Philips LPL21X1 Datasheet

Philips LPL21X1 Datasheet
Philips LED Inspection
LED Inspection lamp
See better, work better
Cordless professional lighting tool
The compact rechargeable Philips LED inspection lamp is ideal for quick inspection and
longer repair operations. It eliminates all shadows with its strong 90° light beam, while its
360° rotating hook provides a hands-free working environment.
More light output
• Light output: 150 lumens
High resistance
• Strong impact resistance -IK07
• Water and dust protected -IP54
Hands-free lighting
• Adjustable and retractable multi-angle hook
LED Inspection lamp
Maximum visibility
Beam angle: 70°
Colour temperature: 6000 K
Light output: 150 lumens
Light intensity: 450 lux at 0.5 m
Number of LEDs: 6
LED lifetime: 10,000 hours
• Impact protection rating (IK): IK07
• Ingress protection rating (IP): IP54
• Resistant to: oil, grease, chemical and workshop
• Operating temperature: -10°C to 40°C
• Materials and finishing: robust rubber and
• Hook: 360° retractable hook
• Battery run time: up to 4 hours
Battery charging time: 4 hours
Battery Type: Li-Ion
Battery capacity: 1500 mAh
Operating line voltage: 100-240 V
Power consumption: 2.5 W
Plug type: UK
White LED light
Product measurement
• Lamp dimensions (L x W x D): 189 x 38 x 63 mm
Product weight
• with batteries: 180 g
Outer Carton
Number of consumer packages: 6
Outer carton (L x W x H): 35 x 23 x 10.5 cm
Gross weight: 2.1 kg
GTIN: 1 87 27900 39172 2
Country of origin
• China
The white LEDs provide 150 lumens of light output
to ensure that you are not left in the dark when
trying to spot even the smallest details. The colour
of the light is soft natural white with a colour
temperature of 6000 K, the best solution for long
repair jobs because it does not strain the eyes.
Impact resistant
The robust case is designed for a tough working
environment and conforms to IK07
Water resistant
The LED inspection lamp is water resistant and
conforms to IP54.
Cordless, with rotating hook
With the adjustable and retractable multi-angle hook
you can hang this professional lighting tool on every
surface. Leaving both hands free for the job.
Issue date 2014-06-03
© 2014 Koninklijke Philips N.V.
All Rights reserved.
Version: 1.0.3
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
12 NC: 9237 956 40202
EAN: 87 27900 39172 5
