2014 PRODUCT CATALOG
Gun Safes
Residential Safes
Luxury Fire & Burglary Safes
Cash Management, Deposit & Smart Safes
U.L. Listed High Security
Pharmacy & Narcotics Safes
Commercial Safes
Locks
Product
Catalog
2014
TABLE OF
CONTENTS
American Security Products Company has been
dedicated to manufacturing high quality, high
security safes since 1946. We offer an extensive
product line of over 400 standard models of
burglary and fire resistant safes in every insurance
classification from “B” rate to Underwriter’s
Laboratories TL-15 and TL-30.
AMSEC is the largest and most respected safe
manufacturer in the industry because:
• Our dedicated customer service
representatives care about you.
• Fully staffed service department
networked with thousands of factory
trained technicians.
• Our quality control department assures
that the products we build are the finest in
the industry.
• State-of-the-art computer controlled
manufacturing equipment helps us meet
demanding deadlines and keeps us on
the leading edge of technology.
• We are located in a major West Coast
distribution point with direct access to all
major domestic and international freight
services.
• We specialize in developing custom
safes to meet specific cash handling
requirements for banks, restaurants,
supermarkets, convenience stores and
many other industries.
• Our engineering and design department
is fully staffed and features the most
advanced CAD system for rapid creation
of sales drawings, design modifications
and precise manufacturing blue prints.
For superior asset protection there is only one
name you can trust for quality, service and
reliability…AMSEC.
AMSEC reserves the right to incorporate any
improvements and alter any specifications without prior
notice. AMSEC reserves the right to update products as
necessary, AMSEC is not responsible for typographical
errors.
WALL SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SQUARE DOOR FLOOR SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES . . . . . . . . . . . . . . . . . . . . .4
FLOOR SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
STAR® ROUND LIFT-OUT DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
STAR® RECTANGULAR BODY, ROUND LIFT-OUT DOOR . . . . . . . . . . . . . . . . .7
MAJOR® ROUND LIFT-OUT DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
UNDERCOUNTER SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
CASH MANAGEMENT SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
RETAIL MONEY MANAGER SAFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CASHWIZARD® BILL READER SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
DEPOSITORY SAFES
BWB SERIES - WIDE BODY CASH CONTROL . . . . . . . . . . . . . . . . . . . . . . . .12
DS SERIES - “B” RATE ROTARY AND FRONT LOADING . . . . . . . . . . . . . . . .13
MONEY MANAGER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
“B” RATE SECURITY SAFES
BWB SERIES AND MS1414 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
IMPORTED U.L. LISTED 1-HR FIRE SAFES . . . . . . . . . . . . . . . . . . . . .16
UL SERIES
U.L. LISTED 2-HOUR FIRE AND IMPACT SAFES . . . . . . . . . . . . . . . . . . . . . .17
BF® SERIES
U.L. LISTED FIRE RATED BURGLARY SAFES. . . . . . . . . . . . . . . . . . . . . . . .18
COMMERCIAL SECURITY SAFES
CSC SERIES COMPOSITE SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
GUN SAFES
NEW! HS SERIES - HIGH SECURITY RFX & RF MODELS . . . . . . . . . . . . . . .20
THE BF® SERIES GUN SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
SF SERIES - SIXTY MINUTE FIRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
FV SERIES - 45 MINUTE FIRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
TF SERIES - THIRTY MINUTE FIRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
DEFENSE VAULT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
VAULT DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
GUN SAFE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
HANDGUN SECURITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
STORAGE OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
HOME SECURITY
AM SERIES HOME SECURITY SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
ELECTRONIC SECURITY SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
ELECTRONIC SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
“B” AND “C” RATE SECURITY CHESTS
BLB AND BLC SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
DXE / DXF AND CDXE / CDXF U.L. LISTED
TL-15 & TL-30 MONEY CHESTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
ACF TL-30 SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
U.L. LISTED FIRE RATED MONEY CHEST . . . . . . . . . . . . . . . . . . . . . . . . . .32
U.L. LISTED FIRE RATED DEPOSITORY SAFE . . . . . . . . . . . . . . . . . . . . . . .33
AMVAULTX6 TL-30X6 HIGH SECURITY SAFE . . . . . . . . . . . . . . . . . . . . . . . .33
AMVAULT TL-30 AND TL-15
FIRE RATED COMPOSITE SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
SAFE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
PHARMACY / NARCOTICS SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
TELLER LOCKERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
CUSTOM SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
OPTIONAL EXTRAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
MECHANICAL LOCKS AND KEY LOCKS . . . . . . . . . . . . . . . . . . . . . . .39
ELECTRONIC LOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
ELECTRONIC LOCK COMPARISON CHART . . . . . . . . . . . . . . . . . . . . . . . . .40
AMSEC SAFEWIZARD® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
NEW! ESLAUDIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
ESL5 AND ESL15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
AMSEC ESLXL SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
SARGENT AND GREENLEAF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
KABA-MAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
LAGARD ELECTRONIC SAFE LOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
MATERIALS HANDLING EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . .45
MERCHANDISING / DISPLAYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
INDEX BY MODEL NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
WALL SAFES
WALL SAFES
AMSEC WALL SAFES are designed to provide hidden protection for documents and miscellaneous valuables. Each
wall safe is also designed for easy installation between 16" o/c wall studs. Pre-drilled anchor holes and a built-in flange
eliminates unnecessary replastering.
WEST2114
FEATURES:
WEST2114
• Heavy duty steel
body, 3/16” solid
steel door and
flange.
• Extra spacious
interior, while
still offering the
convenience of fitting
between studs.
• New State-of-the-art DL5000 electronic lock
with a large 3 ¾" touch screen LCD input
display allows smooth and easy operation.
• Mode altering display changes from orange
in standby mode to bright blue in the open
position.
• Accepts (2) user codes and can show open
door records for the past 14 entries.
• LCD touch screen display shows lowbattery indicator, time, date and keypad.
WS1014
WS1014
WFS149E5LP
FEATURES:
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Electronic lock optional, or Chicago single
key camlock with 2 keys.
• Flat dial allows flush mounted installation.
• 3/16" thick solid steel door with dead bar.
• Emergency key-lock override system with
two (2) keys, power override battery box,
built-in spy-proof function and motion
detector alert.
• Dual live bolts ensure protection against pry
attacks.
• Two removable shelves.
• Cream colored, durable powder coated
finish.
WS1214E5
HEAVY-DUTY WS1214E5
FEATURES:
• Same features as Super Brute Floor safes.
Please see page 4.
• Two removable shelves. Extra deep
interior.
• AMSEC's ESL5 electronic lock with
illuminated keypad.
WS1014
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Wt.
10 x 13¾ x 3½
12¼ x 15¾ x 4
9⅝ x 12¾
481
20
10 x 13¾ x 3½
12¼ x 15¾ x 4
9⅝ x 12¾
481
22
14 x 8½ x 10-5/8
19-1/8 x 13½ x 15¾
14 x 8½
1258
106
14 x 8½ x 10-5/8
19-1/8 x 13½ x 15¾
14 x 8½
1258
106
WS1214E5
12 x 13½ x 5½
12⅝ x 14⅛ x 10
10¾ x 11⅛
891
86
WEST2114
21-1/8 x 13-3/4 x 2-7/8
22-1/4 x 15 x 4
19-1/4 x 10-1/4
733
31
WS1014K
WFS149*
WFS149E5LP*
WFS149
FEATURES:
• UL Listed one hour fire rating, ensuring
the inside temperature never exceeded
350° F (paper chars at 450° F).
• Extra deep interior, with one (1) convenient
drawer shelf.
• Combo lock with key operated sidelocking mechanism incorporating one
chromed locking bolt.
• Each safe is equipped with side locking
boltwork mechanism incorporating 1/2"
steel deadbolts.
• Impressive 1/2" thick door with attractive
two-tone Sage finish.
• Packaged for UPS shipment.
Model
When fire is a concern, there is no
better wall safe than the WFS149 or
WFS149E5LP.
NEW! WFS149E5LP with
New ESL5LP Electronic
Lock:
• Illuminated Keypad
• Factory Reset Combination for resolving
lost combinations without requiring
expensive service calls.
• Beep and flash from every keystroke gives
maximum feedback to the user.
• Lock can be programmed to silence the
beep in stealth mode.
• 15-Minute Penalty Lockout after four
incorrect entries protects against
manipulation attempts.
• One 9-volt battery can be easily replaced
in the keypad housing.
* 350° F, UL Listed, 1-Hr fire rated wall safe.
amsecusa.com/
3
SQUARE DOOR FLOOR SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES
All BRUTE SERIES safes are designed to provide secure storage for documents, jewelry, precious metals and
miscellaneous valuables at an economical price. When properly installed in a concrete floor, BRUTE SERIES safes
provide excellent fire and burglary protection. BRUTE floor safes meet and exceed the requirements of the Insurance
Offices Manual of Burglary Insurance. You may also add many options to customize your safe such as: A drop slot
in the door, depository chute, digital keypad lock and keylocking dial to name a few. BRUTE SERIES safes may be
installed in the floor, wall, cladding or within a larger safe.
B2200E5
(shown with
optional cover)
TOP VIEW
OF B1500E5
SUPER BRUTE
SUPER BRUTE
MODEL 2200E5
W/OPTIONAL COMBO LOCK SHOWN
SUPER BRUTE & BRUTE
STANDARD FEATURES:
• Black textured body and door.
• Attractive design offers strong reliable
welds to protect against burglary
attacks and reduce possible leakage.
• Every Brute Series safe now comes
standard with AMSEC’s ESL5
Electronic Lock with Illuminated
Keypad in Bright Chrome. Optional
combo lock available.
• An additional spring-loaded relocking
device, activated by a punching attack.
• Lock and relocks are protected by a
large carburized hardplate.
• A handle activated locking mechanism
consisting of three 1" diameter locking
bolts. Each one is drive resistant,
chromed steel with a long throw.
• One piece heavy duty dead bar behind
hinge prevents removal of door even
if hinges are removed during a forced
entry attempt.
• Door is designed to fit full body size,
which greatly reduces any possible pry
points.
B1500E5
For Slotted Door see Page 38
• Doors are interchangeable within
product group.
BODY:
• Oversize floor plate ensures strong
installation in concrete.
• Flush cover plate.
• Solid steel hinge mechanism using 3/8"
diameter steel hinge pins and internal
mounting bolts.
SUPER BRUTE SERIES
ADDITIONAL FEATURES:
• The SUPER BRUTE’s new door jamb
design is manufactured with state-ofthe-art equipment, with built-in devices
offering the ultimate protection against
sledgehammer attack.
• “B+” rate door: ¾" solid steel plate
door is standard.
• Doors are removable and
interchangeable.
• A large, convenient 10¾" x 111/8" door
opening for bulky items.
• One sliding shelf with double wide
model (B3700). Two sliding shelves
with triple wide models (B5800).
• Attractive carpeted floor in every unit.
4
B3700E5
DOUBLE COMPARTMENT
Super Brute Floor Safes
Lifetime Replacement Warranty:
If your AMSEC Super Brute floor safe is
subject of a sledgehammer or pry attack
and is forcibly entered, AMSEC will replace
or repair the safe (our option) with a current
production model of comparable value free of charge. The damaged safe must
be returned freight prepaid to the factory
within 30 days of the loss, accompanied by
a properly filled police report. This warranty
does not apply to damage or loss resulting
from accident, alteration, unauthorized entry
or improper installation. AMSEC’s limited
warranty policy and procedures applies to any
extended product warranties.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
SQUARE DOOR FLOOR SAFES
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES
B1816
B1810
MINI BRUTE
Model B400
MINI BRUTE
B1806
BRUTE RECTANGULAR
BODY, WIDE DOOR
DOOR:
• Black textured body and door.
• Convenient, reversible lift-out door with
a heavy duty handle.
ADDITIONAL FEATURES:
• Large brass plated dial and black matte
finish dial ring.
• A large, convenient 11¾" x 16" door
opening, for large bulky items or cash
tray storage.
• ½" A36 solid steel plate. New steel
guards protect lock and relock from
accidental damage.
BODY:
• B-rate door of ½" solid steel plate.
• U.L. listed Group II lock with relock. An
additional relocking device, activated
by punching attack.
• Universal jamb design allows the door
to be positioned in all four
directions.
• Heavy duty dead bar prevents removal
of door during forced entry attempt.
• Optional baffled drop slot in door
• 8" square tubular “B” Rate
construction.
• A flush cover plate for total
concealment under a carpet.
SuperBrute "B" Rate Rectangular Hinged Door Floor Safes
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
B1500E5*
12¼ x 13¼ x 8¾
12¾ x 14⅛ x 11¾
10¾ x 11⅛
1377
102
12¼ x 13¼ x 14
12¾ x 14⅛ x 17½
10¾ x 11⅛
2203
118
B2900E5*
12¼ x 13¼ x 18¼
12¾ x 14⅛ x 21⅜
10¾ x 11⅛
2872
134
12¼ x 18 x 17
12¾ x 18¾ x 21⅜
10¾ x 11⅛
3864
136
B3700E5*
12¼ x 23 x 14
12¾ x 24 x 17½
10¾ x 11⅛
3785
145
12¼ x 35 x 14
12¾ x 36 x 16¾
10¾ x 11⅛
5758
185
Wt.
Model
B2200E5*
B3800E5*
B5800E5*
*Constructed of 3/4" door and B-Rate body. Slotted outer door not recommended for use on B1500.
Brute Wide Door "B" Rate Rectangular Hinged Door Floor Safes
Inside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
B1806
12¼ x 18½ x 6
Outside Dimension
HxWxD
1360
102
B1810
12⅓ x 18½ x 10
13¼ x 19½ x 13
11¾ x 16
2281
116
B1816
12¼ x 18½ x 16
13¼ x 19½ x 19
11¾ x 16
3626
142
Model
B1816D *
12¼ x 18½ x 5¾ (top)
12¼ x 18½ x 10 (btm)
13¼ x 19½ x 9
13¼ x 19½ x 19
11¾ x 16
11¾ x 16 (top)
6⅜ DIA (btm)
1303 (top)
2266 (btm)
152
*Double Compartment - Slotted inner door. Slotted door not recommended for use on B1806.
"B" Rate Square Body / Lift-Out Door Floor Safes
Model
B400*
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
7⅝ x 7⅝ x 6¾
8½ x 8½ x 10⅛
6⅝ x 6⅝
393
32
Slotted door not recommended for use on B400. *Optional UPS packaging available. See inside front cover for information.
5
FLOOR SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
STAR® ROUND LIFT-OUT DOOR
FLOOR SAFES are engineered with advanced security features. STAR Tube safes have been
the standard for gas stations, fast food, small retail establishments and home owners for
over 50 years.
Low cost, combined with the various body styles and optional doors will fit almost any cash handling system. When
properly installed in concrete, STAR® FLOOR SAFES provide maximum fire and burglary protection. Now, with the
water-resistant dust cover, you get protection from water as well.
C7
“C” RATE LIFT-OUT DOOR
FEATURES:
• Manipulation resistant, unitized U.L.
Group II key changeable lock protected
by a revolving carburized hardplate.
• Removable dial and drive/drill
resistant spindle preventing damage
from burglary attack and additional
protection from hold-up.
• Door, 7-1/4" clear opening, is 1-3/4"
solid steel.
• Door is securely locked by three bolts
each requiring over 25,000 pounds to
shear.
• Each locking bolt has its own hardened
steel positive relocking bolt.
OTHER FEATURES:
C5
• Water resistant, high impact molded
dust cover with rubber “O”-ring seal
does not rattle or slide like most
covers.
• STAR’s double compartment models
provide the commercial user with the
most effective cash handling system
available. Hold-up as well as burglary
protection is greatly enhanced by use
of this type of safe.
• Available with dual key inner
compartment. Manager holds one key,
the armored car driver, or employee
holds the second.
C3
STAR® “C” RATE TUBULAR BODY SAFES
• Body — Heavy “B” rate construction.
CUTAWAY VIEW “C” RATE LIFT-OUT DOOR
COMBINATION DOOR WITH DROP SLOT
CUTAWAY VIEW OF
STAR® DOUBLE COMPARTMENT
KEYLOCK DOOR
WATER RESISTANT DUST COVER
Model
6
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
C3
8¼ DIA x 5¾
8¾ DIA x 9
7¼ DIA
280
40
C5
8¼ DIA x 10
8¾ DIA x 13½
7¼ DIA
510
48
C7
When properly installed in concrete,
STAR® Floor Safes provide excellent
fire and burglary protection. Now, with
the water resistant dust cover, you get
protection from water as well.
Inside Dimension
HxWxD
8¼ DIA x 16
8¾ DIA x 19
7¼ DIA
785
55
CD5 *
8¼ DIA x 4¼ (top)
8¼ DIA x 4½ (btm)
8¾ DIA x 13½
7¼ DIA (top)
6⅜ DIA (btm)
225 (top)
240 (btm)
54
CD7 *
8¼ DIA x 5¼ (top)
8¼ DIA x 9 (btm)
8¾ DIA x 19
7¼ DIA (top)
6⅜ DIA (btm)
175 (top)
480 (btm)
66
*Double Compartment - Slotted Inner Door
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
FLOOR SAFES
STAR® RECTANGULAR
“B” RATE ROTARY
BODY, ROUND
AND FRONT
LIFT-OUT
LOADING
DOOR
BD24
B24
Rectangular
Body, Round
Lift-out Door
“B” RATE
FLOOR SAFES offer a large cubic inch
capacity at a reasonable price. Strong,
continuously welded steel bodies are
offered with our standard “C” rate
lift-out combination door and waterresistant dust cover.
B17
B6
“C” RATE LIFT-OUT
FEATURES
DOOR:
• Utilizes the STAR high security “C” Rate
door.
Model
BODY:
• “B” Rate construction available in double
compartment models (D) or outside drop
chute (BDP).
B6
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
12 x 10 x 5¼
12½ x 11¼ x 9¾
7¼ DIA
630
62
B17
12 x 12½ x 10
13 x 13 x 15
7¼ DIA
1500
98
B24
12 x 12½ x 14½
13 x 13 x 19
7¼ DIA
2175
122
BD24 *
12 x 12½ x 5½ (top)
12 x 12½ x 10 (btm)
13 x 13 x 20
7¼ DIA (top)
6⅜ DIA (btm)
825 (top)
1500 (btm)
130
BDP24*
12 x 12½ x 4¼ (top)
12 x 12½ x 13¾ (btm)
13 x 13 x 22
7¼ DIA (top)
6⅜ DIA (btm)
638 (top)
2063 (btm)
142
*Double Compartment-Slotted Inner Door. **Double Compartment - Solid Inner Door with Outside Drop Chute
MAJOR® ROUND LIFT-OUT DOOR
MAJOR® Tubular Body, Round Lift-Out DOOR FLOOR SAFES provide
excellent fire and burglary protection when properly installed in concrete.
“C” RATE LIFT-OUT DOOR
FEATURES
T925
• A positive relocking device jams locking
mechanism in the event of a forced entry
attempt.
• Unitized U.L. Group II key changeable
lock with randomized opening positions
defends against drill attacks.
• Drive resistant dial and spindle blocks
sledgehammer attacks.
• Heavy duty “B” rate solid steel body with
reinforced door jamb.
• Door, 65/8" clear opening, is 1" thick
solid steel.
•Available in double compartment models
(DD) with a key locking inner door.
• Door is securely closed by three 5/8" drive
resistant locking bolts.
Model
Inside Dimension
HxWxD
T625
• Recessed locking mechanism protected
by a large carburized hardplate.
•Inside slot to bottom compartment on all
(DD) models.
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
T425
8¼ DIA x 5¾
8⅝ DIA x 8¾
6⅝ DIA
307
40
T625
8¼ DIA x 10¼
8⅝ DIA x 13¼
6⅝ DIA
545
46
T925
8¼ DIA x 15¾
8⅝ DIA x 18¾
6⅝ DIA
840
54
T625DD*
8¼ DIA x 4½ (top)
8¼ DIA x 5¼ (btm)
8⅝ DIA x 13¾
6⅝ DIA (top)
6⅜ DIA (btm)
241 (top)
285 (btm)
54
T925DD*
8¼ DIA x 7½ (top)
8¼ DIA x 7¾ (btm)
8⅝ DIA x 18¾
6⅝ DIA (top)
6⅜ DIA (btm)
401 (top)
420 (btm)
64
*Double Compartment - Solid Inner Door with Drop Chute.
T425
CUTAWAY VIEW OF “MAJOR” DOOR
7
UNDERCOUNTER SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
UNDERCOUNTER SAFES
AMSEC’S UNDERCOUNTER SAFES limit excess cash register funds by
providing instant protection for interim deposits of cash or checks via the
anti-fish deposit slot. Securely positioning the safe next to the cash register
limits exposed cash and reduces the threat of robbery and internal theft.
Adaptable for multi-unit installation use, ideal for gun control, staff use,
athletics clubs, security areas and much more.
LOCK OPTIONS:
• Chicago single key camlock
equipped with two keys. (Lock
option -1)
(LOCK OPTION -2)
TB0610-2
• Chicago 7 pin radial key camlock,
equipped with 2 keys. (Lock option
1T)
(LOCK OPTION #1T)
TB0610-1T
Chicago 7 pin camlock
FEATURES:
• Heavy gauge solid steel
construction.
• Full width deposit slot over door
equipped with an “anti-fish” saw
tooth baffle to guard against pilferage
or fishing.
• Heavy-duty piano hinges.
• Available with six different lock
options to fit your specialized
security requirements.
• Units can be bolted together
utilizing bolt holes.
• Interchangeable doors allow
flexible means of changing locking
mechanisms without replacing the
entire unit.
• Two anchor holes provided on all
four sides.
• Attractive and durable powder
coated black finish.
• Medeco® U.L. listed high security
single key camlock supplied with
two keys. Medeco’s restricted
keyways protect against
unauthorized key duplication. (Lock
option -2)
(LOCK OPTION -1)
TB0610-1
Medeco® single key camlock
Chicago single key
camlock
(LOCK OPTION -7)
TB0610-7
• Dual custody safe deposit key lock (two
keys required to open safe). (Lock option
-4)
(LOCK OPTION -4)
TB0610-4
• Best removable core key lock
supplied without core. A removable
core system lets you change the
combination of any lock in seconds
and can easily expand to include
new facilities. Supplied without
core. (Lock option -7, without core).
Best removable
core key lock
(core not included)
Dual custody safe
deposit key lock
• Lock1One Group II key changeable
combination lock offers 1 million
possible combinations. (Lock option
-6).
• Optional custom key control
systems designed to your security
requirements:
1) Master Keyed
2) Keyed Alike
K2
K1
3) Keyed Different
HEAVY DUTY SERIES
MODEL K1 AND K2
• 1/4" thick A36 solid steel plate hinged door.
• Full width slot over door.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Wt.
TB0610
5⅞ x 5⅞ x 8⅜
6 x 6 x 10
5⅞ x 5
289
6
K-1 / K-2
5⅝ x 5⅝ x 10
6 x 6 x 12
3-13/16 x 5
316
16
Model
NOTE: Models TB0610 is available with the LaGard 33E electronic lock. (Factory installed primary lock.)
IMPORTANT:
AMSEC Undercounter safes are recommended for an operation that requires a nonreturnable deposit. These safes are not meant for overnight storage of cash
8
• A saw tooth baffle guards against pilferage
or fishing.
• Your choice of U.L. listed dual control
keylock (K-2), a single key Medeco® lock
(K-1), or a Chicago single key lock (K-1A).
• “B” Rate steel construction.
• May be installed vertically or horizontally.
• May be mounted on or under counter as
space permits.
• Durable, impact resistant Charcoal Gray
textured finish.
amsecusa.com/
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
CASH MANAGEMENT SAFES
RETAIL MONEY MANAGER SAFE
AMSEC’s NEW RETAIL MONEYMANAGER SAFE offers unrivaled
value in electronic safe access. Built tough to maximize protection
against burglary attempts, the Retail MoneyManager has all the
advanced features necessary for commercial applications.
Safe Features:
• Solid steel 1/2" thick door equipped with
10 solid steel Anti-Spread Pins
• Formed high tensile steel body and jamb
construction to maximize protection
against pry attack.
• Provided with 6 removable door mounted
coin racks
• Reinforced internal jambs on all four sides
provide protection against sledgehammer
attack.
• 3-way locking system with five 1" dia.
Chrome plated locking bolts.
Interior Locker
Features:
• Heavy 1/4" steel door,
9-1/4" H x 19-3/4" W x
13-1/2" (12-7/8" Clear) D
• Large clear door opening:
6-9/16" H x 14" W
• Locker door closes when
outer door is closed.
Deposit Drawer Features:
• Large “fish” and “pry” resistant solid
steel deposit drawer deposits.
• Drawer size: 2" x 4-1/4" x 9-1/2"
• Bolt detent system engages boltwork and
locks the door automatically.
RMM2620SW-R
Lock Features:
• The Retail MoneyManager Safe is
available with either the AMSEC
SafeWizard® Electronic lock, AMSEC
ESLAudit Electronic Lock or the AMSEC
ESL20-XL Electronic Lock.
• Auxiliary spring-loaded relocking devices.
• Locks and relocks protected by a large
carburized hardplate.
• Standard Four (4) anchor bolt holes.
Description
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Wt.
RMM2620SW-R
C-Store Cash Management Safe
/ Right Swing / with SafeWizard®
25¾" x 19¾" x 15-5/8"
26" x 20" x 18½"
18¼" x 15½"
280
RMM2620ESLAudit-R
C-Store Cash Management Safe
/ Right Swing / with ESLAudit
25¾" x 19¾" x 15-5/8"
26" x 20" x 18½"
18¼" x 15½"
280
RMM2620ESL15-R
C-Store Cash Management Safe
/ Right Swing / with ESL15
(Time Delay)
25¾" x 19¾" x 15-5/8"
26" x 20" x 18½"
18¼" x 15½"
280
Model
RMM2620SW-R
RMM2620ESLAUDIT-R
RMM2620ESL20-R
More information on the SafeWizard® Lock
can be found on Page 41
More information on the ESLAudit Lock can
be found on Page 42
More information on the ESL20XL Lock can
be found on Page 43
9
CASH MANAGEMENT SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
CASHWIZARD® BILL READER SAFES
American Security Products Co. (AMSEC) offers a new line of cash management smart safes for cash-intensive environments.
THE CASHWIZARD® BILL READER SAFES Offers a wide range of capabilities from MEI bill validators increasing cash
processing speeds, a thorough reporting system to make accurate and verified shift reports, a comprehensive access control
system and remote capabilities to transmit data to the financial institution or armored car carrier for provisional credit.
All CashWizard Safes
Feature:
Cash Management
• Deposit tracking system to provide
the highest level of cash management
security
• MEI Cashflow bill readers that count and
verify cash deposits
• Manual Drop tracking for mutilated cash,
coins, checks and other items
• Reports available by transaction, user,
shift and business day
• Armored courier compatible
Access Control
Remote Management
• 10,000 audit entries and up to 40 users
• Remote Management is available using
CashWizard Admin and an Ethernet
network connection
• Time Delay any door
• Time Lock any door, 1-6 windows per day
• Authentication options: PIN code and/or
Dallas Key
• Wrong PIN penalty lockout
• Duress Hold-Up Alarm with Silent Signal
• Burglary Alarm output signal
• Holiday schedule with up to 16
programmable events per year
• Automatic Daylight Savings Adjustment,
selectable and configurable
• Dual control mode on any door
• Audit record written for each transaction
• Add/Edit/Delete Users
• Run Reports – Cash Management and
Audit reports
• Manage System Settings – (Safe Time,
Door Delay, End of Day, etc.)
• Create Event based Alerts for each
safe (Cassette Full, Courier Event, Door
Opened, etc.)
Options
• Single or Bunch Note Feeder bill readers.
• 1200 or 2200 Note Cassettes
• Door mounted printer or detached
• Lockable door for bill reader heads
• Manager Locker with second outer door
High Volume "All-In-One" 3-Door
Dual Bill Reader - Specifications
•
Equipped with the UL Listed AMSEC
CashWizard Access Control
System. Can be connected to Ethernet
network for interface to back
office PC or remote locations.
•
Dual MEI Cashflow SCL-1200 note
validators are standard. Can also
be equipped with optional MEI Cashflow
SCXL-2200 note validators.
•
Integrated thermal direct printer provides
system activity reports.
•
Manual deposit drawer equipped
with CashWizard access control lock.
Authorized users can access deposit
drawer, input currency and make an
audited deposit. Anti-fish deposit drawer
capacity: 7” L x 2½” W x 3¾” H.
•
Inside deposit and storage area capacity:
6¾” H x 15½” W x 18½” D
•
3/8”-thick steel pry-resistant outer door
equipped with a unique 3/8”-thick steel
3-point anti-spread deadlatch locking
system, three dead bars and a bolt detent
system to auto lock the safe when the
door is closed.
•
Provided with four 1/2” dia. anchor holes
and mounting hardware.
10
BR3122x2
High Capacity Dual Bill
Reader Safe with
built-in printer
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
CashWizard High Capacity Dual
Bill Reader Specifications
• Equipped with the UL Listed AMSEC
CashWizard access control system
• ½”-thick steel pry-resistant outer door
equipped with anti-spread deadlatch
locking system, dead bars and a bolt
detent system to auto lock safe door
• Removable bill heads to easily clear jams
• Four ½” diameter anchor holes and
mounting hardware
• Optional Manager Locker with second
outer door: 9” H x 13” W x 18”D
BR3113x2
High Capacity Bill Reader Safe
with built-in printer and showing
optional Manager Locker
BR2213x2PP
High Capacity Bill Reader Safe
BR2213x2
High Capacity Bill
Reader Safe
with built-in printer
CashWizard Low Volume Single
Bill Reader Specifications
• Equipped with the UL Listed AMSEC
CashWizard access control system
• ½”-thick steel pry-resistant outer door
equipped with anti-spread deadlatch
locking system, dead bars and a bolt
detent system to auto lock safe door
• Removable bill heads to easily clear jams
• Four ½” diameter anchor holes and
mounting hardware
• Optional Manager Locker with second
outer door: 9” H x 11⅝” W x 18” D
Optional
Portable Printer
BR2212x1PP
Low Volume Bill Reader Safe
BR2212x1
Low Volume Bill Reader Safe
with built-in printer
BR3112x1PP
Low Volume Bill Reader Safe
with optional Manager Locker
Description
Outside Dimension
HxWxD
Wt.
BR3122x2
High Volume "All-In-One" 3 Door SmartSafe (Dual Bill Readers)
31 x 21.5 x 21
380
BR3113x2
High Volume "2 Door" SmartSafe (Dual Bill Readers)
31 x 13 x 22
256
BR2213x2
High Volume "1 Door" SmartSafe (Dual Bill Readers)
22 x 13 x 22
186
BR3112x1
Low Volume "2 Door" SmartSafe (Single Bill Reader)
31 x 11.625 x 22
234
BR2212x1
Low Volume "1 Door" SmartSafe (Single Bill Reader)
22 x 11.625 x 22
170
BR3113x2PP
High Volume "2 Door" SmartSafe (Dual Bill Readers)
31 x 13 x 18
251
Model
CashWizard Safes with Built-in Printer
CashWizard Safes with Portable Printer
BR2213x2PP
High Volume "1 Door" SmartSafe (Dual Bill Readers)
22 x 13 x 18
181
BR3112x1PP
Low Volume "2 Door" SmartSafe (Single Bill Reader)
31 x 11.625 x 18
229
BR2212x1PP
Low Volume "1 Door" SmartSafe (Single Bill Reader)
22 x 11.625 x 18
165
Extra deep (XD) models also available. For more information, please see the AMSEC Price List, Page 16.
11
CASH MANAGEMENT SAFES
CASHWIZARD® BILL READER SAFES
DEPOSITORY SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
BWB SERIES - WIDE BODY CASH CONTROL
Extensive research and development went into the engineering of AMSEC’S WIDE BODY “B” RATE CASH HANDLING
DEPOSITORY SAFES. Designed to offer complete cash management versatility with a front load depository option and a
pull-out deposit drawer (Model BWB3020D1 only).
BWB3020-D1
BWB2020FL WITH
OPTIONAL SAFEWIZARD®
BWB STANDARD FEATURES:
• Door: Massive ½" thick A36 solid
steel plate.
• Formed high tensile steel body and jamb
construction to maximize protection
against pry attack.
• Reinforced internal jambs on all four
sides to provide protection against
sledgehammer attack.
• U.L. listed Group II, key changeable
combination lock.
• Optional electronic locks available.
• 3-way locking mechanism consisting
of five 1" diameter chromed steel locking
bolts.
• Bolt detent system engages boltwork
automatically.
• Locks and relocks protected by a large
carburized hardplate.
Model
Inside Dim
HxWxD
BWB2020-FL
• Auxiliary spring-loaded relocking devices.
• Convenient, door-mounted, recessed coin
rack.
• Standard Four (4) anchor bolt holes.
INTERIOR LOCKER FEATURES:
• Heavy 1/4" steel door, and single-key
camlock with two keys.
• Large clear door opening:
6" H x 12"W (for 20" W safes) or
6" H x 14"W (for 25" W safes).
• Inside Dimensions:
BWB2020 / BWB3020 / BWB4020:
85/8" x 19¾" x 14"
BWB2025 / BWB3025 / BWB4025:
85/8" x 24¾" x 19"
• Note: Front Load Depository - inside
locker height restricted to 6".
Outside Dim †
HxWxD
Clear Door
HxWxD
Cu. In.
Wt*
• Heavy duty steel sliding drawer.
• Protected by dual “anti-fish baffles.”
• Large package capacity: 4" x 9" x 11½"
(maximum).
• May be ordered in any one of four
directions. Specify front, reversed, right
load or left load.
Shelves
9 x 19¾ x 17
29¾ x 20 x 20
14¾ x 16¼
3,022
218
0
29¾ x 20 x 20
14¾ x 16¼
6,630
260
0
BWB2020FLRNL
19¾ x 19¾ x 17
29¾ x 20 x 20
14¾ x 16¼
6,630
260
0
BWB2020FLR
9 x 19¾ x 17
29¾ x 20 x 20
14¾ x 16¼
3,022
218
0
BWB3020FL
19 x 19¾ x 17
39¾ x 20 x 20
24¾ x 21¼
6,380
278
2
BWB3020FLR
19 x 19¾ x 17
39¾ x 20 x 20
24¾ x 21¼
6,380
278
2
BWB4020FL
29 x 19¾ x 17
49¾ x 20 x 20
34¾ x 16¼
9,737
334
3
BWB4020FLR
29 x 19¾ x 17
49¾ x 20 x 20
34¾ x 16¼
9,737
334
3
BWB2025FL
9 x 24¾ x 22
29¾ x 25 x 25
14¾ x 21¼
4,900
285
1
BWB2025FLR
9 x 24¾ x 22
29¾ x 25 x 25
14¾ x 21¼
4,900
285
1
BWB3025FL
19 x 24¾ x 22
39¾ x 25 x 25
24¾ x 21¼
10,345
352
2
BWB3025FLR
19 x 24¾ x 22
39¾ x 25 x 25
24¾ x 21¼
10,345
352
2
BWB4025FL
29 x 24¾ x 22
49¾ x 25 x 25
34¾ x 21¼
15,790
440
3
BWB4025FLR
29 x 24¾ x 22
49¾ x 25 x 25
34¾ x 21¼
15,790
440
3
BWB3020-D1
19 x 19¾ x 17
30 x 20 x 20
24¾ x 16¼
6,380
270
2
12
Drawer size: 11/8" x 3½” x 7½"
• Recessed heavy duty 1/8" construction
with 1/8" door.
19¾ x 19¾ x 17
B-Rate Wide Body Depository Chest with Drawer
• Large “fish” resistant, pull out drop drawer
deposits directly into standard interior locker.
FRONT LOAD
DEPOSITORY FEATURES:
BWB2020FLNL
BWB2020FL
DEPOSIT DRAWER FEATURES
(ONLY MODEL BWB3020D1):
EACH UNIT COMES EQUIPPED WITH AN
INTERIOR LOCKER TO ACCOMMODATE
DEPOSITS, A LARGE INTERIOR FOR
STORAGE OF CASH TRAYS AND A DOORMOUNTED, RECESSED COIN RACK.
IMPORTANT:
AMSEC depository safes are
recommended for an operation that
requires a non-returnable deposit such
as armored car companies, convenience
stores, restaurants, etc. The top locker is
not meant for overnight storage of cash or
valuables.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
DEPOSITORY SAFES
DS SERIES - “B” RATE ROTARY AND FRONT LOADING
AMSEC’S DS SERIES
DEPOSITORY SAFES
are designed to provide
immediate deposits and
storage for cash, jewelry
and miscellaneous
valuables.
Deposits can be made to
a locked compartment
via a top-loading rotary
hopper, a reverse or a
front-loading deposit door.
REVERSE HOPPER
DSR2014 WITH ESL10XL
STANDARD FEATURES
ADDITIONAL FEATURES:
WIDE BODY MODEL 2731
BODY:
• Strong, formed “B” Rate construction made
of A36 solid steel plate for improved security
and appearance.
• Formed door jamb for increased resistance to
sledgehammer attack.
• Four anchor bolt holes are standard.
• ½" thick A36 solid steel plate, recessed ½" to
increase resistance to pry attack.
• U.L. Group II combo lock (C), U.L. listed dual
nose keylock (K).
• Optional electronic locks available.
• Three 1" diameter chromed steel locking bolts.
• Bolt detent system engages boltwork
automatically.
• Auxiliary spring-loaded relocking device.
Model †
Inside Dimension
HxWxD
• DOOR: (3) 1" x ½" rectangular
plated bolts.
• Unique space-efficient, side-by-side
design creates full depth depository
and large storage compartment.
• Accepts cash trays up to 13" x 18".
• Optional coin rack available on storage
compartment door.
DOOR - MODEL NUMBERS:
2014, 2714 AND 3214
• Lock and relock protected by large
carburized hardplate.
DSF2714K
DSC2014KC
DST2731KC
HOPPER:
• 2014 is available w/reverse hopper.
• Large package sizes:
(Top Load Rotary):
4¾"D x 4¾"W x 10"L
(Front/Reverse Load):
4"D x 2¾"W x 10½"L
• Recessed, heavy duty 3/16"
construction (¼" door).
DSF2014
WITH ESL10XL LOCK
• Protected by dual “anti-fish” baffles.
Outside Dim*
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
DST2014
11½ x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1,739
87
DSF2014
10 x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1513
79
DSR2014
10 x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1513
94
BOT 10¼ x 13¾ x 11
TOP 6⅞ x 13¾ x 12⅜
27¼ x 14 x 14
BOT 9¾ x 9¾
TOP 6 x 10⅜
1513
1127
104
18½ x 13¾ x 11
27¼ x 14 x 14
9¾ x 9¾
2798
101
DSF2714
17¼ x 13¾ x 11
27¼ x 14 x 14
9¾ x 9¾
2609
108
DST3214
TOP 12¼ x 13¾ x 11
BOT 11¼ x 13¾ x 11
32¼ x 14 x 14
9¾ x 9¾
1664
1890
152
DSF3214
TOP 11¼ x 13¾ x 11
BOT 12½ x 13¾ x 11
32¼ x 14 x 14
9¾ x 9¾
DST2731
LEFT 18½ x 14⅜ x 18
RIGHT 27 x 16 x 18
27¼ x 30¾ x 21
LEFT 9 x 9⅞
RIGHT 22½ x 14⅜
4787
7776
285
†Specify Prefix: T=Top Loading, F=Front Loading,
R=Reverse Hopper, K=Key Lock, C=Combo Lock,
E=Electronic Lock
DSF2731
LEFT 16¾ x 14⅜ x 18
RIGHT 27 x 16 x 18
27¼ x 30¾ x 21
LEFT 9 x 9⅞
RIGHT 22½ x 14⅜
4399
7776
276
*Add 2" to outside depth for dial and handle
projection.
DSC2014KC **
DST2714
1437/ 1815 ^
144
1890/ 1702 ^
DSF3214CC
IMPORTANT:
AMSEC depository safes are recommended for an
operation that requires a non-returnable deposit
such as armored car companies, convenience
stores, restaurants, etc. The top locker is not
meant for overnight storage of cash or valuables.
**Camlock on locker, combination on deposit safe.
^Cubic inch capacity on DSF3214 change for CC
and KK
13
DEPOSITORY SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
MONEY MANAGER
AMSEC’s “B” Rate Money Manager Series Undercounter Two Door Depository Safes
are the most effective cash handling systems available. Engineered to help you achieve
total cash control.
AMSEC’s Money Manager Series is recommended for any operation that requires a nonreturnable deposit such as armored car companies, convenience stores, restaurants,
etc. The secured deposit and receiving compartments protect against mysterious
disappearance and pilferage.
NEW! AMSEC’s ESL15 electronic lock is now standard for this series!
MM2820E15 TOP DROP
W/OPTIONAL KEY LOCK
STANDARD FEATURES:
• Heavy duty construction with ½" solid
steel doors.
• Both doors equipped with AMSEC’s
ESL15 electronic lock. Optional key locks
available, offering dual control.
• Optional combination locks available.
• Handle activated locking mechanism
consisting of three 1" diameter locking
bolts.
• Bolt detent device automatically engages
bolts when doors are closed.
MM2820E15 THREE DROP
MM2820E15 CENTER DROP
• Auxiliary spring-loaded relocking device,
activated by a punch attack.
• Four anchor bolts and anchor hardware
included.
• Locks and relocks are protected by a large
carburized hardplate.
• Available as a “top drop,” “center drop,” or
“three drop” model.
• Formed door jamb and full length dead
bar.
• MM2820E15 front load and center drop
hopper measures 16¼"W x 2"H x 3½"D.
• Coin racks are standard on inside of
storage door.
• Three individual color-coded 4” drops for
shift control. Three deposit bins provided
on “three drop” model.
• Fish resistant depository drops accept
bulk items, drop envelopes or bags.
• Attractive Black textured finish.
• Cash drawers and bulky items
conveniently fit into both compartments.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
MM28203-Drop-E15
TOP 9½ x 20 x 17
BTM 11 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
247
MM2820Top-Drop-E15
TOP 9½ x 20 x 17
BTM 11 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
274
MM2820Ctr-Drop-E15
TOP 10 3/8 x 20 x 17
BTM 10 3/8 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
278
Model
14
2014 PRODUCT CATALOG
“B” RATE SECURITY SAFES
“B” RATE SECURITY SAFES
AMERICAN SECURITY PRODUCTS CO.
BWB SERIES AND MS1414
The many different features of the WIDE BODY SAFES, make them perfect for commercial application or home use.
MS1414 WITH
ESL10XL LOCK
BWB2020
BWB3020
Standard Features for
BWB:
• ½" thick solid steel door, recessed for
resistance to pry attacks.
• Formed, high-tensile steel body and
jamb construction to maximize protection
against pry attacks.
• U.L. listed Group II key changeable
combination lock with over 1 million
possible combinations.
• Optional electronic locks available.
• Auxiliary spring-loaded relock device.
• Locks and relocks protected by a large
carburized hardplate.
Additional BWB Series Features:
• Reinforced internal jambs on all four sides
to provide excellent protection against
sledgehammer attack.
• 3-way locking mechanism consisting of
five massive 1" diameter chromed steel
locking bolts.
• Bolt detent system keeps bolts retracted
when the door is open, then automatically
engages when door is shut.
• Convenient door mounted recessed coin
rack.
• Large capacity for storage of cash trays.
• Adjustable shelves.
MS1414KS WITH
SLOT OPTION
Mini Safe (MS Series) Features:
• Strong, formed “B” Rate construction
made of A36 solid steel plate for improved
security and appearance.
• Formed door jamb for increased
resistance to sledgehammer attack.
• Attractive Black textured finish.
• BWB: Four anchor bolt holes with
hardware.
• ½" solid steel door.
Model
Inside Dim
HxWxD
Outside Dim*
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt
Shelves
BWB2020
19¾ x 19¾ x 17
20 x 20 x 20
14¾ x 16¼
6,631
154
1
BWB3020
29¾ x 19¾ x 17
30 x 20 x 20
24¾ x 16¼
9,988
218
2
BWB4020
39¾ x 19¾ x 17
40 x 20 x 20
34¾ x 16¼
13,346
272
3
BWB2025
19¾ x 24¾ x 22
20 x 25 x 25
14¾ x 21¼
10,754
235
1
BWB3025
29¾ x 24¾ x 22
30 x 25 x 25
24¾ x 21¼
16,198
306
2
BWB4025
39¾ x 24¾ x 22
40 x 25 x 25
34¾ x 21¼
21,644
440
3
MS1414
13¾ x 13¾ x 11
14 x 14 x 14
9¾ x 9¾
2080
67
1
*Add 2" to outside depth for handle, dial and hinge projection.
• U.L. Group II combo lock (C), U.L. listed
dual nose keylock (K).
• Three 1" diameter chromed steel locking
bolts.
• Bolt detent system engages boltwork
automatically.
• Auxiliary spring-loaded relocking device.
• Lock and relock protected by large
carburized hardplate.
• Four anchor bolt holes with hardware.
• Adjustable shelf provided.
• Also available with optional deposit slot (s).
(shown above) Slot size: ½" H x 6 W"
15
IMPORTED U.L. LISTED 1-HR FIRE SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
IMPORTED U.L. LISTED SAFES
The economical range of our IMPORTED RESIDENTIAL FIRE SAFES (ELECTRONIC and COMBO) is the answer’s to
today’s high incidence of residential fires. Our Fire Safes also provide burglary protection making them ideal for home and
light commercial applications. Our FS2215 IMPORTED COMMERCIAL FIRE SAFE is larger and perfect for both commercial
and residential applications.
AMSEC's FS Series is the
only 1hr. economical fire
safe with a high-security
electronic lock.
AMSEC
Other Brands
FS149
FS1814E5
FS2215
IMPORTED
RESIDENTIAL FIRE SAFES
(ELECTRONIC)
Models FS914E5LP and FS149E5LP come
with slide-out drawer, anchor holes and anchor
hardware. Models FS1814E5 and FS2215
come with a key-locking drawer, adjustable
shelf, anchor holes and anchor hardware.
FS2215 IMPORTED
COMMERCIAL FIRE SAFE
FEATURES:
FS712E5LP, FS914E5LP /
FS149E5LP / FS1814E5:
Mechanical combination units (FS) come with
standard mechanical combination lock plus
key lock.
U.L. Listed, 350°F, 1-Hr fire protection.
IMPORTED RESIDENTIAL
FIRE SAFES (COMBO)
• Model FS2215 offers a Group 2
combination lock with a Spyproof dial
and ring, one (1) key-lock drawer, one (1)
adjustable shelf, four (4) rolling casters
for ease of movement and additional
chrome “L” handle.
FS914E5LP
Units with NEW ESL5LP Electronic lock feature:
• Illuminated Keypad
FEATURES:
• Factory Reset Combination for resolving lost
combinations without requiring expensive
service calls.
• U.L. Listed 350°F 1-Hour fire rating.
• Beep and flash from every keystroke gives
maximum feedback to the user.
• Lock can be programmed to silence the
beep in stealth mode.
• One 9-volt battery can be easily replaced in
the keypad housing.
• U.L. Listed 350°F 1-Hour fire rating.
• Automatic relocking device triggered by
force entry attempt.
FS914 / FS149:
• Handle operated side, top and bottom
locking mechanism incorporating four
steel chromed locking bolts.
• Models FS914 and FS149 have one
(1) internal anchor hole and hardware,
four (4) rubber feet and one (1) drawer
shelf (except model FS712 that has a
removable shelf).
• Two steel deadbolts prevent door
removal if hinges are removed during a
forced entry attempt.
• Ball bearing hinges for ease of operation.
• Attractive two-toned sage finish.
• Key operated side-locking mechanism
incorporating two chromed locking bolts.
• 15-Minute Penalty Lockout after four
incorrect entries protects against
manipulation attempts.
FEATURES:
• Two deadbolts prevent door removal if
hinges are removed during a forced entry
attempt.
OPTIONAL LED
LIGHT KIT WITH
MOTION SENSOR
AVAILABLE FOR
ALL MODELS.
SEE PAGE 26 FOR
DETAILS.
• Attractive two-toned sage finish.
Residential Fire Safes (Electronic and Combo)
Model
Inside Dim
HxWxD
Outside Dim*
HxWxD
Clear Door
Cu. In.
Wt
*Add 2" for handle, dial and hinge
projection.
FS712E5LP
7 x 11¼ x 8-3/8
11¾ x 16½ x 13¾
7 x 11¼
660
70
Model FS2215 has one key-lock
drawer and one adjustable shelf.
FS914E5LP
8-7/16 x 14 x 10½
13½ x 19-1/8 x 15¾
8-7/16 x 14
1,107
96
FS149E5LP
14-1/8 x 8¼ x 10¾
19-1/8 x 13½ x 15-11/16
14-1/8 x 8¼
1,258
96
18¼ x 13-1/8 x 12-3/8
23-5/8 x 18-7/8 x 18-7/8
18¼ x 13-1/8
2,920
187
FS914
8-3/8 x 14 x 10¾
13½ x 19-1/8 x 15¾
8-3/8 x 14¼
1,189
96
FS149
14-1/8 x 8¼ x 10¾
19-1/8 x 13½ x 15-11/16
14-1/8 x 8¼
1,258
96
FS1814E5
Residential Fire Safes (Electronic and Combo)
Model
FS2215
16
Inside Dim
HxWxD
Outside Dim*
HxWxD
Clear Door
Cu. In.
Wt
17¾ x 13-7/8 x 13-3/8
30-3/8 x 19¾ x 19-3/8
17¾ x 13-7/8
2,786
225
Outside height includes casters on
model FS2215.
Above dimensions have
been converted from metric
measurements. Please allow +¼" to
¼" variation for both outer and inner
dimensions listed.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
FEATURES:
• The best warranty in the business. Lifetime
fire replacement and one year parts and
labor.
• U.L. listed Class 350°F two hour fire and
impact rating.
• Safes withstand fires of up to 1850°F for
two hours and a 30' drop – equivalent to
falling through a 2 story burning building.
• Increased barriers for burglary protection.
Impressive 3½" thick recessed door with
5/8" thick front for excellent pry resistance.
• Handle activated locking mechanism with
7/8" diameter solid steel chrome plated
locking bolts offering smooth operation.
UL1812GR
• Internal anchor bolt hole with hardware.
OPTIONAL LED
LIGHT KIT WITH
MOTION SENSOR
AVAILABLE FOR
ALL MODELS.
SEE PAGE 26 FOR
DETAILS.
U.L Safes Lifetime Replacement
Warranty:
All AMSEC U.L. Listed fire safes
are protected by a LIFETIME FREE
REPLACEMENT GUARANTEE, assuring
the original owner free replacement of
safes that are damaged beyond repair
by a fire with a current production model
of comparable value. The damaged
safe must be returned freight prepaid to
the factory within 30 days of the loss,
accompanied by a properly filed fire
department report.
• U.L. listed Group II key changeable
combination lock with relock. 1 million
possible combinations.
• Auxiliary spring-loaded relock device
activated by severe attack.
• Heavy duty steel hinges provide additional
security and smooth operation.
• For your convenience, rubber feet are
standard on models UL1511 – 1812X.
• Heavy duty rolling casters on UL2018 and up.
• Attractively accented with a brass or
chrome handle, decorative emblems and
plush velour interior.
• Available in durable Sandstone or Granite
textured finishes.
Inside Dim
HxWxD
Outside Dim*
HxWxD
Cu. In.
Capacity
Wt
Shelves
UL1511
15½ x 11½ x 12
21¼ x 17 x 18½
2,139
246
1 Adj. Shelf
1 Base
UL1812
18½ x 12½ x 12
25 x 18 x 18½
2,775
272
1 Adj. Shelf
1 Base
UL1812X
18½ x 12½ x 17
25 x 18 x 23½
3,931
298
1 Adj. Shelf
1 Base
UL2018
20 x 18 x 18
30¼ x 25½ x 25½
6,480
542
2 Adj. Shelf
1 Base
UL3918
39 x 18 x 18
49¼ x 25½ x 25½
12,636
808
2 Adj. Shelf
1 Base
Model
UL SERIES
UL SERIES
U.L. LISTED 2-HOUR FIRE AND IMPACT SAFES
* ADD 2" FOR HANDLE, DIAL AND HINGE PROJECTION. OUTSIDE HEIGHT INCLUDES 1" HIGH RUBBER FEET ON MODELS
UL1511-UL1812XD; 2¾" FOR CASTERS ON THE THREE LARGEST MODELS.
Hardware on above safes specify (*): Brass (LTG) on Sandstone and Chrome (LTE) on Granite
Color Options Specify (**): (GR) = Granite, (ST) = Sandstone
U.L. FIRE RESISTIVE RATING
CLASSIFICATION
THE FOLLOWING IS AN EXPLANATION OF THE
UNDERWRITER’S LABORATORIES’ FIRE RESISTANT
CONTAINER TESTING PROCEDURES ON THE CLASS
350°F, ONE HOUR AND TWO HOUR FIRE LABELS.
U.L. Label/Class 350°F-one hour and Class 350°F-two
hour. The safe will maintain an interior temperature less
than 350°F when exposed to fire for a period of one hour
at 1700°F or for a period of two hours at 1850°F. Safe must
successfully undergo all other requirements for the Fire
Endurance Test, Explosion Hazard Test and the Fire/Impact
Test as stated below.
FIRE ENDURANCE TEST
After heat sensors and paper are placed inside the safe, the
unit is locked and exposed to a uniformly distributed fire.
The furnace is regulated to reach a maximum temperature
of 1700°F for a period of one hour, or 1850°F for two hours,
then allowed to cool without opening the furnace. The
interior temperature is recorded throughout the test and
during the cooling period until a definite drop is shown and
must never exceed 350°F.
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
EXPLOSION HAZARD TEST
The safe is locked and placed into a furnace preheated
to 2000°F. This temperature is maintained for 30 minutes
(2 hour test is 45 minutes) and if no explosion results, the
unit is allowed to cool without opening the furnace doors.
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
FIRE IMPACT TEST
(MANUFACTURER’S OPTION)
After the explosion hazard test the safe is removed from
the furnace and within two minutes is dropped 30’ onto a
riprap of brick on a heavy concrete base. After impact the
unit is examined for deformation, rupture of parts, damaged
insulation and any other openings into the interior of the unit.
Once cooled, the unit is inverted and reheated to 1550°F for
a period of 30 min. (2 hour test: 45 min. at 1638°F).
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
17
BF® SERIES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
U.L. LISTED FIRE RATED BURGLARY SAFES
The AMSEC BF® SERIES offers a unique design that combines all the security
features of a burglary safe and the peace of mind achieved with a fire safe. The
industry’s first U.L. Listed, fire-rated burglary safe offers an affordable solution when
burglary and fire protection are an essential part of your buying decision!
RESIDENTIAL SECURITY
CONTAINER
During Underwriter’s Laboratories grueling testing procedures, the BF® SERIES earned
the U.L. Listed Class 350°F One Hour Fire Label and the (RSC) Residential Security
Container Burglary Label.
BF2116
FEATURES
BF3416ST
SHOWN WITH
OPTIONAL STORAGE
CABINETS (PG 27)
OPTIONAL LED
LIGHT KIT WITH
MOTION SENSOR
AVAILABLE FOR
ALL MODELS.
SEE PAGE 26 FOR
DETAILS.
BF® Safes Lifetime Replacement
Warranty:
If your BF® safe is exposed to fire and
failed to protect the contents, your BF®
safe will be replaced free of charge. Just
return the safe freight prepaid to the
factory accompanied with the fire report.
Contact your dealer for further details.
• The best warranty in the business. Lifetime
fire replacement and one year parts and
labor.
• 1-Hr. 350°F factory fire rating. Tested at
temperatures up to 1700°F.
• U.L. listed Group II lock with spring-loaded
auxiliary relock device.
Door:
• ¼" heavy duty carburized hardplate.
• 3½" thick, consisting of ½" plate steel
with a unique proprietary fire and burglary
resistant material.
• Heavy duty steel hinges provide easy
smooth door operation.
• Dual seal design utilizes a silicone foam
seal with a heat-expanding intumescent
seal.*
Body:
• 25/8" thick, consisting of 1/8" outer and
inner steel plates creating a burglary
resistant structure enclosing a unique
proprietary fire resistant material.
• Three massive 1" diameter solid steel
chrome-plated locking bolts.
*INTUMESCENT
DOOR SEAL:
When the intumescent
seal is exposed to high
temperature (above
250˚F), it expands to as
much as 8 times it’s original thickness.
In this expanded or reactive state,
it has very high thermal insulating
capacity and resistance to breakdown.
This provides a strong positive seal
between the door and body, preventing
heat influx.
18
BF1512
• “B” rated heavy duty construction.
• A full length dead bar locks deep into the
body preventing door removal during a
forced entry attempt.
• One recessed anchor bolt hole and
mounting hardware are provided to
securely anchor safe.
• Attractively accented with a large chromeplated dial, matching handle and a plush
velour interior.
• Durable and attractive granite finish or
sandstone textured with a plush velour
interior. Optional high-gloss finishes available.
• Optional electronic locks are available.
SEE PAGES 42-44.
• Optional storage cabinets available on
models BF3416 and BF1716.
SEE PAGE 27.
Inside Dim
HxWxD
Outside Dim^
HxWxD
Clear Door
HxWxD
Cu. In.
Wt
Shelves
BF1512 (*)(**)
15 x 12 x 13
20¼ x 17¼ x 18¾
15 x 12
2,340
288
1
17 x 16½ x 16
22¼ x 21¾ x 21¾
17 x 16½
4,488
412
1
BF2116 (*)(**)
21 x 16½ x 14½
26¼ x 21¾ x 20¼
21 x 16½
5,024
476
1
34 x 16½ x 16
39¼ x 21¾ x 21¾
34 x 16½
8,976
690
2
Model
BF1716 (*)(**)
BF3416 (*)(**) †
BOLT DOWN KIT INCLUDED, ^ADD 2" FOR DIAL & HANDLE
Hardware on above safes specify (*): Brass (LTG) on Sandstone and Chrome (LTE) on Granite
Color Options Specify (**): (GR) = Granite, (ST) = Sandstone
† 1/2 hour U.L. Fire Rating
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AMSEC CSC SERIES COMPOSITE SAFES are an affordable solution when you
want to protect both documents from fire and valuables from burglary attacks.
During extreme testing procedures the CSC SERIES COMPOSITE safes passed a
2-Hour, 350°F factory fire test certification.
RESIDENTIAL SECURITY
CONTAINER
Interior temperature
less than 350ºF for
a period of
2 hours at 1850ºF
CSC3018 WITH
OPTIONAL STOR-IT CABINET
CSC4520
CSC1913
Features:
Locking Mechanism:
Door:
• Two to four 1½" diameter solid steel
chrome-plated locking bolts.
• Overall thickness of 4-5/8" and is
constructed with a 2" defense barrier of
outer and inner steel plates creating a
burglary resistant structure enclosing a
unique proprietary, fire resistant material.
Body:
• Total protective thickness of 2-7/8"
enclosing a unique, high-density fire and
burglary resistant composite material.
• Durable powder coated adjustable
shelves.
• Removable casters provide easy delivery
and installation.
Fire Endurance:
• 2 hour, 350°F factory fire rating. Tested at
temperatures up to 1700°F.
• Heat expandable intumescent door seal
guards contents against severe fires.
• Two to three 1½" diameter solid steel
dead bolts lock deep into body preventing
door removal during a forced entry
attempt.
• U.L. Listed Group II combination lock with
chrome-plated spy-proof dial. Optional
electronic locks available.
• Lock protected by a tempered glass
relock device.
CSC1413
• Heavy duty steel hinges provide easy,
smooth door operation.
• One internal counter-sunk anchor hole
and mounting hardware are provided to
securely anchor safe.
• Attractively accented with a full width
facia panel and matching three point
handle,
• Durable and attractive charcoal gray
textured finish.
OPTIONAL
STORAGE
CABINETS
AVAILABLE IN
MODELS CSC3018
AND CSC4520.
NO KIT NEEDED,
DRAWERS SLIDE
RIGHT IN.
SEE PAGE 27 FOR
MORE DETAILS
Inside Dim
HxWxD
Outside Dim*
HxWxD
Cu. In.
Wt
Shelves
Rubber Feet
or Casters
CSC1413
14 x 12.5 x 12.2
19.5 x 18 x 19.9
2,135
256
1
Rubber Feet
CSC1913
19 x 12.5 x 12.2
24.5 x 18 x 19.9
2,898
318
2
Rubber Feet
CSC3018
30 x 18 x 16.3
35.5 x 23.5 x 24
8,802
530
3
Casters
CSC4520
45 x 20 x 21.2
50.5 x 25.5 x 28.9
19,080
768
4
Casters
Model
COMMERCIAL SECURITY SAFES
COMMERCIAL SECURITY SAFES
CSC SERIES COMPOSITE SAFES
* Add 2" to outside depth for handle, dial and hinge projection.
* Add 4¼" (casters) and 1" (rubber feet) to outside height.
OPTIONAL LED LIGHT KIT
WITH MOTION SENSOR
AVAILABLE FOR ALL MODELS.
SEE PAGE 26 FOR DETAILS.
19
GUN SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
NEW! HS SERIES - HIGH SECURITY RFX & RF MODELS
RFX703620 & RFX582820
The RF6528 Features:
RF6528
The only U.L. Listed TL-30 burglary and fire resistant gun
safe on the market.
Overall thickness of door is 6” and is constructed with a
3” defense barrier of outer and inner steel plates creating
a single structure enclosing a unique, high density fire
and burglary resistant composite material.
The RF6528 formed body has a total protective thickness
of 3½” enclosing a high density fire resistant composite
material with nuggets and steel fibers.
2 Stage Dual fire seals with silicone seal on door jamb
and expandable Palusol™ seal on door.
A reinforced drill resistant door frame protects the door
and each individual bolt chamber from severe side
attacks.
Group 2M Lock is protected by a proprietary patented
hard plate, dual external relocker and one internal
relocker.
A proprietary inner barrier protects against peeling
attacks.
RF6528
The new RFX Series U.L. Listed TL-30x6, six-sided highsecurity gun safes are made in the United States using
the latest testing procedures set forth by Underwriters
Laboratories.
INTERIOR FOR
RF6528:
“ALL-IN-ONE”
12-18-30 GUN
Model
The high density insulating materials incorporated in
the door and body also insure two hours of certified
fire protection. The superior design and craftsmanship
make the new RFX Series impervious to burglary attacks
attempted by the most sophisticated equipment utilized
today and the vaults contents against intense fires.
No Labor Charge
No Parts Charge
No Freight Charge
Outside
Dimension
HxWxD
RFX703620
76" x 42" x 29¼"
RFX582820
64" x 34" x 29¼"
RF6528
72" x 35" x 29.5"
INTERIORS FOR RFX SERIES:
The new revolutionary RFX Series is constructed with a 3”
defense barrier of inner and outer steel plates enclosing
a unique interlocking heavy duty steel barrier, 12,000 PSI
high-strength concrete and a high-density high-strength
ceramic matrix.
LIFETIME
WARRANTY
Against
Theft & Fire
RESIDENTIAL SECURITY
CONTAINER
RFX703620
RFX Series Safes Feature:
Thickness (Inches)
Interior
Wt. Lbs.
Door
Body
Capacity
6"
3½"
12-14-24-26-38 Gun
4,578
6"
3"
12-18-30 Gun
3,418
6"
3"
12-18-30 Gun
3,455
RFX703620
12-14-24-26-38
GUN
RFX582820
12-18-30 GUN
COLOR OPTIONS FOR
HS SERIES SAFES:
High-Gloss Exterior Colors:
Hunter Green Metallic (HG), Onyx (OX),
Burgundy Metallic (BY), Pearl (PW),
Platinum Metallic (PL), Charcoal Metallic
(CM), Macadamia Metallic (MM)
Textured Exterior Colors:
Granite (GR), Sandstone (ST), Black (BK),
Chocolate Brown (CB)
GUN SAFE FIRE AND BURGLARY PROTECTION
American Security Products Co. is highly acclaimed for offering the industry’s best fire protection. We manufacture the industry’s broadest gamut
of fire-rated products ranging from Underwriters Laboratories (U.L.) Listed 1 and 2 hour fire safes to our independent laboratory tested 2 hr., 1 hr.,
45 minute and 30 minute fire protected gun safes.
*Each safe is designed
to maintain an interior
temperature less
than 350˚F.
Paper products will char at
approximately 450˚F.
20
Series
Fire Label
Outside
Temp
Time
Period
Inside Temp
Less Than
RFX Series
120 Minute
1850ºF
120 min.
350ºF
RF6528
120 Minute
1850ºF
120 min.
350ºF
BF® Series
ETL 120 Minute
1200ºF
120 min.
350ºF
SF Series
60 Minute
1200ºF
60 min.
350ºF
FV Series
45 Minute
1200ºF
45 min.
350ºF
TF Series
30 Minute
1200ºF
30 min.
350ºF
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
THE MOST UNIQUE GUN SAFE IN THE INDUSTRY
THE BF® SERIES FEATURES:
• ½" steel plate door combined with 1"
DryLight insulation. (BF7250 and BF6024 have
3/8" steel plate.)
• 2" total wall thickness on all sides featuring
our poured DryLight insulation and two layers
of steel for exceptional fire and security
protection. Total combined steel thickness of
walls is 7ga.
•U.L. Residential Security Container (RSC)
Burglary Classification.
•11
massive 1½" chrome-plated bolts. Bolt
detent system holds bolts in open position.
•ETL Verified Fire protection of 1200°F for 120
minutes. Designed to maintain an interior
temperature of less than 350°F.
•Adjustable ball bearing hinges.
•Available with Left Swing or Right Swing door
•2 Stage Dual fire seals with silicone seal on
door jamb and expandable Palusol™ seal on
door.
•U.L. Listed Group II Lock with massive hard
plate and two relocking devices.
•Spy-proof, key-locking dial with decorative
five-spoke handle and a convenient pull handle.
•BF6024 offers a chrome or brass “L” handle
and does not come with a pull handle.
•Bold zinc die-cast polished logos and hardware
in brass, chrome or black nickel. (Black nickel
not available on BF6024).
•Optional electronic locks are available.
•Unique mirrored back wall for added interior
visibility.
•Premium Door Organizer (PDO). See Page 27
for more details.
•Standard built in internal AC power port with
removable external power cord.
•4 pre-cut anchor holes.
•Interior features rich pin-dot fabric and
adjustable interior shelving.
NEW BF6024 Gun Safe
120
MINUTES
Fire
Protection
RESIDENTIAL SECURITY
CONTAINER
LIFETIME
WARRANTY
Against
Theft & Fire
No Labor Charge
No Parts Charge
No Freight Charge
BF7240
Shown with Optional Stor-it Cabinets and LED Light Kit
Poured Drylight Fill
Model
Outside Dimension
HxWxD
Thickness (Inches)
Door
Overall / Steel plate
Interior
Wt. Lbs.
Body
Capacity
1,789
BF7250
71.25" x 50" x 28"
4 / / ⅜"
2
12-23-24-35-47 + 2 Gun
73 + 2 Gun
BF7240
71.25" x 40" x 26"
4¾ / ½"
2
12-14-24-26-38 + 2 Gun
58 + 2 Gun
1,585
BF6636
65.25" x 36" x 26"
4¾ / ½"
2
12-19-31 + 2 Gun
1,319
BF6030
59.25" x 30" x 26"
4¾ / ½"
2
11-14-25 + 2 Gun
1036
BF6032
59.25" x 30" x 21"
2
7-11-18 + 2 Gun
913
BF6024
59.25" x 24" x 21"
4¾ / ½"
4¾ / ⅜"
2
8-8-16 Gun + 1 Gun
720
5 8
Dimensions listed are exterior dimensions. Add 2-3/8" on all BF safes to overall depth for lock and handle.
BF7250 &
BF6024 are
3/8" Plate
COLOR OPTIONS:
High-Gloss Exterior Colors:
Hunter Green Metallic (HG),
Onyx (OX), Burgundy Metallic (BY),
Pearl (PW), Platinum Metallic (PL),
Charcoal Metallic (CM), Macadamia
Metallic (MM)
Textured Exterior Colors:
Granite (GR), Sandstone (ST), Black (BK),
Chocolate Brown (CB)
Two-Tone Finishes:
Onyx High-gloss door / Black Textured
body or Charcoal Metallic High-gloss
door / Granite Textured body
Any combination available on request
12-23-24-35-47
GUN INTERIOR
for Model BF7250
73 GUN INTERIOR
for Models: BF7250
12-14-24-26-38
GUN INTERIOR
for Model BF7240
58 GUN INTERIOR
for Models: BF7240
12-19-31 GUN
INTERIOR
for Models: BF6636
11-14-25 GUN
INTERIOR
for Models: BF6030
7-11-18
GUN INTERIOR
for Model BF6032
8-8-16
GUN INTERIOR
for Model BF6024
21
GUN SAFES
THE BF® SERIES GUN SAFES
2014 PRODUCT CATALOG
GUN SAFES
AMERICAN SECURITY PRODUCTS CO.
SF SERIES - SIXTY MINUTE FIRE
All SF Series
Safes Feature:
• 3-point handle in brass, chrome or black
nickel and bold zinc die-cast polished
logos in brass, chrome or black nickel.
• ¼" Steel Plate door with 3 layers of fire
insulating material.
• 4-way boltwork with 9 active 1½"
chrome-plated bolts and 5 deadbolts for
a total of 14 bolts.
• Fire protection of 1200°F for 60 minutes.
Designed to maintain an interior
temperature of less than 350°F.
• All-velour interior.
• Premium Door Organizer (PDO). See
Page 27 for more details.
• U.L. Residential Security Container
(RSC) Burglary Classification.
• Four (4) pre-cut anchor holes with
mounting hardware included and one (1)
pre-cut electrical access hole.
• 2 Stage Dual fire seals with silicone seal
on door jamb and expandable Palusol™
seal on door.
• Available in all high gloss, textured and
two-tone finishes.
• Body constructed of 12-gauge solid
steel plate with a fire insulating material.
• U.L. Listed Group II Lock with massive
hard plate and two relocking devices.
• Optional electronic lock available.
• New ultra smooth cam driven locking
mechanism with increased handle
rotation.
SF6030
RICH VELOUR
INTERIOR
LIFETIME
WARRANTY
Against
Theft & Fire
RESIDENTIAL SECURITY
CONTAINER
No Labor Charge
No Parts Charge
No Freight Charge
COLOR OPTIONS:
High-Gloss Exterior Colors:
Hunter Green Metallic (HG),
Onyx (OX), Burgundy Metallic (BY),
Pearl (PW), Platinum Metallic (PL),
Charcoal Metallic (CM),
Macadamia Metallic (MM)
Textured Exterior Colors:
Granite (GR), Sandstone (ST),
Black (BK), Chocolate Brown (CB)
SF Two-Tone Finishes:
Onyx High-gloss door / Black Textured body
Charcoal High-gloss door / Granite Textured body
SF6030 WITH NEW STANDARD
STOR-IT PDO AND OPTIONAL
STOR-IT CABINETS
Any combination available on request
Model
Outside
Dimension
HxWxD
Thickness (Inches)
Door
Overall / Steel plate
Interior
Body
Capacity
59" x 36" x 26"
4¼ / ¼"
12 ga
17-17-34 + 2 Gun
850
SF6030
59" x 30" x 26"
4¼ / ¼"
12 ga
14-14-28 + 2 Gun
706
SF6032
59" x 30" x 21"
4¼ / ¼"
12 ga
9-9-18 +2 Gun
648
SF5924
59" x 24" x 18"
4¼ / ¼"
12 ga
8-8-16 Gun + 1 Gun
514
22
14-14-28
GUN INTERIOR
for Model: SF6030
9-9-18
GUN INTERIOR
for Model: SF6032
8-8-16
GUN INTERIOR
for Model: SF5924
Wt. Lbs.
SF6036
Dimensions listed are exterior dimensions. Add 2" to overall depth for lock and handle.
17-17-34
GUN INTERIOR
for Model: SF6036
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
GUN SAFES
FV SERIES - 45 MINUTE FIRE
LIFETIME
WARRANTY
Against
Theft & Fire
No Labor Charge
No Parts Charge
No Freight Charge
FV6030E5 WITH STOR-IT PDO
FV7240E5
FV Series Safes Feature:
• 3⁄16" Steel Plate door with 2 layers of fire
insulating material.
• Fire protection of 1200°F for 45 minutes.
Designed to maintain an interior
temperature of less than 350°F.
• 2 Stage Dual fire seals with silicone seal
on door jamb and expandable Palusol™
seal on door.
• Body constructed of 12-gauge (FV7240E5
- 11ga) solid steel plate
with a fire insulating material.
• Every FV Series gun safe comes standard
with AMSEC’s ESL5 Electronic Lock with
illuminated keypad.
• Optional Group II combination lock
available.
• Textured Black exterior and plush gray
fabric interior.
• Drill resistant hardplate with external
spring-loaded re-locking device.
• Premium Door Organizer (PDO). See Page
27 for more details.
• New ultra smooth cam driven locking
mechanism with increased handle rotation.
• Four (4) pre-cut anchor holes with
mounting hardware included and one (1)
pre-cut electrical access hole.
• 3-point chrome tri-spoke handle featuring
slip clutch feature for additional security to
prevent excessive torque to retract bolts
during attempted break in. and bold zinc
die-cast polished chrome logo.
• 4-way boltwork with 9 massive 1¼"
chrome-plated locking bolts, and 5
deadbolts for a total of 14 bolts.
Thickness (Inches)
Outside
Dimension
HxWxD
Overall / Steel plate
FV7240E5
72" x 40" x 26"
Model
GRAY FABRIC INTERIOR
Door
Interior
Wt. Lbs.
Body
Capacity
35/8 / 3/16
11 ga
15-15-15-30-45 +2 Gun
954
FV6036E5
59" x 36" x 26"
35/8 / 3/16
12 ga
17-17-34 +2 Gun
724
FV6030E5
59" x 30" x 26"
3 /8 / /16
12 ga
15-15-30 + 2 Gun
608
FV6032E5
59" x 30" x 21"
35/8 / 3/16
12 ga
11-11-22 + 2 Gun
578
5
3
Dimensions listed are exterior dimensions. Add 2" to overall depth for lock and handle.
AMSEC GUN SAFE NO COST
LIFETIME BURGLARY & FIRE
REPLACEMENT WARRANTY:
• No Cost - Break-In Warranty
• No Cost - Attempted Break-In Warranty
• No Cost - Fire Warranty
See Our Gun Safe Catalog for more details.
15-15-5-30-45
GUN INTERIOR
for Model: FV7240E5
17-17-34
GUN INTERIOR
for Model: FV6036E5
15-15-30
GUN INTERIOR
for Model: FV6030E5
11-11-22
GUN INTERIOR
for Model: FV6032E5
23
GUN SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
TF SERIES - THIRTY MINUTE FIRE
LIFETIME
WARRANTY
Against
Theft & Fire
TF5517E5
TF5924E5
No Labor Charge
No Parts Charge
No Freight Charge
• 4-way boltwork with 9 massive 1¼"
chrome-plated locking bolts, and 5
deadbolts for a total of 14 bolts.
TF5924E5 Features:
• 3/16" Steel Plate door with 2 layers of fire
insulating material.
• Adjustable ball bearing hinges.
• Fire protection of 1200°F for 30 minutes.
Designed to maintain an interior
temperature of less than 350°F.
• Premium Door Organizer (PDO). See page
27 for more details.
• Textured Black exterior and Mocha fabric
interior.
• 2 Stage Dual fire seals with silicone seal
on door jamb and expandable Palusol™
seal on door.
• Four (4) pre-cut anchor holes with
mounting hardware included and one (1)
pre-cut electrical access hole.
• Body constructed of 14-gauge solid steel
plate with a fire insulating material.
• AMSEC’s ESL5 Electronic Lock with
illuminated keypad.
• 3/16" Steel Plate door with 2 layers of fire
insulating material.
• Drill resistant hardplate with external
spring-loaded re-locking device.
• 3-point chrome tri-spoke handle featuring
slip clutch feature for additional security to
prevent excessive torque to retract bolts
during attempted break in.
• Bold zinc die-cast polished chrome logo.
Model
• Fire protection of 1200°F for 30 minutes.
Designed to maintain an interior
temperature of less than 350°F.
• Chrome “L” handle featuring slip clutch
feature for additional security to prevent
excessive torque to retract bolts during
attempted break in.
• 4-way boltwork with 5 active 1" chromeplated bolts and 3 deadbolts for a total of
8 bolts.
• Premium Door Organizer (PDO). See page
27 for more details.
• Textured Black exterior and Mocha fabric
interior.
• Durable hinges.
• 2 Stage Dual fire seals with silicone seal
on door jamb and expandable Palusol™
seal on door.
• Body constructed of 14-gauge solid steel
plate with a fire insulating material.
• Four (4) pre-cut anchor holes with
mounting hardware included and one (1)
pre-cut electrical access hole.
• Warranty: 1 Year Parts and Labor.
TF5517E5
Outside
Dimension
HxWxD
Thickness (Inches)
Door
Overall / Steel plate
TF5924E5
59" x 24" x 18"
35/8 / 3/16
TF5517E5
55.25" x 17.34" x 16"
3¼ / 3/16
24
• Optional Group II combination lock
available.
• Bold zinc die-cast polished chrome logo.
The TF5517E5:
• Optional Group II combination lock
available.
TF5924E5
• AMSEC’s ESL5 Electronic Lock with
illuminated keypad, drill resistant
hardplate and external spring-loaded
re-locking device.
Interior
Wt. Lbs.
Body
Capacity
14 ga
8-8-16 Gun + 1 Gun
388
14 ga
11 Gun
286
8-8-16
GUN INTERIOR
TF5924E5
11
GUN INTERIOR
TF5517E5
Dimensions listed are exterior dimensions.
Add 2" to overall depth for lock and handle.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
DEFENSE VAULT
The AMSEC Defense Vault puts home
security where you need it!
There’s no better place to store your home-defense
weapon within arm’s reach than under your bed in the
secure and easily accessible AMSEC Defense Vault!
The High Security electronic lock is easy to use, and in a
matter of seconds, the door is open and the weapon is in
hand!
Whether you currently have a safe or not, the Defense
Vault should seriously be considered for any gun owner.
Features AMSEC’s new ESL5 electronic lock with an
illuminated keypad. Bright, backlit keys let you enter your
PIN code, even in the dark.
The AMSEC Defense Vault is constructed of 14 ga. steel
with a unique 5-point slide locking bar and features a
foam-padded slide-out gun tray and 4 pre-cut anchor
holes with mounting hardware.
Model
Outside Dimension
HxWxD
Wt. Lbs.
6" x 52" x 14"
90
DV652
Tray Size
3 3/8" x 43¼" x 13"
VAULT DOOR VD8030SF / VD8030BF
Standard Features of The Vault Door:
• U.L. Listed Group II Lock with massive hard plate and two relocking devices.
• Spy-proof key-locking dial with matching five-spoke handle, pull handle and bold zinc die-cast
logo. Available in polished brass, chrome or black nickel finish.
• 10 massive 1½" chrome-plated bolts. (Note: no deadbolts required on In-Swing door)
• Select from four textured finishes.
• Commercial grade, Vault Door hinges.
• 2 Stage Dual fire seals with silicone seal on door jamb and expandable Palusol™ seal on door.
• New - Adjustable door frame slides together to fit a wall thickness of 4-3/4" to 9-3/4".
• Safety Lock Release: allows you to safely exit the vault room from inside. It also allows you to
close and lock the door from the inside when equipped with an electronic lock, turning your
vault into a safe room.
Special Features of the VD8030SF & VD8036SF:
• 2" thick door offers a defense barrier constructed of a 1/8" inner and ¼" outer steel plates
filled with a fire insulation material that provides a barrier against extreme heat.
Special Features of the VD8030BF & VD8036BF:
• 2" thick door offers a defense barrier constructed of a ½" steel plate door combined with
1-3/8" DryLight insulation that provides a barrier against extreme heat.
Model
VD8030SF
VD8030SFIS
VD8036SF
VD8030SF
VD8030BF/VD8030SF
VD8030BF
VD8030SF
VD8036SFIS
VD8030BF
VD8030BFIS
VD8036BF
VD8036BFIS
Description
Wall Opening
Door Opening
Weight
(Door Only)
Shipping
Weight
Vault Door
79½" x 29½"
77½" x 24¾"
523
667
77" x 19¼"
505
649
79½" x 35½
77½" x 31¾"
612
782
77" x 26¼"
575
745
79½" x 29½"
77½" x 24¾"
695
839
77" x 19¼"
672
816
77½" x 31¾"
819
989
77" x 26¼"
792
962
In-Swing Vault Door
Vault Door
In-Swing Vault Door
Vault Door
In-Swing Vault Door
Vault Door
In-Swing Vault Door
79½" x 35½"
25
VAULT DOOR
VAULT DOOR
DEFENSE VAULT
DEFENSE VAULT
GUN SAFE ACCESSORIES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
GUN SAFE ACCESSORIES AND OPTIONS
BATTERY OPERATED
LIGHT KIT
This light fits any safe, yet
gives off a super bright
light, letting you see the
contents of your safe
easily. Battery operated.
PISTOL RACK
Ideal for organizing pistols inside your safe.
This four gun pistol
rack sits on top of an
interior shelf.
“AR” RACK
LED LIGHT KITS
“AR” gun racks are
fully adjustable and
custom fit in the side
shelf area of each “BF”
series gun safe. Each
rack is designed with
enough clearance to
accommodate extra large
front sights or optics.
AMSEC introduces the new HIWL120 LED
AC power light kit with built-in motion sensor.
The HIWL120 has two 39" light strips with
120 high-intensity white LED’s and a motion
sensor that automatically turns itself on when
motion is detected and turns itself off 30
seconds after you leave the area.
The new AMSEC HIWL120 LED AC power
light kit can be installed on any AMSEC safe.
LED Light Kit
SLIDE-OUT WEAPONS
STORAGE RACK
.50 CALIBER HANDLE
Available in Black Nickel.
5-Spoke on BF® Gun Safe,
3-Spoke on SF Gun Safe.
(BF® GUN SAFES ONLY)
Motion Sensor
This six-gun rack slides
out for easy access to
your firearms. Fits models
BF7250, BF7240, BF6636
and BF6030.
GUNSAVER
DEHUMIDIFIER
Will constantly guard your
guns against the threat of
rust, pitting and moisture
damage. Electrical access
is required.
JEWELRY TRAY
Conveniently fits into
every safe.
Burgundy felt lined.
10-3/8” x 9-3/8” x 2”
PREMIUM UPGRADE PACKAGE FOR HS, BF® AND SF SAFES
When you choose to upgrade your HS, BF® or SF Series safe with a “Premium Package,” we’ll
add on some of our most popular options including a jewelry tray, a Gunsaver dehumidifier and
an LED light kit with power strip. (NOTE: No power strip will be supplied on BF Series safes
DESSICANT
Prevents rust and
moisture damage.
Recommended
for safes without
electrical access.
HANDGUN SECURITY
with integrated internal power outlet).
HANDGUN SECURITY
NEW!
PS1210HD
Heavy-Duty
Handgun
Safe
Protective high density pluck foam-lined
interior.
Four pre-drilled bolt down holes.
Packaged for UPS/FedEx shipments.
Made in the USA.
Features:
PB3 Handgun
Safe
High strength 10 ga
solid steel body.
Features:
Massive 3/16 steel
door with two solid steel dead
bars and gas piston for easy
opening.
Welded and concealed continuous hinge.
Reliable fast access Simplex push button
mechanical locking device.
Strong, pry-resistant locking bolt.
Locking mechanism protected by steel
housing, impervious to punch attacks.
Charcoal gray textured finish with chrome
hardware.
Heavy-duty chrome carrying handle.
26
Deep blue powder
coated finish with chrome
hardware.
Heavy- duty chrome handle.
Strong, pry-resistant chrome locking bolt.
Interior cushioned with foam lining to protect
against scratches.
Easy to change combination with
programmable override code.
Four (4) AA batteries provides over 5,000
openings with
low-battery indicator.
Power override battery box included.
IRC412 Drawer Safe
Heavy duty steel
construction offers
excellent burglary
protection.
Convenient
motorized
locking system,
incorporating the
latest technology.
Easy to read, large LED display lets you
know the status of the safe.
Reliable ADA approved keypad.
4 to 6 digit combination, standard hotel room
configuration (customer sets new combination
every time safe is used, quickly and easily), or
electronic credit card.
Lock-out penalty if the combination is
entered wrong, the safe will lock up for 5
minutes, frustrating the would-be burglar.
Emergency key-lock override system with 2
keys.
Fits in a drawer and only requires 5”
clearance
Spacious interior fits tablets and compact
lap top computers.
Exterior Dimensions
Weight
Exterior Dimensions
Weight
Exterior Dimensions
Weight
10.25” x 12.5” x 4.25”
24 lbs
8h x 12w x 4d
10 lbs
4.5 h x 12 w x 14d
15 lbs
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
These elegant, well-appointed 2-DRAWER
AND 4-DRAWER INTERIOR CHESTS are finely
crafted in solid-wood maple drawer fronts and maple veneer and finished in a rich
honey maple stain. Recessed door pulls give these cabinets a more streamlined
appearance and makes for an easier fit into a variety of AMSEC safes. All drawers
are elegantly lined in a silky, dark red felt with heavy-duty, ball-bearing drawer
glides and include a variety of Stor-It Jewelry Organizer Inserts. Each insert can be
removed for easy viewing, selecting and protection of your jewelry.
2-DRAWER OPTION:
• Top drawer includes a Three Compartment Ring
Organizer and a Seven Compartment Jewelry
Organizer. Bottom drawer can be used for bulky
items or converts to a file drawer.
• Outside Dimensions: 16.5" x 15.875" x 14"
• Weight: 28 lbs.
4-DRAWER OPTION:
• Top drawer features a three
compartment ring organizer and
a seven compartment jewelry
organizer. Drawer two features
a three compartment necklace
organizer. Drawer three features a four
compartment watch organizer. Drawer
four can be used for bulky items, or
add more Stor-it Jewelry Organizers.
STOR-IT CABINETS ARE AVAILABLE IN THE
FOLOWING SAFE MODELS:
• Outside Dimensions:
16.5" x 15.875" x 14"
CE AND CF MODELS: 2518* / 3524* / 5524* / 6528* / 7236*
• Weight: 29 lbs.
* No kit needed. Drawers slide right in.
GUN SAFES: RF6528, RFX703620, RFX582820, BF7250*,
BF7240, BF6636, BF6030, SF6036 and SF6030
BURGLARY/FIRE SAFES: BF1716* / BF3416*
CSC MODELS: CSC3018* AND CSC4520*
PREMIUM DOOR ORGANIZER RETROFIT KITS
The AMSEC Premium Door Organizer (PDO)
maximizes storage space, offers quick access to
commonly used items, and are easily installed on
any gun safe.
All PDO’s include:
• Various see-through pouches and zippered
pockets to store valuables.
• Two rows of holders for storage of choke tubes,
small flashlights and ammo.
• Two full-width pistol storage systems to
accommodate multiple handguns. Comes with
four holsters. Additional holsters can be purchased
separately.
• A long gun storage system that accommodates
two guns. Includes the AMSEC exclusive “no
hassle” quick release band.
• PDO Model 28 offers a zippered pocket large
enough to store letter-size folders.
MODEL 13
MODEL 19
MODEL 28
27
STORAGE OPTIONS
STORAGE OPTIONS
STOR-IT CABINETS
HOME SECURITY
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AM SERIES HOME SECURITY SAFES
• Mocha fabric interior including back-cover
and firewalls.
• 3-way boltwork with 5 active 1¼” diameter
chrome-plated steel locking bolts (2020
Model has 4 active locking bolts).
• Deep blue textured finish with bold,
elegant American Security logo.
• 4 pre-cut anchor holes with mounting
hardware included.
• Every AM Series home security safe now
comes standard with AMSEC’s ESL5
Electronic Lock with Illuminated Keypad,
protected by a drill-resistant hard plate.
• Fire protection of 1200°F for a period of 30
minutes. Designed to maintain an interior
temperature of less than 350°F.
• Warranty: 1 Year Parts and Labor
• Adjustable ball bearing hinges.
• High-strength unitized 12 ga. solid steel
body.
AM4020E5
• Massive 1¹⁄8" recessed door constructed
of a ¼" solid steel plate and a fire
insulating material.
Thickness
Model
Outside
HxWxD
Inside
HxWxD
Cubic
Inches
Door
Body
Wt.
Lbs.
Interior
Shelves
Bolts
AM2020E5
20 x 20 x 20
17 x 18¼ x 14½
4,710
1½
12 ga
158
1
6
AM3020E5
30 x 20 x 20
27 x 18¼ x 14½
7,402
1½
12 ga
215
2
8
AM4020E5
40 x 20 x 20
37 x 18¼ x 14½
10,094
1½
12 ga
270
3
8
AM2020E5
ELECTRONIC SECURITY SAFES
EST813, EST916, EST1014,
EST2014
Features:
• New State-of-the-art DL5000 electronic lock
with a large 3 ¾" touch screen LCD input
display allows smooth and easy operation.
• Mode altering display changes from orange
in standby mode to bright blue in the open
position.
EST916
EST813
EST2014
• Can be bolted to the wall or floor.
• Accepts (2) user codes and can show open
door records for the past 14 entries.
• LCD touch screen display shows low-battery
indicator, time, date and keypad.
• Emergency key-lock override system with
two (2) keys, power override battery box,
built-in spy-proof function and motion
detector alert.
• Heavy 14 gauge solid steel construction,
plus dual live bolts made also of heavy
gauge steel.
• Carpeted base.
• Pry-resistant recessed door with internal
hinges for anti-theft protection.
• Mounting feet and anchor hardware
standard.
• Models EST1014 and EST2014 have one
removable shelf.
• Warranty: 1 year parts and labor.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
Cu. In.
Capacity
Wt
EST813
7-11/16 x 12-13/16 x 5½
7-7/8 x 13 x 7¾
5-5/8 x 9
498
16
EST916
8-13/16 x 16-11/16 x 12
9 x 16-7/8 x 14-1/8
6¾ x 13
1,765
30
EST1014
9-9/16 x 13-15/16 x 7¾
9¾ x 14-1/8 x 9¾
7-5/8 x 10¼
1,032
22
EST2014
19-9/16 x 13-9/16 x 10
19-3/4 x 13-3/4 x 12-1/4
17-1/8 x 9-1/4
2,602
40
Model
28
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AMSEC’s IN-ROOM ELECTRONIC SAFE, with its easy installation, maintenance and management features has become a
popular safe in the hospitality industry. Designed with the traveling guests in mind, the IRC916E will adequately secure laptop
computers, cameras, jewelry and other valuables in the most user-friendly safe made.
ALSO AVAILABLE:
THE IRC412
DRAWER SAFE.
SEE PAGE 26
FOR MORE
INFO
•
•
•
•
•
IRC916E
STANDARD FEATURES:
• Heavy duty steel construction offers
excellent burglary
protection.
• Convenient motorized locking
system, incorporating the latest
technology.
• Easy to read, large LED display lets
you know the status of the safe.
• 4 digit combination, standard hotel
Model
IRC916E
•
•
room configuration (customer sets
new combination every time safe
is used, quickly and easily), or
electronic credit card.
• Reliable ADA approved keypad.
• Runs on 4 AA batteries. If batteries
should go dead, each safe has a bypass power cable.
• Lock-out penalty if the combination
is entered wrong, the safe will lock up
for 15 minutes, frustrating the wouldbe burglar.
Emergency key-lock override system
with 2 keys.
Spacious interior fits most lap top
computers.
Two anchor holes with mounting
hardware included.
Attractive carpeted bottom hides
anchor bolts.
Electrostatic powder-coated finish in
textured black.
Guest instruction label included.
Packaged for UPS shipment.
OPTIONS:
• Hand-held, programming device,
offering audit trail and electronic
override (IRCPROG).
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
Cu. In.
Capacity
Wt
8-13/16 x 15-13/16 x 12
9 x 16 x 14
6-9/16 x 13
1,672
29
ESF1214 FINGERPRINT SAFE
FEATURES:
• State-of-the-art fingerprint electronic lock.
• Motorized bolt work system with 2 chrome-plated solid-steel locking
bolts.
• Spring-assisted door auto opens when unlocked.
• Laser-cut arched door design with heavy-duty 7/16" solid steel door and
casing.
• 1/8" thick solid steel body.
• Attractive textured black finish.
• 1 adjustable shelf.
• Includes: 1 emergency key-lock with 2 keys and anchor kit.
ESF1214
Model
ESF1214
• Large 1,692 cu. in. storage capacity.
• Warranty: 1 year parts and labor.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
Cu. In.
Capacity
Wt
11.25 x 14.5 x 10.38
11.5 x 14.75 x 12.75
7.63 x 10.69
1,692
54
29
ELECTRONIC SAFES
IN-ROOM ELECTRONIC SAFES
“B” AND “C” RATE SECURITY CHESTS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
BLB AND BLC SERIES
AMSEC “B” AND “C” RATE SECURITY CHESTS are designed to provide secure storage at an economical price. In addition
to meeting the requirements of the Insurance Offices Manual of Burglary Insurance, these units offer an appearance and many
features similar to AMSEC’S higher rated TL-15 models.
STANDARD FEATURES
DOOR:
• 1" (“C” Rate), or ½" (“B” Rate) steel pryresistant recessed door.
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Additional spring loaded relocking device,
activated by a punching attack.
• Locks and relocks protected by a large
carburized hardplate.
• A handle activated locking mechanism
consisting of three 1" chromed steel
locking bolts. (five in BLB and BLC4024
models).
• Solid steel full length dead bar prevents
door removal if hinges are removed during
a forced entry attempt.
• Adjustable ball bearing hinges.
BODY:
• ½" continuously welded (“C” rate) or 1/4"
(“B” Rate) solid steel bodies.
• Body reinforcing frame gives the
appearance of 1" thick walls to discourage
attack.
• Adjustable shelves.
• Attractive Gray textured finish. Other
colors available.
• Custom sizes, interior options and high
security features available.
• Left swing door optional.
BLC3018
B-Rate Premium Free-Standing Security Chest
Inside Dim
HxWxD
Outside Dim*
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt
Shelves
BLB2018
20 x 18 x 12
20½ x 18½ x 15
18 x 16
4,320
218
2
BLB3018
30 x 18 x 16
30½ x 18½ x 19
28 x 16
8,640
312
2
BLB3024
30 x 24 x 20
30½ x 24½ x 23
28 x 22
14,400
360
3
BLB4024
40 x 24 x 20
40½ x 24½ x 23
38 x 22
19,200
445
4
Model
*Add 2" to outside depth for handle, dial and hinge projection. Custom design available on request.
C-Rate Premium Free-Standing Security Chest
Inside Dim
HxWxD
Outside Dim*
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt
Shelves
BLC2018
20 x 18 x 12
21 x 19 x 16
18½ x 16½
4,320
370
2
BLC3018
30 x 18 x 16
31 x 19 x 20
28½ x 16½
8,640
550
2
BLC3024
30 x 24 x 20
31 x 25 x 24
28½ x 22½
14,400
740
3
BLC4024
40 x 24 x 20
41 x 25 x 24
38½ x 22½
19,200
925
4
Model
*Add 2" to outside depth for handle, dial and hinge projection. Custom design available on request.
30
2014 PRODUCT CATALOG
TL-15 & TL-30 MONEY CHESTS
AMSEC TL-15 and TL-30 U.L. Listed MONEY CHESTS qualify for Mercantile
& Broadform Insurance Class ER (TL-15) and F (TL-30) with a banking rating of
BR (TL-15) and G (TL-30). AMSEC MONEY CHESTS offer the highest level of
security available with many outstanding features and a wide range of options.
CDXE2020
TL-30 Composite
Body and
Plate Door
DXE1818
TL-15 Plate Body
and Door
FEATURES
DOOR:
• DXE and CDXE models are TL-15 rated
constructed of ¾" thick solid steel plate.
• DXF and CDXF models are TL-30
constructed of 1¾" thick laminated steel
with a special hardened drill resistant
plate.
• Oil impregnated bronze bearing hinges.
BODY:
• DXE models: Consist of ½" thick steel
plate (100,000 P.S.I. minimum tensile
strength). All external seams are beveled
and continuously welded.
• DXF models: Models under 50" in height
consist of ½" thick steel plate with100,000
P.S.I. minimum tensile strength. DXF models
over 50" in height constructed of ¾" thick
steel plate with 75,000 P.S.I. minimum
tensile strength. All external seams are
beveled and continuously welded.
• CDXE and CDXF models: consist of 3¼"
thick body constructed of inner and outer
steel plates enclosing a high density
composite material.
• Shelf strips installed allowing shelf
adjustment. Shelves optional.
LOCKING MECHANISM:
• U.L. listed Group II key changeable
combination lock, with relock and 1 million
possible combinations.
• Locks and relocks protected by a large
proprietary drill shattering composite
hardplate.
• A handle activated locking mechanism
consisting of two to five 1" chromed steel
locking bolts.
• Five boltwork sizes allow AMSEC to build
units from 12" (10½" for DXE/DXF) to 88"
high, widths from 14" to 41".
• Solid steel dead bar prevents door
removal if hinges are removed during a
forced entry attempt.
• Compact locking mechanism and boltwork
cover allow for optional door mounted
coin racks.
HINGES:
• Fabricated from high strength steel with
precision machined alloy dowel pins.
• Oil impregnated bronze bearing assures
easy opening doors and reduced
maintenance.
• Vertical height adjustment.
FINISH:
• Available in Satin Black, Parchment,
Standard Gray, Blue Gray, Romanesque
Gray, Charcoal Gray, Granite, Sandstone
or Chocolate Brown textured finish.
• Single auxiliary spring loaded relocking
device, activated by a punching attack.
FOR A DETAILED CHART OF SIzES AND SPECS FOR THESE MODELS,
PLEASE SEE THE AMSEC PRICE LIST, PAGE 12.
OPTIONS:
• Spyproof dial
• Key lock dial
• Coin racks
• Managers lockers
• Interior lockers
• Interior drawers
• Adjustable shelves
• Group 1 and 1R locks
• Electronic locks
• Access Control Systems
• Key-Op locks
• Dual combination locks (some models)
• 144 hour timelock
• 15 minute time delay lock
• External day lock
• Claddings
• Anchor bolt assembly
• Left swing door
• Internal rotary hopper
• Internal deposit slot
• Internal deposit chutes
• Hidden compartments
• Modular alarm
• Hold up duress alarm
• Special sizes
• Custom colors
31
DXE / DXF AND CDXE / CDXF U.L. LISTED
DXE / DXF AND CDXE / CDXF U.L. LISTED
AMERICAN SECURITY PRODUCTS CO.
ACF TL-30 SERIES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
U.L. LISTED FIRE RATED MONEY CHEST
AMSEC TL-15 and TL-30 U.L. Listed MONEY CHESTS qualify for Mercantile
& Broadform Insurance Class ER (TL-15) and F (TL-30) with a banking rating of
BR (TL-15) and G (TL-30). AMSEC MONEY CHESTS offer the highest level of
security available with many outstanding features and a wide range of options.
• Locks and relocks protected by a large
proprietary drill shattering composite
hardplate.
• A handle activated locking mechanism
consisting of three to five 1" diameter
chromed steel locking bolts.
• Five boltwork sizes allow AMSEC to build
units from 12" to 82" high, widths from 18"
to 48" (interior dimensions).
ACF4024
SHOWN WITH
AUXILIARY LOCK
FEATURES:
• 5½" thick door constructed of outer and
inner steel plates enclosing a high density
proprietary composite material.
• Two hour, 350°F factory fire rating. Tested
at temperatures up to 1850°F.
BODY:
• 3¼" thick body constructed of inner and
outer steel plates enclosing a high density
proprietary composite material.
• Door and inner jamb surrounded by thick
solid steel bars.
• Adjustable shelves.
LOCKING MECHANISM:
• Spyproof dial
• Key lock dial
• Coin racks
• Managers lockers
• Interior lockers
• Interior drawers
• Adjustable shelves
• Handle designed to shear in case of
forced entry attempt.
• Group 1 and 1R locks
• Solid steel dead bars prevent door
removal if hinges are removed during a
forced entry attempt.
• Access Control Systems
• Compact locking mechanism allows for
optional door mounted coin racks.
DOOR:
OPTIONS:
HINGES:
• Ball bearing hinges fabricated from high
strength steel.
• Precision machined alloy dowel pins.
• Oil impregnated bronze bearing assures
easy opening doors and reduced
maintenance.
• Vertical height adjustment.
• Electronic locks
• Key-Op locks
• Dual combination locks (some models)
• 144 hour timelock
• 15 minute time delay lock
• External day lock
• Anchor bolt assembly
• Left swing door
• Internal rotary hopper
• Internal deposit slot
• Internal deposit chutes
• Hidden compartments
• Modular alarm
FINISH:
• Available in Satin Black, Parchment,
Standard Gray, Blue Gray, Romanesque
Gray, Charcoal Gray, Granite, Sandstone
or Chocolate Brown textured finish.
• Hold up duress alarm
• Special sizes
• Custom colors
• Custom designs
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Single auxiliary spring-loaded relocking
device, activated by a punching attack.
Model
ACF 2020
Inside Dimension
Outside Dimension*
Clear Door
Cu. In.
Wt
20 x 20 x 20
26¾ x 26½ x 29
19 x 18¾
8,000
1,069
ACF 2020XD
20 x 20 x 24
26¾ x 26½ x 33
19 x 18¾
9,600
1,170
ACF 3020
30 X 20 X 20
36¾ x 26½ x 29
29 x 18¾
12,000
1,369
ACF 3020XD
30 X 20 X 24
36¾ x 26½ x 33
29 x 18¾
14,400
1,492
ACF 4024
40 X 24 X 20
46¾ x 30½ x 29
39 x 22¾
19,200
1,849
ACF 4024XD
40 X 24 X 24
46¾ x 30½ x 33
39 x 22¾
23,040
2,003
ACF 5024
50 X 24 X 20
56¾ x 30½ x 29
49 x 22¾
24,000
2,176
ACF 5024XD
50 X 24 X 24
56¾ x 30½ x 33
49 x 22¾
28,800
2,351
ACF 6030
60 X 30 X 20
66¾ x 36½ x 29
59 x 28¾
36,000
2,847
ACF 6030XD
60 X 30 X 26
66¾ x 36½ x 35
59 x 28¾
46,800
3,162
* Add 2" to outside depth for handle, dial and hinge projection. Standard with two shelves.
Optional 3-way boltwork available on the ACF line, retail price $160.00. Custom size/design quoted upon request.
32
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
The new Amvaultx6 U.L. Listed TL-30x6, six-sided high security composite safes
are made in the United States using the latest 2011 testing procedures set forth by
Underwriters Laboratories.
The new revolutionary Amvaultx6 is constructed with a 3” defense barrier of inner and
outer steel plates enclosing a unique interlocking heavy duty steel barrier, high strength
concrete exceeding 12,000 PSI and a high-density high-strength ceramic matrix.
The high density insulating materials incorporated in the door and body also insure two
hours of certified fire protection. The superior design and craftmanship make the new
Amvaultx6 impervious to burglary attacks attempted by the most sophisticated equipment
utilized today and the vaults contents against intense fires.
Model
Dimension
Dimension*
Outside
Clear
Door
Cu.
In.
Wt
CFX252016
25 x 20 x 16
31 x 26 x 25¼
25 x 20
4.6
1,433
6"
1
CFX352020
35 x 20 x 20
41 x 26 x 29¼
35 x 20
8.1
1,946
6"
2
CFX452020
45 x 20 x 20
51 x 26 x 29¼
45 x 20
10.4
2,343
6"
3
CFX582820
58 x 28 x 20
64 x 34 x 29¼
58 x 28
18.8
3,418
6"
4
CFX703620
70 x 36 x 20
76 x 42 x 29¼
70 x 36
29.2
4,578
6"
4
Inside
AMVAULTX6 TL-30X6
AMVAULTx6 TL-30x6 HIGH SECURITY SAFE
Door
Shelves
Thickness
* Add 2" to outside depth for handle, dial and hinge projection.
Optional 3-way boltwork available on the CFX line, retail price $160.00.
AMSEC’s ACF TL-30 TWO DOOR DEPOSITORY SAFE offers complete cash management
versatility for any operation that requires a nonreturnable deposit such as armored car
companies, convenience stores, restaurants, etc. The U.L. listed TL-30 composite construction
offers peace of mind when overnight protection is required.
In addition to the outstanding features listed under ACF TL-30 Money Chest, the ACF4824DS
Depository safe also offers:
TOP DEPOSIT /
STORAGE COMPARTMENT
ACF4824DS
Options:
• Outer door equipped with a U.L. listed Group
II combination lock and chrome plated front
read dial.
• Large storage capacity: accommodates up
to nine cash register trays.
• Large 3" x 18" deposit chute is protected by
an “anti-fish”, saw-tooth, hinged baffle.
• Two adjustable shelves.
• Door mounted four-opening rolled coin
storage rack.
BOTTOM RECEIVING
COMPARTMENT
• Outer door equipped with a U.L. listed Group
II combination lock, chrome plated front read
dial and an auxiliary key-op lock for dual
control or armored car pick up.
Model
ACF4824DS
Inside Dimension
TOP 26 x 18 x 14
BTM 14 x 18 x 17
• Electronic locks, Group 1 and 1R locks.
• Dual combination locks (Receiving
compartment only).
• Spyproof dial, Keylock dial.
• Modular alarm, Holdup alarm.
• Interior lockers, Interior drawers, Adjustable
shelves.
• Custom sizes/designs quoted upon request.
• Access Control Systems.
FINISH
• Available in Satin Black, Parchment,
Standard Gray, Blue Gray, Romanesque
Gray, Charcoal Gray, Granite, Sandstone or
Chocolate Brown textured finish.
Outside Dimension*
Clear Door
Cu. In.
Wt
47¾ x 24½ x 26
25 x 16¾
13 x 16¾
6,552
4,284
1746
* Add 2" to outside depth for handle, dial and hinge projection. Standard with two shelves.
Optional 3-way boltwork available on the ACF line, retail price $160.00. Custom size/design quoted upon request.
33
ACF TL-30 SERIES
U.L. LISTED FIRE RATED DEPOSITORY SAFE
AMVAULT TL-30 AND TL-15
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
FIRE RATED COMPOSITE SAFES
During extreme testing procedures, AMVAULT
COMPOSITE SAFES demonstrated the ability
to withstand severe attacks by experienced
U.L. experts using powerful tools such as
sledgehammers, power saws, carbide disc
cutters, drills, etc., and without fail, were awarded
the U.L. TL-15 and TL-30 labels.
1850°
AMVAULT
2-Hour,
350° F
rating
(Factory
tested at
1850°
Besides withstanding the most concentrated
attacks by sophisticated burglars, each AMVAULT
safe offers a Two Hour, 350° F factory fire test
certification, ensuring the protection of the vault’s
contents against intense fires.
1200°
Average
House Fire
450° F
Paper Chars
350° F
CF6528
SHOWN WITH
OPTIONAL INTERIOR LOCKERS
FEATURES:
DOOR:
• Overall thickness of 6" and is constructed
with a 3" defense barrier of outer and
inner steel plates creating a single
structure enclosing a unique, high density
fire and burglary resistant composite
material.
• Defense barrier houses a proprietary
amalgamation of nuggets and steel fibers
to withstand concentrated attacks with
the most sophisticated equipment used
by burglars today.
BODY:
CF3524
• The AmVault formed body has a total
protective thickness of 3½" enclosing
a high density fire resistant composite
material with nuggets and steel fibers.
• A reinforced drill resistant door frame
protects the door and each individual bolt
chamber from severe side attacks.
• A proprietary inner barrier protects against
peeling attacks.
• High strength adjustable shelves.
FIRE ENDURANCE:
CE2518 WITH OPTIONAL
STOR-IT CABINET (PG 45)
OPTIONAL STOR-IT
CABINETS AVAILABLE
IN CE AND CF MODELS:
2518 / 3524 / 5524 / 6528 / 7236
Fully upholstered safe interior kits
available for these models.
See Page 27 for more details.
• Two hour, 350°F factory fire rating. Tested
at temperatures up to 1850°F
LOCKING MECHANISM:
• Equipped with six to ten massive 1½"
diameter chrome plated solid steel locking
bolts. Each bolt moves deep into the
body’s protected bolt chambers.
• Entire boltwork mechanism is also protected
by a spring operated boltwork detent
system. Bolts stay in the retracted position
when the door is opened and automatically
engage when the door is closed.
OPTIONAL PREMIUM UPGRADE PACKAGE AVAILABLE
When you choose to upgrade your safe with a “Premium Package,” we’ll add on some of our
most popular options including a jewelry tray, dehumidifier and an LED light kit with power strip.
34
Interior of an AMSEC Safe
THREE-WAY
BOLTWORK OPTION
(TL-30 ONLY):
• Safes can be equipped with a three way
active boltwork mechanism engaging the
bolts horizontally and vertically into the
body of the safe.
LOCKS:
• Equipped with a U.L. listed Group II key
changeable combination lock. The lock
is protected by a massive drill shattering
hard plate and two additional springloaded devices.
HINGES:
• Offers a vertical height adjustment
and utilizes an oil impregnated bearing
ensuring easy door operation.
OPTIONAL AUXILIARY
KEY LOCK:
• U.L. listed, high security auxiliary key lock
is also available on all AMVAULT safes
(except Model 1814). Lock is equipped
with 2 keys and escutcheon plate.
• An additional spring-loaded relock device
protecting lock against punch attacks.
OPTIONAL GLASS
RELOCKING MECHANISM
(TL-30 ONLY):
• Incorporated into the AMVAULT TL30 auxiliary key lock is an optional
high security tempered glass relock
mechanism with a remotely and randomly
placed “cross locking” relocking bolt and
thermal cords to protect against torch
attacks.
• In the event of an attack by tools, torches,
or explosives, the glass will shatter
activating the highly sophisticated relock
mechanism.
• Utilizing the glass relock mechanism can
offer up to a total of six different relock
devices offering the ultimate in high
security protection.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AMVAULT High Security Composite safes have passed Underwriter’s Laboratories most
recent testing procedures ensuring you today’s best protection. AMVAULT TL-15 and TL30 U.L. listed composite safes qualify for Mercantile & Broadform Insurance Class ER (TL15) and F (TL-30) with a Bank Rating of BR (TL-15) and G (TL-30). Two Hour Class 350°F
manufacturers’ fire label. Standard finish is Parchment. Other colors available on request.
Model
Number
Inside
Dimension
Outside
Dimension*
Cubic
Feet
HxWxD
HxWxD
CE1814 **
18 x 14 x 12
25 x 21 x 21½
1.8
710
CE2518
25 x 18 x 16
32 x 25 x 25½
4.2
CE3524
35 x 24 x 20
42 x 31 x 29½
CE4524
45 x 24 x 20
CE5524
Weight
Interior
Shelves
Door Swing
A
B
C
1
14
36
39½
1,105
1
18
44
47½
9.7
1,674
2
24
56
57½
52 x 31 x 29½
12.5
2,003
3
24
56
57½
55 x 24 x 20
62 x 31 x 29½
15.3
2,343
3
24
56
57½
CE6528
65 x 28 x 20
72 x 35 x 29½
21.1
3,153
4
28
64
61½
CE7236
72 x 36 x 23
79 x 43 x 32½
34.5
3,880
4
36
80
72½
CF1814 **
18 x 14 x 12
25 x 21 x 21½
1.8
725
1
14
36
39½
CF2518
25 x 18 x 16
32 x 25 x 25½
4.2
1,195
1
18
44
47½
CF3524
35 x 24 x 20
42 x 31 x 29½
9.7
1,908
2
24
56
57½
CF4524
45 x 24 x 20
52 x 31 x 29½
12.5
2,311
3
24
56
57½
CF5524
55 x 24 x 20
62 x 31 x 29½
15.3
2,679
3
24
56
57½
CF6528
65 x 28 x 20
72 x 35 x 29½
21.1
3,359
4
28
64
61½
CF7236
72 x 36 x 23
79 x 43 x 32½
34.5
4,426
4
36
80
72½
TL-15
CUSTOM AMVAULT
ESCUTCHEON PLATE
Shown with optional auxiliary key lock and pull
handle, with matching operating handle.
*Tri-spoke handle standard on all models.
AMVAULT TL-30 AND TL-15
SAFE SPECIFICATIONS
TL-30
* Add 2" to outside depth for handle, dial and hinge projection.
**Models 1814 can not be equipped with an auxiliary lock, 3-way boltwork or glass relock
mechanism. Left Swing Models: After model #, use suffix L.
UNDERWRITERS LABORATORIES’
BURGLARY RATING CLASSIFICATION
U.L. Label — Burglary
Classification TL-15:
Signifies a combination-locked safe designed
to offer a limited degree of protection against
attack by common mechanical and electrical
hand tools and any combination of these
means.
Construction Requirements
• U.L. listed Group II, 1 or 1R combination
lock.
• 750 lbs. minimum or comes with
instructions for anchoring in a larger safe,
concrete blocks or on the premises where
used.
• Body walls of material equivalent to at
least 1" open hearth steel with a minimum
tensile strength of 50,000 P.S.I.
• Walls fastened in a manner equivalent to
continuous ¼" penetration weld of open
hearth steel with minimum tensile strength
of 50,000 P.S.I.
• One hole ¼" or less, to accommodate
electrical conductors arranged to have
no direct view of the door or locking
mechanism.
Performance Requirements
Successfully resist entry* for a net working
time of 15 minutes when attacked with
common hand tools, picking tools,
mechanical or portable electric tools,
grinding points, carbide drills and pressure
applying devices or mechanisms.
U.L. Label —Burglary
Classification TL-30:
Signifies a combination-locked safe designed
to offer a moderate degree of protection against
attack by common mechanical and electrical
hand tools and any combination of these
means.
Construction Requirements
Same as TL-15
Performance Requirements
Successfully resist entry* for a net working
time of 30 minutes when attacked with
common hand tools, picking tools,
mechanical or portable electric tools,
grinding points, carbide drills and pressure
applying devices or mechanisms, abrasive
cutting wheels and power saws.
*Entry=Safes classed as TL-15 — opening the
door or making a six square inch opening entirely
through the door or front face. Safes classed as
TL-30 — opening the door or making a six square
inch opening entirely through the door or front face.
35
PHARMACY / NARCOTICS SAFES
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
PHARMACY AND NARCOTICS SAFES
AMSEC’s complete line of PHARMACY AND
NARCOTICS SAFES offer a great solution for
keeping your high-value, high-target medications
and facility safe from the devastating occurrence of
a robbery, burglary or internal theft. Choose from
several models that are ideal for small to larger sized
pharmacies, hospitals or health care facilities.
PSSW-38
PSSW-38
WITH ADDITIONAL SHELF AND
TWO OPTIONAL DRAWERS
Pharmacy Safe Features:
• AMSEC Pharmacy safes are designed to
easily replace a standard large or small
wooden pharmacy cabinet.
• Standard Pharmacy safes come in two
sizes with three depths to choose from.
Custom size available upon request.
• Large safes have an outside dimension
of 77” H x 36 ¼” W with a 12”, 18” or 24”
depth.
• Small safes have an outside dimension of
38 ½” H x 36 ¼” W with a 12”, 18” or 24”
depth. Small safes are designed to fit under
the counter or can be stacked and bolted
together to create a 4 door taller unit.
• Two outer doors made of high strength
steel with six heavy duty hinges (4 in
smaller safes) and a two-way locking
system.
• Each safe comes with 5 adjustable shelves
(2 in smaller safes). Additional shelves
available.
• Optional drawers available to securely
store back stock of (CII) controlled
drugs. Each drawer is equipped with 12
adjustable compartments, heavy-duty ball
bearing suspension glides and is secured
by the lock of your choice.
PSE-28
PSK-28
NS Series Narcotic Safe
Features:
Pharmacy & Narcotic Safe
Lock Options:
• ½" thick solid steel recessed door, and
formed, high-tensile steel body and
reinforced jambs on all four sides to
maximize protection against pry and
sledgehammer attacks.
• PSSW Pharmacy safes offer the
SafeWizard Electronic lock. A full featured
Access Control System that controls the
outer door and up to 5 interior drawers,
40 users, programmable time delay,
time lock, full audit feature and remote
connectivity. For more information see
page 41.
• Roll-out narcotic drawers with removable
dividers provide easy-to-organize access
to (CII) controlled drugs. Made in the USA.
• Locks and relocks protected by a large
carburized hardplate and an auxiliary
spring-loaded relock device.
• 3-way locking mechanism consisting of
five massive 1" diameter chromed steel
locking bolts.
• Bolt detent system keeps bolts retracted
when the door is open and then
automatically engages when door is shut.
• Door mounted storage compartments.
• Four anchor bolt holes with hardware.
• Available in Black or Pharmacy White
textured finishes.
• PSAudit Pharmacy safes offer the
ESLAudit Electronic lock. A robust Access
Control System that controls the outer
door and 1 interior drawer, 40 users,
programmable time delay, time lock and a
full audit feature. For more information see
page 42.
• PSE Pharmacy safes offer the ESL20XL
Electronic lock. Controls the outer door, 8
users and programmable time delay. For
more information see page 43.
• PSK Pharmacy safes offer a high security
Medeco key lock that controls the outer
door. Only offered on Pharmacy safes.
• Other lock options available upon request.
• Each safe is provided with 4 anchor holes
and hardware to secure it to the floor.
• Available in Pharmacy White textured
finishes. Custom colors available.
• Approx. weight for Tall Safes: 613 lbs to
866 lbs. Approx. weight for Small Safes:
379 lbs to 487 lbs.
• Made in the USA.
NS3020W
For a detailed chart of sizes and specs for these models, please see the AMSEC Price List, Page 13.
36
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
CLEAR OPENING
4¾ X 15¼
CLEAR OPENING
15¼ X 15¼
CLEAR OPENING
10-1/8 X 15¼
FEATURES:
ATL-2
WEIGHT: 240 LBS.
ATL-3R
WEIGHT: 255 LBS.
ATL-4
WEIGHT: 270 LBS.
ATL-4R
WEIGHT: 270 LBS.
Body:
• 16"H x 32-5/8" W x 24" D, ¼" solid steel construction.
Door:
• ¼" solid steel, hinged from center, divider.
Hinge:
• Solid steel continuous hinge.
TELLER LOCKERS
TELLER LOCKERS
Color:
• Available in Satin Black, Parchment, Standard Gray,
Blue Gray, Romanesque Gray, Charcoal Gray, Granite,
Sandstone or Chocolate Brown textured finish.
Locks:
• U.L. listed double nose and single nose safe deposit locks
or Medeco® camlocks standard. Combination locks
optional extra.
ATL-5R
WEIGHT: 285 LBS.
ATL-6
WEIGHT: 295 LBS.
CUSTOM SAFES
CUSTOM SAFES
AMSEC specializes in manufacturing CUSTOM SAFES for supermarkets,
banks, restaurants, convenience stores, gas stations, hotels, mini-marts
and other businesses. With over 50 years experience building custom safes,
AMSEC has the knowledge and expertise to design a safe to meet your cash
handling requirements. Our engineering department is equipped with the
latest in computer-aided design (CAD) systems for rapid creation of detailed
sales sketches, concept drawings, final product prints and design modifications to help you visualize how the safe will look and function. Custom safes
are available in every insurance classification from “B” Rate to U.L. listed
TL-30 models.
37
OPTIONAL EXTRAS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
OPTIONAL EXTRAS
Interior Lockers
AMSEC offers a wide variety of standard
interior locker compartments to fit your
needs. Standard lockers are constructed of
10 gauge or ¼" solid steel. Options include
slotted doors, combination locks and high
security key locks.
Interior Drawers
SUPER BRUTE “B”
AND “CB” RATE SQUARE
HINGED DOOR
All drawers are commercial quality, heavy
steel construction. Available in letter, legal
and document sizes. Each is furnished with
handle and key lock. All drawer capacities
are 150 lbs. and come with a heavy duty
latch removable ball bearing suspension.
Slotted Doors
Slotted doors are also available on
freestanding plate safes, freestanding clad,
composite chests, interior lockers and
interior drawers.
Note: Safes with slotted doors are not
recommended for overnight storage.
STAR “C” RATE
SLOTTED ROUND DOOR
MINI BRUTE
“B” RATE
SQUARE LIFT-OUT
DOOR
with 3/8" x 3½" slot
Interior/Exterior Hopper
Available in three different package sizes
ranging from 5¾" D x 3½" W x 8¾" L
to 7" D x 4½" W x 10¾" L.
Hoppers can be installed on the interior or
exterior of plate, clad or composite safes.
Modular Alarm System
Detects vibration, heat and door openings.
Heat indicator activates alarm when torch
attack occurs. Internal magnetic door contact
detects door opening. Internal vibration
sensor activates alarm if safe is moved or
during drill attack.
38
Locking Bolt Detent
Keeps locking bolts retracted when door is
in open position. Prevents damage to safe
body and boltwork mechanism caused by
accidental door closure with bolts extended.
Coin Racks
For organized storage of coins.
Mounted on inside safe door. Available with four or six compartments.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AMSEC offers a wide variety of options not listed here. Consult your AMSEC price book or call for other available options.
AMSEC’s staff will also assist in helping you choose the correct options for your security needs.
Features:
Three brass and aluminum combination
wheels provide 1,000,000 theoretical
combinations.
Dual brass locking cams prevent wheel
slippage.
Solid brass locking bolt and zinc drop lever.
Four-way brass drive cam allows mounting
RH, LH, VU or VD.
Internal spring-loaded brass relock trigger
guards against punch attacks.
Safe Lock Kit Includes:
Standard mounting footprint matches most
mechanical and electronic safe locks.
Large front-read convertible dial & ring, B/W
finish.
Large front-read convertible dial and ring.
U.L. Listed Group 2 Mechanical
Combination Safe Lock Kit
Mechanical Combination Safe Locks
have been around for over 100 years
and are very secure and reliable. With
the proper care and service, the AMSEC
mechanical combination safe lock will
last a long time.
Both dial and ring are die cast with black
finish and white letters.
A solid, machined brass spindle – 4 7/8”
Can be converted to a key-locking dial with
a disc tumbler key cylinder and two keys
(shown at right).
U.L. Listed Group 2 mechanical safe lock.
Non-key-locking dial insert.
Key-locking dial insert.
Key cylinder and two keys.
Package mounting hardware and two spline
keys.
Combination change key.
Comes standard with an attractive self-stick
solid dial insert or a key-locking dial insert.
Durable packaging and foam inserts protect
contents from shipping damage.
Spyproof Dial
Key Locking Front Read Dial
144 Hour Time Lock
U.L. Listed Dual Nose Key Lock
U.L. Listed Key Op Lock
U.L. High Security Key Lock
Restricts unauthorized viewing while dialing
combination. Also available with key locking
feature.
Dual control safe deposit lock requires two
different keys to open safe.
Key is used to lock dial in a fixed position
and affords dual custody control. Manager
has the combination, collector has the key.
Both must be present to unlock the safe.
European style seven-lever changeable key
lock offers exceptional security features for
use on inner locker or outer safe doors.
Safes equipped with Time Locks offer the
capability of locking the safe for a preselected period of time. Time periods range
from one hour to 144 hours (6 full days).
European style nine-lever changeable key
lock offers exceptional security features for
use on inner locker or outer safe doors.
39
MECHANICAL LOCKS AND KEY LOCKS
MECHANICAL LOCKS AND KEY LOCKS
40
1
(2) 9V /
AC (Opt.)
1
NO
1
(2) 9V
No A/C Opt
6
YES
(15 min.)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
YES
YES
Number of
Users
Time Delay Override
Safe Doors
Power Source
Combination
(number of digits)
Wrong Try Lock
Out (time)
Dual Mode
Time Delay
Time Delay Open
Input Window
(time/by user)
Time Lock
(periods)
*(variable)
Duress
Audit Trail
(# of events)
PC Software
Audit Records
Alarm Interface
Bolt Options
Auto Lock
Spring Bolt/
Slam Bolt
YES
YES
N/A
N/A
N/A
OPT
N/A
YES
YES
N/A
N/A
N/A
OPT
N/A
N/A
N/A
1-99
min.
1-9
min.
N/A
YES
(15 min.)
6
(2) 9V /
AC (Opt.)
1
NO
1
Type 1
Round
L
L1
0X
ES
YES
YES
(15 min.)
8
YES
8
Pending
U.L.
Pending U.L.
U.L. Listed
Round
Round
Backlit
L1
5
Keypad Housing
L5
ES
ES
6 / 1 deposit
YES
40
Type 1
Horizontal
Rectangle
®
rd
za
eW
i
YES
YES
YES
YES
YES
Opt.
N/A
N/A
N/A
N/A
N/A
(OPT)
N/A
Opt
N/A
N/A
N/A
N/A
N/A
YES
2000
Time &
Date
(4)
(*)
1-99
min.
1-99
min.
Yes
YES
(15 min.)
6
3-Number
Combo
(1) 9V
No A/C
1
YES
YES
NO
NO
NO
OPT
N/A
2 min./
fixed
1-9
min.
NO
4
(15 min.)
6
(2)
9V
1
NO
8
1 w/
3 number
Combo
Back Up
N/A
Type 1
Round
20
61
Type 1
YES
8000 w/ 500
Backup
Time & Date
YES
(Opt.)
YES
(2) 9V /
AC (Opt.)
2
YES
40
Pending
U.L.
Round
w/ Combo
Back Up
O
DU
STD
(6)
(*)
1-99
min.
1-99
min.
YES
Settable
(user only)
(OPT)
YES
ck
Lo
Vertical
Rectangle
it
ud
LA
ES
Key +6
Key +6
8 if Keypad
8 if Keypad
only
only
Fingerprint +6
Card +6
AC with Battery
Back-up
Sa
f
N/A
N/A
OPT
N/A
1-9
min.
1-99
min.
YES
YES
(15 min.)
8
(2) 9V /
AC (Opt.)
1
YES
8
Type 1
Round
20
XL
ES
L
YES
YES
NO
NO
NO
OPT
N/A
2-9
min.
1-99
min.
YES
4
(15 min.)
6
(2)
9V
1
YES
5
Type 1
Round
23
61
NO
YES
YES
(Opt)
Audit Only
YES
400
Time & Date
OPT
N/A
1-10
min.
1-99
min.
YES
5
(10 min.)
6
(2)
9V
1
YES
1 Programmer
3 Manager
6 Super User
20 User
Type 1
Round
26
61
YES
YES
NO
NO
NO
OPT
N/A
1-10
min.
1-99
min.
YES
5
(10 min.)
8
(2)
9V
1
YES
9
Type 1
Round
n
Tit
a
YES
YES
NO
NO
63
Lock
Events
NO
N/A
N/A
N/A
NO
YES
(5 min.)
6
(2)
9V
1
N/A
1
Type 1
Au
YES
YES
YES
(Opt.)
(OPT)
512
Time &
Date
OPT
N/A
1-19
min.
1-99
min.
YES
YES
(5 min.)
6
(2)
9V
1
YES
8
Type 1
Round
rd
oG
a
mb
Co
Round
sic
Ba
YES
YES
YES
(Opt.)
(OPT)
NO
OPT
N/A
1-19
min.
1-99 min.
factory set
YES
YES
(5 min.)
6
(2)
9V
1
YES
1
Type 1
c
Au
dit
Co
n
Self
Generating/
Battery
(1) 9V +
(6) “C”
(Opt.)
YES
(Opt.)
YES
YES
(Opt.)
(OPT)
YES
(500) Time
& Date
OPT
(4)
(*)
YES
YES
NO
NO
NO
OPT
N/A
NO
YES
(Order Model
T-52)
1-19
min.
YES
YES
YES
(3 min.)
1-99
min.
YES
(5 min.)
6
1
6
NO
2
Type 1
Round,
Vertical
52
Au
5
w/interface
options
dit
Co
n
YES
Mgr. + (8)
Type 1
Vertical
Rectangle
ar
tLi
n
Sm
Round
dit
Ga
rd
2
YES
YES
YES
(Opt.)
YES (Opt.)
100
YES
100
OPT
N/A
NO
YES
YES
YES
(3 min.)
8
2
1
YES
99
Type 1
Round,
Vertical
55
YES
YES
YES
(Opt.)
YES (Opt.)
400
YES
400
Time &
Date
OPT
N/A
NO
YES
YES
YES
(3 min.)
8
Self
Generating
dit
Co
n
Self
Generating
1
YES
20
Type 1
Round,
Vertical
25
Au
ELECTRONIC LOCKS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
ELECTRONIC LOCK COMPARISON CHART
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
The SafeWizard® electronic safe controller is a state-of-the-art electronic product for use in controlling and auditing access
to safes. Designed to prevent burglaries and internal theft, the SafeWizard® controls and documents each access to the safe.
Based on contemporary high speed processors, unique user friendly software techniques and ingenious application ideas, this
system surpasses all other safe access control systems.
FEATURES:
• Rechargeable Battery Backup.
• A powerful processor based on the
ColdFire® 32 bit microprocessor.
• Built-in System Diagnostics.
• Flash Memory for quick and cost effective
upgrades.
• Up to 10,000 audit entries and 40 users.
• Controls both outer and inner doors.
• Time Delay any door with a 1-99 minute
delay and 1-99 minute open period with
cancel feature.
• Time Lock any door, 1-6 windows per
day.
• Authentication options: PIN code and/or
Dallas Key access control, optional Finger
Print Reader or Card Swipe devices are
available.
• Wrong Try Count Penalty Lockout.
• Auto-Purge Idle Users option, selectable
by Individual User.
• Forced PIN Changes to decrease risk of
compromised PINs.
• Armored Car courier Time Delay and Lock
Bypass.
• Duress/Hold-up Alarm with Silent Signal.
• Burglary Alarm output triggering from
selectable events.
• Holiday Schedule with up to 16
programmable events per year.
• Automatic Daylight Savings Adjustment,
selectable and configurable.
• Dual Control Mode on any individual door,
selectable by user.
• Built-in key maker, complete with
management tool set, audit trail sorting
by several criteria.
• Deposit Tracking system to provide
the highest level of cash management
security.
• Communications possibilities are
unrivaled. Incorporating Multiple Serial
Devices, optional Ethernet Networking
Port. Audits and administration can
be managed through the Serial Port of
Personal Computer or remotely via a
Network connection.
• Audit utility allows PC based audit
storage management, data filter and
sorting capabilities and excellent
exception reporting to focus on key
security issues.
• Ultra-high contrast 8 line by 21 character
graphics display.
• Alarm Interfaces in the Power
Supply Module interfaces the
system to any conventional Alarm
System, with simple connections for
Alarm Output, Duress Output, CCTV
Activation and an Input for Alarm
System control of the SafeWizard
system.
SafeWizard®
• Parallel Printer Interface.
• English, Spanish, French and German
language options.
New WizAdmin Remote
Communication
Features
• With the optional Ethernet Networking
Port (NMPS) and the WizAdmin remote
safe access software, audits and
administration can be accessed remotely
via a network connection.
• Remote operators are assigned a
USB security key and predetermined
user authority level (UAL) facilitating
administration at any desired level.
THE AMSEC SAFEWIZARD
ELECTRONIC ACCESS CONTROL SYSTEM IS AVAILABLE
ON NEW AMSEC SAFES OR
AS RETROFIT KITS.
Authentication Options:
• Enroll unlimited safes in any time zone
and maintain a full configuration record.
• Safe Audits: Provide date, time, event
and user filtering capability.
• Safe User: Administer individual user
profile list as well as modify, add or delete
functions.
• Safe Locks/Doors: Administer all access
control perimeters.
DALLAS KEYS
FPC
FINGERPRINT
READER
Accessories:
• Exception Event: Provides e-mail
notifications of selected safe activity.
• Group Administration: Group multiple
safes to a region or city and allows group
administration changes to be applied as a
single action.
• Print Summary Report: Provides a list of
enrolled safes and basic information.
• Print Safe Detail: Provides detailed safe
configuration report with time delay, time
lock, holiday schedules, etc.
DOOR SENSOR
Monitors door position
(standard on external
doors)
SAFEGUARD
Protects controller against
accidental damage
• Reboot Controller: Allows a remote
system reset.
• Other Remote Administration Functions:
Set safe clock, time delay settings,
duress, pin reject mode, repeating
holidays and much more!
41
ELECTRONIC LOCKS
AMSEC SAFEWIZARD®
ELECTRONIC LOCKS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
NEW! ESLAUDIT
Every business, large or small, can benefit from an easy to use safe access control
system. AMSEC'S ESL AUDIT ELECTRONIC LOCK makes it easy to manage safe
access with its integrated USB Port and user-friendly PC application. Download lock
settings, Upload lock settings, Download audit trail, Upload software upgrades and
More! In addition, all functions can be securely shared via email.
ESLAUDIT FEATURES:
• Wrong try count & penalty lockout.
• Upgrades made easy! Retrofits most
mechanical or electronic safe locks.
• Armored car (courier) bypass for time delay
and time lock.
• Ultra-high-contrast 4 lines by 21 characters
graphics display.
• 2,000 audit records.
• 40 users with unique security privileges.
• PC application for managing lock &
administration setup.
• Holiday schedule with up to 16
programmable events per year.
• Automatic daylight savings adjustment,
selectable and configurable.
• Dual control mode on any individual door,
selectable by user.
• Audit utility allows PC-based audit storage
management, data filter and sorting.
• Warranty: One year parts, labor and
support.
• USB interface for quick and cost-effective
software upgrades, audit downloads and
lock administration setup.
• MakePIN: a proprietary application that
allows for factory-supported administration.
• Built-in system diagnostics.
• Powered by two 9-volt batteries or optional
power supply.
• Alarm interface in power supply with
connections for alarm output or duress.
ESLAUDIT
POWER
SUPPLY
ESLAUDIT
LATCH LOCK
• Controls 1 or 2 doors.
• Safe doors can be configured in any inner/
outer arrangement.
• Time delay any door with a 1-99 minute
delay and 1-99 minute open period with
cancel feature.
• Time lock any door, 1-6 windows per day.
• Authentication options: PIN code and/or
Dallas Key access control.
ESLAUDIT
SWINGBOLT
LOCK
ESLAUDIT
TOGGLE LOCK
ESL5 AND ESL15
AMSEC is a pioneer in the electronic lock market, and the NEW ESL SERIES offers unrivaled value
in electronic safe access. The ESL5 and ESL15 locks have the best blend of features and function in
electronic safe locks. The ESL5 offers attractive chrome or black rubberized finish ABS housing with
a backlit alphanumeric keypad. The ESL15 offers durable black rubberized finish ABS housing with an
alphanumeric keypad. The ESL5 is a basic keypad lock for home and office applications. The ESL15
offers advanced features necessary for commercial applications.
ESL5 &
ESL15
FEATURES:
• Electronics are encapsulated within the
lock and are sealed to prevent possible
moisture-related failures.
• One 9-volt
battery can be
easily replaced in the keypad housing.
• Replaces
most mechanical
combination locks.
Easy installation
and operation.
• Cable fits through a ½" spindle hole without
cutting and re-crimping connector.
• Pending U.L. Type 1 listing.
• Beep and flash from every keystroke gives
maximum feedback to the user.
• ESL5 has an
attractive chrome or black rubberized finish
ABS housing with a backlit alphanumeric
keypad.
• ESL15 has a durable black rubberized finish
ABS housing with an alphanumeric keypad.
• Factory Reset Combination for resolving
lost combinations without requiring
expensive service calls.
42
• Lock can be programmed to silence the
beep in stealth mode.
• 15-Minute Penalty Lockout after four
incorrect entries protects against
manipulation attempts.
• New swing bolt reversible lock design for
right- or left-handed installation.
• Lock “auto-locks” when boltwork is thrown
to prevent safes from being left in a daylock position.
ESL15 ADDITIONAL
FEATURES:
• Time Delay Mode allows delay to be set
from 1 to 99 minutes.
• Armored Car Override allows an armored
car service to bypass Time Delay.
• Multiple User Mode allows for one master
code and eight user codes to be used
for full supervisory control and code
management.
• Dual Control Mode programs the lock to
require two combinations to open.
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
AMSEC has been a pioneer in the electronic lock market. The ESLXL SERIES locks
offer unrivaled value in electronic safe access. The ESL10XL and ESL20XL locks
have the best blend of features and function in Electronic Safe Locks. The ESLXL
SERIES offer an attractive metal die-cast keypad housing with an alpha-numeric
slanted keypad. The ESL10XL is a basic keypad lock for home and office applications. The ESL20XL offers advanced features necessary for commercial applications.
ESL20XL
ADDITIONAL FEATURES:
ESL10XL
FEATURES:
ESL10XL
WITH BRASS FINISH
• Replaces most mechanical combination
locks. Easy installation and operation.
• Factory Reset Combination for solving lost
combinations without requiring expensive
service calls.
• Electronics are encapsulated within the
lock and are sealed to prevent possible
moisture related failures.
• Cable fits through a ½" spindle hole
without cutting and re-crimping connector.
• Audible beep and flash from every
keystroke gives maximum feedback to the
user.
• Time Delay Mode: Delays can be set from
1 to 99 minutes.
• Multiple User Mode: When enabled, one
Master code and eight user codes are
available with full supervisory control and
code management.
• Dual Control Mode: The lock can be
programmed to require two combinations
to open for added security.
• Armored Car Override: When enabled,
allows an armored car service to bypass
Time Delay.
• External A/C Power: Provides power
for unlimited use with battery power as
backup.
• Control Port: Turn the ESL20XL on/off with
an Alarm System or other device.
• 15 minute Penalty Lockout after four
incorrect entries protects against
manipulation attempts.
Optional Expansion Modules:
• New patented dead-latched lock design
with an internal relock device for maximum
security.
• Duress (Silent Signal) Alarm Output.
Provides relay output for alarm system
connection.
• Lock “auto-locks” when boltwork is
thrown to prevent safes from being left in a
day lock position.
• Slam Bolt version for locker applications.
• Optional internal battery pack extends
operation between battery changes.
Model
Provides these additional capabilities on the
ESL20XL:
• External connection for A/C power
transformer on ESL20XL and ESL10XL.
ESL20XL
WITH BLACK FINISH
All the ESL20XL features are
programmed from the keypad.
The Expansion Modules provide
convenient screw terminal and slip
spade connections for field wiring by
the installer.
A/C Power can be connected to the
ESL10XL and ESL20XL lock (with the
ESLAC kit) or an Expansion Module (with the ESLTFMR kit). Wiring,
conduit and attachment hardware is
provided with all optional kits.
• External connection for control port.
• Provides for connection of one or two
ESL20XL locks.
Description
Finish
ESL10XL
ESL10XL Standard Lock
Black Nickel, Chrome, Brass
ESL10XL-S
ESL10XL Slam Bolt Lock
Black Nickel, Chrome, Brass
ESL20XL
ESL20XL Standard Lock
Black
ESL20XL-S
ESL20XL Slam Bolt Lock
Black
SLAM BOLT
* Lock factory installed in place of the standard Mechanical Combination Lock, Dial and Dial Ring.
** Lock factory installed as an auxiliary lock, includes all mount pads and hardware for installation.
Please refer to our Retail Price List for a complete list of part numbers for primary lock, auxiliary lock and
Retrofit kit options.
Accessory Number
ESLBAT
ESL20XLEXP1
ESL20XLEXP2
ESLAC
ESLTFMR
Description
Aux. Battery pack for any ESL Locks. Provides extended life on battery power.
Expansion Kit for (1) ESL20XL lock. External box with duress capability.
Expansion Kit for (2) ESL20XL locks. External box with duress capability.
STANDARD BOLT
A/C Power kit for use with any ESL lock. Provided with conduit and fasteners.
A/C Transformer for use with any Expansion Kit.
43
ELECTRONIC LOCKS
AMSEC ESLXL SERIES
ELECTRONIC LOCKS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
SARGENT AND GREENLEAF
For detailed specifications,
visit www.sglocks.com
S&G 6120
S&G Titan™
S&G 6126
Audit Lock
S&G 6123-303
S&G 6120
Biometric Lock
KABA-MAS
For detailed specifications,
visit www.kaba-mas.com
AUDITCON®
ROUND PROFILE
LAGARD ELECTRONIC SAFE LOCKS
For detailed specifications
on LaGard locks,
visit www.kaba-mas.com
LG BASIC II
44
SAFEGARD
SMARTLINC
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
Provide a higher level of service to your customer with AMSEC’s new line of MOVING EQUIPMENT, giving you the capability
to deliver and install any size safe -- quickly and safely!
Lift ‘N’ Roll
• Load is always stable and
balanced.
• The hydraulic rams allow
easy raising and gentle
lowering of load from 1/8" to
4½".
• Non-marking polyurethane
wheels and padding system.
• Two handles on each
side provide ease of
maneuvering.
• Lightweight design. Built to
last.
• Sturdy steel construction.
• Capacities up to 1,500 lbs.
LIFT ‘N’ ROLL MODEL 1500NR
UltraLift
Powered Hand Truck
• The operator stays in control by using
a combination of motor power, balance
and leverage.
• One person can easily handle every
load, even up and down the stairs,
reducing labor costs.
• Gentle handling eliminates bumps
and bounces to loads and premises,
eliminating damages.
• Pay-off is approximately 21 installs
(based on a national average of $200
per install).
• Load capacity up to 1,500 lbs. Machine
weight is 120 lbs.
• Optional accessories available. See
AMSEC’s Retail Price Book.
Designed to meet your on-the-job requirements, the UltraLift is the best move you
will ever make. Machine weight includes
strap bar, 4-wheel dolly and spill-proof
gel cel battery. Minimum overall machine
height is with extension handle retracted
for moves in restricted areas. Maximum
height is with handle fully extended for
maximum leverage:
• Great versatility: Handle any load on the
level, up and down the stairs, on and off
trucks, over obstacles and many more.
• Light-weight aluminum stands up to years
of rough use.
Triple L Trailer
The design of this patented,
innovative trailer is the result of
Premco’s extensive engineering
and testing procedures. Triple
L Trailers offer the highest quality and best
value of any trailer on the market!
Features:
• Heavy duty tubular chassis - steel diamond
deck plate supported by 4 tubular members
running the full length of the deck to give
complete wheel support for heavy loads.
Model
248
• Level loading - deck remains level through
out raising and lowering.
• Full width rear ramp angle allows easier
loading.
• Hydraulic System activated by a single
lever.
• Oversized deck bearings rated for 80,000
lbs. - each bearing greaseless and sealed.
• Automatic latch locks upon raising for
added travel security.
• Battery, pump and motor are enclosed in a
lockable compartment.
4610
2200
4500
7000
Deck Size
4' x 8'
6' x 10'
6' x 10'
80"
101"
101"
Lift Mechanism
Winch
Hydraulic
Hydraulic
Axle
Single
Single
Tandem
Suspension
Torsion
Spring
Spring
Wheel Size
15"
14.5"
15"
Brakes
No
Electrical
Electrical
Hitch (Ball Size)
2"
2"
2-5/16"
1,510 lbs.
2,070 lbs.
2,500 lbs.
Weight
• Lockable tool box - ideal for storing chain
binders, tie down straps, etc.
• Heavy duty adjusting tongue jack.
• Lights Standard.
• Charcoal powder coated finish.
• 1 Year Manufacturers Warranty.
7610
Capacity
Overall Width
ULTRALIFT MODEL 1500UL
* Specification and design are subject to improvement and may
change at any time without notice.
MODEL 4610
LOAD
LIFT
45
MATERIALS HANDLING EQUIPMENT
MATERIALS HANDLING EQUIPMENT
MERCHANDISING / DISPLAYS
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
MERCHANDISING / DISPLAYS
AMSEC PROMO PACKS
PART #
DESCRIPTION
1045008
3-PACK SAFES: WS1014K, WFS149E5LP, & WS1214E5
Also includes display stand, POP, product tags, color
poster and consumer brochures. Save $190.00
1045020
4-PACK PROMOTIONAL KIT: safe pedestal, sales banner, 3 hanging signs, safe usage poster, window decal,
consumer brochures, product tags, & authorized dealer
certificate. Save $80.00
1045021
8-PACK PROMOTIONAL KIT: Two safe pedestals, sales
banner, 4 hanging signs, safe usage poster, window decal,
consumer brochures, product tags, & authorized dealer
certificate. Save $75.00
AMSEC INDIVIDUAL SALES AIDS
PART #
DESCRIPTION
1045014
Display Pedestal
1045000
Sales Banner (5ft w x 3ft h)
1045024
"Burglary/Fire Safes" Hanging Sign (21"w x 10"h)
1045028
"Fire Safes" Hanging Sign (21"w x 10"h)
1045029
"Floor Safes" Hanging Sign (21"w x 10"h)
1045030
"Depository Safes" Hanging Sign (21"w x 10"h)
1045134
"Wall Safes" Hanging Sign (21"w x 10"h)
1045133
"Gun Safes" Hanging Sign (21"w x 10"h)
1015241
Authorized Dealer Window Decal
1045073
Guide to Safe Usage Poster (24"w x 18"h)
4305127
Retail Price List
4305128
Guide to All Products Brochure (color 4 x 9)
1045129
Dealer Catalog
4305172
Gun Safe Brochure
4305222
Gun Safe Mini-Brochure
1045072
Gun Safe Warranty Poster (24"w x 18"h)
1045076
BF® Gun Safe Authorized Dealer Banner (5ft w x 3ft h)
1045058
BF® Door Cutaway Plaque
1045071
BF® Body Cutaway Plaque
4305174
Warranty/Operating Booklet
1045004
Magnetic Price Tags (4 x 6) - Pack of 6
1045007
3 pack display only
1045201
PDO Display Kit with PDO, Stand and Straps included
1045202
PDO Display Stand - Stand Only
ELECTRONIC SAFE
DISPLAY RACK
PART #1045161
BF® SAFE BODY
CUTAWAY
PART #1045071
3-PACK DISPLAY
PART #1045007
BF® SAFE DOOR
CUTAWAY
PART #1045058
SALES BANNER
5FT W X 3FT H
PART #1045000
PDO DISPLAY KIT
PART #1045201
SAFE USAGE POSTER
(24"W X 18"H)
PART #1045073
GUN SAFE
CATALOG
PART #4305172
46
PRODUCT
CATALOG
PART #4305129
RETAIL
PRICE LIST
PART #4305126
ALL PRODUCT
BROCHURE
PART #4305128
DISPLAY PEDESTAL
PART #1045014
GUN SAFE “MINI”
BROCHURE
PART #4305222
MAGNETIC PRICE
TAGS (PACK OF 6)
PART #1045004
“BURGLARY / FIRE SAFES”
HANGING SIGN (21" W X 10" H)
PART #1045024
AMERICAN SECURITY PRODUCTS CO.
2014 PRODUCT CATALOG
A
ACF 2020 . . . . . . . . . . . 32
ACF 2020XD. . . . . . . . . 32
ACF 3020 . . . . . . . . . . . 32
ACF 3020XD. . . . . . . . . 32
ACF 4024 . . . . . . . . . . . 32
ACF 4024XD. . . . . . . . . 32
ACF4824DS . . . . . . . . . 33
ACF 5024 . . . . . . . . . . . 32
ACF 5024XD. . . . . . . . . 32
ACF 6030 . . . . . . . . . . . 32
ACF 6030XD. . . . . . . . . 32
AM2020E5 . . . . . . . . . . 28
AM3020E5 . . . . . . . . . . 28
AM4020E5 . . . . . . . . . . 28
B
B6 . . . . . . . . . . . . . . . . . . 7
B17 . . . . . . . . . . . . . . . . . 7
B24 . . . . . . . . . . . . . . . . . 7
B400 . . . . . . . . . . . . . . . . 5
B1500E5. . . . . . . . . . . . . 5
B1806 . . . . . . . . . . . . . . . 5
B1810 . . . . . . . . . . . . . . . 5
B1816 . . . . . . . . . . . . . . . 5
B1816D. . . . . . . . . . . . . . 5
B2200E5. . . . . . . . . . . . . 5
B2900E5. . . . . . . . . . . . . 5
B3700E5. . . . . . . . . . . . . 5
B3800E5. . . . . . . . . . . . . 5
B5800E5. . . . . . . . . . . . . 5
BD24. . . . . . . . . . . . . . . . 7
BDP24 . . . . . . . . . . . . . . 7
BF1512 . . . . . . . . . . . . . 18
BF1716 . . . . . . . . . . . . . 18
BF2116 . . . . . . . . . . . . . 18
BF3416 . . . . . . . . . . . . . 18
BF6024 . . . . . . . . . . . . . 21
BF6030 . . . . . . . . . . . . . 21
BF6032 . . . . . . . . . . . . . 21
BF6636 . . . . . . . . . . . . . 21
BF7240 . . . . . . . . . . . . . 21
BF7250 . . . . . . . . . . . . . 21
BLB2018. . . . . . . . . . . . 30
BLB3018. . . . . . . . . . . . 30
BLB3024. . . . . . . . . . . . 30
BLB4024. . . . . . . . . . . . 30
BLC2018 . . . . . . . . . . . 30
BLC3018 . . . . . . . . . . . 30
BLC3024 . . . . . . . . . . . 30
BLC4024 . . . . . . . . . . . 30
BR2212x1. . . . . . . . . . . 11
BR2212x1PP . . . . . . . . 11
BR2213x2. . . . . . . . . . . 11
BR2213x2PP . . . . . . . . 11
BR3112x1. . . . . . . . . . . 11
BR3112x1PP . . . . . . . . 11
BR3113x2. . . . . . . . . . . 11
BR3113x2PP . . . . . . . . 11
BR3122x2. . . . . . . . . . . 11
BWB2020 . . . . . . . . . . . 15
BWB2020FL . . . . . . . . . 12
BWB2020FLNL. . . . . . . 12
BWB2020FLR. . . . . . . . 12
BWB2020FLRNL . . . . . 12
BWB2025 . . . . . . . . . . . 15
BWB2025FL . . . . . . . . . 12
BWB2025FLR. . . . . . . . 12
BWB3020 . . . . . . . . . . . 15
BWB3020-D1 . . . . . . . . 12
BWB3020FL . . . . . . . . . 12
BWB3020FLR. . . . . . . . 12
BWB3025 . . . . . . . . . . . 15
BWB3025FL . . . . . . . . . 12
BWB3025FLR. . . . . . . . 12
BWB4020 . . . . . . . . . . . 15
BWB4020FL . . . . . . . . . 12
BWB4020FLR. . . . . . . . 12
BWB4025 . . . . . . . . . . . 15
BWB4025FL . . . . . . . . . 12
BWB4025FLR. . . . . . . . 12
C
C3 . . . . . . . . . . . . . . . . . . 6
C5 . . . . . . . . . . . . . . . . . . 6
C7 . . . . . . . . . . . . . . . . . . 6
CD5 . . . . . . . . . . . . . . . . 6
CD7 . . . . . . . . . . . . . . . . 6
CDXE . . . . . . . . . . . . . . 31
CDXF . . . . . . . . . . . . . . 31
CE1814. . . . . . . . . . . . . 35
CE2518. . . . . . . . . . . . . 35
CE3524. . . . . . . . . . . . . 35
CE4524. . . . . . . . . . . . . 35
CE5524. . . . . . . . . . . . . 35
CE6528. . . . . . . . . . . . . 35
CE7236. . . . . . . . . . . . . 35
CF1814. . . . . . . . . . . . . 35
CF2518. . . . . . . . . . . . . 35
CF3524. . . . . . . . . . . . . 35
CF4524. . . . . . . . . . . . . 35
CF5524. . . . . . . . . . . . . 35
CF6528. . . . . . . . . . . . . 35
CF7236. . . . . . . . . . . . . 35
CFX252016. . . . . . . . . . 33
CFX352020. . . . . . . . . . 33
CFX452020. . . . . . . . . . 33
CFX582820. . . . . . . . . . 33
CFX703620. . . . . . . . . . 33
CSC1413 . . . . . . . . . . . 19
CSC1913 . . . . . . . . . . . 19
CSC3018 . . . . . . . . . . . 19
CSC4520 . . . . . . . . . . . 19
D
DSC2014KC . . . . . . . . . 13
DSF2014. . . . . . . . . . . . 13
DSF2714. . . . . . . . . . . . 13
DSF2731. . . . . . . . . . . . 13
DSF3214. . . . . . . . . . . . 13
DSR2014 . . . . . . . . . . . 13
DST2014. . . . . . . . . . . . 13
DST2714. . . . . . . . . . . . 13
DST2731. . . . . . . . . . . . 13
DST3214. . . . . . . . . . . . 13
DV652. . . . . . . . . . . . . . 25
DXE. . . . . . . . . . . . . . . . 31
DXF. . . . . . . . . . . . . . . . 31
E
ESF1214 . . . . . . . . . . . . 29
ESL5 . . . . . . . . . . . . . . . 42
ESL10XL. . . . . . . . . . . . 43
ESL15 . . . . . . . . . . . . . . 42
ESL20XL. . . . . . . . . . . . 43
ESLAUDIT. . . . . . . . . . . 42
EST813 . . . . . . . . . . . . . 28
EST916 . . . . . . . . . . . . . 28
EST1014 . . . . . . . . . . . . 28
EST2014 . . . . . . . . . . . . 28
F
FS149 . . . . . . . . . . . . . . 16
FS149E5LP. . . . . . . . . . 16
FS712E5LP. . . . . . . . . . 16
FS914 . . . . . . . . . . . . . . 16
FS914E5LP. . . . . . . . . . 16
FS1814E5 . . . . . . . . . . . 16
FS2215 . . . . . . . . . . . . . 16
FV6030E5 . . . . . . . . . . . 23
FV6032E5 . . . . . . . . . . . 23
FV6036E5 . . . . . . . . . . . 23
FV7240E5 . . . . . . . . . . . 23
I
IRC412 . . . . . . . . . . . . . 26
IRC916E . . . . . . . . . . . . 29
K
K-1 / K-2. . . . . . . . . . . . . 8
L
LG BASIC II . . . . . . . . . 44
M
MM2820Ctr-Drop-E15 . 14
MM2820Top-Drop-E15 14
MM28203-Drop-E15 . . 14
MS1414 . . . . . . . . . . . . 15
N
NS3020 . . . . . . . . . . . . 36
P
PB3. . . . . . . . . . . . . . . . 26
PS1210HD . . . . . . . . . . 26
PSAUDIT . . . . . . . . . . . 36
PSE. . . . . . . . . . . . . . . . 36
PSK . . . . . . . . . . . . . . . 36
PSSW . . . . . . . . . . . . . . 36
R
RF6528 . . . . . . . . . . . . . 20
RFX582820. . . . . . . . . . 20
RFX703620. . . . . . . . . . 20
RMM2620ESL15-R . . . . 9
RMM2620ESLAudit-R . . 9
RMM2620SW-R . . . . . . . 9
S
SAFEGARD. . . . . . . . . . 44
SF5924 . . . . . . . . . . . . . 22
SF6030 . . . . . . . . . . . . . 22
SF6032 . . . . . . . . . . . . . 22
SF6036 . . . . . . . . . . . . . 22
SMARTLINC . . . . . . . . . 44
T
T425 . . . . . . . . . . . . . . . . 7
T625 . . . . . . . . . . . . . . . . 7
T625DD . . . . . . . . . . . . . 7
T925 . . . . . . . . . . . . . . . . 7
T925DD . . . . . . . . . . . . . 7
TB0610 . . . . . . . . . . . . . . 8
TF5517E5 . . . . . . . . . . . 24
TF5924E5 . . . . . . . . . . . 24
U
UL1511 . . . . . . . . . . . . . 17
UL1812 . . . . . . . . . . . . . 17
UL1812X. . . . . . . . . . . . 17
UL2018 . . . . . . . . . . . . . 17
UL3918 . . . . . . . . . . . . . 17
V
VD8030BF . . . . . . . . . . 25
VD8030BFIS . . . . . . . . . 25
VD8030SF . . . . . . . . . . 25
VD8030SFIS . . . . . . . . . 25
VD8036BF . . . . . . . . . . 25
VD8036BFIS . . . . . . . . . 25
VD8036SF . . . . . . . . . . 25
VD8036SFIS . . . . . . . . . 25
W
WEST2114 . . . . . . . . . . . 3
WFS149 . . . . . . . . . . . . . 3
WFS149E5LP . . . . . . . . . 3
WS1014 . . . . . . . . . . . . . 3
WS1014K . . . . . . . . . . . . 3
WS1214E5 . . . . . . . . . . . 3
47
INDEX BY MODEL NUMBER
INDEX BY MODEL NUMBER
Part #1045129
Revision 14v1 03/2014
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
