2006 Product Catalog
Price Book and Technical Manual
An ASSA ABLOY Group company
Technical Specifications & Product Catalog
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Table of Contents
Page
History of ASSA, Incorporated .................................................................................................................................2
General Information.................................................................................................................................................3
Standard Terms and Conditions...............................................................................................................................5
Keys and Keying .......................................................................................................................................................9
Architectural Specifications......................................................................................................................................16
Mortise Cylinders ......................................................................................................................................................17
High Security Mogul Cylinders.................................................................................................................................40
Rim Cylinders.............................................................................................................................................................49
Mortise & Rim Interchangeable Core Cylinders......................................................................................................57
Key-in-Knob/Lever Cylinders ....................................................................................................................................64
Deadbolts ..................................................................................................................................................................85
Auxiliary Locks ..........................................................................................................................................................93
Padlocks .....................................................................................................................................................................112
Profile Cylinders ........................................................................................................................................................121
Pin Kits, Tools & Accessories.....................................................................................................................................131
Care & Maintenance for ASSA Cylinders & Keys ....................................................................................................136
Parts Index.................................................................................................................................................................153
An ASSA ABLOY Group company
1
ASSA, Incorporated History
History of ASSA, Incorporated
ASSA was established in 1881 by the blacksmith August
Stenman after buying a small hinge manufacturer in
the town of Eskilstuna, Sweden. One day his wife
embroidered a pillow slip with his name forwards and
backwards – “August Stenman, Stenman August,” and
so ASSA became the name of the new company. By 1939,
ASSA had produced its first cylinder lock and delivered its
first 5-pin cylinder master key system seven years later. In
1959, ASSA introduced its first registered key systems
with key control. In 1981, ASSA celebrated its 100th
anniversary as a company with the release of the ASSA
Twin 6000 system, a new cylinder concept utilizing the
dual locking mechanisms of today's ASSA cylinders.
ASSA, Inc. was originally opened in Naperville, IL as a
marketing arm of ASSA AB in Sweden. Incorporated
in 1984, ASSA, Inc. was a full line manufacturer of
mortise locks, padlocks, auxiliary locks, and high
security key systems. Under the direction of Wayne
Wilkerson, who became president and CEO in 1989,
ASSA, Inc. was transformed into the largest high
security cylinder manufacturer in the United States.
Starting in 1992, ASSA, Inc. shifted its sales direction
from independent dealer sales to institutional, industrial,
and government sales. With the introduction of its
new master keying capabilities they became the
logical choice for institutions around the country.
In 1996 alone, sales rose from under $500,000.00
to over 8 million.
Some of the customers who made this possible are
The World Bank, The United States Supreme Court,
Boeing, AT&T, Baltimore Ravens Stadium, The
University of New Hampshire, Prince George's County
School District, Alexandria City Public Schools, Tucson
Unified Schools, and numerous Schools and federal
government facilities.
With the introduction of the Twin V-10 system
in 1996, ASSA ushered in a new generation of
lock technology offering patent protected,
unique geographically exclusive keyways for
ASSA authorized security centers and end users.
The innovative Twin V-10 key design and cylinder
helped to eliminate unauthorized duplicate keys
and to maintain a key control system that is
unmatched in the industry.
2
An ASSA ABLOY Group company
In 2000, ASSA introduced the Twin Exclusive, a
patent-protected upgrade to the highly successful
Twin 6000 series. Utilizing the same dual locking
mechanism, the Twin Exclusive built on the original
design and allowed one key to work both cylinders.
That same year, ASSA, Inc. opened its doors to a new
5,000 square foot facility in New Haven, CT increasing
its production capabilities with state of the art
machinery and assembly equipment.
The high security key control system introduced by
ASSA in 2003 is the Twin Pro, the most sophisticated
key system being offered on the world market today.
Worldwide keyways can be obtained through written
agreement with ASSA for guaranteed exclusivity. The
Twin Pro is not stocked by our traditional distribution
outlets eliminating the possibility of the system being
compromised. ASSA trains facilities to service these
locks in-house or they can be serviced by an ASSA
certified service center.
The Twin Maximum product line introduced in 2005 is set
up to interface with the ASSA CLIQ system. Combining
high security mechanical cylinders and keys with state
of the art electronics, the ASSA CLIQ provides the
user with a level of accountability and system control
unmatched in the industry. A full audit trail with date
and time stamp ensures the security of all or selected
openings within the system while the keys can be used
to operate standard mechanical cylinders as well. The
innovative ASSA CLIQ is yet another example of why
ASSA continues to be the world’s leader in high
security and patented key control solutions.
ASSA General Information
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
General Information
The ALPHA Twin 6000 System, The ALPHA Twin Exclusive System and
The Twin Exclusive Cylinder Program
ASSA introduced the ALPHA System of key control programs to meet the security requirements of locksmiths,
distributors and end users. The Twin Exclusive System is an extension of the Twin 6000 patent. The Twin Exclusive
was introduced as an upgrade to the ASSA Twin 6000 program, introducing new patented keyblanks based on
the Twin V-10 patent and new key profiles offering a low cost advantage for extending patent protection for the
end user. The system consists of virtually the same programs as ALPHA and Twin V-10 Cylect. Briefly, the system
consists of four programs:
TEL/Gamma
TER/Beta
TED/Delta
TEE/Alpha
Locally exclusive keyways for locksmiths
Regionally exclusive keyways for locksmiths
Nationally exclusive keyways for distributors
Regionally exclusive keyways for end-users, sold through normal channels of distribution.
The Twin V-10 Cylect Cylinder Program
The Twin V-10 was introduced as an upgrade to the ASSA Twin 6000 program, introducing new patented keyblanks
and key profiles. The system consists of virtually the same programs as ALPHA:
C2L
C2R
C2D
C2E
Locally exclusive keyways for locksmiths
Regionally exclusive keyways for locksmiths
Nationally exclusive keyways for distributors
Regionally exclusive keyways for end-users, sold through normal channels of distribution.
Keyway Information
Each key control program in the ALPHA and Twin V-10 systems utilizes a standard cylinder plug profile (broaching).
Various sidebar codes are used to create different keyways. Keyblanks produced after August 1988 are stamped
with complete keyway code, e.g., 507-51. Please include keyway code and profile when ordering keys, keyblanks
and cylinders, except SNS cylinders. (See Cylinder form, below).
The Twin Pro Cylinder Program
The Twin Pro program was introduced in 2003 as ASSA’s highest level of controlled security in its delivery
process. Twin Pro product is drop shipped only from the factory and is available to End Users and ASSA
Certified Service Centers.
Twin Maximum Cylinder Program
The Twin Maximum program released in late 2005 has features that none of our other systems offer. The most
advanced secure UL 437 Listed cylinder ever produced. A non UL version is offered for less secure doors. This
system is designed to interface with the new CLIQ 3.0 access control cylinder with full audit trail features for
the cylinders and keys.
CLIQ Cylinder Program
Version 3.0 is the most advanced access control system designed for a stand alone cylinder and key in the industry
today. Offers time zoning, audit trial for cylinder and key. Interface with HID Prox systems in multiple formats.
Offered in Twin Maximum only.
Cylinder Form
ASSA Twin locks and cylinders are available in three different forms:
Keyed-different items include two cut keys per cylinder. Keyed-alike items normally
include two cut keys per cylinder.
SUB (Sub-assembled)
Uncombinated cylinder includes sidebar mechanism, but no tumbler pins, springs or
keyblanks. Pin chamber closure strip, plug and screws provided.
SNS (Sub, No sidebar)
Uncombinated cylinder without sidebar and sidebar springs. Includes sidepins, sidepin
springs, standard tailpiece items and pin chamber closure.
When ordering ASSA Twin locks and cylinders, be sure to indicate CYLINDER FORM.
COMP (Complete)
An ASSA ABLOY Group company
3
ASSA General Information
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
General Information
Red Core
ASSA provides temporary construction cores (red cores) for its interchangeable core cylinders upon request.
Red cores are invoiced at $77.00 and upon return to ASSA, credit will be issued for the full amount less a
50% handling fee. Request for credit must be made in writing to ASSA Customer Service referencing the
original invoice upon which the red cores appear. KEYS ARE NOT INCLUDED IN THE PRICE OF THE RED CORE
AND ARE NOT ELIGIBLE FOR RETURN. All cut keys are invoiced at $11.50 list each.
To order interchangeable core cylinders with temporary cores, specify cylinder model number, Cam, finish, by
RED CORE, example, E6552ICR-1 x 626 x RED CORE. Cylinder will be charged at COMP price. To order red core
separately, specify 70600ICR. Specify change keys as TWIN-KD-RED and control keys as TWIN-CT-RED.
Master Keying
ASSA Twin locks and cylinders may be master keyed to meet virtually any requirement. Contact the Key Records
Department to discuss special needs. Master keying and bitting charges are shown on page 15.
FINISHES
Standard finishes are shown below. Antique brass (609) is available for deadbolts only.
ASSA
BHMA Symbol
Equivalent
U.S. Symbol
Euro Finish
625
626
605
606
609
624
612
US 26
US 26D
US 3
US 4
US 5
US 10B
US 10
11
13
20
23
47
46
33
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Antique Brass
Dark Oxidized
Satin Bronze
Special Function Cylinders
ASSA offers two special function cylinders most commonly used in the Detention market. One is a directional
cylinder, which is operated bi-directionally by one key and in one direction only (clockwise or counterclockwise)
by a subordinate key. This special function is accomplished by a modification to the cylinder plug. The necessity
for this product is clear; to provide functionality in the system design. However, due to the physical modification
of the plug when used in a master key system, the potential size of the master key system will be reduced.
The second special function is a limited rotation cylinder. This cylinder requires two modifications and will be
used in conjunction with a directional function. One key will operate bi-directionally 360º and only one direction
(clockwise or counter-clockwise) by a subordinate key stopping at a determined position prior to 180º. These
modifications will greatly reduce the potential of a master key system.
It is essential to indicate all special function cylinders in the initial master key system design. Otherwise they
may not be possible as part of the master key system.
Special function cylinders are offered in limited models and are indicated by a symbol:
† Prefixing the model number specifies available in special function.
How to order
4
Example
Specify
Profile - Side Bar
Finish
Model No.
V8551CW-14 .............626 ...............95 – 888 (For Directional Cylinders)
Specify
V8551WL-14 .............626 ...............95 –
An ASSA ABLOY Group company
888 (For Limited Rotation Cylinders)
ASSA Standard Terms & Conditions
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Standard Terms & Conditions of Sale
1. General; Definitions
1.1 Entire Agreement
Unless otherwise agreed to in writing by ASSA, Inc.
(“ASSA”), the terms and conditions contained herein
constitute the entire agreement between the parties
with respect to the subject matter hereof and
supercede all prior communications and agreements.
Acceptance by ASSA of Buyer’s Order, or Buyer’s
acceptance of ASSA’s proposal, is expressly limited to
and conditioned upon Buyer’s acceptance of these
terms and conditions which may not be changed or
waived except in writing signed by the parties. Any
additional, inconsistent or different terms and
conditions contained in Buyer’s purchase order or
other documentation are hereby expressly rejected.
1.2 Definitions
In these terms and conditions of sale: (i) “Buyer”
means the person or entity who accepts a quotation of
ASSA for the sale of the Products or whose Order for
the Products is accepted by ASSA; (ii) “Conditions”
means the standard terms and conditions of sale set
out in this document and includes any special terms
and conditions agreed to in writing between Buyer
and ASSA; (iii) “Order” means an order for Products
placed by Buyer with ASSA and accepted by ASSA;
(iv) “Products” means the products ordered by Buyer
and shall include all products, parts and accessories
furnished to Buyer by ASSA.
2. Shipping; Delivery
2.1 Terms of Shipment
Unless otherwise agreed to in writing, all Products are
shipped F.O.B. ASSA’s location. ASSA reserves the right
to deliver in installments.
2.2 Shipping Charges
Subject to Section 2.3, ASSA will pay all shipping
charges in advance of shipment only for shipments of
$1,500.00 net U.S. or more with delivery to Buyer at a
single location. Buyer will pay all shipping charges in
advance of shipment for all shipments that are less
than $1,500.00 net U.S. or that require delivery to
Buyer at more than a single location. Such charges will
be added to Buyer’s invoice.
2.3 Choice of Carrier; Route
Unless otherwise requested on Buyer’s Order, ASSA will
ship by carrier and route of its choice to any freight
service point within the continental United States. If
Buyer requests a carrier or route on its Order, ASSA will
deliver in accordance with such request and Buyer will
An ASSA ABLOY Group company
pay the entire amount of all shipping charges in
advance of shipment.
3. Title and Risk of Loss
Subject to Section 5.3, title to and risk of loss of each
Product purchased by Buyer shall pass to Buyer and
delivery shall be deemed to be complete upon transfer
of the Products to a carrier for shipment at ASSA’s
location or the Products otherwise leave the possession
or control of ASSA. This Section 3 shall survive any
expiration or termination hereof.
4. Orders
4.1 Acceptance
ASSA reserves the right to refuse Orders and is
not bound to honor any Order unless and until such
Order has been accepted by ASSA. ASSA may refuse an
Order by delivering notice, orally or in writing, of such
refusal to Buyer within ten (10) days of ASSA’s receipt
of such Order.
4.2 End User Security Authorization Procedures.
To insure proper control of End User restricted products,
ASSA requires that the End User complete a Delivery of
Controlled ASSA Components for End Users Form. The
form will indicate where and to whom their restricted
product will ship upon leaving the ASSA factory.
Restricted product is defined as high security keyblanks,
cut keys, sidebars, sub-assembled cylinders (SUB),
complete and master keyed cylinders (COMP), and key
charts. All orders involving an End User restricted product
must be signed by the proper authorized personnel on
file at ASSA. This is critical in order to maintain the
integrity of the End User’s key system. ASSA will honor
the specific, written instructions of the authorized
personnel for the shipping and handling of each
purchase order. Such instructions must be included with
each order. A copy of the End User Controlled Product
Delivery Form is available by contacting ASSA customer
service or the local ASSA sales representative. Please
note the option of blanket authorization on the form. If
the distributor chooses this option, it is the distributor’s
responsibility to keep the authorization current and
on file. ASSA does not maintain any files of blanket
authorizations. A copy of a CURRENT authorization form
signed by an authorized signatory must accompany
every Distributor purchase order containing End User
restricted product sent to ASSA whether the product is
shipping to the End User location or not. All orders not
having this form will be suspended indefinitely or until
such form is produced. In the event that any change
occurs in the authorization of any End User personnel,
5
ASSA Standard Terms & Conditions
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Standard Terms & Conditions of Sale
ASSA will require that official written notification be
made to ASSA by the End User on their letterhead
before additional orders will be released.
4.3 Order Identification
All packages are identified as to contents and assigned
an Order number. The Order number also appears
on Order acknowledgements, packing slips, freight
bills and invoices.
4.4 Packing
Unless otherwise specified, all locks and cylinders are
packed individually.
Once received, Items are physically inspected and
checked against the RGA. Information will then
be forwarded to the credit department where credit
invoicing will be applied.
Any Items sent by distributor that are not listed as part
of the authorized return will not be credited and ASSA
will not be responsible for return of these items to
the shipper.
ASSA will not accept Keyed Cylinder returns.
4.5 Changes and Cancellations
5. Price; Taxes; Payment
No Order that has been accepted by ASSA may be
changed or cancelled by Buyer unless ASSA agrees to
such change or cancellation in writing. Buyer will
indemnify ASSA in full against all loss (including loss of
revenue), costs (including the cost of all labor and
materials used), damages, charges, and expenses
incurred by ASSA. Changes will result in a delay in the
scheduled ship date. Additions to Orders will be
entered as a separate Order. Special Orders for noncataloged items and any Orders that are within sixty
(60) days of the original shipment date are not subject
to cancellation.
5.1 Price
4.6 Return Products Authorization
Buyer shall pay the full amount of any tax or other
charge now or hereafter imposed by law upon, with
respect to, or measured by the sale, shipment or price
of any Product sold hereunder, including without
limitation any handling charges; federal, state, or local
sales, use, excise, value added, gross receipts or other
like taxes; customs duties; and any insurance desired by
Buyer. If Buyer is exempt from an applicable tax or
duty, then Buyer must provide ASSA with a valid
exemption certificate before shipment of Products.
Foreign shipments placed with ASSA may require
additional charges for documentation and overseas
packaging. Such charges will be identified on ASSA’s
invoices. This Section 5.2 shall survive any expiration or
termination hereof.
Return Products will not be accepted unless authorized
in advance in writing by ASSA. Used or damaged items
will not be accepted. Products returned to ASSA for
credit must be received by ASSA within sixty (60) days
of initial shipment and must be in saleable condition.
The value of goods returned is subject to appraisal as
to physical condition. Returns will only be accepted for
credit invoicing and a minimum handling charge of
25% will be debited. All returned Products must be
shipped F.O.B. ASSA’s location, freight prepaid. Credit
will not be issued for missing parts. Requirement for
returns are: the ordering distributor must request a
Return Goods Authorization (RGA) in writing through
the same process that purchase orders are done. Each
Item being returned must have full item description
with the original purchase order number that the item
was ordered under or the ASSA order number that the
item was shipped under which can be found on the
Item box label marked REF#.
Return Goods Authorization is then approved or
denied through ASSA’s established internal process. In
either case the requesting distributor is notified by
ASSA in writing. If approved, distributor will receive in
6
writing a Return Goods Authorization Number and
instructions for marking containers for authorized
items being returned.
An ASSA ABLOY Group company
Unless otherwise agreed to in writing, the price for the
Products shall be ASSA’s prevailing price at the time the
Order is accepted by ASSA or any other price quoted
in writing to Buyer. ASSA’s price lists are for general
information only and do not constitute a binding,
open offer by ASSA for the sale of Products. ASSA
reserves the right to modify its standard prices at any
time without notice; prices for some Products may
change frequently due to market fluctuations.
5.2 Taxes
5.3 Payment
Unless otherwise agreed to in writing, payment is
due thirty (30) days from the date of the invoice. If
payments are not made when due, Buyer will pay,
in addition to the overdue payment, a late charge
equal to the lesser of 1.5% per month or the highest
applicable rate allowed by law on such overdue
amounts. Overdue accounts will be assigned to the
credit department for all transactions. Once an
ASSA Standard Terms & Conditions
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Standard Terms & Conditions of Sale
account has been assigned to the credit department,
no Order may be taken, entered or shipped without
approval from the credit manager. Buyer hereby
grants ASSA a purchase money security interest in each
Product and agrees to cooperate with ASSA in protecting
such interest.
6. Insurance
6.1 Insurance Coverage
Buyer shall procure and maintain, at its expense,
the following types of insurance from an insurer
acceptable to ASSA, in the amounts at least equal to
those specified below, with deductibles not in excess of
$100.00. ASSA shall not be required to supply Products
to Buyer at any time that the insurance coverage
provided for herein is not in full force and effect.
6.2 Certificates
Buyer shall, within fifteen (15) days from the date hereof,
furnish ASSA with a certificate of insurance issued by the
insurance company or companies issuing the insurance
policies required hereby. Such certificates shall provide
that written notices shall be given to ASSA at its address
specified herein at least forty-five (45) days prior to any
cancellation or change in any such policy.
7. Warranties and Limitation of Liability
7.1 Warranty
ASSA represents and warrants the Products against
defective material and faulty workmanship for a period
of one year after the date of delivery [and warrants the
finish to meet quality standards at the time of delivery].
This warranty expressly does not apply to faulty product
operation due to: (a) improper installation; (b) the use
of any keys, cylinder pins or other accessories not
expressly approved by ASSA; or (c) failure to provide
reasonable maintenance.
7.2 Limitation of Liability
ASSA’s liability under this warranty shall be limited solely
to the repair or replacement of the Products, or parts
thereof, or refund to the Buyer of the purchase price
thereof. ASSA shall not be responsible for any defect or
non-conformity in the Products that: (a) is created after
the time of delivery; (b) results from Products for which
materials, specifications or designs were provided by
Buyer; or (c) results from modifications to the Products by
Buyer or others. IN NO EVENT SHALL ASSA BE LIABLE
FOR SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES, WHETHER IN CONTRACT, WARRANTY,
NEGLIGENCE, TORT, STRICT LIABILITY, OR OTHERWISE
including but not limited to loss of profits or revenue,
An ASSA ABLOY Group company
loss of use of the Products, delays, or claims of
customers of the Buyer or other third parties for such
other damages. ASSA’s liability on all claims, whether
in contract, warranty, negligence, tort, strict liability or
otherwise for any loss or damage arising out of, or
connected with an Order or the performance or breach
thereof, or from the design, manufacture, sale, or
delivery shall in no case exceed the purchase price of
the Product.
7.3 No Other Warranties
EXCEPT AS EXPRESSLY SET FORTH IN SECTION 7.1,
ASSA MAKES NO OTHER REPRESENTATIONS OR
WARRANTIES, EXPRESS OR IMPLIED, AT LAW OR
IN EQUITY, WITH RESPECT TO THE PRODUCTS OR THEIR
CHARACTERISTICS, QUALITY OR PERFORMANCE,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR
A PARTICULAR PURPOSE, OR NON-INFRINGEMENT
OF ANY INTELLECTUAL PROPERTY RIGHTS OF THIRD
PARTIES AND ANY SUCH REPRESENTATIONS AND
WARRANTIES ARE HEREBY EXPRESSLY DISCLAIMED.
8. Claims
Buyer must notify ASSA of any claim [for adjustment] in
writing at ASSA’s address specified herein within thirty
(30) days after the date of the invoice in question. Buyer
must notify ASSA of any claim for shortages or incorrectly
filled Orders in writing within ten (10) days after receipt
of shipment. Under no circumstances will ASSA be
responsible for any charges for labor or material incurred
by others without the prior written consent of ASSA.
9. Indemnity
9.1 Personal Injury and Property Damage
Buyer shall indemnify ASSA and hold ASSA harmless
against all claims, liability, loss or other damages
(including ASSA’s legal expenses) to all persons for
injury of any nature, including, without limitation,
sickness, and/or death, and for property damage
caused by any Product or part thereof after the time of
delivery of such Product or after such Product otherwise leaves the possession or control of ASSA.
9.2 Compliance with Law
Buyer agrees: (a) to fully comply with all applicable
federal, state and local laws, rules, regulations and
guidelines, including without limitation, all applicable
regulations and guidelines promulgated, from time
to time, by Federal and state environmental and transportation officials, and (b) to indemnify and hold
harmless ASSA from and against all claims, liability, loss
7
ASSA Standard Terms & Conditions
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Standard Terms & Conditions of Sale
or other damages (including ASSA’s legal expenses)
resulting in any way from non-compliance therewith.
9.3 Survival
This Section 9 shall survive any expiration or other
termination hereof.
10. Trademarks and Other Markings
Buyer shall remove any and all of ASSA’s trademarks,
labels, distinctive markings, and designs which may
appear on any Product or on the packaging material
therefore at the time of delivery of such Product and
to refrain from making any use of such trademarks,
labels, distinctive markings and designs.
11. Miscellaneous
11.1 Governing Law
The validity and interpretation of these terms and
conditions of sale shall be governed by the laws of the
State of Connecticut without regard to its principles of
conflicts of law.
11.2 Force Majeure
ASSA shall not be liable for its failure to perform hereunder due to any contingency beyond its reasonable
control, including without limitation acts of God, fires,
floods, wars, sabotage, accidents, labor disputes or
shortages, governmental laws, ordinances, rules and
regulations, whether valid or invalid (including, but
not limited to, priorities, requisitions, allocations,
and price adjustment restrictions), inability to obtain
material, equipment or transportation, and any other
similar contingency. In the event of delay due to any
such cause, the date of delivery will be postponed by
such length of time as may be reasonably necessary to
compensate for the delay.
11.3. No Assignment
These terms and conditions of sale are not assignable
or transferable by Buyer, in whole or in part, without
the prior written consent of ASSA.
11.4 Modification
No modification or waiver of these terms and
conditions of sale shall be effective unless made in a
writing signed by ASSA. No course of action shall be
deemed to modify these terms and conditions of sale.
11.5 Severability.
Whenever possible each provision and term of these
terms and conditions of sale will be interpreted in a
manner to be effective and valid but if any provision or
term hereof is held to be prohibited by law or invalid,
8
An ASSA ABLOY Group company
then such provision or term will be ineffective only to
the extent of such prohibition or invalidity, without
invalidating or affecting in any manner whatsoever the
remainder of such provision or term or the remaining
provisions or terms hereof.
COPYRIGHTS, PATENTS
All products shown in ASSA catalogs, brochures and
price lists are either patented, copyrighted or registered
by ASSA.
*Prices, products, equipment, finishes, models,
specifications and availability are subject to change
without notice.
All notices or other correspondence to ASSA may be
made at the following address:
ASSA, Inc.
110 Sargent Drive
New Haven, CT 06511
(800) 235-7482
(800) 892-3256 fax
ASSA Keys and Keying
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keys and Keying
All ASSA keys are manufactured from the highest quality
nickel silver material. The key’s rounded back facilitates
smooth operation and minimizes wear. The large
key bow simplifies identification and use by
manually impaired people. Keys can
be provided with various options of
tactile identification upon request. Available
in several profiles or broaches, ASSA high
security keys all feature a unique side milling
on the lower portion of the key blade and are precut at the ASSA factory. Each side
milling represents a key section that is factory controlled on a geographic basis
providing an unmatched level of patented key control.
Benefits
• Two sets of key cuts designed to operate independent locking mechanisms
• Innovative key design protected by U.S. and international patents
• Patented key control offers the ultimate in high security
• Top cuts can be generated on standard, quality code cutting equipment
• ASSA’s generous keying capabilities allow over 160,000 change keys under a single master key
Warranty
• ASSA guarantees that if a key should break under normal usage, ASSA will replace it at no charge plus any
reasonable service charge
• ASSA guarantees that no other top level master key for any other ASSA factory generated master key system
will operate as a top level key in an end-user’s system for a specified geographic territory
• ASSA guarantees its patented systems against unauthorized key duplication
Certification
• Twin Exclusive, Twin V-10, Twin Pro and Twin Maximum keys listed under U.S. Patent numbers 5,067,335
and 5,640,865
Technical Information
• High quality nickel silver material
• Key combination is read from tip to bow
• No. 1 cut is deepest, No. 9 is shallowest
• Maximum adjacent cut is 5 (example: 1-6 is acceptable, 1-7, 8 or 9 is not)
• Cut depth is measured as root depth from back of key to bottom of cut
Special stamping and custom coining available
An ASSA ABLOY Group company
9
ASSA Keys and Keying
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keys and Keying
Twin Maximum
Twin Pro
Twin Exclusive
Twin 6000
Twin V-10
ASSA Cut Keys
Item No.
Description
TMAX-KD
TMAX-MK
TPRO-KD
TPRO-MK
Twin-KD
Twin-MK
V-10-KD
V-10-MK
Twin
Twin
Twin
Twin
Twin
Twin
Twin
Twin
Maximum Cut Key
Maximum Cut Keys, In a Master Key System
Pro Cut Keys KD/KA
Pro Cut Keys, In a Master Key System
Exclusive/6000 Classic (Specify Profile) Cut Keys KD/KA
Exclusive/6000 Classic (Specify Profile) Cut Keys, In a Master Key System
V-10 Cut Keys KD/KA
V-10 Cut Keys, In a Master Key System
Price
11.50 ea
11.50 ea
11.50 ea
11.50 ea
11.50 ea
11.50 ea
11.50 ea
11.50 ea
ASSA Key Blanks
Item No.
Description
Price
359644
816313
867091
E867091
250694
969030
Twin Maximum Key Blanks Qty. 100/box
Twin Pro Keyblanks/Sidebar code (specify sidebar code) Qty. 100/box
Twin 6000 Key Blanks (specify sidebar code and profile) Qty. 100/box
4.50 ea
4.50 ea
4.50 ea
Twin Exclusive Key blanks/Sidebar code (specify sidebar code) Qty 100/box
Twin V-10 Keyblanks/Sidebar code (specify sidebar code) Qty 100/box
White Code Tags
4.50 ea
4.50 ea
2.50 ea
ASSA Coined Key Blanks
Item No.
Description
Initial die charge
868996
500 minimum key blank quantity each order (Specify profile and side code)
10
An ASSA ABLOY Group company
Price
400.00/Net
4.50 ea
ASSA Keys and Keying
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keys and Keying
UK
UM
PK
PL
UL
Open: Master-Key systems
Restricted: All
Open: Master-Key Systems
868062
600 Series
Open: Keyed Alike/Keyed Different
600 Series Cut Keys & Key Blanks
Item No.
Description
600-KD
600-MK
868062
Cut Keys KD / KA
Cut Keys, In a Master Key System
Key blanks/ Specify profile (UK, UL, UM, PK, PL)
Price
11.50 ea
11.50 ea
4.50 ea
500 Series Key Blanks
Item No.
Description
462000
Key blanks/ specify profile
Price
5.50 ea
700 Series Key Blanks
Item No.
Description
462001 Key blanks/ specify profile
Price
5.50 ea
Cut Key Set
Item No.
Description
CKS-1
ECKS
TPCKS
TMCKS
V-10 Cut Key Set
Twin Exclusive Cut Key Set
Twin Pro Cut Key Set
Twin Maximum Cut Key Set
An ASSA ABLOY Group company
Price
39.00
39.00
39.00
39.00
ea
ea
ea
ea
11
Technical Specifications & Product Catalog
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
ASSA CLIQ™
ASSA CLIQ™ intelligent locking systems gives control over
all keys, which can easily be upgraded and can be
tailor-made to suit any needs. Since every key has its
own identity, it becomes the “personal property”
of the key holder. CLIQ makes intelligent, flexible
and high security lock systems possible. The key’s
mechanical design creates the basic foundation
made up of different security zones in
the same way as in mechanical lock
systems. The electronic programming
of the keys gives authorization to individuals or to group of individuals. CLIQ
technology’s basic idea is the creation of an intelligent security system. That means
a lock system that retains a high level of security despite upgrading, alterations or
expansion. Even after many years of use by a continual flow of new tenants, new
employees or changes occurring in the workplace, the level of security will remain
the same.
Benefits
• Based on Twin Maximum Technology
• High and Medium Security Levels
• Extreme Master Keying Capacity
• Concealed Keying
• Wide Range of Retrofit Cylinder Shapes
• Possible to Add CLIQ Functionality
Warranty
• Battery Life 2 Years or 20K Openings
• Lifetime on Key Breakage
Certification
• Patented Key Control
• UL Listed
Technical Information
• Power Supply is Provided by the Key
• Data Transfer 64 Bit and Higher
12
An ASSA ABLOY Group company
Technical Specifications & Product Catalog
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
CLIQ™ Keys and Software
CLIQ
Cut
Key
CLIQ
C-Key
CLIQ
Master
C-Key
CLIQ
Contact
Key
CLIQ
Distributor
Key
ASSA CLIQ™ Keys
Item No.
Description
CLIQ-KD
CLIQ-CK
CLIQ-MCK
CLIQ-CON
CLIQ-DIS
CLIQ
CLIQ
CLIQ
CLIQ
CLIQ
Price
Cut Key
C-Key
Master C-Key
Contact Key
Distributor Key
65.00
90.00
125.00
125.00
125.00
CLIQ
Program
Device
CLIQ
Demo
Kit
CLIQ™ Programming Unit & Software
Item No.
Description
CLIQ-END
Program Device with Software
(For Dealer/End-user Use to Manage CLIQ System)
Program Device with Software
(For Distributor/Dealer Use to Manage Multiple CLIQ Systems)
Sales Demo Kit
(For Sales People to demonstrate program device software, padlock,
deadbolt, mortise, and key-in-knob cylinder, operating keys,
1 control key, 1 master key, 1 C-key, 1 mortise cutaway cylinder)
CLIQ-DEA
CLIQ-SDK
An ASSA ABLOY Group company
Price
1,950.00
1,950.00
5,750.00
13
ASSA Keys and Keying
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keys and Keying
Master Key Order Procedure
Master Key system orders for ASSA products are processed using desktop computer systems. Part of our
processing software allows us to import the customer order data when it is submitted to us in the compatible
format described below on a diskette or via E-mail.
Excel File Format
The layout of an Excel file which we can import is shown below. The first line in the file should number the
fields I through 9, the file should not contain headers or formulas.
Field
1
2
3
4
5
6
7
8
9
10
Content
Item #
Cyl. Quan.
Cyl/Cam PN
Finish
Cam
Keyset
Key Quan.
Door #
Comments
Spl. Key stamp
Character limit
4
4
12
5
3 (do not use, include cam with cylinder part #)
12
4
12
20
12 (For stamping other than DHI or SKCS standard)
The import of an Excel format file offers a special feature regarding systems which incorporate a ENG key. If a
particular item is to be operated by the ENG key in addition to the other key indicated by the keyset you can
indicate this to our software by adding a suffix of “-E” to the keyset. In such a case AAI would become AAI-E if it
should be operated by the ENG key. This specification option is not available if the imported file is supplied in
ASCII format.
In order to ensure that correct master keying information is received and accurate records are maintained, ASSA
has designed a Sample Order Template. The following is an example of a completed sample order log that
must accompany each master key order submitted to ASSA. When filling out the key quantity column, unless
otherwise requested, two keys will be supplied per cylinder with all master keyed orders.
The form is available by contacting your ASSA representative, ASSA Customer Service, or by logging onto the
ASSA website www.assalock.com. If a computer or the Excel program is not available to you, contact your ASSA
representative for assistance in getting the form completed. The completed form is then e-mailed to ASSA key
records email address [email protected] Master key purchase orders can be faxed to 800-892-3256 or mailed
to ASSA Inc., 110 Sargent Dr. New Haven, CT. 06511.
14
An ASSA ABLOY Group company
ASSA Keys and Keying
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keys and Keying
The ASSA Key Records Department carefully designs and records master key systems in compliance with
customer requirements and ASSA security policy. System documents are thoroughly detailed, produced, and
professionally presented, and should be considered valuable and confidential. Key Records information and
service is available as follows:
Factory Keyed Cylinders
Cylinders pinned by the factory are supplied “Keyed Different” or if so specified as one of the following
options:
• Master Keyed (Bittings provided at No Charge when requested with the order) .............$11.00 per cylinder
• Keyed Alike/Keyed Different ............................................................................................................No Charge
• Single Keyed Different (Part of MK System).............................................................................11.00 per cylinder
Factory Generated Master Key Systems
ASSA will provide new master key systems for pinning by the locksmith in accordance with prices below:
ON PAPER
Bittings
Bittings &
Only
Pinnings
Quantity
Bittings
Only
ON DISK
Bittings &
Pinnings
1-50.......................................................140.50................422.50................................68.00................140.50
51-200...................................................211.00................562.50................................68.00................280.50
201-1000...............................................280.50................703.00................................68.00................351.50
1001-5000 ............................................351.50.............1,125.00................................68.00................562.50
5001-10000 ..........................................444.00.............1,688.00................................68.00................844.50
10001-25000 ........................................622.00.............2,250.50..............................136.50.............1,125.00
Over 25,000 or more contact Customer Service for quote.
These prices are for a hierarchical Master Key System with no Cross-keying of selective keys. For special
requirements, contact Customer Service or Key Records Department.
Systems prior to 1996, contact Customer Service for quote.
Disks will be provided in flat ASCII text only.
Other Key Charges
System Copy Charge (copy of existing system – MBCC) ($57.00 net min.) .............................2.25 per page
System Expansions: Priced as above
All Other Systems Charges Billed per Request
Standard KD/KA key stamping includes keyway designation code.
Standard MK system stamping includes and key symbol.
Do Not Duplicate and other special stamping requirements will be priced at $2.25 per stamp.
Factory does not recommend cross-keying and will
not warranty any cross-keyed cylinders.
An ASSA ABLOY Group company
15
ASSA Architectural Specifications
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Architectural Specification
High Security Key System
General requirements:
1. Provide a high security key system capable of integrating various type of lock cylinders; mogul, builder hardware, and auxiliary locks, into a patented, geographically restricted, factory master keyed system to allow control over the entire facility.
a. Include detention mogul cylinders, builders hardware cylinders, auxiliary locks, and padlocks keyed into
one compatible system for locks specified in this section and those specified in related sections.
b. Proprietary Keyway: Provide written guarantee from the manufacturer that the Keyway used on this project is for the exclusive use of the Owner on a regional basis..
2. Master Keying
a. Provide level 3 grandmaster key system. As defined in (DHI) "Keying Systems and Nomenclature".
b. Provide factory established key system and keying of cylinders.
1). Arrange for manufacturer to maintain permanent key identification and registration records.
3. Keys
a. Replacement Keys: available only from the manufacturer upon written authorization from the Owner.
b. Stamping of Keys: Stamp keys with an identification code in accordance with "Keying Procedures, Systems,
and Nomenclature" published by DHI.
c.
Quantity:
1) Change keys:
a. Allow for four (4) change keys per lock cylinder.
b. Furnish a minimum of six (6) keys per key set, remaining keys as instructed by the Owner.
2) Master level keys:
a. Furnish a minimum of ten (10) of each masterkey and six (6) of each master level key above the
grandmaster.
d. Material: Nickel silver alloy.
e. Minimum size: 1" x 3" long 1/8 "thick,
4. Cylinders
a. Marking of Cylinders: Using a black indelible ink pen, mark body of cylinders with an identification code
in accordance with "Keying Procedures, Systems, and Nomenclature" published by DHI.
b. Standard compliance
1) Listed under UL 437.
2) ANSI/BHMA A156.30 standard for High Security Cylinders.
3) ASTM 1577 6.6 standards for Correctional Cylinders
5. Temporary Construction Security
a. Provide temporary construction cylinders and keys for exterior doors, automatically locking doors where
security is required, and doors to rooms used for storage.
1) Temporary cylinders and keys remain the property of the contractor.
b. Provide temporary blank strike plates for lock bolt receivers to prevent automatic locking of doors where
temporary construction cylinders are not used and security at the door during construction is not
required..
16
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
ASSA mortise cylinders are designed to replace several
original manufacturers’ cylinders in their locksets offering
the highest level of security available on the market
today. Made to standard U.S. dimensions, these
rugged cylinders are available in a variety of finishes
and lengths and stand up to even the heaviest
abuse. All ASSA mortise cylinders are listed under
U.L. 437, a set of tests for determining the cylinder's
physical resistance against various forms of attack.
ASSA mortise cylinders will improve the security of standard mortise locksets by
Arrow, Corbin/Russwin, Sargent, Schlage, Yale and many other manufacturers.
Benefits:
•
•
•
•
•
•
•
Drill resistant cylinder housing and plug
Case-hardened steel inserts and stainless steel pins
Two independent locking mechanisms to ensure optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Extremely close tolerances
Can be easily rekeyed in the field
With the purchase of one inexpensive kit, 1-1/8" mortise cylinder is easily converted to rim cylinder
Warranty:
• ASSA guarantees its cylinders against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Twin Series Mortise cylinders are U.L. 437 listed as well as ASTM F 1577 6.6 listed for standard test
methods for detention Locks.
Technical Information:
•
•
•
•
•
•
Available in cylinder lengths 1-1/8" through 2" in 1/8’ increments
Available with limited rotation and/or unidirectional features
13 cam options available
Cylinder housing and plug are made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
612
624
U.S. Symbol
US 26
US 26D
US 3
US 4
US 10
US 10B
An ASSA ABLOY Group company
Euro Finishes
11
13
20
23
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Satin Bronze
Dark Oxidized Bronze
17
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders Ordering Information
Model No.
Finish
Program
Security
Form
V6551-1
626
C2R
Sub
Keyway
95-300
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Twin V-10 & Twin Exclusive Mortise Cylinders:
Specify
Model No.
Finish
Security
Program
Form
Keyway
Example: ..........V6551-1 ..................626.......................C2R ......................Sub .....................95-300
How To Order Twin Pro & Twin Maximum Mortise Cylinders:
Specify
Model No.
Finish
Form
Keyway
Example: ..........6151-1.....................605.......................Comp...................0P4-200
18
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders Exploded View
Spool Driver Pins
Standard-pin
Tumbler System
Drill-resistant
Cylinder Housing
Countermilling
Side Bar
Drill-resistant
Cylinder Plug
No key inserted:
• Standard pins block the shear line
• Side bar rests in groove of cylinder
housing, blocking movement of plug
System Code
Shear Line
Coded Side Bar
Locking System
Side Bar
Side Bar Code
Correct key inserted:
• System code of key lifts standard pins to shear line
• Side bar code of key lifts side pins into a position where the side bar can be
received. Side bar then recesses into plug as key is turned
Large Key-bow
Master Pins
Cylinder Springs
Top Pins
Bottom Pins
Cover Strip
Cylinder Housing
Cylinder Plug
Cam
Sidebar Springs
Sidebar
Side Pins
An ASSA ABLOY Group company
Side Pin Spring
19
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-1/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
†
†
†
†
†
†
†
†
†
†
†
†
†
†
V6551-1
V6551-2
V6551-3
V6551-4
V6551-5
V6551-6
V6551-7
V6551-8
V6551-9
V6551-10
V6551-11
V6551-12
V6551-13
V6551-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
91.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
73.00
Twin Exclusive
†
†
†
†
†
†
†
†
†
†
†
†
†
†
E6551-1
E6551-2
E6551-3
E6551-4
E6551-5
E6551-6
E6551-7
E6551-8
E6551-9
E6551-10
E6551-11
E6551-12
E6551-13
E6551-15
Twin 6000 Classic
†
†
†
†
†
†
†
†
†
†
†
†
†
†
6551-1
6551-2
6551-3
6551-4
6551-5
6551-6
6551-7
6551-8
6551-9
6551-10
6551-11
6551-12
6551-13
6551-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
† Available in special function cylinders, see page 4, add $29.00.
20
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
1-1/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
82.00
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
72.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
65.50
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
58.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
51.00
Twin Pro
†
†
†
†
†
†
†
†
†
†
†
†
†
†
6151-1
6151-2
6151-3
6151-4
6151-5
6151-6
6151-7
6151-8
6151-9
6151-10
6151-11
6151-12
6151-13
6151-15
Twin Maximum
†
†
†
†
†
†
†
†
†
†
†
†
†
†
8851-1
8851-2
8851-3
8851-4
8851-5
8851-6
8851-7
8851-8
8851-9
8851-10
8851-11
8851-12
8851-13
8851-15
Twin Maximum Medium Security
†
†
†
†
†
†
†
†
†
†
†
†
†
†
2851-1
2851-2
2851-3
2851-4
2851-5
2851-6
2851-7
2851-8
2851-9
2851-10
2851-11
2851-12
2851-13
2851-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L651-1
L651-2
L651-3
L651-4
L651-5
L651-6
L651-7
L651-8
L651-9
L651-10
L651-11
L651-12
L651-13
L651-15
651-1
651-2
651-3
651-4
651-5
651-6
651-7
651-8
651-9
651-10
651-11
651-12
651-13
651-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
74.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
68.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851-1 x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 4, add $29.00.
An ASSA ABLOY Group company
21
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-1/4" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
† V6552-1
† V6552-2
† V6552-3
† V6552-4
† V6552-5
† V6552-6
† V6552-7
† V6552-8
† V6552-9
† V6552-10
† V6552-11
† V6552-12
† V6552-13
† V6552-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
95.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
86.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
77.00
Twin Exclusive
† E6552-1
† E6552-2
† E6552-3
† E6552-4
† E6552-5
† E6552-6
† E6552-7
† E6552-8
† E6552-9
† E6552-10
† E6552-11
† E6552-12
† E6552-13
† E6552-15
Twin 6000 Classic
† 6552-1
† 6552-2
† 6552-3
† 6552-4
† 6552-5
† 6552-6
† 6552-7
† 6552-8
† 6552-9
† 6552-10
† 6552-11
† 6552-12
† 6552-13
† 6552-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
† Available in special function cylinders, see page 4, add $29.00.
22
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
1-1/4" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
83.00
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
73.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
66.50
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
59.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
53.00
Twin Pro
† 6152-1
† 6152-2
† 6152-3
† 6152-4
† 6152-5
† 6152-6
† 6152-7
† 6152-8
† 6152-9
† 6152-10
† 6152-11
† 6152-12
† 6152-13
† 6152-15
Twin Maximum
†
†
†
†
†
†
†
†
†
†
†
†
†
†
8852-1
8852-2
8852-3
8852-4
8852-5
8852-6
8852-7
8852-8
8852-9
8852-10
8852-11
8852-12
8852-13
8852-15
Twin Maximum Medium Security
†
†
†
†
†
†
†
†
†
†
†
†
†
†
2852-1
2852-2
2852-3
2852-4
2852-5
2852-6
2852-7
2852-8
2852-9
2852-10
2852-11
2852-12
2852-13
2852-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L652-1
L652-2
L652-3
L652-4
L652-5
L652-6
L652-7
L652-8
L652-9
L652-10
L652-11
L652-12
L652-13
L652-15
652-1
652-2
652-3
652-4
652-5
652-6
652-7
652-8
652-9
652-10
652-11
652-12
652-13
652-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
84.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
79.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8852-1 x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 4, add $29.00.
An ASSA ABLOY Group company
23
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-3/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6553-1
V6553-2
V6553-3
V6553-4
V6553-5
V6553-6
V6553-7
V6553-8
V6553-9
V6553-10
V6553-11
V6553-12
V6553-13
V6553-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
157.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
139.50
Twin Exclusive
E6553-1
E6553-2
E6553-3
E6553-4
E6553-5
E6553-6
E6553-7
E6553-8
E6553-9
E6553-10
E6553-11
E6553-12
E6553-13
E6553-15
Twin 6000 Classic
6553-1
6553-2
6553-3
6553-4
6553-5
6553-6
6553-7
6553-8
6553-9
6553-10
6553-11
6553-12
6553-13
6553-15
24
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-3/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
155.00
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
147.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
Twin Pro
6153-1
6153-2
6153-3
6153-4
6153-5
6153-6
6153-7
6153-8
6153-9
6153-10
6153-11
6153-12
6153-13
6153-15
Twin Maximum
8853-1
8853-2
8853-3
8853-4
8853-5
8853-6
8853-7
8853-8
8853-9
8853-10
8853-11
8853-12
8853-13
8853-15
Twin Low & Twin 600 Series Classic
Low
600
Description
L653-1
L653-2
L653-3
L653-4
L653-5
L653-6
L653-7
L653-8
L653-9
L653-10
L653-11
L653-12
L653-13
L653-15
653-1
653-2
653-3
653-4
653-5
653-6
653-7
653-8
653-9
653-10
653-11
653-12
653-13
653-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
141.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8853-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
25
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-1/2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6554-1
V6554-2
V6554-3
V6554-4
V6554-5
V6554-6
V6554-7
V6554-8
V6554-9
V6554-10
V6554-11
V6554-12
V6554-13
V6554-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
158.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
140.50
Twin Exclusive
E6554-1
E6554-2
E6554-3
E6554-4
E6554-5
E6554-6
E6554-7
E6554-8
E6554-9
E6554-10
E6554-11
E6554-12
E6554-13
E6554-15
Twin 6000 Classic
6554-1
6554-2
6554-3
6554-4
6554-5
6554-6
6554-7
6554-8
6554-9
6554-10
6554-11
6554-12
6554-13
6554-15
26
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-1/2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
156.00
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
148.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
141.50
Twin Pro
6154-1
6154-2
6154-3
6154-4
6154-5
6154-6
6154-7
6154-8
6154-9
6154-10
6154-11
6154-12
6154-13
6154-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
Twin Maximum
8854-1
8854-2
8854-3
8854-4
8854-5
8854-6
8854-7
8854-8
8854-9
8854-10
8854-11
8854-12
8854-13
8854-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L654-1
L654-2
L654-3
L654-4
L654-5
L654-6
L654-7
L654-8
L654-9
L654-10
L654-11
L654-12
L654-13
L654-15
654-1
654-2
654-3
654-4
654-5
654-6
654-7
654-8
654-9
654-10
654-11
654-12
654-13
654-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.50
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
133.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8854-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
27
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-5/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6555-1
V6555-2
V6555-3
V6555-4
V6555-5
V6555-6
V6555-7
V6555-8
V6555-9
V6555-10
V6555-11
V6555-12
V6555-13
V6555-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
160.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
Twin Exclusive
E6555-1
E6555-2
E6555-3
E6555-4
E6555-5
E6555-6
E6555-7
E6555-8
E6555-9
E6555-10
E6555-11
E6555-12
E6555-13
E6555-15
Twin 6000 Classic
6555-1
6555-2
6555-3
6555-4
6555-5
6555-6
6555-7
6555-8
6555-9
6555-10
6555-11
6555-12
6555-13
6555-15
28
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-5/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
149.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
142.50
Twin Pro
6155-1
6155-2
6155-3
6155-4
6155-5
6155-6
6155-7
6155-8
6155-9
6155-10
6155-11
6155-12
6155-13
6155-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
Twin Maximum
8855-1
8855-2
8855-3
8855-4
8855-5
8855-6
8855-7
8855-8
8855-9
8855-10
8855-11
8855-12
8855-13
8855-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L655-1
L655-2
L655-3
L655-4
L655-5
L655-6
L655-7
L655-8
L655-9
L655-10
L655-11
L655-12
L655-13
L655-15
655-1
655-2
655-3
655-4
655-5
655-6
655-7
655-8
655-9
655-10
655-11
655-12
655-13
655-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.625
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
144.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
135.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8855-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
29
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-3/4" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6556-1
V6556-2
V6556-3
V6556-4
V6556-5
V6556-6
V6556-7
V6556-8
V6556-9
V6556-10
V6556-11
V6556-12
V6556-13
V6556-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
164.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
145.00
Twin Exclusive
E6556-1
E6556-2
E6556-3
E6556-4
E6556-5
E6556-6
E6556-7
E6556-8
E6556-9
E6556-10
E6556-11
E6556-12
E6556-13
E6556-15
Twin 6000 Classic
6556-1
6556-2
6556-3
6556-4
6556-5
6556-6
6556-7
6556-8
6556-9
6556-10
6556-11
6556-12
6556-13
6556-15
30
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-3/4" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
151.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
144.50
Twin Pro
6156-1
6156-2
6156-3
6156-4
6156-5
6156-6
6156-7
6156-8
6156-9
6156-10
6156-11
6156-12
6156-13
6156-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
Twin Maximum
8856-1
8856-2
8856-3
8856-4
8856-5
8856-6
8856-7
8856-8
8856-9
8856-10
8856-11
8856-12
8856-13
8856-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L656-1
L656-2
L656-3
L656-4
L656-5
L656-6
L656-7
L656-8
L656-9
L656-10
L656-11
L656-12
L656-13
L656-15
656-1
656-2
656-3
656-4
656-5
656-6
656-7
656-8
656-9
656-10
656-11
656-12
656-13
656-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
146.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
138.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8856-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
31
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-7/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6557-1
V6557-2
V6557-3
V6557-4
V6557-5
V6557-6
V6557-7
V6557-8
V6557-9
V6557-10
V6557-11
V6557-12
V6557-13
V6557-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
159.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
Twin Exclusive
E6557-1
E6557-2
E6557-3
E6557-4
E6557-5
E6557-6
E6557-7
E6557-8
E6557-9
E6557-10
E6557-11
E6557-12
E6557-13
E6557-15
Twin 6000 Classic
6557-1
6557-2
6557-3
6557-4
6557-5
6557-6
6557-7
6557-8
6557-9
6557-10
6557-11
6557-12
6557-13
6557-15
32
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
1-7/8" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
164.50
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
157.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
150.00
Twin Pro
6157-1
6157-2
6157-3
6157-4
6157-5
6157-6
6157-7
6157-8
6157-9
6157-10
6157-11
6157-12
6157-13
6157-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
Twin Maximum
8857-1
8857-2
8857-3
8857-4
8857-5
8857-6
8857-7
8857-8
8857-9
8857-10
8857-11
8857-12
8857-13
8857-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L657-1
L657-2
L657-3
L657-4
L657-5
L657-6
L657-7
L657-8
L657-9
L657-10
L657-11
L657-12
L657-13
L657-15
657-1
657-2
657-3
657-4
657-5
657-6
657-7
657-8
657-9
657-10
657-11
657-12
657-13
657-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.875
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
151.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
143.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8857-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
33
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
Twin V-10
V6558-1
V6558-2
V6558-3
V6558-4
V6558-5
V6558-6
V6558-7
V6558-8
V6558-9
V6558-10
V6558-11
V6558-12
V6558-13
V6558-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
179.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
171.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
161.50
Twin Exclusive
E6558-1
E6558-2
E6558-3
E6558-4
E6558-5
E6558-6
E6558-7
E6558-8
E6558-9
E6558-10
E6558-11
E6558-12
E6558-13
E6558-15
Twin 6000 Classic
6558-1
6558-2
6558-3
6558-4
6558-5
6558-6
6558-7
6558-8
6558-9
6558-10
6558-11
6558-12
6558-13
6558-15
34
with
with
with
with
with
with
with
with
with
with
with
with
with
with
An ASSA ABLOY Group company
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
2" Mortise Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
175.50
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
168.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
161.00
Twin Pro
6158-1
6158-2
6158-3
6158-4
6158-5
6158-6
6158-7
6158-8
6158-9
6158-10
6158-11
6158-12
6158-13
6158-15
with
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Mogul Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
Twin Maximum
8858-1
8858-2
8858-3
8858-4
8858-5
8858-6
8858-7
8858-8
8858-9
8858-10
8858-11
8858-12
8858-13
8858-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Low & Twin 600 Series Classic
Low
600
Description
L658-1
L658-2
L658-3
L658-4
L658-5
L658-6
L658-7
L658-8
L658-9
L658-10
L658-11
L658-12
L658-13
L658-15
658-1
658-2
658-3
658-4
658-5
658-6
658-7
658-8
658-9
658-10
658-11
658-12
658-13
658-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
with Mogul Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
HD
HT
BL
BD
R-A
R-B
COMP
SUB
—
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
0.138
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
2.00
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
0.308
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
163.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
154.00
—
—
—
—
—
—
—
—
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8858-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
35
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
Sub
SNS
Corbin Jumbo Mortise Cylinder
Model/Cam#
Twin V-10
Description
† V7551-8
† V7551-12
HD
HT
BL
BD
R-A
R-B
Comp
with Corbin Jumbo Cam
1.648
w/ Cor. Jumbo Clover Cam 1.648
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
0.914 151.00 143.50 136.50
0.828 151.00 143.50 136.50
with Corbin Jumbo Cam
1.648
w/ Cor. Jumbo Clover Cam 1.648
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
0.914 151.00 143.50 136.50
0.828 151.00 143.50 136.50
with Corbin Jumbo Cam
1.648
w/ Cor. Jumbo Clover Cam 1.648
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
0.914 128.00 119.00 110.00
0.828 128.00 119.00 110.00
with Corbin Jumbo Cam
1.648
w/ Cor. Jumbo Clover Cam 1.648
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
0.914 151.00 143.50 136.50
0.828 151.00 143.50 136.50
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
0.914 151.00 143.50 136.50
0.828 151.00 143.50 136.50
HT
BL
BD
R-A
0.138
0.138
1.125
1.125
1.492
1.492
N/A
0.114
Twin Exclusive
† E7551-8
† E7551-12
Twin 6000 Classic
† 7551-8
† 7551-12
Twin Pro
† 7151-8
† 7151-12
Twin Maximum
† 7851-8
with Corbin Jumbo Cam
1.648
† 7851-12
w/ Cor. Jumbo Clover Cam 1.648
Twin Low & Twin Low 600 Series Classic
Low
600
Description
HD
L751-8 751-1 w/ Corbin Jumbo Cam
1.648
L751-12 751-12 w/ Cor. Jumbo Clover Cam 1.648
R-B
COMP
0.914 113.50 104.50
0.828 113.50 104.50
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 7851-8 x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 4, add $29.00.
36
An ASSA ABLOY Group company
SUB
—
—
—
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
#12
BD
HT
BL
#13
#15
Sub
SNS
ASSA Segal Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Segal inside cyl. with Cam
1.439
0.148
1.377
1.367
N/A
N/A
128.50 120.50 113.50
Segal inside cyl. with Cam
1.439
0.148
1.377
1.367
N/A
N/A
128.50 120.50 113.50
Segal inside cyl. with Cam
1.439
0.148
1.377
1.367
N/A
N/A
109.00
Segal inside cyl. with Cam
1.439
0.148
1.377
1.367
N/A
N/A
128.50 120.50 113.50
1.439
0.148
1.377
1.367
N/A
N/A
128.50 120.50 113.50
HD
HT
BL
BD
R-A
R-B
Otis Elevator Cylinder
0.595
0.110
1.377
1.157
N/A
N/A
315.00 307.50 300.50
Otis Elevator Cylinder
0.595
0.110
1.377
1.157
N/A
N/A
315.00 307.50 300.50
Otis Elevator Cylinder
0.595
0.110
1.377
1.157
N/A
N/A
264.50 254.50 246.50
Otis Elevator Cylinder
0.595
0.110
1.377
1.157
N/A
N/A
315.00 307.50 300.50
0.595
0.110
1.377
1.157
N/A
N/A
315.00 307.50 300.50
Twin V-10
V6573
Twin Exclusive
E6573
Twin 6000 Classic
6573
99.00
90.00
Twin Pro
6173
Twin Maximum
8873
Segal inside cyl. with Cam
ASSA Otis Elevator Cylinder
Model/Cam#
Description
Comp
Sub
SNS
Twin V-10
V6551E
Twin Exclusive
E6551E
Twin 6000 Classic
6551E
Twin Pro
6151E
Twin Maximum
8851E
Otis Elevator Cylinder
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8873-1 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
37
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Component Parts
Cylinder Shell
Cylinder Plug
Mortise Cylinder Parts
Model No.
Description
Price
Twin V-10
867429
867430
867431
867432
867433
867434
867435
867436
807987
353970
353971
353972
353973
353974
353975
353976
353977
1-1/8" Cylinder Shell*
1-1/4" Cylinder Shell*
1-3/8" Cylinder Shell*
1-1/2" Cylinder Shell*
1-5/8" Cylinder Shell*
1-3/4" Cylinder Shell*
1-7/8" Cylinder Shell*
2" Cylinder Shell*
Corbin Jumbo 1-1/8" Shell*
1-1/8" Cylinder Plug*
1-1/4" Cylinder Plug*
1-3/8" Cylinder Plug*
1-1/2" Cylinder Plug*
1-5/8" Cylinder Plug*
1-3/4" Cylinder Plug*
1-7/8" Cylinder Plug*
2" Cylinder Plug*
48.50
48.50
77.00
77.50
80.50
83.50
86.00
89.50
97.00
21.50
21.50
24.00
27.50
30.00
32.50
35.50
38.00
Twin Exclusive
867429
1-1/8" Cylinder Shell*
867430
1-1/4" Cylinder Shell*
867431
1-3/8" Cylinder Shell*
867432
1-1/2" Cylinder Shell*
867433
1-5/8" Cylinder Shell*
1-3/4" Cylinder Shell*
867434
867435
1-7/8" Cylinder Shell*
867436
2" Cylinder Shell*
Corbin Jumbo 1-1/8" Shell*
807987
367019
1-1/8" Cylinder Plug*
367020
1-1/4" Cylinder Plug*
367021
1-3/8" Cylinder Plug*
1-1/2" Cylinder Plug*
367022
367023
1-5/8" Cylinder Plug*
1-3/4" Cylinder Plug*
367024
367025
1-7/8" Cylinder Plug*
367026
2" Cylinder Plug*
907050
Corbin Jumbo Cylinder Thread Adapter
* – Indicates Finished Components.
38
An ASSA ABLOY Group company
48.50
48.50
77.00
77.50
80.50
83.50
86.00
89.50
97.00
21.50
21.50
25.00
27.50
30.00
32.50
35.50
38.00
29.00
ASSA Mortise Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise Component Parts
Cylinder Shell
Cylinder Plug
Mortise Cylinder Parts
Model No.
Description
Price
Twin Pro/Twin
867429
867430
867431
867432
867433
867434
867435
867436
807987
356955
356956
356957
356958
356959
356960
356961
356962
Maximum
1-1/8" Cylinder Shell*
1-1/4" Cylinder Shell*
1-3/8" Cylinder Shell*
1-1/2" Cylinder Shell*
1-5/8" Cylinder Shell*
1-3/4" Cylinder Shell*
1-7/8" Cylinder Shell*
2" Cylinder Shell*
Corbin Jumbo 1-1/8" Shell*
1-1/8" Cylinder Plug*†
1-1/4" Cylinder Plug*†
1-3/8" Cylinder Plug*†
1-1/2" Cylinder Plug*†
1-5/8" Cylinder Plug*†
1-3/4" Cylinder Plug*†
1-7/8" Cylinder Plug*†
2" Cylinder Plug*†
48.50
48.50
77.00
77.50
80.50
83.50
86.00
89.50
58.50
21.50
21.50
24.00
27.00
30.00
32.50
32.50
38.00
* – Indicates Finished Components.
† – Specify Profile 0P4 for Twin Pro or 0M7 for Twin Maximum.
An ASSA ABLOY Group company
39
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders
ASSA Mogul cylinders are designed to provide
the maximum level of security and durability.
Available for ADTEC, Folger Adam,
Norment/AirTeq, R.R. Brink, Sargent, and
Southern Steel detention locksets, the ASSA
Mogul is the smart choice for today’s
corrections industry. A hardened cover plate
and hardened steel inserts in the cylinder shell
provide protection against even the most savage and
determined forms of physical attack. As with all
ASSA high security cylinders, our patented key control
ensures the ultimate protection against unauthorized key duplication.
Benefits:
• Hardened plug cover plate to prevent drill attack
• Case-hardened steel inserts and stainless steel pins
• Two independent locking mechanisms to ensure security and optimum pick resistance
• Inactive “false” grooves on side pins designed to enhance pick resistance
• Counter mill in each chamber position to further enhance pick resistance
• Extremely close tolerances
• Can be easily rekeyed in the field
Warranty:
• ASSA guarantees its cylinders against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Twin Series Mogul cylinders are U.L. 437 listed as well as ASTM F 1577 6.6 Certified for standard
test methods for Detention Locks
Technical Information:
• Available in 1-1/8" and 1-1/2" lengths
• Available with limited rotation and/or unidirectional features
• Cylinder housing and plug are made of high quality brass
• Stainless steel top pins
• Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
626
606
40
U.S. Symbol
US 26D
US 4
An ASSA ABLOY Group company
Euro Finish
13
23
Description
Satin Chrome
Satin Brass
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders
Ordering Information
Model No.
Finish
Program
Security
Form
V8551-11
626
C2R
Sub
Keyway
95-300
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Twin V-10 & Twin Exclusive Mogul Cylinders:
Specify
Model No.
Finish
Security
Program
Form
Keyway
Example: ..........V8551-11 ................626.......................C2R ......................Sub .....................95-300
An ASSA ABLOY Group company
41
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders Exploded View
1-1/8" Mogul Cylinder
Pin Chamber Closing Rod
806974
Pin Chamber Closing Screws
806346
Cam
809337
Top Pins
Bottom Pins
Cylinder Plug
250861 Twin V-10
354050 Twin Exclusive/6000 Classic
Cam Screws
867090
Cylinder Housing
354051
Side Bar
267008
Patented, Geographically
Exclusive Key
250694 Twin V-10
E867091 Twin Exclusive
Side Pins
353852 Twin V-10
867015 Twin Exclusive
Hardened
Cover Plate
809339
42
An ASSA ABLOY Group company
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders Exploded View
1-1/2" Mogul Cylinder
Pin Chamber Closing Rod
806974
Pin Chamber Closing Screws
806346
Cam Adapter
354993
Top Pins
Bottom Pins
Cylinder Plug
250894 Twin V-10
250893 Twin Exclusive/6000 Classic
Cam Adapter
Screws
867090
Cylinder Housing
357672
Side Bar
267008
Patented, Geographically
Exclusive Key
250694 Twin V-10
E867091 Twin Exclusive
Side Pins
353852 Twin V-10
867015 Twin Exclusive
Hardened
Cover Plate
809339
An ASSA ABLOY Group company
43
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders
Available Cams
Cam Key:
R-A – Head Radius
R-B – Overall Radius
HD
R-A
R-B
1-1/8" Mogul
AirTeq/Norment
1-1/2" Mogul
SS, FA, NA, BR, AD
BD
HT
BL
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
#11
#14
ASSA 1-1/8" Mogul AirTeq/Norment Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
with Mogul Cam
with Sargent Mogul Cam
2.245
2.245
0.340
0.340
1.260
1.260
2.000
2.000
N/A
N/A
1.165 144.00 136.50 129.50
1.043 144.00 136.50 129.50
with Mogul Cam
with Sargent Mogul Cam
2.245
2.245
0.340
0.340
1.260
1.260
2.000
2.000
N/A
N/A
1.165 144.00 136.50 129.50
1.043 144.00 136.501129.50
2.245
2.245
0.340
0.340
1.260
1.260
2.000
2.000
N/A
N/A
1.165 164.00 155.00 146.00
1.043 164.00 155.00 146.00
Twin V-10
† V8551-11
† V8551-14
Twin Exclusive
† E8551-11
† E8551-14
Twin 6000 Classic
† 8551-11
† 8551-14
with Mogul Cam
with Sargent Mogul Cam
ASSA 1-1/2" Southern Steel Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
2.245
0.120
1.590
2.000
N/A
N/A
164.00 155.00 146.00
Twin V-10
† V8551SS
Twin Exclusive
† E8551SS
Twin 6000 Classic
† 8551SS
shipped without Cams
No Cams offered for 1-1/2" Mogul cylinders
† Available in special function cylinders, see page 4, add $29.00.
44
An ASSA ABLOY Group company
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Cylinders
ASSA 1-1/2" Folger Adam Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
2.245
0.120
1.590
2.000
N/A
N/A
164.00 155.00 146.00
Twin V-10
† V8551FA
Twin Exclusive
† E8551FA
Twin 6000 Classic
† 8551FA
shipped without Cams
ASSA 1-1/2" Norment/AirTeq Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
2.245
0.120
1.590
2.000
N/A
N/A
164.00 155.00 146.00
Twin V-10
† V8551NA
Twin Exclusive
† E8551NA
Twin 6000 Classic
† 8551NA
shipped without Cams
ASSA 1-1/8" R.R. Brink Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
shipped with #11 Cam
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
shipped with #11 Cam
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
2.245
0.120
1.590
2.000
N/A
N/A
164.00 155.00 146.00
Twin V-10
† V8551BR
Twin Exclusive
† E8551BR
Twin 6000 Classic
† 8551BR
shipped with #11 Cam
ASSA 1-1/2" ADTECH Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
shipped without Cams
2.245
0.120
1.590
2.000
N/A
N/A
144.00 136.50 129.50
2.245
0.120
1.590
2.000
N/A
N/A
164.00 155.00 146.00
Twin V-10
† V8551AD
Twin Exclusive
† E8551AD
Twin 6000 Classic
† 8551AD
shipped without Cams
No Cams offered for 1-1/2" Mogul cylinders
† Available in special function cylinders, see page 4, add $29.00.
An ASSA ABLOY Group company
45
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security IC Mogul Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
BD
1-1/8" IC Cylinder
HT
1-1/2" IC Cylinder
BL
ASSA 1-1/2" Southern Steel Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
2.245
0.120
1.590
2.000
N/A
N/A
220.50 211.50 202.50
Twin V-10
V8551SSIC
Twin Exclusive
E8551SSIC
Twin 6000 Classic
8551SSIC
1-1/2" Mogul IC Cylinder
ASSA 1-1/2" Folger Adam Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
2.245
0.120
1.590
2.000
N/A
N/A
220.50 211.50 202.50
Twin V-10
V8551FAIC
Twin Exclusive
E8551FAIC
Twin 6000 Classic
8551FAIC
1-1/2" Mogul IC Cylinder
ASSA 1-1/2" Norment/AirTeq Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
2.245
0.120
1.590
2.000
N/A
N/A
220.50 211.50 202.50
Twin V-10
V8551NAIC
Twin Exclusive
E8551NAIC
Twin 6000 Classic
8551NAIC
46
1-1/2" Mogul IC Cylinder
An ASSA ABLOY Group company
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security IC Mogul Cylinders
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
HD
BD
1-1/8" IC Cylinder
HT
1-1/2" IC Cylinder
BL
ASSA 1-1/2" R.R. Brink Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
2.245
0.120
1.590
2.000
N/A
N/A
220.50 211.50 202.50
Twin V-10
V8551BRIC
Twin Exclusive
E8551BRIC
Twin 6000 Classic
8551BRIC
1-1/2" Mogul IC Cylinder
ASSA 1-1/2" ADTECH Interchangeable Core Mogul Cylinder
Model/Cam#
Description
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
1-1/2" Mogul IC Cylinder
2.245
0.120
1.590
2.000
N/A
N/A
204.50 199.00 192.00
2.245
0.120
1.590
2.000
N/A
N/A
220.50 211.50 202.50
Twin V-10
V8551ADIC
Twin Exclusive
E8551ADIC
Twin 6000 Classic
8551ADIC
1-1/2" Mogul IC Cylinder
ASSA 1-1/2" Temporary Interchangeable Construction Core Mogul Cylinder
Model #
Description
8551SSICR
8551FAICR
8551NAICR
8551BRICR
8551ADICR
1-1/2"
1-1/2"
1-1/2"
1-1/2"
1-1/2"
Mogul
Mogul
Mogul
Mogul
Mogul
IC
IC
IC
IC
IC
Cylinder
Cylinder
Cylinder
Cylinder
Cylinder
HD
HT
BL
BD
R-A
R-B
Comp
Sub
SNS
2.245
2.245
2.245
2.245
2.245
0.120
0.120
0.120
0.120
0.120
1.590
1.590
1.590
1.590
1.590
2.000
2.000
2.000
2.000
2.000
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
206.50
206.50
206.50
206.50
206.50
—
—
—
—
—
—
—
—
—
—
For temporary cores refer to Red Core on page 4.
An ASSA ABLOY Group company
47
ASSA Mogul Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
High Security Mogul Component Parts
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
BD – Body Diameter
BD
1-1/8" Dummy Cylinder
1-1/2" Dummy Cylinder
HT
BL
Mogul Cylinder Parts
Model No.
Description
PRICE
1-1/8" Mogul Cylinder Shell
1-1/2" Mogul Cylinder Shell
1-1/8" Mogul Cylinder Plug
1-1/2" Mogul Cylinder Plug
Cam Adaptor for 1-1/2" Cylinder
Mogul Cylinder Plug Cover Plate
Mogul Chamber Screw Wrench
54.50
56.00
33.50
33.50
9.50
8.25
.75
1-1/8" Mogul Cylinder Shell
1-1/2" Mogul Cylinder Shell
1-1/8" Mogul Cylinder Plug
1-1/2" Mogul Cylinder Plug
Cam Adaptor for 1-1/2" Cylinder
Mogul Cylinder Plug Cover Plate
Mogul Chamber Screw Wrench
54.50
56.00
33.50
33.50
9.50
8.25
.75
Twin V-10
354051
357672
250861
250894
354993
809339
907035
Twin Exclusive
354051
357672
354050
250893
354993
809339
907035
ASSA Mogul Dummy Cylinders
Model
Description
8551DUM
8551SSDUM
1-1/8" Mogul Dummy Cylinder
1-1/2" Mogul Dummy Cylinder
HD
HT
BL
BD
R-A
R-B
Price
2.245
2.245
0.340
0.120
1.260
1.590
2.00
2.00
N/A
N/A
N/A
N/A
74.00
74.00
BD
R-A
R-B
Price
2.00
2.00
N/A
N/A
N/A
N/A
129.50
129.50
ASSA Mogul Interchangeable Core Housings
Model
Description
80601
HD
HT
BL
1-1/8" Mogul IC Housing
2.245 0.340 1.260
1-1/2" Mogul IC Housing
2.245 0.120 1.590
To order Interchangeable Cores separately – see page 62 for details.
48
An ASSA ABLOY Group company
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
Commonly used on apartment and condominium
doors, ASSA rim cylinders are used on vertical
deadbolt locks and are also designed for
commercial exit and panic devices. Available
with either horizontal/vertical break-off or
lazy-motion type break-off tailpieces, ASSA
rim cylinders can be ordered with the standard
or the Sargent rim exit device mounting patterns.
The standard rim cylinder can be easily converted to a mortise cylinder by simply
replacing the rim tailpiece assembly with the appropriate cam.
Benefits:
•
•
•
•
•
•
•
•
Drill resistant cylinder housing and plug
Case-hardened steel inserts and stainless steel pins
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Extremely close tolerances
Can be easily rekeyed in the field
Standard and Sargent hole pattern available
Standard rim cylinder is easily converted to mortise cylinder
Warranty:
• ASSA guarantees its cylinders against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Twin Series Rim cylinders are U.L. 437 Listed as well as ASTM F 1577 6.6 Certified for standard test
methods for Detention Locks
Technical Information:
•
•
•
•
Available with limited rotation and/or unidirectional features
Cylinder housing and plug are made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
612
624
U.S. Symbol
US 26
US 26D
US 3
US 4
US 10
US 10B
An ASSA ABLOY Group company
Euro Finish
11
13
20
23
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Satin Bronze
Dark Oxidized Bronze
49
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders Ordering Information
Model No.
Finish
Program
Security
Form
V6551-H
626
C2R
Sub
Keyway
95-300
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General
Information
Page 3.
General
Information
Page 4.
How To Order Rim Cylinders:
Specify
Model No.
Finish
Security
Program
Form
Keyway
Example: ..........V6551-H..................626.......................C2R ......................Sub .....................95-300
Rim Cylinder mounting plates, screws included with cylinder. All items available separately below:
Price
Description
Part No.
900210 ..........................Rim cylinder mounting plate............................................................1.25 ea
900211 ..........................Rim cylinder mounting screws .........................................................0.75/pr
900209 ..........................Kit, includes plate and 2 screws .......................................................1.75 ea
900212 ..........................Rim cylinder collar rings (Finish 605, 624 & 626 ONLY) ..................3.50 ea
867450 ..........................Horizontal & Vertical Rim Tailpiece Kit, includes 900209 Kit.......16.50 ea
867451 ..........................Lazy Motion Rim Tailpiece Kit, includes 900209 Kit .....................16.50 ea
Aluminum blocking rings, finish 626 or 624 ONLY
Part No.
Width
Price
900219 ..........................1/4".....................................................................................................3.50 ea
900220 ..........................3/8".....................................................................................................3.50 ea
900221 ..........................1/2".....................................................................................................3.50 ea
Adjustable collar ring, Item No. 900222, finish 626,605 or 624 ONLY, $6.00
Hardened collar ring, Item No. 900223, finish 626 or 624 ONLY, $11.50
Corbin Jumbo Collar, Item No. 900224, finish 626, ONLY $9.25
50
An ASSA ABLOY Group company
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders Exploded View
Standard-pin
Tumbler System
Drill-resistant
Cylinder Housing
Tailpiece
Drill-resistant
Cylinder Plug
Rim Cylinder
Mounting Screws
System Code
Rim Cylinder
Mounting Plate
Coded Side Bar
Locking System
Side Bar Code
Top Pins
Large Key-bow
Cover Strip
Cylinder Springs
Master Pins
Bottom Pins
Cylinder Housing
Cylinder Plug
Available Tailpieces
Sidebar
An ASSA ABLOY Group company
Sidebar Springs
Side Pins
Side Pin Spring
51
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
Available Tailpieces
R
H/V
HT
L
BL
1-1/8" Rim Cylinder
Model/TP#
Description
HD
HT
BL
R
Comp
Sub
SNS
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
85.00
85.00
85.00
77.50
77.50
77.50
70.50
70.50
70.50
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
85.00
85.00
85.00
77.50
77.50
77.50
70.50
70.50
70.50
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060 100.00
0.060 100.00
0.060 100.00
91.00
91.00
91.00
82.00
82.00
82.00
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
85.00
85.00
85.00
77.50
77.50
77.50
70.50
70.50
70.50
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
85.00
85.00
85.00
77.50
77.50
77.50
70.50
70.50
70.50
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
68.00
68.00
68.00
62.00
62.00
62.00
56.50
56.50
56.50
HD
HT
BL
BD
COMP
SUB
—
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060
0.060
0.060
84.00
84.00
84.00
75.00
75.00
75.00
—
—
—
Twin V-10
† V6551-H
† V6551-V
† V6551-L
Twin Exclusive
† E6551-H
† E6551-V
† E6551-L
Twin 6000 Classic
† 6551-H
† 6551-V
† 6551-L
Twin Pro
† 6151-H
† 6151-V
† 6151-L
Twin Maximum
† 8851-H
† 8851-V
† 8851-L
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
Twin Maximum Medium Security
† 2851-H
with Horizontal Tailpiece
† 2851-V
with Vertical Tailpiece
† 2851-L
with Lazy-motion Tailpiece
Twin Low & Twin Low 600 Series Classic
Low
600
Description
L651-H
L651-V
L651-L
651-H with Horizontal Tailpiece
651-V with Vertical Tailpiece
651-L w/Lazy-motion Tailpiece
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851-H x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 10, add $29.00.
52
An ASSA ABLOY Group company
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
Available Tailpieces
R
H/V
HT
L
BL
Corbin Jumbo Rim Cylinder
Model/TP#
Description
HD
HT
BL
R
Comp
Sub
SNS
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
0.060 137.50 128.50 119.50
0.060 137.50 128.50 119.50
0.060 137.50 128.50 119.50
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
0.060 155.50 148.00 141.00
HD
HT
BL
1.643
1.643
1.643
0.170
0.170
0.170
1.270
1.270
1.270
Twin V-10
† V7551-H
† V7551-V
† V7551-L
Twin Exclusive
† E7551-H
† E7551-V
† E7551-L
Twin 6000 Classic
† 7551-H
† 7551-V
† 7551-L
Twin Pro
† 7151-H
† 7151-V
† 7151-L
Twin Maximum
† 7851-H
with Horizontal Tailpiece
† 7851-V
with Vertical Tailpiece
† 7851-L
with Lazy-motion Tailpiece
Twin Low & Twin Low 600 Series Classic
Low
600
Description
L651-H
L651-V
L651-L
651-H with Horizontal Tailpiece
651-V with Vertical Tailpiece
651-L w/Lazy-motion Tailpiece
BD
COMP
SUB
0.060 121.00 112.00
0.060 121.00 112.00
0.060 121.00 112.00
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 7851-H x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 10, add $29.00.
An ASSA ABLOY Group company
53
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
Available Tailpieces
R
H/V
HT
L
BL
ASSA Mogul (Detention) Cylinders
Model/TP#
Description
HD
HT
BL
R
Comp
Sub
SNS
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
2.245
2.245
2.245
0.340
0.340
0.340
1.425
1.425
1.425
0.060 166.50 159.00 152.00
0.060 166.50 159.00 152.00
0.060 166.50 159.00 152.00
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
2.245
2.245
2.245
0.340
0.340
0.340
1.425
1.425
1.425
0.060 166.50 159.00 152.00
0.060 166.50 159.00 152.00
0.060 166.50 159.00 152.00
2.245
2.245
2.245
0.340
0.340
0.340
1.425
1.425
1.425
0.060 189.00 180.00 171.00
0.060 189.00 180.00 171.00
0.060 189.00 180.00 171.00
Twin V-10
† V8551-H
† V8551-V
† V8551-L
Twin Exclusive
† E8551-H
† E8551-V
† E8551-L
Twin 6000 Classic
† 8551-H
† 8551-V
† 8551-L
54
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
An ASSA ABLOY Group company
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Cylinders
HD
Mortise Cylinder Key:
HD – Head Diameter
HT – Head Thickness
BL – Body Length
(Includes Cam)
R – Retainer
Available Tailpieces
R
H/V
HT
L
BL
Special SARGENT Cylinders
Model/TP#
(Drilled for SARGENT Devices)
Description
HD
HT
BL
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
0.138
0.138
0.138
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
1.366
1.366
1.366
with Horizontal Tailpiece
with Vertical Tailpiece
with Lazy-motion Tailpiece
R
Comp
Sub
SNS
0.060 101.50
0.060 101.50
0.060 101.50
93.50
93.50
93.50
86.50
86.50
86.50
1.290
1.290
1.290
0.060 101.50
0.060 101.50
0.060 101.50
93.50
93.50
93.50
86.50
86.50
86.50
0.138
0.138
0.138
1.290
1.290
1.290
0.060 119.00 109.00 100.00
0.060 119.00 109.00 100.00
0.060 119.00 109.00 100.00
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060 101.50
0.060 101.50
0.060 101.50
93.50
93.50
93.50
86.50
86.50
86.50
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
0.060 101.50
0.060 101.50
0.060 101.50
93.50
93.50
93.50
86.50
86.50
86.50
HD
HT
BL
SUB
—
1.366
1.366
1.366
0.138
0.138
0.138
1.290
1.290
1.290
Twin V-10
† VS6551-H
† VS6551-V
† VS6551-L
Twin Exclusive
† ES6551-H
† ES6551-V
† ES6551-L
Twin 6000 Classic
† S6551-H
† S6551-V
† S6551-L
Twin Pro
†S6151-H
† S6151-V
† S6151-L
Twin Maximum
† S8851-H
with Horizontal Tailpiece
† S8851-V
with Vertical Tailpiece
† S8851-L
with Lazy-motion Tailpiece
Twin Low & Twin Low 600 Series Classic
Low
600
Description
LS651-H S651-H with Horizontal Tailpiece
LS651-V S651-V with Vertical Tailpiece
LS651-L S651-L w/Lazy-motion Tailpiece
BD
COMP
0.060 102.00 93.00
0.060 102.00 93.00
0.060 102.00 93.00
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: S8851-H x CLIQ x 626 x Sidebar x Comp
† Available in special function cylinders, see page 10, add $29.00.
An ASSA ABLOY Group company
55
ASSA Rim Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Rim Component Parts
Cylinder Shell
Cylinder Plug
Rim Cylinder Parts
Model No.
Description
Price
Twin V-10
354947
867429
807987
353970
SARGENT Drilled Rim Shell*
1-1/8" Cylinder Shell*
Corbin Jumbo 1-1/8" Shell*
1-1/8" Cylinder Plug*
76.50
48.50
58.50
21.50
Twin Exclusive
354947
SARGENT Drilled Rim Shell*
867429
1-1/8" Cylinder Shell*
807987
Corbin Jumbo 1-1/8" Shell*
367019
1-1/8" Cylinder Plug*
76.50
48.50
58.50
21.50
Twin Pro/Twin
354947
867429
807987
356955
76.50
48.50
58.50
21.50
Maximum
SARGENT Drilled Rim Shell*
1-1/8" Cylinder Shell*
Corbin Jumbo 1-1/8" Shell*
1-1/8" Cylinder Plug*†
* – Indicates Finished Components.
† – Specify Profile 0P4 for Twin Pro or 0M7 for Twin Maximum.
56
An ASSA ABLOY Group company
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim Interchangeable Core Cylinders
Designed with both security and convenience in
mind, the ASSA Large Format Interchangeable
core cylinder is perfect for apartment buildings,
dormitories, classrooms, and other applications
requiring instant rekeying capabilities. This versatile
cylinder is adaptable to a wide variety of manufacturers’
locksets including the ASSA Number 2 padlock and ASSA 6000
deadbolt series and can be integrated into master keyed systems that
use both standard and interchangeable cylinders. Available in the
standard ASSA large format as well as the Schlage, Yale 6 pin, and Sargent 6 pin
large formats, all ASSA Interchangeable core cylinders are listed under U.L. 437,
a set of tests for determining the cylinder's physical resistance against various
forms of attack and performance that features our patented key control ensuring
the maximum protection from unauthorized key duplication.
Benefits:
•
•
•
•
•
•
•
Easily rekeyed openings in the field
Can be used in master key system with standard locks
Available in multiple manufacturers’ formats
Drill resistant cylinder housing and plug
Case-hardened steel inserts and stainless steel pins
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Warranty:
• ASSA guarantees its cylinders against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Interchangeable Core cylinders are U.L. 437 Listed as well as ASTM F 1577 6.6 Certified for standard
test methods for Detention Locks
Technical Information
•
•
•
•
•
Available for 1-1/4" mortise and rim cylinders
Build up pins in first four positions operate control feature
Cylinder housing and interchangeable core are made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
612
624
U.S. Symbol
US 26
US 26D
US 3
US 4
US 10
US 10B
An ASSA ABLOY Group company
Euro Finishes
11
13
20
23
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Satin Bronze
Dark Oxidized Bronze
57
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim Interchangeable Core
Cylinders Ordering Information
Model No.
Finish
Program
Security
Form
V6552IC-1
626
C2R
Sub
Keyway
95-300
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Twin V-10, Twin Exclusive Mortise and Rim IC Cylinders:
Specify
Model No.
Finish
Security
Program
Form
Keyway
Example: ..........V6552IC-1 ...............626.......................C2R ......................Sub .....................95-300
How To Order Twin Pro and Twin Maximum Mortise and Rim IC Cylinders:
Specify
Model No.
Finish
Form
Keyway
Example: ..........6152IC-H .................605.......................Comp...................0P4-200
58
An ASSA ABLOY Group company
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim Interchangeable Core
Cylinders Exploded View
ASSA Interchangeable Core
IC Closing Strip
IC Control Chamber Springs
IC Cylinder Housing
Spool Top Pin
Build Up Pins
Bottom Pins
IC Shell
IC C Ring
Cylinder Plug
IC Wave Washer
Side Pin Spring
IC Control Sleeve
Side Pin
Sidebar
An ASSA ABLOY Group company
Sidebar Spring
59
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
Mortise Cylinder Key:
HD – Head Diameter • HT – Head Thickness
BL – Body Length (Includes Cam) • BD – Body Diameter
BH – Body Height • BW – Body Width • R – Retainer
CBL – IC Core Body Length
HD
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
BH
#2
#3
#5
#4
Tailpieces
H/V
BW
R
#6
#7
#9
#8
#10
BD
L
HT
BL
CBL
#12
#13
#15
1-1/4" Mortise Cylinder
Mod/Cam# Description
HD
HT
BL
BD
BH BW
CBL
R
R-A
R-B
Comp
Sub
SNS
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
142.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
132.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
124.00
Twin V-10
V6552IC-1
V6552IC-2
V6552IC-3
V6552IC-4
V6552IC-5
V6552IC-6
V6552IC-7
V6552IC-8
V6552IC-9
V6552IC-10
V6552IC-12
V6552IC-13
V6552IC-15
with
with
with
with
with
with
with
with
with
with
with
with
with
Twin Exclusive
E6552IC-1
E6552IC-2
E6552IC-3
E6552IC-4
E6552IC-5
E6552IC-6
E6552IC-7
E6552IC-8
E6552IC-9
E6552IC-10
E6552IC-12
E6552IC-13
E6552IC-15
with
with
with
with
with
with
with
with
with
with
with
with
with
Twin 6000 Classic
6552IC-1
6552IC-2
6552IC-3
6552IC-4
6552IC-5
6552IC-6
6552IC-7
6552IC-8
6552IC-9
6552IC-10
6552IC-12
6552IC-13
6552IC-15
with
with
with
with
with
with
with
with
with
with
with
with
with
Adams Rite Cam
Sargent Cam
Cor. Clover Leaf Cam
Cor. Beaver Tail Cam
Yale Standard Cam
Schlage “L” Cam
Segal Type Cam
Corbin Jumbo Cam
Best 30H Cam
Norment/AirTeq Cam
Cor. Jumbo Clover Leaf
Sargent Short Cam
Yale Rep. Cam
For temporary cores refer to Red Core on page 4.
60
An ASSA ABLOY Group company
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
Mortise Cylinder Key:
HD – Head Diameter • HT – Head Thickness
BL – Body Length (Includes Cam) • BD – Body Diameter
BH – Body Height • BW – Body Width • R – Retainer
CBL – IC Core Body Length
HD
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
BH
#2
#3
#5
#4
Tailpieces
H/V
BW
R
#6
#7
#9
#8
#10
BD
L
HT
BL
CBL
#12
#13
#15
1-1/4" Mortise Cylinder
Mod/Cam#
Description
HD
HT
BL
BD
BH BW
CBL
R
R-A
R-B
Comp
Sub
SNS
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
120.50
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
113.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
106.00
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
1.366
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
1.055
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
0.655
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.036
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
0.114
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
0.828
0.515
0.308
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
96.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
90.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
84.50
Twin Pro
6152IC-1
6152IC-2
6152IC-3
6152IC-4
6152IC-5
6152IC-6
6152IC-7
6152IC-8
6152IC-9
6152IC-10
6152IC-12
6152IC-13
6152IC-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Maximum
8852IC-1
8852IC-2
8852IC-3
8852IC-4
8852IC-5
8852IC-6
8852IC-7
8852IC-8
8852IC-9
8852IC-10
8852IC-12
8852IC-13
8852IC-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
Twin Maximum Medium Security
2852IC-1
2852IC-2
2852IC-3
2852IC-4
2852IC-5
2852IC-6
2852IC-7
2852IC-8
2852IC-9
2852IC-10
2852IC-12
2852IC-13
2852IC-15
with Adams Rite Cam
with Sargent Cam
with Cor. Clover Leaf Cam
with Cor. Beaver Tail Cam
with Yale Standard Cam
with Schlage “L” Cam
with Segal Type Cam
with Corbin Jumbo Cam
with Best 30H Cam
with Norment/AirTeq Cam
w/ Cor. Jumbo Clover Leaf
with Sargent Short Cam
with Yale Rep. Cam
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8852IC-1 x CLIQ x 626 x Sidebar x Comp. For temporary cores refer to Red Core on page 4.
An ASSA ABLOY Group company
61
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
Mortise Cylinder Key:
HD – Head Diameter • HT – Head Thickness
BL – Body Length (Includes Cam) • BD – Body Diameter
BH – Body Height • BW – Body Width • R – Retainer
CBL – IC Core Body Length
HD
Available Cams
Cam Key:
R-A – Head Radius • R-B – Overall Radius
#1
BH
#2
#3
#5
#4
Tailpieces
H/V
BW
R
#6
#7
#9
#8
#10
BD
L
HT
BL
CBL
#12
#13
#15
1-1/4" Mortise and Rim Cylinders
Mod/Cam# Description
HD
HT
BL
BD
BH BW
CBL
R
R-A
R-B
Comp
Sub
SNS
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
128.00
128.00
128.00
120.50 113.50
120.50 113.50
120.50 113.50
1.643
1.643
1.643
1.643
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
0.665
0.665
0.665
0.665
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
147.50
147.50
154.50
154.50
140.00
140.00
147.00
147.00
133.00
133.00
140.00
140.00
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.055
N/A
1.045
1.045
0.665
N/A
0.628
0.671
1.247
1.247
1.450
1.415
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
75.00
75.00
75.00
75.00
69.50
69.50
69.50
69.50
62.50
62.50
62.50
62.50
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
128.00
128.00
128.00
120.50 113.50
120.50 113.50
120.50 113.50
Twin V-10
Rim Cylinders
V6552IC-H
with Horizontal Tailpiece
V6552IC-V
with Vertical Tailpiece
V6552IC-L
with Lazy-Motion Tailpiece
Corbin Jumbo Rim Cylinders (Mortise & Rim)
V7551IC-8
with Corbin Jumbo Cam
V7551IC-12
with Corbin Jumbo Clover Cam
V7551IC-H
with Horizontal Tailpiece
V7551IC-V
with Vertical Tailpiece
Interchangeable Core Cylinders Only
V70600IC
ASSA IC Cylinder
V90600IC
Sargent IC Cylinder
V10600IC
Schlage IC Cylinder
V80600IC
Yale Style IC Cylinder
Twin Exclusive
Rim Cylinders
E6552IC-H
with Horizontal Tailpiece
E6552IC-V
with Vertical Tailpiece
E6552IC-L
with Lazy-Motion Tailpiece
Corbin Jumbo Rim Cylinders (Mortise & Rim)
E7551IC-8
with Corbin Jumbo Cam
E7551IC-12
with Corbin Jumbo Clover Cam
E7551IC-H
with Horizontal Tailpiece
E7551IC-V
with Vertical Tailpiece
Interchangeable Core Cylinders Only
E70600IC
ASSA IC Cylinder
E90600IC
Sargent IC Cylinder
E10600IC
Schlage IC Cylinder
E80600IC
Yale Style IC Cylinder
0.665
0.665
0.665
0.665
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
147.50
147.50
154.50
154.50
140.00
140.00
147.00
147.00
133.00
133.00
140.00
140.00
N/A 1.055 0.665
N/A N/A N/A
N/A 1.045 0.628
N/A 1.045 0.671
1.247
1.247
1.450
1.415
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
75.00
75.00
75.00
75.00
69.50
69.50
69.50
69.50
62.50
62.50
62.50
62.50
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
142.00
142.00
142.00
132.00 124.00
132.00 124.00
132.00 124.00
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
174.00
174.00
182.00
182.00
164.00
164.00
172.00
172.00
156.00
156.00
164.00
164.00
N/A 1.055 0.665 1.247 0.036
N/A 1.045 0.671 1.415 0.036
N/A
N/A
N/A
N/A
91.00
91.00
82.00
82.00
73.00
73.00
1.643
1.643
1.643
1.643
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
Twin 6000 Classic
Rim Cylinders
with Horizontal Tailpiece
6552IC-H
with Vertical Tailpiece
6552IC-V
with Lazy-Motion Tailpiece
6552IC-L
Corbin Jumbo Rim Cylinders (Mortise & Rim)
with Corbin Jumbo Cam
7551IC-8
with Corbin Jumbo Clover Cam
7551IC-12
with Horizontal Tailpiece
7551IC-H
with Vertical Tailpiece
7551IC-V
Interchangeable Core Cylinders Only
ASSA IC Cylinder
70600IC
Yale Style IC Cylinder
80600IC
1.643
1.643
1.643
1.643
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
N/A
N/A
N/A
N/A
N/A
N/A
For temporary cores refer to Red Core on page 4.
62
An ASSA ABLOY Group company
1.157
1.157
1.157
1.157
1.055
1.055
1.055
1.055
0.665
0.665
0.665
0.665
1.247
1.247
1.247
1.247
ASSA Interchangeable Cores
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Mortise and Rim IC Cylinders
1-1/4" Mortise and Rim Cylinders
Mod/Cam# Description
HD
HT
BL
BD
BH BW
CBL
R
R-A
R-B
Comp
Sub
SNS
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
128.00
128.00
128.00
120.50 113.50
120.50 113.50
120.50 113.50
1.643
1.643
1.643
1.643
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
147.50
147.50
154.50
154.50
140.00
140.00
147.00
147.00
133.00
133.00
140.00
140.00
N/A
N/A
N/A
N/A
1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A N/A N/A
N/A
N/A
N/A 1.045 0.628 1.450 0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.045 0.628 1.450 0.036
N/A
N/A
75.00
75.00
75.00
75.00
69.50
69.50
69.50
69.50
62.50
62.50
62.50
62.50
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
1.366 0.175 1.125 1.157 1.055 0.665 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
128.00
128.00
128.00
120.50 113.50
120.50 113.50
120.50 113.50
1.643
1.643
1.643
1.643
0.175
0.175
0.175
0.175
1.125
1.125
1.125
1.125
1.157
1.157
1.157
1.157
0.036
0.036
0.036
0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
147.50
147.50
154.50
154.50
140.00
140.00
147.00
147.00
133.00
133.00
140.00
140.00
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.055 0.665 1.247 0.036
N/A N/A 1.247 0.036
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.045 0.628 1.450 0.036
1.045 0.671 1.415 0.036
N/A
N/A
N/A
N/A
75.00
75.00
75.00
75.00
69.50
69.50
69.50
69.50
62.50
62.50
62.50
62.50
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1.055
N/A
1.045
1.045
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
60.00
60.00
60.00
60.00
55.50
55.50
55.50
55.50
50.00
50.00
50.00
50.00
—
—
—
—
120.50
127.50
—
—
Twin Pro
Rim Cylinders
6152IC-H
with Horizontal Tailpiece
6152IC-V
with Vertical Tailpiece
6152IC-L
with Lazy-Motion Tailpiece
Corbin Jumbo Rim Cylinders (Mortise & Rim)
7151IC-8
with Corbin Jumbo Cam
7151IC-12
with Corbin Jumbo Clover Cam
7151IC-H
with Horizontal Tailpiece
7151IC-V
with Vertical Tailpiece
Interchangeable Core Cylinders Only
61600IC
ASSA IC Cylinder
69060IC
Sargent IC Cylinder
61060IC
Schlage IC Cylinder
68060IC
Yale Style IC Cylinder
1.055
1.055
1.055
1.055
0.665
0.665
0.665
0.665
1.247
1.247
1.247
1.247
0.036
0.036
0.036
0.036
Twin Maximum
Rim Cylinders
8852IC-H
with Horizontal Tailpiece
8852IC-V
with Vertical Tailpiece
8852IC-L
with Lazy-Motion Tailpiece
Corbin Jumbo Rim Cylinders (Mortise & Rim)
7851IC-8
with Corbin Jumbo Cam
7851IC-12
with Corbin Jumbo Clover Cam
7851IC-H
with Horizontal Tailpiece
7851IC-V
with Vertical Tailpiece
Interchangeable Core Cylinders Only
88600IC
ASSA IC Cylinder
89060IC
Sargent IC Cylinder
81060IC
Schlage IC Cylinder
Yale Style IC Cylinder
88060IC
1.055
1.055
1.055
1.055
0.665
0.665
0.665
0.665
1.247
1.247
1.247
1.247
Twin Maximum Medium Security
Interchangeable Core Cylinders Only
28600IC
ASSA IC Cylinder
29060IC
Sargent IC Cylinder
21060IC
Schlage IC Cylinder
28060IC
Yale Style IC Cylinder
0.665
N/A
0.628
0.671
1.247
1.247
1.450
1.415
0.036
0.036
0.036
0.036
1-1/4" Temporary Interchangeable Construction Core Mortise/Rim Cylinder
6552ICR*
6552ICR*
1-1/4" Mortise IC Cylinder
1-1/4" Rim IC Cylinder
1.366 0.175 1.125 1.157
1.366 0.175 1.125 1.157
—
—
—
—
—
—
—
—
Interchangeable Core Housings
Price
60601*
60601*
80601
45.50
52.50
129.50
IC Housing – Specify Cam
IC Housing – Specify Tailpiece
1-1/2" Mogul IC Housing
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88600IC x CLIQ x 626 x Sidebar x Comp
* – For temporary cores refer to Red Core on page 4.
An ASSA ABLOY Group company
63
Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
ASSA Key in Knob/Key in Lever cylinders
are designed to replace several original
manufacturers’ cylinders in their locksets
offering the highest level of security available
on the market today. These cylinders are
manufactured to exact manufacturers’ specifications
to ensure precise fit and operation. ASSA Key in
Knob/Key in Lever cylinders will improve the security
of standard cylindrical locksets by Arrow, Corbin/Russwin,
Falcon, Sargent, Schlage, Weiser, Yale and many other
manufacturers. All ASSA Key in Knob/Key in Lever cylinders
are listed under U.L. 437.
Benefits:
•
•
•
•
•
•
Designed to exact manufacturers’ specifications
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Extremely close tolerances
Can be easily rekeyed in the field
Patented key control
Warranty:
• ASSA guarantees its cylinders against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Key-in-Knob/Lever cylinders are U.L. 437 listed
Technical Information:
•
•
•
•
Available in 16 different retrofit assemblies
Cylinder shell and plug made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
612
624
64
U.S. Symbol
US 26
US 26D
US 3
US 4
US 10
US 10B
An ASSA ABLOY Group company
Euro Finishes
11
13
20
23
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Satin Bronze
Dark Oxidized Bronze
Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
Ordering Information
Model No.
Finish
Program
Security
Form
V65611
605
C2L
Sub
Keyway
95-200
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Twin V-10, Twin Exclusive Key-in-Knob/Lever Cylinders:
Specify
Model No.
Finish
Security
Program
Form
Keyway
Example: ..........V65611 ...................605.......................C2L.......................Sub ......................95-200
How To Order Twin Pro Key-in-Knob/Lever Cylinders:
Specify
Model No.
Finish
Form
Keyway
Example: ..........61611 ......................605.......................Comp...................0P4-200
An ASSA ABLOY Group company
65
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Levers Cylinders Exploded View
Springs
Closing Strip
Top Pins
Plug Cap Pin
Bottom Pins
Plug Cap
Shell
Tailpiece
Tail Ring
Roll Pin Retainer
Build Up Pins
Plug
Plug Cap Spring
Side Pin Springs
C-Clip Plug Retainer
Sidebar
Side Pin
Sidebar Springs
66
65611 – Schlage
65631 – Yale
65632 – Yale
65651 – Corbin/Russwin
65652 – Corbin/Russwin
65653 – Corbin/Russwin
An ASSA ABLOY Group company
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Levers Cylinders Exploded View
65654 – Corbin/Russwin
65655 – Corbin/Russwin
65661 – Falcon
65671 – Sargent
65672 – Sargent
65673 – Sargent
An ASSA ABLOY Group company
67
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Levers Cylinders Exploded View
65673-TZ – Sargent
65681 – Weiser
65682 – Weiser
65691 – Arrow
65692 – Arrow
68
An ASSA ABLOY Group company
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin V-10
Model #/Make
Description
V65611 - Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
75.50 68.00 61.00
V65631 - Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
75.50 68.00 61.00
V65632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
75.50 68.00 61.00
V65651 - Corbin/Russwin Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
75.50 68.00 61.00
V65652 - Corbin/Russwin Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
75.50 68.00 61.00
V65653 - Corbin/Russwin Russwin cylinder 19F35
1.0238 0.677 1.071
N/A
1.275
0.135 0.560
83.00 75.50 68.50
V65654 - Corbin/Russwin Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
83.00 75.50 68.50
V65655 - Corbin/Russwin Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
83.00 75.50 68.50
An ASSA ABLOY Group company
BL
CD
CH
CL
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
69
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
EL
BL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin V-10
70
Model #/Make
Description
V65661 - Falcon
S & X Series, Use original manufacturer
cap and tailpiece
V65671 - Sargent
CL
EL
1.022 0.634 1.020
N/A
1.325
0.071 0.560
83.00 75.50 68.50
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
83.00 75.50 68.50
V65672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
75.50 68.00 61.00
V65673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
75.50 68.00 61.00
V65673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
75.50 68.00 61.00
V65681 - Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
83.00 75.50 68.50
V65682 - Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
83.00 75.50 68.50
V65691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series Key-in-Knob & Key-in-Lever styles
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
75.50 68.00 61.00
V65692 - Arrow
For Arrow deadbolts only, includes
tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
75.50 68.00 61.00
An ASSA ABLOY Group company
BL
CD
CH
FL
PD
Comp
Sub
SNS
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
EL
BL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Exclusive
Model #/Make
Description
E65611 - Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
75.50 68.00 61.00
E65631 - Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
75.50 68.00 61.00
E65632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
75.50 68.00 61.00
E65651 - Corbin/Russwin Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
75.50 68.00 61.00
E65652 - Corbin/Russwin Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
75.50 68.00 61.00
E65653 - Corbin/Russwin Russwin cylinder 19F35
1.038 0.677 1.071
N/A
1.275
0.135 0.560
83.00 75.50 68.50
E65654 - Corbin/Russwin Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
83.00 75.50 68.50
E65655 - Corbin/Russwin Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
83.00 75.50 68.50
An ASSA ABLOY Group company
BL
CD
CH
CL
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
71
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
EL
BL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Exclusive
72
Model #/Make
Description
E65661 - Falcon
S & X Series, Use original manufacturer
cap and tailpiece
E65671 - Sargent
CL
EL
1.022 0.634 1.020
N/A
1.325
0.071 0.560
83.00 75.50 68.50
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
83.00 75.50 68.50
E65672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
75.50 68.00 61.00
E65673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
75.50 68.00 61.00
E65673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
75.50 68.00 61.00
E65681 - Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
83.00 75.50 68.50
E65682 - Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
83.00 75.50 68.50
E65691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever styles
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
75.50 68.00 61.00
E65692 - Arrow
For Arrow deadbolts only, includes
3 tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
75.50 68.00 61.00
An ASSA ABLOY Group company
BL
CD
CH
FL
PD
Comp
Sub
SNS
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin 6000 Classic
Model #/Make
Description
65611 - Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
82.00 72.00 64.00
65631 - Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
82.00 72.00 64.00
65632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
82.00 72.00 64.00
65651 - Corbin/Russwin
Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
82.00 72.00 64.00
65652 - Corbin/Russwin
Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
82.00 72.00 64.00
65653 - Corbin/Russwin
Russwin cylinder 19F35
1.038 0.677 1.071
N/A
1.275
0.135 0.560
83.00 73.00 65.00
65654 - Corbin/Russwin
Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
83.00 73.00 65.00
65655 - Corbin/Russwin
Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
83.00 73.00 65.00
An ASSA ABLOY Group company
BL
CD
CH
CL
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
73
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin 6000 Classic
74
Model #/Make
Description
65661 - Falcon
S & X Series, Use original manufacturer
cap and tailpiece
65671 - Sargent
CL
EL
1.022 0.634 1.020
N/A
1.325
0.071 0.560
83.00 73.00 65.00
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
83.00 73.00 65.00
65672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
82.00 72.00 64.00
65673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
82.00 72.00 64.00
65673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
82.00 72.00 64.00
65681 - Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
83.00 73.00 65.00
65682 - Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
83.00 73.00 65.00
65691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever style
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
82.00 72.00 64.00
65692 - Arrow
For Arrow deadbolts only, includes
3 tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
82.00 72.00 64.00
An ASSA ABLOY Group company
BL
CD
CH
FL
PD
Comp
Sub
SNS
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Pro
Model #/Make
Description
61611 - Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
75.50 68.00 61.00
61631 - Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
75.50 68.00 61.00
61632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
75.50 68.00 61.00
61651 - Corbin/Russwin
Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
75.50 68.00 61.00
61652 - Corbin/Russwin
Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
75.50 68.00 61.00
61653 - Corbin/Russwin
Russwin cylinder 19F35
1.038 0.677 1.071
N/A
1.275
0.135 0.560
83.00 75.50 68.50
61654 - Corbin/Russwin
Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
83.00 75.50 68.50
61655 - Corbin/Russwin
Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
83.00 75.50 68.50
An ASSA ABLOY Group company
BL
CD
CH
CL
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
75
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Pro
76
Model #/Make
Description
61661 - Falcon
S & X Series, Use original manufacturer
cap and tailpiece
61671 - Sargent
CL
EL
1.022 0.634 1.020
N/A
1.325
0.071 0.560
83.00 75.50 68.50
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
83.00 75.50 68.50
61672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
75.50 68.00 61.00
61673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
75.50 68.00 61.00
61673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
75.50 68.00 61.00
61681 - Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
83.00 75.50 68.50
61682 - Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
83.00 75.50 68.50
61691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever style
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
75.50 68.00 61.00
61692 - Arrow
For Arrow deadbolts only, includes
3 tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
75.50 68.00 61.00
An ASSA ABLOY Group company
BL
CD
CH
FL
PD
Comp
Sub
SNS
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Maximum
Model #/Make
Description
BL
CD
CH
CL
88611 - Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
75.50 68.00 61.00
88631 - Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
75.50 68.00 61.00
88632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
75.50 68.00 61.00
88651 - Corbin/Russwin
Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
75.50 68.00 61.00
88652 - Corbin/Russwin
Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
75.50 68.00 61.00
88653 - Corbin/Russwin
Russwin cylinder 19F35
1.038 0.677 1.071
N/A
1.275
0.135 0.560
83.00 75.50 68.50
88654 - Corbin/Russwin
Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
83.00 75.50 68.50
88655 - Corbin/Russwin
Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
83.00 75.50 68.50
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88611 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
77
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Maximum
Model #/Make
Description
88661 - Falcon
S & X Series, Use original manufacturer
cap and tailpiece
88671 - Sargent
BL
CD
CH
CL
EL
FL
PD
Comp
1.022 0.634 1.020
N/A
1.325
0.071 0.560
83.00 75.50 68.50
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
83.00 75.50 68.50
88672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
75.50 68.00 61.00
88673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
75.50 68.00 61.00
88673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
75.50 68.00 61.00
88681 - Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
83.00 75.50 68.50
88682 - Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
83.00 75.50 68.50
88691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever style
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
75.50 68.00 61.00
88692 - Arrow
For Arrow deadbolts only, includes
3 tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
75.50 68.00 61.00
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88673 x CLIQ x 626 x Sidebar x Comp
78
An ASSA ABLOY Group company
Sub
SNS
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Maximum Medium Security
Model #/Make
Description
28611 - Schlage
1.023 0.634 1.020 2.465 1.250
0.071 0.560
62.50 56.50 51.00
28631 - Yale
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
62.50 56.50 51.00
28632 - Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
62.50 56.50 51.00
28651 - Corbin/Russwin
Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
62.50 56.50 51.00
28652 - Corbin/Russwin
Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
62.50 56.50 51.00
28672 - Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
1.663
0.020 0.560
62.50 56.50 51.00
28673 - Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
62.50 56.50 51.00
28673-TZ - Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
62.50 56.50 51.00
28691 - Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever style
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
62.50 56.50 51.00
An ASSA ABLOY Group company
BL
CD
CH
CL
N/A
N/A
N/A
EL
FL
PD
Comp
Sub
SNS
79
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Low & Twin 600 Series Classic
Low
80
600
Description
BL
CD
CH
CL
EL
FL
PD
Comp
Sub
SNS
L6611 6611
Schlage
Standard and heavy-duty 6-pin, includes
cap, pin, spring and break-off tailpiece.
For B series Deadbolts Corbin/Russwin
CL3300, CL3400, CL3600, CL3700, CK4700,
CL3900 (Must use original manufacturer's
tailpiece and stabilizing sleeve). CK4400
for all functions except 29, 55, & 82. Also
use for A5 & N5 exit trim.
1.023 0.634 1.020 2.465 1.250
0.071 0.560
66.00 57.00
—
L6631 6631
Yale
Standard and heavy-duty
1.000 0.677 1.071
1.429
0.000 0.560
66.00 57.00
—
L6632 6632
Yale
Key-In-Lever style
1.000 0.677 1.071 2.975 1.429
0.000 0.560
66.00 57.00
—
L6651 6651
Corbin/
Russwin
Heavy-duty, new style (Not 3400, 3600,
3800 series) Use for CK4200, & UT5200
1.038 0.677 1.071
1.453
0.135 0.560
66.00 57.00
—
L6652 6652
Corbin/
Russwin
Standard-duty, new style tailpiece
included. For CK4300, 5600, & B2, G2,
G3 exit trim
1.038 0.677 1.071 2.165 1.453
0.135 0.560
66.00 57.00
—
L6653 6653
Corbin/
Russwin
Russwin cylinder 19F35
1.038 0.677 1.071
N/A
1.275
0.135 0.560
66.00 57.00
—
L6654 6654
Corbin/
Russwin
Russwin cylinder 25F26, 25F56, 24F15,
67F69, 55F76
1.038 0.677 1.071
N/A
1.299
0.135 0.560
66.00 57.00
—
L6655 6655
Corbin/
Russwin
Russwin cylinder 25F65
1.038 0.677 1.071
N/A
1.305
0.135 0.560
66.00 57.00
—
An ASSA ABLOY Group company
N/A
N/A
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Cylinders
FL
Key-in-Knob/Lever Key:
BL – Bible Length
CD – Cylinder Diameter
CH – Cylinder Height
CL – Cylinder Length
EL
BL
CH
PD
EL – Effective Length
FL – Front Length
PD – Plug Face Diameter
CL
CD
Key-in-Knob/Lever Cylinders
Twin Maximum
Model #/Make
Description
L6661 6661
Falcon
S & X Series, Use original manufacturer
cap and tailpiece
L6671 6671
Sargent
CL
EL
1.022 0.634 1.020
N/A
1.325
0.071 0.560
66.00 57.00
—
Integra
1.025 0.677 1.071
N/A
1.447
0.000 0.560
66.00 57.00
—
L6672 6672
Sargent
Heavy-duty 7, 8, 9 lines KIK
1.010 0.677 1.071
N/A
1.663
0.020 0.560
66.00 57.00
—
L6673 6673
Sargent
Standard duty 3 tailpieces included
6 Line KIK, 7 Line KIL, 10 Line KIL
0.990 0.634 1.020 2.000 1.235
2.040
2.315
0.000 0.560
66.00 57.00
—
L6673-TZ 6673-TZ
Sargent
T-Zone 11 Line KIL
0.990 0.634 1.020 1.720 1.235
0.000 0.560
66.00 57.00
—
L6681 6681
Weiser
4000 & 9000 single cylinder deadbolts,
entrance style handle locks
1.022 0.634 1.020 3.375 1.335
0.000 0.560
66.00 57.00
—
L6682 6682
Weiser
4000 & 9000 double cylinder deadbolts, entrance style handle locks
1.022 0.634 1.020 1.910 1.335
0.000 0.560
66.00 57.00
—
L6691 6691
Arrow
Standard and heavy-duty, 3 tailpiece
included for Arrow C, H, L, M, Q, S & W
Series key-in-knob & key-in-lever style
1.022 0.634 1.020 2.000 1.268
2.040
2.315
0.070 0.560
66.00 57.00
—
L6692 6692
Arrow
For Arrow deadbolts only, includes
3 tailpieces for double & single cylinders
1.022 0.634 1.020 2.085 1.352
2.340
3.465
0.000 0.560
66.00 57.00
—
An ASSA ABLOY Group company
BL
CD
CH
FL
PD
Comp
Sub
SNS
81
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Component Parts
82
Schlage – 61611
Yale – 61631
Yale – 61632
Corbin/Russwin – 61651
Corbin/Russwin – 61652
Corbin/Russwin – 61653
Corbin/Russwin – 61654
Corbin/Russwin – 61655
Falcon – 61661
Sargent – 61671
Sargent – 61672
Sargent – 61673
Sargent – 61673-TZ
Weiser – 61681
Weiser – 61682
Arrow – 61691
Arrow – 61692
An ASSA ABLOY Group company
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Component Parts
Key-in-Knob/Lever Parts
Model No.
Description
Price
Schlage Cylinder Shell
Yale Cylinder Shell
Russwin/Corbin Cylinder Shell
Sargent Integra Cylinder Shell
Sargent Heavy-duty Cylinder Shell
Sargent Standard-duty Cylinder Shell
Arrow Cylinder Shell
Arrow Deadbolt/Weiser KIK Shell
Schlage Cylinder Plug*
Yale Cylinder Plug* – (Must specify KIK or KIL).
Sargent Integra Cylinder Plug*
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug*
Falcon S & X Series/Weiser Deadbolt Plug
Arrow/Sargent 6-line Cylinder Plug*
Russwin/Corbin std. & Heavy-Duty Cylinder Plug*
Russwin/Corbin 19F35 Cylinder Plug*
Corbin 25F26 Cylinder Plug*
Russwin/Corbin 25F65 Cylinder Plug*
Arrow Deadbolt Plug*
Arrow Deadbolt Cap
Arrow Deadbolt Plug Cap Spring
Arrow Deadbolt Plug Cap Pin
Arrow Deadbolt Washer
Arrow Deadbolt Blocking Piece
Arrow Deadbolt Long Tailpiece (Single Cylinder)
Arrow Deadbolt Short Tailpiece (Double Cylinder)
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
31.00
23.50
32.00
30.00
32.00
23.50
25.50
25.50
25.50
25.50
23.50
2.25/ea.
.50/ea.
.25/ea.
.35/ea.
1.50/ea.
2.10/ea.
1.50/ea.
Schlage Cylinder Shell
Yale Cylinder Shell
Russwin/Corbin Cylinder Shell
Sargent Integra Cylinder Shell
Sargent Heavy-duty Cylinder Shell
Sargent Standard-duty Cylinder Shell
Arrow Cylinder Shell
Arrow Deadbolt/Weiser KIK Shell
Schlage Cylinder Plug*
Yale Cylinder Plug* – (Must specify KIK or KIL).
Sargent Integra Cylinder Plug*
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug*
Falcon S & X Series/Weiser Deadbolt Plug
Arrow/Sargent 6-line Cylinder Plug*
Russwin/Corbin std. & Heavy-Duty Cylinder Plug*
Russwin/Corbin 19F35 Cylinder Plug*
Corbin 25F26 Cylinder Plug*
Russwin/Corbin 25F65 Cylinder Plug*
Arrow Deadbolt Plug*
Arrow Deadbolt Cap
Arrow Deadbolt Plug Cap Spring
Arrow Deadbolt Plug Cap Pin
Arrow Deadbolt Washer
Arrow Deadbolt Blocking Piece
Arrow Deadbolt Long Tailpiece (Single Cylinder)
Arrow Deadbolt Short Tailpiece (Double Cylinder)
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
32.00
30.00
32.00
23.50
25.50
25.50
25.50
25.50
23.50
2.25/ea.
.50/ea.
.25/ea.
.35/ea.
1.50/ea.
2.10/ea.
1.50/ea.
Twin V-10
868056
868057
367156
868060
868061
367159
250619
907203
353978
353979
353980
353981
353982
353983
353984
353985
353986
353787
453978
92C-114
92C-127
92C-128
92C-121
92C-123
D61-44
D62-44
Twin Exclusive
868056
868057
367156
868060
868061
367159
250619
907203
367068
367069
367073
367074
868233
868607
868649
868650
868651
868652
467068
92C-114
92C-127
92C-128
92C-121
92C-123
D61-44
D62-44
* - Indicates Finished Components
An ASSA ABLOY Group company
83
ASSA Key-in-Knob/Lever Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Key-in-Knob/Lever Component Parts
Key-in-Knob/Lever Parts
Model No.
Description
Price
Schlage Cylinder Shell
Yale Cylinder Shell
Russwin/Corbin Cylinder Shell
Sargent Integra Cylinder Shell
Sargent Heavy-duty Cylinder Shell
Sargent Standard-duty Cylinder Shell
Arrow Cylinder Shell
Arrow Deadbolt/Weiser KIK Shell
Schlage Cylinder Plug*†
Yale Cylinder Plug* – (Must specify KIK or KIL)†
Sargent Integra Cylinder Plug*†
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug*†
Arrow/Sargent 6-line Cylinder Plug*†
Russwin/Corbin std. & Heavy-Duty Cylinder Plug*†
Russwin/Corbin 19F35 Cylinder Plug*†
Corbin 25F26 Cylinder Plug*†
Russwin/Corbin 25F65 Cylinder Plug*†
Arrow Deadbolt Cap
Arrow Deadbolt Plug Cap Spring
Arrow Deadbolt Plug Cap Pin
Arrow Deadbolt Washer
Arrow Deadbolt Blocking Piece
Arrow Deadbolt Long Tailpiece (Single Cylinder)
Arrow Deadbolt Short Tailpiece (Double Cylinder)
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
30.00
32.00
30.00
30.00
32.00
32.00
32.00
32.00
2.25/ea.
.50/ea.
.25/ea.
.35/ea.
1.50/ea.
2.10/ea.
1.50/ea.
Twin Pro
868056
868057
367156
868060
868061
367159
250619
907203
356982
356983
356988
356989
356990
356984
356985
356986
356987
92C-114
92C-127
92C-128
92C-121
92C-123
D61-44
D62-44
* – Indicates Finished Components.
† – Specify Profile 0P4 for Twin Pro or 0M7 for Twin Maximum.
84
An ASSA ABLOY Group company
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts
The ASSA 6000 Series deadbolt is designed to withstand
any form of physical attack including drilling, prying,
driving, or pulling. Its free spinning guard collars
protect it from pipe wrenching while its hardened
inserts guard against drilling. The 6000 comes
equipped with the ASSA Hardhat™ to protect
it from outside through-the-door attacks
known as “ice picking.” All ASSA 6000 Series
deadbolts are available with interchangeable core and feature our unique dual
locking mechanism rendering them virtually pick proof. As with all ASSA high
security cylinders, our patented key control ensures the ultimate protection
against unauthorized key duplication.
Benefits:
•
•
•
•
•
•
•
•
ASSA Hardhat™ to prevent physical attack
Free spinning guard collars to prevent wrenching
Available in interchangeable core
High security solid brass cylinders
1/4" Aircraft strength steel mounting bolts
Hardened bolt with full 1" throw
Non-handed
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life Certification
Certification:
• All ASSA 6000 Deadbolts are U.L. 437 Listed as well as ASTM F 1577 6.6 Certified for standard test methods
for Detention Locks
Technical Information:
•
•
•
•
•
•
Available in single and double cylinder and no thumb turn inside models
Available in 2-3/8" and 2-3/4" backsets drive-in or face plate
Available 1-3/8" to 2-1/2" door thickness, 1-3/4" standard
Cylinder housing and plug made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
609
612
624
U.S. Symbol
US 26
US 26D
US 3
US 4
US 5
US 10
US 10B
An ASSA ABLOY Group company
Euro Finishes
11
13
20
23
47
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Antique Brass
Satin Bronze
Dark Oxidized Bronze
85
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts Ordering Information
Model No.
V6000
Finish
605
Backset
#3 – 2-3/8" backset or
Bolt
Type
F
Security
Program
C2L
Form
SUB
Keyway
95-100
#8 – 2-3/4" backset
Contact
Customer
Service
Department
For Keyway
Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Deadbolts:
Specify
Model
No.
Finish
Backset
Bolt
Type
Security
Program
Form
Keyway
Example:....V6000 ....605........2-3/8"...................................................F ..............C2L .............SUB .........95-100
BacksetBolt Type
F - Face Plate
D - Drive-In
86
An ASSA ABLOY Group company
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts Exploded View
Outside Cylinder
Tailpiece
Tailpiece Screw
Pin Chamber Closing Screws
Outside Cylinder Shell
Cylinder Plug
Tailpiece Washer
Security Balls
Inside Cylinder
Tailpiece Screw
Tailpiece
Pin Chamber Closing Screws
Inside Cylinder Shell
Cylinder Plug
Tailpiece Washer
An ASSA ABLOY Group company
87
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts
6000 Series Deadbolt
6000 Series Grade 1 Deadbolt Locks
Model #
Description
Comp
Sub
SNS
V6000
Single cylinder w/thumbturn
V6000DC
Double cylinder
V6000NT
Single cylinder no thumbturn
V6000LB
Single cylinder less bolt
V6000DCLB
Double cylinder less bolt
Twin Exclusive
155.00
206.50
137.50
108.50
160.50
146.00
197.50
130.00
101.00
146.00
141.00
189.00
123.00
94.00
131.50
E6000
Single cylinder w/thumbturn
E6000DC
Double cylinder
E6000NT
Single cylinder no thumbturn
E6000LB
Single cylinder less bolt
E6000DCLB
Double cylinder less bolt
Twin 6000 Classic
155.00
206.50
137.50
108.50
160.50
146.00
197.50
130.00
101.00
146.00
141.00
189.00
123.00
94.00
131.50
6000
6000DC
6000NT
6000LB
6000DCLB
197.00
256.00
156.00
124.00
183.00
187.00
238.00
147.00
114.00
165.00
179.00
220.00
138.00
106.00
147.00
Comp
Sub
SNS
6100
Single cylinder w/thumbturn
Double cylinder
6100DC
6100NT
Single cylinder no thumbturn
6100LB
Single cylinder less bolt
Double cylinder less bolt
6100DCLB
Twin Maximum
155.00
206.50
137.50
108.50
160.50
146.00
197.50
130.00
101.00
146.00
141.00
189.00
123.00
94.00
131.50
Single cylinder w/thumbturn
Double cylinder
Single cylinder no thumbturn
Single cylinder less bolt
Double cylinder less bolt
155.00
206.50
137.50
108.50
160.50
146.00
197.50
130.00
101.00
146.00
141.00
189.00
123.00
94.00
131.50
Twin V-10
Single cylinder w/thumbturn
Double cylinder
Single cylinder no thumbturn
Single cylinder less bolt
Double cylinder less bolt
6000 Series Grade 1 Deadbolt Locks
Model #
Description
Twin Pro
8800
8800DC
8800NT
8800LB
8800DCLB
For extra thick doors of 2" – 2-1/2", please suffix model numbers with -ET.
Example:....V6000-ET ...605 ......2-3/8" backset ..............F...........C2L ......Sub ......95-100
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8800 x CLIQ x 626 x Sidebar x Comp
88
An ASSA ABLOY Group company
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts
600 Series Grade 1 Deadbolt Locks
Model #
Description
Comp
Sub
—
197.00
256.00
156.00
124.00
183.00
187.00
238.00
147.00
114.00
165.00
—
—
—
—
—
Comp
Sub
SNS
600 Series Classic
600
600DC
600NT
600LB
600DCLB
Single cylinder w/thumbturn
Double cylinder
Single cylinder no thumbturn
Single cylinder less bolt
Double cylinder less bolt
6000 Series Grade 1 Deadbolt Locks Interchangeable Core
Model #
Description
Twin V-10
V6000IC
Single cylinder IC
V6000ICLC
Double cylinder IC w/thumbturn less core
V6000DCIC
Double cylinder IC
V6000DCICLC Double cylinder IC less core
Twin Exclusive
180.00 172.50 165.50
123.50
—
—
280.00 265.00 256.50
151.50
—
—
E6000IC
Single cylinder IC
E6000ICLC
Double cylinder IC w/thumbturn less core
E6000DCIC
Double cylinder IC
E6000DCICLC Double cylinder IC less core
Twin 6000 Classic
180.00 172.50 165.50
123.50
—
—
280.00 265.00 256.50
151.50
—
—
6000IC
6000ICLC
6000DCIC
6000DCICLC
212.00 202.00 194.00
146.00
—
—
305.00 286.00 276.00
179.00
—
—
Single cylinder IC
Double cylinder IC w/thumbturn less core
Double cylinder IC
Double cylinder IC less core
6000 Series Grade 1 Deadbolt Locks Interchangeable Core
Model #
Description
Comp
Sub
SNS
Twin Pro
6100IC
Single cylinder IC
6100ICLC
Double cylinder IC w/thumbturn less core
6100DCIC
Double cylinder IC
6100DCICLC
Double cylinder IC less core
Twin Maximum
180.00 172.50 165.50
123.50
—
—
280.00 265.00 256.50
151.50
—
—
8800IC
8800ICLC
8800DCIC
8800DCICLC
180.00 172.50 165.50
123.50
—
—
280.00 265.00 256.50
151.50
—
—
Single cylinder IC
Double cylinder IC w/thumbturn less core
Double cylinder IC
Double cylinder IC less core
For extra thick doors of 2" – 2-1/2", please suffix model numbers with -ET.
Example:....V6000-ET ...605 ......2-3/8" backset ..............F...........C2L ......Sub ......95-100
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8800IC x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
89
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts
Inside
Outside
BD
HD
HT
BL
6000 Series Deadbolt Cylinders Only
Model #
Description
HT
BL
BD
HD
Comp
Sub
SNS
Outside cylinder
Inside cylinder
Inside & Outside cylinder
Outside IC cylinder
Inside IC cylinder
Inside & Outside IC cylinder
Outside IC cylinder less core
Inside IC cylinder less core
Inside & Outside IC cylinder less core
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
105.00
105.00
198.00
173.00
173.00
333.00
82.50
82.50
165.00
97.50
97.50
183.00
165.50
165.50
318.50
—
—
—
90.50
90.50
169.00
158.50
158.50
304.00
—
—
—
Outside cylinder
Inside cylinder
Inside & Outside cylinder
Outside IC cylinder
Inside IC cylinder
Inside & Outside IC cylinder
Outside IC cylinder less core
Inside IC cylinder less core
Inside & Outside IC cylinder less core
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
105.00
105.00
198.00
173.00
173.00
333.00
82.50
82.50
165.00
97.50
97.50
183.00
165.50
165.50
318.50
—
—
—
90.50
90.50
169.00
158.50
158.50
304.00
—
—
—
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
120.00
120.00
226.00
203.50
203.50
392.50
97.00
97.00
194.00
111.00
111.00
217.00
193.50
193.50
374.50
—
—
—
102.00
102.00
190.00
185.50
185.50
356.50
—
—
—
Twin V-10
V65811
V65812
V65813
V65811IC
V65812IC
V65813IC
V65811ICLC
V65812ICLC
V65813ICLC
Twin Exclusive
E65811
E65812
E65813
E65811IC
E65812IC
E65813IC
E65811ICLC
E65812ICLC
E65813ICLC
Twin 6000 Classic
65811
65812
65813
65811IC
65812IC
65813IC
65811ICLC
65812ICLC
65813ICLC
Outside cylinder
Inside cylinder
Inside & Outside cylinder
Outside IC cylinder
Inside IC cylinder
Inside & Outside IC cylinder
Outside IC cylinder less core
Inside IC cylinder less core
Inside & Outside IC cylinder less core
For extra thick doors of 2" – 2-1/2", please suffix model numbers with -ET.
Example:....V65811-ET.....605 ......2-3/8" backset............F...........C2L ......Sub ......95-100
90
An ASSA ABLOY Group company
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts
Inside
Outside
BD
HD
HT
BL
6000 Series Deadbolt Cylinders Only
Model #
Description
HT
BL
BD
HD
Comp
Sub
SNS
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
105.00
105.00
198.00
173.00
173.00
333.00
82.50
82.50
165.00
97.50
97.50
183.00
165.50
165.50
318.50
—
—
—
90.50
90.50
169.00
158.50
158.50
304.00
—
—
—
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.323
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
0.920
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.440
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
1.572
105.00
105.00
198.00
173.00
173.00
333.00
82.50
82.50
165.00
97.50
97.50
183.00
165.50
165.50
318.50
—
—
—
90.50
90.50
169.00
158.50
158.50
304.00
—
—
—
HT
BL
BD
HD
Comp
Sub
SNS
0.323
0.323
0.323
0.920
0.920
0.920
1.440
1.440
1.440
Twin Pro
6181
6182
6183
6181IC
6182IC
6183IC
6181ICLC
6182ICLC
6183ICLC
Outside cylinder
Inside cylinder
Inside & Outside cylinder
Outside IC cylinder
Inside IC cylinder
Inside & Outside IC cylinder
Outside IC cylinder less core
Inside IC cylinder less core
Inside & Outside IC cylinder less core
Twin Maximum
8881
8882
8883
8881IC
8882IC
8883IC
8881ICLC
8882ICLC
8883ICLC
Outside cylinder
Inside cylinder
Inside & Outside cylinder
Outside IC cylinder
Inside IC cylinder
Inside & Outside IC cylinder
Outside IC cylinder less core
Inside IC cylinder less core
Inside & Outside IC cylinder less core
600 Series Deadbolt Cylinders Only
Model #
Description
600 Series Classic
6811
6812
6813
Outside cylinder
Inside cylinder
Inside & Outside cylinder
1.572 114.00 105.00
1.572 114.00 105.00
1.572 215.00 196.00
—
—
—
For extra thick doors of 2" – 2-1/2", please suffix model numbers with -ET.
Example:....6181-ET .........605 ......2-3/8" backset............F...........C2L ......Sub ......95-100
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8881 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
91
ASSA Deadbolts
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Deadbolts Component Parts
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
Cylinder and Thumbturn Cap
Ball Bearing Insert
Cylinder (DC) Mounting Bolts (2-1/4")
Inside Cylinder
Cylinder Ring
Faceplate Bolt
Wood/Metal Combination Screws
Screws for Hardhat
Hardhat
Outside Cylinder
Deadbolts Parts
Model No.
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
352323
352324
352326
353969
356071
816068
442774
907001
907002
907003
907004
907005
907007
907008
806263
352325
806265
806266
806266NT
806256
806267
806269
806268
806270
806346
806483
867046
867090
806262
867109
907015
907010
907011
907012
907013
907016
907035
Description
Price
Outside Cylinder Shell
Inside Cylinder Shell
Thumbturn
Twin V-10 Cylinder Plug
Twin Exclusive Cylinder Plug
Twin Pro / Twin Maximum Cylinder Plug†
Deadbolt Bolt Faceplate
2-3/4" Faceplate Bolt
2-3/4" Drive-In Bolt
2-3/8" Faceplate Bolt
2-3/8" Drive-In Bolt
Strike Plate with Screws
Reinforced Strike Box and Screws
Security Bolt Guard Plate
Thumbturn Tailpiece bushing
Thumbturn Housing Only
Thumbturn Spindle
Cylinder Thumbturn Cap
Cylinder Cap, No Thumbturn
IC Cylinder and Thumbturn Cap
Cylinder Ring
Adapter Ring 2-1/8" Side Hole
Spacer Ring 1-3/8" Door
Thumbturn Ring
Pin Chamber Closing Screws
Thumbturn Set Screws
Tailpiece Washer
Tailpiece Screw
Tailpiece
Tailpiece for Special Door Thickness
Security Balls for Single & Double Cylinder
Deadbolt Mounting Bolts (Std. Single Cyl.)
Deadbolt Mounting Bolts (Std. Double cyl.)
Deadbolt mounting Bolts (3")
Deadbolt Mounting Bolts (3-1/4")
Deadbolt Strike Box Screw
Deadbolt Chamber Screw Wrench
34.00
30.00
34.50
27.00
27.00
27.00
76.00
76.00
76.00
76.00
76.00
14.50
17.50
3.00
2.75
33.00
22.50
2.25
4.50
4.50
29.50
18.50
23.00
26.00
.75
1.00
3.50
1.00
2.00
6.00
1.00
1.00
1.25
1.75
2.50
.75
.75
* – Indicates Finished Components.
† – Specify Profile 0P4 for Twin Pro or 0M7 for Twin Maximum.
92
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
ASSA’s auxiliary lock line brings the same level
of patented key control and durability to cam
locks, window locks, drawer and desk locks,
and tube locks that are standard for all of
our high security products. All of our
auxiliary locks can be keyed into an
existing or new master key system and are
operated by the same 6 pin uniquely side
coded keys as the rest of our high security
line eliminating the need for maintaining
separate key systems.
Benefits:
•
•
•
•
•
•
All locks operated by the same high security key
Unlimited number of applications
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Can be easily rekeyed in the field
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Technical Information:
• Cylinder housing and plug made of high quality brass
• Stainless steel top pins
• Bottom pins and master pins are nickel silver
An ASSA ABLOY Group company
93
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Cam Locks
ASSA manufactures the most rugged high security cam
locks on the market today. The sturdy design makes
it perfect for inner safe doors and compartments,
cash storage containers, drug carts, gun cabinets,
alarm control panels, and key storage cabinets.
ASSA cam locks are operated with the same ASSA
6 pin high security key as the rest of our product
offering and are available in both key retaining and
non-key retaining models.
Benefits:
•
•
•
•
•
•
Operated by 6 pin high security key
Available in key retaining and non-key retaining
31 different catches available
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• UL 437 (Pending)
Technical Information:
•
•
•
•
•
Installation prep 22 mm, 7/8" Double "D" (punch available from ASSA)
Uses hollowed out interchangeable core drivers
Body and plug chromium plated brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
94
U.S. Symbol
US 26
An ASSA ABLOY Group company
Euro Finish
11
Description
Bright Chrome
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Utility Locks
This is truly an innovative lock assembly. A rugged
cast aluminum housing and strike assembly holds
a solid brass six pin high security cylinder. ASSA
Utility Locks are used to secure sliding glass or
wood doors, storage cabinets, and windows.
They can be keyed into any ASSA key system or used
as a stand alone locking device. The body is finished with
baked on white enamel. This assembly locks with just one push of
your thumb or finger, as easy as locking a file cabinet. The Utility Lock comes
with all of its own mounting hardware for standard wood frame applications
and shims for uneven surfaces.
Benefits:
•
•
•
•
6 pin high security cylinder
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive "false" grooves on side pins designed to catch picking tools
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• UL 437 (Pending)
Technical Information:
•
•
•
•
•
Cast aluminum housing
Cast aluminum rim and mortise strike
Cylinder body and plug high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
An ASSA ABLOY Group company
95
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Cabinet Locks
ASSA manufactures the finest quality cabinet
and desk locks featuring our high security
eleven pin cylinders. These locks are listed
with Underwriters Laboratories as U.L. 437.
Our cabinet and desk locks can be keyed into
any ASSA master key system. The cylinder can
be easily rekeyed by removing the setscrew on
the side of the cylinder housing.
Benefits:
•
•
•
•
•
700AS – 138
850AS – 078
ASSA U.L. 437 high security cylinder
Setscrew for easy rekeying
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive “false” grooves on side pins designed to catch picking tools
Patented key control
800AS – 138
850AS – 138
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Cabinet/Drawer lock cylinders are U.L. 437 listed
Technical Information:
•
•
•
•
•
•
Available with plastic spacer and strike
Cabinet lock available with horizontal or vertical bolt
Desk lock available in 7/8" and 1-3/8" mounting thickness
Bolt material high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
626
605
96
U.S. Symbol
US 26D
US 3
An ASSA ABLOY Group company
Euro Finishes
13
20
Description
Satin Chrome
Bright Brass
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Keyswitch Locks
The ASSA Switch Lock is the newest addition to our family
of high security products. Combining state-of-the-art
Securitron® designed electronic technology with the
versatility of an ASSA high security non-key retaining
cam lock, this product is the key switch of the future.
The switch lock is fully reversible from maintained to
momentary and can be integrated into any new or
existing ASSA master key system.
Benefits:
•
•
•
•
•
•
Long operating life
Elongated mounting hole for easier, more accurate mounting
Choice of actuation (plunger as well as a variety of integral and auxiliary actuators)
Choice of electrical termination (solder, quick connect, PCB)
Available with standard or narrow stile mounting plate with LED
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Technical Information:
• Single pull double throw (SPDT) pin actuator and solder
termination standard
• 3 amp at 12 or 24 VDC
• Uses hollowed out interchangeable core drivers
• Body and plug chromium plated brass
• Stainless steel top pins
• Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
626
U.S. Symbol
US 26D
An ASSA ABLOY Group company
Euro Finishes
13
Description
Satin Chrome
97
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks Ordering Information
Model No.
Finish
Program
Security
Form
V700AS-138
605
C2L
Sub
Keyway
95-200
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Auxiliary Locks:
Specify
Model
No.
Security
Program
Form
Keyway
Example:....V6571 ..................C2L.......................SUB .........................95-100
98
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks Exploded Views
Tube Locks
Outer Wall
Interior Wall
Cam Locks
Cover Slide
Stop
Washer
Shell
Plug
Key Retained
Cover Slide
Shell
Stop
Washer
Plug
Pins
Non-Key Retained
An ASSA ABLOY Group company
99
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks Exploded Views
Utility Locks
Bottom Plate
For Strike Plate
Bottom Plate
For Stop Plate
Spring & Pin
Strike Plate
Press Cylinder
Covers
Screws
Lock Case
Switch Locks
ASSA Cam Lock
Key & Cylinder
Pin Insert
Compression Spring
Switch Actuator Cam
Micro Switch
& Housing Unit
100
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
Tube Lock
Model No.
Description
Comp
Sub
SNS
Twin V-10
V65617
Wall Tube Lock
Twin Exclusive
121.50 114.00 107.00
E65617
Wall Tube Lock
Twin 6000 Classic
121.50 114.00 107.00
65617
Twin Pro
Wall Tube Lock
137.50 128.50 119.50
61617
Wall Tube Lock
Twin Maximum
121.50 114.00 107.00
88617
121.50 114.00 107.00
Wall Tube Lock
B
F
B
F
D
D
A
C
C
E
E
Cam Locks
Model
Description
A
B
C
D
E
F
Comp
Sub
SNS
V6571
Key Retaining Cam Lock 90°
1.025
V7571
Non-Key Retaining Cam Lock 360° 1.025
Twin Exclusive
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
43.50
48.50
35.75
40.75
29.00
34.00
E6571
Key Retaining Cam Lock 90°
1.025
Non-Key Retaining Cam Lock 360° 1.025
E7571
Twin 6000 Classic
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
43.50
48.50
35.75
40.75
29.00
34.00
Key Retaining Cam Lock 90°
6571
1.025
7571
Non-Key Retaining Cam Lock 360° 1.025
Twin Pro
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
51.00
57.00
41.00
47.00
32.00
39.00
6171
Key Retaining Cam Lock 90°
1.025
7171
Non-Key Retaining Cam Lock 360° 1.025
Twin Maximum
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
43.50
48.50
35.75
40.75
29.00
34.00
8871
Key Retaining Cam Lock 90°
1.025
8872
Non-Key Retaining Cam Lock 360° 1.025
Twin Maximum Medium Security
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
43.50
48.50
35.75
40.75
29.00
34.00
Key Retaining Cam Lock 90°
1.025
Non-Key Retaining Cam Lock 360° 1.025
0.980
0.980
0.110
0.150
1.070
1.510
1.490
1.865
0.860
0.860
36.00
40.00
30.00
33.50
24.00
28.00
Twin V-10
2871
2872
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8871 x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
101
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
C
A
E
B
D
Utility Locks
Model No.
Description
A
B
C
D
E
Comp
Sub
SNS
Utility Lock
0.970
0.460
1.345
0.670
1.115
59.50
51.75
45.00
Utility Lock
0.970
0.460
1.345
0.670
1.115
59.50
51.75
45.00
Utility Lock
0.970
0.460
1.345
0.670
1.115
67.00
58.00
49.00
Utility Lock
0.970
0.460
1.345
0.670
1.115
59.50
51.75
45.00
0.970
0.460
1.345
0.670
1.115
59.50
51.75
45.00
Twin V-10
V7680
Twin Exclusive
E7680
Twin 6000 Classic
7680
Twin Pro
6180
Twin Maximum
8880
102
Utility Lock
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
A
E
B
C
D
Cabinet Locks
Model No.
Description
A
B
C
D
1-3/8" Door Lock
1-3/8" Drawer Lock
7/8" Deadlocking Latch
1-3/8" Deadlocking Latch
1.010
1.010
1.000
1.010
1.120
1.120
1.120
1.120
1.420
1.420
1.185
1.420
0.515
0.515
0.635
0.515
1-3/8" Door Lock
1-3/8" Drawer Lock
7/8" Deadlocking Latch
1-3/8" Deadlocking Latch
1.010
1.010
1.000
1.010
1.120
1.120
1.120
1.120
1.420
1.420
1.185
1.420
1-3/8" Door Lock
1-3/8" Drawer Lock
7/8" Deadlocking Latch
1-3/8" Deadlocking Latch
1.010
1.010
1.000
1.010
1.120
1.120
1.120
1.120
1-3/8" Door Lock
1-3/8" Drawer Lock
7/8" Deadlocking Latch
1-3/8" Deadlocking Latch
1.010
1.010
1.000
1.010
1-3/8" Door Lock
1-3/8" Drawer Lock
7/8" Deadlocking Latch
1-3/8" Deadlocking Latch
1.010
1.010
1.000
1.010
E
Comp
Sub
SNS
0.965 83.00
0.965 83.00
0.320 100.00
0.965 102.00
75.25
75.25
92.25
94.25
68.50
68.50
85.50
87.50
0.515
0.515
0.635
0.515
0.965 83.00
0.965 83.00
0.320 100.00
0.965 102.00
75.25
75.25
92.25
94.25
68.50
68.50
85.50
87.50
1.420
1.420
1.185
1.420
0.515
0.515
0.635
0.515
0.965 93.50 84.50
0.965 93.50 84.50
0.320 113.50 103.50
0.965 115.50 105.50
75.50
75.50
95.50
97.50
1.120
1.120
1.120
1.120
1.420
1.420
1.185
1.420
0.515
0.515
0.635
0.515
0.965 83.00
0.965 83.00
0.320 100.00
0.965 102.00
75.25
75.25
92.25
94.25
68.50
68.50
85.50
87.50
1.120
1.120
1.120
1.120
1.420
1.420
1.185
1.420
0.515
0.515
0.635
0.515
0.965 83.00
0.965 83.00
0.320 100.00
0.965 102.00
75.25
75.25
92.25
94.25
68.50
68.50
85.50
87.50
Twin V-10
V700AS-138*
V800AS-138*
V850AS-078*
V850AS-138*
Twin Exclusive
E700AS-138*
E800AS-138*
E850AS-078*
E850AS-138*
Twin 6000 Classic
700AS-138*
800AS-138*
850AS-078*
850AS-138*
Twin Pro
61700AS-138*
61800AS-138*
61850AS-078*
61850AS-138*
Twin Maximum
88700AS-138*
88800AS-138*
88850AS-078*
88850AS-138*
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88700AS-138 x CLIQ x 626 x Sidebar x Comp
* Indicate product finish, Cabinet locks are available in 605 & 626 only.
An ASSA ABLOY Group company
103
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
B
A
Keyswitches With Single Gang Plate
Model No.
Description
A
B
Comp
Sub
SNS
Twin V-10
V7700
V7771
Single Gang Plate Bi/LED Momentary
Single Gang Plate Bi/LED On/Off
2.75
2.75
4.50 196.00 188.50 181.50
4.50 196.00 188.50 181.50
Single Gang Plate Bi/LED Momentary
Single Gang Plate Bi/LED On/Off
2.75
2.75
4.50 196.00 188.50 181.50
4.50 196.00 188.50 181.50
Single Gang Plate Bi/LED Momentary
Single Gang Plate Bi/LED On/Off
2.75
2.75
4.50 222.50 213.50 204.50
4.50 222.50 213.50 204.50
Single Gang Plate Bi/LED Momentary
Single Gang Plate Bi/LED On/Off
2.75
2.75
4.50 196.00 188.50 181.50
4.50 196.00 188.50 181.50
2.75
2.75
4.50 196.00 188.50 181.50
4.50 196.00 188.50 181.50
Twin Exclusive
E7700
E7771
Twin 6000 Classic
7700
7771
Twin Pro
6700
6771
Twin Maximum
8870-SG
8871-SG
Single Gang Plate Bi/LED Momentary
Single Gang Plate Bi/LED On/Off
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8870-SG x CLIQ x 626 x Sidebar x Comp
104
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
B
A
Keyswitches With Narrow Stile Plate
Model No.
Description
A
B
Comp
Sub
SNS
Twin V-10
V7700-N
V7771-N
Narrow Stile Plate Bi/LED Momentary
Narrow Stile Plate Bi/LED On/Off
1.75
1.75
4.50 178.50 171.00 164.00
4.50 178.50 171.00 164.00
Narrow Stile Plate Bi/LED Momentary
Narrow Stile Plate Bi/LED On/Off
1.75
1.75
4.50 178.50 171.00 164.00
4.50 178.50 171.00 164.00
Narrow Stile Plate Bi/LED Momentary
Narrow Stile Plate Bi/LED On/Off
1.75
1.75
4.50 222.50 213.50 204.50
4.50 222.50 213.50 204.50
Narrow Stile Plate Bi/LED Momentary
Narrow Stile Plate Bi/LED On/Off
1.75
1.75
4.50 178.50 171.00 164.00
4.50 178.50 171.00 164.00
1.75
1.75
4.50 178.50 171.00 164.00
4.50 178.50 171.00 164.00
Twin Exclusive
E7700-N
E7771-N
Twin 6000 Classic
7700-N
7771-N
Twin Pro
6700-N
6771-N
Twin Maximum
8870-N
8871-N
Narrow Stile Plate Bi/LED Momentary
Narrow Stile Plate Bi/LED On/Off
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8870-N x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
105
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
B
A
Mortise Keyswitches With Single Gang Plate
Model No.
Description
A
B
Comp
Sub
SNS
Twin V-10
V6551MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
V6551MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
V6551MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
V6551MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
E6551MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
E6551MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
E6551MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
E6551MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
Twin Exclusive
Twin 6000 Classic
6551MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
6551MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
6551MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
6551MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
6151MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
6151MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
6151MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
6151MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
Twin Pro
Twin Maximum
8851MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
8851MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
8851MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
8851MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
Twin Maximum - Medium Security
2851MKS*
Single Gang Plate Mortise Bi/LED with One SPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
2851MKSA*
Single Gang Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
2851MKS2*
Single Gang Plate Mortise Bi/LED with One DPDT Momentary Switch
2.75
4.50
212.50
203.00
196.00
2851MKS2A*
Single Gang Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
2.75
4.50
212.50
203.00
196.00
* Mortise Keyswitch assemblies can take up to two switches and are supplied with one switch. All switches are listed on page 108.
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851 MKS x CLIQ x 626 x Sidebar x Comp
106
An ASSA ABLOY Group company
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
B
A
Mortise Keyswitches With Narrow Stile Plate
Model No.
Description
A
B
Comp
Sub
SNS
Twin V-10
V6551MKS-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
V6551MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
V6551MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
V6551MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
E6551MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
E6551MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
E6551MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
Twin Exclusive
E6551MKS-N*
Twin 6000 Classic
6551MKS-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
6551MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
6551MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
6551MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
6151MKS-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
6151MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
6151MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
6151MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
8851MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
8851MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
8851MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
Twin Pro
Twin Maximum
8851MKS-N*
Twin Maximum - Medium Security
2851MKS-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
2851MKSA-N*
Narrow Stile Plate Mortise Bi/LED with One SPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
2851MKS2-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Momentary Switch
1.75
4.50
212.50
203.00
196.00
2851MKS2A-N*
Narrow Stile Plate Mortise Bi/LED with One DPDT Alternate - On/Off Switch
1.75
4.50
212.50
203.00
196.00
* Mortise Keyswitch assemblies can take up to two switches and are supplied with one switch. All switches are listed on page 108.
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8851 MKS-N x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
107
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
Switch Assembly
Switch Position
for 90° Clockwise
(3 O’clock Activation)
Optional/Additional
Switch Position
for 90°
Counter-Clockwise
(9 O’clock Activation)
Or: 180° Individual
CW-CCW
(9 & 3 O’clock
Activation)
Switch
(Momentary/Alternate)
SPTD: 3-Wire (As Shown)
DPDT: 6-Wire (As Shown x 2 Pole Sets)
Optional Switches for Mortise Switch Plates
108
Model No.
Description
ASMKS
ASMKSA
ASMKS2
ASMKS2A
SPDT Momentary
SPDT Alternate (ON/OFF)
DPDT Momentary
DPDT Alternate (ON/OFF)
An ASSA ABLOY Group company
A
B
Comp
NA
NA
NA
NA
NA
NA
NA
NA
43.00
43.00
71.50
71.50
Sub
NA
NA
NA
NA
SNS
NA
NA
NA
NA
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
B
A
C
C
NC
E
NO
D
Keyswitches
Model No.
Description
A
B
C
D
E
Comp
Sub
SNS
Keyswitch Switch Momentary
Keyswitch Switch On/Off
1.025
1.025
0.980
0.980
0.110
0.110
1.510
1.510
0.860 144.50 137.00 130.00
0.860 144.50 137.00 130.00
Keyswitch Switch Momentary
Keyswitch Switch On/Off
1.025
1.025
0.980
0.980
0.110
0.110
1.510
1.510
0.860 144.50 137.00 130.00
0.860 144.50 137.00 130.00
Keyswitch Switch Momentary
Keyswitch Switch On/Off
1.025
1.025
0.980
0.980
0.110
0.110
1.510
1.510
0.860 164.00 155.00 146.00
0.860 164.00 155.00 146.00
Keyswitch Switch Momentary
Keyswitch Switch On/Off
1.025
1.025
0.980
0.980
0.110
0.110
1.510
1.510
0.860 144.50 137.00 130.00
0.860 144.50 137.00 130.00
1.025
1.025
0.980
0.980
0.110
0.110
1.510
1.510
0.860 144.50 137.00 130.00
0.860 144.50 137.00 130.00
Twin V-10
V7700-LP
V7771-LP
Twin Exclusive
E7700-LP
E7771-LP
Twin 6000 Classic
7700-LP
7771-LP
Twin Pro
6700-LP
6771-LP
Twin Maximum
8870-LP
8871-LP
Keyswitch Switch Momentary
Keyswitch Switch On/Off
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 8870-LP x CLIQ x 626 x Sidebar x Comp
An ASSA ABLOY Group company
109
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
Cam Lock Catches
22
All measurements are in millimeters, to convert to inches multiply millimeters x .039370.
22
38
20
20
3
20
390040
390041
14
24
3
8.5
20
3
390042
390043
30.5
28
14
3
20
390056
12
30
3
20
390055
20
13
12
28
3
3
20
14
390069
21
12.5
41
30
3
8.5
20
20
490847
20
390070
3
6
50
20
490827
490800
15
39
14
30
3
3
20
490880
49
3
13
8.5
20
3
390068
390062
390061
20.5
3
20
3
8.5
20
50
3
26
38
20
390058
3
8.5
20
390045
30
13
21.5
33.5
390044
3
390054
33.5
21.5
3
20
3
30.5
3
8.5
20
21.5
38
3
13
20
490890
490907
3
20
490842
15
25
3
1
20
11
3
8.5
20
490926
3
5
490963
15.5
15
34
38
3
20
20
490972
3
3
3
13
20
490973
16
491210
20
491221
10
14
24
3
4
20
491317
3
16.5
14
28
36
3
10.5
20
491331
15
41
20
3
6.5
491498
CLP-D
Cam Lock Accessories
110
Model No.
Description
See Above
CLK-1
CLP-D
Cam Lock Catches
Cam Lock Catch Kit (Includes 2 ea. of 31 Cam Catches)
7/8" Double D Cam Lock/Switch Lock Punch
An ASSA ABLOY Group company
Price
1.50
90.00
402.00
ASSA Auxiliary Locks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Auxiliary Locks
Cam Lock Accessories
All measurements are in millimeters, to convert to inches multiply millimeters x .039370.
34
34
Ø4.5(4x)
24
58
18
Ø4(4x)
24
48
58
Ø22
24
48
58
18
34
48
58
Ø22
1
Ø22
1.5
18
2
Fixing Plate 491449
Fixing Plate 490825
Ø22
18
2
Front Plate 490821
Front Plate 491450
18
Ø34
15°
Ø22
Ø30
77
18 Ø34
Ø22
M22x1
7
Dust Cap 391053
18
Ø26
Cylinder Ring 490271
Ø22
.75
6
Ø22
1
3
Front Plate 490657
Housing Washer 490663
Nail Plate 491299
15°
NV 15
NV 15
15°
Ø11
M 22x1
18 Ø34
Ø11
3.5
NV 26
4.5
Nut
491439
2
Ø22
Front Plate 497008
8
0.5
0.5
Lock Washer
490246
8
2
Nut
490583
Housing Nut 490610
6.5
.2 ± 0.
±0
6
16 Ø1
Ø
M11x1
M11x1
Cam Lock Accessories
Model No.
Description
490271
391053
490825
491449
497008
490657
490821
491450
490246
491299
490583
491439
490610
490663
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Cam
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
Lock
cylinder ring
dust cap
fixing plate
fixing plate
front plate
front plate
front plate
front plate
washer
nail plate
nut
nut (m11x1)
housing nut (m22x1)
housing washer
An ASSA ABLOY Group company
Price
6.00
2.50
2.00
2.00
3.50
3.50
3.50
3.50
.75
1.00
1.50
1.50
2.00
4.00
111
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
ASSA manufactures high security padlocks
in three classes, all of which can be
integrated into any new or existing
ASSA master key system. Our heavy
duty padlocks are made from the
highest quality materials and have
withstood the most rigorous testing
procedures. ASSA padlocks are used
in a wide variety of applications
including storage rooms, perimeter
fences, and armories and feature
the same level of patented key control
as all ASSA high security cylinders.
Benefits:
•
•
•
•
•
•
•
Sturdy design ensures maximum durability
Class 2 available in key retaining and non-key retaining, extended shackle, and interchangeable core
Shackle made of rust proof stainless steel
Hockey Puck style shackleless design provides maximum protection against hacksaw and bolt cutter attacks
Drain holes to prevent freezing
No external screws or rivets
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Padlock cylinders are U.L. 437 listed
Technical Information:
•
•
•
•
•
•
112
Class 2 body extruded brass, stainless steel shackle, tensile strength 1.5 tons
Class 3 body case hardened steel, stainless steel shackle, tensile strength 4.5 tons
Class 2 convertible from key retaining to non-key retaining
Hockey Puck style body can withstand up to 10,000 lbs of force from bolt cutters
Stainless steel top pins
Bottom pins and master pins are nickel silver
An ASSA ABLOY Group company
ASSA Padocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks Ordering Information
Model No.
Program
Security
Form
V65191B
C2R
Sub
Keyway
95-200
Contact Customer
Service Department
For Keyway Numbers.
General Information
Page 3.
Catalog Page.
General Information
Page 3.
How To Order Padlocks:
Specify
Model
No.
Security
Program
Form
Keyway
Example:....V65191B .................C2R ...................SUB...................95-100
An ASSA ABLOY Group company
113
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks Exploded Views
#2 Padlock
Screw
Ball
Shackle
Blocking Plate
Cylinder Plug
Spring
Blocking Pin
Ball
#2 Shrouded Padlock
Bar
Spring
Plug
Cylinder Plug
Blocking Pin
Spring
Screw
Pin
Follower
Blocking Plate
114
An ASSA ABLOY Group company
ASSA Padocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks Exploded Views
#3 Padlock
Screw
Shackle
Balls
Cylinder Plug
Blocking Pin
Blocking Plate
#4-5 Padlock
Bar
Plug
Spring
Blocking Pin
Cylinder Plug
Spring
Screw
Pin
Follower
An ASSA ABLOY Group company
Blocking Plate
115
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
D
C
B
#2
A
#2
Extended
Shackle
#2
Shrouded
#3
#4-5
Shrouded
Padlocks
Model No.
Description
A
B
C
D
Comp
Sub
SNS
Twin V-10
V65190B
V65190LB
V65190SB
V65191B
V65191LB
V65391B
V65391SB
V65591SB
No.2
No.2
No.2
No.2
No.2
No.3
No.3
No.5
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
Key Ret. w/Shrouded Shackle
Key Ret. w/Shrouded Shackle
1.900
1.900
1.900
1.900
1.900
2.450
2.450
3.150
1.100
2.035
0.535
1.100
2.035
1.235
0.710
0.985
0.940
0.940
0.475
0.940
0.940
1.295
0.590
0.830
0.315
0.315
0.315
0.315
0.315
0.395
0.395
0.550
88.00 80.50 73.50
94.00 86.50 79.50
102.00 95.00 88.00
88.00 80.50 73.50
94.00 86.50 79.50
162.00 154.50 147.50
169.00 161.50 154.50
283.00 275.50 268.50
No.2
No.2
No.2
No.2
No.2
No.3
No.3
No.5
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
Key Ret. w/Shrouded Shackle
Key Ret. w/Shrouded Shackle
1.900
1.900
1.900
1.900
1.900
2.450
2.450
3.150
1.100
2.035
0.535
1.100
2.035
1.235
0.710
0.985
0.940
0.940
0.475
0.940
0.940
1.295
0.590
0.830
0.315
0.315
0.315
0.315
0.315
0.395
0.395
0.550
88.00 80.50 73.50
94.00 86.50 79.50
102.00 95.00 88.00
88.00 80.50 73.50
94.00 86.50 79.50
162.00 154.50 147.50
169.00 161.50 154.50
283.00 275.50 268.50
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
Key Ret. w/Shrouded Shackle
Key Ret. w/Shrouded Shackle
1.900
1.900
1.900
1.900
1.900
2.450
2.450
3.150
1.100
2.035
0.535
1.100
2.035
1.235
0.710
0.985
0.940
0.940
0.475
0.940
0.940
1.295
0.590
0.830
0.315
0.315
0.315
0.315
0.315
0.395
0.395
0.550
103.00
110.00
120.00
103.00
110.00
184.00
192.50
322.00
Twin Exclusive
E65190B
E65190LB
E65190SB
E65191B
E65191LB
E65391B
E65391SB
E65591SB
Twin 6000 Classic
65190B
65190LB
65190SB
65191B
65191LB
65391B
65391SB
65591SB
116
No.2
No.2
No.2
No.2
No.2
No.3
No.3
No.5
An ASSA ABLOY Group company
94.00
101.00
111.00
94.00
101.00
175.00
185.00
314.50
85.00
92.00
102.00
85.00
92.00
166.00
178.00
307.50
ASSA Padocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
D
C
B
#2
A
#2
Extended
Shackle
#2
Shrouded
#3
#4-5
Shrouded
Padlocks
Model No.
Description
A
B
C
D
Comp
Sub
SNS
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
Key Ret. w/Shrouded Shackle
Key Ret. w/Shrouded Shackle
1.900
1.900
1.900
1.900
1.900
2.450
2.450
3.150
1.100
2.035
0.535
1.100
2.035
1.235
0.710
0.985
0.940
0.940
0.475
0.940
0.940
1.295
0.590
0.830
0.315
0.315
0.315
0.315
0.315
0.395
0.395
0.550
88.00 80.50 73.50
94.00 86.50 79.50
102.00 95.00 88.00
88.00 80.50 73.50
94.00 86.50 79.50
162.00 154.50 147.50
169.00 161.50 154.50
283.00 275.50 268.50
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
Key Ret. w/Shrouded Shackle
Key Ret. w/Shrouded Shackle
1.900
1.900
1.900
1.900
1.900
2.450
2.450
3.150
1.100
2.035
0.535
1.100
2.035
1.235
0.710
0.985
0.940
0.940
0.475
0.940
0.940
1.295
0.590
0.830
0.315
0.315
0.315
0.315
0.315
0.395
0.395
0.550
88.00 80.50 73.50
94.00 86.50 79.50
102.00 95.00 88.00
88.00 80.50 73.50
94.00 86.50 79.50
162.00 154.50 147.50
169.00 161.50 154.50
283.00 275.50 268.50
Non-Key-Retaining
Non-Key-Retaining Ext. Shackle
Non-Key-Ret. w/Shrouded Shackle
Key-Retaining
Key-Retaining Ext. Shackle
Key-Retaining
1.900
1.900
1.900
1.900
1.900
2.450
1.100
2.035
0.535
1.100
2.035
1.235
0.940
0.940
0.475
0.940
0.940
1.295
0.315
0.315
0.315
0.315
0.315
0.395
103.00
110.00
120.00
103.00
110.00
184.00
Twin Pro
61190B
61190LB
61190SB
61191B
61191LB
61391B
61391SB
61591SB
No.2
No.2
No.2
No.2
No.2
No.3
No.3
No.5
Twin Maximum
88190B
88190LB
88190SB
88191B
88191LB
88391B
88391SB
88591SB
No.2
No.2
No.2
No.2
No.2
No.3
No.3
No.5
600 Series Classic
6190B
6190LB
6190SB
6191B
6191LB
6391B
No.2
No.2
No.2
No.2
No.2
No.3
94.00
101.00
111.00
94.00
101.00
175.00
—
—
—
—
—
—
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88190B x CLIQ x Comp
An ASSA ABLOY Group company
117
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
D
C
B
#2
A
#2
Extended
Shackle
#2
Shrouded
#3
#4-5
Shrouded
Interchangeable Core Padlocks
Model No.
Description
A
B
C
D
Comp
Sub
SNS
No.2 Key-Retaining IC
No.2 Key-Retaining Ext. Shackle IC
1.900
1.900
1.100
2.035
0.940
0.940
0.315 110.00 102.50 95.50
0.315 120.50 113.00 106.00
No.2 Key-Retaining IC
No.2 Key-Retaining Ext. Shackle IC
1.900
1.900
1.100
2.035
0.940
0.940
0.315 110.00 102.50 95.50
0.315 120.50 113.00 106.00
No.2 Key-Retaining IC
No.2 Key-Retaining Ext. Shackle IC
1.900
1.900
1.100
2.035
0.940
0.940
0.315 129.00 120.00 111.00
0.315 142.00 132.00 124.00
No.2 Key-Retaining, IC
No.2 Key-Retaining Ext. Shackle, IC
1.900
1.900
1.100
2.035
0.940
0.940
0.315 110.00 102.50 95.50
0.315 120.50 113.00 106.00
1.900
1.900
1.100
2.035
0.940
0.940
0.315 110.00 102.50 95.50
0.315 120.50 113.00 106.00
Twin V-10
V65191BIC
V65191LBIC
Twin Exclusive
E65191BIC
E65191LBIC
Twin 6000 Classic
65191BIC
65191LBIC
Twin Pro
61191BIC
61191LBIC
Twin Maximum
88191BIC
88191LBIC
No.2 Key-Retaining, IC
No.2 Key-Retaining Ext. Shackle, IC
Padlock Cylinders Only
Model No.
Description
Comp
Sub
SNS
Padlock Cylinder No. 2, 3, 4-5
59.00
51.50
44.50
Padlock Cylinder No. 2, 3, 4-5
59.00
51.50
44.50
Padlock Cylinder No. 2, 3, 4-5
66.00
57.00
48.00
Padlock Cylinder No. 2, 3, 4-5
59.00
51.50
44.50
59.00
51.50
44.50
66.00
57.00
—
Twin V-10
V65911
Twin Exclusive
E65911
Twin 6000 Classic
65911
Twin Pro
61911
Twin Maximum
88911
Padlock Cylinder No. 2, 3, 4-5
600 Series Classic
6911
Padlock Cylinder No. 2, 3, 4-5
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88911 x CLIQ x Comp
118
An ASSA ABLOY Group company
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks
A
“Hockey Puck” Shackle Less Padlock
Model No.
Description
A
Comp
Sub
SNS
Hockey Puck Style Padlock
2.875
89.50
81.00
74.50
Hockey Puck Style Padlock
2.875
89.50
81.00
74.50
Hockey Puck Style Padlock
2.875
89.50
81.00
74.50
2.875
89.50
81.00
74.50
Description
Comp
Sub
SNS
Hockey Puck Cylinder
56.50
49.00
42.00
Hockey Puck Cylinder
56.50
49.00
42.00
Hockey Puck Cylinder
56.50
49.00
42.00
56.50
49.00
42.00
Twin V-10
V6540
Twin Exclusive
E6540
Twin Pro
6140
Twin Maximum
8840
Hockey Puck Style Padlock
“Hockey Puck” Cylinders Only
Model No.
Twin V-10
V65411
Twin Exclusive
E65411
Twin Pro
61411
Twin Maximum
88411
Hockey Puck Cylinder
– Twin Maximum available with CLIQ™ Technology, add $500.00. Example: 88911 x CLIQ x Comp
An ASSA ABLOY Group company
119
ASSA Padlocks
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Padlocks Component Parts
Padlocks Parts
120
Model No.
Description
Price
806898
807217
P250517
806910
809387
809388
P793810
867046
P857300
803607
P793110
806913
803575
806911
353969
367018
No.2 Regular Shackle
No.2 Extended Shackle
No.2 Shackle Spring
No.3 Padlock Shackle
No.2 Key-Retaining Blocking pin
No.2 Non-Key-Retaining Blocking Pin/Spring/Tailpiece
No.2 Tailpiece Cam Screws
No.2 Tailpiece Washer
No.2 Plate & No. 3 Plate
No.2 Locking Balls
No.2 Cylinder Retaining Screw
No.3 Cylinder Retaining Screw
No.3 Locking Ball Bearings
No.3 Blocking Pin
Twin V-10 Padlock Cylinder Plug
Twin Exclusive/6000 Classic Padlock Cylinder Plug (Specify Profile)
21.00
23.00
.75
25.00
3.50
24.00
.75
3.50
.50
.50
.75
4.50
1.25
17.50
26.00
26.00
An ASSA ABLOY Group company
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
ASSA manufactures a wide variety of high security European style profile
cylinders including the Scandinavian oval cylinder used in ASSA modular
locksets, the Euro Din cylinder, and the British Oval cylinder.
Available for different door thicknesses and featuring
an adjustable cam actuator, ASSA profile cylinders can
be used with many types of imported
lockset and specialty hardware.
All profile cylinders are protected
with ASSA’s patented key control and
can be keyed into any new or existing
ASSA key system.
Benefits:
•
•
•
•
•
Retrofits wide variety of European applications
Adjustable cam actuator
Two independent locking mechanisms to ensure security and optimum pick resistance
Inactive "false" grooves on side pins designed to catch picking tools
Patented key control
Warranty:
• ASSA guarantees its products against defective workmanship or wear resulting from defects for life
Certification:
• All ASSA Profile Cylinders are U.L. 437 listed
Technical Information:
•
•
•
•
Euro Din and British Oval available for 3 different door thicknesses
Cylinder housing and plug made of high quality brass
Stainless steel top pins
Bottom pins and master pins are nickel silver
Finishes:
BHMA Symbol
625
626
605
606
612
624
U.S. Symbol
US 26
US 26D
US 3
US 4
US 10
US 10B
An ASSA ABLOY Group company
Euro Finishes
11
13
20
23
33
46
Description
Bright Chrome
Satin Chrome
Bright Brass
Satin Brass
Satin Bronze
Dark Oxidized Bronze
121
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders Ordering Information
Model No.
V6531
Finish
605
Form
COMP
Door Thickness
61
Cam Position
1
Keyway
95-200
Contact
Customer
Service
Department
For Keyway
Numbers.
Catalog Page.
General Information
Page 3.
General Information
Page 4.
How To Order Profile Cylinders:
Specify
Model No.
Finish
Form
Door Thickness
Cam Position
Keyway
Example: ..........V6531 ..........605............Comp ....................61 ...............................1............................95-200
How To Determine Cam Position:
.8
.8
.1
.7
.8
.1
.2
.7
.6
.5
.5
.4
.4
22.5
V6531/V6534
.3
.5
An ASSA ABLOY Group company
.3
.4
22.5
V6523/V6533
V6521/V6524
Twin Pro available through special order.
British Oval and Euro Din Cylinders are available in 626 and 605 finish only.
122
.6
45°
22.5
V6522/V6532
.2
.5
.4
45°
.7
.2
.6
.3
.1
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders Exploded View
6531 – Large Thumbturn Model
6534 – Small Thumbturn Model
Large Thumbturn
Cylinder Plug
Small Thumbturn
Cylinder Shell
Circlip
Cam Piece
6532 – Double Cylinder Model
Cylinder Plug
Cylinder Plug
Cylinder Shell
Circlip
Cam Piece
An ASSA ABLOY Group company
Clutch
123
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders Exploded View
6533 – Single Cylinder Model
Cylinder Plug
Cylinder Shell
Circlip
Cam Piece
Oval Cylinders
Screws
Cam Piece
Cylinder Plug
& Shell
124
An ASSA ABLOY Group company
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Profile Cylinder Key:
TL – Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
TL
A
B
C
British Oval Profile Cylinders
Model No.
Description
TL
A
B
C
Comp
Sub
SNS
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single Cyl.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
3.481
3.875
4.269
3.481
3.875
4.269
2.418
2.812
3.206
1.595
1.794
1.990
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
0.398
0.398
0.398
1.063
1.063
1.063
1.063
1.063
1.063
N/A
N/A
N/A
N/A
N/A
N/A
112.00
112.00
112.00
100.00
100.00
100.00
124.50
124.50
124.50
100.00
100.00
100.00
105.00
105.00
105.00
93.00
93.00
93.00
117.00
117.00
117.00
93.00
93.00
93.00
100.00
100.00
100.00
88.00
88.00
88.00
112.50
112.50
112.50
88.00
88.00
88.00
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single Cyl.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
3.481
3.875
4.269
3.481
3.875
4.269
2.418
2.812
3.206
1.595
1.794
1.990
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
0.398
0.398
0.398
1.063
1.063
1.063
1.063
1.063
1.063
N/A
N/A
N/A
N/A
N/A
N/A
112.00
112.00
112.00
100.00
100.00
100.00
124.50
124.50
124.50
100.00
100.00
100.00
105.00
105.00
105.00
93.00
93.00
93.00
117.00
117.00
117.00
93.00
93.00
93.00
100.00
100.00
100.00
88.00
88.00
88.00
112.50
112.50
112.50
88.00
88.00
88.00
Twin V-10
V6531
V6531
V6531
V6534
V6534
V6534
V6532
V6532
V6532
V6533
V6533
V6533
Twin Exclusive
E6531
E6531
E6531
E6534
E6534
E6534
E6532
E6532
E6532
E6533
E6533
E6533
An ASSA ABLOY Group company
125
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Profile Cylinder Key:
TL – Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
TL
A
B
C
British Oval Profile Cylinders
Model No.
Description
TL
A
B
C
Comp
Sub
SNS
3.481
3.875
4.269
3.481
3.875
4.269
2.418
2.812
3.206
1.595
1.794
1.990
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
0.398
0.398
0.398
1.063
1.063
1.063
1.063
1.063
1.063
N/A
N/A
N/A
N/A
N/A
N/A
128.00
128.00
128.00
112.50
112.50
112.50
142.00
142.00
142.00
112.50
112.50
112.50
119.00
119.00
119.00
104.50
104.50
104.50
133.00
133.00
133.00
104.50
104.50
104.50
113.00
113.00
113.00
98.50
98.50
98.50
127.00
127.00
127.00
95.50
95.50
95.50
3.481
3.875
4.269
3.481
3.875
4.269
2.418
2.812
3.206
1.595
1.794
1.990
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
1.209
1.406
1.603
0.398
0.398
0.398
1.063
1.063
1.063
1.063
1.063
1.063
N/A
N/A
N/A
N/A
N/A
N/A
122.00
122.00
122.00
107.00
107.00
107.00
135.00
135.00
135.00
107.00
107.00
107.00
113.00
113.00
113.00
99.00
99.00
99.00
126.00
126.00
126.00
99.00
99.00
99.00
—
—
—
—
—
—
—
—
—
—
—
—
Twin 6000 Classic
6531
6531
6531
6534
6534
6534
6532
6532
6532
6533
6533
6533
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single Cyl.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
600 Series Classic
631
631
631
634
634
634
632
632
632
633
633
633
126
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single Cyl.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
An ASSA ABLOY Group company
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Profile Cylinder Key:
TL – Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
TL
A
B
C
Din Euro Profile Cylinders
Model No.
Description
TL
A
B
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single CyL.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
3.470
3.864
4.258
3.480
3.864
4.258
4.420
2.814
3.208
1.571
1.768
1.965
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
1.203
1.400
1.597
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
0.368
0.368
0.368
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single CyL.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
3.470
3.864
4.258
3.480
3.864
4.258
4.420
2.814
3.208
1.571
1.768
1.965
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
1.203
1.400
1.597
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
0.368
0.368
0.368
C
Comp
Sub
SNS
1.050 98.50
1.050 98.50
1.050 98.50
1.065 97.50
1.065 97.50
1.065 97.50
N/A 107.00
N/A 107.00
N/A 107.00
68.00
N/A
68.00
N/A
68.00
N/A
89.00
89.00
89.00
88.00
88.00
88.00
98.00
98.00
98.00
59.00
59.00
59.00
84.00
84.00
84.00
83.00
83.00
83.00
92.50
92.50
92.50
54.00
54.00
54.00
1.050 98.50
1.050 98.50
1.050 98.50
1.065 97.50
1.065 97.50
1.065 97.50
N/A 107.00
N/A 107.00
N/A 107.00
68.00
N/A
68.00
N/A
68.00
N/A
89.00
89.00
89.00
88.00
88.00
88.00
98.00
98.00
98.00
59.00
59.00
59.00
84.00
84.00
84.00
83.00
83.00
83.00
92.50
92.50
92.50
54.00
54.00
54.00
Twin V-10
V6521
V6521
V6521
V6524
V6524
V6524
V6522
V6522
V6522
V6523
V6523
V6523
Twin Exclusive
E6521
E6521
E6521
E6524
E6524
E6524
E6522
E6522
E6522
E6523
E6523
E6523
An ASSA ABLOY Group company
127
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
Profile Cylinder Key:
TL – Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
TL
A
B
C
Din Euro Profile Cylinders
Model No.
Description
TL
A
B
C
Comp
Sub
SNS
3.470
3.864
4.258
3.480
3.864
4.258
4.420
2.814
3.208
1.571
1.768
1.965
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
1.203
1.400
1.597
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
0.368
0.368
0.368
1.050
1.050
1.050
1.065
1.065
1.065
N/A
N/A
N/A
N/A
N/A
N/A
106.00 95.00
106.00 95.00
106.00 95.00
105.00 94.00
105.00 94.00
105.00 94.00
116.00 105.00
116.00 105.00
116.00 105.00
74.00 62.00
74.00 62.00
74.00 62.00
89.00
89.00
89.00
87.00
87.00
87.00
99.00
99.00
99.00
56.00
56.00
56.00
3.470
3.864
4.258
3.480
3.864
4.258
4.420
2.814
3.208
1.571
1.768
1.965
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
1.203
1.400
1.597
1.210
1.407
1.604
1.210
1.407
1.604
1.210
1.407
1.604
0.368
0.368
0.368
1.050
1.050
1.050
1.065
1.065
1.065
N/A
N/A
N/A
N/A
N/A
N/A
106.00 95.00
106.00 95.00
106.00 95.00
105.00 94.00
105.00 94.00
105.00 94.00
116.00 105.00
116.00 105.00
116.00 105.00
74.00 62.00
74.00 62.00
74.00 62.00
—
—
—
—
—
—
—
—
—
—
—
—
Twin 6000 Classic
6521
6521
6521
6524
6524
6524
6522
6522
6522
6523
6523
6523
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single CyL.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
600 Series Classic
621
621
621
624
624
624
622
622
622
623
623
623
128
61mm Large Single Cyl.
71mm Large Single Cyl.
81mm Large Single Cyl.
61mm Small Single Cyl.
71mm Small Single CyL.
81mm Small Single Cyl.
61mm Double Cylinder
71mm Double Cylinder
81mm Double Cylinder
40.5mm Single Cylinder
45.5mm Single Cylinder
50.5mm Single Cylinder
An ASSA ABLOY Group company
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Oval Cylinders
Profile Cylinder Key:
TL – Total Length
A – Cylinder Length
B – Cylinder Height
C – Cylinder Width
TL
TL
TL
B
A
B
C
A
B
C
6501
A
6502
C
6503
Oval Cylinders
Model No.
Description
TL
A
B
C
Comp
Sub
SNS
Twin V-10
V6501
V6501L
V6502
V6503
Oval,
Oval,
Oval,
Oval,
Outside
Outside for 505
Double
Inside
1.577
1.577
N/A
1.577
1.236
1.236
1.236
1.236
1.376
1.376
1.376
1.376
0.784 92.00 84.50 77.00
0.784 101.00 93.00 86.00
0.784 198.00 182.50 168.00
0.784 98.50 90.50 83.50
Oval,
Oval,
Oval,
Oval,
Outside
Outside for 505
Double
Inside
1.577
1.577
N/A
1.577
1.236
1.236
1.236
1.236
1.376
1.376
1.376
1.376
0.784 92.00 84.50 77.00
0.784 101.00 93.00 86.00
0.784 198.00 182.50 168.00
0.784 98.50 90.50 83.50
Outside
Outside for 505
Double
Inside
1.577
1.577
N/A
1.577
1.236
1.236
1.236
1.236
1.376
1.376
1.376
1.376
0.784 99.00 90.00 81.00
0.784 109.00 99.00 91.00
0.784 215.00 196.00 179.00
0.784 106.00 97.00 88.00
Outside
Outside for 505
Double
Inside
1.577
1.577
N/A
1.577
1.236
1.236
1.236
1.236
1.376
1.376
1.376
1.376
0.784 99.00 90.00
0.784 109.00 99.00
0.784 215.00 196.00
0.784 106.00 97.00
Twin Exclusive
E6501
E6501L
E6502
E6503
Twin 6000 Classic
6501
6501L
6502
6503
Oval,
Oval,
Oval,
Oval,
600 Series Classic
601
601L
602
603
Oval,
Oval,
Oval,
Oval,
—
—
—
—
NOTE: Oval cylinders do not include cylinder rings, mounting screws or other trim.
An ASSA ABLOY Group company
129
ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Oval Cylinders
Profile Cylinder Key:
TL – Total Length
A – Cylinder Length
B – Cylinder Height
C – Cylinder Width
TL
TL
TL
B
A
B
C
6501
A
B
C
6502
A
C
6503
Oval Cylinder Parts
Model No.
Description
Price
Oval Cyl. Housing, Outside
Oval Cyl. Housing, Inside
Oval Cylinder Plug
23.00
37.50
27.00
Twin V-10
867064
867110
353969
Twin Exclusive/6000 Classic
867064
867110
367018
Oval Cyl. Housing, Outside
Oval Cyl. Housing, Inside
Oval Cylinder Plug (Specify Profile)
23.00
37.50
27.00
Oval Cylinder Adapters
ASSA cylinder adapters allow the use of the Schlage KIK/KIL cylinder with ASSA mortise locks without having
to replace existing master key system.
130
Model No.
Description
Price
803170
803171
804215
Oval Outside Cylinder Adapter, for Schlage KIK/KIL Cylinder
Oval Inside Cylinder Adapter, for Schlage KIK/KIL Cylinder
Schlage Adapter Tailpiece (Will fit 505 function)
59.00
59.00
9.00
An ASSA ABLOY Group company
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Pin Kits, Tools & Accessories
ASSA provides all the necessary tools for both
the retail and institutional locksmith to service
and maintain our locks in the field. We offer
several sizes of pinning kits from large,
full service kits designed for the shop
environment to smaller, convenient kits
appropriate for service calls. Also available are
high quality key cutting equipment, all approved
ASSA cylinder lubricants, and various state-of-the-art
key management and master key software programs
for both single site and network applications.
An ASSA ABLOY Group company
131
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Interchangeable Core Parts
.047"
1.2mm
.071"
1.8mm
T2
809328
.142"
3.6mm
.118"
3.0mm
.094"
2.4mm
.165"
4.2mm
.189"
4.8mm
.213"
5.4mm
.236"
6.0mm
T3
T4
T5
T6
T7
T8
T9
T10
809329
809330
809331
809332
809333
809334
809335
809336
.213"
5.4mm
.236"
6.0mm
.260"
6.6mm
.283"
7.2mm
.307"
7.8mm
.331"
8.4mm
.354"
9.0mm
.378"
9.6mm
.402"
10.2mm
M9
M10
M11
M12
M13
M14
M15
M16
T17
809314
809315
809316
809317
809318
809319
809320
809321
809322
Interchangeable Core Parts
Model No.
Description
Price
354023
353213
353968
807401
807402
807403
807404
807405
810695
807411
809340
809312
Control Sleeve
IC Inner Plug*
V-10 IC Inner Plug*
IC C-Ring
IC Cover Slide
IC Cam Adapter
IC Wave Washer
IC Rubber Stop
IC Core (Figure-8) Housing*
IC Mortise/Rim Housing*
IC Cylinder Springs (1st Four Chambers)
IC Plug Spacer Washer
32.50
30.00
22.50
.50
1.00
22.00
1.00
1.25
49.50
55.00
20.00/c
.75
Top Pins For Interchangeable Core Cylinders Only
Model No.
Description
809328
809329
809330
809331
809332
809333
809334
809335
809336
Top
Top
Top
Top
Top
Top
Top
Top
Top
Pin
Pin
Pin
Pin
Pin
Pin
Pin
Pin
Pin
#2
#3
#4
#5
#6
#7
#8
#9
#10
Package Quantity
100
100
100
100
100
100
100
100
100
Price
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
Master Pins For Interchangeable Core Cylinders Only
Model No.
Description
809314
809315
809316
809317
809318
809319
809320
809321
809322
Master
Master
Master
Master
Master
Master
Master
Master
Master
Pin
Pin
Pin
Pin
Pin
Pin
Pin
Pin
Pin
*Indicate product finish.
132
An ASSA ABLOY Group company
#9
#10
#11
#12
#13
#14
#15
#16
#17
Package Quantity
100
100
100
100
100
100
100
100
100
Price
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
21.00/c
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Pins, Springs & Closers
Pins, Springs & Closers
Model No.
Description
Package Quantity
867066/807261
867067/807262
867068/807263
867069/807264
867070
867071
867072
867073
867074
867075
867076
867077
867078
867079
867080
867081
867082
867083
867084
867085
867086
867065
*267008
867015
353838
816080
807164
807165
867087
867088
868141
867093
806346
Driver Pin 1-2
Driver Pin 3-4
Driver Pin 5-6
Driver Pin 7-8-9
Master Pin 1
Master Pin 2
Master Pin 3
Master Pin 4
Master Pin 5
Master Pin 6
Master Pin 7
Master Pin 8
Bottom Pin 1
Bottom Pin 2
Bottom Pin 3
Bottom Pin 4
Bottom Pin 5
Bottom Pin 6
Bottom Pin 7
Bottom Pin 8
Bottom Pin 9
Cylinder Springs
V-10, Twin 6000, & Twin Exclusive Sidebar
Twin Side Pins
V-10 Left Hand Side Pins
Twin Pro Side Pins
V-10/Twin Pro Sidebar Springs
V-10/Twin Pro Sidepin Springs
Twin Sidepin Springs
Twin Sidebar Springs
Pin Chamber Closing Strips, Mort, Rim, KIK
Closing Plugs, Oval Cylinders
Pin Chamber Closing Screws - Jumbo, Mogul, Dbolt
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
25
50
50
100
100
100
100
100
100
100
100
Price
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
25.00/c
7.50/ea
44.50/c
44.50/c
90.00/c
14.00/c
14.00/c
14.00/c
14.00/c
52.00/c
56.00/c
56.00/c
*Specify Code
An ASSA ABLOY Group company
133
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO
Cams & Tailpieces
Cam Key:
R-A – Head Radius • R-B – Overall Radius
Tailpieces
H/V
#1
#2
#3
#4
#5
#9
#10
#11
#12
#13
#6
#7
#14
#15
#8
L
Cams & Tailpieces
134
Model #
Description
867445
867452
867446
867447
872610
867453
805412
806471
907306
353445
809337
354945
355849
355850
872612
867450
867451
868958
868959
868960
804877
868654
868624
868231
900250
900251
900252
900253
900254
900256
900257
867045
803169
867046
867090
868138
868134
867109
868136
868135
#1 Adams Rite Cam
#2 Sargent Cam
#3 Corbin Clover Leaf Cam
#4 Corbin Beaver Tail Cam
#5 Yale/Standard Cam
#6 Schlage “L” Cam
#7 Segal Type Cam
#8 Jumbo Corbin Cam
#9 Best 30H Series
#10 Airteq/Norment Cam
#11 Airteq/Norment Mogul Cam
#12 Corbin Jumbo Clover Leaf Cam
#13 Sargent Short Cam
#14 Sargent Mogul
#15 Yale Replacement Cam
Horizontal & Vertical Rim Tailpiece kit
Lazy-motion Rim Tailpiece kit
Schlage KIK Plug Cap
Schlage KIK Plug Cap Spring
Schlage KIK Plug Cap Pin
Schlage Break-off Tailpiece
Corbin New Style Standard-duty Tailpiece
Rollpin - Corbin
Cylinder Plug Retaining Ring
Sargent 6-line, Arrow Tailpiece (short)
Sargent 6-line, Arrow Tailpiece (long)
Sargent 6-line, Arrow Tailpiece retaining ring
Sargent/Arrow Tailpiece (Med.)
Sargent 11-line T-Zone Tailpiece
Yale Key-In-Lever Tailpiece
Yale Key-In-Lever Roll Pin
Oval Cylinder Tailpiece
Oval Cylinder Tailpiece, 505 Lock Function
Tailpiece Washer
Phillips Screws for Cams, Mortise & Oval Tailpiece
Slotted Screws for Rim Tailpiece
Tail Extension for Rim Cylinder
Break-off Tailpiece for V/H Rim Cylinder
Lazy Motion Tailpiece for Rim Cylinder
Lazy Motion Tailpiece Washer
An ASSA ABLOY Group company
R-A
R-B
Package Qty.
Price
0.118
N/A
0.114
N/A
N/A
0.124
N/A
N/A
0.114
N/A
N/A
0.114
N/A
N/A
0.742
0.555
0.709
0.602
0.732
0.709
0.516
0.779
0.914
0.602
0.787
1.165
0.828
0.515
1.043
0.308
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
4.50/ea
4.50/ea
4.50/ea
4.50/ea
4.50/ea
10.50/ea
10.50/ea
10.50/ea
10.50/ea
5.00/ea
10.50/ea
10.50/ea
10.50/ea
10.50/ea
10.50/ea
16.50/ea
16.50/ea
2.25/ea
.50/ea
.25/ea
4.25/ea
2.00/ea
.25/ea
.50/ea
2.25/ea
2.25/ea
.50/ea
1.75/ea
4.25/ea
6.00/ea
2.00/ea
3.00/ea
7.50
3.50/ea
1.00/ea
.75/ea
8.00
6.00
5.75
3.50
10
100
100
10
100
10
100
50
50
100
100
ASSA Pin Kits, Tools & Accessories
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO
Pin Kits & Tools
Automatic Code Machine
PS6000A
Positive Stop Code Machine
PS6000T
Pin Kits & Tools
Model No.
Description
PK-1
PK-4
PK-IC
PK-MM
PK-CAM
MPK
MKP
MKP2000/XP
MKSV
KWZ-S*
KWZ-N*
KWZ-D
KWZ-I*
869018
869017
867056
KXASDC
KXASSC
KXAS01
KXAS02
KXAS03
KXAS04
F2SH050A
969020
807718
816296
802631
P872630
V872630
PS-6000T
PS-6000A
907200
907205
907206
907207
907208
907009
SGTRCTOOL
Pin Kit No.1 Full-Size Standard Kit for Twin
Pin Kit No.4 Mini Pin Kit for Twin
Pin Kit-Interchangeable Core Upgrade
Micro Mini Pin Kit
PK Cam Lock Upgrade
Master Pinning Kit Twin & IC
Master Key Program
Master Key Program 2000/XP
ASSA Master Key System Viewer
Key Wizard Key Records Mgmt. Software Single Sight Version
Key Wizard Key Records Mgmt. Software Network Version
Key Wizard Key Records Mgmt. Software Working Demo
Key Wizard Import File for ASSA System
Twin & V-10 Cutter Wheel for HPC 1200 CM90˚/.032"
Twin & V-10 Framon Cutter Wheel
Cutter Wheel for PS-7000R
Depth Cam for KX-1 ASSA
Space Cam for KX-1 ASSA
Cam Set for KX-1
Cam Set Plus Vise
Cam Set Plus Cutter
Cam Set (Cutter Vise)
ASSA Vise
Twin & V-10 Code Card for HPC 1200CM
ASSA Lock Spray Petroleum Lubricant
ASSA Lock Spray Cleaner/De-Icer
ASSA Lock Spray Dry Film Lubricant
ASSA Twin Pro Mortise Cylinder Cutaway
ASSA Twin V-10 Mortise Cylinder Cutaway
Positive Stop Code Key Machine
Automatic Code Machine (Computer required, not supplied)
PK-1 Pin Kit Box Only
PK-IC Pin Kit Box IC Only
MPK Pin Kit Box Only
Micro Mini Pin Kit Box Only
Pin Kit Cam Lock Upgrade Box Only
Clear Deadbolt Mounting Ring
Shearing Tool for Sargent style Interchangeable Core
Price
647.00
273.50
587.00
141.00
96.00
1,153.50
932.00
932.00
786.00
825.00
995.00
Contact your local ASSA Rep.
274.00
360.50
297.50
418.00
121.50
121.50
244.00
421.00
547.00
724.00
191.50
33.50
14.00/ea
14.00/ea
14.00/ea
159.00
159.00
4,892.50
12,566.00
131.00
131.00
171.00
56.50
53.00
14.00
275.00
* Key wizard software is invoiced at Book Net.
An ASSA ABLOY Group company
135
ASSA Care & Maintenance
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Care & Maintenance for ASSA Cylinders & Keys
ASSA products are the highest quality cylinder
products on the market today. The following
information for maintaining proper condition
of your ASSA cylinders and keys will insure
the best performance for you and your clients.
Make sure that all key cutting equipment is
properly calibrated in accordance to ASSA manufacturer specification.
This is the first consideration in the proper performance of ASSA cylinders.
Periodically inspect keys in use and replace any keys that show physical wear.
ASSA cylinders are a mechanical device and like any mechanical device they need
regular preventive maintenance. At the time of installation cylinders must be
lubricated with ASSA approved lubricant. Wipe off any excess lubricant on
exposed surfaces. Cleaning and lubricating the lock mechanism that the ASSA
cylinder is being installed into is important as well. ASSA cylinders should be
lubricated at least twice a year as normal maintenance.
• Do not use graphite or silicone lubricants. Use only ASSA approved lubricants.
• Do not expose ASSA cylinders to chemical wash.
• Do not paint any cylinder surfaces.
Do not over lubricate ASSA cylinders. If you suspect cylinder has been over lubricated or
suspect excessive dirt or other particles or debris, thoroughly flush with ASSA cleaner deicer
or use an alcohol base electrical contact cleaner. Let dry or dry with compressed air then
re-lubricate with ASSA approved lubricant.
As part of the ASSA 5-Way Guarantee
• ASSA will replace any key that breaks under normal use for life.
• ASSA will warranty any ASSA cylinder against manufacture defect for life.
136
An ASSA ABLOY Group company
ASSA Care & Maintenance
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Servicing ASSA Cam Locks
Cover Slide
Cover Slide
Stop
Washer
Shell
Stop
Washer
Shell
Pins
Plug
Plug
Key Retained
Non-Key Retained
ASSA cam locks are serviced with standard Twin bottom and master pins. The tops pins, or drives and springs
used in ASSA cam locks are the hollowed top pins used in the ASSA Interchangeable Core product T-2 through
T-9. The top pin used in each chamber is equal to the total operating stack. A #7 bottom pin uses a T-7 top pin.
For master keying a #5 bottom pin – a #3 master pin equals a total operating stack of 2. The T-2 top pin is used.
Due to stack height restrictions the #1 depth of cut can not be used in ASSA cam locks.
Top Pin #2 – 809328
Top Pin #3 – 809329
Top Pin #4 – 809330
Top Pin #5 – 809331
Top Pin #6 – 809332
Top Pin #7 – 809333
Top Pin #8 – 809334
Top Pin #9 – 809335
Chamber spring – 809335
.047"
1.2mm
T2
809328
.071"
1.8mm
.094"
2.4mm
.118"
3.0mm
.142"
3.6mm
.165"
4.2mm
.189"
4.8mm
.213"
5.4mm
T3
T4
T5
T6
T7
T8
T9
809329
809330
809331
809332
809333
809334
809335
Max 0.905"
0.718"
0.866"
0.875"
0.984"
1.082"
0.875"
1.496"
0.118"
For metal installation use 7/8" double D punch.
An ASSA ABLOY Group company
137
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
250619
250861
250894
267008
352323
352324
352325
352326
353213
353445
353787
353838
353968
353969
353970
353971
353972
353973
353974
353975
353976
353977
353978
353979
353980
353981
353982
353983
353984
353985
353986
354023
354051
354945
354993
355849
355850
356071
356955
356956
356957
356958
356959
356960
356961
356962
Description
Arrow Cylinder Shell
1-1/8" Mogul Cylinder Plug
1-1/2" Mogul Cylinder Plug
V-10, Twin 6000, & Twin Exclusive Sidebar
Outside Cylinder Shell
Inside Cylinder Shell
Thumbturn Housing Only
Thumbturn
IC Inner Plug
#10 Airteq/Norment Cam
Russwin/Corbin 25F65 Cylinder Plug
V-10 Left Hand Side Pins
V-10 IC Inner Plug
Twin V-10 Cylinder Plug
1-1/8" Cylinder Plug
1-1/4" Cylinder Plug
1-3/8" Cylinder Plug
1-1/2" Cylinder Plug
1-5/8" Cylinder Plug
1-3/4" Cylinder Plug
1-7/8" Cylinder Plug
2" Cylinder Plug
Schlage Cylinder Plug
Yale Cylinder Plug – (Must specify KIK or KIL).
Sargent Integra Cylinder Plug
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug
Falcon S & X Series/Weiser Deadbolt Plug
Arrow/Sargent 6-line Cylinder Plug
Russwin/Corbin std. & Heavy-Duty Cylinder Plug
Russwin/Corbin 19F35 Cylinder Plug
Corbin 25F26 Cylinder Plug
Control Sleeve
1-1/8" Mogul Cylinder Shell
#12 Corbin Jumbo Clover Leaf Cam
Cam Adaptor for 1-1/2" Cylinder
#13 Sargent Short Cam
#14 Sargent Mogul
Twin Plug (for profiles 51 & 851)
1-1/8" Cylinder Plug
1-1/4" Cylinder Plug
1-3/8" Cylinder Plug
1-1/2" Cylinder Plug
1-5/8" Cylinder Plug
1-3/4" Cylinder Plug
1-7/8" Cylinder Plug
2" Cylinder Plug
An ASSA ABLOY Group company
Page Number
83, 84
42, 48
43, 48
42, 43, 133
92
92
92
92
132
134
83
133
132
92, 120, 130
38, 56
38
38
38
38
38
38
38
83
83
83
83
83
83
83
83
83
132
42, 48
134
43, 48
134
134
92
39, 56
39
39
39
39
39
39
39
153
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
356982
356983
356984
356985
356986
356987
356988
356989
356990
357672
367018
367019
367020
367021
367022
367023
367024
367025
367026
367068
367069
367073
367074
367156
367159
390040
390041
390042
390043
390044
390045
390054
390055
390056
390058
390061
390062
390068
390069
390070
391053
442774
453978
467068
490246
490271
154
Description
Schlage Cylinder Plug
Yale Cylinder Plug – (Must specify KIK or KIL).
Russwin/Corbin std. & Heavy-Duty Cylinder Plug
Russwin/Corbin 19F35 Cylinder Plug
Corbin 25F26 Cylinder Plug
Russwin/Corbin 25F65 Cylinder Plug
Sargent Integra Cylinder Plug
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug
Arrow/Sargent 6-line Cylinder Plug
1-1/2" Mogul Cylinder Shell
Twin Exclusive Cylinder Plug
1-1/8" Cylinder Plug
1-1/4" Cylinder Plug
1-3/8" Cylinder Plug
1-1/2" Cylinder Plug
1-5/8" Cylinder Plug
1-3/4" Cylinder Plug
1-7/8" Cylinder Plug
2" Cylinder Plug
Schlage Cylinder Plug
Yale Cylinder Plug – (Must specify KIK or KIL).
Sargent Integra Cylinder Plug
Sargent Heavy-Duty 7, 8, 9 Cylinder Plug
Russwin/Corbin Cylinder Shell
Sargent Standard-duty Cylinder Shell
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock dust cap
Deadbolt Bolt Faceplate
Arrow Deadbolt Plug
Arrow Deadbolt Plug
Cam Lock washer
Cam Lock cylinder ring
An ASSA ABLOY Group company
Page Number
84
84
84
84
84
84
84
84
84
43, 48
120, 130
38, 56
38
38
38
38
38
38
38
83
83
83
83
83, 84
83, 84
110
110
110
110
110
110
110
110
110
110
110
110
110
110
110
111
92
83
83
111
111
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
490583
490610
490657
490663
490800
490821
490825
490827
490842
490847
490880
490890
490907
490926
490963
490972
490973
491210
491221
491299
491317
491331
491439
491449
491450
491498
497008
803169
803170
803171
803575
803607
804215
804877
805412
806256
806262
806263
806265
806266
806267
806268
806269
806270
806346
806471
Description
Cam Lock nut
Cam Lock housing nut (m22x1)
Cam Lock front plate
Cam Lock housing washer
Cam Lock Catch
Cam Lock front plate
Cam Lock fixing plate
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock Catch
Cam Lock nail plate
Cam Lock Catch
Cam Lock Catch
Cam Lock nut (m11x1)
Cam Lock fixing plate
Cam Lock front plate
Cam Lock Catch
Cam Lock front plate
Oval Cylinder Tailpiece, 505 Lock Function
Oval Outside Cylinder Adapter, for Schlage KIK/KIL Cylinder
Oval Inside Cylinder Adapter, for Schlage KIK/KIL Cylinder
No.3 Locking Ball Bearings
No.2 Locking Balls
Schlage Adapter Tailpiece (Will fit 505 function)
Schlage Break-off Tailpiece
#7 Segal Type Cam
IC Cylinder and Thumbturn Cap
Tailpiece
Thumbturn Tailpiece bushing
Thumbturn Spindle
Cylinder Thumbturn Cap
Cylinder Ring
Spacer Ring 1-3/8" Door
Adapter Ring 2-1/8" Side Hole
Thumbturn Ring
Pin Chamber Closing Screws - Jumbo, Mogul, Dbolt
#8 Jumbo Corbin Cam
An ASSA ABLOY Group company
Page Number
111
111
111
111
110
111
111
110
110
110
110
110
110
110
110
110
110
110
110
111
110
110
111
111
111
110
111
134
130
130
120
120
130
134
134
92
92
92
92
92
92
92
92
92
42, 43, 92, 133
134
155
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
806483
806898
806910
806911
806913
807164
807165
807217
807401
807402
807403
807404
807405
807411
807987
809312
809314
809315
809316
809317
809318
809319
809320
809321
809322
809328
809329
809330
809331
809332
809333
809334
809335
809336
809337
809339
809340
809387
809388
810695
816068
816080
867015
867045
867046
867064
867065
867070
156
Description
Thumbturn Set Screws
No.2 Regular Shackle
No.3 Padlock Shackle
No.3 Blocking Pin
No.3 Cylinder Retaining Screw
V-10/Twin Pro Sidebar Springs
V-10/Twin Pro Sidepin Springs
No.2 Extended Shackle
IC C-Ring
IC Cover Slide
IC Cam Adapter
IC Wave Washer
IC Rubber Stop
IC Mortise/Rim Housing
Corbin Jumbo 1-1/8" Shell
IC Plug Spacer Washer
Master Pin #9
Master Pin #10
Master Pin #11
Master Pin #12
Master Pin #13
Master Pin #14
Master Pin #15
Master Pin #16
Master Pin #17
Top Pin #2
Top Pin #3
Top Pin #4
Top Pin #5
Top Pin #6
Top Pin #7
Top Pin #8
Top Pin #9
Top Pin #10
#11 Airteq/Norment Mogul Cam
Mogul Cylinder Plug Cover Plate
IC Cylinder Springs (1st Four Chambers)
No.2 Key-Retaining Blocking pin
No.2 Non-Key-Retaining Blocking Pin/Spring/Tailpiece
IC Core (Figure-8) Housing
Twin Pro Cylinder Plug
Twin Pro Side Pins
Twin Side Pins
Oval Cylinder Tailpiece
Tailpiece Washer
Oval Cyl. Housing, Outside
Cylinder Springs
Master Pin 1
An ASSA ABLOY Group company
Page Number
92
120
120
120
120
133
133
120
132
132
132
132
132
132
38, 39, 56
132
132
132
132
132
132
132
132
132
132
132, 137
132, 137
132, 137
132, 137
132, 137
132, 137
132, 137
132, 137
132
42, 134
42, 43, 48
132
120
120
132
92
133
42, 43, 133
134
92, 120, 134
130
133
133, 143
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
867071
867072
867073
867074
867075
867076
867077
867078
867079
867080
867081
867082
867083
867084
867085
867086
867087
867088
867090
867093
867109
867110
867429
867431
867432
867433
867434
867435
867436
867445
867446
867447
867450
867451
867452
867453
868056
868057
868060
868061
868134
868135
868136
868138
868141
868231
868233
868607
Description
Master Pin 2
Master Pin 3
Master Pin 4
Master Pin 5
Master Pin 6
Master Pin 7
Master Pin 8
Bottom Pin 1
Bottom Pin 2
Bottom Pin 3
Bottom Pin 4
Bottom Pin 5
Bottom Pin 6
Bottom Pin 7
Bottom Pin 8
Bottom Pin 9
Twin Sidepin Springs
Twin Sidebar Springs
Phillips Screws for Cams, Mortise & Oval Tailpiece
Closing Plugs, Oval Cylinders
V/H Rim Cylinder Break-off Tailpiece for Special Door Thickness
Oval Cyl. Housing, Inside
1-1/8" Cylinder Shell
1-3/8" Cylinder Shell
1-1/2" Cylinder Shell
1-5/8" Cylinder Shell
1-3/4" Cylinder Shell
1-7/8" Cylinder Shell
2" Cylinder Shell
#1 Adams Rite Cam
#3 Corbin Clover Leaf Cam
#4 Corbin Beaver Tail Cam
Horizontal & Vertical Rim Tailpiece kit
Lazy-motion Rim Tailpiece kit
#2 Sargent Cam
#6 Schlage “L” Cam
Schlage Cylinder Shell
Yale Cylinder Shell
Sargent Integra Cylinder Shell
Sargent Heavy-duty Cylinder Shell
Tail Extension for Rim Cylinder
Lazy Motion Tailpiece Washer
Lazy Motion Tailpiece for Rim Cylinder
Slotted Screws for Rim Tailpiece
Pin Chamber Closing Strips, Mort, Rim, KIK
Cylinder Plug Retaining Ring
Falcon S & X Series/Weiser Deadbolt Plug
Arrow/Sargent 6-line Cylinder Plug
An ASSA ABLOY Group company
Page Number
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133, 143
133
133
42, 43, 92, 134
13
92, 134
130
38, 39, 56
38, 39
38, 39
38, 39
38, 39
38, 39
38, 39
134
134
134
50, 134
50, 134
134
134
83, 84
83, 84
83, 84
83, 84
134
134
134
134
133
134
83
83
157
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
868624
868649
868650
868651
868652
868654
868958
868959
868960
872610
872612
900250
900251
900252
900253
900254
900256
900257
907001
907002
907003
907004
907005
907007
907008
907010
907011
907012
907013
907015
907016
907035
907035
907050
907203
907306
806266NT
867066/807261
867067/807262
867068/807263
867069/807264
92C-114
92C-121
92C-123
92C-127
92C-128
CLK-1
CLP-D
158
Description
Rollpin - Corbin
Russwin/Corbin std. & Heavy-Duty Cylinder Plug
Russwin/Corbin 19F35 Cylinder Plug
Corbin 25F26 Cylinder Plug
Russwin/Corbin 25F65 Cylinder Plug
Corbin New Style Standard-duty Tailpiece
Schlage KIK Plug Cap
Schlage KIK Plug Cap Spring
Schlage KIK Plug Cap Pin
#5 Yale/Standard Cam
#15 Yale Replacement Cam
Sargent 6-line, Arrow Tailpiece (short)
Sargent 6-line, Arrow Tailpiece (long)
Sargent 6-line, Arrow Tailpiece retaining ring
Sargent/Arrow Tailpiece (Med.)
Sargent 11-line T-Zone Tailpiece
Yale Key-In-Lever Tailpiece
Yale Key-In-Lever Roll Pin
2-3/4" Faceplate Bolt
2-3/4" Drive-In Bolt
2-3/8" Faceplate Bolt
2-3/8" Drive-In Bolt
Strike Plate with Screws
Reinforced Strike Box and Screws
Security Bolt Guard Plate
Deadbolt Mounting Bolts (Std. Single Cyl.)
Deadbolt Mounting Bolts (Std. Double cyl.)
Deadbolt mounting Bolts (3")
Deadbolt Mounting Bolts (3-1/4")
Security Balls for Single & Double Cylinder
Deadbolt Strike Box Screw
Mogul Chamber Screw Wrench
Deadbolt Chamber Screw Wrench
Corbin Jumbo Cylinder Thread Adapter
Arrow Deadbolt/Weiser KIK Shell
#9 Best 30H Series
Cylinder Cap, No Thumbturn
Driver Pin 1-2
Driver Pin 3-4
Driver Pin 5-6
Driver Pin 7-8-9
Arrow Deadbolt Cap
Arrow Deadbolt Washer
Arrow Deadbolt Blocking Piece
Arrow Deadbolt Plug Cap Spring
Arrow Deadbolt Plug Cap Pin
Cam Lock Catch Kit (Includes 2 ea. of 31 Cam Catches)
7/8" Double D Cam Lock/Switch Lock Punch
An ASSA ABLOY Group company
Page Number
134
83
83
83
83
134
134
134
134
134
134
134
134
134
134
134
134
134
92
92
92
92
92
92
92
92
92
92
92
92
92
48
92
38
83, 84
134
92
133
133
133
133
83, 84
83, 84
83, 84
83, 84
83, 84
110
110
ASSA Component Parts Index
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Component Parts Index
Model No.
D61-44
D62-44
P250517
P793110
P793810
P857300
Description
Arrow Deadbolt Long Tailpiece (Single Cylinder)
Arrow Deadbolt Short Tailpiece (Double Cylinder)
No.2 Shackle Spring
No.2 Cylinder Retaining Screw
No.2 Tailpiece Cam Screws
No.2 Plate & No. 3 Plate
An ASSA ABLOY Group company
Page Number
83, 84
83, 84
120
120
120
120
159
ASSA, Inc. • 110 Sargent Drive • P.O. Box 9453 • New Haven • CT 06534-0453
Phone: 800-235-7482 • Fax: 800-892-3256 • Website: www.assalock.com
The ASSA ABLOY Group is the world’s leading manufacturer and supplier of locks and associated products,
dedicated to satisfying end-user needs for security, safety and convenience.
An ASSA ABLOY Group company
PB2006
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
