valenatm life

VALENA

TM

LIFE

THE EVOLUTION

THAT TRANSFORMS

YOUR DAILY LIFE

THE

GLOBAL SPECIALIST

IN ELECTRICAL AND DIGITAL BUILDING INFRASTRUCTURES

VALENA LIFE

The evolution that transform your daily life

Drawing from decades of know-how, Legrand’s Valena

Life range is at once timeless and transformative.

With the Valena Life range of products and finishes, you can meet the requirements of all your customers.

VALENA LIFE

The evolution that transform your daily life

Drawing from decades of know-how, Legrand’s Valena

Life range is at once timeless and transformative.

With the Valena Life range of products and finishes, you can meet the requirements of all your customers.

WWW.LEGRAND.COM

INDEX

1. INTRODUCTIONS

- Valena Life Innovation is in progress

- Valena Life Design

- Valena Life freedom of choice

- Valena Life The perfect solution wherever

2. IN’MATIC: NEW MECHANISM

AND INSTALLATION ADVANTAGES

3. TECHONOLGY

- Energy distribution

- Switches

- Lighting controls

- Radio controls

- Multimedia solutions

- Comfort in every situation

- Waterproofness and safety

- Valena MyHOME automation

- Technology and flexibility in the office

- Hotel room management

4. CATALOGUE

2

4

6

14

16

20

22

24

26

30

32

34

36

40

42

44

VALENA LIFE INDEX 1

2

Valena Life

Innovation is in progress

With Valena, Legrand designs new electromechanical and electronic solutions for more and more state of the art systems.

WWW.LEGRAND.COM

Valena mechanism

- Safe

- Reliable

- Performing

New functions

- Comfort

- Communication

- Security

- Wireless

MyHOME

Automation system

VALENA LIFE GENERAL CHARACTERISTICS 3

4

square within a square rationalism contemporary delicacy neutrality

Design

The importance of details

VALENA LIFE renews itself maintaining its sophisticated style and multiplying innovative solutions.

The contemporary design of the new line mirrors actual trends: the square within a square is so delicate in shape and rational in application to satisfy different needs and to easily fit any context.

Lightness at the service of your touch

The modern concave rocker.

The light side of slimness

The backs creates the impression that the product is floating on the wall.

VALENA LIFE GENERAL CHARACTERISTICS

Freedom

of choice

The wide range of cover plate finishes and colours meets aesthetic taste and suits any kind of interior design.

6

The wide range of cover plate finishes and colours meets aesthetic taste and suits any kind of interior design.

WWW.LEGRAND.COM

VALENA LIFE GENERAL CHARACTERISTICS 7

Freedom of choice

Timelessly

Classic

Simple. Subtle.

Finishes that will blend in seamlessly in your environment

8

WHITE

IVORY

PEARL

WHITE-CHROME

IVORY-GOLD

WWW.LEGRAND.COM

WHITE

VALENA LIFE GENERAL CHARACTERISTICS 9

Freedom of choice

Boldy

Expressive

Be daring.

Creative prints and vibrant colors add another dimension to your life.

See where your imagination takes you

10

LINK

LIME

ROYAL IVORY

TERRACOTTA

ADRIA

ROYAL WHITE

LINK

WWW.LEGRAND.COM

VALENA LIFE GENERAL CHARACTERISTICS 11

Freedom of choice

Truly

Contemporary

A modern and refined collection that expertly blends the natural with the industrial, from bold to understated – and everything in between

12

COPPER STYLE

LIGHT WOOD

COPPER STYLE

INOX STYLE

DARK WOOD

WWW.LEGRAND.COM

ALUMINIUM

VALENA LIFE GENERAL CHARACTERISTICS 13

14

Valena Life

The perfect solution wherever

The wide range of proposals meets any expectation, and fits with elegance and simplicity in any room of the residential and tertiary sectors.

More than 150 functions to fit with elegance and simplicity everywhere.

2P+E /USB MIXED SOCKET:

SAVE SPACE

PROGRAMMABLE THERMOSTAT

SWITCHES DIMMERS

ENERGY-SAVING SWITCHES

SOCKET OUTLETS

WWW.LEGRAND.COM

HDMI USB CHARGERS

VALENA LIFE GENERAL CHARACTERISTICS 15

Valena

Safe

Reliable

Robust

PROTECTED CONTACTS

IP2X MECHANISM

No finger contacts with live parts during installation

BIGGER

RELEASE BUTTONS

More comfort to release the cable from automatic terminals

ISOLATED FRAME

Protection against electrical shock and injuries

SHUTTER FOR CHILD

PROTECTION embedded in the mechanism

TEST POINT

Free access without removing the device from the box

Double teeth claw system

16

Detail from one-way switch

1 - More effective grip and better tear resistance

2 - Completely protected claws at the neutral position, to avoid damage to the wires and injuries of the hand during installation

3 - Fast and automatically return to the neutral position

: better performance and maximum quality for sockets and controls

Automatic terminals with coloured cable entry

Fast and tooless: just a few seconds needed to wire the device.

Reliable: longlasting connexion guaranteed.

Taping off: faster and easier than with a screw terminal.

13 mm

Suitable for both rigid and flexible cable.

Protection cover

LED Plug-in

High protection of the device against dust, paint and scratches, even after installation. No need to remove the protection when the product is used before the cover plate installation.

WWW.LEGRAND.COM

Illuminated functions with

LED technology: energy saving, longlasting solution.

VALENA LIFE GENERAL CHARACTERISTICS 17

Valena

Simple

and

The careful design of each component allows the installer to rely on a quick assembly, smoothly and reliable over time.

Faster

BOX

1

MECHANISM

18

INSTALLATION PROCEDURE

1

2

Fix the device into the box

Complete the work by clipping the plate (the screwless cover plate guides you in this process)

Only 2 turns of the screw

Innovative docking system for multi-gang installation

2

PLATE

WWW.LEGRAND.COM

Visual quality of the final seal: perfect alignment of all plates in the covers.

Thanks to an innovative docking system, the support frames can be perfectly and easly joined for multi-gang installation.

The new system guarantees the stability and solidity of the devices during assembly: installation of the plastic cover of the mechanism and the cover plate.

Perfect for installations with both horizontal and vertical orientation

VALENA LIFE GENERAL CHARACTERISTICS 19

Switches

A complete offer for residential and commercial applications

A broad range of solutions to meet all your customer needs.

20

Available in 10AX and 16AX.

TWO WAY

INDICATOR SWITCH

ILLUMINATED TWO GANG

TWO-WAY SWITCH

IP44 PROTECTION

A complete weatherproof range whenever an IP 44 protection index is required.

Plug-in LED for luminous functions

Led technology ensures high reliability, long life and energy saving

LIGHTING

CONTROL

WWW.LEGRAND.COM

MOTION

SENSOR

IP44 PLATE

To make all the

In’matic mechanisms IP44

VALENA LIFE GENERAL CHARACTERISTICS 21

22

Lighting

controls

A complete range for every kind of lamp

Different solutions for your comfort, safety, and energy saving.

ENERGY SAVING SWITCH

Is the perfect solution for a child’s room, cellar, corridor, etc.

The light is switched on by the user and goes off automatically when no one is in the room

New dimmers: for an efficient management of all types of load

PUSH DIMMER

2-wire universal dimmer to control and adjust all types of load, LED and CFL included.

Illumination only when needed

1000W DIMMER

WITH 5 STATUS LED

Can be associated with push-buttons. Memorises previous light level used.

MOTION SENSOR

To manage lighting without waste in the residential and tertiary sectors.

SKIRTING LIGHT

WITH MOTION SENSOR

Light up the path authomatically when somebody is passing.

TIMER SWITCH

Light off after programmable delay.

VALENA LIFE GENERAL CHARACTERISTICS 23

WWW.LEGRAND.COM

24

Multimedia

solutions

All connections at your fingertips

An easy, flexible and High-quality offer.

BLUETOOTH MODULE

The Bluetooth module lets you play your smart phone’s music, directly in your house

DATA, TV AND AUDIO/VIDEO CONNECTIONS

AUDIO/VIDEO

SOCKETS

CONNECTION, ENTERTAINMENT,

AND MULTIMEDIA

A complete range of products dedicated to audio/video connections provides the desired level of entertainment, relax and functionality.

TRIPLE RCA SOCKET

RJ 11 + RJ 45 SOCKET

TV-R-SAT SOCKET HDMI 1.3

HD 15 + 3.5 mm JACK

SOUND DIFFUSION SYSTEM

From the ‘one room’ solution, to the multi-area complete solution.

ONE AREA

SOUND DIFFUSION

Easy to install, full integration inside the wall.

Tuner

Tuner + display

WWW.LEGRAND.COM

BLUETOOTH MODULE

The Bluetooth module lets you play your smart phone’s music, directly in your house

LOUDSPEAKER

A wide choice (flush, false ceilling, invisble one)

VALENA LIFE GENERAL CHARACTERISTICS 25

Valena

TM

Thanks to a wide range of devices,

MyHOME offers simple and efficient solutions to meet the safety, comfort, energy and communication needs of any private home and service sector establishment. Thanks to intelligent and programmable electronic devices, MyHOME makes it possible to access, in a simple and customised way, advanced functions that would be difficult in a traditional electric system.

In addition, its installation modularity and the functional integration of the various devices offer freedom to decide which applications to install immediately, and which in the future, without the need for important structural updates, and with highly effective cost management.

MyHOME can also be integrated with other systems, such as KNX and DALI. Using the appropriate interface, and the TCP/ IP protocol,

MyHOME is capable of managing and supervising the home also remotely, using a fixed telephone line, a mobile phone, or an internet connection.

26

MYHOME_SCREEN10

Thanks to the 10” 16/9 touch screen, users can manage and control the electric system, the multimedia functions (photos, audio, video), and the Internet connection.

POWER SUPPLY

THERMOSTAT

Functions

COMFORT

Light automation

Management of shutters and automations

Scenario activation

LIGHT AND

SHUTTER CONTROL

2 WIRE BUS

BUS 2 FILI

SCENARIO CONTROL LIGHT CONTROL 8-KEY CONTROL

Device for remote control of the functions

WWW.LEGRAND.COM

Internet

VALENA LIFE GENERAL CHARACTERISTICS 27

28

NEW RJ45 TOOLLESS

CONNECTORS

USB CHARGER

Technology and flexibility

in the

office

“Nomadic” working practices and the constant desire to optimize productivity are influencing the way in which office buildings are designed.

An infrastructure is therefore needed for flexible installation of electrical equipment and communication networks at the desired point.

SPECIAL 8 MODULE AND 2x8 MODULE SUPPORTS

With Valena Life plate available in white and aluminium versions.

Flush workstation for commercial buidings

Make the most of the 200 Mosaic functions with Valena Life aesthetics for a functional and compact workstation solution.

Automation system

The Valena offer includes devices which conform to the international standard KNX, which is the most widely used technology for the intelligent management of buildings.

MAIN APPLICATIONS:

- Lighting control

- Shutter/slat controls

1000W DIMMER

For commercial buildings, with 5 status LED.

WWW.LEGRAND.COM

CONTROL KNX

With aesthetic lighting

VALENA LIFE GENERAL CHARACTERISTICS 29

Hotel room management

A complete offer for a state of the art electric system in the hotel room as well

The Legrand Hotel range has been designed for a pleasant hotel stay, making guests feel as if they were in their own homes.

30

Immediately at ease

The presence of a key card switch invites the guest to immediately interact with the room services on offer.

To be left undisturbed simply press the “do not disturb” control.

“DO NOT DISTURB - MAKE UP ROOM”

LAMP WITH DIFFUSER, DOORBELL AND

READER FOR ACCESS CONTROL FUNCTION

INSIDE THE ROOM:

“DO NOT DISTURB -

MAKE UP THE ROOM”

PUSHBUTTONS,

AND KEY CARD SWITCH

Connection, entertainment, and multimediality

A range of products dedicated to audio/video connections provides the desired level of entertainment and relax.

USB

CHARGER

HDMI CONNECTOR

To manage readers and electronic devices such as DVDs, digital cameras and MP3 readers

The right atmosphere, in one move

Thanks to the new MyHOME device control with the 8 keys (customisable) and digital thermostat installed at the side of the bed, you can recreate with a single touch the desired atmosphere, adjusting the light, the temperature, and the shutters.

MyHOME

DIGITAL THERMOSTAT

MyHOME

8-KEY CONTROL

Extra attention to safety

Skirting light with motion sensor for the night, alarmpull cords and sockets to ensure maximum safety at all times.

Supervision software

To control the status of the rooms with the corresponding notifications, and manage the available functions.

It also performs functions connected with the programming of the keycards.

2 TYPES OF SOFTWARE AVAILABLE:

- Management of up to 20 rooms or common areas

- Management of over 20 rooms or common areas

VALENA LIFE GENERAL CHARACTERISTICS 31

WWW.LEGRAND.COM

Valena

TM

Life switches with cover plate

2016

7 521 01 + 7 540 31 7 522 06 + 7 541 11 7 522 65 + 7 541 21 7 521 10 + 7 540 71 7 521 08 + 7 540 91

Valena In’Matic mechanisms supplied with cover plates and support frames. To be equipped with plates.

Supplied with mounted dust protection transparent shield.

After clipping in the rocker, all LED lamps light up blue.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

1

1

1

15

15

15

15

15

15

15

15

15

5

5

5

15

15

15

Cat. Nos

7 521 01

7 522 01

7 523 01

Switches 10 AX - 250 VA

One-way switch

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 06

7 522 06

7 523 06

Two-way switch

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 07

7 522 07

7 523 07

Intermediate switch

Screw terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 05

7 522 05

7 523 05

7 521 08

7 522 08

7 523 08

7 521 65

7 522 65

7 523 65

2-gang one-way switch

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2-gang two-way switch

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Energy saving switch

Automatic terminals

Installed and works like a conventional switch/2-way switch.

But in addition, it switches off automatically after

10 minutes if no movement is detected by the built-in

IR detector cell.

Detection field 160°. Detection range 8 m

Compatible with any lamp

- 12-150 W: incandescent and 230 V halogen

- 12-150 VA: lamps with ferromagnetic or electronic ballast

- 8-30 W (or 650 mA): LED and CFL

All types of lamp can be mixed on the same circuit.

Ideal for rooms where the light may be left switched on needlessly (child’s bedroom, box room).

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Pack

5

5

5

1

1

1

5

5

5

5

5

5

5

5

5

Cat. Nos

7 521 10

7 522 10

7 523 10

Switches 10 AX - 250 VA (continued)

Illuminated one-way switch

Equipped with low consumption LED 0.15 mA

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 04

7 522 04

7 523 04

7 521 26

7 522 26

7 523 26

One-way indicator switch

Automatic terminals

Equipped with 3 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Illuminated two-way switch

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 48

7 522 48

7 523 48

Illuminated intermediate switch

Screw terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 23

7 522 23

7 523 23

Pull cord two-way switch

Automatic terminals

Possible accessory: Cat. No. 0 898 05 pull cord 1.5 m

White Valena Life

Ivory Valena Life

Aluminium Valena Life

32

Valena

TM

Life switches with cover plate

Valena

TM

Life push-buttons with cover plate

2016

7 521 28 + 7 540 31 7 523 28 + 7 541 31 7 521 03 + 7 541 21 7 521 24 + 7 540 81 7 521 14 + 7 540 71

Valena In’Matic mechanisms supplied with cover plates and support frames.

To be equipped with plates.

Supplied with mounted dust protection transparent shield.

After clipping in the rocker, all LED lamps light up blue.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

1

1

1

5

5

5

5

5

5

Cat. Nos

7 521 28

7 522 28

7 523 28

Switches 10 AX - 250 VA (continued)

Illuminated 2-gang one-way switch

Automatic terminals

Equipped with 2 x 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 09

7 522 09

7 523 09

7 521 03

7 522 03

7 523 03

Illuminated 2-gang two-way switch

Automatic terminals

Equipped with 2 x 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

3-gang one-way switch

Screw terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

5

5

5

7 521 02

7 522 02

7 523 02

Switches 16 AX - 250 VA

Double pole switch

Screw terminals

White Valena Life

O

I

Ivory Valena Life

Aluminium Valena Life

Valena In’Matic mechanisms supplied with cover plates and support frames.

To be equipped with plates.

Supplied with mounted dust protection transparent shield.

After clipping in the rocker, all LED lamps light up blue.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

5

5

5

1

1

1

5

5

5

15

15

15

5

5

5

5

Cat. Nos

7 521 11

7 522 11

7 523 11

7 521 15

7 522 15

7 523 15

7 521 24

7 522 24

7 523 24

7 521 12

7 522 12

7 523 12

7 521 16

7 522 16

7 523 16

7 521 14

Push-buttons 6 A - 250 VA

Changeover push-button

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Changeover push-button, bell symbol

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Pull-cord changeover push-button

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Illuminated changeover push-button

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Illuminated changeover push-button, bell

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Illuminated label-holder push-button

Automatic terminals

Equipped with 0.15 mA Low consumption LED

Equipped with transparent rocker with 3 different coloured inserts (white, ivory, aluminium)

White, Ivory, Aluminium Valena Life

5

5

5

5

5

5

7 521 18

7 522 18

7 523 18

7 521 13

7 522 13

7 523 13

2-gang changeover push-button

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena life

Illuminated push-button 12 V

Automatic terminals

Equipped with low consumption LED

White Valena Life

Ivory Valena Life

Aluminium Valena Life

33

Valena

TM

Life dimmers with cover plate

7 521 60 + 7 540 01 7 523 62 + 7 541 31

7 521 63 + 7 540 06

Valena In’Matic mechanisms supplied with cover plates and support frames.

To be equipped with plates.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

1

1

1

1

1

1

1

Cat. Nos

7 521 60

7 522 60

7 523 60

7 521 62

7 522 62

7 523 62

7 520 67

Dimmers 230 VA - 50 Hz

Equipped with overvoltage and short-circuit protection.

When switched on, ight up at the level set before last switch-off

Can be remotely controlled via non-illuminated push-buttons (Cat. No. 7 520 11), with each push-button able to perform the ON/OFF and dimming function

Rotary dimmer without neutral

For all types of lamps:

- dimmable LEDs: 5 W to 75 W (10 lamps max.)

- dimmable compact fluorescent lamps: 5 W to 75 W

(10 lamps max.)

- halogen with ferromagnetic or electronic transformer:

5 VA to 300 VA

- fluorescent tube - ballast: 5 VA to 300 VA

- halogen and incandescent 230 V A: 5 W to 300 W the level set before last switch-off

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Push-dimmer without neutral

For all types of lamps:

- dimmable LEDs: 5 W to 75 W (10 lamps max.)

- dimmable compact fluorescent lamps: 5 W to 75 W

(10 lamps max.)

- halogen with ferromagnetic or electronic transformer:

3 VA to 400 VA

- fluorescent tube - ballast: 3 VA to 200 VA

- halogen and incandescent 230 V: 3 W to 400 W

When switched on, gradually (2 seconds) lights up at the level set before last switch-off

Functioning:

- dimming mode

- pre-set level mode (0%, 33%, 66% and 100%)

- nightlight mode: dimming of the lamp for 1 hour

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Dimmer, with neutral, for 1-10 V ballast

Rocker 7 548 90 (white) 91 (ivory) and 92 (alluminium) not included

Screw terminals

For fluorescent lamps with 1-10 V ballast:

600 VA

1

1

7 521 63

7 523 63

1000 W dimmer, with neutral

Mechanism supplied with cover plate

Screw terminals

For the following kinds of lamps:

- halogen with ferromagnetic or electronic transformer:

100 VA to 100 VA

- halogen and incandescent 230 V: 100 W to 1000 W

When switched on, gradually (2 seconds) lights up at the level set before last switch-off

5 LEDs displaying the current level of the circuit

Complete with 5-module cover

Supplied with with Cat. No. 0 801 02 Batibox multimaterial 2-gang box (depth 40 mm).

Supplied with cover plate.

White Valena Life

Aluminium Valena life

34

LEGRAND

PACKAGING

Products always

PROTECTED

Thanks to the flowpack, the produts can be easily identified and remain protected until the installation.

2016

FULL PROTECTION

AND ADITTIONAL

INFORMATION WITH

QR CODE

the product is protected throughout the delivery process, until the installation

all useful information is printed on the flow pack

additional information by scanning the

QR code

INDIVIDUAL

PROTECTION

AND QUICK

IDENTIFICATION

products are individualy protected and can be hang on or placed in bullk

the product is always visible for a faster identification

Valena

TM

Life motion sensors, roller blind control with cover plate

2016

7 521 70 + 7 540 71 7 522 70 + 7 541 11 7 520 25 + 7 551 60 + 7 540 81 7 521 29 + 7 541 21

Valena In’Matic mechanisms supplied with cover plates and support frames. To be equipped with plates.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

1

1

1

1

1

1

1

1

1

Cat. Nos

7 521 70

7 522 70

7 523 70

7 521 72

7 522 72

7 523 72

7 521 73

7 522 73

7 523 73

Motion sensors

All sensors are compatible with any type of lamp

Detection field 180°

Detection range 8 m

Integrated self-protection against overloads and shortcircuits.

Motion sensor without neutral

Accepted power by lamp type:

- LEDs* 3 W to 100 W

- Compact fluorescent* 3 W to 100 W

- LEDs, CFLs, Halogen, fluorescent tubes with ferromagnetic or electronic ballast: 3 VA to 250 VA

- 230 V halogen, incandescent: 3 W to 250 W

* If several sensors are installed on the same circuit, the minimum load increases (see data sheet).

Up to 3 sensors can be connected in parallel.

Time delay setting from 10 s to 10 min.

Light level threshold setting from 5 lux to 1275 lux.

Standby consumption: 0.02 W

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Motion sensor without neutral, with override

The sensor can be forced to ON, Automatic or OFF mode using a 3-position slider.

Accepted power by lamp type:

- LEDs* 3 W to 100 W

- Compact fluorescent* 3 W to 100 W

- LEDs, CFLs, Halogen, fluorescent tubes with ferromagnetic or electronic ballast: 3 VA to 250 VA

- 230 V halogen, incandescent: 3 W to 250 W

* If several sensors are installed on the same circuit, the minimum load increases (see data sheet).

Up to 3 sensors can be connected in parallel.

Possibility of additional remote manual control with push-button.

Time delay setting from 10 s to 10 min.

Light level threshold setting from 5 lux to 1275 lux.

Standby consumption: 0.02 W

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Motion sensor with neutral

Accepted power by lamp type:

- LEDs: 0 to 50 W

- Compact fluorescent: 0 to 50 W

- LEDs, CFLs, Halogen with ferromagnetic or electronic ballast: 0 to 200 VA

- Fluorescent tubes with ferromagnetic or electronic ballast: 0 to 150 VA

- 230 V halogen, incandescent: 0 to 400 W

Only one sensor per circuit.

No remote manual control with push-button.

Time delay setting from 10 s to 10 min.

Light level threshold setting from 5 lux to 1275 lux.

Standby consumption: 0.55 W

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Pack

5

5

5

5

5

5

1

Cat. Nos

7 521 29

7 522 29

7 523 29

7 521 30

7 522 30

7 523 30

7 520 25

Roller blind controls 10 A - 250 VA

Roller blind switch

Automatic terminals

For direct control of the motor

Roller shutter/awning/canopy control

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Roller blind push-button

Automatic terminals

For control via electronic control unit

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Keycard switches

Electronic card-operated switch

Rockers 7 551 60 (white) 61 (Ivory) 62 (alluminium) not included

Screw terminals

For energizing a circuit by inserting a card

Example of use: hotel room power supply only when the guest is present 230 VA - 50/60 Hz

Mechanism with 30s time delay after card removal.

To be used with the card Cat. no. 0 898 06

Card width max. 54 mm. Card not supplied.

35

Valena

TM key switches

mechanisms Valena

TM

mechanisms thermostats and ventilation controls

7 521 25 + 7 540 01 7 522 19 + 7 541 61

Valena In'Matic mechanisms are supplied with metal support, for claw or screw mounting. Mechanisms are supplied with cover plate. Supplied with mounted dust protection transparent shield. Packaged in boxes

Pack Cat.Nos

Key switch 2 positions

1

1

1

1

1

1

1

1

1

7 521 25

7 522 25

7 523 25

To be equipped with European key barrel

Cat.No 0 697 95 (order separately)

2 contacts NO - 6 A - 230 V A

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Key push-button

7 521 19

7 522 19

7 523 19

3-position key-operated push-button

Changeover switch with off position - 10 A - 230 V A

Key can be removed in off position

To be equipped with European key barrel

Cat.No 0 697 95 (order separately)

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Key switch for emergency lighting

7 521 38

7 522 38

7 523 38

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 35 + 7 540 06 7 521 32 + 7 540 31

Valena In'Matic mechanisms are supplied with metal support, for claw or screw mounting. To be equipped with Valena Life cover plates and plates

Supplied with mounted dust protection transparent shield

Packaged in boxes

Pack

1

1

1

1

1

1

1

1

1

Cat.Nos

7 521 33

7 522 33

7 523 33

Thermostats

Electronic room thermostat

Screw terminals

Control knob with index and adjustable segments for min. and max. settings

Adjustable range from 5°C to 30°C (+/- 0.5°C)

Power supply: 230 V A - 50/60 Hz

One potential-free changeover contact output

Suitable for controlling heated ceilings and underfloor heating

- LV use breaking capacity:

8 A - 250 V A - resistive inductive circuit

2 A - 250 V A - inductive circuit

- ELV use breaking capacity:

12 to 48 VA- 12 to 24 V=, from 1 mA min. to 500 mA max.

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Floor heating thermostat

Screw terminals

With one potential-free N/O contact and LED

16 A - 230 V

Adjustable range from 10°C to 60°C

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 521 34

7 522 34

7 523 34

7 521 35

7 522 35

7 523 35

Programmable thermostat

Mechanism is supplied with cover plate

Provides temperature regulation for oil, gas and electric heating installations in comfort, reduced and frost-free modes. Weekly programming

Permanent display of the current programme

4 preset programmes, 1 free programme,

4 time periods max. per day, 2 adjustable temperature levels. Manual switching possible

Adjustment range: 7°C to 30°C

Adjustment accuracy: ± 0.5°C

Permanent backup of programmes

Working reserve 100 hrs

1 output per changeover contact

Breaking capacity: 8 A max

Complete with a 5-module cover

Supplied with with Cat.No 0 801 02 Batibox multimaterial 2-gang box (depth 40 mm)

White Valena Life

Ivory Valena Life

Aluminium Valena Life

1

1

1

7 521 32

7 522 32

7 523 32

Ventilation control

Ventilation control switch (0, 1, 2, 3)

Mechanism is supplied with cover plate

Screw terminals

AC 23 A 2,5 kW, AC 21 A 20 A

White Valena Life

Ivory Valena Life

Aluminium Valena Life

36

Valena

TM

Life audio sockets and USB chargers with cover plate

Valena

TM

Life socket outlets with cover plate

2016

7 533 20 + 7 541 31 7 531 20 + 7 540 71 7 531 29 + 7 540 01

Valena In’Matic mechanisms supplied with cover plates and support frames.

To be equipped with plates. IP 2X protection.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation

Pack

5

5

5

15

15

15

5

Cat. Nos

7 531 20

7 532 20

7 533 20

7 531 28

7 532 28

7 533 28

7 531 29

German standard socket outlets 16 A - 250 VA

2P+E socket with shutters

Automatic terminals

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2P+E socket with shutters for refurbishments

Special tap-off screw and 6 mm² terminals, big capacity for cables 1x6 mm² or 2x4 mm² or 3x2.5 mm²

To be used in refurbishments with 30 mm depth boxes.

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2P+E socket with shutters, red

Supplied with cover plate

Automatic terminals

Valena Life design

7 531 26 + 7 542 21

Pack

5

5

5

5

5

5

5

5

5

5

1

7 531 31

2P+E socket with shutters, red, tamperproof

Supplied with cover plate.

Automatic terminals. Possible accessory: tamperproof insert Cat. No. 0 502 99 - fits directly into the plug

Valena Life design

7 532 29

2P+E socket with shutters, orange

Supplied with cover plate

Automatic terminals

Valena Life design

1

1

7 531 26 + 7 542 21

Cat. Nos

7 531 26

7 532 26

7 533 26

7 531 27

7 532 27

7 533 27

7 542 25

7 542 35

7 542 45

7 531 10

7 532 10

German standard double socket outlets 16 A

- 250 VA

Automatic terminals

2x2P+E socket with shutters

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2x2P+E socket

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2x2P+E socket plate adaptor

To be used for creating multigang installations of single functions with double sockets (for example

RJ 45 sockets, TV sockets, etc)

White Valena Life

Ivory Valena Life

Aluminium Valena Life

2P+E/USB mixed socket

In renovation, allows a traditional socket to be replaced without changing the wiring. To be installed in minimum

40 mm depth "regular" flush mounting box

2P+E 16 A + USB 1500 mA

Conforms to standard IEC 62684-2011-01

For charging mobile phones, tablet PCs, smartphones,

MP3 and MP4 players quickly. Frees up a socket recess. Consumption in passive mode < 0.1 W class

II SELV

Conforms to the EEC directive on harmonisation of the charging standard for portable terminals and the harmonisation of mobile phone chargers

Supplied cordless. Complete product with cover plate and plate.

White Valena Life

Ivory Valena Life

1 7 533 29

2P+E socket with shutters, green

Supplied with cover plate

Automatic terminals

Valena Life design

37

Valena

TM

Life

TV sockets with cover plate

2016

7 533 52 + 7 541 31 7 533 51 + 7 541 31 7 531 61 + 7 540 01 7 531 64 + 7 540 81 7 532 64 + 7 541 81

Valena In’Matic mechanisms supplied with cover plates and support frames. To be equipped with plates.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

5

5

5

5

5

5

Cat. Nos

Star architecture TV sockets

7 531 52

7 532 52

7 533 52

7 531 51

7 532 51

7 533 51

Star cabling (1 socket = 1 cable to antenna) ensures a

HD quality level of distribution of TV standard

For distribution of TV & Radio signals

All operators (DVBT, satellite, Cablecast)

Meet EN 50083-4 and CEM 50083-2 European

Directive. HDTV compatible: Low fading (<1.5 dB)

LTE ready, shielded socket to protect against interference from mobile phone network 3G & 4G signals

TV male connector (Ø 9.5 mm)

R female connector (Ø 9.5 mm)

SAT "F" type connector

Recommended coaxial cable: 17/19 VATC

Visual check of the connection

TV-R-SAT sockets

TV: 0-862 MHz

R: 87.5 - 108 MHz

SAT: 950-2400 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Male TV socket

TV: 0-2400 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Pack

5

5

5

5

5

5

Cat. Nos

Passthrough TV sockets - 10 dB

7 531 65

7 532 65

7 533 65

7 531 61

7 532 61

7 533 61

Installation in case of maintenance

An amplifier and line balancing are recommended

TV male connector (Ø 9.5 mm)

R female connector (Ø 9.5 mm)

SAT "F" type connector.

Recommended coaxial cable:

17/19 VATC. visual check of the connection

TV-R-SAT socket

TV: 5-68/120-862 MHz

R: 87.5 - 108 MHz

SAT: 950-2400 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena life

Male TV socket

TV: 0-862 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena Life

5

5

5

5

5

5

7 531 64

7 532 64

7 533 64

7 531 60

7 532 60

7 533 60

Terminal TV sockets

Installation in case of maintenance

An amplifier and line balancing are recommended

TV male connector (Ø 9.5 mm)

R female connector (Ø 9.5 mm)

SAT "F" type connector

Recommended coaxial cable:

17/19 VATC. visual check of the connection

1 input with 1 resistance cap socket -10 dB

TV-R-SAT socket

TV: 5-68/120-862 MHz

R: 87.5 - 108 MHz

SAT: 950-2400 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Male TV socket

TV: 0-862 MHz

White Valena Life

Ivory Valena Life

Aluminium Valena Life

38

Valena

TM

Life data and telephone sockets with cover plate

2016

7 533 48 + 7 541 31 7 531 43 + 7 540 71 7 532 39 + 7 540 41

Valena In’Matic mechanisms supplied with cover plates and support frames. To be equipped with plates.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation.

Pack

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

Cat. Nos

7 531 48

7 532 48

7 533 48

7 531 49

7 532 49

7 533 49

Data sockets Cat. 6 A

With LCS² connector with fast connection thanks to integrated crimping

Take AWG 22 single-core cables up to AWG 26 and

AWG multicore cables

Contacts marked with dual colour code and wiring schemes 568 A and 568 B

Conform to standards ISO/IEC 11801 Ed. 2.0, amendment 2, EN 50173-1 and TIA/EIA 568 C2

RJ 45 socket Cat. 6 A STP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ45 socket Cat. 6 A STP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Data sockets Cat. 6

7 531 42

7 532 42

7 533 42

7 531 46

7 532 46

7 533 46

7 531 43

7 532 43

7 533 43

7 531 47

7 532 47

7 533 47

With LCS² connector with fast connection thanks to integrated crimping

Take AWG 22 single-core cables up to AWG 26 and

AWG multicore cables

Contacts marked with dual colour code and wiring schemes 568 A and 568 B

Conform to standards ISO/IEC 11801 Ed. 2.0, amendment 2, EN 50173-1 and TIA/EIA 568 C2

RJ 45 socket Cat. 6 UTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

RJ 45 socket Cat. 6 STP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ 45 socket Cat. 6 UTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ 45 socket Cat. 6 STP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Pack

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

5

Cat. Nos

7 531 40

7 532 40

7 533 40

7 531 53

7 532 53

7 533 53

7 531 41

7 532 41

7 533 41

7 531 54

7 532 54

7 533 54

Data sockets Cat. 5e

With LCS² connector with fast connection thanks to integrated crimping

Take AWG 22 single-core cables up to AWG 26 and

AWG multicore cables

Contacts marked with dual colour code and wiring schemes 568 A and 568 B

Conform to standards ISO/IEC 11801 Ed. 2.0, amendment 2, EN 50173-1 and TIA/EIA 568 C2

RJ 45 socket Cat. 5e UTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

RJ 45 socket Cat. 5e FTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ45 socket Cat. 5e UTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ45 socket Cat. 5e FTP

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 531 38

7 532 38

7 533 38

7 531 39

7 532 39

7 533 39

Telephone sockets

Equipped with a modular Jack connector with 1/4 turn terminal for fast connection. Tap-off possible

RJ 11 socket

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double RJ 11 socket

White Valena Life

Ivory Valena Life

Aluminium Valena Life

39

Valena

TM

USB chargers

mechanisms Valena

TM

mechanisms audio sockets with cover plate

2016

7 531 12 + 7 540 71 7 521 74 + 7 540 91 7 520 69 + 7 541 21

7 531 78 + 7 540 31 7 531 72 + 7 540 81 7 531 72 + 7 540 81

Valena In'Matic mechanisms are supplied with metal support, for claw or screw mounting. IP 2X protection. Supplied with mounted dust protection transparent shield. Packaged in boxes.

Pack Cat. Nos

USB chargers

5

5

5

1

1

7 531 12

7 532 12

7 533 12

7 530 11

7 530 12

Double USB power supply

100-240 V A 50-60 Hz, 5 V - 1500 mA

For charging mobile phones, tablet PCs, smartphones, MP3 and MP4 players quickly. Frees up a socket recess. Consumption in passive mode

< 0.1 W class II SELV

Conforms to the EEC directive on harmonisation of the charging standard for portable terminals and the harmonisation of mobile phone chargers.

For installation in flush-mounting box depth 40 mm minimum. Supplied cordless. Complete product with cover plate and plate.

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Micro USB charging dock

Mechanism is supplied with cover plate

100-240 V A 50-60 Hz, 5 V - 1500 mA remains visible during charging.

To be installed in minimum 40 mm depth flush mounting box.

Conforms to standard IEC 62684-2011-01

For charging mobile phones, tablets, smartphones,

MP3 and MP4 players quickly

Standby consumption less than 0.01 W class II SELV

Conforms to the EC directive on harmonisation of the charging standard for portable terminals and the harmonisation of mobile phone chargers.

- smartphone holder with non-slip coating (fix using screws or adhesive on all surfaces)

White Valena Life

Ivory Valena Life

1

1

1

1

1

1

7 521 74

7 522 74

7 523 74

Skirting light with motion detector

Screw terminals

When someone passes it, the mechanism detects movement and lights the passage.

Detection field 180°. Detection range 6 m

LED lighting.

The function has a disengageable audible signal.

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 520 69

7 521 69

7 522 69

Extractible emergency lamp

The lamp automatically turns on in case of power failure.

Push&pull system to extract the lamp from the charging base: this turns on the lamp which can then be used as a torch (ON-OFF).

Working reserve: 2 hours

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Valena In’Matic mechanisms supplied with cover plates and support frames.

To be equipped with plates.

Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation

Pack

5

5

5

5

5

5

5

5

5

5

5

5

1

1

1

1

1

1

1

Cat. Nos

Loudspeaker sockets

7 531 72

7 532 72

7 533 72

7 531 78

7 532 78

7 533 78

4 mm

2

terminals

Loudspeaker socket

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Double loudspeaker socket

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 531 71

7 532 71

7 533 71

7 531 70

7 532 70

7 533 70

7 530 75

Audio and video sockets

HDMI type A sockets

Mechanism is supplied with cover plate

Used to transmit high-definition digital audio/video streams between a source (computer, HD-DVD drive) and a compatible receiver

(TV, video projector)

Screw-type sockets HDMI 1.3

White Valena Life

Ivory Valena Life

Aluminium Valena Life

HD 15 + 3.5 mm Jack socket

Mechanism is supplied with cover plate

Used to transmit analogue audio/video streams between a source (computer) and a compatible receiver

(TV, video projector).

Video resolution VGA - UXGA

HD 15 female socket + 3.5 mm jack socket (screwed)

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Triple RCA socket

For the composite video and stereo audio connection of any amplifier, DVD drive, VCR type peripheral.

Rocker 7 547 20 (white) 21 (ivory) and 22

(aluminium) is not included

7 531 33

7 532 33

7 533 33

7 531 34

7 532 34

7 533 34

Accessories

Cable outlet with terminals

With 5 terminals to take 2.5 mm² cables

Maximum cable diameter: 12 mm

With cable grip

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Cable outlet without terminals

Maximum cable diameter: 12 mm

With cable grip

White Valena Life

Ivory Valena Life

Aluminium Valena Life

40

Valena

TM

mechanisms sound diffusion and loudspeakers

7 521 42 + 7 540 06

Valena In’Matic mechanisms are with metal support, claw or screw mounting

To be equipped with cover plates and plates of Valena Life

Supplied with mounted dust protection transparent shield. Packaged in boxes

Pack

1

1

1

Cat.Nos

7 521 42

7 522 42

7 523 42

Sound diffusion

LCD RDS tuner with power supply

Mechanism is supplied with cover plate

Built-in 230 V power supply. Manual or automatic station selection (RDS search). Stores 10 stations.

Built-in aerial. Volume, balance and bass/treble control. Has an auxiliary input (3.5 mm Ø jack) for connecting an MP3 player (lead not supplied).

Compatible with 4/8 or 16 Ω loudspeakers except for Cat.No 0 673 30. Stereo or mono output. Output power 2 x 3 W. Station display, creation of 2 lists of favourites (2 x 8 presets). Alarm function (possible to set 2 different times). Loudspeaker selection (left or right) for each of the alarms. Timer function. On/off control (manual/automatic), presence of mains supply.

To be fitted with a 5-module plate. Supplied with

Cat.No 0 801 02 Batibox multimaterial 2-gang box

(depth 40 mm).

White Valena Life

Ivory Valena Life

Aluminium Valena Life

7 520 36 + 7 554 30

+ 7 540 81

Pack

1

1

1

1

Cat.Nos

Sound diffusion (continued)

7 520 36

Bluetooth module

15 V power supply. Has an auxiliary input

(3.5 mm Ø jack) for connecting an MP3 player without Bluetooth (lead not supplied).

Used to receive a musical source from a smartphone or any other Bluetooth peripheral via Bluetooth or a jack input and play it via a wired connection on a 4/8 or

16 loudspeaker. Stereo or mono output.

Rocker 7 554 30 (white), 31 (ivory) and 32

(Aluminium) is not included

0 673 22

Power supply in false ceiling for Bluetooth module

Power supply 230 V

A

Output 15 V= - 3.5 W

For use in Plexo box Cat.No 0 920 52

Loudspeakers

0 673 27

L4566/10

To connect with local control Cat.No 7 520 37 and

LCD RDS tuners

For false ceiling

White

Depth 27 mm

Hole diameter: 65 mm

Visible depth: 11 mm

Power: 2 W - 16 Ω - 2”

Equipped with clips for attachment

Use a 65 mm Ø crown saw to cut the hole

8 Ω false ceiling and plasterboard loudspeaker

L = 100 mm - power 20 W - colour white

0 673 30

False ceiling mounting invisible loudspeaker

For multi-zone sound distribution

Can be connected with the 15 V - 60 W power supply supplied with source input

Max. power 8 W

Depth: 98 mm

Supplied with adhesive and gluing template

41

Valena

TM

Life

IP44 devices with white cover plate

2016

7 521 61 + 7 540 71 7 521 59 + 7 540 81 7 531 19 + 7 540 01 7 521 77 + 7 540 01 7 540 21

Valena In’Matic mechanisms supplied with white cover plates, weatherproof membrane and support frames.

To be equipped with plates. Supplied with mounted dust protection transparent shield.

Flowpack packaging: robust protection to ensure optimum operation

Pack

5

Cat. Nos

7 521 51

Switches 10 AX - 250 VA, IP44

One-way switch

Automatic terminals

White Valena Life

Pack

5

Cat. Nos

7 521 71

Push-buttons 6 A - 250 VA, IP44

Changeover push-button

Automatic terminals

White Valena Life

5 7 521 56

Two-way switch

Automatic terminals

White Valena Life

5 7 521 61

Illuminated one-way switch

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

5 7 521 67

Illuminated two-way switch

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

5

7 521 55

2-gang one-way switch

Automatic terminals

White Valena Life

5

7 521 58

2-gang two-way switch

Automatic terminals

White Valena Life

1

7 521 59

Illuminated 2-gang two-way switch

Automatic terminals

Equipped with 2 PCS 2 x 0.15 mA low consumption

LED

White Valena Life

5 7 521 75

Changeover push-button, bell symbol

Automatic terminals

White Valena Life

6 7 521 76

Illuminated changeover push-button, bell symbol

Automatic terminals

Equipped with 0.15 mA low consumption LED

White Valena Life

5

1

1

7 531 19

German standard socket outlets

16 A - 250 VA, IP44

2P+E socket with shutters, with flap

Automatic terminals

White Valena Life

7 521 77

Motion sensor 250 W IP 44

White Valena Life

Accepted power by lamp type:

- LEDs* 3 W to 100 W

- Compact fluorescent* 3 W to 100 W

- LEDs, CFLs, Halogen, fluorescent tubes with ferromagnetic or electronic ballast: 3 VA to 250 VA

- 230 V halogen, incandescent: 3 W to 250 W

*if several sensors are installed on the same circuit, the minimum load increases (see data sheet).

Up to 3 sensors can be connected in parallel.

Time delay setting from 10 s to 10 min.

Light level threshold setting from 5 lux to 1275 lux.

Standby consumption: 0.02 W

7 540 21

IP 44 plate with flap

Compatible with all Valena In’Matic mechanisms

IP44/IK07 UV-resistant

5

7 521 64

Switches 16 AX - 250 VA, IP44

Double pole switch

Screw terminals

White Valena Life

42

Valena

TM accessories

mechanisms Valena

TM

LED lamps

mechanisms

2016

7 521 45

Pack

5

1

1

1

1

1

1

1

5

5

5

10

10

10

1

1

1

1

7 521 46

Cat. Nos

7 541 91

7 542 01

7 542 11

7 541 92

7 542 02

7 542 12

7 521 45

7 523 45

Accessories

Surface-mounting box 1-gang

Sizes: 89x89x44.8 mm

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Surface-mounting box 2-gang

Sizes: 160x89x44.8 mm

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Support frame 4x2 modules with plate

Takes Mosaic

TM

Programme functions compatible with Batibox open boxes 40 mm depth (Cat. No. 0 801 03),

50 mm depth (Cat. No. 080123)

White Valena Life

Aluminium Valena Life

7 521 46

7 523 46

Support frame 2x4x2 modules with plate

Takes Mosaic

TM

Programme functions compatibles with Batibox open boxes, Cat. No. 0 801 26

White Valena Life

Aluminium Valena Life

7 551 80

7 551 81

7 551 82

7 521 43

7 522 43

7 523 43

7 521 44

7 523 44

Blanking plate

With metal support for claw or screw mounting.

Supplied with mounted dust protection transparent shield. IP 20: against direct contact when the full capacity of the support is not used

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Adaptor for 50X50 mm mechanisms DIN 49075

Is used to adapt specific functions with 50x50 cover plate

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Adaptor for Mosaic

TM

mechanisms

Accept 2-module mechanisms from the Mosaic TM or

Arteor ranges, except special surface mounting type

White Valena Life

Aluminium Valena Life

7 520 01 + 7 550 02

+ 7 541 31 + 0 676 84

7 520 05 + 7 550 20

+ 7 540 01 + 2 x 0 676 84

7 520 06 + 7 550 01

+ 7 541 11 + 0 676 86

All lamps in Valena Life range devices have low consumption LED technology.

After clipping in the rocker, all lamps light up blue.

Pack Cat. Nos

LED lamps for illuminated functions

10 0 676 84

Plug-in LED lamp for illuminated one-way switch and push-button

230 V A - Consumption 0.15 mA

10

10

10

10

10

10

0 676 86

Plug-in LED lamp for illuminated two-way switch

230 V A - Consumption 0.15 mA

6 650 90

LED lamp to be wired for illuminated intermediate switch

230 V A - Consumption 0.15 mA

0 676 87

Plug-in LED lamp for 12-48 V illuminated push-buttons

12-24-48 V

LED lamps for indicator functions

0 676 88

Plug-in LED lamp for two-way switch with indicator and neutral terminal

230 V A - Consumption 3 mA

6 650 91

LED lamp to be wired for indicator functions

230 V A - Consumption 3 mA

0 676 64

LED lamp to be wired for indicator socket

230 V

A - Consumption 3 mA

43

Valena

TM

Life - radio control mechanisms radio receivers for lighting and roller blinds

Valena

TM

Life - radio control mechanisms cover plates offer

0 672 34 0 672 63

Receivers to be equipped with Valena Life cover plates and with

2-module plates. To be installed in flush-mounting boxes min. depth 40 mm. To be equipped with 2-module support frames Cat.No

7 520 44. Connect to the load and can be controlled by remote control transmitters, scenario switches, mobile control units and detectors

Packaged in boxes

Pack Cat.Nos.

Switches

1 0 672 33

Switch with neutral - 2500 W

1 0 672 34

Double switch with neutral - 2 x 1000 W

1

1

1

0 672 21

Switch without neutral - all loads

To control all loads, including energy saving loads (LED, Compact fluorescent)

LED: 5 W-60 W

Halogen and incadescent: 7 W -300 W

Dimmer

0 672 27

All loads dimmer without neutral

To control dimmable loads including dimmable LED and Compact fluorescent lamps

LED dimmable: 5 W-60 W

Halogen and incadescent: 7 W-300 W

Roller blinds radio switch 500 VA

0 672 63

To control one motor

7 547 70 + 7 540 01

Pack

1

1

1

1

1

1

1

1

1

1

1

1

7 547 29 + 7 541 31

Cat.Nos.

Cover plates for radio controls

7 547 09

7 547 13

7 547 02

7 547 70

7 547 71

7 547 72

7 547 40

7 547 41

7 547 42

7 547 24

7 547 28

7 547 29

Cover plates for switches and dimmer

Lighting switch 1 circuit

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Lighting switch 2 circuits

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Lighting dimmer

Marking: + top right - bottom right

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Roller blind switch

Marking: square bottom left up arrow top right down arrow bottom right

White Valena Life

Ivory Valena Life

Aluminium Valena Life

5 7 520 44

In’matic support for radio and MyHOME mechanisms

Accept 2 modules mechanism

1 5 738 62

Receiver control units for false ceiling

- 100-240 VA

Its receiver function is used to execute, on its circuits,

ON/OFF commands received from centralised control units, scenario switches, mobile control units, etc

Universal switch - phase/neutral

1 output - 2500 W

1 5 738 64

Dimmer (excluding fluorescent and LEDs)

- without neutral

1 output - 600 W

1 5 738 66

Dimmer for 1-10 V ballast - phase/neutral

1 output - 500 VA

Four pieces required for a complete product

Support frame Mechanism Cover plate Plate

44

Valena

TM

Life - radio control mechanisms lighting, roller blind and scenario wireless controls

Valena

TM

Life - radio control mechanisms cover plates offer

5 738 70

1

1

1

0 883 07

0 882 32

Wireless controllers to be equipped with Valena Life cover plates and with

2-module plates. Can be fitted directly on the wall without support frame and without flush-mounting box. For remote control of a switch or group of switches. Perfect for achieving a two-way switch function without any additional wiring

Packaged in boxes

Pack

1

Cat.Nos

7 520 82

Control devices on wall - Lithium battery supplied

Wireless switch radio control for 2 circuits

7 520 80

Wireless dimmer switch radio control

7 520 81

Wireless switch radio control for 1 circuit

7 520 83

Wireless scenario radio control 4 push-buttons

7 547 49 + 7 540 01

Pack

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

7 548 34 + 7 541 31 7 548 13 + 7541 31

Cat.Nos.

Cover plates for wireless control mechanisms

7 547 49

7 547 59

7 547 63

7 547 78

7 547 79

7 547 83

7 547 39

7 547 51

7 547 53

7 548 24

7 548 33

7 548 34

7 548 03

7 548 04

7 548 13

Wireless switch 1 circuit

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Wireless switch 2 circuits

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Wireless dimmer

Marking: + top right - bottom right

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Wireless roller blind control

Marking: square bottom left up arrow top right down arrow bottom right

White Valena Life

Ivory Valena Life

Aluminium Valena Life

Wireless scenario control 4 push buttons

White Valena Life

Ivory Valena Life

Aluminium Valena Life

1

7 520 84

Wireless roller blinds radio control

1

1

1

Radio remote control

5 738 70

1 scenario can control several functions: lighting level adjustment, roller blinds, general ON or OFF, etc...

Pocket scenario radio control

4-scenario controller

For radio installation

Supplied with batteries 3 V type CR2032

0 883 07

0 882 32

Radio remote control 6 scenarios

6-scenario controller

Can control a dimmer group by long press contact

Supplied with 2 batteries 1.5 V type LR03

Radio - IR remote control

5-scenario controller

Supplied with batteries

45

Valena

TM

Life - radio controls other radio functions

0 883 06 0 883 33 0 883 26 0 883 32 0 883 10

Pack

1

Load selection charts

p. xxx

Cat.Nos

Radio micromodule switch

0 883 06

Microswitch module receiver 300 W

Connected to a load, controlled by one or more wireless controls, 3-wire installation inside the light source

1 0 883 34

Transmitter/receiver mobile sockets

Connect directly to an existing 2P+E socket to switch the light connected to the socket

Its receiver function is used to execute commands received from scenario controls, centralised control units, detectors, etc. To control halogen, energy saving

(LED and compact fluorescent) and incandescent lamps

Radio mobile dimmer switch-sockets

ON/OFF by short press, dimming by long press

German standard

To control dimmable lamps

1

1

1

1

1

0 883 38 French standard

To control dimmable lamps

0 883 33

Radio mobile switch-sockets

10 A

German standard

0 883 37 French standard

0 695 03 2500 W

Its transmitter function allows it to control another lighting radio receiver switch

Its receiver function is used to execute commands received from centralised control units, scenario controls, mobile control units, etc

3-wire installation in box depth 40 mm min.

0 883 26

Plexo radio transmitter/receiver switch

Microreceiver for shutters

Actuator device for the control of roller shutter motors with max. power 500 VA

For installation in roller shutter boxes or function boxes. To be installed in roller shutter mechanisms or roller shutter control mechanisms

Pack

1

Support frame and plate selection charts

p. xxx-xxx

Cat.Nos

0 883 39

Radio transmitter/receiver multifunction switches

Switches for controlling 1 or 2 circuits connected to its terminals according to 3 different operating modes: time-lag switch, switch, remote control switch. Its receiver function is used to execute, on its circuits, ON/

OFF commands received from individual control units, centralised control units, scenario switches, mobile control units, etc. Phase/neutral power supply

Weatherproof multifunction switch

1 circuit 2500 W or 1 NO/NC contact outputs

1

5 738 60 Weatherproof multifunction 2-gang switch

2 circuits 2500 W or 2 NO/NC contact outputs

1

1

1

1

1

1

0 883 09

Indoor motion sensor

To switch on the lights connected to radio receivers remotely when there are movements, for an adjustable time

Range detection: 2 to 10 m, timing: 1 to

30 min., light level: 1 to 1000 lux

Indoor temperature sensor

0 883 30 IP 21. For indoor use only - surface mounting. Setting:

2 temperature thresholds. Temperature ranges: from

- 10°C to + 40°C. Can be used to initiate 2 scenarios when the temperature is higher than the high threshold or lower than the low threshold

Transmitter with auxiliary inputs

For light control

0 883 31 Can be used to initiate ON/OFF on closing or opening of a volt-free contact. For controlling a radio installation using commercially-available detectors (eg: lightsensitive switch, moisture sensor). Fits behind a traditional switch, without damage to the walls, to control a radio switch

For scenario control

0 883 32 Can be used to launch 2 scenarios when closing and opening with a volt-free contact. For controlling scenario radio installation using commercially available detectors

(moisture sensor, wind/sun sensors or smoke detectors)

0 883 10

WiFi/Radio gateway

To control a radio installation in or outside the home from a smartphone or a tablet

Perfect for switching off a light from your office when you forgot it, to simulate that you are at home. Ios and Android apps available

0 883 28

Open Web Net/ZigBee Gateway Radio interface

Open/ZigBee interface for centralised control of functions through devices which use the Open Web Net communication protocol

46

Valena

TM

Life - radio controls switches and dimmers with maximum loads at 230 V (for 110 V, please halve the values given below)

Universal

Cat.Nos

0 672 21

0 672 33

0 672 34

0 672 63

0 883 26

0 883 34

0 695 03

0 883 06

0 883 39

5 738 60

0 672 27

0 883 33

Incandescent

lamp

7 - 300 W

2500 W

2 x 1000 W

Halogen lamp ELV halogen with ferromagnetic transformer

ELV halogen with electronic transformer

7 - 300 W 35 - 300 VA 10 - 300 VA

2500 W

2 x 1000 W

2500 VA

2 x 1000 VA

2500 VA

2 x 1000 VA

Fluorescent tube

-

Compact fluorescent lamp

9 - 60 W

1250 VA

2 x 500 VA

1250 W

2 x 500 W

-

2500 W

2500 W

300 W

2500 W

2 x 2500 W

7 - 300 W

7 - 300 W

-

2500 W

2500 W

300 W

2500 W

2 x 2500 W

7 - 300 W

7 - 300 W

-

2500 VA

2500 VA

250 VA

2500 VA

2 x 2500 VA

-

2500 VA

2500 VA

250 VA

2500 VA

2 x 2500 VA

35 - 300 VA dimmable transfo

10 - 300 VA dimmable transfo

35 - 300 VA dimmable transfo

10 - 300 VA dimmable transfo

-

LED

5 - 60 W

1250 W

2 x 500 W

-

1250 VA

1250 W

150 W

1250 VA

2 x 1250 VA

-

-

1250 W

1250 W

150 W

1250 W

1250 W

100 W

1250 W

2 x 1250 W

1250 W

2 x 1250 W

9 - 60 W dimmable compact fluorescent

5 - 60 W dimmable LED

9 - 60 W dimmable compact fluorescent

5 - 60 W dimmable LED

Fluorescent lamps with

0-10 V ballast

-

-

-

Reducer motor for shutter

-

-

-

-

-

-

yes yes

500 VA

-

-

-

-

-

-

-

-

-

Local and remote control by Legrand APP

Wireless control

Legrand

Smart Home

Application

TM

Local control

Wi-Fi radio Gateway

Cat No. 0 883 10

Remote control

3G/4G

Cloud

Secure remote access and system backup

47

Valena

TM

Life mechanisms - selection charts

Mechanisms

Switches - 250 V~

One-way switch 10 AX

Double pole switch 16 AX

2-gang one-way switch 10 AX

Two-way switch 10 AX

Intermediate switch 10 AX

2-gang two-way switch 10 AX

Pull cord two-way switch 10 AX

Energy saving switch 10 AX

Switches with LED - 250 V~

Illuminated one-way switch 10 AX

One-way switch with indicator 10 AX

Illuminated 2-gang one-way switch 10 AX

Illuminated two-way switch 10 AX

Illuminated intermediate switch 10 AX

Illuminated 2-gang two-way switch 10 AX

Push-buttons 10 AX - 250 V~

Changeover push-button

Illuminated changeover push-button

Illuminated push-button 12 V

Illuminated label-holder push-button

Changeover push-button, bell symbol

Illuminated changeover push-button, bell symbol

2-gang changeover push-button

Pull cord changeover push button

Dimmers

Rotary dimmer without neutral

Push-dimmer without neutral

Dimmer - 1000 W (5 modules)

Dimmer 1 - 10V

Motion sensors

Motion sensor without neutral

Motion sensor without neutral, with override

Motion sensor with neutral

Roller blind switch

Roller blind switch

Roller blind push-button

48

White

7 521 01

7 521 02

7 521 05

7 521 06

7 521 07

7 521 08

7 521 23

7 521 65

7 521 10

7 521 04

7 521 28

7 521 26

7 521 48

7 521 09

Ivory

7 522 01

7 522 02

7 522 05

7 522 06

7 522 07

7 522 08

7 522 23

7 522 65

7 522 10

7 522 04

7 522 28

7 522 26

7 522 48

7 522 09

7 521 11

7 521 12

7 522 11

7 522 12

7 523 11

7 523 12

7 521 13 7 522 13 7 523 13

7 521 15

7 521 14

(3 different coloured inserts)

7 522 15 7 523 15

7 521 16

7 521 18

7 522 16

7 522 18

7 523 16

7 523 18

7 521 24 7 522 24 7 523 24

Aluminium

7 523 01

7 523 02

7 523 05

7 523 06

7 523 07

7 523 08

7 523 23

7 523 65

7 523 10

7 523 04

7 523 28

7 523 26

7 523 48

7 523 09

7 521 60

7 521 62

7 521 63

7 520 67

+ 7 548 90

7 521 70

7 521 72

7 521 73

7 522 60

7 522 62

7 520 67

+ 7 548 91

7 522 70

7 522 72

7 522 73

7 523 60

7 523 62

7 523 63

7 520 67

+ 7 548 92

7 523 70

7 523 72

7 523 73

7 521 29

7 521 30

7 522 29

7 522 30

7 523 29

7 523 30

Valena

TM

Life mechanisms - selection charts

Mechanisms

IP44 switches - 250 V~

One-way switch

Double pole switch

Two-way switch

2-gang one-way switch

2-gang two-way switch

Illuminated one-way switch

Illuminated two-way switch

Illuminated 2-gang two-way switch

IP44 push-buttons - 6 A - 250 V~

Changeover push-button

Changeover push-button, bell symbol

Illuminated cangeover push-button, bell symbol

IP44 socket outlet 16 A - 250 V~

Motion sensor

IP44 motion sensor

Motion sensor

IP44 plate

IP44 plate with flap

Thermostats

Electronic room thermostat

Floor heating thermostat

Programmable thermostat (5 modules)

Socket outlets 16 A – 250 V~

2P+E socket outlet with shutters

2P+E socket outlet for refurbishment (Screw 6 mm2 terminals)

2P+E socket with shutters, red,

2P+E socket with shutters, red, tamperproof

2P+E socket with shutters, green

2P+E socket with shutters, orange

2x2P+E socket outlet with shutters

2x2P+E socket outlet without shutters

TV sockets

Male TV socket - star (1,5 dB)

Male TV socket - terminal (10 dB)

TV socket - passthrough (14 dB)

TV-R-SAT socket - star (1,5 dB)

TV-R-SAT socket - terminal (10 dB)

TV-R-SAT socket - passthrough (14 dB)

White

7 521 51

7 521 64

7 521 56

7 521 55

7 521 58

7 521 61

7 521 67

7 521 59

7 521 71

7 521 75

7 521 76

7 531 19

7 521 77

7 540 21

7 521 33

7 521 34

7 521 35

7 531 20

7 531 28

7 531 26

7 531 27

7 531 51

7 531 60

7 531 61

7 531 52

7 531 64

7 531 65

7 522 33

7 522 34

7 522 35

7 532 20

7 532 28

7 531 29

7 531 31

7 533 29

7 532 29

7 532 26

7 532 27

Ivory

7 532 51

7 532 60

7 532 61

7 532 52

7 532 64

7 532 65

Aluminium

7 523 33

7 523 34

7 523 35

7 533 20

7 533 28

7 533 26

7 533 27

7 533 51

7 533 60

7 533 61

7 533 52

7 533 64

7 533 65

49

Valena

TM

Life mechanisms - selection charts

Mechanisms

RJ45 sockets

1xRJ45 Cat. 5e UTP

2xRJ45 Cat. 5e UTP

1xRJ45 Cat. 5e FTP

2xRJ45 Cat. 5e FTP

1xRJ45 Cat. 6 UTP

2xRJ45 Cat. 6 UTP

1xRJ45 Cat. 6 STP

RJ45 sockets

2xRJ45 Cat. 6 STP

1xRJ45 Cat. 6A STP

2xRJ45 Cat. 6A STP

Telephone sockets

1xRJ11

2xRJ11

USB chargers

Double USB power supply - 5 V - 1500 mA

Micro USB charging dock - 5 V - 1500 mA

2P+E/USB mixed socket

Other functions

Electronic key card switch

Blanking plate

Cable outlet with terminals

Cable outlet without terminals

Ventilation control (1-2-3)

Skirting light with motion detector

Extractible emergency lamp

Audio sockets

Loudspeaker socket

Double loudspeaker socket

HD15 + 3.5 mm Jack

HDMI 1.3

50

White

7 531 40

7 531 41

7 531 53

7 531 54

7 531 42

7 531 43

7 531 46

7 531 47

7 531 48

7 531 49

7 531 38

7 531 39

7 531 12

7 530 11

7 531 10

7 520 25

+ 7 551 60

7 551 80

7 531 33

7 531 34

7 521 32

7 521 74

7 520 69

7 531 72

7 531 78

7 531 70

7 531 71

7 532 12

7 530 12

7 532 10

7 520 25

+ 7 551 61

7 551 81

7 532 33

7 532 34

7 522 32

7 522 74

7 521 69

7 532 72

7 532 78

7 532 70

7 532 71

Ivory

7 532 40

7 532 41

7 532 53

7 532 54

7 532 42

7 532 43

7 532 46

7 532 47

7 532 48

7 532 49

7 532 38

7 532 39

Aluminium

7 533 40

7 533 41

7 533 53

7 533 54

7 533 42

7 533 43

7 533 46

7 533 47

7 533 48

7 533 49

7 533 38

7 533 39

7 533 12

7 520 25

+7 551 62

7 551 82

7 533 33

7 533 34

7 523 32

7 523 74

7 522 69

7 533 72

7 533 78

7 533 70

7 533 71

Valena

TM

Life plates selection chart

The same Cat. No. of plates can be mounted in horizontal or vertical position.

1

GANG

VALENA LIFE

2

GANG

3

GANG

2016

4

GANG

5

GANG

5 module open plate

Specific 2x2P+E (double socket outlet) single plate* double plate*

PLATES

White

White with labelholder (horizontal)

White IP 44 with flap

White/chrome

Ivory

Ivory with labelholder (horizontal)

Ivory/gold

Terracotta

Lime

Adria

Royal white

Royal ivory

Link

Aluminium

Pearl

Inox style

Copper style

Dark wood

Light wood

SURFACE-MOUNTING BOXES

Surface-mounting box white

Surface-mounting box ivory

Surface-mounting box aluminium

7 540 01 7 540 02 7 540 03 7 540 04 7 540 05 7 540 06 7 542 21 7 542 22

7 540 11 7 540 12 7 540 13

7 540 21

7 540 31 7 540 32 7 540 33 7 540 34 7 540 35

7 540 41 7 540 42 7 540 43 7 540 44 7 540 45 7 540 46 7 542 31 7 542 32

7 540 51 7 540 52 7 540 53

7 540 61 7 540 62 7 540 63 7 540 64 7 540 65

7 540 71 7 540 72 7 540 73 7 540 74 7 540 75

7 540 81 7 540 82 7 540 83 7 540 84 7 540 85

7 540 91 7 540 92 7 540 93 7 540 94 7 540 95

7 541 01 7 541 02 7 541 03 7 541 04 7 541 05

7 541 11 7 541 12 7 541 13 7 541 14 7 541 15

7 541 21 7 541 22 7 541 23 7 541 24 7 541 25

7 541 31 7 541 32 7 541 33 7 541 34 7 541 35 7 541 36 7 542 41 7 542 42

7 541 41 7 541 42 7 541 43 7 541 44 7 541 45

7 541 51 7 541 52 7 541 53 7 541 54 7 541 55

7 541 61 7 541 62 7 541 63 7 541 64 7 541 65

7 541 71 7 541 72 7 541 73 7 541 74 7 541 75

7 541 81 7 541 82 7 541 83 7 541 84 7 541 85

7 541 91 7 541 92

7 542 01 7 542 02

7 542 11 7 542 12

51

FOLLOW US

ALSO ON

www.legrand.com

www.youtube.com/user/legrand www.facebook.com/Legrand twitter.com/legrand_news pinterest.com/legrandgroup

World Headquarters

and International Department

87045 Limoges Cedex - France

: + 33 (0) 5 55 06 87 87

Fax: + 33 (0) 5 55 06 74 55

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
