Welcome To Biema's Audio Field
Professional amplifier
Professional peripheral equipment
I
Professional multi-function mixer
Professional speaker
Public broadcast conference system
Business karaoke system
Professional microphone
:*SSSE!S!
Http://www. biema.com
Biema
1.
F SERIES PROFESSIONAL AMPLIFIER
(F-1/F-3/F-1 H/F-3II)
2.
W SERIES P R O F E S S I O N A L AMPLIFIER
(W1101I/W220II/W330II)
3.
BFSERIESSub-bassAMPLIFIER
(BF300/BF400/BF500/BF600)
4. J SERIES PROFESSIONAL AMPLIFIER
(J16a/J26a/J36a/J46a)
5.
QSERIESPROFESSIONALAMPLIFIER
(Q150/Q250/Q350/Q400)
6.
PASERIES PROFESSIONAL AMPLIFIER
(PaSOO II/PA600 П/РА700 II)
7.
BM SERIES PROFESSIONAL AMPLIFIER
(Bm800II/BM1000II/BM1200II)
8.
GOLD SOUND К SERIES PROFESSIONAL AMPLIFIER
(K2P/K3P/K4P/K5P/K6P)
9. G SERIES PROFESSIONAL AMPLIFIER
(G31i/G41i/G51i/G61i)
10. FW SERIES PROFESSIONAL AMPLIFIER
(FW900/FW1100/FW1300)
Page 03
'
>•••••••**
& ••*•••••••••••••••
PROFESSIONAL SOUND U.S.A.
F SERIES PROFESSIONAL
AMPLIFIER
MODEL :F-1
F-3
SOFT START
LIMITER
SPEAKON
STEREO, BRIDGE AND PARALLEL MODE
DC FAULT CURRENT LIMITED
THERMAL CUT OFF
AC LINE FUSE, 5 WAY BINDING POST
F-1 ii/ F-3ii are both external cooling type
a.Fan without noise
b.Natural convective cooling
c.Sealed cabinet, stable and available operation in
protective way, no dust inside the machine
•
•
Technical data & Introduction:
MODEL
Output power
STEREO 8 OHMS
TA1KHzTHD«1%
4 OHMS
BRIDGE 80HMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Signal/noise ratio a-weighted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
•
Rear panel controls
1 Connector
I
Power consumption half power 8 ohms
^ Power supply
•
Dimensions (WXDXH)mm
N.W/G.W
•j
Page O4
F-1
F-3
75W+75W
100W+100W
100W+100W
150W+150W
200W
300W
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1.4V
21dBV/9V
21dBV/9V
20KOHMS
20KOHMS
>85dB
>90dB
>70dB
>70dB
>150
>200
30V/ PS
30V/ nS
SHORT CIRCUIT, CURRENT LIMITED DC FAULT AC LINE FUSE, THERMAL CUT OFF, POWER UP/DOWN TRANSIENTS, SLOW START
POWER(BLUE) PROTECT(YELLOW) CLIP(RED) BRIDGE(GREEN) PARALLEL(GREEN)
VARIABLE SPEED FAN
LEVELACH.BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1 .4V INPUT SENSITIVITY SWITCH, GROUND /LIFT SWITCH
BALXLR INPUT, BAL 1/4' INPUT, 5 WAY BINDING, POST SPEAKON
<100W
<140W
AC115V/230V50-60HZ
482x350x44(505x370x100)
482x390x88(516x425x172)
8kg /9,5kg
11.4kg /13.1kg
AMPLIFIER
W SERIES PROFESSIONAL
AMPLIFIER
MODEL:W110 II
W22O II
W33O II
Introduction:
UNIQUE TRANSISTORS
VARIABLE SPEED FAN KEEPS THE UNIT
RUNNING COOL EVEN UNDER THE
STRESSFUL CONDITIONS
GROUND/LIFT SWITCH
AC/DC PROTECTION
LARGE CAPACITORS
SPEAKON
1/4" RCA INPUT
Technical data & introduction:
MODEL
Output power
STEREO 8 OHMS
TA1KHzTHD«1%
4 OHMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Signal/noise ratio a-weighted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Damping factor f = 1 kHz 8 ohms
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
Rear panel controls
Connector
Power consumption half power 8 ohms
Power supply
Dimensions ( W X D X H ) m m
N.W/G.W
•
W220H
wsson
W110E
100W + 100W
200W + 200W
300W+300W
150W+150W
300W + 300W
450W+450W
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
0.77V
0.77V
1.4V
21dBV
21dBV
21dBV
20KOHMS
20KOHMS
20KOHMS
>85dB
>90dB
>90dB
>70dB
>70dB
>70dB
>150
>150
>150
20V/ uS
30V/ у S
35V/ nS
SHORT CIRCUIT DC FAULT AC LINE FUSES
POWER(BLUE) CLIP(RED) PROT(YELLOW)
VARIABLE SPEED FAN
LEVEL ACH, BCH POWER SWITCH
GROUND/LIFT SWITCH
1/4"INPUTRCA INPUT, 5 WAY BINDING, POST OUTPUT
<140W
<300W
<450W
AC115V/230V50-60HZ
482x314x88 (516x405x168)
9. 5kg /11. 2kg
11.5kg /13.1kg
13.5k/15.3kg
Ш
•
•
•
•
Ю
§fc
\Лл
Http://www. biema. com
Page O5
PROFESSIONAL SOUND U.S.A.
BF SERIES Sub-Bass AMPLIFIER
MODEL:
BF300
BF400
Kl .TOO
If I f » (II*
Introduction:
•
•
•
•
HIGH QUALITY ELECTRONIC COMPONENTS
PROFESSIONAL SPEAKON
SPECIAL SOFT START DESIGN
INSERTED SOLE CROSSOVER CIRCUIT,
ADJUSTABLE RANGE: 50HZ-1000HZ
• PROFESSIONAL N14
• FRONT AND REAR APPROPRIATIVE ACCESSORIES,
USING THESE ACCESSORIES, 2PCS
• CAN BE PUT IN ONE 19" STUDIO RACK
Model
Output power
BF300
BF400
BF500
BF600
600W/8 ohms
300W/8 Ohms
400W/8ohms
500W/8ohms
Total harmonic distortion
<0.02%
<0.03%
<0.05%
<0.05%
S/N ratio
>90dB
>100dB
>100dB
>100dB
Input impedance
10Kohm
Gain control
0~+15dB
Frequency divide control
50Hz~1000Hz
Speaker impedance
4 ohm ~8 ohm
Power supply
AC115/230V50-60HZ
Dimensions (W x D x H)mm
N.W/G.W
264x472x118(520X280X165)
9.8kg /10.8kg
\
Page 06
11. 4kg /12.6kg
12.8kg /13.3kg
13.2kg/14.3kg
AMPLIFIER
J SERIES PROFESSIONAL
AMPLIFIER
MODEL:
ЛI tin
J26o
J36a
J46a
Introduction;
RELIABLE PCB
SPECIAL TRANSFORMER
CAPACITOR WITH HIGH CAPACITY
SOFT START LIMITER
PERFECT PROTECTION
STEREO, PARALLEL, BRIDGE MODE
INPUT XLR, PHONE JACK
XLR, BINDING POST
MODEL
Output power
STEREO 8 OHMS
TA1KHzTHD^1%
4 OHMS
BRIDGE 8 OHMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Signal/noise ratio a-weighted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Damping factor f = 1 kHz 8 ohms
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
Rear panel controls
Connector
Power consumption half power 8 ohms
Power supply
Dimensions (WXDXH)mm
N.W/G.W
J26a
J36a
J46a
360W+360W
400W+400W
260W+260W
500W+500W
600W+600W
400W+400W
800W
1000W
1200W
10Hz-50KHz-1.5dB
10Hz-50KHM,5dB
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
21dBV/9V
21dBV/9V
21dBV/9V
20KOHMS
20KOHMS
20KOHMS
>95dB
>100dB
>100dB
>70dB
>70dB
>70dB
>150
>200
>200
>200
40V/ uS
40V/ PS
30V/ n S
35V/ uS
SHORT CIRCUIT, CURRENT LIMITED DC FAULT AC LINE FUSE, THERMAL CUT OFF, POWER UP/DOWN TRANSIENTS, SLOW START
POWER(BLUE) PROTECT(YELLOW) CLIP(RED) BRIDGE(GREEN) PARALLEL(GREEN)
VARIABLE SPEED FAN
LEVELACH,BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1 4V INPUT SENSITIVITY SWITCH, GROUND /LIFT SWITCH
BAL XLR INPUT, BAL 1/4" INPUT, 5 WAY BINDING, POST SPEAKON
<480W
<540W
<220W
I
<350W
AC115V/230V50-60HZ
482x450x88(530X520X90)
15kg/17kg
|
16.5kg/18.5kg
18kg/20.5kg
19,5kg/22.5kg
Лба
160W+160W
250W+250W
500W
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
21dBV/9V
20KOHMS
>90dB
>70dB
и
,
™
t
1
Http://www. biema. com
Page 07
1 «•••
PROFESSIONAL SOUND U.S.A.
О SERIES PROFESSIONAL
MODEL:
AMPLIFIER
Q150 Q250
Q350
Q400
Introduction:
UNIQUE AND ATTRACTIVE FRONT PANEL
HIGH QUALITY RING TRANSFORMER
SPECIAL AND RELIABLE CIRCUIT
SOFT START LIMITER
STEREO, PARALLEL, BRIDGE MODE
INPUT XLR, PHONE JACK
OUTPUT XLR, BINDING POST, SPEAKON
MODEL
Output power
STEREO 8 OHMS
TAIKHzTHD-51%
40HMS
BRIDGE 8 OHMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Siqnal/noise ratio a-weiqhted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Damping factor f= 1 kHz 8 ohms
Slew rate internal
Protection
Indicators
Coolinq
Front panel controls
Rear panel controls
Connector
Power consumption half power 8 ohms
Power supply
Dimensions (WXDXH)mm
N.W/G.W
•L^^BMSSr.jfl^"' ^W;MT^^HMM.
Page O8
Q150
Q250
0350
Q400
150W+150W
250W+250W
350W+350W
400W+400W
225W+225W
375W+375W
500W+500W
600W+600W
450W
750W
1000W
1200W
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
21dBV/9V
21dBV/9V
21dBV/9V
21dBV/9V
20KOHMS
20KOHMS
20KOHMS
20KOHMS
>90dB
>95dB
>100dB
>100dB
>70dB
>70dB
>70dB
>70dB
>150
>200
>200
>200
30V/ и S
35V/ nS
40V/ nS
40V/ uS
SHORT CIRCUIT, CURRENT LI MITED DC FAULT AC LINE Ри5Ег THERMAL CUT OFF, POWER UP/DO\ VN TRANSIENTS, SLOW START
POWER(E LUE)PROTECT(YELLOW) CLIP(RED)BRID6E(GREEN) PARALLELfC ,REEN)
VARIABLE SPEED FAN
LEVEL ACH, BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1 .4V INPUT SENSITIVITY SWITCH, GROUND /LIFT SWITCH
BALXLR INPUT, BAL 1/4' INPUT, 5 WAY BINDING, POST SPEAKON
<200W
<340W
<470W
-540W
AC115V/230V50-60HZ
482x460x88(516X500X168)
13.5kg /15.5kg
16kg /19kg
18.5kg /22kg
20.5kg /24kg
AMPLIFIER
PA SERIES PROFESSIONAL
AMPLIFIER
MODEL: PA500II PA600 II
PA TOO II
Introduction:
INCREDIBLE RELIABILITY
HIGH S/N RATIO
UNIQUE AND PATENTED CIRCUIT
STRONG AND HIGH EFFECTIVE OUTPUT RATIO
HIGH QUALITY RING TRANSFORMER
SPECIAL AND HIGH EFFECTIVE COOLING
SYSTEM
CAPACITOR WITH HIGH CAPACITY
SOFT START, LIMITER
SENSITIVITY SWITCH:0.77V,26dB,1.44V
STEREO, BRIDGE, PARALLEL
LIFT/GROUND SWITCH OUTPUT SPEAKON,
BINDING POST
MODEL
Output power
STEREO 8 OHMS
TA1KHzTHDs:i%
40HMS
BRIDGE 8 OHMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Signal/noise ratio a-weighted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
Rear panel controls
Connector
Power consumption half power 8 ohms
Power suDolv
Dimensions (WXDXH)mm
N.W/G.W
РА700П
РА600П
РА500П
700W+700W
600W+600W
500W+500W
1050W+1050W
900W+900W
750W+750W
2100W
1800W
1500W
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1 .4V
0.77V/26dB/1,4V
21dBV/9V
21dBV/9V
21dBV/9V
20KOHMS
20KOHMS
20KOHMS
>90dB
>90dB
>90dB
>70dB
>70dB
>70dB
>300
>300
>300
70V/ uS
60V/ uS
60V/ nS
SHORT CIRCUIT, CURRENT LIMITED DC FAULT AC LINE FUSE, THERMAL CUT OFF, POWER UP/DOWN TRANSIENTS, SLOW START '
POWER(WHITE)PHOTEC F(YELLOW) CLIP(RED) BRIDGE(GREEN)PAR \LLEL(GREEN)
V
VARIABLE SPEED FAN
LEVELACH.BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1 .4V INPUT SENSITIVITY SWITCH, GROUND /LIFT SWITCH
BALXLR INPUT, BAL 1/4' INPUT, 5 WAY BINDING, POST SPEAKON
•
<940W
<670W
<800W
AC115V/230V50-60HZ
482x500x88(570X516X168)
31 kg /36kg
*
29.5kg /35kg
28kg /33kg
<
tf
&
'
II
A,
Http://www. biema. com
Page O9
PROFESSIONAL SOUND U.S.A.
BM SERIES PROFESSIONAL
MODEL:
AMPLIFIER
BM80011
BitffOOOII
BMI200II
Introduction:
INSERTED 5 BANDS PARAMETER EQ:
CONTINUOUSLY ADJUSTABLE
FREQUENCY POINT GAIN RANGE: 12DB- +12DB
COUTINUOUSLY ADJUSTABLE ORANGE : 0.4 ~ 128
INSERTED HIGH AND LOW CROSSOVER FILTER:
CONTINUOUSLY ADJUSTABLE HIGH
FREQUENCY POINT RANGE:10HZ~ 16KHZ
CONTINUOUSLY ADJUSTABLE LOW
FREQUENCY POINT RANGE:35.1 HZ ~ 20KHZ
TIME PARAMETER ADJUSTABLE COMPRESSING
LIMITER
DISTANT PC CONNECTION CONTROL AND MANUAL
LCD CONTROL 11 KINDS OF PRESET PC
CONNECTION PROCEDURE CONTROL
SAVINGSMENU ADJUST AND CONTROL
INSERTED AUTO-CHECK SINE WAVE AND WHITE
NOISE HARDWARE SYSTEM
DIGITAL VOLUME ADJUSTER AND INSERTED
PHASIC REVISING FUNCTION
& Introduction:
MODEL
TA1KHzTHDs;i%
BRIDGE
4 OHMS
8 OHMS
Freguency response
Input sensitivity
Maximum input level
Input impedance active balanced _
_Signal/noise ratio a-weighted RMS
Crosstalk at rated_output power 8 ohm 1kHz
Damping factor (=1kHz 8 ohms
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
Rear panel controls
Connector
_Power consumption half p
Power supply
Dimensions ( W X D X H ) m m
N.W/G.W
ВМВООД
750W+750W
1500W
10Hz:50KHz-1.5dB_
0.77V/26dB/1.4V
ВМ1000П
900W+900W
1800W
10Hz-5QKHz-1.5dB
0.77V/26dB/1.4V
BM1200D
1050W+1050W
2100W
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
2TdBV/9v'
21dBV/9V
21dBV/9V
_ 20K OHMS
20KOHMS
20KOHMS
•>90dB
>90dB
>70dB
>70dB
>70dB
>300
.•300
>30.0
60V/nS
60V/uS
70V/11 S
SHORT CIRCUIT, CURRENT LIMITED DC PAUL" AC UNE FUSE, THERMAL CUT OFF, POWER U '/DOWN TRANSIENTS, SLOW START
POWER(WHITE) PROTECT(YELLOW)CLIP(flED) BRIDGEJGREEN) PARALLEL(GREEN) STEREQ(GREEN)_
VARIABLE SPEED FAN
LEVEL ACH, BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1.4V INPUT SENSITIVITY SWITCH, GROUND/LIFT SWITCH
BALXLR INPUT, BAL1/4" INPUT, 5 WAY BINDING, POST SPEAKQN
<670W
[
<800W
<940W
_AC115V/230V50-60Hz
AMPLIFIER
К SERIES PROFESSIONAL
AMPLIFIER
MODEL:
K2P
КЗР
K4P
K5P K6P
Introduction:
RELIABLE PCB
SPECIAL TRANSFORMER
CAPACITOR WITH HIGH CAPACITY
SOFT START LIMITER
PERFECT PROTECTION
STEREO, PARALLEL, BRIDGE MODE
INPUT XLR, PHONE JACK
XLR BINDING POST
SPEAKON
Technical data £r Introduction;
K2P
K3P
K4P
K5P
K6P
200W+200W
300W+300W
600W
300W+300W
450W+450W
900W
400W+400W
600W+600W
1200W
500W+500W
750W+750W
1500W
600W+600W
900W+900W
1BOOW
MODEL
Output power
STEREO
TA1KHzTHD«;i%
8 OHMS
4 OHMS
BRIDGE
80HMS
Frequency response
Input sensitivity
Maximum input level
Input impedance active balanced
Siqnal/noise ratio a-weiahted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Damping factor f-1 kHz 8 ohms
Slew rate internal
Protection
Indicators
Cooling
Front panel controls
Rear panel controls
Connector
Power consumption half power 8 ohms
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77W26dB/1.4V
0.77V/26dB/1.4V
21dBV/9V
21dBV/9V
21dBV/9V
21dBV/9V
21dBV/9V
20KOHMS
20K OHMS
20K OHMS
20K OHMS
20KOHMS
>100dB
>100dB
•»95dB
>100dB
>90dB
>70dB
>70dB
>70dB
>70dB
>70dB
>200
>200
>300
>200
>150
40V/ii S
40V/H S
40V/H S
30V/P S
35V/H S
SHORT CIRCUIT, CURRENT LIMITED DC FAULTAC LINE FUSE.THERMAL CUT OFF.POWER UP/DOWN TRANSIENTS.SLOW START
'OWER(BLUE) PROTECT(YELLOW) CLIP(RED) BRIDGE GREEN) PARALLEL(GREEN)
VARIABLE SPEED FAN
LEVEL ACH, BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH,0.77V/26dB/1 .4V INPUT SENSITIVITY SWITCH,GROUND/LIFT SWITCH
BAL XLR INPUT, BAL1/4"INPUT,5 WAY В INDING .POST, SPEAKON
800W
540W
670W
270W
400W
AC 115V/230V50-60HZ
482x510x132(570x525x225)
Power supply
Dimensions ( W X D X H ) m m
N.W/G.W
18kg /20.1kg
Http://www. biema. com
19kg /21.1kg
20.5kg / 22.6kg
24kg /26.1 kg
[_27kg/29.1kg
PROFESSIONAL SOUND U.S.A.
G SERIES PROFESSIONAL
AMPLIFIER
MODEL:
G3H
G41i G51i
Introduction:
RELIABLE PCB
SPECIAL TRANSFORMER
CAPACITOR WITH HIGH CAPACITY
SOFT START LIMITER
PERFECT PROTECTION
STEREO, PARALLEL, BRIDGE MODE
INPUTXLR, PHONE JACK
XLR, BINDING POST
SPEAKON
Technical data ft Introduction:
MODEL
Output power
STEREO 8 OHMS
TA1KHzTHD=S1%
4 OHMS
BRIDGE
8 OHMS
_Etetiuencyjesponse
Input sensitivity
Maximum input level
1
lnpjjlimpfidance_acta_balan£ejL_
SignaJ/noisejatio a-weighted RMS
__Cmsstaltatrale.d оШриЦюшег 8 ohm 1kHz
QampingJaclQjJ= 1 kHzJLohms
Slew r^tfi intfirnal
Protection
Cooling
Front panel controls
Вещшпе! controls
Connector
Power consumplionhalf powerJLolims
Power supply
-Dimensions (WXDXH)mm
1 N.W/G.W
Page 12
1НЯИ
§311
G41I
G51i
661 i
310W+310W
410W+410W
510W+510W
610W+610W
450W+450W
600W+600W
750W+750W
900W+900W
900W
1200W
1500W
1800W
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHz-1.5dB
10Hz-50KHr-1.5dB
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
0.77V/26dB/1.4V
21dBV/9V
21dBV/9V
21dBV/9V
21dBV/9V
20KOHMS
20KOHMS
20KOHMS
20KOHMS
>95dB
>90dB
>100dB
>100dB
>70dB
>70dB
>70dB
>70dB
>150
>200
>200
>200
30V/ ц S
35V/ nS
40V/ uS
40V/ iiS
SHORT CIRCUIT, CURRENT LI MITED DC FAULT AC LINE FUSE, THERMAL CUT OFF, POWER UP/DOiVN TRANSIENTS, SLOW START
POWERfBLUE) PROTECT(YELLOW) CLIP(RED) BRID6E[GREEN) PARALLEL(C REEN)
VARIABLE SPEED FAN
LEVEL ACH. BCH POWER SWITCH
STEREO/BRIDGE/PARALL EL MODE SWITCH, 0.77V/26dB/1 4V INPUT SENSITIVITY SWITCH.GRQUNn /LIFT SWITCH
3AL XLR INPUT, BAL 1/4" INPUT, 5 WAY BINDING, POST SPEAKON
• 420W
<550W
<680W
<820W
AC115V/230V50-60HZ
19kg /20,5kg
|
482x510x132(505x570x225)
20.5kg /22.3kg
|
24kg /25.5kg
27kg /28kg
AMPLIFIER
FW SERIES PROFESSIONAL
AMPLIFIER
1101*11:
III 5*00
IIllfOO
Introduction:
SERVO POWER SUPPLY
INTELLECTUALI2ED COOLING SYSTEM
WIDE RANGED FREQUENCY RESPONSE
LOWTHD
SOFT START
LIMITER
STEREO, PARALLEL, BRIDE MODE
PERFECT PROTECTION
XLR
SPEAKON, BINGDING POST
Technical data Er Introduction:
MODEL
Output power
STEREO
8 OHMS
BRIDGE
4 OHMS
8 OHMS
TA1KHzTHD«1%
I
FW900
900W+900W
FW1100
1100W+1100W
FW1300
1300W+1300W
1350W+1350W
1650W+1650W
1900W+1900W
2700W
20Hz-50KHz-1.5dB
Frequency response
0.77V/26dB/1.4V
Input sensitivity
Maximum input level
21dBV/9V
20KOHMS
Input impedance active balanced
Signal/noise ratio a-weighted RMS
Crosstalk at rated output power 8 ohm 1 kHz
Damping factor f = 1 kHz 8 ohms
3800W
3300W
>105dB
>70dB
20Hz-50KHz-1.5dB
0.77V/26dB/1.4V
20Hz-50KHz-1.5dB
21dBV/9V
20KOHMS
>105dB
21dBV/9V
20KOHMS
0.77V/26dB/1.4V
>70dB
>400
>400
>105dB
>70dB
•
>400
I
eov/ us
at
60V/ » S
60V/ nS
SHORT CIRCUIT, CURRENT LIMITED DC FAULT AC LINE FUSE, THERMAL CUT OFF, POWER UP/DOWN TRANSIENTS, SLOW START
Slew rate internal
Protection
Indicators
Cooling
•
POWER(BLUE) PROTECT (YELLOW) CLIP(RED) BRIDGE(GREEN) PARA LLEL(GREEN)
VARIABLE SPEED FAN
Front panel controls
Rear panel controls
rinnrmrtnr
LEVEL ACH, BCH POWER SWITCH
STEREO/BRIDGE/PARALLEL MODE SWITCH, 0.77V/26dB/1 .4V INPUT SENSITIVITY SWITCH, GROUND /LIFT SWITCH
Power consumption rial) power 8 ohms
Power supply
Dimensions (WXDXH)mm
N.W/G.W
BALXLR INPUT, BAL 1/4" INPUT, 5 WAY BINDING, POST SPEAKON
<1200W
I
<1470W
k
J
<1740W
AC115V/230V50-60HZ
35kg /37kg
482x520x132(505x580x225)
37.5kg /40kg
40kg /42.5kg
Http://www. biema. com
Page 13
1. CAE SERIES PROCESSORS
(CAE108/CAE208)
2. EQ SERIES PROFESSIONAL EQUALIZER
(EQ215/EQ231)
3. FEQ SERIES PROFESSIONAL EQUALIZER
(FEQ1502II/FEQ3102II)
5. INTER MAGANNU SERIES DSP PROCESSOR
(DSP2401/DSP2402/DSP2403/DSP2405/DSP2406/DSP2407/DSP4801/DSP4803)
щ4
„
"
Page 14
..l
EQUIPMENT
POWER PROCESSOR/SEQUENCE
CONTROLLER
MODEL:
CAE-108
Biema CAE-1O8 is a strong enforced device. It has
an 8-channel power output socket. The output of each
channel can be as high as 2.2 KW that can meet the
different requirements of your system equipments to
connect. So it can control the power supply perfectly.
At the same time, it reduces and restrains all kinds of
disturbance from controlled power supply system. The
device can assure that the system equipments work
reliably and stably.
Technical data & Introduction:
Channel Number
8CH
Loading per channel
220V/10A,2200W/Channel
Sequence fine per step
1SEC
Control
Sequence on/off-lock switch bypass/normal-button
Output connector
U.S.A Standard three Wire AC Connector
Power
1 15v/230v 50Hz-60Hz standard 3-wire grounded wire Is needed
Dimension! W x D x H )mm
482x190x44(520x330x60)
N.W/G.W
4.5 kg /5.2kg
POWER PROCESSOR/SEOUENCE
CONTROLLER
MODEL:
CAE-208
Introduction:
Biema CAE-2O8 is a systematic device. The signal
distributor splitter has input level with stereo 4 out and
mono 8out. The balance input and the functions of the
device can be used to connect the different equipments
according to different requirement so that it can make
the input level conformed with the input signal.
Moreover the device can also reduce and restrain all
kinds of electric disturbance that makes the system
Equipment work stably and reliably.
Technical data & Introduction:
S/N. Rate (A Weight)
Frequency response
THD%
Input mode
The max increase of the output
Dynamic range
Indicator
>103dB
20 Hz~20 KHz (±3dB)
<0.03%
1 pair in/4 pairs out; 1 mono
Mono out + 6 dB/CH
118dB
Power, Input, Mode
Input impedance
Output impedance
Input connector
Output connector
Power
Dimension(W x D x H)mm
N.W/ G.W
Balanced 20 К / Unbalanced 10 К
Balanced 300 / Unbalanced 150
XLFH1 G,2+,3-)
XLR (1 G, 2 +, 3 -)
AC115v/230v,50Hz-60Hz
482x175x44(520x330x60)
3 kg /3.4kg
Http ://www. biema.com
Page 15
PROFESSIONAL SOUND U.S.A.
EO SERIES PROFESSIONAL
EOUAIZER
MODEL:
EQ215
EQ231
• Delivers outstanding equalization both in live applications
the studio
• Perfectly suited for room equalization and extreme
corrective surgery e.g. notching out unwanted frequencies
• 2 X 31 band ISO frequencies controllable via slide controls
with boost/cut range from +12dB to -12dB
• Additional sweep-able high and low cut filters remove
uselen frequencies e.g. Floor rumble and tape hiss ect
• Servo balanced inputs and outputs on XLR and 1/4 " jack
connectors
• Ultra-low noise audio operational amplifiers offer
outstanding sound performance
• High-quality components and exceptionally rugged
construction ensures long life
Technical data & Introduction:
MODEL:
Frequency response
Total harmonic distortion
EQ231
±1.0dB
20Hz-20KHz
±1.0dB
<0.05%(20Hz-20KHz +3dB)
>90dB
<0.05%(20Hz-20KHz +3dB)
15band (2/3 octave)
31 band(1/3 octave)
Central frequency
25, 40, 63, 100, 160, 250, 400, 630,
1K, 1.6K, 2.5K, 4K, 6.3K, 10K, 16KHZ
Variable zone
Peak
High pass filter
±12dB/±6dB
-3dB before clipping
20, 25, 31.5, 40, 50, 63, 80, 100, 125,
160, 200, 250, 315, 400, 500, 630, 800,
1K, 1.25K, 1.6K, 2K, 2.5K, 3.15K, 4K>
5K, 6.3K, 8K, 10K, 12.5K, 16K, 20KHz
i l2dB/±6dB
-3dB before clipping
-12dB/octave20Hz-200Hz
115V/50-60Hz230V/50-60Hz
15W
Signal-to-noise ratio
Equalizer control
Power supply
-12dB/octave80Hz
115V/50-60Hz230V/50-60Hz
Power consumption
10W
Dimensions ( W X D X H ) m m
482x233x88(512x285x120)
3.6kg /4.6kg
N.W/G.W
Page 16
EQ215
20Hz-20KHz
>90dB
482x233x132 (500x290x160)
5kg /6. 3kg
ROFESSIONAL
2x15 / ZxMBAND STEREO GRAPHIC EOVAUIER WITH FEEDBACK DISPLAY
MODEL: FEQt 50211 FEQ310211
Introduction:
FEQ1502)1
45mm slim potentiometer
Feedback locating system
Gain switchable (6dB/12dB)
40Hz low frequency cut
EQ/Bypass
XLR
Function indicator
15 band 2/3 octave
Introduction:
FEQ31O2K
Absolutely supplement is suitable for application of
stadium and hall
Perfect circuit design for room equalizing and feedback display
Selective + 6dB or +12dBfor increasing or reducing
Additional HPF to restrain low frequency noise, for
example, feet kicking sound, air-conditioning sound,
etc.
Constant Q value
Integrated power supply internally, 115V or 230V
power can be selective
High accuractly potentiometer controlling
Lower noise makes sound perfectly
Technical data & Introduction:
MODEL:
FEQ1502D
Frequency response
20Hz-20KHz±1.0dB
Thdtotal harmonic destortion
<0.05%(20Hz-20KHz +3dB)
S/N ratio
>90dB
Equalizer control
15band(2/3 octave)
Central frequency
25,40,63,100,160,250,400,630,
Variable zone
± 12dBft 6dB
1K,1.6K,2.5K,4K,6.3K,1 OK, 16KHz
Peak LED
-3dB before clipping
Feedback threshold LED
£-22dB
High pass filter
•12dB/octave(40Hz)
Power
115V/50-60HZ230V/50-60HZ
Power consumption
10W
Dimensions(WxDxH)mm
482X228X88(510x286x120)
N.W/G.W
4.5kg /5.5kg
MODEL:
Frequency response
Thdtotal harmonic destortion
Input impedance active balancde
Output impedance active balancde
Maximum input level
Maximum output level
Variable zone
Equalizer control
Central frequency
S/N ratio
Input plus adjustment
Peak sensitivity
Feedback threshold LED
High pass filter
Power supplv
Power
Dimensions(WxDxH)mm
N.W/G.W
FEQ3102D
20Hz-20KHz [email protected]
ЙП1%?ПН7 РПКН? ffi)(MR
20K ohms
100 ohms
516dB
>15dB
+6dB/+12dB
31band(1/3 octave)
20, 25, 31.5, 40, 50, 63, 80100, 125, 160, 200, 250, 315,
400, 500, 630, 800, Ж, 1.25К,
1.6K, 2K, 2.5K, 3.15K, 4K, 5K,
6.3K, 8K, 10K, 12.5K, 16K, 20KHz
>90dB
-co~OdB
Lit ealier 3 dB than clip point
>-22dB
40Hz 12dB/octave
115V/50-60HZ 230V/50-60HZ
15W
482x230x132 (512x285x160)
5.2kg /6.2kg
Http://www. biema.com
3
age 17
24-BIT DHL ENGINE DIGITAL EFFECTS
PROCESSOR
MODEL:
DSPS401
Introduction:
• 24-bit, z -Д AD/DA,48kHz sampling rate
• 48 preset effect programs to direct recall, and 48 user programs to
adjust parameters
• 9 different configurations:
-Reverb (room,hall),
-Gate (forward, reverse left to right)
-Delay/echo
-Chorus/flanging/ leslie
-Pitch shift + delay
-Chorus /flanging-»-reverb
-Chorus -t-delay
-Delay/echo + reverb
-Distortion + reverb
• All effect parameters adjustable, over 700 kinds variation
• 3 bands parametric equalizer
• 2x16 character backlit LCD
• MIDI control
Technical data ft Introduction:
Analog Input
Connectors
Type
Impedance
Nominal Operating Level
Max. Input Level
Analog Output
Connectors
Type
Impedance
Max. Output Level
System specifications
Bandwidth
Noise
THD
Cross-talk
XLR and 1/4 'jack
RF filtered, servo balanced input
40 k ohms balanced.20 k ohms unbalanced
•20dBto+4dB
+ 16 dB at +4 dB nominal level, +2 dB at 20 dB V nominal level
XLR and 1/4 'lack
Electronically senra-balanced output stage
66 ohms balanced, 33 ohms unbalanced
+16 dB at +4 dB nominal level, +2 dB at 10 dB nominal level
20Hz to 20KHz, -1dB
98 dB, weighted, 20 Hz to 20 KHz
0.0065*typ @ +4 dB, 1 KHz. Gain 1
5-Pin-DIN-Socket IN/OUT THRU
Digital processing
Converters
Sampjjng Rate
Display
Tvoe
Power Supply
Mains Voltages
Fuse
Power Consumption
Mains connection
Physical
Dimensions ( W x D x H)mm
NW/G.W
24-bit Siqma-Delta,64/128-times Over-sampling
48KHz
2 1/2 digital LED-Display
General Export Model- 100-1 20V AC, - 200-240V AC. 50-60HZ
100-120VAC: 250mA(Slow-blow)
115V/230V AC: 125mA(Slow-blow)
10 Watts
Standard IEC receptacle
482x175x44(520x330x60)
3kg /3.6kg
-95 dB, 20H2 to 20KHz
24-BIT DIGITAL EOUALHER/2x31
B4\0 O.odB STEP
MODEL:
DSP2402
Introduction:
•
•
•
•
•
•
24-bit dual DSP
24-bit sampling rate, Е-Д.А/D, D/A
Dual 31 band equalizer display
Gain control: 16dB, O.SdB
Internal digital Noese Gate
100 memory program back up by a durable
battery
• Left/Right channel copy & flat function
• Lock function
• 16x2 back light LCD display
• Total real time MIDI control
Technical data ft Introduction:
Analog Inputs
Connectors
Type
Impedance
Nominal Operating Level
Max. Input Level
Analog Outputs
Connectors
Type
Impedance
Max. Output Level
System specifications
Bandwidth
Noise
THD
Cross-talk
Page 18
XLR and 1/4 'jack
RF filtered, servo balanced , 20 k ohms unbalanced
40 k ohms balanced.20 k ohms unbalanced
-20dBto+4dB
+16 dB at +4 dB nominal level, +2 dB at -20 dB V nominal level
XLR and 1/4 'jack
BectranicaJlj servo-balanced output stage
66 ohms balanced, 33 ohms unbalanced
+ 16dBat +4 dB nominal level, +2 dB at -20 dB nominal level
20Hz to 20KHz
98 dB, weighted, 20 Hz to 20 KHz
0.065%typ @ +4 dB, 1 KHz. Gain 1
-95dB,20Hzto20KHz
MIDI Interface
Type
Digital processing
Converters
Sampling Rate
Display
Type
Power Supply
Mains Voltages
Fuse
Power Consumption
Mains connection
Physical
Dimensions (WxDxH)mm
N.W/G.W
5-Pin-DIN-Socket IN/OUT THRU
24-bit Sigma-Delta,64/128-times Over-sampling
48KHz
LED-Display
General Export Model-100-120V AC, - 200-240V AC, 50«>Hz
100-1 20V AC: 250mA(Slow-blow)
115V/230V AC: 125mA(Slow-blow)
10 Watts
Standard IEC receptacle
482x152x44 (520x330x60)
3kg /3.6kg
DCDIDUCDAI
24-BIT DIGITAL VOCAL STIMULUS/LOVNESS
MAXIMIZER
MODEL:
DSP2403
Introduction:
• 24-bit dual DSP respectively processing microphone input and line
input
• Voice processing (from microphone input)
-3 microphone inputs, volume control independently
-3 bands parametric equalizer(PEQ)
-Noise gate
-6 kinds enhance harmonic modes:
3 parts harmony, melody, relative, vocoder, male lead, female lead
-7 kinds effect modes: HALL, ROOM,
PLATE, STEREO, MONO, TEREO ECHO & REV, MONO ECHO & REV
• Music processing (from line input)
-5 bands parametric equalizer(PEQ)
-10 preset modes, 8 user modesfadjustable parameters)
-5 bands parametric equalizer(PEQ)
-Dynamic compressor
-Digital treble and bass control
-Digital stereo key control ( pitch shifter)
-Subwoofer output: adjustable crossover 20Hz~200Hz(low pass)
-Music output: 20Hz~300Hz( high pass)
• 3 DSP respectively processing
• Line remote control
• Parameter can be memorized
Technical data & Introduction:
Analog Inputs
Connectors
Type
Impedance
converter
Nominal Operating
Analog outputs
Connectors
Digital Processing
XLRandWjack
Servo balanced input
40k ohm balanced
20k ohm balanced
-20dB to +4dB
XLRandWjack
24-bit Sigma-Delta
64/128 time over-sampling
48KHz
Sampling rate
2
Display type
115v/230vAC: 125mA (Slow-blow)
Power supply
10W
Power consumption
Mains connection
Standard IEC receptacle
Dimensions ( W x D x H)mm 482x175x44(520x330x60)
3kg /3.5kg
NW / Q.W
24-B/T DIGITAL ll/TOMT/C FEEDBACK DESTROYER/PARAMETRIC EO
MODEL:
DSP2405
Introduction:
• Digital 2-Channel Feedback Suppressor/Parameter EO Based on a
High-Power 24 Bit DSP
• Automatically Search and Suppress Feedback Frequencies
• 24-bit A/D.D/A.48kHz Sampling Frequency, Three Mode for Each
• Filter Sing-Shot, Auto and PEQ
• Single-Shot Mode Automatically Search and Destroy Feedback and
locks
• Auto Mode Continuously Monitors the Up to 2
• Including Frequency, Bandwidth and Gain
• Left and Right Channels Independent or Coupled Control
• Digital PLL, Frequencies and Gains Accurate Control
• Full Midi Control
• All Setting Can be Saved Up to 10Patterns in the Memory
• Free Software Allows for Total Remote Control via PC
• Servo Balanced Input & Output on XLR and TRS jack
• Display 2
• Size 1U, 19"
Technical data & Introduction:
Analog Input
Connectors
Impedance
20 k ohms balanced
Nominal operating Level
Analog output
Connectors
impedance
33 Ohms unbalanced
System specification
Bandwidth
Noise
20 Hz to 20 kHz
THD
XLH and 1/4" jack
40 k ohms balanced.
-20 dB to +4 dB
XLR and 1/4" jack
66 ohms balanced,
20 Hz to 20 kHz, -1dB
> 98 dB. A weighted,
MIDI Interface
Tvpe
Digital processing
Converters
64/128-times over-samolina
Sarrrallng rate
Disolav type
Power suDDlv
Power consumption
Mains connection
Physical
Dimensions ( W x D x H ) m m
NW/G.W
5-Pin-DIN-Socked IN/OUT/THRU
24-bit Sloma-Detta
48kHz
2
1 1 5V/230V AC : 1 25 Ma(slow-blow)
10W
Standard IEC receptacle
482 X 1 75 X 44 (520x330x60)
2.5kg /3.5kg
0.0065% TYR 0 dB, 1 kHz
Http://www. biema. com
3
aqe 1 9
PROFESSIONAL SOUND U.S.A.
DIGITAL
COMPRESSOR/EXPANDER
MODEL:
DSP2406
Introduction:
24-bit i:-AA/D, D/A. 48kHz sampling rate
Internal 32-bit DSP processing
Digital volume adjustment: -64dB~ +24dB. step in 1 dB
Dynamic compressor/expander, Threshold, ratio and time
constants(Detection time, attack time, decay time) adjustable
Key lock function
2X16 LCD display with backlit
MIDI Control
Technical data ft Introduction:
Analog Input
Connector
Type
Impedance
Nominal Operatinq Level
Max. Input Level
Analoq Output
Connector
Type
Impedance
Max. Output Level
System specification
Bandwidth
Noise
THD
Cross-talk
XLR and 1/4 'jack
RF filtered, servo balanced , 20 k ohms unbalanced
40 k ohms balanced.20 k ohms unbalanced
-20dBto+4dB
+16 dB at +4 dB nominal level, +2 dB at -20 dB V nominal level
XLR and 1/4 'jack
Electronically servo-balanced output stage
66 ohms balanced, 33 ohms unbalanced
+16 dB at +4 dB nominal level, +2 dB at -20 dB nominal level
20Hz to 20KHz
98 dB, weighted, 20 Hz to 20 KHz
0.065%typ,1 KHz, OdB INPUT
-95dB,20Hzto20KHz
MIDI Interlace
Type
Digital processing
Converters
Sampling Rate
Display
Type
Power Supply
Mains Voltages
Fuse
Power Consumption
Mains connection
Physical
Dimensions (WxDxH)mm
N.W/G.W
5-Pin-DIN-Socket IN/OUT THRU
24-bit Siqma-Delta,64/128-times Over-sampling
48KHz
16x2LED-Display
100-120VAC: 250mA(Slow-blow)
200-240V AC: 125mA(Slow-blow)
10 Watts
Standard IEC receptacle
482x152x44(520x330x60)
3kg /3.7kg
24-BIT DIGITAL TWO CROSSOVER PROCESSOR
MODEL:
DSP2407
Introduction:
• 24-bit £-Д A/D, D/A, 48kHz sampling rate
• Internal 32-bit DSP processing
• A flexible 2 inputs, 4 outputs multi-mode crossover format
- 2 x 2 way crossover
- 1 X 2 way crossover + 2 sub crossover
-1 x 3 way crossover + 1 aux crossover
- 4 way crossover
• Each parametric section provides -40dB~+6dB gain adjustment, step in 1 dB
• Each parametric section provides Limit control
• Each parametric section has 5 bands PEQ with frequency, gain and bandwidth
adjustable
• Each channel max 8 ms delay with parameters adjustable
• Low pass crossover range: 20Hz~-20kHz, 377 positions
• High pass crossover range: <10Hz~ 16kHz, 380 positions
• Lock function
• Frequency response: 20Hz~20kHz
• MIDI control(with PC software)
* 10 user memories
• 6 X 8 LED inputs/outputs accurate level meters
• 2 x 16 LCD display with backlit
Technical data £r Introduction:
Input
Impedance
CMRR
Output
Source Imp
Frequency Resp.
Dynamic Range
Distortion
Output gain
Parametric Equalization
Filters
Filter gain
Central frequency
Filter Q
D
age 2C
Two electronically balanced
> 10k ohms.
50dB50Hz-10kHz.
Six electronically balnaced.
<60ohms.
20Hz-20kHz, ±1dB.
100dB20Hz-20kHz.
0.06% @1kHz, 0.775Vrms V
Adjustable -40dB to +6dB in 1dB steps and mute.
3 Sections per output.
-12dBto +12dBin 1dB steps.
100Hz-20kHz, ISO Frequency
0.5,1,2,3,4,5,6,7,8,9, 10
Filters
Frequency(HPF)
Frequency(LPF)
Response
Display
Input meter
Output meter
Inputs
Outputs
MIDI In
Power
Power
Consumption
Dimensions ( W x D x H)mm
N.W/G.W
1 of each per output.
20Hz-20kHz, 377 positions
20Hz-20kHz, 377 positions
Butterworth 12/18/24dB per octave
2x16 character backlit LCD.
2x8 point, -36dB to diqital clip.
4x8 point, -36dB to digital clip, mule indication.
3£jn female XLR.
3 pin male XLR
5 pin DIN.
3 pin IEC.
1 1 0V / 220V Two Switched
< 20 watts.
482x161x44 (520x330x60)
3kg /3.7kg
EQUIPMENT
DIGITAL LOUDSPEAKER
MANAGEMENT
MODEL:
DSP4801
Introduction:
• 24-bit dual DSR top S-Д AD/DA, 48kHz sampling rate
• Crossover slopes of 6,12.18,24 or 48dB per octave, filter types
butterworth or linkwitz-riley
• Parametric or shelving equalization tor smoothing system
frequency response
• Up to 630rns signal delay pet signal path
• The threshold of the output compressor adjustable, attack and
release time adjusted automatically
• Polarity reverse on each output
• 60 memory locations fot user programs
• Auto electronically balanced inputs and outputs
• MIDI and RS-232 control
• 2x16 character backlit LCD
Technical data & Introduction:
Input Section
Input Impedance
Maximum Input Level
Input Gain
CMRR
Input Connector
Max Delay time
10kOhm.electronicallv balanced
i 20dBu
+/-15dB variable in О.Ш steps
Better than 50dB(30Hz-20kHz)
XLR-3F or eauivalent
AES/EBU lnterface(stereo,on input A)
Input sample rate
Output Section
Output Impedance
Maximum Output Level
Output Gain
Output Connector
Crossover Filters
Slopes
Type
Delays
Available on Inputs А, В and Outputs
1,2,3,4,5,6
Delay Step
44.1,48,88.2,96kHz
<50 Ohms,electronically balanced
+20dBu into 600 Ohms or greater
+/-21dB,variable in 0.1 dB steps
XLR-3M or equivalent Transformer Balancing optional
6,1 2,18,24,or 48dB per octave (Filter type dependant)
Bessel.Butterworth.or Linkwitz-Riley
1 1 microseconds minimum
IK-KIT DIGITAL THREE CROSSOVER
EQ
Maximum number
of EQ filters
EQ Type
EQ Gain
Q(bandwidth)
EQfreq
Dynamic Slope
General Performance
Frequency Response
Dynamic range
Channel Separation
Distortion(THD)
Input Metering
Output Meter Indication
General
AC power
Dimensions) W x D x H J m m
N.W/G.W
2.6 seconds
60(depending on crossover slopes)
parametric, Bellor shelving on any ffier.
Nine filters assigned to Dynamic EQ.
+/-t5Db,variable in 0.2dB steps
0.05 to 3 octaves.variable in 0.05 steps
15Hz to 20kHz
2:1 to 20:1 (dynamic EQ's only)
with filters out
15Hz.20kHz,+/-0.25dB15Hz-40kHzJt/.3dB
> 1 1 2dB unweighted 22Hz to 22kHz, > 1 1 7dB on AES/EBU input
>80dB,30Hz to 20kHz
<0.005%,[email protected]+10dBu output
-20dB,-12dB,-6dB,-3dB,CUP relative to Clip point(+20dB)
SIG(40dB)!.20dB,-12dB,.6dBr3dB,OdB,OVER(+6fllB)
Relative to limiter threshold setting
110V-240VAC,50/60Hz,30VA
482x161x44 (520x330x60)
3kg /3.6kg
PROCESSOR
MODEL:
DSP48O3
Introduction:
• 24-bit х-Д A/D, D/A, 48kHz sampling rate
• Internal 32-bit DSP processing
• A flexible 2 inputs, 6 outputs multi-mode crossover format
- 2X2 way + 2 sub crossover - 2X3 way crossover
- 4 way + 2 aux crossover - 5 way + 1 aux crossover - 6 way crossover
• Each parametric section provides -40dB~ + 6dB gain adjustment, step
in1 dB
• Each parametric section provides Limit control
• Each parametric section has 5 bands PEG with frequency, gain and
bandwidth adjustable
• Each channel max 8 ms delay with parameters adjustable
• Low pass crossover range: 20Hz~20kHz, 377 positions
• High pass crossover range: <10Hz~16kHz, 380 positions
• Lock function
• Frequency respond: 20Hz- 20kHz
• MIDI control(with PC software)
• 10 user memories
• 8 X 8 LED inputs/outputs accurate level meters
• 2X16 LCD display with backlit
Technical data & Introduction:
Inputs
Impedance
CMRR
Outputs
Source Imp
Frequency Resp.
Dynamic Range
Distortion
Output gain
Parametric Equalization
Filters
Filter gain
Centre frequency
Filter Q
Two electronically balanced
> 10k ohms.
50dB50Hz-10kHz.
Six electronically balnaced.
<60ohms.
20Hz-20kHz, I 1dB.
100dB20Hz-20kHz.
0.06% @1 kHz, 0.775Vrms V
Adjustable -40dB to +6dB in 1dB steps and mute.
3 Sections per output.
-12dBto +12dBin 1dB steps.
100Hz-20kHz, ISO Freguencv
0.5, 1,2,3,4,5,6,7,8,9,10
Filters
Frequency(HPF)
Frequency(LPF)
Response
Display
Input meter
Output meter
Inputs
Outputs
MIDI In
Power
Power
Consumption
Dimensions! W x D x H)mm
N.W/G.W
1 of each per output.
20Hz-20kHz, 377 positions
20Hz-2UkHz, 377 positions
Butterworth l2/18/24dB per octave
2x16 character backlit LCD.
2x8 point, -36dB to digital clip.
6x8 point, -36dB to digital clip, mute indication.
3 pin female XLR.
3 pin male XLR
5 pin DIN.
3 pin IEC.
1 10V / 220V Two Switched
< 20 watts.
482x161x44 (520x330x60)
3kg /3.6kg
Http://www. biema. com
Page 21
Ill»
1. MINI COLOURFUL MIXER
(MINI 802A)
-
2. PSP SERIES PROFESSIONAL MIXER
(PSPD822/PSP1022/PSP1222/PSP1242/PSP16tt/PSPM42).
3. MX SERIES PROFESSIONAL MIXER
(МХ600/МХ800/МХ1000/МХ1Г11"'""""1
'
Page 22
"""SERIES PROFESSIONAL'
PROFESSIONA
If in i colourful
да
т/.^/л
1ШЖй?/4
*v>JM<
4
У тЛ - " /^.i^Kk
/
^^-^
mixer
troduction:
I Technical data ft In
Mono input channels
Mic input
MicE.I.N.(22Hz-22kHz)
|
Bandwidth
Distortion(THD&N)
Gain range
Signal-to-noise ratio
lectronically balanced, discrete input configuration
-129.5 dBu, 150 ohm source
-117.3dBqp,150ohm source
-132.0 dBu, input shorted
-1 22.0 dBqp, input shorted
10Hzto60kHz, + /-3dB
0.007% at +4 dBu, 1 kHz, bandwidth 80 kHz
+ 10dBto +60dB
113. 6dB
Equalization
Hi shelving
Mid range
Lo shelving
12kHz, +/-15dB
2.5kHz, +/-15 dB
80Hz,+/-15dB
Line input
Bandwidth
Distortion(THD&N)
Line level range
electronically balanced
10Hzto60kHz,+/-3dB
0.007% at + 4 dBu, 1kHz, bandwidth 80 kHz
+10 dBu to -40 dBu
Stereo input
Line input
Bandwidth
Disortion(THD&N)
unbalanced
10Hzto55kHz, + / - 3 d B
0.007% at +4 dBu, 1 kHz, bandwith 80 kHz
Equalization
Hi shelving
Mid range
Lo shelving
12kHz, +/-15 dB
2.5kHz, + /-15dB
80 Hz, +/-15dB
Main mix section
Max output
Auxsend max out
Control room out
Signal to noise ratio
• Equivalent input noise
AJT Physical
Dimension (Wx Dx H)mm
N.W/G.W.
+ 22 dBu unbalanced
+ 22 dBu unbalanced
+22 dBu unbalanced
112dB
-90 dBu (all channels open, unity gain)
223.5x197.5x35.5
1.3kg / 2 k g
Http://www. biema. com
Page 23
^^»
PSP/DPS SERIES PROFESSIONAL MIXER
MODEL: PSP0822 PSP1O22 PSP1222 PSP1242
PSP1642 PSP2042
Input characteristics
In these specifications, when dB represents a specific voltage, OdB is referenced to 0.775V PMS.
XLR type connectors are unbalanced, CH phone jacks are balanced(T= +, R = -, S = GND)and another phone jacks are
unbalance. Insert phone jacks *** unbalanced (T=OUT, R = IN, S = GND)
To have max. sensitivity. All faders and level controls should be set at max. Position and it will produce a stereo output of
+4dB(1.23V)
Input terminals
Actual load
GAIN impedance
LO-Z OFF(OdB) -60dB 4Kohms
lOKohms
lOKohms
lOKohms
lOKohms
For use with
nominal
50. .600 ohms
&
600 ohms
600 ohms
600 ohms
600 ohms
lOKohms
600 ohms
PAD
CH
Input line ON(20dB) -16dB
Та зе in (1 ,2)stereo
AUX return(1, 2) stereo
Insert in CH(1...24)
group(1...4)
SUBingroup(1...24)
stereo(L, R)
Input
Sensitivity
-80dB(0.08mV)
-40dB(7.75mV)
-20dB(77.5mV)
-16dB(123mV)
-16dB(123mV)
-20dB(77.5mV)
-10dB(245mV)
-6dB(388mV)
level
Nominal
-60dB(0.8mV)
-20dB(77.5mV)
OdB(0.8V)
+4dB(1.23V)
+4dB(1.23V)
-6dB(338mV)
+4dB(1.23V)
+4dB(1.23V)
Max. Befclip
-40dB(7.75mV)
+4dB(1.23V)
+20dB(7.75V)
> + 20dB(7.75V)
>+20dB(7.75V)
>+20dB(7.75V)
>+20dB(7.75V)
>+20dB(7.75V)
Connection
Mixer
XLR jack
&
phone jack
Phone jack
Phone jack
Phone jack
Phone jack
Phone jack
Output characteristics
• XLR type connector are balanced, phone jacks unbalanced. Insert pone jack. (T = OUT, R = IN,S = GND)
• In these specifications, when dB represents a specific voltage, OdB is referenced to 0.775V RMS.
Outputterminals
Groupout(1...4)
Stereo out(L.R)
Monitor out(L.R)
Phones out
AUXsend(1...6)
Insert out ell (1... 24)
group(1...4)
Mix out
Actual source
Impedance
150 ohms
600 ohms
150 ohms
600 ohms
600 ohms
100 ohms
Output level
Nominal
Max. Before clip
+ 4dBQJ!3V)
+24dB(7.75V)
-10dB(338mV)
+ 10dB(3.88V)
+ 4dB(1.23V)
+ 24dB(12.3V)
-10dB(388mV)
+ 10dB(3.88V)
+4dB(1.23V)
+ 20dB(12.3V)
1mW
20mW
3mW
130mW
+ 4dB(1.23V)
+ 20dB(7.75V)
-6dB(388mV)
+ 20dB(7.75V)
Connector in
Mixer
XLR jack
600 ohms
600 ohms
For use with
Nominal
600 ohms
lOKohms
lOKohms
lOKohms
lOKohms
8 ohms
40 ohms
lOKohms
lOKohms
150 ohms
600 ohms
+4dB(1.23V)
XLR jack
+ 24dB(12.3V)
XLR jack
Phone jack
Stereo
Phone jack
XLR jack
Phone jack
Bieiim AUDI C01VELI/EN SERIES Ml/LTLCHAMEb DIGITAL (07 КО/ MIXER
MODEL-.
мхбоо ffv«o« w v i w o o M\i200
и\fttoo
I MX«00 ЕМА800 EMXIOOO K M X I 2 0 0
24-bit L-) AD/DA converters with 64/128 times over-sampling for ultra-high headroom and resoluiton
8 kind of effect mode(HALL1, HALL2, ROOM1, ROOM2, DELI, DEL2, ECHO- REV/DEL)
Discretional adjust and store the delay time and repeat time
Ultra-low noise multi-channel 4-bus mixer
Master aux sends with gain control
Extremely high headroom-offering more dynamic range
Ultra-low nose discrete mic pre-amps with +48V phantom power
Balanced inputs and main outputs
Peak LEDs and switchable low-cut filter on all mono channels
Ultra-musical 7-band EQ on all channels
Mute/alt 3-4, solo-in-place and pre-fader-listen function on all channels
Separate main mix, control room and headphones outputs
Highly accurate bar graph meter on output
High quality 60mm faders and sealed potentiometers
Rugged design power supply ensures superior transient response
State-of-the-art 4558 Ics and high quality components ensure crystal-clear audio performance and
excellent noise figures
All of the mixers circuit board is dual layer PCB and the devices are SMD
19" rack mounting kit included (MX600, MX800. MX1000, EMX600, EMX800)
1
11^ i
-.*••* I
ЕМХ SERIES
MX SERIES
» « » ' * * * : « * | «•
**.*[»«»
*»*•
*>•'»
»..£> 1
I
• т * * •» « «. * - -. •
ниш
®
Input channels
Input mode
MICE.I.N
THD
Gain bandwidth
Gain control range
Max input
Channel fader range
Monitor send range
Effect send range
Hi shelving
Mid shelving
Low shelving
Channel insert MAX IN/OUT
Channel to channel cross-talk
AUX input
MAX AUX input
MAX play in
AUX in gain range
Electronically balanced, 1 /4" jack or XLR MIC input
-120dBp
0.01 %(+4dBn,1 KHz)
80KHz
•5dB-+60dB
+22dB
-85dB~+10dB
-85dB~OdB
-85dB~OdB
12KHz, ±15dB,Qfixedat20CT
350Hz-8KHz,±15dB,Q fixed all ОСТ
120Hz,+15dB,Qfixedat20CT
+22dBii
$-95dB(1KHz)
+22dBu
+10dBp
-85dB~OdB
EFFECT
Max effect send/return
Effect tone
Effect send gain range
Effect return gain range
+10dBii
±12dB,8KHz
-85dB~OdB
•85dB-OdB
MONITOR OUTPUT
Max monitor output
Monitor hi shelving
Monitor low shelving
+22dBn
±15dB,8KHz
i15dB,120Hz
MIXER OUTPUT
Max output
Dual 7 band graphic equalizer
S/N
Distortion(THD)
Frequency response
Power amplifier output
+22dBii,balanceXLR&1/4"jack
2.5 multiple frequency, Q fixed at 1 0 ОСТ,±12dB
-90dB(ref:+4dBp)
0.01%, 1 KHz, +4dBn
20Hz~40KHz, ±1dB, 10Hz~120KHz, ±3dB
2X300W/4!! (EMX600 EMX800)
2X400W/40 (EMX1000 EMX1200)
Http://www. biema. com
Page 25
••••••*«*»•*•**••
»••••*•*
' >,>"
F SERIES PROFESSIONAL
MODEL: FP11OA II
SPEAKER
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)mm
N.W/G.W
F SERIES PROFESSIONAL
MODEL:
I
70Hz-20KHz
LowL10W120HiP25E
H90° x V40°
8 ohm
120W
240W/5Min
94dB(2.83V/m)
118dB
2 x NL4R speaker
550x375x380 (610x430x430)
16.5kg/29.1kg
SPEAKER
FP2JOAII
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Lona-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x Wx D)mm
N.W/G.W
F SERIES PROFESSiOMAL
MODEL:
дк,Ит-?пки?
1 o w l mW1 9ПХ2 Hi P25E
НЯП° V V40°
4 ohm
250W
500W/5Min
98dB(2.83V/m)
125dB
2 xNL4R speaker
780x380x380 (845x435x435)
23.7kg /29.1 kg
SPEAKER
FP112AII
Frequency response
Components
Directivity angle
Impedance
Lona-term power(RMS)
Power ceak
Sensitivity
Maximum SPL
Connection
DimensionsfH x Wx D)mm
N.W/G.W
Http://www. biema.com
50Hz-20KHz
LowL12W200HiP34E
H90° x V75'
8 ohm
200W
400W/5Min
97dB(2.83V/m)
123dB
2 x NL4R speaker
630x450x450 (695x495x500)
23.7kg /28.6kg
т
Page 27
PROFESSIONAL SOUND U.S.A.
F SERIES PROFESSIONAL
MODEL:
SPEAKER
FP212AII
ivi
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions (H x Wx D)mm
N.W/G.W
F SERIES PROFESSIONAL
MODEL: FPI ISA II
45Hz-20KHz
LowL12W200X2HiP34E
H90" x V75°
4 ohm
300W
600W/5Min
100dB(2.83V/m)
128dB
2 x NL4R speaker
1 000x450x450 (1 060x5 1 5x51 0)
36, 3kg /45kg
SPEAKER
Dimensions
Technical data & Introduction:
45H7-1QKH7
I n«/ L1 SWarm HiP34F
НЯП° x V7S°
8 ohm
300W
600W/5Min
98dB(2.83V/m)
125dB
2 xNL4R speaker
750x495x500 (81 5x560x560)
33kg /39. 3kg
CnmpnnRntR
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DlmensionsfH x W x D)mm
N.W/G.W
F SERIES PROFESSIONAL
MODEL:
SPEAKER
FP2/5AII
Q
Dimensions
i Technical data Er Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x Wx D)mm
N.W/G.W
Page 28
_
35Hz-19KHz
LowL15W300X2HIP44E
H90° x V75"
4 ohm
600W
1200W/5Min
102dB(2.83V/m)
133dB
2 x NL4R speaker
1 1 80x500x500 (1 240x550x5501
51 kg /60kg
F SERIES PROFESSIONAL
MODEL:
SPEAKER
FP153Л II
Dimensions
Technical data £1- Intr oduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMSt
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x Wx D)mm
N.W/G.W
F SERIES PROFESSIONAL
MODEL:
45Hz-19KHz
LowL15w300F06W80 HiP34E
НЭО* x V70'
8 ohm
350W
700W/5Min
97dB(2.83V/m)
125dB
2x NL4R speaker
880x500x500 (930x540x540)
40.5kg /46. 7kg
SPEAKER
FPI83AII
Dimensions
Technical data Er Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)mm
N.W/G.W
SERIES PROEESSIOMAL
MODEL:
.1SH7.10KH7
I ow 1 1.8ШО.О Е08ШШ Hi E340E
Н9П' v V7n'
8 ohm
500W
1000W/5Min
98dB(2.83V/m)
128dB
2 xNL4R speaker
1100x530x30 (1150x585x565)
51 kg /60.6kg
SPEAKER
FC112M II
Dimensions
Technical data Et Introduction:
Http://www. biema. com
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x w x D)mm
N.W/G.W
70Hz-18KHz
LowL12W200HiP25E
H90" x V75°
8 ohm
200W
400W/5MIP
97dB(2.83V/m)
123dB
2 xNL4R speaker
630 X 400 x 370 (700x450x440)
18.4kg/22.6kg
3
age 2£
PROFESSIONAL SOUND U.S.A.
F SERIES PROFESSIONAL
MODEL:
SPEAKER
FCI15MH
Dimensions
Technical data ft IntrotAuction:
Frequency response
Components
Directivity anale
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x W x D J m m
N.W/G.W
F SERiES PROFESSIONAL
MODEL:
40Hz-19KHz
LowL15W300HiP34E
H90' x V75°
8chm
300W
600W/5Min
99dB(2.83V/m)
127dB
2 x NL4R speaker
7 5 0 x 4 8 0 x 4 2 0 (810x500x495)
27. 4kg /32kg
SPEAKER
FD152B11
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x Wx D)mm
N.W/G.W
F SERIES PROFESSIONAL
MODEL:
35Hz-2500Hz
LowL15W300X2
4 ohm
600W
1200W/5Min
99dB(2.83V/m)
130dB
2xNL4R speaker
900 x 550 x 650 (950x595x695)
61 kg /68kg
SPEAKER
I IH it I IS II
Dimensions
Technical data £r Int reduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)mm
N.W/G.W
3
age 30
30Hz-350Hz
LowL18W400
8 ohm
400W
800W/SMin
100dB(2.83V/m)
129dB
2 x NL4R speaker
572x550x650 (630x600x695)
37kg /42. 9kg
>
E SERIES PROFESSIONAL
MODEL:
E1220 II
SPEAKER
Dimensions
Technical data & Intr oduction:
Frequency response
Components
Directivit^angje
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)mm
N.W/G.W
70Hz-20KHz
LowL12W150HiP25E
90° X60°
8 ohm
150W
300W
96dB
122dB
2 xNL4R speaker
630 x 400 x 325 (695x435x370)
18. 4kg /21 kg
E SERIES PROFESSIONAL SPEAKER
MODEL: E1520 II
и
Dimensions
Technical data & liitroduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x W x D)mm
N.W/G.W
E SERIES PROFESSIONAL
MODEL:
El SOOll
42Hz-20KHz
LowL15W250HiP34E
90' X60°
8 ohm
250W
500W
99dJ
126dB
2 xNL4R speaker
750 x 500 x 430 (800x530x475)
29. 3kg /33kg
SPEAKER
Dimensions
Technical data & Introduction:
Http://www. biema. com
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)mm
N.W/G.W
30HZ-300H2
LOW15W450
8 ohm
400W
800W/5Min
99dB(2.83V/m)
128dB
2x NL4R speaker
5 8 2 x 5 5 0 x 6 2 0 (640x590x660)
42.5kg /50.5kg
PROFESSIONAL SOUND U.S.A.
Г SERIES PROFESSIONAL
MODEL:
Til 2/1II
SPEAKER
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity anqle
Impedance
Lonq-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(Hx W x D l m m
N.W/G.W
Т SERIES PROFESSIONAL
MODEL:
60Hz-18KHz
LowP12W450HiPA51E
90" x70°
8 ohm
450W
900W/5Min
97dB{2.83V/ml__
127dB
NL4R speaker
640 x 400 x 388 (700x455x450)
29kg /33. 5kg
SPEAKER
T215A11
524.0—^
ni
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Lonq-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions (H x Wx D)mm
N.W/G.W
Т SERIES PROFESSIONAL
MODEL
35Hz-18kHz
Low P1 5W100X2 MID P6w80 Hi P44E
90° X7Q°
4 ohm
1200W
2400W/5Min
102dB(2.83V/m)
l36dB
NL4R speaker
1 2 1 0 x 5 2 4 x 5 0 7 (1275x590x575)
61.5kg/67.6kg
SPEAKER
TII5F
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMSJ
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x W x D)mm
N.W/G.W
Page 32
35Hz-18kHz
LowP15W450HiP44E
36" x60°
8 ohm
450W
900W/5Min
100dB(2.83V/m)
129dB
NL4R speaker
388x758x440 (440x800x500)
33kg /37kg
SPEAKER
У SERIES PROFESSIONAL SPEAKER
MODEL:
Т181В II
Dimensions
Technical data ft Introduction:
Frequency response
Components
Directivity_angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x Wx D)mm
N.W/G.W
38Hz SOOHz
LOWP18W600
8 ohm
600W
1200W/5Min
100dB(2.83V/m)
131dB
NL4R speaker
8 6 0 x 5 6 0 x 7 9 3 (900x600x835)
60kg /68kg
Т SERIES PROFESSIONAL SPEAKER
MODEL:
Т182 В
__
Dimensions
Technical data & Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x Wx D)mm
N.W/G.W
20Hz-300Hz
LOWP18W600X2
4 ohm
1200W
2400W/5Min
103dB(2.83V/m)
134dB
NL4R speaker
650x1100x800 (710x1160x860)
92kg /110kg
Http://www. biema. com
Page 33
PROFESSIONAL SOUND U.S.A.
SERIES PROFESSIONAL
SPEAKER
MODEL:
Ql-LAKQl-LBll
Dimensions
- 338.0—]
a- Introduction:
MODEL
Frequency channel
Frequency response
Components
Directivity
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Lona-SPL
Connection
DimensionsfH xWx D)mm
N.W/G.W
Page 34
01 -LA II
HF
MF
900Hz-18KHz
PA750 x 1
H90° x V15°
8 ohm
150W
300W75Min
115dB(2.83V/m)
150Hz-5KHz
P12w300x2
H90° x V30°
4 ohm
600W
1200W/5Min
111dB(2.83V/m)
142dB
139dB
NL4R speaker
1 250x600x805 (1 31 5x680x875)
11 5kg /129kg
| Q1-LBH
LF
38Hz-300Hz
P18w600x2
8 ohm + 8 ohm
600W + 600W
1200W+1200W/5Min
103dB(2.83V/m)
136dB
2 xNL4R speaker
1 020X 600 x 805 (1 1 00x680x875)
90kg /104kg
PV SERIES PROFESSIONAL
SPEAKER
MODEL:
PV260B/W
Dimensions
r—- 313
•-
Technical data Er Introduction :
MODEL
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DimensionsfH x W x D)mm
N.W/G.W
PV SERIES PROFESSIONAL
PV260B/W
50Hz-18KHz 45Hz-20KHz(-10dB)
Low12W200
H90" x V40"
8 ohm
200W
400W/5Min
97dB(2.83V/m)
123dB
2 xNL4R speaker
589x430x313 (650x500x390)
12.9kg /15kg
SPEAKER
MODEL:
PV360B
Dimensions
480
—
4IJI
MODEL
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
DlmensionsfH x Wx D)mm
N.W/G.W
Http ://www. biema. com
PV360B
50Hz
LowL15W300Hi P34
H90" x V40"
8 ohm
360W
720W/5Min
97dB(2.83V/m)
125dB
2 xNL4R speaker
710x480x395 (780x530x440)
19. 7kg /23. 5kg
PROFESSIONAL SOUND U.S.A
PV SERIES PROFESSIONAL
SPEAKER
MODEL:
PV4OOSUB
Dimensions
Technical data & liYtrocluction:
MODEL
Frequency response
Components
Impedance
Long-term power(RMSJ
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(HxWxD)mm
N.W/G.W
В SERIES PROFESSIONAL
PV400SUB
35Hz-500Hz
LowP15W400
8 ohm
400W
800W/5Min
99dB(2.83V/m)
127dB
2 xNL4R speaker
670x445x365(715x495x415)
14.5kg/17.8kg
SPEAKER
MODEL:
R4000 S И К
Dimensions
II 11-
,
1
о о
П
©©
о
•
Technical data £* iiitroduction:
MODEL
SPEAKER COMPLEMENT
Frequency response
Components
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
AMPLIFIERS
Power(HMS)
limiter
AUDIO INPUTS
XLR&1/4TRS connector
Sensitivity(line)
(mic)
Power supply
power consumption half power
DimensionsfH x W x D)mm
N.W/G.W
Page 36
B4000SUB
35Hz-500Hz
LowP15W400x1
2. 5 ohm
400W
800W/5Min
99dB(2.83V/m)
127dB
2 xNL4R speaker
[email protected]/1%THD
opto-controlled
balanced
-4d8to + 18dB
-24dBto-4dB
115v/230v 50-60Hz
270w
670x445x365(715x495x415)
20.3kg /25. 6kg
!
•••"
В SERIES PROFESSIONAL
LOUDSPEAKER
SYSTEM
MODEL:
B3000B/W
Introduction:
• 2-way bi-amping for excellent sound reproduction
• High-efficiency components for extremely high sound pressure
levels and ultra-low distortion
• Extensive phase and time correction ensures perfect system
alignment
• Innovative reflex cooling system for automatic convection-type
cooling
• Extremely rugged, low-resonance plastic enclosure
• Special design allows for flying operation
• High-efficiency 1.25" compression driver with titanium dome for
excellent high-frequency reproduction
• 12" long-throw woofer with high-power magnet
• Integrated 5-band PEQ and on-board crossover network with
integrated limiter ensures speaker protection
• Balanced audio inputs on XLR 1/4" TRS connectors
• High-quality microphone preamplifier allows for direct connection
of dynamic microphones
• Signals can be looped through to drive additional B3000B/W
• Clearly visible power and overload LEDs on front and rear panel
for optimal operational control
• Integrated suspension points and socket for pole or stand mounting
Dimensions
itroduction:
SPEAKER COMPLEMENT
Hiah-performance woofer
Diameter
Sensitivity
Impedance
Power(RMS)
Tweeter compression driver
Diameter
Sensitivity
Impedance
Power(RMS/music)
Horn(dispersion angle)
AMPLIFIERS
Woofer range
Power(RMS)
Power(peak)
Tweeter range
Power(RMS)
Power(oeak)
limiter
12P170A3
12" (305mm)
97dB(1W/1m)
2.5 ohms
200W/400W
34P30A8
1.25" (34mm)
97dB(1W/1m)
8 ohms
30W/2KHZ @ 1 2dB/oct
Н9СГ x V40"
1 75W & 2.5 ohms/1 % THD
230W
SOW @ 8 ohms/1% THD
70W
opto-controlled
Http://www. biema. com
AUDIO INPUTS
XLR connector
1/4 TRS
input resistance
Sensitivity(line)
(mic)
(Servo-balanced)
(servo-balanced)
20Kohms
-4dBto +18dB
-24dBto-4dB
SYSTEM DAT
Frequencv range
Crossover frequency
Bass reflex alianment
Max. SPL
50Hzto18KHz
20KHz(12dB/24dB)
6 "order
110dB(1m)
POWER SUPPLY
Mains voltage
Power consumption
Fuse
Mains connection
PHYSICAL
Dimensions(HxWxD)mm
N.W/G.W
115V/230V50-60HZ
SOOWmax
200-240VT3.15A
standard IEC connector
589x430x313 (650x495x390)
20. 7kg /22. 7kg
В SERIES PROFESSIONAL
LOUDSPEAKER
SYSTEM
MODEL:
B5000B
Introduction:
• 2-way bi-amping for excellent sound reproduction
• High-efficiency components for extremely high sound pressure
levels and ultra-low distortion
• Extensive phase and time correction ensures perfect system
alignment
• Innovative reflex cooling system for automatic convection-type
cooling
• Extremely rugged, low-resonance plastic enclosure
• Special design allows for flying operation
• High-efficiency 1.25" compression driver with titanium dome for
excellent high-frequency reproduction
• 12" long-throw woofer with high-power magnet
• Integrated 5-band PEQ and on-board crossover network with
integrated limiter ensures speaker protection
• Balanced audio in puts on XLR 1/4" TRS connectors
• High-quality microphone preamplifier allows for direct connection
of dynamic microphones
• Signals can be looped through to drive additional B3000B/W
• Clearly visible power and overload LEDs on front and rear panel
for optimal operational control
• Integrated suspension points and socket for pole or stand mounting
Dimensions
SPEAKER COMPLEMENT
High-performance woofer
Diameter
Sensitivity
Impedance
Power(RMSJ^
Tweeter compression driver
Diameter
Sensitivity
Impedance
Power(RMS/music)
Horn(dispersion angle)
AMPLIFIERS
Woofer rancje
Power(RMS)
Power(peak)
Tweeter range
Power(RMS)
Power(peak)
limiter
15P180A3
15" (381mm)
95dB(1W/1m)
2.5 ohms
250W/400W
34P30A8
1.25" (34mm)
100dB(1W/1m)
8 ohms
30W/2KMZ @ 1 2СШ/ОС1
H9U" x V4U°
AUDIO INPUTS
XLR connector
1/4 TRS
inout resistance
Sensitivity(line)
(mic)
(Servo-balanced)
(servo-balanced)
20Kohms
-4dBto +18dB
-24dBto-4dB
SYSTEM DAT
Frequency ranae
Crossover frequency
Bass reflex alignment
Max. SPL
50Hz to 18KHz
20KHz(12dB/24dB)
6 "order
110dB(1m)
POWER SUPPLY
1 75W @ 2.5 ohms/1 % THD
230W
SOW ©8 ohms/1% THD
70W
opto-controlled
Mains voltaae
Power consumption
Fuse
Mains connection
PHYSICAL
DimensionsfH x Wx D)mrn
N.W/G.W
115V/230V50-60HZ
300W max
200-240VT3.15A
standard IEC connector
710x485x395 (780x530x440)
26.5kg/31.5kg
GOLD SAHGPRO
SERIES PROFESSIONAL
MODEL:
SPEAKER
2000T
4000T
Technical
MODEL
Frequency response
Axial sensitivity 1W/1m
Maximum [email protected] 1m
Nominal impedance
Low/mid driver
HF driver
Directivity
Crossover frequency
HF protection (passive)
Power handling capacity
Connector
2000T satellite
120Hz-18kHz+/-3dB
99dB
[email protected]%THD
4 ohms
1x8"
4000T satellite
80Hz-18KHzt/-3dB
103dB
[email protected]%THD
8 ohms
1x12'
3/4"
r
90' x40'
2.5 Khz; 1 2 dB per octave
Dynamic protection circuitry
150WRMS
[email protected]
60' x40'
2KHz;1 2 dB per octave
Dynamic protection circuitry
300 W RMS
[email protected]
MODEL
Frequency response
Axial sensitivity 1W/1m
Maximum SPL @ 1m
Bass woofer
Subwoofer power amp
Satellite power amp
Active protection circuitry
Connectors
2000T sub woofer
45-250Hz,t/-3dB
101dB
[email protected]%THD
P15W300.2x1
(300W+300W) RMS for bass
150Wx2 RMS for satellites (4ohms)
Oplo-llmiter, DynaClip, Subsonic filter
2x1/4"TRSinput
2xXLHinput
2 xXLR through
[email protected]
4000T sub woofer
40-150Hz,t/-3dB
103dB
[email protected]%THD
P18W600x1
900W RMS for bass
300Wx2 RMS for satellites (8ohms)
2 xXLR through
[email protected]
2xXLRinput
2x1/4'TRSinput
Http://www. biema. com
Page 39
2. DIGITAL FEEDBACK EXTERMINATOR AMPLIFIER
PROFESSIONAL )('v PROCESSING CENTER
4, Professional Conlence System
(MC100A МСЮОВ MC100CI
t A SERIES CEILING 8РЕАШ
D5/A230/A275)
SERIES Speaker Line Array
D602BW D802BW
-
I. PP Series Plastic Cabinet
M SERIES PROFESSIONAL
AMPLIFIER
MODEL:
M4050/M4100
t EVERY CHANNEL HAS ONE VOLUMN CONTROLL,
FILTER AND BYPASS BUTTON
> EVERY CHANNEL HAS ONE SIGNAL LIGHT AND
CUTTER LIGHT
> STANDAR OUTPUT(EURO BLOCK)
> FULL SEALING COOLING CHANNEL 1 20X1 20 POWER FAN
• COMPREHENSIVE PROTECTION DEVICEI ANTI-SHORT
WAY, OUTPUT DC VOLTAGE EXCYSION PROTECTION.
OVER HEAT PROTECTION
H2DB FILTER OPTIONAL 60-120HZ
With 4 pieces of high quality and circle audio transformers
Standard 100V fixed output by 4-way
Each channel undertakes max. output 10OW
Each loop set patent limited module control
Optional AC or 24 V DC power supply
Technical data & Introduction:
M4050
M4100
MODEL
50WI4
100WX4
OUTPUT POWER
8 OHMS
300WX2
150WX2
THD«1%
BRIDGE «OHMS
20HZ-20KHZ « ±0.3dB
20Hz-20KH2«-±0.3dB
FREQUENCY RESPONSE
0,775V
0.775V
INPUT SENSITIVITY
>95dB(1KHj)
>95dB|lKHz|
SIGNAL/NOISE RATIO A-WEIGHTED RMS
>65dB(1KHz)
>65dB|1KHz)
CROSSTALK AT BATED OUTPUT POWER 8 OHMS 1 KHZ
SIDE FILTER
OPTIONAL FILTER: CROS SOVER POINT 60/120HZ,
OUTER ATTENUATION,ieeDB/OCT
<0.02%
<0.02%
NON-LINEAH DISTORTION
VARIABLE SPEED FAN
COOLING
LEVEL POWER SWITCH
FRONT PANEL CONTROLS
230V:T4A
230V:T2A
FUSE
115V:T8A
115V:T4A
482x410x132»
4B2x410x132mm
DIMENSIONS(WXDXH)mm
16.5kg/19,3kg
13,5kg/16kg
N.W/G.W
M SERIES PROFESSIONAL
AMPLIFIER
MODEL:
M8050/M8100
Introduction:
• EVERY CHANNEL HAS ONE VOLUMN CONTROLL,
FILTER AND BYPASS BUTTON
• EVERY CHANNEL HAS ONE SIGNAL LIGHT AND
CUTTER LIGHT
• STANDAR OUTPUT(EURO BLOCK)
• FULL SEALING COOLING CHANNEL 120X120 POWER FAN
• COMPREHENSIVE PROTECTION DEVICEI ANTI-SHORT
WAY, OUTPUT DC VOLTAGE EXCYSION PROTECTION.
OVER HEAT PROTECTION
• 12DB FILTER OPTIONAL 60-120HZ
Technical data &
MODEL
OUTPUT POWER
8 OHMS
THDS 1%
BRIDGE 8 OHMS
FREQUENCY RESPONSE
INPUT SENSITIVITY
SIGNAL/NOISE RATIO A-WEIGHTED RMS
CROSSTALK AT RATED OUTPUT POWER 8 OHMS 1 KHZ
SIDE FILTER
NON-UNEAR DISTORTION
COOLING
FRONT PANEL CONTROLS
FUSE
DIMENSIONS(WXDXH)mm
N.W/G.W
M8100
tOOWxS
300WX4
150WX4
20Hz-20KHz •-- ±0.3dB
20Hz-20KHz' r i0.3dB
0.775V
0.775V
>95dB(1KHz)
>95dB()KHz)
>65dB(1KHzl
>65dB(1KHz)
OPTIONAL FILTER: CROSSOVER POINT 60/120HZ,
OUTERATTENUATION,I88DB/OCT
<0,02%
<0,02%
VARIABLE SPEED FAN
LEVEL POWER SWITCH
230V T8A
230V:T4A
115V:TI5A
115V:T8A
482x4IOx132mm
482x410«132mm
M8050
sowxa
17.7kg /20.5kg
21 .Okg /23.2kg
Http://www. biema. com
Page 41
PROFESSIONAL SOUND U.S.A.
DIGITAL FEEDBACK EXTERMINATOR
AMPLIFIER
MODEL:
•
•
•
•
•
•
•
DP10OF/DP200F
24-bit, X-A AD/DA, 96kHz sampling rate.
6 microphone adjustable inputs with phantom power
Digital treble & bass control
Strong feedback exterminating function
RMS 2x80W 8ohm load
4 way audio selected inputs, one way mixer line output
2x16 character backlit LCD
PROFESSIONAL AV PROCESSING
CENTER
MODEL:
AV2OOXP/AV3OOXP
Introduction:
Four-way mono channel mic input
Two-way stereo circuit source input
Four group stereo plus vedio converting input
One group of vedio jack output
One group stereo circuit output
One group stereo power output
Internal 200WX2 power amplifier
Internal digital effector
PROFESSIONAL CONFENCE SYSTEM
MODEL:
MC10OA/MCIOOB/MC10OC
Introduction:
Easily operate in Hi-Fi tone
Speaking through pushing button
Connected with 50 pieces of delegates driver and 150
representatives are available in conference room
Suitable for small and midium meeting room
Whistling restrained function
The delegate can speak by telephone away from the
meeting room with telephone coupler fit
Restrained function for number of persons
Internal uni-directional cardioid patterns condenser
Working indicator shows in the microphone
Priority button of chairman driver is convenient to
control the room cosmos
Easy to assemble, own sorts of output jack and
connect with existing amplifier instrument directly
Technical data ft Introduction:
POLAR PATTEM
FREQUENCY RESPONSE
OUTPUT IMPEDANCE
SEMSITIVITY
OPERATING VOLTAGE
S/N
Page 42
UNI-DIRECTIONAL
40HZ-16KHZ
200 Q
15MV/PA
006P9V
72dB
PUBLIC 61?ЮАО(
A SERIES CEILING
SPEAKER
MODEL:
A2O5/A230/A275
Dimensions
Technical data Er Introduction:
MODEL
Continues power loading
Peak power
Sensitivity
Dimensions
Hole dimensions
Weighed
Dimension
D SERIES SPEAKER LINE ARRAY
MODEL:
!
A205
6W(RMS)
A230
8W(RMS)
10W/5min
90dB2.83V/m
15W/5min
92dB2.83V/m
0230x75mm
0205x75mm
0195mm
0165mm
OJkq
5.25"
A275
10W(RMS)
20W/5 min
95dB2.83V/m
0275x1 05mm
0240mm
0.8kg
1.15kq
6.5'
8"
«602B/W
D8O2B/W
Dimensions
275.0
280,Q__
IDJ
Technical data & Introduction:
MODEL
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(HxWxO)mm
N.W
PP SERIES PLASTIC
CABINET
MODEL:
D602B/W
70H2-20KHZ
LowP(6550120CHWHiPA34T
H100' X V50'
4 ohm
120W
240W/5Min
93dB(2.83V/m|
D802B/W
60HZ-20KHZ
Lo»Ple050120CHWHiPA34T
H100' x V50'
4 ohm
150W
300W/5Min
93dB{2.83V/m)
1ШВ
118dB
2 x NL4R speaker
620x220x222
9.9kg
2x NL4R speaker
695x275x280
13.5kg
PP50B/W
PP80B/W
ensions
MODEL
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(HxWxD)
N.W
P50B/W
80Hz-18KHz
LowT05W35
H1001 x V50"
8 ohm
35W
P80B/W
40HZ-20KHZ
Low T08W/0
H100' x V50'
8 ohm
SOW
ieow/5Miri
70W/5Min
86dB(2.e3V/m)
104dB
2 x NL4R speaker
285xl68xt55
93dBg.83V/m)
114dB
2 x NL4H speaker
450x260x245
3kg
8kg
Hffp ://www. biema. com
Page 43
1. АР SERIES PROFESSIONAL KALAR OK AMPLIFIER
(AP1500I/AP2000I)
2 S SERIES PROFESSIONAL KALAR OK SPEAKER
(S01i/S03i)
3. Т SERIES PROFESSIONAL KALAR OK SPEAKER
4. HH INFRAflED WIRELESS MICROPHONE SYSTEM
(№000)
-V
'*•;:
""V\V>,x >
k
age 44
SYSTEM
АР SERIES PROFESSIONAL
KARAOKE
MODEL:
AMPLIFIER
AP1500i/AP2000i
Memory funtion tor echo, music and microphone level.
Therefore, it can be preset according to the areas of the
site. Especially it can obtain singnificant effects on
karaoke room or connecting choosing-song system.
Signal resource alternated automaticly.
Built-in DSP Key controller ±2.5 tones in halftone steps,
total in 1 1 stages. And return automatically to the
standard tone at the end.
Auto vocal changing, music accompaniment function.
3-microphone inputs, and Key controller can be used for
microphone.
Built-in high quality digital echo.
Fit musical output teminal, it can be connected with input
terminal of subwoofer device.
Fit recording output terminal that it can be connected with
extenal recording system.
Can be selected to connect extenal effector.
Whole functional remote controller. Control of music,
microphone tones, echo volume, AV source select, auto
vocal changing, music muting.
is available to add a SOW central amplifier
duction:
Technical d
MODEL
Amplifier maximum out put(1KHZTHD = 1%)
Input jacks
MIC
(sensitivity/impedance)
Ld vcd aux dvd
BGM
Output jacks
(output level/output
impedance)
Frequency response
Line-output
Record-output
Preamp-outcut
MIC
MUSIC
Music
Tone control
Characteristic
mid
treble
bass
microphone
mid
treble
1 system onlv.1 or 2
2 system operation land 2
Speaker output
terminals
Key control ranae
Video input iackstsens tivity/input impe dance)
Video output iacks(out jut level/output mpedance)
Supply voltage
Power consumption
Di mansions (Wx HxDlmm
N.W/G.W
AP 1500i
AP2000J
150W + 1 SOW/8 ohm
200W + 200W/8 ohm
8m v/ 10k ohm (unbalance)
280mv/22k ohm(unbalance)
280mv/22k ohm(unbalance)
280mv/100 ohm(unbalance)
0.75V/620 ohm(unbalance)
0.75V/100 ohm (unbalance)
20HZ--20KHZ =£ ±3dB
20HZ—40KHZ =S +0.5dB
±10dB(75HZ)
±10dB(1.3KHZ)
±10dB(10KHZ)
i10dB(75HZ)
±10dB(1.3KHZ)
+ 10dB(10KHZ)
4 ohm to 16 ohm
8 ohm to 16 ohm
11 steps +2 1/2tone
1 у„.„/75 ohm
1v B _ p /75 ohm
AC 115V(110V -120V)60HZ
/230V(220V ~ 240V)50HZ
230W
300W
440x405x132 (500x435x200)
12. 5kg /14. 2kg
13. 5kg /15kg
Http ://www. biema.com
Page 45
ium 11 и 11 mill I
р
SYSTEM
SERIES PROFESSIONAL KALAR OK SPEAKER
MODEL:
SOH/S031
Technical data £r Introduction:
MODEL
Frequency response
Components
Directivity angle
Impedance
power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(HxWxD)mm
N.W
S01i
40Hz-20KHz
Low 8' Hi25#Slikfilm
H90' x V90'
8 ohm
100W
200W/5Min
93dB(W/m)
113dB
2 x NL4R speaker
456x268x236
8.5kg
S03i
35Hz-20KHz
Low 10' x) Hi 25* Siik film+3" paper cover
H90= x V90'
8 ohm
150W
3QOW/5Min
96dB(W/m)
чТмв
NL4R speaker
530x305x300
13kg
Т SERIES PROFESSIONAL KALAR OK SPEAKER
MODEL:
T22
Technical data Er Introduction:
Frequency response
Components
Directivity angle
Impedance
Long-term power(RMS)
Power peak
Sensitivity
Maximum SPL
Connection
Dimensions(H x W x D)
N.W
HH INFRARED
WIRELESS MICROPHONE
HH2000 Receiver
Receiving Mode
Receiving Freouencv
AF Output
Power Source
Dimension
80Hz-20KHz
Low5"x2 Hi25#Slikfilm
H95° x V95°
6 ohm
SOW
160W/5Min
93dB(W/m)
112dB
NL4R speaker
352x552x100
7.5kg
SYSTEM
MODEL:
ИН20ОО
Channel A:2.35MHz;Channe I B:2.85MHz
100mV6000
DC18V500mA
(L)430X(W)235x(H)55mm
HH2000 Handheld Microphone
Transmitting Mode
Infrared
Transmitting Frequenc X
ChannelA:2.35MHz;Channe I B:2.85MHz
Infrared Transmitting Fange^ 10m
Power Source
3V(2X1. 5V AA Batteries)
Current Consumption
150Ma
Tone Code
32.768KHz
Sensitivity
16dB/Uv
Infrared hand microphone(with typical recharger)
Infrared Mic receiver
External infrared sensor
ACCESSORIES
Infrared microphone charger
External sensor(optional)
Adaptor for infrared receiver
Adaptor for charger
Aabatteries
External extended connection
Http://www. biema. com
Page 46
ят.
1. Y Y SERIES PROFESSIONAL MICROPHONE
(YY1000YYJOOOI
2. UHF58N Series Wireless M i c r o p h o n e
(SM1SM2/SM3I
•
UHF
Page 47
PROFESSIONAL SOUND U.S.A.
YY SERIES WIRING MICROPHONE
MODEL:
WJOOO/W3000
TRANSFORMER OUTPUT. WIDER FREQUENCY RESPONSE
FINE HYPER-CARDIOID POINT
POWERFUL BASS, ALT EXQUISITE
HIGH GAIN BEFORE FEEDBACK, NOT HOWL
LOW NOISE, ANTI-POP
AVAILABLE FOR PROFESSIONAL AMPLIFICATION,
RECORDE, AND KALAR OK
Technical data £r Introduction:
MODEL
Type
Directivity angle
Frequency response
Sensitivity
Impedance
I III ,7«ii SERIES WiRELESS
YylOOO
Dynamic micro phone
Hyper-cardioid
50~1600Hz
-54dBV/PA(2,Omv/pa)
200 ohms
YySOOO
Dynamic microphone
Hyper-cardioid
50~1600Hz
-54dBV/PA(2.0mv/pa)
300 ohms
MICROPHONE
The type of special wireless microphone system in UHF frequent band is designed to solve noise digital restrained circuit besides
normal method such as improving frequency, multi-level high frequency with narrow band and FM filter. It's effective to make up
for shortage of traditional wireless microphone at interference due to frequency too low, especially a lot of harmonic in CD, VCD
and LD by reason of rediation. Sometimes the receiver will occur strongly exposure noise as state noise circuit of microphone
open abruptly. So the new microphone is designed to lock its circuit by PLL phase, and set 16fixed channel to choose with 400
frequency to be adjusted freely, and no interference to be appeared simultaneously operating many machines.
Introducti
Mainframe of receiving
19 typical bracket (two mainframes are available)
Page 48
Using UHF 800 MHz band to avert interferencing frequency.
Equipped wih exquisite LCD pandl, to show receiving channels, and
operate more easily.
Look qutomatically from preset 16 mon-interfered channels, may be
adiust 400 free
Channels.
All use with UHF PLL circuit, so the frequency is very steady.
With audio compredding expanding technology, the machine can
lower noises and increase Cpecial tone edy locked identity functions
to avoid interference signal from outside open
The mute system.
There are mulriple noise detect circuit, multi circuits, So it has strong
anti-jamming speciality.
CPU control diversity receiving mode that contributes not only long
reception range but
Eliminates the signal dropouts and unstabl reception.
Choose excellent chipset and high quality component, sothat its
timbre will be very good.
Fixed receiver
Power supply
Consume power
Signal/noise ratio
Image & spurious rejection
Border upon channel rejection
Receiving sensitivity
De-emphasis
DC 17V
4 water
More than 90dB
More than 80dB
More than 80dB
10dBuV(Sinad = 30dB)
50us
ssie
I III ЛИП SERIES
WIRELESS
MfCROPHO
i
MICROPHONE
MODEL: SMI / handing
Technical data & Introduction:
Handing microphone
Transmitter power
Modulation tvpe
Max deviation
Spurious emission
Battery voltage
Continuous using
1/HF58H SERIES
WIRELESS
9mW
FM.F3F
±25KHz
More than 40dB(With carrier)
9Vx1
6 hours
MICROPHONE
MODEL:
SM2 / Holder
Technical data & Introduction:
Transmitter power
Modulation type
Max deviation
Spurious emission
Battery voltage
Continuous using
I III r.Jiii SERIES
WIRELESS
8.5mW
FM.F3F
+25KHz
More than 40dB(With carrier)
9Vx1
6 hours
MICROPHONE
MODEL:
SMS / Head Wearing
1 Technical data & Introduction:
Head wearing microphone
Transmitter power
Modulation type
Max deviation
Spurious emission
Battery voltage
Continuous using
8mW
FM.F3F
±25KHz
More than 40dB(With carrier)
9Vx1
6 hours
-4-1
Http://www. biema.com
Page 49
U.S. A
P.O.Box 2245Alamoda.CA!J4()Ol U S.A
1Ы t 510 3379285
i ax i 510 /I/H328
E-mail; biom. i ""(.i и ncasl.net
CHINA
No.4,Ro;i(i;' Caler Industrial and business zone
Shlf|i,io liiwn. 1','inyii rli-.liii.l r.iii;iiK|zhou.ChiM,i
PC Ы 1400
ТоГ 8f> 20-22871788 (8 lines)
86 20 22871781 ( u x p o i l )
86 20-22871/8;.1 (domestic)
f a x ж; ;'0 ;';•« / 1 799
I mail ,iu(li(i<. "liic.'ma.com
expo [email protected], com
[email protected]
[email protected]
Компания A-Music, Розничные продажи
тел + 7(095)974-8491, 789-6638
факс +7(095)974-8491
Wtp//:www.amusicshop.ru ; e-mail:[email protected]
Оптовые поставки
тел + 7(095)200-0327, 269-6701,
504-1599 факс +7(095)200-0327
http//:www.amusic.ru ; e-mail:[email protected]
ntomiation on this brochure is general introduction tor the products The
brochure can not be used for other way without approval by our company,
we keep rights to change the specifications or design without notice.
ГУ РосНИИИТ и АП
Ассоциация МВТК
Федеральный информационный фонд отечественных и
иностранных каталогов на промышленную продукцию
Каталог был представлен на выставке
«Музыка - Москва - 2004»
Каталог включен в базу данных
«Федерального информационного фонда
отечественных и
иностранных каталогов на промышленную
продукцию»
Россия,105679, Москва, Измайловское шоссе, 44,
Тел./факс (095)366-5200,366-7008, 365-5445. e-mail:; [email protected],
www.ffpk.ru
Электронная копия издания изготовлена с целью её включения в базы
данных Федерального информационного фонда отечественных и
иностранных каталогов на промышленную продукцию, которые
формируются в соответствии с Постановлением Правительства РФ от 24
июля 1997 г. № 950 и Постановлением Правительства РФ от 31 декабря 1999
г. № 2172-р и зарегистрированы Комитетом по политике информатизации
при Президенте РФ под №№ 39-50.
2005 год
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
