The subject for this next issue is

Digital Electronics.

There will be a story from Ampex on digital recording standards

-a

sub- ject that gets more important to dis- cuss with each passing day.

John Woram is assembling a story based on visits to a new automated re- cording studio in San

Francisco aptly named the Automatt.

Digitally operated automatic loca- tion of a tape will be

A another subject. number of present day systems will be

A detailed. sophisticated digital syncronizer from

BTX is the subject of another article. Learn all about the SMPTE time code and what it can do for you.

The world's first digital tape re- corder directory will appear in this issue.

And there will be articles on micro- processors now available that can do almost everything in your studio and yet cost good almost little more than typewriter. a

All this digitally coming in

No- vember in db, The Sound Engineering

Magazine.

This month's cover shows what one of the first direct -to

-disc sessions looked like.

The illustration is taken from an early issue of Scientific Amer- ican.

For a look at the complete cover see pages

56/57. And don't forget to read our reprint of their cover story, simply titled The appearing on pages

Gramophone and

54/55.

THE

SOUND ENGINEERING MAGAZINE

OCTOBER 1978

VOLUME

12,

NUMBER

10
