PRODUCT CATALOGUE 2014
CONTENTS
HAMMERS
3-4
PERCUSSION DRILLS
5-6
DRILLS / SCREWDRIVERS / CORDLESS TOOLS
6
CORDLESS TOOLS / WALL CHASER /
GRINDERS
ANGLE GRINDERS / DIE GRINDERS
7-9
10-11
POLISHER / SANDER / CHOPSAW / JIGSAW
SAWS / SANDERS
12
13-14
ROUTERS / HEAT GUNS / BLOWER /
VACUUMS
MULTI TOOL / OMNI
15
16-17
BATTERIES / CHARGERS
18
SDS PLUS / SDS MAX DRILL BITS
19
CHISELS / MASONRY DRILL BITS
20
CUTTING AND GRINDING DISCS
21
DIAMOND BLADES
22
HOLESAWS / RECIP SAW BLADES
23
JIGSAW BLADES / CIRCULAR SAW BLADES
24
DRILLING & SCREWDRIVING SETS / ANGLE
ATTACHMENT
25
HSS BIT SET / WOOD BIT SET / JIG SAW
BLADES SET
26
SCREW BITS SET / HSS BIT SET / WOOD BIT
SET
27
AEG HISTORY
Since being founded, AEG HISTORY has been leading the
way in new product development. By introducing the first
transportable drilling machines in 1898, portable powertools
were born. Over 100 years later AEG are still offering the
professional user innovative, powerful solutions...
PROUD PAST...
EXCITING FUTURE....
3
POWER &
HAMMERS
PERFORMANCE
BH 22 E
BH 24 E
22 MM
24 MM
24 MM
SDS-PLUS Rotary
Hammers
SDS-PLUS Rotary
Hammers
SDS-PLUS Combi
Hammers
FEATURES
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
FEATURES
•
•
•
•
•
•
Powerful 650 watt motor
22 mm drilling capacity in concrete
Safety clutch for user protection
Variable speed electronics for control
Hammer action stop for drilling in wood or metal
Forward and reverse mechanism
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Weight
Supplied in
Article Number
EAN No
BH 22 E
650 W
1290 rpm
1.9 J EPTA
0–3700 bpm
22 / 13 / 30 mm
2.5 kgs
Kitbox
4935 4114 80
4002395197026
KH 24 XE
KH 24 E
Powerful 720 watt motor
24 mm drilling capacity in concrete
Safety clutch for user protection
Variable speed electronics for control
Hammer action stop for drilling in wood or metal
Forward and reverse mechanism
Soft-grip handle for comfort
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Weight
Supplied in
Article Number
EAN No
BH 24 E
720 W
1500 rpm
2.3 J EPTA
0–4500 bpm
24 / 13 / 30 mm
2.4 kg
Kitbox
4935 4282 00
4002395194384
KH 26 E
Powerful 720 watt motor
24 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Variable speed electronics for control
Hammer stop function for drilling in wood or metal
Forward and Reverse mechanism
Soft grip handle for comfort
Standard SDS-Plus tool reception
Safety Clutch for user protection
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Below Energy
Hammer rate (under load)
Drilling concrete/steel/wood
Weight
Supplied in
Article Number
KH 28 Super XE
24 MM
26 MM
28 MM
SDS-Plus Combi
Hammer
SDS-Plus Combi
Hammer
SDS-Plus Combi
Hammer
FEATURES
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Powerful 720 watt motor
24 mm drilling capacity in concrete
Rotary stop for light chiselling applications
FIXTEC quick change chuck
Safety clutch for user protection
Variable speed electronics for control
Hammer action stop for drilling in wood or metal
Forward and reverse mechanism
Soft-grip handle for comfort
FEATURES
Powerful 800 watt motor
26 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Safety clutch for user protection
Variable speed electronics for control
Hammer action stop for drilling in wood or metal
Forward and reverse mechanism
Soft-grip handle for comfort
ALSO AVAILABLE: KH 26 XE - with FIXTEC
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Weight
Supplied in
Article Number
EAN No
KH 24 XE
720 W
1500 rpm
2.3 J EPTA
4500 bpm
24 / 13 / 30 mm
2.6 kg
Kitbox
4935 4282 20
4002395194407
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Weight (kg)
Supplied in
Article Number
EAN No
KH 26 E
800 W
1500 rpm
2.5 J EPTA
4500 bpm
26 / 13 / 30 mm
2.6 kgs
Kitbox
4935 4281 80
4002395194360
•
•
•
•
•
•
•
•
•
•
•
Powerful 1010 watt motor
28 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Soft hammer mode reduces blow energy and speed
for drilling/chiselling in sensitive materials
FIXTEC quick change tool system
Safety clutch for user protection
Variable speed electronics for control
Hammer action stop for drilling in wood or metal
Soft-grip handle for comfort
Electronic overload protection
No load speed limitation
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Weight (kg)
Supplied in
Article Number
EAN No
BH 26 LE
BH 26 LXE
26 MM
26 MM
30 MM
Combi Hammer
Combi Hammer
Combi Hammer
FEATURES
•
•
•
•
Powerful 750 watt motor
26 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Soft hammer mode reduces blow energy and speed
for control in chiselling applications
• AVS anti-vibration system significantly reduces
Vibration for user comfort and safety
• Safety clutch for user protection
• SDS-Plus tool reception
FEATURES
•
•
•
•
•
•
•
•
Powerful 750 watt motor
26 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Soft hammer mode reduces blow energy and speed for
drilling/chiselling in sensitive materials
FIXTEC quick change tool system
AVS anti-vibration system significantly reduces vibration
for user comfort and safety
Safety clutch for user protection
Hammer action stop for drilling in wood or metal
SPECIFICATIONS
SPECIFICATIONS
BH 26 LE
Power input (W)
750 W
No load speed (rpm)
0-1400 rpm
Blow energy (EPTA)(J)
2.7 J
Hammer Rate (under Load)
4500 bpm
Drilling capacity: Concrete / Steel / Wood 26 / 13 / 30 mm
Weight (kg)
2.9 kgs
Supplied in
Kitbox
Article Number
4935 4120 42
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / steel / wood
Drilling capacity core cutter
Weight (kg)
Supplied in
Article Number
EAN No
KH 24 E
720 W
0-1500 rpm
2.3 J EPTA
0–4500 bpm
24 / 13 / 30 mm
2.4 kgs
Kitbox
4935 4282 10
BH 26 LXE
750 W
0-1400 rpm
2.7 J
4500 bpm
26 / 13 / 30 mm
68 mm
3.1 kg
Kitbox
4935 4120 00
4002395197187
KH 28 SUPER XE
1010 W
1500 rpm
2.8 J EPTA
5000 bpm
28 / 13 / 30 mm
2.8 kgs
Kitbox
4935 4281 90
4002395194377
PN 3500
FEATURES
•
•
•
•
•
•
•
•
Powerful 750 watt motor
30 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Soft hammer mode reduces blow energy and speed
for control in chiselling applications
FIXTEC quick change tool system
AVS anti-vibration system significantly reduces
vibration for user protection
Hammer action stop for drilling in wood or metal
SDS-Plus reception
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Blow energy (EPTA)(J)
Hammer Rate (under Load)
Drilling concrete / steel / wood
Weight (kg)
Supplied in
Article Number
PN 3500
750 W
0-970 rpm
3.4 J
4200 bpm
30 / 16 / 40 mm
3.6 kgs
Kitbox
4935 4121 52
4
POWER &
HAMMERS
PERFORMANCE
PN 3500 X
KH 5 G
KH 5 E
30 MM
40 MM
40 MM
Combi Hammer
Combi Hammer
Combi Hammer
FEATURES
FEATURES
•
•
•
•
•
•
•
•
Powerful 750 watt motor
30 mm drilling capacity in concrete
Rotary stop for light chiselling applications
Soft hammer mode reduces blow energy and speed for
control in chiselling applications
FIXTEC quick change tool system
AVS anti-vibration system significantly reduces vibration for
user comfort and safety
Safety clutch for user protection
Hammer action stop for drilling in wood or metal
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete /steel / wood
Drilling capacity core cutter
Weight (kg)
Supplied in
Article Number
EAN No
PN 3500 X
750 W
0-970 rpm
3.4 J
4200 bpm
30 / 16 / 40 mm
82 mm
3.6 kgs
Kitbox
4935 4122 10
4002395198337
Powerful 1100 watt Motor
40mm Drill Capacity in Concrete
Roto-Stop and multi position chisel function
Safety clutch for user protection
Low Vibration for user Comfort
Standard SDS Max tool Reception
•
•
•
•
•
SPECIFICATIONS
Power input (W)
No load speed (rpm)
Blow energy (EPTA)(J)
Hammer Rate (under load)
Drilling concrete / core bit / tunnel drill bit
Weight (kg)
Supplied in
Article Number
KH 5 G
1100 W
0-450 rpm
7.5 J
3000 bpm
40 / 105 / 65 mm
6.3 kgs
Kitbox
4935 4181 60
PN 11 E
Powerful 1200 watt motor
40 mm drilling capacity in concrete
Rotary stop for chiselling applications
Soft hammer mode reduces blow energy and speed for
drilling/chiselling in sensitive materials
AVS anti-vibration system significantly reduces vibration for
user comfort and safety
Safety clutch for user protection
Soft start for precise start of drilling/chiselling
Service light provides in-time notice in the case of worn out
brushes
Power light indicates if electricity flows
Chipping Hammer
FEATURES
FEATURES
•
•
•
•
•
•
Powerful 1500 watt motor
45 mm drilling capacity in concrete
Rotary stop for light chiselling applications
AVS anti-vibration system
Soft start for precise start of drilling/chiselling
Service light provides in time notice in the case of worn
out brushes
• Standard SDS-Max tool reception
• Safety clutch for user protection
• Power light indicates if electricity flows
• Powerful 1700 watt motor
• 20 J impact energy for heavy demolition applications
• 50 mm drilling capacity into concrete
• Variable speed electronics for control
• No load speed limitation
• AVS anti-vibration system significantly reduces vibration
for user comfort and safety
• Safety clutch for user protection
• Soft start for precise start of drilling/chiselling
• Service light provides in-time notice in the case of worn
out brushes
• Automatic cut out carbon brushes
• Soft-grip on handles for comfort
SPECIFICATIONS
KH 7 E
1500 W
0-300 rpm
10.5 J
2700 bpm
45 / 150 / 80 mm
7.3 kgs
Kitbox
4935 4321 95
Power input (W)
Impact energy
Hammer rate (full load)
Drilling concrete / core bit / tunnel drill bit
Weight
Supplied in
Article Number
EAN No
PN 11 E
1700 watt
20 J EPTA
975–1950 bpm
50/150/80 mm
11.8 kg
Kitbox
4935 4124 40
4002395198931
FEATURES
• Powerful 720 watt motor
• 3,6 J impact energy for powerful chipping
• Variolock (35 positions) for selecting the most appropriate
chisel angle
• Service hatches for easy changing of carbon brushes
• Lock-on switch function
• AVS anti-vibration aystem significantly reduces vibration
for more comfortable operation
• Soft-grip for more comfortable handling
SPECIFICATIONS
Power input (W)
Impact energy
Hammer rate (full load)
Weight
Supplied in
Article Number
EAN No
MH 5 E
MH 5 G
PM 10 E
5 KG
5 KG
11 KG
Chipping Hammer
Chipping Hammer
Large Demolition
Hammer
FEATURES
FEATURES
• Powerful 1200 watt motor
• 8,5 J impact energy for effortless chipping
• Soft hammer mode reduces blow energy for chiselling in
sensitive materials
• AVS anti-vibration system significantly reduces vibration
for user comfort and safety
• Soft start for precise start of chiselling
• Service light provides in-time notice in the case of worn
out brushes
• Power light indicates if electricity flows
• Powerful 1100 watt motor
• 7.5 J impact energy for effortless chipping
• Soft hammer mode reduces blow energy for chiselling in
sensitive materials
• AVS anti-vibration system significantly reduces vibration
for user comfort and safety
• Soft start for precise start of chiselling
• Service light provides in-time notice in the case of worn
out brushes
SPECIFICATIONS
SPECIFICATIONS
Power input (W)
Impact energy
Hammer rate (full load)
Weight
Supplied in
Article Number
EAN No
MH 5 E
1200 watt
8.5 J EPTA
0–2840 bpm
6.2 kg
Kitbox
4935 4123 61
4002395198795
MH 5 G
1100 watt
7.5 J EPTA
0–3000 bpm
6.0 kg
Kitbox
4935 4431 70
4002395135462
PM 3
720 watt
3.6 J EPTA
0–3650 bpm
3.7 kg
Kitbox
4935 4125 41
4002395199044
FEATURES
•
•
•
•
•
•
•
•
•
Power input (W)
Impact energy
Hammer rate (full load)
Weight
Supplied in
Article Number
EAN No
KH 5 E
1200 W
300 rpm
8.5 J EPTA
2840 bpm
40 / 90 / 65 mm
105 mm
6.6 kg
Kitbox
4935 4123 26
4002395198603
3 KG
Large Combi Hammer
Combi Hammer
Power input (W)
No load speed (rpm)
Impact energy
Hammer rate (full load)
Drilling concrete / core bit / tunnel drill bit
Drilling capacity core cutter
Weight
Supplied in
Article Number
EAN No
PM 3
50 MM
45 MM
Power input (W)
No load speed (rpm)
Blow energy (EPTA)(J)
Hammer Rate (under load)
Drilling concrete / core bit / tunnel drill bit
Weight (kg)
Supplied in
Article Number
•
•
•
•
•
•
•
•
•
•
SPECIFICATIONS
KH 7 E
SPECIFICATIONS
FEATURES
Powerful 1600 watt motor
20 J impact energy for heavy demolition applications
Variable speed electronics for control
No load speed limitation
AVS anti-vibration system significantly reduces vibration for
user comfort and safety
Soft start for precise start of drilling/chiselling
Service light provides in-time notice in the case of worn out
brushes
Automatic cut out carbon brushes
Soft-grip on handles for comfort
SPECIFICATIONS
Power input (W)
Impact energy
Hammer rate (full load)
Weight
Supplied in
Article Number
EAN No
PM 10 E
1600 watt
20 J EPTA
975–1950 bpm
11.0 kg
Kitbox
4935 4124 18
4002395198832
5
POWER &
PERCUSSION DRILLS
PERFORMANCE
SBE 570 R
SBE 500 R
SBE 580 R
10 MM
13 MM
13 MM
Percussion Drill
Percussion Drill
Percussion Drill
FEATURES
FEATURES
• Compact and powerful 500 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse mechanism
• Hammer action stop for rotary drilling
• 10 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
• Compact and powerful 570 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
SPECIFICATIONS
SPECIFICATIONS
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article Numberi
EAN No
SBE 500 R
500 watt
0–2650 rpm
13/10/20 mm
21 Nm
1.5–10 mm
1.6 kg
4935 4198 35
4002395194223
SBE 570 R
570 watt
0–2700 rpm
15 / 13 / 30 mm
23 Nm
1.5–13 mm
1.7 kg
4935 4126 81
4002395199303
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
EAN No
FEATURES
• Compact and powerful 580 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
SPECIFICATIONS
SBE 580 R
580 watt
0–2700 rpm
15 / 13 / 30 mm
23 Nm
1.5–13 mm
1.7 kg
4935 4198 50
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
SBE 600 RKS
SBE 630 R
SB2-650
13 MM
13 MM
13 MM
Percussion Drill
Percussion Drill
Percussion Drill
FEATURES
• Compact and powerful 600 watt motor
• Compact ergonomic design with large soft-grip areas
offers excellent handling
• Variable speed control with forward and reverse
mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
SPECIFICATIONS
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Supplied in
Article No
EAN No
SBE 600 RKS
600 watt
0–2700 rpm
15/13/30 mm
23 Nm
1.5–13 mm
1.7 kg
Kitbox
4935 3817 20
4002395194568
FEATURES
FEATURES
• Compact and powerful 630 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
• Supplied in kitbox
• Compact and powerful 650 watt motor
• Compact ergonomic design with large soft-grip areas offers excellent handling
• Variable speed control
• 2-speed selection for increased torque and versatility
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
• 43 mm gear neck for use in drill stands
SPECIFICATIONS
SPECIFICATIONS
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
SBE 630 R
630 watt
0–2800 rpm
15 / 13 / 30 mm
23 Nm
1.5–13 mm
1.8 kg
4935 4198 65
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
EAN No
SBE 650 RS
SB 20 - 2 E
13 MM
13 MM
13 MM
Percussion Drill
Percussion Drill
Percussion Drill
FEATURES
FEATURES
•
•
•
•
•
•
Compact and powerful 750 watt percussion drill
AVS anti-vibration system for more comfortable use
Safety clutch for user protection
2-speed gearbox for increased torque and versatility
Ergonomic soft-grip design for comfort
Variable speed control with forward and reverse
mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
•
•
•
•
•
•
SPECIFICATIONS
SPECIFICATIONS
SB2-650
650 watt
0–2250/0–3000 rpm
16 / 13 / 30 mm
25 Nm
1.5–13 mm
1.8 kg
4935 3817 60
4002395194575
SB 22 - 2 E
ALSO AVAILABLE: Kit version
FEATURES
• Compact and powerful 650 watt motor
• Compact ergonomic design with large soft-grip areas offers excellent handling
• Variable speed control with forward and reverse mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
SPECIFICATIONS
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
EAN No
SBE 650 RS
650 watt
0–3000 rpm
16 / 13 / 30 mm
25 Nm
1.5–13 mm
1.8 kg
4935 3817 70
4002395194582
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Supplied in
Article No
EAN No
SB 20 - 2 E
750 watt
0–1000/0–3200 rpm
20 / 13 / 40 mm
56 Nm
1.5–13 mm
2.8 kg
Kitbox
4935 4118 03
4002395132430
Compact and powerful 1010 watt percussion drill
AVS anti-vibration system for more comfortable use
Safety clutch for user protection
2-speed gearbox
Ergonomic soft-grip design for comfort
Variable speed control with forward and reverse
mechanism
• Hammer action stop for rotary drilling
• 13 mm metal keyed chuck
Power input (W)
No load speed
Drilling concrete/steel/wood
Max torque
Chuck
Weight
Supplied in
Article No
EAN No
SB 22 - 2 E
1010 watt
0–1000/0–3200 rpm
22/16/40 mm
60 Nm
1.5–13 mm
2.9 kg
Kitbox
4935 4118 06
4002395132447
6
DRILLS / SCREWDRIVERS / CORDLESS TOOLS
POWER &
PERFORMANCE
BE 650 R
BE 705 R
13 MM
10 MM
10 MM
Percussion Drill
Rotary Drill
Rotary Drill
FEATURES
FEATURES
• Compact and powerful 650 watt motor
• Compact ergonomic design offers excellent handling
• Variable speed control with forward and reverse
mechanism
• 10 mm keyless metal chuck
• 43 mm gear neck for use in drill stands
• Speed control with speed dial
• Extremely compact design
• Compact and powerful 705 watt motor
• Variable speed control with forward and reverse
mechanism
• Belt clip
• 10 mm keyed chuck
SPECIFICATIONS
SPECIFICATIONS
SB2E 750 R
FEATURES
• Compact and powerful 750 watt high
torque percussion drill
• 62 Nm torque delivers complete power
• IMB – Integrated-Metal-Block technology for highest durability and stability
• 2-speed gearbox with synchromesh gear lever
• Variable speed control with forward and reverse
mechanism
• Easy access to carbon brushes via removal of soft-grip rubber
• Hammer action stop for rotary drilling
• 13 mm metal keyless chuck
SPECIFICATIONS
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Supplied in
Article No
EAN No
SB2E 750 R
750 watt
0–1200/0–3400 rpm
20 / 13 / 40 mm
62 Nm
1.5–13 mm
2.5 kg
Kitbox
4935 4128 53
4002395192779
B4 - 1050 ST
32 MM
Rotary Drill
Power input (W)
No load speed
Drilling concrete / steel / wood
Max torque
Chuck
Weight
Article No
EAN No
BE 650 R
650 watt
0–3000 rpm
10 / 13 / 30 mm
25 Nm
1.0–10 mm
1.7 kg
4935 3817 75
4002395194599
BE 705 R
705 watt
0–2700 rpm
10 / 16 / 30 mm
15 Nm
1.0–10 mm
1.6 kg
4935 4165 05
4002395129744
Power input (W)
No load speed
Drilling steel / aluminium / wood
Max torque
Chuck
Weight
Article No
EAN No
DB 1500 - 2XE
S 2500 E
High Performance
Dry Diamond Drill
Self Drilling Screwdriver
FEATURES
FEATURES
FEATURES
• Four-speed rotary drill for drilling up to 32 mm
• Breast plate and 57 mm gear neck for use in magnetic drill stands
• Standard morse taper 3 reception
• Attachable handle with adjustable length
SPECIFICATIONS
Power input (W)
No load speed 1st/2nd/3rd/4th gear
Drilling steel / aluminium / wood
Max torque
Tool reception
Weight
Article No
EAN No
B4 - 1050 ST
1050 watt
220/260/350/420 rpm
32/52/64 mm
200 Nm
Morse taper 3
9.7 kg
4935 4150 00
4002395193356
S 4000 E
Dry wall Screwdriver
•
•
•
•
Powerful 720 watt motor for increased productivity
Compact high speed screwdriver for drywall applications
Full metal gearbox for durability
Easily adjustable depth-setting nosepiece for consistent
fastener depth
Forward and reverse mechanism
Ergonomic design and soft-grip for comfortable handling
1⁄4˝ Hex bit reception
Belt clip
SPECIFICATIONS
Power input (W)
No load speed
Drywall screws
Torque
Bit reception
Weight
Article No
EAN No
• Powerful 720 watt motor for increased productivity
• Compact self drilling screwdriver with high torque for self
tapping screws
• Full metal gearbox for durability
• Easily adjustable depth-setting nosepiece for consistent
fastener depth
• Forward and reverse mechanism
• Ergonomic design and soft-grip for comfortable handling
• 1⁄4˝ Hex bit reception
• Belt clip
SPECIFICATIONS
SPECIFICATIONS
Power input (W)
No load speed
Spindle thread
Max. drilling capacity in masonry/brick
Weight
Supplied in
Article No
EAN No
DB 1500 - 2XE
1500 watt
0–1500/0–3000 rpm
M18 x 2,5
162 mm
4.2 kg
Kitbox
4935 4124 75
4002395198955
S 2500 E
720 watt
0–2500 rpm
6.3 / 6 mm
14 Nm
1⁄4˝ Hex
1.5 kg
4935 4132 25
4002395197651
Power input (W)
No load speed
Self-tapping / wood screws
Torque
Bit reception
Weight
Article No
EAN No
SE 3.6
BS 12C Li
3.6 V
12 V
In-line Screwdriver
Ultra Compact Drill/Driver
FEATURES
FEATURES
•
•
•
•
• Powerful 1500 watt motor
• High performance 2-speed dry diamond drill
• Dual protection with interlinked mechanical and electronic
clutches for safety
• Robust construction and full metal gearbox for durability
• 2-speed gear box
• Electronics with soft start for precision drilling and motor overload protection
• Soft hammer mode
S 4000 E
720 watt
0–4000 rpm
5 mm
10 Nm
1⁄4˝ Hex
1.4 kg
4935 4132 15
4002395197637
FEATURES
•
•
•
•
•
In-line or angled handle adjustment
10-stage torque selection plus drill stage
Ergonomic, modern design
2-speed full metal gearbox
1⁄4˝ Hex bit reception
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Length with battery
Drilling aluminium/wood
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
SE 3.6
2 x 1,5 Ah NiCd
30 min*
0.6 kg
28 cm
5/6 mm
6.5 Nm
200/600 rpm
3.6 V
Kitbox
4935 4131 65
4002395197538
•
•
•
•
•
•
•
•
•
Compact pocket drill/screwdriver measuring only 161 mm
Built in fuel gauge
17-stage torque adjustment plus additional drilling stage
Industrial metal gearbox and gears for superior durability
FIXTEC spindle lock and keyless 10 mm chuck
Electronic switch with variable speed
Built in LED light illuminates the work surfaces
Overload protection
Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling steel/soft wood
Chuck
Max torque
No load speed
Voltage
Article No
EAN No
BS 12C Li
2 x 12V / 2.0 Ah Li-on
30 min*
1.0 kg
10/20 mm
1.5–10 mm
18.5 Nm
0–575 rpm
12 V
4935 4339 02
4002395126354
7
POWER &
CORDLESS TOOLS
BS 12C2 Li
PERFORMANCE
BSB 12C2 Li
BS 12 G2 NiCd
12 V
12 V
12 V
2 Speed Ultra Compact Drill/Driver
2 Speed Ultra Compact Drill/Driver
Drill / Driver
FEATURES
FEATURES
•
•
•
•
•
•
•
•
Compact pocket drill/screwdriver measuring only 168 mm
17-stage torque adjustment plus additional drilling stage
2-speed gearbox for a wide range of applications
Industrial metal gearbox and gears for superior durability
FIXTEC spindle lock and keyless 10 mm chuck
Electronic switch with variable speed
Built in LED light illuminates the work surface
Features AEG Pro Lithium-Ion battery technology with
over­load protection for maximum durability of battery and tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling steel / soft wood
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BS 12C2 Li
2 x 12V / 2.0 Ah Li-on
30 min*
1.1 kg
10 / 20 mm
1.5–10 mm
34 Nm
0–350/0–1500 rpm
12 V
Kitbox
4935 4283 75
4002395132171
BS 12 G2 Li
12 V
Drill / Driver
•
•
•
•
•
•
•
•
•
Compact hammer drill/driver measuring only 192 mm
Built in fuel gauge
Belt clip
2-speed gearbox for a wide range of applications
Industrial metal gearbox and gears for superior durability
FIXTEC spindle lock and keyless 10 mm chuck
Electronic switch with variable speed
3 mode selector – ease of use between applications
Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling metal/wood/masonry
Percussion rate
Chuck
Max torque
No load speed
Voltage
Article No
EAN No
BSB 12C2 Li
2 x 12V / 2.0 Ah Li-on
30 min*
1.2 kg
10/20/10 mm
22.500 bpm
1.5–10 mm
32 Nm
0–400/0–1500 rpm
12 V
4935 4339 80
4002395134519
BS 14 G2 NiCd
BS 12 G2 NiCd
2 x 12V / 1.4 Ah NiCd
60 min*
1.6 kg
10 / 30 mm
30 Nm
0–350/0–1350 rpm
12 V
Kitbox
4935 4319 85
4002395195060
BS 14 C Li
14.4V
Drill / Driver
ALSO AVAILABLE: 3.0 Ah Li-Ion version
BS 12 G2 Li
2 x 12V / 1.4 Ah Li-on
60 min*
1.6 kg
10 / 30 mm
30 Nm
0–350/0–1350 rpm
12 V
Kitbox
4935 4466 87
4002395136353
FEATURES
• Compact & powerful for completion of all jobsite
applications
• 32 Nm maximum torque delivers complete power
• 2-speeds – 0–400 rpm/0–1400 rpm
• 24-stage torque adjustment delivers optional control for the user
• FIXTEC 10 mm single sleeve chuck with full metal jaws
SPECIFICATIONS
Battery Pack
No Load Speed
Max Torque
Drilling metal / wood
Weight
Supplied in
Article No
BS 14 G2 NiCd
2 x 14.4V / 1.4 Ah NiCd
0-400 / 0-1400 rpm
32 Nm
10 / 32 mm
1.7 Kgs
Kitbox
4935 4319 87
BS 18C Li
18 V
18 V
Drill / Driver
Drill / Driver
FEATURES
ALSO AVAILABLE: 4.0 Ah Li-Ion version
FEATURES
• Compact & powerful for completion of all jobsite applications
• 50 Nm maximum torque delivers complete power
• 2-speeds – 0–400/0–1500 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm single sleeve full metal chuck
• Built in fuel gauge
• LED – for work place illumination
• Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
No. of batteries
Charger
Weight with battery
Drilling metal/wood
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
No. of batteries
Charger
Weight with battery
Drilling metal / wood
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
Drill / Driver
BS 18 G2 Li
SPECIFICATIONS
SPECIFICATIONS
FEATURES
• Compact & powerful for completion of all jobsite
applications
• 30 Nm maximum torque delivers complete power
• 2-speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment for complete control
• FIXTEC 10 mm single sleeve chuck with full metal jaws
No. of batteries
Charger
Weight with battery
Drilling metal / wood
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
• Compact & powerful for completion of all jobsite
applications
• 30 Nm maximum torque delivers complete power
• 2-speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment for complete control
• FIXTEC 10 mm single sleeve chuck with full metal jaws
14.4 V
FEATURES
SPECIFICATIONS
FEATURES
BS 18 G2 Li
2 x 18V / 1.5 Ah Li-on
60 min*
1.8 kg
13/34 mm
1.5–13 mm
50 Nm
0–400/0–1500 rpm
18 V
Kitbox
4935 4339 50
4002395134441
•
•
•
•
•
•
•
•
•
No. of batteries
Charger
Weight with battery
Drilling wood/metal
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling metal/wood
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BS 14 C Li
2 x 12V / 2.0 Ah Li-on
30 min*
1.7 kg
13/45 mm
1.5–13 mm
43 Nm
0–400/0–1500 rpm
14.4 V
Kitbox
4935 4284 25
4002395132119
BSB12 G2
NiCd
12 V
Hammer Drill / Driver
New 4 poles frameless motor and compact gearbox
Small, compact & powerful for high torque applications
Only 186 mm in length
51 Nm (2.0 Ah) / 60 Nm (4.0 Ah) maximum torque delivers
complete power
2-speeds – 0–450/0–1650 rpm
Integrated clutch and chuck for a more compact design
LED for work place illumination
Forward and reverse
Features AEG Pro Lithium-Ion battery technology with overload
protection for maximum durability of battery and tool
SPECIFICATIONS
• Ultra compact drill/driver measuring 186 mm in length
• Powerful new frameless motor delivering 43 Nm (2.0
Ah) / 47 Nm (3.0 Ah) maximum torque
• 2 speeds – 0–400/0–1500 rpm
• FIXTEC 13 mm keyless chuck
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and tool
BS 18C Li
2 x 18V / 2.0 Ah Li-on
30 min*
1.8 kg
45 /13 mm
1.5–13 mm
51 Nm
0–450/0–1650 rpm
18 V
Kitbox
4935 4284 15
4002395132096
FEATURES
• Compact & powerful for completion of all jobsite applications
• 30 Nm maximum torque delivers complete power
• 2 speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment
• FIXTEC 10 mm single sleeve chuck with full metal jaws
• 3 mode selector – ease of use between functions
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling metal / wood / masonry
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BSB12 G2 NiCd
2 x 12 V / 1.4 Ah Li-ion
60 min*
1.7 kg
10 / 30 / 6 mm
1.5–10 mm
30 Nm
0–350/0–1350 rpm
12 V
Kitbox
4935 4319 86
4002395195053
8
POWER &
CORDLESS TOOLS
PERFORMANCE
BSB 12 G2 Li
BSB 14 G2 NiCd
BSB 14 G2 Li
12 V
14 V
14 V
Hammer Drill / Driver
Hammer Drill / Driver
Hammer Drill / Driver
FEATURES
FEATURES
• Compact & powerful for completion of all jobsite applications
• 30 Nm maximum torque delivers complete power
• 2 speeds – 0–350/0–1350 rpm
• 24-stage torque adjustment
• FIXTEC 10 mm single sleeve chuck with full metal jaws
• 3 mode selector – ease of use between functions
• Compact & powerful for completion of all jobsite applications
• 32 Nm maximum torque
• 2 speeds – 0–1400 rpm
• 24-stage torque adjustment
• FIXTEC 13 mm single sleeve chuck with full metal jaws (10 mm NiCd)
• 3 mode selector – ease of use between functions
SPECIFICATIONS
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling metal / wood / masonry
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BSB 12 G2 Li
2 x 12 V / 1.5 Ah Li-ion
60 min*
1.7 kg
10 / 30 / 6 mm
1.5–10 mm
30 Nm
0–350/0–1350 rpm
12 V
Kitbox
4935 4466 90
4002395136360
No. of batteries
Charger
Weight with battery
Drilling metal / wood / masonry
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BSB 14 G2 NiCd
2 x 14.4 V / 1.4 Ah NiCd
60 min*
1.8 kg
13 / 32 / 8 mm
1.5–13 mm
32 Nm
0–400 rpm
14.4 V
Kitbox
4935 4319 89
4002395195107
BSB 18 G2 Li
BSB 18 C Li
18 V
18 V
Hammer Drill / Driver
Hammer Drill / Driver
FEATURES
FEATURES
• Compact & powerful for completion of all jobsite applications
• 50 Nm maximum torque delivers complete power
• 2 speeds – 0–400/0–1500 rpm
• 24 stage torque adjustment for complete control
• FIXTEC 13 mm single sleeve full metal chuck
• 3 mode selector – ease of use between functions
• Built in fuel gauge
• LED – for work place illumination
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
•
•
•
•
•
•
•
•
•
•
New 4 poles frameless motor and compact gearbox
Compact & powerful for high torque applications
Only 202 mm in length
51 Nm (2.0 Ah) / 60 Nm (4.0 Ah) maximum torque delivers
complete power
2-speeds – 0–450/0–1650 rpm
24 stage torque adjustment for complete control
FIXTEC 13 mm keyless chuck, with spindle lock
LED – for work place illumination
3 mode selector – ease of use between applications
Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and tool
BSB 18 G2 Li
No. of batteries
2 x 18 V / 1.5 Ah Li-ion
Charger
60 min*
Weight with battery
1.9 kg
Drilling wood / metal / masonry 34 / 13 / 12 mm
1.5–13 mm
Chuck
50 Nm
Max torque
0–400/0–1500 rpm
No load speed
Voltage
18 V
Supplied in
Kitbox
Article No
4935 4339 70
EAN No
4002395134489
BSB 18 C Li
No. of batteries
2 x 18 V / 2.0 Ah Li-ion
Charger
30 min*
Weight with battery
1.8 kg
Drilling wood / metal / masonry 45 / 13 / 14 mm
1.5–13 mm
Chuck
51 Nm
Max torque
0–450/0–1650 rpm
No load speed
Percussion rate
5850–21.450 bpm
Voltage
18 V
Supplied in
Kitbox
Article No
4935 4284 35
EAN No
4002395132041
BSS 12C Li
BSS 18 C Li
18 V
• Ultra compact impact driver measuring only 163 mm
• 115 Nm torque
• Industrial metal gearbox and gears for superior durability
• Built in fuel gauge
• ¼˝ Hex bit reception
• Ergonomic soft-grip design
• New 3 beam LED for total workplace illumination
• Belt clip
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Max torque
No load speed
Impact rate
Tool reception
Voltage
Supplied in
Article No
EAN No
BSS 12C Li
2 x 12 V / 2.0 Ah Li-ion
30 min*
1.0 kg
115 Nm
0–2000 rpm
0-3000 bpm
1⁄4˝ Hex
12 V
Kitbox
4935 4410 00
4002395134977
•
•
•
•
BSB 14 G2 Li
2 x 14.4 V / 1.5 Ah Li-ion
60 min*
1.8 kg
13 / 32 / 8 mm
1.5–13 mm
36 Nm
0–400 / 0–1500 rpm
14.4 V
Kitbox
4935 4319 90
4002395132997
No. of batteries
Charger
Weight with battery
Drilling metal / wood / masonry
Chuck
Max torque
No load speed
Voltage
Supplied in
Article No
EAN No
BSB 18 Li
Ultra compact, well balanced impact driver
Only 145 mm overall length
158 Nm maximum torque
Delivers up to 3100 impacts per minute for increased
productivity
Industrial metal gearbox and gears for extended life
¼˝ Hex bit reception
Built in LED illuminates work surface
Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Max torque
No load speed
Impact rate
Tool reception
Voltage
Supplied in
Article No
EAN No
FEATURES
•
•
•
•
•
•
•
New high performance open frame motor
Compact & powerful for high torque applications
70 Nm maximum torque delivers complete power
Full metal gearbox and housing for superior durability
2-speeds – 0–450/0–1600 rpm
24 stage torque adjustment for complete control
FIXTEC 13 mm full metal Rohm keyless chuck, with spindle
lock
• LED – for work place illumination
• 3 mode selector – ease of use between applications
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Drilling wood / metal / masonry
Chuck
Max torque
No load speed
Percussion rate
Voltage
Supplied in
Article No
EAN No
BSB 18 Li
2 x 18 V / 4.0 Ah Li-ion
30 min*
2.5 kg
55 / 13 / 16 mm
1.5–13 mm
70 Nm
0–450/0–1600 rpm
7200-25.600 bpm
18 V
Kitbox
4935 4284 50
4002395132003
BSS 18C 12Z Li
18 V
FEATURES
FEATURES
•
•
•
•
SPECIFICATIONS
Impact Wrench
Impact Driver
FEATURES
overload protection for maximum durability of
battery and tool
Hammer Drill / Driver
ALSO AVAILABLE
4.0 Ah Li-Ion version
SPECIFICATIONS
Impact Driver
• Compact & powerful for completion of all jobsite applications
• 36 Nm maximum torque delivers complete power
• 2 speeds – 0–400/0–1500 rpm 24-stage torque adjustment
• FIXTEC 13 mm single sleeve chuck with full metal jaws
• 3 mode selector – ease of use between functions
• LED – for work place illumination (lithium version only)
• Features AEG Pro Lithium-Ion battery technology with
18 V
SPECIFICATIONS
12 V
FEATURES
BSS 18 C Li
2 x 18 V / 1.5 Ah Li-ion
30 min*
2.0 kg
158 Nm
0–2400 rpm
0–3100 ipm
1⁄4˝ Hex
18 V
Kitbox
4935 4283 95
4002395132133
•
•
•
•
•
•
360 Nm in a compact size and light weight
Die cast gear case for maximum durability
Pro lithium Ion triple protection
3 LED Beam for perfect visibility on the work piece
Micro texture grip for perfect handling
Fuel gauge for always being informed of the remaining power &
Belt clip for easy carrying on the jobsite
• Delivered with ½’’ square Hex ¼’’ adaptor
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Max torque
No load speed
Impact rate
Tool reception
Voltage
Supplied in
Article No
EAN No
BSS 18C 12Z Li
2 x 18 V / 4.0 Ah Li-ion
30 min*
1.8 kg
360 Nm
0-2400 rpm
0–3100 ipm
1⁄4˝ Hex
18 V
Kitbox
4935 4464 56
4002395136254
9
CORDLESS TOOLS / WALL CHASER / GRINDERS
POWER &
PERFORMANCE
BBH 12
BBH 18
BKS 18 Li
12 V
18 V
18 V
SDS Plus / Hammer
Combi Hammer
Circular Saw
FEATURES
FEATURES
FEATURES
•
•
•
•
•
Up to 13mm in concrete (optimum 4/6/8mm)
Upto 20mm in wood and 13mm in metal (800rpm)
Delivered with ¼’’ hex adaptor for screwdriving (40Nm)
LED, Fuel Gauge
Micro texture soft grip for perfect handling
SPECIFICATIONS
BBH 12
2 x 12 V / 4.0 Ah Li-ion
0-800 rpm
0.9 J
5350 bpm
1.7 kgs
Kitbox
4935 4414 71
Battery Pack
No Load Speed
Blow Energy
Hammer Rate (under load)
Weight
Supplied in
Article No
• L-shape SDS hammer for drilling and fixing into concrete up
to 24 mm
• 2,3 Joule impact energy delivers high performance
• Rotary stop for light chiselling applications
• Hammer action stop for rotary drilling in wood and metal
• Metal gearbox for extended durability
• Safety clutch for user protection
• Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
SPECIFICATIONS
BBH 18
No. of batteries
Charger
Weight with battery
Drilling concrete / steel / wood
Impact energy
No load speed
Blows per minute
Voltage
Supplied in
Article No
EAN No
2 x 18 V / 4.0 Ah Li-ion
30 min*
3.5 kg
24 / 13 / 30 mm
2.3 J EPTA
1400 rpm
0–4200 bpm
18 V
Kitbox
4935 4082 75
4002395132751
•
•
•
•
•
•
•
•
Compact, light and well balanced
Extremely fast cutting speed of 5000 rpm
Magnesium base and upper guard for durability
Large 50° bevel capacity
Electronic motor brake, saw blade stops within seconds
Lock off switch for safety
Spindle lock for fast blade changing
Features AEG Pro Lithium-Ion battery technology with
overload protection for maximum durability of battery and
tool
SPECIFICATIONS
No. of batteries
Charger
Weight with battery
Saw blade Ø
Arbor
Bevel capacity
No load speed
Cutting depth at 45°
Cutting depth at 90°
Voltage
Supplied in
Article No
EAN No
BKS 18 Li
2 x 18 V / 3.0 Ah Li-ion
30 min*
3.4 kg
165 mm
15.87 mm (5 ⁄ 8˝ )
50°
5000 rpm
0–41 mm
0–54 mm
18 V
Kitbox
4935 4283 70
4002395132164
BEWS 18-125
BST 18X-0
MFE 1500
Small Angle Grinder
18 V heavy duty jigsaw
Wall Chaser
125 MM
ALSO AVAILABLE: with disc Ø 115 mm
FEATURES
FEATURES
•
•
•
•
•
•
•
•
•
•
•
Compact and powerful cordless angle grinder
Overload protection with LED warning
AVS side handle for comfort and safety
Burst resistant keyless safety guard for easy and fast
guard adjustment
• Fast and tool-free disc change with patented FIXTEC nut
• Built in fuel gauge
• AEG Pro Lithium-Ion battery technology for maximum
durability of battery and tool
SPECIFICATIONS
BEWS 18-125
No. of batteries
2 x 18 V / 3.0 Ah Li-ion
Charger
30 min*
2.5 kg
Weight with battery
No load speed
9000 rpm
Cutting depth Ø 115 mm Ø 125 mm 28 mm, 33 mm
Spindle thread
M14
Voltage
18 V
Supplied in
Kit box
Article No
4935 4319 31
EAN No
4002395132966
Pendulum action for increased cutting performance
Metal gearbox for extended durability
Professional, die-cast aluminium base plate
Patented FIXTEC system for fast keyless blade change
Variable speed trigger
Ergonomic soft-grip for comfortable use
Electronic motor brake
* Battery & Charger not Included
FEATURES
•
•
•
•
•
•
Powerful 1500 watt motor
Electronics with thermal overload protection and soft start
Variable and adjustable cutting depth for accurate results
Variable cutting width for versatility
Bayonet adaptor for dust extraction
Spindle lock
SPECIFICATIONS
SPECIFICATIONS
BST 18X-0
26 mm
0–2050 spm
3,5 kg
to 45°
80 mm
18 V
4935 4131 30
4002395197460
Stroke
No load stroke rate
Weight with battery
Bevel cutting angle
Cutting depth in soft wood
Voltage
Article No
EAN No
Power input
Disc diameter
No load speed
Cutting width/depth
Weight
Supplied in
Article No
EAN No
MFE 1500
1500 watt
125 mm
975–1950 rpm
8–30/8–26 mm
4.1 kg
Kitbox
4935 4136 05
4002395192809
WS 6-100
WS 6-115
WS 6-125
100 MM
115 MM
125 MM
Small Angle Grinder
Small Angle Grinder
Small Angle Grinder
FEATURES
FEATURES
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Compact powerful 720 watt motor
Metal gearbox for durability
Directed air exhaust
Gear head rotates at 90° intervals for added versatility
Flat metal gear head for excellent visibility of work piece
and optimised cutting depth
• Protected air inlets
• Spindle lock
Compact powerful 720 watt motor
Metal gearbox for durability
Directed air exhaust
Gear head rotates at 90° intervals for added versatility
Flat metal gear head for excellent visibility of work piece
and optimised cutting depth
• Protected air inlets
• Spindle lock
Compact powerful 720 watt motor
Metal gearbox for durability
Directed air exhaust
Gear head rotates at 90° intervals for added versatility
Flat metal gear head for excellent visibility of work piece
and optimised cutting depth
• Protected air inlets
• Spindle lock
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Grinding disc Ø
Cutting depth
Spindle Thread
Weight
Article No
SPECIFICATIONS
WS 6-100
720 watt
10.000 rpm
100 mm
24 mm
M 10
1.9 kgs
4935 3932 65
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 6-115
720 watt
10.000 rpm
28 mm
115 mm
M14
1.9 kg
4935 4132 50
4002395197699
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Version
Article No
EAN No
WS 6-125
720 watt
10.000 rpm
33 mm
125 mm
M14
1.9 kg
220–240 V
4935 4134 90
4002395198542
10
POWER &
ANGLE GRINDERS
PERFORMANCE
WS 9-100
WS 9-115
WS 9-125
100 MM
115 MM
125 MM
Small Angle Grinder
Small Angle Grinder
Small Angle Grinder
FEATURES
FEATURES
FEATURES
• Compact and Powerful 900 watt motor
• Power field coating for best protection and longest life
time
• Cooling slots on the side and back of the grinder to
ensure best motor cooling and prevent from overheating
• AVS side handle for low vibrations and less strain on user
• New “snap-in” safety guard for keyless adjustment
• Powerful 900 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece
and work in restricted areas
• Optimised cooling slots prevent overheating, even when
blocking occasionally by hand
• Most compact girth and length for comfortable use all day
long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Spindle lock
• Powerful 900 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece
and work in restricted areas
• Optimised cooling slots prevent overheating, even when
blocking occasionally by hand
• Most compact girth and length for comfortable use all day
long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Spindle lock
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
WS 9-100
900 watt
11.000 rpm
24 mm
100 mm
M10
2.0 kg
4935 4193 70
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 9-115
900 watt
11.000 rpm
33 mm
115 mm
M14
2.0 kg
4935 4193 80
4002395130689
WS 11-115
WS 11-125
115 MM
125 MM
Small Angle Grinder
Small Angle Grinder
FEATURES
• Powerful 1100 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece
and work in restricted areas
• Optimised cooling slots prevent overheating, even when
blocking occasionally by hand
• Most compact girth and length for comfortable use all day
long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Spindle lock
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 11-115
1100 watt
11.000 rpm
33 mm
115 mm
M14
2.1 kg
4935 4194 00
4002395130726
WS 12-125 XE
125 MM
Small Angle Grinder
• Powerful 1100 watt motor with outstanding performance
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece
and work in restricted areas
• Optimised cooling slots prevent overheating, even when
blocking occasionally by hand
• Most compact girth and length for comfortable use all day
long
• Lightweight for best handling
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Spindle lock
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 9-125
900 watt
11.000 rpm
37 mm
125 mm
M14
2.0 kg
4935 4193 90
4002395130719
FEATURES
FEATURES
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 11-125
1100 watt
11.000 rpm
37 mm
125 mm
M14
2.1 kg
4935 4194 10
4002395130757
• Powerful 1200 watt motor with outstanding performance
• Variable speed electronics for lower speed setting
especially in finishing applications
• Constant speed for best performance and high torque, even
in lower speed applications
• Machined metal gears for best durability
• Flat metal gear head for excellent visibility of work piece
and work in restricted areas
• Optimised cooling slots prevent overheating, even when
blocking occasionally by hand
• Compact length and girth for comfortable use all day long
• AVS side handle for comfort and safety
• Burst resistant keyless safety guard for easy and fast guard
adjustment
• Fast and tool-free disc change with patented FIXTEC nut
• Spindle lock
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 12-125 XE
1200 watt
2800–11.000 rpm
37 mm
125 mm
M14
2.3 kg
4935 4194 30
4002395130795
WSE 14-125 MX
WSC 14-125 MX
WS 21-180
125 MM
125 MM
180 MM
Small Angle Grinder
Small Angle Grinder
Large Angle Grinder
FEATURES
FEATURES
FEATURES
• Powerful 1450 watt motor
• Digitronic with variable speed preselection, soft start,
motor overload protection and no load speed limitation
• FIXTEC – patented nut for fast and easy disc changing
• Automatic cut-off, easy change carbon brushes
• Flat metal gearhead for excellent visibility of work piece
and optimised cutting depth
• Epoxy coating field and armature – combat abrasive dust
to increase tool lifetime
• New “snap-in” safety guard for keyless adjustment
• Spindle lock, with safety mechanism
• Large surface safety switch
• Powerful 1450 watt motor
• Digitronic with variable speed preselection, soft start,
motor overload protection and no load speed limitation
• FIXTEC – patented nut for fast and easy disc changing
• Automatic cut-off, easy change carbon brushes
• Flat metal gearhead for excellent visibility of work piece
and optimised cutting depth
• Epoxy coating field and armature – combat abrasive dust
to increase tool lifetime
• New “snap-in” safety guard for keyless adjustment
• Spindle lock, with safety mechanism
• Large surface safety switch
• Powerful 2100 watt motor
• Epoxy-coated field windings and armature – prevents
accumulation of abrasive dust, increasing tool life
• High quality sealed bearings provide superior protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch
• Line lock out function for increased user protection
• Soft start for smooth startup
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Supplied in
Article No
EAN No
WSE 14-125 MX
1450 watt
2600–11.000 rpm
33 mm
125 mm
M14
2.5 kg
Kitbox
4935 4122 42
4002395198375
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WSC 14-125 MX
1450 watt
11.000 rpm
33 mm
125 mm
M14
2.5 kg
4935 4122 33
4002395198368
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 21-180
2100 watt
8300 rpm
43 mm
180 mm
M14
4.7 kg
4935 4117 88
4002395129881
11
ANGLE GRINDERS / DIE GRINDERS
WS 21-230
POWER &
PERFORMANCE
WS 2200-180
WS 2200-230
230 MM
180 MM
230 MM
Large Angle Grinder
Large Angle Grinder
Large Angle Grinder
FEATURES
FEATURES
FEATURES
• Powerful 2100 watt motor
• Epoxy-coated field windings and armature – prevents
accumulation of abrasive dust, increasing tool life
• High quality sealed bearings provide superior protection
• New “snap-in” safety guard for keyless adjustment
• Convenient three-finger switch
• Line lock out function for increased user protection
• Soft start for smooth startup
•
•
•
•
Superior performance with the 2200 watt motor
Powder field coating for long life time
Machined steel gears for highest durability
Compact ergnomomic design with softgrip on main
handle for more comfortable work
• External brush doors for fast brush replacement
•
•
•
•
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 21-230
2100 watt
6400 rpm
68 mm
230 mm
M14
4.9 kg
4935 4115 00
4002395131037
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
WS 2200-180
2200 watt
8500 rpm
43 mm
180 mm
M14
5.7 kg
4935 4285 06
Superior performance with the 2200 watt motor
Powder field coating for long life time
Machined steel gears for highest durability
Compact ergnomomic design with softgrip on main
handle for more comfortable work
• External brush doors for fast brush replacement
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
WS 2200-230
2200 watt
6600 rpm
68 mm
230 mm
M14
5.8 kg
4935 4285 10
WS 22-180
WS 22-230
WS 24-180 V
180 MM
230 MM
180 MM
Large Angle Grinder
Large Angle Grinder
Large Angle Grinder
FEATURES
FEATURES
FEATURES
• Armored protection for Armature guarantees higher life
time
• Strong Angled machined steel gears for best durability
and improved life time
• Compact design ensures better control and ease of use
• Designed for greater overload capabilities to prevent
overheating
• Armored protection for Armature guarantees higher life
time
• Strong Angled machined steel gears for best durability
and improved life time
• Compact design ensures better control and ease of use
• Designed for greater overload capabilities to prevent
overheating
• Armored protection for Armature guarantees higher life
time
• Strong Angled machined steel gears for best durability
and improved life time
• Compact design ensures better control and ease of use
• Designed for greater overload capabilities to prevent
overheating
• Keyless guard for faster & easier changing guard
direction
• Anti-vibration handles for comfort
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
WS 22-180
2200 W
8500 rpm
43 mm
180 mm
M14
5.1 kg
4935 4316 80
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
SPECIFICATIONS
WS 22-230
2200 W
6600 rpm
68 mm
230 mm
M14
5.2 kg
4935 4317 10
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 24-230 V
GS 500E
230 MM
6 MM
6 MM
Large Angle Grinder
Die Grinder
Die Grinder
WS 24-180 V
2400 watt
8500 rpm
43 mm
180 mm
M14
5.0 kg
4935 4170 40
4002395193516
GSL 600 E
FEATURES
FEATURES
• Armored protection for Armature guarantees higher life
time
• Strong Angled machined steel gears for best durability
and improved life time
• Compact design ensures better control and ease of use
• Designed for greater overload capabilities to prevent
overheating
• Keyless guard for faster & easier changing guard direction
• Anti-vibration handles for comfort
SPECIFICATIONS
Power input
No load speed
Cutting depth
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
WS 24-230 V
2400 watt
6600 rpm
68 mm
230 mm
M14
5.1 kg
4935 4079 85
4002395193479
•
•
•
•
•
•
High speed, one handed die grinder
Variable speed electronic
Automatic cut-off carbon brushes
High rotation precision metal gearbox
Weight only 1,3 kg
Ergonomic switch
SPECIFICATIONS
Power input
No load speed
Collet diameter
Max. grinding wheel diameter
Max. grinding pin diameter
Weight
Article No
EAN No
GS 500E
500 watt
10.000–29.000 rpm
6 mm
40 mm (at 80 m/sec)
20 mm (at 45 m/sec)
1.3 kg
4935 4129 85
4002395192939
FEATURES
•
•
•
•
•
•
•
Variable speed electronic
Long spindle for easy access to awkward places
Double bearing spindle seating for smooth rotation
Automatic cut-off carbon brushes
High rotation precision metal gearbox
Weight only 1,9 kg
Ergonomic switch
SPECIFICATIONS
Power input
No load speed
Collet diameter
Max. grinding wheel diameter
Max. grinding pin diameter
Weight
Article No
EAN No
GSL 600 E
600 watt
10.000–29.000 rpm
6 mm
40 mm (at 80 m/sec)
20 mm (at 45 m/sec)
1.9 kg
4935 4129 65
4002395192946
12
POLISHER / SANDER / CHOPSAW / JIGSAW
PE 150
POWER &
PERFORMANCE
SMT 355
SE 12-180
150 MM
355 MM
Right Angle
Sander
Variable Speed
Polisher
Chop Saw
FEATURES
FEATURES
FEATURES
• 1200 watt polisher
• Variable speed electronics for various materials and
finishes
• Special gearing for high spindle torque and ideal polishing
speed
• Automatic cut-off carbon brushes
• Externally accessible brushes for easy replacement
• Spindle lock
• Large 3 finger switch
• 1200 watt sander with full wave electronics
• Variable speed electronics for various materials and
finishing
• High motor torque and optimum speed range for sanding, especially for fine surface work
• Automatic cut-off carbon brushes
• Externally accessible brushes for easy replacement
• Spindle lock
• Large 3 finger switch
•
•
•
•
•
•
•
•
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Power input
No load speed
Polishing disc Ø
Spindle thread
Weight
Article No
EAN No
PE 150
1200 watt
900–2500 rpm
150 mm
M14
2.1 kg
4935 4122 66
4002395198443
Power input
No load speed
Grinding disc Ø
Spindle thread
Weight
Article No
EAN No
SE 12-180
1200 watt
1800–4800 rpm
180 mm
M14
2.5 kg
4935 4122 79
4002395198481
Powerful 2300 watt motor
–45°/0°/45° mitre capacity with quick release mitre clamp
Spindle lock for easy wheel and accessory changing
Deflector protects the user from sparks
Oversize guard for added safety
On board wrench storage
Rubber feet for greater stability
Replaceable carbon brushes
Power input
No load speed
Wheel diameter
Bore diameter
Weight
Article No
EAN No
SMT 355
2300 watt
3800 rpm
355 mm
25.4 mm
16.5 kg
4935 4117 70
4002395129638
JS 500E
STEP 70
STEP 90 X
Pendulum Jig Saw
Top Handle Jig Saw
Top Handle Jig Saw
FEATURES
FEATURES
FEATURES
•
•
•
•
•
•
Powerful 500 watt motor
FIXITEC system for changing saw blades in seconds
4-Stage pendulum adjustment
Variable speed electronics for control
Dust extraction port
Base plate can be moved backwards for cutting close to
edges and for precise mitre cuts to 45°
SPECIFICATIONS
Power input
No load Stroke
Stroke
Max.cutting depth in wood/steel/
aluminium
Weight
Article No
JS 500 E
500 W
0 - 3000 Spm
19 mm
100 / 8 / 15 mm
2.0 kg
030017022
ST 800 XE
Body Grip Jig Saw
FEATURES
• Powerful 705 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• 4–Stage pendulum adjustment
• Variable speed electronics for control
• AVS anti-vibration mechanism for user comfort
• Ergonomic slimline bodygrip design with integrated
soft-grip
• Dust extraction port
• Dust blower keeps cut line clear for accuracy
• Base plate can be moved backwards for cutting close to
edges
SPECIFICATIONS
Power input
No load stroke rate
Mitre cutting angle to
Stroke
Pendulum settings
Max.cutting depth in wood/steel/
aluminium
Weight
Supplied in
Article No
EAN No
ST 800 XE
705 watt
600–2700 spm
45°
26 mm
4 Stages
110/10/25 mm
2.3 kg
Kitbox
4935 4129 50
4002395192892
•
•
•
•
Powerful 500 watt motor
4-Stage pendulum adjustment
Variable speed electronics for control
Ergonomic design with integrated soft-grip for
comfortable handling
• Dust extraction port
• Dust blower keeps cut line clear for accuracy
• Base plate can be moved backwards for cutting close to
edges and for precise mitre cuts to 45°
SPECIFICATIONS
Power input
No load Stroke
Stroke
Max.cutting depth in wood/steel/
aluminium
Weight
Article No
STEP 70
500 W
1000 - 3200 Spm
19 mm
70 / 5 / 10 mm
1.9 kg
4935412900
• Powerful 600 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• 4-Stage pendulum adjustment
• Variable speed electronics for control
• Ergonomic design with integrated soft-grip for
comfortable handling
• Dust extraction port
• Dust blower keeps cut line clear for accuracy
• Base plate can be moved backwards for cutting close to
edges and for precise mitre cuts to 45°
SPECIFICATIONS
Power input
No load stroke rate
Mitre cutting angle to
Stroke
Pendulum settings
Max. cutting depth in wood/steel/
aluminium
Weight
Supplied in
Article No
EAN No
STEP 1200 BX
PST 500
Top Handle Jig Saw
Palm Jig Saw
STEP 90 X
600 watt
1000–3200 spm
45°
19 mm
4 Stages
100/8/15 mm
2.0 kg
Kitbox
4935 4129 10
4002395192816
FEATURES
• Powerful 600 watt motor
• Patented FIXTEC system for changing saw blades in seconds
• 4–Stage pendulum adjustment
• Variable speed electronics for control
• AVS anti-vibration mechanism for user comfort
• Ergonomic top handle design with integrated soft-grip
• Sawdust blower keeps cutting line clear for accuracy
• Base plate can be moved backwards for sawing close to
edges and for precise mitre cuts to 45°
SPECIFICATIONS
Power input
No load stroke rate
Mitre cutting angle to
Stroke
Pendulum settings
Max. cutting depth in wood/steel/
aluminium
Weight
Supplied in
Article No
EAN No
STEP 1200 BX
600 watt
500–3000 spm
45°
26 mm
4 Stages
110/10/30 mm
2.4 kg
Kitbox
4935 4128 19
4002395192694
FEATURES
• Powerful 450 watt motor
• Patented FIXTEC system for changing saw blades in
seconds
• LED light for cut line visibility
• Pendulum function
• Unique palm design for use in tight spaces and easy
handling
• Dust blower keeps cut line clear for accuracy
SPECIFICATIONS
Power input
No load stroke rate
Mitre cutting angle to
Stroke
Pendulum settings
Max.cutting depth in wood/steel/
aluminium
Weight
Article No
EAN No
PST 500
450 watt
3680 spm
45°
15 mm
1 Stage
40/6/10 mm
1.6 kg
4935 4282 60
4002395194315
13
POWER &
SAWS
PERFORMANCE
US 900 XE
US 1300 XE
Reciprocating Saw
Reciprocating Saw
FEATURES
FEATURES
FEATURES
• Powerful 900 W motor, for fast cuts in various materials
• Pendulum function with 19 mm stroke length, for more powerful and faster cutting progress
• Speed regulation from 0–3500 spm, especially needed for
heat-sensitive materials
• FIXTEC – for fast and easy keyless blade change
• 24 % lighter than other saws, for better work control
• One hand blade insertion
• Soft-grip handle, for better ergonomics
• Powerful 1300 watt motor
• FIXTEC blade clamp for fast and easy blade change
• Variable speed switch for increased cutting control and efficiency
• Adjustable shoe for prolonged blade life
• Ergonomic soft-grip handle design for comfort
• Blades can be turned 180° for various applications
•
•
•
•
•
•
SPECIFICATIONS
Power input
No load stroke rate
Length of stroke
Weight
Article No
EAN No
SPECIFICATIONS
US 900 XE
900 watt
0–3500 spm
19 mm
2.9 kg
4935 4196 10
4002395193806
Power input
No load stroke rate
Length of stroke
Weight
Supplied in
Article No
EAN No
KS 55 C
165 MM
Circular Saw
Powerful 1200 watt motor
0–50° bevel capacity with 45° positive position stop
High strength composite shoe for durability
Externally accessible brushes for easy replacement
Integrated dust blower keeps cut line clear for accuracy
Soft-grip handle for comfort
SPECIFICATIONS
US 1300 XE
1300 watt
0–2800 spm
30 mm
3.8 kg
Kitbox
4935 4132 35
4002395197675
Power input
No load speed
Bevel
Cutting depth 90/45/50°
Saw blade/Arbor Ø
Weight
Article No
EAN No
KS 66 C
MBS 30 Turbo
FTS 100
185 MM
127 MM
Tile Saw
Circular Saw
Material Saw
• Powerful 1600 watt motor for heavy duty applications
• 56° bevel capacity with 45° positive position stop
• Magnesium upper and lower guard offers lightweight high strength
• Full length kerf indicator for accurate cutting
• Externally accessible brushes for easy replacement
• Integrated dust blower keeps cut line clear for accuracy
• Soft-grip handle for comfort
SPECIFICATIONS
Power input
No load speed
Bevel
Cutting depth 90/45/50°
Saw blade/Arbor Ø
Weight
Article No
EAN No
FEATURES
FEATURES
FEATURES
KS 66 C
1600 watt
5800 spm
56°
61/49/35 mm
185/30 mm
4.8 kg
4935 4118 40
4002395193172
•
•
•
•
•
•
•
•
75% dust collection efficiency – best in class!
Comes complete with all dust collection components
Height adjustment – for precise depth setting
Powerful 1010 watt motor for cutting a wide range of
materials quickly and easily
Ergonomic inline motor design, well balanced for
extended use
Dust sealed gearbox design for optimal performance in
dusty environments
Lightweight magnesium guards and base for less user
fatigue during extended use
Spindle lock for quick and easy blade changes
SPECIFICATIONS
Power input
No load speed
Cutting depth 90°/45°
Saw blade/Arbor Ø
Weight
Article No
EAN No
KS 55 C
1200 watt
6100 rpm
0–50°
54/45/38 mm
165/20 mm
3.7 kg
4935 4118 30
4002395193141
MBS 30 Turbo
1010 watt
9000 spm
31/26 mm
127/20 mm
3.4 kg
4935 4118 20
4002395193240
• Powerful 5.8 amp motor cuts through ceramic, granite,
marble and masonry
• Extemally accessible motor brushes for easy maintenance
• Lock-on button reduces fatigue during prolonged cutting
activity
• Water supply hose detaches for dry cuts
• Depth of cuts up to 34 mm
• Steel base includes over sized knobs for easy
adjustments
• Bevel adjustment provides range of motion from 0° to 45°
SPECIFICATIONS
Power input
Wheel Diameter
Blade Arbor
Cutting Depth at 90°
Cutting Depth at 45°
No Load Speed
Weight
Article No
FTS 100
1300 W
110mm (no blade is supplied with the tool)
20 mm
34 mm
20 mm
13,000 rpm
3.2 Kgs
4935 4281 45
TS 55 E
PS 305 DG
PS 254 L
Plunge Saw
305 MM
254 MM
FEATURES
Slinding Compound
Miltre Saw
Compound Mitre Saw
•
•
•
•
•
•
FEATURES
FEATURES
• Powerful 1800 watt motor delivers 4400 rpm
• Large cutting capacities include a massive maximum
crosscut of 343 x 111 mm at 90°
• Double bevel 0–47° left or right
• Mitres 60° left or right, perfect for awkward mitres
• Rugged cast construction with huge table area
• Cam operated mitre lock for fast angle adjustment
•
•
•
•
SPECIFICATIONS
SPECIFICATIONS
Powerful 1500 watt motor
Smooth plunge action for precision cuts
55 mm cutting capacity (50 mm with guide rail)
0–45° bevel capacity
Works with all common guide rails
Soft-grip handle for comfort
SPECIFICATIONS
Power input
No Load speed
Mitre cutting angle to
Max. cutting depth at 90°
Max. cutting depth at 45°
Saw blade/Arbor Ø
Weight
Supplied in
Article No
EAN No
TS 55 E
1500 watt
0–1500 spm
45°
55 mm
50 mm
160/20 mm
4.6 kg
Kitbox
4935 4192 90
4002395133130
Power input
Blade diameter
No load speed
Mitre capacity (left/right)
Depth of cut
Crosscut capacity
Weight
Article No
EAN No
PS 305 DG
1800 watt
305 x 30 mm
4400 rpm
60°
111 mm
343 mm
31.0 kg
4935 4115 70
4002395126002
Ample power of 2000 watts for most cutting jobs
Mitre setting indents for the angles most commonly used.
Integrated dust extraction for effective dust extraction
Adjustable Laser for straight cuts with a perfect view of
the cutting line
• Working light: illuminates work piece and cutting line
• Depth Adjustment: For easy and fast cutting of grooves
Power input
Blade diameter
No load speed
Mitre capacity (left/right)
Depth of cut
Crosscut capacity
Weight
Article No
EAN No
PS 254 L
2000 watt
254 x 30 mm
4500 rpm
45°
90 mm
305 mm
19.5 kg
4935 4406 70
4002395134687
14
POWER &
SAWS / SANDERS
PS 216 L
PERFORMANCE
PSU 1000
216 MM
TS 250 K
250 MM
Compound Mitre Saw
Leg Stand
Table Saw
FEATURES
FEATURES
•
•
•
•
Ample power of 1500 watts for most cutting jobs
Mitre setting indents for the angles most commonly used.
Integrated dust extraction for effective dust extraction
Adjustable Laser for straight cuts with a perfect view of
the cutting line
• Working light: illuminates work piece and cutting line
• Depth Adjustment: For easy and fast cutting of grooves
SPECIFICATIONS
Power input
Blade diameter
No load speed
Mitre capacity (left/right)
Depth of Cut
Cross Cut Capacity
Weight
Article No
EAN No
PS 216 L
1500 watt
216 x 30 mm
5000 rpm
45°
65
305 mm
16.5 kg
4935 4406 50
4002395134656
•
•
•
•
FEATURES
• Lightweight construction for optimal mobility
• Compact & Foldable
• Simple adjustment of the legs when working on uneven
surfaces
• Fixed stop legs for quick height adjustment
• Handles up to 180 kg.
•
•
•
•
•
Powerful 1800 watt motor
4800 rpm for effortless accurate cutting
90 mm cutting depth (53 mm at 45°)
Dual clamping parallel fence for high stability and
accuracy
Overload protection ensures durability
Soft start
Integrated table side extension up to 645 mm gives huge
cutting capacity
Collapsible stand with wheels and height adjustment for
easy transportation and portability
On board storage for all tools and spare blades
SPECIFICATIONS
TS 250 K
1800 watt
254 x 30 mm
4800 rpm
45°
90/62 mm
41.0 kg
4935 4192 65
4002395133093
PSU 1000
Extendable to 1.0 m
Folds down to 0.9 m
200 Kg max. load
Lightweight construction for portibility
Power input
Blade diameter
No load speed
Mitre capacity (left/right)
Depth of cut 90/45°
Weight
Article No
EAN No
EX 125 ES
EX 150 ES
HBS 1000 E
125 MM
150 MM
Belt Sander
Random Orbital
Sander
Random Orbital
Sander
FEATURES
•
•
•
•
•
•
Ergonomic & compact 300 watt random orbit sander
Ideal for working in confined spaces and over head
Variable speed for optimum control
Pad brake control: pad brake for a gauge free workpiece
Convenient hook & loop paper fastening
Very efficient dust extraction over 8 holes in the base
plate
• Dust extraction, with dust bag or absorption system
• Soft-grip on handle
SPECIFICATIONS
Power input
No load speed
Oscillation rate
Oscillation diameter
Sanding disc size
Weight
Article No
EAN No
EX 125 ES
300 watt
7000–15.000 rpm
14.000–30.000 opm
2 mm
125 mm
1.5 kg
4935 4161 00
4002395129799
BBSE 1100
SPECIFICATIONS
FEATURES
FEATURES
•
•
•
•
Dual orbits for control of material removal
Variable speed for optimum control
Soft start and pad brake for a gauge free workpiece
Through-body sealed slide switch for reliability and ease
of use
• Convenient hook & loop paper fastening
• Dust extraction, with dust bag or absorption system
• Diecast construction for strength and durability
SPECIFICATIONS
Power input
No load speed
Oscillation rate
Oscillation diameter
Sanding disc size
Weight
Article No
EAN No
EX 150 ES
440 watt
4000–10.000 rpm
8000–20.000 opm
3.2/6.4 mm
150 mm
2.8 kg
4935 4132 00
4002395197606
•
•
•
•
•
•
•
•
Powerful 1010 watt motor
Electronic speed for control and optimum results
Clamping lever for easy, tool free changing of sanding belt
Externally accessible brushes for easy replacement
Control wheel for precise adjustment of sanding belt
Compact design, ideal for sanding close to edges
Die-cast construction for high strength and durability
Dust extraction, with dust bag or absorption system
SPECIFICATIONS
Power input
Belt length
Belt speed
Sanding surface
Belt width
Weight
Supplied in
Article No
EAN No
FDS 140
FS 280
¼ Sheet Sander
½ Sheet Sander
FEATURES
FEATURES
•
•
•
•
•
•
•
•
HBS 1000 E
1010 watt
533 mm
240–450 m/min
75 x 145 mm
75 mm
5.1 kg
Kitbox
4935 4132 05
4002395197613
Belt Sander
FEATURES
•
•
•
•
•
Powerful 1100 watt motor
Extra-large sanding surface 100 x 140 mm
Full-wave electronics with pre-selection of belt speed
Control wheel for precise adjustment of belt alignment
Dust extraction, with dust bag or absorption system
SPECIFICATIONS
Power input
Belt length
Belt speed
Sanding surface
Belt width
Weight
Article No
EAN No
BBSE 1100
1100 watt
560 mm
230–400 m/min
100 x 140 mm
100 mm
5.0 kg
4935 4135 30
4002395199037
Extremely compact 280 watt sheet sander
Ideal for working in confined spaces and over head
Delta base for sanding in corners
Hook & loop and large release tabs for convenient paper
changing
• Magnesium base for more stability and less vibration
• Dust extraction with dust bag or absorption system
• Soft-grip on handle
SPECIFICATIONS
Power input
No load speed
Oscillation rate
Oscillation diameter
Sanding disc size
Weight
Article No
EAN No
FDS 140
280 watt
15.000 rpm
20.000 opm
1,6 mm
115 x 140 mm
1.5 kg
4935 4160 90
4002395129768
Powerful 440 watt motor
Variable speed for optimum control
Convenient hook & loop paper fastening
Dust extraction, with dust bag or absorption system
SPECIFICATIONS
Power input
Oscillation rate
Sanding surface
Weight
Article No
EAN No
FS 280
440 watt
14.000–26.000 opm
115 x 280 mm
3.0 kg
4935 4192 80
4002395133116
15
&
ROUTERS / HEAT GUNS / BLOWERS / VACUUMS POWER
PERFORMANCE
PL 750
RT 1350 E
OF 2050 E
82 MM
12 MM
Planer
Plunge Router
Plunge Router
FEATURES
FEATURES
FEATURES
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Powerful 750 watt motor
Left and right chip ejection for greater convenience
Heel shoe protects the base, blade and work surface
0,2 mm stage depth adjustment setting for greater control
and accuracy
• Depth scale indicator
SPECIFICATIONS
Power input
No load speed
Cutting depth
Cutting width
Max. rebate
Weight
Article No
EAN No
PL 750
750 watt
16000 rpm
2 mm
82 mm
12 mm
2.9 kg
4935 4191 40
4002395130481
Powerful 1350 watt motor
Electronic speed control
Plunge depth set by calibrated dial
Vertical depth adjustment scales
SPECIFICATIONS
Power input
No load speed
Collect Size
Plunge Capacity
Weight
Article No
Powerful 2050 watt motor
Electronic variable speed control
Plunge depth set by calibrated dial
Micro depth adjustment
3-stage depth stop lock
Vertical depth adjustment scales
SPECIFICATIONS
RT 1350 E
1350 watt
15000-25000 rpm
6 mm x 12 mm
50 mm
3.5 kgs
030041018
Power input
Collet capacity
Plunge capacity
No load speed
Weight
Article No
EAN No
OF 2050 E
2050 watt
6/8/12 mm
66 mm
10.000–20.000 rpm
6.2 kg
4935 4036 65
4002395125869
MF 1400 KE
HG 560 D
HG 600 V
Plunge & Fixed
Base Combo
Router
Hot Air Blower
Hot Air Blower
ALSO AVAILABLE: With Accessories
In Kitbox HG 600 VK
FEATURES
FEATURES
• 2 routers in one for maximum flexibility in all kinds of
application
• Soft start to prevent sudden kickback
• Integrated electronics maintain constant speed under
load
• Variable speed electronics for optimum control in a wide
range of materials
• Large soft-grip handles for decreased vibration and
greater comfort
• Flat motor housing with integrated rubber feet for convenient upside down bit change with spindle lock
• Premium collet and shaft design minimises run out
• Built in LED for unparalleled workplace illumination
• Through table depth adjustment for ultimate convenience
SPECIFICATIONS
Power input
Collet capacity
Plunge capacity
No load speed
Weight
Article No
EAN No
MF 1400 KE
1400 watt
8/12 mm
64 mm
10.000–23.000 rpm
5.7 kg
4935 4118 50
4002395193295
•
•
•
•
•
•
•
1500-watt motor
Anti-Slip surface for better grip
2 Adjusting temperature settings: 300/560 ° C
253/420 liters per minute of air flow
Robust fan for continuous operation
Extremely light, only 0.85 kg Accessories
Designed to stand on its own for hands free operation
SPECIFICATIONS
Power input
Air Volume Level1 / Level 2
Temp Control Level 1 / Level 2
Weight
Article No
EAN No
HG 560 D
1500 watt
253 - 420 lpm
300 °C / 560 °C
850 g
4935 4410 15
4002395134991
FEATURES
• 2000-watt motor
• Anti-Slip surface for better grip
• Electronics with temperature sensor control for variable
temperature setting ranging from 90° C to 600° C
• 345/434 liters per minute of air flow
• Robust fan for continuous operation
• Extremely light, only 0.9 kg Accessories
• Designed to stand on its own for hands free operation
SPECIFICATIONS
Power input
Air Volume Level1 / Level 2
Temp Control
Weight
Article No
EAN No
HG 600 V
2000 watt
345 - 434 lpm
90°C - 600 °C
900 g
4935 4410 25
4002395135011
GM 600 E
AP 250 ECP
AP 300 ELCP
Air Blower
Vaccum Cleaner
Vaccum Cleaner
FEATURES
FEATURES
• Variable Speed control switch to adjust the airflow as per
the cleaning job.
• High quality vaccum bag for effective dust collection
• Lock on Switch for Continuous work
FEATURES
•
•
•
•
•
CLEAR-PRESS filter cleaning system
Wet & dry cleaning
Wet overfill protection
Click system – easy to change accessories
Fleece double wall filter bag and disposal bag
SPECIFICATIONS
SPECIFICATIONS
Power input
No load Speed
Air volume
Weight
Article No
GM 600 E
600 watt
0-16000 rpm
0-2.8 mCu
0.6 kgs
4935 4281 50
Power input max
Air volume
Max. vacuum
Container capacity
Suction hose diameter/length
Weight
Article No
AP 250 ECP
1400 watt
3600 l/min
190 mbar
25 l
32 mm x 3.5 m
6.0 kgs
4935 4118 80
• CLEAR-PRESS filter cleaning system
• PET filter cartridge
• Automatic operation when used with powertools
• Dust class L for dust rated up to 1 mg/m3
• Low noise fan for silent cleaning
• Wet & dry cleaning
• Fleece double wall filter bag and disposal bag
SPECIFICATIONS
Power input max
Air volume
Max. vacuum
Container capacity
Suction hose diameter/length
Weight
Article No
AP 300 ELCP
1500 watt
3700 l/min
250 mbar
30 l
32 mm x 3.5 m
10.0 kgs
4935 4118 90
16
POWER &
MULTI TOOL
PERFORMANCE
3 BODIES, 7 HEADS,
1 0 0 + APPLICATIONS
MULTITOOL HEAD
OMNI-MT
IMPACT DRIVER HEAD
OMNI-IH
HAMMER HEAD
OMNI-HH
RIGHT ANGLE
DRILLING HEAD
OMNI-RAD
RATCHED HEAD
OMNI-IR
Article No. 4935 4407 00
EAN No. 4002395134717
Article No. 4935 4407 30
EAN No. 4002395134779
Article No. 4935 4407 10
EAN No. 4002395134731
Article No. 4935 4407 05
EAN No. 4002395134724
Article No. 4935 4407 20
EAN No. 4002395134755
BEST FOR
OMNIPRO 12 V BASE UNIT
ERGONOMICS
OMNI12C
POWER
OMNI18C
The OMNI18C gives more power and more runtime than
the 12 V power base, whilst keeping the advantage of
cordless portability.
The OMNI12C offers users the ultimate in ergonomics.
The light weight, compact body is ideal for working in
tight spaces.
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– Optimum power to weight ratio
– LED for work place illumination
– Built in fuel gauge
213 mm
OMNI12C
SPECIFICATIONS
OMNI18C
Battery voltage
12 V
Battery voltage
18 V
No load oscillation rate
20000 min-1
No load oscillation rate
20000 min-1
Oscillation angle left / right
1,54/1,54
Oscillation angle left / right
1,54/1,54
60 mm
280 mm
FEATURES
FEATURES
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– LED for work place illumination
– Small and compact for working in tight environments
SPECIFICATIONS
BEST FOR
OMNIPRO 18 V BASE UNIT
70 mm
ALL HEADS AND BODIES
17
POWER &
MULTI TOOL
PERFORMANCE
ONE SYSTEM
OMNIPRO is a revolutionary system allowing users to tailor their system depending
on application. All heads and bodies are interchangeable to select the best balance
of power base and head for ultimate productivity.
JIGSAW HEAD
OMNI-JS
RECIPROCATING SAW HEAD
OMNI-RH
Article No. 4935 4407 15
EAN No. 4002395134748
Article No. 4935 4407 25
EAN No. 4002395134762
BEST FOR
OMNIPRO AC BASE UNIT
RUNTIME
OMNI300
FEATURES
SPECIFICATIONS
300 W
No load oscillation rate
20000 min-1
Oscillation angle left / right
1,5 /1,54
Cat No. OMNI12C LI-152C KIT1 Article No.4935 4407 65 Version.12 V power handle, multitool head,
accessories,
2 x 1.5 Ah batteries, charger, bag EAN No.
4002395134809
EAN No.
4002395134816
OMNI18C
260 mm
Cat No.OMNI18C LI-152C KIT1 Article No.4935 4406 44 Version. 18 V power handle, multitool head, accessories,
2 x 1.5 Ah batteries, charger, bag EAN No.4002395134632
Cat No. OMNI 18C-0 KIT1 Article No.4935 4406 45 Version. 18 V power handle, multitool head, no batteries or charger supplied (accessories are also delivered with the 0 version)
4002395134649
EAN No.
OMNI300
Power
OMNI12C
Cat No.
OMNI12C LI-152B KIT3 Article No.4935 4407 80 Version. 12 V power handle, multitool head, jigsaw head, accessories,
Cat No.
OMNI12C LI-152B KIT2 2 batteries, charger, bag Article No.4935 4407 70 EAN
No.4002395134830
Version. 12 V power handle, multitool head, right angle drill head, accessories, 2 batteries, charger, bag The OMNI300 is the choice for longer applications
where a cordless machine is not required, with all the
power expected from an AC machine.
– Tool free interchangeable heads to easily switch between
a wide range of applications
– Large 2 finger switch with adjustable speed
– One handed use of applications
– LED for work place illumination
– Mains machine
CHOOSE
YOUR
SYSTEM
OMNI300
80 mm
ARE INTERCHANGEABLE
Cat No.
OMNI300 KIT1 Article No.4935 4317 90 Version. AC Multitool, multitool head, accessories, soft bag EAN No.4002395194995
18
POWER &
BATTERIES / CHARGERS
PERFORMANCE
ACCESSORIES
BATTERIES
Chemistry
Capacity
L1815R
Li-Ion
1.5
3.6V
12 V
14.4 V
18 V
Catalogue
Number
Charger Compatibility
Charge Time*
AL 9618 / 60 min*
Article
Number
EAN
Number
4932352654
4002395373123
4932430169
4002395378302
L1820R
Li-Ion
2.0
L1830R
Li-Ion
3.0
4932352655
4002395373130
L1840R
Li-Ion
4.0
4932430170
4002395378319
L1415R
Li-Ion
1.5
4932 352656
4002395373147
L1420R
Li-Ion
2.0
4932430167
4002395378289
4932352657
4002395373154
BL 1218 / 30 min*
AL 9618 / 60 min*
L1430R
Li-Ion
3.0
M1430R
NiMH
3.0
4932352110
4002395367634
B1414G
NiCd
1.4
4932352531
4002395371891
L1215
Li-Ion
1.5
4932352658
4002395373161
L1215R
Li-Ion
1.5
4932430365
4002395380268
L1220
Li-Ion
2.0
4932430165
4002395378265
L1240
Li-Ion
4.0
4932430166
4002395378272
4932352107
4002395367603
4932352532
4002395371907
4932352099
4002395367528
4932352098
4002395367511
M1230R
NiMH
3.0
B1214G
NiCd
1.4
SL 3,6
Li-Ion
1.5
BL 1218 / 30 min*
LL 1230 / 30 min*
AL 9618 / 60 min*
BL 1218 / 30 min*
LA 036 / 30 min*
SB 3,6
NiCd
1.4
CHARGERS
Catalogue
Chemistry
Number
AL1214G
Charger Compatibility
Charge Time*
NiCd, NiMH, Li-Ion 12–14,4 V
Article
Number
EAN
Number
4932 3524 81
4002395371402
60 min*
AL1218G
NiCd, NiMH, Li-Ion 12–18 V
4932 3529 57
4002395376155
BL 1218
NiCd, NiMH, Li-Ion 12 – 18 V
4932 3526 59
4002395373178
LL 1230
4932 3520 96
4002395367498
LA 036
4932 3520 97
4002395367504
Li-Ion 12 V
30 min*
NiCd, NiMH, Li-Ion 3,6 V
* Charge times based on 1,5 Ah Li-ion battery
19
POWER &
SDS PLUS / SDS-MAX DRILL BITS
PERFORMANCE
ACCESSORIES
SDS-PLUS DRILL BITS – 2 CUT / 10 PIECE POWER PACKS
High quality 2 cutter carbide tip with 130° tip angle. The carbide tip is set deeper into the head for a more precise fit and better durability. 2 flute geometry for rapid material
removal. Surface treated flute eliminates binding for faster drilling and high abrasion resistance. Made in Germany.
Ø
A
B
Quantity
Art. No. EAN No.
mmmmmm 4932-
4002395
110
50
10
352256369157
5,5
5
110
50
10
352257
369164
6
110
50
10
352258
369171
6
160
100
10
352259
369188
7
160
100
10
352260
369195
8
110
50
10
352261
369201
8
160
100
10
352262
369218
8
210
150
10
352263
369225
10
160
100
10
352264
369232
10
210
150
10
352265
369249
10
260
200
10
352266
369256
12
160
100
10
352267
369263
12
210
150
10
352268
369270
Power Set 8pcs – SDS-plus drill bits
352236
B
A
368952
with Ø 5 / 6 / 8 x 110 mm and Ø 6 (2 pcs) / 8 / 10 / 12 x 160 mm
SDS-plus Starter Set 352653
373116
with Ø 6 / 8 / 10 x 160 mm, point chisel and flat chisel
SDS-MAX DRILL BITS – 2 CUT
Ø
A
B
Quantity
Art. No. EAN No.
mmmmmm 4932-
4002395
16 540400 1352687373451
18
540
400
1
352688373468
20
520
400
1
352689373475
22
520
400
1
352690373482
25
520
400
1
352691373499
28
570
450
1
352692373505
30
570
450
1
352693373512
32
570
450
1
352694373529
B
A
SDS-MAX DRILL BITS - 2 CUT / 4 CUT (S: Pre-drill with a short drill bit of the same diameter. L: 2 cut drill bits)
Ø
A
B
Quantity
Art. No. EAN No.
mmmmmm 4932-
4002395-
12
12
14
14
15
15
16
18
20
20
22
22
24
24
25
25
28
28
30
32
32
35
35
35
38
38
40
40
40
45
52
340
540
340
540
340
540
340
320
320
920
320
920
320
520
320
920
370
920
370
370
920
370
570
920
370
570
370
570
920
570
570
200L
400 SL
200L
400 SL
200L
400 SL
200
200
200 S
800 S
200
800 S
200
400 S
200
800 S
250
800 S
250
250
800 S
250
450 S
800 S
250
450 S
250
450 S
800 S
450 S
450 S
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
352750
352751
352752
352753
352754
352755
352756
352760
352764
352759
352768
352770
352772
352773
352774
352776
352778
352781
352783
352785
352787
352789
352790
352791
352792
352794
352793
352795
352796
352798
352799
315956
315963
315987
315994
316007
316014
316038
316052
316076
316090
316106
316120
316137
316144
316151
316175
316182
359790
316212
316236
316250
316267
316274
359813
316298
316304
316311
316328
316335
353415
353422
B
A
20
POWER &
CHISELS / MASONRY DRILL BITS
PERFORMANCE
ACCESSORIES
SDS-PLUS CHISELS
Description
A
B
Quantity
Art. No.
EAN No.
mm
mm4932-
4002395 Point chisel
200
–
1
352269369287
Flat chisel
200
20
1
352270369294
Wide chisel
200
35
1
352271369300
Set of 3 SDS-plus chisels with 1 pointed, 1 flat, 1 wide chisel
352272369317
A
B
B
SDS-MAX CHISELS
Description
A
B
Quantity
Art. No.
EAN No.
mm
mm4932-
4002395 Point chisel
400
–
1
352685373437
Flat chisel
400
25
1
352686373444
A
MASONRY DRILL BITS
Carbide tip with diamond ground cutting edges with 130° angle – For drilling in brick and aerated concrete blocks
Ø
A
B
Quantity
Art. No. EAN No.
mmmmmm 4932-
4002395
4
75
40
1
363591332410
5
85
50
1
363593332434
5,5
85
50
1
363595332458
6
100
60
1
363597332472
6
150
85
1
367032333967
7
100
60
1
363599332496
8
120
80
1
363600332502
8
200
135
1
363612332366
10
120
80
1
363602332526
10
200
135
1
363613332373
12
150
85
1
363604332540
Power Set 10pcs – masonry drill bits with Ø 4 / 5 / 5,5 / 6 (2 pcs) / 7 / 8 (2 pcs) / 9 / 10 mm
352239368983
B
A
21
POWER &
CUTTING & GRINDING DISCS
PERFORMANCE
ACCESSORIES
CUTTING AND GRINDING DISCS
METAL CUTTING DISCS
Applications : Great performance in cutting mild steel with medium strength, plain alloy tool steel, concrete reinforcing iron and steel rebar.
Characteristics : Efficient cutting properties in combination with high performance.
41
42
Disc Ø
mm
Thickness
mm
Bore Ø
mm
Quantity
Id.No
4932
F 41 / 300
300
2.8
25.4
25
430050
377114
F 41 / 350
350
2.8
25.4
25
430051
377121
F 42 / 100
100
3
16
25
430351
380121
F 42 / 115
115
3
22.2
25
430047
377084
Type
EAN Code
4002395
F 42 / 125
125
3
22.2
25
430357
380183
F 42 / 180
180
3
22.2
25
430048
377091
F 42 / 230
230
3
22.2
25
430049
377107
Thickness
mm
Bore Ø
mm
Quantity
Id.No
4932
EAN Code
4002395
METAL CUTTING DISCS
Type
41
Disc Ø
mm
F 41 / 100
100
1
22.2
50
430354
380152
F 41 / 115
115
1
22.2
50
430057
377183
F 41 / 125
125
1
22.2
50
352916
375745
F 41 / 230
230
1
22.2
50
352917
375752
Quantity
Id.No
4932
EAN Code
4002395
METAL GRINDING DISCS
Applications : Sound performance in mild steel and non-alloy tool steel
Characteristics : Provides good lifetime and efficient grinding characteristics.
Type
27
Disc Ø
mm
Thickness
mm
Bore Ø
mm
F 27 / 100
100
6
16
25
430352
380138
F 27 / 115
115
6
22.2
25
430052
377138
F 27 / 125
125
3
22.2
25
352906
375646
F 27 / 180
180
6
22.2
10
430053
377145
F 27 / 130
230
6
22.2
10
430353
380145
Quantity
Id.No
4932
EAN Code
4002395
375677
STONE CUTTING DISCS
Applications : Great performance in cutting natural stones.
Characteristics : Efficient cutting properties in combination with high performance.
42
Type
Disc Ø
mm
Thickness
mm
Bore Ø
mm
F 42 / 100
100
3
16
50
352909
F 42 / 115
115
3
22.2
50
430054
377152
F 42 / 180
180
3
22.2
50
430055
377169
F 42 / 230
230
3
22.2
50
430056
377176
22
POWER &
DIAMOND BLADES
PERFORMANCE
ACCESSORIES
DIAMOND BLADES
Type
Disc Ø
Bore Ø
mm
mm
Segment height
mm
Quantity
Per Pack
Id.No
4932
EAN Code
4002395
DU - A general Purpose blade for wide variety of construction materials
DU 115
115
22.23
10
1
399521
361687
DU 125
125
22.23
10
1
399522
361694
DU 180
180
22.23
10
1
399523
361700
DU 230
230
22.23
10
1
399524
361717
DUT - A general Purpose turbo rimmed blade for cutting a wide variety of general building materials.
DUT 115
115
22.23
10
1
399526
361731
DUT 125
125
22.23
10
1
399527
361748
DUT 180
180
22.23
10
1
399528
361755
DUT 230
230
22.23
10
1
399529
361762
DUH - A trade laser welded quality blade with exceptional performance in hard materials such as hard concrete.
DUH 115
115
22.23
10
1
399539
361861
DUH 125
125
22.23
10
1
399540
361878
DUH 180
180
22.23
10
1
399541
361885
DUH 230
230
22.23
10
1
399542
361892
DHTS - A trade quality turbo rimmed blade with extra thin body for cuts in thin materials such as granite, marble & tiles.
DHTS 115
115
22.23
10
1
399145
357550
DHTS 125
125
22.23
10
1
399146
357567
DHTS 230
230
22.23
10
1
399550
361977
DHTi - Specially designed turbo rimmed blade for clean cut edges in ceramic tiles and thin natural stone tiles / slabs.
DHTi 115
115
22.23
8
1
399552
361991
DHTi 125
125
22.23
8
1
399553
362004
DHTi 230
230
22.23
8
1
399555
362028
DSU - A trade quality universal blade, specially designed for hard and abrasive materials
DSU 125
125
10
10
1
373147
346455
DSU 150
150
10
10
1
373148
346468
23
POWER &
HOLESAWS / RECIPROCATING SAW BLADES
PERFORMANCE
ACCESSORIES
HIGH PERFORMANCE BI-METAL HOLESAWS / SYSTEM ACCESSORIES
Ø
mm
Ø
Inch
Art. No.
4932-
EAN No.
4002395-
Ø
mm
Ø
Inch
Art. No.
4932-
EAN No.
4002395-
Ø
mm
Ø
Inch
Art. No.
4932-
EAN No.
4002395-
14
16
19
20
21
22
24
25
27
29
30
32
35
⁄16
⁄8
3
⁄4
25
⁄32
13
⁄16
7
⁄8
15
⁄16
1
1 1⁄16
1 1⁄8
1 3⁄16
1 1⁄4
1 3⁄8
367244
367245
367247
367248
367249
367250
367251
367252
367253
367289
367254
367255
367256
335947
335954
335978
335985
335992
336005
336012
336029
336036
336043
336050
336067
336074
38
40
43
44
48
51
54
57
60
64
65
68
70
1 1⁄2
1 9⁄16
1 11⁄16
1 3⁄4
1 7⁄8
2
2 1⁄8
2 1⁄4
2 3⁄8
2 1⁄2
2 9⁄16
2 11⁄16
2 3⁄4
367257
367258
367259
367260
367262
367263
367265
367266
367267
367268
367269
371580
367271
336081
336098
336104
336111
336135
336142
336166
336173
336180
336197
336203
345250
336227
73
76
79
83
89
92
98
102
105
114
121
127
152
2 7⁄8
3
3 1⁄8
3 1⁄4
3 1⁄2
3 5⁄8
3 7⁄8
4
4 1⁄8
4 1⁄2
4 3⁄4
5
6
367272
367273
367274
367275
367277
367278
367280
367281
367282
367284
367285
367286
367288
336234
336241
336258
336265
336289
336296
336319
336326
336333
336357
336364
336371
336395
9
5
FIXTEC arbor 5⁄8 x 18 11 mm Hex for holesaws Ø 32 – 152 mm
Arbor 1⁄2 x 20 Light duty arbor 1⁄2 x 20 Hex 9 for holesaws Ø 14 – 30 mm
Pilot drill bit long For use with arbor 4932367421
Pilot drill bit short For use with arbor 4932367422
Art. No.
4932-
EAN No.
4002395-
367421
367422
367423
367424
337422
337439
337446
337453
EAN No.
4002395-
Application
Art. No.
4932-
Quantity
Ref. No.
Tooth pitch
mm
Blade length
(toothed) mm
RECIPROCATING SAW BLADES FOR WOOD / PLASTICS / METAL
150 2,5 S811H
3
All woods, nail embedded wood, plaster board 3–100 mm, non-ferrous metals, aluminium 3–10 mm, plastic pipes
318127301959
150
4,2
S744D
2
Fast scroll cutting 6 –100 mm
323801304240
150
4
S644D
2
Fast cutting of wood and plastic, plunge cutting, 6–100 mm
323800304233
240
8,5
S1542K
2
Special hardened teeth design, fast coarse cut, as well for green and fire wood, 20–180 mm
323804304271
300
4,2 S1344D
2
Fast cutting large timbers and plastic, clean cut, 6–250 mm
323802304257
150 1,4 S922EF
3
For all metals with a wall thickness between 1,5–4 mm
354792324477
150
S922BF
3
For all metals with a wall thickness between 3–10 mm
354789324446
230Coarse gritS1130R
2
For abrasive materials, fibreglass materials (polyesters, epoxies, melamines), cast iron pipes
373386348817
1,8
24
POWER &
JIG SAW BLADES / CIRCULAR SAW BLADES
ACCESSORIES
PERFORMANCE
Quantity
T 111 C
5
50
1,35 T 101 AO
Application
Cu/Ni/Ms/Zn
ALU
DEPTH OF CUT (mm)
EAN No.
4002395-
Ref. No.
3
75
METAL
Art. No.
4932-
Tooth pitch
mm
Blade length
(toothed) mm
JIGSAW BLADES FOR WOOD / PLASTICS / METAL
5–60
-
-
< 40
-
-
-
352144367979
Fast, clean, curve cutting
< 20
-
< 20
< 15
-
-
-
352145367986
Rough cutting
5
75
4
T 244 D
5
Rough, curve cutting
< 60
-
-
-
-
-
-
352146367993
75
4
T 144 D
5
Fast, rough cutting
< 60
-
-
-
-
-
-
352147368006
75
2,5
T 101 B
5
Very clean, splinter free cutting
< 30
< 60
-
< 30
-
-
-
352148368013
75
4
T 101 D
5
Fast, clean, splinter free cutting
< 60
< 60
-
< 45
-
-
-
352149368020
55
1,2
T 118 A
5
For thin sheet metal
-
-
-
-
1,5–4
1,5–4
-
352150368037
-
-
-
-
3–6
3–6
3–10
352151368044
55
2 T 118 B
5 Rougher cuts in metal
12 piece set in container
373494349944
Suitable for applications in wood, cutting worktops and laminate flooring and metals
Power Set 50pcs – jigsaw blades for wood and metal
10 x T 144 D, 15 x T 118 A, 10 x T 101 B, 15 x T 118 B
352253369126
➀
➁
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Clean / Fine cut
✓
✓
Plasterboard
✓
✓
Plastics
✓
✓
✓
Non ferrous
1,8
1,8
2,2
2,2
2,6
2,8
1,8
Plywood &
OSB boards
6
40
48
48
24
52
24
Laminated
chipboard
20
20
20
20
20
20
30
Number Cutting width
of teeth
(kerf) mm
MDF /
Fibreboard
127
127
160
160
165
165
➄ 184
➀
➁
➂
➃
B
mm
Chipboard
A
mm
Fibre cement
board
CIRCULAR SAW BLADES
✓
✓
✓
✓
✓
✓
➂
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
➃
•
✓
✓
Art. No.
4932-
EAN No.
4002395-
352534
352535
352868
352869
430311
430312
352874
371921
371938
375264
375271
379729
379736
375325
➄
25
DRILLING & SCREWDRIVING SETS / ANGLE ATTACHMENT
POWER &
PERFORMANCE
ACCESSORIES
WB1 SET – SCREWDRIVER ANGLE ATTACHMENT WITH 10 SCREWDRIVING BITS
• Contents: WB1 and screwdriving bits 25 mm PH1 / PH2 / PZ1 / PZ2 (2pcs) / TX15 / TX20 / Hex 4 / Hex 5
• Being only 30 mm high it is ideally suited to working in confined and limited spaces
• Fits to all machines. The ¼˝ Hex shank fits directly into the chuck preventing slippage
• Magnetic ¼˝ Hex reception. Accepts standard ¼˝ Hex screwdriving bits
• Adjustable to working situation. 360° variable thumb lever for extra grip
• Industrial quality up to 11 Nm torque and 400 min–1
• Tough gears made of special hardened steel
Art. No.
4932-
EAN No.
4002395-
Counter display (12 x WB1 Sets)
430174
378357
Single WB1 – screwdriver angle attachment with 10 screwdriving bits
430173
378340
Art. No.
4932-
EAN No.
4002395-
Counter display (20 x sets)
399494
361144
Single Maxi-Bit screwdriving set (10pcs)
Contents:
SL 0,6 x 4,5 / SL 0,8 x 5,5 / SL 1,5 x 6,5 / PH1 / PH2 / PH3 / PZ1 / PZ2 / PZ3
1⁄4˝ Hex magnetic bit holder
399493
361151
Art. No.
4932-
EAN No.
4002395-
Counter display (20 x sets)
399496
361168
Single Profi-Bit screwdriving set (17pcs)
Contents:
SL 0,8 x 5,5 / SL 1,2 x 6,5 / PH1 / PH2 (2pcs) / PH3 / PZ1 / PZ2 (2pcs) / PZ3 / TX10 /
TX15 / TX20 / TX25 / TX30 / TX40
1⁄4˝ Hex magnetic bit holder
399495
361175
MAXI-BIT SCREWDRIVING SET
PROFI-BIT SCREWDRIVING SET
FIXTEC NUTS
• FIXTEC: Disc changing in seconds, no extra tools required
• 12 seconds from removing the worn disc to fixing a new disc
• Only 8 mm thin, enabling more surface of disc on the material
• Compatible to all manufacturers angle grinders up to 150 mm with standard M14 spindle thread
• With integrated keyholes, for removal of the nut with a standard pin spanner in the event of the nut
becoming too tight
5
sec
7
sec
9
sec
11
sec
12
sec
Art. No.
4932-
EAN No.
4002395-
Counter display (12 x FIXTEC Nut)
358936
326693
Single FIXTEC Nut
358225
325528
26
HSS BIT SET / WOOD BIT SET / JIG SAW BLADES SET
POWER &
PERFORMANCE
ACCESSORIES
POWER SET HSS-G TIN DRILL BITS
• Metal drill bits ground from high speed steel according to DIN 338
• Normal point cutting tip with 118° angle
• Standard type N flute design
• Titanium nitride coating increases cutting speed by 50% and lifetime by 300%
• High quality robust and compact power set with secure lock
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352244
369034
Single Power Set HSS-G TiN Drill Bits (19pcs)
Contents:
Ø 2 x 49 mm / Ø 2,5 (2pcs) x 57 mm / Ø 3 (2pcs) x 61 mm / Ø 3,5 (2pcs) x 70 mm / Ø 4 (2pcs) x 75 mm / Ø 4,5 (2pcs) x 80 mm / Ø 5 (2pcs) x 86 mm / Ø 6 (2pcs) x 93 mm / Ø 7 x 109 mm / Ø 8 x 117 mm / Ø 9 x 125 mm / Ø 10 x 133 mm
352245
369041
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352246
369058
Single Power Set Lip & Spur Wood Drill Bits (8pcs)
Contents:
Ø 3 x 60 mm / Ø 4 x 75 mm / Ø 5 x 85 mm / Ø 6 x 97 mm / Ø 7 x 104 mm / Ø 8 x 117 mm /
Ø 9 x 120 mm / Ø 10 x 133 mm
352247
369065
POWER SET LIP & SPUR WOOD DRILL BITS
• Manufactured from chrome vanadium steel according to DIN 7487 E
• Center point guarantees precise positioning
• Sharpened shoulders provide for clean holes avoiding splintering
• High quality robust and compact power set with secure lock
POWER SET HSS-G (DIN 338) METAL DRILL BITS & SCREWDRIVING BITS
• Metal drill bits ground from high speed steel according to DIN 338
• Normal point cutting tip with 118° angle
• Standard type N flute design
• Screwdriving bits are milled from S2 steel
• High quality robust and compact power set with secure lock
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352248
369072
Single Power Set HSS-G & Screwdriving bits (35pcs)
Contents:
Ø 2 / 2,5 / 3 / 3,2 / 3,5 / 4 / 4,5 / 6 / 8 / 10 mm
25 mm length: PH1 (2pcs) / PH2 (2pcs) / PH3 (2pcs) / PZ1 (2pcs) / PZ2 (2pcs) / PZ3 (2pcs) /
TX10 (2pcs) / TX15 (2pcs) / TX20 (2pcs) / TX25 (2pcs) / TX30 / TX40
50 mm length: PH2 / PZ2
1⁄4˝ Hex magnetic bit holder
352249
369089
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352252
369119
Single Power Set Jigsaw Wood & Metal (50pcs)
Contents:
10 x T 144 D / 10 x T 101 B / 15 x T 118 A / 15 x T 118 B
352253
369126
POWER SET JIGSAW BLADES FOR WOOD & METAL
• Wood applications: T144D – Fast cutting T101B – Very clean, splinter free cutting • Metal applications:
T118A – Cutting of thin sheet material Ø 1,5–4 mm
T118B – Cutting of thicker material 3–6 mm
• High quality robust and compact power set with secure lock
27
SCREW BITS SET / HSS BIT SET / WOOD BIT SET
POWER &
PERFORMANCE
ACCESSORIES
POWER SET SCREWDRIVING BITS
• COLDfire® is a special hardening treatment for making metals stronger , tougher and more durable. This
cryogenic pro­cess is a one-time permanent treatment affecting the entire screwdriving bit and it is not
just a surface coating. The cryogenic process consists of two steps, firstly the bit is hardened by heating
it up to 870° and then freezing the bit down to -148° using a dry nitrogen atmosphere. The result of this
process is a bit with exceptional durability
• + 40% stronger - bit tips hold their form and will accept higher torque forces
• + 45% longer life - over the lifetime of a bit one can expect to drive 45% more screws
Art. No.
4932-
EAN No.
4002395-
Counter display (6 x sets)
352254
369133
Single Power Set Screwdriving Bits (40pcs)
Contents:
25 mm length: PH1 / PH2 (2pcs) / PH3 / PZ1 (2pcs) / PZ2 (2pcs) / PZ3 (2pcs) / TX6 / TX7 /
TX8 / TX9 / TX10 (2pcs) / TX15 (2pcs) / TX20 (2pcs) / TX25 (2pcs) / TX30 / TX40 / Hex 3 /
Hex 4 / Hex 5 / Hex 6 / SL 0,6 x 4,5 / SL 0,8 x 5,5 / SL 1,0 x 5,5 / SL 1,2 x 6,5
50 mm length: PH1 / PH2 / PZ1 / PZ2 / TX10 / TX15 / TX20
1⁄4˝ Hex magnetic bit holder
352255
369140
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352460
368976
Single Profi-Box HSS-R Drill Bits (19pcs)
Contents:
Ø 1–10 mm in 0,5 mm incrementals
352459
371181
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352462*
371211
Single Profi-Box HSS-G Drill Bits (19pcs)
Contents:
Ø 1–10 mm in 0,5 mm incrementals
352461*
371204
Art. No.
4932-
EAN No.
4002395-
Counter display (10 x sets)
352464
371235
Single Maxi-Mix Drill Bits (18pcs)
Contents:
Stone drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
HSS-R drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
Wood drill bits: Ø 3 / 4 / 5 / 6 / 8 / 10 mm
352463
371228
PROFI-BOX HSS-R (DIN 338) METAL DRILL BITS
• HSS-Rollforged metal drill bits manufactured according to DIN 338
• 118° cutting tip angle
• Oxide coating for improved swarf removal
• Robust metal box
PROFI-BOX HSS-G (DIN 338) METAL DRILL BITS
• Fully ground drill bits according to DIN338
• 118° cutting tip angle
• Robust metal box
MAXI-MIX DRILL BITS
• Fully ground drill bits according to DIN 338
• Standard tip for cutting geometry with 118° angle
• Standard type N flute design for faster chip removal and faster cutting
• High quality robust and compact power set with secure lock
* while stocks last
CORDLESS/HAMMERS/DRILLING
METALWORKING/WOODWORKING
ACCESSORIES
AEG POWERTOOLS promises to draw upon its heritage and deliver exciting,
high performance, innovative working solutions for the professional tradesmen
of today and the future.
TTI Middle East & Africa FZCO
P.O. Box: 61254, Jebel Ali Free Zone
Dubai, United Arab Emirates
Tel: +971 4 884 1700, Fax: +971 4 884 1704
www.aeg-powertools.com
© AEG POWERTOOLS
AEG POWERTOOLS reserve the right to change all data including images,
specifications and service and warranty information without notice.
AEG POWERTOOLS will hold no liability for printing errors or mistakes.
CODE : 9064
Download PDF

advertising
