Vector Network Analyzer ¸ZVB
December
2007
Data sheet
Titel+Rueck_ZVB_Specs_en.indd 1
13.12.2007 08:42:18
MEASUREMENT RANGE .........................................................................................................................................................................3
MEASUREMENT SPEED ..........................................................................................................................................................................5
MEASUREMENT ACCURACY..................................................................................................................................................................6
EFFECTIVE SYSTEM DATA .....................................................................................................................................................................9
TEST PORT OUTPUT..............................................................................................................................................................................10
TEST PORT INPUT..................................................................................................................................................................................13
ADDITIONAL FRONT PANEL CONNECTORS ......................................................................................................................................14
DISPLAY ..................................................................................................................................................................................................14
REAR PANEL CONNECTORS................................................................................................................................................................14
OPTIONS .................................................................................................................................................................................................16
GENERAL DATA .....................................................................................................................................................................................17
ORDERING INFORMATION....................................................................................................................................................................18
2
®
R&S ZVB Vector Network Analyzer
Version 07.00, December 2007
Specifications apply under the following conditions:
90 minutes warm-up time at ambient temperature, specified environmental conditions met, calibration cycle adhered to, and all internal
adjustments performed. Data designated „overrange“ and data without tolerances: typical values only. Unless stated otherwise,
specifications apply to test ports and a nominal source power of –10 dBm.
Measurement range
Impedance
Test port connector
Number of test ports
Frequency range
Static frequency accuracy
Frequency resolution
Number of measurement points
Measurement bandwidths
®
Dynamic range of the R&S ZVB4 two-port
®
model and the R&S ZVB8 two-port model
(without optional step attenuators)
®
®
R&S ZVB4 and R&S ZVB8
®
®
R&S ZVB14 and R&S ZVB20
®
R&S ZVB4
®
R&S ZVB8
®
R&S ZVB14
®
R&S ZVB20
without optional oven quartz
with optional oven quartz
50 Ω
type N, female
3.5 mm, male
2 or 4
300 kHz to 4 GHz
300 kHz to 8 GHz
10 MHz to 14 GHz
10 MHz to 20 GHz
–6
8 × 10
–7
1 × 10
1 Hz
2 to 20001
1 Hz to 500 kHz
per trace
1/2/5 steps
from PORT 1 to PORT 2
300 kHz to 5 MHz
>80 dB, typ. 100 dB
5 MHz to 100 MHz
>100 dB, typ. 120 dB
100 MHz to 4 GHz
>120 dB, typ. 130 dB
®
4 GHz to 7 GHz (R&S ZVB8 only)
>117 dB, typ. 127 dB
®
7 GHz to 7.5 GHz (R&S ZVB8 only)
>115 dB, typ. 120 dB
®
>108 dB, typ. 118 dB
7.5 GHz to 8 GHz (R&S ZVB8 only)
®
Dynamic range of the R&S ZVB4 four-port from PORT 1 to PORT 2 and
®
model and the R&S ZVB8 four-port model from PORT 3 to PORT 4 (for four-port
(without optional step attenuators)
models only)
300 kHz to 5 MHz
>80 dB, typ. 100 dB
5 MHz to 100 MHz
>100 dB, typ. 120 dB
100 MHz to 500 MHz
>120 dB, typ. 130 dB
500 MHz to 4 GHz
>123 dB, typ. 130 dB
®
4 GHz to 7 GHz (R&S ZVB8 only)
>120 dB, typ. 130 dB
®
7 GHz to 7.5 GHz (R&S ZVB8 only)
>115 dB, typ. 125 dB
®
>108 dB, typ. 125 dB
7.5 GHz to 8 GHz (R&S ZVB8 only)
®
Dynamic range of the R&S ZVB14
from PORT 1 to PORT 2 and
from PORT 3 to PORT 4 (for four-port
model only)
10 MHz to 100 MHz
>80 dB, typ. 110 dB
100 MHz to 700 MHz
>100 dB, typ. 130 dB
700 MHz to 8 GHz
>120 dB, typ. 133 dB
8 GHz to 14 GHz
>110 dB, typ. 122 dB
®
Dynamic range of the R&S ZVB20
from PORT 1 to PORT 2 and
from PORT 3 to PORT 4 (for four-port
model only)
10 MHz to 100 MHz
>80 dB, typ. 110 dB
100 MHz to 700 MHz
>100 dB, typ. 130 dB
700 MHz to 8 GHz
>120 dB, typ. 133 dB
8 GHz to 20 GHz
>110 dB, typ. 122 dB
The dynamic range is defined as the difference between the actually available maximum source power and the rms value of the data
trace of the transmission magnitude, which is produced by noise and crosstalk with the test ports short-circuited. The specification
applies at 10 Hz measurement bandwidth and without system error correction. The dynamic range can be increased by using a
measurement bandwidth of 1 Hz.
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
3
®
Dynamic range in dB versus frequency in GHz of the R&S ZVB4
®
Dynamic range in dB versus frequency in GHz of the R&S ZVB8
®
®
Dynamic range in dB versus frequency in GHz of the R&S ZVB14 (up to 14 GHz) and the R&S ZVB20
4
®
R&S ZVB Vector Network Analyzer
Version 07.00, December 2007
Measurement speed
Measurement time
Measurement time per point
Data transfer time
Time for measurement and data transfer
Switching time between channels
Switching time between two preloaded
instrument settings
for 201 measurements points, with span
100 MHz, 500 kHz measurement
bandwidth, ALC and display switched off
with center frequency 1.1 GHz
with center frequency 5.1 GHz
500 kHz measurement bandwidth,
CW mode
for 201 measurements points
via IEC/IEEE bus
via VX11 over 100 Mbit/s LAN
via RSIB over 100 Mbit/s LAN
for 201 measurements points, with start
frequency 1 GHz, stop frequency 1.1 GHz,
500 kHz measurement bandwidth, and
display switched off
(No additional time for data transfer is
needed, as this occurs simultaneously
during the measurement.)
with no more than 2001 points
with no more than 2001 points
<6 ms
<4.5 ms
<4.5 µs
<2.9 ms
<1.3 ms
<0.7 ms
<6 ms
<1 ms
<10 ms
Typical sweep times versus number of measurement points
Number of measurement points
51
101
801
1601
Start frequency 5 GHz, stop frequency 5.2 GHz, ALC off, and a measurement bandwidth of 100 kHz
With full one-port calibration or
with correction switched off
2.4 ms
3.9 ms
6.3 ms
11 ms
With TOSM calibration
4.7 ms
8.6 ms
16.4 ms
32.4 ms
20.4 ms
65 ms
40.2 ms
170 ms
Start frequency 6 GHz, stop frequency 8 GHz, ALC off, and a measurement bandwidth of 100 kHz
With full one-port calibration or
with correction switched off
3.4 ms
6.2 ms
11 ms
17.3 ms
With TOSM calibration
5.3 ms
9.8 ms
18 ms
33 ms
28.2 ms
63 ms
49 ms
160 ms
®
201
401
®
®
®
Start frequency 10 MHz, stop frequency 4 GHz (R&S ZVB4), 8 GHz (R&S ZVB8), 14 GHz (R&S ZVB14), or 20 GHz (R&S ZVB20),
ALC off, and a measurement bandwidth of 100 kHz
With full one-port calibration or
with correction switched off
8.4 ms
12.6 ms
19.5 ms
30.5 ms
53.2 ms
88.2 ms
With TOSM calibration
10.3 ms
16.6 ms
28 ms
47 ms
81 ms
190 ms
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
5
Measurement accuracy
This data is valid between +18 °C and +28 °C, provided the temperature has not varied by more than 1 K after calibration. Validity of
the data is conditional on the use of a suitable calibration kit. This calibration kit is used to achieve the effective system data specified
below. Frequency points, measurement bandwidth, and sweep time have to be identical for measurement and calibration (no
interpolation allowed).
Accuracy of transmission measurements
®
®
R&S ZVB4 and R&S ZVB8
300 kHz to 1 MHz
+15 dB to –45 dB
<1 dB or <6°
1 MHz to 50 MHz
+15 dB to –30 dB
<0.2 dB or <2°
–30 dB to –45 dB
<1 dB or <6°
Above 50 MHz
+15 dB to +5 dB
<0.2 dB or <2°
+5 dB to –55 dB
<0.1 dB or <1°
–55 dB to –70 dB
<0.2 dB or <2°
–70 dB to –85 dB
<1 dB or <6°
®
®
R&S ZVB14 and R&S ZVB20
10 MHz to 50 MHz
+15 dB to –30 dB
<1 dB or <6°
50 MHz to 400 MHz
+15 dB to –30 dB
<0.2 dB or <2°
–30 dB to –45 dB
<1 dB or <6°
400 MHz to 700 MHz
+15 dB to +5 dB
<0.2 dB or <2°
+5 dB to –35 dB
<0.1 dB or <1°
–35 dB to –50 dB
<0.2 dB or <2°
–50 dB to –65 dB
<1 dB or <6°
700 MHz to 8 GHz
+15 dB to +5 dB
<0.2 dB or <2°
+5 dB to –55 dB
<0.1 dB or <1°
–55 dB to –70 dB
<0.2 dB or <2°
–70 dB to –85 dB
<1 dB or <6°
Above 8 GHz
+15 dB to +5 dB
<0.2 dB or <2°
+5 dB to –35 dB
<0.1 dB or <1°
–35 dB to –50 dB
<0.2 dB or <2°
–50 dB to –65 dB
<1 dB or <6°
Specifications are based on a matched DUT, a measurement bandwidth of 10 Hz, and a nominal source power of –10 dBm.
Magnitude
Phase
1
0.1
0.01
0
100
Uncertainty in deg
Uncertainty in dB
10
-20
-40
-60
-80
Transmission coefficient in dB
-100
10
1
0.1
0
-20
-40
-60
-80
-100
Transmission coefficient in dB
Typical accuracy of transmission magnitude and transmission phase measurements
®
®
of the R&S ZVB4 and the R&S ZVB8 in the frequency range from 300 kHz to 4 GHz
6
®
R&S ZVB Vector Network Analyzer
Version 07.00, December 2007
Phase
Magnitude
100
Uncertainty in deg
Uncertainty in dB
10
1
0.1
10
1
0.1
0.01
0
-20
-40
-60
-80
0
-100
-20
-40
-60
-80
-100
Transmission coefficient in dB
Transmission coefficient in dB
Typical accuracy of transmission magnitude and transmission phase measurements
®
of the R&S ZVB8 in the frequency range from 4 GHz to 8 GHz
Magnitude
Phase
100
Uncertainty in deg
Uncertainty in dB
10
1
0.1
10
1
0.1
0.01
0
-20
-40
-60
-80
0
-100
-20
-40
-60
-80
-100
Transmission coefficient in dB
Transmission coefficient in dB
®
®
Typical accuracy of transmission magnitude and transmission phase measurements of the R&S ZVB14 and the R&S ZVB20
in the frequency range from 10 MHz to 700 MHz
Magnitude
Phase
Phase
Magnitude
U n c e r ta in ty / d e g
1
0.1
0.01
0
100
10
Uncertainty in deg
Uncertainty in dB
U n certain ty / d B
10
-20
-40
-60
-80
Transmission
/ dB
Transmission Coefficient
coefficient in
dB
-100
1
0.1
0
-20
-40
-60
-80
-100
Transmission
Transmissioncoefficient
Coefficientin/ dB
dB
®
Typical accuracy of transmission magnitude and transmission phase measurements of the R&S ZVB14 (in the frequency range from
®
700 MHz to 14 GHz) and the R&S ZVB20 (in the frequency range from 700 MHz to 20 GHz)
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
7
Accuracy of reflection measurements
®
®
R&S ZVB4 and R&S ZVB8
Above 300 kHz
®
+10 dB to +3 dB
+3 dB to –15 dB
–15 dB to –25 dB
–25 dB to –35 dB
<0.6 dB or <4°
<0.4 dB or <3°
<1 dB or <6°
<3 dB or <20°
®
R&S ZVB14 and R&S ZVB20
10 MHz to 50 MHz
+3 dB to –15 dB
<1 dB or <6°
–15 dB to –25 dB
<3 dB or <20°
Above 50 MHz
+10 dB to +3 dB
<0.6 dB or <4°
+3 dB to –15 dB
<0.4 dB or <3°
–15 dB to –25 dB
<1 dB or <6°
–25 dB to –35 dB
<3 dB or <20°
Specifications are based on an isolating DUT, a measurement bandwidth of 10 Hz, and a nominal source power of –10 dBm.
Phase
10
0.05
Uncertainty in deg
Uncertainty (linear)
Magnitude
0.04
0.03
0.02
0.01
0.00
0
0.2
0.4
0.6
0.8
1
8
6
4
2
0
0
Reflection coefficient (linear)
0.2
0.4
0.6
0.8
1
Reflection coefficient (linear)
Typical accuracy of reflection magnitude and reflection phase measurements
®
of the R&S ZVB4 in the frequency range from 300 kHz to 4 GHz,
®
of the R&S ZVB8 in the frequency range from 300 kHz to 8 GHz,
®
of the R&S ZVB14 in the frequency range from 50 MHz to 14 GHz,
®
and of the R&S ZVB20 in the frequency range from 50 MHz to 20 GHz
Trace stability
Trace noise of S11 (rms)
Temperature dependence
8
®
R&S ZVB Vector Network Analyzer
at 0 dBm source power, 0 dB reflection,
and 1 kHz measurement bandwidth
®
®
R&S ZVB4 and R&S ZVB8
above 300 kHz
®
®
R&S ZVB14 and R&S ZVB20
700 MHz to 8 GHz
above 8 GHz
at 0 dB transmission or reflection
<0.004 dB, typ. 0.001 dB
<0.004 dB, typ. 0.001 dB
<0.015 dB, typ. 0.004 dB
<0.05 dB/K or <0.4°/K
Version 07.00, December 2007
Effective system data
This data is valid between +18 °C and +28 °C, provided the temperature has not varied by more than 1 K after calibration. The data is
based on a measurement bandwidth of 10 Hz and system error calibration by means of a suitable calibration kit. Frequency points,
measurement bandwidth, and sweep time have to be identical for measurement and calibration (no interpolation allowed).
®
®
R&S ZVB4 and R&S ZVB8
Directivity
Source match
Reflection tracking
Load match
Transmission tracking
®
300 kHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
300 kHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
300 kHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
300 kHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
300 kHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
>46 dB, typ. 50 dB
>40 dB, typ. 50 dB
>40 dB, typ. 46 dB
>36 dB, typ. 40 dB
<0.04 dB, typ. 0.01 dB
<0.1 dB, typ. 0.01 dB
>46 dB, typ. 50 dB
>40 dB, typ. 46 dB
<0.06 dB, typ. 0.01 dB
<0.1 dB, typ. 0.05 dB
10 MHz to 700 MHz
above 700 MHz
10 MHz to 700 MHz
above 700 MHz
10 MHz to 700 MHz
above 700 MHz
10 MHz to 700 MHz
above 700 MHz
10 MHz to 700 MHz
above 700 MHz
>36 dB, typ. 40 dB
>40 dB, typ. 50 dB
>30 dB, typ. 48 dB
>30 dB, typ. 48 dB
<0.3 dB, typ. 0.05 dB
<0.3 dB, typ. 0.05 dB
>36 dB, typ. 40 dB
>40 dB, typ. 50 dB
<0.2 dB, typ. 0.1 dB
<0.1 dB, typ. 0.05 dB
®
R&S ZVB14 and R&S ZVB20
Directivity
Source match
Reflection tracking
Load match
Transmission tracking
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
9
Test port output
Power range
(without optional step attenuators)
®
®
R&S ZVB4 and R&S ZVB8
300 kHz to 50 MHz
50 MHz to 4 GHz
®
4 GHz to 7 GHz (R&S ZVB8 only)
®
7 GHz to 8 GHz (R&S ZVB8 only)
®
®
R&S ZVB14 and R&S ZVB20
10 MHz to 13 GHz
above 13 GHz
Power accuracy
(with ALC on and
without power calibration)
Power linearity
Power resolution
Harmonics
(output power referenced to maximum
specified output power)
10
®
R&S ZVB Vector Network Analyzer
®
–30 dBm to +10 dBm,
typ. –40 dBm to +15 dBm
–30 dBm to +5 dBm,
typ. –40 dBm to +10 dBm
®
R&S ZVB4 and R&S ZVB8
at –10 dBm
in temperature range +18 °C to +28 °C
above 50 MHz
®
®
R&S ZVB14 and R&S ZVB20
at –10 dBm
in temperature range +18 °C to +28 °C
above 50 MHz
referenced to –10 dBm
in temperature range +18 °C to +28 °C
®
®
R&S ZVB4 and R&S ZVB8
above 50 MHz
®
®
R&S ZVB14 and R&S ZVB20
above 500 MHz
®
–40 dBm to +10 dBm,
typ. –45 dBm to +14 dBm
–40 dBm to +13 dBm,
typ. –45 dBm to +15 dBm
–40 dBm to +10 dBm,
typ. –45 dBm to +13 dBm
–40 dBm to +8 dBm,
typ. –45 dBm to +12 dBm
<2 dB
<0.8 dB, typ. 0.3 dB
<3 dB
<0.8 dB, typ. 0.3 dB
<2 dB
<0.8 dB, typ. 0.2 dB
<0.8 dB, typ. 0.2 dB
0.01 dB
®
R&S ZVB4 and R&S ZVB8
300 kHz to 50 MHz at –3 dB
50 MHz to 4 GHz at –5 dB
®
4 GHz to 7 GHz at –2 dB (R&S ZVB8)
®
7 GHz to 8 GHz at 0 dB (R&S ZVB8)
®
®
R&S ZVB14 and R&S ZVB20
10 MHz to 50 MHz at –3 dB
50 MHz to 13 GHz at 0 dB
above 13 GHz at 0 dB
typ. <–30 dBc
<–20 dBc, typ. <–30 dBc
<–20 dBc, typ. <–30 dBc
<–20 dBc, typ. <–30 dBc
typ. <–30 dBc
<–20 dBc, typ. <–30 dBc
<–20 dBc, typ. <–30 dBc
Version 07.00, December 2007
®
Maximum output power in dBm versus frequency in GHz of the R&S ZVB4
®
Maximum output power in dBm versus frequency in GHz of the R&S ZVB8
®
®
Maximum output power in dBm versus frequency in GHz of the R&S ZVB14 (up to 14 GHz) and the R&S ZVB20
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
11
®
Output power accuracy in dB versus frequency in GHz of the R&S ZVB4
®
Output power accuracy in dB versus frequency in GHz of the R&S ZVB8
®
®
Output power accuracy in dB versus frequency in GHz of the R&S ZVB14 (up to 14 GHz) and the R&S ZVB20
12
®
R&S ZVB Vector Network Analyzer
Version 07.00, December 2007
Test port input
Match
Maximum nominal input level
Power measurement accuracy
Receiver linearity
Damage level
Damage DC voltage
Noise level
without system error correction
®
R&S ZVB4
300 kHz to 4 GHz
®
R&S ZVB8
300 kHz to 7 GHz
7 GHz to 8 GHz
®
®
R&S ZVB14 and R&S ZVB20
10 MHz to 50 MHz
50 MHz to 2 GHz
above 2 GHz
®
®
R&S ZVB4 and R&S ZVB8
®
®
R&S ZVB14 and R&S ZVB20
10 MHz to 8 GHz
above 8 GHz
at –10 dBm without power calibration
in temperature range +18 °C to +28 °C
10 MHz to 8 GHz
above 8 GHz
®
®
(R&S ZVB14 and R&S ZVB20 only)
referenced to –10 dBm
in temperature range +18 °C to +28 °C
®
®
R&S ZVB4 and R&S ZVB8
for +20 dB to –60 dB
50 MHz to 4 GHz
®
4 GHz to 6 GHz (R&S ZVB8 only)
®
6 GHz to 8 GHz (R&S ZVB8 only)
®
®
R&S ZVB14 and R&S ZVB20
for +20 dB to –30 dB
50 MHz to 700 MHz
for +20 dB to +10 dB
700 MHz to 8 GHz
for +15 dB to +10 dB
above 8 GHz
for +10 dB to –45 dB
above 700 MHz
at 10 Hz measurement bandwidth
®
®
R&S ZVB4 and R&S ZVB8
300 kHz to 100 MHz
100 MHz to 4 GHz
®
4 GHz to 8 GHz (R&S ZVB8 only)
®
®
R&S ZVB14 and R&S ZVB20
100 MHz to 700 MHz
700 MHz to 8 GHz
above 8 GHz
The noise level is defined as the rms value of the specified noise floor.
Version 07.00, December 2007
>16 dB
>16 dB
>14 dB
>10 dB
>12 dB
>8 dB
+13 dBm
+10 dBm
0 dBm
<1 dB
<2 dB
<0.1 dB
<0.1 dB
<0.2 dB
<0.1 dB
<0.3 dB
<0.3 dB
<0.1 dB
+27 dBm
30 V
<–70 dBm
<–110 dBm
<–105 dBm
<–70 dBm
<–105 dBm
<–100 dBm
®
R&S ZVB Vector Network Analyzer
13
Additional front panel connectors
USB
(two) universal serial bus connectors for connecting USB devices (USB 1.1);
two additional USB connectors at the rear panel
Display
Screen
Resolution
21 cm (8.4") diagonal color LCD
800 × 600 × 262144 (high color)
Rear panel connectors
IEC BUS
remote control in line with IEEE488, IEC60625; 24 pins
LAN 1
first local area network connector, 8 pins, RJ-45
LAN 2
second local area network connector, 8 pins, RJ-45
USB
(two) universal serial bus connectors for connecting USB devices (USB 1.1);
two additional USB connectors at the front panel
10 MHz REF
Connector type
Input frequency
Maximum permissible deviation
Input power
altenatively input or output for external frequency reference signal
BNC, female
10 MHz
1 kHz
0 dBm ±3 dB
Input impedance
50 Ω
10 MHz
80 Hz
Output frequency
Output frequency accuracy
Output power
DC MEAS 1 V
Connector type
Voltage range
Measurement accuracy
Resolution
Sample rate
Input impedance
–3 dBm ±8 dB at 50 Ω
DC measurement input
4-pin mini DIN, female
–1 V to +1 V
2.5 % of reading + 2.5 mV
12 bits
3 MHz
>10 kΩ
30 V
Damage voltage
DC MEAS 10 V
Connector type
Voltage range
Measurement accuracy
Resolution
Sample rate
Input impedance
Damage voltage
14
®
R&S ZVB Vector Network Analyzer
DC measurement input
4-pin mini DIN, female
–10 V to +10 V
2.5 % of reading + 25 mV
12 bits
3 MHz
>10 kΩ
30 V
Version 07.00, December 2007
PORT BIAS
Connector type
Maximum nominal input voltage
Maximum nominal input current
Damage voltage
Damage current
DC bias input for PORT
MONITOR
IBM-PC-compatible VGA monitor connector, 15-pin D-Sub (for external monitor)
USER CONTROL
several control and trigger signals, 25-pin D-Sub, 3.3 V TTL
for controlling external generators, for limit checks, sweep signals, etc
pin 24 and pin 25 (inputs)
control inputs
pin 16 to pin 19 (outputs)
indicate driving port
pin 8 to pin 11 (outputs)
channel-specific user-configurable bits
pin 13 and pin 14 (outputs)
pass/fail results of limit checks
pin 4 (output)
measurements running
pin 6 (output)
ready for trigger
pin 21 (output)
control signal for external generator
pin 22 (input)
handshake signal from external generator
pin 2 (input)
trigger input for analyzer
FOOT SWITCH 1 and FOOT SWITCH 2
DRIVE PORT 1 to DRIVE PORT 4
CHANNEL BIT 0 to CHANNEL BIT 3
PASS 1 and PASS 2
BUSY
READY FOR TRIGGER
EXT GEN TRIGGER
EXT GEN BLANK
EXTERNAL TRIGGER
EXT TRIGGER
Connector type
TTL signal (edge-triggered)
Polarity (selectable)
Minimum pulse width
Input impedance
Version 07.00, December 2007
BNC, female
30 V
200 mA
30 V
500 mA
trigger input for analyzer
BNC, female
3V
positive or negative
1 µs
>10 kΩ
®
R&S ZVB Vector Network Analyzer
15
Options
Generator step attenuators
Frequency range
Power range
Power accuracy
Power linearity
Match
Receiver linearity
Dynamic range
Direct generator/receiver access
Frequency range
Dynamic range
Power range
Match
Noise level
16
®
R&S ZVB Vector Network Analyzer
®
®
extend the lower limit of the output power range of the R&S ZVB4 or the R&S ZVB8 by
70 dB
®
300 kHz to 4 GHz
R&S ZVB4
®
300 kHz to 8 GHz
R&S ZVB8
upper limit is reduced by 8 dB,
lower limit is extended by 70 dB
at –10 dBm without power calibration
identical to specifications
without optional step attenuators
above –30 dBm
identical to specifications
without optional step attenuators
–30 dBm to –70 dBm
<2 dB
–70 dBm to –100 dBm
<3 dB
without system error correction
®
R&S ZVB4
300 kHz to 2 GHz
>14 dB
2 GHz to 4 GHz
>16 dB
®
R&S ZVB8
300 kHz to 2 GHz
>14 dB
2 GHz to 7 GHz
>16 dB
7 GHz to 8 GHz
>14 dB
referenced to –10 dBm
in temperature range +18 °C to +28 °C
for +13 dB (typ. +20 dB) to –60 dB
50 MHz to 4 GHz
<0.1 dB
4 GHz to 6 GHz
<0.1 dB
6 GHz to 8 GHz
<0.2 dB
is reduced by 8 dB
These options permit direct access to the internal source output as well as to the
internal reference and measurement receiver inputs via the front panel connectors
®
®
(SMA) of the R&S ZVB14 or the R&S ZVB20.
®
10 MHz to 14 GHz
R&S ZVB14
®
10 MHz to 20 GHz
R&S ZVB20
®
R&S ZVB14
10 MHz to 13 GHz
is reduced by 2 dB
13 GHz to 14 GHz
is reduced by 4 dB
®
R&S ZVB20
10 MHz to 13 GHz
is reduced by 2 dB
13 GHz to 20 GHz
is reduced by 4 dB
®
R&S ZVB14
10 MHz to 13 GHz
upper limit is reduced by 1 dB
13 GHz to 14 GHz
upper limit is reduced by 2 dB
®
R&S ZVB20
10 MHz to 13 GHz
upper limit is reduced by 1 dB
13 GHz to 20 GHz
upper limit is reduced by 2 dB
®
R&S ZVB20
16 GHz to 20 GHz
is reduced by 1 dB
®
R&S ZVB14
10 MHz to 13 GHz
13 GHz to 14 GHz
®
R&S ZVB20
10 MHz to 13 GHz
13 GHz to 20 GHz
is increased by 1 dB
is increased by 2 dB
is increased by 1 dB
is increased by 2 dB
Version 07.00, December 2007
General data
Temperature loading
operating temperature range
storage temperature range
Damp heat
Mechanical resistance
vibration, sinusoidal
vibration, random
shock
Calibration interval
EMC
RF emission
other emissions and immunity
Safety
Power supply
Power consumption
Conformity mark
Dimensions (W × H × D)
®
®
Weight
Shipping weight
Version 07.00, December 2007
®
R&S ZVB4 and R&S ZVB8
+5 °C to +40 °C
–40 °C to +70 °C
in line with IEC 60068-2-1 and
IEC 60068-2-2
+40 °C at 95 % rel. humidity,
in line with IEC 60068-2-30
5 Hz to 150 Hz,
in line with IEC 60068-2-6
10 Hz to 300 Hz,
in line with IEC 60068-2-64
40 g shock spectrum,
in line with IEC 60068-2-27, MIL-STD 810
1 year
in line with CISPR 11/EN 55011 group 1
class A for a shielded test setup
in line with IEC/EN 61326,
emission class B (residential
environment),
immunity industrial environment (excluding
operating frequency)
in line with IEC 61010-1, EN61010-1, and
UL 3111-1
100 V to 240 V (AC) with tolerance ±10 %,
50 Hz to 60 Hz with tolerance ±5 %,
safety class I to VDE 411
450 W, typ. 350 W (standby: typ. 10 W)
VDE, GS, CSA, CSA-NRTL/C, CE
465.1 mm × 241.8 mm × 417.0 mm
(18.31 in × 9.52 in × 16.42 in)
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.14 and 11451010.20
®
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.17 and 11451010.23,
or with four ports
®
®
R&S ZVB4 and R&S ZVB8
®
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.14 and 11451010.20
®
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.17 and 11451010.23,
or with four ports
®
®
R&S ZVB4 and R&S ZVB8
®
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.14 and 11451010.20
®
®
R&S ZVB14 and R&S ZVB20
with two ports and order numbers
1145.1010.17 and 11451010.23,
or with four ports
465.1 mm × 241.8 mm × 417.0 mm
(18.31 in × 9.52 in × 16.42 in)
465.1 mm × 286.2 mm × 417.0 mm
(18.31 in × 11.27 in × 16.42 in)
18 kg (40 lb)
16 kg (35 lb)
20 kg (44 lb)
29 kg (64 lb)
30 kg (66 lb)
32 kg (71 lb)
®
R&S ZVB Vector Network Analyzer
17
Ordering information
Designation
Vector Network Analyzer, 4 GHz, 2 ports
Vector Network Analyzer, 4 GHz, 4 ports
Vector Network Analyzer, 8 GHz, 2 ports
Vector Network Analyzer, 8 GHz, 4 ports
Vector Network Analyzer, 14 GHz, 2 ports
Vector Network Analyzer, 14 GHz, 2 ports
Vector Network Analyzer, 14 GHz, 4 ports
Vector Network Analyzer, 20 GHz, 2 ports
Vector Network Analyzer, 20 GHz, 2 ports
Vector Network Analyzer, 20 GHz, 4 ports
Options
Direct generator/receiver access
Direct Generator/Receiver Access for the
®
R&S ZVB14 1145.1010.17 only
Direct Generator/Receiver Access for the
®
R&S ZVB14 1145.1010.19 only
Direct Generator/Receiver Access for the
®
R&S ZVB20 1145.1010.23 only
Direct Generator/Receiver Access for the
®
R&S ZVB20 1145.1010.25 only
Generator step attenuators
®
®
(for the R&S ZVB4 and R&S ZVB8 only)
Generator Step Attenuator for Port 1
Generator Step Attenuator for Port 2
Generator Step Attenuator for Port 3
Time Domain
Mixer and Harmonic Measurements
18
®
R&S ZVB Vector Network Analyzer
Type
®
R&S ZVB4
®
R&S ZVB4
®
R&S ZVB8
®
R&S ZVB8
®
R&S ZVB14
®
R&S ZVB14
®
R&S ZVB14
®
R&S ZVB20
®
R&S ZVB20
®
R&S ZVB20
Order No.
1145.1010.04
1145.1010.06
1145.1010.08
1145.1010.10
1145.1010.14
1145.1010.17
1145.1010.19
1145.1010.20
1145.1010.23
1145.1010.25
®
1164.1240.17
®
1164.1240.19
®
1164.1240.23
®
1164.1240.25
®
1302.5480.02
1302.5073.02
1302.5496.02
1164.1657.02
1164.1592.02
R&S ZVB14-B16
R&S ZVB14-B16
R&S ZVB20-B16
R&S ZVB20-B16
R&S ZVB8-B21
®
R&S ZVB8-B22
®
R&S ZVB8-B23
®
R&S ZVAB-K2
®
R&S ZVB-K3
Version 07.00, December 2007
Version 07.00, December 2007
®
R&S ZVB Vector Network Analyzer
19
Certified Environmental System
ISO 9001
ISO 14001
DQS REG. NO 1954 QM
DQS REG. NO 1954 UM
For product brochure, see PD 0758.1529.12
and www.rohde-schwarz.com
(search term: ZVB)
¸ is a registered trademark of Rohde & Schwarz GmbH & Co. KG · Trade names are trademarks of the owners · Printed in Germany (we)
PD 0758.1529.22 · ¸ZVB · Version 07.00 · December 2007 · Data without tolerance limits is not binding · Subject to change
Certified Quality System
www.rohde-schwarz.com
Europe: +49 1805 12 4242, [email protected]
USA and Canada: +1-888-837-8772, [email protected]
Asia: +65 65 130 488, [email protected]
Titel+Rueck_ZVB_Specs_en.indd 2
13.12.2007 08:42:19
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
