Welcome

Our latest catalogue contains all the essential information to help you identify and order the appropriate structured cabling, fiber optics, racks & cabinet products.

This catalogue gives you comprehensive information on each of the products listed. The product tabs on the side of the catalogue helps you to access the product information easily and quickly.

The combination of our innovation and focus on customer needs has made us bring forth many high performing networking products to a very demanding market.

We add new products to our range continuously and recommend you to visit our website www.avalonnetworks.co.uk for the latest information on our new products and changes to our existing products.

Thank you

Network Solutions

Structured Cabling

Racks & Cabinets

Fiber Optic Solutions

Security Solutions

Access Control Solutions

ABOUT AVALON

Avalon brand is a world-class premium performance end-to-end infrastructure solution designed, manufactured, supported and delivered without compromise.

Avalon has used its expertise to build a comprehensive range of high quality copper, fiber optic products like cable rolls, patch cords, patch panels, pigtails (multimode and singlemode), wall and splice boxes and a full range of network racks, switches and accessories to be used in local, wide area networking and telecommunication applications .

We are driven by a team of industry experts, ensuring the latest innovation and manufacturing capabilities are implemented to surpass industry standards for quality, performance, technical compliance and ease of installation and use.

With an emphasis on compatibility and standards compliance ‘from cable to rack’, reliability and product availability, Avalon is the complete trusted solution. Though the brand was launched in the UK market, Avalon has enjoyed formidable growth and is sold all over Middle East today. Avalon has offices in Europe, America, Canada and Middle East.

The meteoric rise of the brand reflects a growing demand throughout EMEA for a reliable, standards-compliant, readily available, structured cabling and racking system. Avalon is able to deliver this mix through a growing base of distributors and integrators across the region which combines to make the brand an increasingly viable option. With a focus on system performance, independent verification and a 15 year product and application warranty when installed by an Avalon partner, it’s easy to see why this is the system of choice in many government, education, retail, finance and enterprise installations.

Building

The modern intelligent buildings integrate various extra low voltage systems like communication, building management systems and integrated service systems. The traditional systems were installed under various divisions of specifications, now many of them are networked over TCP/IP protocol.

Avalon provides solutions for communication through our comprehensive range of structured cabling solutions. Our end-to-end fiber and copper cabling solutions provide high speed connection to each office, residence and end user to enhance efficiency and quality of the working environment .

Our wide ranging fiber cabling, structured cabling, security and access control solutions cater to building management systems encompassing building automation systems, security automation systems and fire automation systems.

Communication

Communication is the backbone of every known market segment. Today communication industry is moving towards unified network for all communication needs, this convergence of voice, data and video brings the need for scalable infrastructure

Avalon provides solutions for optimization of communication infrastructure and plays a key role in ensuring profitability and superior user experience. Our optimal solutions deliver lowest cost for reliable network for the existing and emerging services.

Our wide ranging fiber and copper solutions cater from service provider to individual customer, from backbone infrastructure to premises network.

Industrial

In this age of computerization, industrial automation is becoming increasingly important in the manufacturing process. The automated machines are capable of doing repetitive work quickly and efficiently. Robotic machines can handle work that is hazardous to human to increase the productivity.

Avalon provides solutions for industrial networking that is structured and customized to individual customer requirement. We have extensive range of control and instrumentation cables that work to various proprietary cabling of reputed brands and open standards.

Avalon’s products and solutions support latest PC based, networking based and networking protocol based systems to automate and control industry wide solutions.

Utilities

The influence of utility automation systems is an important aspect of everyday life in the form of electric power, gas and water utility systems. They form the backbone of the population and will impact their daily business and life.

A new trend has been rising to interconnect automation systems to achieve faster reaction time, to optimize decisions and to collaborate between plant, enterprises and industry sectors. Initially, such interconnections were based on obscure, specialized and proprietary communication means and protocols. Now more and more open and standardized internet technologies are used for this purpose.

Avalon’s fiber and structured cables are used extensively in the distributed control system (DCS) and the supervisory control and data acquisition (SCADA) systems that are widely used in utility systems.

Avalon (UK) Ltd.

Your Global Data Center Solutions Provider

Manufacturer

Avalon UK has over 25+ years of experience in developing and manufacturing data center related products and experience of marketing and promoting under the brand name “Avalon“. Its strength lies in its full range of products like copper, fiber, networking, racks and cabinets, fire suppresion systems, environmental monitoring systems, cooling solutions, power protection solutions, servers, storage etc , giving it an edge over the others in the worldwide market.

Quality & Service

Avalon has a dedicated team for internal quality monitoring, product upgrading, customer support and technical assistance including service and maintenance. Avalon product quality meets and exceeds the standards set by ISO.

25 Years Warranty Policy

Avalon products carry 25 years of standard performance warranty against any manufacturing defects .

Our Advantages

◎ 25 years performance warranty.

◎ Professional sales team for worldwide marketing guidance.

◎ Plant based product management & logistic team for quality and shipment support.

◎ Global availability.

◎ Cost effectiveness and productivity.

RD

P

ARTY TE

THI

ING

Avalon’s Data Center Solutions

Avalon UK is a leading technology solutions provider, offering a wide range of network products, services and turnkey solutions. We provide innovative Information and Communication Technology

(ICT) solutions to enhance small, mid-sized businesses and large enterprises for successful planning, employing and managing their IT infrastructure with a complete range of IT and Network products, network appliances, services and solutions designed to fulfill customer requirements.

A Data Center is usually responsible for the entire information infrastructure of the company or can be regarded as the heartbeat of any company. Most of the companies need or want a facility to store their information, run their network to process the information system. We design, implement, deploy, optimize, help certify, manage and support your data center as your end-to-end solution provider.

Our Solutions

1.

2.

3.

4.

5.

6.

7.

8.

9.

Integrated structured cabling solutions, fiber optic solutions for datacenters with containment, racks, cabinets and enclosures.

Server, storage, routing, switching and networking solutions to increase your datacenter efficiency and performance.

Virtualization and cloud infrastructure for your agile datacenter.

Data center centralized management solutions to manage and monitor all the datacenter equipment.

WAN, application optimization and protection for datacenter.

Power backup and protection solutions to protect mission critical environments from any power failure and problems.

Cooling solutions to optimize your datacenter power utilization efficiency.

Security, access control and surveillance monitoring for a secure data center.

Fire suppression system and environmental monitoring system.

Our Services

Avalon data center services include management of storage repository and dissemination of data organized around a body of knowledge or pertaining to an enterprise. As such, data center services can involve hardware, software, processes and personnel.

We offer our clients the following services:

Hardware installation and maintenance

Managed power distribution

Backup power systems

Cloud based solutions

Hosted exchange services

Virtual mail hosting services

Data backup and archiving

Managed load balancing

Controlled internet access

Managed e-mail and messaging

Managed user authentication and authorization

Diverse firewalls and anti-malware programs

Global Network and Telecom Solutions

www.avalonnetworks.co.uk

Structured Cabling Solutions

Cat.6 Patch Panel

1 2 3 4 5 6

Cat.6 UTP Cable 23AWG

7 8 9 10 11 12 13 14 15 16 17 18

Cat.6 STP LSZH Cable 23AWG

19 20 21 22 23 24

Cat.6A STP LSZH Cable 23AWG

CAT 6

Cat.6 RJ45

Shielded

Connector

Cat.6 RJ45

Unshielded

Connector

Cat.6 STP

Keystone Jack

Cat.6 UTP

Keystone Jack

Faceplate

Fiber Optic Solutions

Armoured Fiber Cable Fiber Optic Pigtail Splitter

Cat.6 UTP Patch Cord

Fiber Patch Panel

Un-Armoured Fiber Cable Fiber Optic Patch Cord Adaptor

Connector

Racks & Cabinet Solutions

Fan Filter Cabinet Fan Fan Unit Brush Panel Cable Manager Rack Shelf PDU

Floor Standing Racks

V

Enclosure Wall Mount Cabinet

4U to 12U

12U-15U 18U-22U 24U-27U 32U-37U 42U-47U

RD

P

ARTY TE

THI

ING

www.

avalonnetworks .co.uk

CONTENTS

Structured Cabling Solutions

01 - 18

Cable Rolls

03 - 05

Patch Cords

Patch Panels

Keystone Jacks

Voice Solutions

Accessories

06 - 08

09 - 11

12 - 14

15 - 16

17 - 18

Fiber Optic Solutions

19 - 34

Fiber Optic Cable Roll

21 - 24

Fiber Optic Patch Panels

Fiber Optic Patch Cords

Fiber Optic Connectors

Fiber Optic Pigtails

Fiber Optic Splice Sleeve

Fiber Optic Adapters

Fiber Optic Splitters

2/4 Core FTTH Termination Box

25 - 25

26 - 29

29 - 30

30 - 31

31 - 31

32 - 32

33 - 33

34 - 34

Racks & Cabinet Solutions

35 - 44

Floor Standing Racks

37 - 38

Wall Mount Cabinets

Wall Mount Enclosures

Accessories

39 - 40

41 - 41

42 - 44

STRUCTURED CABLING SOLUTIONS

With over 20 years experience and know-how on structured cabling products design & development.

With team approach and perfection, definitely we will be your first choice and reliable selection.

Structured Cabling Solutions

With over 20 years of rich experience and know-how on designing and

developing communicating products, Avalon has built matured systems

with high tech development, research centers, complete structural quality

assurance labs and teams. With team approach and high quality

structured cabling products and solutions, we will definitely be your first

choice and reliable selection

Solutions and Components

Avalon delivers end-to-end Category 6A, Category 6 and Category 5e solutions for converged networks with high flexibility and proven inter-operability to ensure smooth deployment and simplified management

With our comprehensive product range, we supply components like

communication cables, keystone jacks, compact outlets, patch panels,

patch cables and others with system warranty. The performance of our

products has been verified and certified by third party laboratory “ETL”.

After years of good result in the market and also systematic upgrading of

our products, we assure you of great benefits both in quality and cost

Our Quality Guarantee

To build a complete high level channel in the project, the precondition is

to make sure each component is built with compatible resistance and

high quality rating, thus, the best solution is to use products from the same

brand or single component with excellent performance. Avalon offers you with a vast range of structured cabling solutions which fulfill these require-

ments. With a specific definition and well defined qualification procedure,

our products ease the installation process and have shown convincible field test results

1

Structured Cabling Solutions

Cable Rolls

03-05

Unshielded Twisted Pair Cable Rolls

Shielded Twisted Pair Cable Rolls

Patch Cords

Unshielded Twisted Pair Patch Cords

Shielded Twisted Pair Patch Cords

Unshielded Patch Panels

Shielded Patch Panels

Blank Patch Panels

Keystone Jacks

12-14

Unshielded 180 and 90 Keystone Jacks

Shielded 180 and 90 Keystone Jacks

Voice Solutions

Multi-core Cables

Voice Patch Panels

LSA Module

Distribution Box

15-16

Accessories

Faceplate

Back Box

Plugs and Boots

RJ45 Connectors

17-18

2

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Category 6, 6A & 5e

Unshielded Twisted Pair Cable Rolls

Avalon cables are the best twisted-pair cables in the market for transmitting data over Local Area Networks

(LAN). As streaming video and multimedia over LAN are gaining popularity, users demand faster data transmission and reduced waiting time. These cables are ideal for simple, cost-effective and high-speed transmission performance.They support a higher signal - to-noise ratio, providing better reliability for current applications and higher data rates for future applications. These cables meet and exceed all the Standards like

ANSI//EIA-568B, ISO/IEC11801: 2011, EN 50173 etc.

Cat.6 UTP Cable

Feature

Conductors

Insulators

Jacket

Pulling Strength

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Thickness (mm)

Material

Force

Minimum Bend Radius

Operating Temperature

Celsius

Value

23

0.55

Solid Bare Copper

0.95±0.03mm

HDPE

6.2 ± 0.4 mm

0.55+/-0.05

PVC / LSZH

110N

4 Times outer diameter

-20

0

C to +75

0

C

Ordering Information

Part No. *

ANC6UPXX23-305MT

ANC6UPXX23-305MT-LSZH

Description

CAT.6 UTP Cable-305 Meter

CAT.6 UTP Cable-

Length

Colour

305 Meters Grey*

305 Meters Grey*

Cat.6A UTP Cable

Feature

Conductors

Insulators

Jacket

Pulling Strength

Minimum Bend Radius

Operating Temperature

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Thickness (mm)

Material

Force

Celsius

Value

23

0.570

Solid Bare Copper

1.03±0.03mm

HDPE

6.2 ± 0.4 mm

0.65+/

-0.05

PVC / LSZH

110N

4 Times outer diameter

-20

0

C to +75

0

C

Ordering Information

ANC6AUP

Part No. *

ANC6AUPXX23-305MT

XX23-305MT-LSZH

Description

CAT.6A UTP Cable

- 305 Meter

CAT.6A UTP Cable -

Length

Colour

305 Meters

Grey*

305 Meters Grey*

* Change XX to GY for Grey, BL for Blue, WH for White, RD for Red, BK for Black, GR for Green or YL for Yellow colour

3

Quality is the priority

www.avalonnetworks.co.uk

Cat.5e UTP Cable

Feature

Conductors

Insulators

Jacket

Pulling Strength

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Thickness (mm)

Material

Force

Minimum Bend Radius

Operating Temperature

Celsius

Value

23

0.55

Solid Bare Copper

0.

95±0.03mm

HDPE

6.2 ± 0.4 mm

0.55+/ -0.05

PVC / LSZH

110N

4 Times outer diameter

-20

0

C to +75

0

C

Ordering Information

Part No. *

ANC5EUPXX23-305MT

Description

CAT.5EUTP Cable-305 Meter

ANC5EUPXX23-305MT-LSZH CAT.5E UTP Cable-305 Meter - LSZH

Category 6, 6A & 5e

Shielded Twisted Pair Cable Roll

Length

Colour

305 Meters Grey *

305 Meters Grey *

Avalon cables are the best twisted-pair cables in the market for transmitting data over Local Area Networks(LAN).

They support a higher signal -to-noise ratio,providing better reliability for current applications and higher data rates for future applications. An Aluminium tape is used to shield all the four pairs of cables giving screened protection against external interference such as EMI and improves external crosstalk.They meet and exceed standards like ANSI/TIA/EIA-568-C.2, ISO/IEC11801: 2011(Ed. 2.2), EN 50173-1:2011, IEC61935-2:2010(Ed.3.0) etc.

Cat.6 STP Cable

Feature

Conductors

Insulators

Jacket

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Shield

Pulling Strength

Thickness (mm)

Material

Material

Force

Minimum Bend Radius

Operating Temperature

Celsius

Value

23

0.565

Bare Copper

1.08 + 0.05mm

HDPE

7.4+/-0.4 mm

0.60+/-0.05

PVC / LSZH

Aluminium Foil

110N

4 Times outer diameter

-20 C to +75 0 C

Ordering Information

Part No. *

ANC6SPXX23-305MT

ANC6SPXX23-305MT-LSZH

Description

CAT.6 STP Cable - 305 Meter

CAT.6 STP Cable - 305 Meter - LSZH

Length

Colour

305 Meters Grey *

305 Meters

Grey *

* Change XX to GY for Grey, BL for Blue, WH for White, RD for Red, BK for Black, GR for Green or YL for Yellow colour

Quality is the priority

4

5

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Cat.6A STP Cable

Feature

Conductors

Insulators

Jacket

Sheath

Pulling Strength

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Thickness (mm)

Material

Material

Minimum Bend Radius

Operating Temperature

Celsius

Value

23

0.50

Solid Bare Copper

1.02 + 0.02mm

HDPE

5.0+/-0.3

0.50+/-0.05

PVC / LSZH

Aluminium Tape

110N

4 Times outer diameter

-20

0 0

Ordering Information

Part No. *

ANC6ASPXX23-305MT

ANC6ASPXX23-305MT-LSZH

Description

CAT.6A STP Cable-305 Meter

CAT.6A STP Cable - 305 Meter - LSZH

Length

Colour

305 Meters Grey *

305 Meters Grey *

* Change XX to GY for Grey, BL for Blue, WH for White, RD for Red, BK for Black, GR for Green or YL for Yellow colour

...............................................................................................................................................................................

Cat.5e STP Cable

Feature

Conductors

Insulators

Sheath

Pulling Strength

Type

AWG

Size(mm)

Material

Diameter(mm)

Material

External O.D.

Thickness (mm)

Material

Material

Minimum Bend Radius

Operating Temperature

Celsius

Value

23

0.50

Solid Bare Copper

1.00 + 0.03mm

HDPE

6.2 +-0.4 mm

0.55+/-0.05

PVC / LSZH

Aluminium Tape

110N

4 Times outer diameter

-20

0

C to +75 C

Ordering Information

Part No. *

ANC5ESPXX23-305MT

Description

CAT.5E STP Cable-305 Meter

ANC5ESPXX23 -305MT -LSZH CAT.5E STP Cable-305 Meter -LSZH

Length

Colour

305 Meters Grey *

305 Meters Grey *

* Change XX to GY for Grey, BL for Blue, WH for White, RD for Red, BK for Black, GR for Green or YL for Yellow colour

Quality is the priority

www.avalonnetworks.co.uk

Category 6, 6A & 5e

Unshielded Twisted Pair Patch Cords

Avalon unshielded patch cords have been designed for high speed data transmission over Local Area Networks (LAN) upto ATM 622 Mbps and for Gigabit Ethernet upto 1000 Mbps applications. These patch cords exceed performance requirements specified by the ANSI/TIA/EIA-568B.2 / TIA/EIA-568C.2, EN50173 - 1:2011, ISO/IEC11801:2011(Ed. 2.2) and IEC

60603-7-4 standards etc.

Cat.6 UTP Patch Cords

Feature

Insulation Material

Value

HDPE

Conductor and Metal

7 Bare Copper Wires, 24 AWG

No of Pairs

Jacket

Plugs

Contact

Contact blade

Molded Boot

Fire Resistant

4

PVC/LSZH , UL94V-0

RJ-45 8P8C

30µ

Phosphor Bronze

Fire Retardant PVC/LSZH

CMG Specifications

Ordering Information

Part No. *

ANC6UPXX-YYMT

Description

Avalon CAT.6 UTP Patch Cord

ANC6UPXX - YYMT - LSZH Avalon CAT.6 UTP Patch Cord - LSZH

* XX - Colour - Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY - Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m...15m...30 meters etc

............................................................................................................................................................................................................

Cat.6A UTP Patch Cords

Feature

Insulation Material

Value

Conductor and Metal 7 Bare Copper Wires, 26 AWG

No of Pairs

Jacket

Plugs

Contact

Contact blade

Molded Boot

Fire Resistant

HDPE

4

PVC/LSZH , UL94V-0

RJ-45 8P8C

Gold plated : 30µ

Phosphor Bronze

CMG Specifications

Fire Retardant PVC/LSZH

Ordering Information

Part No. *

ANC6AUPXX-YYMT

Description

Avalon CAT.6A UTP Patch Cord

ANC6AUPXX-YYMT -LSZH Avalon CAT.6A UTP Patch Cord - LSZH

* XX - Colour -- Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY -Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m...15m...30 meters etc.

Quality is the priority

6

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Cat.5e UTP Patch Cords

Feature

Insulation Material

Jacket

Plugs

Contact

Contact blade

Molded Boot

Fire Resistant

Value

HDPE

Conductor and Metal 7 Bare Copper Wires, 24 AWG

No of Pairs 4

PVC/LSZH , UL94V-0

RJ -45 8P8C

Gold plated : 30µ

Phosphor Bronze

Fire Retardant PVC/LSZH

CMG Specifications

Ordering Information

Part No. *

ANC5EUPXX-YYMT

Description

Avalon CAT. 5E UTP Patch C ord

ANC5EUPXX-YYMT-LSZH Avalon CAT. 5E UTP Patch Cord , LSZH

*

XX - Colour - Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY - Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m...15m...30 meters etc.

.................................................................................................................................................................................................................

Category 6, 6A & 5e

Shielded Twisted Pair Patch Cords

Avalon shielded patch cords have been designed for for high speed data transmission over local area networks (LAN) upto ATM 622 Mbps and for Gigabit Ethernet upto 1000 Mbps applications. These cables exceed performance requirements specified by the ANSI/TIA/EIA -568B.2 /TIA/EIA-568C.2, EN 50173-1:2011,ISO/IEC11801:2011(Ed. 2.2) and

IEC 60603-7-4 standards etc. An Aluminium tape is used to shield all the four pairs of cables giving screened protection against external interference such as EMI and improves external crosstalk

Cat.6 STP Patch Cords

Feature

Insulation Material

Value

Conductor and Metal 7 Bare Copper Wires, 24 AWG

No of Pairs

Jacket

Plugs

Contact

Contact blade

Molded Boot

Fire Resistant

HDPE

4

PVC/LSZH , UL94V-0

RJ-45 8P8C

Gold plated : 30µ

Phosphor Bronze

Fire Retardant PVC/LSZH

CMG Specifications

Cable Shield

Aluminum Mylar for individual pair and overall braided shield

Ordering Information

Part No. *

ANC6SPXX-YYMT

Description

Avalon CAT.6 STP Patch Cord

ANC6SPXX-YYMT-LSZH Avalon CAT.6 STP Patch Cord, LSZH

* XX - Colour - Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY - Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m...15m...30 meters etc.

7

Quality is the priority

www.avalonnetworks.co.uk

Cat.6A STP Patch Cords

Feature

Insulation Material

Value

HDPE

Conductor and Metal 7 Bare Copper Wires, 26 AWG

No of Pairs

Jacket

Plugs

Contact

Contact blade

Molded Boot

Cable Shield

4

PVC/LSZH ,

UL94V-0

RJ-45 8P8C

Gold plated : 30µ

Phosphor Bronze

Fire Retardant PVC/LSZH

Aluminum Mylar for individual pair and overall braided shield

Ordering Information

Part No. *

ANC6ASPXX-YYMT

Description

Avalon CAT.6A STP Patch Cord

ANC6ASPXX-YYMT-LSZH Avalon CAT.6A STP Patch Cord, LSZH

* XX - Colour - Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY - Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m....15m....30 meters etc

.................................................................................................................................................................................................................

Cat.5e STP Patch Cords

Feature

Insulation Material

Value

Conductor and Metal 7 Bare Copper Wires, 24 AWG

No of Pairs

Jacket

Plugs

Contact

HDPE

4

PVC/LSZH , UL94V-0

RJ-45 8P8C

Gold plated : 30µ

Contact blade

Molded Boot

Cable Shield

Phosphor Bronze

Fire Retardant PVC/LSZH

Aluminum Mylar for individual pair and overall braided shield

Ordering Information

Part No. *

ANC5ESPXX-YYMT

ANC5ESPXX-YYMT-LSZH

Description

Avalon CAT.5E STP Patch Cord

Avalon CAT.5E STP Patch Cord , LSZH

* XX - Colour - Grey (GL), Blue (BL), White (WH), Red (RD), Black (BK), Green (GR) or Yellow (YL) color.

YY - Length - 0.5m, 1.0m, 2.0m, 3.0m, 5.0m,…..10m...15m...30 meters etc.

Quality is the priority

8

Category 6, 6A & 5e

Unshielded Patch Panels

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

9

Avalon 24 and 48 Port Patch Panels are the industry's high-quality Panels that support the latest technologies and diverse applications. These panels combine strength and durability with a sleek look, making them ideal for all kinds of environments. These comply with ANSI/TIA-568B-.2, ISO/IEC 11801 and EN 50173-1 Class E specifications. The complete module complies with EU ROHS directive. The construction is in standard 19” size, suits for all 19” rack installations and they accept Cat.6, Cat.6A or Cat.5E Keystone Jacks. Numerical markings on the front side make it easier to use.

Specifications

Features

Size

IDC Accept

Housing

IDC Body

Metal Sheet

Plastic

IDC Contact

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

Specifically Design

Insertion life

Plug /Jack Contact Force

Humidity

Operation Temperature

Thickness of cold-rolled steel

Values

19” 1U or 2U

Accepts AWG 22-26 AWG

ABS 94V-0

PC UL94-V0

Corrosion Resistant Steel Sheet

Fire Self Extinguish High Impact Plastic

Phosphor Bronze with 50µ gold plating on contact area.

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

With Two PCB Panel & Tool less

≥1000 mating cycles

100g min

5 to 93%( non condensing)

-40

0

to 70

0

C

1.5mm

Ordering Information

Part No.

ANC6UPP-24

ANC6UPP-48

Part No.

ANC6AUPP-24

ANC6AUPP-48

Part No.

ANC5EUPP-24

ANC5EUPP-48

Description

CAT.6 Unshielded 24 Port Patch Panels,1U

CAT.6 Unshielded 48 Port Patch Panels, 2U

Description

CAT.6A Unshielded 24 Port Patch Panels , 1U

CAT.6A Unshielded 48 Port Patch Panels , 2U

Description

CAT.5E Unshielded 24 Port Patch Panels ,1U

CAT.5E Unshielded 48 Port Patch Panels , 2U

Quality is the priority

www.avalonnetworks.co.uk

Category 6, 6A & 5e

Shielded Patch Panels

Avalon 24 and 48 port shielded keystone patch panels comes with a design which has redefined engineering elegance. It has complete metal shielded connector structure that includes the front panel, the metal case and the cable management plate. The cable management plate comes with pre-fitted B-Clip that helps in routing cables and provides a perfect strain relief. The front panel has white colour printed for identification of ports. The keystones snap fit on the metal case and can be removed easily whenever required. These comply with ANSI/TIA-

568B-.2, ISO/IEC 11801 and EN 50173-1 Class E specifications. The complete module complies with EU ROHS directive. The construction is in standard 19” size which suits all 19” rack installations and these accept Cat.6,

Cat.6A or Cat.5E shielded keystone jacks. Numerical marking on the front side make them very easy to use.

Specifications

Feature

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Contact Material

Contact Thickness

IDC Contact Plating

IDC Housing

IDC Compatibility

Jack Contact Material

Shield

Printed Circuit Board

Operation Temperature

Thickness of cold-rolled steel

Description

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

Phosphor Bronze – With Gold-plated 3µ-50µ

0.5 mm

Tin Plating

PC +Glass Fiber

22 to 26 AWG

Phosphor Bronze - With Gold-plated 3µ-50µ

50µ Nickel plated over phosphor bronze

FR4 94V-0

-40 to 70 C

1.5mm

0

Ordering Information

Part No.

ANC6SPP-24

ANC6SPP-48

Description

CAT.6 Shielded 24 Port Patch Panel, 1U

CAT.6 Shielded 48 Port Patch Panel, 2U

Part No.

ANC6ASPP-24

ANC6ASPP-48

Part No.

ANC5ESPP-24

ANC5ESPP-48

Description

CAT.6A Shielded 24 Port Patch Panel, 1U

CAT.6A Shielded 48 Port Patch Panel, 2U

Description

CAT.5E Shielded 24 Port Patch Panel, 1U

CAT.5E Shielded 48 Port Patch Panel, 2U

Quality is the priority

10

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Category 6, 6A & 5e

Unloaded/Blank Patch Panel

UTP Blank Patch Panel

STP Blank Patch Panel

Specifications

Feature

Size

IDC Accept

RJ45

IDC Design

IDC Body

Metal Sheet

Plastic

Operation Temperature

19” 1U or 2U

Description

Accepts AWG 22-26 AWG

Housing Nylon 8P8C 50µ gold plated

Suitable for Krone and 110 Punch Tools

UL94-V0

Corrosion Resistant Steel Sheet

Fire self extinguish high impact plastic

0 C 0 C

Ordering Information

Part No.

ANC6UPP-X-BL

ANC6SPP-X-BL

ANC6AUPP-X-BL

ANC6ASPP-X-BL

ANC5EUPP-X-BL

ANC5ESPP-X-BL

Description

Cat6 UTP Blank Patch Panel

Cat6 STP Blank Patch Panel

Cat6A UTP Blank Patch Panel

Cat6A STP Blank Patch Panel

Cat5E UTP Blank Patch Panel

Cat5E STP Blank Patch Panel

* Replace X with 12, 24 or 48 Port.

11

Quality is the priority

www.avalonnetworks.co.uk

UTP Keystone Jacks - Category 6, 6A & 5e

Avalon 180° and 90° Jacks are designed and manufactured to meet the current and future requirements of high bandwidth and forms an essential element of the structured cabling system. The jacks snap easily in and out of wall outlets, surface mount boxes and patch panels. These comply with TIA/EIA-568-C.2 specifications.

Cat.6 UTP Keystone Jacks

Housing

Feature

Spring Wire

IDC Contact

Insertion life

Operating

Temperature Range

IDC Accept

Value

High-impact Flame Retardant

Polycarbonate, UL94V-0

Phosphor Bronze With Gold plated 3µ - 50µ

Phosphor Bronze

≥1000 mating cycles

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Ordering Information

Part No. *

ANC6UPKJ-180

Value

CAT.6 UTP 180º Keystone Jack

ANC6UPKJ -90 Cat.6 UTP 90º Keystone Jack

* Standard Product comes in White Color. For keystone Jacks of other colors add RD (Red), Green(GR), YL(Yellow),

Blue(BL), Grey(GY), Black(BK) after the Part Number.

....................................................................................................................................................................................................................................................................................

Cat.6A UTP Keystone Jacks

Housing

Feature

Spring Wire

IDC Contact

Insertion life

Operating

IDC Accept

Temperature Range

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

Value

High-impact Flame Retardant

Polycarbonate, UL94V-0

Phosphor Bronze With Gold plated 3µ - 50µ

Phosphor Bronze

≥1000 mating cycles

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Ordering Information

Part No. * Value

ANC6AUPKJ-180 CAT.6A UTP 180˚ Keystone Jack

ANC6AUPKJ -90 Cat.6A UTP 90˚ Keystone Jack

* Standard Product comes in White Color. For keystone Jacks of other colors add RD (Red), Green(GR),YL(Yellow),

Blue(BL), Grey(GY), Black(BK) after the Part Number.

Quality is the priority

12

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Cat 5e UTP Keystone Jacks

Housing

Feature

Spring Wire

IDC Contact

Insertion life

Operating

Temperature Range

Value

High-impact Flame Retardant

Polycarbonate,UL94V-0

Phosphor Bronze With Gold plated 3µ 50µ

Phosphor Bronze

≥1000 mating cycles

IDC Accept

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

Jack Shield

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Zinc Die Casting

Ordering Information

Part No. *

ANC5EUPKJ-180

ANC5EUPKJ-90

Value

CAT.5E UTP 180˚ Keystone Jack

CAT.5E UTP 90˚ Keystone Jack

* Standard Product comes in White Color. For keystone

Jacks of other colors add RD (Red), Green (GR) , YL

(Yellow), Blue (BL), Grey (GY), Black (BK) after the Part

Number

.........................................................................................................................................................................................................................................................................................

STP Keystone Jacks - Category 6, 6A & 5e

Avalon 180° and 90° Jacks are designed and manufactured to meet the current and future requirements of high bandwidth and forms an essential element of the structured cabling system. The Jacks snap easily in and out of wall outlets, surface mount boxes and patch panels. These comply with TIA/EIA-568-C.2 specifications.

Cat.6 STP Keystone Jacks

Housing

Feature

Spring Wire

IDC Contact

Insertion life

Operating

Temperature Range

Value

High-impact Flame Retardant

Polycarbonate, UL94V-0

Phosphor Bronze With Gold plated 3µ 50µ

Phosphor Bronze

≥1000 mating cycles

IDC Accept

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

Jack Shield

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Zinc Die Casting

Ordering Information

Part No. *

ANC6SPKJ-180

ANC6SPKJ-90

Value

CAT.6 STP 180˚ Keystone Jack

Cat.6 STP 90˚ Keystone Jack

* Standard Product comes in White Color. For keystone

Jacks of other colors add RD (Red), Green (GR) , YL

(Yellow), Blue (BL), Grey (GY), Black (BK) after the Part

Number.

13

Quality is the priority

www.avalonnetworks.co.uk

Cat.6A STP Keystone Jacks

Housing

Feature Value

High-impact Flame Retardant

Polycarbonate,UL94V-0

Phosphor Bronze With Gold plated 3µ 50µ

Spring Wire

IDC Contact

Insertion life

Operating

Temperature Range

IDC Accept

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

Jack Shield

Phosphor Bronze

≥1000 mating cycles

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Zinc Die Casting

Ordering Information

Part No. *

ANC6ASPKJ-180

ANC6ASPKJ-90

Value

CAT.6A STP 180˚ Keystone Jack

Cat.6A STP 90˚ Keystone Jack

* Standard Product comes in White Color. For keystone Jacks of other colors add RD (Red), Green(GR),YL(Yellow),

Blue(BL), Grey(GY), Black(BK) after the Part Number.

....................................................................................................................................................................................................................................................................................

Cat.5e STP Keystone Jacks

Housing

Feature

Spring Wire

IDC Contact

Insertion life

Operating

Temperature Range

Value

High-impact Flame Retardant

Polycarbonate, UL94V-0

Phosphor Bronze With Gold plated 3µ 50µ

Phosphor Bronze

≥1000 mating cycles

IDC Accept

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

RJ45

Jack Shield

22-26 AWG

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

8P8C 50µ Punch Down Jacks

Zinc Die Casting

Ordering Information

Part No. *

ANC5ESPKJ -180

ANC5ESPKJ -90

Value

CAT.5e STP 180˚ Keystone Jack

Cat.5e STP 90˚ Keystone Jack

* Standard Product comes in White Color. For keystone Jacks of other colors add RD (Red), Green(GR), YL (Yellow),

Blue(BL), Grey(GY), Black(BK) after the Part Number.

Quality is the priority

14

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Voice Solutions

Multi-Core Cables

Avalon Cat.3 UTP 2 Pair, 10 Pair, 25 Pair, 50 Pair and 100 Pairs Telephone Cables are made for riser telephone cabling applications as per TIA/EIA-568-C.2, ISO/IEC 11801:2011 edition 2.2 and EN 50173:201 standards. These are constructed with 24 gauge solid bare copper conductors placed inside a PVC jacket. The color coding is very dark and easily distinguished for easy punch-down, even in low light conditions.

Specifications

Insulation

Feature

Jacket

Ripcord

Operating Temperatures

Voltage Rating

Conductors

Conductor Diameter

Insulated Conductor Diameter

Insulated Cable Diameter

Jacket Thickness

Outer Jacket for Outdoor

Cable Only

Semi - rigid PVC

Description

Flame Retardant Chrome PVC with sequential footage markings

Applied longitudinally under jacket

300 volts

Solid bare copper

24 AWG nominal

3.5mm-20.40mm based on number or pairs

0.5mm to 1.60mm based on number of pairs

PE

Ordering Information

Part No.

ANC3UP-X

*

ANC3UP-X-O

Description

Cat.3 Indoor Voice Cable

Cat.3 Outdoor Voice Cable

Cat. 3 50 Pair

Cat. 3 25 Pair

Cat. 3 100 Pair

Voice Patch Panel

Avalon 25 Port and 50 Port Cat.3 Voice Patch Panels are high-quality Panels that support terminations of voice backbone cabling (vertical) and are designed to utilize minimum rack space by supporting 25 Ports (1U) and 50 Ports (2U) of rack space. These panels support both 1 and 2 pair connectivity for analog/digital telephone services via PABX or for the distribution of direct lines.

Specifications

Feature

Size

IDC Accept

Metal Sheet

IDC Contact

Wire Scheme

Insulation Resistance

Current Rating

DC Resistance

Voltage

Plug Retention Force

Specifically Design

Insertion life

Plug /Jack Contact Force

Humidity

Operation Temperature

Thickness of cold-rolled steel

Description

19” 1U or 2U

Accepts AWG 22-26 AWG

Corrosion Resistant Steel Sheet

Phosphor Bronze with 50µ gold plating on contact area.

T568A/B

500Ω

1.5Amps

0.1 ohm MAX

150 VAC MAX

89N

With Two PCB Panel & Tooless

≥1000 mating cycles

100g min

5 to 93% ( non condensing)

-40 to 70 C

1.5mm

0

Ordering Information

Part No.

ANC3VPP-25

ANC3VPP-50

Description

25 Port Voice Patch Panel

50 Port

15

Quality is the priority

www.avalonnetworks.co.uk

LSA Module

Avalon LSA profile connection/disconnection modules are designed for telecommunication and data communication networks especially to be used in MDF , IDF , cross connection cabinets and DPs. These modules decrease the risk of poor termination and increase the wiring productivity. The disconnection modules have two piece contacts normally closed which incorporate a disconnection facility and give the advantage of individual pair disconnection and four wire test access. The connection modules have a one piece contact providing a continuous link between permanent wiring and jumper wiring, giving provision for monitoring access and over voltage.

Features

Gas tight connection with self-cleaning contact

• One push wire insertion

• No wire-stripping , screw and solder free

• Only one inexpensive tool required

Specifications

• Material-Plastic Parts ABS or PBT

• Flammability -UL94V-0

• Dimension - 124 mm x 21 mm x 30 mm

• IDC Type - Krone or 110

• IDC contact blade - phosphor bronze or tin brass with silver plating (0.5 μm)

• IDC contact positioning - 45° angle across wire axis

• Internal Dia. off connectable solid wire - 0.35 - 0.9 mm (26-20 AWG)

• Outer Dia. of connectable solid wire - 0.68 -1.5 mm with PE, PVC, LSZH Insulation

• Outer Dia. of connectable stranded wire - (7 Tin Coated Strands) up to 2.1 mm (28-20 AWG)

• Wire insulation diameter - 0.7 - 1.6 mm (PE & PVC Ins)

• No of equal wire per contact - Max. 2

Applications

• Suitable for use in all communication networks (POTS, DSL and IP networks)

• VDSL2-capable

• Used in outdoor enclosures with restricted space for cable termination

Ordering Information

Part No.

ANKC-10

ANKDC-10

Description

10 Pair Connection Module

10 Pair Disconnection Module

.....................................................................................................................................................................................................................................................................................

Distribution Box

Avalon distribution boxes are used in various voice and telecommunication applications. These are suitable for indoor and outdoor purposes.

Specifications

• Material for Indoor: ABS material

• Material for Outdoor : IP45 water proof design, UV cured

Ordering Information

Part No. *

ANX-DB-I

ANX-DB-O

Description

Indoor Distribution Box

Outdoor Distribution Box

* X – No: of Pairs –10,30, 50, 100, 400…800 or 1200 Pairs etc.

Quality is the priority

16

STRUCTURED CABLING SOLUTIONS www.avalonnetworks.co.uk

Accessories

Faceplate

Avalon faceplates are manufactured using fire retardant materials and are known for safety and durability. They are available in 1 and 2 ports for different applications and usages. Each of them delivers a high speed signal for all high speed desktop applications. They accept Cat3, Cat5e and Cat 6 UTP keystones to fit with different performance requirements. They also perfectly blend into the decor of the home or office and protect the network connections.

Specifications

Feature

Type

I.D. Plate

Value

UK Style with shutter against dust and labeling plate.

Polycarbonate,

UL94V-2 transparent color.

Face plate ABS, UL94V-0, with

Dust Cover ABS, UL94V-0, with

Screw

Directive

M3.5XL25.0mm

RoHS certified

Ordering Information

Part Number Description Dimensions

AN-WSFP-1P

AN-WSFP-2P

AN-BVFP-86

AN-BVFP-50

Flat Shutter Single Port RJ45 Faceplate, UK

Flat Shutter Dual Port RJ45 Faceplate, UK

86X86mm

86X86mm

UK Euro Angled Beveled Frame - Smooth Surface 86X86mm

UK Euro Single Port RJ45 Beveled Faceplate 50X25mm

AN-BVFP-50-2P UK Euro Dual Port RJ45 Beveled Faceplate

AN-BVA-25 Angular Keystone Adapter

50X25mm

25X50mm

AN-SA-25

AN-BA-25

AN-BA-12

Straight Keystone Adapter

Blank Adapter

Blank Adapter

25X50mm

25X50mm

12X50mm

................................................................................................................................................................................................................

Back Box

Avalon back boxes are manufactured using fire retardant materials and are known for safety and durability.

Each of them delivers a high speed signal for all high speed desktop applications. They also perfectly blend into the decor of the home or office and protect the network connections.

Specifications

Feature

Type

Box

Value

Screw Nut M3.5xL7.0mm

Screw

Screw

Directive

For UK Style Faceplate

ABS, UL94-HB, with white color

M3.5X25.0x7.0 mm

M3.5X19.0X7.5mm

RoHS certified

Ordering Information

Part No.

AN86-BB

Description

Back Box

Dimensions

86X86mm

17

Quality is the priority

www.avalonnetworks.co.uk

Plugs covers (Boots)

Avalon Plug Covers help stop damage from dirt and debris for open RJ45 ports and unused plugs. These RJ45 covers protect your valuable ports and cables. Made from flexible PVC, these covers attach easily and stay in place with a snug friction fit. Jack covers feature a low profile knob making for easy removal when the port in needed again. Plug covers also protect the delicate locking tab on modular plugs. Packaged in bags of 100 pieces and shipped from a vast stock for large projects.

Specifications

Feature

Fit for

Color

Material

Package Content

RJ45 Connectors

Plastic

100 Pcs

Value

Yellow, Black, Blue,Grey,White

Red etc

Ordering Information

Part No. *

ANCBXX

Description

Avalon Cable Boots

* XX denotes Color, Change XX for RD (Red), YL (Yellow), BL (Blue), BK (Black), GR(Green), GY (Grey)

.....................................................................................................................................................................................................................................................................................

RJ45 Connectors

Avalon RJ45 Connectors are designed for today's high performance networks. A superior two-prong contact design works for both solid and stranded conductors. An integrated strain relief boot holds the cable in the proper position while crimping and provides protection to the cable connection after installation.

Specifications

Feature

Housing

Contact terminal

Value

Polycarbonate, 94V -

2, transparent color

Phosphor bronze 30 micro-inch gold plating, over 50 micro inch Nickel plated on contact area

Operating temperature

Cable to plug tensile strength

-40˚C to 80˚C

7.7 Kg

Terminates

Wiring Scheme

24-26 AWG stranded wires

T568A/T568B

Ordering Information

Part No

Description

ANC6URJ45

ANC6SRJ45

Cat.6 Unshielded Modular Connectors

Cat.6 Shielded Modular Connectors

ANC6AURJ45 Cat.6A Unshielded Modular Connectors

ANC6ASRJ45 Cat.6A Shielded Modular Connectors

ANC5EURJ45 Cat.5E Unshielded Modular Connectors

ANC5ESRJ45 Cat.5E Shielded Modular Connectors

Quantity

per bag

100

100

100

100

100

100

Quality is the priority

18

FIBER OPTIC SOLUTIONS

With over 20 years experience and know-how on communicating products design & development. With team approach and perfection, definitely we will be your first choice and reliable selection.

Fiber Optic Solutions

With over 15 years of experience and know-how in designing and develop-

ing fiber optic products, Avalon has built WAN and LAN fiber systems that are very competitive in cost

Our fiber optic solutions are made by the most common substance silicon

dioxide in complete core diameter i.e. 9µm for singlemode, 62.5µm for

OM1 and 50µm for OM2/OM3, which allow light signal transmission that support long distances and high speed data network and telecommunication

Solutions and Components

Avalon fiber solutions include a full range of fiber optic devices, cables,

accessories like pigtails, patch cords, patch panels, adapters, connectors

and different types of terminal boxes

Avalon’s complete range of these fiber components come with low attenuation loss control

Our Quality Guarantee

Avalon offers complete and high quality fiber cabling solutions which

have been manufactured with a specific definition and a streamlined

qualification procedure

Our fiber products and solutions have shown convincible field test results with ease in installation, termination, and reducing the overall project time

19

Fiber Optic Solutions

Fiber Optic Cables

21-24

2 Core Flexi Drop Cable - FTTH Indoor / Outdoor

Singlemode Armoured / Direct Burial Fiber Cable

Singlemode Un-Armoured Fiber Cable

Multimode Armoured / Direct Burial Fiber Cable

Multimode Un-Armoured Fiber Cable

Fiber Optic Patch Panels

12 Port Fiber Patch Panel

24 Port Fiber Patch Panel

48 Port Fiber Patch Panel

Fiber Optic Patch Cords

APC Fiber Patch Cords

UPC Fiber Patch Cords

Multimode Fiber Patch Cords

Singlemode Fiber Patch Cords

26-29

Fiber Optic Connectors

29-30

FC, LC, SC, ST Connectors

Fiber Optic Pigtails

30-31

FC, LC, SC, ST Pigtails

Pack of 100 sleeves

Fiber Optic Adapters

FC, LC, SC, ST Adapters

32-32

Fiber Optic Splitters

33-33

FC, LC, SC, ST Splitters

FTTH Termination Box

2/4 Core FTTH Termination Box

34-34

20

21

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

Fiber Optic Cables

2 Core Flexi Drop Cable – FTTH Indoor / Outdoor

FTTH - Indoor Cable

Avalon 2-fiber singlemode all dielectric Fiber to the Home (FTTH) drop cable is color coded in red and green optical fibers. These two fibers are embedded in sheath along with two ARP/FRP rods. The outer jacket is made of LSZH/LSOH material and is applicable for indoor application. It is designed for internal FTTH applications horizontal, riser and clipping to surfaces including skirting boards.

Features

• ITU-T REC.G657A

• EC Specifications 60793-2-50 Type B1.3

• TIA/EIA 492-CAAB

• Telecordia's GR-20-CORE

• ISO/IEC 11802 0S-1

Outer Sheath

FRP Rod

Optical Fiber

Ordering Information

Part No.

*

ANFTTH-SM-2-IN

Ftth Indoor Cable

Description

Avalon Fiber-to-the-Home (FTTH), 2 Core, Indoor Optical Fiber Cable - Singlemode

.......................................................................................................................................................................................

FTTH - Outdoor Cable

Avalon 2-fiber singlemode all dielectric Fiber to the Home (FTTH) drop cable is color coded in blue and orange optical fibers. The outdoor FTTH flat cable’s outer sheath is flame retardant and is black PE with supporting 1mm

FRP rod. The Fibers used in these cables are bending insensitive making it possible for applications requiring multiple bends. These cables can be buried directly considering its resistance against crush and impact conditions.

Compliance

ITU-T REC. G657A

EC Specifications 60793 -2-50 Type B1.3

ISO/IEC 11802 OS-1

TIA/EIA 492-CAAB

Telecordia's GR-20-CORE

Features

As per ITU-T REC. G.657A

Outdoor Grade

LSZH black jacketing material

Upcoated

wire 2mm FRP Suspension Support

• FRP Rod embedded in the sheath

• Notched construction for easy stripping

• Flame Retardant Black Polyethylene cable jacket

• Core Diameter 9µm

Ftth Outdoor Cable

FRP Road

Web

FRP ROD

2 - Fiber

Outer Sheath

Ordering Information

Part No.

*

ANFTTH-SM-2-OUT

Description

Avalon Fiber-to-the-Home (FTTH) , 2 Core, Outdoor Optical Fiber Cable - Singlemode

Quality is the priority

www.avalonnetworks.co.uk

Singlemode Armoured/Direct Burial Fiber Cable

OUTER SHEATH (HDPE / LSZH)

CORRUGATED STEEL TAPE ARMOUR

INNER SHEATH (PE)

POLYESTER TAPE / POL YAL OPTIONAL

FLOODING JELLY

LOOSE TUBE WITH OPTICAL FIBER

STRENGTH MEMBER FRP

Features

• ITU-T G.652 D

• EC Specifications 60793-2-50 Type B1.3

TIA/EIA 492-CAAB

Telecordia's GR-20-CORE

ISO/IEC 11802 0S-1

Applications

1000BASE-LX  10GBASE-LX4  10GBASE-LR/LW  10GBASE-ER/EW

155 Mbps ATM  622 Mbps ATM  FDDI

531 Mbps Fiber Channel

1062 Mbps Fiber Channel

OS1 Ordering Information

Part No.

*

ANFC-SM-X-AR

Description

Avalon Fiber Armoured Cable - Single Mode

* X – No: of Cores – 02, 04, 06, 08, 12, 24, 48, 96 Cores etc.

.................................................................................................................................................................................................................

Singlemode Un-Armoured Fiber Cable

RIP CORD

OUTER SHEATH (HDPE / LSZH)

POLYESTER TAPE

JELLY

LOOSE TUBE WITH OPTICAL FIBERS

STRENGTH MEMBER (FRP)

Features

• ITU-T G.652 D

• EC Specifications 60793-2-50 Type B1.3

• TIA/EIA 492-CAAB

• Telecordia's GR-20-CORE

• ISO/IEC 11802 0S-1

Applications

100BASE-FX  1000BASE-SX

1062 Mbps Fiber Channel

1000BASE-LX

155 Mbps ATM

 622 Mbps ATM

OS1 Ordering Information

Part No.

*

ANFC-SM-X-LT

Description

Avalon Fiber Optic Un-Armoured - Single Mode

* X – No: of Cores – 02, 04, 06, 08, 12, 24, 48, 96 Cores etc.

FDDI

Quality is the priority

22

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

Multimode Armoured/Direct Burial Fiber Cable

OUTER SHEATH (HDPE / LSZH)

CORRUGATED STEEL RTAPE ARMOUR

POLYSTER / W.S TAPE

GLASS ROVING

FLOODING JELLY

LOOSE TUBE WITH OPTICAL FIBER

LOOSE TUBE WITH OPTICAL FIBER

FRP Rod

Outer Sheath

Rip Cord

ECCS Armour

Water Swellable Tape

Water Swellable Yarns

Loose Tube

Optical Fibers with Thixotropic Jelly

23

Avalon armoured fiber cables (Multitube or Unitube designs) are used for 10Gbps networks to meet the requirement of continuous growing of high data rates. The OM3 fiber cable has been developed according to the latest 10 Gbit standards and allows the data transmission over a distance up to max 300m at 850nm.

The mechanical strength is provided by the corrugated steel tape and glass yarn strength member adding extra shield against rodent and compression for direct burial application. The outer jacket is flame retardant and Low Smoke Zero Halogen. The Tube encloses multiple coated fibers that are surrounded by thixotropic gel compound that protects the cable from moisture in external environment.

Ordering Information

Part No.

*

ANFC-OM4-X-AR

ANFC-OM3-X-AR

ANFC-OM2-X-AR

Description

Avalon Fiber Optic Outdoor Loose Tube Armoured Cable OM4

Avalon Fiber Optic Outdoor Loose Tube Armoured Cable OM3

Avalon Fiber Optic Outdoor Loose Tube Armoured Cable OM2

ANFC-OM1-X-AR

Avalon Fiber Optic Outdoor Loose Tube Armoured Cable OM1

* X – No: of Cores – 02, 04, 06, 08, 12, 24, 48, 96 Cores etc.

Quality is the priority

www.avalonnetworks.co.uk

Multimode Un-Armoured Fiber Cable

OUTER SHEATH (HDPE / LSZH)

STRENGTH MEMBER (FRP)

GLASS ROVING

LOOSE TUBE

JELLY FILLED TUBE WITH OPTICAL FIBERS

RIP CORD

OUTER SHEATH (HDPE/LSZH)

POLYESTER TAPE

JELLY

LOOSE TUBE WITH OPTICAL FIBERS

STRENGTH MEMBER (FRP)

Avalon multimode optical fiber cable is recommended for duct installation. All six tubes are constructed of PBPT material with eight color coded optical fibers located in each tube. LSZH sheath allows indoor installation. The cable is protected against rodent, but is not recommended for direct burial application.

The tube encloses multiple coated fibers that are surrounded by thixotropic gel compound that protects the cable from moisture in external environment. The Fiber Reinforced Plastic (FRP) rod is present at the center of the core and PBTB loose tubes. It is filled with water resistance filing compound, containing primary coated fibers that are stranded around the central strength member (FRP) into a compact and circular cable core.The outer sheath is made of HDPE/LSZH.

Ordering Information

Part No.

*

ANFC-OM4-X-LT

ANFC-OM3-X-LT

Description

Avalon Fiber Optic Un-Armoured Cable - Multimode OM4

Avalon Fiber Optic Un-Armoured Cable - Multimode OM3

ANFC-OM2-X-LT

Avalon Fiber Optic Un-Armoured Cable - Multimode OM2

ANFC-OM1-X-LT Avalon Fiber Optic Un-Armoured Cable - Multimode OM1

* X – No: of Cores – 02, 04, 06, 08, 12, 24, 48, 96 Cores etc.

Quality is the priority

24

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

Fiber Optic Patch Panel

Avalon 12, 24 and 48 ports sliding patch panels can be ordered for ports such as SC, LC, ST or FC type. The panel can also be pre- loaded completely with the required adapters and simple management kit. The sliding system in its basic form can be supplied with or without adapters. The tray is locked in place and has two plastic catches for simple installation. When fully extended the tray is designed to lower at 45 degrees or move the tray to the side and locks at 10 degrees only. It fully provides a perfect working platform for simple installation and easy maintenance.

12 Ports Fiber Patch Panel 24 Ports Fiber Patch Panel 48 Ports Fiber Patch Panel

Specifications

Element

U Size

Width

1U

483mm

Number of ports 12

12 Port

Depth 200mm

Weight

Packaged

Dimensions

IP Rating

2.8kgs fully

450mm W X 55mm H x

260 mm D

IP20

Adapter Options

SC Duplex/Quad

Cable Entry 20mm 2

Mounting adjustment range

50mm

Material Cold Rolled Steel

Material thickness 1.2mm

Material coating Powder coating

Colour

Black RAL 9004

Operating

Temperature

Compliant to

-40°C to + 50°C

RoHS, Reach / SVHC

Designed in accordance

TIA/EIA 568.C, ISO/IEC

11801, EN 50173,IEC 60304

24 Port

1U

483mm

200mm

2.8kgs fully

450mm W X 55mm H x

260mm D

IP20

SC /FC/ST/LC/E2000

24

2

50mm

2U

483mm

200mm

48 Port

2.8kgs fully

520 x 310 x 222 mm

IP20

SC /FC/ST/LC/E2000

48

2

50mm

Cold Rolled Steel

1.2mm

Powder coating

Black RAL 9004

-40°C to + 50°C

RoHS, Reach / SVHC

TIA/EIA 568.C, ISO/IEC

11801, EN 50173,IEC 60304

Cold Rolled Steel

1.2mm

Powder coating

Black RAL 9004

-40°C to + 50°C

RoHS, Reach / SVHC

TIA/EIA 568,C, ISO/IEC

11801, EN 50173,IEC 60304

Ordering Information

Fiber Type Number of Ports

FC

LC

ST

SC

12

ANPP-12-1U-FC

ANPP-12-1U-LC

24 48

ANPP-24-1U-FC ANPP-48-2U-FC

ANPP-24-1U-LC ANPP-48-2U-LC

ANPP-12-1U-ST

ANPP-24-1U-ST

ANPP-48-2U-ST

ANPP-12-1U-SC ANPP-24-1U-SC ANPP-48-2U-SC

25

Quality is the priority

www.avalonnetworks.co.uk

APC Fiber Patch Cords

Avalon APC fiber patch cords support high speed data applications over installations that include entrance facilities, carrier equipment, telecommunications, patch field and CATV etc.

Our APC patch cords are 100% factory inspected and comply with GR 326 issue 3.

FC/UPC - FC/UPC FC/UPC - SC/APC LCAPC - FCUPC SC/APC - SC/APC FCAPC - LCAPC

FCAPC - SCUPC FCAPC - FCUPC SCAPC - FCUPC FCAPC - FCAPC FCAPC - LCAPC

SCAPC - SCUPC STAPC - LCUPC STAPC - SCAPC STAPC - STAPC FCAPC - LCAPC

Specifications

Characteristics

Insertion Loss Return Loss

Fiber Type

Return Loss

Durability

Temperature Cycling

Humidity Cycling

Conditions

Singlemode , Simplex or Duplex

1000 Matings

-40 to

0

Value

< 0.2 dB

>-45dB

< 0.2 dB

< 0.2 dB

< 0.2 dB

Ordering Information

Description

ANPC-SM-XX-XX/APC-LSZH-YY-ZMT Avalon APC Single Mode Fiber Patch Cords LSZH

ANPC-SM-XX-XX/APC-YY-ZMT Avalon APC Single Mode Fiber Patch Cords

* Replace XX with SC, LC, ST or FC. YY with SP (Simplex) or DP (Duplex) and Z with 1, 2, 3... 10…or 30 meters etc.

Quality is the priority

26

27

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

UPC Fiber Patch Cords

Singlemode & Multimode

Avalon UPC fiber patch cords provide connections from active components to patch panels and to wall outlets.

The fiber patch cords are polished, crimped and tested with superior performance and manufactured as duplex.

All terminations passed the 400x visual inspection, inserted and return loss test. The fiber offers various type of connectors such as LC, SC, ST, FC, MTRJ, Duplex to Simplex type. Various fiber microns are available such 62.5/125

(0M1), 50/125 (0M2) 50/125 (0M3), 9/125 (0S1).

FC UPC Fiber Optic Patch Cords

Avalon FC fiber optic patch cord are available in both singlemode and multimode versions, and is fully intermateable with NTT-FC products. Both singlemode and multimode FC fiber patch cords come with a Zirconia ceramic ferrule with pre-polished UPC profile and APC profile in cases of singlemode. These end face types allow for faster polishing and low back reflection and optical loss, while ensuring maximum repeatability. Avalon Patch

Cords come with different connector combinations such as FC-FC, FC-LC, FC-SC, FC-ST in different lengths.

LC UPC Fiber Optic Patch Cords

Avalon LC fiber optic patch cords are ideal for high density applications. The LC fiber patch connector has a

Zirconia ceramic ferrule measuring 1.25mm O.D. with either a UPC or APC end face and provides optimum insertion and return loss. The LC fiber patch cable connector is used on small diameter mini-cordage (1.6 mm/2.0mm) as well as 3.0mm cable. The LC fiber cable connectors are available in cable assembled or one piece connectors. Avalon Patch Cords come with different connector combinations such as LC - LC, LC - SC,

LC-ST and LC-FC etc. multimode or singlemode in different lengths.

SC UPC Fiber Optic Patch Cords

Avalon SC fiber optic patch cords are ideal for a wide range of applications where back reflection must be kept to a minimum. The connector has a UPC or APC polish on the fiber optic connector end face. The SC fiber optic patch cords such as SC-LC, SC-ST, SC-FC and SC-SC etc. The SC fiber optic cable assemblies come with microns such as 9/125 (G.657 A, G.657B, G.655, G.652D), 50/125 and 62.5/125.

ST UPC Fiber Optic Patch Cords

Avalon ST fiber optic patch cords have a UPC or APC polish on the connector end face. This polish results in a highly radius domes end face surface that optimizes physical contact between the mated fiber optic cores. The

Patch cords come with different connector combinations such as ST-ST, ST-LC, ST-SC, ST-FC, fiber optic patch cables and fiber optic jumper cables. The custom design types include single mode 9/125, multimode 50/125, multimode 62.5/125, simplex and duplex.

Specifications

Characteristics

Insertion Loss Return Loss

Description

Against Reference Connector

UPC

Value

< 0.2 dB

> 50 dB

> 60 dB APC

Durability

Temperature Cycling

-40 C to +80 C (42 Cycles)

Humidity Cycling

Vibration

Flex Test

1000 Matings

< 0.2 dB

< 0.2 dB

10-55HZ

< 0.2 dB

< 0.2 dB

0 to 90 degrees to 0 to 90, 5kgf(100 cycles) < 0.2 dB

Twist Test

Straight Pull Test

Impact

0.9mm : .75kgf, 2.0mm:1.53kgf

100N Load

1.5m drop, 8times

< 0.2 dB

< 0.2 dB

< 0.2 dB

Quality is the priority

www.avalonnetworks.co.uk

Single Mode - Fiber Patch Cords

Ordering Information

Part Number *

ANPC-SM-XX-XX/UPC-LSZH-YY-ZMT

ANPC-SM-XX-XX/UPC-YY-ZMT

Description

Avalon UPC Fiber Patch Cords Single Mode LSZH

Avalon UPC Fiber Patch Cords Single Mode

OM4 - Multimode Fiber Patch Cords

Ordering Information

Part Number *

ANPC-OM4-XX-XX/UPC-LSZH-YY-ZMT

ANPC-OM4-XX-XX/UPC-YY-ZMT

Description

Avalon OM4 Fiber Patch Cords LSZH

Avalon OM4 Fiber Patch Cords

OM3 - Multimode Fiber Patch Cords

Ordering Information

Part Number *

ANPC-OM3-XX-XX/UPC-LSZH-YY-ZMT

ANPC-OM3-XX-XX/UPC-YY-ZMT

Description

Avalon OM3 Fiber Patch Cords LSZH

Avalon OM3 Fiber Patch Cords

* Replace XX with SC, LC, ST or FC. YY with SP (Simplex) or DP (Duplex) and Z with 1, 2, 3... 10…or 30 meters etc.

Quality is the priority

28

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

OM2 - Multimode Fiber Patch Cord

Ordering Information

Part Number *

ANPC-OM2-XX-XX/UPC-LSZH-YY-ZMT

ANPC-OM2-XX-XX/UPC-YY-ZMT

Description

Avalon OM2 Fiber Patch Cords LSZH

Avalon OM2 Fiber Patch Cords

OM1 - Multimode Fiber Patch Cord

29

Ordering Information

Part Number *

ANPC-OM1-XX-XX/UPC-LSZH-YY-ZMT

ANPC-OM1-XX-XX/UPC-YY-ZMT

Description

Avalon OM1 Fiber Patch Cords LSZH

Avalon OM1 Fiber Patch Cords

Fiber Optic Connectors

Avalon connectors are manufactured in accordance with ANSI/TIA/ EIA-604-2 standards. Each connector consists of a housing, a crimp sleeve and a strain relief boot. The types of fiber connectors available are FC, LC,

SC, ST in Multimode (62.5/125, 50/125) and Singlemode (9/125). Avalon APC fiber connectors polishes the fiber at either an 8 or 9 degrees angle with a radius of curvature between 5 and 12mm. Through angle polishing at the end of the fiber, one ensures that the reflection at the fiber air interface is not captured by the fiber core. This reduces the reflection level in the fiber optic system and reduces feedback problems.

Specifications

Characteristics

Insertion Loss

Mating Durability

Temperature Cycling

Humidity Cycling

Vibration

Impact

Description

500 Time

-40 C to + 85 C

(42 Cycles)

0

75

95% / 336hr

10-55 Hz ( 2 Hrs)

1.5m drop, 8 Times

Value

< 0.2

< 0.2

< 0.2

< 0.2

< 0.2

< 0.2

< 0.2

Quality is the priority

www.avalonnetworks.co.uk

FC Fiber Optic Connector

Avalon FC Connectors are specifically designed for telecom applications and provide a non-optical disconnect performance. This is designed with a threaded coupling for durable connection. The ferrule is UPC finished to a pre-radius, which ensures low back reflection. The Connector is available with Zirconia or stainless alloy ferrules.

LC Fiber Optic Connector

Avalon LC connectors provide a pull-proof design and small size perfect for high density applications. The connector comes with Zirconia ferrule about half the size of a standard SC ferrule. The LC fiber optic connector provides a good performance and can be ordered either for singlemode or multimode fiber optic applications.

The connector also incorporates a unique latching mechanism that provides stability in the system rack mounts.

SC Fiber Optic Connector

Avalon SC connectors are non-optical disconnect connector with a 3.0 mm pre-radiused Zirconia ferrule. Available in simplex and duplex styles, this connector features a push - pull connection design for quick patching of cables into rack or wall mounts.

ST Fiber Optic Connector

Avalon ST connectors utilize a bayonet twist-lock connection with 3.0mm ferrule. Available in singlemode and multimode versions, the ST connector features reliable and durable field installation. The design of the ST connector enables installers to crimp the back of the body directly onto the cable jacket.

Ordering Information

Part Number *

Condition

Singlemode Connectors

ANCN-SM-XX-YYY

Avalon Single Mode Connector

Multimode Connectors

ANCN-OM1-XX

ANCN-OM2-XX

Avalon OM1 Connector

ANCN-OM3-XX

ANCN-OM4-XX

Avalon OM2 Connector

Avalon OM3 Connector

Avalon OM4 Connector

* Replace XX with SC, LC, ST or FC and YYY with APC or UPC

Fiber Optic Pigtails

Specifications

Characteristics

Insertion Loss

Return Loss

Conditions

Value

Against Reference Connector < 0.2 dB

SPC

> 40 dB

UPC

APC

> 50 dB

> 60 dB

Durability

Temperature

Cycling

Humidity

Vibration

Flex Test

1000 Matings

-40 C to +80 C

(42 Cycles)

0

< 0.2 dB

< 0.2 dB

< 0.2 dB

10 to 55 HZ ( 2 hours)

0 to 90 degrees to 0 to 90, 5kgf

(100 cycles)

< 0.2 dB

< 0.2 dB

Twist Test

0.9mm : 0.75kgf, 2.0mm:1.53 kg < 0.2 dB

Straight Pull Test 100 N Load

Impact 1.5m drop, 8 times

< 0.2 dB

< 0.2 dB

Quality is the priority

30

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

Avalon fiber optic pigtails come with 0.2mm or 0.9mm fiber cable diameter and are usually installed inside the ODF unit. Avalon offers different types of pigtails such as SC, ST, FC and LC with microns such as 62.5/125 (OM1) , 50/125

(OM2), 50/125 (0M3) for multimode and 09/125 for singlemode types. These pigtails are commonly used for splicing on to outside plant or riser rated fiber optic cables. All pigtails are jacketed as PVC or LSZH and comply with the latest ITU-T recommendation G.652D and G.657A. The angle polished (APC) pigtails are made by polishing the fiber either at 8 or 9 degrees angle with a curvature between 5mm and 12mm. The fiber has a typical insertion loss of 0.2dB per connection and APC polished end faces at 65dB minimum return loss. These pigtails have passed the international standards of TIA/EIA-568-B.3, ISO/IEC 11801 OS1 and comply with the UL 1666 flame rating.

SC Fiber Optic Pigtails

Avalon SC fiber optic pigtail connectors compose of singlemode and multimode types, they are premium grade connectors with 0.9mm outer diameter cables either of a simplex or duplex construction. It is a single piece construction and full proof design. The SC type pigtail is a low cost but high performance pigtail.

ST Fiber Optic Pigtails

Avalon ST fiber optic pigtail comes with 0.9mm outer diameter cable. It has a metal outer body and along spring loaded ferrule that holds the optical fiber. The ST cable can be 9/125 singlemode or 50/125 or 62.5/125 multimode.

This connector is of the older generation, but it is still widely used in fiber optic communications especially for multimode networks.

LC Fiber Optic Pigtails

Avalon LC fiber pigtails come with premium grade connectors come with 0.2mm or 0.9mm outer diameter cables either in simplex or duplex construction. It features the RJ-45 style interface with low insertion loss and low back refl

-ection with a high precision alignment. The connector comes with Zirconia ceramic ferrule.

FC Fiber Optic Pigtails

Avalon FC fiber optic pigtail composes of singlemode and multimode types and comes with a Zirconia ceramic ferrule. The FC connector has a low back reflection and optical loss while ensuring maximum repeatability.

Ordering Information

Singlemode Part No.* Description

ANPT-SM-XX/YYY-ZMT

Multimode Part No.*

ANPT-OM1-XX-LSZH-ZMT

ANPT-OM2-XX-LSZH-ZMT

ANPT-OM3-XX-LSZH-ZMT

ANPT-OM4-XX-LSZH-ZMT

ANPT-OM1-XX-ZMT

ANPT-OM2-XX-ZMT

ANPT-OM3-XX-ZMT

ANPT-OM4-XX-ZMT

Avalon Single Mode Fiber

Pigtail

Description

Avalon OM1 Fiber LSZH Pigtail

Avalon OM2 Fiber LSZH Pigtail

Avalon OM3 Fiber LSZH Pigtail

Avalon OM4 Fiber LSZH Pigtail

Avalon OM1 Fiber Pigtail

Avalon OM2 Fiber Pigtail

Avalon OM3 Fiber Pigtail

Avalon OM4 Fiber Pigtail

Fiber Optic Splice Sleeve

Avalon Splice Sleeves are a combination of transparent plastic tubing and stainless-steel rods that are ideal for safeguarding fusion fiber optic splices in field and factory operations. It can be used in wall-mount, aerial strand-mount, pedestal, underground, strand-mount and pole-mount applications.

Ordering Information

Part Number *

ANFS-100

Description

Fiber Sleeve for splicing (Pack of 100)

31

Quality is the priority

www.avalonnetworks.co.uk

Fiber Optic Adapters

SC/UPC

FC/UPC ST/UPC FC/APC ST/APC SC/APC

Avalon fiber optic adapters compose of FC, SC, ST, LC, and hybrid fiber optic adapters either singlemode or multimode including simplex and duplex types. The Avalon adapters are used to load in a fiber patch panel or work outlets. It complies with the international standards of TIA/EIA 568-0.3. Avalon APC Adapters are mechanical devices designed to align optical fiber connectors.

SC Fiber Optic Adapter

Avalon fiber optic adapters consist of plastic housing. The singlemode SC UPC is labelled as blue color whereas the multimode SC comes in beige color. The adapters generally come with ceramic sleeves and bronze sleeves which are multimode types.

LC Fiber Optic Adapter

Avalon LC fiber optic adapters come as simplex or duplex and in single mode and multimode versions with plastic housing and Zirconia sleeve. The optional bronze sleeve adapters are for multimode version.

ST Fiber Optic Adapter

Avalon ST fiber optic adapters come as simplex or duplex and in singlemode and multimode versions with plastic housing and Zirconia sleeve. The optional bronze sleeve adapters are for multimode version.

FC Fiber Optic Adapter

Avalon FC square fiber optic adapter has a standard body style with nickel plated brass or nickel plated zinc housing. The FC round fiber optic adapters come with a choice of D Flange (08.85 x 7.95mm) or double D flange

(9.35 x 7.65mm), and feature nickel plated brass housing for corrosion resistance.

Specifications

Characteristics

Insertion Loss

Return Loss

Mating Durability

Temperature

Humidity Cycling

Vibration

Impact

Condition

1000 times

75 , 95%/336hr

10-55Hz (2hr)

1.5m drop, 8 times

Value

>=0.2dB

>=45dB

0.20

0.20

0.20

0.20

0.20

LC/UPC LC/APC

Ordering Information

Singlemode Part No.*

ANA-SM-XX-XX/YYY-ZZ

Multimode Part No.*

ANA-OM1-XX-XX/UPC-ZZ

Description

Avalon Singlemode Adapter

Description

Avalon OM1 Multimode Adapter

ANA-OM2-XX-XX/UPC-ZZ

Avalon OM2 Multimode Adapter

ANA-OM3-XX-XX/UPC-ZZ Avalon OM3 Multimode Adapter

ANA-OM4-XX-XX/UPC-ZZ Avalon OM4 Multimode Adapter

Multimode SC

Simplex

Multimode LC

Duplex

* Replace XX with SC, LC, ST or FC, YYY with APC or UPC and ZZ with SP (Simplex) and DP (Duplex)

Quality is the priority

32

Fiber Optic Splitter

FIBER OPTIC SOLUTIONS www.avalonnetworks.co.uk

33

Avalon’s PLC (Planar Lightwave Circuit) Splitters are branching devices that are used to distribute optical signals to multiple locations for processing. They are designed for FTTX passive optical networks, CWDM, DWDM and optical cable TV Systems etc. Our PLC splitter performs superbly across temperatures and wave lengths providing low insertion, low PDL, excellent uniformity and low return loss. They come in various configurations of 1X2, 1X4,

1X8.1X16 …upto 1X64. The Connectorized PLC Splitters are available with different choices of fiber optic connectors such as LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, and ST/UPC etc.

Features

• Compact design

• Low insertion loss and low PDL High reliability

• High channel counts

• Wide wavelength range

• Wide operating temperature range

• Customized packaging and configuration

Applications

FTTx Systems

LAN, WAN and Metro Networks Analog/Digital

Passive Optical Networks CAM/ Networks

Other applications in fiber optic systems

Specifications

Port Configuration

Fiber

Operation Wavelength (nm)

Insertion Loss (dB)

Uniformity (dB)

Polarization Dependent Loss (dB)

Return Loss (dB)

Directivity (dB)

Operating Temperature (°C)

Storage Temperature ( °C)

Dimension (mm)- (L)(W)(H)

Nx4

SMF-28 or SMF-28e

1260 - 1620

7.4/7.2

0.5

0.2

Nx8

10.7/10.5

Nxl6

13.7/13.5

0.8

0.2

50

55

1.2

0.3

-40 to +80

-60 to +80

40 4 4

Nx32

16.9/16 .5

1.5

0.3

55 7 4

Ordering Information

Part Number *

ANS-1*2-XX/YYY

Description

Avalon PLC SPLITTER 1X2

ANS-2*8-XX/YYY

ANS-2*32-XX/YYY

ANS-2*64-XX/YYY

Avalon PLC SPLITTER 2X8

Avalon PLC SPLITTER 2X32

Avalon PLC SPLITTER 2X64

* Replace XX with SC, LC, FC or ST

YYY with APC or UPC

Quality is the priority

www.avalonnetworks.co.uk

2/4 Core FTTH Termination Box

Avalon’s termination boxes come in different sizes. The smaller size fiber optic terminal box is used for fiber optic distribution and organization. Our typical fiber terminal boxes come with 4, 8 and 16 ports. We have different FTTH termination boxes which can be used for indoor or outdoor terminations and distribution. The fiber optic boxes are made of cold rolling steel and the surface of the box is made up of dim blowing plastic. This type of fiber optic box is available with a variety of adapter cutouts. Additional splice trays can be stacked on top to increase the capacity. Each splice tray can install up to 24 single fiber splice protection sleeves (with diameter of 2.3mm) or 6 ribbon splice protection sleeves. These splice trays can be opened individually and removed from the box.

Any excess lengths of cables/pigtails are stored as reels in the front panel.

Features

• Ability to allow cables to enter from rear or bottom of the unit.

• All fibers are positively managed to maintain a 30mm minimum bend radius.

• Optional removable rear entry cable management.

• Flip tray to allow access to connect tails and cable entry

• Compact, low profile, wall mounted unit used for small and large Business premises.

• Removable cover for easy access.

• Tamper proof cover security screws available as an option

• Unit manufactured from fire resistant UL94-V0 rated material.

• Patch cord exit unit on bottom face and are protected by two protection covers.

• Standard Colour white. Other colours available on request.

Technical Specifications

Characteristics

Maximum input cable diameter (mm)

Maximum Capacity

Maximum no. of customer feeds

Operating temperature

Material

Cap

Base

Splitter trays

Testing

Value

10mm

4 Fibers

4 Patch Cords

(5 to 95% RH)

FR High Impact Polystyrene

FR High Impact Polystyrene

FR High Impact Polystyrene

Optical Tested 1310nm,1550nm and 1625nm

Dry heat

Damp heat

Change of temperature

BS EN 60068-2-2 Test Bb

IEC 60068-2-3: 1969

IEC 60068-2-14: 1984

Vibration

Shock

Ordering Information

Part Number Description

IEC 60068-2-6: 1995

IEC 60068-2-27: 1987

Capacity Cores

ANFTTHTB-2P FTTH Termination Box 2 Port SC, E-2000 - 2 cores, LC - 4 Cores

ANFTTHTB-4P FTTH Termination Box 4 Port SC, E-2000 - 4 cores, LC - 8 Cores

Dimensions (mm)

80x 80x24

120x80x24

Quality is the priority

34

RACKS & CABINET SOLUTIONS

With over 20 years of rich experience and know-how on designing and developing Racks & Cabinets, we will definitely be your first choice and reliable selection.

Racks & Cabinet Solutions

Cabinets are a core part of the cabling system and take an irreplaceable

role in the equipment room. Nowadays cabinets not only have the simple function of storing devices but also can provide protection, stop electro-

magnetic interference and arrange equipment orderly to facilitate future

maintenance

Avalon provides a complete cabinet solution including sever cabinets, wall

mount cabinets, cable management units & mounting accessories with

active power supply devices etc

Solutions and Components

Avalon delivers strong and high quality wall mountable and free standing

racks from sizes 4U to 47U with different dimensions. Along with the racks,

Avalon also has a huge range of rack components like fans, shelves, locks, power distribution units and cable managers etc

Our Quality Guarantee

Avalon racks are manufactured out of solid steel in Armada CNC machines

and are powder coated through a seven tank process giving it the resistance and capability to last for years

These racks are designed in the United Kingdom and come with perforat-

ed doors to provide the required ventilation inside the rack which increases

the life of the equipment placed inside them and robust locking system to provide security

35

Racks & Cabinet Solution

Racks & Cabinets

37-41

Floor Standing Racks

Wall Mount Cabinets

Wall Mount Enclosures

Accessories

Cabinet Fan

Brush Panel

Cable Managers

Power Distribution Unit

Rack Shelf

Fan Unit

Rail Kit

Filter Kit

Rack Door

Cage Nuts & Screws

42-44

36

Floor Standing Racks

RACKS & CABINET SOLUTIONS www.avalonnetworks.co.uk

37

Avalon floor standing racks are feature-rich rack enclosures optimized for easy installation, managing cables, integrating power distribution and maximizing airflow. These racks are multi-functional rack enclosures designed to meet current IT market trends and applications ranging from high density computing and networking to broadcast and audio-video. With a strong focus on cooling, power distribution, cable management and environmental monitoring, the Avalon rack enclosure provides a reliable rack-mounting environment for mission-critical equipment.

Power Distribution

• Max current: 13 Amps

• Max output Power: 3250 Watts

• Rated voltage: 200 - 250 Volts 50-60 HZ

• Six outlet UK Type

• Lower noise, Less than 48dB, Air flow 50 110 CBM/H

Cabinet Features

• Earthing screw

• 19” mounting angles

• Front glass door with lock and handle

• Rear metal door with lock

• Removable side panels

• Adjustable jacking feet

• Cooling fans fitted in a fan tray with cable for connection

• Extra cage nuts provided (30 Nos)

• Both the doors can be mounted to be opening from either side.

• Lock on the front door with handle and rear door with duplicate keys.

• Earthing screws & two-way vertical cable managers ( for few models only)

Technical Specifications

• All steel construction

• Frame made of 1.2 mm thick SPCC

• Fixed shelves made of 1.2 mm thick SPCC (optional)

• Mounting angles made of 2.0 mm thick steel

• Strong structure of individually fabricated components

• Manufactured using CNC machines only

• Surface Finish is made of Matt Black epoxy powder coated paint (RAL 9005)

Cooling Fan With Effective Ventilation

• Lower noise, less than 48dB, air flow 50 110 CBM/H

Quality is the priority

www.avalonnetworks.co.uk

Ordering Information

Part No.

AN-FS12U600X600

AN-FS15U600X600

AN-FS15U600X800

AN-FS18U600X600

AN-FS18U600X800

AN-FS18U600X1000

AN-FS22U600X600

AN-FS22U600X800

AN-FS22U600X1000

AN-FS22U800X1000

AN-FS24U600X800

AN-FS24U800X1000

Description Size Width Depth

12 U 600(W) x 600(D) - Floor Standing Rack 12U 600mm 600mm

15 U 600(W) x 600(D) - Floor Standing Rack

15 U 600(W) x 800(D) - Floor Standing Rack

22 U 600(W) x 600(D) - Floor Standing Rack

27 U 600(W) x 600(D) -

18 U 600(W) x 800(D) - Floor Standing Rack

18 U 600(W) x 1000(D) - Floor Standing Rack

22 U 600(W) x 800(D) - Floor Standing Rack

22 U 800(W) x 1000(D) - Floor Standing Rack

24 U 800(W) x 1000(D) - Floor Standing Rack

15U 600mm 600mm

15U 600mm 800mm

18U 600mm 600mm

18U 600mm 800mm

18U 600mm 1000mm

22U 600mm 600mm

22U 600mm 800mm

22U 600mm 1000mm

22U 800mm 1000mm

24 U 600(W) x 800(D) - Floor Standing Rack 24U 600mm 800mm

24U 800mm 1000mm

AN-FS27U600X600

AN-FS27U600X800

AN-FS27U800X800

27 U 600(W) x 800(D) - Floor Standing Rack 27U 600mm 800mm

27 U 800(W) x 800(D) - Floor Standing Rack 27U 800mm 800mm

AN-FS27U800X1000 27 U 800(W) x 1000(D) - Floor Standing Rack 27U 800mm 1000mm

AN-FS27U600X1000 27 U 600(W) x 1000(D) - Floor Standing Rack 27U 600mm 1000mm

AN-FS32U600X600

32 U 600(W) x 600(D) - Floor Standing Rack 32U 600mm 600mm

AN-FS32U600X800 32 U 600(W) x 800(D) - Floor Standing Rack 32U 600mm 800mm

AN-FS32U600X1000 32 U 600(W) x 1000(D)- Floor Standing Rack 32U 600mm 1000mm

AN-FS37U600X600

AN-FS37U600X800

AN-FS37U600X1000

AN-FS37U800X800

AN-FS37U800X1000

AN-FS42U600X600

AN-FS42U600X800

37 U 600(W) x 600(D) - Floor Standing Rack

37 U 600(W) x 800(D) - Foor Standing Rack

37 U 600(W) x 1000(D) - Floor Standing Rack

37 U 800(W) x 800(D) - Floor Standing Rack

37U 600mm 600mm

37U 600mm 800mm

37U 600mm 1000mm

37U 800mm 800mm

37U 800mm 1000mm

42U 600mm 600mm

42 U 600(W) x 800(D) - Floor Standing Rack 42U 600mm 800mm

AN-FS42U800X800 42 U 800(W) x 800(D)- Floor Standing Rack 42U 800mm 800mm

AN-FS42U600X1000 42 U 600(W) x 1000(D) - Floor Standing Rack 42U 600mm 1000mm

AN-FS42U800X1000 42 U 800(W) x 1000(D) - Floor Standing Rack 42U 800mm 1000mm

AN-FS42U800X1200 42 U 800(W) x 1200(D) - Floor Standing Rack 42U 800mm 1200mm

AN-FS47U800X800 47 U 800(W) x 800(D) - Floor Standing Rack

AN-FS47U800X1000

47 U 800(W) x 1000(D) - Floor Standing Rack

47U 800mm

800mm

47U 800mm 1000mm

Golden Series Racks

AN-FS42U600X800G

42U x 600(W) x 800(D) - Golden Series Rack

42U 600mm 800mm

AN-FS42U600X1000G 42U x 600(W) x 1000(D) - Golden Series Rack 42U 600mm 1000mm

AN-FS42U800X800G 42U x 800(W) x 800(D) - Golden Series Rack 42U 800mm 800mm

AN-FS42U800X1000G 42U x 800(W) x 1000(D) - Golden Series Rack 42U 800mm 1000mm

AN-FS42U800X1200G 47U x 800(W) x 1200(D) - Golden Series Rack 47U 800mm 1200mm

AN-FS47U800X1000G 47 U 800(W) x 1000(D) Floor Standing Rack

47U 800mm 1000mm

AN-FS47U800X1200G 47 U 800(W) x 1200(D) Floor Standing Rack

47U 800mm 1200mm

Quality is the priority

38

RACKS & CABINET SOLUTIONS www.avalonnetworks.co.uk

Wall Mount Cabinets

39

Single Section Wall Mount Cabinet Double Section Wall Mount Cabinet

Avalon Wall Mount Cabinets are feature-rich enclosures optimized for easy installation, managing cables, integrating power distribution and maximizing airflow. These racks are multi-functional rack enclosures designed to meet current IT market trends and applications ranging from high density computing and networking to broadcast and audio-video. With a strong focus on cooling, power distribution, cable management and environmental monitoring, the Avalon rack enclosure provides a reliable rack-mounting environment for mission-critical equipment.

Cabinet Features

• 19” Mounting Angles

• Front glass door with lock (Tempered glass)

• Door can be mounted to be opening from either side

• Lock on the front door with duplicate keys

• Removable side panels

• Extra cage nuts provided

• Earthing Screw

• Cooling fan for effective ventilation (Optional)

• A swing rear section with lock (100mm Depth)- Contruction adds to the operation and maintenance.

Technical Specifications

• All Steel construction

• Frame Made of 1.2 mm thick SPCC

• Fixed shelves made of 1.2 mm thick SPCC (Optional)

• Mounting Angles made of 2.0 mm thick steel

• Strong structure of individually fabricated components

• Manufactured using CNC machines only

Surface Finish: Matt Black Epoxy Powder Coated Paint (RAL9005)

Cooling Fan With Effective Ventilation (Optional)

• Lower noise, less than 48dB, Air flow 50 - 110 CBM/H

Quality is the priority

www.avalonnetworks.co.uk

Ordering Information

Part No.

AN-WM4U600X450

AN-WM6U600X450

AN-WM6U600X550

AN-WM9U600X450

AN-WM9U600X550

AN-WM12U600X450

AN-WM12U600X550

AN-WM15U600X450

AN-WM15U600X550

AN-WM18U600X450

AN-WM18U600X550

AN-WM18U600X600

Description

4 U x 600(W) x 450(D) Wall Mount Cabinet

6 U x 600(W) x 450(D) Wall Mount Cabinet

6 U x 600(W) x 550(D) Wall Mount Cabinet

9 U x 600(W) x 450(D) Wall Mount Cabinet

9 U x 600(W) x 550 (D) Wall Mount Cabinet

12 U x 600(W) x 450(D) Wall Mount Cabinet

15 U x 600(W) x 550(D) Wall Mount Cabinet

18 U x 600(W) x 450(D) Wall Mount Cabinet

18 U x 600(W) x 550(D) Wall Mount Cabinet

18 U x 600(W) x 600(D) Wall Mount Cabinet

Size Width

4U

6U

6U

9U

9U

12U

12U

15U

15U

18U

18U

18U

600mm

600mm

600mm

600mm

600mm

600mm

600mm

600mm

600mm

600mm

600mm

600mm

Depth

450mm

450mm

550mm

450mm

550mm

450mm

550mm

450mm

550mm

AN-WM15U600X600 15 U x 600(W) x 600(D) Wall Mount Cabinet 15U 600mm 600mm

450mm

550mm

600mm

Top 7 tips while buying server cabinets

1. Decide if you need an enclosed cabinet or an open Rack.

2. Assess the width, depth and height that you require depending on the equipment you will be putting inside the Rack

3. Make a list of the equipment which would be placed in the Rack . It can include CPU, Monitors,

Keyboards, Modem, servers, Switches, Hubs, routers and UPSs etc.

4. Always ensure that you do not buy a rack that houses your equipment perfectly. Provide for future growth by having extra space in the Rack as you would not know which equipment would be added in the future.

5. One Rack unit (generally denoted as “U”) is 1.75’’ (4.4 cm). E.g. A 24U Rack has 24 spaces for equipment and is 42” high (105.6 cm).

6. Measure the width, depth and height of the server room before you purchase the Rack.

7. Always ensure that there is at least 10 inches gap between the top of the Rack and the ceiling of the room for effective ventilation.

Quality is the priority

40

RACKS & CABINET SOLUTIONS www.avalonnetworks.co.uk

12U - Wall Mount Enclosures

Network Cabinets

41

Avalon wall mount enclosures are designed to satisfy the most specific requirements of communication and networking and are specially manufactured for telecom services eg. Etisalat and DU. These come with cable entry from top to bottom, front section with glass door, keys and locks. These are constructed with 1.0 mm steel frames are made of 0.8 mm steel and with 19’’ vertical mounting rails (1.0 mm thick steel).

Cabinet Features

• 19 " Mounting Angles

• Front glass door with lock

• Door can be mounted to be opening from either side

• Cable entry from top to bottom

Specifications

Make

Type

• Dimensions Type

Size

: AVALON

: Wall mount Enclosure

: 19 inch standard

: 12U

Technical Specifications

All Steel construction

Frame Made of 1.2 mm thick SPCC

Fixed shelves made of 1.2 mm thick SPCC (Optional)

Mounting Angles made of 1.0 mm thick steel

Strong structure of individually fabricated components

Manufactured using CNC machines only

Surface Finish : Grey Epoxy powder coated paint (RAL 7035)

Packaging

Packed in single carton

Ordering Information

Part No.

ANWM-12U600X600X150

ANWM-12U600X425X120

ANWM-12U600X600X300

Height

600

600

600

Width

600

425

600

Depth Gross Weight Net Weight

150

120

300

12

6.5

16

11

5.3

14

Quality is the priority

www.avalonnetworks.co.uk

Accessories

Cabinet Fan

Avalon rack fans are used to help facilitate air flow within the rack by adding ventilation where it is needed the most. These rack fans can be mounted in cabinet doors, cabinet sides and cabinet roofs.

Dimensions

• 120mm×120mm×38mm

Ordering Information

Part No.

AN-FN13A-20

Description

Cabinet Fan

.......................................................................................................................................................................................................

Brush Panel

Avalon brush panels are 1U cable pass through panels with brush strip. The brush strip blocks unwanted airflow inside rack enclosures and server cabinets. This panel improves the cooling efficiency and segregates cold aisle from hot aisle. These panels are manufactured from mild steel and are powder coated.

Package Includes

1 piece of brush panel

Mounting hardware

Ordering Information

Part No.

AN-1UBRPNL

Description

Brush Panel

.......................................................................................................................................................................................................

Horizontal Cable Manager with Cover

Avalon horizontal cable managers with cover are capable of managing cables on the front and rear of any standard EIA 19” rack or cabinet. These cable organisers feature a removable top cover that makes it easy to add or remove bundled cables quickly. The duct also offers a series of fingers on either side or pass-through holes at the back to help you route your cables wherever you need them and reduce cable strain in the process.

Ordering Information

Part No.

AN-HCM-C

Description

19” Horizontal Cable Managers with cover,1U

.......................................................................................................................................................................................................

Horizontal Cable Managers with Rings

Avalon horizontal cable managers with rings are capable of managing cables on the front and rear of any standard EIA 19" rack or cabinet. These panels are constructed of a steel panel with plastic D-rings Mounted to any rack. The horizontal panels have pass-through holes and are available as either front and rear versions or front only versions.

Ordering Information

Part No.

AN-HCM-OA-4

AN-HCM-OA-5

Description

19” Horizontal Cable Managers with 4 Rings,1U

19” Horizontal Cable Managers with 5 Rings,1U

Quality is the priority

42

RACKS & CABINET SOLUTIONS www.avalonnetworks.co.uk

43

Horizontal Cable Managers - Open Type

Avalon horizontal cable managers which are closed type are capable of managing cables on the front and rear of any standard EIA 19″ rack or cabinet. These panels are constructed of a steel panel with gaps in between for easy access. The horizontal panels have pass-through gaps and are available as either front and rear versions or front only versions.

Ordering Information

Part No.

AN-HCM-OT

Description

19” Horizontal Cable Managers with open type access

......................................................................................................................................................................................................

Horizontal Cable Managers - Closed Type

Avalon Horizontal Cable Managers which are closed type are capable of managing cables on the front and rear of any standard EIA 19″ rack or cabinet. These panels are constructed of a steel panel with gaps in between for easy access. Horizontal panels shall have pass-through gaps and shall be available in both front and rear versions and front only versions.

Ordering Information

Part No.

AN-HCM-CT

Description

19” Horizontal Cable Managers – Closed Type

......................................................................................................................................................................................................

Power Distribution Units

PDU, UK Type With Circuit Breaker

Avalon Power Distribution Units (PDU’s) are used for controlling electrical power in a data center. The circuit breaker is suitable for lines with AC 50 Hz frequency and voltage from 230V – 400V. The circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by overload or short circuit. Its basic function is to interrupt current flow after protective relays detect a fault.

Ordering Information

Part No.

*

AN-XWPDU13UK-BR

Description

PDU – UK Type with Circuit breaker

* X can be 6 Way , 8 Way or 10 Way

PDU, UK Type

Avalon Power Distribution Units (PDU’s) are used for controlling electrical power in a data center.

Features

• UK Type BS1363 Sockets

• 19” Rack Mountable

• Master on /off switch

Ordering Information

Part No.

*

AN-XWPDU13UK

Description

PDU - UK Type

* X denotes 6, 8 or 10 Way PDU.

.....................................................................................................................................................................................................

PDU, German Type

Avalon Power Distribution Units (PDU’s) are used for controlling electrical power in a data center.

Features

• German sockets

19” rack mountable

Master on /off switch

Ordering Information

Part No.

*

Description

AN-XWPDU13G PDU- German Type

* X denotes 8 or 10 Way PDU.

Quality is the priority

www.avalonnetworks.co.uk

Other Accessories

19" Rack Mount Keyboard Sliding Tray

(AN-KBTR300MM)

19” Rack Sliding Shelves

(AN-SLD600MM, AN-SLD800MM, AN-SLD1000MM)

...........................................................................................................................................................................................................

General Purpose 1U Fan Unit (AN-1UFNX3)

1U Universal Rack Mount Sliding Shelf

(AN-1U/SLD300MM)

...........................................................................................................................................................................................................

1U Rack Mount Shelf (AN-1U300MM) 2U Rack Mount Shelf (AN-2U350MM)

...........................................................................................................................................................................................................

19” Fixed Rack Shelf

(AN-FX600MM, AN-FX800MM, AN-FX1000MM)

19" 300mm L-Rail / Support brackets

(AN-LRAIL-300)

...........................................................................................................................................................................................................

19” 2U server cabinet drawer locker

(AN-2U/DWR3OOMM)

Rail Kit

(AN-1UADLRAIL1000M)

...........................................................................................................................................................................................................

Rack Door

(AN-800MM27U/DP, AN-600MM42U/SP,

AN-800MM42U/DP, AN-800MM47U/DP)

Fan Filter Kit

(AN-120x120-FK)

Front Panel Mounting Hardware (Cage Nut & Screws)

(AN-CAGN/10)

Quality is the priority

44

CERTIFICATIONS AND APPROVALS

CERTIFICATIONS AND APPROVALS

3933 US Route 11

Cortland, New York 13045 USA

Phone Number: (800) 345-3851

Fax Number: (607) 758-6637

Web: www.intertek.com

ETL Verified Certificate of Conformance Number: 102600457CRT-001

On the basis of the tests undertaken, the sample(s) of the below product have been found to comply with the essential requirements of the referenced specifications at the time the tests were carried out.

Rendered to:

Avalon Networks (UK) Ltd.

68 Manning Gardens, Croydon, Surrey,

London CR0 7DU, United Kingdom

Contact: Mr. Agilio Pereira

Product Tested

Category 6 U/UTP CM 24 AWG Modular Cord

Model(s) and or Brand Name:

Category 6 Patch Cord, part number not available (Length = 1 meter to 10 meters)

Standard(s)/Specification

Product labeling shall include:

ANSI/TIA-568-C.2 Category 6 with the applicable electrical transmission characteristics

ETL Verified to ANSI/TIA-568-C.2 Category 6 and the product model(s) and or brand name

Continuing compliance to this specification is monitored through production testing, ongoing inspections by

Intertek at the production facility and random sample testing.

Date Issued:

May 31, 2016

Approved By:

Antoine Pelletier, Project Engineer

This verification supersedes all previous verifications with the noted Verification/Report number(s) dated before this verification notice.

NOTE: This verification is part of the full test report(s) and should be read in conjunction with it.

This Verification is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client.

Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this Verification. Only the

Client is authorized to copy or distribute this Verification. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this

Verification are relevant only to the sample tested. This Verification by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.

CERTIFICATIONS AND APPROVALS

3933 US Route 11

Cortland, New York 13045 USA

Phone Number: (800) 345-3851

Fax Number: (607) 758-6637

Web: www.intertek.com

ETL Verified Certificate of Conformance Number: 102604360CRT-001

On the basis of the tests undertaken, the sample(s) of the below product have been found to comply with the essential requirements of the referenced specifications at the time the tests were carried out.

Rendered to:

Avalon Networks (UK) Ltd.

68 Manning Gardens, Croydon, Surrey,

London CR0 7DU, United Kingdom

Contact: Mr. Agilio Pereira

Product Tested:

4 pair, 23 AWG, UTP, CMR, Non-Plenum Riser, Horizontal (solid) Cable.

Model(s) and or Brand Name: ANC6UPGY23-305MT

Standard(s)/Specification:

Jacket marking shall include:

ANSI/TIA-568-C.2 and ISO/IEC 11801 Category 6 with the applicable electrical transmission characteristics

ETL Verified to ANSI/TIA-568-C.2 and ISO/IEC 11801 Category 6

Continuing compliance to this specification is monitored through production testing, ongoing inspections by

Intertek at the production facility and random sample testing.

Date Issued:

May 31, 2016

Approved By:

Antoine Pelletier, Project Engineer

This verification supersedes all previous verifications with the noted Verification/Report number(s) dated before this verification notice.

NOTE: This verification is part of the full test report(s) and should be read in conjunction with it.

This Verification is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client.

Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this Verification. Only the

Client is authorized to copy or distribute this Verification. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this

Verification are relevant only to the sample tested. This Verification by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.

CERTIFICATIONS AND APPROVALS

3933 US Route 11

Cortland, New York 13045 USA

Phone Number: (800) 345-3851

Fax Number: (607) 758-6637

Web: www.intertek.com

ETL Verified Certificate of Conformance Number: 102604343CRT-001

On the basis of the tests undertaken, the sample(s) of the below product have been found to comply with the essential requirements of the referenced specifications at the time the tests were carried out.

Rendered to:

Avalon Networks (UK) Ltd.

68 Manning Gardens, Croydon, Surrey,

London CR0 7DU, United Kingdom

Contact: Mr. Agilio Pereira

Product Tested:

4 pair, 23 AWG, UTP, LSOH, Non-Plenum, Horizontal (solid) Cable.

Model(s) and or Brand Name: ANC6UPGY23-305MT

Standard(s)/Specification:

Jacket marking shall include:

ANSI/TIA-568-C.2, ISO/IEC 11801 and EN 50173-1 Category 6 with the applicable electrical transmission characteristics

ETL Verified to ANSI/TIA-568-C.2, ISO/IEC 11801 and EN 50173-1 Category 6

Continuing compliance to this specification is monitored through production testing, ongoing inspections by

Intertek at the production facility and random sample testing.

Date Issued:

May 31, 2016

Approved By:

Antoine Pelletier, Project Engineer

This verification supersedes all previous verifications with the noted Verification/Report number(s) dated before this verification notice.

NOTE: This verification is part of the full test report(s) and should be read in conjunction with it.

This Verification is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client.

Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this Verification. Only the

Client is authorized to copy or distribute this Verification. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this

Verification are relevant only to the sample tested. This Verification by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.

CERTIFICATIONS AND APPROVALS

3933 US Route 11

Cortland, New York 13045 USA

Phone Number: (800) 345-3851

Fax Number: (607) 758-6637

Web: www.intertek.com

ETL Verified Certificate of Conformance Number: 102799820CRT-001

On the basis of the tests undertaken, the sample(s) of the below product have been found to comply with the essential requirements of the referenced specifications at the time the tests were carried out.

Rendered to:

Avalon Networks (UK) Ltd.

68 Manning Gardens, Croydon, Surrey,

London CR0 7DU, United Kingdom

Contact: Mr. Agilio Pereira

Product Tested:

4 pair, 23 AWG, U/FTP, LSZH, Non-Plenum, Horizontal (solid) Cable.

Model(s) and or Brand Name: ANC6AUPGY23-305MT

Standard(s)/Specification:

Jacket marking shall include:

ANSI/TIA-568-C.2, ISO/IEC 11801 and IEC 61156-5 Category 6A with the applicable electrical transmission characteristics

ETL Verified to ANSI/TIA-568-C.2, ISO/IEC 11801 and IEC 61156-5 Category

6A

Continuing compliance to this specification is monitored through production testing, ongoing inspections by

Intertek at the production facility and random sample testing.

Date Issued:

November 03, 2016

Approved By:

Antoine Pelletier, Project Engineer

This verification supersedes all previous verifications with the noted Verification/Report number(s) dated before this verification notice.

NOTE: This verification is part of the full test report(s) and should be read in conjunction with it.

This Verification is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client.

Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this Verification. Only the

Client is authorized to copy or distribute this Verification. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this

Verification are relevant only to the sample tested. This Verification by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.

Our Partners

AFL

Canada

America

Network Products

Europe

Middle East

Europe

United Kingdom

Tel: +44 796 621 9961

World

Class

Network

Products

America

North America

Tel: +1 780 932 0336

Canada

Edmonton

Tel: +1 780 932 0336 [email protected]

Middle East

United Arab Emirates

Tel: +971 4 3444 417 www.avalonnetworks.co.uk

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
