Philips S221C3AFD/01 Datasheet

Philips S221C3AFD/01 Datasheet
Smart All-in-One display
22 (Viewable 21.5" / 54.6 cm)
Smart All-in-One
The world at your fingertips!
Open up a new world of opportunities with the Philips Smart All-in-One powered by
Android™. The expansive 21.5-inch multi-touch display is perfect for streaming HD
videos, music, e-Learning and web surfing to the next level.
Android with a big view
• Large optical multi-touch display for easy navigation
• 16:9 Widescreen Full HD display for best viewing experience
• Fast internet access with Wi-Fi or Ethernet port
• App downloads from Google Play™ Store
• Pre-loaded apps get you started right away
Prime multimedia experience
• Webcam and mic keeps you connected with family and friends
• Superb stereo sound for multimedia
• Play movies, photos & music directly from USB & SDHC drives
Easy to connect and enjoy
• Connect your own keyboard and mouse and explore the world
• Expand your storage with SDHC media
• USB Hub with 4 ports for easy connections
• SmartStand design features one-touch adjustment for easy use
Smart All-in-One display
Android 22 (Viewable 21.5" / 54.6 cm)
Big multi-touch screen
Open up a new world of opportunities with
the Philips Smart All-in-One powered by
Android. Thanks to its built in advanced optical
multi-touch technology, you can now
manipulate your content with pinch, zoom,
rotate, swipe or scroll. Its generous, large
screen frees you from squinting on a small size
smart display. Reading e-books or newspapers
is easy on your eyes thanks to its large font and
picture capabilities. Its large touch screen is
just the right tool to enable young children to
express their creativity with e-painting, learn
their ABC's, or use interactive educational
16:9 Widescreen Full HD
will take you to the store via Wi-Fi or Ethernet
connection. Download and install apps for
entertainment, games, utilities, office, photos,
video, news, social network, etc., which are
available and updated from the store. The
clear, easy-to-use interface helps you to
browse intuitively which can be sorted by
rating, category or popularity.
Socialize with webcam
The integrated webcam, with superb, bright
and crisp images, enables you to socialize with
your family and friends just like face to face.
The Smart All-in-One's ultra-sensitive
microphone ensures that your voice carries
through crisp and clear. You can hear clear
audio either from its built in stereo speakers,
or attach your own headphones for private
conversation. This simple built-in solution is
easy and ready to go at any time.
external SDHC card or USB flash using the
built-in expansion slot.
4 Ports USB 2.0 HUB
A USB Hub allows you to conveniently
connect and play multimedia devices such as
USB memory devices, camera, portable HDD,
web camera, PDA, printer and many other
devices. The conveniently located USB 2.0 Hub
on the monitor allows USB 2.0 signals to pass
thru to the computer for more ease-of-use.
Note that many devices like cameras and HDD
may need to be powered independently, as
they have higher power requirements than the
monitor USB Hub can provide.
Superb stereo sound
The Smart All-in-One features a 16:9 Full HD
(1920 x 1080 resolution) screen for a fullyimmersive entertainment experience. It's fully
future-proof as it supports 1080p signals from
all sources, including the most recent Blu-ray
and advanced HD game consoles. It produces
brilliant flicker-free progressive scan pictures
with superb brightness and colors.
Google Play™ Store
Enjoy great applications from the Google
Play™ Store. A single touch on the app icon
Immerse yourself with the high quality built-in
stereo speakers.
Expand your storage
Accommodate your ever growing library. You
can expand your storage capacity by adding
The Philips Smart All-in-One features a
SmartStand with maximum recline adjustability
and easy-one-touch-adjustment. The easy
adjustment of the SmartStand enables you to
use it in various ergonomic positions. With just
under 60 degree recline position, you can now
interact with the display naturally to touch and
type, or you can use it in an upright position to
sit and do some serious work.
Built-in Audio
Smart All-in-One display
Android 22 (Viewable 21.5" / 54.6 cm)
LCD panel type: ADS-LCD
Backlight type: W-LED system
Panel Size: 21.5 inch / 54.6 cm
Multi-touch optical panel: 2-point touch
Effective viewing area: 476.64 (H) x 268.11 (V)
Aspect ratio: 16:9
Optimum resolution: Android: 1280 x 720, PC:
1920 x 1080 @ 60 Hz
Response time (typical): 14 ms
SmartResponse (typical): 5 ms (Gray to Gray)
Brightness: 250 cd/m²
Contrast ratio (typical): 1,000:1
SmartContrast: 20,000,000:1
Viewing angle: 178º (H) / 178º (V), @ C/R > 10
Picture enhancement: SmartImage
Display colors: 16.7 M
• Built-in Audio: 2.0 watts x 2
Video/Audio Playback
• Video format: MPEG4, H.264, WMV
• Audio format: MPEG1, MPEG2, MP3, WMA, WAV,
Ogg Vorbis, AAC
• Photo format: JPEG, BMP, PNG, GIF
System Specifications
• Operating system: Android 4.1
• Processor: Dual-core, ARM-based, Amlogic,
• Built-in memory capacity: 1GB DDR3, 8GB EMMC
• External memory expansion: Optional external
SDHC card, or USB flash drive upto 64GB, or
external HDD
Preloaded applications
Google Play
Music Player
Web Browser
• User convenience: Power On/Off, Menu/OK,
Volume/Up, Input/Down, SmartImage/Back
• OSD Languages: Brazil Portuguese, Czech, Dutch,
English, Finnish, French, German, Greek,
Hungarian, Italian, Japanese, Korean, Polish,
Russian, Portuguese, Simplified Chinese, Spanish,
Swedish, Traditional Chinese, Turkish, Ukranian
• Other convenience: Kensington lock, VESA mount
• Plug & Play Compatibility: DDC/CI, Mac OS X,
sRGB, Windows 7, Windows 8
• Tilt: 12~54 degree
• On mode: 27.17 W (typ.) (EnergyStar 5.2 test
• Android standby mode: 6.42 W (typ.)
• Off mode: 0.3 W (typ.)
• Power LED indicator: Operation - White, Standby
mode- White (blinking)
• Power supply: External, 100-240VAC, 50-60Hz
• Product with stand (mm): 524 x 373 x 78 mm
• Product without stand (mm): 524 x 337 x 51 mm
• Packaging in mm (WxHxD): 580 x 446 x 137 mm
• Product with stand (kg): 4.76 kg
• Product with packaging (kg): 6.4 kg
Operating conditions
Temperature range (operation): 0°C to 40°C °C
Temperature range (storage): -20°C to 60°C °C
Relative humidity: 20%-80 %
Altitude: Operation: +12,000ft (3,658m), Nonoperation: +40,000ft (12,192m)
• MTBF: 30,000 hour(s)
• Environmental and energy: RoHS, Lead-free,
Mercury Free
• Recyclable packaging material: 100 %
• Signal Input: VGA (Analog ), HDMI, RJ 45
• SDHC card slot
• Wireless connections: Wi-Fi (Built-in), Wireless
LAN (802.11 b/g/n)
• USB: USB 2.0 x 4
• Audio (In/Out): PC audio-in, Headphone jack
• Webcam: 1 MP
• Mic in
Compliance and standards
• Regulatory Approvals: CCC, CECP, cETLus, CE
Mark, CEL, FCC Class B, WEEE
• Color: Black Cherry
• Finish: Glossy
Issue date 2014-11-14
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Version: 2.0.1
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
12 NC: 8670 001 05973
EAN: 87 12581 69602 3
* Requires external keyboard and mouse for Android (Not included in
the offer)
* External HDD may require additional power supply.
* Google and Android are trademarks of Google, Inc. Corporate
names, trademarks stated here are the property of their respective
