch
scale. Matt-black anodised aluminium-section tube column with
cm/inch scale. Hand-cranked height adjustment. Horizontally adjustable camera arm. 1/4” mounting thread. Baseboard (WxHxD): approx.
40 x 2.5 x 50 cm (15.7 x 1 x 19.7 in.). Column height: approx. 76 cm
(30 in.). Maximum load: 1.5 kg (3.3 lbs.). Code no. 5411
RB 5020 DS LED Lighting Unit
With two small light banks, each
with 192 white high-CRI LEDs,
5600 K, angle of radiation: 60°.
Lights can be dimmed individually
or synchronized. Lights are tiltable
and adjustable in height. Angle of
vertical arms adjustable by lock
joint. Mounted with strong diecast clamp bases. Code no. 5465
RB 218N HF Lighting Unit
With two small light banks with interior reflector and 18 W, 5400 K
daylight fluorescent lamp. High frequency operating system. Lights are
tiltable and adjustable in height.
Angle of vertical arms adjustable by
lock joint. Mounted with strong diecast clamp bases. Code no. 5464
RB 2 Lighting Unit
With four tiltable and adjustable
reflectors on mounting arms which
are in turn tiltable and adjustable
in height. Lights can be switched
on separately. Suitable lamps:
4 x 150 W max. Supplied without
lamps. Code no. 5450
„reprokid“ Camera Stand
Super-compact camera stand for small, lightweight cameras.
Non-reflective, matt-black baseboard. Column with cm/inch
scale. Height-adjustable camera arm. 1/4” mounting thread. Baseboard
(WxHxD): 32 x 1.9 x 38 cm (12.6 x 0.7 x 15 in.). Column height:
59 cm (23.2 in.). Max. load: 1 kg (2.2 lbs.). Includes lighting unit with
two E 27 screw-in mounts for lamps up to 250 Watt (supplied without
lamps). Code no. 5360
26
5411 with 5464
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:35 Seite 27
Pixel-Perfect Cut?
T
his is not required. But it would be nice to have all
the things “produced” on your printer with a neat
and precise cut. This makes a trimmer a PC peripheral –
it is very useful anyway.
Hand-Held
Magnifier
"easy cut" Safety Trimmer
Easy and safe cutting with ground circular
blade. Automatic paper clamping at cutting
position. Sturdy metal base board with scales,
format and angle markings.
4306: easy cut 1
cutting length: 32 cm (12.6 in.)
cutting thickness: 1.0 mm (0.04 in.)
4306-07
4307: easy cut 2
cutting length: 45 cm (17.7 in.)
cutting thickness: 0.8 mm (0.03 in.)
Stylish magnifier with
LED illumination.
Ergonomically
designed handle.
Lens edge mattfinished and
rounded off.
Batteries
included.
2368: Lens diameter: 65 mm (2.6 in.),
magnification: 3x
2369: Lens diameter: 80 mm (3.2 in.),
magnification: 2.2x
„hobby cut“ Safety Trimmer
Self-sharpening circular blade in closed plastic housing. Automatic paper clamping at
cutting position. Transparent paper-holding
strip. Two angle stops with cm and inch scales. Sturdy metal base board with printed fine
grid, scales, format and angle markings.
4314
4313
4313: hobby cut 3
Cutting length: 33 cm (13.0 in.),
Cutting thickness: 1 mm (0.04 in.)
4314: hobby cut 4
Cutting length: 46 cm (18.1 in.),
Cutting thickness: 1 mm (0.04 in.)
Pocket
Magnifier
Flat magnifier with LED
light. The LED lights
up when loupe
slides out.
Magnification: 2.4x
Lens size: 52/34
mm (2/1.3 in.)
2371
27
9084_DigitalZub_GB_1012_DigitalZub_9084_GB_0812 23.10.12 11:35 Seite 28
Worth Watching!
T
oday's digital cameras and flashguns
offer an almost endless number of
features and settings. Manuals covering
every detail require several hundred
pages.
To get the most out of your digital SLR or flashgun
quickly and easily you should try these video tutorials from Blue Crane Digital. All you need now is a
DVD player and about two hours of your time. Then
you will learn how to create the images you want.
You can closely follow settings and procedures,
basic knowledge will be explained and sample
images will show the results. All topics are arranged
in chapters, so you can move at your own pace and
return later to individual subjects.
These German language DVDs are produced specifically for the European market and are distributed
exclusively by Kaiser Fototechnik.
NEW
Nikon D800
Canon 5D Mark III, Grundlagen
NEW
Nikon D90, Erweiterte Funktionen
Canon 50D
Canon 500D
Canon 7D, Grundlagen
Perfekte Videos mit Canon-DSLR-Kameras
Canon 60D, Grundlagen
Nikon D7000
Nikon D3100
Canon 600D
Canon 1100D
Nikon D5100
NEW
Nikon Speedlight SB-910
Nikon Speedlight SB-700
Nikon Speedlight SB-900/800/600
Canon Speedlite 580 EX II / 430 EX II
Please note: Tutorials are
German language only.
USA
HP Marketing Corp.
P.O., Box 715
Pine Brook, NJ 07058
Tel (+1) 973-8089010
Fax (+1) 973-8089004
www.hpmarketingcorp.com
info@hpmarketingcorp.com
United Kingdom
Fotospeed Distribution
Jay House Ltd.
6B Park Lane Industrial Estate
Park Lane, Corsham
SN13 9LG
Tel (+44) 1249-714555
Fax (+44) 1249-714999
www.fotospeed.com
info@fotospeed.com
Canada
Nadel Enterprises Inc.
425 Attwell Drive
Rexdale, Ontario
M9W 5C4
Tel (+1) 416-7452622
Fax (+1) 416-7422616
www.nadel.ca
info@nadel.ca
New Zealand
Photo Warehouse Ltd.
175 GT North Rd.
Ponsonby-Auckland
Tel (+64) 9-3032148
Fax (+64) 9-3099721
www.photowarehouse.co.nz
enquiries@photowarehouse.co.nz
Kaiser Fototechnik GmbH & Co. KG
Im Krötenteich 2 · 74722 Buchen · Germany
Tel.: +49(0)6281 407- 0
Fax: +49(0)6281 40755
www.kaiser-fototechnik.de
info@kaiser-fototechnik.de
Rights reserved to make technical modifications. All specifications are approximate. Printed in Germany
6432:
6434:
6439:
6440:
6445:
6447:
6449:
6450:
6451:
6452:
6453:
6454:
6455:
6456:
6457:
6458:
6459:
09084.02.1012.5000
Available titles:
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
