CanoScan Toolbox 1.6

U s e r ’ s G u i d e f o r M a c i n t o s h

Trademarks

CanoScan is a trademark of Canon, Inc.

Macintosh, Power Macintosh, Mac OS are trademarks of Apple Computer Inc. registered in the United

States and other countries. iMac is a trademark of Apple Computer, Inc.

Adobe, Photoshop are trademarks of Adobe Systems Incorporated.

All other names are trademarks or registered trademarks of their respective companies.

Copyright

© CANON INC., 2001

This manual is copyrighted with all rights reserved. Under the copyright laws, no part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language, in any form or by any means, without express written permission.

The contents of this manual are subject to change without notice.

CanoScan Toolbox 2

Table of Contents

1. Introduction ...........................................................................................................................4

About the CanoScan Toolbox .......................................................................................................... 4

Obtaining Customer Support .......................................................................................................... 4

2. Installing the CanoScan Toolbox .........................................................................................5

System Requirements .................................................................................................................... 5

Installing the CanoScan Toolbox ..................................................................................................... 5

3. Starting CanoScan Toolbox - with Start Buttons ................................................................6

4. Starting CanoScan Toolbox - with Double-clicking the icon .............................................7

5. Selecting the Scanner ...........................................................................................................8

6. Scanning ................................................................................................................................8

7. Saving Scanned Images (Toolbox) ......................................................................................9

8. Opening Files .......................................................................................................................10

Opening a Stored File ................................................................................................................... 10

Opening a New Image Window ..................................................................................................... 10

9. Saving a Scanned Image (Assistant) .................................................................................11

Saving Document .......................................................................................................................... 11

Saving Film ................................................................................................................................... 12

10. Faxing a Scanned Image ..................................................................................................13

Scanning and Faxing a Photo/Document ..................................................................................... 13

Selecting the Fax Driver ................................................................................................................ 13

11. Printing Copies of a Scanned Image ...............................................................................14

Printer ........................................................................................................................................... 14

Copying a Document .................................................................................................................... 14

Copying Film ................................................................................................................................. 15

12. Enhancing a Scanned Image ............................................................................................16

Cropping a Scanned Image .......................................................................................................... 16

Changing the Image Viewing Size ................................................................................................ 16

Inverting Image Tones ................................................................................................................... 17

Adjusting the Contrast and Brightness Settings ........................................................................... 17

Adjusting the Color Balance ......................................................................................................... 17

Sharpening an Image ................................................................................................................... 18

13. Editing a Scanned Image ..................................................................................................20

Resizing a Scanned Image ........................................................................................................... 20

Rotating an Image ........................................................................................................................ 20

Flipping a Scanned Image ............................................................................................................ 21

Changing the Image Depth ........................................................................................................... 21

Using Plug-in ................................................................................................................................ 22

Using the Editing Commands ....................................................................................................... 22

Using the Editing Tools ................................................................................................................. 23

Using the Color Pallet ................................................................................................................... 24

Selecting a Brush Size .................................................................................................................. 24

14. Working with Catalogs ......................................................................................................25

Creating a Catalog ........................................................................................................................ 25

Saving an Image to a Catalog ....................................................................................................... 25

Viewing an Image Catalog ............................................................................................................ 26

Opening a Scanned Image from the Catalog ............................................................................... 26

15. Linking and Using the Applications ................................................................................27

CanoScan Toolbox 3

1. Introduction

This User’s Guide describes the features and functions of the CanoScan Toolbox for Macintosh.

About the CanoScan Toolbox

The CanoScan Toolbox provides easy-to-use scanning and image editing functions you can use to scan, edit and integrate digital images into a variety of applications (i.e., email, fax, desktop publishing, word processing, etc.). You can also use the CanoScan Toolbox to instantly fax or copy scanned documents with a click of the mouse. The advanced image enhancement features provided by the CanoScan Toolbox let you adjust the color balance, contrast and brightness, image sharpness and more, so you can create high-quality images.

In addition to the CanoScan Toolbox, the Canon Plug-in Module CS plug-in is also included in the

CanoScan Setup Utility CD-ROM. It provides an interface to the scanner. The Canon Plug-in Module CS plug-in launches when you click the Scan button from the CanoScan Toolbox. After the scan process is complete, the plug-in closes and you are returned to the CanoScan Toolbox so you can edit, fax, copy or integrate the image into other applications.

Obtaining Customer Support

If you are having problems setting up or running the CanoScan Toolbox CS, contact the Canon help desk at one of the following locations:

CANON U.S.A., INC.

Degital Home and Personal Systems Division

2995 Redhill Avenue

Costa Mesa, CA 92626, U.S.A.

1-800 OK CANON http://www.ccsi.canon.com

CANON (UK) LTD.

Woodhatch, Reigate

Surrey RH2 8BF, United Kingdom

For technical support, please contact Canon

Helpdesk.

Helpdesk:

P.O. Box 431, Wallington, Surrey SM6 0XU

TEL: (08705) 143 723

FAX: (08705) 143 340

For sales enquiries: (0121) 666-6262

CANON FRANCE S.A.

17, quai du Président Paul-Doumer

92414 Courbevoie Cedex, France

Tél.01 4199 7777

Fax.01 4199 7951

Hotline:

Tél.01 4199 7070

CANON DEUTSCHLAND GmbH

Postfach 528, 47705 Krefeld, Germany

CANON- Hotline-Service

Customer Support: (0 21 51)349-555

Info-Desk: (0 21 51)349-566

Mailbox: (0 21 51)349-577

Telefax: (0 21 51)349-588

CANON ITALIA S.p.A

Palazzo L, Strada 6,

20089 Milanofiori-Rozzano (MI), Italy

TEL: 02/8248. 1

FAX: 02/8248. 4604

Pronto Canon 02/8249. 2000 http://www.canon.it

CANON OY AB

Kornetintie, 3, 00380 Helsinki, Finland

Puhelin: 010 544 20

Help Desk: 0600-0-22606 (maksu 14,80 mk/min)

Fax: 010 544 4571

CANON SVENSKA AB

Stensätravägen 13, S-127 88, Skärholmen

Sweden

CANON DANMARK

Vasekær 12, DK-2730 Herlev, Denmark

Hotline: 44 88 26 66 http://www.canon.dk

CANON NORGE AS

Hallagerbakken 110, Boks 33, Holmlia 1210 Oslo

12, Norway

Tlf: 2262 9321

FAX. 2262 0615

CANON BENELUX NEDERLAND N.V.

Neptunusstraat 1, 2132 JA Hoofddorp

The Netherlands

Tel: 023-5 670 123

Fax: 023-5 670 124

Helpdesk: 023-5 681 681

CANON BENELUX BELGIUM N.V./S.A.

Bessenveldstraat 7, 1831 Diegem, Belgium

Tel: 02 7220411

Fax: 02 7213274

Helpdesk: 02 7220404

CANON GmbH

Zetschegasse 11, 1232 Wien, Austria

CANON (SCHWEIZ) A.G.

Industriestrasse 12, CH-8305 Dietlikon

Switzerland

Tel: (01)835 61 61

Fax: (01)835 68 60

Hotline: 157 30 20

CANON ESPAÑA S.A.

C/Joaquin Costa No 41, 28002

Madrid, Spain

HelpDesk: 906-301255

Tel.: 91-5384500

Fax.: 91-4117780

CANON AUSTRALIA PTY. LTD.

1 Thomas Holt Drive, North Ryde, Sydney N.S.W.

2113, Australia

Info-Line: (02)9805 2864

CANON NEW ZEALAND LTD.

Fred Thomas Drive, Takapuna

P.O. Box 33-336 Auckland, New Zealand

Info-Line: 0900-522666

CANON HONGKONG CO., LTD.

9/F, The Hong Kong Club Building

3A Chater Road, Central, Hong Kong

Tel: (852)2739 0802

Fax: (852)2739 6428

CANON SINGAPORE PTE. LTD.

79 Anson Road #09-01/06

Singapore 079906

CANON MARKETING SERVICES PTE. LTD.

2, Alexandra Road, #04-01A

Delta House

Singapore 159919

Tel: 65 2735311

Fax: 65 2733317

CANON MARKETING (MALAYSIA) SDN. BHD.

Wisma General Lumber Block D. Peremba Square

Saujana Resort, Section U2, 40150 Shah Alam

Selangor Darui Ehsan, Malaysia

Tel: 603-744-6000

Fax: 603-745-0505

CANON MARKETING (THAILAND) CO.LTD.

2nd Floor, Indosuez House

152 Wireless Road, Bangkok 10330

Thailand

Tel: 66-2-6514000

Fax: 66-2-6514096

CANON MARKETING (PHILIPPINES) INC.

Marvin Plaza Building,

2153 Don Chino Roces Ave,

Makati City, Metro Manila, Philippines

Tel: 632-812-6047

Fax: 632-812-0067/810-9797

CANON CANADA, INC.

6390 Dixie Road Mississauga

Ontario L5T 1P7, Canada

1-800 OK CANON (652-2666) http://www.canon.ca

CANON LATIN AMERICA, INC.

6505 Blue Lagoon Drive Suite 325

Miami, Florida 33126, U.S.A.

CANON EUROPA N.V.

P.O. Box 2262

1180 EG Amstelveen, The Netherlands

CANON INC.

30-2 Shimomaruko 3-chome, Ohta-ku

Tokyo 146-8501, Japan

CanoScan Toolbox 4

2. Installing the CanoScan Toolbox

System Requirements

The following indicates the minimum CanoScan Toolbox system requirements:

Computers:

Power Macintosh which standardly equips the proper interface for connection with the scanner

System:

(Macintosh compatibles are not supported)

Mac OS 8.5 ~ 9

Memory Requirements:

32 MB or more (64 MB or more recommended)

Hard Disk Space:

50 MB (5 MB for the application and 40-50 MB to store scanned images)

Installing the CanoScan Toolbox

Installing the CanoScan Toolbox is very simple.

To install the CanoScan Toolbox:

1.

Insert the CanoScan Setup Utility CD-ROM accompanied with the scanner into your CD-ROM drive. Inserting the CanoScan Setup Utility CD-ROM automatically displays the main menu.

2.

Choose the Install the Software command from the main menu and select the CanoScan Toolbox option.

3.

Follow the on-screen instructions to start the installation. Click [Install].

4.

When you finish the installation, click [Quit].

Installing the Plug-in

You should locate the Plug-in Module CS in the same folder where the CanoScan Toolbox locates.

When you install the Plug-in Module CS with the CanoScan Setup Utility CD-ROM, you should specify also the folder name where the CanoScan Toolbox locates (usually CanoScan Toolbox).

CanoScan Toolbox 5

3. Starting CanoScan Toolbox - with Start Buttons

Pressing the Start Button on front of the scanner or the Film Scan Button on the document cover,

CanoScan Toolbox starts and the Canon Scanner Assistant will be displayed.

Pressing the Start Button on front of the scanner shows the assistant for scanning the photos or documents from the platen while pressing the Film Scan Button on the Film Adapter Unit shows the assistant for scanning the films from the Film Adapter Unit.

by the Start Button by the Film Scan Button

[Scan and Open the Image in Toolbox editor], [Scan and Save the Image], [FAX](not available when you press the Film Scan Button on the Film Adapter Unit), [Copy], [Show CanoScan Toolbox Toolbar

before scanning], [Scan with same settings as the previous scan] are the options. Select one from the dialog and click [Next].

Several setting dialogs (the numbers of the dialogs and the content differs from the functions) are displayed. After setting these dialogs, the function starts.

CanoScan Toolbox 6

4. Starting CanoScan Toolbox - with Double-clicking the icon

You can also start CanoScan Toolbox with double-clicking the CanoScan Toolbox icon in the [CanoScan

Toolbox] folder.

With this method of starting;

1.

The CanoScan Toolbox toolbar is displayed (if the toolbar was displayed when closing last time);

2.

Or CanoScan Toolbox is loaded into the memory (if the toolbar was not displayed when closing last time). In this case, click [CanoScan Toolbox] from the [Window] menu to display the toolbar.

You may also display the toolbar with selecting [Show CanoScan Toolbox Toolbar before scanning] option in the Canon Scanner Assistant.

CanoScan Toolbox Toolbar

Iaunching the Canon

Plug-in Module CS

Opening an image stored in a catalog

Opening to use the editing tools, brush and color palettes

Closing the CanoScan Toolbox Toolbar.To

open the toolbar again, follow the methed

2 above.

Specifying an application you want to access directly from the

CanoScan Toolbox. (P. 27)

CanoScan Toolbox 7

5. Selecting the Scanner

When one or more scanners are connected to your computer, you can select which scanner to use with the

CanoScan Toolbox.

Select the scanner in the submenu of the [Select Scanner] command from the [File] menu.

6. Scanning

Once the scanner is connected and the software is installed you are ready to scan. The scanning process is very simple.

To scan a document:

1.

Place the photo, document or film on the scanner as indicated in the scanner documentation.

2.

Perform one of the followings;

1

Select [Scan and Open the Image in Toolbox editor] option or [Scan and Save the Image] from the Canon Scanner Assistant,

2

3

Click on the [Scan] button from the toolbar,

Choose the [New Scan] command from the [File] menu.

3.

The Canon Plug-in Module CS opens so you can select your scan settings.

4.

Click the [Preview] button to preview the scanning area.

5.

Click the [Scan] button to scan the document. The plug-in closes and the scanned image appears in a new CanoScan Toolbox Image window.

6.

Choose the [Save] command from the [File] menu to save the scanned image.

CanoScan Toolbox 8

7. Saving Scanned Images (Toolbox)

You can save an image that you scan and/or edit in the CanoScan Toolbox.

To save an image for the first time:

1.

Choose [Save] from the [File] menu.

2.

Enter a file name and select the folder and drive in which you want to save the image.

3.

Specify the image format. When you choose JPEG or TIFF formats, an Options dialog box appears so you can specify the compression level.

4.

Click OK.

To save changes to an image that has already been saved on your computer, choose the [Save] command from the [File] menu.

To save a file with a different name, to a different location or in a different file format, use the [Save As] command.

To save the scanned image directly without displaying it (i.e. whin you scan the image continnously),

select [Scan and Save the Image] from the Canon Scanner Assistant. For details, refer to P. 11

CanoScan Toolbox 9

8. Opening Files

Opening a Stored File

You can store image files that you have scanned as well as other image files using the CanoScan Toolbox.

To open a stored file:

1.

Choose the [Open Image] command from the [File] menu, or click the [Edit] button in the

CanoScan Toolbox toolbar. The Open Image dialog box appears.

2.

Select the desired file and click the [Open] button. The selected file opens in an image window.

Opening a New Image Window

When you choose the [New Image] command from the [File] menu, an empty image window appears.

You can create a new image by pasting data into or drawing directly in the image window. The image window remains [Untitled] until you save the data to a file.

CanoScan Toolbox 10

9. Saving a Scanned Image (Assistant)

Saving Document

To save the scanned document;

1.

Set the document on the scanner.

2.

Push the Start Button to start the CanoScan Toolbox.

3.

Select [Scan and Save the Image] from the Canon Scanner Assistant and click [Next].

4.

Select either [Quick and Easy Scanning](displaying scanner driver window) or [Expert

Scanning](without displaying scanner driver window).

5.

If you select [Quick and Easy Scanning];

(1) Specify the setting items and click [Next].

If you select [Expert Scanning];

(1) The Plug-in Module CS window displays.

(2) Adjust the previewed image and click [Scan].

6.

The document is scanned. Enter the file name and specify the folder and the drive in which the image is saved (Initially, the file name is set to Image0001 and the folder is set to [Photo] in

[CanoScan Toolbox]).

CanoScan Toolbox 11

Saving Film

To save the scanned film;

1.

Set the film in the film guide and place it on the scanner.

2.

Push the Film Scan Button to start the CanoScan Toolbox.

3.

Select [Scan and Save the Image] from theCanon Scanner Assistant and click [Next].

4.

Select either [Quick and Easy Scanning](displaying scanner driver window) or [Expert

Scanning](without displaying scanner driver window).

5.

If you select [Quick and Easy Scanning];

(1) Specify the setting items and click [Next].

When you scan the 35mm film without displaying the driver software, the scanned area is slightly smaller than the actual frame.

With 35mm sleeve film, up to 3 frames can be scanned continuously. Select [Sleeve] in [Scan

Frames] and specify the scanned frames in

[Frame Selection].

When you scan 2 or 3 frames continuously, sometimes the gap between frames may be scanned and the vertical stripe may appear in the image. This occurs because the width between frames differing from the film type and setting position causes slight disalignment of the scanned area. In this case, place the objective frame in the first position and scan one frame at a time.

If you select [Expert Scanning];

(1) The Plug-in Module window displays.

(2) Select [Film] from [Preferences] menu and specify [Film Size] and [Film Type] in the

[Film] menu.

(3) Adjust the previewed image and click [Scan].

6.

The document is scanned. Enter the file name and specify the folder and the drive in which the image is saved (Initially, the file name is set to Image0001 and the folder is set to [Photo] in

[CanoScan Toolbox]).

CanoScan Toolbox 12

10. Faxing a Scanned Image

Using the CanoScan Toolbox, your scanner and a computer-based fax application, you can fax virtually anything from your computer.

This function is available only when you start CanoScan Toolbox with pressing the Start Button on front of the scanner.

Film cannot be faxed.

Scanning and Faxing a Photo/Document

To scan and fax a photo/document:

1.

Place the original you want to fax in the scanner.

2.

Press the Start Button to start CanoScan Toolbox.

3.

Select [FAX] in the Canon Scanner Assistant dialog and click [Next].

4.

Select either [Color Photo] or [Line Art] and click [Next].

5.

The original is scanned. The fax driver launches and the scanned image will be faxed.

Selecting the Fax Driver

To select the fax driver (only required the first time you fax from the CanoScan Toolbox):

1.

After the step 4 above, [Select a Fax Driver] dialog will be open. Click to highlight the driver and click [Open].

To change the fax driver, delete the CanoScan Toolbox Prefs file in the Preferences folder in the System

Folder. Then set the new driver with the method above. Here, all other settings will be initialized.

CanoScan Toolbox 13

11. Printing Copies of a Scanned Image

You can use your scanner and printer to make black and white or color copies of any scanned image.

This function is available only when you start CanoScan Toolbox with pressing the Start Button of the scanner.

Printer

The Printer used in [Copy] is the one selected by the Chooser in the Apple Menu. Before using the

CanoScan Toolbox, set the printer using the Chooser. To change the printer you wish to use, alos use the

Chooser.

Copying a Document

To copy documents using your scanner and printer:

1.

Place the document or the film you want to copy in the scanner.

2.

Press the Start Button on front of the scanner to start CanoScan Toolbox.

3.

Select [Copy] in the Canon Scanner Assistant dialog and click [Next].

4.

Select either [Color Photo] or [Line Art] and click [Next].

5.

Printer setting dialog is displayed. Specify the number of copies to print and so on, and click

[Print].

6.

The original is scanned. The scanned image will be printed.

CanoScan Toolbox 14

Copying Film

1.

Set the film in the film guide and place it on the scanner.

2.

Push the Film Scan Button to start the CanoScan Toolbox.

3.

Select [Copy] from the Canon Scanner Assistant and click [Next].

4.

Specify [Film Type], [Scan Frames] and [Frame Selection](only when you have selected [Sleeve] in [Scan Frames]), and click [Next].

5.

Printer dialog appears. Specify items such as the number of copies and click [Print].

6.

The film is scanned. The image is printed.

CanoScan Toolbox 15

12. Enhancing a Scanned Image

The CanoScan Toolbox provides a wide variety of imaging tools you can use to modify and enhance images you scan.

Cropping a Scanned Image

To crop an image:

1.

Open the image you want to crop by choosing [Open Image] from the File menu, or click the

[Scan] button from the CanoScan Toolbox toolbar to scan a new image.

2.

Select either the [Rectangle Select] tool (to select regular shapes) or the [Lasso] tool (to select irregular shapes) from the editing toolbox and move the cursor over the image window.

3.

Click and drag the cursor over the image, so the portion of the image you want to keep is contained inside the selection area.

4.

Choose [Crop] from the Image menu. The area outside of the selected portion of the image is discarded.

Changing the Image Viewing Size

To change the image viewing size:

1.

Open the image you want to view using the [Open Image] command from the File menu, or scan a new image by clicking on the [Scan] button.

2.

Choose the [Zoom In] or [Zoom Out] command from the Image menu, or click the [Magnifier] tool in the Editing toolbox.

3.

Position the cursor over the image window and click to enlarge the view (Zoom In) or press the

Option key and click the mouse to reduce the view (Zoom Out).

Zoom in on an image when you want to see more details in the image. Use the [Zoom Out] feature to see more of the image.

NOTE:

Changing the image viewing size does NOT alter the actual image size. The zoom capabilities only modify the image display.

CanoScan Toolbox 16

Inverting Image Tones

Inverting image tones makes a negative of the image.

To invert the tones in an image:

1.

Open the image you want to invert using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Choose the [Invert] command from the [Image] menu.

Adjusting the Contrast and Brightness Settings

To adjust the contrast and brightness:

1.

Open the image you want to adjust using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Choose [Brightness/Contrast] from the Image menu. The Brightness/Contrast dialog box displays.

3.

Adjust the settings by moving the slider to the left or right, or by entering a number. Brightness values range from -100 (dark) to 100 (light). Contrast values range from -100 (little contrast) to 100

(more contrast).

4.

Click [OK] when you are finished, or [Reset] to return to the default image brightness and contrast settings.

Adjusting the Color Balance

You can use the Color Balance feature to adjust the colors in an image.

To adjust the color balance of an image:

1.

Open the image you want to adjust using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button from CanoScan Toolbox toolbar.

2.

Choose the [Color Balance] command from the [Image] menu.

CanoScan Toolbox 17

3.

You can adjust the blue, red and yellow colors by moving the applicable slider to the left (to decrease) or the right (to increase).

4.

You adjust the color balance for specific color groups (i.e., modify the blue tones in the shadows of an image) by clicking on one of the radio buttons and then moving the Cyan slider.

5.

Click [OK] when you are finished, or [Reset] to return to the default color balance settings.

Sharpening an Image

The CanoScan Toolbox CS Sharpen command has three options: A Little, A Lot and Unsharp

Masking.

To sharpen an image or a selected portion of an image:

1.

Open the image you want to sharpen using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Click and hold the [Sharpen] command from the Image menu. Choose [A Little] from the

[Sharpen] submenu for a slight change, or choose [A Lot] for a significant change. The

Sharpen filter is automatically applied to the image.

Sharpened - A Little

Sharpened - A Lot

To use the Unsharp Masking command:

1.

Open the image you want to sharpen using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Click and hold the [Sharpen] command from the [Image] menu. Choose the [Unsharp

Masking] selection from the [Sharpen] submenu.

CanoScan Toolbox 18

3.

Specify the percentage of sharpening you want in the Amount field.

4.

Enter a number in the Radius field to specify the distance (in pixels) from an edge you want to sharpen. A low number indicates sharpening close to the image edges, and a higher number indicates sharpening farther away.

5.

Enter a number in the Threshold field to specify the level at which pixels are sharpened.

6.

Click [OK] to sharpen the image.

CanoScan Toolbox 19

13. Editing a Scanned Image

CanoScan Toolbox provides a wide variety of editing commands and tools you can use to modify images.

Resizing a Scanned Image

Resizing an image changes the actual image size.

To resize an image:

1.

Open the image you want to resize using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Choose [Resize] from the [Image] menu.

3.

Choose the unit type (pixels, inches or centimeters).

4.

Type the desired size in the [New Size] section of the dialog box. Check [Preserve Aspect Ratio] to maintain the original image height and width ratio.

5.

Click [OK] to resize the image.

Rotating an Image

You can use the Rotate commands to rotate all or part of an image 90º, 180º or specify the degree of rotation.

To rotate an image:

1.

Open the image you want to rotate using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Choose the [Rotate] command from the [Image] menu. Select one of the following rotation options:

90º Left

90º Right

180º

Arbitrary Rotate (rotates the image to a specified setting)

CanoScan Toolbox 20

Flipping a Scanned Image

To flip an image or a selected portion of an image:

1.

Open the image you want to flip using the [Open Image] command from the [File] menu, or scan a new image by clicking on the Scan button.

2.

Choose [Flip] from the [Image menu], then select [Vertical] or [Horizontal] from the [Flip] submenu.

3.

The image is automatically flipped.

Changing the Image Depth

You can change the actual image file size by changing the image depth.

NOTE:

Changing the image depth does NOT change the image dimensions. It changes the saved file size.

To change the image depth:

1.

Open the image you want to change using the [Open Image] command from the [File] menu, or scan a new image by clicking on the [Scan] button.

2.

Choose the [Image Depth] command from the [Image] menu. Select one of the following image depth options from the [Image Depth] submenu:

Millions of Colors

Thousand of Colors

256 System Colors

256 Custom Colors

256 Shades of Gray

16 Shades of Gray

Black and white

Image depth reduced to 256 System Colors

3.

The image depth is automatically changed to reflect your selection.

CanoScan Toolbox 21

Using Plug-in

You can utilize CanoScan Toolbox effectively by using various image adjusting and enhancing functions of Plug-in Module CS. Refer to the Plug-in Module CS User’s Guide bundled with your scanner for its installation and functions.

Using the Editing Commands

The commands on the [Edit] menu allow you to cut, copy, paste, clear, select all, deselect, and set scanning preferences for images.

Undo

To reverse the effects of a command you have selected, choose the [Undo] command.

Cut

To cut a portion of the image:

1.

Select an area to cut using the select tool.

2.

Choose the [Cut] command.

Copy

To copy a portion of the image:

1.

Select an area to copy using the select tool.

2.

Choose the [Copy] command.

Paste

To paste a selection onto the image:

1.

Place the cursor where you want to put the selection.

2.

Choose the [Paste] command.

Clear

To delete a portion of the image:

1.

Select an area to delete by using the select tool.

2.

Choose the [Clear] command.

Select All

To select everything in the image, choose the [Select All] command.

None

To deselect items you have selected using either the [Lasso] or [Select] tools, choose the [None] command.

CanoScan Toolbox 22

Using the Editing Tools

The CanoScan Toolbox editing tools appear when you open an image. You can also control the palette display by using the [Show/Hide Tools] command from the Window menu.

To use an editing tool, click on the desired tool and then move your cursor over the image window. Notice that the cursor changes shape to reflect the tool you have selected.

The image editing tools included with the CanoScan Toolbox are described below:

Rectangle Select Tool: defines a rectangular area.

Hand Tool: moves a picture in window.

Fill Tool: fills an area with color or a tile pattern.

Eraser Tool: erases to the background color.

Air Brush Tool: sprays smooth color.

Clone Tool: paints with pixels from another area.

Foreground/Background Color

Tool: replaces the foreground color with the background color.

Lasso Tool: defines an irregular area.

Magnify/Zoom Tool: changes magnification level. Choosing

Actual Size from the Image menu resets the image to the original image size.

Text Tool: adds text to annotate the picture.

Pencil Tool: draws freehand.

Paint Tool: paints freehand.

Smudge Tool: smears colors.

CanoScan Toolbox 23

Using the Color Pallet

The CanoScan Toolbox color pallet appears when you open an image. You can also control the palette display by using the [Show/Hide Tools] command from the Window menu.

To select a color from the color pallet to use with the [Fill], [Air Brush], [Freehand Paint] or [Pencil] tools:

1.

Move your cursor over the desired color block and click.

2.

Select the desired editing tool and start editing with the selected color.

Note that the selected color appears in the [Foreground/Background Color] tool.

Selecting a Brush Size

The CanoScan Toolbox [Brush Size] window appears when you open an image. You can also control the palette display by using the [Show/Hide Brushes] command from the Window menu. The brush size controls the width of the selected editing tool.

To select a different brush size, click on the desired size and then on the tool you want to use.

Brush palette

Small brush Larger brush

CanoScan Toolbox 24

14. Working with Catalogs

Creating a Catalog

CanoScan Toolbox Catalogs are designed to let you look through many image files as you use a photo album. When you open the catalog it displays all the images stored in the catalog in thumbnail form.

To create a catalog:

1.

Choose [New Catalog] from the [File] menu, or click the [Scan] button to scan a new image. The

New Archive window appears.

2.

Enter a catalog name.

3.

Click the [Create] button. An empty catalog window opens. Now you can save related images to the new catalog.

Saving an Image to a Catalog

To save an image to a catalog:

1.

Create a new catalog.

2.

Scan a new image or open a saved image.

3.

Choose [Save As] from the [File] menu. Locate the catalog you created (catalogs appear as folders).

4.

Double click the created catalog to save the image in the catalog.

CanoScan Toolbox 25

Viewing an Image Catalog

You can open a catalog so you can view and access the stored images.

To open a catalog window:

1.

Choose [Open Catalog] from the [File] menu. The New Archive dialog box appears.

2.

Select the desired catalog from the list box.

3.

The selected catalog window opens displaying the images you have stored in the catalog in thumbnail form.

4.

Choose the [View By] command from the [Image] menu to sort the thumbnails by name, type, date or size.

Printing the Catalog View

You can print the open [Catalog] window to see all of the stored images in thumbnail format similar to a traditional photographic contact sheet.

To print a catalog view:

1.

Open the desired catalog window.

2.

Choose the [Print Catalog View] command from the [File] menu.

3.

Specify the number of copies to print and click the [Print] button.

Opening a Scanned Image from the Catalog

To open an image file you have stored in a catalog:

1.

Open the catalog that contains the image you want to modify by choosing [Open Catalog] from the

[File] menu.

2.

Double-click on the desired image to open the [Image] window. The [Editing] toolbox, [Brush

Size Pallet] and [Color Pallet] windows open.

CanoScan Toolbox 26

15. Linking and Using the Applications

You can link frequently used applications such as Optical Character Recognition (OCR), photo retouching and Email applications to the CanoScan Toolbox toolbar so you can access them from the CanoScan

Toolbox.

To link an application:

1.

Click on one of the [Unassigned] buttons in the CanoScan Toolbox toolbar.

2.

Select the executable file for the application you want to include in the CanoScan Toolbox toolbar.

3.

Click [Select] to add the application to the CanoScan Toolbox toolbar.

The icon for the assigned application appears as a button in the CanoScan Toolbox toolbar.

To access the application you assigned to the main button bar, drag an image in the album onto the application icon.

The application launches so you can work with the image.

Drag and Drop

CanoScan Toolbox

I-OE-046A

27

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
