TABLE OF CONTENTS
American Security Products Company has been
dedicated to manufacturing high quality, high
security safes since 1946. We offer an extensive
product line of over 400 standard models of
burglary and fire resistant safes in every insurance
classification from “B” rate to Underwriter’s
Laboratories TL-15 and TL-30.
AMSEC is the largest and most respected safe
manufacturer in the industry because:
• Our dedicated customer service
representatives care about you.
• Fully staffed service department
networked with thousands of factory
trained technicians.
• Our quality control department assures
that the products we build are the finest in
the industry.
• State-of-the-art computer controlled
manufacturing equipment helps us meet
demanding deadlines and keeps us on the
leading edge of technology.
• We are located in a major West Coast
distribution point with direct access to all
major domestic and international freight
services.
• We specialize in developing custom
safes to meet specific cash handling
requirements for banks, restaurants,
supermarkets, convenience stores and
many other industries.
• Our engineering and design department
is fully staffed and features the most
advanced CAD system for rapid creation
of sales drawings, design modifications
and precise manufacturing blue prints.
For superior asset protection there is only
one name you can trust for quality, service
and reliability…AMSEC.
AMSEC reserves the right to incorporate any improvements
and alter any specifications without prior notice. AMSEC
reserves the right to update products as necessary,
AMSEC is not responsible for typographical errors.
SQUARE DOOR FLOOR SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES. . . . . . . . . . . . . . . . . . . . . 4
FLOOR SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
STAR® ROUND LIFT-OUT DOOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
STAR® RECTANGULAR BODY, ROUND LIFT-OUT DOOR . . . . . . . . . . . . . . . . 7
MAJOR® ROUND LIFT-OUT DOOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
UNDERCOUNTER SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WALL SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DEPOSITORY SAFES
BSW SERIES - THE SAFEWIZARD® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
BWB SERIES - WIDE BODY CASH CONTROL. . . . . . . . . . . . . . . . . . . . . . . . 11
DS SERIES - “B” RATE ROTARY AND FRONT LOADING. . . . . . . . . . . . . . . . 12
MONEY MANAGER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
“B” RATE SECURITY SAFES
BWB SERIES, US2015 AND MS1414 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
“B” AND “C” RATE SECURITY CHESTS
BLB AND BLC SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
HOTEL & RESIDENTIAL ELECTRONIC SAFES . . . . . . . . . . . . . . . . . . 16
COMMERCIAL SECURITY SAFES
NEW! CSC SERIES COMPOSITE SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
BF® SERIES
U.L. LISTED FIRE RATED BURGLARY SAFES . . . . . . . . . . . . . . . . . . . . . . . 18
UL SERIES
U.L. LISTED 2-HOUR FIRE AND IMPACT SAFES. . . . . . . . . . . . . . . . . . . . . . 19
IMPORTED U.L. LISTED 1-HR FIRE SAFES
RESIDENTIAL - ELECTRONIC AND COMBO. . . . . . . . . . . . . . . . . . . . . . . . . 20
COMMERCIAL FIRE SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CASH BOXES AND KEY CABINETS . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
ELECTRONIC SECURITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
GUN SAFES
HS SERIES - HIGH SECURITY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
THE BF® SERIES GUN SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
HS/BF® SERIES ACCESSORIES AND OPTIONS . . . . . . . . . . . . . . . . . . . . . . 25
SF SERIES - SIXTY MINUTE FIRE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
TF SERIES - THIRTY MINUTE FIRE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
VAULT DOOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
HOME SECURITY
HORIZONTAL CABINET HC1854 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
AM SERIES HOME SECURITY SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
HANDGUN SECURITY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
DXE / DXF AND CDXE / CDXF U.L. LISTED
TL-15 & TL-30 MONEY CHESTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
COMPARISON CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
AMVAULT TL-30 AND TL-15
FIRE RATED COMPOSITE SAFES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
SAFE SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
OPTIONAL EXTRAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
TELLER LOCKERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
CUSTOM SAFES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
ELECTRONIC LOCKS
ELECTRONIC LOCK COMPARISON CHART. . . . . . . . . . . . . . . . . . . . . . . . . 39
AMSEC SAFEWIZARD® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
AMSEC ESL-XL SERIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
AMSEC ACCESS MANAGER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
SARGENT AND GREENLEAF COMPTRONIC™. . . . . . . . . . . . . . . . . . . . . . . 42
KABA-MAS AUDITCON® 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
LAGARD ELECTRONIC SAFE LOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
MATERIALS HANDLING EQUIPMENT. . . . . . . . . . . . . . . . . . . . . . . . . . 44
STORAGE CABINETS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
MERCHANDISING / DISPLAYS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
INDEX BY MODEL NUMBER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
A Guide to Safe Usage
REQUIRED FED EX / UPS PACKAGING
Additional packaging is required for all safes shipping via FedEx or UPS to protect the safe from transit
damage. This excludes products already packaged for FedEx or UPS shipment.*
Maximum weight for FedEx or UPS is 150 lbs.
AMSEC will not be held liable for damages if this packaging is not requested at the time of order.
Order Part #4505400
Net up charge $8.00 per package.
*PB2 / WS1814 / SWVV1014
SQUARE DOOR FLOOR SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES
All BRUTE SERIES safes are designed to provide secure storage for documents, jewelry, precious metals and
miscellaneous valuables at an economical price. When properly installed in a concrete floor, BRUTE SERIES safes
provide excellent fire and burglary protection. BRUTE floor safes meet and exceed the requirements of the Insurance
Offices Manual of Burglary Insurance. You may also add many options to customize your safe such as: A drop slot
in the door, depository chute, digital keypad lock and keylocking dial to name a few. BRUTE SERIES safes may be
installed in the floor, wall, cladding or within a larger safe.
B3800
TOP VIEW
OF B1500
SUPER BRUTE
SUPER BRUTE
Model 1500
SUPER BRUTE & BRUTE
• Black textured body and door.
• Large brass plated dial and black matte
finish dial ring with matching handle.
• Doors are interchangeable within
product group.
• 3M Lexan escutcheon plate covers the
entire door surface.
BODY:
• End user can get combination changes
by just bringing the door to a locksmith.
• Oversize floor plate ensures strong
installation in concrete.
• Flush cover plate.
• Attractive design offers strong reliable
welds to protect against burglary
attacks and reduce possible leakage.
• Solid steel hinge mechanism using 3/8"
diameter steel hinge pins and internal
mounting bolts.
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
SUPER BRUTE SERIES
• An additional spring loadedrelocking
device, activated by a punching attack.
• The SUPER BRUTE’s new door jamb
design is manufactured with state-ofthe-art equipment, with built-in devices
offering the ultimate protection against
sledgehammer attack.
• Lock and relocks are protected by a
large carburized hardplate.
• A handle activated locking mechanism
consisting of three 1" diameter locking
bolts. Each one is drive resistant,
chromed steel with a long throw.
• One piece heavy duty dead bar behind
hinge prevents removal of door even
if hinges are removed during a forced
entry attempt.
ADDITIONAL FEATURES:
• “B+” rate door: ¾" solid steel plate
door is standard.
• Doors are removable and
interchangeable.
• A large, convenient 10¾" x 111/8" door
opening for bulky items.
• One sliding shelf with double wide
model (B3700). Two sliding shelves
with triple wide models (B5800).
• Attractive carpeted floor in every unit.
B1500
For Slotted Door see Page 35
• Door is designed to fit full body size,
which greatly reduces any possible pry
points.
STANDARD FEATURES:
B3700
DOUBLE COMPARTMENT
Super Brute Floor Safes
Lifetime Replacement Warranty:
If your AMSEC Super Brute floor safe is
subject of a sledgehammer or pry attack
and is forcibly entered, AMSEC will replace
or repair the safe (our option) with a current
production model of comparable value - free of
charge. The damaged safe must be returned
freight prepaid to the factory within 30 days
of the loss, accompanied by a properly filled
police report. This warranty does not apply
to damage or loss resulting from accident,
alteration, unauthorized entry or improper
installation. AMSEC’s limited warranty policy
and procedures applies to any extended
product warranties.
amsecusa.com/floor-safes-brute-superbrute.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
SQUARE DOOR FLOOR SAFES
BRUTE, SUPER BRUTE AND MINI BRUTE SERIES
B1816
B1810
MINI BRUTE
Model B400
B1806
BRUTE RECTANGULAR
BODY, WIDE DOOR
MINI BRUTE
ADDITIONAL FEATURES:
• Black textured body and door.
• A large, convenient 11¾" x 16" door
opening, for large bulky items or cash
tray storage.
• Large brass plated dial and black matte
finish dial ring.
• B-rate door of ½" solid steel plate.
MINI BRUTE
Model B700
DOOR:
• Convenient,reversible lift-out door with
a heavy duty handle.
• Optional baffled drop slot in door
• ½" A36 solid steel plate. New steel
guards protect lock and relock from
accidental damage.
BODY:
• U.L. listed Group II lock with relock. An
additional relocking device, activated by
punching attack.
• Universal jamb design allows the door
to be positioned in all four
directions.
• Heavy duty dead bar prevents removal
of door during forced entry attempt.
• A flush cover plate for total
concealment under a carpet.
• 8" square tubular “B” Rate
construction.
SuperBrute "B" Rate Rectangular Hinged Door Floor Safes
Model
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
B1500*
117/8 x 13¼ x 8¾
12¾ x 141/8 x 11¾
10¾ x 111/8
1377
102
B2200*
11 /8 x 13¼ x 14
12¾ x 14 /8 x 17½
10¾ x 11 /8
2203
118
B2900*
117/8 x 13¼ x 18¼
12¾ x 141/8 x 213/8
10¾ x 111/8
2872
134
B3800*
125/8 x 18 x 17
12¾ x 18¾ x 213/8
10¾ x 111/8
3864
136
B3700*
11¾ x 23 x 14
12¾ x 24 x 17½
10¾ x 111/8
3785
145
B5800*
11¾ x 35 x 14
12¾ x 36 x 16¾
10¾ x 11 /8
5758
185
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
7
1
1
1
*Constructed of 3/4" door and B-Rate body. Slotted outer door not recommended for use on B1500.
Brute Wide Door "B" Rate Rectangular Hinged Door Floor Safes
Model
Inside Dimension
HxWxD
B1806
12¼ x 18½ x 6
13¼ x 19½ x 9
11¾ x 16
1360
102
B1810
121/3 x 18½ x 10
13¼ x 19½ x 13
11¾ x 16
2281
116
B1816
12¼ x 18½ x 16
13¼ x 19½ x 19
11¾ x 16
3626
142
12¼ x 18½ x 5¾ (top)
12¼ x 18½ x 10 (btm)
13¼ x 19½ x 19
11¾ x 16 (top)
63/8 DIA (btm)
1303 (top)
2266 (btm)
152
B1816D*
*Double Compartment - Slotted inner door. Slotted door not recommended for use on B1806.
"B" Rate Square Body / Lift-Out Door Floor Safes
Model
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Capacity
Wt.
B400*
75/8 x 75/8 x 6¾
8½ x 8½ x 101/8
65/8 x 65/8
393
32
B700*
7 /8 x 7 /8 x 11¾
8½ x 8½ x 15 /8
65/8 x 65/8
683
42
5
5
1
Slotted door not recommended for use on B400. *Optional UPS packaging available. See inside front cover for information.
amsecusa.com/floor-safes-mini-brute.htm
FLOOR SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
STAR® ROUND LIFT-OUT DOOR
FLOOR SAFES are engineered with advanced security features. STAR Tube safes have
been the standard for gas stations, fast food, small retail establishments and home owners for
over 50 years.
Low cost, combined with the various body styles and optional doors will fit almost any cash handling system. When
properly installed in concrete, STAR® FLOOR SAFES provide maximum fire and burglary protection. Now, with the
water-resistant dust cover, you get protection from water as well.
c7
“C” Rate Lift-Out Door
Features:
• Manipulation resistant, unitized U.L.
Group II key changeable lock protected
by a revolving carburized hardplate.
• Removable dial and drive/drill
resistant spindle preventing damage
from burglary attack and additional
protection from hold-up.
• Door, 7-1/4" clear opening, is 1-3/4"
solid steel.
does not rattle or slide like most covers.
• STAR’s double compartment models
provide the commercial user with the
most effective cash handling system
available. Hold-up as well as burglary
protection is greatly enhanced by use
of this type of safe.
c5
• Available with dual key inner
compartment. Manager holds one key,
the armored car driver, or employee
holds the second.
c3
• Door is securely locked by three bolts
each requiring over 25,000 pounds to
shear.
star® “C” rate tubular body safes
• Each locking bolt has its own hardened
steel positive relocking bolt.
• Body — Heavy “B” rate construction.
OTHER FEATURES:
• Water resistant, high impact molded
dust cover with rubber “O”-ring seal
KEYLOCK WITH COMBINATION DUAL CONTROL
CUTAWAY VIEW “C” Rate Lift-Out Door
CUTAWAY VIEW OF
STAR® DOUBLE COMPARTMENT
KEYLOCK door
water resistant dust cover
Model
When properly installed in concrete,
STAR® Floor Safes provide excellent
fire and burglary protection. Now, with
the water resistant dust cover, you get
protection from water as well.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Wt.
C3
8¼ DIA x 5¾
8¾ DIA x 9
7¼ DIA
280
40
C5
8¼ DIA x 10
8¾ DIA x 13½
7¼ DIA
510
46
C7
8¼ DIA x 16
8¾ DIA x 19
7¼ DIA
785
55
CD5*
8¼ DIA x 4¼ (top)
8¼ DIA x 4½ (btm)
8¾ DIA x 13½
7¼ DIA (top)
63/8 DIA (btm)
225 (top)
240 (btm)
54
CD7*
8¼ DIA x 5¼ (top)
8¼ DIA x 9 (btm)
8¾ DIA x 19
7¼ DIA (top)
63/8 DIA (btm)
175 (top)
480 (btm)
66
*Double Compartment-Slotted Inner Door
amsecusa.com/floor-safes-star-round.htm
October, 2008
Product Catalog
American Security Products Co.
FLOOR SAFES
STAR® RECTANGULAR BODY, ROUND LIFT-OUT DOOR
Rectangular
Body, Round
Lift-out Door
“B” RATE
FLOOR SAFES offer a large cubic inch
capacity at a reasonable price. Strong,
continuously welded steel bodies are
offered with our standard “C” rate lift-out
combination door and water-resistant
dust cover.
BDP24
B24
B17
B6
“C” RATE LIFT-OUT
FEATURES
DOOR:
Model
• Utilizes the STAR high security “C” Rate
door.
BODY:
• “B” Rate construction available in double
compartment models (D) or outside drop
chute (BDP).
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
B6
12 x 10 x 5¼
12½ x 11¼ x 9¾
B17
12 x 12½ x 10
13 x 13 x 15
B24
12 x 12½ x 14½
BD24*
BDP24**
Cu. In.
Wt.
7¼ DIA
630
62
7¼ DIA
1500
98
13 x 13 x 19
7¼ DIA
2175
122
12 x 12½ x 5½(top)
12 x 12½ x 10 (btm)
13 x 13 x 20
7¼ DIA
63/8 DIA (btm)
825
1500
(btm)
130
12 x 12½ x 4¼ (top)
12 x 12½ x 13¾ (btm)
13 x 13 x 22
7¼ DIA
63/8 DIA (btm)
638
2063
(btm)
142
*Double Compartment-Slotted Inner Door. **Double Compartment - Solid Inner Door with Outside Drop Chute
MAJOR® ROUND LIFT-OUT DOOR
MAJOR® Tubular Body, Round Lift-Out DOOR FLOOR SAFES provide
excellent fire and burglary protection when properly installed in concrete.
t925
“C” RATE LIFT-OUT DOOR
FEATURES
• A positive relocking device jams locking
mechanism in the event of a forced entry
attempt.
• Unitized U.L. Group II key changeable lock
with randomized opening positions defends
against drill attacks.
• Recessed locking mechanism protected by
a large carburized hardplate.
• Drive resistant dial and spindle blocks
sledgehammer attacks.
• Heavy duty “B” rate solid steel body with
reinforced door jamb.
• Door, 65/8" clear opening, is 1" thick
solid steel.
•Available in double compartment models
(DD) with a key locking inner door.
• Door is securely closed by three 5/8" drive
resistant locking bolts.
•Inside slot to bottom compartment on all
(DD) models.
t625
t425
Model
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Wt.
T425
8¼ DIA x 5¾
85/8 DIA x 8¾
65/8 DIA
307
40
T625
8¼ DIA x 10¼
8 /8 DIA x 13¼
6 /8 DIA
545
46
T925
8¼ DIA x 15¾
85/8 DIA x 18¾
65/8 DIA
840
54
T625DD*
8¼ DIA x 4½ (top)
8¼ DIA x 5¼ (btm)
85/8 DIA x 13¾
65/8 DIA
65/8 DIA
241
285
54
T925DD*
8¼ DIA x 7½ (top)
8¼ DIA x 7¾ (btm)
85/8 DIA x 18¾
65/8 DIA
65/8 DIA
401
420
64
5
*Double Compartment - Solid Inner Door with Drop Chute.
amsecusa.com/floor-safes-major-round.htm
5
CUTAWAY VIEW of “major” Door
UNDERCOUNTER SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
UNDERCOUNTER SAFES
AMSEC’S UNDERCOUNTER SAFES limit excess cash register funds by providing
instant protection for interim deposits of cash or checks via the anti-fish deposit
slot. Securely positioning the safe next to the cash register limits exposed cash and
reduces the threat of robbery and internal theft. Adaptable for multi-unit installation
use, ideal for gun control, staff use, athletics clubs, security areas and much more.
LOCK OPTIONS:
• Chicago single key camlock
equipped with two keys.
(Lock option #1)
• Chicago 7 pin radial key
camlock, equipped with 2
keys. (Lock option #1-T)
Medeco® single key camlock
• Medeco® U.L. listed high security single key
camlock supplied with two
keys. Medeco’s restricted
keyways protect against
unauthorized key duplication.
(Lock option #2)
(Lock option #1t)
tb0610-1t
Chicago 7 pin camlock
FEATURES:
• Heavy gauge solid steel
construction.
• Full width deposit slot over
door equipped with an “antifish” saw tooth baffle to guard
against pilferage or fishing.
• Heavy-duty piano hinges.
• Available in three models with
eight different lock options to
fit your specialized security
requirements.
• Units can be bolted together
utilizing bolt holes.
• Interchangeable doors allow
flexible means of changing
locking mechanisms without
replacing the entire unit.
• Two anchor holes provided
on all four sides.
(Lock option #1)
tb0610-1 OR
tb0612-1
Chicago single key
camlock
• Dual custody safe deposit key
lock (two keys required to open
safe). (Lock option #4)
• Best removable core key
lock supplied without core. A
removable core system lets
you change the combination
of any lock in seconds and
can easily expand to include
new facilities. Supplied
without core. (Lock option #7,
without core).
(Lock option #4)
tb0610-4 OR
tb0612-4
(Lock option #6)
tb061210-6
Dual custody safe
deposit key lock
S&G Group II key changeable
combination lock
• S&G Group II key changeable
combination lock offers 1
million possible combinations.
(Lock option #6).
• Optional custom key control
systems designed to your
security requirements:
1) Master Keyed
• Attractive and durable
powder coated black finish.
(Lock option #2)
tb0610-2 OR
tb0612-2
K2
(Lock option #7)
tb0610-7
Best removable core
key lock
2) Keyed Alike
3) Keyed Different
OPTIONS:
K1
HEAVY DUTY SERIES
MODEL K1 AND K2
• 1/4" thick A36 solid steel plate
hinged door.
• Deposit envelopes.
• Full width slot over door.
• A saw tooth baffle guards against
pilferage or fishing.
Model
Inside Dimension
H" x W" x D"
Outside Dimension
H" x W" x D"
Clear Door
H" x W"
Cu. In.
Cap
Wt.
Lbs
TB0610(*)
57/8 x 57/8 x 83/8
6 x 6 x 10
57/8 x 5
289
6
TB0612(*)
5 /8 x 5 /8 x 10 /8
6 x 6 x 12
57/8 x 5
359
8
• Your choice of U.L. listed dual
control keylock (K-2), a single key
Medeco® lock (K-1), or a Chicago
single key lock (K-1A).
TB1210(*)
117/8 x 57/8 x 83/8
12 x 6 x 10
57/8 x 5
585
15
• “B” Rate steel construction.
55/8 x 55/8 x 10
6 x 6 x 12
313/16 x 5
316
16
• May be installed vertically or
horizontally.
K-1 / K2
7
7
3
NOTE: Models TB0610, TB0612 & TB1210 are available with the LaGard 33E electronic lock. (Factory
installed primary lock.)
IMPORTANT:
AMSEC Undercounter safes are recommended for an operation that requries a nonreturnable deposit. These safes are not meant for overnight storage of cash
• May be mounted on or under
counter as space permits.
• Durable, impact resistant Charcoal
Gray textured finish.
amsecusa.com/safes-under-counter.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
WALL SAFES
WALL SAFES
AMSEC WALL SAFES are designed to provide hidden protection for documents and miscellaneous valuables. Each wall
safe is also designed for easy installation between 16" o/c wall studs. Pre-drilled anchor holes and a built-in flange eliminates
unnecessary replastering.
WES2114
NEW!
WES2114
FEATURES:
WES149
WS1814
• Heavy duty steel body, 3/16” solid steel door
and flange.
• Extra spacious interior, while still offering the
convenience of fitting between studs.
• Easy to use DL4000 push button electronic
lock offers solid protection with the
accessibility of quick entry and easy-change
combo.
• Standard key override, in case of lost
combination.
• Dual live bolts ensure protection against pry
attacks.
• Two removable shelves.
• Cream colored, durable powder coated finish.
• Packaged for UPS shipment.
WS1814 FEATURES:
• AMSEC’s 5BE electronic push button lock
is fast and easy to use.
• Solid steel construction with a 3/16" pryresistant door offers burglary protection.
• Built-in enhanced LCD interior lighting is
activated when door is opened.
• Comes standard with two storage shelves or
one shelf with hanging file rack.
• Open Door Signaling feature provides a
signal that notifies the user or a monitoring
service that the safe is unlocked.
• Silent Signal Alarm feature allows the user
to secretly signal a monitoring service that
an intruder is in the home.
• Expandable interior provides easy
installation between 16"o/c wall studs and
enables depths of either 4", 5" or 6".
WS1014
FEATURES:
Model
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Electronic lock optional, or Chicago single
key camlock with 2 keys.
• Flat dial allows flush mounted installation.
• WS1014: 3/16" thick solid steel door with
dead bar.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu.
In.
Wt.
Lbs
Interior
Shelves
WS1014**
10 x 13¾ x 3½
12¼ x 15¾ x 4
95/8 x 12¾
481
20
1
WS1514**
15 x 14 x 3½
16½ x 15½ x 4
14 x 13¼
688
24
2
WS1814 (2x4)
153/8 x 1311/16 x 35/8
187/8 x 14 x 4
15 x 13¼
651
34
2
(2x6 installation)
15 /8 x 13 /16 x 3 /8
18 /8 x 14 x 4
15 x 13¼
1184
34
2
WFS149*
14 /8 x 8¾ x 10
19½ x 14 x 15 /16
14 /8 x 8¾
1258
154
1
WES149*
143/8 x 8¾ x 10
19½ x 14 x 15 5/16
143/8 x 8¾
1258
154
1
WS1214
12 x 13½ x 5½
125/8 x 141/8 x 10
10¾ x 111/8
891
86
2
205/8 x 13¾ x 27/8
221/8 x 151/8 x 4
19 3/16 x 113/8
733
32
2
WES2114
3
11
5
3
7
5
3
* 350° F, UL Listed, 1-Hr fire rated wall safe. **Specify suffix -K = Camlock
amsecusa.com/safes-wall.htm
WFS149
FEATURES:
• UL Listed one hour fire rating, insuring the
inside temperature never exceeded 350° F
(paper chars at 450° F).
• Extra deep interior, with one (1)
convenient drawer shelf.
• Group 2 combination lock with knoboperated locking mechanism.
• Each safe is equipped with side locking
boltwork mechanism incorporating 1/2"
steel deadbolts.
• Impressive 1/2" thick door with attractive
two-tone Sage finish.
NEW! WES149 with
DL4000 Electronic Lock
FEATURES:
WS1014 / WS1514
WS1514
When fire is a concern, there is no
better wall safe than the WFS149 or
WES149.
• Same outstanding features of the WFS149
and comes equipped with our easy
to operate and easy change DL4000
electronic keypad. Plus, one (1) auxiliary
key lock with two (2) keys, bright blue LCD
display with a low-battery indicator and a
power override battery box. (See DL4000
lock features on page 20.)
WS1214
HEAVY-DUTY WS1214
FEATURES:
• Same features as Super Brute Floor safes.
Please see page 4.
• Two removable shelves. Extra deep
interior.
DEPOSITORY SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
BSW SERIES - THE SAFEWIZARD®
The SAFEWIZARD® Electronic Safe Controller is a state-of-the-art electronic product for use in controlling and auditing access
to safes. Designed to prevent burglaries and internal theft, the THE SAFEWIZARD® controls and documents each access to the
safe. Based on contemporary high speed processors, unique user friendly software techniques and ingenious application ideas,
this system surpasses all other safe access control systems.
BSW STANDARD
FEATURES:
DOOR:
• Massive ½" thick solid steel plate with
formed body and jamb for maximum
protection.
• 3-way locking mechanism using five 1"
chrome plated locking bolts with bolt detent
that automatically engages boltwork.
• Lock protected by a carburized hardplate
with auxiliary spring loaded relocker.
INTERIOR FEATURES:
• Heavy ¼" steel door, with slam-bolt lock
controlled by the SafeWizard® and a large
clear door opening of 6"H x 14"W(*) or 6"H
x 19"W (†).
• Storage below locker I.D.:
BSW2020/BSW3020:
10½" x 19¾" x 14"
BSW2025/BSW3025:
10½" x 24¾" x 14"
BSW4020: 291/8" x 19¾" x 17"
• Duress/Hold-up Alarm with Silent Signal.
• Burglary Alarm output triggering from
selectable events.
• Holiday Schedule with up to 16
programmable events per year.
• Automatic Daylight Savings Adjustment,
selectable and configurable.
• Dual Control Mode on any individual door,
selectable by user.
• Built-in key maker, complete with
management tool set, audit trail sorting by
several criteria.
• Deposit Tracking system to provide
the highest level of cash management
security.
• Audit trial can be downloaded to a
Windows CE® based palmtop via
the IR Port for compact and portable
administration.
• Audit utility allows PC based audit storage
management, data filter and sorting
capabilities and excellent exception
reporting to focus on key security issues.
BSW4025: 291/8" x 24¾" x 22"
• Ultra-high contrast 8 line by 21 character
graphics display.
• Large “fish” resistant, pull out drop drawer
accepts filled envelopes.
• Rechargeable Battery Backup.
THE SAFEWIZARD®
FEATURES:
• Parallel Printer Interface.
• A powerful processor based on the
ColdFire® 32 bit microprocessor.
• Up to 10,000 audit entries and 40 users.
• Controls up to 6 safe doors and 1 deposit
lock. Safe doors can be configured in any
inner-outer arrangement. Man Trap feature to
maintain security in a safe room so the Entry
Door and the Safe can’t be opened at the
same time.
• Time Delay any door with a 1-99 minute
delay and 1-99 minute open period with
cancel feature.
BSW2020FL
• Built-in System Diagnostics.
• English and Spanish language options.
BSW3020
For More SafeWizard® Features
authentication options:
See Page 40
Dallas key
Card swipe
reader
fingerprint
reader
Model
Inside Dimension
HxWxD
Outside Dim.
HxWxD
Clear Door
Safe Only
Cu. In.
Wt.
No. of
Shelves
• Authentication options: PIN code and/or
Dallas Key access control, optional Finger
Print Reader or Card Swipe devices are
available.
BSW2020
LOCKER: 61/8 x 19¾ x 13½
STORAGE: 91/8 x 19¾ x 17
22 x 20 x 20
14¾ x 16¼
1,633
3,022
190
0
BSW3020
LOCKER: 61/8 x 19¾ x 13½
STORAGE: 191/8 x 19¾ x 17
32 x 20 x 20
24¾ x 16¼
1,633
6,380
250
2
• Wrong Try Count Penalty Lockout.
BSW4020
LOCKER: 61/8 x 19¾ x 13½
STORAGE: 291/8 x 19¾ x 17
42 x 20 x 20
34¾ x 16¼
1,633
9,737
310
3
• Auto-Purge Idle Users option, selectable
by Individual User.
BSW2025
22 x 25 x 25
14¾ x 21¼
2,804
4,900
240
0
• Forced PIN Changes to decrease risk of
compromised PINs.
LOCKER: 61/8 x 24¾ x 18½
STORAGE: 91/8 x 24¾ x 22
BSW3025
LOCKER: 61/8 x 24¾ x 18½
STORAGE: 191/8 x 24¾ x 22
32 x 25 x 25
24¾ x 21¼
2,804
10,345
320
2
• Armored Car courier Time Delay and Lock
Bypass.
BSW4025
LOCKER: 61/8 x 24¾ x 18½
STORAGE: 291/8 x 24¾ x 22
42 x 25 x 25
34¾ x 21¼
2,804
15,790
400
3
• Time Lock any door, 1-6 windows per day.
10
amsecusa.com/safe-wizard-depository.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
DEPOSITORY SAFES
BWB SERIES - WIDE BODY CASH CONTROL
Extensive research and development went into the engineering of AMSEC’S WIDE BODY “B” RATE CASH HANDLING
DEPOSITORY SAFES. Designed to offer complete cash management versatility with a front load depository option and a pullout deposit drawer (Model BWB3020D1 only).
Bwb3025-fl
Bwb3020-D1
Bwb3020-fl
BWB STANDARD FEATURES:
INTERIOR LOCKER FEATURES:
• Door: Massive ½" thick A36 solid
steel plate.
• Heavy 1/4" steel door, with Medeco® high
security camlock.
• Formed high tensile steel body and jamb
construction to maximize protection against
pry attack.
• Large clear door opening:
• Recessed heavy duty 1/8" construction
with 1/8" door.
6" H x 12"W (for 20" W safes) or
• Protected by dual “anti-fish baffles.”
6" H x 14"W (for 25" W safes).
• Large package capacity: 4" x 9" x 11½"
(maximum).
• Reinforced internal jambs on all four
sides to provide protection against
sledgehammer attack.
• U.L. listed Group II, key changeable
combination lock.
• Optional electronic locks available.
• 3-way locking mechanism consisting
of five 1" diameter chromed steel locking
bolts.
• Inside Dimensions:
• May be ordered in any one of four
directions. Specify front, reversed, right
load or left load.
BWB2020 / BWB3020 / BWB4020:
85/8" x 19¾" x 14"
BWB2025 / BWB3025 / BWB4025:
85/8" x 24¾" x 19"
• Note: Front Load Depository - inside locker
height restricted to 6".
• Bolt detent system engages boltwork
automatically.
DEPOSIT DRAWER FEATURES
(ONLY MODEL BWB3020D1):
• Locks and relocks protected by a large
carburized hardplate.
• Large “fish” resistant, pull out drop drawer
deposits directly into standard interior
locker.
• Auxiliary spring-loaded relocking devices.
• Convenient, door-mounted, recessed coin
rack.
Drawer size: 11/8" x 3½” x 7½"
• Heavy duty steel sliding drawer.
• Standard Four (4) anchor bolt holes.
Model
Inside Dim.
HxWxD
Outside Dim.†
HxWxD
Door
Opening
Cu. In.
Capacity
Wt.*†
No. of
Shelves
BWB2020
19¾ x 19¾ x 17
20 x 20 x 20
14¾ x 16¼
6,631
168
1
BWB3020
29¾ x 19¾ x 17
30 x 20 x 20
24¾ x 16¼
9,988
228
2
BWB4020
39¾ x 19¾ x 17
40 x 20 x 20
34¾ x 16¼
13,346
284
3
BWB2025
19¾ x 24¾ x 22
20 x 25 x 25
14¾ x 21¼
10,754
235
1
BWB3025
29¾ x 24¾ x 22
30 x 25 x 25
24¾ x 21¼
16,198
302
2
BWB4025
39¾ x 24¾ x 22
40 x 25 x 25
34¾ x 21¼
21,644
390
3
amsecusa.com/safe-b-rate-wide-body.htm
FRONT LOAD
DEPOSITORY FEATURES:
EACH UNIT COMES EQUIPPED WITH AN
INTERIOR LOCKER TO ACCOMMODATE
DEPOSITS, A LARGE INTERIOR FOR
STORAGE OF CASH TRAYS AND A DOORMOUNTED, RECESSED COIN RACK.
IMPORTANT:
AMSEC depository safes are
recommended for an operation that
requries a non-returnable deposit such
as armored car companies, convenience
stores, restaurants, etc. The top locker is
not meant for overnight storage of cash
or valuables.
Specify: D1 = Drawer (Model BWB3020 only).
Specify: FL = Front Loading Depository.
† Add 9¾ for Front Load Depository.
Minus 10¾ for clear I.D. with Locker.
* Add 50 lbs. for Front Load Depository.
11
DEPOSITORY SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
DS SERIES - “B” RATE ROTARY AND FRONT LOADING
AMSEC’S DS SERIES
DEPOSITORY SAFES
are designed to provide
immediate deposits and
storage for cash, jewelry
and miscellaneous
valuables.
Deposits can be made
through a locked door
via a top-loading rotary
hopper, a reverse or a
front-loading deposit door.
REVERSE HOPPER
DSR2014F WITH ESL10XL
DSF2714K
DSC2014KC
STANDARD FEATURES
ADDITIONAL FEATURES:
WIDE BODY MODEL 2731
BODY:
• Strong, formed “B” Rate construction made
of A36 solid steel plate for improved security
and appearance.
• Formed door jamb for increased resistance to
sledgehammer attack.
• Four anchor bolt holes are standard.
• DOOR: (3) 1" x ½" rectangular
plated bolts.
• Unique space-efficient, side-by-side
design creates full depth depository
and large storage compartment.
• Accepts cash trays up to 13" x 18".
• Optional coin rack available on storage
compartment door.
DOOR - MODEL NUMBERS:
2014, 2714 AND 3214
• ½" thick A36 solid steel plate, recessed ½" to
increase resistance to pry attack.
• U.L. Group II combo lock (C), U.L. listed dual
nose keylock (K).
• Optional electronic locks available.
• Three 1" diameter chromed steel locking bolts.
• Bolt detent system engages boltwork
automatically.
HOPPER:
• 2014/2714 are available
w/reverse hopper.
• Large package sizes:
(Top Load Rotary):
4¾"D x 4¾"W x 10"L
(Front/Reverse Load):
4"D x 2¾"W x 10½"L
DSF2014
WITH ESL10XL LOCK
• Auxiliary spring-loaded relocking device.
• Recessed, heavy duty 3/16"
construction (¼" door).
• Lock and relock protected by large carburized
hardplate.
• Protected by dual “anti-fish” baffles.
Model †
Inside Dim.
HxWxD
Outside Dim.*
HxWxD
Door
Opening
Cu. In.
Wt.
DST2014
11½ x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1,739
87
DSF2014
10 x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1513
79
DSR2014
10 x 13¾ x 11
20¼ x 14 x 14
9¾ x 9¾
1513
94
BOT 10¼ x 13¾ x 11
TOP 67/8 x 13¾ x 123/8
27¼ x 14 x 14
BOT 9¾ x 9¾
TOP 6 x 103/8
1513
1127
104
DST2714
18½ x 13¾ x 11
27¼ x 14 x 14
9¾ x 9¾
2798
101
DSF2714
17¼ x 13¾ x 11
27¼ x 14 x 14
9¾ x 9¾
2609
108
DSR2714
17¼ x 13¾ x 11
27¼ x 14 x 14
9¾ x 9¾
2609
92
DST3214
TOP 12¼ x 13¾ x 11
BOT 11¼ x 13¾ x 11
32¼ x 14 x 14
9¾ x 9¾
1664
1890
152
DSF3214
TOP 11¼ x 13¾ x 11
BOT 12½ x 13¾ x 11
32¼ x 14 x 14
9¾ x 9¾
1437/1815^
1890/1702^
144
DST2731
LEFT 18½ x 143/8 x 18
RIGHT 27 x 16 x 18
27¼ x 30¾ x 21
LEFT 9 x 97/8
RIGHT 22½ x 143/8
4787
7776
285
DSF2731
LEFT 16¾ x 143/8 x 18
RIGHT 27 x 16 x 18
27¼ x 30¾ x 21
LEFT 9 x 97/8
RIGHT 22½ x 143/8
4399
7776
276
DSC2014KC**
12
DST2731CC
DSF3214CC
IMPORTANT:
AMSEC depository safes are recommended for an
operation that requries a non-returnable deposit
such as armored car companies, convenience
stores, restaurants, etc. The top locker is not meant
for overnight storage of cash or valuables.
†Specify Prefix: T=Top Loading, F=Front Loading, R=Reverse
Hopper, K=Key Lock, C=Combo Lock, E=Electronic Lock
*Add 2" to outside depth for dial and handle projection. **Camlock on locker, combination on deposit safe.
^Cubic inch capacity on DSF3214 change for CC and KK
amsecusa.com/safe-b-rate-depository.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
DEPOSITORY SAFES
MONEY MANAGER
AMSEC’s “B” Rate Money Manager Series Undercounter Two Door Depository Safes are
the most effective cash handling systems available. Engineered to help you achieve total cash
control.
AMSEC’s Money Manager Series is recommended for any operation that requires a nonreturnable deposit such as armored car companies, convenience stores, restaurants, etc. The
secured deposit and receiving compartments protect against mysterious disappearance and
pilferage.
mm2820 top drop
STANDARD FEATURES:
• Heavy duty construction with ½" solid steel
doors.
• Both doors equipped with high security
combinations and key locks, offering dual
control.
• Optional electronic locks available.
• Handle activated locking mechanism
consisting of three 1" diameter locking
bolts.
• Bolt detent device automatically engages
bolts when doors are closed.
mm2820 three drop
mm2820 center drop
• Auxiliary spring-loaded relocking device,
activated by a punch attack.
• Four anchor bolts and anchor hardware included.
• Locks and relocks are protected by a large
carburized hardplate.
• Available as a “top drop,” “center drop,” or
“three drop” model.
• Formed door jamb and full length dead bar.
• MM2820 front load and center drop hopper
measures 16¼"W x 2"H x 3½"D.
• Coin racks are standard on inside of
storage door.
• Fish resistant depository drops accept bulk
items, drop envelopes or bags.
• Cash drawers and bulky items
conveniently fit into both
compartments.
• Three individual color-coded 4” drops for
shift control. Three deposit bins provided
on “three drop” model.
• Attractive Black textured finish.
• Optional colors available upon request.
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear Door
HxWxD
Cu. In.
Wt.
MM2820
3-Drop
TOP 9½ x 20 x 17
BTM 11 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
247
MM2820
Top-Drop
TOP 9½ x 20 x 17
BTM 11 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
274
TOP 103/8 x 20 x 17
BTM 103/8 x 20 x 17
28 x 20½ x 20
8½ x 16¼
8½ x 16¼
3,230
3,740
278
Model
MM2820
Center-Drop
amsecusa.com/safe-doubledoor-depository.htm
13
“B” RATE SECURITY SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
BWB SERIES, US2015 AND MS1414
The many different features of the WIDE BODY SAFES, make them perfect for commercial application or home use.
MS1414 with
ESL10XL LocK
US2015C
BWB3020
Standard Features for
BWB and US2015C:
• ½" thick solid steel door, recessed for
resistance to pry attacks.
• Formed, high-tensile steel body and
jamb construction to maximize protection
against pry attacks.
• U.L. listed Group II key changeable
combination lock with over 1 million
possible combinations.
• Optional electronic locks available.
• Auxiliary spring-loaded relock device.
• Locks and relocks protected by a large
carburized hardplate.
• Attractive Black textured finish.
Additional US2015 Features:
• Five ¾" diameter steel chromed locking
bolts.
• Solid steel deadbar.
• Two adjustable shelves.
Additional BWB Series Features:
• Reinforced internal jambs on all four sides
to provide excellent protection against
sledgehammer attack.
• 3-way locking mechanism consisting of five
massive 1" diameter chromed steel locking
bolts.
• Bolt detent system keeps bolts retracted
when the door is open, then automatically
engages when door is shut.
• Convenient door mounted recessed coin
rack.
• US2015 :Two anchor bolt holes.
• BWB: Four anchor bolt holes.
• Large capacity for storage of cash trays.
• Adjustable shelves.
MS1414 with
slot option
Mini Safe (MS Series) Features:
• Strong, formed “B” Rate construction
made of A36 solid steel plate for improved
security and appearance.
• Formed door jamb for increased resistance
to sledgehammer attack.
• ½" solid steel door.
• U.L. Group II combo lock (C), U.L. listed
dual nose keylock (K).
Model
• Three 1" diameter chromed steel locking
bolts.
Inside Dim.
HxWxD
Outside Dim.*
HxWxD
Door
Opening
Cu. In.
Capacity
Wt.
Shelves
BWB2020
19¾ x 19¾ x 17
20 x 20 x 20
14¾ x 16¼
6,631
154
1
• Bolt detent system engages boltwork
automatically.
BWB3020
29¾ x 19¾ x 17
30 x 20 x 20
24¾ x 16¼
9,988
218
2
• Auxiliary spring-loaded relocking device.
BWB3025
29¾ x 24¾ x 22
30 x 25 x 25
24¾ x 21¼
16,198
306
2
BWB4020
39¾ x 19¾ x 17
40 x 20 x 20
34¾ x 16¼
13,346
272
3
• Lock and relock protected by large
carburized hardplate.
BWB4025
39¾ x 24¾ x 22
40 x 25 x 25
34¾ x 21¼
21,644
440
3
• Four anchor bolt holes are standard.
US2015C
20 x 15¼ x 15
20¼ x 15½ x 18
15 / x 10 /
4,575
130
2
• Adjustable shelf provided.
13¾ x 13¾ x 11
14 x 14 x 14
9¾ x 9¾
2,080
67
1
MS1414
*Add 2" to outside depth for handle, dial and hinge projection.
14
5 8
7 8
• Also available as a “Mini-Deposit” safe with
optional deposit slot or drawer. Drawer
size: 11/8" x 3½" x 7½"
amsecusa.com/b-rate-security-safes.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
AMSEC “B” AND “C” RATE SECURITY CHESTS are designed to provide secure storage at an economical price. In addition
to meeting the requirements of the Insurance Offices Manual of Burglary Insurance, these units offer an appearance and many
features similar to AMSEC’S higher rated TL-15 models.
STANDARD FEATURES
DOOR:
• 1" (“C” Rate), or ½" (“B” Rate) steel pryresistant recessed door.
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Additional spring loaded relocking device,
activated by a punching attack.
• Locks and relocks protected by a large
carburized hardplate.
• A handle activated locking mechanism
consisting of three 1" chromed steel
locking bolts. (five in BLB and BLC4024
models).
• Solid steel full length dead bar prevents
door removal if hinges are removed during
a forced entry attempt.
• Adjustable ball bearing hinges.
BODY:
• ½" continuously welded (“C” rate) or 1/4"
(“B” Rate) solid steel bodies.
• Body reinforcing frame gives the
appearance of 1" thick walls to discourage
attack.
• Adjustable shelves.
• Attractive Gray textured finish. Other
colors available.
• Custom sizes, interior options and high
security features available.
• Left swing door optional.
BLC3018
B-Rate Premium Free Standing Security Chest
Model
Inside Dimension
Outside Dimension
Clear Door
Cu. In.
Wt.
Shelves
BLB2018
20 x 18 x 12
20½ x 18½ x 15
18 x 16
4,320
218
2
BLB3018
30 x 18 x 16
30½ x 18½ x 19
28 x 16
8,640
312
2
BLB3024
30 x 24 x 20
30½ x 24½ x 23
28 x 22
14,400
360
3
BLB4024
40 x 24 x 20
40½ x 24½ x 23
38 x 22
19,200
445
4
Outside Dimension
Clear Door
Cu. In.
Wt.
Shelves
* Add 2" to outside depth for handle, dial and hinge projection. Custom design available on request.
C-Rate Premium Free Standing Security Chest
Model
Inside Dimension
BLC2018
20 x 18 x 12
21 x 19 x 16
18½ x 16½
4,320
370
2
BLC3018
30 x 18 x 16
30½ x 18½ x 19
28½ x 16½
8,640
550
2
BLC3024
30 x 24 x 20
30½ x 24½ x 23
28½ x 22½
14,400
740
3
BLC4024
40 x 24 x 20
40½ x 24½ x 23
38½ x 22½
19,200
925
4
* Add 2" to outside depth for handle, dial and hinge projection. Custom design available on request.
amsecusa.com/b-and-c-rate-safes.htm
15
“B” AND “C” RATE SECURITY CHESTS
“B” AND “C” RATE SECURITY CHESTS
BLB AND BLC SERIES
HOTEL & RESIDENTIAL ELECTRONIC SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
HOTEL & RESIDENTIAL ELECTRONIC SAFES
AMSEC’s HOTEL AND RESIDENTIAL ELECTRONIC SAFE, with its easy installation, maintenance and management features
has become a popular safe in the hospitality industry. Designed with the traveling guests in mind, the HR916E/HRC916E will
adequately secure laptop computers, cameras, jewelry and other valuables in the most user-friendly safe made.
STANDARD FEATURES:
• Heavy duty steel construction offers
excellent burglary
protection.
• Convenient motorized locking
system, incorporating the latest
technology.
• Easy to read, large LED display lets
you know the status of the safe.
• 4 digit combination, standard hotel
room configuration (customer sets
new combination every time safe
is used, quickly and easily), or
electronic credit card.
HRC916E
• Reliable ADA approved keypad.
• Electronic override can be set by
security personnel.
• Runs on 4 AA batteries. If batteries
should go dead, each safe has a
by-pass power cable (9v battery
required).
• Lock-out penalty if the combination is
entered wrong, the safe will lock up
for 15 minutes, frustrating the wouldbe burglar.
• Spacious interior fits most lap top
computers.
• Two anchor holes with mounting
hardware included.
HR916E
• Attractive carpeted bottom hides
anchor bolts.
• Electrostatic powder-coated finish in
an attractive cream color.
OPTIONS:
• Guest instruction label included.
• Hand-held, print-out interrogation device,
offering audit trail (HRPROG).
• Packaged for UPS shipment.
• Convenient 12" high safe pedestal
(HRPED).
Model
Inside Dimension
HxWxD
Outside Dimension
HxWxD
Clear
Door
Cu. In.
Capacity
Wt.
Lbs.
HR916E
8 x 15¾ x 11
9 x 16 x 14
7 x 12
1386
34
HRC916E
8 x 15¾ x 11
9 x 16 x 14
7 x 12
1386
32
16
HRPED
HRPROG
amsecusa.com/hotel-safe.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
COMMERCIAL SECURITY SAFES
COMMERCIAL SECURITY SAFES
NEW! CSC SERIES COMPOSITE SAFES
AMSEC CSC SERIES COMPOSITE SAFES are an affordable solution when you
want to protect both documents from fire and valuables from burglary attacks. During
extreme testing procedures the CSC SERIES COMPOSITE safes passed a 2-Hour,
350°F factory fire test certification.
CSC3018
CSC4520
Features:
Locking Mechanism:
Door:
• Two to four 1½" diameter solid steel
chrome-plated locking bolts.
• Overall thickness of 4-5/8" and is
constructed with a 2" defense barrier of
outer and inner steel plates creating a
burglary resistant structure enclosing a
unique proprietary, fire resistant material.
Body:
• Total protective thickness of 2-7/8"
enclosing a unique, high-density fire and
burglary resistant composite material.
• Two to three 1½" diameter solid steel dead
bolts lock deep into body preventing door
removal during a forced entry attempt.
• U.L. Listed Group II combination lock with
chrome-plated spy-proof dial. Optional
electronic locks available.
• Lock protected by a tempered glass
relock device.
• Durable powder coated adjustable
shelves.
• Heavy duty steel hinges provide easy,
smooth door operation.
• Removable casters provide easy delivery
and installation.
• One internal counter-sunk anchor hole
and mounting hardware are provided to
securely anchor safe.
Fire Endurance:
• 2 hour, 350°F factory fire rating. Tested at
temperatures up to 1700°F.
• Heat expandable intumescent door seal
guards contents against severe fires.
Model
CSC1913
CSC1413
• Attractively accented with a full width facia
panel and matching three point handle,
• Durable and attractive light gray textured
finish.
optional
storage
cabinets
available in
models CSC3018
and CSC4520.
No Kit Needed,
drawers slide
right in.
See page 45 for
more details
Inside Dim
HxWxD
Outside Dim
HxWxD
Weight
Cubic In.
Capacity
Bolts
Shelves
Rubber Feet
or Casters
CSC1413
14 x 12.5 x 12.2
19.5 x 18 x 19.9
256
2,135
4
1
Rubber Feet
CSC1913
19 x 12.5 x 12.2
23.8 x 18 x 19.9
318
2,898
4
2
Rubber Feet
CSC3018
30 x 18 x 16.3
35.5 x 23.5 x 24
462
8,802
7
3
Casters
CSC4520
45 x 20 x 21.2
50.5 x 25.5 x 28.9
768
19,080
7
4
Casters
* Add 2" to outside depth for handle, dial and hinge projection.
* Add 4¼" (casters) and 1" (rubber feet) to outside height.
amsecusa.com/safes-commercial-security.htm
17
BF® SERIES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
U.L. LISTED FIRE RATED BURGLARY SAFES
The AMSEC BF® SERIES offers a unique design that combines all the security
features of a burglary safe and the peace of mind achieved with a fire safe. The
industry’s first U.L. Listed, fire-rated burglary safe offers an affordable solution when
burglary and fire protection are an essential part of your buying decision!
During Underwriter’s Laboratories grueling testing procedures, the BF® SERIES earned
the U.L. Listed Class 350°F One Hour Fire Label and an E (RSC) Residential Security
Container Burglary Label.
BF1512
BF2116
FEATURES
BF3416ST
shown with
optional storage
cabinets
BF® Safes Lifetime Replacement
Warranty:
If your BF® safe is exposed to fire and
failed to protect the contents, your BF®
safe will be replaced free of charge. Just
return the safe freight prepaid to the factory
accompanied with the fire report. Contact
your dealer for further details.
• The best warranty in the business. Lifetime
fire replacement and one year parts and
labor.
• “B” rated heavy duty construction.
Door:
• 3½" thick, consisting of ½" plate steel
with a unique proprietary fire and burglary
resistant material.
• Dual seal design utilizes a silicone foam
seal with a heat-expanding intumescent
seal.*
Body:
• 25/8" thick, consisting of 1/8" outer and inner
steel plates creating a burglary resistant
structure enclosing a unique proprietary
fire resistant material.
*INTUMESCENT
DOOR SEAL:
When the intumescent
seal is exposed to high
temperature (above
250˚F), it expands
to as much as 8 times it’s original
thickness. In this expanded or reactive
state, it has very high thermal insulating
capacity and resistance to breakdown.
This provides a strong positive seal
between the door and body, preventing
heat influx.
• Three massive 1" diameter solid steel
chrome-plated locking bolts.
• U.L. listed Group II lock with spring-loaded
auxiliary relock device.
• ¼" heavy duty carburized hardplate.
• Heavy duty steel hinges provide easy
smooth door operation.
• One recessed anchor bolt hole and
mounting hardware are provided to
securely anchor safe.
• Attractively accented with a large chromeplated dial, matching handle and a plush
velour interior.
• Durable and attractive granite finish or
sandstone textured with a plush velour
interior.
• Optional electronic locks are available.
SEE PAGES 41-43.
• Optional storage cabinets available on
models BF3416 and BF1716.
SEE PAGE 45.
• A full length dead bar locks deep into the
body preventing door removal during a
forced entry attempt.
Model
Inside Dim.
HxWxD
Outside Dim.^
HxWxD
Door
Opening
Cu. In.
Capacity
Wt.
Lbs.
Interior
Shelves
15 x 12 x 13
20¼ x 17¼ x 18¾
15 x 12
2,340
288
1
BF1716(*)(**)
17 x 16½ x 16
22¼ x 21¾ x 21¾
17 x 16½
4,488
412
1
BF2116(*)(**)
21 x 16½ x 14½
26¼ x 21¾ x 20¼
21 x 16½
5,024
476
1
BF3416(*)(**)†
34 x 16½ x 16
39¼ x 21¾ x 21¾
34 x 16½
8,976
628
2
BF1512(*)(**)
BOLT DOWN KIT INCLUDED, ^ADD 2" FOR DIAL & HANDLE
Hardware on above safes specify (*): Brass (LTG) on Sandstone and Chrome (LTE) on Granite
Color Options Specify (**): (GR) = Granite, (ST) = Sandstone
† 1/2 hour U.L. Fire Rating
18
amsecusa.com/safes-ul-burglary.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
FEATURES:
• The best warranty in the business. Lifetime
fire replacement and one year parts and
labor.
• U.L. listed Class 350°F two hour fire and
impact rating.
• Safes withstand fires of up to 1850°F for
two hours and a 30' drop – equivalent to
falling through a 2 story burning building.
• Increased barriers for burglary protection.
Impressive 3½" thick recessed door with
5/8" thick front for excellent pry resistance.
• Handle activated locking mechanism with
7/8" diameter solid steel chrome plated
locking bolts offering smooth operation.
• Internal anchor bolt hole with hardware.
UL1511
• U.L. listed Group II key changeable
combination lock with relock. 1 million
possible combinations.
• Auxiliary spring-loaded relock device
activated by severe attack.
• Heavy duty steel hinges provide additional
security and smooth operation.
• For your convenience, rubber feet are
standard on models UL1511 – 1812XD.
• Heavy duty rolling casters on UL2018 and
up.
• Attractively accented with a brass-plated
dial, brown powder coated handle,
decorative emblems and plush velour
interior.
• Available in durable Sandstone or Granite
textured finishes.
U.L Safes Lifetime Replacement Warranty:
If your U.L. safe is exposed to fire and failed to protect the contents, your U.L. safe will be
replaced free of charge. Just return the safe freight prepaid to the factory accompanied with
the fire report. Contact your dealer for further details.
Model
UL1812
Inside Dim.
HxWxD
Outside Dim.
HxWxD
Door
Opening
Cu. In.
Capacity
Wt.
Lbs.
Interior
Shelves
UL1511(*)(**)
15½ x 11½ x 12
21¼ x 17 x 18½
14¾ x 11¼
2,139
246
1
UL1812(*)(**)
18½ x 12½ x 12
25 x 18 x 18
18½ x 12½
2,775
272
1
UL1812XD(*)(**)
18½ x 12½ x 17
25 x 18 x 23
18½ x 12½
3,931
298
1
UL2018(*)(**)
20 x 18 x 18
30¼ x 25½ x 25½
20 x 18
6,480
542
2
UL2818(*)(**)
28 x 18 x 18
38¼ x 25½ x 25½
28 x 18
9,072
702
2
UL3918(*)(**)
39 x 18 x 18
49¼ x 25½ x 25½
39 x 18
12,636
808
2
* ADD 2" FOR HANDLE, DIAL AND HINGE PROJECTION. OUTSIDE HEIGHT INCLUDES 1" HIGH RUBBER FEET ON
MODELS UL1511-UL1812XD; 2¾" FOR CASTERS ON THE THREE LARGEST MODELS.
Hardware on above safes specify (*): Brass (LTG) on Sandstone and Chrome (LTE) on Granite
Color Options Specify (**): (GR) = Granite, (ST) = Sandstone
U.L. FIRE RESISTIVE RATING
CLASSIFICATION
THE FOLLOWING IS AN EXPLANATION OF THE
UNDERWRITER’S LABORATORIES’ FIRE RESISTANT
CONTAINER TESTING PROCEDURES ON THE CLASS
350°F, ONE HOUR AND TWO HOUR FIRE LABELS.
EXPLOSION HAZARD TEST
U.L. Label/Class 350°F-one hour and Class 350°F-two
hour. The safe will maintain an interior temperature less
than 350°F when exposed to fire for a period of one hour at
1700°F or for a period of two hours at 1850°F. Safe must
successfully undergo all other requirements for the Fire
Endurance Test, Explosion Hazard Test and the Fire/Impact
Test as stated below.
The safe is locked and placed into a furnace preheated
to 2000°F. This temperature is maintained for 30 minutes
(2 hour test is 45 minutes) and if no explosion results, the
unit is allowed to cool without opening the furnace doors.
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
FIRE ENDURANCE TEST
After heat sensors and paper are placed inside the safe, the
unit is locked and exposed to a uniformly distributed fire.
The furnace is regulated to reach a maximum temperature
of 1700°F for a period of one hour, or 1850°F for two hours,
then allowed to cool without opening the furnace. The
interior temperature is recorded throughout the test and
during the cooling period until a definite drop is shown and
must never exceed 350°F.
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
amsecusa.com/fire-safes-ul-impact.htm
FIRE IMPACT TEST
(MANUFACTURER’S OPTION)
After the explosion hazard test the safe is removed from
the furnace and within two minutes is dropped 30’ onto a
riprap of brick on a heavy concrete base. After impact the
unit is examined for deformation, rupture of parts, damaged
insulation and any other openings into the interior of the unit.
Once cooled, the unit is inverted and reheated to 1550°F for
a period of 30 min. (2 hour test: 45 min. at 1638°F).
Once cooled, the unit is opened and examined for usability.
The units locking mechanisms and parts fastenings are
examined for security and the interior examined for visible
evidence of undue heat transmission.
19
UL SERIES
UL SERIES
U.L. LISTED 2-HOUR FIRE AND IMPACT SAFES
IMPORTED U.L. LISTED 1-HR FIRE SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
RESIDENTIAL - ELECTRONIC AND COMBO
The economical range of our IMPORTED RESIDENTIAL FIRE SAFES (ELECTRONIC and COMBO) is the answer’s to
today’s high incidence of residential fires. Our Fire Safes also provide burglary protection making them ideal for home and light
commercial applications.
ES149
FS149
ES1814
IMPORTED RESIDENTIAL
FIRE SAFES
(ELECTRONIC)
• One (1) drawer shelf.
FEATURES:
ES914 / ES149 / ES1814:
• Four (4) rubber feet. (ES1814 model has
four rolling casters).
• Impressive 1/2" thick door with attractive
two-toned sage finish (ES1814 model: 5/8"
thickness).
FEATURES:
FS712 / FS914 / FS149:
• U.L. Listed 350°F 1-Hour fire rating.
• Models FS712, FS914 and FS149 have
one (1) internal anchor hole and hardware,
four (4) rubber feet and one (1) drawer
shelf (except model FS712 that has a
removable shelf).
• U.L. Listed 350°F, 1-Hour fire rating.
• Side boltwork mechanism incorporating
two 1/2" diameter steel deadbolts
prevent door removal during a forced
entry attempt. (ES1814 model: 1 x 4-1/2"
rectangular steel deadbolts).
• Key operated side, locking mechanism incorporating two chromed locking bolts.
• State-of-the-art DL4000 electronic lock.
Combination changes are fast and easy.
Emergency key-lock override system with
two (2) keys, bright blue LCD display with
a low-battery indicator, power override
battery box, built-in spy-proof function and
motion detector alert.
Low Battery Indicator
IMPORTED RESIDENTIAL
FIRE SAFES (COMBO)
• Two deadbolts prevent door removal if
hinges are removed during a forced entry
attempt.
ES914
• Attractive two-toned sage finish.
LCD Display
FS712
The DL4000 electronic lock features:
Turn knob
Power Override Hole
Keypad
power
override
Box
emergency
keys
emergency
keyhole
battery
compartment
Emergency Key Cover Plate
20
amsecusa.com/fire-safes-import.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
IMPORTED U.L. LISTED 1-HR FIRE SAFES
COMMERCIAL FIRE SAFES
These larger model of IMPORTED COMMERCIAL FIRE SAFES are designed for commercial and residential applications.
The loss of important documents can severely cripple a business. Surveys have shown that 46% of all businesses do not
survive after a devastating fire and that these fires strike an average of four minutes.
FS2215
FS3018
IMPORTED COMMERCIAL
FIRE SAFES
FEATURES:
FS2215 / FS3018 / FS4622:
• U.L. Listed 350°F 1-Hour fire rating.
• Models FS2215, FS3018 and FS4622
offer a Group 2 combination lock with a
Spyproof dial and ring, one (1) key-lock
drawer, two (2) adjustable shelves, four (4)
rolling casters for ease of movement and
additional chrome “L” handle.
• Automatic relocking device triggered by
force entry attempt.
• Handle operated side, top and bottom
locking mechanism incorporating four to
six steel chromed locking bolts.
FS4622
oUR IMPORTED COMMERCIAL
SAFES FEATURE:
• Two to three steel deadbolts prevent door
removal if hinges are removed during a
forced entry attempt.
• Ball bearing hinges for ease of operation.
• Attractive two-toned sage finish.
AN “L” HANDLE, KEY LOCK AND
SPYPROOF DIAL AND rING
Residential Fire Safes (Electronic and Combo)
Model
Inside Dim
Outside Dim**
Clear Door
Cu. In.
Wt.
Shelves/
Drawers
ES914
89/16 x 14¼ x 9¾
14 x 19½ x 153/8
8-9/16 x 14¼
1,189
150
1
ES149
14 /8 x 8¾ x 10
19½ x 14 x 155/16
14-3/8 x 8¾
1,258
126
1
ES1814
14 x 13 x 125/8
235/8 x 187/8 x 18½
18 x 13
2,298
256
1
** Add 2" for handle, dial and hinge
projection.
FS712
7 x 11¾ x 8½
1113/16 x 165/8 x 13¾
7 x 11¾
699
100
1
FS914
8 /16 x 14¼ x 9¾
14 x 19½ x 153/8
8-9/16 x 14¼
1,189
124
1
FS149
143/8 x 8¾ x 10
19½ x 14 x 155/16
14-3/8 x 8¾
1,258
126
1
Models FS2215, FS3018, and
FS4622 have one key-lock
drawer and two adjustable
shelves.
Outside height includes casters
on models FS2215, FS3018, and
FS4622.
Above dimensions have
been converted from metric
measurements. Please allow +¼"
to ¼" variation for both outer and
inner dimensions listed.
3
9
Commercial Fire Safes
Model
Inside Dim
Outside Dim**
Clear Door
Cu. In.
Wt.
Shelves/
Drawers
FS2215
17¾ x 115/8 x 13½
279/16 x 19¾ x 19¼
17¾ x 11-5/8
2,786
318
2/1
FS3018
26½ x 15½ x 16½
36¼ x 23 /8 x 22½
26½ x 15½
6,777
503
2/1
FS4622
40¼ x 21¼ x 18¾
51¼ x 2711/16 x 253/16
40¼ x 21¼
16,037
884
2/1
5
amsecusa.com/fire-safes-import.htm
21
CASH BOXES AND KEY CABINETS
ELECTRONIC SECURITY
American Security Products Co.
Product Catalog
FEBRUARY, 2009
CASH BOXES AND KEY CABINETS
CB10
Cash Box with
Key Lock
CB23
Cash Box with
Key Lock
Features three cash-compartment tray. Spring clips secure
bills to lid. Additional storage
compartment and carry handle.
Powder-coatied finish.
Features 5 cash-compartment
tray. Spring clips secure bills to
lid. Additional storage compartment and carry handle. Powdercoated finish.
Outside Dimensions:
Outside Dimensions:
Weight:
2.3 lbs
Weight:
4.6 lbs
39/16 H x 77/8 W x 65/16 D
39/16 H x 1113/16 W x 97/16 D
KB20
Key Cabinet
with Key Lock (20 Keys
capacity)
KB93
Key Cabinet
with Key Lock
(93 Keys capacity)
Solid steel construction with
powder-coating finish. Includes
pre-drilled holes and screws for
mounting it to a drawer or wall.
Holds 20 keys with number tags.
Solid steel construction with
powder-coating finish.Includes
pre-drilled holes and screws for
mounting it to a drawer or wall.
Holds 93 keys with number tags.
Outside Dimensions:
Outside Dimensions:
Weight:
2.3 lbs
Weight:
6 lbs
77/8 H x 65/16 W x 31/8 D
1113/16 H x 97/16 W x 31/8 D
ELECTRONIC SECURITY
ES813
ES813
ES1014 ES916
ES2014
ES916
• Can be bolted to the wall or floor.
• Carpeted base.
Features:
• State-of-the-art DL4000 electronic lock.
Combination changes are fast and easy.
Includes: One (1) emergency key-lock with
two (2) keys, bright blue LCD display with
a low-battery indicator, power override
battery box, built-in spy-proof function and
motion detector alert.
• Pry-resistant recessed door with internal
hinges for anti-theft protection.
ES2014
• Mounting feet and anchor hardware
standard.
DL4000 Electronic Lock
Features
• Models ES1014 and ES2014 have one
removable shelf.
• Power Override Box
• Emergency Keys
• Emergency Keyhole
• Heavy 14 gauge solid steel construction,
plus dual live bolts made also of heavy
gauge steel.
• Battery Compartment
Model
Inside Dimension
Outside Dimension
Clear Door
Cu. In.
Wt.
ES813
713/16 x 121/16 x 5
8 x 12¼ x 7¾
5¾ x 8
471
14
ES916
8 x 15¾ x 10-5/8
9 x 16 x 13 /8
7 /8 x 12 /8
1,339
24
ES1014
9½ x 13½ x 7
9¾ x 13¾ x 9¾
7-3/4 x 97/8
898
22
ES2014
19½ x 13½ x 9½
19¾ x 13¾ x 12¼
175/8 x 11
2,501
50
22
1
1
7
amsecusa.com/cash-boxes.htm or http://www.amsecusa.com/electronic-security-safes.htm
Product Catalog
American Security Products Co.
HS SERIES - HIGH SECURITY
RF6528
HS7943 & HS6743
The RF6528 Features:
• The only U.L. Listed TL-30 burglary and fire resistant
gun safe on the market.
• 2¾" thick door constructed of outer and inner steel
plates enclosing a unique burglary-resistant high
security material and an ARMOR steel plate barrier
protecting the entire door.
The HS6743 and HS7943 Features:
• U.L. Listed TL-15 burglary and fire resistant high
security gun safe.
• 2¾" thick door constructed with 1" thick solid steel
plate and an inner steel plate enclosing a unique
burglary-resistant, high security material.
• 3½" thick body constructed with 1" thick solid steel
plate inner wall and an outer steel plate enclosing a
unique burglary-resistant, high security material.
All HS Series Safes Feature:
rf6528-LE-F-OX-A
your choice of interiors:
• Mercury Class IV fire protection of 1850°F for 2 hours.
Designed to maintain an interior temperature of less
than 350°F.
HS6743-LG-F-MM-A
interiors:
• U.L. listed Group 2M lock with spy-proof key-locking
dial, drill shattering hard plate and two additional
spring-loaded relocking devices.
• Plush tan pin-dot fabric interior.
• 5-point handle in brass or chrome and bold zinc diecast polished brass or chrome logos.
• 10 massive 1½" solid steel chrome plated locking bolts.
HS7943
12-23-35 Gun
• Available in several gloss and textured finishes.
“All-in-one”
12-18-30 Gun
All shelf
AMSEC GUN SAFE
NO COST LIFETIME
REPLACEMENT WARRANTY:
Thickness (Inches)
Outside Dimension
HxWxD
(Overall / Steel Plate)
Body
RF6528 (TL-30)
72 x 35 x 29½
5¾
HS7943 (TL-15)
79 x 43 x 29½
HS6743 (TL-15)
67 x 43 x 29½
Model
Wt. Lbs.
Interior
Capacity
Bolts
3½
3,455
12-18-30
10
5¾ / 1 in
3½
6,840
12-23-35
10
5¾ / 1 in
3½
4,824
12-23-35
10
Door
HS6743
12-23-35 Gun
• No Cost - Break-In Warranty
• No Cost - Attempted Break-In Warranty
• No Cost - Fire Warranty
See Our Gun Safe Catalog for more details.
FIRE AND BURGLARY PROTECTION
American Security Products Co. is highly acclaimed for offering the industry’s best fire protection. We manufacture the industry’s broadest gamut of
fire-rated products ranging from Underwriters Laboratories (U.L.) Listed 1 and 2 hour fire safes to our Mercury Class I, Class II, Class III, and Class
IV fire protected gun safes.
Series /
Model
*Each safe is designed
to maintain an interior
temperature less
than 350˚F.
Paper products will char at
approximately 450˚F.
Outside
Temperature
Period
(Time)
Inside Temp
Less Than
U.L. Burglary
Rating
Meets DOJ
Standards
Warranty
RF6528
1850° F
120 Minutes
350° F
TL-30
Yes
Lifetime
HS Series
1850° F
120 Minutes
350° F
TL-15
Yes
Lifetime
BF® Series
1275° F
90 Minutes
350° F
RSC
Yes
Lifetime
SF Series
1200° F
60 Minutes
350° F
B-Rate
Yes
Lifetime
TF Series
1200° F
30 Minutes
350° F
B-Rate
Yes
Lifetime
TF5517
1200° F
30 Minutes
350° F
B-Rate
Yes
1-Yr Parts & Labor
HC1854
1200° F
45 Minutes
350° F
B-Rate
No
1-Yr Parts & Labor
AM Series
Home Safes
1200° F
30 Minutes
350° F
B-Rate
Yes
1-Yr Parts & Labor
amsecusa.com/gun-safes-HS-main.htm
23
GUN SAFES
GUN SAFES
FEBRUARY, 2009
GUN SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
THE BF® SERIES GUN SAFES
THE MOST UNIQUE GUN SAFE IN THE INDUSTRY
• Commercial grade, adjustable ball
bearing hinges.
The BF® Series Features:
• ½" steel plate door (BF7250 is 3/8"
steel plate) combined with 1" DryLight
insulation.
• Dual fire seals with silicone seal on door
jamb and Palusol seal on door.
• 2" total wall thickness on all sides
featuring our poured DryLight insulation
and two layers of steel for exceptional
fire and security protection.
• U.L. Listed Group II Lock with massive
hard plate and two relocking devices.
• U.L. Residential Security Container
(RSC) Burglary Classification.
• Unique mirrored back wall for added
interior visibility.
• 10 massive 1½" chrome-plated bolts.
Bolt detent system holds bolts in open
position.
• Bold zinc die-cast polished brass or
chrome logos.
• Spy-proof, key-locking dial with
decorative five-spoke handle.
• 4 pre-cut anchor holes and 1 pre-cut
electrical access hole.
• Mercury Class III fire protection of
1275°F for 90 minutes. Designed to
maintain an interior temperature of less
than 350°F.
• E-Z Slant-Out Interior for easy access
to your long guns. Interior features rich
pin-dot fabric and adjustable interior
shelving.
• Available in several gloss and textured
finishes.
BF6030 WITH
OPTIONAL ESL10XL
ELECTRONIC LOCK
AMSEC GUN SAFE
NO COST LIFETIME
REPLACEMENT WARRANTY:
• No Cost - Break-In Warranty
• No Cost - Attempted Break-In Warranty
BF6636
Optional: Shown with
Storit Pack, Storit Shelves and
Fluorescent Light Kit
• No Cost - Fire Warranty
See Our Gun Safe Catalog for more details.
Thickness (Inches)
Model
Outside Dimension
HxWxD
Overall / Steel plate
Body
Wt. Lbs.
BF7250
71¼ x 50 x 28
5 8
4/
2
BF7240
71¼ x 40 x 26
4¾
2
BF6636
65¼ x 36 x 26
4¾
BF6030
59¼ x 30 x 26
BF6032
59¼ x 30 x 21
12-23-24-35-47
GUN INTERIOR
for Model BF7250
24
58 GUN INTERIOR
for Models: BF7240
Interior
Capacity
Bolts
1,736
12-23-24-35-47
10
1,402
12-18-24-30-42 or 58 Gun
10
2
1,218
12-23-35
10
4¾
2
885
12-18-30
10
4¾
2
810
8-14-22
10
Door
12-18-24-30-42
GUN INTERIOR
for Model BF7240
8-14-22
GUN INTERIOR
for Model BF6032
12-18-30 GUN
INTERIOR
for Models: RF6528, BF6030
12-23-35 GUN
INTERIOR
for Models: BF6636
ALL SHELF INTERIOR
Optional for all BF Models
Model BF7240: 5 Shelves
amsecusa.com/gun-safes-BF-main.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
GUN SAFES
HS/BF® SERIES ACCESSORIES AND OPTIONS
COLOR OPTIONS:
High-Gloss Exterior Colors:
Hunter Green Metallic (HG), Onyx (OX), Burgundy Metallic (BY), Pearl (PW), Platinum Metallic (PL),
NEW Charcoal Metallic (CM), NEW Macadamia Metallic (MM)
Textured Exterior Colors:
Granite (GR), Sandstone (ST), Black (BK), Green (GN), NEW Chocolate Brown (CB)
UPGRADE to the
“Premium” package
NEW! BF® Two-Tone Finishes:
Onyx High-gloss door / Black Textured body
Charcoal Metallic High-gloss door / Granite Textured body
Door-mounted storage
system designed to manage all your gear with
multiple pouches, elastic
shot shell holder and a
clear license holder.
OUTSIDE DIMENSIONS:
16" H x 18" W x 3" D
Built with 16 ga. steel. Includes
2 hand gun storage slots.
Raised edge on all shelves
keep items in place. Provides
convenient storage space for
your safe
GUNSAVER
DEHUMIDIFIER
Will constantly guard your
guns against the threat of
rust, pitting and moisture
damage. Electrical access
is required.
JEWELRY TRAY
Conveniently fits into
every safe. Burgundy
felt lined.
10-3/8” x 9-3/8” x 2”
FROM TOP
TO BOTTOM:
PISTOL RACK
Ideal for organizing pistols
inside your safe. This
four gun pistol rack sits on
top of an interior shelf.
GUNSAVER
DEHUMIDIFIER
DESSICANT
Prevents rust and moisture damage. Recommended for safes without
electrical access (Safes
with the fireliner option).
OUTSIDE DIMENSIONS:
27½" H x 14" W x 2 7∕8" D
When you choose to
upgrade your
American Security HS
or BF series safe with
a “Premium” package,
we’ll add on some
of our most popular
options including:
FLUORESCENT
LIGHT KIT
JEWELRY TRAY
INTERNAL
POWER
OUTLET
2-DRAWER AND 4-DRAWER STORAGE CABINETS
These elegant, well-appointed 2-Drawer and 4-Drawer Interior Chests are the most sophisticated
way to store and display your jewelry collection and letter files. These stunning chests are finely
crafted in solid-wood maple drawer fronts and maple veneer and finished in a rich honey maple stain.
2-DRAWER OPTION
Has a top drawer and a non-lined bottom
drawer that converts into a letter-size file
drawer with a metal file bracket.
Outside Dimensions: 16¾" x 16" x 15¾",
Weight: 32 lbs.
4-DRAWER OPTION
Has two top drawers, a middle drawer and a
felt-lined bottom drawer. Both drawer options
offer heavy-duty, ball-bearing drawer glides.
Outside Dimensions: 16¾" x 16" x 15¾",
Weight: 37 lbs.
Available in Fully Upholstered Safe Interior
Kits for the following models:
BF6030, BF6636, BF7240, and RF6528.
BF6030 shown with both Storage
Cabinets stacked together
Standard BF7250 interior accommodates
drawer options.
http://www.amsecusa.com/StorageCabinets-Main.htm
25
GUN SAFES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
SF SERIES - SIXTY MINUTE FIRE
All SF Series
Safes Feature:
• Group II, key-changeable lock with
internal relocker, spy-proof key-locking
dial and drill-resistant hardplate.
• ¼" Steel Plate door with 2 to 3 layers of
fire insulating material.
• Optional electronic lock available.
• 3-spoke handle in brass or chrome and
bold zinc die-cast polished brass or
chrome logos.
• Mercury Class II fire protection of 1200°F
for 60 minutes. Designed to maintain an
interior temperature of less than 350°F.
• 3-way boltwork with 5 active 1¼"
chrome-plated bolts and 3 deadbolts.
• Palusol™ door seal - expands up to 8
times its original thickness when exposed
to high temperatures.
• Adjustable ball bearing hinges.
• All-velour interior including back-cover
and firewalls.
• Body constructed of 12-gauge solid steel
plate with a fire insulating material.
• Four (4) pre-cut anchor holes with
mounting hardware included and one (1)
pre-cut electrical access hole.
• Available in several gloss and textured
finishes.
• Optional 4-shelf kit available
Sf6030
COLOR OPTIONS:
High-Gloss Exterior Colors:
Hunter Green Metallic (HG),
Onyx (OX), Burgundy Metallic (BY),
Pearl (PW), Platinum Metallic (PL),
NEW Charcoal Metallic (CM),
NEW Macadamia Metallic (MM)
AMSEC GUN SAFE
NO COST LIFETIME
REPLACEMENT WARRANTY:
Textured Exterior Colors:
Granite (GR), Sandstone (ST),
Black (BK), Green (GN),
NEW Chocolate Brown (CB)
NEW! SF Two-Tone Finishes:
Onyx High-gloss door /
Black Textured body
Charcoal High-gloss door /
Granite Textured body
• No Cost - Break-In Warranty
• No Cost - Attempted Break-In Warranty
• No Cost - Fire Warranty
See Our Gun Safe Catalog for more details.
Sf6030 interior view
Thickness
Model
Outside Dim
HxWxD
Door (Overall / Steel Plate)
Body
Wt. Lbs.
Interior
Capacity
Bolts
SF6036
59 x 36 x 26
4¼ / ¼
12 ga
718
17-17-34
8
SF6030
59 x 30 x 26
4¼ / ¼
12 ga
646
14-14-28
8
SF6032
59 x 30 x 21
4¼ / ¼
12 ga
576
10-10-20
8
SF5924
59 x 24 x 18
4¼ / ¼
12 ga
462
8-8-16
8
17-17-34
GUN INTERIOR
for Model: SF6036
26
14-14-28
GUN INTERIOR
for Model: SF6030
10-10-20
GUN INTERIOR
for Model: SF6032
8-8-16
GUN INTERIOR
for Model: SF5924
amsecusa.com/gun-safes-SF-main.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
Gun SAFES
TF SERIES - THIRTY MINUTE FIRE
AMSEC GUN SAFE
NO COST LIFETIME
REPLACEMENT WARRANTY:
• No Cost - Break-In Warranty
• No Cost - Attempted Break-In Warranty
• No Cost - Fire Warranty
See Our Gun Safe Catalog for more details.
tf5517
nOTE: AMSEC’S NO COST WARRANTY APPLIES TO
MODELS tf6036, tf6030, tf6032 AND tf5924 ONLY
tf6030
• 3/16" Steel Plate door with 2 layers of
TF6036, TF6030, TF6032
and TF5924 Feature:
fire insulating material.
• Mercury Class I fire protection of 1200°F
for 30 minutes. Designed to maintain an
interior temperature of less than 350°F.
• Palusol™ door seal - expands up to
• Mercury Class I fire protection of
• 3-point brass tri-spoke handle
and bold zinc die-cast polished brass
logo.
• 3-way boltwork with 5 active 1¼"
chrome-plated bolts and 3 deadbolts.
• Adjustable ball bearing hinges.
• Textured Black exterior and Mocha
fabric interior including back-cover and
firewalls.
8 times its original thickness when
exposed to high temperatures.
• Body constructed of 12-gauge (5924
fire insulating material.
• Optional electronic lock available.
• 3/16" Steel Plate door with 2 layers of
• Four (4) pre-cut anchor holes with
mounting hardware included and one
(1) pre-cut electrical access hole.
- 14ga) solid steel plate with a fire
insulating material.
• Optional 4-shelf kit available.
• Group II, key-changeable lock with
• Body constructed of 14-gauge solid
steel plate with a fire insulating
material.
• 3-wheel combination lock with spy-
proof dial and drill resistant hardplate.
• Optional electronic lock available.
chrome-plated bolts and 3 deadbolts.
• Textured Black exterior and Mocha
Outside Dim
HxWxD
Door (Overall /
Steel Plate)
Body
Wt. Lbs.
Interior
Capacity
Bolts
TF6036
59 x 36 x 26
35/8 / 3/16
12 ga
602
17-17-34
8
TF6030
59 x 30 x 26
3 /8 / /16
12 ga
528
14-14-28
8
TF6032
59 x 30 x 21
35/8 / 3/16
12 ga
472
10-10-20
8
TF5924
59 x 24 x 18
3 /8 / /16
14 ga
388
8-8-16
8
TF5517
55¼ x 17¾ x 16
3¼ / 3/16
14 ga
286
11
8
3
8 times its original thickness when
exposed to high temperatures.
die-cast polished brass logo.
Model
5
• Palusol™ door seal - expands up to
• 3-way boltwork with 5 active 1"
Thickness
3
1200°F for 30 minutes. Designed to
maintain an interior temperature of
less than 350°F.
• Brass “L” handle and bold zinc
spy-proof dial, internal relocker and drill
resistant hardplate.
5
The TF5517:
fabric interior including back-cover
and firewalls.
• Durable hinges.
• Four (4) pre-cut anchor holes with
mounting hardware included and one
(1) pre-cut electrical access hole.
• Optional 4-shelf kit available.
• Warranty: 1 Year Parts and Labor.
17-17-34
GUN INTERIOR
for Model: SF6036
14-14-28
GUN INTERIOR
for Model: SF6030
amsecusa.com/gun-safes-TF-main.htm
10-10-20
GUN INTERIOR
for Model: SF6032
8-8-16
GUN INTERIOR
for Model: SF5924
8-8-16
GUN INTERIOR
for Model: TF5517
27
VAULT DOOR
American Security Products Co.
Product Catalog
FEBRUARY, 2009
VAULT DOOR VD8030
Turn an entire room or closet into a security center.
As time goes on, all collections grow – not just guns, but personal
heirlooms, business and family records, jewelry, photographs and
works of art. Instead of buying three different safes over a lifetime,
the AMSEC vault door turns your room into a security center. It is designed for easy installation that retrofits a standard 80" x 30" opening.
Massive 1" door is constructed of 1/8" inner and outer steel plates
filled with a fire insulating material that provides a barrier against
extreme heat.
Select from four textured finishes: Black, Sandstone, Granite and
Chocolate Brown.
Each vault door offers elegant scrollwork and pinstripes accompanied by the renowned American Security logo.
Group II, key-changeable lock with internal relocker, brass spyproof key-locking dial and drill-resistant hardplate.
Decorative 3-point handle is standard.
5 massive 1¼" thick active bolts, with 5 deadbolts you can rest
assured that your valuables are protected. (Note: no deadbolts
required on in-swing door.)
Safety Lock Release: In case the door closes behind you, this
safety feature allows you to exit the vault quickly.
Make your vault room double as a storm shelter with our in-swing
vault door. Offering the same features as our standard vault door,
the in-swing vault door will insure opening from the inside even if
debris has blocked the door.
Minimum opening required:
79½" H x 29½" W
Door opening:
77½" H x 26½" W
In-Swing Door opening:
77½" H x 20-5/16" W
HOME SECURITY
Weight:
395 lbs.
VD8030
HORIZONTAL CABINET HC1854
Attractive wood cabinet in oak or cherry finish with tan or
black cushion conceals the horizontal safe discreetly and
can be used as a comfortable bench seat in a bedroom,
office or den.
Assisted by two hydraulic gas pistons, the door opens
and closes gently.
Inside lined with rich pin dot fabric.
Mercury Class I fire at 1200°F for a period of 30 minutes.
Designed to maintain an interior temperature of less than
350°F.
High-strength, double-wall unitized 12 ga. body and a ¾"
thick formed door.
Group II lock and front read dial protected by a drillresistant hard plate.
5 one-inch, chrome-plated steel locking bolts.
Outside dimensions include wood cabinet:
22½"H x 56¾"W x 24¼"D
HC1854
Weight: 450 lbs.
Warranty: 1 Year Parts and Labor
28
amsecusa.com/vault-door.htm or amsecusa.com/gun-safe-HC1854.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
• 3-way boltwork with 5
active 1¼” diameter
chrome-plated steel
locking bolts (2020
Model has 4 active
locking bolts).
• All-velour interior including back-cover and
firewalls.
• Deep blue textured finish with bold, elegant
American Security logo.
• Spy-proof dial and chrome “L” handle.
• Adjustable ball bearing hinges.
• 4 pre-cut anchor holes
with mounting hardware included.
• High-strength unitized 12 ga. solid steel
body.
• Fire protection of 1200°F for a period of 30
minutes. Designed to maintain an interior
temperature of less than 350°F.
• Massive 1¹⁄8" recessed door constructed of
a ¼" solid steel plate and a fire insulating
material.
AM3020
AM3020
open
• Warranty: 1 Year Parts and Labor
• 3-wheel combination lock protected by a
drill-resistant hard plate. (U.L. Listed Group
II Combination or Electronic lock available).
Thickness
Model
Outside
HxWxD
Inside
HxWxD
Cubic
Inches
Door
Body
Wt.
Lbs.
Interior
Shelves
Bolts
AM2020
20 x 20 x 20
17½ x 18¼ x 16¼
4,710
1½
12 ga
158
1
6
AM3020
30 x 20 x 20
27½ x 18¼ x 16¼
7,402
1½
12 ga
215
2
8
AM4020
40 x 20 x 20
37½ x 18¼ x 16¼
10,094
1½
12 ga
270
3
8
Handgun Safe
PB2
Drawer/Shelf Safe
ES412
Features:
Features:
• Deep blue powder coated finish with chrome hardware.
• State-of-the-art DL4000 electronic lock.
• Heavy-duty chrome handle.
• Heavy 16 gauge solid steel construction.
• Strong, pry-resistant chrome locking bolt.
• Pry-resistant recessed 10 gauge door with internal hinges.
• Interior cushioned with foam lining to protect against scratches.
• Two tempered-steel live bolts.
• Easy to change combination with programmable override code.
• 9V DC battery provides over 5,000 openings with low-battery
indicator.
• Fits in a drawer and only requires 5" clearance.
• Key override system.
• Excellent for protecting valuables, handguns or laptop computers.
• Optional quick release anchor plate available.
Outside Dimensions:
8 x 12 x 4
Weight:
8 lbs
amsecusa.com/
amsecusa.com/home-security.htm
or amsecusa.com/hand-gun-safes.htm
Outside Dimensions:
5 3/16 x 11 7/8 x 14 1/16
Weight:
19 lbs
29
HANDGUN SECURITY
HANDGUN SECURITY
• External auxiliary battery connection.
HOME SECURITY
“B” RATE
ROTARY
ANDSECURITY
FRONT LOADING
AM SERIES
HOME
SAFES
DXE / DXF AND CDXE / CDXF U.L. LISTED
American Security Products Co.
Product Catalog
FEBRUARY, 2009
“B” RATE
ROTARY
ANDCHESTS
FRONT LOADING
TL-15
& TL-30
MONEY
AMSEC TL-15 and TL-30 U.L. Listed MONEY CHESTS qualify for Mercantile &
Broadform Insurance Class ER (TL-15) and F (TL-30) with a banking rating of
BR (TL-15) and G (TL-30). AMSEC MONEY CHESTS offer the highest level of
security available with many outstanding features and a wide range of options.
CDXE2020
TL-30 Composite
Body and
Plate Door
DXE1818
TL-15 Plate Body
and Door
FEATURES
DOOR:
• DXE and CDXE models are TL-15 rated
constructed of ¾" thick solid steel plate.
• DXF and CDXF models are TL-30
constructed of 1¾" thick laminated steel
with a special hardened drill resistant plate.
• Oil impregnated bronze bearing hinges.
BODY:
• DXE models: Consist of ½" thick steel
plate (100,000 P.S.I. minimum tensile
strength). All external seams are beveled
and continuously welded.
• DXF models: Consist of ¾" thick steel plate
(75,000 P.S.I. minimum tensile strength).
All external seams are beveled and
continuously welded.
• CDXE and CDXF models: consist of 3¼"
thick body constructed of inner and outer
steel plates enclosing a high density
composite material.
• Shelf strips installed allowing shelf
adjustment. Shelves optional.
LOCKING MECHANISM:
• U.L. listed Group II key changeable
combination lock, with relock and 1 million
possible combinations.
• Single auxiliary spring loaded relocking
device, activated by a punching attack.
OPTIONS:
• Locks and relocks protected by a large
proprietary drill shattering composite
hardplate.
• A handle activated locking mechanism
consisting of two to five 1" chromed steel
locking bolts.
• Five boltwork sizes allow AMSEC to build
units from 12" (10½" for DXE/DXF) to 88"
high, widths from 14" to 41".
• Solid steel dead bar prevents door removal
if hinges are removed during a forced entry
attempt.
• Compact locking mechanism and boltwork
cover allow for optional door mounted coin
racks.
HINGES:
• Fabricated from high strength steel with
precision machined alloy dowel pins.
• Oil impregnated bronze bearing assures
easy opening doors and reduced
maintenance.
• Vertical height adjustment.
FINISH:
•Available in Black, Blue Gray, Parchment or
the standard Gray textured finish.
• Spyproof dial
• Key lock dial
• Coin racks
• Managers lockers
• Interior lockers
• Interior drawers
• Adjustable shelves
• Group 1 and 1R locks
• Electronic locks
• Access Control Systems
• Key-Op locks
• Dual combination locks (some models)
• 144 hour timelock
• 15 minute time delay lock
• External day lock
• Claddings
• Anchor bolt assembly
• Left swing door
• Internal rotary hopper
• Internal deposit slot
• Internal deposit chutes
• Hidden compartments
• Modular alarm
• Hold up duress alarm
• Special sizes
• Custom colors
30
amsecusa.com/safes-tl-15-30-plate.htm
DXE / DXF AND CDXE / CDXF U.L. LISTED
MODEL DXE or CDXE — ER RATED — Underwriter's Laboratories Listed TL-15, MODEL DXF or CDXF — F RATED — Underwriter's Laboratories Listed
TL-30
4024
3624
3030
3028
3024
3020
3018xD
3018
2424xD
2424
2420
2416
2020
2018
1818
1616
1414
1212
45½ x 24½ x 20
40½ x 34½ x 26
40½ x 24½ x 20
36½ x 24½ x 20
30½ x 30½ x 20
30½ x 28½ x 20
30½ x 24½ x 20
30½ x 20½ x 20
30½ x 18½ x 20
30½ x 18½ x 16
24½ x 24½ x 24
24½ x 24½ x 20
24½ x 20½ x 20
24½ x 16½ x 16
20½ x 20½ x 20
20½ x 18½ x 16
18½ x 18½ x 12
16½ x 16½ x 12
14½ x 14½ x 12
12½ x 12½ x 12
51½ x 31½ x 24¼
51½ x 25½ x 24¼
46½ x 25½ x 24¼
41½ x 35½ x 30¼
41½ x 25½ x 24¼
37½ x 25½ x 24¼
31½ x 31½ x 24¼
31½ x 29½ x 24¼
31½ x 25½ x 24¼
31½ x 21½ x 24¼
31½ x 19½ x 24¼
31½ x 19½ x 20¼
25½ x 25½ x 28¼
25½ x 25½ x 24¼
25½ x 21½ x 24¼
25½ x 17½ x 20¼
21½ x 21½ x 24¼
21½ x 19½ x 20¼
19½ x 19½ x 16¼
17½ x 17½ x 16¼
15½ x 15½ x 16¼
13½ x 13½ x 16¼
DXE
H" x W" x D"
54 x 26 x 25½
52 x 36 x 31½
52 x 32 x 25½
52 x 26 x 25½
47 x 26 x 25½
42 x 36 x 31½
42 x 26 x 25½
38 x 26 x 25½
32 x 32 x 25½
32 x 30 x 25½
32 x 26 x 25½
32 x 22 x 25½
32 x 20 x 25½
32 x 20 x 21½
26 x 26 x 29½
26 x 26 x 25½
26 x 22 x 25½
26 x 18 x 21½
22 x 22 x 25½
22 x 20 x 21½
20 x 20 x 17½
18 x 18 x 17½
16 x 16 x 17½
14 x 14 17½
DXF
H" x W" x D"
36,905 / 36,905
36,225 / 36,225
25,725 / 25,725
45,299 / 45,299
30,805 / 30,805
24,745 / 24,745
22,295 / 22,295
36,329 / 36,329
19,845 / 19,845
17,885 / 17,885
18,605 / 18,605
17,385 / 17,385
14,945 / 14,945
12,505 / 12,505
11,285 / 11,285
9,028 / 9,028
14,406 / 14,406
12,005 / 12,005
10,045 / 10,045
6,468 / 6,468
8,405 / 8,405
6,068 / 6,068
4,107 / 4,107
3,267 / 3,267
2,523 / 2,523
1,875 / 1,875
1,951 / 3,308
1,520 / 2,597
1,404 / 2,382
1,353 / 2,305
1,091 / 1,824
1,454 / 2,454
1,211 / 2,047
1,058 / 1,767
975 / 1,623
1,240 / 2,070
891 / 1,479
825 / 1,363
835 / 1,387
799 / 1,321
725 / 1,191
651 / 1,060
614 / 995
558 / 909
677 / 1,098
620 / 1,013
555 / 899
442 / 713
494 / 795
419 / 675
349 / 564
298 / 478
254 / 402
212 / 332
WEIGHT
LBS.
DXE / DXF
81½ x 33
71½ x 33
59½ x 33
59½ x 29
51½ x 33
51½ x 23
49½ x 33
49½ x 29
49½ x 23
44½ x 23
39½ x 33
39½ x 23
35½ x 23
29½ x 29
29½ x 27
29½ x 23
29½ x 19
29½ x 17
29½ x 17
23½ x 23
23½ x 23
23½ x 19
23½ x 15
19½ x 19
19½ x 17
17½ x 17
15½ x 15
13½ x 13¼
11½ x 11¼
CLEAR DOOR
OPENING FOR
ALL MODELS
DXE / DXF
82 x 34 x 26
72 x 34 x 26
60 x 34 x 20
60 x 30 x 20
52 x 34 x 20
52 x 24 x 20
50 x 34 x 26
50 x 30 x 20
50 x 24 x 20
45 x 24 x 20
40 x 34 x 26
40 x 24 x 20
36 x 24 x 20
30 x 30 x 20
30 x 28 x 20
30 x 24 x 20
30 x 20 x 20
30 x 18 x 20
30 x 18 x 16
24 x 24 x 24
24 x 24 x 20
24 x 20 x 20
24 x 16 x 16
20 x 20 x 20
20 x 18 x 16
18 x 18 x 12
16 x 16 x 12
14 x 14 x 12
12 x 12 x 12
88-3/4 X 40½
78-3/4 X 40½
66-3/4 X 40½
66-3/4 X 36½
58-3/4 X 40½
58-3/4 X 30½
56-3/4 X 40½
56-3/4 X 36½
56-3/4 X 30½
51-3/4 X 30½
46-3/4 X 40½
46-3/4 X 30½
42-3/4 X 30½
36-3/4 X 36½
36-3/4 X 34½
36-3/4 X 30½
36-3/4 X 26½
36-3/4 X 24½
36-3/4 X 24½
30-3/4 X 30½
30-3/4 X 30½
30-3/4 X 26½
30-3/4 X 22½
26-3/4 X 26½
26-3/4 X 24½
24-3/4 X 24½
22-3/4 X 22½
20-3/4 X 20½
18-3/4 X 18½
CDXE / CDXF
33
33
27
27
27
27
33
27
27
27
33
27
27
27
27
27
27
27
23
31
27
27
23
27
23
19
19
19
19
CDXE
33-3/4
33-3/4
27-3/4
27-3/4
27-3/4
27-3/4
33-3/4
27-3/4
27-3/4
27-3/4
33-3/4
27-3/4
27-3/4
27-3/4
27-3/4
27-3/4
27-3/4
27-3/4
23-3/4
31-3/4
27-3/4
27-3/4
23-3/4
27-3/4
23-3/4
19-3/4
19-3/4
19-3/4
19-3/4
CDXF
72,488
63,648
40,800
36,000
35,360
24,960
44,200
30,000
24,000
21,600
36,360
19,200
17,280
18,000
16,800
14,400
12,000
10,800
8,640
13,824
11,520
9,600
6,144
8,000
5,760
3,888
3,072
2,352
1,728
CUBIC INCH
CAPACITY
CDXE / CDXF
4,103 / 4,685
3,706 / 4,218
2,877 / 3,308
2,671 / 3,054
2,582 / 2,957
2,115 / 2,388
2,821 / 3,183
2,326 / 2,648
2,054 / 2,317
1,901 / 2,139
2,424 / 2,717
1,749 / 1,962
1,626 / 1,819
1,641 / 1,841
1,574 / 1,762
1,438 / 1,601
1,301 / 1,440
1,235 / 1,080
1,105 / 1,232
1,381 / 1,514
1,254 / 1,387
1,131 / 1,245
902 / 995
1,018 / 1,115
857 / 945
710 / 790
618 / 684
536 / 589
457 / 498
WEIGHT
LBS.
CDXE /
CDXF
81 x 32-3/4
71 x 32-3/4
59 x 32-3/4
59 x 28-3/4
51 x 32-3/4
51 x 22-3/4
49 x 32-3/4
49 x 28-3/4
49 x 22-3/4
44 x 22-3/4
39 x 32-3/4
39 x 22-3/4
35 x 22-3/4
29 x 28-3/4
29 x 26-3/4
29 x 22-3/4
29 x 18-3/4
29 x 16-3/4
29 x 16-3/4
23 x 22-3/4
23 x 22-3/4
23 x 18-3/4
23 x 14-3/4
19 x 18-3/4
19x 16-3/4
17 x 16-3/4
15 x 14-3/4
13 x 12-3/4
11 x 10-3/4
CLEAR DOOR
OPENING
FOR ALL
MODELS
CDXE / CDXF
COMPOSITE BODY AND PLATE DOOR
State CDXE (TL-15) or CDXF (TL-30) before model number
4034
50½ x 24½ x 20
51½ x 35½ x 304¼
54 x 36 x 25½
41,745 / 41,745
2,169 / 3,692
PLATE BODY AND PLATE DOOR
State DXE (TL-15) or DXF (TL-30) before model number
4524
50½ x 30½ x 20
53½ x 25½ x 24¼
62 x 32 x 25½
65,033 / 65,033
OUTSIDE DIMENSIONS*
5024
50½ x 34½ x 26
53½ x 35½ x 24¼
62 x 36 x 25½
74,003 / 74,003
OUTSIDE DIMENSIONS*
5030
52½ x 24½ x 20
61½ x 31½ x 24¼
74 x 36 x 31½
DEPTH
5034
52½ x 34½ x 20
61½ x 35½ x 24¼
84 x 36 x 31½
HEIGHT / WIDTH
5224
60½ x 30½ x 20
73½ x 35½ x 30¼
INSIDE DIM.
H" W" D"
CDXE** / CDXF
5234
60½ x 34½ x 20
83½ x 35½ x 30¼
CUBIC INCH
CAPACITY
DXE / DXF
6030
72½ x 34½ x 26
INSIDE DIM.
H" W" D"
DXE** / DXF
6034
82½ x 34½ x 26
MODEL #
Remember
to use
one of the
following
prefixes:
7234
DXE
DXF
CDXE
CDXF
8234
* Add 2" to outside depth for handle, dial and hinge projection.
31
amsecusa.com/catalog/product_catalog/DXECDXEChart.pdf
American Security Products Co.
Product Catalog
FEBRUARY, 2009
COMPARISON CHART
ACF TL-30 SERIES
American Security Products Co.
Product Catalog
FEBRUARY, 2009
U.L. LISTED FIRE RATED MONEY CHEST
AMSEC TL-15 and TL-30 U.L. Listed MONEY CHESTS qualify for Mercantile &
Broadform Insurance Class ER (TL-15) and F (TL-30) with a banking rating of
BR (TL-15) and G (TL-30). AMSEC MONEY CHESTS offer the highest level of
security available with many outstanding features and a wide range of options.
OPTIONS:
• Spyproof dial
• Key lock dial
• Coin racks
• Locks and relocks protected by a large
proprietary drill shattering composite
hardplate.
ACF4024
SHOWN WITH
AUXILIARY LOCK
FEATURES:
DOOR:
• 5½" thick door constructed of outer and
inner steel plates enclosing a high density
proprietary composite material.
• Two hour, 350°F factory fire rating. Tested
at temperatures up to 1850°F.
BODY:
• 3¼" thick body constructed of inner and
outer steel plates enclosing a high density
proprietary composite material.
• Door and inner jamb surrounded by thick
solid steel bars.
• Adjustable shelves.
LOCKING MECHANISM:
• Managers lockers
• Interior lockers
• A handle activated locking mechanism
consisting of three to five 1" diameter
chromed steel locking bolts.
• Interior drawers
• Adjustable shelves
• Group 1 and 1R locks
• Five boltwork sizes allow AMSEC to build
units from 12" to 82" high, widths from 18"
to 48" (interior dimensions).
• Electronic locks
• Access Control Systems
• Bolt tensioner keeps locking bolts retracted
in the open position.
• Key-Op locks
• Handle designed to shear in case of forced
entry attempt.
• 144 hour timelock
• Dual combination locks (some models)
• 15 minute time delay lock
• Solid steel dead bars prevent door removal
if hinges are removed during a forced entry
attempt.
• External day lock
• Anchor bolt assembly
• Compact locking mechanism allows for
optional door mounted coin racks.
• Left swing door
• Internal rotary hopper
HINGES:
• Internal deposit slot
• Ball bearing hinges fabricated from high
strength steel.
• Internal deposit chutes
• Hidden compartments
• Precision machined alloy dowel pins.
• Modular alarm
• Oil impregnated bronze bearing assures
easy opening doors and reduced
maintenance.
• Hold up duress alarm
• Special sizes
• U.L. listed Group II key changeable
lock, with relock and 1 million possible
combinations.
• Vertical height adjustment.
• Custom colors
FINISH:
• Custom designs
• Single auxiliary spring-loaded relocking
device, activated by a punching attack.
• Available in Satin Black, Blue Gray,
Parchment or the standard Gray textured
finish.
Model
Inside Dimension
Outside Dimension*
Clear Door
Cu. In.
Wt.
Shelves
ACF2020
20 x 20 x 20
26¾ x 26½ x 28¾
19 x 18¾
8,000
1,121
2
ACF2020XD
20 x 20 x 24
26¾ x 26½ x 32¾
19 x 18¾
9,600
1,235
2
ACF3020
30 X 20 X 20
36¾ x 26½ x 28¾
29 x 18¾
12,000
1,435
2
ACF3020XD
30 X 20 X 24
36¾ x 26½ x 32¾
29 x 18¾
14,400
1,572
2
ACF4024
40 X 24 X 20
46¾ x 30½ x 28¾
39 x 22¾
19,200
1,939
2
ACF4024XD
40 X 24 X 24
46¾ x 30½ x 32¾
39 x 22¾
23,040
2,105
2
ACF5024
50 X 24 X 20
56¾ x 30½ x 28¾
49 x 22¾
24,000
2,280
2
ACF5024XD
50 X 24 X 24
56¾ x 30½ x 32¾
49 x 22¾
28,800
2,468
2
ACF6030
60 X 30 X 20
66¾ x 36½ x 28¾
59 x 28¾
36,000
2,981
2
ACF6030XD
60 X 30 X 26
66¾ x 36½ x 34¾
59 x 28¾
46,800
3,320
2
* Add 2" to outside depth for handle, dial and hinge projection. Standard with two shelves.
Optional 3-way boltwork available on the ACF line, retail price $160.00. Custom size/design quoted upon request.
32
amsecusa.com/composite-safe-acf-series.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
AMSEC’s ACF TL-30 TWO DOOR DEPOSITORY SAFE
offers complete cash management versatility for any
operation that requires a nonreturnable deposit such as
armored car companies, convenience stores, restaurants,
etc. The U.L. listed TL-30 composite construction offers
peace of mind when overnight protection is required.
In addition to the outstanding features listed under ACF
TL-30 Money Chest, the ACF4824DS Depository safe also
offers:
ACF TL-30 SERIES
U.L. LISTED FIRE RATED DEPOSITORY SAFE
TOP DEPOSIT /
STORAGE COMPARTMENT
• Outer door equipped with a U.L. listed Group II combination lock
and chrome plated front read dial.
• Large storage capacity: accommodates up to nine cash register
trays.
• Large 3" x 18" deposit chute is protected by an “anti-fish”, saw-tooth,
hinged baffle.
• Two adjustable shelves.
• Door mounted four-opening rolled coin storage rack.
BOTTOM RECEIVING
COMPARTMENT
• Outer door equipped with a U.L. listed Group II combination lock,
chrome plated front read dial and an auxiliary key-op lock for dual
control or armored car pick up.
ACF4824DS
Options:
• Electronic locks, Group 1 and 1R locks.
• Dual combination locks (Receiving compartment only).
• Spyproof dial, Keylock dial.
• Modular alarm, Holdup alarm.
• Interior lockers, Interior drawers, Adjustable shelves.
• Custom sizes/designs quoted upon request.
• Access Control Systems.
FINISH
• Available in Satin Black, Blue Gray, Parchment or the standard Gray
textured finish.
INTERIOR VIEW
OF ACF4824ds
(FROM THE SIDE)
Model
ACF4824DS
Inside Dimension
Outside Dimension*
Clear Door
Cu. In.
Wt.
TOP 26 x 18 x 14
BOTTOM 14 x 18 x 17
47¾ x 24½ x 25¾
25 x 16¾
13 x 16¾
6,552
4,284
1,746
* Add 2" to outside depth for handle, dial and hinge projection. Standard with two shelves.
Optional 3-way boltwork available on the ACF line, retail price $160.00. Custom size/design quoted upon request.
amsecusa.com/composite-safe-acf-series.htm
33
AMVAULT TL-30 AND TL-15
American Security Products Co.
Product Catalog
FEBRUARY, 2009
FIRE RATED COMPOSITE SAFES
During extreme testing procedures, AMVAULT COMPOSITE SAFES
demonstrated the ability to withstand severe attacks by experienced U.L. experts
using powerful tools such as sledgehammers, power saws, carbide disc cutters,
drills, etc., and without fail, were awarded the U.L. TL-15 and TL-30 labels.
Besides withstanding the most concentrated
attacks by sophisticated burglars, each
AMVAULT safe offers a Two Hour, 350° F
factory fire test certification, ensuring the
protection of the vault’s contents against
intense fires.
1850°
AMVAULT
2-Hour,
350° F
rating
(Factory
tested at
1850°
1200°
Average
House
Fire
450° F
Paper Chars
350° F
Interior of an AMSEC Safe
CE2518
FEATURES:
DOOR:
• Overall thickness of 5¾" and is
constructed with a 2¾" defense barrier
of outer and inner steel plates creating
a single structure enclosing a unique,
high density fire and burglary resistant
composite material.
• Defense barrier houses a proprietary
amalgamation of nuggets and steel fibers
to withstand concentrated attacks with the
most sophisticated equipment used by
burglars today.
• The AmVault TL-30 offers a massive solid
steel hard plate covering the entire door.
CF5524
BODY:
• The AmVault formed body has a total
protective thickness of 3½" enclosing
a high density fire resistant composite
material with nuggets and steel fibers.
• A reinforced drill resistant door frame
protects the door and each individual bolt
chamber from severe side attacks.
• A proprietary inner barrier protects against
peeling attacks.
• High strength adjustable shelves.
FIRE ENDURANCE:
• Two hour, 350°F factory fire rating. Tested
at temperatures up to 1850°F
LOCKING MECHANISM:
• Equipped with six to ten massive 1½"
diameter chrome plated solid steel locking
bolts. Each bolt moves deep into the
body’s protected bolt chambers.
CF6528
SHOWN WITH
optional interior lockers
34
• Entire boltwork mechanism is also protected
by a spring operated boltwork detent
system. Bolts stay in the retracted position
when the door is opened and automatically
engage when the door is closed.
THREE-WAY
BOLTWORK OPTION
(TL-30 ONLY):
• Safes can be equipped with a three way
active boltwork mechanism engaging the
bolts horizontally and vertically into the
body of the safe.
LOCKS:
• Equipped with a U.L. listed Group II key
changeable combination lock. The lock
is protected by a massive drill shattering
hard plate and two additional springloaded devices.
HINGES:
• Offers a vertical height adjustment and
utilizes an oil impregnated bearing
ensuring easy door operation.
OPTIONAL AUXILIARY
KEY LOCK:
• U.L. listed, high security auxiliary key lock
is also available on all AMVAULT safes
(except Model 1814). Lock is equipped
with 2 keys and escutcheon plate.
• An additional spring-loaded relock device
protecting lock against punch attacks.
OPTIONAL GLASS
RELOCKING MECHANISM
(TL-30 ONLY):
• Incorporated into the AMVAULT TL-30
auxiliary key lock is an optional high
security tempered glass relock mechanism
with a remotely and randomly placed
“cross locking” relocking bolt and thermal
cords to protect against torch attacks.
• In the event of an attack by tools, torches,
or explosives, the glass will shatter
activating the highly sophisticated relock
mechanism.
• Utilizing the glass relock mechanism can
offer up to a total of six different relock
devices offering the ultimate in high
security protection.
amsecusa.com/composite-safe-am-vault.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
AMVAULT TL-30 AND TL-15
SAFE SPECIFICATIONS
AMVAULT High Security Composite safes have passed Underwriter’s Laboratories most
recent testing procedures ensuring you today’s best protection. AMVAULT TL-15 and TL-30
U.L. listed composite safes qualify for Merchantile & Broadform Insurance Class ER (TL15) and F (TL-30) with a Bank Rating of BR (TL-15) and G (TL-30). Two Hour Class 350°F
manufacturers’ fire label. Standard finish is Parchment. Other colors available on request.
Inside
Dimension
Outside
Dimension*
HxWxD
HxWxD
CE1814**
18 x 14 x 12
25 x 21 x 21½
1.8
710
CE2518
25 x 18 x 16
32 x 25 x 25½
4.2
CE3524
35 x 24 x 20
42 x 31 x 29½
9.7
CE4524
45 x 24 x 20
52 x 31 x 29½
CE5524
55 x 24 x 20
62 x 31 x 29½
CE6528
65 x 28 x 20
CE7236
Model
Number
Cubic
Feet
Weight
Interior
Shelves
Door Swing
A
B
C
1
14
36
39½
1,110
1
18
44
47½
1,720
2
24
56
57½
12.5
2,060
3
24
56
57½
15.3
2,410
3
24
56
57½
72 x 35 x 29½
21.1
3,238
4
28
64
61½
72 x 36 x 23
79 x 43 x 32½
34.5
4,000
4
36
80
72½
CF1814**
18 x 14 x 12
25 x 21 x 21½
1.8
732
1
14
36
39½
CF2518
25 x 18 x 16
32 x 25 x 25½
4.2
1,220
1
18
44
47½
CF3524
35 x 24 x 20
42 x 31 x 29½
9.7
1,954
2
24
56
57½
CF4524
45 x 24 x 20
52 x 31 x 29½
12.5
2,368
3
24
56
57½
CF5524
55 x 24 x 20
62 x 31 x 29½
15.3
2,746
3
24
56
57½
CF6528
65 x 28 x 20
72 x 35 x 29½
21.1
3,444
4
28
64
61½
CF7236
72 x 36 x 23
79 x 43 x 32½
34.5
4,546
4
36
80
72½
TL-15
Custom AmVault
Escutcheon Plate
Shown with optional auxiliary key lock and pull
handle, with matching operating handle.
*Tri-spoke handle standard on all models.
TL-30
* Add 2" to outside depth for handle, dial and hinge projection.
**Models 1814 can not be equipped with an auxiliary lock, 3-way boltwork or glass relock mechanism. Left Swing
Models: After model #, use suffix L.
UNDERWRITERS LABORATORIES’
BURGLARY RATING CLASSIFICATION
U.L. Label — Burglary
Classification TL-15:
Signifies a combination-locked safe designed to
offer a limited degree of protection against attack
by common mechanical and electrical hand tools
and any combination of these means.
Construction Requirements
• U.L. listed Group II, 1 or 1R combination
lock.
• 750 lbs. minimum or comes with
instructions for anchoring in a larger safe,
concrete blocks or on the premises where
used.
• Body walls of material equivalent to at
least 1" open hearth steel with a minimum
tensile strength of 50,000 P.S.I.
• Walls fastened in a manner equivalent to
continuous ¼" penetration weld of open
hearth steel with minimum tensile strength
of 50,000 P.S.I.
amsecusa.com/ul_burglary_class.htm
• One hole ¼" or less, to accommodate
electrical conductors arranged to have
no direct view of the door or locking
mechanism.
Performance Requirements
Successfully resist entry* for a net
working time of 15 minutes when attacked
with common hand tools, picking tools,
mechanical or portable electric tools, grinding
points, carbide drills and pressure applying
devices or mechanisms.
U.L. Label —Burglary
Classification TL-30:
Signifies a combination-locked safe designed
to offer a moderate degree of protection against
attack by common mechanical and electrical
hand tools and any combination of these means.
Construction Requirements
Same as TL-15
Performance Requirements
Successfully resist entry* for a net
working time of 30 minutes when attacked
with common hand tools, picking tools,
mechanical or portable electric tools, grinding
points, carbide drills and pressure applying
devices or mechanisms, abrasive cutting
wheels and power saws.
*Entry=Safes classed as TL-15 — opening the door
or making a six square inch opening entirely through
the door or front face. Safes classed as
TL-30 — opening the door or making a six square
inch opening entirely through the door or front face.
35
OPTIONAL EXTRAS
American Security Products Co.
Product Catalog
FEBRUARY, 2009
OPTIONAL EXTRAS
AMSEC offers a wide variety of options not listed here. Consult your AMSEC price book or call for other available options.
AMSEC’s staff will also assist in helping you choose the correct options for your security needs.
Modular Alarm System
Interior Drawers
144 Hour Time Lock
Detects vibration, heat and door openings.
Heat indicator activates alarm when torch
attack occurs. Internal magnetic door contact
detects door opening. Internal vibration
sensor activates alarm if safe is moved or
during drill attack.
All drawers are commercial quality, heavy
steel construction. Available in letter, legal
and document sizes. Each is furnished with
handle and key lock. All drawer capacities are
150 lbs. and come with a heavy duty latch
removable ball bearing suspension.
Safes equipped with Time Locks offer the
capability of locking the safe for a preselected period of time. Time periods range
from one hour to 144 hours (6 full days).
U.L. Listed Dual Nose Key Lock
U.L. Listed Key Op Lock
U.L. High Security Key Lock
Dual control safe deposit lock requires two
different keys to open safe.
European style seven-lever changeable key
lock offers exceptional security features for
use on inner locker or outer safe doors.
European style nine-lever changeable key
lock offers exceptional security features for
use on inner locker or outer safe doors.
36
Spyproof Dial
Key Locking Front Read Dial
Restricts unauthorized viewing while dialing
combination. Also available with key locking
feature.
Key is used to lock dial in a fixed position and
affords dual custody control. Manager has the
combination, collector has the key. Both must
be present to unlock the safe.
amsecusa.com/optional_extras.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
Interior Lockers
AMSEC offers a wide variety of standard interior locker compartments to fit
your needs. Standard lockers are constructed of 10 gauge or ¼" solid steel.
Options include slotted doors, combination locks and high security key locks.
SUPER BRUTE “B”
AND “CB” RATE
SLOTTED SQUARE
HINGED DOOR
OPTIONAL EXTRAS
OPTIONAL EXTRAS
with 3/8” x 4” slot
Slotted Doors
Slotted doors are also available on
freestanding plate safes, freestanding clad,
composite chests, interior lockers and
interior drawers.
Note: Safes with slotted doors are not
recommended for overnight storage.
STAR “C” RATE
SLOTTED ROUND DOOR
MINI BRUTE
“B” RATE
SLOTTED SQUARE
LIFT-OUT DOOR
with 3/8" x 3½" slot
with 3/8" x 4½" slot
Interior/Exterior Hopper
Available in three different package sizes
ranging from 5¾" D x 3½" W x 8¾" L
to 7" D x 4½" W x 10¾" L.
Hoppers can be installed on the interior or
exterior of plate, clad or composite safes.
Locking Bolt Detent
Coin Racks
Keeps locking bolts retracted when door
is in open position. Prevents damage
to safe body and boltwork mechanism
caused by accidental door closure with
bolts extended.
For organized storage of coins.
Mounted on inside safe door. Available with four or six compartments.
amsecusa.com/optional_extras.htm
37
TELLER LOCKERS
American Security Products Co.
Product Catalog
FEBRUARY, 2009
TELLER LOCKERS
FEATURES:
Body:
• 16"H x 32-5/8" W x 24" D, ¼"
solid steel construction.
Door:
ATL-2
Weight: 240 Lbs.
ATL-3R
Weight: 255 Lbs.
ATL-4
Weight: 270 Lbs.
ATL-4R
Weight: 270 Lbs.
ATL-5R
Weight: 285 Lbs.
ATL-6
Weight: 295 Lbs.
• ¼" solid steel, hinged from
center, divider.
Hinge:
• Solid steel continuous hinge.
Color:
• Available in Gray, Blue Gray, Parchment, or standard
Charcoal Gray textured finish.
Locks:
CUSTOM SAFES
• U.L. listed double nose and single nose safe deposit
locks or Medeco® camlocks standard. Combination locks
optional extra.
38
CUSTOM SAFES
AMSEC specializes in manufacturing CUSTOM SAFES for supermarkets,
banks, restaurants, convenience stores, gas stations, hotels, mini-marts and
other businesses. With over 50 years experience building custom safes,
AMSEC has the knowledge and expertise to design a safe to meet your cash
handling requirements. Our engineering department is equipped with the latest
in computer-aided design (CAD) systems for rapid creation of detailed sales
sketches, concept drawings, final product prints and design modifications
to help you visualize how the safe will look and function. Custom safes are
available in every insurance classification from “B” Rate to U.L. listed TL-30
models.
amsecusa.com/custom_safes.htm
ELECTRONIC LOCKS
A
C
C
ES
S
F
SA
®
D
1
20
1
23
1
2
SA
F
E
G
A
R
D
SM
A
R
TL
I
N
C
A
U
D
I
TC
O
N
52
A
U
D
I
TC
O
N
25
2
A
U
D
I
TC
O
N
55
2
Round,
Verticle
R
Round,
Verticle
99
A
Round,
Verticle
20
1
EW
IZ
Rectangle
2
1
Self
Generating
M
A
N
A
G
ER
Round
Mgr. + (8)
1
Self
Generating
8
XL
1
5
Self Generating/
Battery
8
YES
20
1
(1) 9V +
(6) “C” (Opt.)
6
YES
ES
L
1
(2)
9V
6
YES
XL
(2)
9V
6
YES
10
1
8
YES
YES
ES
L
1
(2)
9V
5
YES
YES
Safe Doors
Power Source
Round
6 / 1 deposit
(2)
9V
8
(10 min.)
YES
YES
NO
Round
N/A
AC with Battery
Back-up
4
YES
(Order Model T-52)
NO
N/A
Round
1
AC with
Battery Back-up
6
(15 min.)
YES
1-99
min.
NO
N/A
OPT
Rectangle
(2)
4
YES
1-99 min.
1-19
min.
N/A
OPT
Rectangle
1
9V/AC
Key +6
8 if Keypad only
Fingerprint +6
Card +6
(15 min.)
YES
1-99
min.
(4)
(*)
OPT
YES
Round
(2)
N/A
Settable
NO
1-99
min.
1-10
min.
N/A
OPT
Time & Date
YES
Round
9V/AC
6
N/A
YES
1-9
min.
2-9
min.
N/A
OPT
(OPT)
Housing
6
YES
N/A
1-99
min.
2 min./
fixed
N/A
OPT
YES
5
YES
YES
N/A
1-99
min.
N/A
OPT
NO
(Opt.)
8
Combination
(number of digits)
N/A
1-99
min.
N/A
(6)
(*)
OPT
600
Time & Date
YES
(Opt.)
YES
40
Wrong Try Lock
Out (time)
N/A
1-9
min.
1
STD
NO
(Opt)
Audit Only
(Opt.)
YES
N/A
Dual Mode
N/A
N/A
N/A
NO
NO
YES
YES
8
Time Delay
N/A
OPT
8000 w/ 500 Backup
NO
NO
YES
YES
1
Time Delay Open
Input Window
(time/by user)
OPT
N/A
(OPT)
NO
YES
NO
Number of
Users
Time Lock
(periods)
*(variable)
N/A
N/A
YES
YES
YES
1 Programmer
3 Manager
6 Super User
20 User
Duress
N/A
N/A
N/A
YES
YES
1-19
min.
factory set
NO
(500)
YES
(Opt.)
100
YES (Opt.)
100
400
YES (Opt.)
400
Time & Date
YES
YES
YES
(Opt.)
YES
YES
YES
(Opt.)
YES
YES
NO
NO
NO
YES
Audit Trail
(# of events)
N/A
N/A
YES
factory set
PC Software
Audit Records
N/A
YES
N/A
YES
Alarm Interface
YES
YES
YES
Bolt Options
Auto Lock
YES
YES
Spring Bolt/
Slam Bolt
ELECTRONIC LOCKS
ELECTRONIC LOCK COMPARISON CHART
39
amsecusa.com/catalog/product_catalog/ElectronicLockComparisonChart.pdf
American Security Products Co.
Product Catalog
FEBRUARY, 2009
Electronic Locks
American Security Products Co.
Product Catalog
FEBRUARY, 2009
AMSEC SAFEWIZARD®
The SafeWizard® electronic safe controller is a state-of-the-art electronic product for use in controlling and auditing access
to safes. Designed to prevent burglaries and internal theft, the SafeWizard® controls and documents each access to the safe.
Based on contemporary high speed processors, unique user friendly software techniques and ingenious application ideas, this
system surpasses all other safe access control systems.
FEATURES:
• A powerful processor based on the
ColdFire® 32 bit microprocessor.
• Flash Memory for quick and cost effective
upgrades.
• Up to 10,000 audit entries and 40 users.
• Controls up to 6 safe doors and 1 deposit
lock. Safe doors can be configured in any
inner-outer arrangement.
• Time Delay any door with a 1-99 minute
delay and 1-99 minute open period with
cancel feature.
• Time Lock any door, 1-6 windows per day.
• Authentication options: PIN code and/or
Dallas Key access control, optional Finger
Print Reader or Card Swipe devices are
available.
• Dallas Keys are color-coded: Factory Key
(Black), Audit Key (Yellow), Manager Key
(Red), User Key (Blue) and Courier Key
(Teal).
• Wrong Try Count Penalty Lockout.
• Auto-Purge Idle Users option, selectable
by Individual User.
• Forced PIN Changes to decrease risk of
compromised PINs.
• Armored Car courier Time Delay and Lock
Bypass.
• Duress/Hold-up Alarm with Silent Signal.
• Burglary Alarm output triggering from
selectable events.
• Holiday Schedule with up to 16
programmable events per year.
• Built-in key maker, complete with
management tool set, audit trail sorting by
several criteria.
• Deposit Tracking system to provide
the highest level of cash management
security.
• Communications possibilities are
unrivaled. Incorporating a built in Infra-Red
(IR) Port, Multiple Serial Devices, optional
Ethernet Networking Port. Audits and
administration can be managed through
the Serial Port of Personal Computer or
remotely via a Network connection.
THE AMSEC SAFEWIZARD
ELECTRONIC ACCESS CONTROL SYSTEM IS AVAILABLE
ON NEW AMSEC SAFES OR
AS RETROFIT KITS.
Authentication Options:
• Audit trail can be downloaded to a
Windows CE® based palmtop via
the IR Port for compact and portable
administration.
• Audit utility allows PC based audit storage
management, data filter and sorting
capabilities and excellent exception
reporting to focus on key security issues.
Dallas Keys
• Ultra-high contrast 8 line by 21 character
graphics display.
• Rechargeable Battery Backup.
• Built-in System Diagnostics.
Card Swipe
• Alarm Interfaces in the Power Supply
Module interfaces the system to any
conventional Alarm System, with simple
connections for Alarm Output, Duress
Output, CCTV Activation and an Input for
Alarm System control of the SafeWizard
system.
• Parallel Printer Interface.
FPC
Fingerprint
Reader
• English, Spanish, French and German
language options.
• Automatic Daylight Savings Adjustment,
selectable and configurable.
Accessories:
• Dual Control Mode on any individual door,
selectable by user.
Door sensor
Monitors door position
(standard on external
doors)
SafeWizard®
40
Safeguard
Protects controller against
accidental damage
amsecusa.com/electronic-locks-safe-wizard.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
AMSEC has been a pioneer in the electronic lock market. The ESLXL SERIES locks
offer unrivaled value in electronic safe access. The ESL10XL and ESL20XL locks
have the best blend of features and function in Electronic Safe Locks. The ESLXL
SERIES offer an attractive metal die-cast keypad housing with an alpha-numeric
slanted keypad. The ESL10XL is a basic keypad lock for home and office applications. The ESL20XL offers advanced features necessary for commercial applications.
ESL20XL
ADDITIONAL FEATURES:
• Time Delay Mode: Delays can be set from
1 to 99 minutes.
esl10xl
with brass finish
ESL10XL
FEATURES:
• Replaces most mechanical combination
locks. Easy installation and operation.
• Factory Reset Combination for solving lost
combinations without requiring expensive
service calls.
• Electronics are encapsulated within the
lock and are sealed to prevent possible
moisture related failures.
• Cable fits through a ½" spindle hole
without cutting and re-crimping connector.
• Audible beep and flash from every keystroke
gives maximum feedback to the user.
• 15 minute Penalty Lockout after four
incorrect entries protects against
manipulation attempts.
• New patented dead-latched lock design
with an internal relock device for maximum
security.
• Lock “auto-locks” when boltwork is thrown
to prevent safes from being left in a day
lock position.
• Slam Bolt version for locker applications.
• Multiple User Mode: When enabled, one
Master code and eight user codes are
available with full supervisory control and
code management.
• Dual Control Mode: The lock can be
programmed to require two combinations
to open for added security.
• Armored Car Override: When enabled,
allows an armored car service to bypass
Time Delay.
• External A/C Power: Provides power for
unlimited use with battery power as backup.
• Control Port: Turn the ESL20XL on/off
with an Access Manager, Alarm System or
other device.
ELECTRONIC LOCKS
AMSEC ESL-XL SERIES
esl10xl
with BLACK finish
All the ESL20XL features are
programmed from the keypad.
The Expansion Modules provide
convenient screw terminal and slip
spade connections for field wiring by
the installer.
Optional Expansion Modules:
Provides these additional capabilities on the
ESL20XL:
• Duress (Silent Signal) Alarm Output.
Provides relay output for alarm system
connection.
• External connection for A/C power
transformer on ESL20XL and ESL10XL.
A/C Power can be connected to the
ESL10XL and ESL20XL lock (with
the ESLAC kit) or an Expansion Module (with the ESLTFMR kit). Wiring,
conduit and attachment hardware is
provided with all optional kits.
• External connection for control port.
• Provides for connection of one or two
ESL20XL locks.
• Optional internal battery pack extends
operation between battery changes.
Model
Description
Finish
ESL10XL
ESL10XL Standard Lock
Black, Chrome, Brass
ESL10XL-S
ESL10XL Slam Bolt Lock
Black, Chrome, Brass
ESL20XL
ESL20XL Standard Lock
Black
ESL20XL
ESL20XL Slam Bolt Lock
Black
slam bolt
* Lock factory installed in place of the standard Mechanical Combination Lock, Dial and Dial Ring.
**Lock factory installed as an auxiliary lock, includes all mount pads and hardware for installation.
Please refer to our Retail Price List for a complete list of part numbers for primary lock, auxiliary lock and
Retrofit kit options.
Accessory Number
ESLBAT
Description
Aux. Battery pack for any ESL Locks. Provides extended life on battery power.
ESL20XLEXP1
Expansion Kit for (1) ESL20XL lock. External box with duress capability.
ESL20XLEXP2
Expansion Kit for (2) ESL20XL locks. External box with duress capability.
ESLAC
ESLTFMR
A/C Power kit for use with any ESL lock. Provided with conduit and fasteners.
standard bolt
A/C Transformer for use with any Expansion Kit.
amsecusa.com/electronic-lock-esl.htm
41
Electronic Locks
American Security Products Co.
Product Catalog
FEBRUARY, 2009
AMSEC ACCESS MANAGER
The ACCESS MANAGER® is not a lock by itself, but an electronic time lock control device. When controlling the ESL20 electronic lock, it allows the user the capability of setting the system to their specific needs. The Access Manager® will control one
or two electronic locks. One lock operation allows four open time periods during a 24
hour period. If two locks are to be controlled, user may program two open time periods
Easy Installation / Operation
• Eight conductor phone communication.
• All mounting hardware and cable included
for normal installation.
• Retrofittable to the AMSEC/Major
Defender Time Delay Lock.
• Works with most electronic locks.
• Easy to read illuminated display.
• 24 hour clock, military format.
• Alarm clock style programming.
ACCESS MAN-
• Internal key control for programming.
Multiple Power Sources
Keeping in mind every possible situation
the commercial environment can demand,
AMSEC has made several different power
sources standard.
• AC wall mount transformer.
• 4 AA battery back-up.
• On board Ni-Cad battery backup.
• Auxiliary emergency power port on display
board.
SARGENT AND GREENLEAF COMPTRONIC™
Standard features on all
COMPTRONIC™ Electronic
Safe Locks:
• All Combination changes and programming
are easily made at keypad.
S&G 6120
e-z keypad
• Uses two (2), 9V Alkaline batteries
-Duracell® recommended. (E-Z keypad
uses (1) 9V battery.)
• Keypad feedback with beep and LED flash.
• Multiple users.
• Programmable Time Delay.
• Motor driven bolt.
• Wrong combination try penalty.
• U.L. Type 1 listed.
s&g 6120
round keypad
COMPTRONIC™ Keypad Finishes:
• Chrome - satin or bright.
• Brass - satin or bright.
• Black - matte only
• Gold - 14K or 24K
Optional Security Enhancement
Accessories:
• Spy-Proof ® Cover.
• Time Delay Status Indicator.
• Bolt Position Indicator.
• Duress and Remote Activation Modules.
• Audit Trail (Model 6124/25 only).
For detailed specifications, visit www.sglocks.com
KABA-MAS AUDITCON® 2
Featuring PowerStar Technology:
Use of an internal generator creates all the necessary power. No batteries or external power is required.
AUDITCON®
round profile
Model 52 Series:
• Time Delay.
• Stand-alone, single combination access
control.
• Multi-user access control with audit capability.
• Dual Mode (2-user) function that provides
a small business or individual with the
convenience of electronic locking.
Model 552 Series:
• Model T52 meets all specifications of the
Model 52, plus is fitted with a time delay
feature.
Model 252 Series:
• Offers advantages of basic electronic locking.
For detailed specifications,
visit www.kaba-mas.com
42
• Programmable keypad with resetable
combinations.
• Audit Software Extra.
• Easily replace traditional mechanical
Group I and Group II locks.
• Upgrades the security of any safe or
archive storage unit.
• Perfect for security applications where
shared access and audit capability are
necessary.
• Audit Software Extra.
amsecusa.com/electronic-locks.htm
FEBRUARY, 2009
Product Catalog
American Security Products Co.
lg bASIC ANGULAR
rOUND ENTRY
(pART #3715)
LG BASIC II
Electronic Lock
Standard Features:
• Manager Mode.
• Wrong Try Penalty.
• Outside Battery Compartment (Located
under input housing).
• Uses one (1) user-supplied 9V Alkaline
Battery.
ELECTRONIC LOCKS
LAGARD ELECTRONIC SAFE LOCKS
DUAL-HANDED
sWINGBOLT lOCK
lg BASIC
(pART #3765)
• Satin-Chrome Angular Input Housing
(Brass Optional).
• U.L. Listed.
• Made in USA.
Part # 3715 Angular Round Entry
Part # 3765 Dual-Handed Swing-Bolt
LG BASIC II
SAFEGUARD
Digital Combination Lock
Standard Features:
• Direct Replacement - Most Mechanical
Combination Locks.
• Wrong Try Penalty.
Programmable Features:
(with Optional Hand-Held Programmer)
• Second user.
• Time Delay
– Delay Period: 1-99 minutes
– Open Period: 1-19 minutes
• Optional Features: Programmable at any
time by Authorized Service.
• Time Delay override.
• Uses user-supplied 9V Alkaline Batteries.
• Silent Signal Alarm
• Dual Combination.
– Optional box required
• U.L. Listed.
• Remote Override Signal
• Made in USA.
– Optional Alarm box required
SAFEGARD
Part # 4100 Swingbolt Lock
SMARTLINC
Serial Access Control
Programmable Features:
Standard Features:
• Multiple users.
• Wrong Try Penalty.
• Dual Combination.
• Signal to Disable Lock.
• Time Delay
– Optional Alarm/Battery Box required
– Delay Period: 1-99 minutes
• System Status shown on LCD or optional
printer.
• Time Delay override. (#9 osev).
• Audit trail by way of optional software.
• Silent Signal Alarm
• Optional battery box contains six usersupplied C-Cell Alkaline Batteries.
• U.L. Listed.
• Made in USA.
SMARTLINC
• Manager Mode.
– Open Period: 1-19 minutes
– Optional box required
• Time Lock set, 4 standard lock periods per
day. (Special events takes precedence
over Standard Week).
• Languages: Manager LCD display in
English, Spanish, French, German or Italian.
For detailed specifications on LaGard locks, visit www.lagard.com
amsecusa.com/electronic-locks.htm
43
MATERIALS HANDLING EQUIPMENT
American Security Products Co.
Product Catalog
FEBRUARY, 2009
MATERIALS HANDLING EQUIPMENT
Provide a higher level of service to your customer with AMSEC’s new line of MOVING EQUIPMENT, giving you the capability
to deliver and install any size safe -- quickly and safely!
Lift ‘N’ Roll
• Load is always stable and
balanced.
• The hydraulic rams allow
easy raising and gentle
lowering of load from 1/8" to
4½".
• Two handles on each
side provide ease of
maneuvering.
• Lightweight design. Built to
last.
• Sturdy steel construction.
• Capacities up to 1,500 lbs.
• Non-marking polyurethane
wheels and padding system.
LIFT ‘N’ ROLL MODEL 1500NR
UltraLift
Powered Hand Truck
• The operator stays in control by using
a combination of motor power, balance
and leverage.
Designed to meet your on-the-job requirements, the UltraLift is the best move you
will ever make. Machine weight includes
strap bar, 4-wheel dolly and spill-proof
gel cel battery. Minimum overall machine
height is with extension handle retracted
for moves in restricted areas. Maximum
height is with handle fully extended for
maximum leverage:
• Gentle handling eliminates bumps
and bounces to loads and premises,
eliminating damages.
• Pay-off is approximately 21 installs
(based on a national average of $200
per install).
• Great versatility: Handle any load on the
level, up and down the stairs, on and off
trucks, over obstacles and many more.
• Load capacity up to 1,500 lbs. Machine
weight is 120 lbs.
• Light-weight aluminum stands up to years
of rough use.
• Optional accessories available. See
AMSEC’s Retail Price Book.
Triple L Trailer
The design of this patented,
innovative trailer is the result of
Premco’s extensive engineering
and testing procedures. Triple
L Trailers offer the highest quality and best
value of any trailer on the market!
Features:
• Level loading - deck remains level through
out raising and lowering.
• Lockable tool box - ideal for storing chain
binders, tie down straps, etc.
• Full width rear ramp angle allows easier
loading.
• Heavy duty adjusting tongue jack.
• Hydraulic System activated by a single lever.
• Charcoal powder coated finish.
• Oversized deck bearings rated for 80,000
lbs. - each bearing greaseless and sealed.
• 1 Year Manufacturers Warranty.
• Battery, pump and motor are enclosed in a
lockable compartment.
Model
248
4610
7610
Capacity
2200
4500
7000
Deck Size
4' x 8'
6' x 10'
6' x 10'
80"
101"
101"
Lift Mechanism
Winch
Hydraulic
Hydraulic
Axle
Single
Single
Tandem
Suspension
Torsion
Spring
Spring
Wheel Size
15"
14.5"
15"
Brakes
No
Electrical
Electrical
Hitch (Ball Size)
Weight
2"
2"
2-5/16"
1,510 lbs.
2,070 lbs.
2,500 lbs.
* Specification and design are subject to improvement and may change at any
time without notice.
44
• Lights Standard.
• Automatic latch locks upon raising for
added travel security.
• Heavy duty tubular chassis - steel diamond
deck plate supported by 4 tubular members
running the full length of the deck to give
complete wheel support for heavy loads.
Overall Width
ultralift MODEL 1500Ul
• One person can easily handle every
load, even up and down the stairs,
reducing labor costs.
MODEL 4610
LOAD
LIFT
amsecusa.com/contact/
FEBRUARY, 2009
Product Catalog
American Security Products Co.
STORAGE CABINETS
STORAGE CABINETS
These elegant, well-appointed 2-DRAWER and 4-DRAWER interior
chests are the most sophisticated way to store and display your jewelry collection and letter files. These stunning chests are finely crafted
in solid-wood maple drawer fronts and maple veneer, and finished
in a rich honey maple stain. Place these unique drawer storage
cabinets inside an AMSEC security safe to organize and protect your
most valued posessions. Optional fully upholstered safe interiors with
dividers and shelving are also available on selected AMSEC safes.
STORAGE CABINET
FEATURES:
• All drawers are elegantly lined in silky,
dark red felt.
• Top drawers have one (1) ring-holder
compartment, three (3) large open
compartments for miscellaneous jewelry
and one (1) long open compartment for
necklaces.
• Middle drawer is designed with six
(6) watch holder compartments, each
compartment comes with a watch pillow,
one (1) small open compartment and one
(1) large easy access compartment.
• Bottom drawer is left open for easy
access of large bulky items.
2-DRAWER
OPTION:
• 2-drawer option has a top drawer and a
non-lined bottom drawer that converts
into a letter-size file drawer with a metal
file bracket and heavy-duty, ball-bearing
drawer glides.
• Exterior Dimensions:
16¾" H x 16" W x 15¾" D
• Weight: 32 lbs.
4-DRAWER
OPTION:
• 4-drawer option has two
top drawers, a middle
drawer, and a felt-lined
bottom drawer.
This option also comes with heavy-duty,
ball-bearing drawer glides.
• Exterior Dimensions:
16¾" H x 16" W x 15¾" D
• Weight: 37 lbs.
Storage Cabinets are available for the following safe models:
AVAILABLE
IN ALL CE’S
AND CF’S:
1814 / 2518 / 3524
5524 / 6528 / 7236
AVAILABLE
IN MODELS:
BF1716 / BF3416
Fully upholstered safe
interior kits available for
these models
No kit needed.
Drawers slide right in.
ce5524
bf1716
ce3524
ce2518
AVAILABLE
IN BF® AND
HS GUN SAFE
MODELS:
RF6528, HS7943,
HS6743, BF7250*,
BF7240, BF6636
AND BF6030
*No kit needed.
Drawers slide right in.
amsecusa.com/storageCabinets-Main.htm
ce2518
bf3416
with stacked
cabinets
ALSO AVAILABLE IN
CSC MODELS:
CSC3018 AND CSC4520
(SEE PAGE 17)
No kit needed. Drawers slide right in.
45
MERCHANDISING / DISPLAYS
American Security Products Co.
Product Catalog
FEBRUARY, 2009
MERCHANDISING / DISPLAYS
PART #
DESCRIPTION
1045008
3-PACK SAFES: WS1014, WS1514, & WS1214 Also
includes display stand, POP, product tags, color poster and
consumer brochures
1045020
4-PACK PROMOTIONAL KIT: safe pedestal, sales banner, 3 hanging signs, safe usage poster, window decal,
consumer brochures, product tags, & authorized dealer
certificate.
1045021
8-PACK PROMOTIONAL KIT: Large illuminated clock, two
safe pedestals, sales banner, 4 hanging signs, safe usage
poster, window decal, consumer brochures, product tags, &
authorized dealer certificate.
AMSEC INDIVIDUAL SALES AIDS
PART #
DESCRIPTION
1045022
Illuminated Clock (15" x 30")
1045014
Display Pedestal
1045000
Sales Banner (5ft w x 4ft h)
1045024
"Burglary/Fire Safes" Hanging Sign (21"w x 10"h)
1045028
"Fire Safes" Hanging Sign (21"w x 10"h)
1045029
"Floor Safes" Hanging Sign (21"w x 10"h)
1045030
"Depository Safes" Hanging Sign (21"w x 10"h)
1045134
"Wall Safes" Hanging Sign (21"w x 10"h)
1045133
"Gun Safes" Hanging Sign (21"w x 10"h)
1015241
Authorized Dealer Window Decal
1045073
Guide to Safe Usage Poster (24"w x 18"h)
4305127
Retail Price List
4305128
Guide to All Products Brochure (color 4 x 9)
1045129
Dealer Catalog (8½ x 11)
4305172
Gun Safe Brochure
4305222
Gun Safe Mini-Brochure
4305226
Cash Box Trifold / Self-Mailer
4305224
Gun Safe Trifold / Self-Mailer
4305225
Wall Safe Trifold / Self-Mailer
4305238
Storage Cabinets Trifold / Self-Mailer
1045072
Gun Safe Warranty Poster
1045076
BF® Gun Safe Authorized Dealer Banner
1045075
BF® Gun Safe Brochure Holder
1045058
BF® Door Cutaway Plaque
1045071
BF® Body Cutaway Plaque
1045070
AMSEC Color Panel Display
4305174
Warranty/Operating Booklet
1045004
Magnetic Product Tags (6)
1045007
3 pack display only
Gun Safe
Catalog
Part #4305172
46
product
Catalog
Part #4305129
display pedestal
Part #1045014
3-pack display
Part #1045007
BF® safe body
cutaway
Part #1045071
BF® safe door
cutaway
Part #1045071
sales banner
5ft w x 4ft h
Part #1045000
bf® gun safe
brochure holder
Part #1045075
authorized
dealer window
decal
Part #1015241
safe usage poster
(24"w x 18"H)
Part #1045073
retail
price list
Part #4305126
all product
brochure
Part #4305128
Gun Safe “Mini”
brochure
Part #4305222
“Burglary / Fire Safes”
hanging sign (21" w x 10" h)
Part #1045024
amsecusa.com/catalogs/
FEBRUARY, 2009
Product Catalog
American Security Products Co.
A
ACCESS MANAGER . .
ACF2020 . . . . . . . . . . . .
ACF2020XD . . . . . . . . .
ACF3020 . . . . . . . . . . . .
ACF3020XD . . . . . . . . .
ACF4024 . . . . . . . . . . . .
ACF4024XD . . . . . . . . .
ACF4824DS . . . . . . . . .
ACF5024 . . . . . . . . . . . .
ACF5024XD . . . . . . . . .
ACF6030 . . . . . . . . . . . .
ACF6030XD . . . . . . . . .
AM2020 . . . . . . . . . . . . .
AM3020 . . . . . . . . . . . . .
AM4020 . . . . . . . . . . . . .
AUDITCON® . . . . . . . . .
42
32
32
32
32
32
32
33
32
32
32
32
29
29
29
42
B
B1500 . . . . . . . . . . . . . . . 5
B17 . . . . . . . . . . . . . . . . . 7
B1806 . . . . . . . . . . . . . . . 5
B1810 . . . . . . . . . . . . . . . 5
B1816 . . . . . . . . . . . . . . . 5
B1816D . . . . . . . . . . . . . . 5
B2200 . . . . . . . . . . . . . . . 5
B24 . . . . . . . . . . . . . . . . . 7
B2900 . . . . . . . . . . . . . . . 5
B3700 . . . . . . . . . . . . . . . 5
B3800 . . . . . . . . . . . . . . . 5
B400 . . . . . . . . . . . . . . . . 5
B5800 . . . . . . . . . . . . . . . 5
B6 . . . . . . . . . . . . . . . . . . 7
B700 . . . . . . . . . . . . . . . . 5
BD24 . . . . . . . . . . . . . . . . 7
BDP24 . . . . . . . . . . . . . . . 7
BF1512 . . . . . . . . . . . . . 18
BF1716 . . . . . . . . . . . . . 18
BF2116 . . . . . . . . . . . . . 18
BF3416 . . . . . . . . . . . . . 18
BF6030 . . . . . . . . . . . . . 24
BF6032 . . . . . . . . . . . . . 24
BF6636 . . . . . . . . . . . . . 24
BF7240 . . . . . . . . . . . . . 24
BF7250 . . . . . . . . . . . . . 24
BLB2018 . . . . . . . . . . . . 15
BLB3018 . . . . . . . . . . . . 15
BLB3024 . . . . . . . . . . . . 15
BLB4024 . . . . . . . . . . . . 15
BLC2018 . . . . . . . . . . . . 15
BLC3018 . . . . . . . . . . . . 15
BLC3024 . . . . . . . . . . . . 15
BLC4024 . . . . . . . . . . . . 15
BSW2020 . . . . . . . . . . . 10
BSW2025 . . . . . . . . . . .
BSW3020 . . . . . . . . . . .
BSW3025 . . . . . . . . . . .
BSW4020 . . . . . . . . . . .
BSW4025 . . . . . . . . . . .
BWB2020 . . . . . . . . . . .
BWB2020 . . . . . . . . . . .
BWB2025 . . . . . . . . . . .
BWB3020 . . . . . . . . . . .
BWB3020 . . . . . . . . . . .
BWB3025 . . . . . . . . . . .
BWB3025 . . . . . . . . . . .
BWB4020 . . . . . . . . . . .
BWB4020 . . . . . . . . . . .
BWB4025 . . . . . . . . . . .
BWB4025 . . . . . . . . . . .
10
10
10
10
10
11
14
11
11
14
11
14
11
14
11
14
C
C3 . . . . . . . . . . . . . . . . . . 6
C5 . . . . . . . . . . . . . . . . . . 6
C7 . . . . . . . . . . . . . . . . . . 6
CB10 . . . . . . . . . . . . . . . 22
CB23 . . . . . . . . . . . . . . . 22
CD5 . . . . . . . . . . . . . . . . . 6
CD7 . . . . . . . . . . . . . . . . . 6
CDXE . . . . . . . . . . . . . . 31
CDXF . . . . . . . . . . . . . . . 31
CE1814 . . . . . . . . . . . . . 35
CE2518 . . . . . . . . . . . . . 35
CE3524 . . . . . . . . . . . . . 35
CE4524 . . . . . . . . . . . . . 35
CE5524 . . . . . . . . . . . . . 35
CE6528 . . . . . . . . . . . . . 35
CE7236 . . . . . . . . . . . . . 35
CF1814 . . . . . . . . . . . . . 35
CF2518 . . . . . . . . . . . . . 35
CF3524 . . . . . . . . . . . . . 35
CF4524 . . . . . . . . . . . . . 35
CF5524 . . . . . . . . . . . . . 35
CF6528 . . . . . . . . . . . . . 35
CF7236 . . . . . . . . . . . . . 35
CSC1413 . . . . . . . . . . . . 17
CSC1913 . . . . . . . . . . . . 17
CSC3018 . . . . . . . . . . . . 17
CSC4520 . . . . . . . . . . . . 17
22
12
12
12
12
12
31
31
E
ES1014 . . . . . . . . . . . . .
ES149 . . . . . . . . . . . . . .
ES1814 . . . . . . . . . . . . .
ES2014 . . . . . . . . . . . . .
ES412 . . . . . . . . . . . . . .
ES813 . . . . . . . . . . . . . .
ES813 . . . . . . . . . . . . . .
ES914 . . . . . . . . . . . . . .
ES916 . . . . . . . . . . . . . .
ESL10XL . . . . . . . . . . . .
ESL20XL . . . . . . . . . . . .
22
21
21
22
29
22
22
21
22
41
41
F
FS149 . . . . . . . . . . . . . .
FS2215 . . . . . . . . . . . . .
FS3018 . . . . . . . . . . . . .
FS4622 . . . . . . . . . . . . .
FS712 . . . . . . . . . . . . . .
FS914 . . . . . . . . . . . . . .
21
21
21
21
21
21
H
HC1854 . . . . . . . . . . . . .
HR916E . . . . . . . . . . . . .
HRC916E . . . . . . . . . . .
HS6743 . . . . . . . . . . . . .
HS7943 . . . . . . . . . . . . .
28
16
16
23
23
K
K-1 / K2 . . . . . . . . . . . . . . 8
KB20 . . . . . . . . . . . . . . . 22
KB93 . . . . . . . . . . . . . . . 22
L
LG BASIC II . . . . . . . . . . 43
M
D
DSC2014 . . . . . . . . . . . .
DSC2014KC . . . . . . . . .
DSF2014 . . . . . . . . . . . .
DSF2014 . . . . . . . . . . . .
DSF2714 . . . . . . . . . . . .
DSF2731 . . . . . . . . . . . .
DSF3214 . . . . . . . . . . . .
DSR2014 . . . . . . . . . . . .
DSR2014 . . . . . . . . . . . .
DSR2714 . . . . . . . . . . . .
DST2014 . . . . . . . . . . . .
DST2714 . . . . . . . . . . . .
DST2731 . . . . . . . . . . . .
DST3214 . . . . . . . . . . . .
DXE . . . . . . . . . . . . . . . .
DXF . . . . . . . . . . . . . . . .
22
12
12
22
12
12
12
12
MM2820 . . . . . . . . . . . . 13
MS1414 . . . . . . . . . . . . . 14
S
S&G 6120 . . . . . . . . . . .
SAFEGARD . . . . . . . . . .
SafeWizard® . . . . . . . . .
SF5924 . . . . . . . . . . . . .
SF6030 . . . . . . . . . . . . .
SF6032 . . . . . . . . . . . . .
SF6036 . . . . . . . . . . . . .
SMARTLINC . . . . . . . . .
STORAGE CABINET . .
SWVV1014 . . . . . . . . . .
42
43
40
26
26
26
26
43
45
29
T
T425 . . . . . . . . . . . . . . . . 7
T625 . . . . . . . . . . . . . . . . 7
T625DD . . . . . . . . . . . . . . 7
T925 . . . . . . . . . . . . . . . . 7
T925DD . . . . . . . . . . . . . . 7
TB0610 . . . . . . . . . . . . . . 8
TB0612 . . . . . . . . . . . . . . 8
TB1210 . . . . . . . . . . . . . . 8
TF5517 . . . . . . . . . . . . . 27
TF5924 . . . . . . . . . . . . . 27
TF6030 . . . . . . . . . . . . . 27
TF6032 . . . . . . . . . . . . . 27
TF6036 . . . . . . . . . . . . . 27
INDEX BY MODEL NUMBER
INDEX BY MODEL NUMBER
U
UL1511 . . . . . . . . . . . . .
UL1812 . . . . . . . . . . . . .
UL1812XD . . . . . . . . . . .
UL2018 . . . . . . . . . . . . .
UL2818 . . . . . . . . . . . . .
UL3918 . . . . . . . . . . . . .
US2015C . . . . . . . . . . . .
19
19
19
19
19
19
14
V
VD8030 . . . . . . . . . . . . . 28
W
WES149 . . . . . . . . . . . . .
WES2114 . . . . . . . . . . . .
WFS149 . . . . . . . . . . . . .
WS1014 . . . . . . . . . . . . . .
WS1214 . . . . . . . . . . . . . .
WS1514 . . . . . . . . . . . . . .
WS1814 . . . . . . . . . . . . . .
9
9
9
9
9
9
9
P
PB2 . . . . . . . . . . . . . . . . 29
R
RF6528 . . . . . . . . . . . . . 23
47
Part #1045129
Revision 03/09
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
