POWERING
PROFESSIONALS
SINCE 1898
2013/14
2
Contents
AEG POWERTOOLS
promises to draw upon
its heritage and deliver
exciting, high performance,
innovative working
solutions for the professional
tradesmen of today and
the future.
CORDLESS SYSTEMS
06 – 27
18 V POWER
10 – 15
14,4 V POWER
16 – 17
12 V POWER
18 – 24
3,6 V POWER
25 – 25
FLASHLIGHTS/BATTERY LAMPS
25 – 25
BATTERIES & CHARGERS
26 – 27
HAMMER SYSTEMS
28 – 37
12 V CORDLESS HAMMER
30 – 30
18 V CORDLESS HAMMER
30 – 30
ROTARY HAMMERS
31 – 31
COMBI HAMMERS
31 – 36
CHIPPING HAMMERS
34 – 35
LARGE DEMOLITION HAMMERS
36 – 36
DRILLING SYSTEMS
38 – 44
ROTARY DRILLS
40 – 40
PERCUSSION DRILLS
41 – 43
DIAMOND DRILLS
44 – 44
WALL CHASERS
44 – 44
SCREWDRIVERS
45 – 45
METALWORKING
46 – 59
SMALL ANGLE GRINDERS
49 – 53
LARGE ANGLE GRINDERS
54 – 56
DIE GRINDERS
57 – 57
POLISHER
58 – 58
RIGHT ANGLE SANDER
58 – 58
ABRASIVE METAL CHOPSAW
59 – 59
WOODWORKING
60 – 74
ROUTERS
62 – 63
PLANER
63 – 63
JIGSAWS
64 – 65
CIRCULAR SAWS
66 – 67
RECIPROCATING SAWS
68 – 68
SANDERS
69 – 70
TABLE SAW
71 – 71
MITRE SAW
72 – 72
MITRE SAW LEGSTAND
72 – 72
DUST EXTRACTION
73 – 73
HEAT GUNS
74 – 74
ACCESSORIES
75 – 85
3
Features Key
FIXTEC System
For changing accessories
in seconds.
Keyless Safety Guard
Safety guard adjustment
without the use of a tool.
Impact Driver
For heavy duty
screwdriving
applications.
Anti-Vibration-System
Significantly reduces
vibration by up to 50%.
Soft Hammer Mode
Reduces blow energy for
increased control.
HEX 1⁄4˝
1
⁄4˝ quick release
hex fitment.
Safety Clutch
Protects user and machine
if a drill bit should jam.
2-Speed Gear
2-speed gearbox,
for optimum speed to
suit application.
Pendulum Action
For a faster, more
aggressive cut.
Dust Extraction
Integrated dust extraction
for a clean working
environment.
Drill Only
Single mode – rotary
drilling.
Kitbox
Heavy duty kitbox.
Electronics
Drill And Hammer Drill
2 mode – rotary and rotary
hammer drilling.
Kitbag
Heavy duty kitbag.
L.E.D.
For workplace
illumination.
Chisel And Hammer Drill
2 mode – rotary hammer
drill with chipping/
demolition function.
Crosscut Capacity
Maximum crosscut
capacity of saw.
Metal Chuck
For enhanced
durability.
Combi Hammer
3 mode – rotary and rotary
hammer drilling with
chiselling/demolition function.
Mitre Saw Blade
Laser
Projects the cut line
onto material.
Rotatable Handle
Provides optimum comfort
during grinding and
cutting.
Chisel Drill
Chiselling/demolition
machine.
Mitre Capacity
Maximum mitre
angle right and left.
Diamond System
Designed for maximum
performance when used
with diamond accessories.
Hook And Loop
Easy sandpaper
attachment without
the clamps.
Bevel Capacity
Maximum bevel
angle right and left.
With variable speed preselection, soft start, constant speed
and overload protection.
History
POWERING
PROFESSIONALS
SINCE 1898
Since being founded, AEG POWERTOOLS has
been leading the way in new product development.
By introducing the first transportable drilling
machines in 1898, portable powertools were born.
Over 100 years later AEG are still offering the
professional user innovative, powerful solutions…
PROUD PAST…
EXCITING FUTURE…
4
6
TOTAL
CORDLESS
POWER
AEG POWERTOOLS
offer today’s professional
user a wide range of
innovative, powerful
cordless solutions that are
capable of performing in
the toughest conditions.
THE CORDLESS SYSTEM RANGE
18 V POWER
14,4 V POWER
12 V POWER
3,6 V POWER
BATTERIES & CHARGERS
8
The complete Lithium-Ion range
Split into compact and heavy duty products, the AEG
POWERTOOLS 18 V Pro Lithium-Ion range offers the power
and performance required for more substantial applications,
but offers the flexibility of more compact units with 1,5 Ah
batteries, or heavy duty products using 3,0 Ah batteries.
Products in this range:
New microtexture grip
with LED trigger switch
New battery fuel gauge
9
The 14,4 V Pro Lithium-Ion range
from AEG POWERTOOLS strike
a balance between ergonomics,
comfort and power. Slightly
bigger and heavier than the 12 V
range, they offer more power and
run time, but are still lighter than
their 18 V counterparts.
Products in this range:
The AEG POWERTOOLS range
of 12 V Pro Lithium-Ion products
are ideal for applications
which require a lightweight
ultracompact unit. The Pro Lithium
cells still provide optimum power
to suit this type of task, and
also benefit from a 30 minute
charge time, and have overload
protection built into the product
to ensure maximum durability of
the battery and the tool.
Products in this range:
All batteries and charger are fully
backwards compatible
10 CORDLESS SYSTEMS
18 V PREMIUM HAMMERDRILL/DRIVER
BSB 18 Li
Features
• New high performance open frame motor
• Compact & powerful for high torque applications
• 70 Nm maximum torque delivers complete power
• Full metal gearbox and housing for superior durability
• 2-speeds – 0–450/0–1600 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm full metal Rohm keyless chuck, with spindle lock
• LED – for work place illumination
• 3 mode selector – ease of use between applications
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 3,0 Ah
No. of batteries
30 min*
Charger
2,5 kg
Weight with battery
Drilling
wood/metal/masonry
55/13/16 mm
1,5–13 mm
Chuck
70 Nm
Max torque
No load speed
0–450/0–1600 rpm
Percussion rate
7200–25.600 bpm
18 V
Voltage
Standard Equipment – 2 x batteries, charger, side handle and kitbox
Cat No. BSB 18 Li-302C Article No. 4935 4284 50 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132003
18 V COMPACT HAMMERDRILL/DRIVER
Features
ALSO AVAILABLE: 3,0 Ah Li-Ion version
• New 4 poles frameless motor and compact gearbox
• Compact & powerful for high torque applications
• Only 202 mm in length
• 51 Nm (1,5 Ah) / 60 Nm (3,0 Ah) maximum torque delivers complete power
• 2-speeds – 0–450/0–1650 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm keyless chuck, with spindle lock
• LED – for work place illumination
• 3 mode selector – ease of use between applications
• Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
Specification
No. of batteries
2 x 1,5 Ah
30 min*
Charger
1,8 kg
Weight with battery
Drilling
wood/metal/masonry
BSB 18C Li
45/13/14 mm
Chuck
Max torque
1,5–13 mm
51 Nm
No load speed
0–450/0–1650 rpm
Percussion rate
5850–21.450 bpm
Voltage
18 V
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BSB 18C Li-152C Article No. 4935 4284 35 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132041
Cat No. BSB 18C Li-302C Article No. 4935 4284 30 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132027
* Charge times based on 1,5 Ah Li-Ion battery
CORDLESS SYSTEMS 11
BSB 18 G2 Li
18 V HAMMERDRILL/DRIVER
Features
• Compact & powerful for completion of all jobsite applications
• 50 Nm maximum torque delivers complete power
• 2 speeds – 0–400/0–1500 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm single sleeve full metal chuck
• 3 mode selector – ease of use between functions
• Built in fuel gauge
• LED – for work place illumination
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 1,5 Ah
No. of batteries
60 min*
Charger
1,9 kg
Weight with battery
Drilling
wood/metal/masonry
Chuck
Max torque
No load speed
1,5–13 mm
50 Nm
0–400/0–1500 rpm
18 V
Voltage
34/13/12 mm
Standard Equipment – 2 x batteries, charger and kitbox
NEW
Cat No. BSB 18 G2 Li-152C Article No. 4935 4339 70 Version. 2 x 1,5 Ah Li-Ion batteries, 60 min* charger EAN No. 4002395134489
BS 18 G2 Li
18 V DRILL/DRIVER
Features
• Compact & powerful for completion of all jobsite applications
• 50 Nm maximum torque delivers complete power
• 2-speeds – 0–400/0–1500 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm single sleeve full metal chuck
• Built in fuel gauge
• LED – for work place illumination
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
No. of batteries
Charger
2 x 1,5 Ah
60 min*
Weight with battery
1,8 kg
Drilling metal/wood
13/34 mm
Chuck
1,5–13 mm
Max torque
No load speed
Voltage
50 Nm
0–400/0–1500 rpm
18 V
Standard Equipment – 2 x batteries, charger and kitbox
NEW
Cat No. BS 18 G2 Li-152C Article No. 4935 4339 50 Version. 2 x 1,5 Ah Li-Ion batteries, 60 min* charger EAN No. 4002395134441
* Charge times based on 1,5 Ah Li-Ion battery
12 CORDLESS SYSTEMS
18 V ULTRA COMPACT DRILL/DRIVER
BS 18C Li
Features
ALSO AVAILABLE: 3,0 Ah Li-Ion version
• New 4 poles frameless motor and compact gearbox
• Small, compact & powerful for high torque applications
• Only 186 mm in length
• 51 Nm (1,5 Ah) / 60 Nm (3,0 Ah) maximum torque delivers complete power
• 2-speeds – 0–450/0–1650 rpm
• Integrated clutch and chuck for a more compact design
• LED for work place illumination
• Forward and reverse
• Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
Specification
No. of batteries
2 x 1,5 Ah
30 min*
Charger
Weight with battery
1,8 kg
Drilling wood/metal
45/13 mm
Chuck
1,5–13 mm
51 Nm
Max torque
No load speed
0–450/0–1650 rpm
18 V
Voltage
Standard Equipment – 1 x double ended bit, 2 x batteries, charger and kitbox
Cat No. BS 18C Li-152C Article No. 4935 4284 15 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132096
Cat No. BS 18C Li-302C Article No. 4935 4284 10 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132089
18 V ULTRA COMPACT IMPACT DRIVER
Features
ALSO AVAILABLE: 3,0 Ah Li-Ion version and 0-version
• Ultra compact, well balanced impact driver
• Only 145 mm overall length
• 158 Nm maximum torque
• Delivers up to 3100 impacts per minute for increased productivity
• Industrial metal gearbox and gears for extended life
• ¼˝ Hex bit reception
• Built in LED illuminates work surface
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
No. of batteries
2 x 1,5 Ah
30 min*
Charger
2,0 kg
Weight with battery
Impact rate
Tool reception
Voltage
0–3100 ipm
⁄4˝ Hex
1
18 V
158 Nm
Max torque
No load speed
BSS 18C Li
0–2400 rpm
Standard Equipment – 1 x single PZ2 bit, 2 x batteries, charger and kitbox
Cat No. BSS 18C Li-152C Article No. 4935 4283 95 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132133
Cat No. BSS 18C Li-302C Article No. 4935 4284 00 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132126
Cat No. BSS 18C-0 Article No. 4935 4284 05 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132140
* Charge times based on 1,5 Ah Li-Ion battery
CORDLESS SYSTEMS 13
18 V SDS-PLUS HAMMER
BBH 18 Li
Features
ALSO AVAILABLE: 0-version
• L-shape SDS hammer for drilling and fixing into concrete up to 24 mm
• 2,3 Joule impact energy delivers high performance
• Rotary stop for light chiselling applications
• Hammer action stop for rotary drilling in wood and metal
• Metal gearbox for extended durability
• Safety clutch for user protection
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 3,0 Ah
No. of batteries
30 min*
Charger
3,5 kg
Weight with battery
Drilling
concrete/steel/wood
Impact energy
No load speed
Blows per minute
Voltage
2,3 J EPTA
1400 rpm
0–4200 bpm
18 V
24/13/30 mm
Standard Equipment – 2 x battery, charger and kitbox
Cat No. BBH 18 Li-302C Article No. 4935 4082 75 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132751
Cat No. BBH 18-0 Article No. 4935 4083 30 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132744
18 V PENDULUM ACTION RECIPROCATING SAW
Features
BUS 18 Li
ALSO AVAILABLE: 0-version
• Pendulum action for increased performance
• 3600 strokes per minute and 19 mm stroke length
for fast cutting applications
• Robust bladeclamp for demolition applications
• FIXTEC for fast and easy keyless blade change
• Adjustable shoe
• Saw blade can be turned 180° for various applications
• Variable speed trigger
• Soft-grip
• Features AEG Pro Lithium-Ion battery technology
with overload protection for maximum durability
of battery and tool
Specification
No. of batteries
Charger
Weight with battery
2 x 3,0 Ah
30 min*
3,5 kg
Stroke length
Strokes per minute
Voltage
19 mm
0–3600 spm
18 V
Standard Equipment – 2 x blades, 2 x batteries, charger and kitbox
Cat No. BUS 18 Li-302C Article No. 4935 4283 65 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132157
Cat No. BUS 18-0 Article No. 4935 4313 70 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132805
* Charge times based on 1,5 Ah Li-Ion battery
14 CORDLESS SYSTEMS
18 V HEAVY DUTY CIRCULAR SAW
BKS 18 Li
Features
ALSO AVAILABLE: 0-version
• Compact, light and well balanced
• Extremely fast cutting speed of 5000 rpm
• Magnesium base and upper guard for durability
• Large 50° bevel capacity
• Electronic motor brake, saw blade stops within seconds
• Lock off switch for safety
• Spindle lock for fast blade changing
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 3,0 Ah
No. of batteries
30 min*
Charger
3,4 kg
Weight with battery
Saw blade Ø
Arbor
165 mm
15,87 mm (5⁄8˝)
50°
Bevel capacity
No load speed
5000 rpm
Cutting depth
at 45°
0–41 mm
Cutting depth
at 90°
0–54 mm
Voltage
18 V
Standard Equipment – 2 x batteries, charger, 165 mm TCT blade, side fence and kitbox
Cat No. BKS 18 Li-302C Article No. 4935 4283 70 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132164
Cat No. BKS 18-0 Article No. 4935 4313 75 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132812
18 V HEAVY DUTY JIGSAW
BST 18X-0
Features
• Pendulum action for increased cutting performance
• Metal gearbox for extended durability
• Professional, die-cast aluminium base plate
• Patented FIXTEC system for fast keyless blade change
• Variable speed trigger
• Ergonomic soft-grip for comfortable use
• Electronic motor brake
Specification
26 mm
Stroke
No load stroke rate
0–2050 spm
Weight with battery
3,5 kg
Bevel cutting angle
to 45°
Cutting depth in soft wood
Voltage
80 mm
18 V
Standard Equipment – Plastic shoe cover, anti splintering device, 2 x blades
Cat No. BST 18X-0 Article No. 4935 4131 30 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395197460
* Charge times based on 1,5 Ah Li-Ion battery
CORDLESS SYSTEMS 15
18 V HEAVY DUTY ANGLE GRINDER
BEWS 18-125
ALSO AVAILABLE: with disc Ø 115 mm
ALSO AVAILABLE: 0-versions
Features
• Compact and powerful cordless angle grinder
• Overload protection with LED warning
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Fast and tool-free disc change with patented FIXTEC nut
• Built in fuel gauge
• AEG Pro Lithium-Ion battery technology for maximum
durability of battery and tool
Specification
No. of batteries
Charger
Weight with battery
No load speed
Cutting depth Ø 115 mm
Ø 125 mm
2 x 3,0 Ah
30 min*
2,5 kg
9000 rpm
28 mm
33 mm
Spindle thread
M14
Voltage
18 V
Standard Equipment – Grinding keyless guard, 2 batteries 18 V 3,0 Ah Pro Lithium-Ion,
30 min charger, FIXTEC nut, flange nut, AVS side handle and kitbox
NEW
Cat No. BEWS 18-115 Li-302C Article No. 4935 4319 31 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132966
Cat No. BEWS 18-115-0 Article No. 4935 4333 19 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395133222
Cat No. BEWS 18-125 Li-302C Article No. 4935 4319 91 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132973
Cat No. BEWS 18-125-0 Article No. 4935 4319 98 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132980
* Charge times based on 1,5 Ah Li-Ion battery
16 CORDLESS SYSTEMS
14,4 V COMPACT HAMMERDRILL/DRIVER
Features
BSB 14C Li
ALSO AVAILABLE: 3,0 Ah Li-Ion version
• 3 mode selector
• Powerful new frameless motor delivering 43 Nm (1,5 Ah) / 47 Nm (3,0 Ah)
maximum torque
• 2 speeds – 0–400/0–1500 rpm
• FIXTEC 13 mm keyless chuck
• Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
Specification
2 x 1,5 Ah
No. of batteries
30 min*
Charger
1,8 kg
Weight with battery
Drilling
wood/metal/masonry
1,5–13 mm
Chuck
43 Nm
Max torque
No load speed
0–400/0–1500 rpm
14,4 V
Voltage
45/13/14 mm
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BSB 14C Li-152C Article No. 4935 4284 45 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132072
Cat No. BSB 14C Li-302C Article No. 4935 4284 40 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132065
14,4 V HAMMERDRILL/DRIVER
BSB 14 G2 Li
Features
ALSO AVAILABLE: NiCd Version
• Compact & powerful for completion of all jobsite applications
• 36 Nm maximum torque delivers complete power (32 Nm NiCd)
• 2 speeds – 0–400/0–1500 rpm (0–1400 rpm NiCd)
• 24-stage torque adjustment
• FIXTEC 13 mm single sleeve chuck with full metal jaws (10 mm NiCd)
• 3 mode selector – ease of use between functions
• LED – for work place illumination (lithium version only)
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool**
Specification
No. of batteries
Charger
Weight with battery
Drilling
metal/wood/masonry
2 x 1,5 Ah
60 min*
1,8 kg
Chuck
Max torque
No load speed
Voltage
1,5–13 mm
36 Nm
0–400/0–1500 rpm
14,4 V
13/32/8 mm
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BSB 14 G2 LI-152C Article No. 4935 4319 90 Version. 2 x 1,5 Ah Li-Ion batteries, 60 min* charger EAN No. 4002395132997
Cat No. BSB 14 G2 NC-142C Article No. 4935 4319 89 Version. 2 x 1,4 Ah NiCd batteries, 60 min* charger EAN No. 4002395195107
* Charge times based on 1,5 Ah Li-Ion battery ** Lithium-Ion products only
NEW
18 CORDLESS SYSTEMS
14,4 V COMPACT DRILL/DRIVER
BS 14C Li
Features
ALSO AVAILABLE: 3,0 Ah Li-Ion version
• Ultra compact drill/driver measuring 186 mm in length
• Powerful new frameless motor delivering 43 Nm (1,5 Ah) / 47 Nm (3,0 Ah)
maximum torque
• 2 speeds – 0–400/0–1500 rpm
• FIXTEC 13 mm keyless chuck
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
No. of batteries
Charger
2 x 1,5 Ah
30 min*
Weight with battery
1,7 kg
Drilling metal/wood
13/45 mm
Chuck
1,5–13 mm
43 Nm
Max torque
No load speed
0–400/0–1500 rpm
14,4 V
Voltage
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BS 14C Li-152C Article No. 4935 4284 25 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132119
Cat No. BS 14C Li-302C Article No. 4935 4284 20 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132102
14,4 V DRILL/DRIVER
BS 14 G2 Li
Features
ALSO AVAILABLE: NiCd version
• Compact & powerful for completion of all jobsite applications
• 36 Nm maximum torque delivers complete power (32 Nm NiCd)
• 2-speeds – 0–400/0–1500 rpm (0–1400 rpm NiCd)
• 24-stage torque adjustment for complete control
• FIXTEC 13 mm single sleeve chuck with full metal jaws (10 mm NiCd)
• Built in fuel gauge
• LED – for work place illumination (lithium version only)
• Features AEG Pro Lithium-Ion battery technology with overload protection
for maximum durability of battery and tool**
Specification
No. of batteries
Charger
2 x 1,5 Ah
60 min*
Weight with battery
1,7 kg
Drilling metal/wood
13/32 mm
Chuck
1,5–13 mm
Max torque
No load speed
Voltage
36 Nm
0–400/0–1500 rpm
14,4 V
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BS 14 G2 LI-152C Article No. 4935 4319 88 Version. 2 x 1,5 Ah Li-Ion batteries, 60 min* charger EAN No. 4002395195084
Cat No. BS 14 G2 NC-142C Article No. 4935 4319 87 Version. 2 x 1,4 Ah NiCd batteries, 60 min* charger EAN No. 4002395195077
* Charge times based on 1,5 Ah Li-Ion battery ** Lithium-Ion products only
NEW
CORDLESS SYSTEMS 19
12 V HAMMERDRILL/DRIVER
BSB 12 G2 NiCd
Features
• Compact & powerful for completion of all jobsite applications
• 30 Nm maximum torque delivers complete power
• 2 speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment
• FIXTEC 10 mm single sleeve chuck with
full metal jaws
• 3 mode selector – ease of use between functions
Specification
2 x 1,4 Ah
No. of batteries
60 min*
Charger
1,7 kg
Weight with battery
Drilling
metal/wood/masonry
Chuck
Max torque
No load speed
Voltage
1,5–10 mm
30 Nm
0–350/0–1350 rpm
12 V
10/30/6 mm
Standard Equipment – 2 x batteries, charger and kitbox
NEW
Cat No. BSB 12 G2 NC-142C Article No. 4935 4319 86 Version. 2 x 1,4 Ah NiCd batteries, 60 min* charger EAN No. 4002395195053
12 V DRILL/DRIVER
BS 12 G2 NiCd
Features
• Compact & powerful for completion of all jobsite applications
• 30 Nm maximum torque delivers complete power
• 2-speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment for complete control
• FIXTEC 10 mm single sleeve chuck with full metal jaws
Specification
No. of batteries
Charger
2 x 1,4 Ah
60 min*
Weight with battery
1,6 kg
Drilling metal/wood
10/30 mm
Chuck
1,5–10 mm
Max torque
No load speed
Voltage
30 Nm
0–350/0–1350 rpm
12 V
Standard Equipment – 2 x batteries, charger and kitbox
NEW
Cat No. BS 12 G2 NC-142C Article No. 4935 4319 85 Version. 2 x 1,4 Ah NiCd batteries, 60 min* charger EAN No. 4002395195060
* Charge times based on 1,5 Ah Li-Ion battery
3 BODIES, 7 HEADS,
100 + APPLICATIONS
MULTITOOL HEAD
OMNI-MT
IMPACT DRIVER HEAD
OMNI-IH
HAMMER HEAD
OMNI-HH
RIGHT ANGLE
DRILLING HEAD
OMNI-RAD
RATCHED HEAD
OMNI-IR
Article No. 4935 4407 00
EAN No. 4002395134717
Article No. 4935 4407 30
EAN No. 4002395134779
Article No. 4935 4407 10
EAN No. 4002395134731
Article No. 4935 4407 05
EAN No. 4002395134724
Article No. 4935 4407 20
EAN No. 4002395134755
BEST FOR
OMNIPRO 12 V BASE UNIT
ERGONOMICS
OMNI12C
OMNI18C
The OMNI12C offers users the ultimate in ergonomics.
The light weight, compact body is ideal for working in
tight spaces.
The OMNI18C gives more power and more runtime than
the 12 V power base, whilst keeping the advantage of
cordless portability.
FEATURES
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– LED for work place illumination
– Small and compact for working in tight environments
OMNI12C
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– Optimum power to weight ratio
– LED for work place illumination
– Built in fuel gauge
213 mm
SPECIFICATIONS
POWER
SPECIFICATIONS
OMNI18C
Battery voltage
12 V
Battery voltage
18 V
No load oscillation rate
20000 min-1
No load oscillation rate
20000 min-1
Oscillation angle left / right
1,5°/1,5°
Oscillation angle left / right
1,5°/1,5°
60 mm
280 mm
FEATURES
BEST FOR
OMNIPRO 18 V BASE UNIT
70 mm
ALL HEADS AND BODIES
ONE SYSTEM
OMNIPRO is a revolutionary system allowing users to tailor their system depending
on application. All heads and bodies are interchangeable to select the best balance
of power base and head for ultimate productivity.
JIGSAW HEAD
OMNI-JS
RECIPROCATING SAW HEAD
OMNI-RH
Article No. 4935 4407 15
EAN No. 4002395134748
Article No. 4935 4407 25
EAN No. 4002395134762
BEST FOR
OMNIPRO AC BASE UNIT
RUNTIME
OMNI300
The OMNI300 is the choice for longer applications
where a cordless machine is not required, with all the
power expected from an AC machine.
SPECIFICATIONS
300 W
No load oscillation rate
20000 min-1
Oscillation angle left / right
1,5°/1,5°
Cat No.
OMNI12C LI-152C KIT1
Article No. 4935 4407 65
Version.
12 V power handle, multitool head, accessories,
2 x 1.5 Ah batteries, charger, bag
EAN No. 4002395134809
Cat No.
OMNI12C LI-152B KIT3
Article No. 4935 4407 80
Version.
12 V power handle, multitool head, jigsaw head,
accessories, 2 batteries, charger, bag
EAN No. 4002395134830
OMNI18C
260 mm
Cat No.
OMNI18C LI-152C KIT1
Article No. 4935 4406 44
Version.
18 V power handle, multitool head, accessories,
2 x 1.5 Ah batteries, charger, bag
EAN No. 4002395134632
Cat No.
OMNI 18C-0 KIT1
Article No. 4935 4406 45
Version.
18 V power handle, multitool head, no batteries or charger supplied
(accessories are also delivered with the 0 version)
EAN No. 4002395134649
OMNI300
Power
OMNI12C
Cat No.
OMNI12C LI-152B KIT2
Article No. 4935 4407 70
Version.
12 V power handle, multitool head, right angle drill head,
accessories, 2 batteries, charger, bag
EAN No. 4002395134816
FEATURES
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– LED for work place illumination
– Mains machine
CHOOSE
YOUR
SYSTEM
OMNI300
Cat No.
Article No.
Version.
EAN No.
80 mm
ARE INTERCHANGEABLE
OMNI300 KIT1
4935 4317 90
AC Multitool, multitool head, accessories, soft bag
4002395194995
22 CORDLESS SYSTEMS
12 V 2-SPEED ULTRA COMPACT PERCUSSION DRILL
BSB 12C2 Li
192 mm
Features
• Compact hammer drill/driver measuring only 192 mm
• Built in fuel gauge
• Belt clip
• 2-speed gearbox for a wide range of applications
• Industrial metal gearbox and gears for superior durability
• FIXTEC spindle lock and keyless 10 mm chuck
• Electronic switch with variable speed
• 3 mode selector – ease of use between applications
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 1,5 Ah
No. of batteries
30 min*
Charger
1,2 kg
Weight with battery
Drilling
metal/wood/masonry
Percussion rate
Chuck
1,5–10 mm
32 Nm
Max torque
No load speed
10/20/10 mm
22.500 bpm
0–400/0–1500 rpm
12 V
Voltage
Standard Equipment – 2 x batteries, charger and bag
NEW
Cat No. BSB 12C2 LI-152B Article No. 4935 4339 80 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395134519
12 V 2-SPEED ULTRA COMPACT DRILL/DRIVER
Features
168 mm
• Compact pocket drill/screwdriver measuring only 168 mm
• 17-stage torque adjustment plus additional drilling stage
• 2-speed gearbox for a wide range of applications
• Industrial metal gearbox and gears for superior durability
• FIXTEC spindle lock and keyless 10 mm chuck
• Electronic switch with variable speed
• Built in LED light illuminates the work surface
• Features AEG Pro Lithium-Ion battery technology with over load protection
for maximum durability of battery and tool
Specification
No. of batteries
BS 12C2 Li
2 x 1,5 Ah
30 min*
Charger
1,1 kg
Weight with battery
Drilling steel/soft wood
10/20 mm
Chuck
1,5–10 mm
Max torque
No load speed
Voltage
34 Nm
0–350/0–1500 rpm
12 V
Standard Equipment – 2 x batteries, charger and kitbox
Cat No. BS 12C2 LI-152C Article No. 4935 4283 75 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132171
Cat No. BS 12C2 Li-151B Article No. 4935 4283 85 Version. 1 x 1,5 Ah Li-Ion battery, 30 min* charger EAN No. 4002395132195
* Charge times based on 1,5 Ah Li-Ion battery
CORDLESS SYSTEMS 23
BS 12C Li
12 V ULTRA COMPACT DRILL/DRIVER
161 mm
Features
• Compact pocket drill/screwdriver measuring only 161 mm
• Built in fuel gauge
• 17-stage torque adjustment plus additional drilling stage
• Industrial metal gearbox and gears for superior durability
• FIXTEC spindle lock and keyless 10 mm chuck
• Electronic switch with variable speed
• Built in LED light illuminates the work surfaces
• Overload protection
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
No. of batteries
Charger
Weight with battery
2 x 1,5 Ah
30 min*
1,0 kg
Drilling steel/soft wood
10/20 mm
Chuck
1,5–10 mm
Max torque
No load speed
18,5 Nm
0–575 rpm
12 V
Voltage
Standard Equipment – 2 x batteries, charger and bag
NEW
Cat No. BS 12C Li-152B Article No. 4935 4339 02 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395126354
Cat No. BS 12C Li-151B Article No. 4935 4339 01 Version. 1 x 1,5 Ah Li-Ion batterie, 30 min* charger EAN No. 4002395126347
12 V ULTRA COMPACT IMPACT DRIVER
BSS 12C Li
163 mm
Features
• Ultra compact impact driver measuring only 163 mm
• 115 Nm torque
• Industrial metal gearbox and gears for superior durability
• Built in fuel gauge
• ¼˝ Hex bit reception
• Ergonomic soft-grip design
• New 3 beam LED for total workplace illumination
• Belt clip
• Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
Specification
No. of batteries
Charger
Weight with battery
Max torque
No load speed
2 x 1,5 Ah
30 min*
1,0 kg
Impact rate
Tool reception
Voltage
0–3000 ipm
1
⁄4˝ Hex
12 V
115 Nm
0–2000 rpm
Standard Equipment – 2 x batteries, charger and kitbox
NEW
Cat No. BSS 12C Li-152C Article No. 4935 4410 00 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395134977
* Charge times based on 1,5 Ah Li-Ion battery
24 CORDLESS SYSTEMS
12 V CORDLESS HAMMER
Features
BBH 12 Li
ALSO AVAILABLE: 1,5 Ah version
• L-shape SDS hammer for drilling and fixing into concrete
up to 13 mm
• 0,9 Joule EPTA impact energy delivers high performance
• Hammer action stop for rotary drilling
in wood and metal
• Built in fuel gauge
• Metal gearbox for extended durability
• Safety clutch for user protection
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
Specification
No. of batteries
Charger
Weight with battery
Drilling metal/wood/concrete
2 x 3,0 Ah
30 min*
1,8 kg
8/10/13 mm
Impact energy
0,9 J EPTA
No load speed
0–800 rpm
Blows per minute
Voltage
0–5350 bpm
12 V
Standard Equipment – 2 x batteries, charger, screwdriving bit adaptor, case
Cat No. BBH12Li-152C Article No. 4935441148 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395135097
Cat No. BBH12Li-302C Article No. 4935441471 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395135165
NEW
CORDLESS SYSTEMS 25
SE 3.6 Li
3,6 V INLINE SCREWDRIVER
Features
ALSO AVAILABLE: NiCd version
• In-line or angled handle adjustment
• 10-stage torque selection plus drill stage
• Ergonomic, modern design
• 2-speed full metal gearbox
• ⁄ ˝ Hex bit reception
1
4
Specification
No. of batteries
Charger
2 x 1,5 Ah
30 min*
Weight with battery
0,6 kg
Length with battery
28 cm
Drilling aluminium/wood
Max torque
No load speed
6,5 Nm
200/600 rpm
3,6 V
Voltage
5/6 mm
Standard Equipment – 2 x 1,5 Ah batteries, charger and kitbox
Cat No. SE 3.6 Li-152C Article No. 4935 4131 65 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395197538
Cat No. SE 3.6 NC-142C Article No. 4935 4131 55 Version. 2 x 1,4 Ah NiCd batteries, 30 min* charger EAN No. 4002395197514
FLASHLIGHTS/BATTERY LAMPS
Model
Voltage
Article
Number
4932-
EAN
Number
4002395-
BLL 12C
12 V
3521 62
368150
FL 12
12 V
3521 00
367535
FL 14
14 V
3521 01
367542
FL 18
18 V
3521 02
367559
BAL 18
18 V
3526 61
373192
* Charge times based on 1,5 Ah Li-Ion battery
w
26
Pro Lithium-Ion technology
Fuel gauge
helps user manage
run time
Slide pack design
for an easy, secure fit
Independently
activated buttons
Recessed terminals
prevent accidental short
circuiting
prohibit accidental
battery removal
Large heat sink
Triple
dissipates heat quicker
protection circuitry
High capacity
Rigid cell cradle
Lithium-Ion cells
absorbs impacts
and holds cells firmly
in place to prevent
damage
Rubber dampers
Double spot welds
Absorb movement to
prevent damage
ensure durability during
high vibration
applications and are
more resistant to heat
Durable
Outer housing
TRIPLE PROTECTION
THERMAL MONITORING
Protects over heating
OVER CURRENT MONITORING
INDIVIDUAL CELL MONITORING
Protects over loading
Protects over/under
charging
AEG POWERTOOLS Lithium-Ion technology provides the optimum power platform for
todays professional user by protecting both battery and machine in 3 ways:
1)
–
–
–
Electronic current protection
shuts down if excessive current draw may harm battery and machine
thermal shutdown protects battery if temperature gets too high
protects individual cells from over discharging
2) Robust construction
– AEG POWERTOOLS Lithium-Ion technology benefits from robust internal and external design features
as illustrated above, to ensure optimum durability
3) Individual cell monitoring
– individual cells charge and discharge at different rates – AEG POWERTOOLS Lithium-Ion technology
offers tailored charging and discharging for individual cells for maximum cell life
27
Batteries and Chargers
AEG BATTERY PACKS
Long-life, high capacity packs without any memory effect. The excellent contact system with
perfectly protected self cleaning contacts offers the lowest possible resistance between battery and
tool for optimum performance.
BATTERIES
Chemistry
Capacity
L1830R
Li-Ion
3,0
L1815R
Li-Ion
1,5
B1814G
NiCd
1,4
B1817G
NiCd
L1430R
3,6 V
12 V
14,4 V
18 V
Catalogue
Number
Charger Compatibility
Charge Time*
Article
Number
EAN
Number
4932 3526 55
4002395373130
4932 3526 54
4002395373123
4932 3525 33
4002395371914
1,7
4932 3524 80
4002395371396
Li-Ion
3,0
4932 3526 57
4002395373154
L1415R
Li-Ion
1,5
4932 3526 56
4002395373147
M1430R
NiMH
3,0
4932 3521 10
4002395367634
B1414G
NiCd
1,4
4932 35 2531
4002395371891
L1215
Li-Ion
1,5
4932 3526 58
4002395373161
M1230R
NiMH
3,0
4932 3521 07
4002395367603
B1214G
NiCd
1,4
4932 3525 32
4002395371907
SL 3,6
Li-Ion
1,5
4932 3520 99
4002395367528
SB 3,6
NiCd
1,4
4932 3520 98
4002395367511
Article
Number
EAN
Number
4932 3524 81
4002395371402
AL 9618 / 60 min*
BL 1218 / 30 min*
AL 9618 / 60 min*
BL 1218 / 30 min*
LL 1230 / 30 min*
AL 9618 / 60 min*
BL 1218 / 30 min*
LA 036 / 30 min*
CHARGERS
Catalogue
Number
Chemistry
AL1214G
NiCd, NiMH, Li-Ion 12–14,4 V
Charger Compatibility
Charge Time*
60 min*
AL1218G
NiCd, NiMH, Li-Ion 12–18 V
4932 3529 57
4002395376155
BL 1218
NiCd, NiMH, Li-Ion 12 – 18 V
4932 3526 59
4002395373178
LL 1230
Li-Ion 12 V
4932 3520 96
4002395367498
LA 036
NiCd, NiMH, Li-Ion 3,6 V
4932 3520 97
4002395367504
* Charge times based on 1,5 Ah Li-ion battery
30 min*
29
REAL
HAMMER
POWER
AEG POWERTOOLS offer
an extensive selection of
high performance rotary,
combination, chipping and
demolition hammers.
THE HAMMER RANGE
12 V CORDLESS HAMMER
18 V CORDLESS HAMMER
SDS-PLUS ROTARY HAMMERS
SDS-PLUS COMBI HAMMERS
SDS-PLUS CHIPPING HAMMERS
SDS-MAX LARGE COMBI HAMMERS
SDS-MAX LARGE DEMOLITION HAMMERS
30 HAMMER SYSTEMS
12 V CORDLESS HAMMER
BBH 12 Li
Features
ALSO AVAILABLE: 1,5 Ah version
• L-shape SDS hammer for drilling and fixing into concrete up to 13 mm
• 0,9 Joule impact energy delivers high performance
• Hammer action stop for rotary drilling in wood and metal
• Built in fuel gauge
• Metal gearbox for extended durability
• Safety clutch for user protection
• Features AEG Pro Lithium-Ion battery technology with overload protection for
maximum durability of battery and tool
Specification
2 x 3,0 Ah
No. of batteries
30 min*
Charger
1,8 kg
Weight with battery
Drilling
metal/wood/concrete
Impact energy
0,9 J EPTA
No load speed
0–800 rpm
Blows per minute
0–5350 bpm
12 V
Voltage
8/10/13 mm
Standard Equipment – 2 x batteries, charger, screwdriving bit adaptor, case
NEW
Cat No. BBH 12 Li-152C Article No. 4935441148 Version. 2 x 1,5 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395135097
Cat No. BBH 12 Li-302C Article No. 4935441471 Version. 2 x 3,0 Ah Li-Ion batteries, 60 min* charger EAN No. 4002395135165
BBH 18 Li
18 V CORDLESS HAMMER
Features
ALSO AVAILABLE: 0-version
• L-shape SDS hammer for drilling and fixing into concrete up to 24 mm
• 2,3 Joule impact energy delivers high performance
• Rotary stop for light chiselling applications
• Hammer action stop for rotary drilling in wood and metal
• Metal gearbox for extended durability
• Safety clutch for user protection
• Features AEG Pro Lithium-Ion battery technology with overload protection
for maximum durability of battery and tool
Specification
No. of batteries
2 x 3,0 Ah
30 min*
Charger
3,5 kg
Weight with battery
Drilling
concrete/steel/wood
Impact energy
No load speed
Blows per minute
Voltage
2,3 J EPTA
1400 rpm
0–4200 bpm
18 V
24/13/30 mm
Standard Equipment – 2 x battery, charger and kitbox
Cat No. BBH 18 Li-302C Article No. 4935 4082 75 Version. 2 x 3,0 Ah Li-Ion batteries, 30 min* charger EAN No. 4002395132751
Cat No. BBH 18-0 Article No. 4935 4083 30 Version. Zero version – no batteries, charger or kitbox EAN No. 4002395132744
* Charge times based on 1,5 Ah Li-Ion battery
HAMMER SYSTEMS 31
SDS-PLUS ROTARY HAMMER
Features
• Powerful 650 watt motor
• 22 mm drilling capacity in concrete
• Safety clutch for user protection
• Variable speed electronics for control
• Hammer action stop for drilling in wood or metal
• Forward and reverse mechanism
BH 22 E
Specification
Power input
No load speed
Impact energy
Hammer rate (full load)
Drilling concrete/steel/wood
Weight
650 watt
0–1290 rpm
1,9 J EPTA
0–3700 bpm
22/13/30 mm
2,5 kg
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. BH 22 E Article No. 4935 4114 80 Version. 220–240 V EAN No. 4002395197026
SDS-PLUS ROTARY HAMMER
Features
• Powerful 720 watt motor
• 24 mm drilling capacity in concrete
• Safety clutch for user protection
• Variable speed electronics for control
• Hammer action stop for drilling in wood or metal
• Forward and reverse mechanism
• Soft-grip handle for comfort
BH 24 E
Specification
Power input
720 watt
No load speed
1500 rpm
Impact energy
Hammer rate (full load)
Drilling concrete/steel/wood
Weight
2,3 J EPTA
0–4500 bpm
24/13/30 mm
2,4 kg
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. BH 24 E Article No. 4935 4282 00 Version. 240 V EAN No. 4002395194384
SDS-PLUS COMBI HAMMER
Features
• Powerful 720 watt motor
• 24 mm drilling capacity in concrete
• Rotary stop for light chiselling applications
• FIXTEC quick change chuck
• Safety clutch for user protection
• Variable speed electronics for control
• Hammer action stop for drilling in wood or metal
• Forward and reverse mechanism
• Soft-grip handle for comfort
KH 24 XE
Specification
ALSO AVAILABLE: KH 24 E – No FIXTEC
Power input
720 watt
No load speed
1500 rpm
Impact energy
Hammer rate (full load)
Drilling concrete/steel/wood
Weight
Standard Equipment – Side handle, FIXTEC adaptor and
keyless chuck, metal depth gauge, 4 m cable and kitbox
Cat No. KH 24 XE Article No. 4935 4282 20 Version. 220–240 V EAN No. 4002395194407
Cat No. KH 24 E Article No. 4935 4282 10 Version. 220–240 V EAN No. 4002395194391
2,3 J EPTA
0–4500 bpm
24/13/30 mm
2,6 kg
32 HAMMER SYSTEMS
SDS-PLUS COMBI HAMMER
KH 26 E
Features
ALSO AVAILABLE: KH 26 XE - with FIXTEC
• Powerful 800 watt motor
• 26 mm drilling capacity in concrete
• Rotary stop for light chiselling applications
• Safety clutch for user protection
• Variable speed electronics for control
• Hammer action stop for drilling in wood or metal
• Forward and reverse mechanism
• Soft-grip handle for comfort
Specification
Power input
800 watt
No load speed
1500 rpm
Drilling
concrete/steel/wood
Impact energy
2,5 J EPTA
Weight
Hammer rate (full load)
26/13/30 mm
2,6 kg
0–4500 bpm
Standard Equipment – Side handle, metal depth gauge, 4 m cable and kitbox
Cat No. KH 26 E Article No. 4935 4281 80 Version. 220–240 V EAN No. 4002395194360
Cat No. KH 26 XE Article No. 4935 4289 10 Version. 220–240 V EAN No. 4002395194681 with FIXTEC adaptor
SDS-PLUS COMBI HAMMER
BH 26 LXE
Features
ALSO AVAILABLE: BH 26 LE – no FIXTEC
• Powerful 750 watt motor
• 26 mm drilling capacity in concrete
• Rotary stop for light chiselling applications
• Soft hammer mode reduces blow energy and speed for drilling/chiselling in
sensitive materials
• FIXTEC quick change tool system
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Safety clutch for user protection
• Hammer action stop for drilling in wood or metal
Specification
Power input
No load speed
Impact energy
Hammer rate (full load)
750 watt
0–1400 rpm
2,7 J EPTA
0–4500 bpm
Drilling
concrete/steel/wood
26/13/30 mm
Drilling capacity core cutter
68 mm
Weight
3,1 kg
Standard Equipment – Side handle, FIXTEC adaptor and keyless chuck, metal depth
gauge, 4 m cable and kitbox
Cat No. BH 26 LXE Article No. 4935 4120 00 Version. 220–240 V EAN No. 4002395197187
Cat No. BH 26 LE Article No. 4935 4120 42 Version. 220–240 V EAN No. 4002395197903
hammer systems 33
SDS-PLUS Combi Hammer
Features
•Powerful 1010 watt motor
•28 mm drilling capacity in concrete
•Rotary stop for light chiselling applications
•Soft hammer mode reduces blow energy and speed
for drilling/chiselling in sensitive materials
•FIXTEC quick change tool system
•Safety clutch for user protection
•Variable speed electronics for control
•Hammer action stop for drilling in wood or metal
•Soft-grip handle for comfort
•Electronic overload protection
•No load speed limitation
Specification
Power input
1010 watt
No load speed
1500 rpm
Impact energy
2,8 J EPTA
Hammer rate (full load)
Drilling
concrete/steel/wood
Weight
0–5000 bpm
28/13/30 mm
2,8 kg
Standard Equipment – Side handle, FIXTEC adaptor and keyless chuck, metal depth
gauge, 4 m cable and kitbox
Cat No. KH 28 Super XE Article No. 4935 4281 90 Version. 220–240 V EAN No. 4002395194377
KH 28 Super XE
34 HAMMER SYSTEMS
SDS-PLUS COMBI HAMMER
PN 3500 X
Features
ALSO AVAILABLE: PN 3500 – No FIXTEC
• Powerful 750 watt motor
• 30 mm drilling capacity in concrete
• Rotary stop for light chiselling applications
• Soft hammer mode reduces blow energy and speed for control in chiselling
applications
• FIXTEC quick change tool system
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Safety clutch for user protection
• Hammer action stop for drilling in wood or metal
Specification
750 watt
Power input
No load speed
0–970 rpm
Impact energy
3,4 J EPTA
Hammer rate (full load)
0–4200 bpm
Drilling
concrete/steel/wood
30/16/40 mm
Drilling capacity core cutter
82 mm
Weight
3,6 kg
Standard Equipment – Side handle, FIXTEC adaptor and keyed chuck, metal depth
gauge, 4 m cable and kitbox
Cat No. PN 3500 X Article No. 4935 4122 10 Version. 220–240 V EAN No. 4002395198337
Cat No. PN 3500 Article No. 4935 4121 52 Version. 220–240 V EAN No. 4002395198306
SDS-PLUS CHIPPING HAMMER
PM 3
Features
• Powerful 720 watt motor
• 3,6 J impact energy for powerful chipping
• Variolock (35 positions) for selecting the most appropriate chisel angle
• Service hatches for easy changing of carbon brushes
• Lock-on switch function
• AVS anti-vibration aystem significantly reduces vibration for more comfortable
operation
• Soft-grip for more comfortable handling
Specification
Power input
Impact energy
720 watt
3,6 J EPTA
Hammer rate (full load)
Weight
Standard Equipment – Side handle, 4 m cable and kitbox
Cat No. PM 3 Article No. 4935 4125 41 Version. 220–240 V EAN No. 4002395199044
0–3650 bpm
3,7 kg
HAMMER SYSTEMS 35
SDS-MAX COMBI HAMMER
KH 5 E
Features
• Powerful 1200 watt motor
• 40 mm drilling capacity in concrete
• Rotary stop for chiselling applications
• Soft hammer mode reduces blow energy and speed for drilling/chiselling in
sensitive materials
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Safety clutch for user protection
• Soft start for precise start of drilling/chiselling
• Service light provides in-time notice in the case of worn out brushes
• Power light indicates if electricity flows
Specification
1200 watt
Power input
300 rpm
No load speed
8,5 J EPTA
Impact energy
Hammer rate (full load)
0–2840 bpm
Drilling concrete/
core bit/tunnel drill bit
40/90/65 mm
Drilling capacity core cutter
Weight
105 mm
6,6 kg
Standard Equipment – Side handle, metal depth gauge, grease, 6 m cable and kitbox
Cat No. KH 5 E Article No. 4935 4123 26 Version. 220–240 V EAN No. 4002395198603
SDS-MAX CHIPPING HAMMER
MH 5 E
Features
• Powerful 1200 watt motor
• 8,5 J impact energy for effortless chipping
• Soft hammer mode reduces blow energy for chiselling in sensitive materials
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Soft start for precise start of chiselling
• Service light provides in-time notice in the case of worn out brushes
• Power light indicates if electricity flows
Specification
Power input
1200 watt
Hammer rate (full load)
Impact energy
8,5 J EPTA
Weight
Standard Equipment – D front handle, grease, 6 m cable and kitbox
Cat No. MH 5 E Article No. 4935 4123 61 Version. 220–240 V EAN No. 4002395198795
0–2840 bpm
6,2 kg
36 HAMMER SYSTEMS
SDS-MAX LARGE COMBI HAMMER
PN 11 E
Features
• Powerful 1700 watt motor
• 20 J impact energy for heavy demolition applications
• 50 mm drilling capacity into concrete
• Variable speed electronics for control
• No load speed limitation
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Safety clutch for user protection
• Soft start for precise start of drilling/chiselling
• Service light provides in-time notice in the case of worn out brushes
• Automatic cut out carbon brushes
• Soft-grip on handles for comfort
Specification
1700 watt
Power input
20 J EPTA
Impact energy
Hammer rate (full load)
975–1950 bpm
Drilling concrete/
core bit/tunnel drill bit
Weight
50/150/80 mm
11,8 kg
Standard Equipment – D front handle, additional side handle, grease, 6 m cable and
kitbox
Cat No. PN 11 E Article No. 4935 4124 40 Version. 220–240 V EAN No. 4002395198931
SDS-MAX LARGE DEMOLITION HAMMER
Features
• Powerful 1600 watt motor
• 20 J impact energy for heavy demolition applications
• Variable speed electronics for control
• No load speed limitation
• AVS anti-vibration system significantly reduces vibration for user comfort and safety
• Soft start for precise start of drilling/chiselling
• Service light provides in-time notice in the case of worn out brushes
• Automatic cut out carbon brushes
• Soft-grip on handles for comfort
Specification
Power input
Impact energy
1600 watt
20 J EPTA
Hammer rate (full load)
Weight
Standard Equipment – D front handle, grease, 6 m cable and kitbox
Cat No. PM 10 E Article No. 4935 4124 18 Version. 220–240 V EAN No. 4002395198832
975–1950 bpm
11,0 kg
PM 10 E
POWER TO PROTECT
AEG POWERTOOLS is committed to producing hard hitting, low vibration hammers which allow professional users to carry out
heavy duty job site applications safely.
A new directive in 2005 – The EU Physical Agents (Vibration) Directive 2002/44/EC states that Hand Arm Vibration (HAV) should
be considered an official risk to health and safety in the workplace. These vibrations are expressed in terms of acceleration –
m/s2. All AEG POWERTOOLS hammers are rated by their tri-axle vibration levels as required by this directive, as shown in the
table below, so professional users can work safely in line with this directive.
ROTARY/COMBINATION HAMMERS
Model
Power
input
Impact
energy
Hammer
rate
Tri-axle vibration
level drilling
Tri-axle vibration
level chiselling
Weight
BBH 12 Li
12 V
0,9 J
0–5350 bpm
4,4 m/s2
n/a
1,8 kg
BBH 18 Li
18 V
2,3 J
0–4200 bpm
16,0 m/s2
8,8 m/s2
3,5 kg
BH 22 E
650 W
1,9 J
0–3700 bpm
15,5 m/s2
n/a
2,5 kg
BH 24 E
720 W
2,3 J
0–4500 bpm
14,0 m/s2
n/a
2,4 kg
KH 24 XE
720 W
2,3 J
0–4500 bpm
14,0 m/s2
11,6 m/s2
2,6 kg
KH 26 E
800 W
2,5 J
0–4500 bpm
15,0 m/s2
12,4 m/s2
2,6 kg
BH 26 LXE
750 W
2,7 J
0–4500 bpm
14,5 m/s2
13,0 m/s2
3,1 kg
KH 28 Super XE
1010 W
2,8 J
0–5000 bpm
15,4 m/s2
13,5 m/s2
2,8 kg
PN 3500 X
750 W
3,4 J
0–4200 bpm
20,0 m/s2
13,5 m/s2
3,6 kg
KH 5 E
1200 W
8,5 J
0–2840 bpm
13,0 m/s2
9,0 m/s2
6,6 kg
PN 11 E
1700 W
20 J
975–1950 bpm
12,5 m/s2
11,0 m/s2
11,8 kg
DEMOLITION HAMMERS
Model
Power
input
Impact
energy
Hammer
rate
Tri-axle vibration
level drilling
Tri-axle vibration
level chiselling
Weight
PM 3
720 W
3,6 J
0–3650 bpm
n/a
15,5 m/s2
3,7 kg
MH 5 E
1200 W
8,5 J
0–2840 bpm
n/a
11,5 m/s2
6,2 kg
PM 10 E
1600 W
20 J
975–1950 bpm
n/a
11,0 m/s2
11,0 kg
38
POWER
TO DRILL
DEEPER
AEG POWERTOOLS offer the power
to drill deeper with their powerful range
of percussion drills offering enhanced
performance, reliability and durability for
todays professional user.
DRILLING SYSTEM RANGE
ROTARY DRILLS
PERCUSSION DRILLS
DIAMOND SYSTEM
WALL CHASER
SCREWDRIVERS
40 DRILLING SYSTEMS
ROTARY DRILL
Features
• Compact and powerful 650 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse
mechanism
• 10 mm keyless metal chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
BE 650 R
Specification
Power input
No load speed
Drilling steel/aluminium/wood
Max torque
Chuck
Weight
650 watt
0–3000 rpm
10/13/30 mm
25 Nm
1,0–10 mm
1,7 kg
Standard Equipment – Chuck, cable
Cat No. BE 650 R Article No. 4935 3817 75 Version. 220–240 V EAN No. 4002395194599
BE 705 R
ROTARY DRILL
Features
• Extremely compact design
• Compact and powerful 705 watt motor
• Variable speed control with forward and reverse
mechanism
• Belt clip
• 10 mm keyless chuck
Specification
Power input
No load speed
Drilling steel/aluminium/wood
Max torque
Chuck
Weight
705 watt
0–2700 rpm
10/16/30 mm
15 Nm
1,0–10 mm
1,6 kg
Standard Equipment – Chuck, 4 m cable and softbag
Cat No. BE 705 R Article No. 4935 4165 05 Version. 220–240 V EAN No. 4002395129744
ROTARY DRILL
Features
• Four-speed rotary drill for drilling up to 32 mm
• Breast plate and 57 mm gear neck for use in
magnetic drill stands
• Standard morse taper 3 reception
• Attachable handle with adjustable length
B4-1050 ST
Specification
Power input
No load speed
1st/2nd/3rd/4th gear
Drilling steel/aluminium/wood
Max torque
Tool reception
Weight
Standard Equipment – Breast plate, attachable handle,
4 m cable
Cat No. B4-1050 ST Article No. 4935 4150 00 Version. 220–240 V EAN No. 4002395193356
1050 watt
220/260/350/
420 rpm
32/64/52 mm
> 200 Nm
Morse taper 3
9,7 kg
DRILLING SYSTEMS 41
PERCUSSION DRILL
Features
• Compact and powerful 500 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and
reverse mechanism
• Hammer action stop for rotary drilling
• 10 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
SBE 500 R
Specification
Power input
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
500 watt
0–2650 rpm
13/10/20 mm
21 Nm
1,5–10 mm
1,6 kg
Standard Equipment – Chuck, cable
Cat No. SBE 500 R Article No. 4935 4126 37 Version. 220–240 V EAN No. 4002395199242
SBE 570 R
PERCUSSION DRILL
Features
• Compact and powerful 570 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and
reverse mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
Specification
Power input
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
570 watt
0–2700 rpm
15/13/30 mm
23 Nm
1,5–13 mm
1,7 kg
Standard Equipment – Chuck, side handle, metal depth
gauge and cable
Cat No. SBE 570 R Article No. 4935 4126 81 Version. 220–240 V EAN No. 4002395199303
PERCUSSION DRILL
SBE 600 R
Features
Specification
• Compact and powerful 600 watt motor
• Compact ergonomic design with large soft-grip areas
Power input
offers excellent handling
• Variable speed control with forward and reverse
mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
Standard Equipment – Chuck, side handle, depth gauge
and cable
Cat No. SBE 600 R Article No. 4935 3817 00 Version. 220–240 V EAN No. 4002395194544
Cat No. SBE 600 R Kit Article No. 4935 3817 20 Version. 220–240 V delivered in kitbox EAN No. 4002395194568
ALSO AVAILABLE: Kit version
600 watt
0–2700 rpm
15/13/30 mm
23 Nm
1,5–13 mm
1,8 kg
42 DRILLING SYSTEMS
PERCUSSION DRILL
SBE 650 R
Features
Specification
• Compact and powerful 650 watt motor
• Compact ergonomic design with large soft-grip areas
Power input
offers excellent handling
• Variable speed control with forward and reverse
mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
ALSO AVAILABLE: Kit version
650 watt
0–3000 rpm
16/13/30 mm
25 Nm
1,5–13 mm
1,8 kg
Standard Equipment – Chuck, side handle, depth
gauge, cable
Cat No. SBE 650 R Article No. 4935 3817 70 Version. 220–240 V EAN No. 4002395194582
Cat No. SBE 650 R Kit Article No. 4935 3817 10 Version. 220–240 V delivered in kitbox EAN No. 4002395194551
SB2-650
PERCUSSION DRILL
Features
Specification
• Compact and powerful 650 watt motor
• Compact ergonomic design with large soft-grip areas
Power input
offers excellent handling
• Variable speed control
• 2-speed selection for increased torque and versatility
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
650 watt
0–2250/0–3000 rpm
16/13/30 mm
25 Nm
1,5–13 mm
1,8 kg
Standard Equipment – Chuck, side handle, depth
gauge, cable
Cat No. SB2-650 Article No. 4935 3817 60 Version. 220–240 V EAN No. 4002395194575
HIGH TORQUE PERCUSSION DRILL
Features
Specification
• Compact and powerful 750 watt high torque
Power input
percussion drill
• 62 Nm torque delivers complete power
• IMB – Integrated-Metal-Block technology for highest
durability and stability
• 2-speed gearbox with synchromesh gear lever
• Variable speed control with forward and reverse
mechanism
• Easy access to carbon brushes via removal of
soft-grip rubber
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. SB2E 750 RX ST Article No. 4935 4128 53 Version. 220–240 V EAN No. 4002395192779
Cat No. SB2E 750 R ST Article No. 4935 4128 39 Version. 220–240 V EAN No. 4002395192700
SB2E 750 RX ST
ALSO AVAILABLE: SB2E 750 R ST – No FIXTEC
750 watt
0–1200/0–3400 rpm
20/13/40 mm
62 Nm
1,5–13 mm
2,5 kg
DRILLING SYSTEMS 43
L-SHAPE PERCUSSION DRILL
Features
ERGOMAX
Specification
• Ultra compact powerful 750 watt percussion drill
• Superior ergonomic design
• Removable main handle
• IMB – Integrated-Metal-Block technology for highest durability &
stability
• Variable speed control with forward and reverse mechanism
• Patented FIXTEC system for quick and easy changing of accessories
• 2-speed planetary synchromesh gear
• Direct bit reception for reduced weight, reduced length, improved
visibility
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
750 watt
Power input
0–1200/0–3400 rpm
No load speed
Drilling concrete/steel/wood
20/13/40 mm
58 Nm
Max torque
1,5–13 mm
Chuck
2,6 kg
Weight
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. Ergomax Article No. 4935 4123 96 Version. 220–240 V EAN No. 4002395198870
SB 20-2E
PERCUSSION DRILL
Features
• Compact and powerful 750 watt percussion drill
• AVS anti-vibration system for more comfortable use
• Safety clutch for user protection
• 2-speed gearbox for increased torque and versatility
• Ergonomic soft-grip design for comfort
• Variable speed control with forward and reverse
mechanism
Specification
Power input
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
750 watt
0–1000/0–3200 rpm
20/13/40 mm
56 Nm
1,5–13 mm
2,8 kg
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. SB 20-2E Article No. 4935 4110 00 Version. 220–240 V EAN No. 4002395196609
PERCUSSION DRILL
Features
• Compact and powerful 1010 watt percussion drill
• AVS anti-vibration system for more comfortable use
• Safety clutch for user protection
• 2-speed gearbox
• Ergonomic soft-grip design for comfort
• Variable speed control with forward and reverse
mechanism
SB 22-2E
Specification
Power input
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
Standard Equipment – Side handle, metal depth gauge,
4 m cable and kitbox
Cat No. SB 22-2E Article No. 4935 4110 30 Version. 220–240 V EAN No. 4002395196630
Cat No. SB 22-2E with keyed chuck Article No. 4935 4118 06 Version. 220–240 V EAN No. 4002395132447
ALSO AVAILABLE: with keyed chuck
1010 watt
0–1000/0–3200 rpm
22/16/40 mm
60 Nm
1,5–13 mm
2,9 kg
44 DRILLING SYSTEMS
DRY DIAMOND DRILL
DB 1500-2 E
Features
• Powerful 1500 watt motor
• High performance 2-speed dry diamond drill
• Dual protection with interlinked mechanical and electronic
clutches for safety
• Robust construction and full metal gearbox for durability
• 2-speed gear box
• Electronics with soft start for precision drilling and motor
overload protection
• Soft hammer mode
Specification
1500 watt
Power input
No load speed
0–1500/
0–3000 rpm
Spindle thread
M18 x 2,5
Max. drilling capacity
in masonry/brick
162 mm
4,2 kg
Weight
Standard Equipment – Kitbox and handle
Cat No. DB 1500-2 E Article No. 4935 4124 75 Version. 220–240 V EAN No. 4002395198955
WALL CHASER
MFE 1500
Features
• Powerful 1500 watt motor
• Electronics with thermal overload protection and soft start
• Variable and adjustable cutting depth for accurate results
• Variable cutting width for versatility
• Bayonet adaptor for dust extraction
• Spindle lock
Specification
Power input
1500 watt
No load speed
Cutting width/depth
125 mm
Disc diameter
8–30/8–26 mm
4,1 kg
Weight
975–1950 bpm
Blade for MFE 1500
Type
DSU 125 – Laser welded
universal blade especially
suitable for wall chasers
Blade
Ø
Bore
Ø
Segment
height
mm
mm
mm
125
22,23
10
Quantity
1
Article No.
EAN
No.
4932-
4002395-
373147
346455
Standard Equipment – Kitbox, 4 m cable, special break out chisel, front handle, suction
adaptor, spanner
Cat No. MFE 1500 Article No. 4935 4136 05 Version. 220–240 V EAN No. 4002395192809
DRILLING SYSTEMS 45
SELF DRILLING SCREWDRIVER
S 2500 E
Features
Specification
• Powerful 720 watt motor for increased productivity
• Compact self drilling screwdriver with high torque for
Power input
self tapping screws
720 watt
0–2500 rpm
No load speed
6,3/6 mm
Self-tapping/wood screws
• Full metal gearbox for durability
• Easily adjustable depth-setting nosepiece for
14 Nm
Torque
consistent fastener depth
• Forward and reverse mechanism
• Ergonomic design and soft-grip for comfortable
handling
• 1⁄4˝ Hex bit reception
• Belt clip
⁄4˝ Hex
Bit reception
1
1,5 kg
Weight
Standard Equipment – 2 depth gauges, 3⁄8˝ & 5⁄16˝ Hex
sockets, bit holder, PH 2 bit, belt clip, 4 m cable
Cat No. S 2500 E Article No. 4935 4132 25 Version. 220–240 V EAN No. 4002395197651
DRYWALL SCREWDRIVER
S 4000 E
Features
Specification
• Powerful 720 watt motor for increased productivity
• Compact high speed screwdriver for drywall
Power input
applications
720 watt
0–4000 rpm
No load speed
5 mm
Drywall screws
• Full metal gearbox for durability
• Easily adjustable depth-setting nosepiece for
10 Nm
Torque
consistent fastener depth
• Forward and reverse mechanism
• Ergonomic design and soft-grip for comfortable
handling
• 1⁄4˝ Hex bit reception
• Belt clip
⁄4˝ Hex
Bit reception
1
1,4 kg
Weight
Standard Equipment – Depth gauge, bit holder, PH 2
bit, belt clip, 4 m cable
Cat No. S 4000 E Article No. 4935 4132 15 Version. 220–240 V EAN No. 4002395197637
SCREWDRIVING POWERSET
Set of 40 screwdriving bits
Coldfire is a special hardening treatment for making metals stronger, tougher and more durable. This cryogenic process is a one-time permanent treatment
affecting the entire screwdriving bit and it is not just a surface coating. The cyrogenic process consists of two steps, firstly the bit is hardened by heating it
up to 870° and then freezing the bit down to -148° using a dry nitrogen atmosphere. The result of this process is a bit with exceptional durability.
+ 40% stronger – bit tips hold their form and will accept higher torque forces
+ 45% longer life – over the lifetime of a bit one can expect to drive 45% more screws
Qty Description
Art. No.
4932-
EAN No.
4002395-
352255
369140
Screwdriving bits 25 mm length
1
PH 1
2
PZ 3
1
0,6 x 4,5
1
TX 7
2
TX 20
2
PH 2
1
Hex 3
1
0,8 x 5,5
1
TX 8
2
TX 25
1
PH 3
1
Hex 4
1
1,0 x 5,5
1
TX 9
1
TX 30
2
PZ 1
1
Hex 5
1
1,2 x 6,5
2
TX 10
1
TX 40
2
PZ 2
1
Hex 6
1
TX 6
2
TX 15
1
TX 20
Screwdriving bits 50 mm length
1
PH 1
1
PZ 1
1
TX 10
1
PH 2
1
PZ 2
1
TX 15
1
⁄4˝ Hex magnetic
bit holder
47
POWER
TO
PERFORM
AEG POWERTOOLS offer an extensive range of
grinders in a wide variety of power classes for the
most diverse professional applications. These high
performance tools are equipped with advanced
features to ensure comfort and ease of use in the
most challenging environments.
METALWORKING RANGE
SMALL ANGLE GRINDERS
LARGE ANGLE GRINDERS
DIE GRINDERS
POLISHERS / SANDERS
ABRASIVE METAL CHOPSAW
METALWORKING SYSTEMS 49
SMALL ANGLE GRINDER
Features
• Compact powerful 670 watt motor
• Metal gearbox for durability
• Directed air exhaust
• Gear head rotates at 90° intervals for added
versatility
WS 6-115
Specification
Power input
No load speed
Cutting depth
Grinding disc Ø
• Flat metal gear head for excellent visibility of work
Spindle thread
piece and optimised cutting depth
• Protected air inlets
• Spindle lock
Weight
670 watt
10.000 rpm
28 mm
115 mm
M14
1,9 kg
Standard Equipment – Additional handle, flange,
flange nut, spanner and cable
Cat No. WS 6-115 Article No. 4935 4132 50 Version. 220–240 V EAN No. 4002395197699
SMALL ANGLE GRINDER
Features
• Compact powerful 700 watt motor
• Metal gearbox for durability
• Directed air exhaust
• Gear head rotates at 90° intervals for added
versatility
WS 6-125
Specification
Power input
No load speed
Cutting depth
Grinding disc Ø
• Flat metal gear head for excellent visibility of work
Spindle thread
piece and optimised cutting depth
• Protected air inlets
• Spindle lock
Weight
Standard Equipment – Additional handle, flange,
flange nut, spanner and cable
Cat No. WS 6-125 Article No. 4935 4134 90 Version. 220–240 V EAN No. 4002395198542
700 watt
10.000 rpm
33 mm
125 mm
M14
1,9 kg
50 METALWORKING SYSTEMS
SMALL ANGLE GRINDER
WS 9-115
Features
• Powerful 900 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece and work in
restricted areas
• Optimised cooling slots prevent overheating, even when blocking
occasionally by hand
• Most compact girth and length for comfortable use all day long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard adjustment
• Spindle lock
Specification
Power input
No load speed
Cutting depth
900 watt
11.000 rpm
33 mm
Grinding disc Ø
Spindle thread
Weight
115 mm
M14
2,0 kg
Standard Equipment – AVS side handle, keyless safety guard, flange, flange nut, spanner
and 4 m cable
Cat No. WS 9-115 Article No. 4935 4193 80 Version. 220–240 V EAN No. 4002395130689
SMALL ANGLE GRINDER
WS 9-125
Features
ALSO AVAILABLE: WS 9-125 Kit – with kitbox
• Powerful 900 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece and work in
restricted areas
• Optimised cooling slots prevent overheating, even when blocking
occasionally by hand
• Most compact girth and length for comfortable use all day long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard adjustment
• Spindle lock
Specification
Power input
No load speed
Cutting depth
900 watt
11.000 rpm
37 mm
Grinding disc Ø
Spindle thread
Weight
125 mm
M14
2,0 kg
Standard Equipment – AVS side handle, keyless safety guard, flange, flange nut, spanner
and 4 m cable
Cat No. WS 9-125 Article No. 4935 4193 90 Version. 220–240 V EAN No. 4002395130719
Cat No. WS 9-125 Kit Article No. 4935 4282 70 Version. 220–240 V EAN No. 4002395194346
METALWORKING SYSTEMS 51
SMALL ANGLE GRINDER
WS 11-115
Features
• Powerful 1100 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece and work in
restricted areas
• Optimised cooling slots prevent overheating, even when blocking
occasionally by hand
• Most compact girth and length for comfortable use all day long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard adjustment
• Spindle lock
Specification
Power input
No load speed
Cutting depth
1100 watt
Grinding disc Ø
11.000 rpm
Spindle thread
33 mm
Weight
115 mm
M14
2,1 kg
Standard Equipment – AVS side handle, keyless safety guard, flange, flange nut, spanner
and 4 m cable
Cat No. WS 11-115 Article No. 4935 4194 00 Version. 220–240 V EAN No. 4002395130726
SMALL ANGLE GRINDER
WS 11-125
Features
ALSO AVAILABLE: WS 11-125 Kit – with kitbox & 2 diamond discs
• Powerful 1100 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece and work in
restricted areas
• Optimised cooling slots prevent overheating, even when blocking
occasionally by hand
• Most compact girth and length for comfortable use all day long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard adjustment
• Spindle lock
Specification
Power input
No load speed
Cutting depth
1100 watt
Grinding disc Ø
11.000 rpm
Spindle thread
37 mm
Weight
125 mm
M14
2,1 kg
Standard Equipment – AVS side handle, keyless safety guard, flange, flange nut, spanner
and 4 m cable
Cat No. WS 11-125 Article No. 4935 4194 10 Version. 220–240 V EAN No. 4002395130757
Cat No. WS 11-125 Kit Article No. 4935 4194 95 Version. 220–240 V EAN No. 4002395130832
52 METALWORKING SYSTEMS
SMALL ANGLE GRINDER
WS 12-125 XE
Features
ALSO AVAILABLE: WS 12-125 XE Kit – with kitbox, 3 x flap discs,
1 x flexible backing pad, 10 x fibre discs
• Powerful 1200 watt motor with outstanding performance
• Variable speed electronics for lower speed setting especially in finishing applications
• Constant speed for best performance and high torque, even in lower speed
applications
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece and work in restricted areas
• Optimised cooling slots prevent overheating, even when blocking occasionally
by hand
• Compact length and girth for comfortable use all day long
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard adjustment
• Fast and tool-free disc change with patented FIXTEC nut
• Spindle lock
Specification
Power input
No load speed
Cutting depth
1200 watt
2800–11.000 rpm
37 mm
Grinding disc Ø
125 mm
M14
Spindle thread
2,3 kg
Weight
Standard Equipment – AVS side handle, keyless safety guard, flange, FIXTEC nut,
spanner and 4 m cable
Cat No. WS 12-125 XE Article No. 4935 4194 30 Version. 220–240 V EAN No. 4002395130795
Cat No. WS 12-125 XE Kit Article No. 4935 4195 05 Version. 220–240 V EAN No. 4002395130870
5
sec
7
sec
9
sec
11
sec
12
sec
METALWORKING SYSTEMS 53
SMALL ANGLE GRINDER
WSC 14-125 MX
Features
• Powerful 1450 watt motor
• Digitronic with constant speed electronics, soft start, motor overload protection and
no load speed limitation
• FIXTEC – patented nut for fast and easy disc changing
• Automatic cut-off, easy change carbon brushes
• Flat metal gear head for excellent visibility of work piece and optimised cutting depth
• Epoxy coating field and armature – combat abrasive dust to increase tool lifetime
• New “snap-in” safety guard for keyless adjustment
• Spindle lock, with safety mechanism
• Large surface safety switch
Specification
Power input
No load speed
1450 watt
Grinding disc Ø
11.000 rpm
Spindle thread
33 mm
Cutting depth
Weight
125 mm
M14
2,5 kg
Standard Equipment – 4 m cable, additional handle, flange nut, safety guard
Cat No. WSC 14-125 MX Article No. 4935 4122 33 Version. 220–240 V EAN No. 4002395198368
SMALL ANGLE GRINDER
WSE 14-125 MX
Features
ALSO AVAILABLE: WSE 14-125 MX DMS
• Powerful 1450 watt motor
• Digitronic with variable speed preselection, soft start, motor overload protection
and no load speed limitation
• FIXTEC – patented nut for fast and easy disc changing
• Automatic cut-off, easy change carbon brushes
• Flat metal gearhead for excellent visibility of work piece and optimised cutting depth
• Epoxy coating field and armature – combat abrasive dust to increase tool lifetime
• New “snap-in” safety guard for keyless adjustment
• Spindle lock, with safety mechanism
• Large surface safety switch
Specification
Power input
No load speed
Cutting depth
1450 watt
2600–11.000 rpm
33 mm
Grinding disc Ø
125 mm
M14
Spindle thread
Weight
2,5 kg
Standard Equipment – 4 m cable, additional handle, FIXTEC nut, safety guard, flange
nut, kitbox
Cat No. WSE 14-125 MX Article No. 4935 4122 42 Version. 220–240 V EAN No. 4002395198375
Cat No. WSE 14-125 MX DMS Article No. 4935 4122 61 Version. 220–240 V DMS EAN No. 4002395198436
54 METALWORKING SYSTEMS
LARGE ANGLE GRINDER
WS 21-180 E
Features
Specification
• Powerful 2100 watt motor
• Epoxy-coated field windings and armature –
Power input
prevents accumulation
of abrasive dust, increasing tool life
• High quality sealed bearings provide superior
protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch
• Line lock out function for increased user protection
• Soft start for smooth startup
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
2100 watt
8300 rpm
43 mm
180 mm
M14
4,7 kg
Standard Equipment – 4 m cable, additional handle,
flange nut, safety guard and spanner
Cat No. WS 21-180 E Article No. 4935 4117 88 Version. 220–240 V EAN No. 4002395129881
LARGE ANGLE GRINDER
Features
• Powerful 2100 watt motor
• Epoxy-coated field windings and armature –
prevents accumulation of abrasive dust, increasing
tool life
• High quality sealed bearings provide superior
protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch
• Line lock out function for increased user protection
• Soft start for smooth startup
WS 21-230 E
ALSO AVAILABLE: WS 21-230 DMS (without Line lock out and Soft start function)
Specification
ALSO AVAILABLE: WS 21-230 E Kit – with kitbox
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
2100 watt
6400 rpm
68 mm
230 mm
M14
4,9 kg
Standard Equipment – 4 m cable, additional handle,
flange nut, safety guard and spanner
Cat No. WS 21-230 E Article No. 4935 4114 95 Version. 220–240 V EAN No. 4002395131037
Cat No. WS 21-230 DMS Article No. 4935 4115 05 Version. 220–240 V EAN No. 4002395131044
Cat No. WS 21-230 E/K Article No. 4935 4193 62 Version. 220–240 V with kitbox EAN No. 4002395193714
LARGE ANGLE GRINDER
WS 21-230 E GVX
Features
Specification
• Powerful 2100 watt motor
• AVS: additional handle and motor housing for more
Power input
comfort handling and less strain on body joints
• Epoxy-coated field windings and armature – prevents
accumulation of abrasive dust, increasing tool life
• High quality sealed bearings provide superior protection
• Rotating rear handle providing optimum comfort and
versatility
• FIXTEC nut for fast and easy disc changing
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch
• Line lock out function for increased user protection
• Soft start for smooth startup
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Standard Equipment – Safety guard, FIXTEC nut, antivibration additional handle, 4 m cable
Cat No. WS 21-230 E GVX Article No. 4935 4079 90 Version. 220–240 V EAN No. 4002395193455
Cat No. WS 21-230 GVX DMS Article No. 4935 4125 79 Version. 220–240 V EAN No. 4002395199068
ALSO AVAILABLE: WS 21-230 GVX DMS
(without Line lock out and Soft start function)
2100 watt
6600 rpm
68 mm
230 mm
M14
5,1 kg
METALWORKING SYSTEMS 55
LARGE ANGLE GRINDER
WS 24-180 E
Features
Specification
• Powerful 2400 watt motor
• Epoxy-coated field windings and armature –
Power input
prevents accumulation of abrasive dust, increasing
tool life
• High quality sealed bearings provide superior
protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch with soft start
• Line lock out function for increased user protection
• Soft start for smooth startup
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
2400 watt
8500 rpm
43 mm
180 mm
M14
5,0 kg
Standard Equipment – 4 m cable, flange nut, safety
guard, additional handle and spanner
Cat No. WS 24-180 E Article No. 4935 4170 40 Version. 220–240 V EAN No. 4002395193516
WS 24-230 E
LARGE ANGLE GRINDER
Features
Specification
• Powerful 2400 watt motor
• Epoxy-coated field windings and armature –
Power input
prevents accumulation of abrasive dust, increasing
tool life
• High quality sealed bearings provide superior
protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch with soft start
• Line lock out function for increased user protection
• Soft start for smooth startup
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Standard Equipment – 4 m cable, flange nut, safety
guard, additional handle and spanner
Cat No. WS 24-230 E Article No. 4935 4079 85 Version. 220–240 V EAN No. 4002395193479
Cat No. WS 24-230 DMS Article No. 4935 4126 24 Version. 220–240 V DMS EAN No. 4002395199181
ALSO AVAILABLE: WS 24-230 DMS
(without Line lock out and Soft start function)
2400 watt
6600 rpm
68 mm
230 mm
M14
5,1 kg
56 METALWORKING SYSTEMS
LARGE ANGLE GRINDER
Features
ALSO AVAILABLE: WS 24-230 GVX DMS
(without Line lock out and Soft start function)
• Powerful 2400 watt motor
• AVS: additional handle and motor housing for more comfort handling and less
strain on body joints
• Epoxy-coated field windings and armature – prevents accumulation of abrasive
dust, increasing tool life
• High quality sealed bearings provide superior protection
• Rotating rear handle providing optimum comfort and versatility
• FIXTEC nut for fast and easy disc changing
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch with soft start
• Line lock out function for increased user protection
• Soft start for smooth startup
Specification
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
WS 24-230 E GVX
2400 watt
6600 rpm
68 mm
230 mm
M14
5,3 kg
Standard Equipment – 4 m cable, FIXTEC nut, anti-vibration additional handle and safety
guard
Cat No. WS 24-230 E GVX Article No. 4935 4079 80 Version. 220–240 V EAN No. 4002395193462
Cat No. WS 24-230 GVX DMS Article No. 4935 4126 33 Version. 220–240 V DMS EAN No. 4002395199204
METALWORKING SYSTEMS 57
DIE GRINDER
GS 500 E
Features
• High speed, one handed die grinder
• Variable speed electronic
• Automatic cut-off carbon brushes
• High rotation precision metal gearbox
• Weight only 1,3 kg
• Ergonomic switch
Specification
500 watt
Power input
No load speed
10.000–29.000 rpm
6 mm
Collet diameter
Max. grinding wheel
diameter
Max. grinding pin
diameter
Weight
20 mm
(at 45 m/sec)
1,3 kg
40 mm
(at 80 m/sec)
Standard Equipment – Key, 6 mm collet, 4 m cable
Cat No. GS 500 E Article No. 4935 4129 85 Version. 220–240 V EAN No. 4002395192939
DIE GRINDER
GSL 600 E
Features
• Variable speed electronic
• Long spindle for easy access to awkward places
• Double bearing spindle seating for smooth rotation
• Automatic cut-off carbon brushes
• High rotation precision metal gearbox
• Weight only 1,9 kg
• Ergonomic switch
Specification
Power input
No load speed
Collet diameter
Max. grinding wheel
diameter
600 watt
10.000–29.000 rpm
6 mm
Max. grinding pin
diameter
Weight
40 mm
(at 80 m/sec)
Standard Equipment – Key, 6 mm collet, 4 m cable
Cat No. GSL 600 E Article No. 4935 4129 65 Version. 220–240 V EAN No. 4002395192946
20 mm
(at 45 m/sec)
1,9 kg
58 METALWORKING SYSTEMS
PE 150
POLISHER
Features
Specification
• 1200 watt polisher
• Variable speed electronics for various materials and
Power input
finishes
• Special gearing for high spindle torque and ideal
polishing speed
• Automatic cut-off carbon brushes
• Externally accessible brushes for easy replacement
• Spindle lock
• Large 3 finger switch
1200 watt
No load speed
900–2500 rpm
Polishing disc Ø
150 mm
M14
Spindle thread
2,1 kg
Weight
Standard Equipment – 4 m cable, additional handle,
cap, and backing pad
Cat No. PE 150 Article No. 4935 4122 66 Version. 220–240 V EAN No. 4002395198443
RIGHT ANGLE SANDER
SE 12-180
Features
Specification
• 1200 watt sander with full wave electronics
• Variable speed electronics for various materials and
Power input
finishing
• High motor torque and optimum speed range for
sanding,
especially for fine surface work
• Automatic cut-off carbon brushes
• Externally accessible brushes for easy replacement
• Spindle lock
• Large 3 finger switch
No load speed
Grinding disc Ø
Spindle thread
Weight
Standard Equipment – 4 m cable, additional handle
with guard, flange nut, flexible backing pad
Cat No. SE 12-180 Article No. 4935 4122 79 Version. 220–240 V EAN No. 4002395198481
1200 watt
1800–4800 rpm
180 mm
M14
2,5 kg
METALWORKING SYSTEMS 59
ABRASIVE METAL CHOPSAW
SMT 355
Features
• Powerful 2300 watt motor
• –45°/0°/45° mitre capacity with quick release mitre clamp
• Spindle lock for easy wheel and accessory changing
• Deflector protects the user from sparks
• Oversize guard for added safety
• On board wrench storage
• Rubber feet for greater stability
• Replaceable carbon brushes
Specification
Power input
No load speed
2300 watt
3800 rpm
Wheel diameter
355 mm
Bore diameter
25,4 mm
Weight
16,5 kg
Standard Equipment – 4 m cable, 355 mm cutting disc, spanner
Cat No. SMT 355 Article No. 4935 4117 70 Version. 220–240 V EAN No. 4002395129638
90º max 120x110mm
90º max 115mm
90º max 115mm
90º max 125mm
45º max 120x95mm
45º max 95mm
45º max 115mm
45º max 95mm
60
POWER
THROUGH
WOOD
AEG POWERTOOLS woodworking range offers
a comprehensive selection of high performance
machines to take on the most varied, professional
applications. All of these tools offer ease of
use, reliability, durability and features to ensure
professional efficiency and best results.
THE WOODWORKING RANGE
ROUTERS
PLANER
JIGSAWS
CIRCULAR SAWS
RECIPROCATING SAWS
SANDERS
TABLE SAW
MITRE SAW AND LEGSTAND
DUST EXTRACTION
HEAT GUNS
62 WOODWORKING SYSTEMS
COMBO ROUTER
MF 1400 KE
Features
• 2 routers in one for maximum flexibility in all kinds of
application
• Soft start to prevent sudden kickback
• Integrated electronics maintain constant speed under load
• Variable speed electronics for optimum control in a wide
range of materials
• Large soft-grip handles for decreased vibration and greater
comfort
• Flat motor housing with integrated rubber feet
for convenient upside down bit change with spindle lock
• Premium collet and shaft design minimises run out
• Built in LED for unparalleled workplace illumination
• Through table depth adjustment for ultimate convenience
PLUNGE BASE
Specification
Power input
Collet capacity
FIXED BASE
Standard Equipment – 5 guide bushes, 3 dust extraction adaptors, parallel guide,
2 collets (8/12 mm), 2 keys, oval base, round base, chip shield and contractors bag
Cat No. MF 1400 KE Article No. 4935 4118 50 Version. 220–240 V EAN No. 4002395193295
1400 watt
8/12 mm
Plunge capacity
64 mm
No load speed
10.000–23.000 rpm
Weight
5,7 kg
WOODWORKING SYSTEMS 63
ROUTER
OF 2050 E
Features
• Powerful 2050 watt motor
• Electronic variable speed control
• Plunge depth set by calibrated dial
• Micro depth adjustment
• 3-stage depth stop lock
• Vertical depth adjustment scales
Specification
Power input
Collet capacity
Plunge capacity
2050 watt
6/8/12 mm
No load speed
10.000–20.000 rpm
Weight
6,2 kg
66 mm
Standard Equipment – 4 m cable, 6/8/12 mm collet, spanner, parallel guide, 4 guide
bushes, router bit and dust adaptor
Cat No. OF 2050 E Article No. 4935 4036 65 Version. 220–240 V EAN No. 4002395125869
PL 750
PLANER
Features
• Powerful 750 watt motor
• Left and right chip ejection for greater convenience
• Heel shoe protects the base, blade and work surface
• 0,2 mm stage depth adjustment setting for greater control and accuracy
• Depth scale indicator
Specification
Power input
No load speed
Cutting depth
750 watt
Cutting width
82 mm
16.000 rpm
Max. rebate
12 mm
Weight
2,9 kg
2 mm
Standard Equipment – 2 blades, edge guide, dust bag, key
Cat No. PL 750 Article No. 4935 4191 40 Version. 220–240 V EAN No. 4002395130481
2.0 mm
64 WOODWORKING SYSTEMS
PALM JIGSAW
PST 500 X
Features
• Powerful 450 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• LED light for cut line visibility
• Pendulum function
• Unique palm design for use in tight spaces and easy handling
• Dust blower keeps cut line clear for accuracy
Specification
450 watt
Power input
3680 spm
No load stroke rate
45°
Mitre cutting angle to
15 mm
Stroke
Pendulum settings
Max. cutting depth in
wood/steel/plastic
1 Stage
13/5/15 mm
1,6 kg
Weight
Standard Equipment – Clear dust cap, splintering device, 1 saw blade, 4 m cable and
contractors bag
Cat No. PST 500 X Article No. 4935 4282 60 Version. 220–240 V EAN No. 4002395194315
TOPHANDLE JIGSAW
STEP 90 X
Features
• Powerful 600 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• 4-Stage pendulum adjustment
• Variable speed electronics for control
• Ergonomic design with integrated soft-grip for comfortable handling
• Dust extraction port
• Dust blower keeps cut line clear for accuracy
• Base plate can be moved backwards for cutting close to edges and for precise
mitre cuts to 45°
Specification
Power input
No load stroke rate
Mitre cutting angle to
Stroke
600 watt
1000–3200 spm
45°
19 mm
Pendulum settings
Max. cutting depth in
wood/steel/aluminium
4 Stages
100/8/15 mm
Weight
Standard Equipment – 4 m cable, blade, anti-splintering guard, dust cap and kitbox
Cat No. STEP 90 X Article No. 4935 4129 10 Version. 220–240 V EAN No. 4002395192816
2,0 kg
WOODWORKING SYSTEMS 65
BODYGRIP JIGSAW
ST 800 XE
Features
Specification
• Powerful 705 watt motor
• Patented FIXTEC system for changing saw blades in
Power input
seconds
• 4–Stage pendulum adjustment
• Variable speed electronics for control
• AVS anti-vibration mechanism for user comfort
• Ergonomic slimline bodygrip design with integrated
soft-grip
• Dust extraction port
• Dust blower keeps cut line clear for accuracy
• Base plate can be moved backwards for cutting
705 watt
600–2700 spm
No load stroke rate
45°
Mitre cutting angle to
26 mm
Stroke
4 Stages
Pendulum settings
Max. cutting depth in
wood/steel/aluminium
110/10/25 mm
2,3 kg
Weight
close to edges
Standard Equipment – 4 m cable, blade, anti splintering
guard, sliding shoe, dust cap and kitbox
Cat No. ST 800 XE Article No. 4935 4129 50 Version. 220–240 V EAN No. 4002395192892
TOPHANDLE JIGSAW
STEP 1200 BX
Features
Specification
• Powerful 600 watt motor
• Patented FIXTEC system for changing saw blades in
Power input
seconds
• 4–Stage pendulum adjustment
• Variable speed electronics for control
• AVS anti-vibration mechanism for user comfort
• Ergonomic top handle design with integrated soft-grip
• Sawdust blower keeps cutting line clear for accuracy
• Base plate can be moved backwards for sawing
600 watt
500–3000 spm
No load stroke rate
45°
Mitre cutting angle to
26 mm
Stroke
4 Stages
Pendulum settings
Max. cutting depth in
wood/steel/aluminium
110/10/30 mm
2,4 kg
Weight
close to edges and for precise mitre cuts to 45°
Standard Equipment – 4 m cable, blade, anti splintering
guard, sliding shoe, dust cap, suction adaptor and kitbox
Cat No. STEP 1200 BX Article No. 4935 4128 19 Version. 220–240 V EAN No. 4002395192694
BODYGRIP JIGSAW
Features
• Powerful 730 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• 4–Stage pendulum adjustment
• Variable speed selection for correct speed to match the material and blade
• Soft start prevents sudden kick back of machine on start up
• Integrated electronics allows constant speed under load
• AVS anti-vibration mechanism for user comfort
• Ergonomic and very slim body grip design with integrated soft-grip zone
• Dust extraction port
• Sawdust blower keeps cutting line clear for accuracy
• Adjustable dust extraction (front or back) over switch
• Base plate can be moved backwards for cutting close to edges and for
precise mitre cuts to 45°
Standard Equipment – 4 m cable, 1 saw blade, anti
splintering guard, dust cap, suction adaptor and kitbox
Cat No. STEP 1200 XE Article No. 4935 4128 78 Version. 220–240 V EAN No. 4002395192762
STEP 1200 XE
Specification
Power input
No load stroke rate
Mitre cutting angle to
Stroke
Pendulum settings
Max. cutting depth in
wood/steel/aluminium
Weight
730 watt
500–3000 spm
45°
26 mm
4 Stages
135/10/30 mm
2,4 kg
66 WOODWORKING SYSTEMS
MULTI CONSTRUCTION MATERIAL SAW
MBS 30 Turbo
Guide Rail 1,4 m
Article No. 4932 3525 58
EAN No. 4002395372164
Unique on board active dust
collection – patent pending
Features
• 75% dust collection efficiency – best in class!
• Comes complete with all dust collection components
• Height adjustment – for precise depth setting
• Powerful 1010 watt motor for cutting a wide range of materials quickly and easily
• Ergonomic inline motor design, well balanced for extended use
• Dust sealed gearbox design for optimal performance in dusty environments
• Lightweight magnesium guards and base for less user fatigue during extended use
• Spindle lock for quick and easy blade changes
Specification
Power input
No load speed
Standard Equipment – Premium 6 tooth fibre cement saw blade, premium 40 tooth saw
blade for accurate cuts in wood, diamond disc for tiles, granite, ceramic, cover & clamp
for dust free job site (for 10 l bucket), hose 2,60 m for dust extraction, second flange for
diamond disc, edge guard, allen key for quick saw blade change, delivered in box
Cutting depth 90°/45°
Saw blade/Arbor Ø
Weight
1010 watt
9000 spm
31/26 mm
127/20 mm
3,4 kg
Cat No. MBS 30 Turbo Article No. 4935 4118 20 Version. 220–240 V EAN No. 4002395193240
PLUNGESAW
TS 55 E
Features
• Powerful 1500 watt motor
• Smooth plunge action for precision cuts
• 55 mm cutting capacity (50 mm with guide rail)
• 0–45° bevel capacity
• Works with all common guide rails
• Soft-grip handle for comfort
Specification
Power input
No load speed
Mitre cutting angle to
1500 watt
0–1500 spm
45°
Max. cutting depth at 90°
55 mm
Max. cutting depth at 45°
50 mm
Saw blade/Arbor Ø
Weight
160/20 mm
4,6 kg
Standard Equipment – 4 m cable, 48 tooth TCT blade, spanner and kitbox
Cat No. TS 55 E Article No. 4935 4192 90 Version. 220–240 V EAN No. 4002395133130
Guide Rail 1,4 m
Article No. 4932 3525 58
EAN No. 4002395372164
WOODWORKING SYSTEMS 67
165 MM CIRCULAR SAW
KS 55 C
Features
Specification
• Powerful 1200 watt motor
• 0–50° bevel capacity with 45° positive position
Power input
1200 watt
No load speed
6100 spm
stop
• High strength composite shoe for durability
• Externally accessible brushes for easy replacement
• Integrated dust blower keeps cut line clear for
accuracy
• Soft-grip handle for comfort
0–50°
Bevel
Cutting depth 90/45/50°
Saw blade/Arbor Ø
54/45/38 mm
165/20 mm
3,7 kg
Weight
Adaptor to fit saw on guide rail
Article No. 4931 4165 18
EAN No. 4002395828807
Guide Rail 1,4 m
Article No. 4932 3525 58
EAN No. 4002395372164
Standard Equipment – Contractors bag, 4 m cable,
parallel fence, 24 tooth TCT blade, spanner
Cat No. KS 55 C Article No. 4935 4118 30 Version. 220–240 V EAN No. 4002395193141
185 MM CIRCULAR SAW
KS 66 C
Features
Specification
• Powerful 1600 watt motor for heavy duty
Power input
1600 watt
No load speed
5800 spm
applications
• 56° bevel capacity with 45° positive position stop
• Magnesium upper and lower guard offers lightweight
high strength
• Full length kerf indicator for accurate cutting
• Externally accessible brushes for easy replacement
• Integrated dust blower keeps cut line clear for
accuracy
• Soft-grip handle for comfort
Bevel
Cutting depth 90/45/56°
Saw blade/Arbor Ø
Weight
Standard Equipment – Contractors bag, 4 m cable,
parallel fence, 24 tooth TCT blade, spanner
Cat No. KS 66 C Article No. 4935 4118 40 Version. 220–240 V EAN No. 4002395193172
56°
61/49/35 mm
185/30 mm
4,8 kg
Guide Rail 1,4 m
Article No. 4932 3525 58
EAN No. 4002395372164
68 WOODWORKING SYSTEMS
US 400 XE
MINI RECIPROCATING SAW
Features
• Innovative design for confined spaces
• Extremely compact design
• Operational with one hand with exceptional balance
• 3500 strokes per minute and 13 mm stroke length for
fast cutting applications
• FIXTEC – for fast and easy keyless blade change
• Built-in LED
• 2-Finger variable speed trigger
Specification
Power input
No load stroke rate
400 watt
0–3500 spm
Length of stroke
13 mm
Weight
1,7 kg
Standard Equipment – 4 m cable, 3 blades and
contractors bag
Cat No. US 400 XE Article No. 4935 4118 14 Version. 220–240 V EAN No. 4002395193219
US 900 XE
RECIPROCATING SAW
Features
Specification
• Powerful 900 W motor, for fast cuts in various
Power input
materials
• Pendulum function with 19 mm stroke length, for more
powerful and faster cutting progress
• Speed regulation from 0–3500 spm, especially
needed for heat-sensitive materials
• FIXTEC – for fast and easy keyless blade change
• 24 % lighter than other saws, for better work control
• One hand blade insertion
• Soft-grip handle, for better ergonomics
No load stroke rate
900 watt
0–3500 spm
Length of stroke
19 mm
Weight
2,9 kg
Standard Equipment – 4 m cable, 3 blades and
contractors bag
Cat No. US 900 XE Article No. 4935 4196 10 Version. 220–240 V EAN No. 4002395193806
US 1300 XE
RECIPROCATING SAW
Features
• Powerful 1300 watt motor
• FIXTEC blade clamp for fast and easy blade change
• Variable speed switch for increased cutting control
and efficiency
• Adjustable shoe for prolonged blade life
• Ergonomic soft-grip handle design for comfort
• Blades can be turned 180° for various applications
Specification
Power input
No load stroke rate
1300 watt
0–2800 spm
Length of stroke
30 mm
Weight
3,8 kg
Standard Equipment – 4 m cable, 2 blades and kitbox
Cat No. US 1300 XE Article No. 4935 4132 35 Version. 220–240 V EAN No. 4002395197675
WOODWORKING SYSTEMS 69
EX 125 ES
RANDOM ORBIT SANDER
Features
• Ergonomic & compact 300 watt random orbit sander
• Ideal for working in confined spaces and over head
• Variable speed for optimum control
• Pad brake control: pad brake for a gauge free
workpiece
• Convenient hook & loop paper fastening
• Very efficient dust extraction over 8 holes in the base
plate
• Dust extraction, with dust bag or absorption system
• Soft-grip on handle
Specification
300 watt
Power input
No load speed
7000–15.000 rpm
Oscillation rate
14.000–30.000 opm
2 mm
Oscillation diameter
125 mm
Sanding disc size
1,5 kg
Weight
Standard Equipment – 4 m cable, 3 sheets (80, 120,
180 grit) sanding pads and dust bag
Cat No. EX 125 ES Article No. 4935 4161 00 Version. 220–240 V EAN No. 4002395129799
RANDOM ORBIT SANDER
Features
• Dual orbits for control of material removal
• Variable speed for optimum control
• Soft start and pad brake for a gauge free workpiece
• Through-body sealed slide switch for reliability and
ease of use
• Convenient hook & loop paper fastening
• Dust extraction, with dust bag or absorption system
• Diecast construction for strength and durability
EX 150 E
Specification
440 watt
Power input
No load speed
4000–10.000 rpm
Oscillation rate
8000–20.000 opm
Oscillation diameter
Sanding disc size
Weight
3,2/6,4 mm
150 mm
2,8 kg
Standard Equipment – 4 m cable, 3 x 80 grit sanding
pads, dust bag and pommel handle
Cat No. EX 150 E Article No. 4935 4132 00 Version. 220–240 V EAN No. 4002395197606
FDS 140
PALM DELTA SANDER
Features
• Extremely compact 280 watt sheet sander
• Ideal for working in confined spaces and over head
• Delta base for sanding in corners
• Hook & loop and large release tabs for convenient
paper changing
• Magnesium base for more stability and less vibration
• Dust extraction with dust bag or absorption system
• Soft-grip on handle
Specification
Power input
280 watt
No load speed
15.000 rpm
Oscillation rate
20.000 opm
Oscillation diameter
Sanding disc size
Weight
Standard Equipment – 4 m cable, 3 sheets (60, 80,
120 grit) sanding pad, delta base plate and dust bag
Cat No. FDS 140 Article No. 4935 4160 90 Version. 220–240 V EAN No. 4002395129768
1,6 mm
115 x 140 mm
1,5 kg
70 WOODWORKING SYSTEMS
1
⁄2 SHEET SANDER
Features
• Powerful 440 watt motor
• Variable speed for optimum control
• Convenient hook & loop paper fastening
• Dust extraction, with dust bag or absorption system
FS 280
Specification
440 watt
Power input
Oscillation rate
14.000–26.000 opm
Sanding surface
Weight
115 x 280 mm
3,0 kg
Standard Equipment – 4 m cable, 3 sheets (80, 120,
240 grit) sanding pads, dust bag and pommel handle,
bag
Cat No. FS 280 Article No. 4935 4192 80 Version. 220–240 V EAN No. 4002395133116
BELT SANDER
Features
• Powerful 1010 watt motor
• Electronic speed for control and optimum results
• Clamping lever for easy, tool free changing of
sanding belt
• Externally accessible brushes for easy replacement
• Control wheel for precise adjustment of sanding belt
• Compact design, ideal for sanding close to edges
• Die-cast construction for high strength and durability
• Dust extraction, with dust bag or absorption system
HBS 1000 E
Specification
Power input
1010 watt
Belt length
533 mm
Belt speed
240–450 m/min
Sanding surface
75 x 145 mm
Belt width
75 mm
Weight
5,1 kg
Standard Equipment – 4 m cable, 1 x 80 grit sanding
belt, dust bag, pommel handle and kitbox
Cat No. HBS 1000 E Article No. 4935 4132 05 Version. 220–240 V EAN No. 4002395197613
BELT SANDER
Features
• Powerful 1100 watt motor
• Extra-large sanding surface 100 x 140 mm
• Full-wave electronics with pre-selection of belt speed
• Control wheel for precise adjustment of belt
alignment
• Dust extraction, with dust bag or absorption system
BBSE 1100
Specification
Power input
1100 watt
Belt length
560 mm
Belt speed
230–400 m/min
Sanding surface
Belt width
Weight
Standard Equipment – 4 m cable, 1 x 100 grit sanding
belt and dust bag
Cat No. BBSE 1100 Article No. 4935 4135 30 Version. 220–240 V EAN No. 4002395199037
100 x 140 mm
100 mm
5,0 kg
WOODWORKING SYSTEMS 71
TABLE SAW
TS 250 K
Features
• Powerful 1800 watt motor
• 4800 rpm for effortless accurate cutting
• 90 mm cutting depth (53 mm at 45°)
• Dual clamping parallel fence for high stability and accuracy
• Overload protection ensures durability
• Soft start
• Integrated table side extension up to 645 mm gives huge
cutting capacity
• Collapsible stand with wheels and height adjustment for
easy transportation and portability
• On board storage for all tools and spare blades
Specification
Power input
1800 watt
Blade diameter
254 x 30 mm
No load speed
4800 rpm
Mitre capacity (left/right)
Depth of cut 90/45°
Weight
45°
90/62 mm
41,0 kg
Standard Equipment – 36 tooth TCT blade, rip fence, mitre gauge and fence, collapsible
stand with wheels, push stick, wrench
Cat No. TS 250 K Article No. 4935 4192 65 Version. 220–240 V EAN No. 4002395133093
72 WOODWORKING SYSTEMS
SLIDING COMPOUND MITRESAW
Features
Specification
• Powerful 1800 watt motor delivers 4400 rpm
• Large cutting capacities include a massive maximum
Power input
crosscut of 343 x 111 mm at 90°
• Double bevel 0–47° left or right
• Mitres 60° left or right, perfect for awkward mitres
• Rugged cast construction with huge table area
• Cam operated mitre lock for fast angle adjustment
PS 305 DG
1800 watt
Blade diameter
305 x 30 mm
No load speed
4400 rpm
Mitre capacity (left/right)
60°
Depth of cut
111 mm
Crosscut capacity
343 mm
Weight
31,0 kg
Standard Equipment – 60 tooth 305 mm blade
Cat No. PS 305 DG Article No. 4935 4115 70 Version. 220–240 V EAN No. 4002395126002
UNIVERSAL MITRE SAW LEGSTAND
Features
• Extendable to 2,5 m
• Folds in half for easy transportation and storage
• Lightweight construction for portability
• 250 kg maximum load
Cat No. PSU 2500 Article No. 4935 4115 85 EAN No. 4002395129621
PSU 2500
VACUUM CLEANERS 73
AP 250 ECP
25 L VAC
Standard Equipment – Tool adaptor, hand tube, 2 x extension tube, floor nozzle, crevice
nozzle, hose 32 mm x 3,5 m, fleece filter bag, disposal bag
AP 300 ELCP
30 L VAC
Standard Equipment – Tool adaptor, hand tube, 2 x extension tube, floor nozzle, crevice
nozzle, hose 32 mm x 3,5 m, fleece filter bag, disposal bag, accessory box
Product
Specification
Features
Application
Art. No.
4935-
EAN No.
4002395-
AP 250 ECP
Power input max. – 1400 watt
Air volume – 3600 l/min
Max. vacuum – 190 mbar
Container capacity – 25 l
Suction hose diameter/length –
32 mm x 3,5 m
Weight – 6,0 kg
• CLEAR-PRESS filter cleaning system
• Wet & dry cleaning
• Wet overfill protection
• Click system – easy to change accessories
• Fleece double wall filter bag and disposal bag
Wet & dry dust
extraction in external
environments, wet
cleaning, general
cleaning
411880
131051
Wet & dry dust
extraction in external
environments, wet
cleaning, general
cleaning
411890
131068
AP 300 ELCP
Dust class L
standard
MAK-factor
> 1 mg/m3
Power input max. – 1500 watt
Air volume – 3700 l/min
Max. vacuum – 250 mbar
Container capacity – 30 l
Suction hose diameter/length –
32 mm x 3,5 m
Weight – 10,0 kg
• CLEAR-PRESS filter cleaning system
• PET filter cartridge
• Automatic operation when used with
powertools
• Dust class L for dust rated up to 1 mg/m3
• Low noise fan for silent cleaning
• Wet & dry cleaning
• Fleece double wall filter bag and disposal bag
DUST BUSTING POWER!!!
CLEAR-PRESS
FILTER
CLEANING
SYSTEM
EXPLAINED:
Accessories
Filter cartridge
Press the button
AP 250
ECP
●
●
Filter cartridge
Close the
aspirating port
High speed
airstream
cleans filter
Filter bags: 5 pcs
(4 x fleece filter bags, 1 x fleece wet
filter with rubber band)
AP 300
ELCP
●
Art. No.
4932-
EAN No.
4002395-
352303
369621
352304
369638
352306
369652
Filter bags:
5 x fleece filter bags. Capacity 30 l
●
352307
369669
Extension hose, anti static.
4 m long 36 mm diameter
with tool adaptor
●
352311
369706
●
352312
369713
Extension hose.
3,5 m long 32 mm diameter
with tool adaptor
●
74 WOODWORKING SYSTEMS
HEAT GUN
Features
• 2 temperature adjustment modes 300°/560°
• 400–450 l/min
• Reinforced fan for continuous use
• Extremely light product – 0,6 kg
• Rubber overmold on back end for safe stationnary
HG 560 D
Specification
Power input
Air flow
Temperature control
Weight
1500 watt
400–450 l/min
300/560° C
0,85 kg
use
NEW
0.85kg
Cat No. HG 560 D Article No. 4935 4410 15 Version. 220–240 V EAN No. 4002395134991
HEAT GUN
HG 600 V
Features
Specification
• Electronic precise adjustement of temp from
Power input
90° up to 600°
• 300–500 l/min
• Reinforced fan for continuous use
• Extremely light product – 0,9 kg
• Rubber overmold on back end for safe stationnary
use
Air flow
Temperature control
Weight
2000 watt
300–500 l/min
90–600° C
0,9 kg
NEW
Cat No. HG 600 V Article No. 4935 4410 25 Version. 220–240 V EAN No. 4002395135011
HEAT GUN
Features
• Electronic precise adjustement of temp from
90° up to 600°
• 300–500 l/min
• Reinforced fan for continuous use
• Extremely light product – 0,9 kg
• Delivered in case with 3 nozzles
• Rubber overmold on back end for safe stationnary
use
HG 600 VK
Specification
Power input
Air flow
Temperature control
Weight
2000 watt
300–500 l/min
90–600° C
0,9 kg
NEW
Cat No. HG 600 VK Article No. 4935 4410 35 Version. 220–240 V EAN No. 4002395135035
ACCESSORIES 75
ACCESSORIES
POWER SET SDS-PLUS DRILL BITS
• High quality 2 cutter carbide tip with 130° tip angle
• The carbide tip is set deeper into the head for a more precise fit and better durability
• 2 flute geometry for rapid material removal
• Surface treated flute eliminates binding for faster drilling and high abrasion resistance
• High quality robust and compact power set with secure lock
• Made in Germany
Art. No.
4932-
EAN No.
4002395-
Counter display (12 x sets)
352315
369744
Single Power Set SDS-Plus Drill Bits (8pcs)
Contents:
Ø 5 / 6 / 8 x 110 mm and Ø 6 (2pcs) / 8 / 10 / 12 x 160 mm
352236
368952
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352238
368976
Single Power Set Stone Drill Bits (10pcs)
Contents:
Ø 5 / 5.5 / 6 (2pcs) / 7 / 8 (2pcs) / 9 / 10 mm
352239
368983
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352240
368990
Single Power Set HSS-R Drill Bits (19pcs)
Contents:
Ø 2 x 49 mm / Ø 2.5 (2pcs) x 57 mm / Ø 3 (2pcs) x 61 mm / Ø 3.5 (2pcs) x 70 mm /
Ø 4 (2pcs) x 75 mm / Ø 4.5 (2pcs) x 80 mm / Ø 5 (2pcs) x 86 mm / Ø 6 (2pcs) x 93 mm /
Ø 7 x 109 mm / Ø 8 x 117 mm / Ø 9 x 125 mm / Ø 10 x 133 mm
352241
369003
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352242
369010
Single Power Set HSS-G Drill Bits (19pcs)
Contents:
Ø 2 x 49 mm / Ø 2.5 (2pcs) x 57 mm / Ø 3 (2pcs) x 61 mm / Ø 3.5 (2pcs) x 70 mm /
Ø 4 (2pcs) x 75 mm / Ø 4.5 (2pcs) x 80 mm / Ø 5 (2pcs) x 86 mm / Ø 6 (2pcs) x 93 mm /
Ø 7 x 109 mm / Ø 8 x 117 mm / Ø 9 x 125 mm / Ø 10 x 133 mm
352243
369027
POWER SET STONE DRILL BITS
• Extra sharp diamond ground carbide tip with 130° angle
• Polished silver and black finish eliminates binding for faster cutting and material removal
• Made from special alloy steel for best precision and robustness
• High quality robust and compact power set with secure lock
POWER SET HSS-R (DIN 338) METAL DRILL BITS
• HSS-Rollforged metal drill bits manufactured according to DIN 338
• Oxide coating for improved swarf removal
• Normal point cutting tip with 118° angle
• Standard type N flute design
• High quality robust and compact power set with secure lock
POWER SET HSS-G (DIN 338) METAL DRILL BITS
• Fully ground drill bits according to DIN 338
• Standard tip for cutting geometry with 118° angle
• Standard type N flute design for faster chip removal and faster cutting
• High quality robust and compact power set with secure lock
76 ACCESSORIES
ACCESSORIES
POWER SET HSS-G TIN DRILL BITS
• Metal drill bits ground from high speed steel according to DIN 338
• Normal point cutting tip with 118° angle
• Standard type N flute design
• Titanium nitride coating increases cutting speed by 50% and lifetime by 300%
• High quality robust and compact power set with secure lock
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352244
369034
Single Power Set HSS-G TiN Drill Bits (19pcs)
Contents:
Ø 2 x 49 mm / Ø 2,5 (2 pcs) x 57 mm / Ø 3 (2 pcs) x 61 mm / Ø 3,5 (2 pcs) x 70 mm /
Ø 4 (2 pcs) x 75 mm / Ø 4,5 (2 pcs) x 80 mm / Ø 5 (2 pcs) x 86 mm / Ø 6 (2 pcs) x 93 mm /
Ø 7 x 109 mm / Ø 8 x 117 mm / Ø 9 x 125 mm / Ø 10 x 133 mm
352245
369041
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352246
369058
Single Power Set Lip & Spur Wood Drill Bits (8pcs)
Contents:
Ø 3 x 60 mm / Ø 4 x 75 mm / Ø 5 x 85 mm / Ø 6 x 97 mm / Ø 7 x 104 mm / Ø 8 x 117 mm /
Ø 9 x 120 mm / Ø 10 x 133 mm
352247
369065
POWER SET LIP & SPUR WOOD DRILL BITS
• Manufactured from chrome vanadium steel according to DIN 7487 E
• Center point guarantees precise positioning
• Sharpened shoulders provide for clean holes avoiding splintering
• High quality robust and compact power set with secure lock
POWER SET HSS-G (DIN 338) METAL DRILL BITS & SCREWDRIVING BITS
• Metal drill bits ground from high speed steel according to DIN 338
• Normal point cutting tip with 118° angle
• Standard type N flute design
• Screwdriving bits are milled from S2 steel
• High quality robust and compact power set with secure lock
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352248
369072
Single Power Set HSS-G & Screwdriving bits (35pcs)
Contents:
Ø 2 / 2,5 / 3 / 3,2 / 3,5 / 4 / 4,5 / 6 / 8 / 10 mm
25 mm length: PH1 (2pcs) / PH2 (2pcs) / PH3 (2pcs) / PZ1 (2pcs) / PZ2 (2pcs) / PZ3 (2pcs) /
TX10 (2pcs) / TX15 (2pcs) / TX20 (2pcs) / TX25 (2pcs) / TX30 / TX40
50 mm length: PH2 / PZ2
1
⁄4˝ Hex magnetic bit holder
352249
369089
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352252
369119
Single Power Set Jigsaw Wood & Metal (50pcs)
Contents:
10 x T 144 D / 10 x T 101 B / 15 x T 118 A / 15 x T 118 B
352253
369126
POWER SET JIGSAW BLADES FOR WOOD & METAL
• Wood applications:
T144D – Fast cutting
T101B – Very clean, splinter free cutting
• Metal applications:
T118A – Cutting of thin sheet material Ø 1,5–4 mm
T118B – Cutting of thicker material 3–6 mm
• High quality robust and compact power set with secure lock
ACCESSORIES 77
ACCESSORIES
POWER SET SCREWDRIVING BITS
• Coldfire is a special hardening treatment for making metals stronger , tougher and more durable. This cryogenic
pro cess is a one-time permanent treatment affecting the entire screwdriving bit and it is not just a surface coating.
The cryogenic process consists of two steps, firstly the bit is hardened by heating it up to 870° and then freezing the
bit down to -148° using a dry nitrogen atmosphere. The result of this process is a bit with exceptional durability
• + 40% stronger - bit tips hold their form and will accept higher torque forces
Art. No.
EAN No.
• + 45% longer life - over the lifetime of a bit one can expect to drive 45% more screws
49324002395Counter display (6 x sets)
352254
369133
Single Power Set Screwdriving Bits (40pcs)
Contents:
25 mm length: PH1 / PH2 (2pcs) / PH3 / PZ1 (2pcs) / PZ2 (2pcs) / PZ3 (2pcs) / TX6 / TX7 /
TX8 / TX9 / TX10 (2pcs) / TX15 (2pcs) / TX20 (2pcs) / TX25 (2pcs) / TX30 / TX40 / Hex 3 /
Hex 4 / Hex 5 / Hex 6 / SL 0,6 x 4,5 / SL 0,8 x 5,5 / SL 1,0 x 5,5 / SL 1,2 x 6,5
50 mm length: PH1 / PH2 / PZ1 / PZ2 / TX10 / TX15 / TX20
1
⁄4˝ Hex magnetic bit holder
352255
369140
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352460
368976
Single Profi-Box HSS-R Drill Bits (19pcs)
Contents:
Ø 1–10 mm in 0,5 mm incrementals
352459
371181
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352462*
371211
Single Profi-Box HSS-G Drill Bits (19pcs)
Contents:
Ø 1–10 mm in 0,5 mm incrementals
352461*
371204
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352464
371235
Single Maxi-Mix Drill Bits (18pcs)
Contents:
Stone drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
HSS-R drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
Wood drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
352463
371228
PROFI-BOX HSS-R (DIN 338) METAL DRILL BITS
• HSS-Rollforged metal drill bits manufactured according to DIN 338
• 118° cutting tip angle
• Oxide coating for improved swarf removal
• Robust metal box
PROFI-BOX HSS-G (DIN 338) METAL DRILL BITS
• Fully ground drill bits according to DIN338
• 118° cutting tip angle
• Robust metal box
MAXI-MIX DRILL BITS
• Fully ground drill bits according to DIN 338
• Standard tip for cutting geometry with 118° angle
• Standard type N flute design for faster chip removal and faster cutting
• High quality robust and compact power set with secure lock
* while stocks last
78 ACCESSORIES
ACCESSORIES
WB1 SET – SCREWDRIVER ANGLE ATTACHMENT WITH 10 SCREWDRIVING BITS
• Contents: WB1 and screwdriving bits 25 mm PH1 / PH2 / PZ1 / PZ2 (2pcs) / TX15 / TX20 / Hex 4 / Hex 5
• Being only 30 mm high it is ideally suited to working in confined and limited spaces
• Fits to all machines. The ¼˝ Hex shank fits directly into the chuck preventing slippage
• Magnetic ¼˝ Hex reception. Accepts standard ¼˝ Hex screwdriving bits
• Adjustable to working situation. 360° variable thumb lever for extra grip
• Industrial quality up to 11 Nm torque and 400 min–1
• Tough gears made of special hardened steel
Art. No.
4932-
EAN No.
4002395-
Counter display (12 x WB1 Sets)
430173
378340
Single WB1 – screwdriver angle attachment with 10 screwdriving bits
430174
378357
Art. No.
4932-
EAN No.
4002395-
Counter display (20 x sets)
399494
361144
Single Maxi-Bit screwdriving set (10pcs)
Contents:
SL 0,6 x 4,5 / SL 0,8 x 5,5 / SL 1,5 x 6,5 / PH1 / PH2 / PH3 / PZ1 / PZ2 / PZ3
1
⁄4˝ Hex magnetic bit holder
399493
361151
Art. No.
4932-
EAN No.
4002395-
Counter display (20 x sets)
399496
361168
Single Profi-Bit screwdriving set (17pcs)
Contents:
SL 0,8 x 5,5 / SL 1,2 x 6,5 / PH1 / PH2 (2pcs) / PH3 / PZ1 / PZ2 (2pcs) / PZ3 / TX10 / TX15 /
TX20 / TX25 / TX30 / TX40
1
⁄4˝ Hex magnetic bit holder
399495
361175
MAXI-BIT SCREWDRIVING SET
PROFI-BIT SCREWDRIVING SET
FIXTEC NUTS
• FIXTEC: Disc changing in seconds, no extra tools required
• 12 seconds from removing the worn disc to fixing a new disc
• Only 8 mm thin, enabling more surface of disc on the material
• Compatible to all manufacturers angle grinders up to 150 mm with standard M14 spindle thread
• With integrated keyholes, for removal of the nut with a standard pin spanner in the event of the nut becoming too tight
5
sec
7
sec
9
sec
11
sec
12
sec
Art. No.
4932-
EAN No.
4002395-
Counter display (12 x FIXTEC Nut)
358936
326693
Single FIXTEC Nut
358225
325528
ACCESSORIES 79
ACCESSORIES
RETRO SCREWDRIVING BITS
• COLDFIRE quality bits. + 40% stronger – bit tips hold their form and will accept higher torque forces;
+ 45% longer life – over the lifetime of a bit one can expect to drive 45% more screws
• New merchandising concept – Compact Tin box with best seller assortment
• Collectable box with 2 new box designs a year
• Metal counter display – open type display for good product visibility
Art. No.
4932-
EAN No.
4002395-
Counter display (20 x sets)
430004*
376650
Single Retro Bits box (9pcs)
Contents:
SL 0,6 x 4,5 / SL 0,8 x 5,5 / PH2 / PZ2 / PZ3 / TX25 / Hex 4 / Hex 5
1
⁄4˝ Hex magnetic bit holder
430003*
376643
MULTIMIX SET 75PCS – DRILLING AND SCREWDRIVING SET
Art. No.
4932-
EAN No.
4002395-
352670
373284
Contents:
Screwdriving bits 25 mm length
1 x PH 0 / 1 x PH 1 / 3 x PH 2 / 1 x PH 3 / 1 x PZ 0 / 1 x PZ 1 / 3 x PZ 2 / 1 x PZ 3 /
1 x SQ 1 / 1 x SQ 2 / 1 x SQ 3 / 1 x TX 10 / 1 x TX 15 / 1 x TX 20 / 1 x TX 25 / 1 x TX 30 /
1 x TX 40 / 1 x Hex 4 / 1 x Hex 5 / 1 x Hex 6 / 1 x SL 3 / 1 x SL 4 / 1 x SL 5 / 1 x SL 6 /
1 x SL 7 / 1 x SL 8
1
⁄4˝ Hex magnetic bit holder
Screwdriving bits 50 mm length
1 x PH 2 / 1 x PZ 2 / 1 x SL 4 / 1 x SL 6 / 1 x SL 8
Nut drivers
1 x 5 mm / 1 x 6 mm / 1 x 7 mm / 1 x 8 mm / 1 x 10 mm / 1 x 12 mm
Metal drill bits HSS-R DIN 338
2 x 1 mm / 1 x 1,5 mm / 1 x 2 mm / 1 x 2,5 mm / 1 x 3 mm / 1 x 3,5 mm / 1 x 4 mm
Lip & Spur wood drill bits
3 x 3 mm / 3 x 4 mm / 2 x 5 mm / 1 x 6 mm / 1 x 7 mm / 1 x 8 mm / 1 x 10 mm
Countersink with 1⁄4˝ Hex reception 45°
Masonry drill bits
1 x 4 mm / 1 x 5 mm / 1 x 5,5 mm / 3 x 6 mm / 1 x 6,5 mm / 2 x 7 mm / 1 x 8 mm /
1 x 10 mm / 1 x 12 mm
* while stocks last
80 ACCESSORIES
ACCESSORIES
SDS-PLUS DRILL BITS – 2 CUT / 10 PIECE POWER PACKS
High quality 2 cutter carbide tip with 130° tip angle. The carbide tip is set deeper into the head for a more precise fit and better durability. 2 flute
geometry for rapid material removal. Surface treated flute eliminates binding for faster drilling and high abrasion resistance. Made in Germany.
Ø
mm
A
mm
B
mm
Quantity
Art. No.
4932-
5
110
50
10
352256
369157
5,5
110
50
10
352257
369164
EAN No.
4002395-
6
110
50
10
352258
369171
6
160
100
10
352259
369188
7
160
100
10
352260
369195
8
110
50
10
352261
369201
8
160
100
10
352262
369218
8
210
150
10
352263
369225
10
160
100
10
352264
369232
10
210
150
10
352265
369249
10
260
200
10
352266
369256
12
160
100
10
352267
369263
12
210
150
10
352268
369270
352236
368952
352653
373116
Power Set 8pcs – SDS-plus drill bits
B
A
with Ø 5 / 6 / 8 x 110 mm and Ø 6 (2 pcs) / 8 / 10 / 12 x 160 mm
SDS-plus Starter Set
with Ø 6 / 8 / 10 x 160 mm, point chisel and flat chisel
SDS-MAX DRILL BITS – 2 CUT
Ø
mm
A
mm
B
mm
Quantity
Art. No.
4932-
EAN No.
4002395-
16
540
400
1
352687
373451
18
540
400
1
352688
373468
20
520
400
1
352689
373475
22
520
400
1
352690
373482
25
520
400
1
352691
373499
28
570
450
1
352692
373505
30
570
450
1
352693
373512
32
570
450
1
352694
373529
B
A
SDS-PLUS CHISELS
Description
A
mm
B
mm
Quantity
Art. No.
4932-
EAN No.
4002395-
Point chisel
200
Flat chisel
200
–
1
352269
369287
20
1
352270
369294
Wide chisel
200
35
1
Set of 3 SDS-plus chisels with 1 pointed, 1 flat, 1 wide chisel
352271
369300
352272
369317
Art. No.
4932-
EAN No.
4002395-
A
B
B
SDS-MAX CHISELS
Description
A
mm
B
mm
Quantity
Point chisel
400
–
1
352685
373437
Flat chisel
400
25
1
352686
373444
Quantity
Art. No.
4932-
EAN No.
4002395-
12
354236
320639
ROUTER BIT SET
Description
8 mm shank
A
B
ACCESSORIES 81
ACCESSORIES
MASONRY DRILL BITS
Carbide tip with diamond ground cutting edges with 130° angle – For drilling in brick and aerated concrete blocks
Ø
A
B
Quantity
mm
mm
mm
4
75
40
1
5
85
50
1
5,5
85
50
1
6
100
60
1
6
150
85
1
7
100
60
1
8
120
80
1
8
200
135
1
10
120
80
1
10
200
135
1
12
150
85
1
Power Set 10pcs – masonry drill bits with Ø 4 / 5 / 5,5 / 6 (2 pcs) / 7 / 8 (2 pcs) / 9 / 10 mm
Art. No.
4932363591
363593
363595
363597
367032
363599
363600
363612
363602
363613
363604
352239
EAN No.
4002395332410
332434
332458
332472
333967
332496
332502
332366
332526
332373
332540
368983
B
A
HIGH PERFORMANCE BI-METAL HOLESAWS / SYSTEM ACCESSORIES
Ø
mm
14
16
19
20
21
22
24
25
27
29
30
32
35
Ø
Inch
9
⁄16
5
⁄8
3
⁄4
25
⁄32
13
⁄16
7
⁄8
15
⁄16
1
1 1⁄16
1 1⁄8
1 3⁄16
1 1⁄4
1 3⁄8
Art. No.
4932367244
367245
367247
367248
367249
367250
367251
367252
367253
367289
367254
367255
367256
EAN No.
4002395335947
335954
335978
335985
335992
336005
336012
336029
336036
336043
336050
336067
336074
Ø
mm
38
40
43
44
48
51
54
57
60
64
65
68
70
Ø
Inch
1 1⁄2
1 9⁄16
1 11⁄16
1 3⁄4
1 7⁄8
2
2 1⁄8
2 1⁄4
2 3⁄8
2 1⁄2
2 9⁄16
2 11⁄16
2 3⁄4
Art. No.
4932367257
367258
367259
367260
367262
367263
367265
367266
367267
367268
367269
371580
367271
FIXTEC arbor 5⁄8˝ x 18 → 11 mm Hex for holesaws Ø 32 – 152 mm
Arbor 1⁄2˝ x 20 → Light duty arbor 1⁄2˝ x 20 Hex 9 for holesaws Ø 14 – 30 mm
Pilot drill bit long For use with arbor 4932367421
Pilot drill bit short For use with arbor 4932367422
EAN No.
4002395336081
336098
336104
336111
336135
336142
336166
336173
336180
336197
336203
345250
336227
Ø
mm
73
76
79
83
89
92
98
102
105
114
121
127
152
Art. No.
4932-
EAN No.
4002395-
367421
367422
367423
367424
337422
337439
337446
337453
Ø
Inch
2 7⁄8
3
3 1⁄8
3 1⁄4
3 1⁄2
3 5⁄8
3 7⁄8
4
4 1⁄8
4 1⁄2
4 3⁄4
5
6
Art. No.
4932367272
367273
367274
367275
367277
367278
367280
367281
367282
367284
367285
367286
367288
EAN No.
4002395336234
336241
336258
336265
336289
336296
336319
336326
336333
336357
336364
336371
336395
82 ACCESSORIES
ACCESSORIES
Ref. No.
Quantity
3
T 111 C
5
50
1,35 T 101 AO
Application
Rough cutting
5
Cu/Ni/Ms/Zn
ALU
DEPTH OF CUT (mm)
EAN No.
4002395-
Tooth pitch
mm
75
METAL
Art. No.
4932-
Blade length
(toothed) mm
JIGSAW BLADES FOR WOOD / PLASTICS / METAL
5–60
-
-
< 40
-
-
-
352144 367979
Fast, clean, curve cutting
< 20
-
< 20
< 15
-
-
-
352145 367986
75
4
T 244 D
5
Rough, curve cutting
< 60
-
-
-
-
-
-
352146 367993
75
4
T 144 D
5
Fast, rough cutting
< 60
-
-
-
-
-
-
352147 368006
75
2,5
T 101 B
5
Very clean, splinter free cutting
< 30
< 60
-
< 30
-
-
-
352148 368013
75
4
T 101 D
5
Fast, clean, splinter free cutting
< 60
< 60
-
< 45
-
-
-
352149 368020
55
1,2
T 118 A
5
For thin sheet metal
-
-
-
-
1,5–4
1,5–4
-
352150 368037
55
2
T 118 B
5
Rougher cuts in metal
-
-
-
-
3–6
3–6
3–10
352151 368044
12 piece set in container
Suitable for applications in wood, cutting worktops and laminate flooring and metals
373494 349944
Power Set 50pcs – jigsaw blades for wood and metal
10 x T 144 D, 15 x T 118 A, 10 x T 101 B, 15 x T 118 B
352253 369126
Ref. No.
Quantity
2,5
S811H
3
All woods, nail embedded wood, plaster board 3–100 mm, non-ferrous metals, aluminium 3–10 mm, plastic pipes
318127 301959
150
4,2
S744D
2
Fast scroll cutting 6 –100 mm
323801 304240
150
4
S644D
2
Fast cutting of wood and plastic, plunge cutting, 6–100 mm
323800 304233
240
8,5
S1542K
2
Special hardened teeth design, fast coarse cut, as well for green and fire wood, 20–180 mm
323804 304271
300
4,2
S1344D
2
Fast cutting large timbers and plastic, clean cut, 6–250 mm
323802 304257
150
1,4
S922EF
3
For all metals with a wall thickness between 1,5–4 mm
354792 324477
150
1,8
S922BF
3
For all metals with a wall thickness between 3–10 mm
354789 324446
230 Coarse grit S1130R
2
For abrasive materials, fibreglass materials (polyesters, epoxies, melamines), cast iron pipes
373386 348817
EAN No.
4002395-
Tooth pitch
mm
150
Application
Art. No.
4932-
Blade length
(toothed) mm
RECIPROCATING SAW BLADES FOR WOOD / PLASTICS / METAL
ACCESSORIES 83
ACCESSORIES
GUIDE RAIL
Description
Art. No.
4932-
EAN No.
4002395-
GR 1400 Guide rail 1400 mm long. Supplied with carry-bag. Adaptors to fix guide rail
to following machines: MBS 30: 4931 4118 18, KS 55 C (only suitable for machines with
production date after 6/2010) / KS 66 C (only suitable for machines with production date
after 8/2011): 4931 4165 18, CS 60: 4931 4165 18
352558
372164
Connector piece For combining two guide rails together
352559
372171
Clamps Set of 2 clamps for fixing the guide rail to the work material
352560
372188
➀
➁
➂
➃
127
127
160
160
165
165
➄ 184
➁
➀
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
➂
➃
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Clean /
Fine cut
Non ferrous
1,8
1,8
2,2
2,2
2,6
2,8
1,8
Plasterboard
6
40
48
48
24
52
24
Plastics
20
20
20
20
20
20
30
Plywood &
OSB boards
Cutting
width
(kerf) mm
Laminated
chipboard
Number
of teeth
MDF /
Fibreboard
B
mm
Chipboard
A
mm
Fibre cement
board
CIRCULAR SAW BLADES
✓
✓
✓
✓
✓
✓
Art. No.
4932-
EAN No.
4002395-
352534
352535
352868
352869
430311
430312
352874
371921
371938
375264
375271
379729
379736
375325
➄
ATTACHMENTS
Description
Xtractor
Art. No.
4932-
EAN No.
4002395-
373501
351862
The ideal dust extraction solution.
The Xtractor can be used with all household vacuum cleaners and
industrial dust extraction units with a hose diameter from 26–41 mm.
✗
✓
SYSTEM ACCESSORIES – HOT AIR GUNS
Description
Qty
Art. No.
4932-
EAN No.
4002395-
➀ Flat jet nozzle
1
312435
300518
➁ Round jet nozzle Ø 12 mm
1
312436
300525
➀
➁
84 ACCESSORIES
ACCESSORIES
UNIVERSAL
UNIVERSAL
ACCESSORIES FOR OSCILLATING TOOL
Universal blade reception makes AEG blades compatible with most popular oscillating tools.
Description
➀ Bi-Metal plunge cutting blade
Application:
Wood, metal, PVC.
Plunge cutting in wood / steel / copper /aluminium.
A
mm
B
mm
Qty
Art. No.
4932-
EAN No.
4002395-
28
40
1
430315
379767
➀
B
➁
A
➁ Plunge cutting blade
Application:
Wood, PVC.
Plunge cutting in soft and hard wood, PVC.
Recess cutting in wood. Flush cutting to length in wood.
➂
28
1
430316
379774
B
A
B
➂ Plunge cutting blade
Application:
Wood, PVC.
Plunge cutting in soft and hard wood, PVC.
Blade sits flush when cutting in door jambs.
Recess cutting in wood.
9
➃ Flush cutting blade
Application:
Wood, metal, PVC.
Plunge cutting in solid wood.
Flush cutting in wood.
Cutting steel / copper /aluminium / metal pipes and
profiles with small dimensions. Cutting PVC pipes to length.
88
➄ Grout removal blade
Application:
Grout, mortar, soft tiles.
Routing grout joints on wall and floor tiles.
40
A
40
1
430317
379781
➃
20
1
430319
A
379804
B
➄
85
20
1
430318
A
379798
B
➅ 9pc Set:
2 x bimetal plunge cutting blades
2 x plunge cutting blades 28 mm
2 x plunge cutting blades 9 mm
1 x flush cutting blade
1 x scraper
1 x grout blade
➅
➆ Washer Set
to fit Bosch keyless oscillating tool
to fit Dremel keyless oscillating tool
9
430314
379750
1
4931441298
872541
➆
*Every blade pack contents both washers
Description
Grit
AxB
mm
Qty
Art. No.
4932-
EAN No.
4002395A
➇
➇ Sanding pad
➈ 10pc Set:
Sanding paper Hook & Loop
4 x Grit 60
3 x Grit 80
60 / 80 / 120
3 x Grit 120
Application:
Wood, PVC.
Sanding small areas, e.g. in corners, along edges, in restricted
areas and tight spaces, sanding down of surface blemishes.
93 x 93
1
430320
379811
B
➈
93 x 93
10
430321
379828
A
B
ACCESSORIES 85
ABRASIVE PAPER – HOOK & LOOP FOR FDS 140
Perforated sanding discs for wood, metal, paint, lacquer, plaster.
Grit type: fused alumina, half-open. Artificial resin-bonded on special tear-resistant paper.
Grit
A
mm
B
mm
Qty
Art. No.
4932-
EAN No.
4002395-
60
115
107
10
352420
370795
80
115
107
10
352421
370801
120
115
107
10
352422
370818
240
115
107
10
352423
370825
B
A
ABRASIVE PAPER – CLAMP TYPE FOR FDS 140
Perforated sanding discs for wood, metal, paint, lacquer, plaster.
Grit type: fused alumina, half-open. Artificial resin-bonded on special tear-resistant paper.
Grit
A
mm
B
mm
Qty
Art. No.
4932-
EAN No.
4002395-
60
115
140
10
352424
370832
80
115
140
10
352425
370849
120
115
140
10
352426
370856
240
115
140
10
352427
370863
B
A
ABRASIVE DELTA PAPER – HOOK & LOOP FOR FDS 140
Grit
A
mm
B
mm
Qty
Art. No.
4932-
EAN No.
4002395-
60
110
88
10
352925
375837
80
110
88
10
352926
375844
120
110
88
10
352927
375851
240
110
88
10
352928
375868
B
A
BASE PLATES
Description
Ø
mm
No.
of holes
Art. No.
4932-
EAN No.
4002395-
Base plate for EX 125 ES
Complete with rubber ring as spare.
125
8
352870
375288
Base plate for EX 150 E
Complete with rubber ring as spare.
150
6
352871
375295
86 INDEX
INDEX
CORDLESS SYSTEMS
06–27
18 V POWER
BSB 18 Li 18 V Premium Hammerdrill/Driver
BSB 18C Li 18 V Compact Hammerdrill/Driver
BSB 18 G2 Li 18 V Hammerdrill/Driver
BS 18 G2 Li 18 V Drill/Driver
BS 18C Li 18 V Ultra Compact Drill/Driver
BSS 18C Li 18 V Ultra Compact Impact Driver
BBH 18 Li 18 V SDS-PLUS Hammer
BUS 18 Li 18 V Pendulum Action Reciprocating Saw
BKS 18 Li 18 V Heavy Duty Circular Saw
BST 18X-0 18 V Heavy Duty Jigsaw
BEWS 18-125 18 V Heavy Duty Angle Grinder
10–15
10
10
11
11
12
12
13
13
14
14
15
14,4 V POWER
BSB 14C Li 14,4 V Compact Hammerdrill/Driver
BSB 14 G2 Li 14,4 V Hammerdrill/Driver
BS 14C Li 14,4 V Compact Drill/Driver
BS 14 G2 Li 14,4 V Drill/Driver
16–18
16
16
18
18
12 V POWER
BSB 12 G2 NiCd 12 V Hammerdrill/Driver
BS 12 G2 NiCd 12 V Drill/Driver
OMNIPRO
BSB 12C2 Li 12 V 2-speed Ultra Percussion Drill
BS 12C2 Li 12 V Ultra Compact Drill/Driver
BS 12C Li 12 V Ultra Compact Drill/Driver
BSS 12C Li 12 V Ultra Compact Impact Driver
BBH 12 Li 12 V Cordless Hammer
19–24
19
19
20–21
22
22
23
23
24
3,6 V POWER
SE 3.6 Li 3,6 V Inline Screwdriver
25
25
SPECIALS
Flashlights/Battery Lamps 12/14,4/18 V
25
25
BATTERIES & CHARGERS
26–27
BATTERIES
L1830R 18 V Li-Ion 3,0 Ah
L1815R 18 V Li-Ion 1,5 Ah
B1814G 18 V NiCd 1,4 Ah
B1817G 18 V NiCd 1,7 Ah
L1430R 14,4 V Li-Ion 3,0 Ah
L1415R 14,4 V Li-Ion 1,5 Ah
M1430R 14,4 V NiMH 3,0 Ah
B1414G 14,4 V NiCd 1,4 Ah
L1215 12 V Li-Ion 1,5 Ah
M1230R 12 V NiMH 3,0 Ah
B1214G 12 V NiCd 1,4 Ah
SL 3.6 3,6 V Li-Ion 1,5 Ah
SB 3.6 3,6 V NiCd 1,4 Ah
27
27
27
27
27
27
27
27
27
27
27
27
27
27
CHARGERS
AL 1214G 12–14,4 V
AL 1218G 12–18 V
BL 1218 12–18 V
LL 1230 12 V
LA 036 3,6 V
27
27
27
27
27
27
HAMMER SYSTEMS
28–37
CORDLESS HAMMERS
BBH 12 Li 12 V Cordless Hammer
BBH 18 Li 18 V Cordless Hammer
30
30
30
ROTARY HAMMERS
BH 22 E SDS-PLUS Rotary Hammer
BH 24 E SDS-PLUS Rotary Hammer
31
31
31
COMBI HAMMERS
KH 24 XE SDS-PLUS Combi Hammer
KH 26 E SDS-PLUS Combi Hammer
BH 26 LXE SDS-PLUS Combi Hammer
KH 28 Super XE SDS-PLUS Combi Hammer
PN 3500 X SDS-PLUS Combi Hammer
KH 5 E SDS-MAX Combi Hammer
PN 11 E SDS-MAX Large Combi Hammer
31–36
31
32
32
33
34
35
36
CHIPPING HAMMERS
PM 3 SDS-PLUS Chipping Hammer
MH 5 E SDS-MAX Chipping Hammer
34–35
34
35
LARGE DEMOLITION HAMMERS
PM 10 E SDS-MAX Large Demolition Hammer
DRILLING SYSTEMS
ROTARY DRILLS
BE 650 R Rotary Drill
BE 705 R Rotary Drill
B4-1050 ST Rotary Drill
PERCUSSION DRILLS
SBE 500 R Percussion Drill
SBE 570 R Percussion Drill
SBE 600 R Percussion Drill
SBE 650 R Percussion Drill
SB2-650 Percussion Drill
SB2E 750 RX ST High Torque Percussion Drill
ERGOMAX L-Shape Percussion Drill
SB 20-2E Percussion Drill
SB 22-2E Percussion Drill
36
36
38–45
40
40
40
40
41–43
41
41
41
42
42
42
43
43
43
DIAMOND DRILLS
DB 1500-2 E Dry Diamond Drill
44
44
WALL CHASERS
MFE 1500 Wall Chaser
44
44
SCREWDRIVERS
S 2500 E Self Drilling Screwdriver
S 4000 E Drywall Screwdriver
45
45
45
METALWORKING
SMALL ANGLE GRINDERS
WS 6-115 Small Angle Grinder
WS 6-125 Small Angle Grinder
WS 9-115 Small Angle Grinder
46–59
49–53
49
49
50
INDEX 87
INDEX
WS 9-125 Small Angle Grinder
WS 11-115 Small Angle Grinder
WS 11-125 Small Angle Grinder
WS 12-125 XE Small Angle Grinder
WSC 14-125 MX Small Angle Grinder
WSE 14-125 MX Small Angle Grinder
LARGE ANGLE GRINDERS
WS 21-180 E Large Angle Grinder
WS 21-230 E Large Angle Grinder
WS 21-230 E GVX Large Angle Grinder
WS 24-180 E Large Angle Grinder
WS 24-230 E Large Angle Grinder
WS 24-230 E GVX Large Angle Grinder
50
51
51
52
53
53
54–56
54
54
54
55
55
56
DIE GRINDERS
GS 500 E Die Grinder
GSL 600 E Die Grinder
57
57
57
POLISHERS
PE 150 Polisher
58
58
SANDERS
SE 12-180 Right Angle Sander
58
58
ABRASIVE/METAL CHOPSAWS
SMT 355 Abrasive Metal Chopsaw
59
59
WOODWORKING
ROUTERS
MF 1400 KE Combo Router
OF 2050 E Router
PLANERS
PL 750 Planer
60–74
62–63
62
63
63
63
JIGSAWS
PST 500 X Palm Jigsaw
STEP 90 X Tophandle Jigsaw
ST 800 XE Bodygrip Jigsaw
STEP 1200 BX Tophandle Jigsaw
STEP 1200 XE Bodygrip Jigsaw
64–65
64
64
65
65
65
CIRCULAR SAWS
MBS 30 Turbo Multi Construction Material Saw
TS 55 E Plungesaw
KS 55 C 165 mm Circular Saw
KS 66 C 185 mm Circular Saw
66–67
66
66
67
67
RECIPROCATING SAWS
US 400 XE Mini Reciprocating Saw
US 900 XE Reciprocating Saw
US 1300 XE Reciprocating Saw
68
68
68
68
SANDERS
EX 125 ES Random Orbit Sander
EX 150 E Random Orbit Sander
FDS 140 Palm Delta Sander
FS 280 1⁄2 Sheet Sander
HBS 1000 E Belt Sander
BBSE 1100 Belt Sander
69–70
69
69
69
70
70
70
TABLE SAWS
TS 250 K Table Saw
71
71
MITRE SAWS
PS 305 DG Sliding Compound Mitre Saw
72
72
MITRE SAW LEGSTANDS
PSU 2500 Universal Mitre Saw Legstand
72
72
VACUUM CLEANERS
AP 250 ECP 25 l Vac
AP 300 ELCP 30 l Vac
73
73
73
HEAT GUNS
HG 560 D Heat gun
HG 600 V Heat gun
HG 600 VK Heat gun
74
74
74
74
ACCESSORIES
75–85
ACCESSORY SETS / COUNTER DISPLAYS
75–79
SDS-PLUS DRILL BITS – 2 Cut / 10 Piece Power Pack
80
SDS-MAX DRILL BITS – 2 Cut
80
SDS-PLUS CHISELS
80
SDS-MAX CHISELS
80
ROUTER BIT SET
80
MASONRY DRILL BITS
81
BI-METAL HOLESAWS/SYSTEM ACCESSORIES
81
JIGSAW BLADES WOOD / PLASTICS / METAL
82
RECIPROCATING SAW BLADES WOOD / PLASTICS / METAL 82
GUIDE RAIL
83
CIRCULAR SAW BLADES
83
ATTACHMENTS
83
SYSTEM ACCESSORIES – HOT AIR GUNS
83
ACCESSORIES FOR OSCILLATING TOOL OMNIPRO
84
ABRASIVE PAPER – HOOK & LOOP
85
ABRASIVE PAPER – CLAMP TYPE
85
ABRASIVE DELTA PAPER – HOOK & LOOP
85
BASE PLATES
85
CORDLESS/HAMMERS/DRILLING
METALWORKING/WOODWORKING
ACCESSORIES
AEG POWERTOOLS promises to draw upon its heritage and deliver
exciting, high performance, innovative working solutions for the professional
tradesmen of today and the future.
AEG POWER TOOLS
P.O. Box 320
D-71361 Winnenden
Germany
Tel.: +49 71 95 12-0
Fax: +49 71 95 12-666
A&M Middle East
P.O Box 61254
Jebel Ali Free Zone South
Dubai, UAE
Tel: +97148861399
Fax: +97148861400
www.aeg-powertools.com
© AEG POWERTOOLS
AEG POWERTOOLS reserve the right to change all data including images,
specifications and service and warranty information without notice.
AEG POWERTOOLS will hold no liability for printing errors or mistakes.
4939 XXXX 00
Download PDF

advertising
