LABEL PRINTER

Operator’s Manual

PREFACE

This manual explains how to operate and control the IP48Win Label Printer so that you can use and maintain the printer in an optimal fashion.

Before attempting to use the printer, be sure to read this manual all of the way through. Keep this manual and the Unpacking Instructions that are packaged with the printer in a safe place for future reference.

In order to use this printer with a personal computer, the printer must be connected to the personal computer via a SCSI interface.

The requirements for using a SCSI interface are as follows:

You must use an Adaptec SCSI host adapter.

Models: AHA-1510B, AHA-1520B,AHA-1522B, APA-1460A

Adaptec's EZ-SCSI software must be installed in Windows before

installing the Printer Driver.

For information on how to install the printer driver and on how to use the printer driver to set functions, refer to the Setup Guide that is packed with the printer.

Note that due to our continuing efforts to improve and refine our products, the descriptions and illustrations provided in this manual may differ slightly from your printer.

"Windows" is a registered trademarks of Microsoft Corporation of the U.S.

"Adaptec" is a registered trademark of Adaptec, Inc.

"AHA" and "EZ-SCSI" are trademarks of Adaptec, Inc.

Other product names and company names that appear in this manual are

trademarks or registered trademarks of their respective owners.

CONTENTS

................................

................................

.............. 1111

................................

................................

................................

.....................

2-1. C

HECKING THE

P

ACKING

L

IST

............................................................................................ 2

2-2. R

EMOVING THE

P

ROTECTIVE

D

EVICES ON THE

P

RINTER

................................................... 3

3. INSTALLATION ENVIRONMENT AND POWER SUPPLY CONNECTIONS ...............

3-1. I

NSTALLATION

E

NVIRONMENT

........................................................................................... 4

3-2. G

ROUND AND

P

OWER

S

UPPLY

C

ONNECTIONS

.................................................................... 5

3-3. A

TTACHING THE

O

UTPUT

P

APER

G

UIDE

............................................................................ 6

................................

................................

................................

................ 7777

4-1. N

OTES ON

H

ANDLING

......................................................................................................... 7

4-2. N

OTE ON

U

SING

L

ABELS

/T

AGS

........................................................................................... 7

................................

................................

5-1. N

AMES OF

P

ARTS

................................................................................................................ 8

5-2. F

RONT

C

ONTROL

P

ANEL

..................................................................................................... 9

5-3. P

APER

D

ETECTION

S

ENSORS

.............................................................................................. 9

................................

................

6-1. P

RINTER

I

NITIALIZATION

O

PERATION

.............................................................................. 10

6-2. S

ETTING THE

DIP S

WITCHES THE

R

EAR OF THE

P

RINTER

(S

ETTING THE

SCSI ID)........ 10

6-3. C

ONNECTING THE

SCSI T

ERMINATOR

............................................................................. 11

7. LOADING LABELS/TAGS ................................

................................

...............................

................................

................................

................................

.........

8-1. L

OADING

R

IBBON

.............................................................................................................. 15

8-2. R

EPLACING

R

IBBON

.......................................................................................................... 18

................................

.........................

................................

................................

................................

...........

................................

................................

11-1. C

LEANING THE

I

NSIDE OF THE

P

RINTER

........................................................................ 21

Cleaning the Paper Guide.................................................................................................. 22

Cleaning the Platen Roller................................................................................................. 22

Cleaning the Paper Sensors............................................................................................... 23

Cleaning the Ribbon Peeler and the Ribbon Take-up Bar............................................... 23

Cleaning the Thermal Head............................................................................................... 24

11-2. R

EMOVING THE

I

NTERRUPTIVE

-

TYPE

C

ENTER

S

ENSOR

................................................. 25

................................

................................

12-1. R

EPLACING THE

T

HERMAL

H

EAD

................................................................................... 27

12-2. R

EPLACING THE

P

LATEN

R

OLLER

................................................................................... 29

12-3. R

EPLACING

F

USE

............................................................................................................ 30

................................

................................

................................

APPENDIX A. BASIC SPECIFICATIONS ................................

................................

..........

................................

................................

................................

..................

R

ECOMMENDED

S

PECIFICATIONS FOR

C

ONSUMABLE

.............................................................. 34

................................

................................

............

APPENDIX E. LABEL SPECIFICATIONS ................................

................................

.........

1. L

AYOUT OF PAGE DETECTION AREAS

.................................................................................... 36

2. M

ISCELLANEOUS

(P

RINTING

A

REA

)..................................................................................... 37

1. Organization of This Manual

l Read this manual from the beginning. Read the cautions, notes, and Chapters

3 and 4 in particular very carefully before using the printer.

l Unpacking (Chapter 2)

This chapter provides instructions for unpacking, and describes the items included with the printer.

l Installation (Chapter 3)

This chapter explains points that require special attention when setting up the printer.

l Cautions Concerning Use (Chapter 4)

This chapter provides cautions concerning the handling of the printer and the use of labels/tags.

l Description of Parts (Chapter 5)

This chapter explains the names of the parts of the printer and how to operate the front control panel.

l Functions (Chapter 6)

This chapter explains the initial settings of the printer, and tasks that must be performed each time the labels/tags are replaced.

l Loading labels/tags and ribbon, and changing the thermal head pressure

(Chapters 7, 8, and 9)

This chapter explains how to load labels/tags and ribbon, and how to change the thermal head pressure. (Use the specified labels/tags and ribbon.) l Test printing (Chapter 10)

This chapter explains the test printing procedure. Test printing is used to determine whether a problem lies with hardware or software. It is also used to check printing quality.

l Maintenance and inspections (Chapter 11)

This chapter explains how to clean each section of the printer. Periodic and proper cleaning of the printer will enable you to use it in optimal condition for a long time.

l Component replacement (Chapters 12)

This chapter explains how to replace the thermal head, platen roller, and fuse.

l Troubleshooting (Chapter 13)

This chapter explains how to resolve problems.

1

2. Unpacking

Detailed illustrations are provided in the "Unpacking Instructions" that are included in the carton.

Open the outer carton, and remove the accessories and padding material.

Lift the printer up and out of the outer carton.

Carry the printer carefully in both hands with it leaning against your body, and gently place it on a desk or table.

Remove the vinyl bag and the packet of silica gel.

Fig.01

Caution:

2-1. Checking the Packing List

provided in the "Unpacking Instructions" that are included in the carton.)

Main unit

Two ribbon roller gear units

One ribbon core

Two roll holder plates

One 3.94"(100mm)-inner diameter paper tube attachment set

One roll holder shaft

One power cord

One spare fuse

One screwdriver

One Operation Manual (this manual)

Unpacking Instructions

Two screw locks

One SCSI terminator

One printer driver floppy disk

One Setup Guide

One output paper guide

2

2-2. Removing the Protective Devices on the Printer

Remove the screws in the locking brackets attached to the top of the printer, and then remove the brackets. Screw the screws back into the printer.

Fig.02

Remove the thermal head protective sheet.

Thermal head protective sheet

Fig. 03

3

3. Installation Environment and Power Supply

Connections

3-1. Installation Environment

l Select a stable location where the printer can be installed with plenty of room.

In order to get the maximum performance from the printer and in order to ensure safe usage, keep the following points in mind.

l In order to make it easier to operate and inspect the printer, allow for plenty of space around the printer. A space of 6"(150mm) or more should on the left side of the printer in particular should be kept free of obstacles.

l The printer should be used in a dust- and dirt-free environment.

l Make sure that the power supply that is input to the printer is not subjected to large, temporary fluctuations in voltage or current, and that the printer is not subjected to broad-band noise or electrostatic discharge.

l Install the printer in a location that is not exposed to direct sunlight and is not subjected to rapid changes in temperature and humidity.

l When connecting the power cord, be sure to connect the ground.

l Do not install the printer in a location that is subject to vibration.

l Install the printer as far away as possible from radios and television sets.

Caution:

When installing the printer, make sure that at least 6"(150mm) or more area on the left side of the printer is free of obstructions, as shown in the diagram at right. If this clearance is not provided, there is a danger that the printer could fall from the desk or table when the cover is opened.

Caution:

When installing or moving the printer, tilt the printer towards yourself, insert your fingers in the space under the printer and lift the printer from the bottom.

Fig.04

The dimensions and weight of the printer are as follows:

Width: 11.42"(290mm), Depth: 14.96"(380mm) including the built-in roll holder,

Height: 12.99"(330mm), Weight: 41.8lbs(19kg)

The operating temperature and humidity requirements are as follows:

Operating temperature: 41

°

to 95

°

F(5

°

to 35

°

C)

Operating humidity: 10 to 85% (with no condensation)

4

3-2. Ground and Power Supply Connections

In order to assure safe operation, observe the following cautions: l In order to avoid damage from electrostatic discharge, lightning strikes, leak current, etc., be sure to connect the ground before connecting the power supply.

Do not use a gas pipe as a ground. Doing so could result in a fire, gas explosion, or damage to the equipment.

l The outlet that is used for the printer should be used only for the printer.

Using a multi-outlet adapter or extension cord can result in a fire or in mis-operation.

l Stepping on or pressing on the power cord can result in an accident, such as a fire or electric shock. Be careful not to crush the cord, especially when moving desks, etc.

l Make sure that the power cord is plugged in as far as it will go. Do not use a loose outlet, which can result in a poor connection. Such an outlet could cause a fire. If you will not be using the printer for an extended period of time, unplug the power cord from the outlet.

5

3-3. Attaching the Output Paper Guide

Remove the output paper guide from the carton. Check for the output paper guide notches in the upper part of the form ejection opening (on the left and right sides) in the bottom cover. Then insert the beveled edge of the output paper guide into the opening with the left and right corners facing up.

Output paper guide Upper part of the from ejection opening

Beveled edge Bottom cover

Fig.05

Push the output paper guide in until the left and right corners touch the stoppers on the notches and the output paper guide clicks into place.

Output paper guide

Fig.06

6

4. Notes on Use

4-1. Notes on Handling

l Do not move or carry the printer while it is printing.

l This printer does not have a waterproof construction.

Do not spill water or other liquids on it.

l Use a shielded cable for the interface cable. If an unshielded cable is used, it is possible that noise will be generated on nearby television sets and radios.

l Whenever plugging in any connectors, be sure to turn the power off first.

l Whenever plugging in or unplugging the power cord, always grasp the plug, not the cord.

l Do not modify the printer or remove any components.

l If you suspect a malfunction or other abnormality (such as abnormal odors, heat, or sounds), turn off the power immediately, unplug the power cord, and contact your service representative. Do not continue to use the printer if it has malfunctioned or if any other abnormality has occurred.

4-2. Note on Using Labels/Tags

l Label rolls and ribbon rolls

Store unused label rolls or ribbon rolls in a cool dark place, such as a desk drawer. When using a tag roll, use one that is wound with the tags on the inside.

7

5. Descriptions of Parts

5-1. Names of Parts

Front cover

Form ejection opening

Front control panel

Power switch

Rear DIP switches

Fig. 07 Front View

Fuse holder

Power connector

SCSI interface connector

Fig. 08 Rear View

8

5-2. Front Control Panel

Each of the functions of the front control panel are described below.

Fig. 09

5-3. Paper Detection Sensors

Power

This indicates whether printer power is on or off. This lamp lights when the power is on.

Error

Off: The printer is in the "ready" state.

Blinking: The printer is in the "paused" state.

On: The printer is in the "error" state.

The printer beeps continuously while it is in this state.

Pause

Use this switch to select between the "ready" state and the "paused" state. Each time this switch is pressed, the Error lamp switches between blinking and being off.

Feed

Each time this switch is pressed, the printer feeds forward one page of labels.

Fig. 10

Reflective sensor (movable)

This sensor can detect "eye" marks on the back of forms, and notches in the edge of forms. (This sensor provides paper feed accuracy that is inferior to that of sensor below.)

Interruptive-type center sensor (fixed)

This sensor detects gaps between forms

(breaks in the backing paper) and detects center holes. (This sensor provides the best paper feed accuracy.)

Interruptive-type form edge sensor

(movable)

This sensor detects gaps between forms

(breaks in the backing paper), and notches in the edge of forms. (This sensor provides paper feed accuracy that is inferior to that of sensor 2 above.)

9

6. Description of Functions of Each Section

6-1. Printer Initialization Operation

When the power is turned on, after the hardware completes initialization, the printer performs a thermal head check (checking for disconnected wires). While the thermal head check is in progress, the Error LED flashes at one second intervals and the printer beeps intermittently. When the Error LED turns off and the beeping stops, the printer has completed the initialization operation.

6-2. Setting the DIP Switches the Rear of the Printer (Setting the

SCSI ID)

1. Setting the SCSI ID

The SCSI ID is set through the DIP switches on the rear of the printer.

When the printer is shipped from the factory, the SCSI ID is set to "2".

When connecting just the printer, or when "2" is not the SCSI ID of any other

SCSI device, there is no need to change the setting of the SCSI ID on the printer.

If the SCSI ID of another SCSI device is also "2," it is necessary to set the SCSI

IDs so that each device has a unique SCSI ID.

SCSI ID correspondence table

DIP SW 1

SCSI ID No. 0 OFF

3

4

1

2

OFF

OFF

OFF

ON

5

6

7

ON

ON

ON

2

OFF

OFF

ON

ON

OFF

OFF

ON

ON

3

OFF

ON

OFF

ON

OFF

ON

OFF

ON

Factory setting

2. Setting the parity

DIP switch 4 ON: Parity on

DIP switch 4 OFF: Parity off

3. Forms mode during printing

DIP switch 6 OFF: Label marker detection

DIP switch 6 ON: Continuous paper

Factory setting

Factory setting

4. Miscellaneous

DIP switch 5 ON: .

(Always leave this switch on.) Factory setting

10

6-3. Connecting the SCSI Terminator

l If the only SCSI device that is connected to the computer is a printer, connect the SCSI terminator to the printer. It does not matter if the SCSI terminator is connected to the top or bottom connector.

l If multiple SCSI devices are connected to the computer:

Connect the SCSI terminator to the last device in the chain of SCSI devices connected to the computer. For details, read the manual provided with the

SCSI host adapter, and the Setup Guide.

When turning on the power, turn on each of the SCSI devices first, including the printer. When turning the power off, turn off the computer first, and then turn off the SCSI devices.

SCSI Terminator

Fig. 11

11

7. Loading Labels/Tags

This printer can print on certain types of labels and tags. Note that if other labels or tags are used, it might not be possible to print on them properly.

Place the label/tag roll on the roll holder plate.

Roll holder plates label/tag roll Roll holder shaft

l

Fig. 12

Fig. 13

There is a scale on the roll holder shaft. Line up the label/tag roll so that it is positioned at the center of the scale.

12

Open the upper cover, and place the left and right ends of the roll holder shaft in the shaft holders on the printer.

When loading or replacing labels/tags, the roll holder plates fall off of the core of the label/tag roll, so be sure to hold the roll holder plates in place with both hands when loading the labels/tags into the printer. Dropping one of the roll holder plates on the thermal head can damage the head.

Shaft

Shaft holder

Fig. 14

Spread the paper guides wider than the width of the label, and then load the labels/tags by threading them through the paper guide and the sensors, until the labels/tags reach the platen roller.

Push the paper guides towards the center until they touch both edges of the label.

Close the top cover.

Platen Interruptive-type center sensor

Interruptive-type form edge sensor

Paper guides

Fig. 15

13

l φ 3.94"(φ 100mm)-inner diameter paper tube attachment

When using a roll that has a φ 3.94"(φ 100mm)-inner diameter paper tube, install the attachments provided on the roll holder plates with the screw locks.

Attachment

Roll holder plate

Screw locks

Fig. 16

14

8. Loading Ribbon

8-1. Loading Ribbon

the center of the ribbon roller gear unit.

Ribbon roller gear unit

Ribbon core

Open the top cover of the printer.

Top cover

Fig. 17

Fig. 18

15

the new ribbon core is positioned at the center of the ribbon roller gear unit, just as in step ①.

Supply ribbon

Fig. 19

Take the ribbon roller gear unit with a ribbon core on it that was prepared in step 1, and place it in the v-shaped notches on the top cover. Then lift up the leader tape on the supply ribbon and attach it to the ribbon core.

Ribbon core

Fig. 20

Caution:

The thermal head may be hot. When loading a ribbon, be careful not to touch the thermal head.

16

Push the roller gear unit (the one with the ribbon core on it and the leader tape attached) into the take-up ribbon shaft holder on the top cover until the roller gear unit clicks into place.

Take-up ribbon shaft holder

Fig. 21

Turn the take-up knob counterclockwise to take up the slack in the ribbon.

Take-up knob

Fig. 22

17

8-2. Replacing Ribbon

ribbon shaft holder on the top cover of the printer.

Used ribbon

Fig. 23

Pull out the ribbon roller gear unit from the used ribbon.

Ribbon roller gear unit

Fig. 24

Use the empty supply ribbon core as the next take-up ribbon core.

18

9. Changing the Thermal Head Pressure

Caution:

l Turn the power off before performing this procedure.

l Note that the thermal head may still be hot even if the power has been turned off. This warning label is located near the thermal head.

of the thermal head with your finger and insert the thermal head pressure changing plate under the two discs.

Thermal head pressure changing plate

Fig. 25

If the labels are 2"(50mm) or more wide, hold down the heating element side of the thermal head with your finger and remove the thermal head pressure changing plate under the two discs.

Thermal head pressure changing plate

Fig. 26

19

10. Test Printing

The test printing procedure is described below. When installing the printer, always be sure to perform a test print once before connecting the printer to the computer.

l Confirm that the form mode is "continuous form" mode. (DIP switch 6 on the back of the printer should be "ON.") l Load 3.94"(100mm)-wide continuous forms (normal paper of coated paper) and 4.72"(120mm)-wide recommended ribbon(Wax/resin type) into the printer.

l To execute a test print, hold down the "Feed" button on the front panel and then turn on the power.

l To end the test, press the "Pause" switch and then turn the power off.

l The start of the test print checks the thermal head for abnormalities. 10mil and 5mil patterns are printed on the first page, and demo printing patterns are printed on the second and subsequent pages.

Test printing examples

10mil pattern

Demo printing pattern

20

11. Maintenance and Inspection

In order to keep the printer operating in peak condition for a long time, be sure to perform the maintenance and inspections described below. If these maintenance and inspection procedures are not performed, the printer will not be covered by its warranty.

Caution:

l When performing maintenance and inspections, be sure to turn both the printer and the computer off, and disconnect the power cords from the power outlets.

l Use isopropyl alcohol, methanol, or ethanol to clean the thermal head, platen rollers, and form sensors. Using other solvents could damage the components. Handle isopropyl alcohol and methanol carefully, as both are flammable. Also, do not attempt to clean the thermal head while it is hot.

Use a clean and previously unused cloth when cleaning.

Never use chemical cleaning cloths.

If you will be touching the inside of the printer, remove any precious

Be careful not to scratch the thermal head with any metallic buttons, rings, bracelets, or other metallic objects.

Do not apply any lubricants to any part of the printer. Lubricants are applied at the factory, and do not need to be applied by the user.

Do not spray solvents, cleansers, or other such materials on or near the printer. Doing so could damage the printer.

11-1. Cleaning the Inside of the Printer

Caution:

Be certain to turn the power off first.

The inside of the printer should be cleaned after every 985ft(300m) of labels. (In other words, after using one standard 985ft ribbon.)

Clean the following locations:

Paper guide, platen roller, paper sensors, ribbon peeler (the stainless cover), ribbon take-up bar, and thermal head.

Turn the power off, disconnect the power cord from the power outlet, open the top cover of the printer, remove the labels and ribbon, and then clean the locations listed above with a clean cloth dampened with isopropyl alcohol, methanol, or ethanol.

21

Cleaning the Paper Guide

Fig. 27

Cleaning the Platen Roller

Clean while turning the gears manually.

Fig. 28

22

Cleaning the Paper Sensors

The sensor located between the paper guide and the platen roller through which the labels pass is a Interruptive-type sensor. Pass a cloth dampened with alcohol through the region where the labels pass and then move the cloth back and forth several times to clean the sensor.

Fig. 29

Cleaning the Ribbon Peeler and the Ribbon Take-up Bar

Ribbon peeler

Ribbon take-up bar

Fig. 30

23

Cleaning the Thermal Head

Fig.31

Caution:

Note that the thermal head may still be hot even if the power has been turned off.

the thermal head.

24

11-2. Removing the Interruptive-type Center Sensor

If a label accidentally sticks to the bottom portion (tunnel portion) of the

Interruptive-type center sensor, remove the Interruptive-type center sensor as described below and remove the label.

Use a coin to remove the left and right screws holding the Interruptive-type center sensor in place.

Interruptive-type center sensor

Screw

Fig. 32

Remove the Interruptive-type center sensor unit and then remove the label.

Fig. 33

Re-attach the Interruptive-type center sensor unit by reversing step

, and then use a coin to tighten the left and right screws.

25

12. Replacing Components

After being used for a long period of time, the thermal head may reach the end of its operational life, which will manifest itself through a deterioration in print quality resulting from broken wiring in the thermal head (resulting in white vertical lines), blurred bar codes and text, etc. It is then necessary to replace the thermal head in order to maintain the print quality. The thermal head replacement procedure is described below. (The thermal head is considered to be a consumable component.)

Turn the power switch off, open the top cover, and remove the ribbon on the take-up side.

Caution:

Note that the thermal head may still be hot even if the power has been turned off.

This warning label is located near

the thermal head.

Press the left and right release levers, and remove the thermal head.

Release levers

Fig. 34

26

12-1. Replacing the Thermal Head

Disconnect the two connectors on the thermal head. After disconnecting them, remove the thermal head from the printer.

Connectors

Fig. 35

Being careful not to scratch it, connect the connectors to the new thermal head.

Fig. 36

27

After setting the thermal head bracket into the guide holes in the printer, push the thermal head in until it locks in place.

When doing so, be careful not to bend the ribbon peeler.

Guide holes in printer

Fig. 37 l thermal head, or get it dirty.

l element surface with your fingers. Sweat on your fingers will contain salt,

28

12-2. Replacing the Platen Roller

After being used for a long period of time, wear on the platen roller may result in a deterioration in print quality, such as blurred bar codes and text, etc. It is then necessary to replace the platen roller in order to maintain the print quality. The platen roller replacement procedure is described below. (The platen roller is considered to be a consumable component.)

Press down the release levers at the left and right ends of the platen roller and remove the platen roller. (Remove the end with the gears first.)

Release levers

Gear

Install the new platen roller.

Fig. 38

Fig. 39

29

12-3. Replacing Fuse

Using a coin, turn the fuse holder cap counterclockwise and pull out the fuse.

Fig. 40

After removing the old fuse, push a new fuse into place. (One replacement fuse is included with the printer.)

Caution:

Replace the fuse only with the a fuse of the same type and ratings. Using a different fuse could result in a fire. The ratings for the fuse are: 3.15A time lag, 125V AC or 1.6A time lag, 250V AC.

Fig. 41

30

13. Troubleshooting

This chapter explains what to check when the printer does not operate correctly, and what steps to take to resolve the problem.

Cannot perform test print.

Printer does not print.

The print quality is poor.

The "Feed" switch was

not pressed.

Either the ribbon was loaded backwards, or no ribbon has been loaded.

The power is not on.

Hold down the "Feed" switch while turning the power on.

Load the ribbon so that the inked surface (the front surface) is facing to the outside.

Connect the power cord and turn the power on.

Replace the I/F cable.

The I/F cable is not connected correctly, or there is a broken wire.

The selected label and/or ribbon types or the selected density is incorrect.

The printer is in the

paused state.

The label and/or ribbon materials are not normal.

Label and/or ribbon different from that which is specified is being used.

The platen roller is worn.

The thermal head has reached the end of its operational life.

The ribbon is wrinkled.

Set the label and ribbon types and density selections to suitable values.

Push the Pause switch so that the Error LED is off.

Increase the printing density.

Change to the specified label and ribbon supplies.

Replace the platen roller.

Replace the thermal head.

The ribbon is loaded at an angle.

The selected label and/or ribbon types or the selected density is incorrect.

The paper guides are not positioned properly.

Reload the ribbon so that there are no wrinkles.

Reload the ribbon correctly.

Set the label and ribbon types and density selections

to suitable values.

Set the paper guides so that they just touch the paper guides and so that there are no gaps between the paper guides and the paper.

31

Appendix A.

Basic Specifications

1. Printing method:

2. Dot density:

3. Printing speed:

5. Maximum printing width:

6. Maximum printing length:

7. Paper width:

8. Page length:

9. Paper thickness:

10.Internal paper roll:

Thermal transfer method

400 dpi (15.75 dots/mm)

0.5"/sec. to 4.0"/sec.(13mm/sec to 100mm/sec)

3.84"(97.54mm)

12.00"(304.8mm)

0.98" to 4.33"(25mm to 110mm)

0.19" to 12.00"(5mm to 304.8mm)

0.005" to 0.01"(0.12mmto 0.25mm)

(1) Winding direction : Printing surface outside/inside

(2) Paper roll outer

diameter

:

φ

7.08"(

φ

180mm) or less

(3) Paper tube inner

diameter

:

φ

3.0"(

φ

76.2mm)

and φ 3.93"

( φ 100mm)

(when using the

φ

3.93"diameter attachment provided)

11.Fanfold forms:

12.Paper sensor types:

13.Ribbon width:

14.Supply ribbon roll

15.Host interface:

16.Weight:

17.Input power:

18. Operating temperature and humidity requirements:

19.Options

-1. External roll holder:

Page pitch quality is not guaranteed in a

0.08"(2mm) region before and after perforations.

Detects notches in the forms (1) Interruptive-type form edge sensor

(movable)

(2) Reflective sensor (movable) Detects "eye" marks

(3) Interruptive-type center sensors (fixed) Detects backing paper and center hole. A blue backing paper is recommended for (1) and (3).

1. 97" to 4.72"

(50 to 120mm)

(1) Winding direction:

(2) Paper tube inner

diameter:

(3) Length of ending

silver tape:

: 2.76"(70mm) or more

Ink on the outside

φ 1.0" ( φ 25.4)

Fanfold forms are placed outside the printer. Print

At least 0.39"(10mm) wider than the forms.

5.91" (150mm) or more

φ 2.76"( φ 70mm) diameter or less (4) Winding

dimensions:

(5) Ribbon length:

SCSI conforming

41.8lbs(19kg)

120, 220, 230V AC, available

41 to 95

°

F(5 to 35

°

C),

10 to 85% RH

985ft(300m) : reference value

50/60 Hz

Field option Model number: RH-63

Roll diameter: No more than

φ

9.84"(

φ

250mm)

-2. Cutter: Factory option

32

Appendix B.

Interface

The SCSI communications ports are located on the right rear side of the printer.

The signal assignments for the two SCSI connectors are shown below.

No. Signal name No. Signal name No. Signal name No. Signal name

8

9

6

7

3

4

1

2

5

10

11

12

13

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

26

27

28

29

30

31

32

33

34

35

36

37

DB0

DB1

DB2

DB3

DB4

DB5

DB6

DB7

DB8

GND

GND

GND

38 TERMPWR

14

15

16

17

18

19

20

21

22

23

24

25

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

39

40

41

42

43

44

45

46

47

48

49

50

GND

GND

ATN

GND

BSY

ACK

RST

MSG

SEL

C/D

REQ

I/O

The connector is the centronics half 50pin.

Electrical requirements

The transmission system is considered to be a single-end system, and the electrical requirements concerning the SCSI bus I/O characteristics and timing characteristics conform with SCSI (Small Computer System Interface -

ANSI X3.131-1986 and JIS X 6051-1990/ISO 9316-1989).

However, the operating characteristics are stipulated only for the case where the printer is a target. The printer supplies terminator power.

33

Appendix C.

Specifications for Consumable

Recommended Specifications for Consumable

Labels/ribbons

1 Wood free paper

2 Coated paper

3 Synthetic paper

4

5

PET(Silver)

PET(White)

#3037,

B110A

#3037,

B110A

SD622.5,

B110A

B110C

B110C

B110C

General purpose

General-purpose

Water resistant, paper dust resistant

Water resistant, paper dust resistant, smearing resistant

Heat resistant, solvent resistant

Heat resistant, solvent resistant

1. Using non-recommended labels or ribbons can result in problems such as poor print quality, paper jams, and thermal head damage.

2. Selecting the right label and ribbon for each application requires specialized knowledge about label, adhesives, etc. When purchasing

Thermal head

A warranty period applies to the thermal head. Contact your dealer.

34

Appendix D: List of Accessories

Two ribbon roller gear units

• One ribbon core

Two roll holder plates

• One φ 3.94"( φ 100mm)-inner diameter paper tube attachment set

One roll holder shaft

• One power cord

One spare fuse

• One screwdriver

One Operation Manual (this manual)

• Unpacking Instructions

Two screw locks

• One SCSI terminator

One printer driver floppy disk

• One Setup Guide

One output paper guide

35

Appendix E.

Label specifications

1.

Layout of page detection areas

(1) Backing paper

Dimensions: 0.24"(6mm):W or more

×

0.08"(2mm) to 0.20"(5mm):H

Backing paper of 0.24"(6mm):W or more

×

0.08"(2mm) to 0.20"(5mm):H, must enter the region indicated by the dotted line in the illustration at right, and the edge of the backing paper must be no more than 0.24"(6mm) wide.

(2) Notches

Detection is possible by the type form edge sensor

Interruptive-

if there are notches in the left edge of the forms (looking from the front of the printer) that satisfy the dimensions indicated below:



0.24”(6mm)or less







     0.08”(2mm)or more

0.20”( 5mm) or less







      0.24”(6mm)or more



                            H

    H



        W                   W



Dimensions when page length is less than 2.75"(70mm):

0.24"(6mm):W or more × 0.08"(2mm):H to 0.16"(4mm):H

Dimensions when page length is 70mm or more:

0.24"(6mm):W × 0.08"(2mm):H to 0.47"(12mm):W ×

0.20"( 5mm):H



Back of page

(3) Back-side "eye" marks

Dimensions: 5mm or less

There must be an "eye" mark of 0.47"

(12mm):W or more

×

0.12"(3mm) to 0.20"

(5mm):H within the region indicated by dotted lines in the figure at right.

    55mm   44mm



(4) Center hole

Inner diameter: φ 0.12"(3mm) to

0.20"(5mm)

The center of the hole must be within

0.02"(0.5mm) of the center of the width of the form.

0.12”(3mm)or more 0.20”(5mm)or less

36

2.

Miscellaneous (Printing Area)

Printing must occur within the shaded regions in the illustrations.

(1) Diecut label

Label length up to 3.94"(100mm): 0.06"(1.5mm) or more : in direction of height

Label length over 3.94"(100mm) : 0.10"(2.5mm) or more : in direction of height



Printing Area 0.06”(1.5mm)or more





Label Height



0.08”(2mm) or more

0.08”(2mm) or more



     0.06”(1.5mm) or more



Label width

(2) Other than diecut label

Page length up to 3.94"(100mm):0.06"(1.5mm) or more : in direction of height

Page length over 3.94"(100mm) :0.10"(2.5mm) or more : in direction of height

Printing Area



0.06”(1.5mm)or more







0.08”(2mm)or more   0.08”(2mm)or more

Notched edge



      0.06”(1.5mm)or more



Page width

37

Printed in JAPAN

7C388609A

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
