Government of India

Department of Atomic Energy



GLOBAL CENTRE FOR NUCLEAR ENERGY PARTNERSHIP

GCNEP/NIT/16/12-33 Date: 23/12/2016

NOTICE INVITING TENDER



Project  Director,  GCNEP,  Bahadurgarh,  Haryana,  on  behalf of  the President  of  India  invites  sealed  item  rate  tender  (under

Three Stage System –ELIGIBITY, TECHNICAL and FINANCIAL BID

),  from  reputed,  qualified,  experienced,  technically  and  financially  sound  agencies  for  the  work



SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV  SYSTEMS  AT  GCNEP,  JASAUR‐

KHERI, BAHADURGARH, HARYANA”.

The details are as mentioned below.

SECTION‐I





PART A: INSTRUCTIONS FOR SUBMITTING THE TENDER



1. The intending bidders must read the terms and conditions of the tender documents. He  should  only  submit  bids  if  he  considers  himself  eligible  and  he  is  in  possession  of  all  required documents.

2. The information and instruction for bidders alongwith technical bid and financial bids etc.  posted on website shall form part of the bid document.

3.

CORRIGENDUM(s), IF ANY, SHALL BE UPLOADED ON WEBSITE  www.gcnep.gov.in  ONLY.

And  the  intending  bidders  should  therefore  keep  following/  checking  the  website  regularly.





4. If  an  agency  is  found  ineligible,  after  opening  of  Eligibility  Bid,  his  tender  shall  become  invalid and the tender fee shall not be refunded.

5. Submission  of  the  tender  documents  after  the  due  date  and  time  (including  extended  period) shall not be permitted.

6. Information  and  Instructions  for  tenderers  posted  on  website  shall  form  a  part  of  this  tender document.

7. The tenderers are advised to submit their documents etc. well in advance to the Tender

Inviting  Authority,  so  that  it  should  reach  on  or  before  the  due  date  and  time.  Delay  in  receipt of hard copies due to security restriction, postal delay or delay due to any other  reasons etc. shall not be accepted and tender shall be rejected forthwith.







PART B: NIT DETAILS

NIT Number

GCNEP/NIT/16/12-33 dated 23/12/2016

Name of works

SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV

Location of work

SYSTEMS AT GCNEP,  JASAUR‐ KHERI , BAHADURGARH, HARYANA.

GCNEP, Jasaur‐Kheri, Bahadurgarh, Haryana

For more details, visit our website at www.gcnep.gov.in.

Tender Cost  Rs.500/‐ (Rupees Five hundred only)

Page | 1



Estimated Cost

Earnest Money Deposit



Cost (non‐refundable, non‐transferable)



Payable  in  the  form  of  DD/Pay  Orders  drawn  in  favour  of  ‘Pay  and

Accounts Officer BARC’, payable at Mumbai.

The  Tender  Document  can  only  be  downloaded  from  website,  and  bidders  have  to  pay  the  Tender  Fee  at  the  time  of  submission  via



above specified means.

Note: Tender Fee in the form of cheque will not be accepted.

Rs. 1,98,00,000/‐(Rupees One Hundred Ninety Eight Lakh only)



Rs. 3,96,000/‐ (Rupees Three Lakh Ninety Six Thousand only)

Payable  in  the  form  of  DD/Pay  Orders  drawn  in  favour  of  ‘Pay  and

Accounts Officer BARC’, payable at Mumbai.

Note: EMD in the form of cheque will not be accepted.



Completion Period

Security Deposit

60 Days (Calendar Days)

2.5% of the tendered value; deductible from each running bill and/ or/  as well as final bill of the contractor, as applicable

5% of the tendered value

Performance

Guarantee

Availability/  Sale  of

Tender

27‐12‐2016 to 10‐01‐2017

Pre‐Bid Meeting

12‐01‐2017,  11:30  Hrs  (Venue:  GCNEP  Transit  Office,  Bahadurgarh,

Haryana)

Due date & time for  submission of quotations



Date & time for opening



of  ELIGIBILITY  &

TECHNICAL BID

19‐01‐2017   up to 16:00 Hrs

19‐01‐2017   at 17:00 Hrs

Date & time for opening  of FINANCIAL BID

    Will be notified later

Submission of tender  The Three Stage Bid System shall consist of:



Sealed Cover‐I super‐scribed “ELIGIBILITY”.

Sealed Cover‐II super‐scribed “TECHNICAL BID”.

Sealed Cover‐III super‐scribed “FINANCIAL BID”.

(For details on enclosures, refer



PART E: Document Checklist



A  Sealed  Envelope  containing  the  above  Three  Sealed  Covers  super‐ scribed as:

NIT No: GCNEP/NIT/16/12-33 dated 23/12/2016”

“Works: SUPPLY, INSTALLATION, TESTING AND COMMISSIONING OF



AV SYSTEMS AT GCNEP, JASAUR‐KHERI, BAHADURGARH, HARYANA.”

Page | 2



Should reach the following address

  by Registered Post or Speed Post

Services of India Post, on or before the specified last date:



Project Director

Global Centre for Nuclear Energy Partnership (GCNEP)

2nd Floor, BSNL T.E. Building, Near Main Bus Stand

Bahadurgarh (Haryana) -124507

BIDS NOT RECEIVED UNDER THE PRESCRIBED THREE STAGE SYSTEM ARE

LIABLE TO BE REJECTED.

Place of opening  As Above

Note :

1. Department reserves the right to accept or reject any application(s), without assigning any  reason thereof. The applications with any condition shall be rejected forthwith.

2. Tenders not accompanied by Tender Fee and those found incomplete or received after due  date shall be rejected without assigning any reason thereof. The quotations must be sent  only by either Registered Post or Speed Post Services of India Post.

3. This Tender document can be downloaded from our website  www.gcnep.gov.in





PART C: REQUIREMENTS AND ELIGIBILTY CRITERIA



1.   Contractors who fulfill the following requirements shall ONLY be eligible to apply.

(Joint  ventures are not accepted).



2.   Bidder should be an Indian registered Company and must have at least seven (07) years of

Networking,  Telephony,  IP  Telephony  or  Audio‐Video  System  projects  implementation  experience in India, ending previous day of the last day of submission of tender.

3.   The bidder should have satisfactorily completed similar works during the last seven years  ending previous  day of last date of submission of tenders. For this  purpose cost  of  work  shall  mean gross  value of  the completed  work  including  cost of material supplied by the

Government/Client but excluding those supplied free of cost. This should be certified by an

  officer not below the rank of Project Manager/ Engineer‐In‐Charge or equivalent.

Completed THREE similar works each of value not less than the amount equal to 40% of

  the Estimated cost put to this tender.  or



Completed TWO similar works each of value not less than the amount equal to 60% of

  the Estimated cost put to this tender.  or



Completed  ONE  similar  work  of  value  not  less  than  the  amount  equal  to  80%  of  the

Estimated cost put to this tender.



Important Notes:

Page | 3

i)  Similar  work  shall  mean:  Networking,  Telephony,  IP  Telephony  or  Audio‐Video  System  works.

  ii)  ‘Cost  of  work'  shall  mean  gross  value  of  the  completed  work  including  the  cost  of  materials  supplied  by  the  Client,  but  excluding  those  supplied  free  of  cost.  The  value  of  executed works shall be brought to the current costing level by enhancing the actual value  of work at a simple rate of 7% per annum; calculated from the date of completion to the  last date of receipt of applications for tender.

4.   The bidder must have a registered office, with valid PAN/ VAT/ TIN numbers etc. The bidder  must furnish a copy of PAN, VAT details along with the quote.

5.   The  bidder  should  have  adequate  financial  stability  &  status  to  meet  the  financial  obligations  of  the  scope  of  work.  CA  Certificate  of  Financial  Turnover  for  the  last  three  consecutive financial years should be furnished.

6.   The  bidder  should  not  have  incurred  losses  in  more  than  two  years  during  the  last  five  years, ending 31 st

 March 2016.

7.   The bidder should have a solvency of 40% of the Estimated Cost put to this tender.

8.   The

bidding capacity

 of the bidder should be equal to or more than the estimated cost of

  the work put to tender. The bidding capacity shall be worked out by the following formula:

Bidding Capacity = {[A x N x 2] – B}



Where,



A=

 Maximum turn over of similar works executed in any one year during the last five years  taking  into  account  the  completed  as  well  as  works  in  progress.  The  value  of  completed

  works  shall  be  brought  to  current  costing  level  by  enhancing  at  a  simple  rate  of  7%  per  annum.



N=

 Number of years prescribed for completion of work for which bids has been invited.

B =

 Value of existing commitments and ongoing works to be completed during the period  of completion of work for which bids have been invited.

9.   List of works in hand & List of similar works carried out by them for last 7 years indicating:  i)  Agency  for  whom  executed,  ii)  Value  of  work,  iii)  Completion  time  as  stipulated  and  actual, or present position of the work.

10.

List of technical staff they possess and propose to deploy for the work.



11.

Department  reserves  the  right  of  Non‐  consideration  of  Tender  documents  of  the  agencies who are not fulfilling the NIT stipulations and/ or having adverse report on the  works carried out by them in the past.





PART D: General Rules and Directions

1.

The works have to be executed by a single party, Joint ventures are not acceptable. Partial  quotes/  quotes  for  partial  works  are  liable  to  be  rejected  without  any  further  correspondence. No joint/ multi‐party bidding is allowed.

2.

Bidder  has  to  submit  OEM  support  commitment  letter  stating  that  the  quoted  products

Page | 4



  should not be end of support for next 5 years.

3.

Bidders  are  requested  to  quote  for  above  work  as  per  the  enclosed  specifications.  All

items/ materials (including cables & connectors) offered should be of repute make/ well  established brands. The quotes must be accompanied by the make & model of the items  offered, alongwith technical datasheets. Offers without technical details are liable to be  rejected without any further correspondence.

4.

Taxes  will  be  deducted  from  the  running/  final  bill  as  per  the  prevailing  Government  norms and a TDS Certificate will be issued for the same, as applicable.

5.

Signing of Tender: In the event of the tender being submitted by a firm, it must be  signed   separately  by  each  partner  thereof  or  in  the  event  of  the  absence  of  any  partner,  it   must  be  signed  on  his behalf by a person holding a power‐of‐attorney authorizing him to  do so, such power of attorney to be produced with the tender, and it must disclose that  the firm is duly registered under the Indian Partnership Act‐1952.

6.

Declaration  by  tenderer: The  tenderers  shall  sign  a  declaration  under  the  Official

Secret  Act‐1923  for maintaining  secrecy  of  the  tender  documents,  drawings  or  other   records    connected    with    the    work    given    to    them.    The  unsuccessful  tenderers  shall  return all the drawings given to them.

7.

Guidelines for quoting the rates:  All rates shall be quoted on the prescribed tender form.

The  amount  for  each  item  should  be  worked  out  and  requisite  totals  given.  Special  care  should be taken to write the rates in figures as well as in words, and the amount in figures  only, in such a way that interpolation is not possible. The total amount should be written  both in figures and in words. In case of figures, the words “Rs.” should be written before  the figures of rupees and word “P” after the decimal figures, e.g. “Rs. 2.15 P”,  and in case  of words, the word, “Rupees” should precede and the word  “Paise”  should  be  written  at   the  end.  Unless  the  rate  is  in  whole  rupees  followed  by  the  word  'only'  it  should  invariably  be  upto  two  decimal  places.  While  quoting  the  rate  in  schedule  of  quantities,  the  word  'only'  should  be  written  closely  following  the  amount  and  it  should  not  be  written in the next line.

8.

Quoted rates to include all taxes: Sales tax, VAT, Purchase tax or any other tax on materials  in  respect  of  this  contract,  including  State  Sales  tax  and  Turnover  tax  on  transfer  of  property  as  per  Works  Contract  Act  etc.  if  any,  shall  be  payable  by  the  contractor  and

Government  will  not  entertain  any  claim  whatsoever  in  respect  of  the  same.  As  per  the  directives  of  the  Sales  Tax  Authorities,  the  tax  due  at  the  rates  notified  by  the  State

Government  from  time  to  time,  shall  be  deducted  from  the  bills  payable  to  the

Contractors, for which TDS certificate shall be issued by the Department.

9.

Filling‐up  of Financial  Bid: Unless otherwise  called for, any tender containing percentage  below / above the estimated  cost  put  to  tender  is  liable  to  be  rejected.  All  rates  shall   be    quoted    on    the    tender    form    by    the    tenderers    in  figures  and  words  shall  be  accurately  filled  in,  so  that  there  is  no  discrepancy  in  the  rates  written  in  figures  and  in  words.  The  amount  for  each  item  should  be  worked  out  and  requisite  totals  given.

However,    i)  The rate(s) must be quoted in decimal coinage. Amounts must be quoted in full rupees  by ignoring fifty paise and considering more than fifty paise as rupee one.   ii)  If  a discrepancy is found,  the rates  which correspond with the amount  worked out by  the contractor shall, unless otherwise proved, be taken as correct.

Page | 5

  iii) If the amount of an item is not worked out by the tenderer, or it does not correspond  with the rate written either in figures or in words, then the rates quoted by the tenderer in  words shall be taken as correct.   iv) Where the rate quoted by the tenderer in figures and in words tally but the amount is  not worked out correctly, the rate quoted by the tenderer will, unless otherwise proved, be  taken as correct and not the amount.       v)  In  event  no  rate  has  been  quoted  for  any  item(s),  leaving  space  both  in  figure(s),   word(s),  and  amount blank, it will be presumed that the contractor has included the cost  of this / these item(s) in other items and rate for such item(s) will be considered as zero  and work will be required to be executed accordingly.

10.

Action  in  case  of  unrealistic  rates: In  the  case  of  any  tender  where  unit  rate  of  any   item (s)  appear unrealistic,  such  tender  will  be  considered  as  unbalanced  and  in  case   the  tenderer  is  unable  to  provide satisfactory explanation, such a tender is liable to be  disqualified and rejected.

11.   Furnishing of PG & SD on acceptance of Tender:

i)  The  tenderer,  whose  tender  is  accepted,  will  be  required  to    furnish    performance   guarantee  of  5%  of  the  tendered  amount  within  the  period  specified as in  Annexure‐

D (Section‐III).  This guarantee  shall  be  in  the  form  of  Department’s  cash  receipt  (in   case  guarantee  amount  is  less  than  Rs.10,000/‐)  or  Deposit at call receipt /  Demand

Draft / Pay Order / Banker’s cheque issued by a Scheduled Bank (in case guarantee amount  is  less  than  Rs.1,00,000/‐)  or  Government  Securities  /  Fixed  Deposit  Receipt  (FDR)  or

Guarantee Bonds of any Scheduled Bank or The State Bank of India in accordance with the  prescribed form.   ii)  The  tenderer,  whose  tender  is  accepted,  will  also  be  required  to  furnish  by  way  of

Security  Deposit  for  fulfillment  of    his    contract,    an    amount    equal    to    2.5%    of    the   tendered    value   of   the    work.   The   security   deposit    will    be    collected    by deduction   from  the  running  bills  of  the  contractors  at  the  rates  mentioned  above.  The  security   amount  will  also  be  accepted  in  cash  or  in  the shape  of  Government  Securities.

Fixed  Deposit   Receipt  (FDR)   of   a   Scheduled   bank   will  also   be    accepted   for  this  purpose, provided confirmatory advice is enclosed.

12.

The  supplier  shall  not  dispatch  the  equipment  without  the  prior  approval  of  the

Department/  Users/  Inspectors  and  subsequent  written  instruction  to  do  so.  Necessary  inspection  facilities  should  be  provided  to  our  engineer  during  fabrication  at  no  extra  costs.

13.

The  bidder  shall  deliver  the  finished  components  within  the  completion  period  effective  from the date of work order issued to the bidder. Any delay which is attributable to the  contractor is liable for penalty.

Compensation for delay of work:  @ 1.5% per month of delay to be computed on per day  basis, provided always that the total amount of compensation for delay to be paid under  this condition shall not exceed 10% of the tendered value of work or of the tendered value  of  the  item  or  group  of  items  of  work  for  which  a  separate  period  of  completion  is  originally given.  The amount of compensation may be adjusted or set‐off against any sum  payable to the Contractor under this contract.

14.

If  required,  the  interested  parties  can  plan  a  visit  to  Office  Site  for  mapping  the  exact  requirements but with a prior intimation & approval of this office only.

15.

There is no free issue material. All items/material to be supplied/ used should be in brand  new factory condition.

Page | 6





16.

The Security  Deposit  shall  be  refunded  to  the contractor  after  the  completion of  on‐site  support period. 75% of Performance Guarantee shall be refunded after the completion of  supply,  installation,  testing  and  commissioning,  and  the  balance  shall  be  refunded  after  the completion of on‐site support period.

17.

The agency shall not sub‐contract any work without written consent from GCNEP.

18.

The quoted rate should be inclusive of all transportation, loading/ unloading, delivery or  any other consequential charges. No extra costs shall be payable beyond the quoted price.

19.

The contractor shall work in close cooperation with other agencies working at site, so as to  make the execution of work smooth.

20.

The safety & security of personnel, material & machinery shall be the responsibility of the  contractor. Contractor should have a qualified person carrying out the job.

21.

RESTRICTED  INFORMATION:  The  contractor  shall  ensure  strict  compliance  of  the  instructions under Section 18 of the ‘Atomic Energy Act 1962’ and under Section 5 of the

Official Secrets Act 1923’. Any contravention of the above‐mentioned provisions by the  contractor, sub‐contractor, consultant, advisor or the employees of a contractor will invite  penal consequences under the aforesaid legislation.

22.   PROHIBITION  AGAINST  USE  OF  GCNEP'S  NAME  WITHOUT  PERMISSION  FOR  PUBLICITY

PURPOSES: The contractor, sub‐contractor, consultant advisor or the employees engaged  by the contractor shall not use GCNEP's name for any publicity purpose through any public  media like Press, Radio, Television or Internet without prior written approval of GCNEP.

23.

For  any  detailed  clarifications,  kindly  refer  to  the  document  entitled  CONDITIONS  AND

CLAUSES  OF  CONTRACT  2008  (and  the  Corrigendum  issued  thereon),  Directorate  of

Construction,  Services  and  Estate  Management  (DCSEM),  Department  of  Atomic  Energy,

Government of India. The document can be downloaded under the Section 'Tenders' from  the website www.dcsem.gov.in.

24.

The quantities of items indicated in this tender document are provisional and may change  as per requirement.

25.

Quotation  must  also  indicate  the  validity  of  offer.  The  offer  should  be  valid  for  a

minimum of 120 days

26.

GCNEP  reserves  the  right  to  accept  /  reject  any  or  all  quotations  without  assigning  any  reason.





PART E: Document Checklist

i) Document Checklist for ELIGIBITY BID

Sealed Cover‐I super‐scribed “ELIGIBITY” must contain the following documents:

1) DD/Pay Order towards the Tender Cost (non‐refundable, non‐transferable).

2) DD/Pay Order towards the Earnest Money Deposit (EMD) for the works.

3) Duly filled Annexure‐A (Section‐III), on company letterhead.

ii) Document Checklist for TECHNICAL BID

Sealed Cover‐II super‐scribed “TECHNICAL BID” must contain the following documents:

1) Duly filled Annexure‐B (Section‐III), on company letterhead.

2) Self attested copy of Company Registration Certificate.

3) Self attested copy of PAN, VAT, TIN cards/ certificates.

Page | 7















4) Latest Bank Solvency Certificate.

5) CA Certificate of Financial Turnover for the last three consecutive financial years.

6) The Profit/ Loss statement of the company for the last five years, ending 31 st

 March 2016.

7) Power of Attorney/ Authorization for signing the bid documents.

8) Duly signed physical/ hard copies of all technical datasheets (along with the make, model) of  the products offered.

9) OEM support commitment letter, as per Annexure‐C (Section‐III), on OEM letterhead.

10) Duly filled Annexure‐D (Section‐III), on company letterhead.

11) Signed & Stamped copy of SECTION‐I and SECTION‐II of this Tender document.

12) Any additional documents in support, as found suitable by the bidder.





iii) Document Checklist for FINANCIAL BID

Sealed Cover‐III super‐scribed “FINANCIAL BID” must contain the following document(s):

1) Duly filled‐in, Signed & Stamped copy of Annexure‐E (Section‐III), on company letterhead.



Project Director, GCNEP

































Enclosed:

1) Section‐II

2) Section‐III (Annexure‐A, Annexure‐B, Annexure‐C, Annexure‐D, Annexure‐E)



Total No. of Pages in this document: 52 Pages

NOTE: CORRIGENDUM (S), IF ANY, SHALL BE UPLOADED ON WEBSITE www.gcnep.gov.in.

For any queries, approach GCNEP Helpdesk: Information, Suggestions and Feedback: [email protected]

Page | 8

NIT FOR PRESS











Page | 9

















THIS PAGE IS INTENTIONALLY LEFT BLANK





















Page | 10

SECTION‐II

TECHNICAL SPECIFICATIONS

Work overview: The proposed work is to be carried out at newly constructed premises. The LAN cable is  already  existent  at  places  as  per  the  existing  scopes,  and  the  location  of  various  communication  end  points/  exchange  room  etc  is  already  identified.  Any  additional  LAN  cables  &  connectors,  additional  electrical  cables/  switch/  sockets,  PDUs,  face  plates  etc  as  per  the  requirements  related  to  the  commissioning of the system are in the scope of proposed works. The agencies willing to take up this  work can plan a visit to office site for mapping the exact requirements. Such a visit, however, must be  with a prior intimation to & approval of this office.

PART I: Scope of Work



1.

Supply, installation, integration, testing and commissioning of all the items and peripherals  meeting  the  listed  specifications  and  providing  three  years  onsite  comprehensive  warranty.  The  installation,  testing  and  commissioning  shall  be  carried  out  as  per  the  instructions of Engineer‐in‐Charge.

2.   All items/ materials (including cables & connectors) offered should be of repute make/  well established brands.

3.

Supply  shall  include  all  the  installation  material/  accessories/  consumables  (e.g.  screws,  clamps, fasteners, ties anchors, supports, wires, patch cords, patch panels etc.) necessary  for the installation of the systems. Any minor works related to laying of conduits, cables  and  conductors,  installation  of  display,  audio,  and  cabling  (VGA,  Audio,  Speaker,  LAN  cabling etc.), providing access points that are required to make the system operational, is  included in the scope.

4.

Successful  bidder  shall  have  to  program  and  configure  the  systems  with  proper  inputs  from Engineer‐in‐charge so that it can be operated by the staff involving minimum efforts.

The scope of works also includes training of GCNEP staff on the configuration and use of  the system as a whole. Installation work shall be done  in  a conscientious manner as per  the  OEM  guidelines  and  best  industry  practices.  The  system  shall  be  subjected  to  inspection at various stages.

5.

All  items  used  should  be  as  supplied  by  OEM.  The  specifications/  descriptions  listed  are  the minimal ones. All licenses should be absolute lifetime licenses in the name of GCNEP.

Anything higher/ better in configuration/ performance can be considered for acceptance.

6.

The  successful  bidder  shall  submit  to  the  Engineer‐in‐Charge  detailed  time  schedule  covering  phases  involved,  detailed  plans,  procurement,  inspection,  test,  delivery,  and  installation etc. within fifteen (15) days of receipt of work order by the contractor.

7.

All  offered  components  for  the  works  should  be  compatible  with  each  other  for  all  functional  and  performance  aspects  to  achieve  the  highest  level  of  integrated  services.

Finished works shall be able to achieve a minimum 80% of the rated performance on full  load at communication end points.

8.

The bidder shall submit all the technical information/ details as requested, to enable the

Department/ User to make an accurate comparison and evaluation of tenders without the  need of further information from the bidder.

Page | 11



9.

All rack items wherever included (like switches, rack servers, etc.) should include the rack  mounting kit/ brackets.

10.

Unless  otherwise  specifically  mentioned,  design,  manufacture,  testing  &  performance  of  all items shall conform to the latest edition of the applicable codes/ standards/ regulatory  norms.

11.

All  material  used  including  the  color,  texture,  shade  etc.  wherever  applicable  should  be  with a prior approval of Engineer‐in‐charge.

12.

All equipment should operate under Indian power supply standards.

13.

Engineer‐in‐Charge  reserves  the  right  for  inspection/  demonstration  of  any  items  proposed in the work, at supplier’s premises.

14.

The vendor should be capable of providing local support at GCNEP Bahadurgarh.





PART II: On‐site support & warranty

1.   COMPREHENSIVE MAINTENANCE CONTRACT: The offer by a company/ firm/ agency shall  include  a  “Comprehensive  Maintenance  Contract”  (CMC)  for  the  works  including  the  supplied  instruments/  materials  and  workmanship,  immediately  after  completion  of  the  works  for  a  period  of  Three  (3)  Years  from  the  date  of  satisfactory  installation,  commissioning & integration of the system. This shall include the offered warranty period  also. A dedicated onsite operation & comprehensive maintenance support in the form of  at  least  one  qualified  operator  should  be  provided  at  site  throughout  this  CMC  period,  during  office  hours,  all  office  days  a  year,  purely  at  the  cost  of  the  supplier  &  with  all  liabilities  to  the  supplier  only.  GCNEP  shall  not  extend  any  medical,  housing,  transportation facilities or any other benefits to any contract/ hired workers of the agency  in  order  to  meet  the  CMC  requirements.  GCNEP  shall  not  be  liable  to  any  additional/  future claims arising out of these CMC works and onsite support requirements. The CMC  shall  generally  include  attending  of  preventive  maintenance  at  regular  intervals  and  attending  of  all  kinds  of  break  down  calls,  with  supply/  provision  of  all  necessary  spare  parts  of  the  instrument  required  for  restoring  function  of  the  instrument  under  CMC.

Spare  parts shall  mean all  items  required for restoring function  of  the  instrument  under

CMC.

2.   All items being offered under works should have India based service support.

3.   GCNEP may lodge complaints by any mode i.e. phone, e‐Mail etc.

4.   The  entire  Hardware  as  supplied  under  the  project  should  be  interoperable.  In  case  any  additional  device/  software  is  required  for  interoperability,  the  same  shall  be  provided,  installed and maintained by the bidder at no extra cost for entire warranty period.

5.   In the event of an operation critical item not repaired/ replaced within 48 hours, a backup  of the item shall be provided until the item is repaired/ replaced.

6.   The visit of any external service engineers of the firm to GCNEP premises, other than the  dedicated  operational  support  made  available  by  the  firm/  agency  at  site,  shall  be  arranged by the firm at no extra cost during the warranty period.

7.   All works related to workmanship shall be subject to warranty of three years with effect  from  the  date  of  installation  by  the  supplier  and  all  item/material  should  have  a  three  years  warranty  from  OEM  wherever  applicable.  Maintenance  service  shall  be

Page | 12







Comprehensive  and  Onsite  in  nature  which  shall  include  preventive  and  corrective  maintenance of all assets.

8.   In the event the firm does not attend to the service calls of the office within the stipulated  time, the office reserves the right to get the items/parts repaired/replaced through other  firms  or  individuals,  the  expenditure  incurred  thereby  shall  be  recovered  from  any  payments due to the firm.

9.   If  at  all,  any  asset  or  its  part  shall  require  to  be  moved  out  of  this  office  premises  for  rectification  of  any  complaint,  then  written  permission  is  to  be  sought,  specifying  the  details of the items to be taken out of office and reasons thereof. Safety & security as well  as the transportation of assets to the firm’s premises and vice versa shall be at the risk and  cost of the firm.

10.   Defective parts shall be replaced by new parts of the same model & make and the cost of  replacement  shall  be  borne  by  the  firm.  In  the  event  of  such  new  part  not  being  compatible with the existing part, such existing part shall also  be replaced with the new  original  part.  The  contractor  shall  keep  sufficient  stock  of  all  spare  parts  of  assets  and  standby assets.

11.   If  a  particular  asset  is  irreparable,  then  the  irreparable  item  shall  be  replaced  by  a  new  asset of the same brand/model or higher and the cost of the new asset shall be borne by  the firm. This office may also ask the firm to repair/replace/supply the items damaged due  to  fire/flood/natural  disaster/earth    leakage    or    to    upgrade    any    hardware    on   chargeable    basis.  However,  the  charges  for  these  items  shall  not,  in  any  case,  be  more  than  the  prevailing  wholesale  market  price.  This  office  may  also  arrange  to  rectify/repair/replace  those  exempted  items  through  other  firms  or  from  the  open  market.  In  that  case,  after  rectification/repair/replacement  of  the  said  exempted  items  shall automatically come under the warranty.





















Page | 13

























THIS PAGE IS INTENTIONALLY LEFT BLANK





























Page | 14























SECTION‐III



ANNEXURES















Page | 15































THIS PAGE IS INTENTIONALLY LEFT BLANK







Page | 16

To be put in the SEALED COVER‐I super scribed  “ELIGIBILITY”

To be submitted on company letterhead

NIT No: GCNEP/NIT/16/12-33 dated 23/12/2016

Works: SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV  SYSTEMS  AT  GCNEP,

JASAUR‐KHERI, BAHADURGARH, HARYANA.



Annexure‐A

ELIGIBILITY



UNDERTAKING



It is certified that my firm/agency/company has never been blacklisted by any of the Departments/

Autonomous Institutions/ Universities/ Public Sector Undertakings of the Government of India or

Government of Haryana or any other State Government and no criminal case is pending against the said firm/ agency as on ______________.

Further, I/we undertake and confirm that eligible similar work(s) has/ have not been got executed through another contractor on back to back basis. Further that, if such a violation comes to the notice of

Department, then I/we shall be debarred from bidding in GCNEP / DAE in future forever. Also, if such a violation comes to the notice of Department before date of start of work, the Engineer-in-Charge shall be free to forfeit the entire amount of Earnest Money Deposit / Performance Guarantee.

Signature



Place:

Date:   /___/_____



Name of the Signatory

Name of the firm/agency

Seal of the firm/agency











Page | 17

















































THIS PAGE IS INTENTIONALLY LEFT BLANK

Page | 18

To be put in the SEALED COVER‐II super scribed “ TECHNICAL BID”

To be submitted on company letterhead

NIT No: GCNEP/NIT/16/12-33 dated 23/12/2016

Works: SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV  SYSTEMS  AT  GCNEP,  JASAUR‐

KHERI, BAHADURGARH, HARYANA.



Annexure‐B

TECHNICAL BID











DETAILS OF THE AGENCY

1. Name of the Firm/ Agency



2. Address with Phone Number



3. Registration No of the Firm

(attach a copy)



4. Name,  Designation,  Address,  Telephone  No.  &  email‐id of the Authorized contact person





5. PAN Number

(attach a copy)





6. Sales Tax, TIN, VAT Number

(attach a copy)

7. Details of Tender Fee enclosed











8. Details of EMD enclosed



9. List  of  technical  staff  possessed  and  proposed  to  be deployed  for  the  works,  along  with  qualification  and

  experience

10. Experience details of last seven consecutive years for providing similar works (a work completion certificate issued by the institute/ organization where  the  job  was/ is being carried out to be attached)

Name of Organization with complete address and  contact information

Details of work carried out  with  date including  ongoing works

Stipulated  completion time



Actual  completion time

Value (Rs.)

i)

      ii)          iii)

* Note: Add rows as per the requirements, affix seal and signature on each page.





This is to certify that I/we have carefully read the contents of the enquiry and fully understood all the terms and  conditions therein and undertake myself/ourselves to abide by the same.







Place:

Date:  /___/_____



Signature

Name of the Signatory

Name of the firm/agency

Seal of the firm/agency



Page | 19













































THIS PAGE IS INTENTIONALLY LEFT BLANK

Page | 20

To be put in the SEALED COVER‐II super scribed “ TECHNICAL BID”

Annexure‐C



(TO BE PROVIDED ON OEM’s LETTER HEAD)

FORMAT FOR COMMITMENT LETTER FOR SUPPORT FROM PRINCIPAL

MANUFACTURER/ OEM

(Original Equipment Manufacturer)

Ref: ________________________ Date ……………………..

To

Project Director

GCNEP, Bahadurgarh, Haryana

NIT No: GCNEP/NIT/16/12-33 dated 23/12/2016

Works: SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV  SYSTEMS  AT  GCNEP,  JASAUR‐

KHERI, BAHADURGARH, HARYANA.

Dear Sir

……………………………………………………………..… (OEM) is pleased to offer this letter for the proposed ………………………………………………..……………. (name of works) submitted by

M/s……………………………………………………..……… (henceforth referred to as partner) in response to Tender No. ……………………….…..

I/We hereby commit & confirm the following:

1) The partner will enter into back to back service agreement with us for a period of 3 (three) years from the date of installation of items/ material at site.

2) We assure the availability of spare parts for the product quoted for a minimum period of 5 (Five) years from the date of installation of items/ material at site.

3) We extend our full support and guarantee/warranty as per Service Level Agreement (SLA) for the goods offered for supply by us against this tender for following items:

Sr. No. Item Name

1.

2.

3.

Note: Add rows as per requirement.

Make of Item Model of Item

Signature ………………….………..….

Name …………………………….……..

Stamp of OEM

Designation …………………….………

Contact No and E-Mail ID…………….…………….………

Note: This undertaking should be signed by a person competent and having the power of attorney to bind the

Manufacturer.

S eal and Signature of Tenderer

Page | 21













































THIS PAGE IS INTENTIONALLY LEFT BLANK

Page | 22

To be put in the SEALED COVER‐II super scribed  “TECHNICAL BID”

To be submitted on company letterhead

Annexure‐D

(To be submitted as a part of acceptance of the BG format)

FORM OF PERFORMANCE SECURITY - BANK GUARANTEE BOND (BG)

1. In consideration of the President of India (hereinafter called “The Government”) having agreed under the terms and conditions of Letter of Intent / Agreement No.................. dated................. made between

...................................and .................................................. (hereinafter called “the said Contractor{s}” ) for the work ................... .................................................................................................. (hereinafter called “the said Letter of Intent / Agreement”) having agreed to production of an irrevocable bank Guarantee for

Rs………............... (Rupees ........................................................ only), as a security /guarantee from the contractor(s) for compliance of his obligations in accordance with the terms and conditions in the said agreement, we ............................................................. (Indicate the name of the Bank) (hereinafter referred to as “the Bank”) hereby undertake to pay to the Government an amount not exceeding Rs. ...................

(Rs.................................................................................................only) on demand by the Government.

2. We ................................................. (indicate the name of Bank) do hereby undertake to pay the amounts due and payable under this guarantee without any demur, merely on a demand from the Government stating that the amount claimed is required to meet the recoveries due or likely to be due from the said

Contractor(s). Any such demand made on the bank shall be conclusive as regards the amount due and payable by the Bank under this guarantee. However, our liability under this guarantee shall be restricted to an amount not exceeding Rs..................... Rupees.................................................................................only).

3. We, the said bank, further undertake to pay to the Government any money so demanded notwithstanding any dispute or disputes raised by the Contractor(s) in any suit or proceeding pending before any Court or

Tribunal relating thereto, our liability under this present being absolute and unequivocal.

The payment so made by us under this bond shall be a valid discharge of our liability for payment thereunder and the Contractor(s) shall have no claim against us for making such payment.

4. We................................ (indicate the name of Bank) further agree that the guarantee herein contained shall remain in full force and effect during the period that would be taken for the performance of the said

Agreement and that it shall continue to be enforceable till all the dues of the Government under or by virtue of the said Agreement have been fully paid and its claims satisfied or discharged or till Engineer-in-charge on behalf of the Government certifies that the terms and conditions of the said Agreement have been fully and properly carried out by the said Contractor(s) and accordingly discharges this guarantee.

5. We .............................. (indicate the name of Bank) further agree with the Government that the

Government shall have the fullest liberty without our consent and without affecting in any manner our obligations hereunder to vary any of the terms and conditions of the said Agreement or to extend time of performance by the said Contractor(s) from time to time or to postpone for any time or from time to time any of the powers exercisable by the Government against the said Contractor(s) and to forbear or enforce

Page | 23



any of the terms and conditions relating to the said Agreement and we shall not be relieved from our liability by reason of any such variation, or extension being granted to the said Contractor(s) or for any forbearance, act of omission on the part of the Government or any indulgence by the Government to the said Contractor(s) or by any such matter or thing whatsoever which under the law relating to sureties would, but for this provision, have effect of so relieving us.

6. This guarantee will not be discharged due to the change in the constitution of the Bank or the Contractor(s).

7. We, ............................... (indicate the name of Bank) lastly undertake not to revoke this guarantee except with the previous consent of the Government in writing.

8. This guarantee shall be valid up to ........................, unless extended on demand. Notwithstanding anything mentioned above, our liability against this guarantee is restricted to Rs. ................................ (Rupees

............................................................................................................. only) and unless a claim in writing is lodged with us within six months of the date of expiry or the extended date of expiry of this guarantee, all our liabilities under this guarantee shall stand discharged.



Signed and Sealed









Dated the ............. day of ................. for ................................................(indicate the name of Bank)

* * *





We have read the above “FORM OF PERFORMANCE SECURITY ‐ BANK GUARANTEE BOND (BG)”,  and undertake to produce the same duly filled on demand.

Signature

Place:

Date:   /___/_____



Name of the Signatory

Name of the firm/agency

Seal of the firm/agency







Page | 24



To be put in the SEALED COVER‐III super scribed “ FINANCIAL BID”

Annexure‐E

FINANCIAL BID





To be Signed & Stamped on each page





NIT No: GCNEP/NIT/16/12-33 dated 23/12/2016

Works: SUPPLY,  INSTALLATION,  TESTING  AND  COMMISSIONING  OF  AV  SYSTEMS  AT  GCNEP,  JASAUR‐

KHERI, BAHADURGARH, HARYANA.





Name of the Firm/ Agency (with address):



Note:

1) The  quoted  rate  should  be  inclusive  of  all  transportation,  loading/  unloading,  delivery  or  any  other  consequential charges. No extra costs shall be payable beyond the quoted price.

2) In  event  no  rate  has  been  quoted  for  any  item(s),  it will be presumed that the contractor has  included the cost of this / these item(s) in other items and rate for such item(s) will be considered as  zero and work will be required to be executed accordingly.



Remark: Please quote for the items ‘Rate’ and ‘Amount’ under  Column 5  and  Column 6  below:

(Please sign and stamp each page)

Sr. No. Item Name & Description Quantity Unit Rate Amount

(1)

(2) (3)



(4) (5) (6)

1. High Definition Video Conferencing System at Main

Conference Room

1 System as described

Set

The scope includes

1) Projection system:

One number of Full HD LCD projector, 5200lm

White/Colour Light Output, WUXGA resolution 1920 x 1200,

16:10 aspect ratio, 360° vertical rotation, Resolution

WUXGA, Contrast Ratio 5000:1, 380W Lamp, lamp life of

2500h - 4000h durability, Keystone Correction Manual vertical: ± 30°, Manual horizontal ± 30°, Edge blending, arc correction, Split Screen projection support, Approx.

Projection Ratio of 1.25-2.30 : 1, Manual Zoom Factor: 1 -

1.8, Optical Lens, Manual Lens Shift of Vertical ±65% horizontal ±30%, Projection Size of 50 inches - 300 inches,

Projection Distance of 2.5m - 15m for a 300", Lens F

Number 1.65 - 2.55, Focal Distance 21.00mm - 37.00mm,

Manual Focus, CONNECTIVITY: Interfaces RS-232C,

Ethernet interface 100/10 Base-T, VGA in, VGA out, HDMI

Page | 25



Sr. No.

(1)

Item Name & Description

(2)

in, Display Port, Composite in, BNC in, S-Video in, Stereo mini jack audio out, Stereo mini jack audio in, Kensington lock, Inclusive of Cable, cover, VGA cable, HDMI Cable

Clamp, Lens cap, Power cable, Remote control incl. batteries, ceiling mount, User manual

Quantity

(3)



2) Fixed Screen

One number of 150” diagonal fixed frame screen, ISF certified High Definition (HD) White Fabric WB-5 screen,

16:10 aspect ratio format, consisting of 8mm Side frame

8mm Horizontal aluminium frame, aluminium frame covered with Black Velvet cover, Inclusive of all OEM supplied installation brackets, fixing lugs, etc.

3) Full HD video conferencing

One number of 1080p HD video conferencing system licenced for Multipoint license for up to 6 sites at 720p30 or 4 sites at 1080p30, 1/2.33” CMOS camera with 4k sensor, f=3.76–37.6mm, 12x optical zoom with 180degree panning radius, 65 degree Horizontal field of view,

39° Vertical field of view, auto focus, Pan range 100°/-

100, Tilt range +20, -30°, IR detectors, Supported Video standards and protocols: H.261, H.263, H.264, H.264 video error concealment, Video input: 1 HDCI, 1 HDMI

1.3, 1 VGA, Video out: 2 HDMI 1.3, Supported video resolution: 1080p 60 fps from 1740 Kbps, 1080p 30 fps from 1024 Kbps, 720p 60 fps from 832 Kbps, 720p 30 fps from 512 Kbps, 4SIF/4CIF 60 fps from 512 Kbps,

4SIF/4CIF 30 fps from 128 Kbps, SIF (352 x 240) CIF

(352 x 288) from 64 kbps, QSIF (176 x 120) QCIF (176 x

144) from 64 kbps, w288p from 128 Kbps, w448 from 384

Kbps, w576p from 512 Kbps, Input: HD (1920 x 1080i),

HD (1920 x 1080p), WSXGA+ (1680 x 1050), UXGA (1600 x 1200), SXGA (1280 x 1024), WXGA (1280 x 768), HD

(1280 x720p), XGA (1024 x 768), SVGA (800 x 600),

Output: WUXGA (1920 x 1200), HD (1920 x 1080),

WSXGA+ (1680 x 1050), SXGA+ (1400 x 1050), SXGA

(1280 x 1024), HD (1280 x 720), XGA (1024 x 768), VGA

(640 x 480), Content frame rate: 5–60fps (up to 1080p resolution at 30 fps), support for content sharing during a

VC call, Audio input: microphone array input port

(supporting minimum 2 microphone arrays), 1 HDCI

(camera), 1 HDMI, 1 3.5mm stereo line-in, Audio output:

1 HDMI, 1 3.5mm stereo line-out, 2 USB 2.0, 1 RS-232, automatic noise suppression, audio error concealment, 7 kHz bandwidth with G.722, G.722.1; 3.4 kHz bandwidth with G.711, G.728, G.729A, Supported standards:

H224/H.281, H.323 Annex Q, H.225, H.245, H.241, H.239,

H.243, H.460, BFCP (RFC 4582), Network: IPv4/ IPv6

Unit

(4)

Rate

(5)

Amount

(6)

Page | 26



Sr. No.

(1)

Item Name & Description

(2)

support, 1 10/100/1G Ethernet, H.323 and/or SIP up to 6

Mbps, Automatic gain control, Reconfigurable MTU size,

Security: Media Encryption (H.323, SIP) AES-128, AES-

256, authenticated access to admin menus, web interface and telnet API, FIPS 140-2 Validated Cryptography,

PKI/Certificate Management: SSL 3.0, TLS 1.0, 1.1, 1.2,

Self-signed and CA-signed certificate support, CRL and

OCSP-based certificate, revocation checking, Network intrusion detection system, Local account password, policy configuration, Security profiles, Web UI / SNMP Whitelists,

Local account and login port lockout, integration with audio mixer through a digital interface or equivalent,

Operating temperature: 0 to 40 °C, Operating humidity:

15 to 80%, should include all accessories like cables etc.

The equipment should ensure interoperability between competitive videoconferencing products prevailing in the market.

Quantity

(3)



4) White opaque glass writing board

One number of 2m wide x 1.5m height white opaque glass dry-erase board of a repute make with ghost/ stain proof smooth writing surface, frameless design hangs vertically or horizontally and conceals hanging hardware for a sleek, contemporary look, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc.

5) LED Displays

Two numbers of Professional Full HD (1920 × 1080 pixels)

LED displays, screen size 55" (139.7cm), 16:9 Aspect Ratio,

100Hz Backlight Scanning, 178°/ 178° Viewing Angle,

Video In RCA, Audio In (L/R) RCA Pin Type, 3 HDMI In

Type A Connectors, Component In, 2 USB Input, RCA

Audio out, SPDIF, VGA In, PC Audio In, Built-in Media

Player supporting Mpeg1/2, H.264, VC1, HEVC, JPEG, BMP,

PNG, MP3, WMA formats, AC 110~240V 50/60 Hz Power,

Approx. Rated Power Consumption of 100W, Built -in Full range 20W (10W +10W) 10% PHD Speakers, Operating

Temperature: 0 °C to 40 °C, Operating Humidity: 20% to

80%, IS 13252:2010 Safety confirmations, inclusive of AC cord, remote, table mount, approved VESA wall mount assembly

6) Document Presenter

One number of document camera with 1/2.7" CMOS sensor, 1920 x 1080 Effective Pixels, 30 fps Frame Rate,

VGA Output: SXGA (1280 x 1024), XGA (1024 x

Unit

(4)

Rate

(5)

Amount

(6)

Page | 27



Sr. No.

(1)

Item Name & Description

(2)

768),WXGA, (1280 x 800), HD (1360 x 768), 1080p (1920 x 1080), USB Output: VGA, SVGA, XGA, SXGA, WXGA,

720p, 1080p, HDMI Output: 480p/720p/1080p, Auto White

Balance, Adjustable Exposure, Adjustable Brightness, Lens

F-number: 3.4-5, Maximum Capture Area: 11.7" x 20.7" (at

1080p), 11.7" x 16.5" (at XGA), 10x digital zoom, 12x optical zoom, Automatic Focus with one-touch button, 180 degrees (Horizontal/ Vertical) Camera Head Rotation, LED

Illumination, Brightness 250lx or above @ A3 shooting area, Built-in functionality: Zoom, Freeze, Auto Focus,

Focus Lock, LED, Brightness, Contrast, Negative, Black and

White, Split Screen, Playback, Video Capture, Digital Scroll

(pan/tilt), Flicker Reduction, Image Rotation, Source (PC/

DC), Auto-detect Aspect, Video Recording, Video Playing,

Saving Formats supported: JPG, BMP, PNG, AVI, MOV,

PDF, Storage: Memory SD card slot (SD/SDHC only) 32GB

Class 10 card included, Kensington lock support, Approx.

Closed/Folded size (WxDxH) 15"x5"x5", Approx. Power

Consumption 15W, Inclusive of AC power adapter with power cord, USB cable, application software CD, remote control with AA batteries, VGA cable, adapters, carrying case, RoHS compliant

Quantity

(3)



7) Cable cubby

Five numbers of Table Mount Modular Multi-Connection

Tilt-Up Lid Cable cubby with HDMI, VGA, Audio, LAN & 2

Power ports, Manual cover open/ close, Adjustable connector depth, Approx. Dimensions(WxDxH)

20cmx17cmx13cm, Approx. weight 1.5kg, inclusive of enclosure, inner frame, power socket, cable pass through arrangements, power cord & other inserts by OEM, UL and

CE Qualified

8) Wireless Presentation System

One number of Wireless Presentation System with 2 USB

Dongles & facility to project Mobile devices, supported

Operating systems: Windows 7/8/10, Mac OSX 10, Android

4.1 and above, iOS 7.0 and above, 1 HDMI Video output,

30 fps Frame rate, 1920x1200 output resolution, Fanless, support for 2 simultaneous sources on screen, 16 simultaneous connections, Audio via HDMI, Audio via Jack

3.5mm, S/PDIF, WiFi protocol WPA2PSK, IEEE 802.1X,

IEEE 802.11 a/g/n, dual Frequency band 2.4 GHZ and 5

GHz, Connections: 1 Ethernet LAN, 3 USB (front & back),

Audio analog line out on 3.5mm, digital S/PDIF, Operating

Temperature: 0°C to 40°C, Humidity:0 to 85% RH noncondensing, approx. size (HxWxD)

200mmx110mmx40mm, approx. weight 800g, approx.

Power consumption 20W, Kensington slot, inclusive of

Unit

(4)

Rate

(5)

Amount

(6)

Page | 28



Sr. No.

(1)

Item Name & Description

(2)

antennas, Certifications: FCC/CE

9) Scalar cum switcher

One number of multi input digital switcher cum scalar with audio de-embedder, support for 10 HDMI & 2 computer graphics video on 15pin HD connectors, 2 HDMI Scaled

Outputs, support for up to WUXGA/1080p output resolution, 2 Microphone Inputs for mixing, switching or talk over, Auto Input Scanning and Switching Companion

AFV (Audio-Follow-Video) feature, 12 stereo Audio Inputs & embedded audio for HDMI inputs each with individual level controls, Audio Outputs: 1 S/PDIF on an RCA connector, 1 balanced stereo audio on a terminal block, embedded audio on the HDMI outputs, multiple aspect ratio selections, Audio DSP including audio equalization, mixing, delay etc, Built-in Processing Amp for Colour, hue, sharpness, noise, contrast & brightness, Constant Output

Sync , freeze frame feature, with IR remote, RJ-45

Ethernet port, Compatible with HDTV, HDCP Compliant

Quantity

(3)



10) Distribution Amplifier

One number of HDMI Distribution Amplifier for HDMI signals with resolutions up to and including WUXGA

(1920x1200) and 1080p, support for reclock and equalizing of the signal and distribution to up to four identical outputs, 1 input HDMI, 4 output HDMI, support for up to

2.25Gbps bandwidth per graphic channel, 3D Pass-

Through, compliance with HDMI 1.3 and HDCP, LED output indicators with active indication, 19" rack mountable 1U size, approx. weight 2.5kg, inclusive of rack ears

11) Ceiling Microphones Array

Ceiling Microphones Array consisting of One (1) Primary and Three (3) white spherical microphone elements Array extensions pick up audio in a 360-degree pattern around the microphone, including 2ft/60cm drop cables, electronics interfaces, wall plates with 10ft/3m & 50ft/15m plenum cables, RJ45(F)/Walta(M), 25ft/7.6m plenum cables,

Adjustable drop height provides, 22kHz Stereo audio, ceiling microphone with a directional microphone beam feature to automatically capture the speaker, Electronics enclosure with ceiling mounting hardware (UL 2043 compliant), three cardioid elements per microphone elements spaced 120 degrees apart, each ceiling microphone array with 24’ diameter coverage, Full-duplex digital audio, Instant adaptation echo cancellation,

Automatic noise suppression (ANS), Automatic gain control

(ACG) featured

12) Conference audio processor

Unit

(4)

Rate

(5)

Amount

(6)

Page | 29



Sr. No.

(1)

Item Name & Description

(2)

One number of a sixteen channel single rack unit

Conference audio processing device with stereo acoustic echo cancellation (AEC) from 20Hz to 22 kHz on 16 inputs and 16 outputs, with both monaural and stereo acoustic echo cancellation capabilities on all inputs, Feedback elimination on all inputs, Equalization options on all inputs, outputs, and submixes, Dynamics processing on all inputs, outputs, and submixes, Modular telephony options, Submix processing, Analog input gain-10 Kohms, Input EMI Filter,

Analog input gain-100 to 20 dB, Output Impedence-50 ohm, Output EMI filter, Idle Channel noise < -109 dB,

Cross talk-<-110 dB, 20-20,000 HZ, channel to channel,

Acoustic echo cancellation -260ms, Noise cancellation-0-20 dB, software selectable, Latency -Mic/Line input to output:

23ms, AEC and NC processing enabled, Ethernet port for configuration and device management, including OEM supplied VoIP SIP telephony interface, including OEM supplied VoIP telephony interface, IR remote, Operating

Temperature-0-40 o

C, Phantom power 48 VDC

Quantity

(3)



13) Ceiling Speakers

Six numbers of white color 2-way 100V/70V/16 ohm builtin ceiling speakers with 8” woofer, 1” coaxial tweeter and high quality 100/70 volt speaker line transformer, mounting frame made of high quality ABS, woofer cone material polypropylene, approx. outside diameter 240mm, depth

80mm, 16 ohms impedance, 50 - 20kHz frequency response, aluminium grille, IP54 rated, inclusive of mounting arrangements

14) Stereo Power Amplifier

One number of 2-channel stereo power amplifier with dynamic output power (4 ohms) 2 x 350W, dynamic output power (8 ohms) 2 x 200W, dynamic output power bridged

(8 ohms) 750W, 10 - 50kHz frequency response, RMS output power (4 ohms) 2 x 180W, RMS output power (8 ohms) 2 x 120W, output power RMS bridged (8 ohms)

350W, convection cooled, approx. weight 7kg, 19" rack mountable with rack height of 1U

15) IP based conference room device control system

One number of IP based conference room device control system with real-time, pre-emptive multithreaded/multitasking engine, on-board 1GB RAM & 4GB

Flash memory, Expandable storage up to 1TB, Rear panel memory card slot, High-speed USB 2.0 host port, Industrystandard Ethernet wired communications, Web based control, iPhone/ iPad and Android control app support,

SNMP remote management support, Two RS-232/422/485

Unit

(4)

Rate

(5)

Amount

(6)

Page | 30



Sr. No.

(1)

Item Name & Description

(2)

COM ports with hardware and software handshaking, Four

RS-232 COM ports with software handshaking only, Eight

IR/serial, eight relay, and eight Versiport I/O ports, IEC

61000-4-5 Installation Class 4 surge immunity on COM

Versiport and network connections, Secure access through full user/group management, Hardware level security using

802.1X authentication, TLS, SSL, SSH, and SFTP network security protocols, FIPS 140-2 compliant encryption, IIS v.6.0 Web Server, Ethernet: 10/100/1000 Mbps, autoswitching, auto-negotiating, auto discovery, full/half duplex, industry-standard TCP/IP stack, UDP/IP, CIP,

DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol),

FIPS 140-2 compliant encryption, IEEE 802.1X, SNMP, ,

IPv4 or IPv6, Active Directory authentication, IIS v.6.0 Web

Server, SMTP e-mail client, Control Subnet: 10/100/1000

Mbps Ethernet, auto-switching, auto negotiating, autodiscovery, full/half duplex, DHCP server, DNS Server, port forwarding, Isolation Mode, Series control card expansion slots, IR outputs up to 1.2 MHz, Relay outputs normally open, isolated relays, arc suppression across contacts, IPv6 ready, USB computer console port, Dedicated Control

Subnet, Temperature: 5° to 45°C, Humidity: 10% to 90%

RH, approx. weight 2kg, 2U 19-inch rack-mountable.

Quantity

(3)



This conference room control device should be augmented with two numbers of 16GB Wi-Fi iPad2 device or equivalent or higher as approved (inclusive of two numbers of iPad inwall metal, flush-mountable, docking station of Crestron make or equivalent or higher in configuration as approved) with OEM software application (2 licences, by IP based conference room device control system) installed for networked based conference room device control/ management, including eight IR probes for controlling the

IR devices, one 8 switch channel DIN Rail High Voltage

Switch with digital inputs Crestron DIN8sw8 or equivalent or higher as approved, 4 zone lighting control panel from

Lutron Grafik Eye Quantum QS Wireless series or equivalent or higher as approved, with 8 button panel

Crestron CNXB8 for room control from Crestron or equivalent or higher as approved, one 802.3 a/b/g/n WiFi access point to connect to the conference room control processor over local control network, conference room lighting control including four number of 2’x2’ false roof mountable and dimmable light modules, all above networked as a turn-key solution with all IR and high voltage devices connected for remote touch panel, key control based on conference room device control system.

16) 18U Floor/ Table Rack

Unit

(4)

Rate

(5)

Amount

(6)

Page | 31



Sr. No.

(1)

Item Name & Description

(2)

One number of 18U Table Rack with accessories, Rack

Width: 19", Color: Light grey, Type: On castor wheels,

Weight Capacity: Static load-40 Kg 500 Kg. on castor

Wheels and 750Kg on base frame, Approximate Depth

(mm): 600, Top & bottom CRCA steel, Four side CRCA

Steel folded panels, 19" Mounting Angles, wall mounting hardware, Cable entry provision, front glass/vented door

(lockable), should have 19" 1U Horizontal PVC cable manager (2 Nos.), accessories including 19 AC power distribution channel with 5 Amp power universal standard socket & surge and spike protection, equipment mounting screws/hardware packets, with two fans, Certifications:

Standard Finish Power Quoted (RAL 7035), DIN- 41494,

EIA-310, IEC-60297.

Quantity

(3)



17) Presentation device

One presentation device based on Intel Core i7-5500U, 4M

L3 Cache, 3.00 GHz, dual-core, 8GB Single Channel DDR3L

1600MHz, 1TB SATA 5400RPM hard drive, NVIDIA GeForce

820M with 2GB DDR3, Windows 8.1, 8x optical drive

DVD+/-RW, LED Backlit Screen Size 39.62cm (15.6"), 1366 x 768 Resolution, integrated HD (720p) webcam,

Touchpad, Standard Keyboard, Stereo Speakers, Wireless

LAN, Bluetooth v4.0, Up to 4 hours Battery Backup, 1 x

USB 3.0, 2 x USB 2.0 ports, RJ45 port, HDMI Port, Media

Card (SD, SDHC, SDXC), Kensington Lock Slot, Approx.

Unit

(4)

380x250x25mm, Color Silver/ Black, as approved.

18) Presentation touch display with pen/ stylus pen  with  adjustable stand

Two  numbers  of  13”  multi‐touch  diagonal  screen  size  based  presentation  tablets  with  stylus

  pen,  Active  Matrix

TFT  LCD,  Full  HD  display,  aspect  ratio  16:9,  viewing  angle

178°  H/  V,    contrast  ratio  700:1,  16.7  million  displayable  colors,  250  cd/m2  brightness,  5080  lpi  Resolution,  HDMI  graphics  input,  4  customizable  application‐specific  keys,  detachable  stand  adjustable  at  3  angles,  silicone  rubber  grip,  PC  connectivity:  HDMI  and  USB,  approx.  power  consumption 9.0 W (active), 1 W (asleep), compatible with

Presentation device in No. 17,

  Certifications  VCCI  Class  B,

FCC  Part  15  Subpart  B  (class  B)  and  C,  CE,  KCC,  BSMI,  C‐ tick,  CB,  CCC,  GOST‐R,  EU  RoHS,  approx.  size  380  x  250  x

15mm,  approx.  weight  1.0  kg,  4  position  customizable  rocker  ring,  home  button,  toggle  display  support,  compatible with Windows 8, Windows 7 SP1, Mac 10.8 or  later,  inclusive  of  OEM  AC  power  adapter  &  accessory

Rate

(5)

Amount

(6)

Page | 32



Sr. No.

(1)

Item Name & Description

(2)

Quantity

(3)

  cables.

2.

19) Cables & Connectors

AV, LAN cables & connectors, electrical switch/ sockets,

PDUs, face plates of repute make as recommended by equipment OEM, and as per the site requirements.

Conferencing System at Secondary Conference Room

The scope includes

1) Projection system

One number of Ultra-short Throw Interactive Projector,

LCD Size 0.59", Native Resolution WXGA (1280 x 800)

16:10 aspect ratio, Manual Focus, F-Number 1.80, Focal

Length 3.71mm, Throw Ratio 0.27 -0.37 (Wide - Tele),

245W UHE Lamp, Lamp Life expectancy 4000-6000 hours,

Screen Size 60"-100" @Projected Distance 0.348-0.597m,

3300lm brightness, contrast ratio of 10000:1, 16W internal speaker, Keystone Correction (Vertical/ Horizontal) ±3°,

Connectivity: Analog RGB Input D-Sub 15Pin, Composite

RCA input, Video Output D-Sub 15Pin, 2 HDMI HDCP

Supported, Audio Input Stereo Mini Jack, Audio Output

Stereo Mini Jack, USB Input USB Type A, USB Type B,

Control I/O RS-232C D-Sub 9pin, Remote Control Input

Stereo mini, Wired LAN RJ45, Wireless, supports USB

Display, Mouse, K/B, Control, Interactive projector,

Interactive Unit Technology: Infrared, Input Devices:

Interactive Pen Digital Pen, interaction using fingers supported, 25 point Auto / Manual Calibration, Functions:

Hover, Right Click, Auto Adjust Pen Area etc, White Board sharing Operating Temperature: 5-35°C, 20%-80% humidity, approx. power consumption 365W, approx. size

(DxWxH)370x370x150mm, approx. weight 5kg, inclusive of

Power Cable, Remote Control, USB Cable, External Control

Pad, 2 Easy Interactive Pens, Pen Tray, Wall mount Setting

Plate.

1 System as described

2) Fixed Screen

One number of matte white dry-erase board cum projector screen of approx. size 8feet x 4feet for compatible 16:10 widescreen (WXGA) projector viewing, low-gloss surface for quality projection with minimal glare or reflection, scratch resistant no-ghosting surface, framed in aluminium section frames, rounded corners, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc., an ISO 9001 certified manufacturer

Unit

(4)

Rate

(5)

Amount

(6)

Set

Page | 33



Sr. No.

(1)

Item Name & Description

(2)

Quantity

product.

3) White opaque glass writing board

One number of 2m wide x 1.5m height white opaque glass dry-erase board of a repute make with ghost/ stain proof smooth writing surface, frameless design hangs vertically or horizontally and conceals hanging hardware for a sleek, contemporary look, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc.

4) Document Presenter

One number of document camera with 1/2.7" CMOS sensor, 1920 x 1080 Effective Pixels, 30 fps Frame Rate,

VGA Output: SXGA (1280 x 1024), XGA (1024 x

768),WXGA, (1280 x 800), HD (1360 x 768), 1080p (1920 x 1080), USB Output: VGA, SVGA, XGA, SXGA, WXGA,

720p, 1080p, HDMI Output: 480p/720p/1080p, Auto White

Balance, Adjustable Exposure, Adjustable Brightness, Lens

F-number: 3.4-5, Maximum Capture Area: 11.7" x 20.7" (at

1080p), 11.7" x 16.5" (at XGA), 10x digital zoom, 12x optical zoom, Automatic Focus with one-touch button, 180 degrees (Horizontal/ Vertical) Camera Head Rotation, LED

Illumination, Brightness 250lx or above @ A3 shooting area, Built-in functionality: Zoom, Freeze, Auto Focus,

Focus Lock, LED, Brightness, Contrast, Negative, Black and

White, Split Screen, Playback, Video Capture, Digital Scroll

(pan/tilt), Flicker Reduction, Image Rotation, Source (PC/

DC), Auto-detect Aspect, Video Recording, Video Playing,

Saving Formats supported: JPG, BMP, PNG, AVI, MOV,

PDF, Storage: Memory SD card slot (SD/SDHC only) 32GB

Class 10 card included, Kensington lock support, Approx.

Closed/Folded size (WxDxH) 15"x5"x5", Approx. Power

Consumption 15W, Inclusive of AC power adapter with power cord, USB cable, application software CD, remote control with AA batteries, VGA cable, adapters, carrying case, RoHS compliant.

5) Presentation device

One presentation device based on Intel Core i7-5500U, 4M

L3 Cache, 3.00 GHz, dual-core, 8GB Single Channel DDR3L

1600MHz, 1TB SATA 5400RPM hard drive, NVIDIA GeForce

820M with 2GB DDR3, Windows 8.1, 8x optical drive

DVD+/-RW, LED Backlit Screen Size 39.62cm (15.6"), 1366 x 768 Resolution, integrated HD (720p) webcam,

Touchpad, Standard Keyboard, Stereo Speakers, Wireless

LAN, Bluetooth v4.0, Up to 4 hours Battery Backup, 1 x

(3)



Unit

(4)

Rate

(5)

Amount

(6)

Page | 34



Sr. No.

(1)

Item Name & Description

(2)

USB 3.0, 2 x USB 2.0 ports, RJ45 port, HDMI Port, Media

Card (SD, SDHC, SDXC), Kensington Lock Slot, Approx.

Quantity

(3)



Unit

(4)

380x250x25mm, Color Silver/ Black, as approved.

6) Cable cubby

Five numbers of Table Mount Modular Multi-Connection

Tilt-Up Lid Cable cubby with HDMI, VGA, Audio, LAN & 2

Power ports, Manual cover open/ close, Adjustable connector depth, Approx. Dimensions(WxDxH)

20cmx17cmx13cm, Approx. weight 1.5kg, inclusive of enclosure, inner frame, power socket, cable pass through arrangements, power cord and other inserts by OEM. UL and CE Qualified.

7) Wireless Presentation System

One number of Wireless Presentation System with 2 USB

Dongles & facility to project Mobile devices, supported

Operating systems: Windows 7/8/10, Mac OSX 10, Android

4.1 and above, iOS 7.0 and above, 1 HDMI Video output,

30 fps Frame rate, 1920x1200 output resolution, Fanless, support for 2 simultaneous sources on screen, 16 simultaneous connections, Audio via HDMI, Audio via Jack

3.5mm, S/PDIF, WiFi protocol WPA2PSK, IEEE 802.1X,

IEEE 802.11 a/g/n, dual Frequency band 2.4 GHZ and 5

GHz, Connections: 1 Ethernet LAN, 3 USB (front & back),

Audio analog line out on 3.5mm, digital S/PDIF, Operating

Temperature: 0°C to 40°C, Humidity:0 to 85% RH noncondensing, Approx size (HxWxD)

200mmx110mmx40mm, approx. weight: 800g, approx.

Power consumption 20W, Kensington slot, inclusive of antennas, Certifications: FCC/CE.

8) Scalar cum switcher

One number of multi input digital switcher cum scalar with audio de-embedder, support for 10 HDMI & 2 computer graphics video on 15pin HD connectors, 2 HDMI Scaled

Outputs, support for upto WUXGA/1080p output resolution,

2 Microphone Inputs for mixing, switching or talkover, Auto

Input Scanning and Switching Companion AFV (Audio-

Follow-Video) feature, 12 stereo Audio Inputs & embedded audio for HDMI inputs each with individual level controls,

Audio Outputs: 1 S/PDIF on an RCA connector, 1 balanced stereo audio on a terminal block, embedded audio on the

HDMI outputs, multiple aspect ratio selections, Audio DSP including audio equalization, mixing, delay etc., Built-in

Processing Amp for colour, hue, sharpness, noise, contrast

& brightness, Constant Output Sync, freeze frame feature, with IR remote, RJ-45 Ethernet port, Compatible with

Rate

(5)

Amount

(6)

Page | 35



Sr. No.

(1)

Item Name & Description

(2)

HDTV, HDCP Compliant.

9) Table top microphones

Eight number of sturdy on table top boundary microphones, microphone shall be a cardioid pre-polarized condenser, Frequency response:40 Hz – 20 kHz, Nominal impedance at 1 kHz: 200 Ohm, Sensitivity: 10 mV/Pa,

Maximum sound pressure level: 140 dB, Equivalent noise level: 29 dB, Equivalent noise level weighted as per CCIR

468-3: 39 dB (CCIR), Dynamic range: 111 dB, Phantom power: 48V, optimized for speech intelligibility, bi-color LED indicators (red/ green), Microphone Modes: Toggle on/off,

Push to mute, Push to talk, with a programmable microphone button (Toggle on/off, PTM, PTT and permanent on), Switchable low cut: at 120 Hz, Connection: clip contact, Logic out: high level output voltage > 2.4 V, low level output voltage < 0.4 V, Logic In: high level input voltage > 2.0 V, low level input voltage < 0.8 V, approx. weight 300g, approx. size (WxDxH):90x100x20mm, including microphone cable.

10) Audio system

One number of rack mountable 10 port DSP professional audio system with 8 mic line inputs & 2 PC inputs,

Frequency response:20Hz to 22kHz, Noise (EIN): −124 dBu

22 kHz, Dynamic range 100 dB (non A-weighted),

Crosstalk: < −91 dB, rel 17 dBu, Sampling rate: 48 kHz,

A/D – D/A converters: 24-bit, MIC/ Line inputs Impedance:

10 kOhm balanced, Echo cancellation: 128ms tail time,

Phantom power: 24V DC at 10 mA, One Telephone line interface Frequency response 250 Hz to 3.3 kHz ±1 dB,

SNR > 62 dB re-max level, Telco line echo cancellation Tail time: 32ms Null: 55 dB, Telephone noise cancellation 6–

15dB attenuation, Audio performance Frequency response

40 - 3300Hz THD, approx. size (WxHxD):430x190x500mm, approx. weight 2kg, inclusive of all rack mount accessories

& connecting cables.

11) Ceiling Speakers

Four numbers of white colour 2-way 100V/70V/16 ohm built-in ceiling speakers with 8” woofer, 1” coaxial tweeter and high quality 100/70 volt speaker line transformer, mounting frame made of high quality ABS, woofer cone material polypropylene, approx. outside diameter 240mm, depth 80mm, 16 ohms impedance, 50 - 20kHz frequency response, aluminium grille, IP54 rated, inclusive of mounting arrangements.

12) Stereo Power Amplifier

One number of 2-channel stereo power amplifier with

Quantity

(3)



Unit

(4)

Rate

(5)

Amount

(6)

Page | 36



Sr. No.

(1)

Item Name & Description

(2)

dynamic output power (4 ohms) 2 x 350W, dynamic output power (8 ohms) 2 x 200W, dynamic output power bridged

(8 ohms) 750W, 10 - 50kHz frequency response, RMS output power (4 ohms) 2 x 180W, RMS output power (8 ohms) 2 x 120W, output power RMS bridged (8 ohms)

350W, convection cooled, approx. weight 7kg, 19" rack mountable with rack height of 1U.

Quantity

(3)



13) Audio Conference Station

One number of SIP-Based IP Conference Phone equipped with built-in IEEE 802.3a Power over Ethernet (PoE), White

LED backlight with custom intensity control Display,

Standard 12-key keypad, 4 Context-dependent soft keys,

On-hook/Off-hook, redial, mute, volume up/down,

Directional navigation wheel, Loudspeaker Frequency: 160–

22000Hz, Adjustable Volume to 88dB at 1/2 meter peak volume, Full-duplex Type 1 compliant with IEEE 1329 full duplex standards, Individual volume settings with visual feedback for each audio path, Voice activity detection,

DTMF tone generation/DTMF event RTP payload, Lowdelay audio packet transmission, Adaptive jitter buffers,

Packet loss concealment, Acoustic echo cancellation,

Background noise suppression, Supported codecs: G.711

(A-law and Mu-law), G.729a (Annex B), G.722, G.722.1,

G.722.1C, Call handling features: Shared call/bridged line appearance, Busy Lamp Field (BLF), Distinctive incoming call treatment/ call waiting, Call timer, Call transfer, hold, divert (forward), pickup, Called, calling, connected party information, Local three-way conferencing, One-touch speed dial, redial, Call waiting, Remote missed call notification, Automatic off-hook call placement, Do not disturb function; Network: Ethernet 10/100 Base-T, DHCP,

SNTP server, FTP/TFTP/HTTP/HTTPS, QoS Support—IEEE

802.1p/Q tagging (VLAN), Layer 3 TOS and DSCP, Network

Address Translation (NAT), RTCP support (RFC 1889),

Event logging, Security: Transport Layer Security (TLS),

Encrypted configuration files, Digest authentication, HTTPS secure provisioning, Safety: UL60950-1, IEC60950-1,

EN60950-1, CE Mark, CSA C22.2, No. 60950-1-03,

AS/NZS60950-1, EMC: FCC (47 CFR Part 15) Class A, ICES-

003 Class A, RoHS compliant, IETF SIP (RFC 3261 and companion RFCs) protocol support.

14) 18U Floor/ Table Rack

One number of 18U Table Rack with accessories, Rack

Width: 19", Color: Light grey, Type: On castor wheels,

Weight Capacity: Static load-40 Kg 500 Kg. on castor

Wheels and 750Kg on base frame, Approximate Depth

(mm): 600, Top & bottom CRCA steel, Four side CRCA

Unit

(4)

Rate

(5)

Amount

(6)

Page | 37



Sr. No.

(1)

3.

Item Name & Description

(2)

Steel folded panels, 19" Mounting Angles, wall mounting hardware, Cable entry provision, front glass/vented door

(lockable), should have 19" 1U Horizontal PVC cable manager (2 Nos.), accessories including 19 AC power distribution channel with 5 Amp power universal standard socket & surge and spike protection, equipment mounting screws/hardware packets, with two fans, Certifications:

Standard Finish Power Quoted (RAL 7035), DIN- 41494,

EIA-310, IEC-60297.

Quantity

(3)



15) Cables & Connectors

AV, LAN Cables & connectors, face plates of repute make as recommended by equipment OEM, in required quantity.

AV facilities for E-Classroom

The scope includes

1) Projection system

One number of Ultra-short Throw Interactive Projector,

LCD Size 0.59", Native Resolution WXGA (1280 x 800)

16:10 aspect ratio, Manual Focus, F-Number 1.80, Focal

Length 3.71mm, Throw Ratio 0.27 -0.37 (Wide - Tele),

245W UHE Lamp, Lamp Life expectancy 4000-6000 hours,

Screen Size 60"-100" @Projected Distance 0.348-0.597m,

3300lm brightness, contrast ratio of 10000:1, 16W internal speaker, Keystone Correction (Vertical/ Horizontal) ±3°,

Connectivity: Analog RGB Input D-Sub 15Pin, Composite

RCA input, Video Output D-Sub 15Pin, 2 HDMI HDCP

Supported, Audio Input Stereo Mini Jack, Audio Output

Stereo Mini Jack, USB Input USB Type A, USB Type B,

Control I/O RS-232C D-Sub 9pin, Remote Control Input

Stereo mini, Wired LAN RJ45, Wireless, supports USB

Display, Mouse, K/B, Control, Interactive projector,

Interactive Unit Technology: Infrared, Input Devices:

Interactive Pen Digital Pen, interaction using fingers supported, 25 point Auto / Manual Calibration, Functions:

Hover, Right Click, Auto Adjust Pen Area etc, White Board sharing, Operating Temperature: 5-35°C, 20%-80% humidity, approx. power consumption 365W, approx. size

(DxWxH)370x370x150mm, approx. weight 5kg, inclusive of

Power Cable, Remote Control, USB Cable, External Control

Pad, 2 Easy Interactive Pens, Pen Tray, Wall mount Setting

Plate, Wireless LAN, Light Curtain Unit.

1 System as described

2) Trolley based VC system

One number of Trolley based 720p video conferencing system licenced for Multipoint license for up to 6 sites at

720p30, 1/2.33” CMOS camera with 4k sensor, f=3.76–

37.6mm, one 55-inch professional 1080p HD display

Unit

(4)

Rate

(5)

Amount

(6)

Set

Page | 38



Sr. No.

(1)

Item Name & Description

(2)

mounted on top of the included OEM stand with casters offering 19-inch storage space for scaling the system, 12x optical zoom with 180-degree panning radius, 65 degree

Horizontal field of view, 39° Vertical field of view, auto focus, Pan range 100°/-100, Tilt range +20, -30°, IR detectors, Supported Video standards and protocols:

H.261, H.263, H.264, H.264 video error concealment, Video input: 1 HDCI, 1 HDMI 1.3, 1 VGA, Video out: 2 HDMI 1.3,

Supported video resolution: 720p 60 fps from 832 Kbps,

720p 30 fps from 512 Kbps, 4SIF/4CIF 60 fps from 512

Kbps, 4SIF/4CIF 30 fps from 128 Kbps, SIF (352 x 240) CIF

(352 x 288) from 64 kbps, QSIF (176 x 120) QCIF (176 x

144) from 64 kbps, w288p from 128 Kbps, w448 from 384

Kbps, w576p from 512 Kbps, Input: WXGA (1280 x 768),

HD (1280 x720p), XGA (1024 x 768), SVGA (800 x 600),

Output: HD (1280 x 720), XGA (1024 x 768), VGA (640 x

480), Content frame rate: 5–60fps, support for content sharing during a VC call, Audio input: microphone array input port (supporting minimum 2 microphone arrays), 1

HDCI (camera), 1 HDMI, 1 3.5mm stereo line-in, Audio output: 1 HDMI, 1 3.5mm stereo line-out, 2 USB 2.0, 1 RS-

232, automatic noise suppression, audio error concealment, 7 kHz bandwidth with G.722, G.722.1; 3.4 kHz bandwidth with G.711, G.728, G.729A, Supported standards: H224/H.281, H.323 Annex Q, H.225, H.245,

H.241, H.239, H.243, H.460, BFCP (RFC 4582), Network:

IPv4/ IPv6 support, 1 10/100/1G Ethernet, H.323 and/or

SIP up to 6 Mbps, Automatic gain control, Reconfigurable

MTU size, Security: Media Encryption (H.323, SIP) AES-

128, AES-256, authenticated access to admin menus, web interface and telnet API, FIPS 140-2 Validated

Cryptography, PKI/Certificate Management: SSL 3.0, TLS

1.0, 1.1, 1.2, Self-signed and CA-signed certificate support,

CRL and OCSP-based certificate, revocation checking,

Network intrusion detection system, Local account password, policy configuration, Security profiles, Web UI /

SNMP Whitelists, Local account and login port lockout, integration with audio mixer through a digital interface or equivalent, Operating temperature: 0 to 40 °C, Operating humidity: 15 to 80%, should include all accessories like cables etc. The equipment should ensure interoperability between competitive videoconferencing products prevailing in the market, inclusive of the OEM supplied microphone array and audio kit with 240w audio system or higher

Quantity

(3)



3) Fixed Screen

One number of matte white dry-erase board cum projector screen of approx. size 8feet x 4feet for compatible 16:10

Unit

(4)

Rate

(5)

Amount

(6)

Page | 39



Sr. No.

(1)

Item Name & Description

(2)

widescreen (WXGA) projector viewing, low-gloss surface for quality projection with minimal glare or reflection, scratch resistant no-ghosting surface, framed in aluminium section frames, rounded corners, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc., an ISO 9001 certified manufacturer product

Quantity

(3)



4) White opaque glass writing board

One number of 2m wide x 1.5m height white opaque glass dry-erase board of a repute make with ghost/ stain proof smooth writing surface, frameless design hangs vertically or horizontally and conceals hanging hardware for a sleek, contemporary look, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc.

5) Document Presenter

One number of document camera with 1/2.7" CMOS sensor, 1920 x 1080 Effective Pixels, 30 fps Frame Rate,

VGA Output: SXGA (1280 x 1024), XGA (1024 x

768),WXGA, (1280 x 800), HD (1360 x 768), 1080p (1920 x 1080), USB Output: VGA, SVGA, XGA, SXGA, WXGA,

720p, 1080p, HDMI Output: 480p/720p/1080p, Auto White

Balance, Adjustable Exposure, Adjustable Brightness, Lens

F-number: 3.4-5, Maximum Capture Area: 11.7" x 20.7" (at

1080p), 11.7" x 16.5" (at XGA), 10x digital zoom, 12x optical zoom, Automatic Focus with one-touch button, 180 degrees (Horizontal/ Vertical) Camera Head Rotation, LED

Illumination, Brightness 250lx or above @ A3 shooting area, Built-in functionality: Zoom, Freeze, Auto Focus,

Focus Lock, LED, Brightness, Contrast, Negative, Black and

White, Split Screen, Playback, Video Capture, Digital Scroll

(pan/tilt), Flicker Reduction, Image Rotation, Source (PC/

DC), Auto-detect Aspect, Video Recording, Video Playing,

Saving Formats supported: JPG, BMP, PNG, AVI, MOV,

PDF, Storage: Memory SD card slot (SD/SDHC only) 32GB

Class 10 card included, Kensington lock support, Approx.

Closed/Folded size (WxDxH) 15"x5"x5", Approx. Power

Consumption 15W, Inclusive of AC power adapter with power cord, USB cable, application software CD, remote control with AA batteries, VGA cable, adapters, carrying case, RoHS compliant

6) Presentation devices

Unit

(4)

Rate

(5)

Amount

(6)

Page | 40



Sr. No.

(1)

Item Name & Description

(2)

One presentation device based on Intel Core i7-5500U, 4M

L3 Cache, 3.00 GHz, dual-core, 8GB Single Channel DDR3L

1600MHz, 1TB SATA 5400RPM hard drive, NVIDIA GeForce

820M with 2GB DDR3, Windows 8.1, 8x optical drive

DVD+/-RW, LED Backlit Screen Size 39.62cm (15.6"), 1366 x 768 Resolution, integrated HD (720p) webcam,

Touchpad, Standard Keyboard, Stereo Speakers, Wireless

LAN, Bluetooth v4.0, Up to 4 hours Battery Backup, 1 x

USB 3.0, 2 x USB 2.0 ports, RJ45 port, HDMI Port, Media

Card (SD, SDHC, SDXC), Kensington Lock Slot, Approx. weight 2Kg, Approx. Dimension(W*D*H) 380x250x25mm,

Color Silver/ Black, as approved

Quantity

(3)



7) Wireless Lapel Microphone

One number of Wireless Lapel Microphone, clip on microphone, Wideband FM Modulation, Frequency Range

A: 548-572 MHz B: 614-638 MHz, Signal to noise ratio ≥

103 dBa, Total harmonic distortion ≤ 1%, AF Frequency response 60 Hz – 16 kHz, synchronization via RF remote channel, Frequencies tunable in steps of 25kHz, 13/ 24MHz bandwidth, 8 frequency banks with each max 12 presets,

960 tunable frequencies, mute button, inclusive of stationary receiver, bodypack transmitter, power supply unit

Handheld

Two numbers of Wireless Handheld Microphones,

Wideband FM Modulation, Frequency Range A: 548-572

MHz B: 614-638 MHz, Signal to noise ratio ≥ 103 dBa,

Total harmonic distortion ≤ 1%, AF Frequency response

60 Hz – 16 kHz, synchronization via RF remote channel,

Frequencies tunable in steps of 25kHz, 13/ 24MHz bandwidth, 8 frequency banks with each max 12 presets,

960 tunable frequencies, mute button, inclusive of stationary receiver, bodypack transmitter, power supply unit

9) Ceiling Speakers

Four numbers of white colour 2-way 100V/70V/16 ohm built-in ceiling speakers with 8” woofer, 1” coaxial tweeter and high quality 100/70 volt speaker line transformer, mounting frame made of high quality ABS, woofer cone material polypropylene, approx. outside diameter 240mm, depth 80mm, 16 ohms impedance, 50 - 20kHz frequency response, aluminium grille, IP54 rated, inclusive of mounting arrangements

10) Stereo Power Amplifier

One number of Stereo Power Amplifier with 4 mic and 4 line inputs, multi-level input prioritization, Rated output

Unit

(4)

Rate

(5)

Amount

(6)

Page | 41



Sr. No.

(1)

Item Name & Description

(2)

125W RMS, Frequency response 40Hz 22kHz (+1/-3 dB),

Distortion <0,5% @ -6dB 1kHz, Bass control +/- 10dB 100

Hz, Treble control +/- 10dB 10 kHz, S/N: amplifier better than 95dB, line better than 81dB, mic better than 70dB;

LED indicators, Mic input Sensitivity 1.5 mV, Impedance

600 ohm, S/N (at max. volume) > 70 dB, Phantom power

14 V, Frequency response > 90Hz-> 15Khz (+1/-3 dB), speech filter, approx. weight 10kg

Quantity

(3)



11) Data processing equipment

Four number of OEM supplied data processing machines for e-Classroom each based on Intel Xeon E5-2609v3, with

16GB DDR4 RAM, 3 x 1TB SATA 7.2K RPM HDD, 2x8GB

DDR4 RAM, RAID 0,1,5 (H330), dual NIC, DVD Writer, Red

Hat Enterprise Linux, Red Hat Enterprise Virtualization,

495W, Wireless keyboard & mouse, 21” LED display

12) Software based VC

Five licenses of PC based secure video conference application compatible with the video conferencing solution provided for the trolley based VC solution for e-Classroom, support for HD quality audio, video and content sharing on

PC over existing video enabled network, alongwith a remote controlled USB powered conference camera 1080p

30fps 78-degree FOV ZEISS lens certified, H.264 UVC 1.1 /

AVC, PTZ, Omnidirectional 8ft mic pickup radius, 200Hz -

8kHz Microphone bandwidth, Max output level: 80dB SPL

@ 1ft (0.30 meters), inclusive of a Hands-free high-fidelity

USB speaker with two high-quality stereo microphones

(200 Hz to 20 kHz) confirming to Regulatory compliance:

FCC Part 15, ICES-003, CE, CB/NRTL Safety, EN55024,

EN61000-3-3

13) Recording & Streaming Server

One number of 2U Recording & Streaming Server with a capability to records 6 SIP/H323 calls, up to 3 can be streamed live, self-service recording, Recording specifications, including minimum 2TB storage: Call protocols: H.323, SIP, Support video codecs: H.264 , H.264

HP, H.263, H.263+, H.261, Supported content protocols:

H.239 in H.323 call, BFCP (over TCP or UDP) in SIP call, up to 1080p30, Supported audio codecs: G.711, G.722,

G.722.1 and G.722.1C., G.729A, Siren 14 (mono & stereo),

Siren 22 (mono & stereo), Siren LPR (mono & stereo), User

Generated Content (UGC), supported file formats: MP4,

MOV, RAW, WMV, M4A, Supported bitrate range: Up to 4M,

Supported recording resolutions: People Video - 1080p30,

720p, 4CIF, CIF, Content Video - H.263: XGA (30); H.264:

1080p30, 720p3, SUPPORTED FEATURES: Point-to-Point

Unit

(4)

Rate

(5)

Amount

(6)

Page | 42



Sr. No.

(1)

Item Name & Description

(2)

and 2 endpoint recording without a bridge, Multi-Point recording with a bridge/MCU, Record from standards based

3rd party SIP and H.323 video endpoints, Browser-based user access for PC, Mac, iOS and Android, Share recordings and media to public or private channels, Video playback to any standards based H.323 or SIP endpoint or MCU,

Transcodes all video calls to H.264 (.mp4), WMV video format, or m4a audio, Streaming, Standard Recording,

Streaming & Playback 1080p30, Live stream URL failover,

Recording, Streaming & Playback resolution and frame rates up to 1080p60, Unicast and Multicast support, 3rd

Party CDN Support, Policy controlled manual or automatic backup, Off system storage to FTP server, and ability to auto-archive, Automatically publish recordings to specific private or public channels; Networking and Security: TLS v1.2/SSL and HTTPS support, SNMP monitoring, AES media encryption including SRTP, Encryption (SRTP—AES

128/256) and secured signaling (TLS—1024), Encrypted

Media Streams – supports 256 bit encryption ciphers on media streams, CRL Support - certification revocation, CSR

Compliant support, Customizable user authentication

14) Cables & Connectors

AV, LAN Cables & connectors, face plates of repute make as recommended by equipment OEM, in required quantity

Quantity

(3)



4.

AV facilities for Lecture & Tutorial Rooms

The scope of each system includes

1) Projection system

One number of Ultra-short Throw Interactive Projector,

LCD Size 0.59", Native Resolution WXGA (1280 x 800)

16:10 aspect ratio, Manual Focus, F-Number 1.80, Focal

Length 3.71mm, Throw Ratio 0.27 -0.37 (Wide - Tele),

245W UHE Lamp, Lamp Life expectancy 4000-6000 hours,

Screen Size 60"-100" @Projected Distance 0.348-0.597m,

3300lm brightness, contrast ratio of 10000:1, 16W internal speaker, Keystone Correction (Vertical/ Horizontal) ±3°,

Connectivity: Analog RGB Input D-Sub 15Pin, Composite

RCA input, Video Output D-Sub 15Pin, 2 HDMI HDCP

Supported, Audio Input Stereo Mini Jack, Audio Output

Stereo Mini Jack, USB Input USB Type A, USB Type B,

Control I/O RS-232C D-Sub 9pin, Remote Control Input

Stereo mini, Wired LAN RJ45, Wireless, supports USB

Display, Mouse, K/B, Control, Interactive projector,

Interactive Unit Technology: Infrared, Input Devices:

Interactive Pen Digital Pen, interaction using fingers supported, 25 point Auto / Manual Calibration, Functions:

10

Systems as described

Unit

(4)

Rate

(5)

Amount

(6)

Set

Page | 43



Sr. No.

(1)

Item Name & Description

(2)

Hover, Right Click, Auto Adjust Pen Area etc, White Board sharing, Operating Temperature: 5-35°C, 20%-80% humidity, approx. power consumption 365W, approx. size

(DxWxH)370x370x150mm, approx. weight 5kg, inclusive of

Power Cable, Remote Control, USB Cable, External Control

Pad, 2 Easy Interactive Pens, Pen Tray, Wall mount Setting

Plate.

Quantity

(3)



2) Fixed Screen

One number of matte white dry-erase board cum projector screen of approx. size 8feet x 4feet for compatible 16:10 widescreen (WXGA) projector viewing, low-gloss surface for quality projection with minimal glare or reflection, scratch resistant no-ghosting surface, framed in aluminium section frames, rounded corners, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc., an ISO 9001 certified manufacturer product

3) White opaque glass writing board

One number of 2m wide x 1.5m height white opaque glass dry-erase board of a repute make with ghost/ stain proof smooth writing surface, frameless design hangs vertically or horizontally and conceals hanging hardware for a sleek, contemporary look, compatible for use with any dry erase marker, hidden mounting hardware underneath the mounting bolts, inclusive of standard accessories, manufacturer approved/ supplied mounting brackets/screws etc.

4) Presentation device

One presentation device based on Intel Xeon E5-2400 v2 family, 8GB DDR3 ECC memory, HDD, Microsoft Windows

8, 350W Power supply, 64GB SSD installed, 1TB 7.2K RPM

HDD, 2 PCIe slots, Dual Port 1Gb Ethernet NIC, CD/DVD burner (DVD+/-RW), RAID: PERC S110, PERC H310, PERC

H710 etc, 2.5"& 3.5" Bay support, SATA, SAS or SSD support, Energy Star Compliant, mounted on rack using tool-less mounting, 21” LED display, wireless keyboard and mouse

5) Wireless Lapel Microphone

One number of Wireless Lapel Microphone, clip on microphone, Wideband FM Modulation, Frequency Range

A: 548-572 MHz B: 614-638 MHz, Signal to noise ratio ≥

103 dBa, Total harmonic distortion ≤ 1%, AF Frequency response 60 Hz – 16 kHz, synchronization via RF remote channel, Frequencies tunable in steps of 25kHz, 13/ 24MHz

Unit

(4)

Rate

(5)

Amount

(6)

Page | 44



Sr. No.

(1)

5.

Item Name & Description

(2)

bandwidth, 8 frequency banks with each max 12 presets,

960 tunable frequencies, mute button, inclusive of stationary receiver, bodypack transmitter, power supply unit

6) Wireless Handheld Microphone

One number of Wireless Handheld Microphones, Wideband

FM Modulation, Frequency Range A: 548-572 MHz B: 614-

638 MHz, Signal to noise ratio ≥ 103 dBa, Total harmonic distortion ≤ 1%, AF Frequency response 60 Hz – 16 kHz, synchronization via RF remote channel, Frequencies tunable in steps of 25kHz, 13/ 24MHz bandwidth, 8 frequency banks with each max 12 presets, 960 tunable frequencies, mute button, inclusive of stationary receiver, bodypack transmitter, power supply unit

Quantity

(3)



7) Ceiling Speakers

Four numbers of white color 2-way 100V/70V/16 ohm builtin ceiling speakers with 8” woofer, 1” coaxial tweeter and high quality 100/70 volt speaker line transformer, mounting frame made of high quality ABS, woofer cone material polypropylene, approx. outside diameter 240mm, depth

80mm, 16 ohms impedance, 50 - 20kHz frequency response, aluminium grille, IP54 rated, inclusive of mounting arrangements

8) Stereo Power Amplifier

One number of Stereo Power Amplifier with 4 mic and 4 line inputs, multi-level input prioritization, Rated output

125W RMS, Frequency response 40Hz 22kHz (+1/-3 dB),

Distortion <0,5% @ -6dB 1kHz, Bass control +/- 10dB 100

Hz, Treble control +/- 10dB 10 kHz, S/N: amplifier better than 95dB, line better than 81dB, mic better than 70dB;

LED indicators, Mic input Sensitivity 1.5 mV, Impedance

600 ohm, S/N (at max. volume) > 70 dB, Phantom power

14 V, Frequency response > 90Hz-> 15Khz (+1/-3 dB), speech filter, approx. weight 1kg

9) Cables & Connectors

AV, LAN Cables & connectors, face plates of repute make as recommended by equipment OEM, in required quantity

AV facilities in reception lobby 1 System

The scope includes

1) Two number of floor standing digital signage each with

(Customization: GCNEP Logo minimum of size 18"x18" engraved/ marked/ printed on front side), Material: Highstrength aluminium alloy, Stainless steel, PVC/ foam sheet

Poster, Screen Size: fitted with horizontal Professional Full as described

Unit

(4)

Rate

(5)

Amount

(6)

Set

Page | 45



Sr. No.

(1)

Item Name & Description

(2)

HD (1920 × 1080 pixels) LED displays, screen size 55"

(139.7cm), 16:9 Aspect Ratio, 100Hz Backlight Scanning,

178°/ 178° Viewing Angle, Video In RCA, Audio In (L/R)

RCA Pin Type, 3 HDMI In Type A Connectors, Component

In, 2 USB Input, RCA Audio out, SPDIF, VGA In, PC Audio

In, Built-in Media Player supporting Mpeg1/2, H.264, VC1,

HEVC, JPEG, BMP, PNG, MP3, WMA formats, AC 110~240V

50/60 Hz Power, Approx. Rated Power Consumption of

100W, Built -in Full range 20W (10W +10W) 10% PHD

Speakers, Operating Temperature: 0 °C to 40 °C,

Operating Humidity: 20% to 80%, IS 13252:2010 Safety confirmations.

Quantity

(3)



6.

2) Two numbers of Professional Display for AVSI & Digital notice board each with 46" D-LED DID, Resolution 1920 X

1080(FHD), Pixel Pitch(mm) 0.53025mm (H) * 0.53025mm

(V), Brightness(Typ.) 500 nit, Contrast Ratio 3500:01:00,

Viewing Angle(H/V) 178/178, Response Time(G-to-G) 8ms,

Display Colors 8 bit - 16.7M, Dynamic C/R 10000:1, H-

Scanning Frequency 30kHz ~ 81kHz, V-Scanning

Frequency 48Hz ~ 75Hz, Maximum Pixel Frequency,

148.5MHz, Connectivity RGB, Video, Audio, USB,

Detachable type(IR, Ambient), Input: Analog D-SUB, DVI-

D, Display Port, 2 HDMI, HDMI, RJ45, Built-in-Speakers,

Inbuilt Media Player, Super Narrow Bezel, ACM

Support(Advanced Color Management), Auto Source

Switching & Recovery, Haze 44%, Temperature Sensor,

RS232C/RJ45 MDC,Plug and Play (DDC2B), Video

Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot

Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy

Chain(Supporting UHD Resolution, HDCP support), Smart

F/W update, Clock Battery(80hrs Clock Keeping), Safety:

UL 60950-1, 60950-1 TUV, EN60950-1 KC, K60950-1 CCC, inclusive of wall VESA wall mounts

3) Cables & Connectors

AV, LAN Cables & connectors, face plates of repute make as recommended by equipment OEM, in required quantity

Two 20KVA online UPS in parallel operation for

redundancy, with individual battery banks:

1 System

UPS system having two 20KVA online UPS in parallel operation for redundancy, with individual battery banks, and with following specifications:

Nominal Input Voltage: 230V, Input Frequency: 40 - 70 Hz (auto sensing), Input Connections: Hard Wire 3 wire (1PH+N+G), 5wire (3PH + N + G), Input voltage range: 160 - 280V, Other

Input Voltages: 220, 240, 400, 415; Maximum Input Current:

115A; Input Breaker Capacity: 125A ; Output Power Capacity: 16 kW / 20 kVA; Nominal Output Voltage: 230V; Output Voltage

Note

Efficiency at Full Load: 92.0%; Output Voltage Distortion: Less as described

Unit

(4)

Rate

(5)

Amount

(6)

Set

Page | 46



Sr. No.

(1)

7.

Item Name & Description

(2)

than 4%; Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz user adjustable +/- 0.1; Other Output Voltages: 220, 240, 400,

415; Topology: Double Conversion Online; Waveform Type: Sine wave; Output Connections: 8; Communications Ports: RS-232,

RJ-45 10/100 Base-T; Control panel type: Multi-function LCD status and control console; Audible Alarm: Yes; Emergency

Power Off (EPO): Yes; Surge Protection and Filtering: Yes; Rack mountable: Optional; Approximate Net Weight: 75.00 Kg; Color:

Black, Dark Grey; Operating Environment: 0 - 40 °C; Operating

Relative Humidity: 0 - 95%; Protection Class: IP 20;

Conformance: EN/IEC 62040-2, EN/IEC 62040-1-1; It should accompany the required 3.5m extension cable(s) for connecting external battery packs. Open rack and interconnect link; External

Battery Bank for each UPS 384VDC (16nos 12V 150Ah or 32nos of 12V 65Ah, 150Ah, sealed maintenance free) Rack mount kit for ups to be included.

Ethernet based temperature and humidity logger

Quantity

(3)



Unit

(4)

Rate

(5)

Amount

2 Nos.

(6)

8.

Semiconductor based temperature sensor, Temperature Range: -

55°C to +125°C, Accuracy: ±0.5°C (from -10°C to +85°C);

Semiconductor based humidity sensors: Humidity Range: 0-

100%, Accuracy: ±1.8%; Temperature/ Humidity Logging, Real

Time Clock: Manual or NTP (Network Time Protocol) Sync support; I/O: supports minimum 2 Temperature/Humidity

Sensors, one sensor of each type included; Relay Contacts: Max

Voltage: 28VAC, 24VDC, Max Current: 3A, Operating Voltage: 9-

28VDC; Network support: 10/100 Base-T Ethernet, 8-pin RJ-45 connector, Static IP address assignment or DHCP, HTTP port selectable, password protected web based monitor/ control,

SNMP, Remote Monitoring and Data Logging, local Nonvolatile

Flash, Minimum of 10,000 local logs, unlimited data storage on

Web Monitoring Service, LED Indicators, approx. size

(WxHxD)mm:35x100x80, approx. weight 150g, Flame resistant enclosure.

PA lectern with a built-in amplifier system

A lectern with a built-in amplifier system. It should be supplied with a detachable gooseneck podium microphone and a reading light on the podium top. It should have a built-in digital recorder cum player. It should contain a built in VHF wireless microphone receiver and a high quality VHF handheld wireless microphone. It should have a rugged & stable floor standing base, with a provision of fixing to the floor with brackets (provided), if required.

Color: Black, Dark-grey; Operating voltage: 220-240V, 50/ 60Hz mains supply; Built-in amplifier & speaker system: Yes; Power

Output: 40W; Frequency Response: 100-16,000Hz; Provision given for connecting external speaker: Yes; Provision for connecting a wired microphone: Yes; Provision for connecting a

2 Nos.

Page | 47



Sr. No.

(1)

9.

Item Name & Description

(2)

stereo auxiliary source through L&R RCA plug: Yes; USB pen drives or SD cards support: Yes; Provision for sensitivity adjustment of auxiliary signal: Yes; Provision for connecting lectern system to external amplifiers (through LINE OUT & REC

OUT): Yes; Voice priority feature (selectable): Yes; Approximate dimensions (mm): 400(W) X 1130(H) X 570(D); Approximate Net weight: 20 Kg; Handheld wireless microphone included: Yes

(One); Microphone RF Output Power: 15mW (max); Microphone

Frequency Response: 50-15,000Hz; Microphone Dynamic Range:

100dB; Microphone Battery: 9V

Portable speaker cum amplifier system

Quantity

(3)



Unit

(4)

Rate

(5)

Amount

2 Nos.

(6)

Color: Black; Power output: 25W; Built-in VHF high band wireless receiver; Wireless microphone supplied alongwith: Yes (One);

Wired microphone inputs: Two; Aux input: One; Cut/boost type

Bass & Treble controls: Yes; Switchable Priority: Yes; Provision for connecting a recorder or another amplifier: Yes; Power requirements: Operates on AC mains or 12V external battery or built-in rechargeable battery; Stand mounting provision: Yes;

Approximate Dimensions (mm): 210(W) × 280(H) × 150(D);

Approximate Weight: 4.0kg; Handheld wireless microphone included: Yes (One); Microphone RF Output Power: 10mW;

Microphone Frequency Response: 50Hz - 15,000Hz; Microphone

Battery: 1×9V Battery



12 Nos.

10. Office Paper/ CD/ DVD Shredder

11.

Application : Paper , CD/ DVD; Type: Movable, Caster wheels;

Shred Type : Cross Cut; Desired cutting size: 4 x 44mm

Approx.); Bin Volume : 30 Ltr; Color: Black/ White/ Silver; Feed width : 230 mm; Approximate Weight : 20 Kg



Indoor Pan/ Tilt HD network camera

12.

Type of camera: Indoor, Dome/ Wall; 720p HD @ 30fps; 1.3M

MOS sensor; Wide range monitoring using Pan, Tilt support

(Horizontal: 180deg, Vertical: 120deg); H.264 support, PoE IEEE

802.3af support; Digital Noise Reduction support; Selectable light control modes; Zoom support: Yes; Face detection feature: Yes;

Video motion detection: Yes; JPEG Image support; SDHC/SD card support; Network: HTTP, IPv4/ IPv6 support, SSL, DDNS support; Built-in microphone: Yes

Wooden Podium/ Lecture stand

Color: cherry/ oak/ natural wood color or as approved; Material:

Premium quality solid wood, HDF/ MDF, Veneer; Size Range:

Approx. standing height of lectern/ podium 46"H, reading surface 23"W x 15 3/4"D sloping at 15 degree, with pencil groove, covered from three sides (Refer to the attached sketch drawing), the framing must be all solid wood, no sharp edges/

12 Nos.

10 Nos.

Page | 48



Sr. No.

(1)

Item Name & Description

(2)

corners, all exposed corners should be moulded with solid wood

Miscellaneous: Round moulding serves as paper stop, two open storage shelves; Material: Bore & termite proof, life expectancy of >10 Years; Certification: ISO9001/ ISO14001; Customization:

GCNEP Logo minimum of size 18"x18" engraved/ marked on front side

Quantity

(3)



13.

Security Cable for Notebook/Laptop

Unit

(4)

Rate

(5)

Amount

(6)

100 Nos.

14.

Security Cable for Notebook/Laptop Lock with Numbers to fit in

Kensington slot, of approved make, 1 Metre Length, Keyless 4‐ wheel combination

24-Port Gigabit Ethernet Switch

8 Nos.

Switching Capacity: 48Gbps; Type: Desktop and Rack Mountable

Design; MAC Address Table Size: 8K; Transmission Method:

Store-and-Forward; Diagnostic LEDs: Power, Per Port:

Activity/Link, Speed; Packet Buffer Memory: 500KB Buffer

Memory per Device; Max Power Consumption: 28 Watts;

Interface Options: RJ-45, 10BASE-T, 100BASE-TX & 1000BASE-

T; Network Protocol and Standards: IEEE 802.3 Ethernet, 802.3u

Fast Ethernet, 802.3x Flow Control, 802.3ab Gigabit Ethernet,

802.1p Priority Queuing; Operating Temperature: 0° to 40°C;

Operating Humidity: 5% to 95% RH (Non-Condensing);

Approximate Dimensions (mm): 300(W) x 200(D) x 50(H);

Approximate Weight: 2Kg; Conformance: RoHS, FCC Class A, CE

Class A

15. Videography System

1 System

1) One number of Digital single-lens reflex, AF/AE camera with built-in flash; approx. 18MP; 8GB SD memory card and support for SDHC memory card and SDXC memory card; CMOS sensor of approx. 22.3mm x 14.9mm, aspect ratio 3:2; DCF 2.0 compliant; JPEG, RAW, RAW+JPEG

5184x3456 simultaneous recording possible, video recording of 17.9 MP, 8MP, 4.5MP, 3.5MP; picture style: auto, standard, portrait, landscape, monochrome, and three user defined modes; white balance: auto, daylight, shade, cloudy, tungsten light, white fluorescent light, flash, custom white balance correction and white balance bracketing features provided; Quick-return type Viewfinder; as described

TTL secondary image-registration, phase detection

Autofocus, nine cross-type AF points; One-Shot AF, AI

Servo AF, AI Focus AF; ISO 100 - ISO 12800 set manually,

ISO 100 - ISO 6400 set automatically, ISO 100 - ISO 12800 set automatically (Handheld Night Scene); 1/4000sec. to

30secs shutter speed; retractable, auto pop-up built-in flash; single shooting, continuous shooting, self-timer with

10-secs./2-secs. delay and 10-secs. delay with continuous shooting; 22 shot max. burst at max. resolution for JPEG;

Set

Page | 49



Sr. No.

(1)

Item Name & Description

(2)

MPEG-4 AVC / H.264 support;

1920  x  1080  30/25/24fps  video  recording;

TFT color LCD display, approx. 77mm wide (3:2) 1MP, 7 level brightness adjustment, capacitive sensing touch screen; playback: single-image display with approx. 1.5x - 10x zoom, 4-image index, 9-image index, slideshow, movie playback enabled with built-in speaker; fish-eye correction and image resize possible; Direct

Printing with PictBridge-compatible printers; HDMI mini

OUT terminal Type C, CEC-compatible; External microphone IN terminal 3.5mm diameter stereo mini-jack;

Analog video / stereo audio output; 7.2V, 1120mAh

Lithium-ion battery pack, approx. 440 viewfinder shots or approx. 80 mins. video shooting on full battery; approx. size 133.1mm x 99.8mm x 78.8mm approx. weight 600g;

0°C - 40°C / 32°F - 104°F, 85% or less; with battery charger, connector cable shoulder strap and travel bag

2) One number of Video camera with tripod

1/5.8 type (0.12 in) back-illuminated CMOS Sensor, approx.

2.29 MP (16:9) video; approx. 1.71 MP (4:3), approx.

2.29 MP (16:9) still images; Auto/Manual focus F1.8 - F4.0,

26.8 - 804.0 mm (16:9) focal length video and 26.8-

804.0 mm (16:9), f=32.8-984.0 mm (4:3) focal length still images; 30 X optical zoom, 60 digital zoom; face detection, smile shutter, image stabilization, intelligent auto, motion shot video; auto, manual exposure  modes;  backlight

compensation;  Auto, Indoor, One Push, Outdoor white balance modes; min. 2.5” LCD display 0.2Mdot wide(16:9) with brightness control and angle adjustable max. 90⁰ opening angle max. 270⁰ turning angle; 1/8–1/10000 sec.

(auto control range), 1/30-1/10000 sec. (manual iris control), 1/8–1/10000 sec. (manual shutter), 1/30–1/10000 sec. (standard shutter speed); 10 sec. self-timer; 8GB

Micro SD/SDHC/SDXC; supports MPEG4-AVC/H.264, MP4:

MPEG-4 AVC/H.264, MPEG4-AVC/H264, XAVC S format; built-in zoom microphone; supports Dolby Digital 2 ch

Stereo, Dolby Digital Stereo Creator, MPEG-4 AAC-LC 2ch,

MPEG-4 Linear PCM 2ch; composite video out, HDMI terminal; approx. weight 540 g, approx. size 160mm x

120mm x 90mm; OEM rechargeable 3.6 V 1240mAH

Lithium ion battery pack; micro USB cable, HDMI (micro) cable; AC adapter OEM tripod Aluminum, ABS, POM, PC, and PS material, approx. size 570mm x 132mm x 122mm, approx. weight 998g

Quantity

(3)



16. 8-Port Gigabit Ethernet Switch

eight 10/100/1000 Mbps Gigabit ports; auto MDI/MDIX crossover for all ports; secure store-and-forward switching scheme, full/half-duplex for Ethernet/Fast Ethernet speeds; IEEE 802.3x

Flow Control; supports 9,216 Byte Jumbo Frames; supports IEEE

Unit

(4)

Rate

(5)

Amount

(6)

25 Nos.

Page | 50

Sr. No.

(1)

Item Name & Description

(2)

802.1p QoS (4 Queues, Strict Mode); supports Cable Diagnostics

Function; RoHS compliant; plug-and-play installation; IEEE 802.3

10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet,

IEEE 802.3ab 1000BASE-T Gigabit Ethernet, ANSI/IEEE 802.3 N way auto negotiation, IEEE 802.3x Flow control, IEEE 802.1p

QoS, IEEE 802.3az Energy-Efficient Ethernet (EEE); CSMA/CD;

LED indicators per port: Link/Activity/Speed, per device: power;

Mac address table: 8K entries per device; Mac address learning: automatic update; packet filtering/forwarding rates Ethernet:

14,880 pps per port, Fast Ethernet: 148,800 pps per port,

Gigabit Ethernet: 1,488,000 pps per port; RAM Buffer: 128KB per device; DC input : external 5V/1A power adapter; power consumption power on (Standby): 0.5 watts (DC input), 0.8 watts(AC input), maximum: 3.48 watts (DC input), 5.4 watts (AC input); MTBF 1,150,498 hours or more; 0 to 40 °C (operating);

10% to 90% RH non-condensing (operating); approx. 39mm x

144mm x 84mm; FCC class B, ICES-003 class B, CE class B, C-

Tick class B, VCCI class B, cUL Certifications

Quantity

(3)



Unit

(4)

17. Cost towards first year comprehensive AMC, including onsite support

One (1) Year

18. Cost of Second year comprehensive AMC, including onsite support

One (1) Year

19. Cost of Third year comprehensive AMC, including onsite support

One (1) Year

Rate

(5)

Amount

(6)







Total Cost: ____________________ (in figures)



Total Cost: ______________________________________________________________ (in words)







NOTE:

I. The required Onsite Support for works, under Sr. No. 17, 18 and 19 above shall include three years onsite maintenance (preventive/ corrective), operational support for the above in the form of at least one qualified operator, during office hours, all office days a year. This shall include day to day operational support required for the equipment infrastructure, attending of all kinds of break down calls, taking complaints, attending configuration issues etc. The scope of these works shall include the following: i) Daily inspection and upkeep of all items on all working days. The items shall be maintained clean, and should be tested to ensure availability on demand. ii) Daily stock keeping and report generation on the equipment status at various locations, in a format as provided by GCNEP. iii) Preventive maintenance of all items to be carried out at least once a week.

Page | 51

















  iv) Corrective maintenance to be provided on all working days as well as after office hours/ during holidays depending upon the urgency of work, and as per the instructions of the GCNEP authorities. v) Switching on/off the AV equipment as when required and assisting in operating the equipment on demand. This should be inline with the requirements at GCNEP office and following the policies and procedures laid down by GCNEP. vi) Supplying two toolsets of items required for onsite maintenance. These should include items like crimpers, cable testers, punching tools, required keys, screw drivers, spare patch cables, etc.





II. The cost comparison will be done on Total Cost basis. The cost of items under Sr. No. 17, 18 & 19 above,  shall be taken into  consideration

 for the purpose of cost comparisons.



This is to certify that I before signing this offer have read and fully understood all the terms and conditions  contained herein and undertake myself/ourselves to abide by them.

Our offer is valid for One Twenty (120) days from the date of submission.



Place:

Date:   /___/_____



Signature

Name of the Signatory

Name of the firm/agency

Seal of the firm/agency

Page | 52

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
