CV-57VA
HDMI over Cat.X Extender
HDMI 2.0(YUV 4:2:0) Extender over Single Cat.X with
HDBaseT-Lite, RS-232, Bi-directional IR & PoC
HDMI over Coaxial Extender
HDMI over Cat.X Splitter
HDMI over Cat.X Repeater
HDMI over Cat.X Receiver
KEY FEATURES
HDMI over Cat.X Matrix
Support HDMI Deep Color & full 3D & [email protected] (HDBaseT technology)
HDMI Splitter
Extend the transmission up to 60m (198ft) from the HDMI source at Full
HDMI Switcher
HD 1080p 48-bit and
HDMI Matrix
40m (130ft) at [email protected]
Support PoC(Power over Cable) which can power both units from TX or RX
side with power supply
HDMI over Optical Extender
HDCP & EDID Bypass
CEC support
HDMI Repeater
Auto equalization
HDMI Pattern Generator
Pure unaltered uncompressed 7.1ch digital HDMI over Cat.5/5e/6 cable
transmission
DTS-HD Master Audio and Dolby TrueHD high bit rate audio support
DVI Series
Support full frequency IR signal from 20KHz to 60KHz
Analog Series
Bi-directional IR path-through
Full Duplex RS-232 control up to 115,200 bps through connector
Wall Plate Series
Wall mounting housing design for easy and robust installation
Converter Series
Video Processor
SDI Series
HD Surveillance
HD Testing Kits
OVERVIEW
The CV-57VA HDMI 2.0 (YUV 4:2:0) Extender over Single Cat.X with HDBaseT-Lite, RS-232, Bi-directional IR & PoC
boosts up your video/audio transmission distance up to 60m (198ft) in HDTV 1080p with 48-bit color depth. CV-57VA also supports the
most advanced 3D video format complaint with HDMI specification and therefore guarantees the highest 3D video compatibility on the
market. With only one cost effective Cat.5/5e/6 cable, users can readily extend HDTV sources from DVD players, Blu-ray Disc player, PS3,
PC, and any other kinds of sources compliant with TMDS to distant display monitors including HDMI or DVI enabled TV sets or LCD PC
Digital Signage Units
monitors. With the advanced design for the latest HDMI technology, deep color video, DTS-HD or Dolby TrueHD audio, and HDCP
supports and compatibility are all further insured. This flexibility makes HDCP compliant DVD players or PS3 transmit utmost high quality
Others
video and audio with a greater distance at the minimal cost, when integrating several components apart. In addition, CV-57VA is also
Discontinued
equipped with bi-directional IR pass-through path and RS-232 serial port control. These bonus features allow users to boost IR control
distance up to 60m (198ft) and makes IR control possible through only single Cat.5/5e/6 cable including HDMI signals. In addition, serial
port offers the convenient path for interactive application, such as touch panels. In addition, CV-57VA also supports PoC (Power over
Cable) which can power both units from TX or RX with power supply.
The CV-57VA includes two units: transmitting unit CV-57VA-TX and receiving unit CV-57VA-RX. The transmitting unit is used to capture
the input HDMI / DVI signals with IR control packets and carry the signals via one cost effective Cat.5/5e/6 cable. The receiving unit is
responsible for equalizing the transmitted HDMI signal and reconstructing IR and serial control signals. CV-57VA offers the most
convenient solution for digital signage with long distance A/V transmission path, and with 10G transmission width ready, CV-57VA is ready
for your next HDMI generation and applications!
