Level
Pressure
Flow
Solenoid Valves
sensors, controls
and fluidic systems
OUR EXPERIENCE
YOUR SOLUTION
product overview
Our Experience | Your Solution
Gems Sensors & Controls
is a leading manufacturer of a broad
portfolio of liquid level, flow, and pressure sensors, miniature solenoid valves,
solid-state electronics and fluidic systems. Decades of application engineering
experience has given Gems the knowledge required to deliver tailored products
that measure up to today’s most sophisticated and critical applications. Working
around the world with global resources, and to exact customer application and
manufacturing requirements, products from Gems Sensors & Controls are used
in almost every industry from medical to waste water treatment, semiconductor
fabrication to off-highway vehicles and HVACR to food and beverage.
Your Solution Partner
Supporting our customers with the best possible product while reducing time
to market is our One Goal. To achieve it we apply a wealth of tools and global
resources that include:
— A dedicated team of application engineers, with over 50 years of experience,
who specialize in developing custom solutions to meet unique customer
needs
— An extensive portfolio of thousands of proven designs that reduce the time
required to successfully deliver your solution when it’s needed
— A global direct sales force of experts in fluid level, flow and pressure
sensors, controls, solenoid valves and associated fluidic systems
— The resources of Danaher Corporation, a Fortune 500 company; committed
to quality, lean manufacturing, and ISO certification—with facilities in North
America, Europe and Asia
— Dedicated tools and processes that eliminate product and process variation
at every stage of manufacturing, including:
t %FTJHO'BJMVSF.PEF&GGFDU"OBMZTJT%'.&"
t 1SPDFTT'BJMVSF.PEF&GGFDU"OBMZTJT1'.&"
t 1SPDFTT$BQBCJMJUZ4UVEJFT
t (BVHF$BQBCJMJUZ4UVEJFT
t %FTJHO7FSJGJDBUJPOBOE7BMJEBUJPO
t $PSSFDUJWFBOE1SFWFOUBUJWF"DUJPO$"1"
t -FBO5PPMT
t %1SPCMFN4PMWJOH.FUIPEPMPHZ
Our Application Specialists are ready to discuss your system requirements.
Contact us today at one of our global offices listed on the back cover.
Full product details are available at www.GemsSensors.com
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
SOLENOID VALVES | 2
All Gems valves are available with a wide range
of options. Our modular designs can be easily
configured to your specific application. For
products with specifications not shown here
please contact Gems.
General Purpose
Providing 2- and 3-way functions and available in miniature and subminiature sizes, Gems general purpose solenoid valves deliver Flow
Coefficients (Cv) of .018 to .880. Select from NPT port, manifold or barbed
connection types. Body materials include brass, stainless steel, acetal,
aluminum, and polypropylene. Versions within this group will control
operating pressure differentials up to 1000 psi (70 bar).
D
C
Gems General Purpose
Solenoid Valve Series:
M
E
B
G
A
Isolation for High Purity
or Aggressive Fluids
Cryogenic Valves to
-320° F (-196° C)
Available in miniature and sub-miniature
sizes, these units feature a diaphragm
design to isolate the media from the
internal components. Diaphragm materials
include Viton®, EPR, nitrile (NSF/FDA),
perfluoroelastomer and EPDM. Numerous
port configurations, voltage options, and
coil constructions enable Gems Isolation
valves to easily integrate into any complex or
demanding system.
These miniature 2-way valves can be configured
for liquid nitrogen, liquid carbon dioxide and other
extreme temperature media. Teflon® coated
plungers, 316 stainless steel guide tubes and
plunger springs, encapsulated coils, and Teflon® or
Rulon™ seat seals produce a truly robust cryogenic
valve for applications requiring high cycle life in
extreme environments.
KL
KS
Gems Cryogenic Solenoid Valve
Series: B-Cryo and D-Cryo
Pinch Valves
Gems Isolation
Solenoid Valve
Series:
AS
By the nature of their design Gems Pinch Valves
keep fluid separate from the valve operating
mechanism and provide excellent temperature
erature
buffering as well. Gems pinch valves operate
erate on as
little as 2.8 Watts, with fluid pressure ranging
nging 15
to 30 psig (1.03 to 2.07 bar), and
are available with 2-way Normally
Open (NO) and Normally Closed
sed
(NC), or 3-way Directional Control
ontrol
operation. They support tubing
ng up
to 1/4” (6.35mm) O.D..
Gems Pinch Solenoid
Valve Series:
BS
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
3 | LEVEL SENSORS
—
—
Switches
Switches
Electro-Optic
Float
Industry’s largest selection of electro-optic
liquid level sensors is right here at Gems.
Compact design for a small footprint
anywhere space is at a premium. Solidstate switching and no moving parts
ensures dependability over long service life.
Available in a vast range of sizes, mountings and materials, Gems offers the broadest
selection of float-type level switches anywhere. Using a proven reed switch design,
float type switches deliver long, trouble-free service with precise repeatability. They are
available in both single point and multi-point configurations. Multi-point switches
monitor up to six levels with a single unit; lengths from a few inches (centimeters)
to 10 feet (3 m).
multi
multi-point
—
Switches
top or bottom
mounting
single point
®
Warrick
Conductivity
These single- or multi-point
sensors have no moving parts.
Stainless steel electrodes can
be cut to desired length. Team
with Gems conductivity controls
to provide alarm, pump-up or
pump-down
control in
electrically
conductive
liquids.
—
—
includes bent stems,
ms,
slosh shields,
temperature sensing,
ing
ing,
siphon tubes and
many others
Switches
High Purity
Switches
Capacitance
Level Sensors
Gems high purity sensors are
designed for ultra-pure fluid
applications. PTFE and PVDF resist
build-up of foreign material and
sticky media. These high-purity level
sensors come in single, multi-point,
float and electro-optic types.
An excellent choice for turbulent
or coating liquids, Gems offers
multiple solid-state capacitance
e
point level switches, including
non-contact versions that sense
e
liquid level from the outside of
non-metallic vessels. Heavy
duty CAP-300 is designed for
off-highway vehicles and powerr
generator coolant monitoring.
Medical
special purpose
side
mounting
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
LEVEL SENSORS | 4
—
—
Switches/Transmitters
Ultrasonic
Gems ultrasonic switches and transmitters
are ideal for applications requiring solidstate level measurement such as those with
ultrapure, dirty, coating, scaling or corrosivetype liquids. Available in contact and noncontact single point, or multi-point versions.
Up to four actuation levels or continuous
measurement to 26 feet (8 m). Also available
han 4 ft. (1.2 m).
for small tanks less than
Made of polypropylene,
ne,
PVDF, PFA.
—
Pop the cap, pull the tab—and up comes
the tape to tell you exactly how much liquid
remains in the tank or drum. Ideal
for hazardous areas, DIPTAPE and
DRUMTAPE indicators are
non-electric, plus liquids
and vapors remain sealed
from the atmosphere.
DIPTAPE indicators are
designed for tanks;
DRUMTAPE indicators
fit 30 or 55 gallon storage
drums. DIPTAPE and
DRUMTAPE are available
in alloy, all PVC and
engineered plastic
versions.
These robust transmitters
are particularly ideal where
extremely accurate level
measurement is required;
providing accuracy to within
±0.2mm, and a resolution
better than 0.1mm. The
temperature-compensated
signal output is 4 to 20 mA.
These units are available in
lengths ranging from 8˝ to 157˝
7˝
(200 to 6,000 mm). The
HART protocol version
allows dual float tracking,
and the explosion-proof
version enables operation
in Category 1 (Zone 0) or
Category 1/2 environments.
—
Transmitters
Float
This solid-state sensor is an
n
innovative, no-moving-parts
g-parts
solution specificallyy designed
to detect the presence
ce of
water in fuel. The sensor
sor is an
ideal solution for OEM’ss of offhighway vehicles, locomotive
tive
and generator sets. It is also
o
ideal for use with fuel filters,
and in compressor crank
cases to determine if water is
present in lubricating oil.
Sta
Standard
lengths offer measurement
from a few inches (centimeters) to 18
feet (5.
(5.5 m). Choose from a
variety o
of materials for
mountings, stems and
mountings
floats that in
includes PVC,
polypropylene
polypropylene, PVDF,
stainless st
steel, brass
and Bu
Buna N. Signal
conditioning provides
c
outputs of 4-20 mA,
0-5 VDC and 0-12 VDC.
standard size
transmitters
Switches
compact, OEM
transmitters
Non-Intrusive
ve
Visual Level Indicators
SureSite®
WIF-1250
—
Transmitters
Magnorestrictive
DIPTAPE™ and
DRUMTAPE™
—
Switches
—
Indicators
A more durable and safer alternative to
breakable sight glasses. SureSite visual
level indicators feature stainless steel, alloy
or engineered plastic housings that mount
externally to top or sides of
tanks to provide easy-to-read,
continuous level gauging.
Magnetic flags flip to change
color as an internal float
moves with the liquid surface.
Optional switches,
transmitters and
scales increase
control capabilities.
Available in alloy and
engineered plastic.
The ExOsense™ sensor is a
break-through in liquid sensor
ensor
technology. The unique, patented
atented
piezo-resonant transducer and
microprocessor based electronic
onic
control module allow the sensor
or
to accurately detect liquid levelss
non-intrusively from the outside of
plastic bottles. ExOsense virtually
eliminates all concerns over sensorr
compatibility, calibration and liquid
media contamination.
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
5 | PRESSURE SENSORS
—
—
Switches
Piston/Diaphragm
Solid-State
Gems offers a choice of pressure
e switches
switches, from compact cylindrical models for OEM
use, to larger enclosed units for rugged process applications. A piston/diaphragm design,
incorporating the high proof pressure of piston technology allows these switches to operate
with the sensitivity and accuracy of a diaphragm design. Repeatability ranges from 0.2 to
2% of the highest set point. Enclosures include aluminum, stainless steel, baked-on enamel
coating, reinforced plastic and zinc-plated steel. All are NEMA4 or NEMA4X certified.
Utilizing our proven pressur
p
pressure
re sensor and
ASIC design
design, Gems solid st
state pressure
switches offer greater accuracy and
repeatability in high shock and vibration
environments. They also provide an
advantage over electromechanical switches
when actuations exceed 50 cycles/minute
and a broad frequency response is needed.
Available with a large selection of pressure
port and electrical connection options.
s.
—
—
Switches
Transducers
Submersible
Transducers
Capacitive
9500 Series pressure transducers
are designed specifically to meet the
rigorous
orous conditions for ground water
monitoring
onitoring while providing ultimate
performance.
erformance. They feature a true leve
level
el
reading
ading through built in specific gravit
gravity
ty
compensation
ompensation over a 23° F to
113°
13° F (-5° C to 45° C)
temperature
emperature range.
2400
Series
9500
Series
Capacitive transducers are simple, durable and fundamentally stable. Variable capacitor
technology, a rugged physical configuration, stainless steel wetted parts and a careful
marriage of the mechanical assembly to the electronic circuitry combine to create highly
repeatable transducers with low hysteresis and only .5% long-term-drift full scale per year, for
low pressure applications. This large family of sensors includes models for positive pressures
to 10,000 psi (700 bar), absolute vacuums, differential pressures, barometric pressure, low
pressures (0-15 psi/ 0-1 bar), and clean-in-place 3A sanitary applications.
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
The 2400 Series features silicon-based
Micro-Electro-Mechanical
M chanical Systems (MEMS).
Its complete ‘system-on-chip’ enables an
ultra-slim design for bore hole applications.
Both series are impervious to the effects
of water, even in the highest humidity and
long-term submersion.
Power Systems
Semiconductors
PRESSURE SENSORS | 6
—
Transducers
Sputtered Thin Film
Sputtered thin film technology provides years
of worry-free measurements under demanding
real-world conditions. Sputtered metallic strain
gauge sensors have terrific thermal properties
and superior stability specifications. Ideal for
harsh applications demanding long-term service
where precise laboratory-type measurements are
required.
3100/3200 Series
3100 Series — Delivers an output signal for both temperature and
pressure, providing full scale accuracy of 0.25% and long term
drift to just 0.1% over the full scale per year. Unbeatable price to
performance ratio in a compact package.
— 3200 Series — Features thicker diaphragm and pressure snubber to
withstand pressure spikes and cavitation.
—
—
4000 Series — The King of Stability: just 0.06%
drift per year (non-cumulative). A broad range of
models include submersible, high temperature,
and weather proof versions.
—
Transducers
Chemical Vapor
Deposition
2200
Series
2600
Series
3300
Series
Gems Chemical Vapor Deposition (CVD)
pressure transducers and transmitters
are based on a solid, proven technology.
Our CVD instruments provide an effective
method of overcoming the often severe
limitations of other low-cost pressure
measuring products. A state-of-the-art ASIC
chip in each transducer provides greater
linearity correction than traditional thermal
compensation methods.
Thicker Diaphragm
Handles pulsating
pressures—all stainless
steel wetted parts.
—
1200/1600 Series — 4X full-scale proof pressure.
Typical 0.5% full-scale accuracy.
—
2200/2600 Series — 2X full-scale proof pressure.
Typical 0.25% full-scale accuracy.
—
3300 Series — Compact versions for pressures to
600 PSI (41 bar).
—
6000 Series — 5 to 1 turndown. Typical 0.15%
full-scale accuracy.
CVD Sensor
Stability and high sensitivity allow use
of our thicker diaphragm. 17-4 PH
SS sensor beam is laser welded for
distortion-free construction.
ASIC Chip
Programmability provides greater
linearity correction than common
thermal compensation methods.
RFI/EMI & ESD protection circuit
Meets and exceeds requirements for
CE marking. Protecting against noise, voltage
spikes and static discharge.
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
7 | FLOW SENSORS
—
Sensors/Indicators
Electronic
RotorFlow®: These highly visible, paddle wheel
designs offer accurate visual indication, flow rate
sensing and switching. The visual indication is
combined with a choice of either pulsed DC output
0-10V DC analog or adjustable 1 Amp switched
output. Available with brass, stainless steel or
hydrolytically-stable polypropylene housings.
Line sizes: 1/4˝ to 1˝ (.64 to 2.5 cm). Adjustable
settings: 0.1 to 60 GPM (.38 to 227 l/m).
—
Switches
No Moving Parts
TurboFlow®: Ultra-compact TurboFlow®
low flow rate sensors provide continual
measurement ranging from 0.1 to 8 GPM
(0.5 to 30 lpm). Their Hall-effect sensor
delivers accuracy to ±3 % of reading and
0.5 % repeatability. Lightweight, they mount
in any position. Incorporate flow sensing
into custom assemblies with the tiny
TurboFlow® Insert.
Tiny TurboFlow®
insert
FS-600 series features solid-state
thermal dispersion technology
to provide reliable flow switch
operation even without filtration.
They are compatible with both
conductive and non-conductive
fluids. A straight-through
design makes the FS-600
ideally suited for fluids with
particulates or slurries, or
alternating media viscosity.
—
RotorFlow® sensors
—
Switches
Switches
TurboFlow®
sensors
—
Switches
Piston
Paddle
Shuttle
Proven piston switch technology
delivers high repeatability and
precise calibration for liquids or
gases. Fixed setpoints range from
a low 50 cc/min to 1.5 GPM (5.7
l/m); adjustable version features
setting of 0.5 to 20 GPM (2 to 76
l/m). Special capability versions
offer viscosity compensation, and
high pressure handling to 1,500
PSIG (103 bar). Brass, plastic or
stainless steel bodies.
Flow/No-Flow detection for pipes with
1-1/4˝ (3 cm) diameter and up. Paddles are
cut to length for desired actuation setting
(from 1-1/4˝ to 5-1/2˝
(3 to 14 cm). Unique,
patented cam design
assures low pressure
drop and does not
require bellows,
seals or mechanical
linkages.
For monitoring water and oil—in line sizes
3/4˝ to 3˝ (2.5 to 7.6 cm). Accurate with 1%
repeatability and low-pressure drop. Plastic,
bronze, stainless steel and marine grade
housings. Fixed settings from 0.5 to 100
GPM (1.9 to 378.5 l/m); adjustable settings
from 0.75 to 15 GPM
(2.8 to 56.8 l/m).
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
CONTROLS | 8
—
—
Solid-State
Intrinsically Safe Relays and Controls
Render any non-voltage-producing sensor, switch or conductivity electrode intrinsically safe
with these relays and barriers from Gems. They amplify sensor load-handling capabilities
in a wide range of AC and DC control switching applications. They are designed for easy
installation in standard circuit boxes in non-hazardous areas. The amount of energy they send
to sensors and switches within hazardous areas is insufficient to cause ignition of a specific
hazardous atmospheric mixture in its most ignitible concentration.
In addition to safety, they offer great
economy by reducing your need for
costly explosion-proof sensors, switches,
controls and housings. Solid-state reliability
assures consistent performance, and with a
completely encapsulated construction they
are impervious to dust, moisture or foreign
material. Select from a broad choice of SafePak® and Warrick models.
Warrick®
Series 17/27
conductivity
level control
Warrick®
Series 47
4-channel
relay alarm
panel control
Standard Relays and
Conductivity Level
Controls
These relays boost your sensor’s load
handling ability in non-hazardous locations
with the reliability and advantages inherent
in solid-state controls. Available with plug-in
bases, open board or threaded terminals.
Warrick®
Series 16/26M
SAFE-PAK® relays
& Zener barriers
Warrick®
Dual Function
on
Series DF
—
—
Solid-State
Transmitters
Receivers
Electrical
Standard and Custom
Warrick® Panels
Gems manufactures both custom
and standard control panels, bearing
the safety mark of UL or CSA, for
use in hazardous (UL 913) and nonhazardous (UL 508A) locations. We
offer a complete selection of controls
including solid-state relays, timers,
alternators, transformers, alarms,
indicator lights and more.
DMS-470/570 Series
Your sensors know
what’s going on, but
you’re still in the dark
without one of Gems
receivers. Each
receiver features
all the calibration
adjustments needed
to complete a
continuous level
indication system.
Some available
compact level
with relay output
cubes and panel
switching.
mounted receivers
RA-431
alarm panel
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
9 | Custom Modification & Sub-Assemblies
This brochure provides a broad overview of the range of Gems products. We offer
thousands of variations of the fluid sensors and controls seen within, and for many
more not included here. We’re proud of the wide array of these products, yet we
know that no matter how many variations we manufacture, what is a “Standard”
product may not be exactly what you need.
Always keep in mind that since day one, Gems has been ready to modify a
component to deliver the specific needs of performance and installation improvement
nt
to meet customer needs.
Our Sales, Engineering and Manufacturing groups, along with Application Specialists
ts
work daily with customers to customize our current products and to develop new
components, sub-assemblies and complete fluid systems. We’ll do the same for you.
ou.
Customization includes:
— Wetted and Non-Wetted Materials: Alloys and Engineered Plastics
— Electrical Terminations of All Types
— Port Sizes, Fittings and Other Installation Methods
— Sub-assembly Design and Manufacturing
— Integrated Sensor and Control Modules
When you don’t see exactly what you need, or your manufacturing process would
benefit from a supplied sub-assembly incorporating Gems components, simply let us
know. We turn your “wish lists” into reality.
Solutions Engineeering
Gems is dedicated to lean manufacturing and understands
the critical need for a robust quality system that includes the
right documentation, supplier qualification and ISO certification
to meet the demanding requirements of the most specialized
industries. With manufacturing facilities in the US, Europe and
Asia, our global presence reduces lead-times and allows Gems
to cost effectively ship ready-to-use systems throughout the
world, exactly when customers request delivery.
With more than 50 years of engineering and application
experience, a broad portfolio of key products, lean
manufacturing tools and quality systems, Gems has one goal:
To enable our customers to get to market fast with the best
possible solution
Gems experience and passion for providing solutions to OEMs
produces further benefits to our customers, including:
— Collaborative Engineering
— Reduced Development Costs
— Quicker Time to Market
— Reduced Supplier Base
GemsSensors.com
— Managed Inventory
Medical
OHV
Water
HVAC
Marine
Transport
Food
Oil and Gas
Power Systems
Semiconductors
North America
Gems Sensors & Controls,
One Cowles Road, Plainville, CT 06062-1198
Tel: +1 860 747 3000
Fax: +1 860 747 4244
Email: [email protected]
Europe
Gems Sensors & Controls,
Lennox Road,
Basingstoke, Hampshire, RG22 4AW
Tel: +44 (0)1256 320244
Fax: +44 (0)1256 473680
Email: [email protected]
Asia
Danaher Setra-ICG(Tianjin) Co.,Ltd.
28 Weiwu Road
Micro-electronics Industrial Park
Jingang Highway Xiqing District Tianjin
300385
China
Tel: +86-22-83988098
Fax: +86-22-83988099
Email: [email protected]
OUR EXPERIENCE
#801 - 30M - 9/12
YOUR SOLUTION
www.gemssensors.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
