IN26+
Display
Native Aspect Ratio:
4x3
Supported Aspect Ratio:
16:9, 4:3
Brightness: (max ANSI
lumens)
Whisper: 1760 max ANSI lumens
High Bright: 2200 max ANSI lumens max ANSI lumens
Contrast Ratio:
2000 : 1 Full On/Full Off
Display Technology:
DLP by Texas Instruments: 0.55" XGA DDR DMD
Data Compatibility:
640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050
Video Compatibility:
Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i
Color Wheel (DLP Only):
4-segment, 2-speed
Native Resolution:
XGA
Projector Placement:
Ceiling Projection, Front Projection, Rear Projection
SMPTE Brightness:
Not Available
Lamp Wattage:
Whisper: 200 Watts
High Bright: 250 Watts
Lamp Life:
Whisper: 2000 Hours
High Bright: 2000 Hours
Minimum Image Size:
2.8 ft (0,85 m)
Maximum Image Size:
20.7 ft (6,31 m)
Standard Lens Zoom:
1.1 : 1
Standard Lens Throw
Ratio:
1.94 - 2.13 (Distance/Width)
Standard Lens Image
Offset Ratio:
112.2% (4:3)
Standard Lens Projection 4.9 - 32.8 ft (1,49 - 10 m)
Distance:
Digital Keystone
Correction (Vertical):
+30°/-25°
Digital Keystone
Correction (Horizontal):
Lens Shift:
Not Available
Inputs and Outputs
DVI:
Not Available
M1:
Not Available
HDMI:
Not Available
BNC:
Not Available
Component (RCA):
Number of Inputs: 1
Progressive only supported. Requires VESA to Component adapter (SP-VESA-ADPT)
VESA (HD15):
Number of Inputs: 1
15-pin analog
S-Video:
Number of Inputs: 1
4-pin DIN
Composite (RCA):
Number of Inputs: 1
Standard Definition TV:
Composite RCA, S-Video, Component RCA
Enhanced Definition TV:
Component RCA, VGA
High Definition TV:
Component RCA, VGA
Computer:
VGA
HDCP Support:
No
Stereo RCA Jacks
Inputs:
Yes
Stereo 3.5 mm Mini-jack
Inputs:
No
12v trigger for motorized
screens (3.5 mm minijack):
No
Projector Control:
Projector Keypad, Remote
Speakers:
1.0 Watt mono speaker
Monitor Output:
Yes
Audio Output:
3.5mm mini-jack
Compatibility
Data Compatibility:
640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1400 x 1050
H-Sync Range:
15.8 - 85kHz
V-Sync Range:
50 - 85Hz
Video Compatibility:
Full NTSC, PAL, SECAM, 480i, 576i, 480p, 576p, 720p, 1080i
General
Audible Noise:
35 dB
Actual Dimensions:
Height: 3.97 in (10,08 cm)
Length: 9.45 in (24 cm)
Width: 11.97 in (30,4 cm)
Actual Weight:
5.95 lbs (2,7 kg)
Shipping Dimensions:
Height: 13.3 in (33,78 cm)
Length: 17.9 in (45,47 cm)
Width: 8 in (20,32 cm)
Shipping Weight:
9.7 lbs (4,4 kg)
Projector Warranty:
2 Year
Lamp Warranty:
6 months
Accessories Warranty:
90 Days
Operating temperature:
(at sea level)
41 - 104° F (5 - 40° C)
Maximum Altitude
Supported:
10000 ft (3048 m)
Typical Power
Consumption:
250 Watts
Maximum Power
Consumption:
300 Watts
Power Supply:
100 - 240 Volts at 50 - 60 Hz
Menu Languages:
English, French, German, Italian, Portuguese, Russian, Simplified Chinese, Spanish
Approvals:
UL and c-UL (US/Canada), FCC-B (US/Canada), GOST (Russia), TUV GS (Germany), CCC (China),
IRAM (Argentina), NOM (Mexico) C-Tick (Australia)
