Wherever we go, we like to be heard.

We aim for total customer satisfaction.

We believe in fully customised sound-designs.

To provide high quality sound for every setting.

We achieve this thanks to our highly fl exible range, customised designs and constant research into innovation.

Highly specialised in ambient amplifi cation systems

Audio Contractor: a young and wise leader

This Brand, with a strategic and productive lay-out of the latest generation, was offi cially set up in 1998 as a Division of the FBT Group.

Highly specialised in ambient amplifi cation systems, Audio

Contractor benefi ts from all the know-how and extensive expertise acquired by the parent company in over 40 years of business.

In a short space of time, Audio Contractor has made its mark on the market, integrating and implementing a winning combination of strengths: attaining total customer satisfaction, constant innovation, offering an extensive range of products, top quality sound performance, and non-stop after-sales service 365 days a year.

Sound design: stylish designs Music in the genes

At the very heart of the corporate philosophy, the concept of “Sound Design”, an original outlook on production and service aiming for standards of excellence in terms of technology and acoustics along with the “custom-made” design of the application venue - including theatres, conference halls, shopping centres, factories and hospitals. The major strengths of the brand, i.e. top quality, new developments and maximum reliability all contribute to offer an extensive and constantly updated range of products, distinguished by a stylish aesthetic look that epitomises the “made in Italy”.

The love of music and the application of this love, in an industrial context, to sound reinforcement are part of FBT’s genetic make-up. A

Group destined for success, because it traces its origins back to a special, unique part of the world in the Marche region called Recanati, where music has always bee an essential part of the very fabric of society. Originally a small workshop established in the Nineteen

Sixties, the Group is today recognised on a national and international scale as a leader in the manufacture of a variety of equipment, ranging from the Professional Audio Equipment amplifi cation systems to the Audio Contractor ambient amplifi cation, and also the Musical

Instrument Distribution division, with a continuous growth trend.

... extensive range of products, top quality sound performance, and non-stop after-sales service...

5

Sound systems for large venues...

Solutions for professionals...

66

Clear announcements.

Hi-Fi music programming. Integrated control consoles, designed to create certain “frequencies” in every setting. Customised equipment.

To make our customers feel even more at home, both in Italy and abroad, we design integrated sound systems. To refl ect and interpret the sound “image” of every venue.

The Eighteenth-Century Villa Foscarini -

Cornaro in Gorgo al Monticano - Treviso, the

“Le Brentelle” Shopping Centre in Rubano -

Padua and the Municipal Casino in Venice, overlooking the Grand Canal, are but a few of the most prestigious projects completed.

Solutions for professionals

Thanks to a sturdy know-how geared towards attaining the utmost standards of excellence,

Audio Contractor provides sound designs to meet the requirements of every “leading” venue.

All of which are stubbornly devised to integrate the use of the most advanced technologies, with the smoothest aesthetic and architectural blend.

SECuRIty And

EMERgEnCy SyStEMS

Polideportivo Romareda, Zaragoza

Spain

7

This series of products has been designed and engineered to offer the most innovating solutions in the realization of alarms systems, in order to manage emergency situations and to permit the guided evacuation, according to actual regulations (EN 54-16, ISO 7240-19 e EN 60849).

The VAIE 2250 offers the right answer for any system requirement; the combined action of the new control units and the new digital amplifiers permits flexible and easily expandable installations both for numbers of zones and for sound power, in compliance with safety standards.

The complete architecture of

VAIE 2250 system is based on the controller VAC 2006, the management and diagnostics unit. It is highly recommended for big as well as small installations, where high performance of security, flexibility and easiness are required.

Each VAC 2006 can manage 6 lines to which the following units can be directly connected:

• DPU range of digital amplifiers, equipped with a diagnostics card (up to 16 per line)

• Router VAR 2006 for up to

6 outputs zones with A & B speaker lines

• VAC 2006 Integrated Voice

Evacuation Systems with 6 zones

The remote consoles FMD 2001 and FMD 2012 are fully diagnosed, and allow greater operational and management flexibility for any service and/or emergency calls and/or prerecorded messages on the zones of the system.

The possibility to connect in daisy chain up to 6 controller VAC 2006 and to manage up to 36 lines allows to realize up to 216 zones for voice evacuation/music.

CAT5 network assures an easy connection of the several units, controllers, routers, digital amplifiers and emergency and/ or paging call stations. This solution performs in efficient and economic installation also in big buildings, allowing the usage of both local and centralized equipment.

8

VAC 2006 CONTROLLER AND

DIGITAL AMPLIFIER DPU

SERIES

It is possible to connect 6 controllers VAC 2006 to each other and to manage up to a maximum of 36 groups of DPU digital amplifiers, obtaining a 2 channel system with 36 output zones with double line.

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

I/O CONTACTS

FIRE UNIT

VAC 2006

CONTROLLER

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT ALRM FAULT DIS. SYS. BATT. ON

EMERGENCY

ALRT

RESET MENU TO PC

OK

EXT.

EVAC.

ESC

1 2 3 4 5 6

CAT5 SFTP

VAC 2006

CONTROLLER

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT

EMERGENCY RESET

ALRT

ALRM FAULT DIS. SYS. BATT. ON

MENU

OK

TO PC

EXT.

EVAC.

ESC

1 2 3 4 5 6

Z.1

Z.6

LINE A

LINE B

LINE A

LINE B

VAR 2006

COM.-SYS

CTRL.IN

MAINS

GND

SP.Z1-3

SP.Z4-6

BATTERY

FAULTS

MUS.-SPARE FAULT

STATUS

VOICE ALARM ROUTER

ALARM

CTRL.IN

DISABLE

ZONE OUTPUT

MSG.

LINE A

LINE B

Z.7

PROGRAM INSERTION

VAR 2006

ROUTER

EMERG.

CALL

ON

BATT.

LINE A

LINE B

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1500C

Digital Power Unit

DPU 1500C

BACKUP 100V

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit DPU 1125C

ON

DPU 1125C

LINE A

LINE B

ON dB dB

-40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1250C

Digital Power Unit

DPU 1250C

LINE A

LINE B

BACKUP

100V

500 W

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1500C

Digital Power Unit

DPU 1500C

MPA 5480 BOOSTER 1

VOICE

500 W

MPA 5480 BOOSTER 2

MUSIC/SPARE

Z.8

Z.9

24VDC OUT

TO ALL

SECONDARY PSU IN

SON 24V 6A MS40

BATTERY CHARGER

LINE A

LINE B

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1125C

ON

Digital Power Unit

DPU 1125C

LINE A

LINE B

ON dB dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1250C

Digital Power Unit

DPU 1250C

BACKUP

100V

ON dB -40 -10 -6 -3 dB

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1250C

Digital Power Unit

DPU 1250C

COM.-SYS

CTRL.IN

MAINS

VAR 2006

GND

SP.Z1-3

SP.Z4-6

BATTERY

FAULTS

MUS.-SPARE

VOICE ALARM ROUTER

ALARM

CTRL.IN

DISABLE

STATUS

FAULT

ZONE OUTPUT

MSG.

LINE A

LINE B

LINE A

LINE B

LINE A

LINE B

PROGRAM INSERTION

VAR 2006

ROUTER

EMERG.

CALL

ON

BATT.

500 W

MPA 5480 BOOSTER 1

PMD Series

VOICE

500 W

MPA 5480 BOOSTER 2

PMD Series

VOICE

500 W

MPA 5480 BOOSTER 3

MUSIC/SPARE

Z.10

Z.15

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

VAC 2006 CONTROLLER AND VAR

2006 ROUTER

In a system which includes 6 controller VAC 2006, each one connected to a maximum of 6 routers VAR 2006, it is possible to obtain up to 216 double line output zones.

I/O CONTACTS

FIRE UNIT

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

VAC 2006

CONTROLLER

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT

EMERGENCY RESET

ALRM FAULT DIS. SYS. BATT. ON

ALRT

MENU TO PC

OK

EXT.

EVAC.

ESC

1 2 3 4 5 6

CAT5 SFTP

Z.1

Z.6

LINE A

LINE B

LINE A

LINE B

Z.7

VAIE 2250

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT

EMERGENCY RESET

ALRM FAULT DIS. SYS. BATT. ON

ALRT

EVAC.

1 2 3 4 5 6

MENU

OK

ESC

TO PC

EXT.

LINE A

LINE B

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1500C

Digital Power Unit

DPU 1500C

BACKUP 100V

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1125C

ON

Digital Power Unit

DPU 1125C

LINE A

LINE B

ON dB -40 -10 -6 -3

ON dB

GND

SPK

AMP.

OVL

HOT POWER

OFF

DPU 1250C

Digital Power Unit

DPU 1250C

LINE A

LINE B

BACKUP

100V

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit DPU 1500C

DPU 1500C

Z.8

Z.9

24VDC OUT

TO ALL

SECONDARY PSU IN

LINE A

LINE B

ON dB -40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit DPU 1125C

ON

DPU 1125C

LINE A

LINE B

dB dB

-40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT

ON

POWER

OFF

DPU 1250C

Digital Power Unit

DPU 1250C

BACKUP

100V

ON dB dB

-40 -10 -6 -3

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit DPU 1250C

DPU 1250C

VAC 2006

CONTROLLER

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT

EMERGENCY RESET

ALRM FAULT DIS. SYS. BATT. ON

MENU

TO PC

ALRT

EVAC.

OK

ESC

EXT.

1 2 3 4 5 6

LINE A

LINE B

LINE A

LINE B

Z.10

Z.15

COM.-SYS

CTRL.IN

VAR 2006

MAINS

BATTERY

FAULTS

GND

SP.Z1-3

SP.Z4-6

MUS.-SPARE

VOICE ALARM ROUTER

ALARM

CTRL.IN

STATUS

DISABLE

FAULT

ZONE OUTPUT

MSG.

LINE A

LINE B

PROGRAM INSERTION

VAR 2006

ROUTER

EMERG.

CALL

ON

BATT.

500 W

MPA 5480 BOOSTER 1

PMD Series

VOICE

500 W

MPA 5480 BOOSTER 2

PMD Series

VOICE

500 W

MPA 5480 BOOSTER 3

MUSIC/SPARE

SON 24V 6A MS40

BATTERY CHARGER

VAC 2006

CONTROLLER

482

Code 37713

The controller VAC 2006 is the heart of VAIE 2250 evacuation system; it has been designed to drive all the supervising functions of the entire system, in compliance with the current safety standard for voice evacuation systems. It also manage and controls all the audio signals (evacuation, alert and standard messages and background music).

Feature:

• Controlled emergency microphone on the front panel

• 2-channel broadcast system

• Built-in message generator to broadcast prerecorded messages (EVAC and ALERT)

• USB input for background music source

• RJ45 CAT5 connections for:

- 6 control lines for PMD digital amplifiers and/or router

VAR 2006 and/or integrated voice evacuation system

VAIE 2250

- 4 redundant lines to connect other VAC 2006 in daisy chain

(max 6)

- 2 redundant lines for emergency microphone consoles, FMD 2001 range

(max 7)

• 2 lines for call stations FMD range (max 16 with 7 priority levels)

• Back-up power amplifier management

• Secondary emergency power supply input (24 VDC)

• 7 controlled input contacts

• 3 relay outputs

• Graphic display 128x64 pixel monochrome, for displaying multiple windows management

• Complete diagnostic of system fault events

• Standard rack mounting 19” (2 units)

I/O CONTACTS

FIRE UNIT

VAC 2006

CONTROLLER

MICROPHONE

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT

EMERGENCY

RESET

ALRM FAULT DIS. SYS. BATT. ON

ALRT

EVAC.

MENU

OK

ESC

TO PC

EXT.

1 2 3 4 5 6

MBT 1106

MBT 1112

(up to 16)

DIGITAL AMP

LINE A

ON dB -40 -10 -6 -3 0

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit

DPU 1125C

DPU 1125C

LINE B

LINE A

ON dB -40 -10 -6 -3 0

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit

DPU 1125C

DPU 1125C

LINE B

LINE A

ON dB dB

ON

-40

GND

-10 -6 -3

SPK

AMP.

OVL

0

HOT POWER

OFF

Digital Power Unit

DPU 1250C

DPU 1250C

LINE B

Z.1

(125W)

Z.2

(375W)

FMD 2001

FMD 2012

(up to 7)

24VDC OUT

TO ALL

SECONDARY PSU IN

SON 24V 6A MS40

BATTERY CHARGER

A

ON dB -40 -10 -6 -3 0

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit

DPU 1500C

DPU 1500C

BACKUP

100 V

B

ON dB -40 -10 -6 -3 0

ON

GND

SPK

AMP.

OVL

HOT POWER

OFF

Digital Power Unit

DPU 1500C

DPU 1500C

Z.6

(500W)

9

VAR 2006

ROUTER

482

Code 37712

The router VAR 2006 is the best solution for the sound systems with a very interesting compromise between price and performance; connected to a VAIE

2250 control line, it can drive up to 6 zones with external power amplifiers (MPA5000 range) to a maximum of 1000 W.

Each output line consists of 2 speaker circuits (A & B) in order to guarantee the complete area coverage also in case of one loudspeaker circuit failure. The maximum system configuration includes 6 controllers connected to 36 routers (6 for each VAIE

2250) for a total of 216 zones.

The router can be used with power signals (amplifier 100 V output).

Two different configurations are possible: in the first one you can connect 2 amplifiers (one for music and one for speech); in the second configuration it is possible to manage 2 voice amplifiers (3 zones each) and one music amplifier. In any case all connected amplifiers are constantly monitored and the music one can be also used as backup: in case of a failure it automatically replaces the voice amplifier.

• 6 speakers zones with double output lines A+B

• Double input 100 V for 1 or 2 voice amplifiers (IN 1 zone 1÷3,

IN 2 zone 4÷6)

• Front panel push button to switch on/off the music on each single zone

• RJ45 socket for VAIE 2250 connection

• 7 controlled input contacts

• 6 open collector outputs

• 2 relay outputs

10

Z.6

Z.4

Z.3

500 W MAX Z.1

LINE A

LINE B

LINE A

LINE B

LINE A

LINE B

LINE A

LINE B

VAR 2006

ROUTER N°1

VAR 2006

COM.-SYS

CTRL.IN

MAINS

BATTERY

FAULTS

GND

SP.Z1-3

SP.Z4-6

MUS.-SPARE

VOICE ALARM ROUTER

ALARM

CTRL.IN

DISABLE

FAULT

STATUS

1 2 3 4 5

ZONE OUTPUT

6

MSG.

LINE A

LINE B

1

1 2 3 4 5

PROGRAM INSERTION

6

EMERG.

CALL

ON

BATT.

6

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

MICROPHONE

VAC 2006

CONTROLLER

VAIE 2250 VOICE ALARM INTEGRATED EQUIPMENT ALRM FAULT DIS. SYS. BATT. ON

RESET MENU

EMERGENCY TO PC

ALRT OK

EXT.

EVAC.

ESC

1 2 3 4 5 6

1 6

CAT5 SFTP

I/O CONTACTS

FIRE UNIT

MPA 5480 BOOSTER 1

PMD Series Digital power unit

VOICE

500 W

VAR 2006

COM.-SYS

CTRL.IN

MAINS

BATTERY

FAULTS

GND

SP.Z1-3

SP.Z4-6

MUS.-SPARE

VOICE ALARM ROUTER

STATUS

ALARM

CTRL.IN

DISABLE

FAULT

1 2 3 4 5

ZONE OUTPUT

6

MSG.

LINE A

LINE B

VAR 2006

ROUTER N°6

1 2 3 4 5 6

PROGRAM INSERTION

EMERG.

CALL

ON

BATT.

ROUTER AND MPA 5000 AMPLIFIERS

TO MANAGE ZONE 30÷36

MPA 5480 BOOSTER 2

PMD Series

VOICE

500 W

MPA 5480 BOOSTER 3

MUSIC/SPARE

500 W

24VDC OUT

TO ALL

SECONDARY PSU IN

SON 24V 6A MS40

BATTERY CHARGER

EN 54 - 16

DPU RANGE

CLASS D MODULAR AMPLIFIERS

MPA 5240/5480

MAIN FRAME

EN 54 - 16

Careful design and a choice of reliable high-tech components led to the creation of this range of extremely compact Class D amplifiers, capable of functioning even in the toughest conditions and with a minimum energy consumption.

They include a diagnostics board which permits easy and rapid test of the correct unit operation and the check of the loudspeaker’s line integrity. The double output circuit with a separate control (A and B) allows realizations of redundant line plants. In case of short circuit on one of the two output lines, the damaged line will automatically be disconnected to allow the regular working of the other one.

The CHA 1004 (Code

37711)

power card-cage enables amplifier units to be installed in a standard

19” rack. On each cage can be installed up to 4 amplifiers DPU

1125 C and/or DPU 1250 C or up to

2 amplifiers DPU 1500 C.

The DPU amplifiers have been designed to be used with the

VAIE 2250 system; they can allow to develop high power zones when they are connected to the controller VAC 2006 through a shielded cable CAT5 SFTP.

A maximum of 16 DPU units can be connected to each of the six

VAC 2006 output lines (zones); a backup amplifier for each group can be set.

The independent power supply of each amplifier makes this system really reliable and fully in compliance with safety standards.

Code

DPU 1125 C

37724

Rated output power

@230 VAC

125 W RMS

DPU 1250 C

37725

250 W RMS

DPU 1500 C

37726

500 W RMS

Power outputs

100 V 100 V 100 V

Distorsion at rated power

< 1%

Input

Double RJ45, In/Out audio/RS485 from

VAC 2006

Frequency response

Low Cut filter

(- 3 dB)

Mains power supply

Power consumption

230 Vac

Power consumption 24

Vdc

80-20.000 Hz

330 Hz

230 Vac ± 10% -

50/60 Hz / 24 Vdc

200 W (240 VA)

4.6 A

< 1%

Double RJ45, In/Out audio/RS485 from

VAC 2006

Double RJ45, In/Out audio/RS485 from

VAC 2006

80-20.000 Hz

330 Hz

230 Vac ± 10% -

50/60 Hz / 24 Vdc

400 W (480 VA)

9 A

< 1%

80-20.000 Hz

330 Hz

230 Vac ± 10% -

50/60 Hz / 24 Vdc

800 W (960 VA)

17 A

19” rack mounting

CHA1004 optional basket unit (H: 3U

+ 1U for support brackets)

CHA1004 optional basket unit (H: 3U

+ 1U for support brackets)

CHA1004 optional basket unit (H: 3U

+ 1U for support brackets)

Installable quantity

for each CHA 1004 4

Dimensions

(WxHxD)

Weight

100x130x395 mm

6 kg

4

100x130x395 mm

9 kg

2

200x130x395 mm

18 kg

Code

Rated output power

@230 VAC

MPA 5240

37489

240 W RMS

MPA 5480

37491

480 W RMS

Power outputs

100-70-50 V, 8 Ω

Distorsion at rated power < 1%

Input

Frequency response

Balanced line input, XLR Balanced line input, XLR

30-20.000 Hz

100-70-50 V, 8 Ω

< 1%

30-20.000 Hz

Mains power supply

230/115 Vac ± 10% - 50/60

Hz / 24 Vdc

230/115 Vac ± 10% - 50/60

Hz / 24 Vdc

Power consumption

230 Vac

Power consumption

24 Vdc

535 W (610 VA)

13.2 A

1160 W (1330 VA)

33 A

19” rack mounting

Dimensions (WxHxD)

Weight

RMK 5000 optional brackets

(H: 2U ) with AC50 lateral support

RMK 5000 optional brackets

(H: 2U ) with AC50 lateral support

432x88x272 mm

10.5 kg

432x88x360 mm

16 kg

Thanks to the great reliability of the protection circuits used, combined with an attractive appearance and the very tough structures, the MPA

range constitutes the ideal product for quality amplification, with a particularly interesting price/performance ratio.

If this amplifier is used in emergency systems, it is possible to disable all the front-panel controls (tone and volume controls). In this way it is possible to avoid any accidental modification of the preset levels

(NORM/DIRECT switch).

11

VAIE 2250

VOICE ALARM INTEGRATED EQUIPMENT

482

On premises where large numbers of people are present it is essential to provide a suitable sound-broadcasting system that, following activation by the firefighting control unit, will handle the emergency situation and enable guided and controlled evacuation of the building.

Current standards define in detail the features of an electroacoustic system for evacuation and emergency purposes in terms of design and installation so that it will meet the applicable safety and reliability requisites.

The VAIE 2250 sound-broadcasting system is FBT’s current answer to the needs specified in standards.

• Complete diagnostic of system fault events

• Control and monitoring of the integrity of the ‘critical path’

(audio signal starting from the capsule of the emergency microphone and/or from the message generator to the loudspeaker line, through the amplification chain)

• Continuous loudspeaker line monitoring (integrity and dispersion to earth) without interruption of BGM or paging calls

• Simultaneous broadcasting of the EVACUATION and ALERT message to different areas

• Supervision of the link with the fire-fighting system

• Back-up power amplifier management (built-in)

• Management of a secondary source of 24 VDC power with a battery-charging unit

It is possible to connect easily (by simple CAT 5 cable) two main VAIE

2250 to create systems of up to 12 zones, for a maximum of 1000 W and connect up to 14 emergency microphone units (thanks to the

FMD 2011 and FMD 2012 console units). Another important aspect is the possibility to manage different input audio sources like microphones, paging units and music source devices.

12

Code

Power supply

Max consumption @ rated output power RMS

Typical consumption with voice signal

Consumption with no signal

(test tone only)

Secondary power supply

Max consumption

@24 Vdc (@28 Vdc)

Typical consumption with voice signal

@24 Vdc (@28 Vdc)

Consumption with no signal

(test tone only)

Operating environmental conditions

VAIE 2250

37484

230 Vca 50/60 Hz

(500 W System) P = 650 W/800 VA

(250 W System) P = 370 W/480 VA

(500 W System) P = 160 W/200 VA

(250 W System) P = 90 W/120 VA

P = 30 W/45 VA

24 VCC (min 22 Vdc ÷ max 28 Vdc)

500 W System = 17 A (21 A)

250 W System = 9 A (11 A)

500 W System = 4,3 A (5 A)

250 W System = 2,2 A (2,5 A)

0,8 A

Mounting

Dimensions (W x H x D)

Weight

Temperature: +5° C to +40° C Relative humidity: 25%-75% non-condensing

Optional AC8506 brackets for mounting in 19” rack (height: 3 U + 1 U support brackets)

439x387x132 mm

20,5 Kg

VAIE 2250

VOICE ALARM INTEGRATED EQUIPMENT

MAIN SYSTEM FEATURES MAIN EMERGENCY FEATURES

• 2-channel broadcast system

• Up to 12 broadcasting zones

• Music volume control for each zone

• 1000 W maximum total power

VAIE 2250 technical features

• Two built-in 250 W RMS class D power amplifiers

• External 250 W amplifier to increase power (MPA 5240)

• Up to 7 remote emergency microphone units (SFTP CAT5 cable)

• Up to 16 paging units, 7 priority levels (SFTP CAT5 cable)

• Balanced microphone input (IN

1) with Phantom power supply and priority contact

• Balanced microphone or line input (IN 2) with Phantom power supply (MIC), priority contact or automatic precedence (VOX)

• Balanced line input (IN 3) with automatic precedence (VOX)

• Auxiliary line input for an external music source

• USB input for background music source

• 6 open collector outputs

(system status or override to by-pass attenuators)

• 8 programmable and controlled input contacts

• 2 relay outputs for ‘emergency’ and ‘failure’ conditions

• Built-in loudspeaker for channel monitoring and acoustic failure signalling (beep)

• Easy and simple confi guration

(large LCD display)

• Emergency zone disabling and

Do Not Disturb functions (DND)

• Frontal Fireman’s microphone

• Remote emergency microphones units

• Control and monitoring of the integrity of the critical path

(from the emergency signal sources to the loudspeaker lines)

• Continuous loudspeaker line monitoring without interruption of BGM or paging calls

• Two output loudspeaker lines for each zone (A & B)

• Built-in message generator unit alarms

• Back-up power amplifi er management (built-in unit)

• Complete diagnostic of system fault events

VAIE 2250 Voice Alarm

Integrated Equipment

The Fireman Microphone Desktop

FMD 2012 and FMD 2001 are fully diagnosed, and allow greater operational and management fl exibility for any service and/ or emergency calls and/or prerecorded messages on the zones of the system.

The LEDs on the front panel provide the main information on the status of the emergency system and on any failures. The

FMD 2001 Fireman station enables a single All-Call to be made; if the alarm messages have to be sent to separate zones, it will be necessary to use the FMD 2012

Fireman station, which enables a maximum of 12 zones to be selected.

Each station must be completed with an additional microphone to be chosen from among the following models: FMG 2000

(dynamic gooseneck microphone) or FMH 2000 (dynamic hand-held microphone with P.T.T. key)

SOLUTION WITH A MIXED

CONFIGURATION

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

MBT 1106

MBT 1112

(up to 16)

FMD 2001

FMD 2012

(up to 7)

I/O CONTACTS

FIRE UNIT

VAIE 2250 n.1

MICROPHONE

VAIE 2250

VOICE ALARM INTEGRATED EQUIPMENT

ALRM FAULT DIS. SYS. BATT. ON

EMERGENCY

RESET

ALRT

EVAC.

1 2 3 4 5 6

MENU

OK

ESC

TO PC

EXT.

REMOTE LINK

CAT5 SFTP

LINE A

LINE B

LINE A

LINE B

Z.1

Z.6

24VDC OUT

TO ALL

SECONDARY PSU IN

VAIE 2250 n.2

MICROPHONE

VAIE 2250

VOICE ALARM INTEGRATED EQUIPMENT

ALRM FAULT DIS. SYS. BATT. ON

EMERGENCY

RESET

ALRT

EVAC.

1 2 3 4 5 6

MENU

OK

ESC

TO PC

EXT.

LINE A

LINE B

LINE A

LINE B

Z.7

Z.12

MPA 5240

EN 54-16 BOOSTER (OPTIONAL)

SON 24V 6A MS40

BATTERY CHARGER

MPA 5240

EN 54-16 BOOSTER (OPTIONAL)

SON24V 6A MS40

Battery Charger

Code 37751

The battery charger SON24V 6A MS40 (24 Vdc) is intended for a Voice

Evacuation System. The battery chargers are microprocessor based devices that have been designed to charge lead-acid batteries

(backup batteries connected to the Voice Evacuation System) and, simultaneously, to provide power to auxiliary applications.

The battery charger, which is fully compliant with EN54-4 (certificate n. 0333-CPD-075382), offers a maximum charge current of 6 A.

It is two rack units (2 U) high, and has to be installed in a 19” rack.

13

FMd 2001

EN 54 - 16

FMd 2012

EMERGENCY PAGING UNITS

EN 54 - 16

• Fully diagnosed

• Emergency key

• Live emergency calls

• Sending of pre-recorded Evacuation/Alert messages

• Broadcast calls

• Zone-selection keys with status-LEDs (FMD 2012 only)

• Faults/Failures LEDs

• AUX function to call pre-set messages

• Reset of emergency messages

• Muting of the buzzer for failure detection (ACK)

The remote consoles FMd 2012 and FMd 2001 are fully diagnosed, and allow greater operational and management flexibility for any service and/or emergency calls and/or prerecorded messages on the zones of the system. The LEDs on the front panel provide the main information on the status of the emergency system and on any failures.

The FMd 2001 station enables a single All-Call to be made; if the alarm messages have to be sent to separate zones, on the other hand, it will be necessary to use the FMd 2012 station, which enables a maximum of 12 zones to be selected.

Each station must be completed with an additional microphone to be chosen from among the following models:

FMg 2000 Dynamic gooseneck microphone

FMH 2000 Dynamic hand-held microphone with P.T.T. key

According to the used system units, it is possible to set-up the

PTT and AUX keys and, only for the FMd 2012, each of the 12 selection keys in order to enable selection of groups of zones (keys

1 to 12 and the PTT key) or to create a specific combination of messages for the different zones

(AUX key).

It is possible to connect up to 7 remote station units in cascade formation by means of the IN/OUT sockets provided for this purpose, which can be used as inputs or outputs as required. The connections to the units are made by means of CAT5e SF/UTP shielded cable and a shielded STP connector.

14

200

200

FMg 2000 EN 54 - 16

FMH 2000

EN 54 - 16

MBt dynamic gooseneck microphone

Code 37488 dynamic hand-held microphone

Code 37487

Broadcasting paging units

Standard paging units can be used in the

Voice Evacuation Systems.

Code n° of zone selectable typical output level

Frequency response distortion

LOW Cut filter

S/n ratio

Connections

Power supply voltage

-

FMd 2001

37485

300 mV

130 ÷ 19.000 Hz

< 1%

-3 dB / 380 Hz

> 60 dB

RJ45 (IN/OUT)

24 Vdc

Maximum absorption

@24Vdc

60 mA

dimensions (W x H x d)

140 x 80 x 200 mm

net weight

0,77 kg

FMd 2012

37486

12

300 mV

130 ÷ 19.000 Hz

< 1%

-3 dB / 380 Hz

> 60 dB

RJ45 (IN/OUT)

24 Vdc

130 mA

230 x 80 x 200 m

1,55 Kg

MAD 4IP

HIGH QUALITY

AUDIO

15

16

Have you ever wondered if it could be possible to control music as well as lights, blinds, security system and even temperature from across the room?

And what do you think about possibility to get full control from across the globe?

The future is now: you can start with a simple touch!

FBT Elettronica with Audio Contractor Division takes a big step forward, introducing a brand new system, designed to provide comfort as well as more convenience than you ever thought possible.

Customized to fit the specific lifestyle, these solutions range from Multi-Room Music System to full whole Building Automation. If you’re moving around your room or around the globe, the system is just as easy to use as you can get a complete control of everything in your hands.

MAD 4IP - Multimedia Automation Distribution over IP Networks

MMU4000 CUW4000 CUD4000 EAC4000

MAD 4IP will catalog your entire collection and you can add music to every room with the touch of your finger: you can play the same song in every room or different songs in different rooms, the choice is yours.

MAD 4IP will give you instant access to the world of music, no matter where it comes from: MP3 or Tuner or Internet Radio from your computer or your MP3 player or your SD card or your USB memory key.

Multi-Room Multi-Source application - combination of streaming of Digital Music with

Building Automation

For instance lighting and music control can be integrated in scenes, which can be selected at the push of a button from anywhere in the building. Audio streams are transmitted over

IP networks or wireless networks, from a main server to music players and in turn controlled with a web based visualization. Thanks to the Graphical User Interfaces in a web page, you can control all room functions completely intuitively with a touch screen: lighting scenario, automatic lowering of blinds, music in every room, door communication, heating, ventilation and air-conditioning systems and even irrigation.

With a customized control of the building it’s possible an intelligent management of all these functions, assuring time and energy saving.

Your smartphone or tablet will be converted into your universal remote control.

17

18

MMU4000

Multimedia MASTER UNIT cod. 34553

• Reduced dimensions

(WxHxD) 360 x 88 x 216 mm

• 1 serial interfaces RS 232

• 6 usb 2.0 ports

• Ethernet

• Temperature Range 0-50 0

• Power supply 230V

• Consumption 45W

• Stand alone or rack mounting with included brackets

• Automatic start up in case of power failure

• 2 Audio line-in

• 2 audio Mic/line in with gain, and tone control

(Low and High)

• 48V phantom for microphone input with switch)

MMU4000 is the Multimedia Master Unit, a complete Multi-Room Music System, integrating music/video source components and user interfaces, providing you with one-touch entertainment throughout the building.

MMU4000 is the simple, economic solution for distributing music and video in streaming.

It’s a totally modular system, configurable via software, versatile and easy to use.

MMU4000 is a compact, independent unit that reproduces and manages audio files in the most popular formats Mp3 and WAV from hard disk

–all in streaming on standard IP network, using the RTP protocol, Real Time Protocol, controlled by a web based supervision software, from touch-screens or from management devices distributed over the various areas.

MMU4000 can be integrated into the building automation installation to offer high quality music in any room. It can be upgraded with

3 different software license, adding also the complete integration of Music streaming with

Building Automation System.

OPTIONAL SOFTWARE LICENSE for

MMU4000

BAL (Building Automation Light)

With this software license option, the Multi-

Room Music System is combined with a

Building Automation System, with a standard web Interface, 2 simultaneous users, 2 selectable skins, 2 scenarios, 8 control points with MODBUS protocol, 2 configurable environments.

BA1 (Building Automation 1 Driver)

With this software license the Multi-Room Music

System is combined with a Building Automation

System, with a standard web Interface, 1 driver included and chosen among several protocols,

150 control points.

BA3 (Building Automation 3 Driver)

With this software license the Multi-Room Music

System is combined with a Building Automation

System, with a standard web Interface, 3 drivers included and chosen among several protocols, 300 control points, 3 simultaneous users, no limit to configurable environments and elements for environment, IP security cameras visualization, selectable skins.

CUW4000

Control Unit wall mounted cod. 34555

EAC4000

Ethernet Audio Card

Cod. 34556

CUW4000 Control Unit is a fully configurable,

7” touch panel featuring a contemporary, thin elegant design that complements the aesthetics of any environment. The CUW4000 has a

800x480 resolution and incorporates 48VPoE -

Power over Ethernet, allowing the touch panel to receive its power via the Ethernet connector.

CUW4000 can receive audio input signals over standard CAT 5 cable. It’s equipped also with an additional jack input for external players and with an USB port for an external USB key for MP3 file local reproduction This enhanced connectivity provides integration flexibility

One or more touch panels can be installed, depending on your own needs or to make the management of the building automation system available from different areas.

EAC4000 is the complete audio Ethernet card.

It’s used to stream the audio signals into the IP network, to be used when it’s not necessary a display, because it’s used a PC or a smartphone.

It has the same features of CUW4000, without

LCD display.

• Dimensions:

225 x 105 x 30 mm

• Power Supply : 3W

OPTIONAL:

• External Power Supply 12V 1A for CUW4000,

CUD4000 and EAC4000, when PoE is not available.

CUD4000

Control Unit Desktop

Cod. 34554

It’s equipped with:

• 1 USB for pen drive

• 1 Lan port (with 48V POE)

• 1 Stereo lIne-in

• 2 balanced audio out

• Power supply connector : 12V

• Power : 6.5W on and 3W standby

FEATURES

• 7-inch color LCD touch panel Full-color video monitor/in-wall

• 16:9 aspect ratio Controls

• Non-volatile flash memory

Connections

• System Port (RJ-45)

• Wiring Requirements Cat-5 (data),

• Display 7” Diagonal, 16:9 Color TFT LCD

Resolution 800 (W) x 480 (H)

• Frame Dimensions (WxHxD) 280 x 175 x 6 mm

• Cutout Dimensions Approx. 265 x 170 x 72mm

CUD 4000 has the same features of CUW

4000 but sits on a tabletop and it’s equipped with a gooseneck microphone for paging announcements.

• Dimensions: 320x 172 x 57 mm

19

MMU4000 Rear Panel:

• 1 serial interfaces RS 232

• 4 USB 2.0 ports + 2 USB 2.0 ports on front

• Ethernet port

• 2 Audio line-in

• 2 audio Mic/line in with gain and tone control

• 48V phantom for microphone input

20

smartphone tablet CUW4000 CUD4000 EAC4000 PC

MMU4000 audio lighting shutter/blind heating ventilation

KEY FEATURES:

• Web based application : you can use any device with an Internet Browser on board, so you can get full control from your PC, as well as from any smartphone or any tablet PC, that could be converted into your universal remote control. No need to install any software or to download any applet, with no compromise features and with reaction to commands in real time.

• Independent from BUS: you can have

3 different drivers selectable among the following: KNX, Modbus TCP, Modbus RTU,

IP Camera and many others

• 3 simultaneous web user

• Unlimited number of scenarios

• Simultaneous management of 300 control points

• Selectable graphic skins

• MAD4IP MAP management of the entire building automation system through images of the ambient: it’ll be possible to have layout or images of the rooms and to manage the controls through icons, directly in the visualized ambient. With this module MAD4IP

MAP it will be possible also to look at IP camera video, in real time, keeping under control the security of all the environments.

ConferenCe SyStemS and interCom SyStemS

Sound Design Project for Council Chamber - Potenza

21

FBt AC CS 1Cu

CONTROL UNIT

FBt AC CS 1du FBt AC CS 1CH

MICROPHONE CONSOLES

The innovative design makes the

CS series more than just another conference system. With its ECM capsule, intelligent automatic mixing technology and integrated acoustic and mechanical system, the conference system provides turnkey solution with natural, feedback-free audio performance whatever the environment. This conference system is ideal for conferences up to 150 attendees.

The system is composed of 1 central unit and up to a maximum of 150 chairman or delegate console.

Control unit

Code 27510

• Controls the chairman and delegate microphones as well as the connections to other audio inputs and outputs

• Self-powered

delegate microphone base

Code 27512

Provides the facility for the user to take part in the conference via the gooseneck microphone, a PTT

ON/OFF switch is provided as is an internal loudspeaker and an external earphone socket

• Flexible condenser microphone

• Diameter without microphone

170x115x90mm

• Microphone length 400mm

• Net weight 1100g

Chairman microphone base

Code 27511

It has the same features of the CS

DU model, but with the following difference:

• A priority switch allowing the chairman to control the conference by muting temporarily or completely clearing all active delegate microphone units

CS1-CH CS1-Cu

FBt AC d7P

Cables

Model Code dimensions

FBt AC d7P-10 37648 10 mt

FBt AC d7P-20 37649 20 mt

FBt AC d7PdH-1 37650

Voltage

dC supply to contribution units

Input sensitivity

COnFEREnCE SyStEM CS SERIES

Vac 100 ~ 264, 50/60Hz

±15V ±1V

Line, telephone and Insertion-unbalanced

-14dBV/+11dBV (nominal/maximum)

Input impedance 33Kohm

Output level 14dBV/+11dBV (nominal/maximum)

Output impedance 500ohm

Input sensitivity

Input impedance

Adjustment

Output level tape Recorder-unbalanced

-20dBV/+5dBV (nominal/maximum)

47Kohm (for L & R channel)

-20dBV/+5dbBV

+0/-30dB

Output impedance

Input sensitivity

Adjustment

Power supply Phantom

Output level

Allowed Impedance type

Frequency Response

Polar Pattern

Max. SPL for 1% tHd gooseneck Length dimensions (WxHxd) dimensions

Weight

500ohm

External Microphone input-balanced

-56dBV

+6dBV/-6dB

12V±1V, 2*680ohm (±2%)

Headphone Output

-8dBV/+2dBV

22ohm

gooseneck Microphone

Back Electret Condenser

50 ÷ 18000Hz

Cardioid

125dB

400mm (15”)

CS-1Cu

300x89x150mm 115x60x173mm

-

CS-1CH e CS-1du

400mm (15”)

1745gr 1100gr

300

173

115

FBt AC EXM-1

EXPANSION KIT

FBt AC EXS-1

FBT AC expansion kit, combined with D7PDM-1 extension cables, can expand the number of using units of conference discussion system from 50 to 150 by adding maximum two additional FBTAC

CS-1CU functioning as power supply units only. The system is controlled by the master FBTAC

CS-1CU unit.

Using D7P-10 or D7P-20 extension cables to extend the operation distance.

Code

Input

Output dimension

FBt AC EXM -1

37646

7-pin DIN Connector

7-pin DIN Connector

115x65x38mm

FBt AC EXS-1

37647

23

IntERCOM 1300

MICROPHONE INTERCOM SYSTEM

Installed in different rooms the intercom system allows users to speak and listen at each end without having to press any buttons. The kit is composed of three separate modules: control station, power supply, and loudspeaker unit with integral microphone.

The devices function in halfduplex (one-at-a-time) mode and activation thresholds are modified automatically in relation to environmental background noise levels. The operator station can enable one-way operation, i.e. exclusively automatic listening, with speak facility at the press of a button.

Intercom 1300 composed of:

SIBK 013 control station,

AASL 012 power supply,

SICK 012 loudspeakermicrophone enclosure with connection cable

Optional:

SICK 013 supplementary loudspeaker for operator station

• headset with microphone

for operator station

24

IntERCOM 1300

Code 18083

Power supply

220 Vac, 50 Hz

Power input 16VA

Power input 1W

External loudspeaker impedance 8ohm

Bases dimensions 220x157x55mm

Flex cable and microphone length 358mm

External loudspeaker dimensions 110x64x54mm (bracket excluded)

MICROPHONES

MICROPHONE baSES

WIRELESS MICROPHONES

Camera di Commercio di Montelupone

25

Md-S 1100 Md-S 1300

HAND-HELD MICROPHONES

Md-F 5044

GOOSENECK MICROPHONES SKLKLAKMSK

dynamic microphones cardioid

• ON-OFF switch

• Male XLR connector

• Anthracite grey body

• Black mesh and antipop filter

• High performance

• High-quality voice reproduction

• Low distortion

• High resistance to knocks

• Special cartridge suspension mount to isolate the microphone from handling noise

• Ideally suited for speech

applications dynamic microphones percardioid

• ON-OFF switch

• Male XLR connector

• Anthracite grey body

• Black mesh and antipop filter

• High performance

• High-quality voice reproduction

• Low distortion

• High resistance to knocks

• Special cartridge suspension mount to isolate the microphone from handling noise

• Ideally suited for singing applications dynamic microphones cardioid with gooseneck

• Male XLR connector

• Low reflectivity black finish

• Outstanding directional characteristics

• Ideal for:

- hotels

- shopping centres

- churches

- conferences

- offices

Electret microphone with gooseneck

• Male XLR connector

• Low reflectivity black finish

• Outstanding directional characteristics

• Ideal for:

- auditoriums

- shopping centres

- conference halls

54 54

Code

Characteristics

directivity

Frequency Response

Md-S 1100

10040

Md-S 1300

10042

Dynamic Dynamic

Cardioid Hiper-Cardioid

80Hz÷13 kHz 50Hz÷18 kHz

Sensitivity (OdB-1V/micro bar,1000 Hz) -75dB±3dB

Output impedance

-72dB±3dB

500ohm 250ohm

Material

Weight

dimensions

Accessories included

Microphone cables (optional)

Zamak Zamak

220 g

ø 54x175mm

Stand SU30

CI-M 5 X

CI-M 5 d

CI-M 5 J

359 g

ø 54x187mm

Stand SU30

CI-M 5 X

CI-M 5 d

CI-M 5 J

29 19

Code

Characteristics

directivity

Frequency Response

Output impedance

Power supply

Weight

dimensions

Accessories included

Md-F 5044

10045

MC-F 5042

10044

Dynamic Electrete

Cardioid Cardioid

80Hz÷16 kHz

Sensitivity (OdB-1V/micro bar,1000 Hz) -68dB±3dB

500ohm 250ohm

-

215 g

ø 29x438mm

Stand SU30

80Hz÷16 kHz

-68dB±3dB

Phantom 9:52 Vdc

135 g

ø 19x424mm

Stand SU30

Md-F 5045 S

GOOSENECK MICROPHONES SKLKLAKMSK

dynamic microphones cardioid with gooseneck

• Push-to lock switch

• Male XLR connector

• Low reflectivity black finish

• Outstanding directional characteristics

• Ideal for:

- hotels

- shopping centres

- churches

- offices

dynamic microphones cardioid with gooseneck

• Same characteristics as the

MD-F 5045 S with push-to-talk switch

• Code: 15294

MS 30 BK

Floor stand

Code 18245

Adjustable floor stand

ASg 230

Boom arm

Code 11864

Boom arm for MS 30 BK microphone stand

tB 30 BK

table microphone stand

29

Code

Characteristics

Md-F 5045 S

10046

Dynamic microphone

Md-F 5045 SI

15294

Dynamic microphone

Material

directivity

Frequency Response

Sensitivity with push-to lock switch with push-to-talk switch

-

Cardioid

100Hz÷12 kHz

-

Cardioid

100Hz÷12 kHz

-77±3dB -77±3dB

(OdB-1V/micro bar, 1000 Hz) (OdB-1V/micro bar, 1000 Hz)

Output impedance 500ohm 500ohm

Weight 315 g 315 g

dimensions ø 29x440mm ø 29x440mm

Code 18248

Adjustable table microphone stand

Su 30

universal clamp-on

Code 11586

Universal hand-help microphone clamp-on

CM 601

CONDENSER MICROPHONE

Low profile panoramic microphone, electret condenser

• On/off switch,

• The switch can be programmed for the push on/off, push/ to talk, push/to mute functions

• LED indicator

• Three-position low cut switch,

minimizing mechanical noise

• 3 pin Mini XLR-M output connector

• 36-52 VDC Phantom Power, 88 g net weight

• Specially suitable for conference tables, altars and stage floors

FBtAC gM 5206 L - 5212 L - 5218 L

CONDENSER MICROPHONE

Condenser microphone

• XLR connector

72

CM 601

Code 27516

Characteristics Electrete Condenser

directivity Half-Cardioid

30Hz÷12.000 Hz Frequency Response

Sensitivity (OdB-1V/micro bar,1000 Hz) -53dB±3dB

Low Frequency Roll-off 80Hz, 120Hz

Output impedance 100ohm

Max SPL

125dB at 1kHz

Signal to noise ratio 67dB

Phantom 36÷52 Vdc Power supply

Power consumption

Switches

≤6mA

Push control: on/off

Function selection: push on/off, momentary on, momentary off

Output connector

Low cut: low frequency roll-off

3P Mini XRL-M type

Weight

88 g

dimensions 72x110mm

Code

Characteristics directivity

FBtAC gM 5206L

27515

Electrete Condenser

Super Cardioid

Frequency Resp.

80Hz÷18.000 Hz

Sensitivity

(1000 Hz) -60dB (1mV)

FBtAC gM 5212L FBtAC gM 5218L

27514 27513

Output impedance 220ohm

Max SPL

125dB

oer 1% tHd

Phantom Power 36-52Vdc

Output connector XLR

dimensions

FBTAC GM5206L 152mm (6”)

FBTAC GM5212L 305mm (12”)

FBTAC GM5218L 457mm (18”)

FBtAC St 5050

MICROPHONE BASES

universal microphone base

• Both phantom power and 9V battery power supply

• On/off switch with possible push/ to talk, push/to mute

FBtAC St 850

MICROPHONE BASES

Microphone base

It is automatically set to be wired or wireless, adding the transmitter and receiver

• On/off switch

• The base operates with power transmitters and it is compatible with FBTAC-PT-850B transmitters

• Where wireless transmitters not available, it will be enough to connect ST850 to a microphone cable with Phantom power supply: it will function as a standard flexible microphone

100 150

FBtAC St 5050

Code 27499

Frequency response

Stand-By power consumption

Operating power consumption

Switches

20Hz÷20.000 Hz

1mA

2.07mA (BAL), 1.34mA (UNBAL)

Microphone selection: ECM MIC unbalanced input, ECM MIC

Connectors

Weight

dimensions

balanced input, Dynamic MIC input

Unbalanced and balanced audio input (XRL 3P Female)

Unbalanced and balaced audio output (XRL 3P Male)

0,82 Kg

100x155mm

FBtAC St 850

Code 27500

Features

Frequency response

directivity

Output level (at 1,000 Hz)

Back Electret Condenser

50Hz÷18.000 Hz

Supercadioid

Wireless -66±3dB (1.58mV) 0dB=1V/bar

Wired -56±3dB (1.58mV) 0dB=1V/μ bar

Impedance Wireless 2kΩ Wired 100Ω

Max SPL for 1% tHd 125dB

Power supply Wireless 5VDC

Wired 12-48 VDC phantom power

Power consumption Wireless

Output connector Wireless 4P <mini XRL Wired 3P XRL (M)

Switches Push control on/of

Cable lenght 305mm

Weight

dimensions (WxHxd)

1 kg

100x65x150mm

MB-t 6400 S

DESK MICROPHONE BASE

desk base with On/OFF switch, flexible gooseneck with cardioid dynamic microphone

• 5 metre cable with male XLR connector and 2 conductors for priority activation (ding-dong)

BF-t 5043 L

MICROPHONE BASES WITH GOOSENECK AND SWITCH

desktop base with On-OFF switch, gooseneck and cardioid electret condenser microphone

• Complete with a 5-metre cable fitted with a male XLR connector and 2 wires for the activation of the chime

priority

• Die-cast zinc base

• Lamp ring

• Touch-switch

• Ideal for all applications, especially for

- churches

- conference halls

MB-t 6400 S

Code 28840

Features Dynamic

directivity Cardioid

Frequency response

100Hz÷12 kHz

Sensitivity (OdB-1V/micro bar,1000 Hz) -75dB±3dB

Output impedance 500ohm

Material Zamak

Weight 1750 g

dimensions (WxHxd) 160x98x45mm

160 145

BF-t 5043 L

Code 18322

Features Electrete

directivity Cardioid

Frequency response

70Hz÷18 kHz

Sensitivity (OdB-1V/micro bar,1000 Hz) -59dB±3dB

Output impedance 250ohm

Power supply Phantom 12÷48 Vdc

Material Zamak

Weight 786 g

dimensions (WxHxd) 145x100x36mm

150 150

MB-t 8001 MB-t 8004

DESKTOP BASES

MB-t 8008

the microphone bases in the

MB-t 8000 series feature a plastic body with a metal base. These products stand out for their high sensitivity and wide frequency response and the microphones feature a cardioid polar curve.

The bases are equipped with a functional 3-position switch, ON push-to-lock, OFF and push-to talk ON as well as an emergency button.

• Pre-amplified (output 0dBu)

• Dynamics compressor to ensure optimal level of clarity

• Internal message generator to indicate the start and end of microphone messages and for an emergency signal.

• Option to control priority (music off)

• Management of 4 or 8 zones independently, depending on the model, and general calls

• For the management of a larger number of zones, upon request

150

MB-T 8004

MB-T 8001 MB-T 8008

AL 8000

Power Supply

Code 17074

Power Supply +15/-15V for pre amplified microphone bases of MB-T8000 series

StH 022

Multipair Shielded cable

Model Code dimensions

StH 02-022 13360

2x2x0,22

StH 05-022 13103

5x2x0,22

StH 09-022 13104

9x2x0,22

Code

Features

MB-t 8001

Base with switch, emergency button

MB-t 8004

19543 11828 12122

Base with switch,

4-zone selection,

MB-t 8008

Base with switch,

8-zone selection, emergency button emergency button

Microphone Electret Electret Electret

Polar curve Cardioid Cardioid Cardioid

Frequency response 70Hz ÷ 18KHz 70Hz ÷ 18KHz 70Hz ÷ 18KHz

Sensitivity -63dB± 3dB -63dB± 3dB -63dB± 3dB

Output impedance 600ohm 600ohm 600ohm

gooseneck L=370mm ø 9mm L=370mm ø 9mm L=370mm ø 9mm

Warning/emergency CHIME:2Tones CHIME:2Tones CHIME:2Tones

signals

Output voltage

Power supply

Material

Accessories included

Optional accessories

CHIME:4Tones Emergency CHIME:4Tones Emergency CHIME:4Tones Emergency

0dBu (0,775Vrms) balanced 0dBu (0,775Vrms) balanced 0dBu (0,775Vrms balanced)

±15Vdc/80mA ±15Vdc/80mA ±15Vdc/100mA

Plastic with steel base

Antipop filter

Multipair

Shielded cable 5x2x0.22

Plastic with steel base

Antipop filter

Multipair

Shielded cable 5x2x0.22

Plastic with steel base

Antipop filter

Multipair

Shielded cable 9x2x0.22

StH05-022 StH05-022 StH09-022

31

MBt 1101

PRE-AMPLIFIED BASES

MBt 1106 MBt 1112

BROADCASTING PAGING UNITS

MBt 1112E

ABS structure with electret microphone and stem with a flexible section at the bottom.

Equipped with one hold-down

(PTT) call key, one toggle (LOCK) call key for long messages and a LED signaling activation of the microphone. The bases can be mixed with one another or interlocked with two priority levels. The level of the microphone signal and that of the alerting signal (chime generator included) are adjustable from the rear.

Standard paging units can be used in the Voice Evacuation Systems.

The units are connected to one another in cascade formation, and the connecting cables (CAT5e

SF/UTP) carry both the analogue audio signal and the digital signal for the controls and station addresses. MBt 1106 call station can make selective calls to up to a maximum number of 6 zones and the MBt 1112 up to 12.

The MBt 1106E extension module enables 12 programmable shortcut keys for one or more functions to be added. It is possible to connect up to two expansion modules to the MBT 1112.

MBT 1101 microphone stations can be used simply and rapidly with the amplifiers of the MPA

5000, MXA 1000, MXA 3000 and

MDS 6000 range.

It is essential to use CAT5e SF/UTP shielded cables (IN input UNITS), and it is possible to connect up to

6 microphone stations in cascade fashion. The output level can be adjusted by means of the appropriate rear-panel control

(LEV).

200 200 200

CV 2010

Cable

Code 35541

32

Code type n° of selectable zones

Power supply

Absorption @ 12 Vdc

Absorption @ 24 Vdc

Frequency response

Speech filter @100 Hz

Audio output level

Audio level adjustable

Warning signal level

(chime) adjustable dynamic limiter dimensions

Weight

MBt 1101

37739

Electret

-

12 Vcc / 24 Vcc

40 mA

50 mA

-

100 ÷ 15.000 Hz

-

1,2 Vrms (balanced)

0,8 Vpp yes

116x60x200 mm

0,82 Kg

MBt 1106

37492

Electret

6

18 Vcc / 36 Vcc

-

16 mA

100 ÷ 14.000 Hz

-10dB

-

2,2 Vmax

yes

116x60x200 mm

0,58 Kg

MBt 1112

37493

Electret

12

18 Vcc / 36 Vcc

-

22 mA

100 ÷ 14.000 Hz

-10dB

-

2,2 Vmax

yes

116x60x200 mm

0,60 Kg

-

-

-

MBt 1112E

37494

-

12

-

-

-

20 mA

-

-

116x60x200 mm

0,50 Kg

40 130

WM 505/...

WM 705 A/L

Wireless microphones

Design philosophy and technology aimed at guaranteeing optimal quality and reliability with high level performance. Receiver with SWITCHING DIVERSITY technology, to ensure signal selection at all times at the radio frequency with the best intensity, thereby ensuring top quality and reproduction stability in sound amplification systems.

30 130

LM - 10

HM - 26

AVL 606

Lavalier microphones code 13544

lavalier microphones have electrical and mechanical characteristics to guarantee reproduction of clear and intelligible speech for the entire system. The compact dimensions and weight ensure use in all cases where the utmost freedom of movement is indispensable.

Headset microphones code 13543

headset microphones have electrical and mechanical characteristics to guarantee reproduction of clear and intelligible speech for the entire system. The compact dimensions and weight ensure use in all cases where the utmost freedom of movement is indispensable.

Microphone code 14142

As well as the characteristics of the other two models, this microphone features special sweatproof protection to enable use in all applications subject to high levels of humidity or perspiration. (Typical applications include gymnasiums, swimming pools, camp sites etc.).

WM 505/...

code 11573 175 mhz

WM 705 A/L

14827 181 mhz

11574 214 mhz 14828 203 mhz

14922 204 mhz

14923 212 mhz

14924 203 mhz hand-held Transmitter type

Audio band

Microphone type Dynamic electrect

Directivity cardioid cardioid

power rF

power supply

50 hz-15 Khz

10mW 5mW

1,5V (AA, e91, lr6,

Am3 Alkaline) lavalier and headset

50 hz-15 Khz

3V (2 x AAA, Alkaline)

Absorption 60mA 25mA

Duration Tipico 12 ore Tipico 12 ore

Weight

operation

210 g sW Diversity

100 g sW

Quartz-controlled Quartz-controlled

Antenna 2 2

power supply

12/18V external

12 V dc/300 m A with power supplier

squelch

Audio output

Weight

Adjustable Adjustable

0:300mV

0,9 Kg

12V dc/300 m A 0:300mV

0,9 Kg

33

FBTAc Us 8001D FBTAc Mh 750 FBTAc Us 902D

Wireless microphones UHF

FBTAc Mh 920

UHF pLL true diversity receiver

• Suitable for 1 transmitter (FBTAC

Mh 750, FBTAC Mh 920, FBTAC

PT 850 B)

• Preset with 16 selectable UHF channels (782MHz-806MHz)

• Diversity technology preventing from signal losses in RF links

• Noise Mute e and pilot tone squelch circuit to avoid interferences

• Balanced and unbalanced XLR outputs

• 1/2 U rack metal chassis

Microphone with UHF pLL transmitter code 27494

• 16 selectable channels

• Frequency band: 782MHz -

806MHz

• Advanced circuits guaranteeing stable transmission signals

• Squelch tone-key

• Wide dynamic range and flat frequency response

• Internal antenna, lightweight hard plastic case

UHF pLL true diversity receiver

• Preset with 16 selectable UHF channels (782MHz-806MHz)

• Suitable for 2 transmitters

(FBTAC Mh 750, FBTAC Mh 920,

FBTAC PT 850 B)

• Diversity technology preventing from signal losses in RF links

• Noise Mute e and pilot tone squelch circuit to avoid interferences

• LCD Display

• Balanced and unbalanced outputs

• 1 U rack metal chassis

Microphone with UHF pLL transmitter code 27496

16 selectable channels

• Frequency band: 782MHz -

806MHz

• Advanced circuits guaranteeing stable transmission signals

• Wide dynamic range and flat frequency response

• Advanced circuits and squelch key avoiding interferences

• Internal antenna

• Suitable for condenser or dynamic cartridge

• LOCK-ON function to avoid accidental interruptions

34

FBTAC Mh 750 FBTAC US 8001D FBTAC Mh 902 FBTAC US 902D

FBTAc pT 850B

FBTAc cM 501

FBTAc cX 504

Body pack transmitter code 27495

• 16 selectable channels

• Frequency band: 782MHz -806MHz

• AA battery supply

• Featuring 4P mini XLR connector

• Hard and solid plastic case

• Compatible with lavalier and boom microphones

• LED display, designed for waist carrying

Lavalier microphone code 27497

lavalier unidirectional cardioid condenser microphone

4P mini XLR connection, frequency response 100-15,000Hz;

Sensitivity (at 1,000Hz): -60±3 dB* (1mV)*0dB=1V/µbar, 1kz;

Impedance 2.2Kohm; wide dynamic range and excellent frequency response; small size for low visibility; including the clip for easy hanging on ties, suits, lapels. net weight: 21.5 gr.

cardioid microphone code 27498

Cardioid condenser boom microphone; perfect for voice. 4P mini XLR connection, frequency response

30-18,000Hz; Sensitivity (at 1,000Hz): -68±3 dB*

(0.4mV)*0dB=1V/µbar, 1kz; impedance 680Kohm; excellent pre-feedback gain and noise insulation; light weight enabling free movement; ergonomic design guaranteeing wearing comfort; net weight: 56.3 gr.

code

FBTAc Us 8001 D

27493

FBTAc Us 902 D

27492

rF FreQUencY range 782mhz-806mhz 782mhz-806mhz

oscillation Type

pll pll

16 16

channel

Frequency response

Bandwidth operating range receiver mode signal/noise ratio sensitivity rF

Display controls

50hz-18khz 50hz-18khz

24mhz 24mhz

100 m 100 m

Diversity Diversity

>100dB >100dB

-107dBm (12dB s/n AD) leD on/off, volume, channel Up/Down

-107dBm (12dB s/n AD) lcD on/off, volume, channel Up/Down ,

Audio output Level

Squelch level

-12dB -12dB

AF output impedance

600ohm unbalanced 2,2Kohm unbalanced pilot tone and noise mute pilot tone and noise mute

squelch operating voltage outputs

12-18VDc, 600mA

1 balanced XLR and

12-18VDc, 600mA

2 balanced XLR and

1 unbalanced Jack 6,3mm 1unbalanced Jack 6,3mm

Dimensions (WxHxD)

221x40x152mm 480x45x232mm

FBTAc Mh 750 FBTAc Mh 920 code 27494 27496

Frequency Deviation

+/-48Khz

s/n

>100dB (1khz - A)

+/-48Khz

>100dB (1khz - A)

100mA

current consumption

100mA

LcD / LeD indicators power on/off power

Battery level

Batteries

2xAA 1,5V on/off power

Battery level

2xAA 1,5V

preAMpLiFier eQUipMenT conTroL UniTs AnD

MiXers poWer AMpLiFiers rAcKs

MUsic soUrces

AMpLiFicATion eQUipMenT

Sound Design Project for World Trade Center

(Zaragoza)

420

FBT Ac MX-8

AUTOMATIC MICROPHONE MIXER

The microphone automatic mixers provide great convenience to sound reinforcement installation with any size and any combination. full feature design includes

• Daisy-chain with unlimited number of the mixer

• Three operation modes: onechannel-at-a-time, all active or override

• Switchable output levels between mic. and line level

• Individual gain control and phantom power for each channel

• Last in stays on for continuous ambience sound

• Control voltage provided to trigger external device such as a speaker switching and camera switching

The outstanding performance enables effective managing of multi-microphone installation including corporate boardrooms, conference rooms, government builds, houses of wokship, classrooms

36

D8p-1 extension cable code 37936

• Din 8 Pin Male/Male Cable

• Lenght 0,8 m

code

Type

Mic

Line output

Type

Mic

Line

MAX output Level

MAX Gain

Frequency respond

THD% signal-to-noise radio input Attenuation phantom power

Mic in Attenuation

Mic Attenuation output Attenuation

Voltage output power supply power consumption

Fuse

Weight

Dimensions

FBT Ac MX-8

37645

XLR

4.7Kohm

20Kohm

XLR

300ohm

200ohm

>17dB

>70dB

35~20,000 hz

<0.06%

>70 dB

-50dB

+48V

-10dB / -20dB

-10dB / -15dB / -20dB

-50dB

+4VDc ±0.3V

18VDc, 1A

13.5W

T0.5Ae 250V (slow-Blow)

2.25 kg

420x44x198.5mm

482

M 12X4

PREAMPLIFIER MIXER

preamplifier/mixer with 12 inputs and 4 outputs

• 4 micro/line inputs;

• Priority of the 4 microphone inputs over all other inputs and priority of the first input over the other 3

• Volume control and voice control for the 4 microphone inputs

• Phantom 24V. 4 stereo line inputs on double RCA with selection via purpose-provided selector knob

• General volume and tone control

• 2 XLR outputs for

• Left and right channel with independent volume control for each channel

• One stereo output and one stereo recording output

• 1 rack unit

cp-2

cassette player

sTUDio pro 9BA

Amplified Box

TM-2

Digital tuner

McA 2240 o McA 4240

power unit

MD-s 1100

microphones

cD-2

cD player

MD-s 1100

microphones

M 12X4 code 18147

Mono channels

micro impedance kohm max input signal dBu max gain (@ main out)dB

2,2

0

65

Equivalent input noise (EIN)

(between 22hz and 22Khz unweighted)

- 118 max gain (@main out) dB

Mono channels tone Voice dB

stereo channels

tone impedance kohm max input signal dBu max gain (@ main out) dB

stereo channels tone high shelving (@12khz) dB

General outputs

power supply cmrr (@main out, Gain 75dB)dB

Mono channels line impedance kohm max input signal dBu low shelving (@80khz) dB impedance kohm max output (main out) dBu

Distortion + [email protected]

(main out, 40dB gain) signal/noise ratio 20dB

Frequency response (@0/1dB)

- 65

33

30

25

± 12

22

10

10

± 15

± 15

600

22

0,025%

96

20Hz-20kHz

100V÷230V - 50hz÷60hz with internal power supply unit cassette

sTUDio 3 BT/Wp

loudspeaker

37

482

MMZ 8004 s

4-ZONE PREAMPLIFIER

preamplifier/mixer with 10 inputs and 4 outputs

• 6 Combo inputs

• 4 stereo line inputs for CD, Tape,

Tuner and Aux, selected on each output zone

• 4 output buses with independent control

• Microswitch on each input for routing to each output

• Adjustable sensitivity of micro and line inputs

• Designed for connection to up to 2 amplified microphone bases from the MBT8000 series equipped with zone selector switches

• Designed for connection to emergency detection systems for guided evacuation, with priority over all inputs

• Automixer operating mode on

3 microphone channels, thanks to the GATING function (this function allows for the level of speech to be increased before the “Larsen effect” - feedback whistling - occurs)

• Internal switching power supply from 100V to 230V and from 50Hz to 60Hz

• 2 rack units

38

4 ZONE PAGING

MB-T 8004

microphone base

in

MMZ 8004s

4 zones preamplifier

1/4 power unit zone 1

1/4 power unit

1/4 power unit

MpU series

1/4 power unit zone 2 zone 3 zone 4

code

Features

MMZ 8004 s

19812

Dimensions 2 racks with frame with rAl 7035 grey paint finish

Microphone-Max

gain line

input 1 and 2

6 micro/line inputs with combo connector

(XLR and JACK) 75dB/2kohm

Terminal board with option to select output 1,2,3 and 4 from a remote microphone

Direct outputs channels 1-6 + recording socket output

1,2,3 and 4 0 dBu/600 ohm

Max. gain line/imp. 4 stereo inputs pin jack rcA 40dB/33kohm

Frequency [email protected]/-1dB 20hz÷80Khz

s/n [email protected] of gain

Level control

High pass filter

Voice control

Tone control

phantom power supply

output 1, 2, 3 and 4

inputs Music

110dB

8 Volume controls, 6 GAin controls, 2 master channels1:6 micro/[email protected]/oct.

6 adjustment trimmers for voice presence on mic. inputs

2 separate bass and treble tone controls on music inputs only

48 VDc activated on micro inputs only selectors enable routing of each input to output 1,2,3, 4

4 stereo inputs on double rcA for cD, Tape,

outputs dB/impedance

Auxiliary outputs

Tuner and Aux selected on each output zone

28 dBu/600 ohm balanced

priority on music

remote controls

emergency control

insert bus 1 and 2

Luminous indicators

power supply VAc

optional accessories

Direct outputs channels 1-6 + recording socket output

1,2,3 and 4 0 dBu/600 ohm optional cards for: remote volume for outputs 1,2,3 and

4 - Automatic level control according to background noise on output 1 input with photo coupler, open collector output

6.3mm stereo jack socket to connect auxiliary equipment led indicating saturation level (peak) on outputs 1,2,3, and 4 - phantom on (48 VDc micro)

230 VAc or 120 VAc with internal power supply unit

MMZ-Ar card for automatic level control according to background noise (output 1 only)

MMZ-Vrc card for remote volume control for pair of outputs 1/2

MZU 2008

Zone pAGinG UniT

The MZU 2008 switching unit can be installed in 19” racks for selective voice/music switching in

8 audio zones, with the possibility to increase the number of zones as multiple of 8, adding other MZU

2008 in cascade.

Selection of the zones in which the music is to be interrupted and an announcement transmitted is carried out from the MBT 8008 control console.

Using the 8 “MUSIC” keys on the front panel, you can choose in which of the 8 audio zones to play the normal background music and in which zones no music is to be played. The system can be configured in one of the following ways:

• a) the 2 inputs of the unit are driven by two amplifiers, one of which is dedicated to voice transmission and the other to music transmission.

The 8 outputs of the unit drive the 8 speakers of the 8 audio zones.

• b) the 2 inputs of the unit are driven by two signal preamplifiers, one of which is dedicated to voice transmission and the other to music transmission.

The 8 outputs of the unit drive the 8 power amplifiers dedicated to sound diffusion in the 8 audio zones.

MB-T 8008

microphone base

MZU 2008

paging unit

MXA 1120

integrated amplifier cD or TApe

MXA 3120

integrated amplifier

MZU 2008 code 12944 characteristics inputs

1 rack unit with frame with rAl 7035 light grey paint finish

2 music inputs with two wires, speech with three wires, one of which is used for emergencies (for amplifiers)

outputs for loudsp. line (zones) 8 with three wires, one of which is used for emergencies

Max. applicable power

1200 Watt/100 V, 840 Watt/70V, 600 Watt/50V, 300

Watt/25V

controls remote controls output power supply

Luminous indicators

VAc power supply optional accessories

speech key for each zone. music key for each zone.

General call key. Power ON-OFF key

Zone selection control. General call command.

Activation of emergency and open collecTor output power supply +15/0/-15 VDc speech led and music led per zone. General call indicator led. emergency indicator led.

Power ON-OFF indicator led

230 VAc with external power supply unit

120 VAc with external power supply unit mBT 8008 microphone base

39

482

MpU 2120 MpU 4060

mUlTi chAnnel 100V line poWer UniTs

• Output with transformers for

100V and 70V lines

• Frequency response

40Hz to 20kHz

• 40Hz internal high-pass filter

• Configurations: 2x120W, 1x240W

• Thermal and short-circuit protections

• 2 U rack

Same features as the MPU 2120 model except for the following difference:

• Configurations: 4x60W, 2x120W

40

MpU 2120 MpU 4060 code 31080 31079

Features

2-channel monoblock amplifier

output power of all the driven channels

2x120Wrms 100V/70V

1x240Wrms 100V

4-channel monoblock amplifier

4x60Wrms 100V/70V

2x120Wrms 100V

Frequency response

(@1 W, -3dB 100V output)

40hz÷20khz

40hz internal high-pass filter

signal/noise ratio 96dB (with filter 22hz÷22khz)

separation between chan. [email protected]/8ohm > 80dB

40hz÷18khz

40hz internal high-pass filter

96dB (with filter 22hz÷22khz)

> 80dB

0,005% 0,004%

[email protected]/8ohm

inputs

input sensitivity balanced with screw connector

0dBu (0.775V) balanced

6dBu (1.5V) unbalanced balanced with screw connector

0dBu (0.775V) balanced

6dBu (1.5V) unbalanced

input impedance

controls

20kohm balanced

10kohm unbalanced

Volume control for each channel located in the back panel

20kohm balanced

10kohm unbalanced

Volume control for each channel located in the back panel

Light indicators

power supply Vac input signal presence for each oc (over current) channel and Fault every two channels internal setting 85÷132Vac

170÷264Vac (default) input signal presence for each oc (over current) channel and Fault every two channels internal setting 85÷132Vac

170÷264Vac (default)

Absorption

operating conditions

protections

cooling

300VA (@ max power with music signal)

-20°c+40°c with max. humidity <90%

Short-circuit (OC), thermal (Fault)

1 ø 60mm fan

Dimensions (WxHxD) 482x88x430mm (2 U rack)

250VA (@ max power with music signal)

-20°c+40°c with max. humidity <90%

Short-circuit (OC), thermal (Fault)

1 ø 60mm fan

482x88x430mm (2 U rack)

482

MpU 4120 MpU 4240

mUlTi chAnnel 100V line poWer UniTs

• Output with transformers for

100V and 70V lines

• Frequency response

40Hz to 20kHz

• 40Hz internal high-pass filter

• Configurations:

4x120W, 2x240W

• Thermal

and short-circuit protections

• 2 U rack

Same features as the MPU 2120 model except for the following difference:

• Configurations:

4x240W, 2x480W

MpU 4120 MpU 4240 code 31059 31078

Features

4-channel monoblock amplifier

output power of all the driven channels

4x120Wrms 100V/70V

2x240Wrms 100V

4-channel monoblock amplifier

4x240Wrms 100V/70V

2x480Wrms 100V

Frequency response

(@1 W, -3dB uscita 100V)

signal/noise ratio

separation between channels

[email protected]/8ohm

inputs

input sensitivity

40hz÷20khz

40hz internal high-pass filter

96dB (with filter 22hz÷22khz)

> 80dB

40hz÷18khz

40hz internal high-pass filter

96dB (with filter 22hz÷22khz)

> 80dB

0,005% 0,005% balanced with screw connector

0dBu (0.775V) balanced

6dBu (1.5V) unbalanced balanced with screw connector

0dBu (0.775V) balanced

6dBu (1.5V) unbalanced

input impedance

controls

20kohm balanced

10kohm unbalanced

Volume control for each channel located in the back panel

20kohm balanced

10kohm unbalanced

Volume control for each channel located in the back panel

Light indicators

power supply Vac input signal presence for each oc (over current) channel and Fault every two channels internal setting 85÷132Vac

170÷264Vac (default) input signal presence for each oc (over current) channel and Fault every two channels internal setting 85÷132Vac

170÷264Vac (default)

Absorption

operating conditions

protections

cooling

600VA (@ max power with music signal)

-20°c+40°c with max. humidity <90%

Short-circuit (OC), thermal (Fault)

1 ø 60mm fan

Dimensions (WxHxD) 482x88x430mm (2 U rack)

1200VA (@ max power with music signal)

-20°c+40°c with max. humidity <90%

Short-circuit (OC), thermal (Fault)

2 ø 60mm fan

482x88x430mm (2 U rack)

41

482

McA 4030

mUlTi-chAnnel consTAnT VolTAGe (100 V)

Monoblock power amplifier with

4 independent channels and 4

100V line transformers

• Configurations possible: 4x30W or 2x60W on 100V

• Level control on front panel

• Luminous indication of the operating mode

• Emergency control with an output open collector and an input for the alarm signal activation command

• Outputs with 3 wires for line, common and emergency

42

McA 4030 code 20236 characteristics continuous power with all

Frequency response @1 W, -3dB

Harmonic distortion THD+n

monoblock amplifier with 4 channels

4x30W (100V) 2X60W (100V) piloted channels from 20hz to 50 khz

< 0.05%

85dB (with filter 22hz-22khz)

signal/noise ratio separation between channels inputs input impedance input sensitivity controls indicators output connector type

VAc power supply

Absorption operating conditions protections

Dimensions

-66dB @100hz, -75dB @ 1khz, -70dB @ 10khz

A and B balanced, with screw connector (B priority)

10kohm (unbalanced) 20kohm (balanced)

0dBu (0.775V) with balanced input, 6dBu (1.5) with unbalanced input

Volume control for each channel

Visual led indicators for each channel

“Faston” connectors

100V÷230V - 50hz÷60hz with internal power supply unit

300 W (@ max power with music signal)

-20°c+40°c with max. humidity <90%

Thermal, short circuit, soft start

482x88x220mm (2 U rack)

cM

rAcKs

rack

depth 500mm, ready-to-assemble kit, made of sheet steel with RAL

7035 paint finish, comprising:

• Base (W=534xD=500mm) with four M10 threaded fittings

• Lid (W=534xD=500mm)

• Two side panels with 19” vertical pitch and ventilation slits

• Four swivel castors

• Assembly hardware set

Note: 1U = 44mm

MrK

rAcK cABineT

preassembled rack cabinet

depth 600mm, made of sheet steel with RAL 7035 paint finish, comprising:

• Two side panels with 19” vertical pitch with ventilation slits

• Solid rear panel

• Reversible hinged door with glass window and lock

• Four swivel castors (optional)

Note: 1U = 44mm

Grey racks rAl7035

code

cM 08 cM 12 cM 18 cM 22 cM 26

12682 12681 12385 11827 12669

Description 8U 12U 18U 22U 26U

500x530 500x530 500x530 500x530 500x530

400 580 850 1030 1200

Weight 19 22,6 27,2 30 34,3

plexiglas doors with lock code

Description

Ap 08 Ap 12 Ap 18 Ap 22 Ap 26

12897 12898 12667 12178 12668

8U 12U 18U 22U 26U

rear perforated panels code

Description pp-A 02 pp-A 08 pp-A 12

12899 12900 12901

2U 8U 12U

Grey racks rAL7035

MrK 12 MrK 20 MrK 24 MrK 30 MrK 36 code

Description

36546 35673 35839

12U 20U 24U 30U 36U

Dimensions WxD 600x600 600x600 600x600 600x600 600x600

Dimensions H

43

so pair of omega rack supports

Model code Height Weight cabinet

so-12 12907 532mm 1,4 kg Ar12

Accessories

so-18 12908

978mm 2,6 kg Ar22

pA-A pc rp 02 cabinet panels

Model code Description colour

pA-A 01 12905 perforated 1U grey rAl7035

pc 01 pc 02 pc 03

12117 solid 1U

12116 solid 2U

12912 solid 3U grey rAl7035 grey rAl7035 grey rAl7035

Universal internal shelf

Model code Description colour rp 02

12913 2U grey rAl7035

sA 02 rack upright

Model code sA 02 12906

DG 01 cage nut

Model code pack

DG 01

12114 50 pcs

Mps1016 power supply panel code 04693

(1 rack unit) mUsic soUrces AnD poWer sUpply pAnel

482

482 remote control included with ms02 cD3/T

Ms02 cD3/T

mUsic soUrces

Ms02 cD3/DG

Dual source

• 2 sections, each one featuring a stereo output with its own volume control

• One selector, shared by both sources, can mix stereo channels changing to mono the cD and radio output for applications that do not need stereo sound

• It can be installed into a

19” rack 1U

• The CD player can play audio tracks and mp3 files from compact disc

(cD, cD-r, cD-r/W) or UsB drives

(“Flash memory-stick with mp3 files)

• USB port on the front panel

• FM radio tuner (87.5-108 MHz) that can store up to 10 radio stations

• LCD display

Dual sound source system

composed of:

UsB & sD card reader and recorder / remote control

• recording through the line-in is directly store to UsB or sD card

• offers UsB and sD card function of each replication

• recording format: mp3

• playing format: mp3, WmA

• Accept the capacity of 128mB to

16G UsB or sDhc card

• With a language learning function, can be broadcast repeatedly at designated areas

• Adjustable recording quality, provide choice of,128Kbps and 192Kbps

Anti shock cD / UsB & sD card reader / remote control

• Features

• offers UsB, sD card and cD playing function of each replication

• playing format: mp3, WmA

• Accept the capacity of 128mB to

16G UsB or sD card

• With a language learning function, can be broadcast repeatedly at designated area

Ms02 cD3/T

Ms02 cD/DG

Ms02 cD3/T code 27867

Tuner

Memories for the tuner (FM10 e AM10)

Mechanics

AM/FM

20

Antishock mechanics and electronics cD player that can play cD, cD-r, cD-r/W,

inputs/outputs mp3, UsB mp3

Input: unbalanced 75ohm FM Antenna terminals - Am antenna loop terminals -

UsB port for memory stick - output: audio

RCA for AM/FM tuner - audio RCA for CD

player

power supply 220Vac

power consumption 50VA

Weight 3.5 kg

Dimensions (WxHxD) 482x44x250mm

Ms02 cD3/DG code

Mains power supply

Dc external power supply

Mains consumption

Dc consumption

Weight

Dimensions (WxHxD)

27868

230 VAc ±10% 50/60 hz

24 VDc

45 VA

700 mA (max)

cD/UsB/sD player output level

250 mV

UsB/sD reader &recorder output level

900 mV

4,5 kg

81 x 44 x 285

45

430

MpA 5120

120W POWER AMPLIFIERS

EN 54 - 16

MpA 5240

240W POWER AMPLIFIERS

MpA 5480

480W POWER AMPLIFIERS

This is a new range of power units designed specifically for professional sound-broadcasting systems with service and emergency messages. Thanks to the great reliability of the protection circuits used, combined with an attractive appearance and the very tough structures, the

MPA range constitutes the ideal product for quality amplification, with a particularly interesting price/ performance ratio. If this amplifier is used in emergency systems, it is possible to disable all the front-panel controls (tone and volume controls).

In this way it is possible to prevent the levels set at the time of commissioning the system from being altered accidentally.

• Balanced line input/output

(XLR-F and XLR-M sockets, with adjustable sensitivity)

• Unbalanced line input (double

RCA socket)

• MBT 1101 microphone station input (RJ45 socket)

• Telephone/emergency audio input for priority calls with adjustable threshold and sensitivity

• Front panel overall volume control and treble and bass controls

• Rear-panel selector switch for enabling/disabling front-panel tone and volume controls

• Constant voltage (50/70/100 V) or 8 Ω impedance loudspeaker line output.

• LED-type Vu meter for clear and immediate monitoring of output power

• Contacts for activating precedence on line input

• Alerting signal (chime) with level control

• Selectable 230/115 VAC and 24

VDC mains power supply

46 code rated output power costant voltage output / low impedance output

Tones control in UniTs

sensitivity / impedance s/n ratio

Frequency response number of consoles mBT 1101

Line input

sensitivity / impedance s/n ratio

Frequency response

Telephone input

sensitivity / impedance s/n ratio

Frequency response

Line oUT power supply

Mains power supply external Dc power supply rack dimensions 19”

Dimensions (L x H x p)

Weight

MpA 5120

37490

120 W

MpA 5240

37489

240 W

MpA 5480

37491

480 W

100-70-50 V / 8 Ω 100-70-50 V / 8 Ω 100-70-50 V / 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz) Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz) Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz) rJ45 (mBT 1101) rJ45 (mBT 1101) rJ45 (mBT 1101)

1250 mV

> 78 dB

30 ÷ 20.000 hz

320 mV

> 78 dB

30 ÷ 20.000 hz

320 mV

> 78 dB

30 ÷ 20.000 hz max 6 consoles in daisy chain max distance 200 mt max 6 consoles in daisy chain max distance 200 mt max 6 consoles in daisy chain max distance 200 mt balanced XLR, unbalanced RCA

300 mV / 60 kΩ

>77 dB

30 ÷ 20.000 hz balanced with priority activation

120 mV / 6 kΩ

>75 dB

230 ÷ 13.000 hz balanced, XLR

230/115 Vca - 50/60 hz / 24 Vcc

280 W (320 VA)

6,6 A / 0,2 A optional bracket rmK 5000

432 x 88 x 272 mm

8,2 kg balanced XLR, unbalanced RCA

300 mV / 60 kΩ

>77 dB

30 ÷ 20.000 hz balanced with priority activation

120 mV / 6 kΩ

>75 dB

230 ÷ 13.000 hz balanced, XLR

230/115 Vca - 50/60 hz / 24 Vcc

535 W (610 VA)

13,2 A / 0,2 A optional bracket rmK 5000

432 x 88 x 272 mm

10,5 kg balanced XLR, unbalanced RCA

300 mV / 60 kΩ

>77 dB

30 ÷ 20.000 hz balanced with priority activation

120 mV / 6 kΩ

>75 dB

230 ÷ 13.000 hz balanced, XLR

230/115 Vca - 50/60 hz / 24 Vcc

1160 W (1330 VA)

33 A / 0,8 A optional bracket rmK 5000

432 x 88 x 360 mm

16 kg

320

AM 5030

INTEGRATED AMPLIFIERS

30W Integrated amplifier

• 2 microphone sockets

• Priority of microphone over music

• Low impedance and 100V

outputs

• 2 rack units

AM 5030 code 11583

Features

100W desktop amplifier

rated/Maximum power 30/40W

Frequency response 50÷18khz

Distortion (rated p. 1kHz) <3% linea 100mV inputs/sensitivity -impedance

output impedance 4-8-16ohm

output voltage 100V

Tone controls 150hz/1khz-6khz

VAc power supplies 220Vac

Weight

4,7 Kg

Dimensions (WxHxD) 320x80x190mm

430

MXA 1060

INTEGRATED AMPLIFIERS

MXA 1120

• 2 microphone inputs with phantom power supply (XLR). MIC

1 with automatic precedence function (VOX) and threshold adjustment control

• Microphone input (XLR) with phantom power supply or RJ45 for connecting up to 6 MBT 1101 microphone stations (maximum distance 200 m)

• MIC/PH/LINE input with associated selector switch 2 auxiliary inputs for sound sources (TAPE/CD)

• Telephone/emergency audio input for priority calls with adjustable threshold and sensitivity

• Front-panel level control for each microphone and auxiliary input

• Front panel overall volume control and treble and bass controls

• Constant voltage (50/70/100 V) or

8 Ω impedance loudspeaker line output

• Auxiliary line output

• LED-type Vu meter for immediate monitoring of output power

• Microswitches for setting priorities and input functions

• Inclusion/exclusion of speech filter on all microphone inputs

• Contacts for activating input precedence

• Alerting signal (chime) with level control

• Selectable 230/115 VAC and 24

VDC mains power supply

48 code rated power output costant voltage output / low impedance output

Tones control

Mic.1 and Mic.2 input

sensitivity / impedance s/n ratio

Mic3 / UniTs input

sensitivity / impedance s/n ratio number of consoles mBT 1101

Mic / Line 4 input

sensitivity / impedance (mic / line 4) s/n ratio mic / line 4

Auxiliary input

sensitivity / impedance s/n ratio

Telephon input

sensitivity / impedance s/n ratio

Line oUT power supply

Max power consuption

Max power at 24 Vcc rack dimensions 19”

Dimensions (L x H x p)

Weight

MXA 1060

37638

60 W

100-70-50 V e 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

0,9 mV / 900 Ω

>62 dB balanced, XLR (phantom power) Rj45 (MBT 1101) mic.: 0,9mV / 900 Ω - UniTs: 290 mV / 700 k Ω mic.: >62 dB – UniTs: >65 dB max 6 consoles in daisy chain max distance 200 mt balanced, XLR with Phantom selector/Mic/Line mic: 0,9 mV / 900 Ω - line: 90 mV / 50 kΩ mic: >62 dB – line: >70 dB

2 unbalanced, rcA (cD, TApe)

150 mV / 6 kΩ

>70 dB balanced with priority activation

150 mV / 6 kΩ

> 72 dB

900mV / 100 Ω unbalanced, rcA

230/115 Vca - 50/60 hz / 24 Vcc

130 W (150 VA)

3,4 A / 0,1 A optional bracket rmK 5000

430 x 88 x 234 mm

6,5 kg

MXA 1120

37639

120 W

100-70-50 V e 8 Ω

Bassi± 10 dB (100 Hz) ; Treble± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

0,9 mV / 900 Ω

>62 dB balanced, XLR (phantom power) Rj45 (MBT 1101) mic.: 0,9mV / 900 Ω - UniTs: 290 mV / 700 k Ω mic.: >62 dB – UniTs: >65 dB max 6 consoles in daisy chain max distance 200 mt balanced, XLR with Phantom selector/Mic/Line mic: 0,9 mV / 900 Ω - line: 90 mV / 50 kΩ mic: >62 dB – line: >70 dB

2 unbalanced, rcA (cD, TApe)

150 mV / 6 kΩ

>70 dB balanced with priority activation

150 mV / 6 kΩ

> 72 dB

900mV / 100 Ω unbalanced, rcA

230/115 Vca - 50/60 hz / 24 Vcc

270 W (320 VA)

6,7 A / 0,2 A optional bracket rmK 5000

430 x 88 x 234 mm

9 kg

MXA 3120

INTEGRATED AMPLIFIERS

MXA 3240

430

UsB 3000

UsB/sD card Module code 37642

• 2 balanced/unbalanced microphone inputs with phantom power supply

• Microphone input or microphone stations of the MBT 1000 range

• 2 MIC/PH/LINE inputs with specific selector switch

• 2 auxiliary inputs for sound sources (TAPE/CD)

• Telephone/emergency audio input for priority calls with adjustable threshold and sensitivity

• Front-panel adjustment of the level of each microphone and auxiliary input

• Front-panel control of overall volume and of treble and bass tones

• Provisions for inserting via the front panel a USB/SD CARD module ( )

• Constant voltage (50/70/100 V) or

8 Ω impedance loudspeaker line output

• 3 output lines for zones

• Balanced line output for connection to other amplifiers

• Output/input for connection to audio processors

• LED-type Vu meter for clear and immediate reading of power emitted

• Microswitches for setting operating modes

• Includable/excludable speech filters on all microphone inputs

• Contacts for activating input precedence and override

• “Music On Hold” output with output level control (output of the selected auxiliary signal)

• Alerting signal (chime) with level control

• Front-panel keys for selecting music listening zones

• Selectable mains power supply -

230/115 VAC or 24 VDC

code rated power output costant voltage output / low impedance output

Tones control

Mic.1 e Mic.2 input

sensitivity / impedance s/n ratio

Mic3 / UniTs input

sensitivity / impedance s/n ratio number of consoles mBT 1101

Mic / Line 4 input

sensitivity / impedance s/n ratio

Auxiliary inputs

sensitivity / impedance s/n ratio

Telephone output

sensitivity / impedance s/n ratio

Line oUT power supply

Max power consuption

Max power at 24 Vcc rack dimensions 19”

Dimensions (L x H x p)

Weight

MXA 3120

37640

120 W

100-70-50 V e 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

0,9 mV / 900 Ω

>62 dB balanced, XLR (phantom power) Rj45 (MBT 1101) mic.: 0,9mV / 900 Ω - UniTs: 290 mV / 700 k Ω mic.: >62 dB – UniTs: >65 dB max 6 consoles in daisy chain max distance 200 mt balanced, XLR with Phantom selector/Mic/Line mic: 0,9 mV / 900 Ω - line: 90 mV / 50 kΩ mic: >62 dB – line: >70 dB

2 unbalanced, rcA (cD, TApe)

150 mV / 6 kΩ

>70 dB balanced with terminal for priority activation

150 mV / 6 kΩ

> 72 dB

900mV / 100 Ω, unbalanced rcA

230/115 Vca - 50/60 hz / 24 Vcc

130 W (150 VA)

3,4 A / 0,1 A optional bracket

430 x 88 x 234 mm

6,5 kg

MXA 3240

37641

240 W

100-70-50 V e 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

0,9 mV / 900 Ω

>62 dB balanced, XLR (phantom power) Rj45 (MBT 1101) mic.: 0,9mV / 900 Ω - UniTs: 290 mV / 700 k Ω mic.: >62 dB – UniTs: >65 dB max 6 consoles in daisy chain max distance 200 mt balanced, XLR with Phantom selector/Mic/Line mic: 0,9 mV / 900 Ω - line: 90 mV / 50 kΩ mic: >62 dB – line: >70 dB

2 unbalanced, rcA (cD, TApe)

150 mV / 6 kΩ

>70 dB balanced with terminal for priority activation

150 mV / 6 kΩ

> 72 dB

900mV / 100 Ω, unbalanced rcA

230/115 Vca - 50/60 hz / 24 Vcc

270 W (320 VA)

6,7 A / 0,2 A optional bracket

430 x 88 x 234 mm

9 kg

49

MDs 1060 MDs 1120

mUsic DisTriBUTion sysTem

MDs 1240

430

The MDS 1000 compact systems combine a reliable amplifier, an

MP3 player, an SD/MMC card drive, a USB socket for connection to external storage units and a digital FM tuner in a single piece of equipment that also features a range of functions typical of sound-broadcasting systems.

The XLR sockets on the rear panel can be separately configured as microphone inputs (with or without phantom power supply) or as line inputs. The operating mode can be selected by means of the specific three-position switches above the sockets. Each of these inputs has its own level control so as to be able to adjust the amplitude of the various different signals suitably. In addition, the

MIC/LINE 1 microphone input has an automatic precedence function (VOX): when speaking with the microphone connected to this input, all the music and microphone inputs will be automatically muted.

It is possible to connect all dynamic microphones and the

MBT 6400S microphone bases to the MDS 1000 Compact Systems.

• MP3 file player via USB, SD or

MMC card

• FM digital tuner

• n°3 MIC./LINE inputs with operating mode selector switches.

• n°1 VOX input (MIC/LINE 1)

• n°1 auxiliary input for sound sources (TAPE/CD)

• XLR sockets for connection to dynamic microphones and/or

MBT 6400S microphone bases

• Terminal strip for speakers output (25-70-100V/4ohm)

• Terminal strip for external 24

Vdc power supply

• Terminal strip for microphone precedence

• Possibility to connect an external equalizer and/or booster.

• Selectable mains power

(230/120Vac)

50 code rMs output power (THD <1%) constant voltage outputs

Low impedance outputs

Tones control

Bass tones @100 hz

Treble tones @10 khz microphone/line inputs sensitivity/impedance s/n ratio s/n ratio (‘A’ weighted)

MIC/LINE 1 VOX activation threshold

Frequency response phantom supply

Auxiliary input

sensitivity/impedance s/n ratio s/n ratio (‘A’ weighted)

Frequency response

VOX and precedence attenuation

pWr in input

sensitivity/impedance s/n ratio s/n ratio (‘A’ weighted)

Frequency response

Line oUT output

output level/impedance

pre oUT output output level consumption

230/120V Mains power supply

±10% 50/60 Hz external 24Vdc power supply

Dimensions

Weight

MDs 1060

37495

60 W

100, 70, 25 V

4 ohm

± 12 dB

± 11 dB mic

3 mV/1,5 k line

250mV/100kohm

68 dB

73 dBA

0,9 mV

35÷16.000 hz

18 V / 2,2 kohm -

72 dB

-

80 dBA

400 mV/22 kohm

78 dB

85 dBA

30÷18.000 hz

-60 dB

1 V / 22 kohm

85 dB

100 dBA

30÷18.000 hz

1 V / 200 ohm

1 V p = 150 W

4 A

430x88x270 mm

6,3 kg

-

MDs 1120

37496

120 W

100, 70, 25 V

± 12 dB

± 11 dB mic line

3 mV/1,5 kohm 250mV/100kohm

70 dB

73 dBA

0,9 mV

35÷16.000 hz

18 V / 2,2 kohm -

76 dB

-

82 dBA

400 mV/22 kohm

80 dB

82 dBA

30÷18.000 hz

-60 dB

1 V / 22 kohm

93 dB

100 dBA

30÷18.000 hz

1 V / 200

1 V p = 300 W

10 A

430x88x270 mm

8,3 kg

-

MDs 1240

37497

240 W

100, 70, 25 V

± 12 dB

± 11 dB line line

250mV/100kohm 250mV/100kohm

76 dB

-

82 dBA

35÷16.000 hz

18 V / 2,2 kohm -

76 dB

-

82 dBA

400 mV/22 kohm

80 dB

85 dBA

30÷18.000 hz

-60 dB

1 V / 22 kohm

93 dB

100 dBA

30÷18.000 hz

1 V / 200

1 V p = 600 W

20 A

430x88x270 mm

10,5 kg

MDs 6120 MDs 6240

mUsic DisTriBUTion sysTem

432

• 2 balanced/unbalanced microphone inputs with phantom power supplies

• Microphone input or microphone bases of the MBT 1000 range

• 2 MIC/PH/LINE inputs with associated selector switch

• 2 auxiliary inputs for sound sources (TAPE/CD)

• Telephone/emergency audio input for priority calls with adjustable threshold and sensitivity

• Front-panel level controls for each microphone and auxiliary input

• Front panel overall volume control and treble and bass controls

• Multi-purpose sound source module with CD-MP3/ USB/SD

CARD player and AM/FM tuner.

• Constant voltage (50/70/100 V) or

8Ω impedance loudspeaker output lines

• 6 output lines (zones) with frontpanel level control for the music signal for each single zone

• Balanced line output for connection to other amplifiers

• Output/input for connection to audio processors

• Connection to an external amplifier for simultaneous music and speech in different zones

• LED-type Vu meter for clear and immediate monitoring of output power

• Microswitches for setting the operating modes

• Inclusion/exclusion of speech filter on all microphone inputs

• Contacts for activating input precedence and override

• “Music On Hold” output with output level control (output of selected auxiliary signal)

• Alerting signal (chime) with level control

• Selectable 230/115 VAC and 24

VDC mains power supply

code rated power output constant voltage outputs / Low impedance outputs

Tones control

Microphone inputs Mic.1 and Mic.2

sensitivity / impedance s/n ratio

Microphone input Mic.3/UniTs

sensitivity / impedance s/n ratio number of consoles mBT 1106

Microphone inputs Mic./Line 4 and 5

sensitivity / impedance s/n ratio

Auxiliary inputs

sensitivity / impedance s/n ratio

Telephone input

sensitivity / impedance s/n ratio

Frequency response

signal outputs

line oUT pre oUT

Ape oUT music on hold (moh) pre-amplified line music on hold (moh) Amplified line

power supply

Max power consuption rack dimensions 19”

Dimensions (L x H x p)

Weight

MDs 6120

37643

120 W

100-70-50 V e 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

1,2 mV / 1300 Ω

> 66 dB balanced, XLR (phantom power 17,5 V) / 1 Rj45

(mDs 1106) mic: 1,2 mV / 1,3 kΩ ; UNITS: 850mV / 800 kΩ

MIC: >66 dB ; UNITS: >76 dB max 8 consoles in daisy chain max distance 1 km

2 balanced XLR Phantom selector/Mic/Line mic: 1,2 mV / 1,3 kΩ ; LINE: 110 mV / 130 kΩ

MIC: >66 dB ; LINE: >77 dB

2 rcA (cD + TApe) cD: 450 mV / 35 kΩ ; TAPE: 220 mV / 18 kΩ

> 80 dB balanced with terminals for priority activation

105 mV / 6 kΩ

> 74 dB

200 ÷ 20.000 hz

5

XLR balanced, 1 V / 3,9 kΩ rcA, 0,8 V / 3,8 kΩ

2 rcA, 0,9 V / 2 kΩ terminal strip (hoT-com), 2 V / 300 Ω terminal strip (GnD-mon), 1,9 W / 8 Ω

230/115 VcA - 50/60 hz / 24 Vcc

280 W (325 VA)

6,8 A / 0,2 A

432 x 133 x 360 mm

14 kg

MDs 6240

37644

240 W

100-70-50 V e 8 Ω

Bass ± 10 dB (100 Hz) ; Treble ± 10 dB (10 kHz)

2 balanced, XLR (phantom power 17,5 V) mic1 with priority activation

1,2 mV / 1300 Ω

> 66 dB balanced, XLR (phantom power 17,5 V) / 1 Rj45

(mDs 106) mic: 1,2 mV / 1,3 kΩ ; UNITS: 850mV / 800 kΩ

MIC: >66 dB ; UNITS: >76 dB max 8 consoles in daisy chain max distance 1 km

2 balanced XLR Phantom selector/Mic/Line mic: 1,2 mV / 1,3 kΩ ; LINE: 110 mV / 130 kΩ

MIC: >66 dB ; LINE: >77 dB

2 rcA (cD + TApe) cD: 450 mV / 35 kΩ ; TAPE: 220 mV / 18 kΩ

> 80 dB balanced with terminals for priority activation

105 mV / 6 kΩ

> 74 dB

200 ÷ 20.000 hz

5

XLR balanced, 1 V / 3,9 kΩ rcA, 0,8 V / 3,8 kΩ

2 rcA, 0,9 V / 2 kΩ terminal strip (hoT-com), 2 V / 300 Ω terminal strip (GnD-mon), 1,9 W / 8 Ω

230/115 VcA - 50/60 hz / 24 Vcc

510 W (590 VA)

13,1 A / 0,3 A

432 x 133 x 360 mm

16,5 kg

51

IN-CEILING SPEAKERS

IN-WALL SPEAKERS

SURFACE SPEAKERS

SOUND PROJECTORS

HORN SPEAKERS

53

206

206

SAFE 10 PT

ABS SurfAce mounting wAll loudSpeAker

DNH surface mounting self-extinguishing polycarbonate wall loudspeaker

• Power 10 Watt

• 100V transformer

• SPL 1W/1m 85dB

• Dispersion (-6dB) 1kHz/4kHz

140°/100°

• Grey RAL7035 colour

ø 264

WCS 650

ABS SurfAce ceiling/wAll mounting SpeAker

ABS ceiling/wall mounting speaker

• 10Watt dual cone loudspeaker with 153 g ferrite magnet

• 70V/100V line transformer and loudspeaker with 6,5” cone

• Easy mounting with the supports included

SAFE 10 PT

Code 09356

Features ip56 weatherproof and V0 self-extinguishing, with transformer

Mounting system

Rated/Maximum power

Screw terminals

10/15w rmS

Colour grey

Frequency response 150÷20.000Hz

Sensitivity 1W/1m 85dB

Maximum SPL 1m 95dB

Weight 0,8 kg

Dimensions (WxHxD) 206x55x104mm

WCS 650

Code 29470

Features ABS ceiling/wall mounting speaker

Colour white

Frequency response 80÷18kHz

Sensitivity 1W/1m 93dB

10 / 5 / 2,5wrms Power taps

Transformer 100V

Weight

Dimensions

1 kg

ø 264x85mm

210

WSH 1006

ABS WALL MOUNTING SPEAKER

ABS wall mounting speaker with painted metal protective grille

• 6 Watt dual cone loudspeaker

• Mounted horizontally or vertically

• 100V line transformer

• Easy mounting thanks to the hole cover plugs provided

184

184

85

fpS/505T

ABS SURfAcE MOUNTING WALL SPEAKERS

ABS wall mounting speaker

2-way

• Rated power 10W (20W max) at

4 Ohm

• Dispersion (-6dB) 1kHz/4kHz

150°/70°

• Power 10 Watt with 100V transformer

• Woofer 5” 1/4 with dome tweeter

• SPL @1W/1m 90dB

• White colour

WSH 1006 code 29419

features Wall speaker with painted metal protective grill

colour White

frequency response 130÷15kHz

SpL 98dB at 100V 6W

Sensitivity 1W/1m 92dB

power taps

6 / 3W

Transformer 100V

Weight 1,4 Kg

Dimensions (WxHxD) 210x320x85mm

fpS/505T code 35302

features

Mounting system

ABS surface mounting wall speaker

Screw fit

power taps 10W / 4 Ohm

colour White

frequency response 120÷20.000Hz

Sensitivity 1W/1m 80dB

Maximum SpL 1m 96dB

Input

Weight

100V / 4 Ohm

1 Kg

Dimensions (WxHxD) 184x271x37mm

ø 137

25

53

AQUA 30

loudspeaker for underwater applications

DNH ABS wall or surface mounted loudspeaker for underwater applications

• IP68 grade of protection

• Rated power 20W at 8 Ohm

• Max/min operating temperature

90 C°/-30°C

• Dispersion (-6dB) 1kHz/4kHz

180°/180°

• SPL 1W/1m 105dB

• Guarantees superb audio quality for the reproduction of music and speech in underwater environments, positioned at a max of 2 metres below the water’s surface

ø 165

ø 139 - ø 142

BK 560 CRT

loudspeaker for clean rooms

DNH aluminium ceiling loudspeaker with paint finish

• Specifically designed for use in sterile environments

• Loudspeaker fitted with special protections to ensure that no dust or airborne particles are generated or affect operation

• Rated power 6W

• Sensitivity 1W/1m 88dB

100V transformer

• Dispersion (-6dB) 1kHz/4kHz

170°/60°

• Grey RAL9010 colour

56

AQUA 30

Code 10436

Features

Mounting system

Rated/Maximum power

Colour ip68 watertight recessed or on bracket included

20/30 watt

Blue ncs 1070B

Frequency response 80÷20.000 Hz

Sensitivity 1W/1m 105dB

Maximum SPL 1m 118dB

Weight 2,5 kg

Dimensions ø 137x53mm

BK 560 CRT

Code 09309

Features

Mounting system spring-clips

Rated/Maximum power

Colour developed for clean rooms

6 watt white ral 9010

Frequency response 70÷15.000 Hz

Sensitivity 1W/1m 88dB

Maximum SPL 1m 95dB

Weight 1,1 kg

Dimensions ø 165x84mm

146 72

iW-100 T

ABs in-WAll / in-ceilinG speAKer

ABs surface mounting ceiling loudspeaker

• 2-way with 4” woofer and 1” dome tweeter

• Rated power 1/2/4/7.5/15W RMS with 100V transformer

• Frequency response 60-

20,000Hz, sensitivity @1W/1m of

88dB

• Dispersion (-6dB) 1kHz/4kHz

80°/150°

257 109

iW-200 Tcp

ABs in-WAll / in-ceilinG speAKer

ABs surface mounting ceiling loudspeaker

• 2-way with 8” woofer

and 1” dome tweeter

• Rated power 1/2/4/7.5/15/30W

RMS

• 100V transformer

• Frequency response

40-20,000Hz, sensitivity @1W/1m of 90dB

• ABS base

• Dispersion (-6dB) 1kHz/4kHz

80°/140°

iW-100 T code 17859

power taps

Loudspeaker

1/2/4/7,5/15W rms

2-way, 4” woofer with 1” dome tweeter

Frequency response 60÷20.000hz

sensitivity 1W/1m 88dB

Maximum spL 1m 99dB

input voltage 100V

Weight 1,3 Kg

Dimensions (WxHxD) 146x220x72mm

cut-out diameter 195x120mm

Accessories surface mounting recess rB100

rB-100 surface mounting recess code 18159

surface mounting recessed box for iW-100T speakers

iW-200 Tcp code 17862

power taps

Loudspeaker

2/4/7.5/15/30W rms with transformer

100V with regulator 2-way,

8” woofer with 1” dome tweeter

Frequency response 40÷20.000hz

sensitivity 1W/1m 90dB

Maximum spL 1m 105dB

input voltage 100V

Weight

3 Kg

Dimensions (WxHxD) 257x360x109mm

cut-out diameter 225x330mm

Accessories surface mounting recess rB200

rB-200 surface mounting recess code 18160

surface mounting recess for iW-200T speakers

McsL 006 TW McsL 006 TWp

in-ceilinG speAKers

ABs in-ceiling speaker with metal grille

• Colour white RAL9016

• Full range 2,5” dual cone

ABs weather-proof in-ceiling speaker with metal grille

• ABS back cover equipped with cable sleeve to ensure good sealing

• Colour white RAL9016

• Full range 4” dual cone

csL 106/T

in-ceilinG speAKers

csL 520 Tic

in-ceiling speaker with metal grille

• Colour white RAL9016

• 5” dual cone loudspeaker

in-ceiling speaker with metal grille

• Metal back cover

• Colour white RAL9016,

• Coaxial loudspeaker with 5” woofer and 1/2” tweeter

• 88dB+/- 3dB sensitivity @1W/1m

• Nominal Power

2,5/5/10/20W/8ohm with

100V/70V line transformer

• Building-in hole 170mm

103

95

140

120

150

150

203

170

58 code

Features

power taps

Frequency response

sensitivity 1W/1m

Maximum spL 1m

input voltage

cut-out diameter

Weight

Dimensions

McsL 006/TW McsL 006/TWp

29425 29426

ABs in-ceiling speaker with metal grille

6 / 3W 6 / 3W

120:20.000hz 150:18.000hz

87dB 91dB

91dB 95dB

100V 100V

95mm 125mm

0,5 Kg 0,9 Kg

ø 103x80mm ø 140x130mm

code

power taps

Frequency response

sensitivity 1W/1m

input voltage

cut-out diameter

Weight

Dimensions

csL 106/T csL 520 Tic

29427 29416

3/6W 2.5/5/10/20W/8ohm

100:15.000hz 100:20.000hz

93dB 88dB

100V 100V / 70V

150mm 170mm

0,5 Kg

ø 150x60mm

1,8 Kg

ø 203x145mm

CSL 630 TIC

IN-CEILING SPEAKERS

CSL 840 TIC CSL 606 TWP

WEATHER-PROOF SPEAKERS

In-ceiling speaker with metal grille

• Metal back cover

• Colour white RAL9016,

• Coaxial loudspeaker with

6” woofer and 1/2” tweeter

• Nominal Power

3.8/7.5/15/30W/8Ohm with

100V/70V line transformer

• 90-20,000Hz frequency response

• 88dB+/- 3dB sensitivity @1W/1m

• Dimensions 230x150mm

• Building-in hole 200mm

In-ceiling speaker with metal grille

• Metal back cover

• Colour white RAL9016,

• Coaxial loudspeaker with

8” woofer and 1/2” tweeter

• Nominal Power

5/10/20/40W/8ohm with

100V/70V line transformer

• 90-20,000Hz frequency response

• 88dB+/- 3dB sensitivity @1W/1m

• Dimension 270x185mm

• Building-in hole 240mm

ABS weather-proof in-ceiling speaker

• Plastic basket and white RAL

9016 grille

• 5” loudspeaker with coaxial 1” tweeter, water-resistant and resistant to the corrosion due to outdoor mounting

• 100V integrated transformer

• Low impedance socket (8ohm)

• Maximum power 45W (Rated

20W)

230

200

270

240

167

120

Code

Power taps

Frequency response

Sensitivity 1W/1m

Input voltage

Cut-out diameter

Weight

Dimensions

CSL 630 TIC CSL 840 TIC

29417 29418

3.8/7.5/15/30W/8ohm 5/10/20/40W/8ohm

90:20.000Hz 50:20.000Hz

88dB

100V / 70V

88dB

100V / 70V

200mm 240mm

2,3 Kg 3,1 Kg

ø 230x150mm ø 270x185mm

CSL 606 TWP

Code 29429

Power taps 20W/8ohm

Frequency response 95:20.000Hz

Sensitivity 1W/1m

Input

90dB

100V / 8ohm

Cut-out diameter 122mm

Weight 0,7 Kg

Dimensions ø 167x115mm

59

DP 10 T DPD 10 T

PLASTIC DNH SOUND PROJECTORS

DNH IP 55 rated sound projector

• Made in anticorrosion polyamide

• Wall or ceiling mounted articulated support

• 10 Watt power

• 100V line transformer

• Maximum/minimum operating temperature 150 C°/-40°C

• SPL 1W/1m 96dB

• Dispersion (-6dB) 1kHz/4kHz

110°/40°

DNH IP 55 rated sound projector

• Made in anticorrosion polyamide

• Articulated support

• Wall or ceiling mounted

• 10 Watt power

• 100 V line transformer

• Maximum/minimum operating temperature 150 C°/-40°C

• SPL 1W/1m 94dB

• Dispersion (-6dB) 1kHz/4kHz

110°/40° bidirectional

210 210

ø 146

220

312

175

445

CAR 6 FT

DNH FIRE RESISTANT SOUND PROJECTORS

DNH bi-directional loudspeaker

• Anodised aluminium or white

• NEMKO certified fire resistant at 150°C for 24 hours, at 750° for

30 minutes

• Power 6 Watt

• 100V transformer

• Max/min operating temperature

150 C°/-40°C

• SPL 1W/1m 92dB

• Dispersion (-6dB)

1kHz/4kHz 150°/150°

60

Code

Features

DP 10 T

IP55

Sound Projector

DPD 10 T

09352 11818

IP55 Bidirectional

Sound Projector

CAR 6 FT

Code 11956

Features Bi-directional fire-resistant with

transformer

Mounting system

Rated/Maximum power

Colour

Sensitivity 1W/1m

Maximum SPL 1m

Input voltage

Operating temperature

Weight

Accessories of the kit

Dimensions (WxHxD)

Bracket

10/15 Watt

RAL 7035

100 Volt

2,7 Kg

Bracket

Bracket

10/15 Watt

Light grey Light grey

RAL 7035

Frequency response

150÷15.000 Hz 150÷15.000 Hz

Dispersion (-6dB) 1kHz/4kHz 110°/40° 110°/40°

96dB 94dB

105dB 103dB

100 Volt da -40°C a 150°C da -40°C a 150°C

3,7 Kg

Bracket

210x150x312mm 210x150x445mm

Mounting system Bracket

Rated/Maximum power 6/8 Watt

Colour Aluminium/anodised

Frequency response 150÷15.000Hz

Sensitivity 1W/1m 92dB

Maximum SPL 1m 99dB

bidirectional

Operating temperature

100 Volt da -40°C a 150°C

Weight 2,2Kg

Dimensions ø145x175mm

45ϒ

145

26 174

CAD 20 T

ABS SOUND PROJECTORS

ABS weather-proof sound projector

• Metal U bracket

• 5.1” dual cone polypropylene loudspeaker

• Power 20 Watt

• 100V transformer

• SPL 1W/1m 92dB

• Dispersion [email protected] 120°

• UV protection

SP 115 WP SP 115 B/WP

ABS SOUND PROJECTORS

IP44 Weather-proof ABS sound projector

• White RAL 9010

• Power 3.75/7.5/15W

• 50/70/100V transformer

• Complete with steel bracket

• 5.5” plastic cone loudspeaker

• Frequency response 150-20kHz

[email protected]/1m 94dB

• Dispersion (-6dB) @2kHz 110°

IP44 Weather-proof ABS bi-directional sound projector

• White RAL 9010

• 50/70/100V transformer

• Complete with stainless steel bracket

• 2x 5.5” plastic cone loudspeaker

• Frequency response 150-20kHz

[email protected]/1m 94dB

• Dispersion (-6dB) @2kHz 120°

ø 150

196,5

CAD 20 T

Code 11469

Features

Mounting system

ABS sound projector weather-proof

Stainless steel U bracket

Power taps 20 / 10 / 5 / 2,5Watt

Colour White

Frequency response 110÷18.000 Hz

Sensitivity 1W/1m 31dB

Input voltage

Weight

Dimensions

100/70 Volt

1,9 Kg

ø 138x200mm

Code

Features

Mounting system

Power taps

Colour

Frequency response

Sensitivity 1W/1m

Input voltage

Weight

Dimensions

SP 115 WP SP 115 B/WP

37636 37637

IP44 Weather-proof Bi-directional sound projector IP44 Weather-proof sound projector

Stainless steel

U bracket

Stainless steel

U bracket

15 / 7.5 / 3.75W 6 / 15W

White White

150-20 kHz 150-20 kHz

94dB 94dB

100/70/50 Volt 100/70/50 Volt

1,3 Kg 2,3 Kg

ø 150x196,5mm ø 150x196,5mm

61

CESL 10T CESL 20T CESL 10T BIDI

ALUmINIUm SOUND PROJECTORS

Aluminium

Weather-proof sound projector

• White RAL9016

• 5” dual cone loudspeaker

• 10/5/2.5 Watt power

• 100V Transformer

• SPL 1W/1m 91dB

• Dispersion (-6dB)

@2kHz 110°

Aluminium

Weather-proof sound projector

• White RAL9016

• 6,5” dual cone loudspeaker

• 20/10/5Watt power

• 100V Transformer

• SPL 1W/1m 92dB

• Dispersion (-6dB)

@2kHz 110°

Aluminium

Weather-proof sound projector

• White RAL9016

• 2x5” dual cone loudspeaker

• 10/5/2.5 Watt power

• 100V Transformer

• SPL [email protected] 5W

• Dispersion (-6dB)

@2kHz 110°

for each direction

ø 254

GB 820/T

SPHERICAL PENDANT SPEAKER

ABS spherical speaker

• White RAL9016

• 8” dual cone loudspeaker

• 360° horizontal and 140° vertical dispersion (@2kHz)

• 20 Watt power

• 100V Transformer

• Equipped with 2 mt cable

Code

Power taps

Frequency response

Sensitivity 1W/1m

Input voltage

Weight

Dimensions

CESL 10T CESL 20T CESL 10T BIDI

29420 29421 29429

10/5/2,5W 20/10/5W 10/5/2,5W

130Hz:15.000Hz 110Hz:15.000Hz 130Hz:15.000Hz

91dB 92dB 91dB

100V 100V 100V

2,2 Kg 2,8 Kg 2,8 Kg

ø 138x205mm ø 170x252mm ø 138x205mm

GB 820/T

Code 29430

Power 20W/10W/5W

Frequency response 130Hz:15000Hz

Sensitivity 1W/1m 92dB

Input voltage 100V

Weight 2,2Kg

Dimensions ø 254mm

362

300

MHS 50T

ABS MUSIC HORN SPEAKER

ABS weather-proof two-way music horn speaker

• Wide frequency-response

• Stainless steel adjustable bracket, ABS light grey body treated to be resistant to sunlight

• 50Watt power with 100V transformer

330

347

HS 50T

ALUMINIUM HORN SPEAKER

Aluminium ABS weather-proof circular horn speaker

• 100V line transformer

• Suitable for internal and external environments

• RAL7035

• Stainless steel bracket

• Double insulation

MHS 50T

Code 29431

Power taps

Colour

Frequency response

Sensitivity 1W/1m

Weight

Dimensions (WxHxD)

50 / 25 / 12,5 / 9 / 4,5 / 3,5W 8ohm

Light Grey RAL 7035

90-20.000Hz

99dB

3,9 Kg

362x315x300mm

HS 50T

Code 29422

Power taps

Colour

50 / 25W

Light Gray RAL 7035

Frequency response 380-6.500Hz

Sensitivity 1W/1m 109dB

Maximum SPL 1m 126dB

Input voltage 100Volt

Weight

Dimensions

2,3 Kg

ø 330x347mm

63

PH 10 T

ABS horn SpeAkerS

PH 20 T

IP 66 weather-proof ABS circular horn speaker

• RAL 7035 light grey colour

• Stainless steel U bracket

• Power 10/5/2,5/1,25 Watt

• 100V / 70V transformer

• SPL 1W/1m 106dB

• UV protection

IP 66 weather-proof ABS circular horn speaker

• RAL 7035 light grey colour

• Stainless steel U bracket

• Power 20/5/2,5 Watt

• 100V / 70V transformer

• SPL 1W/1m 108dB

• UV protection

105

20

95

200

120

109,5

254

135

118

287

PH 30 T

ABS horn SpeAkerS

IP 66 weather-proof ABS circular horn speaker

• RAL 7035 light grey colour

• Stainless steel U bracket

• Power 30/15/7.5/3.75 Watt

• 100V / 70V transformer

• SPL 1W/1m 110dB

• UV protection

64

Code

Features

Mounting system

Power taps

Colour

Frequency response

Sensitivity 1W/1m

Maximum SPL 1m

Input voltage

Weight

Dimensions

PH 10 T PH 20 T

11474 11475

Ip66 weather-proof Ip66 weather-proof

ABS circular horn speaker

ABS circular horn speaker

U Bracket U Bracket

10/5/2,5/1,25 Watt 20/10/5/2,5 Watt

Light Grey rAL 7035

Light Grey rAL 7035

400÷8.000 khz 350÷8.000 khz

106dB 108dB

116dB 121dB

100/70 Volt 100/70 Volt

1,3 kg

ø 138x200mm

1,9 kg

ø 203x254mm

PH 30 T

Code 10446

Features Ip66 weather-proof ABS circular horn speaker

Mounting system

Power taps

Colour

Frequency response

U Bracket

30/15/7,5/3,75 Watt

Light Grey rAL 7035

330÷8.000 khz

Sensitivity 1W/1m 110dB

Maximum SPL 1m 124dB

Input voltage 100/70 Volt

Weight

Dimensions

2,1 kg

ø 238x287mm

SPEAKER SYSTEMS

SOUND COlUMN SPEAKERS

OUTDOOR SPEAKERS

Sound Design Project for Pasaron Stadium

Pontevedra - Spagna

65

EN 54 - 24

VERTUS DlA 1244A VERTUS DlA 804A VERTUS ClA

Digital Control aCtive line array Passive Column line array

• Perfect for the reproduction of high-quality speech/vocal application in reverberant environments, it can be used also for sound reinforcement as well as for fixed installations

• Possibility of stacking on a subwoofer from the MITUS range through the optional mounting accessory and of wall-mount installation with the supplied bars

• Standard white finish RAL 9016

• 16 x 50W RMS - 126dB SPL

• 2-way active column line array with digital beam steering technology

• 12 x 100mm (4”) full-range custom speakers with 25mm (1”) voice coil

• 4 x 25mm (1”) dome neodymium tweeter on waveguides

• Frequency response from 100Hz to 20kHz

• 16 x 50W RMS power amplifiers in Class D with switching mode power supply for a total of 800 W

RMS

• the 2 way system design allows a high-quality full-range reproduction of the musical signal

• 8 x 50W RMS - 123dB SPL

• Active column line array with digital beam steering technology

• 8 x 100mm (4”) full-range custom speakers with 25mm

(1”) voice coil

• Frequency response from 120Hz to 10kHz

• 8 x 50W RMS power amplifiers in Class D with switching mode power supply for a total power of 400 W RMS

• 500W 8ohm 123dB SPL

• 2-way passive column line array

• 6 x 100mm (4”) custom woofer with 25mm (1”) voice coil

• 4 x 25mm (1”) dome neodymium tweeter on a waveguide

• Frequency response from 130Hz to 20kHz

• 100V transformer with 2 levels of power, 100 and 200W

• 100°H x 20°V dispersion

• 4-pole Euroblock input connector: 8ohm - 100W/100V -

200W/100V

• Extruded-aluminum powdercoated cabinets

• Wall-mount installation bars are supplied

• Expandable line array by adding

CLA604 modules in order to increase SPL and reduce the vertical radiation lobe width

• Ideal for fixed installation in reverberant environments, it can improve both music and voice intelligibility by improving direct/reflected sound quality

66

Code

Configuration

Built-in amplifier cont. rms lF/HF

Built-in amplifier max. rms lF/HF

DlA 1244A

36187

16 way

16 x 40 W

16 x 50 W

DlA 804A

36186

8 way

8 x 40 W

8 x 50 W

Built-in amplifier max. peak lF/HF

16 x 100 W 8 x 100 W

Frequency response low frequency woofer

100Hz - 20KHz @-6dB

12 x 4 - 1 coil

High frequency driver

4 x 1 - 1 coil - neodymium

Maximum SPl cont/peak 123 / 126 dB

-

120Hz - 20KHz @-6dB

8 x 4 - 1 coil

120 / 123 dB

100° x Digital Controlled 100° x Digital Controlled

Dispersion HxV

Steering Angle

Beamwidth Angle

Input impedance

+30 / -30v

10 / 40v

22 kohm

Crossover frequency

3 kHz

AC Power requirements

650 va

+30 / -30v

10 / 40v

22 kohm

3 kHz

400 va

Input connectors

Power cord

euroblock with loop and suB out

5 / 16.4 mm/inch euroblock with loop and suB out

5 / 16.4 mm/inch

130x965x131 mm

5.11x38x5.15 inch

22 / 48,5 kg/lb

Net weight

Transport dimensions(WxHxD)

Transport weight

5 / 16.4 kg/lb

220x1760x220 mm

8.66x69.29x8.66 inch

13 / 28,6 kg/lb

220x1040x220 mm

8.66x40.94x8.66 inch

25 / 55 kg/lb

Code

Configuration

Recommended amplifier long term power

Short term power IEC 268-5

Transformer

Nominal impedance

Frequency response low frequency woofer

High frequency driver

Sensitivity (@1W/1m)

Maximum SPl cont/peak (Bi-Amp)

Dispersion HxV

Crossover frequency

Recommended HP filter

Input connectors

Net dimensions (WxHxD)

Net weight

Transport dimensions(WxHxD)

Transport weight

ClA 604

36145

2 way

500 W rms

250 W

1000 W

100 / 200 v/W

8 ohm

100Hz - 20KHz @-6dB

6 x 4 - 1 coil

4 x 1 - 1 coil - neodymium

93 dB

120 / 123 dB

100° x 20°

3 kHz

80hz - 24dboct

4 x euroblock

130x841x130 mm

5.12x33.1x5.12 inch

8/17,6 kg/lb

170x900x170 mm

6.7x35.4x6.7 inch

10/22 kg/lb

MSP 420 TW/EN

sounD ProJeCtors

EN 54 - 24

Aluminium alloy housing and hot galvanised steel front grille.

Due to its very sturdy and waterproof construction it is specially designed for industrial halls, warehouses, as well as open spaces exposed to outdoor weather conditions. Equipped with broadband loudspeaker to ensure excellent sound reproduction, adjustable sliding mounting bracket and a line transformer 100/70/50 V to set power output 20- 10-5 W. The

MSP 420 0TW/EN speakers include a thermal fuse which excludes the speaker in case of overheating and a flame resistant connecting cable (80 cm long).

SOP 412 T/EN

EN 54 - 24

sounD ProJeCtors

SOP 426 TB/EN

Thanks to use of excellent wide band speakers, the

SOP 412 T/EN and SOP 426 TB/EN

units prove to be suitable for both music and speech applications.

The speakers are enclosed in white cylindrical casings made of V0 self-extinguishing ABS

(UL94-V0) and equipped with adjustable swivelling bracket for easy installation, wall or ceiling.

Designed to achieve directional characteristic of sound emission they are mostly applied on circulation routes, corridors and in the wide areas.

Each models include a line transformer, a thermal fuse which excludes the speaker in case of overheating and a flame resistant connecting cable (80 cm long).

Code

Rated power

Adjustable power

Material

Speakers

Sound press.

SPl Pnom/1m

Sensivity 1W/1m

Frequency response

Dispersion angle @2kHz

Protection degree

Installation

Colour

Dimensions (W x H x D)

Weight

MSP 420 TW/EN

37734

20 W

20 / 10 / 5 W aluminium, galvanised steel front grill

1 broadband

103 dB

90 dB

150 ÷ 15.000 Hz

90° iP 65 adjustable brackets and fire resistant cable included silver, black grill

180 x 145 x 178 mm

2,4 kg

Code

Rated power

Adjustable power

Material

Speakers

Sound press.

SPl Pnom/1m

SOP 412 T/EN

37733

12 W

12 / 6 / 3 W aBs ul94-v0

1 broadband

99 dB

Sensivity 1W/1m

Frequency response

89 dB

Dispersion angle @2kHz 160°

Protection degree

180 ÷ 15.000 Hz iP 44

Installation

adjustable swivelling bracket and fire resistant cable included

Colour

white

Dimensions (W x H x D)

Ø 140 x 207 mm

Weight

1,4 kg

SOP 426 TB/EN

37732

6 W + 6 W

12 / 6 / 3 W aBs ul94-v0

2 broadband

96 dB

89 dB

170 ÷ 12.000 Hz

140° iP 44 adjustable swivelling bracket and fire resistant cable included white

Ø 140 x 207 mm

1,85 kg

67

WMS 406 T/EN

Wall-mounting sPeaKers

EN 54 - 24

WMS 406 T/EN speakers have been designed as surface or ceilingmounted units for a wide area of applications. Thanks to their steel casings the speakers are tough to vandals and more resistant to any and all mechanical damages. They are equipped with ceramic terminal block and thermal fuse that ensure continuous operations of sound transmitting line connected with the loudspeaker even in the case the latter is damaged or burnt as a result of fire.

WSP 406 T/EN

Wall-mounting sPeaKers

EN 54 - 24

The WSP 406 T/EN speakers, with elegant and discrete design, are specifically aimed at schools, hospitals, waiting rooms, hotels, where both music and speech have to be heard by customers.

Can be mounted in any position on a wall or ceiling. Selfextinguishing ABS (UL94-V0) body with metal front grille. Ceramic bloc

68

Code

Rated power

Adjustable power

Material

Speakers

Sound press. SPl Pnom/1m

Sensivity 1W/1m

Frequency response

Dispersion angle @2kHz

Installation

Color

Dimensions (W x H x D)

Weight

WMS 406 T/EN

37730

6 W

6 / 3 / 1,5 W metal

1 broadband

98 dB

91 dB

120 ÷ 15.000 Hz

130°

Wall and ceiling with screw white

210 x 190 x 70 mm

1,6 kg

Code

Rated power

Adjustable power

Material

Speakers

Sound press. SPl Pnom/1m

Sensivity 1W/1m

Frequency response

Dispersion angle @2kHz

Installation

Color

Dimensions (W x H x D)

Weight

WSP 406 T/EN

37729

6 W

6 / 3 / 1,5 W aBs ul94-v0, metal grille

1 broadband

96 dB

89 dB

150 ÷ 10.000 Hz

150°

Wall and ceiling with screw white

258 x 169 x 72 mm

0,8 kg

EN 54 - 24

CSP 406 T/EN

in-Ceiling sPeaKers

CSP 412 T/EN

EN 54 - 24

RWS 412 T/EN

FlusH-mounting Wall/Ceiling sPeaKers

The CSP 406 T/EN and CSP 412

T/EN speaker units, suitable for

mounting in false ceilings, ensure excellent reproduction of both speech and music. Made of stamped metal sheeting treated with white scratchproof and non-reflecting paint, they will fit elegantly into any environment.

Each unit consists of a loadbearing ring with quick-fitting hooks with springs for easy securing to the ceiling. The central mask with the loudspeaker cabled to the line transformer fits into the ring with a handy turning movement. According to the specification of the EN 54-24 voice evacuation system, this range of speakers has a double-galvanized steel flameproof cap, combined with ceramic input/output terminal strips, a thermal fuse and a ground termination. The built-in transformer enables connection to constant-voltage lines at 100,

70 and 50V with the adjustable outputs.

The ideal applications for RWS

412 T/EN speaker units are

in hospitals, hotels, offices, schools, shops and whenever flush-mounting with a discreet and elegant aesthetic impact is required. Made of selfextinguishing plastic material to UL94-V0 with a front metal grille, they are available with a line transformer. Ceramic block and temperature limit fuse are installed inside the loudspeaker.

A metal box for flush mounting enables easy and rapid wall or ceiling mounting.

Code

Rated power

Adjustable power

Material

Speakers

Sound press. SPl

Pnom/1m

Sensivity 1W/1m

CSP 406 T/EN

37727

6 W

6 / 3 / 1,5 W metal

1 dual cone broadband

99 dB

92 dB

Frequency response

100 ÷ 15.000 Hz

Dispersion angle @2kHz 150°

Mounting

Installation hole

Colour

spring fixing system

Ø 160 ÷ 165 mm

Dimensions (W x H x D) Ø 180 x 120 mm

Weight

white

1,5 kg

CSP 412 T/EN

37728

12 W

12/ 6 / 3 W metal

1 dual cone broadband

105 dB

95 dB

80 ÷ 20.000 Hz

130° spring fixing system

Ø 200 ÷ 205 mm white

Ø 220 x 140 mm

1,7 kg

Code

Rated power

Adjustable power

Material

Speakers

Sound press. SPl Pnom/1m

Sensivity 1W/1m

Frequency response

Dispersion angle @2kHz

Installation hole

Colour

Dimensions (W x H x D)

Weight

RWS 412 T/EN

37731

12 W

12 / 6 / 3 W aBs ul94-v0, metal grille

1 broadband

99 dB

89 dB

150 ÷ 15.000 Hz

120°

Box for flush mounting wall/ceiling white

165 x 280 x 90 mm

2 kg

69

MHO 420 TW/EN

Horn sPeaKers

EN 54 - 24

The MHO 420 TW/EN horn type speaker units are particularly well suited for outdoor use, even in difficult weather conditions.

They feature a watertight construction and a high level of weatherproofing.

The body is made of die-cast aluminium while the screws and brackets are made of stainless steel. The horn is made of aluminium sheeting. Each model has a line transformer and a rear switch for selecting the operating output (5 steps).

The MHO 420 TW/EN has been designed to be used in security installations and has a thermal fuse which excludes the speaker in case of overheating, a ground connector and a flame resistant connecting cable (80 cm long).

70

Code

Rated power

Adjustable power

Material

Speakers

Sound press. SPl Pnom/1m

Sensivity 1W/1m

Frequency response

Dispersion angle @2kHz

Protection degree

Installation

Colour

Dimensions (W x H x D)

Weight

MHO 420 TW/EN

37735

20 W

20 / 15 / 10 / 5 / 2.5 W aluminium

Complete with driver unit

123 dB

110 dB

160 ÷ 10.000 Hz

80° iP 65 adjustable brackets and fire resistant cable included light grey

Ø 213x230 mm

1,8 kg

STYlE A40 STYlE P80

all PurPose sPeaKer systems

STYlE S80

The new series of STYLE sound speakers combines high quality sound play with innovative design, creating a new concept and a catching look that are able to satisfy several architectural needs.

The sound speaker shall no more be hidden, with the risk of affecting the sound quality.

Instead, it will be integrated in the environment, combining form and function, acoustics and integration in the environment.

The nature itself has inspired this loudspeaker: in the nature the sound spreads to all directions, and, hence, we have developed a speaker that could reproduce a natural sound feeling. The sound diffusion in the nature is 360°, whereas in standard speakers its propagation is conic-shaped and, hence, has a narrow angle.

Thanks to the conic-shape of the diaphragm, STYLE sound speakers provide a 360° sound diffusion, reaching even the highest frequencies. The sound diffusion spreads to all directions, keeping the sound natural and accurate even when the volume is very high.

Thanks to this new technology you will immediately forget the geometric diffusion you are used to and you will be able to recreate a holographic and threedimensional sound effect in any environment.

Moreover, thanks to the material

Style speakers are made of and to the aluminium loudspeaker, they are suitable for outdoor mounting and resist to various weather conditions.

• 360° even sound diffusion

• Even sound diffusion over a wide frequency range (120 Hz ÷

20KHz) to all directions

• They can be powered using standard amplifiers

• The listening position is not bound by the orientation towards the axis

STYlE A40

• Perfect both for high-fidelity systems and for sound diffusion in environments such as train stations, airports, restaurants, shopping centres etc.

• Full end even sound energy pressure everywhere in the environment

• High sound efficiency

STYlE P80

• Excellent results with reference to the Larsen effect thanks to the sound energy that is reduced to one fourth towards the microphone

• Low intermodulation

• Low second harmonic distortion

• Classic modern design, perfect for any environment

STYlE S80

Customization is possible upon request

TR-20

Switching unit

Cod. 31011

STYlE A40 STYlE P80 STYlE S80

Code 31150 31151 31152

Type

System

Ceiling mounted one way system suspending mounted one way system

Wall hanging speaker one way system

Enclosure

Palstic flange

(Duroplast)

Colour

Driver equipment

White ral 9010 matte

Plastic flange

(Duroplast)

White ral 9010 matte

Plastic material

(PC+aBs+Duroplast Fenol)

White ral 9010 matte

1x FDs 100/40 alu sonus/newtec 1 x FDs 100/40 alu sonus/newtec 1x FDs 100/40 alu sonus/newtec

Nom. Imp. / DC Widerstand

8Ω / 6,2Ω 8Ω / 6,2Ω 8Ω / 6,2Ω

Nominal / Music Power

40 Watt rms / 90 Watt music power 80 Watt / 165 Watt 80 Watt / 165 Watt

Sensitivity ([email protected] 2,[email protected]) 86,4dB (+6dB auf 360°)

Maximum SPl

104dB (active high pass

120Hz/18dB - oktave)

86,4dB (+6dB auf 360°)

104dB (active high pass

86,4dB (+6dB auf 360°)

104dB (active high pass

Frequency response

Connectors

105 - 20.000 Hz (+/-3dB)

120 Hz / 18dB - oktave)

105 - 20.000 Hz (+/-3dB)

120 Hz / 18dB - oktave)

100 - 20.000 Hz (+/-3dB)

Press-terminal Press-terminal screw-terminal

Net weight (only the loutspeaker) 470gr 830gr 1160gr

Gross weight ( inc. Package) 720gr 1170gr 1530gr

Dimensions

ø 180x15mm ø 134x135mm + cab. stand. lenght 1mt - ø 134x130x220mm installation depth 35mm Deckendose (Baldachin) Höhe 72mm, ø60

Accessories

Nominal Power 100V

TR-20 Code 31011

100volt / 2000Ω - 250Ω

2,5-5-10-20 Watt

TR-20 Code 31011

Deckendose (Baldachin) Höhe transformer 5 pole print-terminal transformer 5 pole print-terminal

100volt / 2000Ω - 250Ω

2,5-5-10-20 Watt

TR-20 Code 31011

100volt / 2000Ω - 250Ω

2,5-5-10-20 Watt

71

143 162

PROJECT 315

SPEAKER SYSTEMS

PROJECT 320

White RAL 9016 or black RAL 9005

ABS speaker

• Bracket included

• 2 way bass reflex

• 3.5” woofer and 0.5” tweeter

• 100V line transformer (Multi taps)

• Frequency response @-10dB is

100Hz-15kHz

• Dispersion HxV 120°x120°

• High-pass filter recommended

70Hz-24dB/oct

• 8-piece multiple packing

• 15W/30W nominal/maximum power

• Setting 2/4/7.5/15W/8ohm

• Sensitivity 85dB

• Max SPL 100dB

White RAL 9016 or black RAL 9005

ABS speaker

It has the same characteristics as the 315 version, with the following features:

• 20W/40W nominal/maximum power

• Setting 4/8/15/20W/8ohm

• Sensitivity 87dB

• Max SPL 103db

Project 315 WHT

Project 320 WHT

Project 315 BT

Project 320 BT

72

Wall bracket manufactured from die-cast aluminium with ball/socket multi angle adjustment capability and steel security cable.

Code

Configuration

Recommended amplifier

Project 315 BT / WHT

29350 / 32372

2 way

30W rms

Long term power

Short term power

15W

60W

Line transformer (100V) 1-2-4-7,5-15W

Nominal impedance

Sensitivity (@1W,1m)

Max. Spl

Dispersion

Recommended hp filter

85dB

100dB

120x120 HxV

70Hz-24dB/oct

Input connector Euroblock

Dimensions

(WxHxD)

143x204x162mm

Project 320 BT / WHT

29221 / 32367

2 way

40W rms

20W

80W

4-8-15-20W

8ohm

Frequency response @-10dB

Low frequency woofer

8ohm

100Hz-15kHz

88mm

100Hz-20kHz

88mm

Tweeter 13mm 13mm

87dB

103dB

120x120 HxV

70Hz-24dB/oct

Euroblock

143x204x162mm

168 180

PROJECT 530

SPEAKER SYSTEMS

PROJECT 550

White RAL 9016 or black RAL 9005

ABS speaker

• Bracket included

• White or black ABS speaker

• 2 way bass reflex

• 5” woofer and 0.75” tweeter

• 100V line transformer(Multi Taps)

• Frequency response @-10dB

85Hz-20kHz

• Dispersion HxV 100°x100°

• High-pass filter recommended

55Hz-24dB/oct

• 30W/60W nominal/maximum power

• Setting 10/15/20/30W/8ohm

• Sensitivity 87.5dB

• Max SPL 106dB

White RAL 9016 or black RAL 9005

ABS speaker

It has the same characteristics as the 530 version, with the following differing features:

• 50W/100W nominal/maximum power

• Setting 15/25/40/50W/8ohm

• Sensitivity 89dB

• Max SPL 109Db

Project 315 BT

Project 320 BT

Wall bracket manufactured from die-cast aluminium with ball/socket multi angle adjustment capability and steel security cable.

Code

Configuration

Recommended amplifier

Long term power

Short term power

Line transformer (100V)

Nominal impedance

Frequency response @-10dB

Low frequency woofer

Tweeter

Sensitivity (@1W,1m)

Max. Spl

Dispersion

Recommended hp filter

Input connector

Dimensions (WxHxD)

Project 530 BT / WHT

29223 / 32368

2 way

60W rms

30W

120W

10-15-20-30W

8ohm

85Hz-20kHz

130mm

20mm

87,5dB

106dB

100x100 HxV

55Hz-24dB/oct

Euroblock

168x240x180mm

Project 530 WHT

Project 530 WHT

Project 550 BT / WHT

29225 / 32369

2 way

100W rms

50W

200W

15-25-40-50W

8ohm

80Hz-20kHz

130mm

25mm

89dB

109dB

100x100 HxV

50Hz-24dB/oct

Euroblock

168x240x180mm

Project 550 BT

Project 550 BT

73

218 219

PROJECT 640

COMPACT ABS SPEAKER SYSTEM

PROJECT 660

Black RAL 9005 or White RAL 9016

ABS loudspeaker

• Bracket included

• 2 way bass reflex

• 6.5” woofer and 1” tweeter

• 100V line transformer(multi Tapp)

• Frequency response @-10dB

70Hz-20kHz

• Dispersion HxV 90°x90°

• High-pass filter recommended

40Hz-24dB/oct

• 4-piece multiple packing

• 40W/80W nominal/maximum power

• Setting 10/20/30/40/8ohm

• Sensitivity 89dB

• Max SPL 108dB

Black RAL 9005 or White RAL 9016

ABS loudspeaker

It has the same characteristics as the 640 version, with the following differing features:

• 60W/120W nominal/maximum power

• Setting 15/30/45/60W/8ohm

• Sensitivity 90dB

• Max SPL 111dB

Project 640 WHT

Project 660 WHT

Project 640 BT

Project 660 BT

74

Wall bracket manufactured from die-cast aluminium with ball/socket multi angle adjustment capability and steel security cable.

Code

Configuration

Recommended amplifier

Project 640 BT / WHT

29227 / 32370

2 way

80W rms

Long term power

Short term power

40W

160W

Line transformer (100V) 10-20-30-40W

Nominal impedance

Project 660 BT / WHT

29229 / 32371

2 way

120W rms

60W

240W

15-30-45-60W

8ohm 8ohm

Frequency response @-10dB 70Hz-20kHz

Low frequency woofer 165mm

70Hz-20kHz

165mm

Tweeter 25mm 25mm

Sensitivity (@1W,1m) 89dB 90dB

Max. Spl 108dB 111dB

Dispersion

90x90 HxV

Recommended hp filter 40Hz-24dB/oct

Input connector Euroblock

Dimensions (WxHxD) 218x312x219mm

90x90 HxV

40Hz-24dB/oct

Euroblock

218x312x219mm

360mm

prOJeCt sub 1180a

amplified subwoofer

amplified subwoofer

• Black colour wooden construction

• 1 way bass reflex

• 180W rms internal amplifier

• Frequency response

@-10dB 28Hz-180Hz

• Sensitivity 90dB

• Max SPL 112dB

• Dispersion HxV omnidirectional

• RCA input and output connector

• Crossover frequency and volume control

project sub 1180a

Code 29351

Configuration

Internal amplifier

Frequency response @-10dB

Low frequency woofer

sensitivity (@1W,1m) 90db

max. spl 112db

Dispersion omnidirectional

Input connector

power consumption

1 way

180w rms

28Hz-180kHz

250mm

2 x rCa

200Va

Dimensions (WxHxD) 360x450x360mm

75

STUDIO.PRO 9 STUDIO.PRO 9 T

aBs 2-Way sPeaKer system

STUDIO.PRO 9 A

Cabinet speakers

• Extremely light and sturdy enclosure made of gas injection moulded polypropylene, black (STUDIO.

PRO 9B) or RAL 7035 grey colour

(STUDIO.PRO 9W), stand adapter,

2 M6 anchoring points

• 2-way bass-reflex system with

130mm woofer and 25mm high frequency tweeter

• Power 120 Watt

• Frequency response 80Hz-20 kHz

• Sensitivity 95.5dB 1W/1m Maximum

SPL 116.5dB

• Dispersion (HxV) 90°x60°

• SUB-D input connectors

Cabinet speakers

Same characteristics as the

STUDIO.PRO 9B/W models except for the following:

• Power 80W

• 70-100V 4-position line transformers: 5W/20W/45W/80W

• Sensitivity 95.5dB 1W/1m

Maximum SPL 114.5dB

Cabinet speakers

Same characteristics as the STUDIO.

PRO 9B/W models except for the following:

• 80W RMS internal amplifiers for the woofer and 20W RMS for the driver

• ADAP® (Advanced Dynamic

Active Protection) designed to limit amplifier saturation and ensure complete reliability of the system even in extreme conditions; 24dB/ oct active filters

• Frequency response 70Hz-20 kHz

• Sensitivity 95dB 1W/1m

• Maximum SPL 115dB

• Control panel with Ground Lift,

Combo XLR/JACK inputs, XLR male output, limiter, volume control

76

SJ 9 B/W

SJ 9 UB/UW

Adjustable wall support

Model Code Colour

SJ 9 B 19706

SJ 9 W 19705

black ral 7035 grey

Wall mounting brackets

Model Code Colour

SJ 9 UB 19708

black

SJ 9 UW 19707

ral 7035 grey

ST 20 B

Adjustable floor stand

Code 19710

adjustable metal floor stand, with safety locking device, max weigh 55 kg

Code

Colour

Configuration

STUDIO.PRO 9 B/W

19678 / 19677

black - ral 7035 grey

Recommended amplifier

Internal amplifier

2 way

120W rms

-

long term power (AES) 60W

Short term power (IEC 268-5) 240W nominal impedance 8ohm

STUDIO.PRO 9 BT/WT

19680 / 19679

black - ral 7035 grey

2 way

80W rms

-

-

-

-

-

-

-

-

STUDIO.PRO 9 BA

19681

black

2 way

80W + 20W

line transformer -

Frequency response (@-6dB) 80Hz - 20kHz

low frequency woofer

ø 38 mm coil

High frequency woofer

ø 20 mm coil

70v-100v

80Hz - 20kHz

ø 38 mm coil

ø 20 mm coil

-

70Hz - 20kHz

ø 38 mm coil

ø 20 mm coil

Sensitivity 1W/1m

Max. SPl 1m 116,5dB 114,5dB 115dB

Dispersion

Crossover frequency

Recommended hp filter

Input connectors

90°x60° Hxv

3,5 kHz

60Hz 24dB oct spring terminals

Weight

4,8 kg

Dimensions (WxHxD)

90°x60° Hxv

3,5 kHz

60Hz 24dB oct spring terminals

4,8 kg

-

90°x60° Hxv

2,5 kHz

Combo Xlr-m/JaCK

5,4 Kg

255x415x245mm 255x415x245mm 255x415x245mm

STUDIO.PRO 14 STUDIO.PRO 14BA

aBs 2-Way sPeaKer system

Cabinet speakers

• Extremely light and sturdy enclosure made of gas injection moulded polypropylene, black colour, integral handle

• Stand adapter, 2 M6 anchoring points

• 2-way bass-reflex system with

320mm woofer and 25mm high frequency tweeter

• Built-in class G amplifiers 150W

RMS for the woofer and 50W

RMS for the high frequency unit;

ADAP (Advance Dynamic Active

Protection) designed to limit amplifier saturation and ensure complete reliability of the system even in extreme conditions

(STUDIO.PRO 14BA)

• 24dB/oct active filters

(STUDIO.PRO 14BA)

• Power 250 Watt

• Impedance 8 Ohm

• Frequency response

60Hz-20 kHz

• Sensitivity 98dB 1W/1m

• Maximum SPL 122/125dB

(STUDIO.PRO 14B) 121dB

(STUDIO.PRO 14BA)

• Dispersion (HxV) 90°x60°

• 2 speakon input connectors

• Control panel with Ground Lift switch, Combo XLR/JACK inputs,

XLR male output, limiter, volume control (STUDIO.PRO 14BA)

SJ 14 UB

ST 30 B

ST 40 B

Wall mounting brackets

Model Code Colour

SJ 14 UB 19709

Adjustable floor stand

Adjustable floor stand

Code 18240

adjustable, metal floor stand, with safety locking device black

Code 18239

adjustable, aluminium floor stand, with safety locking device

Code

Configuration

Recommended amplifier

STUDIO.PRO 14B

2 way

250W rms

Internal amplifier

-

long term power (AES) 125W

Short term power (IEC 268-5) 500W

Nominal impedance 8ohm

Frequency response (@-6dB) 60Hz - 20kHz

low frequency woofer 1x320

ø 51 mm coil

-

-

-

-

STUDIO.PRO 14BA

19682 19683

2 way

150W+50W rms

60Hz - 20kHz

1x320

ø 51 mm coil

High frequency woofer 1x25.4+horn

ø 25.4 mm coil

Sensitivity 1W/1m 98dB

1x25.4+horn

ø 25.4 mm coil

98dB

Maximum SPl 1m 122/125dB 121dB

Dispersion 90°x60° Hxv 90°x60° Hxv

2,5 kHz 2 kHz Crossover frequency

Recommended hp filter

Input connectors

Weight

40Hz 24dB oct

2xspeakon

13,5 kg

40Hz 24dB oct

Combo Xlr/JaCK

16 kg

Dimensions (WxHxD) 410x663x387mm 410x663x387mm

77

ARCHON 108 ARCHON 106

Permanent installation sPeaKer system

• 2-way, passive sound reinforcement systems

• 12mm (0.47”) baltic birch plywood cabinets

• Custom designed LF woofers, made in Italy

• Custom designed HF dome tweeter, Made in Italy

• Crossover networks equipped with 4 x Euroblock speaker terminals; factory preset for optimal line transformer installation

• Multiple M5 threaded rigging points

• Acoustically transparent steel grille and antidust protection cloth

• New FBT rotatable logo badge following vertical or horizontal installation

• Optional mounting hardware

• Optional line transformer (100W for Archon 108 and 106, 50W for

Archon 105)

• Passive Sound Reinforcement

350W / 8 ohm - 121dB SPL

• 1 x 8” (1.5” VC) custom made LF woofer with rubber surround

• 1 x 1.5” HF high-end dome tweeter

• 8 x M5 threaded rigging points

• Passive Sound Reinforcement

300W / 8 ohm - 119dB SPL

• 1 x 6.5” (1.5” VC) custom made

LF woofer with rubber surround

• 1 x 1” HF dome tweeter

• 6 x M5 threaded rigging points

78

AC-W 568

Code 36987

Directional wall metal bracket black for archon 106

AC-W 568W

Code 37330

Directional wall metal bracket white for archon 106

Code

Configuration

ARCHON 108

36252

2 way

Recommended amplifier

350 W rms

System long term power

175 W

700 W

100 / 100 v/W optional

System Short term power IEC 268-5

Transformer

Nominal impedance

Frequency response low frequency woofer

AES power

High frequency driver

AES power

Sensitivity (@1W/1m)

Maximum SPl cont/peak (Bi-Amp)

Dispersion HXV

Crossover frequency

Recommended HP filter

Input connectors

Net dimensions (WxHxD)

Net weight

Transport dimensions(WxHxD)

Transport weight

8 ohm

55Hz - 22KHz @-6dB

8 - 1.5 coil

150 W

1.5 - 1.5 coil dome

35 W

92.5 dB

118 / 121 dB

90°

2 kHz

40hz - 24dboct

4 x euroblock 0-8-100v (low-high)

248x411x248mm

6,5/14,3 kg/lb

330x491x330mm

8,5/18,7 kg/lb

ARCHON 106

36251

2 way

300 W rms

150 W

600 W

100 / 100 v/W optional

8 ohm

60Hz - 22KHz @-6dB

6.5 - 1.5 coil

120 W

1 - 1 coil dome

20 W

91 dB

116 / 119 dB

100°

2.5 kHz

45hz - 24dboct

300x440x300 mm

7,5/16,5 kg/lb

18/39,6 kg/lb

690x370x625mm

20/44 kg/lb

ARCHON 105 ARCHON 208S

Permanent installation sPeaKer system

• Passive Sound Reinforcement

200W / 8 ohm - 115dB SPL

• 1 x 5” (1.25” VC) custom made

LF woofer with rubber surround

• 1 x 1” HF dome tweeter

• 4 x M5 threaded rigging points

• Passive Sound Reinforcement

Subwoofer

600W / 8ohm 132dB SPL

• 2 x 8” (2” VC) custom made high excursion woofer with bassreflex enclosure

• 15mm (5/8) birch plywood enclosure

• Two pocket handles

• 2 x Speakon NL-4 connectors

AC-W 568

Code 36987

Directional wall metal bracket black for archon 105

AC-W 568W

Code 37330

Directional wall metal bracket white for archon 105

Code

Configuration

ARCHON 105

36250

2 way

Recommended amplifier

200 W rms

System long term power

100 W

400 W

100 / 50 v/W optional

System Short term power IEC 268-5

Transformer

Nominal impedance

Frequency response low frequency woofer

AES power

High frequency driver

AES power

Sensitivity (@1W/1m)

Maximum SPl cont/peak (Bi-Amp)

Dispersion HXV

Crossover frequency

Recommended HP filter

Recommended external filter

Input connectors

Net dimensions (WxHxD)

Net weight

Transport dimensions(WxHxD)

Transport weight

-

8 ohm

70Hz - 22KHz @-6dB

5 - 1.25 coil

70 W

1 - 1 coil dome

20 W

89 dB

112 / 115 dB

110°

3 kHz

60hz - 24dboct

4 x euroblock 0-8-100v (low-high)

180x300x180 mm

4/8,8 kg/lb

260x380x260 mm

6/13.2 kg/lb

ARCHON 208S

36256

1 way

600 W rms

300 W

-

1200 W

8 ohm

50Hz - 500Hz @-6dB

2 x 8 - 2 coil

150 W

-

-

95 dB

129/132 dB half space omni external active

40hz - 24dboct

Digital management with presets

2 x speakon nl4 in & thru

550x285x480mm

18/39,6 kg/lb

690x370x625mm

20/44 kg/lb

79

CS3130/TW CS3150/TW

tWo-Way Column sPeaKers

CS3180/TW

Column speaker with aluminium body

• Power 30 Watt RMS with

100V transformer and 7.5/15/30W power selection

• Frequency response

200Hz-16kHz

• Sensitivity 91dB

• Maximum SPL 106dB

• 4x2” speakers + 1x1” tweeter

• Horizontal dispersion (-6dB)

1kHz/4kHz 180°/120°

Column speaker with aluminium body

• Power 50 Watt RMS with

100V transformer and

12,5/25/50W power selection

• Frequency response

200Hz-16kHz

• Sensitivity 94dB

• Maximum SPL 110dB

• 10x2” speakers + 1x1” tweeter

• Horizontal dispersion (-6dB)

1kHz/4kHz 180°/120°

Column speaker with aluminium body

• Power 80 Watt RMS with

100V transformer and 20/40/80W power selection

• Frequency response

200Hz-15kHz

• Sensitivity 96dB

• Maximum SPL 114dB

• 14x2” speakers + 1x1” tweeter

• Horizontal dispersion (-6dB)

1kHz/4kHz 180°/120°

80

65 65 65

SC A2

Wall fastening bracket

Code 20130

CS3130/TW CS3150/TW CS3180/TW

CS3130/TW CS3150/TW CS3180/TW

Code 37922 37923 37924

Power taps 7,5-15-30W - 100v 12,5-25-50W - 100v 20-40-80W - 100v

91dB 94dB 96dB

Frequency response 200÷16.000Hz

200 ÷ 16.000Hz 200 ÷ 15.000Hz

(± 6dB)

Speakers

Cabinet

Weight n° 4 x 2” + 1x1”

1,94 Kg n° 10 x 2”+ 1x1” n° 14 x 2”+ 1x1” aluminium aluminium aluminium

3,4 Kg

Dimensions (WxHxD) 65x285x65 mm 65x708x65mm

4,63 Kg

65x924x65mm

WEATHER PROOF

SPEAKERS

81

SHADOW 112CT SHADOW 108CT

all WeatHer sPeaKers

SHADOW 105T

4 wires cable to select the desired power tapping

Water-stop grill with 3 layers of protection

IP55 weather resistant

Standard grey finish RAL 7011

• Multipurpose High

Performance 12” Coax

600W/8ohm - 128dB SPL

• 12” coaxial woofer with 2.5” coil and 1” HF driver with 1.7” coil on conical 90° horn

• 100V line transformer with selectable 200W/100W power tapping

• Sturdy molded polyethylene curved enclosure

• Multipurpose 8” Coax

450W/8ohm - 124dB SPL

• 8” coaxial woofer with 2” coil and 1” HF driver with 1.4” coil on conical 90° horn

• 100V line transformer with selectable100W/50W power tapping

• Sturdy molded polyethylene curved enclosure

• Steel U bracket and other included hardware accessories

• Multipurpose 5” Full Range

120W/8ohm - 112dB SPL

• 2 way configuration with an high power 5” cone and 1” dome for high frequencies

• 100V line transformer with selectable 50W/25W power tapping

• Die-cast aluminum wall bracket with ball/socket for multi angle adjustment capability, with a security cable

82

Code

Configuration

SHADOW 112CT

Recommended amplifier (Biamp lF/HF) 600 W rms

System long term power (Biamp lF/HF) 300 W

System Short term power IEC 268-5

(Biamp lF/HF)

36194

2 way

1200 W

Transformer

100 / 200 v/W

Nominal impedance (Biamp lF / HF) 8 ohm

Frequency response low frequency woofer

70Hz - 20KHz @-6dB

12 - 2.5 coil

AES power

High frequency driver

250 W

1 - 1.7 coil

AES power

50 W

Sensitivity (@1W/1m) (Biamp lF/HF) 98 dB

124 / 128 dB

Maximum SPl cont/peak

Dispersion HxV

Crossover frequency

Recommended HP filter

Input connectors

Net dimensions (WxHxD)

Net weight

Transport dimensions(WxHxD)

Transport weight

90° conical

1.6 kHz

50hz - 24dboct

4 wire cable

430x430x400mm

15 / 33 kg/lb

530x530x500mm

17/37 kg/lb

SHADOW 108CT

36193

2 way

450 W rms

225 W

900 W

100 / 100 v/W

8 ohm

80Hz - 20KHz @-6dB

8 - 2 coil

200 W

1 - 1.4 coil

25 W

95 dB

120 / 124 dB

90° conical

1.8 kHz

60hz - 24dboct

4 wire cable

285x285x250mm

7 / 15,4 kg/lb

365x365x330mm

9/19,8 kg/lb

SHADOW 105T

36192

2 way

120 W rms

60 W

240 W

100 / 50 v/W

8 ohm

90Hz - 20KHz @-6dB

5 - 1 coil

50 W

1 - dome

10 W

89 dB

109 / 112 dB

100°

3 kHz

70hz - 24dboct

7 wire cable

168x222x200mm

3,5 / 7,7 kg/lb

250x300x280mm

4,5/9,9 kg/lb

430

GDS 200T/DT

garDen sounD sPeaKers

Weather-proof sound speaker

• Dual cone two way loudspeaker

• Polyurethane framework

• 8” diameter

• Polypropylene diaphragm

• Rubber suspension

• ø 25,5mm coil

• ø 100mm coil ferrite magnet

• 8 ohm impedance

• 40 Hz - 18.000 Hz passband

• 90dB +/- 2dB sensitivity (1W/1m)

• Size 430x295x300mm

• Weight 3.6 kg

GS 20/T

garDen sounD sPeaKers

Weather-proof sound speaker

• Guaranteed to resist to difficult weather conditions

• It can be placed near pools, on terraces or in gardens

• This versatile speaker can be mounted on the surface or underground

• Speaker’s base has been designed to guarantee a firm and safe positioning

• Offers extraordinary coverage thanks to its design, enabling a

360° sound dispersion

• 80Hz-15,000Hz frequency response

• 85dB+/-3dB sensitivity

• 100V Transformer

• 4” Woofer

• ABS, green coloured

• Diameter 215x245mm

• Net weight 2.1Kg

GDS 200T/DT

Code 20010

System 2 way dual cone

IP-rating 55

75/150W (8ohms)

Power handling

Power taps

Transformer

SPl Sensitivity

Dimensions (WxHxD) 430x295x300mm

Weight

30/20/10W (8ohms)

100 v

Frequency Response 40-18.000Hz

90 +/- 2dB (1W/1m)

3,6 kg

GS 20/T

Code 29432

System 1 way dual cone

IP-rating weather-proof

Power taps 20/10W

Sensitivity 95dB+/-3dB

Transformer 100v

Woofer 4”

Colour

Dimensions

Weight green in aBs

ø 215x245mm

2,1 kg

83

84

FBT: EXCEllENCE WITH A

VAST SElECTION

FBT offers a vast and comprehensive range of speakers to meet all sound requirements and applications. Specifically designed to enable simple and safe installation, with a modern and eye-catching design, these products are the ideal choice to solve all ambient sound distribution requirements.

All product lines, from recessed ceiling speakers in paint-finished metal or in plastic with dual cone or coaxial speakers, speakers constructed using fireresistant materials, IP

55-56-68 weatherproof elements, speakers designed for clean rooms or special production departments, to the industrial or entertainment sound models, have been designed according to the latest electro-acoustical parameters.

The result is absolute excellence; perfect music reproduction and optimal voice clarity and speech fidelity. Special attention has been paid to the simplification and reduction in time required for installation and network connections of the power cables, thanks to a special accessory kit supplied as standard. response and uniform sound pressure to give optimum listening pleasure and clarity. To meet these requirements, the hypothetical ideal solution would be to place each sound source at an equal distance from all possible listening points.

The basic principles of effective surface mount ceiling loudspeaker installation

The first priority of a high quality sound reproduction system is that of providing listeners with sound information at an acoustic level that is higher than any possible background noise. The system must simultaneously assure a very wide frequency band and the maximum intelligibility. It should also guarantee a flat frequency

CEIlING APPlICATION

In environments offering suitable height, this ideal reference standard can be approximated by using speakers with very wide response and dispersion angles that remain unchanged at different frequencies, arranged in a ceiling or shower type configuration.

This gives the following benefits:

1- Maximum sound distribution uniformity

2- Maximum speech intelligibility

3- Constant quality of music reproduction

4- Reduced presence of reverberation and stationary waves in the environment

5- Sound source remains at a constant distance from the listening position

6- Ample sound energy also at the lowest level

Once the required type of loudspeaker has been chosen, and the characteristic parameters considered (particularly the relationship between the dispersion angle and the room surface area), the number of units needed to obtain constant and uniform sound diffusion can be easily calculated.

The number of speakers is calculated by dividing the floor area in square metres by the area of coverage of each loudspeaker on the listening plane. Figure

1 clearly illustrates the above concept.

WAll APPlICATIONS

If the architectural

figure 1 figure 2 figure 3

features of the room are not compatible with a ceiling configuration or if a “wall” application is preferred, it is essential to observe a few basic rules to obtain the best possible sound distribution. In order to maintain the listening point inside the direct signal area, both surface mounted and external speakers, with power from 6 to 20 Watt, should be installed at a height of between 2 and 2.5 m. The maximum distance between adjacent speakers must be no more than 5/6 metres along the length of the room, which should be no wider than

4/5 metres. For wider rooms, e.g. about 8-10 metres, it is recommended to install speakers in an alternated pattern along both the opposing walls in such a way as to provide adequate coverage and maintain sound pressure at the most constant possible level in the area in question (see figures 2 and 3).

A quick and approximate

calculation can be made

of distance d, which separates the centres of two speakers, when the angle of emission A and height of the ceiling H is known: d=2*(H-1)*B where H is the height of the ceiling expressed in metres, constant 1 is the height of the listening surface of a seated person and B is the tangent of A/2.

From the above data, it is evident that for the same ceiling height H, speakers with wider dispersion angles offer a larger sound diffusion area and therefore a smaller number of speakers are effectively needed.

figure 4

layout of speakers for 80% coverage

figure 5

layout of speakers for 100% coverage

Figure 4 shows the surface area covered by the sound signal with relative dark zones, and figure 5 with a different grid and greater number of speakers (50%) guarantees maximum uniformity.

Angle of

emission

Coefficient d with d with d with d with loudspeaker B H=3m H=3.5m H=4m H=4.5m

80 0,84 3,36 4,2 5,04 5,88

100

110

1,19

1,43

4,76

5,72

5,95

7,15

7,14

8,58

8,33

10,01

120 1,73 6,92 8,65 10,38 12,11

130 2,14 8,56 10,7 12,84 14,98

For sound distribution in corridors, tunnels, passenger platforms in railway or underground railway stations, horn speakers are used, suited for vocal reproduction, and higher quality speakers called “sound projectors”.

In all cases these speakers must be installed at a maximum distance of 15 metres from one another, mounted all in the same direction and in observance of the phase of each loudspeaker.

Alternatively bi-directional versions of these speakers can be considered, positioned at max. 30 metres from one another and again in observance of the connection phase. (see figure 6)

DEGREES OF PROTECTION

The characteristics of a product in terms of its resistance to the penetration of solid objects and liquids is indicated by the letters IP

(International Protection) followed by two numbers.

The first number identifies the protection against the ingress of solid objects, while the second indicates liquid penetration resistance, in accordance with EN standards 60529-

CEI 70-1.

IP degree of protection

• The first number identifies the level of protection against the ingress of solid objects.

Number from 0 to 6.

• The second number identifies the level of protection against penetration of liquids.

Number from 0 to 8.

First IP number:

0 Not protected

1 Protected against the ingress of solid objects larger than 50 mm

2 Protected against the ingress of solid objects larger than 12 mm

3 Protected against the ingress of solid objects larger than 2.5 mm

4 Protected against the ingress of solid objects larger than 1 mm

5 Protected against dust penetration

6 Totally dust-proof

Second IP number:

0 Not protected

1 Protected against vertically dripping water

2 Protected against water dripping at an angle (up to 15° from the vertical)

3 Protected against rain

4 Protected against water spray

5 Protected against water jets

6 Protected against waves

7 Protected against the effects of temporary immersion

8 Protected against the effects of permanent immersion

Constant impedance lines are used above all in the case of a low number of speakers, placed at a minimum distance from the amplifier (<20m).

The constant voltage connection system offers a host of advantages making it ideal for sound systems of all sizes, above all in the case of long distances.

This connection system

figure 6

requires each loudspeaker to be equipped with its own line transformer, which adapts the impedance of the loudspeaker (usually very low) to the much higher level of the line itself.

In proportion to power transmitted, the current circulating on a line at 100V is considerably lower than that circulating on wires of a constant impedance system, and consequently drops along the line are less frequent; therefore the cable section can be smaller.

The function of the device named “AMPlIFIER” is

to raise the signal of a

sound source, such as a

microphone, CD player, cassette recorder or an

AM/FM tuner to a sufficient

level to pilot the transducer

“lOUDSPEAKER”.

The amplifier has several

inputs, to which the various sound sources are connected.

The sound sources have to be mixed (mixer) and acoustically modified with tone control and equalisers to optimise listening in relation to the environment’s characteristics. A terminal board is also fitted on output indicating impedance and voltage to which the loudspeaker line is connected.

A few basic rules must always be observed:

1. When the load is on

“constant impedance”, this must be connected to the relative socket.

For example a load of 4 ohm must be connected to socket marked 4 ohm, and so on. The power that the load can withstand must always be greater than the amplifier’s rated power.

For example in the case

of a load of 100 Watt, the amplifier must have a power equal to or less than 100 Watt.

2. When the load is at

“constant voltage”, this must be connected to the sockets indicating output at constant voltage -50-70 or 100

Volt; the power that the load can withstand must always be less than or equal to the amplifier rated power. For example a load of 100

Watt, the amplifier must have a power equal to or greater than 100 Watt.

To calculate the value of the amplifier power, simply add together the power of each loudspeaker, in the case of a “constant voltage” system.

However, on a constant impedance system, the load must have an equivalent impedance

(series/parallel) equal to or greater than the minimum value indicated on the amplifier output.

The loudspeaker power supply lines, with no connected attenuator, must be with 2 sheathed wires; cables with 3 sheathed wires are required in the case of lines using attenuators which can be disabled if an emergency is activated. Adequate wire sections are required: 1.5 mm2 for lines up to 500

Watt power

2.5 mm2 for lines with power over 500Watt. The following general standards must also be observed:

• Never use a single cable

(lead) for loudspeaker connections: this would cause disturbance producing a loud “HUM”

• Never use shielded cables for the loudspeaker connections: this would cause serious damage to the power units.

85

86

Model Code

CS 3060/T

CSl 106/T

CSl 520 TIC

CSl 606 TWP

CSl 630 TIC

CSl 840 TIC

CSP 406 T/EN

CSP 412 T/EN

CUD4000

CUW4000

CV 2010

D8P-1

DG 01

DP 10 T

DPD 10 T

DPU 1125 C

DPU 1250 C

DPU 1500 C

EAC4000

FBT AC CS 1CH

FBT AC CS 1CU

FBT AC CS 1DU

FBT AC D7P-10

FBT AC D7P-20

FBT AC D7PDH-1

FBT AC EXM-1

FBT AC EXS-1

FBT AC MX-8

FBTAC CM 501

FBTAC CX 504

FBTAC GM 5206l

FBTAC GM 5212l

FBTAC GM 5218l

FBTAC Mh 750

FBTAC Mh 920

FBTAC PT 850B

FBTAC ST 5050

FBTAC ST 850

FBTAC US 8001 D

BF-T 5043 l

BK 560 CRT

CAD 20 T

CAR 6 FT

CESl 10T

CESl 10T BIDI

CESl 20T

CHA 1004

CM 08

CM 12

CM 18

CM 22

CM 26

CM 601

CS 3030/T

CS 3040/T

AC-W568

AC-W568W

Al 8000

AM 5030

AP 08

AP 12

AP 18

AP 22

AP 26

AQUA 30

ARCHON 105

ARCHON 106

ARCHON 108

ARCHON 208S

ASG 230

AVl 606

37650

37646

37647

37645

27497

27498

27515

27514

37725

37726

34556

27511

27510

27512

37648

37649

27513

27494

27496

27495

27499

27500

27493

34554

34555

35541

37936

12114

09352

11818

37724

20129

29427

29416

29429

29417

29418

37727

37728

12682

12681

12385

11827

12669

27516

20128

20131

18322

09309

11469

11956

29420

29429

29421

37711

12668

10436

36250

36251

36252

36256

11864

14142

37987

37330

17074

11583

12897

12898

12667

12178 page

34

34

28

28

22

23

23

36

22

22

22

22

11

11

19

22

29

29

34

28

34

34

34

44

60

60

11

19

19

32

36

59

59

69

69

80

58

58

59

43

28

80

80

43

43

43

43

62

62

62

11

30

56

61

60

78

79

27

33

43

56

79

78

78-79

78-79

31

47

43

43

43

43

Model Code

MD-S 1100

MDS 1120

MDS 1240

MD-S 1300

MDS 6120

MDS 6240

MHO 420 TW/EN

MHS 50T

MMU4000

MMZ 8004 S

MPA 5120

MPA 5240

MPA 5480

MPS1016

MPU 2120

MPU 4060

MPU 4120

MPU 4240

MRK 12

MRK 20

MRK 24

MRK 30

MRK 36

MS 30 BK

MS02 CD3/DG

MS02 CD3/T

MSP 420 TW/EN

MXA 1060

MXA 1120

MXA 3120

MXA 3240

MZU 2008

PA-A 01

PC 01

PC 02

PC 03

PH 10 T

PH 20 T

PH 30 T

FBTAC US 902 D

FMD 2001

FMD 2012

FMG 2000

FMH 2000

FPS/505T

GB 820/T

GDS 200T/DT

GS 20/T

HM-26

HS 50T

INTERCOM 1300

IW-100 T

IW-200 TCP lM-10

M 12X4

MBT 1101

MBT 1106

MBT 1112

MBT 1112E

MB-T 6400 S

MB-T 8001

MB-T 8004

MB-T 8008

MCA 4030

MC-F 5042

MCSl 006 TW

MCSl 006 TWP

MD-F 5044

MD-F 5045 S

MD-F 5045 SI

MDS 1060

27868

27867

37734

37638

37639

37640

37641

12944

31059

31078

36546

35673

35839

18245

12905

12117

12116

12912

11474

11475

10446

34553

19812

37490

37489

37491

04693

31080

31079

10040

37496

37497

10042

37643

37644

37735

29431

20236

10044

29425

29426

10045

10046

15294

37495

37739

37492

37493

37494

28840

19543

11828

12122

29432

13543

29422

18083

17859

17862

13544

18147

27492

37485

37486

37488

37487

35302

29430

20010 page

48

49

49

39

45

45

67

48

43

43

43

27

41

41

43

43

64

64

64

44

44

44

44

18

38

46

11-46

11-46

44

40

40

51

51

70

63

26

50

50

26

26

27

27

50

42

26

58

58

30

31

31

31

32

32

32

32

57

57

33

37

83

33

63

24

14

55

62

83

34

14

14

14

Model Code

SO-18

SO-22

SON24V 6A MS40

SOP 412 T/EN

SOP 426 TB/EN

SP 115 B/WP

SP 115 WP

ST 20 B

ST 30 B

ST 40 B

STH 02-022

STH 05-022

STH 09-022

STUDIO.PRO 14 B

STUDIO.PRO 14 BA

STUDIO.PRO 9 B

STUDIO.PRO 9 BA

STUDIO.PRO 9 BT

STUDIO.PRO 9 W

STUDIO.PRO 9 WT

STYlE A40

STYlE P80

STYlE S80

SU 30

TB 30 BK

TR-20

USB 3000

VAC 2006

VAIE 2250

VAR 2006

VERTUS ClA 604

VERTUS DlA 1244A

VERTUS DlA 804A

WCS 650

WM 505/…

WM 505/…

WM 505/…

WM 505/…

WM 505/…

PP-A 02

PP-A 08

PP-A 12

PROJECT 315 BT

PROJECT 315 WHT

PROJECT 320 BT

PROJECT 320 WHT

PROJECT 530 BT

PROJECT 530 WHT

PROJECT 550 BT

PROJECT 550 WHT

PROJECT 640 BT

PROJECT 640 WHT

PROJECT 660 BT

PROJECT 660 WHT

PROJECT Sub 1180A

RB-100

RB-200

RP 02

RWS 412 T/EN

SA 02

SAFE 10 PT

SC A2

SHADOW 105T

SHADOW 108CT

SHADOW 112CT

SJ 14 UB

SJ 9 B

SJ 9 UB

SJ 9 UW

SJ 9 W

SO-12

36186

29470

11573 (175 Mhz)

11574 (214 Mhz)

14922 (204 Mhz)

14923 (212 Mhz)

14924 (203 Mhz)

18248

31011

37642

37713

37484

37712

36145

36187

19681

19680

19677

19679

31150

31151

31152

11586

18239

18240

13360

13103

13104

19682

19683

19678

12908

12909

37751

37733

37732

37637

37636

19710

36193

36194

19709

19706

19708

19707

19705

12907

18159

18160

12913

37731

12906

09356

20130

36192

32368

29225

32369

29227

32370

29229

32371

29351

12899

12900

12901

29350

32372

29221

32367

29223 page

12

10

66

66

27

71

49

9

71

71

71

27

76

76

76

76

33

33

33

66

54

33

33

31

77

77

76

77

77

31

31

67

61

61

76

44

44

13

67

76

76

76

44

82

82

77

76

44

54

80

82

57

57

44

69

74

74

74

75

73

73

73

74

72

72

72

73

43

43

43

72

Model Code

WM 705 A/l

WM 705 A/l

WMS 406 T/EN

WSH 1006

WSP 406 T/EN

14827 (181 Mhz)

14828 (203 Mhz)

37730

29419

37729 page

33

33

68

55

68

87

Artwork studio Conti

Photos F:16 studio

Printers tecnostampa

FBT Elettronica S.p.a. has the right to amend products and specifications without notice.

FBT Elettronica SpA has the right to amend products and specifications without notice.

ALPS

TM

, B&C and Neutrik

TM

are the trademarks of their respective owners.

Graphics

Studio Conti

Photography

Giuseppe Saluzzi

Printing

Tecnostampa - Loreto

Date of printing: May 2013

FBT Elettronica SpA

62019 Recanati (MC) - Italy

Tel: +39 071 750591

Fax: +39 071 7505920

[email protected] - www.fbt.it

(International Headquarter - Factory)

FBT Audio (UK) Ltd

South Croydon, Surrey, UK

Tel: 0844 310 4592

Fax: 0844 310 4594

[email protected]

www.fbtaudio.co.uk

FBT USA, Inc.

Palm Coast, Florida, US

Tel: 800 333 9383

[email protected]

Distributed by

AUDIO CONTRACTOR general catalogue 2013•2014

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
