Site Configuration
SETUP GUIDE
Linux Hosts
Single Workstation Installation
May08
May 08
Copyright © 2008 Wind River Systems, Inc.
All rights reserved. No part of this publication may be reproduced or transmitted in any
form or by any means without the prior written permission of Wind River Systems, Inc.
Wind River, Tornado, and VxWorks are registered trademarks of Wind River Systems, Inc.
The Wind River logo is a trademark of Wind River Systems, Inc. Any third-party
trademarks referenced are the property of their respective owners. For further information
regarding Wind River trademarks, please see:
http://www.windriver.com/company/terms/trademark.html
This product may include software licensed to Wind River by third parties. Relevant
notices (if any) are provided in your product installation at the following location:
installDir/product_name/3rd_party_licensor_notice.pdf.
Wind River may refer to third-party documentation by listing publications or providing
links to third-party Web sites for informational purposes. Wind River accepts no
responsibility for the information provided in such third-party documentation.
Corporate Headquarters
Wind River Systems, Inc.
500 Wind River Way
Alameda, CA 94501-1153
U.S.A.
toll free (U.S.): (800) 545-WIND
telephone: (510) 748-4100
facsimile: (510) 749-2010
For additional contact information, please visit the Wind River URL:
http://www.windriver.com
For information on how to contact Customer Support, please visit the following URL:
http://www.windriver.com/support
Site Configuration Setup Guide: Linux Hosts, Single Workstation Installation
May 08
Part #: DOC-16245-ND-00
Contents
1
2
Overview ...............................................................................................
1
1.1
Introduction .............................................................................................................
1
Host System Requirements ................................................................
3
2.1
Supported Host Types for Wind River Products ..............................................
3
2.2
Host System Hardware Requirements ...............................................................
4
2.2.1
Requirements for Eclipse-Based Products ............................................
4
2.2.2
Command-Line Users ..............................................................................
5
2.2.3
Optional Hardware ..................................................................................
5
Host System Software Requirements .................................................................
5
2.3.1
Requirements for Eclipse-Based Products ............................................
5
2.3.2
Optional Software and Resources ..........................................................
6
Licensing and Installation Workflow ..................................................
7
3.1
How Licensing Works ...........................................................................................
7
3.2
Overview of Licensing Tasks ...............................................................................
7
3.3
Overview of Installation Tasks ............................................................................
8
2.3
3
iii
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
4
Generating Node-Locked Workstation Licenses ............................... 11
4.1
5
11
Installing Wind River Products on a Development Workstation ...... 15
5.1
Before You Begin ....................................................................................................
15
5.2
Installing Wind River Products ...........................................................................
16
5.2.1
Standard Installation ................................................................................
16
5.2.2
Installing a Service Pack ..........................................................................
18
Non-Typical Installations .....................................................................................
19
5.3.1
Installing Workbench into an Existing Eclipse Environment ............
19
5.3.2
Incremental Installation ...........................................................................
19
5.3.3
Parallel Installation ..................................................................................
19
5.3
6
Generating a Node-Locked License File ............................................................
Post-Installation Tasks ........................................................................ 21
6.1
Installing Patches ...................................................................................................
21
6.2
Permanently Activating a Temporary Installation ...........................................
22
6.2.1
Activating Temporary Installations .......................................................
22
Distributing License Files ........................................................................
Setting an Environment Variable to Access a License Server ............
23
23
Uninstalling a Development Computer License File ..........................
24
Downloading and Installing Board Support Packages ...................................
24
6.3.1
When Should You Download a BSP? ....................................................
24
6.3.2
Navigating the BSP Web Site ..................................................................
25
Locating a Specific BSP ............................................................................
25
Downloading and Installing a BSP ........................................................
26
The BSP Download Page .........................................................................
Installing a BSP with the Maintenance Tool .........................................
26
26
6.2.2
6.3
6.3.3
iv
Contents
6.4
Building the VxWorks Run-Time Source ..........................................................
27
6.4.1
The Kernel and Platform Build Processes ............................................
28
Building VxWorks Kernel Source Code ................................................
Building Wind River VxWorks Platforms Source Code .....................
28
29
Where to Find Additional Information .................................................
29
Building the Linux Target Run-Time Source ....................................................
30
6.5.1
When Is It Necessary to Build Linux Source Code? ............................
30
6.5.2
Choosing a Build Method .......................................................................
30
6.5.3
Where to Find Additional Information .................................................
31
Uninstalling Wind River Products ......................................................................
31
Archiving Downloaded Plug-Ins ...........................................................
Preserving Workbench Project Files ......................................................
31
31
6.6.1
Uninstalling Through the Maintenance Tool .......................................
32
6.6.2
Uninstalling a Service Pack .....................................................................
32
Wind River Environment Utility (wrenv) .............................................
33
7.1
What Is wrenv? .......................................................................................................
33
7.2
When Are You Required to Invoke the wrenv Utility? ...................................
34
7.2.1
Invoking the wrenv Utility .....................................................................
34
7.3
wrenv Command Options ....................................................................................
35
7.4
wrenv Usage Examples ..........................................................................................
35
Creating a Development Shell ................................................................
Setting the Development Environment Without Spawning a Shell .
35
35
7.5
How Does wrenv Create a Unified Environment Setting? ............................
36
7.6
What Is the Installation Properties File? ............................................................
37
7.6.1
Package Descriptor ..................................................................................
39
Advanced wrenv Topics ........................................................................................
39
6.4.2
6.5
6.6
7
7.7
v
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
8
7.7.1
Using Packages from Multiple Installation Locations ........................
39
7.7.2
Special Packages .......................................................................................
41
Initializer Packages ..................................................................................
Extension Packages ..................................................................................
41
41
Configuring a Remote Build Server ................................................... 43
8.1
Do You Need to Set Up a Remote Build Server? ..............................................
43
8.2
Performing Remote Builds with Wind River Workbench ..............................
43
8.3
General Requirements for Remote Builds ........................................................
44
vi
1
Overview
1.1 Introduction
This document guides you through the process of installing and configuring
Wind River products on a single Linux developer workstation.
You, or someone in your organization, may need to complete the following site
configuration tasks:
■
■
■
■
Installing the product.
Permanently activating your product installation.
Obtaining node-locked licenses.
Compiling run-time source code.
What This Guide Does Not Cover
The workflow outlined in this document does not describe:
■
■
■
batch (automated) workstation installations
shared (file server) installations
installations for Windows and Solaris workstations
You can find documentation for these topics, as well as the most current version of
this document, at
www.windriver.com/licensing/
1
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
2
2
Host System Requirements
2.1 Supported Host Types for Wind River Products 3
2.2 Host System Hardware Requirements 4
2.3 Host System Software Requirements 5
2.1 Supported Host Types for Wind River Products
Wind River products support development on either Windows, Solaris, or Linux
hosts (in many cases, all three host types are supported). This chapter outlines a
recommended host system configuration for your chosen host type (both
hardware and software) that is applicable to most Wind River products.
Product-specific information on supported host types, as well as minimum and
recommended host system hardware and software requirements, are provided in
your product release notes.
NOTE: The guidelines in this chapter are generalized for all Wind River products.
Your host system may require more resources or less, depending on what product
you have purchased and your performance requirements. For more specific
information, see your product release notes.
3
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
2.2 Host System Hardware Requirements
This section provides a set of Wind River-recommended host system hardware
requirements for development using a typical Wind River product. The
recommended configuration is expected to provide good performance for
development on a typical user system. Primarily, this section addresses
development using Wind River Eclipse-based products. It also briefly addresses
command-line user requirements and optional hardware recommendations. For
more information on specific host system requirements for your product, see your
product release notes.
For information on host software requirements, see 2.3 Host System Software
Requirements, p.5.
2.2.1 Requirements for Eclipse-Based Products
This section lists the recommended host hardware configuration for development
using a Wind River Eclipse-based product (such as Workbench).
NOTE: The following requirements do not represent a minimum configuration.
Depending on your development requirements and any other third-party
software that you are running, you may require more or less than this
configuration.
Linux Host Hardware Requirements
Wind River recommends the following hardware configuration for typical
development with an Eclipse-based product on a Linux host:
■
Intel Pentium 4 class processor, 1.7 GHz or higher recommended.
■
1 GB of RAM.
■
Disk space:
The amount of disk space required for a typical installation varies from
product to product. Depending on your product, the size of your own
applications, and your development environment, your host may require
several gigabytes of disk space.
■
4
A DVD-ROM drive or networked DVD-ROM for installation.
2 Host System Requirements
2.3 Host System Software Requirements
2.2.2 Command-Line Users
If you are a command-line user, you may achieve acceptable performance from a
host system with fewer resources than the recommended configuration provided
in 2.2.1 Requirements for Eclipse-Based Products, p.4. However, note that even a small
amount of development in the Eclipse-based environment requires that you meet
the minimum configuration for your product. For product-specific information on
minimum host system requirements, see your product release notes.
2.2.3 Optional Hardware
The following hardware is optional but may be useful to you during your
development:
■
A network interface card for debugging over a network is recommended.
2.3 Host System Software Requirements
This section provides a set of Wind River-recommended host system software
requirements for development using a typical Wind River product. The
recommended configuration is expected to provide good performance for
development on a typical user system. Primarily, this section addresses
development using Wind River Eclipse-based products. For more information on
specific host system requirements for your product, see your product release
notes.
For information on host hardware requirements, see 2.2 Host System Hardware
Requirements, p.4.
2.3.1 Requirements for Eclipse-Based Products
This section lists the recommended host software configuration for development
using a Wind River Eclipse-based product (such as Workbench).
5
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
NOTE: Software requirements for Wind River products vary considerably from
one product to another. Be sure to check your product release notes for additional
information before beginning development.
Linux Host Software Requirements
Wind River recommends the following OS version and software for typical
development with an Eclipse-based product on a Linux host:
■
One of the following host operating systems:
–
–
–
–
–
Red Hat Enterprise Linux Workstation 4.0 (Update 5)
Red Hat Enterprise Linux 5 Desktop with Workstation option (32- or
64-bit)
SUSE Linux/openSUSE 10.2
Novell SUSE Linux Enterprise Desktop 10 (Service Pack 1)
Fedora 7
■
Additional required packages for the development host, as listed in the
installDir/wrlinux-2.0/wrlinux/required-host.txt files.
■
The X Window System, with the GNOME, KDE, or other desktop of your
choice.
■
A current version of a standards-compliant browser.
■
TCP/IP must be installed on the host system, even if it is being used as a
standalone computer with a serial connection to the target.
2.3.2 Optional Software and Resources
The following software and resources are optional but may be useful to you during
your development:
■
6
An active Internet connection is recommended during initial installation to
access patches, documentation, and other important information from the
Wind River Online Support Web site.
3
Licensing and Installation
Workflow
3.1 How Licensing Works 7
3.2 Overview of Licensing Tasks 7
3.3 Overview of Installation Tasks 8
3.1 How Licensing Works
Many Wind River products are license-managed. This means that your
organization buys a license that allows your developers to run a certain number of
copies (also known as seats) of a Wind River product simultaneously.
To run a license-managed product, each development host must have its own
license file, generated from the Wind River licensing Web site. Licensing tasks can
be completed either before or after installation tasks.
3.2 Overview of Licensing Tasks
You or someone in your organization must complete the following tasks before
you can run license-managed Wind River products.
7
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
For detailed information on the steps below, see 4. Generating Node-Locked
Workstation Licenses.
Step 1:
Log in to the Wind River licensing Web site.
Before you can activate your Wind River product and your developers can use it,
you must log in to and create an account on the Wind River licensing Web site:
http://www.windriver.com/licensing:
Step 2:
Add the development computer to your account.
You must add information about each development host computer in your
organization that will run license-managed products.
Step 3:
Generate Product Activation files.
You must generate a Product Activation file for each development computer.
3.3 Overview of Installation Tasks
You can install Wind River products before or after generating a Product
Activation file.
Step 1:
Install Wind River products on a workstation.
Your developers can wait for you to give them a Product Activation file before
installing, or they can install using installation keys from the Developer Essentials
sheet and receive a temporary license.
For more information on this step, see 5. Installing Wind River Products on a
Development Workstation.
Step 2:
Activate workstation licenses.
If your developers installed their license-managed products using a temporary
license (also known as temporary activation), you or they must permanently activate
those products.
For more information, see 6.2 Permanently Activating a Temporary Installation, p.22.
8
3 Licensing and Installation Workflow
3.3 Overview of Installation Tasks
Step 3:
Uninstall Wind River products from a workstation.
If you no longer need to use a particular Wind River product, you can uninstall it
from your development computer using the Wind River Maintenance Tool.
For more information, see 6.6 Uninstalling Wind River Products, p.31.
Step 4:
Rehost product seats on a different development computer (optional).
After you uninstall a product from a workstation, you can reassign its license to
another development computer.
9
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
10
4
Generating Node-Locked
Workstation Licenses
4.1 Generating a Node-Locked License File
Complete the following steps to generate a node-locked license file for a
development computer.
1.
Log in to the Wind River licensing Web site and create your account.
2.
Activate your license.
3.
Add your development computer as a new host.
4.
Activate your products and generate a license file for the development
computer.
These tasks are described in greater detail in the following sections.
Step 1:
Log in to the Wind River licensing Web site and create your account.
1.
Locate your License Administrator Essentials sheet, as in Figure 4-1. You will
need information from it to complete this task.
11
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
Figure 4-1
Sample License Administrator Essentials Sheet
2.
Go to http://www.windriver.com/licensing.
3.
Check the list of products that can be activated from this site to be sure your
product appears here. If it appears in the list, click Login.
NOTE: Some older products cannot be activated from the licensing Web site;
to activate those products, see the installation information that was included
with the products. If you do not have access to installation instructions for an
older product, contact Wind River Customer Support or e-mail to
[email protected]
4.
12
Log in to the site:
4 Generating Node-Locked Workstation Licenses
4.1 Generating a Node-Locked License File
■
If you already have a Wind River User ID and Password (for example
because you previously logged in to this site or the Wind River support
site), type them and click Login.
or
■
Step 2:
If you are not yet a registered user on any Wind River site, click
Register for a User ID and Password. Type your user profile information,
including your license number from the License Administrator Essentials or
the Developer Essentials sheet. Type a password, confirm it, then click
Submit.
Activate your license.
1.
Click Activate your products to open the Add Licenses screen. Type in your
License Number and License Administrator Token from the License
Administrator Essentials sheet.
If you expect to eventually manage several product licenses, also type in a
label (for example, VxWorks GPP 3.4 or Alameda Campus) to make it easier
to identify this particular license in the future.
2.
Click Submit. On the Add Licenses Confirmation screen, check to be sure all
the information you typed in is correct.
Your license has now been added to your account. If you order additional Wind
River products in the future, click Manage Licenses and then click Add New
License to add the new products to your account.
Step 3:
Add your development computer as a new host.
Once your license has been activated, use the Manage Hosts screen to add
information about the development computer. If you have any hosts already
defined, they appear on this screen.
1.
To add a host, click Add New Host.
2.
On the Create Host screen, enter the host computer’s name, host ID, and other
requested information.
NOTE: For descriptions of the fields, including instructions for finding your
host ID, click More information.
3.
When you have filled in all required fields, click Create.
Your new host appears on the Create Host Confirmation screen.
13
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
Step 4:
Activate your products and generate a license file for the development computer.
1.
After you have added the development computer to your account, click
Manage Licenses to activate the products you have purchased.
2.
From the drop-down list next to the license on the Manage Licenses screen,
select Activate Products.
3.
Select the product you want to allocate to this development computer (look for
NL in the License Type column). Click Next.
4.
From the Host Label drop-down list, select this development computer, then
click Next.
5.
Confirm that you have selected the correct host, then click Next.
6.
Click Download to download the license file immediately, or enter an e-mail
address if you want the license file to be sent to the person responsible for this
host computer. If you entered an e-mail address, click Send.
NOTE: You can both download the license file and receive it in e-mail.
If you download the file, you must be sure to preserve the .lic ending on the
license file or the file will not work properly.
If you chose to send licenses by e-mail, the E-mail Licenses Confirmation
screen displays to whom they were sent.
Once you have the node-locked license file (WRSLicense.lic), see 5. Installing Wind
River Products on a Development Workstation for instructions on how to use it.
14
5
Installing Wind River Products
on a Development Workstation
5.1 Before You Begin 15
5.2 Installing Wind River Products 16
5.3 Non-Typical Installations 19
5.1 Before You Begin
Before you can install your Wind River products, make sure you have the
following items available:
■
Your product box, which includes:
–
–
–
■
installation media (discs or image files).
the Developer Essentials sheet
the Getting Started book
Several gigabytes (GB) of disk space on your development computer for
Standard (recommended) installations.
The amount of disk space required varies for each product. For a given
installation disk, the installer calculates the amount of space required for all
features you selected; this is less than the actual space required if your
installation contains multiple disks. Verify that you have adequate free space
before you begin installation.
15
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
■
Write permissions to your installation directory.
■
For typical installations, either:
–
A Product Activation file to permanently activate your products during
installation.
or
–
■
A license authorization code and Internet access to temporarily activate
your products.
For non-typical installations, installation keys (printed on your Developer
Essentials sheet).
5.2 Installing Wind River Products
You can install a Wind River product from the physical media, or from DVD
images that have been copied onto a server.
5.2.1 Standard Installation
To install a Wind River product on a development workstation, complete the
following steps.
1.
Launch the installer by putting the disc labelled Install First into your drive,
or by navigating to the product image, and running setup_linux.
NOTE: If you are installing the product from a shared network directory,
ensure that the directory name and path do not include spaces. If there is a
space character anywhere in the absolute path, some elements of the
installation will not be available.
16
5 Installing Wind River Products on a Development Workstation
5.2 Installing Wind River Products
NOTE: If you are installing a product suite that includes Wind River
Workbench, the Workbench image must be installed first. The rest of the
products in the suite can be installed in any order.
If you are installing a product suite that includes more than one product (such
as a Wind River Platform), be sure to choose the same installation directory for
all products.
2.
Read each installer screen and provide the requested information, then click
Next.
3.
From the Choose Activation Type screen, select the type of installation you
want:
Temporary activation
Select this method if you wish to install and use the products for a limited
time. However, to continue using them, you must later permanently
activate this installation (using a license file).
When you select this option, the installer program automatically locates
your License Authorization Code (LAC). To use this method, you must
have Internet access.
Permanent activation
Select this option if you have a Product Activation file. You do not need
Internet access to install and activate Wind River products using this
option.
When you select this option, you can browse to the directory location of
your Product Activation file.
Advanced
When you click the Advanced button, a third option, Manual activation
(not typical), appears. Under this method, you install products by
entering installation keys without activating your products. This is only
performed when you do not have a Product Activation file, do not have an
Internet connection, and prefer to set up your licensing manually.
Select an installation type, then enter the required information.
4.
On the Choose Installation Filters screen, select Standard Installation or
Custom Installation.
17
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
NOTE: Wind River recommends a standard installation, but if disk space is a
problem, a customized installation allows you to install just those products
and tools that you need.
You can also click the Advanced button on this screen to select host types. For
single-workstation installations, your host type is pre-selected.
5.
If you selected Standard Installation, the next screen shows you the products
and features that will be installed; click Install to start the installation process.
If you selected Custom Installation, click Next. Select the products and tools
you want to install, then click Install.
CAUTION: Use caution when unselecting features, as unselecting critical
features could prevent the products from functioning properly.
!
If you installed using a Product Activation file, your Wind River products are now
installed, activated, and ready for you to begin working with them.
If you installed using a license authorization code or installation keys, you may use
your products now but you must permanently activate them to continue working
with them. For information on how to do this, see 6.2 Permanently Activating a
Temporary Installation, p.22.
If you were not able to install, see your license administrator.
5.2.2 Installing a Service Pack
Each Wind River product service pack is delivered with its own installer program,
similar to the one you used to install your products in 5.2.1 Standard Installation,
p.16. The installer program automatically uses the installation keys that are
included with the service pack.
Service packs are installed as additions to a previous installation; they do not
overwrite existing product installations.
18
5 Installing Wind River Products on a Development Workstation
5.3 Non-Typical Installations
5.3 Non-Typical Installations
You may not need the instructions in this section, depending on your
organization’s setup.
5.3.1 Installing Workbench into an Existing Eclipse Environment
Wind River Workbench provides a complete Eclipse framework. You do not need
to install Eclipse separately. However, if you have your own customized Eclipse
installation, and you prefer to integrate Workbench into it, you must:
1.
Install Wind River Workbench (as described in this document).
2.
Follow the instructions in Wind River Workbench User’s Guide: Using Workbench
in an Existing Eclipse Environment to integrate Wind River Workbench into
your existing Eclipse installation.
5.3.2 Incremental Installation
An incremental product installation can be performed in situations such as the
following:
■
You installed only certain features of a Wind River product (by selecting
Custom rather than Standard installation) and now wish to add the excluded
features.
■
You are installing complementary Wind River products (for example, adding
On-Chip Debugging to your existing installation of Wind River Workbench).
When you do an incremental installation, you can again choose Standard or
Custom mode. In a standard installation, the installer program installs only those
products or features that are not yet present in your installation directory. If you
select Custom installation, the installer program shows you a full list of the
available products and features, indicating which ones are already installed. You
can choose whether to re-install what is already present. (By default, existing
features are not re-installed.)
5.3.3 Parallel Installation
If you have a previous version of Workbench installed, you can install a later
version alongside it as long as the two are in different directories.
19
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
20
6
Post-Installation Tasks
6.1 Installing Patches 21
6.2 Permanently Activating a Temporary Installation 22
6.3 Downloading and Installing Board Support Packages 24
6.4 Building the VxWorks Run-Time Source 27
6.5 Building the Linux Target Run-Time Source 30
6.6 Uninstalling Wind River Products 31
6.1 Installing Patches
To install patches for your Wind River products, use the Wind River Product
Maintenance Tool, provided with products from Wind River Workbench 3.0
forward and available from your installation directory. The Maintenance Tool
handles all updates to Wind River software after initial installation, as well as
product uninstallation.
To launch the Maintenance Tool, do the following:
■
From the GUI
Select Applications (the main menu on the panel) > Wind River > Uninstall
and Maintenance > Maintenance Tool.
21
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
■
From the command line
Execute the following commands from the command shell:
% cd installDir/maintenance/mtool
% ./mtool_linux
NOTE: Patches cannot be installed with a silent or unattended installation method.
6.2 Permanently Activating a Temporary Installation
If you used a Product Activation file (install.txt) when installing Wind River
products, those products are permanently activated and require no further action.
If you used a license authorization code (LAC) or installation key to temporarily
activate your products, you can use those products for a limited time but you must
obtain a license file to permanently activate your products.
NOTE: The length of a temporary activation varies by product, but is typically no
less than 30 days. Wind River license-managed tools display a warning as they
approach expiration.
Permanent activation means that a product may be used to the fullest extent of its
license.
6.2.1 Activating Temporary Installations
There are two ways to permanently activate Wind River products that were issued
temporary licenses:
■
You can create and distribute license files for each development workstation.
or
■
22
On each development workstation, you can set an environment variable to
access a license server.
6 Post-Installation Tasks
6.2 Permanently Activating a Temporary Installation
Distributing License Files
The easiest (and recommended) way to activate temporary licenses is to make a
license file available to each member of your team.
1.
Follow the instructions in the Generating Workstation Licenses chapter to create
the appropriate license file(s).
2.
Name the new file WRSLicense.lic.
3.
Copy the file into the installDir/license directory of each development system.
or
3.
Place the license file on a server and make it available for your development
team to download onto their computers. Be sure to instruct them to copy the
file to their installDir/license directory.
NOTE: Each node-locked development computer requires a separate license file,
generated using that computer’s host ID.
Setting an Environment Variable to Access a License Server
The second way to permanently activate temporary licenses is to set an
environment variable to point to a license server.
NOTE: In order to use this method, you (or someone in your organization) must
first generate a server license file and install a license server.
1.
Create, or instruct each member of your team to create, an environment
variable on the development computer called WRSD_LICENSE_FILE.
2.
Set the value of this variable to the [email protected] indicated in the SERVER
line of the Product Activation file you downloaded from the licensing Web
site.
For example, the SERVER line may look like the following:
SERVER jupiter hostID 27000
In this example, the server name is jupiter and the port number is 27000, so
you would set the variable to [email protected]
Once the variable is set, this permanently activates the temporary licenses.
23
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
6.2.2 Uninstalling a Development Computer License File
If you are uninstalling a Wind River product from a development computer, the
uninstallation process described in 6.6 Uninstalling Wind River Products, p.31, does
not remove the license file.
You must manually remove it by navigating to the installDir/license directory and
deleting the file, usually named WRSLicense.lic.
NOTE: If the product you are uninstalling was listed in a merged license file that
resides in the product’s installation tree, removing the license file affects all
products whose licenses are also under the file’s control.
Wind River recommends that you back up the file, delete the entry for the
product(s) you are uninstalling, then save the file. The remaining products on the
development computer (and listed in the license file) should work as before.
6.3 Downloading and Installing Board Support Packages
Wind River provides board support packages (BSPs) for both the VxWorks and Wind
River Linux operating systems. Although the specific details of a BSP vary
considerably between VxWorks and Linux, BSPs serve the same purpose on each
operating system. That is, BSPs provide the necessary code to run your customized
VxWorks or Wind River Linux operating system instance on specific target
hardware. BSPs provided by Wind River can be used for development on available
hardware or can be used as a base for BSP development for your custom hardware.
NOTE: Wind River recommends that, when developing for custom hardware, you
try to customize an existing BSP instead of trying to write your BSP from scratch.
For more information on BSP development, see the VxWorks BSP Developer’s Guide
or the Wind River Linux Platforms Users Guide.
6.3.1 When Should You Download a BSP?
Many VxWorks and Wind River Linux distributions provide board support
packages directly on the product installation media. However, new BSPs and
24
6 Post-Installation Tasks
6.3 Downloading and Installing Board Support Packages
updates are continuously added to the BSP Web page. Therefore, to have access to
the latest board support packages and updates, you must visit the BSP Web page.
If the BSP you wish to use for development is included on your installation media,
check the BSP Web site to be sure that it is the latest version. If the BSPs included
on your installation media are not suitable for your development, see the BSP Web
site for a full list of available BSPs.
Compatibility
The Wind River installation program does not verify version compatibility
between your Wind River products and BSPs. For compatibility information, see
the documentation that accompanies the BSP.
6.3.2 Navigating the BSP Web Site
The Wind River public Web site provides you with access to a listing of all
available Wind River BSPs. The BSP main page is:
http://www.windriver.com/products/bsp_web/
You can also navigate to this page from the Wind River Web site home page by
selecting Products > Board Support Packages.
NOTE: This Web page is publicly accessible, but you must have a valid Online
Support login in order to download a BSP .zip file.
Locating a Specific BSP
From the BSP main page, you can choose to locate a specific BSP by:
Architecture
This is the generic processor family to which the desired CPU belongs. For
example, ARM or PowerPC. If you know the architecture family for your
development processor, use this category.
Hardware Vendor
This is a list of hardware vendors for the development boards that are
supported by the Wind River BSPs. If you know the manufacturer of the
development board for the BSP you wish to use, use this category.
25
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
NOTE: This category is organized by hardware development board vendors,
not by processor manufacturer. In many cases, the CPU manufacturer is not
the board vendor.
Market
This is the general market targeted by the development board or processor.
For example, processors that are targeted for use in medical equipment are
grouped into one category while processors targeted for the automotive
market are grouped into that category.
Platform
This is a list of available Wind River products that include BSP support. You
can use this category to see a list of all BSPs available for your specific
Wind River product and version.
6.3.3 Downloading and Installing a BSP
This section provides detailed instructions for downloading and installing BSPs
for products from Wind River Workbench 3.0 forward.
The BSP Download Page
Once you have located your desired BSP, you must download and install the
associated .zip file. To get to the download page, find the correct entry in the BSP
list and click More (this button appears at the far right end of the specific BSP entry
line). This link brings you to the BSP technical details page.
If a version of the BSP is available for download, a link to a downloadable .zip file
appears at the top of the page under the BSP Sales Contact field. Certain BSPs are
only available as part of a product distribution. If this is the case, the Product
Availability field indicates that the BSP is available on CD-ROM (or DVD-ROM).
If you do not have the product CD (or DVD) for the BSP, contact Wind River
Customer Support for assistance.
Installing a BSP with the Maintenance Tool
Downloaded BSPs are placed in your installDir/updates directory. To install a new
BSP, launch the product Maintenance Tool:
26
6 Post-Installation Tasks
6.4 Building the VxWorks Run-Time Source
■
From the GUI
Select Applications (the main menu on the panel) > Wind River > Uninstall
and Maintenance > Maintenance Tool.
■
From the command line
Execute the following commands from the command shell:
% cd installDir/maintenance/mtool
% ./mtool_linux
6.4 Building the VxWorks Run-Time Source
The information in this section applies to one or more of the following product
bundles:
■
Wind River General Purpose Platform, VxWorks Edition
■
Wind River Workbench for VxWorks
■
Wind River VxWorks Platforms
NOTE: Wind River VxWorks Platforms includes:
Wind River Platform for Automotive Devices, VxWorks Edition (Platform AD)
Wind River Platform for Consumer Devices, VxWorks Edition (Platform CD)
Wind River Platform for Industrial Devices, VxWorks Edition (Platform ID)
Wind River Platform for Network Equipment, VxWorks Edition (Platform NE)
Any of the above products can be optionally purchased as a source code product.
However, Wind River VxWorks Platforms products (Platform AD, Platform CD,
Platform ID, and Platform NE) always include source code for technologies such
as the Wind River Network Stack. The General Purpose Platform and the
Wind River Workbench for VxWorks products are pre-compiled and do not
require a source code build (even if you have purchased the source code option).
The Platform AD, Platform CD, Platform ID, and Platform NE source code must
be compiled prior to using the Platform product.
NOTE: Platform AD, Platform CD, Platform ID, and Platform NE include a
pre-built kernel; but all other Platform technologies, including the network stack,
must be built from source prior to first use.
27
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
6.4.1 The Kernel and Platform Build Processes
Depending on what product and options you have purchased as well as your
development requirements, you may wish to perform a VxWorks kernel build or
a Platform technology build, or both. (Note that for the General Purpose Platform
and the Wind River Workbench for VxWorks products, neither build is required).
Additional information on each build process (and when it must be performed) is
provided in the remaining sections. Complete build instructions and additional
information on each build type is available from one of the following manuals
(depending on which product you have purchased):
■
Wind River General Purpose Platform, VxWorks Edition Getting Started: Compiling
Source
■
Wind River Workbench for VxWorks Getting Started: Compiling Source
■
Wind River VxWorks Platforms Getting Started: Compiling Platform Component
Source
Building VxWorks Kernel Source Code
In general, you are not required to compile the VxWorks operating system (kernel)
source code in order to begin development with any VxWorks-based product,
even if you purchase a source code product. The General Purpose Platform is
shipped fully pre-compiled and users are not required to compile any source code
before using this product. Wind River VxWorks Platforms users must compile
their product before use, but that requirement is limited to the network stack and
other technologies that sit above the underlying operating system. The kernel itself
is pre-compiled and does not need to be built prior to use. (For more information
on building Wind River VxWorks Platforms products, see Building Wind River
VxWorks Platforms Source Code, p.29.)
Although it is not required, there are many reasons for which you might wish to
build or, at a minimum, reference the VxWorks source code. One of the most
common reasons is to ease the application debugging process (the pre-built
VxWorks kernel images are not built with debug symbols).
28
6 Post-Installation Tasks
6.4 Building the VxWorks Run-Time Source
Building Wind River VxWorks Platforms Source Code
Wind River VxWorks Platforms products (Platform AD, Platform CD, Platform
ID, and Platform NE) are always shipped as source code and must be compiled
prior to using the product.
NOTE: In all Wind River VxWorks Platforms products, the VxWorks kernel and
system libraries are shipped in a pre-built form as well as source form. You can use
these pre-built binaries to develop a custom VxWorks image. However, the
pre-built code does not include networking facilities or any other Platform
technologies. Therefore, you will not have access to any of those features until you
have built the Platform source.
The following section provides a brief overview of the build process.
Wind River VxWorks Platforms Build Process Overview
Building the Wind River VxWorks Platforms source is a two step process.
1.
First, you can customize the features in your Platform using the Platform
Makefile. This makefile allows you to specify what features you want to have
available in your Platform during development. You can also choose to skip
this customization and compile your Platform without modification using the
default makefile options.
For complete information on customizing your Platform using the Platform
Makefile, see Wind River VxWorks Platforms Getting Started: Customizing the
Default Configuration.
2.
Next, you must execute the source code compile using Wind River Workbench
or the vxprj command-line utility. (For more information on the vxprj
command-line utility, see the VxWorks Command-Line Tools User’s Guide.) This
step also requires you to choose the compiler and target architecture you wish
to compile for.
6.4.2 Where to Find Additional Information
Complete build instructions and additional information on each build type is
available from one of the following manuals (depending on which product you
have purchased):
■
■
Wind River General Purpose Platform, VxWorks Edition Getting Started
Wind River Workbench for VxWorks Getting Started
29
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
■
Wind River VxWorks Platforms Getting Started
6.5 Building the Linux Target Run-Time Source
6.5.1 When Is It Necessary to Build Linux Source Code?
All Wind River Linux Platforms require a source code build prior to using the
product for development. You must build the source using one of the two build
methods that are available for building the product. The available methods are the
Red Hat package manager (RPM) build method and the source build method.
Additional information on each build type is provided in the following section.
Complete instructions for building your source code with each build type are
provided in the Wind River Linux Platforms Users Guide.
6.5.2 Choosing a Build Method
As stated previously, you must build your Platforms source before using the
product, and there are two methods available for building your Platform source
code. The first method is the RPM build method. This method is the fastest way to
build a complete run-time system. The RPM build method uses a pre-built, target
hardware and file system-specific kernel as well other pre-built elements to
assemble a complete run-time system. Because this method uses largely pre-built
source code to assemble the target run-time, the build completes in just minutes.
The second build option is a full source code build. This method allows you to
build the entire run-time system, including the kernel, from source. However,
when using this method, it can take several hours for a complete system to build
the first time it is run. If necessary, you can shorten the build time while still
maintaining control over what source code is built, by using the source build
method for your first build and then using the RPM build method for subsequent
builds. You can choose the source code build method to build only certain aspects
of the system (such as a kernel-only build) and then assemble the final run-time
system using the RPM method.
30
6 Post-Installation Tasks
6.6 Uninstalling Wind River Products
6.5.3 Where to Find Additional Information
Complete information on the available build types and step-by-step tutorials that
walk you through the Wind River Linux Platforms target run-time build process
are provided in the Wind River Linux Platforms User’s Guide.
6.6 Uninstalling Wind River Products
This section describes the process for removing Wind River products from a
system. If you are uninstalling a Wind River product in preparation for reinstalling
a newer version, or you are moving the product to a new development computer
and you want to continue working with it, you may first wish to archive some files
before uninstalling.
Archiving Downloaded Plug-Ins
If you installed any third-party plug-ins in the installation directory of your
Wind River product and you want to preserve them, you must move them outside
the installation directory. For more information about working with plug-ins, see
Wind River Workbench User’s Guide: Integrating Plug-Ins.
Preserving Workbench Project Files
To preserve the state of Workbench projects and be able to recreate them after
reinstalling the product, copy the following files to a location outside the
Workbench installation directory:
Project File
Description
.project
Eclipse platform project file containing general information
about the project.
.wrproject
Workbench project file containing mostly general build
properties.
31
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
.wrfolder
Workbench project file containing folder-level build properties
(located in subfolders of your projects).
.wrmakefile
Workbench managed build makefile template used to generate
makefiles.
*.makefile
Workbench managed build extension makefile fragments (for
example, for VxWorks image projects or some Platform projects).
*.wpj
VxWorks Image project file containing specific data not
managed directly by Workbench but by the TCL engine.
For user-defined projects, all makefiles must also be version-controlled.
6.6.1 Uninstalling Through the Maintenance Tool
To remove Wind River products, it is recommended that you use the Maintenance
Tool provided with your product installation. The Maintenance Tool can uninstall
many products at the same time.
NOTE: The Maintenance Tool removes all Wind River products from Wind River
Workbench 3.0 forward; it does not uninstall products from previous releases.
To launch the uninstallation tool, do the following:
■
From the GUI
Select Applications (the main menu on the panel) > Wind River > Uninstall
and Maintenance > Maintenance Tool.
■
From the command line
Execute the following commands from the command shell:
% cd installDir/maintenance/mtool
% ./mtool_linux
6.6.2 Uninstalling a Service Pack
Service packs are uninstalled the same way a standard release is uninstalled.
Follow the instructions in 6.6.1 Uninstalling Through the Maintenance Tool, p.32, to
uninstall the product(s) you no longer want to use.
32
7
Wind River
Environment Utility
(wrenv)
7.1 What Is wrenv? 33
7.2 When Are You Required to Invoke the wrenv Utility? 34
7.3 wrenv Command Options 35
7.4 wrenv Usage Examples 35
7.5 How Does wrenv Create a Unified Environment Setting? 36
7.6 What Is the Installation Properties File? 37
7.7 Advanced wrenv Topics 39
7.1 What Is wrenv?
The Wind River environment utility, wrenv, is primarily used to create a
command shell with a pre-loaded environment. The utility guarantees a
consistent, portable execution environment for tools (such as make) that are
launched from Wind River Workbench or from a command-line automation
environment such as the VxWorks development shell. The wrenv utility also
provides services that other tools can use to query environment settings that are
set by wrenv. The wrenv utility replaces the need for the multiple host and
shell-specific scripts (Vars scripts) that were used to set environment variables and
paths in earlier Wind River products.
33
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
7.2 When Are You Required to Invoke the wrenv Utility?
In many cases, the Wind River environment utility (wrenv) is invoked
automatically by the Wind River tools when your product is launched. Therefore,
when you are using a standard tools product (such as Wind River Workbench) to
do standard development, you are not required to launch wrenv manually.
However, there are certain cases where this is required. For example, when using
the Workbench tools for VxWorks from the command line (using the vxprj
command-line facility), you must begin by invoking wrenv.
For more information on using the wrenv utility, see 7.2.1 Invoking the wrenv
Utility, p.34, and 7.5 How Does wrenv Create a Unified Environment Setting?, p.36, as
well as the VxWorks Command-Line Tools User’s Guide: Creating a Development Shell
with wrenv.
7.2.1 Invoking the wrenv Utility
To invoke the wrenv utility, open a host shell and type the following:
% installDir/wrenv.sh -p package
where package is the name of the product package you wish to use.
For example, to invoke the proper environment for VxWorks 6.4 development,
type the following:
% installDir/wrenv.sh -p vxworks-6.4
NOTE: If your shell configuration file overwrites the environment each time a new
shell is created, the above command may not work. If you have difficulty invoking
the Workbench tools after executing the above command, invoke wrenv as
follows:
% eval ‘installDir/wrenv.sh -p vxworks-6.4 -o print_env -f shell’
where shell is sh or csh, depending on your current shell program.
34
7 Wind River Environment Utility (wrenv)
7.3 wrenv Command Options
7.3 wrenv Command Options
The general syntax for a wrenv command is as follows:
% wrenv options env=value command [args]
The -p option (-p package) selects the package to use for the environment
initialization and is used for all invocations. The only exception is when an
initializer package is defined in install.properties. (For more information on
initializer packages, see Initializer Packages, p.41.)
In addition to the -p option, wrenv accepts a number of additional command-line
options that allow you to further customize your development environment. For
information on these additional wrenv command-line options, see the VxWorks
Command-Line Tools User’s Guide: Creating a Development Shell with wrenv.
7.4 wrenv Usage Examples
The following are some common use case scenarios for the wrenv utility. An
advanced use case regarding installing packages from multiple installation
locations is also provided later in this text (see 7.7.1 Using Packages from Multiple
Installation Locations, p.39).
Creating a Development Shell
As mentioned previously, the most common usage of wrenv is to set up a specific
development environment prior to using your Wind River product. The preferred
syntax is as follows:
% wrenv.sh –p package
This command spawns a development shell with the environment for the selected
package (package).
Setting the Development Environment Without Spawning a Shell
In some cases, it is not desirable to start a development shell—for example, when
you are using scripting to set the environment on a host, or when you cannot start
35
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
a development shell because your .cshrc or .profile file overrides PATH or other
variables whenever a shell is started.
In these cases, the following command can be used to output the environment
variables to standard out:
% wrenv.sh –p package –o print_env –f format
In this example, format specifies the output format or shell type, which can be set
to plain, sh, csh, bat, or tcl.
For example, to set the environment in csh without starting a sub-shell, use the
following command:
% eval 'wrenv.sh –p package –o print_env –f csh'
7.5 How Does wrenv Create a Unified Environment Setting?
The wrenv utility takes advantage of an installation properties file
(install.properties). The installation properties file, which can be considered a type
of installation registry, consolidates various pieces of information in a single
location, including the information needed for environment settings. The
installation properties file is independent of host platform and provides
information to help enforce correct environment setting dependencies across
multiple installed component packages (such as Wind River Workbench,
Wind River VxWorks Platforms, documentation, and test packages). At product
installation time, the installation properties file is created by aggregating the
package property files (package.properties) that accompany each installed
package. The installer invokes a post-installation script
(installDir/setup/postinstall.sh) to aggregate the necessary package.properties
files. The wrenv utility is the primary processing engine for information stored in
the installation properties file. Typically, wrenv processes any environment
setting information related directly or indirectly to the selected package (-p option)
in the installation properties file and then creates a new command shell containing
the specified environment.
36
7 Wind River Environment Utility (wrenv)
7.6 What Is the Installation Properties File?
7.6 What Is the Installation Properties File?
NOTE: Do not edit the install.properties file. The information provided in this
section is for reference purposes only.
The following is a typical example of the contents of an installation properties file.
Comment lines in a properties file begin with a # symbol as the first
non-white-space character.
#Sample install.properties file
vxworks66.name=vxworks-6.6
vxworks66.version=6.6
vxworks66.type=platform
vxworks66.subtype=vxworks
vxworks66.label=Wind River VxWorks 6.6
vxworks66.bdp_type=preference
vxworks66.bdp_creationcmd=cat
$WIND_BASE/host/resource/bdgen/%projecttype%.cache
vxworks66.eval.01=export WIND_HOME=$(builtin:InstallHome)
vxworks66.eval.02=export WIND_BASE=$(WIND_HOME)$/vxworks-6.6
vxworks66.eval.03=export WIND_USR=$(WIND_BASE)$/target$/usr
vxworks66.eval.04=require
[compiler,diab,5.6.0],[compiler,gnu-vxworks-6.6,4.1.2]
vxworks66.eval.05=require [workbench,,3.0]
vxworks66.eval.06=addpath PATH $(WIND_BASE)$/vxtest$/src$/scripts
vxworks66.eval.07=addpath PATH $(WIND_BASE)$/host$/$(WIND_HOST_TYPE)$/bin
vxworks66.eval.08=addpath LD_LIBRARY_PATH
$(WIND_BASE)$/host$/$(WIND_HOST_TYPE)$/lib
vxworks66.eval.09=addpath WIND_SAMPLES $(WIND_BASE)$/target$/src$/demo
vxworks66.eval.10=addpath WIND_SAMPLES $(WIND_USR)$/apps$/samples
vxworks66.eval.11=addpath MANPATH $(WIND_BASE)$/man
vxworks66.eval.12=export TCLLIBPATH=$(WIND_BASE)/host/resource/tcl
vxworks66.eval.13=export WIND_PLATFORM=vxworks-6.6
vxworks66.eval.14=optional [components,,1.0]
vxworks66.eval.15=optional wrmscomponents
workbench30.name=workbench-3.0
workbench30.version=3.0
workbench30.type=workbench
workbench30.label=Wind River Workbench 3.0
workbench30.eval.01=export WIND_HOME=$(builtin:InstallHome)
workbench30.eval.02=export WIND_DOCS=$(WIND_HOME)$/docs
workbench30.eval.03=export WIND_HOST_TYPE=$(builtin:HostType)
workbench30.eval.04=export WIND_TOOLS=$(WIND_HOME)$/workbench-3.0
workbench30.eval.05=define WIND_LICENSE=$(WIND_HOME)$/license
workbench30.eval.06=export WIND_DFW_PATH=$(WIND_TOOLS)$/dfw$/0199_1
workbench30.eval.07=define WIND_JRE_PATH=$(WIND_HOME)$/jre$/1.5.0_11
workbench30.eval.08=export WIND_JRE_HOME=$(WIND_JRE_PATH)$/$(WIND_HOST_TYPE)
workbench30.eval.09=export
WIND_WRWB_PATH=$(WIND_TOOLS)$/wrwb$/platform$/eclipse
workbench30.eval.10=export
WIND_FOUNDATION_PATH=$(WIND_TOOLS)$/foundation$/4.1.1
37
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
workbench30.eval.11=export WIND_WRSV_PATH=$(WIND_TOOLS)$/wrsv$/4.10
workbench30.eval.12=addpath PATH
$(WIND_FOUNDATION_PATH)$/$(WIND_HOST_TYPE)$/bin
workbench30.eval.13=addpath LD_LIBRARY_PATH
$(WIND_FOUNDATION_PATH)$/$(WIND_HOST_TYPE)$/lib
workbench30.eval.14=addpath PATH $(WIND_TOOLS)$/$(WIND_HOST_TYPE)$/bin
workbench30.eval.15=addpath LD_LIBRARY_PATH
$(WIND_TOOLS)$/$(WIND_HOST_TYPE)$/lib
workbench30.eval.16=addpath LD_LIBRARY_PATH
$(WIND_WRWB_PATH)$/$(WIND_HOST_TYPE)$/bin
workbench30.eval.17=addpath WRSD_LICENSE_FILE $(WIND_LICENSE)
workbench30.eval.18=addpath WIND_SAMPLES $(WIND_TOOLS)$/samples
workbench30.eval.19=addpath PATH $(WIND_HOME)
workbench30.eval.20=export
WIND_USERMODE_AGENT_PATH=$(WIND_HOME)$/linux-2.x$/usermode-agent
workbench30.eval.21=export
WIND_USERMODE_AGENT=$(WIND_USERMODE_AGENT_PATH)$/bin$/usermode-agent.sh
workbench30.eval.22=optional scopetools-6.0
workbench30.eval.23=optional unittester-2.6
workbench30.eval.24=undefine TCL_LIBRARY
workbench30.eval.25=export WIND_OCD_PATH=$(WIND_TOOLS)$/ocd$/0127
workbench30.eval.26=addpath DFW_PLUGIN_PATH $(WIND_TOOLS)$/ocd$/0127
workbench30.bdp_dir=$(WIND_TOOLS)/buildDefaults
workbench30.compatible.01=[platform,vxworks,6.3,6.7]
workbench30.compatible.02=[platform,wrlinux,1.3,2.0]
workbench30.compatible.03=[platform,vxworks653,2.2,2.4]
The install.properties file is a hierarchical registry of package components. It
aggregates information from the package.properties files that accompany each
installed package. An entry in a properties file has the following form:
rootkey.subkey=value.subkey=value ...
The install.properties file is dynamically created at installation time by
concatenating all package.properties files found in the first- and second-level
directories under the installation home directory (installDir). This is done by a
post-installation program without any involvement from the wrenv program.
Each entry in the installation properties file can be considered as a hierarchical
registry entry. The root key of each entry is a unique key determined by the name
of an installed package component and is used by wrenv to group related entries
together into packages. A hierarchical system of subkeys exists under each root key,
with each subkey having its own unique interpretation. Subkeys define items such
as the package name or version numbers and compatibility with other packages as
well as more complex environment settings.
38
7 Wind River Environment Utility (wrenv)
7.7 Advanced wrenv Topics
7.6.1 Package Descriptor
Package descriptors are used to reference other packages. The format of a package
descriptor is as follows:
[type-name,subtype-name,low-version,high-version]
The type-name and subtype-name values select the package class of the referenced
package. The low-version and high-version values are used to specify a range of
version numbers from the installed packages of the specified class that wrenv
should reference. By default, wrenv selects the highest matching version. You can
control this by specifying preferred packages using the –P command-line option.
The high-version field is optional and, when not specified, wrenv matches on all
versions with the same major and minor version number that are greater or equal
to the low-version.
For example, [platform,vxworks,6.3,6.6] refers to any version of VxWorks version
6.3 up to—but not including—6.6. It might seem awkward at first that the
high-version field is non-inclusive; however, this was done by design because one
would otherwise have to use something like 6.5.999.999 to specify the same
behavior.
7.7 Advanced wrenv Topics
This section includes information on advanced topics. These features may not be
supported for your installation. If you have questions on these topics and their
support, contact Wind River Customer Support.
7.7.1 Using Packages from Multiple Installation Locations
In some cases, you may wish to install each package in a separate installation root
directory. Two different ways to accomplish this scenario are described in the
following sections.
Note that the following examples use three sample packages as follows:
■
IDE
– Installation location: /inst/ide
– Root path variable: IDE_PATH
39
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
■
■
Run-time
– Installation location /inst/runtime
– Root path variable: RUNTIME_PATH
Compiler
– Installation location: /inst/compiler
– Root path variable: COMPILER_PATH
Each package contains a package.properties file in the top-level directory.
Using Multiple -i Options
With multiple -i options, wrenv concatenates the contents of each file specified,
dynamically creating an install.properties file with all the relevant packages. (For
more information on the install.properties file, see 7.6 What Is the Installation
Properties File?, p.37.) The package root environment variable for each package is
specified as follows:
% wrenv.sh –p runtime –i /inst/ide/package.properties
–i /inst/runtime/package.properties –i /inst/compiler/package.properties
INSTALL_PATH=/inst/root IDE_PATH=/inst/ide RUNTIME_PATH=/inst/runtime
COMPILER_PATH=/inst/compiler
Using the Initializer Package
The initializer package approach removes the need to specify numerous
command-line options. For this example, the initializer package is as follows:
initializer.name=initializer
initializer.type=initializer
initializer.eval.01=export INSTALL_PATH=/inst/root
initializer.eval.02=export IDE_PATH=/inst/ide
initializer.eval.03=export RUNTIME_PATH=/inst/runtime
initializer.eval.04=export COMPILER_PATH=/inst/compiler
initializer.eval.05=include $(IDE_PATH)$/package.properties
initializer.eval.06=include $(RUNTIME_PATH)$/package.properties
initializer.eval.07=include $(COMPILER_PATH)$/package.properties
initializer.eval.08=default runtime
Assuming the above is in the file myplatform, the following command is used to
set up the environment:
% wrenv.sh –i ~/myplatform
For more information on using the initializer package, see the next section.
40
7 Wind River Environment Utility (wrenv)
7.7 Advanced wrenv Topics
7.7.2 Special Packages
This section describes the special package types that are available for wrenv.
Initializer Packages
An initializer package (if provided, see 7.7.1 Using Packages from Multiple
Installation Locations, p.39) is evaluated prior to evaluating the package specified
by the -p option. This package is intended to include other properties files (see
7.6 What Is the Installation Properties File?, p.37), define variables, and set the default
package name.
An example initializer package file might include the following lines:
initializer.name=initializer
initializer.type=initializer
initializer.eval.01=export TEST_HOME=$(builtin:InstallHome)
initializer.eval.02=include $(TEST_HOME)$/install.properties1
initializer.eval.03=include $(TEST_HOME)$/install.properties2
initializer.eval.04=include $(TEST_HOME)$/install.properties3
initializer.eval.05=default vxworks-6.1
Extension Packages
Packages of the type extension are used to dynamically extend other packages.
These packages are evaluated automatically when the package they extend is
evaluated. This is very useful to add properties to packages that cannot be
modified directly. For example, this can happen in the following situations:
■
When the package to be extended is not owned by your company or your
group.
■
For packages that are optionally installed but still must be integrated with
some package.
An extension package has the same format as any other package with the
following key points to remember:
■
The type value must be set to extension.
■
Extension packages are matched with the extended package using one or more
compatibility properties.
For example, the add-on package to Workbench 2.5 could look as follows:
testext.name=testext
41
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
testext.type=extension
testext.subtype=testext
testext.version=1.0
testext.compatible=[workbench,,2.5]
testext.eval.01=export TESTEXT_BASE=$(WIND_HOME)$/textext
testext.eval.02=addpath PATH $(TESTEXT_BASE)$/bin$/$(WIND_HOST_TYPE)
testext.eval.04=addpath SAMPLES $(TESTEXT_BASE)$/samples
testext.eval.06=addpath WIND_EXTENSIONS $(TESTEXT_BASE)$/extensions
42
8
Configuring a Remote
Build Server
8.1 Do You Need to Set Up a Remote Build Server? 43
8.2 Performing Remote Builds with Wind River Workbench 43
8.3 General Requirements for Remote Builds 44
8.1 Do You Need to Set Up a Remote Build Server?
A remote build server is desirable if your developers want to offload build cycles
to a remote system rather than doing builds on their development computers.
8.2 Performing Remote Builds with Wind River Workbench
The Workbench remote build feature allows you to develop, build, and run your
applications on a local host that is running Workbench, using a workspace that is
located on a remote host as if it were on a local disk.
43
Site Configuration Setup Guide
Linux Hosts, Single Workstation Installation
When you launch the build, a network connection (rlogin or SSH) is established
to the build host, and the actual build command is executed there, using an
intermediate script that allows you to set up the needed environment for the build
process.
8.3 General Requirements for Remote Builds
■
The workspace root directory must be accessible from both computers.
■
Only Eclipse projects located underneath the workspace root can be remotely
built. In other words, linked resources are not supported for files outside the
workspace.
■
A rlogin or SSH remote connection to the build host must be possible.
For more information about the Workbench remote build feature, see the
Developing on Remote Hosts section of Wind River Workbench User’s Guide: Building:
Use Cases.
44
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
