MC2: Practicality for Calibration
There are a few must-have tools for an instrument
technician: the MC2 is definitely one of them. The
MC2 series includes three different hand-held
calibrators for field use: the MC2 Pressure/Electrical
Calibrator, the MC2 Temperature/Electrical Calibrator
and the MC2 Multifunction Calibrator. An MC2 is a
compact and easy-to-use, hand-held calibrator.
Once you begin using any of the MC2 calibrators,
you will notice it is a straightforward, user-friendly
calibrator. First of all, the MC2 is compact in size
and design. It is easy to carry and use. Secondly, the
MC2 has a large graphical display, a menu-based
interface and full numerical keyboard. Performing
calibrations is quick and simple. In addition to this,
the standard rechargeable battery and battery
charger facilitate active use of MC2. Thirdly, the MC2
has impact protectors and a membrane keyboard.
This makes MC2 a robust, weatherproof calibrator
made to withstand tough use. Although the MC2 is
a straightforward, practical calibrator, it still provides
a wide range of functions and possibilities for
calibrating.
Being a Beamex calibrator, MC2 represents the
high, uncompromised quality standards evident in
other Beamex calibration equipment. It is another
MC calibrator you can rely on and a calibrator that
completes your range of MC calibrators.
The MC2 Series Includes
Three Different Portable Calibrators
MC2 Pressure/Electrical Calibrator, MC2 Temperature/Electrical Calibrator and MC2 Multifunction Calibrator.
A series of practical, compact and user-friendly portable calibrators for field use.
MC2 Feature comparison
Features
Internal pressure module
Connection for external pressure modules
Current measurement
(with internal and external supply)
Voltage measurement
Frequency measurement
Pulse counting
Switch sensing
Internal HART® compatible
24 VDC loop supply
Current generation
(with internal and external supply)
MC2-PE
Pressure/Electrical
Calibrator
MC2-TE
Temperature/Electrical
Calibrator
•
•
•
•
•
•
•
•
-
-
Voltage generation
-
Frequency generation
-
Pulse generation
-
mV measurement / simulation
-
Resistance measurement / simulation
-
RTD measurement / simulation
-
TC measurement / simulation
-
MC2-MF
Multifunction
Calibrator
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Features of the MC2 Calibrator
1
2
1.
MC2 has a large graphical display with
a multilingual interface. The interface
is menu-based, which makes the MC2
extremely user-friendly.
2.
MC2 provides a number of configuration
possibilities, such as both internal and
external pressure modules.
3
4
3.
MC2 is robust and made for tough use.
The impact protectors and membrane
keyboard make it field compatible and
weatherproof.
4.
MC2 has a full numerical keyboard.
Entering numbers is both quick and easy.
Other Advanced Features
Feature
Specification
Error % display
When calibrating a transmitter, the transmitter’s output may be displayed in an error % unit rather than in
an engineering unit.
Error display in input or
output units
When calibrating a transmitter, the transmitter’s output may be displayed as error in input or output
engineering units.
%-display
Any measurement or generation may be presented as a percent within the
user-programmable range.
Scaling
A versatile, programmable scaling function allows the user to scale any measured or generated unit into
any custom unit. Scaling also includes a rooting transfer function for flow applications, as well as custom
transfer functions.
User setups
The unit has a large number of user-configurable setups that make it easy to save and quickly recall the
desired configuration.
Leak testing
The leak test function indicates the pressure drop and leak rate during the user-programmable period.
Step and Ramp
The unit includes versatile and programmable automatic step and ramp generation function, as well as
manual step function.
Programmable alarms
Any measurement can be programmed to have an alarm based on the measurement value or on its
rate of change.
Damping
Programmable damping allows the user to select different filterings for the measurements.
Bar graph
The bar graph allows the user to display the measurement or generation as an analogue bar, including
programmable starting and ending points.
Difference
Difference measurement allows the user to measure the difference between two pressure modules.
Deviation
The deviation function allows the user to display a deviation between a given reference value and the
actual measurement.
Redundancy
Redundancy measurement allows the user to measure the same pressure using two pressure modules (internal
and external) simultaneously. The unit’s alarms sounds if the readings excessively differ from each other.
Additional information
The unit also allows the user to view various pieces of additional additional information such as Min / Max /
Rate / Internal temperature / Thermocouple’s thermovoltage / RTD sensor’s resistance /, etc.
Games
The unit even includes two games.
MC2 - General specifications for all models
General Specifications
Feature
Display
Weight
Dimensions
Keyboard
Battery type
Charging time
Charger supply
Battery operation
Battery operation with optional dry battery
cartridge and 4 alkaline AA cells
Operating temperature
Operating temp. while charging batteries
Storage temperature
Humidity
Warm-up time
Max. input voltage
Safety
EMC
Specification
60 mm x 60 mm (2.36” x 2.36”), 160 x 160 pixels, back lit LCD
720 ... 830 g (1.59 ... 1.83 lbs)
215 mm (8.5”) x 102 mm (4”) x 49 mm (1.9”) (d/w/h)
Membrane keyboard
Rechargeable NiMH pack, 4000 mAh, 3.6V DC
5 hours
100 ... 240 VAC, 50-60 Hz
13 ... 24 hours in measurement mode, back light off.
8 ... 12 hours when sourcing an average of 12 mA to loop, with back light on.
4 ... 8 hours in measurement mode, back light off.
3 ... 4 hours when sourcing an average of 12 mA to loop, with back light on.
-10 ... 50°C (14 ... 122°F)
0 … 35°C (32 ... 95°F)
-20 ... 60°C (-4 ... 140°F)
0 to 80% R.H. non-condensing
Specifications valid after a 5-minute warm-up period.
30 V AC, 60 V DC
Directive 73/23/EEC, EN 61010-1
Directive 89/336/EEC, EN 61326
Voltage measurement –1…60 V DC
Range
±0.25 V
±(0.25 ... 1 V)
1 ... 25 V
25 ... 60 V
Resolution
0.001mV
0.01 mV
0.1 mV
1 mV
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
>1 MW
V, mV, µV
3 / second
Input impedance
Supported units
Display update rate
1 Year Uncertainty(±)(1
0.02% RDG + 5 µV
0.02% RDG + 5 µV
0.02% RDG + 0.25 mV
0.02% RDG + 0.25 mV
mA measurement ±100 mA
Range
±25mA
±(25 ... 100 mA)
Resolution
0.0001 mA
0.001 mA
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
< 7.5 W
mA, µA
3 / second
Input impedance
Supported units
Display update rate
1 Year Uncertainty(±)(1
0.02% RDG + 1.5 µA
0.02% RDG + 1.5 µA
Loop supply
Feature
Maximum output current
Output voltage
Output impedance in HART® compatible mode
Specification
> 25 mA, short circuit protected
24 V ± 10%
300 W ± 20%
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2).
Electrical measurements
Frequency measurement 0.0027 … 50 000 Hz
Range
0.0027 ... 0.5 Hz
0.5 ... 5 Hz
5 ... 50 Hz
50 ... 500 Hz
500 ... 5000 Hz
5000 ... 50000 Hz
Resolution
0.000001 Hz
0.00001 Hz
0.0001 Hz
0.001 Hz
0.01 Hz
0.1 Hz
Feature
Temperature coefficient
Input impedance
Trigger level
Minimum signal amplitude
Supported units
Gate period
Specification
Specification valid from -10 to 50°C (14 ... 122°F)
> 1 MW
-1…14 V in 1 V steps and open collector inputs
2 Vpp (< 10 kHz), 3 Vpp (10...50 kHz)
Hz, kHz, cph, cpm, 1/Hz (s), 1/kHz (ms), 1/MHz (µs)
267 ms + 1 signal period
1 Year Uncertainty(±)(1
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2)
Pulse counting 0 ... 9 999 999 pulses
Feature
Range
Input impedance
Trigger level
Minimum signal amplitude
Specification
0 to 9 999 999 pulses
> 1 MW
-1 … 14 V in 1 V steps and open collector inputs
2 Vpp (pulse length > 50 µs), 3 Vpp (pulse length 10 ... 50 µs)
Switch test
Feature
Potential free contacts
Voltage level detection
Specification
Test voltage (Trigger level)
Trigger level
Input impedance
3 V, 0.13 mA (1 V) or 24 V, 35 mA (2 V)
-1…14 V in 1 V steps
> 1 MW
Pressure Measurements
Internal Pressure Modules (IPM)
Internal Module(3
IPM200mC
IPM2C
IPM20C
IPM160
Barometric option
Unit
Range(2
Resolution
1 Year Uncertainty(±)(1
kPa
±20
0.001
0.05% RDG + 0.05% FS
mbar
±200
0.01
iwc
±80
0.01
kPa
-100 to 200
0.01
0.05% FS
bar
-1 to 2
0.0001
psi
-14.5 to 30
0.001
kPa
-100 to 2000
0.1
0.05% FS
bar
-1 to 20
0.001
psi
-14.5 to 300
0.01
MPa
0 ... 16
0.001
0.05% FS
bar
0 ... 160
0.01
psi
0 ... 2400
0.1
Also enables absolute pressure measurement for the above pressure inputs. When using the
barometric option, add 0.1 kPa (0.0146 psi) uncertainty for absolute pressure measurement.
Feature
Temperature coefficient
Maximum overpressure
Pressure port
Media compatibility
Supported pressure units
Display update rate
Specification
< ±0.001% RDG /°C outside 15 … 35°C.
< ±0.0006% RDG /°F outside 59 … 95°F
2 × Range
G 1/8” female (G 1/8 (ISO 228/1) 60° internal cone adaptor, except IPM160)
Wetted parts: AISI316 stainless steel, Nitrile rubber.
Pa, hPa, kPa, MPa, mbar, bar, lbf/ft2, psi, ozf/in2, gf/cm2, kgf/cm2, kgf/m2, kp/cm2, at,
mmH2O, cmH2O, mH2O, iwc, ftH2O, mmHg, cmHg, mHg, inHg, mmHg(0°C), inHg(0°C),
mmH2O(4°C; 60°F; 68°F/20°C), cmH2O(4°C; 60°F; 68°F/20°C), inH2O(4°C; 60°F;
68°F/20°C), ftH2O(4°C; 60°F; 68°F/20°C), torr, atm, + four (4) user-configurable units
2.5 / second
External Pressure Modules (EXT) Standard Accuracy
External Module
Range(2
EXT200mC-s
±200 mbar
±80 iwc
EXT2C-s
-1 ... 2 bar
-14.5 ... 30 psi
EXT20C-s
-1 ... 20 bar
-14.5 ... 300 psi
EXT160-s
0 ... 160 bar
0 ... 2400 psi
Resolution
0.01 mbar
0.01 iwc
0.0001 bar
0.001 psi
0.001 bar
0.01 psi
0.01 bar
0.1 psi
1 Year Uncertainty(±)(1
0.05% RDG + 0.05% FS
0.05% FS
0.05% FS
0.05% FS
External Pressure Modules (EXT) High Accuracy
Module
Barometric
EXT10mD
EXT100m
EXT400mC
EXT1C
EXT2C
EXT6C
EXT20C
EXT60
EXT100
EXT160
EXT250
EXT600
EXT1000
800 … 1200 mbar abs
±10 mbar differential
0 … 100 mbar gauge
±400 mbar
±1 bar
-1 … 2 bar
-1 … 6 bar
-1 … 20 bar
0 … 60 bar
0 … 100 bar
0 … 160 bar
0 … 250 bar
0 … 600 bar
0 … 1000 bar
Range(2
23.6 … 35.4 inHg a
±4 iwc differential
0 … 40 iwc
±160 iwc
-14.5 … 15 psi
-14.5 … 30 psi
-14.5 … 90 psi
-14.5 … 300 psi
0 … 900 psi
0 … 1500 psi
0 … 2400 psi
0 … 3700 psi
0 … 9000 psi
0 … 15000 psi
1 Year Uncertainty(±)(1
0.5 mbar (0.015 inHg)
0.1% RDG + 0.05% Span
0.04% RDG + 0.025% FS
0.04% RDG + 0.02% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.01% FS
0.04% RDG + 0.013% FS
0.04% RDG + 0.015% FS
0.04% RDG + 0.015% FS
0.04% RDG + 0.015% FS
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2)
2) The internal pressure module’s range may also be displayed in absolute pressure if a Barometric Module is used.
3) The MC2 Calibrator can hold one internal pressure module and the barometric option
All external pressure modules (EXT) are also compatible with Beamex MC5 and MC5P Calibrators.
Electrical generation, measurement and simulation
mV measurement (T/C-terminals) -25 ... 150 mV
Range
-25 ... 150 mV
Resolution
0.001 mV
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
> 10 MW
V, mV, µV
3 / second
Input impedance
Supported units
Display update rate
1 Year Uncertainty(±)(1
0.02% RDG + 4 µV
mV generation (T/C-terminals) -25 ... 150 mV
Range
-25 ... 150 mV
Resolution
0.001 mV
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
5 mA
< 5µV/mA
V, mV, µV
Maximum load current
Load effect
Supported units
1 Year Uncertainty(±)(1
0.02 % RDG + 4 µV
Voltage generation -3 ... 12 V
Range
±0.25 V
-3 ... -0.25 V
0.25 ... 12 V
Resolution
0.01 mV
0.1 mV
0.1 mV
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
5 mA
< 50 µV/mA
V, mV, µV
Maximum load current
Load effect
Supported units
1 Year Uncertainty(±)(1
0.02 % RDG + 0.1 mV
0.02 % RDG + 0.1 mV
0.02 % RDG + 0.1 mV
mA generation (source/sink) 0 ... 25 mA
Range
0 ... 25 mA
Resolution
0.0001 mA
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
800 W (0 ... 20 mA), 640 W (20 ... 25 mA)
60 V
mA, µA
Max load impedance (source)
Max loop voltage (sink)
Supported units
1 Year Uncertainty(±)(1
0.02 % RDG + 1.5 µA
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2).
Electrical generation, measurement and simulation
Resistance measurement 0 ... 4000 W
Range
0 ... 250 W
250 ... 2650 W
Resolution
1 mW
10 mW
2650 ... 4000 W
100 mW
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
Pulsed, bi-directional 1 mA (0..500 W), 0.2 mA (>500 W).
W, kW
3 / second
Measurement current
Supported units
Display update rate
1 Year Uncertainty(±)(1
4-wire connection:
0.02 % RDG + 3.5 mW
3-wire connection:
0.02% RDG + 13.5 mW
Resistance simulation 0 ... 4000 W
Range
0 ... 400 W
400 ... 4000 W
Resolution
10 mW
100 mW
Feature
Temperature coefficient
Specification
< ±0.0015% RDG / °C outside of 18 ... 28°C
< ±0.0008% RDG / °F outside of 64.4 ... 82.4°F
5 mA (0 ... 650 W)
Iexc × Rsim < 3.25 V (650 ... 4000 W)
1 ms
W, kW
Maximum Resistance excitation current
Settling time (pulsed currents)
Supported units
1 Year Uncertainty(±)(1
0.04 % RDG or 30 mW (Whichever is greater)
0.04 % RDG or 30 mW (Whichever is greater)
Frequency generation 0.0005 ... 10 000 Hz
Range
0.0005 ... 0.5 Hz
0.5 ... 5 Hz
5 ... 50 Hz
50 ... 500 Hz
500 ... 5000 Hz
5000 ... 10000 Hz
Resolution
0.000001 Hz
0.00001 Hz
0.0001 Hz
0.001 Hz
0.01 Hz
0.1 Hz
Feature
Temperature coefficient
Maximum load current
Output amplitude positive square wave
Output amplitude symmetric square wave
Duty cycle
Supported units
Jitter
Specification
Specification valid from –10 to 50°C (14 ... 122°F)
5 mA
0 .. 12 Vpp ±(0.2 V+5%)
0 .. 6 Vpp ±(0.2 V+5%)
1 ... 99 % (0.0009 … 500 Hz), high / low time: min 25µs, max 1165 s
Hz, kHz, cph, cpm, 1/Hz (s), 1/kHz (ms), 1/MHz (µs)
< 0.28 µs
1 Year Uncertainty(±)(1
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
0.01% RDG
Pulse generation 0 ... 9 999 999 pulses
Feature
Range
Resolution
Maximum load current
Output amplitude positive pulse
Output amplitude symmetric pulse
Pulse frequency
Duty cycle
Specification
0 to 9 999 999 pulses
1 pulse
5 mA
0 .. 12 Vpp ±(0.2 V+5%)
0 .. 6 Vpp ±(0.2 V+5%)
0.0005 ... 10 000 Hz
1 ... 99 % (0.0009 … 500 Hz), high / low time: min 25µs, max 1165 s
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2).
Temperature measurement and simulation
Thermocouple measurement and simulation
Thermocouple types available as standard
Type
Range (°C)
B(2
0 ... 1820
R(2
-50 ... 1768
S(2
-50 ... 1768
E(2
-270 ... 1000
J(2
-210 ... 1200
K(2
-270 ... 1372
N(2
-270 ... 1300
T(2
-270 ... 400
U(4
-200 ... 600
L
-200 ... 900
C(5
0 … 2315
G(6
0 … 2315
D(5
0 … 2315
(4
Feature
Resolution
Temperature
coefficient
Input impedance
Supported units
Display update rate
Maximum load current
Load effect
Range (°C)
0...200
200...400
400...1820
-50...0
0...100
100...1768
-50...0
0...1768
-270...-200
-200..1000
-210...1200
-270...-200
-200...1000
1000...1372
-270...-200
-200...1300
-270...-200
-200...-100
-100...400
-200...-100
-100...600
-200... 900
0 … 1000
1000 … 2000
2000 … 2315
0 … 100
100 … 2315
0 … 1000
1000 … 2000
2000 … 2315
Measurement
0.01 °C
< ±0.0015%
of thermovoltage / °C outside of 18...28°C
< ±0.0008%
of thermovoltage / °F outside of 64.4 ...82.4°F
>10 MW
°C, °F, K
3 / second
-
1 Year Uncertainty (±)(1
(3
2.0 °C
1.0 °C
1.0 °C
0.8 °C
0.6 °C
1.0 °C
0.7 °C
(3
0.25 °C
0.3 °C
(3
0.3 °C
0.4 °C
(3
0.4 °C
(3
0.3 °C
0.2 °C
0.3 °C
0.2 °C
0.25°C
0.4 °C
0.8 °C
1.2 °C
(3
1.0 °C
0.4 °C
0.8 °C
1.2 °C
Simulation
0.01 °C
< ±0.0015%
of thermovoltage / °C outside of 18...28°C
< ±0.0008%
of thermovoltage / °F outside of 64.4 ...82.4°F
°C, °F, K
5 mA
< 5 µV/mA
Internal Reference Junction
Range (°C)
-10 … 50 °C
1 Year Uncertainty
±0.25 °C
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2).
Uncertainty does not include reference junction uncertainty.
2) IEC 584, NIST MN 175, BS 4937, ANSI MC96.1
3) ±0.02 % of thermovoltage + 4 µV
4) DIN 43710
5) ASTM E 988 - 96
6) ASTM E 1751 - 95e1
Temperature measurement and simulation
RTD measurement and simulation
Sensor Type
Pt 50 ... 1000
Ni 100
Ni 120
Cu10
Feature
Temperature
coefficient
Measurement current
Maximum Resistance
excitation current
Supported units
Display update rate
Range
Resolution
-200 ... 200 °C
200 ... 600 °C
600 … 850 °C
-60 ... 180 °C
-80 ... 260 °C
-200 ... 260 °C
0.01 °C
0.01 °C
0.01 °C
0.01 °C
0.01 °C
0.01 °C
Measurement
< ±0.0015%
of resistance / °C outside of 18 ... 28°C
< ±0.0008%
of resistance / °F outside of 64.4 ... 82.4°F
Pulsed, 1 mA (0..500 W),
0.2 mA (>500 W).
Simulation 1 Year
Uncertainty (±)(1, 2
0.15 °C
0.25 °C
0.35 °C
0.15 °C
0.15 °C
0.8 °C
Simulation
< ±0.0015%
of resistance / °C outside of 18 ... 28°C
< ±0.0008%
of resistance / °F outside of 64.4 ... 82.4°F
5 mA (0 ... 650 W)
Iexc × Rsim < 3.25 V (680 ... 4000 W)
°C, °F, K
-
°C, °F, K
3 / second
RTD types available as standard
Pt50 (385)
Pt400 (385)
Pt100 (385)
Pt500 (385)
Pt200 (385)
Pt1000 (385)
Measurement 1 Year
Uncertainty (±)(1
0.1 °C
0.2 °C
0.3 °C
0.1 °C
0.1 °C
0.2 °C
Pt100 (3926)
Pt100 (391)
Pt100 (375)
Pt100 (3923)
Ni100 (618)
Ni120 (672)
Cu10 (427)
1) Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long-term stability for the mentioned period. (k=2).
2) Specification valid with an excitation current >0.2 mA (0...400 W), >0.1 mA (400 ... 4000 W)
Standard Accessories
•User guide
•Calibration certificate
•Internal rechargeable NiMH battery pack + battery charger
•Test leads and clips
•USB cable
•Adapter pressure connector - from G1/8” female
to G 1/8” male with 60° internal cone (included in PE and MF models)
Optional Accessories
•Pressure T-hose
•Soft carrying case
•Connection cable for external pressure modules
•Dry battery cartridge
•Calibration handpumps
All specifications are subject to change without prior notice
HART® is a registered trademark of the HART communication Foundation.
w
w
w .
b
e
a
m
e
x
.
c
o
m
Portable calibrators
Workstations
Calibration software
Professional services
For more information, please visit www.beamex.com or contact [email protected]
Beamex Oy Ab -492005
Industry solutions
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
