PORTABLE GRAIN DRYING
TOTAL VALUE. TOTAL SYSTEMS.™
GRAIN DRYERS
With over 37 years of experience in the agricultural equipment manufacturing
business, Grain Systems (GSI) has all the resources and expertise necessary to
meet your specific needs.
GSI offers the most technologically advanced and reliable dryers on the market
today. We also offer the widest selection of dryer models, suitable for a wide
variety of applications.
All GSI dryers feature easy-to-use and state-of-the-art controls, heavy-duty
galvanized steel construction, and industrial grade electrical components.
GSI dryers can help solve even the most complex grain conditioning problems.
HIGH EFFICIENCY
GSI’s high efficiency one-piece fan and
heater unit provides optimal heated air
flow for all dryer applications and utilizes
only 1725 rpm low-speed and low-noise
fans which are more energy efficient
than centrifugal fans in this application.
All units feature fiberglass reinforced
polypropylene fan blades with a very low
starting load, high air flow across a wide
static pressure range, precise balance
and quiet operation.
Ten different fan configurations are
available. An electronic ignition system
monitors the burner and a view window
provides easy observation. The Optimizer
Blue Burn System is standard on
all LP models and assures energy
efficient operation.
Other value-added features include an
easy to adjust vaporizer, a large service
access door, and oil filled gas gauges.
WHY BUY A DRYER?
Grain dryers would be unnecessary if harvesting could be done when the grain was at the optimal
moisture level for long term storage. But because so many factors influence harvest times, grain
dryers give growers the flexibility to harvest when necessary and to dry grain to the ideal levels for
storage. This significantly minimizes risk of loss and adds tremendous value to an operation.
• Start harvest earlier to minimize potentially significant field losses from grain shatter
and lodged crops.
• Condition grain early, before adverse weather conditions appear and avoid catastrophic crop
losses that could occur by waiting for the grain to dry in the field.
• Prevent elevator shrinkage charges applied to grain delivered above requested moisture limits.
By avoiding these charges, customers can add more dollars to their bottom line.
• Deliver grain closer to the moisture level desired by the elevator and avoid dockage charges.
• Gain greater marketing flexibility by storing properly conditioned grain for long periods
of time without deterioration.
• Eliminate harvest bottlenecks by conditioning grain at a pace that compliments
today’s high-capacity combines.
This brochure will help explain what sets GSI grain dryers apart from the competition and will point
out the features, advantages and benefits that make GSI dryers an outstanding value.
PAGE 2
Carrying on GSI’s proud history of innovation in grain drying, the
new X-Stream dryer features fans and heaters mounted in a
staggered fashion on opposite ends of the dryer. Traditional
dryers feature fans and heaters mounted on the same end of
the dryer. As a result, the drying temperature of the grain varies
based on which column it is in during the drying process.
Recent Independent University testing documented significant
savings from the X-Stream design. By mounting the fans and
heaters on opposite ends of the dryer and staggering each fan,
the X-Stream delivers more uniform heat throughout the entire
dryer, regardless of column location. As grain passes through
the X-Stream, it is exposed to more consistent levels of heat.
The result is a higher quality grain that is more evenly dried at a
lower cost.
The X-Stream dryer is available in stack dryers in lengths from 20
through 26 feet, plus longer two fan single module dryers. GSI
strongly recommends adding optional grain inverters to the
(stack) X-Stream dryer for greater performance improvement.
PAGE 3
GSI FEATURES
1
5
3
2
8
4
7
6
14
12
11
13
9
19
10
15
18
17
20
21
22
LARGEST GRAIN HOLDING CAPACITY
allows for higher bushels per hour to
consistently achieve maximum drying.
Long retention times result in better
grain quality.
HIGH/LOW FIRE CYCLING
Helps to maintain a uniform plenum temperature.
14” wide columns hold the maximum amount of grain while
minimizing the difference from the inside to the outside of
the column.
Each plenum chamber also has an air mixing chamber to
thoroughly mix the air and heat, and to shield the grain
columns from direct contact with the burner infra red waves.
16
”STAR-FIRE BURNERS”
provide optimal heat delivery efficiency
and a lower cost of operation. LP units
feature patented ”Blue Burn” optimizer.
OPTIMIZED AIRFLOW TO 80 CFM PER BUSHEL
sized to match the basket to achieve consistent airflow
on all models.
AIR MIXERS mixing vanes eliminate
”hot spots” and create a uniform plenum
temperature.
Multiple heat zones in two-fan and larger model dryers put
the hottest air on the highest moisture grain.
OPTIONAL ON/OFF FIRE offers a wider
range of plenum temperature control.
PAGE 4
ADJUSTABLE FLOW GATES
allow customized control of grain volume
in each column for improved quality and
more even drying when grain quality is
poor and there are a lot of fines present.
1
2
Perforated low profile wet bin improves
preheating by allowing heated airflow
through the wettest grain.
3
4
Work light doubles as a shutdown indicator.
Ladders with toe clearance ensure easy
and safe climbing.
7
8
Perforated cover allows for easy
viewing of the auger drive pulley and
verification of operation.
Turnbuckle belt tightener allows for
easy belt tensioning and maintenance.
5
6
Level auger with DuraEdge® flighting
mounted on oil-impregnated wood
hanger bearings adds to long life
and dependability.
14” grain columns allow maximum
capacity and also help promote even
and efficient drying.
Air mixing chambers thoroughly mix
heat and air before it enters the
drying chamber.
9
Industrial grade IEC rated contactors, breakers
and overloads insure durability and quality
while the provided Load and Unload Auxiliary
contactors help reduce installation costs.
10 Air pressure switch checks for air
pressure in plenum to verify airflow
for safety.
11
Highly effective air straighteners create
maximum airflow and even temperatures.
12 Exclusive High/Low or On/Off
burner operation allows low plenum
temperatures for sensitive grain even
when summer temperatures near 100°.
13 Low speed, high performance composite 1725 rpm
fan blades move air with less noise than high speed
blades, use less energy than centrifugals, and their
low start up load promotes longer motor life.
14 Galvanized fan housing minimizes rust
and corrosion to extend life.
15 Non-service rated safety disconnect circuit
breaker integrated into door handle for safe,
economical installation and maintenance
while reducing installation costs.
16 User friendly computerized dryer controls.
17 Large 15” doors give easy access to
unload auger without the use of tools.
18 Column access doors provide fast
unloading and easy access to meter rolls.
19 The handle brought to the outside of the
dryer frame makes opening the auger
clean-out doors much quicker and easier.
20 Adjustable flow gates regulate grain
flow, eliminate column plugging, and
allow manual column emptying into
bottom auger.
21 Full-length, aluminum meter rolls with
over-the-top operation ensure gentle,
accurate grain flow and low horsepower.
22 Heavy 8” auger with 1/4” DuraEdge®
flighting for fast unloading and longer life.
PAGE 5
REAR DISCHARGE AUTO-SHUTDOWN
A 2’ discharge extension with manual grain
sampler is standard equipment. An automatic
discharge shutdown operates off of a hinged lid
switch at the rear discharge. It is activated when
grain overfills the discharge auger
and forces the lid to open.
THREE-PIECE SIDEWALL SCREENS
GSI’s three-piece sidewall panels allow the top angle section
alone, the top angle and side sections, or all of the exterior
screens including the bottom angle section to optionally be
stainless steel. This allows for economical protection against
rust and corrosion where needed
based on the size of the dryer and
the type of usage it will experience.
All fastening hardware are also
stainless steel to eliminate
future corrosion.
CLEAN-OUT MADE EASY
Large plenum clean-out doors make for easy access to the
unload auger and metering rolls.
Inside metering and unload auger access panels lift out of
the way without tools to better accommodate service and
maintenance needs.
ACCESS LADDERS
GSI ladders feature heavy-duty construction and
slip-resistant patterns to give extra grip in wet
conditions. Our attention to detail and quality
design gives GSI a solid foothold in the grain
drying business.
Sealing strips reduce air pressure
and heat loss into the
unload chamber.
8” DURA-EDGE® AUGER FLIGHTING
All augers feature the new DURA-EDGE® 8” diameter flighting with 1/4”
ribbon. The DURA-EDGE® flighting has an outside edge that is 30%
thicker than regular flighting. This contributes to the product’s long life
and dependability.
LOW PROFILE, FOLD-UP WET BIN
The 14’6” low profile overall height permits
easy set-up into existing installations and allows
the GSI dryer to fit in places others can’t.
The wet bin is perforated to enable pre-heating
of the grain to increase capacity and
reduce operating costs.
PAGE 6
OPTIONAL FEATURES
Entering Drying Column
Entering Drying Column
PATENTED GRAIN INVERTERS
Promote more even drying, higher test weights, and also
help reduce operating costs by up to 25%.
Be sure to maximize the efficiency of every GSI stack dryer
by including the optional Grain Inverters.
While the older grain exchangers move grain from the
inside of the grain column to the outside of the column in
6” columns, the new and patented GSI Grain Inverters put a
new twist on this process.
GSI’s Grain Inverters move all grain, except the outer two
inches, within the column to eliminate over-dried grain and to
maximize drying efficiency and grain quality. These patented
Grain Inverters redirect the warmest grain from the inside of
the column to be next to the wettest grain left at the outside
of the column where it is dried by the captured heat which
would have otherwise escaped the dryer. (See diagram to
right for visual illustration.)
This process maintains optimal grain temperature,
thus maximizing grain quality while using less fuel and
significantly reducing operating costs.
A convenient clean-out door also provides easy access
for quick maintenance.
NOISE SUPPRESSOR
Optional noise abatement kit features perforated, galvanized
construction. Noise-absorbing
insulation reduces noise levels
to levels equal to or lower
than that of centrifugal fans,
allowing quiet operation in
sound-sensitive areas.
Can be integrated
with Heat Reclaimer.
Exhaust Air
Exhaust Air
130° at Cooling Section
Plenum 210°
DRYING WITHOUT THE
GSI GRAIN INVERTERS.
Plenum 210°
DRYING WITH THE
GSI GRAIN INVERTERS.
Up to 205° Entering Cooling Section
KERNEL TEMPERATURE
Under 100°
= Seed
100° to 120° = Human Food Grade
- Full Nutrition and Taste
120° to 140° = Animal Food Grade
- Full Nutrition
140° to 160° = Range where moderate damage
and test weight loss starts
160° & above = Severe damage including physical
breakage and severe test weight loss
HEAT RECLAIMER
On multi-fan dryers, reduces the amount of heat lost when
operating in Dry & Cool mode to the atmosphere and recycles
it, thereby reducing
fuel consumption
and lowering
operating costs by
up to 30%. Open
ductwork is optimally
sized for 0% capacity
loss as it prevents
accumulation of fine
material. Sized to
reduce air velocity
very little chaff or air
debris is pulled into
the dryer.
Can be integrated
with Noise Suppressor.
PAGE 7
VISION DRYER CONTROLS
The GSI Vision dryer control system features a wide array
of settings that offers unparalleled options and control.
Boasting a large color screen with easy-to-use touch screen
controls, the Vision can be remote-mounted, via a simple
seven wire harness, up to 1000 feet away from the dryer.
Because safety and dependability are paramount for all GSI
products, the Vision system features a low voltage safety
circuit and a safety disconnect on every dryer. Each safety
is monitored individually and its status displayed on-screen.
With no moving parts – timers, time delays, thermostats,
etc. – the Vision system is less prone to wear-and-tear that
leads to costly repairs and downtime.
Plenum and grain temperatures can be modified on-screen
using temperature and moisture based controls. Switch
from High/Low to On/Off fire modes with a simple switch in
the software.
The Vision also puts help at your fingertips when you need
it most. Owner’s Manuals are available on-demand and
on-screen at the control box.
GSI Vision allows users to track the dryer’s history. All shut
downs are logged with time and date information. This data
can be saved to a flash memory card (via USB) for viewing
on a home computer.
MOISTURE CONTROL
Every GSI Vision dryer is equipped with three different modes of moisture control. Users
select the mode that best fits their needs in a particular situation.
1 Temperature Based 2 Speed with optional 5 Speed Mode: This temperature based
control uses grain temperature to determine the final moisture content. As grain
moisture increases or decreases from the desired moisture set point, the metering
rolls speed up or slow down an amount pre-determined by the user in order for the
dryer to bring the moisture level back to the desired setting. The optional 5 Speed
ed
Mode includes automatic speed averaging. When moisture changes significantly,
ly, all
5 speeds will change accordingly to bring the operation back into sync with the
output moisture.
2 Moisture Based Infinite Speed: This is a moisture-based system that extracts data
ata from
three different points in the dryer: the moisture of the incoming grain, the temperature
erature
of the grain in the middle of the dryer, and the grain moisture upon exiting
the dryer. All three measurements are factored to determine final moisture.
Simply enter the desired moisture set point for finished grain and the Vision’s
moisture control will speed up or slow down the metering rolls to maintain
moisture at the desired setting. This setting makes very slow and calculated
adjustments to the grain and is most effective when the moisture of the
incoming grain does not vary much and is within a narrow range, i.e. one or
two points.
3 Moisture Based 5 Speed: This moisture control method makes very quick meterr
roll changes and uses only the rear (exiting grain) sensor for adjustments. This
setting works best when the moisture of the incoming grain varies quite a bit and has a
wider degree of variance, i.e. three or more points.
ELECTRICAL CONTROL FEATURES:
• Exclusive MET (nationally recognized
testing lab) approved controls.
• Built to UL 508a specifications:
Nationally recognized (US & Canada)
CSA electrical compliant.
• IEC Branch Breakers: IEC controls
are higher quality, rated for more
cycles, and meet domestic and
international electric codes. All dryers
have branch breakers for each motor.
• IEC Motor Overloads: IEC overloads
allow a wide range of adjustment to
accommodate variances in
incoming voltage.
• Auxiliary Auger IEC Contactors/
Overloads*: Load and unload
auxiliary motor branch circuits
are standard. If load and unload
HP are specified at time of order,
GSI will install properly sized
breaker, contactor, and overload for
customer’s application.
• Entrelec Terminals: Color-coded
Entrelec terminals are used for
all computer control circuits
connections, making for easy
installation, diagnosis and service.
• Safety Disconnect*: For safely
disconnecting power from main
panel for servicing dryer controls.
Also provides an easy connection
point for incoming electric supply.
• Work Light and Shutdown Indicator:
The light on the outside of the dryer
doubles as a shutdown indicator.
Patent Pending Sidekick
Moisture Sensor Auger
CONTROL BOX ACCESSIBILITY
For added convenience, the dryer control box height can be adjusted
on site by moving the two control boxes as a unit on two rails bolted to
the side of the dryer. No reaching up, bending over, or building steps
or a platform to monitor and adjust your dryer
controls. All wiring has adequate flexibility to adjust
the controls height with no additional wiring or
electrical changes. Refer to your dryer manual for
proper adjustment procedures.
PAGE 8
”DEFINING THE FUTURE OF NETWORK
DRYER CONTROLS”
Welcome to a new era in network dryer controls.
The GSI Vision dryer control system provides users with
unmatched options and control for the very best results.
The first and only dryer on the market that software updates
are downloadable from the web and transferred to the dryer
from a USB Flash Drive.
VISION CONTROL FEATURES
• 10.4” TFT Diagonal color screen (Touch Screen Control)
• No moving parts (timers, time delays, thermostats)
• 32 Bit Microprocessor Control
• Each Safety monitored individually and its status displayed
on screen
• All shut-downs logged with time and date
• Remote mounted control box requires just a simple seven
wire harness
• Load and Unload Auxiliary Contactors and Overloads on
every dryer
• Safety Disconnect on every dryer
• Low voltage safety circuit
• USB Flash Drive to transfer data to personal computer
MOISTURE CONTROL FEATURES
• Every GSI Vision dryer is equipped with three different
modes of moisture control, allowing greater flexibility for a
variety of needs and settings.
• Integrated into main control of dryer
• Graphing and time stamping
• Software updates are always available by download from
the GSI web site and all that is needed to do the update is
a simple Flash Memory Card or any USB based
removable drive
OPTIONAL WATCHDOG SOFTWARE
CONFIGURATION
SCREEN
MODIFYING
TEMP SETPOINT
CONFIGURATION
SCREEN
SELECTION
SCREEN
M/C - Moisture
Control Setup
On-Screen
GSI’s optional Watchdog™ System allows remote monitoring
of dryer functions such as moisture, temperature and dryer
status from a web accessible computer. Settings and
Adjustments safe to change remotely may also be made.
Web based for greater accessibility, the Watchdog keeps
you advised from the comfort and convenience of a home or
office through your computer, Smart Phone or PDA. Contact
the GSI dealer nearest you for more information.
Shutdown Help File
Extended
Configuration
Free software updates are available for
download from the GSI web site. All that
is needed to do the update is a simple
flash memory card or any USB based
removable drive.
PAGE 9
SPECIFICATIONS
DRYING CAPACITY, SHELLED CORN1
Dry and Cool 25% to 15% Staged Batch
Dry and Cool 20% to 15% Staged Batch
Full Heat 30% to 15%2
Full Heat 25% to 15%2
Full Heat 20% to 15%2
Basic Construction
Grain Columns
Total Holding Capacity
Grain Column Holding Capacity
Top Auger (Loading)
Capacity
Bottom Auger (Unloading)
Meter Roll Drive
Maximum Capacity
1100 SERIES DRYER
1108
1112
1114
1116
1118
1120
1122
1126
170 BPH
220 BPH
190 BPH
260 BPH
420 BPH
210 BPH
270 BPH
250 BPH
340 BPH
530 BPH
250 BPH
320 BPH
300 BPH
390 BPH
610 BPH
280 BPH
370 BPH
320 BPH
440 BPH
710 BPH
320 BPH
430 BPH
380 BPH
510 BPH
820 BPH
360 BPH
480 BPH
410 BPH
560 BPH
910 BPH
390 BPH
520 BPH
460 BPH
610 BPH
990 BPH
460 BPH
610 BPH
540 BPH
720 BPH
1,160 BPH
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
1 Module
1 Stage
14” x 8’
14” x 12’
14” x 14’
14” x 16’
14” x 18’
14” x 20’
14” x 22’
14” x 26’
Long
Long
Long
Long
Long
Long
Long
Long
219 BU
327 BU
381 BU
436 BU
490 BU
544 BU
599 BU
708 BU
190 BU
282 BU
329 BU
376 BU
423 BU
470 BU
517 BU
611 BU
8” Flight
8” Flight
8” Flight
8” Flight
8” Flight
8” Flight
8” Flight
8” Flight
2 HP
2 HP
3 HP
5 HP
5 HP
7.5 HP
7.5 HP
10 HP
3,800 BPH 3,800 BPH 3,800 BPH 3,800 BPH 3,800 BPH 3,800 BPH 3,800 BPH 3,800 BPH
8”
8”
8”
8”
8”
8”
8”
8”
Flight/10” Flight/10” Flight/10” Flight/10” Flight/10” Flight/10” Flight/10” Flight/10”
Tube
Tube
Tube
Tube
Tube
Tube
Tube
Tube
1.5 HP
1.5 HP
3 HP
5 HP
5 HP
7.5 HP
7.5 HP
10 HP
SCR, 3/4
SCR, 3/4
SCR, 3/4
SCR, 3/4
SCR, 3/4
SCR, 3/4
SCR, 3/4
SCR, 3/4
HP
HP
HP
HP
HP
HP
HP
HP
1,125 BPH 1,680 BPH 1,960 BPH 2,240 BPH 2,520 BPH 2,800 BPH 3,080 BPH 3,640 BPH
Transport Length
17’-2”
21’-2”
23’-2”
25’-2”
27’-2”
29’-2”
31’-2”
35’-2”
Transport Width
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
8’
13’-5”
(11’-9”)
5,200 lbs.
6,300 lbs.
7,000 lbs.
7,500 lbs.
8,000 lbs.
8,700 lbs.
15’-2”
8’
19’-2”
8’
21’-2”
8’
23’-2”
8’
25’-2”
8’
27’-2”
8’
29’-2”
8’
33’-2”
8’
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
10-16 HP,
36”
10-16 HP,
36”
10-16 HP,
36”
10-16 HP,
40”
10-16 HP,
40”
N/A
N/A
N/A
N/A
15 HP, 36”
15 HP, 40”
15 HP, 40”
20 HP, 42”
25 HP, 42”
30 HP, 42”
40 HP, 42”
6.75 Mil.
btu/hr
7.5 Mil.
btu/hr
8.75 Mil.
btu/hr
10.25 Mil.
btu/hr
N/A
88/138
81/130
43/65
36/54
N/A
117/193
107/178
56/89
46/73
N/A
128/204
117/188
61/94
50/77
N/A
167/244
157/228
81/114
67/94
(Hitch to Discharge Auger)
Transport Height
3
Transport Weight (approx.)
(Less Transport Kit)
Installed Length
Installed Width
Installed Height
(Excluding Foundation Supports)
Fan 1 PH
Fan 3 PH
3.5 Mil.
4.5 Mil.
5.75 Mil.
5.75 Mil.
btu/hr
btu/hr
btu/hr
btu/hr
ELECTRIC LOAD (MIN/MAX AMPS) (FAN, LOAD AUGER, UNLOAD. AUGER.)4
Single Phase, 230 V.
101/122
101/156
109/164
124/179
Three Phase, 208 V.
57/95
57/95
64/115
77/127
Three Phase, 230 V.
53/83
53/88
60/108
71/120
Three Phase, 460 V.
29/41
29/44
32/54
38/60
Three Phase, 575 V.
25/36
25/36
28/45
33/50
Heater (Max BTU)
1
2
3
4
PAGE 10
9,500 lbs. 11,000 lbs.
Capacities listed are wet bushels, shelled corn at listed moisture content and are estimates based on drying principles, field results and
computer simulation. Variance may occur due to grain’s physiological factors (kernal size, chemical composition, variety, maturity), excessive
fines, adverse weather conditions, etc.
Grain discharged hot from the dryer will result in a final moisture content of 15% after cooling in the bin.
Shortest possible height in ( ).
Minimum: Fan(s) & Dryer Load & Unload motor name plate amperages + 5 for control & SCR load.
Maximum: Fan(s) & Dryer Load & Unload & largest auxiliary motor name plate amperages + 5 for control & SCR load.
SPECIFICATIONS
DRYING CAPACITY, SHELLED CORN1
Dry and Cool 25% to 15%
Dry and Cool 20% to 15%
Full Heat 30% to 15%2
Full Heat 25% to 15%2
Full Heat 20% to 15%2
Basic Construction
Grain Columns
Total Holding Capacity
Grain Column Holding Capacity
Top Auger (Loading)
Capacity
Bottom Auger (Unloading)
Meter Roll Drive
Maximum Capacity
Transport Length
(Hitch to Discharge Auger)
Transport Width
Transport Height3
Transport Weight (approx.)
(Less Transport Kit)
Installed Length
Installed Width
Installed Height
(Excluding Foundation Supports)
Fans 1 PH
Fans 3 PH
1200 SERIES DRYER
1214
1216
1218
1220
1222
1226
250 BPH
400 BPH
330 BPH
420 BPH
680 BPH
290 BPH
470 BPH
380 BPH
480 BPH
770 BPH
320 BPH
510 BPH
410 BPH
520 BPH
840 BPH
350 BPH
560 BPH
430 BPH
590 BPH
950 BPH
400 BPH
640 BPH
480 BPH
650 BPH
1,060 BPH
450 BPH
730 BPH
540 BPH
730 BPH
1,180 BPH
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
14” x 14’ Long 14” x 16’ Long 14” x 18’ Long 14” x 20’ Long 14” x 22’ Long 14” x 26’ Long
381 BU
436 BU
490 BU
544 BU
599 BU
708 BU
329 BU
376 BU
423 BU
470 BU
517 BU
611 BU
8”, 5 HP
8”, 5 HP
8”, 5 HP
8”, 7.5 HP
8”, 7.5 HP
8”, 10 HP
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
8” Flight/10” Tube 8” Flight/10” Tube 8” Flight/10” Tube 8” Flight/10” Tube 8” Flight/10” Tube 8” Flight/10” Tube
5 HP
5 HP
5 HP
7.5 HP
7.5 HP
10 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
1,960 BPH
2,240 BPH
2,520 BPH
2,800 BPH
3,080 BPH
3,640 BPH
23’-2”
25’-2”
27’-2”
29’-2”
31’-2”
35’-2”
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5”(11’-9”)
8’
13’-5” (11’-9”)
7,600 lbs.
8,200 lbs.
9,000 lbs.
9,800 lbs.
10,500 lbs.
12,000 lbs.
21’-2”
8’
23’-2”
8’
25’-2”
8’
27’-2”
8’
29’-2”
8’
33’-2”
8’
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
[email protected] HP,
36”
[email protected] HP,
26”
[email protected] HP,
36”
[email protected] HP,
26”
[email protected] HP,
36”
[email protected] HP,
26”
[email protected] HP,
36”
[email protected] HP,
26”
[email protected] HP,
36”
[email protected] HP,
26
[email protected] HP,
36”
[email protected] HP,
26”
[email protected] HP,
40”
[email protected] HP,
28”
[email protected] HP,
40”
[email protected] HP,
28”
N/A
N/A
N/A
N/A
[email protected] HP,
42”
[email protected] HP,
28”
[email protected] HP,
42”
[email protected] HP,
28”
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
191/246
125/202
116/187
61/93
54/81
N/A
136/213
126/197
66/98
57/84
N/A
164/240
154/225
80/112
68/95
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
btu/hr
btu/hr
btu/hr
[email protected] Mil.
[email protected] Mil.
[email protected] Mil..
btu/hr
btu/hr
btu/hr
ELECTRIC LOAD (MIN/MAX AMPS) (FAN, LOAD AUGER, UNLOAD. AUGER.)4
Single Phase, 230 V.
157/212
177/232
177/232
Three Phase, 208 V.
112/162
112/162
112/162
Three Phase, 230 V.
99/148
104/153
104/153
Three Phase, 460 V.
52/74
55/76
55/76
Three Phase, 575 V.
48/66
49/66
49/66
Heaters (Max BTU)
1
2
3
4
Capacities listed are wet bushels, shelled corn at listed moisture content and are estimates based on drying principles, field results and
computer simulation. Variance may occur due to grain’s physiological factors (kernal size, chemical composition, variety, maturity), excessive
fines, adverse weather conditions, etc.
Grain discharged hot from the dryer will result in a final moisture content of 15% after cooling in the bin.
Shortest possible height in ( ).
Minimum: Fan(s) & Dryer Load & Unload motor name plate amperages + 5 for control & SCR load.
Maximum: Fan(s) & Dryer Load & Unload & largest auxiliary motor name plate amperages + 5 for control & SCR load.
PAGE 11
SPECIFICATIONS
DRYING CAPACITY, SHELLED CORN1
Dry and Cool 25% to 15% Staged Batch
Dry and Cool 20% to 15% Staged Batch
Dry and Cool 25% to 15%
Dry and Cool 20% to 15%
Full Heat 30% to 15%2
Full Heat 25% to 15%2
Full Heat 20% to 15%2
Basic Construction
Grain Columns
Total Holding Capacity
Grain Column Holding Capacity
Top Auger (Loading)
Capacity
Bottom Auger (Unloading)
Meter Roll Drive
Maximum Capacity
Transport Length
(Hitch to Discharge Auger)
Transport Width
Transport Height3
Transport Weight (approx.)
(Less Transport Kit)
Installed Length
Installed Width
Installed Height
(Excluding Foundation Supports)
Fans 1 PH
Fans 3 PH
1200S AND H-SERIES DRYERS
1214S
1218S
1220S/1220H†
1222S/1222H†
1226S/1226H†
260 BPH
360 BPH
185 BPH
300 BPH
300 BPH
450 BPH
730 BPH
350 BPH
450 BPH
240 BPH
385 BPH
390 BPH
540 BPH
860 BPH
400 BPH
520 BPH
280 BPH
445 BPH
450 BPH
620 BPH
990 BPH
430 BPH
570 BPH
300 BPH
485 BPH
490 BPH
670 BPH
1,080 BPH
530 BPH
700 BPH
375 BPH
600 BPH
620 BPH
820 BPH
1,330 BPH
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
1 Module
2 Stages
14” x 14’ Long
381 BU
329 BU
5 HP
3,800 BPH
8” Flight/10” Tube
5 HP
SCR, 3/4 HP
1,960 BPH
14” x 18’ Long
490 BU
423 BU
5 HP
3,800 BPH
8” Flight/10” Tube
5 HP
SCR, 3/4 HP
2,520 BPH
14” x 20’ Long
544 BU
470 BU
7.5 HP
3,800 BPH
8” Flight/10” Tube
7.5 HP
SCR, 3/4 HP
2,800 BPH
14” x 22’ Long
599 BU
517 BU
7.5 HP
3,800 BPH
8” Flight/10” Tube
7.5 HP
SCR, 3/4 HP
3,080 BPH
14” x 26’ Long
708 BU
611 BU
10 HP
3,800 BPH
8” Flight/10” Tube
10 HP
SCR, 3/4 HP
3,640 BPH
23’-2”
27’-2”
29’-2”
31’-2”
35’-2”
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5”(11’-9”)
8’
13’-5” (11’-9”)
9,500 lbs.
11,500 lbs.
14,500 lbs.
15,500 lbs.
18,500 lbs.
21’-2”
8’-8”
25’-2”
8’-8”
27’-2”
8’-8”/ 8’†
30’-2”
8’-8”/ 8’†
33’-2”
8’-8”/ 8’†
14’-6”
14’-6”
14’-6”
14’-6”
14’-6”
[email protected] HP, 28”
[email protected] HP, 28”
[email protected] HP, 36”
[email protected] HP, 36”
[email protected] HP, 36”
[email protected] HP, 36”
[email protected] HP, 36”
[email protected] HP, 36”
N/A
[email protected] HP, 40”
[email protected] Mil.btu/hr
[email protected] Mil.btu/hr
211/266
131/208
121/192
63/96
54/81
N/A
196/273
183/254
94/127
77/104
Heaters (Max BTU)
[email protected] Mil.btu/hr
[email protected] Mil.btu/hr
[email protected] Mil.btu/hr
ELECTRIC LOAD (MIN/MAX AMPS) (FAN, LOAD AUGER, UNLOAD. AUGER.)4
Single Phase, 230 V.
157/212
157/212
211/266
Three Phase, 208 V.
106/156
106/144
131/208
Three Phase, 230 V.
99/148
99/134
121/192
Three Phase, 460 V.
52/74
52/68
63/96
Three Phase, 575 V.
48/66
48/66
54/81
Capacities listed are wet bushels/tonnes, shelled corn at listed moisture content and are estimates based on drying principles, field results and computer
simulation. Variance may occur due to grain’s physiological factors (kernel size, chemical composition, variety, maturity), excessive fines, adverse weather
conditions, etc.
2
Grain discharged hot from the dryer will result in a final moisture content of 15% after cooling in the bin.
3
Shortest possible height in ( ).
4
Minimum: Fan(s) & Dryer Load & Unload motor name plate amperages + 5 for control & SCR load.
Maximum: Fan(s) & Dryer Load & Unload & largest auxiliary motor name plate amperages + 5 for control & SCR load.
† = S-Series dryers are upgradable with additional modules, while the H-Series is not.
1
Also check out our
• Exclusive mixing chambers blend
heated drying air for even drying
• Eliminates front-to-back moisture
variation and heat loss, resulting
in better grain quality and higher
efficiency drying
• Field-tested and proven
PAGE 12
DRYERS MODELS: 1220S, 1222H, 1222S, 1226S
SPECIFICATIONS
2314
DRYING CAPACITY, SHELLED CORN1
Dry and Cool 25% to 15%
620 BPH
Dry and Cool 20% to 15%
1,000 BPH
670 BPH
Full Heat 30% to 15%2
900 BPH
Full Heat 25% to 15%2
1,460 BPH
Full Heat 20% to 15%2
Basic Construction
Grain Columns
Total Holding Capacity
Grain Column Holding Cap.
Top Auger (Loading)
Capacity
Bottom Auger (Unloading)
Meter Roll Drive
Maximum Capacity
Transport Length
(Hitch to Discharge Auger)
Transport Width
Transport Height3
Transport Weight (approx.)
(Less Transport Kit)
Installed Length
Installed Width
Installed Height
(Excluding Foundation Supports)
Fans 1 PH
Fans 3 PH
2300 & 2400 SERIES DRYER
2318
2320
2322
2326
2420
2426
770 BPH
1,240 BPH
830 BPH
1,120 BPH
1,810 BPH
850 BPH
1,380 BPH
920 BPH
1,250 BPH
2,010 BPH
930 BPH
1,500 BPH
1,010 BPH
1,360 BPH
2,200 BPH
1,130 BPH
1,840 BPH
1,200 BPH
1,670 BPH
2,700 BPH
850 BPH
1,380 BPH
920 BPH
1,250 BPH
2,010 BPH
1,130 BPH
1,840 BPH
1,200 BPH
1,670 BPH
2,700 BPH
2 Modules
4 Stages
2 Modules
4 Stages
2 Modules
4 Stages
2 Modules
4 Stages
2 Modules
4 Stages
2 Modules
4 Stages
2 Modules
4 Stages
14” x 14’ Long
731 BU
679 BU
5 HP
3,800 BPH
8” Flight/
10” Tube
5 HP
SCR, 3/4 HP
1,960 BPH
14” x 18’ Long
940 BU
873 BU
5 HP
3,800 BPH
8” Flight/
10” Tube
5 HP
SCR, 3/4 HP
2,520 BPH
23’-2”
27’-2”
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
16,000 lbs.
19,000 lbs.
21,000 lbs.
22,500 lbs.
25,000 lbs.
23,500 lbs.
28,000 lbs.
23’-10”
8’-8”
27’-10”
8’-8”
29’-10”
8’-8”
31’-10”
8’-8”
35’-10”
8’-8”
29’-10”
8’-8”
35’-10”
8’-8”
25’-11”
25’-11”
25’-11”
25’-11”
25’-11”
25’-11”
25’-11”
14” x 20’ Long 14” x 22’ Long 14” x 26’ Long 14” x 20’ Long 14” x 26’ Long
1,044 BU
1,149 BU
1,304 BU
1044 BU
1,340 BU
970 BU
1,067 BU
1,261 BU
970 BU
1,261 BU
7.5 HP
7.5 HP
10 HP
7.5 HP
10 HP
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
8” Flight/
8” Flight/
8” Flight/
8” Flight/
8” Flight/
10” Tube
10” Tube
10” Tube
10” Tube
10” Tube
7.5 HP
7.5 HP
10 HP
7.5 HP
10 HP
SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP SCR, 3/4 HP
2,800 BPH
3,080 BPH
3,640 BPH
2,800 BPH
3,640 BPH
29’-2”
31’-2”
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
btu/hr
btu/hr
btu/hr
btu/hr
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
btu/hr
btu/hr
btu/hr
btu/hr
ELECTRIC LOAD (MIN/MAX AMPS) (FAN, LOAD AUGER, UNLOAD. AUGER.)4
Single Phase, 220 V.
230/285
N/A
N/A
N/A
Three Phase, 208 V.
147/197
158/208
199/275
199/275
Three Phase, 230 V.
137/186
135/184
183/254
183/254
Three Phase, 460 V.
71/93
70/92
94/127
99/132
Three Phase, 575 V.
65/82
68/86
78/105
82/109
2
3
4
29’-2”
35’-2”
[email protected] HP, 40”
N/A
N/A
N/A
N/A
N/A
N/A
[email protected] HP, 28”
N/A
N/A
N/A
N/A
N/A
N/A
[email protected] HP, 40”
[email protected] HP, 42” [email protected] HP, 42” [email protected]0 HP, 42” [email protected] HP, 42” [email protected] HP, 36” [email protected] HP, 40”
[email protected] HP, 28” [email protected] HP, 36” [email protected] HP, 36” [email protected] HP, 36” [email protected] HP, 40”
Heaters (Max BTU)
1
35’-2”
8’
8’
8’
8’
8’
13’-5” (11’-9”) 13’-5”(11’-9”) 13’-5” (11’-9”) 13’-5” (11’-9”) 13’-5” (11’-9”)
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
N/A
302/379
281/352
143/176
115/142
359/421
213/295
197/273
101/139
85/117
N/A
382/464
313/389
159/197
128/160
Capacities listed are wet bushels/tonnes, shelled corn at listed moisture content and are estimates based on drying principles, field results
and computer simulation. Variance may occur due to grain’s physiological factors (kernel size, chemical composition, variety, maturity),
excessive fines, adverse weather conditions, etc.
Grain discharged hot from the dryer will result in a final moisture content of 15% after cooling in the bin.
Shortest possible height in ( ).
Minimum: Fan(s) & Dryer Load & Unload motor name plate amperages + 5 for control & SCR load.
Maximum: Fan(s) & Dryer Load & Unload & largest auxiliary motor name plate amperages + 5 for control & SCR load.
Also check out our
• Exclusive mixing chambers blend
heated drying air for even drying
• Eliminates front-to-back moisture
DRYERS MODELS: 2320, 2322, 2326, 2420, 2426
variation and heat loss, resulting
in better grain quality and higher
efficiency drying
• Field-tested and proven
• GSI patented Grain Inverters
available (highly recommended but
optional equipment)
PAGE 13
SPECIFICATIONS
3414
DRYING CAPACITY, SHELLED CORN1
Dry and Cool 25% to 15%
840 BPH
Dry and Cool 20% to 15%
1,340 BPH
1,000 BPH
Full Heat 30% to 15%2
1,360 BPH
Full Heat 25% to 15%2
2,190 BPH
Full Heat 20% to 15%2
Basic Construction
3 Modules
6 Stages
Grain Columns
14” x 14’ Long
Total Holding Capacity
1,074 BU
Grain Column Holding Cap.
1,022 BU
Top Auger (Loading)
5 HP
Capacity
3,800 BPH
8” Flight/
Bottom Auger (Unloading)
10” Tube
5 HP
Meter Roll Drive
SCR, 3/4 HP
Maximum Capacity
1,960 BPH
Transport Length
(Hitch to Discharge Auger)
Transport Width
Transport Height3
Transport Weight (approx.)
(Less Transport Kit)
Installed Length
Installed Width
Installed Height
(Excluding Foundation Supports)
3418
3420
3422
3426
3620
3626
1,040 BPH
1,670 BPH
1,250 BPH
1,680 BPH
2,720 BPH
1,120 BPH
1,800 BPH
1,400 BPH
1,830 BPH
2,950 BPH*
1,250 BPH
2,020 BPH
1,510 BPH
2,040 BPH
3,300 BPH*
1,520 BPH
2,450 BPH
1,820 BPH
2,480 BPH
4,000 BPH*
1,120 BPH
1,800 BPH
1,400 BPH
1,830 BPH
2,950 BPH
1,520 BPH
2,450 BPH
1,820 BPH
2,480 BPH
4,000 BPH
3 Modules
6 Stages
3 Modules
6 Stages
3 Modules
6 Stages
3 Modules
6 Stages
3 Modules
6 Stages
3 Modules
6 Stages
14” x 18’ Long 14” x 20’ Long 14” x 22’ Long 14” x 26’ Long 14” x 20’ Long 14” x 26’ Long
1,381 BU
1,534 BU
1,688 BU
1,995 BU
1,534 BU
1,995 BU
1,314 BU
1,460 BU
1,606 BU
1,898 BU
1,460 BU
1,898 BU
5 HP
7.5 HP
7.5 HP
10 HP
7.5 HP
10 HP
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
3,800 BPH
8” Flight/
8” Flight/
8” Flight/
8” Flight/
8” Flight/
8” Flight/
10” Tube
10” Tube
10” Tube
10” Tube
10” Tube
10” Tube
5 HP
7.5 HP
7.5 HP
10 HP
7.5 HP
10 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP
SCR, 3/4 HP SCR, 3/4 HP
2,520 BPH
2,800 BPH
3,080 BPH
3,640 BPH
2,800 BPH
3,640 BPH
23’-2”
27’-2”
29’-2”
31’-2”
35’-2”
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5” (11’-9”)
8’
13’-5”(11’-9”)
8’
13’-5” (11’-9”)
23,000 lbs.
26,500 lbs.
29,500 lbs.
30,500 lbs.
35,000 lbs.
30,170 lbs.
38,750 lbs.
23’-10”
8’-8”
27’-10”
8’-8”
29’-10”
8’-8”
31’-10”
8’-8”
35’-10”
8’-8”
29’-10”
8’-8”
35’-10”
8’-8”
37’-3”
37’-3”
37’-3”
37’-3”
37’-3”
37’-3”
37’-3”
N/A
N/A
[email protected] HP, 42”
[email protected] HP, 36”
N/A
N/A
[email protected] HP, 42”
[email protected] HP, 36”
N/A
N/A
[email protected] HP, 42”
[email protected] HP, 40”
N/A
N/A
[email protected] HP, 36”
N/A
N/A
[email protected] HP, 40”
[email protected] Mil.
btu/hr
[email protected] Mil.
btu/hr
N/A
295/377
273/349
139/177
117/149
N/A
539/620
441/517
223/261
179/211
[email protected] HP, 40”
N/A
[email protected] HP, 28”
N/A
[email protected] HP, 40”
[email protected] HP, 42”
[email protected] HP, 28” [email protected] HP, 36”
Fans 1 PH
Fans 3 PH
3400 & 3600 SERIES DRYER
29’-2”
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
[email protected] Mil.
btu/hr
btu/hr
btu/hr
btu/hr
btu/hr
[email protected] Mil.btu/hr [email protected] Mil.btu/hr [email protected] Mil.btu/hr [email protected] Mil.btu/hr [email protected] Mil.btu/hr
ELECTRIC LOAD (MIN/MAX AMPS) (FAN, LOAD AUGER, UNLOAD. AUGER.)4
Single Phase, 230 V.
303/358
N/A
N/A
N/A
N/A
Three Phase, 208 V.
188/238
210/260
266/343
266/343
300/377
Three Phase, 230 V.
175/224
183/232
245/316
245/316
279/350
Three Phase, 460 V.
90/112
94/116
125/158
135/168
192/225
Three Phase, 575 V.
81/98
88/106
103/130
111/138
154/181
Heaters (Max BTU)
35’-2”
8’
8’
13’-5” (11’-9”) 13’-5” (11’-9”)
Capacities listed are wet bushels/tonnes, shelled corn at listed moisture content and are estimates based on drying principles,
field results and computer simulation. Variance may occur due to grain’s physiological factors (kernel size, chemical composition,
variety, maturity), excessive fines, adverse weather conditions, etc.
2
Grain discharged hot from the dryer will result in a final moisture content of 15% after cooling in the bin.
3
Shortest possible height in ( ).
4
Minimum: Fan(s) & Dryer Load & Unload motor name plate amperages + 5 for control & SCR load.
Maximum: Fan(s) & Dryer Load & Unload & largest auxiliary motor name plate amperages + 5 for control & SCR load.
* Limited by Meter Roll maximum capacity.
1
Also check out our
• Exclusive mixing chambers blend
heated drying air for even drying
• Eliminates front-to-back moisture
PAGE 14
DRYERS MODELS: 3420, 3422, 3426, 3620, 3626
variation and heat loss, resulting
in better grain quality and higher
efficiency drying
• Field-tested and proven
• GSI patented Grain Inverters
available (highly recommended
but optional equipment)
SPECIFICATIONS
X-STREAM SERIES
X-STREAM PORTABLE DRYER
• Exclusive mixing chambers blend heated drying air for the most
even drying.
• Eliminates the natural tendency to over-dry the grain furthest
from the fan and heater by reversing the direction of the
heated air in the plenum.
• Eliminates front-to-back moisture variation and heat loss,
resulting in higher efficiency drying.
• Field-tested and proven in GSI Pistachio Food Grade Dryers.
In this stringent market, with an extraordinarily expensive
product, even drying is the difference between profitable
pistachios that can be sold for human consumption versus
those that are simply thrown out or downgraded to animal
feed.
• GSI patented Grain Inverters (highly recommended but
optional equipment) and the new X-Stream stack dryer
design combine to dry grain evenly from front to back and
across the entire column without the loss of usable heat.
• Vision™ controls standard on X-Stream dryers.
Available for 1200H, 1200S, 2300,
2400, 3400, and 3600 Series Dryers
1220SX 1222SX 1226SX
&
&
&
2320X 2322X 2326X 2420X 2426X 3420X 3422X 3426X 3620X 3626X
1220HX † 1222HX † 1226HX †
STACKABLE
Modules
Fans
ELECTRICAL
Phase
Voltage
Fuel
1
2
1
2
1
2
2
3
2
3
2
3
2
4
2
4
3
4
3
4
3
4
3
6
3
6
1 or 3
ALL
1 or 3
ALL
3
ALL
LP or NG
LP or NG
LP or NG
15,500
18,500
3
ALL
LP or
NG
21,000
3
ALL
LP or
NG
22,500
3
ALL
LP or
NG
25,000
1 or 3
ALL
LP or
NG
24,100
3
ALL
LP or
NG
28,600
3
ALL
LP or
NG
29,500
3
ALL
LP or
NG
30,500
3
ALL
LP or
NG
35,000
1 or 3
ALL
LP or
NG
31,000
3
ALL
LP or
NG
39,600
670
1,080
820
1,330
1,245
2,010
1,355
2,195
1,670
2,700
1,250
2,010
1,670
2,700
1,825
2,9501
2,040
3,3001
2,475
4,0001
1,830
2,9501
2,480
4,0001
300
485
375
600
850
1,375
930
1,500
1,130
1,835
850
1,380
1,130
1,840
1,120
1,800
1,250
2,015
1,520
2,445
1,120
1,800
1,520
2,020
Dryer Wt. (lbs.)
14,500
WET BUSHELS FULL HEAT
10 pt.* 25% to 15% (BPH)
615
5 pt.* 20% to 15% (BPH)
990
WET BUSHELS DRY & COOL
10 pt.* 25% to 15% (BPH)
280
5 pt.* 20% to 15% (BPH)
445
† S-Series dryers are upgradable with additional modules, while the H-Series is not.
* Measured in wet bushels per hour (BPH)
1 Limited by Meter Roll maximum capacity.
PAGE 15
www.gsiag.com
1004 East Illinois Street | Assumption, IL 62510 USA
Ph: 888-GSI-BINS | Int’l Tel: 1-217-226-BINS
Fax: 800-800-5329 | Int’l Fax: 1-217-226-3404
GS-020
GS-020 JAN/11
Copyright ©2011 by The GSI Group, LLC | Printed in the USA | Due to continual improvements,
The GSI Group LLC reserves the right to change designs and specifications without notice.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
