Indoor sirens and speakers ALARM W ARNING DEVICES

HESA S.p.A was established in 1974 to provide the most
advanced and highest quality technology available to properly serve
the needs of our customers. Our activity has allowed us to make
significant contributions in the area of electronic segurity for the
protection of people and properties.
We have achieved very high goals and standards because we
have many years of technical experience, and we are totally
dedicated to serving our customers in a very professional manner.
By doing this we are helping to create an environment where the
market, our customers, and ourselves can achieve greater success.
Electronic security technology is changing very rapidly. To
keep pace with this change, so our customers can receive the best
products available, we constantly monitor the performance of uor
products and make suggestions to our suppliers for improvements.
We insist on the highst quality standards and back up alla our
products with proper warranty and after sale service.
HESA has been successful because we are dedicated to the
winning formula of customer service and technical excellence.
Enzo Hruby
chairman
II
Exit
Hesa S.p.A
U TOURN
Via Triboniano, 25 - 20156 Milano - Italy
Phone +39.02.380361
Fax +39.02.38036.701
www.hesa.com
[email protected]
III
IV
CONTENTS
OUTDOOR PROTECTION
Long Range Microwave Barriers ..................................................2
HE400 ........................................................................................2
Medium Range Microwave Barriers ............................................4
HE340 - HE370 ..........................................................................4
Active Infrared Beams ..................................................................6
AX-70TN, AX-130TN, AX-200TN - Short range
photoelectric detectors ..............................................................6
AX-250PLUS, AX-500PLUS - Long range
photoelectric detectors ..............................................................7
AX-100TF, AX-200TF - Selectable beam frequency
short range photoelectric detector..............................................8
AX-100TFRP, AX-200TFRP - Selectable beam frequency
short range photoelectric detector - wireless ............................9
AX-350TF, AX-650TF - Selectable beam frequency
long range photoelectric detector ............................................10
AX-350DHMKIII, AX-650DHMKIII - Digital
photoelectric detector ..............................................................11
GARDIAN Beam Towers................................................................12
Series 6000 - Cylindrical towers ..............................................12
Series 4498 - Semi-cylindrical single-sided (180°) towers......14
Series 4598 - Semi-cylindrical double-sided (360°) towers ....16
Infrared coded beams for outdoor perimeter protection ........18
Series 8000 ..............................................................................18
Wall Protection Beams ..............................................................20
Series 7000 ..............................................................................20
Active Infrared Beams ................................................................22
BX-100PLUS ............................................................................22
Outdoor PIR detectors ................................................................23
BX-80N, BX-80NR ....................................................................23
Active Infrared Beams for doors & windows protection ..........25
Series 5000 and 5000T ..........................................................25
Double PIR detectors for windows and doors............................27
HE-100 Series ..........................................................................27
Outdoor PIR detectors ................................................................28
HX-80N, HX-80NAM e HX-80NRAM ..........................................28
HX-40, HX-40AM, HX-40RAM, HX-40DAM ................................30
VX-402, VX-402R (low current version),
VX-402REC (voice warning version) ........................................32
LX-402, LX-802N ......................................................................34
Outdoor dual-tech detectors, with anti-masking ......................35
Series FIT ..................................................................................35
GUARD ......................................................................................38
OUT-SMART ..............................................................................39
OUT-LOOK ................................................................................40
CURTAIN....................................................................................41
Outdoor dual-tech detectors ......................................................43
PIRAMID....................................................................................43
Outdoor Shock sensors ..............................................................45
VIBRA-SENS..............................................................................45
VOLUMETRIC INDOOR PROTECTION
Dual PIR/Microwave detectors with anti-masking ....................48
C-101STLRE11, C-101STLRE15, M7300STE, M9000STE
Adaptive® Series ......................................................................48
Dual PIR/Microwave detectors ..................................................50
MX-40QZ, MX-50QZ ..................................................................50
High-end indoor detectors..........................................................51
OPTIMAL....................................................................................51
PIR detectors ..............................................................................52
IQ VISION ..................................................................................52
RX-40QZ ..................................................................................53
EX-35T, EX-35R ........................................................................54
FX-40, FX-40D ..........................................................................55
CX-702, CX-702RS ..................................................................56
FX-360......................................................................................57
SX-360Z....................................................................................58
LOCAL PROTECTION DEVICES
Recessed mount Magnetic Contacts ..............................62
Miniature recessed magnetic contact
with bare magnet, ’ 6.4 mm ................................................62
Press-fit miniature recessed magnetic contact
with bare magnet, ’ 6.4 mm ................................................62
Press-fit recessed magnetic contact, ’ 9 mm ......................62
Press-fit recessed magnetic contact
with screw terminals, ’ 9 mm ..............................................62
Press-fit recessed magnetic contact
with supervisor loop, ’ 9 mm ................................................62
Flanged recessed magnetic contact
with supervisor loop, ’ 9.2 mm ............................................62
“Stubby” Press-fit recessed magnetic contact, ’ 9.5 mm......62
Recessed magnetic contact for Steel Doors, ’ 19 mm ..........62
Roll plunger flush contact ........................................................62
Surface mount Magnetic Contacts ................................63
Sub miniature magnetic contact, 26 mm long ........................63
Sub miniature flange magnetic contact, 28 mm long..............63
Miniature flange magnetic contact, 34 mm long ....................63
Design magnetic contact with screw terminals........................63
Standard magnetic contact with screw terminals,
cover spacer ............................................................................63
Industrial magnetic contact with screw terminals ..................63
Industrial Aluminium supervised contact with stainless
steel armored cable..................................................................63
Floor mount overhead door contact with stainless
steel armored cable..................................................................63
V
Contacts for Roller-shutters, Shock sensors & Glass
break detectors ..........................................................................64
ContaCtS for RollER-Shutters ..................................................64
Piezo shock sensor....................................................................64
Glass break detectors ..............................................................64
Water Presence sensors & Emergency Hold-Up devices ........65
Water presence sensors............................................................65
Emergency hold-up Devices......................................................65
LiteSUN ........................................................................................66
SicurSPOT ....................................................................................68
ALARM CONTROL SYSTEMS
Modulo XP Systems ....................................................................72
MODULO XP6 ............................................................................72
MODULO XP6 - Keypads............................................................73
Wireless ....................................................................................74
Indoor wireless PIR detectors ..................................................75
Outdoor wireless PIR detectors ................................................76
Wireless door/window transmitters and keyfobs ......................80
Wireless perimeter protection detectors ..................................81
Wireless smoke sensors, call points, water sensors ................82
Alkaline and Lithium Batteries ................................................83
REMOTE CONTROL STATIONS - KEYSWITCHES
Key Control Stations....................................................................86
KABA High Security Registered Key Systems ............................86
Round key and flat key series ..................................................87
Digital Keypad Systems ..............................................................88
Keyswitches ................................................................................90
ALARM WARNING DEVICES
Multifunction phone dialers with voice synthesis on PSTN
and GSM networks ....................................................................94
INFORMA 600 Series ................................................................94
Outdoor self-powered electronic sirens ....................................97
SCUDO-1500 and SCUDO-SFB..................................................97
SAE16SF ..................................................................................99
Indoor sirens and speakers......................................................100
Strobe Warning Lights ..............................................................102
POWER SUPPLIES - ACCESSORIES
Power Supplies..........................................................................106
Single Output Switching Power Supplies................................106
Linear, Buffer Power Supply Units ..........................................107
Constant voltage power supply ..............................................108
AC/AC Adapters ........................................................................109
Battery Chargers for lead acid batteries ................................111
Metal Housings..........................................................................112
Accessories ..............................................................................113
Tamper switches ....................................................................113
BATTERIES - CABLES
ECOPOWER Sealed Lead-Acid Batteries ..................................116
Series HH ................................................................................116
FIAMM-GS Sealed Lead-Acid Batteries ....................................118
ENERSYS Cyclon High performance Pure Lead Batteries ......120
ENERSYS Genesis High performance Pure Lead Batteries ....122
NORTHSTAR High performance Pure Lead Batteries ..............124
Industrial Range ....................................................................124
NORTHSTAR High performance Pure Lead Batteries................126
Front Terminal (FT) Range ......................................................126
Alarm Cables ............................................................................127
CCTV Cables ..............................................................................129
CCTV PRODUCTS
Color Cameras ..........................................................................132
IR Outdoor Cameras, Fixed Lens ............................................132
IR Outdoor Cameras, Fixed Lens, High Resolution..................133
Day/Night Color Cameras ........................................................134
IR Outdoor Cameras, Vari-Focal, ICR Filter ............................134
IR Outdoor Cameras, Vari-Focal, High Resolution, ICR Filter..137
True Day & Night IR-LED “all-in-one” Cameras ....................138
Entry level, IR Outdoor Cameras, Fixed Lens ..........................141
Entry level, IR Outdoor Cameras, Vari-Focal, ICR Filter ..........142
Day/Night Color Cameras..........................................................143
UTP Cameras ..........................................................................143
IR Outdoor Cameras, Vari-Focal, ICR Filter
and Plastic Fiber integrated transmitter(*)............................144
Color Cameras ..........................................................................147
High Sensitivity, Standard Resolution ....................................147
High Sensitivity, High Resolution............................................148
Day&Night, High Resolution ..................................................149
Day&Night Wide Dynamic ......................................................151
36X Day&Night Auto Focus Zoom High Resolution ................152
Outdoor Dome Cameras..........................................................153
3-AXIS Gimbal Vari-focal, Indoor Dome Cameras ..................154
Outdoor Dome Cameras..........................................................155
Indoor Miniature Cameras ......................................................159
Miniature Board Camera ........................................................161
Speed-Dome SD Series ..........................................................163
Camera Brackets ......................................................................166
Outdoor Camera Housings ........................................................167
Side opening technopolymer housing ......................................168
Cases External PoE Megapixel IP cameras ............................169
CCTV Lenses ..............................................................................170
1/3” - Manual Iris, Vari-Focal Lenses ....................................171
1/3” - Manual Iris, IR Lenses ................................................172
1/3” - Manual Iris, IR, Vari-Focal Lenses ..............................173
1/3” - DC Iris (AI w/o Control Circuit) Lenses ........................174
1/3” - DC Iris (AI w/o Control Circuit), IR, Lenses ..................175
1/3” - Video Auto Iris (w. Control Circuit) Lenses ..................177
1/3” Ultra High Definition MEGAPIXEL Lenses........................179
1/2” Ultra High Definition MEGAPIXEL Lenses........................180
VI
1/3” - Motorized Zoom Lens ..................................................181
1/2” - Manual Iris, DC Iris lenses, Zoom Lenses ....................182
Color LCD TFT Monitors ............................................................183
Touch screen series ................................................................186
Video Testers ............................................................................187
IR illuminators ..........................................................................188
Quad Processors ......................................................................189
Video Distributors & Amplifiers ................................................190
Distributors, Amplifiers, Surge Protections & Power Supplies191
H.264 Stand Alone DVR ............................................................195
Entry level Series ..................................................................195
Network H.264 Series..............................................................196
COMBO DVR ..............................................................................197
IP Cameras................................................................................198
Indoor compact cameras ........................................................198
Professional cameras high resolution ....................................199
H.264 2.0 MEGAPIXEL IP Box Cameras ..................................200
H.264 2.0 MEGAPIXEL IR Bullet and Vandal Dome ................201
WDR Outdoor IP Camera ........................................................203
Switches, splitters, injector, PoE Repeater..............................204
IP Cameras ..............................................................................206
Speed-Dome NSD Series ........................................................206
Camera Servers ........................................................................208
1 & 4 Channel Camera Servers ..............................................208
Encoder/Decoders ....................................................................209
IP video transmission on coaxial cable ..................................210
IP Transmitters ......................................................................210
Maxi Watch Professional Software ..........................................211
NVR System High Density Recording and Management
for IP Cameras..........................................................................212
Mini-NVR System High Density Recording
and Managementfor IP Cameras..............................................214
Central Management System (CMS) ........................................215
LiteWire™ Plastic Fiber (POF) for Video Transmission ..........218
Day/Night Color Cameras ........................................................220
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber
integrated transmitter............................................................220
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic
Fiberintegrated transmitter ....................................................221
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber
integrated transmitter............................................................222
Twisted-Pair Systems for Color Video Transmission ..............223
Video Transceiver....................................................................223
Receivers & Extenders ............................................................224
Channel Video Transceivers & Cable Hub ..............................225
Video Interference ..................................................................228
Day/Night Color Cameras..........................................................229
UTP Cameras ..........................................................................229
VII
OUTDOOR PROTECTION
pag. 2 to pag. 45
VOLUMETRIC INDOOR PROTECTION
pag. 48 to pag. 59
LOCAL PROTECTION DEVICES
pag. 62 to pag. 69
ALARM CONTROL SYSTEMS
pag. 72 to pag. 83
REMOTE CONTROL STATIONS - KEYSWITCHES
pag. 86 to pag. 91
ALARM WARNING DEVICES
pag. 94 to pag. 103
POWER SUPPLIES - ACCESSORIES
pag. 106 to pag. 113
BATTERIES - CABLES
pag. 116 to pag. 129
CCTV PRODUCTS
pag. 132 to pag. 229
OUTDOOR PROTECTION
Microwave Barriers
Active Infrared Beams for doors & windows protection
Long range Active Infrared Beams
GARDIAN Beam Towers
Indoor Active Infrared Beams
Outdoor PIR detectors
Outdoor Dual PIR/Microwave detectors
Outdoor Shock sensors
Long Range Microwave Barriers
HE400
HE400
Outdoor Microwave barrier,
200 m range
FEATURES
• Bistatic microwave barrier
• Vibration, wind, fog, rain,
snow, dust and extreme
temperatures insensitive
• Low current drain (80mA
per barrier)
• 200 m range
• 4 on-site programmable FM
wave bands
• Phase-locked loop (PLL)
signal processing with
wide dynamic range
• Multi-barrier
synchronisation possibility
DETECTION DIAGRAMS
HE400 Microwave Barrier can
be adjusted on-site according
to the sensitivity and
detection speed required.
Generally speaking, the range
of the protected area varies
proportionally to the distance
between the receiver and the
transmitter.
www.hesa.com
Radiation lobe width (metres)
OUTDOOR PROTECTION
2
3rd level
• Directive radiation pattern
modification option for
improved detection
• Up to 36 hours of operation
with 12V 2.1 Ah back-up
battery
• IMQ Security Systems
3rd level Certification
Maximum horizontal coverage (Top view)
10
8
4
0
4
8
10
0
20
40
60
80
100
120
140
Distance between the Receiver and the Transmitter (metres)
160
180
200
3
Long Range Microwave Barriers
HE400
SPECIFICATIONS
Model
Operating channels
Operating frequency(*)
Detection range
Power input
Tx
Rx
Current drain:
Maximum power
Alarm output
Tamper contact
IP rating
Operating temperature
Weight g
IMQ Certification
HE400
4, on-site selectable
9.9 GHz
5 ~ 200 m
19VAC, 340mA / 11.5 ~ 14.8VDC
38mA/13VDC
45mA/13VDC
3mW
100mA@28VDC N.C. contact
N.C. with cover in place
IP55
–25°C ~ +55°C
3200 (each set of equipment)
8100 (complete with mounting
brackets and carton packing)
3rd level
(*) Different frequencies available upon request
DIMENSIONS (mm)
270
65
135
250
HE400
CODE
MODEL
DESCRIPTION
HE400
HE400
Outdoor Microwave barrier, complete with transmitter, receiver
and two HE401 joint clamps. Detection range 200 m.
HE401
HE402
HE403
HE405
HE410
HE401
HE402
HE403
HE405
HE410
HETS400
TS400
Sturdy joint clamp for mounting the unit on posts 70~120mm diameter
Horizontally hinged mounting for wall installation
Clamps for mounting cabinet on posts 70~120mm diameter
Transformer 230VAC/19VAC, 30VA
Outdoor cabinet to house a 230/19VAC transformer.
Requires 2xHE403 clamps for mounting on posts 70~120 mm diameter
Alignment and adjustment tool for HE400, HE340, HE370
HE401
HE402
HE403
HE405
HE410
TS400
Accessories
www.hesa.com
Medium Range Microwave Barriers
HE340 - HE370
HE340
Outdoor Microwave barrier,
40 m range
FEATURES
• Maximum range: 40 metres
HE340, 70 metres HE370
• 4 on-site selectable modulation frequencies
• Anti-shifting detection
• Planar technology antenna
• Version with synchronism
available (HE340S &
HE370S) for stacking
installations
Radiation lobe width (metres)
Top view (metres)
6
4
2
0
2
4
6
0
10
20
HE370 / HE370C / HE370S
Radiation lobe width (metres)
OUTDOOR PROTECTION
4
30
40
Maximum horizontal coverage
Top view (metres)
6
4
2
0
2
4
6
0
20
30
Maximum
horizontal
coverage
HE340 / HE340C / HE340S
www.hesa.com
10
40
50
60
70
HE370
Outdoor Microwave barrier,
70 m range
• Easy alignment and control
using TS400 adjusting tool
• Elegant and modern design
5
Medium Range Microwave Barriers
HE340 - HE370
SPECIFICATIONS
Model
Power input
Current drain:
HE340
HE340C
Tx
Rx
Operating frequency
Maximum power to emitting
Operating channels
Synchronism
Detection range (m)
Alarm output
Tamper contact
IP rating
Operating temperature
NO
HE340S
HE370
HE370C
11.50VDC~14.8VDC
50mA (Max)
32mA (Max)
10.50 GHz ~ 10.60 GHz
20 to 500 mW P.I.R.E. according to national regulations
4, on-site selectable
YES
NO
40
70
N.C. 100 mA@28VDC
N.C. with cover in place
IP67
-25°C ~ +55°C
HE370S
YES
DIMENSIONS (mm)
205
80
160
HE340 / HE370
CODE
MODEL
DESCRIPTION
HE340
HE340
HE370
HE370
HE340C
HE340C
HE370C
HE370C
HE340S
HE340S
HE370S
HE370S
Outdoor Microwave barrier, complete with transmitter, receiver
and two pole mounting brackets. Detection range 40 m.
Outdoor Microwave barrier, complete with transmitter, receiver
and two pole mounting brackets. Detection range 70 m.
Outdoor Microwave barrier, including transmitter, receiver
and plates for mounting in towers Series 4498/4598 and 6000.
Detection range 40 m. Supplied without housing
Outdoor Microwave barrier, including transmitter, receiver
and plates for mounting in towers Series 4498/4598 and 6000
Detection range 70 m. Supplied without housing
Outdoor Microwave barrier with synchronism, complete with
transmitter, receiver. Detection range 40 m. Supplied without
housing, for installation in towers Series 4498/4598 and 6000
Outdoor Microwave barrier with synchronism, complete with
transmitter and receiver. Detection range 70 m. Supplied without
housing, for installation in towers Series 4498/4598 and 6000
Accessories
HETS400
www.hesa.com
TS400
Alignment and adjustment tool for HE400, HE340, HE370
TS400
OUTDOOR PROTECTION
6
Active Infrared Beams
AX-70TN, AX-130TN, AX-200TN - Short range photoelectric detectors
AX-70TN
Photoelectric detector,
20m range
DESCRIPTION
The AX-70/130/200TN Series
of short range photoelectric
detectors is compact in
designed with IP65 high
durable structure.
Rubber packing is used for all
conceivable points where
water, dust or bugs may
penetrate, such as wiring
holes, wire ports and the outer
chassis. Preventing these
factors helps deliver
AX-130TN
Photoelectric detector,
40m range
AX-200TN
Photoelectric detector,
60m range
FEATURES
• IP65 structure
• Lightning and surge
protection
• Anti-frost hood cover
• 99% beam blocking
stability
DETECTION RANGE
• A.G.C. circuit
• Adjustable interruption
time
DIMENSIONS (mm)
SPECIFICATIONS
Model
Maximum detection range
Maximum arrival range
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Alarm output
Tamper switch
Operating temperature
Environmental humidity
IP rating
Alignment angle
Mounting
Weight (transmitter+receiver)
performance with higher
reliability in severe outdoor
environmental condition.
In addition, the length
between the upper and lower
optics, and the width of the
optics are ideally engineered to
produce the most intelligent
detection pattern which
reduces false alarms by
detecting human intruders
only.
AX-70TN
AX-130TN
AX-200TN
20m
40m
60m
200m
400m
600m
Selectable between 50, 100, 250, and 500 msec.
10.5 - 28V DC
38mA (max.)
41mA (max.)
45mA (max.)
2 sec.(±1) nominal
N.C. 28V DC 0.2A max
Opens when cover is removed at 28V DC, 0.2A max.
-35°C to +60 °C Use the optional heating unit (HU-3)
under the environment of -25°C or less minus.
95% max.
IP65
±90° Horizontal, ±5° Vertical
Wall and pole mounting
650g
CODE
MODEL
DESCRIPTION
OX70TN
OX130TN
OX200TN
AX-70TN
AX-130TN
AX-200TN
Photoelectric detector, 20 m range
Photoelectric detector, 40 m range
Photoelectric detector, 60 m range
HU-3
BC-3
PSC-3
Heating unit: 24V DC/AC, 420mA max.
Back cover
Pole side cover: cover for installing 2 units to 1 pole
AX-70TN / AX-130TN /
AX-200TN
HU-3
BC-3
Accessories
OXHU-3
OXBC-3
OXPSC-3
www.hesa.com
PSC-3
7
Active Infrared Beams
AX-250PLUS, AX-500PLUS - Long range photoelectric detectors
AX-250PLUS
Long range photoelectric
detector, 75 m range
AX-500PLUS
Long range photoelectric
detector, 150 m range
FEATURES
• Lightning and surge
protection
• Anti-frost design
• Twin beams require
simultaneous interruption
to create activation.
• Easy installation and
alignment
• Sealed optics to prevent
ingress of insects and dust
• 99% beam blocking
stability
• A.G.C. circuit
• Adjustable beam
interruption time
DETECTION RANGE
DESCRIPTION
AX-250/500PLUS Series are
cost-effective long-range dual
beams for internal or external
applications.
Suitable for external ranges up
to 150m outdoors, the beams
have twin infrared
transmitters and receivers to
reduce the potential for alarms
from small animals, blowing
debris and falling leaves.
Beams operate by only
triggering an alarm when both
beams are broken
simultaneously. Initial
alignment can be carried out
using the built in optical
aiming device to roughly set
the sensors and then finetuning can be carried out
using a standard volt meter.
SPECIFICATIONS
Model
Maximum detection range
Maximum arrival range
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Alarm output
Tamper switch
Operating temperature
Environmental humidity
Alignment angle
Mounting
IP rating
Weight (transmitter+receiver)
AX-250PLUS
AX-500PLUS
75m
150m
750m
1500m
Selectable 50~500 msec.
10.5 - 30V DC
DIMENSIONS (mm)
50mA (max.)
2 sec. (±1) nominal
Form C relay 28V DC 0.2A max.
N.C. opens when cover is
removed (Receiver only)
-25°C to +55°C
95% max.
±90° Horizontal, ±10°Vertical
Wall and pole mounting
IP54
2700g
CODE
MODEL
DESCRIPTION
OX250-P
OX500-P
AX-250PLUS
AX-500PLUS
Long range photoelectric detector, 75m range
Long range photoelectric detector, 150m range
BC-1
HU-1
Back cover
Heating unit: 24V DC/AC, 430mA max
400
100
104
AX-250PLUS / AX-500PLUS
Accessories
OXBC-1
OXHU-1
www.hesa.com
BC-1
HU-1
OUTDOOR PROTECTION
8
Active Infrared Beams
AX-100TF, AX-200TF - Selectable beam frequency short range photoelectric detector
AX-100TF
Selectable beam frequency
photoelectric detector,
30m range
AX-200TF
Selectable beam frequency
photoelectric detector,
60m range
FEATURES
• Selectable 4 channel beam
frequencies
• 4 step LED indicator
• Environmental
disqualification circuit
• IP65 structure
• Lightning and surge
protection
2nd level
• Anti-frost hood cover
• 99% beam blocking
stability
• A.G.C. circuit
• Adjustable interruption
time
DESCRIPTION
The AX-100/200TF Series of
short range photoelectric
detectors are compact in
design with selectable beam
frequencies.
The selectable beam
frequencies can be used to
avoid unwanted crosstalk that
can occur when using multiple
photobeams over long
distances or for beam stacking
applications.
DETECTION RANGE
SPECIFICATIONS
DIMENSIONS (mm)
Model
Maximum detection range
Maximum arrival range
Selectable beam frequencies
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Alarm output
Tamper switch
AX-100TF
30m
300m
Environmental humidity
Alignment angle
Mounting
IP rating
Weight (transmitter+receiver)
IMQ Certification
AX-200TF
60m
600m
4 channel
Selectable between 50, 100, 250, and 500 msec.
10.5 - 28V DC
44mA (max.)
Operating temperature
Also the AX-TF Series carries
the IP65 high durable
structure, which prevents
water, dust or bugs from
getting into the unit. The ideal
optical pitch design reduces
false alarms due to accidental
beam interruption by falling
leaves, birds, and so on. These
features deliver performance
with higher reliability in severe
outdoor environmental
condition.
48mA (max.)
2 sec. (±1) nominal
N.C./N.O. 28V DC 0.2A max.
Opens when cover is removed at 28V DC, 0.2A max.
35°C to +60°C
Use the optional heating unit (HU-3) under the environment of
-25°C or less minus.
95% max.
±90° Horizontal, ±5° Vertical
Wall and pole mounting
IP65
700g
2nd level
CODE
MODEL
DESCRIPTION
OX100TF
OX200TF
AX-100TF
AX-200TF
Selectable beam frequency photoelectric detector, 30m range
Selectable beam frequency photoelectric detector, 60m range
AX-100TF / AX-200TF
HU-3
BC-3
Accessories
OXHU-3
OXBC-3
OXPSC-3
www.hesa.com
HU-3
BC-3
PSC-3
Heating unit: 24V DC/AC, 420mA max.
Back cover
Pole side cover: cover for installing 2 units to 1 pole
PSC-3
9
Active Infrared Beams
AX-100TFRP, AX-200TFRP - Selectable beam frequency short range photoelectric detector - wireless
AX-100TFRP
Selectable beam frequency
photoelectric detector, low
current version, 30m range
AX-200TFRP
Selectable beam frequency
photoelectric detector, low
current version, 60m range
FEATURES
• Easy battery replacement
• Triple tamper functions
• Low battery output and LED
indication
• Intermittent output
function
SPECIFICATIONS
DIMENSIONS (mm)
Model
Power supply
AX-100TFRP
AX-200TFRP
3.6V 13.0Ah, LSH20 lithium batteries
Transmitter: 2 units
Receiver: 2 units
Current consumption
(@ 25°C, 3.6VDC):
Maximum detection range
Maximum arrival range
Alignment angle
Interruption period
Selectable beam frequencies
Detection method
Battery life:
transmitter
riceiver
Output:
alarm output
alarm period
D.Q. output
low battery output
tamper output for front cover
tamper output for back box
Indicator:
• Compatible with numerous
wireless transmitters
• Battery saving timer
function for wireless
transmitters
alarm indicator (riceiver)
power (transmitter)
low battery
Operating temperature
Environmental humidity
IP rating
Mounting
Weight (transmitter+receiver)
620µA T:300µA+R:320µA
810µA T:490µA+R:320µA
30m
60m
265m
530m
±90° horizontal, ±5° vertical
Selectable between 50, 100, 250, and 500 msec.
4 channel
Infrared beam interruption detection
5 years
3 years
5 years
5 years
Form C-Solid State Switch: 3.6VDC, 0.01A
2 sec (±1) nominal
Form A/B-Solid State Switch: 3.6VDC, 0.01A
Form A/B-Solid State Switch: 3.6VDC, 0.01A
(transmitter & riceiver)
Form C: 3.6VDC, 0.01A, activates when cover removed
Form C: 3.6VDC, 0.01A, activates when either back box
or chassis is removed from the installment
(1) Light on - IR Beam not received
(2) Flickering Light - IR Beams not received sufficiently
(3) Light off - IR Beams received
Power ON: ON, Power OFF: OFF
Voltage Reduction: flicker
–20°C - +60°C
95% max.
IP55
Indoor/Outdoor, Wall/Pole/Tower mounting
1600g (excluding accessories)
CODE
MODEL
DESCRIPTION
OX100TFP
AX-100TFRP
OX200TFP
AX-200TFRP
Selectable beam frequency photoelectric detector, low current version, 30m
range with 4 battery al litio SAFT LSH20
Selectable beam frequency photoelectric detector, low current version, 60m
range with 4 battery al litio SAFT LSH20
217
89
163
AX-100TFRP / AX-200TFRP
Accessories
OX200TFR4
LASH20
www.hesa.com
MP-4
LSH20
Main unit mounting bracket set (for tower mounting)
Lithium battery 3.6V 13.0Ah
MP-4
LSH20
OUTDOOR PROTECTION
10
Active Infrared Beams
AX-350TF, AX-650TF - Selectable beam frequency long range photoelectric detector
FEATURES
• Selectable 4 channel beam
frequencies
• 16 step LED indicator
• Environmental
disqualification circuit
• IP54 structure
DIMENSIONS (mm)
AX-350TF
Selectable beam frequency
photoelectric detector,
100m range
400
AX-650TF
Selectable beam frequency
photoelectric detector,
200m range
SPECIFICATIONS
Model
Maximum detection range
Maximum arrival range
Selectable beam frequenies
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Alarm output
Tamper switch
Operating temperature
Environmental humidity
Alignment angle
IP rating
Mounting
AX-350TF
AX-650TF
100m
200m
1000m
2000m
4 channel
50 - 500 msec.
10.5 - 30V DC
60mA(max.)
62mA(max.)
normal operation normal operation
78mA(max.)
80mA(max.)
optical operation optical operation
2 sec.(±1) nominal
Form C relay 28V DC 0.2A max.
N.C. opens when cover is removed
-35°C to +60°C
95% max.
±90° Horizontal, ±5° Vertical
IP54
Wall and pole mounting
100
99
104
AX-350TF / AX-650TF
• Lightning and surge
protection
• Anti-frost design
• 99% beam blocking
stability
• A.G.C. circuit
• Adjustable interruption
time
DESCRIPTION
The AX-350/650TF Series of
long range photoelectric
detectors with selectable beam
frequencies.
The selectable beam
frequencies can be used to
avoid unwanted crosstalk that
can occur when using multiple
photobeams over long
distances or beam stacking
applications.
Also the AX-TF Series employs
multiple beam technology and
utilizes an AND circuit that
requires all beams to be
interrupted simultaneously
before an alarm is generated.
This reduces false alarms due
to accidental beam
interruption by falling leaves
and small animals.
DETECTION RANGE
CODE
MODEL
DESCRIPTION
OX350TF
AX-350TF
OX650TF
AX-650TF
Selectable beam frequency photoelectric detector,
100m range
Selectable beam frequency photoelectric detector,
200m range
Accessories
OXBC-1
OXHU-1
www.hesa.com
BC-1
HU-1
Back cover
Heating unit: 24V DC/AC, 430mA max
BC-1
HU-1
11
Active Infrared Beams
AX-350DHMKIII, AX-650DHMKIII - Digital photoelectric detector
AX-350DHMKIII
Digital photoelectric detector,
100m range
AX-650DHMKIII
Digital photoelectric detector,
200m range
SPECIFICATIONS
Model
Maximum detection range
Maximum arrival range
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Alarm output
Tamper switch
Operating temperature
Environmental humidity
Alignment angle
Mounting
IP rating
Weight (transmitter+receiver)
IMQ Certification
AX-350DHMKIII AX-650DHMKIII
100m
200m
1000m
2000m
Selectable 35~500 msec.
10.5 - 30V DC
105mA (max.)
FEATURES
• No crosstalk by advanced
digital communication
• Simplified optical
alignment:
- LED which can be checked
the beam strength easily
- No need for beam blocking
plate
- Highly accurate alignment
with no need to use a
voltmeter
• Reliable detection with
ATPC™ in spite of
environmental change
• Trouble free channel
setting
• IP65 structure
• Up to 4 sets for multiple
installations
2nd level
2nd level
DESCRIPTION
AX-350/650DHMKIII is ideal for
stacking applications for high
security use. The complicated
channel setting is not required
so it reduces the costs for
installation time and planning
of large systems.By utilizing the
world's first digital technology,
AX-350/650DHMKIII eliminates
possible crosstalk from other
beams or external sources and
also automatically controls,
adjusts, and optimizes the
power of beams and maintains
optimal performance.
DIMENSIONS (mm)
131
110mA (max.)
2 ± 1 sec. nominal
Form C relay (28V DC 0.2A max.)
N.C. open when cover is removed
-35°C to +60°C Use the optional
heating unit (HU-2) under
the severe outd
95% max.
±90°Horizontal, ±20°Vertical
Wall and pole mounting
IP65
2750g
2nd level
DETECTION RANGE
415
112
183
AX-350DHMKIII
AX-650DHMKIII
CODE
MODEL
DESCRIPTION
OX350DH
OX650DH
AX350DHMKIII
AX650DHMKIII
Digital photoelectric detector, 100m range
Digital photoelectric detector, 200m range
BC-1
HU-2
Back cover
Heating unit: 24V DC/AC, 430mA max
Accessories
OXBC-1
OXHU-2
www.hesa.com
BC-1
HU-2
OUTDOOR PROTECTION
12
GARDIAN Beam Towers
Series 6000 - Cylindrical towers
DESCRIPTION
The cylindrical shape of this
beam tower and its fairly
small diameter, mean that a
security barrier and a garden
lamp can be combined into
just one piece of equipment,
which blends attractively
into its surroundings.
Infrared beam barriers can
be installed inside, with
optical units that can be
directed through 180°, while
the black screen, which is
transparent to infrared
beams, prevents
identification of the direction
and position of the optical
units.
The sturdy anodised
aluminium profile and the
screen in schockproof
polycarbonate make for
solid, hardwearing
installations, which keep
their characteristics even in
harsh climatic conditions.
Tower must be fixed to the
ground by optional base
secured to an easy-to-create
cement foundation.
Available in standard
heights of 1m, 1.5m, 2m,
2.5m and 3m to satisfy all
requirements, both in terms
of installation and exterior
design.
Screen in shockproof
polycarbonate
Microswitch
Sturdy anodised
aluminium
Bottom cover
Screws with rubber O-rings
for the top cover
Top cover
FEATURES
• Accommodate various
brands and models of
infrared beam barriers
• Total concealment of the
aiming height and number
of barriers installed inside
• Optical units can be
directed through 180°
• Blend perfectly into the
surroundings as garden
lights
Sturdy
anodised
aluminium
Screen in
shockproof
polycarbonate
Bottom
cover
www.hesa.com
Top cover
Steel base
13
GARDIAN Beam Towers
Series 6000 - Cylindrical towers
SPECIFICATIONS
Model
Material
Screen
Covers
Colour
Size mm
6100
Diameter
Height
1015
Base
Light fixture
IP rating
Weight g
6800
6150
6200
6250
anodised aluminium extrusion
black polycarbonate IR transparent
polycarbonate
black
’ 130
1515
2015
2515
steel, black painted ’ 200mm, 3 holes ’ 8.5mm
’ 60 mm diameter standard, compatible with most common light fictures
IP54
7200
7300
9500
6300
3015
10000
DIMENSIONS (mm)
1000 ÷ 3000
120
130
158
130
Series 6000
158
158
BC-6000
CODE
MODEL
DESCRIPTION
HE6100
HE6150
HE6200
HE6250
HE6300
6100
6150
6200
6250
6300
Cylindrical beam tower, height 1.00 m
Cylindrical beam tower, height 1.50 m
Cylindrical beam tower, height 2.00 m
Cylindrical beam tower, height 2.50 m
Cylindrical beam tower, height 3.00 m
Accessories*
HE60BC
HE60FP
HE6000H
HE60STR
HE60AL
HE60AOX
BC-6000
FP-6000
H-6000
STR-6000
AL-6000
AP-OX/6000
Steel base
Wall mounting kit
Heater and thermostat
Transformer 230VAC/16VAC
Power supply 230VAC /24VAC - 12VDC
Mounting plate for Optex AX-70TN/-130TN/-200TN,
AX-100TF/-200TF & BX-100PLUS
HE60MK3
MK3-6000P
Mounting plate for Optex AX-350/650DH MKIII
HE60TF
TF-6000
Mounting kit for Optex AX-350/650TF
HE60SL
SL-6000
Lamp fixture base
HE60G40
G400-6000
Clear polycarbonate bubble, ’ mm 400
HE60G50
G500-6000
Clear polycarbonate bubble, ’ mm 500
HE60BPP
BPP-6000
Plastic base and E27 lamp holder, ’ mm 60, black colour
HE60BPA
BPA-6000
Aluminium base and E27 lamp holder, ’ mm 60, black colour
HE60/18
6018
Transformer 230VAC/18VAC for H-6000
HE60/25
6025
Power supplies 13VDC/2.5Ah
* Other beam manufacturers mounting plates available upon request
www.hesa.com
BC-6000
H-6000
STR-6000
AP-OX/6000
MK3-6000P
SL-6000
G400-6000
G500-6000
BPP-6000
BPA-6000
FP-6000
AL-6000
OUTDOOR PROTECTION
14
GARDIAN Beam Towers
Series 4498 - Semi-cylindrical single-sided (180°) towers
DESCRIPTION
The semi-cylindrical shape of
this column means that
infrared beams installed
inside can be directed
through 180°, while the black
screen that is transparent to
infrared beams prevents
identification of the exact
number, height and direction
of the optical units.
The sturdy aluminium section
allows the tower to be fixed to
walls or joined up to another
beam tower to provide
protection at 360°.
The aluminium cover has
ventilation slots to prevent
condensation and has been
specially designed to offset
natural warping of the black
screen at high temperatures.
FEATURES
• Total concealment of the
aiming, height and number
of photobeams installed
inside
• Possibility of aiming photo
beams through 180°
horizontally.
• Available in standard
heights of 1.00 m, 1.50 m,
2.00 m, 2.50 m and 3.00 m
• Excellent resistance to
atmospheric agents and
condensation
• Sturdy aluminium extrusion
and die-casting covers
Aluminium die-casting
top cover
Possibility of aiming
optical units horizontally
over 180°
Deep guides to
fasten the screen
securely
Sturdy aluminium
structure for wall or
I-beam mounting
Black acrylic screen
Aluminium die-casting
bottom cover
SPECIFICATIONS
Model
Material
Screen
Covers
Colour
Size mm (WxDxH)
Base
IP rating
Weight g
www.hesa.com
4498/1
188x168x1000
6800
4498/1.5
4498
4498/2.5
painted aluminium extrusion
black acrylic IR transparent
aluminium casting
black
188x168x1500
188x168x2000
188x168x2500
steel black painted, 400x400x400 mm
IP54
7200
7300
9500
4498/3
188x168x3000
10000
15
GARDIAN Beam Towers
Series 4498 - Semi-cylindrical single-sided (180°) towers
DIMENSIONS (mm)
A = heights
4498/1 1.00 m
4498/1.5 1.50 m
4498
2.00 m
4498/2.5 2.50 m
4498/3 3.00 m
Front view
Side view
Top view
Series 4498
CODE
MODEL
DESCRIPTION
HE44981
HE44985
HE4498
HE44987
HE44983
4498/1
4498/1.5
4498
4498/2.5
4498/3
Semi-cylindrical single-sided beam tower, height 1.00 m
Semi-cylindrical single-sided beam tower, height 1.50 m
Semi-cylindrical single-sided beam tower, height 2.00 m
Semi-cylindrical single-sided beam tower, height 2.50 m
Semi-cylindrical single-sided beam tower, height 3.00 m
Accessories*
HZF4498
Steel base, WxHxD mm 400x400x400, complete with rails and
screws
HZS4400
SC-4400
Wall mounting plate
HE44AOX
AP-OX/4498
Mounting plate for Optex AX-70TN/-130TN/-200TN,
AX-100TF/-200TF and BX-100PLUS
HEAXMK2
AX-MK2P
Mounting plate for Optex AX-250/500PLUS and AX-350/650TF
HEAXMK3
AX-MK3P
Mounting plate for Optex AX-350/650DH MKIII infrared barriers
HE4498A
4498A
Tamper kit
HE4498AC
4498AC
Anti-climb tamper pressure switch top kit
HE4498T
4498T
Heating control kit
HE4498H
4498H
Heater controlled by 4498T
HE44/18
4418
Transformer 230/18VAC for heater 4498H
HE44/25
4425
Power supplies 13.8VDC/2.5Ah
HEA44989
44989
Support stand cm 190
* Other beam manufacturers mounting plates available upon request
www.hesa.com
BC-4498
AX-MK3P
SC-4400
AP-OX/4498
AX-MK2P
4498A
4498T
4498H
4498AC
4418
BC-4498
4425
OUTDOOR PROTECTION
16
GARDIAN Beam Towers
Series 4598 - Semi-cylindrical double-sided (360°) towers
DESCRIPTION
These double-sided models
allow the installation of
infrared beams at the same
height aiming at different
angles, for a total coverage of
360°.
These models are very
popular for long perimeter
protections of high security
sites.
FEATURES
• Total concealment of the
aiming, height and number
of photobeams installed
inside
• Sturdy aluminium extrusion
and die-casting covers
• Possibility of aiming
photobeams through 360°
horizontally
• Available in standard
heights of 1.00 m, 1.50 m,
2.00 m, 2.50 m and 3.00 m
• Excellent resistance to
atmospheric agents and
condensation
SPECIFICATIONS
Model
Material
Screen
Covers
Colour
Size mm (WxDxH)
Base
IP rating
www.hesa.com
4598/1
188x330x1000
4598/1.5
4598
4598/2.5
painted aluminium extrusion
black acrylic IR transparent
aluminium casting
black
188x330x1500
188x330x2000
188x330x2500
steel black painted, 400x420x400 mm
IP54
4598/3
188x330x3000
17
GARDIAN Beam Towers
Series 4598 - Semi-cylindrical double-sided (360°) towers
DIMENSIONS (mm)
A = heights
4598/1 1.00 m
4598/1.5 1.50 m
4598
2.00 m
4598/2.5 2.50 m
4598/3 3.00 m
Front view
Side view
Top view
Series 4598
CODE
MODEL
DESCRIPTION
HE45981
HE45985
HE4598
HE45987
HE45983
4598/1
4598/1.5
4598
4598/2.5
4598/3
Semi-cylindrical double-sided (360°) beam tower, height 1.00 m
Semi-cylindrical double-sided (360°) beam tower, height 1.50 m
Semi-cylindrical double-sided (360°) beam tower, height 2.00 m
Semi-cylindrical double-sided (360°) beam tower, height 2.50 m
Semi-cylindrical double-sided (360°) beam tower, height 3.00 m
BC-4598
AX-MK3P
AP-OX/4498
AX-MK2P
4498A
4498T
Accessories*
HZF4598
Steel base for double-sided 4598 towers, WxHxD mm 400x420x400,
complete with rails and screws
HE44AOX
AP-OX/4498
Mounting plate for Optex AX-70TN/130TN/200TN,
AX-100TF/200TF and BX-100PLUS
HEAXMK2
AX-MK2P
Mounting plate for Optex AX-250/500PLUS and AX-350/650TF
HEAXMK3
AX-MK3P
Mounting plate for Optex AX-350/650DH MKIII infrared barriers
HE4498A
4498A
Tamper kit
HE4598AC
4598AC
Anticlimb tamper pressure (18 kg) switch top kit for double-sided towers
HE4498T
4498T
Heating control kit
HE4498H
4498H
Heater controlled by 4498T
HE44/18
4418
Transformer 230/18VAC for heater 4498H
HE44/25
4425
Power supplies 13.8VDC/2.5Ah
* Other beam manufacturers mounting plates available upon request
www.hesa.com
BC-4598
4498H
4418
4598AC
4425
OUTDOOR PROTECTION
18
Infrared coded beams for outdoor perimeter protection
Series 8000
FEATURES
• Optical system on three
separate lenses with
automatic solar energy
compensation
• Thermostat and heater
provided in each barrier
• Easy installation with wall
mounting brackets
provided
DESCRIPTION
• Outdoor perimeter
protection is the “New
Frontier” today against
intruder attacks. Reliability
issue in outdoors
environment has been
solved with the Outdoor
Protection Beams Series
8000, where an array of
multiple beams provide the
maximum operating
stability, even under the
worst weather conditions.
At the same time, the AND
setting of adjacent beams
eliminates any false alarm
caused by falling leaves or
birds interrupting infrared
beams.
• Installation is very simple,
one single barrier protects
an outdoor distance of
60m. Each barrier is
provided with built-in
www.hesa.com
thermostat and heating
system, steel base, output
terminals for alignment via
multi-meter and connection
terminals.
• Each barrier has multiple
beams, each beam is
made by 4 coded infrared
rays to prevent crosstalks
caused by mutual
interferences.
All emitting LEDs are located at one end, all receiving
diodes at the opposite end.
• The choice of 4 different
heights: 1.00m with 2
beams, 1.50m with 3
beams, 2.00m with 4
beams and 2.50m with 5
beams allows to select the
right barrier for the best
protection according to
the installation
requirements.
• DIP switch setting:
AND/OR operation, beam
interruption time and
environmental monitoring
circuit
• Range: Outdoor 60m at
80% attenuation
• Heights: 1.00m with 2
beams, 1.50m with 3
beams, 2.00m with 4
beams, 2.50m with 5
beams
• Alarm solid state relay and
environmental
disqualification solid state
relay
• Output terminals for
alignment via multi-meter
• Alarm and disqualification
LED indicators
• Tamper protection
• IP55
• Very thin profile for smooth
integration in any
environment
19
Infrared coded beams for outdoor perimeter protection
Series 8000
SPECIFICATIONS
Model
Power Supply
Current Consumption (at 12VDC):
Transmitter
8100
8150
8200
8250
25mA
(50mA)*
15mA
35mA
(60mA)*
15mA
11.5 ~ 14.5VDC
Receiver
Thermostat & Heater Power Supply
Heater Current Consumption
Detection range (outdoor)
Interruption Time
2 Beams Interruption Alarm
Environmental Disqualification
Attenuation allowed
Alarm Relay
Alarm Disqualification Relay
Monitor Output for alignment
via multi-meter
Tamper
Operating Temperature
Weatherproof
Dimensions (mm)
Accessories provided
Colour
15mA
(25mA)*
15mA
20mA
(40mA)*
15mA
135mA
200mA
24VAC
265mA
60m
selectable by DIP switch: fast (90 ms) / slow (120 ms)
selectable by DIP switch: AND / OR
selectable by DIP switch: no alarm / alarm released
> 80%
Solid state N.C. 100mA @ 60 VDC
Solid state N.C. 100mA @ 60 VDC
330mA
YES, on the terminal block
N.C. opens on fastening screw removal
–20°C ~ +60°C
IP55
Ø 50 x 1130
Ø 50 x 1630
Ø 50 x 2130
Ø 50 x 2630
Wall mounting brackets, 150mm long, optional extensions on demand
Black
* in AND mode
DIMENSIONS (mm)
1000 ÷ 2500
72
72
Series 8000
CODE
MODEL
DESCRIPTION
HE8100
HE8150
HE8200
HE8200
8100
8150
8200
8250
Outdoor protection beam, height 1.00m, 2 beams
Outdoor protection beam, height 1.50m, 3 beams
Outdoor protection beam, height 2.00m, 4 beams
Outdoor protection beam, height 2.50m, 5 beams
AL-8000
MA-8000
SL-8000
G400-6000
G500-6000
BATINF600
Power supply 230VAC/24VAC - 12VDC
Alignment tool
Lamp fixture base
Clear polycarbonate bubble, ’ 400mm
Clear polycarbonate bubble, ’ 500mm
Battery 12VDC, 0.5Ah
Accessories
HE80AL
HE80MA
HE80SL
HE60G40
HE60G50
HEINF6BT
www.hesa.com
SL-8000
G400-6000
AL-8000
BATINF600
OUTDOOR PROTECTION
20
Wall Protection Beams
Series 7000
FEATURES
• A reliable and easy solution
for building wall protection
• Coded infrared optical
system on three separate
lenses with automatic solar
energy compensation
• Thermostat and heater
provided in each barrier
• DIP switch setting: AND/OR
operation, beam
interruption time and
environmental monitoring
circuit
• Range: Outdoor 70m at
80% attenuation
• Heights: 1.00m with 4
beams, 1.50m with 5
beams, 2.00m and 2.50m
with 7 beams
DESCRIPTION
Outdoor perimeter protection
is the “New Frontier” today
against intruder attacks.
Reliability issue in outdoors
environment has been solved
with the Wall Protection
Beams Series 7000, where an
array of multiple beams
provide the maximum
operating stability, even
under the worst weather
conditions.
www.hesa.com
At the same time, the AND
setting of adjacent beams
eliminates any false alarm
caused by falling leaves or
birds interrupting infrared
beams.
Installation is very simple, as
one single barrier protects an
entire front of a building up
to a distance of 70m. Each
barrier is provided with
thermostat and heating
system built-in, wall
mounting brackets, output
terminals for alignment via
multi-meter and connection
terminals.
Each barrier has multiple
beams, each beam is made
by 3 coded infrared rays to
prevent crosstalks caused by
mutual interferences.
All emitting LEDs are located
at one end, all receiving
• Easy installation with wall
mounting brackets
provided
• Alarm solid state relay and
environmental
disqualification solid state
relay
• Output terminals for
alignment via multi-meter
• Alarm and disqualification
LED indicators
• Tamper protection
• IP55 Weatherproof
diodes at the opposite end.
The choice of 4 different
heights, 1.00m with 4 beams,
1.50m with 5 beams, 2.00m
with 7 beams and 2.50m with
7 beams allows to select the
right barrier for the best
protection according to the
installation requirements.
21
Wall Protection Beams
Series 7000
SPECIFICATIONS
Model
Power Supply
Current Consumption (at 12VDC)
Thermostat & Heater Power Supply
Detection range (outdoor)
Interruption Time
2 Beams Interruption Alarm
Environmental Disqualification
Attenuation allowed
Alarm Relay
Alarm Disqualification Relay
Monitor Output for alignment
via multi-meter
Tamper
Operation Temperature
Weatherproof
Dimensions (mm)
Accessories provided
Colour
Weight g (without mounting brackets)
1 m couple
1.5 m couple
2 m couple
7100
7150
7200
100mA
130mA
160mA
24VAC
70m
selectable by DIP switch: fast (90 ms) / slow (120 ms)
selectable by DIP switch: AND / OR
selectable by DIP switch: no alarm / alarm released
> 80%
Solid state N.C. 100mA @ 60 Vc.c.
Solid state N.C. 100mA @ 60 Vc.c.
YES, on the terminal block
N.C. opens on fastening screw removal
–20°C ~ +60°C
IP55
Ø 50 x 1130
Ø 50 x 1630
Ø 50 x 2130
Ø 50 x 2630
Wall Mounting Brackets, 150mm long, optional extensions on demand
Black
2000
3000
4000
DIMENSIONS (mm)
1130 ÷ 2630
50
50
Series 7000
CODE
MODEL
DESCRIPTION
HE7100
HE7150
HE7200
HE7250
7100
7150
7200
7250
Wall Protection Beam, height 1.00m, 4 beams
Wall Protection Beam, height 1.50m, 5 beams
Wall Protection Beam, height 2.00m, 7 beams
Wall Protection Beam, height 2.50m, 7 beams
S17-7000
Kit 4 brackets L = 17cm for mounting on the wall barriers Series 7000
Accessori
HE7000S17
www.hesa.com
7250
11.5 ~ 14.5VDC
OUTDOOR PROTECTION
22
Active Infrared Beams
BX-100PLUS
BX-100PLUS
Photoelectric detector for
building perimeter,
60 m range
APPLICATIONS
FEATURES
• Dual IR pulsed beam system
• Internal sounder
• Easy alignment with visual
and audible indicator
• Light Reduction Filter
• 99% beam blocking
stability
• N.O. and N.C. relay outputs
• Active Infrared Technology
• Slim design
DETECTION RANGE
DESCRIPTION
The BX-100PLUS consists of a
pair of small, discreet dualinfrared beams designed to
protect the immediate
perimeter of a building. The
beams are particularly useful
in providing coverage for
windows, doors and roller
shutter doors and can be used
to activate an intruder alarm
system, lights or CCTV before
a break-in occurs, minimising
damage to property and risk to
on-site personnel.
Retail
SPECIFICATIONS
DIMENSIONS (mm)
Business
Model
Maximum detection range
Maximum arrival range
Interruption period
Power supply
Current consumption
(transmitter + receiver)
Alarm period
Domestic
BX-100PLUS
Industrial
BX-100PLUS
30m
300m
50 msec.
10.5 - 28V DC
75mA (max.)
2 ± 1 sec. (delay)
2 relay outputs N.O. and N.C.
Relay output
28V DC 0.2A (max.) each
Beeping period
15 ± 1 sec. (delay)
Volume of audible alarm indicator Approx. 70dB (at 1 meter distance)
Tamper switch
N.C. opens when cover is removed
Operating temperature
-35°C to +55°C
Environmental humidity
95% max.
Alignment angle
±92° Horizontal
Mounting
Wall
IP rating
IP54
Weight (transmitter+receiver)
400g
CODE
MODEL
DESCRIPTION
OXBX100
BX-100PLUS
Photoelectric detector for building perimeter, range 60m
WC-1
MG-1
SP-1
White decorative cover
Vandal and tamper resistant metal guard
Spacer unit mm 50
Accessories
OXBXWC1
OXBXMG1
OXBXSP1
www.hesa.com
WC-1
MG-1
SP-1
23
Outdoor PIR detectors
BX-80N, BX-80NR
BX-80N
Outdoor PIR detector for
building perimeter. Detection
range 24m (12m on each
side)
BX-80NR
Battery operated outdoor PIR
detector for building
perimeter. Detection range
24m (12m on each side)
BX-80N
BX-80NR
FEATURES
• Patented double conductive
shielding
• Advanced temperature
compensation
• Limited detection range
function
• Size judging function to
avoid false alarms
• Variable detection range up
to 24m (12m on each side)
• Audible alarm indicator to
deter intruders
• Attractive, slender design
• Battery saving circuit
(BX-80NR only)
• Form C alarm output and
tamper output
(BX-80NR only)
• Low current draw
(BX-80NR only)
DESCRIPTION
With long, narrow detection
areas that extend from both
its sides the BX-80N is
specifically designed to be
wall-mounted centrally on a
building, covering the building
perimeter with a multilayered, horizontal barrier that
detects intruders before they
break in. To help reduce false
activations, the range can be
adjusted so that detection
extends only to the end of the
building. The unit also has a
size-judging function, which
helps it discriminate between
large and small objects within
the detection area.
The BX-80NR is quick and
easy to install. This unit
requires no complicated
wiring as it is a battery
operated PIR detector. Not
only does one save on
installation time and cost,
but an added benefit of the
unit is its slick design that
blends in with any
architecture.
The BX-80NR offers flexible
features. It can easily be
added on to any wireless
system which has already
been installed as this unit is
effective with any
manufactures' transmitter
and receiver.
In addition, this high-tech
detector, designed to be wallmounted centrally on a
building, is a new concept in
outdoor protection as it
increases the effectiveness a
security system.
DETECTION RANGE (m)
Front view
12
10
5
0
5
10
12
Approx. m 1.3
at m 12
The angles of all detection areas are
adjustable horizontally 0° or 3°
The angles of all detection areas
are adjustable horizontally 0° or 3°
Detection Area: 12m (single side)
Side view
12
10
5
0
0
5
10 12
Detection Area: 8m (single side)
5
10
12
Detection Area: 5m (single side)
0
5
10
12
Detection Area: 2m (single side)
Multiple Detection Pattern
www.hesa.com
0
5
10
12
OUTDOOR PROTECTION
24
Outdoor PIR detectors
BX-80N, BX-80NR
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current consumption
Alarm period
Alarm output
Battery saving time
Tamper switch
Warm-up period
Volume of audible alarm
LED indicator
Operating temperature
Environmental humidity
RF interference
Mounting height
Mounting
IP rating
Weight
BX-80N
BX-80NR
24m (12m on each side)
4 zones (2 zones on each side)
2.0°C at 0.6m/sec.
0.3m - 2.0m/s
0.3m - 1.5m/s
10 - 28 VDC
3 - 9VDC lithium or alkaline Battery
38mA (max.)
3mA(Walktest, LED on)
15µA(Standby)
2 ± 1 sec.
2 relay outputs N.O. and
Form C-Solid state switch:
N.C. 28 VDC 0.2A (max.) each
10V DC 0.01A
–
Approx. 120 sec. or 5 sec.
N.C. opens when cover removed
Approx. 45 sec. (LED blinks)
Approx. 2 min.
Approx. 70dB (at 1 meter distance)
–
LED is blinking during warm-up
Disable during normal operation
Alarm condition
Enable during walktest
-20°C to +50°C
95% max.
No Alarm 20V/m
0.8m ~ 1.2m
Wall
IP55
400g
520g
DIMENSIONS (mm)
BX-80N
BX-80NR
CODE
MODEL
DESCRIPTION
OXBX80N
BX-80N
OXBX80W
BX-80NR
Outdoor PIR detector for building perimeter.
Detection range 24m (12m on each side)
Battery operated Outdoor PIR detector for building perimeter.
Detection range 24m (12m on each side)
Accessories
OXBXMG1
OXBXBA1
OXBXSP2
www.hesa.com
MG-1
BA-1W
SP-2
Vandal and tamper resistant metal grid (BX-80N only)
Multi angle wall mount bracket
Spacer unit (BX-80N only)
MG-1
BA-1W
SP-2
25
Active Infrared Beams for doors & windows protection
2nd level
Series 5000 and 5000T
DESCRIPTION
Coded Infrared Barriers Series
5000 and 5000T represent a
reliable, complete and cost
effective outdoor perimeter
protection against
undesiderable intrusions. With
the protection of Series 5000
Barriers it is possible to leave
doors and windows open with
the confidence that any
intrusion is immediately
detected by the alarm system.
Each beam in made by 2
separate and independent
infrared rays, to avoid that a
large insect may interrupt the
beam and cause an alarm.
FEATURES
• 2 versions: with1.80 m wire
(Series 5000) or with
terminal block (Series
5000T)
• Optional removal tamper
switch
• Sturdy aluminium
structure, low profile
• Thin slot (7.5 mm) for
infrared rays transmission
• Self-alignment system with
automatic beam
synchronization
• Two operating modes:
OR or AND
• Protection:
- skylights: height 0.60 m.
with 2 coded beams
- skylights: height 1.10 m.
with 4 coded beams
- skylights: height 1.60 m.
with 5 coded beams
- skylights: height 2.10 m.
with 7 coded beams
• Perfect matching with the
existing window and door
frames: white or black
colour, optional profile
extension
• Mounting between frame
and roller shutter or
jalousie
• Possibility to have a
complete intrusion
protection, still keeping
doors and windows open
• Highest operating reliability
• IMQ 2nd level Certification
Active
Infrared
Emitting
Diode
A
Max. distance m 5
SPECIFICATIONS
Model
Power input
Current drain @13.8VDC: Transmitter
standby
Receiver
alarm
Maximum detection range (outdoor)
Sampling time
Maximum allowed obscuration
Alarm relay
Tamper contact
Wall removal protection
Operating temperature
IP rating
Dimensions:
series 5000 height (A)
series 5000T height (B)
LxW
Weight g
* * IMQ Security Systems - 2° level Certification
www.hesa.com
5050B/N
5050TB/N
5051B/N
5100B/N
5051TB/N* 5100TB/N
20mA
22mA
27mA
NO
YES
587 mm
607 mm
450
5110B/N
5150B/N
5151B/N 5200B/N
5210B/N
5110TB/N* 5150TB/N 5151TB/N* 5200TB/N 5210TB/N*
11.5 ~ 14.5VDC
30mA
40mA
49mA
31mA
39mA
50mA
47mA
56mA
83mA
5.00m
90 ms
50%
N.C., 2A @ 30VDC
N.C., with cover in place
NO
YES
NO
YES
NO
YES
–20°C ~ +60°C
IP54
1087 mm
1587 mm
2087 mm
1107 mm
1607 mm
2107 mm
25 mm x 23 mm
900
1400
1800
OUTDOOR PROTECTION
26
Active Infrared Beams for doors & windows protection
Series 5000 and 5000T
DIMENSIONS (MM)
Version with
terminal block
Front view
Version with 1.80 m wire
Side view
Front view
Series 5000
Side view
Series 5000T
CODE
MODEL
HE505B
HE505N
HE5051B
HE5051N
HE510B
HE510N
HE511B
HE511N
HE515B
HE515N
HE5152B
HE5152N
HE520B
HE520N
HE521B
HE521N
5050B
5050N
5051B
5051N
5100B
5100N
5110B
5110N
5150B
5150N
5151B
5151N
5200B
5200N
5210B
5210N
HE50TB
HE50TN
HE502TB
HE502TN
HE51TB
HE51TN
HE512TB
HE512TN
HE515TB
HE515TN
HE5153B
HE5153N
HE52TB
HE52TN
HE522TB
HE522TN
5050TB
5050TN
5051TB*
5051TN*
5100TB
5100TN
5110TB*
5110TN*
5150TB
5150TN
5151TB*
5151TN*
5200TB
5200TN
5210TB*
5210TN*
DESCRIPTION
Series 5000 - 1.80 m wire version
2 beams infrared coded barrier 0.60 m, white colour
2 beams infrared coded barrier 0.60 m, black colour
2 beams infrared coded barrier 0.60 m, white colour with removal tamper switch
2 beams infrared coded barrier 0.60 m, black colour with removal tamper switch
4 beams infrared coded barrier 1.10 m, white colour
4 beams infrared coded barrier 1.10 m, black colour
4 beams infrared coded barrier 1.10 m, white colour with removal tamper switch
4 beams infrared coded barrier 1.10 m, black colour with removal tamper switch
5 beams infrared coded barrier 1.60 m, white colour
5 beams infrared coded barrier 1.60 m, black colour
5 beams infrared coded barrier 1.60 m, white colour with removal tamper switch
5 beams infrared coded barrier 1.60 m, black colour with removal tamper switch
7 beams infrared coded barrier 2.10 m, white colour
7 beams infrared coded barrier 2.10 m, black colour
7 beams infrared coded barrier 2.10 m, white colour with removal tamper switch
7 beams infrared coded barrier 2.10 m, black colour with removal tamper switch
Series 5000T - Terminal block version
2 beams infrared coded barrier 0.60 m, white colour
2 beams infrared coded barrier 0.60 m, black colour
2 beams infrared coded barrier 0.60 m, white colour with removal tamper switch
2 beams infrared coded barrier 0.60 m, black colour with removal tamper switch
4 beams infrared coded barrier 1.10 m, white colour
4 beams infrared coded barrier 1.10 m, black colour
4 beams infrared coded barrier 1.10 m, white colour with removal tamper switch
4 beams infrared coded barrier 1.10 m, black colour with removal tamper switch
5 beams infrared coded barrier 1.60 m, white colour
5 beams infrared coded barrier 1.60 m, black colour
5 beams infrared coded barrier 1.60 m, white colour with removal tamper switch
5 beams infrared coded barrier 1.60 m, black colour with removal tamper switch
7 beams infrared coded barrier 2.10 m, white colour
7 beams infrared coded barrier 2.10 m, black colour
7 beams infrared coded barrier 2.10 m, white colour with removal tamper switch
7 beams infrared coded barrier 2.10 m, black colour with removal tamper switch
* IMQ Security Systems - 2° level Certification
Accessories
HE519B
5190B
HE519N
5190N
www.hesa.com
Connecting extrusion, H1.50 m, supplied with 2 stoppers and a slot in the profile at each end.
It can be cut as required, white colour
Connecting extrusion, H1.50 m, supplied with 2 stoppers and a slot in the profile at each end.
It can be cut as required, black colour
27
Double PIR detectors for windows and doors
HE-100 Series
HE-100
Double PIR detector, detection
range m 2, narrow angle,
white colour
HE-110
Double PIR detector, detection
range m 2, narrow angle, low
current version, white colour
HE-101
Double PIR detector, detection
range m 2, narrow angle,
brown colour
HE-111
Double PIR detector, detection
range m 2, narrow angle, low
current version, brown colour
DESCRIPTION
Designed to be mounted on the top side of window or door to be protected offer two PIR sensors
with narrow curtain coverage.
SPECIFICATIONS
Model
Power input
Current drain
stand-by
alarm
Detection zones
Alarm output
Tamper
Alarm LED Indicator
Operating temperature
Operating humidity
IP rating
Colour
Dimensions mm (LxWxH)
Weight g
HE-100
HE-101
11.5 ~ 16VDC
10 mA
3 mA
HE-110
HE-111
3.6 ~ 6VDC (3.6V lithium battery built in)
75µA
1mA
4
N.C. relay 1A@30VDC
open collector 100mA@45VDC
N.C., open when cover is removed
ON/OFF selectable
-20°C ~ +50°C
85% max
IP54
White
Brown
White
Brown
200x40x30
280x40x30
101
157
DIMENSIONS (mm)
FEATURES
• Selectable 1 or 2 pulse count
• Alarm LED indicator
selectable ON/OFF
• Tamper swicth
• Fresnel lenses
• Automatic temperature
compensation
• Low current version for
wireless systems (wireless
trasmitter not included)
• AND/OR selectable operating
function
• Compact design
DETECTION RANGE (m)
Side view
Front view
40
200
30
HE-100 / HE-101
2
40
34°
280
30
HE-110 / HE-111
0.5
CODE
MODEL
DESCRIPTION
HE100
HE101
HE110
HE111
HE-100
HE-101
HE-110
HE-111
Double PIR detector for windows and door, white
Double PIR detector for windows and door, brown
Double PIR detector for windows and door, low current version, white
Double PIR detector for windows and door, low current version, brown
www.hesa.com
1.2
OUTDOOR PROTECTION
28
Outdoor PIR detectors
HX-80N, HX-80NAM e HX-80NRAM
DESCRIPTION
The HX-80N provides multiple
pattern detection area with 20
highly density detection zones
and accurate discrimination
function for spot temperature
changes of moving objects.
HX-80N
High mount outdoor PIR detector, 24m long and narrow range
HX-80NAM
High mount outdoor PIR
detector, 24m long and
narrow range, with
antimasking
HX-80NRAM
High mount outdoor PIR
detector, 24m, low power
consumption, with
antimasking
FEATURES
• 24m x 2m narrow coverage
• Mounting height 2.5m~3m
• Multiple pattern detection
area technology with
unique pyro-element
• Digital anti-masking
function (HX-80AM only)
• Intelligent AND logic Dual
signal processing circuit
- Summer night
compensation logic
- Advanced temperature
compensation logic
- Vegetation sway analysis
logic
• Patented double conductive
shielding
• Ideal detection area setting
- adjustable detection length
- spot area flexible masking
• 180° angle adjustable
bracket / hood
The HX-80AM has all the
features of the HX-80 but in
addition, provides unique
Multi Anti-Masking
Technology. Optex has
developed the world's first
Anti-Masking Technology to
prevent any kind of detecting
disturbances by applying and
developing various forms of
anti-masking optical
technology. Twin-Window
detects with high sensitivity
the variations of optical
expansions and optical
direction differences caused
from two photoelectric
detection beams.
DETECTION RANGE (m)
DIMENSIONS (mm)
Top view
Including bracket
24 m
93
286
1.0 m
0
197.5
1.0 m
Side view
24 m
4
8
12
16
20
a
3.0 m
Without bracket
93
b
j i
h
g
f
e
d
c
197.5
24 m
4
8
12
16
20
a
2.5 m
b
j i h
www.hesa.com
g
f
e
d
c
205
29
Outdoor PIR detectors
HX-80N, HX-80NAM e HX-80NRAM
SPECIFICATIONS
Model
Power input
Power drain
HX-80N
HX-80NAM
HX-80NRAM
3 ~ 7.2VDC
30 µA (standby)
4mA (max) @ 3VDC
9,5 ~18 VDC
35mA (max.)
40mA (max.)
Pir coverage
Sensitivity
Detectable speed
RF interference
24m x 2m narrow / 20 zones
2.0°C at 0.6 m/s
0.3 m/s - 1.5 m/s
No alarm 10V/m
Alarm output
Form C
Solid State Switch
10Vc.c. @ 0.01A (max)
Form C 28VDC 0.2A (max)
Alarm period
2.0 ± 1s
Trouble output
–
N.C., 28VDC, 0,1 A (max) N.C. open
when cover removed
Tamper output
Warm-up period
Anti-masking
Operating temperature
Environment humidity
Weatherproof
Mounting
Mounting height m
Bracket adjust angle
Weight g
N.C./N.O. Selectable
Solid State Switch
10Vc.c. @ 0.01 A max
Form C., 28VDC,
0,1 A (max) activates
when cover removed
N.C. 28VDC, 0.1A max
Approx. 60s (LED blinks)
–
Approx. 90s (LED blinks)
YES
–20°C ~ +60°C
95% (max.)
IP 55
wall
2.5~3.0m
V ±20°, H ±95°
720
780
APPLICATIONS HX-80
Residential
Commercial
CODICE
ARTICOLO
DESCRIZIONE
OXHX80N
HX-80N
High mount outdoor PIR detector, 24m long and narrow range
OXHX80NAM HX-80NAM
OXHX80NRAM HX-80NRAM
www.hesa.com
Industrial
High mount outdoor PIR detector, 24m long and narrow range, with antimasking
High mount outdoor PIR detector, 24m, low power consumption, with antimasking
OUTDOOR PROTECTION
30
Outdoor PIR detectors
HX-40, HX-40AM, HX-40RAM, HX-40DAM
HX-40
High mount outdoor PIR
detector, detection range 12m
HX-40AM
High mount outdoor PIR
detector with anti-masking
technology,
detection range 12m
DESCRIPTION
The HX-40 provides multiple
pattern detection area with
94 highly density detection
zones and accurate
discrimination function for
spot temperature changes of
moving objects.
HX-40RAM
High mount outdoor PIR
detector with anti-masking
technology, low current
version,
detection range 12m
HX-40DAM
High mount outdoor PIR&MW
detector with anti-masking
technology, detection range
12m
The HX-40AM, HX-40 RAM
and HX-40DAM have all the
features of the HX-40 but in
addition, provides unique
Multi Anti-Masking
Technology. Optex has
developed the world's
first Anti-Masking Technology
to prevent any kind of
detecting disturbances by
applying and developing
various forms of antimasking optical technology.
• Intelligent AND logic Dual
signal processing circuit
– Summer night
compensation logic
– Advanced temperature
compensation logic
– Vegetation sway analysis
logic
• Patented double conductive
shielding
• Ideal detection area setting
– adjustable detection length
– spot area flexible masking
• 180° angle adjustable
bracket / hood
• Low current version
(HX-40RAM)
• PIR&MW version
(HX-40DAM)
• Micro-wavw Intelligent
Quantification logic
(HX-40DAM only)
Twin-Window detects with
high sensitivity the variations
of optical expansions and
optical direction differences
caused from two photoelectric
detection beams.
DIMENSIONS (mm)
FEATURES
• 12m 85° wide coverage
• Mounting height 2.5m~3m
• Multiple pattern detection
area technology with
unique pyro-element
• Digital anti-masking
function (HX-40AM,
HX-40RAM, HX-40DAM
only)
Using bracket and hood
99
266
205
Without bracket and hood
92
148
DETECTION RANGE
197
8
Vista dall’alto
Microonda
(HX-40DAM)
Vista laterale
12
0
3
12
PIR
3
8
www.hesa.com
12
HX-40 / HX-40AM /
HX-40RAM / HX-40DAM
31
Outdoor PIR detectors
HX-40, HX-40AM, HX-40RAM, HX-40DAM
SPECIFICATIONS
Model
Detection method
Anti-masking
PIR coverage
Distance limit
Detectable speed
Sensitivity
Power input
Current draw
Alarm period
Warm-up period
Alarm output
Tamper output
Trouble output
Aux input
LED indicator
RF Interference
Operating temperature
Environment humidity
IP rating
Mounting
Mounting height
Bracket adjust angle
Weight
HX-40
HX-40AM
Passive infrared
HX-40RAM
HX-40DAM
Passive infrared & Microware
–
YES
12 m (40 ft.) 85° wide / 94 zones
4 m, 5.5 m, 9 m, 12 m (13 ft, 18 ft, 30 ft, 40 ft.)
0.3 - 1.5 m/s (1 - 5 ft/s)
2.0°C (3.6°F) at 0.6 m/s
9.5 - 18VDC
2.5 - 9 VDC Lithium Battery
9.5 - 18VDC
35 mA (max) at 12VDC
40 mA (max) at 12VDC
4 mA (max) at 3VDC
50 mA (max) at 12VDC
2.0 ± 1 sec
Approx. 60 sec(LED blinks)
Approx. 90 sec(LED blinks) Approx. 60 sec(LED blinks)
Form C 28VDC 0.2A max
Form C 10VDC 0.01A max
Form C 28VDC 0.2A max
N.C. 28V DC, 0.1A max.
N.C. 10VDC, 0.01A max.
N.C. 28V DC, 0.1A max.
N.C. open when cover removed
N.C. open when cover removed N.C.open when cover removed
N.C. 28V DC, 0.1A max
N.C./N.O. Solid State Switch
N.C. 28V DC, 0.1A max.
10VDC, 0.01A max.
N.C. 28V DC, 0.1A max
–
N.C. 28V DC, 0.1A max
Red: Warm-up, Alarm
Red: Warm-up, Alarm, Trouble
Normaly disable
Red: Warm-up, Alarm, Trouble
Enable during walk test
Green: Warm-up, PIR detect
Red: Warm-up, Alarm,
Yellow: Warm-up, MW detect
Trouble, Low battery
No alarm 10 V/m
-20 ~ +60°C
95% max
IP55
Wall (Outdoor, Indoor)
2.5 - 3.0 m
Vertical: ± 20° Horizon: ± 95°
600g
700g
CODE
MODEL
DESCRIPTION
OXHX40
OXHX40AM
OXHX40RAM
OXHX40DAM
HX-40
HX-40AM
HX-40RAM
HX-40DAM
High mount outdoor PIR detector, detection range 12m
High mount outdoor PIR detector with anti-masking technology, detection range 12m
High mount outdoor PIR detector with anti-masking technology, low current version, detection range 12m
High mount outdoor PIR & Microwave Double technology detector with anti-masking technology,
detection range 12m
www.hesa.com
OUTDOOR PROTECTION
32
Outdoor PIR detectors
VX-402, VX-402R (low current version), VX-402REC (voice warning version)
VX-402
Multiple detection pattern
outdoor PIR detector.
Detection range 12m, 90°
VX-402R
Multiple detection pattern
outdoor PIR detector with low
current draw. Detection range
12m, 90°
VX-402REC
Multiple detection pattern
outdoor PIR detector with
voice warning function.
Detection range 12m, 90°
FEATURES
• Limited detection range
function
• Size judging function
• Patented double conductive
shielding
• Sensitivity selection switch
• Photocell for day and night
operation
• Temperature compensation
• Selectable NC or NO alarm
output
• External speaker terminal
• Battery saving circuit
(VX-402R only)
• From C alarm output and
tamper output (VX-402R
only)
• Low current draw (VX-402R
only)
• Limited detection range
function (VX-402R only)
• Easy voice recording
• Voice warning function
(VX-402R only):
- Sequential playback
- Directional detection
playback
- Day/night message
playback
- Arm/Disarm playback
www.hesa.com
DETECTION RANGE (m)
Side view
Top view
A m 12
1
0
0
5
10 12
Bm8
1
0
0
5
10 12
1
0
0
5
5
5
Active detection zones
(90° wide, 7
fingers)
0
Cm5
5
Dm2
10
12
10 12
1
0
0
Adjustable zones
(15° per notch)
12
10
10 12
When only the lower zone detects a moving object, the unit is not activated.
DESCRIPTION
The VX-402 provides an
innovative solution to external
area detection. It employs a
highly reliable dual detection
technique, which prevents
false activations caused by
small animals and birds.
Two discrete detection areas
are created and only when an
intruder is detected inside
both areas is an alarm output
triggered.
Double Conductive Shielding
ensures that the sensor is
resistant to interference from
foreign light sources such as
the sun and car headlights.
In addition, the VX-402REC
provides great flexibility in
detector-activated voice
applications as well as the
ability to record messages in
any language.
With its superior playback
settings, it allows the right
message to be played in every
situation.
The VX-402R can be
integrated into wireless
security systems.
Adjustable zones
(15° per notch)
0
5 10 12
When only the upper zone detects a moving object, the unit is not activated.
When both the upper & lower zones detect
a moving object, the unit is activated.
33
Outdoor PIR detectors
VX-402, VX-402R (low current version), VX-402REC (voice warning version)
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current consumption
Alarm period
Alarm output
Battery saving timer
Tamper switch
Pulse count
Warm up period
LED indicator
Operating temperature
Environmental humidity
RF interference
Mounting height
Mounting
VX-402
9.5 - 18 VDC
N.C.: 28mA (max.)
N.O.: 35mA (max.)
2 ± 1 sec.
Selectable N.C./N.O.
28 VDC 0.2A max.
–
N.C. opens when cover removed
20 ± 5 sec. 2 or 4
Approx. 30 sec. (LED blinks)
LED is blinking during warm-up
Alarm condition
Recording condition
VX-402R
12m 90° wide
14 zones
2°C at 0.6m/s
0.3m -1.5m/s
3 - 9 VDC lithium or alkaline battery
3mA (walktest, LED on)
10µA (standby)
Approx. 2.5 sec.
Form C - solid state switch:
10VDC 0.01A
Approx. 120 sec. or 5 sec.
Form C opens when cover removed
Approx. 20 sec. 2 or 4/(1pulse)
Approx. 2 min.
Disable during normal operation
Enable during walk test
VX-402REC
9.5 - 18 VDC
NC: 180mA (max.)
NO: 200mA (max.)
2 ± 1 sec.
Selectable N.C./N.O.
28 VDC 0.2A max.
–
N.C. opens when cover removed
20 ± 5 sec. 2 or 4
Approx. 30 sec. (LED blinks)
LED is blinking during warm-up
Alarm condition
Recording condition
-20°C to +50°C
95% max.
No Alarm 30V/m
0.8m - 1.2m
Wall, pole, conduit and
electrical box
IP rating
Weight
550g
Wall, pole
IP54
480g
Wall, pole, conduit and
electrical box
550g
DIMENSIONS (mm)
VX-402R
VX-402 / VX-402REC
CODE
MODEL
DESCRIPTION
OXVX402
OXVX40W
OXVX40R
OXVXC40
VX-402
VX-402R
VX-402REC
VXC40
Multiple detection pattern outdoor PIR detector. Detection range 12m, 90°
Multiple detection pattern outdoor PIR detector with low current draw. Detection range 12m, 90°
Multiple detection pattern outdoor PIR detector with voice warning function. Detection range 12m, 90°
Replacement cover and lens
www.hesa.com
OUTDOOR PROTECTION
34
Outdoor PIR detectors
LX-402, LX-802N
LX-402
Wide angle,
detection range m 12x15,
120°
LX-802N
Narrow and long range,
detection range m 24x2
SPECIFICATIONS
DESCRIPTION
The LX Series is robust,
weatherproof and specifically
designed for short-range
outdoor applications. With
wide-angle and long-range
options, advanced features
such as sensitivity and range
adjustment and a built-in
light sensor providing day
and night modes, the LX
Series is highly versatile. An
ingenious mirror assembly
provides a pet alley
configuration and Double
Conductive Shielding ensures
that the sensor is resistant to
interference from foreign light
sources such as the sun and
car headlights.
FEATURES
• Patented double conductive
shielding
• Patented double conductive
shielding
• Selectable detection
patterns
(Pet Alley or Multi-Level)
• Area-masking strips
(LX-402 only)
• Sensitivity selection switch
(high, mid and low)
• Selectable pulse count
(test or 2)
• Day & night modes
DETECTION RANGE (m)
Model
LX-402
LX-802N
Coverage
12m x 15m 120°
24m x 2m
Detection zones: Multi-level
40 zones
12 zones
Pet
18 zones
4 zones
Sensitivity
Selectable 3 position (High / Middle / Low)
Detectable speed
0.3m - 1.0m/sec.
Power supply
10.8 - 13.2 VDC
Current consumption
25mA max.
Alarm period
2 ± 1 sec. (delay timer)
Alarm output
N.C. N.O. 28V DC 0.2A max.
Tamper switch
Opens when cover removed
Pulse count
2 (20 ± 5 sec.) or TEST (1 pulse)
Warm up period
Approx. 60 sec.
LED indicator
LED lights during detection
Operating temperature
-20°C to +50°C
Environmental humidity
95% max.
Mounting height
Multi-level area 2.5m max.
Pet alley area 1.2m - 1.5m
Mounting
Wall
IP rating
IP54
Weight
170g
190g
Top view
LX-402
LX-802N
Side view
MULTI-LEVEL AREA
MULTI-LEVEL AREA
PET ALLEY AREA
PET ALLEY AREA
CODE
MODEL
DESCRIPTION
OXLX402
OXLX82N
LX-402
LX-802N
Outdoor PIR detector, wide angle m 12x15, 120°
Outdoor PIR detector, long range m 24x2
CA-1W
CA-2C
Wall mount bracket
Ceiling mount bracket
Accessories
OXCA-1W
OXCA-2C
www.hesa.com
CA-1W
CA-2C
35
Outdoor dual-tech detectors, with anti-masking
Series FIT
FTN-ST / FTN-AM
Multiple detection pattern
outdoor PIR detector.
Detection range 5m/2m
DESCRIPTION
FTN Series offers the perfect
solution for those outdoor
areas where environmental
disturbances and small
animals may cause false
alarm
FEATURES
• Built in bracket (190°
horizontal)
• 5m/2m switchable lens
• SMDA Logic
• Intelligent AND logic
• Digital Anti-masking
function (FTN-AM)
• Wall tamper (options)
FTN-R / FTN-RAM
Multiple detection pattern
outdoor PIR detector.
Detection range 5m/2m.
Low current version
DESCRIPTION
FTN-R/RAM are battery
operated outdoor PIR detector
and therefore requires no
complicated wiring. It saves
installation time and cost
FEATURES
• Long battery life
• Built in bracket (190°
horizontal)
• Digital Anti-masking
function (FTN-RAM)
• Wall tamper (option)
DIMENSIONS (mm)
Box
m5/m2 switchable lens
155
155
35
FTN-ST / FTN-AM
(m)
0
0.8
1.0
1.2
0
(m)
0
0.8
1.0
1.2
www.hesa.com
1
2
3
4
5 (m)
43
35
FTN-R / FTN-RAM
43
OUTDOOR PROTECTION
36
Outdoor dual-tech detectors, with anti-masking
Series FIT
DETECTION RANGE (m)
Top wiew
Side wiew
(m)1
0
1
2
Adjustable range: 95° (by 5° pitch)
3
Adjustable range: 95° (by 5° pitch)
5m detection lenght
2m detection lenght
(m)
0
0.8
1.0
1.2 0
(m)
0
0.8
1.0
1.2 0
1
2
3
4
5 (m)
1
2
3
4
5 (m)
4
5
5
4
3
2
1
0
1
2
3
4
5 (m)
SPECIFICATIONS
Articolo
Detection method
PIR coverage
Detection lenght limit
Detectable speed
Sensitivity
Operation voltage
Power input
Current draw
Alarm period
Warm-up period
Alarm output
Trouble output
LED indicator
Operation temperature
Environment humidity
IP rating
Mounting
Mounting height
Weight
FTN-ST
FTN-AM
FTN-R
FTN-RAM
passive infrared
5 x 1m
2m, 5m
0.3 – 1.5 m/s
2.0°C (at 0.6 m/s)
9.5 - 18VDC
––
2.5 - 10VDC
3 - 9 VDC (lithium or alkaline battery)
9mA (at stand-by)
10mA (at stand-by)
17mA max. (at 12VDC)
20mA max. (at 12VDC)
3mA max. (at 3VDC)
3mA max. (at 3VDC)
2.0 ± 1.0 s
approx. 60 sec (LED blinks)
approx. 120 sec (LED blinks)
N.C./N.O. selectable-solid state
N.C./N.O. selectable 28VDC 0.1 A (max.)
switch 10VDC 0.01 A (max.)
N.C. 28VDC 0.1 A (max.) open
N.C./N.O. selectable-solid state
when the cover is removed
switch 10VDC 0.01 A (max.)
- enable: during DIP switch 1 (walk test mode)
or DIP switch 4 (LED) ON
light/blink: warm-up, alarm,
- disable: during normal operation
masking detection (FTN-AM only)
light/blink: warm-up, alarm,
masking detetion (FTN-AM only)
–20°C - +60°C
95% max
IP55
wall (outdoor/indoor)
0.8m– 1.2m
100g
190g
CODE
MODEL
DESCRIPTION
OXFTNST
OXFTNAM
FTN-ST
FTN-AM
OXFTNR
FTN-R
OXFTNRAM
FTN-RAM
Multiple detection pattern outdoor PIR detector. Detection range 5m/2m
Multiple detection pattern outdoor PIR detector. Detection range 5m/2m,
anti-masking function
Multiple detection pattern outdoor PIR detector. Detection range 5m/2m,
low current version
Multiple detection pattern outdoor PIR detector. Detection range 5m/2m,
low current version, anti-masking function
WRS-02
Accessories
OXWRS02
OXWRS03
www.hesa.com
WRS-02
WRS-03
Wall tamper for FTN-ST and FTN-AM
Wall tamper for FTN-ST and FTN-RAM
WRS-03
37
Outdoor dual-tech detectors, with anti-masking
GUARD
GUARD GREY
Outdoor dual-tech detector,
with anti-masking, detection
range m 12, 110°, black color
GUARD
Outdoor dual-tech detector,
with anti-masking, detection
range m 12, 110°, white color
DESCRIPTION
The two synchronized PIR
sensors produce a threedimensional thermal
imaging of the protected
area. Combining the fourth
dimension as a microwave
scanning contributes to an
amazing detection capacity
and in the same time it also
increases the reliability and
immunity to false alarms.
Using this technique allows
high sensitivity level
adjustment in both detection
technologies without the
need of pulse count. GUARD
is equipped with unique
protection mechanisms
against any attempt to
damage or to disable its
operation, whether the alarm
system is Armed or
Disarmed:
1. Frontal Anti-masking by a
continuous active infrared
beams scan, against
masking the near field-ofview of the detector.
2. Unique 360° Antimasking by a continuous
microwave scan, against
approaching the detector
SPECIFICATIONS
Model
Power supply
Current drain
Microwave frequency
Detection range m
Detection speed
RFI immunity
Response time to masking
Masking relay activation time
Alarm contacts
Alarm time
Warm-up time
Tamper contacts
Operating temperature
IP rating
Weight g
www.hesa.com
GUARD
10VDC~16VDC
24mA @ 12VDC
10.525GHz
12x12, angle 110°
0.1 ~ 5 m/s
> 20V/m, DC to 1GHz
Up to 2 Minutes
All time of masking (at least 2 Sec)
Changeover relay (N.C. or N.O.)
0.25A @ 50VDC Max
2 sec
1 minute
N.C. 0.1A @ 28VDC max
–35°C ~ +70°C
IP65
250
from any direction
(Switchable).
3. Imposes "OR" mode in
distress. If, from any
reason, the PIR detection
channel is neutralized (for
example, the detector's
front was masked), the
microwave detection
channel will guard the
protected area.
4. Anti-case-shifting, by
inertial switch that alerts
if someone shifts, moves
or turns the detector.
5. Traditional tamper switch.
FEATURES
• 4-dimensional, all-in-one
motion detector
• Two PIR sensors
• Microwave sensor
• Waterproof and all-weather
resistant
• Pet immune
• Frontal Anti-masking, by
active infrared
• Unique 360° Anti-masking,
by microwave
• Anti-case-shifting, by
inertial switch: Alerts when
detector has been shifted
• Any adjustment may ALSO
execute remotely, from the
control-panel
• Lighting immune
• Microprocessor controlled
• Selectable PIR detection
sensitivity
• Selectable microwave
detection sensitivity
• Selectable detection
technology combination
(AND/OR)
• Memory latched input
• Wide-angle (110°)
field-of-view
• Auto temperature
compensation
• High level of RFI/EMI
immunity
• Vertical adjustment
• Multi-directional mounting
bracket (Option)
OUTDOOR PROTECTION
38
Outdoor dual-tech detectors, with anti-masking
GUARD
DETECTION RANGE (m)
DIMENSIONS (mm)
Top view
Active IR
Anti-masking
DIP switch
e
110°
LED
wav
Microwave
sensitivity
adjustment
LED
cro
Mi
8
6
4
2
0
2
4
6
8
PIR sensors
Microwave
sensor
Alarm relay
Tamper switch
Terminals
PIR
regulation
Knockouts
for wall
mounting
Mounting height fine tuning
Side view
2
Microwave
0 2 4 5 8 10 12
16
CODE
MODEL
DESCRIPTION
PR14G-B
GUARD
PR14G-G
GUARD GREY
Outdoor/Indoor intrusion detector, combined PIR & Microwave
Double technology, Anti-masking, Pet immune, 12m 110°, white color
Outdoor/Indoor intrusion detector, combined PIR & Microwave
Double technology, Anti-masking, Pet immune, 12m 110°, black color
GUARD
Accessories
PR14GBS
PR14GGS
www.hesa.com
STGUARD
STGUARD GREY
Multi-directional mounting bracket, white color
Multi-directional mounting bracket, black color
STGUARD
39
Outdoor dual-tech detectors, with anti-masking
OUT-SMART
OUT-SMART
Outdoor/Indoor dual technology intrusion detector that
combines 2 independent PIR
detection zones for increased
reliability, plus microwave
sensor
DESCRIPTION
OUT-SMART is an
Outdoor/Indoor dual
technology intrusion detector,
which maximizes movement
detection reliability by
combining two independent
PIR detection zones and a
microwave sensor. The Upper
PIR detection zone is parallel
to the ground while the Lower
FEATURES
• Dual technology: 2 x PIR
sensors plus Microwave
sensor
• Flexible installation height,
between 1~2 meters
• Pet immune
• Anti-masking
• Selectable horizontal
detection angle: 120°,
105°, 90°
• Aiming is done within the
detector, Internal unit
rotates horizontally 180°
• Detector settings can also
be controlled by Remote
Control (option)
PIR detection zone is
diagonal. Both Upper and
Lower PIR detection zone
sensitivity levels can be
adjusted separately.
OUT-SMART will alert only if
both PIR detection zones and
the supportive microwave
radiation are crossed at he
same time.
• Anti-vandalism sensor
(Shock & Vibration)
• Detection range can be
automatically changed to
a different re-programmed
detection range at night
(darkness)
• Tone indication will be
heard during any
detection event
• DVR/Camera Trigger
• Front and back Tamper
switch
• Waterproof and all
weather resistance
SPECIFICATIONS
Model
Power supply
Current drain
Alarm contact
Warm-up time
Alarm time
Response time to masking
Masking relay activation time
Detection range m
Operating temperature
IP rating
OUT-SMART
11VDC~14VDC
35mA~70 mA
N.C. 20 mA @ 15VDC
1 minute
2 sec
90 sec (max.)
All time of masking (at least 2 sec)
12m, angle 90°, 105°, 120°
–10°C ~ +60°C
IP63
CODE
MODEL
DESCRIPTION
PR17S-B
OUT-SMART
Outdoor/Indoor dual technology intrusion detector that combines
2 independent PIR detection zones for increased reliability, plus microwave
sensor
RM-1
Remote control
DIMENSIONS (mm)
214
83
95
OUT-SMART
Accessori
PR17S-T
www.hesa.com
RM-1
OUTDOOR PROTECTION
40
Outdoor dual-tech detectors, with anti-masking
OUT-LOOK
OUT-LOOK
Outdoor dual-tech detector,
with anti-masking, detection
range m 12, 110°
SPECIFICATIONS
Model
Power supply
Current drain
Microwave frequency
Detection range m
Detection speed
RFI immunity
Response time to masking
Masking relay activation time
Alarm contacts
Alarm time
Warm-up time
Tamper contacts
Operating temperature
IP rating
Weight g
OUT-LOOK
10VDC~16VDC
24mA @ 12VDC
10.525GHz
12x12, angle 110°
0.1 ~ 5 m/s
> 20V/m, DC to 1GHz
20 sec max
All time of masking (at least 2 sec)
N.C. 0.1A @ 30VDC Max
2 sec
2 minutes
N.C. 0.1A @ 30VDC max
–35°C ~ +70°C
IP65
136
DIMENSIONS (mm)
125
68
DESCRIPTION
The PIR sensor and
microwave scanning produce
a three-dimensional imaging
of the protected area.
Using this technique allows
high sensitivity level
adjustment in both detection
technologies without the
need of pulse count.
In addition to an
unprecedented amazing and
reliable detection skill,
OUTLOOK equipped with
unique protection
mechanisms against any
attempt to damage or to
disable its operation.
These following protection
mechanisms always workwhether the alarm system is
Armed or Disarmed:
FEATURES
• 3-dimensional, all-in-one
motion detector
• Dual tech (PIR+
microwave) detector
• Waterproof and all-weather
resistant
• Adjustable Pet/creep zone
• Frontal Anti-masking, by
active infrared
• Lighting immune
• Any adjustment may also
be executed remotely, from
the control-panel
• Anti-vandalism (Shock and
vibration) sensor
1. Frontal Anti-masking by a
continuous active infrared
beams scan, against
masking the near field-ofview of the detector.
2. Unique 360° Anti-masking
by a continuous microwave
scan, against approaching
the detector from any
direction (switchable).
3. Imposes "OR" mode in
distress. If, from any
reason, the PIR detection
channel is neutralized (for
example, the detector's
front was masked), the
microwave detection
channel will guard the
protected area.
4. Traditional tamper switch.
• Microprocessor controlled
• Selectable PIR detection
sensitivity
• Selectable microwave
detection sensitivity
• Selectable detection
technology combination
(AND/OR)
• Memory latched input
• Wide-angle (110°)
field-of-view
• Auto temperature
compensation
• High level of RFI/EMI
immunity
55
OUTLOOK
CODE
MODEL
DESCRIPTION
PR16K-B
OUT-LOOK
Outdoor/Indoor intrusion detector, combined PIR & Microwave
Double technology, Anti-masking, Pet immune, 12m 110°
STOTLK
RM-1
Multi-directional mounting bracket
Remote control
Accessories
PR16KBS
PR17S-T
www.hesa.com
STOTLK
41
Outdoor dual-tech detectors, with anti-masking
CURTAIN
CURTAIN
Outdoor dual-tech detector,
with anti-masking, detection
range m 10, narrow angle 3°
Example 1
www.hesa.com
DESCRIPTION
CURTAIN creates a super
narrow protective screen of
3° (like a curtain) to secure
openings and open fields
against intruders. This type
of protection allows free
movement of people within
the protected site- without
setting off an alarm. CURTAIN
is waterproof and can be
installed outdoors or indoors.
In addition to an
unprecedented amazing and
reliable detection capability,
CURTAIN is equipped with
excellent protection against
any attempt to disable its
operation by blocking
(masking) its near field-ofview, whether the alarm
system is Armed or Disarmed
(Anti-masking protection).
The protection against
masking the near field-ofview of the detector is
achieved by a continuous
active infrared beams scan.
CURTAIN will detect almost
any type of material that
blocks (masks) its near fieldof-view. It will also detect
transparent objects such as
clear glass and plastic bags.
It will activate an alert even
if its lens was sprayed with
paint or covered by a sticker.
CURTAIN combines two
detection technologiesMicrowave and Passive
Infrared (PIR), and verifies
any intrusion by both
methods. An advanced and
unique algorithm enables it
to work in the most difficult
environmental conditions and
where high security is
required, while maintaining
unprecedented immunity to
false alarms.
FEATURES
• Creates a super narrow
protective screen of 3°.
• Selectable Microwave and
PIR detection sensitivity
• Selectable detection
technology combination:
AND/OR
• Masking protected
(Anti-masking) by active
infrared beams
• Auto temperature
compensation
• Automatic adaptation to
background noise
• A/D signal analyzer
• Memory latched input
• Extremely reliable & highly
immune to false alarms.
• Waterproof and all-weather
resistant
• 90° wall mounting bracket
Example 2
Example 3
OUTDOOR PROTECTION
42
Outdoor dual-tech detectors, with anti-masking
CURTAIN
DETECTION RANGE
DIMENSIONS (mm)
Side view
Top view
Microw
ave
Microwave
102
43
CURTAIN
Microwave
Microwave
SPECIFICATIONS
Model
Power Supply
Current drain
standby:
operation:
Microwave frequency
Detection range m
Detection speed
RFI immunity
Response time to masking
Masking relay activation time
Alarm contacts
Alarm time
Warm-up time
Tamper contacts
Operation temperature
IP Rating
Weight g
CURTAIN
9~14 VDC
20mA
30mA
24.125GHz
10, angle 3°
0.1 ~ 5 m/s
> 20V/m, DC to 1GHz
90 sec.
All time of masking (at least 2 Sec)
relay 20mA@15VDC
2 sec
1 minute
N.C. 0.1A @ 24VDC max
–35°C ~ +70°C
IP65
80
CODE
MODEL
DESCRIPTION
PR15C-B
CURTAIN
Outdoor/Indoor intrusion detector, combined PIR & Microwave Double technology,
Anti-masking, 10 m narrow 3° angle and 90° bracket included
www.hesa.com
46
43
Outdoor dual-tech detectors
PIRAMID
SDI-77XL
Outdoor dual-tech detector,
detection range m27x15
DESCRIPTION
Dual technology intrusion
sensor combining Stereo
Doppler Microwave Technology
with a dual element Passive
Infared Sensor. The
indipendent sensor
technologies are “And Gated”
and must activate
simultaneously to create an
overall sensor alarm. It
incorporates advanced signal
processing for enhanced bird
and animal immunity. Its
sensors are unique in that
they provide reliable outdoor
volumetric protection under
even the most severe
environmental conditions.
SDI-77XL-DIR-LT
Outdoor dual-tech detector,
narrow angle detection with
direction control
www.hesa.com
The key to its success is the
unique dual channel Stereo
Doppler Microwave Portion
and its ability to ignore
randomly moving objects. An
internal sensitivity switch
selects the distance an
intruder must move to initiate
an alarm. This built-in
flexibility affords a high level
of security while virtually
eliminating false alarms.
Generally, the PIRAMID sensor
are used for strategic areas or
asset protection. They are also
frequently used in conjunction
with outdoor perimeter
systems as “gap fillers”.
DESCRIPTION
PIRAMID version specifically
designed to protect against
intruders climbing up ladders
and towers. The sensor is
configured so that
technologies must activate
simultaneously for a sensor
alarm. For protecting ladders
and tower it is generally
mounted at the top of the
structure looking downward.
FEATURES
• Stereo Doppler Microwave
Detector with 2 receiving
channels to eliminate
vibration and periodically
moving objects as sources
of false alarms
• Infrared Detectors is very
responsive to rapid infrared
changes created by an
intruder
• Microprocessor provides
enhanced digital signal
processing for both
microwave and passive
infrared technologies
• Automatically balanced
temperature compensation
• Stereo Doppler Supervision:
a component or power
failure will cause the
sensor to lock-in alarm
• Digital range control: 10
selectable positions
FEATURES
• It is equipped with a threeposition Direction Control
Switch that selects the
direction of movement
required for a sensor
alarm. The Direction
Control Switch can be set
to one of three detection
modes: 1) Approach Mode sensor detects only
approaching targets, 2)
Recede Mode - Sensor
• 3 lens supplied for
different ranges: 27x15 m,
30x10 m and 38x6 m
• Digital Sensitivity Control:
10 position digital switch
adjusts the amount of
movement required to
initiate an alarm condition
• Master Alarm LED display
the alarm relay status
• Analytic LED’s for specific
alarm and Environmental
Caution
• Swivel Mounting Bracket:
±90° Horizontal and
±45° Vertical
• Tamper proof
• Rugged, metal, weatherproof housing
• Metal hood for maximum
protection from ice, snow,
wind, sun and rain
detects only receding
targhets, 3) Both Mode Sensor detects both
approaching and receding
targets
• Narrow Angle detection
range 30x3 m
• Enhanced bird/animal
Immunity Control
• Sensitivity adjustment to
ignore movement on the
ground such as animals,
pedestrians, small vehicles
OUTDOOR PROTECTION
44
Outdoor dual-tech detectors
PIRAMID
DETECTION RANGES
SDI-77XL
SDI-77XL-DIR-LT
DIMENSIONS (mm)
120
158
240
168
SDI-77XL / SDI-77XL-DIR-LT
SPECIFICATIONS
Model
Power supply
Detection range m
Current drain
Microwave frequency
RF Power density
Alarm relay
Tamper switch
Operating temperature
Weight g
SDI-77XL
SDI-77XL-DIR-LT
8.5~20VDC
Wide angle 27x15
Medium angle 30x10
Narrow angle 30x3
Narrow angle 38x6
150mA (LED off)@12VDC
9.9GHz
120µW/cm2 max.at the face of the unit
N.C. 0.1A @ 50VDC
N.C. contact
–35°C~+55°C
2600
CODE
MODEL
DESCRIPTION
PR77XL
SDI-77XL
PR77DIR
SDI-77XL-DIR-LT
PIRAMID outdoor dual tech detector, supplied with 3 interchangeable lenses,
range m27x5, m 30x10, m 38x6
PIRAMID outdoor dual tech detector, narrow angle with direction control.
Range m 30x3
LENS-A-PET
LENS-B-PET
LENS-C-PET
PH-4
Accessories
PR77LAP
PR77LBP
PR77LCP
PR7PH4
PR7PH4A
PR7PH6
PR7PH6J
www.hesa.com
LENS-A-Pet
LENS-B-Pet
LENS-C-Pet
PH-4
PH-4A
PH-6
PH-6JB
Lens A for PET immune, m 27x15
Lens B for PET immune, m 30x10.5
Lens C for PET immune, m 38x6
Universal pole mount Ø mm 70~120
Universal pole mount Ø mm 115~216
Ladder mounting bracket
Ladder mounting bracket with junction box
PH-6
PH-6JB
45
Outdoor Shock sensors
VIBRA-SENS
VIBRA-SENS
Detector of vibration, shock
and sawing
DESCRIPTION
VIBRA-SENS detects
vibration, shock and sawing.
It consists of two parts: the
sensor which is to be firmly
attached to the protected
surface, and the electronic
card which can be placed in
a safe location inside the
site.
FEATURES
• Suitable for installation on
any grille type (curved or
flat), as well as fences &
nets
• Mounting kit for curved
grille included
• Only the detector’s sensor
should be mount on the
protected surface, while the
electronic card can be
placed in a safe location
inside the site
• Alerts in case of attempt to
disconnect or short-circuit
the sensor or its connecting
cable
SPECIFICATIONS
Model
Power supply
Current drain
Alarm relay contact
Tamper switch contact
Warm-up time
Alarm time
• Latched memory
• Fast, easy installation
• Suitable for outdoor and
indoor installations
• Adjustable detection
sensitivity
• Tamper switch
DIMENSIONS (mm)
VIBRA-SENS
8 ~ 15VDC
11mA @ 12VDC
N.C. 0.1A @ 24VDC
N.C. 0.1A @ 24VDC
Instantaneous
2 sec.
74
72
20
VIBRA-SENS
CODE
MODEL
DESCRIPTION
PR16VS
VIBRA-SENS
Detector of vibration, shock and sawing
www.hesa.com
A 2-wire cable connects the
two parts.
Once the sensor detects
vibration/shock or sawing,
the alarm relay and the LED
indicator in the electronic
card will activate for 2
seconds
20
38
ELECTRONIC CARD
20
VOLUMETRIC INDOOR
PROTECTION
Dual PIR/Microwave detectors
High-end indoor detectors
PIR detectors
VOLUMETRIC INDOOR PROTECTION
48
Dual PIR/Microwave detectors with anti-masking
C-101STLRE11, C-101STLRE15, M7300STE, M9000STE Adaptive® Series
C-101STLRE11
Dual tech detector,
range 11x10.7 m
1st level,
2nd level (with WRS-01 kit)
C-101STLRE15
Dual tech detector,
range 15x12 m
FEATURES
• For residential/commercial
applications
• Active Self-Test Supervision
of both Microwave & PIR
channels every 12 Hrs
• Trouble Output Selectable
NC or NO
DESCRIPTION
Adaptive® Dual
Microwave/PIR Detectors
automatically adjust to their
environment, minute by
minute, for the ultimate false
alarm immunity & reliability
• Patented Adaptive® technology continuously monitors the environment, counteracting false alarms and
re-sensitizing to optimize
intruder catch
• EN50131 compliant
DIMENSIONS (mm)
116
63
63
C-101STLRE11 / C-101STLRE15
140
M7300STE
Dual tech detector,
range 21x18 m
FEATURES
• For commercial application
• Alarm memory with
exit/entry delay
85
60
M7300STE
M9000STE
Dual tech detector,
range 36x3.6 m, 24x15 m and
16x13 m
FEATURES
• For industrial/commercial
application
• Alarm memory with entry/
exit delay
• Locking swivel bracket
included
• Trio-range of lenses
• Vandal-resistant
industrial/institutional
strenght housing
175
123
130
M9000STE
SPECIFICATIONS
Model
Power supply
Current drain
Microwave frequency
Adaptive® Technology
Trouble and antimasking output
Detection range m
Alarm output
Tamper switch
Active Self Test
Active Self Test interval
IMQ Certification
Operating temperature
Mounting height m
Weight g
www.hesa.com
C-101STLRE11
C-101STLRE15
M7300STE
M9000STE
10.2~14.2VDC
9~18VDC
Idle 37mA, Alarm: 40mA
10.525GHz ± 25MHz
9.900 GHz ± 25MHz
YES
YES
11X11
15x12
21x18
16x13, 24x15, 36x3.6
N.C. 0.1A@24VDC with internal 10 1 current-limiting resistor
N.C., Closed with cover in place
YES
11 to 16 hours
1st level (2nd level with WRS-01 kit)
–
– 10°C ~ + 50°C
1.80 ~ 3.00
1.80 ~ 3.60
198
214
1130
49
Dual PIR/Microwave detectors with anti-masking
C-101STLRE11, C-101STLRE15, M7300STE, M9000STE Adaptive® Series
DETECTION RANGE (m)
C-101STLRE11
C-101STLRE15
Top View
Top View
11
15
Side View
Side View
85°
11
PIR
MW
12
85°
1.8
PIR
PIR
MW
1.8
1.8
MW
4
5.5
8
11
PIR
3
MW
6
9
12 15
M7300STE
Wide standard range
Top View
Side View
30 beams
m 21
1.8
3.5
10
21
M9000STE
Wide Standard Range
Middle Range
Top View 30 Beams 16 m
Side View
Top View 24 Beams 24 m
1.8
13
0
Long Range
Side View
Top View 24 Beams 36 m
1.8
3
10
16
15
0
3.6
Side View
4.5
15
24
CODE
MODEL
DESCRIPTION
NP10111
C-101STLRE11
NP10115
C-101STLRE15
NP7300
M7300STE
NP9000
M9000STE
Dual Microwave/PIR Detector with Antimasking, detection range 11 m,
IMQ approved
Dual Microwave/PIR Detector with Antimasking, detection range 15 m,
IMQ approved
Dual Microwave/PIR Detector with Mask/Block Supervision and Trouble
& Antimasking output
Dual Microwave/PIR Detectors with Mask/Block Supervision
and Trouble & Antimasking output
1.8
0
4.50
15
36
Accessories
NP-SVL2
SVL2
NP-SVL
OXWRS01
SVLBKT
WRS-01
www.hesa.com
Wall locking swivel bracket for C-101STLR11/15, PIR-1510, IQ-VISION
(pack of 3 pcs.)
Wall locking swivel bracket for M7300STE
Anti-shifting Kit
SVL2
SVLBKT
VOLUMETRIC INDOOR PROTECTION
50
Dual PIR/Microwave detectors
MX-40QZ, MX-50QZ
MX-40QZ
PIR/Microwave detector, with
Quad Zone logic,
detection range 12x12m
MX-50QZ
PIR/Microwave detector with
Quad Zone logic,
detection range 15x15m
1st level
1st level
DESCRIPTION
The MX Series combines state
of the art microwave and PIR
technologies in attractive,
easy-to-install units and
underlines Optex absolute
commitment to provide
detectors with unprecedented
reliability and detection
performance at very
reasonable prices.
Incorporating Anti-Crosstalk
Technology, which prevents
false alarms caused by
microwave interference when
several detectors are
operating in the same area,
and also Quad Zone Logic,
which discriminates between
humans and other sources of
infrared, the MX Series is
unrivalled in its performance.
DETECTION RANGE (m)
DIMENSIONS (mm)
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current drain
Alarm period
Alarm output
Tamper switch
Pulse count
Warm-up period
LED indicator
Operating temperature
Environmental humidity
Microwave frequency
RF interference
Mounting height
Weight
IMQ Certification
MX-40QZ
MX-50QZ
2m x 12m
18m x 18m 85°
85° wide
85° wide
78 zones (PIR)
2°C at 0.6m/sec.
0.3m - 1.5m/sec.
9.5~16V DC
18mA (max.) at 12V DC
20mA (max.) at 12V DC
Approx. 2.5 sec.
N.C. 28V DC 0.2A max.
N.C, Open when cover is removed:
N.C., 28V DC 0.1A max.
Approx 20 sec. 2 or 4
Approx. 60 sec.
Alarm condition
-10°C ~+55°C
95% max.
2.45GHz
(FCC, IC, ETS300-440 approval)
No Alarm 20V/m
1.5m - 2.4m
1.8m - 2.4m
110g
1st level
FEATURES
• Patented quad zone logic
• Spherical lens design
• Anti-crosstalk technology
• Noise reduction circuit
Top View
8
6
4
2
0
2
4
6
8
3
6
9
12
15
MX-40QZ / MX-50QZ
Side View
1.5
2.4
0
3
6
: Range MX-40
CODE
MODEL
DESCRIPTION
OXMX40
OXMX50
MX-40QZ
MX-50QZ
PIR/Microwave combination detector, detection range m 12x12
PIR/Microwave combination detector, detection range m 15x15
FA-1W
FA-3
Wall mounting bracket
Wall and ceiling mounting bracket
9
12
2.2
3.0
15
: Range MX-50
Accessories
OXFA-1W
OXFA-3
www.hesa.com
FA-1W
FA-3
51
High-end indoor detectors
OPTIMAL
FEATURES
• 15m x 15m 85° wide
coverage
• OPTIMAL anti-masking
function (OML-AT &
OML-DAM)
• EOL (End-of-line) resistors
• Microwave control switch
• Patented double conductive
shielding
• Patented quad zone logic
• Advanced temperature
compensation logic
• Microwave are shaping
technology (OML-DT &
OML-DAM)
OML-ST
PIR detector,
range 15x15m
OML-AM
PIR detector with
Anti-masking, range 15x15m
OML-DT
PIR/Microwave detector,
range 15x15m
OML-DAM
PIR/Microwave detector with
Anti-masking, range 15x15m
SPECIFICATIONS
Model
EN-Grade
PIR
OML-ST
OML-AM
OML-DT
OML-DT
Grade 2
Grade 3
Grade 2
Grade 3
Microwave
DESCRIPTION
OPTIMAL provides a
comprehensive product
lineup from standard to
high-end model suitable for
any applications.
OPTIMAL provides compliance
with EN50131-1
DETECTION RANGE (m)
Top View
7
5
0
Anti-masking
5
OML-ST
OML-AM
OML-DT
OML-DAM
Passive infrared
Passive infrared & Microwave
prEN50131-2-2
prEN50131-2-2 prEN50131-2-4 prEN50131-2-4
(Grade 2)
(Grade 3)
(Grade 2)
(Grade 3)
Masking detection method
–
AIR type
–
AIR type
PIR Coverage [Detection zones]
15m x 15m, 85° wide [82 zones]
Power supply
9 - 18V DC
16mA (normal) / 22mA (normal) / 19mA (normal) / 25mA (normal) /
Current drain
18mA (max.)
23mA (max.)
24mA (max.)
29mA (max.)
at 12V DC
at 12V DC
at 12V DC
at 12V DC
Alarm output
N.C. 28V DC 0.2A max.
N.C. Opens when cover is removed and when the wall tamper switch operates.
Tamper switch
28V DC 0.1A max.
N.C. 28V DC
N.C. 28V DC
Trouble output
–
–
0.2A max.
0.2A max.
Operating temperature
-10°C ~+50°C
Environmental humidity
95% max.
RF interference
No alarm 30V/m
Mounting height
1.8 - 3.0m (6 - 10ft.)
1.8 - 2.4m (6 - 8ft.)
Weight
180g (6.3oz)
7
0
CODE
MODEL
DESCRIPTION
OXOMLST
OXOMLAT
OXOMLDT
OXOMLDAM
OML-ST
OML-AM
OML-DT
OML-DAM
PIR detector, detection range m 15x15
PIR detector with anti-masking, detection range m 15x15
PIR/Microwave combination detector, detection range m 15x15
PIR/Microwave combination detector with anti-masking, detection range m 15x15
FA-1W
FA-3
CL-80N
Wall mounting bracket
Wall and ceiling mounting bracket
Long Range Lens (24m x 1.8m)
OXFA-1W
OXFA-3
OXCL80N
www.hesa.com
5
10
15
Side View
MW
PIR
0
1.8
3.0
0
Model
Detection method
Detector standard
Accessories
MW
PIR
5
10
Down Zone
When using Down Zone detection,
peal off the lens surface sticker.
15
DIMENSIONS (mm)
138
53
OPTIMAL
VOLUMETRIC INDOOR PROTECTION
52
PIR detectors
IQ VISION
IQ VISION
Range 12x12 m and 14 kg Pet
Immunity
FEATURES
• ASIC Advanced Technology
• Features look-down/creep
zone
• Auto temperature
compensation
• SSP™ (Signal Selective
Processing) for the easiest
and most stable
installations
• Excellent EMI-/RMI/Lightning protection with
resilient SMD circuitry
• Sealed sensor chamber
prevents insect/draft
interference
• Attractive two-tone
white/grey styling bi-optic
case
SPECIFICATIONS
Model
Power supply
Current drain @12VDC
Detection range
Alarm time
Alarm output
IQ VISION
10.6~16VDC
23mA Idle / 33mA Alarm
12x15m 85° Angle
2 - 3 sec
N.C. 0.1A @ 24VDC with 10 1
current limiting resistor
3 min
2 or Auto
N.C., Closed with
Cover in place
Red in alarm condition
may be disabled
-10°C ~ +50°C
95% max
2.00 to 2.60
180
Warm up
Pulse count
Tamper switch
LED
Operating temperature
Relative humidity
Mounting height m
Weight g
DETECTION RANGE
Top
TopView
View
85°
Side
Sideview
View
2, 10
12
1
DIMENSIONS (mm)
5
7
12
Pet immunity
(Jumper SSP off and Pet mask)
Top View
View
Top
Side View
view
115
85°
2,10
64
46
IQ-VISION
10
CODE
MODEL
DESCRIPTION
NP-IQVS
IQ VISION
Indoor PIR detector with ASIC Advanced Technology, detection range 12x12 m
SVL2
Wall locking swivel bracket for C-101STLR11/15, PIR-1510,
IQ-VISION (pack of 3 pcs.)
6
10
35’
Accessories
NP-SVL2
www.hesa.com
SVL2
53
PIR detectors
RX-40QZ
RX-40QZ
PIR detector,
range m 12x12
DIMENSIONS (mm)
FEATURES
• Patented quad zone logic
• Spherical lens design
• Temperature compensation
• Small animal immunity
• Sealed optics
• Selectable pulse count
(2 or 4)
RX-40QZ
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current consumption
Alarm period
Alarm output
Tamper switch
Pulse count
Warm-up period
LED indicator
Operating temperature
Environmental humidity
RF interference
Mounting height
Weight
RX-40QZ
12m x 12m 85° wide
78 zones
2°C at 0.6m/sec.
0.3m~1.5m/sec.
9.5 - 16V DC
11mA (max.) at 12V DC
Approx. 2.5 sec.
N.C. 28V DC 0.2A max.
N.C. Opens when cover is removed
Approx. 20 sec. 2 or 4
Approx. 30 sec.
Alarm condition
-20°C~+50°C
95% max.
No Alarm 20V/m
1.5m - 2.4m
70g
MODEL
DESCRIPTION
OX40QZ
RX-40QZ
Small animal immunity PIR detector
Accessories
www.hesa.com
DESCRIPTION
The RX-40QZ gives extremely
high false alarm protection
with excellent tolerance to
spot temperature changes
from curtains, small animals,
and pet. Using patented
Quad Zone Logic, it is able to
accurately discriminate
between humans and other
sources of infrared, providing
reliable detection in a diverse
range of applications.
The attractive housing
incorporates the unique Optex
spherical lens design, which
is not only robust, but also
helps to maximise the
performance of Quad Zone
Logic by providing an
accurate focal length for
each detection zone.
DETECTION RANGE
CODE
OXFA-1W
OXFL60N
OXFA-3
OXWRS01
1st level,
2nd level (with WRS-01 kit)
Wide angle
Top view
6
4
2
0
2
4
6
2.4
Long range
(With FL-60N optional lens)
1.5
0
1.5
2 4 6 8 10 12
Side view
0
2 4 6 8 10 12
2.4
Top view
0
5
10
15 18
10
15 18
Side view
0
5
FA-1W
FL-60N
FA-1W
FL-60N
FA-3
WRS-01
Wall mounting bracket
18m long-range lens
Wall and ceiling mounting bracket
Anti-shifting Kit
WRS-01
VOLUMETRIC INDOOR PROTECTION
54
PIR detectors
EX-35T, EX-35R
EX-35T
PIR detector wide angle 11x11
m or long range 7x1.7 m
1st level,
2nd level (with WRS-01 kit)
SPECIFICATIONS
Model
EX-35R
Low current battery operated
PIR detector, wide angle
detector 11x11 m or long
range detector 17x1.7 m
DESCRIPTION
The EX-35 combines a unique
dual-purpose lens, patented
Multi-Focus Technology and
Selectable Sensitivity to
create four detection patterns
- wide-angle or long-range
and multi-level or pet alley.
The unique spherical lens
eliminates sensitivity
problems caused by changes
in detection patterns.
EX-35T
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Operating voltage Current consumption
Alarm period
Alarm output
Alarm interval
Tamper switch
Pulse count
Warm-up period
LED indicator
Operating temperature
Environmental humidity
RF interference
Mounting height
Weight
EX-35R
WIDE : 11m x 11m 85°wide
LONG : 17m x 1.7m long range
WIDE : 64 zones / 28 zones(pet alley)
LONG : 12 zones / 4 zones(pet alley)
1.6°C at 0.6m/sec.
0.3m - 1.5m/sec.
9.5 - 14V DC
3 - 9V alkaline battery or
lithium battery
–
2.3 - 10V DC
11mA (max.) at 12V DC
3.5µA (standby)
–
10mA (walktest, LED on)
Approx. 2.5 sec.
N.C. 28V DC 0.2A max.
Form C-solid state switch
10V DC 0.01A (max.)
Alarm output is inactive until
–
there is a 2 min. period of inactivity
in the pattern area.
N.C Opens when cover removed: 28V DC 0.1A max.
Approx. 20 sec. 2 or 4
IMPORTANT: When selecting the
Approx. 20 sec. 2 or 4
long range detection pattern,
always set pulse count selector on "2".
Approx. 30 sec.
Approx. 60 sec.
Alarm condition
Disable during normal operation
Alarm condition (walk test)
-20°C to +50°C
-10°C to +50°C
95% max.
No Alarm 20V/m
Normal: 1.2-2.4m / Pet alley: 0.6m - 1.2m
70g
142g
CODE
MODEL
DESCRIPTION
OXEX35T
OXEX35R
EX-35T
EX-35R
PIR detector wide angle 11x11 m or long range 17x1.7 m
Low current battery operated PIR detector.
Wide angle detector 11x11 m or long range 17x1.7 m
FEATURES
• Spherical lens design
• Wide-angle or long-range
detection in multi-level or
pet alley patterns
• High detection sensitivity
• Stable even in high
temperature conditions
• Selectable pulse count
(2 or 4)
DETECTION RANGE
Top view
6
4
2
0
2
4
6
0
2
4
6
8
10 12 14 16 18
Side view
2.4
0 2
4
6
8 10 12 14 16 18
4
6
8 10 12 14 16 18
0.9
0 2
: llong range
: wide range
DIMENSIONS (mm)
114
70
44
EX-35T
114
Accessories
OXEA-1W
OXFA-2C
OXFA-1W
OXFA-3
OXFA-1W
OXWRS01
www.hesa.com
EA-1W
FA-2C
FA-1W
FA-3
FA-1W
WRS-01
Wall mounting bracket
Multi-angle ceiling mounting bracket
Wall mounting bracket
Wall and ceiling mounting bracket
Wall mounting bracket
Anti-shifting Kit
70
EX-35R
76
55
PIR detectors
FX-40, FX-40D
FX-40
PIR detector, range 12x12 m
1st level, 2nd level (with WRS-01 kit)
FX-50QZL
PIR detector with alarm
memory latch, range 15x15 m
DESCRIPTION
The FX series is designed to
provide stable and reliable
detection in the most hostile
of environments, where many
other detectors struggle to
function. The highly accurate
DETECTION RANGE
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current drain
Alarm period
Alarm output
Tamper switch
Pulse count
Warm-up period
LED indicator
Operating temperature
Environmental humidity
RF interference
Mounting height
Weight
FEATURES
• Patented multi-focus optics
• Alarm memory latch
(FX-50QZL only)
• Sealed optics
• Spherical lens design
• Temperature compensation
• For residential and light
commercial applications
and reliable detection pattern
maintains its sensitivity
throughout the detection area
even in high temperature or
low contrast environments
such as conservatories.
FX-40
FX-50QZL
12mx12m 85° wide 15mx15m 85° wide
36 zones
39 zones
1.1°C at 0.6m/sec.
2°C at 0.6m/sec.
0.3m - 1.5m/sec.
9.5 - 16V DC
11mA
25mA
Approx. 2.5 sec.
N.C. 28V DC 0.2A max.
N.C, Open when cover
is removed: 28V DC 0.1A max.
Approx 20 sec. 2 or 4
Approx. 30 sec.
Alarm condition
-20°C to +50°C
95% max.
No Alarm 20V/m
1.5m - 2.4m
90g
Wide angle
Long range
(With FL-60N optional lens)
Top view
6
3
0
3
6
0
2.4
0
5
Side view
5
10 12
1.5
0
1.5
Top view
0
5
Side view
10
15 18
0
5
10
15
2.4
10 12
CODE
MODEL
DESCRIPTION
OXFX-40
OXFX5QL
FX-40
FX-50QZL
PIR detector for residential and light commercial, detection range m 12x12
PIR detector with alarm memory latch, range 15x15 m
18
DIMENSIONS (mm)
FX-40 / FX-50QZL
Accessories
OXFL60N
OXEA-1W
OXFA-3
OXFA-1W
OXFA-2C
OXWRS01
www.hesa.com
FL-60N
EA-1W
FA-3
FA-1W
FA-2C
WRS-01
18m long-range lens
Wall Mount Bracket, Adjustable ±20° Horizonally, 0-15° Vertically
Wall and ceiling mounting bracket
Wall mounting bracket
Multi Angle Ceiling Mount Bracket
Anti-shifting Kit
FL-60N
FA-3
WRS-01
VOLUMETRIC INDOOR PROTECTION
56
PIR detectors
CX-702, CX-702RS
CX-702
PIR detector, wide angle
21x21 m or long range
45x2.4 m
CX-702RS
Low current battery operated
PIR detector, wide angle
21x21 m or long range
detector 45x2.4 m
DESCRIPTION
The CX-702 is designed to
give extremely stable longrange detection performance
in a variety of internal
commercial and industrial
applications. With patented
Multi-Focus Technology,
sensitivity is maintained
through the entire coverage
area, even in high
temperature areas or in
applications with low
temperature contrast.
Combined with double
conductive shielding and
temperature compensation, a
high level of false alarm
protection is guaranteed.
The CX-702RS offers flexible
features. It can easily be
added on to any wireless
system which has already
been installed as this unit is
effective with any
manufacturers transmitter
and receiver.
SPECIFICATIONS
Model
CX-702
CX-702RS
WIDE : 21m x 21m 85° wide
Coverage
LONG : 45m x 2.4m long range
Detection zones
68 zones
Sensitivity
1.6°C at 0.6m/sec. at 2.4m mounting height
Detectable speed
0.3 - 1.5m/sec.
3 - 9V DC
Power supply
9.5-16VDC
alkaline batttery
or lithium battery
5µ (standby)
Current drain
11mA (max.) at 12VDC
10mA (walktest)
Alarm period
Approx. 2.5 sec.
N.C. 28VDC 0.2A max.
Form C
Alarm output
10 DC 0.01A max.
Succeeding signals
are not output even
Alarm interval
though detection
occurs within 2 min.
after the first alarm.
N.C, Open when
Form C
Tamper switch
cover is removed.
28VDC 0.1A max.
28 VDC 0.1A max.
Pulse count
Approx. 20 sec. 2 or 4
Warm-up period
Approx. 60 sec.
Approx. 90 sec.
LED indicator
Alarm condition
Operating temperature
-20°C ~ +50°C
-10°C ~ +50°C
Environmental humidity
95% max.
RF interference
No Alarm 30V/m
No Alarm 20V/m
Mounting height
1.5m~3.6m
Weight
200g
DETECTION RANGE
Wide angle
FEATURES
• Patented Multi-Focus
Technology
• Patented Double
Conductive Shielding
• Temperature Compensation
• Sealed Optics
• Spherical Lens Design
Top view
10
• Dual Purpose Optics: Wide
angle or long range
• 3-step lens angle adjustment
• 100% factory tested for
reliability
Side view
3.6
2.4
1.5
5
0
5
10
15
20 21
Long range
0
Top view
2
0
5
2
0
3.6
2.4
1.5
10
0
5
10
15
20 21
0
5
Side view
5
10
15
20
25
30
35
40
45
10
15
20
25
30
35
40
45
DIMENSIONS (mm)
CODE
MODEL
DESCRIPTION
OX702
OX702RS
CX-702
CX-702RS
Long range PIR detector with selectable detection pattern
Low current battery operated PIR detector with selectable detection pattern,
wide angle detector 21x21 m or long range 45x2.4 m
140
100
Accessories
OXCA-1W
OXCA-2C
OXBA-70
www.hesa.com
CA-1W
CA-2C
BA-70
Multi-angle wall mounting bracket
Multi-angle ceiling mounting bracket
Back box for wireless transmitter
CX-702 / CX-702RS
69
57
PIR detectors
FX-360
FX-360
360° ceiling-mount PIR
detector, range Ø m8 ~ m12
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current drain
Alarm period
Alarm output
Tamper switch
Pulse count
Warm-up period
LED indicator
Environmental humidity
Operating temperature
RF interference
Mounting height
Weight
FX-360
Ø 8m~ Ø12m
62 zones
1.6°C at 0.6m/sec.
at 2.4m mounting height
0.3m - 1.5m/sec.
9.5 - 18V DC
18mA (max.) at 12V DC
20 ± 0.5 sec.
N.C. 28V DC 0.2A max.
N.C, Open when cover is removed:
30V DC 0.1A max.
20 ± 0.5 sec. 2 or 4
Approx. 30 sec. (LED blinks)
LED blinks during warm-up period
Alarm indicator optional
-20°C to +50°C
95% max.
No Alarm 20V/m
2.4m - 3.6m
140g
CODE
MODEL
DESCRIPTION
OXFX36
FX-360
360° ceiling-mount PIR detector
www.hesa.com
FEATURES
• Spherical Lens design
• RFI protection
• Temperature protection
• Noise reduction circuit
• Selectable pulse count
(2 or 4)
• LED remote control terminal
DESCRIPTION
The FX-360 ceiling-mount
detector with its unique,
highly durable spherical lens
offers unparalleled 360°
detection performance. False
alarm protection
technologies, such as RFI
Protection, Temperature
Protection and Noise
Reduction, come as standard,
giving the FX-360 the most
unbeatable reliability in its
class.
The FX-360 is extremely cost
effective and its sleek and
compact design suits all
types of installation
applications.
DIMENSIONS (mm)
DETECTION RANGE
Top view
12
120
Side view
3.6
3.0
2.4
37
6
FX-360
4
2
0
Detection range (m)
Mounting height
Detection range ’
2
4
6
0
3.6 3.0 2.4
12 10 8
VOLUMETRIC INDOOR PROTECTION
58
PIR detectors
SX-360Z
SX-360Z
360° ceiling-mount PIR
detector, range ’ m 18
1st level,
2nd level (with WRS-01 kit)
FEATURES
• Patented multi-focus
technology
• Highly dense coverage
(276 zones)
• Zoom function/ pattern
adjustment
• Temperature protection
• Noise reductioncircuit
• LED remote control terminal
SPECIFICATIONS
Model
Coverage
Detection zones
Sensitivity
Detectable speed
Power supply
Current drain
Alarm period
Alarm output
Alarm memory
Initial alarm memory
Tamper switch
Pulse count
Warm-up period
LED indicator
Environmental humidity
Operating temperature
RF interference
Mounting height
Weight
SX-360Z
Ø 18m 360° zoom
276 zones
1.6°C at 0.6m/sec. at 2.4m mounting height
0.3m - 1.8m/sec.
6 - 18V DC
18mA (max.)
2.0 ± 0.5 sec.
N.C. 28V DC 0.2A max.
–
–
N.C, Open when cover is removed:
30V DC 0.1A max.
20 ± 0.5 sec. 2 or 4
Approx. 20 sec. (LED blinks)
LED blinks during warm-up period
Alarm indicator optional
-20°C to +50°C
95% max.
No Alarm 30V/m
2.4m - 5m
224g
CODE
MODEL
DESCRIPTION
OX360Z
SX-360Z
360° ceiling-mount PIR detector
DESCRIPTION
The SX-360 Series ceilingmount detector, with its
unique zoom function and
highly dense, triple-element
detection pattern, provides
unsurpassed detection
performance at any ceiling
height up to 5 metres. By
simply twisting the units
domed lens, the detection
pattern can be easily
adjusted at any installation
height, making it one of the
most flexible ceiling detectors
on the market. This,
combined with its compact
design, makes the SX-360
suitable for a variety of
applications - large or small,
residential or commercial.
DETECTION RANGE
Zoom “A” position
5
3.6
2.4
0
9
6
3
www.hesa.com
Anti-shifting kit
6
9
ZOOM
3.6
2.4
0
9
6
3
0
3
6
9
ZOOM
Zoom “E” position
’ 18
2.4
0
9
6
3
0
3
DIMENSIONS (mm)
67-73
’ 128
WRS-01
3
Zoom “C” position
Accessories
OXWRS01
0
SX-360Z
6
9
59
www.hesa.com
LOCAL PROTECTION
DEVICES
Recessed mount Magnetic Contacts
Surface mount Magnetic Contacts
Contacts for roller-shutters
Shock sensors
Glass break detectors
Water Presence sensor
Emergency Hold-Up devices
LOCAL PROTECTION DEVICES
62
Recessed mount Magnetic Contacts
• A complete line of high quality magnetic contacts, for the best
performances
• Contacts in rhodium and magnets in N35 alloy for reliable
operation and long life
• Contacts N.C. when magnet is within the gap
• Lifetime warranty
• Maximum initial contact resistance: 0.2 ohm
• Maximum contact rating: 10W
• Maximum switching voltage: 100VDC/VAC
• Maximum switching current: 0.5A
• All contacts must be ordered in packs of 10 pcs.
Model
Description
Gap
MINIATURE RECESSED MAGNETIC CONTACT WITH BARE MAGNET, ’ 6.4 mm
CL-1000
N.C. contact
19 mm
CL-1001
N.C. contact
19 mm
Leads
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
PRESS-FIT MINIATURE RECESSED MAGNETIC CONTACT WITH BARE MAGNET, ’ 6.4 mm
CL-1100
N.C. contact
25 mm 2x550 mm
AWG 22
CL-1101
N.C. contact
25 mm 2x550 mm
AWG 22
PRESS-FIT RECESSED MAGNETIC CONTACT, ’ 9 mm
CL-2000
N.C. contact
19 mm 2x450 mm
AWG 22
CL-2001
N.C. contact
19 mm 2x450 mm
AWG 22
PRESS-FIT RECESSED MAGNETIC CONTACT WITH SCREW TERMINALS, ’ 9 mm
CL-2300
N.C. contact
23 mm Screw
terminals
CL-2301
N.C. contact
23 mm Screw
terminals
PRESS-FIT RECESSED MAGNETIC CONTACT WITH SUPERVISOR LOOP, ’ 9 mm
CL-2204
N.C. contact, 4-wire
25 mm 4x450 mm
AWG 22
FLANGED RECESSED MAGNETIC CONTACT WITH SUPERVISOR LOOP, ’ 9.2 mm
CL-2400
N.C. contact, 4-wire
“STUBBY” PRESS-FIT RECESSED MAGNETIC CONTACT, ’ 9.5 mm
CL-2100
N.C. contact
with “Mini-Max” magnet
CL-2101
N.C. contact
with “Mini-Max” magnet
RECESSED MAGNETIC CONTACT FOR STEEL DOORS, ’ 19 mm
www.hesa.com
MODEL
CL-1000
CL-1001
CL-1100
CL-1101
CL-2000
CL-2001
CL-2100
CL-2101
CL-2204
CL-2300
CL-2301
CL-2400
CL-3000
CL-3001
CL-4000
Brown
White
Brown
White
Brown
White
4x450 mm White
AWG 22
19 mm
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
19 mm
N.C. contact
19 mm
CL-3001
N.C. contact
19 mm
N.C. contact
6 mm
ROLL PLUNGER FLUSH CONTACT
CODE
CL1000
CL1001
CL1100
CL1101
CL2000
CL2001
CL2100
CL2101
CL2204
CL2300
CL2301
CL2400
CL3000
CL3001
CL4000
White
19 mm
CL-3000
CL-4000
Colour
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
2x450 mm White
AWG 22
DESCRIPTION
Recessed mount miniature contact, 0.5A, white colour
Recessed mount miniature contact, 0.5A, brown colour
Recessed mount miniature contact, 0.5A, white colour
Recessed mount miniature contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, white colour
Recessed mount standard contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, white colour
Recessed mount standard contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, 4-wire, white colour
Recessed mount standard contact, screw terminals, 0.5A, white colour
Recessed mount standard contact, screw terminals, 0.5A, brown colour
Recessed mount standard contact, 0.5A, 4-wire, white colour
Recessed mount contact for steel doors, 0.4A, white colour
Recessed mount contact for steel doors, 0.4A, brown colour
Recessed mount roll plunger flush contact, 0.5A, white colour
Dimensions (mm)
63
Surface mount Magnetic Contacts
• A complete line of high quality magnetic contacts, for the
best performances.
• Contacts in rhodium and magnets in N35 alloy for reliable
operation and long life
• Contacts N.C. with magnet in the gap
• Lifetime warranty
• Maximum initial contact resistance: 0.2 ohm
• Maximum contact rating: 10W
• Maximum switching voltage: 100VDC/VAC
• Maximum switching current: 0.5A
• All contacts must be ordered in packs of 10 pcs. except
Industrial contacts, Overhead door contacts and
CL-6000/CL-6001 which are packed individually
Model
Description
SUB MINIATURE MAGNETIC CONTACT, 26 mm LONG
CL-5200
N.C. contact
CL-5200
N.C. contact
CL-5300
N.C. contact
Gap
Leads
12 mm
12 mm
22 mm
2x450mm AWG 22 White
2x450mm AWG 22 White
2x95mm AWG 22 White
SUB MINIATURE FLANGE MAGNETIC CONTACT, 28 mm LONG
CL-5000
N.C. contact
24 mm
2x450 mm
AWG 22
2x450 mm
AWG 22
CL-5001
N.C. contact
24 mm
MINIATURE FLANGE MAGNETIC CONTACT, 34 mm LONG
CL-5100
N.C. contact
25 mm
N.C. contact
25 mm
DESIGN MAGNETIC CONTACT WITH SCREW TERMINALS
CL-6000
N.C. contact
CL-5101
25 mm
CL-6001
N.C. contact
25 mm
STANDARD MAGNETIC CONTACT WITH SCREW TERMINALS, COVER SPACER
CL-6100
N.C. contact
30 mm
CL-6101
N.C. contact
30 mm
CL-6200
SPDT contact
28 mm
INDUSTRIAL MAGNETIC CONTACT WITH SCREW TERMINALS
CL-7000
N.C. contact
65 mm
Colour
White
Brown
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
Screw
terminals
Screw
terminals
White
Screw
terminals
Screw
terminals
Screw
terminals
White
Screw
terminals
INDUSTRIAL ALUMINIUM SUPERVISED CONTACT WITH STAINLESS STEEL ARMORED CABLE
Brown
Brown
White
Grey
CL-7100
N.C. contact
38 mm
4x450 mm Aluminium
CL-7200
N.C. contact, with bracket
75 mm
4x290 mm Aluminium
FLOOR MOUNT OVERHEAD DOOR CONTACT WITH STAINLESS STEEL ARMORED CABLE
CL-8000
CODE
CL5000
CL5001
CL5100
CL5101
CL5200
CL5201
CL5300
CL6000
CL6001
CL6100
CL6101
CL6200
CL7000
CL7100
CL7200
CL8000
www.hesa.com
MODEL
CL-5000
CL-5001
CL-5100
CL-5101
CL-5200
CL-5201
CL-5300
CL-6000
CL-6001
CL-6100
CL-6101
CL-6200
CL-7000
CL-7100
CL-7200
CL-8000
N.C. contact with bracket
60 mm
4x500 mm Aluminium
DESCRIPTION
Surface mount sub-miniature contact, 0.5A, white colour
Surface mount sub-miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount standard contact, 0.5A, white colour
Surface mount standard contact, 0.5A, brown colour
Surface mount standard contact, 0.5A, white colour
Surface mount standard contact, 0.5A, brown colour
Surface mount standard contact, 0.2A, white colour
Surface mount industrial contact, 0.5A, grey colour
Surface mount industrial contact, 0.4A, aluminium
Surface mount industrial contact, 0.4A, aluminium
Overhead door contact, 0.4A, aluminium
Dimensions (mm)
LOCAL PROTECTION DEVICES
64
Contacts for Roller-shutters, Shock sensors & Glass break detectors
Model
Description
Colour
H-666
Stick contact for roller-shutters
Brown
Dimensions (mm)
CONTACTS FOR ROLLER-SHUTTERS
96
60
SWITCHALARM2 Switch contact for roller-shutters
with precision mechanism
White
SWITCHALARM3 Switch contact for roller-shutters with
precision and high sliding mechanism.
Cable holder plate as an option
White
ANALYSER
43
100
89
16
90
85
Analyser circuit for SWITCH ALARM
contacts
15
56
PIEZO SHOCK SENSOR
IMPACTOR
IMPACTOR-M
Piezo shock sensor
Piezo shock sensor
60
White
Brown
1st Level
IMPACTOR-LC
GLASS BREAK DETECTORS
LC-105-DGB
Piezo shock sensor, low current version
FEATURES
• Adjustable sensitivity
• LED alarm memory
• Alarm relay output
86
White
25
Digital Glassbreak detector
FEATURES
• Form “A”alarm contact and tamper switch
• Digital signal analysis
• Detects the sound of all types of breaking
framed glass
• Phased frequency detector sensor
•
•
•
•
Able to adjust sound sensors separately
Ceiling or wall mount installation
Slim profile design
Features ABS plastic for shock and impact
protection
CODE
MODEL
DESCRIPTION
HV666
SM03
SM03A
SM02
LDSS-IM
LDSSBRN
LDSIMLC
D2L105GB
H-666
SWITCHALARM2
SWITCHALARM3
ANALYSER
IMPACTOR
IMPACTOR-M
IMPACTOR-LC
LC-105-DGB
Stick contact for rolling-shutters, brown colour
Switch contact for rolling-shutters with precision mechanism, white colour
Contatto a filo per tapparelle, meccanismo di precisione e alta scorrevolezza, colore bianco
Analyser circuit for SWITCHALARM contacts
Piezo shock sensor, white colour. IMQ 1° Level Certification
Piezo shock sensor, brown colour . IMQ 1° Level Certification
Piezo shock sensor, low current version, white colour
Digital glassbreak detector
www.hesa.com
20
• Detection range up to 6 sqm
• IMQ 1° Level Certification
• Power Input 3 ~ 4.5VDC (IMPACTOR-LC only)
65
Water Presence sensors & Emergency Hold-Up devices
Model
Description
Colour
WA-2
Water presence sensor
FEATURES
• Alarm buzzer built-in,
• Relay Output: 1A@28VDC
• Power Input 12VDC
White
Additional probe for WA-2
water presence sensor
White
Dimensions (mm)
WATER PRESENCE SENSORS
WA-P
105
94
28
72
65
20
EMERGENCY HOLD-UP DEVICES
266-IT
Hold-up Foot Rail
IMQ 1st Level Certification
Grey
120
420
85
1st Level
269
Emergency Hold-Up button
Grey
269-IT
Emergency Hold-Up button
with tamper protection.
IMQ 2nd Level Certification
Grey
88
2nd Level
CODE
MODEL
DESCRIPTION
HE266IT
HE269
HE269IT
HEWA-2
HEWA-P
266-IT
269
269-IT
WA-2
WA-P
Hold-up foot rail, grey colour. IMQ 1st level Certification
Emergency Hold-Up button, white colour
Emergency Hold-Up button with tamper, white colour. IMQ 2nd level Certification
Water presence sensor, white colour
Additional probe for WA-2 water presence sensor, white colour
www.hesa.com
54
30
LOCAL PROTECTION DEVICES
66
LiteSUN
Anti-theft system for photovoltaic solar panels
with plastic optical fiber
DESCRIZIONE
Photovoltaic solar panels are more and more employed and they are really
appreciated expecially by thiefes. People who invest on alternative energies know that
they can only be profitable on the long run. Up to now, no solutions have been available that were cheap and easy to install, and that could be installed also on existing
photovoltaic fields. LiteSun is an anti-theft system that protects your solar panels
joining them together in an unbreakable ring. The way it works is very simple: you
cannot remove a panel without breaking the plastic optical fiber LiteWire.
LS300C1S
Single Ring Transmitter + Receiver
sensitive to breaking fiber
LS300C2S
Double Ring Dual Transmitter + Dual
Receivers sensitive to breaking fiber
LS300P
Single Ring Transmitter + Receiver
sensitive to folding and breaking fiber
LS300C1T
Single Transmitter sensitive to breaking
fiber
LS300C1R
Single Receiver sensitive to breaking
fiber
LS300C2T
Dual Transmitter sensitive to breaking
fiber
LS300C2R
Dual Receiver sensitive to breaking fiber
LS300R1R
Amplifier sensitive to breaking fiber
SPECIFICATIONS
Possible configurations
Ring length
Type of signal
Type of fiber
Input
Output
Signals
Power supply
Consumption (mA)
Protection rate
Operating temperature
www.hesa.com
Single ring transceiver
Double ring transceiver
Single transmitter
Single receiver
Double transmitter
Double receiver
Link repeater
300 m
Optical, encoded 525nm
Plastic Fiber LiteWire with attenuation <100dB
Device test
Alarm relay (max. 0.25A/50VDC)
Ring status, Power, Test
12VDC
54 max.
IP40 (IP65 optional)
-40°C ~ +85°C
FEATURES
• Easy: plastic optical fiber LiteWire are
connectorized in 30 seconds without
special instruments
• Flexible: it has a diameter of just
2.2mm and a bending radius of only
20mm for a quick and simple
installation
• Resistant: it is an optical fiber, it
doesn't age or oxidize and has a life
time of a hundred years
• Protective: it is an optical fiber, you
cannot by-pass it to steal a panel
• Secure: it completely removes false
contacts
• Certain: it is a mechanical system, it
cannot be tapped or removed
67
LiteSUN
Anti-theft system for photovoltaic solar panels
with plastic optical fiber
CONNECTION DIAGRAM
SINGLE RING CONNECTION
DOUBLE RING CONNECTION
Alarm 1 out
Alarm 2 out
Alarm out
LS300C1S
LS300C2S
LINEAR CONNECTION WITH REPEATERS
Alarm out
sensitive to breaking fiber
CODE
MODEL
DESCRIPTION
H9LS301S
H9LS302S
H9LS301T
H9LS301R
H9LS302T
H9LS302R
H9LS30R
H9LS300P
LS300C1S
LS300C2S
LS300C1T
LS300C1R
LS300C2T
LS300C2R
LS300R1R
LS300P
Single Ring Transmitter + Receiver sensitive to breaking
Double Ring Dual Transmitters + Dual Receivers sensitive to breaking
Single Transmitter sensitive to breaking
Single Receiver sensitive to breaking
Dual Transmitter sensitive to breaking
Dual Receiver sensitive to breaking
Amplifier
Single Ring Transmitter + Receiver sensitive to breaking and folding
Accessories
H9CSMA
H9CHFBR10
H9CPSMA
H9CHEX
H9CSA
H9LWKIT
CSMA
HFBR-10P
PSMA
CHEX
CSA
LWKIT
H9CASMA
H9CV25M
H9CV25B
H9CT25B
H9LSBL1
H9LSBL2
ASMA
CV25M
CV25B
CV25R
LSBOLT1
LSBOLT2
F-SMA Connectors (10 pcs. Kit)
10 pcs. connectors HFBR + 1 puck for plastic fiber
Puck to polish bugs on connectors
Crimping Tool HEX 3mm for F-SMA Connectors
Stripping Tool
Complete kit for Fiber Plastic connection, including crimping tool,
cutter, stripping tool, puck, 10 pcs. F-SMA connectors, 5 pcs. hooks,
in ABS briefcase
F-SMA sand for Junctions
Plastic Fiber 200m roll
Plastic Fiber 500m spool
Plastic Fiber Anti-rodent version, 500m spool
8 mm bolt head
15 mm bolt head
www.hesa.com
CSMA
CV25M
HFBR
PSMA
CHEX
CSA
LWKIT
ASMA
CV25B
CV25R
LOCAL PROTECTION DEVICES
68
SicurSPOT
Anti-theft system for photovoltaic solar panels
with optical fiber
SICURSPOT
Single Ring Transmitter + Receiver
sensitive to breaking fiber
SPECIFICATIONS
Item
Ring length
Type of signal
Supervisor
Sensitive to cutting
Sensitive to folding
Output
Power supply
Current drain
EMI/RFI immunity
Operating temperature
Operating umidity
USES
SicurSPOT
0~1000m
Optical, encoded 850nm
1000/s
YES
–
1 potential-free contact relay
10VDC~14VDC
max. 100mA (with relay activated)
YES
0°C~+60°C
70%
CODE
H9SPOT
MODEL
SicurSPOT
DESCRIPTION
Single Ring Transmitter + Receiver sensitive to breaking
Accessori
H9SPCV5
H9SPCV10
H9SPCV25
H9SPCV50
H9SPCVSPL
H9SPCVSPLU
H9SPCVVFL
H9SPCVST5
H9SPCVST2
H9SPCVKIT
CV-FO50
CV-FO100
CV-FO250
CV-FO500
CV-FOSPL
CV-FOSPLU
CV-FOVFL
CV-ST50/125
CV-STMOD
CV-FOKIT
Optical Fiber 50m roll
Optical Fiber 100m roll
Optical Fiber 250m roll
Optical Fiber 500m spool
Antitorsion CamSplice Mechanical Splice
Crimp Tool for Antitorsion CamSplice Mechanical Splice
Fiber Optic Light Source
ST50/125 Unicam Connector
Barrel adapter for optic junctions
Complete kit for Unicam connection for ST, SC and LC connectors
www.hesa.com
FEATURES
• Optical fiber has a diameter of just
2.8mm and doesn't age or oxidize and
has a life time of a hundred years
• It is a simple and cost-effective
system that builds fiber rings of
1000m to join hundreds of panel
together with a single cable
• Optical fiber cannot by-pass tapped or
removed
69
www.hesa.com
LOCAL PROTECTION
DEVICES
Recessed mount Magnetic Contacts
Surface mount Magnetic Contacts
Contacts for roller-shutters
Shock sensors
Glass break detectors
Water Presence sensor
Emergency Hold-Up devices
LOCAL PROTECTION DEVICES
62
Recessed mount Magnetic Contacts
• A complete line of high quality magnetic contacts, for the best
performances
• Contacts in rhodium and magnets in N35 alloy for reliable
operation and long life
• Contacts N.C. when magnet is within the gap
• Lifetime warranty
• Maximum initial contact resistance: 0.2 ohm
• Maximum contact rating: 10W
• Maximum switching voltage: 100VDC/VAC
• Maximum switching current: 0.5A
• All contacts must be ordered in packs of 10 pcs.
Model
Description
Gap
MINIATURE RECESSED MAGNETIC CONTACT WITH BARE MAGNET, ’ 6.4 mm
CL-1000
N.C. contact
19 mm
CL-1001
N.C. contact
19 mm
Leads
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
PRESS-FIT MINIATURE RECESSED MAGNETIC CONTACT WITH BARE MAGNET, ’ 6.4 mm
CL-1100
N.C. contact
25 mm 2x550 mm
AWG 22
CL-1101
N.C. contact
25 mm 2x550 mm
AWG 22
PRESS-FIT RECESSED MAGNETIC CONTACT, ’ 9 mm
CL-2000
N.C. contact
19 mm 2x450 mm
AWG 22
CL-2001
N.C. contact
19 mm 2x450 mm
AWG 22
PRESS-FIT RECESSED MAGNETIC CONTACT WITH SCREW TERMINALS, ’ 9 mm
CL-2300
N.C. contact
23 mm Screw
terminals
CL-2301
N.C. contact
23 mm Screw
terminals
PRESS-FIT RECESSED MAGNETIC CONTACT WITH SUPERVISOR LOOP, ’ 9 mm
CL-2204
N.C. contact, 4-wire
25 mm 4x450 mm
AWG 22
FLANGED RECESSED MAGNETIC CONTACT WITH SUPERVISOR LOOP, ’ 9.2 mm
CL-2400
N.C. contact, 4-wire
“STUBBY” PRESS-FIT RECESSED MAGNETIC CONTACT, ’ 9.5 mm
CL-2100
N.C. contact
with “Mini-Max” magnet
CL-2101
N.C. contact
with “Mini-Max” magnet
RECESSED MAGNETIC CONTACT FOR STEEL DOORS, ’ 19 mm
www.hesa.com
MODEL
CL-1000
CL-1001
CL-1100
CL-1101
CL-2000
CL-2001
CL-2100
CL-2101
CL-2204
CL-2300
CL-2301
CL-2400
CL-3000
CL-3001
CL-4000
Brown
White
Brown
White
Brown
White
4x450 mm White
AWG 22
19 mm
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
19 mm
N.C. contact
19 mm
CL-3001
N.C. contact
19 mm
N.C. contact
6 mm
ROLL PLUNGER FLUSH CONTACT
CODE
CL1000
CL1001
CL1100
CL1101
CL2000
CL2001
CL2100
CL2101
CL2204
CL2300
CL2301
CL2400
CL3000
CL3001
CL4000
White
19 mm
CL-3000
CL-4000
Colour
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
2x450 mm White
AWG 22
DESCRIPTION
Recessed mount miniature contact, 0.5A, white colour
Recessed mount miniature contact, 0.5A, brown colour
Recessed mount miniature contact, 0.5A, white colour
Recessed mount miniature contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, white colour
Recessed mount standard contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, white colour
Recessed mount standard contact, 0.5A, brown colour
Recessed mount standard contact, 0.5A, 4-wire, white colour
Recessed mount standard contact, screw terminals, 0.5A, white colour
Recessed mount standard contact, screw terminals, 0.5A, brown colour
Recessed mount standard contact, 0.5A, 4-wire, white colour
Recessed mount contact for steel doors, 0.4A, white colour
Recessed mount contact for steel doors, 0.4A, brown colour
Recessed mount roll plunger flush contact, 0.5A, white colour
Dimensions (mm)
63
Surface mount Magnetic Contacts
• A complete line of high quality magnetic contacts, for the
best performances.
• Contacts in rhodium and magnets in N35 alloy for reliable
operation and long life
• Contacts N.C. with magnet in the gap
• Lifetime warranty
• Maximum initial contact resistance: 0.2 ohm
• Maximum contact rating: 10W
• Maximum switching voltage: 100VDC/VAC
• Maximum switching current: 0.5A
• All contacts must be ordered in packs of 10 pcs. except
Industrial contacts, Overhead door contacts and
CL-6000/CL-6001 which are packed individually
Model
Description
SUB MINIATURE MAGNETIC CONTACT, 26 mm LONG
CL-5200
N.C. contact
CL-5200
N.C. contact
CL-5300
N.C. contact
Gap
Leads
12 mm
12 mm
22 mm
2x450mm AWG 22 White
2x450mm AWG 22 White
2x95mm AWG 22 White
SUB MINIATURE FLANGE MAGNETIC CONTACT, 28 mm LONG
CL-5000
N.C. contact
24 mm
2x450 mm
AWG 22
2x450 mm
AWG 22
CL-5001
N.C. contact
24 mm
MINIATURE FLANGE MAGNETIC CONTACT, 34 mm LONG
CL-5100
N.C. contact
25 mm
N.C. contact
25 mm
DESIGN MAGNETIC CONTACT WITH SCREW TERMINALS
CL-6000
N.C. contact
CL-5101
25 mm
CL-6001
N.C. contact
25 mm
STANDARD MAGNETIC CONTACT WITH SCREW TERMINALS, COVER SPACER
CL-6100
N.C. contact
30 mm
CL-6101
N.C. contact
30 mm
CL-6200
SPDT contact
28 mm
INDUSTRIAL MAGNETIC CONTACT WITH SCREW TERMINALS
CL-7000
N.C. contact
65 mm
Colour
White
Brown
2x450 mm White
AWG 22
2x450 mm Brown
AWG 22
Screw
terminals
Screw
terminals
White
Screw
terminals
Screw
terminals
Screw
terminals
White
Screw
terminals
INDUSTRIAL ALUMINIUM SUPERVISED CONTACT WITH STAINLESS STEEL ARMORED CABLE
Brown
Brown
White
Grey
CL-7100
N.C. contact
38 mm
4x450 mm Aluminium
CL-7200
N.C. contact, with bracket
75 mm
4x290 mm Aluminium
FLOOR MOUNT OVERHEAD DOOR CONTACT WITH STAINLESS STEEL ARMORED CABLE
CL-8000
CODE
CL5000
CL5001
CL5100
CL5101
CL5200
CL5201
CL5300
CL6000
CL6001
CL6100
CL6101
CL6200
CL7000
CL7100
CL7200
CL8000
www.hesa.com
MODEL
CL-5000
CL-5001
CL-5100
CL-5101
CL-5200
CL-5201
CL-5300
CL-6000
CL-6001
CL-6100
CL-6101
CL-6200
CL-7000
CL-7100
CL-7200
CL-8000
N.C. contact with bracket
60 mm
4x500 mm Aluminium
DESCRIPTION
Surface mount sub-miniature contact, 0.5A, white colour
Surface mount sub-miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount miniature contact, 0.5A, brown colour
Surface mount miniature contact, 0.5A, white colour
Surface mount standard contact, 0.5A, white colour
Surface mount standard contact, 0.5A, brown colour
Surface mount standard contact, 0.5A, white colour
Surface mount standard contact, 0.5A, brown colour
Surface mount standard contact, 0.2A, white colour
Surface mount industrial contact, 0.5A, grey colour
Surface mount industrial contact, 0.4A, aluminium
Surface mount industrial contact, 0.4A, aluminium
Overhead door contact, 0.4A, aluminium
Dimensions (mm)
LOCAL PROTECTION DEVICES
64
Contacts for Roller-shutters, Shock sensors & Glass break detectors
Model
Description
Colour
H-666
Stick contact for roller-shutters
Dimensions (mm)
CONTACTS FOR ROLLER-SHUTTERS
100
89
Brown
96
16
60
SWITCHALARM 2 Switch contact for roller-shutters
with precision mechanism
White
43
102
90
ANALYSER
15
Analyser circuit for SWITCH ALARM contacts
56
60
PIEZO SHOCK SENSOR
IMPACTOR
IMPACTOR-M
Piezo shock sensor white colour
Piezo shock sensor, brown colour
IMPACTOR-LC
Piezo shock sensor, low current version,
white colour
1st Level
FEATURES
• Adjustable sensitivity
• LED alarm memory
• Alarm relay output
• Detection range up to 6 sqm
• IMQ 1° Level Certification
• Power Input 3 ~ 4.5VDC (IMPACTOR-LC only)
86
25
20
GLASS BREAK DETECTORS
LC-105-DGB
Digital Glassbreak detector
FEATURES
• Form “A”alarm contact and tamper switch
• Digital signal analysis
• Detects the sound of all types of breaking
framed glass
• Phased frequency detector sensor
• Able to adjust sound sensors separately
• Ceiling or wall mount installation
• Slim profile design
• Features ABS plastic for shock and impact
protection
CODE
MODEL
DESCRIPTION
HV666
SM03
SM02
LDSS-IM
LDSSBRN
LDSIMLC
D2L105GB
H-666
SWITCHALARM2
ANALYSER
IMPACTOR
IMPACTOR-M
IMPACTOR-LC
LC-105-DGB
Stick contact for rolling-shutters, brown colour
Switch contact for rolling-shutters with precision mechanism, white colour
Analyser circuit for SWITCHALARM contacts
Piezo shock sensor, white colour. IMQ 1° Level Certification
Piezo shock sensor, brown colour . IMQ 1° Level Certification
Piezo shock sensor, low current version, white colour.
Digital glassbreak detector
www.hesa.com
65
Water Presence sensors & Emergency Hold-Up devices
Model
Description
Colour
WA-2
Water presence sensor
FEATURES
• Alarm buzzer built-in,
• Relay Output: 1A@28VDC
• Power Input 12VDC
White
Additional probe for WA-2
water presence sensor
White
Dimensions (mm)
WATER PRESENCE SENSORS
WA-P
105
94
28
72
65
20
EMERGENCY HOLD-UP DEVICES
266-IT
Hold-up Foot Rail
IMQ 1st Level Certification
Grey
120
420
85
1st Level
269
Emergency Hold-Up button
Grey
269-IT
Emergency Hold-Up button
with tamper protection.
IMQ 2nd Level Certification
Grey
88
2nd Level
CODE
MODEL
DESCRIPTION
HE266IT
HE269
HE269IT
HEWA-2
HEWA-P
266-IT
269
269-IT
WA-2
WA-P
Hold-up foot rail, grey colour. IMQ 1st level Certification
Emergency Hold-Up button, white colour
Emergency Hold-Up button with tamper, white colour. IMQ 2nd level Certification
Water presence sensor, white colour
Additional probe for WA-2 water presence sensor, white colour
www.hesa.com
54
30
LOCAL PROTECTION DEVICES
66
LiteSUN
Anti-theft system for photovoltaic solar panels
with plastic optical fiber
DESCRIZIONE
Photovoltaic solar panels are more and more employed and they are really
appreciated expecially by thiefes. People who invest on alternative energies know that
they can only be profitable on the long run. Up to now, no solutions have been available that were cheap and easy to install, and that could be installed also on existing
photovoltaic fields. LiteSun is an anti-theft system that protects your solar panels
joining them together in an unbreakable ring. The way it works is very simple: you
cannot remove a panel without breaking the plastic optical fiber LiteWire.
LS300C1S
Single Ring Transmitter + Receiver
sensitive to breaking fiber
LS300C2S
Double Ring Dual Transmitter + Dual
Receivers sensitive to breaking fiber
LS300P
Single Ring Transmitter + Receiver
sensitive to folding and breaking fiber
LS300C1T
Single Transmitter sensitive to breaking
fiber
LS300C1R
Single Receiver sensitive to breaking
fiber
LS300C2T
Dual Transmitter sensitive to breaking
fiber
LS300C2R
Dual Receiver sensitive to breaking fiber
LS300R1R
Amplifier sensitive to breaking fiber
SPECIFICATIONS
Possible configurations
Ring length
Type of signal
Type of fiber
Input
Output
Signals
Power supply
Consumption (mA)
Protection rate
Operating temperature
www.hesa.com
Single ring transceiver
Double ring transceiver
Single transmitter
Single receiver
Double transmitter
Double receiver
Link repeater
300 m
Optical, encoded 525nm
Plastic Fiber LiteWire with attenuation <100dB
Device test
Alarm relay (max. 0.25A/50VDC)
Ring status, Power, Test
12VDC
54 max.
IP40 (IP65 optional)
-40°C ~ +85°C
FEATURES
• Easy: plastic optical fiber LiteWire are
connectorized in 30 seconds without
special instruments
• Flexible: it has a diameter of just
2.2mm and a bending radius of only
20mm for a quick and simple
installation
• Resistant: it is an optical fiber, it
doesn't age or oxidize and has a life
time of a hundred years
• Protective: it is an optical fiber, you
cannot by-pass it to steal a panel
• Secure: it completely removes false
contacts
• Certain: it is a mechanical system, it
cannot be tapped or removed
67
LiteSUN
Anti-theft system for photovoltaic solar panels
with plastic optical fiber
CONNECTION DIAGRAM
SINGLE RING CONNECTION
DOUBLE RING CONNECTION
Alarm 1 out
Alarm 2 out
Alarm out
LS300C1S
LS300C2S
LINEAR CONNECTION WITH REPEATERS
Alarm out
sensitive to breaking fiber
CODE
MODEL
DESCRIPTION
H9LS301S
H9LS302S
H9LS301T
H9LS301R
H9LS302T
H9LS302R
H9LS30R
H9LS300P
LS300C1S
LS300C2S
LS300C1T
LS300C1R
LS300C2T
LS300C2R
LS300R1R
LS300P
Single Ring Transmitter + Receiver sensitive to breaking
Double Ring Dual Transmitters + Dual Receivers sensitive to breaking
Single Transmitter sensitive to breaking
Single Receiver sensitive to breaking
Dual Transmitter sensitive to breaking
Dual Receiver sensitive to breaking
Amplifier
Single Ring Transmitter + Receiver sensitive to breaking and folding
Accessories
H9CSMA
H9CHFBR10
H9CPSMA
H9CHEX
H9CSA
H9LWKIT
CSMA
HFBR-10P
PSMA
CHEX
CSA
LWKIT
H9CASMA
H9CV25M
H9CV25B
H9CT25B
H9LSBL1
H9LSBL2
ASMA
CV25M
CV25B
CV25R
LSBOLT1
LSBOLT2
F-SMA Connectors (10 pcs. Kit)
10 pcs. connectors HFBR + 1 puck for plastic fiber
Puck to polish bugs on connectors
Crimping Tool HEX 3mm for F-SMA Connectors
Stripping Tool
Complete kit for Fiber Plastic connection, including crimping tool,
cutter, stripping tool, puck, 10 pcs. F-SMA connectors, 5 pcs. hooks,
in ABS briefcase
F-SMA sand for Junctions
Plastic Fiber 200m roll
Plastic Fiber 500m spool
Plastic Fiber Anti-rodent version, 500m spool
8 mm bolt head
15 mm bolt head
www.hesa.com
CSMA
CV25M
HFBR
PSMA
CHEX
CSA
LWKIT
ASMA
CV25B
CV25R
LOCAL PROTECTION DEVICES
68
SicurSPOT
Anti-theft system for photovoltaic solar panels
with optical fiber
SICURSPOT
Single Ring Transmitter + Receiver
sensitive to breaking fiber
SPECIFICATIONS
Item
Ring length
Type of signal
Supervisor
Sensitive to cutting
Sensitive to folding
Output
Power supply
Current drain
EMI/RFI immunity
Operating temperature
Operating umidity
USES
SicurSPOT
0~1000m
Optical, encoded 850nm
1000/s
YES
–
1 potential-free contact relay
10VDC~14VDC
max. 100mA (with relay activated)
YES
0°C~+60°C
70%
CODE
H9SPOT
MODEL
SicurSPOT
DESCRIPTION
Single Ring Transmitter + Receiver sensitive to breaking
Accessori
H9SPCV5
H9SPCV10
H9SPCV25
H9SPCV50
H9SPCVSPL
H9SPCVSPLU
H9SPCVVFL
H9SPCVST5
H9SPCVST2
H9SPCVKIT
CV-FO50
CV-FO100
CV-FO250
CV-FO500
CV-FOSPL
CV-FOSPLU
CV-FOVFL
CV-ST50/125
CV-STMOD
CV-FOKIT
Optical Fiber 50m roll
Optical Fiber 100m roll
Optical Fiber 250m roll
Optical Fiber 500m spool
Antitorsion CamSplice Mechanical Splice
Crimp Tool for Antitorsion CamSplice Mechanical Splice
Fiber Optic Light Source
ST50/125 Unicam Connector
Barrel adapter for optic junctions
Complete kit for Unicam connection for ST, SC and LC connectors
www.hesa.com
FEATURES
• Optical fiber has a diameter of just
2.8mm and doesn't age or oxidize and
has a life time of a hundred years
• It is a simple and cost-effective
system that builds fiber rings of
1000m to join hundreds of panel
together with a single cable
• Optical fiber cannot by-pass tapped or
removed
69
www.hesa.com
ALARM CONTROL SYSTEMS
MODULO XP Systems
Control panels
Keypads
Wireless receiver & devices
ALARM CONTROL SYSTEMS
72
MODULO XP Systems
MODULO XP6
MODULO XP6
6-zone hybrid
hardwire/wireless systems
promise even the
discriminating consumer,
some of the most reliable
security technology available
at an unsurpassed value
DIMENSIONS (mm)
282
310
80
MODULO XP6
SPECIFICATIONS
Model
Transformer supplied
Loop voltage
Loop resistance
Loop current:
Zone 1, 2, 3
Zone 4, 5 ,6
Alarm out burglary
Alarm output fire
Combined stand-by current
Operating temperature
Max battery size
www.hesa.com
MODULO XP6
16.5 VAC 15VA
5 VDC
100 ⏲ max
0.9mA
0.55mA
12VDC, max 2A
12VDC 125 mA
500 mA
0°C ~ +49°C
12VDC 7Ah
FEATURES
• 6 programmable, hardwire
zones plus 1 fire zone
• 6 individually reporting
users codes
• Super-easy, LED keypads
with 3 keypad panics
buttons, privacy door and
concealed zone directory great new decor- blending
contemporary styling!
• Up to 6 wireless points,
plus 2 to 4 wireless
keyfobs. (Assured
trasmitter signal stregth
annunciated at keypad)
• Modulo XP6 ncludes
2-wireUL fire supporting up
to wireless smoke detectors
• Adjustable supervisory time
for transmitter check-in
• Programmable telephone
line cut supervision
• 2 Programmable outputs
for burglary, siren, strobe,
audio verification- by-zone,
access control, etc.
• EZ-Loops™ exclusive,
intuitive, easy-to-wire
double zoning with fault
supervision
• EZ-Wire full-size terminal
strip
• Home/away with delay for
auto interior bypass
• Chime feature
• Supervised bell output
• Swinger shutdown
• Quickloader® PCD-WINDOWS
Software for easy
up/downloading. Includes
unique unattended method,
selectable call-back or
instant-connect, keypadactivated method.
• Reports in all major
formats: 3/1, 4/2, Ademco
Slow. Radionics Fast, Silent
Knight Fast, Universal High
Speed & Point ID.
• Also Reports on Pager
Format
• Reporting to up to 3 phone
numbers.
• Wireless support for up to 4
key fobs with
programmable audible
“chirp” arm/disarm; plus 6
points from your choice of
any MDXP transmitters
• Support up to 4 RPX-6 or
RPX6-AG keypads
73
MODULO XP Systems
MODULO XP6 - Keypads
RPX-6
MODULO XP6 Keypad,
white color
RPX6-AG
MODULO XP6 Keypad,
silver color
SPECIFICATIONS
Model
LED display
Keypad-activated panic alarms
Keypad backlight
Power voltage
RPX-6
RPX6-AG
6
3
YES
12VDC from
panel MODULO XP6
65 mA
0°C ~ + 49°C
Current drain max
Operating temperature
Color
white
DIMENSIONS (mm)
118
116
30
RPX-6 / RPX6-AG
CODE
MODEL
DESCRIPTION
NPXP60I
NPRPX-6
NPRX6G
MODULO XP6
RPX-6
RPX6-AG
Hybrid 6-zone control panel. RPX-6 keypad included
6-zone LED additional keypad white colour
6-zone LED additional keypad silver colour
www.hesa.com
silver
FEATURES
• Deluxe backlit keypad RPX-6
supplied with Modulo XP6
System
• Very easy to use and learn.
• Attractive, decorator white
keypads with compact
styling
• Multilingual displays
available
• Vivid LED keypad display.
• 3 Keypad activated panics.
• Visual & audible indicators
for actual wireless
transmitter signal strength
(1-4) through keypad’s
sounder & LEDs
• Full-size touch-tone keys.
• Keypad display of:
transmitter trouble,
transmitter low battery,
telephone line failure (also
with audible annunciation)
• Up to 4 Keypads Supported
• Keyswitch Option
ALARM CONTROL SYSTEMS
74
MODULO XP Systems
Wireless
REC-XP433
RF receiver for MODULO XP6
systems
FEATURES
• Support up to 8 wireless
detectors, 4 keyfobs, 4
wireless smoke detectors
• Dual diversity antennas
minimize nulls & enhance
reliability
• Separate programmable
supervisory times by device
type
SPECIFICATIONS
• Possibility to monitor the
signal strenght of the
detectors on the keypad
• Maximum 2 receivers per
system
• Tamper and RF-jamming
supervision
DIMENSIONS (mm)
Model
Tamper
Power voltage
Current drain (max)
Operating temperature
Weight g
REC-XP433
N.C. with cover in place
12VDC from MODULO XP4 / XP6 panels
60 mA
0° C ~ + 49°C
196
355
180
REC-XP433
CODE
MODEL
DESCRIPTION
NPXZREC
REC-XP433
Supervised 8-zone wireless receiver for and MODULO XP6 systems
www.hesa.com
44
75
MODULO XP Systems
Indoor wireless PIR detectors
MDXP-PIR
Wireless PIR
• EMI/RFI protected with
fully-shielded SMD
circuitry
• Interchangeable lenses
• Pulse Count
DIMENSIONS (mm)
• Signal selective processing
• Auto temperature
compensation
• Tamper
• Broad 15x15 m coverage
114
64
58
MDXP-PIR
MDXP-170
Wireless long range PIR
• Pulse count
• 3-step lens angle
adjustment
• Double conductive
shielding
• Multi-focus optics
• Tamper
• Wide-angle 21x21 m
or long-range 45x2.4 m
detection
144
105
93
MDXP-170
SPECIFICATIONS
Model
Detection range m
Power supply
Battery life
Wireless range
Operating temperature
Weight g
CODE
NPXZPIR
NPXZ170
MODEL
MDXP-PIR
MDXP-170
Accessories for MDXP-PIR
NP-818
LENS818
NP-SLV2
SVL2
Accessories for MDXP-170
OXCA-1W
CA-1W
OXCA-2C
CA-2C
www.hesa.com
MDXP-PIR
MDXP-170
15x15
21x21 or 45x2.4
2 Li-Ion batteries 3VDC DL123A
Li-Ion battery 3VDC DL123A
5 ~ 6 years
4 ~ 5 years
120 m in a typical residential environment
0° C ~ + 50°C
181
200
DESCRIPTION
Wireless PIR, detection range 15x15 m
Wireless long range PIR, Multi focus optics:
wide-angle 21x21 m or long-range 45x2.4 m
SVLBKT
SVL2
CA-1W
CA-2C
Curtain lens
Wall mounting swivel bracket for PIR-650EX and IQ VISION
Wall mounting swivel bracket
Ceiling mounting swivel bracket
ALARM CONTROL SYSTEMS
76
MODULO XP Systems
Outdoor wireless PIR detectors
MDXP-402
Multiple detection pattern
outdoor PIR detector.
Detection range 12m, 90°
DETECTION PATTERNS (m)
Position
Side View
A m 12
1
0
0
FEATURES
• Limited detection range
function
• Size judging function
• Patented double conductive
shielding
• Sensitivity selection switch
• Photocell for day and night
operation
• Temperature compensation
• Selectable NC or NO alarm
output
MDXP-80NR
Battery operated outdoor PIR
detector for building
perimeter. Detection range
24m (12m on each side)
DESCRIPTION
The MDXP-402 provides an
innovative solution to external
area detection. It employs a
highly reliable dual detection
technique, which prevents
false activations caused by
small animals and birds.
Two discrete detection areas
are created and only when an
intruder is detected inside
both areas is an alarm output
triggered.
Double Conductive Shielding
ensures that the sensor is
resistant to interference from
foreign light sources such as
the sun and car headlights.
DESCRIPTION
With long, narrow detection
areas that extend from both
its sides the MDXP-80NR is
specifically designed to be
wall-mounted centrally on a
building, covering the
building perimeter with a
multi-layered, horizontal
barrier that detects intruders
before they break in. To help
reduce false activations, the
range can be adjusted so
that detection extends only to
the end of the building.
5
10 12
5
Bm8
1
0
0
5
10 12
1
0
0
5
5
Active detection zones
(90˚ wide
7 fingers)
0
Cm5
5
Dm2
10
12
10 12
1
0
0
Adjustable zones
(15˚ step per notch)
12
10
Adjustable zones
(15˚ step per notch)
0
10 12
5
10 12
DETECTION PATTERNS (m)
Front view
12
10
5
0
5
10
12
Approx. m 1.3
at m 12
The angles of all detection areas are
adjustable horizontally 0° or 3°
The angles of all detection areas
are adjustable horizontally 0° or 3°
Detection Area: 12m (single side)
Side view
12
10
5
0
0
5
10 12
Detection Area: 8m (single side)
5
10
12
Detection Area: 5m (single side)
0
5
10
12
Detection Area: 2m (single side)
0
FEATURES
• Patented double conductive
shielding
• Advanced temperature
compensation
• Limited detection range
function
www.hesa.com
Top View
• Size judging function to
avoid false alarms
• Variable detection range up
to 24m (12m on each side)
• Audible alarm indicator to
deter intruders
5
10
12
• Attractive, slender design
• Battery saving circuit
• Form C alarm output and
tamper output
• Low current draw
77
MODULO XP Systems
Outdoor wireless PIR detectors
SPECIFICATIONS
Model
Detection range m
Detection areas
Power consumption: N.C.
Sensitivity
Detectable speed
Pulse count
RF noise
Alarm relay
Tamper switch
LED
MDXP-402
MDXP- 80NR
12m*, angle 90° (standard)
24m* (12m per side)
14
4 (2 per side)
10µA
15µA (idle) 3 mA (alarm)
2.0°C / 0.6 m/s
2.0°C / 0.6 m/s
from 0.3 to 1.5 m/s
from 0.3 to 1.5 m/s
2 or 4 pulses every 20s ± 5 s
–
no alarm up to 30V/m
no alarm up to 20V/m
N.C./N.O.: 0.01A @ 10VDC
SPDT contact 10VDC or 0.01A
N.C. with cover in place
off during work,
blinking during warm-up,
light in alarm condition
enabled in walk test
3VDC Li-Ion Battery DL123A
4 - 5 years
120m in a typical residential environment
-20° C ~ + 50°C
95%
IP54
IP55
Pole or Wall mount
Indoor/Outdoor Wall mount
0.8m ~ 1.20m
Pole mounting kit, mounting screws
grey
500
583
Power supply
Battery life
Wireless range
Operating temperature
Relative humidity
IP rating
Mounting
Mounting height m
Accessories
Colour
Weight g
* Detection range may vary between m10 and m15 depending on operating temperature
DIMENSIONS (mm)
235
190
55
128
108
80
MDXP-402
MDXP-80NR
CODE
MODEL
DESCRIPTION
NPXZ402
MDXP-402
NPXZ80N
MDXP-80NR
Multiple detection pattern outdoor PIR detector with low current draw.
Detection range 12m, 90°
Battery operated Outdoor PIR detector for building perimeter.
Detection range 24m (12m on each side)
Accessories per rivelatori MDXP-80NR
OXBXBA1
www.hesa.com
BA-1W
Wall mounting swivel bracket kit
BA-1W
ALARM CONTROL SYSTEMS
78
MODULO XP Systems
Outdoor wireless PIR detectors
MDXP-80AM
High mount outdoor PIR
detector, 24m with
antimasking
MDXP-40AM
High mount outdoor PIR
detector with anti-masking
technology, detection range
12m
FEATURES
• 94 highly density detection
zones (MDXP-40AM)
• Digital anti-masking
function
• Intelligent AND logic Dual
signal processing circuit
- Summer night
compensation logic
- Advanced temperature
compensation logic
- Vegetation sway analysis
logic
DETECTION RANGE (m)
• Patented double conductive
shielding
• Ideal detection area setting
- adjustable
detection
length
- spot area flexible masking
• Mounting height 2.5m~3m
• 180° angle adjustable
bracket / hood
DETECTION RANGE (m)
Top View
Top View
Side View
Side View
DIMENSIONS (mm)
Including brachet
Using bracket and hood
99
Without bracket and hood
266
92
93
MDXP-40AM
www.hesa.com
93
148
198
205
Without brachet
286
197
MDXP-80AM
198
205
79
MODULO XP Systems
Outdoor wireless PIR detectors
SPECIFICATIONS
Model
Power input
Power drain
MDXP-40AM
MDXP-80AM
3VDC Li-Ion Battery
30 µA (standby)
4mA (max) @ 3VDC
Pir coverage
Sensitivity
Detectable speed
RF interference
4m~12m, 85°/ 94 zones
24m x 2m narrow / 20 zones
2.0°C at 0.6 m/s
0.3 m/s - 1.5 m/s
No alarm 10V/m
Form C
Solid State Switch
10Vc.c. @ 0.01A (max)
2.0 ± 1s
N.C./N.O. Selectable
Solid State Switch
10Vc.c. @ 0.01 A max
Form C., 28VDC, 0,1 A (max) activates when cover removed
Approx. 90s (LED blinks)
YES
–20°C ~ +60°C
95% (max.)
IP 55
wall
2.5~3.0m
V ±20°, H ±95°
600
780
Alarm output
Alarm period
Trouble output
Tamper output
Warm-up period
Anti-masking
Operating temperature
Environment humidity
Weatherproof
Mounting
Mounting height m
Bracket adjust angle
Weight g
CODE
MODEL
DESCRIPTION
NPXZ40AM
MDXP-40AM
NPXZ80AM
MDXP-80AM
High mount outdoor PIR detector with anti-masking technology,
detection range 12m
High mount outdoor PIR detector with anti-masking technology,
detection range 24m
www.hesa.com
ALARM CONTROL SYSTEMS
80
MODULO XP Systems
Wireless door/window transmitters and keyfobs
TRANS2-B
Wireless door/window
magnetic contact,
white colour
TRANS2-N
Wireless door/window
magnetic contact,
black colour
FEATURES
• Compact and low profile
• Reversible mounting position for left or right handed
operation
• Low battery clearly
displayed at keypad by
zone and trasmitter number
• All models include built-in
reed switch, magnet,
lithium battery, tamper and
terminals
DIMENSIONS (mm)
80
40
26
38
14
11
TRANS2-B / TRANS2-M /
TRANS2-N
SPECIFICATIONS
TRANS2-M
Wireless door/window
magnetic contact,
brown colour
MDXP-KEYF
Wireless keyfob/emergency
pendant transmitter
SPECIFICATIONS
Model
Power Supply
Battery life
Wireless range
Operanting Temperature
Weight g
MDXP-KEYF
Li-Ion Battery 3VDC CR2032
5 - 6 years
100 m in a typical residential
environment
0° C ~ + 49°C
39
Model
Power supply
Battery life
Wireless range
Operating temperature
Color
Weight g
FEATURES
• 4-button operation: 2 for
on/off of security system
and 2 programmable for
aux. functions, e.g. panic,
medical, relays or relay
groups, instant or X-10
control
• Visual indicator confirms
transmission or low battery
• Includes key ring, neck
chain, replaceable battery,
2 & 4 key (button) sets and
plugs for unused keys
CODE
MODEL
DESCRIPTION
NPXZRTB
NPXZRTM
NPXZRT2
NPXZKEY
TRANS2-B
TRANS2-M
TRANS2-N
MDXP-KEYF
Wireless door/window magnetic contact, white colour
Wireless door/window magnetic contact, brown colour
Wireless door/window magnetic contact, black colour
Wireless keyfob/emergency pendant transmitter
www.hesa.com
TRANS2-B TRANS2-M TRANS2-N
Li-Ion battery 3VDC DL123A
5 - 6 years
120 m in a typical residential
environment
0° C ~ + 49°C
White
Brown
Black
63
DIMENSIONS (mm)
70
40
MDXP-KEYF
18
81
MODULO XP Systems
Wireless perimeter protection detectors
MDXP-IMP
Wireless piezo shock sensor
FEATURES
• Adjustable sensitivity
• Tamper
• White colour
DIMENSIONS (mm)
88
MDXP-TAP
Wireless switch contact for
roller shutters against lifting
and cut
FEATURES
• Adjustable sensitivity
• Tamper
• White colour
30
27
40
26
80
MDXP-IMP
90
MDXP-GB
Wireless acoustic glass break
detector with Shatterpro II
technology
FEATURES
• Superior-immunity to false
alarms and excellent
detection, even through
blinds & light drapes
• Pattern Recognition
Technology - recognizes the
actual pattern of glass
breaking across the full
audio band
• 7m coverage radius with
automatic test for easy
installation
• Enduser hand clap sensor
verification
• Includes lithium battery,
tamper & mounting kit
102
15
65
65
21
80
40
26
MDXP-TAP
80
SPECIFICATIONS
106
Model
Power supply
MDXP-IMP
MDXP-TAP
Li-Ion Battery 3VDC DL123A
MDXP-GB
2 Li-Ion Batteries
3V DL123A
4 - 5 years
5 - 6 years
120 m in a typical residential environment
0° C ~ + 49°C
0° C ~ + 50°C
100
230
167
Battery life
Wireless range
Operating temperature
Weight g
CODE
MODEL
DESCRIPTION
NPXZIMP
NPXZTAP
NPXZGB
MDXP-IMP
MDXP-TAP
MDXP-GB
Wireless piezo shock sensor
Wireless switch contact for roller shutters against lifting and cut
Wireless acoustic glass break detector with Shatterpro II technology
www.hesa.com
MDXP-GB
45
ALARM CONTROL SYSTEMS
82
MODULO XP Systems
Wireless smoke sensors, call points, water sensors
MDXP-SMK
Wireless photoelectric
smoke detector
FEATURES
• Built-in test switch
• Visual LED indicates alarm
and standby
• Includes batteries and
mounting kit
DIMENSIONS (mm)
140
140
58
MDXP-SMK
WA-P
Water presence sensor
to be connected to TRANS2
FEATURES
• It detects water presence
between the two probes
• To be wired to TRANS2
input
72
65
WA-P
SPECIFICATIONS
Model
Power supply
Battery life
Wireless range
Operating temperature
Weight g
MDXP- SMK
WA-P
2 alkaline batteries 9V
Li-Ion battery 3VDC DL123A
2 - 3 years
4 - 5 years
120 m in a typical residential environment
0° C ~ + 49°C
300
98
CODE
MODEL
DESCRIPTION
NPXZSMK
HEWA-P
MDXP-SMK
WA-P
Wireless photoelectric smoke detector
Water presence sensor to be connected to TRANS2
www.hesa.com
20
83
MODULO XP Systems
Alkaline and Lithium Batteries
MN1604/10
Pack of 10 pcs. Alkaline 9V
batteries
MN1604/50
Pack of 50 pcs. Alkaline 9V
batteries
2032
Lithium 3V battery CR2032
2032C
Pack of 10 pcs. Lithium 3V
batteries CR2032
2032P
Pack of 25 pcs.
3V Lithium batteries CR2032
DL123A
Lithium 3V Battery DL123A
CODE
MODEL
DESCRIPTION
UL9-1
UL9-2
LR2032
LR2032C
LR2032P
II687PR
MN1604/10
MN1604/50
2032
2032C
2032P
DL123A
Pack of 10 pcs. Duracell Alkaline 9V batteries for MDXP-SMK
Pack of 50 pcs. Duracell Alkaline 9V batteries for MDXP-SMK
Duracell Lithium 3V battery CR2032 for MDXP-KEYF
Pack of 10 pcs. Duracell Lithium 3V battery CR2032 for MDXP-KEYF
Pack of 25 pcs. Duracell Lithium 3V battery CR2032 for MDXP-KEYF
Duracell Lithium 3V battery DL123A for TRANS2-B, TRANS2-M, TRANS2-N, MDXP-PIR, MDXP-161, MDXP-170,
MDXP-402, MDXP-80NR, MDXP-IMP, MDXP-TAP, MDXP-GB and MDXP-288
www.hesa.com
REMOTE CONTROL STATIONS KEYSWITCHES
Key Control Stations
Digital Keypad Systems
Keyswitches
REMOTE CONTROL STATIONS - KEYSWITCHES
86
Key Control Stations
KABA High Security Registered Key Systems
SER-6
KABA QUATTRO PLUS SPDT
keyswitch
1st Level
SER-7
KABA QUATTRO PLUS SPDT
keyswitch with spring return
1st Level
SER-8
SPDT round key switch
FEATURES
• Supplied with an
aluminium anodized front
cover and sturdy aluminium die-cast
• 2 LED indicators
• Two mounting versions:
Surface mount (SR version)
or Recessed mount (MSB
version)
• Supplied with 3 keys, or 5
keys (5 version)
• Registered keys are supplied
to a specific number
• Cylinders are supplied to a
specific code
• KABA QUATTRO PLUS is the
key system to offer key registration for the strict control
of keys against authorised
signature
DIMENSIONS (mm)
118
73
52
SER-6
SER-7
118
95
73
52
SER-6/MSB
SER-7/MSB
118
1st Level
74
63
SER-8
SER-9
SER-10
SER-8
118
95
SER-9
SPDT flat key switch
74
SER-10
SPDT flat key switch with
spring return
SER-9
www.hesa.com
SER-10
SER-8/MSB
SER-9/MSB
63
87
Key Control Stations
Round key and flat key series
SPECIFICATIONS
Model
Key withdrawal position
Spring return
Key angle movement
Switch
Contacts rating
Supplied keys
Cylinders supplied to a specific key
Key supplied to a specific cylinder
IMQ Certification
(only surface mounting version)
CODE
HE6-3P
HE6-5P
HE6-3I
HE6-5I
HE7-3P
HE7-5P
HE7-3I
HE7-5I
HE8-2P
HE8-2I
HE9-2P
HE9-2I
HE10-2P
MODEL
SER-6/SR
SER-6/SR-5
SER-6/MSB
SER-6/MSB-5
SER-7/SR
SER-7/SR-5
SER-7/MSB
SER-7/MSB-5
SER-8/SR
SER-8/MSB
SER-9/SR
SER-9/MSB
SER-10/SR
Accessories
HE3L
3L
www.hesa.com
SER-6
2
NO
180°
SER-7
1
YES
45°
SER-8
SER-9
SER-10
1
YES
45°
2
NO
90°
SPDT
3A@125VDC
3 or 5
YES
YES
YES (max 20 pcs.)
YES
1st level
1A@250VDC
2
YES (max 25 pcs.)
YES (max 25 pcs.)
Keyblank
–
DESCRIPTION
KABA QUATTRO PLUS SPDT keyswitch, surface mounting version, supplied with 3 keys. 1st level IMQ Certification
KABA QUATTRO PLUS SPDT keyswitch, surface mounting version, supplied with 5 keys. 1st level IMQ Certification
KABA QUATTRO PLUS SPDT keyswitch, recessed mounting version, supplied with 3 keys.
KABA QUATTRO PLUS SPDT keyswitch, recessed mounting version, supplied with 5 keys.
KABA QUATTRO PLUS SPDT keyswitch with spring return, surface mounting version, supplied with 3 keys. 1st level IMQ Certification
KABA QUATTRO PLUS SPDT keyswitch with spring return, surface mounting version, supplied with 5 keys. 1st level IMQ Certification
KABA QUATTRO PLUS SPDT keyswitch with spring return, recessed mounting version, supplied with 3 keys.
KABA QUATTRO PLUS SPDT keyswitch with spring return, recessed mounting version, supplied with 5 keys.
SPDT round keyswitch, surface mounting version, supplied with 2 keys. 1st level IMQ Certification
SPDT round keyswitch, recessed mounting version, supplied with 2 keys.
SPDT flat keyswitch, surface mounting version, supplied with 2 keys.
SPDT flat keyswitch, recessed mounting version, supplied with 2 keys.
SPDT flat keyswitch with spring return, surface mounting version, supplied with 2 keys.
3 LED Indicator: Green - Yellow - Red for all SER versions.
REMOTE CONTROL STATIONS - KEYSWITCHES
88
Digital Keypad Systems
SEC3C+TEC2C
Split-decoded, 3-output
keypad system
TEC-5C
Self-contained, 3-output
keypad system
www.hesa.com
DESCRIPTION
Split-decoded, three output
keypad system designed for
office and home security and
access control applications.
The system is adopting “Split
Decoded” design philosophy
to give highest security. Each
unit is split in two parts, the
remote keypad unit and the
master decoder unit, they
communicate with each other
in digital data. Anyone who
tries to cut or short the
connection wires at the
remote keypad can not
compromise the security of
the system or bypass the
keypad function.
The SEC3C+TEC2C uses
current mode data bus
communication, one master
unit can accommodate up to
3 remote keypad units
connected in parallel for
totally indipendent operation,
It employs 3 User codes and
one Super User code for
operating of the 3 outputs
which are designed for door
strike and other security and
access control applications.
With its E2PROM memory, the
system’s programmed data is
nonvolatile in case of power
failure. Over 100 million
combinations are possible for
the 3 User codes, the Master
code (it also acts as the
Super User code) and the
Duress code.
FEATURES
• Split-decoded system
• Weatherproof &
tamperproof
• Keypad programmable,
1-8 digit code length
• E2PROM non-volatile
memory
• Over 100 million code
combinations
• Momentary or start/stop
mode outputs
• Duress & accelerated codes
• Egress input for easy exit
• Audible key beep & visible
LED signals
• Multi-station operations
• Door auto re-lock
• 12V DC/AC operation
DESCRIPTION
TEC-5C digital access keypad
is a self-contained, three
output system, designed for
door strike and other security
& access control
applications. It employs
E2PROM, the system’s
programmed data is
nonvolatile in case of power
failure. Over 100 million
combinations are possible for
the three indipendent user
codes and the Master code (it
also acts as the Super User
code). The user code 1 can be
altered to act as a Duress
code for reporting duress to
an alarm system or to a
telephone dialer. Other
security features include door
sensing for door auto re-lock
function and built-in tamper
switch. For convenience, the
keypad also provides the
facility for connecting an
egress button inside the
protected area for easy exit.
The plastic case of the
keypad unit is precisely
engineered, in which, the
front panel and the mounting
box are sealed with a water
resistant gasket making the
keypad suitable for both indoor and outdoor
installations.
FEATURES
• Self-contained system
• Weatherproof &
tamperproof
• Keypad programmable, 1-8
digit code length
• E2PROM non-volatile
memory
• Over 100 million code
combinations
• Momentary or start/stop
mode outputs
• Duress & accelerated codes
• Egress input for easy exit
• Audible key beep & visible
LED signals
• Door auto re-lock
• 12V AC/DC operation
89
Digital Keypad Systems
DIMENSIONS (mm)
130
120
80
86
42
TEC2C / TEC-5C
32
SEC3C
SPECIFICATIONS
Model
Power supply
Current drain
PIN available
Relay Output
IP rating
Programmable keypad
Programmable codes
Door auto re-lock function
Non-volatile memory
Panic alarm logic output
Invalid PIN lockout
SEC3C+TEC2C
TEC-5C
12VDC/AC
110mA
100.000.000
1 to 5A@125VAC 1 to 5A@125VAC
2 to 1A@12VDC
1 to 1A@12VDC
IP55
YES
1 to 8 keys
YES
YES
YES
YES
CODE
MODEL
DESCRIPTION
HESEC3C
HETEC2C
HETEC5C
SEC3C+TEC2C
TEC-2C
TEC-5C
Split-decoded, 3 output keypad system
Remote digital keypad for SEC-3C
Self-contained, 3 output keypad system
www.hesa.com
REMOTE CONTROL STATIONS - KEYSWITCHES
90
Keyswitches
DESCRIPTION
The reversible key is extremely
difficult to copy. The code on
the key is not made by drilling
but by using a special type of
milling which conceals the
exact dimensions of the code
on the key.
There are also millings made
on the edge positions. This
gives additional security
against unauthorized key
duplications.
376-N
SPDT KABA QUATTRO PLUS
keyswitch, supplied with 3
registered keys
FEATURES
• The system can have up to
22 pairs of pins per cylinder
side
• The four rows of pins are
radial positioned and can
be fully variade to give
an unlimited amount
of variations
376-70
SPDT KABA QUATTRO PLUS
keyswitch with spring return,
supplied with 3 registered keys
• The modular construction
allows the easy installation
of inserts in other cylinder
housing
• Versions with 3 or 5
supplied keys available
DIMENSIONI (mm)
26
21
50
376-N
376-N5
376-70
376-75
375-N-D
375-N5-D
375-70-D
375-75-D
376-N5
SPDT KABA QUATTRO PLUS
keyswitch, supplied with 5
registered keys
376-75
SPDT KABA QUATTRO PLUS
keyswitch with spring return,
supplied with 5 registered keys
375-N-D
DPDT KABA QUATTRO PLUS
keyswitch, supplied with 3
registered keys
375-70-D
DPDT KABA QUATTRO PLUS
keyswitch with spring return,
supplied with 3 registered keys
375-N5-D
DPDT KABA QUATTRO PLUS
keyswitch, supplied with 5
registered keys
375-75-D
DPDT KABA QUATTRO PLUS
keyswitch with spring return,
supplied with 5 registered keys
016AL
Double throw switch, supplied
with 2 keys
23
376-N / 376-N5 / 376-70 /
376-75
26
21
52
23
375-N-D / 375-N5-D / 375-70-D
/ 375-75-D
25
45
25
016AL
016AL
99
Flat keyswitch closing contact
ON-OFF, supplied with 2 keys
31
50
31
50
23
99
99
52-J
SLC-S52J
www.hesa.com
52-J
SPDT Flat keyswitch closing
contact ON-OFF, supplied with
2 keys
SLC-S52J
SPDT Flat keyswitch with
spring return closing contact
ON-OFF, supplied with 2 keys
23
52-J / SLC-S52J
91
Keyswitches
SPECIFICATIONS
Model
Key withdrawal position
Spring return
Key angle movement
Contacts rating
Supplied keys
Key supplied to a specific cylinder
Cylinders supplied to
a specific key
CODE
MODEL
HV376-N
HV376N5
HV37670
376-N
376-N5
376-70
HV37675
376-75
HV375NQ
HV375N5Q
HV37570Q
375-N-D
375-N5-D
375-70-D
HV37575Q
375-75-D
Accessories
KA1004
8088
KA1007
8048
MW16AL
016AL
Accessories
MW16
MW16
99
52-J
SLC-S52J
Accessories
BS8044
8044
KK8047C
8049
www.hesa.com
376-70/75 375-N-D/N5-D 375-70-D/75-D
1
2
1
YES
45°
180°
45°
SPDT
Switch
BS99
GE52-J
GE52-SJ
376-N/N5
2
NO
180°
DPDT
016AL
99
2
SLC-S52J
1
YES
45°
NO
90°
Double throw
Single switch
switch
1A@125VAC
3 or 5
YES
YES
52-J
SPDT
2
Keyblank
YES
(max 20 pcs.)
DESCRIPTION
KABA Key Series
SPDT KABA QUATTRO PLUS keyswitch, supplied with 3 registered keys
SPDT KABA QUATTRO PLUS keyswitch, supplied with 5 registered keys
SPDT KABA QUATTRO PLUS keyswitch with spring return, supplied with 3
registered keys
SPDT KABA QUATTRO PLUS keyswitch with spring return, supplied with 5
registered keys
DPDT KABA QUATTRO PLUS keyswitch, supplied with 3 registered keys
DPDT KABA QUATTRO PLUS keyswitch, supplied with 5 registered keys
DPDT KABA QUATTRO PLUS keyswitch with spring return, supplied with 3
registered keys
DPDT KABA QUATTRO PLUS keyswitch with spring return, supplied with 5
registered keys
YES
YES
(max 25 pcs.)
8088
8048
Registered KABA QUATTRO PLUS key supplied to a specific number
Registered KABA-20 key supplied to a specific number
Round Key Series
Double throw switch, supplied with 2 keys
MW16 / 303
Round Keyblank for 016AL (10 pcs)
Flat Key Series
Flat keyswitch closing contact ON-OFF, supplied with 2 keys (10 pcs)
SPDT Flat keyswitch closing contact ON-OFF, supplied with 2 keys (10 pcs)
SPDT Flat keyswitch with spring return closing contact ON-OFF, supplied with
2 keys (10 pcs)
Flat key blank for 99 (10 pcs)
Flat key blank for 52-J
8044
8049
ALARM
WARNING
DEVICES
Multifunction phone dialers with voice synthesis on PSTN and GSM networks
Telephone Dialer with Synthesized Voice for PSTN network
Outdoor self-powered electronic sirens
Indoor sirens and speakers
Strobe warning lights
ALARM WARNING DEVICES
94
Multifunction phone dialers with voice synthesis on PSTN
and GSM networks
INFORMA 600 Series
INFORMA 600E
4 channels, 24 telephone
numbers, only PSTN
INFORMA 600GSM
4 channels, 24 telephone
numbers, PSTN+GSM
INFORMA 600GSMVV
4 channels,
24 telephone numbers,
2-Way Voice Communication,
PSTN+GSM
DESCRIPTION
INFORMA 600 is a new multifunction phone
communication system
designed to provide a wide
range of services in one
single compact equipment, at
a really competitive price.
Firstly, INFORMA 600 can send
pre-recorded alarm messages
on a normal switched phone
line (PSTN) or on the GSM
network. The messages and
telephone data are stored in
the non-volatile memory,
which guarantees that no
information is lost, even in
GENERAL FEATURES
• Calling up to 24 phone
numbers, of 20 digits each.
These numbers are
independently assigned to
each of the 4 channels
• Messages can be repeated
up to 9 times
• LCD display with 16
alphanumeric characters of
telephone numbers and
stored functions
• Long-distance
interrogations about the
www.hesa.com
case of electric cut-off.
INFORMA 600 has 4 channels
which can record up to 24
phone numbers. These
numbers can be freely
divided among the channels
at any proportion whatsoever.
All the calls are stored, to
enable the recognition of the
emergency time (date, hour
and minute), and the
successful calls as well.
The control keypad and
display make it possible to
program and view the call
logger (up to 64 events).
Secondly, INFORMA 600 can
be remote-interrogated from
any telephone set. This way it
is possible to know the status
of the inputs, the system, and
battery, and receive clear
voice answers. It is possible
to jump answering machines
or faxes, by re-contacting
INFORMA 600 within 30
seconds from the first call.
Thirdly, INFORMA 600 can
carry out 2 remote controlled
functions on logic outputs,
and obtain a voice answer for
the executed operation.
INFORMA 600 is also equipped
with weekly programming
scheduler to process up to 6
different programs (ex.
switching the water heater on,
inserting the alarm system).
Lastly, the following versions
are available: PSTN+GSM
(INFORMA 600GSM) and
PSTN+GSM with two-way
voice (INFORMA 600GSMVV),
communication which
combine very special
functions.
system status (with
answering machine or fax
jump function)
• Storage of the last 64
events with date, time,
enabled inputs, and phone
numbers which have
answered the call
• Simple and quick keypad
programming through
guided menu, or local PC
software programming
• Failure output caused by
telephone line cut-off, low
battery and failed calls
• Local activation by means
of a keypad with 2 logic
outputs
• Long-distance
interrogations with voice
answer about the status of
the system, occurred
alarms, channel, and time
indication
• Direct recording with
immediate hearing of the 7
messages (maximum
duration 15 seconds each)
divided into 4 alarm
messages and 3 failure
messages
• Alarm cancellation input
• Programmable call delay
from 1 to 240 seconds
• Power voltage control
95
Multifunction phone dialers with voice synthesis on PSTN
and GSM networks
INFORMA 600 Series
INFORMA 600GSM
4 channels, 24 telephone
numbers, PSTN+GSM
DESCRIPTION
Through the programming
mode of the INFORMA 600GSM
version it is possible to
choose the preferential PSTN
or GSM telephone line for
each number. After a failed
call on the PSTN line, it is
possible to call through the
GSM network. It allows the
forwarding of 8 SMS text
messages, and the checking
of the remaining credit and
the expiry date of the GSM
SIM card.
This version has also the
free-of-charge GSM remotecontrol function (CLIP
function) which allows the
outputs activation,
recognising thus the caller’s
number.
FEATURES
• The dialer uses the GSM
network for calling, after a
failed call attempt on the
PSTN line
• Failure output for GSM
network non-coverage.
• Forwarding of 8 SMS text
messages, of 100
characters maximum. The
first 4 messages regard the
4 alarm inputs and the
other 4 regard warning of
problems related to power
supply, telephone line
failure, low remaining
credit and SIM expiry
• Checking the remaining
credit in the GSM SIM card
(in case of using a prepaid card)
• Expiry date of the GSM SIM
card (in case of using a
pre-paid card)
• Remote programming by
sending SMS text messages
from a PC with remotecontrolling software and
SMS modem
• PC local firmware update
DESCRIPTION
Apart from being a GSM
telephone dialer used to
send SMS and voice
messages, the
INFORMA 600GSMVV version
can also be used as a real
mobile phone to forward and
receive hands-free calls.
In fact, the hands-free and/or
two-way voice system can
enable the help-for-theelderly and the anti-robbery
functions, operated by private
persons, as well as the longdistance interception and/or
hands-free functions on
mobile phone networks,
allowing thus to hear sounds
from protected areas and
speak through the in-built
microphone and loudspeakers for 5 minutes.
INFORMA 600GSM-AE
4 channels, 24 telephone
numbers, PSTN+GSM,
external aerial
INFORMA 600GSMVV
4 channels,
24 telephone numbers,
2-Way Voice Communication,
PSTN+GSM
www.hesa.com
FEATURES
• Possibility to select the
preferential PSTN or GSM
line and hands-free
functions for each
telephone number
• In-built hands-free function
to speak, and to hear
sounds and voice from
remote places
ALARM WARNING DEVICES
96
Multifunction phone dialers with voice synthesis on PSTN
and GSM networks
INFORMA 600 Series
SPECIFICATIONS
Model
Power supply
Power consumption
standby
maximum
Alarm Inputs
Outputs
20 called digit phone numbers
Total recordable messages
SMS text messages
Programming
Display
Keypad
Auto-protection
Telephone remote interrogation
Events memory
Two-way voice feature
Online period
GSM fatures
GSM module
Hands-free telephone function
Local firmware update
Operating temperature
Weight g
INFORMA 600E
INFORMA 600GSM /600GSM-AE
11.5~13.8 VDC
160 mA
200 mA
INFORMA 600GSMVV
200 mA
700 mA
with 2A peak
7, N.C., N.A. and N.U.
5 logic outputs
24
7 messages of a maximum duration of 15 sec.
NO
8 of maximum 100 characters
Keypad and local software
Keypad, and local and remote software
2-line 16-character LCD
16 alphanumeric keys
Anti-opening and anti-removal
YES, by means of a voice menu
64 events with time and date
NO
YES
n. a.
5 minutes
NO
Free of charge CLIP function
Remaining credit and SIM expiry control
NO
Dual Band 900/1800MHz
NO
YES
YES
+5°C ~ +40°C
579
587
590
DIMENSIONS (mm)
225
280
150
45
INFORMA 600E /
INFORMA 600GSM /
INFORMA 600GSMVV
INFORMA 600GSM-AE
CODE
MODEL
DESCRIPTION
HEINF6E
HEINF6G
HEINF6G
HEINF6V
INFORMA 600E
INFORMA 600GSM
INFORMA 600GSM-AE
INFORMA 600GSMVV
Telephone dialer with voice synthesis on remote-controlled switched phone network
Telephone dialer with PSTN+GSM remote-controlled voice synthesis
Telephone dialer with PSTN+GSM remote-controlled voice synthesis, external aerial
Telephone dialer with PSTN+GSM remote-controlled voice synthesis, and two-way voice function
HEINF6SW
SWINF600
HEANT-A
CVRG174-3
CVRG174-5
CVRG174-10
HEINF6MD
HEINF6BT
ANT-A
RG174-3
RG174-5
RG174-10
MODINF600
BATINF600
Programming and remote-control software for INFORMA 600 dialer.
Local connection cable included
High-gain antenna for INFORMA 600GSM-AE
3m Antenna Extension Cable for INFORMA 600GSM-AE
5m Antenna Extension Cable for INFORMA 600GSM-AE
10m Antenna Extension Cable for INFORMA 600GSM-AE
Remote programming modem for INFORMA 600GSM and INFORMA 600GSMVV dialer
Optional battery for INFORMA 600 dialer
150
45
Accessories
www.hesa.com
97
Outdoor self-powered electronic sirens
SCUDO-1500 and SCUDO-SFB
SCUDO-1500BF/GF
Self-powered electronic siren.
Filament bulb flasher. Alarm
auto-out off time, 4 different
alarm tones. Colours: white
(BF) or gray (GF)
FEATURES
• Double wire or
supervised lines
connection (2-wires or 4wires operating modes)
• SMD fully scaled pc
board
• Alarm memory indication
on siren’s lamp, resettable from control panel
• Optionl form and drilling
detection boards
• High-resistance ABS
housing
• Inner steel cover
• Private labelling service
SCUDO-SFB
Supervised Wireless siren.
High power LED flasher with
system status indication. Fault
indication and 2 different
alarm tones.
DESCRIPTION
Smart design, reliability and
hi-tech performance make the
SCUDO sirens the ideal complement for any security
alarm system.
Their tough outer casing in
ABS (polycarbonate also
available) and inner steel
cover offers total protection
from rust and weathering, as
in saline or corrosive environments.
4 different alarm tones, alarm
memory indication, bright
light from the two filament
bulbs or xenon lamp are only
some of the features which
make this siren truly versatile.
FEATURES
• Built-in bidirectional
transceiver for low battery
indication, supervision
failure, wireless jamming
indication
• Needs SCUDO-SFB-MB
wireless module to be
installed in control panel
for siren’s triggering
• Sound pressure level
114dB @ 1m
2nd level certification
3rd level certification
(with HEK31BL)
SCUDO-1500BS/GS
Self-powered electronic siren.
High brightness Xenon lamp.
Alarm auto-out off time, 4 different alarm tones. Colours:
white (BS) or gray (GS)
2nd level certification
3rd level certification
(with HEK31BL)
EXAMPLES OF PRIVATE LABELLING
www.hesa.com
Perfectly fit for supervised
lines, it detects tamper
attempts by foam and
drilling.
By means of an optional antidrilling board it is possible to
monitor low battery and lamp
failures.
ALARM WARNING DEVICES
98
Outdoor self-powered electronic sirens
SCUDO-1500 and SCUDO-SFB
SPECIFICATIONS
Model
Power supply
SCUDO-1500BF
SCUDO-1500GF
SCUDO-1500BS
SCUDO-1500GS
SCUDO-SFB
Internal sealed
lead-acid battery
90µa
900mA
Wireless
(SCUDO-SFB-MB)
30 sec
2, selectable
114dB @ 1 m
LED
13.8VDC (13.6~14.4 VDC)
Power consumation: stand-by
maximum
Wiring connection
15mA
300mA
Double wire or 4 supervised lines
Alarm auto-stop time
Alarm tones
Sound pressure level
Flasher
Flashing frequency
4 or 8 min, selectable
4, selectable
(max) 109 dB @ 3 m
Filament bulb
IP Rating
Operating temperature
Internal battery
Xenon lamp
60 flashes/min,
8 flashes/min, as alarm memory
IP34
–25°C ~ +55°C
50 flashes/min
–
Li-Ion Battery
7.2V 13Ah
White
2700
YES
NO
12VDC 2Ah
Color
Weight g
2nd level IMQ Certification
3rd level with foam
and drilling detection
White
Grey
White
Grey
DIMENSIONS (mm)
300
220
120
SCUDO-1500 / SCUDO-SFB
CODE
MODEL
DESCRIPTION
HE31-BF
HE31-GF
HE31-BS
HE31-GS
HE30-RB
HE30-MB
SCUDO-1500BF
SCUDO-1500GF
SCUDO-1500BS
SCUDO-1500GS
SCUDO-SFB
SCUDO-SFB-MB
Self-powered electronic siren, filament bulb flasher, white colour
Self-powered electronic siren, filament bulb flasher, gray colour
Self-powered electronic siren, Xenon flasher, white colour
Self-powered electronic siren, Xenon flasher, gray colour
Supervised wireless siren
Bidirectional wireless module for siren’s triggering
SCUDO-K31BL
SCUDO-K31AS
K3000AD
K31TS
Accessories
HEK31BL
HEK31AS
HEK30AD
HEK31TS
HE30-TC
www.hesa.com
SCUDO-K31BL
SCUDO-K31AS
K3000AD
K31TS
SCUDO-SFB-TC
Anti-drilling kit for SCUDO-1500
Anti-foam kit SCUDO-1500
Metal plate reinforced SCUDO-1500
Connecting cable for anti-drilling and anti-foam kits
Bidirectional wireless 4-channel keyfob for SCUDO-SFB siren
SCUDO-SFB-TC
99
Outdoor self-powered electronic sirens
SAE16SF
SAE16SF
Solar powered
wireless outdoor
siren with strobe
DESCRIPTION
The SAE16SF package
includes a solar wireless
siren with strobe and an
associated siren transmitter
module which are compatible
with any standard wireless or
hard wired alarm system.
The siren, strobe light and
solar panel are all
encapsuled within a tough
polycarbonate housing. This
housing provides full
protection against adverse
weather conditions.
FEATURES
• Xenon Strobe light
• Solar panel charges
internal 6V, 12Ah sealed
lead-acid battery
• Supplied with transmitter
module to be installed in
control panel
SPECIFICATIONS
Model
Power supply
Current drain: Stand-by
Sounder
Xenon light
Time out
Sound pressure level
Housing
Protection
Wireless receiver and antenna
Wireless range
Weight g
• Dual front and rear antitamper
• Anti-foam detection
• Piezo sounder power: 98dB
• Polycarbonate housing
DIMENSIONS (mm)
SAE16SF
Solar panel 7.5V charge rate: 60mA
typically
850 µA (typically)
150mA
125mA (1 Watt)
3 or 15 min, selectable
98 dB @ 3 m
Polycarbonate, 3 mm thick
Tamper, foam detection
433MHz built-in
100 meters in open space
2000
CODE
MODEL
DESCRIPTION
HE16SSF
SAE16SF
Outdoor Solar Wireless Self-powered electronic siren with flasher
www.hesa.com
All electronic components are
specially treated to ensure
long, reliable, trouble free
operation and an integral
tamper switch which gives
maximum protection to the
unit. The solar panel mounted
on the housing will maintain
a charge to the rechargeable
battery during daylight hours.
During darkness, a negligible
amount of energy is released
by the rechargeable battery to
operate the siren.
246
300
SAE16SF
100
ALARM WARNING DEVICES
100
Indoor sirens and speakers
SELP-12P
Piezo siren, 12VDC 200mA
SELP-12L
Two-tone electronic siren,
12VDC 290mA
SELP-12N
Two-tone electronic siren,
12VDC 720mA
FEATURES
• 3 different alarm tones
(SELP-12P)
• 2 Modulated sounds
(SELP-12L & SELP-12N)
• White ABS housing
• Surface mounting
DESCRIPTION
The Indoor Electronic Sirens
have to match the interior
decoration to satisfy the most
demanding customers, but at
the same time they also have
to offer the highest
performance and reliability to
meet maximum efficiency.
APC-12P
8 ⏲ speaker
APC-16P
16 ⏲ speaker
SELC-12L
Two-tone electronic siren,
12VDC 290mA
SELC-12N
Two-tone electronic siren,
12VDC 950mA
FEATURES
• Modulated sounds
(SELC-12L e SELC-12N)
• Steel housing with double
cover protection with
tamper
• Surface mounting
APC-12
8 ⏲ speaker
APC-16
16 ⏲ speaker
SELC-12L-INC
Two-tone electronic siren,
12VDC 290mA
SELC-12N-INC
Two-tone electronic siren,
12VDC 950mA
APC-12-INC
8 ⏲ speaker
APC-16-INC
16 ⏲ speaker
S100-12
Speaker 12VDC, 85mA, 105dB
S110-12
Maxi-speaker 12VDC, 300mA,
115dB, 3 different alarm
tones
www.hesa.com
FEATURES
• 2 Modulated sounds
(SELC-12L-INC
e SELC-12N-INC)
• Steel housing with double
cover protection
with tamper
• Recessed mounting
1st level
101
Indoor sirens and speakers
SPECIFICATIONS
Model
Power supply
Power consumption
Sound pressure level
Sound frequency:
Speaker's impedance
Housing
Operating temperature
Weight g
1st level IMQ Certification
SELP-12P
200mA
Continuous: 94dB @ m 3
Bitonal: 98dB @ m 3
Continuous: 2870Hz
Bitonal: 2870Hz & 2700Hz
–
ABS
350
NO
SELP-12L SELC-12L SELP-12N SELC-12N APC-12P APC-12 APC-16P APC-16
12VDC (11~14VDC)
Modulated
Modulated
290mA
950mA
–
–
90dB @ 3 m
95dB @ 3 m
2400Hz
61
ABS
Steel
NO
YES
–
–
–
–
81
ABS
Steel
ABS
+5°C ~ +40°C
700
NO
16 1
Steel
ABS
700
NO
YES
Steel
600
NO
DIMENSIONS (mm)
106
105
140
175
53
32
150
92
99
SELP-12P / SELP-12L /
SELP-12N / APC-12P
CODE
MODEL
HE12P-P
HE12P-L
HE12P-N
HE12-L
HE12-N
HE12L/I
HE12N/I
SELP-12P
SELP-12L
SELP-12N
SELC-12L
SELC-12N
SELC-12L-INC
SELC-12N-INC
HEAPP12
HEAPC12
HEAPP16
HEAPC16
HEA12-I
HEA16-I
APC-12P
APC-12
APC-16P
APC-16
APC-12-INC
APC-16-INC
LD100-1
LD110-1
S100-12
S110-12
www.hesa.com
SELC-12L / SELC-12N /
APC-12 / APC-16
54
120
75
SELC-12L-INC / SELC-12N-INC /
APC-12-INC / APC-16-INC
DESCRIPTION
Sirens
Piezoelectric siren, 3 different alarm tones, 12VDC, 200 mA
Two-tone electronic siren, ABS housing, 12VDC, 290 mA
Two-tone electronic siren, ABS housing, 12VDC, 950 mA
Two-tone electronic siren, steel housing, 12VDC, 290 mA
Two-tone electronic siren, steel housing, 12VDC, 950 mA
Two-tone electronic siren, flush mount version, 12VDC, 290 mA
Two-tone electronic siren, flush mount version, 12VDC, 950 mA
Speakers
8 ⏲ speaker, ABS housing
8 ⏲ speaker, steel housing
16 ⏲ speaker, ABS housing
16 ⏲ speaker, steel housing
8 ⏲ speaker, flush mount version
16 ⏲ speaker, flush mount version
Piezoelectric Speakers
Piezoelectric speaker, 12VDC
Piezoelectric speaker, 3 different alarm tones, 12VDC
92
S100-12 / S110-12
32
ALARM WARNING DEVICES
102
Strobe Warning Lights
LL-12R
Red Strobe Light, 12VDC
LL-24R
Red Strobe Light, 24VDC
LL-12A
Amber Strobe Light, 12VDC
LL-24A
Amber Strobe Light, 24VDC
DESCRIPTION
HESA Strobe Lights should be
used wherever continuous
high intensity flashes are
needed to call attention to an
alarm condition.
The flash rate of 38-72
flashes per minute is the
most suitable to draw
people’s attention.
The weather resistant
housing includes a high
impact lens able to withstand
vandalism.
They are ideal to outdoor
installations in shopping
malls, industrial complexes
and housing developments.
FEATURES
• High intensity flashes for
fast premises identification
• Excellent visibility and
widest angle coverage
• Surface mounted or
mounted on alarm siren
housing
• Weather resistant housing
for outdoor use
SPECIFICATIONS
Model
Power supply
Power consumption
Flash rate
Operating life
Operating temperature
Housing
LL-12R
LL-12A
12VDC (10~14.5VDC)
140mA (typically)
38-72 times/min at 12VDC
102
80
LL-12R / LL-24R
LL-12A / LL-24A
CODE
MODEL
DESCRIPTION
HESL-1R
HESL-2R
HESL-1A
HESL-2A
LL-12R
LL-24R
LL-12A
LL-24A
Red Strobe Light, 12VDC
Red Strobe Light, 24VDC
Amber Strobe Light, 12VDC
Amber Strobe Light, 24VDC
www.hesa.com
LL-24A
24VDC (20~29VDC)
85mA (typically)
38-72 times/min at 24VDC
>250 hours
–10°C ~ +50°C
Black ABS base, methacrylate lens
DIMENSIONS (mm)
100
LL-24R
103
www.hesa.com
POWER SUPPLIES
ACCESSORIES
Power Supplies
AC/DC Adapters
Battery Chargers for lead acid batteries
Power packs
Metal Housings
Accessories
POWER SUPPLIES - ACCESSORIES
106
Power Supplies
Single Output Switching Power Supplies
ALS12-1.1A
12VDC 1.3A 15W
FEATURES
• Protections: Short circuit /
Overload / Over voltage /
Over temperature
• LED indicator for power on
• Compliace to UL60950-1,
TUV EN60950-1
• Withstand 5G vibration test
• High efficiency, long life and
high reliability
ALS12-3A
12VDC 3.5A 35W
ALS12-6A
12VDC 6.4A 75W
ALS24-3A
24VDC 3.2A 75W
ALS12-12A
12VDC 12.5A 150W
SPECIFICATIONS
Model
Input voltage
Output voltage
Max load current @13.8VDC
Max output power
Switch frequency
Operation temperature
Efficiency
Ripple & Noise
Dimension
Weight g
ALS12-1.1A
1.08A
15W
63x51x28
130
ALS12-3A
ALS12-6A
88 ~ 264VAC
10.8 ~ 13.8VDC
2.5A
5.4A
35W
75W
47 ~ 63Hz
–25°C ~ +70°C
81%
120mV p-p
99x82x36
129x97x38
300
410
CODE
MODEL
DESCRIPTION
MYW1211
MYW1225
MYW1250
MYW2425
MYW12100
ALS12-1.1A
ALS12-3A
ALS12-6A
ALS24-3A
ALS12-12A
Single Output Switching Power Supply 12VDC 1.3A 15W
Single Output Switching Power Supply 12VDC 3A 35W
Single Output Switching Power Supply 12VDC 6A 75W
Single Output Switching Power Supply 24VDC 3A 75W
Single Output Switching Power Supply 12VDC 12A 150W
www.hesa.com
ALS12-12A
ALS24-3A
10.8A
150W
22 ~ 27.8VDC
2.7A
75W
83%
85%
199x98x38
700
129x97x38
410
107
Power Supplies
Linear, Buffer Power Supply Units
AL-12-1
Linear power supply 12V/DC
1A enclosed in a metal, flush
mounted casing with space
for the battery 1.2Ah
AL-12-2
Linear power supply 12V/DC
2A enclosed in a metal, flush
mounted casing with space
for the battery 7Ah
FEATURES
• Protections: SCP, OLP, OHP,
microswitch signaling opening the door
FEATURES
• Protections: SCP, OLP, OHP,
microswitch signaling opening the door
AL-12-5
Linear power supply 12V/DC
5A enclosed in a metal, flush
mounted casing with space
for the battery 40Ah
AL-12-3
Linear power supply 12V/DC
3A enclosed in a metal, flush
mounted casing with space
for the battery 17Ah
FEATURES
• Protections: SCP, OLP, OVP,
UVP, microswitch signaling
opening the door and
ripping off from a wall
FEATURES
• Protections: SCP, OLP, OHP,
UVP, microswitch signaling
opening the door
• Equipped with dynamic
battery test, also with
optical and acoustic
signaling informing about
operation status
SPECIFICATIONS
Model
Power supply
AL-12-1
AL-12-2
AL-12-3
AL-12-5
230V/AC
Output voltage
Output current
Space for battery
Dimensions (WxHxD) mm
Weight g
12.8V÷13.8V (buffer op.)
12.8V÷13.8V (buffer op.)
12.8V÷13.8V (buffer op.)
13.3V@1A, Vpp<30mV max. 13.4V@2A, Vpp<30mV max. 13.4V@3A, Vpp<30mV max.
1A max
1.2Ah/12V lead-acid
dry (SLA)
175x185x88
1600
2A max.
7Ah/12V lead-acid
dry (SLA)
205x235x88
2500
3A max.
17Ah/12V lead-acid
dry (SLA)
235x305x98
3600
11V÷13.8Vdc (buffer op.)
10V-13.8Vdc - battery,
Vpp< 250mV
2x 2.5A or 5A
40Ah/12V lead-acid
dry (SLA)
350x425x180
9700
CODE
MODEL
DESCRIPTION
HEAL121
HEAL122
HEAL123
HEAL125
AL-12-1
AL-12-2
AL-12-3
AL-12-5
Linear power supply 12V/DC 1A enclosed in a metal, flush mounted casing with space for the battery 1.2Ah
Linear power supply 12V/DC 2A enclosed in a metal, flush mounted casing with space for the battery 7Ah
Linear power supply 12V/DC 3A enclosed in a metal, flush mounted casing with space for the battery 17Ah
Linear power supply 12V/DC 5A enclosed in a metal, flush mounted casing with space for the battery 40Ah
www.hesa.com
POWER SUPPLIES - ACCESSORIES
108
Power Supplies
Constant voltage power supply
CAR12-1.5S
12Vc.c. 1.5A
CARP12/0.5
12Vc.c. 550mA
SPECIFICATIONS
Model
Power supply
Output voltage
Output current
Weight g
CARP12/0.5
13.4~14.4VDC adjustable
550mA
700
DIMENSIONS (mm)
145
140
150
68
55
105
CARP12/0.5
CAR12-1.5S
CODE
MODEL
DESCRIPTION
HEP1205
HE12/15
CARP12/0.5
CAR12-1.5S
Constant voltage power supply 12VDC 550mA
Constant voltage power supply 12VDC 1.5A
www.hesa.com
CAR12-1.5S
230Vc.a.
13~15VDC adjustable
1.5A
2200
109
AC/AC Adapters
TF15/16
230/16VAC 15VA
DESCRIPTION
AC/AC adapters trasform the
mains voltage to a lower AC
voltage
DIMENSIONS (mm)
85
FEATURES
• Thermal fuse or PTC
breaker protection
48
53
TF15/16
TF30/16
230/16VAC 30VA
117
56
75
TF30/16
TF40/16
230/16VAC 40VA
90
60
76
TF40/16
TF60/16
230/16VAC 60VA
100
65
65
TF60/16
SPECIFICATIONS
Model
Input voltage
Output voltage
Max load current
Housing
Input & Output
Thermal fuse with fuse holder
TF15/16
TF40/16
TF60/16
40VA
metal bracket
terminal block
YES
60VA
Class II isolating
wire with plug
NO
230VAC
16VAC
15VA
Class II isolating
terminal block
NO
CODE
MODEL
DESCRIPTION
TFMED-4
VM30/16
TFP40VA
TF60/16
TF15/16
TF30/16
TF40/16
TF60/16
AC/AC Adapter 230/16VAC 15VA
AC/AC Adapter 230/16VAC 30VA
AC/AC Adapter 230/16VAC 40VA
AC/AC Adapter 230/16VAC 60VA
www.hesa.com
TF30/16
30VA
wire
NO
POWER SUPPLIES - ACCESSORIES
110
Battery Chargers for lead acid batteries
CAR12-3S-2.7A
12VDC 2.7A
CAR12-3S-4A
12VDC 4A
CAR12-3S-10A
12VDC 10A
CAR12-3S-20A
12VDC 20A
DESCRIPTION
HESA’s 3-step chargers work
in three different modes. An
LED-indicator with three
different colors shows the
charger mode. Unlike the so
called taper chargers, these
models charge with a
constant current in the first
mode. When the battery
voltage rises to the maximum
cycle voltage during
charging, the chargers do not
immediately change to
standby mode.
Instead, a timer starts and
the charger remains in
constant voltage mode until
the timer period has elapsed.
When the timer starts, the
battery is already charged to
80 - 90% of full capacity and
can be used at this point if
desired.
www.hesa.com
The time boost period
ensures, however, that the
battery will receive the
remaining 10 to 20%
capacity in a very short time
compared to chargers not
having this feature.
The LED-indicator changes to
yellow when the timer starts,
and changes again to green
when the timer period is out.
At this point the constant
voltage level is reduced to a
safe value where the battery
can be left for an unlimited
time without risk of
overcharge.
This is the float charge or
standby mode.
FEATURES
• Compact high-quality
chargers
• 3-step charge control for
safe, fast charging and
stand-by charge
• LED - indicator with three
different colours shows the
charge status
• Built-in timer for
prolongued boost “absorption charge”
• Charge current not affected
by fluctuations in mains
voltage
• Leads with battery clips
• Low leakage current from
battery when mains
disconnected
• Protected against reversed
polarity and short circuit
proof
• Automatic start of new
charging cycle when
battery voltage falls due to
loading
111
Battery Chargers for lead acid batteries
SPECIFICATIONS
Model
Imput voltage
Charge voltage
CAR12-3S-2.7A
CAR12-3S-4A
14.7V (timer)
13.8V (float)
Max output power
40W
60W
Current limit (max.)
2.7A
4A
Switch frequency
45 kHz
40 kHz
Input surge current limitation
–
–
Leakage current with mains disconnected
<100µA
<200µA
Protection
Against reversed polarity
Operating temperature
-10°C÷+40°C
Ripple
<20mVp-p 40kHz e 100Hz
Temperature compensation
NO
Efficiency (at full load)
Insulation class
Indication:
- Red (constant current, boost)
- Yellow (constant voltage, timer)
- Green (constant voltage, float)
Timer
Weight
NO
>81%
II
2.7A
14.7V
13.8V
CAR12-3S-10A
CAR12-3S-20A
190-264VAC
14.7V (timer)
13.7V (float)
147W
295W
10A
20A
63 kHz
67 kHz
<30A
<35A
<2.5mA
0.5mA
Against reversed polarity and short circuit
25°C÷+40°C
<100mVp-p
Yes,
NO
with external heat sensor
>83%
I
4A
14.7V
13.8V
10A
14.7V
13.7V
g 350
g 980
2 h ± 30 min.
g 250
20A
14.7V
13.7V
4 h ± 30 min.
g 1550
DIMENSIONS (mm)
135
100
51
63
192
80
210
44
109
CAR12-3S-2.7A
CAR12-3S-4A
CODE
MODEL
DESCRIPTION
9640
2040H
2047
2044
CAR12-3S-2.7A
CAR12-3S-4A
CAR12-3S-10A
CAR12-3S-20A
Battery charger 12V, 2.7A
Battery charger 12V, 4A
Battery charger 12V, 10A
Battery charger 12V, 20A
www.hesa.com
CAR12-3S-10A
54
148
CAR12-3S-20A
58
POWER SUPPLIES - ACCESSORIES
112
Metal Housings
DESCRIPTION
Wall mounting metal
housings for optional
modules, power supplies,
batteries
C-1.0
Metal housing, white colour
HE-BOX2S
Metal housing, white colour
HE-BOX4
Metal housing, white colour
NX-002
Metal housing, gray colour
NX-003
Metal housing, with cam lock,
gray colour
NX-003C
Metal housing, with cam lock,
gray colour
SPECIFICATIONS
Model
Housing with door
Cam lock
Dimensions (WxHxD) mm
Weight (Kg)
C-1.0
YES
YES
270x270x65
–
HE-BOX2S
YES
NO
285x295x80
–
HE-BOX4
YES
NO
330x400x100
–
CODE
MODEL
DESCRIPTION
HZC1.0
HEBOX2S
HEBOX4
NX002
NX003
NX003C
C-1.0
HE-BOX2S
HE-BOX4
NX-002
NX-003
NX-003C
Metal housing with door and cam lock
Metal housing with door
Metal housing with door closing with screws and tamper
Metal housing with door
Metal housing with door and cam lock
Metal housing with door and cam lock
OL12
600-CL
Universal cam lock
Cam lock with 2 keys for NX-002, NX-003, NX-003C
Accessories
OL12
NXA600
www.hesa.com
NX-002
YES
YES
235x210x90
1.2
NX-003
YES
YES
230X230X90
2.02
OL12
NX-003C
YES
YES
390X470X115
7.1
600-CL
113
Accessories
Tamper switches
TSW2
Tamper switch for NX-002/003
CHERRY
Universal tamper switch
TP-12
Metal bracket for Cherry tamper switch
NX-005
Tamper switch with anti-removal metal bracket for NX-002/003
NX-005-C
Tamper switch with anti-removal metal bracket for NX-003C
CODE
MODEL
DESCRIPTION
KBTSW-1
SO7053
HETP-12
NX005
NX005C
TSW2
CHERRY
TP-12
NX-005
NX-005-C
Tamper switch for NX-002/003
Universal tamper switch
Metal bracket for Cherry tamper switch
Tamper switch with anti-removal metal bracket for NX-002/003
Tamper switch with anti-removal metal bracket for NX-003C
www.hesa.com
BATTERIES
CABLES
ECOPOWER Sealed Lead-Acid Batteries
FIAMM-GS Sealed Lead-Acid Batteries
ENERSYS Cyclon High performance Pure Lead Batteries
ENERSYS Genesis High performance Pure Lead Batteries
NORTHSTAR High performance Pure Lead Batteries
Alarm Cables
BATTERIES-CABLES
116
ECOPOWER Sealed Lead-Acid Batteries
Series HH
GP3.8-6
6V 3.8Ah
GP65-12
12V 7.0Ah
GP5-6
6V 5.0Ah
GP12-12
12V 12.0Ah
GP12-6
6V 12.0Ah
GP1.2-12
12V 1.3Ah
GP2.1-12
12V 2.2Ah
DESCRIPTION
ECOPOWER batteries adopt
fashionable design, modem
manufacturing process,
advanced lead-calcium
electrode plate, super-fine
glass fiber separators and
airproof design. With the
adoption of advanced
international technologies,
these batteries have the
FEATURES
• Leak-resistant structure
• Long service life (3-5 years)
• Easy maintenance
• No sulfuric acid midst or
gases
• Exceptional deep discharge
recovery
www.hesa.com
advantages of high energy,
long lifespan, zero pollution,
maintenances-free, safe and
reliable performance, and have
exploited the new realm of the
application of storage
batteries
GP15-12
12V 18.0Ah
GP26-12
12V 26.0Ah
GP42-12
12V 40.0Ah
DESCRIPTION
Wide range of 6V and 12V
high-performance sealed
maintenance free lead acid
batteries
APPLICATIONS
• Stand-by/Back-up power
applications
• Communication equipment
• Back-up for power failure
• Emergency equipment
• Alarm systems for Security
and Fire protection
• Main power applications
• Communication and
telephone equipment
• Tools and engine starters
• Industrial
equipment/instruments
and life-critical medical
equipment, measuring
equipment
117
ECOPOWER Sealed Lead-Acid Batteries
Series HH
SPECIFICATIONS
Model
GP3.8-6
Constant voltage charge
Cyclic applications:
max initial charging current
Stand-by applications:
max initial charging current
Nominal Voltage
Nominal Capacity (Ah)
3.8
Internal resistance m1 (@25°C)
–
Terminal type
type 1
Weight g
750
GP5-6
GP12-6
GP1.2-12 GP2.1-12 GP65-12
GP12-12
GP15-12
GP26-12
GP42-12
12V
12.0
20
type 1
4.000
18.0
15
type 2
6.200
26.0
10
type 2
9.100
40.0
8
type 3
14.000
2.42 – 2.48 vpc*
0.3C**
2.27 – 2.30 vpc*
0.15C**
6V
5.0
22
type 1
862
12.0
10
type 1
1.760
1.3
110
type 1
580
2.2
90
type 1
950
7.0
10
type 1
2.700
* vpc = volt per cell
** C = capacity, A
TERMINAL TYPE (mm)
4.8
3.2
6.35
12
Type 1
5
7.5
5
0.8
15
2
5.5
12
Type 2
5.5
18
Type 3
DIMENSIONS (mm)
70
97
47
151
43
178
107
58
GP1.2-12
65
100
GP65-12
98
GP2.1-12
181
76
166
175
167
101
GP12-12
65
GP12-6
151
35
99
GP5-6
151
50
GP15-12
125
GP24-12
197
165
172
CODE
MODEL
DESCRIPTION
II003
HH5-6
HH12-6
HH12-12
HH19-12
HH65-12
HH12012
HH15-12
HH24-12
HH42-12
GP3.8-6
GP5-6
GP12-6
GP1.2-12
GP2.1-12
GP65-12
GP12-12
GP15-12
GP24-12
GP42-12
6V 3.08Ah battery
6V 5.0Ah battery
6V 12.0Ah battery
12V 1.3Ah battery
12V 2.2Ah battery
12V 7.0Ah battery
12V 12.0Ah battery
12V 18.0Ah battery
12V 26.0Ah battery
12V 40.0Ah battery
www.hesa.com
GP42-12
124
GP3.8-6
65
33
BATTERIES-CABLES
118
FIAMM-GS Sealed Lead-Acid Batteries
FG20121
12V 1.2Ah
FG21803
12V 18.0Ah
FG20201
12V 2.1Ah
FG22703
12V 27.0Ah
FG20721
12V 7.2Ah
FG21202
12V 12.0Ah
DESCRIPTION
All FIAMM-GS batteries have
been specifically developed to
enhance economy of
operation, reliability and
energy output. The values
reached in these areas
position FIAMM-GS batteries
among the very best presently
available on the market.
They represent the ideal
solution for all applications.
APPLICATIONS
Stand-by use
• UPS systems
• Alarm systems and security
equipment
• Telephone and telecom
equipment
• Emergency lighting
• Fire and gas detection
devices
www.hesa.com
FEATURES
• Total absence of
maintenance
• Low self-discharge (long
shelf life)
• Sealed construction
• Economy of operation
• High energy density
• Wide ranging operating
temperature
• Deep discharge recovery
Cycle use
• Portable measuring
instruments and registers
• Electro-medical equipment
• Portable videocameras and
televisions
• Power tools
• Models and toys
FG24204
12V 42.0Ah
FG27004
12V 70.0Ah
119
FIAMM-GS Sealed Lead-Acid Batteries
SPECIFICATIONS
Model
Constant voltage charge
Cyclic applications
max initial charging current
Stand-by applications
max initial charging current
Nominal VoltageV
Nominal Capacity (Ah***)
Terminal type
Weight g
FG20121
FG20201
1.2
FG20721
2.0
7.2
FG21202
FG21803
930
FG24204
FG27004
27.0
42.0
70.0
2.42 – 2.48 vpc*
0.3C**
2.27 – 2.30 vpc*
0.15C**
12V
12.0
18.0
type 1
600
FG22703
type 2
2.450
3.750
5.900
type 3
8.500
14.000
22.600
* vpc = volt per cell
** C = capacity, A
TERMINAL TYPE (mm)
0.8
12
6.5
4.8
FASTON
5
7.5
5
12
Type 1
15
2
5.5
18
5.5
Type 3
Type 2
DIMENSIONS (mm)
50.5
174
350
166
FG27004
48.5
97
98
FG21803
CODE
MODEL
DESCRIPTION
HE12-12
HE19-12
HE65-12
HE12012
HE15-12
HE24-12
HE42-12
HE70-12
FG20121
FG20201
FG20721
FG21202
FG21803
FG22703
FG24204
FG27004
12V 1.2Ah, battery
12V 2.0Ah, battery
12V 7.2Ah, battery
12V 12.0Ah, battery
12V 18.0Ah, battery
12V 27.0Ah, battery
12V 42.0Ah, battery
12V 70.0Ah, battery
www.hesa.com
163
FG22703
151
FG20721
174
125
181
76
FG21202
65
FG20201
167
151
178
34
FG20121
94
94
60
163
166
FG24204
196
BATTERIES-CABLES
120
ENERSYS Cyclon High performance Pure Lead Batteries
0810-0004
2V 2.5Ah
0819-0020
12V 2.5Ah 2x3
0800-0004
2V 5.0Ah
0809-0016
12V 5.0Ah 1x6
0819-0012
6V 2.5Ah
0809-0020
12V 5.0Ah 2x3
0809-0012
6V 5.0Ah
0859-0016
12V 8.0Ah 1x6
0859-0012
6V 8.0Ah
0859-0020
12V 8.0Ah 2x3
0819-0016
12V 2.5Ah 1x6
DESCRIPTION
Thin plate rechargeable cells
can solve many of the
problems associated with
“conventional” lead alloy
batteries. The sealed
constructions uses a
patented, starved electrolyte
system, providing numerous
advantages including long
service life, rugged
constructions, extreme
temperature performance,
APPLICATIONS
CYCLON “pure lead”
batteries are used in a wide
variety of standby and
portable/cyclic applications
including those in:
• Telecommunications
• Electronics
• Uninterruptible power
supplies
• Defense installations
• Aviation
• Computer back-up
• Electric vehicles
• Medical equipment
• Solar power
• Lawn and garden
equipment
• Specialty engine start
www.hesa.com
fast recharge, high discharge
rates and low internal
resistance. In addition to the
standard cylindrical
configurations, Cyclon cells
offer a high degree of
flexibility to meet unusual
requirements and can be
configured in an infinite
number of designs to meet
your precise voltage and amp
hour requirements.
FEATURES
• Widest temperature range:
-65°C ~ +85°C
• High rate charge &
discharge capabilities
• Long life in stand-by and
cyclic applications
• High power density
• High stable voltage delivery
• Excellent deep discharge
recovery
• Lowest internal resistance
results in fastest recharge
• The rugged outer metal
case of the single cell
design increases its
resistance to shock,
crushing or damage due to
dropping
121
ENERSYS Cyclon High performance Pure Lead Batteries
0859-0020
0859-0016
0809-0020
0809-0016
0819-0020
0819-0016
0859-0012
0809-0012
0819-0012
Model
Constant voltage charge
Cyclic applications
Stand-by applications
Nominal Voltage
Nominal Capacity (Ah***)
Terminal mm
Operating temperature
Peso g
0800-0004
0810-0004
SPECIFICATIONS
2.45 – 2.50 vpc*
2.27 – 2.35 vpc*
2V
2.5
5.0
5x6
6.5x7
–65°C ~ +65°C
180
365
6V
5.0
2.5
5x6
8.0
6x8
520
980
1430
12V
2.5
5.0
8.0
5x6
6x8
–40°C ~ +40°C
1050
1050
1970
1970
2870
2870
* vpc = volt per cell
** C = capacity, A
DIMENSIONS (mm)
1
1
35
46
54
45
114
82
69
140
70
0810-0004
0800-0004
55
77
0819-0012
0809-0012
90
226
278
46
54
140
114
102
70
70
0859-0012
0819-0016
0819-0020
0809-0016
278
106
77
90
54
114
140
77
0809-0020
0859-0016
CODE
MODEL
DESCRIPTION
GA81-04
GA80-04
GA81912
GA80912
GA85912
GA8112L
GA8112Q
GA8012L
GA8012Q
GA85-16
GA85-20
0810-0004
0800-0004
0819-0012
0809-0012
0859-0012
0819-0016
0819-0020
0809-0016
0809-0020
0859-0016
0859-0020
2V 2.5Ah, Single cell battery
2V 5.0Ah, Single cell battery
6V 2.5Ah, Monobloc battery
6V 5.0Ah, Monobloc battery
6V 8.0Ah, Monobloc battery
12V 2.5Ah, 1x6 Monobloc battery
12V 2.5Ah, 2x3 Monobloc battery
12V 5.0Ah, 1x6 Monobloc battery
12V 5.0Ah, 2x3 Monobloc battery
12V 8.0Ah, 1x6 Monobloc battery
12V 8.0Ah, 2x3 Monobloc battery
www.hesa.com
102
102
0859-0020
BATTERIES-CABLES
122
ENERSYS Genesis High performance Pure Lead Batteries
G12V13Ah10EP
12V 13Ah
G12V42Ah10EP
12V 42Ah
G12V16Ah10EP
12V 16Ah
G12V70Ah10EP
12V 70Ah
G12V26Ah10EP
12V 26Ah
DESCRIPTION
Since its introduction in the
early 1990s, the GENESIS thin
plate pure lead-tin (TPPL)
battery has estabilished itself
as a premium high
performance battery suitable
for a wide range of
demanding applications.
Today, TPPL technology can
be found in applications as
diverse as emergency power,
avionics, medical, military
and consumer equipment.
www.hesa.com
The purity of the materials
used is key to supporting the
GENESIS battery’s
performance benefits. A
longer service life, meaning
fewer replacements and the
cost associated with it,
combined with higher
reliability and fewer system
failures, result in a lower
long-term cost of ownership
to the end user or equipment
owner.
FEATURES
• Power density - Per unit
weight, the power provided
bypure lead-tin products
offers the greatest high-rate
power density for your
energy dollar. The pure leadtin construction also gives
more watts-per-unit weight
at high discharge rates.
• Cycle life - GENESIS product
will deliver up to 400 cycles
(80% DOD, C/5).
• Float life - At 20°C,
GENESIS Single Cells offer a
fifteen-year design life.
• High stable voltage
delivery - It results from the
low internal resistance of
these batteries. GENESIS are
able to discharge and
recharge their power more
quickly and efficiently and
offer greater application
flexibility.
• Widest temperature range Due to the product’s strong
construction and high vent
pressures, these batteries
will maintain their
performance and physical
parameters in extreme
conditions. Pure lead-tin
technology resists to high
temperatures more
effectively than alloyed lead,
thus allowing a battery to
have a longer service life.
GENESIS has twice the
delivered capacity of
conventional sealed-lead
batteries at temperatures
APPLICATIONS
Batteries from EnerSys’ “pure
lead-tin” family are used in a
wide variety of standby and
portable/cyclic applications
including those in:
• Telecommunications
• Electronics
below -20°C, offering
unparalleled lowtemperature performance.
• Rugged construction - Due
to their strong external
packaging and internal pure
lead-tin composition,
EnerSys’ products can
withstand not only extreme
temperatures but also harsh
usage.
• Fastest recharge - GENESIS
offer the shortest recharge
efficiency of any sealed-lead
battery on the market. With
pure lead-tin, you can
achieve a 95% state of
recharge in less than one
hour.
• Orientation/placement/
transport - GENESIS can be
mounted and operated in
any position (except
inverted). GENESIS offer
UL94 V-0 non-halogenated
flame-retardant packaging,
thus allowing the mounting
in sensitive areas and
human environments.
GENESIS products are
classified as “nonspillable
batteries”.
• Shelf life - Pure lead-tin
batteries have an extremely
low self-discharge rate.
GENESIS must be recharged
(boost charged) once every
24 months or when the open
circuit voltage drops to
12.00 volts per battery.
• UPS
• Defense installations
• Computer back-up
• Electric vehicles
• Medical equipment
• Solar power
• Lawn and garden equipment
123
ENERSYS Genesis High performance Pure Lead Batteries
SPECIFICATIONS
Model
Nominal Voltage
15 minutes power to 1.67 vpc
Constant voltage charge:
Cyclic applications
Stand-by applications
Operating temperature
Life expectancy:
Cycle life
Float life
Nominal Capacity:
Terminal type
Weight kg
G12V13Ah10EP
G12V16Ah10EP
361W/cell
454W/cell
G12V26Ah10EP
12V
751W/cell
4.9
76
176
182
168
130
G12V16Ah10EP
167
198
166
176
166
197
171
126
171
G12V42Ah10EP
CODE
MODEL
DESCRIPTION
GA7027K
GA6925C
GA6521K
GA6621K
GA7121K
G12V13Ah10EP
G12V16Ah10EP
G12V26Ah10EP
G12V32Ah10EP
G12V70Ah10EP
12V 13Ah battery
12V 16Ah battery
12V 26Ah battery
12V 42Ah battery
12V 70Ah battery
www.hesa.com
1173W/cell
1940W/cell
400 cycle (C/5, 100% DOD)
10 years (@25°C), 15 years (@20°C)
16Ah
26Ah
42Ah
M6x1
6.1
10.1
14.9
13Ah
83
G12V26Ah10EP
G12V70Ah10EP
14.7V ~ 15V @ 25°C
13.5V ~ 13.8V @ 25°C
-40°C ~ +45°C (-40°C ~ +60°C with optional metal jacket)
DIMENSIONS (mm)
G12V13Ah10EP
G12V42Ah10EP
G12V70Ah10EP
70Ah
24.3
BATTERIES-CABLES
124
NORTHSTAR High performance Pure Lead Batteries
Industrial Range
NSB40
12V 40Ah
NSB70
12V 66Ah
NSB75
12V 69Ah
NSB90
12V 96Ah
NSB125
12V 129Ah
DESCRIPTION
The NSB series of premium
high density valve-regulated
lead acid (VRLA) batteries
from NorthStar Battery has
been specifically designed to
FEATURES
In addition to the benefits
offered by its valve regulated
technology the NSB battery
offers a long list of features
that serve to increase the
reliability and overall
performance of your system.
• Specifically design for
indoor/outdoor telecom
cabinet applications
• 10 year float life @25°C or
15 year float life @20°C
• Long cycle life capability up to 500 cycles to 80%
DOD at C/3 rate
• Rapid recharge capability
• 2 year shelf life
• High power output makes
the NSB series ideal for
UPS system
www.hesa.com
offer ten to fifteen years’
trouble free service in standby
emergency power (float)
applications as well as
delivering high power and
cycling capability.
• 3 step terminal seal
ensuring leak-free
operation
• Wide operating temperature
range of -40°C to +60°C
• Industrial standard
footprints assure
mechanical
interchangeability
• Non-halogenated flame
retardant (UL94-V0)
PC/ABS case and cover
• High conductivity female
terminals
• High charge acceptance
• Can be installed in any
orientation
QUALIFICATIONS, APPROVALS
AND CERTIFICATIONS
• Telcordia SR-4228 (Bellcore
TR-NWT-000766)
• Bellcore GR-63-Core,
Compliance Test Program
• DOT 49CFR173.159(d) (i)
and (ii) - Non-hazardous
shipping
• UL Approval - All NSB
products meet the UL
requirements for flame
retardancy, UL V-0, and
proper venting operation
• Deutsche Telecom
TL 4423-06
• Russian Telecom
• British Standard
BS 6290: Part 4:1997
• IEC 6096-21/22.2003
• Telkom Specification
SP-AP0016
• Design life
> 15-years @ 20°C
125
NORTHSTAR High performance Pure Lead Batteries
Industrial Range
SPECIFICATIONS
Model
Nominal Voltage
15 minutes power to 1.67 vpc
Constant voltage charge:
Cyclic applications
Stand-by applications
Nominal Capacity:
(10 hours)
(5 hours)
(1 hour)
Terminal type
Weight kg
NSB40
NSB70
180W/cell
297W/cell
40Ah
37Ah
30Ah
66Ah
63Ah
51Ah
16
27.3
NSB75
12V
310W/cell
14.6V ~ 14.9V @ 25°C
13.5V ~ 13.8V @ 25°C
69Ah
66Ah
54Ah
M6x1.25
27.3
NSB90
NSB125
400W/cell
540W/cell
96Ah
92Ah
73Ah
129Ah
126Ah
100Ah
37.8
54
DIMENSIONS (mm)
176
165
197
331
NSB40
NSB70
275
173
345
NSB125
CODE
MODEL
DESCRIPTION
NS40
NS70
NS75
NS90
NS125
NSB40
NSB70
NSB75
NSB90
NSB125
12V 40Ah battery
12V 66Ah battery
12V 69Ah battery
12V 96Ah battery
12V 129Ah battery
www.hesa.com
200
176
165
261
NSB75
213
341
173
NSB90
173
BATTERIES-CABLES
126
NORTHSTAR High performance Pure Lead Batteries
Front Terminal (FT) Range
NSB40FT
12V 39Ah
NSB100FT
12V 102Ah
NSB60FT
12V 59Ah
NSB110FT
12V 113Ah
NSB90FT
12V 90Ah
NSB155FT
12V 150Ah
NSB170FT
12V 175Ah
SPECIFICATIONS
Model
Nominal Voltage
15 minutes power to 1.67vpc
Coustant voltage charge
Cyclic applications
Stand-by applications
Nominal Capacity:
(10 hours)
(5 hours)
(1 hour)
Terminal type
Weight kg
NSB40FT
NSB60FT
NSB90FT
164W/cell
225W/cell
377W/cell
39Ah
36Ah
29Ah
M6x1.25
20.6
59Ah
55Ah
42Ah
90Ah
84Ah
66Ah
30
33.1
NSB100FT
12V
414W/cell
NSB110FT
NSB155FT
NSB170FT
478W/cell
610W/cell
627W/cell
150Ah
143Ah
116Ah
175Ah
162Ah
120Ah
52
58
14.6V ~ 14.9V @ 25°C
13.5V ~ 13.8V @ 25°C
102Ah
113Ah
97Ah
103Ah
70Ah
82Ah
M8x1.25
33.1
38.1
DIMENSIONS (mm)
250
287
208
396
287
255
96
NSB40FT
108
108
NSB60FT
NSB90FT
560
560
125
320
125
NSB155FT
NSB110FT
CODE
MODEL
DESCRIPTION
NS40FT
NS60FT
NS90FT
NS100FT
NS110FT
NS155FT
NS170FT
NSB40FT
NSB60FT
NSB90FT
NSB100FT
NSB110FT
NSB155FT
NSB170FT
12V 39Ah battery
12V 59Ah battery
12V 90Ah battery
12V 102Ah battery
12V 113Ah battery
12V 150Ah battery
12V 175Ah battery
125
NSB170FT
108
NSB100FT
560
280
227
www.hesa.com
396
263
127
Alarm Cables
DESCRIPTION
Traditional security cable
both multipolar and
combined with external PVC
sheathing and PVC
conductors in either rigid or
flexible versions, produced to
www.hesa.com
meet the required IEC, CEI,
VDE and NFC standards.
FEATURES
• Flame retardant
• Various degrees of
insulation available
• 200 m rolls
• Operating voltage levels:
- 2nd level: V/Vo = 300/300
- 3rd level: V/Vo = 450/750
- 4th level: V/Vo = 0.6/1KV
CAVO2X0.22S
2x0.22mm2 shielded cable,
2nd level
CAVO8X0.22
8x0.22mm2 unshielded cable
2nd level
CAVO4X0.22S
4x0.22mm2 shielded cable,
2nd level
CAVO8X0.22S
8x0.22mm2 shielded cable,
2nd level
CAVO4X0.22S/4
4x0.22mm2 shielded cable,
4th level
CAVO8X0.22S/4
8x0.22mm2 shielded cable,
4th level
CAVO6X0.22/2
6x0.22mm2 unshielded cable,
2nd level
CAVO12X0.22S
12x0.22mm2 shielded cable,
2nd level
CAVO6X0.22S/2
6x0.22mm2 shielded cable,
2nd level
CAVO2X0.5+4X0.22S
2x0.50mm2 + 4x0.22mm2
shielded cable, 2nd level
CAVO6X0.22S/4
6x0.22mm2 shielded cable,
4th level
CAVO2X0.5+4X0.22S/3
2x0.50mm2 + 4x0.22mm2
shielded cable, 3nd level
CAVO2X0.75+6X0.22S/4
2x0.75mm2 + 6x0.22mm2
shielded cable, 4th level
CAVO2X0.5+4X0.22S/4
2x0.50mm2 + 4x0.22mm2
shielded cable, 4nd level
Alarm Cables
CAVO2X0.75+4X0.22S
2x0.75mm2 + 4x0.22mm2
shielded cable,
2nd level
CAVO2X0.5+8X0.22
2x0.50mm2 + 8x0.22mm2
shielded cable,
2nd level
CAVO2X0.75+4X0.22S/4
2x0.75mm2 +4x0.22mm2
shielded cable,
4th level
6
6
–
–
–
–
–
–
NO YES
2
2
white white
6
8
6
8
–
–
–
–
–
–
–
–
–
–
2
–
YES NO
YES YES
4
2
4
2
blue white white white
8
–
–
–
YES
4
blue
12
4
4
–
–
–
–
2
2
–
–
–
YES YES YES
2
2
3
white white white
4
–
2
–
YES
4
blue
CODE
MODEL
DESCRIPTION
CV20
CV18
CV34
CV35
CV35S
CV36
CV08
CV19
CV22
CV37
CV12X22
CV14
CV30
CV38
CV24
CV26
CV39
CAVO2x0.22S
CAVO4x0.22S
CAVO4x0.22S/4
CAVO6x0.22/2
CAVO6x0.22S/2
CAVO6x0.22S/4
CAVO8x0.22
CAVO2X0.75+6x0.22S/4
CAVO8x0.22S
CAVO8x0.22S/4
CAVO12x0.22S
CAVO2x0.5+4x0.22S
CAVO2x0.5+4x0.22S/3
CAVO2x0.5+4x0.22S/4
CAVO2x0.5+8x0.22
CAVO2x0.75+4x0.22S
CAVO2x0.75+4x0.22S/4
2x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
4x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
4x0.22 mm2 conductors, shielded alarm cable, 4th level insulation (200m roll)
6x0.22 mm2 conductors, unshielded alarm cable, 2nd level insulation (200m roll)
6x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
6x0.22 mm2 conductors, shielded alarm cable, 4th level insulation (200m roll)
8x0.22 mm2 conductors, unshielded alarm cable, 2nd level insulation (200m roll)
2x0.75+6x0.22 mm2 conductors, shielded alarm cable, 4th level insulation (200m roll)
8x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
8x0.22 mm2 conductors shielded, alarm cable, 4th level insulation (200m roll)
12x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
2x0.50+4x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
2x0.50+4x0.22 mm2 conductors, shielded alarm cable, 3rd level insulation (200m roll)
2x0.50+4x0.22 mm2 conductors, shielded alarm cable, 4th level insulation (200m roll)
2x0.50+8x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
2x0.75+4x0.22 mm2 conductors, shielded alarm cable, 2nd level insulation (200m roll)
2x0.75+4x0.22 mm2 conductors, shielded alarm cable, 4th level insulation (200m roll)
www.hesa.com
8
4
–
–
2
–
–
2
YES YES
2
2
white white
CAVO2x0.75+4x0.22S/4
CAVO2x0.75+4x0.22S
CAVO2x0.5+8x0.22
CAVO2x0.5+4x0.22S/4
CAVO2x0.5+4x0.22S/3
CAVO2x0.5+4x0.22S
CAVO12x0.22S
CAVO8x0.22S/4
CAVO8x0.22S
CAVO2x0.75+6x0.22S/4
CAVO8x0.22
CAVO6x0.22S/4
CAVO6x0.22S/2
Model
Q.ty 0.22mm2 cond.
2
4
4
–
–
–
Q.ty 0.35mm2 cond.
Q.ty 0.50mm2 cond.
–
–
–
–
–
–
Q.ty 0.75mm2 cond.
Shielded
YES YES YES
Insulation level
2
2
4
Sheath colour
white white blue
CAVO6x0.22/2
CAVO4x0.22S/4
CAVO4x0.22S
SPECIFICATIONS
CAVO2x0.22S
BATTERIES-CABLES
128
4
–
–
2
YES
4
blue
129
CCTV Cables
CAVO RG59/300
Coaxial cable for CCTV
CAVO RG59+2X0.5/300
Combined cable for CCTV
DESCRIPTION
High performance RG59 cable
for CCTV installations,
751 impedance
DESCRIPTION
RG59 cable for CCTV
installations + 2 x 0.50 mm2
for power supply
CV-UTPAC5
CAT 5 UTP 4 Pairs Twisted Pair
Cable With Power Cord
CV-UTPC5
CAT 5 UTP 4 Pairs Twisted
Pair Cable
DESCRIPTION
CAT 5 Unshielded Twisted Pair
4 pairs cable. AWG24 Solid
anneals copper wire.
DESCRIPTION
CAT 5 Unshielded Twisted
Pair 4 pairs cable
RG174
Mini coaxial cable for CCTV
(300m roll) ’ mm2.9
DESCRIPTION
Mini RG59 coaxial
cable suitable for CCTV
installation in areas with
space costraint, white sheath
CODE
MODEL
DESCRIPTION
CV59300
CV59A300
CV59MC
CVUTPC5
CVUTPAC5
CAVO RG59/300
CAVO RG59+2X0.5/300
RG174
CV-UTPC5
CV-UTPAC5
Coaxial cable for CCTV (300m roll)
Combined cable for CCTV (300m roll)
Mini coaxial cable for CCTV (300m roll) ’ mm2.9
CAT5 UTP 4 Pair Twisted Pair Cable 305m
CAT5 UTP 4 Pair Twisted Pair Cable + power wire, 100m
CV-UTPTK
CV-UTPBNCSF
CV-UTPCT
CV-UTPRJ1
CV-UTPRJC
BNC59
BNC174
CV-59CT
CV-174CT
Accessories
CVUTPTK
CV-UTPTK
CVUTPSF
CVUTPCT
CV-UTPBNCSF
CV-UTPCT
CVUTPRJ1
CVUTPRJC
HEBNC59
HEBNC61
CV59CT
CV174CT
CV-UTPRJ1
CV-UTPRJC
BNC59
BNC174
CV-59CT
CV-174CT
www.hesa.com
Twisted Pair Tool Kit iclude: Ratchet modular connector crimping tool
crimping tool, for 6P2C, 8P8C modular connector stripper & punch down
tool, universal coacial crimping tool, RJ11 modular plug (6P4C flat) x
50pcs, RJ45 Modular (8P8C round solid) x 25pcs, RJ45 protection cap x
20pcs
Multi-Function Wire Stripper
Modular Crimping Tool, for 4, 6, 8 poles modular stripper is simple (RJ45,
RJ11 ratchet type. This tool is for all necessary tools to cut, strip and
crimp modular telephone wires
Modular RJ45 Plug, pack of 10 pcs
RJ45 Protection Cap 100pcs
BNC Crimp-on connector for RG59 video cable (10 Pce/Pack)
BNC Crimp-on connector for RG174 video cable
Coaxial Crimp Tool, application for crimping RG59 RG6 cable
Coaxial Crimp Tool, application for crimping RG174
CCTV PRODUCTS
Color Cameras
Camera Brackets
Outdoor Camera Housings
CCTV Lenses
Color LCD TFT Monitors
Video Testers
IR illuminators
Quad Processors
Distributors, Amplifiers, Surge Protections &
Power Supplies
H.264 Stand Alone DVR
19” Combo DVR
Veltra Plastic Fiber (POF) for Video
Transmission
Twisted-Pair Systems for Video Transmission
IP Cameras
Camera Servers
Encoder/Decoders
NVR Systems for IP Cameras
CCTV PRODUCTS
132
Color Cameras
IR Outdoor Cameras, Fixed Lens
TCC-70A
IR Camera 12m range, 350 TVL, 12VDC
TCC-72A
IR Camera 25m range, 380 TVL, 12VDC
TCC-73A
IR Camera 40m range, 380 TVL, 12VDC
FEATURES
• Built-in 12 IR LEDs
• Sunshield and bracket included
FEATURES
• Built-in 24 IR LEDs
• Sunshield and bracket included
FEATURES
• Built-in 48 IR LEDs
• Sunshield and bracket included
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
IR LEDs
H./V. Illumination Angle
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Weight g
TCC-70A
TCC-72A
1/3” Color Sony Super HAD
500x582
TCC-73A
350 TVL
380 TVL
0 lux (LED ON)@ F2.0
> 48dB
Auto 1/50~1/110.000sec
4.3mm @ F2.0
Internal
AGC
AWC
24
20°/50°
up to 25m
IP66
12VDC±10%
4.0mm @ F2.0
12
35°
up to 12m
6mm @ F2.0
48
20°/50°
up to 40m
230mA (IR ON)
120mA (LED OFF) 320mA (LED ON)
110mA (LED OFF) 450mA (LED ON
380
–10°C~+50°C
700
800
DIMENSIONS (mm)
72
60
122
108.5
125
118
66
77
132
69
122
TCC-70A
CODE
KUTC70A
KUTC72A
KUTC73A
MODEL
TCC-70A
TCC-72A
TCC-73A
www.hesa.com
’ 73
’ 83
100
TCC-72A
DESCRIPTION
1/3” IR Color camera, 350 TVL, IP66, IR 12m range, 12VDC
1/3” IR Color camera, 380 TVL, IP66, IR 25m range, 12VDC
1/3” IR Color camera, 380 TVL, IP66, IR 40m range, 12VDC
TCC-73A
104
133
Color Cameras
IR Outdoor Cameras, Fixed Lens, High Resolution
TCC-72B
IR Camera 25m range, 600 TVL, 12VDC
TCC-73B
IR Camera 40m range, 540 TVL, 12VDC
FEATURES
• Built-in 30 IR LEDs
• High resolution 600 TVL
• 4.0 mm @ F2.0 lens
• Sunshield and bracket included
FEATURES
• Built-in 48 IR LEDs
• High resolution 540 TVL
• 6 mm @ F2.0 lens
• Sunshield and bracket included
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
IR LEDs
H./V. Illumination Angle
IR Distance
IP Rating
Power Supply
Power Consumption
Weight g
TCC-72B
TCC-73B
1/3” color Sony Super HAD
752x582
600 TVL
540 TVL
0 lux @ F2.0
> 48dB
1/50~1/110.000s
mm 4.0 @ F2.0
mm 6 @ F2.0
internal, negative synchronism
AGC
YES (2500°K~9500°K)
30
48
20°/50°
25m
40m
IP66
12VDC±10%
320mA (IR ON)
160mA (IR OFF) 540mA (IR ON)
700
800
DIMENSIONS (mm)
72
60
122
108.5
125
77
132
69
122
TCC-72B
CODE
KUTC72B
KUTC73B
www.hesa.com
MODEL
TCC-72B
TCC-73B
’ 83
104
TCC-73B
DESCRIPTION
1/3” IR Color camera, 600 TVL, IP66, IR 25m range, 12VDC
1/3” IR Color camera, 540 TVL, IP66, IR 40m range, 12VDC
CCTV PRODUCTS
134
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter
TCC-740
IR Camera 20m range, Vari-Focal
3.8~9.5 mm, 420 TVL, 12VDC
FEATURES
• Sony 1/3” Super HAD color CCD
• 3.8~9.5 mm Vari-Focal, DC auto iris
F1.2 day & night lens
• Color & B/W auto switchable by
photocell
• Auto switching IR LED control by
phtocell:
- IR LED: 18pcs
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
Back Light Compensation
OSD function Control
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
MODEL
KUTCC740
TCC-740
KUTCC74BBU TCC-74B
www.hesa.com
TCC-74B
IR Camera 40m range, Vari-Focal
2.8~11mm, 600 TVL, 12VDC/24VAC
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• Hi-resolution: 600TVL (color), 650TVL
(B/W)
• 2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Built-in 2DNR, OSD function
• Back Light or HighLigh Compensation
(BLC/HLC) function
TCC-740
TCC-74B
1/3” Color Sony Super HAD
500x582
752x582
420 TVL Color
600 TVL Color
480 TVL B/W
650 TVL B/W
0 lux with LED ON
> 48dB
Auto 1/50~1/100.000sec
DC drive vari-focal
DC Auto Iris F1.2 D/N Lens
mm 3.8~9.5 @ F1.2
mm 2.8~11Vari-Focal
Internal
AGC
ATW1/ATW2/AWC/Manual
YES (2500°K~9500°K)
(STW1:2300~9500°K,
ATW2: 2000~11000°K)
ON/OFF
YES
–
YES
18 IR LEDs
36 IR LEDs
m 20
m 40
IP66
12VDC
12VDC/24VAC
180mA (LED OFF 12VDC)
500 mA/DC12V
340mA (LED ON 12VDC)
9.8VA/AC24V (IR-LED ON)
–10°C~+50°C
1200
1300
• Various automatic functions (DIP
switch built-in):ELC/ALC, FLK, BLC,
ATW/AWC, IR LED Brightness control
• DC Iris level adjustment volume built-in
• Service monitor (second video) port
built-in
• Cable managed (feed through) bracket
• Weatherproof housing (IP-66)
• Auto switvhing IR LED control by
photocell
- IR LED: 36pcs
• Built-in Service monitor port
& External OSD Set-up Port
• Cable managed bracket
• Weatherproof Housing (IP-66)
DIMENSIONS (mm)
118
100
66
’60
73
100
’74
TCC-740
92
193
103
80
107
TCC-74B
DESCRIPTION
1/3” IR D&N Color camera, 420 TVL, vari-focal, IR 20m range, 12VDC
1/3” IR D&N Color camera, 600 TVL, vari-focal, IR 40m range, 12VDC/24VAC
175
135
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter
TCC-75B
IR Camera 40m range, Vari-Focal, Sony
Super HAD II, 2.8~11mm, 600 TVL,
12VDC/24VAC
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• Hi-resolution: 600TVL (color), 650TVL
(B/W)
• 2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Externally adjustable Focus length
&Focus
• Built-in 2DNR, OSD function
• Back Light or HighLigh Compensation
(BLC/HLC) function
• Auto switvhing IR LEDcontrol by
photocell
- IR LED: 36pcs
• Built-in Service monitor port
& External OSD Set-up Port
• Cable managed bracket
• Weatherproof Housing (IP-66)
TCC-75A
IR Camera 45m range, Vari-Focal
9-22 mm, 550 TVL, EX-View,
12VDC/24VAC
FEATURES
• Sony 1/3” EX-View high-resolution
• 550TVL hi-resolution: 550TVL (color),
580TVL (B/W)
• 9.0~22mm vari-focal, DC auto iris
F1.8 day & night lens built-in
• Focal length, focus and DC iris level
externally adjustable
• Two glasses adapted
• Viewable length at night over 45m
• CDS auto switching IR LED control
• 42pcs LEDs built-in
• 24VAC/12VDC dual power source
• Cable managed bracket
• Weatherproof (IP-66)
TCC-75C
IR Camera 45m range, Vari-Focal
2.8~11 mm, 600 TVL, Super HAD, OSD,
12VDC/24VAC
FEATURES
• Sony 1/3” EX-View high-resolution
color CCD
• 600TVL hi-resolution
• 2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens
• External adjustable focal length & focus
• Built-in DNR, sens-up, d-zoom, OSD
function
• Built-in WDR (Wide Dynamic Range)
function (Option)
www.hesa.com
• Auto switching IR LED control by
photocell
- IR LED: 42
• Built-in service monitor & external
OSD set-up port
• Cable managed bracket
• Weatherproof bullet housing (IP-66)
• Power: 12VDC/24VCA
CCTV PRODUCTS
136
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter
SPECIFICATIONS
Model
CCD Image Sensor
TCC-75B
TCC-75A
1/3” Color Sony Super HAD II
1/3” Color Sony EX-View
600 TVL Color
650 TVL B/W
752x582
550 TVL Color
580 TVL B/W
0 lux with LED ON
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
TCC-75C
1/3”Color
Sony Super HAD
600 TVL Color
640 TVL B/W
> 48dB
1/50~1/110.000sec
DC auto iris
vari-focal
mm 2.8~11 @ F1.2
Synchronization
Gain Control
White Balance
> 52dB
1/50~1/100.000sec
DC auto iris
vari-focal
mm 2.8~11 @ F1.2
DC drive
vari-focal
mm 9.0~22.0 @ F1.8
Internal
AGC
ATW1/ATW2/AWC/Manual
ATW1:2300~9500°K,
ATW2:2000~11000°K)
Back Light Compensation
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
selectable
ATW1/ATW2/AWC/Manual
(ATW1: 2500~9500°K/
ATW2: 1800~10500°K)
ATW/AWC selectable
YES
42 IR LEDs
36 IR LEDs
m 40
36 IR LEDs
m 45
IP66
12VDC/24VAC
10.5VA (LED ON 24VAC)
680mA (LED ON 12VDC)
5.3VA (LED OFF 24VAC)
240mA (LED OFF 12VDC)
–10°C~+50°C
1400
500mA/DC12V
9.8VA/AC24V (IR-LED ON)
Operating Temperature
Weight g
500mA (LED ON 12VDC)
10.8VA (LED ON 24VDC)
DIMENSIONS (mm)
92
92
153
192
193
103
80
107
175
TCC-75B
CODE
KUTCC75B
KUTCC75A
KUTCC75C
www.hesa.com
IR VARI-FOCAL CAMERA
∅78
88
TCC-75A
MODEL
TCC-75B
TCC-75A
TCC-75C
129
85
103
95
∅110
80
113
TCC-75C
DESCRIPTION
1/3” IR D&N Color camera, 600 TVL, Super-HAD II, vari-focal, IR 40m range, 12VDC/24VAC
1/3” IR D&N Color camera, 550 TVL, EX-View, vari-focal, IR 45m range, 12VDC/24VAC
1/3” IR D&N Color camera, 600 TVL, Super-HAD, vari-focal, IR 45m range, 12VDC/24VAC
177
137
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, High Resolution, ICR Filter
TCC-76A
IR Camera 60m range, Vari-Focal
6-50mm, 540 TVL, 12VDC/24VAC
FEATURES
• 60 IR LEDs, IR distance 60m
• Autoiris lens DC drive vari-focal built-in
(6~50mm / F1.4)
• Externally adjustable focal length,
focus and DC iris level
• CDS auto switching IR LED control
• External service monitor output built-in
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
Back Light Compensation
IR LEDs
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTCC76A
www.hesa.com
MODEL
TCC-76A
• Dip switch control of day&night delay
time, flickerless, BLC and white
balance (built-in)
• 2-glasses window adapted for clear
image without IR reflection
• Metal housing and bracket included
• Dual power 12VDC/24VAC
DIMENSIONS (mm)
TCC-76A
1/3” Color Sony Super HAD
752x582
540 TVL Color
580 TVL B/W
0.3 lux (Color) 0 lux (B/W, LED ON)
> 48dB
Auto 1/50~1/110.000sec
DC Drive
Vari-Focal
6~50mm @ F1.4
Day&Night lens
Internal
AGC
ATW/AWC selectable
YES
60
60m
IP66
12VDC/24VAC
18VA (IR ON 24VAC)
990mA (IR ON 12VDC)
4.8VA (IR OFF 24VAC)
250mA (IR OFF 12VDC)
–10°C~+50°C
1630
169
140
’88
102
TCC-76A
DESCRIPTION
1/3” IR D&N Color camera, 540 TVL, vari-focal 6-50 mm, IR 60m range, 12VDC/24VAC
144
’110
CCTV PRODUCTS
138
Day/Night Color Cameras
True Day & Night IR-LED “all-in-one” Cameras
TCC-80
IR Camera 50m range, Vari-Focal
6~50mm, 540 TVL, 12VDC/24VAC
TCC-80FH
IR Camera 50m range, Vari-Focal
6~50mm, 540 TVL, 12VDC/24VAC
TCC-81
IR Camera 50m range, Vari-Focal
3.8~38mm, 500 TVL, 12VDC/24VAC
www.hesa.com
FEATURES
• Externally adjustable focal length, focus
• Built-in DC iris level adjustment volume
• Auto switching IR-LED control by
photocell
- High defination IR-LED: 48pcs
• Built service monitor port
• Fan & Heater built-in (TCC-80FH)
• Cable managed bracket
• Weatherproof housing (IP-66)
FEATURES
• x100 zoom (optical zomm: x10, digital
zoom: x10)
• Auto focus and auto iris
• OSD function built-in
• Viewable length at night over 50m
• Auto switching IT-LED control by
photocell
• 47pcs high definition LEDs built-in
• IR remote for camera set-up and zoom
control
• RS-485 comunication (Pelco-D)
• Cable managed bracket
• Weatherproof housing (IP-66)
139
Day/Night Color Cameras
True Day & Night IR-LED “all-in-one” Cameras
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
TCC-80
TCC-80FH
1/3” Color Sony Super HAD
752x582
540 TVL Color
580 TVL B/W
0 lux with (LED ON)
> 48dB (AGC off)
1/50~1/120.000s
DC auto iris
varifocal
mm 6~50 @ F1.4
YES
internal
AGC
ATW1/ATW2/AWC/manual (ATW1:2300~9500°K, ATW2:2000~11000°K)
ON/OFF selectable
ON/OFF selectable
48 LED IR
m 50
YES
–
–
IP66
–
YES
12VDC/24VAC
normal: 5.0VA, max.: 23VA/24VAC
normal: 160mA,
(IR LED & Heater ON)
max.: 800mA/12VDC (IR LED ON)
normal: 5.3VA, max.: 15VA/24VAC.
(IR LED ON, Heater OFF)
–30°C~+50°C (with Fan
–10°C~+50°C
& Heater)
max. 90% RH
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Day&Night function
Synchronization
Gain Control
White Balance
DNR
DWDR
IR LED
IR Distance
OSD function Control
Comand RS485
Remote Control
IP Rating
Fan & Heater
Power Supply
Power Consumption
Operating Temperature
Operating Humidity
DIMENSIONS (mm)
87
305
229
130
195
84
90
189
TCC-80 / TCC-80FH / TCC-81
CODE
KUTCC80
KUTCC80FH
KUTCC81
www.hesa.com
MODEL
TCC-80
TCC-80FH
TCC-81
DESCRIPTION
1/3” IR D&N Color camera, 540 TVL, IP66, vari-focal, IR 50m range, 12VDC/24VAC
1/3” IR D&N Color camera, 540 TVL, IP66, vari-focal, IR 50m range, 12VDC/24VAC
1/3” IR D&N Color camera, 500 TVL, IP66, vari-focal, IR 50m range, 12VDC/24VAC
TCC-81
1/4” Color Sony Super HAD
500 TVL Color
570 TVL B/W
> 50dB (AGC off)
DC auto iris varifocal
zoom auto focus 10X
mm 3.8~38 @ F1.8
internal/line-lock
YES
–
–
47 LED IR
YES
YES
710mA (IR ON a 24VAC)
680mA (IR ON a 12VDC)
–30°C~+50°C
CCTV PRODUCTS
140
Day/Night Color Cameras
True Day & Night IR-LED “all-in-one” Cameras
TCC-82
IR Camera 80m range, Vari-Focal
7.5~50mm, 580 TVL, 12VDC
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Digital zoom
Synchronization
Video Output
Fan & Heater
Gain Control
White Balance
OSD function Control
3D-DNR
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
CODE
KUTCC82
www.hesa.com
MODEL
TCC-82
FEATURES
• Built-in DC Iris Vari-Focal Lens
(7.5~50mm)
• XWDR (Wide Dynamic Range)
• TDN (ICR), OSD, 3D-DNR, 6.13x Digital
Zoom
• Digital Slow Shutter2x~128x Field (DSS)
• Built-in SR LEDs (12 EA)
• IR Visible Range: Max. 80m
• Motion Detection, Ecplise Function
• Built-in Fan/Heater
• Cable Trough Type Camera Bracket
• Weatherproof housing (IP-67)
DIMENSIONS (mm)
TCC-82
1/3” Color
795x596
580 TVL Color, 650 TVL B/W
0.005 lux/0.0002 lux (DSS ON, BW)/
0.00 lux (IR LED ON), F1.2, 30IRE
> 52dB (AGC OFF)
1/50 ~ 1/90.000sec.
DC Iris VariFocal Lens (f=7.5~50mm)
6.13x
internal
1.0Vp-p/75 1
YES
AGC
ATW/Manual
YES
YES
SR LEDs 12EA & Sensor1EA
m 80
IP67
12VDC
max. 20W/1.7A
–30°C~+50°C
372.4
297
222.3
TCC-82
DESCRIPTION
1/3” IR D&N Color camera, 580 TVL, IP67, vari-focal, IR 80m range, 12VDC 0
141
Day/Night Color Cameras
Entry level, IR Outdoor Cameras, Fixed Lens
TCC-70SL
IR Camera, 420TVL
3.6mm, 23 LEDs, 12VDC
FEATURES
• CDS auto switching IR LED control
• Anti-flare Double Glass
• 23pcs LEDs built-in
• Cable Management Bracket
TCC-72SL
IR Camera, 540TVL
3.6mm, 23 LEDs, 12VDC
DIMENSIONS (mm)
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTCC70SL
KUTCC72SL
www.hesa.com
MODEL
TCC-70SL
TCC-72SL
TCC-70SL
TCC-72SL
1/3” Color Sony Super HAD
500x580
752x582
420 TVL Color
540 TVL Color
0 lux (LED ON)
> 48dB
1/50~1/100.000sec
3.6mm @ F2
Internal
AGC
YES
23
12 m
IP66
12VDC
80mA (IR OFF)
2000mA (IR ON)
–10°C~+50°C
360
540
DESCRIPTION
1/3” IR D&N Color camera, 420 TVL, 3,6 mm, IR 12m range, 12VDC
1/3” IR D&N Color camera, 540 TVL, 3,6 mm, IR 12m range, 12VDC
70
151
78
170
TCC-70SL / TCC-72SL
CCTV PRODUCTS
142
Day/Night Color Cameras
Entry level, IR Outdoor Cameras, Vari-Focal, ICR Filter
DIMENSIONS (mm)
70
151
78
170
TCC-74SL
TCC-74SL
IR Camera 25m range, Vari-Focal
4-9mm, 540 TVL, 36 LED, 12VDC
TCC-75SL
IR Camera 40m range, Vari-Focal
9-22mm, 540 TVL, 42 LED, 12VDC
FEATURES
• CDS auto switching IR LED control
• 36pcs LEDs built-in
• Cable managed bracket
TCC-750SL
IR Camera 40m range, Vari-Focal
2.8-10mm, 540 TVL, 42 LED, 12VDC
185
FEATURES
• CDS auto switching IR LED control
• 36pcs LEDs built-in
• Cable managed bracket
185
283
298
TCC-75SL / TCC-750SL
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
IR LEDs
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTCC74SL
KUTCC75SL
KUTCC75SL
www.hesa.com
MODEL
TCC-74SL
TCC-75SL
TCC-750SL
TCC-74SL
1/3” Color
Sony Super HAD
TCC-75SL
TCC-750SL
1/3” Color
Sony Super HAD II
752x582
540 TVL Color
0 lux (LED ON)
> 48dB
Vari-Focal 4~9mm @ F1.2
> 50dB
1/50~1/100.000sec
Vari-Focal 9~22mm @ F1.2
Internal
AGC
YES
36
25 m
Vari-Focal 2.8~10mm @ F1.2
42
40 m
IP66
12VDC
100mA (IR OFF)
420mA (IR ON)
150mA (IR OFF)
510mA (IR ON)
–10°C~+50°C
950
1300
DESCRIPTION
1/3” IR D&N Color camera, 540 TVL, vari-focal 4-9 mm, IR 25m range, 12VDC
1/3” IR D&N Color camera, 540 TVL, vari-focal 9-22 mm, IR 40m range, 12VDC
1/3” IR D&N Color camera, 540 TVL, vari-focal 2.8-10 mm, IR 40m range, 12VDC
143
Day/Night Color Cameras
UTP Cameras
TCC-74BBU
IR Camera 40m range, Vari-Focal
2.8-11 mm, 600 TVL, 12VDC/24VAC
DOMEHC-5BU
IR Camera 30m range, Vari-Focal
2.8-11 mm, 540 TVL, 12VDC/24VAC
FEATURES
• 1/3” Sony Super HAD II High-resolution
color CCD
• 600TVL High-resolution
• f=2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Built-in 2DNR, OSD function
• Back Light or High Light
Compensation (BLC/HLC) function
• Auto switching IR LED control by
photocell
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• 540TVL hi-resolution
• 2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens
• Built-in function selection dip switch
- ICR switching time, FLK, BLC, white
balance
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Lens
UTP Signal Level
Synchronization
Gain Control
White Balance
Back Light Compensation
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Operating Humidity
CODE
MODEL
KUTC74BBU TCC-74BBU
KUDOMH5BU DOMEHC-5BU
www.hesa.com
• IR LED: 36pcs
• Built-in UTP transmitter with UTP
cable length switch
• Built-in Service monitor port &
External OSD Set-up Port
• Cable managed bracket
• Weatherproof Housing (IP-66)
• Power: AC24V/DC12V
• Built-in DC Iris level adjustment volume
• Auto switching IR-LED control (36pcs)
• Easy adjustment of focal length & focus
• Built-in service monitor port
• 3-AXIS gimbal bracket
• Flush & surface mount
• Vandal resistant & weatherproof
housing (IP-66)
DIMENSIONS (mm)
TCC-74BU
DOMEHC-5BU
1/3” Sony Super HAD II
1/3” Sony Super HAD
High-resolution Color CCD
752x582
600 TVL Color
540 TVL Color
640 TVL B/W
580 TVL B/W
0 lux @ F1.2
0 lux with LED ON
> 48dB
f=2.8~11mm Vari-focal, DC Auto Iris F1.2 D/N
Short 1.0Vp-p/Long 2.5Vp-p
Internal
AGC
ATW1/ATW2/AWC/Manual
ATW/AWC selectable
YES
36 IR LEDs
m 40
m 30
IP66
12VDC/24VAC
9.5VA (LED ON 24VAC)
13VA (LED ON 24VAC)
530MA (LED ON 12VDC)
550mA (LED ON 12VDC)
–10°C~+50°C
Max. 90% RH
92
192
103
80
113
177
TCC-74BU
149
102
DOMEHC-5BU
DESCRIPTION
1/3” IR D&N Color camera, 600 TVL, vari-focal, IR 40m range, 12VDC/24VAC
1/3” IR D&N Color camera, 540 TVL, vari-focal, IR 30m range, 12VDC/24VAC
36
16
50
116146
CCTV PRODUCTS
144
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber integrated transmitter(*)
TCC-74LW
IR Camera 40m range, Vari-Focal
3.8-9.5 mm, 550 TVL, 12VDC/24VAC
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• 550TVL resolution: 550TVL (color),
580TVL (B/W)
• 3.8~9.5mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Function selection dip switch built-in CDS switching time, FLK, BLC, AWB
• DC iris level adjustment volume built-in
• Viewable length at night over 40m
• CDS auto switching IR LED control
• 36pcs LEDs built-in
• 24VAC/12VDC dual power source
• Cable managed bracket
• Weatherproof (IP-66)
• Integrated connector for signal
transmission over Plastic Optical Fiber
up to a distance of 150m
TCC-75LW
IR Camera 40m range, Vari-Focal
3.8-9.5 mm, 550 TVL, EX-View,
12VDC/24VAC
FEATURES
• Sony 1/3” EX-View high-resolution
color CCD
• 540TVL hi-resolution: 540TVL (color),
580TVL (B/W)
• 3.8~9.5mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Focal length, focus and DC iris level
externally adjustable
• Two glasses adapted
• Viewable length at night over 40m
• CDS auto switching IR LED control
www.hesa.com
• 36pcs LEDs built-in
• Service monitor (second video) port
built-in
• 24VAC/12VDC dual power source
• Cable managed bracket
• Weatherproof (IP-66)
• Transmission distance up to 150m
• Integrated connector for signal
trasmission over Plastic Optical Fiber
up to a distance of 150m
145
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber integrated transmitter(*)
SPECIFICATIONS
DIMENSIONS (mm)
Model
TCC-74LW
1/3” Color
Sony Super HAD
CCD Image Sensor
Effective Pixels (HxV)
752x582
550 TVL Color
580 TVL B/W
0 lux with LED ON
> 48dB
Auto 1/50~1/110.000sec
DC drive
vari-focal
mm 3.8~9.5 @ F1.2
Internal
AGC
YES (2500°K~9500°K)
ATW/AWC selectable
YES
36 IR LEDs
m 40
IP66
12VDC/24VAC
260mA (IR OFF)
320mA (IR OFF 12VDC)
530mA (IR ON)
680mA (IR ON 12VDC)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
Back Light Compensation
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Plastic Fiber transmission system
Bandwidth
Transmission distance
Optical connector
Operating Temperature
CODE
KUTC74LW
KUTC75LW
www.hesa.com
MODEL
TCC-74LW
TCC-75LW
TCC-75LW
1/3” Color
Sony EX-View
155
95
77
’70
83
’110
134
TCC-74LW
140
82
∅73
85
123
TCC-75LW
0 ~ 5.5 MHz
120 m ~ 300 m
SMA
-10°C~+50°C
DESCRIPTION
1/3” IR D&N Color camera, 480TVL, vari-focal, IR 40m range, integrated Plastic Fiber transmitter, 12VDC
1/3” IR D&N Color camera, 550TVL EX-View, vari-focal, IR 40m range, integrated Plastic Fiber
transmitter, 12VDC
95
∅110
CCTV PRODUCTS
146
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber integrated transmitter(*)
DOMEHC-5LW
550 TVL, Vari-Focal, Vandalproof IP66,
IR LED, 12VDC/24VAC
FEATURES
• 1/3” Sony Super HAD High-Resolution
Color CCD
• 550TVL High-Resolution
• F=3.8~9.5mm Vari-focal/ F1.2 built-in
• Color & B/W Auto Switchable by
Photocell
• Auto Switching IR-LED control (36pcs)
• Built-in function selection dip switch
- ICR switching time, FLK, BLC, white
balance
• Built-in DC Iris level adjustment volume
• Easy adjustment of focal length & focus
DIMENSIONS (mm)
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
Video output
UTP signal level
S/N Ratio
Electronic Shutter
IR LED
Synchronization
Iris Control
Gain Control
White Balance
Power Supply
Power Consumption
IP Rating
Operating Temperature
Operating Humidity
Dimension
Weight g
CODE
MODEL
KUDOMH5LW DOMEHC-5LW
• Built-in UTP transmitter with UTP
cable length switch
• Built-in service monitor port
• 3-AXIS gimbal bracket
• Flush & surface mount
• Vandal resistant & Weatherproof
housing (IP66)
• Power: 24VAC/12VDC
• Integrated connector for signal
trasmission over Plastic Optical Fiber
up to a distance of 150m
DOMEHC-5LW
1/3” Color Sony Super HAD High-Resolution
752x582
550 TVL Color
580 TVL B/W
0 lux (LED ON)
Vari-Focal 3.8~9.5mm /F1.2
VBS 1.0Vp-p (751 Load)
Short 1.0Vp-p/Long 2.5Vp-p
> 48dB (AGC OFF)
Auto 1/50sec
36
Internal
DC drive
AGC
ATW/AWC Selectable
12VDC/ 24VAC ±10%
650mA@12VDC (LED ON)
13VA@24VAC (LED ON)
IP66
–10°C~+50°C
Max. 90% RH
157mm (Ø) x 110mm (L)
1014
146
108
40
18
50
99 146
DOMEHC-5LW
DESCRIPTION
1/3” Color Dome camera, 550 TVL, integrated Plastic Fiber transmitter,
Vandalproof, IR LED, 12VDC/24VAC
DOME-SP
Accessori
KUDOMSP
KUDOMSA
www.hesa.com
DOME-SP
DOME-SA
Wall mount bracket
Angle mount bracket
DOME-SA
147
Color Cameras
High Sensitivity, Standard Resolution
TCC-34A
420 TVL, 12VDC/24VAC
TCC-35A
420 TVL, 90~260VAC
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Back Light Compensation (BLC)
Flickerless
Digital Day&Night
Gamma Correction
Synchronizing System
Iris Control
Adjustment VR
Lens Mount
Video Output
Automatic Gain Control
White Balance
Power Supply
Power Consumption
Operating Temperature
Dimensions
Weight g
CODE
KUTCC34A
KUTCC35A
www.hesa.com
MODEL
TCC-34A
TCC-35A
FEATURES
• Using Advanced 1/3” SONY SuperHAD
II CCD
• Flickerless function is available for
50/60Hz
• Backlight Compensation ON/OFF
• Automatic Gain Control ON/OFF
• Designed with dual power
AC24V/DC12V, isolated power 90V-260V
DIMENSIONS (mm)
TCC-34A
TCC-35A
1/3” SONY Super HAD CCD
537X597
420 TVL
0.15 lux @ F1.0
> 50dB (Super AGC off)
AES: ON: 1/50(60) ~1/100.000 sec AES: OFF: 1/50(60) sec
ON/OFF
ON/OFF
Automatic
0.45
Internal
DC Iris
DC Level
C/CS mount (With Adaptor)
1Vp-p Composite/75 1
ON/OFF
Automatic
12VDC/24VAC
90~260VAC
12VDC: 1.6W max.
90~260VAC 1.6W max.
24VAC: 2.2W max.
–20°C~+60°C
68x51x120 mm
470
DESCRIPTION
1/3” Color camera, 420 TVL, 12VDC/24VAC
1/3” Color camera, 420 TVL, 90~260VAC
68
124
36
36
TCC-34A / TCC-35A
CCTV PRODUCTS
148
Color Cameras
High Sensitivity, High Resolution
TCC-54A
540 TVL, D&N, 12VDC/24VAC
TCC-55A
540 TVL, D&N, 90~260VAC
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Gamma
Back Light Compensation (BLC)
Flickerless
Synchronization
Iris Control
Video Output
Gain Control (AGC)
White Balance
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTCC54A
KUTCC55A
www.hesa.com
MODEL
TCC-54A
TCC-55A
FEATURES
• Using advanced 1/3” Sony Super HAD II
CCD
• Built in digital noise reduction for
better clarity and vivid picture during
night time survaillance
• Linelock with V-phase adjustment
• Digital Day & Night feature is
automatically built in to switch from
color to monochrome at low light level
• Flickerless function is available for
50/60Hz
• Backlight compensation ON/OFF
DIMENSIONS (mm)
TCC-54A
TCC-55A
1/3” Color Sony Super HAD II
795x596
540 TVL Color, 600 TVL B/W
0.15 lux @ F1.0 (Color)
0.01 lux @ F1.0 (B/W)
> 50dB (Super AGC OFF)
Auto 1/50~1/100.000sec
0.45
ON/OFF
ON/OFF
Internal
Internal/Linelock
DC Iris
1.0Vp-p/75 ⏲
ON/OFF
automatic
12VDC/24VAC
90~260VAC
2.0W
–10°C~+50°C
470
520
DESCRIPTION
1/3” Color camera, 540 TVL, 12VDC/24VAC
1/3” Color camera, 540 TVL, 90~260VAC
51
68
TCC-54A / TCC-55A
96
120
149
Color Cameras
Day&Night, High Resolution
TCC-60A
540 TVL, D&N, 12VDC/24VAC
TCC-64A
540 TVL, EX-View, D&N, 12VDC/24VAC
TCC-61A
540 TVL, D&N, 90~260VAC
TCC-65A
540 TVL, EX-View, D&N, 90~260VAC
FEATURES
• 540 TVL Color, 600 TVL B/W mode
• Color/Mono switchable by ICR filter
• Easy backfocus adjustment
FEATURES
• Sony EX-View CCD
• 540 TVL Color, 600 TVL B/W mode
• Color/Mono switchable by ICR filter
• Easy backfocus adjustment
DIMENSIONS (mm)
68
124
36
36
TCC-60A / TCC-61A / TCC-64A / TCC-65A
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Digital S/N Ratio
Electronic Shutter
Lens
Gamma correction
Back Light Compensation (BLC)
Synchronization
Iris Control
Video Output
Gain Control
White Balance
Flickerless Mode
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTCC60A
KUTCC61A
KUTCC64A
KUTCC65A
www.hesa.com
MODEL
TCC-60A
TCC-61A
TCC-64A
TCC-65A
TCC-60A
TCC-61A
1/3” Sony Super HAD
TCC-64A
TCC-65A
1/3” Sony EX-View
795x596
540 TVL Color, 600 TVL B/W
540 TVL, Sony HQ1
- Day mode: 0.15 lux @ F1.2
- Day mode: 0.05 lux @ F1.0
- Night mode: 0.01 lux @ F1.2 ICR Filter
- Night mode: 0.01 lux @ F1.0 ICR Filter
>50dB (Super AGC OFF)
1/50sec~1/100.000sec.
ON: 1/50sec.~1/100000sec. / OFF: 1/50sec.
C/CS mount (With adaptor)
0.45
ON/OFF
Internal
Internal/Linelock
Internal
Internal/Linelock
DC Iris
1.0Vp-p/75 ⏲
ON/OFF
Automatic
ON/OFF
12VDC/24VAC
90~260VAC
12VDC/24VAC
90~260VAC
2.0W
5.0W
–10°C~+50°C
550
470
520
470
DESCRIPTION
1/3” Day&Night Color camera, 540 TVL, 12VDC/24VAC
1/3” Day&Night Color camera, 540 TVL, 100~240VAC
1/3” EX-View, Day&Night Color camera, 540 TVL, 12VDC/24VAC
1/3” EX-View, Day&Night Color camera, 540 TVL, 100~240VAC
CCTV PRODUCTS
150
Color Cameras
Day&Night, High Resolution
TCC-62A
540 TVL, D&N, 12VDC/24VAC
TCC-63A
540 TVL, D&N, 90~260VAC
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Gamma
Back Light Compensation (BLC)
Synchronization
Iris Control
Video Output
Gain Control (AGC)
White Balance
Power Supply
Power Consumption
Operating Temperature
Weight g
CODE
KUTC62A
KUTC63A
www.hesa.com
MODEL
TCC-62A
TCC-63A
FEATURES
• Horizontal resolution Day (Color):
540TVL/ Night (B/W): 600TVL
• Gain control Auto (normal/super)
• White balance ATW1/ATW2
• BLC ON/OFF
• Day & Night mode Auto/Manual/BW
• Lumii technology for ultra low lux performance
DIMENSIONS (mm)
TCC-62A
TCC-63A
1/3” Sony SuperHAD Lumii technology
752x582
540 TVL Color, 600 TVL B/W
- Day mode: 0.01 lux (F1.2, AGC ON, 10 IRE);
0.2 lux (F1.2, AGC ON, 50 IRE)
- Night mode: 0.003 (F1.2, AGC ON, 10 IRE);
0.01 lux (F1.2, AGC ON, 50 IRE)
> 50dB (AGC OFF)
Auto 1/50~1/100.000sec./Manual 8 steps 1/50, 1/120,
1/250, 1/500, 1/1K, 1/2K, 1/4K, 1/10Ksec.)
CS mount
0.45
ON/OFF
Internal/Linelock
Video/DC drive
1Vp-p composite output, 75 ⏲
Auto (normal/super)
ATW1/ATW2
12VDC/24VAC
90~260VAC
7W (max.)
–10°C~+50°C
500
DESCRIPTION
1/3” Color camera, 540 TVL, D&N, 12VDC/24VAC
1/3” Color camera, 540 TVL, D&N, 90~260VAC
62
50
TCC-62A / TCC-63A
126
151
Color Cameras
Day&Night Wide Dynamic
TCC-660W
600 TVL, D&N, Sony Super HAD, 12VDC
FEATURES
• 1/3” Sony Super HAD High-resolution
Color CCD
• 600TVL High-Resolution
• Min. Illumination: 0.4Lux (F1.2, 50IRE,
Sens-Up Off)
• Day & Night functionality with ICR
• Built-in DNR (Digital Noise Reduction,
2D+3D) function
SPECIFICATIONS
S/N Ratio
Electronic Shutter
Synchronization
Video Output
White Balance
Lens
OSD Function Control
DNR
Power Supply
Power Consumption
Operating Temperature
CODE
KUTCC660W
www.hesa.com
MODEL
TCC-660W
DIMENSIONS (mm)
TCC-660W
1/3” Sony Super HAD High-resolution Color CCD
752x582
600 TVL Color, 640 TVL B/W
Color: 0.4lux (sens off)/0.001 lux (sens x256),
B/W: 0.04 lux (sens off)/0.0001 lux (sensx256)@F1.2, 50IRE
>52dB (AGC OFF)
1/50~1/100,000sec.
Internal
VBS 1.0Vp-p (75 1 Load)
ATW1/ATW2/AWC/Manual
(ATW: 2.500~9.500°K, ATW2: 1.800~10.500°K)
DC/VIDEO Auto iris lens
Built-in
User, High, Middle, Low Off selectable
12VDC
250mA (12VDC)
–10°C~+50°C
DESCRIPTION
1/3” Sony Super HAD, 600 TVL, 12VDC
108
64
54,3
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
• Built-in Sens-Up, D-Zoom and OSD
function
• Privacy Mask function (Polygonal
method, 4 points)
• Auto/Manual Iris lens selectable in
OSD menu
• C/CS mount lens available
• Power: 12VDC
6.7
TCC-660W
CCTV PRODUCTS
152
Color Cameras
36X Day&Night Auto Focus Zoom High Resolution
TCC-67A
550 TVL, D&N, Sony Super HAD IIWD,
36X Zoom, 12VDC
FEATURES
• 1/4” CL 36x (ICR) Auto Focus Zoom
Camera (HR)
• Effio platform 550 TV Line
• 1/4” Sony Super HAD IIWD CCD sensor
• 36X Auto Focus Zoom Lens
• Min illumination 0.05~0.008 Lux
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Gamma
Back Light Compensation (BLC)
Synchronization
Video output
Iris Control
Gain Control
Focus Mode
White Balance
OSD Function Control
Day & Night (ICR)
IR-Cut filter
Lens
Remote Control
Power Supply
Power Consumption
Operating Temperature
CODE
KUTCC67A
www.hesa.com
MODEL
TCC-67A
• Day and Night Control by AE / External
• Support Protocol: Pelco P / D
• 12VDC Power Support
• RS232/485, Alarm Out Interface
DIMENSIONS (mm)
TCC-67A
1/4” Color Sony Super HAD II Double-Density WD CCD
976x582
550 TVL
0.05 lux (Day Mode), 0.008 lux (Night Mode),
0.0008 lux (DSS)/F1.6
>50dB
NTSC: 1/60~1/100.000, PAL: 1/50~1/100.000
include flickerless (PAL: 1/120)
0.45
7 areas & smart area, level: 0~225
Internal
1.0Vp-p/75 ⏲
Auto/Manual
Auto/Manual
Auto/Manual/Push Auto
Auto/Indoor/Outdoor/Manual/Push Auto
English/Simple Chinese
AE/Day/Night/External
YES
36X Auto focus zoom (3.4~122.4mm/F1.6~4.5)
RS-485/422
12VDC
max. 4.5 W
–10°C~+50°C
DESCRIPTION
36X D&N Auto Focus Zoom Color camera, 540 TVL, 12VDC
TCC-67A
153
Color Cameras
Outdoor Dome Cameras
DOMEC-3
420 TVL, 12VDC
DOME-HCV
540 TVL, Vari-Focal, 12VDC
FEATURES
• Sony Super HAD II high sensitivity CCD
sensor
• Lens 3.6mm/F2.0 built-in
• 3-Axis Mechanism for free lens
rotation
FEATURES
• Sony Super HAD II high sensitivity CCD
sensor
• Vari-Focal lens 3.7~12mm/F1.6
built-in
• 3-Axis Mechanism for free lens
rotation
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
Back Light Compensation (BLC)
Synchronization
Iris Control
Gain Control
White Balance
Power Supply
Video Output
Power Consumption
Operating Temperature
Weight g
CODE
KUDOM63
KUDOMH1
www.hesa.com
MODEL
DOMEC-3
DOME-HCV
DIMENSIONS (mm)
DOMEC-3
DOME-HCV
1/3” Color Sony Super HAD II (Hi-Res.)
500x582
752x582
420 TVL
540 TVL
0.01 lux @ F1.2
0.02 lux @ F1.2
Vari-Focal
3.6mm/F2.0
3.7~12mm/F1.6
> 48dB
Auto 1/50~1/110.000sec
–
ON/OFF
Internal
–
DC Drive
Auto
High/Low
Auto
12VDC±10%
1 Vp-p /75 W
117mA
175mA
-10°C~+50°C
180
340
DESCRIPTION
1/3”, Color Dome camera, 420 TVL, 12VDC
1/3”, Color Dome camera, Vari-Focal, 540 TVL, 12VDC
’ 88
57
DOMEC-3
’ 107
91
DOME-HCV
CCTV PRODUCTS
154
Color Cameras
3-AXIS Gimbal Vari-focal, Indoor Dome Cameras
DOMEC-4
600 TVL, Vari-Focal, 12VDC/24VAC
DOMEHC-5IA
600 TVL, Vari-Focal, 12VDC/24VAC
FEATURES
• 1/3” Sony Super HAD High-resolution
Color CCD
• Resolution 600TVL-Lines
• 2.8~11mm Vari-focal DC Auto Iris F1.2
Day&Night Lens
• Color & B/W Auto switchable by
photocell
• Function selection Dip switch built-in
- Day&Night switching time, FLK, BLC,
AWC
• DC Iris level adjustment volume built-in
• Easy adjustment of Focal Length &
Focus
• Service monitor (second video) port
built-in
• Surface mount type
FEATURES
• 1/3” Sony Super HAD II High-resolution
Color CCD
• Resolution 600TVL-Lines
• 2.8~11mm Vari-focal DC Auto Iris F1.2
Day&Night Lens
• Built-in Function selection Dip Switch
- Day&Night/IR LED type: ICR switching
time, FLK, BLC, AWB
• Auto switching IR LED control by
photocell
- IR LED: 24 pcs
• Built-in DC Iris Level Adjustment Volume
• Easy Adjustment of Focal Length & Focus
• Built-in Service Monitor Port
• 3-Axis Gimbal bracket
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Synchronization
White Balance
Power Supply
Power Consumption
Operating Temperature
Operating Humidity
Dimension (mm)
CODE
KUDOM64
KUDOMH5IA
www.hesa.com
MODEL
DOMEC-4
DOMEHC-5IA
DIMENSIONS (mm)
DOMEC-4
DOMEHC-5IA
1/3” Coloror Sony Super HAD 1/3” Coloror Sony Super HAD II
(Hi-Res.)
(Hi-Res.)
752x582
600 TVL Color, 650 TVL B/W
0.2 lux (Color),
0 lux (IR-LED ON)
0.02 lux (B/W) @ F1.2
Vari-Focal 2.8~11mm/F1.2 DC Auto Iris D/N Lens
> 48dB
Internal
ATW1/ATW2/AWC/Manual
(ATW1: 2300~9500°K, ATW2: 2000~11000°K)
12VDC/24VAC
Max.: 8.4VA/AC24V
Max.: 5.1VA/AC24V,
(LED-IR on)
160mA/DC12V
380mA/DC12V
–10°C~+50°C
Max. 90% RH
122 Ø x 95 (H) (Dome: Ø 90)
DESCRIPTION
1/3”, Color Dome camera, 600 TVL, Vari-Focal, 12VDC/24VAC
1/3”, Color Dome camera, 600 TVL, Vari-Focal, 12VDC/24VAC
95
Ø122
Ø90
DOMEC-4 / DOMEHC-5IA
155
Color Cameras
Outdoor Dome Cameras
DOMEHC-3
380 TVL, Vandalproof, 12VDC
DOMEC-5
550 TVL, Vandalproof, 12VDC/24VAC
FEATURES
• Lens 3.6mm /F2.0 built-in
• Construction: aluminium for upper
housing, polycarbonate dome
FEATURES
• Varifocal Lens mm 2.8~11 /F1.2 built-in
• Dip switch control of Day & Night time
delay
• Vandal resistant & Weatherproof
housing (IP66)
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
Back Light Compensation (BLC)
Synchronization
Gain Control
White Balance
Vandalproof Housing
Power Supply
Power Consumption
IP Rating
Operating Temperature
Weight g
CODE
KUDOM69
KUDOM65
www.hesa.com
MODEL
DOMEHC-3
DOMEC-5
DIMENSIONS (mm)
DOMEHC-3
1/3” Color Sony Super HAD
(Hi-Res.)
500x582
380 TVL
0.2 lux @ F2.0
3.6mm/F2.0
DOMEC-5
1/3” Interline transfer
type color CCD (Sony)
752x582
550 TVL color
580 TVL B/W
0.3 lux Color,
0.03 lux B/W
mm 2.8~11/ F1.2
> 48dB
Auto 1/50~1/110.000sec
–
YES
–
Internal
AGC
–
YES (2500°K~9500°K)
ATW/AWC selectable
YES
12VDC
12VDC/24VAC
4.8VA (24VAC)
250mA
250mA (12VDC)
–
IP66
-10°C~+50°C
340
–
’ 104
67
DOMEHC-3
145
100
Ø145
DOMEC-5
DESCRIPTION
1/3”, Color Dome camera, 380 TVL, Vandalproof, 12VDC
1/3”, Color Dome camera, 550 TVL, Varifocal, Vandalproof, 12VDC/24VAC
CCTV PRODUCTS
156
Color Cameras
Outdoor Dome Cameras
DOMEHC-5E
600 TVL, Vari-Focal, Vandalproof IP66,
12VDC/24VAC
DOMEHC-5U
600 TVL, Vari-Focal, Vandalproof IP66,
12VDC/24VAC
FEATURES
• Vari-Focal Lens 2.8~11mm/F1.2
• Built-in DNR, Sens-up, D-zoom, OSD
function
• Color & B/W auto switchable by
photocell
• Easy adjustment of focal length & focus
• Built-in service monitor port & OSD
control port
• 3-Axis Gimbal bracket
• Flush & surface mount
• Vandal resistant & weatherproof
housing IP-66
DIMENSIONS (mm)
146
40
18
50
108
99 146
FEATURES
• 1/3” Sony Super HAD High-resolution
Color CCD
• 600TVL High-resolution
• Vari-Focal Lens 2.8~11mm/F1.2
• Built-in DNR, Sens-up, D-Zoom, OSD
function
• Color & B/W Auto switchable by
photocell
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Synchronization
White Balance
DOMEHC-5U
DNR Digital Noise Reduction
Digital Zoom
OSD Function Control
Power Supply
Power Consumption
116
Ø91
Ø158
DOMEHC-5E
• Easy Adjustment of Focal Length &
Focus
• Built-in Service Monitor & OSD Control
Port
• 3-Axis Gimbal Bracket
• Surface mount type
• Vandal Resistant & weatherproof
Housing (IP-66)
IP Rating
Operating Temperature
DOMEHC-5U
DOMEHC-5E
1/3” Color Sony Super HAD
752x582
600 TVL Color - 640 TVL B/W
- color: 0.4 lux/0.001lux (sens x256)
- B/W: 0.04 lux/0.0001lux (sens x256) @ F1.2, 50IRE
> 52dB
1/50~1/120000sec.
Internal
ATW1/ATW2/AWC/Manual
(ATW1: 2500~9500K/ATW2: 1800~10500K)
User, High, Middel, Low, Off selectable
x1~x10/x0.1 step
Built-in
12VDC/ 24VAC ±10%
180mA (12VDC)
200mA (12VDC)
4.5VA (24VAC)
5.8VA (24VAC)
IP66
-10°C~+50°C
CODE
KUDOMH5U
KUDOMH5E
MODEL
DOMEHC-5U
DOMEHC-5E
DESCRIPTION
1/3” Color Dome camera, 600 TVL, Vandalproof, IR LED, 12VDC/24VAC
1/3” Color Dome camera, D&N, 600 TVL, Vandalproof, 12VDC/24VAC
Accessori
KUDOMSP
KUDOMSA
DOME-SP
DOME-SA
Wall mount bracket (only for DOMEHC-5U)
Angle mount bracket (only for DOMEHC-5U)
www.hesa.com
DOME-SP
DOME-SA
157
Color Cameras
Outdoor Dome Cameras
DOMEHC-5
600 TVL, Vari-Focal, Vandalproof IP66,
IR LED, 12VDC/24VAC
DOMEHC-6
600 TVL, Vari-Focal, Vandalproof IP66,
IR LED, 12VDC/24VAC
FEATURES
• Vari-Focal lens 6~50mm/F1.4 built-in
• Day&Night DC auto iris
• DC iris control volume built-in
• 36 IR-LEDs, IR distance 30m
• Real 3-Axis gimbal bracket
• Flush & surface mount
• Service monitor output built-in
FEATURES
• Vari-Focal lens 2.8~10.5mm/F1.2
built-in
• Built-in DNR, sens-up, D-zoom, OSD
function
• Color & B/W auto switchable by
photocell
• Auto switching IR-LED control (36pcs)
• Easy adjustment of focal length & focus
• Built-in service monitor port & OSD
control port
DIMENSIONS (mm)
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
IR LED
Synchronization
Iris Control
Gain Control
White Balance
DNR Digital Noise Reduction
OSD Function Control
Power Supply
Power Consumption
IP Rating
Operating Temperature
Weight g
DOMEHC-5
DOMEHC-6
1/3” Color Sony Super HAD
752x582
600 TVL Color
600 TVL Color
650 TVL B/W
650 TVL B/W
0 lux (LED ON)
Vari-Focal 6~50mm/F1.4 Vari-Focal 2.8~10.5mm /F1.2
> 48dB (AGC OFF)
> 52dB (AGC OFF)
Auto 1/50~1/110.000sec
Auto 1/50~1/10.000sec
36
Internal
DC drive
–
AGC
–
ATW1/ATW2/AWC/Manual
ATW1/ATW2/AWC/Manual
(ATW1: 2300~9500°K/
(ATW1: 2500~9500°K/
ATW2: 2000~11000°K)
ATW2: 1800~10500°K)
User, High, Middel, Low
–
On/Off selectable
Off selectable
YES
Built-in
12VDC/ 24VAC ±10%
490mA (LED ON)
450mA (12VDC)
10.5VA (LED ON)
11VA (24VAC)
IP66
–10°C~+50°C
1014
–
146
108
99 146
DOMEHC-5 / DOMEHC-6
CODE
KUDOMH5
KUDOMH6
MODEL
DOMEHC-5
DOMEHC-6
DESCRIPTION
1/3” Color Dome camera, 600 TVL, Vandalproof, IR LED, 12VDC/24VAC
1/3” Color Dome camera, 600 TVL, Vandalproof, IR LED, 12VDC/24VAC
Accessori
KUDOMSP
KUDOMSA
DOME-SP
DOME-SA
Wall mount bracket
Angle mount bracket
www.hesa.com
40
18
50
DOME-SP
DOME-SA
CCTV PRODUCTS
158
Color Cameras
Outdoor Dome Cameras
DOME-WDR
600 TVL, Vari-Focal, Wide Dynamic,
Vandalproof IP66, 12VDC/24VAC
FEATURES
• Vari-Focal lens 2.8~11mm/F1.2 builtin
• High sensitivity 0.4lux (Color) 0.08 lux
(DSS ON)
• OSD function control
• Real 3-Axis Gimbal bracket
• Service monitor output built-in
• Vandalproof housing IP66
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Digital Slow Shutter
Wide Dynamic Range
Synchronization
Iris Control
Gain Control
White Balance
OSD Function Control
Power Supply
Power Consumption
IP Rating
Operating Temperature
CODE
KUDOMWD
www.hesa.com
MODEL
DOME-WDR
DIMENSIONS (mm)
DOME-WDR
1/3” Color Sony Double-Density Interline
720x540
600 TVL
0.4 lux color 0.08 lux (DSS ON)
> 50dB (AGC OFF)
1/50~1/30720sec.
OFF, x2~x32
102dB, max. 120db
Internal
DC drive
AGC
YES
YES
12VDC/ 24VAC
240mA
IP66
-10°C~+50°C
146
108
40
18
50
DOME-WDR
DESCRIPTION
1/3”, Color DSP Image Sensor (pixim), 600 TVL, Vari-Focal, Wide Dynamic, 12VDC/24VAC
99 146
159
Color Cameras
Indoor Miniature Cameras
TCC-F1
520 TVL, 12VDC
TCC-S1
420 TVL, 12VDC
TCC-30
380 TVL, 12VDC
FEATURES
• Halogen hole insert interior camera
• Built-in 12IR LEDS
•Clear image performance
FEATURES
• Minimum illumination of 0.1 lux/F2.0
• Built-in fixed hidden 3.7mm pinhole lens
FEATURES
• In-ceiling installation application
• Cone lens 3.7mm/F2.0, 90°, built-in
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
Synchronization
Gain Control
White Balance
Power Supply
Power Consumption
Weight g
TCC-F1
TCC-S1
1/3” Color Sony Super HAD
752x582
500x582
520 TVL
420 TVL
0.1 lux/F1.2 (0 lux/LED ON)
0.1 lux/F2.0
3.6mm
3.7mm, 92°
> 50dB (AGC OFF)
Auto 1/50~1/100.000sec
–
Internal
AGC
YES (2100°K~8200°K)
12VDC
90mA (12VDC)
110mA
–
DIMENSIONS (mm)
112
51
30
45
TCC-F1
CODE
KUTCCF1
KUTCCS1
KUTCC30
www.hesa.com
56
MODEL
TCC-F1
TCC-S1
TCC-30
TCC-30
75
DESCRIPTION
Halogen hole camera, 520 TVL, 12VDC
Sprinkler shaped camera, 420 TVL, 12VDC
1/3” In-Ceiling Color camera, 380 TVL, 12VDC
TCC-30
380 TVL
0.3 lux @ F1.2
3.7mm/F2.0, 90°
> 48dB
YES (2500°K~9500°K)
117mA
200
CCTV PRODUCTS
160
Color Cameras
Indoor Miniature Cameras
TCC-B3
350 TVL, 12VDC
TCC-P1
PIR Camera with built-in PIR, 380 TVL
FEATURES
• Mini bullet
• Board lens 4mm, built-in
• Bracket included
• Water resistant IP66
TCC-P2
PIR Camera with built-in PIR, 470 TVL
FEATURES
• Cone lens 3.7mm/F2.0 built-in
• Audio output
• Bracket included
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
Synchronization
Gain Control
White Balance
TCC-B3
TCC-P1
TCC-P2
1/3” Color Sony Super HAD
752x582
500x582
380 TVL
470 TVL
0.2 lux @ F2.0
0.3 lux @ F2.0
pinhole 3.7mm/F2.0
> 48dB
Auto 1/50~1/110.000sec
Internal
AGC
YES (2500°K~9500°K)
PIR sensor
512x582
350 TVL
0.3 lux @ F1.2
4mm /F1.2
Detection Range
Detection Angle
Relay Output
Alarm Time
–
Power Supply
Power Consumption
IP Rating
Operating Temperature
Weight g
10 m
H. 100°, V. 45°
N.C./N.O. 2A@30VDC
2~40sec (adjustable)
12VDC ±10%
200mA
180mA
IP66
-10°C~+50°C
172
–
DIMENSIONS (mm)
95
28
90
90
50
120
’ 40
’ 25
31
TCC-B3
CODE
KUTCCB3
KUTCCP1
KUTCCP2
www.hesa.com
70
48
TCC-P1 / TCC-P2
MODEL
TCC-B3
TCC-P1
TCC-P2
110mA
–
DESCRIPTION
1/3” Bullet Color camera, 350 TVL, 12VDC
1/3” PIR Color camera, 380 TVL, 12VDC
1/3” PIR Color camera, 470 TVL, 12VDC
72
173
161
Color Cameras
Miniature Board Camera
TLC-SC04
350 TVL, 12VDC
FEATURES
• Lens 3.6mm 92° built-in
• Back light compensation
DIMENSIONS (mm)
32.0
28.0
Ø
2.
2
24
16.4
1.2
4.2
TLC-SC04
CODE
KUHSVS4
MODEL
TLC-SC04
DESCRIPTION
1/3” Color Board camera, lens 3.6mm/F2.0, 92°
Accessories
KUHSO29
KUHSO36
KUHS43
KUHS60
KUHSP37
KUHSP60
SPV-OB2.9
SPV-OB3.6
SPV-4.3
SPV-6.0
SPV-P3.7
SPV-P6.0
Optional lens 2.9mm, 92°
Optional lens 3.6mm, 92°
Optional lens 4.3mm, 78°
Optional lens 6.0mm, 54°
Optional pinhole lens 3.7mm, 90°
Optional pinhole lens 6.0mm, 54°
www.hesa.com
4-
Ø 1 4 .0
TLC-SC04
1/3” Color Sony Super HAD
500x582
350 TVL
0.3 lux @ F1.2
3.6mm /F2.0, 92°
> 48dB
Auto 1/50~1/110.000sec
Internal
YES
YES
12VDC ±10%
150mA
-10°C~+50°C
50
Ø 1 6 .0
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Electronic Shutter
Synchronization
White Balance
Back Light Compensation (BLC)
Power Supply
Power Consumption
Operating Temperature
Weight g
28 .0
32 .0
SPECIFICATIONS
SPV-OB2.9
SPV-OB3.6
SPV-4.3
SPV-P6.0
SPV-P3.7
SPV-6.0
CCTV PRODUCTS
162
Color Cameras
Speed-Dome SD Series
SD-PTZ1
Speed-Dome, Day & Night, Zoom 10X,
Surface Mount
SD-PTZ1W
Outdoor Speed-Dome, Day & Night, Zoom
10X, Pole Mount
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
S/N Ratio
Zoom
Electronic Shutter
Gamma
IR LED
Synchronization
Iris Control
AGC
White Balance
SSNR
Pan/Tilt Speed
OSD Function Control
Power Supply
Power Consumption
IP Rating
Operating Temperature
Weight Kg
DIMENSIONS (mm)
SD-PTZ1
SD-PTZ1W
1/4” Interline transfer
752x582
540 TVL Color, 580TVL B/W
0.7 lux (color)/0.02 lux (B/W), 50 IRE
Vari-Focal 3.8~38mm/F1.8
> 50dB (AGC OFF)
x10 Optical zoom, x10 Digital zoom
1/50~1/120.000sec
selectable
36
Internal
Auto/Manual
Normal/High/Off
Auto/Manual (Red, Blue Gain Adjustable)
Pan: 360° (Endless)
Tilt: 180° (Auto-Flip), 95° (Normal)
Menu/PTZ information etc
12VDC
max. 0.8A @ 12VDC
max. 1.1A @ 12VDC
IP55
IP66
–0°C~+40°C
–30°C~+50°C
1.2
2.4
CODE
KUSDPTZ1
KUSDPTZ1W
MODEL
SD-PTZ1
SD-PTZ1W
DESCRIPTION
Speed-Dome, Day & Night, Zoom 10X, Surface Mount
Outdoor Speed-Dome, Day & Night, Zoom 10X, Pole Mount
Accessories
KUSDPTZT
KUSDPTZB
KUSDPTZBA
KUSDPTZBP
SD-PTZT
SD-PTZB
SD-PTZBA
SD-PTZBP
Remote Keyboard for SD-PTZ1 and SD-PTZ1W
Wall mount bracket (SD-PTZ1)
Corner bracket (SD-PTZ1W)
Pole bracket (SD-PTZ1W)
www.hesa.com
FEATURES
• CCD 1/4”
• Zoom 10X
• Privacy mask
• Communication interface RS485
• Flickerless
187
SD-PTZ1
’ 127
201
205
SD-PTZ1W
SD-PTZT
SD-PTZB
163
Color Cameras
Speed-Dome SD Series
Outdoor Models
SD-6HEA
540 TVL, D&N, 18X, Outdoor, 24VAC
Flush Mount Indoor Models
SD-6HI
540 TVL, D&N, 18X, Flush Mount, 24VAC
Surface Mount Indoor Models
SD-6HS
540 TVL, D&N, 18X, Surface Mount, 24VAC
SD-8HEB
700 TVL, D&N, 36X, Outdoor, 24VAC
SD-8HIB
700 TVL, D&N, 36X, Flush Mount, 24VAC
SD-8HSB
700 TVL, D&N, 36X, Surface Mount, 24VAC
SD-6H SERIES
• 1/4” Sony EX-View
• Day&Night + ICR
• 18X Optical zoom
• Heater, Fan, Power adapter
included (SD-6HEA)
SD-8H SERIES
• 1/4” Sony Super HAD II
• Day&Night + ICR
• 36X Optical Zoom
• Heater, Fan, Power adapter
included (SD-8HEB)
• Minimum Illumination
DIMENSIONS (mm)
300
306
238
225
213
10
110
84
60
41
140
160
191
251
10
’ 218
’ 152
’ 236
SD-6HEA / SD-8HEB
www.hesa.com
SD-6HI / SD-8HIB
’ 152
SD-6HS / SD-8HSB
CCTV PRODUCTS
164
Color Cameras
Speed-Dome SD Series
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Synchronization
Optical Lens
Digital Zoom Ratio
Viewing Angle (H)
Minimum Working Distance
Day&Night
Minimum Illumination
Electronic Shutter (ELC)
S/N Ratio
Gain Control
BLC Backlight Compensation
White Balance
AE Compensation
EV Compensation
Focusing System
Preset
Pan Range
OSD
Camera Control
Baud Rate
Protocols
Alarms
IP integration
Operating Temperature
Power Supply
Power Consumption
Manual Pan Speed
Tilt Range
Manual Tilt Speed
Preset Speeds
CODE
KUSD6HEA
KUSD6HI
KUSD6HS
KUSD8HEB
KUSD8HIB
KUSD8HSB
www.hesa.com
MODEL
SD-6HEA
SD-6HI
SD-6HS
SD-8HEB
SD-8HIB
SD-8HSB
SD-6H
1/4” Color SONY EX-View HAD
752x582
540 TVL
SD-8H
1/4” SONY Super HAD II (double Scan) CCD
1028x596
700 TVL
Internal/External V-lock
Zoom 18X, F = 4.1~73.8mm
Zoom 36X,
(F1.4~3.0)
F= 3.4~122.4mm F1.6~4.5)
12X
32X
(216X with Optical Zoom)
(432X with Optical Zoom)
57.8° (wide)
–
to 1.7° (tele)
–
320 mm (wide), to 1500 mm (tele)
YES, with ICR Filter
0.7 lux (F1.4, 1/50sec)
1.0 lux (F1.6, 1/50sec)
0.01 lux (F1.4, 1/3sec) ICR ON
0.01 lux (F1.6, 1/3sec) ICR ON
Auto: 1/50 ~ 1/10000sec ; Manual: 22 steps
>50dB
Auto/Manual (-3~28dB, 16 steps)
ON/OFF
Auto: (3000°K-7500°K) ATW (2000°K-10000°K), Indoor, Outdoor, One-push, Manual
Auto, Manual, Backlight Compensation, EV Compensation, Priority Mode, Bright
–10.5~+10.5dB (1.5dB Steps)
Auto (sensitivity normal, low) Manual, Infinity, Interval AF, Zoom Trigger AF
220 preset, 4 sequences each one with up to 32 preset dwell time
360° continuous; 0.1°~160°/sec.
YES, many languages
RS485/RS422, (Manchester, Biphase, Coaxitron)
2400/4800/9600/19200 bps
Pelco-P/D, VCL, Kalatel, Ernitec, Lilin, Vicon, Molynx, Diamond, Panasonic, Pelco-Coaxitron, AD, Philips, Sensornet
7 Alarm Inputs/2 Alarm Outputs
YES, board NET-CD1
-20°C~+60°C (Humidity 30%~90%)
24VAC ±10%, 50/60Hz
10W (Indoor), 50W (Outdoor)
0.5°~140°/sec
0.1°~160°/sec
90°, 0.1~160°/s
0.5°~140°/sec
0.1°~160°/sec
Pan>300°/sec, Tilt>300°/sec
Pan>360°/sec, Tilt>360°/sec
DESCRIPTION
Color Speed-Dome camera, Day&Night, 540 TVL, 18X, Outdoor
Color Speed-Dome camera, Day&Night, 540 TVL, 18X, Flush Mount Indoor
Color Speed-Dome camera, Day&Night, 540 TVL,18X, Surface Mount Indoor
Color Speed-Dome camera, Day&Night, 700 TVL,36X, Wide Dynamic, Outdoor
Color Speed-Dome camera, Day&Night, 700 TVL,36X, Wide Dynamic, Flush Mount Indoor
Color Speed-Dome camera, Day&Night, 700 TVL,36X, Wide Dynamic, Surface Mount Indoor
165
Color Cameras
Speed-Dome SD Series
CK-103
Remote keyboard for SD Speed-Domes
FEATURES
• Directly control fast Speed Domes
• Support up to 128 Speed Domes,
Cameras or receivers, 4 Remote
keyboards
• Real time clock generator built-in
• Firmware upgrade from PC via RS-232
port
• PTZ control
SD-ATB
Tracking Box for Speed PTZ Camera
FEATURES
• Highly compatible with normal high
speed PTZ cameras, with no affect on
the existing functions of the cameras
• Auto search and track on moving
object, with adjustable precision and
tracking state
• Auto return to home position/preset
and keep tracking after a
programmable interval when object is
out of adjustable area
• Independent OSD menu to display and
program camera
• Cost effective solution without extra
cost on the cameras
• Up to 4 alarm inputs
• Compact design and easy operation
• Auto actions (such as tracking, preset,
cruise etc.) on park
• Multi-protocols supported (such as
Pelco D/P) with adjustable baud rate
SPECIFICATIONS
Model
Interface
Baud Rate
Menu
Spectra Address
Protocols
Power
Accessories
KUSDSPEA
KUSDSSE
KUSDSPP
KUSDSAE
KUFCK12
KUFCK13
KUSDATB
KUSDPTPH
KUSDPTAD
KUSDPTPC
KUSDPTSN
KUSDPTBBV
KUSDNET1
KUSDNETH
KJCOWP1
KJCOWP2
www.hesa.com
SD-SPEA
SD-SSE
SD-SPP
SD-SAE
CK-102
CK-103
SD-ATB
PT-PH
PT-AD
PT-PC
PT-SEN
PT-BBV
NET-CD1
NET-CDH
CONV232-485/422
CONV232OPT
SD-ATB
RS485 (one to controller, the other to PTZ camera)
2400bps, 4800bps, 9600bps
OSD
0~255
Pelco D/P
9~12VDC
Aluminium wall mount bracket
Aluminium pendant mount bracket
Aluminium pole mount bracket
Aluminium corner mount bracket
Remote Keyboard for Speed-Dome SD Series and Multiplexer D9-X & D16-X
Remote Keyboard for Speed-Dome SD Series
Auto tracking box for SD Speed-Domes
Bi-Phase Protocol Board
American Dynamics Protocol Board
Pelco Coaxitron Protocol Board
Sensornet Board
BBV Module Protocol Board
Network Card MPEG4
Network Card H.264
RS-232 to RS-485 or RS-422 unpowered data converter
Optocoupled RS-232 to RS-485 or RS-422 data converter
(it requires 12VDC power supply)
SD-SSE
SD-SPEA
SD-SPP
SD-SAE
CK-102
NET-CD1
CCTV PRODUCTS
166
Camera Brackets
ST-02
ST-03
SPECIFICATIONS
Model
Length (mm)
Pan Range
Tilt Range
Baseplate (mm)
Maximum Load Capacity kg
Construction
Colour
Weight g
ST-02
160
ST-03
126
360°
± 110°
’ 89
4
ABS
’ 45
3
Aluminium
Ivory
250
200
DIMENSIONS (mm)
160
126
ST-02
CODE
KUST02
KUST03
www.hesa.com
ST-03
MODEL
ST-02
ST-03
DESCRIPTION
ABS Camera bracket, ivory colour
Aluminium Camera bracket, ivory colour
167
Outdoor Camera Housings
CUST-07V
CUST-08V
Polycarbonate Camera Housing, with sunshield
Polycarbonate Camera Housing, with sunshield
DIMENSIONS (mm)
270
FEATURES
• Indoor/Outdoor installations
• Polycarbonate construction
• Side opening
• Weatherproof IP66 with glands
• High resistance to impacts
70
70
70
466
113
77
= Usable Area
CUST-07V
SPECIFICATIONS
Model
Installation
Internal Usable Area (WxHxL)
Internal Usable Length with Heater &
Power Supply
Window (WxH)
Length (mm)
Cable Glands
Colour
Operating Temperature
IP Rating
Weight g
CODE
KUCUSTV
KUCUST8
MODEL
CUST-07V
CUST-08V
CUST-08V
Indoor/Outdoor
70x70x270mm
63x63x210mm
270mm
210mm
270mm
210mm
105x64mm
98x55mm
466mm
400mm
2xPG9 + 1xPG11
1xPG9 + 1xPG11
Ivory White
-20°C ~ +50°C (with Heater)
IP66 (With Cable Glands)
1500
700
CUST-07V
DESCRIPTION
Polycarbonate Camera Housing, with sunshield
Polycarbonate Camera Housing, with sunshield
Accessories
KUSUCUS
ST-CUST-2S
KUSUCUV
KURV24
ST-CUST-7V
RISCV-12-24
KURV230
RISCV-230
KUALCU8
KUALC7
KUCUCOL
ALXCUST-7V
ALXCUST-7V-24
COL-1S/2S
KUPVCF3
OHPVCF3
www.hesa.com
160
100
Wall Bracket with Cable Conduit for CUST-2S, CUST-07V,
CUST-08V
Wall Bracket for CUST-07V, CUST-08V
Heater Thermostatically Controlled, 12VDC/24VAC, 20W,
Ton 15°C±3°C Toff 22°C±3°C for CUST-07V, CUST-08V, CUST-2S
Heater Thermostatically Controlled, 230VAC, 40W,
Ton 15°C±3°C Toff 22°C±3°C for CUST-07V, CUST-08V, CUST-2S
Power Adapter 230VAC/12VDC, 1A, for CUST-07V, CUST-08V
Power Adapter 230VAC/24VAC, 400mA, for CUST-07V, CUST-08V
Pole Mount Bracket ’ 65~110mm for CUST-1, CUST-1S, CUST-2S,
CUST-07V, CUST-08V
Fan Cooling Kit
210
70
63
400
94 100
94
= Usable Area
15
15
18
128
CUST-08V
ST-CUST-2S
ST-CUST-7V
RISCV-12-24
RISCV-230
ALXCUST-7V
ALXCUST-7V-24
COL-1S/2S
OHPVCF3
CCTV PRODUCTS
168
Side opening technopolymer housing
CUST-9P
Side opening technopolymer housing
with 230VAC integrated heater
CUST-9PA
Side opening technopolymer housing
with 24VAC integrated heater
FEATURES
• IP66/IP67
• Suitable for a variety of combinations
of cameras and lenses
• Integrated heater
• Available accessories: sunshield and
camera power supply Internal usable
area (WxHxL): 70x70x250mm
(2.7x2.7x9.8in)
CUST-9PS
Side opening technopolymer housing
with 230VAC integrated heater and wall
bracket
CUST-9PAS
Side opening technopolymer housing
with 24VAC integrated heater and wall
bracket
FEATURES
• IP66/IP67
• Arranged for cable management bracket
• Suitable for a variety of combinations
of cameras and lenses
• Integrated heater
• Available accessories: sunshield and
camera power supply Internal usable
area (WxHxL): 70x70x250mm
(2.7x2.7x9.8in)
DIMENSIONS (mm)
60
391
57
101
95
70
250
70
= USEFUL AREA
CUST-9P / CUST-9PS / CUST-9PA / CUST-9PAS
SPECIFICATIONS
Model
Use
Internal dimensions
CUST-9P
- basis
- height
- length with heater and / or power
Window (BxH)
Total length
Glands
Operating Temperature
Heater supply
Bracket with cable
IP rating
Weight g
CODE
KUCUST9P
KUCUST9PS
KUCUST9PA
KUCUST9PAS
CUST-9PS
CUST-9PA
CUST-9PAS
Indoor / Outdoor
mm 70
mm 70
mm 250
60/95x63 mm
mm 391
2
–20°C ~ +60°C
230VAC
–
24VAC
YES
–
YES
600
1200
IP66 (with glands)
600
1200
MODEL
CUST-9P
CUST-9PS
CUST-9PA
CUST-9PAS
DESCRIPTION
Side opening technopolymer housing with 230VAC integrated heater
Side opening technopolymer housing with 230VAC integrated heater and wall bracket
Side opening technopolymer housing with 24VAC integrated heater
Side opening technopolymer housing with 24VAC integrated heater and wall bracket
CUST-9PT
ALXCUST-9P
ALXCUST-9P-24
Sunshield for CUST-9P
Power supply 230VAC/12VDC, 1A, for CUST-9P
Power supply 230VAC/24VAC, 400mA, for CUST-9P
CUST-9PT
Accessories
KUALCU9PT
KUALCU9P
KUALCU9PA
www.hesa.com
ALXCUST-9P
169
Cases External PoE Megapixel IP cameras
DIMENSIONS (mm)
163
100
412
AREA
UTILE
88
145
FEATURES
• HiPoE to power heater & network camera
• Integrated HiPoE splitter 24W, 12VDC
• Standard cable cat. 5e
• Compatible with IEEE 802.3at/PoE Plus
• Gigabit ready
• Arranged for cable management bracket
• Special cable gland for a fast Ethernet
connection/disconnection without cutting the RJ45 connector
• Indoor / Outdoor installations
• Side opening system, easy access to
the camera
• Weatherproof standard IP66/IP67
• Version with reinforced cooling system
• Internal usable area (WxHxL):
70x70x230mm (2.7x2.7x9.0in)
14
FEATURES
• HiPoE to power heater & network camera
• Integrated HiPoE splitter 24W, 12VDC
• Standard cable cat. 5e
• Compatible with IEEE 802.3at/PoE Plus
• Gigabit ready
• Arranged for cable management bracket
• Special cable gland for a fast Ethernet
connection/disconnection without cutting the RJ45 connector
• Indoor / Outdoor installations
• Side opening, easy camera servicing
• Weatherproof standard IP66/IP67
• Version with reinforced cooling system
• Internal usable area (WxHxL):
100x70x250mm (3.9x2.7x9.8in)
250
76
117.5
400
514
176
160
CUST-7VPOE
Polycarbonate case with side opening,
length 230 mm, with sunshield and heater 230VAC Integrated, PoE
70
CUST-2SPOE
Aluminum housing side opening, length
250 mm, with sunshield Hi-splitters and
PoE
SPECIFICATIONS
Model
use
Internal dimensions
CUST-2SPOE
- basis
- height
- length
Window
Window Dimensions mm
Total length
Glands
Color
Power supply HiPoE
Operating temperature
IP rating
Weight g
CUST-7VPOE*
Indoor / Outdoor
mm 100
mm 70
mm 70
mm 70
mm 250
mm 230
in vetro
in policarbonato
118x75
105x64
mm 514
mm 466
2xPG9 + 1xPG11
2xPG9 + 1xPG11
grigio
power injection PoE integrated 12VDC 24W
–20°C ~ +50°C
IP66
3100
1600
76
CUST-2SPOE
230
70
70
70
466
113
= USEFUL AREA
CUST-7VPOE
77
100
160
*Also available with heater 12VDC/24VAC
CODE
MODEL
KUCUS2SPOE CUST-2SPOE
KUCUSTVPOE CUST-7VPOE
DESCRIPTION
Aluminum housing side opening, with sunshield Hi-splitters and PoE
Polycarbonate case, PoE
Accessories
KUSUCUS
ST-CUST-2S
KUSUCUV
ST-CUST-7V
KUCUCOL
COL-1S/2S
Bracket for wall mounting with cable CUST-2SPOE, CUST-7VPOE
Bracket for wall mounting with cable CUST-7VPOE
Support Pole ’ mm 65~110, CUST-2SPOE, CUST-7VPOE
www.hesa.com
ST-CUST-2S
ST-CUST-7V
COL-1S/2S
CCTV PRODUCTS
170
CCTV Lenses
DESCRIPTION
Empowered by 50 years of optical expertise, TAMRON proceeds to open new horizons that change the concept of industrial optics.
Concentrating on meeting the demands of professionals in the field, TAMRON pioneered the Vari-Focal lens design and continues to
research new technologies in order to bring to market lenses that are compact and lightweight, high performance and high quality.
FEATURES
• Very comprehensive Lens program
Practically any application can be handled by TAMRON's wide selection of 1/3” and 1/2” format lenses that range from an ultra-wide
angle 2.2mm, which provides a 118° angle of view, to a 100mm ultra telephoto lens with a 2.8° angle of view.
• Outstanding Image Quality through the Employment of Aspherical Elements
The main TAMRON Vari-Focal lenses use aspherical elements in order to achieve
high re-solution and high contrast performance over the entire focal length range.
The designers paid particular attention to peripheral image quality in light of the
increasing use of these lenses with digital recorders that require image
degradation in the periphery be at an absolute minimum. The use of aspherical
elements also contributes to the compact design of the Vari-Focal lenses for which
TAMRON is well known.
Compensation effect with an aspherical lens element (Schematic Illustration)
• Wide Dynamic Range
The standard 3.0-8mm Vari-Focal lens for the 1/3" format, which meets the needs of
the most frequent job applications, offers an impressive maximum open aperture of
F/1.0 and F/360 minimum aperture. This wide dynamic range increases the versatility
of this lens since it can be used in situations where light conditions are extreme or
ever-changing.
• Compatible with Day/Night Cameras
TAMRON IR’s 1/3” format 2.2mm, 2.8mm, 4mm, 6mm and 8mm lenses are precisely
compatible with day/night cameras and designed to minimize focus shift in the near
infrared range by expanding chromatic aberration compensation to include both daylight
and the near infrared ranges. The lens therefore exhibits its power in 24-hour aroundthe-clock surveillance when combined with a day/night camera.
• High Quality Lens Series for maximum Mega-Pixel camera performance
Each lens in TAMRON’s Mega-Pixel-compatible Vari-Focal lens series uses hybrid
aspherical elements to minimize various optical aberrations and ensure high optical
quality while realizing the compact design. Through the employment of innovative
optical technologies, each lens delivers high-resolution and high-contrast images that
are uniformly sharp from the center to the periphery.
www.hesa.com
171
CCTV Lenses
1/3” - Manual Iris, Vari-Focal Lenses
Vari-Focal
Articolo
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Mount
Colour
Focus
Dimensions (mm)
Weight g
13VM2812ASII
2.8÷12
Wide 97°x73°
Tele 24°x18°
F1.4~C
13VM550TASII
5÷50
Wide 54°x40°
Tele 6°x4°
F1.4~C
CS
Black
Manual with Lock
’ 44x60
84
’ 44x60
72
13VM20100ASII
20÷100
Wide 14°x10°
Tele 3°x2°
F1.6~C
’ 49x110
148
DIMENSIONS (mm)
13
(in aria)
1-32UNF
(Passo CS)
q40
q44
60
13VM2812ASII
CODE
KUTDM12
KUTDMV5
KUTDMV1
www.hesa.com
MODEL
13VM2812ASII
13VM550TASII
13VM20100ASII
13VM550TASII
DESCRIPTION
1/3” Manual Vari-Focal lens, 2.8÷1 mm, F1.4~C
1/3” Manual Vari-Focal lens, 5÷50mm, F1.4~C
1/3” Manual Vari-Focal lens, 20÷100mm, F1.6~C
4
30
5
q44
4
1-32 UNF
(Passo CS)
q41
55
q41
(5)
(MAX)
13
(in aria)
13
(in aria)
13VM20100ASII
CCTV Lenses
1/3” - Manual Iris, IR Lenses
Mono Focal
Model
Focal Length (mm)
Angle of View (HxV)
Aperture Range (C=Close)
Mount
Colour
Focus
Dimensions (mm)
Weight g
13FM22IR
2.2
118.6°x90.0°
13FM28IR
2.8
93.2°x70.7°
’ 37x38
41
36
13FM04IR
13FM06IR
4
6
65.6°x49.7°
46.5°x34.6°
F1.2~C
CS
Black
Manual with Lock
’ 37x36
33
32
13FM08IR
8
34.5°x25.7°
33
DIMENSIONS (mm)
13FM22IR
35
13
(in AIR)
www.hesa.com
www.hesa.com
1-32 UNF
(CS Mount)
q29
q34
q37
1-32 UNF
(CS Mount)
q29
q34
13
(in AIR)
4
13FM08IR
13FM06IR
MODEL
13FM22IR
13FM28IR
13FM04IR
13FM06IR
13FM08IR
DESCRIPTION
1/3” Manual Iris, IR Mono-Focal lens, Wide, 2.2mm, F1.2~C
1/3” Manual Iris, IR Mono-Focal lens, Wide, 2.8mm, F1.2~C
1/3” Manual Iris, IR Mono-Focal lens, Standard, 4mm, F1.2~C
1/3” Manual Iris, IR Mono-Focal lens, Tele, 6mm, F1.2~C
1/3” Manual Iris, IR Mono-Focal lens, Tele, 8mm, F1.2~C
1-32 UNF
(CS Mount)
q29
q34
q37
13FM04IR
4
13
4
13FM28IR
35
CODE
KUTM1IR
KUTM2IR
KUTM4IR
KUTM6IR
KUTM8IR
35
13
(in AIR)
1-32 UNF
(CS Mount)
4
29
35
q37
CCTV PRODUCTS
172
173
CCTV Lenses
1/3” - Manual Iris, IR, Vari-Focal Lenses
Vari-Focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Mount
Colour
Focus
Dimensions (mm)
Weight g
13VM2811ASIR
2.8÷11
Wide 97.4°x72.4°
Tele 26.2°x19.7°
F1.4~C
’ 44x59
72
13VM308ASIRII
3.0÷8
Wide 92.5°x68°
Tele 35.7°x26.8°
F1.0~C
CS
Black
Manual with Lock
’ 36x43
39
13VM1040ASIR
10÷40
Wide 37.5°x27.5°
Tele 9.2°x7.0°
F1.4~C
’ 39x67
80
DIMENSIONS (mm)
4
13VM2811ASIR
CODE
KUTDMIR
KUTDMVI6
KUTDMV4
www.hesa.com
MODEL
13VM2811ASIR
13VM308ASIRII
13VM1040ASIR
39
13VM308ASIRII
DESCRIPTION
1/3” Manual Iris, Vari-Focal IR lens, 2.8÷11mm, F1.4~C
1/3” Manual Iris, Vari-Focal IR lens, 3.0÷8mm, F1.0~C
1/3” Manual Iris, Vari-Focal IR lens, 10÷40mm, F1.4~C
13VM1040ASIR
13
(in AIR)
43
67
13
(in AIR)
30
4
1-32 UNF
(CS Mount)
55
1-32UNF
(CS Mount)
(4)
(MAX)
CCTV Lenses
1/3” - DC Iris (AI w/o Control Circuit) Lenses
Vari-Focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Connector
Mount
Colour
Focus
Dimensions (mm)
Weight g
13VG2812AS
2.8÷12
Wide 97°x73°
Tele 24x18°
F1.4~360
13VG550T
13VG20100AS
5÷50
20÷100
Wide 54°x40°
Wide 14°x10°
Tele 6°x4°
Tele 3°x2°
F1.4~185
F1.6~360
D4 - 4 pin Square Connector
CS
Black
Manual with Lock
’ 41x60
’ 49x110
95
156
’ 40x59
79
DIMENSION (mm)
13
(in AIR)
30
1-32 UNF
(CS Mount)
q41
5
q41
1-32UNF
(CS Mount)
4
33
55
q40
(5)
(MAX)
13
27
CCTV PRODUCTS
174
(in AIR)
4
25
27
13VG2812AS
CODE
KUTIG12
KUTIGV9
KUTIGV5
KUTIGV1
www.hesa.com
60
13VG550T
MODEL
13VG2812AS
13VG308AS
13VG550T
13VG20100AS
DESCRIPTION
1/3” DC Iris, Vari-Focal lens, 2.8÷12mm, F1.4~360
1/3” DC Iris, Vari-Focal lens, 3.0÷8mm, F1.0~360
1/3” DC Iris, Vari-Focal lens, 5÷50mm, F1.4~185
1/3” DC Iris, Vari-Focal lens, 20÷100mm, F1.6~360
13
(in AIR)
13VG20100AS
175
CCTV Lenses
1/3” - DC Iris (AI w/o Control Circuit), IR, Lenses
Mono Focal
Model
Focal Length (mm)
Angle of View (HxV)
Aperture Range (C=Close)
Connector
Mount
Colour
Focus
Dimensions (mm)
Weight g
13FG22IR
2.2
118.6°x90.0°
13FG28IR
2.8
93.2°x70.7°
’ 34X38
49
44
13FG04IR
13FG06IR
4
6
65.6°x49.7°
46.5°x34.6°
F1.2~360
D4 - 4-pin Square Connector
CS
Black
Manual with Lock
’ 34X35
40
38
13FG08IR
8
34.5°x25.7°
40
DIMENSION (mm)
(in AIR)
(CS Mount)
(CS Mount)
(in AIR)
13FG22IR
13FG28IR
(in AIR)
(CS Mount)
(CS Mount)
(in AIR)
13FG06IR
CODE
KUTG1IR
KUTG2IR
KUTG4IR
KUTG6IR
KUTG8IR
www.hesa.com
13FG08IR
MODEL
13FG22IR
13FG28IR
13FG04IR
13FG06IR
13FG08IR
13FG04IR
DESCRIPTION
1/3” DC Iris, IR lens, Wide, 2.2mm, F1.2~360
1/3” DC Iris, IR lens, Wide, 2.8mm, F1.2~360
1/3” DC Iris, IR lens, Standard, 4mm, F1.2~360
1/3” DC Iris, IR lens, Tele, 6mm, F1.2~360
1/3” DC Iris, IR lens, Tele, 8mm, F1.2~360
CCTV Lenses
1/3” - DC Iris (AI w/o Control Circuit), IR, Lenses
Vari-Focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Connector
Mount
Colour
Focus
Dimensions (mm)
Weight g
13VG2811ASIR
2.8÷11
Wide 97.4°x72.4°
Tele 26.2°x19.7°
F1.4~360
’ 40x59
79
13VG308ASIRII
3.0÷8
Wide 92.5°x68°
Tele 36.7°x26.8°
F1.0~360
D4 - 4-pin Square Connector
CS
Black
Manual with Lock
’ 33X43
45
13VG1040ASIR
10÷40
Wide 37.5°x27.5°
Tele 9.2°x7.0°
F1.4~360
’ 39X67
89
DIMENSIONS (mm)
39
1-32UNF
(CS Mount)
4
31
4
(4)
(MAX)
(27)
55
13VG2811ASIR
CODE
KUTIGIR
KUTIGVI6
KUTIGV4
www.hesa.com
MODEL
13VG2811ASIR
13VG308ASIRII
13VG1040ASIR
13
(in AIR)
32
13VG308ASIRII
DESCRIPTION
1/3”, DC Iris, Vari-Focal IR lenses, 2.8÷11mm, F1.4~360
1/3”, DC Iris, Vari-Focal IR lenses, 3.0÷8 mm, F1.0~360
1/3”, DC Iris, Vari-Focal IR lenses, 10÷40mm, F1.4~360
13VG1040ASIR
13
(in AIR)
1-32 UNF
(CS Mount)
30
67
27
CCTV PRODUCTS
176
177
CCTV Lenses
1/3” - Video Auto Iris (w. Control Circuit) Lenses
Mono focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range
Connector
Mount
Colour
Focus
Dimensions (mm)
Weight g
13FA28T
2.8
13FA04T
4
13FA08T
8
95°x72°
66°x50°
35°x26°
F1.4~125
F1.2~125
D4 - 4 pin Square Connector
CS
Black
Manual with Lock
’ 43x46
73
F1.2~150
79
70
DIMENSION (mm)
13FA28T
CODE
KUTIV28
KUTIV40
KUTIV80
www.hesa.com
q38
24
24
3
31
12
4
3
13FA04T
MODEL
13FA28T
13FA04T
13FA08T
13
(in aria)
34
34
24
46
1-32 UNE
(Passo CS)
q43
q38
q38
34
13
(in aria)
1-32 UNE
(Passo CS)
q43
46
13
(in aria)
1-32 UNE
(Passo CS)
q43
46
DESCRIPTION
1/3” wide Angle lens, mm 2.8, F1.4~125
1/3” normal lens, mm 4, F1.2~125
1/3” tele, mm 8.0, F1.2~150
31
12
3
4
13FA08T
31
12
4
CCTV Lenses
1/3” - Video Auto Iris (w. Control Circuit) Lenses
Vari-Focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Connector
Mount
Colour
Focus
Dimensions (mm)
Weight g
13VA2812AS
13VA550T
2.8÷12
5÷50
Wide 97.4°x72.5°
Wide 53.6°x40.3°
Tele 24.1°x18.1°
Tele 5.6°x4.2°
F1.4~360
F1.4~185
D4 - 4-pin Square Connector
CS
Black
Manual with Lock
’ 40x60
’ 41x59
82
101
DIMENSION (mm)
1-32 UNF
(CS Mount)
q41
13
(in AIR)
q41
4
37
55
1-32UNF
(CS Mount)
q40
(5)
(MAX)
32
CCTV PRODUCTS
178
4
28
31
13VA2812AS
CODE
KUTIV12
KUTIVV5
www.hesa.com
59
13
(in AIR)
13VA550T
MODEL
13VA2812AS
13VA550T
DESCRIPTION
1/3” Video Auto Iris, Vari-Focal lens, 2.8÷12mm, F1.4~360
1/3” Video Auto Iris, Vari-Focal lens, 5÷50mm, F1.4~185
179
CCTV Lenses
1/3” Ultra High Definition MEGAPIXEL Lenses
FEATURES
• High Quality lens series for maximum
Mega-Pixel camera performance
• Multiple-Layer coatings
• Highly Accurate and High Quality
mechanical construction to achieve
maximum performance
• Covers Wide range from 2.4mm Ultra
Wide-angle to 50mm Telephoto
• Lock mechanism for each control ring
• Slip-Mount mechanism
• Wide Dynamic range up to the maximum aperture of F/1.0
Vari-Focal
Articolo
M13VM246
M13VG246
M13VM308
M13VG308
M13VM550
M13VG550
Focal Length (mm)
2.4÷6
3.0÷8
5.0÷50
Angle of View
Wide 111°x84°
Wide 93°x69°
Wide 54°x40°
(Horizontal x Vertical)
tele 47°x35°
tele 35°x27°
tele 6°x4°
Aperture Range (C=Close)
F1.2~C
F1.2~360
F1.0~C
F1.0~360
F1.4~C
F1.4~360
Iris
Manual
DC Auto Iris
Manual
DC Auto Iris
Manual
DC Auto Iris
Connector
4-pin Square Connector
Mount
CS
Colour
Black
Focus
Manual with lock
Focus range
0.3m - '
1m - '
Zoom
Manual with lock
Operating temperature
-20°C~+60°C
Dimensions (mm)
’ 43x58
’ 43x55
’ 46x60
Weight g
65
75
64
74
64
77
M13VM288IR M13VG288IR
2.8÷8
Wide 100°x73°
tele 33°x25°
F1.2~C
F1.2~360
Manual
DC Auto Iris
0.3m - '
’ 40x55
n.d.
n.d.
DIMENSIONS (mm)
51.33
4
12.5
(in AIR)
(3.1)
(MAX)
M13VM246
3 G
4
12.5
(in AIR)
M13VM308
4
ø 3 1 .8
ø 41
1 -3 2 U N F
60.2
( C S M o unt )
ø 46
ø 40
ø 3 3 .6
ø 4 0 .8
1 -3 2 U N F
51.33
( C S M o unt )
ø 4 3 .2
ø 40
ø 3 3 .6
ø 4 0 .8
1 -3 2 U N F
ø 4 3 .2
ø 40
(6.3)
(MAX)
( C S M o unt )
(4.725)
12.5
(in AIR)
M13VM550
6
M 13VG 550
(6.3)
(MAX)
(24.6)
www.hesa.com
4
(3.1)
(MAX)
51.33
4
12.5
(in AIR)
M13VG308
MODEL
M13VM246
M13VG246
M13VM308
M13VG308
M13VM550
M13VG550
M13VM288IR
M13VG288IR
60.2
DESCRIPTION
1/3” MegaPixel Manual Iris, Vari-Focal lens, 2.4÷6mm, F1.2~C
1/3” MegaPixel DC Iris, Vari-Focal lens, 2.4÷6mm, F1.2~360
1/3” MegaPixel Manual Iris, Vari-Focal lens, 3.0÷8mm, F1.0~C
1/3” MegaPixel DC Iris, Vari-Focal lens, 3.0÷8mm, F1.0~360
1/3” MegaPixel Manual Iris, Vari-Focal lens, 5÷50mm, F1.4~C
1/3” MegaPixel DC Iris, Vari-Focal lens, 5÷50mm, F1.4~360
1/2” MegaPixel Manual Iris, Vari-Focal lens, 2.8÷8mm, F1.2~C
1/2” MegaPixel DC Iris, Vari-Focal lens, 2.8÷8mm, F1.2~360
M13VG550
4
12.5
(in AIR)
ø 3 1 .8
ø 42
1 -3 2 U N F
( C S M o unt )
ø 46
ø 40
ø 3 3 .6
ø 4 0 .8
1 -3 2 U N F
( C S M o unt )
ø 4 3 .2
ø 40
12.5
(in AIR)
(24.6)
M13VG246
CODE
KUTMM26
KUTMG26
KUTMM38
KUTMG38
KUTMM55
KUTMG55
KUTMM28
KUTMG28
51.33
31
32
32
ø 3 3 .6
ø 4 0 .8
1 -3 2 U N F
ø 4 3 .2
ø 40
( C S M o unt )
(4.725)
CCTV PRODUCTS
180
CCTV Lenses
1/2” Ultra High Definition MEGAPIXEL Lenses
FEATURES
• High Quality lens series for maximum
Mega-Pixel camera performance
• Multiple-Layer coatings
• Highly Accurate and High Quality
mechanical construction to achieve
maximum performance
Vari-Focal
Articolo
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Iris
Connector
Mount
Colour
Focus
Focus range
Zoom
Operating temperature
Dimensions (mm)
Weight g
M12VM412
M12VG412
4.0÷12
Wide 100°x73°
tele 33°x25°
F1.4~C
Manual
F1.4~360
DC Auto Iris
4-pin Square Connector
C
CS
Black
Manual with lock
0.3m - '
Manual with lock
-20°C~+60°C
’ 40x55
59
69
DIMENSIONI (mm)
M12VM412
CODE
KUT12MM4
KUT12MG4
www.hesa.com
M12VG412
MODEL
M12VM412
M12VG412
DESCRIPTION
1/2” MegaPixel Manual Iris, Vari-Focal lens, 4.0÷12mm, F1.4~C
1/2” MegaPixel DC Iris, Vari-Focal lens, 4.0÷12mm, F1.4~C
• Covers Wide range from 2.4mm Ultra
Wide-angle to 50mm Telephoto
• Lock mechanism for each control ring
• Slip-Mount mechanism
• Wide Dynamic range up to the maximum aperture of F/1.0
181
CCTV Lenses
1/3” - Motorized Zoom Lens
Vari-Focal
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Connector
Iris
Mount
Colour
Focus
13ZG10X6CT
6-60 (10X)
Wide 43.4°x32.7°
Tele 4.5°x3.4°
F1.4~360
–
DC Auto
CS
Black
Range (Motorized)
1.2m-'
’ 70x70x113
380
Dimensions (mm)
Weight g
DIMENSIONS (mm)
1-32 UNF
(CS Mount)
q59
70
q54
70
13
(in AIR)
4
37
M52 P0.75
113
9
13ZG10X6CT
CODE
KUTZG66
www.hesa.com
MODEL
13ZG10X6CT
DESCRIPTION
1/3” Motorized Zoom Lens, 10X, 6÷60mm, F1.4~360
CCTV Lenses
1/2” - Manual Iris, DC Iris lenses, Zoom Lenses
SPECIFICATIONS
Model
Focal Length (mm)
Angle of View
(Horizontal x Vertical)
Aperture Range (C=Close)
Iris
Connector
Mount type
Colour
Focus
Dimensions (mm) WxHxD
Weight g
12FA04CST
4
12FA06CST
6
87°x66°
60°x45°
F1.4~150
F1.4~150
YES
CS
’ 43x46
78
76
12FA12CST
12
12VM1040ASIR
12VG1040ASIR
10-40
Wide 37.5°x27.5°
31°x23°
Tele 9.2°x7.0°
F1.4~200
F1.4~C
F1.4~360
Manual with Lock
DC Iris
D4 - 4-pin Square Connector
C
Black
Manual with Lock
’ 39x62
79
77
87
12ZG10X8CT
8-80 (10X)
Wide 44.1°x33.2°
Tele 4.6°x3.5°
F1.8~360
DC Iris
Motorized
70x70x108
380
DIMENSIONS (mm)
24
24
3
31
12
3
31
12
3
12
18
(in aria)
39
4
32
1-32 UNF
(C)
30
62
43
31
12FA12CST
18
(in aria)
1-32 UNF
(Passo C)
30
39
4
q38
4
12FA06CST
62
13
(in aria)
24
4
12FA04CST
46
34
q38
34
q38
13
(in aria)
1-32 UNE
(Passo CS)
q43
46
1-32 UNE
(Passo CS)
q43
13
(in aria)
1-32 UNE
(Passo CS)
q43
46
34
CCTV PRODUCTS
182
32
12VM1040ASIR
CODE
KUT1204
KUT1206
KUT1212
KUT12M4
KUT12G4
KUTZG88
12VG1040ASIR
MODEL
12FA04CST
12FA06CST
12FA12CST
12VM1040ASIR
12VG1040ASIR
12ZG10X8CT
DESCRIPTION
1/2”, mm 4.5, F1.4.~150
1/2”, mm 6, F1.4~150
1/2”, mm 12, F1.4~200
1/2” Manual Iris, Vari-Focal IR Lens, 10÷40mm, F1.4~C
1/2” DC Vari-Focal IR Lens, 10÷40mm, F1.4~360
1/2” Motorized Zoom Lens, 10X, 8÷80mm, F1.8~360
25.5-PL
Polarizer filter for CCTV C-mount lenses ’ mm 25
12ZG10X8CT
Accessories
KUTPL25
www.hesa.com
25.5-PL
4
183
Color LCD TFT Monitors
MTLCD-5A
5.6”, LCD TFT
MTLCD-57
7”, LCD TFT (16:9)
MTLCD-5U
10.4”, LCD TFT
SPECIFICATIONS
Model
Size
Display pixel
Brightness
Contract Ratio
View Angle
Response time
OSD
Input/analogic outputs
Power supply
Power consumption
Operating Temperature
Dimension
Weight g
Included accessories
CODE
KUMLCD5A
KUMLCD57
KUMLCD5U
www.hesa.com
MODEL
MTLCD-5A
MTLCD-57
MTLCD-5U
MTLCD-5A
5.6”, mm 113x85
960x234
MTLCD-57
7” (16:9)
1440x234
200 cd/m2
150:1
±90°/±20°
MTLCD-5U
10.4”, mm 211x158
800x600
350 cd/m2
400:1
150°
12ms
±65°/±55°
15ms
Color, Tint, Brightness, Contrast and Mirror
2x input video RCA
2x input video RCA
1x input audio RCA (mono)
2x input audio RCA (mono)
12/24VAC ±10%
12VAC ±10%
9W
10W
0°C ~ +60°C
155x105x25
177x116x28
267x194x38
390
450
2000
remote control, mounting bracket, power supply 230VAC/12VDC
DESCRIPTION
5.6”, LCD TFT Color Monitor
7”, LCD TFT Color Monitor
10.4”, LCD TFT Color Monitor
CCTV PRODUCTS
184
Color LCD TFT Monitors
MTLCD-6A
15”, LCD TFT High resolution, audio
MTLCD-7A
17”, LCD TFT High resolution, audio
FEATURES
• High Breightness, Wide Viewing Angle,
High Contrast Ratio, High Stability
• VESA wall mounting
• Multimedia speakers
• 3D Comb filter to reduce signal noise
MTLCD-8A
19”, LCD TFT High resolution, audio
SPECIFICATIONS
Model
Size
Display pixel
Pixel Pitch (mm)
Brightness
Contrast Ratio
View Angle
Response Time
OSD
Input connector digital signal
Input/analogic outputs
Speaker
Power Supply
Power Consumption
Operating Temperature
Dimension
Weight g
Included accessories
Remote control
CODE
KUMLCD6A
KUMLCD7A
KUMLCD8A
www.hesa.com
MODEL
MTLCD-6A
MTLCD-7A
MTLCD-8A
MTLCD-6A
15”, mm 304x228
1024x768 VGA/SVGA/XGA
0.297x0.297mm
250 cd/m2
700:1
MTLCD-7A
MTLCD-8A
17”, mm 338x270
19”, mm 376x301
1280x1024 VGA/SVGA/XGA, SXGA
0.264x0.264mm
0.294x0.294mm
300 cd/m2
800:1
±80° / ±80°
8ms
5ms
5ms
Picture Mode, Contrast, Brightness, Color, Tint, Sharpness, Color Temp, DNR
1 input HDMI
2 input video BNC
2 output video BNC, bypass
1 input VGA
2 input + 2 audio output stereo RCA
2 x 2.5W
100~240VAC 50Hz
35W max., in “ON” Mode <5W in “Power saving” Mode (240VAC)
5°C ~ 40°C, storage -25°C ~ 60°C
340x370x190
370x380x190
420x425x190
2600
3300
3800
Power Supply 230VAC/12VDC
YES
DESCRIPTION
15” LCD TFT Color Monitor, High resolution
17” LCD TFT Color Monitor, High resolution
19” LCD TFT Color Monitor, High resolution
185
Color LCD TFT Monitors
MTLCD-11A
22”, LCD TFT High resolution, audio
MTLCD-9A
26”, LCD TFT High resolution, audio
MTLCD-10A
32”, LCD TFT High resolution, audio
SPECIFICATIONS
Model
Size
Display pixel
Pixel Pitch (mm)
Brightness
Contrast Ratio
View Angle
Response Time
OSD
Input connector digital signal
Input/analogic outputs
Speaker
Power Supply
Power Consumption
Operating Temperature
Dimensions (mm)
Weight g
CODE
KUMLCD11A
KUMLCD9A
KUMLCD10A
MODEL
MTLCD-11A
MTLCD-9A
MTLCD-10A
MTLCD-11A
MTLCD-9A
MTLCD-10A
22”, mm 437x296
26”, mm 575x363
32”, mm 698x392
1680x1050
1366x768
0.282x0.282mm
0.421x0.421mm
0.510x0.510mm
500 cd/m2
300 cd/m2
1000:1
800:1
1000:1
±160° / ±170°
±160° / ±160°
±178° / ±178°
5ms
8ms
6ms
Picture Mode, Contrast, Brightness, Color, Tint, Sharpness, Color Temp, DNR
1 input HDMI
2 input video BNC
2 output video BNC
1 input VGA
2 input RCA, 1 audio PC input
2 x 2.5W
2 x 1.5W
100~240VAC
40W
100W
120W
5°C ~ +40°C
510x420x190
631x387x89
765x464x101
4900
9000
14000
DESCRIPTION
22”, LCD TFT Color Monitor, High resolution
26”, LCD TFT Color Monitor, High resolution
32”, LCD TFT Color Monitor, High resolution
Accessories
KUMLCD10ST MTLCD-10ST
www.hesa.com
Mounting bracket for MTLCD-10A
MTLCD-10ST
CCTV PRODUCTS
186
Color LCD TFT Monitors
Touch screen series
FEATURES
• Ultra long life design for surveillance
use
• Mini-jack connector audio-in
• Support VESA 75*75 wall mount kit 1+
• Support up to 1280 x 1024 SXGA high
resolution
• DVI-I input
• High Contrast ratio
• 4 watts stereo speakers with amplifier
included
• Low power consumption
• Type: Five-Wire Analog Resistive
• Input interface: USB
• Capable with Windows XP, Vista, Linux
MTLCD-7TS
17” “Touch screen” color monitor LCD
TFT, High resolution
MTLCD-8TS
19” “Touch screen” color monitor LCD
TFT, High resolution
SPECIFICATIONS
Model
Size
Display pixel
Pixel Pitch
Brightness
Contrast Ratio
Response Time
OSD control
Input connector digital signal
Analogic input
Speaker
Power Input
Operation temperature
Dimension (mm)
Weight g
CODE
KUMLCD7TS
KUMLCD8TS
www.hesa.com
MODEL
MTLCD-7TS
MTLCD-8TS
MTLCD-7TS
17”, mm 338 x 270
MTLCD-8TS
19”, mm 336 x 301
1280 x 1024 (SXGA)
0.264 x 0.264 mm
0.294 x 0.294 mm
300cd/ m2
800:1
1000:1
5 ms
Auto Config, Brightness, Contrast, Color-temp, Position, Image Quality, menu
DVI-I
1xVGA, 1x mini-jack
2 x 2W Speaker with Amplifier
110V~240VAC
0°C ~ +50°C
395 x 385 x 170
5150
5350
DESCRIPTION
17” “Touch screen” color monitor LCD TFT, high resolution
19” “Touch screen” color monitor LCD TFT, high resolution
187
Video Testers
MTVTK
4”, LCD Video Test Kit
SPECIFICATIONS
Model
LCD Panel
Display pixel
Brightness
Contrast Ratio
Input/analogic outputs
Power Supply
Power Consumption
Operating Temperature
Dimensions (mm)
Weight g
Included accessories
MTVTK
4”, mm 82x62
480x234
250 cd/m2
150:1
1x video RCA
1x s- video Y/C
1x audio stereo RCA
1x output audio minijack
12VDC
5W
0°C to +60°C
139x115x36
1360
Rechargeable Battery, bag,
RCA/BNC adaptor
SDTS-1
CCTV video field monitor with 2.5”
TFT LCD
PRESTAZIONI
• Brightness, contrast, chroma
adjustable
• With 2400 bps, 4800 bps, 9600 bps,
19200 bps communication baud rate
selectable via OSD menu
• With Pelco-D, Pelco-P etc. protocols
selectable via OSD menu, strong
compatibility with most of the PTZ
cameras, Pelco-Coaxitron added, make
testing easier for connecting only
video cable to transmit both video and
digital signal
• Can display the PTZ camera OSD menu
and set all the PTZ functions with up,
down, left right direction key and Iris
open, close, focus, far, near, zoom tele
wide keys for the PTZ control
CODE
KUMVTK
KUSDTS1
www.hesa.com
MODEL
MTVTK
SDTS-1
DESCRIPTION
4”, LCD Video Test Kit
CCTV video field monitor with 2.5” TFT LCD
• Receive PTZ code so that user can
analyze the PTZ command
• With a RJ45 testing terminal
(equipped in the package), can test
the network cable status, LED display
and wrong information display on the
screen for 8 pins connection
• Can test the RS485 data cable
polarity, display on the LCD screen
with + or -
CCTV PRODUCTS
188
IR illuminators
IR-E01A
m16, 50W
IR-E02
m 50, 300W
IR-E01
m20, 50W
IR-E04
m 100, 300W
SPECIFICATIONS
Model
Distance (m)
H. V. Angle
Power Supply
Power consumption
Construction
Installation
IP Rating
Operating Temperature
Accessories Included
Dimensions (mm) WxHxD
Weight g
CODICE
KUIRE01A
KUIRE01
KUIRE02
KUIRE04
DIMENSION (mm)
IR-E01A
16
40°
IR-E01
20
10°
IR-E02
50
40°
12VAC
50W, 4.2A
IR-E04
100
12° Spot
230VAC
300W, 1.4A
black aluminum
Outdoor
IP66
–20°C ~ +60°C
–
108x125x146
900
IP64
–10°C ~ +50°C
steel mounting bracket included
250x300x280
2900
IR-E01A / IR-E01
ARTICOLO
IR-E01A
IR-E01
IR-E02
IR-E04
DESCRIZIONE
IR Outdoor Illuminator, 12VAC 50W, 40°, m16, IP66
IR Outdoor Illuminator, 12VAC 50W, spot 10°, m20, IP66
IR Outdoor Illuminator, 230VAC 300W, m 50
IR Outdoor Illuminator, 230VAC 300W, 100m Spot Light
TIR-E02
Electronic Power Adapter 230VAC/12VAC for IR-I01, IR-E01 and IR-E03 IR
Illuminators, 100W Power
Accessori
KUTRE02
www.hesa.com
TIR-E02
189
Quad Processors
QC-01
Color Quad Processor, Alarm Input
QC-03
Color Quad Processor, Motion Detection
FEATURES
• Real Time Refresh Rate
• User-friendly front panel design
• OSD Set-Up Menu
FEATURES
• Real Time Refresh Rate
• User-friendly front panel design
• OSD Set-Up Menu
SPECIFICATIONS
Model
Video System
Resolution (HxV)
Input Video Connector
Output Video Connector
Video Format
Video Refresh Rate
Alarm Time
Alarm Output
Motion Detection
Video Loss Detection
Power Supply
Power Consumption
Dimensions (mm) WxHxD
Weight g
CODE
KUQC01
KUQC03
www.hesa.com
MODEL
QC-01
QC-03
QC-01
QC-03
Color
720x576
860x625
4x BNC
2x BNC
Full Screen/Quad/PIP
Full Screen/Auto Switch
25 fps
50 fps
1~20sec
Buzzer 0~240sec
1 relay N.O./N.C.
YES
Alarm or Freeze Image
12VDC ±10%
1A
6W
295x45x210
220x44x210
1800
1265
DESCRIPTION
Color Quad Processor, 4 Video Inputs, Alarm Input
Color Quad Processor, 4 Video Inputs, Motion Detection
CCTV PRODUCTS
190
Video Distributors & Amplifiers
DV-01
Video Distributor 1 Input, 4 Outputs
DV-02
Video Distributor 1 Input, 8 Outputs
DV-03
Video Distributor 8 Inputs, 16 Outputs
AV-01
Video Amplifier 1 Input, 1 Output
DV-00
Video Distributor 4 Inputs, 8 Outputs
SPECIFICATIONS
Model
Video Input 1.0Vp-p/751
Video Output 1.0Vp-p/751
Amplifier Range
Video Gain
Color Adjustment
Power Supply
Power Consumption
Dimensions (mm)
Weight g
DV-01
1
4
DV-02
1
8
DV-00
4 programmable
8 programmable
DV-03
8 programmable
16 programmable
AV-01
1
1
m 200
13dB (max)
YES
230VAC
1.8W
218x44x200
1350
–
1dB
2dB
–
230VAC
2.5W
218x44x200
1450
12VDC
15W
220x40x180
1500
19” rack, 1U
2000
1600
DIMENSIONS (mm)
218
220
1U
40
44
DV-03
200
40
44
180
DV-01 / AV-01
CODE
KUDV01
KUDV-02
KUDV-00
KUDV-03
KUAV01
www.hesa.com
MODEL
DV-01
DV-02
DV-00
DV-03
AV-01
19” rack
DV-02 / DV-00
DESCRIPTION
Video Distributor 1 Input, 4 Outputs
Video Distributor 1 Input, 8 Outputs
Video Distributor 4 Inputs, 8 Outputs
Video Distributor 8 Inputs, 16 Outputs
Video Amplifier 1 Input, 1 Output
191
Distributors, Amplifiers, Surge Protections & Power Supplies
DRS-4
RS485 Distributor 1 input 4 output
FEATURES
• Input option: 1 x RS232, 2 x RS485 (3
input pcan be “stand by” status at the
same time, but only one controller will
be activated at once)
• Output: 4 x RS485, each channel
connection range up to 1200 m by
twisted pair cable
• Built-in surge protection at each
channel
• Ability to cascade connection to other
units DRS-4/DRS-8/DRS-16
• The application gives serial data back
on 4 outputs at the same time, provide
perfect configurations
DRS-8
RS485 Distributor 1 input 8 output In 1U
Rack Mounting Panel
FEATURES
• Indical to DRS-4, but 1 input 8 output
DRS-16
RS485 Distributor 1 input 16 output In
1U Rack Mounting Panel
FEATURES
• Indical to DRS-4, but 1 input 16
output
DA-9
1 In 9 Out Power Distributor Box
FEATURES
• Built-in LED indication on each channel
• Built-in 1 AMP PTC for short protection
on each output
WIRING DIAGRAM
Power 12VDC
RS485 o RS232
RS485
DRS-16
CODE
KUDRS4
KUDRS8
KUDRS16
KUDA9
www.hesa.com
MODEL
DRS-4
DRS-8
DRS-16
DA-9
DESCRIPTION
RS485 Distributor 1 input 4 output
RS485 Distributor 1 input 8 output In 1U Rack Mounting Panel
RS485 Distributor 1 input 16 output In 1U Rack Mounting Panel
1 In 9 Out Power Distributor Box
RS232
CCTV PRODUCTS
192
Distributors, Amplifiers, Surge Protections & Power Supplies
camera
cable
coaxial cable
CX-01 / CX-02
CX-01
Coaxial Video Ground Loop Isolator
CX-02
Hi Performance Video Ground Loop
Isolator
FEATURES
• BNC male to BNC fermale whit mini
cable 15cm on both sides
• Eliminates picture tearing, cross talk
and rolling
• Prevents video-signal distorsion
caused by video ground loops
FEATURES
• BNC male to BNC fermale whit mini
cable 15cm on both sides
• Hi Performance to eliminate ground
loop problem
camera
• Passive, no power required
• Prevents power cables laid by others
interfering whit the CCTV system
• Built-in TVS (Transient Voltage
Suppressors) for surge protection
• Passive, no power required
• low video loss, Bandwidth: 20Hz-11MHz,
+0/-3dB
cable
coaxial cable
CX-03
CX-03
Coaxial Video Ground Loop Isolator builtin Video BALUN
FEATURES
• BNC male to BNC fermale whit mini
cable 15cm on both sides
• Other same as CX-01 Ground Loop
Isolator function
• Built-in TVS (Transient Voltage
Suppressors) for surge protection
• Built-in Video BALUN, perfect to work
with DVR to iummunity DVR
interference, for extra interference
rejection
cable connection
coaxial cable
coaxial cable
CX-04
CX-04
Coaxial BALUN for DVR
CODE
KUCX01
KUCX02
KUCX03
KUCX04
www.hesa.com
MODEL
CX-01
CX-02
CX-03
CX-04
cable connection
FEATURES
• BNC male to BNC fermate with mini
cable 30cm
• Perfect work with DVR to immunity
DVR interference
DESCRIPTION
Coaxial Video Ground Loop Isolator
Hi Performance Video Ground Loop Isolator
Coaxial Video Ground Loop Isolator built-in Video BALUN
Coaxial BALUN for DVR
coaxial cable
CX-04
• Built-in a highly balance mode of
video transmission, wich is immune to
interference from these, and other
sources of noise: Data signals, other
video signals, nearby power, ringing
telephones, fluorescent lights,
transformers, and more...
193
Distributors, Amplifiers, Surge Protections & Power Supplies
CODE
KUCX06V
KUCX06A
KUCX06C
www.hesa.com
MODEL
CX-06V
CX-06A
CX-06C
CX-06V
Coaxial Video Surge Protector BNC
Connector
FEATURES
• BNC male to BNC fermale, Hi frequency
for both CCTV and CATV use
CX-06A
AC Power Surge protection Device
Terminal Connector
FEATURES
• Terminal connector to terminal
connector
• Application for protect AC100-120V,
AC220-240V equipment
• Max current up 2Amp
CX-06C
Power Surge protection
FEATURES
• 2 pin terminal for power input to 2 pin
terminal for power output
• Max power input 40VAC (max), 56VDC
(max)
• Max current up 2Amp
DESCRIPTION
Coaxial Video Surge Protector BNC Connector
AC Power Surge protection Device Terminal Connector
Power Surge protection
CCTV PRODUCTS
194
Distributors, Amplifiers, Surge Protections & Power Supplies
ALS12-1.1A
Switching Power Supply, 220VAC/12VDC,
15W, 1.3A
FEATURES
• Universal AC Input / Full range
• Protections: Short circuit / Overload /
Over voltage
• Cooling by free air convection
• 100% full load burn-in test
AT1A12V
Switching wall plug-in power adaptor
supply, 220VAC/12VDC, 1A
AT15A12V
Switching wall plug-in power adaptor
supply, 220VAC/12VDC, 1.5A
AT3A12V
Power supply "in line" for cameras,
220VAC/12VDC, 3A
AT4A12V
Switching Power Supply, 220VAC/12VDC,
4,2A
CODICE
MYW1211
KUAT1A
KUAT15A
KUAT3A
KUAT4A
www.hesa.com
ARTICOLO
ALS12-1.1A
AT1A12V
AT15A12V
AT3A12V
AT4A12V
DESCRIZIONE
Switching Power Supply, 220VAC/12VDC, 15W, 1.3A
Power adapter for cameras, 220VAC/12VDC, 1A
Power adapter for cameras, 220VAC/12VDC, 1.5A
Power Supply "in line" for cameras, 220VAC/12VDC, 3A
Switching Power Supply, 220VAC/12VDC, 4,2A
FEATURES
• Self-extinguishing plastic housing UL
V-0, degree of insulation class II
• Protection against overload and short
circuit
195
H.264 Stand Alone DVR
Entry level Series
DVR-4HFL
4 channel, H.264 Stand Alone DVR
FEATURES
• 4 channels Full D1 720x480 Display
• Full D1 recording and playback
• H.264 Hardware Compression
• Digital zoom x8
• On Board VGA
• With free bundled CMS
• 3GPP, PDA, Smart phone Blackberry,
HTC, iPhone support
• 2 USB port
• RS485 support
• 1 Audio input & output
SPECIFICATIONS
Model
Video system
Video Input
Video Output
Audio
Display Split
Recording Resolution
Display resolution
Hard Disk
Hardware Compression
Recording Mode
Speed Playback
Search Method
Zoom
Motion Detection
Archiving
Operation Devices
Image Quality Setting
Power supply
Weight gr
CODE
KUDV4HL
www.hesa.com
MODEL
DVR-4HL
DVR-4HFL
PAL
4
1 BNC +VGA (max. 1280x1024)
1 input, 1 output RCA
Singol / Sequence / Quad / PIP
704x576 (100 fps); 704x288 (100 fps); 352x288 (100 fps)
720x576 (100 fps)
320GB
H.264
Manual / Continuos / Motion Detection
Real time @ D1
Date / Time / Event (motion, alarma) camera
Digital x2 ~ x8
Each control / channel
Sensitivity: 10 steps for each channel
Area: Programmable motion detection area for each camera individually
2 x USB (ver 2.0)
remote control / mouse
5 level (selectable)
12VDC, 3A, 36W
770
DESCRIPTION
4 channel H.264 Stand Alone DVR
CCTV PRODUCTS
196
H.264 Stand Alone DVR
Network H.264 Series
DVR-4HD
4 channels, H.264, D1, network, HD
500GB
DVR-8HD
8 channels, H.264, D1, network, DVD-RW,
HD 500GB
FEATURES
• Full D1 recording and playback
• H.264 Hardware Compression
• Digital Zoom x8
• 2 x SATA HDD Space plus DVD+RW
• On Board VGA
• With free bundled CMS
• 3GPP, PDA, Smart phone Blackberry,
HTC, iPhone suppport
• 2 USB port
• Alarm in & out
• 4 Audio Input & 2 output / 1 output
DVR-16HD
16 channels H.264, D1, network, DVD-RW,
HD 500GB
SPECIFICATIONS
Model
Video system
Video Input
Video output
Display Split
DVR-4HD
Recording resolution
Hard Disk
Alarm Input
Alarm Output
DVD
Hardware Compression
Recording Mode
Pre-alarm
Post-alarm
Zoom
Search Mode
Motion Detection
Remote connection
Archiving
Audio
Image Quality Setting
Power Supply
Dimensions (mm)
Weight g
CODE
KUDV4HD
KUDV8HD
KUDV16HD
www.hesa.com
MODEL
DVR-4HD
DVR-8HD
DVR-16HD
DVR-8HD
DVR-16HD
PAL/NTSC
4 BNC inputs
8 BNC inputs
16 BNC inputs
1 BNC, 1VGA, 1 monitor SPOT
Singol /Sequence / Quad/
Singol /Sequence / Quad/
Singol / Sequence / Quad
6, 8
8, 13, 16
704x576 (50 fps), 704x288 (100 fps) 704x576 (50 fps), 704x288 (100 fps) 704x576 (100 fps), 704x288 (200 fps)
352x288 (100fps)
352x288 (200fps)
352x288 (400fps)
500GB
4 input N.A. o N.C.
8 input N.A. o N.C.
16 input N.A. o N.C.
1 relay output
1 relay output
2 relay outputs
–
SI
H.264
manual / motion / alarm / schedule
10 second
1~60 second
digital x8
date / time / event (motion, alarm) camera
Each control / panel
Sensitivity: 10 steps for each channel
Area: Programmable motion detection area for each camera individually
LAN card, protocol TCP/IP, SMTP, HTTP, DHCP, PPPOE (ADSL) port RS485 for Speed-Dome
USB (ver. 2.0)
4 input, 1 output
4 input, 2 output
5 steps (Highest, High, Normal, Basic, Below Basic)
240VAC power supply 12VDC included
430x60x307
2.850
3500
DESCRIPTION
4 channels, H.264, D1, network, HD 500GB
8 channels, H.264, D1, network, DVD-RW, HD 500GB
16 channels H.264, D1, network, DVD-RW, HD 500GB
197
COMBO DVR
DVR-4CMBH
19” COMBO DVR
SPECIFICATIONS
Model
Video System
LCD Size
Video Input
Video Output
Audio Input
Audio Output
Response Time (TR+TF)
Mouse
IR Remote Control
Internal HDD
Display Division
Zoom
Recording Compression
Recording Mode
Resolution
Frame Rate
Quality
Motion Detection
Alarm
Water Mark
Playback Speed
Search Method
Remote Software
Remote Operation
Network Service
3G Device
GUI Interface
Dome Protocal
External
Network Backup
File
CODE
MODEL
KUDV4CMBH DVR-4CMBH
www.hesa.com
DVR-4CMBH
PAL
19"
BNC X 4, 1.0vp-p, 751
BNC X 2, 1.0vp-p, 751
1ch, RCA
1ch, RCA
5ms
USB Mouse
YES
320 GB
1, 4
2x~8x (Playback Zoom Support)
H.264 Main Profile
Manual, Schedule, Alarm, Holiday
720x576, 720x288, 352x288
50, 100, 100 Fps
Highest, High, Normal, Low, Lowest
Sensitivity: 15 level, 16x12 GRID
16mb (Pre-Alarm)/1~999 Sec (Post-Alarm)
YES
Normal, Rew & FF (2x/4x/8x/16x/32x/64x)
Segment, Time, Event, Calander
CMS, IE BROWSER, MOBILE
Virtual DVR- Same AS Local OSD
TCP/IP, HTTP, DHCP, SMTP (SSL), ADSL, LAN, DDNS
Win 5.0,6.0, Symbian, IPhone, PDA, Blackberry
Supported GUI 16 Bit True Color
Pelco P, Pelco D
USB X1 (Front panel)
Yes
H.264 Compression/Avi Format
DESCRIPTION
19” COMBO DVR
FEATURES
• NTSC/PAL auto detect
• Supports up to 1280 x 1024SXGA high
resolution
• High contrast ratio up to 1000:1
• 4CH DVR with H.264 Video
compression
• Provide Graphical User Interface (GUI)
and mouse/touch screen for easier and
user friendly configuration and
operation
• Supports smart search function for
faster and easier playback retrieval
• Picture-in-picture display & channel
screen popup on monitor/sensor
• Role-based multiple network users
access to exclusive channel view &
peration
CCTV PRODUCTS
198
IP Cameras
Indoor compact cameras
TCN-CB
Indoor IP camera, 1.3 Megapixel, H.264,
audio, PoE
TCN-CBW
Indoor IP camera, 1.3 Megapixel, H.264,
audio, Wi-Fi
TCN-CBPIR
Indoor IP camera, 1.3 Megapixel, H.264,
audio microphone & speaker, PIR sensor
and illumination LED, PoE
TCN-CBPIRW
Indoor IP camera, 1.3 Megapixel, H.264,
audio microphone & speaker, PIR sensor
and illumination LED, Wi-Fi
FEATURES
• Functional and smart design
• Multiple H.264 streams
• H.264, MPEG4, and MJPEG triple code
compression
• Resolution 1280 x 800
• Easy & flexible installation
• Built in microphone
• Support Maxi-watch Professional IP
Software
• Free bundled 64 channel recording
software
FEATURES
• Functional and smart design
• Multiple H.264 streams
• Built in microphone & speaker
• H.264, MPEG4, and MJPEG triple code
compression
• Resolution 1280 x 800
• easy & flexible installation
• PIR sensor and illumination LED
• Support Maxi-watch Professional IP
Software
• Free bundled 64 channel recording
software
SPECIFICATIONS
Model
Sensor Type
Sensor resolution
Minimum Illumination
Lens Type
Maximum Image Resolution
Image Compression
Display Frame Rate
Wi-Fi
Support Protocols
Auto Exposure Control
Gain Control
White Balance
Input / Output
Audio
Power
Operating Temperature
Dimension LxWxH (mm)
Weight g
CODE
KUNTCB
KUNTCBW
KUNTCBPIR
KUNTCBPIRW
www.hesa.com
MODEL
TCN-CB
TCN-CBW
TCN-CBPIR
TCN-CBPIRW
TCN-CB
TCN-CBW
TCN-CBPIR
TCN-CBPIRW
1/4” CMOS 1.3 Megapixel
1280x800
1 lux
1 lux (IR OFF), 0 lux (IR ON)
[email protected]
1200x800, 640x400
H.264, MPEG4 e MJPEG
30 fps (640x400)
NO
YES
NO
YES
TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, Samba, PPPoE, UpnP, Bonjour, RTP, RTSP, RTCP
YES
AGC
AWB
1 Output Ethernet 10/100 RJ45
Built in microphone
2 way audio
PoE
12VDC
PoE
12VDC
0°C~ +50°C
29x70x105
33x69x103
97
103
108
DESCRIPTION
Indoor IP camera 1.3 Megapixel, H.264, audio, PoE
Indoor IP camera 1.3 Megapixel, H.264, audio, Wi-Fi
Indoor IP camera 1.3 Megapixel, H.264, audio 2 way, PIR, PoE
Indoor IP camera 1.3 Megapixel, H.264, audio 2 way, PIR, Wi-Fi
199
IP Cameras
Professional cameras high resolution
TCN-10DN
IP camera 1/3” Sony Super HAD,
540 TVL, D&N
TCN-11SDDNW
IP camera 1/3” Sony Super HAD
540 TVL, SD, Wi-Fi, D&N
FEATURES
• Internal built-in 1/3" CCD
• Remote Surveillance Through Internet
or Intranet
• Dual streamingMPEG4 & MPEG
Compression
• Event triggered picture can be sent via
FTP or E-mail
• System base on Java platform for
better stability
• Remote recording
• PPPoE or DDNS support
• Video motion detection
• Support 3GPP / PDA service
• Easy set up with UPnP support
• Support 2-way audio
• Day Night Function With ICR Filter
Mechanism
• Support Maxi-Watch Professional IP
soft ware
• Free Bundle Basic 36 Channel
Recording Software Provided
• SDK for software integration provided
SPECIFICATIONS
Model
Sensor Type
Effective Pixel
Horizontal Resolution
Day&Night functions
Wi-Fi
Minimum Illumination
Image resolution
Network Compression
Image Frame Rate
Motion detection
Protocol
Input / Output
Back-Up
SDK
Alimentazione
Assorbimento
CODE
MODEL
KUNTC10D
TCN-10DN
KUNTC11SDW TCN-11SDDNW
www.hesa.com
TCN-10DN
TCN-11SDDNW
1/3” CCD Sony Super HAD
752x582
540 TVL color - 600 B/W
IR filter
–
YES
0.01 lux @ F1.2
D1 (720x576), 4 CIF, (704x576) CIF, (352x288), QCIF (176x144)
Dual streaming MPEG4/MJPEG
30/25 fps
YES (3 windows)
TCP/IP, ICMP, HTTP, FTP, STTP, DDNS, PPPoE
TCP/IP, HTTP, FTP, NTP, SMTP, DDNS, PPoE, UPnP
2 digital input, 2 digital output, 1 Audio output, 1 BNC output
–
SD
YES
12VDC
12VDC (PoE Optional)
8W
DESCRIPTION
IP camera 1/3” Sony Super HAD, 540 TVL, D&N
IP camera 1/3” Sony Super HAD, 540 TVL, SD, Wi-Fi, D&N
CCTV PRODUCTS
200
IP Cameras
H.264 2.0 MEGAPIXEL IP Box Cameras
TCN-20MDN
2.0 Megapixel 1/3”Micron Progressive
Scan CMOS, H.264 compression, with IR
cut filter, SXGA Network Camera, with
2-way audio, 12VDC e POE
FEATURES
• 720P @ 30FPS
• 2.0 Megapixel
• H.264/MKJPEG/MPEG4 compression
• Video motion detection
• Support 3GPP/PDA service
• Easy set up with UPnP support
• Expansion SD Back up for data storage
• SDK for software integration provided
• Free bundled basic 36 channel
recording software provided
• Support Maxi-Watch Professional IP
software (option)
• Wireless (option)
SPECIFICATIONS
Model
CCD Image Sensor
Minimum Illumination
Effective Resolution (HxV)
Video compression
Image Frame Rate
Motion Detector
Protocol
AGC
BLC
Frickerless
S/N Ratio
Input/Output
SDK
Power Supply
Power Consumption
Dimensions (mm)
Weight g
CODE
KUNTC20MDN
www.hesa.com
MODEL
TCN-20MDN
TCN-20MDN
1/3” CMOS Micron Progressive Scan 2.0 Megapixel
0.05 lux
1600x1200, 1280x1024, 1280x960, 1280x720, 800x600, 649x480, 320x240, 176x120
H.264 /MJPEG / MPEG4 (only 3GPP)
1280x720@30fps
YES (Windows)
HTTP, FTP, SMTP, TCP/IP, DHCP, PPPoE, DDNS, UPnP, NTP, 3GPP
Auto
ON/OFF
ON/OFF
>42dB
1 input / 1 digital allarm output, 1 speaker output, 1 output Ethernet (10/100 base-T) RJ45 Connector
YES
12VDC, PoE
450 mA
137x65x80
450
DESCRIPTION
2.0 Megapixel 1/3”Micron Progressive Scan CMOS, H.264 compression, with IR cut filter, SXGA Network Camera,
12VDC e POE
201
IP Cameras
H.264 2.0 MEGAPIXEL IR Bullet and Vandal Dome
SPECIFICATIONS
Model
CCD Image Sensor
Minimum Illumination
Lens
Electronic Shutter
Effective Resolution (HxV)
Compression
Image frame rate
Motion Detector
Protocol
AGC
BLC
Frickerless
S/N Ratio
Input/Output
SDK
IP Rating
Power Supply
Power Consumption
Dimensions (mm)
Weight g
CODE
KUNTC20BM
MODEL
TCN-20BM
KUNTC20DM
TCN-20DM
www.hesa.com
TCN-20BM
2.0 Megapixel 1/3” Micron Progressive
Scan CMOS, H.264 compression, IP Bullet,
whit Vari-focal 3.6~16mm lens, SXGA
Network, Built in IR LEDs 20 m, D&N +
ICR cut camera, IP66, 12VDC, POE
FEATURES
• Up to 1600x1200 resolution at 15fps
• Triple streaming H.264/JPEG/MPEG4
compression format
• Video motion detection
• Support cell phone/PDA/3GPP
• Free bundled 36 channel recording
software
• SDK for software integration provided
• Support Maxi-Watch Professional IP
software (option)
TCN-20DM
2.0 Megapixel 1/3” Micron Progressive
Scan CMOS, H.264 compression, IP
Vandal Dome, with Vari-focal DC Iris
2.7~9 mm lens, SXGA Network, D&N +
ICR cut camera, IP66, 12VDC, POE
FEATURES
• Up to 1600x1200 resolution at 15fps
• Video motion detection
• Power over Ethernet
• Dual streaming H.264/MPEG4/MJPEG
compression format
• Support 3GPP/PDA service
• With SD back up
• Free bundled 36 channel recording
software
• SDK for software integration
TCN-20BM
TCN-20DM
1/3” CMOS Micron Progressive Scan 2.0 Megapixel
0.5 lux Color (day mode)
0 lux B/W (night mode)
Vari-focal 3.6~16mm
Vari-focal 2.7~9mm
–
1/50 ~1/100.000 s
1600x1200, 1280x1024, 1280x960, 1280x720, 800x600, 649x480, 320x240, 176x120
H.264 /MJPEG / MPEG4
1280x720@30fps
1280x960@25fps
YES, 3 Windows
YES, 3 Windows
HTTP, FTP, SMTP, TCP/IP, DHCP, PPPoE, DDNS,
HTTP, FTP, SMTP, TCP/IP, DHCP, PPPoE, DDNS, NTP
UPnP, NTP, 3GPP, UPD, RTP, RTSP, ICMP, ARP
Auto
ON/OFF
ON/OFF
>42dB
1 input / 1 digital allarm output,
1 input / 1 audio output, 1 output Ethernet
1 input / 1 audio output ,
(10/100 base-T) RJ45 Connector
1 output Ethernet( 10/100 base-T) RJ45 Connector
YES
IP66
12VDC, PoE
450 mA
560 mA
180x83
103x137
700
DESCRIPTION
2.0 Megapixel 1/3” Micron Progressive Scan CMOS, H.264 compression, IP Bullet, whit Vari-focal 3.6~16mm lens,
SXGA Network, Built in IR LEDs 20 m, D&N + ICR cut camera, IP66, 12VDC, POE
2.0 Megapixel 1/3” Micron Progressive Scan CMOS, H.264 compression, IP Vandal Dome, with Vari-focal DC Iris
2.7~9 mm lens, SXGA Network, D&N + ICR cut camera, IP66, 12VDC, POE
CCTV PRODUCTS
202
IP Cameras
WDR Outdoor IP Camera
TCN-15MIR2
1/3” IP Wide Dynamic Range color
camera, Varifocal Auto Iris, D&N, IR LED,
Working Distance 30M, 560 TVL
TCN-17MIR2
1/3” IP Wide Dynamic Range color
camera, Varifocal Auto Iris, D&N, IR LED,
Working Distance 50M, 560 TVL
FEATURES
• D-WDR
• Support 3D DNR
• Sens-Up Function
• IP66
• External Vari-focal lens adjustment
• True Day/Night Function
• Mechanism IR Cut Filter available
• Fan Built-in
• Two-Way audio
• IR Distance: 50/30 Meter
• H.264/MJPEG/MPEG4 compression
• Support cell phone / PDA / 3GPP
• SDK for software integration
• Free Bundle 36 Channel Recording
Software
• 8 Step shutter Adjustment
• Support Maxi-Watch Professional IP
Software
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixel
Horizontal Resolution
Day/Night
Lens
Minimum Illumination
IR LED
IR Working Distance
IP Rating
Picture Resolution
Network Compression
Image Frame Rate
Motion Detector
Network Protocol
Input / Output
Audio
SDK
Power supply
Power Consumption
Dimension (Ø x L mm)
Weight (g)
CODE
MODEL
KUNTC15IR2 TCN-15MIR2
KUNTC17IR2 TCN-17MIR2
www.hesa.com
TCN-15MIR2
TCN-17MIR2
1/3” CCD Sony Super HAD
752x582
560 TVL
filtro IR meccanico
Varifocal 3.7~12mm
Varifocal 9~22mm
0.5 lux (IR ON)
42 Unit
30 M
12 Unit + E Power 7 Unit
50 M
IP66
D1 (720x576), 4CIF (704x576), CIF (352x288), QCIF (176x144)
triple streaming H.264 MPEG-4/MJPEG
25 fps (resolution D1)
YES (3 windows)
HTTP, TCP/IP, SMTP, FTP, PPPoE, DHCP, DDMS, NTP, UPnP, 3GPP
1 Input, 1 Relay Output
Two Way
YES
12VDC
12.5W
114 x 260
1600
DESCRIPTION
1/3” IP Wide Dynamic Range color camera, IR LED, 560 TVL, Working Distance 30 M, 12VDC
1/3” IP Wide Dynamic Range color camera, IR LED, 560 TVL, Working Distance 50 M, 12VDC
203
IP Cameras
WDR Outdoor IP Camera
TCN-15MIRHD
1/3” IP color camera, 2.0 Megapixel,
Varifocal 3.6~16 mm, D&N, 42 IR LED,
Working Distance 30M
FEATURES
• IP66
• 720P @ 30FPS
• 2Mega pixel CMOS sensor
• External Vari-focal lens adjustment
• True Day/Night Function
• Mechanism IR Cut Filter available
• Fan Built-in
• Two-Way audio
• IR Distance: 30 Meter
• H.264/MJPEG/MPEG4 compression
• Support cell phone/PDA/3GPP
• Triple streaming
• SDK for software integration
• Free Bundle 36 Channel Recording
Software
• Support Maxi-Watch Professional IP
software (option).
SPECIFICATIONS
Model
CCD Image Sensor
Day/Night
Lens
Minimum Illumination
IR LED
IR Working Distance
Flickerless
S/N Ratio
IP Rating
Picture Resolution
Network Compression
Image Frame Rate
Motion Detector
Network Protocol
Input / Output
Audio
SDK
AGC
Power supply
Power Consumption
Dimension (Ø x L mm)
Weight (g)
CODE
MODEL
KUNTC15IRH TCN-15MIRHD
www.hesa.com
TCN-15MIRHD
1/3” CMOS Progressive Scan 2.0 Megapixel
filtro IR meccanico
Varifocal 3.6~16mm
0.5 lux Color (day mode)
0 lux B/W (night mode)
42 Unit
30 M
YES
>42dB
IP66
1600x1200, 1280x1024, 1280x960, 1280x720,
800x600, 640x480, 320x240, 176x120
triple streaming H.264 MPEG-4/MJPEG
25 fps (1280x960)
YES (3 windows)
Onvif, HTTP, TCP/IP, SMTP, FTP, PPPoE, DHCP, PPPoE,
DDNS, NTP, UPnP, 3GPP, UPD
1 Input, 1 Relay Output,
1 Output Ethernet (10/100 Base-T) RJ-45 connector
Two Way
YES
Auto
12VDC
12.5W
114 x 260
1600
DESCRIPTION
1/3” IP color camera, 2.0 Megapixel, Varifocal 3.6~16 mm, D&N, 42 IR LED, Working Distance 30M
CCTV PRODUCTS
204
Switches, splitters, injector, PoE Repeater
SPN-4
5-port 10M/100M Desktop PoE Fast
Ethernet Switch with 4 PSE/PoE ports
SPN-8
8-port 10M/100M Desktop PoE Fast
Ethernet Switch
SPN-16
Rack-mount PoE Fast Ethernet Switch
16-port 10M/100M
FEATURES
• 5-Port 10/100BaseT(X) with 4
PSE/Power over Ethernet Ports
• Complaint with IEEE 802.3 af/at
• Metal Case with Palm Size
• Auto-MDI/MDI-X
• Auto-Negotiation
• External Power Supply
FEATURES
• 8 PSE/Power over Ethernet Ports
• 11" Metal Case
• Rack-Mount to 19" Cabinet
• Web-based configuration & management
• Auto-MDI / MDI-X
• Auto-Negotiation
• Non-Blocking
• Internal Power Supply
FEATURES
• 16 PSE/Power over Ethernet Ports
• 19" Industrial Size
• Auto-MDI/MDI-X
• Auto-Negotiation
• Web-based configuration & management
• Non-Blocking
• Internal Power Supply
NPI-1
Single Port Injector
NPI-8
8 Port Rack-Mount POE Mid-Span
Injector
FEATURES
• Up to 30W of PoE Power Feeding on 2pairs
• IEEE 802.3at Compliant with 2-event
classification
• IEEE 802.3af backward compatible
• Compatible with IEEE 802.3af or
Legacy PoE applications
• Safe on Low Power Devices Receive
Only the Power They Need
• Safe and Reliable Power to WLAN
Access Points
• Automatic Detection and Protection of
Non–standard Ethernet Terminals
• Supports 10/100/1000Base-T LAN
environment
• Pararell slide-in design to ease the
installation
FEATURES
• 8 port 10/100/1000BaseT(X) Data-In
Ports + 8 10/100BaseT(X) Data and
Power-Out Ports
• 19" Rack-Mount Size
• Internal Power Supply
www.hesa.com
205
Switches, splitters, injector, PoE Repeater
NSPL
Single Port PoE Splitter
NPR-2
2-port PoE Repeater
FEATURES
• 5v, 9v, 12v output adjustable
• IEEE802.3af compliance
• Short circuit protection
• Plug-and-Play
• Delivering power and data to power
device
• Light weight and compact size
• For Wireless AP, Bluetooth AP, IP
Camera, IP Phone, remote power feeding application
• Regulated output voltage by switch
FEATURES
• Extends Ethernet cable installations for
another 100 meters
• 2-Port Ethernet Power Sourcing
Equipment (PSE)
• No power cable installation required
• Fully Ethernet protocol transparent – no
restrictions to network traffic 100Mbps
Ethernet Wire Speed
• Compatible with IEEE 802.3af PoE
standard
• IP66 Weather-Proof for FPR102-ODU
outdoor unit
• Simple to install – Plug & Play
SPECIFICATIONS
Model
Port
Power supply
Network Protocol
Operating Temperature
Dimensions (mm)
Weight g
www.hesa.com
Switches
SPN-8
SPN-16
NPI-1
NPI-8
5 which 4 POE
8POE
16POE
1
8 POE output
e 8 data input
100~240VAC
90~260VAC
52VDC
30 Watt
48VDC
130 Watt
48VDC
Output voltage
Power Consumption
Medium transmission
CODE
KUNPS4
KUNPS8
KUNPS16
KUNPI1
KUNPI8
KUNPSPL
KUNPR2
SPN-4
MODEL
SPN-4
SPN-8
SPN-16
NPI-1
NPI-8
NSPL
NPR-2
Injectors
100~240VAC
48VDC
40W max.
65W max.
260W max.
10 BaseT Cat. 3, 4, 5 UTP/STP
100BaseTX Cat 5 UTP/STP
IEEE-802.3af/at
0°C~+40°C
0°C~+50°C
130x97x24
266x166x44
440x220x44
1300
1400
3800
DESCRIPTION
Switch PoE 1 Ethernet port + 4 PoE ports
Switch PoE 8 PoE ports
Switch PoE 16 PoE ports
PoE injector 1 port
PoE injector 8 ports rack mount
Single Port PoE Splitter
2-port PoE Repeater
Splitter
NSPL
1 RJ-45 input
female, 1 RJ-45
output data
male, power
jack
36~48 VDC,
350mA
5/9/12VDC
12.9 Watt
–
–
–10°C ~ +45°C
88 x 52 x 166
350
0°C ~ +40°C
440x220x44
2700
IEEE802.3/u/af
0°C~+45°C
81x55x28
45
CCTV PRODUCTS
206
IP Cameras
Speed-Dome NSD Series
Outdoor Models
NSD-H6HE
540 TVL, D&N, H.264 e JPEG, 18X, WDR,
24VDC
Flush Mount Indoor Models
NSD-H6HI
540 TVL, D&N, H.264 e JPEG, 18X, WDR,
24VDC
Surface Mount Indoor Models
NSD-H6HS
540 TVL, D&N, H.264 e JPEG, 18X, WDR,
24VDC
NSD-H8HEB
700 TVL, D&N, H.264 e JPEG, 36X, WDR,
24VDC
NSD-H8HIB
700 TVL, D&N, H.264 e JPEG, 36X, WDR,
24VDC
NSD-H8HSB
700 TVL, D&N, H.264 e JPEG, 36X, WDR,
24VDC
FEATURES
• CCD 1/4” Sony EX-View
• H.264/JPEG streaming network
• Support 3GPP/PDA Service
• Mechanical ICR for true day & night
• Zoom 18X / 36X
• Wide dynamic
• Privacy zone
• Video Output: BNC/UTP
SD-8H SERIES
• 1/4” Sony Super HAD II
• Day&Night + ICR
• 36X Optical Zoom
• Heater, Fan, Power adapter
included (NSD-H8HEB)
• Minimum Illumination
CODE
KUNSDH6HE
KUNSDH6HI
KUNSDH6HS
KUNSDH8HEB
KUNSDH8HIB
KUNSDH8HSB
Accessories
KUSDSPEA
KUSDSSE
KUSDSPP
KUSDSAE
www.hesa.com
MODEL
NSD-H6HE
NSD-H6HI
NSD-H6HS
NSD-H8HEB
NSD-H8HIB
NSD-H8HSB
SD-SPEA
SD-SSE
SD-SPP
SD-SAE
DESCRIPTION
Color Speed-Dome IP, 540 TVL, D&N, 18X, H.264, WDR, Outdoor
Color Speed-Dome IP, 540 TVL, D&N, 18X, H.264, WDR, Flush Mount Indoor
Color Speed-Dome IP, 540 TVL, D&N, 18X, H.264, WDR, Surface Mount Indoor
Color Speed-Dome IP, 700 TVL, D&N, 36X, H.264, WDR, Outdoor
Color Speed-Dome IP, 700 TVL, D&N, 36X, H.264, WDR, Flush Mount Indoor
Color Speed-Dome IP, 700 TVL, D&N, 36X, H.264, WDR, Surface Mount Indoor
Aluminum Wall Mount Bracket
Aluminum Pendant Mount Bracket
Aluminum Pole mount bracket
Aluminum Corner Mount
SD-SPEA
SD-SSE
SD-SPP
SD-SAE
207
IP Cameras
Speed-Dome NSD Series
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Synchronization
Optical Lens
NSD-H6H
1/4” Color SONY EX-View HAD
752x582
540 TVL
NSD-H8H
1/4” SONY Super HAD II (double Scan) CCD
1028x596
700 TVL
Internal/External V-lock
Zoom 18X, F = 4.1~73.8mm
Zoom 36X,
(F1.4~3.0)
F= 3.4~122.4mm F1.6~4.5)
12X
32X
(216X with Optical Zoom)
(432X with Optical Zoom)
57.8° (wide)
–
to 1.7° (tele)
–
320 mm (wide), to 1500 mm (tele)
YES, with ICR Filter
0.7 lux (F1.4, 1/50sec)
1.0 lux (F1.6, 1/50sec)
0.01 lux (F1.4, 1/3sec) ICR ON
0.01 lux (F1.6, 1/3sec) ICR ON
Auto: 1/50 ~ 1/10000sec ; Manual: 22 steps
>50dB
Auto/Manual (-3~28dB, 16 steps)
ON/OFF
Auto: (3000°K-7500°K) ATW (2000°K-10000°K), Indoor, Outdoor, One-push, Manual
Auto, Manual, Backlight Compensation, EV Compensation, Priority Mode, Bright
–10.5~+10.5dB (1.5dB Steps)
Auto (sensitivity normal, low) Manual, Infinity, Interval AF, Zoom Trigger AF
220 preset, 4 sequences each one with up to 32 preset dwell time
360° continuous; 0.1°~160°/sec.
YES, many languages
RS485/RS422, (Manchester, Biphase, Coaxitron)
2400/4800/9600/19200 bps
Pelco-P/D, VCL, Kalatel, Ernitec, Lilin, Vicon, Molynx, Diamond, Panasonic, Pelco-Coaxitron, AD, Philips, Sensornet
7 Alarm Inputs/2 Alarm Outputs
YES, board NET-CD1
-20°C~+60°C (Humidity 30%~90%)
24VAC ±10%, 50/60Hz
10W (Indoor), 50W (Outdoor)
0.5°~140°/sec
0.1°~160°/sec
90°, 0.1~160°/s
0.5°~140°/sec
0.1°~160°/sec
Pan>300°/sec, Tilt>300°/sec
Pan>360°/sec, Tilt>360°/sec
Digital Zoom Ratio
Viewing Angle (H)
Minimum Working Distance
Day&Night
Minimum Illumination
Electronic Shutter (ELC)
S/N Ratio
Gain Control
BLC Backlight Compensation
White Balance
AE Compensation
EV Compensation
Focusing System
Preset
Pan Range
OSD
Camera Control
Baud Rate
Protocols
Alarms
IP integration
Operating Temperature
Power Supply
Power Consumption
Manual Pan Speed
Tilt Range
Manual Tilt Speed
Preset Speeds
DIMENSIONS (mm)
300
306
238
225
213
10
110
84
60
41
140
160
191
251
10
’ 218
’ 152
’ 236
NSD-H6HE / NSD-H8HEB
www.hesa.com
NSD-H6HI / NSD-H8HIB
’ 152
NSD-H6HS / NSD-H8HSB
CCTV PRODUCTS
208
Camera Servers
1 & 4 Channel Camera Servers
SN-H1SD
H.264 1-Channel camera server
SN-H1SDW
H.264 1-Channel camera server, Wi-Fi
SN-H4SD
H.264 4-Channel camera server
SN-H4SDW
H.264 4-Channel camera server, Wi-Fi
FEATURES
• Support Full D1 Resolution
(NTSC:720 x 480, PAL: 720 x 576)
• Real-time display up to 30FPS / NTSC,
25FPS / PAL with D1 resolution
• 3 Streaming MPEG4 / MJPEG / H.264
• Support dynamic IP, PPPoE via free
DDNS service
• Support RS-485 to control the speed
dome
• SD Back Up for Data Storage
Application
• Wired / Wireless Network
(SN-H1SD / SN-H1SDW only)
• 2 way audio function
• Support 3Gpp service
• Support Maxi-Watch Professional IP
software (option)
• Free Bundle Basic 36 Channel
Recording Software Provided
• SDK for software integration provided
upon customer request
• CMS support (option)
SPECIFICATIONS
Model
Video input
Wi-Fi
Risoluzione immagini
Compression format
Image Frame Rate
Motion Detector
Network Protocol
Remote Connection
Input / Output
Back-up
SDK
Power supply
Power consumption
CODE
KUNS1SH
KUNS1SWH
KUNS4SH
KUNS4SWH
www.hesa.com
MODEL
SN-H1SD
SN-H1SDW
SN-H4SD
SN-H4SDW
SN-H1SD
SN-H1SDW
SN-H4SD
1
–
SN-4HSDW
4
YES
–
YES
D1 (720x576), 4 CIF (704x576), CIF (352x288), QCIF (176x144)
streaming MPEG-4/
streaming
streaming MPEG-4/MJPEG/H.264
MJPEG/H.264
H.264/MJPEG
D1 at 25 fps
D1 at 20 fps
su 3 aree indipendenti
1 Area 1 Channel
HTTP, TCP/IP, SMTP, FTP, PPPoE, DHCP,
HTTP, TCP/IP, SMTP, FTP,
DDMS, NTP, UPnP, 3GPP
PPPoE, DHCP, DDMS, NTP
up to 10 simultaneous users
1 video input, 1 video output
4 video input, 4 video output
2 alarm input, 2 relay output
4 alarm input, 4 alarm output
1 audio input, 1 audio output
4 audio input, 1 audio output
1 RS232 port
1 RS232 port, 1 RS485 (PTZ) port
1 RS485 (PTZ) port
SD Card
disponibilità protocollo per integrazione
12VDC / POE
12VDC
4W
DESCRIPTION
H.264 1-Channel camera server, SD backup
H.264 1-Channel camera server, SD backup, Wi-Fi
4-Channel camera server, SD backup, streaming MPEG4/MJPEG/H.264
4-Channel camera server, SD backup, Wi-Fi, dual streaming H.264/MJPEG
209
Encoder/Decoders
ED-1SDH
1-Channel video Encoder/Decoder
ED-1SDHW
1-Channel video Encoder/Decoder, Wi-Fi
FEATURES
• H.264 / MPEG4 / M-JPEG compression
• Support SD card
• Wireless (ED-1SDW only)
SPECIFICATIONS
Model
Video In / Out
Audio In / Out
I/O
RS 485
Wireless
Network Protocol
Effective Pixels
Compression Format
Motion Detection
Simultaneous Connection
Power Consumption
CODE
KUNE1SH
KUNE1SHW
www.hesa.com
MODEL
ED-1SDH
ED-1SDHW
ED-1SDH
ED-1SDHW
1 In / 1 Out
1 in / 1 Out
2 in / 2 Out
1
–
YES
HTTP,TCP/IP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP ,UPnP, 3GPP
720x576, 704x576, 352x288, 176x144
H.264 / JPEG-4 / MPEG4
3 different areas
UP to 10
12VDC, 4W
DESCRIPTION
1-Channel Video Encoder/Decoder, SD backup
1-Channel Video Encoder/Decoder, SD backup, Wi-Fi
CCTV PRODUCTS
210
IP video transmission on coaxial cable
IP Transmitters
FEATURES
• Send IP Camera Signal Over existing
Coaxial Cable.
• Passive, no power required.
• Exceeds 802.3 10BaseT NEXT
specification, isolating the receiver
from the transmitted signal.
• Transmission up to 200 meters (Max.)
NTC-P01
IP Ectender Over Coax
IP Camera
or
Video Server
NTC-P01
Coaxial cable RG59 200m (Max)
NTC-P01
computer
NTC-P01K
4 x IP extender With 4 port Ethernet
Switch Kit
IP camera
NTC-P01 Coaxial cable RG59 200m (Max)
IP camera
NTC-P01 Coaxial cable RG59 200m (Max)
IP camera
NTC-P01 Coaxial cable RG59 200m (Max)
IP camera
NTC-P01 Coaxial cable RG59 200m (Max)
NTC-P01H
4 port Switch Ethernet
NVR
NTC-111VPLK
KIT Video & Power Transmission over one
CAT5 cable
Power supply
Camera power supply
BNC
CODE
KUNTCP01
KUNTCP01K
KUNT111LK
www.hesa.com
MODEL
NTC-P01
NTC-P01K
NTC-111VPLK
TTP111VPJ-L
FEATURES
• Package include 4 pcs x TCP01, 1pcs x
TCP01H with power adapter.
• TCP01H: Ethernet Switch with 4Port
10Base-T+ 1Port 10/100 Base-T
• Built in 4 pcs TCP01 with BNC
interface, to send and extender.
• TCP/IP signal coaxial cable.
• 4Port 10 Base-T over coax cable +
1Port 10/100base-T over CAT5 cable.
• Complies with IEEE802.3.
BNC
DESCRIZIONE
IP/coax transmitter single camera
4 x IP extender With 4 port Ethernet Switch Kit
KIT Video & Power Transmission over one CAT5 cable
FEATURES
• With Pigtail version for easy mounting
and installation.
• Compact size with pigtail, could be
mounted multi whits behind multiplexer, quad, DVR
211
Maxi Watch Professional Software
SWN-MWIP
Maxi Watch IP software
FEATURES
• Recording dynamic or static live video
synchronously with IP cameras up to
64 channels
• Dual Monitoring live display and
playback support
• Recording time could be set and
adjusted by user to fit in with the local
law or the requirement of the
organization
• Support all series IP cameras and
Megapixel of HESA, Axis, ACTi, Arecont
Vision, D-Link, Etrovision, Hitron, IQ
eye, JVC, Level one, Lumenera,
Mobotix, PIXORD, PLANET, PANASONIC,
Probe, Samsung, SONY, Toshiba,
Vivotek, ZAVIO, Atlantis
• Other servers in local network could
install free user terminal software
SPECIFICATIONS
Model
Number of cameras
Audio support
Monitoring Mode
Camera Display
Recording Mode
Recording FPS
Video Analytics
Alerting
Playback
Remote
User Account
CODE
KUNSWMI4
KUNSWMI8
KUNSWMI16
KUNSWMI25
KUNSWMI32
KUNSWMI64
www.hesa.com
MODEL
SWN-MWIP4
SWN-MWIP8
SWN-MWIP16
SWN-MWIP25
SWN-MWIP32
SWN-MWIP64
Maxi Watch Professional Software
8 channel 16 channel 32 channel 64 channel
Max. 64 Audio In
1/4/6/9/10/13/16/ Ntype (25,36,49,64) divided screen
Rotation Window, Dual Monitor Display support
Continuous recording
Record by Event
Record by schedule
Record by motion
Record with Audio
Auto Recycle support
30 FPS
General motion, Missing object, Foreign object,
Lose focus, Counting Application
Email, Phone call, Sound playing, IO control,
Alert on screen, PTZ preset go
Simultaneous Playback 16 Channel
Regular Playback Mode
Search Mode With Analytic Feature
Video Enancement Tool Supported
Remote Live View Client 16 Channel
Remote Playback Client 16 Channel
IE Browser Client
Password restriction on user rights
4 channel
DESCRIPTION
Maxi Watch IP software 4 cameras
Maxi Watch IP software 8 cameras
Maxi Watch IP software 16 cameras
Maxi Watch IP software 25 cameras
Maxi Watch IP software 32 cameras
Maxi Watch IP software 64 cameras
• Recording mode - continuous record,
record by event, record by motion and
record by schedule
• Support video smart analysis software
such as Missing object, Foreign object,
Lose focus, Cameras occlusion and
Signal lost. Users could be alarmed by
display on screen, Play sound, Send
e-mail, Phone call, PTZ preset go and
Signal digital output
• Monitoring on condition of connection
such as account, log in time, flow rate
and IP address
• Support the newest 3Gpp format
service
• Counting application to count people
or cars flow
• User-friendly GUI interface recording
schedule support
• Optional I/O integration for alarm
control
• Remote access via web browser
• CMS support (option)
CCTV PRODUCTS
212
NVR System High Density Recording and Management for IP Cameras
FEATURES
• Windows Embedded operation system
• Operation System Software in DOM
(Disk On Module)
• Up to 64 Channels Live surveillance
• External SATA Disk (Max. Up to 4HDD,
3TB) Raid Level 0, 1, 0+1, 5 support
• Real Time video and audio recording
• Support TCP / IP, DDNS and DHCP via
router
• Support NAS or USB external Device
• Remote Viewing and Playback via Web
browser and AP software
• Support alarm message through
E-mail or phone call
NVR-4S
4 Channels Network Video Recorder
NVR-16S
16 Channels Network Video Recorder
NVR-8S
8 Channels Network Video Recorder
NVR-32S
32 Channels Network Video Recorder
• Support 3GPP Service
• Maxi Watch Megapixel TCP-Plus
software support (option) with
Megapixel brands include Arecont
Vision, Axis, IQinvision, Lumenera,
Mobitix and Vivotek
• Embedded smart guard system to
handle unusual events and instant
notification actions
• GUI interface to setup recording
schedule
• Dual monitor support for viewing live
video and playback
• Enable I/O connection on cameras
• Printing and image / video export
support
• Support video smart analysis software
such as Missing object, Foreign object,
Lose focus, Cameras occlusion and
Signal lost. Users could be alarmed by
display on screen, Play sound, Send
e-mail, Phone call, PTZ preset go and
Signal digital output
• Complete system and event log
database
• Enables manual control, preset and
patrol of PTZ and dome camera
• CMS Support (option)
SPECIFICATIONS
Model
Number of IP channels
Sensor Input / Relay Output
Compression Standard
VGA Output
Communication Protocols
Video Encryption
Operation System
Back Up Function
Language
Redundant Power Supply
Size (Lx W x H)
www.hesa.com
NVR-4S
4
NVR-8S
NVR-16S
NVR-32S
8
16
32
4 in / 4 out and 16 in / 16 out
MPEG4 / JPEG
24 Bit True Color
TCP / IP, DHCP, PPPoE
Yes
Windows XP
SCSI / USB Interface HDD / CDR-W / DVD-RW
Internal IDE or SATA Hard Disk (Max. Up to 4HDD, 3TB)
English, Chinese, France, Germary, Spain, Russian,
Italian, Portuguese, Greek
100V ~ 240VAC Auto Switch
51cm x 45cm x 38cm
213
NVR System High Density Recording and Management for IP Cameras
CMS
Dual monitor
Live
Remote
Browser
Playback
Remote Ap
Software
IP Cameras
PDA
External I/O Device
(max. 16 in or 16 out)
Smart Phone
Alarm
In
CODE
KUNVR4
KUNVR8
KUNVR16
KUNVR32
MODEL
NVR-4S
NVR-8S
NVR-16S
NVR-32S
Accessories
KUNVR414U NVR-414U
KUNVR16I
NVR-16I
KUNVR16U
NVR-16U
KUNVRTC1
TCP-1M
www.hesa.com
Alarm
Out
Alarm
In
Alarm
Out
Disk Array
RAID 0.1, 0 + 1.5
DESCRIPTION
4 Channels Network Video Recorder and Management System
8 Channels Network Video Recorder and Management System
16 Channels Network Video Recorder and Management System
32 Channels Network Video Recorder and Management System
GPIO Module 4 digital input/output, comunication interface RS485, transmission
distance max. m500
GPIO Module 16 digital input/4 digital output, comunication interface RS485,
transmission distance max. m1200
GPIO Module 16 digital output, comunication interface RS485, transmission distance
max. m1200
Additional 1 IP camera licence
NVR-414U
NVR-16I
NVR-16U
CCTV PRODUCTS
214
Mini-NVR System High Density Recording and Management
for IP Cameras
NVR-M2
Mini NVR 2 Channels Network Video
Recorder
NVR-M8
Mini NVR 8 Channels Network Video
Recorder
NVR-M4
Mini NVR 4 Channels Network Video
Recorder
NVR-M16
Mini NVR 16 Channels Network Video
Recorder
FEATURES
• Linux embedded - Free from PC crash
and virus attack
• Browser as Microsoft Internet Explorer
• Online GUI recording schedule
• Support Megapixel Camera and H.264
Compression Format
• Support D1, Real-time Recording
• Support RAID 0, 1, 5, 5+spare, 10,
prevention of dat loss
• Recording without PC turning on
• CMS Support (option)
• Support audio recording
• Camera I/O integration
• Real-time digital output, email and
CMS alert
• Four kinds of user authorities:
administrator, power user, user, and
guest
• Log System
• Support Point of Sale (POS)
SPECIFICATIONS
Model
Operation System
Browser
Recording IP Cameras
LAN Transmission Speed
I/O Interface
RAID Level
Recording performance
Compression Format
Number of Drives
Recording Type
Smart Search
Auto Backup
Temperature Operating:
Power Supply
Weight kg
Dimensions (mm)
NVR-M2
NVR-M4
2
NVR-M16
8
16
4
10/100/1000 Mbps (RJ45)
1xUSB 2.0 (for UPS)
2xUSB 2.0 (for UPS)
RAID 0, 1
RAID 0, 1, 5, 10
Camera dependent
Camera dependent
Camera dependent
(Around 60fps at 1.3M)
(Around 185fps at 1.3M)
(Around 160fps at 1.3M)
Total bitrate: 20Mbps
Total bitrate: 65Mbps
Total bitrate: 55Mbps
H.264, M-JPEG, MPEG4, MxPEG (Depends on IP camera)
2 SATA II
4 SATA II
Continuous record, Record by schedule, Manual record, Event trigger record, Digital input trigger record
General motion, Missing object, Foreign object, Lose focus, Camera occlusion
Automatically backup the recorded video of the previous date to FTP
5°C to 35°C
100~230VAC
1
2.5
146x92x214
153x189x228
CODE
KUNVRM2
KUNVRM4
KUNVRM8
KUNVRM16
MODEL
NVR-M2
NVR-M4
NVR-M8
NVR-M16
DESCRIPTION
Mini NVR 2 Channels Network Video Recorder
Mini NVR 4 Channels Network Video Recorder
Mini NVR 8 Channels Network Video Recorder
Mini NVR 16 Channels Network Video Recorder
Accessori
AIXHD5S
AIXHD1TS
HDD500GB
HDD1TB
Hard Disk 500GB Sata 2, 7200 RPM, including mounting
Hard Disk 1TB Sata 2, 7200 RPM, including mounting
www.hesa.com
NVR-M8
Linux embedded
Internet Explorer
215
Central Management System (CMS)
• Alarm Priority: four different priorities
(critical, high, normal, low) can be
defined for each alarm so that user
can deal with alarms in order.
• Alarm Coverage: user can define a
valid period time for each alarm, for
example, detecting general motion
only during off-office time.
• Alarm Management Guide: when an
alarm occurs, user can access
management guide from the alarm
notification on map.
• Alarm Procedure: user is allowed to
manually change the selected
one/multiple/all alarm status and
alarm priority. Also, alarm can be
assigned to different owners in case
default owner is unable to deal with it.
• Alarm Auto Notifications: when an
alarm occurs, client system can play
user-define sound, go to device's map
layer, popup device's live video
window, show live video or related
camera's live video in the chosen
matrix; server will send email or SMS
message to any selected user.
• Alarm Viewing: system will show the
specific alarm image and alarm detail
automatically once the alarm is
triggered. User can export selected
alarm details to Excel file or even print
alarm details.
www.hesa.com
• Advanced Alarm Search: when
searching for alarms, user can search
by alarm name, owner name, alarm
state, alarm priority, time periods,
source device and alarm type. By
editing/saving filter criterion, user can
access required alarm logs in an
efficient way.
• Live Matrix System
- Live Matrix System receives all
commands from CMS Client system
to enable live video viewing on CCTV
monitors.
- Each matrix can support up to 64
concurrent camera viewing.
- Support 9 various grid types.
- Support flexible auto scan viewing
mechanism and full screen video
preview with automatically hidden
toolbar.
- CMS Client User can activate
floating PTZ panel to manipulate
selected camera on the matrix
system.
- User can select any matrix grid to
popup live video associated with
alarms when events are detected.
- Client users can access to different
matrix profiles. System can save
unlimited matrix profiles and one
matrix profile can be loaded by
many users.
• Remote Playback System
- From CMS Client window, user can
access remote playback system for
any connected server.
- Support up to 16 concurrent camera
viewing.
- Support various grid types such as
1, 4, 9 and 16.
- Export video to "AVI" or "ASF" file;
Export single frame to "BMP" and
"JPEG" file.
- Support intelligent search for
general motion, missing object,
foreign object, lose focus and
camera occlusion
• User Group Authority: user can define
the authority of UserGroup in a most
flexible way. Privilege functions,
including alarm management, view
alarm image, view live video, view
recorded video, PTZ control, control
digital output and remote desktop,
and access devices can be defined
differently for each User Group.
• User Authority
- Each User belongs to one UserGroup
and shares the UserGroup's
authority. Moreover, coverage period
and access matrix profile can be
defined differently for each user.
- Build-in Remote Desktop CMS users
can configure each connected
surveillance server through remote
desktop protocol if they have remote
desktop authority.
CCTV PRODUCTS
216
SPECIFICATIONS
Model
Key features
Client Server Architecture
Supported Devices
Unlimited Server Solution
Multiple Matrix System
Live Viewing
Full Alarm Management
Triple Monitor Scenario
Default Monitor #1
Default Monitor #2
Default Monitor #3
CMS Server
Alarm Database
Central Server
Supported Notification Type
E-Map
Map Tree Hierarchy
Maps Formats
Define Surveillance Servers
Define Cameras
Navigation Tools
Indicators on Maps
Instant Status Notification
Intuitive Operation on Maps
Live Popup Window
Playback Popup Window
Alarm Management
Supported Alarm Type
Action when Alarm
Alarm Viewing
Alarm Detail Popup
Advanced Alarm Search
Matrix System
Live Viewing
Grid Type
View Type
Automatically Popup
PTZ Panel
Remote Playback System
Remote Playback
Grid Type
Export Function
Smart Search
Miscellaneous
UserGroup Authority
User Authority
Built-in Remote Desktop
CODE
KUNSWCMSB
KUNSWCMST
KUNSWCMSIO
KUNSWCMSPS
www.hesa.com
MODEL
SWN-CMS-BASE
SWN-CMS-ST
SWN-CMS-IO
SWN-CMS-POS
Central Management System (CMS)
One CMS server could be connected by several CMS clients
Support all NVR/NDVR site, as well as all IP camera brands supported by MaxiWatch. (HESAVISION IP, ACTi, Axis,
Panasonic, Sony, JVC, Lumenera, Arecont, IQeye, Mobotix, Panasonic, Pixord, Sony, VIVOTEK
Unlimited access of cameras and NDVR/NVR site
Unlimited matrix consoles could be connected through network
Up to 64 concurrent camera viewing for each matrix console
Acknowledge or manage alarm log in the most efficient way.
Navigation Panel / Map Section
Live Matrix System
Alarm List / Message List / Remote Playback
Use SQL Server 2005 Express to store all the alarms
Store the site map data by hierarchical structures,
Directly connect to surveillance server to get alarm notifications
Provide TCP service for CMS clients’ access through network, Registers different time zones into UTC format
Send E-mail / SMS message
Unlimited level of display site map
Supported image format: BMP, GIF, JPEG, PNG, and TIFF
New / Edit / Delete / Disable and Enable
New / Edit / Delete
Use to use zoom in, zoom out and drag operation
Indicators for maps, servers, cameras and I/O devices
Indicator icons support image format with alpha channel (TIFF)
Show correspondingly small icon nearby the devices automatically to notify users of the events
Open Last Alarm, Open Live Video Window, Open Instant Playback Window,
Backup Recorded Video, View Server Status Report
Live popup window to show live video with PTZ control panel
Remote playback popup window to show recorded video
Video Signal Abnormal, Digital Input Trigger (Normal / Emergency)
Network Abnormal, DVR / NVR Abnormal, Motion / Missing / Foreign / Focus / Blocked,
Low Disk Space, CPU temperature High / Fan Speed Low
Instant notifications on map and event list, Go to specific map layer, Play sounds, Send SMS, Send Email
Automatically show live video on popup window, Automatically show live video on live matrix system
Filter tools to survey existing alarm history
Show / Print a specific alarm with image preview
Access required alarm logs in the most efficient way
Up to 64 concurrent camera viewing
1, 4, 9, 13, 16, 25, 36, 49, 64
Flexible auto scan mechanism and full screen viewing
Show the live video associated with alarms
Floating PTZ panel to manipulate cameras on the matrix system
Up to 16 concurrent camera viewing
1, 4, 9, 16
Save as image and video, as well as printing
Fast search based on the specific event
Alarm Management, View Alarm Image, View Live Video, View Recorded Video, PTZ Control,
Control Digital Output, Remote Desktop, Access Devices
User/Password, Phone Number, Email, UserGroup, Coverage, Matrix Profile
CMS could control NVR/NDVR through remote desktop protocol
DESCRIPTION
Central Management System. Includes 1 basic licence, 48 camera connections, 8 I/O connections
Central Management System. Includes 1 basic licence camera additional
Central Management System. Includes 1 basic licence input/output additional
Central Management System. Includes 1 basic licence POS
CCTV PRODUCTS
220
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber integrated transmitter
www.hesa.com
TCC-74LW
IR Camera 40m range,
Vari-Focal 3.8-9.5 mm, 550 TVL,
12VDC/24VAC
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• 550TVL resolution: 550TVL (color),
580TVL (B/W)
• 3.8~9.5mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Function selection dip switch built-in CDS switching time, FLK, BLC, AWB
• DC iris level adjustment volume built-in
• Viewable length at night over 40m
• CDS auto switching IR LED control
• 36pcs LEDs built-in
• 24VAC/12VDC dual power source
• Cable managed bracket
• Weatherproof (IP66)
• Integrated connector for signal
transmission over Plastic Optical Fiber
up to a distance of 300m
TCC-75LW
IR Camera 40m range, Vari-Focal
3.8-9.5 mm, 550 TVL, EX-View,
12VDC/24VAC
FEATURES
• Sony 1/3” EX-View high-resolution
color CCD
• 550TVL hi-resolution: 550TVL (color),
580TVL (B/W)
• 3.8~9.5mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Focal length, focus and DC iris level
externally adjustable
• Two glasses adapted
• Viewable length at night over 40m
• CDS auto switching IR LED control
• 36pcs LEDs built-in
• Service monitor (second video) port
built-in
• 24VAC/12VDC dual power source
• Cable managed bracket
• Weatherproof (IP-66)
• Trasmission distance up to 150m
• Integrated connector for signal
transmission over Plastic Optical Fiber
up to a distance of 300m
221
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiberintegrated transmitter
SPECIFICATIONS
Model
TCC-74LW
1/3” Color
Sony Super HAD
CCD Image Sensor
Effective Pixels (HxV)
TCC-75LW
1/3” Color
Sony EX-View
752x582
550 TVL Color
580 TVL B/W
0 lux with LED ON
> 48dB
Auto 1/50~1/110.000sec
DC drive
vari-focal
mm 3.8~9.5 @ F1.2
Internal
AGC
YES (2500°K~9500°K)
ATW/AWC selectable
YES
36 IR LEDs
m 40
IP66
12VDC/24VAC
260mA (IR OFF)
320mA (IR OFF 12VDC)
530mA (IR ON)
680mA (IR ON 12VDC)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Electronic Shutter
Lens
Synchronization
Gain Control
White Balance
Back Light Compensation
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Plastic Fiber transmission system
Bandwidth
Transmission distance
Optical connector
Operating Temperature
0 ~ 5.5 MHz
120 m ~ 300 m
SMA
-10°C~+50°C
DIMENSIONS (mm)
140
155
95
82
77
’70
83
134
TCC-74LW
CODE
KUTC74LW
KUTC75LW
www.hesa.com
’110
∅73
85
123
95
∅110
TCC-75LW
MODEL
TCC-74LW
TCC-75LW
DESCRIPTION
1/3” IR D&N Color camera, 550TVL, vari-focal, IR 40m range, integrated transmitter, 12VDC/24VAC
1/3” IR D&N Color camera, 550TVL EX-View, vari-focal, IR 40m range, integrated transmitter, 12VDC/24VAC
CCTV PRODUCTS
222
Day/Night Color Cameras
IR Outdoor Cameras, Vari-Focal, ICR Filter and Plastic Fiber integrated transmitter
DOMEHC-5LW
550 TVL, Vari-Focal, Vandalproof IP66,
IR LED, 12VDC/24VAC
FEATURES
• 1/3” Sony Super HAD High-Resolution
Color CCD
• 550TVL High-Resolution
• F=3.8~9.5mm Vari-focal/ F1.2 built-in
• Color & B/W Auto Switchable by
Photocell
• Auto Switching IR-LED control (36pcs)
• Built-in function selection dip switch
- ICR switching time, FLK, BLC, white
balance
• Built-in DC Iris level adjustment volume
• Easy adjustment of focal length & focus
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
Lens
Video output
UTP signal level
S/N Ratio
Electronic Shutter
IR LED
Synchronization
Iris Control
Gain Control
White Balance
Power Supply
Power Consumption
IP Rating
Operating Temperature
Operating Humidity
Dimension
Weight g
CODE
MODEL
KUDOMH5LW DOMEHC-5LW
www.hesa.com
• Built-in UTP transmitter with UTP
cable length switch
• Built-in service monitor port
• 3-AXIS gimbal bracket
• Flush & surface mount
• Vandal resistant & Weatherproof
housing (IP66)
• Power: 24VAC/12VDC
• Integrated connector for signal
trasmission over Plastic Optical Fiber
up to a distance of 150m
DIMENSIONS (mm)
DOMEHC-5LW
1/3” Color Sony Super HAD High-Resolution
752x582
550 TVL Color
580 TVL B/W
0 lux (LED ON)
Vari-Focal 3.8~9.5mm /F1.2
VBS 1.0Vp-p (751 Load)
Short 1.0Vp-p/Long 2.5Vp-p
> 48dB (AGC OFF)
Auto 1/50sec
36
Internal
DC drive
AGC
ATW/AWC Selectable
12VDC/ 24VAC ±10%
650mA@12VDC (LED ON)
13VA@24VAC (LED ON)
IP66
–10°C~+50°C
Max. 90% RH
157mm (Ø) x 110mm (L)
1014
146
108
DOMEHC-5LW
DESCRIPTION
1/3” IR Color Dome Camera 550TVL, Vari-Focal, Day & Night, LED IR, 12VDC/24VAC
40
18
50
99 146
223
Twisted-Pair Systems for Color Video Transmission
Video Transceiver
UTP-111VL
Video Transceiver with 250mm Mini Coax
Cable
UTP-111VT
Video Transceiver BNC Male to Terminal
Block
FEATURES
• BNC male to terminal block
• Weatherproof IP65
• Compact size; pigtail could be
mounted multi units behind
Multiplexer, Quad, DVR
FEATURES
• BNC male to 2-pin terminal block
UTP-111VK
UTP Video Kit (UTP-111VL + UTP-111VT)
FEATURES
• UTP Video Kit (Tx+Rx) fast and easy to
install. Range of transmission: B/W
signal 600m, color signal 400m
UTP-SPB1
Twisted-Pair Video Balun
FEATURES
• Eliminate interferences under long
range cabling caused by “Impedance
Matching”. Add UTP-SPB1 at
“connecting point” between two-wire
connections for compensation
UTP-KM01
Keyboard mouse CAT5 extender - PS/2
interface
UTP-VKM01
VGA Keyboard mouse CAT5 extender PS/2 interface
UTP-HDMI
HDMI CAT5 extender, Single CAT5 Cable
FEATURES
• Transmission range up to 100 meters
• Including transmitter: dual 6 pin mini
DIN male for keyboard/mouse side to
RJ45 and Receiver: dual 6 pin mini DIN
female with 6” lead for PC side to RJ45
FEATURES
• Extend VGA and Keyboard mouse over
2 CAT5 UTP cable to instead of VGA
cable and Keyboard mouse cable
• Transmission range up to 100 meters
• Including local and remote units
FEATURES
• HDMI 1.2 compliant
• Transmission rang up to 40 meters at
1080p resolution
• Minimize the cable skew by adjustable
equalization with 8 levels
• HDCP compliant
CODE
KUU11VL
KUU11VT
KUU11VK
KUUSPB1
KUUKM01
KUUVKM01
KUUVKM01
www.hesa.com
MODEL
UTP-111VL
UTP-111VT
UTP-111VK
UTP-SPB1
UTP-KM01
UTP-VKM01
UTP-HDMI
DESCRIPTION
Video Transceiver with 250mm Mini Coax Cable
Video Transceiver BNC Male to Terminal Block
UTP Video Kit (UTP-111VL + UTP-111VT)
Twisted-Pair Video Balun
Keyboard mouse CAT5 extender - PS/2 interface, passive no power required
VGA Keyboard mouse CAT5 extender - PS/2 interface, passive no power required
HDMI CAT5 extender, Single CAT5 Cable
CCTV PRODUCTS
224
Twisted-Pair Systems for Color Video Transmission
Receivers & Extenders
VE05AL
1 In 5 Out VGA with Stereo Audio CAT5
Extender Distribution Amplifier,
Chainable Function
FEATURES
• Each set including one piece VE05AL
transmitter and one piece VE02ALR
receiver
• Dual output: 1VGA loop output for
local, plus 4 x CAT5 RJ45 output for
remote side
• Each VGA display equipment request
one VE02ALR receiver at remote side
(order separately)
• Long range transmission up to 300
meters (max.)
• Supports up to 1600x1200 @ 85Hz
VE02ALR
VGA with Stereo Audio CAT5 Receiver,
Chainable Function
FEATURES
• Work with VE02ALR, VE05AL as
receiver for extra remote VGA display
equipment
• It could be daisy chained for another
VE02ALR to extended working range
over 300 meters and multiple displays
• Built-in equalization, gain adjustment
• Supports up to 1600x1200 @ 85Hz
WIRING DIAGRAM
VE02ALR#1
VE05ALT
VE02ALR#2
VE02ALR#n
CODE
KUUVE05
KUUVE02R
www.hesa.com
MODEL
VE05AL
VE02ALR
DESCRIPTION
1 In 5 Out VGA with Stereo Audio CAT5 Extender Distribution Amplifier, Chainable Function
VGA with Stereo Audio CAT5 Receiver, Chainable Function
225
Twisted-Pair Systems for Color Video Transmission
Channel Video Transceivers & Cable Hub
UTP-414V
4 Channel Video Transceiver & Terminal
Block
UTP-P414V
4 Channel Cable Hub
UTP-444VPD
4 Channel Video Transceiver
FEATURES
• 4 x BNC female to 1 x RJ45 female +
8 pin terminal block
• 4 passive transceivers in one product
FEATURES
• 4 RJ45 female to 1 x RJ45 female
Cable Hub
• Combine 4 UTP cables into 1 cable
FEATURES
• 4 x BNC female to 4 x RJ45 female
• 4 passive transceivers in one product
WIRING DIAGRAM
UTP-414VD
4 Channel Video Transceiver with Data
14VDC 150mA 200m
12VDC 150mA 150m
12VDC 250mA 60m
FEATURES
• 4 x BNC female + 1 RJ45 female + 1
terminal block (for RS485/RS422 data
transmission)
• Using 4 pairs CAT 5 Cable to
transmit/receive 3 sets video signals
plus 1 data signal or transmit/receive
4 sets video signals only
UTP-444VPD
DVR
keyboard
UTP-111VPD
CODE
KUU414V
KUU444V
KUU414P
KUU414D
www.hesa.com
MODEL
UTP-414V
UTP-444VPD
UTP-P414V
UTP-414VD
DESCRIPTION
4 Channel Video Transceiver and Terminal Block
4 Channel Video Transceiver 4 x BNC Female to 4 x RJ45 Female
4 Channel Cable Hub
4 Channel Video and Data Transceiver
CCTV PRODUCTS
226
Twisted Pair Systems for Color Video Transmission
Channel Video Transceivers & Cable Hub
4 Cameras to Hub CCTV
WIRING DIAGRAM
B/W 600 m, color 400 m (max)
UTP-414V
UTP-111VT
DVR
UTP-P414V
Speed-Dome Data Transmission Application
WIRING DIAGRAM
600 m (max)
QUAD
SPEED-DOME
UTP-414VD
www.hesa.com
UTP-414VD
CONTROLLER
227
Twisted-Pair Systems for Color Video Transmission
Channel Video Transceivers & Cable Hub
Transmitter
Receiver
UTP-A111AV
Active Video & Audio & Data Twisted Pair
Transmission
UTP-A111V
Active Video Twisted Pair Transmission
Kit, 1 Channel
UTP-A414VR
4 Channel Active Receiver
FEATURES
• Transmit video, audio and data signal
(RS422, RS485)
• Three position range switch for gain
select on transmitter
• Five position distance range switch on
Receiver, brightness adjustment, two
video output
• Built in transient protection and
ground lifting
FEATURES
• Kit made of UTP-A111VT Transmitter
and UTP-A111VR Receiver
• 3 position range switch for gain select
on trasmitter
• Easy setting with 2 adjustments for
color gain & brightness at
UTP-A111VR Receiver
• Built in transient protection & ground
lifting
• System integrated with alarm sensor
(PIR, magnetic, etc.) or RS485/422 data
FEATURES
• Built in 4 port active receivers
• Others identical same as SP-A111VR
• Built in a highly balanced mode of
video transmission for extra
interference immunity
CODE
KUUA11AV
KUUA11V
KUUA414V
MODEL
UTP-A111AV
UTP-A111V
UTP-A414VR
Accessories
CVUTPC5
CV-UTPC5
CVUTPAC5
CV-UTPAC5
CVUTPTK
CV-UTPTK
CVUTPSF
CVUTPCT
CV-UTPBNCSF
CV-UTPCT
CV59CT
CVUTPRJ1
CVUTPRJC
CV-59CT
CV-UTPRJ1
CV-UTPRJC
www.hesa.com
DESCRIPTION
Active Video & Audio & Data Twisted Pair Transmission
Active Video Twisted Pair Transmission Kit, 1 Channel
4 Channel Active Receiver
CAT5 UTP 4 Pair Twisted Pair Cable 305m
CAT5 UTP 4 Pair Twisted Pair Cable + power wire, 100m
Twisted Pair Tool Kit iclude: Ratchet modular connector crimping
tool crimping tool, for 6P2C, 8P8C modular connector stripper &
punch down tool, universal coacial crimping tool, RJ11 modular
plug (6P4C flat) x 50pcs, RJ45 Modular (8P8C round solid) x 25pcs,
RJ45 protection cap x 20pcs
Multi-Function Wire Stripper
Modular Crimping Tool, for 4, 6, 8 poles modular stripper is simple
(RJ45, RJ11 ratchet type. This tool is for all necessary tools to cut,
strip and crimp modular telephone wires
Coaxial Crimp Tool, application for crimping RG59 RG6 cable
Modular RJ45 Plug, pack of 10 pcs
RJ45 Protection Cap 100pcs
CV-UTPC5
CV-UTPAC5
CV-UTPTK
CV-UTPBNCSF
CV-UTPCT
CV-59CT
CV-UTPRJ1
CV-UTPRJC
CCTV PRODUCTS
228
Twisted-Pair Systems for Color Video Transmission
Video Interference
CODE
KUUTGP1
KUUTGP1H
www.hesa.com
MODEL
UTP-TGP1
UTP-TGP1H
UTP-TGP1
Twisted Pair Ground Loop lsolator built in
Video BALUN
FEATURES
• BNC male to 2 pin terminal block
• Others same as GL001 Ground Loop
lsolate function
• Built in Video BALUN, color video
signal up tp 300 meters
• Elimate Coaxial Cable
• Built in TVS ( Transient Voltage
Suppressors) for surge prtection
UTP-TGP1H
Twisted Pair Hi Performance Video
Ground Loop lsolator
FEATURES
• Identical to above, but for twisted pair
cable use
DESCRIPTION
Twisted Pair Ground Loop lsolator built in Video BALUN
Twisted Pair Hi Performance Video Ground Loop lsolator
229
Day/Night Color Cameras
UTP Cameras
TCC-74BU
IR Camera 40m range, Vari-Focal
2.8-11 mm, 600 TVL, 12VDC/24VAC
DOMEHC-5BU
IR Camera 30m range, Vari-Focal
2.8-11 mm, 540 TVL, 12VDC/24VAC
FEATURES
• 1/3” Sony Super HAD II High-resolution
color CCD
• 600TVL High-resolution
• f=2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens built-in
• Built-in 2DNR, OSD function
• Back Light or High Light
Compensation (BLC/HLC) function
• Auto switching IR LED control by
photocell
FEATURES
• Sony 1/3” Super HAD high-resolution
color CCD
• 540TVL hi-resolution
• 2.8~11mm vari-focal, DC auto iris
F1.2 day & night lens
• Built-in function selection dip switch
- ICR switching time, FLK, BLC, white
balance
SPECIFICATIONS
Model
CCD Image Sensor
Effective Pixels (HxV)
Horizontal Resolution
Minimum Illumination
S/N Ratio
Lens
UTP Signal Level
Synchronization
Gain Control
White Balance
Back Light Compensation
IR LED
IR Distance
IP Rating
Power Supply
Power Consumption
Operating Temperature
Operating Humidity
CODE
MODEL
KUTC74BU
TCC-74BU
KUDOMH5BU DOMEHC-5BU
www.hesa.com
• IR LED: 36pcs
• Built-in UTP transmitter with UTP
cable length switch
• Built-in Service monitor port &
External OSD Set-up Port
• Cable managed bracket
• Weatherproof Housing (IP-66)
• Power: AC24V/DC12V
• Built-in DC Iris level adjustment volume
• Auto switching IR-LED control (36pcs)
• Easy adjustment of focal length & focus
• Built-in service monitor port
• 3-AXIS gimbal bracket
• Flush & surface mount
• Vandal resistant & weatherproof
housing (IP-66)
DIMENSIONS (mm)
TCC-74BU
DOMEHC-5BU
1/3” Sony Super HAD II
1/3” Sony Super HAD
High-resolution Color CCD
752x582
600 TVL Color
540 TVL Color
650 TVL B/W
580 TVL B/W
0 lux with LED ON
> 48dB
f=2.8~11mm Vari-focal, DC Auto Iris F1.2 D/N
Short 1.0Vp-p/Long 2.5Vp-p
Internal
AGC
ATW1 / ATW2 / AWC / Manual
ATW/AWC selectable
YES
36 IR LEDs
m 40
m 30
IP66
12VDC/24VAC
9.5VA (LED ON 24VAC)
13VA (LED ON 24VAC)
530MA (LED ON 12VDC)
550mA (LED ON 12VDC)
-10°C~+50°C
Max. 90% RH
92
192
103
80
113
177
TCC-74BU
149
102
DOMEHC-5BU
DESCRIPTION
1/3” IR D&N Color camera, 600 TVL, vari-focal, IR 40m range, 12VDC/24VAC
1/3” IR D&N Color camera, 540 TVL, vari-focal, IR 30m range, 12VDC/24VAC
36
16
50
116146
HESA S.p.A.
Via Triboniano, 25 - 20156 MILANO - ITALY
Phone: +39.02.380361
Fax: +39.02.38036701
[email protected] - www.hesa.com

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
