Slim Under Cabinet Interior Design
Bass Reflex Sound System
Built-in Audio Cable with Attachable Holder for Digital Music Players
Digital FM/AM Tuner with 15 Presets
Easy Set, One Touch Cooking Timer
CD-R/RW Playback1
ATS (Automatic Time Set)
Magnetic Remote Control (Included)
Slim Under Cabinet Interior Design brings a multi-media
entertainment center to your kitchen, mounting under a
cabinet so it takes up none of your precious counter area.
Bass Reflex Sound System produces rich, deep bass tones for
more powerful overall sound.
Built-in Audio Cable With attachable holder for easy play back
of digital music players.
Weight: 6.4 lbs (2.9kg)
Measurements: 13.7 x 3.4 x 12.2" (L:350 x H:88 x D:310mm)
Supplied Accessories
Remote Commander® Remote Control
Instruction Manual
Assurance Card
UPC Code: 027242726512
Digital FM/AM Tuner With 15 station presets makes tuning in a
desired station simple and precise with accurate, drift-free
tuning of AM and FM radio stations. Set up to 10 of your favorite
FM and 5 AM stations.
Easy Set , One Touch Cookign Timer is built-in and eliminates
the need for an additional timer in your kitchen for food
preparation and other purposes.
1. CD-R/RW media/formats are not universally compatible.
© 2008 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved.
Sony and Mega Bass are trademarks of Sony. Features and specifications are subject to change without
notice. All Weights and measures are approximate.
CD-R/RW Playback1 Accomodates not only factory-pressed
CD-Audio discs, but also consumer-recorded CD-R and CD-RW
ATS (Automatic Time Set) The correct EST(Eastern Standard
Time)has been preset at the factory so all you have to do is
plug it in and adjust the time zone if necessary. In the case of a
power interruption, the built-in Lithium battery maintains the
correct time so when the power returns you don't have to
reset the clock.
Magnetic Remote Control (Included) Play, Stop,Pause and
Search through a CD. Control the volume of the radio as well
as muting and radio funcitons with the remote control. And
with the magnetic backing you can attach it to your fridge so
you don't lose it.
Frequency Range: FM: 87.5-108MHz; AM: 530-1710kHz
Antenna System: Ferrite
Tuner Type: Digital
CD Play Mode(s): Shuffle, Repeat 1/All
Station Preset(s): 15 (FM:10; AM:5)
Timer Clock: Count-down Timer
Remote Control Functions: Preset, CD Play/Stop/Pause, CD
Track/Search, Volume Control, Muting, Band
Convenience Features
Clock: Forward/Reverse Time Setting
Remote Control: Remote Commander®
Display: Green LCD Backlit Color
Inputs and Outputs
Audio In: Stereo mini
Please visit the Dealer Network for current information at
Sony Electronics Inc. •16530 Via Esprillo •San Diego, CA 92127 •1.800.222.7669 •www.sony.com
Last Updated: 07/02/2008
