Tailored for Retail Business SRN-472S

Tailored for Retail Business SRN-472S
4CH NVR with PoE Switch
SRN-472S
SRN-472S
Display
Video
Live
Dimensions
Unit : mm (inch)
Inputs
Resolution
Protocols
Local Display
Multi Screen Display
Performance
Operating System Embedded
Compression
Recording Bandwidth
Resolution
Recording
Mode
Event Trigger
Event Action
Playback Bandwidth
Mode
Search &
Simultaneous Playback
Playback
Resolution
Playback Control
Built-in
Storage
Internal
Capacity
File Back up
Back up
Function
Sensor
Input / Output
Input
Audio
Compression
Audio Communication
Network
320.0
(12.6")
320.0
(12.6")
323.9
(12.75")
323.9
(12.75")
Protocol Support
DDNS
Transmission Bandwidth
Max. Remote Users
IP
Security
Language
GUI / Web Viewer
OS
Web Browser
370.0(14.57")
(14.57")
370.0
Viewer Software
44.0(1.73")
(1.73")
44.0
50.7 (2")
(2")
50.7
Functions
Camera Setup
PTZ
Smart phone
Type
CMS Support
Register
Setup Items
Control
Preset
OS
Control
System Control
Indicator / Interface
Front
Connections
System
Log
General
Electrical
Environmental
Mechanical
The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
Approvals
Up to 4CH
CIF ~ 5M
Samsung, ONVIF
HDMI / VGA
[Local monitor] 1 / 4 / Auto sequence, [Web] 1 / 4 / Auto sequence
Linux
H.264, MJPEG
32Mbps (2M 4CH real-time recording)
CIF ~ 5M
Normal, Scheduled, Event (Pre / Post)
Alarm input(4), Video loss, Camera event (Sensor, MD, Video analytics)
E-mail, PTZ preset, Alarm out, Buzzer, Monitor out
32Mbps (4CH simultaneously)
Date & Time (Calendar) / Event log list
[Local monitor] Up to 4CH, [Web, CMS] Up to 4CH
CIF ~ 5M
Fast forward / backward, Move one step up / down
1ea
2ea (Fixed)
Internal max. 8TB
[USB] : BU/Exe, [Web, CMS] : JPEG, AVI
Single channel play, Date-time/title display
4 / 3 (NO/NC selectable)
4CH (Network)
G.711, G.726
2-way
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client),
PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S)
Samsung iPOLiS DDNS
Min. 32Mbps
Search 3 / Live unicast 10 / Live multicast 20
IPv4 / IPv6
IP address filtering, User access log, 802.1x authentication, Encryption
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech,
Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean,
Chinese, Japanese, Thai
[Window] : XP SP2 or above, Vista, 7, 8, [Mac OS] : OSX 10.7 or above
[Internet Explorer] : ver.8 ~ 11, [Firefox] : ver.19.x or above
[Chrome] : ver.26.x or above, [Safari] : ver.6.0.3 or above (OSX 10.6 or above)
SSM, Webviewer, SmartViewer
SDK / CGI
4CH Compact PoE NVR
SRN-472S
4CH NVR with PoE Switch
• Up to 32Mbps network camera recording
• Easy camera installation via dedicated 4 PoE ports
• Up to 5megapixel IP camera supported
• Max 2 internal HDDs (Max 8TB, Over 2-months @2MP)
• Alarm, MD & VA event recording & search
• Support Samsung viewers (iPOLiS mobile, SmartViewer)
PnP mode, Manual mode
IP Address, Add Profile Edit, Bitrate, Compression, GOP, Quality,
Video Setup (MD, VA, ABF, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter)
Via GUI, Webviewer
255
Android, iOS
Live 4 / Playback 1
Mouse, IR Remocon
USB
HDMI / VGA
Audio
Ethernet
Alarm
Power Cord
Power status LED 1ea, HDD action LED 1ea, Alarm status LED 1ea
Record status LED 1ea, Network action LED 1ea, Back up LED 1ea
2ea
1ea / 1ea
Out 1ea (RCA, Line)
2ea (100Mbps) + PoE 4ea (10/100Mbps)
In 4ea (Terminal block) / Out 3ea (Terminal block)
AC inlet 1ea
Log List
System log : Max. 20000, Event log : Max. 20000
Input Voltage / Current
NVR Power Consumption
Camera Power Output
Operating Temperature
Operating Humidity
Color / Material
Dimensions (WxHxD)
Weight
Safety
EMC
100 ~ 240V AC / 3.5A 50Hz/60Hz
Max. 30W (With 1TB HDD 1ea)
15.4W per Channel, Total 61.6W (PoE, IEEE 802.3af)
+0°C ~ +40°C (+32°F ~ +104°F)
20% ~ 85% RH
Black / Metal
370.0 x 44.0 x 320.0mm (14.57" x 1.73" x 12.6") (1U)
2.73Kg (6.02 lb) without HDD
UL, KC
CE, FCC, KCC, CCC, Gost-R
Indicator
Tailored for Retail Business
Design and specifications are subject to change without notice.
DISTRIBUTED BY
SAMSUNG TECHWIN CO., LTD.
6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA
Tel : +82-70-7147-8741~8749, 8752~8760 Fax : +82-31-8018-3745
COPYRIGHT BY SAMSUNG TECHWIN. ALL RIGHT RESERVED
I.H-1406
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : +1-877-213-1222 Direct : +1-201-325-6920
Fax : +1-201-373-0124
www.samsungsecurity.com www.samsungcctv.com
SAMSUNG TECHWIN EUROPE LTD.
2nd Floor, No. 5 The Heights, Brooklands, Weybridge,
Surrey, KT13 0NY, UK
Tel : +44-1932-82-6700 Fax: +44 1932 82 6701
SHANGHAI SAMSUNG TECHWIN CO., LTD.
32F, Blk B, International Business Center,
No. 391 Guiping Rd., Shanghai, China, 200233
Tel : +86-21-5427-1155 Fax : +86-21-5423-5122
REVISED 06-2014
www.samsungipolis.com
4CH NVR with PoE Switch I SRN-472S
SRN-472S compatible
PoE network cameras
and management software
SRN-472S lets you focus
more on your business and sales.
3MP Fisheye Camera
SNF-7010V
• Real-time WDR (3M 20fps, 120dB)
• Various viewing composition
• IP66, IK10
You don’t understand IP, don’t worry!
JUST Plug and Play
Maximized the stores security while
reducing costs
Protecting the store, it’s customers and assets are important factors in
the minds of the owner and management ; the understanding of network
surveillance systems is not. However, the SRN-472S, with it’s built-in
PoE switch and zero configuration, has been specifically designed for
retail it takes the away any need understand network systems or invest
in additional equipment such as a PoE switch.
Recording 4CH in real-time for up to [email protected] HD quality 4CH
(1 HDD standard, max. 2 HDDs (4TB ea)
This gives the store peace of mind that nothing will be missed and that
vital information will still be there weeks after the event. Allowing you
the flexibility to search and track the data not only for criminal
evidence but also for business analysis.
Remote Viewing
View live and playback video from anywhere, whether on the stores PC
or your Smart Phone / Tablet when out and about, Samsung Techwin’s
free of charge software will allow you to keep in touch with the stores
activities anytime of the day or night.
2MP Compact Dome Camera
SNV-6012M/6013
• [email protected]
• Day & Night (Electrical)
• WDR (120dB), Enhanced DIS, Defog
• IP66, Weatherproof IK10, Vandal-resistant
SNV-6012M
SNV-6013
Samsung Retail Software
SRN-472S is designed to be harmonious with
store interior
Display Full HD images on a local monitor
Samsung Techwin’s SRN-472S and retail specific domes and fisheye
cameras are all of a compact design allowing them to sit well with any
interior, without compromising the stores image nor the customers
comfort while at the same time securing the stores and assets.
SRN-472S supports a HDMI full HD output as well as a standard VGA,
giving the owner the option of having an “In store” monitor that
demonstrates to the customers that they are being protected by a high
quality professional surveillance solution.
SmartViewer
• Local & Remote Viewing
• Sequence and favorite view
• Event search sensor, Video loss, Motion,
VA (Passing, Entering, Exiting, Disappearing/Appearing,
Tampering, Tracking, Face detection, Audio detection)
iPOLiS mobile
• Android & IOS supported
• Live, playback & PTZ control
• Up to 100 devices supported
VGA
Full HD
Linked to POS (Available in 2014 4Q)
iPOLiS mobile
SmartViewer
