HP EliteBook Folio
Business Ultrabook™
Rudolf Gruber
ACM Business PCs and Notebooks
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
The Consumerization of IT
Businesses are consumers too
• Rapid innovation in consumer devices
• Growth of knowledge-based, mobile workforce
• Generational and cultural changes in the workforce
• Increased reliance on web/cloud
2
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
Consumerization is Driving
the Ultrabook™ Trend
New class of devices that are:
• Ultra Thin
• Ultra Secure
• Ultra Responsive
To be classified as an UltrabookTM in 2012, a notebook must meet specific
guidelines:
 Processor – Ultra low voltage
 System Thinness – 18mm for <14.0”, 21mm for 14.0”+;
2mm allowance for convertible tablet
 Responsiveness Capabilities – hibernate to keyboard input in < 7 seconds
 Battery Life – 5hrs min
 Connectivity – Hi-Speed data transfer (i.e. USB 3.0), WiFi required
3
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
Today’s UltraBookTM Devices Fall Short of Enterprise
Requirements
Gartner Magic Quadrant for Global
Enterprise Desktops and Notebooks
Common RFQ Specs
Docking
Security
Manageability
Durability
Long purchase cycle
Stable/consistent
Serviceable on-site
“Global enterprise PC buyers have some unique requirements, which go
beyond price to include platform stability, global account management,
support, service capabilities and fast turnaround on warranty repairs.”*
4
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
3+ year warranty
*Gartner Magic Quadrant Report, October 2011
HP EliteBook Folio Target Segments
High
Executives
Essence
Profile
Business Role
Sleek, thin, light
Executive
responsibilities while
representing their
company requires
premium products.
C-Level
Influence on the IT Decision Maker
Vertical Specialists
Travelers
High performance, app
compatibility
Mobility & remote
connectivity
App compatibility
drives decisions. Their
tools “deliver” mission
critical client goods,
and constant usage
demands effective
interface & design.
Client-facing
workers are
constantly on
the road – and
their tools must
reflect credibility
& performance.
Graphics & Engineering
design
Sales, business
development
Knowledge
Workers
Low
Back Office
Trusted reliability
Access
Informationbased
professionals
focused on
deliverables that
support client
services and
product delivery.
Administrative
workers providing
back office
support for
employees and
customer support.
Marketing, IT, legal
HR, accounting, call
centers
IT Decision Maker Mandatory Policy Requirements
5
 Security – authentication, protection
 Stability – managed lifecycle, stable and
 Serviceability – warranty, replaceable parts
consistent image, Global Series
© Copyright 2012 Hewlett-Packard Development Company, L.P.
information contained
herein is
subject to change without notice.
TheProductivity
– VGA port,
docking
 Durability – metal casing, HP Total Test Process
Field
Field Technicians
Technicians
Real-time data
capture/access,
durability
Client service,
installation, and
inspectors focused
on site visits and
reporting.
Installers,
maintenance,
inspectors
HP EliteBook Folio
The Ultimate Business UltrabookTM
+ 14” antiglare display
+ removable battery, extended battery option
+ full array of ports
+ integrated 4G WWAN
+ enterprise-class side mount docking station
+ point stick and touchpad
+ configurable memory
+ fully serviceable
+ stable, long-lifecycle, global availability
+ comprehensive security and manageability tools
6
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
How thin
is thin?
18.95mm
7
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
Thin without compromises…
typical bid spec
+ 14” display

+ fully serviceable 
+ removable battery 
+ 8 to 20-hour battery life 
+ 4G integrated 
+ security 
- smart card
reader
+ enterprise level dock
+1.75 mm
- USB dock
- VGA dongle
+ common adapter
+ connect to display, projector …
without a dongle
8
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
- RJ 45dongle
HP EliteBook Folio 9470m
Optional HD webcam
HP’s first enterprise-ready
UltrabookTM
Vent
USB 3.0
Smart card
reader
Dual point stick/touchpad
14” LED Display
Side dock
connector
Security
lock slot
Combo
headphone/
microphone
jack
RJ-45
Full size, backlit,
spill-resistant keyboard
9
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
DisplayPort
USB 3.0
VGA
HP UltraSlim Docking Station
Ultrathin connectivity designed as sleek as your
notebook
Product #
B9C87AA
Product Features and Benefits
•
Designed exclusively for ultraslim HP EliteBook Notebooks
•
Expands display, network, and device connectivity so you can be
more productive throughout the day—all through a simple oneclick slide-in side dock
•
Four USB 3.0 ports offer high-speed connectivity to the USB
devices you use most. USB 3.0 reduces the time required for
data transmission (vs. USB 2.0)1, is backward compatible with
USB 2.0, and is bi-directional
•
DisplayPort and VGA ports deliver legacy and future
compatibility with your choice of video devices and an
Ethernet/LAN port keeps you online
•
Headphone and microphone jacks support your multimedia and
video conferencing requirements
•
The optional HP Docking Station Cable Lock secures the
connected notebook to the dock
1 Your notebook, docking station, cable and monitor must all support USB 3.0 to benefit from the advanced
HP Confidential
speeds or features that this technology provides. If one of the devices does not support USB 3.0, the
system will only support USB 2.0 functionality
HP EliteBook Folio – Product Definition
Form Factor
Communications
•
•
•
•
• No modem
• NIC: Intel 82579LM Gigabit Network Connection
• WLAN
• Intel Centrino Advanced N 6205, 2x2 a/b/g/n (Taylor Peak), Intel
Centrino Advanced N 6235, 2x2 a/b/g/n + BT 4.0 HS combo
(Jackson Peak ), Atheros 802.11 2x2 a/b/g/n + BT 4.0 HS
combo (Miami), Broadcom 801.11 1x1 b/g/n + BT 4.0 HS combo
(Valentine)
• WWAN
• Gobi3000 HSPA/CDMA, (Warthog A-10) , Ericsson 5321 HSPA+
(TranSonic); GPS enabled, HP lt2522 LTE/EV-DO Mobile
Broadband Module (Garter VZW) (US only)
• Supports WWAN After Market Option (TBD)
1-spindle design, magnesium enclosure
0.75 × 13.31 x 9.09 in
18.95 × 338 × 231 mm HD
Target starting at 3.6 lb / 1.63 kg
Processor/Chipset
•
•
•
•
Intel Chief River platform
3rd Generation Intel Core i7, i5, and i3 dual-core ULV processors
Mobile Intel QM77 chipset
vPro support
Graphics
• UMA: Intel HD and HD+ Graphics 4000
Expansion Slots
Display
• 14.0” HD (1366x768) HD+ (1600x900) AG/SVA
• LVDS – flat/thin, LED backlit
Memory
• DDR3 PC3-12800 (1600 MHz)
• 2 SODIMM slots; up to 16 GB dual-channel memory (2 x 8 GB)
Primary Storage
•
•
•
•
User-removable SATA hard drives (7.0mm, 2.5”)
320/500 GB 7200 rpm HDD; 500 GB 7200rpm SED
180 GB SSD; 256 GB SED SSD
HP 3D DriveGuard
Optical Drive
• External only
• SD/MMC media reader (supports SDHC, SDXC, MMC (MultiMedia
Card), and MMC+)
• Intel 24 GB mSATA module (Intel Smart Response Technology)
Ports
• (3) USB 3.0 ports (two standard, one charging/high-power);
DisplayPort 1.1a; RJ-45 (Ethernet); VGA; combo
headphone/microphone; docking connector; slice battery connector,
power connector
Input Devices/Camera
•
•
•
•
•
Full-sized chiclet keyboard; spill-resistant design with drain
Backlit keyboard
Dual pointing devices (touchpad with scroll zone and pointstick)
720p HD Webcam (optional)
Wireless on/off button, mute button on keyboard
Audio
• HD Audio with SRS Premium Sound PRO
• Integrated dual-microphone array
• (2) Integrated stereo speakers
11
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
Battery
•
•
52WHr polymer battery (4 cell)
Secondary 60WHr slice battery support (6 cell)
Power
• 3-pin 45W Smart AC adapter
• HP Power Assistant
Security
•
•
•
•
•
•
•
HP ProtectTools
TPM 1.2 Embedded Security Chip
Optional HP Fingerprint Sensor (plug)
Integrated Smart Card Reader
Security lock slot
Full Volume Encryption
Security screw for bottom access door
Operating Systems
• Preinstalled: Windows 7 Home Basic 32 (limited
localizations), Windows 7 Home Premium 32/64,
Windows 7 Professional 32/64, FreeDOS, Windows 8
• Supported: Windows 7 Enterprise 32/64, Windows 7
Ultimate 32/64, Windows XP Pro 32, Windows 7 Home
Basic 64
• Certified: SUSE Linux Enterprise Desktop
Key Options
• Support for Ultrabook docking
• Slice battery
• 2/4/8 MB memory upgrade modules
Warranty
• Limited 1-year and 3-year warranty options available
Thank you
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
HP EliteBook Folio Eco-system
Keep Your Accessories Thin Like Your Sleek Notebook
HP Mobile USB DVD/RW
Powered by AC power or powered USB, the
drive can read/write CD’s and DVD formats.
HP USB Keyboard and Mouse Bundle
Everything you need to replicate the Desktop experience
FPO
FPO
Display and Notebook Stands
HP Business Slim Top Load
Fits up to 14.1” x 0.73” (19mm)
Designed for the Slim Notebook
HP Ultra-Thin Dock
Ideal expansion for HP Ultra-Thin notebooks.
HP LAN and USB Travel Hub
A compact USB/LAN hub designed
to be ultra-portable
USB Graphics Adapter
13
65 Watt Slim AC Adapter
TBD
TBD
HP Ultra-Thin
Keyed Cable Lock
HP Extended Life Slice Battery
© Copyright 2012 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice.
HP Wireless Optical
Mobile Mouse
