Xonar U7 MKII
Xonar U7 MKII
7.1 USB Soundcard & Headphone
Amplifier
User Manual
E12129
First Edition
November 2016
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless
such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to the
owners’ benefit, without intent to infringe.
English
Table of Content
1.Introduction...................................................................................... 4
1.1
Package contents .............................................................. 4
1.2
System requirements.......................................................... 4
1.3General Specification.......................................................... 5
2.Hardware........................................................................................... 7
Xonar U7 MKII Audio Card................................................................. 7
Top view............................................................................................ 7
Rear view........................................................................................... 7
Bottom view........................................................................................ 7
3.
Driver Installation............................................................................. 9
Installing the Xonar U7 MKII Card Driver........................................... 9
4.
Connecting Speakers and Peripherals........................................ 10
4.1
Input connection ............................................................... 10
4.2
Output connection............................................................. 13
5.Troubleshooting............................................................................. 19
ASUS Xonar U7 MKII User Manual
3
1.Introduction
English
1.1
Package contents
Check your ASUS Xonar™ U7 MKII audio card package for the following items:
•
ASUS XonarTM U7 MKII 7.1-Channel USB Audio Card
•
S/PDIF TOSLINK optical adapter x 1
•
Quick Start Guide
•
USB Cable x 1
1.2
System requirements
To ensure a successful installation of the Xonar U7 MKII audio card, make sure
that your computer meets the following requirements:
4
•
USB port 2.0 and above
•
Microsoft® Windows® 10 / 8.1 / 7 (32/64bit)
•
Intel® Pentium® 4 1.4GHz or AMD Athlon 1400 CPU or faster CPU
•
More than 256MB system memory
•
More than 60MB available storage space for driver installation
ASUS Xonar U7 MKII User Manual
Items
English
1.3General Specification
Description
Audio Performance
Output Signal-to-Noise Ratio (AWeighted)
up to 114dB
Input Signal-to-Noise Ratio (AWeighted):
110dB
Output Total Harmonic Distortion +
Noise at 1kHz (A-Weighted) :
up to 0.0006% (104dB)
Input Total Harmonic Distortion +
Noise at 1kHz (A-Weighted) :
up to 0.0001% (-100dB)
Frequency Response (-3dB, 24bit/96kHz format):
< 10Hz to 46KHz
Output / Input Full-Scale Voltage
1 Vrms (2.828 Vp-p) for line out
1.3 Vrms (3.677 Vp-p) for headphone out
1 Vrms (3.677 Vp-p) for line in
Bus Compatibility
USB audio class
- USB audio class 2.0 for all functions
- USB audio class 1.0 for playback
Main Chipset
Audio Processor
Cmedia 6632AX High-Performance Sound
Processor (Max. 192KHz / 24bit)
D-A Converter of Digital Sources
Cirrus CS4398* 1 (120dB SNR, Max. 192kHz/24bit)
Cirrus CS4362* 1 (114dB SNR, Max. 192kHz/24bit)
A-D Converter for Analog Inputs
Cirrus CS5361* 1 (114dB SNR, Max. 192kHz/24bit)
Sample Rate and Resolution
Analog Playback Sample Rate and
Resolution
44.1K/48K/88.2K//96K/172.4K/192KHz @ 16/24bit
Analog Recording Sample Rate
and Resolution
44.1K/48K/88.2K//96K/172.4K/192KHz @ 16/24bit
S/PDIF Digital Output
44.1K/48K/88.2K//96K/172.4K/192KHz @ 16/24bit
ASIO 2.0 Driver Support
44.1K/48K/88.2K//96K/172.4K/192KHz @ 16/24bit
ASUS Xonar U7 MKII User Manual
5
English
Items
Description
I/O Ports
Analog Output Jack
RCA (phone) jack * 2 (Front left / Front right)
3.50mm mini jack * 3 for surround
(Side/Center-Subwoofer/Rear-out)
3.50mm mini jack * 1 (Headphone out)
Analog Input Jack
3.50mm mini jack * 1 (Shared by Line-In / Mic-In)
Button
Output volume knob/Output selection / Microphone
Volume)
Digital S/PDIF Output
High-bandwidth coaxial port supports 192HKz/24bit
with one S/PDIF TOSLINK optical adapter
Driver Features
Operating System
6
Windows® 10 / 8.1 / 7 (32/64bit)
ASUS Xonar U7 MKII User Manual
11 2
Xonar
1 U7 MKII Audio Card
Top view
1 22 3
English
2.Hardware
1 2 33 4
1
2
1 2 3
44 5
2
1 2 3
3
3 4 55 6
1
1 2 3
4
4 5 66 7
4
1
2
2
3 4
5
5 6 77 8
5
1 2
3
3
4 5 6 7 88 9
6
Rear view
2 3
4 6
4
7
5 6 7 8 99 10
7
3 4
5
8
5 6 7 8 9 10
10 11
8
4 5
6
9
11 12
6 7 8 9 10 11
9
Bottom
10 view 57 6 8 79 10 11 12
12 13
10
11
68 7 9 810 11 12
13
11 13
9
79 8 10 11
12
12 13
12
10
9
810 11 12
13
13
13
11
9111012
13
10
121113 12
11 12
13U7 MKII User Manual
13 ASUS Xonar
7
No.
English
1.
Items
Description
Headphone Out port
Connect your headphone to this port.
Microphone In port
Connect your external PC microphone to this 3.5mm
port for voice input.
Line In port
Connect analog devices like MP3 players, CD players,
music synthesizers, and other line-level sound sources
to this 3.5mm port for audio recording or processing.
2.
3.
Microphone Volume
Control
Press to increase or decrease microphone volume.
4.
Output Selection
Indicator
LED indicator indicates different output selection
(Headphone/Speaker/S/PDIF).
5.
Output Selection/
Volume Control
Rotate to adjust the playback volume. Press to select
an output source.
6.
Front (R) Out port
For 2/4/5.1/7.1 channel speaker systems, connects to
the front right input on the powered speakers.
7.
Front (L) Out port
For 2/4/5.1/7.1 channel speaker systems, connects to
the front left input on the powered speakers.
8.
Side Surround Out
port
Connects to the surround channel input on 7.1 powered
analog speakers.
9.
Center/Subwoofer Out
port
Connects to the center/subwoofer input on 5.1/7.1
powered analog speakers.
10.
Rear Out port
Connects to the back surround input on 4/5.1/7.1
powered analog speakers.
11.
S/PDIF Out port
Coaxial digital output port. Connects to an external
digital decoder or digital speaker systems, Home
Theater systems, AV receivers for outputting digital
audio including PCM, Dolby Digital, DTS, etc. Connects
to the surround channel input on 4/5.1/7.1 powered
analog speakers. Through S/PDIF-Out it will deliver
stereo PCM and use DDL for 5.1 channel.
12.
USB Port
Connects to your computer using a USB Type B-A lead.
13.
USB Audio 1.0/2.0
switch
Move this switch to toggle between USB Audio 2.0
and USB Audio 1.0 connection. Use USB Audio 1.0
for plug and play. Use USB Audio 2.0 on a mac (Apple
computer).
USB Audio 1.0/2.0 switch is located at the bottom side of the audio card. USB
Audio 1.0 connection has the following limitations:
8
•
Only supports playback features.
•
7.1 speakers, Headphone, Mic In / Line-In, and SPDIF Out can only
support sample rates of 44.1KHz/48KHz @16-bit.
ASUS Xonar U7 MKII User Manual
Driver Installation
English
3.
Installing the Xonar U7 MKII Card Driver
After installing the Xonar U7 MKII audio card on your computer, you need to
install the device driver that enables the Xonar U7 MKII audio card to work with
Windows® operating system. Go to ASUS official website www.asus.com to
download the latest driver.
The driver is required only when you connect the Xonar U7 MKII to a PC or
notebook.
ASUS Xonar U7 MKII User Manual
9
English
4.
Connecting Speakers and Peripherals
4.1
Input connection
4.1.1
Connecting to a USB 2.0 port on your computer
OR
PC
NB
1
USB
2
3
No.
1.
Items
USB Port
Description
Connects to your computer using a USB Type B-A
lead.
4
5
6
7
8
9
10
10
ASUS Xonar U7 MKII User Manual
11
Connecting digital audio systems
English
4.1.2
AVR
S/PDIF
1
2
3
No.
Items
1.
S/PDIF Output port
Description
Connect an AVR to this S/PDIF output port.
4
5
6
7
8
9
10
11
ASUS Xonar U7 MKII User Manual
11
4.1.3Connecting microphone / Line-In
English
OR
1
2
HP Out
Mic In/Line In
3
4
No.
1.
Items
5
Microphone In /
Line In port
6
7
Description
Connect the microphone’s 3.5mm plug into this Mic-In
port for voice communication, recording, or karaoke.
Connect the 3.5mm plug of the CD/MP3 Player or any
other Line level analog audio sources into this Line-In
port for sound recording.
8
9
10
12
ASUS Xonar U7 MKII User Manual
11
Output connection
4.2.1
Connecting Stereo Headphones
1
HP Out
English
4.2
Mic In/Line In
2
3
No.
1.
Items
4
Headphone Out
Port
5
Description
The Headphone Out port has a built-in high-quality
amplifier to drive headphones. Connect your stereo
headphones directly to this port.
6
7
8
9
10
11
12
ASUS Xonar U7 MKII User Manual
13
4.2.2
Connecting 5.1 channel headphones
English
1
1 2
No.
1.
2.
1
2 3
1 2
3 4
2 3
4 5
3 4
5 6
4 5
6 7
5 6
7 8
9Description
8
7
Connects
to
the
front
input port of 5.1 channel
6 headphones using theright
RCA cable.
10left input port of 5.1 channel
front
Front (L) Out port Connects to the
using the RCA cable.
7 8headphones 9
Items
Front (R) Out port
3.
Center/Subwoofer
Out port
Connect the Center/Bass-channel 3.5mm plug of your
11 into this jack.
5.1 channel10
headphone
9
4.
Rear Surround
Out port
Connects to the rear surround input port of your 5.1
channel headphone.
8
9 10
11 12
10 11
12 13
11 12
13
12 13
14
ASUS Xonar U7 MKII User Manual
13
4.2.3
Connecting analog speaker systems
English
Connecting 2 channel speakers
1
1 2
2 3
3 4
4 5
5 6
No.
Items
6
1.
Front (R) Out port
2.
Front (L) Out port
7
Description
Connects to the front right input port of 2 channel
speakers using the RCA cable.
Connects to the front left input port of 2 channel
8 using the RCA cable.
7 speakers
8
9
9 10
10 11
11 12
ASUS Xonar U7 MKII User Manual
12 13
15
Connecting 4 channel speakers / power amplifier
English
OR
1
Amplifier
No.
1.
2.
3.
1
2
1 2
3
2 3
4
3 4
5
4 5
6
5 6
7
Items
Description
to8the front right input port of 4 channel
Front (R) Out
6 port7 Connects
speakers.
Connects to the front left input port of 4 channel
Front (L) Out port
7 8 speakers. 9
Rear Surround Out
port
8 9
Connects to the rear surround input port of 4 channel
speakers.
10
9 10
11
10 11
12
11 12
13
12 13
16
ASUS Xonar U7 MKII User Manual
13
English
Connecting 5.1 channel speakers
1
1 2
No.
1
2 3
1 2
3 4
2 3
4 5
3 4
5 6
4 5
6 7
5 6
7 8
Items
6 7
1.
Front (R) Out port
2.
Front (L) Out port
3.
4.
Description
8 9
Connects to the front right input port of 5.1 channel
speakers.
Connects to the 10
9 front left input port of 5.1 channel
7 8speakers.
Connects to the Center and Subwoofer input ports of 5.1
Center/Subwoofer
Out port
10 11
9channel speakers.
8
Rear Surround Out Connects to the rear surround input port of 5.1 channel
speakers.
port
11 12
9 10
10 11
12 13
11 12
13
ASUS Xonar U7 MKII User Manual
12 13
17
Connecting 7.1 channel speakers
English
1
1 2
1 2 3
1 2 3 4
1 2 3 4 5
2 3 4 5 6
3 4 5 6 7
No.
1.
2.
3.
4.
5.
4 5 6 7 8
9
5 6 7 8
Items
9 10 Description
8
7
Connects
to the front right input port of 7.1 channel
Front (R) Out
port
6
speakers.
Connects
the front left input port of 7.1 channel
Front (L) Out port
9 10 to11
7 8 speakers.
Side Surround Out
port
Connects to the Left surround and Right surround input
ports 11
of 7.1 12
channel speakers.
9 10
8
Connects to the Center/Subwoofer input port of 7.1
Center/Subwoofer
channel speakers using the mini-jack cable.
Out port
12 the rear surround input port of 7.1 channel
11
10
9
Connects to13
Rear Surround Out
port
speakers.
10 11 12 13
18
ASUS Xonar U7 MKII User Manual
11 12
13
5.Troubleshooting
I cannot install the audio card driver in my PC.
English
1.
(1). Ensure that you have switched the USB sound card to USB Audio 2.0 and
plugged it to the USB port.
(2). Make sure that the LEDs light up.
(3). Ensure that you have the latest driver version.
(4). Check that the Windwos hardware Device Manager has detected the device.
(5). Restart your computer.
(6). Try to plug the device into another USB port.
2. I cannot find the Xonar U7 MKII Audio Center.
(1). Make sure you have installed the driver.
(2). Find the Xonar U7 MKII Audio Center icon in the system tray on the right
bottom of the screen. Double click the icon to launch the Xonar U7 MKII
Audio Center utility.
(3). If you cannot find the icon in the system tray, go to the Windows Control
Panel and double click the Xonar U7 MKII Audio Center icon to make it
visible in the system tray again.
(4). After the driver installation is complete, it’s recommended that you reboot
your computer to complete the setup. If the icon still doesn’t appear, please
try installing the driver package again.
3. I can’t hear any sound from my analog speakers
(1). Ensure that you have connected speakers properly and have powered on
your speakers.
(2). Ensure that the device master volume or the software player has NOT been
muted in the Xonar U7 MKII Audio Center.
(3). Ensure that the output LED indicator matches the output source configured in
the device.
ASUS Xonar U7 MKII User Manual
19
English
(4). If you are using Dolby Digital Live encoder through the S/PDIF output, the
analog output will be muted to get rid of the interference between your digital
speaker system and analog speakers or headphones. Please check if this is
the case.
(5). Please go to the sound and audio device of Windows® Control Panel to check
whether the playback default device is set to Xonar U7 MKII Audio Device,
instead of other onboard AC97 or HDA codec device. If it’s not, please set it
to Xonar U7 MKII Audio Device and restart your applications.
(6). Restart your computer.
4. I can’t hear any sound from the S/PDIF output
(1). Ensure that you have enabled S/PDIF output in the Audio Center GUI (Main
page).
(2). Ensure that you have connected the correct S/PDIF output jack in the card to
the decoder’s (AV receiver) S/PDIF input jack.
(3). You may need to select the correct input and mode of your decoder or AV
receiver. For Dolby Digital or DTS output, double check that the AV receiver
is in that decoding mode.
(4). If you are using 192KHz PCM output, make sure that your decoder can
support 192KHz decoding. Try changing it to 44.1K or 48KHz first.
20
ASUS Xonar U7 MKII User Manual
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
