Table of Contents
PREFACE
Manual Objectives
This manual shows you how to set up and use the Programmable Digital Meter.
Standard Procedures:
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Checking voltage jumpers, or changing voltage power
Mounting the panel
Selecting the input type
Selecting a decimal point position
Scaling with known loads (on-line calibration)
Scaling without known loads
Enabling/disabling the front-panel tare
Displaying the filtered/unfiltered input signal
Selecting a display color
Setting the setpoint's active band
Selecting a latched or unlatched operation
Setting setpoint deadbands
Enabling/disabling setpoint changes
Enabling/disabling the RESET button in the Run Mode
Optional Procedures:
*
*
*
*
*
*
*
Setting input resolution
Enabling/disabling analog output
Selecting analog output as current or voltage
Selecting analog output or proportional control
Selecting proportional band
Using manual reset (offsetting setpoint errors)
Scaling analog output
For first-time users: Refer to the QuickStart Manual for basic operation and setup instructions.
i
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of Contents
Table A-1. Sections of the Manual
If you want to read about:
Refer to section
Unpacking; safety considerations
1
Introduction
Meter description and features
2
