Moderro Interactive Experience Platform

Moderro Interactive Experience Platform

31 July 2017

Moderro Interactive Experience

Platform

Developer Guide

Version 2.6

Copyright ©

31 July 2017

Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Table of Contents

Preface ...................................................................................................................................................................... 4

Purpose ................................................................................................................................................................................................................... 4

Audience ................................................................................................................................................................................................................ 4

Organization ......................................................................................................................................................................................................... 4

Document Conventions .................................................................................................................................................................................... 5

Related Documentation ................................................................................................................................................................................... 5

System Overview ................................................................................................................................................... 6

Chapter Overview .............................................................................................................................................................................................. 6

System Overview ................................................................................................................................................................................................ 7

Properties ..................................................................................................................................................................................................................... 7

Management System ............................................................................................................................................................................................... 7

Management Protocol ............................................................................................................................................................................................ 8

Applications ................................................................................................................................................................................................................ 8

Thin Client Features ................................................................................................................................................................................................ 9

Cobra Browser .................................................................................................................................................................................................. 13

Cobra JavaScript API ...................................................................................................................................................................................... 13

Japanese Fonts .................................................................................................................................................................................................. 15

APIs for the IEM Server ..................................................................................................................................... 16

Chapter Overview ........................................................................................................................................................................................... 16

How to Use a Service API ............................................................................................................................................................................. 17

API Authorization.................................................................................................................................................................................................. 17

Input Data Format ................................................................................................................................................................................................ 17

Output Data Format ............................................................................................................................................................................................ 18

General Notes .......................................................................................................................................................................................................... 19

Performance Service Examples ....................................................................................................................................................................... 19

Basic API for Device List, Create, Edit, List of Groups, and Profile Properties (examples) .................................................. 20

Schedule Rules Format and Examples ......................................................................................................................................................... 21

Service API Documentation ........................................................................................................................................................................ 23

Account Service ...................................................................................................................................................................................................... 23

Address Service ....................................................................................................................................................................................................... 24

Authentication Service ........................................................................................................................................................................................ 25

Company Service .................................................................................................................................................................................................... 26

Contact Service ....................................................................................................................................................................................................... 27

Country Service ....................................................................................................................................................................................................... 28

Device Service .......................................................................................................................................................................................................... 29

Device_model Service ........................................................................................................................................................................................... 30

Event Service ........................................................................................................................................................................................................... 31

Firmware Service................................................................................................................................................................................................... 33

Group Service .......................................................................................................................................................................................................... 34

Image Service .......................................................................................................................................................................................................... 36

Notification Service .............................................................................................................................................................................................. 37

Person Service ......................................................................................................................................................................................................... 39

Policy Service ........................................................................................................................................................................................................... 40

Copyright © 31 July 2017 Moderro Technologies, Inc. 2

Moderro Interactive Experience Platform

Product Service ....................................................................................................................................................................................................... 42

Profile Service ......................................................................................................................................................................................................... 43

Role Service .............................................................................................................................................................................................................. 47

Schedule Service ..................................................................................................................................................................................................... 48

Specification Service ............................................................................................................................................................................................ 50

System Service ......................................................................................................................................................................................................... 52

User Service .............................................................................................................................................................................................................. 53

Widgets ................................................................................................................................................................... 55

Chapter Overview ........................................................................................................................................................................................... 55

Plugins API ......................................................................................................................................................................................................... 55

Camera Widget ................................................................................................................................................................................................. 56

DrmViewer Widget ......................................................................................................................................................................................... 60

Jabber Client Framework (JCF) Widget ................................................................................................................................................. 62

PdfViewer Widget ........................................................................................................................................................................................... 81

RemoteDesktop Widget ................................................................................................................................................................................ 83

SipPhone Widget ............................................................................................................................................................................................. 86

Ticker Widget ................................................................................................................................................................................................. 100

VideoPlayer Widget ..................................................................................................................................................................................... 105

VncViewer Widget ....................................................................................................................................................................................... 113

WebBrowser Widget ................................................................................................................................................................................... 117

WebClip Widget ............................................................................................................................................................................................ 120

WebRTC Widget ............................................................................................................................................................................................ 121

JavaScript Global Objects .............................................................................................................................. 124

Chapter Overview ........................................................................................................................................................................................ 124

global.applicationData Object ................................................................................................................................................................. 125

global.database Object ............................................................................................................................................................................... 128

global.device Object ..................................................................................................................................................................................... 132

global.display Object ................................................................................................................................................................................... 135

global.ir Object............................................................................................................................................................................................... 138

global.keyboard Object .............................................................................................................................................................................. 141

global.magstripe Object ............................................................................................................................................................................. 144

global.mediaCache Object ......................................................................................................................................................................... 147

global.network Object ................................................................................................................................................................................ 152

global.networkCache Object .................................................................................................................................................................... 154

global.printer Object ................................................................................................................................................................................... 159

global.registry Object .................................................................................................................................................................................. 165

global.resources Object .............................................................................................................................................................................. 170

global.scanner Object .................................................................................................................................................................................. 171

global.serialPorts Object ........................................................................................................................................................................... 176

global.system Object ................................................................................................................................................................................... 181

global.videoEncoder Object ..................................................................................................................................................................... 184

global.vncServer Object ............................................................................................................................................................................. 198

global.window Object ................................................................................................................................................................................. 202

3 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Preface

This preface describes the purpose, audience, content organization, and conventions in this guide, and provides information on the related documents.

Purpose

Audience

Organization

Document Conventions

Related Documentation

Purpose

This guide provides information about the Moderro Interactive Experience platform system. It describes different APIs for the IEM server and configuration for widgets. Additionally, it has information about standard and non-standard global objects.

Audience

This guide is intended for web developers and application programmers who will develop applications for the kiosk.

Organization

Title

System Overview

Purpose

Provides an overview of the Moderro Interactive Experience Platform system.

APIs for the IEM Server Provides information about APIs for the IEM server, including how to use a service API and service API documentation.

Widgets Provides an overview of the supported widgets that can be configured and controlled using javascript.

JavaScript Global Objects Provides an overview on the javascript global objects that allow web applications to be better integrated with the IEC.

Copyright © 31 July 2017 Moderro Technologies, Inc. 4

Moderro Interactive Experience Platform

Document Conventions

Convention Indication

bold font

italic font

Commands, keywords, and user-entered text appear in the bold font.

Document titles, new or emphasized terms, and arguments for which you assign values are in the italic font.

[ ]

{x | y | z}

[x | y | z] string courier font

courier bold

font

< >

[ ]

!, #

Option > Option

Elements in the square brackets are optional.

Required alternative keywords are grouped in braces and separated by vertical bars.

Optional alternative keywords are grouped in brackets and separated by vertical bars.

A non-quoted set of characters. Do not use quotation marks around the string or the string will include the quotation marks.

Terminal sessions and information that the system displays appear in the courier font.

Command names and samples appear in the

courier bold

font.

Non-printing characters, such as passwords, are in the angle brackets.

Default responses to the system prompts are in the square brackets.

An exclamation point (!) or a pound sign (#) at the beginning of a line of code indicates a comment line.

Used to describe a series of menu options.

Note

Means reader take note. Notes contain suggestions or references to materials that are not covered in the guide.

Related Documentation

Moderro Interactive Experience Platform Installation Guide

Copyright © 31 July 2017 Moderro Technologies, Inc. 5

Moderro Interactive Experience Platform

System Overview

Last Revised: October 27, 2016

This product includes cryptographic software written by Eric Young

( [email protected]) . This product includes software written by Tim Hudson

( [email protected]) .

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit.

( http://www.openssl.org/).

Chapter Overview

This guide is intended for web developers and application programmers who will develop applications for the kiosk.

This chapter provides an overview of the Moderro Interactive Experience Platform system. The topics in this chapter include:

System Overview

Properties

Management System

Management Protocol

Applications

Thin Client Features

Security

Application Development

JavaScript Injection

User-Agent Rules

Content Caching

Off-Line Caching

Cobra Browser

Cobra JavaScript API

Japanese Fonts

Copyright © 31 July 2017 Moderro Technologies, Inc. 6

Moderro Interactive Experience Platform

System Overview

This section contains some details to help you to understand how the entire platform works.

Moderro's Interactive Experience Platform includes two components: Moderro Interactive Experience

Client (IEC), which is the thin client, and Moderro Interactive Experience Manager (IEM), which is the management server. The IECs can be configured and controlled remotely using the IEM.

The IEC is a Linux-based device, which is designed to run feature rich HTML and JavaScript applications. The central part of its software is a specially designed embedded web browser called

Cobra.

Properties

IEC software is configured and controlled using properties. A property is similar to a Microsoft

Windows Registry item, but provides much more functionality. For example, in contrast to a registry item, the IEC properties have a very rich type system and have an ability to subscribe to property changes.

A software engineer will declare a property with some type. In contrast to other systems, the IEC supports virtually any type - an integral type (e.g. enumerate, integer, boolean, real, etc.), a collection type (e.g. structure, list, map, hash, set, etc.), or even a composition of those types (e.g. list of structures or a field of the structure can be a map of an integer or a vector of a string).

A property can be declared persistent, which means that it can contain a configuration parameter for the application. At the same time that property can be used from another application to control or get information from the application, which owns the property. That property can be replicated to and from the IEM, and thus, provide a way to configure the application remotely.

Management System

The IEM is an appliance. Its user interface is implemented as a web application. It does not require the installation of any software on the administrator's computer. The user interface's terminology is similar to those of Microsoft Management Server. For example, the IEM uses the terms that a Windows administrator would be familiar with such as domain, group, profile, and policy.

The IEM requires HTTPS to access it from the IECs that you want to control and from the administrators' computers.

In contrast to other management systems, the IEM does not require the IEC and the management system to be within the same network. Hence, the IECs can be located behind firewalls. To support firewalls, the IEM's management protocol is designed as a one way protocol, which means the IEC always initiates the communication.

The management protocol is based on HTTPS, consists of requests and responses, and is synchronous.

In addition to HTTPS, the IEM protocol uses a token-based device authentication algorithm to increase security. When an IEC is registered in the IEM, it receives a token from the IEM. In every request the

IEC must provide that token to be authenticated in the IEM. In every response, the IEM sends a new token, which must be used in the next IEC request.

The IEM supports different versions of IEC firmware at the same time.

7 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Existing systems can be integrated with the IEM using a protocol based on XML and HTTPS.

Management Protocol

The following is a list of requests that the current revision of management protocol supports:

Is available: Asks the IEM if it is available. The IEM can reply that it is not available such as when it is undergoing maintenance.

Is registered: Asks if the IEC is registered in the IEM.

Register: Registers the IEC in the IEM. To perform this request successfully, the device must provide a name and a password of a user who is registered in the management system and has the right to register devices.

Unregister: Unregisters the IEC in the IEM. To perform this request successfully, the device must provide a name and a password of a user who is registered in the IEM and has the right to unregister devices.

Load device information: Loads IEC information from the IEM including device name, description, and location.

Save device information: Saves IEC information to the IEM.

Load device profile: Loads the IECs properties from the IEM.

Save device profile: Saves the IEC's properties to the IEM.

Sync device profile: Synchronizes the IEC’s properties with the IEM.

Ping: Reports IEC’s device status to the IEM.

Save events: Saves IEC’s device events to the IEM.

Save screenshot: Saves a screenshot from the IEC to the IEM.

Applications

The core application in this solution is a web browser named Cobra. Thus its applications are essentially web applications.

Cobra is not only a browser, but also an application environment. That means it contains many features to meet specific needs of customer applications. For example, it allows you to control the device entirely.

From a web application you can access any property of any application in the system, so, you have a full control over the device your application is running on.

In addition to that, you can easily control peripherals connected to the system such as printers, web cameras, and other devices connected via the serial port. For example, you can print a resource given by a URL (i.e. HTML page, PDF document, or image) from your web application without a print dialog box appearing or set all the printing parameters for your printing job (i.e. paper size, resolution, etc.).

All those features are implemented asynchronously so you do not stop your web application animations or interactivity.

There are also many specialized widgets available that can be used in your web applications. The widgets provide a functionality which is very difficult to implement in JavaScript. For example, the

Copyright © 31 July 2017 Moderro Technologies, Inc. 8

Moderro Interactive Experience Platform

VideoPlayer widget supports most video and audio formats and codecs. In contrast to regular video players implemented as NP plugins, the VideoPlayer widget has an easy to use JavaScript API and features that other players lack such as smart caching. Another example is the Ticker widget. Although the Ticker widget can be implemented in JavaScript, it works much faster being implemented in C++.

See the Moderro Interactive Experience Platform Content Creation Guidelines for the widgets.

Thin Client Features

The thin client, otherwise known as the IEC, contains many features that you should be aware of in order to build applications for it:

Security

Application development

Third party systems integration

JavaScript injection

User-agent rules

Content caching

Off-line caching

Security

Virus free environment: Since the IEC is a Linux-based device, it cannot be infected by viruses.

Read only file system: All file systems that contain device software are read-only file systems. They cannot be remounted in read-write mode. Thus you can be sure the device software is not altered by an intruder. The IEC has two read-write file systems: a small read-write file system to store settings and another to store content cache. Binary applications, however, cannot be run from those file systems.

No third party binary software: The IEC does not allow any third party binary software to run on it.

The only type of applications allowed are web applications (i.e. applications written using HTML and JavaScript). This type is totally controlled as they are executing in the browser's security sandbox.

Application Development

APIs: The IEC can only run web applications. However, in contrast to regular desktop web browsers, the IEC provides proprietary APIs to create feature rich applications. Those APIs allow applications to communicate with various types of peripherals, such as cameras, printers, optical scanners, barcode scanners, magnetic card readers, remote controls, etc. It is even possible to control a peripheral via a serial port from your web application.

Feature rich widgets: In addition to APIs, the IEC provides visual components to enhance the capabilities of your application. The PDF viewer and video player are examples of widgets.

Instead of viewing PDF documents or playing video in desktop web applications as you regularly do, you will be able to have complete control over those parts of your application. For example, you can open a PDF document on any page, turn over the pages, print any page, etc.

Copyright © 31 July 2017 Moderro Technologies, Inc. 9

Moderro Interactive Experience Platform

You cannot do that with a regular PDF reader plug-in within your desktop browser.

Touch screens support: The IEC supports a wide variety of touch screens.

Dual head support: The UEC can work with two monitors at the same time.

Voice over IP support: The IEC supports IP telephony using Session Initiation Protocol (SIP). It is compatible with Cisco VoIP products, such as Cisco Unified Communications Manager

(CUCM).

Video conference support: Applications can easily utilize its video conferencing capabilities.

JavaScript Injection

This feature allows you to incorporate JavaScript code into an alien web page. This feature gives a way to modify existing web content to better fit in the current application environment. If you want to show a web site as a part of your application in iframe and that alien web site contains controls to do a search, you can remove those controls with JavaScript injection.

To turn this feature on you must set two properties:

1.

2.

The browser.content.javascript.injection.enabled property must be set to ‘true’.

The browser.content.javascript.injection.rules must contain injection rules. This property is a map with URL wildcard as a key and JavaScript code as a value.

Both properties are runtime properties so you are able to change their values inside your application and those changes become effective immediately.

With this feature turned on, Cobra loads an URL and checks that URL against injection rules. If one rule matches, Cobra executes the corresponding JavaScript code from that rule for the current window object.

If multiple rules match, the code from all those rules will be executed.

Note

Cobra's global JavaScript objects are registered before any injection so you are able to use them in the injected code.

The following example shows how to use JavaScript injection in an application

(file.../.../test/js/injection.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>5

<title>..:: JavaScript injection example ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#000000; color :

#eeeeee; font-weight:

Copyright © 31 July 2017 Moderro Technologies, Inc. 10

Moderro Interactive Experience Platform

bold; fontfamily: Arial; font-size: 20px; color : #eeeeee;

}

</style>

<script type="text/javascript"> function init ()

{ global . registry .setValue("browser.content. javascript . injection .enabled",

"true"); global . registry .setValue("browser.content. javascript . injection . rules",

'<map><item><key>*osnews*</key><value>function hide () { document.getElementById("sidebar").style.display = "none"; } addEventListener("load", hide , false);</value></item></map>'); document.getElementById("content").src = "http://www.osnews.com";

}

</script>

</head>

<body onload="init()">

This application hides sidebar on OS News web site.

<br />

<br />

<iframe id="content" width="1024" height="768" />

</body>

</html>

Sample code 2 (file ../../test/js/useragent-print.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: Print User-Agent ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#ff0000; color: #eeeeee; font-weight:

Copyright © 31 July 2017 Moderro Technologies, Inc. 11

Moderro Interactive Experience Platform

bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script language="JavaScript"> function init ()

{ document.getElementById("userAgent").innerHTML = '"' + navigator.userAgent +

'"';

}

</script>

</head>

<body onload="init()">

Browser User-Agent is: <span id="userAgent" />

</body>

</html>

Content Caching

When you develop an application that must be usable when you have limited bandwidth, content caching becomes a very important feature of your application.

Regular desktop browsers do not give your application the ability to fully control content caching but

Cobra has special APIs to control content caching. Regular web content like HTML documents,

JavaScript code, CSS code, images, etc. are distinguished from media content like video and audio files.

There are two different APIs to control caching for both types of content: global.networkCache and global.mediaCache.

Off-Line Caching

The user can set properties within a device profile or applied policy in the IEM that enables aggressive caching on an IEC. As a result, web and media content is cached by the IEC so that if the IEC becomes off-line (connection to the startup URL is lost), it can still display the content that users had previously interacted with before going off-line.

Note

Only static page content is cached. Images and embedded videos are also cached. Dynamic page content is NOT cached.

Copyright © 31 July 2017 Moderro Technologies, Inc. 12

Moderro Interactive Experience Platform

In order to activate aggressive caching, you must first configure property settings in the IEC’s device profile or an applied policy within the IEM. Refer to the Moderro Interactive Experience Client 4600

Series User Guide for instructions on how to configure off-line caching.

Cobra Browser

The name Cobra is derived from COBALT Browser, where COBALT is a C++ library that is used for embedded applications device software.

As explained above, Cobra is both a web browser and application environment. It contains features for kiosk specific web applications. In contrast to regular desktop browsers, such as Mozilla Firefox or

Google Chrome, Cobra is not only a browser for HTML documents, but a platform for feature rich applications. This platform is tightly integrated with device's hardware, its capabilities are far beyond the capabilities of regular desktop browsers. For example, in your HTML and JavaScript application you can easily implement a video conferencing or a communication with monitor, connected to the device via serial port.

From a web application developer's prospective, those new features are represented by new JavaScript objects and functions introduced by Cobra.

Cobra assumes that a touch screen is connected and end users are operating it with either fingers or a stylus. A mouse and keyboard are supported also.

There are specialized widgets to use in kiosk web applications. Those widgets provide a functionality which is very hard if even possible to implement in JavaScript. As an example, there is a videoplayer, which supports most of video and audio formats and codecs. In contrast to regular video players implemented as NP plugins, this widget has a very rich and easy to use JavaScript API, has some interesting features (like smart caching) other players lack. Another example is the ticker widget, which can be implemented in JavaScript, but being implemented in C++ works much faster. In addition to regular plugins support (like Adobe Flash Player), Cobra provides several proprietary widgets to simplify developer's life. Those widgets can be configured and controlled from JavaScript.

Cobra JavaScript API

In contrast to statically typed programming languages like C and C++, there is no common way to declare JavaScript classes, object prototypes, and functions. However, it is very helpful for a developer to have such a description as a reference. So, instead IDL-like notation is used to solve this problem.

The following is an example of IDL-like notation: interface Factorial

{ readonly attribute int lastValue; int value(in int n) const;

};

In the example above, it declares a Factorial interface which allows you to calculate n! with function value() and to get the last calculated value using lastValue read-only attribute.

Copyright © 31 July 2017 Moderro Technologies, Inc. 13

Moderro Interactive Experience Platform

Note

Consider the statement "object A implements interface B". However, if you try to call typeof() function for object A you will not see B as the result. The result will be Object. Interfaces are introduced here to simplify objects description.

Cobra introduces a new communication mechanism for JavaScript objects. It is called signals and slots, a mechanism which comes from NOKIA’s Qt library that Cobra had been built upon. Signals and slots are used for communication between objects. The signals and slots mechanism is a central feature of

Cobra JavaScript API. In GUI programming, when one widget is changed, we often want another widget to be notified. More generally, we want objects of any kind to be able to communicate with one another.

For example, if a user clicks a Close button, the desire is to have the window's close() function to be called. A signal is emitted when a particular event occurs. Cobra's JavaScript classes have many predefined signals. As an example of signal-slot mechanism usage network operations can be mentioned.

Since web applications are primarily related to network, the majority of new JavaScript classes, introduced by Cobra, are network-related as well. So, to allow web application to have a responsive user interface, all those new classes perform asynchronously. To support that asynchrony, Cobra uses signals and slots.

Note

At first, you can think about signals like about JavaScript events with a different API, and about slots like about JavaScript event handlers.

Example

The following is a Clock JavaScript class interface: interface Clock

{ readonly attribute Date timestamp; signals: void tick();

};

This interface declared signal tick() which is fired by the object every second. To use this signal in

JavaScript you can write the following code. var clock;

... function updateClock

{ document.getElementById("textClock").innerHTML = clock.timestamp.toString();

} function init()

{ clock.tick.connect(updateClock);

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 14

Moderro Interactive Experience Platform

Assuming function init() is called when HTML document is loaded, that function connects signal tick() to slot updateClock() . As the result the innerHTML attribute of DOM element with textClock id will be changed to current timestamp every second.

Japanese Fonts

For 2.5, four new Japanese fonts were added:

1.

IPA Gothic

2.

3.

4.

IPA P Gothic

IPA Mincho

IPA P Mincho

To use the fonts in applications, use the following values for the font-family variable: font-family: "IPAGothic"; font-family: "IPAPGothic"; font-family: "IPAMincho"; font-family: "IPAPMincho";

Copyright © 31 July 2017 Moderro Technologies, Inc. 15

Moderro Interactive Experience Platform

APIs for the IEM Server

Chapter Overview

This chapter provides information about APIs for the IEM server.

Topics in this document include:

“How to Use a Service API”

“API Authorization”

“Input Data Format”

“Output Data Format”

“General Notes”

“Performance Service Examples”

“Basic API for Device List, Create, Edit, List of Groups, and Profile Properties (examples)”

“Schedule Rules Format and Examples”

“Service API Documentation”

“Account Service”

“Address Service”

“Authentication Service”

“Company Service”

“Contact Service”

“Country Service”

“Device Service”

“Device_model Service”

“Event Service”

“Firmware Service”

“Group Service”

“Image Service”

“Notification Service”

“Person Service”

“Policy Service”

“Product Service”

“Profile Service”

Copyright © 31 July 2017 Moderro Technologies, Inc. 16

Moderro Interactive Experience Platform

“Role Service”

“Schedule Service”

“Specification Service”

“System Service”

“User Service”

How to Use a Service API

API Authorization

When calling the service, append the parameter “auth” at the end:

&auth={“account”:”account_name”,”user”:”user_login”,”password”:”user_password”}

For example: http://[service host]//xml/?service=specification.set_action_property&args=[69,”screenmonitor.update”,

1]&auth={“account”:”Root”,”user”:”Administrator”,”password”:”TopSecret”}

Input Data Format

The XML gate URL is http://your-service-host/xml?[service].[method] where:

[service] - service name (auth, account, device,...)

[method] - service method name

You can use either the XML (recommended for long data input) or JSON (recommended for small data input) arguments format.

If you want to use the XML input, you must send a GET or POST request with one argument "data". The argument "data" must contain XML with input parameters in this format:

Use the GET or POST parameter "data" to send arguments in XML format:

<xml>

<param1_name>[param1_value]</param1_name>

<param2_name>[param2_value]</param2_name>

<param3_name>[param3_value]</param3_name>

...

</xml> where: param[X]_name - name of argument X param[X]_value - value of argument X

17 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

For example: http://your-service-host/xml/?service=user.get_by_id&data=<xml><id>1</id></xml> data is:

<xml>

<id>1</id>

</xml>

First argument is called "id" and has the value 1.

If you want to use the JSON input, you must send GET with the argument “args”. The argument "args" must contain a JSON-object or JSON-array with arguments.

For example: http://your-service-host/xml/?service=user.get_by_id&args={"id":"1"}

OR http://your-service-host/xml/?service=user.get_by_id&args=["1"]

Sometimes you need to pass arrays. In the JSON-format, they are transmitted in the form of jsonarrays. In XML, elements of the array pass in item-tags. For example: http://your-service-host/xml/?service=xxx.xxx&data=<xml><id><item index="1">first</item><item index="2">second</item></id></xml>

OR http://your-service-host/xml/?service=xxx.xxx&args={"id":["first","second"]}

OR http://your-service-host/xml/?service=xxx.xxx&args=[["first","second"]]

To use the methods, you need to be logged on. However, you can perform individual searches without having to log in. To do this, you need to transfer data to authorize an additional JSON-object: auth={"user":"MyUser","account":"MyAccount","password":"MyPass"}

Example: http://your-service-host/xml/?service=user.get_by_id&args=["1"]&auth={"user":"MyUser",

"account":"MyAccount","password":"MyPass"}

If its parameter is set, the request is processed with "auth" authentication data. The session (normal) authentication will be ignored.

Output Data Format

The answer comes in this XML format:

<xml>

<status>

<code>[ OK | FAILURE | ERROR]</code>

Copyright © 31 July 2017 Moderro Technologies, Inc. 18

Moderro Interactive Experience Platform

<message>[Human-readable result message string]</message>

</status>

<data>

[Additional data]

</data>

</xml> where CODE is result-type code:

OK - request is successful

FAILURE - request failed but it is not an error (i.e., the login was incorrect)

ERROR - error occurred during request

Note

The data tag may be empty.

General Notes

Many methods, especially create, update, and delete, take the input parameter object. This parameter is analogous to the output from the get_by_id method. It has to be provided in JSON format. The format of the object and the required fields can be viewed as a result of the output the method object (), which almost every service has. This method is needed just for this purpose.

Parameter names are validated. They must start with an English letter and contain at least three characters which could be letters, numbers, dashes, or underscores. Otherwise, there will be a validation error.

Performance Service Examples

http://[service]//xml/?service=event.index&args=["device","_deviceID_","_limit_","_(severity separated by comma, empty means all)_","_(facility separated by comma, empty means all)_"]

For example: http://[service]//xml/?service=event.index&args=["device","168","100","ERROR,INFO","replicat or,co"]

Performance-Event: http://[service]//xml/?service=event.device_perfomance_info&args=["_device_ID_","_limit_"]

For example: http://[service]/xml/?service=event.device_perfomance_info&args=["168", "100"]

The list of possible facility for a device: http://[service]/xml/?service=event.get_facility_list&args=["device","_deviceID_"]

For example: http://[service]//xml/?service=event.get_facility_list&args=["device","168"]

The severities are standard: ERROR, INFO, WARNING, etc.

Copyright © 31 July 2017 Moderro Technologies, Inc. 19

Moderro Interactive Experience Platform

When sending notifications to a URL, the data comes in the following format:

< ? Xml version="1.0" encoding="UTF-8"?>

<xml>

<event>

<severity>INFO</severity>

<module>system</module>

<message>(test: INFO / system) USB device</message><data>

<item type="string" name="usb-device"><![CDATA[/dev/sdb1]]></ item>

<item type="string" name="usb-model"><![CDATA[DISK 2.0]]></item>

<item type="string" name="usb-product"><![CDATA[EMERGENCY]]></ item>

<item type="string" name="usb-vendor"><![CDATA[USB]]></ item>

</data>

</event>

<event>

<severity>ERROR</severity>

<module>replicator </module>

<message>(test: ERROR / replicator) Cannot open file \ '/ persistent

/ MODEL \' (No such file or directory).</message>

<data></data>

</event>

......

</xml>

Basic API for Device List, Create, Edit, List of

Groups, and Profile Properties (examples)

http://[service]//xml/?service=device.get_by_serial&args=["300074500007"] Or by ID: http://[service]//xml/?service=device.get_by_id&args=[2465

] Create: https://[service]//xml/?service=device.create&args=[{"account_id":"ACCOUNT_ID","serial_num ber":"SERIAL_NUMBER", .... The rest of fields are optional... }]

&auth={"account":"ACCOUNT","user":"USER","password":"PASSWORD"}

Edit:

Note

Only send the fields that you need to change. https://[service]//xml/?service=device.update&args=[{"id":"DEVICE_ID", .... The rest of fields are optional ... }] &auth={"account":"ACCOUNT","user":"USER","password":"PASSWORD"}

List of groups: https://[service]/xml/?service=group.get_tree_by_objects&args={"TYPE","ACCOUNT_ID","AS_

TREE"}&auth={"account":"ACCOUNT","user":"USER","password":"PASSWORD"}

TYPE - device or user

ACCOUNT_ID - account id

Copyright © 31 July 2017 Moderro Technologies, Inc. 20

Moderro Interactive Experience Platform

AS_TREE - 1 (output as tree), 0 (output as list)

List of profile properties of user or device:

Device tree:

https://[service]/xml/?service=profile.device_tree&args={"device_id":"DEVICE_ID"}&auth=

{"account":"ACCOUNT","user":"USER","password":"PASSWORD"}

Device list:

https://[service]/xml/?service=profile.device_list&args={"device_id":"DEVICE_ID"}&auth=

{"account":"ACCOUNT","user":"USER","password":"PASSWORD"}

User tree: https://[service]/xml/?service=profile.user_tree&args={"user_id":"USER_ID"}&auth={"acco unt":"ACCOUNT","user":"USER","password":"PASSWORD"}

User list: https://[service]/xml/?service=profile.user_list&args={"device_id":"DEVICE_ID"}&auth={"a ccount":"ACCOUNT","user":"USER","password":"PASSWORD"}

DEVICE_ID - device id

USER_ID - user id

Schedule Rules Format and Examples

rules- rules for schedules, an array type of rule

Description of the rule object: public $schedule_rules = array (

'recurrent_type' => 'no_recurrent', // no_recurrent, daily, weekly, monthly, yearly

// flag until unappiled

'until_unappiled' =>

1,

// corresponds to the position recurrent_type = no_recurrent.

// If until_unappiled = 0 you need to set the interval during which

// the policy will be active. It is set in seconds. 'until_duration' => 0,

// !!! this field must be filled in as it acts as the start marker

'start_date' => 0, // timestamp of beginning date with time 00:00

'start_time' => 0, // time in seconds from the beginning of the start_date

// start_date + start_time = time the schedule starts working

// Corresponds to the position recurrent_type = daily

// day - sets recurrence in days 'every_days' => array (

'day' => 1

),

// corresponds to the recurrent_type = weekly

21 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

// recur_every_week - sets recurrence in weeks from the start marker

// days_of_week - array of included days of the week: array('Sun','Mon','Tue','Wed','Thu','Fri','Sat').

// Only the ones that have been set are listed, empty stands for all days.

'every_week' => array (

'recur_every_week' =>

1, 'days_of_week' => array()

),

// Corresponds to the position recurrent_type = monthly

// recur_flag - flag that sets recurrance type as in "every day of the week" vs

"every day of the month"

// every_day - day if recur_flag = 0

// every_month - month if recur_flag = 0

// recur_counter - day of the month if recur_flag = 1

// recur_day_of_week - day of the week if recur_flag = 1

// recur_month_counter - month if recur_flag =

1 'every_month' => array (

'recur_flag' => 0,

'every_day' => 1,

'every_month' => 1,

'recur_counter' => 1,

'recur_day_of_week' =>

'Sun',

'recur_month_counter' => 1

),

);

// Relatively to position recurrent_type = yearly

// recur_flag - flag to switch among types "every day of the year", "every day of the week of certain month"

// every_month - month if recur_flag = 0

// every_day - day if recur_flag = 0

// recur_counter - date if recur_flag = 1

// recur_day_of_week - day of the week if recur_flag = 1

// recur_month_counter - month if recur_flag = 1

'every_yearly' => array (

'recur_flag' => 0,

'every_day' => 1,

'every_month' => 1,

'recur_counter' => 1,

'recur_day_of_week' =>

'Sun',

'recur_month_counter' => 1

)

Example of object rules:

[

{"until_duration":86400,"every_days":[{"start_time":65580,"day":1}],

"until_unapplied":"0","start_date":1331582400,"start_time":65580,"recurrent_type":"daily"}

,

{"every_week":[{"recur_every_week":"1","start_time":66000,"days_of_week":["Tue","Wed","Fri

","Sat"]}],

"until_duration":172800,"until_unapplied":"0","start_date":1331582400,"start_time":66000," recurrent_type":"weekly"},

{"until_duration":259200,"until_unapplied":"0","start_date":1331582400,"start_time":66600,

Copyright © 31 July 2017 Moderro Technologies, Inc. 22

Moderro Interactive Experience Platform

"every_month":[{"every_day":3,"every_month":"1","start_time":66600,"recur_flag":"0"}],"rec urrent_type":"monthly"},

{"until_duration":86400,"until_unapplied":"0","start_date":1331582400,"start_time":67200," every_yearly":[{"every_day":3,"every_month":"May","start_time":67200,"recur_flag":"0"}],"r ecurrent_type":"yearly"}

]

Service API Documentation

Account Service

Entity-metaname: account

Facility-metaname: fcl_account

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<description>{description}</description>

<left_key>{left_key}</left_key>

<right_key>{right_key}</right_key>

<level>{level}</level>

<company_id>{company_id => [company object]}</company_id>

<person_id>{person_id => [person object]}</person_id>

<xml>

Fields of the object requirements:

name: The name may contain latin and numeric characters, spaces, and the following characters: “.”, “-”, and “_”. The name must start with an alphabetic character and then end with either a latin or numeric character. The name should have a minimum of 3 characters and a maximum of 64 characters. id: numeric description: 512 characters maximum

Table 2-1 Methods

Method

Get_childs

Description

Gets all child objects for current account

Call as

account.get_childs

Parameters

id: account ID (required)

Get_by_name

Get_top_account

Gets account object by name

Get_tree_by_object s

Gets account objects tree account.get_by_name name: account name

(required) none account.get_top_account account.get_tree_by_objects account_id: account object

ID (optional, default 0)

23 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Create Creates a new account object account.create

Update

Delete

Registration

Get_by_id

Get_full

Get_list_in account.update

Deletes account object

Creates a new account and it immediately registers the user and the device. account.delete account.registration

Three input parameters of the object (account, user, and device) are the objects of the appropriate services.

Gets account object by ID account.get_by_id

Gets full information of account object including account.get_full sub-objects

Gets account objects whose IDs are in the input array account.get_list_in

Gets account index account.index Index

Address Service

Entity-metaname: address

Facility-metaname: fcl_account

Basic input/output object format:

<xml>

<id>{id}</id>

<street_address>{street_address}</street_address>

<city>{city}</city>

<state_id>{state_id => [state object]}</state_id>

Copyright © 31 July 2017 Moderro Technologies, Inc.

parent_id: account parent object ID (required) object: account object

(required) object: account object

(required) object: account object

(required) account (required) user (required) device (required) id: account ID (required) id: account ID (required) in: account ID array (required) none

24

Moderro Interactive Experience Platform

<province>{province}</province>

<zip_code>{zip_code}</zip_code>

<country_id>{country_id => [country object]}</country_id>

<xml>

Fields of the object requirements:

street_address: 256 characters maximum province: 128 characters maximum zip_code: 16 characters maximum

Method

Create

Update

Table 2-2

Description

Creates a new address object

Methods

Call as

address.create address.update

Parameters

object: address object

(required) object: address object

(required) object: address object

(required) id: address ID (required)

Delete

Get_by_id

Get_full

Get_list_in

Index

Deletes address object

Gets address object by ID address.delete address.get_by_id

Gets full information of address object including sub-objects address.get_full

Gets address objects whose IDs are in the input array address.get_list_in

Gets address index address.index

Authentication Service

System authentication service

Facility-metaname: fcl_security

Table 2-3

Method Description

Methods

Call as

id: address ID (required) in: address ID array

(required) none

Parameters

Copyright © 31 July 2017 Moderro Technologies, Inc. 25

Moderro Interactive Experience Platform

Login auth.login

Is_logined

Logout

Company Service

auth.is_logined auth.logout

Entity-metaname: company

Facility-metaname: fcl_account

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<description>{description}</description>

<contact_id>{contact_id => [contact object]}</contact_id>

<xml> account (required) user (required) password (required) client_name (optional, default false) client_version (optional, default false) use_experimental (optional, default false) none none

Fields of the object requirements:

Method

Get_by_name

Create

Update

Delete

Get_by_id

Table 2-4

Description

Gets company object by name

Creates a new company object

Methods

Call as

company.get_by_name company.create company.update

Deletes company object

Gets company object by ID company.delete company.get_by_id

Parameters

name: company name

(required) object: company object

(required) object: company object

(required) object: company object

(required) id: company ID (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 26

Moderro Interactive Experience Platform

Get_full

Get_list_in

Index

Gets full information of company object including sub-objects company.get_full

Gets company objects whose IDs are in the input array company.get_list_in

Gets company index company.index id: company ID (required) in: company ID array

(required) none

Contact Service

Entity-metaname: contact

Facility-metaname: fcl_account

Basic input/output object format:

<xml>

<id>{id}</id>

<phone>{phone}</phone>

<cell_phone>{cell_phone}</cell_phone>

<email>{email}</email>

<notification_url>{notification_url}</notification_url>

<web>{web}</web>

<skype>{skype}</skype>

<address_id>{address_id => [address object]}</address_id>

<xml>

Fields of the object requirements:

phone: 64 characters maximum

cell_phone: 64 characters maximum email: 128 characters maximum

notification_url: 512 characters maximum

web: 256 characters maximum skype: 64 characters maximum

Method

Create

Update

Table 2-5

Description

Creates a new contact object

Methods

Call as

contact.create contact.update

Parameters

object: contact object

(required) object: contact object

(required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 27

Moderro Interactive Experience Platform

Delete

Get_by_id

Get_full

Get_list_in

Index

Deletes contact object

Gets contact object by ID

Gets full information of contact object including sub-objects contact.delete contact.get_by_id contact.get_full

Gets contact objects whose IDs are in the input array contact.get_list_in

Gets contact index contact.index

Country Service

Entity-metaname: country

Facility-metaname: fcl_default

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<xml>

Method

Index

Get_by_name

Get_by_id

Get_full

Get_list_in

Table 2-6 Methods

Description Call as

Gets country index country.index

Gets country object by name country.get_by_name

Gets country object by ID country.get_by_id

Gets full information of country object including country.get_full sub-objects

Gets country objects whose IDs are in the input array country.get_list_in

Copyright © 31 July 2017 Moderro Technologies, Inc.

object: contact object

(required) id: contact ID (required) id: contact ID (required) in: contact ID array

(required) none

Parameters

none name: country name

(required) id: country ID (required) id: country ID (required) in: country ID array (required)

28

Moderro Interactive Experience Platform

Device Service

Entity-metaname: device

Facility-metaname: fcl_device

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<mac>{mac}</mac>

<serial_number>{serial_number}</serial_number>

<is_disabled>{is_disabled}</is_disabled>

<last_ip>{last_ip}</last_ip>

<last_external_ip>{last_external_ip}</last_external_ip>

<location>{location}</location>

<description>{description}</description>

<device_status>{device_status}</device_status>

<address_id>{address_id => [address object]}</address_id>

<account_id>{account_id => [account object]}</account_id>

<timezone>{timezone}</timezone>

<timezone_offset>{timezone_offset}</timezone_offset>

<is_muted>{is_muted}</is_muted>

<is_notlicensed>{is_notlicensed}</is_notlicensed>

<is_updaterequired>{is_updaterequired}</is_updaterequired>

<user_online_id>{user_online_id}</user_online_id>

<xml>

Fields of the object requirements:

name: 3 characters minimum, 128 characters maximum description: 512 characters maximum mac: 12 characters maximum serial_number: 4 characters minimum, 32 characters maximum

Method

Search

Mark

Table 2-7

Description

Marks device as online, checks device over time, and marks it as offline

Methods

Call as

device.search device.mark

Get_by_serial Gets device object by serial number device.get_by_serial

Parameters

mask (required) now_connected_device

(required) uptime (optional, default 0) muted (optional, default false) serial: serial number

(required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 29

Moderro Interactive Experience Platform

Get_by_name Gets device object by name device.get_by_name device.get_by_serial_and_n ulltoken account_id: account object

ID (required) name: device name

(required) serial: serial number

(required)

Get_by_serial_and_ nulltoken

Gets device object by serial number and null token

Get_full

Index

Get_online

Get_online_count

Get_all_count

Create

Update

Delete

Effective_profile

Effective_profile_li st

Gets full information of device object

(including sub-objects) device.get_full

Gets device index device.index

Creates a new device object

Deletes device object id: device ID (required) device.get_online device.get_online_count device.get_all_count device.create account_id: account object

ID (optional, default false) account_id: account object

ID (optional, default false) none none device.update device.delete object: device object

(required) object: device object

(required) object: device object

(required) device.effective_profile id: device ID (required) device.effective_profile_list id: device ID (required) time (optional, default false) n (optional, default 1)

Effective_policy

Get_by_id

Get_list_in device.effective_policy

Gets device object by ID device.get_by_id

Gets device objects whose IDs are in the input array device.get_list_in id: device ID (required) id: device ID (required) in: device ID array (required)

Device_model Service

Entity-metaname: model

Facility-metaname: fcl_device

Copyright © 31 July 2017 Moderro Technologies, Inc. 30

Moderro Interactive Experience Platform

Basic input/output object format:

<xml>

<id>{id}</id>

<product_id>{product_id => [product object]}</product_id>

<name>{name}</name>

<description>{description}</description>

<xml>

Fields of the object requirements:

name: 2 characters minimum, 64 characters maximum description: 512 characters maximum

Method

Index

Create

Update

Delete

Get_by_name

Get_by_id

Get_full

Get_list_in

Table 2-8 Methods

Description

Gets device_model index

Creates a new device_model object

Call as

device_model.index device_model.create

Parameters

none object: device_model object

(required)

Deletes device_model object

Gets device_model object by name

Gets device_model object by ID device_model.update device_model.delete object: device_model object

(required) object: device_model object

(required) device_model.get_by_name product_id: product object

ID (required) device_model.get_by_id

Gets full information of device_model device_model.get_full object including subobjects

Gets device_model objects whose IDs are in the input array device_model.get_list_in name: device_model name

(required) id: device_model ID

(required) id: device_model ID

(required) in: device_model ID array

(required)

Event Service

Entity-metaname: events

Basic input/output object format:

<xml>

31 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<id>{id}</id>

<object_type>{object_type}</object_type>

<object_id>{object_id}</object_id>

<event_time>{event_time}</event_time>

<severity>{severity}</severity>

<facility>{facility}</facility>

<message>{message}</message>

<data>{data}</data>

<xml>

Fields of the object requirements:

object_type: 16 characters maximum severity: 16 characters maximum facility: 64 characters maximum message: 1024 characters maximum data: 4096 characters maximum

Method

Register

Table 2-9

Description

Registers a new event object

Methods

Call as

event.register

Get_facility_list

Index event.get_facility_list

Gets event index event.index

Parameters

object_type (required) object_id (required) severity (required) facility (required) message (optional, default '') data (optional, default '') time (optional, default false) object_type (required) object_id (required) object_type (optional, default 'device') object_id (optional, default

0) limit (optional, default '') severity (optional, default '') facility (optional, default '') search (optional, default '') start (optional, default 0) end (optional, default 0)

Copyright © 31 July 2017 Moderro Technologies, Inc. 32

Moderro Interactive Experience Platform

Device_perfomance

_info

Device_perfomance

_info_advanced

Create_notification

Get_by_id Gets event object by ID event.device_perfomance_in fo device_id: device object ID

(required) limit (optional, default '') event.device_perfomance_in fo_advanced start (optional, default 0) end (optional, default 0) device_id: device object ID

(required) limit (optional, default '') event.create_notification event.get_by_id start (optional, default 0) end (optional, default 0) senders (required) types (required) contains (required) receivers (required) id: event ID (required)

Firmware Service

Entity-metaname: firmware

Facility-metaname: fcl_device

Basic input/output object format:

<xml>

<id>{id}</id>

<version_major>{version_major}</version_major>

<version_sys>{version_sys}</version_sys>

<version_app>{version_app}</version_app>

<model_id>{model_id}</model_id>

<is_release>{is_release}</is_release>

<is_enabled>{is_enabled}</is_enabled>

<description>{description}</description>

<specification_path>{specification_path}</specification_path>

<sys_image_path>{sys_image_path}</sys_image_path>

<app_image_path>{app_image_path}</app_image_path>

<build>{build}</build>

<pversion>{pversion}</pversion>

<xml>

Fields of the object requirements:

name: The name may contain latin and numeric characters, spaces, and the following characters: “.”, “-”, and “_”. The name must start with an alphabetic character and then end with either a latin or numeric character.

Copyright © 31 July 2017 Moderro Technologies, Inc. 33

Moderro Interactive Experience Platform

sys_image_path: 2048 characters maximum app_image_path: 2048 characters maximum specification_path: 2048 characters maximum description: 512 characters maximum

Table 2-10

Method

To_release_all

Support_index

Support_versions

Description

Index

Create

Update

Gets firmware index

Creates a new firmware object

Methods

Call as

firmware.to_release_all firmware.create firmware.update

Parameters

none firmware.support_index none firmware.support_versions model_id (required) firmware.index where (optional, default '')

Delete

Disable

Enable

Get_by_id

Get_full

Deletes firmware object

Gets firmware object by ID

Gets full information of firmware object including sub-objects firmware.delete firmware.disable firmware.enable firmware.get_by_id firmware.get_full object: firmware object

(required) object: firmware object

(required) object: firmware object

(required) id: firmware ID (required) id: firmware ID (required) id: firmware ID (required) id: firmware ID (required)

Group Service

Account group management service Entity-metaname: group

Facility-metaname: fcl_account

Method

Table 2-11

Description

Methods

Call as Parameters

Copyright © 31 July 2017 Moderro Technologies, Inc. 34

Moderro Interactive Experience Platform

Get_full Gets full information of group object including sub-objects

Get group object by name group.get_full group.get_by_name type (required) group_id: group object ID

(required)

Get_by_name

Get_by_id

Get_tree_by_object s

Create account_id: account object

ID (required) type (required)

Gets group object by ID

Gets group objects tree

Creates a new group object group.get_by_id name: group name (required) type (required) group_id: group object ID

(required) group.get_tree_by_objects type (required) group.create account_id: account object

ID (required) return_as_tree (optional, default true) type (required) account_id: account object

ID (required)

Update

Delete

Get_childs

Deletes group object

Gets all child objects for current group group.update group.delete group.get_childs name: group name (required) description (optional, default

'') parent_id: group parent object ID (optional, default false) type (required) group_id: group object ID

(required) name: group name (optional, default false) description (optional, default false) type (required) group_id: group object ID

(required) type (required) group_id: group object ID

(required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 35

Moderro Interactive Experience Platform

Get_all_childs

Add_object

Set_objects

Remove_object

Object_not_membe r_of

Object_member_of

If the is_reset parameter is set, then the group will be cleared of prior entities group.get_all_childs group.add_object group.set_objects type (required) group_id: group object ID

(required) type (required) group_id: group object ID

(required) object_id (required) type (required) list_group_id (required) object_id (required) group.remove_object is_reset (optional, default 0) type (required) group_id: group object ID

(required) group.object_not_member_o f object_id (required) type (required) group.object_member_of group_id: group object ID

(required) type (required) object_id (required) return_as_tree (optional, default true)

Image Service

Table 2-12

Method

Get_favicon_by_url

Description

Image_file_resize

Image_file

Image_base64_resi ze

Methods

Call as

image.get_favicon_by_url image.image_file_resize

Parameters

url (required) filedata (required) toWidth (required) toHeight (required) image.image_file filedata (required) image.image_base64_resize base64encodedImage

(required) toWidth (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 36

Moderro Interactive Experience Platform

Notification Service

Entity-metaname: notification

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<ts>{ts}</ts>

<account_id>{account_id => [account object]}</account_id>

<period>{period}</period>

<severity_facility>{severity_facility}</severity_facility>

<message_contains>{message_contains}</message_contains>

<rules>{rules}</rules>

<messages>{messages}</messages>

<logic>{logic}</logic>

<xml>

Fields of the object requirements:

name: 3 characters minimum, 64 characters maximum

Method

Specification

Add_user

Set_user_list

Set_notification_lis t

Remove_user

Notification_user_li st

User_notification_li st

Table 2-13

Description

Methods

Call as

notification.specification notification.add_user notification.set_user_list

Parameters

none notification_id: notification object ID (required) user_id: user object ID

(required) notification_id: notification object ID (required) notification.set_notification_ list user_id_array (required) user_id: user object ID

(required) notification.remove_user notification.notification_use r_list notification.user_notificatio n_list notification_id_array

(required) notification_id: notification object ID (required) user_id: user object ID

(required) notification_id: notification object ID (required) user_id: user object ID

(required)

37 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Create

Update

Delete

Creates a new notification object

(See the notification.create method)

Deletes notification notification.create notification.update notification.delete account_id: account object ID

(required) name: notification name

(required) types (required) - see the

“Arrays” section below message_contains (required) rules (required) - see the

“Arrays” section below period (required) or_logic (optional, default 0) id: notification ID (required) name: notification name

(required) types (required) - see the

“Arrays” section below message_contains (required) rules (required) - see the

“Arrays” section below period (required) or_logic (optional, default 0) object: notification object

(required) id: notification ID (required) Get_by_id

Get_by_name

Index

Close_opened_notif ications

Gets notification object by ID notification.get_by_id

Gets notification object by name

Gets notification index notification.get_by_name notification.index notification.close_opened_n otifications account_id: account object ID

(required) name: notification name

(required) account_id: account object ID

(required) none

Arrays

In the Create method (see the table above), the following parameters are arrays:

1.

types - An array of settings under which Severity and Facility the notification will fire. The format is an array of objects with two parameters - severity and facility:

[{"severity":"ERROR","facility":"*"},{"severity":"*","facility":"Co"}] severity: ERROR, WARNING, INFO, etc.

Copyright © 31 July 2017 Moderro Technologies, Inc. 38

Moderro Interactive Experience Platform

facility: from output of the event::get_facility_list

Both can be replaced with asterisks to include all

2.

errors:

{"severity":"ERROR","facility":"*"}

Or replaced with “Co” for any messages from Cobalt (the communication module):

{"severity":"*","facility":"Co"} rules - An array of thresholds. Data for this array is contained in the Specification method (notification.specification) of this service.

[{"name":"cpu-avg","operator":">",

"value":"60"},{"name":"cpu-memory","operator":">","value":"50"},...]

Person Service

Entity-metaname: person

Facility-metaname: fcl_account

Basic input/output object format:

<xml>

<id>{id}</id>

<title>{title}</title>

<first_name>{first_name}</first_name>

<middle_name>{middle_name}</middle_name>

<last_name>{last_name}</last_name>

<contact_id>{contact_id => [contact object]}</contact_id>

<company_id>{company_id => [company object]}</company_id>

<xml>

Fields of the object requirements:

title: 60 characters maximum

first_name: 50 characters maximum middle_name: 50 characters maximum last_name: 50 characters maximum

Method

Create

Update

Delete

Table 2-14

Description

Creates a new person object

Methods

Call as

person.create person.update

Deletes person object person.delete

Parameters

object: person object

(required) object: person object

(required) object: person object

(required)

39 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Get_by_id

Get_full

Get_list_in

Index

Gets person object by ID person.get_by_id

Gets full information of person object including sub-objects person.get_full

Gets person objects whose IDs are in the input array person.get_list_in

Gets person index person.index

Policy Service

Policy management service

Entity-metaname: policy

Facility-metaname: fcl_profile

Method

Copy

Table 2-15

Description

Methods

Call as

policy.copy id: person ID (required) id: person ID (required) in: person ID array (required) none

Duplicate policy.duplicate

Create Creates a new policy object

Copyright © 31 July 2017 Moderro Technologies, Inc.

policy.create

Parameters

account_id_des (required) policy_id_list (required) new_name (optional, default false) policy_id: policy object ID

(required) new_name (required) account_id: account object

ID (required) policy_name (required) property_list (required) - see

“Array” section below policy_description (optional, default '') is_action (optional, default

0) is_menu_set (optional,

40

Update

Group_get_list

Group_set_list

Moderro Interactive Experience Platform

(See policy.create method) policy.update

Get

Get_full

Get_by_name

Get_tree

Get_list

Get_list_in

Get_index

Add

Set

Delete

Check_depends

Device_get_list

Device_set_list

Gets policy object policy.get

Gets full information of policy object including policy.get_full sub-objects

Gets policy object by name policy.get_by_name policy.get_tree

(See policy.create method) policy.get_list

Gets policy objects whose IDs are in the input array policy.get_list_in policy.get_index policy.add

(See policy.create method) policy.set

Deletes policy object policy.delete policy.check_get_list policy.device_get_list policy.device_set_list

Copyright © 31 July 2017 Moderro Technologies, Inc.

policy.group_get_list policy.group_set_list default 0) policy_id: policy object ID

(required) name: policy name (optional, default false) description (optional, default false) is_action (optional, default false) is_menu_set (optional, default false) policy_id: policy object ID

(required) policy_id: policy object ID

(required) account_id: account object ID

(required) name: policy name (required) policy_id: policy object ID

(required) policy_id: policy object ID

(required) in: policy ID array (required) account_id: account object ID

(required) policy_id: policy object ID

(required) property_list (required) policy_id: policy object ID

(required) property_list (required) policy_id: policy object ID

(required) policy_id: policy object ID

(required) device_id: device object ID

(required) device_id: device object ID

(required) policy_list (required) schedule_list (optional, default null) type (required) group_id: group object ID

(required) type (required) group_id: group object ID

(required) policy_list (required)

41

Moderro Interactive Experience Platform

Index Gets policy index policy.index schedule_list (optional, default null) none

Array

In the Create method (see the table above), the property-list parameter is an array:

property_list - An array of objects.

{"name of spec property":"value"}

For example:

[{"browser.url":"cnn.com"},{"display.rotation":"0"}]

Product Service

Entity-metaname: product

Facility-metaname: fcl_device

Basic input/output object format:

<xml>

<id>{id}</id>

<name>{name}</name>

<description>{description}</description>

<xml>

Fields of the object requirements:

name: The name may contain latin and numeric characters, spaces, and the following characters: “.”, “-”, and “_”. The name must start with an alphabetic character and then end with either a latin or numeric character. description: 512 characters maximum

Method

Index

Create

Update

Table 2-16 Methods

Description Call as

Gets product index product.index product.create Creates a new product object product.update

Parameters

none object: product object

(required) object: product object

(required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 42

Moderro Interactive Experience Platform

Delete

Get_by_name

Get_by_id

Get_full

Get_list_in

Deletes product object

Gets product object by name

Gets product object by ID

Gets full information of product object including sub-objects

Gets product objects whose IDs are in the input array product.delete product.get_by_name product.get_by_id product.get_full product.get_list_in

Profile Service

Profile management service

Entity-metaname: profile

Facility-metaname: fcl_profile

Method

Index

Default_copy

Table 2-17 Methods

Description Call as

Gets profile index profile.index profile.default_copy

Default_create

Default_update profile.default_create profile.default_update object: product object

(required) name: product name

(required) id: product ID (required) id: product ID (required) in: product ID array

(required)

Parameters

data (required) account_id_des (required) profile_id_list (required) account_id: account object

ID (required) profile_name (required) property_list (required) profile_description

(optional, default '') profile_id: profile object ID

(required) name: profile name

(optional, default false) description (optional, default false)

Copyright © 31 July 2017 Moderro Technologies, Inc. 43

Default_get

Moderro Interactive Experience Platform

profile.default_get profile_id: profile object ID

(required)

Default_get_full profile.default_get_full profile_id: profile object ID

(required)

Default_get_by_na me

Default_tree profile.default_get_by_name account_id: account object

ID (required) profile_name (required) profile.default_tree profile_id: profile object ID

(required)

Default_list profile.default_list profile_id: profile object ID

(required)

Default_index profile.default_index account_id: account object

ID (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 44

Default_get_list_in

Moderro Interactive Experience Platform

profile.default_get_list_in in: profile ID array

(required)

Default_add

Default_set

Default_delete profile.default_add pprofile_id: profile object

ID (required) pproperty_list (required) profile.default_set pprofile_id: profile object

ID (required) pproperty_list (required) profile.default_delete profile_id: profile object ID

(required)

User_tree profile.user_tree user_id: user object ID

(required)

User_list profile.user_list user_id: user object ID

(required) use_attaching (optional, default false)

Copyright © 31 July 2017 Moderro Technologies, Inc. 45

User_create

Moderro Interactive Experience Platform

profile.user_create user_id: user object ID

(required) default_id (required)

User_add profile.user_add user_id: user object ID

(required) property_list (required)

User_set profile.user_set user_id: user object ID

(required) property_list (required)

Device_tree profile.device_tree device_id: device object ID

(required)

Device_list

Device_create profile.device_list device_id: device object ID

(required) use_attaching (optional, default false) profile.device_create device_id: device object ID

(required) default_id (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 46

Device_add

Moderro Interactive Experience Platform

profile.device_add device_id: device object ID

(required) property_list (required)

Device_set profile.device_set device_id: device object ID

(required) property_list (required)

Get_by_id

Gets profile object by

ID profile.get_by_id id: profile ID (required)

Get_full

Gets full information of profile object including sub-objects profile.get_full id: profile ID (required)

Get_list_in

Gets profile objects whose IDs are in the input array profile.get_list_in in: profile ID array

(required)

Role Service

Entity-metaname: role

Facility-metaname: fcl_security

Basic input/output object format:

<xml>

<id>{id}</id>

<title>{title}</title>

<name>{name}</name>

Copyright © 31 July 2017 Moderro Technologies, Inc. 47

Moderro Interactive Experience Platform

<description>{description}</description>

<xml>

Fields of the object requirements:

name: The name may contain latin and numeric characters, spaces, and the following characters: “.”,

“-”, and “_”. The name must start with an alphabetic character and then end with either a latin or numeric character. The name should have a maximum of 64 characters.

title: 128 characters maximum

description: 512 characters maximum

Method

Get_by_name

Create

Table 2-18 Methods

Description

Gets role object by name

Call as

role.get_by_name

Creates a new role object role.create role.update

Deletes role object role.delete

Parameters

name: role name (required) object: role object (required)

Update

Delete object: role object (required) object: role object

(required) id: role ID (required) Get_by_id

Get_full

Get_list_in

Index

Gets role object by

ID

Gets full information of role object including sub-objects

Gets role objects whose IDs are in the input array

Gets role index role.get_by_id role.get_full role.get_list_in role.index

Schedule Service

Entity-metaname: schedule

Basic input/output object format:

<xml>

<id>{id}</id>

<account_id>{account_id => [account object]}</account_id>

<name>{name}</name>

<rules>{rules}</rules>

<description>{description}</description>

<xml> id: role ID (required) in: role ID array (required) none

Copyright © 31 July 2017 Moderro Technologies, Inc. 48

Moderro Interactive Experience Platform

See the “Schedule Rules Format and Examples” section of this chapter. Fields of the object requirements:

1.

name: The name may contain latin and numeric characters, spaces, and the following characters: “.”, “-”, and “_”. The name must start with an alphabetic character and then end with either a latin or numeric character. The name should have a minimum of 3 characters and a maximum of 64 characters.

2.

description: 512 characters maximum.

Table 2-19 Methods

Method

Get_simple

Get_by_name

Index

Get_list

Create

Update

Description

Gets schedule object by name

Call as

schedule.get_simple schedule.get_by_name

Gets schedule index schedule.index

Delete

Unset_device_polic y

Deletes schedule object

Set_device_policy

Parameters

id: schedule ID (required) account_id: account object

ID (required) name: schedule name

(required) account_id: account object

ID (optional, default false) none object: schedule object

(required)

Creates a new schedule object

See the “Schedule

Rules Format and

Examples” section.

See the “Schedule

Rules Format and

Examples” section. schedule.get_list schedule.create schedule.update schedule.delete object: schedule object

(required)

See the “Schedule Rules

Format and Examples” section. object: schedule object

(required) device_id: device object ID

(required) schedule.unset_device_polic y policy_id: policy object ID

(required) schedule.set_device_policy device_id: device object ID

(required) policy_id: policy object ID

(required) schedule_id: schedule object

ID (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 49

Moderro Interactive Experience Platform

Unset_group_polic y

Set_group_policy

Assign_to

Processing_device_ list

Processing_device schedule.unset_group_polic y group_id: group object ID

(required) policy_id: policy object ID

(required) schedule.set_group_policy group_id: group object ID

(required) policy_id: policy object ID

(required) schedule.assign_to schedule_id: schedule object

ID (required) schedule_id: schedule object

ID (required) schedule.processing_device_ list device_id: device object ID

(required) time (optional, default 0) count (optional, default 1 schedule.processing_device device_id: device object ID

(required) schedule.get_by_id time (optional, default 0) return_policy_id_only

(optional, default false) id: schedule ID (required) Get_by_id Gets schedule object by ID

Specification Service

Specification control service

Entity-metaname: specification

Facility-metaname: fcl_profile

Table 2-20

Method Description

Get

Methods

Gets specification object

Call as

specification.get

Get_list

Get_actions specification.get_list specification.get_actions

Parameters

type (optional, default null) use_experimental (optional, default false) type (optional, default null) use_experimental (optional, default false) account_id: account object

ID (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 50

Moderro Interactive Experience Platform

Get_menu_actions

Set_action_policy

Set_action_property specification.get_menu_acti ons specification.set_action_poli cy account_id: account object

ID (required) device_id: device object ID

(required) specification.set_action_pro perty policy_id: policy object ID

(required) device_id: device object ID

(required) action_name (required) action_value (required) device_id: device object ID

(required) action_list (required)

Set_action_property

_list action_list is always an array of objects

{"name of the action property":"value"} specification.set_action_pro perty_list

Set_action_group_p olicy

For example:

[{"power.reboot":"1

"},{"display.rotatio n":"0"}] specification.set_action_gro up_policy

Set_action_group_p roperty specification.set_action_gro up_property account_id: account object

ID (required) group_id: group object ID

(required) policy_id: policy object ID

(required) account_id: account object

ID (required) group_id: group object ID

(required)

Set_action_group_p roperty_list action_list is always an array of objects

{"name of the action property":"value"}

For example:

[{"power.reboot":"1

"},{"display.rotatio n":"0"}] specification.set_action_gro up_property_list action_name (required) action_value (required) account_id: account object

ID (required) group_id: group object ID

(required) action_list (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 51

Moderro Interactive Experience Platform

System Service

Table 2-21 Methods

Method

Import_device_csv

Import

Description Call as Parameters

system.import_device_csv account_id: account object

ID (required) system.import csv_file (required) account_id: account object

ID (required) xml (required) is_validation (optional, default false)

All_export

All_import

Bulk_export system.all_export system.all_import

Input is an array of objects {entity:id}. entity : 'user', 'device',

'profile', 'policy',

'notification', 'schedule' id - identifiers For example:

[{"device":"32"},{" system.bulk_export device":"39"},{"use r":"89"}]

Returns a link to the file that can be downloaded. system.account_export none filename (required) objects (required)

Account_export account_id: account object

ID (required) entity (required) Export system.export

Change_log

Change_log_types

Change_log_operati on_types

Changes

Maintainance_code system.change_log system.change_log_types system.change_log_operatio n_types system.changes data (required) none none none system.maintainance_code serial (required)

Preferences_load system.preferences_load

Preferences_save

Saves preferences.

Input is an array of objects

Changes_log

{property_name:val ue} system.preferences_save system.changes_log none preferences (required) for_last_time (optional, default 0)

Changes_log_full system.changes_log_full id: system ID (required) for_last_time (optional, default 0)

Check_license system.check_license license_string (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 52

Moderro Interactive Experience Platform

Get_licenses

Add_license

Remove_license

Mac_address_list

Admin_warning

Testing

Search system.get_licenses system.add_license system.remove_license system.mac_address_list system.admin_warning system.testing system.search none license_string (required) license_string (required) none none none mask (required)

User Service

Entity-metaname: user

Facility-metaname: fcl_user

Basic input/output object format:

<xml>

<id>{id}</id>

<account_id>{account_id => [account object]}</account_id>

<title>{title}</title>

<login>{login}</login>

<passwd>{passwd}</passwd>

<description>{description}</description>

<person_id>{person_id => [person object]}</person_id>

<role_id>{role_id => [role object]}</role_id>

<temp_code>{temp_code}</temp_code>

<lock_time>{lock_time}</lock_time>

<failed_attempts>{failed_attempts}</failed_attempts><xml>

<xml>

Fields of the object requirements:

login: 3 characters minimum, 64 characters maximum

description: 512 characters maximum

Table 2-22 Methods

Method

Index

Description

Gets user index

Call as

user.index

Full_index

Get_by_login user.full_index

Gets user object by login user.get_by_login

Parameters

account_id: account object

ID (optional, default false) account_id: account object

ID (optional, default false) account_id: account object

ID (required) login (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 53

Moderro Interactive Experience Platform

Get_full

Create

Change_password

Gets full information of user object including sub-objects

Creates a new user object user.get_full user.create user.change_password

Update

Delete

Get_by_id

Get_list_in

Gets user object by

ID user.update

Deletes user object user.delete user.get_by_id

Gets user objects whose IDs are in the input array user.get_list_in id: user ID (required) object: user object (required) id: user ID (required) oldpassword (required) newpassword (required) object: user object (required) object: user object (required) id: user ID (required) in: user ID array (required)

Copyright © 31 July 2017 Moderro Technologies, Inc. 54

Moderro Interactive Experience Platform

Widgets

Chapter Overview

In addition to regular plugins support (like Adobe Flash Player), Cobra provides several proprietary widgets to simplify developer's life. Those widgets can be configured and controlled using

JavaScript.

The topics in this chapter include:

Plugins API

Camera Widget

DrmViewer Widget

Jabber Client Framework (JCF) Widget

RemoteDesktop Widget

SipPhone Widget

Ticker Widget

VideoPlayer Widget

VncViewer Widget

WebBrowser Widget

WebClip Widget

WebRTC Widget

Plugins API

Every plugin inherits the following interface: interface Plugin

{ readonly attribute int status ; signals : void statusChanged(in int status) ; void ready(); void error(in string message);

};

status: Contains current plugin status.

Copyright © 31 July 2017 Moderro Technologies, Inc. 55

Moderro Interactive Experience Platform

0: Ready to be used

1: In progress, which usually means that the initialization process in not finished yet

2: Error statusChanged(): Fires when plugin's status is changed. ready(): Fires when plugin becomes ready (i.e. plugin’s status changed to 0). error(): Fires when an error occurs (i.e. plugin's status changed to 2).

Tip

It is a good practice to always check a plugin's status before you use it. It is especially important when you use network-related plugins, which load their content from network, because those plugins perform asynchronously. See the VideoPlayer plugin usage example for an example of such a good practice.

Camera Widget

The Camera plugin allows you to access an USB camera connected to the IEC4600 Series. This plugin allows you to make shots and get those shots as JPEG images. It is highly recommended to use an USB video class (UVC) camera.

Note

Camera hot plugging is supported by the application, but hot unplugging is not.

The Camera interface declaration is the following: interface Camera

{ readonly attribute string errorString; readonly attrbute string toJpeg; readonly attrbute bool ready; attribute bool controlsVisible; attribute int delay; attribute string cameraDevice; readonly attribute int camerasFound; parameters: string cameraDevice; int delay; bool constrolsVisible ; slots: void discover(); void shoot(); void setEnabled(in bool enabled); signals: void

Copyright © 31 July 2017 Moderro Technologies, Inc. 56

Moderro Interactive Experience Platform

captured(); void error(); void discovered(in int numberOfCameras); void discovered();

};

Note

Starting with 2.2.1, the following variables should not be used: cameraDevice , camerasFound , discover() . Instead use global.system.webCameras to get the map with the found cameras and their associated devices.

Table 3-1 Variables

Variable

cameraDevice camerasFound cameraDevice delay constrolsVisible discover()

Description

Specifies the system device associated with the selected camera.

Note

Use global.system.webCameras to get the map with the found cameras and their associated devices.

The number of found cameras.

Note

This variable is deprecated. Use global.system.webCameras.

This parameter is used to specify the low level device to be used for the camera object.

This parameter is used to specify the delay in seconds before shooting.

This parameter is used to show controls.

Use this to discover cameras.

Note

This variable is deprecated. Use global.system.webCameras.

The following HTML document contains an example of camera usage

(file.../.../test/plugins/camera.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: camera plugin test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e>

Copyright © 31 July 2017 Moderro Technologies, Inc. 57

Moderro Interactive Experience Platform

body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family: Arial; font-size:

20px; color :

#eeeeee;

}

</style>

<script type="text/javascript"> var camera; var image; var camerasFound; function init

()

{ camera = document.getElementById("camera"); image

= document.getElementById("image"); camerasFound = document.getElementById("camerasFound");

// image has been captured camera.captured.connect(captured);

// error occured camera.error.connect(error)

;

// discovering has finished , use camera.camerasFound to read

// the number of cameras found camera.discovered.connect(discovered);

} function captured()

{

// camera.toJpeg doesn’t cache images, so 3 calls to ’camera.toJpeg’


} function error ()

{

// display error string alert

(camera.errorString);

} function discovered()

{

} function isReady()

{

// camera.camerasFound == -1 if not initialized camerasFound.innerHTML = "Cameras found: " + camera.camerasFound; alert (camera.ready);

} function setEnabled(enab)

Copyright © 31 July 2017 Moderro Technologies, Inc. 58

Moderro Interactive Experience Platform

{ camera.setEnabled(enab);

} function showAvailable()

{ var map = global.system.webCameras; var result = "";

// key = camera device (for example "/dev/video0")

// value = camera's human

• readably name (for example "HD-1000 USB video camera") for (var i in map)

{ result += i + ": " + map[i];

} alert ( result ) ;

}

• function setDevVideo(index)

{

// you can also assign keys from the map retrieved from global.system.webCameras,

// see showAvailable() camera.cameraDevice = "/dev/video" + index;

}

</script>

</head>

<body onload="init()">

<center>

<a href='#' onclick="showAvailable()">Show available</a>

<a href='#' onclick="setDevVideo(0)">/dev/video0</a>

<a href='#' onclick="setDevVideo(1)">/dev/video1</a>

<a href='#' onclick="alert(camera.cameraDevice)">Current camera</a>

<!-- deprecated, use global.system.webCameras instead (bear in mind backward compability) -->

<a href=’#’ onclick="camera.discover()">Discover</a>

<a href=’#’ onclick="camera.shoot()">Shoot</a>

<a href=’#’ onclick="isReady()">Ready?</a>

<a href=’#’ onclick="setEnabled(true)">Enable</a>

<a href=’#’ onclick="setEnabled(false)">Disable</a>

<div id="camerasFound" style="text-align: center;">

</div>

<br/>

<div>

<object id="camera" type="application/x-qt-plugin" classid="camera" width="50%" height="40%">

<param name="delay" value="4" /> <!-- delay before shooting -->

<param name="constrolsVisible" value="true" /> <!-- show controls -->

</object>

</div>

<br/>

<div id="result">

<img id="image" src="" width="640" height="480" />

59 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

</div>

</center>

</body>

</html>

DrmViewer Widget

The DrmViewer plug-in plays Digital Rights Management (DRM) content from a Swank media player.

The widget includes APIs for Shaka-player related trick mode operations and has full screen toggle on/off without viewing interruptions.

The interface declaration is the following: interface DrmViewer

{ attribute string url

; methods: void runJavaScript(in string scriptSource) ; variant evaluateJavaScript(in string scriptSource)

; parameters: string url

; signals : void loadStarted(); void loadFinished(in bool ok); void loadProgress(in int percent); void urlChanged(in url url) ; void titleChanged(in string title ) ;

};

Table 3-2 Variables

Variable

runJavaScript evaluateJavaScript url useragent

Description

Executes the specified JavaScript code

scriptSource in drmviewer. The JS code is executed asynchronously.

Executes the specified JavaScript code

scriptSource in drmviewer. The JS code is executed synchronously and its result is returned.

URL pointing to an HTML document.

HTTP User-Agent.

The following HTML document contains an example of drmviewer usage.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: drmviewer plugin test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl

Copyright © 31 July 2017 Moderro Technologies, Inc. 60

Moderro Interactive Experience Platform

e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; fontsize: 20px; color : #eeeeee;

}

</style>

<script type="text/javascript"> var addressBar; var webBrowser; function init

()

{ addressBar = document.getElementById("addressBar"); webBrowser

= document.getElementById("webBrowser"); addressBar.value = webBrowser.url;

} function deinit ()

{ webBrowser.evaluateJavaScript("terminate();");

} function go()

{ webBrowser.url = addressBar.value;

} function msg()

{ webBrowser.runJavaScript("alert('Hello from inside drmviewer');");

} function changeSize()

{ webBrowser.style. left = "20px"; webBrowser.style.top = "120px"; webBrowser.style.width =

"800px"; webBrowser.style.height

= "480px";

} function runJSSync()

{ alert (webBrowser.evaluateJavaScript("returnInteger();"));

}

</script>

</head>

<body onload="init()" onbeforeunload="deinit()">

<input id="addressBar" type="text" />

<button onclick="go()">Go</button>

<button onclick="msg()">Message</button>

<button onclick="changeSize()">Change size</button>

<button onclick="runJSSync()">Get a JS result from drmviewer</button>

<br />

<br />

<font

Copyright © 31 July 2017 Moderro Technologies, Inc. 61

Moderro Interactive Experience Platform

color="#FFFFFF">WebEngine

• based browser</font>

<div style="text-align: center ;">

<object id="webBrowser" type="application/x-qt-plugin" classid="drmviewer" style="position:absolute; left: 0px; top: 100px; width: 640px; height: 400px; border: 3px solid #00FF00">

<param name="url" value="http://127.0.0.1:8000/test/plugins/drmcontent.html"/>

</object>

</div>

</body>

</html>

Jabber Client Framework (JCF) Widget

JCF is the native implementation of Cisco Jabber Client Framework. This widget offers functionality similar to the SipPhone widget, except that JCF is Cisco proprietary implementation. This plugin enables the application to perform like a feature-rich SIP endpoint and supports a wide range of audio and video codecs such as g711, g722, g722.1, g729 for audio and H.264, H.263, H.261 for video codecs respectively.

The Cisco H.264 implementation is open sourced and is compatible with most H.264 decoders. If your deployment uses many Cisco endpoints, it is recommended that you to use this widget instead of the

SipPhone widget. interface Jcf

{ attribute string status; attribute string idleImage; parameters: string camera; slots: int start (in string domain, in string username, in string password, in string tftpAddr); void call(in string sipUri, in bool withVideo); void hangup(); int callHold(); int callResume(); int setVolume(in int vol); int mute(); int unmute(); bool isRegistered(); void sendDtmf(in string dtmfkey); string cameraDevice(); int setCameraDevice(in string cameraName); int answer(in bool videoFlag); int reject();

Copyright © 31 July 2017 Moderro Technologies, Inc. 62

Moderro Interactive Experience Platform

bool setidleImage(in string imgurl, in bool stretchFlag); bool changeidleImage(in string imgurl, in bool stretchFlag); bool addVideoToCall(in bool videoFlag); signals: void idle(); void incomingCall(in string peer); void placingCall(); void ring(); void trying(); void established(); void disconnected(); void registered(); void telemetry(in string callStats); void hold(); void resume(); void novideo(); void video(); void error(in int code, in string message);

};

Table 3-2 JCF Variables includes the description of the methods used for various features. Additionally, it lists the signals available in the system.

Table 3-3 JCF Variables

Variable

camera

Description

Use this method to specify the name of the camera to be used for the call. start(in string domain, in string username, in string password)

Use this method to set the JCF credentials that are needed to get registered with the CUCM specified by the variable domain, either as an IP address or as a FQDN. You can use this credential to register as a Cisco endpoint with the UCM. call(in string sipUri, in bool withVideo)

This method should be used only after the start(...) method is called. This method initiates the call to

SIP URI (Called party). hangup()

Note The second parameter, in bool withVideo, is optional and is set to True, by default. So, if you do not specify the parameter, it will initiate a video call. You can set the second argument as False to make only audio calls.

This method disconnects the ongoing call.

63 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

callHold() callResume() setVolume(in int vol) mute() unmute() isRegistered() sendDtmf(in string dtmfkey) cameraDevice() setCameraDevice(in string cameraName) answer(in bool withVideo) reject() setidleImage(in string imgUrl, in bool stretchFlag) changeidleImage(in string imgUrl, in bool stretchFlag) addVideoToCall(in bool videoFlag)

This method puts the remote caller on hold. The remote caller will stay on hold unless the callResume() method is called.

This method will resume the call on hold.

This method enables you to set/control the volume of the application. The advantage of JCF over

SipPhone is that it provides application level volume control.

This method mutes the microphone. It prevents transmission of any audio output.

This method is used to unmute the microphone and start transmitting the audio output.

Based on whether the endpoint is registered or not, this method returns Boolean True or False, to make and receive calls.

This method sends Dual Tone Multiple Frequencies

(DTMF) as RFC2833 to the other end. Valid DTMF keys are 0-9, *, and #.

This method returns the configured webcam that is currently being used by the JCF widget.

Use this method to let the JCF widget know which webcam to use while placing the call.

Use this method to accept an incoming call. The

‘withVideo’ parameter is optional. By default, it is set to True. If you would like to have only audio call, set “Audio only’ parameter as ‘False’.

This method is used to reject the incoming call.

This method can be used to display an image such as a logo or some graphic when the SIP widget is registered and not on a call. The parameters are imgUrl, the URL for the image to be displayed, and stretchFlag, which indicates whether to auto-resize the image to the given frame.

This method has similar functionalities as setidleImage. This method can be used to change the appearance of the widget, like coding it in the javascript to change the idleimage to create a screen saver for the widget.

This method enables you to add or remove the video stream from an existing call. In order to use this method, the call should be negotiated as a video call. Set the function as:

True - To enable the video stream in the call

Or

False - To disable the video stream.

By default, the video stream is enabled.

Copyright © 31 July 2017 Moderro Technologies, Inc. 64

Moderro Interactive Experience Platform

Signals ready() registered() placingCall() incomingCall() established() ring() disconnected() telemetry(in string callStats) video() novideo() hold() resume() error(in int code, in string explanation)

Description

It indicates that the values given for initializing the

JCF is accepted.

It means that the JCF is now registered with the SIP

Registrar (or Call Manager) and you can make/receive calls from the widget.

The widget is trying to make a call to the desired party.

The widget is receiving an incoming call from another SIP peer.

It indicates that the call is established.

This signal means that the called party has been notified about the incoming call.

The call has been terminated.

This signal contains the complete details of the previous disconnected call. Use this to display as regular Telemetry data.

This signal means that a video call is initiated and the remote site/caller video is available to display.

This signal means that the video is not sent by the remote end for the call. The application can use video/novideo signal to enhance the user experience. For example, displaying a message like

Please wait....

The remote caller has put the call on hold.

The remote caller has resumed the call.

This signal is indicative of any errors while using the widget. The signal has an error code along with the explanation/details of the error.

The Following HTML document contains an example showing how to use jcf.

<!DOCTYPE html>

<html>

<head>

<link rel="stylesheet" type="text/css" href="css/time.css">

<link rel="stylesheet" type="text/css" href="css/button.css">

<link rel="stylesheet" type="text/css" href="css/modal.css">

<link rel="stylesheet" type="text/css" href="css/keypad.css">

<script type="text/javascript" src="js/alert.js"></script>

<styl e> body

{ background-image: url(’img/CiscoBlack.png’); backgroundrepeat: no-repeat; background-attachment: fixed; backgroundposition: center;

65 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

}

.frame { float: left ; width:49.5%; height:100%; overflow:auto;

}

.frame .frame { background:cyan

}

.frame.border { border-right:3px ridge buttonface

} p.normal { font-style: normal;

} p. italic { font-style: italic ;

} p.oblique { font-style: oblique; color: white; text-align: center;

} div { font-style: oblique; color: white; text-align: center; vertical-align: center;

} statusLabel { font-style: oblique; fontsize: larger; color: white; text-align: left

; top:30px; vertical-align: center;

} h2 { color: #1d1d1d;

} a:visited { color:

#fff;

} a:link { color: #fff;

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 66

Moderro Interactive Experience Platform

a:active { color: #fff;

}

#m1 { position:absolute

; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:-330px;

}

#m2 { position:absolute; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:-230px;

}

#m3 { position:absolute; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:-130px;

}

#m4 { position:absolute

; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:-30px;

}

#m5 { position:absolute

; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:+70px;

}

#m6 { position:absolute

; width:20; height:20; bottom:80px; right:25

%; left:50%

;

Copyright © 31 July 2017 Moderro Technologies, Inc. 67

Moderro Interactive Experience Platform

margin-left:+170px;

}

#m7 { position:absolute

; width:20; height:20; bottom:80px; right:25%; left:50%; margin-left:+270px;

} videoView { position: fixed; top: 0; left : 0; right: 0; bottom:

130px; width: 100%; height:

720px; overflow: hidden; background:

#fff;

} label { color: #B4886B; font-weight: bold; display: block; width:

150px; float: left;

} textarea { border: 1px solid #888;

}

#dtmfModal { position: fixed; bottom:

30px; overflow: hidden; width:

100%;

}

#volumeModal { position: absolute; bottom:

40px; overflow: hidden; width:

100%; margin-left: +110px;

}

@font-face { font-family: CiscoSansTTLightOblique; src: url(font/CiscoSansTTLightOblique.ttf); font-weight: bold;

Copyright © 31 July 2017 Moderro Technologies, Inc. 68

Moderro Interactive Experience Platform

}

</style>

</head>

<!-- CODE & LOGIC HERE -->

<script> var jcfPhone = null; var dtmfPadShow = true; var volumeShow

= true; var micMuted

= false; var callHeld = false; var inCall = false; var prevSignal = ""; function init()

{

GetClock(); setInterval(GetClock,1000);

//console.log("** JCF Script (mod. April-27-2016) **"); connectSlots(); getStatus();

}

</script>

<!-- MAIN CODE ENDS -->

<body onLoad="init()">

<!--

<script> function displayDate()

{ var d = new Date(); if (d){ document.getElementById("demo").innerHTML = d.toString();

}

}

</script>

-->

</p>

<script type="text/javascript"> tday=new Array("Sunday","Monday","Tuesday","Wednesday","Thursday","Friday","Saturday"); tmonth=newArray"January","February","March","April","May","June","July","August",

"September","October","November","December"); function

GetClock(){ var d=new Date(); var nday=d.getDay(),nmonth=d.getMonth(),ndate=d.getDate(),nyear=d.getYear(); if(nyear<1000) nyear+=1900; var nhour=d.getHours(),nmin=d.getMinutes(),nsec=d.getSeconds(),ap; if(nhour==0){ap="

AM";nhour=12;} else if(nhour<12){ap="AM";} else if(nhour==12){ap="PM";}

69 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

else if(nhour>12){ap="PM";nhour-=12;} if(nmin<=9) nmin="0"+nmin; if(nsec<=9) nsec="0"+nsec; document.getElementById(’clockbox’).innerHTML=""+tday[nday]+", "+tmonth[nmonth]+"

"+ndate+", "+nyear+" "+nhour+ ":"+nmin+":"+nsec+ap+"";

}

</script>

<div id="clockbox"></div>

<div id="statusLabel"></div>

<!--

<div id="Avatar" align="center" class="round-button">

<div class="round-button-circle">

<a href="javascript:getStatus();" class="round-button">

</a>

</div>

</div>

-->

<table align=center>

<tr>

<td>

<div id="m1" align="center" class="round-button">

<div class="round-button-circle">

<a href="#dialModal" class="round-button" id="phoneAction">

<img src="img/phone.svg" id="phoneImage" width="48" height="48"></img>

</a>

</div>

</div>

</td>

<td>

<div id="m2" align="center" class="round-button">

<div class="round-button-circle">

<a href="javascript:onHoldPress();" class="round-button">

<img src="img/pause.svg" id="pause" width="48" height="48"></img>

</a>

</div>

</div>

</td>

<td>

<div id="m3" align="center" class="round-button">

<div class="round-button-circle">

<a href="javascript:onDtmfPad();" class="round-button">

<img src="img/dial.svg"></img>

</a>

</div>

</div>

</td>

<td>

<div id="m4" align="center" class="round-button">

<div class="round-button-circle">

<a href="#statsModal" class="round-button">

<img src="img/stats.png" width="48" height="48"></img>

</a>

Copyright © 31 July 2017 Moderro Technologies, Inc. 70

Moderro Interactive Experience Platform

</div>

</div>

</td>

<td>

<div id="m5" align="center" class="round-button">

<div class="round-button-circle">

<a href="javascript:onVolumePress();" class="round-button">

<img src="img/speaker.png" id="speaker" width="48" height="48"></img>

</a>

</div>

</div>

</td>

<td>

<div id="m6" align="center" class="round-button">

<div class="round-button-circle">

<a href="javascript:onMicPress();" class="round-button">

<img src="img/microphone.png" id="mic" width="48" height="48"></img>

</a>

</div>

</div>

</td>

<td>

<div id="m7" align="center" class="round-button">

<div class="round-button-circle">

<a href="#configModal" class="round-button">

<img src="img/config.png"></img>

</a>

</div>

</div>

</td>

</tr>

</table>

<!-- Configuration Dialog -->

<div id="configModal" class="modalDialog">

<div>

<a href="#close" title="Close" class="close">X</a>

<h2>Configure JCF</h2>

<table>

<tr>

<td>

<h3>CUCM IP / Name</h3>

</td>

<td>

<input type="text" name="CucmIP" id="CucmIP">

</td>

</tr>

<tr>

<td>

<h3>CUCM UserName</h3>

</td>

<td>

<input type="text" name="CucmUser" id="CucmUser">

</td>

</tr>

<tr>

<td>

<h3>CUCM Password</h3>

</td>

<td>

<input type="password" name="CucmPass" id="CucmPass">

</td>

Copyright © 31 July 2017 Moderro Technologies, Inc. 71

Moderro Interactive Experience Platform

</tr>

</table>

<input type="image" src="img/save.png" onclick="saveAndApply()" width="60%" >

</div>

</div>

<!-- Status Window Starts --> <div id="statsModal" class="statsDialog">

<div>

<a href="#close" title="Close" class="close">X</a>

<h2>Call Telemetry</h2>

<textarea id="callStats" rows="20" cols="80"></textarea>

</div>

</div>

<!-- Status Window Ends -->

<script> function onDtmfPad() {

// Dont do anything if we are not In a call if (inCall != true) return; if (dtmfPadShow == true)

{ dtmfPadShow = false; document.getElementById("dtmfModal").style.display = ’block’;

} else

{ dtmfPadShow = true; document.getElementById("dtmfModal").style.display =

’none’;

}

} function onVolumePress()

{ if (volumeShow == true) { volumeShow = false; document.getElementById("volumeModal").style.display

= ’block’;

} else

{ volumeShow = true; document.getElementById("volumeModal").style.display

= ’none’;

}

} function onMicPress()

{ if (micMuted == false)

{ micMuted = true; document.getElementById("mic").src = "img/mutedmic.png"; var jcfPhone = document.getElementById("jcf");

//console.log("Calling MUTE : "); jcfPhone.mute();

Copyright © 31 July 2017 Moderro Technologies, Inc. 72

Moderro Interactive Experience Platform

} else

{ micMuted = false; document.getElementById("mic").src = "img/microphone.png"; var jcfPhone = document.getElementById("jcf");

//console.log("Calling UNMUTE : "); jcfPhone.unmute();

}

} function onHoldPress() {

// Dont do anything if we are not in a

Call if (inCall != true) return; var jcfPhone = document.getElementById("jcf"); if (callHeld

== false)

{ callHeld = true; document.getElementById("pause").src = "img/accept.png";

//console.log("Calling CALL HOLD"); jcfPhone.callHold();

}

} callHeld = false; document.getElementById("pause").src = "img/pause.svg";

//console.log("Calling CALL RESUME"); jcfPhone.callResume(); function appendDial(num) { document.getElementById("DIAL").value += num;

} function trimDial() { var cur = document.getElementById("DIAL").value; cur = cur.substring(0, cur.length - 1); document.getElementById("DIAL").value = cur;

} function onCallButton() { var c = document.getElementById("DIAL").value; var jcf = document.getElementById("jcf");

//console.log("NUMBER IS " + c); jcf.call(c, true); document.getElementById("phoneImage").src = "img/conversation_end_button.png"; document.getElementById("phoneAction").href = "javascript:endCall();"; inCall = true; location.href="#close";

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 73

Moderro Interactive Experience Platform

function saveAndApply() { var cucmIP = document.getElementById("CucmIP").value; var cucmUser = document.getElementById("CucmUser").value; var cucmPass

= document.getElementById("CucmPass").value;

//console.log("CUCM IP " + cucmIP);

//console.log("CUCM USR " + cucmUser);

//console.log("CUCM PASS " + cucmPass); saveToApplicationData(); var jcfPhone = document.getElementById("jcf"); jcfPhone.start(cucmIP, cucmUser, cucmPass); location.href="#close";

} function endCall() { var jcfPhone = document.getElementById("jcf"); jcfPhone.hangup(); inCall = false;

} document.getElementById("phoneImage").src = "img/phone.svg"; document.getElementById("phoneAction").href = "#dialModal"; function acceptCall() { location.href="#close"; var jcfPhone = document.getElementById("jcf"); jcfPhone.answer(); document.getElementById("phoneImage").src = "img/conversation_end_button.png"; document.getElementById("phoneAction").href = "javascript:endCall();"; inCall = true;

} function rejectCall() { location.href="#close"; var jcfPhone = document.getElementById("jcf"); jcfPhone.reject(); document.getElementById("phoneImage").src = "img/phone.svg"; document.getElementById("phoneAction").href = "#dialModal"; inCall = false;

} function holdCall(toggle) { var jcfPhone = document.getElementById("jcf"); if (toggle) { jcfPhone.hold(); showHideInCallButton(false);

} else { jcfPhone.resume();

} showHideInCallButton(false);

} function showHideInCallButton(flag) {

/* if (flag)

{

// SHOW

//console.log("SHOWING IN CALL BUTTON"); document.getElementById("m1").style.display = ’none’; document.getElementById("m3").style.display = ’none’; document.getElementById("m5").style.display = ’block’;

Copyright © 31 July 2017 Moderro Technologies, Inc. 74

Moderro Interactive Experience Platform

} document.getElementById("m6").style.display = ’none’;

} else

{

// HIDE

//console.log("HIDING IN CALL BUTTON"); document.getElementById("m1").style.display = ’block’; document.getElementById("m3").style.display = ’block’; document.getElementById("m5").style.display = ’none’; document.getElementById("m6").style.display = ’none’;

}

*/ function getStatus() { var jcfPhone = document.getElementById("jcf"); var status = jcfPhone.status; if (!status)

{ status = " initializing ... ";

} document.getElementById("statusLabel").innerHTML = status;

//console.log("STATUS is " + status);

} function connectSlots() { var jcf = document.getElementById("jcf"); jcf.ready.connect(onReady); jcf.incomingCall.connect(onIncomingCall); jcf.placingCall.connect(onPlacingCall); jcf.ring.connect(onRing); jcf.trying.connect(onTrying); jcf.established.connect(onEstablished); jcf.disconnected.connect(onDisconnected); jcf.registered.connect(onRegistered); jcf.hold.connect(onHold); jcf.resume.connect(onResume); jcf.novideo.connect(onNoVideo); jcf.video.connect(onVideo); jcf.error.connect(onError); jcf.telemetry.connect(onTelemetry);

} function onReady() {

//console.log("OnReady Received"); document.getElementById("statusLabel").innerHTML = "Ready";

} function onIncomingCall(peer) {

// Dont react to multiple Firing of same signal if (prevSignal == ’incoming’) return; prevSignal = ’incoming’;

//console.log("Incoming Call From Peer : " + peer); document.getElementById("statusLabel").innerHTML = "Incoming Call From " + peer; location.href ="#incomingModal";

}

75 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

function onPlacingCall() {

//console.log("Calling ..."); document.getElementById("statusLabel").innerHTML = "Calling...";

} function onRing() {

//console.log("Ringing..."); document.getElementById("statusLabel").innerHTML = "Ringing";

} function onTrying() {

//console.log("Trying..."); document.getElementById("statusLabel").innerHTML = "Trying";

} function onEstablished() {

//console.log("Call Established ..."); document.getElementById("statusLabel").innerHTML = "Established"; setTimeout(function(){ document.getElementById("statusLabel").innerHTML = "In

Call";}, 5000);

} function onDisconnected() {

//console.log("Call

Disconnected..."); location.href

="#close"; document.getElementById("statusLabel").innerHTML = "Disconnected"; prevSignal = ""; setTimeout(function(){ document.getElementById("statusLabel").innerHTML =

"Ready";}, 5000);

} function onRegistered() {

//console.log("Registered Successfully ... "); document.getElementById("statusLabel").innerHTML = "Registered Successfully"; setTimeout(function(){ document.getElementById("statusLabel").innerHTML =

"Ready";}, 5000);

} function onHold() {

//console.log("Call Held ...."); document.getElementById("statusLabel").innerHTML = "Call Held";

} function onResume() {

//console.log("Call Resumed...."); document.getElementById("statusLabel").innerHTML = "Call Resumed"; setTimeout(function(){ document.getElementById("statusLabel").innerHTML =

"Ready";}, 5000);

} function onVideo() {

//console.log("On Video Signal..."); var l = document.getElementById("statusLabel").innerHTML; document.getElementById("statusLabel").innerHTML = "Video";

Copyright © 31 July 2017 Moderro Technologies, Inc. 76

Moderro Interactive Experience Platform

} setTimeout(function(){ document.getElementById("statusLabel").innerHTML = l;}, 5000); function onNoVideo() {

//console.log("On No Video Signal..."); var l = document.getElementById("statusLabel").innerHTML; document.getElementById("statusLabel").innerHTML = "Video"; setTimeout(function(){ document.getElementById("statusLabel").innerHTML = l;}, 5000);

} function onError(code, msg) {

//console.log("ERROR MSG : " + msg); document.getElementById("statusLabel").innerHTML = "ERROR:" + code + msg;

} function onSendDTMF(key) { var jcfPhone = document.getElementById("jcf");

//console.log ("SENDING DTMF With Key " + key); jcfPhone.sendDtmf(key);

} function onTelemetry(msg) { document.getElementById("callStats").innerHTML = msg; location.href ="#statsModal";

//console.log ("CALL TELEMETRY : " + msg);

}

</script>

<!-- Incoming Call Dialog -->

<div id="incomingModal" class="modalDialogSmall">

<div>

<a href="#close" title="Close" class="close">X</a>

<h2>Incoming Call</h2>

<br>

<div id="peerCalling"></div>

<br>

<br>

<script> document.getElementById(’peerCalling’).innerHTML

= document.getElementById(’statusLabel’).innerHTML

;

</script>

<input type="image" src="img/accept.png" onclick="acceptCall()" width="64" height="64">

<input type="image" src="img/exit.svg" onclick="rejectCall()" width="64" height="64">

</div>

</div>

<!-- Dial Pad -->

<div id="dialModal" class="modalDialogSmall">

<div>

<a href="#close" title="Close" class="close">X</a>

<h2>Dial Pad</h2>

<label>

<table align="center">

<tr>

<td><input type="text" name="DIAL" id="DIAL"> </td>

77 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<td>

<input type="image" src="img/delete.svg" width="24" height="24" onclick="trimDial()">

</td>

</tr>

</table>

</label>

<table align="center">

<container>

<tr>

<td onclick="appendDial(’1’)">

<a href="#dialModal"><block>1</block></a>

</td>

<td onclick="appendDial(’2’)">

<a href="#dialModal"><block>2</block></a>

</td>

<td onclick="appendDial(’3’)">

<a href="#dialModal"><block>3</block></a>

</td>

</tr>

<tr>

<td onclick="appendDial(’4’)">

<a href="#dialModal"><block>4</block></a>

</td>

<td onclick="appendDial(’5’)">

<a href="#dialModal"><block>5</block></a>

</td>

<td onclick="appendDial(’6’)">

<a href="#dialModal"><block>6</block></a>

</td>

</tr>

<tr>

<td onclick="appendDial(’7’)">

<a href="#dialModal"><block>7</block></a>

</td>

<td onclick="appendDial(’8’)">

<a href="#dialModal"><block>8</block></a>

</td>

<td onclick="appendDial(’9’)">

<a href="#dialModal"><block>9</block></a>

</td>

</tr>

<tr>

<td onclick="appendDial(’*’)">

<a href="#dialModal"><block>•</block></a>

</td>

<td onclick="appendDial(’0’)">

<a href="#dialModal"><block>0</block></a>

</td>

<td onclick="appendDial(’#’)">

<a href="#dialModal"><block>#</block></a>

</td>

</tr>

</container>

</table>

<input type="image" src="img/accept.png" onclick="onCallButton()" width="64"height="64">

</div>

</div>

Copyright © 31 July 2017 Moderro Technologies, Inc. 78

Moderro Interactive Experience Platform

<div id="frame">

<div id="frame border">

<object id="jcf" type="application/x-qt-plugin" classid="jcf" camera="TANDBERG" width="1280px" height="720px">

</object>

</div>

</div>

<!-- DTMF Pad -->

<div id="dtmfModal" align="center" style="display:none;">

<div>

<table bgcolor="#cdcdcd" align="center">

<tr>

<td onclick="onSendDTMF(’1’)">

<a href="#dtmfModal"><block1>1</block1></a>

</td>

<td onclick="onSendDTMF(’2’)">

<a href="#dtmfModal"><block1>2</block1></a>

</td>

<td onclick="onSendDTMF(’3’)">

<a href="#dtmfModal"><block1>3</block1></a>

</td>

<td onclick="onSendDTMF(’4’)">

<a href="#dtmfModal"><block1>4</block1></a>

</td>

<td onclick="onSendDTMF(’5’)">

<a href="#dtmfModal"><block1>5</block1></a>

</td>

<td onclick="onSendDTMF(’6’)">

<a href="#dtmfModal"><block1>6</block1></a>

</td>

<td onclick="onSendDTMF(’7’)">

<a href="#dtmfModal"><block1>7</block1></a>

</td>

<td onclick="onSendDTMF(’8’)">

<a href="#dtmfModal"><block1>8</block1></a>

</td>

<td onclick="onSendDTMF(’9’)">

<a href="#dtmfModal"><block1>9</block1></a>

</td>

<td onclick="onSendDTMF(’0’)">

<a href="#dtmfModal"><block1>0</block1></a>

</td>

<td onclick="onSendDTMF(’*’)">

<a href="#dtmfModal"><block1>•</block1></a>

</td>

<td onclick="onSendDTMF(’#’)">

<a href="#dtmfModal"><block1>#</block1></a>

</td>

</tr>

</table>

</div>

</div>

<!-- Speaker Volume START -->

<div id="volumeModal" align="center" style="display:none;">

<script> function updateSlider(slideAmount) { var sliderDiv = document.getElementById("sliderAmount"); var jcfPhone

79 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

= document.getElementById("jcf"); sliderDiv.innerHTML

= slideAmount; setTimeout(function(){ volumeShow = false; onVolumePress();

}, 4000); if (slideAmount == 0)

{ document.getElementById("speaker").src = "img/mutespeaker.png";

} else

{ document.getElementById("speaker").src = "img/speaker.png";

}

//console.log("CALLING setVolume with : " + slideAmount); jcfPhone.setVolume(slideAmount);

}

</script>

<input id="slide" type="range" min="0" max="100" step="1" value="75" onchange="updateSlider(this.value)">

<div id="sliderAmount"> </div>

</div>

<!-- Speaker Volume END -->

<!-- DEBUG PURPOSE ONLY START -->

<script> function saveToApplicationData()

{ var cucmIP; var cucmUser; var cucmPass; cucmIP = document.getElementById("CucmIP").value; cucmUser = document.getElementById("CucmUser").value; cucmPass

= document.getElementById("CucmPass").value;

// Check? global.applicationData.insert("sip.domain", cucmIP); global.applicationData.insert("sip.username", cucmUser); global.applicationData.insert("sip.password", cucmPass);

}

// Camera? setTimeout(function(){ var temp = "default"; var cucmIP = global.applicationData.value("sip.domain", temp); var cucmUser = global.applicationData.value("sip.username", temp); var cucmPass = global.applicationData.value("sip.password", temp); if ((cucmIP == temp) || (cucmUser == temp) || (cucmPass == temp))

{ alert("Please Configure Application Data via IEM"

+ " or via the Application’s Configure button ");

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 80

Moderro Interactive Experience Platform

else

{ document.getElementById("CucmIP").value = cucmIP; document.getElementById("CucmUser").value = cucmUser; document.getElementById("CucmPass").value

= cucmPass; saveAndApply();

}

}, 5000);

</script>

<!-- DEBUG PURPOSE ONLY END -->

</div>

</body> </html>

PdfViewer Widget

The PdfViewer plugin provides the ability to display Adobe PDF documents on the browser. interface PdfViewer

{ attribute string url; attribute int dpi; attribute bool controlsVisible; attribute bool pageNumberVisible; attribute int pageNumber; readonly attribute int numberOfPages; int next(); int previous(); signals: void loadStarted(); void loadFinished(in bool ok);

}; attribute bool controlsVisible; attribute bool pageNumberVisible; attribute int pageNumber; readonly attribute int numberOfPages; int next(); int

}; previous(); signals: void loadStarted(); void loadFinished(in bool ok);

The following HTML document contains an example of Pdf

Copyright © 31 July 2017 Moderro Technologies, Inc. 81

Moderro Interactive Experience Platform

Viewer usage (file ../../test/plugins/pdfviewer.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: pdfviewer plugin test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; fontsize: 20px; color: #eeeeee;

}

</style>

<script type="text/javascript"> var pdfViewer; var textDpi; var checkBoxControlsVisible; var checkBoxPageNumberVisible; function main()

{ textDpi.value = pdfViewer.dpi; checkBoxControlsVisible.checked =

} function error(message)

{ pdfViewer.controlsVisible; checkBoxPageNumberVisible.checked = pdfViewer.pageNumberVisible; alert ("PDF viewer error: " + message);

} function init()

{ pdfViewer = document.getElementById("pdfViewer"); textDpi = document.getElementById("textDpi"); checkBoxControlsVisible = document.getElementById("checkBoxControlsVisible"); checkBoxPageNumberVisible = document.getElementById("checkBoxPageNumberVisible");

Copyright © 31 July 2017 Moderro Technologies, Inc. 82

Moderro Interactive Experience Platform

} pdfViewer.loadFinished.connect(main); pdfViewer.error.connect(error); function setControlsVisible()

{ pdfViewer.controlsVisible = checkBoxControlsVisible.checked;

} function setPageNumberVisible()

{ pdfViewer.pageNumberVisible = checkBoxPageNumberVisible.checked;

} function setDpi()

{ pdfViewer.dpi = textDpi.value;

}

</script>

</head>

<body onload="init()">

<div align="center">

DPI <input id="textDpi" type="text" />

<input type="button" value="Set DPI" onclick="setDpi();" />

&nbsp;&nbsp;

<input type="button" value="Previous page" onclick="pdfViewer.previous();" />

<input type="button" value="Next page" onclick="pdfViewer.next();" />

<br />

<object id="pdfViewer" type="application/x-qt-plugin" classid="pdfviewer" width="480" height="640">

<param name="url" value="http://embedded-computing.com/pdfs/QNX.Jan05.pdf"/>

<param name="dpi" value="150"/>

<param name="controlsVisible" value="true"/>

<param name="pageNumberVisible" value="true"/>

<param name="pageNumber" value="3"/>

</object>

<br />

<input id="checkBoxControlsVisible" type="checkbox" onchange="setControlsVisible()" />Controls visible

<input id="checkBoxPageNumberVisible" type="checkbox" onchange="setPageNumberVisible()" />Page number visible

</div>

</body>

</html>

RemoteDesktop Widget

interface RemoteDesktop

{ readonly attribute bool isConnected; attribute bool interactive ;

83 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

methods: void connectToHost(in string host, in int port, in string password, in bool interactive = true, in string serverPublicKey =

""); void disconnect() ; string errorString (in int code); signals : void error(in int code); void connected(); void disconnected();

};

Table 3-4 Variables

Variable

interactive connectToHost disconnect errorString

Description

Whether the user can control the remote desktop with mouse and keyboard. Even if interactive is true, the server can decline the user activity events.

Connect to the given host and port with the given password. If serverPublicKey is not empty, it will be compared to the public key of the server. If it does not match, the connection will not be established. serverPublicKey must be generated using the RSA algorithm and encoded in the PEM format.

Disconnect from the host.

Returns the error description.

Note

This plugin uses a proprietary protocol and is only compatible with the Remote Desktop Server.

The following HTML contains an example of remotedesktop usage.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: remotedesktop plugin test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; font-

Copyright © 31 July 2017 Moderro Technologies, Inc. 84

Moderro Interactive Experience Platform

size: 20px; color : #eeeeee;

}

</style>

<script type="text/javascript"> var host; var port; var password; var interactive

; var rd; var status

; var key; function connected()

{ status .innerHTML = "<font color='#00FF00'>CONNECTED</font>";

} function disconnected()

{ status .innerHTML = "<font color='#FF0000'>DISCONNECTED</font>";

} function error(code)

{ alert ("Remote desktop error: " + rd.errorString(code));

} function init ()

{ host = document.getElementById("host"); port

= document.getElementById("port"); password = document.getElementById("password"); interactive = document.getElementById("interactive"); key = document.getElementById("key"); rd = document.getElementById("rd"); status = document.getElementById("status"); rd.connected.connect(connected); rd.disconnected.connect(disconnected);

} function connect()

{ rd. error .connect(error)

; disconnected();

// host, port, password, interactive , public key to check (can be empty) rd.connectToHost(host.value, parseInt(port.value) , password.value, interactive

.checked, key.value) ;

} function disconnect()

{ rd.disconnect() ;

} function isConnected()

{ alert (rd.isConnected ? "Yes" : "No");

} function interactiveChanged(obj)

{ rd. interactive = obj.checked;

85 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

}

</script>

</head>

<body onload="init()">

<div align="center">

Host: <input id="host" type="text" />

: <input id="port" type="text" value="6050"

/> Password: <input id="password" type="text" />

<label><input id="interactive" type="checkbox" onclick='interactiveChanged(this);'

/>Interactive</label>

<br />

Public key to check:

<br />

<textarea id="key" rows="4" cols="64" style="font-family:Bitstream Vera Sans

Mono,Courier New,monospace;">

</textarea>

<br />

<button onclick="connect()">Connect</button>

<button onclick="disconnect()">Disconnect</button>

<button onclick="isConnected()">Connected?</button>

<br />

<object id="rd" type="application/x-qt-plugin" classid="remotedesktop" width="640" height="480">

</object>

<br />

<span id="status"></span>

</div>

</body>

</html>

SipPhone Widget

The SipPhone widget allows you to make SIP video calls to another SIP endpoint.

This plugin acts like a True SIP endpoint and supports both audio and video calls. Both SD (g711) and HD

(g7221) audio codecs are supported. For video, it supports H.263 and H.264 codecs. interface SipPhone

{ attribute int height; attribute int width; attribute string backgroundColor; attribute string idleImage; attribute bool videoEnabled; // Is true by default. attribute string status; parameters: int width;

Copyright © 31 July 2017 Moderro Technologies, Inc. 86

Moderro Interactive Experience Platform

int height; int backgroundColor; string camera; string resolution

; string bitrate

; string fps ; slots: int start (in string username, in string password, in string domain, in string transport); void call(in string sipUri); void hangup(); void sendDtmf(in string dtmfkey); bool setidleImage(in string imgurl, in bool stretchFlag); bool changeidleImage(in string imgurl, in bool stretchFlag); bool addVideoToCall(in bool videoFlag); bool enableAudibleTones(in bool toneFlag); string cameraDevice() const; int setCameraDevice(in string deviceId); int capture() const; string getImage() const; // Returns the Jpeg imgage if captured void answer(); void reject(); void setAutoAnswer(in bool autoAnswerFlag); signals:

} void ready(); void registered(); void placingCall(); void incomingCall(); void established(); void ring(); void disconnected(); void video(); void novideo(); void hold(); void resume(); void captured(); void error(in int code, in string explanation);

Copyright © 31 July 2017 Moderro Technologies, Inc. 87

Moderro Interactive Experience Platform

Parameters

width height backgroundColor camera resolution bitrate fps

Table 3-5 SipPhone Parameters

Description

Use this parameter to define the width for the Sip widget.

This parameter is used to define the height for the

Sip widget.

Use this parameter to define the background color of the Sip widget.

This parameter is used to specify the USB webcam to be used. This should be in the Unix

Device format; like, /dev/video0.

This parameter could be used when you want Sip widget to send the video at a specified resolution.

Note

If you choose higher resolution like

1280x720 or 1920x1080, the CPU utilization will increase. Additionally, the resolution should be in the format of

WxH. If WxH is not in the Aspect

Binding Ratio, SipPhone will try to match the video encode to the closest possible resolution.

Use this parameter to specify the minimum bitrate that the Sip Widget should use when sending the encoded frame.

Usr this parameter to specify the minimum fps

(Frames Per Second) that should be captured for the video encoding.

Table 3-6 SipPhone Variables

Variable

start(in string username, in string password, in string domain, in string transport) call(in string sipUri) hangup()

Description

This method call is to be used to set the SIP credentials that are needed to get registered with the SIP Registrar (or Call Manager). The needed credentials are Username, Password, Domain (IP

Address or Domain Name of the SIP Registrar) and the transport to be used (UDP or TCP).

This method should be used only after the start(...) method is called. This method initiates the call to the sipUri (called party).

This method, when called, disconnects the existing call.

Copyright © 31 July 2017 Moderro Technologies, Inc. 88

Moderro Interactive Experience Platform

sendDtmf(in string dtmfkey) setidleImage(in string imgUrl, in bool stretchFlag)

This method sends DTMF tones to the SIP proxy.

Valid DTMF keys are 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 0,

*, and #.

This method can be used to display an image, like logo or some graphic when the SIP widget is registered and not in a call. This method provides a mechanism for the widget to display an image when it is not in a call. The parameters are imgUrl, the URL for the image to be displayed, stretchFlag, which indicates whether to auto resize or not the image to the given frame. changeidleImage(in string imgUrl, in string sipUri)

This method is similar in functionality to setidleImage. You could use this method to change the appearance of the widget like coding it in javascript to change the idleimage to create the sense of screen saver for the widget. addVideoToCall(in bool videoFlag)

This method enables to either add or remove the video stream from an existing video call. The prerequisite is that the call should be negotiated as a video call.

Set this function as True to enable the video stream in the call.

Or enableAudibleTones(in bool toneFlag) cameraDevice() setCameraDevice()

Set this function with videoFlag as False to disable the video stream from the video call.

By default, video stream is enabled.

If you would like to enable the default audible alerts for all the call events, set the parameter of this API as True. By default, audible alerts are disabled.

This method returns the currently configured webcam that is being used by the SipPhone widget. The value returned would be in the UNIX format similar to “/dev/video0”.

Use this method to let the SipPhone widget know which webcam to use to place the call. You need to call this API with UNIX format identifier for camera, such as “/dev/video0” or “/dev/video1”. capture()

Note Call this API before the start() method in the Javascript.

Use this method to initiate taking a still image when the video call is in progress. This is useful if you would like to take a snapshot of the

89 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

getImage() answer() reject() setAutoAnswer(in bool autoAnswerFlag) ready() registered() placingCall() incomingCall() established() ring() disconnected() video() novideo() hold() resume() participant and save it for future reference.

Caution Call this routine only when there is an active video call.

Call this method after you have received the captured() signal. When this method is called, the routine returns base64 content of the captured

JPEG image.

Accepts incoming call.

Rejects incoming call.

Enables auto answer mode if the autoAnswerFlag is “true”.

This signal is indicative that values given for initializing the sipphone are accepted.

This signal means that the sipphone is now registered with the SIP Registrar (or Call

Manager) and you can make and receive calls from the widget.

This signal means the widget is trying to place the call to the called party of interest.

This signal means the widget is receiving an incoming call request from another SIP peer.

This signal is indicative that the call is in progress.

This signal means that the called party has been notified about the incoming call.

This signal means that the call has been terminated.

This signal means that the call was negotiated as a video call and the remote site video is available to display.

This signal means that the call that was negotiated does not have video being sent by the remote end.

The application can use the novideo signal to improve the user experience such as displaying a

“Please wait” message.

This signal means that the remote party has put the call on hold. An image can be displayed on the screen when a SIP call is placed on hold. The image that is included in this signal will be shown on the screen.

This signal means that the remote party has resumed the call. Upon receiving this signal, the application will revert to the original screen and the on-hold image will be hidden.

Copyright © 31 July 2017 Moderro Technologies, Inc. 90

Moderro Interactive Experience Platform

captured() error(in int code, in string explanation)

This signal is fired when an user action of taking a still snapshot of an video call is successfully finished. Once this signal is fired, the application can call getImage() to get the captured image (as a JPEG image).

This signal is indicative of any errors whilst the widget operation. The signal has a code and an explanation about the error that was encountered.

Error Codes:

404: No answer

401: Registration failed

485: User busy

494: User not found

486: Call manager not able to route call

503: Service unavailable

The following HTML document contains an example of SipPhone usage.

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0

Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1transitional.dtd">

<html xmlns="http://www.w3.org/1999/xhtml">

<head>

<meta http-equiv="Content-Type" content="text/html; charset=UTF-8" />

<title>..:: sipphone test ::..</title>

<style type="text/css"> html, body

{ padding: 0; margin: 0; width: 100%; height: 100%

} body

{ background:

#1e2024; color:

#ffffff; font: normal 12px Arial, Helvetica, sans-serif;

}

.cameraDisabled,

.cameraReady,

.cameraOnline,

.cameraError

Copyright © 31 July 2017 Moderro Technologies, Inc. 91

Moderro Interactive Experience Platform

{ width:

44px; height:

24px; background: transparent url('images/webcam-DISABLED.png') center center no-repeat;

}

.cameraReady

{ background-image: url('images/webcam-READY.png');

}

.cameraOnline

{ background-image: url('images/webcam-ONLINE.png');

}

.cameraError

{ background-image: url('images/webcam-OFFLINE.png');

}

.topPanel

{ background: #0e1014 url('images/bg-top-panel.png') top left repeat-x; color: #4c5058; text-shadow: 0 -1px 1px #000; font: normal 14px Arial, Helvetica, sansserif; height: 41px;

}

.status

{ color: #848d9d; text-shadow: 0 -1px 1px #000; font: normal 14px Arial, Helvetica, sansserif; padding: 0 20px;

}

.bottomPanel

{ background: #0e1014 url('images/bg-bottom-panel.png') top left repeat-x; color: #4c5058; text-shadow: 0 -1px 1px #000; font: normal 14px Arial, Helvetica, sansserif; height: 80px;

}

.calltime

{ color: #b1b6c3; font: normal 14px Arial, Helvetica, sansserif; height: 41px; text-shadow: 0 -1px 1px #000;

}

.buttons

Copyright © 31 July 2017 Moderro Technologies, Inc. 92

Moderro Interactive Experience Platform

{

} text-align: center; display: inlineblock; padding: 0

30px 0 30px;

.callButton,

.endCallButton,

.acceptButton,

.rejectButton

{ width:

170px; height:

56px; background: transparent url('images/call-IDLE.png') center center no-repeat; border: none;

}

.callButton:hover

{ background-image: url('images/call-HOVER.png');

}

.callButton:active

{ background-image: url('images/call-PRESSED.png');

}

.callButton:disabled

{ background-image: url('images/call-DISABLED.png');

}

.endCallButton

{ background-image: url('images/call-end-IDLE.png');

}

.endCallButton:hover

{ background-image: url('images/call-end-HOVER.png');

}

.endCallButton:active

{ background-image: url('images/call-end-PRESSED.png');

}

.endCallButton:disabled

{ background-image: url('images/call-end-DISABLED.png');

}

.acceptButton

{

Copyright © 31 July 2017 Moderro Technologies, Inc. 93

Moderro Interactive Experience Platform

} background-image: url('images/accept-IDLE.png');

.acceptButton:hover

{ background-image: url('images/accept-HOVER.png');

}

.acceptButton:active

{ background-image: url('images/accept-PRESSED.png');

}

.acceptButton:disabled

{ background-image: url('images/accept-DISABLED.png');

}

.rejectButton

{ background-image: url('images/reject-IDLE.png');

}

.rejectButton:hover

{ background-image: url('images/reject-HOVER.png');

}

.rejectButton:active

{ background-image: url('images/reject-PRESSED.png');

}

.rejectButton:disabled

{ background-image: url('images/reject-DISABLED.png');

}

.view

{ background: #000; border: solid 1px

#3b3d40; text-align: center; width: 100%;

}

.timerOn,

.timerOff

{ color: #b1b6c3; font: normal 36px Arial, Helvetica, sansserif; height: 41px; text-shadow: 0 -1px 1px #000;

}

.timerOff

Copyright © 31 July 2017 Moderro Technologies, Inc. 94

Moderro Interactive Experience Platform

{ color: #292e33;

}

.dislpad_disabled

{ width:

43px; height:

43px; background: transparent url('images/dialpad-DISABLED.png') center center no-repeat; border: none;

}

</style>

<script type="text/javascript"> var sipphone;

// These are the Credentials for the SIP endpoint

// It is recommended that you use the

// Application Data at the IEM profile to set these

// Values and get them via the global.applicationData.value() API. var username

"default");

= global.applicationData.value("sip.username", var password = global.applicationData.value("sip.password", "default"); var domain = global.applicationData.value("sip.domain", "default"); var transport = global.applicationData.value("sip.transport", "default"); function init()

{ sipphone = document.getElementById("sipphone");

// Now Call Start Routine with the SIP Credentials

// that we got from the applicationData sipphone.start(username, password, domain, transport); sipphone.placingCall.connect(onPlacingCall); sipphone.incomingCall.connect(onIncomingCall); sipphone.ready.connect(onReady); sipphone.registered .connect(onRegistered); sipphone.established .connect(onEstablished); sipphone.ring.connect(onRing); sipphone.disconnected.connect(onDisconnected); sipphone.novideo.connect(onNoVideo); sipphone.video.connect(onVideo); sipphone.hold.connect(onHold); sipphone.resume.connect(onResume); sipphone.error .connect(onError); } function onNoVideo()

{ document.getElementById("Status").innerHTML = "No Video...";

} function onVideo()

Copyright © 31 July 2017 Moderro Technologies, Inc. 95

Moderro Interactive Experience Platform

{ document.getElementById("Status").innerHTML = "Video Started (In Call)";

} function onHold()

{ document.getElementById("Status").innerHTML = "Call Held by Remote End";

} function onResume()

{ document.getElementById("Status").innerHTML = "Call Resumed (In

Call)"; function onPlacingCall()

{ document.getElementById("Status").innerHTML = "Calling"; document.getElementById("CallButton").className = "callButton"; document.getElementById("cameraStatusLed").className = "cameraReady"; document.getElementById("Status").innerHTML = "Calling..."; document.getElementById('theTime').className = "timerOn";

} function onIncomingCall()

{ document.getElementById("Status").innerHTML = "Incoming call"; document.getElementById("CallButton").className = "acceptButton"; document.getElementById("cameraStatusLed").className = "cameraReady"; document.getElementById('theTime').className = "timerOn";

} function onReady()

{ document.getElementById("Status").innerHTML = "Ready"; document.getElementById("CallButton").className = "callButton"; document.getElementById("cameraStatusLed").className = "cameraDisabled"; document.getElementById('theTime').className = "timerOff";

} function onRegistered()

{ document.getElementById("Status").innerHTML = "Registered"; document.getElementById("CallButton").className = "callButton";

} document.getElementById("cameraStatusLed").className = "cameraDisabled"; document.getElementById('theTime').className = "timerOff"; function onEstablished()

{ document.getElementById("Status").innerHTML = "In Call"; document.getElementById("CallButton").className = "endCallButton"; document.getElementById("cameraStatusLed").className =

"cameraOnline"; document.getElementById('theTime').className =

"timerOn"; countDown(1);

} function onRing()

{ document.getElementById("Status").innerHTML = "Calling";

Copyright © 31 July 2017 Moderro Technologies, Inc. 96

Moderro Interactive Experience Platform

} document.getElementById("CallButton").className = "acceptButton"; document.getElementById("cameraStatusLed").className = "cameraReady"; document.getElementById('theTime').className = "timerOn"; function onDisconnected()

{ document.getElementById("Status").innerHTML = "Ready"; document.getElementById("CallButton").className = "callButton"; document.getElementById("cameraStatusLed").className = "cameraDisabled"; document.getElementById('theTime').className = "timerOff"; countDown(0);

} function onError(code, explanation)

{ document.getElementById("Status").innerHTML = "<span style='color:#ff6920;'>Error :

</span>" + explanation + " (SIP code = " + )"; document.getElementById("CallButton").className = "callButton"; document.getElementById("cameraStatusLed").className = "cameraError";

} var callInProgress = false; function call(uri)

{ if (callInProgress)

{ callInProgress = false; sipphone.hangup();

} else

{ callInProgress = true; sipphone.call(uri);

}

}

// Conversation time. var sec = 0; var min =

0; var hrs

= 0; var conversationTimer; function stopConversationTimer()

{ window.clearTimeout(conversationTimer); sec = 0; min = 0;

} function tickConversationTimer()

{

++nse; if (sec == 59)

97 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

{ sec = 00;

++min;

} if (min == 59)

{ min = 00;

++hrs;

} if (sec <= 9) sec = "0" + sec;

} time = (hrs <= 9 ? "0" + hrs : hrs) + ":" + (min <= 9 ? "0" + min : min) + ":" + sec; document.getElementById('theTime').innerHTML = time; conversationTimer = window.setTimeout("tickConversationTimer();", 1000);

</script>

</head>

<body onload="init()">

<table border="0" cellpadding="0" cellspacing="0" width="100%" height="100%">

<tr>

<td align="center">

<table border="0" cellpadding="0" cellspacing="1" align="center">

<tr>

<td class="topPanel">

<table border="0" cellpadding="0" cellspacing="0" width="100%" height="100%" style="width: 100%; max-width: 640px">

<tr>

<td width="49%" style="min-width: 160px" align="left"><span class=" status" id="Status">&nbsp;</span></td>

<td align="center">

<div style="min-width: 162px">

<table border="0" cellpadding="0" cellspacing="0" height="100%">

<tr>

<td width="44"><div style="width:

44px">&nbsp;</div></ td>

<td width="74" align="center" style="width: 74px"><img id="camera" src="images/eye.png" width="30" height="30" /></td>

<td width="44"><img id="cameraStatusLed" class=" cameraDisabled" src="images/spacer.png" width="44 " height="24" /></td>

</tr>

</table>

</div>

</td>

<td width="49%" style="min-width: 160px" align="right">&nbsp;</td>

</tr>

</table>

</td>

</tr>

<tr>

<td class="view">

<object id="sipphone" type="application/x-qt-plugin" classid="sipphone" width="640" height="480">

Copyright © 31 July 2017 Moderro Technologies, Inc. 98

Moderro Interactive Experience Platform

<param name="url" value="http://"/>

<param name="width" value="640"/>

<param name="height" value="480"/>

</object>

</td>

</tr>

<tr>

<td class="bottomPanel">

<table border="0" cellpadding="0" cellspacing="0" width="100%" height=" 100%" style="width: 100%; max-width: 640px">

<tr>

<td align="right" width="49%" style="min-width: 160px"><span class=

"timerOff" id="theTime">0:00</span></td>

<td align="center">

<div class="buttons">

<input type="button" id="CallButton" class="callButton" value="" onclick="call('sip:130');" />

</div>

</td>

<td width="49%" style="min-width: 160px; text-align: right">

<div style="display: inline-block; padding: 0 20px; width: 80%; text

-align: left;">

<input type="button" value="" id="dialpad" class=" dialpad_disabled" title="Show dialpad" />

</div>

</td>

</tr>

</table>

</td>

</tr>

</table>

</td>

</tr>

</table>

<div style="display:none; visibility:hidden">

<!-- Changing images. -->

<img src="images/webcam-DISABLED.png" width="0" height="0" />

<img src="images/webcam-READY.png" width="0" height="0" />

<img src="images/webcam-ONLINE.png" width="0" height="0" />

<img src="images/webcam-OFFLINE.png" width="0" height="0" />

<img src="images/call-IDLE.png" width="0" height="0" />

<img src="images/call-HOVER.png" width="0" height="0" />

<img src="images/call-PRESSED.png" width="0" height="0" />

<img src="images/call-DISABLED.png" width="0" height="0" />

<img src="images/call-end-IDLE.png" width="0" height="0" />

<img src="images/call-end-HOVER.png" width="0" height="0" />

<img src="images/call-end-PRESSED.png" width="0" height="0" />

<img src="images/call-end-DISABLED.png" width="0" height="0" />

<img src="images/accept-IDLE.png" width="0" height="0" />

<img src="images/accept-HOVER.png" width="0" height="0" />

<img src="images/accept-PRESSED.png" width="0" height="0" />

<img src="images/accept-DISABLED.png" width="0" height="0" />

<img src="images/reject-IDLE.png" width="0" height="0" />

<img src="images/reject-HOVER.png" width="0" height="0" />

<img src="images/reject-PRESSED.png" width="0" height="0" />

<img src="images/reject-DISABLED.png" width="0" height="0" />

</div>

</body>

Copyright © 31 July 2017 Moderro Technologies, Inc. 99

Moderro Interactive Experience Platform

</html>

You can enter the call manager information either in this widget or in an IEM policy. If you want to hard code the call manager information in this widget, enter the information in the sipphone.start(username, password, domain, transport) line. You will need the call manager ID, which is a number, for the username, the call manager password, and the IP address for the domain. Enter “udp” for the transport.

See Appendix F of the Moderro Interactive Experience Client 4600 Series User Guide for detailed instructions on how to configure a SIP client.

Ticker Widget

The Ticker plugin allows you to create a ticker displaying a scrolling text. The native ticker widget's text size is limited to 1024 characters. interface Ticker

{ attribute string text; attribute int fontSize; attribute string fontFamily; attribute bool fontBold; attribute bool fontItalic; attribute string backgroundImage; attribute string backgroundColor; attribute string textColor; attribute string direction; attribute int speed; parameters: string text

; int fontSize ; string fontFamily; bool fontBold; bool fontItalic

; string backgroundImage; string backgroundColor; string textColor; string direction ; int speed;

};

Table 3-7 Variables

Variable Description

Copyright © 31 July 2017 Moderro Technologies, Inc. 100

Moderro Interactive Experience Platform

text fontSize fontFamily fontBold fontItalic backgroundImage backgroundColor textColor direction speed

Use this method to specify the text to be displayed.

This method can be used to specify the font size.

Specify the font family using this method.

Use this method if the specified text font is bold.

Use this method to display the specified text in italics.

Use this method to include background image as a pure BASE64 data (without data: HTML prex).

This method can be used to specify the background color.

Use this method to specify the text color in

#RRGGBB format.

Specify the scrolling direction. The possible values are:

LeftToRight

RightToLeft

TopToBottom

BottomToTop.

Specify the scrolling speed. Possible values are from

1 to 12.

The following HTML document contains an example of ticker usage

(file.../../test/plugins/scrollingtext.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: scrollingtext plugin test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; fontsize: 20px; color : #eeeeee;

}

</style>

<script type="text/javascript"> var st

; var ind; var ndirection = 1;

Copyright © 31 July 2017 Moderro Technologies, Inc. 101

Moderro Interactive Experience Platform

function init ()

{ st = document.getElementById("scrollingtext"); ind = 0;

} function start ()

{ st . start () ;

} function stop()

{ st .stop() ;

} function stext ()

{ st . text = "New text #" + ind++;

} function direction ()

{ ndirection++; if (ndirection >

3) ndirection

= 0; switch(ndirection)

{ case 0: st . direction = "LeftToRight"; break; case 1: st . direction =

"RightToLeft"; break; case 2: st . direction

= "TopToBottom"; break; case 3: st . direction = "BottomToTop"; break;

}

} function bold()

{ st .fontBold = !st .fontBold;

} function italic ()

{ st . fontItalic = !st . fontItalic ;

}

</script>

</head>

<body onload="init()">

<center>

<br/>

<div>

<object id="scrollingtext" type="application/x-qt-plugin" classid="ticker" width="100%" height="80px">

<!--

All these parameters are available from JavaScript as object attributes . E.g. you can read and write them with

// get object var st = document.getElementById("scrollingtext");

// set new text st . text = "New text";

Copyright © 31 July 2017 Moderro Technologies, Inc. 102

Moderro Interactive Experience Platform

// set new font size st . fontSize

= 30;

// read current text alert (st . text) ;

-->

<!-- text to show (empty by default) -->

<param name="text" value="Lorem ipsum dolor sit amet, consectetur adipiscing elit.

Vestibulum ut sem leo." />

<param name="fontSize" value="24" /> <!-- font size (system-dependent by default)-->

<param name="fontFamily" value="Arial" /> <!-- font family (system-dependent by default) -->

<param name="fontBold" value="false" /> <!-- bold font (system-dependent by default) -->

<param name="fontItalic" value="false" /> <!-- italic font (system-dependent by default) -->

<!-- background image as a base64 data (empty by default) -->

<param name="backgroundImage" value="\

/9j/4AAQSkZJRgABAQEASABIAAD//gA8Q1JFQVRPUjogZ2QtanBlZyB2MS4wICh\

1c2luZyBJSkcgSlBFRyB2NjIpLCBxdWFsaXR5ID0gMTAwCv/bAEMAAQEBAQEBAQ\

EBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBA\

QEBAQEBAQEBAf/bAEMBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEB\

AQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAQEBAf/AABEIAPYAMAMBIgACEQE\

DEQH/xAAaAAADAQEBAQAAAAAAAAAAAAAAAQQCAwUK/8QALxABAAIBAwMDAwIHAQ\

EBAAAAAREhMQJBUQASYQNxgRMikTKhQlJyscHR8GKS4v/EABsBAAIDAQEBAAAAA\

AAAAAAAAAECAAMEBQkK/8QALxEAAQIEBAUEAQQDAAAAAAAAAREhAAIxQVFhcfAD\

EoGRoROxwdHhIkJSYjLC8f/aAAwDAQACEQMRAD8A+ifXqNUQuFZw48FMzdQRQSZ\

XCVSBqcRkuLmtv9cter9LpXMML939NzUpYZq+s69U9sNzs5IL1IYIeW52v5kFol\ aIFwAVrm+MegQlJSyr4jt3ZBFtTOdqueYrPFKSKomd8bO901ilhrrh3avNtM6bZ\ bGVIoYC72noHX5YKvTOXeX498kdRSbm18Kb6w3p5+PzFBq0kxRBzl9p4jxFTL1j\

U1M90SRBvvSLEXtPi3nOqoWd/wBPhwO1Pznpffzqm/5fw3vvne76ImIR2wy3SCJ\

EKq+mm9ucEpbhaedJlkhbscbnPVq7RiV2rTj58PAbfynXMFP1TGIWZdp2jFjAs9\

LXGkltXEwCzMTk5MzDVdLve0i0SkmhGq73rGu/GwbBaR905LsHJNsHT+pRGLLFo\ lWCZeO4iquR4/V0i/a8RUFcxMu8ruZnp/U0z+m3adJ/z4zmZIgqcTROkHkOW97v\

1PVY3L8/p8s5JtnfL031IiO6JZztNARwRBucnXL6xP6WY5N7D546PqXDo/EYvM+\

9uJkvoROQ4hb/ABaOOj1AZsgpYZOXKsbv7dadSzN/IHlEa2nLLWJ6h060iZ3kVW\

4iVuv2vJKB60MFaRhtVfBppaUObIvpZgVlIFD0sy0Bw+0XVLKrkB6AL7b0EVOtF\

BdTJgg2lmHE7TzjpfUXKjtZfARh9lpOpH1SXcim8kDmazny7vR9bMu2JbKfAYS4\

X7vfoiYMpGJpkuHkv3MWch/j7ZfQ0TKK31HZWhrTz8YzZOMX0PqJhU5gPzOI36k\ fUSftS/8A19xISyRNkmM31l9RViYqbRUjzj2nxVg55cfBich/jcI2lcPhBhE5q1\

RHdxkC2c/atJ4JnjpOp5mPhBxO04AS5w1PF1Y+6ZPepG2Q+fLxKd7TOrnELUS25\

Xc3YsIgmkLMNQwHtbE2ZUjR6SIwNVQIVZHQZhnYRt1EqagZdmFmRZ2aOBt2Ot/U\

IzpmdmPZySNU4jaeoXVK0Ef1FITETupXA7da71rt0xEVMohYSGlvO3NdEygigbA\

AGyPfR0TCHHDKPXGtgoNFtS73i36k26K4XiIw/wDeK6f1UyDTlj/sUK7Rt1Gesb\ k7t2TaySXMREk+OuneWhmWMZZrcZf75CFDLKP5ai9N0HVoh4UwSinzolfESGuYZ\ tBPJExH4lGeKy+5tGAlLEnw+JkPHnqQ1gY1G0ycZ8xEmWZZ5O7eWNnbm7qXHLEx\

1SJ5TeN44ZAq7fC7+4ofUBYF4lGbCrkxDmyQgEwatTUunVO0LEFSKAfkxddcVbh\ kn4+CQzewcTPS79RH3cfzQFxB+ZlMUO9gmIAFQED1bOG9IGxVnS6BGS6Y6IkUuq\

9nxw7++rVw5h6Z6moWXuLkMudrgEjyhnqR7pzqJhgUNsGBMPlHEwd3lndllAuxf\ eJSMXXVksxmqKAfXxnC+kURAQRZQBTEDFVpnSJ31NQtsRLN9sMbXUxSLnFdM9TW\

R908GrTCtZx88TEu0/1GgdJmcIxMBOrVEPImd4OsuvUlm+0FryP7EqLEdc3mlYj\ mlOVHSoJFL0VOsaxIQHCqiMrnBtLnpHZ9UlrVBMo1OXYy75l9ug9TQ/xJnk5nk9\ pVziol1ayyGTJia03GMyxTUzwdyldr2mFhJDkPIcQ/F0syAIRMC9aKlbDowJKxa\

JWFQTlSgzYOigLdIrNemf1J+/wZl5ldqxDNRMSy6YqqMF2O8TJEsQxF3pA6Uc6h\ bSG7c/BFwY6RrZmCFSpIOcwmZ42Surgbg4UPV0v7GJyf2FU29con1a6QQmUhm/d\ pj7f1H5s6f1tYOlRH+7tLOahuuLibVrNQcilGDKaU+R97pnrKsx3OMZWJKmMWSo\

17dc9Ha6dygt89Uts5ZSjCu194pfVV0/ba47szJiqN44veF9TVOItbWHagTatv3\

103 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Ym1a41WNFQSY3th5Te4ies6vV3043ki7/3NkLv1ZJKgVSMEREFPx4gjgiYDlDJU\

KQ4DF2SxGLg0is9UkUIyPcmMy/OI2nnrqa9ObLvOonmat8tDEQ9eeeoNRPiInHi\

IW7i811n6rMBczFDnETfn92OrASLpZV0RW8DzZZeDMHMoMtVIYeGQrnXBI4nqOr\

7TXZiInO0mXNZ28J16jVDqZX+JYY9wN/hfAdTHqQ+P4VqcmCvlZxt031R2YzD2x\

OTN3xNmKnrM60bFaU3rgI2+kDcMEpbJ/akVfVnVeYmS+SJYzEsThBqsuu9puSEk\

TZLV/Jk46k7+3UAJIEK8w4mZjzWzMpq9Q8ll6ri2J/8ALEWuH2bBOwAsnUBKJ+W\ xhpeEJURQSLFFC0x0XoLRW6pmZ0yREyXNkX3Ts5t2esd2o3YCPuj5JiiCF2cxfU\

+n1XLKMpTZHHETOeJnrL6gCprXu8wi4vOMzT+6mYl6d+mifcOP+7aOXfqJt1Rkb\ jb+WJuyyJurHXrLVqCQ2nFB5/J7kdqq4VI24tjjiuKU15HPliPMQ834V3jKJ5QQ\

5FLZjE9XuKIkaRIS/wCnIByihHpR+3Wg12ZdWSfu5Ga2p5siY6HVBkzRibXjMlX\ dSm8xJRt3bwapxG03/tm+k6naRsuUqWxNuXx4enHEEyULtQElkKG+jOcDE5Zrg1\

OHxaj+1BYanSfb21ZU+7msfKZs6HWrnTkgCcYxngHga2lfU1+JMyBGyb/au3D4j\ p/U1TB5RJ3TbtolxvBno88xsKljUIjVC/Lo0AyGqGzouCOQXtj1iTvilh2+1zN7\

Nw7EfM9Lv80Sz2sXN4eSaXOJeuD6m9IEMwIZ3xndiLt6X1C0PIwCzuXR5ZlozBz\

/AFCECLmvutc0jojghAiEoHIctcop7CKDUIjP4jjdPY9xYiOju0xluiIhZf2ov3\

6mdWmu0m7tj2L+6LmOKjpdyydumYl+6X8TnfY8nR9TLz+II4S2lfR6YB8NiKjVp\ unaMMhvXNYvzdhr0qS6uQvMzSyJE3O1QQdS96rQ247gnZf1Hx5hzTdWoMHdyfuw\

7tRmiJ5I4pYOKD/IsKeInp5S9sMGfavE2vWTptIf1csIm8bwEmYi4yOmhfiWPa2\

K35j46m16q7ndn7fEy/wrU3O8eesPqQNahC5R/wA0+d9i2KQVcbYb2sbpeCz+ai\ mB1Yq64taagntSvIGMF1+POemetDCEvkxfCGZ/y7dQ95Ew7Cu02JLWSxYZgz0n1\

QmmEhJM73ct3ghypHRhxw0YImpydFL9hSPQ+tpN9NVvn83/ANz1n6ir9zEu8AeN\

5mo6j+qP8LIl0Z2bfaL+HpPqFmEtXEpszWftoonk6kQcIGoBXVbXD4xPq1CELJq\

KmUElaxMYAhNr6z3u5K8wbMZ/EvtLvw1agDsRl2307HLLMZGLrGT1FG5vdJjzM1\ cfL56rlChQZhkCjtdMlGCo5eNg4YuJpq0YWCMCwQ37UipWP1UnGmLkynnm95VnJ\ rZtUf6cu0do0s1zJvHA9RxV8aZMTsQ1Y4/BIepq2InP22RWIJPJj8SQCFWYzWuM\

Kor5gBPMEcOVVImKuj5UcMUOissUOvUMTnglMqvbzUSn+Oh1kBYsWE3EpCZYmyY\

IXrhp16mViWSqxiyZPPiIYHpCk06p8lEQhLW8fEuejKoDub/Q3W8MOHUoh7YWiX\

X6ggGk0xqqGZp4CkmxceTrOnV2rFjzCu9m0Zm58Q9cPqKnmYmY2lXxAjx7z0TBk\

4oFkc7TMTLZJDnqkEgqGSNYkAD+KV33OUVHqJvzcBXGa8fFY6R6nl9oIjjN75yu\

NmFufOWP+8U0sv8AE9dA1BkmSSNm/L7hw9NzTM9NvBHCWi+PqLj1YAg+dX/5xxt\ iFk6f1v8Ayf8A1+/6cf4vHUU6pZdRs0Xds8c8SZ6zq1wx3Mh/KMHjEREO8xBwec\

3AhvS/qNWye+AxpHJ1GrfC8e2FjbiQMFdZXQBHa74zN1TzOaiOo31WR1Elxl/Vt\

IfksRVej6hBLI53Xgm94xzUyTnlsSTVqpXGjmNI4ZACBV0WrL42ClwGYPgI/wCM\

SZ+K33PL+XqM9WGki8i6cq8XFuZvFvR9XA6kpfPssJEHE+WGGQs+r4CXU1yuaKF\ ccKZKJ0dWr2/EVOtntG1mmIpvVEzzia33BdNsLM3JfwEu9/4nqQ1gqaoV+5mIn3\

JgrxMDOw+p3Qd2limdWmNxYqfebH46KpUsz4nR0B6X1gGQhgHerFNF7q7jOJJDV\ qlIoZXIywBlpzWLL66ZJvaN5Gvb7hs8T1x1T3M2S7XJW3xAzvZB0zVrKnbgj8Tn\

M81xaCZBKz65go16L2xA3ScOUOWFn0V8PkoopHVj+0tJjBMRmRiJfMdY1atsxM6\ iLiYPN5Ejz1z7ptbyz/ofMfjNPWe5Z7TGyP3fMWxGGvPQ5yAwpg9UxP4uihYYyp\ cDVFboWOD1xjqs/md/nff+/iulLsxc1zv8ss+/WGYlnONLz+6+J9q6HVFBLsabq\

MuKmPz7TVzTkuClsbI5KBaEeVhRw1/aOqfSxx+vMwMCUv8AUXHCU5KczJ9Weat8\ k4LrPyeb6OjpiAa+5jUJQwTD/T7MDrSWAuKzMLnhEHfeZyHrULLccRFO95bc7h0\ dHVQAKKtUqReUWOBMJC+qMzpV2vHjOOP+Og9UQY3HbEfmfnzM9HR0BJK1bfum/p\ nmepWJ37nL6j//2Q==\

" />

<param name="backgroundColor" value="" /> <!-- background color (white by default)

-->

<param name="textColor" value="" /> <!-- text color (black by default) -->

<param name="direction" value="RightToLeft" /> <!-- direction (RightToLeft by default, possible values: LeftToRight, RightToLeft, TopToBottom,BottomToTop) -->

<param name="speed" value="7" /> <!-- speed [1..12] (8 by default) -->

</object>

</div>

<br/>

<a href=’#’ onclick="javascript:start()">Start</a>

<a href=’#’ onclick="javascript:stop()">Stop</a>

<a href=’#’ onclick="javascript:stext()">Change text</a>

Copyright © 31 July 2017 Moderro Technologies, Inc. 104

Moderro Interactive Experience Platform

<a href=’#’ onclick="javascript:direction()">Change direction</a>

<a href=’#’ onclick="javascript:bold()">Bold</a>

<a href=’#’ onclick="javascript: italic ()">Italic</a>

</center>

</body>

</html>

VideoPlayer Widget

The VideoPlayer plugin allows you to play video in your application. It supports the majority of modern video and audio formats and codecs. It also allows you to use various transport protocols for your video

(such as HTTP, RTSP, MMS, etc.).

This plugin also provides a minimal user interface to control video playback and volume. That user interface can be turned off, however.

The following declares the VideoPlayer JavaScript API: interface VideoPlayer

{ attribute bool safeMode; attribute string url; attribute bool autoPlay; attribute bool loop; attribute int volume; attribute bool isMuted; attribute double speed; attribute double position; readonly attribute long long length; // Current media length in milliseconds. attribute long long time; // Current media time in milliseconds. readonly attribute bool isPlaying; readonly attribute bool isTrickPlaying; readonly attribute bool isPaused; readonly attribute bool isSeekable; attribute bool isFullScreen; readonly attribute int subtitlesCount; // Number of subtitle tracks. readonly attribute map<string, string> subtitlesMap; attribute int subtitle ; // Current subtitle track. Tracks numbers start from 1. readonly attribute string errorString; readonly attribute int audioTracksCount; readonly attribute map<string, string> audioTracksMap; attribute int audioTrack; parameters: bool safeMode; bool autoPlay; bool loop; int volume; bool muted; int fileCaching ;

105 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

int networkCaching; bool hwAcceleration; string deinterlacing

; int fontSize ; string url ; slots: int play(in string url); int pause(); int resume(); int stop(); void setSubtitle (in int subtitle ) ; void fastForward (in double rate=10.0, in int frameDisplayTime =

500); void rewind (in double rate=10.0, in int frameDisplayTime =

500); signals: void opening(); void buffering(); void started(); void paused(); void resumed(); void stopped(); void endReached(); void error(); void volumeChanged(in int volume); void muted(in bool muted); void seekableChanged(in bool seekable); void fullScreenMode(in bool enabled);

};

Variable

length time subtitlesCount subtitlesMap

Table 3-8

Copyright © 31 July 2017 Moderro Technologies, Inc.

Video Player Variables

Description

Current media length in milliseconds.

Current media time in milliseconds.

Number of subtitle tracks.

An associative array with subtitle's Id as a key, and subtitle's description as a value.

Caution

Remember that the Id is passed as a string. Use parseInt() to convert it to an integer. The array is not sorted by key.

106

subtitle audioTracksCount audioTracksMap audioTrack isTrickPlaying safeMode autoPlay loop volume muted fileCaching networkCaching hwAcceleration deinterlacing fontSize url fastForward

Moderro Interactive Experience Platform

Current subtitle track.

Number of audio tracks.

An associative array with an audio track's Id as a key, and an audio track's description as its value.

Caution

Remember that the Id is passed as a string. Use parseInt() to convert it to an integer. The array is not sorted by key.

Current audio track.

This method is set to True if fast forward or rewind is in progress.

If true, the videoplayer object will recreate internal video object every time it starts playing.

Starts playing automatically.

This is used to loop video playing.

Specify the volume level, from 0 to 100.

Starts in muted state.

File caching in milliseconds.

Network caching in milliseconds.

Specify whether you want to use hardware acceleration.

Deinterlacing mode. If this method is set to auto, video player will try to deinterlace the interlaced video.

If it is turned on, deinterlacing is enforced.

If it is turned off, deinterlacing is off.

Font size for subtitles.

URL to play.

Starts fast forward playback. Rate defines the forwarding speed. For example, if rate == 10:0, it will forward ten times faster than the regular playback.

Rate must be greater than 1.

During fast forwarding, the player displays separate frames instead of contiguous video. frameDisplayTime defines the milliseconds each frame will be displayed.

frameDisplayTime must be greater or equal to 100; otherwise, 100 milliseconds will be used as its value.

Copyright © 31 July 2017 Moderro Technologies, Inc. 107

Moderro Interactive Experience Platform

rewind

Starts rewind playback. Rate defines the rewind speed. For example, if rate == 10:0, it will rewind ten times faster than the regular playback.

Rate must be greater than 1.

During rewind, the player displays separate frames instead of contiguous video. frameDisplayTime defines the milliseconds each frame will be displayed.

frameDisplayTime must be greater or equal to 100; otherwise, 100 milliseconds will be used as its value.

Note

isFullScreen must be used before video playback is started; otherwise, it will only take effect after playback stop and restart.

Note

You cannot use file:// URL in <param> tag of VideoPlayer object. Instead, you must set its url attribute at run time.

Note

When fast forward or rewind is in progress, and player hits the movie end or beginning, the endReached signal is executed.

The following HTML document contains an example of VideoPlayer usage

(file.../../test/plugins/videoplayer.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: videoplayer widget example::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 32px; background-color:

#EEEEEE; font-weight: bold; font-family:

Arial; fontsize: 20px; color: #333333;

}

</style>

Copyright © 31 July 2017 Moderro Technologies, Inc. 108

Moderro Interactive Experience Platform

<script type="text/javascript"> var player ; var subtitlesCount; var currentSubtitle

; var selectSubtitle ; var checkBoxFullScreen; var checkBoxLoop; var isVisible = true; var duration, position ; var endReached, endReachedCount = 0; function update()

{ if (player . isPlaying

|| player . isTrickPlaying)

{ duration.innerHTML = Math.round(player.length / 1000.0) + " seconds"; position .innerHTML = Math.round(player.time / 1000.0) + " seconds";

// reset substitles . TODO: subtitles in the streamed media may appear after a small delay.

// In this case we need to check for them all the time. In the case of a local file we probably

// don't need that logic and can call updateTrackInfo() only once when the video has started updateTrackInfo();

} window.setTimeout(update, 1000);

} function updateTrackInfo()

{ var c = player. subtitle ; currentSubtitle .innerHTML = c >= 0 ? c : "-

"; var n = player.subtitlesCount; if (n == selectSubtitle.options.length) return; subtitlesCount.innerHTML = n;

// remove all elements for (var i = selectSubtitle

.options.length

1; i >= 0; i--)

{ selectSubtitle .remove(i);

} var map = [];

// id => description mapping var apiMap = player.subtitlesMap;

// the mapping is not sorted, let ' s sort it by id for (var i in apiMap)

{ map.push({id: parseInt(i) , description : apiMap[i]});

} map.sort(function(a, b) { return a.id

• b.id; } ) ;

109 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

// append new elements for (var i in map)

{ var opt = document.createElement("option"); opt.value = map[i].id; opt.innerHTML = "" + map[i].id + ": " + map[i].description;

} function incEndReached()

{ selectSubtitle .appendChild(opt);

} endReached.innerHTML = ++endReachedCount;

} function main()

{ subtitlesCount = document.getElementById("subtitlesCount"); currentSubtitle = document.getElementById("currentSubtitle"); selectSubtitle = document.getElementById("selectSubtitle"); checkBoxFullScreen = document.getElementById("checkBoxFullScreen"); checkBoxLoop = document.getElementById("checkBoxLoop"); checkBoxVisible = document.getElementById("checkBoxVisible"); checkBoxFullScreen.checked = player.isFullScreen; checkBoxLoop.checked = player.loop; duration = document.getElementById("duration"); position

= document.getElementById("position"); update(); window.setTimeout(update, 1000);

} function error(message)

{ alert ("Video player error : " + message);

} function init ()

{ player = document.getElementById("player"); if

(player . status == 0) // 0 means ready. main(); else

{ player .ready.connect(main); player . error .connect(error)

;

}

} function setSubtitle ()

{ player . started .connect(updateTrackInfo); player .endReached.connect(incEndReached); player . subtitle = selectSubtitle .value;

} function setFullScreen ()

{

Copyright © 31 July 2017 Moderro Technologies, Inc. 110

Moderro Interactive Experience Platform

player . isFullScreen = checkBoxFullScreen.checked;

} function setLoop()

{ player .loop = checkBoxLoop.checked;

} function setVisible ()

{ isVisible = ! isVisible ; player . style . display = isVisible ? "block" : "none"; function setSpeed(speed)

{ player .speed = speed;

}

}

</script>

</head>

<body onload="init()">

<table width="80%" cellspacing="8" cellpadding="0" border="0" align="center" >

<tr>

<td width="50%" align="center">

<object id="player" type="application/x-qt-plugin" classid="videoplayer" width="720" height="480" >

<!-- <param name="url" value="http://html5videoformatconverter.com/data/images/happyfit2.ogv"/>

-->

<!-- <param name="url" value="mms://media.sonoma.edu/pinball.wmv"/>

-->

<!-- <param name="url" value="file:///var/www/v/p.mp4"/>-->

<param name="url" value="http://192.168.0.110/video/im_glad_cc.mov"/>

<param name="volume" value="50"/> <!-- 75 by default -->

<param name="autoPlay" value="true"/>

</object>

<br />

<button onclick="player.play()">Play</button>

<button onclick="player.stop()">Stop</button>

<button onclick="player.pause()">Pause</button>

<button onclick="player.fastForward()">Fast forward</button>

<button onclick="player.rewind()">Rewind</button>

</td>

<td width="50%">

<table width="100%" align="center" cellspacing="8" cellpadding="0" border="0"

>

<tr>

<td align="right">

Player is visible

</td>

<td>

<input id="checkBoxVisible" type="checkbox" checked="1" onchange="setVisible()" />

</td>

</tr>

<tr>

<td align="right">

Subtitles available

:

111 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

</td>

<td>

<span id="subtitlesCount">0</span>

</td>

</tr>

<tr>

<td align="right">

Current subtitle

:

</td>

<td>

<span id="currentSubtitle"></span>

</td>

</tr>

<tr>

<td align="right">

Change subtitle:

</td>

<td>

<select id="selectSubtitle"></select>

<input type="button" value="Apply" onclick="setSubtitle()" />

</td>

</tr>

<tr>

<td align="right">

Full screen mode

</td>

<td>

<input id="checkBoxFullScreen" type="checkbox" onchange="setFullScreen()" />

</td>

</tr>

<tr>

<td align="right"

> Loop

</td>

<td>

<input id="checkBoxLoop" type="checkbox" onchange="setLoop()" />

</td>

</tr>

<tr>

<td align="right"

> Duration:

</td>

<td>

<span id="duration"></span>

</td>

</tr>

<tr>

<td align="right">

Current position:

</td>

Copyright © 31 July 2017 Moderro Technologies, Inc. 112

Moderro Interactive Experience Platform

<td>

<span id="position"></span>

</td>

</tr>

<tr>

<td align="right">

Speed:

</td>

<td>

<a href='#' onclick="setSpeed(1)">1x</a>

<a href='#' onclick="setSpeed(2)">2x</a>

<a href='#' onclick="setSpeed(3)">3x</a>

</td>

</tr>

<tr>

<td align="right"> endReached signal

?red:

</td>

<td>

<span id="endReached"></span>

</td>

</tr>

</table>

</td>

</tr>

</table>

</body>

</html>

Copy the above text to an html file and transfer the file to a web server from where it can be accessed.

Ensure to have the location of the file as a URL.

There are two ways to test the video player widget:

1.

Using the policy:

1.

2.

Create a policy with startup URL as the URL of the video player html and apply the policy

Reboot the IEC

2.

As a result, the IEC boots up with the policy loaded.

Using the Kiosk menu:

1.

From IEC, press Ctl + Alt + S and then choose Kiosk

2.

3.

Enter the video player widget URL

Reboot the IEC

As a result, the IEC boots up with the video player URL loaded.

VncViewer Widget

The VncViewer provides a VNC viewer in the form of a browser widget.

113 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

interface VncViewer

{ readonly attribute int port; readonly attribute bool isConnected; attribute bool readOnly; attribute bool scalingEnabled; bool connect(in string host, in int port,in string password = ""); parameters: string host; int port; bool autostart ; bool scale ; bool readonly; string password; slots : void disconnect()

; signals : void connected(); void disconnected(); void error(in string message);

};

Variable

port isConnected host autostart

Scale readonly

Table 3-9 VncViewer Variables

readOnly connect(in string host, in int port, in string password)

Description

Specifies port number to which the viewer is connecting. Default value is 5900.

Specifies if the viewer accepts any user input.

Use this method to connect to a VNC server running at the host and listening port.

Note

This method accepts a port and not a display number.

Returns ‘true’ if the viewer is connected to a VNC server.

The host to which the viewer is connecting.

Use this method to start the connection immediately.

Specify the scaling factor.

Use this method if the controls are disabled.

Copyright © 31 July 2017 Moderro Technologies, Inc. 114

Moderro Interactive Experience Platform

password disconnect() connected() disconnected() error(in string message)

Specify the password if the connection is protected.

Closes the connection to a VNC server.

This method can be executed when a connection to a VNC server is established. This signal executes for both active and listening mode.

This method can be executed when the connection to a VNC server breaks.

This method can be executed when an error occurs.

The following HTML document contains an example of VncViewer usage

(file.../../test/plugins/vncviewer.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: vncviewer plugin test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family: Arial; font-size: 20px; color: #eeeeee;

}

</style>

<script type="text/javascript"> var v; var connectedId; function init()

{ v = document.getElementById("vncviewer"); connectedId = document.getElementById("connected"); v.connected.connect(connected); v.disconnected.connect(disconnected);

} disconnected();

Copyright © 31 July 2017 Moderro Technologies, Inc. 115

Moderro Interactive Experience Platform

function connected()

{ connectedId.innerHTML = "Connected";

} function disconnected()

{ onnectedId.innerHTML = "Disconnected";

} function disconnect()

{ try

{ v.disconnect();

} catch(ex)

{ alert("Exception: " + ex);

}

} function connect()

{ try

{ v.connect("vnc://192.168.0.105");

// or

// v.connect("vnc://192.168.0.105", 5900);

// or

// v.connect("vnc://192.168.0.105", 5900, "my-password");

// or

/ v.connect("vnc://192.168.0.105", -1, "my-password");

} catch(ex)

{ alert("Exception: " + ex);

}

} function setReadOnly(ro)

{

Try

{ v. setReadOnly(ro);

} catch(ex)

{ alert("Exception: " + ex);

}

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 116

Moderro Interactive Experience Platform

function isReadOnly()

{ alert(v.readOnly);

}

</script>

</head>

<body onload="init()">

<center>

<br/>

<div>

<object id="vncviewer" type="application/x-qt-plugin" classid="vncviewer" width="640px" height="480px">

<!-- host to connect to -->

<param name="host" value="vnc://192.168.0.105" />

<!-- port to connect to. "5900" by default -->

<param name="port" value="5900" />

<!-- password to access the host (optional). Don't use this field if a server doesn't have a password -->

<!-- <param name="password" value="123" /> -->

<!-- fit to window? "true" by default -->

<param name="scale" value="true" />

<!-- ignore user input? "true" by default -->

<param name="readonly" value="false" />

<!-- start connection right now? If "false", no connection is established and all other parameters are ignored. If "true", start a VNC connection right now.

"true" by default -->

<param name="autostart" value="true" />

</object>

</div>

<br/>

<a href='#' onclick="javascript:isReadOnly()">Is read-only?</a>

<a href='#' onclick="javascript:disconnect()">Disconnect</a>

<a href='#' onclick="javascript:connect()">Connect</a>

<div id="connected" style="text-align: center;">

</div>

</center>

</body>

</html>

WebBrowser Widget

The WebBrowser plugin is an alternative of the iframe HTML element. In contrast to iframe, it allows to completely control the web document loaded within it and does not obey the same origin policy.

The WebBrowser interface declaration is the following: interface WebBrowser

{

117 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

attribute string url; attribute bool navigationPanelVisible; attribute bool titlePanelVisible; attribute double zoomfactor; parameters: string url ; bool navigationPanelVisible; bool titlePanelVisible ; double zoomFactor; slots: variant evaluateJavaScript(in string scriptSource); signals: void loadStarted(); void loadFinished(in bool ok); void loadProgress(in int percent); void urlChanged(in string url); void linkClicked(in string url); void titleChanged(in string title);

};

Table 3-10

Variable

url navigationPanelVisible titlePanelVisible zoomFactor

Variables

Description

URL to display.

Use this method to make the navigation panel visible.

Use this method to display the title.

Specify the zoom factor. It is set to 1.0, be default.

The following HTML document contains an example of WebBrowser usage

(file../../test/plugins/webbrowser.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: webbrowser plugin test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style>

Copyright © 31 July 2017 Moderro Technologies, Inc. 118

Moderro Interactive Experience Platform

body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; fontsize: 20px; color: #eeeeee;

}

</style>

<script type="text/javascript"> var addressBar; var webBrowser; function init()

{ addressBar = document.getElementById("addressBar"); webBrowser

= document.getElementById("webBrowser"); addressBar.value = webBrowser.url;

}

} function go()

{ webBrowser.url = addressBar.value;

</script>

</head>

<body onload="init()">

<input id="addressBar" type="text" />

<button onclick="go()">Go</button>

<br />

<br />

<font color="#FFFFFF">WebKi t

• based browser</font>

<div style="text-align: center ;">

<object id="webBrowser" type="application/x-qt-plugin" classid="webbrowser" width="800" height="600">

<param name="url" value="http://google.com"/>

<param name="navigationPanelVisible" value="false"/>

<param name="titlePanelVisible" value="false"/>

</html>

<param name="zoomFactor" value="2.0"/>

</object>

</div>

</body>

119 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

WebClip Widget

The WebClip plugin is inspired by Mac OS X dashboard plugin with the same name. This plugin allows you to include other web site elements in your web application. You need the web site URL and the CSS selector that addresses the element that you want to include. interface WebClip

{ readonly attribute string url; readonly attribute string selector; attribute int reloadInterval; // In seconds.

}; void load();

The following HTML document contains an example of WebClip usage

(file.../../test/plugins/webclip.html). This page contains two webclips. They take elements from Yahoo!

Finance and Yahoo! Weather web sites.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: webclip widget example ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 32px; background-color:

#EEEEEE; font-weight: bold; font-family:

Arial; fontsize: 20px; color : #333333;

}

</style>

<script type="text/javascript"> var stockClip; var weatherClip; function init

()

{ stockClip = document.getElementById("stockClip"); weatherClip = document.getElementById("weatherClip");

}

</script>

</head>

<body onload="init()">

<table border="0" cellpadding="20" cellspacing="20" align="center" width="90%">

Copyright © 31 July 2017 Moderro Technologies, Inc. 120

Moderro Interactive Experience Platform

<tr>

<td align="center">

<object id="stockClip" type="application/x-qt-plugin" classid="webclip" width="320" height="240">

<param name="url" value="http://finance.yahoo.com/q?s=CSCO&ql=1"/>

<param name="selector" value=".chart"/>

<param name="reloadInterval" value="600"/>

<param name="timeout" value="5"/>

<param name="progressIndicatorVisible" value="false"/>

</object>

<br />

<input type="button" value="Reload" onclick="stockClip.reload();" />

</td>

</tr>

<tr>

<td align="center">

<object id="weatherClip" type="application/x-qt-plugin" classid="webclip" width="950" height="280">

<param name="url" value="http://www.cisco.com"/>

<param name="selector" value="#spotlight-container"/>

<param name="reloadInterval" value="300"/>

</object>

<br />

<input type="button" value="Reload" onclick="weatherClip.reload();" />

</td>

</tr>

</table>

</body>

</html>

WebRTC Widget

WebRTC (Web Realtime Communications) enables peer to peer video, audio, and data communication in

Cobra. This allows video calling, video chat, and peer to peer file sharing entirely in Cobra browser, with no plugins. Additionally, it can be used for screen sharing, presentation sharing, and so on. It can work with any WebRTC service provider such as Google AppSpot, opentokrtc.com, easyrtc.com, and so on.

The interface declaration is the following: interface rtcclient

{ attribute string url

; methods: int startClient (in string url) ; void runJavaScript(in string scriptSource) ; variant evaluateJavaScript(in string scriptSource)

; int stopClient() ; parameters: string url ; signals : void loadStarted(); void loadFinished(in bool ok); void loadProgress(in int

121 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

percent); void urlChanged(in url url) ; void titleChanged(in string title )

; void error(in string errorMsg);

};

Table 3-11 Variables

Variable

startClient runJavaScript evaluateJavaScript stopClient url

Description

Use this method to initialize the widget with the desired URL.

Executes the specified javascript code

ScriptSource in the RTC client. The javascript code is executed asynchronously.

Executes the specified javascript code

ScriptSource in the RTC client. The javascript code is executed synchronously and the result is returned.

Use this method to deinitialize the widget.

URL pointing to the HTML document.

The following HTML document contains an example of RTC client usage.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: webrtc plugin test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 0; background-color:

#000000; font-weight: bold; font-family:

Arial; fontsize: 20px; color : #eeeeee;

}

</style>

<script type="text/javascript" src="rtcclient . js"></script>

<script type="text/javascript"> var

Copyright © 31 July 2017 Moderro Technologies, Inc. 122

Moderro Interactive Experience Platform

addressBar; var rtcclient ; function init ()

{ addressBar = document.getElementById("addressBar"); rtcclient

= document.getElementById("rtcclient"); addressBar.value = rtcclient . url ; setTimeout(start, 3000); // Call start after 3 seconds

} function deinit ()

{ rtcclient .stopClient() ;

} function start ()

{ rtcclient . startClient (addressBar.value);

}

</script>

</head>

<body onload="init()" onbeforeunload="deinit()">

<input id="addressBar" type="text" align="center"/>

<button onclick="start()" align="center">Start</button>

<br />

<br />

<font color="#FFFFFF"><center>..:: webrtc plugin test ::..</center></font>

<div style="text-align:center ;width:1280px;height:720px;margin:0 auto;">

<object id="rtcclient" type="application/x-qt-plugin" classid="rtcclient" style="width:100%;height:100%">

<param name="url" value="https://apprtc.appspot.com/"/>

</object>

</div>

</body>

</html>

Copyright © 31 July 2017 Moderro Technologies, Inc. 123

Moderro Interactive Experience Platform

JavaScript Global Objects

Chapter Overview

In addition to standard JavaScript global objects (such as window or document) COBRA provides several non-standard global objects to allow web applications to be better integrated with the IEC.

Those objects implement functionality which is not available in a regular browser's JavaScript.

The topics in this chapter include:

“global.applicationData Object”

“global.bus Object”

“global.database Object”

“global.device Object”

“global.display Object”

“global.ir Object”

“global.keyboard Object”

“global.magstripe Object”

“global.mediaCache Object”

“global.network Object”

“global.networkCache Object”

“global.printer Object”

“global.registry Object”

“global.resources Object”

“global.scanner Object”

“global.serialPorts Object”

“global.system Object”

“global.videoEncoder Object”

“global.vncServer Object”

“global.window Object”

Copyright © 31 July 2017 Moderro Technologies, Inc. 124

Moderro Interactive Experience Platform

global.applicationData Object

The global.applicationData object allows the web application to store its persistent data on the management server. This object is a convenience API to access application.data property. Once you change the data, it will automatically be saved to the management server.

This object does not allow you to control the application in real time. For example, if you construct some policy containing application.data property on the management server and apply that policy as an action to the device running your application, the application will not know about that until the next reboot. Moreover, if the application changes the data after that policy has been applied, the changes you are trying to make with that policy will be lost. This approach tries to prevent inconsistent behavior of the application. interface ApplicationData

{ readonly attribute bool isReadOnly; readonly attribute int size; readonly attribute bool isEmpty; readonly attribute List<String> keys; readonly attribute List<String> values; bool contains(in String key) const; String value(in String key) const;

String value(in String key, in String defaultValue) const; void insert(in String key, in String value); bool remove(in String key);

String take(in String key); // Returns value and removes it from the data. slots: void clear();

};

Sometimes the value of application.data property can be defined with a policy. That means it cannot be changed on the management server from the device side. In that case isReadOnly attribute returns true. The application still can change its data using insert(), remove(), take() or clear() methods. However, the data will not be saved on the management server.

global.bus Object

The global.bus is an unidirectional bus to communicate with other Cobra instances. This object implements a Bus interface: interface Bus

{ void send(in object obj) const; bool haveOtherInstances() const; signals : void received(in object obj)

};

125 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

Table 4-1 global.bus variables

Variable

send() haveOtherInstances() received()

Description

Sends the given object to other Cobra instances. The object itself can represent simple types (e.g. integers, strings, etc.) as well as complex types like associative arrays.

Returns true if there are other Cobra instances that can receive events.

Fires when an event has arrived from another Cobra instance.

The following HTML is an example of global.bus usage for sending events (file.../../test/js/bus-send.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .bus test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 20px; background-color:

#111111; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 18px; color: #eeeeee;

}

</style>

<script type="text/javascript"> var instancesId ; var textId; function init

()

{ instancesId = document.getElementById("instances"); textId = document.getElementById("text");

} function enumerate()

{ try

{ var have = global.bus.haveOtherInstances(); if

(!have) instancesId .innerHTML = "<font color='#?0000'>NOT

Copyright © 31 July 2017 Moderro Technologies, Inc. 126

Moderro Interactive Experience Platform

DETECTED</font>"; else instancesId .innerHTML = "<font color='#00?00'>DETECTED</font>";

} catch(ex)

{ alert ("Exception: " + ex);

}

} function send()

{ try

{ global .bus.send({id: textId.value});

} catch(ex)

{ alert ("Exception: " + ex);

}

}

</script>

</head>

<body onload="init()">

<input type="button" value="Detect other instances" onclick="enumerate()" /><span id="instances"></span><br>

<input id="text" type="text" /><input type="button" value="Send as { id: <value>

}" onclick="send()" />

</body>

</html>

The following HTML is an example of global.bus usage for receiving events (file.../../test/js/busreceive.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .bus test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 20px; background-color:

#111111; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 18px; color: #eeeeee;

}

</style>

<script type="text/javascript"> function init ()

{ global .bus.received .connect(recieve) ;

} function deinit ()

{ global .bus.received .disconnect(recieve ) ;

Copyright © 31 July 2017 Moderro Technologies, Inc. 127

Moderro Interactive Experience Platform

} function recieve (value)

{ alert ("Received data: " + value + "\nID: " + value.id);

}

</script>

</head>

<body onload="init()" onunload="deinit()">

Waiting for events with { id : &lt;value&gt;

}

</body >

</html>

global.database Object

The global.database object can open or remove a database and list its files. interface Database

{ object open(in string uuid, int string name, int int version , int string sql ) ; bool remove(in string uuid, in string name); list <string> list(in string uuid);

};

Table 4-2 global.database Variables

Variable

open()

Description

Opens a database with name name and version version. If the database version doesn't match the version passed as an argument then it is recreated using SQL sql. sql must contain a single SQL statement per line. Every SQL statement must be followed one empty line. Returns a database object on success. You also need to check the database status (see below). The database itself is based on

SQLite. Refer to SQLite documentation on how to use its SQL statements. remove() list()

Removes the given database name from the local storage.

Lists the database files available in the local storage.

The open() variable returns an object, which implements the DatabaseObject interface. interface DatabaseObject

{ readonly attribute int status ; readonly attribute list <list<value>> result; void close () ;

Copyright © 31 July 2017 Moderro Technologies, Inc. 128

Moderro Interactive Experience Platform

bool begin(); bool commit(); bool rollback

() ;

} bool exec(in string sql , in map<string, variant> binds = map<string, variant>());

Table 4-3 DatabaseObject Variables

Variable

status result close() begin() commit() rollback() exec()

Description

The database status. 0=unknown, 1=healthy, 2=migrated,

3=recreated, 4=created.

The result of the last call to exec().

Closes the database discarding any uncommitted data.

Starts a new transaction.

Commits the transaction.

Rollbacks the transaction.

Executes a single SQL statement sql and stores its result in result.

The following HTML document contains an example of global.database usage.

<!DOCTYPE HTML PUBLIC "//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .database example ::..</title>

<meta httpequiv="ContentType" content="text/html; charset=utf8">

<styl e> body

{ margin: 32px; backgroundcolor:

#EEEEEE; fontweight: bold; fontfamily:

Arial; fontsize: 20px; color : #333333;

}

</style>

<script type="text/javascript"> var log; var number; var explanation; var db;

// unique application id in any format (UUID v1/v4 is recommended) var UUID = "69c6fb59b4bf4afa9a282bee7eb1ca10"; function init ()

{ log = document.getElementById("log");

Copyright © 31 July 2017 Moderro Technologies, Inc. 129

Moderro Interactive Experience Platform

number = document.getElementById("number"); explanation = document.getElementById("explanation");

/*

SQL string must contain just a single SQL statement per line. Every SQL statement must be followed by one empty line (e.g. by two \n characters).

*/ db = global.database.open(UUID, "numbers", 2,

"\ DROP TABLE IF EXISTS numbers; \n\n\

VACUUM; \n\n\

CREATE TABLE numbers \

(\ number INTEGER, \ explanation VARCHAR(128)

\

)

;

\

"

)

; log .innerHTML += "DB status: " + db.status + "<br><br>Explanation:<br>0 = unknown<br>1 = healthy<br>2

= migrated<br>3 = recreated<br>4 = created<br>"; log . scrollTop = log. scrollHeight ;

} function deinit ()

{ db.close () ;

} function list ()

{ alert (global .database. list (UUID));

} function cleartbl ()

{ log .innerHTML += "CLEAR: "

+ ( db.exec("DELETE FROM numbers")

? "OK" : "FAILED"

)

+ "<br>"; log . scrollTop = log. scrollHeight ;

} function unlink()

{ alert ("Removed: " + (global.database.remove(UUID, "numbers") ? "yes" : "no"));

} function insert ()

{ log .innerHTML += "INSERT ‘"

+ number.value

+ "': "

+ ( db.exec("INSERT INTO numbers VALUES (" + number.value + ", '" + explanation.value

+

Copyright © 31 July 2017 Moderro Technologies, Inc. 130

Moderro Interactive Experience Platform

"

')

")

? "OK" : "FAILED"

)

+ "<br>";

/*

Another way to do exec(): var binds = []; binds[":num"] = number.value; binds[":explanation"] = explanation.value; db.exec("INSERT INTO numbers VALUES (:num, :explanation)", binds);

*/ log . scrollTop = log. scrollHeight ;

} function insertTransaction()

{ if (!db.begin())

{ log .innerHTML += "Cannot start transaction<br>"; log . scrollTop = log. scrollHeight ; return;

} var tobe = 5; var actual =

0; var ret ; for (var i = 0;i < tobe;i++)

{ log .innerHTML += "INSERT ‘"

+ number.value

+ "': "

+ (

(ret = db.exec("INSERT INTO numbers VALUES (" + number.value + ", '" + explanation.value + "')"))

? "OK" : "FAILED"

)

+ "<br>"; actual += ret;

} if (actual != tobe)

{ db.rollback() ; log .innerHTML += "Cannot exec some statements<br>"; log . scrollTop = log. scrollHeight ; return;

} if (!db.commit())

{ log .innerHTML += "Cannot commit transaction<br>"; log . scrollTop = log. scrollHeight ; return;

} log . scrollTop = log. scrollHeight ;

} function select ()

{ db.exec("SELECT * FROM numbers"); log .innerHTML += "SELECT [size:" + db.result.length + "]: " + db.result + "<br>";

131 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

log . scrollTop = log. scrollHeight ;

}

</script>

</head>

<body onload="init()" onunload="deinit()">

<div style="textalign: center ;">

<button onclick="list()">List databases</button>

<input id="number" type="number" value="0" style="width: 60px">

<input id="explanation" type="text" placeholder="explanation" style="width:

100px">

<button onclick="insert()">Insert</button>

<button onclick="insertTransaction()">Insert with a transaction</button>

<button onclick="select()">Select all</button>

<button onclick="cleartbl()">Clear table</button>

<button onclick="unlink()">Remove database 'numbers'</button>

<br>

<span id="log" style="height: 300px; display: block; overflow: auto;"></span>

</div>

</body>

</html>

global.device Object

It is possible to obtain some general device-related information using global.device global object. This object implements device interface. interface Device

{ readonly attribute string name; readonly attribute string description; readonly attribute string product; readonly attribute string family; readonly attribute string model; readonly attribute string version; readonly attribute string versionSystem; readonly attribute string versionApplications; readonly attribute string location; readonly attribute string serialNumber; readonly attribute string licenseKey; readonly attribute bool licenseValid; readonly attribute string buildTimestamp; readonly attribute string buildTimestampSystem; readonly attribute string buildTimestampApplications;

};

Table 4-4 global.device Variables

Variable

name

Description

device name

Copyright © 31 July 2017 Moderro Technologies, Inc. 132

Moderro Interactive Experience Platform

description product family model version versionSystem versionApplications location serialNumber licenseKey licenseValid buildTimestamp buildTimestampSystem buildTimestampApplications device description that can contain any text supplied by administrator product name family name that specifies device hardware in general so you can use model name to make assumptions about device capabilities model name that specifies device hardware (i.e. how much memory it has) device firmware version device system firmware version device applications firmware version device location that contains text supplied by administrator device serial number device license key returns ‘true’ if the license key is valid or ‘false’ if otherwise firmware build time stamp in human-readable form system firmware build time stamp in human-readable form applications firmware build time stamp in human-readable form

The following is the global.device usage in HTML (file../../test/js/device.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.device test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script type="text/javascript"> function init()

{ document.getElementById("name").innerHTML = global.device.name; document.getElementById("description").innerHTML = global.device.description; document.getElementById("product").innerHTML = global.device.product; document.getElementById("model").innerHTML = global.device.model;

133 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

document.getElementById("version").innerHTML = global.device.version; document.getElementById("versionSystem").innerHTML = global.device.versionSystem; document.getElementById("versionApplications").innerHTML = global.device.versionApplications; document.getElementById("location").innerHTML = global.device.location; document.getElementById("serialNumber").innerHTML = global.device.serialNumber; document.getElementById("buildTimestamp").innerHTML = global.device.buildTimestamp; document.getElementById("buildTimestampSystem").innerHTML = global.device.buildTimestampSystem; document.getElementById("buildTimestampApplications").innerHTML = global.device.buildTimestampApplications;

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="50%">

<tr>

<td>Device name</td>

<td id="name"></td>

</tr>

<tr>

<td>Device description</td>

<td id="description"></td>

</tr>

<tr>

<td>Product</td>

<td id="product"></td>

</tr>

<tr>

<td>Model</td>

<td id="model"></td>

</tr>

<tr>

<td>Version</td>

<td id="version"></td>

</tr>

<tr>

<td>Version of system</td>

<td id="versionSystem"></td>

</tr>

<tr>

<td>Version of applications</td>

<td id="versionApplications"></td>

</tr>

<tr>

<td>Device location</td>

<td id="location"></td>

</tr>

<tr>

<td>Device serial number</td>

<td id="serialNumber"></td>

</tr>

<tr>

<td>Firmware build timestamp</td>

<td id="buildTimestamp"></td>

</tr>

<tr>

Copyright © 31 July 2017 Moderro Technologies, Inc. 134

Moderro Interactive Experience Platform

<td>System firmware build timestamp</td>

<td id="buildTimestampSystem"></td>

</tr>

<tr>

<td>Applications firmware build timestamp</td>

<td id="buildTimestampApplications"></td>

</tr>

</table>

</body>

</html>

global.display Object

This object implements the display interface. interface System

{ readonly attribute bool isBrightnessEnabled; attribute int brightness; readonly attribute bool isContrastEnabled; attribute int contrast;

}; attribute int rotationAngle;

Note

This object controls brightness and contrast using DDC (Display Data Channel). Not all displays support that so for some displays, brightness and contrast adjustment will not work.

Note

This object in its implementation changes values of display.* properties. So, if some policy containing display.* properties is applied to the device, this object will not work.

Cali

If you have multiple displays connected to the device, the rotationAngle attribute will rotate all the screens. As to brightness and contrast, in the current version only the first found display will be affected.

Table 4-5

Variable

isBrightnessEnabled isContrastEnabled

global.display Variables

Description

Returns value of display.brightness.enabled property (which is false by default). If it is false, display brightness cannot be adjusted.

Returns value of display.contrast.enabled property (which is false by default). If it is false, display contrast cannot be adjusted.

Copyright © 31 July 2017 Moderro Technologies, Inc. 135

Moderro Interactive Experience Platform

rotationAngle

Gets and sets screen rotation angle. Only the following values are valid: 0, 90, 180 and 270. If you use an invalid value, this method does nothing.

The following HTML contains an example of global.display usage:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.display test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script type="text/javascript"> var brightness; var contrast; var rotationAngle; function init()

{ brightness = document.getElementById("brightness"); contrast = document.getElementById("contrast"); rotationAngle = document.getElementById("rotationAngle"); document.getElementById("minBrightness").innerHTML = global.display.minBrightness; document.getElementById("maxBrightness").innerHTML = global.display.maxBrightness; document.getElementById("isBrightnessEnabled").innerHTML = global.display.isBrightnessEnabled ?"Yes" : "No"; brightness.value = global.display.brightness; document.getElementById("minContrast").innerHTML = global.display.minContrast; document.getElementById("maxContrast").innerHTML = global.display.maxContrast; document.getElementById("isContrastEnabled").innerHTML = global.display.isContrastEnabled ? "Yes" : "No"; contrast.value = global.display.contrast; rotationAngle.value = global.display.rotationAngle;

} function getBrightness()

{ brightness.value = global.display.brightness;

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 136

Moderro Interactive Experience Platform

function setBrightness()

{ global.display.brightness = brightness.value;

} function getContrast()

{ contrast.value = global.display.contrast;

} function setContrast()

{ global.display.contrast = contrast.value;

} function getRotationAngle()

{ rotationAngle.value = global.display.rotationAngle;

} function setRotationAngle()

{ global.display.rotationAngle = rotationAngle.value;

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="50%">

<tr>

<td>Minimum brightness</td>

<td id="minBrightness"></td>

</tr>

<tr>

<td>Maximum brightness</td>

<td id="maxBrightness"></td>

</tr>

<tr>

<td>Brightness adjustment enabled</td>

<td id="isBrightnessEnabled"></td>

</tr>

<tr>

<td>Current brightness</td>

<td>

<input id="brightness" type="text" size="3" maxlength="3" />

<input type="button" value="Get" onclick="getBrightness()" />

<input type="button" value="Set" onclick="setBrightness()" />

</td>

</tr>

<tr>

<td>Minimum contrast</td>

<td id="minContrast"></td>

</tr>

<tr>

<td>Maximum contrast</td>

<td id="maxContrast"></td>

137 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

</tr>

<tr>

<td>Contrast adjustment enabled</td>

<td id="isContrastEnabled"></td>

</tr>

<tr>

<td>Current contrast</td>

<td>

<input id="contrast" type="text" size="3" maxlength="3" />

<input type="button" value="Get" onclick="getContrast()" />

<input type="button" value="Set" onclick="setContrast()" />

</td>

</tr>

<tr>

<td>Display rotation angle (can be 0, 90, 180 or 270)</td>

<td>

<input id="rotationAngle" type="text" size="3" maxlength="3" />

<input type="button" value="Get" onclick="getRotationAngle()" />

<input type="button" value="Set" onclick="setRotationAngle()" />

</td>

</tr>

</table>

</body>

</html>

global.ir Object

An Infrared (IR) Cisco Remote Control can be connected to the Moderro Interactive Experience Client

4600 (IEC 4600) Series device so that the end user can control applications and remote playback without touching the screen or using a mouse. Refer to the Moderro Interactive Experience Client 4600 Series

User Guide for a list of supported remote controls.

The IR port is active by default. No additional configuration is required. The global.ir object implements the IR interface. It allows an application to receive signals from the infrared remote control.

Embed the global.ir object into your application code so that your applications will perform the expected action when the end user presses a button on the remote control.

The global.ir object code interface is the following: interface Ir

{ readonly attribute string lastError;

List <String> availableControls() const; bool setCurrentControl(in string device); signals: event(in uint key, in string skey, in string configName) const; error(in string err) const;

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 138

Moderro Interactive Experience Platform

Table 4-6 global.ir Object Variables

Variable

lastError availableControls() setCurrentControl(in string device) event(in uint key, in string skey, in string configName) error(in string err)

Description

Last error that occurred

Returns the list of the supported remote controls

Sets the current remote control to use. The device name must be obtained from the availableControls() list. Leave the device name empty to use browser.ir.configuration

.

In this case, you should set browser.ir.configuration to the valid LIRC configuration.

Remote control event where the event control code is set to ‘key’, the control name (such as

‘poweroff’, ‘ch1’, ‘up’, etc.) is set to ‘skey’, and the configuration name, which is rarely needed, is set to ‘configName’.

An error has occurred. Use the method lastError() or argument ‘err’ to get the error string.

The following HTML code contains an example of global.ir usage (file../../test/js/ir.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.ir test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 20px; background-color:

#111111; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 18px; color: #eeeeee;

}

</style>

<script

139 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

type="text/javascript"> var errorId; var eventId; var controlId; var timer; var remoteInfo; function init()

{ errorId = document.getElementById("error"); eventId = document.getElementById("event"); controlId = document.getElementById("control"); remoteInfo = document.getElementById("remoteInfo"); global.ir.error.connect(onError); writeLog("onError() connected to signal global.ir.error"); global.ir.event.connect(onEvent); writeLog("onEvent() connected to signal global.ir.event"); try{ var irconf = global.registry.value("browser.ir.configuration"); if(irconf=='<binary mimeType="text/plain"><![CDATA[]]></binary>' || irconf==''){

// set default remote as current.

//global.ir.setCurrentControl(defaultRemote); remoteInfo.innerHTML = "Default (Cisco remote control)"; writeLog("Default remote control configuration applied.");

}

} catch(ex){ writeLog("Exception: "+ex);

}

} else{ global.ir.setCurrentControl(); remoteInfo.innerHTML = "* user defined remote control *"; writeLog("User defined remote control configuration applied.");

} function deinit()

{ global.ir.error.disconnect(onError); global.ir.event.disconnect(onEvent);

} function onError(err)

{ errorId.innerHTML = err; writeLog("onError():

"+err);

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 140

Moderro Interactive Experience Platform

function onEvent(key, skey, config)

{ eventId.innerHTML = "" + key + ' ' + skey + ' ' + config; writeLog("onEvent(): "+key + " " + skey + " " + config);

} clearTimeout(timer); timer = setTimeout(function() { eventId.innerHTML = ""; }, 750);

</script>

</head>

<body onload="init()" onunload="deinit()">

Remote: <span id="remoteInfo"></span><br><br> Event:

<span id="event"></span><br><br>

Error log: <span id="error"></span>

<!-- This part of code is used for tracing application states -->

<div id="appDebugInfo" style="background:rgba(0,0,0,.9); position:absolute; top:0px; right:0; width:15%; min-width:300px; bottom:0; overflow-x:hidden; border:solid 1px

#666666; overflow-y:scroll; color:white; padding:20px; font:normal

10px/12px sans-serif"></div>

<script> function writeLog(msg){ var c = document.getElementById('appDebugInfo'); if(c){ c.innerHTML=c.innerHTML + msg + "<br><br>";

}

}

</script>

</body>

</html>

global.keyboard Object

This object allows you to control a screen’s keyboard. This keyboard can interfere with the popup screen keyboard. If you want to control screen keyboard in your JavaScript application, it is strongly recommended to turn the popup screen keyboard off by changing the setting browser.input.popup.keyboard.enabled property to false. You can use only one screen keyboard in your application. interface Keyboard

{ readonly attribute bool isVisible; void show(in int globalX, in int globalY); void hide(); void move(in int globalX, in int globalY);

141 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

}

Note

The globalX and globalY coordinates are relative to the DOM window.

The following is an example of global.keyboard usage in HTML (file ../../test/js/keyboard.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose. dtd">

<html>

<head>

<title>..:: global.keyboard example ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 32px; background-color:

#EEEEEE; font-weight: bold; font-family:

Arial; fontsize: 20px; color: #333333;

}

</style>

<script type="text/javascript"> var radioAutoKeyboardEnabled; var radioAppKeyboardEnabled; var keyboardPosition; function showKeyboard()

{ if (!radioAppKeyboardEnabled.checked) return; global .keyboard.show(300, 300);

} function hideKeyboard()

{ if (!radioAppKeyboardEnabled.checked) return; global .keyboard.hide();

} function toggleAutoScreenKeyboard()

{ global . registry .setValue("browser.screen.keyboard.enabled", radioAutoKeyboardEnabled.checked);

} function setAutoScreenKeyboardPosition()

Copyright © 31 July 2017 Moderro Technologies, Inc. 142

Moderro Interactive Experience Platform

{ global . registry .setValue("browser.screen.keyboard.position", keyboardPosition.value);

} function init ()

{ var text = document.getElementById("text"); radioAutoKeyboardEnabled = document.getElementById("radioAutoKeyboardEnabled"); radioAppKeyboardEnabled = document.getElementById("radioAppKeyboardEnabled"); keyboardPosition = document.getElementById("keyboardPosition"); text .onfocus = showKeyboard; text . onclick = showKeyboard; text .onblur = hideKeyboard; radioAutoKeyboardEnabled.checke

d = global.registry.value("browser.screen.keyboard.enabled") == "true"; radioAppKeyboardEnabled.checked = !radioAutoKeyboardEnabled.checked; radioAutoKeyboardEnabled.onclick = toggleAutoScreenKeyboard; radioAppKeyboardEnabled.onclick = toggleAutoScreenKeyboard; keyboardPosition.value = global. registry .value("browser.screen.keyboard.position"); keyboardPosition.onchange = setAutoScreenKeyboardPosition;

}

</script>

</head>

<body onload="init()">

<div style="text-align: center

;"> Text input

<input id="text" type="text" />

<br />

<br />

<input id="radioAutoKeyboardEnabled" type="radio" name="keyboardType" />

Browser automatic screen keyboard enabled

<br />

<input id="radioAppKeyboardEnabled" type="radio" name="keyboardType" />

Application screen keyboard enabled

<br />

<br />

Automatic keyboard position

<br />

<select id="keyboardPosition">

<option value="KeyboardPositionAuto">Auto</option>

<option value="KeyboardPositionLeft">Left side</option>

<option value="KeyboardPositionTopLeft">Top

• left corner</option>

<option value="KeyboardPositionTop">Top side</option>

<option value="KeyboardPositionTopRight">Top

• right corner</option>

<option value="KeyboardPositionRight">Right side</option>

<option value="KeyboardPositionBottomRight">Bottom

• right corner</option>

<option value="KeyboardPositionBottom">Bottom side</option>

<option value="KeyboardPositionBottomLeft">Bottom

Copyright © 31 July 2017 Moderro Technologies, Inc. 143

Moderro Interactive Experience Platform

</div>

</body>

</html> left corner</option>

</select>

global.magstripe Object

The global.magstripe object is a widget that provides an interface to magnetic card readers and barcode scanners. In the case of a card reader, the widget reacts to a scan of a card and returns the value of the data that is recorded on the magnetic stripe. For credit cards, the data returned is typically cardholder’s name, card number, and expiration date. The widget returns the data in an unparsed form, so it is the responsibility of the developer to decrypt if necessary and parse the data. For a barcode reader, the widget registers a scanned event and returns the string that represents the barcode.

Refer to the latest Moderro Interactive Experience Client 4600 Series User Guide for a list of supported magnetic card readers and barcode scanners.

The global.magstripe object code is: interface Magstripe { void open(in string deviceName); void close(); signals: void opened(); void scanning(); void scanned(out string data); void error(out string error);

}

Table 4-7 global.magstripe Object Variables

Variable

open(in string deviceName) close() opened() scanning() scanned(out string data) error(out string error)

Description

Opens the device for reading data. If deviceName is not empty, use this device name, and browser.magstripe.scanner property otherwise.

Closes the device

The device has been open successfully.

The device has started data scanning.

The device has finished scanning and read the scanned data from deviceName .

An error has occurred.

To enable the magnetic card reader or barcode scanner, you will need the exact name of the card reader

Copyright © 31 July 2017 Moderro Technologies, Inc. 144

Moderro Interactive Experience Platform

or barcode scanner by which the IEC recognizes the peripheral. Follow these steps to retrieve that name:

Step 1

Step 2

Step 3

Plug the magnetic card reader or barcode scanner into the USB port of the IEC.

Reboot the IEC so that the IEC will recognize the new peripheral.

Run the

lsinput command at the shell prompt to get a list of connected input devices.

Note

Alternatively, you can get the name from the Moderro Interactive Experience Manager

(IEM). Go to the device and click the Status tab.

Step 4

Find the name of the magnetic card reader or barcode scanner. In the example below, the magnetic card reader is “Mag-Tek USB Swipe Reader”.

Virtual core pointer id=2[master pointer (3)]

Virtual core XTEST pointer id=4[slave pointer (2)]

Microsoft Microsoft® Digital Media Keyboardid=12[slave pointer (2)]

Filtered Elo TouchSystems, Inc. Elo TouchSystems 2700 IntelliTouch(r)

USB Touchid=14[slave pointer (2)]

MCE IR Keyboard/Mouse (ite-cir) id=15[slave pointer (2)]

Elo TouchSystems, Inc. Elo TouchSystems 2700 IntelliTouch(r) USB Touchmonitor

Interfaceid=9[slave pointer (2)]

Virtual core keyboard id=3[master keyboard (2)]

Virtual core XTEST keyboard id=5[slave keyboard (3)]

Power Button id=6[slave keyboard (3)]

Video Bus id=7[slave keyboard (3)]

Power Button id=8[slave keyboard

(3)]

PWC snapshot button id=10[slave keyboard (3)]

Microsoft Microsoft® Digital Media Keyboardid=11[slave keyboard

(3)] Mag-Tek USB Swipe Reader id=13[slave keyboard (3)]

ACPI Virtual Keyboard Device id=16[slave keyboard (3)]

ITE8704 CIR transceiver id=17[slave keyboard (3)]

Step 5

Replace the deviceName variable in the global.magstripe object with the name of the peripheral that the

IEC recognizes.

Step 6

In the device’s profile or a property applied to that device within the IEM, configure the application data property with “barcode.scanner” or “magstripe.scanner” for the key and the name of the peripheral that the IEC recognizes for the value.

The following is an example global.magstripe usage (file ../../test/js/magstripe.html).

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .magstripe test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

Copyright © 31 July 2017 Moderro Technologies, Inc. 145

Moderro Interactive Experience Platform

{ margin: 20px; background-color:

#111111; color :

#eeeeee; font-weight: bold; fontfamily: Arial; font-size: 18px;

}

</style>

<script type="text/javascript"> var nameId; var dataId; var errorId

; var statusId ; function init ()

{ nameId = document.getElementById("name"); dataId = document.getElementById("data"); errorId = document.getElementById("error"); statusId = document.getElementById("status"); global

.magstripe.error .connect(onError); global

.magstripe.scanning.connect(onScanning); global

.magstripe.scanned.connect(onScanned); global .magstripe.opened.connect(onOpened);

} function sopen()

{ errorId .innerHTML =

""; statusId .innerHTML

= ""; try

{ global .magstripe.open(nameId.value);

} catch(ex)

{ alert ("Exception: " + ex);

}

} function sclose ()

{ try

{

} global .magstripe.close () ; catch(ex)

{

} alert ("Exception: " + ex);

} function onError(e)

Copyright © 31 July 2017 Moderro Technologies, Inc. 146

Moderro Interactive Experience Platform

{ statusId .innerHTML = "Error";

} errorId .innerHTML = e; function onScanning()

{ dataId.innerHTML = ""; statusId .innerHTML = "Scanning";

} function onScanned(data)

{ dataId.innerHTML = data; statusId .innerHTML =

"Scanned";

} function onOpened()

{ statusId .innerHTML = "Opened";

}

</script>

</head>

<body onload="init()">

Device name: <input id="name" type="text" />

<input type="button" value="Open" onclick="sopen()" />

<input type="button" value="Close" onclick="sclose()" /> <br><br>

Incoming data: <span id="data"></span><br>

Status: <span id="status"></span><br>

Error: <span id="error"></span>

</body>

</html>

global.mediaCache Object

This object allows you to control the local media cache. interface MediaCache

{ readonly attribute long long capacity; readonly attribute long long size; readonly attribute long long free; readonly attribute bool isEmpty; readonly attribute int fileCount READ fileCount; readonly attribute Array urls; int clear(in long long size) const; bool contains(in string url) const; int load(in string url) const; bool remove(in string url) const; bool isLocked(in string url) const; long long fileSize(in string url) const; Date created(in string url) const;

Date lastAccessed(in string url) const; QString mimeType(in string url) const; slots:

Copyright © 31 July 2017 Moderro Technologies, Inc. 147

Moderro Interactive Experience Platform

int clear(); signals: void overloaded(); void loadStarted(in string url); void loadFinished(in string url); void loadError(in string url, in string errorString); void removed(in string url); void cleared(); void locked(in string url); void unlocked(in string url);

};

Table 4-8 global.mediaCache Variables

Variable

capacity size free isEmpty fileCount urls clear(in long long size) contains(in string url) load(in string url) remove(in string url) isLocked(in string url) fileSize(in string url) created(in string url) lastAccessed(in string url) mimeType(in string url) clear()

Description

Cache capacity in bytes

Cache size (occupied space) in bytes

Available space in the cache in bytes

Returns true if there are no files in the cache

Number of files in the cache

List of cached URLs in the order of last access date and time. Files accessed earlier go first.

Removes the most rarely used files to get at least size bytes available in the cache.

Returns true if the cache has the result of HTTP GET request to

URL url cached.

Loads the specified URL into the cache.

Removes the file correspondent to URL url from the cache.

Returns true if the file correspondent to URL url is in use.

Returns size in bytes for the file correspondent to URL url.

Returns creation date and time for the file correspondent to URL url.

Returns last access date and time for the file correspondent to URL url.

Returns MIME type for the file correspondent to URL url.

Clears the cache. All the files (including locked ones) will be removed from the cache.

All the signals purpose is clear.

Copyright © 31 July 2017 Moderro Technologies, Inc. 148

Moderro Interactive Experience Platform

Note

You should use clear() method very carefully since it can put your application in an inconsistent state.

For example, it can cause playback errors for the video player.

The following HTML contains an example of global.mediaCache usage (file

../../test/js/mediacache.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.mediaCache test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script type="text/javascript"> var textUrl; function flag(f)

{ return f ? "Yes" : "No";

} function updateCacheStatus()

{ document.getElementById("isEmpty").innerHTML = flag(global.mediaCache.isEmpty); document.getElementById("capacity").innerHTML = global.mediaCache.capacity; document.getElementById("size").innerHTML = global.mediaCache.size; document.getElementById("free").innerHTML = global.mediaCache.free; document.getElementById("fileCount").innerHTML = global.mediaCache.fileCount; document.getElementById("urls").innerHTML = global.mediaCache.urls.join("<br />");

} function init()

{ textUrl document.getElementById("textUrl");

= global.mediaCache.removed.connect(onRemoved); updateCacheStatus();

}

149 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

function check()

{ var url = textUrl.value; var contains = global.mediaCache.contains(url); document.getElementById("contains").innerHTML = flag(contains); document.getElementById("mimeType").innerHTML = contains ? global.mediaCache.mimeType(url) : "&nbsp;"; document.getElementById("fileSize").innerHTML = contains ? global.mediaCache.fileSize(url) : "&nbsp;"; document.getElementById("created").innerHTML = contains ? global.mediaCache.created(url).toLocaleString() : "&nbsp;"; document.getElementById("lastAccessed").innerHTML = contains ? global.mediaCache.lastAccessed(url).toLocaleString() : "&nbsp;"; document.getElementById("isLocked").innerHTML = contains ? flag(global.mediaCache.isLocked(url)): "&nbsp;";

} function remove()

{ var url = textUrl.value; global.mediaCache.remove(url)

; updateCacheStatus();

} function onRemoved(url)

{ document.getElementById("removed").innerHTML = url;

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="100%">

<tr>

<td width="50%">Is empty</td>

<td id="isEmpty"></td>

</tr>

<tr>

<td>Capacity in bytes</td>

<td id="capacity"></td>

</tr>

<tr>

<td>Size in bytes</td>

<td id="size"></td>

</tr>

<tr>

<td>Free space in bytes</td>

<td id="free"></td>

</tr>

<tr>

<td>Number of files</td>

<td id="fileCount"></td>

</tr>

<tr>

<td>

URL to check

Copyright © 31 July 2017 Moderro Technologies, Inc. 150

Moderro Interactive Experience Platform

<input id="textUrl" type="text" />

</td>

<td>

<input type="button" value="Check" onclick="check()" />

<input type="button" value="Remove" onclick="remove()" />

</td>

</tr>

<tr>

<td>Exists</td>

<td id="contains"></td>

</tr>

<tr>

<td>MIME type</td>

<td id="mimeType"></td>

</tr>

<tr>

<td>File size in bytes</td>

<td id="fileSize"></td>

</tr>

<tr>

<td>Creation time</td>

<td id="created"></td>

</tr>

<tr>

<td>Last access time</td>

<td id="lastAccessed"></td>

</tr>

<tr>

<td>Is locked</td>

<td id="isLocked"></td>

</tr>

<tr>

<td>URL removed</td>

<td id="removed"></td>

</tr>

<tr>

<td valign="top">URLs in the Cache</td>

<td id="urls"></td>

</tr>

</table>

</body>

</html>

The following IEM properties are connected to media cache:

browser.cache.media.enabled: Specifies whether media cache is enabled. You must set this property to ‘true’ to turn on the media cache.

browser.cache.media.size: Specifies media cache size in megabytes (default is 2048). Must not be set to zero in order to turn on media content caching. It is not recommend to use a size less than 50 megabytes. browser.cache.media.path: Specifies the path where the cached content will be stored. You do not need to change this property unless you want to place the cache on an external storage connected via USB. browser.cache.media.mode: Specifies the caching mode. This is the most important

151 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

property for media cache. Here is the list of values you can set for this property:

MediaCacheCheckIfExpired: Default value. Every time your application requests some media resource, this value will tell the IEC to check if the content has expired. If this is the case, the content will be re-cached. If not, the cached content will be returned.

MediaCacheNeverExpired: If content is cached, this value tells the IEC to never check if it’s expired (i.e. it is in offline mode). In contrast to the ‘CacheAlwaysCache’ value for browser.cache.web.mode, media cache in this mode will try to load uncached content from the network.

global.network Object

Network information can be obtained using global.network global object. It implements the Network interface. interface Network

{ readonly attribute string ifName; readonly attribute bool isWireless; readonly attribute string ip; readonly attribute string mask; readonly attribute string mac; readonly attribute string defaultGateway; readonly attribute string[] dnsServers;

};

Variable

ifName isWireless ip mask mac defaultGateway dnsServers

Table 4-9 global.network Variables

Description

Active network interface name (e.g. 'eth0' or 'wan0')

If true, the wireless network interface is active.

Active network interface IP address

Active network interface subnet mask

Active network interface MAC address

Default gateway IP address

List of DNS servers IP addresses

The following HTML is an example of global.network usage:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose. dtd">

<html>

<head>

<title>..:: global.network test ::..</title>

Copyright © 31 July 2017 Moderro Technologies, Inc. 152

Moderro Interactive Experience Platform

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style>

} body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

</style>

<script type="text/javascript"> var stockClip; var weatherClip; function init()

{ document.getElementById("ifName").innerHTML = global.network.ifName; document.getElementById("isWireless").innerHTML = global.network.isWireless ?

"Yes" : "No"; document.getElementById("ip").innerHTML = global.network.ip; document.getElementById("mask").innerHTML = global.network.mask; document.getElementById("mac").innerHTML = global.network.mac; document.getElementById("defaultGateway").innerHTML = global.network.defaultGateway; document.getElementById("dnsServers").innerHTML

= global.network.dnsServers.join(", ");

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="50%">

<tr>

<td>Interface name</td>

<td id="ifName"></td>

</tr>

<tr>

<td>Is a wireless interface</td>

<td id="isWireless"></td>

</tr>

<tr>

<td>IP address</td>

<td id="ip"></td>

</tr>

<tr>

<td>Network mask</td>

<td id="mask"></td>

</tr>

153 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<tr>

<td>MAC address</td>

<td id="mac"></td>

</tr>

<tr>

<td>Default gateway</td>

<td id="defaultGateway"></td>

</tr>

<tr>

<td>DNS servers</td>

<td id="dnsServers"></td>

</tr>

</table>

</body>

</html>

global.networkCache Object

Similar to the global.mediaCache object, the global.networkCache object allows you to control the local network cache. interface networkCache

{ readonly attribute bool isEnabled; readonly attribute long long capacity; readonly attribute long long size; readonly attribute long long free; readonly attribute bool isEmpty; bool contains(in string url) const; bool remove(in string url) const;

Date lastModified(in string url) const; slots: int clear();

};

Variable

isEnabled capacity size

Table 4-10 global.networkCache Variables

Description

Returns true if the network cache is enabled or returns false if otherwise

Cache capacity in bytes

Cache size (occupied space) in bytes

Copyright © 31 July 2017 Moderro Technologies, Inc. 154

Moderro Interactive Experience Platform

free isEmpty contains(in string url) remove(in string url) lastModified(in string url) clear()

Available space in the cache in bytes

Returns true if there are no files in the cache

Returns true if the cache has the result of HTTP GET request to

URL cached

Removes the file correspondent to URL from the cache

Returns last modification date and time for the file correspondent to

URL

Clears the cache: All the files (including locked ones) will be removed from the cache.

The following HTML contains an example of global.networkCache usage

(file../../test/js/networkcache.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.networkCache test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script type="text/javascript"> var textUrl; function flag(f)

{ return f ? "Yes" : "No";

} function updateCacheStatus()

{ document.getElementById("isEmpty").innerHTML = flag(global.networkCache.isEmpty); document.getElementById("capacity").innerHTML = global.networkCache.capacity; document.getElementById("size").innerHTML = global.networkCache.size; document.getElementById("free").innerHTML = global.networkCache.free;

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 155

Moderro Interactive Experience Platform

function init()

{ textUrl = document.getElementById("textUrl"); updateCacheStatus();

} function check()

{ var url = textUrl.value; var contains = global.networkCache.contains(url); document.getElementById("contains").innerHTML = flag(contains); document.getElementById("lastModified").innerHTML = contains ? global.networkCache.lastAccessed(url).toLocaleString() : "&nbsp;";

} function remove()

{ var url = textUrl.value; global.networkCache.remove(url); updateCacheStatus();

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="100%">

<tr>

<td width="50%">Is empty</td>

<td id="isEmpty"></td>

</tr>

<tr>

<td>Capacity in bytes</td>

<td id="capacity"></td>

</tr>

<tr>

<td>Size in bytes</td>

<td id="size"></td>

</tr>

<tr>

<td>Free space in bytes</td>

<td id="free"></td>

</tr>

<tr>

<td>

URL to check

<input id="textUrl" type="text" />

</td>

<td>

<input type="button" value="Check" onclick="check()" />

<input type="button" value="Remove" onclick="remove()" />

</td>

</tr>

<tr> function updateCacheStatus()

{ document.getElementById("isEmpty").innerHTML = flag(global.networkCache.isEmpty);

Copyright © 31 July 2017 Moderro Technologies, Inc. 156

Moderro Interactive Experience Platform

document.getElementById("capacity").innerHTML = global.networkCache.capacity; document.getElementById("size").innerHTML = global.networkCache.size; document.getElementById("free").innerHTML = global.networkCache.free;

} function init()

{ textUrl = document.getElementById("textUrl"); updateCacheStatus();

} function check()

{ var url = textUrl.value; var contains = global.networkCache.contains(url); document.getElementById("contains").innerHTML = flag(contains); document.getElementById("lastModified").innerHTML = contains ? global.networkCache.lastAccessed(url).toLocaleString() : "&nbsp;";

} function remove()

{ var url = textUrl.value; global.networkCache.remove(url); updateCacheStatus();

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="100%">

<tr>

<td width="50%">Is empty</td>

<td id="isEmpty"></td>

</tr>

<tr>

<td>Capacity in bytes</td>

<td id="capacity"></td>

</tr>

<tr>

<td>Size in bytes</td>

<td id="size"></td>

</tr>

<tr>

<td>Free space in bytes</td>

<td id="free"></td>

</tr>

<tr>

<td>

URL to check

<input id="textUrl" type="text" />

</td>

<td>

<input type="button" value="Check" onclick="check()" />

<input type="button" value="Remove" onclick="remove()" />

</td>

</tr>

<tr>

157 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<td>Exists</td>

<td id="contains"></td>

</tr>

<tr>

<td>Last modified</td>

<td id="lastModified"></td>

</tr>

</table>

</body>

</html>

The following properties are related to network cache:

Table 4-11

Variable

browser.cache.web.enabled browser.cache.web.size browser.cache.web.path browser.cache.media.clear browser.cache.web.mode

global.networkCache Properties

Description

Specifies whether web cache is enabled. This property must be set to true to turn on web content caching.

Specifies web cache size in megabytes (default is 1024). Must not be zero to turn on web content caching. It is not recommend that you use a size less than 50 megabytes.

Specifies the path, where the cached content will be stored. You do not need to change this property, unless you want to place the cache on an external storage connected via USB.

Once you set this property to true, the media cache is cleared. If you read value of this property, you always get false.

This is the caching mode. This is the most important property for web cache. Here is the list of values you can set for this property:

CacheAlwaysNetwork : Always load from network and do not check if the cache has a valid entry (similar to the Reload feature in browsers).

CachePreferNetwork : Default value. Load from the network if the cached entry is older than the network entry.

CachePreferCache : Load from cache if available, otherwise load from network. Note that this can return possibly stale (but not expired) items from cache.

CacheAlwaysCache : Only load from cache, indicating error if the item was not cached (i.e., off-line mode).

If you need to cache some web content to be able to use it later in off-line mode, you have to load that content with browser.cache.web.mode set to any value but "CacheAlwaysCache". After that from your application you have to set this property to "CacheAlwaysCache" or “CachePreferCache”. Note that in that mode if you did not cache some content your application requires, that content will not be loaded from the network when your application requests it. Instead you will see the "Service temporarily unavailable" error message.

Copyright © 31 July 2017 Moderro Technologies, Inc. 158

Moderro Interactive Experience Platform

global.printer Object

The global.printer object implements a printer interface which allows control of the printer connected to the IEC4600 Series either locally or via the network. This object allows end users to print PDF files, images, plain text documents and HTML documents. Plain text and HTML documents must be UTF-8 encoded in order to be printed correctly.

Refer to the latest Moderro Interactive Experience Client 4600 Series User Guide for a list of supported printers and instructions on how to set up and test your printer.

Note

While printing HTML documents, the end user will not be able to print external resources referred by that document such as images, flash clips or plugins.

The following is the global.printer object code: interface Printer

{ attribute bool collateCopies; readonly attribute int colorCount; attribute ColorMode colorMode; attribute int copyCount; attribute bool doubleSidedPrinting; attribute

DuplexMode duplex; attribute bool fontEmbeddingEnabled; readonly attribute int fromPage; readonly attribute int toPage; attribute bool fullPage; readonly attribute int widthMM; readonly attribute int heightMM; readonly attribute bool isValid; readonly attribute string name; attribute Orientation orientation; attribute PageOrder pageOrder; attribute PaperSize paperSize; attribute PaperSource paperSource; readonly attribute PrinterState state; attribute int resolution; readonly attribute list <int> supportedResolutions; readonly attribute list <PaperSize> supportedPaperSizes; readonly attribute bool supportsMultipleCopies; readonly attribute list <string> availablePrinters; readonly attribute string defaultPrinter; readonly attribute map status; slot bool abort(); slot bool newPage(); slot bool clearJobQueue(); list <real> getPageMargins(in Unit unit) const; void setPageMargins(in real left, in real top, in real right, in real bottom, in

Unit unit); bool setCurrentPrinter(in string printerName); list <real> paperExactSize(Unit unit) const; void setPaperExactSize(in real width, in real height, Unit unit) const; int print(in string url);

159 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

int printCurrentPage(); int printCurrentPageRect(in int left , in int top, in int width, in int height); int printElementBySelector(in string cssSelector ); void setFromTo(in int from, in int to); void clearStatusHistory(); signals: void errorStatus(in Date date, in int code, in string errorString);

}

Variable

collateCopies colorCount colorMode copyCount doubleSidedPrinting duplex fontEmbeddingEnabled fromPage toPage fullPage widthMM heightMM

Table 4-12 global.printer Variables

Description

Contains true if collation is turned on when multiple copies is selected. Contains false if it is turned off when multiple copies is selected. When collating is turned off the printing of each individual page will be repeated the numCopies amount before the next page is started. With collating turned on all pages are printed before the next copy of those pages is started.

Contains the number of different colors available for the printer

Contains the current color mode

Contains the number of copies that will be printed: The default value is 1.

Contains true if double side printing is enabled

Contains the current duplex mode

Contains true if font embedding is enabled

Contains the number of the first page in a range of pages to be printed. Pages in a document are numbered according to the convention that the first page is page 1. By default, this attribute contains a special value of 0, meaning that the "from page" setting is unset. This is read-only attribute. Use the setFromTo() method to set page range.

Contains the number of the last page in a range of pages to be printed. Pages in a document are numbered according to the convention that the first page is page 1. By default, this attribute contains a special value of 0, meaning that the "to page" setting is unset. This is a read-only attribute. Use the setFromTo() method to set page range.

Contains true if the origin of the printer's coordinate system is at the corner of the page and false if it is at the edge of the printable area

Contains the width of printing area in millimeters

Contains the height of printing area in millimeters

Copyright © 31 July 2017 Moderro Technologies, Inc. 160

Moderro Interactive Experience Platform

isValid name orientation pageOrder paperSize paperSource printerState resolution supportedResolutions supportedPaperSizes supportsMultipleCopies availablePrinters defaultPrinter status abort() newPage() clearJobQueue() getPageMargins() setPageMargins() setCurrentPrinter() paperExactSize() setPaperExactSize() print() printCurrentPage()

Contains true if the printer currently selected is a valid printer in the system

Contains the printer name

Contains the orientation setting

Contains the current page order

Contains the printer paper size

Contains the printer's paper source

Contains the current state of the printer: This may not always be accurate (for example if the printer doesn't have the capability of reporting its state to the operating system).

Contains the current assumed resolution of the printer

Contains a list of the resolutions (a list of dots-per-inch integers) that the printer says it supports

Contains a list of paper sizes that the printer says it supports.

Returns true if the printer supports printing multiple copies of the same document in one job; otherwise false is returned. On most systems this function will return true.

Contains a list of names of supported printers connected to the device

Contains a name of default printer.

Printer status as reported by the driver. Works only with HP printers.

For example, it returns ‘1014’ for a paper jam or ‘1009’ when the printer is out of paper.

Aborts the current print run. Returns true if the print run was successfully aborted and printerState will return Printer:Aborted; otherwise returns false. It is not always possible to abort a print job.

For example, all the data has gone to the printer but the printer cannot or will not cancel the job when asked to do.

Tells the printer to eject the current page and to continue printing on a new page. Returns true if this was successful; otherwise returns false.

Tells the printer to cancel all print jobs. Returns true on success; otherwise returns false.

Returns the page margins for this printer for the left, top, right, and bottom margins. The unit of the returned margins are specified with the unit parameter.

Sets the left, top, right and bottom page margins for this printer. The unit of the margins are specified with the unit parameter.

Sets the printer identified by its name as a current printer. Returns true on success, false on failure. List of all printer’s names can be retrieved using availablePrinters attribute. Initially defaultPrinter is considered current.

Returns the paper size as an array of two real numbers for page width and height in specified length unit.

Sets the paper width and height in specified length unit.

Prints document given by its URL. The URL can be local file system path or an HTTP URL. Returns PrintJob object.

Prints web page currently opened in a browser. Returns PrintJob

161 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

printCurrentPageRect() printElementBySelector() setFromTo() clearStatusHistory() errorStatus() object.

Prints rectangle of the current web page defined by left, top, width and height arguments. Returns PrintJob object.

Prints first element matching given CSS selector. Returns PrintJob object.

Sets the range of pages to be printed. Pages in a document are numbered according to the convention that the first page is page 1.

All pages will be printed if the both arguments are 0.

Clears the queue with the printer status history.

Fires when an error status event has arrived from the printer.

All global.printer methods related to performing actual printing return objects implementing the

PrintJob interface. interface PrintJob { readonly attribute JobState state; readonly attribute string errorString; readonly attribute string printerName; readonly attribute bool isFinished; void cancel(); void remove(); signal void finished(); signal void error(); signal void stateChanged();

}

Variable

state errorString printerName

Table 4-13 PrintJob Variables

Description

Contains current state of the print job and has one of the following values:

'Downloading' — document is being downloaded from remote server

'Held' — job is held for printing

'Pending' — job is waiting to be printed

'Processing' — job is currently printing

'Completed' — job has completed successfully

'Stopped' — job has been stopped

'Aborted' — job has aborted due to an error

Contains string describing the error that has occurred

Contains name of a printer performing the job

Copyright © 31 July 2017 Moderro Technologies, Inc. 162

Moderro Interactive Experience Platform

isFinished cancel() remove() finished() error() stateChanged()

Contains ‘true’ if printer finished processing the job regardless if it was successful or not or ‘false’ if printer has not finished processing the job

Tells the printer to cancel processing the print job. Returns ‘true’ on success or

‘false’ on failure. Note that it is not always possible to stop printing immediately if this process already started.

Tells the browser to remove job object. Information about all processed and finished jobs are kept in memory. If application uses printing extensively, it may be necessary to free resources associated with finished jobs manually using this method. Job object should never be used after the call of this method.

Returns when the job is finished processing regardless if it was successful or not

Returns when error related to the job occurs

Returns every time job state changes

The following HTML contains an example of global.printer usage.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.printer test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<sty le> body

{ margin: 20px; background-color:

#000000; color:

#eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

<script type="text/javascript"> function init ()

{ var printerSelect = document.getElementById("printer"); var printerList = global. printer . availablePrinters ; var defaultPrinter = global. printer . defaultPrinter ; for (var i = 0; i < printerList .length; ++i) { var printer = printerList [ i ]; printerSelect [ i ] = new Option(printer, printer); if ( printer == defaultPrinter)

Copyright © 31 July 2017 Moderro Technologies, Inc. 163

Moderro Interactive Experience Platform

} printerSelect .selectedIndex = i;

} printerChanged(); global . printer . finished .connect(onFinished); global . printer

.pagePrinted.connect(onPagePrinted); function printerChanged()

{ var printerSelect = document.getElementById("printer"); var printerName = printerSelect[printerSelect .selectedIndex ]. value; global . printer .setCurrentPrinter(printerName); document.getElementById("resolution").innerHTML = global.printer.resolution; document.getElementById("state").innerHTML = global.printer.state;

} function onFinished(ok)

{ document.getElementById("jobState").innerHTML = ok

? "Succeeded"

: ("Failed: " + global. printer . errorString ) ;

} function onPagePrinted(number)

{ document.getElementById("pageNumber").innerHTML = number;

} function print ()

{ global . printer . print("http://embedded-computing.com/pdfs/QNX.Jan05.pdf");

}

</script>

</head>

<body onload="init()">

<form onsubmit="print()">

<table cellpadding="2" cellspacing="0" border="1" align="center" width="50%">

<tr>

<td>Printer</td>

<td><select id="printer" onchange="printerChanged()"></select></td>

</tr>

<tr>

<td>Resolution</td>

<td id="resolution"></td>

</tr>

<tr>

<td>State</td>

<td id="state"></td>

</tr>

<tr>

<td>Page printed</td>

<td id="pageNumber"></td>

</tr>

<tr>

<td>Job status</td>

<td id="jobState"></td>

</tr>

Copyright © 31 July 2017 Moderro Technologies, Inc. 164

Moderro Interactive Experience Platform

<tr>

<td colspan="2" align="center">

<input type="submit" value="Print" />

</td>

</tr>

</table>

</form>

</body>

</html>

See the Moderro Interactive Experience Client 4600 Series User Guide for more examples, tips, and testing information related to the global.printer object.

global.registry Object

This object implements the Registry interface. It allows you to get and set properties values. It also allows you to get and set persistent values in the device profile.

Note

Wrong use of this API can be very dangerous. For example, wrong values for network-related properties can make your device inaccessible. In the worst case, you will have to re-burn the firmware of your device with an emergency USB stick.

Note

When you use this object first time it will take several seconds for it to be initialized, since it has to get the information on all properties in the system. interface Registry

{ readonly attribute string[] properties; readonly attribute string module; readonly attribute bool isStandalone; readonly attribute string serviceHost; readonly attribute unsigned int servicePort; readonly attribute bool isDmmEnabled; readonly attribute string dmmUrl; readonly attribute int lastUpdated; readonly attribute int expiresIn; bool exists(in string propertyName) const; string value(in string propertyName) const; int setValue(in string propertyName,in string propertyValue) const; string title(in string propertyName) const; string description(in string propertyName) const; bool isPersistent(in string propertyName) const; bool isGlobal(in string propertyName) const; bool isInternal(in string

Copyright © 31 July 2017 Moderro Technologies, Inc. 165

Moderro Interactive Experience Platform

propertyName) const; bool isRunTime(in string propertyName) const; bool isIpc(in string propertyName) const; bool isReadable(in string propertyName) const; bool isWritable(in string propertyName) const; string persistentValue(in string propertyName) const; int setPersistentValue(in string propertyName, in string propertyValue) const; bool subscribe(in string propertyName); signals: void changed(in string propertyName);

};

Table 4-14 global.registry Variables

Variable

properties module isStandalone serviceHost servicePort isDmmEnabled dmmUrl lastUpdated expiresIn exists() value() propertyName. setValue() title() description() isPersistent()

Description

Returns names for all available properties in the system

Returns module name for the browser process

Returns true if the device is in stand-alone mode (is not registered in the IEM)

IEM host name or IP address

IEM port

Returns true if Cisco DMM support is turned on

Returns Cisco DMM URL

Returns time stamp in seconds since the beginning of Epoch

(1-Jan-1970,12:00 AM), when the registry was updated from the management server.

Returns time in seconds after that amount of time the registry has to be considered as expired and has to be refreshed from the management server side. If contains a negative number or zero, the registry will not expire. Note that this value is not counted down as time goes. It updates every time the registry updates from the management server.

Returns true if the property with name propertyName exists

Returns string serialization for the value of property propertyName.

Note that if the property type is not integral (something like struct or list) this method returns XML.

Note that if the property type is not integral (e.g. struct or list) this method returns XML.

Sets value for property propertyName. If the property type is not integral, you must provide an XML serialization as a property value.

Returns zero on success, or -1 on error.

Returns property title

Returns property description

Returns true if the property is persistent. That means its value will be

Copyright © 31 July 2017 Moderro Technologies, Inc. 166

Moderro Interactive Experience Platform

isGlobal(): isInternal(): isRunTime(): isIpc(): isReadable(): isWritable(): persistentValue(): setPersistentValue(): subscribe() changed() obtained from the persistent storage at the module startup and it'll be saved to the persistent storage every time the property value changes.

Returns true if the property is global. If property is global that means it has only one persistent value for all modules and it appears in the spec only once. Its full qualified name does not contain module section.

Returns true if the property is internal. This property cannot be accessed from a module this property does not belong to.

Returns true if the property is run time. Changing this property's value implies immediate action.

Returns true if the property is used for IPC. It's an internal property used for IPC purposes only. So, it has to be ignored by management systems.

Returns true if the property value can be read

Returns true if the property value can be changed

Returns string serialization for the value of property propertyName from the persistent storage

Sets value for property propertyName in the persistent storage

Subscribes global.registry object to monitor propertyName property changes. When you subscribe global.registry to monitor some property, signal changed() fires every time property value changes.

Note that subscriptions persist even if you unload the page where you called the subscribe() method.

Fires when value of property propertyName changes. It fires only if you previously called the subscribe() method with that property name.

The following HTML contains an example of global.registry usage:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.registry test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<sty le> body

{ margin: 20px; background-color:

#000000; color:

#eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

167 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

</style>

<script type="text/javascript"> var textPropertyName; var textPropertyValue; function init()

{ textPropertyName = document.getElementById("textPropertyName"); textPropertyValue = document.getElementById("textPropertyValue"); document.getElementById("module").innerHTML = global.registry.module; document.getElementById("isStandalone").innerHTML = flag(global.registry.isStandalone); document.getElementById("serviceHost").innerHTML = global.registry.serviceHost; document.getElementById("servicePort").innerHTML

= global.registry.servicePort; document.getElementById("properties").innerHTML = global.registry.properties.join(",

"); global . registry .changed.connect(onPropertyChanged);

} function flag(f)

{ return f ? "Yes" : "No";

} function get()

{ var name = textPropertyName.value; textPropertyValue.value = global.registry.value(name); document.getElementById("exists").innerHTML = flag(global.registry.exists(name)); document.getElementById("title").innerHTML = global.registry.title(name); document.getElementById("description").innerHTML = global.registry.description(name); document.getElementById("isPersistent").innerHTML = flag(global.registry.isPersistent(name)); document.getElementById("isGlobal").innerHTML = flag(global.registry.isGlobal(name)); document.getElementById("isInternal").innerHTML = flag(global.registry.isInternal(name)); document.getElementById("isRunTime").innerHTML = flag(global.registry.isRunTime(name)); document.getElementById("isIpc").innerHTML = flag(global.registry.isIpc(name)); document.getElementById("isReadable").innerHTML = flag(global.registry.isReadable(name)); document.getElementById("isWritable’).innerHTML = flag(global.registry.isWritable(name));

{ function set()

{ global.registry.setValue(textPropertyName.value, textPropertyValue.value);

}

Copyright © 31 July 2017 Moderro Technologies, Inc. 168

Moderro Interactive Experience Platform

function subscribe()

{ global . registry .subscribe(textPropertyName.value);

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1px" align="center" width="100%">

<tr>

<td>Module</td>

<td id="module"></td>

</tr>

<tr>

<td>Is standalone mode</td>

<td id="isStandalone"></td>

</tr>

<tr>

<td>Management Service host</td>

<td id="serviceHost"></td>

</tr>

<tr>

<td>Management Service port</td>

<td id="servicePort"></td>

</tr>

<tr>

<td>Property changed recently</td>

<td id="isDmmEnabled"></td>

</tr>

<tr>

<td>DMM URL</td>

<td id=”changed”></td>

</tr>

<tr>

<td>

Property name

<input id="textPropertyName" type="text" />

</td>

<td

>

Val ue

<input id="textPropertyValue" type="text" />

<input type="button" value="Get" onclick="get()" />

<input type="button" value="Set" onclick="set()" />

</td>

</tr>

<tr>

<td>Exists</td>

<td id="exists"></td>

</tr>

<tr>

<td>Title</td>

<td id="title"></td>

</tr>

<tr>

<td>Description</td>

<td id="description"></td>

169 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

</tr>

<tr>

<td>Is persistent</td>

<td id="isPersistent"></td>

</tr>

<tr>

<td>Is global</td>

<td id="isGlobal"></td>

</tr>

<tr>

<td>Is internal</td>

<td id="isInternal"></td>

</tr>

<tr>

<td>Is run time</td>

<td id="isRunTime"></td>

</tr>

<tr>

<td>Is IPC</td>

<td id="isIpc"></td>

</tr>

<tr>

<td>Is readable</td>

<td id="isReadable"></td>

</tr>

<tr>

<td>Is writable</td>

<td id="isWritable"></td>

</tr>

<tr>

<td valign="top">All available properties</td>

<td id="properties"></td>

</tr>

</table>

</body>

</html>

global.resources Object

interface Resources

{ readonly attribute int cpuLoad; // CPU load in percents. readonly attribute List<double> cpuFrequency; // Instant frequency in MHz per core. readonly attribute int memoryAllocated; // Available memory in percents. readonly attribute long long memoryTotal; // RAM size in bytes. readonly attribute int storageAllocated; // Occupied room in data partition in percents. readonly attribute unsigned long long storageFree; // Available room in data partition in bytes. readonly attribute unsigned long long storageTotal; // Capacity of the data partition in bytes. readonly attribute unsigned long long storageCapacity; // Capacity of the entire

Copyright © 31 July 2017 Moderro Technologies, Inc. 170

Moderro Interactive Experience Platform

};

SSD in bytes.

global.scanner Object

The global.scanner object implements an interface for optical scanners allowing an application displayed on a kiosk to scan and manipulate a document. Refer to the latest Moderro Interactive Experience Client

4600 Series User Guide for a list of supported optical scanners and instructions on how to set up and test your scanner.

The scanner library used is from SANE and the list of compatible devices can be found here: http://www.sane-project.org/sane-supported-devices.html

The global.scanner object code is: interface Scanner

{ attribute uint dpiX; attribute uint dpiY; attribute bool color; attribute string source; readonly attribute List<String> devices; readonly attribute

List<String> sources; readonly attribute string lastError; readonly attribute string base64Data; readonly attribute bool busy; void setCurrentScanner(in string deviceName); signals: void finished(); void error(out string error); slots: start(); stop(); shutdown();

};

Table 4-15 global.scanner Object Variables

Variable

dpiX dpiY color source devices

Description

DPI X of the selected scanner

DPI Y of the selected scanner

Selected scanner in color mode

Document source

List of available scanners

171 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

sources lastError base64Data busy setCurrentScanner(in string deviceName) finished() error(out string error) start() stop() shutdown()

List of available document sources

Last error occurred

Scanned image as base64 JPEG data

Checks if the scanner is busy

Sets the current scanner to use. You need to call this method before scanning.

Indicates that the scanner has finished scanning

Indicates an error has occurred

Starts scanning from the selected scanner and document source

Stops scanning

Shuts down scanning subsystem and resets all internal caches

Note

Scanner hot plugging (or unplugging) is not supported by the application.

Tip

If you plug in a new scanner, you will need to restart the application to use it.

The following HTML contains an example of global.scanner usage (file../../test/js/scanner.html):

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .scanner test ::.. </title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style> body

{ margin: 20px; background-color:

#111111; color: #eeeeee; font-weight: bold; fontfamily: Arial;

} font-size: 18px;

</style>

<script type="text/javascript"> var scannersId; var errorId

; var

Copyright © 31 July 2017 Moderro Technologies, Inc. 172

Moderro Interactive Experience Platform

colorId ; var dpixId; var dpiyId; var sourceId; var startId , stopId; var imageId; var error; function init ()

{ scannersId = document.getElementById("scanners"); errorId = document.getElementById("error"); dpixId = document.getElementById("dpix"); dpiyId = document.getElementById("dpiy"); colorId = document.getElementById("color"); sourceId = document.getElementById("source"); startId

= document.getElementById("start"); stopId

= document.getElementById("stop"); imageId

= document.getElementById("image"); global .scanner.error .connect(onError) global .scanner. finished .connect(onFinished)

} error = false ; function getDevices()

{ try

} var data = global.scanner.devices ; scannersId.options.length = 0; if (data != null && data.length)

{ scannersId.options.add(new Option("-", 0)); for (var i = 0;i < data.length;i++)

{ scannersId.options.add(new Option(data[i], i+1));

}

}

} catch(ex)

{ alert ("Exception: " + ex);

}

} function apply()

{ if (global .scanner.setCurrentScanner(scannersId.options[scannersId.selectedIndex ]. text))

{ errorId .innerHTML =

"Set"; getDpiX(); getDpiY(); getColor();

Copyright © 31 July 2017 Moderro Technologies, Inc. 173

Moderro Interactive Experience Platform

} getSource(); startId .disabled = false

; stopId.disabled = false

;

} else

{ startId .disabled = true; stopId.disabled = true;

} function check()

Try}

} var available = global.scanner. isAvailable

(scannersId.options[scannersId.selectedIndex ]. text) ; alert

("Available : " + (available ? "yes" : "no"));

} catch(ex)

{ alert ("Exception: " + ex);

}

} function start ()

{ try

} setSource() ; setDpiX(); setDpiY(); setColor() ; imageId.src = " file :///"; errorId

.innerHTML = "Scanning..."; global

.scanner. start () ;

} catch(ex)

{ alert ("Exception: " + ex);

}

} function stop()

{ global .scanner.stop() ;

} function getDpiX()

{ dpixId.value = global.scanner.dpiX;

} function setDpiX()

{ global .scanner.dpiX = parseInt(dpix.value); getDpiX();

Copyright © 31 July 2017 Moderro Technologies, Inc. 174

Moderro Interactive Experience Platform

} function getDpiY()

{ dpiyId.value = global.scanner.dpiY;

} function setDpiY()

{ global .scanner.dpiY = parseInt(dpiy.value); getDpiY();

} function getColor()

{ colorId .checked = global.scanner.color ;

} function setColor()

{ global .scanner.color = colorId.checked; getColor();

} function getSource()

{

Try

} var data = global.scanner.sources; sourceId.options.length = 0; sourceId.options.add(new Option("-", 0)); for (var i = 0;i < data.length;i++)

{ sourceId.options.add(new Option(data[i], i+1));

} var src = global.scanner.source; if

(! src) src = "-"; for (var i = 0;i < sourceId.length; i++)

{ if (sourceId.options[ i ]. text === src)

{ sourceId.options[ i ]. selected = true; break;

}

} catch(ex)

{ alert ("Exception: " + ex);

}

} function setSource()

{ global .scanner.source = sourceId.options[sourceId.selectedIndex ]. text ; getSource();

} function onError(err)

{

Copyright © 31 July 2017 Moderro Technologies, Inc. 175

Moderro Interactive Experience Platform

} errorId .innerHTML = err; function onFinished()


}

</script>

</head>

<body onload="init()">

Available scanners: <select size="1" id="scanners"></select>

<input type="button" value="Detect scanners" onclick="getDevices()" />

<input type="button" value="Check" onclick="check()" />

<input type="button" value="Apply" onclick="apply()"

/><br><br> DPI-X: <input id="dpix" type="text" />

<input type="button" value="Get" onclick="getDpiX()"

/><br><br> DPI-Y: <input id="dpiy" type="text" />

<input type="button" value="Get" onclick="getDpiY()"

/><br><br> Color: <input id="color" type="checkbox" />

<input type="button" value="Get" onclick="getColor()" /><br><br>

Source:

<select size="1" id="source"></select><br><br>

<input type="button" value="Start scan" id="start" disabled="true" onclick="start()"

/>

<input type="button" value="Stop scan" id="stop" disabled="true" onclick="stop()"

/><br><br>

Log: <span id="error"></span><br><br>

<div style="height:1024px;width:1024px;overflow:scroll;">

<img id="image"></img>

</div>

</body>

</html>

See the Moderro Interactive Experience Client 4600 Series User Guide for more examples, tips, and testing information related to the global.scanner object.

global.serialPorts Object

global.serialPorts object is a factory for SerialPort objects. You can create multiple SerialPort objects in your application.

The following is the serialPort Object Interface: readonly attribute stringlist availableDevices; readonly attribute intlist standardBaudRates; bool contains(in string deviceName) const; SerialPort port(in string deviceName); bool deletePort(in Object port); bool deletePort(in string deviceName); void deleteAll (); attribute int baudRate;

Copyright © 31 July 2017 Moderro Technologies, Inc. 176

Moderro Interactive Experience Platform

attribute int dataBits; attribute int parity; attribute int stopBits; attribute int flowControl; attribute int dataErrorPolicy; attribute bool dataTerminalReady; attribute bool requestToSend; readonly attribute int error; attribute bool settingsRestoredOnClose;

ByteArray readAll(); long long write(in ByteArray data); signals: void aboutToClose(); void bytesWritten(in long long bytes); void readChannelFinished(); void readyRead(); void baudRateChanged(in int baudRate, in int direction); void dataBitsChanged(in int dataBits); void parityChanged(in int parity); void stopBitsChanged(in int stopBits); void flowControlChanged(in int flow); void dataErrorPolicyChanged(in int policy); void dataTerminalReadyChanged(in bool set); void requestToSendChanged(in bool set); void error(in int serialPortError); void settingsRestoredOnCloseChanged(in bool restore);

The following is the serialPort usage in HTML:

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global.serialPorts test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 20px; background-color:

#000000; color: #eeeeee; font-weight: bold; fontfamily: Arial; font-size: 20px;

}

</style>

Copyright © 31 July 2017 Moderro Technologies, Inc. 177

Moderro Interactive Experience Platform

<script type="text/javascript"> var deviceName; var device; var dataRead; var dataToWrite; function read()

{ var data = device.readAll(); var str

= ""; for (var i = 0; i < data.length; ++i) str += data[i] < 32 ? ’.’ :

String.fromCharCode(data[i]); dataRead.value += str; device.write(data);

} function send()

{ device.write(dataToWrite.value

); dataToWrite.value = "";

} function apply()

{ if

(!deviceName.value.leng

th) return; global . serialPorts . deleteAll () ; device = global. serialPorts .port(deviceName.value); device.baudRate = parseInt(document.getElementById("baudRate").value); document.getElementById("baudRate").value = device.baudRate; device.dataBits = parseInt(document.getElementById("dataBits").value); document.getElementById("dataBits").value = device.dataBits; device.flowControl = parseInt(document.getElementById("flowControl").value); document.getElementById("flowControl").value = device.flowControl; device. parity = parseInt(document.getElementById("parity").value); document.getElementById("parity").value = device.parity; device.stopBits = parseInt(document.getElementById("stopBits").value); document.getElementById("stopBits").value = device.stopBits; device.readyRead.connect(read);

} function init ()

{ global . serialPorts . deleteAll () ; deviceName = document.getElementById("deviceName"); var devices = global. serialPorts . availableDevices ; for (var i = 0; i < devices.length; ++i)

{ var opt =

Copyright © 31 July 2017 Moderro Technologies, Inc. 178

Moderro Interactive Experience Platform

document.createElement("option"); opt.value = devices[i ]; opt.innerHTML = opt.value; deviceName.appendChild(opt

);

} var baudRates = global.serialPorts.standardBaudRates; for (var i =

0; i < baudRates.length; ++i)

{ var opt = document.createElement("option"); opt.value = baudRates[i]; if (opt.value == 115200) opt. selected = true; opt.innerHTML = opt.value; baudRate.appendChild(opt)

;

} dataRead = document.getElementById("dataRead"); dataToWrite = document.getElementById("dataToWrite");

}

</script>

</head>

<body onload="init()">

<table cellpadding="2" cellspacing="0" border="1" align="center" width="50%">

<tr>

<td colspan="2" align="center">Serial port settings</td>

</tr>

<tr>

<td>Device</td>

<td>

<select id="deviceName">

<option value="">Not selected</option>

</select>

</td>

</tr>

<tr>

<td>Baud rate</td>

<td>

<select id="baudRate" />

</td>

</tr>

<tr>

<td>Data bits</td>

<td>

<select id="dataBits">

<option value="5">5</option>

<option value="6">6</option>

<option value="7">7</option>

<option value="8" selected>8</option>

</select>

</td>

</tr>

<tr>

<td>Flow control</td>

179 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<td>

<select id="flowControl">

<option value="0" selected>No</option>

<option value="1">Hardware</option>

<option value="2">Software</option>

</select>

</td>

</tr>

<tr>

<td>Parity</td>

<td>

<select id="parity">

<option value="0" selected>No</option>

<option value="2">Even</option>

<option value="3">Odd</option>

<option value="4">Space</option>

<option value="5">Mark</option>

</select>

</td>

</tr>

<tr>

<td>Stop bits</td>

<td>

<select id="stopBits">

<option value="1" selected>1</option>

<option value="3">1.5</option>

<option value="2">2</option>

</select>

</td>

</tr>

<tr>

<td colspan="2" align="right">

<input type="button" value="Apply" onclick="apply()" />

</td>

</table>

<br />

<table cellpadding="2" cellspacing="0" border="1" align="center" width="50%">

<tr>

<td>Data read</td>

<td>

<textarea id="dataRead" readonly ></textarea>

</td>

</tr>

<tr>

<td>Data to write</td>

<td>

<textarea id="dataToWrite" ></textarea>

<br />

<input type="button" value="Send" onclick="send()" />

</td>

</tr>

</table>

</body>

</html>

Copyright © 31 July 2017 Moderro Technologies, Inc. 180

Moderro Interactive Experience Platform

global.system Object

This object implements system interface. interface System

{ readonly attribute int screen; readonly attribute int masterScreen; readonly attribute list <string> usbDevices; readonly attribute list<string, string> webCameras; attribute int idleTimeout; string envVariable(in string name) const; int setEnvVariable(in string name, in string value,in bool overwrite = true); int unsetEnvVariable(in string name);

Screenshot screenshot(in int width, in int height); void debug(in string message) const; void info(in string message) const; void warning(in string message) const; void error(in string message) const; void moveMouse(in int x, in int y) const; void mouseClick(in int button =

0) const; signals: void mouseDoubleClicked(in int x, in int y,in int button); void mouseMoved(in int x, in int y,in int button); void mousePressed(in int x, in int y,in int button); void mouseReleased(in int x, in int y,in int button); void mouseWheelRotated(in int x, in int y, in int button); void idle(); void usbConnected(in string idAndName); void usbDisconnected(in string idAndName);

};

Table 4-16 global.system Variables

Variable

screen

Description

masterScreen usbDevices webCameras idleTimeout

Returns screen number the browser started on. Using this value web application can show different content on different monitors.

Returns the number of screen showed on the master display.

Contains the list of the connected USB devices. Each string has the following format: "<ID1>:<ID2> <NAME>", for example

"0000:1111 Company Ltd. Optical Mouse". See http://www.linux-usb.org/usb-ids.html for more about ID1 and ID2.

Contains the map of the connected web cameras. Each entry has a camera device as a key, and the camera name as a value.

Contains timeout in seconds. After that time of user inactivity idle() signal fires. Default value is 5.

181 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

envVariable() setEnvVariable() unsetEnvVariable() screenshot() debug() info() warning() error() moveMouse() mouseClick() mouseDoubleClicked() mouseMoved() mousePressed() mouseReleased() mouseWheelRotated() idle() usbConnected() usbDisconnected()

Returns value of environment variable name or empty string if there is no a variable with that name.

Adds the variable name to the environment with the value, if name does not already exist. If name does exist in the environment, then its value is changed to value if overwrite is true; if overwrite is false, then the value of name is not changed. Returns zero on success, or

-1 on error.

Deletes the variable name from the environment. If name does not exist in the environment, then the method succeeds, and the environment is unchanged. Returns zero on success, or -1 on error.

Takes screenshot and scales it to width by height size with respect of aspect ratio.

Sends debug message to syslog and to event system.

Sends info message to syslog and to event system.

Sends warning message to syslog and to event system.

Sends error message to syslog and to event system.

Move the mouse cursor to the specified global position.

Simulate the mouse button click. If button is 0 (the default) the left button is simulated, and the right otherwise.

Fires when some mouse button is double clicked.

Fires when mouse is moving.

Fires when some mouse button is pressed.

Fires when some mouse button is released.

Fires when mouse wheel is rotated.

Fires when system is in idle state (no user interaction).

Fires when USB device is connected. The string parameter has the following format: "<ID1>:<ID2> <NAME>", for example

"0000:1111 Company Ltd. Optical Mouse". See http://www.linux-usb.org/usb-ids.html for more about ID1 and ID2.

Please remember that all the existing USB devices will fire this signal during application startup, so if you have 5 USB devices connected you will get 5 usbConnected() signals with ids of that devices during application startup.

Fires when USB device is disconnected. The string parameter has the following format: "<ID1>:<ID2> <NAME>", for example

"0000:1111 Company Ltd. Optical Mouse". See http://www.linux-usb.org/usb-ids.html for more about ID1 and

ID2. screenshot() returns object, which implements Screenshot interface: interface Screenshot

{ readonly attribute int width; readonly attribute int height; readonly attribute string base64Data;

Copyright © 31 July 2017 Moderro Technologies, Inc. 182

Moderro Interactive Experience Platform

}

The following HTML contains an example of global.system usage.

<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN"

"http://www.w3.org/TR/html4/loose.dtd">

<html>

<head>

<title>..:: global .system example ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<styl e> body

{ margin: 32px; background-color:

#EEEEEE; font-weight: bold; font-family:

Arial; fontsize: 20px; color: #333333;

}

</style>

<script type="text/javascript"> var textVarName; var textVarValue; var screenshotImage; function init ()

{ textVarName = document.getElementById("textVarName"); textVarValue = document.getElementById("textVarValue"); screenshotImage = document.getElementById("screenshotImage"); document.getElementById("screen").innerHTML = global.system.screen; document.getElementById("masterScreen").innerHTML = global.system.masterScreen;

} function get()

{ textVarValue.value = global.system.envVariable(textVarName.value);

} function set ()

{ global .system.setEnvVariable(textVarName.value, textVarValue.value);

} function unset()

{ global .system.unsetEnvVariable(textVarName.value);

} function getScreenshot()

{ global .system.screenshot(640, 480).assignToHTMLImageElement(screenshotImage);

183 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

}

</script>

</head>

<body onload="init()">

<div style="text-align: center ;">

Screen: <span id="screen"></span>

</div>

<div style="text-align: center ;">

Master screen: <span id="masterScreen"></span>

</div>

<div style="text-align: center

;"> Environment variable name

<input id="textVarName" type="text"

/> Value

<input id="textVarValue" type="text" />

<input type="button" value="Get" onclick="get()" />

<input type="button" value="Set" onclick="set()" />

<input type="button" value="Unset" onclick="unset()" />

</div>

<div style="text-align: center ;">

<img id="screenshotImage" align="middle" width="640" height="480" /><br>

<input type="button" value="Get screenshot" onclick="getScreenshot()" />

</div>

</body>

</html>

global.videoEncoder Object

The global.videoEncoder object allows the web application to take a video feed from either a webcam or a HDMI Source and encode it to MPEG2-TS (MPEG2 Transport Stream) and stream it out to an endpoint either via UDP or via TCP. This object can be coupled with the video player and can serve as a local view of the encoded frame that is being sent out on the wire.

Note

While using TCP as the connection type, ensure that the TCP endpoint on the host to which you are interested to stream to is listening on the port of interest.

Note

While using the webcam, make sure the Input resolution that you select is supported by the camera. It is recommended that you use either a 720p or a 1080i camera. A lower resolution camera may not give the desired output. interface videoEncoder

{ readonly attribute bool isAvailable; // Checks if Encoder is Available readonly attribute int status; readonly attribute int errorCode; readonly attribute string

Copyright © 31 July 2017 Moderro Technologies, Inc. 184

Moderro Interactive Experience Platform

errorMessage; readonly attribute int videoInputCount; readonly attribute stringlist videoInputDescription; readonly attribute string snapshot; attribute string targetHost; // Target Host where MPEG2-TS has to be sent attribute int targetPort; // Target Port on Target Host to Receive it attribute int protocol; // Udp=0, Tcp=1 attribute int videoMode; // SD=0, HD=1, CUSTOM=2 attribute int videoSource; // Must be in [0, videoInputCount] range. 0 is for

HDMI, 1-videoInputCount is for webcams attribute int h264Profile; attribute int inputResolution; attribute bool isProgressive; attribute int streamType; attribute int inputFrameRate; // 15, 24, 30, 60 attribute int outputFrameRate; // 15, 24, 30,

60 attribute int averageOutputBitRate; attribute int minimumOutputBitRate; attribute int maximumOutputBitRate; attribute int outputResolution; attribute int audioBitRate; signals: notready(); ready(); started(); stopped(); error(in int code, in string message); slots: start(); stop(); takeSnapShot();

}

Variable

isAvailable status errorCode

Table 4-17 global.videoEncoder Object Variables

Description

Use this routine to check if the box has videoEncoder Module in it. A ‘true’ value indicates presence of the module.

Represents status of video encoder. The status are listed in the section below as enumeration for your reference.

This attribute will be set when an error occurs.

Use this attribute for error handling in your application.

Copyright © 31 July 2017 Moderro Technologies, Inc. 185

errorMessage videoInputCount videoInputDescription snapshot targetHost targetPort protocol videoMode videoSource h264Profile inputResolution isProgressive streamType inputFrameRate outputFrameRate averageOutputBitRate

Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

This routine returns the error string corresponding to the errorCode that was set. Use this function to display an error message to the user in your application.

Returns the available video sources including the

HDMI input from the USB dongle and all available webcams.

Returns the description of all video input devices present in the box.

Returns the captured snapshot from the HDMI encode stream as base64data. The returned data is the JPEG image.

Returns the target host to which the encoded stream is being sent.

Returns the port number on which the encoded stream is being sent.

Returns integer value for the Transport Protocol: ‘0’ for UDP or ‘1’ for TCP.

Returns video mode on which the video encoder is operating. Values are: ‘0’ - SD, ‘1’ - HD, and ‘2’ for

Custom.

Returns the video source being selected for encoding either as ‘0’ for HDMI or ‘1’ for videoInputCount for webcam.

Returns the encoding H.264 profile being used by the encoder: ‘0’ for Baseline, ‘1’ for Main, and ‘2’ for Extended Profile.

Returns the input resolution that is being used for the source. Possible values are ‘0’ for 1920x1080 resolution, ‘1’ for 1280x720, and ‘2’ for 1024x600.

Returns ‘true’ if the scan format is set to

Progressive.

Returns the input stream type that is configured on the encoder. Possible values are ‘0’ = Program

Stream, ‘1’ = Transport Stream, ‘2’ = Mpeg4 Stream

(default), ‘3’ = Elementary Stream, and ‘4’ = Raw

Stream.

Returns the Video-In Frame Rate as integer value in fps. Possible values are ‘0’ for 15fps, ‘1’ for 24fps,

‘2’ for 30fps, and ‘3’ for 60 fps.

Returns the Video-Out Frame Rate as integer value in fps. Possible values are ‘0’ for 15fps, ‘1’ for

24fps, ‘2’ for 30fps, and ‘3’ for 60 fps.

Returns the Video-Out Average Bit Rate in kbps

186

Moderro Interactive Experience Platform

minimumOutputBitRate

Returns the Video-Out Minimum Bit Rate in kbps maximumOutputBitRate

Returns the Video-Out Maximum Bit Rate in kbps outputResolution audioBitRate

Returns the Video-Out Resolution from the encoding stream. Possible values are ‘0’ for

1920x1080, ‘1’ for 1280x720, ‘2’ for 1200x672,

‘3’ for 1168x656, ‘4’ for 1024x576, and ‘5’ for

768x432.

Returns the Audio-Out Bit Rate being sent from the encoder in bps. setTargetHost(in string targetHost)

Allows you to set the Target Host (IP Address either as Unicast or Multicast ipv4 Address). setTargetPort(in string targetPort)

Allows you to set the Target Host's (Layer4) port

Number (TCP or UDP port number). setProtocol(in int transportProtocol) setVideoMode(in int videoMode) setVideoSource(in int videoSource) setH264Profile(in int h264Profile) setInputResolution(in int inputResolution) setProgressive(in int flag) setStreamType(in int streamType) setInputFrameRate(in int frameRate) setOutputFrameRate(in int frameRate) setAverageOutputFrameRate(in int avgRate)

Allows the Transport (Layer4) Protocol to be used when sending the encoded stream. Choices are ‘0’ for UDP or ‘1’ for TCP.

Allows you to set video Encode mode either as SD

(Standard Definition) or HD (High Definition). If you would like to still fine tune the encoding properties, you can select the custom option.

Choices are ‘0’ for SD, ‘1’ for HD, and ‘2’ for

Custom.

Allows you to set the video source for the encoder.

Choices are ‘0’ for HDMI Input from USB Dongle, and ‘1’ for all available (v4l compliant) webcams.

Allows you to set the H.264 profile to be used for encoding. Choices are ‘0’ for baseline profile, ‘1’ for main profile, and ‘2’ (default) for extended profile.

Allows you to set the input resolution for the video source. Choices are ‘0’ for 1920x1080, ‘1’ for

1280x720, and ‘2’ for 1024x600.

Allows you to set the input scan format to

Progressive. Call this API with parameter of ‘1’ to set to Progressive. Choices are ‘0’ or ‘1’.

Allows you to set the stream type for the Video-In stream. Choices are ‘0’ for PS, ‘1’ for TS (default),

‘2’ for Mp4, ‘3’ for ES, and ‘4’ for Raw.

Allows you to set the Incoming (Video-In) Frame rate in fps. Choices are ‘0’ for 15fps, ‘1’ for 24fps,

‘2’ for 30fps, and ‘3’ for 60fps.

Allows you to set the Output (Video-Out) Frame rate in fps. Choices are ‘0’ for 15fps, ‘1’ for 24fps,

‘2’ for 30fps, and ‘3’ for 60fps.

Allows you to set the Average Output Rate (Video-

Out) in kbps.

187 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

setMinimumOutputBitRate(in int minRate)

Allows you to set the Minimum Output Rate (Video-

Out) in kbps. setMaximumOutputBitRate(in int maxRate)

Allows you to set the Maximum Output Rate

(Video-Out) in kbps. setOutputResolution(in int outputResolution)

Allows you to set the Output Resolution for Video-

Out. Choices are ‘0’ for 1920x1280, ‘1’ for

1280x720, ‘2’ for 1200x672, ‘3’ for 1168x656,

‘4’ for 1024x576, and ‘5’ for 768x432. setAudioBitRate(in int bitRate)

Allows you to set the Audio-In bit rate in kbps.

global.videoEncoder object Enumeration

{ enum ErrorCodes

{ videoEncoderNotPresent = -1,

UnabletoStopStreaming = -2,

UnabletoStartStartStreaming = -3,

RemoteSideNotListening = -4,

MemoryExuastionError = -5,

NoHdmiVideoSignal = -6,

}; enum Protocol

{

BothUsbAndPcieTogetherNotSupported = -7,

HdmiVideoFormatNotUnderstood = -8,

ProtocolUdp = 0,

ProtocolTcp = 1,

}; enum VideoMode

{

VideoModeSD = 0,

VideoModeHD = 1,

VideoModeCustom = 2,

}; enum VideoSource

{

}; enum H264Profile

{

HdmiVideo = 0,

WebcamVideo = 1,

H264ProfileBaseLine = 0,

H264ProfileMain = 1,

H264ProfileExtended = 2,

}; enum InputResolution

{

InputResolution1920x1080 = 0,

InputResolution1280x720 = 1,

InputResolution1024x600 = 2,

};

Copyright © 31 July 2017 Moderro Technologies, Inc. 188

Moderro Interactive Experience Platform

enum OutputResolution

{

OutputResolution1920x1080 = 0,

OutputResolution1280x720 = 1,

OutputResolution1024x576 = 4,

OutputResolution768x432 = 5,

}; enum StreamType

{

OutputResolution1200x672 = 2,

OutputResolution1168x656 = 3,

StreamPgoram = 0,

StreamTransport = 1,

StreamMp4 = 2,

StreamElementary = 3,

StreamRaw = 4,

}; enum InputFrameRate

{

Input30fps = 2,

Input60fps = 3,

}; enum OutputFrameRate

{

Input15fps = 0,

Input24fps = 1,

Output15fps = 0,

Output24fps = 1,

Output30fps = 2,

Output60fps = 3,

};

}

The following is an example of global.videoEncoder usage (file../../test/js/encoder.html):

<!doctype html>

<html>

<head>

<meta http-equiv="Content-Type" content="text/html; charset=UTF-8" />

<title>..:: Encoder App ::..</title>

<style type="text/css"> html, body {width:100%; height:100%; padding:0; margin:0; position: absolute;}

* {-webkit-box-sizing:border-box; -moz-box-sizing:border-box; box-sizing:border-box;} div, span, td, ul , ol , li , h1, h2, h3, h4, h5, h6, iframe, form, table , td, tr , th

{padding:0; margin:0; border:none} ul , ol , li { list

-style:none;} img {border:none;}

@font-face {font-family: timerDisplay; src: url(fonts/PFDinTextPro-Regular.ttf)} body {background: #777; color: #ffffff ; font :normal 12px Arial, Helvetica, sans-serif;} object {display:block; background:black}

.cameraDisabled, .cameraReady, .cameraOnline, .cameraError {width:44px; height:24px; background:transparent url(’img/encoder/LED.png’) 0px 0px no-repeat;}

.cameraReady {background-position:-44px 0}

.cameraOnline {background-position:-88px 0}

189 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

.cameraError {background-position:-132px 0}

/*.status .devicetype .devicename {color:#848d9d; text-shadow:0 -1px 1px #000; font:normal

14px Arial, Helvetica, sans-serif; padding:0 20px}

. calltime {color:#b1b6c3; font:normal 14px Arial, Helvetica, sans-serif ; height:41px; text-shadow:0 -1px 1px #000;}

.buttons {text-align:center; display: inline-block;}*/

/* ============= */

.topPanel {background:#0e1014 url(’img/encoder/top_panel_background.png’) left bottom repeat-x; color:#4c5058; text-shadow:0 -1px 1px #000; height:64px; paddingbottom:7px; border-top:solid 1px #444444}

.bottomPanel {background:#0e1014 url(’img/encoder/status_panel_background.png’) top left repeat-x; color:#4c5058; text-shadow:0 -1px 0 #000; padding:0 30px; textalign:center; font:normal 12px Arial, Helvetica, sans-serif; height:23px; lineheight:23px; vertical-align:middle; overflow:hidden}

. display {border-style: solid ; border-width: 0px 10px 0px 10px;

-webkit-border-image:url(’img/encoder/small_rec_display.png’) 0 10 0 10 stretch; border-image:url(’img/encoder/small_rec_display.png’) 0 10 0 10 fill stretch; height:35px; line-height:35px; width:100%; text-align:center}

.timerOn, .timerOff {color:# ffffff ; font :normal 26px/35px timerDisplay,

Arial, Helvetica, sans-serif ; text-shadow:0 -1px 1px #000; verticalalign:middle; display:inline-block; margin-top:3px; overflow:hidden}

.timerOff {opacity:.1}

.startButton, .stopButton, .startButtonON {width:50px; height:50px; lineheight:50px; padding:0; margin:0; background:transparent url(’img/encoder/buttons.png’) 0px 0px no-repeat; border:none; text-shadow:0 -1px 0 black}

.startButton:hover, .stopButton:hover {background-position:0px 0px}

.startButton:active , .stopButton:active {background-position:-50px 0px}

.startButton:disabled, .stopButton:disabled {background-position:0px 0px}

.startButtonON {background-position:-100px 0px}

.startButtonON:hover {background-position:-100px 0px}

.startButtonON:active {background-position:-150px 0px}

.startButtonON:disabled {background-position:-100px 0px}

.startButton:active img, .stopButton:active img, .startButtonON:active img {opacity:.7}

.startButton:disabled img, .stopButton:disabled img {opacity:.4}

.view {background:#000; border:solid 1px #3b3d40; text-align:center; width:100%;}

/* hiding spin buttons */ input::-webkit-outer-spinbutton, input::-webkit-innerspin-button {

/* display: none; <- Crashes Chrome on hover */

-webkit-appearance: none; margin: 0; /* <-- Apparently some margin are still there even though it’s hidden */

}

.sidepanel {background:#24252a url(img/encoder/sh.png) left top repeaty; border-left:solid 1px #777; max-width:400px;text-shadow:0 -1px 0

#000;}

#configWindow {display:block; text-align:center; width:400px; background:rgba(0,0,0,.8); color:#aaa; padding:20px; border:solid 1px #333333; font:normal 12px Arial, Helvetica, sans-serif ; box-shadow:0 10px 30px rgba(0,0,0,.7)}.sidepanel #configWindow {height:100%; box-shadow:none; background:none; border:none}

#configWindow fieldset {border:none; padding:20px}

#configWindow legend {text-align:center;}

#configWindow label {padding-right:20px; text-align:right;

Copyright © 31 July 2017 Moderro Technologies, Inc. 190

Moderro Interactive Experience Platform

width:100%; display:inline-block}

#configWindow input[type=text], #configWindow input[type=number]

{background

• color:#FEFEFE}

#configWindow input.invalid {background-color:#FFA7B1}

#configWindow table {width:100%;}

#configWindow td {width:48%; text-align:left;}

#configWindow button { background:none; border-style: solid; border-width: 0px 10px 0px

10px; -webkit-border-image:url(’img/encoder/btn_idle.png’) 0 10 0 10 stretch; border-image:url(’img/encoder/btn_idle.png’) 0 10 0 10 fill stretch; height:24px; line-height:24px; font:normal 12px/22px Arial, Helvetica, sans-serif; color:#191d21; text-shadow:0 1px 0 rgba(255,255,255,.3);}

#topMenu button {background:transparent url(img/encoder/btn_idle.png) left top no-repeat; width:172px; height:24px; border:none; }

#configWindow button:hover {-webkit-border-image:url(’img/encoder/btn_hover.png’) 0 10 0

10 stretch; border-image:url(’img/encoder/btn_hover.png’) 0 10 0 10 fill stretch;}

#configWindow button:active {-webkit-border-image:url(’img/encoder/btn_pressed.png’) 0 10

0 10 stretch; border-image:url(’img/encoder/btn_pressed.png’) 0 10 0 10 fill stretch; color:#002960}

#configWindow button:disabled {-webkit-border-image:url(’img/encoder/btn_disabled.png’) 0

10 0 10 stretch; border-image:url(’img/encoder/btn_disabled.png’) 0 10 0 10 fill stretch; color:#545b65; text-shadow:0 -1px 0 rgba(0,0,0,1);}

#configErrorMsg {background:#6b0202; color:#fff; text-align:center; margin:10px 30px; border:solid 1px red; border-radius:4px; padding:6px}

/* debug */

.onSignal {margin-left:-13px; border-left:solid 3px white; padding-left:5px}

</style>

<script type="text/javascript"> var player ; var incall = false

; var inputCount; var Status; var GUI_startButton, GUI_startButtonIcon, GUI_stopButton, GUI_stopButtonIcon,

GUI_timer; var useApplicationData = false; var videoEncoder_targetHost; var videoEncoder_targetPort; var videoEncoder_videoSource; var videoEncoder_videoMode; var videoEncoder_protocol; var encoderStatus; var configWindow, targetAddr, targetPort, videoSource, videoMode, videoProtocol; function init (){ player = document.getElementById("player");

GUI_startButton = document.getElementById("StartButton");

GUI_startButton.className = "startButton";

GUI_startButton.disabled = true;

GUI_startButtonIcon = document.getElementById("StartButtonIcon");

GUI_startButtonIcon.src = "img/encoder/start_icon.png";

GUI_stopButton = document.getElementById("StopButton");

GUI_stopButton.className = "startButton";

GUI_stopButton.disabled = true;

GUI_stopButtonIcon =

Copyright © 31 July 2017 Moderro Technologies, Inc. 191

Moderro Interactive Experience Platform

document.getElementById("StopButtonIcon");

GUI_stopButtonIcon.src = "img/encoder/stop_icon.png";

GUI_timer = document.getElementById("theTime"); configWindow = document.getElementById("configWindow"); targetAddr = document.getElementById("targetAddr"); targetPort = document.getElementById("targetPort"); videoSource = document.getElementById("videoSource"); videoMode = document.getElementById("videoMode"); videoProtocol = document.getElementById("videoProtocol");

// looking for ’useAppData’ keyword in the query string var l=String(window.location); var qs=l.substring( l .indexOf("?", 0)+1, l .length)

; useApplicationData = (qs.indexOf("useAppData",

0)>=0);

} if (useApplicationData){ readAppData(); //fill config form with values from appData. applyParams(false); // applying values (but not saving to registry ) . In case if invalid data the config panel with highlighted errors will appear.

} else {

//popup configuration window configWindow.style.display =

"block";

} function readAppData(){ targetAddr.value = global.applicationData.value("encoder.target", null

) ; targetPort.value = global.applicationData.value("encoder.port", null

) ; if (global .applicationData.contains("encoder.videoSource")){ var val = global.applicationData.value("encoder.videoSource"); for (var i=0; i<videoSource.length; i++){videoSource.options[ i ]. selected =

(videoSource.options[i ]. value.toUpperCase()==val.toUpperCase())

}

} if (global .applicationData.contains("encoder.videoMode")){ var val = global.applicationData.value("encoder.videoMode"); for (var i=0; i<videoMode.length; i++){videoMode.options[i]. selected =

(videoMode.options[i].value.toUpperCase()==val.toUpperCase())

}

} if (global .applicationData.contains("encoder.protocol")){ var val = global.applicationData.value("encoder.protocol"); for (var i=0; i<videoProtocol.length; i++){videoProtocol.options[ i ]. selected =

(videoProtocol.options[i ]. value.toUpperCase()==val.toUpperCase())

}

}

} function applyParams(save){ var configErrorMsg = document.getElementById("configErrorMsg"); var invalid = false

;

// Validating inputs if (targetAddr.value==null || targetAddr.value==""){ targetAddr.className = "invalid";

Copyright © 31 July 2017 Moderro Technologies, Inc. 192

Moderro Interactive Experience Platform

invalid = true;

} else { targetAddr.className = null;

} if (isNaN(Number(targetPort.value)) || Number(targetPort.value)<257 ||

Number(targetPort.value)>65535){ targetPort.className =

"invalid"; invalid = true;

} else { targetPort.className = null;

} if (! invalid ){ videoEncoder_targetHost = targetAddr.value; videoEncoder_targetPort = Number(targetPort.value); videoEncoder_videoSource = videoSource.value; videoEncoder_videoMode = videoMode.value; videoEncoder_protocol = videoProtocol.value;

} if (!! save){

// save values to registry if (global .applicationData.isReadOnly){ alert ("Application Data is read only. Configuration params will be lost after reboot.");

} global .applicationData.insert ("encoder.target", videoEncoder_targetHost); global .applicationData.insert ("encoder.port", videoEncoder_targetPort); global .applicationData.insert ("encoder.videoSource", videoEncoder_videoSource); global .applicationData.insert ("encoder.videoMode", videoEncoder_videoMode); global .applicationData.insert ("encoder.protocol", videoEncoder_protocol);

} configErrorMsg.style. visibility = "hidden"; configWindow.style.display = "none"; initVideoEncoder();

} else { configWindow.style.display = "block"; configErrorMsg.style. visibility = "visible";

} function initVideoEncoder(){ inputCount = global.videoEncoder.inputCount; global .videoEncoder.targetHost = videoEncoder_targetHost; global

.videoEncoder.targetPort = videoEncoder_targetPort; global .videoEncoder.videoSource = videoEncoder_videoSource; global .videoEncoder.videoMode = videoEncoder_videoMode; global .videoEncoder.protocol = videoEncoder_protocol;

// Connect Signals global .videoEncoder.ready.connect(onReady); global

.videoEncoder.notready.connect(onNotReady); global

.videoEncoder.started.connect(onStarted); global

.videoEncoder.stopped.connect(onStopped); global .videoEncoder.error.connect(onError);

Copyright © 31 July 2017 Moderro Technologies, Inc. 193

Moderro Interactive Experience Platform

}

// For UDP Stream Viewer player

.endReached.connect(player.play); global .videoEncoder.start();

// For Encoder App function onReady()

{

GUI_startButton.className = "startButton";

GUI_startButton.disabled = false;

GUI_stopButton.disabled = false;

} document.getElementById("Status").innerHTML = "Ready" document.getElementById("cameraStatusLED").className = "cameraDisabled"; document.getElementById("theTime").className = "timerOff"; function onNotReady() {

GUI_startButton.className =

"startButton"; GUI_startButton.disabled = true; GUI_stopButton.disabled = true;

} document.getElementById("Status").innerHTML = "Not Ready" document.getElementById("cameraStatusLED").className = "cameraDisabled"; document.getElementById("theTime").className = "timerOff"; countDown(0); function onStarted() {

GUI_startButton.className =

"startButtonON"; GUI_startButton.disabled = true; GUI_stopButton.disabled = false;

} document.getElementById("Status").innerHTML = "Encoding"; document.getElementById("cameraStatusLED").className="cameraOnline"; player .play("udp://@127.0.0.1:"+videoEncoder_targetPort); countDown(1); function onStopped() {

GUI_startButton.className =

"startButton"; GUI_startButton.disabled

= false; GUI_stopButton.disabled = true;

} document.getElementById("Status").innerHTML = "Stoped"; document.getElementById("cameraStatusLED").className="cameraDisabled"; countDown(0); function onPaused() {

GUI_startButton.className =

"startButton"; GUI_startButton.disabled

= false; GUI_stopButton.disabled = true; document.getElementById("Status").innerHTML = "Paused"; document.getElementById("cameraStatusLED").className="cameraDisabled";

Copyright © 31 July 2017 Moderro Technologies, Inc. 194

Moderro Interactive Experience Platform

} countDown(0); function onError(code, explanation) {

GUI_startButton.className = "startButton";

GUI_startButton.disabled = false;

GUI_stopButton.disabled = false;

} var msg = code + ’ : ’ + explaination; alert (msg); document.getElementById("Status").innerHTML = "<span style=’color:#ff6920;’>Error: "

+ explaination + " </span>"; document.getElementById("camera").src = "img/encoder/webcam_disabled.png"; function startEncoder(){

GUI_startButton.disabled = false; GUI_stopButton.disabled

= false; global

.videoEncoder.start();

} function stopEncoder(){

GUI_startButton.disabled = false; GUI_stopButton.disabled

= false; global

.videoEncoder.stop();

}

// For Timing to be shown var timer_sec = 00; // set the seconds var timer_min = 00; // set the minutes var timer_hrs = 00; // set the Hours var timer_OneSecond; function countDown(flag){ clearTimeout(timer_OneSecond); //preventing many timeouts creation when receiving multiple signals at the same time var calltime

; if ( flag

) { timer_sec++; if (timer_sec == 59)

{ timer_sec = 00; timer_min = timer_min + 1;

} if (timer_min == 59)

{ timer_min = 00; timer_hrs = timer_hrs + 1;

} if (timer_sec <= 9){ timer_sec = "0" + timer_sec;

} calltime = (timer_hrs<1 ? "" : ((timer_hrs<=9 ? "0" + timer_hrs : timer_hrs) +

":")) + (timer_min<=9 && timer_hrs>0 ? "0" + timer_min : timer_min) + ":" + timer_sec;

GUI_timer.innerHTML = calltime;

GUI_timer.title = "Last call duration:

"+calltime; timer_OneSecond =

195 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

setTimeout("countDown(1)", 1000);

} else {

GUI_timer.innerHTML =

"0:00"; clearTimeout(timer_OneSecond)

; timer_sec = 00; timer_min = 00; writeLog("<span style=’color:yellow’>Timer stopped.</span>");

}

}

</script>

</head>

<body onload="init()">

<table border="0" cellpadding="0" cellspacing="0" width="100%" height="100%">

<tr>

<td align="center" style="border-right:solid 1px #444444">

<table border="0" cellspacing="0" cellpadding="0" style="box-shadow:0 10px 30px rgba(0,0,0,.7)">

<tr>

<td class="topPanel">

<table width="100%" border="0" cellspacing="0" cellpadding="0">

<tr align="center">

<td width="25%"><button id="StartButton" class="startButton" onClick="startEncoder()"><img id="StartButtonIcon" src="img/encoder/start_icon.png"></button><button id="StopButton" class="stopButton" onClick="stopEncoder()"><img id="StopButtonIcon" src="img/encoder/stop_icon.png"></button></td>

<td><div class="display"><span class="timerOff" id="theTime">0:00</span></div></td>

<td width="25%"><img id="cameraStatusLED" class="cameraDisabled" src="img/encoder/spacer.png"align="left" width="44" height="24" /></td>

</tr>

</table>

</td>

</tr>

<tr>

<td><!-- For UDP Stream Player -->

<object id="player" type="application/x-qt-plugin" classid="videoplayer" width="720" height="480">

<param name="url" value="udp://@127.0.0.1:31319"/>

<param name="controlsVisible" value="false"/>

</object>

</td>

</tr>

<tr>

<td class="bottomPanel"><span class="status" id="Status">status</span></td>

</tr>

</table>

</td>

<td width="1" class="sidepanel">

<div id="configWindow" style="display:none">

<fieldset>

<legend>Encoder configuration</legend>

<table border="0" cellspacing="0" cellpadding="0" align="center">

<tr>

<td><label for="targetAddr">Target Address:</label></td>

<td><input id="targetAddr" type="text" placeholder="0.0.0.0"

Copyright © 31 July 2017 Moderro Technologies, Inc. 196

Moderro Interactive Experience Platform

onChange="this.className=null" value="225.1.1.1" required></td>

</tr>

<tr>

<td><label for="targetPort">Target port:</label></td>

<td><input id="targetPort" type="number" min="257" max="65535" onChange="this.className=null"placeholder="31319" value="31319" required></td>

</tr>

<tr>

<td><label for="videoSource">Video source:</label></td>

<td>

<select id="videoSource">

<option value="1">Webcam</option>

<option value="0" selected>HDMI</option>

</select>

</td>

</tr>

<tr>

<td><label for="videoMode">Video mode:</label></td>

<td><select id="videoMode">

<option value="0">SD</option>

<option value="1" selected>HD</option>

<option value="2">Custom</option>

</select></td>

</tr>

<tr>

<td><label for="videoProtocol">Protocol:</label></td>

<td><select id="videoProtocol">

<option value="0" selected>UDP</option>

<option value="1">TCP</option>

</select></td>

</tr>

</table>

<div id="configErrorMsg" style="visibility:hidden">Invalid params.<br>Please, fix values marked red.</div>

<button onClick="applyParams(false)">Apply</button>

<button

Apply</button> onClick="applyParams(true)">Save

<button and onClick="readAppData()">Use

AppData</button>

</fieldset>

<div style="padding:20px 50px">

Note: if application.data property is defined with a policy, configuration values cannot be saved on the management server and will be lost after reboot.

</div>

</div>

</td>

</tr>

</table>

<div style="display:none; visibility :hidden">

<!-- chaching images -->

<img src="img/encoder/start_icon.png" width="0" height="0" />

<img src="img/encoder/stop_icon.png" width="0" height="0" />

<img src="img/encoder/encoder/pause_icon.png" width="0" height="0" />

</div>

<!-- This part of code is used for tracing application states -->

<div id="appDebugInfo" style="visibility:hidden; background:rgba(0,0,0,.75); position:absolute; top:0; left :0; width:300px;overflow-x:hidden; overflow-y: scroll ; color :white; padding:20px; font:normal 10px/12px sans-serif">

</div>

<script>

197 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

function writeLog(msg){ var c = document.getElementById(’appDebugInfo’); if

(c){ c.innerHTML=c.innerHTML + msg + "<br><br>";

}

} function isDebugMode(){ var l=String(window.location); var qs=l.substring( l .indexOf("?", 0)+1, l .length)

; if (qs.indexOf("debug", 0)>=0){ document.getElementById(’appDebugInfo’).style.visibility = "visible";

} else { document.getElementById(’appDebugInfo’).style.visibility = "hidden";

}

} isDebugMode(); document.getElementById(’appDebugInfo’).style.height = document.body.offsetHeight+"px";

</script>

</body>

</html>

global.vncServer Object

The global.vncServer object allows you to control a local Virtual Network Computing (VNC) server. This server can be used to give virtual access to the IEC device such as to share a remote desktop. The remote desktop requires a VNC client. You can establish a remote session from either direction (IEC or remote desktop) or from both directions.

Note

This object will not traverse firewalls.

The global.vncServer object code is: interface VncServer

{ bool start(in string password = "", in string host = "", in int port = -1, in bool readOnly = false); bool start(in rect rc, in string password = "", in string host = "", in int port = -

1, in bool readOnly = false); bool start(in int x, in int y, in int width, in int height, in string password ="", in string host = "", in int port = -1, in bool readOnly = false); readonly attribute bool isRunning; readonly attribute bool isReadOnly; readonly attribute Rect geometry; slots: bool stop();

};

Table 4-18

Copyright © 31 July 2017 Moderro Technologies, Inc.

global.vncserver Variables

198

Moderro Interactive Experience Platform

Variable

start(in string password, in string host, in int port, in boolreadOnly)

Description

Starts the VNC server for full screen. If password is not empty, use this password to protect the VNC connection. If host is not empty, try to connect to this host, and start locally otherwise. If port is less than zero, use the default VNC port, or use this port otherwise. If readOnly is true, the VNC server does not accept any input from connected clients.

Returns true in the case of success and false in the case of failure. start(in int x, in int y, in int width, in int height, in string password, in string host, in int port, in bool readOnly

Starts the VNC server for rectangular area (x; y;width; height). If password is not empty, use this password to protect the VNC connection. If host is not empty, try to connect to this host, and start locally otherwise. If port is less than zero, use the default VNC port, or use this port otherwise. If readOnly is true, the VNC server does not accept any input from connected clients.

If the rectangular area is empty, this method does nothing and returns false. Returns true in the case of success and false in the case of failure. start(in rect rc, in string password, in string host, in int port, in bool readOnly)

Starts the VNC server for rectangular area (rc). If password is not empty, use this password to protect the VNC connection. If host is not empty, try to connect to this host, and start locally otherwise. If port is less than zero, use the default

VNC port, or use this port otherwise. If readOnly is true, the VNC server does not accept any input from connected clients. If the rectangular area is empty, this method does nothing and returns false.

Returns true in the case of success and false in the case of failure. isRunning

Returns true if the VNC server is running. isReadOnly

Returns true if the VNC server does not accept any input from connected VNC clients. geometry

Returns geometry of the rectangular area the VNC server is running for. If the server is not running or no coordinates have been specified via start(), returns an empty rectangle. stop()

Stops the VNC server. Returns true in the case of success (or the server is not running) and false in the case of failure.

Note

You should avoid running the VNC server for areas containing video, either playing in Flash or in the VideoPlayer widget.

199 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<!doctype html>

<html>

<head>

<meta charset="UTF-8">

<title>..:: global.vncserver test ::..</title>

<meta http-equiv="Content-Type" content="text/html; charset=utf-8">

<style

> body

{ margin: 20px; background-color: #111111; color: #eeeeee; font-weight: bold; font-family: Arial; font-size: 18px;

} input {background-color:#fffffe}

.note {color:#91CAFF}

</style>

<script type="text/javascript"> var hostId; var portId; var roId; var passwordId; var xId, yId, widthId, heightId; function isNumber(n)

{ return !isNaN(n) && isFinite(n);

} function init()

{ hostId = document.getElementById("host"); portId = document.getElementById("port"); roId = document.getElementById("ro"); passwordId = document.getElementById("password"); xId = document.getElementById("x"); yId = document.getElementById("y"); widthId = document.getElementById("width"); heightId = document.getElementById("height");

Copyright © 31 July 2017 Moderro Technologies, Inc. 200

Moderro Interactive Experience Platform

} function start()

{ try

{

// determine port var port = parseInt(portId.value); if(!isNumber(port)) port = -1;

// coordinates var x = parseInt(xId.value); var y = parseInt(yId.value); var width = parseInt(widthId.value); var height = parseInt(heightId.value); var useCoordinates = (isNumber(x) && isNumber(y) && isNumber(width) && isNumber(height));

}

// read-only var ro = roId.checked; alert("Started: " + (useCoordinates ? global.vncserver.start(x, y, width, height, passwordId.value, hostId.value, port, ro) : global.vncserver.start(passwordId.value, hostId.value, port, ro)));

} catch(ex)

{ alert("Exception: " + ex);

} function stop()

{ try

{ alert("Stopped: " + global.vncserver.stop());

} catch(ex)

{ alert("Exception: " + ex);

}

}

</script>

</head>

<body onload="init()">

<div class="note">Protect your connection with a password (leave empty to ignore):</div>

Password: <input id="password" type="text"> <br><br>

201 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

<div class="note">To connect remotely use the following host (leave empty to start locally):</div>

Remote host: <input id="host" type="text"> <br><br>

<div class="note">Connection port (local or remote, 5900 by default):</div> Port:

<input id="port" type="number" min="257" max="65535"> <br><br>

<div class="note">To disallow user activity check the following button:</div>

<input id="ro" type="checkbox"> Read-only <br><br>

<div class="note">To share a rectangle use the following coordinates:</div> x: <input id="x" type="text"> y: <input id="y" type="text"> <br> width:

<input id="width" type="text"> height: <input id="height" type="text"> <br><br>

<div class="note">Start or stop the VNC server with the given parameters:</div>

<button onclick="start()">Start</button>

<button onclick="stop()">Stop</button><br><br>

<div class="note">VNC server status:</div>

<button onclick="alert(global.vncserver.isRunning)">Is running?</button>

<button onclick="alert(global.vncserver.isReadOnly)">Is read-only?</button>

<button onclick="alert(global.vncserver.geometry)">Geometry?</button>

</body>

</html>

global.window Object

The global.window API can be used to manipulate browser windows.

Note

Enter the absolute path in global.window.open().

The following is the global.window object interface implementation: interface Window {

Object open(in string url, in bool isModal

= true, in bool showDecorations = false); bool close(in Object window); bool close(in DomElement e); signals:

} void closed(in string windowObjectName);

Copyright © 31 July 2017 Moderro Technologies, Inc. 202

Moderro Interactive Experience Platform

Variable

open() close() closed()

Table 4-19 global.window Variables

Description

Opens a new browser window. The URL must be a fully qualified

URL; relative URLs are not supported. If showDecorations is false both navigation bar and window title will be hidden.

Closes a window previously opened with the open() method. You can pass to this method either an Object returned from the open() method or any DOM element. In the case of the DOM element, the window that the DOM element belongs to will be closed.

This method is fired when windows opened with the open() method are closed.

New Window Object Interface Implementation

When you open a new window with open() method, you will get a new window object in return. That object has the following interface: interface NewWindow { attribute string objectName; attribute int x; attribute int left; attribute int y; attribute int top; attribute int width; attribute int height;

}

Variable

objectName x, left y, top width height

Table 4-20 NewWindow Variables

Description

Name of the object: This name will be passed to closed() signal of global.window object when some window is closed. It is an empty string by default. It can be any string. Duplicates are not checked.

Horizontal position of the window

Vertical position of the window

Window width: If you have window decorations visible in your new window or if you have the debug panel enabled there, you are not able to make your window smaller then the minimum size of those decorations.

Window height

203 Copyright © 31 July 2017 Moderro Technologies, Inc.

Moderro Interactive Experience Platform

The following HTML contains an example of global.window usage

(file.../../test/js/global-window.html):

<html>

<head>

<title>..:: global .window API test ::..</title>

<styl e> body

{ margin: 0;

}

</style>

<script language="JavaScript"> var display; var lastWindow; var nextId =

0; function openWindow()

{ lastWindow = global.window.open("test/js/global-window-content.html", false , true) ; lastWindow.objectName = "window-" + (++nextId); display.innerHTML = "Window ’" + lastWindow.objectName + "’ opened."; lastWindow.x = 100; lastWindow.y = 100; lastWindow.width = 600; lastWindow.height = 600; global .system.info("New window geometry is ("

+ lastWindow.width

+ ’x’

+ lastWindow.height

+ ’+’

+ lastWindow.x

+ ’+’

+ lastWindow.y

+ ").");

} function closeWindow()

{ global .window.close(lastWindow);

} function onWindowClosed(windowName)

{ display.innerHTML = "Window ’" + windowName + "’ closed.";

} function init ()

{ display = document.getElementById("display"); global .window.closed.connect(onWindowClosed);

}

</script>

<body onload="init()">

<div id="display">Status</div>

<a href="javascript:openWindow()">Open new window</a>

<br />

Copyright © 31 July 2017 Moderro Technologies, Inc. 204

Moderro Interactive Experience Platform

<a href="javascript:closeWindow()">Close last opened window</a>

</body>

</html>

The following is usage of global.window for new window content (file

../../test/js/global-window-content.html):

<html>

<head>

<title>..:: global .window API test (new window) ::..</title>

<styl e> body

{ margin: 0;

}

</style>

<script language="JavaScript"> function closeWindow()

{ global .window.close(document.documentElement);

}

</script>

<body>

<a href="javascript:closeWindow()">Close this window</a>

</body>

</html>

Copyright © 31 July 2017 Moderro Technologies, Inc. 205

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
