Philips CE132/94 Datasheet

Philips CE132/94 Datasheet
Philips CarStudio
Car audio system
Experience live music in car
Obsessed with sound
Philips CE132 lets you seamlessly enjoy multiple source music from USB, SDHC &
portable MP3 players in your car. The system features anti-theft detachable front panel
for security and anti-shock protection for smooth grooves on the go.
Enjoy superior sound
• MAX Sound for instant power boost
• Music Zone for adjustable sweet spots
• Dynamic Bass Boost electronically enhances the low tones
• 2-band parametric equalizer with 8 presets
• Super anti-shock protection for smooth music enjoyment
• Built-in 50W x 4 amplifiers for excellent sound quality
Easy to use
• Browse by folder or song for instant search or quick access
• Audio out for amplifier addition
• USB Direct and SDHC card slots for MP3 playback
Design that blends into your car
• High contrast LCD for perfect viewing
• Detachable front panel for anti-theft security
Car audio system
Music Zone
Browse by folder or song
• Type: High contrast B/W LCD
• Key illumination: Red
Playback media
• USB flash drive
• SD/SDHC card
• MP3 Link: for portable MP3 music playback
Audio Playback
Philips' innovative Music Zone technology lets the
driver and the passengers enjoy their music with
more vivid spatial effect, just as the artist intended it
to be heard. Users can easily switch the music
listening zones from the driver to the passengers and
back again to get the best sonic focus in the car. A
dedicated zone control button provides three predefined settings - Left, Right and Front (and All) - so
you can best match your listening needs easily and
dynamically alone or with your passengers.
DBB Dynamic Bass Boost
This function allows you to find a track or album
much faster by letting you browse through songs and
folders, which are the usual contents of USB/SDHC
devices. With the dedicated folder/song button, only
three simple steps are needed to make a search –
press folder/song, rotate the volume knob and push
to select. This simple process lets you search
through your music quickly and easily, letting you to
focus on your driving.
MAX Sound
Compression format: MP3
ID3 Tag support: Song title, artist, album
MP3 bit rates: 32-320kbps and variable bit rate
USB Direct / SD Modes: Play/Pause, Fast
Backward/Fast Forward, Previous/Next, Repeat,
Tuner Bands: AM, FM Stereo
Auto digital tuning
Tuner Enhancements: Auto search and store
No. of preset stations: 18(FM), 12(AM)
• Equalizer: 2-bands
• Equalizer settings: Classic, Jazz, Pop, Rock, Flat,
Optimal, Techno, User defined
• Sound Enhancement: MAX Sound, Dynamic Bass
Boost, Music zone
• Output power (MAX): 50Wx4 channels
• Output power (RMS): 22Wx4 channels (4 ohms,
10% T.H.D.)
• Preamp output: 1 pair Rear RCA (L/R)
Activate the Dynamic Bass Boost (DBB), and the
low-end bass frequencies are electronically
enhanced to achieve consistent sound reproduction,
especially when the speaker volume is set at a low
level. You hear impressive bass at all times.
MAX Sound technology produces an instant boost in
bass and treble, maximizing volume performance and
instantly creating the most impressive listening
experience with just the touch of a button. Its
sophisticated electronic circuitry calibrates existing
sound and volume settings, instantly boosting bass,
treble and volume beyond original maximum levels
without distortion. The end result is a noticeable
amplifying of both sound spectrum and volume and a
potent audio boost that will add mileage to any
• Front panel: Detachable
• Remote control: Included
• User Manual: English, Spanish
• Quick start guide: English
• Power supply: 12V DC
Issue date 2013-05-10
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Version: 1.0.3
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
12 NC: 8670 000 97514
EAN: 87 12581 66767 2
• Product dimensions (W x H x D):
188 x 58 x 140 mm
• Chassis: 1 Din
