DATA SHEET
1 /5
E-CORE LED TRACKLIGHT 1200
This elegant spotlight offers creative leeway in accent
lighting for many applications – with its excellent light
quality and appealing design it is the ideal solution
for the presentation of goods or for displaying art.
Offering precise beam characteristics and great
power density make it a suitable substitute for previous applications of 20W HID lamps. The Tracklight
1200 is specially laid-out for the LED technology
and ensures an optimized thermo-management of
the integrated chip-on-board module.
Application:
Precise accent lighting for the
presentation of goods and display
of art
Excellent colour rendition with
special filter
Usable in most standard 3-circuit
tracks due to quality 3-circuit
universal adapter
E-CORE LED TRACKLIGHT 1200
2 /5
Product details
Tracklight with integrated chip-on-board
LED module
Driver included in attached box
Fixture is rotating 330°, pivoting +/- 90°
Luminaire efficacy up to 61 lm/W
IP
20
220V
I
240V
IK
03
40000 h
Colour rendition Ra 80, possibility for Ra 90
with designated filter
Beam angle 22° or 40°
With 3-circuit universal adapter
Twist & Lock cover for installation
850
°C
Optical parameters
MODEL NAME
E-CORE LED TRACKLIGHT 1200 / WHITE
Product code
Colour *
Colour description
Colour temperature
Beam angle
Luminous flux
System efficacy
Luminous Intensity
Colour rendering index
LEDEUS00005N30
White
Warm white
3000 K
22°
1,100 lm
52 lm/W
4,700 cd
Ra > 80
LEDEUS00005N40
White
Neutral white
4000 K
22°
1,300 lm
61 lm/W
5,600 cd
Ra > 80
LEDEUS00006N30
White
Warm white
3000 K
40°
1,000 lm
47 lm/W
2,200 cd
Ra > 80
LEDEUS00006N40
White
Neutral white
4000 K
40°
1,300 lm
61 lm/W
2,600 cd
Ra > 80
* Available also in black and silver (for more information please see logistic data)
Please find here an indication of the CRI values when using the colour rendering (R9) improvement filter:
Ra
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R12
R13
R14
R15
3000 K
3000 K with filter
4000 K
4000 K with filter
80
90
80
87
81
99
79
96
85
92
82
88
86
79
84
75
81
90
81
87
78
94
77
91
77
86
74
80
89
90
88
86
73
94
73
91
32
94
24
92
62
75
57
66
76
90
77
87
51
66
50
59
81
97
79
92
91
86
90
85
78
97
76
98
CCT (K)
LUMEN OUTPUT (LM)
CBCP (22°)
CBCP (40°)
3000 K
3000 K with filter
4000 K
4000 K with filter
3,000
3,070
4,000
4,325
1,100
830
1,300
980
4,700
3,570
5,600
4,250
2,200
1,670
2,600
1,970
E-CORE LED TRACKLIGHT 1200
3 /5
Projekt 1
Projekt 1
27.09.2013
27.09.2013
Optical parameter
Bearbeiter(in)
Telefon
Fax
e-Mail
Bearbeiter(in)
Telefon
Fax
e-Mail
TOSHIBA LEDEUS00006N30 E-CORE LED TRACKLIGHT 1200 / Kegeldiagramm
TOSHIBA LEDEUS00006N30 E-CORE LED TRACKLIGHT 1200 / LVK (Polar)
POLAR CANDELA DISTRIBUTION
ILLUMINANCE
Leuchte: TOSHIBA LEDEUS00006N30 E-CORE LED TRACKLIGHT 1200
Lampen: 1 x LED
LEDEUS00006N30 / LEDEUS00006N40
Leuchte: TOSHIBA LEDEUS00006N30 E-CORE LED TRACKLIGHT 1200
Lampen: 1 x LED
105°
105°
90°
90°
75°
75°
0.34
E(0°)
E(C0)
18.6°
8800
3773
1.0
0.67
E(0°)
E(C0)
18.6°
2200
943
1.5
1.01
E(0°)
E(C0)
18.6°
978
419
2.0
1.35
E(0°)
E(C0)
18.6°
550
236
1.68
E(0°)
E(C0)
18.6°
352
151
18.6°
244
105
800
60°
60°
1200
1600
45°
45°
2.5
Projekt 1
Projekt 1
30°
15°
0°
07.10.2013
07.10.2013
2400
Bearbeiter(in)
Telefon
Fax
e-Mail
15°
3.0
30°
Bearbeiter(in)
Telefon
Fax
e-Mail
2.02
cd/klm
cd/klm
Abstand [m]
[m]
Distance
Leuchte: TOSHIBA LEDEUS00005N30 E-CORE LED TRACKLIGHT 1200
Lampen: 1 x LED
Leuchte: TOSHIBA LEDEUS00005N30 E-CORE LED TRACKLIGHT 1200
Lampen: 1 x LED

η =99%
99%
C0 -C0
C180
C90 - C270 C90 - C270
TOSHIBA
E-CORE LED TRACKLIGHT 1200 / LVK (Polar)
- C180 LEDEUS00005N30
LEDEUS00005N30 / LEDEUS00005N40
0.5
105°
105°
90°
90°
75°
75°
E(0°)
E(C0)
Kegeldurchmesser
[m]
Beleuchtungsstärke
[lx]
Cone Diameter [m]
Illuminance [lx]
C0 - C180 (Halbstreuwinkel:
37.2°) E-CORE LED TRACKLIGHT 1200 / Kegeldiagramm
TOSHIBA
LEDEUS00005N30
C0 - C180 (Half-value Angle: 37.2°)
0.5
0.19
E(0°)
E(C0)
10.7°
19000
9076
1.0
0.38
E(0°)
E(C0)
10.7°
4750
2269
1.5
0.57
E(0°)
E(C0)
10.7°
2111
1008
2.0
0.76
E(0°)
E(C0)
10.7°
1187
567
2.5
0.94
E(0°)
E(C0)
10.7°
760
363
3.0
1.13
E(0°)
E(C0)
10.7°
528
252
Seite 2
Seite 3
60°
60°
2000
3000
45°
45°
4000
5000
30°
15°
cd/klm
cd/klm
C0 - C180
C0 - C180
C90 - C270
0°
15°
30°

η =99%
99%
Abstand [m]
[m]
Kegeldurchmesser
[m]
Distance
Cone Diameter [m]
C0 - C180 (Halbstreuwinkel: 21.4°)
C90 - C270
Beleuchtungsstärke
[lx]
Illuminance [lx]
C0 - C180 (Half-value Angle: 21.4°)
Seite 2
Seite 3
E-CORE LED TRACKLIGHT 1200
4 /5
Electrical parameters
MODEL NAME
E-CORE LED TRACKLIGHT 1200
Rated wattage
System efficacy
Rated voltage
Frequency
Power factor
Rated lifetime
Lumen maintenance
Connection
Dimmable
21 W
up to 61 lm/W
220-240 V
50/60 Hz
> 0.9
40,000 h
70% at the rated lifetime
3-circuit universal track adapter
No
Mechanical parameters
MODEL NAME
E-CORE LED TRACKLIGHT 1200
Material
Colour
Type of installation
Electrical class
IP rating
IK rating
LED module
Ambient temperature range
Approval mark
Operation temperature
Dimensions (L x W x H)
Net weight
Die cast aluminium
White / Silver / Black
3-circuit track
Class I
IP20
IK03
CE / ENEC
850 °C
Integrated (non-replaceable)
+5 °C – +35 °C
150 x 142 x 160 mm
1,300 g
Drawings
Ø 100 mm
160 mm
150 mm
123 mm
142 mm
E-CORE LED TRACKLIGHT 1200
5 /5
Logistic data
PRODUCT CODE
EAN CODE
DESCRIPTION
SIZE OF PACKAGING (mm) L x H x W
GROSS WEIGHT (g)
LEDEUS00005N30
4974550451048
E-CORE LED TRACKLIGHT 1200
3000 K / 22° / White
226 x 196 x 206
1,650
LEDEUS00005N40
4974550451109
E-CORE LED TRACKLIGHT 1200
4000 K / 22° / White
226 x 196 x 206
1,650
LEDEUS00006N30
4974550451055
E-CORE LED TRACKLIGHT 1200
3000 K / 40° / White
226 x 196 x 206
1,650
LEDEUS00006N40
4974550451116
E-CORE LED TRACKLIGHT 1200
4000 K / 40° / White
226 x 196 x 206
1,650
LEDEUS00008N30
4974550451062
E-CORE LED TRACKLIGHT 1200
3000 K / 22° / Silver
226 x 196 x 206
1,650
LEDEUS00008N40
4974550451123
E-CORE LED TRACKLIGHT 1200
4000 K / 22° / Silver
226 x 196 x 206
1,650
LEDEUS00009N30
4974550451079
E-CORE LED TRACKLIGHT 1200
3000 K / 40° / Silver
226 x 196 x 206
1,650
LEDEUS00009N40
4974550451130
E-CORE LED TRACKLIGHT 1200
4000 K / 40° / Silver
226 x 196 x 206
1,650
LEDEUS00011N30
4974550451086
E-CORE LED TRACKLIGHT 1200
3000 K / 22° / Black
226 x 196 x 206
1,650
LEDEUS00011N40
4974550451147
E-CORE LED TRACKLIGHT 1200
4000 K / 22° / Black
226 x 196 x 206
1,650
LEDEUS00012N30
4974550451093
E-CORE LED TRACKLIGHT 1200
3000 K / 40° / Black
226 x 196 x 206
1,650
LEDEUS00012N40
4974550451154
E-CORE LED TRACKLIGHT 1200
4000 K / 40° / Black
226 x 196 x 206
1,650
LEDEUSX0001
4974550453998
Colour rendering improvement filter (R9) 150 x 150 x 100
515
Handling and safety information
Do not cover the lamp with paper, cloth or other easily flammable materials
Do not expose the lamp to water or high humidity
Avoid additional mechanical stress on the lamp
Do not touch the lamp during or shortly after usage. Risk of burn!
Ambient temperature range: +5 °C to +35 °C
Do not look directly into the lamp
Do not spray pesticide on this lamp
Please ensure the mains power is disconnected before undertaking any work on the luminaire or lamp
11/2013
